7/11/2021 GNSS Processing Report

inacors.big.go.id/SBC/User/Xpos/CoordinateComputationReport/7164 1/9
7/11/2021 GNSS Processing Report

Table of Contents
GNSS Processing Report - Summary
1. Point Results
2. TDTV
2.1. TDTV - 2021-07-09 14:42:02
2.1.1. cmgl - TDTV
2.1.2. cpts - TDTV
2.1.3. csdg - TDTV
2.1.4. csem - TDTV
2.1.5. jogs - TDTV

inacors.big.go.id/SBC/User/Xpos/CoordinateComputationReport/7164 2/9
7/11/2021 GNSS Processing Report

GNSS Processing Report - Summary

Request Details

General User Details

Processed at: 2021-07-11 21:17:18 User name: jossdee017
SBC version: 7.5.0.434 Name: Joshua Paskah
Company: Kementerian Agraria dan Tata Ruang/Badan Pertanahan Nasional
E-Mail: joshuabennington017@gmail.com

inacors.big.go.id/SBC/User/Xpos/CoordinateComputationReport/7164 3/9
7/11/2021 GNSS Processing Report

1. Point Results
WGS84 Ellip.

Point-ID Solution Type Occupations / Baselines WGS84 Latitude WGS84 Longitude Height [m] SD Latitude SD Longitude SD Height
TDTV Phase Fixed 1/5 7° 47' 02.7345" S 110° 20' 38.2673" E 139.6112 m 0.0007 m 0.0007 m 0.0016 m

Point-ID Solution Type Occupations / Baselines WGS84 Cartesian X WGS84 Cartesian Y WGS84 Cartesian Z SD X SD Y SD Z
TDTV Phase Fixed 1/5 -2197143.2418 m 5925672.5676 m -858146.7027 m 0.0008 m 0.0015 m 0.0007 m

Target Coordinate System

Name: ID_TM3 49.1
Ellipsoid: WGS 1984
Projection Type: TransverseMercator
Geoid Model: -
CSCS Model: -

Ellip. Height

Point-ID Coordinate System Northing Easting Ortho. Height SD Easting SD Northing SD Height
TDTV ID_TM3 49.1 639219.7977 m 293083.5174 m 139.6112 m
0.0007 m 0.0007 m 0.0016 m
-

inacors.big.go.id/SBC/User/Xpos/CoordinateComputationReport/7164 4/9
7/11/2021 GNSS Processing Report

2.1.
TDTV - 2021-07-09 14:42:02

Point Occupation Results

Marker Name: TDTV

Receiver Type / SN:
ComNav / 03303595

Antenna Type / SN: -/-

Occupation Start: 2021-07-09 14:42:02
Occupation End: 2021-07-09 15:26:42

Averaged Point Summary: TDTV

Weighted Average: Yes

WGS84 Latitude: 7° 47' 02.7345" S SD Latitude: 0.0007 m

WGS84 Longitude: 110° 20' 38.2673" E SD Longitude: 0.0007 m
WGS84 Ellip.Height: 139.6112 m SD Height: 0.0016 m

WGS84 Cartesian X: -2197143.2418 m SD X: 0.0008 m

WGS84 Cartesian Y: 5925672.5676 m SD Y: 0.0015 m
WGS84 Cartesian Z: -858146.7027 m SD Z: 0.0007 m

Easting: 293083.5174 m SD Easting: 0.0007 m

Northing: 639219.7977 m SD Northing: 0.0007 m
Ellip. Height: 139.6112 m SD Height: 0.0016 m
Ortho. Height: -

Baseline Summary TDTV

Max Distance between Average and Measurement

Position: 0.1 m
Height: 0.1 m

∆Pos [m] &

Point-ID Reference Baseline Length [m] 3D CQ [m] ∆Pos [m] ∆Height [m] Height [m] Easting [m] Northing [m] Height [m]
TDTV 293083.5174 m 639219.7977 m 139.6112 m
cmgl 36866.5245 m 0.0153 m 0.0736m -0.1602 m 0.1763m 293083.4483 m 639219.7723 m 139.7714 m
cpts 25288.9431 m 0.0134 m 0.0596m -0.1628 m 0.1734m 293083.5752 m 639219.8122 m 139.7740 m
csdg 67384.2653 m 0.0978 m 0.4025m 0.9622 m 1.0430m 293083.5375 m 639219.3956 m 138.6490 m
csem 88198.6097 m 0.0139 m 0.0805m -0.2743 m 0.2859m 293083.5972 m 639219.7871 m 139.8855 m
jogs 6508.3951 m 0.0018 m 0.0000m 0.0000 m 0.0000m 293083.5174 m 639219.7977 m 139.6112 m

Baseline Results

2.1.1. Baseline: cmgl - TDTV

Used Processing Parameters

Cut-Off Angle: 10°
Frequency: L1, L2
Sampling Rate: 10 sec
Satellite System: GPS, GLONASS, Galileo
Disabled Satellites:
Solution Type: Phase Float
Solution Optimization: Iono minimized
Frequency to use in Iono Minimized: L1, L2
Tropospheric Model: VMF
Ionospheric Model: Computed
Ephemeris type Broadcast
Allow Widelane Fix: Yes

Min. Distance for Iono Minimized: 15 km

Possible Ambiguities Fix up to: 300 km
Min. Duration for Float Solution (static): 5 min

Antennas and Receivers

  Reference - cmgl Rover - TDTV
Receiver Type / SN: LEICA GR50 / - ComNav / 03303595

inacors.big.go.id/SBC/User/Xpos/CoordinateComputationReport/7164 5/9
7/11/2021 GNSS Processing Report
Antenna Type / SN: LEIAR25 LEIT / - -/-
Coordinates
  Reference - cmgl Rover - TDTV
WGS84 Latitude: 7° 28' 32.7874" S 7° 47' 02.7354" S
WGS84 Longitude: 110° 13' 01.1950" E 110° 20' 38.2650" E
WGS84 Ellip.Height: 422.761 m 139.7714 m

WGS84 Cartesian X: -2185668.470 m -2197143.2311 m

WGS84 Cartesian Y: 5935038.734 m 5925672.7371 m
WGS84 Cartesian Z: -824386.587 m -858146.7497 m

Baseline Vector and Quality

ΔLatitude: 0° 18' 29.9479" S SD ΔLatitude: 0.0035 m M0: 0.30386475
ΔLongitude: 0° 07' 37.0700" E SD ΔLongitude: 0.0113 m Q11: 0.00013007 Q12: 0.00011167 Q13: -0.00005956
ΔHeight: -282.9896 m SD ΔHeight: 0.0098 m Q22: 0.00137140 Q23: -0.00043150
Q33: 0.00104808

ΔX: -11474.7611 m SD ΔX: 0.0099 m M0: 0.30386475

ΔY: -9365.9969 m SD ΔY: 0.0111 m Q11: 0.00105950 Q12: 0.00042881 Q13: -0.00009576
ΔZ: -33760.1627 m SD ΔZ: 0.0039 m Q22: 0.00132716 Q23: -0.00022808
Baseline Length: 36866.5245 m SD Baseline Length: 0.0153 m Q33: 0.00016289
CQ 1D: 0.0039 m
CQ 2D: 0.0148 m
CQ 3D: 0.0153 m

GDOP: 2.1 - 1.6

PDOP: 1.6 - 1.2
HDOP: 0.7 - 0.5
VDOP: 1.4 - 1.1

2.1.2. Baseline: cpts - TDTV

Used Processing Parameters

Cut-Off Angle: 10°
Frequency: L1, L2
Sampling Rate: 10 sec
Satellite System: GPS, GLONASS, Galileo
Disabled Satellites:
Solution Type: Phase Float
Solution Optimization: Iono minimized
Frequency to use in Iono Minimized: L1, L2
Tropospheric Model: VMF
Ionospheric Model: Computed
Ephemeris type Broadcast
Allow Widelane Fix: Yes

Min. Distance for Iono Minimized: 15 km

Possible Ambiguities Fix up to: 300 km
Min. Duration for Float Solution (static): 5 min

Antennas and Receivers

  Reference - cpts Rover - TDTV
Receiver Type / SN: LEICA GRX1200+GNSS / C
- omNav / 03303595
Antenna Type / SN: LEIAR20 NONE / - -/-
Coordinates
  Reference - cpts Rover - TDTV
WGS84 Latitude: 8° 00' 31.9635" S 7° 47' 02.7340" S
WGS84 Longitude: 110° 18' 06.9913" E 110° 20' 38.2691" E
WGS84 Ellip.Height: 47.334 m 139.7740 m

WGS84 Cartesian X: -2191579.964 m -2197143.3528 m

WGS84 Cartesian Y: 5923993.383 m 5925672.7006 m
WGS84 Cartesian Z: -882758.887 m -858146.7103 m

Baseline Vector and Quality

ΔLatitude: 0° 13' 29.2294" N SD ΔLatitude: 0.0031 m M0: 0.23988257
ΔLongitude: 0° 02' 31.2778" E SD ΔLongitude: 0.0099 m Q11: 0.00017007 Q12: 0.00017776 Q13: -0.00009643
ΔHeight: 92.4400 m SD ΔHeight: 0.0086 m Q22: 0.00169345 Q23: -0.00039672
Q33: 0.00127514

ΔX: -5563.3888 m SD ΔX: 0.0090 m M0: 0.23988257

ΔY: 1679.3176 m SD ΔY: 0.0094 m Q11: 0.00139675 Q12: 0.00043120 Q13: -0.00013167

inacors.big.go.id/SBC/User/Xpos/CoordinateComputationReport/7164 6/9
7/11/2021 GNSS Processing Report
ΔZ: 24612.1767 m SD ΔZ: 0.0035 m Q22: 0.00152568 Q23: -0.00030605
Baseline Length: 25288.9431 m SD Baseline Length: 0.0134 m Q33: 0.00021622
CQ 1D: 0.0035 m
CQ 2D: 0.0130 m
CQ 3D: 0.0134 m

GDOP: 2.8 - 1.7

PDOP: 2.2 - 1.4
HDOP: 1.0 - 0.7
VDOP: 2.0 - 1.2

2.1.3. Baseline: csdg - TDTV

Used Processing Parameters

Cut-Off Angle: 10°
Frequency: L1, L2
Sampling Rate: 10 sec
Satellite System: GPS, GLONASS, Galileo
Disabled Satellites:
Solution Type: xRTK
Solution Optimization: None
Frequency to use in Iono Minimized: Automatic
Tropospheric Model: VMF
Ionospheric Model: Computed
Ephemeris type Broadcast
Allow Widelane Fix: Yes

Min. Distance for Iono Minimized: 15 km

Possible Ambiguities Fix up to: 300 km
Min. Duration for Float Solution (static): 5 min

Antennas and Receivers

  Reference - csdg Rover - TDTV
Receiver Type / SN: TRIMBLE ALLOY / - ComNav / 03303595
Antenna Type / SN: TRM59900.00 SCIS / - -/-
Coordinates
  Reference - csdg Rover - TDTV
WGS84 Latitude: 8° 11' 25.8313" S 7° 47' 02.7476" S
WGS84 Longitude: 110° 47' 57.5813" E 110° 20' 38.2679" E
WGS84 Ellip.Height: 30.895 m 138.6490 m

WGS84 Cartesian X: -2241912.277 m -2197142.9111 m

WGS84 Cartesian Y: 5902084.203 m 5925671.6153 m
WGS84 Cartesian Z: -902643.904 m -858146.9707 m

Baseline Vector and Quality

ΔLatitude: 0° 24' 23.0837" N SD ΔLatitude: 0.0138 m M0: 0.96888369
ΔLongitude: 0° 27' 19.3134" W SD ΔLongitude: 0.0080 m Q11: 0.00020386 Q12: -0.00002775 Q13: 0.00095662
ΔHeight: 107.7540 m SD ΔHeight: 0.0965 m Q22: 0.00006889 Q23: 0.00001566
Q33: 0.00990974

ΔX: 44769.3659 m SD ΔX: 0.0346 m M0: 0.96888369

ΔY: 23587.4123 m SD ΔY: 0.0908 m Q11: 0.00127548 Q12: -0.00324238 Q13: 0.00016020
ΔZ: 44496.9333 m SD ΔZ: 0.0108 m Q22: 0.00878185 Q23: -0.00034687
Baseline Length: 67384.2653 m SD Baseline Length: 0.0978 m Q33: 0.00012516
CQ 1D: 0.0108 m
CQ 2D: 0.0972 m
CQ 3D: 0.0978 m

GDOP: 17.8 - 1.8

PDOP: 15.5 - 1.2
HDOP: 3.6 - 0.5
VDOP: 15.1 - 1.1

2.1.4. Baseline: csem - TDTV

Used Processing Parameters

Cut-Off Angle: 10°
Frequency: L1, L2
Sampling Rate: 10 sec
Satellite System: GPS, GLONASS, Galileo

inacors.big.go.id/SBC/User/Xpos/CoordinateComputationReport/7164 7/9
7/11/2021 GNSS Processing Report
Disabled Satellites:
Solution Type: Phase Float
Solution Optimization: Iono minimized
Frequency to use in Iono Minimized: L1, L2
Tropospheric Model: VMF
Ionospheric Model: Computed
Ephemeris type Broadcast
Allow Widelane Fix: Yes

Min. Distance for Iono Minimized: 15 km

Possible Ambiguities Fix up to: 300 km
Min. Duration for Float Solution (static): 5 min

Antennas and Receivers

  Reference - csem Rover - TDTV
Receiver Type / SN: LEICA GR50 / - ComNav / 03303595
Antenna Type / SN: TPSCR.G3 TPSH / - -/-
Coordinates
  Reference - csem Rover - TDTV
WGS84 Latitude: 6° 59' 14.1686" S 7° 47' 02.7349" S
WGS84 Longitude: 110° 22' 36.9745" E 110° 20' 38.2699" E
WGS84 Ellip.Height: 37.729 m 139.8855 m

WGS84 Cartesian X: -2204462.348 m -2197143.4107 m

WGS84 Cartesian Y: 5934931.581 m 5925672.7933 m
WGS84 Cartesian Z: -770741.357 m -858146.7502 m

Baseline Vector and Quality

ΔLatitude: 0° 47' 48.5663" S SD ΔLatitude: 0.0031 m M0: 0.26762849
ΔLongitude: 0° 01' 58.7046" W SD ΔLongitude: 0.0102 m Q11: 0.00013630 Q12: 0.00013374 Q13: -0.00007545
ΔHeight: 102.1565 m SD ΔHeight: 0.0089 m Q22: 0.00146419 Q23: -0.00049754
Q33: 0.00110321

ΔX: 7318.9373 m SD ΔX: 0.0089 m M0: 0.26762849

ΔY: -9258.7877 m SD ΔY: 0.0101 m Q11: 0.00110640 Q12: 0.00049011 Q13: -0.00011705
ΔZ: -87405.3932 m SD ΔZ: 0.0035 m Q22: 0.00142301 Q23: -0.00025930
Baseline Length: 88198.6097 m SD Baseline Length: 0.0139 m Q33: 0.00017429
CQ 1D: 0.0035 m
CQ 2D: 0.0135 m
CQ 3D: 0.0139 m

GDOP: 2.4 - 1.6

PDOP: 1.8 - 1.2
HDOP: 0.8 - 0.5
VDOP: 1.6 - 1.1

2.1.5. Baseline: jogs - TDTV

Used Processing Parameters

Cut-Off Angle: 10°
Frequency: L1, L2
Sampling Rate: 10 sec
Satellite System: GPS, GLONASS, Galileo
Disabled Satellites:
Solution Type: Phase Fixed
Solution Optimization: None
Frequency to use in Iono Minimized: Automatic
Tropospheric Model: VMF
Ionospheric Model: Computed
Ephemeris type Broadcast
Allow Widelane Fix: Yes

Min. Distance for Iono Minimized: 15 km

Possible Ambiguities Fix up to: 300 km
Min. Duration for Float Solution (static): 5 min

Antennas and Receivers

  Reference - jogs Rover - TDTV
Receiver Type / SN: LEICA GR50 / - ComNav / 03303595
Antenna Type / SN: TPSCR3_GGD CONE / - - / -
Coordinates
  Reference - jogs Rover - TDTV

inacors.big.go.id/SBC/User/Xpos/CoordinateComputationReport/7164 8/9
7/11/2021 GNSS Processing Report
WGS84 Latitude: 7° 48' 59.9438" S 7° 47' 02.7345" S
WGS84 Longitude: 110° 17' 41.3164" E 110° 20' 38.2673" E
WGS84 Ellip.Height: 156.304 m 139.6112 m

WGS84 Cartesian X: -2191895.132 m -2197143.2418 m

WGS84 Cartesian Y: 5927112.413 m 5925672.5676 m
WGS84 Cartesian Z: -861716.492 m -858146.7027 m

Baseline Vector and Quality

ΔLatitude: 0° 01' 57.2093" N SD ΔLatitude: 0.0007 m M0: 1.43014860
ΔLongitude: 0° 02' 56.9508" E SD ΔLongitude: 0.0007 m Q11: 0.00000022 Q12: -0.00000004 Q13: 0.00000003
ΔHeight: -16.6928 m SD ΔHeight: 0.0016 m Q22: 0.00000023 Q23: -0.00000000
Q33: 0.00000120

ΔX: -5248.1098 m SD ΔX: 0.0008 m M0: 1.43014860

ΔY: -1439.8454 m SD ΔY: 0.0015 m Q11: 0.00000034 Q12: -0.00000031 Q13: 0.00000007
ΔZ: 3569.7893 m SD ΔZ: 0.0007 m Q22: 0.00000108 Q23: -0.00000008
Baseline Length: 6508.3951 m SD Baseline Length: 0.0018 m Q33: 0.00000023
CQ 1D: 0.0007 m
CQ 2D: 0.0017 m
CQ 3D: 0.0018 m

GDOP: 2.8 - 1.8

PDOP: 2.1 - 1.4
HDOP: 1.0 - 0.6
VDOP: 1.8 - 1.2

inacors.big.go.id/SBC/User/Xpos/CoordinateComputationReport/7164 9/9
