Salah Berdouk

Advanced PLC Programming

Connecting the PLC to the PC
Connecting the PLC to the PC
 GX Developer – Creating a Project
• Start Menu => Type or Click on GX Developer
 GX Developer – Creating a Project
• Project => New Project
 GX Developer – Creating a Project

1. PLC series => FXCPU 4. Type a “Project name” and “Title”

2. PLC Type => FX1N(C) 5. Click “OK”
3. Tick the “Setup project name” box 6. Click “Yes”

1 5

3 6

4
GX Developer – Creating a Project

TOOLBARS

WORKSPACE
PROJECT
DATA LIST
 Backup PLC Program
• Online > Read from PLC
 Backup PLC Program
• Select “MAIN”, “PLC parameter”, “Device data”
• Wait > Click “OK” when completed.

3
 Backup PLC Program
• Click on “Close” > The program appears

1
 Monitoring
• Online > Monitor > Start monitor (All windows)
Monitoring
• The monitor window appears in the top right corner.
• The PLC should be in RUN mode
 SAVE THE PROGRAM
• Click on Save to have a backup program

1
Force Inputs & Outputs
• Right click on an input > Device test

1
 Force Inputs & Outputs
1. Type the input or output address 3. Outputs lit up on PLC
2. FORCE ON or FORCE OFF 4. “Close” when finished

4
1

3
 Transfer Program to PLC
1. Online > Remote operation
2. Execute > Wait > 3. OK > Close

3
1 3

4
Transfer Program to PLC

3
1
2 9

4 5

6. Wait

7 8
Create a new program
 Create a new program
• Once finished the program: Online > Convert
