Single Package

Cooling Only R410A(60Hz)

6CUK0-01A

P/No. : MFL67452912
Single Package
Introduction
Preface
Thank you very much for your special patronage of LG air conditioners.

LG’s "Roof Top or Single Package" is an ideal choice when we talk about high load applications.
As the name Roof Top signifies, this unit is generally installed on the top of the roof. Also the Single Package signifies that
both condenser and evaporator are enclosed in a single body(same as window type). The unit is used along with ducts and
has flexible air flow as per installation conditions. The air flow can be horizontal or vertically downward which offers wider
flexibility in the field applications.

This unit is ideal for Single story and Double story houses as they offer high static pressure.
With its easy installation and simple control system, this product is suitable for Factories, Shopping malls, Multiplex, Hotels
etc.

A lot of information regarding the design & installation of this system is provided in this edition. This new product series con-
tains data on the same pattern.
Please utilize all the information for conducting your business efficiently.
Make sure the specification, dimensions and other technical data are same as provided in enginering data book before you
start the project.

We look forward to your continuing support.

LG Electronics Inc.
 Single Package

1. Model line up
2. Nomenclature
3. Features & Benefits
4. List of functions
5. Specifications
6. Dimensions
7. Roof Curbs
8. Wiring diagrams
9. Capacity tables
10. Fan Performance data
11. Electric Characteristics
12. Piping diagrams
13. Operation range
14. Controller
15. Appendix
Single Package
1. Model line up
n 1 Series

Power Supply Model Name

(V, Ø, Hz) 20 RT 25 RT
400, 3, 60 AK-Q2409C01 AK-Q3009C01

R410A _ 1
 Single Package
2. Nomenclature
AK-Q300 9C01

Development Sequence

SEER Grade
There is no SEER regulation for these units
10~25RT
so "0" is allotted to these units.

Type of Flow
H: Horizontal, C: Convertible

Electric Standard (Volts, Phase, Freq.)

8 : 380-415 V, 3 Ø, 50 Hz
9 : 400 V, 3 Ø, 60 Hz
D : 460 V, 3 Ø, 60 Hz
B : 220 V, 3 Ø, 60 Hz

Cooling capacity grade

Ex) 300 : 300,000 Btu/h

Model Type
Q : Inverter Cooling Only

Type of Air Conditioner

AK : LG Single Package Air Conditioner, R410A

2 _ R410A
Single Package
3. Features & Benefits
n 20 / 25RT

Front View

Air outlet vents

Return

Drain Hole

Motor Access Panel

Supply

Rear View

Air outlet
vents

Control
access panel

Compressor
access panel

Air intake vents

R410A _ 3
 Single Package
3. Features & Benefits
n Eco-friendly leadership

n Higher Energy Efficiency

• LG BLDC Inverter Compressor
• BLDC Inverter Fan Motor
• Newly designed propeller fan
• Wide Louver Fin in Heat Exchanger

n High Reliability & Comfort

• Enhanced Logic
• Emergency back up operation & Alternate-Cycling
• Auto Restart Operation
• Soft Start Function
• Automatic emergency back-up operation
• Night silent operation
• Pressure & Temperature Control

n Easy Maintenance & Service

• Automatic test run
• Additional functions available with duct system

Higher Energy Efficiency

LG BLDC Inverter compressor

- Improved the energy efficiency by 11%, compared to the AC inverter compressor, by using the high efficiency
LG BLDC inverter compressor.
We have developed a new compressor with better performance, higher efficiency, and a more enhanced relia-
bility than the conventional compressors.
For the motor, which is the core of the compressor, the product uses a BLDC motor.
The BLDC motor is a highly efficient motor, where strong Nd magnetism inside the rotor produces magnetic
torque and the metal part of the rotor produces reluctance torque to generate strong rotational force.
Efficiency is improved because it has no slip loss, which always occurs in the normal induction motor, and
noise is also reduced due to its low torque ripple design.
In addition, because the LG BLDC inverter compressor has the back pressure structure in which the interior of
the compressor is maintained at a high pressure, the compression efficiency is improved.
The compressor is also a high pressure type that makes oil lubrication smoother. Compared to the conven-
tional models, the LG BLDC inverter compressor has more improved performance and reliability.

4 _ R410A
Single Package
3. Features & Benefits
BLDC Inverter Fan Motor
- BLDC inverter fan motor reduced to motor energy consumption power 35% and improved to motor output 75%
The product is equipped with highly efficient BLDC motor.
The BLDC motor power consumption has been reduced and output has been improved, compared to the nor-
mal induction motor. With strong torque and powerful Neodymium magnet inside the rotor, the BLDC motor
provides large air volume and high static pressure.

Newly designed propeller fan

- The Super Aero fan is a large air volume and high static pressure fan, and at the same time it produces low
levels of noise.
To provide our customers with high cooling and heating performance at a minimum size, and as well as a
pleasant environment ensured by quiet operation,
LG inverter single package uses various low noise technologies.
It has minimized operation noise by using a compressor with BLDC motors, low noise fan motors, new sound-
proof technology, outdoor fans, and a newly developed shroud shape.

Wide Louver Fin in Heat Exchanger

- Fin Efficiency improvement by 14% Change heat exchange shape.
Improved efficiency by using wide louver fins with an increased thermal transfer area.
LG’s patented chloride-induced corrosion resistant Gold-fin has low corrosion and erosion rates and high
hydrophilicity.
Its performance will not be affected even in a humid area.
The exchangers of our outdoor unit are treated against corrosion and pollution.
This treatment guarantees the durability of the systems and high-level performance.

R410A _ 5
 Single Package
3. Features & Benefits
More Reliability

Emergency back up operation & Alternate-Cycling

- Minimizing any inconvenience that may occur in an emergency situation
• For emergency, it makes back up operation possible before trouble-shooting
• Error notice in indoor unit : 4 times per day (every 6hour)
• To extend compressors life span by operating them alternately
• To meet diverse load in operation

Auto Restart Operation :

- Whenever there is electricity failure the system shuts off and resumption of the power, unit will start in the
same mode as prior to the power failure.
Memorized condition are on / off condition, operating mode (cooling), set temperature and fan speed.

Soft Start Function:

- All single package air conditioners has soft start function i.e.
Indoor fan, outdoor fan & compressor start in sequence to prevent overcurrent during starting.

Automatic emergency back-up operation

- Minimizing any inconvenience that may occur in an emergency situation. For emergency, it makes back-up
operation possible before trouble-shooting. Error notice in indoor unit : 4 time per day (every 6hour)

Night silent operation

- It is possible to operate air-conditioner silently by V-scroll compressor, Fan control technology and real-time
sensing the outdoor temperature. The night silent operation function can save the running cost 55%.

Pressure & Temperature Control

- Conventional temperature control sensed temperature and calculated target pressure based on in/ outdoor
temperature, desired temperature, etc. It was hard to respond to target load quickly.
To control the cycle, pressure sensor is added to the conventional temperature control to enable elaborate
control to Improve reliability with stabilized system and quick and proper response.

6 _ R410A
Single Package
3. Features & Benefits
More Convenience

Fast Cooling Operation

- With PI control logic, the set temperature is achieved more quickly and also the air conditioning efficiency is
improved by 30% , It provides not only quick but powerful air conditioning operation.

Cooling & Fan Operation :

- LG air conditioners can provide cooling & fan operation. In the cooling mode, it cools the air with an operation
range of -5~56°C. In the fan operation mode, only indoor fan at the selected speed will run, outdoor fan and
compressor will be off.

Real time smart operation

- In situations where the cooling load difference is large, if performance of one side is high enough, perfor-
mance of the other side can be overloaded.
To control these situations, the product uses the real-time power saving operation algorithm, which enables
the product to automatically decide on the operation status for the indoor units and automatically control them
to maintain an optimal operation level and reduce power consumption.

Time Delay Relay

- It delays restarting of the compressor by three minutes thereby preventing damage to the compressor

Self Diagnosis Function :

- This function provides diagnosis of the unit.
An error code will be displayed on the LCD wired remote controller & diagnosis can be done as per the code
indication.
The same is also printed on key cover of the LCD wired remote controller.

R410A _ 7
 Single Package
3. Features & Benefits
Easy Installation, Maintenance & Service

- The unit can be installed outside to save valuable indoor space or where no ceiling space is available. Install
the unit on the ground or on the roof. This means that the installation is totally flexible depending on your
requirements.
Since the unit has not been split into two, maintenance is easy, especially because all access panels are on
the same side of the unit and all wiring inside has been color coded.

Automatic test run

- Easy and fast automatic test run by dip switch, help you to save the checking time during the final stage of
installation. If it detects errors, it sends error messages on PC screen.

Additional functions available with duct system

All units come standard in Reverse Cycle, however electric heating can be added (Electric Heating provided by
Specialist Dealers). You have complete control over the fresh air input, amount of air purification and zone
controls (extras provided by Specialist Dealers), all using the powerful LG control system.

Typical Installation

① Roof Jack Installation

② Slab on Ground Installation

8 _ R410A
Single Package
3. Features & Benefits
Controller & Accessories

LCD Wired Remote Control :

- It can control all the functions of the unit. You can check/set temperature, change operation
mode, set timer & also diagnose the error of the unit. It also has the weekly program.

Two Thermistor Control(Return Air Control):(Accessory)

- There may be a significant difference between the return air temperature in the duct and the room tempera-
ture. Return air sensing temperature is designed to control temperature more accurately by applying additional
thermistor which senses the return air temperature inside the duct specially.
After selecting the duct thermistor, which is connected to the main PCB, the room temperature measurement
by LCD wired remote control thermistor is neglected. It helps to control the room temperature more accurate-
ly.(Thermistor is a field-installed accessory)
1 2 ........ 16
Group Control :(Accessory)
- It enables to control max of 16 units with the help of one
wired remote controller. All the units will follow same set-
ting of temperature & other sub functions.

........

V net :(Accessory)
- LG V-Net supports to interlock with all LG commercial air conditioner.
In addition, LG V-Net can extend central control to BMS Interface (LonWork / BACnet) as well.

R410A _ 9
 Single Package
3. Features & Benefits
Child Lock Function :
- It prevents the children or others from tampering with the control
buttons.
Press button repeatedly until the is flashing.
If moving to 'setup' icon area by using button, 'setup' icon
blinks, and child lock function is setup if pressing button at
that time.
When cancelling lock function, if moving to 'cancel' icon by
pressing button and then, pressing button, child lock
function is cancelled. Press button to exit.
h After setup, it automatically gets out of setup mode if there is
no button input for 25 seconds.
h When exiting without pressing set button, the manipulated
value is not reflected.

Main" M" M" M" M" M" M"

Central Control :(Accessory) PCB 1 2 16 17 18 128

- It enables to control 16 x 8 = 128 units with the help T/B" T/B" T/B" T/B" T/B" T/B"
1 2 16 17 18 128
of 8 controllers. All units can be put on and off from
one Central Room.For Setting Temperature, Fan
Speed and other sub functions, access the LCD
wired remote controller of each unit. Controller" Controller" Controller"
#1 #2 #8
(T/B: Terminal Block)

Wireless Remote Control:(Accessory)

- It provides ease of control.

Electric Heater:(Accessory)
- Electric Heater can be used to provide heat in addition to cycle
heat. It also provides quick heating. It can also work as a stand
alone heater with only fan operation.

10 _ R410A
Single Package
4. List of functions
n 1 Series
Category Functions AK-Q2409C01 / AK-Q3009C01
Air supply outlet 1
Air flow Airflow steps (fan/cool/heat) 1/1/-
Jet cool/heat X/X
Air purifying Long-life prefilter (washable / anti-fungus) O
E.S.P. control X
Installation
Electric heater LKAEH368L
Hot start X
Self diagnosis O
Soft dry operation X
Defrost / Deicing X
High pressure switch O
Reliability
Low pressure switch X
Phase protection O
Restart delay (3-minutes) O
Soft start O
Test function X
Auto changeover X
Auto operation(artificial intelligence) X
Auto Restart O
Child lock O
Group control PZCWRCG3
Convenience
Sleep mode X
Timer(on/off) O
Timer(weekly) O
Two thermistor control PQRSTA0
Night Silent Operation O
Wired remote controller O
Deluxe wired remote controller X
Individual Simple wired remote controller X
control Simple Wired remote controller(for hotel use) X
Extension wire for Wired remote controller PZCWRC1
Wireless remote controller PQWRCQ0FDB/ PQWRCSF0
General central controller (Non LGAP) X
Network Solution(LGAP) O
Network
Dry contact PQDSBNGCM1
Function
PDI(power distribution indicator) PQNUD1S00
PI 485 X*
Zone controller X
Special
CTI(Communication transfer interface) PKFC0
function kit
Electronic thermostat X

Note :
1. * : This function does not require PI 485 kit, Because it can communicate through RS485 method by itself.
O : Applied X : Not applied
Accessory model name : Installed at field, ordered and purchased separately by the corresponding model name, supplied with separate package.

R410A _ 11
 Single Package
4. List of functions

Device AK-Q2409C01 / AK-Q3009C01

Simple Controller PQCSB101S0
AC Ez PQCSZ250S0
Central AC Smart ll PQCSW320A1E
Controller ACP(Advanced Control Platform) PQCPA11A0E / PQCPB11A0E
AC Manager PQCSS520A0E
DO(Digital Output) Kit PQNFP00T0
BNU (Building LONWORKS Gateway PQNFB16A1
Network Unit) BACnet Gateway PQNFB17B0
ODU Dry Contact X
Low Ambient Kit O (Logical operation)

Note :
O : Applied X : Not applied
Accessory model name : Installed at field, ordered and purchased separately by the corresponding model name, supplied with separate package.

12 _ R410A
Single Package
5. Specifications
n 1 Series
Nominal Capacity RT 20 25
Model Name - AK-Q2409C01 AK-Q3009C01
kW 70.6 80.9
Net Capacity kcal/h 60,700 69,600
Btu/h 241,000 276,000
Cooling Capacity
kW 73.6 85.0
Gross Capacity kcal/h 63,300 73,100
Btu/h 251,000 290,000
EER Btu / Wh 11.2 10.5
Power Input Cooling kW 21.5 26.2
Power Supply V, Ø, Hz 400 , 3 , 60 400 , 3 , 60
Fin Type - LG Louver LG Louver
Tube Size Outer Dia. mm (inch) 9.52 (3/8) 9.52 (3/8)
Indoor Coil
(Row x Column x Fins per inch) x No. - (3 x 26 x 16) x 2 (3 x 26 x 16) x 2
Face Area m2 (ft2 ) 2.18 (23.47) 2.18 (23.47)
Type Sirocco Fan Sirocco Fan
Diameter mm (inch) 457.2 (18) 457.2 (18)
Motor Output Hp 5.0 7.5
Indoor Fan
Nominal m3/min 226.5 283.2
Air Flow Rate
Nominal ft3/min 8,000 10,000
Drive type Belt Belt
Type HSS DC SCROLL HSS DC SCROLL
Compressor Motor Output W x No. 5,300 x 1 5,300 x 1
(#1, A-Circuit) Oil Type FVC68D FVC68D
Oil Charge cc x No. 1,800 x 1 1,800 x 1
Type HSS DC SCROLL HSS DC SCROLL
Compressor Motor Output W x No. 5,300 x 1 5,300 x 1
(#2, B-Circuit) Oil Type FVC68D FVC68D
Oil Charge cc x No. 1,800 x 1 1,800 x 1
Type - -
Motor Output W x No. - -
Compressor (#3)
Oil Type - -
Oil Charge cc x No. - -
Type - -
Motor Output W x No. - -
Compressor (#4)
Oil Type - -
Oil Charge cc x No. - -
Fin Type Wide Louver Plus Wide Louver Plus
Tube Size Outer Dia. mm(inch) 7.0 (9/32) 7.0 (9/32)
Outdoor Coil
(Row x Column x Fins per inch) x No. (2 x 42 x 14) x 4 (2 x 42 x 14) x 4
Face Area m2(ft2) 7.06 (75.99) 7.06 (75.99)
Type Propeller Fan Propeller Fan
Diameter mm(inch) 680 (26-25/32) 680 (26-25/32)
Motor Output W x No. 900 x 4 900 x 4
Outdoor Fan m3/min x No. 105 x 4 105 x 4
Air Flow Rate
ft3/min x No. 3,700 x 4 3,700 x 4
Drive BLDC Inverter BLDC Inverter
Discharge Direction Top Top
Dehumidification rate ℓ/h 26.18 29.82
Drain Connection Size Male NPT 1 Male NPT 1
Refigerant name R410A R410A
Precharged A-Circuit kg 12.0 12.0
Refigerant
Amount B-Circuit kg 12.0 12.0
Control Electronic Expansion Valve Electronic Expansion Valve
mm 2,230 x 1,242 x 3,520 2,230 x 1,242 x 3,520
Dimensions (W*H*D)
inch 87-25/32 x 48-29/32 x 138-19/32 87-25/32 x 48-29/32 x 138-19/32
Net Weight kg(lbs) 950 (2,094) 950 (2,094)
Sound pressure levels Cooling dB(A) 85 85
Operation Range (Outdoor Temperature) Cooling Min. ~ Max. ℃ DB (℉ DB) -5 ~ 54(23.0 ~ 129.2) -5 ~ 54(23.0 ~ 129.2)
Note :
1. All data are based on the following conditions: 4. Sound Level Values are measured at Anechoic chamber.
- Indoor 26.7°C(80°F) DB / 19.4°C(67°F) WB Its back ground noise is 55dB(A).
- Outdoor 35°C(95°F) DB / 23.9℃(75℉) WB Therefore, these values can be increased owing to ambient conditions dur-
2. Wiring cable size must comply with the applicable local and national code. ing opration.
3. Due to our policy of innovation some specifications may be changed with- 5. EER : Energy Efficiency Ratio
out notification.

R410A _ 13
 Single Package
6. Dimensions
n 20 / 25RT
Single packaged cooling unit are designed for outdoor mounting with vertical condenser discharge. They can be located
either at ground level or on roof.
Each unit contains an operating charge of Refrigerant as shipped.

[Unit : mm (inch)]
Product Dimensions (Figure 1A) CLEARANCE 860mm
CLEARANCE 1160mm

Tool 20 / 25 RT
A 1,242 (48-29/32)
B 2,230 (87-25/32)
C 3,520 (138-19/32)
D 1,911 (75-1/4) A

C Drain Hole

CLEARANCE 1160mm D CLEARANCE 860mm

Horizontal Flow Application (Figure 1B) Figure 1A

Tool 20 / 25 RT CLEARANCE 860mm

CLEARANCE 1160mm
A 616 (24-1/4)
B 678 (26-11/16)
C 655 (25-25/32)
Panel Enclosure
D 60 (2-3/8) 1 Inch Male (NPT)

E 125 (4-29/32)
75mm (3 inch) 75mm (3 inch)

F
minimum

Static pressure
F 882 (34-23/32) Drain Pan
E
minimum

G 115 (4-17/32) Cleanout D

Plug C
H 860 (33-27/32) H B

CLEARANCE 1160mm A
G
CLEARANCE 860mm

Figure 1B

Down Flow Application (Figure 1C) A B C D

G
E

Tool 20 / 25 RT
A 655 (25-25/32)
F

SUPPLY
RETURN
H

B 457 (18)
C 616 (24-1/4)
D 196 (7-23/32)
E 116 (4-9/16)
F 882 (34-23/32)
G 116 (4-9/16)
H 860 (33-27/32)

TOP VIEW
Figure 1C

14 _ R410A
Single Package
6. Dimensions

Weights

n 1 Series
Maximum Weights [kg (lb)] Center of Gravity [mm (inch)]
Model Name
Shipping Net A B
AK-Q2409C01
AK-Q3009C01
980 (2,161) 950 (2,094) 995 (39) 1,786 (70)

RETURN SUPPLY

CENTER OF GRAVITY TOP VIEW

Note: 1. Corner weights are given for information only.

2. Weights are approximate.

R410A _ 15
 Single Package
7. Roof Curbs
n 20 / 25RT

[Unit : mm (inch)]

Note: ① Roof Curb – Galvanized steel

② Remove the Fork Guides for Roof Curb installation

16 _ R410A
Single Package
8. Wiring diagrams
Model : AK-Q2409C01 / AK-Q3009C01 [Master]

R410A _ 17
 Single Package
8. Wiring diagrams
Model : AK-Q2409C01 / AK-Q3009C01 [Slave]

18 _ R410A
Single Package
9. Capacity tables

20RT AK-Q2409C01 (SI)

Outdoor DB(°C) 27.5 35.0
Indoor WB(°C) 16.1 19.4 22.8 16.1 19.4 22.8
l/s DB(°C) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
23.9 47.7 39.1 5.78 52.7 29.4 5.96 56.7 13.1 6.07 60.9 49.2 19.24 67.3 37.0 19.85 72.4 16.5 20.21
26.7 49.7 44.8 5.80 53.7 37.0 5.98 56.7 24.2 6.09 63.5 56.4 19.30 68.5 46.7 19.91 72.4 30.4 20.27
3022
29.4 51.6 49.1 5.82 54.4 44.3 6.00 56.5 33.5 6.11 65.9 61.9 19.36 69.5 55.8 19.97 72.2 42.2 20.34
32.2 53.3 51.9 5.83 55.0 49.5 6.02 56.2 41.0 6.13 68.1 65.3 19.41 70.3 62.3 20.03 71.8 51.6 20.40
23.9 49.7 43.1 5.83 54.9 32.4 6.02 59.0 14.4 6.13 63.5 54.3 19.41 70.1 40.8 20.02 75.4 18.2 20.39
26.7 51.8 49.4 5.85 55.9 40.8 6.04 59.1 26.6 6.15 66.2 62.2 19.47 71.4 51.4 20.09 75.5 33.6 20.45
3399
29.4 53.8 53.8 5.87 56.7 48.9 6.05 58.9 36.9 6.16 68.7 68.2 19.53 72.4 61.6 20.14 75.2 46.5 20.52
32.2 55.5 55.5 5.89 57.3 54.5 6.07 58.5 45.2 6.18 71.0 71.0 19.59 73.2 68.7 20.20 74.8 56.9 20.58
23.9 51.2 46.9 5.90 56.6 35.3 6.08 60.8 15.7 6.19 65.4 59.1 19.62 72.3 44.4 20.24 77.7 19.8 20.61
26.7 53.4 53.4 5.91 57.6 44.4 6.10 60.8 29.0 6.21 68.2 67.7 19.68 73.6 56.0 20.30 77.7 36.5 20.67
3777
29.4 55.4 55.4 5.93 58.4 53.2 6.12 60.7 40.2 6.23 70.8 70.8 19.74 74.6 67.0 20.36 77.5 50.6 20.74
32.2 57.2 57.2 5.95 59.0 59.0 6.14 60.3 49.2 6.25 73.1 73.1 19.80 75.4 74.7 20.42 77.0 61.9 20.80
23.9 52.1 50.2 5.93 57.6 37.7 6.11 62.0 16.8 6.23 66.6 63.2 19.73 73.6 47.5 20.35 79.2 21.2 20.73
26.7 54.4 54.4 5.95 58.7 47.6 6.13 62.0 31.0 6.25 69.5 69.5 19.79 75.0 59.9 20.41 79.2 39.1 20.79
4155
29.4 56.5 56.5 5.96 59.5 56.9 6.15 61.8 43.0 6.27 72.1 72.1 19.85 76.0 71.7 20.47 79.0 54.2 20.85
32.2 58.3 58.3 5.98 60.2 60.2 6.17 61.5 52.6 6.28 74.5 74.5 19.90 76.9 76.9 20.53 78.5 66.3 20.91
23.9 52.6 52.6 5.96 58.2 40.0 6.15 62.5 17.8 6.26 67.2 67.0 19.84 74.3 50.3 20.46 79.9 22.4 20.84
26.7 54.9 54.9 5.98 59.2 50.4 6.17 62.6 32.9 6.28 70.1 70.1 19.90 75.6 63.4 20.53 79.9 41.4 20.90
4532
29.4 57.0 57.0 6.00 60.1 60.1 6.19 62.4 45.5 6.30 72.8 72.8 19.96 76.7 75.9 20.58 79.7 57.4 20.97
32.2 58.8 58.8 6.01 60.7 60.7 6.20 62.0 55.7 6.32 75.2 75.2 20.01 77.6 77.6 20.65 79.2 70.2 21.03

Outdoor DB(°C) 40.0 46.0 52.0

Indoor WB(°C) 16.1 19.4 22.8 16.1 19.4 22.8 16.1 19.4 22.8
l/s DB(°C) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
23.9 61.6 48.2 25.59 68.1 36.3 26.40 73.2 16.1 26.89 51.6 45.8 21.70 57.1 34.4 22.39 61.3 15.3 22.80 41.3 40.1 19.71 45.7 30.1 20.33 49.1 13.4 20.71
26.7 64.2 55.2 25.67 69.3 45.7 26.48 73.2 29.8 26.97 53.8 52.4 21.77 58.1 43.4 22.46 61.4 28.3 22.87 43.1 43.1 19.77 46.5 38.0 20.40 49.2 24.8 20.77
3022
29.4 66.7 60.6 25.74 70.3 54.7 26.56 73.0 41.3 27.05 55.9 55.9 21.83 58.9 51.9 22.52 61.2 39.2 22.94 44.8 44.8 19.83 47.2 45.4 20.46 49.0 34.3 20.84
32.2 68.8 64.0 25.82 71.0 61.0 26.63 72.6 50.6 27.13 57.7 57.7 21.90 59.6 57.9 22.59 60.8 48.0 23.01 46.2 46.2 19.89 47.7 47.7 20.52 48.7 42.0 20.90
23.9 64.1 53.1 25.82 70.9 40.0 26.63 76.2 17.8 27.12 53.8 50.5 21.90 59.4 38.0 22.59 63.9 16.9 23.01 43.1 43.1 19.89 47.6 33.2 20.52 51.2 14.8 20.90
26.7 66.9 60.9 25.89 72.2 50.4 26.71 76.3 32.9 27.21 56.1 56.1 21.96 60.5 47.8 22.66 63.9 31.2 23.07 44.9 44.9 19.95 48.5 41.9 20.58 51.2 27.3 20.96
3399
29.4 69.4 66.8 25.97 73.2 60.3 26.79 76.0 45.5 27.29 58.2 58.2 22.03 61.4 57.2 22.72 63.8 43.2 23.14 46.6 46.6 20.01 49.2 49.2 20.64 51.1 37.8 21.02
32.2 71.7 70.5 26.05 74.0 67.2 26.87 75.6 55.7 27.37 60.1 60.1 22.09 62.0 62.0 22.79 63.4 52.9 23.21 48.2 48.2 20.07 49.7 49.7 20.70 50.8 46.3 21.08
23.9 66.1 57.8 26.09 73.0 43.5 26.92 78.5 19.4 27.41 55.4 54.9 22.13 61.2 41.3 22.83 65.8 18.4 23.25 44.4 44.4 20.10 49.1 36.1 20.74 52.7 16.1 21.12
26.7 68.9 66.3 26.17 74.4 54.8 27.00 78.6 35.8 27.50 57.8 57.8 22.20 62.3 52.1 22.90 65.9 34.0 23.32 46.3 46.3 20.16 49.9 45.5 20.80 52.8 29.7 21.18
3777
29.4 71.5 71.5 26.25 75.4 65.6 27.08 78.3 49.6 27.58 60.0 60.0 22.26 63.2 62.3 22.97 65.7 47.1 23.39 48.0 48.0 20.22 50.7 50.7 20.86 52.6 41.2 21.25
32.2 73.9 73.9 26.33 76.2 73.2 27.16 77.9 60.6 27.66 61.9 61.9 22.33 63.9 63.9 23.03 65.3 57.6 23.46 49.6 49.6 20.28 51.2 51.2 20.92 52.3 50.4 21.31
23.9 67.3 61.9 26.24 74.4 46.6 27.06 80.0 20.7 27.57 56.4 56.4 22.25 62.4 44.2 22.95 67.1 19.7 23.38 45.2 45.2 20.21 50.0 38.7 20.85 53.7 17.2 21.24
26.7 70.2 70.2 26.32 75.8 58.7 27.15 80.0 38.3 27.65 58.9 58.9 22.32 63.5 55.7 23.03 67.1 36.3 23.45 47.2 47.2 20.27 50.9 48.7 20.91 53.8 31.8 21.30
4155
29.4 72.9 72.9 26.40 76.9 70.2 27.23 79.8 53.0 27.73 61.1 61.1 22.39 64.4 64.4 23.09 66.9 50.4 23.52 49.0 49.0 20.33 51.6 51.6 20.97 53.6 44.1 21.36
32.2 75.3 75.3 26.47 77.7 77.7 27.31 79.3 64.9 27.81 63.1 63.1 22.45 65.1 65.1 23.16 66.5 61.6 23.59 50.6 50.6 20.39 52.2 52.2 21.04 53.3 53.3 21.43
23.9 67.9 65.6 26.38 75.1 49.3 27.21 80.7 21.9 27.72 57.0 57.0 22.38 63.0 46.8 23.08 67.7 20.8 23.51 45.6 45.6 20.32 50.4 41.0 20.97 54.2 18.2 21.35
26.7 70.9 70.9 26.46 76.5 62.1 27.30 80.8 40.5 27.80 59.4 59.4 22.44 64.1 59.0 23.15 67.7 38.5 23.58 47.6 47.6 20.39 51.3 51.3 21.03 54.3 33.7 21.42
4532
29.4 73.5 73.5 26.54 77.6 74.4 27.38 80.6 56.2 27.89 61.7 61.7 22.51 65.0 65.0 23.22 67.5 53.3 23.65 49.4 49.4 20.45 52.1 52.1 21.09 54.1 46.7 21.48
32.2 76.0 76.0 26.62 78.4 78.4 27.46 80.1 68.7 27.97 63.7 63.7 22.58 65.7 65.7 23.29 67.1 65.3 23.72 51.0 51.0 20.51 52.6 52.6 21.15 53.8 53.8 21.55
Notes:
1. All capacities are gross, evaporator fan motor heat is not deducted. 5. SHC = Sensible Heat Capacity(Unit : kW)
To obtain net cooling capacity, subtract evaporator fan motor heat. 6. PI = Power Input(kW), Sum of Compressor & Outdoor Fan Power Input
2. DB = Dry Bulb Temperature(°C), WB = Wet Bulb Temperature(°C) 7. The rated capacity at the outdoor temperature of 27.5 DB is the
3. l/s = Liters per second same as that at IEER B test condition.
4. TGC = Total Gross Cooling Capacity(Unit : kW) The rated capacity at the outdoor temperature of 35.0 DB is the
Net Cooling Capacity = TGC – Fan motor heat same as that at IEER A test condition.
Fan motor heat = 1.28 x BkW (Refer to the Fan performance data)

R410A _ 19
 Single Package
9. Capacity tables

20RT AK-Q2409C01 (English)

Outdoor DB(°F) 81.5 95.0
Indoor WB(°F) 61.0 67.0 73.0 61.0 67.0 73.0
CFM DB(°F) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
75 162.7 133.4 5.78 179.9 100.3 5.96 193.4 44.6 6.07 207.8 168.0 19.24 229.8 126.4 19.85 247.0 56.2 20.21
80 169.7 152.8 5.80 183.1 126.4 5.98 193.5 82.5 6.09 216.8 192.5 19.30 233.9 159.2 19.91 247.1 103.9 20.27
6400
85 176.1 167.6 5.82 185.7 151.3 6.00 192.9 114.3 6.11 225.0 211.1 19.36 237.3 190.6 19.97 246.4 144.0 20.34
90 181.9 177.0 5.83 187.7 168.8 6.02 191.8 139.9 6.13 232.4 223.0 19.41 239.8 212.6 20.03 244.9 176.2 20.40
75 169.5 147.0 5.83 187.4 110.6 6.02 201.5 49.2 6.13 216.5 185.2 19.41 239.4 139.3 20.02 257.3 62.0 20.39
80 176.8 168.4 5.85 190.8 139.3 6.04 201.5 90.9 6.15 225.9 212.1 19.47 243.7 175.5 20.09 257.4 114.5 20.45
7200
85 183.5 183.5 5.87 193.5 166.8 6.05 201.0 126.0 6.16 234.4 232.6 19.53 247.2 210.0 20.14 256.7 158.7 20.52
90 189.5 189.5 5.89 195.6 186.0 6.07 199.8 154.2 6.18 242.1 242.1 19.59 249.8 234.3 20.20 255.2 194.2 20.58
75 174.6 160.0 5.90 193.0 120.3 6.08 207.5 53.6 6.19 223.0 201.6 19.62 246.6 151.6 20.24 265.1 67.5 20.61
80 182.2 182.2 5.91 196.5 151.6 6.10 207.6 98.9 6.21 232.7 230.9 19.68 251.0 191.0 20.30 265.2 124.6 20.67
8000
85 189.0 189.0 5.93 199.3 181.5 6.12 207.0 137.1 6.23 241.5 241.5 19.74 254.6 228.6 20.36 264.5 172.7 20.74
90 195.2 195.2 5.95 201.5 201.5 6.14 205.8 167.8 6.25 249.4 249.4 19.80 257.4 255.0 20.42 262.9 211.3 20.80
75 177.9 171.3 5.93 196.7 128.8 6.11 211.5 57.3 6.23 227.3 215.7 19.73 251.2 162.2 20.35 270.1 72.2 20.73
80 185.6 185.6 5.95 200.2 162.3 6.13 211.6 105.9 6.25 237.1 237.1 19.79 255.8 204.4 20.41 270.2 133.4 20.79
8800
85 192.6 192.6 5.96 203.1 194.2 6.15 211.0 146.7 6.27 246.0 246.0 19.85 259.4 244.7 20.47 269.5 184.9 20.85
90 198.9 198.9 5.98 205.3 205.3 6.17 209.7 179.6 6.28 254.1 254.1 19.90 262.2 262.2 20.53 267.8 226.2 20.91
75 179.5 179.5 5.96 198.5 136.4 6.15 213.4 60.7 6.26 229.3 228.4 19.84 253.5 171.8 20.46 272.6 76.5 20.84
80 187.3 187.3 5.98 202.0 171.9 6.17 213.5 112.1 6.28 239.2 239.2 19.90 258.1 216.5 20.53 272.7 141.2 20.90
9600
85 194.4 194.4 6.00 205.0 205.0 6.19 212.9 155.4 6.30 248.3 248.3 19.96 261.8 259.1 20.58 271.9 195.8 20.97
90 200.8 200.8 6.01 207.2 207.2 6.20 211.6 190.2 6.32 256.4 256.4 20.01 264.6 264.6 20.65 270.3 239.5 21.03

Outdoor DB(°F) 104.0 114.8 125.6

Indoor WB(°F) 61.0 67.0 73.0 61.0 67.0 73.0 61.0 67.0 73.0
CFM DB(°F) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
75 210.1 164.5 25.59 232.2 123.7 26.40 249.7 55.1 26.89 176.1 156.2 21.70 194.7 117.5 22.39 209.3 52.3 22.80 141.1 136.7 19.71 156.0 102.8 20.33 167.7 45.8 20.71
80 219.1 188.4 25.67 236.4 155.9 26.48 249.8 101.7 26.97 183.7 178.9 21.77 198.2 148.0 22.46 209.4 96.6 22.87 147.2 147.2 19.77 158.8 129.6 20.40 167.8 84.5 20.77
6400
85 227.4 206.7 25.74 239.8 186.6 26.56 249.1 141.0 27.05 190.7 190.7 21.83 201.1 177.2 22.52 208.8 133.9 22.94 152.8 152.8 19.83 161.1 155.1 20.46 167.3 117.1 20.84
90 234.9 218.3 25.82 242.4 208.2 26.63 247.6 172.5 27.13 196.9 196.9 21.90 203.2 197.7 22.59 207.6 163.8 23.01 157.8 157.8 19.89 162.8 162.8 20.52 166.3 143.3 20.90
75 218.8 181.3 25.82 241.9 136.4 26.63 260.1 60.7 27.12 183.5 172.2 21.90 202.8 129.5 22.59 218.1 57.6 23.01 147.0 147.0 19.89 162.5 113.3 20.52 174.7 50.4 20.90
80 228.3 207.7 25.89 246.3 171.8 26.71 260.2 112.1 27.21 191.4 191.4 21.96 206.5 163.2 22.66 218.2 106.5 23.07 153.3 153.3 19.95 165.4 142.8 20.58 174.8 93.2 20.96
7200
85 236.9 227.8 25.97 249.8 205.7 26.79 259.5 155.4 27.29 198.6 198.6 22.03 209.5 195.3 22.72 217.6 147.6 23.14 159.1 159.1 20.01 167.8 167.8 20.64 174.3 129.1 21.02
90 244.7 240.7 26.05 252.5 229.4 26.87 257.9 190.1 27.37 205.2 205.2 22.09 211.7 211.7 22.79 216.2 180.6 23.21 164.4 164.4 20.07 169.6 169.6 20.70 173.2 158.0 21.08
75 225.4 197.4 26.09 249.2 148.4 26.92 267.9 66.1 27.41 189.0 187.4 22.13 208.9 140.9 22.83 224.6 62.7 23.25 151.4 151.4 20.10 167.4 123.3 20.74 180.0 54.9 21.12
80 235.2 226.1 26.17 253.7 187.0 27.00 268.1 122.0 27.50 197.2 197.2 22.20 212.7 177.6 22.90 224.7 115.9 23.32 158.0 158.0 20.16 170.4 155.4 20.80 180.0 101.4 21.18
8000
85 244.1 244.1 26.25 257.4 223.8 27.08 267.3 169.1 27.58 204.6 204.6 22.26 215.8 212.6 22.97 224.1 160.6 23.39 163.9 163.9 20.22 172.9 172.9 20.86 179.5 140.5 21.25
90 252.1 252.1 26.33 260.1 249.7 27.16 265.7 206.9 27.66 211.3 211.3 22.33 218.1 218.1 23.03 222.7 196.5 23.46 169.3 169.3 20.28 174.7 174.7 20.92 178.4 172.0 21.31
75 229.7 211.2 26.24 253.9 158.8 27.06 273.0 70.7 27.57 192.6 192.6 22.25 212.9 150.8 22.95 228.9 67.1 23.38 154.3 154.3 20.21 170.6 132.0 20.85 183.4 58.7 21.24
80 239.6 239.6 26.32 258.5 200.2 27.15 273.1 130.6 27.65 200.9 200.9 22.32 216.7 190.1 23.03 229.0 124.0 23.45 161.0 161.0 20.27 173.6 166.3 20.91 183.5 108.5 21.30
8800
85 248.7 248.7 26.40 262.2 239.6 27.23 272.4 181.0 27.73 208.5 208.5 22.39 219.9 219.9 23.09 228.4 171.9 23.52 167.0 167.0 20.33 176.1 176.1 20.97 182.9 150.4 21.36
90 256.9 256.9 26.47 265.1 265.1 27.31 270.7 221.5 27.81 215.3 215.3 22.45 222.2 222.2 23.16 227.0 210.3 23.59 172.5 172.5 20.39 178.0 178.0 21.04 181.8 181.8 21.43
75 231.8 223.7 26.38 256.2 168.2 27.21 275.5 74.9 27.72 194.3 194.3 22.38 214.8 159.7 23.08 231.0 71.1 23.51 155.7 155.7 20.32 172.1 139.8 20.97 185.0 62.2 21.35
80 241.8 241.8 26.46 260.9 212.0 27.30 275.6 138.3 27.80 202.7 202.7 22.44 218.7 201.3 23.15 231.1 131.3 23.58 162.4 162.4 20.39 175.2 175.2 21.03 185.1 114.9 21.42
9600
85 251.0 251.0 26.54 264.6 253.7 27.38 274.8 191.7 27.89 210.4 210.4 22.51 221.9 221.9 23.22 230.4 182.0 23.65 168.6 168.6 20.45 177.7 177.7 21.09 184.6 159.3 21.48
90 259.2 259.2 26.62 267.5 267.5 27.46 273.2 234.5 27.97 217.3 217.3 22.58 224.2 224.2 23.29 229.0 222.7 23.72 174.1 174.1 20.51 179.6 179.6 21.15 183.5 183.5 21.55

Notes:
1. All capacities are gross, evaporator fan motor heat is not deducted. 5. SHC = Sensible Heat Capacity(Unit : kW)
To obtain net cooling capacity, subtract evaporator fan motor heat. 6. PI = Power Input(kW), Sum of Compressor & Outdoor Fan Power Input
2. DB = Dry Bulb Temperature(°C), WB = Wet Bulb Temperature(°C) 7. The rated capacity at the outdoor temperature of 27.5 DB is the
3. l/s = Liters per second same as that at IEER B test condition.
4. TGC = Total Gross Cooling Capacity(Unit : kW) The rated capacity at the outdoor temperature of 35.0 DB is the
Net Cooling Capacity = TGC – Fan motor heat same as that at IEER A test condition.
Fan motor heat = 3.1 x BHP (Refer to the Fan performance data)

20 _ R410A
Single Package
9. Capacity tables

25RT AK-Q3009C01 (SI)

Outdoor DB(°C) 27.5 35.0
Indoor WB(°C) 16.1 19.4 22.8 16.1 19.4 22.8
l/s DB(°C) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
23.9 55.1 46.6 7.39 60.9 35.0 7.63 65.5 15.6 7.77 70.4 58.6 24.55 77.8 44.1 25.32 83.6 19.6 25.79
26.7 57.5 53.3 7.41 62.0 44.1 7.65 65.5 28.8 7.79 73.4 67.1 24.62 79.2 55.5 25.40 83.7 36.2 25.87
3776 29.4 59.7 58.5 7.44 62.9 52.8 7.67 65.3 39.9 7.81 76.2 73.6 24.69 80.3 66.5 25.47 83.4 50.2 25.95
32.2 61.6 61.6 7.46 63.6 58.9 7.69 64.9 48.8 7.84 78.7 77.8 24.77 81.2 74.2 25.55 82.9 61.5 26.02
23.9 57.4 51.3 7.46 63.5 38.6 7.69 68.2 17.2 7.84 73.3 64.6 24.77 81.0 48.6 25.55 87.1 21.6 26.02
26.7 59.9 58.8 7.48 64.6 48.6 7.72 68.3 31.7 7.86 76.5 74.0 24.84 82.5 61.2 25.63 87.2 39.9 26.10
4248
29.4 62.2 62.2 7.50 65.5 58.2 7.74 68.1 44.0 7.88 79.4 79.4 24.91 83.7 73.3 25.70 86.9 55.4 26.18
32.2 64.2 64.2 7.53 66.2 64.9 7.76 67.7 53.8 7.91 82.0 82.0 24.99 84.6 81.8 25.78 86.4 67.7 26.25
23.9 59.1 55.8 7.54 65.4 42.0 7.78 70.3 18.7 7.92 75.5 70.3 25.03 83.5 52.9 25.82 89.8 23.5 26.30
26.7 61.7 61.7 7.56 66.6 52.9 7.80 70.3 34.5 7.94 78.8 78.8 25.11 85.0 66.6 25.90 89.8 43.5 26.38
4720
29.4 64.0 64.0 7.58 67.5 63.3 7.82 70.1 47.9 7.97 81.8 81.8 25.18 86.2 79.8 25.97 89.5 60.3 26.46
32.2 66.1 66.1 7.61 68.2 68.2 7.85 69.7 58.6 7.99 84.4 84.4 25.26 87.1 87.1 26.05 89.0 73.7 26.53
23.9 60.3 59.8 7.58 66.6 45.0 7.82 71.6 20.0 7.96 77.0 75.3 25.17 85.1 56.6 25.96 91.5 25.2 26.44
26.7 62.9 62.9 7.60 67.8 56.6 7.84 71.7 37.0 7.99 80.3 80.3 25.24 86.6 71.3 26.04 91.5 46.5 26.52
5192
29.4 65.2 65.2 7.63 68.8 67.8 7.87 71.5 51.2 8.01 83.3 83.3 25.32 87.9 85.4 26.12 91.2 64.5 26.60
32.2 67.4 67.4 7.65 69.5 69.5 7.89 71.0 62.7 8.04 86.0 86.0 25.40 88.8 88.8 26.20 90.7 78.9 26.68
23.9 60.8 60.8 7.62 67.2 47.6 7.86 72.3 21.2 8.01 77.7 77.7 25.31 85.8 59.9 26.11 92.3 26.7 26.59
26.7 63.4 63.4 7.64 68.4 60.0 7.89 72.3 39.1 8.03 81.0 81.0 25.38 87.4 75.5 26.19 92.3 49.3 26.67
5664 65.8 65.8 7.67 69.4 69.4 7.91 72.1 54.2 8.06 84.1 84.1 25.46 88.6 88.6 26.26 92.1 68.3 26.75
29.4
32.2 68.0 68.0 7.69 70.2 70.2 7.93 71.7 66.4 8.08 86.8 86.8 25.54 89.6 89.6 26.34 91.5 83.6 26.83

Outdoor DB(°C) 40.0 46.0 52.0

Indoor WB(°C) 16.1 19.4 22.8 16.1 19.4 22.8 16.1 19.4 22.8
l/s DB(°C) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
23.9 71.5 53.8 29.95 79.0 40.4 30.89 85.0 18.0 31.47 60.9 53.5 25.40 67.4 40.2 26.20 72.4 17.9 26.69 44.2 43.0 26.35 48.9 32.3 27.18 52.6 14.4 27.68
26.7 74.6 61.6 30.04 80.5 51.0 30.99 85.0 33.2 31.56 63.6 61.2 25.48 68.6 50.7 26.28 72.5 33.1 26.77 46.2 46.2 26.43 49.8 40.7 27.26 52.6 26.6 27.77
3776
29.4 77.4 67.6 30.13 81.6 61.0 31.08 84.8 46.1 31.65 66.0 66.0 25.55 69.6 60.6 26.36 72.3 45.8 26.85 47.9 47.9 26.51 50.5 48.8 27.34 52.5 36.8 27.85
32.2 79.9 71.4 30.22 82.5 68.0 31.17 84.3 56.4 31.75 68.1 68.1 25.63 70.3 67.7 26.44 71.8 56.1 26.93 49.5 49.5 26.59 51.0 51.0 27.42 52.1 45.1 27.93
23.9 74.5 59.3 30.22 82.3 44.6 31.17 88.5 19.8 31.75 63.5 58.9 25.63 70.2 44.3 26.43 75.4 19.7 26.92 46.1 46.1 26.58 50.9 35.6 27.42 54.8 15.9 27.93
26.7 77.7 67.9 30.31 83.8 56.2 31.27 88.6 36.6 31.84 66.2 66.2 25.70 71.4 55.8 26.52 75.5 36.4 27.00 48.1 48.1 26.66 51.9 44.9 27.51 54.8 29.3 28.01
4248
29.4 80.6 74.5 30.40 85.0 67.2 31.36 88.3 50.8 31.94 68.7 68.7 25.78 72.5 66.8 26.59 75.3 50.5 27.09 49.9 49.9 26.74 52.6 52.6 27.58 54.6 40.6 28.10
32.2 83.3 78.7 30.49 85.9 75.0 31.45 87.8 62.2 32.03 71.0 71.0 25.86 73.2 73.2 26.67 74.8 61.8 27.17 51.5 51.5 26.82 53.2 53.2 27.67 54.3 49.7 28.18
23.9 76.7 64.5 30.54 84.8 48.5 31.50 91.2 21.6 32.09 65.4 64.1 25.90 72.3 48.2 26.72 77.7 21.5 27.21 47.5 47.5 26.87 52.5 38.8 27.71 56.4 17.3 28.23
26.7 80.0 73.9 30.63 86.3 61.1 31.60 91.2 39.9 32.18 68.2 68.2 25.98 73.6 60.8 26.80 77.8 39.7 27.29 49.5 49.5 26.95 53.4 48.9 27.80 56.5 31.9 28.31
4720
29.4 83.1 81.0 30.72 87.6 73.2 31.69 91.0 55.3 32.28 70.8 70.8 26.06 74.7 72.8 26.88 77.5 55.0 27.38 51.4 51.4 27.03 54.2 54.2 27.88 56.3 44.2 28.40
32.2 85.8 85.6 30.81 88.5 81.6 31.79 90.4 67.6 32.37 73.1 73.1 26.13 75.5 75.5 26.96 77.1 67.3 27.46 53.1 53.1 27.11 54.8 54.8 27.96 56.0 54.1 28.48
23.9 78.2 69.0 30.71 86.4 51.9 31.68 92.9 23.1 32.26 66.6 66.6 26.04 73.7 51.6 26.86 79.2 23.0 27.36 48.4 48.4 27.01 53.5 41.5 27.87 57.5 18.5 28.38
26.7 81.6 79.1 30.80 88.0 65.4 31.77 93.0 42.7 32.36 69.5 69.5 26.12 75.0 65.1 26.95 79.2 42.4 27.44 50.5 50.5 27.10 54.4 52.3 27.95 57.5 34.1 28.47
5192
29.4 84.6 84.6 30.89 89.2 78.3 31.87 92.7 59.2 32.46 72.1 72.1 26.20 76.1 76.1 27.03 79.0 58.8 27.53 52.4 52.4 27.18 55.2 55.2 28.03 57.4 47.3 28.55
32.2 87.4 87.4 30.98 90.2 87.4 31.96 92.1 72.4 32.55 74.5 74.5 26.28 76.9 76.9 27.11 78.5 72.0 27.61 54.1 54.1 27.26 55.8 55.8 28.12 57.0 57.0 28.64
23.9 78.9 73.1 30.88 87.2 55.0 31.85 93.8 24.5 32.44 67.2 67.2 26.19 74.3 54.7 27.01 79.9 24.3 27.51 48.8 48.8 27.16 54.0 44.0 28.02 58.0 19.6 28.54
26.7 82.3 82.3 30.97 88.8 69.3 31.95 93.8 45.2 32.54 70.1 70.1 26.27 75.7 68.9 27.10 79.9 44.9 27.60 50.9 50.9 27.25 54.9 54.9 28.11 58.0 36.1 28.63
5664
29.4 85.4 85.4 31.06 90.1 82.9 32.04 93.5 62.7 32.64 72.8 72.8 26.34 76.8 76.8 27.18 79.7 62.3 27.68 52.8 52.8 27.33 55.7 55.7 28.19 57.9 50.1 28.71
32.2 88.2 88.2 31.16 91.0 91.0 32.14 93.0 76.7 32.73 75.2 75.2 26.42 77.6 77.6 27.26 79.2 76.2 27.76 54.6 54.6 27.41 56.3 56.3 28.27 57.5 57.5 28.80
Notes:
1. All capacities are gross, evaporator fan motor heat is not deducted. 5. SHC = Sensible Heat Capacity(Unit : kW)
To obtain net cooling capacity, subtract evaporator fan motor heat. 6. PI = Power Input(kW), Sum of Compressor & Outdoor Fan Power Input
2. DB = Dry Bulb Temperature(°C), WB = Wet Bulb Temperature(°C) 7. The rated capacity at the outdoor temperature of 27.5 DB is the
3. l/s = Liters per second same as that at IEER B test condition.
4. TGC = Total Gross Cooling Capacity(Unit : kW) The rated capacity at the outdoor temperature of 35.0 DB is the
Net Cooling Capacity = TGC – Fan motor heat same as that at IEER A test condition.
Fan motor heat = 1.28 x BkW (Refer to the Fan performance data)

R410A _ 21
 Single Package
9. Capacity tables

25RT AK-Q3009C01 (English)

Outdoor DB(°F) 81.5 95.0
Indoor WB(°F) 61.0 67.0 73.0 61.0 67.0 73.0
CFM DB(°F) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
75 188.0 158.8 7.39 207.9 119.5 7.63 223.5 53.2 7.77 240.1 200.0 24.55 265.5 150.4 25.32 285.4 66.9 25.79
80 196.2 182.0 7.41 211.6 150.5 7.65 223.6 98.2 7.79 250.5 229.1 24.62 270.2 189.5 25.40 285.5 123.7 25.87
8000
85 203.6 199.5 7.44 214.7 180.2 7.67 223.0 136.1 7.81 260.0 251.3 24.69 274.1 226.9 25.47 284.7 171.4 25.95
90 210.3 210.3 7.46 217.0 201.0 7.69 221.6 166.6 7.84 268.5 265.4 24.77 277.1 253.1 25.55 283.0 209.7 26.02
75 195.9 175.1 7.46 216.6 131.7 7.69 232.8 58.6 7.84 250.1 220.5 24.77 276.5 165.8 25.55 297.3 73.8 26.02
80 204.4 200.6 7.48 220.5 165.9 7.72 232.9 108.3 7.86 261.0 252.5 24.84 281.5 208.9 25.63 297.5 136.3 26.10
9000
85 212.1 212.1 7.50 223.6 198.6 7.74 232.3 150.0 7.88 270.8 270.8 24.91 285.6 250.1 25.70 296.6 188.9 26.18
90 219.0 219.0 7.53 226.0 221.5 7.76 230.9 183.6 7.91 279.7 279.7 24.99 288.6 279.0 25.78 294.8 231.2 26.25
75 201.8 190.6 7.54 223.1 143.3 7.78 239.8 63.8 7.92 257.7 240.0 25.03 284.9 180.5 25.82 306.3 80.3 26.30
80 210.5 210.5 7.56 227.1 180.6 7.80 240.0 117.8 7.94 268.8 268.8 25.11 290.0 227.4 25.90 306.4 148.4 26.38
10000
85 218.5 218.5 7.58 230.4 216.1 7.82 239.3 163.3 7.97 279.0 279.0 25.18 294.2 272.2 25.97 305.6 205.6 26.46
90 225.6 225.6 7.61 232.8 232.8 7.85 237.8 199.8 7.99 288.1 288.1 25.26 297.3 297.3 26.05 303.7 251.6 26.53
75 205.6 204.0 7.58 227.3 153.4 7.82 244.4 68.3 7.96 262.6 256.8 25.17 290.3 193.1 25.96 312.1 86.0 26.44
80 214.5 214.5 7.60 231.4 193.3 7.84 244.5 126.1 7.99 273.9 273.9 25.24 295.5 243.4 26.04 312.2 158.8 26.52
11000
85 222.6 222.6 7.63 234.7 231.3 7.87 243.8 174.8 8.01 284.3 284.3 25.32 299.8 291.3 26.12 311.3 220.1 26.60
90 229.9 229.9 7.65 237.3 237.3 7.89 242.3 213.8 8.04 293.6 293.6 25.40 303.0 303.0 26.20 309.5 269.3 26.68
75 207.5 207.5 7.62 229.4 162.4 7.86 246.6 72.3 8.01 265.0 265.0 25.31 292.9 204.5 26.11 314.9 91.0 26.59
80 216.5 216.5 7.64 233.5 204.7 7.89 246.7 133.5 8.03 276.4 276.4 25.38 298.2 257.7 26.19 315.1 168.1 26.67
12000
85 224.6 224.6 7.67 236.9 236.9 7.91 246.0 185.1 8.06 286.9 286.9 25.46 302.5 302.5 26.26 314.2 233.0 26.75
90 232.0 232.0 7.69 239.4 239.4 7.93 244.5 226.5 8.08 296.3 296.3 25.54 305.7 305.7 26.34 312.3 285.1 26.83

Outdoor DB(°F) 104.0 114.8 125.6

Indoor WB(°F) 61.0 67.0 73.0 61.0 67.0 73.0 61.0 67.0 73.0
CFM DB(°F) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
75 243.9 183.5 29.95 269.7 138.0 30.89 289.9 61.4 31.47 207.9 182.4 25.40 229.8 137.2 26.20 247.1 61.1 26.69 150.9 146.7 26.35 166.9 110.3 27.18 179.4 49.1 27.68
80 254.5 210.2 30.04 274.5 173.9 30.99 290.0 113.5 31.56 216.9 209.0 25.48 234.0 172.9 26.28 247.2 112.8 26.77 157.5 157.5 26.43 169.9 139.0 27.26 179.5 90.7 27.77
8000
85 264.1 230.5 30.13 278.5 208.1 31.08 289.2 157.2 31.65 225.1 225.1 25.55 237.4 206.9 26.36 246.5 156.3 26.85 163.4 163.4 26.51 172.3 166.4 27.34 179.0 125.7 27.85
90 272.8 243.5 30.22 281.5 232.2 31.17 287.5 192.4 31.75 232.5 232.5 25.63 239.9 230.8 26.44 245.0 191.3 26.93 168.8 168.8 26.59 174.2 174.2 27.42 177.9 153.8 27.93
75 254.1 202.3 30.22 280.9 152.1 31.17 302.0 67.7 31.75 216.6 201.1 25.63 239.4 151.2 26.43 257.4 67.3 26.92 157.2 157.2 26.58 173.8 121.6 27.42 186.9 54.1 27.93
80 265.1 231.7 30.31 286.0 191.7 31.27 302.2 125.1 31.84 226.0 226.0 25.70 243.8 190.6 26.52 257.6 124.3 27.00 164.0 164.0 26.66 177.0 153.2 27.51 187.0 100.0 28.01
9000
85 275.1 254.1 30.40 290.1 229.4 31.36 301.3 173.3 31.94 234.5 234.5 25.78 247.3 228.1 26.59 256.8 172.3 27.09 170.2 170.2 26.74 179.5 179.5 27.58 186.5 138.5 28.10
90 284.2 268.4 30.49 293.2 255.9 31.45 299.5 212.1 32.03 242.2 242.2 25.86 249.9 249.9 26.67 255.3 210.8 27.17 175.8 175.8 26.82 181.4 181.4 27.67 185.3 169.5 28.18
75 261.8 220.1 30.54 289.4 165.5 31.50 311.1 73.7 32.09 223.1 218.9 25.90 246.7 164.6 26.72 265.2 73.3 27.21 162.0 162.0 26.87 179.1 132.3 27.71 192.5 58.9 28.23
80 273.1 252.2 30.63 294.6 208.6 31.60 311.3 136.1 32.18 232.8 232.8 25.98 251.1 207.4 26.80 265.3 135.3 27.29 169.0 169.0 26.95 182.3 166.7 27.80 192.6 108.8 28.31
10000
85 283.4 276.5 30.72 298.8 249.7 31.69 310.4 188.6 32.28 241.6 241.6 26.06 254.7 248.2 26.88 264.6 187.5 27.38 175.4 175.4 27.03 184.9 184.9 27.88 192.1 150.8 28.40
90 292.7 292.2 30.81 302.1 278.5 31.79 308.5 230.8 32.37 249.5 249.5 26.13 257.5 257.5 26.96 263.0 229.5 27.46 181.1 181.1 27.11 186.9 186.9 27.96 190.9 184.5 28.48
75 266.7 235.6 30.71 294.9 177.2 31.68 317.0 78.9 32.26 227.3 227.3 26.04 251.3 176.2 26.86 270.2 78.4 27.36 165.1 165.1 27.01 182.5 141.6 27.87 196.2 63.0 28.38
80 278.3 269.9 30.80 300.2 223.3 31.77 317.2 145.7 32.36 237.2 237.2 26.12 255.9 222.0 26.95 270.3 144.8 27.44 172.2 172.2 27.10 185.8 178.5 27.95 196.3 116.4 28.47
11000
85 288.8 288.8 30.89 304.5 267.2 31.87 316.3 201.9 32.46 246.1 246.1 26.20 259.5 259.5 27.03 269.6 200.7 27.53 178.7 178.7 27.18 188.4 188.4 28.03 195.7 161.4 28.55
90 298.3 298.3 30.98 307.8 298.1 31.96 314.4 247.0 32.55 254.2 254.2 26.28 262.3 262.3 27.11 267.9 245.6 27.61 184.6 184.6 27.26 190.5 190.5 28.12 194.5 194.5 28.64
75 269.2 249.5 30.88 297.6 187.6 31.85 319.9 83.5 32.44 229.4 229.4 26.19 253.6 186.5 27.01 272.7 83.0 27.51 166.6 166.6 27.16 184.1 150.0 28.02 198.0 66.7 28.54
80 280.8 280.8 30.97 302.9 236.4 31.95 320.1 154.3 32.54 239.3 239.3 26.27 258.2 235.1 27.10 272.8 153.4 27.60 173.8 173.8 27.25 187.4 187.4 28.11 198.1 123.3 28.63
12000
85 291.4 291.4 31.06 307.3 283.0 32.04 319.2 213.8 32.64 248.4 248.4 26.34 261.9 261.9 27.18 272.0 212.6 27.68 180.3 180.3 27.33 190.1 190.1 28.19 197.5 170.9 28.71
90 301.0 301.0 31.16 310.6 310.6 32.14 317.2 261.6 32.73 256.5 256.5 26.42 264.7 264.7 27.26 270.4 260.1 27.76 186.2 186.2 27.41 192.2 192.2 28.27 196.3 196.3 28.80

Notes:
1. All capacities are gross, evaporator fan motor heat is not deducted. 5. SHC = Sensible Heat Capacity(Unit : kW)
To obtain net cooling capacity, subtract evaporator fan motor heat. 6. PI = Power Input(kW), Sum of Compressor & Outdoor Fan Power Input
2. DB = Dry Bulb Temperature(°C), WB = Wet Bulb Temperature(°C) 7. The rated capacity at the outdoor temperature of 27.5 DB is the
3. l/s = Liters per second same as that at IEER B test condition.
4. TGC = Total Gross Cooling Capacity(Unit : kW) The rated capacity at the outdoor temperature of 35.0 DB is the
Net Cooling Capacity = TGC – Fan motor heat same as that at IEER A test condition.
Fan motor heat = 3.1 x BHP (Refer to the Fan performance data)

22 _ R410A
Single Package
10. Fan Performance data

Evaporator Fan Performance Data AK-Q2409C01 (SI)

External Static Pressure(mmAq.)
l/s 2.54 5.08 7.62 10.16 12.70 15.24 17.78 20.32 22.86 25.40
RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW
3,021 - - - - 526 2.30 539 2.45 553 2.61 569 2.77 586 2.92 604 3.08 624 3.24 645 3.39
3,398 517 2.17 525 2.33 536 2.49 548 2.64 562 2.80 578 2.96 595 3.11 614 3.27 634 3.43 654 3.58
3,776 529 2.40 537 2.56 547 2.71 560 2.87 574 3.03 590 3.18 607 3.34 626 3.50 645 3.65 666 3.81
4,154 543 2.66 551 2.82 562 2.97 575 3.13 589 3.29 605 3.44 622 3.60 640 3.76 660 3.91 681 4.07
4,531 560 2.96 569 3.12 579 3.27 592 3.43 606 3.59 622 3.74 639 3.90 658 4.06 677 4.21 698 4.37

External Static Pressure(mmAq.)

l/s 27.94 30.48 33.02 35.56 38.10 40.64 43.18 45.72 48.26 50.80
RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW
3,021 667 3.55 690 3.71 713 3.86 738 4.02 764 4.17 791 4.33 818 4.49 846 4.64 875 4.80 905 4.96
3,398 676 3.74 699 3.90 723 4.05 748 4.21 773 4.36 800 4.52 827 4.68 856 4.83 885 4.99 914 5.15
3,776 688 3.97 711 4.12 735 4.28 760 4.43 785 4.59 812 4.75 839 4.90 868 5.06 897 5.22 926 5.37
4,154 703 4.23 726 4.38 749 4.54 774 4.69 800 4.85 826 5.01 854 5.16 882 5.32 911 5.48 941 5.63
4,531 720 4.53 743 4.68 767 4.84 792 4.99 817 5.15 844 5.30 871 5.46 899 5.62 - - - -

• Test condition : 5HP Standard Motor & Standard Drive

① Voltage : 220V 7.5HP Oversized Motor & Drive
② Operating Mode : Fan operation mode with clean filter, dry coil without electric heater. 7.5HP Oversized Motor & High Static Drive

Evaporator Fan Performance Data AK-Q2409C01 (English)

External Static Pressure(in.Aq.)
CFM 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
6,400 507 2.66 515 2.87 526 3.08 539 3.29 553 3.50 569 3.71 586 3.92 604 4.13 624 4.34 645 4.55
7,200 517 2.92 525 3.13 536 3.34 548 3.55 562 3.76 578 3.97 595 4.18 614 4.39 634 4.60 654 4.81
8,000 529 3.22 537 3.43 547 3.64 560 3.85 574 4.06 590 4.27 607 4.48 626 4.69 645 4.90 666 5.11
8,800 543 3.57 551 3.78 562 3.99 575 4.20 589 4.41 605 4.62 622 4.83 640 5.04 660 5.25 681 5.46
9,600 560 3.97 569 4.18 579 4.39 592 4.60 606 4.81 622 5.02 639 5.23 658 5.44 677 5.65 698 5.86

External Static Pressure(in.Aq.)

CFM 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
6,400 667 4.76 690 4.97 713 5.18 738 5.39 764 5.60 791 5.81 818 6.02 846 6.23 875 6.44 905 6.65
7,200 676 5.02 699 5.22 723 5.43 748 5.64 773 5.85 800 6.06 827 6.27 856 6.48 885 6.69 914 6.90
8,000 688 5.32 711 5.53 735 5.73 760 5.94 785 6.15 812 6.36 839 6.57 868 6.78 897 6.99 926 7.20
8,800 703 5.67 726 5.88 749 6.08 774 6.29 800 6.50 826 6.71 854 6.92 882 7.13 911 7.34 941 7.55
9,600 720 6.07 743 6.28 767 6.48 792 6.69 817 6.90 844 7.11 871 7.32 899 7.53 - - - -
• Test condition : 5HP Standard Motor & Standard Drive
① Voltage : 400V,60Hz 7.5HP Oversized Motor & Drive
② Operating Mode : Fan operation mode with clean filter, dry coil without electric heater. 7.5HP Oversized Motor & High Static Drive

Fan speed Data AK-Q2409C01

Fan speed Data (RPM)
Fixed Pulley Variable Pulley Turn open V-Belt
Spec. O.D(mm) P.D(mm) 0 Turn 1 Turn 2 Turn 3 Turn 4 Turn 5 Turn 6 Turn NO.
Standard 508 497 736 701 666 631 596 561 526 B-85
Oversized Motor & Drive 432 421 869 827 786 745 703 662 621 B-78
Oversized Motor & High 381 370 988 941 894 847 800 753 706 B-74
• Factory set at 3 turns open.
• Oversized Motor & Drive are field supplied Accessory.

R410A _ 23
 Single Package
10. Fan Performance data

Evaporator Fan Performance Data AK-Q3009C01 (SI)

External Static Pressure(mmAq.)
l/s 2.54 5.08 7.62 10.16 12.70 15.24 17.78 20.32 22.86 25.40
RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW
3,776 529 2.40 537 2.55 547 2.71 560 2.87 574 3.02 590 3.18 607 3.34 626 3.49 645 3.65 666 3.81
4,248 547 2.73 555 2.88 566 3.04 579 3.20 593 3.35 609 3.51 626 3.67 644 3.82 664 3.98 685 4.14
4,720 570 3.12 579 3.28 589 3.43 602 3.59 616 3.75 632 3.90 649 4.06 668 4.22 687 4.37 708 4.53
5,192 599 3.58 607 3.73 618 3.89 630 4.05 644 4.20 660 4.36 677 4.51 696 4.67 716 4.83 736 4.98
5,664 633 4.10 641 4.25 652 4.41 664 4.57 678 4.72 694 4.88 711 5.04 730 5.19 750 5.35 770 5.51

External Static Pressure(mmAq.)

l/s 27.94 30.48 33.02 35.56 38.10 40.64 43.18 45.72 48.26 50.80
RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW RPM BkW
3,776 688 3.96 711 4.12 735 4.28 760 4.43 785 4.59 812 4.75 839 4.90 868 5.06 897 5.22 926 5.37
4,248 707 4.29 730 4.45 753 4.61 778 4.76 804 4.92 830 5.08 858 5.23 886 5.39 915 5.55 945 5.70
4,720 730 4.69 753 4.84 777 5.00 801 5.16 827 5.31 854 5.47 881 5.63 - - - - - -
5,192 758 5.14 781 5.30 805 5.45 830 5.61 - - - - - - - - - - - -
5,664 792 5.66 - - - - - - - - - - - - - - - - - -
• Test condition : 7.5HP Standard Motor & Low static Drive
① Voltage : 220V, 60Hz 7.5HP Standard Motor & Standard Drive
② Operating Mode : Fan operation mode with clean filter, dry coil without electric heater. 7.5HP Standard Motor & High static Drive

Evaporator Fan Performance Data AK-Q3009C01 (English)

External Static Pressure(in.Aq.)
CFM 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
8,000 529 3.21 537 3.42 547 3.63 560 3.84 574 4.05 590 4.26 607 4.47 626 4.68 645 4.89 666 5.10
9,000 547 3.66 555 3.87 566 4.08 579 4.29 593 4.50 609 4.71 626 4.92 644 5.13 664 5.34 685 5.55
10,000 570 4.18 579 4.39 589 4.60 602 4.81 616 5.02 632 5.23 649 5.44 668 5.65 687 5.86 708 6.07
11,000 599 4.79 607 5.00 618 5.21 630 5.42 644 5.63 660 5.84 677 6.05 696 6.26 716 6.47 736 6.68
12,000 633 5.49 641 5.70 652 5.91 664 6.12 678 6.33 694 6.54 711 6.75 730 6.96 750 7.17 770 7.38

External Static Pressure(in.Aq.)

CFM 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
8,000 688 5.31 711 5.52 735 5.73 760 5.94 785 6.15 812 6.36 839 6.57 868 6.78 897 6.99 926 7.20
9,000 707 5.76 730 5.97 753 6.18 778 6.39 804 6.60 830 6.81 858 7.02 886 7.23 915 7.44 945 7.65
10,000 730 6.28 753 6.49 777 6.70 801 6.91 827 7.12 854 7.33 881 7.54 - - - - - -
11,000 758 6.89 781 7.10 805 7.31 830 7.52 - - - - - - - - - - - -
12,000 792 7.59 - - - - - - - - - - - - - - - - - -
• Test condition : 7.5HP Standard Motor & Low static Drive
① Voltage : 400V, 60Hz 7.5HP Standard Motor & Standard Drive
② Operating Mode : Fan operation mode with clean filter, dry coil without electric heater. 7.5HP Standard Motor & High static Drive

Fan speed Data AK-Q3009C01

Fan speed Data (RPM)
Fixed Pulley Variable Pulley Turn open V-Belt
Spec. O.D(mm) P.D(mm) 0 Turn 1 Turn 2 Turn 3 Turn 4 Turn 5 Turn 6 Turn NO.
Low Static 559 548 667 636 604 572 540 509 477 B-88
Standard 457 446 820 781 742 703 664 625 586 B-81
High Static 368 357 1024 976 927 878 829 781 732 B-73
• Factory set at 3 turns open.
• Oversized Motor & Drive are field supplied Accessory.

24 _ R410A
Single Package
11. Electric Characteristics

Accessory Static Pressure Drops

Electric heater
Air Flow Standard filter Panel filter (2inch)
Model 9kW 18kW 36kW
CFM l/s in.Aq. mmAq. in.Aq. mmAq. in.Aq. mmAq. in.Aq. mmAq. in.Aq. mmAq.
6,400 3,020 0.035 0.89 0.094 2.39 - - - - 0.05 1.27
AK-Q2409C01 8,000 3,775 0.052 1.32 0.125 3.17 - - - - 0.09 2.29
9,600 4,530 0.069 1.75 0.151 3.83 - - - - 0.14 3.56
8,000 3,775 0.068 1.73 0.113 2.87 - - - - 0.07 1.78
AK-Q3009C01
10,000 4,720 0.084 2.13 0.142 3.61 - - - - 0.13 3.30
12,000 5,663 0.098 2.49 0.165 4.19 - - - - 0.17 4.32

Electric Heating Capacity

Total Stage 1 Stage 2
Model No. of Stages
Input(kW) Output(MBH) Input(kW) Output(MBH) Input(kW) Output(MBH)
AK-Q2409C01
36 122.86 2 18 61.43 18 61.43
AK-Q3009C01

< Correction Coefficient>

Note:
1. The output ratings shown above is at 240V. Voltage Capacity Multiplier
For other voltage, Output = Capacity Multiplier x Rated Output 208 0.75
2. Electric Heater Voltage range is 208-240V. 220 0.84
230 0.92
240 1.00
380 0.84
400 0.92
415 1.00

Air Temperature Rise Across Electric Heater(°F)

Model Stage 9kW 18kW 36kW
AK-Q2409C01
2 - - 14.2
(8,000CFM)
AK-Q3009C01
2 - - 11.4
(10,000CFM)

(kW x 3413)
• Temp. Rise across Electric Heater =
(1.08 x CFM)
• If you want to take temp rise at different airflow use above equation.

R410A _ 25
 Single Package
11. Electric Characteristics

Electrical Data Unit Wiring - Cooling

Standard indoor fan motor Oversized indoor fan motor

Model
MCA MOP MFA MCA MOP MFA
AK-Q2409C01 106.7 174.7 150 110.0 178.0 150
AK-Q3009C01 110.0 178.0 150 - - -

① MCA : Minimum Circuit Amperes

MCA = (1.25 x Ampere of largest motor) + Load2 + Load3 + Load4.
② MOP : Maximum Over-current Protective Device
MOP = (2.25 x Ampere of largest motor) + Load2 + Load3 + Load4.
③ MFA: Maximum Fuse Amperes(A)
MFA is used to select the circuit breaker and ground fault circuit interrupter (earth leakage circuit breaker)

Electrical Data Unit Wiring with Electric Heating

Standard indoor fan motor Oversized indoor fan motor
Heater Heater
Model
Model No. Capacity(kW) MCA MOP MFA MCA MOP MFA

AK-Q2409C01 LKAEH368L 36 77.2 90 90 82.4 90 90

AK-Q3009C01 LKAEH368L 36 82.4 100 100 - - -
① MCA : Minimum Circuit Amperes
MCA = (1.25 x Ampere of largest motor) + Load2 + Load3 + Load4.
② MOP : Maximum Over-current Protective Device
MOP = (2.25 x Ampere of largest motor) + Load2 + Load3 + Load4.
③ MFA: Maximum Fuse Amperes(A)
MFA is used to select the circuit breaker and ground fault circuit interrupter (earth leakage circuit breaker)

Electrical Characteristics Indoor Fan Motor

Standard indoor fan motor Oversized indoor fan motor

Model
No. Phase HP FLA LRA No. Phase HP FLA LRA
AK-Q2409C01 1 3 5.0 7.7 80.0 1 3 7.5 11.0 81.0
AK-Q3009C01 1 3 7.5 11 81.0 - - - - -
① FLA : Full Load Amperes (A)
② LRA : Locked Rotor Amperes (A)

Electrical Characteristics Compressor and Outdoor Fan Motor

Compressor (INV) Outdoor Fan Motor

Model
No. Phase HP FLA No. Phase HP FLA
AK-Q2409C01 2 3 10 34.0 4 3 1.21 4.0
AK-Q3009C01 2 3 10 34.0 4 3 1.21 4.0

① FLA : Full Load Amperes (A)

② LRA : Locked Rotor Amperes (A)

26 _ R410A
Single Package
12. Piping diagrams
n 20 / 25RT
Hot Gas Valve
S

High Pressure High Pressure Low Pressure Sensor

Switch Sensor

Suction
Outdoor Temperature
Temperature Sensor
Sensor

Accumulator
Comp Discharge
Temperature
Sensor
M

Inverter
Comp

Indoor HEX
EEV M

EEV
EEV

EEV

Indoor HEX
Hot Gas Valve
S

High Pressure High Pressure Low Pressure Sensor

Switch Sensor
M
Suction
Temperature
Sensor

Outdoor
Temperature Comp Discharge
Accumulator

Sensor Temperature
Sensor

Inverter
Comp

S
Pressure Sensor Temperature Sensor Hot Gas valve

Pressure Switch EEV Strainer

Remarks

M Motor + Fan Motor + Fan Distributor

M
(Propeller Fan) (Sirocco Fan)

R410A _ 27
 Single Package
13. Operation range
n 1 Series

SI Unit English Unit

60 140

54 129.2

50 122

40 104
Outdoor Temperature (℃ DB)

Outdoor Temperature (℉ DB)

30 86
Continuous Cotinuous
Operation Operation
20 68

10 50

0 32

-5 23

-10 14

-20 -4
5 10 15 16 20 23 25 28 41 50 59 61 68 73 77 82.4
Indoor Temperature (℃ WB) Indoor Temperature (℉ WB)

• Without low ambient kit, unit can be operated when outdoor temperature goes down to -5ºC.

28 _ R410A
Single Package
14. Controller
1) LCD wired remote controller

1 OPERATION INDICATION SCREEN

1 2 SET TEMPERATURE BUTTON

10
9
2
3 FAN SPEED BUTTON
8
3
7
4 4 ON/OFF BUTTON
11
12 5
13 5 OPERATION MODE SELECTION BUTTON
6
14 6 WIRELESS REMOTE CONTROLLER RECEIVER
15
7 AIR FLOW BUTTON

8 SUB FUNCTION BUTTON

9 FUNCTION SETTING BUTTON

Please attach the inform label inside of the door. 10 VENTILATION BUTTON
Please choose proper language depend on your
country.
11 RESERVATION

12 UP, DOWN, LEFT, RIGHT BUTTON

• To check the indoor temperature, press button.

13 ROOM TEMPERATURE BUTTON

14 SETTING/CANCEL BUTTON

15 EXIT BUTTON

R410A _ 29
 Single Package
15. Appendix

Unit Conversion

Cooling Capacity

RT Btu/h kcal/h W

1 12,000 3024.2 3516.7

Volume

CMM CFM l/s

1 35.3 16.67

Length

m cm mm inch

1 100 1000 39.37

Power

HP W kW

1 746 0.746

Temperature

C = 5 (F - 32)
9
Where,
C is Temperature in °C
F is Temperature in °F

30 _ R410A
 P/No.: MFL67452912

Air Conditioner
20 Yeouido-dong, Yeongdeungpo-gu,
Yeouido P.O.Box 335 Seoul,
150-721, Korea.
http://www.lgeaircon.com

All rights reserved

Printed in Korea September / 2015 The air conditioners manufactured by LG have received ISO9001 certificate for quality assurance and
The specifications, designs, and ISO14001 certificate for environmental management system.
information in this brochure are subject to
change without notice.
