IDENTIFICATION CARD

120D61492-1
TABLE OF CONTENTS Sandvik DD321-40 200824

2. IDENTIFICATION CARD
* UNIT IDENTIFICATION CARD...........................................................................................................................................................

Sandvik Mining and Construction Oy Drills Tampere © 2020

 1/9

UNIT IDENTIFICATION CARD

Sandvik DD321-40
SERIAL NO: 120D61492-1

EQUIPMENT
Equipment main assembly BG01469799

DRILLING MODULE
Rock Drill (Left)
ID Type/Serial number
Rock Drill BG01100261 RD520/M051029

Feed assembly (Left)

Type ID code Serial number
Feed assembly (Left) TF500-16 55159293 M04244

Feed cylinder (Left)

ID Serial number
Feed cylinder 55082949 13/20

Rock Drill (Right)

ID Type/Serial number
Rock Drill BG01100261 RD520/M051028

Feed assembly (Right)

Type ID code Serial number
Feed assembly (Right) TF500-16 55159973 M04245

Feed cylinder (Right)

ID Serial number
Feed cylinder 55082949 13/20

Main components (Left)

ID-code Type/Serial number
Boom BG01121982 M12215
Inner pipe - 620525 600 744 TK
2020 09 A
Outer pipe - 620525 600 155 TK
2020 09 A
Cradle BG00245423 620132 61 2020 15 F

SANDVIK MINING AND CONSTRUCTION

UNDERGROUND DRILLS
P.O.Box 100
FIN 33311 TAMPERE, FINLAND
Tel. +358 205 44 121
Telefax +358 205 44 120
 2/9

UNIT IDENTIFICATION CARD

Sandvik DD321-40
SERIAL NO: 120D61492-1

Boom castings (Left)

ID-code Manufacturer/
Serial number
Rear part, Swing arm 32894868B CLAAS 532
24D9
Rear part, Mounting plate 32669528-G CLAAS 26?8
1019
Rear part, Cross piece 32118948 CLAAS 02M8E
Boom head, Tilt clevis 55005000 TWEER
20086B
Boom head, Swing piece 55002383 TWEER
19635B
Boom head, Cross piece 32118818-D CLAAS 28A04
Cradle Swing Pipe

Cylinders (Left)
ID-code Batch-number
Torque motor BG01035613 87595
Boom lift cylinder 55099748 HES 16/20
Boom swing cylinder 55156082 HES 15/20
Zoom cylinder 55160993 HL 35/18
Feed tilt cylinder 55004120 HES 16/20
Feed swing cylinder 55004124 HES 6/20
Feed bolting cylinder
Feed extension cylinder 55216227 HL 13/20

Main components (Right)

ID-code Type/Serial number
Boom BG01121831 M12216
Inner pipe - 620525 838 155 TK
2020 10 A
Outer pipe - 620525 600 617 TK
2020 10 A
Cradle BG00245423 620132 61 2020 14 F

SANDVIK MINING AND CONSTRUCTION

UNDERGROUND DRILLS
P.O.Box 100
FIN 33311 TAMPERE, FINLAND
Tel. +358 205 44 121
Telefax +358 205 44 120
 3/9

UNIT IDENTIFICATION CARD

Sandvik DD321-40
SERIAL NO: 120D61492-1

Boom castings (Right)

ID-code Manufacturer/
Serial number
Rear part, Swing arm 32894868B CLAAS 531
24D9
Rear part, Mounting plate 32621008-G CLAAS 06E9
583
Rear part, Cross piece 32118948-G CLAAS 02M9E
Boom head, Tilt clevis 55005000 TWEER20086C
Boom head, Swing piece 55002384 TWEER
15646B
Boom head, Cross piece 32118818-D CLAAS 28704
Cradle Swing Pipe

Cylinders (Right)
ID-code Batch-number
Torque motor BG01035613 87594
Boom lift cylinder 55099748 HES 17/20
Boom swing cylinder 55156082 HES 15/20
Zoom cylinder 55160993 HL 18/20
Feed tilt cylinder 55004120 HES 13/20
Feed swing cylinder 55004124 HES 7/20
Feed bolting cylinder
Feed extension cylinder 55216227 HL 13/20

POWERTRAIN
Axle assembly
Front axle Rear axle
ID- code 55036863 55036882
Manufacturer / gear ratio DANA 123/59- DANA 123/56-
006 007
Serial number C-ITA-723910 C-ITA-724724

Engine assembly

ID- code 55212841

Manufacturer / type/ power DAIMLER TRUCK AG
OM904LA 110kW
Serial number 904.975-C-1168948
Engine cooler's serial number 2020 001938 004 2020/4

SANDVIK MINING AND CONSTRUCTION

UNDERGROUND DRILLS
P.O.Box 100
FIN 33311 TAMPERE, FINLAND
Tel. +358 205 44 121
Telefax +358 205 44 120
 4/9

UNIT IDENTIFICATION CARD

Sandvik DD321-40
SERIAL NO: 120D61492-1

Engine components
ID-code Serial number
Purifier/Silencer 55215624 1320-0006
Gearbox/Converter 55036885 CBEA 139500
Pump assembly 55047241 11/20
66221833/006

CARRIER
Jack beam
ID- code Manufacturer /
Serial number
Jack beam 55175021 201260 PTK
2020 01

Cylinder checks, front jacks

ID- code Batch number Batch- right
Front jack, left 55000437 14/20
Front jack, right 55000437 14/20

Components, Powerpack left

ID- code Type/Serial number
Powerpack unit BG00966169 M02179/HPP555
Piston pump BG00970518 00497574
Gear pump 55039459 18/20, 66225343/007

Components, Powerpack right

ID- code Type/Serial number
Powerpack unit BG00961688 M02180/HPP555
Piston pump BG00970518 00503306
Gear pump 55039459 18/20, 66225343/008

Components, THC left

ID- code Type/Serial number
THC-operation panel BG01399120 THC561/M09111

Components, THC right

ID- code Type/Serial number
THC-operation panel BG01399120 THC561/M09112

SANDVIK MINING AND CONSTRUCTION

UNDERGROUND DRILLS
P.O.Box 100
FIN 33311 TAMPERE, FINLAND
Tel. +358 205 44 121
Telefax +358 205 44 120
 5/9

UNIT IDENTIFICATION CARD

Sandvik DD321-40
SERIAL NO: 120D61492-1

Frames
ID- code Manufacturer /
Serial number
Front frame 55174555 620515 KT 20/3 116
Rear frame 55172617 620515 KT 20/4 6

Cylinder checks, steering cylinders

ID- code Batch number Batch- right
Steering cylinder, left 55039519 16/20
Steering cylinder, right 55039519 16/20

Cylinder checks, rear jacks

ID- code Batch number Batch- right
Rear jack, left 55000439 35/18
Rear jack, right 55000439 40/18

Boom Support
ID- code Manufacturer /
Serial number
Boom Support 55005583 FI450536 HL 2020 8

Components, Central grease unit

ID- code Serial number
Central greaser unit 88627899 2020229203/10

Components, Electric motor left

ID- code Serial number
Electric motor 55060678 411478/0001 H

Components, Electric motor right

ID- code Serial number
Electric motor 55060678 411478/0002H

Rims
Batch code
Left front middle plate 11/19
Right front middle plate 11/19
Left rear middle plate 11/19
Right rear middle plate 11/19

SANDVIK MINING AND CONSTRUCTION

UNDERGROUND DRILLS
P.O.Box 100
FIN 33311 TAMPERE, FINLAND
Tel. +358 205 44 121
Telefax +358 205 44 120
 6/9

UNIT IDENTIFICATION CARD

Sandvik DD321-40
SERIAL NO: 120D61492-1

Fire suppression system tracing information, FS1000

Fire suppression system ID 551729123

Tank size (Litres) 65L
Tank serial number 65X12860
Head valve serial number II519

TCAD basic information

TCAD software ID 3.5_r6404

User panel serial number 001163

COMPONENTS
Compressor
ID- code Type/ Serial Voltage/ Freq.
number
Compressor BG01052070 CT28 F031639

Water pump
ID-code Type/Serial
number
Water pump BG00864172 WBP1008
111XYV
Electric motor of the water pump BG00202072 1048480146

IP5
ID-code Serial number
IP5 BG00234900 88079

Cable reel
ID-code Type/Serial
number
Cable reel 55164306 2000866/01

Fuel tank and Hydraulic receiver

ID- code Serial number
Fuel tank 55171142 620445 22TX 146
Hydraulic receiver BG00769069 620445 1TX 105

SANDVIK MINING AND CONSTRUCTION

UNDERGROUND DRILLS
P.O.Box 100
FIN 33311 TAMPERE, FINLAND
Tel. +358 205 44 121
Telefax +358 205 44 120
 7/9

UNIT IDENTIFICATION CARD

Sandvik DD321-40
SERIAL NO: 120D61492-1

Oil coolers
ID-code Serial number
Oil cooler 55179838 02/20
Oil cooler 55179838 02/20

Brake pressure accumulator

ID- code Serial number Voltage/ Freq.
Brake pressure accumulator, front BG00369454 2019 11 21
SN6269375
Brake pressure accumulator, rear BG00369454 2019 11 21
SN6269374

Cylinder checks, Safety canopy

ID- code Batch number Batch- right
Safety canopy cylinder, right 32361241 36/19
Safety canopy cylinder, left 32361241 36/19

OTHER INFORMATION
Main switchgear

Electric power 440V/60Hz/140kW

Weight

Total Weight 22700 kg

Front Axle 16100 kg
Rear Axle 6600 kg

SANDVIK MINING AND CONSTRUCTION

UNDERGROUND DRILLS
P.O.Box 100
FIN 33311 TAMPERE, FINLAND
Tel. +358 205 44 121
Telefax +358 205 44 120
 8/9

UNIT IDENTIFICATION CARD

Sandvik DD321-40
SERIAL NO: 120D61492-1

SPECIFICATION
(* replaces the standard component)

Spec
Sandvik DD321 (TS2-125:03)
Basic Units
Sandvik DD321 development drill:
1 x NC7 undercarrier with hydrodynamic transmission
1 x M-B OM904LA diesel engine (110 kW Tier3)
1 x FOPS/ROPS (ISO3449/3471) operator’s cabin
-- Cabin airconditioning system
-- Cabin front screen safety grill
2 x Hydraulic jacks (front)
2 x Hydraulic jacks (rear)
2 x RD520 hydraulic rock drills
2 x TF500-12 feeds
2 x SB40 telescopic booms
2 x THC561 drilling control systems
2 x HPP555 powerpacks (55 kW)
2 x OW30 oil coolers
1 x SLU2 shank lubrication device
1 x CTN10 air compressor for shank lubrication
1 x WBP2 water booster pump
1 x MSE20 main switch gear
1 x TCR 3E automatic cable reel
1 x Remote control for cable and water hose reels
6 x 50 W (24 V) LED lights (front)
4 x 50 W (24 V) LED lights (rear)
2 x Parking LED lights
1 x Stair and service lights
1 x Tramming alarm
1 x Carrier centralized greasing points (TS 5-2110-A)
1 x Electric filling pump for hydraulic oil
1 x Hand held fire extinguisher (type ABC)
1 x MySandvik Remote Monitoring
Sandvik standard colour scheme
Documentation:
2 x Operator's manual
2 x Maintenance manual
2 x Technical manual (in English only)
2 x Parts manual (in English only)
2 x Toolman CD

SANDVIK MINING AND CONSTRUCTION

UNDERGROUND DRILLS
P.O.Box 100
FIN 33311 TAMPERE, FINLAND
Tel. +358 205 44 121
Telefax +358 205 44 120
 9/9

UNIT IDENTIFICATION CARD

Sandvik DD321-40
SERIAL NO: 120D61492-1

Options
*End-of-hole air flushing (including CT28)
Air mist flushing kit (IP5 cleaner and flow control for external air and water)
*FOPS (ISO 3449) operator's canopy
Automatic greasing system for carrier and booms (2-boom)
High pressure (180 bar) cleaning system with reel (TS2-343)
Manual greasing unit with pump, reel and nozzle (TS 5-2110)
*Feed length 16' instead of 12' (two feeds)
Constant speed drilling (2-boom)
Drilling instrument: TCAD+ with TLOG and iSURE I (2-boom)
Automatic fire suppression system Sandvik Eclipse™ (Sustain)
Extra options
Keep RD520 - as standard unit.
Package: LAM specific options for DD321
Spare: RD520 rock drill
Special tools for RD520 and RD525 rock drills
