Lab Guide Information
Overview:
This lab guide contains exercises that are designed to enable the
student to configure the concepts and technologies learnt in the course
Objectives:
The student will be performing the following:
➢ SLX CLI Essentials

➢ System Configuration and Monitoring
➢ VLAN and Port Configuration
➢ L2 Redundancy
➢ LACP and LLDP Configuration
➢ Advanced Configuration of IGP’s
➢ Configuring BGP (Numbered Interfaces)
➢ Configuring BGP (Un-numbered Interfaces)
➢ Configuring BGP EVPN (Un-numbered Interfaces)
➢ MCT Configuration
Login Information:
Accounts the student will be using to access the lab equipment
S.No Student Device Allocated Username Password

1 Student 1 G1-Leaf1 admin password
7 Student 7 G1-Spine1 admin password
Table 1: Group-1 Device Login Information

S.No Student Device Allocated Username Password

Table 2: Group-2 Device Login Information
Note: Students are advised to access XOS switch using management ip address
whenever needed due to the fact that console access is restricted to one user all the
time.
S. No Device Name Username Password

1 G1-XOS admin ‘no password’
2 G2-XOS admin ‘no password’
Table 3: XOS Switches Login Information

Lab 1: SLX CLI Essentials
Overview:
This lab introduces you to the SLX OS software CLI. In this lab, you will be introduced
to various CLI operational and configuration mode features and capabilities.
Upon completion of this lab, you will be able to perform the following tasks:
• Operational Mode:
− Access SLX Device, issue CLI commands, and obtain context-sensitive
help
− View CLI error messages
− Learn CLI keyboard sequences
− Modify the CLI environment
− Use CLI features to navigate and search through command output
• Configuration Mode:
− Navigate and view the configuration hierarchy
− Run operational commands from within the configuration mode
− Saving configuration files
Key Commands
Key operational mode commands used in the lab are as follows
dhcp ztp cancel

show interfaces
show ip route
configure
configure terminal
do show running-config
copy running-config startup-config

Lab Access Topology:
All the SLX devices can be accessed using console by coonecting to the Terminal
server having its IP address set as 10.140.8.100 and mapped with the ports such as
2001,2002,2003 etc to the respective SLX devices.
Table 1 indicates the IP addresses and ports that the SLX devices are accessed
using console.
Device Management IP Port: Telnet
G1-Leaf1 10.140.8.100 2001
G1-Leaf2 10.140.8.100 2002
G1-Leaf3 10.140.8.100 2003
G1-Leaf4 10.140.8.100 2004
G1-Leaf5 10.140.8.100 2005
G1-Leaf6 10.140.8.100 2006
G1-Spine1 10.140.8.100 2007
G1-Spine2 10.140.8.100 2008
G2-Leaf1 10.140.8.100 2009
G2-Leaf2 10.140.8.100 2010
G2-Leaf3 10.140.8.100 2011
G2-Leaf4 10.140.8.100 2012
G2-Leaf5 10.140.8.100 2013
G2-Leaf6 10.140.8.100 2014
G2-Spine1 10.140.8.100 2015
G2-Spine2 10.140.8.100 2016
Table 2: SLX Device Console Access IP addresses and ports

Table 2 indicates the IP addresses and ports that the SLX devices are accessed
using Management IPs.
Device Management IP Port : Telnet

G1-Leaf1 10.140.8.101/24 23
G1-Leaf2 10.140.8.102/24 23
G1-Leaf3 10.140.8.103/24 23
G1-Leaf4 10.140.8.104/24 23
G1-Leaf5 10.140.8.105/24 23
G1-Leaf6 10.140.8.106/24 23
G1-Spine1 10.140.8.107/24 23
G1-Spine2 10.140.8.108/24 23
G2-Leaf1 10.140.8.109/24 23
G2-Leaf2 10.140.8.110/24 23
G2-Leaf3 10.140.8.111/24 23
G2-Leaf4 10.140.8.112/24 23
G2-Leaf5 10.140.8.113/24 23
G2-Leaf6 10.140.8.114/24 23
G2-Spine1 10.140.8.115/24 23
G2-Spine2 10.140.8.116/24 23
Table 2: SLX Device Mamanagement Access IP addresses
Part 1: Accessing SLX Device, Basic commands and Context

sensitive help
Note: Please login to your assigned device as allocated by the instructor using the
login credentials listed in the lab guide information section.
.
Step 1: Disabling Zero Touch Provisioning (ZTP)
All SLX devices are pre-enabled with ZTP and the relevant messages keeps
on getting displayed on the terminal. This step of disabling ZTP stops those messages
on terminal/console
1.1 Log in to the SLX Device with username admin using a password of
password.
SLX-OS (SLX)
SLX login: admin

Password:
SECURITY WARNING: The default password for at least one

default account (root, admin and user) have not been changed.
SLX#

1.2 Enter the dhcp ztp cancel command

SLX# dhcp ztp cancel
Warning: This command will terminate the existing ZTP session

After ZTP has been confirmed canceled, you need to run "reload
system" before configuring the switch.
Do you want to continue? [y/n] y
Part 2: Context Sensitive Help

2.1 Enter ? in CLI Prompt to get the possible completions.
SLX#?
Possible completions:
alias Creat/Update Alias
bootmenu MENU operations commands
capture Capture Packet Options
cd Change working directory
certutil Security Certificate Management Operations
cfm
chassis Enable/Disable Chassis
cipherset Configure FIPS-compliant secure ciphers for
RADIUS/LDAP
clear Clear parameter
clock set switch date, time, and timezone
cluster Cluster
configure Manipulate software configuration information
copy copy configuration data
crypto Crypto Certificate Management Operations
debug Debugging Options
delete delete a file
df show filesystem disk space usage
dhcp Commands to manage DHCP auto-deployment
diag
dir show directory listing
dot1x IEEE 802.1X Port-Based Access Control
event-handler Event Handler Commands
execute-script Run user-level BASH scripts
exit Exit the management session
firmware firmware operations
ha High availability operations
help Provide help information
history Configure history size
host Host IP operations
license Command to manage license keys
log-shell Enable/Disable Linux shell activity logging
logging Logging configuration: raslog
logout Logout a user

no Negate a command or set its defaults

onie ONIE operations commands
oscmd Execute Linux Command
ping ping
power-off Power off a linecard
power-on Power on a linecard
prompt1 Set operational mode prompt
prompt2 Set configure mode prompt
pwd Display current mode path
python Python interpreter shell
quit Exit the management session
rasman View raslog messages
reload reload switch
rename rename a file
resequence Resequence list
script Script actions
send Send message to terminal of one or allusers
show Show information about the system
slot Enables or Disables a slot
ssh Outbound SSH command
start-shell Start Linux shell
sysmon System Monitoring
system
telemetry Telemetry commands
telnet Outbound Telnet command
terminal Terminal Configurations
timestamp Enable/disable the display of timestamp
tpvm TPVM operations commands
trace-l2 Trace Path to L2 node
traceroute traceroute
unlock Unlock a user account
usb USB management
write Cleanup operation
SLX#
2.2 Enter c? at CLI Prompt

SLX# c ?
set set local clock date and time
SLX# c?
capture Capture Packet Options
cd Change working directory
certutil Security Certificate Management Operations
cfm
chassis Enable/Disable Chassis
cipherset Configure FIPS-compliant secure ciphers for
RADIUS/LDAP
clear Clear parameter

clock set switch date, time, and timezone

cluster Cluster
configure Manipulate software configuration information
copy copy configuration data
crypto Crypto Certificate Management Operations
SLX#
SLX# clear ?
arp Address Resolution Protocol (ARP)
bfd BFD
bpswitch
counters Clear statistics
dot1x Clear dot1x
filter-change-update Send filter change update.
history Clear command history
ip
ipv6 Internet Protocol (IPv6)
lacp Link Aggregation Control Protocol Clear
command
lldp Link Layer Discovery Protocol(LLDP).
logging Clear logging messages
mac-address-table clear mac-address table
maps Clear MAPS info
openflow Delete Flow
policy-map-counters Clear the policy map counters
ptp Clear PTP metrics
sessions Logout the user sessions in the switch`
sflow Clear sflow
spanning-tree Spanning-tree Protocol(STP).
ssh-key clear ssh-key
statistics Clear Statistics
support Clear core/FFDC files
vrrp Virtual Router Redundancy Protocol
SLX#
2.3 Explore more with command completions
SLX# show int

Loopback 1 is up, line protocol is up
Hardware is Loopback
Pluggable media not present
Interface index (ifindex) is 1476395009 (0x58000001)
IP MTU 1500 bytes
LineSpeed Actual : Nil
LineSpeed Configured : Auto
Last clearing of show interface counters: 07:26:34
Queueing strategy: fifo

Primary Internet Address is 10.1.1.7/32

FEC Mode - Disabled
Loopback 2 is up, line protocol is up
Hardware is Loopback
Pluggable media not present
IP MTU 1500 bytes
LineSpeed Actual : Nil
LineSpeed Configured : Auto
Primary Internet Address is 10.10.10.7/32
FEC Mode - Disabled
Ethernet 0/1 is up, line protocol is down (link protocol down)
<Truncated output>
Part 3: Error Messages in CLI
3.1 CLI will not let you complete invalid and incomplete commands
SLX# clear route

-----------^
syntax error: incomplete path
SLX#
Clear routes by entering clear ip route
SLX# show ip
-------------^
syntax error: unknown argument.
SLX#
Part 4: Keyboard Shortcuts
4.1 Enter show interfaces command at operational mode CLI Prompt and do not
hit enter key. After typing the command, enter the key combinations mentioned
below.
SLX# show interfaces <do not hit enter>
Press cntrl-b. – The curser moves one character backwards

Press cntrl-f – The curser moves one character forward
Press cntrl-a. – The curser moves to beginning of command
Press cntrl-e. – The curser moves end of the command
Press cntrl-w. – The curser deletes one word before curser
Press cntrl-u. – Deletes the whole command

Part 5: Operational Commands
5.1 Enter show ip route command
SLX# show ip route

Total number of IP routes: 0
SLX#
5.2 Enter show mac command
SLX# show mac

Total MAC addresses : 0
SLX#
5.3 Enter show ip interface ? command to explore possible completions in

finding the status of the interface.
SLX# show ip interface ?

brief All interface status
ethernet Ethernet interface
loopback Loopback interface
port-channel Port-channel interface
ve Ve interface
5.4 Enter show ip interface brief command to see all the interfaces
information
SLX# show ip interface brief
Flags: U - Unnumbered interface, I - Insight Enabled

Interface IP-Address Vrf Status
Protocol
========== ========== ===== ========= ========
Ethernet 0/1 unassigned default-vrf administratively down down
<Truncated/>

5.5 Enter show ip interface ethernet 0/1 command to know about a

particular interface i.e. ethernet 0/1
SLX# show ip interface e 0/1

Ethernet 0/1 is up protocol is down
IP unassigned
IP MTU is 1500
Proxy Arp is not Enabled
Vrf : default-vrf
5.6 Enter Show media command to know about the optical modules installed in
the switch
SLX# show media

Interface Ethernet 0/1
Identifier 3 SFP
Connector 7 LC
Transceiver 0000000000000010 10_GB/s
Name sw
Encoding 6
Baud Rate 103 (units 100 megabaud)
Length 9u 0 (units km)
Length 9u 0 (units 100 meters)
Length 50u 8 (units 10 meters)
Length 62.5u 3 (units 10 meters)
Length Cu 0 (units 1 meter)
Vendor Name BROCADE
Vendor OUI 00:05:1e
Vendor PN 57-0000075-01 (10GE SR SFP+)
Vendor Rev A
Wavelength 850 (units nm)
Options 001a
BR Max 0
BR Min 0
Serial No AAA318393005522
Date Code 180926
Optical Monitor Yes
<Truncated/>
5.7 Enter show li command to explore possible completions in

finding the status of the license
G1-Leaf1# show li
license Display license keys installed on the
switch.
linecard Show linecard
link-fault-signaling Show Link Fault Signalling configs

5.8 Enter Show license command to know about the license information in
the switch
G1-Leaf1# show license

No entries available
G1-Leaf1# show chassis
Chassis Name: SLX9250-32C

switchType: 3012
FAN Unit: 1
Time Awake: 0 days
FAN Unit: 2
Time Awake: 0 days
FAN Unit: 3
Time Awake: 0 days
FAN Unit: 4
Time Awake: 0 days
FAN Unit: 5
Time Awake: 0 days
FAN Unit: 6
Time Awake: 0 days
POWER SUPPLY Unit: 1

Time Awake: 0 days
POWER SUPPLY Unit: 2

Time Awake: 0 days
ID: ARTESYN
Part Num: 700-013684-0100
Serial Num: L21403007Z06P
CHASSIS/WWN Unit: 1
Power Consume Factor: 0
Factory Part Num: 800986-00-AB
Factory Serial Num: 2009Q-30008
Manufacture: Day: 21 Month: 2 Year: 2020
Update: Day: 24 Month: 3 Year: 2020
Time Alive: 0 days
Time Awake: 0 days

5.9 Enter Show version command to display the OS information which is

running in the switch
G1-Spine1# show version
SLX-OS Operating System Version: 20.1.1

Copyright (c) 1995-2020 Extreme Networks, Inc.
Firmware name: 20.1.1_bosch_bootloader_v5
Build Time: 07:25:28 Nov 28, 2019
Install Time: 00:21:03 Mar 24, 2020
Kernel: 4.14.67
Control Processor: Intel(R) Atom(TM) CPU C3758 @ 2.20GHz, 8 cores
Microcode Version: 0x24
Memory Size: System Total: 15632 MB
System Uptime: 0days 19hrs 23mins 34secs
Name Primary/Secondary Versions

------------------------------------------
SLX-OS 20.1.1_bosch_bootloader_v5
20.1.1_bosch_bootloader_v5
5.10 Enter Show cli command to display the cli information
SLX# show cli

autowizard false
complete-on-space false
devtools false
history 100
idle-timeout 600
ignore-leading-space false
output-file terminal
paginate true
prompt1 \H\M#
prompt2 \H(\m)#
screen-length 24
screen-width 80
service prompt config true
show-defaults false
terminal vt102
timestamp disable
5.11 Enter show environment ? command to explore possible completions

finding in the switch
SLX# show environment ?

fan Show fan info
history Show history info

power Show power info

sensor Show sensor info
temp Show temperature info
G1-Spine1# show environment history
FAN Unit 1 Inserted at Tue Mar 24 00:17:02 2020

Factory Part Number: Not Available
Factory Serial Number: Not Available





POWER SUPPLY Unit 1 Inserted at Tue Mar 24 00:17:02 2020

Factory Part Number: 700-013684-010
Factory Serial Number: L21403001T06
POWER SUPPLY Unit 2 Inserted at Tue Mar 24 00:17:02 2020

Factory Part Number: 700-013684-010
Factory Serial Number: L21403007Z06
Records: 8
Part 6: Enterning into the Configuration mode and issuing the

relevant commands to explore
6.1 Enter configure or conf or conf t at CLI Prompt
SLX# conf t
Entering configuration mode terminal
SLX(config)#

Note: Configure command takes you to the configuration terminal
6.2 Enter exit at CLI Prompt to exit from configuration terminal
SLX(config)# exit
SLX# conf t
6.3 Enter “do” followed by the operational command to execute the same while
in configuration mode
G1-Spine1(config)# do show running-config
clock timezone Etc/GMT
ha
no process-restart bgp
no process-restart ospfv2
no process-restart ospfv3
!
switch-attributes chassis-name SLX9250-32C
switch-attributes host-name G1-Spine1
no support autoupload enable
support ffdc
resource-monitor cpu enable threshold 90 action raslog
resource-monitor memory enable threshold 100 action raslog
resource-monitor process memory enable alarm 1500 critical 1800
system-monitor fan threshold marginal-threshold 1 down-threshold 2
system-monitor fan alert state removed action raslog
system-monitor power threshold marginal-threshold 1 down-threshold
2
system-monitor power alert state removed action raslog
system-monitor temp threshold marginal-threshold 1 down-threshold 2
system-monitor cid-card threshold marginal-threshold 1 down-
threshold 2
system-monitor cid-card alert state none action none
system-monitor compact-flash threshold marginal-threshold 1 down-
threshold 0
system-monitor MM threshold marginal-threshold 1 down-threshold 0
system-monitor LineCard threshold marginal-threshold 1 down-
threshold 2
system-monitor LineCard alert state none action none
system-monitor SFM threshold marginal-threshold 1 down-threshold 2
system-monitor port
crc enable
!
system-monitor tm
!
system interface utilization-watermark
line vty
exec-timeout 10

!
threshold-monitor Buffer limit 70
vrf mgmt-vrf
address-family ipv4 unicast
!
!
!
ssh server key rsa 2048
ssh server key ecdsa 256
ssh server key dsa
ssh server use-vrf default-vrf
ssh server use-vrf mgmt-vrf
telnet server use-vrf default-vrf
telnet server use-vrf mgmt-vrf
http server use-vrf default-vrf
http server use-vrf mgmt-vrf
role name admin desc Administrator
role name user desc User
aaa authentication login local
aaa accounting exec default start-stop none
aaa accounting commands default start-stop none
aaa authorization command none
service password-encryption
username admin password
$6$mAog0c./JxVGu1zy$6wFogQmek0KOEgTav.0DVKXz1vRodc1UCAbipYft/DWnT5R
6/Y3qpq7V3JHlhRNVtwguLgXnzdtBDKPKaXbBg/ encryption-level 10 role
admin desc Administrator
username user password
$6$mAog0c./JxVGu1zy$6wFogQmek0KOEgTav.0DVKXz1vRodc1UCAbipYft/DWnT5R
6/Y3qpq7V3JHlhRNVtwguLgXnzdtBDKPKaXbBg/ encryption-level 10 role
user desc User
snmp-server sys-descr "Extreme SLX9250 Switch"
vlan 1
!
vlan 10
!
vlan 20
!
vlan 30
!
protocol lldp
system-description Extreme SLX9250 Switch
!
vlan dot1q tag native
ip router-id 10.1.1.7
class-map default
!
no protocol vrrp
no protocol vrrp-extended

router bgp
local-as 65101
bfd interval 140 min-rx 125 multiplier 44
neighbor 10.20.10.1 remote-as 64101
neighbor 10.20.10.1 bfd
redistribute connected
neighbor 10.20.60.1 allowas-in 1
maximum-paths 8
!
!
address-family l2vpn evpn
!
!
router ospf vrf default-vrf
area 0
area 1
area 2
area 3
!
interface Loopback 1
ip address 10.1.1.7/32
no shutdown
!
ip ospf area 0
ip address 10.10.10.7/32
no shutdown
!
interface Management 0
no tcp burstrate
no shutdown
vrf forwarding mgmt-vrf
ip icmp unreachable

ip icmp echo-reply
no ip address dhcp
ip address 10.140.8.107/24
no ipv6 address autoconfig
no ipv6 address dhcp
!
interface Ethernet 0/1
speed 10000
no shutdown
!
speed 10000
no shutdown
!
speed 10000
no shutdown
!
speed 10000
no shutdown
!
speed 10000
no shutdown
!
speed 10000
no shutdown
!
no shutdown
!
no shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown

!
shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!

shutdown
!
shutdown
!
shutdown
!
shutdown
!
logging raslog console INFO
logging auditlog class SECURITY
logging auditlog class CONFIGURATION
logging auditlog class FIRMWARE
logging syslog-facility local LOG_LOCAL7
telemetry profile system-utilization
default_system_utilization_statistics
interval 60
add total-system-memory
add total-used-memory
add total-free-memory
add cached-memory
add buffers
add total-swap-memory
add total-free-swap-memory
add total-used-swap-memory
add user-process
add system-process
add niced-process
add iowait
add hw-interrupt
add sw-interrupt
add idle-state
add steal-time
add uptime
!
telemetry profile interface default_interface_statistics
interval 30
add out-pkts
add in-pkts
add out-unicast-pkts
add in-unicast-pkts
add out-broadcast-pkts
add in-broadcast-pkts
add out-multicast-pkts
add in-multicast-pkts
add out-pkts-per-second
add in-pkts-per-second
add out-bandwidth

add in-bandwidth
add out-octets
add in-octets
add out-errors
add in-errors
add out-crc-errors
add in-crc-errors
add out-discards
add in-discards
!
6.6 The configuration snippets of specific required configuration can be

displayed with various possible options. do show running-config
interface command displays the interfaces configuration of the device.
SLX(config)# do show running-config interface

no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.101/24
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown

!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!

no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!


no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
6.7 Enter do show running-config ? to know about the possible completion

options to display specific configuration snippets
SLX(config)# do show running-config ?
aaa Configure preferred order of types
of AAA server
alias-config Command Alias
arp Address Resolution Protocol (ARP)
banner Configure Banner message
bridge-domain bridge-domain name for Node Specific
configuration
cee-map CEE map command

chassis Configure Chassis Virtual address

class-map Class Map Configuration
clock Configure System Timezone
cluster MCT Cluster Specific configuration
crypto Configure Crypto services
dot1x IEEE 802.1X Port-Based Access
Control
event-handler Event Handler Commands
filter-change-update-delay Change filter change update delay
timer
hardware Hardware Management configuration
http Configure HTTP Server
interface Interface configuration
ip IP access list
ipv6 The Internet Protocol (IPv6).
lacp LACP commands
ldap-server LDAP server configuration
line CLI session configuration
link-fault-signaling Configure a link-fault-signaling
load-balance load-balance
logging Logging configuration: raslog/syslog
mac MAC access list
mac-address-table MAC forwarding table information
monitor Entering span sessions
ntp NTP commands
openflow enables openflow and version
password-attributes Configure system wide user password
attributes
police-remark-profile Configure police remark profile
policy-map Policy Map Configuration
protocol Protocol configuration
pw-profile pw-profile for Node Specific
configuration
qos Quality of Service (QoS)
qos-mpls MPLS Quality of Service (QoS)
radius-server RADIUS server configuration
resource-monitor Configure resource monitoring
rmon Remote Monitoring Protocol (RMON)
role Role configuration
root Configure root account/access
route-map Configure a route-map instance
router Configure Router
rule Rule Configuration
service Perform services
sflow Sflow Configuration
sflow-profile Sflow Profile Configuration
snmp-server Snmp server configurations.
ssh Configure SSH
support Support configuration
switch-attributes Switch attributes configurations

system-monitor Configure FRU threshold and alert
<Truncated Outpur/>
7 Enter do show running-config clock to display about the time zone
SLX(config)# do show running-config clock

clock timezone Etc/GMT
End of Lab 1

Lab 2: System Configuration and Monitoring

This lab covers the initial configuration and troubleshooting guidelines using
an approach that is designed to make you think through each step. For additional
guidance and sample router output, please see the detailed version of this lab in
Appendix A.
In this lab, you will load a factory default configuration and perform configuration steps
typical for a new installation. You will also monitor the operation of the router using
various show commands.
By completing this lab, you will perform the following tasks:
Objectives:
• Load a factory configuration
• Set the date and time
• Setting a Host name to the device
• Enabling and Disabling interfaces
• Configuring Managament IP’s and Loopback 1 adresses.
• Creating User accounts
Part 1: Loading a Default Configuration

Log into the router with the login: admin using a password: password.
Enter configuration mode, and issue the following command to load a default
configuration:
1.1 Enter the copy default-config startup-config command to load

default configuration
1) Copy default configuration
G1-Leaf1# copy default-config startup-config
This operation will modify your startup configuration. Do you

want to continue? [y/n]:y
WARN: "reload system" is required to have configuration changes
take effect!
2020/06/12-17:58:13, [DCM-1103], 6976,, INFO, SLX9140, Copy

default-config to startup-config operation successful on this
node.
2) Reload for changes to take place
G1-Leaf1# reload

Warning: Unsaved configuration will be lost. Please run `copy

running-config startup-config` to save the current configuration
if not done already.
Are you sure you want to reload the switch? [y/n]:y

The system is going down for reload NOW !!
[114069.858121] VBLADE: vblade_control: FEPORTS_DISABLE
xpDma::quiesce:335 devId=0
xpDriverWrapper::quiesce:146 devId=0
3) Set the host-name:
SLX(config)# switch-attributes host-name G1-leaf1
Part 2: Set the date and time
The Extreme device allows you to manually set the system clock.the time
counter setting is retained across power cycles.
2.1 Change the time zone using clock timezone America/Los_Angeles

command:
SLX(config)# clock timezone America/Los_Angeles
%%INFO: Reload is recommended to update all system entities
with the configured time zone
SLX(config)# exit
2.2 In privileged EXEC mode set the date and time (YYYY-MM-DD)
G1-Spine2# clock set 2020-05-13T19:18:42
G1-Spine2# Wed May 13 19:18:42 GMT 2020
G1-Spine2(config)# do show clock

2020-05-13 19:18:42 Etc/GMT
G1-Spine2(config)#
Part – 1 & 2 Alternative:

In Place of write erase, you could also these commands to load default configuration
This operation will modify your startup configuration. Do you want to

continue? [y/n]:y

WARN: "reload system" is required to have configuration changes take

effect!
2020/06/12-17:58:13, [DCM-1103], 6976,, INFO, SLX9140, Copy default-

config to startup-config operation successful on this node.
G1-Leaf1# reload
Warning: Unsaved configuration will be lost. Please run `copy running-

config startup-config` to save the current configuration if not done
already.

Note: If you want to reload the device but keep the configuration intact:
G1-Leaf1# copy running-config startup-config

G1-Leaf1# reload
Part 3: Setting a Host name to the device

3.1 Use the given stated command to set your device name.
SLX(config)# switch-attributes host-name G1-Spine1
2020/05/13-22:48:49, [IPAD-1002], 8793,, INFO, SLX9250-32C,

Switch name has been successfully changed to G1-Spine1.
G1-Spine1(config)#
Part 4: Enabling and Disabling Interfaces

By default all interfaces are enabled. Enter show run interface command to
verify the default configuration, Best Practice is to disable the interfaces that are not
being used. Hence disable all the interfaces and enable only the interfaces that are
used in the respective labs as given in the lab topology diagrams.
4.1 Use show running-config interface command to check the status of

interfaces
G1-leaf1# show running-config interface

no tcp burstrate
no shutdown
ip address dhcp
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown<Truncated output>
4.2 The following steps will disable a particular interface.
G1-leaf1(config)# interface e 0/7

G1-leaf1(conf-if-eth-0/7)# shutdown
4.3 The following steps will disable a range of interfaces.
Note: Since, the Spine devices are of 9250, there are 32 interfaces. On the other
hand, Leaf devices are of 9140 and has 54 interfaces
For Leaf Devices:
G1-leaf1(config)# interface e 0/1-54

G1-leaf1(conf-if-eth-0/1-54)# shutdown
For Spine Devices:
G1-Spine1(config)# int e 0/1-32

G1-Spine1(conf-if-eth-0/1-32)# shutdown
G1-Leaf1(conf-if-eth-0/1-54)# do show ip interface brief

Interface IP-Address Vrf

Status Protocol
================== ========== ==================
==================== ========
Ethernet 0/1 unassigned default-vrf
administratively down down
administratiAborted: by user
<truncated output>
4.4 The following steps will enable the required interfaces.

G1-leaf1# conf t
G1-leaf1(config)# int e 0/1-7
G1-leaf1(conf-if-eth-0/1-7)# no shutdown
2020/05/13-17:05:51, [NSM-1019], 137485, DCE, INFO, G1-leaf1,
Interface Ethernet 0/7 is administratively up.
2020/05/13-17:05:51, [NSM-1042], 137491, DCE, WARNING, G1-
leaf1, Unqualified SFP transceiver for interface Ethernet 0/2
is detected.


2020/05/13-17:05:51, [NSM-1042], 137493, DCE, WARNING, G1-
leaf1, Unqualified SFP transceiver for interface Ethernet 0/1
is detected .
4.5 Run the operational command show ip interfaces brief to see the
enabled interfaces
G1-leaf1(config)# do show ip interface brief

Interface IP-Address Vrf Status Protocol
======== ========== ======== ====== ========
Ethernet 0/1 unassigned default-vrf up down
<Truncated Output/>
Part 5: Configuring Management and Loopback addresses

Configure the management IP addresses and Loopback addresses as
mentioned in the table given and on the respective allocated SLX device.
5.1 The following steps will enable Management IP as specified in the table
below.
G1-leaf1(config)# interface Management 0

G1-leaf1(config-Management-0)# no shutdown
G1-leaf1(config-Management-0)# no ip address dhcp
G1-leaf1(config-Management-0)# ip address 10.140.8.101/24
Device Loopback 1 Interface Management IP

G1-Leaf1 10.1.1.1/32 10.140.8.101/24
G1-Leaf2 10.1.1.2/32 10.140.8.102/24
G1-Leaf3 10.1.1.3/32 10.140.8.103/24
G1-Leaf4 10.1.1.4/32 10.140.8.104/24

G1-Leaf5 10.1.1.5/32 10.140.8.105/24

G1-Leaf6 10.1.1.6/32 10.140.8.106/24
G1-Spine1 10.1.1.7/32 10.140.8.107/24
G1-Spine2 10.1.1.8/32 10.140.8.108/24
G2-Leaf1 10.11.1.1/32 10.140.8.109/24
G2-Leaf2 10.11.1.2/32 10.140.8.110/24
G2-Leaf3 10.11.1.3/32 10.140.8.111/24
G2-Leaf4 10.11.1.4/32 10.140.8.112/24
G2-Leaf5 10.11.1.5/32 10.140.8.113/24
G2-Leaf6 10.11.1.6/32 10.140.8.114/24
G2-Spine1 10.11.1.7/32 10.140.8.115/24
G2-Spine2 10.11.1.8/32 10.140.8.116/24
Table 3: Management IP and Loopback 1 Interface Information
5.2 The following steps will enable Loopback 1 Interface as specified in the
table below.
G1-leaf1(config)# interface loopback 1

G1-leaf1(config-loopback-1)# no shutdown
G1-leaf1(config-loopback-1)# ip address 10.1.1.1/32
2020/05/13-17:50:33, [IPAD-1000], 28439,, INFO, SLX9140, IP
Config change: Entity:SW/0 Interface:Ether/0 Addresss
family:IPv4 Source of change:manual Address:10.140.8.101/24
DHCP:Off.
5.3 Run the operational command show running-config interface to see

the interface configurations made
Leaf:
G1-leaf1(config)# do show running-config interface
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp

ip address 10.140.8.101/24
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
Spine:
G1-Spine1(config-Loopback-1)# do show running-config interface

no shutdown
!
no tcp burstrate
no shutdown
ip icmp unreachable
ip icmp echo-reply
no ip address dhcp
ip address 10.140.8.107/24
no ipv6 address autoconfig
no ipv6 address dhcp
!
no shutdown
!
Part 6: Creating User accounts

6.1 Create the new user named User name: extreme and password: slx123
G1-Leaf1(config)# username extreme password slx12345 role

admin
2020/05/13-13:47:27, [SEC-1180], 137222,, INFO, SLX9140, Added
account extreme with admin authorization.
2020/05/13-13:47:27, [SEC-3501], 137223,, INFO, SLX9140, Role

'admin' is changed.
6.2 Issue the operational command show users to see all the logged in users
G1-leaf3(config)# do show users

**USER SESSIONS**
Username Role Host IP Device Time Logged In
admin admin 127.0.0.1 Cli 2020-05-13 17:58:14
**LOCKED USERS**
Username
no locked users
End of Lab 2

Lab 3: VLAN and Port Configuration

In this lab, you will create VLANs and configure ports
Objectives:
In this lab exercise,
• You will use CLI to configure VLANs and port Configuration
Note: Now that you have configured Management IP, you can enter Management IP
in the telnet session for gaining access to corresponding switch.
Device VLAN’s to be configured Device VLAN’s to be configured

G1-Leaf1 Vlan 20 Vlan 30 G2-Leaf1 Vlan 20 Vlan 30
G1-Leaf3 Vlan 10 Vlan 20 Vlan 30 G2-Leaf3 Vlan 10 Vlan 20 Vlan 30
G1-Leaf4 Vlan 10 Vlan 20 Vlan 30 G2-Leaf4 Vlan 10 Vlan 20 Vlan 30
G1-Spine1 Vlan 10 Vlan 20 Vlan 30 G2-Spine1 Vlan 10 Vlan 20 Vlan 30
G1-Spine2 Vlan 10 Vlan 20 Vlan 30 G2-Spine2 Vlan 10 Vlan 20 Vlan 30
Table: VLAN Configuration Information for Lab 3
The configuration steps are explained by taking leaf-1 as an example. Please use the given
data for configuration of other switches.
Device G1- G1- G1- G1- G1-Leaf5 G1-Leaf6 G1- G1-

Leaf1 Leaf2 Leaf3 Leaf4 Spine1 Spine2
G1-Leaf1 -- -- -- -- -- -- E0/49 E0/50
G1-Leaf2 -- -- -- -- -- -- E0/50 E0/49
G1-Leaf3 -- -- -- -- -- -- E0/49 E0/50
G1-Leaf4 -- -- -- -- -- -- E0/50 E0/49
G1-Leaf5 -- -- -- -- -- -- E0/49 E0/50
G1-Leaf6 -- -- -- -- -- -- E0/50 E0/49
G1-Spine1 E0/1 E0/2 E0/3 E0/4 E0/5 E0/6 -- --
G1-Spine2 E0/2 E0/1 E0/4 E0/3 E0/6 E0/5 -- --
Table: Connectivity Diagram for Lab: 3 Group 1 Switches


G2-Leaf1 -- -- -- -- -- -- E0/49 E0/50
G2-Leaf2 -- -- -- -- -- -- E0/50 E0/49
G2-Leaf3 -- -- -- -- -- -- E0/49 E0/50
G2-Leaf4 -- -- -- -- -- -- E0/50 E0/49
G2-Leaf5 -- -- -- -- -- -- E0/49 E0/50
G2-Leaf6 -- -- -- -- -- -- E0/50 E0/49
G2-Spine1 E0/1 E0/2 E0/3 E0/4 E0/5 E0/6 -- --
G2-Spine2 E0/2 E0/1 E0/4 E0/3 E0/6 E0/5 -- --
Table: Connectivity Diagram for Lab: 3 Group 2 Switches
Note: Connectivity ON a particular switch is present in its row. For Eg: It is through E0/1,
G1-leaf1 is connected to G1-Spine1. E0/1 is on G1-leaf1
.
Lab Topology
Part 1: Configure VLAN’s

In this section of the lab, you will configure VLANs
1.1 Create several VLAN’s 10, 20, 30
G1-leaf1# conf t
G1-leaf1(config)# vlan 10
G1-leaf1(conf-vlan-10)# vlan 20
G1-leaf1(conf-vlan-20)# vlan 30

G1-leaf1(conf-vlan-30)# exit
1.2 Confirm that the vlans were created by issuing the show vlan brief
command.
Hint: Use “do” before the command in show vlan brief when you are in configuration
terminal
G1-leaf1(config-vlan-30)# do show vlan brief

Total Number of VLANs configured : 4
VLAN Name State Ports
(R)-RSPAN (u)-Untagged
(t)-Tagged
========= =========== ================== ==========
1 default INACTIVE(no member port)
10 VLAN0010 INACTIVE(no member port)
1.3 Configure an edge port interface for VLAN as specified in the topology:
G1-leaf1(conf-if)# int ethernet 0/5

G1-leaf1(conf-if-eth-0/5)# switchport
G1-leaf1(conf-if-eth-0/5)# switchport mode access
G1-leaf1(conf-if-eth-0/5)# switchport access vlan 30
Note: Check if the configuration of ethernet 0/5 matches with this using the below specified command
G1-leaf1(conf-if-eth-0/5)# do show running-config int e 0/5

switchport
switchport mode access
switchport access vlan 30
no shutdown
1.4 Configure trunk port interfaces for VLAN’s as specified in the topology:
G1-leaf1(config)# interface Ethernet 0/49-50

G1-leaf1(conf-if-eth-0/49-50)# switchport
G1-leaf1(conf-if-eth-0/49-50)# switchport mode trunk
G1-leaf1(conf-if-eth-0/49-50)# switchport trunk allowed vlan
add 30
G1-leaf1(conf-if-eth-0/49-50)# switchport trunk allowed vlan
add 20
Note: Check if the configuration of ethernet 0/49-50 matches with this using the below specified
command. Also check your own ports if you are not using leaf -1&2.

G1-leaf1(conf-if-eth-0/49-50)#do show running-config int e

0/49-50
switchport
switchport mode trunk
switchport trunk allowed vlan add 20,30
switchport trunk tag native-vlan
no shutdown
!
switchport
no shutdown
!
1.5 Display the interfaces assigned to each VLAN, by running the do show vlan
brief command. See example below:
G1-leaf1(conf-if-eth-0/49-50)# do show vlan brief

Total Number of VLANs configured : 4
VLAN Name State Ports Classification
(R)-RSPAN (u)-Untagged
(t)-Tagged
=========== ============ ============= =========== ===========
1 default ACTIVE Eth 0/5(u)
Eth 0/49(t)
Eth 0/50(t)
10 VLAN0010 ACTIVE INACTIVE(no member port)
20 VLAN0020 ACTIVE Eth 0/50(t)

Eth 0/49(t)
30 VLAN0030 ACTIVE Eth 0/5(u)

Eth 0/50(t)
Eth 0/49(t)

1.6 Display the running configuration of interface e 0/49-50, by running the

do show run int e 0/49-50 command.
G1-Leaf1 (conf-if-eth-0/49-50)# do show running-config int e 0/49-50

switchport
no shutdown
!
switchport
no shutdown
!
Example Configurationg for a Spine Device
G1-Spine1(config)# do show running-config int e 0/1-7

switchport
switchport trunk allowed vlan add 10,20,30
no shutdown
!
switchport
no shutdown
!
switchport

no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
1.7 Testing the Set-up
To test the set up, ping a different PC and test to see if the ICMP messages are
travelling.

End of Lab 3

Lab 4: L2 Redundancy
Objectives:
In this laboratory exercise, you perform tasks related to Spanning Tree and RSTP
• Observe the network impact when transitioning from 802.1d (STP) to 802.1w
(RSTP)
• Record the 802.1w states
• Load balance traffic across two uplinks using 802.1 w port priorities
• Observe 802.1w failover time
Lab Topology
Part 1: Configuring VLAN on the interfaces as mentioned below:
Device E 0/3 E 0/4 E 0/7 E 0/8

G1-leaf1 VLAN 10 VLAN 10 -- --
G1-Leaf5 VLAN 50 VLAN 50 -- --
G1-Spine1 -- -- VLAN 40 VLAN 40
Device E 0/3 E 0/4 E 0/7 E 0/8



1.1 Configure trunk port interfaces for VLAN’s as specified in the topology:
Note: If your device doesn’t have the corresponding vlan configured from the
previous lab, then use this command to create one.
Example for Leaf:
G1-leaf1# conf t
G1-leaf1(conf-vlan-10)# exit
G1-leaf1(config)# interface Ethernet 0/3-4

G1-leaf1(conf-if-eth-0/3-4)# switchport
G1-leaf1(conf-if-eth-0/3-4)# switchport mode trunk
G1-leaf1(conf-if-eth-0/3-4)# switchport trunk allowed vlan add
10
Example for Spine:
G1-spine1# conf t
G1-spine1 (config)# vlan 40
G1-spine1 (conf-vlan-40)# exit
G1-spine1(config)# interface Ethernet 0/7-8

G1-spine1(conf-if-eth-0/7-8)# switchport
G1-spine1(conf-if-eth-0/7-8)# switchport mode trunk
G1-spine1(conf-if-eth-0/7-8)# switchport trunk allowed vlan
add 40
Part 2: Configuring RSTP

2.1 Enable RSTP on all the switches.
G1-leaf1# configure
G1-Leaf1(config)# protocol spanning-tree ?
mstp Multiple spanning tree
pvst PVST spanning-tree
rpvst Rapid PVST spanning tree
rstp Rapid spanning tree
stp STP spanning-tree

G1-leaf1(config)# protocol spanning-tree rstp

G1-leaf1(config-rstp)#
Note: A spanning tree can be disabled by entering the no protocol spanning-

tree rstp command.
2.2 Describe or name the STP.

G1-leaf1(config-stp)# description stp1
G1-leaf1(config-stp)#
2.3 Configuring the bridge priority.
G1-leaf1(config-stp)# bridge-priority 4096

2020/05/13-22:06:06, [MSTP-2002], 137537, DCE, INFO, G1-
leaf1, RSTP root changed.
My Bridge ID: 4096:609c.9fec.2000
Old Root: 32768:609c.9fec.1200
New Root: 4096:609c.9fec.2000.
2.4 Configuring the bridge forward delay.
G1-leaf1(config-stp)# forward-delay 20
Note: The forward delay specifies how long an interface remains in the listening and
learning states before it begins forwarding all spanning tree instances. The valid range is
from 4 through 30 seconds. The default is 15 seconds.
2.5 Configure the maximum aging time.
G1-leaf1(config-stp)# max-age 25
2.6 Configure the maximum hello time.
G1-leaf1(config-stp)# hello-time 8
Note: The hello time determines how often the switch interface broadcasts hello BPDUs to
other devices. The default is 2 seconds while the range is from 1 through 10 seconds.
2.7 Enable the error disable timeout timer.
G1-leaf1(config-stp)# error-disable-timeout enable
2.8 Set the error disable timeout timer.
G1-leaf1(config-stp)# error-disable-timeout interval 60

2.9 Configure the port channel path cost.
G1-leaf1(config-stp)# port-channel path-cost custom
2.10 Summarizing the configuration steps
G1-leaf1# configure terminal

G1-leaf1(conf-rstp)# bridge-priority 4096
G1-leaf1(conf-rstp)# forward-delay 20
G1-leaf1(conf-rstp)# max-age 25
G1-leaf1(conf-rstp)# error-disable-timeout enable
G1-leaf1(conf-rstp)# error-disable-timeout interval 60
G1-leaf1(conf-rstp)# port-channel path-cost custom
G1-leaf1(conf-rstp)# hello-time 8
G1-leaf1(conf-rstp)# transmit-holdcount 5
G1-leaf1(conf-rstp# end
2.11 RSTP configuration on edge ports

G1-leaf1(config)# interface ethernet 0/5
G1-leaf1(conf-if-eth-0/5)# switchport
G1-leaf1(conf-if-eth-0/5)# no spanning-tree shutdown
G1-leaf1(conf-if-eth-0/5)# spanning-tree priority 128
G1-leaf1(conf-if-eth-0/5)# spanning-tree cost 20000000
G1-leaf1(conf-if-eth-0/5)# spanning-tree edgeport
G1-leaf1(conf-if-eth-0/5)# spanning-tree edgeport bpdu-guard
G1-leaf1(conf-if-eth-0/5)# spanning-tree autoedge
G1-leaf1(conf-if-eth-0/5)# spanning-tree guard root
G1-leaf1(conf-if-eth-0/5)# spanning-tree link-type point-to-
point
G1-leaf1(conf-if-eth-0/5)# end
2.12 Use show spanning-tree brief command for concise output
Leaf:
G1-Leaf1# show spanning-tree brief
Spanning-tree Mode: Rapid Spanning Tree Protocol
Root ID Priority 4096

Address 0004.96d6.afce
Hello Time 8, Max Age 25, Forward Delay 20
Root Port: Eth 0/49
Bridge ID Priority 4096

Address 609c.9fec.2000
Hello Time 8, Max Age 25, Forward Delay 20,
Tx-HoldCount 5
Migrate Time 3 sec
Interface Role Sts Cost Prio Link-type Edge

-------------------------------------------------------------
Eth 0/3 DIS DSC 20000000 128 P2P No
Eth 0/4 DIS DSC 20000000 128 P2P No
Eth 0/5 DIS DSC 20000000 128 P2P Yes
Eth 0/49 RTPT FWD 500 128 P2P No
Eth 0/50 DIS DSC 20000000 128 P2P No
Spine:
G1-Spine2# show spanning-tree brief
Root ID Priority 4096

Address 0004.96d6.aa1a
Hello Time 8, Max Age 25, Forward Delay 20
Bridge ID Priority 4096

Address 0004.96d6.aa1a
Hello Time 8, Max Age 25, Forward Delay
20, Tx-HoldCount 5
Migrate Time 3 sec
Interface Role Sts Cost Prio Link-type Edge

---------------------------------------------------------
Eth 0/7 DIS DSC 20000000 128 P2P No
Eth 0/8 DES FWD 500 128 P2P No
Eth 0/9 DIS DSC 20000000 128 P2P Yes
2.13 Use show spanning-tree for Detailed Output
G1-Leaf1# show spanning-tree

Root Id: 1000.0004.96d6.afce

Bridge Id: 1000.609c.9fec.2000
Root Bridge Forward Delay: 20; Hello Time: 8; Max Age: 25;
Max-hops: 20
Configured Forward Delay: 20; Hello Time: 8; Max Age: 25;
Max-hops: 20
Tx-HoldCount: 5
Number of topology change(s): 4; Last change occurred
00:12:04 ago on Eth 0/49
Bpdu-guard errdisable timeout: enabled

Bpdu-guard errdisable timeout interval: 60 sec
Migrate Time: 3 sec
Port Eth 0/3 enabled

Ifindex: 201351552; Id: 8003; Role: Disabled; State:
Discarding
Designated Path Cost: 0
Configured Path Cost: 20000000
Designated Port Id: 0; Port Priority: 128
Designated Bridge: 0000.0000.0000.0000
Number of forward-transitions: 0
Version: Rapid Spanning Tree Protocol - Received None -
Sent RSTP
Edgeport: off; AutoEdge: no; AdminEdge: no; EdgeDelay: 3
sec
Configured Root guard: off; Operational Root guard: off
Bpdu-guard: off
Link-type: point-to-point
Received BPDUs: 0; Sent BPDUs: 0

Discarding


Sent RSTP
sec
Bpdu-guard: off

Discarding
Sent RSTP
Edgeport: on; AutoEdge: yes; AdminEdge: yes; EdgeDelay: 3
sec
Configured Root guard: on; Operational Root guard: off
Bpdu-guard: on

Ifindex: 201728256; Id: 8031; Role: Rootport; State:
Forwarding
Designated Port Id: 8f00; Port Priority: 128
Designated Bridge: 1000.0004.96d6.afce
Version: Rapid Spanning Tree Protocol - Received RSTP -
Sent RSTP
sec
Bpdu-guard: off


Discarding
Sent RSTP
sec
Bpdu-guard: off
Part 3: Clearing spanning tree-detected protocols

These commands force a spanning tree renegotiation with neighboring devices
on either all interfaces or on a specified interface.
3.1 Restart the spanning tree migration process on all interfaces.

G1-leaf1# clear spanning-tree detected-protocols
3.2 Restart the spanning tree migration process on a specific Ethernet

interface.
G1-leaf1# clear spanning-tree detected-protocols interface
ethernet 0/3
3.3 Restart the spanning tree migration process on a specific port channel
interface.
G1-leaf1# clear spanning-tree detected-protocols port-channel
12
Part 4: Debugging Spanning Tree

4.1 debug spanning-tree.
debug spanning-tree { all | bpdu [ rx | tx [ all | [ interface { ethernet

slot/port | port-channel number }
Eg:

G1-Spine2# debug spanning-tree bpdu tx interface ethernet 0/8

G1-Spine2# terminal monitor
G1-Spine2# no terminal monitor to stop terminal monitor
Part 5: Shutting down RSTP

5.1 Shut down STP globally and return to privileged EXEC mode.

G1-leaf1(conf-rstp)# shutdown
G1-leaf1(conf-rstp)# end
5.2 Shut down RSTP on a specific interface and return to privileged EXEC
mode.
G1-leaf1(config)# interface ethernet 0/50

G1-leaf1(conf-if-eth-0/50)# spanning-tree shutdown
G1-leaf1(conf-if-eth-0/50)# end
5.3 Shut down RSTP on a specific VLAN and return to privileged EXEC mode.
G1-leaf1(config-vlan-10)# spanning-tree shutdown
G1-leaf1(config-vlan-10)# end
End of Lab 4

LAB 5: LACP & LLDP Configuration

Lab Topology:
Objectives:
In this section you will configure Dynamic LAG’s between the L3 Switches.
Device Ports Vlan Port Ch. Device Ports Vlan Port Ch.
G1-Leaf1 E 0/3-4 Vlan 10 PO 1 G2-Leaf1 E 0/3-4 Vlan 10 PO 1

G1-Spine1 E 0/7-8 Vlan 40 PO 1 G2-Spine1 E 0/7-8 Vlan 40 PO 1
G1-Spine2 E 0/7-8 Vlan 40 PO 1 G2-Spine2 E 0/7-8 Vlan 40 PO 1
Note: Please do delete any previously configured port channel using “no interface
Port-channel XX”

Part 1: LACP Configuration
Note: If your device doesn’t have the corresponding vlan configured from the
previous lab, then use this command to create one.
G1-spine1# conf t
G1-Spine1(config)# vlan 40
G1-Spine1(config-vlan-40)# exit
1.1 Create a port channel by issuing the following commands.

G1-Spine1(config)# interface port-channel 1
1.2 Configure port channel as trunk port:

G1-spine1(config-Port-channel-1)# speed 10000
G1-spine1(config-Port-channel-1)# switchport
G1-spine1(config-Port-channel-1)# switchport mode trunk
G1-spine1(config-Port-channel-1)# switchport trunk allowed vlan
add 40
G1-spine1(config-Port-channel-1)# no shutdown
1.3 Add the interface ports to the port channel 1
G1-spine1(config-Port-channel-1)# int e 0/7-8
Note: Since these ports were used in last lab, switchport has to be disabled
G1-spine1(conf-if-eth-0/7-8)# no switchport
G1-spine1(conf-if-eth-0/7-8)# channel-group 1 mode active
1.4 Configuring the LACP timeout period

Specify the LACP timeout long period for the interface.
G1-spine1(conf-if-eth-0/7-8)# lacp timeout long

G1-spine1(conf-if-eth-0/7-8)# no shut
G1-spine1(conf-if-eth-0/7-8)#
Part 2: Verify Interface Configuration

2.1 Verify configuration of the port-channel and the physical
Interfaces

G1-spine1# show run interface port-channel 1

interface Port-channel 1
speed 10000
switchport
switchport trunk allowed vlan add 40
no shutdown
G1-spine1# show running-config int e 0/7-8

speed 10000
channel-group 1 mode active type standard
lacp timeout long
no shutdown

speed 10000
lacp timeout long
no shutdown
2.2 Enter show port-channel summary command to display brief

information of all port-channels.
G1-spine2# show port-channel summary
Flags: D - Down P - Up in port-channel (members)
U - Up (port-channel) * - Primary link in port-channel
S - Switched I - Insight Enabled
M - Not in use. Min-links not met
===== =============== ========== ===============
Group Port-channel Protocol Member ports
===== =============== ========== ===============
1 Po 1 (SU) LACP Eth 0/7 (P)
Eth 0/8 (P)
G1-Leaf1# show port-channel summary

Flags: D - Down P - Up in port-channel (members)
U - Up (port-channel) * - Primary link in port-channel
S - Switched I - Insight Enabled
M - Not in use. Min-links not met
===== =============== ========== ===============
Group Port-channel Protocol Member ports
===== =============== ========== ===============
1 Po 1 (SU) LACP Eth 0/3 (P)
Eth 0/4 (P)

2.3 Enter show interface port-channel 1 command to

display brief information of a specific port channel
G1-spine2# show interface port-channel 1
Port-channel 1 is up, line protocol is up
Hardware is AGGREGATE, address is 0004.96d6.aa23
Current address is 0004.96d6.aa23
Minimum number of links to bring Port-channel up is 1
MTU 1548 bytes
LineSpeed Actual : 80000 Mbit
Allowed Member Speed : 40000 Mbit
Priority Tag disable
Forward LACP PDU: Disable
Route Only: Disabled
Tag-type: 0x8100
FEC Mode - Disabled
Receive Statistics:
457 packets, 56448 bytes
Unicasts: 0, Multicasts: 454, Broadcasts: 0
64-byte pkts: 0, Over 64-byte pkts: 230, Over 127-byte
pkts: 228
Over 255-byte pkts: 0, Over 511-byte pkts: 0, Over 1023-
byte pkts: 0
Over 1518-byte pkts(Jumbo): 0
Runts: 0, Jabbers: 0, CRC: 0, Overruns: 0
Errors: 0, Discards: 0
Transmit Statistics:
860 packets, 82176 bytes
Unicasts: 0, Multicasts: 861, Broadcasts: 0
Underruns: 0
Errors: 0, Discards: 0
Rate info:
Input 0.000000 Mbits/sec, 0 packets/sec, 0.00% of line-rate
Output 0.000000 Mbits/sec, 0 packets/sec, 0.00% of line-
rate
Route-Only Packets Dropped: 0
Time since last interface status change: 00:55:00
2.4 Debugging LACP
Eg: To enable debugging of LACP PDUs for transmitted and received on a particular
interface:

G1-Spine2# debug lacp pdu rx interface ethernet 0/7

G1-Spine2# debug lacp pdu tx interface ethernet 0/7
G1-Spine2# debug lacp pdu rx interface all (on all interaces)

G1-Spine2# debug lacp pdu tx interface all
Use terminal monitor to check the packet information
Part 3: Verifying LLDP Configuration

.
Note: LLDP is pre-enabled and hence LLDP configuration can be verified using the
operational commands shown below
3.1 To Know about LLDP neighbours, use show lldp neighbor

command
G1-Leaf1# show lldp neighbors
Local Port Dead Interval Remaining Life Remote Port ID
Eth 0/3 120 96 Ethernet 0/3
Eth 0/4 120 96 Ethernet 0/4
Remote Port Descr Chassis ID Tx Rx System Name

Eth 0/3 609c.9fec.1200 246 246 G1-Leaf2
Eth 0/4 609c.9fec.1200 246 246 G1-Leaf2
3.2 Use show lldp statistics command to view LLDP interface

statistics related to Ports
G1-leaf1# show lldp statistics
LLDP Interface statistics for Eth 0/3
Frames transmitted: 253
Frames Aged out: 0
Frames Discarded: 0
Frames with Error: 0
Frames Recieved: 253
TLVs discarded: 0
TLVs unrecognized: 0
Frames Aged out: 0
Frames Discarded: 0
TLVs discarded: 0


Frames Aged out: 0
Frames Discarded: 0
TLVs discarded: 0
G1-spine1# show lldp statistics

Frames Aged out: 0
Frames Discarded: 0
TLVs discarded: 0
Frames Aged out: 0
Frames Discarded: 0
TLVs discarded: 0
Frames Aged out: 0
Frames Discarded: 0
TLVs discarded: 0
Frames Aged out: 1
Frames Discarded: 0
TLVs discarded: 0
Frames Aged out: 0
Frames Discarded: 0

TLVs discarded: 0
3.3 Debug LLDP:
3.3.1 : debug lldp dump
Syntax: debug lldp dump { all | [ ethernet slot/port ] [ both ] ] | [ detail

[ both | rx | tx ] }
Output will be displayed on the console, no terminal monitor is required

Eg: G1-leaf1# debug lldp dump ethernet 0/3
G1-leaf1# debug lldp dump all
3.3.2. debug lldp packet
Syntax: debug lldp packet { all | [ ethernet slot/port ] [ both ] ] | [

detail [ both | rx | tx ] }
To disable: no debug lldp packet { all | interface ethernet slot/port }
Eg: G1-leaf1# debug lldp packet interface ethernet 0/3 both

Use terminal monitor for display.
End of Lab 5

Lab 6: Configuring BGP (numbered

interfaces)
Lab Topology
Connectivity Information for Group-1:

Device AS ID Loopback 1 Loopback 2 Router ID
G1-Leaf1 AS: 64101 10.1.1.1/32 10.10.10.1/32 10.1.1.1
G1-Leaf2 AS: 64101 10.1.1.2/32 10.10.10.2/32 10.1.1.2
G1-Leaf3 AS: 64102 10.1.1.3/32 10.10.10.3/32 10.1.1.3
G1-Leaf4 AS: 64102 10.1.1.4/32 10.10.10.4/32 10.1.1.4
G1-Leaf5 AS: 64103 10.1.1.5/32 10.10.10.5/32 10.1.1.5
G1-Leaf6 AS: 64103 10.1.1.6/32 10.10.10.6/32 10.1.1.6
G1-Spine1 AS: 65101 10.1.1.7/32 10.10.10.7/32 10.1.1.7
G1-Spine2 AS: 65101 10.1.1.8/32 10.10.10.8/32 10.1.1.8

Device AS ID Eth 0/49 Eth 0/50 Eth 0/1 Eth 0/2 Eth 0/3 Eth 0/4 Eth 0/5 Eth 0/6
G1- AS: 64101 10.20.10.1/30 -- -- -- -- -- --

10.20.110.1/30
Leaf1
G1- AS: 64101 10.20.120.1/30 -- -- -- -- -- --

10.20.20.1/30
Leaf2
G1- AS: 64102 10.20.30.1/30 -- -- -- -- -- --

10.20.130.1/30
Leaf3
G1- AS: 64102 10.20.140.1/30 -- -- -- -- -- --

10.20.40.1/30
Leaf4
G1- AS: 64103 10.20.50.1/30 -- -- -- -- -- --

10.20.150.1/30
Leaf5
G1- AS:64103 10.20.160.1/30 -- -- -- -- -- --

10.20.60.1/30
Leaf6
G1- AS: 65101 -- -- 10.20.10.2/30

10.20.20.2/30 10.20.30.2/30 10.20.40.2/30 10.20.50.2/30 10.20.60.2/30
Spine1
G1- AS: 65101 -- -- 10.20.120.2/30

10.20.110.2/30 10.20.140.2/30 10.20.130.2/30 10.20.160.2/30 10.20.150.2/30
Spine2

G1-Leaf1 -- -- -- -- -- -- E0/49 E0/50
G1-Leaf2 -- -- -- -- -- -- E0/50 E0/49
G1-Leaf3 -- -- -- -- -- -- E0/49 E0/50
G1-Leaf4 -- -- -- -- -- -- E0/50 E0/49
G1-Leaf5 -- -- -- -- -- -- E0/49 E0/50
G1-Leaf6 -- -- -- -- -- -- E0/50 E0/49
G1-Spine1 E0/1 E0/2 E0/3 E0/4 E0/5 E0/6 -- --
G1-Spine2 E0/2 E0/1 E0/4 E0/3 E0/6 E0/5 -- --
Connectivity Information for Group-2:

G2-Leaf1 AS: 64201 10.11.1.1/32 10.110.10.1/32 10.11.1.1
G2-Leaf2 AS: 64201 10.11.1.2/32 10.110.10.2/32 10.11.1.2
G2-Leaf3 AS: 64202 10.11.1.3/32 10.110.10.3/32 10.11.1.3
G2-Leaf4 AS: 64202 10.11.1.4/32 10.110.10.4/32 10.11.1.4
G1-Leaf5 AS: 64203 10.11.1.5/32 10.110.10.5/32 10.11.1.5
G1-Leaf6 AS: 64203 10.11.1.6/32 10.110.10.6/32 10.11.1.6
G2-Spine1 AS: 65201 10.11.1.7/32 10.110.10.7/32 10.11.1.7
G2-Spine2 AS: 65201 10.11.1.8/32 10.110.10.8/32 10.11.1.8

G2- AS: 64201 10.120.10.1/30 -- -- -- -- -- --

10.120.110.1/30
Leaf1
G2- AS: 64201 10.120.120.1/30 -- -- -- -- -- --

10.120.20.1/30
Leaf2
G2- AS: 64202 10.120.30.1/30 -- -- -- -- -- --

10.120.130.1/30
Leaf3
G2- AS: 64202 10.120.140.1/30 -- -- -- -- -- --

10.120.40.1/30
Leaf4
G2- AS: 64203 10.120.50.1/30 -- -- -- -- -- --

10.120.150.1/30
Leaf5
G2- AS:64203 10.120.160.1/30 -- -- -- -- -- --

10.120.60.1/30
Leaf6
G2- AS: 65201 -- -- 10.120.10.2/30

10.120.20.2/30 10.120.30.2/30 10.120.40.2/30 10.20.50.2/30 10.20.60.2/30
Spine1
G2- AS: 65201 -- -- 10.120.120.2/30

10.120.110.2/30 10.120.140.2/30 10.120.130.2/30 10.120.160.2/30 10.120.150.2/30
Spine2

G2-Leaf1 -- -- -- -- -- -- E0/49 E0/50
G2-Leaf2 -- -- -- -- -- -- E0/50 E0/49
G2-Leaf3 -- -- -- -- -- -- E0/49 E0/50
G2-Leaf4 -- -- -- -- -- -- E0/50 E0/49
G2-Leaf5 -- -- -- -- -- -- E0/49 E0/50
G2-Leaf6 -- -- -- -- -- -- E0/50 E0/49
G2-Spine1 E0/1 E0/2 E0/3 E0/4 E0/5 E0/6 -- --
G2-Spine2 E0/2 E0/1 E0/4 E0/3 E0/6 E0/5 -- --
Part 1: Configuration on the devices
Note: Loopback 2, Router ID and Interfaces might have already been configured on your
device and if not present then follow these instructions. Also, if they have a different IP than
the one specified, use “no ip address XX.XX.XX.XX” to remove IP address
In whichever port you are issuing it.
1.1 LEAF-1:
Loopback 2 Configuration:
G1-leaf1(config)# int lo 2
G1-leaf1(config-Loopback-2)# ip address 10.10.10.1/32
G1-leaf1(config-Loopback-2)# no shutdown

Router ID Configuration:
G1-Leaf(config)# ip router-id 10.1.1.1
Configuration of Interfaces connected to Spine-1 & Spine-2:

G1-leaf1(config)# int e 0/49
G1-leaf1(conf-if-eth-0/49)# speed 10000
G1-leaf1(conf-if-eth-0/49)# ip address 10.20.10.1/30
G1-leaf1(conf-if-eth-0/49)# no shutdown
G1-leaf1(conf-if-eth-0/49)# int e 0/50

EBGP Configuration:
G1-Leaf1(config)# router bgp
G1-Leaf1(config-bgp-router)# local-as 64101
G1-Leaf1(config-bgp-router)# bfd interval 140 min-rx 125
multiplier 44
G1-Leaf1(config-bgp-router)# neighbor 10.20.110.2 remote-as
65101
G1-Leaf1(config-bgp-router)# neighbor 10.20.110.2 bfd
65101
G1-Leaf1(config-bgp-router)# address-family ipv4 unicast
G1-Leaf1(config-bgp-ipv4u)# redistribute connected
G1-Leaf1(config-bgp-ipv4u)# neighbor 10.20.10.2 allowas-in 1
G1-Leaf1(config-bgp-ipv4u)# maximum-paths 8
G1-Leaf1(config-bgp-ipv4u)# next-hop-recursion
G1-Leaf1(config-bgp-ipv4u)# !
G1-Leaf1(config-bgp-ipv4u)# address-family ipv6 unicast
G1-Leaf1(config-bgp-ipv6u)# end
IBGP Configuration:
G1-Leaf1(config-bgp-router)# neighbor 10.1.1.2 remote-as 64101
G1-Leaf1(config-bgp-router)# neighbor 10.1.1.2 update-source
loopback 1
G1-Leaf1(config-bgp-router)# redistribute connected

1.2 LEAF-2:
G1-Leaf2config)# ip router-id 10.1.1.2
Configuration of Interfaces Connected to Spine 1 and Spine 2:


BGP Configuration:
G1-leaf2(config)# router bgp
G1-leaf2(config-bgp-router)# local-as 64101
G1-leaf2(config-bgp-router)# bfd interval 140 min-rx 125
multiplier 44
G1-leaf2(config-bgp-router)# neighbor 10.20.120.2 remote-as
65101
G1-leaf2(config-bgp-router)# neighbor 10.20.120.2 bfd
65101
G1-leaf2(config-bgp-router)# address-family ipv4 unicast
G1-leaf2(config-bgp-ipv4u)# redistribute connected
G1-leaf2(config-bgp-ipv4u)# neighbor 10.20.20.2 allowas-in 1
G1-leaf2(config-bgp-ipv4u)# maximum-paths 8
G1-leaf2(config-bgp-ipv4u)# next-hop-recursion
G1-leaf2(config-bgp-ipv4u)# !
G1-leaf2(config-bgp-ipv4u)# address-family ipv6 unicast
IBGP Configuration:


loopback 1
1.3 Leaf-3:
G1-Leaf3(config)# ip router-id 10.1.1.3


BGP Configuration:
multiplier 44
65101
65101

IBGP Configuration:
loopback 1
1.4 LEAF-4:
G1-Leaf4(config)# ip router-id 10.1.1.4


BGP Configuration:
multiplier 44
65101
64101

G1-leaf4(config-bgp-ipv6u)#
IBGP Configuration:
loopback 1
1.5 LEAF-5:
G1-leaf5(config)# ip router-id 10.1.1.5


BGP Configuration:
multiplier 44
65101
64101


IBGP Configuration:
loopback 1
1.6 LEAF-6:


BGP Configuration:
multiplier 44


65101
64101
IBGP Configuration:
loopback 1
1.7 SPINE-1:
Loopback 2 configuration:
G1-spine1(config)# int lo 2
G1-spine1(config-Loopback-2)# ip address 10.10.10.7/32
G1-spine1(config-Loopback-2)# no shutdown
G1-spine1(config)# ip router-id 10.1.1.7
Configuration of Interfaces Connected to Leaf Devices:

G1-spine1(config)# int e 0/1
G1-spine1(conf-if-eth-0/1)# speed 10000
G1-spine1(conf-if-eth-0/1)# ip address 10.20.10.2/30
G1-spine1(conf-if-eth-0/1)# no shutdown
G1-spine1(conf-if-eth-0/1)# int e 0/2






BGP Configuration:
G1-Spine1# conf t
G1-spine1(config)# router bgp
G1-spine1(config-bgp-router)# local-as 65101
G1-spine1(config-bgp-router)# bfd interval 140 min-rx 125
multiplier 44
G1-spine1(config-bgp-router)# neighbor 10.20.10.1 remote-as
64101
G1-spine1(config-bgp-router)# neighbor 10.20.10.1 bfd
64101
64102
64102
64103
64103
G1-spine1(config-bgp-router)# address-family ipv4 unicast
G1-spine1(config-bgp-ipv4u)# redistribute connected

G1-spine1(config-bgp-ipv4u)# neighbor 10.20.50.1 allowas-in 1

G1-spine1(config-bgp-ipv4u)# maximum-paths 8
G1-spine1(config-bgp-ipv4u)# !
G1-spine1(config-bgp-ipv4u)# address-family ipv6 unicast
1.6 SPINE-2:
Loopback 2 configuration:
G1-Spine2(config)# int lo 2
G1-Spine2(config-Loopback-2)# ip address 10.10.10.8/32
G1-Spine2(config-Loopback-2)# no shutdown
G1-Spine2(config)# ip router-id 10.1.1.8
Configuration of Interfaces connected to Leaf Devices:

G1-Spine2(config)# int e 0/1
G1-Spine2(conf-if-eth-0/1)# speed 10000
G1-Spine2(conf-if-eth-0/1)# ip address 10.20.120.2/30
G1-Spine2(conf-if-eth-0/1)# no shutdown
G1-Spine2(conf-if-eth-0/1)# int e 0/2






BGP Configuration:
G1-Spine1# show running-config router bgp
multiplier 44
64101
64101
64102
64102
64103
64103
Part 2: Summary Commands

Note: Examples are given on a Spine followed by a leaf device:

2.1 Use show ip bgp summary command to view the establishment of BGP
Peers
A. Spine-1:
G1-spine1# show ip bgp summary
BGP4 Summary
Router ID: 10.1.1.7 Local AS Number: 65101
Confederation Identifier: not configured
Confederation Peers:
Maximum Number of IP ECMP Paths Supported for Load Sharing: 8
Number of Neighbors Configured: 6, UP: 3
Number of Routes Installed: 49, Uses 7693 bytes
Number of Routes Advertising to All Neighbors: 125 (24
entries), Uses 1824 bytes
Number of Attribute Entries Installed: 11, Uses 2101 bytes
*Dynamically created based on a listen range command
Dynamically created neighbors: 0/100(max)
A: Auto Discovered Neighbors using LLDP
Auto Neighbors Count: 0
'+': Data in InQueue '>': Data in OutQueue '-': Clearing
'*': Update Policy 'c': Group change 'p': Group change
Pending
'r': Restarting 's': Stale '^': Up before Restart '<': EOR
waiting
'$': Learning-Phase (for Delayed Route Calculation)
'#': RIB-in Phase
Neighbor Address AS# State Time Rt Filtered Sent ToSend
10.20.10.1 64101 ESTAB 0h2m16s 15 0 11 0
10.20.20.1 64101 ESTAB 0h2m16s 13 0 21 0
10.20.30.1 64102 ESTAB 0h2m15s 13 0 21 0
10.20.40.1 64102 ESTAB 0h0m1s 0 0 0 24
10.20.50.1 64103 ESTAB 0h0m0s 0 0 0 24
10.20.60.1 64103 ESTAB 0h0m1s 0 0 0 24
B. Leaf-1:
G1-Leaf1# show ip bgp summary

BGP4 Summary


Neighbor Address AS# State Time Rt Filtered Sent ToSend
10.20.10.2 65101 ESTAB 0h14m14s 11 0 15 0
10.20.110.2 65101 ESTAB 0h12m53s 17 0 13 0
Note:
You can test the setup by pinging from a pc to a different PC.
Also use tracert to trace the path of the ICMP packet over
different routers.
2.2 Use show ip bgp neighbours routes command to view the routes learnt
from BGP
A. Spine
G1-spine1# show ip bgp neighbors routes
Total number of BGP Neighbors: 6
1 IP Address: 10.20.10.1
Routes Accepted/Installed:15, Filtered/Kept:0, Filtered:0
Routes Selected as BEST Routes:10
BEST Routes not Installed in IP Forwarding Table:0
Unreachable Routes (no IGP Route for NEXTHOP):0
History Routes:0
NLRIs Received in Update Message:15, Withdraws:0 (0),

Replacements:0
NLRIs Discarded due to
Maximum Prefix Limit:0, AS Loop:0
Maximum Add-paths per Prefix per Peer Limit:0
Invalid Nexthop:0, Invalid Nexthop Address:0.0.0.0
Invalid Confed aspath:0, maxas-limit aspath:0
Duplicated Originator_ID:0, Cluster_ID:0
Routes Advertised:11, To be Sent:0, To be Withdrawn:0

NLRIs Sent in Update Message:11, Withdraws:0, Replacements:0
Peer Out of Memory Count for:

Receiving Update Messages:0, Accepting Routes(NLRI):0
Attributes:0, Outbound Routes(RIB-out):0 Outbound Routes
Holder:0

2 IP Address: 10.20.20.1
History Routes:0

Replacements:0


Holder:0
3 IP Address: 10.20.30.1
History Routes:0

Replacements:0




Holder:0
4 IP Address: 10.20.40.1
History Routes:0

Replacements:0


Holder:0
<\Truncated>
B. Leaf:
G1-Leaf1# show ip bgp neighbors routes
Total number of BGP Neighbors: 2
1 IP Address: 10.20.10.2
History Routes:0

Replacements:0



Holder:0
2 IP Address: 10.20.110.2
History Routes:0

Replacements:0


Holder:0
2.3 Other Useful Commands While Debugging BGP
1) show ip bgp attribute-entries : Displays BGP4 route-attribute entries that

are stored in device memory
2) show ip bgp dampened-paths : To display all dampened Routes
3) show ip bgp filtered-routes 10.20.110.2 prefix-list
myprefixlist: Displays BGP4 filtered routes that are received from a neighbor or peer
group.
4) show ip bgp neighbors 10.20.110.2: for a detailed information of a
specific neighbor.
End of Lab 6

Lab 7: Configuring BGP (unnumbered

interfaces)
Lab Topology:
G1-Leaf1 AS: 64101 10.1.1.1/32 10.10.10.1/32 10.1.1.1
G1-Leaf2 AS: 64101 10.1.1.2/32 10.10.10.2/32 10.1.1.2
G1-Leaf3 AS: 64102 10.1.1.3/32 10.10.10.3/32 10.1.1.3
G1-Leaf4 AS: 64102 10.1.1.4/32 10.10.10.4/32 10.1.1.4
G1-Leaf5 AS: 64103 10.1.1.5/32 10.10.10.5/32 10.1.1.5
G1-Leaf6 AS: 64103 10.1.1.6/32 10.10.10.6/32 10.1.1.6
G1-Spine1 AS: 65101 10.1.1.7/32 10.10.10.7/32 10.1.1.7
G1-Spine2 AS: 65101 10.1.1.8/32 10.10.10.8/32 10.1.1.8
Table: Loopback Interfaces and Router ID’s for Group-1
G2-Leaf1 AS: 64201 10.11.1.1/32 10.110.10.1/32 10.11.1.1
G2-Leaf2 AS: 64201 10.11.1.2/32 10.110.10.2/32 10.11.1.2
G2-Leaf3 AS: 64202 10.11.1.3/32 10.110.10.3/32 10.11.1.3
G2-Leaf4 AS: 64202 10.11.1.4/32 10.110.10.4/32 10.11.1.4
G2-Leaf5 AS: 64203 10.11.1.5/32 10.110.10.5/32 10.11.1.5
G2-Leaf6 AS: 64203 10.11.1.6/32 10.110.10.6/32 10.11.1.6

G2-Spine1 AS: 65201 10.11.1.7/32 10.110.10.7/32 10.11.1.7
G1-Spine2 AS: 65201 10.11.1.8/32 10.110.10.8/32 10.11.1.8
Table: Loopback Interfaces and Router ID’s for Group-2
G1-Leaf1 AS: 64101 10.20.10.1/30 Un Numbered -- -- -- -- -- --
G1-Leaf2 AS: 64101 Un Numbered 10.20.20.1/30 -- -- -- -- -- --
G1-Leaf4 AS: 64102 Un Numbered 10.20.40.1/30 -- -- -- -- -- --
G1-Leaf6 AS:64103 Un Numbered 10.20.60.1/30 -- -- -- -- -- --
G1- AS: 65101 -- -- 10.20.10.2/30 10.20.20.2/30 10.20.30.2/30 10.20.40.2/30 10.20.50.2/30 10.20.60.2/30

Spine1
G1- AS: 65101 -- -- Un Numbered Un Numbered Un Numbered Un Numbered Un Numbered Un Numbered

Spine2
Table: Physical Interface Information for Group-1 device
AS: 64101 10.120.10.1/3 Un -- -- -- -- -- --

G2-Leaf1
0 Numbered
AS: 64101 Un Numbered 10.120.20.1 -- -- -- -- -- --

G2-Leaf2
/30
AS: 64102 10.120.30.1/3 Un -- -- -- -- -- --

G2-Leaf3
0 Numbered
AS: 64102 Un Numbered 10.120.40.1 -- -- -- -- -- --

G2-Leaf4
/30
AS: 64103 10.120.50.1/3 Un -- -- -- -- -- --

G2-Leaf5
0 Numbered
AS:64103 Un Numbered 10.120.60.1 -- -- -- -- -- --

G2-Leaf6
/30
G2- AS: 65101 -- -- 10.120.10.2/30 10.120.20.2/30 10.120.30.2/30 10.120.40.2/30 10.120.50.2/30 10.120.60.2/30

Spine1
G2- AS: 65101 -- -- Un Numbered Un Numbered Un Numbered Un Numbered Un Numbered Un Numbered

Spine2
Table: Physical Interface Information for Group-2 device

Note: Since, this is a continuation of previous lab, first configure unnumbered interfaces and then
establish EBGP on un-numbered interface connected devices
Part 1: Configure unnumbered interfaces from the leaf devices to spine 2

1.1 Delete the IP addresses configured on the interfaces specified in the table below
and configure the unnumbered interfaces as given below.
From Device To Device Interface connected IP Address to configure
Leaf-1 Spine-2 E 0/50 Unnumbered

From Device To Device Interface connected IP Address to configure
Spine-2 Leaf-1 E 0/2 Unnumbered


Spine 2 Leaf-5 E 0/6 Unnumbered
A) LEAF-1:
G1-Leaf1(config)# int e 0/50

G1-Leaf1(conf-if-eth-0/50)# no ip address
G1-Leaf1(conf-if-eth-0/50)# ip unnumbered loopback 1
G1-Leaf1(conf-if-eth-0/50)# no shut
B) LEAF-2:


C) LEAF-3:

D) LEAF-4:

E) LEAF-5:

F) LEAF-6:

G) SPINE-1:
No Configuration changes. Keep the BGP peering with interfaces configured with IP
addresses
H) SPINE-2:
G1-spine2(config)# int e 0/1-6

G1-spine2(conf-if-eth-0/1-6)# no ip address
G1-spine2(conf-if-eth-0/1-6)# ip unnumbered loopback 1
G1-spine2(conf-if-eth-0/1-6)# no shut

Part 2: Establishing EBGP on un-numbered interface

connected devices
2.1 LEAF-1:
BGP Configuration:
multiplier 44
G1-Leaf1(config-bgp-router)# neighbor 10.1.1.8 ebgp-multihop 2
G1-leaf1(config-bgp-router)# neighbor 10.1.1.8 update-source
loopback 1
65101
G1-Leaf1(config-bgp-ipv6u)# end
2.2 LEAF-2:
BGP Configuration:
G1-leaf2(config)# no router bgp
multiplier 44
G1-leaf2(config-bgp-router)# neighbor 10.1.1.8 remote-as 65101
G1-leaf2(config-bgp-router)# neighbor 10.1.1.8 ebgp-multihop 2
loopback 1
65101


2.3 LEAF-3:
BGP Configuration:
G1-Leaf3(config)# no router bgp
multiplier 44
loopback 1
65101
2.4 LEAF-4:
BGP Configuration:
multiplier 44


loopback 1
65101
2.5 Leaf-5:
BGP Configuration:
multiplier 44
loopback 1
65101
2.6 Leaf-6:

BGP Configuration:
multiplier 44
loopback 1
65101
2.7 SPINE-2:
BGP Configuration:
G1-spine2# conf t
G1-spine2(config)# no router bgp
multiplier 44
G1-spine2(config-bgp-router)# neighbor 10.1.1.1 remote-as 64101
G1-spine2(config-bgp-router)# neighbor 10.1.1.1 ebgp-multihop 2
G1-spine2(config-bgp-router)# neighbor 10.1.1.1 update-source
loopback 1
loopback 1


loopback 1
loopback 1
loopback 1
loopback 1
Part 3: Veryfying BGP Configuration

2.1 Use show ip bgp summary command to view the establishment of BGP
Peers
A) Spine-2
G1-spine2# show ip bgp summary

BGP4 Summary


'+': Data in InQueue '>': Data in OutQueue '-': Clearing
'*': Update Policy 'c': Group change 'p': Group change
Pending
'r': Restarting 's': Stale '^': Up before Restart '<': EOR
waiting
'$': Learning-Phase (for Delayed Route Calculation)
'#': RIB-in Phase
Neighbor Address AS# State Time Rt:Accepted Sent
10.1.1.1 64101 ESTAB 2h22m31s 9 11
10.1.1.2 64101 ESTAB 2h22m30s 9 12
10.1.1.3 64102 ESTAB 2h22m19s 3 12
10.1.1.4 64102 ESTAB 2h22m30s 3 12
10.1.1.5 64103 ESTAB 2h22m19s 3 12
10.1.1.6 64103 ESTAB 2h22m30s 3 12
Note: Even after doing everything correctly, if the state says CONN, then use
these commands to reset the connections
copy running-config startup-config
reload
B) Leaf-4
G1-leaf4# show ip bgp summary

G1-Leaf3# show ip bgp summary
BGP4 Summary

Neighbor Address AS# State Time Rt: Filtered Sent

10.1.1.8 65101 ESTAB 0h10m 7s 2 0 20
10.20.30.2 65101 ESTAB 1h46m 4s 20 0 5
2.2 Use show ip bgp routes command to view the routes learnt from BGP
G1-spine2# show ip bgp routes
G1-leaf4# show ip bgp routes

3.3 Other Useful Commands While Debugging BGP
show ip bgp attribute-entries : Displays BGP4 route-attribute entries that are

stored in device memory
show ip bgp dampened-paths : To display all dampened Routes
show ip bgp neighbors 10.20.110.2: For a Detailed Summary of a Particualr
neighbor.
End of Lab 7

Lab 8: Configuring BGP EVPN

Lab Topology
Part-1: Configuring EVPN peering using VXLAN

encapsulation
1.1 Leaf Devices:
Configure l2vpn peering on all the leaf devices(G1-Leaf1, G1-Leaf2, G1-Leaf3,
G1-Leaf4, G1-Leaf5, G1-Leaf6) to both the spine devices

G1-leaf1(config-bgp-router)# address-family l2vpn evpn
G1-leaf1(config-bgp-evpn)# neighbor 10.1.1.8 encapsulation
vxlan
G1-leaf1(config-bgp-evpn)# neighbor 10.1.1.8 next-hop-unchanged
G1-leaf1(config-bgp-evpn)# neighbor 10.1.1.8 activate
1.2 Spine-2:
G1-Spine2(config-bgp-router)# router bgp

G1-Spine2(config-bgp-router)# address-family l2vpn evpn
G1-Spine2(config-bgp-evpn)# retain route-target all
G1-Spine2(config-bgp-evpn)# neighbor 10.1.1.1 encapsulation
vxlan
G1-Spine2(config-bgp-evpn)# neighbor 10.1.1.1 next-hop-
unchanged

G1-Spine2(config-bgp-evpn)# neighbor 10.1.1.1 activate

vxlan
unchanged
vxlan
unchanged
vxlan
unchanged
vxlan
unchanged
vxlan
unchanged
Part-2: Summary Commands
2.1 Use show ip bgp summary to view the establishment of BGP peers
A) Leaf-2:

B) Spine-2:
2.2 Use show ip bgp routes to view the routes learnt from BGP.
A) Spine-1:


B) Leaf-2:
2.3 Use show bgp evpn summary command to view the establishment of
BGP EVPN peers
A) Leaf-1:
Part-3: Configuring BGP EVPN Instance

3.1 Configure BGP EVPN Instance on all Leaf Devices as given below
Add the VLANs in EVPN Instance as per the table given below
Device VLAN Device VLAN

G1-Leaf1 100 G2-Leaf1 100

G1-leaf1(config)# evpn evpn1

G1-leaf1(config-evpn-evpn1)# route-target both auto
ignore-as
G1-leaf1(config-evpn-evpn1)# rd auto
G1-leaf1(config-evpn-evpn1)# vlan add 100
G1-leaf1(config-evpn-evpn1)# !
3.2 Configure Overlay gateway as per the table given below.
Device overlay-gateway Device overlay-gateway

G1-Leaf1 PoD1 G2-Leaf1 PoD1
G1-leaf1(config)# overlay-gateway PoD1

G1-leaf1(config-overlay-gw-PoD1)# type layer2-extension
G1-leaf1(config-overlay-gw-PoD1)# ip interface Loopback 1
G1-leaf1(config-overlay-gw-PoD1)# map vni auto
G1-leaf1(config-overlay-gw-PoD1)# activate
G1-leaf1(config-overlay-gw-PoD1)# !
3.3 Configure BGP EVPN tunnels between the Leaf devices as given in the
table below
Device EVPN Tunnel 1 EVPN Tunnel 2

G1-Leaf1 G1-Leaf3 (64102) G1-Leaf5 (64103)

multiplier 44


G1-leaf1(config-bgp-router)# address-family l2vpn evpn

vxlan
vxlan
3.4 . Please run operational and monitoring commands to verify the establishment
of evpn tunnels.
G1-leaf1# show bgp evpn summary

BGP4 Summary
Number of Routes Advertising to All Neighbors: 11 (4 entries),
Uses 208 bytes
Neighbor Address AS# State Time Rt:Accepted Filtered Sent ToSend
10.1.1.3 64102 ESTAB 11h41m43s 1 3 3 0
10.1.1.5 64103 ESTAB 11h41m43s 1 3 3 0
10.1.1.8 65101 ESTAB 11h42m 6s 0 0 0 4
G1-leaf1# show tunn status

Tnlid Adm state Oper state BFD state Tnl dest IP VeId Ve state
========= ========= ========== ========= =========== =========
61441 up up 10.1.1.3 NA NA
61441 up up 10.1.1.5 NA NA
End of Lab 8

Lab 9: MCT Configuration

Objectives:
In this lab exercise, you will perform the tasks of configuring and verifying the
operation of Multi-Chassis Trunking (MCT)
• Configure MCT on SLX devices
• Verify the operation of MCT using SLX-OS CLI
Lab Topology:

Device Port Channel 1 Ve 4090 Peer Loopback 1 Peer IP address
G1-leaf1 E 0/3 & E 0/4 10.1.1.21/30 10.1.1.2/32 10.1.1.22
G1-leaf2 E 0/3 & E 0/4 10.1.1.22/30 10.1.1.1/32 10.1.1.21
G1-leaf3 E 0/3 & E 0/4 10.1.1.26/30 10.1.1.4/32 10.1.1.25
G1-leaf4 E 0/3 & E 0/4 10.1.1.25/30 10.1.1.3/32 10.1.1.26
G1-Leaf5 E 0/3 & E 0/4 10.1.1.30/30 10.1.1.6/32 10.1.1.29
G1-Leaf6 E 0/3 & E 0/4 10.1.1.29/30 10.1.1.5/32 10.1.1.30
Device Port Channel 1 Ve 4090 Peer Loopback 1 Peer IP address
G2-leaf1 E 0/3 & E 0/4 10.11.1.21/30 10.11.1.2/32 10.11.1.22
G2-leaf2 E 0/3 & E 0/4 10.11.1.22/30 10.11.1.1/32 10.11.1.21
G2-leaf3 E 0/3 & E 0/4 10.11.1.25/30 10.11.1.4/32 10.11.1.26
G2-leaf4 E 0/3 & E 0/4 10.11.1.26/30 10.11.1.3/32 10.11.1.25
G2-Leaf5 E 0/3 & E 0/4 10.11.1.29/30 10.11.1.6/32 10.11.1.30
G2-Leaf6 E 0/3 & E 0/4 10.11.1.30/30 10.11.1.5/32 10.11.1.29
Table: Interface Information for MCT Lab

Part-1: ICL Port-channel Configuration
1.1 Configuring Port Channel interface
Peer 1:
G1-Leaf1# conf t
G1-Leaf1(config)# interface Port-channel 1
G1-Leaf1(config-Port-channel-1)# no shutdown
Peer 2:
G1-Leaf2# conf t
1.2 Adding Ethernet interfaces (e 0/3 and e 0/4) to Port Channel
Peer 1:
G1-Leaf1(config-Port-channel-1)# interface Ethernet 0/3
G1-Leaf1(conf-if-eth-0/3)# channel-group 1 mode active type
standard
G1-Leaf1(conf-if-eth-0/3)# no shutdown
G1-Leaf1(conf-if-eth-0/3)# interface Ethernet 0/4
standard
Peer 2:
standard
G1-Leaf2(conf-if-eth-0/3)# interface Ethernet 0/4
standard
Part-2: Configuring Cluster Control VLAN

Peer 1:
G1-Leaf1(config)# vlan 4090

G1-Leaf1(config-vlan-4090)# router-interface Ve 4090
G1-Leaf1(config-vlan-4090)# interface Ve 4090
G1-Leaf1(config-if-Ve-4090)# ip address 10.1.1.21/30
G1-Leaf1(config-if-Ve-4090)# no shutdown
Note: Configure static route pointing to the loopback 1 address of MCT peer with next hop ip
address of cluster control vlan. Information on next hop and Loopback 1 addresses is provided
in the table
G1-Leaf1(config-if-Ve-4090)# ip route 10.1.1.2/32 10.1.1.22
Peer 2:
G1-Leaf2(config)# vlan 4090

G1-Leaf2(config-vlan-4090)# router-interface Ve 4090
G1-Leaf2(config-vlan-4090)# interface Ve 4090
G1-Leaf2(config-if-Ve-4090)# ip address 10.1.1.22/30
G1-Leaf2(config-if-Ve-4090)# no shutdown
G1-Leaf2(config-if-Ve-4090)# ip route 10.1.1.1/32 10.1.1.21
Part-3: Configuring MCT Cluster

Peer 1:
G1-Leaf1(config-Port-channel-1)# cluster MCT1 1

G1-Leaf1(config-cluster-1)# peer-interface Port-channel 1
G1-Leaf1(config-cluster-1)# peer 10.1.1.22
G1-Leaf1(config-cluster-1)# deploy
2019/04/07-19:44:31, [MCT-1001], 107782,, INFO, SLX9140,
Cluster 1/MCT1 is up.
G1-Leaf1(config-cluster-1)# evpn default
G1-Leaf1(config-evpn-default)# route-target both auto ignore-as
G1-Leaf1(config-evpn-default)# rd auto
G1-Leaf1(config-evpn-default)# vlan add 1-4088
Peer 2:
G1-Leaf2(config-Port-channel-1)# cluster MCT1 1

G1-Leaf2(config-cluster-1)# peer-interface Port-channel 1

G1-Leaf2(config-cluster-1)# peer 10.1.1.21

G1-Leaf2(config-cluster-1)# deploy
2019/04/07-19:44:31, [MCT-1001], 107782,, INFO, SLX9140,
Cluster 1/MCT1 is up.
G1-Leaf2(config-cluster-1)# evpn default
G1-Leaf2(config-evpn-default)# route-target both auto ignore-as
G1-Leaf2(config-evpn-default)# rd auto
G1-Leaf2(config-evpn-default)# vlan add 1-4088
Part-4: Configuring iBGP peering with MCT Peer
Peer 1:

G1-Leaf1(config-bgp-router)#neighbor 10.1.1.22 remote-as 64101
loopback 1
G1-Leaf1(config-bgp-router)#address-family l2vpn evpn
G1-Leaf1(config-bgp-evpn)#neighbor 10.1.1.22 encapsulation nsh
G1-Leaf1(config-bgp-evpn)#neighbor 10.1.1.22 activate
G1-Leaf1(config-bgp-evpn)#do clear ip bgp neighbor all
Peer 2:

G1-Leaf2(config-bgp-router)#neighbor 10.1.1.21 remote-as 64101
loopback 1
G1-Leaf2(config-bgp-router)#address-family l2vpn evpn
G1-Leaf2(config-bgp-evpn)#neighbor 10.1.1.21 encapsulation nsh
G1-Leaf2(config-bgp-evpn)#neighbor 10.1.1.21 activate
G1-Leaf2(config-bgp-evpn)#do clear ip bgp neighbor all
Part-5: Configuring MCT Client interface
Peer 1:

G1-Leaf1(config-Port-channel-11)# speed 1000
G1-Leaf1(config-Port-channel-11)# switchport
G1-Leaf1(config-Port-channel-11)# switchport mode trunk

Note: The cluster client interface in all the lab SLX devices is connected on port e 0/32 to cluster
client device i.e. XOS switch. Please refer to lab topology for further clarification.

standard
Peer 2:
G1-Leaf2(config-Port-channel-11)# speed 1000
G1-Leaf2(config-Port-channel-11)# switchport
G1-Leaf2(config-Port-channel-11)# switchport mode trunk
standard
Part-6: Configuring cluster Client to MCT Cluster
Peer 1:
G1-Leaf1(conf-if-eth-0/32)#cluster MCT1 1
G1-Leaf1(config-cluster-1)#client G1-XOS 1
G1-Leaf1(config-cluster-client-1)#client-interface Port-channel
11
G1-Leaf1(config-cluster-client-1)#deploy
G1-Leaf1(config-cluster-client-1)#
Peer 2:
G1-Leaf2(conf-if-eth-0/32)#cluster MCT1 1
G1-Leaf2(config-cluster-1)#client G1-XOS 1
G1-Leaf2(config-cluster-client-1)#client-interface Port-channel
11
G1-Leaf2(config-cluster-client-1)#deploy
G1-Leaf2(config-cluster-client-1)#
Part-7: Configuring cluster Client switch i.e XOS switch
7.1 Login to XOS Switch using the credentials given in lab guide
information section.

login: admin
password:
ExtremeXOS
Copyright (C) 1996-2013 Extreme Networks. All rights reserved.
Protected by US Patent Nos: 6,678,248; 6,104,700; 6,766,482;
6,618,388; 6,034,957; 6,859,438; 6,912,592; 6,954,436;
<Truncated/>
==============================================================
Press the <tab> or '?' key at any time for completions.

Remember to save your configuration changes.
* Group 1 XOS.1 #
Note: Please login using the management IP address of XOS switch so that multiple users can
connect and configure the switch as needed
7.2 On XOS switch configure port sharing group using the ports
given in the table
Peer 1:
* Group 1 XOS.1 # enable sharing 21 grouping 21,22 lacp
Peer 2:
* Group 1 XOS.1 # enable sharing 22 grouping 21,22 lacp
The following output is displayed

Warning: Any config on the master port is lost (STP, IGMP
Filter, IGMP Static Group, MAC-Security, CFM, TRILL, etc.)
* Group 1 XOS.2 #
Cluster Device G1-XOS Port

G1-Leaf1 21
G1-Leaf2 22
G1-Leaf3 23
G1-Leaf4 24
G1-Leaf5 25
G1-Leaf6 26

Cluster Device G2-XOS Port

G2-Leaf1 21
G2-Leaf2 22
G2-Leaf3 23
G2-Leaf4 24
G2-Leaf5 25
G2-Leaf6 26

Part-8: Veryfying Configuration
8.1 Use show cluster command to verify the MCT cluster status
8.2 Use show cluster 1 client command to verify the cluster client
status
G1-leaf1# show cluster 1 client
Client Info:
============
Name Id Label(Lo/Re) Interface Local/Remote State
---- -- ------------ --------- --------------
G1-XOS 1 1025/ 1025 Port-channel 11 Up / Up
8.3 Use show cluster 1 client command to verify the cluster client
status
G1-leaf1# show cluster 1 client 1
Client Info:
============
Client : G1-XOS
Client-id : 1
Client state : Deployed
Interface state : Up

Interface : Port-channel 11
Vlans : 1
Bridge Domains :
Number of DF Vlans : 1
Elected DF for vlans : 1
Number of DF Bridge Domains : 0
Elected DF for Bridge Domains :
END of Lab 9

Appendix A: OSPF Configuration Lab

In this lab session, you will be configuring OSPF using a Multi-area Topology across
all the switches.
Clean up before this lab:
This operation will modify your startup configuration. Do you want

to continue? [y/n]:y
WARN: "reload system" is required to have configuration changes
take effect!
2020/06/12-17:58:13, [DCM-1103], 6976,, INFO, SLX9140, Copy

default-config to startup-config operation successful on this
node.
G1-Leaf1# reload
Warning: Unsaved configuration will be lost. Please run

`copy running-config startup-config` to save the current
configuration if not done already.

3) Set the host-name:
SLX(config)# switch-attributes host-name G1-leaf1
4) Check if Management IP is already configured.

G1-Leaf1# show running-config interface Management 0
If it isn’t, follow these steps to configuring Management IP:
G1-leaf1(config)# interface Management 0

G1-leaf1(config-Management-0)# no ip address dhcp
G1-leaf1(config-Management-0)# ip address 10.140.8.101/24

G1-leaf1(config-Management-0)# no shutdown
G1-leaf1(config-Management-0)# exit
5) Also, Configure Loopback I addresses as specified in Lab: 2.
G1-leaf1(config)# interface loopback 1

G1-leaf1(config-loopback-1)# no ip address dhcp
G1-leaf1(config-loopback-1)# ip address 10.1.1.1/32
G1-leaf1(config-loopback-1)# no shutdown
Note: The configuration details such as Management IP and loopback address information are
available in Lab 2 for your assigned device. Also, Refer to Lab 2 for clear explanation of
commands and usage
Lab Topology:
Device Loopback 2 Router ID Area
G1-Leaf1 10.10.10.1/32 10.1.1.1 1
G1-Leaf2 10.10.10.2/32 10.1.1.2 1
G1-Leaf3 10.10.10.3/32 10.1.1.3 2
G1-Leaf4 10.10.10.4/32 10.1.1.4 2
G1-Leaf5 10.10.10.5/32 10.1.1.5 3
G1-Leaf6 10.10.10.6/32 10.1.16 3
G1-Spine1 10.10.10.7/32 10.1.1.7 0,1,2,3
G1-Spine2 10.10.10.8/32 10.1.1.8 0,1,2,3
Table: Loopback 2 and Router ID information

G2-Leaf1 10.110.10.1/32 10.11.1.1 1
G2-Leaf2 10.110.10.2/32 10.11.1.2 1
G2-Leaf3 10.110.10.3/32 10.11.1.3 2
G2-Leaf4 10.110.10.4/32 10.11.1.4 2
G2-Leaf5 10.110.10.5/32 10.11.1.5 3
G2-Leaf6 10.110.10.6/32 10.11.1.6 3
G2-Spine1 10.110.10.7/32 10.11.1.7 0,1,2,3
G2-Spine2 10.110.10.8/32 10.11.1.8 0,1,2,3
Table: Loopback 2 and Router ID information

G1-Leaf1 -- -- -- -- -- -- E0/49 E0/50
G1-Leaf2 -- -- -- -- -- -- E0/50 E0/49
G1-Leaf3 -- -- -- -- -- -- E0/49 E0/50
G1-Leaf4 -- -- -- -- -- -- E0/50 E0/49
G1-Leaf5 -- -- -- -- -- -- E0/49 E0/50
G1-Leaf6 -- -- -- -- -- -- E0/50 E0/49
G1-Spine1 E0/1 E0/2 E0/3 E0/4 E0/5 E0/6 -- --
G1-Spine2 E0/2 E0/1 E0/4 E0/3 E0/6 E0/5 -- --
Table: Connectivity Diagram - Group 1 Switches

G2-Leaf1 -- -- -- -- -- -- E0/49 E0/50
G2-Leaf2 -- -- -- -- -- -- E0/50 E0/49
G2-Leaf3 -- -- -- -- -- -- E0/49 E0/50
G2-Leaf4 -- -- -- -- -- -- E0/50 E0/49
G2-Leaf5 -- -- -- -- -- -- E0/49 E0/50
G2-Leaf6 -- -- -- -- -- -- E0/50 E0/49
G2-Spine1 E0/1 E0/2 E0/3 E0/4 E0/5 E0/6 -- --
G2-Spine2 E0/2 E0/1 E0/4 E0/3 E0/6 E0/5 -- --
Table: Connectivity Diagram - Group 2 Switches

Device Eth 0/49 Eth 0/50 Eth 0/1 Eth 0/2 Eth 0/3 Eth 0/4 Eth 0/5 Eth 0/6
G1- 10.20.10.1/30 -- -- -- -- -- --
10.20.110.1/30
Leaf1
G1- 10.20.120.1/30 -- -- -- -- -- --
10.20.20.1/30
Leaf2
G1- 10.20.30.1/30 -- -- -- -- -- --
10.20.130.1/30
Leaf3
G1- 10.20.140.1/30 -- -- -- -- -- --
10.20.40.1/30
Leaf4
G1- 10.20.50.1/30 -- -- -- -- -- --
10.20.150.1/30
Leaf5
G1- 10.20.160.1/30 -- -- -- -- -- --
10.20.60.1/30
Leaf6
G1- -- -- 10.20.10.2/30
10.20.20.2/30 10.20.30.2/30 10.20.40.2/30 10.20.50.2/30 10.20.60.2/30
Spine1
G1- -- -- 10.20.120.2/30
10.20.110.2/30 10.20.140.2/30 10.20.130.2/30 10.20.160.2/30 10.20.150.2/30
Spine2
Table: Information of IP Addresses to be configured on corresponding physical interfaces
Device Eth 0/49 Eth 0/50 Eth 0/1 Eth 0/2 Eth 0/3 Eth 0/4 Eth 0/5 Eth 0/6
G2- 10.120.10.1/30 -- -- -- -- -- --
10.120.110.1/30
Leaf1
G2- 10.120.120.1/30 -- -- -- -- -- --
10.120.20.1/30
Leaf2
G2- 10.120.30.1/30 -- -- -- -- -- --
10.120.130.1/30
Leaf3
G2- 10.120.140.1/30 -- -- -- -- -- --
10.120.40.1/30
Leaf4
G2- 10.120.50.1/30 -- -- -- -- -- --
10.120.150.1/30
Leaf5
G2- 10.120.160.1/30 -- -- -- -- -- --
10.120.60.1/30
Leaf6
G2- -- -- 10.120.10.2/30
10.120.20.2/30 10.120.30.2/30 10.120.40.2/30 10.20.50.2/30 10.20.60.2/30
Spine1
G2- -- -- 10.120.120.2/30
10.120.110.2/30 10.120.140.2/30 10.120.130.2/30 10.120.160.2/30 10.120.150.2/30
Spine2
Table: Information of IP Addresses to be configured on corresponding physical interfaces
Please follow the Lab Topology Diagram, Loopback and Ethernet IP address
information given to configure the assigned device as per stated topology. Ensure you
understand which device you are responsible for configuring. Please consult with your
instructor if you are unsure!
Note: An Example Spine Configuration and Leaf Configuration have been explained below. Use
the information provided above to configure the assigned device.

Part 1: OSPF configuration on a Spine: (For Eg: Spine-2)

3.6 Configure area using router ospf command.
Spine:
G1-spine2# configure terminal

G1-spine2(config)# router ospf
G1-spine2(config-router-ospf-vrf-default-vrf)# area 0
1.2 Configure loopback 2 and router ID’s.
Spine:
G1-spine2(config)# int lo 2
G1-spine2(config-Loopback-2)# ip address 10.10.10.8/32
G1-spine2(config-Loopback-2)# ip ospf area 0
G1-spine2(config-Loopback-2)# no shutdown
G1-spine2(config-Loopback-2)# exit
G1-spine2(config)# ip router-id 10.1.1.8
1.3 Configure Ethernet Ports:
Spine:
G1-spine2(config)# int e 0/1

G1-spine2(conf-if-eth-0/1)# ip ospf area 1






Part 2: OSPF configuration on a Leaf: (For Eg: Leaf-2)

2.3 Configure area using router ospf command.

G1-leaf1(config)# router ospf
G1-leaf1(config-router-ospf-vrf-default-vrf)# area 1
G1-leaf1(config-router-ospf-vrf-default-vrf)# exit
2.4 Configure loopback 2 and router ID’s.
G1-leaf1(config-Loopback-2)# ip ospf area 1
G1-leaf1(config-Loopback-2)# exit
2.5 Configure Ethernet Ports on the Leaf-2:
G1-leaf1(conf)# int e 0/49

G1-leaf1(conf-if-eth-0/49)# ip ospf area 1

G1-leaf1(conf-if-eth-0/50)# ip ospf area 1
Part 3: Show Commands to verify configuration

3.1 Enter the show ip ospf interface command to display OSPF interface
information
G1-spine2# show ip ospf interface

G1-Spine2# show ip ospf interface
Ethernet 0/5 admin up, oper up

IP Address 10.20.150.2, Area 3
BFD is disabled
Database Filter: Not Configured
State DR, Pri 1, Cost 1, Options ------E-, Type broadcast
Events 2
Timers(sec): Transmit 1, Retrans 5, Hello 10, Dead 40
DR: Router ID 10.1.1.8 Interface Address 10.20.150.2
BDR: Router ID 0.0.0.0 Interface Address 0.0.0.0
Neighbor Count = 0, Adjacent Neighbor Count= 0
Authentication-Key: None
MD5 Authentication: Key None, Key-Id None , Auth-change-wait-
time 300
RFC7474 Authentication-Key-Chain: Not Configured
RFC7474 Authentication-Key-Id: None
RFC7474 Authentication-Key: None
RFC7474 Authentication-Algorithm: None
RFC7474 Authentication-Key-Tolerance-Time: None
LDP-SYNC: Disabled, State: -

BFD is disabled
Events 2
time 300

BFD is disabled
Events 7


Neighbor: 10.20.120.1 [id 10.1.1.2] (BDR)
time 300

BFD is disabled
Events 3
Neighbor: 10.20.110.1 [id 10.1.1.1] (BDR)
time 300

BFD is disabled
Events 3
Neighbor: 10.20.140.1 [id 10.1.1.4] (BDR)
time 300



BFD is disabled
Events 8
Neighbor: 10.20.130.1 [id 10.1.1.3] (BDR)
time 300
Loopback 2 admin up, oper up

BFD is disabled
Events 2
time 300
3.2 Enter the show ip ospf interface brief command to display the
summarized OSPF interface information.
G1-spine2# show ip ospf interface brief

G1-Spine2# show ip ospf interface brief
Interface Area IP Addr/Mask Cost State Nbrs(F/C)
Eth 0/5 3 10.20.160.2/30 1 DR 0/0

Eth 0/6 3 10.20.150.2/30 1 DR 0/0

Eth 0/1 1 10.20.120.2/30 1 DR 1/1
Eth 0/2 1 10.20.110.2/30 1 DR 1/1
Eth 0/3 2 10.20.140.2/30 1 DR 1/1
Eth 0/4 2 10.20.130.2/30 1 DR 1/1
Lo 2 0 10.10.10.8/32 1 DR 0/0
3.3 Enter the show ip ospf command to display OSPF information.
G1-spine2# show ip ospf
OSPF Version Version 2

Router Id 10.1.1.8
ASBR Status No
ABR Status Yes (1)
Redistribute Ext Routes from
Initial SPF schedule delay 0 (msecs)
Minimum hold time for SPFs 0 (msecs)
Maximum hold time for SPFs 0 (msecs)
External LSA Counter 0
External LSA Checksum Sum 0
Originate New LSA Counter 109
Rx New LSA Counter 115
External LSA Limit 18641351
Administrative Distance
- External Routes: 110
- Intra Area Routes: 110
- Inter Area Routes: 110
Database Overflow Interval 0
Database Overflow State : NOT OVERFLOWED
RFC 1583 Compatibility : Disabled
NSSA Translator: Enabled
Nonstop Routing: Disabled
Graceful Restart: Enabled
Graceful Restart Helper Enabled
Graceful Restart Time 120
BFD Disabled
BFD HoldoverInterval 0
RFC7474 Transition Mode: Disabled
LDP-SYNC: Not globally enabled
Interfaces with LDP-SYNC enabled:
None
3.4 Enter the show ip ospf area command to display information about an OSPF
area.
G1-Spine2# show ip ospf area

Number of Areas is 4
Index Area Type Cost SPFR ABR ASBR LSA Chksum(Hex)

1 0 normal 0 47 0 0 15 00076459

2 1 normal 0 46 1 0 30 000dc95b
3 2 normal 0 46 1 0 36 0011028d
4 3 normal 0 45 0 0 19 0007c9e7
3.7 Enter the show ip ospf neighbor command to display OSPF neighbor
information.
G1-spine1# show ip ospf neighbor
Number of Neighbors is 6, in FULL state 6
Port Address Pri State Neigh Address Neigh ID Ev Opt Cnt

Eth 0/1 10.20.10.2 1 FULL/BDR 10.20.10.1 10.1.1.1 6 66 0
Eth 0/2 10.20.20.2 1 FULL/BDR 10.20.20.1 10.1.1.2 6 66 0
Eth 0/3 10.20.30.2 1 FULL/BDR 10.20.30.1 10.1.1.3 5 66 0
Eth 0/4 10.20.40.2 1 FULL/BDR 10.20.40.1 10.1.1.4 6 66 0
Eth 0/5 10.20.50.2 1 FULL/BDR 10.20.50.1 10.1.1.5 6 66 0
Eth 0/6 10.20.60.2 1 FULL/BDR 10.20.60.1 10.1.1.6 6 66 0
3.8 Enter the show ip ospf summary command to display OSPF detailed
information.
G1-spine1# show ip ospf summary

Seq Instance Intfs Nbrs Nbrs-Full LSAs Routes
1 default-vrf 7 6 6 104 20
G1-spine2# show ip ospf summary

Seq Instance Intfs Nbrs Nbrs-Full LSAs Routes
1 default-vrf 7 4 4 100 20
3.9 Enter the show ip ospf traffic command to display OSPF traffic information
G1-spine1# show ip ospf traffic

Packets Received Packets Sent
Hello 1281 1297
Database 18 17
LSA Req 8 6
LSA Upd 84 134
LSA Ack 105 45
3.10 Enter the show ip ospf database command to display OSPF database
information.
G1-spine2# show ip ospf database

<Truncated/>
3.11 Enter the show ip interface brief command to display interfaces

information
G1-spine2# show ip interface brief
Flags: U – Unnumbered interface, I – Insight Enabled

Interface IP-Address Vrf Status Protocol
========== ========== ===== ========= ========
Loopback 1 10.1.1.8 default-vrf up up
Loopback 2 10.10.10.8 default-vrf up up
Ethernet 0/1 10.20.120.8 default-vrf up up


<Truncated/>
3.10 Enter the show ip ospf routes command to display all the routes.
G1-spine2# show ip ospf routes
<Truncated/>
Part 4: Clean up of OSPF configuration

Please enter the below command on all the devices to remove ospf configuration
G1-leaf1(config)# no router ospf
End of OSPF Configuration Lab

Appendix-B: Detailed Device Configurations
Lab 2: System Configuration and Monitoring
Group-1:
A. G1-Leaf-1
switch-attributes host-name G1-leaf1
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.101/24
!
B. G1-Leaf-2
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.102/24
!
C. G1-Leaf-3
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.103/24

D. G1-Leaf-4
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.104/24
!
E. G1-Leaf-5
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.105/24
!
F. G1-Leaf-6
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.106/24
!
G. G1-Spine-1
switch-attributes host-name G1-spine1
no tcp burstrate
no shutdown

no ip address dhcp
ip address 10.140.8.107/24
!
H. G1-Spine-2
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.108/24
!
Group-2:
A. G2- Leaf-1
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.109/24
!
B. G2-Leaf-2
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.110/24
!
C. G2-Leaf-3

no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.111/24
!
D. G2-Leaf-4
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.112/24
!
E. G2-Leaf-5
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.113/24
!
F. G2-Leaf-6
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.114/24
!

G. G2-Spine-1
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.115/24
!
H. G2-Spine-2
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.116/24
!

Lab 3: VLAN and Port Configuration
Group-1
A. G1-Leaf-1:
vlan 20,30

switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!

switchport
no shutdown
!
B. G1-Leaf-2:
vlan 20,30


switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!

switchport
no shutdown
!
C. G1-Leaf-3:
vlan 10,20

switchport
no shutdown
!
switchport


no shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!

switchport
no shutdown
!
D. G1-Leaf-4:
vlan 10,20

switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!


shutdown
!
shutdown
!

switchport
no shutdown
!
E. G1-Leaf-5:
vlan 30,20

switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!

switchport

no shutdown
!
F. G1-Leaf-6:
vlan 30,20

switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!

switchport
no shutdown
!
G. G1-Spine-1:
vlan 10,20,30

switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!

switchport
no shutdown
!
H. G1- Spine-2
vlan 10,20,30

switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport

no shutdown
!
switchport
no shutdown
!

switchport
no shutdown
!
Group-2
A. G2-Leaf-1:
vlan 20,30

switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown


switchport
no shutdown
!
B. G2-Leaf-2:
vlan 20,30

switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!

switchport
no shutdown
!
C. G2-Leaf-3:

vlan 10,30

switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!

switchport
no shutdown
!
D. G2-Leaf-4:
vlan 10,30

switchport
no shutdown
!


switchport
no shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!

switchport
no shutdown
!
E. G2-Leaf- 5:
vlan 30,20

switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!


shutdown
!
shutdown
!
shutdown
!

switchport
no shutdown
!
F. G2-Leaf-6:
vlan 30,20

switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!
shutdown
!
shutdown
!


switchport
no shutdown
!
G. G2-Spine-1:
vlan 10,20,30

switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport


no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
H. G2-Spine-2:
vlan 10,20,30

switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!


switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!

Lab 4: L2 Redundancy
Group-1
A. G1-Leaf-1
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!

switchport
no shutdown
!

configure terminal
protocol spanning-tree rstp
bridge-priority 28582
forward-delay 20
max-age 25
error-disable-timeout enable
error-disable-timeout interval 60
port-channel path-cost custom
hello-time 5 forward-delay 16 max-age 21
transmit-holdcount 5
configure terminal
interface ethernet 0/5
no spanning-tree shutdown
spanning-tree priority 128
spanning-tree cost 20000000
spanning-tree edgeport
spanning-tree edgeport bpdu-guard
spanning-tree autoedge
spanning-tree guard root
spanning-tree link-type point-to-point
B. G1-Leaf-2
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport


no shutdown
!
shutdown
!
shutdown
!

switchport
no shutdown
!
configure terminal
forward-delay 20
max-age 25
configure terminal
C. G1-Leaf-3
switchport
no shutdown
!


switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!
switchport
no shutdown
!
configure terminal
forward-delay 20
max-age 25
configure terminal

D. G1-Leaf-4
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!
switchport
no shutdown
!
configure terminal
forward-delay 20
max-age 25

configure terminal
E . G1-Leaf-5
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
shutdown

!
shutdown
!

switchport
no shutdown
!
configure terminal
forward-delay 20
max-age 25
configure terminal
F. G1-Leaf-6
switchport
no shutdown
!
switchport
no shutdown
!


switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!
switchport
no shutdown
!
configure terminal
forward-delay 20
max-age 25
configure terminal

G. G1-Spine-1
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport


no shutdown
!

switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
configure terminal
forward-delay 20
max-age 25
configure terminal

H . G1-Spine-2
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport


no shutdown
!

switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
configure terminal
forward-delay 20
max-age 25
configure terminal

Group-2
A. G2-Leaf-1
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!
switchport
no shutdown
!
configure terminal
forward-delay 20
max-age 25

configure terminal
B. G2-Leaf-2
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
shutdown

!
shutdown
!
switchport
no shutdown
!
configure terminal
forward-delay 20
max-age 25
configure terminal
C. G2-Leaf-3
switchport
no shutdown
!
switchport

no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!
switchport
no shutdown
!
configure terminal
forward-delay 20
max-age 25
configure terminal

D. G2-Leaf-4
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
configure terminal
forward-delay 20
max-age 25

configure terminal
E. G2-Leaf-5
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!


switchport
no shutdown
!
configure terminal
forward-delay 20
max-age 25
configure terminal
F. G2-Leaf-6
switchport
no shutdown
!
switchport
no shutdown
!
switchport


no shutdown
!
switchport
no shutdown
!
shutdown
!
shutdown
!
switchport
no shutdown
!
configure terminal
forward-delay 20
max-age 25
configure terminal
G. G2-Spine-1
switchport


no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!

switchport


no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
configure terminal
forward-delay 20
max-age 25
configure terminal
spanning-tree priority 128int e
H. G2-Spine-2
switchport
no shutdown

!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!
switchport
no shutdown
!

switchport
no shutdown
!

switchport
no shutdown
!
switchport
no shutdown
!
configure terminal
forward-delay 20
max-age 25
end

Lab 5: LACP and LLDP Configuration
Group-1
A. G1-Leaf-1
no interface Port-channel 1
vlan 10
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!
speed 10000
lacp timeout long
no shutdown
B.G1-Leaf-2
vlan 10
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!


speed 10000
lacp timeout long
no shutdown
C.G1-Leaf-3
vlan 30
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!
speed 10000
lacp timeout long
no shutdown
D. G1-Leaf-4
vlan 30
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!


speed 10000
lacp timeout long
no shutdown
!
E. G1-Leaf-5
vlan 50
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!
speed 10000
lacp timeout long
no shutdown
F. G1-Leaf-6
vlan 50
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!

speed 10000
lacp timeout long
no shutdown
!
G. G1-Spine-1
vlan 40
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!
H. G1-Spine-2
vlan 40
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long

no shutdown
!
speed 10000
lacp timeout long
no shutdown
!
Group-2
A. G2-Leaf-1
vlan 10
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!
speed 10000
lacp timeout long
no shutdown
B. G2-Leaf-2
vlan 10
speed 10000
switchport
no shutdown
!
speed 10000

lacp timeout long

no shutdown
!
speed 10000
lacp timeout long
no shutdown
C. G2-Leaf-3
vlan 30
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!
speed 10000
lacp timeout long
no shutdown
D. G2-Leaf-4
vlan 30
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long
no shutdown

!
speed 10000
lacp timeout long
no shutdown
!
E. G2-Leaf-5
vlan 50
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!
speed 10000
lacp timeout long
no shutdown
F. G2-Leaf-6
vlan 50
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!


speed 10000
lacp timeout long
no shutdown
G. G2-Spine-1
vlan 40
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!
H. G2-Spine-2
vlan 40
speed 10000
switchport
no shutdown
!
speed 10000
lacp timeout long
no shutdown
!


speed 10000
lacp timeout long
no shutdown
!

Lab 6: MCT Configuration
Group-1
A. G1-Leaf-1
no shutdown

no shutdown
no shutdown
exit
vlan 4090
router-interface Ve 4090
interface Ve 4090
ip address 10.1.1.21/30
no shutdown
ip route 10.1.1.2/32 10.1.1.22
cluster MCT1 1
peer-interface Port-channel 1
peer 10.1.1.22
deploy
evpn default
route-target both auto ignore-as
rd auto
vlan add 1-4088
exit
router bgp
neighbor 10.1.1.2 update-source loopback 1
neighbor 10.1.1.22 encapsulation nsh
neighbor 10.1.1.22 activate
exit
speed 1000

switchport
no shutdown
exit

no shutdown
exit
cluster MCT1 1
client G1-XOS 1
client-interface Port-channel 11
deploy
exit
B. G1-Leaf-2
no shutdown

no shutdown
no shutdown
exit
vlan 4090
interface Ve 4090
ip address 10.1.1.22/30
no shutdown
ip route 10.1.1.1/32 10.1.1.21
cluster MCT1 1
peer 10.1.1.21
deploy
evpn default
rd auto
vlan add 1-4088
exit

router bgp
exit
speed 1000
switchport
no shutdown
exit

no shutdown
exit
cluster MCT1 1
client G1-XOS 1
deploy
exit
C. G1-Leaf-3
no shutdown

no shutdown
no shutdown
exit
vlan 4090
interface Ve 4090
ip address 10.1.1.26/30
no shutdown

ip route 10.1.1.4/32 10.1.1.25
cluster MCT1 1
peer 10.1.1.25
deploy
evpn default
rd auto
vlan add 1-4088
exit
router bgp
exit
speed 1000
switchport
no shutdown
exit

no shutdown
exit
cluster MCT1 1
client G1-XOS 1
deploy
exit
D. G1-Leaf-4
no shutdown

no shutdown


no shutdown
exit
vlan 4090
interface Ve 4090
ip address 10.1.1.25/30
no shutdown
ip route 10.1.1.3/32 10.1.1.26
cluster MCT1 1
peer 10.1.1.26
deploy
evpn default
rd auto
vlan add 1-4088
exit
router bgp
exit
speed 1000
switchport
no shutdown
exit

no shutdown
exit
cluster MCT1 1
client G1-XOS 1
deploy
exit

E . G1-Leaf-5
no shutdown

no shutdown
no shutdown
exit
vlan 4090
interface Ve 4090
ip address 10.1.1.30/30
no shutdown
ip route 10.1.1.6/32 10.1.1.29
cluster MCT1 1
peer 10.1.1.29
deploy
evpn default
rd auto
vlan add 1-4088
exit
router bgp
exit
speed 1000
switchport
no shutdown
exit


no shutdown
exit
cluster MCT1 1
client G1-XOS 1
deploy
exit
F . G1-Leaf-6
no shutdown

no shutdown
no shutdown
exit
vlan 4090
interface Ve 4090
ip address 10.1.1.29/30
no shutdown
ip route 10.1.1.5/32 10.1.1.30
cluster MCT1 1
peer 10.1.1.30
deploy
evpn default
rd auto
vlan add 1-4088
exit
router bgp


exit
speed 1000
switchport
no shutdown
exit

no shutdown
exit
cluster MCT1 1
client G1-XOS 1
deploy
exit
Group-2
A. G2-Leaf-1
no shutdown

no shutdown
no shutdown
exit
vlan 4090
interface Ve 4090
ip address 10.11.1.21/30
no shutdown
ip route 10.11.1.2/32 10.11.1.22
exit
cluster MCT1 1

peer 10.11.1.22
deploy
evpn default
rd auto
vlan add 1-4088
exit
router bgp
exit
speed 1000
switchport
no shutdown
exit

no shutdown
exit
cluster MCT1 1
client G1-XOS 1
deploy
exit
B. G2-Leaf-2
no shutdown

no shutdown


no shutdown
exit
vlan 4090
interface Ve 4090
ip address 10.11.1.22/30
no shutdown
ip route 10.11.1.1/32 10.11.1.21
exit
cluster MCT1 1
peer 10.11.1.21
deploy
evpn default
rd auto
vlan add 1-4088
exit
router bgp
exit
speed 1000
switchport
no shutdown
exit

no shutdown
exit
cluster MCT1 1
client G1-XOS 1
deploy

exit
C. G2-Leaf-3
no shutdown

no shutdown
no shutdown
exit
vlan 4090
interface Ve 4090
ip address 10.11.1.25/30
no shutdown
ip route 10.11.1.4/32 10.11.1.26
exit
cluster MCT1 1
peer 10.11.1.26
deploy
evpn default
rd auto
vlan add 1-4088
exit
router bgp
exit
speed 1000
switchport

no shutdown
exit

no shutdown
exit
cluster MCT1 1
client G1-XOS 1
deploy
exit
D. G2-Leaf-4
no shutdown

no shutdown
no shutdown
exit
vlan 4090
interface Ve 4090
ip address 10.11.1.26/30
no shutdown
ip route 10.11.1.3/32 10.11.1.25
exit
cluster MCT1 1
peer 10.11.1.25
deploy
evpn default
rd auto
vlan add 1-4088
exit
router bgp


exit
speed 1000
switchport
no shutdown
exit

no shutdown
exit
cluster MCT1 1
client G1-XOS 1
deploy
exit
E . G2-Leaf-5
no shutdown

no shutdown
no shutdown
exit
vlan 4090
interface Ve 4090
ip address 10.11.1.29/30
no shutdown
ip route 10.11.1.6/32 10.11.1.30
exit
cluster MCT1 1

peer 10.11.1.30
deploy
evpn default
rd auto
vlan add 1-4088
exit
router bgp
exit
speed 1000
switchport
no shutdown
exit

no shutdown
exit
cluster MCT1 1
client G1-XOS 1
deploy
exit
F . G2-Leaf-6
no shutdown

no shutdown
no shutdown

exit
vlan 4090
interface Ve 4090
ip address 10.11.1.30/30
no shutdown
ip route 10.11.1.5/32 10.11.1.29
exit
cluster MCT1 1
peer 10.11.1.29
deploy
evpn default
rd auto
vlan add 1-4088
exit
router bgp
exit
speed 1000
switchport
no shutdown
exit

no shutdown
exit
cluster MCT1 1
client G1-XOS 1
deploy
exit


Lab 7: Configuring BGP (Numbered devices)
Group-1
A. G1-Leaf-1
no protocol vrrp
router bgp
local-as 64101
maximum-paths 8
next-hop-recursion
!
!
no shutdown
!
ip address 10.10.10.1/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.101/24
!
ip address 10.20.10.1/30
no shutdown
!
ip address 10.20.110.1/30

no shutdown
!
B. G1-Leaf-2
no protocol vrrp
router bgp
local-as 64101
maximum-paths 8
next-hop-recursion
!
!
no shutdown
!
ip address 10.10.10.2/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.102/24
!
ip address 10.20.120.1/30
no shutdown
!
ip address 10.20.20.1/30
no shutdown
!

C. G1-Leaf-3
no protocol vrrp
router bgp
local-as 64102
maximum-paths 8
next-hop-recursion
!
!
no shutdown
!
ip address 10.10.10.3/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.103/24
!
ip address 10.20.30.1/30
no shutdown
!
ip address 10.20.130.1/30
no shutdown
!

D . G1-Leaf-4
no protocol vrrp
router bgp
local-as 64102
maximum-paths 8
next-hop-recursion
!
!
!
no shutdown
!
ip address 10.10.10.4/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.104/24
!
ip address 10.20.140.1/30
no shutdown
!
ip address 10.20.40.1/30
no shutdown
!

E. G1-Leaf-5
no protocol vrrp
router bgp
local-as 64103
maximum-paths 8
next-hop-recursion
!
!
no shutdown
!
ip address 10.10.10.5/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.105/24
!
ip address 10.20.50.1/30
no shutdown
!
ip address 10.20.150.1/30
no shutdown
!
F. G1-Leaf-6

no protocol vrrp
router bgp
local-as 64103
maximum-paths 8
next-hop-recursion
!
!
!
no shutdown
!
ip address 10.10.10.6/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.106/24
!
ip address 10.20.160.1/30
no shutdown
!
ip address 10.20.60.1/30
no shutdown
!
G. G1-Spine-1
no protocol vrrp

router bgp
local-as 65101

maximum-paths 8
!
!
!
no shutdown
!
ip address 10.10.10.7/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.107/24
!
ip address 10.20.10.2/30

no shutdown
!
ip address 10.20.20.2/30
no shutdown
!
ip address 10.20.30.2/30
no shutdown
!
ip address 10.20.40.2/30
no shutdown
!
ip address 10.20.50.2/30
no shutdown
!
ip address 10.20.60.2/30
no shutdown
!
H. G1-Spine-2
no protocol vrrp
router bgp
local-as 65101


maximum-paths 8
!
!
no shutdown
!
ip address 10.10.10.8/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.108/24
!
ip address 10.20.120.2/30
no shutdown
!
ip address 10.20.110.2/30
no shutdown
!
ip address 10.20.140.2/30
no shutdown
!
ip address 10.20.130.2/30
no shutdown
!
ip address 10.20.160.2/30
no shutdown
!
ip address 10.20.150.2/30
no shutdown

Group-2
A. G2-Leaf-1
no protocol vrrp
router bgp
local-as 64201
maximum-paths 8
next-hop-recursion
!
!
ip address 10.11.1.1/32
no shutdown
!
ip address 10.110.10.1/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.109/24
!
ip address 10.120.10.1/30
no shutdown
!

ip address 10.120.110.1/30
no shutdown
!
B. G2-Leaf-2
no protocol vrrp
router bgp
local-as 64201
maximum-paths 8
next-hop-recursion
!
!
ip address 10.11.1.2/32
no shutdown
!
ip address 10.110.10.2/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.110/24
!
ip address 10.120.120.1/30
no shutdown
!
ip address 10.120.20.1/30
no shutdown
!

C. G2-Leaf-3
no protocol vrrp
router bgp
local-as 64202
maximum-paths 8
next-hop-recursion
!
!
ip address 10.11.1.3/32
no shutdown
!
ip address 10.110.10.3/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.111/24
!
ip address 10.120.30.1/30
no shutdown
!
ip address 10.120.130.1/30
no shutdown
!
D. G2-Leaf-4

no protocol vrrp
router bgp
local-as 64202
maximum-paths 8
next-hop-recursion
!
!
!
ip address 10.11.1.4/32
no shutdown
!
ip address 10.110.10.4/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.112/24
!
ip address 10.120.140.1/30
no shutdown
!
ip address 10.120.40.1/30
no shutdown
!
E. G2-Leaf-5
no protocol vrrp

router bgp
local-as 64203
maximum-paths 8
next-hop-recursion
!
!
ip address 10.11.1.5/32
no shutdown
!
ip address 10.110.10.5/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.113/24
!
ip address 10.120.50.1/30
no shutdown
!
ip address 10.120.150.1/30
no shutdown
!
F. G2-Leaf-6
no protocol vrrp
router bgp
local-as 65203


maximum-paths 8
next-hop-recursion
!
!
!
ip address 10.11.1.6/32
no shutdown
!
ip address 10.110.10.6/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.114/24
!
ip address 10.120.160.1/30
no shutdown
!
ip address 10.120.60.1/30
no shutdown
!
G . G2-Spine-1
no protocol vrrp
router bgp
local-as 65201



maximum-paths 8
!
!
!
ip address 10.11.1.7/32
no shutdown
!
ip address 10.110.10.7/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.115/24
!
ip address 10.120.10.2/30
no shutdown
!
ip address 10.120.20.2/30

no shutdown
!
ip address 10.120.30.2/30
no shutdown
!
ip address 10.120.40.2/30
no shutdown
!
ip address 10.120.50.2/30
no shutdown
!
ip address 10.120.60.2/30
no shutdown
!
H . G2-Spine-2
no protocol vrrp
router bgp
local-as 65201


maximum-paths 8
!
!
ip address 10.11.1.8/32
no shutdown
!
ip ospf area 0
ip address 10.110.10.8/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.116/24
!
int e 0/1
ip address 10.120.120.2/30
no shutdown
!
int e 0/2
ip address 10.120.110.2/30
no shutdown
!
int e 0/3
ip address 10.120.140.2/30
no shutdown
!
int e 0/4
ip address 10.120.130.2/30
no shutdown
!
int e 0/5
ip address 10.120.160.2/30
no shutdown
!
int e 0/6
ip address 10.120.150.2/30
no shutdown
!

Lab 8: Configuring BGP on Un-numbered devices
Group-1
A. G1-Leaf-1
no protocol vrrp
router bgp
local-as 64101
neighbor 10.1.1.8 ebgp-multihop 2
maximum-paths 8
next-hop-recursion
!
!
!
no shutdown
!
ip address 10.10.10.1/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.101/24
!
ip address 10.20.10.1/30
no shutdown
!


ip unnumbered loopback 1
no shutdown
!
B. G1-Leaf-2
no protocol vrrp
router bgp
local-as 64101
maximum-paths 8
next-hop-recursion
!
!
!
no shutdown
!
ip address 10.10.10.2/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.102/24
!
no shutdown
!


ip address 10.20.20.1/30
no shutdown
!
C. G1-Leaf-3
no protocol vrrp
router bgp
local-as 64102
maximum-paths 8
next-hop-recursion
!
!
no shutdown
!
ip address 10.10.10.3/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.103/24
!
ip address 10.20.30.1/30
no shutdown
!

no shutdown
!
D . G1-Leaf-4
no protocol vrrp
router bgp
local-as 64102
maximum-paths 8
next-hop-recursion
!
!
!
no shutdown
!
ip ospf area 2
ip address 10.10.10.4/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.104/24
!
no shutdown
!


ip address 10.20.40.1/30
no shutdown
!
E . G1-Leaf-5
no protocol vrrp
router bgp
local-as 64103
maximum-paths 8
next-hop-recursion
!
!
no shutdown
!
ip address 10.10.10.5/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.105/24
!
ip address 10.20.50.1/30
no shutdown
!

no shutdown
!
F . G1-Leaf-6
no protocol vrrp
router bgp
local-as 64103
maximum-paths 8
next-hop-recursion
!
!
!
no shutdown
!
ip address 10.10.10.6/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.106/24
!
no shutdown
!

ip address 10.20.60.1/30
no shutdown
!
A. G1-Spine-1
no protocol vrrp
router bgp
local-as 65101

maximum-paths 8
!
!
!
no shutdown
!
ip address 10.10.10.7/32
no shutdown
!

no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.107/24
!
ip address 10.20.10.2/30
no shutdown
!
ip address 10.20.20.2/30
no shutdown
!
ip address 10.20.30.2/30
no shutdown
!
ip address 10.20.40.2/30
no shutdown
!
ip address 10.20.50.2/30
no shutdown
!
ip address 10.20.60.2/30
no shutdown
!
B. G1-Spine-2
no protocol vrrp
router bgp
local-as 65101


maximum-paths 8
!
!
!
no shutdown
!
ip address 10.10.10.8/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.108/24
!
no shutdown

!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
Group-2
A. G2-Leaf-1
police-remark-profile default
no protocol vrrp
router bgp
local-as 64201
maximum-paths 8
next-hop-recursion
!

!
!
ip address 10.11.1.1/32
no shutdown
!
ip address 10.110.10.1/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.109/24
!
ip address 10.120.10.1/30
no shutdown
!
no shutdown
!
B. G2-Leaf-2
no protocol vrrp
router bgp
local-as 64201
maximum-paths 8
next-hop-recursion
!
!

!
ip address 10.11.1.2/32
no shutdown
!
ip address 10.110.10.2/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.110/24
!
no shutdown
!
ip address 10.120.20.1/30
no shutdown
!
C. G2-Leaf-3
no protocol vrrp
router bgp
local-as 64202
maximum-paths 8
next-hop-recursion
!
!

ip address 10.11.1.3/32
no shutdown
!
ip address 10.110.10.3/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.111/24
!
ip address 10.120.30.0/30
no shutdown
!
no shutdown
!
D. G2-Leaf-4
no protocol vrrp
router bgp
local-as 64202
maximum-paths 8
next-hop-recursion
!
!
!
ip address 10.11.1.4/32

no shutdown
!
ip address 10.110.10.4/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.112/24
!
no shutdown
!
ip address 10.120.40.1/30
no shutdown
!
E. G2-Leaf-5
no protocol vrrp
router bgp
local-as 64203
maximum-paths 8
next-hop-recursion
!
!
ip address 10.11.1.5/32
no shutdown
!

ip address 10.110.10.5/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.113/24
!
ip address 10.120.50.1/30
no shutdown
!
no shutdown
!
F. G2-Leaf-6
no protocol vrrp
router bgp
local-as 64203
maximum-paths 8
next-hop-recursion
!
!
!
ip address 10.11.1.6/32
no shutdown
!

ip address 10.110.10.6/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.114/24
!
no shutdown
!
ip address 10.120.60.1/30
no shutdown
!
G . G2-Spine-1:
no protocol vrrp
router bgp
local-as 65201



maximum-paths 8
!
!
!
ip address 10.11.1.7/32
no shutdown
!
ip address 10.110.10.7/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.115/24
!
ip address 10.120.10.2/30
no shutdown
!
ip address 10.120.20.2/30
no shutdown
!
ip address 10.120.30.2/30
no shutdown
!
ip address 10.120.40.2/30
no shutdown
!
ip address 10.120.50.2/30
no shutdown
!
ip address 10.120.60.2/30
no shutdown
!
H. G2-Spine-2

no protocol vrrp
router bgp
local-as 65201
maximum-paths 8
!
!
!
ip address 10.11.1.8/32

no shutdown
!
ip ospf area 0
ip address 10.110.10.8/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.116/24
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!

Lab 9: Configuring BGP EVPN

Group 1
A. G1-LEAF-1
no protocol vrrp
router bgp
local-as 64101
maximum-paths 8
next-hop-recursion
!
!
neighbor 10.1.1.8 encapsulation vxlan
neighbor 10.1.1.8 next-hop-unchanged


!
!
no shutdown
!
ip address 10.10.10.1/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.101/24
!
ip address 10.20.10.1/30
no shutdown
!
no shutdown
!
B. G1-Leaf-2
no protocol vrrp
router bgp
local-as 64101


maximum-paths 8
next-hop-recursion
!
!
!
!
no shutdown
!
ip address 10.10.10.2/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.102/24
!
no shutdown
!
ip address 10.20.20.1/30
no shutdown
!

C. G1-Leaf-3
no protocol vrrp
router bgp
local-as 64102
maximum-paths 8
next-hop-recursion
!
!
!
!

no shutdown
!
ip address 10.10.10.3/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.103/24
!
ip address 10.20.30.1/30
no shutdown
!
no shutdown
!
D. G1-Leaf-4
no protocol vrrp
router bgp
local-as 64102


maximum-paths 8
next-hop-recursion
!
!
!
!
no shutdown
!
ip address 10.10.10.4/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.104/24
!
no shutdown
!
ip address 10.20.40.1/30
no shutdown
!
E. G1-Leaf-5

no protocol vrrp
router bgp
local-as 64103
maximum-paths 8
next-hop-recursion
!
!
!
!
no shutdown

!
ip address 10.10.10.5/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.105/24
!
ip address 10.20.50.1/30
no shutdown
!
no shutdown
!
F. G1-Leaf-6
no protocol vrrp
router bgp
local-as 64103


maximum-paths 8
next-hop-recursion
!
!
!
!
no shutdown
!
ip address 10.10.10.6/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.106/24
!
no shutdown
!
ip address 10.20.60.1/30
no shutdown
!
G . G1-Spine-1
router bgp
local-as 65101


maximum-paths 8
!
!
!
!
no shutdown
!
ip address 10.10.10.7/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.107/24
!
ip address 10.20.10.2/30
no shutdown
!

ip address 10.20.20.2/30
no shutdown
!
ip address 10.20.30.2/30
no shutdown
!
ip address 10.20.40.2/30
no shutdown
!
ip address 10.20.50.2/30
no shutdown
!
ip address 10.20.40.2/30
no shutdown
!
H . G1-Spine-2
no protocol vrrp
router bgp
local-as 65101


maximum-paths 8
!
!
retain route-target all
!
!
no shutdown
!
ip address 10.10.10.8/32
no shutdown
!

no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.108/24
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
no shutdown
!
Group 2
A. G2-LEAF-1
police-remark-profile default
no protocol vrrp
router bgp
local-as 64201


maximum-paths 8
next-hop-recursion
!
!
!
!
ip address 10.11.1.1/32
no shutdown
!
ip address 10.110.10.1/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp

ip address 10.140.8.109/24
!
ip address 10.120.10.1/30
no shutdown
!
no shutdown
!
B. G2-Leaf-2
no protocol vrrp
router bgp
local-as 64201
maximum-paths 8
next-hop-recursion
!
!


!
!
ip address 10.11.1.2/32
no shutdown
!
ip address 10.110.10.2/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.110/24
!
no shutdown
!
ip address 10.120.20.1/30
no shutdown
!
C. G2-Leaf-3
no protocol vrrp
router bgp
local-as 64202


maximum-paths 8
next-hop-recursion
!
!
!
!
ip address 10.11.1.3/32
no shutdown
!
ip address 10.110.10.3/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.111/24
!
ip address 10.120.30.1/30
no shutdown

!
no shutdown
!
D. G2-Leaf-4
no protocol vrrp
router bgp
local-as 64202
maximum-paths 8
next-hop-recursion
!
!


!
!
ip address 10.11.1.4/32
no shutdown
!
ip address 10.110.10.4/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.112/24
!
no shutdown
!
ip address 10.120.40.1/30
no shutdown
!
E . G2-Leaf-5
no protocol vrrp
router bgp
local-as 64203


maximum-paths 8
next-hop-recursion
!
!
!
!
ip address 10.11.1.5/32
no shutdown
!
ip address 10.110.10.5/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.113/24
!
ip address 10.120.50.1/30
no shutdown
!
no shutdown

!
F . G2-Leaf-6
no protocol vrrp
router bgp
local-as 64203
maximum-paths 8
next-hop-recursion
!
!
!
!

ip address 10.11.1.6/32
no shutdown
!
ip address 10.110.10.6/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.114/24
!
no shutdown
!
ip address 10.120.60.1/30
no shutdown
!
G . G2-Spine-1
router bgp
local-as 65201


maximum-paths 8
!
!
!
!
ip address 10.11.1.7/32
no shutdown
!
ip address 10.110.10.7/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.115/24
!
ip address 10.120.10.2/30
no shutdown
!
ip address 10.120.20.2/30
no shutdown
!
ip address 10.120.30.2/30
no shutdown
!
ip address 10.120.40.2/30
no shutdown
!
ip address 10.120.50.2/30
no shutdown
!
ip address 10.120.60.2/30
no shutdown
!

H . G2-Spine-2
no protocol vrrp
router bgp
local-as 65201
maximum-paths 8
!
!
retain route-target all


!
!
ip address 10.11.1.8/32
no shutdown
!
ip address 10.110.10.8/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.116/24
!
no shutdown
!
no shutdown
!
no shutdown
!


no shutdown
!
no shutdown
!
no shutdown
!

Lab Appendix-A : OSPF Configuration
Group-1
A. G1-Leaf-1
router ospf
area 1
!
no shutdown
!
ip ospf area 1
ip address 10.10.10.1/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.101/24
!
ip ospf area 1
ip address 10.20.10.1/30
no shutdown
!
ip ospf area 1
ip address 10.20.110.1/30
no shutdown
!
B. G1-Leaf-2
router ospf
area 1
!
no shutdown
!

ip ospf area 1
ip address 10.10.10.2/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.102/24
!
ip ospf area 1
ip address 10.20.120.1/30
no shutdown
!
ip ospf area 1
ip address 10.20.20.1/30
no shutdown
!
C. G1-Leaf-3
router ospf
area 2
!
no shutdown
!
ip ospf area 2
ip address 10.10.10.3/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.103/24
!
ip ospf area 2

ip address 10.20.30.1/30
no shutdown
!
ip ospf area 2
ip address 10.20.130.1/30
no shutdown
!
D. G1-Leaf-4
router ospf
area 2
!
no shutdown
!
ip ospf area 2
ip address 10.10.10.4/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.104/24
!
ip ospf area 2
ip address 10.20.140.1/30
no shutdown
!
ip ospf area 2
ip address 10.20.40.1/30
no shutdown
!
E. G1-Leaf-5
router ospf
area 3
!

no shutdown
!
ip ospf area 3
ip address 10.10.10.5/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.105/24
!

ip ospf area 3
ip address 10.20.50.1/30
no shutdown
!
ip ospf area 3
ip address 10.20.150.1/30
no shutdown
!
F. G1-Leaf-6
router ospf
area 3
!
no shutdown
!
ip ospf area 3
ip address 10.10.10.6/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp

ip address 10.140.8.106/24
!
ip ospf area 3
ip address 10.20.160.1/30
no shutdown
!
ip ospf area 3
ip address 10.20.60.1/30
no shutdown
!
G. G1-Spine-1
router ospf
area 0
area 1
area 2
area 3
!
no shutdown
!
ip ospf area 0
ip address 10.10.10.7/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.107/24
!
ip ospf area 1
ip address 10.20.10.2/30
no shutdown
!
ip ospf area 1
ip address 10.20.20.2/30

no shutdown
!
ip ospf area 2
ip address 10.20.30.2/30
no shutdown
!
ip ospf area 2
ip address 10.20.40.2/30
no shutdown
!
ip ospf area 3
ip address 10.20.50.2/30
no shutdown
!
ip ospf area 3
ip address 10.20.60.2/30
no shutdown
!
H. G1-Spine-2
router ospf
area 0
area 1
area 2
area 3
!
no shutdown
!
ip ospf area 0
ip address 10.10.10.8/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.108/24
!


ip ospf area 1
ip address 10.20.120.2/30
no shutdown
!
ip ospf area 1
ip address 10.20.110.2/30
no shutdown
!
ip ospf area 2
ip address 10.20.140.2/30
no shutdown
!
ip ospf area 2
ip address 10.20.130.2/30
no shutdown
!
ip ospf area 3
ip address 10.20.160.2/30
no shutdown
!
ip ospf area 3
ip address 10.20.150.2/30
no shut
!
Group-2
A. G2-Leaf-1
router ospf
area 1
!
ip address 10.11.1.1/32
no shutdown
!
ip ospf area 1
ip address 10.110.10.1/32
no shutdown

!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.109/24
!
ip ospf area 1
ip address 10.120.10.1/30
no shutdown
!
ip ospf area 1
ip address 10.120.110.1/30
no shutdown
!
B. G2-Leaf-2
router ospf
area 1
!
ip address 10.11.1.2/32
no shutdown
!
ip ospf area 1
ip address 10.110.10.2/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.110/24
!
ip ospf area 1
ip address 10.120.120.1/30
no shutdown
!

ip ospf area 1
ip address 10.120.20.1/30
no shutdown
!
C. G2-Leaf-3
router ospf
area 2
!
ip address 10.11.1.3/32
no shutdown
!
ip ospf area 2
ip address 10.110.10.3/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.111/24
!
ip ospf area 2
ip address 10.120.30.1/30
no shutdown
!
ip ospf area 2
ip address 10.120.130.1/30
no shutdown
!
D. G2-Leaf-4
router ospf
area 2
!
ip address 10.11.1.4/32
no shutdown
!
ip ospf area 2

ip address 10.110.10.4/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.112/24
!
ip ospf area 2
ip address 10.120.140.1/30
no shutdown
!
ip ospf area 2
ip address 10.120.40.1/30
no shutdown
!
E. G2-Leaf-5
router ospf
area 3
!
ip address 10.11.1.5/32
no shutdown
!
ip ospf area 3
ip address 10.110.10.5/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.113/24
!
ip ospf area 3
ip address 10.120.50.1/30

no shutdown
!
ip ospf area 3
ip address 10.120.150.1/30
no shutdown
!
F. G2-Leaf-6
router ospf
area 3
!
ip address 10.11.1.6/32
no shutdown
!
ip ospf area 3
ip address 10.110.10.6/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.114/24
!
ip ospf area 3
ip address 10.120.160.1/30
no shutdown
!
ip ospf area 3
ip address 10.120.60.1/30
no shutdown
!
G. G2-Spine-1
router ospf
area 0
area 1
area 2
area 3
!

no shutdown
!
ip ospf area 0
ip address 10.10.10.7/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.115/24
!
ip ospf area 1
ip address 10.120.10.2/30
no shutdown
!
ip ospf area 1
ip address 10.120.20.2/30
no shutdown
!
ip ospf area 2
ip address 10.120.30.2/30
no shutdown
!
ip ospf area 2
ip address 10.120.40.2/30
no shutdown
!
ip ospf area 3
ip address 10.20.50.2/30
no shutdown
!
ip ospf area 3
ip address 10.20.60.2/30
no shutdown
!

H . G2-Spine-2
router ospf
area 0
area 1
area 2
area 3
!
ip address 10.11.1.8/32
no shutdown
!
ip ospf area 0
ip address 10.110.10.8/32
no shutdown
!
no tcp burstrate
no shutdown
no ip address dhcp
ip address 10.140.8.116/24
!
ip ospf area 1
ip address 10.120.120.2/30
no shutdown
!
ip ospf area 1
ip address 10.120.110.2/30
no shutdown
!
ip ospf area 2
ip address 10.120.140.2/30
no shutdown
!
ip ospf area 2
ip address 10.120.130.2/30
no shutdown
!
ip ospf area 3

ip address 10.20.160.2/30
no shutdown
!
ip ospf area 3
ip address 10.20.150.2/30
no shutdown
!

SLX Lab Guide

Uploaded by

Document Information

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

SLX Lab Guide

Uploaded by

Copyright:

Available Formats

SLX Configuration and Implementation Lab Guide SLX

© 2020 Extreme Networks, Inc. All rights reserved .

For additional information refer to:

© 2020 Extreme Networks, Inc. All rights reserved .

© 2020 Extreme Networks, Inc. All rights reserved . 3

Lab Guide Information

➢ SLX CLI Essentials

S.No Student Device Allocated Username Password

© 2020 Extreme Networks, Inc. All rights reserved . 4

S.No Student Device Allocated Username Password

S. No Device Name Username Password

© 2020 Extreme Networks, Inc. All rights reserved . 5

Lab 1: SLX CLI Essentials

dhcp ztp cancel

© 2020 Extreme Networks, Inc. All rights reserved . 6

Lab Access Topology:

© 2020 Extreme Networks, Inc. All rights reserved . 7

Device Management IP Port : Telnet

Part 1: Accessing SLX Device, Basic commands and Context

SLX login: admin

SECURITY WARNING: The default password for at least one

© 2020 Extreme Networks, Inc. All rights reserved . 8

1.2 Enter the dhcp ztp cancel command

Warning: This command will terminate the existing ZTP session

Part 2: Context Sensitive Help

© 2020 Extreme Networks, Inc. All rights reserved . 9

no Negate a command or set its defaults

2.2 Enter c? at CLI Prompt

© 2020 Extreme Networks, Inc. All rights reserved . 10

clock set switch date, time, and timezone

2.3 Explore more with command completions

SLX# show int

© 2020 Extreme Networks, Inc. All rights reserved . 11

Primary Internet Address is 10.1.1.7/32

Part 3: Error Messages in CLI

SLX# clear route

Clear routes by entering clear ip route

Part 4: Keyboard Shortcuts

SLX# show interfaces <do not hit enter>

Press cntrl-b. – The curser moves one character backwards

© 2020 Extreme Networks, Inc. All rights reserved . 12

Part 5: Operational Commands

5.1 Enter show ip route command

SLX# show ip route

5.2 Enter show mac command

SLX# show mac

5.3 Enter show ip interface ? command to explore possible completions in

SLX# show ip interface ?

SLX# show ip interface brief

Flags: U - Unnumbered interface, I - Insight Enabled

© 2020 Extreme Networks, Inc. All rights reserved . 13

5.5 Enter show ip interface ethernet 0/1 command to know about a

SLX# show ip interface e 0/1

SLX# show media

5.7 Enter show li command to explore possible completions in

© 2020 Extreme Networks, Inc. All rights reserved . 14

G1-Leaf1# show license

G1-Leaf1# show chassis

Chassis Name: SLX9250-32C

POWER SUPPLY Unit: 1

POWER SUPPLY Unit: 2

© 2020 Extreme Networks, Inc. All rights reserved . 15

5.9 Enter Show version command to display the OS information which is

G1-Spine1# show version
