1 SAP Process Integration, business-to-
business add-on Configuration
Use
This section provides you with information on configuring various components of SAP Process Integration,
business-to-business add-on 2.0 release.
For more information, see :
● Configuring Adapters [page 3]

● Configuring Adapter Modules [page 115]
● Importing User Defined Functions [page 141]
● B2B Integration Cockpit [page 155]
● Monitoring B2B Messages [page 252]
1.1 Configuring Adapters
Use
This section provides you with information on configuring the adapters of the SAP Process Integration,
business-to-business add-on.
For more information, see:
● Configuring the Communication Channels with the AS2 Adapter [page 3]

● Configuring the Communication Channels with the OFTP Adapter [page 23]
● Configuring the Communication Channels with the X.400 Adapter [page 47]
● Configuring the Communication Channel with EDI Separator Adapter [page 75]
1.1.1 Configuring the Communication Channels with the AS2

Adapter
Prerequisites
● You have logged on to the Integration Directory in the SAP Process Integration environment.

SAP Process Integration, business-to-business add-on Configuration PUBLIC 3
● You have deployed the AS2 adapter in the SAP Process Integration environment.
● You have created the business component and communication channels.
● You have generated and stored your private keys in the SAP NetWeaver Administrator keystore.
● You have received and stored the partner's public keys in the SAP NetWeaver Administrator keystore.
Context
You configure communication channels with the Applicability Statement 2 (AS2) adapter to transmit business
documents over the Internet securely using the HTTP and S/MIME protocols. It also ensures non-repudiation
of the business document exchange by transmitting an acknowledgment receipt known as a Message
Disposition Notification (MDN). The AS2 adapter specifies a comprehensive set of data security features,
specifically data confidentiality and data authenticity, which are aimed at the B2B commerce environment.
You use Multiple Attachment (MA) in AS2 adapter to transfer multiple documents within a single AS2 message.
In some transactions, multiple attachments are interpreted and stored in a single message. Multiple
documents, including non-EDI payloads, can be attached and transmitted in a single EDI message. These
attachments are stored within the MIME Multipart/Related structure.
AS2 adapter can switch between two security providers, that is BC (Bouncy castle) and IAIK. By default, the
security provider of AS2 adapter is IAIK.
Procedure
1. Configure the sender channel with the AS2 adapter to process the inbound messages.
For more information, see Configuring the AS2 Sender Channel [page 5].
2. Configure the receiver channel with the AS2 adapter to process the outbound messages.
For more information, see Configuring the AS2 Receiver Channel [page 14].
3. To view the technical logs generated by the AS2 adapter, refer Scheduling Log Clean-up Job [page 159]
4. To configure alerts for AS2 adapter, refer B2B Alerts [page 258]
5. If you want to change the default security provider from IAIK to BC, perform the following substeps:
a. Navigate to the URL, http://<host>:<port>/nwa/sys-config.
b. Choose the Applications tab page.
c. Filter com.sap.aii.adapter.as2.app
d. In the Extended Details section, select the default.security.provider parameter.
e. Choose Modify, and update the value as BC.
f. Save the changes.

4 PUBLIC SAP Process Integration, business-to-business add-on Configuration
1.1.1.1 Configuring the AS2 Sender Channel
Context
You use this procedure to configure the sender channel settings in the AS2 adapter.
Procedure
1. Configure the sender channel with the AS2 adapter to process the inbound messages.
For more information, see Configuring AS2 Sender Channel for Inbound Message Processing [page 5].
2. Configure the sender channel with the AS2 adapter to create a new XI message for the received MDN.
For more information, see Creating New XI Message for the Received MDN [page 13].
1.1.1.1.1 Configuring AS2 Sender Channel for Inbound

Message Processing
Context
You use this procedure to configure the sender channel settings in the AS2 adapter.
Procedure
1. On the Display Configuration Scenario screen, choose the Objects tab page.
2. In the Type column, double-click the Communication Channel.
3. Choose to configure the adapter.

4. In the Edit Communication Channel screen area, enter the channel parameters.
5. In the Display Language field, select the required application UI language.
6. Choose the Identifiers tab page and enter the parameters that identify the sender and receiver agencies.
7. Choose the Module tab page and enter the parameters that specify generic modules for the adapters
based on the business scenario.
8. Choose the Parameters tab page.

9. In the Adapter Type field, select the AS2 adapter.
10. Select the Sender radio button for the AS2 adapter to perform inbound message processing.
11. In the Transport Protocol field, select the Hypertext Transfer Protocol.
12. In the Message Protocol field, select AS2.
13. In the Adapter Engine field, select Central Adapter Engine.
14. Choose the General tab page and enter the values in the respective fields based on the description of the
parameters in the table below:
Component Parameter Description
Server Expected URL Path Provide the <path> mentioned in the

AS2 URL from which you receive the
messages.
The format used to define AS2 URL is

http://<local:port>/AS2/
<path>
 Note
The UME action AS2Deliverage
must be assigned to the J2EE
user created for the purpose of
sending messages to the adapt
er’s public HTTP URL. The au
thentication credentials are pro
vided to the partner in order to
call the adapter using HTTP(s).
Message Expected MessageID Left This parameter determines the left

side of the AS2 message ID. The name
to the left of the “@” symbol is consid
ered as Message ID left.
Expected MessageID Right This parameter determines the right

to the right of the “@” symbol is con
sidered as Message ID right. It must
be something unique that represents
the host environment, for example, a
host name.
Expected Sender's AS2 Name This parameter determines the part

ner's unique AS2 name.
Expected Own AS2 Name This parameter determines the com

pany's (using PI) unique AS2 name.

Expected Subject This parameter defines the message

header of the incoming AS2 message.
Send Negative MDN if Filename is not This parameter enables the AS2
present adapter to check for the filename of
an inbound AS2 message. If the
adapter receives an AS2 message
without a filename, then it dispatches
a negative MDN to the trading partner.
Charset Charset Conversion This parameter enables you to encode

the characters in the message.
Source Encoding This parameter defines the encoding

format used at the source.
Destination Encoding This parameter defines the encoding

format used the destination.
Ambivalent Configuration Alert on messages in channels with This parameter enables the adapter to
ambivalent configuration set adapter-specific message attrib
utes for the PI message, from the in
coming AS2 message.
You are alerted if multiple sender

channels receive similar sets of mes
sages.
Duplicate Handling Enable Duplicate Handling This parameter enables the duplicate-
handling feature. It determines if the
current file received by the sender
channel is a duplicate of an already
processed file. If the message is a du
plicate, then it ignores it and creates
an alert based on the configuration.
Duplicate Message Threshold This parameter defines the threshold

for processing the given number of
duplicate messages. If the duplicate
count exceeds the threshold value,
the subsequent message is ignored
and you are alerted.
Disable channel if threshold exceeded This parameter enables the sender

channel to become inactive if the du
plicate threshold is exceeded.
Time Period for Duplicate Check This parameter defines the interval for
checking the duplicate messages.

Time Period for Duplicate Check (Unit) This parameter determines the unit of
the interval for checking for duplicate
message. The units available are given
below:
○ Hour
○ Day
Enable Duplicate Filename Handling This parameter enables the adapter to

check an inbound AS2 message for
duplicate filenames. If identical file-
name is found in the PI server, then an
MDN is dispatched to the trading part
ner.
Time Period for Duplicate Filename This parameter defines the interval in
Check (Minutes) minutes for checking the duplicate
messages.
Type of MDN for Duplicate Filename Define the type of MDN to be dis
patched to the trading partner. The
following options are available:
○ Send Warning MDN

○ Send Error MDN
Message Configuration Set Dynamic Parameters This parameter enables the adapter to
use the adapter-specific message at
tributes from the PI message instead
of the configured values.

Quality of Service This parameter determines the man

ner in which the recipients receive the
messages from the Integration En
gine.
The following types of quality of serv

ice are available:
○ Exactly Once (asynchronous) :

The sender does not wait for a re
sponse before continuing the
process. This quality-of-service
option ensures that the mes
sages are delivered and proc
essed exactly once.
○ Exactly Once In Order
(asynchronous) : The messages
with an identical queue name are
delivered to the recipient. This
quality-of-service option ensures
that the messages are in the
same sequence as they are sent
by the sender.
○ Better effort (synchronous) : The
sender waits for a response from
the recipient before continuing
the process.
Archiving Archive Messages and MDN This parameter archives AS2 and
MDN messages on the PI server.
The adapter archives both synchro

nous and asynchronous MDN mes
sages.
Incoming Wired Message This parameter archives incoming

AS2 message on the PI server.
Payload after Charset Conversion This parameter archives payload at

tached to an incoming AS2 message
on the PI server. The coded data in the
payload is converted and archived.
Payload after Decryption This parameter archives payload at

on the PI server. The payload is first
decoded and archived. This option is
available only if you choose to Decrypt
the AS2 message.

Archive Error Message This parameter archives AS2 error

messages on the PI server. Error mes
sages occur when the validation of the
AS2 message fails.
Archive Positive MDN This parameter archives positive MDN

acknowledgements on the PI server. If
the AS2 transaction is successful,
then receiver of AS2 messages trans
mits a positive MDN receipt to the
sender.
Archive Negative MDN This parameter archives negative

MDN acknowledgements on the PI
server. If the AS2 transaction is un
successful, then receiver of AS2 mes
sages transmits a negative MDN re
ceipt to the sender.
Archive Name The Archive Name defines the location

of the target folder for archiving. Use
the archiving parameters to specify
and define the file path of the archive
location.
Adapter Status Adapter Status This parameter has two options:
○ Active: Enables the adapter to ex

change messages.
○ Inactive: Disables the exchange of
messages.
 Note
Archiving: This feature enables you to save messages transmitted from a source or destination
database "in original format" on your file system. It is the first task practiced after receiving messages
with regard to sender channel and the final task practiced before sending messages with regard to
receiver channel. The location of the archived files are shown in the Archive name text box. The file
path of the archiving location can contain the substitution parameters to ensure uniqueness of the
archived file.
The archiving parameters used in the Integration Engine are as follows:

○ %SEQNUM: A sequence number, starting with 1
○ %RTSEQNUM: A server wide sequence number, starting with 1
○ %START: The start time of the adapter
○ %TIME: The archiving period in milliseconds
○ %MSGID: The XI message ID

For example, the archiving parameters used to define a file path to an archive location are shown as
"D:/x400Archiv/%TIME_%SEQNUM.msg".
15. Choose the Signature and Encryption tab page and enter the values in the respective fields based on the
description of the parameters in the table below:
Signature Verify Signature This parameter enables you to verify

the signature of the partner.
View to sender’s public key certificate This parameter determines the send
er's public key certificate from the
NetWeaver Administrator keystore.
Alias of sender’s public key certificate This parameter determines the pseu
donym file of the sender's public key
certificate from the NetWeaver Ad
ministrator keystore.
Decryption Decrypt This parameter enables you to de

crypt the received message.
View to own private key This parameter determines your pri

vate key certificate from the NetWea
ver Administrator keystore.
Alias of own private key This parameter determines the pseu

donym file of your private key certifi-
cate from the NetWeaver Administra
tor keystore.
 Note
The following are the signing algorithms supported by the sender channel:
○ MD5
○ SHA-1
○ SHA-2
The following are the encrypting algorithms supported by the sender channel:
○ AES 128
○ AES 192
○ AES 256
○ 3DES
○ RC2
16. Choose the MDN tab page and enter the values in the respective fields based on the description of the

Signature Sign MDN This parameter enables you to sign

the Message Delivery Notification
(MDN) receipt to notify the sender of
the message upon successful delivery.
View to own public key certificate This parameter determines your pub
lic key certificate from the NetWeaver
Administrator keystore.
Alias of own public key certificate This parameter determines the pseu
donym file of your public key certifi-
tor keystore.
View to own private key This parameter determines your pri

Alias of own private key This parameter determines the pseu

tor keystore.
Asynchronous Message Disposition Send Options This parameter delivers an asynchro

Notification nous MDN receipt either immediately
or after receiving an acknowledge
ment from the recipient's application.
After receiving a permanent applica
tion acknowledgement (app ack) from
the receiver channel do not use this
option when the corresponding re
ceiving channel in the PI message flow
does not support app ack.
Override URL for MDN This parameter allows you to change

the URL of the MDN.
Async MDN URL This parameter defines the URL of an

asynchronous MDN.
Basic HTTP Authentication This parameter provides authentica

tion to the Web server that uses HTTP
to deliver an Async MDN over the net
work.
Username This parameter authenticates the Web

server using a valid user name.

Password This parameter authenticates the Web

server using a valid password.
Proxy Server This parameter determines the proxy

server that is used to deliver an Async
MDN over the network.
Host This parameter determines the

TCP/IP address or the host name of
the proxy server that establishes con
nection with the proxy server on the
network.
Port This parameter identifies the port of

the proxy server.
Basic Proxy Authentication This parameter provides authentica

tion to the proxy server.
Username This parameter authenticates the

proxy server using a valid user name.
Password This parameter authenticates the

proxy server using a valid password.
 Note
Monitoring Acknowledgment
○ The local message monitor has been enhanced to monitor acknowledgments. For more
information, refer SAP Note 1815991 .
○ You can view the acknowledgements in communication channel logs and also in audit logs.
○ You can also enable the channel archiving option to archive inbound and outbound MDN receipts.
17. To set the channel status and to add additional parameters, choose the Advanced tab page.
18. Save the settings.
1.1.1.1.2 Creating New XI Message for the Received MDN
Use
You configure the sender channel of the AS2 adapter to create a new XI message for the received Message
Delivery Notification (MDN). The purpose of the MDN is to acknowledge the receipt of a payload message
delivered successfully and to ensure the message has been transferred without modifications. The sender
MDN channel should be created under the same party and communication component that are used in the

receiver agreement of the receiver AS2 channel. This feature is currently available for asynchronous
acknowledgment only.
Procedure

 Note
The channel parameters entered must map with the AS2 receiver channel.

7. In the Transport Protocol field, select AS2 MDN.
8. In the Message Protocol field, select AS2 MDN XML.
10. From the Adapter Status dropdown list, select Active if you want to enable the adapter to exchange
messages; otherwise select Inactive.
11. Save the changes.
 Note
The enhanced version of the local message monitor has been introduced with Related Messages to find
related acknowledgments.
1.1.1.2 Configuring the AS2 Receiver Channel
Context
You use this procedure to configure the receiver channel settings in the AS2 adapter.
Procedure
2. Double-click the Communication Channel, in the Type column.

8. Choose the Parameters tab page.
11. In the Transport Protocol field, select the Hypertext Transfer Protocol.
12. In the Message Protocol field, select AS2.
14. Choose the General tab page and enter the values in the respective fields based on the description of the
Recipient Recipient URL This parameter determines the URL of

the partner's AS2 server.
The format used to define the part

ner's AS2 URL is http://
<local:port>/AS2/<path>
 Note
If you use the HTTPS protocol to
access the target partner's URL,
the public key certificate of the
HTTP server of that remote sta
tion must be deposited in the key
store view Trusted CAs of the
J2EE engine.
Basic HTTP Authentication This parameter provides authentica

tion to the Web server that uses HTTP
to deliver the AS2 message over the
network.
Username This parameter authenticates the Web

server using a valid user name.
Password This parameter authenticates the Web

server using a valid password.

Configure Client Certificate This parameter allows client and

Authentication server based authentication on mes
sages.
Proxy Server This parameter determines the proxy

server that is used to deliver the AS2
message over the network.

the proxy server that establishes con
nection with the proxy server on the
network.

the proxy server.
Basic Proxy Authentication This parameter provides authentica

tion to the proxy server.
Username This parameter authenticates the

proxy server using a valid user name.

proxy server using a valid password.
Message File Name This parameter determines the file

name of the encrypted message that
is transmitted.
MessageID Left This parameter determines the left

to the left of the “@” symbol is consid
ered as Message ID left. If this field is
empty, then the XI MessageID is used.
MessageID Right This parameter determines the right

to the right of the “@” symbol is con
sidered as Message ID right. It must
be something unique that represents
the host environment, for example, a
host name.
Use Compatible Message ID (shorter) This parameter enables you to

shorten the entire MessageID to a
maximum of 255 characters.

Own AS2 Name This parameter specifies the compa

ny's unique AS2 name.
Recipient‘s AS2 Name This parameter specifies the partner's

unique AS2 name.
Own E-mail Address This parameter specifies the e-mail

address obtained from the sender for
transmitting the MDN receipt.
Message Subject This parameter determines the sub

ject of the message, which helps to
identify the transmitted message.
Content-Type This parameter specifies the content

type that the message is marked with.
For example, EDIFACT files are

marked withapplication/edi-x12.
Enable AS2 Attachments This parameter enables the receiver

channel to transmit AS2 messages
with attachments. By default, this
functionality remains disabled.
Charset Charset Conversion This parameter enables to encode the

characters in the message.
Source Encoding This parameter defines the encoding

algorithm at the source.
Destination Encoding This parameter defines the encoding

algorithm at the destination.

Dynamic Configuration Respect Parameters This parameter enables you to over

write various AS2 message parame
ters with the content of the dynamic
parameters in the XI message, instead
of using the values from the channel.
The following parameters exist in the

namespace http://
sap.com/xi/XI/AS2/AS2:
○ AS2URL: URL of the server

○ AS2Subject: Subject
○ AS2From: Sender name
○ AS2To: Recipient name
○ AS2FromEmail: E-mail Address of
the sender
○ AS2MessageId: Complete Messa
geID
○ AS2MessageIdLeft: Left part of
the MessageID
○ AS2MessageIdRight: Right part
of the MessageID
○ AS2ContentType: Content type of
the message
○ AS2Filename: XI Message ID
Archiving Archive Messages and MDN This parameter archives AS2 and
MDN messages on the PI server. The
adapter archives both synchronous
and asynchronous MDN messages.
Incoming Payload to Channel This parameter archives incoming

payload attached to the AS2 message
on the PI server.
Payload after Charset Conversion This parameter archives payload at

on the PI server. The coded data in the
payload is converted and archived.
Outgoing Wired Message This parameter archives outgoing AS2

message on the PI server.

Archive Positive MDN This parameter archives positive MDN

acknowledgements on the PI server. If
the AS2 transaction is successful,
then receiver of AS2 messages trans
mits a positive MDN receipt to the
sender.
Archive Negative MDN This parameter archives negative

MDN acknowledgements on the PI
server. If the AS2 transaction is un
successful, then receiver of AS2 mes
sages transmits a negative MDN re
ceipt to the sender.
Archive Name The Archive Name defines the location

of the target folder for archiving. Use
the archiving parameters to specify
and define the file path of the archive
location.

change messages.
messages.
 Note
archived file.

15. Choose the Signature and Encryption tab page and enter the values in the respective fields based on the
description of the parameters in the table below:

Compression Compress Message This parameter enables you to com

press the message before sending.
Signature Sign Message This parameter authenticates the AS2

message with a digital signature.
Algorithm This parameter defines the algorithm

for signing the AS2 message. The fol
lowing algorithms are available in the
AS2 adapter:
○ SHA 1
○ SHA 224
○ SHA 256
○ SHA 384
○ SHA 512
View to own public key certificate This parameter determines your pub
lic key certificate from the NetWeaver
Administrator key store.
Alias of own public key certificate This parameter determines the pseu
donym file of your public key certifi-
tor keystore.
View to Own Private Key This parameter determines your pri

Alias to Own Private Key This parameter determines the pseu

tor keystore.
Encryption Encrypt Message This parameter enables you to en

crypt the message before sending it.

for encrypting the AS2 message. The
following algorithms are available in
the AS2 adapter:
○ AES 128
○ AES 192
○ AES 256
○ 3DES
○ RC2

Key Length This parameter defines the length of

the RC2 key.
View to recipients public key certificate This parameter determines the recipi
ent's public key certificate from the
Alias of Recipients Certificate This parameter determines the pseu

donym file of the recipient's public key
16. Choose the MDN tab page and enter the values in the respective fields based on the description of the
MDN Message Delivery Notification This parameter determines the appro

priate Message Delivery Notification
(MDN) type.
Two types of MDN are available:
○ Synchronous: This type of AS2

MDN uses the same URL to de
liver the receipt.
○ Asynchronous: This type of AS2
MDN uses a separate URL to de
liver the receipt. You must pro
vide the target URL in the MDN
Target-URL field.
The URL format used to define
AS2 MDN http://
<local:port>/AS2/
<path>/mdn
Request Message Integrity Check This parameter enables the adapter to

(MIC) request the partner for MIC.
Verify MIC This parameter enables the adapter to

verify the received MIC from the part
ner.
Request Signing This parameter enables you to sign

the message before sending it.


for signing the AS2 message. The fol
lowing algorithms are available in the
AS2 adapter:
○ SHA 1
○ SHA 224
○ SHA 256
○ SHA 384
○ SHA 512
○ Same as Signed Message
Verify Signature This parameter enables you to verify

the signature of the message.
Choose the public key certificate from

the NW administrator keystore.
Choose the certificate file from the

keystore.
View to signer's public key certificate This parameter determines the sign
er's public key certificate from the
Alias of signer's public key certificate This parameter determines the pseu
donym file of the signer's public key
Creating New XI message for received This parameter allows the adapter to
MDN create acknowledgement for the re
ceived MDN. The types of content of
the XI message are given below:
○ Both Positive and Negative MDN:

This acknowledgement contains
details on both successful and
unsuccessful interchange.
○ Negative MDN Only: This ac
knowledgement contain details
on unsuccessful interchange.
Communication Channel This parameter specify the channel

that maps the AS2 sender channel
configured with AS2 MDN as the
transport protocol.

Party This parameter determines the

the partner system, which establishes
connection to the partner system on
the network.
Communication Component This parameter specify the communi

cation component of the AS2 sender
channel configured with AS2 MDN as
the transport protocol.
1.1.2 Configuring the Communication Channels with the

OFTP Adapter
Prerequisites
● You have deployed the OFTP adapter in the SAP Process Integration environment.
● You have created business component and communication channels.
● You have generated SSL key pair and stored it in the SAP NetWeaver Administrator Key Store.
● You have generated CMS key pair, only if you are using OFTP 2.0 version, and stored it in the SAP
NetWeaver Administrator Key Store.
Context
You configure the communication channels with the Odette File Transfer Protocol (OFTP) adapter to enable
secure and reliable data exchange, either by direct point-to-point, or indirectly via VAN, between computer
systems within industries such as Automotive, Engineering, Transport and so on. It is an add-on that runs on
the SAP Process Integration Adapter Framework. The OFTP protocol enables secure authentication by using
unique Odette ID, SSL protocol, message encrypting and digital signing algorithm, and these parameters are
supported both at the sender and receiver side in an OFTP adapter. If the OFTP communication channels are
configured with TCP/IP transport protocol, then the data is exchanged over the Internet or private networks. If
the OFTP channels are configured with ISDN transport protocol, then the data is exchanged over dedicated
communication links.

The features of the OFTP adapter are given below:
● It encrypts the messages

● It digitally signs the message to establish the origin of the message
● It establishes the proof of data integrity
● It provides enhanced data compression
● It establishes the proof of identity
● It can switch between two security providers, that is BC (Bouncy castle) and IAIK. By default, the security
provider of OFTP adapter is IAIK.
Procedure
1. Configure the sender channel with the OFTP adapter to process inbound messages.
For more information, see Configuring the OFTP Sender Channel [page 24].
2. Configure the receiver channel with the OFTP adapter to process outbound messages.
For more information, see Configuring the OFTP Receiver Channel [page 38].
3. To view the technical logs generated by the OFTP adapter. For more information, see Filtering OFTP Logs
[page 156].
4. If you want to change the default security provider from IAIK to BC, perform the following substeps:
a. Navigate to the URL, http://<host>:<port>/nwa/sys-config.
b. Choose the Applications tab page.
c. Filter com.sap.aii.adapter.oftp2.app
d. In the Extended Details section, select the default.security.provider parameter.
e. Choose Modify, and update the value as BC.
f. Save the changes.
1.1.2.1 Configuring the OFTP Sender Channel
Context
You use this procedure to configure the sender channel settings in the OFTP adapter.
Procedure
1. Configure the sender channel with the OFTP adapter to process inbound messages.

For more information, see Configuring OFTP Sender Channel for Inbound Message Processing [page 25].
2. Configure the sender channel with the OFTP adapter to create a dedicated channel for delivering reports.
For more information, see Creating New XI Message for Received ERP [page 37].
1.1.2.1.1 Configuring OFTP Sender Channel for Inbound

Message Processing
Context
You use this procedure to configure the sender channel with OFTP adapter to receive and decrypt an Odette
message from the business partner.
The OFTP 2.0 version supports Cryptographic Message Syntax (CMS. See IETF RFC 3852, RFC 3274) that is a
standard developed by the IETF to ensure secure message exchange. It is capable of encrypting, signing and
compressing messages sent by OFTP.
Procedure

5. On the Displayed Language field, select the applications UI language.
7. Choose the Module tab page and enter the parameters that specify generic modules for adapters.
8. Select the Sender radio button.
9. In the Message Protocol dropdown, select either OFTP 2.0 or OFTP 1.4.
 Note
If you select the OFTP 2.0 version, then the CMS tab page appears to allow you to configure then
encrypt and decrypt files.
10. In the Adapter Engine, select Central Adapter Engine.

11. In the Transport Protocol dropdown, select TCP/IP or ISDN.

1. If you have selected the transport protocol as TCP/IP, then provide the parameters in the General tab
page as described in the following table:
TCP/IP settings Local Hostname This parameter determines the

TCP/IP address or Fully Qualified
Domain Name (FQDN) of the local
machine that allows the OFTP
adapter to connect to the address of
the network interface.
Local SSL Port This parameter defines the local the

port number that allows the OFTP
adapter to bind with the local sys
tem. The default port number is
3305.
If the partner is using SSL protocol

then provide the SSL port number.
The default SSL port number is
6619.
SSL Use SSL This parameter provides secure

communication over the Internet us
ing SSL protocol.
Use client authentication This parameter performs client au

thentication by validating the secur
ity certificates.
View containing SSL Keypair This parameter enables the process

of uploading the SSL Keypair from
the SAP NetWeaver Administrator
Key Store.
View containing trusted certificates This parameter enables the process

of uploading the security certificates
from the SAP NetWeaver Adminis
trator Key Store. The security certifi-
cate helps to authenticate the client.
If SSL protocol is chosen, then the

certificate of the host must be
added to the view of the J2EE en
gine.

2. If you have selected the transport protocol as TCP/IP Poll to connect to the partner system and
retrieve the messages during a specified polling interval, then provide the parameters in the General
tab page based on the description mentioned in the table below:
TCP/IP Settings Partner Host This parameter determines the

Domain Name (FQDN) of the remote
machine that allows the OFTP
the partner system.
Port This parameter defines the local the

port number that allows the OFTP
adapter to bind with the local sys
tem. The default port number is
3305.
SSL Port If the partner is using SSL protocol

then provide the SSL port number.
The default SSL port number is
6619.
Specify Local Host This parameter determines the spe

cific TCP/IP address or Fully Quali
fied Domain Name (FQDN) of the lo
cal machine.
Local Host The OFTP adapter acts as an initia

tor and sends a connection request
to the partner system. The “0.0.0.0”
address is used for binding to one of
the available local interfaces.
Use SSL This parameter provides secure

ing SSL protocol.
Verify hostname This parameter determines the

Domain Name (FQDN) of the web
server.
Use client authentication This parameter performs client au

ity certificates.

Key Store.

trator Key Store. The security certifi-

gine.
Interval Poll Interval (min.) This parameter determines the re

sponse time of the adapter to check
for stored files in the source direc
tory of the partners system.
3. If you have selected the transport protocol as ISDN to enable digital transmission of either voice or
data communication between two users for the duration of a call, then provide the parameters in the
General tab page based on the description mentioned in the table below:
ISDN Router Settings Router Address This parameter determines the IP

address or Fully Qualified Domain
Name (FQDN) of the ISDN router.
Router Port This parameter determines the

RCAPI server on the ISDN router.
The default port number is 2662.
Router User This parameter authenticates the

ISDN router's administration con
sole using a valid user name. The au
thentication credentials are associ
ated with the router's RCAPI access
channel.
Router Password This parameter authenticates the

sole using a valid password.

Use Additional Routers This parameter enables you to spec
ify an additional router in case the
primary router is unavailable. Once
you enable this checkbox, provide
the necessary details in the fields
that appear.
General ISDN Settings Enable Multiple Controller numbers This parameter enables you to spec
ify multiple controller numbers using
comma separators.
Controller Number (1 ‑ 255) / This parameter determines a valid

Controller Number (1 ‑ 255, 1 - ISDN controller number. The con
255, ...) troller represents a physical connec
tion to ISDN router. Contact your
ISDN router administrator to obtain
the controller number.
Own Number This parameter defines your ISDN

number.
4. If you have selected the transport protocol as ISDN Poll to enable the digital transmission of either
voice or data communications between two users for the duration of a call, then provide the
parameters in the General tab page based on the description mentioned in the table below:



channel.

General ISDN Settings Remote Number This parameter determines the re
cipients ISDN number.

number.
Controller Number (1 ‑ 255) This parameter determines a valid

ISDN controller number. The con
troller represents a physical connec
12. In the General tab page, provide values for the remaining parameters based on the description mentioned
in the table below:
Partner Password (Sender) Own Odette-ID This parameter determines a unique

Odette-ID of the sender. It helps to
identify the inbound messages.
Final File Destination (SFIDDEST) This parameter determines the desti

nation of the final recipient of the vir
tual file. This is also the location that
analyzes the virtual file content and
performs the mapping functions. The
End-to-End Response (EERP) com
mand for the received files are found
at this location.
Partner Odette-ID This parameter determines a unique

Odette-ID of the partner. It helps to
identify the outbound message.
File Originator (SFIDORIG) This parameter determines the origi

nator of the virtual file.
Enable Clear Text for Passpharse This parameter allows the user to en
ter password in plain text.
Own Password (Receiver) This parameter authenticates the re

ceiver with a valid password.
Partner Password (Sender) This parameter authenticates the

sender with a valid password.
File Settings Expected Virtual File Dataset Name This parameter determines the data
set name of the virtual file being
transferred.

Encoding This parameter defines the format to
encode the file before transmission.
The available file encoding formats
are given below:
○ ISO-8859-1
○ EBCDIC
Duplicate Handling Enable Duplicate Handling This parameter enables duplicate

handling feature. It determines if the
current file received by the sender
channel is a duplicate of an already
processed file. If the message is dupli
cate, then it ignores and creates an
alert based on the configuration.
Duplicate Message Threshold This parameter defines the threshold

for processing the given number of
duplicate messages. If the duplicate
count exceeds the threshold value,
the subsequent message is ignored
and you are alerted.
Disable Channel if Threshold Exceeded This parameter enables the sender

channel to become inactive if the du
plicate threshold is exceeded.
Time Period for Duplicate Check This parameter defines the interval to
check for duplicate messages.
Time Period for Duplicate Check (Unit) This parameter determines the unit of
the interval to check for duplicate
message. The units available are given
below:
○ Hour
○ Day

Quality of Service Quality of Service This parameter determines the man
ner in which the recipient’s receive the
gine.
The following types of Quality of Serv

ice are available:
○ Exactly Once (asynchronous):

process. This Quality of Service
essed exactly once.
(asynchronous): The messages
with the identical queue name
are delivered to the recipient.
This Quality of Service option en
sures that the messages are in
the same sequence as they are
sent by the sender.
○ Better effort (synchronous): The
the process.
Archiving Archiving Messages This parameter archives the OFTP

messages on the PI server.
The archiving options are available

only in OFTP 2.0 message protocol.
Incoming Wired Message This parameter enables you to archive

the incoming OFTP messages to a lo
cation provided in the Filename field.
Payload After Decryption This parameter archives payload at

tached to an incoming message on
the PI server. The payload is first de
coded and then archived. This option
is available only if you choose
theDecrypt files option available in
CMS tab page.
Incoming EERP This option archives incoming EERP

messages to a location provided in the
Filename field.

Incoming NERP This option archives incoming NERP
Filename field.
Archive Error Messages This parameter enables you to archive

error messages to a location provided
in the Filename field.
13. Choose the Technical Settings tab page and based on the Transport Protocol you have specified, follow the
sub-steps below:
1. If you select the transport protocol as TCP/IP or ISDN, enter the values of the parameters as described
in the table below:
Technical Settings Allow Compression (1.X RLE) This parameter enables the adapter
to compress the data as per the Run
Length Encoding (RLE) compression
type.
Version Negotiable This parameter enables the adapter

to negotiate the OFTP version with
the partner.
Send / Receive Capabilities This parameter allows you to specify

the send/receive capabilities of the
location (whether receive only or
both send and receive).
Max Credit Count This parameter determines the max

imum credit limit available for the
data exchange buffers sent to the lis
tener. The credit count value de
pends on the router.
Max Exchange Buffer Size This parameter determines the max

imum exchange buffer size that can
be accepted by this location. The
value of this size depends on the
router.

Userfield SSID This parameter defines the Service
Set Identifier (SSID), which is a
unique ID used for establishing con
nection with the wireless network.
There must exist a bilateral agree
ment between two FTPs for realizing
this service.
If this field is unused then initialize it

to spaces.
Userfield SFID This parameter defines the Service

Flow Identifier (SFID), which is a
unique ID defined by DOCSIS and it
represents either an upstream or a
downstream flow of data. There
must exist a bilateral agreement be
tween two FTPs for realizing this
service.
If this field is unused, then initialize it

to spaces.
2. If you select the transport protocol as TCP/IP Poll, enter the values of the parameters as described in
the table below in addition to the technical setting parameters that are available for TCP/IP:
Associate with same SSID and Polling Channel This parameter allows you to asso
password ciate the polling channel with the
same SSID and password for ses
sion negotiation.
Sender Channel This parameter allows you to asso

ciate the sender channel with the
sion negotiation.
3. If you select the transport protocol as ISDN Poll, enter the values of the parameters as described in the
table below in addition to the technical setting parameters that are available for ISDN:
Associate with same SSID and Polling Channel This parameter allows you to asso
password ciate the polling channel with the
sion negotiation.

Sender Channel This parameter allows you to asso
ciate the sender channel with the
sion negotiation.
X.25 Settings Use X.25 This parameter allows you to use the
X.25 protocol for electronic data ex
change over the network.
Called Number This parameter defines the destina

tion number of the partner without
the area code.
Calling Number This parameter defines the senders

number without the area code.
Packet size This parameter determines the size

of data used in the X.25 interchange.
Retain the default values.
Window Size This parameter determines the max

imum number of data packets that
are exchanged. Retain the default
values.
14. Choose the ERP tab page and enter the values in the respective fields based on the description of the
parameters mentioned in the table below:
ERP Settings Suppress End Response (EERP/NERP) This parameter initiates the sender
channel not to send an end-to-end re
sponse to the originator of a file.
Asynchronous ERP Settings Send Asynchronous ERP This parameter allows you to sends
asynchronous ERP receipt to the part
ner.
Partner Host This parameter determines the

the network.
Port This parameter identifies the part

ner's port number.

Send Options This parameter delivers an Asynchro
nous ERP receipt either immediately
or after receiving an application ac
knowledgment from the receiver. The
On Application Acknowledgement op
tion is an acknowledgment requested
by the sender after the message was
processed by the receiver success
fully.
 Note
○ You can view the acknowledgments in communication channel logs and also in audit logs.
15. If you select the Message Protocol as OFTP 2.0, choose the CMS tab page and enter the values in the
respective fields based on the description of the parameters mentioned in the table below:
 Note
All CMS features are supported by OFTP Version 2.0 and above. If you have chosen a version prior to
2.0, then the CMS tab page is unavailable.
CMS Parameters Key store containing own certificates This parameter allows you to view and
and keys use your certificates and keys from
the SAP NetWeaver Administrator key
store.
Key store containing partner This parameter allows you to view and
certificates use partners certificates and keys
from the SAP NetWeaver Administra
tor key store.
Decrypt Files This parameter enables you to de

crypt the received messages. There
tween two FTPs for activating this
service.
Verify Signature This parameter enables you to verify

the signature of the received files.
ment between two FTPs for activating
this service.

Use Secure Handshake This parameter allows the sender
channel to identify the originator of
the message before opening a ses
sion.
Use Compression This parameter indicates the algo

rithm used to compress the incoming
message.
Send Signed ERP This parameter enables the adapter to

send signed EERP/NERP response.
 Note
The CMS option does not negotiate between the FTP systems. If the CMS options in the sender and
receiver channels do not correspond with each other, then the file transfer fails.
16. To configure the channel status and to add additional parameters, choose the Advanced tab page.
1.1.2.1.2 Creating New XI Message for Received ERP
Use
You configure the sender channel of the OFTP adapter to create a new XI message for the received End-to-End
Response (ERP). The content in the XI message gives you details about the delivery status of the OFTP
message.
Procedure

 Note
The channel parameters must be referred to OFTP receiver communication channel.
5. In the Adapter Type field, select the OFTP adapter.

6. Select the Sender radio button for the OFTP adapter to perform inbound message processing.
7. In the Transport Protocol field, select OFTP ERP.
8. In the Message Protocol field, select OFTP ERP XML.

10. In the Adapter Status dropdown list, if you select Active, this enables the adapter to exchange messages;
choose Inactive.
 Note
1.1.2.2 Configuring the OFTP Receiver Channel
Context
You use this procedure to configure the receiver channel with OFTP adapter to send and encrypt an Odette
message from the business partner. The OFTP 2.0 version supports Cryptographic Message Syntax (CMS. See
IETF RFC 3852, RFC 3274) that is a standard developed by the IETF to ensure secure message exchange. It is
capable of encrypting, signing and compressing messages sent by OFTP.
Procedure
2. In the Type column, double-click the communication channel.

5. On the Displayed Language field, select the application UI language.
8. Select the Receiver radio button.
9. In the Message Protocol dropdown, select either OFTP 2.0 or OFTP 1.4.
 Note
If you select the OFTP 2.0 version, the CMS tab page appears to allow you to configure then encrypt
and decrypt files.
10. In the Adapter Engine, select Central Adapter Engine.

11. In the Transport Protocol dropdown, select either TCP/IP or ISDN.

1. If you select the transport protocol as TCP/IP, then provide the parameters in the General tab page
based on the description mentioned in the table below:
TCP/IP settings Partner Host This parameter determines the

Domain Name (FQDN) of the part
ner system that allows the OFTP
the network interface.
SSL Port / Port This parameter determines the port

number of the partner system. The
default port number is 3305.
If the partner is using SSL protocol,

then provide the SSL port number in
the SSL port field. The default SSL
port number is 6619.
Specify local host This parameter enables you to spec

ify the TCP/IP address of the local
system. Provide the TCP/IP address
in the Local Host field.
SSL Use SSL This parameter provides secure

ing SSL protocol.
Use Additional Destination This parameter enables you to con

nect to the required partner using an
additional destination in case the
primary destination is unavailable.
Once you enable this checkbox, pro
vide the Partner Host and SSL Port /
Port details.
Verify Hostname This parameter enables the adapter

to verify the hostname of the sys
tem, from which the message origi
nates.
Use Client Authentication This parameter performs client au

ity certificates.

key store.

trator key store. The security certifi-

gine.
2. If you select the transport protocol as ISDN to connect to the partner system and retrieve the
messages during a specified polling interval, then provide the parameters in the General tab page
based on the description mentioned in the table below:



channel.

Enable Multiple Controller numbers This parameter enables you to spec

ify multiple controller numbers using
comma separators.

Controller Number (1 ‑ 255) / This parameter determines a valid
Controller Number (1 ‑ 255, 1 - ISDN controller number. The con
255, ...) troller represents a physical connec
Use Additional Routers This parameter enables you to spec

ify an additional router to connect to
the partner in case the primary
router is unavailable. Once you ena
ble this checkbox, provide the nec
essary details in the fields that ap
pear.
General ISDN Settings Remote Number This parameter defines the partners
ISDN number.

number.
Use Additional Destination This parameter enables you to spec

ify an additional remote number to
connect to the partner in case the
primary remote number is unavaila
ble. Once you enable this checkbox,
provide the Remote Number.
12. In the General tab page, provide values for the remaining parameters based on the description mentioned
in the table below:
Partner Password (Receiver) Own Odette-ID This parameter determines a unique

Odette-ID of the receiver. It helps to
identify the outbound messages.
File Originator (SFIDORIG) This parameter determines the origi

nator of the virtual file. In case the dy
namic parameter
con.partner.SFIDORIG is set in the PI
message, then the receiver channel
uses this parameter.
Partner Odette-ID This parameter determines a unique

Odette-ID of the partner. It helps to
identify the outbound message.

Final File Destination (SFIDDEST) This parameter determines the desti
nation of the final recipient of the vir
tual file. In addition, this location ana
lyzes the virtual file content and per
forms the mapping functions. The
End-to-end Response (EERP) com
mand for the received files is found at
this location.
In case the dynamic parameter

con.partner.SFIDDEST is set in the PI
message, then the receiver channel
uses this parameter.
Enable Clear Text for Passpharse This parameter allows the user to en
ter password in plain text.
Own Password (Sender) This parameter authenticates the

sender with a valid password.
Partner Password (Receiver) This parameter authenticates the re

ceiver with a valid password.
File Settings Outgoing Virtual File Dataset Name This parameter determines the data
set name of the outgoing virtual file.
File Format This parameter determines the for

mat of the outgoing file. The options
available are given below:
○ Fixed Length
○ Text
○ Variable
○ Unstructured
Encoding This parameter defines the format to

encode the file before transmission.
The available file encoding formats
are given below:
○ ISO-8859-1
○ EBCDIC
Description This parameter allows you to describe

the outgoing file.

Quality of Service Quality of Service This parameter determines the man
ner in which the recipient’s receive the
gine.
The following types of Quality of Serv

ice are available:
○ Exactly Once (asynchronous) :

essed exactly once.
(asynchronous) : The messages
sent by the sender.
○ Better effort (synchronous) : The
the process.
Archiving Archiving Messages This parameter archives the OFTP

messages on the PI server.
Incoming Payload to the Channel This parameter enables you to archive

the incoming OFTP messages to a lo
Outgoing Wired Message This parameter enables you to archive

the outgoing OFTP messages to a lo
Incoming EERP This option archives incoming EERP

Filename field.
Incoming NERP This option archives incoming NERP

Filename field.
13. Choose the Technical Settings tab page and based on the Transport Protocol you have specified, follow the
sub-steps below:

1. If you select the transport protocol as TCP/IP, enter the values of the parameters as described in the
table below:
Technical Settings Allow Compression (1.X RLE) This parameter enables the adapter
to compress the data as per the Run
Length Encoding (RLE) compression
type.
Version Negotiable This parameter enables the adapter

to negotiate the OFTP version with
the partner.
Send / Receive Capabilities This parameter allows you to specify

the send/receive capabilities of the
location (whether send only or both
send and receive).
Max Credit Count This parameter determines the max

imum credit limit available for the
data exchange buffers sent to the lis
tener. The credit count value de
pends on the router.
Max Exchange Buffer Size This parameter determines the max

imum exchange buffer size that can
be accepted by this location. The
value of this size depends on the
router.
Userfield SSID This parameter defines the Service

Set Identifier (SSID), which is a
unique ID used for establishing con
nection with the wireless network.
ment between two FTPs for realizing
this service.

to spaces.

Userfield SFID This parameter defines the Service
Flow Identifier (SFID), which is a
unique ID defined by DOCSIS and it
represents either an upstream or a
downstream flow of data. There
tween two FTPs for realizing this
service.

to spaces.
2. If you select the transport protocol as ISDN, enter the values of the parameters as described in the
table below in addition to the technical setting parameters that are available for TCP/IP:
X.25 Settings Use X.25 This parameter allows you to use the
X.25 protocol for electronic data ex
change over the network.
Called Number This parameter defines the destina

tion number of the partner without
the area code.
Calling Number This parameter defines the senders

number without the area code.
Packet Size This parameter determines the size

of data used in the X.25 interchange.
Retain the default values.
Window Size This parameter determines the max

imum number of data packets that
are exchanged. Retain the default
values.
14. Choose the ERP tab page and enter the values in the fields based on the description of the parameters
mentioned in the table below:

ERP Create New XI Message for received This parameter allows the adapter to
ERP create acknowledgment for the re
ceived ERP. The types of content of
the XI message are given below:
○ Both Positive and Negative ERP:

This acknowledgment contains
details on both successful and
unsuccessful interchange.
○ Negative ERP Only: This acknowl
edgment contains details on un
successful interchange.
Referenced ERP Channel Communication Channel This parameter specify the channel
that maps the OFTP sender channel
configured with OFTP ERP as the
transport protocol.
Party This parameter determines the

the network.
Communication Component This parameter specify the communi

cation component of the OFTP sender
channel configured with OFTP ERP as
the transport protocol.
15. Choose the CMS tab page and enter the values in the fields based on the description of the parameters
mentioned in the table below:
 Note
All CMS features are supported by OFTP Version 2.0 and above. If you have chosen a version prior to
2.0, then the CMS tab page is unavailable.
OFTP 2.0 Parameters Key store containing own certificates This parameter allows you to view and
and keys use your certificates and keys from
the SAP NetWeaver Administrator key
store.
Key store containing partner This parameter allows you to view and
certificates use partners certificates and keys
from the SAP NetWeaver Administra
tor key store.

Encrypt Files This parameter defines the algorithm
for encrypting the received messages.
ment between two FTPs for activating
this service. You use the appropriate
algorithm from the Encryption
Algorithm field.
Sign Files This parameter defines the algorithm

for signing the OFTP message. There
tween two FTPs for activating this
service. You use the appropriate algo
rithm from the Signing Algorithm field.
Use Secure Handshake This parameter allows both the com

munication channels to identify them
selves before opening a session.
Use Compression This parameter enables the adapter to

compress the file before sending it.
Request Signed ERP This parameter enables the adapter to

sends a request to the partner for
signed End-to-End Responses.
 Note
The CMS options does not negotiate between the FTP systems. If the CMS options in the sender and
receiver channels do not correspond with each other, then the file transfer fails.
1.1.3 Configuring the Communication Channels with the X.

400 Adapter
Use
You configure communication channels with the X.400 adapter to enable the exchange of electronic mails for
commercial communication. The X.400 mailing system is used in business environments that focus on a highly
reliable messaging system for routine data exchange between trading partners. For example, a mail or message
can contain a bill or invoice that is exchanged between end users. The X.400 message consists of several
addressing elements that are user specific.
Consider X.400 adapter as an e-mail client that is used to access and manage the messages stored on a mail
server based on the attributes defined in the adapter. The X.400 adapter communicates with systems specific

to a domain through the X.400 Message Store (MS). It is implemented using the P7 protocol, which enables
the adapter to connect to mailboxes.
For more information on what is supported, please refer to the following topics:
● Configuring X.400 Sender Channel [page 53]

● Configuring X.400 Receiver Channel [page 64]
Prerequisites
● You have deployed the X.400 adapter in the SAP Process Integration environment.
● You have created Business Component and Communication channels.
● You have obtained the latest BusinessMail X.400 or MTA certificates, and imported them to the trusted
keystore.
● You have chosen and imported the Root CA or the Intermediate CA certificate of the host MTA.
● You have obtained all the User Data and Recipient parameters of the X.400 mailbox.
Procedure
1. Configure the sender channel with the X.400 adapter to process inbound messages and to read the
delivery reports from the X.400 mailbox.
For more information, see Configuring X400 Sender Channel [page 53].
2. Configure the receiver channel with the X.400 adapter to process outbound messages.
For more information, see Configuring X400 Receiver Channel [page 64].
 Note
Do not configure sender or receiver channels in development, test and production landscapes with the
same mailbox. The X.400 adapter does not support sharing the same mailbox between distinct PI systems.
You use different mailboxes for individual PI system.
1.1.3.1 Multiplexing Mode for Telebox Connections in

Cluster Environment
The X.400 Sender and/or Receiver Channels support the following four types of connections to communicate
with X.400 Servers:
● Singleton (The default one): Opens and closes the connection to the X.400 mailbox account. You can use it
if the X.400 server supports multiple connections or the expected load is very low. For example, one
message at a time and no parallel processing.

● Shared: Shared for all sender and receiver X.400 communication channels for the same X.400 mailbox
account, and can be relocated between the server nodes of a multi-node/cluster PI system. You should use
it in cluster environment with one java application server node.
● Multiplexing all channels: Recommended connection type in cluster environment with more than one java
application server node.
● Multiplexing single channel: Use this connection if you want to have single connection to the Telebox Server
per channel instead of per X.400 Account.
Multiplexing connections type uses X.400 Multiplex Proxy where XI messages on all server nodes are
processed in parallel. There is no relocation of the connection between the server nodes. This increases the
overall transmission performance and avoids the message processing errors due to connection relocation
timeout.
Our recommendation is to use the Shared connection mode in case of single-node/cluster PI environments,
and Multiplexing connection mode in case of multi-node/cluster PI environments.
In order to enable the new connection type, you should change the property "connection.type" of application
"com.sap.aii.adapter.x400.app". Additional optional parameters are provided for tuning the new connection
type.
You can configure the below mentioned parameters by navigating to http://host:port/nwa/sys-config

Applications tab Filter for "com.sap.aii.adapter.x400.app" .

Parameter name Type/Possible values Default value Description
connection.type LONG 16 The type of the connection to be used for one

X400 mailbox account.
2
2 - Multiplexing All Channel connection is reused
4
by all X.400 channels on all server nodes to one
8 X.400 mailbox account. In one moment only one
connection to the X.400 mailbox account exists
16
in the whole cluster and all server nodes can
share that connection through the X.400 proxy.
This means that all server nodes can send/
receive X.400 messages in parallel. There is no
cluster locking to obtain the connection, and
therefore no timeout for the same. The proxy
used for the communication is started on re
quest on the server node that has first initiated
the connection and on the port specified with
the property X.400.proxy.port (see below). Once
the proxy is started, the entire communication to
the X.400 servers is routed through that proxy.
The proxy is relocated only in case the server
node on which it was started is stopped due to
some reason. The requests from all X.400 com
munication channels configured for the same X.
400 mailbox account are placed in first-in-first-
out queue for inbound connections of the X.400
proxy. The proxy then reuses the single out
bound connection to the X.400 mailbox account
for each request.
4 - Multiplexing Channel is similar to the

Multiplexing All Channels connection type. The
only difference is that the single connection is
not per X.400 mailbox account but per X.400
communication channel.
8 - Shared connection is reused for all communi

cation to one X.400 mailbox account and is relo
cated between the server nodes. This means
that in one moment only one connection to the
X.400 mailbox account exists in the whole clus
ter and is shared between all sender and receiver
X.400 channels connected to that X.400 mail
box account. The connection is opened on re
quest (i.e. sending/receiving X.400 messages)
and is closed either after a specified idle time, or
if it needs to be relocated to another server
node. Before relocating the connection to an
other server node first it disconnects from the X.

400 server on the currently processing node

(when no channels are using it) and connects
again to the X.400 server on the waiting server
node. If more than one server nodes are waiting
for the connection then only one will "lock" the
connection and use it and the rest will continue
to wait till the connection is being relocated to
them.
16 - Singleton connection is opened and closed

each time a call to the X.400 mailbox account is
performed. This means that there could be as
many connections to one X.400 mailbox ac
count as many parallel channels/XI messages
are executing/being processed at the same
time. The connection will be disconnected each
time the channel processing is completed.
X400.proxy.hosts STRING Comma separated list of the IP Addresses of all

Java Instances of the PI system. This parameter
IP addresses
is optional and must be used only if the auto
matic resolve of the IP Addresses is not possible.
Used in case of Multiplexing connection type.
X400.proxy.check.client BOOLEAN true Option to verify the IP Address of the caller to

the proxy in case of Multiplexing connection
Caller's IP address
type. If enabled, the X.400 proxy will check if the
check
IP Address of the caller is one of the IP Ad
dresses of the Java Instances of that SAP Sys
tem. If it is not part of that list, then the call is re
jected.
X400.proxy.port LONG 59973 Option to specify the port number on which the
X400 proxy will listen for incoming connections
X400 proxy listening
(connections from X.400 Channels)
port
X400.proxy.debug BOOLEAN false Option to enable tracing of the content passing

through the X.400 proxy. If enabled, the content
tracing of content
will be written in the default traces in case of
through the proxy
tracing severity set to DEBUG for tracing loca
tion com.sap.aii.adapter.x400.ra.integra
tion.connection.
connection.idle.time LONG 30 The maximum time (in seconds), for which a

Shared connection can stay idle after which the
number of seconds
connection will be closed.

connection.ttl LONG 3600 Time to live - the maximum time (in seconds),
for which a Shared connection can stay opened.
number of seconds
connection.try.lock.time LONG 60 The maximum time (in seconds) a server node

tries to get a lock to open a Shared connection. A
number of seconds
server node cannot open a connection to the X.
400 mailbox account unless it has already ac
quired the enqueue lock for that connection. If a
server node has acquired the enqueue lock for
the X.400 mailbox account connection then it is
either connecting or already connected to the X.
400 mailbox account.
If the lock cannot be obtained within the speci

fied time, a ConnectionTimeoutException ap
pears. You may consider increasing the lock wait
time in case you experience the ConnectionTi
meoutException often and your performance re
quirements allow so. Increasing this value will
mean that messages can wait up to the specified
time in seconds until they are processed or
marked as failed.
connection.try.connect.co LONG 5 The maximum number of attempts a Shared

unt connection tries to connect to the X.400 mailbox
number of connect at
account once a connection lock is acquired (see
tempts
connection.try.lock.time). The several connect
attempts support the case in which the X.400
server requires some time between a discon
nect-connect sequence of operations, this value
can be increased accordingly.
Each attempt is executed in 1 second interval.
This property should be increased in case the X.

400 mailbox account needs more time to re
cover from a disconnect event before a connec
tion can be established again.

sender.blockingDelete BOOLEAN false An option to enable blocking delete from the

X400 mailbox account in case of Shared connec
true/false
tion type.
If this option is not enabled, the delete operation

will allow parallel communication through that
connection (for example, the receiver channels
can take the connection and send messages to
the same X.400 mailbox account) on the same
server node. This can significantly slow down the
delete operation and therefore the whole poll ex
ecution.
If the option is enabled, the bulk delete per

formed by a polling sender channel will block all
other communication through that connection
on the same server node. However, the delete
operation will require less time compared to a
non blocking delete.
The properties “connection.type” and "sender.blockingDelete” can also be configured on channel level as
additional property in Advanced Mode.
1.1.3.2 Configuring X.400 Sender Channel
Context
You use this procedure to configure the sender channel settings in the X.400 adapter.
Procedure
1. Configure the sender channel with the X.400 adapter to process inbound messages.
For more information, see Configuring X.400 Sender Channel for Inbound Message Processing [page 54].
2. Configure the sender channel with the X.400 adapter to read the delivery reports from the X.400 mailbox.
For more information, see Configuring X.400 Sender Channel with X.400 Delivery Report XML [page 61].

1.1.3.2.1 Configuring X.400 Sender Channel for Inbound
Message Processing
Context
You use this procedure to configure the sender channel with X.400 Message Transfer Agent (MTA) to retrieve
messages from the mailbox.
Procedure

8. Choose the Parameters tab page and select the Sender radio button for the X.400 adapter to perform
inbound message processing.
9. Choose the Mailbox tab page and enter the values in the respective fields based on the description of the
parameters given in the table below:
Telebox Server Host This parameter determines the host

name of the X.400 Message Store.
The X.400 adapter supports only
TCP/IP-based network connectivity.
The host name of the mail server,
which uses SSL protocol, must match
the host name specified in the certifi-
cate.
Contact your “Message Store” pro

vider to obtain the host name of the
mail server.

Server Port This parameter identifies the port
number of the mail server. Contact
your “Message Store” provider to ob
tain the port number of the mail
server.
Presentation Selector This parameter addresses a layer in

the Open Systems Interconnection
(OSI) framework configured on an
MTA. The default value is “OMSPSAP.”
Session Selector This parameter addresses a layer in

the OSI framework configured on an
MTA.
The default value is

“SOMS_OSI_SERVER.”
Transport Selector This parameter addresses a layer in

MTA.

“TOMS_OSI_SERVER.”
SSL Use SSL This parameter allows the adapter to

connect to the X.400 Message Store
host using SSL encryption.
To access the X.400 Message Store

using SSL protocol, you must import
the public key certificate of the mes
sage store and deposit them in the
trusted keystore of the PI system.

vider to obtain the certificates and
also ensure the validity of the certifi-
cates as it is updated at regular inter
vals.
SOCKS Proxy Use SOCKS Proxy This parameter allows the adapter to
establish connection with the mail
server using a proxy server. The X.400
adapter supports SOCKS proxy, but it
does not support user authentication
SOCKS proxy.

SOCKS proxy host name.

Port This parameter identifies the SOCKS
proxy port number.
User Data Common Name (CN) This parameter describes the user's
name created in the mailbox.
Contact the “Message Store” provider

to obtain details about the mailbox.
Surname (S) This parameter describes the user's

surname created in the mailbox.

Administrative Domain (A) This parameter describes the network

connection that identifies the sender’s
location within the organization. The
domain can usually be a public mail
service provider.

Country (C) This parameter describes the name of

the country that is specific to the Ad
ministrative Domain.

Organization Name (O) This parameter describes an organi

zation to which the sender belongs.

Organization Unit Name (OU) This parameter describes a specific

division or department in an organiza
tion, to which the sender belongs.

Private Domain Name (P) This parameter describes the private

network connection within an organi
zation.


sender message using a valid pass
word.

Period Poll Interval (min) This parameter defines that the

adapter checks for mails in the mes
sage store.
Maximum number of messages per This parameter specifies the maxi

poll mum number of messages that is re
trieved during each polling interval.
10. Choose the Processing tab page and enter the values in the respective fields based on the description of
the parameters given in the table below:
 Note
The parameters on the Processing tab page allow you to define the message transfer process in an
adapter.
Message Do not delete messages from server This parameter defines that the
adapter retains the messages after
reading. According to the values in the
Period component, the adapter re
trieves the same set of messages
from the message store. Tip: You can
test the connectivity of the server by
checking this option.
Discard empty body parts This parameter defines that the

adapter rejects messages with empty
content.

Multiple Body Parts This parameter determines the proc
essing of EDI documents based on the
two options given below:
○ Create one PI message per X.400

message: Allows you to create
one EDI document, and then at
taches the remaining body parts
as an additional attachment.
○ Create one PI message per X.400
body Part: Allows you to create
one EDI document, without any
attachment.

ner in which the recipients receive the
gine, based on the two options:

essed exactly once.
(asynchronous): Messages with
the identical queue name are de
livered to the recipient. This
Quality of Service option ensures
that the messages are in the
by the sender.
the process.

Content based Sender Determination Enable This parameter enables the Content-
based Sender Determination option to
deliver the message to the sender on
the basis of the content in the mes
sage. The description for each column
in the table is given below:
○ Attachment Number: This col

umn determines the body part
number; the number starts from
zero. According to the rule of the
content search, the value in the
column applies only to the body
part.
○ Contains: This column defines a
list of values that are separated
by commas. These values em
bedded in the message identify
the partner’s message by match
ing the parameters.
○ S Party: This column determines
the sender party of the PI mes
sage created by the X.400
adapter. The message content is
identified by the attachment
number.
○ R Party: This column determines
the receiver party of the PI mes
sage created by the X.400
number.
○ S Service: This column deter
mines the sender service of the
PI message created by the X.400
number.
○ R Service: This column deter
mines the receiver service of the
PI message created by the X.400
number.
○ Action/Interface: This column de
termines the sender interface of
the PI message created by the X.
400 adapter. The message con

tent is identified by the attach
ment number.
○ Namespace: This column deter
mines the sender interface
namespace of the PI message
created by the X.400 adapter.
The message content is identified
by the attachment number.
Use Matching Sender Agreement This parameter determines a particu

lar sender agreement that matches
the security attributes of the mes
sage. A sender agreement defines
that the Integration Engine processes
the messages. We recommend that
you enable this option.
 Note
○ You can view the acknowledgements in communication channel logs and also in audit logs.
11. Choose the Advanced tab page and enter the values in the respective fields based on the description of the
parameters given in the table below:
Archiving Archive X.400 Messages This parameter archives X.400 mes

sages on any file server. The location
of the target folder is provided in the
Archive name field.
Archive Payload of Messages This parameter archives X.400 mes

sages with a payload on any file
server. A payload can be an additional
file such as a PDF document that is at
tached to the message. The location
Archive name field.

change messages.
messages.

 Note
archived file.

1.1.3.2.2 Configuring X.400 Sender Channel with X.400

Delivery Report XML
Use
You configure the communication channels to process and retrieve Delivery Reports generated in X.400
mailbox. The communication channel retrieves the delivery report as per the polling interval set in the referred
X.400 sender channel configured with X.400 Message Content. The referencing channel creates the PI
message as per the Integrated Configuration.
You use this procedure to configure the X.400 sender channel with the X.400 Delivery Report XML type
message protocol to read the delivery reports from the X.400 mailbox in line with the polling interval of the
referred channel.
Prerequisites
● You have created dedicated Communication Channels for retrieving Delivery Reports in the same
configuration scenario where X.400 communication channels are created.
Procedure

2. In the Type column, double-click the communication channel.
3. In the Display Communication Channel screen area, enter the channel parameters.

8. Choose the Parameters tab page and select the Sender radio button.
9. In the Adapter Type field, select X400.
10. In the Transport Protocol field, select TCP/IP.
11. In the Message Protocol field, select X.400 Delivery Report XML.
12. In the Adapter Engine dropdown list, select Central Adapter Engine.
13. In the Referenced Polling Channel section, enter the values in the fields based on the description of the
Referenced Polling Channel Communication Channel This parameter determines to polls

the X.400 sender communication
channel.
Party This parameter defines a business

partner or an organization of the
sender.
Communication Component This parameter represents a technical

or business entity that addresses the
sender of the message.
 Note
1.1.3.2.3 Configuring the X.400 Sender Polling Channels

for Automatic Deletion of Duplicate Entries
You can configure the X.400 sender polling channels to automatically delete duplicate entries.
Prerequisites
You have applied SAP Note 2357976 and you have enabled the sender.duplicateCheck on global or channel
level.
In case of failed delete operation (for example, due to connection/network issues), you need to manually delete
the corresponding X.400 messages from the X.400 mailbox account.

Configuration
You can configure this option by the following steps:
1. Navigate to http://host:port/nwa/sys-config Applications tab Filter for

"com.sap.aii.adapter.x400.app" property sender.deleteDuplicates
2. You can also configure t he property on sender channel level as additional property in Advanced Mode.
By default, the value of the property sender.deleteDuplicates is false.
 Note
If you want to activate the automatic deletion of messages recognized as duplicates by a polling X.400
sender channel, you need to enable this option manually as described above.
If an X.400 message is read and processed successfully, but the delete operation failed, on the next poll the
message will be recognized as duplicate and will not be processed. If the option sender.deleteDuplicates is
enabled the polling channel will try to delete the duplicate message.
For more information about the duplicate check, see 2357976
1.1.3.2.4 Configuring the X.400 Sender Polling Channels

for Duplicate Check
You can configure a default duplicate check for the sender X.400 sender polling channels.
Overview
If an X.400 message is read and processed but the delete operation fails, on the next poll the message will be
recognized as duplicate and will not be processed.
 Note
Please, note that the X.400 adapter will not make a second attempt to delete the message from the
Telebox.
Therefore, the message should be deleted manually or by activating automatic deletion using the property
sender.deleteDuplicates.
Use
The duplicate check for delivery and non-delivery reports assumes that either one delivery or non-delivery
report can be received for a sent message.
You can enable/disable the duplicate check on global and channel level.
● You can make the global configuration via the property sender.duplicateCheck of the application
com.sap.aii.adapter.x400.app.
● You can add the channel configuration can sender polling channels as additional property
sender.duplicateCheck in Advanced mode. The duplicate check data will be kept for a default period of time
that is one day.
● You can change the duplicate check persist time on global level via the com.sap.aii.adapter.x400.app
application property duplicateCheckPersist.

 Note
Please, note that the duplicate check should not be enabled in case the sender polling channels are
configured with the option Do not delete Messages from Server.
1.1.3.3 Configuring X.400 Receiver Channel
Use
You use this procedure to configure the receiver channel with the X.400 adapter to transmit the message to the
mailbox.
Procedure

8. Choose the Parameters tab page and select the Receiver radio button for the X.400 adapter to perform
outbound message processing.
9. Choose the Mailbox tab page and enter the values in the respective fields based on the description of the
Telebox Server Host This parameter determines the host

name of the X.400 Message Store.
The X.400 adapter supports only
TCP/IP-based network connectivity.
The host name of the mail server,
which uses SSL protocol, must match
with the host name specified in the
certificate.

vider to obtain the host name of the
mail server.

Server Port This parameter identifies the port
number of the mail server.

vider to obtain the port number of the
mail server.
Presentation Selector This parameter addresses a layer in

the Open Systems Interconnection
(OSI) framework configured on an
MTA.
The default value is “OMSPSAP.”
Session selector This parameter addresses a layer in

MTA.

“SOMS_OSI_SERVER.”
Transport selector This parameter addresses a layer in

MTA.

“TOMS_OSI_SERVER.”
SOCKS Proxy Use SOCKS Proxy This parameter allows the adapter to
establish connection with the mail
server via a proxy server. The adapter
does not support SOCKS proxy au
thentication.

SOCKS proxy host name.
Port This parameter identifies the SOCKS

proxy port number.

SSL Use SSL This parameter allows the adapter to
connect to the X.400 Message Store
host using SSL encryption.
To access the X.400 Message Store

using SSL protocol, you must import
the public key certificate of the mes
sage store and deposit it in the trusted
keystore of the PI system.

vider to obtain the certificates and
also ensure the validity of the certifi-
cates, as they are updated at regular
intervals.
10. Choose the Processing tab page and enter the values in the respective fields based on the description of
the parameters in the table below:
 Note
The parameters on the Processing tab page allow you to define the message transfer process in an
adapter.
Userdata Common Name (CN) This parameter describes the user's

name created in the mailbox.

Surname (S) This parameter describes the user's

surname created in the mailbox.


connection that identifies the sender’s
location within the organization. The
domain can be usually a public mail
service provider.




zation to which the sender belongs.


tion to which the sender belongs.


zation.


sender message using a valid pass
word.

Recipient Common Name (CN) This parameter describes the name of

the recipient’s address.

to obtain details about the recipient’s
address.
Given Name (G) This parameter describes the name

that precedes the surname of the re
cipient’s address.

address.

Surname (S) This parameter describes the sur
name of the recipient’s address.

address.

connection that identifies the recipi
ent’s location within the organization.
The domain can usually be a public
mail service provider.

to obtain details about the recipient.



zation to which the recipient belongs.


tion to which the recipient belongs.


zation.

Domain Defined Attributes This parameter defines the attributes

that are not found in the standard X.
400 message envelope. These addi
tional attributes are provided by the
recipient’s organization.

Message Configuration Content Type This parameter determines the stand
ard of the content or payload in the
business document. Only
Interpersonal Message type is availa
ble.
Subject This parameter defines the subject of

the message.
Delivery Report This parameter requests an acknowl

edgement if the message delivery is
successful. For more information, see
Configuring Delivery Report Message
Protocol [page 75].
Non-Delivery Report This parameter requests an acknowl

edgement if the message delivery is
not successful. For more information,
see Configuring Delivery Report Mes
sage Protocol [page 75].

Bodypart Type This parameter determines the type
of information interchange format
used in parts of a multipart message.
The available types of the body part

are given below:
○ IA5 text: This allows 7 bit ASCII

characters
○ Bilaterally defined: This is defined
for binary data and allows the
character set conversion in a
message received by the recipi
ent. This scenario arises when
the message at the source has
characters encoded by a unique
data format that is different from
the data format when the mes
sage is decoded at the destina
tion. For example, consider a
message that contains signs that
are not supported by the data
format available at the destina
tion. These unmatched or un
mappable characters can be re
placed, ignored, or reported. The
Replace option in the
Unmappable Characters field al
lows you to replace the charac
ters in the message. You can de
fine the replaceable character in
the Replacement Character field.
 Note
Please, note that when an
adapter receives a UTF-8
document from PI and this
document is converted to 7-
bit ASCII format, then you
lose the information in the
document.
General text: This type of body can

use any number of character sets and
announces them in the encoded infor
mation types of the X.400 envelope
and the parameters of the body part.

 Note
Please, note that X.400 Receiver
channels cannot generate and
sent such body parts.
More information about this body

type and its features is given in the fol
lowing specification: https://
tools.ietf.org/html/rfc1502
11. Choose the Advanced tab page and enter the values in the respective fields based on the description of the
Message Submission Report Send submission result to HTTP This parameter submits a report
adapter about a message to the HTTP
adapter. The report contains meta
data about the submission of a mes
sage to the mailbox such as address,
time, identifiers, and so on.
Use this parameter to store the X.400

message according to the message
delivery time.

TCP/IP or host name of the mail
server.

the mail server.
Path This parameter identifies the address

path of the mail server.
Sender Namespace This parameter determines the con

text of the message in abstract. For
example, the namespace can be tech
nical terms or words specific to the
message.
You find this information in the mes

sage header.

Sender Interface This parameter determines the inter
face to communicate with the sender
system.

sage header.
Sender Service This parameter determines the type

of sender service.

sage header.
Sender Party This parameter determines the com

munication party, which helps you to
address the sender message.

sage header.
Sender Agency This parameter determines the

agency, which recommends the mes
sage format.

sage header.
Sender Scheme This parameter identifies the scheme

based on a value specified by the
Sender Agency.

ner in which the individual recipients
receive the message from the Integra
tion Engine based on two options:
○ Exactly Once: The message is

sent and processed exactly once.
○ Exactly Once in Order: The recipi
ent receives the messages in the
by the mail server. This sequenc
ing of messages is known as Ex
actly Once In Order (EOIO).
Queue ID This parameter is available only if the

quality of service is EOIO. It deter
mines the conversation ID of the mes
sage in the queue, whose length is 16
characters.

SAP User This parameter authenticates the SAP
user with a valid user name.
SAP Password This parameter authenticates the SAP

user with a valid password.
SAP Client This parameter determines the num

ber of SAP clients.
SAP Language This parameter defines the language

of the report.
Priority This parameter defines the priority of

the messages and has the following
values:.
Urgent
Normal (default)
Non Urgent
Probe Submission This is different type of message argu

ment. Its purpose is to check whether
a message can get from one User
Agent to the Message Store, then to
the desired recipient of the message,
and back to the originator of the mes
sage. This functionality is imple
mented in the channel ping.
Deferred Delivery Time This parameter defines when the

message store (not the X400
Adapter) have to send the message to
the target user agent (the recipient).
The configuration is in minutes. This
means that the time will be set ac
cording to the time that the X400
starts to process the message the mi
nutes set in the channel. The default
time is 60 min.
 Note
Please, note that there is no way
to cancel deferred delivery mes
sages neither from the X.400
Adapter, nor from the B2B Inte
gration Cockpit.

Archiving Archive X.400 Messages This parameter archives X.400 mes
sages on any file server. The location
Archive name field.
Archive payload of messages This parameter archives X.400 mes

sages with a payload on any file
server. A payload can be an additional
file such as a PDF document that is at
tached to the message. The location
Archive name field.

change messages.
messages.
 Note
Archiving: This feature enables you to save messages transmitted from a source or destination database
"in original format" on your file system. It is the first task practiced after receiving messages with regard to
sender channel and the final task practiced before sending messages with regard to receiver channel. The
location of the archived files are shown in the Archive name text box. The file path of the archiving location
can contain the substitution parameters to ensure uniqueness of the archived file.
● %SEQNUM: A sequence number, starting with 1

● %RTSEQNUM: A server wide sequence number, starting with 1
● %START: The start time of the adapter
● %TIME: The archiving period in milliseconds
● %MSGID: The XI message ID
For example, the archiving parameters used to define a file path to an archive location are shown as "D:/
x400Archiv/%TIME_%SEQNUM.msg".

1.1.3.3.1 Configuring Delivery Report Message Protocol
Prerequisites
You have created dedicated Communication Channels for retrieving Delivery Reports in the same configuration
scenario where X.400 communication channels are created.
Context
You configure the communication channels to process and retrieve Delivery Reports generated in X.400
mailbox. The communication channel retrieves the delivery report as per the polling interval set in the referred
X.400 sender channel configured with X.400 Message Content. The referencing channel creates the PI
message as per the Integrated Configuration.
Procedure
1. Configure the X.400 sender channel with the X.400 delivery report XML. For more information, see
Configuring X.400 Sender Channel with X.400 Delivery Report XML [page 61].
2. Configure receiver channel with the File adapter to access and retrieve the delivery reports from the X.400
mail server.
1.1.4 Configuring the Communication Channel with EDI

Separator Adapter
Prerequisites
● You have deployed the EDI separator adapter in the SAP Process Integration environment.
● You have created business component and communication channels.

Context
You configure the communication channels with the EDI separator adapter to split the incoming batch EDI
messages into individual EDI messages. The messages are split based on the content of the business
document and the partner type.
The batch EDI message contains specific EDI formats for each of the message types that represent various
business documents or transactions such as Purchase Order, Invoice, Delivery Forecast, and so on. The SAP
Process Integration I EDI separator adapter supports the following EDI formats:
● ANSI ASC X12

● EDIFACT
● EANICOM
● TRADACOM
● Odette
● VDA
● Custom Format
Procedure
1. Configure the sender channel to allow the Integration Engine to process inbound messages.
For more information, see Configuring the EDI Separator Sender Channel [page 76].
2. Configure the receiver channel to allow the Integration Engine to process outbound messages.
For more information, see Configuring the EDI Separator Receiver Channel [page 91].
3. To configure alerts for EDI Separator adapter, see B2B Alerts [page 258]
1.1.4.1 Configuring the EDI Separator Sender Channel
Context
You use this procedure to configure the sender channel with EDI separator adapter based on the message
protocol.
Procedure

5. Display Language field, select the required application UI language.
6. Choose the In the Identifiers tab page and enter the parameters that identifies the sender and receiver
agencies.
7. Choose the Module tab page and enter the parameters that specifies generic modules for the adapters
8. Choose the Parameters tab page and select the Sender radio button to enable the EDI separator adapter to
perform inbound message processing.
9. In the Transport Protocol field, select PI.
10. In the Message Protocol dropdown, select the required message protocols and follow substeps given below:
1. If you select the message protocol as ANSI X12, enter the values for the filter parameters as described
in the table below:
Receive Split ISA In the When a message contains

more than one interchange (ISA/
IEA), the EDI Separator Adapter
splits the messages on ISA level and
sends the child ISA/IEA inter
changes to an appropriate EDI Sepa
rator Sender channel with this op
tion enabled.
Receive Bulk message When a batch X12 message is being

processed and the parameter Keep
Bulk message is enabled in the EDI
Separator Receiver channel, the
Adapter does not split the bulk X12
message into child messages and
sends the whole message to an ap
plicable EDI Separator Sender
channel with this option enabled.
Filter Version/Release/Industry Identifier This parameter allows you to deter

Code mine the appropriate predefined
ANSI ASC X12 standards.
You can define a parameter using

regular expressions in the field.
Other Code This parameter allows you to define

a suitable ANSI ASC X12 standard in
the Version/Release/Industry
Identifier Code field.

Receive Splitted Group This parameter enables the adapter

to receive
group message after splitting.
Transaction Set Identifier Code This parameter determines the

transaction set number of the mes
sage. The number helps to identify
the transmission of the transaction
from the sender channel.

Interchange Sender ID This parameter identifies the sender

of the interchange. The identification
of the sender must be same as the
values in the ISA segment of the in
coming message.

Interchange Sender ID Qualifier Provide the EDI qualifier ID for iden

tifying the sender party’s inter
change.

Interchange Receiver ID This parameter identifies the re

ceiver of the interchange. The identi
fication of the receiver must be
same as the values in the ISA seg
ment of the incoming message.

Interchange Receiver ID Qualifier Provide the EDI qualifier ID for iden

tifying the receiver party’s inter
change.

Interchange Application Sender ID Define the interchange ID of the

sender party.

Interchange Application Receiver ID Define the interchange ID of the re

ceiver party.
2. If you select message protocol as EDIFACT, enter the values for the filter parameters as described in
the table below:
Receive Split UNB When a message contains more

than one interchange (UNB/UNZ),
the EDI Separator Adapter splits the
messages on UNB level and sends
the child UNB/UNZ interchanges to
an appropriate EDI Separator
Sender channel with this option ena
bled.
Receive Bulk message When a batch Edifact message is be

ing processed and the parameter
Keep Bulk message is enabled in the
EDI Separator Receiver channel, the
Adapter does not split the bulk Edi
fact message into child messages
and sends the whole message to an
applicable EDI Separator Sender
Filter Enter the Message type using free This parameter allows you to enter
text free text in the message type field.
Enter Message Release Number This parameter allows you to enter

using free text free text in the message release
number field.
Enter Message Version Number This parameter allows you to enter

using free text free text in the message version
number field.
Message type This parameter allows you to deter

mine the appropriate predefined ED
IFACT message types.


Message version number This parameter allows you to deter
IFACT version number.

Message release number This parameter determines the re

lease number of the message. The
number helps to identify the trans
mission of the transaction from the
sender channel.

Message Subversion This parameter allows you to deter

IFACT subversion (association as
signed code).

Interchange sender identification This parameter identifies the sender

values in the UNB segment of the in
coming message.
Interchange sender identification This parameter allows you to deter

code qualifier mine the appropriate standard code
qualifier for the sender.
Interchange recipient identification This parameter identifies the re

same as the values in the UNB seg

Interchange recipient identification This parameter allows you to deter

qualifier for the receiver.
3. If you select message protocol as EANCOM, enter the values for the filter parameters as described in
the table below:

Receive Split UNB When a message contains more
than one interchange (UNB/UNZ),
the EDI Separator Adapter splits the
messages on UNB level and sends
the child UNB/UNZ interchanges to
an appropriate EDI Separator
bled.
Filter Enter Message Version Number This parameter allows you to enter
number field.

mine the appropriate predefined
EANCOM message types.


EANCOM version number.

Message release number This parameter determines the re

lease number of the message. The
number helps to identify the trans
mission of the transaction from the
sender channel.

Message Subversion This parameter allows you to deter

EANCOM subversion (association
assigned code).


values in the UNB segment of the in
coming message.



same as the values in the UNB seg


4. If you select message protocol as Odette, enter the values for the filter parameters as described in the
table below:
None Receive Bulk message When a batch Odette message is be

'Keep Bulk message' is enabled in
the EDI Separator Receiver channel,
the Adapter does not split the bulk
Odette message into child messages
Enter Message Version Number This parameter allows you to enter

number field.

Odette message types.


Odette version number.


of the interchange.



ceiver of the interchange.


5. If you select message protocol as VDA, enter the values for the filter parameters as described in the
table below:
None Receive Bulk message When a batch VDA message is being

processed and the parameter 'Keep
Bulk message' is enabled in the EDI
Separator Receiver channel, the
Adapter does not split the bulk VDA
message into child messages and
sends the whole message to an ap
plicable EDI Separator Sender chan
nel with this option enabled.

VDA message types.


Customer number This parameter determines the cus
tomers' identification number.

Vendor number This parameter determines the ven

dors' identification number.

6. If you select message protocol as Tradacom, enter the values for the filter parameters as described in
the table below:
None Receive Bulk message When a batch Tradacom message is

being processed and the parameter
Tradacom message into child mes
sages and sends the whole message
to an applicable EDI Separator
bled.
Message Version This parameter allows you to provide

the appropriate tradacom version
number.


mine the appropriate predefined tra
dacom message types.

Sender Code This parameter determines the iden

tification code of the message
sender.


Sender Name This parameter determines the
name of the sender.

Receiver Code This parameter determines the iden

tification code of the message re
ceiver.

Receiver Name This parameter determines the

name of the receiver.

7. If you select message protocol as Plain, enter the values for the filter parameters as described in the
table below:
None Receive Bulk message When a batch Plain message is be

Plain message into child messages
Filter Message Type This parameter allows you to define

appropriate plain message type. The
adapter without splitting the mes
sage dispatches it to the appropriate
channel.

8. If you select message protocol as XML, enter the values for the filter parameters as described in the
table below:

Filter Enter XPath using free text You can define the path of the in
coming XML document, at which the
message is split. Using free text de
fine a parameter in the Split XPath
Expression field.
XPath This parameter finds specific infor

mation in an XML document. You de
fine a value that searches through el
ements and attributes for the re
quired information. For example, //
<root element>//<child element>
Condition This parameter defines logic for an

XPath Value to perform the valida
tion. The options available in this
field are as follows:
○ Equals
○ Not Equals
○ Exists
○ Does Not Exists
If you select Exists or Does Not
Exists option, then the XPath Value
field does not appear.
XPath Value This parameter defines the string

used in the XML document. The
string validates the value present in
the XPath. The result of the valida
tion depends on criteria set in the
condition field.
XML handling options Split XML This parameter splits the XML docu
ment at a specific node defined in
the split expression.
XML Split Path This parameter defines a path that

navigates to a node in the source
XML document, at which the mes
sage is split. If the node contains
multiple elements with the same
string, then the message is split into
several XML documents.

 Note
In the Advanced tab page provide the edi.xml.includeheader parameter to publishes only the
specific node in the source XML document as defined in the XML Split Path. You have to add this
parameter in name column of the Additional Parameters table and set the value to True.
9. If you select message protocol as Default, then the adapter detects messages that of unknown EDI
format and dispatches them to a appropriate sender channel without splitting.
11. Dynamic Configuration Routing enables the EDISeparator Adapter to support message routing based on a
configurable Dynamic Configuration header
Dynamic Configuration Filter Use Dynamic Configuration Filter This parameter enables the Adapter
to use Dynamic Configuration based
routing. To use this option, you need
to enable Use Dynamic Configuration
Routing in the EDI Separator Receiver
channel and define the parameters
Dynamic Configuration Header Name
and Dynamic Configuration Header
Namespace, as well.
Dynamic Configuration Header Name This parameter determines the

Dynamic Configuration header name
used for the message routing.
 Note
You cannot define this parameter
using regular expressions in the
field.
Dynamic Configuration Header This parameter determines the

Namespace Dynamic Configuration header
namespace used for the message
routing.
 Note
field.

Dynamic Configuration Header Value This parameter determines the
Dynamic Configuration header value
used for the message routing.
 Note
12. Enter the values for the parameters under Encoding, QoS, and Adapter Status sections based on the
description mentioned below:
Encoding Character encoding This parameter determines to encode

the message with specific character
encoding formats. The character en
coding supports EDIFACT, ANSI X12,
VDA, and Odette message types.
Given below are character encoding
formats that are available in the EDI
separator adapter:
○ UTF-8
○ ISO-8859-15
○ US-ASCII

QoS Quality of Service This parameter determines the man
ner in which the recipient's receive the
gine. The following types of Quality of
Service are available:

essed exactly once.
(asynchronous): The messages
sent by the sender.
the process.
Adapter status Adapter status This parameter has two options,

which are given below:

change messages.
○ Inactive: Disables the adapter to
exchange messages.
13. Enter the values for the Routing additional settings based on the description below:
Routing Create Copy and Route Will create a copy of the bulk message
and will send it to an EDI Separator
Sender channel with Message Proto
col Copy.

Routing Route on Error Whenever an error occurs, a copy of
the bulk message will be created and
will be sent to an EDI Separator
col 'Error'.
This means that you need an addi

tional ICO with EDI Separator Sender
channel with Message Protocol Copy
or Error, and a receiver channel that
will process the message - either send
it to the Partner, or keep it somewhere
on a file system.
1.1.4.1.1 EDI Sender Channel Detection
The EDI Separator adapter now detects and dispatches incoming split EDI messages to the relevant EDI sender
channels. In this context, an EDI receiver channel processes each incoming split EDI message by matching
specific message parameters with the EDI sender channel parameters. If the parameters match according to
their priority, the EDI receiver channel dispatches the EDI message to the relevant EDI sender channel.
The following list contains message parameters by priority:
● Sender ID
● Receiver ID
● Message Version
● Message Type
If any of the above-mentioned channel parameters contains “.*” as a value, the receiver channel checks the
next channel for the appropriate matching value based on the priorities.
If the option Use Dynamic Configuration Routing the match parameters priority changes. The following list
contains the parameters by priority:
● Dynamic Configuration Header Value

● Sender ID
● Receiver ID
● Message Version
● Message Type

1.1.4.2 Configuring the EDI Separator Receiver Channel
Context
You use this procedure to configure the receiver channel with the EDI separator adapter to split incoming batch
EDI messages into individual messages, and notify the recipient by transmitting an acknowledgment once the
EDI messages have been processed.
 Note
When an EDI message is split and sent to different ICOs, system must pass the dynamic headers to these
ICOs. The system passes all the dynamic headers except the three TPM namespaces:
● http://sap.com/xi/XI/EDISeparator/EDISeparator
● http://sap.com/xi/b2b/tpm
● http://sap.com/xi/b2b/tpm/agreement
Procedure

8. Choose the Parameters tab page and select the Receiver radio button to enable the EDI separator adapter
to perform outbound message processing.
9. In the Transport Protocol field, select PI.
10. In the Message Protocol field, select Electronic Document Interchange.
11. To transmit an acknowledgment for incoming message formats, choose the General tab page and enter the
values in the respective fields based on the description of the parameters mentioned below:

Splitting Keep Bulk message This option enables the adapter not to
split the incoming batch EDI mes
sages. To use this option, you need to
enable Receive Bulk message in the
EDI separator sender channel.
Trading Partner Management (TPM) Read from Dynamic Headers This option enables the adapter to
Configuration read data from the message dynamic
headers such as the TPM Sender and
Receiver Partner information, TPM
agreement, etc. To use this option,
you need to add the
TPMContentAccessModule in
the Communication Channel module
sequence. The module takes the infor
mation from the TPM database and
adds it as dynamic headers to the
message.
Formatting Indent messages This parameter defines whether to in

dent the message payload.
Enable Plain This enables the adapter to process

plain messages.
Enable XML This enables the adapter to process

XML messages.
Enable Default This enables the adapter to process

default messages.
Routing Route on Error When an error occurs, a copy of the

bulk message is created and is sent to
an EDI Separator Sender channel with
Message Protocol 'Error'.

channel with Message Protocol Error
and a receiver channel that will deal
with the message - either send it to
the Partner or keep it somewhere on
the file system.

Create a copy and route This creates a copy of the bulk mes
sage and sends it to an EDI Separator
col Copy.

channel with Message Protocol Copy
and a receiver channel that will deal
with the message - either send it to
the Partner or keep it somewhere on
the file system.
Use Dynamic Configuration Routing This enables the adapter to route the
messages based on a configurable
Dynamic Configuration header.
Dynamic Configuration Header Name This parameter defines the Dynamic

Configuration header name that the
message will be routed based on. To
use this option you need to enable pa
rameter Use Dynamic Configuration
Routing.
 Note
field.
Dynamic Configuration Header This parameter defines the Dynamic

Namespace Configuration header namespace that
the message will be routed based on.
To use this option you need to enable
parameter Use Dynamic Configuration
Routing.
 Note
field.

Fail if Dynamic Configuration is This enables the adapter to fail the in
missing coming message if the Dynamic
Header specified in the previous two
parameters is missing. If this parame
ter is not enabled the adapter will
process messages with the header
and without it successfully. If the
header is missing, the Adapter will
search for EDI separator sender chan
nels that haven't enabled the parame
ter Use Dynamic Configuration Filter
and find the most suitable channel
based on the Message Filter values
only. If the header is present, the
adapter will search for EDI separator
sender channels that have enabled
Use Dynamic Configuration Filter pa
rameter and match the message
based on the Dynamic Configuration
Filter and the Message Filter values. To
use this option you need to enable pa
rameter Use Dynamic Configuration
Routing.
12. To transmit the 997 acknowledgment for ANSI ASC X12 messages, choose the ANSI X12 tab page and
enter the values in the respective fields based on the description of the parameters mentioned below:
 Note
For more information about ANSI ASC X.12 997 FA, see Introduction to ANSI ASC X12 997 FA [page
98].
ANSI X12 Enable Group Based Splitting This parameter allows splitting of in
coming batch X12 EDI messages in
different groups, which makes proc
essing of X12 messages easier.
TA1 Acknowledgment Required Not Required This parameter does not create and
transmit TA1 interchange acknowledg
ment receipt.
Read from envelop segment This parameter enables the adapter to

read the ISA segment of an EDI docu
ment. If adapter detects that the part
ner has requested TA1, then it trans
mits the TA1.

Required This parameter creates and transmits
a TA1 receipt.
 Note
For more information, see
2534916 .
Acknowledgment Required Not Required This parameter does not create and
transmit a 997 FA receipt.

a 997 FA receipt.
 Note
For more information, see Config-
uring the ANSI ASC X12 997
Functional Acknowledgement
[page 99].

read the ISA segment of an EDI docu
ment. If adapter detects that the part
ner has requested an FA, then it trans
mits the FA.
Duplicate Check Enable Duplicate Check This parameter allows the receiver
channel to check whether any incom
ing messages are duplicate. You can
enable the duplicate check at either
group level or message level. If you de
fine the check at group level, then in
case of a duplicate group, you can
specify whether the group or inter
change of the group needs to be dis
carded. On the other hand, if you de
fine the check at message level, then
in case of a duplicate message, you
can specify whether the message,
group of the message, or interchange
of the message needs to be discarded.
Validity (Days) Defines the number of days for which

the adapter checks for and processes
duplicate messages.
13. To transmit the CONTRL acknowledgment for EDIFACT messages, choose the EDIFACT tab page and enter
the values in the respective fields based on the description of the parameters mentioned below:

transmit CONTRL acknowledgment.

CONTRL acknowledgment.
 Note
For more information, see Intro
duction to EDIFACT CONTRL
Message [page 103].

read the UNB segment of an EDI
document. If adapter detects that the
partner has requested an acknowl
edgment, then it transmits the
CONTRL.
Duplicate Check Enable Duplicate Check The duplicate check is performed on

the Correlation ID, which is made by
the following elements:
○ Interchange Number
○ Sender Identifier
○ Sender Qualifier
○ Receiver Identifier
○ Receiver Qualifier

duplicate messages.
14. To transmit the CONTRL acknowledgment for EANCOM messages, choose the EANCOM tab page and
enter the values in the respective fields based on the description of the parameters mentioned below:
transmit CONTRL acknowledgment.

CONTRL acknowledgment.
 Note
For more information, see Config-
uring the EANCOM CONTRL Mes
sage [page 111].

read the UNB segment of an EDI
document. If adapter detects that the
partner has requested an acknowl
edgment, then it transmits the
CONTRL.
Duplicate Check Enable Duplicate Check The duplicate check is performed on

the Correlation ID, which is made by
the following elements:
○ Interchange Number
○ Sender Identifier
○ Sender Qualifier
○ Receiver Identifier
○ Receiver Qualifier

duplicate messages.
15. To set the channel status and to add additional parameters, choose the Advanced tab page and select the
Advanced Mode checkbox. You can use the following additional parameters:
Additional Parameter Name Description
edi.xml.includeheader Publishes only the specific node in the source XML

document as defined in the XML Split Path. To enable it,
set its value to true.
edi.recv.input.encoding Defines the encoding of the input message. If you do not

use this parameter, the adapter will use encoding
ISO-8859-15.
edi.recv.keep.attachments Enables the EDI Separator Adapter to add attachments of

the bulk message to newly created messages when
processing XI messages with attachments. To activate it,
edi.x12.disable.cache Disables the converter cache for EDI Separator Receiver

validation of X12 and X12ConverterModule. To enable it,
edi.remove.linebreaks Removes the line breaks of the EDIFACT or EANCOM

messages that are being processed by the EDI Separator
Receiver channel. To enable it, set its value to true.

1.1.4.2.1 Introduction to ANSI ASC X12 997 FA
Use
This document helps you to understand how ANSI ASC X12 997 FA functions in the SAP NW PI environment.
The 997 transaction set is known as functional acknowledgment or FA, and is an electronic confirmation
receipt sent to the client in response to a received EDI transaction. The received message can contain either
single or multiple EDI transaction set. The EDI separator is a PI adapter that is responsible for splitting
incoming batch EDI message into individual message components. The message is split based on the type of
business document.
You can configure the EDI separator to send the 997 FA message to the business partner for both incoming
single message as well as batch EDI message. The 997 FA message contains the acceptance or rejection status
of individual messages that are received by the EDI separator. The status contained in the 997 FA message is
based on the processing of the original single or split batch message and the delivery or non-delivery of an
individual message to the SAP NW PI receiver. The 997 FA publishes the message status by validating the
syntactical correctness of the message, which is an optional feature.
The figure below illustrates a typical business communication scenario between business partners. In this
scenario, the business partner transmits business documents in a batch EDI message, which contains 810,
853, and 860 transactions. On the PI side, the batch messages are processed at the sender channel configured
on a business-to-business adapter, for example, the AS2 adapter. The messages are then forwarded to the EDI

separator receiver channel by the PI messaging system. The EDI separator splits the batch EDI message into
individual transaction sets and then creates an XI message for each individual messages. These XI messages
are dispatched to the respective EDI separator sender channels, which are configured to receive the
transaction set from the EDI separator receiver channel.
The receiver channel of an EDI separator is configured to generate the 997 FA receipt. The EDI separator
adapter generates a 997 FA message receipt after processing the EDI messages, and then transmits the 997 FA
receipt to the business partner through the receiver channel of a business-to-business adapter.
1.1.4.2.2 Configuring the ANSI ASC X12 997 Functional

Acknowledgement
Use
You use this procedure to configure the receiver channel of the EDI separator with ANSI ASC X12 997 FA, to
transmit an 997 acknowledgement for the processed EDI documents.
The content of the ANSI ASC X12 997 FA message depends on the following:
● The processing of the interchange or individual split messages

● The syntactic validation of the message (optional)
● The delivery (or non-delivery) of the message to the receiver

Prerequisites
To enable message transmission between channels:
● You have to successfully deployed the EDI separator.

● You also have to specify additional adapter-specific parameters.
Procedure
You use this procedure to create and transmit an ANSI ASC X12 997 FA message receipt.
1. Choose the ANSI X12 tab page.

2. In the Acknowledgement Required field, select Required.
 Note
If you select the Not Required option, the ANSI ASC X12 997 FA receipt is not created or transmitted.
3. Enter the values in the respective fields based on the description of the parameters in the table below:
The table below provides information on the Acknowledgment Required filtering parameters of 997
acknowledgments found on the ANSI X12 tab page.
Acknowledgment Required Required This parameter allows the EDI separa

tor to generate and transmit a 997 FA
receipt to the sender of the original
message.
Transaction Mode All This parameter defines the transaction

mode in which the EDI separator treats
all individual transaction sets as a single
related entity.
 Note
If an individual EDI transaction set
fails, then all the transactions will
be rolled back, and all transaction
sets in the 997 FA receipt will ap
pear Rejected (R). If you choose
both the Negative Acknowledge
ment not required and Positive Ac
knowledgement not required , then
the business partner does not re
ceive a 997 FA message related to
the status of the EDI transactions.

Negative Acknowledgement not This parameter notifies the adapter not
required to transmit the 997 FA message when a
transaction set is Rejected (R). When
the adapter does not transmit a 997 FA
in an event of a message rejection the
administrator has an option for retriev
ing the details from the channel status
and correcting the errors by editing the
messages in “Red”. If the message goes
into a “Waiting” state due to an error,
then it can be retried after rectifying the
announced errors. If a message goes
into the “Failed” state only after it has
been automatically retried by the mes
saging system ‘n’ number of times,
where ‘n’ is configurable. It can also be
edited and restarted.
Positive Acknowledgement not required This parameter notifies the adapter not
to transmit a 997 FA message when all
transaction sets are Accepted (A).
The 997 FA receipt contains only Re

jected (R) transaction sets.
Transaction Mode Individual This parameter defines the transaction

mode, in which the EDI separator treats
each individual transaction set as an in
dependent entity.
If an individual transaction set fails, only

the failed transaction is rolled back and
the code appears in the 997 FA receipt
as Rejected (R).
Exclude “Partially Accepted” This parameter defines that partially

acknowledgement code accepted transactions appears as re
jected or accepted. The field level code
of a functional group indicating Partially
Accepted (P) appears as Rejected (R)
or Accepted (A) in the 997 FA receipt.
Execution Mode Receipt Only This parameter notifies the adapter

only about the status of the EDI dis
patch. It does not to validate the syntax
of the EDI transaction. The separator
transmits the 997 FA receipt, which
contains either Rejected (R) or Ac
cepted (A) acknowledgement on the
basis of successful dispatch.

Receipt and Validation This parameter notifies the adapter to
validate the syntax of the transaction
sets and also transmits the 997 FA re
ceipt as per the validation results.
Exclude AK3 and AK4 This parameter notifies the adapter to

exclude the AK3 and AK4 segments
from the 997 FA message. But it retains
the details of AK1, AK2, AK5, and AK9
segments in the 997 FA message.
Enable NRO for Interchange Number This parameter enables the NRO tool to
generate interchange number for func
tional acknowledgments. In the NRO
Name field enter the NRO name.
For more information on the 997 FA error codes, see Error Codes of 997 FA Message [page 102].
1.1.4.2.2.1 Error Codes of 997 FA Message
Use
The table below gives information about AK3 and AK4 segment syntax error codes in the 997 FA message.
Error Code Error Name Supported
1 Unrecognized Segment ID Yes
2 Unexpected Segment Yes
3 Mandatory Segment Missing Yes
4 Loop Occurs Over Maximum Times Yes
5 Segment Exceeds Maximum Use Yes
6 Segment not found in defined transac Yes

tion set
8 Segment has Data Element Errors Yes
1 Mandatory Data Element Missing Yes
3 Too Many Data Elements Yes

4 Data Element Too Short Yes
5 Data Element Too Long Yes
1.1.4.2.3 Introduction to EDIFACT CONTRL Message
Concept
This document helps you to understand how EDIFACT syntax and service report messages (CONTRL) function
in the SAP NW PI environment, and also explains how to configure the EDI separator to create an EDIFACT
CONTRL message.
The EDIFACT CONTRL is a message syntactically acknowledging or rejecting, with an error indication, a
received interchange, functional group, or message. A CONTRL message is used to do the following:
1. Acknowledge or reject a received interchange, functional group, or message and list any internal errors
2. Indicate only the receipt of an interchange
The figure below explains a typical business communication scenario between trading partners. In this
scenario, the business partner transmits business documents in batch EDI messages, which contain ORDERS,

INVOIC, and DESADV messages. On the PI side, the batch messages are processed at the sender channel
configured on a business-to-business adapter, for example, the AS2 adapter. The messages are then forwarded
to the EDI separator receiver channel by the PI messaging system. The EDI separator splits the batch EDI
messages into individual messages and then creates an XI message for each individual message. These XI
messages are dispatched to the respective EDI separator sender channels.
The receiver channel of an EDI separator is configured to generate an EDIFACT CONTRL message. The EDI
separator adapter generates an EDIFACT CONTRL message receipt after processing the messages, and then
transmits the receipt to the business partner through the receiver channel of a business-to-business adapter.
For more information on the document structure of the EDIFACT CONTRL message, see EDIFACT CONTRL
Message Format [page 105].

1.1.4.2.3.1 EDIFACT CONTRL Message Format
Concept
The table below describes the different segments of an EDIFACT CONTRL message:
Tag Name Description
UNH, Message header This mandatory start segment identifies and specifies a
message.
UCI, Interchange response This mandatory segment identifies the subject interchange
and indicates the status interchange receipt, and contains
references of the received interchange. The UCI segment
has a max occurrence of 1; as a result, it reports the first er
ror encountered in one of the control segments.
UCM, Message response This mandatory segment identifies the message or package
in the subject interchange, indicates the action taken by the
message, and also identifies errors related to USA, USC,
USD, USH, USR, UST, or USU security segments.
UCS, Segment error indication This mandatory segment identifies either an error segment
or a missing segment, and any error related to the complete
segment.
UCD, Data element error indication This conditional segment identifies an incorrect stand-alone,
composite, or component data element, and the nature of
the error.
UCF, Functional group response This mandatory segment identifies the message in the group
segment and indicates the nature of any error.
UNT, Message trailer This mandatory end segment checks the completeness of a
message.

Below is the document format of an EDIFACT CONTRL message:
1.1.4.2.4 Configuring the EDIFACT CONTRL Message
Use
The EDI separator is a PI adapter that is responsible for splitting incoming batch EDI messages into their
individual message components. The messages are split according to the values in envelope segments and
individual messages.
You configure the EDI separator to transmit the CONTRL message to the recipient for both single or batch EDI
messages. The CONTRL message contains the acceptance or rejection status of either the entire interchange
or the individual messages that are processed by the EDI separator.
The content of the CONTRL message depends on the following:


Prerequisites
To configure the EDIFACT CONTRL service, you must do the following:

Procedure
You use this procedure to create and transmit the EDIFACT CONTRL message receipt.
1. Choose the EDIFACT tab page.

 Note
If you select the Not Required option, the EDIFACT CONTRL receipt is not created or transmitted.
3. The following table describes the CONTRL message parameters; you must enter the values in the
respective fields:
Acknowledgement Required Required This parameter allows the EDI separa

tor to transmit a CONTRL message to
the recipient.
EDIFACT CONTRL Message Version and Version D, Release 3 This parameter determines the product
Release release and version.
Directory Version of EDI message This parameter determines the product

release and version of the EDI message
from the EDI directory.


all individual messages as a single re
lated entity.
If an individual EDI message fails, then

all the transactions will be rolled back
and the information of all messages in
the CONTRL receipt appears Rejected
(4).
For more information, see “EDIFACT

Action Codes” in the same page.
 Note
If you select both of these options,
the recipient will not receive any
CONTRL message related to the
status of the EDI transactions.
Negative Acknowledgement Not This parameter determines that no

Required CONTRL receipt is generated when a
message is Rejected (4).

Action Codes” in this document.
 Note
Since this option does not generate
a CONTRL message in the event of
a failure, the administrator has the
option to retrieve the failure details
from the channel status and cor
rect the errors by editing the mes
sage in “Red”. If the message goes
into the“Waiting” state due to an
error, it can be retried once the an
nounced errors have been cor
rected. A message only goes into
the “Failed” state after it has been
automatically retried by the mes
saging system ‘n’ number of times
(‘n’ is configurable).
The CONTRL message contains Ac

knowledged (7) messages only.

Positive Acknowledgement Not This parameter determines that the ED

Required IFACT messages has been successfully
validated.


each individual message as an inde
pendent entity.
If an individual message fails, only the

failed transaction is rolled back and it
appears in the CONTRL message as Re
jected (4). All successfully validated
messages appear as accepted.

Execution Mode Receipt Only This parameter defines that the separa
tor does not validate the content of the
messages. The separator transmits the
CONTRL receipt according to the split
and dispatch of individual messages.
Receipt and Validation This parameter defines that the separa

messages and transmits the CONTRL
receipt according to the validation re
sults.
UNA Segment Required This parameter defines special charac

ters, such as separators and indicators
used in the interchange. If the UNA seg
ments are not included, then the de
fault characters are used.
For more information on the EDIFACT CONTRL error codes, see Error Codes of EDIFACT CONTRL Message
[page 110].
EDIFACT Action Codes

The table below describes the action codes used in the EDIFACT document:
Code Description
4 Rejection: This indicates the corresponding messages at the referenced level, and all its
lower referenced levels are rejected.
7 Acknowledgement: This indicates that the messages or functional groups are acknowl
edged, except those explicitly reported as rejected at the next lower reporting level in this
CONTRL message.
8 Interchange received: This indicates that the recipient of the message has received the in
terchange.
1.1.4.2.4.1 Error Codes of EDIFACT CONTRL Message
Concept
The table below gives description about the errors notifications that are supported by the EDIFACT CONTRL:
2 Syntax Version or Level Not Supported Yes
13 Missing Yes
15 Not Supported in This Position Yes
16 Too Many Constituents Yes
17 No Agreement Yes
18 Unspecified Error Yes
19 Invalid decimal notation Yes
28 References do not match Yes
29 Control count does not match number Yes

of instances received
30 Functional groups and messages mixed Yes
31 More than one message type in group Yes
32 Lower Level Empty Yes

33 Invalid occurrence outside message, Yes

package, or group
35 Too many data element or segment Yes

repetitions
36 Too many segment group repetitions Yes
37 Invalid type of characters Yes
38 Missing digit in front of decimal sign Yes
1.1.4.2.5 Configuring the EANCOM CONTRL Message
Use
The EDI separator is a PI adapter that is responsible for splitting incoming batch EDI messages into their
individual message components. The messages are split according to the values in envelope segments and
individual messages.
You configure the EDI separator to transmit the CONTRL message to the recipient for both single or batch EDI
messages. The CONTRL message contains the acceptance or rejection status of either the entire interchange
or the individual messages that are processed by the EDI separator.
The content of the CONTRL message depends on the following:

Prerequisites
To configure the EANCOM CONTRL service, you must do the following:

Procedure
You use this procedure to create and transmit the EANCOM CONTRL message receipt.

1. Choose the EANCOM tab page.
 Note
If you select the Not Required option, the EANCOM CONTRL receipt is not created or transmitted.
3. The following table describes the CONTRL message parameters; you must enter the values in the
respective fields:
Acknowledgement Required Required This parameter allows the EDI separa

tor to transmit a CONTRL message to
the recipient.
EANCOM CONTRL Message Version Version D, Release 3 This parameter determines the product
and Release release and version.
Directory Version of EDI message This parameter determines the product

release and version of the EDI message
from the EDI directory.

all individual messages as a single re
lated entity.
If an individual EDI message fails, then

all the transactions will be rolled back
and the information of all messages in
the CONTRL receipt appears Rejected
(4).
For more information, see “EANCOM

Action Codes” in the same page.
 Note
If you select both of these options,
the recipient will not receive any
CONTRL message related to the
status of the EDI transactions.

Negative Acknowledgement Not This parameter determines that no

Required CONTRL receipt is generated when a
message is Rejected (4).

 Note
Since this option does not generate
a CONTRL message in the event of
a failure, the administrator has the
option to retrieve the failure details
from the channel status and cor
rect the errors by editing the mes
sage in “Red”. If the message goes
into the“Waiting” state due to an
error, it can be retried once the an
nounced errors have been cor
rected. A message only goes into
the “Failed” state after it has been
automatically retried by the mes
saging system ‘n’ number of times
(‘n’ is configurable).
The CONTRL message contains Ac

knowledged (7) messages only.
Positive Acknowledgement Not This parameter determines that the

Required EANCOM messages has been success
fully validated.


each individual message as an inde
pendent entity.
If an individual message fails, only the

failed transaction is rolled back and it
appears in the CONTRL message as Re
jected (4). All successfully validated
messages appear as accepted.


Execution Mode Receipt Only This parameter defines that the separa
messages. The separator transmits the
CONTRL receipt according to the split
and dispatch of individual messages.
Receipt and Validation This parameter defines that the separa

messages and transmits the CONTRL
receipt according to the validation re
sults.
UNA Segment Required This parameter defines special charac

ters, such as separators and indicators
used in the interchange. If the UNA seg
ments are not included, then the de
fault characters are used.
For more information on the EANCOM CONTRL error codes you can refer EDIFACT error codes, see Error
Codes of EDIFACT CONTRL Message [page 110].
EANCOM Action Codes
The table below describes the action codes used in the EANCOM document:
Code Description
4 Rejection: This indicates the corresponding messages at the referenced level, and all its
lower referenced levels are rejected.
7 Acknowledgement: This indicates that the messages or functional groups are acknowl
edged, except those explicitly reported as rejected at the next lower reporting level in this
CONTRL message.
8 Interchange received: This indicates that the recipient of the message has received the in
terchange.

1.2 Configuring Adapter Modules
Use
This section provides you with information on configuring the business-to-business add-on adapter modules.
For more information, see:
● Configuring the Archiver Module [page 115]

● Configuring the NRO Module [page 119]
● Configuring the ANSI ASC X12-XML Converter Module [page 123]
● Configuring the EDIFACT-XML Converter Module [page 124]
● Configuring the EANCOM-XML Converter Module [page 125]
● Configuring the Generic Converter Module [page 126]
● Configuring the ODETTE-XML Converter Module [page 127]
● Configuring the PLAIN-XML Converter Module [page 128]
● Configuring the TRADACOMS-XML Converter Module [page 129]
● Configuring the VDA-XML Converter Module [page 130]
● Configuring the EDI Search Parameter Module [page 131]
● Configuring the Module Configuration Parameters [page 135]
1.2.1 Configuring the Archiver Module
Prerequisites
● You have imported the archiver mapping (JAR) file to the Enterprise Services Builder.
Context
The SAP NW PI adapter is configured with an archiver module to archive the business message interchange on
the file system. It also performs the correlation of the EDI documents with an IDoc number.
You use this procedure to configure the archiver module in the SAP NW PI adapters.
Procedure
1. Configure the receiver channel to enable archiving of messages in the sender and receiver channels.

For more information, see Configuring the Communication Channel with Archiver Module [page 116].
2. Configure the Archiver Java Mapping to ensure that either the original message or the final message is
archived.
For more information, see Mapping and Archiving Messages [page 118].
1.2.1.1 Configuring the Communication Channel with

Archiver Module
Context
You use this procedure to configure the communication channel of the business-to-business adapter with the
archiver module for archiving messages from the sender and receiver channels.
Procedure

5. Choose the Module tab page.
6. In the Module Name column, enter the module name as localejbs/ArchiverModuleBean.
 Note
The module name keywords are case-sensitive.
7. In the Type column, select the type as Local Enterprise Bean.

8. In the Module Configuration screen area, enter the appropriate parameter name as described in the table
below:
 Note
An error is reported if an incorrect parameter name is entered.
Parameter Name Description

archiveBaseDir This parameter archives messages to a base directory on
the PI server.
Enter the directory name in the parameter value text box.

If the directory does not exist, it is created when the first
file is archived.
archiveFile This parameter archives messages to a directory on the PI

server and also describes the file name of the archived
files.
Enter the directory name in the parameter value text box.
removeErroneous This parameter, when set to true, removes the archived

files created by a faulty archiver module or archive map
ping.
A faulty archiver module or archive mapping means that

you have used the combination more that once.
If the remove erroneous flag is set to false, the faulty com

binations are ignored, and the files are archived for all the
combinations.
9. The parameter values may contain substitution patterns. Enter the appropriate substitution patterns
based on the description given in the table below:
Substitution Pattern Description
%id This pattern is a substitution of the message ID.
%TS This pattern is a substitution of the time stamp in the for

mat yyyy.MM.dd_HH-mm- ss.SSS.
%fp This pattern is a substitution of the sending party.
%tp This pattern is a substitution of the receiving party.
%fs This pattern is a substitution of the sending service.
%ts This pattern is a substitution of the receiving service.
[…] The values in square brackets must be dynamic; if no con

figuration value with the given name is found, the value is
left empty.
For example, if you want to place an IDoc-number set by

the archiver Java mapping, then place it as "[http://
sap.com/xi/XI/System/idocNo]".

{…} The curly brackets are parsed by the "Java SimpleDateFor
mat" function. Hence, before applying the expression
make sure that it is parsable. For an overview, see the Java
SimpleDateFormat documentation. Note that erroneous
expressions lead to errors in message processing. Further
more, all white spaces are interpreted.
1.2.1.2 Mapping and Archiving Messages
Use
This document gives an overview of operation mapping and archiving of inbound or outbound messages using
the Archiver Java Mapping.
Importing the Archiving Mapping JAR file
Importing the archiving mapping JAR file is mandatory for the Java Mapping to run with the Archive Module.
● Archive mapping JAR is available in the PIB2BCONTENT02_*.zip file

● com.sap.aii.adapter.archiver.mapping.jar is the Archive mapping JAR file
● com/sap/aii/archiver/mapping/ArchiverMapping is the mapping class required to be imported in the ESR
To import the archiving mapping JAR file, proceed as follows:
1. Import the JAR file by going to ESR Create Object Mapping Objects Imported Archive
2. Choose Create
3. From the Imported Archive screen, choose Folder, and
4. From its Choose Folderdrop-down menu, search for the B2B MAPPING KIT 2.0
5. Then choose the JAR file for importing.
Operation Mapping
The Archiver Java Mapping has to be added to the Operation Mapping list (called 'Mapping Program') in the
integrated configuration that defines the order of the called mappings.
The order of the Archiver Java Mapping is explained below:
● Adding this mapping first guarantees that the original version of a message is archived.
● Adding this mapping last guarantees that the final version of a message is archived.
 Note
The dynamic configuration has to be defined in the Archiver module to persist the message to a custom
path and name.
 Note
If there are modules that alter the message, the final version is not present at any time during the mapping
execution steps. To capture such messages, the archiving module must be used.

Archiving of Inbound Messages
The Archiver Java Mapping checks if the message has been archived by the Archiver module before. If this is
the case, the Archiver mapping archives the message"s main payload to the same path with the file extension
".arc.1".
If the message has not been archived by the module before, the mapping saves the message to the Java temp
directory. The path of the file is attached to the dynamic configuration parameters. If a "DOCNUM" tag is
detected within the message payload, the corresponding number is saved as a dynamic configuration
parameter.
Archiving of Outbound Messages
When a message arrives in the Archiver module, it checks if the message has been archived by the Archiver
Java Mapping before. If this is the case, the temp file created by the Archiver Java mapping is archived to the
destination configured in the module. The current message is archived to the same location with the file
extension ".arc.1". This is to save both message versions to the same directory with corresponding file names.
If the message has not been archied before, it is archived to the configured location. The path is stored in the
message header as a dynamic configuration.
1.2.2 Configuring the Number Range Objects (NRO) Module
Prerequisites
● You have access to the NRO maintenance tool.
Context
The Number Range Objects (NRO) module provides the option of automatically inserting continuous counters
into outgoing messages. You create these numbers and assign them to the respective objects for defined
intervals.
You use this document to configure the NRO (Number Range Objects) module in the SAP Process Integration
environment.
Procedure
1. Configure the NRO maintenance user interface to generate the number intervals and to perform a few
additional functions.
For more information, see Maintaining Number Range Objects [page 120].

2. Configure the communication channels by adding the NRO module to automatically insert continuous
counters into the outgoing message.
For more information, see Configuring the Communication Channels with NRO Module [page 121].
3. Configure the SAP NetWeaver Administrator to clean up NRO database. For more information, see
Cleaning NRO Database [page 122].
4. A new API has been introduced for NRO module that help you to provide the configuration values
dynamically. For more information, refer SAP Note 1769055 .
1.2.2.1 Maintaining Number Range Objects
Context
The Number Range Objects (NRO) module provides options to automatically insert continuous counters into
the outgoing messages. These numbers are created using Number Range Objects and are assigned to the
defined intervals in the respective objects. You create new values and maintain them on the NRO maintenance
user interface.
You use this procedure to define the NRO values.
Procedure
1. To access NRO maintenance, enter the URL format as http:<localhost:port>b2bic in the Web browser.
2. On the B2B Integration Cockpit Web page, choose NRO Maintenance.
3. In the Number Range Objects screen area, choose Create new number range object to define new NRO
values. The following table describes the parameters for creating the NRO values:
Parameter Description
Number Range Object Name This parameter defines the name of the NRO.
Description This parameter allows you to describe the NRO.
Minimum Value This parameter allows you to calculate the minimum value
for the NRO.
Maximum Value This parameter allows you to calculate the maximum

value for the NRO.
Formatted Value Length This parameter allows you to calculate the length of the
NRO value.

Warn Level (%) This parameter allows you to calculate and specify an inte
ger at which an warning is issued. The integer value must
lie between 0 and 100.
You can disable the Warn Level (%) field by selecting the
Rotate checkbox.
4. Choose Save and create to save the settings and to create the NRO values.
5. To generate the successive number for the given NRO value, select an NRO from the number range object
table and choose Get next number.
6. To edit values in an existing NRO, select an NRO from the number range object table and choose Edit
number range object.
1.2.2.2 Configuring the Communication Channels with NRO

Module
Procedure

6. In the Module Name column, enter the module name as localejbs/TransmissionNumberModule.
The number range object adapter module can be called via localejbs/TransmissionNumberModule. It
replaces all occurrences in the PI message payload of the character sequences $B2B_UEBNR<nroName>
$B2B_END_UEBNR with the next number of the number range object /B2B/<nroName>.
Instead of getting the next number of a range object, you can also get the last number again by using the
placeholder $B2B_UEBNR_BEFORE<nroName>$B2B_END_UEBNR.
The integration developer has to add the character sequences as described above into the message using
the PI mapping.
 Example
If the "/B2B/<nroName>" is "/B2B/Partner", then "$B2B_UEBNR_BEFORE<nroName>

$B2B_END_UEBNR" is "$B2B_UEBNR_BEFOREPartner$B2B_END_UEBNR"
 Note
The module name key words are case-sensitive.

8. In the Module Configuration screen area enter the appropriate parameter name as mentioned in the table
below:
multipleNumbersPerMessage If you want to insert multiple continuous numbers in a

message, then use this parameter.
useLocalLock If you want to aquire lock on the individual NRO that is be
ing used instead of global lock, then use this parameter.
Its default value is true.
sourceEncoding Defines the encoding of the input message. If not specified

the default value is ISO-8859-15.
destinationEncoding Defines the encoding of the output file. If not specified the
default value is ISO-8859-15.
1.2.2.3 Cleaning NRO Database
Use
The number range module stores every XI-Message the provided values in an database table, to get the same
number when the same message is processed again.
You use this procedure to execute the clean up job.
Procedure
1. To login to the to the SAP NetWeaver Administrator, enter the URL http://server:port/nwa/jobs in the
Web browser.
2. Choose Tasks and then choose Add.
3. On the Job field, select AssignedNumbersCleanUp and then choose Next.
4. Enter the Task Details and choose Next.
5. On the messageIDLifetime field enter the parameters and choose Next.
 Note
The parameter messageIDLifetime defines the time in hours for a value that should be stored in the
database.
6. To configure the execution time, choose the Cron and then choose the time of the old entries that should
be deleted.

7. Choose Add and then choose Finish.
 Recommendation
Check if the Task "AssignedNumbersCleanUp" is configured and active.
1.2.3 Configuring the ANSI ASC X12-XML Converter Module
Prerequisites
● You have logged on to the Integration Directory in the SAPProcess Integration environment.
● You have deployed the ANSI ASC X12-XML converter module in the SAP Process Integration environment.
Context
You configure the communication channels of any Process Integration adapter with the ANSI ASC X12-XML
converter module to convert business documents encoded in ANSI ASC X12 message standards into XML and
the other way round. It must be configured in the sender and receiver channels based on the business scenario.
The ANSI ASC X12-XML converter module runs on the SAP Process Integration Adapter framework.
You use this procedure to configure the parameters of the ANSI ASC X12-XML converter module.
Procedure

6. In the Processing Sequence table, enter the appropriate converter module parameters.
7. In the Module Name column, enter the module name as localejbs/X12ConverterModule.
 Note

9. In the Module Configuration table, enter the appropriate converter module parameters. For more
information, see Configuring the Module Configuration Parameters [page 135].

1.2.4 Configuring the EDIFACT-XML Converter Module
Prerequisites
 Note
Please, note that the SAP Process Integration, business-to-business add-on supports UN/EDIFACT Message
Standard up to UN/EDIFACT Syntax Version 3.
● You have deployed the EDIFACT-XML converter module in the SAP Process Integration environment.
Context
You configure the communication channels of any Process Integration adapter with the EDIFACT-XML
converter module to convert business documents encoded in EDIFACT message standards into XML and the
other way round. It must be configured in the sender and receiver channels based on the business scenario.
The EDIFACT-XML converter module runs on the SAP Process Integration Adapter framework.
You use this procedure to configure the parameters of the EDIFACT-XML converter module.
Procedure

7. In the Module Name column, enter the module name as localejbs/EdifactConverterModule.
 Note

1.2.5 Configuring the EANCOM-XML Converter Module
Prerequisites
● You have deployed the EANCOM-XML converter module in the SAP Process Integration environment.
Context
You configure the communication channels of any Process Integration adapter with the EANCOM-XML
converter module to convert business documents encoded in EANCOM message standards into XML and the
The EANCOM-XML converter module runs on the SAP Process Integration Adapter framework.
You use this procedure to configure the parameters of the EANCOM-XML converter module.
Procedure
3. Choose , to configure the adapter.

7. In the Module Name column, enter the module name as localejbs/EdifactConverterModule.
 Note


1.2.6 Configuring the Generic Converter Module
Prerequisites
● You have deployed the Generic converter module in the SAP Process Integration environment.
Context
You configure the communication channels of any SAP Process Integration adapter with the generic converter
module that helps to detect unknown EDI messages and automatically map the messages to the
corresponding converter module. It must be configured in the sender or receiver channels based on the
business scenario.
You use this procedure to configure the parameters of the generic converter module.
Procedure
3. Choose , to configure the adapter.

7. In the Module Name column, enter the module name as localejbs/GenericConverterModule.
 Note

 Note
If you receive a message in an unknown EDI format, then enter all module configuration parameters for
accessing the suitability of the message.

 Example
If you receive an unknown EDI message, which might contain ANSI ASC X12, VDA and Odette of EDI
formats, then do as given below:
○ Enter "x12.encoding" as the parameter name and specify "ISO-8859-1" as the parameter value.
○ Enter "vda.encoding" as the parameter name and specify "ISO-8859-1" as the parameter value.
○ Enter "odette.encoding" as the parameter name and specify "ISO-8859-1" as the parameter value.
1.2.7 Configuring the ODETTE-XML Converter Module
Prerequisites
● You have deployed the ODETTE-XML converter module in the SAP Process Integration environment.
Context
You configure the communication channels of any Process Integration adapter with the ODETTE-XML
converter module to convert business documents encoded in ODETTE message standards into XML and the
The ODETTE-XML converter module runs on the SAP Process Integration Adapter Framework.
You use this procedure to configure the parameters of the ODETTE-XML converter module.
Procedure

7. In the Module Name column, enter the module name as localejbs/OdetteConverterModule.
 Note

1.2.8 Configuring the PLAIN-XML Converter Module
Prerequisites
● You have deployed the PLAIN-XML converter module in the SAP Process Integration environment.
Context
You configure the communication channels of any Process Integration adapter with the PLAIN-XML converter
module to convert business documents encoded in EDIFACT message standards into XML and the other way
round. It must be configured in the sender and receiver channels based on the business scenario. The PLAIN-
XML converter module runs on the SAP Process Integration Adapter framework.
You use this procedure to configure the parameters of the PLAIN-XML converter module.
Procedure

7. In the Module Name column, enter the module name as localejbs/PlainConverterModule.
 Note


1.2.9 Configuring the TRADACOMS-XML Converter Module
Prerequisites
● You have deployed the TRADACOMS-XML converter module in the SAP Process Integration environment.
Context
You configure the communication channels of any Process Integration adapter with the TRADACOMS-XML
converter module to convert business documents encoded in TRADACOMS message standards into XML and
the other way round. It must be configured in the sender and receiver channels based on the business scenario.
The TRADACOMS-XML converter module runs on the SAP Process Integration Adapter framework.
You use this procedure to configure the parameters of the TRADACOMS-XML converter module.
Procedure

7. In the Module Name column, enter the module name as localejbs/TradacomsConverterModule.
 Note


1.2.10 Configuring the VDA-XML Converter Module
Prerequisites
● You have logged on to the Integration Directory in the SAP NetWeaver Process Integration environment.
● You have deployed the VDA-XML converter module in the SAP NetWeaver Process Integration
environment.
Context
You configure the communication channels of any Process Integration adapter with the VDA-XML converter
module to convert business documents encoded in VDA message standards into XML and the other way
round. It must be configured in the sender and receiver channels based on the business scenario. The VDA-
XML converter module runs on the SAP NetWeaver Process Integration Adapter Framework.
You use this procedure to configure the parameters of the VDA-XML converter module.
Procedure

7. In the Module Name column, enter the module name as localejbs/VdaConverterModule.
 Note


1.2.11 Configuring the EDI Search Parameter Module
You use this procedure to configure the EDI search parameters module with the EDI Separator Receiver
Channel. This module automatically assigns correlation ID and dynamic parameters on detecting any format of
EDI messages such as EDIFACT, EANCOM, X12, TRADACOMS and Odette.
Context
EDI Search Parameter module publishes the parameters described in the following table to local PI message
monitoring. This enhances the monitoring with EDI specific capabilities.
The module will also publish part of the parameters as XI Dynamic Headers (with namespace http://
sap.com/xi/XI/EDISeparator/EDISeparator).
You can set these parameters externally, either via message mapping or by a custom adapter module. If the
parameters are not set externally, this module attempts to parse the payload to read these parameters.
Currently, EDI payloads of message formats ANSI X12, EDIFACT, ODETTE, and EANCOM are recognized.
Name Description
SenderId EDI Sender ID and Qualifier (for example, ‘123455678:01’)
ReceiverId EDI Receiver ID and Qualifier (for example, ‘123455678:02’)
InterchangeControlNumber EDI message unique identification number (or control

number)
CorrelationId Correlation ID that identifies all EDI messages that are part
of an EDI transaction
MessageType EDI message type or transaction set ID (for example,

‘ORDERS’ or ‘850’)
MessageVersion EDI message version
MessageRelease EDI message release
EDIDirection EDI message direction (‘Inbound’ or ‘Outbound’)
EDIMessageSize EDI payload size (in bytes)
MessageFormat EDI message format (for example, ‘EDIFACT’ or ‘X12’)
/EDI/IdocNumber Identification number of the corresponding IDoc message.

You must set this parameter externally.
/EDI/DocumentNumber Identification number of the document (such as Purchase

order ID or Invoice number). You must set this parameter
externally.
/EDI/DocumentType Type of EDI document (such as ‘Purchase Order’ or

‘Invoice’). You must set this parameter externally.

Procedure

7. In the Module Name column, enter the module name as localejbs/ EDISearchParametersModule.
 Note
encoding Defines the encoding of the input message. If not

specified, the default value is ISO-8859-1.
msg.direction Defines the message direction. The possible values are:

INBOUND and/or OUTBOUND. For more information see:
2131642
publishAllEDIParams This parameter, if set to true, will publish all of the

extracted parameters to XI header. The default value is
false.
1.2.12 Configuring the EDI Security Module (AUTACK)

AUTACK is a secure authentication and acknowledgement message, which you can use for content integrity,
message authentication, and non repudiation by sender/receiver.
Context
In case of outbound scenarios, we recommend to attach the EDI security module on the sender adapter of the
Integrated Configuration (ICO), which calls the partner. If you use mapping in this ICO, then you must attach
the module on the receiver channels (such as AS2 and OFTP receiver channels) that calls the partner.
In case of inbound scenarios, we recommend you to attach the EDI security module to the EDI separator
receiver channel.
 Note
For various usecase related to EDI security module, see SAP note 2071830.

Procedure
3. Choose Edit to configure the adapter.
7. In the Module Name column, enter the module name as EdiSecurityModule.
8. In the Module Configuration table, enter secureMsgDirection in the Parameter Name column and specify
Inbound / Outbound in the Parameter Value column.
The table below describes different parameters of AUTACK.
Parameter Direction Description
ownPrivateKeyView Inbound / Outbound This parameter is the owner's private-

key view of the NWA key storage.
ownPrivateKeyAlias Inbound / Outbound This parameter is the owner's private-

key alias of the NWA key storage.
ownCertificateView Inbound / Outbound This parameter is the owner's

certificate view of the NWA key
storage.
ownCertificateAlias Inbound / Outbound This parameter is the owner's

certificate alias of the NWA key
storage.
partnerCertificateView Inbound This parameter is the partner's

storage.
partnerCertificateAlias Inbound This parameter is the partner's

storage.
encodingType Inbound / Outbound This parameter is used for encoding

the messages; supported encodings
are UTF-8 and US- ASCII.
filterAlgorithm Inbound / Outbound This parameter is the name of the

filtering algorithm to be used;
supported algorithms are EDC, EDA,
and BASE64.
securityScope Inbound / Outbound This parameter is used to indicate

whether the security functions are
applied at interchange (UNB) or
message level (UNH).
includeOwnCertificate Inbound / Outbound This parameter specifies whether to

include the certificate in the payload;
possible options are YES and NO.

generateAutAck Inbound This parameter specifies whether to

generate AUTACK message for
acknowledgment; possible options
are YES and NO.
requireAUTACK Outbound This parameter requests the partner

to send AUTACK message as
acknowledgment; possible options
are YES and NO.
usePartnerCertFromNWA Inbound This parameter indicates whether to

consider partner's certificate from
NWA key storage or from the
message payload.
verifyMsgSignature Inbound This parameter indicates whether to

verify the signature or not.
autackVersion Inbound This parameter specifies the version

and release of the AUTACK message
type; possible values are 1:1 and DIR.
If the value is DIR, the security
module considers the version and
release of the incoming payload, and
if the value is 1:1, the security module
considers release as 1 and version as
1.
edi.sec.service Inbound This parameter specifies the security

service applied to the message.
 Note
You can also configure the AUTACK from TPM. For more information, see Adding Trading Partner
Profile [page 211].
1.2.12.1 AUTACK Message
The AUTACK message is a B2B module that is applied to have secure exchange of EDIFACT messages.
Use
You use AUTACK message to ensure:
● Integrity of the payload

● Non-repudiation of receipt and origin of the EDIFACT message
● Authentication of an interchange
You use edi.ack.direction in the Parameter Name column while configuring the module in EDI Separator
adapter receiver channel to implement AUTACK requests and provide the parameter value as Outbound.

 Note
Please, note that you can verify the message status in SAP NetWeaver Administrator Channel Monitor tool
by choosing B2B Acknowledgement tab page.
1.2.13 Configuring the Converter Module Parameters
Context
This document helps you to understand the module configuration parameters for configuring the EDI-XML
converter modules. For more information, refer SAP Note 1800802 .
Procedure
1. Enter the parameters for the appropriate converter modules as described in the table below:
EDI-XML Converter Module Name Parameter Name Description
EDIFACT edifact.encoding This parameter specifies the encoding

of the EDI message (not of the XML).
The default value is ISO-8859-1.
edifact.copy This parameter adds the source mes

sage as an attachment to the PI mes
sage before the actual conversion
starts. The default value is false.
edifact.namespace This parameter specifies the name

space of the XML document.
edifact.indent This parameter formats the messages

with CRLFs and tabs. The default
value is false.
edifact.audit This parameter logs all the processes

carried out by the converter module.
edifact.trace This parameter tracks all the proc

esses involving the converter module.

edifact.monitor.ackstatus This parameter enables the acknowl

edgment logging in the converter
module.
edifact.disable.correlationID This parameter removes Correlatio

nID and ConversationID headers.
edifact.useXMLDecimalMark This parameter, if set to true, replaces

the Delimiter Mark used in the mes
sage with the point '.' symbol in the
present numbers.
edifact.rootElementTag This parameter specifies the root ele

ment name of the XML document. Its
value should be custom root element
name wanted.
For more information, see 3018503

.
EANCOM eancom.encoding This parameter specifies the encoding

eancom.subversion.prefix This parameter allows you to define

the subversion name either as EAN or
GS.
eancom.indent This parameter formats the messages

value is false.
eancom.copy This parameter adds the source mes

eancom.namespace This parameter specifies the name

space of the XML document.
eancom.audit This parameter logs all the processes

carried out by the converter module.
eancom.trace This parameter tracks all the proc

eancom.disable.correlationID This parameter removes Correlatio

nID and ConversationID headers.

eancom.useXMLDecimalMark This parameter, if set to true, replaces

the Delimiter Mark used in the mes
sage with the point '.' symbol in the
present numbers.
eancom.rootElementTag This parameter specifies the root ele

ment name of the XML document. Its
value should be custom root element
name wanted.
For more information, see 3018503

.
ODETTE odette.encoding This parameter specifies the encoding

odette.copy This parameter adds the source mes

odette.indent This parameter formats the messages

value is false.
ANSI ASC X12 x12.encoding This parameter specifies the encoding

x12.copy This parameter adds the source mes

x12.indent This parameter formats the messages

value is false.
x12.monitor.ackstatus This parameter enables the acknowl

edgment logging in the converter
module.
x12.audit This parameter logs all processes car

ried out by the converter module.
x12.trace This parameter tracks all the proc


x12.disable.cache This parameter disables the B2B EDI

Cache while converting an X12 mes
sage.
ANSI X12 to XML x12.default.segmentseparator Default segment separator in case of

invalid XML character.
x12.default.dataseparator Default data separator in case of inva

lid XML character.
x12.default.compositeseparator Default composite separator in case

of invalid XML character.
x12.default.repetitionseparator Default repetition separator in case of

invalid XML character.
TRADACOMS tradacoms.encoding This parameter specifies the encoding

tradacoms.copy This parameter adds the source mes

tradacoms.indent This parameter formats the messages

value is false.
VDA vda.encoding This parameter specifies the encoding

Default value is ISO-8859-1.
vda.copy This parameter adds the source mes

vda.indent This parameter formats the messages

value is false.
vda.trimWhitespaces This parameter removes all the white

spaces from various fields of the out
put. The default value is false.

PLAIN plain.copy This parameter adds the source mes

plain.indent This parameter formats the messages

value is false.
XML - EDI Converter Module Name Parameter Name Description
EDIFACT edifact.handleNumberFormat This parameter handles the number

format (truncating leading and trailing
zeroes) for numeric data elements
with variable length in EDIFACT. As a
decimal mark, a dot “.” has to be used,
as per the XML specification.
EANCOM eancom.handleNumberFormat This parameter handles the number

format (truncating leading and trailing
zeroes) for numeric data elements
with variable length in EANCOM. As a
decimal mark, a dot “.” has to be used,
as per the XML specification.
ANSI ASC X12 x12.checkOfValueMinLength This parameter ensures that the con
verter checks whether all data fields
fulfill the minimal length restriction. If
the minimal length restriction is vio
lated, an error will occur. The default
value is false.
x12.fillUpToMinlength This parameter ensures that the con

verter automatically fills up the data
fields with whitespace characters until
the minimal length restriction has
been reached. This parameter is use
ful only if x12.checkOfValueMinLength
is activated.
xml.x12.segmentseparator Modified segment separator for XML

to X12 conversion.
xml.x12.dataseparator Modified data element separator for

XML to X12 conversion.

XML - EDI Converter Module Name Parameter Name Description
xml.x12.compositeseparator Modified composite separator for

XML to X12 conversion.
xml.x12.repetitionseparator Modified repetition separator for XML

to X12 conversion.
PLAIN plain.handleNumberFormat This parameter handles the number

format to truncate leading and trailing
zeroes during XML to Plain Conver
sion.
2. To use the TPM in the B2B Converter Modules, add the following parameters to each converter module:
tpm.enable This parameter will fetch the TPM Agreement properties

as Control Key and other module parameters, and will use
them for the conversion of the message. To use it, you
need to add the TPMContentAccessModule module
in the Communication Channel module sequence.
tpm.disableControlKeyFromTPM This parameter is used along with the tpm.enable

parameter and disables the option to fetch the Control
Key from the TPM Agreement. The Control Key will be
taken from the Scenario Association Table.
3. You can use the following common parameters for all converter modules:
edi.copy This parameter adds the source message as an

attachment to the PI message before the actual
conversion starts. The source message can be a
supported EDI format. The default value is false.
If you are using SAP NetWeaver 7.31 provide localejbs/

AF_Modules/MessageLoggerBean as the module name,
and then define the parameter name as log.condition and
log.location to ensure persistence for outbound
scenarios.
For more information, refer SAP Note 1815991 .

1.3 Importing User Defined Functions
Use
The SAP NW PI User Defined Functions (UDF) are used for graphical mapping. The UDFs are compatible with
Java version 1.5 or higher, and additional SLD settings or deployments are required.
You use this procedure to import UDFs into the SAP NetWeaver Enterprise Services Repository.
 Note
All UDFs and generic content such as external definitions (of XSDs) and Java mappings are part of the
"B2BMAPPINGKIT1000 patch #0 (SP-level #00)" software component.
Procedure
1. To import the B2B file, open the Enterprise Service Builder, go to the menu and choose 'Tools' -> 'Import
Design Objects'. In the import window, select your B2B file from the file system and choose OK.
2. Refresh the software component tree until you can view the new software component.
3. To use a UDF inside your mapping, you have to connect your software component to the BASIS
component. Double-click your software component version (SCV) and choose Details. Add the BASIS
component as an underlying SCV. Save and activate your changes.
4. Now you can import the required function into a message mapping. If any unexpected errors occur,
contact your technical consultant.
 Note
Before you can use any library, you have to save the mapping first. Otherwise, the graphical mapping
does not process nodes correctly.
User Defined Functions
FunctionLibrary: UDFArithmeticsPool
Function Name Description Sl No Description of Input Return Value

Arguments
bigDecimalAdd Adds two values 1 First value of addition The result of the addi
tion
2 Second value of addi

tion

Arguments
bigDecimalSubtract Subtracts the second 1 The minuend The result of the sub
value from the first traction
value
2 The subtrahend
bigDecimalMultiply Multiplies two values 1 First factor The result of the multi
plication
2 Second factor
bigDecimalDivide Divides the first value 1 The dividend The result of the divi
by the second value, sion
rounding to the num 2 The divisor
ber of decimal places
3 Number of results dec
given by the third value
imal places
bigDecimalRound Rounds the first value 1 The value to be The rounded value
to the number of deci rounded
mal places given by the
second value 2 Number of results dec
imal places
bigDecimalRoundUp Rounds up the first 1 The value to be The rounded value

value to the number of rounded
decimal places given
by the second value 2 Number of results dec
imal places
bigDecimalSum Calculates the sum of 1 A context of values to The sum of the context
all context values be added values
bigDecimalMod Returns the remainder 1 The dividend The remainder

of dividing the first
value by the second 2 The divisor
value
bigDecimalFormat Inserts a decimal point 1 The number to be for The formatted number
Num at given index if possi matted
ble (if index is out of
range, it simply returns
the number)
2 The index of the deci

mal point to be set
FunctionLibrary: UDFDateTimePool

Arguments
getDate Creates a YYYYMMDD 1 Date values to be for Formatted first argu

date from the first ar matted ments date values
gument using the sec
ond argument (an EDI 2 EDIFACT-F2379- com
FACT- F2379-compli pliant qualifier
ant qualifier). The third
argument has one of
the values constant
Date, constantDate
From, or constantDa
teTo provided by this
function library
getTime Creates a HHMM time 1 Date values to be for Formatted first argu
value from the first ar matted ment date values
gument using the sec
ond argument (an EDI 2 EDIFACT-F2379- com
FACT- F2379-compli pliant qualifier
ant qualifier). If the
3 (constant) values:
third argument has the
"true" (dateformat:
value TRUE, the time
HHMM) or "false" (da
format is HHMMSS
teformat: HHMMSS)
constantDate Use this generated 1 No arguments, func

constant as an input tion represents a con
for UDF getDate: indi stant
cates a single date
value
constantDateFrom Use this generated 1 No arguments, func

cates the beginning of
a time period
constantDateTo Use this generated 1 No arguments, func

cates the end of a time
period
getDateDifference Gets the number of 1 Beginning of the time The number of days
days between two interval
dates with YYYYMMDD
format. The first argu
ment marks the begin

Arguments
ning of the time inter 2 End of the time interval

val.
getMonthDifference Gets the number of 1 Beginning of the time The number of months
months between two interval
dates with YYYYMMDD
format. Dates within a 2 End of the time interval
calendar month yield a
0. The first argument
marks the beginning of
the time interval.
getDateAfterDays Gets the date after the 1 A date The date after the
date of the first argu specified days
ment (YYYYMMDD) by
adding a number of 2 Number of days to be
days contained in the added to the date
second argument
getFirstOfMonthAfter Gets the first of month 1 A date The date of the first
Months date after the date of day in the specified
the first argument month
(YYYYMMDD) by add
ing a number of 2 Number of months to
months contained in be added to the date
the second argument
getDateFormat Returns an EDIFACT- 1 A date The format of the date

F2379- compliant
qualifier describing the
date’s format.
getEndDateOfTime Generates the last day 1 A date The date of the last
Period of the week (Argument day of the week/month
2: "W") or month ("M")
for a given date in Ar 2 (constant) values: "W"
gument 1 (last day of week) or
"M" (last day of
month)
getStartOfOneOrTwo Gets the older date of 1 A context of one or two

Dates two dates (if there is dates The older date
only one date, then it is
returned)

Arguments
getStartDateOfTime Generates the first day 1 A date The date of the

Period of the week (Argument first day of the week/
2: "W") or month ("M") month
for a given date in Ar
gument 1 2 (constant) values: "W"
(first day of week) or
"M" (first day of
month)
FunctionLibrary: UDFGlobalsPool

Arguments
initGlobalCounter Creates a global pa 1 Name of the global ""

rameter with name counter
given by the first argu
ment. The initial value
is set to "0".
increaseGlobalCounter Increments the value 1 Name of the global ""

of a global counter counter
(identified by the first
argument) by "1"
getGlobalCounterValue Gets the value of global 1 Name of the global The current counter
counter identified by counter value
the first argument
setParameter Sets a global parame 1 Name of the global pa The value of the pa
ter; first value defines rameter rameter that has been
the name, the second set
one sets the value
2 Value of the global pa
rameter
getParameter Returns the value of a 1 Name of the global pa The value of the pa
global parameter, iden rameter rameter
tified by the argument
increaseOrCreateGlo Increments the value 1 Context of boolean val The current counter
balCounterIfTrue of a global counter ues value
(identified by the sec
ond argument) by "1" 2 Name of the global
for every value con counter
taining "true" in the

Arguments
first argument; if nec 3 Initial value for counter

essary the counter is
initialized with the ar
gument.
hasGlobalCounter Returns "true" if a 1 Name of the global

counter (identified by counter "true" or
the first argument) al "false"
ready exists, otherwise
"false"
FunctionLibrary: UDFNodePool

Arguments
createIfHasValue Produces empty value 1 A context of values Context with values ""
if argument is not or SUPPRESS
empty; ResultList.
SUPPRESS otherwise
createIfExistsAndHas Produces empty value 1 A context of values Context with values ""
Value if argument is not or SUPPRESS
empty and exists; Re
sultList. SUPPRESS
otherwise
createIfHasOneOf Produces empty value 1 A context of values Context with values ""
SuchValues when the first argu or SUPPRESS
ment has one of the 2 (constant) Values to be
values passed as a checked; separated by
constant in the second semicolon (e.g.
argument (separated "AG;BY")
by a semicolon); Re
sultList. SUPPRESS
otherwise
passIfHasValue Passes all context val 1 A context of values Input context with
ues and empty values empty values replaced
are replaced by Result by SUPPRESS
List. SUPPRESS
assignValueByCondi Passes a value from 1 A context of condition Third argument con

tion the third argument values text with values not
when the correspond matching the condition
ing value from the first

Arguments
argument has one of 2 (constant) Values to be replaced by SUP

the values contained in checked; separated by PRESS
the second value semicolon (e.g.
(these conditions are "AG;BY")
separated by a semico
lon); passes ResultList. 3 A context of values
SUPPRESS otherwise
simpleUseOneAsMa Uses the first argu 1 A context containing A number of contexts

nyAndSplitByEach ment (the context one value (containing one value)
Value should have exactly defined by 2.argu
one value) as often as 2 A context of values ments length
the length of the sec
ond context indicates
and splits the result by
each value.
simpleUseOneAsMany Uses the first argu 1 A context containing The second context fil-
ment (the context one value led with the value from
should have exactly the first argument
one value) as often as
the length of the sec
ond context indicates
deleteSuppress Maps every context 1 A context of values Input context reduced

value to itself when not in length by number of
null and not ResultList. SUPPRESS fields
SUPPRESS - maybe
the context queue is
shorter
getFirstContextValue Returns the first non- 1 A context of values A value or SUPPRESS

empty context value or
ResultList. SUPPRESS
if no such value exists.
existsAndHasValue Produces "true" if the 1 A context of values Context with boolean

argument is not values
empty; "false" other
wise

Arguments
existsAndHasOneOf Produces "true" if the 1 (constant) Values to be Context with boolean

SuchValues first argument has one checked; separated by values
of the values passed as semicolon (e.g.
a constant in the sec "AG;BY")
ond argument (sepa
rated by a semicolon);
otherwise "false"
contextHasOneOf Produces a single 1 A context of values Boolean value

SuchValues "true" if the first argu
ment (a context 2 (constant) Values to be
queue) contains one of checked; separated by
the values passed as a semicolon (e.g.
constant in the second "AG;BY")
argument (separated
by a semicolon); other
wise "false"
useOneContextAs Uses the first argu 1 A context of values A number of contexts

Many ment context as often defined by 2.argu
as values exist in the 2 A context of values ments length
second argument con
text.
concatToOneQueue Puts all arguments se 1 A context of values A context (length de
quentially into one fined by sum of all in
queue 2 A context of values puts length)
3 A context of values
deleteMultipleContext Removes all multiple 1 A context of values A context reduced in

Values values from the con size by number of dou
text, leaving only the ble values
first.
concatContextValues Concatenates all val 1 A context of values One string value

ues of a context sepa
rated by second argu 2 Separator
ment
formatByContextEx Format contexts in first 1 Queue (input queue) Queue (with first argu
ample queue (input queue) ments length and for
by values (represent

Arguments
ing contexts) in second 2 Queue (example matted by second ar

queue (example queue) guments format)
queue); requirement:
number of contexts in
inputQueue = number
of values in example
queue
createMultipleCopies Duplicates first argu 1 A context of values to A context of values

ment's value as often be duplicated (equal or enlarged in
as value in second ar size to first arguments
gument indicates; con 2 A context of values in size)
texts must have the dicating the number of
same size duplications
fragmentSingleValue Fragments the first ar 1 The value to be frag Context containing
gument into a max. mented fragments as values
number of pieces
(given by the second 2 Maximum number of
argument) of length fragments
from the third; the last
3 Fragment length
one may be shorter. All
arguments are treated
like constants.
concatTwoQueues Puts all arguments se 1 A context of values A context contains

ToOne quentially into one both input arguments
queue 2 A context of values
rearrangeByKey Rearranges the third 1 Context of values rep A context of rear

argument by the corre resenting the rear ranged values
sponding key set in the ranged key set
second argument for
matted by the first ar 2 Context of values rep
gument resenting the key set
3 Context of values to be
rearranged
getValueByIndex Returns a value from a 1 A context of values Value at given index

context(arg1) by given
index(arg2) (starting 2 Index
at 1)
createNumberRange Creates an empty 1 Start value Context with values ""

string for each number
missing between first

Arguments
and second argument 2 End value

values
createContextsForFix Splits context in first 1 A context of values Split context

edBlockSize argument into blocks
defined in size by pa 2 (parameter) Block size
rameter
buildBlocksAndGetVa Splits context in first 1 A context of values Value at given index

lueByIndex argument into blocks
defined in size by pa 2 Index
rameter and returns
3 (parameter) Block size
value at index given by
second argument
createContextsForFix Splits context in first 1 A context of values Split context

edBlockSize001 argument into blocks
defined in size by sec 2 Block size
ond argument
FunctionLibrary: UDFUtilsPool

Arguments
hasValue Returns "true" if the 1 Empty or non-empty Boolean value

first argument is not value
empty; "false" other
wise
hasOneOfSuchValues Returns "true" when 1 A value Boolean value

the first argument has
one of the values 2 (constant) Values to be
passed as a constant checked; separated by
in the second argu semicolon (e.g.
ment (separated by a "AG;BY")
semicolon); "false"
otherwise
trimZeroLeft Removes leading ze 1 Value representing a Input number without

ros. number leading zeros
trimRight Removes trailing white 1 A value Input value without

spaces (leading white trailing white spaces
spaces may be signifi-
cant)

Arguments
splitToIndex Splits the first argu 1 A value Part of input value

ment by a delimiter
(third argument) and 2 Index
returns the partial
3 Delimiter
string requested by the
second argument (or
an empty string if no
such partial string ex
ists)
formatValueByZero Creates a new string 1 A value Formatted input value

from a non-empty first
argument with length 2 Length of new value
given by the second as
3 "left" or "right" end cut
follows: cut at left or
right end (the third ar
4 Boolean ("true" = fill)
gument) or fill with "0"
(if the fourth says 5 "left" or "right" end fill
"true") at left or right
side (defined by the
fifth))
headString Removes the trailing 1 A value Head string of input

characters of the first value
argument leaving the 2 Length of new value
number of characters
given by the second ar
gument. Attention:
white spaces are sig
nificant, no trim is in
action.
tailString Removes the leading 1 A value Tail string of input

characters of the first value
argument leaving the 2 Length of new value
number of characters
given by the second ar
gument. Leading or
trailing white spaces
do not count.
isNumber Returns "true" if the ar 1 A value Boolean value

gument is a number,
"false" otherwise

Arguments
toNumber Formats a string like a 1 A value A number

number (removes +
sign and leading/trail
ing zeros)
minusFromBegin Sets the minus sign 1 A value Modified input value

ToEnd from the beginning to
the end
minusFromEndToBe Sets the minus sign 1 A value Modified input value

gin from the end to the be
ginning
isNumberEqualZero Returns "true" if the ar 1 A value Boolean value

gument is the number
zero, "false" otherwise
isNumberNotEqual Returns "true" if the ar 1 A value Boolean value

Zero gument is a number
but not zero, "false"
otherwise
FunctionLibrary: UDFVdaPool
Function Name Description Sl Description of In Return Value

N put Arguments
o
setVDADecimalSepara Sets a decimal point so that the last digits (their 1 A value represent Input value in deci
tor number is contained in the second argument) of ing a VDA number mal number for
the first argument become decimal places mat
2 Number of deci
mal places
formatToVDAValue Transfers a (decimal) number (the first argument) 1 A value represent Input value in VDA
into an integer considering the last digits (their ing a decimal number format
number is contained in the second argument) as number
decimal places
2 Number of deci
mal places
isValidVDADate Checks if a date is a valid VDA date (a YYMMDD 1 A date Boolean value
date string)
transformFromVDADate Transforms a valid VDA date (the argument) to for 1 A VDA date A date (format
mat YYYYYMMDD; an invalid VDA date produces a YYYYMMDD)
ResultList.SUPPRESS

Function Name Description Sl Description of In Return Value
N put Arguments
o
transformToVDADate Transforms a YYYYYMMDD date (the argument) to 1 A date (format A VDA date
a valid VDA date YYMMDD YYYYMMDD)
trimVDAZeroRight Convenience when removing unnecessary VDA 1 A value Input value short
decimal places: removes a number of zeros from ened by number of
the tail of a value. Pay attention: There is no check 2 Number of zeros zeros
on whether the last number of zero characters
really are all zero.
User Defined Functions: Trading Partner Management
Function Name Description Sl Input Argu Description

No ment
getParty Gets the party name for the given 1 agency Agency Name
agency, scheme and party identifier as
maintained in the PI party identifiers. 2 scheme Scheme name
3 partyIdentifier Party Identifier for Agency
addDynamicHeader Adds the dynamic header with the given 1 headerNS Dynamic header namespace
header key, header namespace, and
header value. It passes the given header 2 headerKey Dynamic header key
value as output.
3 headerValue Dynamic header value
getPartyID Gets the party ID for the given party 1 partyName Name of the party as mentioned
Name, agency, scheme as maintained in in the Integration Directory.
the PI party identifiers.
2 agency Agency Name for which the iden
tifier is required.
3 scheme Scheme name for which the

identifier is required.
getAgreementID Gets the agreement ID for the given set 1 senderParty Sender ID as configured in TPM
of PI Message context maintained in Partner Profile.
TPM. If more than 1 agreements are re
trieved, then most matching agreement 2 senderQual Sender Qual as configured in
is retrieved. TPM Partner Profile.
3 receiverParty Receiver ID as configured in TPM

partner profile.
4 receiverQual Receiver Qual as configured in

TPM partner profile.

No ment
5 senderService Sender service as configured in

TPM agreement.
6 receiverSer Receiver service as configured in

vice TPM agreement.
7 interf Interface name as configured in

TPM agreement.
8 namespace Interface Namespace as config-

ured in TPM agreement.
getAgreementID Use this UDF to retrieve parameters 1 senderID Sender partner identifier as con
such as message format, message re figured in TPM Partner Profile.
lease, and so on. It fetches the agree
ment ID for the given EDI message con 2 senderIDQual Sender partner agency qualifier
text maintained in TPM. If more than 1 code as configured in TPM Part
agreements are retrieved, then most ner Profile.
matching agreement will be retrieved.
3 receiverID Receiver partner identifier as
configured in TPM partner pro
file.
4 receiverIDQ Receiver partner agency qualifier

ual code as configured in TPM part
ner profile.
5 msg_protc Message Protocol
6 msg_type Message Type
7 msg_ver Message version
8 msg_subver Message Sub version
9 msg_rel Message release
10 msg_agency Message agency
11 direction Message direction
getAgreementID Returns the TPM agreement ID for given 1 senderProfi- Sender Partner name
Partner Parameters. The values should leID
match exactly as defined in agreement
2 receiverProfi- Receiver Partner Name
leID
3 msg_protc Message format

No ment
4 msg_type Message type
5 msg_ver Message version
6 msg_subver Message subversion
7 msg_rel message release
8 msg_agency Message Agency
9 direction Message direction
getFunctionalProfile- Gets the functional profile name for the 1 agreementID Agreement ID for which the
Name given agreement ID. Functional Profile name needs to
be retrieved.
getSystemEnviron Returns the current activated system

environment test or production from
ment
TPM.
getIdentity Returns the required identity for the 1 sourceID Partner Identifier
given partner ID and Qualifier code
2 sourceQual Source partner qualifier agency
code
3 targetQual Target partner qualifier agency

code
getFunctionalProfile- Gets the functional profile property 1 profileName Functional profile name.
Property value for the given Functional profile
name. 2 keyName Property Name for which the
property needs to be extracted.
1.4 B2B Integration Cockpit
Use
The B2B integration cockpit is a central application that allows you to monitor and access business-to-
business add-on from SAP NW PI environment. You can use the B2B integration cockpit:
● For more information about technical logs generated by the OFTP adapter, see Log Viewer [page 156].
● For more information about configuring the EDI documents, see Configuring the EDI Content Manager
[page 159].

● For more information about defining and maintaining NRO values, see Maintaining Number Range Objects
[page 120].
● For more information about defining and maintaining partner specific data, see Trading Partner
Management [page 209].
● For more information about securely storing PGP keys, refer Secure Connectivity add-on
Configuration Guide Configuring PGP Module Maintaining PGP Keys
● For more information about logs generated by the AS2 adapter, see Scheduling Log Clean-up Job [page
159]
● For more information about generating X12 content, see
1.4.1 Log Viewer
Use
You use this document to understand the filtering criteria for viewing the list of log events that are generated by
the OFTP and AS2 adapters. The OFTP log viewer provides the following information:
● The date and time details of the log

● The communication channel of the message
● The status of the communication channel
● The message ID and its description
● The IP address of the communication system
● The nature of the message that is represented with an icon
● The Partner Odette ID
● The virtual FDSN
● The direction of the message
 Note
Enter the URL format as http:<localhost:port>/b2bic in the Web browser and then choose OFTP Log
Viewer.
The filtering criteria available in the OFTP and AS2 log viewer are described in the table below:
Filter criteria Description
From Determines the starting date and time from, which the query
has to be executed
To Determines the end date and time until, which the query has
to be executed
Maximal number of rows to read Reads and displays the number of logs according to the
given number of rows

Number of rows to display Displays the logs according to the given number of rows
Wrap text Wraps long text displayed in the table
The advanced filtering criteria available in the OFTP and AS2 log viewer are described in the table below:
Filter Criteria AS2 / OFTP Description
AS2 URL (Local / Remote) AS2 URL of AS2 sender
AS2 Message Subject AS2 Subject of the AS2 message
Partner AS2 Name AS2 Partner's unique AS2 name
Own AS2 Name AS2 Company's (using PI) unique AS2

name
AS2 Message ID AS2 Unique ID of the AS2 message
Local Address OFTP TCP/IP address or Fully Qualified

Domain Name (FQDN) of the machine
that allows the OFTP adapter to
connect to the partner system
Remote Address OFTP TCP/IP address or Fully Qualified

Domain Name (FQDN) of the remote
machine that allows the OFTP adapter
to connect to the partner system
Partner Odette ID OFTP Unique Odette-ID of the partner, which

helps to identify the outbound
message
Own Odette ID OFTP Unique Odette-ID of the sender, which

helps to identify the inbound messages
Virtual FDSN OFTP Dataset name of the virtual file being

transferred
Channel AS2 / OFTP Channel name which can be selected

based on protocol type
PI Party AS2 / OFTP Name of the PI party
Business Component AS2 / OFTP Name of the business component
Direction AS2 / OFTP Direction of the message, whether

outbound or inbound
Status AS2 / OFTP Status of the message
 Note
You can export the table content as an XML file by choosing the Export button.

1.4.1.1 Configuring Java System Properties
Context
You use this procedure to configure the Java System Properties tool to enable the application to store AS2 and
OFTP logs in the B2B database
Procedure
1. To access SAP NetWeaver Administrator, enter the URL format as http:<localhost:port>/nwa
2. Choose Configuration Infrastructure Java System Properties .

3. Choose the Applications tab page, and enter AS2 or OFTP in the filter field.
4. From the application details table, select com.sap.aii.adapter.as2.app or com.sap.aii.adapter.oftp2.app.
5. From the Extended Details table, select the b2b.log.level and then choose Modify to set the custom
calculated value to log AS2 and OFTP transaction instances.
 Note
WARN is the default value for this parameter
6. Enter one of the following log levels in the Modify Property Value dialog box:
Log Levels Description
ALL All level of log entries are stored
FATAL Stores severe errors
ERROR Stores transaction errors and fatal log entries
WARN Stores warnings encountered by the transactions as well

as error and fatal log entries
INFO Stores information about the transactions as well as warn

ings, errors, and fatal log entries
OFF This value turns off the process of storing the logs during
the transaction

1.4.2 Scheduling Log Clean-up Job
You have to schedule a predefined job LogViewerCleanJob in the Java Scheduler to clean up log entries. Set the
interval to clean up the entries by defining the maximum age in days (maxAgeDays) and with reference to the
scheduled interval it deletes logs that older than the interval.
 Note
You can schedule LogViewerCleanJob under Java Scheduler menu in SAP NetWeaver Administrator
application.
Example
Consider you have provided the maxAgeDays parameter as 31; the job deletes all the log entries that are older
than 31 days.
1.4.3 Configuring the EDI Content Manager
Context
The EDI content manager is an application that allows you to do the following:
● Create or edit different components of EDI messages
 Note
You can create or update the different message components in an EDI document only if you have
defined a customized "control key."
● Generate XSD files

● Export or import EDI documents
● Convert EDI documents to XML and the other way round
● Test the conversion of EDI messages
● Assign user roles to manage EDI content manager. The table below provides information on user roles
privileges to be assigned to users.
For more information about assigning roles to users for managing EDI content manager, refer B2B Security
Guide (Assigning user roles for managing the EDI content manager application).

You use this procedure to configure the settings of different EDI message formats in the EDI content manager.
Procedure
1. To access the EDI content manager, enter the URL format as http:<localhost:port>/b2bic in the Web
browser.
2. On the B2B Integration Cockpit Web page, choose EDI Content Manager.
3. To configure the EDIFACT message settings, choose Edifact.
 Note
For more information, see Configuring the EDIFACT Message Format [page 161].
4. To configure EANCOM message settings, choose EANCOM.
 Note
For more information, see Configuring the EANCOM Message Format [page 171].
5. To configure ANSI X12 message settings, choose Ansi X12.
 Note
For more information, see Configuring the ANSI X12 Message Format [page 182].
6. To configure Odette message settings, choose Odette.
 Note
For more information, see Configuring the Odette Message Format [page 191].
7. To configure Tradacoms message settings, choose Tradacoms.
 Note
For more information, see Configuring the Tradacoms Message Format [page 196].
8. To configure VDA message settings, choose VDA.
 Note
For more information, see Configuring the VDA Message Format [page 199].
9. To configure Plain message settings, choose Plain.
 Note
For more information, see Configuring the Plain Message Format [page 200].
10. To compare the message contents of two similar EDI messages, choose Compare Messages.
 Note
For more information, see Comparing EDI Messages [page 206].

1.4.3.1 Configuring the EDIFACT Message Format
Prerequisites
 Note
Please, note that the SAP Process Integration, business-to-business add-on supports UN/EDIFACT Message
Standard up to UN/EDIFACT Syntax Version 3.
Procedure
1. For more information on importing or exporting EDIFACT message content, see Importing or Exporting
Message Content [page 161].
2. For more information on creating or editing message components of EDIFACT, see Editing EDIFACT
Message [page 162].
3. For more information on conversion of EDIFACT to XML and vise versa, see Converting EDIFACT Message
[page 166].
4. For more information on generating XSD files, see Generating XSD Files [page 166].
5. For more information on editing tables, see Editing Tables [page 167].
1.4.3.1.1 Importing or Exporting Message Content
Procedure
1. To browse and import the "b2b" file contents , choose Edifact Import/Export Content Import .
2. To export selected EDIFACT message types, choose Edifact Import/Export Content Export .

1.4.3.1.2 Editing EDIFACT Message
Context
You use this procedure to create, edit, or delete message components in an EDIFACT document. These
features are available only for user defined control keys.
 Note
When editing or creating an EDIFACT message always follow bottom-up approach that begins with editing
or creating data elements and progress hierarchically.
Procedure
1. To create or edit an EDIFACT message, choose Edifact Editor Message Editor .

1. To edit or create EDIFACT message components, select the appropriate component link from the name
column and enter the parameters as described in the table below:
Edit Message Message Format This parameter specifies the mes

sage format of the EDI document.
Create Messages This parameter allows you to create

a new EDIFACT message. This fea
ture is available only for user defined
control key.
Update Messages This parameter allows you to add,

edit or delete segment or segment
group.
Remove Messages This parameter allows you to remove

selected messages from the trans
action.
Control Key This parameter defines the type of

control key used.
For more information on control key,

see the note below.

Version This parameter determines the ver

sion of the EDI message.
Message This parameter determines the EDI

message type.
Copy Control Key This parameter allows you to copy

EDI message contents from SAP de
fined control key to a new control
key or an existing control key.
Delete Control Key This parameter allows you to delete

control keys other than SAP defined
control key.
Edit This parameter allows you to edit

segments or segment groups that
are defined for user specific control
key.
Add This parameter allows you to add

key.
Delete This parameter allows you to delete

segment or segment group that are
defined for user specific control key.
Segment Details Show Segment This parameter displays only those

segments that are defined for user
specific control key.
Move Index This parameter allows you to move

the segment from the current posi
tion to a new position. This feature is
available only for user defined con
trol key.
Create Segment This parameter allows you to create

a new EDIFACT segment. This fea
control key.
Update Segment This parameter allows you to update

the segments in the table with new
values. This feature is available only
for user defined control key.

Remove Selected Segment Fields This parameter allows you to remove

the selected segments from the ta
ble. This feature is available only for
user defined control key.
Description This parameter allows you to provide

a short description on the segment.
Note This parameter allows you to provide

a brief remark on the segment.
Available Composite and Data This section contains features to

Elements add selected composites and data
elements to the segment.
Create/Edit Composites Composites This parameter determines the

batch of composite elements that
key.
Move To Index This parameter allows you to move

the composite element from the cur
rent position to a new position. This
feature is available only for user de
fined control key.
Create Composite This parameter allows you to create

a new composite element. This fea
control key.
Update Composite This parameter allows you to update

the composite elements in the table
with new values. This feature is avail
able only for user defined control
key.
Remove Selected Fields This parameter allows you to remove

the selected composite elements
from the table. This feature is availa
ble only for user defined control key.

a short description on the composite
element.


a brief remark on the composite ele
ment.
Available Data Elements This section contains features to

add selected data elements to the
composite elements.
Create/Edit Data Element Create Data Element This parameter allows you to create
new data element. This feature is
trol key.
Edit Data Element This section contains parameter to

edit and update the different values
in an existing data element.
 Note
The control key represents a version of an EDI message definition. You can maintain different
control keys for a single EDI message for customizing the EDI message definitions. The standard
EDI content for individual transaction sets are delivered by SAP in the control key label "SAP". The
SAP defined control key cannot be edited or modified. This is to ensure that you never lose the
original version and receive new updates for SAP delivered control key. However, you can modify or
customize the message definitions by making an additional copy of the SAP defined control key
and include selected message type and versions required for your business scenarios. You save the
newly created control key with a unique name, which allows alphanumeric characters, reflecting
the business context.
2. To edit and map the control key as per the required business scenario, choose Edifact Editor
Control Key Scenario Association .
1. To define a new mapping scenario for a control key and to insert it into a row as per the specified index
value, choose Insert.
 Caution
Do not define identical mapping scenarios for any two control keys.
2. To delete a mapping scenario from the table, select a control key name and then choose Delete.
3. To edit an existing mapping scenario in the table, select a control key name and then choose Edit.
4. To refresh the contents in the table, choose Refresh.
3. To describe the purpose of a control key, choose Edifact Editor Control Key Description Editor .
1. To describe a control key, click on the Description column and enter the details.
2. To save the changes, choose the Save Button.

1.4.3.1.3 Converting EDIFACT Message
Context
You use this procedure to test the conversion from EDIFACT to XML message and vise versa.
Procedure
1. To test the conversion of an EDIFACT message to XML message format, choose Edifact Edifact - XML -
Converter Edifact to XML .
2. To test the conversion an XML message to EDIFACT message format, choose Edifact Edifact - XML -
Converter XML to Edifact .
1.4.3.1.4 Generating XSD Files
Context
You use this procedure to generate XSD file for a specific EDIFACT message type and version.
Procedure
1. To generate an XSD file, choose Edifact XSD Generator .

2. On the Edifact XSD Generator page, enter the parameters as described in the following table:
Edifact XSD Generator XML-Namespace Define the path of XML file.
Target Namespace Define the path of the target file.
Control Key Name Define the specific control key at

tached to the Edifact message.

Include Notes Attach notes to the XSD file.
Restrict Charset to UNOB The character set that is used to vali

date the Edifact interchange is limited
to UNOB character set.
Enable Batch Message Support Allows you to add requirement spe

cific Edifact message types.
Define the name of the XSD root ele

ment.
Maintain Compatibility to Previous This parameter allows to maintain the

Releases compatibility with previous Edifact re
leases.
Type Define the Edifact message type.
Version Define the Edifact message version.
Add UNG Segment Allows you to add UNG segment to

the XSD file.
All Versions Allows you to include all version of Ed

ifact standards to the XSD file.
3. To generate an XSD file, choose Start.
1.4.3.1.5 Editing Tables
Procedure
1. To perform actions such as editing the table, inserting a new row, deleting selected rows, or exporting
selected rows from the table of an EDIFACT message type, choose Edifact Tables .
2. Select the appropriate table to be edited. For more information on EDIFACT tables, refer the EDIFACT
Tables section below.
3. To display the number of rows in a table, enter the numerical value in the Rows displayed field.
4. To update the contents of the table, choose Refresh.
5. To export the selected rows of a table in "*.b2b" file format, choose Export selected rows.
6. To edit the selected table, choose Edit.
7. Select the appropriate column to be edited and enter the parameters.
8. To insert a new row in the table, choose Insert new row.
9. To delete selected rows from the table, choose Delete selected rows.
EDIFACT Tables

The EDIFACT module uses two different types of tables:
● The control tables ("B2B_EDI_CTRL_*") contain rules for creating the nesting structure for the conversion
of the messages.
○ B2B_EDI_CTRL_IF: This control table manages single interfaces, with which the key (EDI_CTRL_KEY)
to be used can be determined.
○ B2B_EDI_CTRL_MSG: This control table contains corresponding instructions for every message type
and every version, which is used to interpret and construct the structural description of an EDIFACT
message. The single states and state transitions of the "Mealy machine" have to be specified here.
Field Description
CTRL_KEY "Control Key" for predefined interface from

"B2B_EDI_CTRL_IF"
MESSAGETYP Message type
MESSAGEVERSION Directory version
STATUS_CURRENT Current status - Context to which the table entry refers
SEGMENT Segment that was found
STATUS_NEW New status
SEG_ACTION Action to be performed for building the segment struc

ture. The letter C representing the Segment-XML-Struc
ture.
○ B2B_EDI_CTRL_SEG : This table contains the structural description for the segments. As these
segments are structured in the same way for all messages of a specific version, the reference to the
message type is no longer required. The structure of the composites is managed in a separate table.
Field Description

"B2B_EDI_CTRL_IF"
SEGMENT Segment to which the entry refers
IDX Index of the composites in the segment
COMP Name of the composites that can be found under the

corresponding segment and index
○ B2B_EDI_CTRL_CMP: This table is used to manage the data objects of the composites. This and the
previous table are used to build the Segment-XML-Structure.

Field Description

"B2B_EDI_CTRL_IF"
COMP Composite to which the entry refers
IDX Index of the element in the composite
EDI_ELEMENT Name of the element that can be found under the corre
sponding composite and index
● The definition tables ("B2B_EDI_DEF_*") manage information for generating the XML Definition Schemes
(XSD).
○ B2B_EDI_DEF_MSG: This table is used to define the message structure on the highest level. It
determines, depending on the message type and directory version, the number of segments and their
order according to an index.
Field Description
MESSAGETYPE Message version
MSG_INDEX Position of the segment in the message
MSG_SG Message segment
○ B2B_EDI_DEF_MSG_SG : This table is used for a more precise definition of the arrangement of the
segments, and segment groups in terms of message type, directory version and segment.
Field Description
ID Message segment. Defined in previous table (MSG_SG)
STATUS Comment whether it is a mandatory segment or not
○ C: Optional ( Conditional, " Can")

○ M: Mandatory ( Mandatory, " Must")
REPETITION Possible occurrence of the segment
NAME Name of the segment

DESCRIPTION Description for the segment
SEGTYPE Segment type:
○ S: Segment
○ G: Segment group
PARENT Reference to the superordinate segment in regard to

segments within one segment group
PARENT_INDEX Index of the segment with regard to Parent
○ B2B_EDI_DEF_SEG : This table provides names and arrangement of the composites in a segment.
Field Description
SEGMENT Name of the segment
SEG_INDEX Position of the composite in the segment
FIELD Name of the composite

OCCURRENCES Possible occurrence of the composite
SEG_FUNCTION Notes
SEG_NOTE Description for the segment
○ B2B_EDI_DEF_CMP : This table contains the description on the arrangement of the single fields within
the composites.
Field Description
COMPOSITE Name of the composite
COMP_INDEX Position of the field in the composite
FIELD Identifier for the field


DESCRIPTION Description about the content of the composite
NOTE Notes
○ B2B_EDI_DEF_ELE : Analogous to the previous tables this table contains a more precise description
for the single fields.
Field Description
IDENTIFIER Identifier of the field. Defined in previous table (FIELD)
NAME Name of the field
REPR Value formats
○ a: alphabetical
○ n: numerical
○ an: alphanumerical
○ ..xy: Number (=xy) of valid characters
DESCRIPTION Description about the content of the field
NOTE Notes
1.4.3.2 Configuring the EANCOM Message Format
Procedure
1. For more information on importing or exporting EANCOM message content, see Importing or Exporting
2. For more information on creating or editing message components of EANCOM, see Editing EANCOM
Message [page 172].
3. For more information on conversion of EANCOM to XML and vise versa, see Converting EANCOM Message
[page 176].

Procedure
1. To browse and import the "b2b" file contents , choose EANCOM Import/Export Content Import .
2. To export selected EANCOM message types, choose EANCOM Import/Export Content Export .
1.4.3.2.2 Modifying EANCOM Message
Context
You use this procedure to create, edit, or delete message components in an EANCOM document. These
 Note
When editing or creating an EANCOM message always follow bottom-up approach that begins with editing
Procedure
1. To create or edit an EANCOM message, choose EANCOM Editor Message Editor .

1. To edit or create EANCOM message components, select the appropriate component link from the
name column and enter the parameters as described in the table below:


a new EANCOM message. This fea
control key.


edit or delete segment or segment
group.

action.

control key used.

see the note below.


message type.


control key.

key.

key.




trol key.

a new EANCOM segment. This fea
control key.






key.

fined control key.

control key.


key.


element.

ment.

composite elements.
trol key.

 Note
2. To edit and map the control key as per the required business scenario, choose EANCOM Editor

 Caution
3. To describe the purpose of a control key, choose EANCOM Editor Control Key Description Editor .
1.4.3.2.3 Converting EANCOM Message
Context
You use this procedure to test the conversion from EANCOM to XML message and vise versa.
Procedure
1. To test the conversion of an EANCOM message to XML message format, choose EANCOM EANCOM -
XML - Converter EANCOM to XML .
2. To test the conversion an XML message to EANCOM message format, choose EANCOM EANCOM -
XML - Converter XML to EANCOM .
Context
You use this procedure to generate XSD file for a specific EANCOM message type and version.

Procedure
1. To generate an XSD file, choose EANCOM XSD Generator .

2. On the EANCOM XSD Generator page, enter the parameters as described in the following table:
EANCOM XSD Generator XML-Namespace Define the path of XML file.
Target Namespace Define the path of the target file.

tached to the EANCOM message.
Include Notes Attach notes to the XSD file.
Restrict Charset to UNOB The character set that is used to vali

date the EANCOM interchange is lim
ited to UNOB character set.

cific EANCOM message types.

ment.

Releases compatibility with previous EANCOM
releases.
Type Define the EANCOM message type.
Version Define the EANCOM message version.
Subversion Define the EANCOM message subver

sion.
Add UNG Segment Allows you to add UNG segment to

the XSD file.
All Versions Allows you to include all version of

EANCOM standards to the XSD file.

Procedure
selected rows from the table of an EANCOM message type, choose EANCOM Tables .
2. Select the appropriate table to be edited. For more information on EANCOM tables, refer the EANCOM
EANCOM Tables
The EANCOM module uses two different types of tables:
of the messages.
○ B2B_EDI_CTRL_CMP: This table is used to manage the data objects of the composites. This and the
Field Description

"B2B_EDI_CTRL_IF"
COMP Composite to which the entry refers
○ B2B_EDI_CTRL_IF: This control table manages single interfaces, with which the key (EDI_CTRL_KEY)
○ B2B_EDI_CTRL_MSG: This control table contains corresponding instructions for every message type
and every version, which is used to interpret and construct the structural description of an EANCOM
message. The single states and state transitions of the "Mealy machine" have to be specified here.
Field Description

"B2B_EDI_CTRL_IF"

ture.
○ B2B_EDI_CTRL_SEG : This table contains the structural description for the segments. As these
Field Description

"B2B_EDI_CTRL_IF"
SEGMENT Segment to which the entry refers

(XSD).
○ B2B_EDI_DEF_CMP : This table contains the description on the arrangement of the single fields within
the composites.
Field Description


NOTE Notes
○ B2B_EDI_DEF_ELE : Analogous to the previous tables this table contains a more precise description
Field Description
REPR Value formats
○ a: alphabetical
○ n: numerical
NOTE Notes
○ B2B_EDI_DEF_MSG: This table is used to define the message structure on the highest level. It
Field Description
○ B2B_EDI_DEF_MSG_SG : This table is used for a more precise definition of the arrangement of the
segments, and segment groups in terms of message type, directory version and segment.
Field Description


SEGTYPE Segment type:
○ S: Segment

○ B2B_EDI_DEF_SEG : This table provides names and arrangement of the composites in a segment.
Field Description

OCCURRENCES Possible occurrence of the composite
SEG_FUNCTION Notes
SEG_NOTE Description for the segment

1.4.3.3 Configuring the ANSI X12 Message Format
Procedure
1. For more information on importing or exporting ANSI X12 message content, see Importing or Exporting
2. For more information on creating or editing message components of ANSI X12, see Editing ANSI X12
Message [page 182].
3. For more information on conversion of ANSI X12 to XML and the other way round, see Converting ANSI X12
Message [page 186].
Procedure
1. To browse and import contents in ANSI X12 message, choose ANSI X12 Import/Export Content
Import .
2. To export selected ANSI X12 message types, choose ANSI X12 Import/Export Content Export .
1.4.3.3.2 Modifying ANSI X12 Message
Context
You use this procedure to create, edit, or delete message components in an ANSI X12 document. These
 Note
When editing or creating an ANSI X12 message always follow bottom-up approach that begins with editing

Procedure
1. To create or edit an ANSI X12 message, choose ANSI X12 Editor Message Editor .
1. To edit or create ANSI X12 message components, select the appropriate component from the Edit drop
down and enter the parameters as mentioned in the table below:


a new ANSI X12 message. This fea
control key.

edit or delete segment or loop.

action.

control key used.

see the note below.


message type.


control key.

key.

key.



trol key.

a new ANSI X12 segment. This fea
control key.






key.

fined control key.

control key.

key.


element.

ment.

composite elements.
trol key.

 Note

2. To edit and map the control key as per the required business scenario, choose ANSI X12 Editor
 Caution
3. To describe the purpose of a control key, choose ANSI X12 Editor Control Key Description Editor .
1.4.3.3.3 Converting ANSI X12 Message
Context
You use this procedure to test the conversion from ANSI X12 to XML and other way round.
Procedure
1. To test the conversion of an ANSI X12 message to XML message format, choose ANSI X12 ANSI X12 -
XML - Converter ANSI X12 to XML .
2. To test the conversion of an XML message to ANSI X12 message format, choose ANSI X12 ANSI X12 -
XML - Converter XML to ANSI X12 .

Context
You use this procedure to generate XSD file for a specific ANSI X12 message type and version.
Procedure
1. To generate an XSD file, choose ANSI X12 XSD Generator .

2. On the XSD Generator page, enter the parameters as described in the following table:
XSD Generator Include Syntax Notes The XSD file comprises of syntax
notes that defines the meaning and
relationship of the data elements.
Include Semantic Notes The XSD file comprises of semantic

notes that defines the structure of X12
document.
Include Comments Attaches comments related to the X12

message.
Namespace Provide the URL path of the X12 inter

change.

tached to the ANSI X12 message.

cific ANSI X12 message types.

ment.

Releases compatibility with previous ANSI X12
releases.
Set Define the ANSI X12 message type.
Version Define the ANSI X12 message version.

All Versions Allows you to include all version of

ANSI X12 standards to the XSD file.
Procedure
selected rows from the table of an ANSI X12 message type, choose ANSI X12 Tables .
2. Select the appropriate table to be edited. For more information on ANSI X12 tables, refer the ANSI X12
ANSI X12 Tables
The ANSI X12 module uses two different types of tables:
of the messages.
○ B2B_X12_CTRL_IF: This control table manages single interfaces, with which the key (X12_CTRL_KEY)
(XSD).
○ B2B_X12_DEF_MSG : This table is used to define the message structure on the highest level. It is
determined depending on the message type and directory version, the number of segments and their
order according to the index.
Field Description
VERSION Directory version
SET_NAME Name of the message
SEGMENT Segment name

PARENT Hierarchically superordinate segment
PARENT_INDEX Index of the sub-segments within the superordinate

segment
MANDATORY Mandatory field indicator
OCCURRENCES Occurrences
DESCRIPTION Description
○ B2B_X12_DEF_SEG: This table provides the description texts of a segment.
Field Description
DESCRIPTION Description of the segment
○ B2B_X12_DEF_SEG_CM: This table provides the composites within a segment.
Field Description
SEGMENT_NAME Name of the segment
SEGMENT_INDEX Index in the segment
COMPOSITE_NAME Name of the composite
REPETITION Repetition of the composite
DATA_REQUIREMENT Requirement of the composite
SYNTAX_NOTES Additional syntactic information
SEMANTIC_NOTES Additional semantic information
COMMENTS Comments
○ B2B_X12_DEF_SEG_FL: This table provides the data fields within a segment.
Field Description

FIELD_NAME Name of the field
DATA_REQUIREMENT Requirement of the field
COMMENTS Comments
○ B2B_X12_DEF_FIELD: This table contains the description of the data fields.
Field Description
MINLENGTH Minimum length of the field
MAXLENGTH Maximum length of the field
DESCRIPTION Description text of the field
○ B2B_X12_DEF_COMP: This table contains the description of the composites.
Field Description
NAME Name of the composite
DATATYPE Data type
DESCRIPTION Description of the composite
○ B2B_X12_DEF_COM_FL: This table provides the data fields within a composite.
Field Description
COMPOSITE_INDEX Index of the field within the composite

DATA_REQUIREMENT Requirement of the field
COMMENTS Comments
1.4.3.4 Configuring the Odette Message Format
Procedure
Editing Tables
selected rows from the table of an Odette message type, choose Odette Tables .
2. To browse and import contents in Odette message, choose Odette Import/Export Content Import .
3. To export selected Odette message types, choose Odette Import/Export Content Export .
Odette Tables
The Odette module uses two different types of tables:
● The control tables ("B2B_ODE_CTRL_*") contain rules for creating the nesting structure for the conversion
of the messages.
○ B2B_ODE_CTRL_IF : The control table manages single interfaces, with which the key
(ODE_CTRL_KEY) to be used can be determined.
○ B2B_ODE_CTRL_MSG: This control table contains corresponding instructions for every message type
and every version for the interpretation and for the construction of the structural description of an
ODETTE message. The single states and state transitions of the "Mealy machine" have to be specified
here.
Field Description

"B2B_ODE_CTRL_IF"
MESSAGETYPE Message type

ture.
○ B2B_ODE_CTRL_SEG: This table contains the structural description for the segments. As these
Field Description

"B2B_ODE_CTRL_IF"
MESSAGEVERSION Value for this field is directory version for Ctrl_key 1, and
* for Ctrl_Key 2, because segments have segment ver
sion and not message version any more
SEGMENTVERSION Value for this field is segment version for Ctrl key2, and
value is * for Ctrl key1
SEGMENT Segment, to which the entry refers

○ B2B_ODE_CTRL_CMP :This table is used to manage the data objects of the composites. This and the
Field Description

"B2B_ODE_CTRL_IF"
MESSAGETYPE Value for this field is message type to which the CMP
belongs, in case of Ctrl_key 2 . Value for this field is * in
case of Ctrl_Key 1, because Composites are common
for all message types
MESSAGEVERSION Value for this field is directory version for Ctrl_key 1, and
* for Ctrl_Key 2, because segments have segment ver
sion and not message version any more
SEGMENTVERSION Value for this field is segment version for Ctrl key2, and
value is * for Ctrl key1
COMP Composite, to which the entry refers

● The definition tables ("B2B_ODE_DEF_*") manage information for generating the XML Definition Schemes
(XSD).
○ B2B_ODE_DEF_MSG: This table is used to define the message structure on the highest level. It
Field Description

"B2B_ODE_CTRL_IF"
○ B2B_ODE_DEF_MSG_SG: This table is used for a more precise definition of the arrangement of the
segments and segment groups in terms of message type, directory version and segment.
Field Description

"B2B_ODE_CTRL_IF"
SEGMENTVERSION Value is segment version of the segment. In case of

Ctrl_Key 1, the value is ‘*’ as segments for ctrl_key car
ries message version only and no segment version


SEGTYPE Segment type
○ S: Segment

○ B2B_ODE_DEF_SEG : This table provides names and arrangement of the composites in a segment.
Field Description

"B2B_ODE_CTRL_IF"
MESSAGEVERSION Directory Version for Ctrl_key 1. The value for this in

Ctrl_Key 2 is ‘*’, as segments have segment version but
not message version
SEGMENTVERSION Segment Version for Ctrl_key 2. Value for this in

Ctrl_Key 1 is ‘*’, as segments for ctrl_key carries mes
sage version only but not segment version

OCCURENCES Possible occurrence of the composite
SEG_FUNCTION Description about the function the segment has to per

form
SEG_NOTE Notes
○ B2B_ODE_DEF_CMP : This table contains the description on the arrangement of the single fields
within the composites.
Field Description

CRTL_KEY "Control Key" for predefined interface from
"B2B_ODE_CTRL_IF"
MESSAGETYPE Value for Ctrl_key 2 is Message Type to which the CMP

belongs, and value for Ctrl_Key 1 is ‘*’, as composites
are common for all message types
MESSAGEVERSION Value for Ctrl_key 1 is Directory Version, and value for

not message version
SEGMENTVERSION Value for Ctrl_key 2 is Segment Version of the segment,

and value for Ctrl_Key 1 is ‘*’, as segments for ctrl_key
carries message version only but not segment version

NOTE Notes
○ B2B_ODE_DEF_ELE : Analogous to the previous tables this table contains a more precise description
Field Description

"B2B_ODE_CTRL_IF"
MESSAGEVERSION Value. for Ctrl_key 1 is Directory Version, and value for

not message version
SEGMENTVERSION Value for Ctrl_key 2 is Segment Version of the segment,

and value for Ctrl_Key 1 is ‘*’, as segments for ctrl_key
carries message version only but not segment version

REPR Value formats
○ a: alphabetical
○ n: numerical
NOTE Notes
Importing or Exporting Message Content
 Note
If you want to enable the system to use the message types of control key SAPExt for conversion
(processing), you must configure the control key scenario association.
● To browse and import contents of Odette message, choose Odette Import/Export Content Import .
● To export selected Odette message types, choose Odette Import/Export Content Export .
Converting Odette Message
1. To convert a Odette message to XML message format, choose Odette Odette - XML - Converter
Odette to XML .
2. To convert an XML message to Odette message format, choose Odette Odette - XML - Converter
XML to Odette .
Generating XSD Files
1. To generate an XSD file, choose Odette XSD Generator .

2. On the XSD Generator screen page, enter the mandatory parameters.
1.4.3.5 Configuring the Tradacoms Message Format
Procedure
Editing Tables
selected rows from the table of a Tradacoms message type, choose Tradacoms Tables .
2. To browse and import contents in Tradacoms message, choose Tradacoms Import/Export Content
Import .
3. To export selected Tradacoms message types, choose Tradacoms Import/Export Content Export .
Tradacoms Tables

The Tradacoms module uses two different types of tables:
● B2B_TRA_CTRL_IF : The control table manages single interfaces with which the key (TRA_CTRL_KEY) to
be used can be determined.
● B2B_TRA_DEF_MSG : Table used to define the message structure on the highest level. It determines,
depending on the message type and directory version, the number of segments and their order according
to an index.
Field Description
SET_NAME Name of the message
SEGMENT Segment name
PARENT Hierarchically superordinate segment
PARENT_INDEX Index of the sub-segments within the superordinate seg

ment
MANDATORY Mandatory field indicator
OCCURRENCES Occurrences
DESCRIPTION Description
● B2B_TRA_DEF_SEG: This table provides the description texts of a segment.
Field Description
DESCRIPTION Description of the segment
● B2B_TRA_DEF_SEG_CM : This table provides the composites within a segment.
Field Description
● B2B_TRA_DEF_SEG_FL: This table provides the data fields within a segment.

Field Description
● B2B_TRA_DEF_FIELD: This table contains the description of the data fields.
Field Description
MANDATORY Mandatory field flag
MINLENGTH Minimum length of the field
MAXLENGTH Maximum length of the field
● B2B_TRA_DEF_COMP : This table contains the description of the composites.
Field Description
NAME Name of the composite
DATATYPE Data type
● B2B_TRA_DEF_COM_FL : This table provides the data fields within a composite.
Field Description
COMPOSITE_INDEX Index of the field within the composite

● To browse and import contents of Tradacoms message, choose Tradacoms Import/Export Content
Import .
● To export selected Tradacoms message types, choose Tradacoms Import/Export Content Export .
Converting Tradacoms Message
1. To convert a Tradacoms message to XML message format, choose Tradacoms Tradacoms - XML -
Converter Tradacoms to XML .
2. To convert an XML message to Tradacoms message format, choose Tradacoms Tradacoms - XML -
Converter XML to Tradacoms .
Generating XSD Files
1. To generate an XSD file, choose Tradacoms XSD Generator .
1.4.3.6 Configuring the VDA Message Format
Procedure
CDO:/content/authoring/thp1510043165171.xml
Editing Tables
selected rows from the table of a VDA message type, choose VDA Tables .
2. To browse and import contents in VDA message, choose VDA Import/Export Content Import .
3. To export selected VDA message types, choose VDA Import/Export Content Export .
VDA Tables
● B2B_VDA_CTRL_IF : The control table manages the single interfaces with which the key (VDA_CTRL_KEY)
● B2B_VDA_CTRL_FIELD: This table contains the structural description for the segments. As these
message type is no longer required.
Field Description
CTRL_KEY Control Key for predefined interface from

"B2B_VDA_CTRL_IF"
SET_NAME Record type
FIELD_NAME Name of the field in the record type
FIELD_INDEX Index of the field in the record type

FIELD_LENGTH Field length in native format
DATATYPE Data type (numeric or alphanumeric)
● B2B_VDA_CTRL_MSG : For the construction of the structural description of a VDA message, this control
table contains corresponding instructions for every message type and every version for the interpretation.
The single states and state transitions of the "Mealy machine" have to be specified here.
Field Description

"B2B_VDA_CTRL_IF"
STATUS_CURRENT Current status - context the table entry refers to
SET_NAME Name of the record type
SET_ACTION Action to be performed for building the segment struc

ture.
● To browse and import contents of VDA message, choose VDA Import/Export Content Import .
● To export selected VDA message types, choose VDA Import/Export Content Export .
Converting VDA Message
1. To convert a VDA message to XML message format, choose VDA VDA - XML - Converter VDA to
XML .
2. To convert an XML message to VDA message format, choose VDA VDA - XML - Converter XML to
VDA .
1.4.3.7 Configuring the Plain Message Format
Procedure
Editing Tables
selected rows from the table of a Plain message type, choose Plain Tables .
2. To browse and import contents in Plain message, choose Plain Import/Export Content Import .
3. To export selected Plain message types, choose Plain Import/Export Content Export .

Plain Tables
Plain Java accesses tables with different functions.
● The control table (B2B_PLA_CTRL_MSG) contains rules for creating the nesting structure for the
conversion of the messages.
○ B2B_PLA_CTRL_IF : This table manages single interfaces via which the key to be used
(PLA_CTRL_KEY) is determined. This key can also be used to develop, in addition to cross-interface
standard conversion rules, interface-specific versions of conversion rules.
Field Description
IF_INDEX Index of a line
S_PARTY Sender partner, can also be filled with wildcard charac

ter (.*)
S_SERVICE Sender service can also be filled with wildcard character

(.*)
R_PARTY Receiver partner, can also be filled with wildcard charac

ter (.*)
R_SERVICE Receiver service can also be filled with wildcard charac

ter (.*)
ACTION_NAMESPACE Namespace of the adapter
ACTION_NAME Name of the converter
DIRECTION Direction of the channel
PATTERN Beginning of the message structure (can be filled with a

regular expression)
MESSAGE_TYPE Message type
NEWLINE Line separator of the record types
STRICT_LENGTH Fixed field length, "Y" or "N"
CHARSET Character set
PLA_CTRL_KEY Table key for the dependent Plain conversion tables and
the default is "1"
DOCUMENTSTART Starting line of the converted document (inserted dur

ing conversion)
DOCUMENTEND End line of the converted document (inserted during

conversion)

○ B2B_PLA_CTRL_SETID: This table is required for identifying the message record type through use of
the pattern. The content of the tables will only be accessed when converting Plain-Text to XML.
Field Description
INDEX Sequence of the occurring record types in the message
PATTERN Starting character of the record type, which can be used

to clearly determine the record type
SET_TYPE Type of the record type "CS" (character-separated re

cord type) "FF" (record type with fixed field length)
FIELDSEPERATOR Field separator for CS record types
○ B2B_PLA_CTRL_MSG: This table is used to control the message conversion.
Field Description
STATUS_CURRENT Current status - context the table entry refers to
SET_ACTION Action for forming the record structure. "C" stands for
the field structure.
○ B2B_PLA_CTRL_FIELD :This table describes the structure of the record types and the fields.
Field Description
SETTYPE Set type
FIELD_NAME Field name
FIELD_INDEX Sequence of the fields in the record type
FIELD_LENGTH Length of the field
FILL_CHAR Fill character for the field (#20 corresponds to a blank

character or #30 to a zero)

ORIENTATION Orientation of the field ("L" = left-aligned, "R" = right-
aligned)
● To browse and import contents of Plain message, choose Plain Import/Export Content Import .
● To export selected Plain message types, choose Plain Import/Export Content Export .
Converting Plain Message
1. To convert a Plain message to XML message format, choose Plain Plain - XML - Converter Plain to
XML .
2. To convert an XML message to Plain message format, choose Plain Plain - XML - Converter XML to
Plain .
For more information about plain messages, refer SAP Note 2010221
1.4.3.7.1 Editing Plain Message
You use this procedure to create, edit, or delete message components in a plain document.
Procedure
1. To create or edit a plain message, choose Plain Editor Message Editor .

2. To create a control key, proceed as follows:
a. Choose Create Control Key .

b. In the Create Control Key dialog, enter a name and description.
c. Choose Create.
3. To create message types under a control key, proceed as follows:
a. In the Control Key dropdown, select the required control key.
b. Choose Create Message .
c. Enter the details based the table below:
Name Name of the message type
Starts With Start string of the message type that will be appended
between ^ and .*
New Line Type of new line character
Enable Customized New Line Option to enable user-defined new line character
Customized New Line Hexadecimal character of user-defined new line

Strict Length Option to specify if the message follows strict length
Char Set Encoding of the message
Document Start XML tag for the document start. For example,
<ns:MT_FORTRAS_V100_BORD512>
Document End XML tag for the document end. For example, </
ns:MT_FORTRAS_V100_BORD512>
 Note
You can also create a message type by using an existing XSD file:
1. Choose Import.
2. In the Import XSD screen, provide the XSD file name and other necessary details.
3. Choose Import.
The property values that are not part of the XSD file have the best match values, by default. If
required, you can edit them. Also, the structure of the XSD file must match the file generated
using plain XSD generator.
d. Choose Create.
4. To update message types, proceed as follows:
a. Choose Update Edit Message .

b. In the Update Message dialog, update the required parameter values.
c. Choose Update.
5. To create a set under a message type, proceed as follows:
a. In the Message Type dropdown, select the required message type.
b. Choose Create .
c. Enter the details based the table below:
Name Name of the set
Starts With Start string of the set that will be appended between ^
and .*
Set Type Type of the set, fixed or CSV format
Field Separator Option to set the field separator character
Comment Set Option to specify a set without any fields inside
d. Choose Create.
e. To create a subset within a set, select the required set from the table tree.
f. Choose Update Inner Set .
g. Choose one of the following options:
○ New – if you want to create a new sub set under the selected set
○ Existing – if you want to use an existing set
h. Specify the required details.

i. Choose Create.
6. To update set, proceed as follows:

a. Select the required set from the table tree.
b. In the Details section, choose Edit.
c. Update the required parameter values.
d. Save the changes.
7. To create field, proceed as follows:
a. Select the required set other than comment set, from the table tree.
b. Choose Update Add Field .
c. In the Create Field dialog, enter the details based on the table below:
Name Name of the field
Length Length of the field
Orientation Reading orientation, whether from left or right
Fill Character Type of fill character
Enable Customized Fill Char Option to enable user-defined fill character
Customized Fill Character Hexadecimal fill character
d. Choose Create.
 Note
If you want to add a field above or below a selected field, use the Add Field Above and Add Field
Below options from Update.
8. To update field, proceed as follows:

a. Select the required field from the table tree.
b. In the Details section, choose Edit.
c. Update the required parameter values.
d. Save the changes.
1.4.3.7.2 Generating XSD Files for Plain Converter
You use this procedure to generate XSD files for plain message types.
Procedure
1. To generate an XSD file, choose Plain XSD Generator .

2. On the XSD Generator page, enter the parameters as described in the following table:

Control Key Name Define the specific control key attached to the plain
message.
Plain Message Types Define the plain message type.
Namespace Define the namespace of the adapter.
XSD root element name Provide a name for the root element to be defined in the
XSD schema.
3. 3. To generate an XSD file, choose Generate XSD.
 Note
You can verify the correctness of the XSD file by importing it into the ESR.
1.4.3.8 Comparing EDI Messages
Context
The message comparison feature allows you to analyze the contents of two similar EDI message formats. The
content of the message consist of segments, composites, and data elements. The following scenarios describe
the use case of message comparison tool:
● If you have copied a control key, and choose to compare its content with the original control key.
● If you have edited the message content, and choose to compare its content with the original message
content.
The message table displays the contents in the message and placing these tables adjacent to each other
makes the analysis easier. Specific colors highlight the rows to show the difference between the message
contents. The following table describes the colors used to highlight the rows:
Color Description
Green The values in the all columns are identical
Red The values in the all columns are different. However, if the
corresponding row contains no values, then Blue color high
lights the row.
Yellow The values in second, third or both the columns are different.
You can compare the content of the following EDI message formats:
● ANSI
● EDIFACT

● EANCOM
 Note
You can compare messages of same EDI formats.
You use this procedure to configure the parameters for comparing EDI messages.
Procedure
1. If you select EDIFACT as the message format, then select the parameter value as described in the following
table:
EDI Message Format Parameter Description
EDIFACT Control Key This parameter represents a version

of an EDIFACT message definition. You
can maintain different control keys for
a single EDIFACT message and cus
tomize it by defining new message
definitions.
Version This parameter defines the version of

the EDIFACT message.
Message This parameter defines the EDIFACT

message type.
2. If you select EANCOM as the message format, then select the parameter value as described in the
following table:
EANCOM Control Key This parameter represents a version

of an EANCOM message definition.
You can maintain different control
keys for a single EANCOM message
and customize it by defining new mes
sage definitions.

the EANCOM message.
Message This parameter defines the EANCOM

message type.

Subversion This parameter determines EANCON

subversion type.
3. If you select ANSI as the message format, then select the parameter value as described in the following
table:
ANSI Control Key This parameter represents a version

of an ANSI message definition. You
can maintain different control keys for
a single ANSI message and customize
it by defining new message defini-
tions.

the ANSI message.
Message This parameter defines the ANSI mes

sage type.
4. To displays all segments embedded in the message, select the Include Segment Details checkbox.
5. In the Show field, select one of the following options for displaying the message content:
○ Complete Message: Displays all the message contents.
○ Only Differences: Displays the content of messages that are not same.
6. To display the content of the compared messages, choose Compare.
1.4.4 Maintaining Number Range Objects
Context
The Number Range Objects (NRO) module provides options to automatically insert continuous counters into
the outgoing messages. These numbers are created using Number Range Objects and are assigned to the
defined intervals in the respective objects. You create new values and maintain them on the NRO maintenance
user interface.
You use this procedure to define the NRO values.

Procedure
1. To access NRO maintenance, enter the URL format as http:<localhost:port>b2bic in the Web browser.
2. On the B2B Integration Cockpit Web page, choose NRO Maintenance.
3. In the Number Range Objects screen area, choose Create new number range object to define new NRO
values. The following table describes the parameters for creating the NRO values:
Number Range Object Name This parameter defines the name of the NRO.
Description This parameter allows you to describe the NRO.
Minimum Value This parameter allows you to calculate the minimum value
for the NRO.
Maximum Value This parameter allows you to calculate the maximum

value for the NRO.
Formatted Value Length This parameter allows you to calculate the length of the
NRO value.
Warn Level (%) This parameter allows you to calculate and specify an inte
ger at which an warning is issued. The integer value must
lie between 0 and 100.
You can disable the Warn Level (%) field by selecting the
Rotate checkbox.
4. Choose Save and create to save the settings and to create the NRO values.
5. To generate the successive number for the given NRO value, select an NRO from the number range object
table and choose Get next number.
6. To edit values in an existing NRO, select an NRO from the number range object table and choose Edit
number range object.
1.4.5 Trading Partner Management
Use
SAP B2B Trading Partner Management (TPM) is a centralized application that meets the needs of B2B
commerce in EDI environment. B2B users have different levels of EDI requirements for data exchange over the
Internet. The TPM application helps you manage EDI business relationships with multiple trading partners. The
easy-to-use user interface solves the complexity of B2B communication between trading partners.
SAP B2B TPM application helps you to:

● Maintain centralized partner information
● Create agreements between partners
● Define certificate rollover
● Configure functional profiles for custom value maps
TPM is divided into the following functional areas:
● For more information about trading partner profiles, see Managing Trading Partner Profiles [page 210].
● For more information about the different types of TPM profiles, see Overview of TPM Profiles [page 226].
● For more information about trading partner agreements, see Managing Trading Partner Agreements [page
240].
● For more information about configuring TPM system settings, see Configuring TPM Settings [page 247].
● For more information about importing TPM files into a TPM database, see Importing TPM Data [page 249].
● For more information about exporting TPM data as a TPM file, see Exporting TPM Data [page 249].
1.4.5.1 Managing Trading Partner Profiles
Context
You use trading partner profiles to store business information about trading partners that helps you to enhance
EDI business communication with them. The TPM application centrally manages and maintains partner
specific profiles. You create profiles of trading partners to store information such as partner name, partner
type, industry, region, agreements, documents, and so on. This partner-specific information helps to identify
the binding definitions required to conduct the EDI business transaction.
You use the following procedure to perform actions such as adding, copying, editing, and finding trading
partner profiles.
Procedure
1. To access trading partner profiles, choose Trading Partner Management Partners .

2. For more information about creating new partner profiles, see Adding Trading Partner Profile [page 211].
3. For more information about copying data from an existing partner profile and creating a new partner
profile, see Copying Trading Partner Profile [page 215].
4. For more information about editing partner profiles, see Modifying Trading Partner Profile [page 220].
5. To search and view logs related to changes made to partner profiles by users, choose Change Log.
6. For more information about basic and advanced search options, see Finding Trading Partner Profiles [page
225].

1.4.5.1.1 Adding Trading Partner Profile
Context
You use this procedure to create and add a trading partner profile to the TPM database.
Procedure
1. To create a new trading partner profile, choose Add.

2. On the Partner Profile screen, enter the parameter values as described in the following table:
General Partner Name Define the name of the partner. This

field is mandatory.
Description Provide a short description about the

partner profile.
Partner Type Determine the type of the partner en

gaged in business. The following op
tions are available:
○ Customer
○ Supplier
○ Others
○ VAN Provider
○ Self
Classification Industry Determine the type of industry by se

lecting industry-specific codes.
Region Determine the country by selecting

country-specific codes.
Parent Group Company Determine the parent group company

by selecting the appropriate business
organization as defined in TPM.

Integration Directory Association Party Name Define the communication party de
ployed on the Integration Directory
that is configured to exchange EDI in
terchanges according to the required
business scenario. This field is man
datory.
Trading Partner Status Partner Status This parameter determines the cur
rent status of the trading partner.
3. To add partner contact details such as First Name, E-mail, Address, and so on, choose the Contacts tab
page and then choose Add.
4. To store document details and to specify its location, choose the Documents tab page and then choose
Add.
5. To add details such as partner ID, partner agency, and so on for identifying business partners, choose the
Identities tab page and then choose Add.
6. To store EDI message details such as message format, message type, control key, and so on, choose the
Messages tab page and then choose Add.
7. To enable the processing of EDI acknowledgements, such as EDIFACT, EANCOM and ANSI X12, for inbound
and outbound EDI communications, choose EDI Acknowledgements tab page and then select either
Required or Read from Envelop Segment.
 Note
During runtime EDI Separator adapter uses these parameters.
The following table describes inbound message parameters in EDIFACT and EANCOM tab pages:
Advance Properties Parameters for EDIFACT and EANCOM Description
EDIFACT CONTRL Message Version and Release This parameter determines the details of the CONTRL
message version and release.
Transaction Mode This parameter defines the mode of transaction that

allows the EDI separator to process incoming message as
All (all individual transactions as single entity) or
Individual (each individual transactions as independent
entity).
Negative Acknowledgment Not Required This parameter notifies the adapter not to transmit the
CONTRL message when a transaction set is Rejected (R).
Positive Acknowledgement Not Required This parameter notifies the adapter not to transmit a
CONTRL message when all transaction sets are Accepted
(A).
Execution Mode This parameter defines the mode of execution for the
adapter to validate, acknowledge or do both activities for

an incoming message.The modes of execution are as

follows:
○ Receipt Only
○ Receipt and Validation
UNA Segment Required This segment defines special characters, such as

separators and indicators used in the EDI interchange. If
UNA segments are not included, then default characters
are used.
Enable NRO for Interchange Number This parameter enables the NRO tool to generate
interchange number for functional acknowledgments. In
the NRO Name field select the NRO name.
The following table describes inbound message parameters in ANSI X12 tab page:
Advance Properties Parameters for ANSI X12 Description
Enable Group Based Splitting This parameter allows splitting of incoming batch X12 EDI
messages in different groups, which makes processing of
X12 messages easier.

entity).
997 FA message when a transaction set is Rejected (R).
Positive Acknowledgement Not Required This parameter notifies the adapter not to transmit a 997
FA message when all transaction sets are Accepted (A).
follows:
○ Receipt Only
Exclude AK3 and AK4 This parameter notifies the adapter to exclude the AK3
and AK4 segments from the 997 FA message. But it
retains the details of AK1, AK2, AK5, and AK9 segments
in the 997 FA message.

The following table describes message parameters in AUTACK tab page:
Use Certificate from NWA Key Storage Inbound This parameter indicates whether to
message payload.
Partner Certificate View Inbound This parameter is the partner's

storage.
Partner Certificate Alias Inbound This parameter is the partner's

storage.
Acknowledgment Required Inbound This parameter specifies whether to

generate an AUTACK message as
acknowledgment.
AUTACK Message Version and Inbound This parameter specifies the version
Release and release of the AUTACK message
1.
Own Certificate View Inbound / Outbound This parameter is the owner's

storage.
Own Certificate Alias Inbound / Outbound This parameter is the owner's

storage.
Own Private Key View Inbound / Outbound This parameter is the owner's private-
Own Private Key Alias Inbound / Outbound This parameter is the owner's private-
Signing Algorithm Inbound / Outbound This parameter specifies the signing

algorithm; currently RSA is
supported.
Hashing Algorithm Inbound / Outbound This parameter specifies the hashing

algorithm; currently SHA1 is
supported.
Filtering Algorithm Inbound / Outbound This parameter is the name of the

and BASE64.
Encoding Inbound / Outbound This parameter is used for encoding

are UTF-8 and ASCII.

Signature Scope Inbound / Outbound This parameter is used to indicate

Enable NRO for Interchange Number Inbound This parameter helps in assigning
NRO number in the place of the NRO
name, which is used for generating
interchange control number.
Sign EDI Message Outbound This parameter digitally signs the

outgoing EDI message.
Request AUTACK Outbound This parameter requests the partner

to send an AUTACK message as
acknowledgment.
8. To add functional profiles that are specific to a trading partner, choose the Functional Profiles tab page and
then choose Add.
9. To create partner-specific agreements, choose the Agreements tab page.
10. To view details of partner-specific certificates such as certificate profile, rollover time and so on, choose the
Certificates tab page.
11. To define SLAs as per the partner for inbound and outbound functional acknowledgments, choose the
SLAs tab page. You can notify SLA violations through alerts. For more information about configuring alerts,
see B2B Alerts [page 258]
1.4.5.1.2 Copying Trading Partner Profile
Context
You use this procedure to copy the data from an existing trading partner profile for creating a new trading
partner profile.
Procedure
1. To create a copy of an existing trading partner profile select the appropriate profile from the table, and
choose Copy.


field is mandatory.

partner profile.

○ Customer
○ Supplier
○ Others
○ VAN Provider
○ Self



datory.
3. To edit existing partner contact details such as First Name, E-mail, Address, and so on, choose the Contacts
tab page and then choose Add.
4. To edit existing document details and to specify its location, choose the Documents tab page and then
choose Add.
5. To edit existing details such as partner ID, partner agency, and so on for identifying business partners,
choose the Identities tab page and then choose Add.
6. To edit existing EDI message details such as message format, message type, control key, and so on, choose
the Messages tab page and then choose Add.

 Note

entity).
(A).
follows:
○ Receipt Only

are used.



entity).
follows:
○ Receipt Only
message payload.

storage.

storage.

acknowledgment.


1.

storage.

storage.

supported.

supported.

and BASE64.




acknowledgment.
8. To edit existing functional profiles that are specific to a trading partner, choose the Functional Profiles tab
9. To edit existing partner-specific agreements, choose the Agreements tab page.
10. To edit existing details of partner-specific certificates such as certificate profile, rollover time and so on,
choose the Certificates tab page.

1.4.5.1.3 Modifying Trading Partner Profile
Context
You use this procedure to edit trading partner profile to the TPM database.
Procedure
1. To create a new trading partner profile, choose Add.


field is mandatory.

partner profile.

○ Customer
○ Supplier
○ Others
○ VAN Provider
○ Self




datory.
3. To add partner contact details such as First Name, E-mail, Address, and so on, choose the Contacts tab
4. To store document details and to specify its location, choose the Documents tab page and then choose
Add.
5. To add details such as partner ID, partner agency, and so on for identifying business partners, choose the
Identities tab page and then choose Add.
6. To store EDI message details such as message format, message type, control key, and so on, choose the
Messages tab page and then choose Add.
 Note

entity).

(A).
follows:
○ Receipt Only

are used.

entity).
follows:
○ Receipt Only


message payload.

storage.

storage.

acknowledgment.
1.

storage.

storage.

supported.


supported.

and BASE64.




acknowledgment.
8. To add functional profiles that are specific to a trading partner, choose the Functional Profiles tab page and
then choose Add.
9. To create partner-specific agreements, choose the Agreements tab page.
10. To view details of partner-specific certificates such as certificate profile, rollover time and so on, choose the
Certificates tab page.
Related Information
Modifying Multiple Partner Properties [page 225]

1.4.5.1.4 Modifying Multiple Partner Properties
You can select multiple partners and update their properties.
Procedure
1. In the Partner Profile overview screen, select the required partners.

2. Choose Mass Update.
3. In the Mass Update screen, select the type of the mass update template.
4. Select the Enable for Mass Update checkbox next to the properties you want to update.
5. Specify the values for the properties.
6. Choose Apply.
1.4.5.1.5 Finding Trading Partner Profiles
Context
You use this procedure to find and display partner profiles by entering appropriate parameters.
Procedure
1. To find profiles in basic mode, enter the partner profile name in the Find field and choose Go.
2. To expand the search criteria, choose Advanced Search.
3. Enter the known parameters and choose Go.
The following table provides descriptions of the advanced search parameters:
Industry Define the type of industry that the profile belongs to.
Region Define a country.
Parent Group Company Determine the parent group company by selecting the
appropriate business organization as defined in TPM.
Partner Type Define the type of the business partner.

Party Name Define the communication party deployed on the

Integration Directory that is configured to exchange EDI
interchanges according to the required business
scenario.
1.4.5.2 Overview of TPM Profiles
Use
Trading Partner Management (TPM) profiles consist of a template containing runtime parameters (keys) that
are used to configure B2B adapters. The template stores SAP-defined and user-defined runtime parameters
that are specific to an adapter. TPM profiles are defined based on the EDI communication environment
established between the trading partners. You can create multiple profiles based on the trading partners'
business requirements. By defining and managing profiles, you improve the performance of information
exchange between trading partners.
The communication channels of an adapter provide an option to retrieve keys from the TPM profiles that are
defined for inbound or outbound scenarios. You can use this operation to automate the process for configuring
an adapter.
● For more information about functional profiles, see Managing Functional Profiles [page 226].
● For more information about TPM templates, see Managing TPM Templates [page 231].
● For more information about TPM code lists, see Managing TPM Code Lists [page 234].
● For more information about security certificates associated with trading partners, see Managing
Certificates [page 237].
1.4.5.2.1 Managing Functional Profiles
Context
Functional profile is a collection of TPM templates that store custom key values. It can be independent or can
be attached to a trading partner agreement. During runtime based on the conditions in an agreement, the
functional profiles values can be used for messages mapping.
You can access functional profile during runtime by calling an agreement or a functional profile name by using
predefined UDF’s. The Details view pane provides summary about the profile, and it displays the where-used
details and the number of templates added to the profile.
You use the following procedure to perform actions such as adding, copying, editing, and finding functional
profiles.

Procedure
1. To access functional profiles, choose Trading Partner Management Profiles Functional Profiles .
2. For more information about creating new functional profiles for EDI separator adapters, see Adding
Functional Profile [page 227].
3. For more information about copying data from existing functional profiles and creating a functional profile,
see Copying Functional Profile [page 228].
4. For more information about editing functional profiles, see Modifying Functional Profile [page 229].
5. To search and view logs related to changes made to profiles by users, choose Change Log.
6. For more information about basic and advanced search options, see Finding Functional Profiles [page 230].
1.4.5.2.1.1 Adding Functional Profile
Context
You use this procedure to create and add a functional profile to the TPM database.
Procedure
1. To create a new functional profile, choose Add.

2. On the Functional Profile screen, enter the parameter values as described in the following table:
Template Add Allows you to add multiple functional

templates.
Remove Deletes existing functional templates.
Apply Templates Apply template parameters to the

profile.
Header Name Define the name for a functional pro

file. This is a mandatory field.
Description Provide a short description of the

functional profile.

Properties Mass Update Property This parameter updates the common
keys associated with other functional
profiles. A Mass Update confirmation
dialog box appears, which allows you
to select the profiles and update them
collectively.
1.4.5.2.1.2 Copying Functional Profile
Context
You use this procedure to replicate the data from an existing functional profile to create a new functional
profile.
Procedure
1. To copy a functional profile, select a functional profile from the table and choose Copy.
2. On the Functional Profile screen, enter the parameter values as described in the following table:

templates.

profile.


functional profile.

collectively.
1.4.5.2.1.3 Modifying Functional Profile
Context
You use this procedure to edit a functional profile.
Procedure
1. To edit a functional profile, choose the appropriate profile link from the name column of the Functional
Profiles table.
2. On the Functional Profile screen, choose Edit and enter the parameter values as described in the following
table:

templates.

profile.


functional profile.

collectively.
1.4.5.2.1.4 Finding Functional Profiles
Context
You use this procedure to find and display profiles by entering appropriate parameters.
Procedure
1. To find profiles in basic mode, enter the functional profile name in the Find field and choose Go.
2. To expand the search criteria, choose Advanced.
The following table provides descriptions of the advanced search parameters.
Advanced Name Define the name of the functional pro

file.
Last Modified Date Define the last date of modification.

1.4.5.2.2 Managing TPM Templates
Context
TPM template is a form that consists of unique set of referential values that is defined as per the business
transaction. These custom build forms stores generic data which can be reusable with different profiles. Each
TPM template is made up of key-pair values.
You define the values for specific business requirements and must be noted that the custom values are case
sensitive. You can attach a template to multiple functional profiles and use them during message mapping
runtime. For example you can create templates for Material Code Mapping, status Indicator fields and so on.
You use the following procedure to perform actions such as adding, copying, editing, and finding TPM
templates.
Procedure
1. To access TPM templates, choose Trading Partner Management Profiles Templates .

2. For more information about creating new TPM templates, see Adding TPM Template [page 231].
3. For more information about copying data from existing TPM templates and creating a template, see
Copying TPM Template [page 232].
4. For more information about editing TPM templates, see Modifying TPM Template [page 233].
5. To search and view logs related to changes made to templates by users, choose Change Log.
6. For more information about basic and advanced search options, see Finding TPM Templates [page 233].
1.4.5.2.2.1 Adding TPM Template
Context
You use this procedure to create and add a TPM template to the TPM database.
Procedure
1. To create a new TPM template, choose Add.

2. On the Template screen, enter the parameter values as described in the following table:
General Name Define the name for a TPM template.

This is a mandatory field.
Description Provide a short description of the TPM

template.
3. To enter custom values, choose Add and then define the appropriate values.
 Note
You can define custom values in the following formats:

○ TEXT
○ BOOLEAN
○ CODE LIST
○ CERTIFICATE VIEW
○ CERTIFICATE ALIAS
1.4.5.2.2.2 Copying TPM Template
Context
You use this procedure to replicate the adapter-specific parameters from an existing TPM template to create a
new TPM template.
Procedure
1. To create a new TPM template, choose Copy.

2. On the Template screen, enter the parameter values as described in the following table:


template.
3. To edit custom values, choose Add and then define the appropriate values.
1.4.5.2.2.3 Modifying TPM Template
Context
You use this procedure to edit a template.
Procedure
1. To edit a TPM template, choose the appropriate link from the name column in the Template table.
2. On the Template screen, choose Edit and enter the parameter values as described in the following table:


template.
1.4.5.2.2.4 Finding TPM Templates
Context
You use this procedure to find and display TPM templates by entering appropriate parameters.

Procedure
1. To find templates in basic mode, enter the template name in the Find field and choose Go.
Advanced Name Define the name of the template.
1.4.5.2.3 Managing TPM Code Lists
Context
You use code lists to define runtime parameters with specific values. You use the following procedure to
perform actions such as adding, copying, editing, and finding TPM code lists.
Procedure
1. To access functional profiles, choose Trading Partner Management Profiles Code Lists .
2. For more information about creating new code lists, see Adding TPM Code List [page 235].
3. For more information about copying data from an existing code list and creating a new code list, see
Copying TPM Code List [page 235].
4. For more information about editing code lists, see Modifying TPM Code List [page 236].
5. To search and view logs related to changes made to profiles by users, choose Change Log.
6. For more information about basic and advanced search options, see Finding TPM Code Lists [page 237].

1.4.5.2.3.1 Adding TPM Code List
Context
You use this procedure to create and add a new TPM code list to the TPM database.
Procedure
1. To create a new code list, choose Add.

2. On the Code List screen, enter the parameter values as described in the following table:
Header Name Define the name for a code list. This is

a mandatory field.

code list.
3. To enter parameters, choose Add and then define the appropriate values.
1.4.5.2.3.2 Copying TPM Code List
Context
You use this procedure to replicate the parameters from an existing code list to create a new code list.
Procedure
1. To create a new code list, choose Copy.

2. On the Code List screen, enter the parameter values as described in the following table:


a mandatory field.

code list.
3. To enter parameters, choose Add and then define the appropriate values.
1.4.5.2.3.3 Modifying TPM Code List
Context
You use this procedure to edit the properties of a code list.
Procedure
1. To edit a code list, choose the appropriate link from the name column in the Code Lists table.
2. On the Code List screen, choose Edit and enter the parameter values as described in the following table:

a mandatory field.

code list.

1.4.5.2.3.4 Finding TPM Code Lists
Context
You use this procedure to find and display TPM code lists by entering appropriate parameters.
Procedure
1. To find a code list in basic mode, enter the code list name in the Find field and choose Go.
Advanced Name Define the name of the code list.
1.4.5.2.4 Managing Certificates
Context
You use this feature in TPM to store security certificates associated with the trading partner. Use the following
procedure to perform actions such as adding and editing certificates.
Procedure
1. To access partner-specific security certificates, choose Trading Partner Management Profiles

Certificate Rollover Profiles .
2. For more information about creating new certificates, see Adding Certificate [page 238].
3. For more information about editing certificates, see Editing Certificate [page 239].

1.4.5.2.4.1 Adding Certificate
Context
You use this procedure to create a new certificate profile for a selected trading partner.
Procedure
1. To create a new certificate, choose Add.

2. On the Certificate Profile screen, enter the parameter values as described in the following table:
Header Name Define the name of the certificate.

Description Provide a short description of the cer

tificate.
Partner Name Define the partner using the certifi-

cate. This is a mandatory field.
Adapter Engine Select the adapter engine for certifi-

cate rollover.
Certificate Rollover Settings Activate Certificate View Displays name of the certificate.
Activate Certificate Name Define the certificate to be activated

from the certificate store. This is a
mandatory field.
Activate Certificate Expiry Time Displays the expiry details of the acti
vated certificate, for example,
17/07/2036 01:59:59 GMT + 01:00.
Rollover Certificate Rollover Certificate View Displays information about the view of
the certificate store.

Rollover Certificate Name Define automatic certificate rollovers
for NWA certificates. After rollover,
new certificate replaces the old active
certificate. You can also define the
backup view to archive the replaced
certificate.
Rollover Rollover Date Define a date to perform replacement

of the certificate after the expiration
date.
Rollover Time Define a time to perform certificate

rollover.
 Note
Please, note that if the specified
Rollover Time is in the next 24
hours, the Certificate Rollover
may not be executed.
Backup View Define a view to store expired certifi-

cates.
1.4.5.2.4.2 Editing Certificate
Context
You use this procedure to edit a certificate.
Procedure
1. To edit a certificate, choose the appropriate link from the name column in the Certificate Profiles table.
2. On the Certificate Profile screen, choose Edit enter the parameter values as described in the following table:

Header Description Provide a short description of the cer
tificate.
Certificate Rollover Settings Activate Certificate Name Define the certificate to be activated
from the certificate store. This is a
mandatory field.
Rollover Certificate Rollover Certificate Name Define automatic certificate rollovers

for NWA certificates. After rollover,
new certificate replaces the old active
certificate. You can also define the
backup view to archive the replaced
certificate.
Rollover Rollover Date Define a date to perform replacement

of the certificate after the expiration
date.
Rollover Time Define a time to perform certificate

rollover.
 Note
Please, note that if the specified
Rollover Time is in the next 24
hours, the Certificate Rollover
may not be executed.
Backup View Define a view to store expired certifi-

cates.
1.4.5.3 Managing Trading Partner Agreements
Context
You use a trading partner agreement between two trading partners to regulate the exchange of EDI documents
and to define the communication scenario for participating in a specific business transaction.
You use the following procedure to perform actions such as adding, copying, and editing of trading partner
agreements.

Procedure
1. To access trading partner agreements, choose Trading Partner Management Agreements .

2. For more information about adding agreements, see Adding Trading Partner Agreement [page 241].
3. For more information about copying agreements, see Copying Trading Partner Agreement [page 243].
4. For more information about editing agreements, see Editing Trading Partner Agreement [page 245].
5. To search and view logs related to changes made to agreements by users, choose Change Log.
1.4.5.3.1 Adding Trading Partner Agreement
Context
You use this procedure to create and add a trading partner agreement to the TPM database.
Procedure
1. To create a new trading partner agreement, choose Add.

2. On the Trading Partner Agreement screen, enter the parameter values as described in the following table:
Header Message Direction Determine the direction of the mes

sage flow. This is a mandatory field.

agreement. This is a mandatory field.
Partners Partner Name (Sender Partner) Define the sender partner profile.
Identifier Define a unique ID assigned to the

sender party.
Agency Code Define the appropriate standard code

qualifier of the sender party agency.
Partners Partner Name (Receiver Partner) Define the receiver partner profile.
Identifier Define a unique ID assigned to the re

ceiver party.

qualifier of the receiver party agency.
Messages Message Format Determine the format of the EDI mes

sage.
Message Type Determine the type of the EDI mes

sage format.
Message Release Provide the release details of the EDI

message.
Message Version Provide the version of the EDI mes

sage.
Message Agency Provide the details of the message

agency that develops and maintains
the message types.
Message Sub-version Provide the subversion of the EDI

message.
Control Key Name Determine the control key assigned to

the EDI transaction.
Directory Parameters (Optional) Interface This parameter defines the interface

for communication between sender
and receiver systems.
Namespace Define the service interface of the EDI

message.
For example, http://xxx.com/xxx/1234
Sender Business Component Define the sender party’s communica

tion component.
Receiver Business Component Define the receiver party’s communi

cation component.

1.4.5.3.2 Copying Trading Partner Agreement
Context
You use this procedure to replicate the parameters from an existing trading partner agreement to create a new
trading partner agreement.
Procedure
1. To copy and create a new trading partner agreement, choose Copy.

2. On the Trading Partner Agreement screen, enter the parameter values as described in the following table:



sender party.


ceiver party.


sage.

sage format.

message.

sage.

the message types.

message.



message.

tion component.

cation component.
Parameters Functional Profiles Allows to change the functional profile

assigned to the partner.
EDI Parameters Displays converter module based on

EDI message type. If the values are
blank, then the converter module re
places the value as defined by the
module in the integration directory or
default values are assigned during
runtime.
Generate Autack For inbound direction, a checkbox ap

pears if the message type is selected
as EDIFACT or EANCOM. Enable this
checkbox if you need AUTACK for EDI
messages mentioned in above sec
tion.

Sign EDI Message For outbound direction, a checkbox
appears if the message type is se
lected as EDIFACT or EANCOM. Ena
ble this checkbox if you need to digi
tally sign the EDI message mentioned
in above section.
1.4.5.3.3 Editing Trading Partner Agreement
Procedure
1. To edit a trading partner agreement, choose the appropriate link from the agreement column in the Partner
Agreements table.
2. On the Trading Partner Agreement screen, choose Edit and enter the parameter values as described in the
following table:



sender party.


ceiver party.


sage.

sage format.

message.

sage.

the message types.

message.



message.

tion component.

cation component.
Parameters Functional Profiles Allows to change the functional profile

assigned to the partner.
EDI Parameters Displays converter module based on

EDI message type. If the values are
blank, then the converter module re
places the value as defined by the
module in the integration directory or
default values are assigned during
runtime.

Generate Autack For inbound direction, a checkbox ap
pears if the message type is selected
as EDIFACT or EANCOM. Enable this
checkbox if you need AUTACK for EDI
messages mentioned in above sec
tion.
Sign EDI Message For outbound direction, a checkbox

appears if the message type is se
lected as EDIFACT or EANCOM. Ena
ble this checkbox if you need to digi
tally sign the EDI message mentioned
in above section.
1.4.5.4 Configuring TPM Settings
Context
You use this procedure to configure the change log settings for the TPM execution system.
Procedure
1. To configure the change log settings, choose Trading Partner Management Administration .
2. To enable the change log settings for a specific execution system, select the Enable Change Log checkbox.
3. To specify the execution environment of the TPM system, enter Test or Production.

1.4.5.5 Configuring Alerts for Certificates
You use the alerting feature in Trading Partner Management (TPM) to create alerts for certificates stored in the
PI system.
Context
You use the alerting feature in Trading Partner Management (TPM) to create alerts for certificates stored in the
PI system. The user receives alerts as an e-mail containing the following details:
● Certificate rollover
● Certificate expiration
You use this procedure to configure alerts for certificates in TPM.
Procedure
1. Choose Trading Partner Management Administration .

2. To enable the alerts for certificate rollover and certificate expiration, select the Enable Alert checkbox.
 Note
The system generates alerts for either TPM Certificate Profiles or NWA KeyStore.
3. To receive alerts upon certificate rollover, select the Enable Rollover Alerts checkbox and use the
appropriate parameters, as described below:
Generate Alerts for Certificate Rollover This parameter allows the system to generate alerts
based on the certificate rollover statuses. You can receive
alerts on the following statuses:
○ Success
○ Error
○ Both
For example, if you select the Success option, the system
generates alerts only for successful rollovers.
Enable Reminder Alerts This parameter generates and dispatches alerts to

remind the user about the scheduled rollover.
Generate Reminder Alert for Rollover (Days Before) This parameter allows the user to enter a specific period
(in days), which enables the system to dispatch alerts
until the scheduled rollover day.

 Note
You must enter a day that is before the planned
rollover day.
4. To receive alerts before the certificate expiration, select the Enable Expiry Alert checkbox and use the
appropriate parameters, as described below:
Generate Alerts for Certificates Expiring In This parameter generates alerts upon certificate
expiration in TPM Certificate Profiles or NWA KeyStore.
Generate Alert for Expiry (Days Before) This parameter allows the user to enter a specific period
(in days), which enables the system to dispatch alerts
until the expiration day.
 Note
You must enter a day that is before the certificate
expiration day.
1.4.5.6 Importing TPM Data
Procedure
1. Choose Trading Partner Management Administration Mass Import .

2. Choose Browse and select the appropriate .ZIP file that contains the .TPM and .TPZ files.
3. Choose Import.
1.4.5.7 Exporting TPM Data
Procedure
1. Choose Trading Partner Management Administration Mass Export .

2. Choose Create Export File.

3. To download the TPM data to the local system, choose Download Exported File.
1.4.5.8 Importing Specific TPM Data
You can import partner profiles, functional profiles, templates, or codelists to TPM.
Prerequisites
In case of CSV file import, you have created the required files on the server system. For more information about
the files, naming convention, and structure, refer to the SAP Note 2072376 .
Context
 Note
Import of templates and codelists is supported for CSV formats only.
Procedure
1. To import the partner data to the TPM database, choose Import.

2. On the dialog that appears, perform the following substeps:
a. From the table, select the required type.
b. Provide the file name (in case of TPM content type) or directory path (in case of CSV file).
 Note
The directory path you provide in this step must be existing on the server system.
c. In case of CSV format, if the file contains the header row, select the Consider Header Information
checkbox.
3. To overwrite the selected file in an existing partner data, select Overwrite.
4. Choose Import.

1.4.5.9 Exporting Specific TPM Data
You can export partner profiles, functional profiles, templates, or codelists from TPM.
Context
 Note
Export of templates and codelists is supported for CSV formats only.
Procedure
1. From the table, select the required partner data and then choose Export.
2. On the dialog that appears, perform the following substeps:
a. In the Select Type field, select the required file type.
b. Provide the directory path (in case of CSV file), and if you want to export the header information, select
the Add Header Information checkbox.
 Note
The directory path you provide in this step must be existing on the server system.
a. In case of TPM content, specify the required partner data you want to export, by selecting the relevant
checkboxes.
3. Choose Export.
System exports the relevant data to the server system.

4. To download the data onto your local machine, choose Download.
1.4.5.10 TPM Web Service APIs
TPM Web service APIs enable you to manage TPM objects programatically.
The following are the TPM Web services:
Web Service Name WSDL URL Description
TPMPartnerService http://<host>:<port>/ Used to create, update, delete, and get

TPMPartnerService/ partner profiles.
TPMPartnerBean?wsdl

Web Service Name WSDL URL Description
TPMAgreementService http://<host>:<port>/ Used to create, update, delete, and get

TPMAgreementService/ partner agreements.
TPMAgreementBean?wsdl
TPMFunctionalProfileService http://<host>:<port>/ Used to create, update, delete, and get

TPMFunctionalProfileService/ functional profiles.
TPMFunctionalProfileBean?wsdl
TPMTemplate2Service http://<host>:<port>/ Used to create, update, delete, and get

TPMTemplate2Service/ templates.
TPMTemplate2Bean?wsdl
TPMCodelistService http://<host>:<port>/ Used to create, update, delete, and get

TPMCodelistService/ codelists.
TPMCodelistBean?wsdl
TPMCertificateProfileService http://<host>:<port>/ Used to create, update, delete, and get

TPMCertificateProfileService/ certificate rollover profiles.
TPMCertificateProfileBean?wsdl
For more information, refer to the SAP Note 2072577 .
1.5 Monitoring B2B Messages
Use
The message monitoring in SAP Process Integration, helps to monitor the processing of EDI messages that are
exchanged to different trading partners using B2B adapters in your system landscape.
You can obtain an overview of the message processing based on the different intervals. You can search for
messages that were sent or received by the trading partners based on the message correlation ID. For more
information about correlation ID, see Searching EDI Messages Using Correlation ID [page 253]
This monitoring application provides information about B2B acknowledgments that are transmitted by the
trading partner. It contains different columns such as type of functional or technical acknowledgments, status
indicator, status code, correlation ID, and etc. For more information about status codes related to functional
and technical acknowledgments, see Status Codes [page 253].
 Note
The local message monitor has been enhanced in specific SAP Process Integration releases. For more

1.5.1 Searching EDI Messages Using Correlation ID
Use
The correlation ID also referred to as a conversation ID, included in the header segment of an XI message
consists of interchange control number, sender and receiver identifiers.
In the message monitoring application, you can use the correlation ID as a search criterion to identify and track
the outgoing and incoming EDI transactions. It also helps you to understand the correlation between the EDI
message and the corresponding EDI payload.
The table below defines the formats of correlation ID:
Message Flow Correlation ID format
Outbound message flow interchangeid_senderidentifier_receiveridentifier
Inbound message flow
 Note
The local message monitor has been enhanced to include B2B usecases in SAP NW PI releases. For more
B2B Acknowledgements
This tab page provides information about acknowledgements that are exchanged between the trading
partners. Two new columns have been introduced for viewing technical and functional acknowledgment status.
It also contains different columns such as status indicator, status code, correlation ID and so on.
1.5.2 Status Codes
Use
The following tables describe the different status codes of functional and technical acknowledgements that are
generated during an EDI message flow.
Status Codes of Functional Acknowledgement
Status Codes Description
PARTIALLY_ACCEPTED_RECV Outgoing EDI message was partially accepted by the partner.
PARTIALLY_ACCEPTED_SENT Incoming EDI message is partially accepted and an acknowl

edgement is sent to the partner.

PARTIALLY_ACCEPTED_NOT_SENT Incoming EDI message is partially accepted and an acknowl

edgement is not sent to the partner.
PARTIALLY_ACCEPTED_GENERATED Incoming EDI message is partially accepted and an acknowl

edgement is generated.
REJECTED_RECV Outgoing EDI message was rejected by the partner.
REJECTED_SENT Outgoing EDI message is rejected and an acknowledgement

sent to the partner.
REJECTED_NOT_SENT Outgoing EDI message is rejected and an acknowledgement

not sent to the partner.
REJECTED_GENERATED Outgoing EDI message is rejected and an acknowledgement

is generated.
ACCEPTED_RECV Outgoing EDI message was accepted by the partner.
ACCEPTED_SENT Incoming EDI message is accepted and an acknowledge

ment sent to the partner.
ACCEPTED_NOT_SENT Incoming EDI message is accepted and an acknowledge

ment not sent to the partner.
ACCEPTED_GENERATED Incoming EDI message is accepted and an acknowledge

ment is generated.
RECEIPT_PEINDING EDI message was sent to the partner and an acknowledge

ment was solicited from the partner.
ACK_NOT_REQUESTED EDI message was sent by the partner and an acknowledge

ment was not requested by the partner.
ACK_NOT_SOLICITED EDI message was sent to the partner and an acknowledge

ment was not solicited from the partner.
ACK_SOLICITED EDI message was sent to the partner and an acknowledge

ACK_RECEIVED EDI message was sent to the partner and an acknowledge

ment was received from the partner.
ACK_REQUESTED EDI message was sent to the partner and an acknowledge

ment is requested from the partner.
Status Codes Technical Acknowledgement (MDN)

POSITIVE_MDN_GENERATED Incoming AS2 message is accepted and a positive MDN is

generated.
NEGATIVE_MDN_GENERATED Incoming AS2 message is rejected and a negative MDN is

generated.
SUCCESSFULLY_SENT Incoming AS2 message accepted and MDN successfully

SUCCESSFULLY_RECEIVED Incoming AS2 message accepted and acknowledgement

successfully received from the partner.
SUCCESSFULLY_PROCESSED Incoming AS2 message accepted and processed success

fully.
GEN_ASYNC_POS Incoming AS2 message accepted and a positive asynchro

nous MDN is generated as requested by the partner.
GEN_ASYNC_NEG Incoming AS2 message rejected and a negative asynchro

GEN_SYNC_POS Incoming AS2 message accepted and a positive synchro

GEN_SYNC_NEG Incoming AS2 message rejected and a negative synchronous

MDN is generated as requested by the partner.
SENT_ASYNC_POS Incoming AS2 message accepted and a positive asynchro

nous MDN is sent to the partner.
SENT_ASYNC_NEG Incoming AS2 message rejected and a negative asynchro

SENT_SYNC_POS Incoming AS2 message accepted and a positive synchro

SENT_SYNC_NEG Incoming AS2 message rejected and a negative synchronous

MDN is sent to the partner.
RECV_ASYNC_POS The positive asynchronous MDN sent to the partner was ac
cepted.
RECV_ASYNC_NEG The negative asynchronous MDN sent to the partner was ac
cepted.
RECV_SYNC_POS The positive synchronous MDN sent to the partner was ac
cepted
RECV_SYNC_NEG The negative synchronous MDN sent to the partner was ac
cepted.

VALIDATED_ASYNC_POS The asynchronous positive MDN was validated at the part

ners side.
VALIDATED_ASYNC_NEG The asynchronous negative MDN was validated at the part

ners side.
VALIDATED_SYNC_POS The synchronous positive MDN was validated at the partners

side.
VALIDATED_SYNC_NEG The synchronous negative MDN was validated at the part

ners side.
VALIDATION_FAILED_ASYNC_POS Validation of the asynchronous positive MDN failed at the

partners side.
VALIDATION_FAILED_ASYNC_NEG Validation of the asynchronous negative MDN failed at the

partners side.
VALIDATION_FAILED_SYNC_POS Validation of the synchronous positive MDN failed at the

partners side.
VALIDATION_FAILED_SYNC_NEG Validation of the synchronous negative MDN failed at the

partners side.
ACK_REQUESTED AS2 message was sent to the partner and an acknowledge

ACK_SOLICITED AS2 message was sent to the partner and an acknowledge

ACK_NOT_SOLICITED AS2 message was sent to the partner and an acknowledge

ACK_NOT_SENT Acknowledgement not sent successfully to the partner.
ACK_NOT_GENERATED Acknowledgement generation is not successful.
Status Codes Technical Acknowledgement (ERP)
SUCCESSFULLY_RECEIVED Incoming OFTP message accepted and acknowledgement

successfully received from the partner.
SUCCESSFULLY_PROCESSED Incoming OFTP message accepted and processed success

fully.
SUCCESSFULLY_SENT Incoming OFTP message accepted and ERP successfully


EERP_GENERATED Incoming OFTP message is accepted and a EERP is gener

ated.
NERP_GENERATED Incoming OFTP message is rejected and a NERP is gener

ated.
ACK_REQUESTED OFTP message was sent to the partner and an acknowledge

ACK_SOLICITED OFTP message was sent to the partner and an acknowledge

ACK_NOT_SOLICITED OFTP message was sent to the partner and an acknowledge

GEN_ASYNC_POS Incoming OFTP message accepted and a positive asynchro

nous ERP is generated as requested by the partner.
GEN_ASYNC_NEG Incoming OFTP message rejected and a negative asynchro

GEN_SYNC_POS Incoming OFTP message accepted and a positive synchro

GEN_SYNC_NEG Incoming OFTP message rejected and a negative synchro

ACK_NOT_GENERATED Acknowledgement generation is not successful.
ACK_NOT_SENT Acknowledgement not sent successfully to the partner.
SENT_ASYNC_POS Incoming OFTP message accepted and a positive asynchro

nous ERP is sent to the partner.
SENT_ASYNC_NEG Incoming OFTP message rejected and a negative asynchro

SENT_SYNC_POS Incoming OFTP message accepted and a positive synchro

SENT_SYNC_NEG Incoming OFTP message rejected and a negative synchro

RECV_ASYNC_POS The positive asynchronous ERP sent to the partner was ac
cepted.
RECV_ASYNC_NEG The negative asynchronous ERP sent to the partner was ac
cepted.

RECV_SYNC_POS The positive synchronous ERP sent to the partner was ac
cepted.
RECV_SYNC_NEG The negative asynchronous ERP sent to the partner was ac
cepted.
VALIDATED_ASYNC_POS The asynchronous positive ERP was validated at the part

ners side
VALIDATED_ASYNC_NEG The asynchronous negative ERP was validated at the part

ners side
VALIDATED_SYNC_POS The synchronous positive ERP was validated at the partners

side
VALIDATED_SYNC_NEG The synchronous negative ERP was validated at the partners

side
VALIDATION_FAILED_ASYNC_POS Validation of the asynchronous positive ERP failed at the

partners side
VALIDATION_FAILED_ASYNC_NEG Validation of the asynchronous negative ERP failed at the

partners side
VALIDATION_FAILED_SYNC_POS Validation of the synchronous positive ERP failed at the part

ners side
VALIDATION_FAILED_SYNC_NEG Validation of the synchronous negative ERP failed at the

partners side
UNKNOWN_ERROR Unknown error occurred either at sender or receiver side
1.5.3 B2B Alerts
You configure alerts in B2B landscape to handle exceptional situation occurred during B2B communication.
Alerts report about the EDI Service Level Agreement (SLA) violations, EDI acknowledgement statuses, AS2
negative MDNs (inbound and outbound), and duplicate interchange check.
Example
Consider an EDI communication between two trading partners using SAP B2B add-on. In this scenario partner
A transmits an EDI document to partner B. As per the Service Level Agreement (SLA) defined for the EDI
scenario partner B must dispatch an acknowledgement within a stipulated time. If partner B violates the SLA,

then the system issues an alert. In this way, you can configure an alert to monitor the SLA violations and notify
you through an e-mail.
 Note
You must add TPMContentAccessModule parameter in EDI communication channel to monitor SLA’s.
You can configure alerts for B2B add-on in the following ways:
● To configuring alerts using Integration Builder, see Alert Configuration in Integration Builder
● To configuring alerts using SAP NetWeaver Administrator (SAP NWA), see Alert Configuration in SAP
NetWeaver Administrator
 Note
If you need to run the B2B integration scenarios on a Decentral Adapter Engine (DAE), you must perform
additional configuration on DAE. For more information, refer SAP Note 2072353 .
 Note
Configuring alerts using SAP NWA is based on specific SAP NW PI releases. For more information, refer
SAP Note 1815991 .
1.5.4 Archiving B2B Acknowledgements
You use this procedure to archive B2B acknowledgements along with the PI message.
The system stores the achived acknowledgements under the folder xi_af_ack_msg. You can configure the
archiving by adding a new homepath with the name as /<SYSID>/xi_af_ack_msg.
For more information about configuring the homepath, for example see Configuring Message Archiving for the
Advanced Adapter Engine.

Important Disclaimers and Legal Information
Hyperlinks
Some links are classified by an icon and/or a mouseover text. These links provide additional information.
About the icons:
● Links with the icon : You are entering a Web site that is not hosted by SAP. By using such links, you agree (unless expressly stated otherwise in your
agreements with SAP) to this:
● The content of the linked-to site is not SAP documentation. You may not infer any product claims against SAP based on this information.
● SAP does not agree or disagree with the content on the linked-to site, nor does SAP warrant the availability and correctness. SAP shall not be liable for any
damages caused by the use of such content unless damages have been caused by SAP's gross negligence or willful misconduct.
● Links with the icon : You are leaving the documentation for that particular SAP product or service and are entering a SAP-hosted Web site. By using such
links, you agree that (unless expressly stated otherwise in your agreements with SAP) you may not infer any product claims against SAP based on this
information.
Videos Hosted on External Platforms

Some videos may point to third-party video hosting platforms. SAP cannot guarantee the future availability of videos stored on these platforms. Furthermore, any
advertisements or other content hosted on these platforms (for example, suggested videos or by navigating to other videos hosted on the same site), are not within
the control or responsibility of SAP.
Beta and Other Experimental Features

Experimental features are not part of the officially delivered scope that SAP guarantees for future releases. This means that experimental features may be changed by
SAP at any time for any reason without notice. Experimental features are not for productive use. You may not demonstrate, test, examine, evaluate or otherwise use
the experimental features in a live operating environment or with data that has not been sufficiently backed up.
The purpose of experimental features is to get feedback early on, allowing customers and partners to influence the future product accordingly. By providing your
feedback (e.g. in the SAP Community), you accept that intellectual property rights of the contributions or derivative works shall remain the exclusive property of SAP.
Example Code
Any software coding and/or code snippets are examples. They are not for productive use. The example code is only intended to better explain and visualize the syntax
and phrasing rules. SAP does not warrant the correctness and completeness of the example code. SAP shall not be liable for errors or damages caused by the use of
example code unless damages have been caused by SAP's gross negligence or willful misconduct.
Gender-Related Language
We try not to use gender-specific word forms and formulations. As appropriate for context and readability, SAP may use masculine word forms to refer to all genders.

260 PUBLIC Important Disclaimers and Legal Information
Important Disclaimers and Legal Information PUBLIC 261
www.sap.com/contactsap
© 2021 SAP SE or an SAP affiliate company. All rights reserved.
No part of this publication may be reproduced or transmitted in any form

or for any purpose without the express permission of SAP SE or an SAP
affiliate company. The information contained herein may be changed
without prior notice.
Some software products marketed by SAP SE and its distributors

contain proprietary software components of other software vendors.
National product specifications may vary.
These materials are provided by SAP SE or an SAP affiliate company for

informational purposes only, without representation or warranty of any
kind, and SAP or its affiliated companies shall not be liable for errors or
omissions with respect to the materials. The only warranties for SAP or
SAP affiliate company products and services are those that are set forth
in the express warranty statements accompanying such products and
services, if any. Nothing herein should be construed as constituting an
additional warranty.
SAP and other SAP products and services mentioned herein as well as
their respective logos are trademarks or registered trademarks of SAP
SE (or an SAP affiliate company) in Germany and other countries. All
other product and service names mentioned are the trademarks of their
respective companies.
Please see https://www.sap.com/about/legal/trademark.html for

additional trademark information and notices.
THE BEST RUN

B2B Addon Configuration

Uploaded by

Document Information

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

B2B Addon Configuration

Uploaded by

Copyright:

Available Formats

PUBLIC

Process Integration, business-to-business add-on

THE BEST RUN

1 SAP Process Integration, business-to-business add-on Configuration. . . . . . . . . . . . . . . . . . . . 3

1.1 Configuring Adapters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Configuring the Communication Channels with the AS2 Adapter. . . . . . . . . . . . . . . . . . . . . . . . . 3

Configuring the Communication Channels with the OFTP Adapter. . . . . . . . . . . . . . . . . . . . . . . 23

Configuring the Communication Channels with the X.400 Adapter. . . . . . . . . . . . . . . . . . . . . . . 47

Configuring the Communication Channel with EDI Separator Adapter. . . . . . . . . . . . . . . . . . . . .75

1.2 Configuring Adapter Modules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Configuring the Archiver Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Configuring the Number Range Objects (NRO) Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119

Configuring the ANSI ASC X12-XML Converter Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Configuring the EDIFACT-XML Converter Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124

Configuring the EANCOM-XML Converter Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Configuring the Generic Converter Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Configuring the ODETTE-XML Converter Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Configuring the PLAIN-XML Converter Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Configuring the TRADACOMS-XML Converter Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Configuring the VDA-XML Converter Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .130

Configuring the EDI Search Parameter Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Configuring the Converter Module Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

1.3 Importing User Defined Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

1.4 B2B Integration Cockpit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

Log Viewer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .156

Scheduling Log Clean-up Job. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

Configuring the EDI Content Manager. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

Maintaining Number Range Objects. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208

Trading Partner Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209

1.5 Monitoring B2B Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252

Searching EDI Messages Using Correlation ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .253

Status Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .253

B2B Alerts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258

Archiving B2B Acknowledgements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259

Process Integration, business-to-business add-on Configuration

For more information, see :

● Configuring Adapters [page 3]

1.1 Configuring Adapters

For more information, see:

● Configuring the Communication Channels with the AS2 Adapter [page 3]

1.1.1 Configuring the Communication Channels with the AS2

Process Integration, business-to-business add-on Configuration

Process Integration, business-to-business add-on Configuration

1.1.1.1.1 Configuring AS2 Sender Channel for Inbound

3. Choose to configure the adapter.

Process Integration, business-to-business add-on Configuration

Component Parameter Description

Server Expected URL Path Provide the <path> mentioned in the

The format used to define AS2 URL is

Message Expected MessageID Left This parameter determines the left

Expected MessageID Right This parameter determines the right

Expected Sender's AS2 Name This parameter determines the part­

Expected Own AS2 Name This parameter determines the com­

Process Integration, business-to-business add-on Configuration

Expected Subject This parameter defines the message

Charset Charset Conversion This parameter enables you to encode

Source Encoding This parameter defines the encoding

Destination Encoding This parameter defines the encoding

You are alerted if multiple sender

Duplicate Message Threshold This parameter defines the threshold

Disable channel if threshold exceeded This parameter enables the sender

Process Integration, business-to-business add-on Configuration

Enable Duplicate Filename Handling This parameter enables the adapter to

○ Send Warning MDN

Expected Sender's AS2 Name This parameter determines the part

Expected Own AS2 Name This parameter determines the com

Quality of Service This parameter determines the man

The following types of quality of serv

The adapter archives both synchro

Payload after Charset Conversion This parameter archives payload at

Payload after Decryption This parameter archives payload at

○ Active: Enables the adapter to ex

Decryption Decrypt This parameter enables you to de

View to own private key This parameter determines your pri

Alias of own private key This parameter determines the pseu

View to own private key This parameter determines your pri

Alias of own private key This parameter determines the pseu

Asynchronous Message Disposition Send Options This parameter delivers an asynchro

Basic HTTP Authentication This parameter provides authentica

Basic Proxy Authentication This parameter provides authentica

The format used to define the part

Basic HTTP Authentication This parameter provides authentica

Basic Proxy Authentication This parameter provides authentica

Own AS2 Name This parameter specifies the compa

Message Subject This parameter determines the sub
