Engine Assembly

ENGINE ASSEMBLY
120D61492-1
TABLE OF CONTENTS Sandvik DD321-40 200824
9. ENGINE ASSEMBLY
* 552 128 41 NSS ENGINE ASSEMBLY.............................................................................................................................................. 2
** 551 673 76 NSS TANK, EXPANSION............................................................................................................................................ 10
** 550 368 85 GEARBOX AND TORQUE CONVERTER................................................................................................................... 13
*** 550 768 37 NSS CONVERTER HOUSING ASSEMBLY............................................................................................................ 16
*** 550 768 39 NSS TRANSMISSION, CASE & COVER................................................................................................................ 18
*** 550 768 40 NSS SHAFT ASSEMBLY, TURBINE....................................................................................................................... 20
*** 550 478 77 PLATE, FLEX........................................................................................................................................................... 22
*** 550 768 44 TORQUE CONVERTER ASSEMBLY...................................................................................................................... 24
*** 550 768 45 GEAR KIT................................................................................................................................................................ 26
*** 550 768 51 NSS PUMP DRIVE KIT........................................................................................................................................... 28
*** 550 768 53 NSS PUMP DRIVE KIT........................................................................................................................................... 30
*** 550 768 54 NSS SHAFT ASSEMBLY......................................................................................................................................... 32
*** 550 768 60 NSS GEAR............................................................................................................................................................... 36
*** 550 768 61 NSS GROUP, LOW SPEED SHAFT....................................................................................................................... 38
*** 550 768 69 PUMP ASSEMBLY................................................................................................................................................... 46
*** 550 768 73 NSS VALVE, GEAR CONTROL.............................................................................................................................. 48
**** 550 768 74 VALVE ASSEMBLY.............................................................................................................................................. 50
** 551 817 42 CONNECTING PIECE................................................................................................................................................. 52
** BG 006 047 42 NSS PIECE, CONNECTING................................................................................................................................. 54
** 550 472 41 PUMP ASSEMBLY....................................................................................................................................................... 55
** 551 712 35 NSS HOSE SET.......................................................................................................................................................... 58
* ENGINE MB OM 904 LA, TIER3, SEE SEPARATE CATALOGUE..................................................................................................
Sandvik Mining and Construction Oy Drills Tampere © 2020

552 128 41 dDg NSS
1 (59) ENGINE ASSEMBLY 200824
79 37 50 22 175 508 563
24 506 562
1
4 176 563
36 37
498 599 508 552
87
25 508 563
210 511 564
31 76 77
37 51 222 511 564
5 88 8 17 54 614 49 28 78 9
35 121 592 499 556
47 48 6 144 562 41 12 175 508 563 13 20
46 21 175 508 563
24 506 562
45
3
530 4 176 563
100 11 16
25 508 563
210 511 564 10 144 562
14 20
26
23 175 508 563
222 511 564

7 38 15 20
9 144 551 265 555 208 511 553

552 128 41 dDg NSS
200824 ENGINE ASSEMBLY 2 (59)
Ref. Part no. Description EN Standard designation Qty

e
1 552 128 30 DIESEL ENGINE SEE SEPARATE CATALOGUE 1
2 550 368 85 GEARBOX AND TORQUE CONVERTER SECTION 9 PAGE 13 1
3 551 571 35 COOLER Combi cooler MB OM 904 LA 1
4 550 856 74 PLATE, MOUNTING 2
5 550 855 67 BRACKET For engine assembly 1
. . . . .
6 550 834 35 GUARD D=6 1
7 550 417 54 BRACKET 1
8 550 417 68 BRACKET 1
9 550 418 32 BRACKET 2
10 550 957 96 GUARD Left guard for radiator fan, D=678 1
. . . . .
11 550 802 00 PIPE, INTAKE 1
12 550 421 79 PIPE, INTAKE 1
13 550 423 28 HOSE, RUBBER 1
14 550 423 00 HOSE, RUBBER 1
15 550 413 54 HOSE, RUBBER INTAKE PIPING 1
. . . . .
16 093 700 70 O-RING 85,09X5,33, NBR , 70 SHORE A 1
17 550 431 57 PLATE, COVER FOR ELECTRIC CONNECTORS 1
20 550 422 47 CLAMP, HOSE 90-110mm 6
21 550 421 90 PLATE 1
22 550 421 89 PLATE 1
. . . . .
23 552 102 12 PLATE 1
24 883 203 69 DAMPER, THREAD MOUNT 2
25 550 751 45 DAMPER, THREAD MOUNT D40/h30/M10 55shore 4
26 550 414 91 RUBBER PAD SET 6
28 551 817 42 CONNECTING PIECE SECTION 9 PAGE 52 1
. . . . .
31 550 672 95 PIPING, COOLER 1
35 551 713 29 SHEET, RUBBER Cover sheet for engine connectors. 1
36 550 667 23 ELBOW, RUBBER 1
37 550 204 53 CLAMP, HOSE 50-65 6
38 550 444 36 ELBOW ELBOW 1
. . . . .
41 551 673 76 NSS TANK, EXPANSION SECTION 9 PAGE 10 1
45 550 477 65 HOSE OIL FILLING HOSE 1.5
46 550 473 55 PIPE, SLEEVE Motor oil filling sleeve pipe 1
47 550 473 84 CAP, FILLING Motor oil filling cap 1
48 280 678 90 CLAMP, HOSE d50 2
. . . . .
50 550 801 21 HOSE, WATER 1
51 550 667 24 ELBOW, RUBBER RUBBER CURVE, ENGINE ASSY, MB 1
54 550 492 66 CONNECTOR 1
76 800 348 19 BONDED SEAL U d27, 2xD36xs2 SC 1
77 812 607 89 PLUG G3/4 1
. . . . .
78 816 708 79 SWIVEL NUT ELBOW 90 JIC 1,5/16-12, 90 deg 1
79 817 094 69 STRAIGHT THREAD ADAPTER G 1/2 x JIC 3/4-16 1
87 552 165 08 ADAPTER, HYDRAULIC JIC 1.5/16-12 2
88 550 442 96 STRAIGHT THREAD ADAPTER M16x1,5 / JIC 3/4-16 2
100 550 472 41 PUMP ASSEMBLY SECTION 9 PAGE 55 1
. . . . .

552 128 41 dDg NSS
79 37 50 22 175 508 563
24 506 562
1
4 176 563
36 37
498 599 508 552
87
25 508 563
210 511 564
31 76 77
37 51 222 511 564
5 88 8 17 54 614 49 28 78 9
35 121 592 499 556
47 48 6 144 562 41 12 175 508 563 13 20
46 21 175 508 563
24 506 562
45
3
530 4 176 563
100 11 16
25 508 563
210 511 564 10 144 562
14 20
26
23 175 508 563
222 511 564

7 38 15 20
9 144 551 265 555 208 511 553

552 128 41 dDg NSS

e
121 866 024 29 HEXAGON HEAD SCREW M6X12-8.8 2
144 AF0 010 0322 SCREW, HEXAGON HEAD, FULL THREAD M8x20 8
176 AF0 010 0637 SCREW, HEXAGON HEAD, PARTIAL M10x40 4
THREAD
. . . . .
210 AF0 010 0841 SCREW, HEXAGON HEAD, PARTIAL M12x60-8.8 Zn 8
THREAD
222 AF0 010 0850 SCREW, HEXAGON HEAD, PARTIAL M12x120 8
THREAD
498 550 473 45 HEXAGON SOCKET HEAD SCREW UNF 3/8x1 - 1 1/4 (32mm) - 10.9 8
499 065 355 03 HEXAGON HEAD SCREW 3/4 UNC X 1 3/4 GRADE 5 (45mm) 8
. . . . .
506 AF0 190 0004 NUT, HEXAGON, PREVAILING TORQUE M8 2
530 550 444 02 NUT, HEXAGON M10 MS 4
551 AF0 300 0030 WASHER, LOCK, PAIR NL8 2
. . . . .
555 AF0 300 0124 WASHER, LOCK, PAIR NL16-sp 8
. . . . .
592 800 509 69 WASHER M6 2
599 065 814 22 WASHER 10,5/18X1,6 16
614 AF0 310 0172 STUD, DOUBLE END M10x35 12
. . . . .
*49 550 478 77 PLATE, FLEX SECTION 9 PAGE 22 1

552 128 41 dDg NSS
61 600 80 81
GEARBOX COOLING
80
43 42
SPECIAL GENERATOR ASSEMBLY
870 60

552 128 41 dDg NSS

e
60 551 615 74 GUARD For alternator 1
61 551 526 30 SIGN Finger cover, Engine's blower 2
80 816 700 59 STRAIGHT THREAD ADAPTER G 1 x JIC 1 5/16-12 2
81 864 270 09 SWIVEL NUT ELBOW 45 45` ,1,5/16-12JIC 1
600 455 332 90 SCREW 2X5 8
. . . . .

552 128 41 dDg NSS
29 497 553 93
94
71
B
72
73
74
91 95
90
92
92
96 75 DETAIL B
75
89 97
27
27

552 128 41 dDg NSS

e
27 AF0 410 0020 BOLT, LIFTING EYE M16 Zn 2
29 BG 006 047 42 NSS PIECE, CONNECTING SECTION 9 PAGE 54 1
71 817 098 79 STRAIGHT THREAD ELBOW G 1/2 x JIC 3/4-16 1
72 865 407 99 ADAPTER, HYDRAULIC JIC 3/4-16 1
73 800 156 19 VALVE, BALL 2/2, p_max 16 bar 1
. . . . .
74 817 094 69 STRAIGHT THREAD ADAPTER G 1/2 x JIC 3/4-16 1
75 817 097 49 PLUG JIC 3/4-16 3
89 867 163 79 STRAIGHT THREAD ADAPTER 9/16-18 JIC 1
92 817 099 09 ADAPTER, HYDRAULIC JIC 3/4-16 2
93 283 356 60 SEAL, COPPER 27x32x2 1
. . . . .
94 550 562 40 ADAPTER, HYDRAULIC 1
95 864 095 09 STRAIGHT THREAD ELBOW JIC 3/4-16 1
96 817 163 39 ADAPTER, TEE 3/4-16 JIC 1
97 817 180 79 ELBOW, SWIVEL NUT 9/16-18JIC 1
497 857 012 49 HEXAGON SOCKET HEAD SCREW 1/2 in UNC X 2 1/4 in 1
. . . . .
889 551 712 35 NSS HOSE SET SECTION 9 PAGE 58 1

551 673 76 fF NSS
9 (59) TANK, EXPANSION 200824
30 1
574 508 31 8
15
55
8
8
16 7
9
14

551 673 76 fF NSS
200824 TANK, EXPANSION 10 (59)

e
1 550 395 18 TANK, SURGE 1
1.1 550 736 31 CAP, FILLING 75 kPa 1
1.2 BG 002 940 66 SIGHT GLASS Radiator Surge Tank 2
1.3 BG 003 852 45 DECAL Decal MIN MAX 1
7 280 675 00 CLAMP, HOSE 32 2
. . . . .
8 280 672 20 CLAMP, HOSE D 13-20 mm, Steel 5
9 551 922 76 SWITCH, LEVEL DC 9-36V, M14x1.5 1
14 550 448 72 HOSE Rubber 1
15 550 448 72 HOSE Rubber 1
16 800 923 29 WASHER 15 1
. . . . .
30 BG 006 196 38 BRACKET Expansion Tank 1
31 550 468 81 STRAP, METAL Expansion Tank 2
55 550 708 14 RUBBER SHEET For surge tank mounting 2
508 284 773 10 NUT, LOCK M10 - 8, Zn 4
574 AF0 230 0006 WASHER, PLAIN, NORMAL M10 4
. . . . .

551 673 76 fF NSS
11 (59) TANK, EXPANSION 200824
8 1 8 15
14 11 10 8
8
7
12
13 7
32 10 11 32
13

551 673 76 fF NSS
200824 TANK, EXPANSION 12 (59)

e
1 550 395 18 TANK, SURGE 1
1.1 550 736 31 CAP, FILLING 75 kPa 1
1.2 BG 002 940 66 SIGHT GLASS Radiator Surge Tank 2
1.3 BG 003 852 45 DECAL Decal MIN MAX 1
7 280 675 00 CLAMP, HOSE 32 2
. . . . .
8 280 672 20 CLAMP, HOSE D 13-20 mm, Steel 5
9 551 922 76 SWITCH, LEVEL DC 9-36V, M14x1.5 1
10 816 702 09 STRAIGHCT THREAD ADAPTER 9/16-18 JIC 1
11 886 915 49 FITTING 90 deg JIC 1
12 550 448 70 HOSE Rubber 1
. . . . .
13 550 448 71 HOSE Rubber 1
14 550 448 72 HOSE Rubber 1
15 550 448 72 HOSE Rubber 1
32 BG 004 979 27 GROMMET 2

550 368 85 b
13 (59) GEARBOX AND TORQUE CONVERTER 200824
18 17 11 8
7 5 3 1
16
15
10 9 6 2
14 13 12

e
1 550 768 37 NSS CONVERTER HOUSING ASSEMBLY SECTION 9 PAGE 16 1
2 550 768 39 NSS TRANSMISSION, CASE & COVER SECTION 9 PAGE 18 1
3 550 768 40 NSS SHAFT ASSEMBLY, TURBINE SECTION 9 PAGE 20 1
4 550 478 77 PLATE, FLEX SECTION 9 PAGE 22 1
5 550 768 44 TORQUE CONVERTER ASSEMBLY SECTION 9 PAGE 24 1
. . . . .
6 550 768 45 GEAR KIT SECTION 9 PAGE 26 1
7 550 768 51 NSS PUMP DRIVE KIT SECTION 9 PAGE 28 1
8 550 768 53 NSS PUMP DRIVE KIT SECTION 9 PAGE 30 1
9 550 768 54 NSS SHAFT ASSEMBLY SECTION 9 PAGE 32 1
. . . . .
11 550 768 60 NSS GEAR SECTION 9 PAGE 36 1
12 550 768 61 NSS GROUP, LOW SPEED SHAFT SECTION 9 PAGE 38 1
. . . . .
16 550 768 69 PUMP ASSEMBLY SECTION 9 PAGE 46 1
17 550 768 73 NSS VALVE, GEAR CONTROL SECTION 9 PAGE 48 1
18 550 268 55 SEAL KIT Incl. all seals and gaskets 1

550 768 37 NSS
15 (59) CONVERTER HOUSING ASSEMBLY / GEAR T20000 200824

550 768 37 NSS
200824 CONVERTER HOUSING ASSEMBLY / GEAR T20000 16 (59)

e
1 560 079 99 HOUSING, CONVERTER 1
2 046 913 90 BUSHING 2
3 046 952 90 PLUG 1
4 046 995 73 PLUG 1
5 046 912 67 SEAL 1
. . . . .
6 046 991 81 SCREW 18
7 046 991 82 WASHER 18
8 046 913 86 PIN 1
9 046 990 51 LOCK 2
10 046 991 75 SCREW 2
. . . . .
11 046 943 01 WASHER 2
12 046 995 56 BREATHER 1
13 046 971 54 PLUG INCL. PARTS 14 5
14 046 998 07 O-RING 5
15 046 913 87 PLUG 1
. . . . .
16 046 913 88 O-RING 1
17 046 913 89 SCREW 1

550 768 39 NSS
17 (59) TRANSMISSION, CASE & COVER 200824

550 768 39 NSS
200824 TRANSMISSION, CASE & COVER 18 (59)

e
1 560 092 63 CASE, TRANSMISSION 1
2 046 913 79 PIPE 1
3 046 913 80 O-RING 1
4 046 995 81 PIPE 1
5 047 005 32 BUSHING 4
. . . . .
6 046 913 81 PIPE 1
7 046 913 82 CLAMP 1
8 046 995 92 SCREW 1
9 046 991 82 WASHER 1
10 046 971 54 PLUG INCL. PARTS 11 1
. . . . .
11 046 998 07 O-RING 1
12 046 985 92 PLUG 2
13 046 997 00 O-RING 2
14 046 913 83 COVER, REAR 1
15 046 971 54 PLUG INCL. PARTS 16 1
. . . . .
16 046 998 07 O-RING 1
17 046 913 84 PLATE 1
18 046 913 85 SEAL 1
19 046 995 80 O-RING 4
20 046 993 77 O-RING 1
. . . . .
21 046 913 86 PIN 2
22 046 912 53 SCREW 20
23 046 991 82 WASHER 20
24 047 007 08 PLUG 2
25 047 008 28 PLUG 1
. . . . .
26 046 913 87 PLUG 2
27 046 913 88 O-RING 2
28 046 913 89 SCREW 2
30 046 952 19 COVER 1
31 046 998 30 GASKET 1
. . . . .
32 046 951 37 SCREW 2
33 047 004 89 WASHER 2
34 046 995 94 TUBE, DIPSTICK 1
35 046 995 95 DIPSTICK ASSEMBLY 1

550 768 40 NSS
19 (59) SHAFT ASSEMBLY, TURBINE / GEAR T20000 200824

550 768 40 NSS
200824 SHAFT ASSEMBLY, TURBINE / GEAR T20000 20 (59)

e
1 560 080 00 SHAFT ASSEMBLY, TURBINE INCL. PARTS 2 1
2 046 987 04 CIRCLIP 1
3 046 914 20 BEARING 1
4 046 957 96 RING, LOCK 1
5 046 996 33 WASHER, THRUST 1
. . . . .
6 047 009 05 CIRCLIP 1
7 560 010 42 RING, PISTON 1
8 560 092 66 SUPPORT 1
9 046 910 93 SCREW 6
10 046 967 52 RING, PISTON 1
. . . . .
11 887 828 19 BAFFLE OIL BAFFLE & SEAL ASSY INCL. PARTS 1
12
12 046 993 67 SEAL 1
13 884 148 19 RING, SEAL 1
14 046 982 42 CIRCLIP 1

550 478 77 b
21 (59) PLATE, FLEX / DRIVE PLATE KIT 200824

550 478 77 b
200824 PLATE, FLEX / DRIVE PLATE KIT 22 (59)

e
3 550 278 70 RING 1
4 550 768 43 SCREW CAP SCREW 6
5 550 174 91 WASHER 6

550 768 44
23 (59) TORQUE CONVERTER ASSEMBLY / GEAR T20000 200824

550 768 44
200824 TORQUE CONVERTER ASSEMBLY / GEAR T20000 24 (59)

e
1 615 088 35 TORQUE CONVERTER TORQUE CONVERTER ASSY 1203F 1
2 046 977 03 BEARING 1
3 560 092 68 BACK UP RING 1
4 046 995 45 PLUG 1
5 046 995 44 O-RING 1
. . . . .
6 046 995 46 CIRCLIP 1
7 560 056 16 RING, RETAINING 2

550 768 45
25 (59) GEAR KIT / GEAR GROUP, T20000 200824

550 768 45
200824 GEAR KIT / GEAR GROUP, T20000 26 (59)

e
1 046 913 94 GEAR WHEEL 1
2 550 768 46 GEAR WHEEL 1ST. DRIVE 1
3 550 768 47 GEAR WHEEL LOW CLUTCH 1
4 560 080 14 WHEEL Idler gear wheel 1
5 550 768 49 GEAR WHEEL FRONT IDLER 1
. . . . .
6 550 768 50 GEAR WHEEL OUTPUT 1

550 768 51 NSS
27 (59) PUMP DRIVE KIT / AUXILIARY PUMP 200824

550 768 51 NSS
200824 PUMP DRIVE KIT / AUXILIARY PUMP 28 (59)

e
1 560 092 70 RETAINER, BEARING 1
2 560 092 71 SCREW 1
3 560 092 72 PIN 1
4 560 092 74 BALL 1
5 046 979 64 RING, BACKING 1
. . . . .
6 560 092 75 GEAR WHEEL 1
7 046 985 36 COVER 1
8 560 085 95 GASKET 1
9 046 988 65 SCREW 2
10 047 003 11 WASHER 2
. . . . .

550 768 53 NSS
29 (59) PUMP DRIVE KIT / CHARGING PUMP 200824

550 768 53 NSS
200824 PUMP DRIVE KIT / CHARGING PUMP 30 (59)

e
1 560 092 70 RETAINER, BEARING 1
2 560 092 72 PIN 1
3 560 092 71 SCREW 1
4 560 092 74 BALL 1
5 046 979 64 RING, BACKING 1
. . . . .
6 560 092 77 GEAR WHEEL 1
7 560 092 78 GEAR WHEEL 1
8 560 085 98 SHAFT 1
9 046 994 97 BALL 1
10 047 006 65 BEARING 1
. . . . .
11 046 979 62 CIRCLIP 2
12 046 996 15 RING 2

550 768 54 NSS
31 (59) SHAFT ASSEMBLY / FORWARD SHAFT GROUP 200824

550 768 54 NSS
200824 SHAFT ASSEMBLY / FORWARD SHAFT GROUP 32 (59)

e
1 550 768 55 SHAFT AND DRUM ASSEMBLY FWD SHAFT, DRUM & PLUG 1
2 615 096 47 PISTON, CLUTCH INCL. PARTS 3-4 1
3 046 996 62 RING, PISTON 1
4 046 996 63 SEAL 1
5 046 996 65 CLUTCH DISC 8
. . . . .
6 046 996 60 CLUTCH DISC 8
7 046 996 01 BUSHING 1
8 550 768 56 PLATE, END END PLATE 1
9 046 996 58 RING 1
10 046 976 61 DISC SPRING KIT 1
. . . . .
11 046 995 99 RING 1
12 560 086 02 RING, PISTON 2
13 046 996 11 BEARING 1
14 046 914 01 BEARING 1
15 046 996 09 RING 1
. . . . .
16 046 914 02 RING, RETAINING 1
17 550 768 46 GEAR WHEEL 1ST. DRIVE 1

550 768 57 NSS
33 (59) SHAFT ASSEMBLY / REVERSE & 2ND SHAFT GROUP 200824

550 768 57 NSS
200824 SHAFT ASSEMBLY / REVERSE & 2ND SHAFT GROUP 34 (59)

e
1 550 768 58 SHAFT AND DRUM ASSEMBLY REV & 2ND SHAFT, DRUM & PLUG 1
3 046 996 62 RING, PISTON 1
4 046 996 63 SEAL 1
5 046 914 10 CLUTCH 1
. . . . .
6 046 996 62 RING, PISTON 1
7 046 996 63 SEAL 1
8 046 996 65 CLUTCH DISC 8
9 046 996 65 CLUTCH DISC 6
10 046 996 60 CLUTCH DISC 8
. . . . .
11 046 996 60 CLUTCH DISC 6
12 046 996 01 BUSHING 1
14 046 996 58 RING 2
15 046 996 02 SPRING 1
. . . . .
16 046 996 03 RETAINER, SPRING 1
17 046 976 61 DISC SPRING KIT 1
18 046 996 04 CIRCLIP 1
19 047 006 81 BEARING 1
20 047 006 79 BEARING 1
. . . . .
21 046 995 96 RING 2
22 046 978 95 BEARING 1
23 046 967 75 CIRCLIP 1
24 047 007 92 CIRCLIP 1
25 560 086 02 RING, PISTON 3
. . . . .
26 046 995 99 RING 1
27 046 914 11 HUB 1
28 046 996 04 CIRCLIP 1
29 046 914 12 BEARING 1
30 046 914 13 STOPPER 1
. . . . .
31 046 914 14 STOPPER 1
32 046 914 15 BUSHING 1
33 046 913 94 GEAR WHEEL 1

550 768 60 NSS
35 (59) GEAR / REVERSE IDLER GROUP 200824

550 768 60 NSS
200824 GEAR / REVERSE IDLER GROUP 36 (59)

e
1 560 080 05 SHAFT 1
2 046 995 66 BEARING TIMKEN LM603049 ASM 90025 1
3 046 914 04 WASHER 1
4 046 914 05 NUT 1
5 046 914 06 LOCK DEVICE 1
. . . . .
6 046 987 15 BALL 1
7 046 914 07 GEAR WHEEL 1
8 046 914 08 O-RING 1

550 768 61 NSS
37 (59) GROUP, LOW SPEED SHAFT 200824

550 768 61 NSS
200824 GROUP, LOW SPEED SHAFT 38 (59)

e
1 560 080 08 SHAFT ASSEMBLY 1
2 046 914 17 CLUTCH 1
3 046 996 62 RING, PISTON 1
4 046 996 63 SEAL 1
5 046 996 59 CLUTCH DISC 8
. . . . .
6 046 996 60 CLUTCH DISC 8
8 046 996 58 RING 1
9 046 914 18 SPRING 1
10 046 996 04 CIRCLIP 1
. . . . .
11 046 914 19 BUSHING 1
12 886 878 59 BEARING BEARING 1
13 046 956 20 BEARING 1
14 046 981 35 CIRCLIP 2
15 046 992 38 RING, PISTON 1
. . . . .
16 046 914 20 BEARING 1
17 046 914 21 BUSHING 1
18 046 914 22 BEARING 1
19 046 957 96 RING, LOCK 1
20 046 914 23 SPRING 1
. . . . .
21 550 768 47 GEAR WHEEL LOW CLUTCH 1

550 768 63 NSS
39 (59) SHAFT ASSEMBLY / 3RD SHAFT GROUP 200824

550 768 63 NSS
200824 SHAFT ASSEMBLY / 3RD SHAFT GROUP 40 (59)

e
1 550 768 64 SHAFT AND DRUM ASSEMBLY 3RD SHAFT, DRUM & PLUG 1
3 046 996 62 RING, PISTON 1
4 046 996 63 SEAL 1
5 046 996 65 CLUTCH DISC 6
. . . . .
6 046 996 60 CLUTCH DISC 6
8 046 996 58 RING 1
9 046 996 02 SPRING 1
10 046 996 03 RETAINER, SPRING 1
. . . . .
11 046 996 04 CIRCLIP 1
12 046 967 75 CIRCLIP 1
13 046 978 95 BEARING 1
14 047 007 92 CIRCLIP 1
15 560 086 02 RING, PISTON 2
. . . . .
16 046 987 19 GEAR 1
17 046 996 06 RING 1
18 046 914 12 BEARING 1

550 768 65 NSS
41 (59) SHAFT ASSEMBLY / IDLER SHAFT GROUP 200824

550 768 65 NSS
200824 SHAFT ASSEMBLY / IDLER SHAFT GROUP 42 (59)

e
1 550 768 66 GEAR SHAFT IDLER SHAFT 1
2 046 914 20 BEARING 1
3 046 957 96 RING, LOCK 1
4 046 914 26 BEARING 1
5 047 007 41 NUT 1
. . . . .
6 047 005 09 WASHER 1
7 046 996 56 SPACER 1
8 046 991 17 CIRCLIP 1
9 550 768 49 GEAR WHEEL FRONT IDLER 1
10 560 080 14 WHEEL Idler gear wheel 1
. . . . .

550 768 67 NSS
43 (59) SHAFT ASSEMBLY / OUTPUT SHAFT GROUP 200824

550 768 67 NSS
200824 SHAFT ASSEMBLY / OUTPUT SHAFT GROUP 44 (59)

e
1 550 768 68 GEAR SHAFT OUTPUT 1
2 046 914 28 BEARING 1
3 046 986 43 BEARING 1
4 046 969 98 RING, LOCK 1
5 047 006 64 CIRCLIP 2
. . . . .
6 046 914 29 SEAL 2
7 046 987 22 STUD 4
8 046 992 06 WASHER 4
9 046 996 46 NUT 4
10 046 914 30 BEARING 1
. . . . .
11 046 996 51 GASKET 1
12 615 096 49 SPACER RING SPACER RING 1
13 046 996 56 SPACER 1
14 886 881 79 O-RING O-RING 2
15 047 005 09 WASHER 2
. . . . .
16 047 007 41 NUT 2
17 550 768 50 GEAR WHEEL OUTPUT 1
18 046 983 12 FLANGE 1
19 046 983 12 FLANGE 1

550 768 69 a
45 (59) PUMP ASSEMBLY / CHARGING PUMP & FILTER 14.5 GPM 200824

550 768 69 a
200824 PUMP ASSEMBLY / CHARGING PUMP & FILTER 14.5 GPM 46 (59)

e
1 BG 008 283 60 PUMP, CHARGING 240-280psi 1
2 046 975 05 FILTER 1
3 852 033 49 GASKET PUMP ASSY 1
4 046 993 77 O-RING 1
5.1 550 768 71 SCREW SCREW 1
. . . . .
5.2 550 768 72 SCREW SCREW 4
6 046 991 82 WASHER 5

550 768 73 NSS
47 (59) VALVE, GEAR CONTROL / VALVE 3 SPEED GROUP 200824

550 768 73 NSS
200824 VALVE, GEAR CONTROL / VALVE 3 SPEED GROUP 48 (59)

e
1 550 768 74 VALVE ASSEMBLY SECTION 9 PAGE 50 1
2 550 768 75 GASKET GASKET 1
3 047 005 24 HEX BOLT 4
4 047 004 88 SCREW 3
5 046 999 97 SCREW 2
. . . . .
6 047 004 89 WASHER 9

550 768 74
49 (59) VALVE ASSEMBLY 200824

550 768 74
200824 VALVE ASSEMBLY 50 (59)

e
1 550 770 74 SOLENOID DEUTCH 24V 4
2 046 995 73 PLUG 8
3 550 770 75 BODY, VALVE - 1
4 550 770 76 PLATE, COVER COVER FOR SOLENOID 1
5 550 770 77 SCREW CAP SCREW 10
. . . . .

551 817 42
51 (59) CONNECTING PIECE / TRANSMISSION OIL HOSING 200824
5 6

551 817 42
200824 CONNECTING PIECE / TRANSMISSION OIL HOSING 52 (59)

e
1 550 428 53 PIECE, CONNECTING TRANSMISSION OIL HOSING 1
2 816 703 39 SWIVEL NUT MALE ADAPTER 1,5/16-12 JIC 1
4 816 885 99 FITTING, QUICK CONNECT 1
5 869 054 89 TRANSDUCER, TEMPERATURE 1
. . . . .
6 800 987 99 SEAL, COPPER A14X18 CU 1
7 550 299 75 PLUG M14x1,5 1

BG 006 047 42 cC NSS
53 (59) PIECE, CONNECTING 200824
20
1
51
3
23
8
2
20
22
21
50
23

BG 006 047 42 cC NSS
200824 PIECE, CONNECTING 54 (59)

e
1 BG 005 749 65 PIECE, CONNECTING 1
2 550 431 51 SENSOR TRANSMISSION OIL PRESSURE 1
3 BG 005 756 81 BREATHER Filter for two-way ventilation 2
8 800 987 99 SEAL, COPPER A14X18 CU 1
20 AF1 015 0002 ADAPTER, MALE STUD ELBOW JIC 7/16 - BSPP 1/4 2
. . . . .
22 AF1 028 0005 ADAPTER, MALE STUD ELBOW JIC 9/16 - M 14x1.5 1
23 AF1 014 0002 ADAPTER, MALE STUD CONNECTOR JIC 7/16 - BSPP 1/4 4
50 806 448 09 PLUG G1/4 1
51 AF1 146 0002 ADAPTER, SWIVEL NUT ELBOW JIC 7/16 1

550 472 41 dD
55 (59) PUMP ASSEMBLY 200824
9 10 11
3 4
5 6
7 8

e
1 550 394 71 HYDRAULIC PUMP, EXTERNAL GEAR, 16cc+16cc 1
DOUBLE
1.1 550 394 60 SEAL KIT 2
3 817 095 99 ADAPTER 3/4-16 JIC 2
4 817 163 39 ADAPTER, TEE 3/4-16 JIC 2
. . . . .
5 850 778 99 CONNECTOR, PRESSURE GAUGE 9/16-18 JIC 2
6 816 885 99 FITTING, QUICK CONNECT 2
7 818 001 09 NUT JIC 3/4-16 2
8 853 780 09 REDUCER, TUBE END 9/16JIC, 3/4X 2
9 550 443 93 GASKET For SAE B pump flange 1
. . . . .
10 451 335 30 HEXAGON HEAD SCREW 1/2 UNCX32 M8.8 2

551 712 35 D NSS
57 (59) HOSE SET / DIESEL MOTOR ASSEMBLY 200824
61 600 80 81
GEARBOX COOLING
80
43 42
SPECIAL GENERATOR ASSEMBLY
870 60

551 712 35 D NSS
200824 HOSE SET / DIESEL MOTOR ASSEMBLY 58 (59)

e
42 592 009 53 HOSE ASSEMBLY, HYDRAULIC 1SN16MS AD-1800-JIC 1
43 592 009 55 HOSE ASSEMBLY, HYDRAULIC 1SN BC-16-J16A-J16A-0-0-1150 1
90 592 009 27 HOSE ASSEMBLY, HYDRAULIC 2SC08MS AB-600-JIC 1
91 592 009 25 HOSE ASSEMBLY, HYDRAULIC 2SC08MS AA-900-JIC 1

Engine Assembly

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Engine Assembly

Uploaded by

Copyright:

Available Formats

ENGINE ASSEMBLY

Sandvik Mining and Construction Oy Drills Tampere © 2020

79 37 50 22 175 508 563

498 599 508 552

37 51 222 511 564

35 121 592 499 556

47 48 6 144 562 41 12 175 508 563 13 20

46 21 175 508 563

530 4 176 563

210 511 564 10 144 562

222 511 564

9 144 551 265 555 208 511 553

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

79 37 50 22 175 508 563

498 599 508 552

37 51 222 511 564

35 121 592 499 556

47 48 6 144 562 41 12 175 508 563 13 20

46 21 175 508 563

530 4 176 563

210 511 564 10 144 562

222 511 564

9 144 551 265 555 208 511 553

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

SPECIAL GENERATOR ASSEMBLY

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty
