Abstract
The aim for this lab was to calibrate a gap-meter for measuring fluid flow using the
volumetric method. The gap meter was set at readings of 0, 4, 8, 12, 16 & 20 to measure the
volume of water flowing though the meter, and the time taken. The data used to calculate the
average mass flow rate for meter-calibration. A calibration for the gap-meter was obtained by
plotting the average mass flow rate against meter scale readings. A linear calibration equation
of: y=0.0183 x +0.0473 was obtained. This equation gives the correlation between meter
scale reading and mass flow rate. The calibration curve failed to pass through the origin as
Introduction
A Gap-meter is a flow measurement instrument that is used to measure the rate of fluid flow
through a pipe or a system. For professional use where flow measurements are critical, it is
important that the flow measurements become accurate (LaNasa & Loy Upp, 2014). This
makes it crucial to calibrate the flow meter to assure that the measurements are highly
accurate as specified, because flow meters can be out of calibration. Calibration is the process
Like any other instrument, the performance of a gap-meter depreciates over time as parts
break or wear out. Flow measurement devices can also be affected by corrosion or
accumulated dirt delivered by the fluid flowing through them, or get damaged by improper
installation, variations in the flow process, or impact (Hardy, et al., 1999). Thus, the need to
ensure that flow meters are properly calibrated to deliver accurate flow measurement
readings. Accurate flow measurements are used by control and instrumentation engineers to
monitor and regulate the rate and efficiency of industrial devices and processes (Integrated
This lab aimed to use the volumetric method to calibrate a gap-meter that can be used to
measure fluid flow more accurately. It was expected that the calibration graph for predicting
fluid mass flow rate will be linear, passing through the origin.
Methodology
4
Procedure:
Initially, the flow control valve was adjusted so that the gap-meter scale reading was at zero.
The flow rate was measured in three trials using the volumetric method. The three flow
measurements were used to calculate the average mass flow rate. This procedure was
repeated with the gap-meter scale readings of 4, 8, 12, 16, & 20.
Results
Sample calculation:
At meter reading of zero, volume of water passing through the meter is 200 ml for the first
trial.
Mass flow rate ¿ [mass of water ÷ time ] ¿ 0.2 kg /4.06 sec=0.049 kg/ sec
The other two trials were repeated as shown in the above calculation and the average mass
flow rate of the three measurements calculated and found to be 0.049 kg/sec.
When the average mass flow rates for different gap-meter readings were plotted against the
meter scale readings, the graph shown in figure 1 below was obtained.
0.3
0.25
0.2
0.15
0.1
0.05
0
0 5 10 15 20 25
Meter reading
From the calibration curve presented in figure 1 above, the calibration equation of the gap-
meter is:
y=0.0183 x +0.0473
Where:
From this equation, it is possible to predict the mass flow rate of water through the meter at
any scale reading. It was expected that the curve will pass through the origin because the rate
of fluid flow is directly proportional to gap-meter reading. However, it is observed that zero
meter reading, there are small flow rates being recorded. This was not expected because at
full closure of the valve, there is supposed to be zero flow. This is likely to be caused by the
meter-gap itself; either damaged, worn out, fouled or improperly installed (National
Measurement System (U.K.), 2019). There was also some leakages observed from the
hydraulic bench and this could have contributed to lower volume measurements of water
flow. In addition to instrumental errors mentioned above, there is also the possibility of
human error. It is possible that parallax error may have occurred when taking volume
These errors can be avoided or minimized by ensuring that the flow measurement device is in
good working condition prior to the calibration exercise. Parallax error can be avoided by
ensuring that water volume readings are taken in a position that is perfectly horizontal to the
water level. The person operating the stop watch should be extra-keen and concentrate on the
experiment to minimize timing errors. These steps can improve the outcome of this
experiment.
7
References
Baker, R. C., 2002. An Introductory Guide to Flow Measurement. 2 ed. London, U.K.: John
Hardy, E. J. et al., 1999. Flow Measurement Methods and Applications. London, U.K.: John
Integrated Flow Solutions (IFS) LLC, 2019. How to Calibrate a Flow Meter & Calibration
Procedures. [Online]
LaNasa, J. P. & Loy Upp, E., 2014. Fluid Flow Measurement: A Practical Guide to Accurate
National Measurement System (U.K.), 2019. The calibration of flow meters. [Online]
Available at:
https://www.tuv-sud.co.uk/uploads/images/1523011053028922650326/calibration-of-flow-
meters.pdf
