 Assembly Language Lab # 2
Data Transfer & Arithmetic (1)
Objective:
To be familiar with Assembly Language

Introduction:
1. Data Transfer

 MOV Instruction
Move from source to destination.

Note that : No more than one memory operand permitted , the registers CS, EIP, and
IP cannot be the destination and No immediate to segment moves

Syntax:

MOV destination,source

 MOVZX
When you copy a smaller value into a larger destination, the MOVZX instruction fills
(extends) the upper half of the destination with zeros.

Syntax:

MOVZX destination,source
  MOVSX
The MOVSX instruction fills the upper half of the destination with a copy of the
source operand's sign bit.

Syntax:

MOVSX destination,source

 XCHG Instruction
XCHG exchanges the values of two operands. At least one operand must be a register.
No immediate operands are permitted.

2. Arithmetic( Adding and Subtracting Numbers)

 INC destination

destination  destination + 1

Add 1 from destination operand ,operand may be register or memory

 DEC destination

destination  destination – 1

subtract 1 from destination operand ,operand may be register or memory

 ADD instruction
Previous labs have already used the ADD instruction. The form of the ADD
instruction is:
ADD destination, source ;dest operand = dest operand + source operand

The destination operand can be a register or in memory. The source operand can be a
register, in memory or immediate.
Flags:
ZF = 1 iff dest + src = 0
SF = 1 iff dest + src < 0
CF = 1 iff dest + src generated carry out of most significant bit
OF = 1 iff dest + src resulted in signed overflow
AF = 1 iff when an operation produces a carry out from bit 3 to bit 4
PF = 1 iff an instruction generates an even number of 1 bits in the low byte of the
destination operand.
  SUB instruction

SUB dest, source ;dest = dest – source

Flags:
ZF = 1 iff dest - src = 0
SF = 1 iff dest - src < 0
CF = 1 iff required a borrow at most-significant-bit
OF = 1 iff resulted in signed overflow
AF = 1 iff resulted in borrow into the low-ordered four bit of 8-,16-, or 32-bit
operands
PF = 1 iff an instruction generates an even number of 1 bits in the low byte of the
destination operand.

 NEG (negate) Instruction

Reverses the sign of an operand. Operand can be a register or memory operand.

Lab work:
Excercise1:
Use the following variables with attached assembly code to initialize ebx to the value
1234ABEFh
var1 = 12345678h
var2 = 0ABCDh
var3 = 0EFh

Note :Use MASM assembler

 Assemble file
Debugg File

Excericse2:
Repeat the previous exercise without using the equal sign directive. Define the three
variable using data definition statements.
Exercise3:
Exchange the content of the following variables
Var1 dw 1000h
Var2 dw 2000h

1. Open new File called lab23

2. Assemble it
2
3. Linking it
.
4.Execute it .

5.Debug it .
Var1 and Var2 in Data Segment before exchanging :

Var1 Exchanging Operation

Var2
doesn't executed yet

Var1 and Var2 in Data Segment after exchanging :

Var1 Var2
Exercise4:
print the following output on the command window
*
**
***
****
*****
Debugger :

Offset msg1

Offset msg2

Offset msg3

Offset msg4

Offset msg5

Exercise5:
Write a code to increment the odd elements in the array numbers and decrement the
even elements on the same array
Numbers 1, 2, 3, 4
Debugger :

numbers array

Data Segment after code execution :

Exercise6:
Debug the following code to find which flags will be after each instructions from
these flags (CF, ZF, OF, SF)

mov ax,7FFOh
add al,1Oh
add ah,1
add ax,2

Excericse7:
Write an assembly code that perform the following addition
val1= (-Al+ Bl) - va12.
Consider the following intialization
val1 db ??
val2 db 23
mov al,17
mov bl,29
H.W1:
Write an assembly code to put the byte array Vowels in the double word array
New_Vowels in the opposite direction
Vowels db a,e,i,o,u
New_Vowels dd 5 dup(?)
Then print the content of array New_Vowels

H.W2:
use the array odd to find the square of the numbers between 1 and 5 and put the
square of each number in the array square
odd db 1,3,5,7,9
square 5 dup(?)

H.W3:
How can you calculate the result of 7FFFh+FFFFh without causing the carry flag to
be set

The END
