How To Start Learning Embedded Systems: A

Complete Roadmap

Amit Rana

kitflix.com
 1


Are you looking for how to learn embedded systems?

Are you looking for a clear roadmap to start learning embedded systems?

Are you a complete beginner and need no-fuss clear guidance on studying and
experimenting with embedded systems?

We’re going to cover all above questions in this tutorial. And we’re going to see a clear
roadmap to start learning embedded systems. We’re going to see what it takes for anyone
to get started with embedded systems and what is the flow that one can follow if he or she
wishes to excel in learning and developing embedded systems.

This tutorial is specially created for complete beginners to give the simplest guide to start
learning embedded systems quickly and understand all that is there to learn about it. This
tutorial will help you map your learning objectives based on where you are at this stage.
Even if you’re in the middle of something like you understand little bit of Arduino
programming, this tutorial will help you shape your knowledge and is intended to provide
guidelines to excel. So lets get started.

kitflix.com

 2


What is an embedded system?

An embedded system is a dedicated computerized system which can perform one
dedicated task or similar associated tasks. Let’s take an example of a temperature
controller. This type of temperature controller is very commonly used in wide variety of
manufacturing industries. The typical jobs of temperature controller are

● Read the temperature value

● Display the temperature value
● Configure a set point for temperature value
● If the temperature is below the set point, make the output device off
● If the temperature is above the set point, make the output device on
● Repeat the cycle

As you can see in above steps, its obvious that we do not expect an embedded system to
stop functioning. An embedded system is always running unless its power off or turned of
by the user. So to create such simple system what are the options we have?

● Analog + Digital Design

● Embedded Design

kitflix.com

 3


Analog Design
Now such a system like a temperature controller, can it be built using a simple analog
circuit? Yes off course it can be developed. By using temperature sensor, analog to digital
converter, the seven-segment display drives and lot of conditioning circuits and digital
timer circuits. We definitely can create such a system for temperature controller, but it
requires a lot of design efforts. Moreover, if we want to change anything or any element of
this system, it’ll be very difficult to make changes as we’ll need to reconfigure lot of
component values itself. Even if you want to add some time delay or some timed
operations, you’ll need to make lot of changes to the system. So what is the option here?

The option is instead of creating a simple circuit design, make it using embedded system
principles.

Embedded Design



kitflix.com

 4


An embedded design if very simple to build. All it will consist of is the microcontroller unit
which will do the job of sensor reading, display driving and output device (relay) switching.
How it does all of this, how it prints value and how it reads the temperature sensor and all
is controlled by a software written inside the controller. An embedded controller can not
function directly as compared to normal analog or digital circuits. Instead an embedded
microcontroller needs a program written in its memory which will do the job of controlling
the devices. The microcontroller is a reconfigurable IC. The pins of microcontroller can do
the job of input or output or analog input and so on. Depending on the software written,
the pins of the microcontroller can behave differently. In order to get excelled in
microcontrollers coding, we need to understand the microcontroller architecture. After
studying the microcontroller architecture well, we can start writing the programs for it. But
because of this big limitation, many people can not dive into embedded systems directly.
And here the Arduino board comes into the picture. In order to program an Arduino board
we do not need any knowledge of the underlying hardware which is called the
microcontroller Board. We’ll discuss about the Arduino board in details soon.

How an embedded system is built?

So, a system which is built using this type of microcontroller as the heart of the
system is called as an embedded system. An embedded system has all the related
input and output devices interfaced directly to the microcontroller or connected to it
via some driver circuit. Depending upon the application at hand, an embedded
system may have few or all of the components shown in the below diagram.



kitflix.com

 5


What are the different components of Embedded

Systems?




Just take a look at the above block diagram. It’s a very simple block diagram of an
embedded system. Mind well, when I say simple, it really is. The block diagram hides
almost everything that is complex and gives a bird eye view of an embedded system. The
embedded systems block diagram shows mainly 3 components of embedded system.

Inputs can be usually coming from switches, or sensors. In the example of temperature
controller, the inputs will be switches to accept the setpoint and the temperature sensor
itself. Just like, a plant watering system will have input as moisture level sensor.

Controller is the heart of an embedded system. A controller’s job is to process the given
inputs and generate outputs. For a temperature controller, the job of the controller inside
is to read the temperature value, read the switches. Now compare the temperature value
with set point, and control output devices. Controller cannot do any of these things out of
the Box and every controller needs a software sitting inside it to do these things. This
creates a demand for software programming in embedded systems.

The most popular controllers used in embedded systems are

kitflix.com

 6


● Microcontroller
● Microprocessor
● PLDs (FPGA / CPLD)
● System on Chip (SoC)
● Outputs

This is the sole purpose of designing any system. We need to generate outputs. Usually
outputs are generated using a variety of driver circuits that can create output action.
Microcontroller (if used) can only generate small signals as their output. +3.3v/0v or +5v/0v
as output voltages. These voltages are very small and cannot drive any output device
directly and hence we need something called as output driver for turning things on or off.
Outputs of embedded systems are in form of below examples with their respective drivers

● LED On / Off (No Driver)

● Devices turning on / off. (transistor + relay driver)
● Motors rotating with varying speed (motor driver)
● Buzzer On off and sound generation (no driver)
● Fan on / off (transistor / relay / thyristor driver)
● Sending SMS (GSM Module)
● Sending data over internet to for remote monitoring (wifi interface)
● Displaying data on a screen (LCD / LED screen interfacing)
● And many more such things

kitflix.com

 7


Where Arduino fits in embedded Systems?




You’re reading this tutorial means one thing is sure, you’ve heard about Arduino 😊.
In an embedded system, generally, the most emphasis on study is given for understanding
the controller. The developer of embedded systems has to be very good at understanding
the microcontrollers used in the system with all of their instructions and way of writing
programs for them. Every microcontroller is equipped with some or all of below-mentioned
features which are used for properly programming an embedded systems

● Input / output ports

● Timers / counter
● Serial Ports
● Memory (RAM / Flash / EEPROM)
● Analog to Digital Converter
● Digital to analog Converter
● Protocols interfacing (I2C / SPI)
● Interrupts ( To make processing faster and solve programming challenges easily)
● And many such user interfaces are on-chip

kitflix.com

 8


A single-chip microcontroller has all such features on the chip. In order to use any of these
features, the microcontroller developer creates some unique way of configuring the
microcontroller.

● First, there are unique instructions for every microcontroller, which can execute
some job like reading / writing data from memory / Input-output ports / all the
registers inside the controller.
● Secondly, there are many special function registers inside the microcontroller. And
each feature may have one or many Special Function registers inside the
microcontroller.
● The study of the Instruction set and all the internal register organization combinedly
is called a study of Architecture of microcontrollers

So every embedded systems developer has to be very good at an understanding of the

microcontroller architecture as well as the knowledge of inputs and outputs to be used.
Every electronics/computer engineering student usually learns this as part of their studies
and anyone else who is interested to excel in microcontroller studies has to study this on
their own. One thing is sure that the proper understanding of microcontroller architecture
is a must.

But

What about those hobbyists/artists who don’t know about microcontroller and still want to
make embedded systems?

For exact people like these, who don’t want to study architecture and get started
developing systems faster and smoother, in 2005 Arduino boards were launched in Italy.
There is a long history behind Arduino boards which can be read​ ​here​. The sole purpose of
Arduino is to enable non-techie people to get started with designing hobby projects using
embedded systems.

But over the years, due to the open-source nature of the entire Arduino system, millions of
people started using it including seasoned developers for very simple reasons

● Lots of clean libraries available for almost every single interface out there
● Free and open source
● Quick prototyping is possible
● It’s cheap

As of writing this tutorial, Arduino is undoubtedly the number 1 hardware prototyping

platform. And there is no need to take any survey on that. Everyone will agree with this.
This is how Arduino slowly got adjusted in the crowded market of microcontrollers.

kitflix.com

 9


But what is Arduino anyway?

Arduino is a microcontroller-based board that is ready for usage. You don’t need to study
the microcontroller architecture in order to use Arduino. You just should be able to read
the board; understand basic English and you can get started with programming Arduino.
I’ve written a separate tutorial about it which can be found h
​ ere








Steps to Learn About Embedded Systems

kitflix.com

 10


Now that we’ve gotten a fair idea of how to create an embedded system, lets jump to
understand how to learn embedded systems. This will help you get a clear picture of how
to get started with embedded systems and embedded programming.

Understanding of basic electronics


The first thing then is to understand basic electronics. Probably one of the most important
points. Everything we’re discussing here is electronics and hence having an understanding
of electronic components, their workings, and their usages will prove to be very beneficial
to learn embedded systems effectively. Electronic components are used in entire
embedded systems development and hence you should know about them as much as you
can. But to get started, understanding of below-mentioned things is the first step.

kitflix.com

 11


Resistors



Resistors are those tiny little electronics components that oppose the flow of electric
current. Whenever we try to build a small circuit, if a resistor is added into that circuit, the
job of a resistor is to resist (or oppose) the current flow.The value of resistance offered by a
resistor never changes. Resistors are passive components means it doesn’t matter in which
direction you connect it in a circuit, it will work the same way. By using resistors, we can
limit the current flowing through a circuit. As seen in previous tutorial, resistance offered by
a resistor is measured in Ohms (capital omega symbol Ω)



kitflix.com

 12


Capacitors

A capacitor (originally known as a condenser) is a passive electronic component having 2

leads. Capacitor is used to store energy in an electric circuit. There are different types of
capacitors which are used. But all them contain at least two electrical conductors plates
which are separated by a dielectric i.e., insulator material. The conductors can be thin films
of metal like aluminum foil. The ‘nonconducting’ dielectric material helps increase the
capacitor’s charge storage. More about capacitor can be read at a very nice tutorial by
adafruit h
​ ere

Diodes




kitflix.com

 13


Diode is a unidirectional switch used in electronics. Job of diode is to allow the flow of
electricity in only one direction and blocking its flow in the other direction. Most primarily,
diodes are used in a rectifier circuit. Rectifier circuit is used to convert AC voltage to DC
voltage. Rectifiers are used to create power supplies. Apart from rectifier, diode is used in
circuit protection and in variety of applications where this conduction in one direction
property is needed. More about it is​ here

Transistors




Transistors are used for mainly 3 types of circuits

● Switching
● Amplification
● Oscillation generation
In embedded systems, transistors are mostly used for switching purposes. In analog
circuits like amplifiers and oscillators, transistors server different purpose. It’s a simple 3
terminal device that comes as either PNP or NPN transistor. Their properties differ on how
they conduct electricity and how it can be controlled. Transistors theory can be​ read here


kitflix.com

 14


LEDs



LED’s are perhaps the most interesting electronic component that we use in circuit. LED’s
are (Light Emitting Diode) components which can emit a specific light. It can be RED, Green,
Blue or Yellow. LED’s require very less voltage to turn ON (typically 3v) and they have a very
long life. We see LED’s in power indicators in almost any electronic appliance. The power
light we see on TV, DVD, microwave, in TV remote control are all LED’s. We have LED TV’s
now a day’s which uses LED’s to give the backlighting to the LCD Panel in it. More about
LEDs is here

Switching devices: relays

kitflix.com

 15



Switching devices and circuits are needed to turn on / off devices using microcontroller
output. Usually, the output of microcontroller board like Arduino or any other
microcontroller is only a digital signal. This digital signal can have a value of either 1 or 0.
Electrically, 1 means the operating voltage of microcontroller and 0 means the ground
voltage. Usually, 1 stands for +5v or +3.3v and 0 stands for GND of DC supply or negative of
the power supply circuit. This small voltage cannot turn on / off a physical device like a light
bulb. So, this voltage is given to a transistor which turns on something called Relay. This
relay then can switch the major AC appliances.

Understanding of basic C Programming

kitflix.com

 16


Microcontroller is programmed using instructions. This is called assembly language

programming. In order to write effective programs faster, C programming is used. A
separate software called cross compiler is used which can convert the C program to
microcontroller understandable code. This microcontroller understandable code is then
created in a special file format called a hex file. This hex file is then burned or written in the
permanent memory of a microcontroller called flash memory. Microcontroller reads a
program from flash memory and executes the program accordingly. This whole process is
called embedded C programming. There are various Integrated Development
Environments for writing embedded C programming. These IDE combine the cross
compiler of microcontroller and text editor to give a smooth coding experience to the
programmer. The choice of IDE depends on the microcontroller being used. For example,
Arduino uses the Arduino IDE. Various other microcontroller uses different IDE tools. Some
of them are free, some are commercial versions. Here’s a shortlist of IDE’s used for various
microcontrollers

AVR series microcontrollers by atmel (Now Microchip)

● Atmel Studio
● AVRGCC Programmer notepad
● codevisionAVR
● mikroC Pro for AVR

kitflix.com

 17


Microchip PIC

● MPLAB
● mikroC Pro for PIC
● CCS C Compiler

8051 and ARM architecture

● Keil Microvision
● Tasking
● IAR Embedded Workbench

Your first microcontroller: Arduino

Now you got the idea of what all to study in embedded systems. It's best to choose with
Arduino if you’re a beginner. Arduino provides easy access to microcontroller features with
the help of ready-made libraries and software tools. Using Arduino will be the first step to
enter into the embedded systems world. In order to study about Arduino, simply grab an
Arduino board and start using it. You can download your first C program to Arduino very
fast, mostly within 5 minutes. In order to use Arduino, you first need to install the Arduino
IDE on your computer. Arduino IDE can be found at​ ​arduino.cc​ Depending upon your
operating system you can download the appropriate and latest version of Arduino IDE.
Once you have the board and IDE installed, you’re ready to get started with coding in

kitflix.com

 18


Arduino. You can follow the below video to see how you can get started with Arduino and
download your first program.

https://youtu.be/cKYMasBGj1g


Understanding controller IO



Once you download the first program on Arduino for blinking LEDs, the next step is to
understand the nature of digital Input and output. Digital input and output of Arduino
works with simple 2 functions. You can generate +5v or 0v output on any Arduino pin. You
can also read the input pin on any Arduino pin, but for reading voltage on any Arduino pin,
it must be either 0v or +5v. Arduino reads the input as LOW or HIGH. LOW means 0 volt
and HIGH means +5v. We can read input using a

● Push-button

● Sound sensor

● Moisture sensor

● Infrared proximity sensor

● Many different modules

kitflix.com

 19


Reading inputs is made really simple with the digitalRead() function of Arduino.

Understanding IO interfaces, like a buzzer, Relay,

digital sensors, LCD, etc



After understanding the basic digital input and output, next step is to understand what all
you can do with these functions. Now that you can read and write digital signal values,
there are lots of possibilities open for you to create a number of different embedded
systems. Even this much knowledge will get started with your hobby projects which can use
a number of different interfaces like

● LEDs

● Switches

● Sensors

● Relays

● Buzzer

● Speakers

kitflix.com

 20


● LCD

You don’t need to understand everything with respect to Arduino or embedded systems to
create a hobby project. For example, how to create a distance meter using the ultrasonic
sensor? You need just enough knowledge of Digital IO of Arduino and you can connect an
ultrasonic sensor to Arduino with LCD and measure distance and print it on the screen.

Interfaces using GPIO, stepper motor, DC Motor, etc


With simple input and output, you can control many different devices except simple relays.
Relays are good to turn on/off any appliance but there are many other actuators who need
controlling. These actuators include stepper motors, dc / ac motors, servo motors. The
primary job of a motor is to provide a rotational force. A motor converts electricity into a
rotational force for performing some action. It may include a robot movement, or a 3d
printer or a robotic arm. And each type of motor requires a controlled supply given to it. DC
motors need an H-bridge driver circuit. AC motors need thyristorised control circuit and
servo motor needs a PWM pulse.Most of the motor’s speed can be controlled by a
time-varying digital signal given to them. This signal is called PWM. PWM is pulse width
modulation. PWM signal means the digital output from an output pin which is not HIGH all
the time; instead it’s continuously made HIGH / LOW with varying duration of High pulse.
This high-frequency pulse is responsible for the control action of motors. Most of the

kitflix.com

 21


microcontrollers like atmega328 (heart of Arduino board) do have on-chip PWM capability.
A clear understanding of PWM helps us design better control circuits.

Serial Port or UART

Every microcontroller like atmega328 (heart of Arduino Uno Board) has at least one serial
port on it. Serial port, technically called as UART is a module on the controller chip which
allows the microcontroller to perform asynchronous serial communication. This
asynchronous communication is made possible with 2 wires which are TXD and RXD. Apart
from connecting these 2 wires, we also need to connect the GND wire from microcontroller
to the device with which we’re communicating

TXD of microcontroller goes to RXD of the device with which we’re communicating

RXD of microcontroller goes to TXD of the device with which we’re communicating.

The speed of communication needs to be set before initializing communication. Since its
asynchronous communication, there is no clock shared. Hence for synchronization, baud
rates or bits per second of communication have to be pre-decided and set into the
controller as well as the device with which we’re performing microcontrollers serial
communication. Learning about Serial port of microcontroller opens up options to
interface with many interesting peripherals like

● Bluetooth module (helps a mobile communicate with controller)

● RFID Reader
● GPS Receiver
● GSM Module (send/receive SMS and calls)
● Wifi interface



kitflix.com

 22


Understanding communication protocols, Serial, i2c,

SPI

While studying about the devices which can be interfaced with a microcontroller, it's very
clear that only a few devices can be connected to the IO pins of any microcontroller.
Because the number of input-output pins is limited, we cannot connect as many devices as
we want to a microcontroller at the same time. Of course this limitation can be removed by
using a higher microcontroller like atmega2560 which has more IO pin. But this can not be
always done due to cost and size constraints.

In order to tackle such issues, some simple communication protocols are developed by
industries to communicate a microcontroller with a number of different devices at the
same time using the same common wire connection. And the most popular such
communication protocol is called I2C which was developed by Philips (now NXP). Many
other manufacturers call I2C as TWI. Because Philips invented I2C, only they use the name
Inter IC Communication or I2C and others use a generic name like Two Wire Interface (TWI).
I2C allows a microcontroller to communicate with up to 127 different devices using just 2
Wires. These 2 wires are SCL and SDA. Not to mention, the microcontroller can only
communicate with one device on this bus at a time. Hence I2C is slower and usually used
while interfacing with peripherals where speed is not a major concern like sensors.

Most common peripherals that support I2C protocol

● Real-Time Clock

● Accelerometer sensor

● Digital Compass Sensor

● Gyroscope sensor

kitflix.com

 23


● Analog to Digital Converters

● EEPROM Chips

Similar to I2C, there is another protocol called SPI, which was developed by Motorola. Since
communication is happening on only 2 lines, I2C is slower. So when high-speed
communications are needed, SPI or serial peripheral interface is required. SPI utilizes a
full-duplex synchronous communication with Serial Data In, Serial Data Out, Clock, Reset
and Chip select signals. SPI allows for much faster communication and usually used when
high-speed data transfer is needed like memory card storage.

Popular SPI chips

● Memory Storage, SD Card

● EEPROM

● Function generators

● ADC and DAC’s

Interfaces based on communication protocols,

ethernet, wifi.

kitflix.com

 24


With the same I2C and (or) SPI Protocols some advanced network interfaces can also be
interfaced with the microcontroller which allows the device to get connected to a LAN. A
connection may be to a Lan or full internet connectivity is also possible. This internet
connectivity then leads to a much larger application area we call as Internet of Things. With
a microcontroller, we can interface below-mentioned network interfaces to get connected
to internet

● Ethernet Interface Controller (SPI Protocol)

● Wifi Interface (SPI / Serial)

Understanding microcontroller (Atmega328)



With Arduino, we can use many features of microcontroller but still not all of them. In order
to make the Arduino functional, some things are disabled by the Arduino firmware and
hence you don’t have access to the entire feature set of the controller. And although as
powerful it may be, most professionals and product development firms still consider
Arduino only for amateurs. So, if you want to get a job in Industry, then you need to know
the bits and pieces of embedded development from scratch; and it begins with an
understanding microcontroller. With Arduino, we got the bigger picture of what things can
be done using a microcontroller, the next obvious step is to understand how all that can be
done using Raw microcontroller coding. And in order to do that, you need to first choose a
controller. If you’ve used Arduino Uno before, then you have already used atmega328p

kitflix.com

 25


which is the microcontroller on Arduino. So next best thing is to open the datasheet of this
controller and start reading it.

How to read microcontroller datasheet



A device datasheet is the user manual of an IC provided by the manufacturer. Just like we
get a user manual when we buy a new microwave oven. Consider if the microwave oven
manufacturer doesn’t give a user manual with their product, what will happen? We won’t
be able to use it properly. Hence probably, we won’t buy it. While the microwave is still a
very simple device, an Integrated Circuit is a very, very complex one. Hence the
manufacturer provides something called a datasheet for every device they produce. The
purpose of datasheet is to enable the user to understand the IC and start using it easily. In
a similar context, a microcontroller is also an IC, albeit a much more complex one. So, the

kitflix.com

 26


microcontroller also gets a datasheet. We can download the device datasheet if we know
who manufactured it from their respective websites. Otherwise, you can just web search
with the name of the IC and you’ll find the datasheet.

Here’s a sneak peek of Atmega328 microcontroller datasheet’s first page

kitflix.com

 27


The datasheet provides with every single detail about the device we’re studying. But
reading datasheets directly is not very simple for a beginner. It’s very confusing because
every manufacturer organizes and shows data differently. But usually, there are some
common grounds whenever you view the device datasheet of any IC. Be it microcontroller
or a simple Op-Amp, there are some common things that are there in the datasheet and
understanding them will make things simpler. They are as follows

● Features

This section contains a birds-eye view of the entire controller. It lists all the features of that
microcontroller in a single list view. Just by reading this page, you can understand most of
the features of a microcontroller.

● Pinout Diagrams

This section usually contains the pinout diagrams of the various packages of a
microcontroller. The pinout in PDIP package as well as all the other SMT versions of
packages. This section gives the user the pin number and names. If you want to create a
package of this device in your favorite PCB design software, then you’ll need this section.
Also, it’ll help a programmer understand which pins are GPIO and which pins are for timers
and serial ports and I2C and so on

● Pin functions

In this section, the job of each pin is described in detail. We’ll understand which are power
pins, which are oscillator pins and which are gpio pins. Most microcontrollers have more
than one function associated with every single pin, and all of them will be described in
detail over here.

● Internal Block Diagram

This section gives an internal block diagram of the microcontroller. In theoretical studies, its
called the “Architecture of Microcontroller”. The name justifies because this block diagram
shows everything that is there inside the microcontroller IC. But now every circuit is laid out
in detail. Instead, it gives a complete overview of all that is inside the controller. It helps to
know things better about the controller.

kitflix.com

 28


● Electric Specifications

This section details the different electrical specifications of a microcontroller IC. All the
electrical specifications including

● Maximum and maximum operating voltages, IO voltages

○ Operating temperature ranges

○ Minimum and Maximum Current and power consumption ratings

○ DC Characteristics

● Features Explanation

This is perhaps the biggest section of them all. This section shows all the workings, the
internal registers descriptions, how to configure each one to be used. And how to use every
single feature of the microcontroller. This section has it all. Whatever that you're trying to
use, be it an interrupt or timer, or ADC / DAC, you can use it by following this section here.

Concluding Remarks

Now that you've got a fair idea of what are the embedded systems, it'll be good idea to get
started with your own experimentation. There are plenty many tutorials available on the
particular microcontroller which you want to start learning embedded systems. If you want
to learn embedded systems on arduino, we've a detailed course on it​ ​here​. Thanks for
reading.

kitflix.com
