BLL UI User Guide

BLL 4.
Bally Local Link

User Guide
Audience
• Casino Administrators
BLL 4.0 User Interface Guide
© Copyright 2014 - 2015 Scientific Games Corporation. All Rights Reserved. Unauthorized Distribution Prohibited.
© Copyright 2014 - 2015 Scientific Games Corporation. All Rights Reserved. Unauthorized Distribution
Prohibited.
This Document (in this section referred to as “Document”) contains a variety of (a) materials and other items
relating to products or services of Scientific Games Corporation, or one or more of its directly or indirectly wholly
owned companies (collectively referred to in this Document as “Scientific Games”), products and services, and
similar items from Scientific Games’ licensors and other third parties, including all layout, information, text and
scripts, data, files, images, photographs, pictures, artwork, designs, graphics, logos, drawings, charts, button icons,
instructions, illustrations, advertising copy, technology, interactive features, “look and feel,” and the compilation,
assembly and arrangement of the materials of the Document, and any and all copyrightable material; (b) service
marks, trademarks, logos, trade names and trade identities of Scientific Games or their licensors, where applicable
(collectively referred to in this section as “Trademarks”); and (c) other forms of intellectual property (all of the
foregoing, collectively referred to in this section as “Content”). The Document and the Content are owned or
controlled by Scientific Games or its licensors, where applicable. All right, title, and interest in and to the Content is
the property of Scientific Games, where applicable, and is protected by the copyright, trademark or other
intellectual property laws of the United States and elsewhere to the fullest extent possible. Scientific Games owns the
copyright in the selection, compilation, assembly, arrangement, and enhancement of the Content in the Document.
All trademark notices designate marks owned by, or under license to or from, Scientific Games, or one or more of
its directly or indirectly wholly owned companies, in the United States or elsewhere. For a more comprehensive
statement of any specific right or interest, please contact the Legal Department at counsel@scientificgames.com.
Scientific Games grants you a limited, non-exclusive, revocable, non-assignable, personal, and non-transferable
license to view and/or print one copy of the Content, but Scientific Games or its licensors, as the case may be, retain
ownership of such Content. The foregoing limited license does not provide you any ownership of, or any other
intellectual property interest in, any Content and this license may be immediately suspended or terminated for any
reason, by Scientific Games in their sole discretion, and without advance notice or liability.
The specifications and information contained in this documentation are subject to change without notice. All
statements, information, illustrations, specifications and recommendations in this documentation are believed to be
accurate, but are provided without warranty of any kind, express or implied. The product referenced in this
Document is being provided by Scientific Games as is.
Scientific Games Corporation

6650 S. El Camino Road
Las Vegas, NV 89118, USA
1 855 777 7435 (Toll Free)
702 897 7150
http://www.scientificgames.com
ii CONFIDENTIAL 29 DEC 2015

Contents
Chapter 1: BLL Overview

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
BLL Application Workflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3
Application Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4
BLL Manager Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5
Tool Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 6
Tab Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 7
Configuration Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 7
Maintenance Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 8
Reports Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 9
Footer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 10
Chapter 2: Configuring Links, Cabinets, and Games

About Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
Configuring Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
Viewing the Configuration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 4
About Links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 5
Configuring Progressive Link Levels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 5
Adding a Progressive Link Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7
Editing a Progressive Link Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 9
Viewing a Progressive Link Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 10
Deleting a Progressive Link Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 11
Configuring Progressive Links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 13
Creating a Progressive Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 14
Editing a Progressive Link. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 20
CONFIDENTIAL 29 DEC 2015 i

Deleting a Progressive Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 21

Viewing a Progressive Link. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 24
Configuring Games. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 27
Adding a Game . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 28
Editing Game Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 30
Deleting a Game . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 32
Viewing Game Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 34
Configuring Cabinets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 36
Adding a Cabinet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 37
Assigning a Game and link to an existing Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 41
Editing a Cabinet’s Game Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 45
Deleting a Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 46
Viewing Cabinets Error Log History Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 48
Viewing Cabinets Status History Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 51
About Signs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 53
Configuring Signs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 53
Adding a Sign Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 54
Editing a Sign Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 58
Viewing a Sign Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 60
Deleting a Sign Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 62
Chapter 3: Managing Jackpots, Links, and Sites

Adjusting the Jackpot Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 1
Processing a Manual Jackpot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 4
Resetting a LAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 6
Rolling back a Jackpot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 8
End Of Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 13
Chapter 4: Reports
Reports Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
Award Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
Award History Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 5
Bet History Report. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 7
Daily Accumulation Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 9
Daily Performance Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 11
Event Log Report. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 13
ii 29 DEC 2015 CONFIDENTIAL

Exception Log Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 15

Link Information Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 17
Machine Bet Status Report. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 19
Machine Information Report. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 21
Manual Adjustments Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 23
System Release Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 25
User Activity Log Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 26
Chapter A: Appendix
Game Theme Conversion and Maintenance Instructions for BLL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A - 1
BLL Game Theme Conversion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A - 1
Completing a RAM Clear. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A - 1
Replacing the GMM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A - 2
Verifying a Cabinet that reported Zero Max Coin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A - 2
Assigning a link to a Cabinet or Re-assigning a Cabinet with a new link. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A - 3
List of Progressive System Error Conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A - 3
CONFIDENTIAL 29 DEC 2015 iii

iv
29 DEC 2015
CONFIDENTIAL
Chapter 1
BLL Overview
Overview
Bally Local Link, a bank controller, provides a secure and user-friendly method for configuring,
monitoring, and reporting Bally progressive-capable games. The scalable solution provides progressive
management from a small bank configuration to multiple bank support, while integrating with CoolSign
and Paltronics media controllers, for a full-service progressive system solution.
Following are the features of Bally Local Link:
• Progressive Connections
Supports Bally ALPHA 1, ALPHA 2, Equinox, and Shuffle gaming machines with only Single
Game Single Denom (SGSD).
Operates Standard or Mystery (where approved) progressives.
Maintains machine-triggered progressive functionality for up to 32 gaming machines.
Operates 32 progressive jackpot links, and configures 8 jackpot levels for each link.
Works with protocols GASS 3.0, SAS 6.02, MML 2.0 and MML 2.2.
• Scalable Solution
Offers localization of reports supporting numerous currency symbols (Version 3.2.2), date,
and time formats.
Supports standalone control to single and multiple bank operation.
Operates independently from the progressive game, and does not require a special card
adapter.
Integrates with CoolSign and Paltronics overhead sign controllers providing a multi-media
experience with video, winner celebrations, and progressive odometers operating on LCD
overheads.
CONFIDENTIAL 29 DEC 2015 1-1

Chapter 1: BLL Overview BLL 4.0 User Interface Guide
• Full Reporting
Supports jackpot, event and exception processing while maintaining progressive amounts and
contributions for each link.
Monitors accumulated bets.
Offers browser-based reporting of progressive game activity, events, contributions, monitoring
of accumulated bets, and performance by each progressive game.
Provides 'at-a-glance' monitoring of links, progressive games, events and errors.
• Security
Provides restricted user access with defined user names and passwords.
1-2 29 DEC 2015 CONFIDENTIAL Overview

BLL 4.0 User Interface Guide Chapter 1: BLL Overview
BLL Application Workflow

Following are the significant tasks performed in the BLL application. The tasks are listed in the sequence
in which they are carried out within a business.
STEP 1. Configure Settings from the BLL Manager Application. See Configuring Settings on page 2-1.
STEP 2. Configure Link Levels from the BLL Manager Application. See Configuring Progressive Link
Levels on page 2-5.
STEP 3. Configure Links using the Link Levels created, from the BLL Manager application. See
Configuring Progressive Links on page 2-13.
STEP 4. Add Cabinets to BLL network, and start services, LSS and ECCS.
STEP 5. Create Games from the BLL Manager application. See Configuring Games on page 2-27.
STEP 6. Add Cabinets, and assign game and link to them. See Configuring Cabinets on page 2-36.
STEP 7. Add Cool Signs from the BLL Manager application. See Configuring Signs on page 2-53.
NOTE: When cabinets are added to BLL network using SAS or GASS GMM, MML; games
and cabinets are created and populated automatically in the BLL Manager UI.
Links will be auto-assigned, but it is preferred to verify that correct links are
assigned.
STEP 8. Generate reports to suit business requirements from the various reports supported in the BLL
Manager application. See Reports Overview on page 4-1.
BLL Application Workflow CONFIDENTIAL 29 DEC 2015 1-3

Application Login
Follow these steps to log on to the BLL application.
STEP 1. Go to Start > All Programs > BLL Manager UI. The BLL Manager - Login screen is displayed.
STEP 2. Type the user name and password in the Username and Password fields respectively.
STEP 3. Type the first name and last name of the user in the First Name and Last Name fields
respectively.
STEP 4. Click Login. The BLL Manager application appears.
NOTE: The Login button is enabled only when the user enters the username, password,
first name, and last name.
1-4 29 DEC 2015 CONFIDENTIAL Application Login

BLL Manager Application

The interface provides easy-to-navigate options that are grouped based on their functionality.
Tool Bar
Tab Options
Menu Bar
Footer
BLL Manager Application CONFIDENTIAL 29 DEC 2015 1-5

Tool Bar
The tool bar resides on the top left corner of the application screen. It displays commonly used tasks.
Option Description
Click to view the user guide for the BLL application.
To be able to view the guide, copy the user guide from the CD to the location where the BLL
Manager is installed (C:\Program Files (x86)\Bally Technologies\BLL\BLL Manager UI\). If not, a
message is displayed instructing the user to copy the guide. Also, ensure that the file name of the
User Guide is not changed from ‘BLL UI User Guide.pdf’.
Click to view the system and application version information of the BLL application. The following
window is displayed.
Click to log off from the BLL application. On clicking, the application logs off, and the logon screen
re-appears.
Click to exit from the BLL application. The following warning message is displayed.
Click Yes to exit, else click No.
1-6 29 DEC 2015 CONFIDENTIAL BLL Manager Application

Tab Options
The BLL Manager application provides commands and options grouped under three tabs to access all the
supported features.
Configuration Tab
The Configuration tab allows the user to manage links, link levels, games, cabinets, and cool sign
configuration settings.
Following are the options:

• Configure Link Levels
• Configure Links
• Configure Games
• Configure Cabinets
• Configure Settings
• CoolSign (CEI)
• View Links
• View Games
• View Cabinet Status

Maintenance Tab
The Maintenance tab allows the user to manage manual jackpots, adjust current jackpot amount, rollback
jackpot, and reset Local Area Progressives (LAP).
Following are the options:
Manual Adjustments
Manual Jackpot
End of Life
Reset LAP
Jackpot Rollback
1-8 29 DEC 2015 CONFIDENTIAL BLL Manager Application

Reports Tab
The Reports tab provides various reports for users to view configuration, daily accounting, operations,
and system reports.
Followings are the reports:

Award
Award History
Bet History
Daily Accumulation
Daily Performance
Event Log
Exception Log
Link Information
Machine Bet Status
Machine Information
Manual Adjustments
System Release
User Activity Log

Footer
The footer is displayed towards the end of the screen, and displays the BLL system and user information.
The footer displays:
• Site name
• Bank name
• BLL MAC address
• BLL version number
• Current logged-in user name
• Current date and time
NOTES: The following warning message is displayed when the button is clicked.
Click Yes to exit from the BLL Manager, else click No.
Clicking the icon will not exit the BLL Manager.
1 - 10 29 DEC 2015 CONFIDENTIAL BLL Manager Application

Chapter 2
Configuring Links, Cabinets, and Games
This chapter explains links, cabinets, games, and cool sign devices configurations using the BLL
application. The application provides options to manage and operate links. It also provides options to
manage cabinet operations.
About Settings
The Configuration settings applicable to the system are displayed on this screen.
NOTE: All the menu will be disabled until the settings are configured.
A
Configuring Settings
Follow these steps to change the system configuration settings.

Chapter 2: Configuring Links, Cabinets, and Games BLL 4.0 User Interface Guide
STEP 1. Go to Configuration > Configure Settings. The BLL Manager v4.0 - Settings window is
displayed.
STEP 2. Enter the following details.
Field Name Description
SiteName The name of the BLL site.
BankName The name of the bank.
BreakRateFeatureEnabled Type True to enable the break rate feature, else type False. The break rate feature is
enabled and this value is set to True, by default.
BLL MAC Address The MAC address of the BLL system.
BLL IP Address The IP address of the BLL system.
2-2 29 DEC 2015 CONFIDENTIAL Configuring Settings

BLL 4.0 User Interface Guide Chapter 2: Configuring Links, Cabinets, and Games
STEP 3. Click Save. The following information is displayed.

STEP 4. Click OK. The configuration settings values are saved.
Configuring Settings CONFIDENTIAL 29 DEC 2015 2-3

Viewing the Configuration Settings

Follow these steps to view the system configuration settings.
STEP 1. Go to Configuration > Configure Settings. The BLL Manager v4.0 - Settings window is
displayed.
2-4 29 DEC 2015 CONFIDENTIAL Configuring Settings

About Links
A link is a single set of progressive parameters, which include the progressive level parameters and the
cabinets that participate for a common progressive jackpot. The configuration of a link includes the Link
and the Level settings. Each link will have one or more levels (up to 8 levels). The link is the primary unit
that governs the association of games and cabinets to a set of levels.
Configuring Progressive Link Levels

Configuring link levels from the BLL Manager includes the following actions:
• Add a progressive link level
• Edit a progressive link level
• View a progressive link level
• Delete a progressive link level
Refer to the subsequent sections in this chapter for detailed information on the above options.
The default screen under Configuration > Configure Link Levels menu displays all the progressive link
levels in the system.
About Links CONFIDENTIAL 29 DEC 2015 2-5

By default, the available progressive link levels are listed on the Configure Link Levels screen.
2-6 29 DEC 2015 CONFIDENTIAL Configuring Progressive Link Levels

Adding a Progressive Link Level

Follow these steps to create a progressive link level.
STEP 1. From the Configuration tab, click Configure Link Levels. The BLL Manager v4.0 -
Configure Link Levels window is displayed.
Configuring Progressive Link Levels CONFIDENTIAL 29 DEC 2015 2-7

Level ID When creating a progressive link level, the Level Editor automatically assigns the next
available Level ID. The user cannot enter or modify the Level Id.
Reset Amount The base amount of the progressive.
Break Threshold The threshold at which the break rate will be used as the percentage of wagers contributed
to the prize level.
Progressive Rate (%) The percentage of bets that is to be added to the current progressive amount.
Break Rate (%) The percentage of wagers contributed to the prize level after the break threshold.
Hidden Rate (%) The percentage of bets that is to be added to the hidden amount.
STEP 3. Click Back to go back to the main screen.
STEP 4. Click Save Progressive Link Levels. The following information is displayed.
STEP 5. Click OK. The progressive link levels are saved.
2-8 29 DEC 2015 CONFIDENTIAL Configuring Progressive Link Levels

Editing a Progressive Link Level

Follow these steps to edit a progressive link level.
STEP 2. Edit the fields as required, and click Save Progressive Link Levels. The following information
is displayed.
STEP 3. Click OK.The progressive link levels are updated.
Configuring Progressive Link Levels CONFIDENTIAL 29 DEC 2015 2-9

Viewing a Progressive Link Level

Follow these steps to view a progressive link level.
NOTE: The Link Levels with End Of Life processed, will be displayed (with grey
background) and are non editable.
2 - 10 29 DEC 2015 CONFIDENTIAL Configuring Progressive Link Levels

Deleting a Progressive Link Level

Follow these steps to delete a progressive link level.
Configuring Progressive Link Levels CONFIDENTIAL 29 DEC 2015 2 - 11

STEP 2. Select and right-click the progressive link level. The following window is displayed.
STEP 3. Click Delete Link Level. The progressive link level is deleted.
2 - 12 29 DEC 2015 CONFIDENTIAL Configuring Progressive Link Levels

Configuring Progressive Links

Configuring progressive links from the BLL Manager includes the following actions:
• Create a progressive link
• Edit a progressive link
• View a progressive link
• Delete a progressive link
The default screen under Configuration > Configure Links menu displays all the progressive link in the
system.
By default, the available progressive links are listed on the Configure Links screen.
Configuring Progressive Links CONFIDENTIAL 29 DEC 2015 2 - 13

Creating a Progressive Link

Follow these steps to create a progressive link.
STEP 1. From the Configuration tab, click Configure Links. The BLL Manager v4.0 - Configure
Links window is displayed.
2 - 14 29 DEC 2015 CONFIDENTIAL Configuring Progressive Links

STEP 2. In the Standard Links tab, enter the link name in the box, and click Display/Create. The
following window is displayed.

STEP 3. Drag and drop the progressive levels from the Standard Levels list to the Standard Links
region to populate the link. The following window is displayed.
NOTES: The level details can be changed only in the Configure Link Levels window.
As the levels are populated/removed in the link, the total link rates (Link
primary rate, Link hidden rate, and Link contribution rate) are calculated
automatically and displayed.

STEP 4. Following are the details.
Standard Levels The list of all the progressive levels.
Standard Links: It includes only SAS links.
Level The number of the link level. It is populated by default. A maximum of 8 levels can be
assigned to a link.
Reset Amount The reset amount of the level.
Break Threshold The progressive amount after which the break rate is applied instead of the progressive
rate.This field is invisible if the BreakRateFeatureEnabled settings value is False.
Progressive Rate (%) The percentage of bets that is added to the current progressive amount.
Break Rate (%) The rate applied to the progressive amount when break threshold is reached, instead of the
progressive rate. This field is invisible if the BreakRateFeatureEnabled settings value is False.
Hidden Rate (%) The percentage of bets that is added to the hidden amount.
Link Details
Link Primary rate The total progressive rate of all the levels in the link.
Link Hidden rate The total hidden rate of all the levels in the link.
Link Contribution rate The sum of Link Primary rate and Link Hidden rate of the link.
Configuration last The date and time when the link was modified last.
modified

STEP 5. Click Save Standard Link. The following link confirmation window is displayed.
STEP 6. Click Cancel to go to the previous screen.
STEP 7. Click Submit. The following information is displayed.

STEP 8. Click OK. The following information is displayed.

STEP 9. Click OK. The following information is displayed only for the first progressive link.
STEP 10. Click OK. A progressive link with one or more progressive levels, is created.

Editing a Progressive Link

Follow these steps to edit a progressive link.
STEP 2. Repeat STEP 3 to STEP 9 in Creating a Progressive Link on page 2-14.
STEP 3. Select a link level that has to be deleted, and press delete on keyboard. The link level is deleted
from the link, and saved.
STEP 4. The progressive link is updated.

Deleting a Progressive Link

Follow these steps to delete a progressive link.

STEP 2. Click Delete Link.The following window is displayed.
STEP 3. Select the link from the Choose the Link list, and click Delete Link. The following
information is displayed.

STEP 4. Click OK. The progressive link is deleted.
NOTE: If the link is assigned to a cabinet, the link cannot be deleted and the following
information is displayed.

Viewing a Progressive Link

Follow these steps to view a progressive link.
STEP 1. From the Configuration tab, click View Links. The BLL Manager v4.0 - View Links window
is displayed.

STEP 2. Select the link from the Choose the Link name list to view the details of the link.
NOTE: If cabinets are assigned to the link, the following window is displayed.

Link Details
Level The number of the link level.
Break Threshold The progressive amount after which the break rate is applied instead of the progressive
rate.This field is invisible if the BreakRateFeatureEnabled settings value is False.
Progressive Rate (%) The percentage of bets that is added to the current progressive amount.
Break Rate (%) The rate applied to the progressive amount when break threshold is reached, instead of the
progressive rate. This field is invisible if the BreakRateFeatureEnabled settings value is False.
Hidden Rate (%) The percentage of bets that is added to the hidden amount.
EGM’s using this link
Cabinet ID The identification number of the cabinet assigned to the link.
Game Number The number of the game assigned to the cabinet that is assigned to the link. It is always ‘1’ as
only one game is supported.

Configuring Games
The configuring games feature allows users to view the list of games that are currently found at the site.
Configuring games from the BLL Manager includes the following actions:
• Add a Game
• Edit Game Details
• View Game Details
• Delete a Game
Configuring Games CONFIDENTIAL 29 DEC 2015 2 - 27

Adding a Game
Follow these steps to add a game.
STEP 1. From the Configuration tab, click Configure Games. The BLL Manager v4.0 - Configure
Games window is displayed.
2 - 28 29 DEC 2015 CONFIDENTIAL Configuring Games

SMI Number The SMI number of the game.
Game Name The name of the game.
Maxcoin The maximum number of coins that can be bet.

Denom The denominations of the game.
RTP (%) The Return To Player percentage. It must be greater than or equal to 80 and less than 100.
Comment The additional information of the game.
STEP 3. Click Save. The following information displaying the SMI number, Denom, and Maxcoin of
the game, is displayed.
STEP 4. Click OK. The game is created.

Editing Game Details

Follow these steps to edit game details.

STEP 2. Click Edit Game. The following window is displayed.

STEP 3. Select the game from the Edit an existing Game list, and change the values.
STEP 5. Click OK. The game details are updated.
NOTE: Only the Game Name and Comments fields can be edited.

Deleting a Game
Follow these steps to delete a game.

STEP 2. Click Delete Game. The following window is displayed.

STEP 3. Select the game from the Delete a Game list, and click Delete. The following information is
displayed.
STEP 4. Click OK. The game is deleted.

Viewing Game Details

Follow these steps to view game details.
STEP 1. From the Configuration tab, click View Games. The BLL Manager v4.0 - View Games
STEP 2. Select the game from the Choose the SMI name list.

Gameid The identification number of the game. It is always ‘1’ as only one game is supported for a
link.

Maxcoin The maximum number of coins that can be bet.
Denom The denominations of the game.
RTP (%) The Return To Player percentage.
Comment The additional information of the game.
Cabinet ID The list of cabinets running the game.
NOTE: If the game is assigned to cabinets, the following window is displayed.

Configuring Cabinets
Managing EGMs from the BLL Manager includes the following actions:
• Add a Cabinet
• Assign a Game to an existing Cabinet
• Edit a Cabinet’s Game Details
• Delete a Cabinet
• View Cabinets Error Log History Details
• View Cabinets Status Details
2 - 36 29 DEC 2015 CONFIDENTIAL Configuring Cabinets

Adding a Cabinet
Follow these steps to add a cabinet.
STEP 1. From the Configuration tab, click Configure Cabinets. The BLL Manager v4.0 - Configure
Cabinets window is displayed.
Configuring Cabinets CONFIDENTIAL 29 DEC 2015 2 - 37

STEP 2. In the Cabinet Creation section, enter the unique identification number of the cabinet in the
Enter Cabinet ID field, and click Save. The following window is displayed.
STEP 3. Select the following details in the Game Creation section.
Game Creation
Select an SMI The SMI number of the game that has to be added to the cabinet.
Select a Link The link that has to be assigned to the cabinet.
EGM Game Number The game number of the cabinet.

STEP 4. Click Save. The following message is displayed.

STEP 5. Click Yes. The following information is displayed.

STEP 6. Click OK. The cabinet is added and the game details are assigned to it.

Assigning a Game and link to an existing Cabinet

Follow these steps to assign a game and link to an existing cabinet.
NOTES: The Cabinet ID cannot be changed.

The user is not allowed to assign a game to a cabinet, with Max Coin value as
zero and Theoretical Hold value as zero.

STEP 2. Select the Cabinet from the EGM list. The following window is displayed.
STEP 3. Select the following details in the Game Creation section.
Game Creation
Select an SMI The SMI number of the game that has to be added to the cabinet.
Select a Link The link that has to be assigned to the cabinet.

EGM Game Number The game number of the cabinet.

1. If the game number already exists, the following message is displayed.
2. Click Yes to replace the game number, else click No and enter a different game number.
STEP 4. Click Save. The following window is displayed.

STEP 5. Click OK. The game and link are assigned to the cabinet.
NOTE: The deletion of a game position entry is not supported.

Editing a Cabinet’s Game Details

Follow these steps to edit a cabinet’s game details.
NOTE: The Cabinet ID cannot be changed.
STEP 2. Repeat STEP 2 to STEP 5 in Assigning a Game and link to an existing Cabinet on page 2-41.

Deleting a Cabinet
Follow these steps to delete a cabinet.

STEP 2. Select and right-click the Cabinet from the EGM list. The following window is displayed.
STEP 3. Click Delete. The Cabinet is deleted.

Viewing Cabinets Error Log History Details

Follow these steps to view cabinets error log history details.

STEP 2. Select and right-click EGM. The following window is displayed.


STEP 3. Click Display Error Log. The following window is displayed.
STEP 4. The following details are displayed in the Message Table window.
DATE The date and time when the event occurred.
MESSAGE The error message details.

Viewing Cabinets Status History Details

Follow these steps to view cabinets status details.
STEP 1. From the Configuration tab, click View Cabinet Status. The BLL Manager v4.0 - Cabinet
Status window is displayed.
STEP 2. The following details are displayed.
View Cabinet Status
Total Cabinets The total number of online cabinets to the total number of cabinets.
Total Links Assigned The total links assigned to the cabinets with respect to the total number of links present.
Total GMMs The total number of online GMMs connected to cabinets to the total number of GMMs.
EGM Id The unique identification number of the cabinet.
EGM Serial # The unique serial number of the cabinet.
Game The name of the game assigned to the cabinet.
Denom The denomination of the game assigned to the cabinet.

Max Coin The maximum number of coins that can be placed in a bet.
Status The status of the cabinet.
Last Bet Date Time The date and time when the last bet was played.
Last Bet Meter The bet meter when the last bet was played.
Last Bet Amount The bet amount when the last bet was played.
GMM IP Address The IP address of GMM when the cabinet is connected to SAS/GASS GMM. For MML cabinets,
it is the IP address of ECCS.
STEP 3. Click Refresh to refresh the data.
NOTE: The data is refreshed every 30 seconds.

About Signs
Progressives may require overhead and in-machine displays to convey the current progressive meter
values and jackpot hits to the patrons on a casino floor. To support this, the BLL product has incorporated
a Signage functionality which is implemented in ECCS. The application interface communicates with
CoolSign and Paltronics Sign to display progressives data.
Sign devices are configured from the BLL application. Once configured, these devices get periodic updates
of standard progressive values. The sign devices can be configured to display jackpot hit messages,
winning amount, and reset amount. They also play the jackpot celebration themes for cabinet-paid
jackpots. For handpay jackpots, the jackpot celebration is played until the attendant key is turned.
Sign device represents the physical device which connects to one or more signs. This device will be
identified with a sign ID, and will be assigned one or more meter groups.
Configuring Signs
The CoolSign devices are supported by sending progressive data to the Casino Equipment Interface (CEI).
The user may add one or more CoolSign devices.
Depending on the business needs, there are multiple ways of configuring signs. The user may configure all
the CoolSign devices to display the same, common content that is configured from a server. Alternatively,
the user may configure the signs to display discrete content based on the bank of cabinet.
The default screen under Configuration > CoolSign (CEI) menu displays the available sign devices. The
users are allowed to add, view, edit, and remove the sign devices. This screen provides options to perform
the following:
• Add a Sign Device
• Edit a Sign Device
• View a Sign Device
• Remove a Sign Device
NOTE: The user is restricted to add only one CoolSign device to the BLL controller. The
user can add multiple nodes for a CoolSign device using multiple ports.
About Signs CONFIDENTIAL 29 DEC 2015 2 - 53

Adding a Sign Device

Follow these steps to add a sign device.
STEP 1. From the Configuration tab, click CoolSign (CEI). The BLL Manager v4.0 - CoolSign
Devices window is displayed.
2 - 54 29 DEC 2015 CONFIDENTIAL Configuring Signs

STEP 2. Click Add. The following window is displayed.

IP Address The IP Address of the cool sign device.
Port The port number on which the cool sign device acknowledges for incoming connection
from BLL. The ECCS shall forward the corresponding meter group updates and any jackpot
hit related events to the signage upon establishing connection. Click Find Available Port to
assign the available port number. The port number for the first CoolSign device will be
defaulted to 11001.
Description The description of the cool sign device.
Assign LinkLevels
Configuring Signs CONFIDENTIAL 29 DEC 2015 2 - 55

Link Select the link from the list.
Level Select All or a particular level assigned to the link.
STEP 4. Click Add Level(s). The following window is displayed.

STEP 5. Following are the link details.
Link Details
Order The order of the link.
Link Name The name of the link.

Type The type of the link.
Level Index The level index number.
Celebration Type The type of celebration. Options include: TimeBased and Key Turn.
Celebration Timeout (sec) The celebration time period in seconds.
STEP 6. Select a level, and click Remove Level to remove the level from the link.
STEP 7. Select a level, and click Move Up or Move Down to move the level up or down the list.
STEP 8. Click Save. The cool sign device is added.

Editing a Sign Device

Follow these steps to edit a sign device.

STEP 2. Select a cool sign device, and click View/Edit. The following window is displayed.
STEP 3. Repeat STEP 3 to STEP 8 in Adding a Sign Device on page 2-54.
NOTES: When the link levels in a link are changed, the user has to manually update the
signs with correct link levels.
If celebration timeout is set less than 60 sec, CoolSign shows the celebration for
60 sec.
For lower jackpot levels, it is not recommended to configure Celebration Type
with KeyTurn. (If configured, the celebration message will play forever.)
Make sure that the Key turn limit on a Cabinet is greater than or equal to the
Level Reset Amount, when configuring with Key Turn.

Viewing a Sign Device

Follow these steps to view a sign device.

STEP 2. Click View/Edit. The following window is displayed.


Deleting a Sign Device

Follow these steps to delete a sign device.
STEP 2. Click Delete. The following message is displayed.
STEP 3. Click Yes. The cool sign device is deleted.

Chapter 3
Managing Jackpots, Links, and Sites
This chapter explains adjusting jackpots, manual jackpots, and resetting LAPs supported in the BLL
application. The application provides options to view jackpot information, manage jackpots and awards,
and reset LAPs.
Adjusting the Jackpot Details

The application allows users to modify certain jackpot parameters through the Maintenance > Manual
Adjustments menu. The current amount and hidden amount values are editable.When the current or
hidden amount is adjusted, the adjustment will be recorded.
Follow these steps to adjust the jackpots.

Chapter 3: Managing Jackpots, Links, and Sites BLL 4.0 User Interface Guide
STEP 1. From the Maintenance tab, select Manual Adjustments. The BLL Manager v4.0 - Manual
Adjustments window is displayed.
STEP 2. Select the link from the Choose the Link name list.
3-2 29 DEC 2015 CONFIDENTIAL Adjusting the Jackpot Details

BLL 4.0 User Interface Guide Chapter 3: Managing Jackpots, Links, and Sites
STEP 3. Edit the following details.
Level The level number assigned to the link.
Current Amount The total jackpot amount.
Hidden Amount The total reserve amount.

STEP 5. Click OK. The adjustments are saved.
NOTE: The adjustments are effective immediately and the current jackpot amount on the
cabinets will be updated.
Adjusting the Jackpot Details CONFIDENTIAL 29 DEC 2015 3-3

Processing a Manual Jackpot

The application allows authorized users to manually process a jackpot hit for SAS links through the
Maintenance > Manual Jackpot menu. It shall be used to process jackpot manually at the system, in case
of any malfunction in gaming machine or the network that caused failure to deliver valid jackpot to the
player. When a jackpot is manually processed, the details are not sent to the Cabinet. The processing is
identical to a regular jackpot hit request.
Follow these steps to process a jackpot manually.
STEP 1. From the Maintenance tab, select Manual Jackpot. The BLL Manager v4.0 - Manual Jackpot
3-4 29 DEC 2015 CONFIDENTIAL Processing a Manual Jackpot

Current Amount The total jackpot amount.
Hidden Amount The total reserve amount.

Cabinet ID The unique identification number of the cabinet.
Game Number The game number assigned to the cabinet.
STEP 3. Select the link from the Choose the Link name list.
STEP 4. Select the link level and cabinet from the list, and click Submit Manual JP. The following
message is displayed.
STEP 6. Click OK. The jackpot is processed manually.
Processing a Manual Jackpot CONFIDENTIAL 29 DEC 2015 3-5

Resetting a LAP
The application allows users to manually reset a Local Area Progressive (LAP) site. Resetting a LAP will
delete all current games, links, and cabinets.
Follow these steps to reset a LAP.
STEP 1. From the Maintenance tab, select Reset LAP. The BLL Manager v4.0 - Reset LAP window is
displayed.
WARNING: The Reset LAP feature deletes all the information related to links, cabinets,
games in BLL system.
3-6 29 DEC 2015 CONFIDENTIAL Resetting a LAP

STEP 2. Click Next. The following message is displayed.

STEP 4. Click OK. The LAP is reset.
Resetting a LAP CONFIDENTIAL 29 DEC 2015 3-7

Rolling back a Jackpot

The application allows authorized users to rollback a requested jackpot through the Maintenance >
Jackpot Rollback menu.
Follow these steps to rollback a jackpot.
STEP 1. From the Maintenance tab, select Jackpot Rollback. The BLL Manager v4.0 - Jackpot
Rollback window is displayed.
3-8 29 DEC 2015 CONFIDENTIAL Rolling back a Jackpot

STEP 2. Click Set Date Range. The following window is displayed.

Rolling back a Jackpot CONFIDENTIAL 29 DEC 2015 3-9

STEP 3. Select a link from the list. The following window is displayed.
3 - 10 29 DEC 2015 CONFIDENTIAL Rolling back a Jackpot

STEP 4. Click a jackpot from the link. The following window is displayed, followed by the information
window.
STEP 5. Click Cancel to stop the jackpot rollback.
Rolling back a Jackpot CONFIDENTIAL 29 DEC 2015 3 - 11

STEP 8. Click OK.The jackpot is rolled back.
3 - 12 29 DEC 2015 CONFIDENTIAL Rolling back a Jackpot

End Of Life
Follow these steps to set the Progressive Rate, Break Rate, and Hidden Rate values of a link to zero.
STEP 1. From the Maintenance tab, select End of Life. The BLL Manager v4.0 - End Of Life window
is displayed.
End Of Life CONFIDENTIAL 29 DEC 2015 3 - 13

STEP 2. Select the link from the Choose the Link name list. The following window is displayed.
STEP 3. Click Save. The following window is displayed.
3 - 14 29 DEC 2015 CONFIDENTIAL End Of Life

STEP 4. Click Yes. The following information is displayed.

STEP 5. Click OK. The End of Life is processed.
End Of Life CONFIDENTIAL 29 DEC 2015 3 - 15

3 - 16 29 DEC 2015 CONFIDENTIAL End Of Life

Chapter 4
Reports
Reports Overview
The BLL application provides various reports for users to view Configuration, Daily Accounting,
Operations, and System reports. The reports can be either launched from the BLL Manager UI or from the
URL http://localhost/Reports.
NOTES: The BLL Reports provide only data accumulated for Progressive Jackpots.
The User name will be displayed in the report footer, when the reports are
launched from BLL Manager UI and will not be displayed in the report footer,
when the reports are launched from the Reports desktop shortcut.
Award Report
The report displays the details of an award. The user can filter the report data by Link, Jackpot, Start and
End Date.
Following is an example of the filter criteria.

Chapter 4 Reports BLL 4.0 User Interface Guide
Following is an example of the Award report.
4-2 29 DEC 2015 CONFIDENTIAL Award Report

BLL 4.0 User Interface Guide Chapter 4 Reports
The following table describes the report fields.
Filter Criteria
Start Date The user-selected start date for the search criteria.
End Date The user-selected end date for the search criteria.
Link Select the name of the link.
Jackpot Select the jackpot Id number.
Report Fields
Report generated date time The date and time when the report was generated.
BLL Software Version The version number of BLL.
Criteria: For field information, refer the descriptions in the Filter Criteria section.
Award Amount The amount of the award.
Jackpot Id The jackpot Id number.
Start Date The start date of the award.
Award Date The date and time when the jackpot was hit.
Starting Amount The starting award amount in dollars.
Progressive Rate The progressive rate of the award.
Contribution The total contribution made to the jackpot, in dollars.
Calculated Coin-In The total coin-in meter amount in dollars.
Winning Cabinet The serial number of the winning cabinet.
SMI Number The SMI number of the game
Award Status The status of award.
Rolled Back The status of Jackpot Rollback.
Manual Jackpot The status of manual adjustment of the jackpot.
Mystery Jackpot It denotes whether the jackpot is a Mystery jackpot or not.
Award Report CONFIDENTIAL 29 DEC 2015 4-3

Days Running The number of days the jackpot is running from.
Break Threshold The break threshold amount in dollars.
Break Rate The break rate of the jackpot amount.
Paid The total paid amount recorded by the cabinet, in dollars.
Calculated Break Coin-In The calculated break coin-in amount.
Game Number The game number assigned to the cabinet.
Denomination The denomination of the game in dollars.
Max Coin The maximum number of coins.
Contribution Details
Denom The denomination of the game in dollars.
Max Coin The maximum number of coins.
Cabinet Id The unique identification number of the cabinet.
Game The name of the game.
Game # The game number assigned to the cabinet.
Coin-In The total coin-in amount in dollars.
Total The total of all the Coin-In and Contribution amount respectively in the link.
Adjustments Details
Jackpot Id The identification number of jackpot.
Manual Adjustment The day, date, and time when the manual adjustment was made.
Hidden Adjustment The hidden adjustment amount in dollars.
Jackpot Adjustment The jackpot adjustment in dollars.
Total The total of all the Hidden Adjustment and Jackpot Adjustment amount
respectively in the link
4-4 29 DEC 2015 CONFIDENTIAL Award Report

Award History Report

The user can filter the report data by Start, End, and EGM.
Following is an example of the Award History report.
Award History Report CONFIDENTIAL 29 DEC 2015 4-5

Filter Criteria
Start The user-selected start date for the search criteria.
End The user-selected end date for the search criteria.
EGM Select All Cabinets or a particular cabinet from the list.
Report Fields
Awarded Jackpots (JP)
Jackpot ID The identification number of the cabinet.
Award Amount The total award amount in dollars recorded by the cabinet
Paid Amount The total paid amount recorded by the cabinet, in dollars.
EGM Id The identification number of the EGM.
Link The number of links assigned to the cabinet.
Award Date and Time The day, date, and time of the award.
Roll Back The status of Jackpot Rollback.
Manual The status of manual adjustment of the jackpot.
Mystery It denotes whether the jackpot is a Mystery jackpot or not.
4-6 29 DEC 2015 CONFIDENTIAL Award History Report

Bet History Report

The user can filter the report data by One Hour history from this date/time.
Following is an example of the Bet History report.
Bet History Report CONFIDENTIAL 29 DEC 2015 4-7

Filter Criteria
One Hour history from this The one hour history from the user-selected start date and time for the search
date/time criteria.
Report Fields
Date The date and time of the bet processed.
EGMId The Id number of the EGM.
Bet Meter The bet meter value.
Bet The bet amount reported by the cabinet, in dollars.
4-8 29 DEC 2015 CONFIDENTIAL Bet History Report

Daily Accumulation Report

The user can filter the report data by Period Start, Period End, and Link.
Following is an example of the Daily Accumulation report.
Daily Accumulation Report CONFIDENTIAL 29 DEC 2015 4-9

Filter Criteria
Period Start The user-selected start date for the search criteria.
Period End The user-selected end date for the search criteria.
Link Select the name from the link.
Report Fields
Link The name of the link.
Denom The denomination of the game assigned to the cabinet, in dollars.
Date The day and date when the jackpot was hit.
Coin In The coin-in amount in dollars.
SMI Number The SMI number of the game assigned to the cabinet.
Cabinet Total The total coin-in amount of the cabinet.
Link Total The total coin-in amount of all the cabinets in the link.
4 - 10 29 DEC 2015 CONFIDENTIAL Daily Accumulation Report

Daily Performance Report

The user can filter the report data by Period Start, and Period End.
Following is an example of the Daily Performance report.
Daily Performance Report CONFIDENTIAL 29 DEC 2015 4 - 11

Filter Criteria
Period Start The user-selected start date for the search criteria.
Period End The user-selected end date for the search criteria.
Report Fields
Game The game number assigned to the cabinet.
Days The number of days the game was played.
AVG Bet The AVG bet amount in dollars.
Games The total number of games.
Coin In The coin-in amount in dollars.
Game PPM The game PPM amount.
Utilization (%) The utilization based on one game for a maximum of 3 seconds.
Grand Total The total of all the games, and coin-in amount respectively.
4 - 12 29 DEC 2015 CONFIDENTIAL Daily Performance Report

Event Log Report

The user can filter the report data by Period Start, Period End, Cabinet ID, and Event Type.
Following is an example of the Event Log report.
Event Log Report CONFIDENTIAL 29 DEC 2015 4 - 13

Filter Criteria
Period Start The user-selected start date and time for the search criteria.
Period End The user-selected end date and time for the search criteria.
Cabinet ID Select All Cabinets or a particular cabinet from the list.
Event Type Select All Event Types or a particular event from the list.
Report Fields
Event Date The event day, date, and time.
Event The type of event.
EGM ID The EGM identification number.
Cabinet ID The serial number of the cabinet.
Award The award amount in dollars.
Jackpot Id The identification number of the jackpot.
Bet Meter The bet meter amount.
4 - 14 29 DEC 2015 CONFIDENTIAL Event Log Report

Exception Log Report

The user can filter the report data by Period Start, Period End, Cabinet ID, and Exception Type.
Following is an example of the Exception Log report.
Exception Log Report CONFIDENTIAL 29 DEC 2015 4 - 15

Filter Criteria
Cabinet ID Select All Cabinets or a particular cabinet from the list.
Exception Type Select All Exception Types or a particular exception from the list.
Report Fields
Exception Date The date and time of the exception.
Exception The type of exception.
EGM ID The identification number of the EGM.
Cabinet ID The identification number of the cabinet.
4 - 16 29 DEC 2015 CONFIDENTIAL Exception Log Report

Link Information Report

The user can view the information about all the links.
Following is an example of the Link Information report.
Link Information Report CONFIDENTIAL 29 DEC 2015 4 - 17

Report Fields
Start Date The day, date, and time of the event.
Current Amount The current amount of the level in dollars.
Reset The reset amount of the level in dollars.
Reserve The reserve amount of the level in dollars.
HR (%) The Hidden Rate for the level.
PR (%) The Progressive Rate for the level.
Break Threshold The break threshold amount of the level in dollars.
BR (%) The Break Rate for the level.
Link Total The sum total of all the levels of all the respective fields in the link.
4 - 18 29 DEC 2015 CONFIDENTIAL Link Information Report

Machine Bet Status Report

The user can view the status of bets for 7 days prior to the selected date.
Following is an example of the Machine Bet Status report.
Machine Bet Status Report CONFIDENTIAL 29 DEC 2015 4 - 19

GRAND TOTAL The total of all the bets of all the cabinets for 7 days prior to the current date
Report Fields
SMI Number The SMI number or name of the game assigned to the cabinet.
EGM ID The identification number of the EGM.
First Bet Date The date of the first bet.
<Day/Month/Year> The bet amount in dollars for the day.
Total Bet The total of all the bets of the cabinet for 7 days prior to the current date.
Total The total of all the bets of all the cabinets for 7 days prior to the current date
respectively.
4 - 20 29 DEC 2015 CONFIDENTIAL Machine Bet Status Report

Machine Information Report

Following is an example of the Machine Information report.
Report Fields
Machine Information Report CONFIDENTIAL 29 DEC 2015 4 - 21

GP # The game number assigned to the cabinet.
Max Coin The maximum number of coins assigned to the cabinet.
SMINumber The SMI number of the game.
E-Id The identification number of the EGM.
Link Name The name of the link.
Setup Date The machine setup date.
Machine-Bet Details
G-Id The game Id number.
Bet Total The total bet amount of the cabinet, in dollars.
GP# The game number assigned to the cabinet.
Machine-Award Details
GP# The game number assigned to the cabinet.
Awarded Total The total of all the awards of the cabinet, in dollars.
Total number of Awards The total number of awards of the cabinet.
Total The total of all the awards in dollars, and total number of awards of all the cabinets
respectively.
4 - 22 29 DEC 2015 CONFIDENTIAL Machine Information Report

Manual Adjustments Report

The user can view the manual adjustments, manual jackpots, and jackpot rollback information.
Following is an example of the Manual Adjustments report.
Report Fields
Manual Adjustments
Level Id The level number of the link for which the manual adjustment was made.
Manual Adjustments Report CONFIDENTIAL 29 DEC 2015 4 - 23

Jackpot Id The jackpot Id number.
Previous The previous amount before the manual adjustments, in dollars.
Adjusted Amount The adjusted amount in dollars.
Adjusted Hidden The hidden adjustment amount in dollars.
Event Date Time The event day, date and time.
Total The total adjusted amount and adjusted hidden amount of all the levels
respectively, in dollars.
Manual Jackpots
Jackpot Id The jackpot Id number for which the jackpot was adjusted manually.
Award Amount The award amount in dollars.
Event Date Time The event day, date, and time.
Total The total of the award amount for all the jackpots adjusted manually, in dollars.
Jackpot Roll Back
Jackpot Id The jackpot Id number for which the jackpot was rolled back.
Award Amount The award amount in dollars.
Event Date Time The event day, date, and time.
Total The total of the award amount for all the jackpots rolled back, in dollars.
Invalid Bets - Displays bets that have failed sanity.
EGM The identification number of EGM.
Bet Amount The bet amount in dollars.
Event Date Time The date and time when the event had taken place.
4 - 24 29 DEC 2015 CONFIDENTIAL Manual Adjustments Report

System Release Report

The user can view the system release information.
Following is an example of the System Release report.
Report Fields
System Components The name of the system component.
Version The version number of the system component.
System Release Report CONFIDENTIAL 29 DEC 2015 4 - 25

User Activity Log Report

The user can filter the report data by Period Start, Period End, Activity Type, User Name, Entity, and
Entity Name.
4 - 26 29 DEC 2015 CONFIDENTIAL User Activity Log Report

Following is an example of the User Activity Log report.

User Activity Log Report CONFIDENTIAL 29 DEC 2015 4 - 27

Filter Criteria
Activity Type Select All Activity Types or a particular activity from the list.
User Name Select All Users or a particular user from the list.
Entity Select All or a particular entity from the list.
Entity Name Select All or a particular entity name from the list.
Report Fields
User Name The user-selected user name.
Activity Type The user-selected activity type.
Date Time The date and time of the activity.
Entity The user-selected entity type.
Entity Name The user-selected entity name.
Description The description of the activity.
4 - 28 29 DEC 2015 CONFIDENTIAL User Activity Log Report

Chapter A
Appendix
Game Theme Conversion and Maintenance Instructions for BLL

The following instructions will assist Field Service Technicians in completing a game theme conversion
and other maintenance for the Bally Local Link (BLL).
BLL Game Theme Conversion

Follow these steps for BLL Game Theme Conversion.
STEP 1. Verify that all cabinets undergoing a game theme conversion are disabled and powered off.
STEP 2. Log on to the BLL Manager, click Configure Cabinets and Delete the cabinet.
STEP 3. Restart the GMM.
STEP 4. Complete a RAM Clear and configure each cabinet with a new game theme.
STEP 5. Verify that each cabinet is configured correctly in the BLL UI, complete a coin test (if possible),
and verify that the jackpot amounts increment correctly.
Completing a RAM Clear

Follow theses steps to perform a RAM Clear.
STEP 1. Verify that all cabinets undergoing a RAM Clear are disabled and powered off.
STEP 3. Complete a RAM Clear and configure options for each cabinet.
CONFIDENTIAL 29 DEC 2015 A-1

Chapter A: Appendix BLL 4.0 User Interface Guide
STEP 4. Verify that each cabinet is configured correctly, complete a coin test (if possible), and verify
that the jackpot amounts increment correctly.
Replacing the GMM

Follow these steps to replace the GMM.
STEP 1. Verify that all cabinets attached to the GMM undergoing replacement are disabled and
powered off.
STEP 2. Power off the GMM.
STEP 3. Replace the GMM, power on each cabinet and then power on the new GMM.
STEP 4. Verify that each cabinet is configured correctly, complete a coin test (if possible), and verify
that the jackpot amounts increment correctly.
NOTE: Do not change the BLL progressive controller’s IP address. It must remain static.
Verifying a Cabinet that reported Zero Max Coin

Follow these steps to verify a Cabinet that reported Zero Max Coin.
STEP 1. Log on to the BLL Manager UI and verify if the cabinet reported Zero Max Coin. Refer
Application Login on page 1-4.
STEP 2. Click Configure Games and manually create a game theme with correct Max Coin
amount.The Max Coin amount can be viewed from the View Games screen. Refer Adding a
Game on page 2-58 and Viewing Game Details on page 2-64.
STEP 3. Click Configure Cabinets and assign the manually created game theme to the cabinet.
STEP 4. Assign a link and wait for the cabinet to come to playable state. Refer Assigning a Game and a
Link to an existing Cabinet on page 2-72.
STEP 5. Complete a coin test (if possible) and verify if the jackpot amounts increment correctly.
A-2 29 DEC 2015 CONFIDENTIAL Game Theme Conversion and Maintenance Instruc-
BLL 4.0 User Interface Guide Chapter A: Appendix
Assigning a link to a Cabinet or Re-assigning a Cabinet with a new link

Follow these steps to assign a link to a cabinet or re-assign a cabinet with a new link.
STEP 1. Assign a link to the cabinet or re-assign a cabinet with a new link. Refer Assigning a Game and
a Link to an existing Cabinet on page 2-72.
STEP 3. Complete a coin test (if possible) and verify if the jackpot amounts increment correctly.
List of Progressive System Error Conditions

Following are the list of progressive error conditions:
• Progressive Link Unavailable
• Client Rejected Progressive Configuration
• HandleMessage - Malformed Message
• GMM key not found
• An error occurred while processing message for EGM
• Error getting the Links, LSS is not functional
• Link Server cannot access the DB. Retrying in 30 seconds
Game Theme Conversion and Maintenance Instructions for BLLCONFIDENTIAL 29 DEC 2015 A-3
Chapter A: Appendix BLL 4.0 User Interface Guide
A-4 29 DEC 2015 CONFIDENTIAL Game Theme Conversion and Maintenance Instruc-

BLL UI User Guide

Uploaded by

Document Information

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

BLL UI User Guide

Uploaded by

Copyright:

Available Formats

BLL 4.

Bally Local Link

Scientific Games Corporation

ii CONFIDENTIAL 29 DEC 2015

Chapter 1: BLL Overview

Chapter 2: Configuring Links, Cabinets, and Games

CONFIDENTIAL 29 DEC 2015 i

Deleting a Progressive Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 21

Chapter 3: Managing Jackpots, Links, and Sites

ii 29 DEC 2015 CONFIDENTIAL

Exception Log Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 15

CONFIDENTIAL 29 DEC 2015 iii

CONFIDENTIAL 29 DEC 2015 1-1

1-2 29 DEC 2015 CONFIDENTIAL Overview

BLL Application Workflow

BLL Application Workflow CONFIDENTIAL 29 DEC 2015 1-3

STEP 4. Click Login. The BLL Manager application appears.

1-4 29 DEC 2015 CONFIDENTIAL Application Login

BLL Manager Application

BLL Manager Application CONFIDENTIAL 29 DEC 2015 1-5

Click to view the user guide for the BLL application.

Click Yes to exit, else click No.

1-6 29 DEC 2015 CONFIDENTIAL BLL Manager Application

Following are the options:

BLL Manager Application CONFIDENTIAL 29 DEC 2015 1-7

1-8 29 DEC 2015 CONFIDENTIAL BLL Manager Application

Followings are the reports:

BLL Manager Application CONFIDENTIAL 29 DEC 2015 1-9

The footer displays:

Clicking the icon will not exit the BLL Manager.

1 - 10 29 DEC 2015 CONFIDENTIAL BLL Manager Application

CONFIDENTIAL 29 DEC 2015 2-1

Field Name Description

SiteName The name of the BLL site.

BankName The name of the bank.

BLL MAC Address The MAC address of the BLL system.

BLL IP Address The IP address of the BLL system.

2-2 29 DEC 2015 CONFIDENTIAL Configuring Settings

STEP 3. Click Save. The following information is displayed.

STEP 4. Click OK. The configuration settings values are saved.

Configuring Settings CONFIDENTIAL 29 DEC 2015 2-3

Viewing the Configuration Settings

2-4 29 DEC 2015 CONFIDENTIAL Configuring Settings

Configuring Progressive Link Levels

About Links CONFIDENTIAL 29 DEC 2015 2-5

2-6 29 DEC 2015 CONFIDENTIAL Configuring Progressive Link Levels

Adding a Progressive Link Level

Configuring Progressive Link Levels CONFIDENTIAL 29 DEC 2015 2-7

STEP 2. Enter the following details.

Field Name Description

Reset Amount The base amount of the progressive.

STEP 3. Click Back to go back to the main screen.

STEP 5. Click OK. The progressive link levels are saved.

2-8 29 DEC 2015 CONFIDENTIAL Configuring Progressive Link Levels

Editing a Progressive Link Level

STEP 3. Click OK.The progressive link levels are updated.

Configuring Progressive Link Levels CONFIDENTIAL 29 DEC 2015 2-9

Viewing a Progressive Link Level

2 - 10 29 DEC 2015 CONFIDENTIAL Configuring Progressive Link Levels

Deleting a Progressive Link Level

Configuring Progressive Link Levels CONFIDENTIAL 29 DEC 2015 2 - 11

2 - 12 29 DEC 2015 CONFIDENTIAL Configuring Progressive Link Levels

Configuring Progressive Links

Configuring Progressive Links CONFIDENTIAL 29 DEC 2015 2 - 13
