Alarm Message

INSTRUCTION MANUAL
WIRE ELECTRICAL DISCHARGE MACHINE
ALARM MESSAGE
(ALARM, MESSAGE, GUIDE)
MAKINO MILLING MACHINE CO., LTD.

10WC4-ND01-0201(E)
PRECAUTIONS:
1. In general, function not covered by this manual cannot be used.

2. Be sure to observe notes provided in the manual, otherwise functions won ’t operation
properly and the system could be affected adversely.
3. Specifications in the manual are subject to change for improvement without notice.
4. If you have any uncertainty about descriptions in the manual, please contact us.
TABLE OF CONTENTS
Page
1. HOW TO SEE THE ALARM MESSAGE LIST ..................................................... 1
1.1 Trouble Remedy List .............................................................................................. 2
1.2 Resetting Method ................................................................................................... 3
1.3 Dialog Box .............................................................................................................. 4
1.4 Classification of Message Numbers ..................................................................... 5
1.5 Confirming Contents of Alarm .............................................................................. 5
1.6 Confirming Conditions in Which Alarm Occurs .................................................. 6
1.7 Operation Buttons and Keyboard ......................................................................... 7
2. DESCRIPTION OF MESSAGES ............................................................................ 8
3. ALARM MESSAGE (INDEX) .................................................................................. 290

Alarm Message WIRE EDM
1. HOW TO SEE THE ALARM MESSAGE LIST

Section 2 "Description of Alarms" describes all messages registered to the MGW-JL and subsequent
power supply units in order of message numbers. If the message number is unknown, check it in
Section 3 "Index" (alphabetical order). The MGW-J in the text is a generic name of MGW-JL and
MGW-J1. Also, the MGW-K is a generic name of MGW-K, MGW-K2, MGW-N, MGW-N2, and MGW-
N3. For the alarms that will occur in a different way depending on the machine model, the machine
model such as U32K or EU64 is mentioned.
Also, the messages larger than No.10000 are displayed on the models of the MGW-R or later power
supply units. If the messages less than No.10000 are displayed on the models of the MGW-R or later
power supply units, these messages are compatible with the MGW-K.
The EIS card in the text is a generic name of EIS, EIS2, and EIS3 cards. For the alarms having
different meaning depending on the cards, the card name is mentioned.
No. Name Level Reset
Cause:
Remedy:
Number : Indicates the message number.

Name : Indicates the name displayed in the message area of the screen.
Level : Indicates the level for the trouble remedy. (See the Trouble Remedy List on the next
page.)
"Guide" : Displays message in white letters.
"Warning 1 to 3" : Displays message in yellow letters.
"Alarm 1 to 3" : Displays message in red letters.
"Dialog" : Displays message in dialog.
(See 1.3 Dialog Box.)
Reset : Indicates resetting method of trouble occurred. (See the Resetting Method on the next
page.)
Cause : Indicates cause of trouble.
Remedy : Indicates how to remove trouble.
* The number and name are displayed on the screen.

[Example]
0001: EMERGENCY STOP
How to See The Alarm Message List 1

WIRE EDM Alarm Message
[Note 1] Alarm messages not registered to this alarm message list may be displayed
because of addition or change of functions. If you don’t understand the meaning
of displayed massage, stop the operation and contact us immediately.
[Note 2] Some messages may not be displayed depending on the machine model, even if
they have been registered to this list. Please contact us whenever you are
uncertain.
1.1 Trouble Remedy List
Trouble remedy (minor major)

Classification
Level Test Run
of trouble Guide Diagnosis Starting Machining Servo
mode mode
display list display disabled power OFF OFF
stop stop
Alarm Alarm 3
Alarm 2
Alarm 1
Warning Warning 3
Warning 2
Warning 1
Operator
Guide
message
Dialog
Dialog Operation cannot continue
message
"Test mode stop" refers to the warning or alarm where the dry run or the operation with GRAPHIC
screen stops.
"Run mode stop" refers to the warning or alarm where actual machining stops.
2
1.2 Resetting Method
(1) Alarm 1, 2, 3 : Press RESET key.
WARN
(2) Warning 1, 2, 3 : Press RESET key.
WARN
(3) Guide : Press RESET key.
Or, if the key-in line is selected

ENTER
Press , or key, and the message is
cleared automatically.
Note: Though the warning 1, 2, 3 or the guide can be reset also with the RESET key, two
keys have different functions as mentioned below, thus bewaring of the key
operation.
WARN
RESET : Clears the message, but continues operation.
RESET : Deletes message and stops action at this time.
The operation cannot continue.

1.3 Dialog Box

A dialog box is popped up and current operation is suspended.
No further operation can continue until the button is pressed to close the dialog box.
This dialog box appears for system errors, etc. where the operation cannot continue, and therefore
usually the operation quits immediately.
However, there is a way to continue the operation as it is for saving the edited data or grasping the
situation. (Exit and restart the operation at customer’s convenience. However, the data for which the
error occurred cannot be saved actually.)
In such a case, a similar error could occur after the dialog box was closed, and thus you may select
the error ignoring function.
Dialog box display example
Error occurred. Reboot the NC unit. Operation guidance
10001 MESSAGE TEXT NOT FOUND Guide message
Press [Continue] button to ignore the error and continue the operation.
Error handling, if continued

Ignore Ignore Operation continue
Continue Same
All button
Error
Error value: Error value
Kind and meaning of buttons
: The operation of the screen can continue successively, but the operation will not be
Continue normal. Use this for saving current data temporarily or grasping the situation.
Ignore : Check this box and press the [Continue] button, and all errors that may occur in the
All future are ignored.
Ignore : Check this box and press the [Continue] button, and the error that may occur by the
Same
Error same cause in the future is ignored.
4
1.4 Classification of Message Numbers
Number Group Contents
0001 – 0999 (Emerency stop levels)

1000 – 1999 (NC program errors)
2000 – 2999 (Machining power errors)
3000 – 3999 (Machine control errors)
4000 – 4999 (Machine alarms)
5000 – 5999 (EIS alarms)
6000 – 6999 (Man-machine messages)
7000 – 7999 (Driver detection alarms)
1000 – (AVOH message)
1.5 Confirming Contents of Alarm

Confirm the message number and its description on the DIAGNOSE screen, if an alarm or warning
occurs.
Notes: (1) The last one is displayed in the status bar if two or more message occurs.
(2) The quantity of alarms and warnings is displayed “status display tab” of the screen
right side.
(3) The message No., name and occurs time are displayed on the DIAGNOSE, (ALARM
or WARNING) screen.

1.6 Confirming Conditions in Which Alarm Occurs

Before contacting use to ask for help, please make sure the following items:
(1) Confirm in detail that when and what alarm occurred under what conditions.
(2) Confirm the alarm or warning message No. and its contents.
Confirm the power supply unit name and the software version number on the DIAGNOSE
VERSION screen or DIAGNOSE MAINTENANCE screen.
(3) In the automatic mode
Confirm the program No., sequence No. and contents of program.
Confirm setting conditions on NC FUNC screen and SET screen (OFFSET, etc.).
(4) In the manual mode
Confirm the contents of operation (including pre- and post-operations).
(5) Check whether the same alarm recurs when the same operation is executed again, and confirm
its frequency.
(6) Check whether the same alarm recurs when the conditions are changed.
Try to change the contents of program and operating procedure.
* If “No Text FOR MESSAGE” or “NPC SYSTEM ERROR” occurred, please contact us after confirm-
ing the situations where the error occurred and the message number.
6
1.7 Operation Buttons and Keyboard

The operation buttons and keyboard are different in notation between MG W-R and MGW-K
generators (see table below).
As this manual gives descriptions using the notation for the MGW-K generator, understand the
operation buttons and keyboard by applying the notation for the MGW-R generator.
MGW-R generator MGW-K generator Description
START
START
(Main ope panel & portable Starts automatic operation
(Portable operation panel only)
operation panel)
STOP STOP Stops functional operation
RESET RESET Resets the alarm
WARN RESET WARN RESET Resets the warning and guide
BUZZER OFF BUZZER OFF Stops buzzer sounding
SEARCH Command key for search
DEL ERASE Command key for erasure
ADD IN Command key for addition
ENTER IN Command key for input
HELP HELP Help display
PAGE UP + Page changeover (+)
PAGE DOWN – Page changeover (–)
F buttons
Note. LF buttons (left) and BF
buttons (bottom) are provided, Function keys Select respective functions
and they are referred to as F
buttons.
OT RELEASE
(NC FUNC screen)
OT RELEASE
OT RELEASE Overtravel release key
(Main operation panel)
(Main operation panel)
[CE machines]

2. DESCRIPTION OF MESSAGES
0001 EMERGENCY STOP Alarm 3 See Remedy.
Description : The EMERGENCY STOP signal was turned on (ESP=1).
Causes : (1) The EMERGENCY STOP switch was pressed.

(2) Either ±X, ±Y, ±U, ±V, ±Z, or ±C axis overran and it actuated the OVERTRAVEL limit
switch.
Remedy : In the case of (1), reset the EMERGENCY STOP switch.

In the case of (2), in the manual mode, press simultaneously the OT RELEASE key on
the POSITION screen 2 and the RESET key to turn on the servo. Then, with
OT RELEASE key kept pressed, return the axis that actuated the over travel limit switch
with axis select key.
Note: At this time, take care not to move extremely in the opposite direction
(dangerous zone).
After executing (1) or (2), press the RESET key and execute the reference point return
operation.
0002 NC, +24 VDC DROP Alarm 3 See Remedy.
0003 NC, +15 VDC DROP Alarm 3 See Remedy.
0004 NC, –15 VDC DROP Alarm 3 See Remedy.
Description : The +24 VDC power voltage in NC unit dropped (below 19 V).
The +15 VDC power voltage in NC unit dropped (below 11 V).
The –15 VDC power voltage in NC unit dropped (ober –8 V).
Causes : (1) Defective switching power supply.

(2) Shorted power supply line.
Remedy : Either VBB, VMC, V0H, or EIS card is faulty.

Alarm related to power supply (faulty power unit).
Contact to us.
8
0005 FLAME SENSOR ON Warning 3 See Remedy.
Cause : On the machine with a flame sensor, the flame sensor operated. (*FLM=0)
Remedy : (1) If no abnormality is found due to a fire, make sure the safety, then restart machining.
(2) If this message is displayed frequently, the flame will be defective. Check the input
signal, and please contact us.
0007 FIRE EXTINGUISHER OPERATED Alarm 3 See Remedy.
Description : On the machine with a fire extinguisher, the fire extinguisher operated. (*FIRE=0)
Causes : (1) The fire extinguisher operated.

(2) The TEST switch on fire extinguisher was pressed.
Remedy : (1) Replace the dielectric fluid.

(2) Press the RESET switch when the test was conducted with the fire extinguisher
locked.
0008 OVERTRAVEL (OT2) Alarm 3 See Remedy.
Cause : Either ±X, ±Y, ±U, ±V, or ±Z overran and actuated the overtravel limit switch. (OT2-LS=1)
OT
Remedy : (1) In the MANUAL mode, press the f • 8 RELEASE key on the POSITION screen or
the button on the right side of CRT simultaneously with the RESET key.
OT RELEASE
OT
(2) Then, with the RELEASE button kept pressed, return the axis that actuated the over-
travel limit switch using the axis selection key.
(3) Next, press the RESET key to reset the alarm, then perform the reference point
return.
Description of Message 9
0011 MC POWER, –15 VDC DROP Alarm 3 See Remedy.
0012 MC POWER, +15 VDC DROP Alarm 3 See Remedy.
0013 MC POWER, +24 VDC DROP Alarm 3 See Remedy.
Description : The –15 VDC of the machining power dropped (over –8 V).
The +15 VDC of the machining power dropped (below 11 V).
The +24 VDC of the machining power dropped (below 19V).
Causes : (1) –15 VDC overloaded. Defective CIO or VOH card.

(2) +15 VDC and +24 VDC overloaded. Defective CIO or VOH card. Shorted terminal or
wiring on the machine side.
(3) Faulty power supply –15 VDC
PS2 (Defective switching power supply)
(4) Faulty power supply +15 VDC
PS1 (Defective switching power supply)
(5) Faulty power supply +24 VDC
Defective 24VR rectifier (SB1)
Remedy : Alarm related to power supply (faulty power unit).

Contact to us.
0015 CHECK SUM ERROR (VMC-ROM) Alarm 3 See Remedy.
Causes : (1) The contents of system ROM on the VMC card changed.
Faulty ROM or VMC card.
Erroneous contents in RAM on VOH card.
(2) This alarm is caused when turning power ON after changing ROM or when making
RAM clear (turning power ON while pressing STOP and RESET keys
simultaneously). This operation always causes this alarm, however, it is normal
condition. Reset the alarm by remedy (2).
Remedy : (1) For the machines with the power supply unit before MGW-J, please let us know the data
of machine parameters No.830 - 836.
For the machines with MGW-J or subsequent power supply units, please let us know
the data of machine parameters No.864 - 866.
(2) Perform the RAM clear operation.
Note: Execution of RAM clear will erase all program data in the RAM, and therefore
it should not be executed unless otherwise instructed by Makino personnel.
10
0016 CHECK SUM ERROR (PARAMETER)
Description : Not used.
0017 CHECK SUM ERROR (EIS-ROM) Alarm 3 See Remedy.
Causes : (1) The contents of system ROM on the EIS card changed.
Faulty ROM or EIS card.
(2) This alarm is caused when turning power ON after changing ROM or when making
RAM clear (turning power ON while pressing STOP and RESET keys
simultaneously). This operation always causes this alarm, however, it is normal
condition. Reset the alarm by remedy (2).
Remedy : (1) In the case of cause (1) above, please let us know the data of machine parameters
No.864 - 866.
(2) Perform the RAM clear operation.
Note: Execution of RAM clear will erase all program data in the RAM, and therefore it
should not be executed unless otherwise instructed by Makino personnel.
0019 PARAMETER INITIALIZED Alarm 2
Cause : Occurs when cleaning RAM (turning power ON while pressing STOP and RESET keys
simultaneously).
Display disappears soon.
0020 BATTERY DROP Alarm 2 See Remedy.
Description : Voltage of the battery for the NC unit program backup dropped abnormally.
Causes : (1) Limit of battery life

(2) Erroneous connection, disconnector contact.
(3) When replacing the card, check the setting of DIC1 switch on the VMC card.
Remedy : Aalrm related to power supply (faulty power unit).

Note: Replacement of battery unit is to be made within an hour after turning power
OFF. If the power supply is turned OFF continuously for more than one hour,
RAM data may be lost.
0021 CENTRAL CONTROLLER FAN ALARM
0022 RAM ERROR
0025 AUTO POWER OFF BY ALARM OR WARNING W ARN RESET key
Cause : Automatic power off was executed because the set data No. 34 bit 7 was turned on due to
an alarm or warning. This message is displayed at the power on operation next time. When
the bit 7 is turned on, the AUTO PWR OFF key returns to "0", which indicates that the
power was turned off normally.
Remedy : Press the RESET key, and check the 0/1/2 position of AUTO PWR OFF key, and the
set data No. 34.
12
0026 MISMATCHED ASC UNIT Alarm 3
Description : The power on check found mismatch of version numbers between EIS firmware and ASC
firmware on the EIS card.
Remedy : Contact to us of the trouble condition.

Replace the firmwares on the EIS card with those having proper version numbers
respectively.
0027 PROCESS OF POWER FAIL INCOMPLETELY Alarm 3
Description : RAM was not protected at power off (manual or power failure).
Remedy : The contents of RAM could be destroyed.

Contact to us of the trouble condition.
0034 ROM-MACRO IS NO ENTRY
0035 ROM-MACRO NOT ENOUGH AREA
0036 ROM-MACRO ERROR
1000 INTERSECTION POINT OUTSIDE OF PRM 83 LIMIT Alarm 2 RESET key
Description : An intersection was not determined at blocks before and after inner wire offset.
Causes : (1) Program error

(2) Small value of set data No. 83 (standard value = 17)
Remedy : (1) Correct the program.

(2) Change the wire offset value.
(3) This error will easily occur where adjacent blocks may or may not contact. In case of
an error, increase the set value (to 50–100). After a machining is finished, return the
setting to standard value (17).
1001 NOT TANGENT DUE TO OFFSET CHANGE, OUTSIDE RAD. Alarm 2 RESET key
Cause : When the wire offset value is illegal, the intersection may not be determined
diagrammatically.
Intersection is
not determined.
D1
Program D2
Remedy : (1) Change the wire offset value.

(2) Correct the program.
1002 M 02, M 30 PR OG R AM ED BE FO RE OFF SET CAN C EL (G 40) Alarm 2 RESET key
Cause : M02 or M30 was commanded during the wire offset mode.
Remedy : Command G40 before commanding M02 or M30.
14
1003 G2, G3 COMND. MISSING I.J OR R VALUE Alarm 2 RESET key
Cause : A radius was not commanded in the block with movement in the case of arc modal.
(This alarm will occur if I, J or R is not programmed for arc, or if G01/G00 is not programmed
for the line after arc.)
Remedy : Correct the program.

When the modal is arc and the movement amount is to be commanded, be sure to
command a radius.
Alternatively, set the G00 or G01 modal. There are two kinds of radius specifications; I, J
and R.
1004 PLANE INCONSISTENT IN G02, G03 COMND Alarm 2 RESET key
Cause : In arc radius specification, there is other than I, J or R.
1005 G48, G68 OR G26 OVERLAP COMND Alarm 2 RESET key
Cause : G48 was specified in G48, G68 specified in G68 or G26 specified in G26.
1006 END POINT INCORRECT IN G02, G03 COMND Alarm 2 RESET key
Causes : (1) Radii at start and end are inconsistent.

(2) When specifying R, R = 0 was specified.
(3) There are R specification and I, J specification in the same block.
(4) There is no G00 or G01 in the line block after G02 and G03 modals.
(5) In specifying R, the start point and the end point are same (a full circle), and the center
cannot be determined.
Calculating method for (1) (If the condition of the following expression i not satisfied, an
error results.)
Set data No. 0080 setting > √(X – I)2 + (Y – J)2 – √2 + J 2

Radius R2 determined Radius R1 determined
from end coordinate from center coordinate
value value
Theoretical wire path

Actual wire path
X
Allowable amount
Y End point
Start point
R2 = (X-I)2 + (Y-J)2
R1 = I2 + J2
J
I Center of circular arc
Remedy : Correct the program or increase the set data No. 0080 setting (for example, 1 → 5).
Note: Set higher especially in the case of automatic programming output.
16
1007 G48, G68 COMND ORDER ERROR Alarm 2 RESET key
Cause : The cancel specification G47 and G69 to G48 and G68 were commanded in incorrect order.
G48 Specification G48 Specification
G68 Specification G68 Specification
G69 Reset G47 Reset
G47 Reset G69 Reset
Correct command Command order error
G48 commanded outside G26.
G48
G47 (cancel) in G26 also

causes an alarm.
G26 G47
1008 MIRROR IMAGE (G71) COMND ERROR Alarm 2 RESET key
Cause : Values other than 0 (OFF) and 1 (ON) were commanded to X and Y in G71X_Y_; block.
1009 G92 SPECIFIED AFTER G48, G68 OR G26 Alarm 2 RESET key
Cause : G92A_ was specified in G48, G68 or G26.

However, without A specification, this does not cause an alarm.
Remedy : Correct the program or execute after specifying G92A0;.
1010 G CODES IN SAME GROUP CAN’T BE IN SAME BLOCK Alarm 2 RESET key
Cause : There are prohibited G code combinations in the same block.
G code (63) (64)

04 22 28 29 30 40 41 42 48 68 70 71 92
G code
04
22
(63)
28
(64)
29
30
40
41
42
48
68
70
71
92
Automatic reference
Wire offset to right

Work limit
point return
Return from
reference point
Undefined
Wire offset cancel
Wire offset to left
Mirror OFF
Coordinate system
Dwell
Scaling
Rotation
Mirror ON
setting
Note: Circle indicates illegal combination. Symmetrical one is of course inhibited.
18
1011 OPTIONAL G CODE SPECIFIED Alarm 2 RESET key
Description : Unused G code was specified.
Cause : G code other than the ones listed in the table was specified.
1012 G41, G42 IN G02, G03 BLOCK Alarm 2 RESET key
Cause : The model of wire offset start block was an arc.

Specify a linear command (G01, G00) in the wire offset start block.
1013 OFFSET CANCELLED (G40) IN G2, G3 BLOCK Alarm 2 RESET key
Causes : (1) The modal of wire offset cancel block was an arc.
(2) Movement command outside of compensation plane is in the wire offset cancel block.

(1) Specify a linear command (G01, G00) in the wire offset cancel block.
(2) Do not specify movement (Z, C) outside the compensation plane in the wire offset
cancel block.
1014 MDI OR M6 DURING G41, G42 Warning 3 W ARN RESET key
Cause : While wire offset was under way in memory run, it was stopped and a movement command
was executed in MDI mode or M06; was specified but an alarm was caused due to fixed
amount movement.
Remedy : Switch to manual operation for manual movement.
1015 ILLEGAL PLANE MOVE.COMND EXIST G41, G42 BLOCK Alarm 2 RESET key
Cause : Movement command outside of compensation plane was in the wire offset start block.

Do not specify movement (Z, C) outside the compensation plane in the wire offset start
block.
1016 OVERCUT CAUSED BY OFFSET OR TAPER Warning 2 W ARN RESET key
Cause : An interference occurred as a result of wire offset.

(1) When machining the inside of an arc smaller than the offset amount:
Overcut of wire
(2) When a movement amount is too small:
Remedy : Change an offset amount or correct the program.

When an interference can be tolerated, continue as it is.
Pressing the WARN RESET key causes the message to disappear.
20
1017 MORE THAN 2 NON-MOVEMENT BLKS DURING Alarm 2 W ARN RESET key
G41, G42
Cause : In the wire offset, there are more than two blocks without movement so that an intersection
can be determined, causing a turn around the corner.
Ex) G41 D** Y10.; G41 D** Y10.;
M98 P1; Block without movement M98 P1;
N1; Block without movement N1 G91 X10.;
G91 X10.;
Alarm is caused. Alarm is not caused.
1018 OVERCUT CAUSED BY G44 COMPENSATION Warning 2 W ARN RESET key
Cause : G44 compensation results in insufficient offset length. This alarm may occur in a short
block.
Compensated length
Alarm is not caused. Alarm is caused.
Remedy : Change the offset amount (H) or correct the program.

When the overcut can be tolerated, continue as it is.
Pressing the WARN RESET key causes the message to disappear.
1019 G44 PROGRAMMED BEFORE G41, G42 Warning 3 W ARN RESET key
Description : The corner profile control ON was specified during wire offset cancel.
Cause : During the wire offset canceling, G44 also becomes invalid. It becomes valid from the block
in which the wire offset ON is specified.
Remedy : Check the program.

Continue operation as it is if a following block.
Contains the radius compensation command, or correct the program if not.
Note: In the following case, also G44 (corner profile control) does not work.
(1) At the corner with the block without movement during wire offset (G41 or
G42).
(2) Until return to the original machining condition during recovery from wire
breakage or from power failure.
1020 G25 COMND WITHOUT OFFSET OR TAPER Warning 2 W ARN RESET key
Cause : Spiral interpolation command (G25) was executed in other than wire offset mode.
Remedy : It is valid only in the wire offset mode. Program G41 or G42.
1021 G24 COMND WITHOUT OFFSET OR TAPER Warning 2 W ARN RESET key
Cause : Taper corner tangential circle insection (G24) command was executed in other than the
taper mode.
Remedy : It is valid only in the taper mode. Program G51 or G52.
1022 G49 COMND WITHOUT OFFSET OR TAPER Alarm 2 RESET key
Cause : The Upper – lower same R command (G49) was executed in other than the taper mode.
Remedy : It is valid only in the taper mode. Program G51 or G52.
22
1023 G22 COMND ERROR Alarm 2 RESET key
Causes : (1) G22 command is not in pair.

X ––––– I U ––––– K
Y ––––– J V ––––– L
(2) G22 command can specify only axes X, Y, U and V.
(3) G22 command can be specified only after the reference point return.
Remedy : (1), (2) Correct the program.

(3) Execute the reference point return.
1024 MOVEMENT END COORD. WITHIN PROHIBITED AREA Alarm 2 RESET key
Cause : When a prohibited area was set with G22 command, the end of movement entered the
prohibited area.
1025 G95 IN G41, G42 INVALID Alarm 2 RESET key
Cause : Z axis position was specified in the G41 or G42 block.
Remedy : The G95 should be specified in the G40 modal mode.
1026 OVERCUT CAUSED BY G44 Q-COMPENSATION Warning 2 W ARN RESET key
Cause : An overcut occurred due to radius compensation or corner control.
Remedy : Correct the program, or continue machining as it is.

Normally, a machining may be continued as it is.
1028 G04 COMND WITHOUT P, X WORD Alarm 2 RESET key
Cause : P_ or X_ command for specifying a dwell length is not in the G04 dwell command.
1029 G30 IS ONLY VALID AFTER REF. POS. RETURN Alarm 2 RESET key
Causes : (1) The number of reference point (P command) specified together with the G30 command
is not 2, 3 or 4.
Note: When P is omitted, it becomes the 2nd reference point.
(2) When G30 was specified, the reference point return had not been completed.

(2) Make reference point return.
1030 G53 IS ONLY VALID AFTER REF. POS. RETURN Alarm 2 RESET key
Cause : When G53 was specified, the reference point return had not been completed.
Remedy : Make reference point return.
Causes : (1) The L command in the same block as the G28 command is other than 0, 1 (it becomes
L0 when omitted).
(2) The reference point return is executed to search for DEC when that operation has not
been executed yet, but its condition is improper.
The set data No. 66 setting is not "0"

(2) Set the set data No. 66 to "0", or execute the reference point return manually.
24
1032 G28, G29 COMND ORDER ERROR Alarm 2 RESET key
Causes : (1) The G28 command was not specified before the G29 command.
(2) An axis not specified with the G28 command was specified with the G29 command.
Cause : In the G95 command (Z axis position control command), improper value was specified.
1036 MEMORY PROTECT PARAM. ILLEGAL BY G10 Alarm 2 RESET key
Cause : A value other than the defined L value of the G10 command was specified or other address
code is out of range.
The L value that the user can specify is either of the following:
L1 : Changing offset value
L2 : Changing work offset value
L10 : Changing machining condition
L20, 21 : Changing entered machining condition (main, sub)
L50 : Changing model data
L80 : Changing taper surface data
L999 : Changing parameters (set data/machine parameter/system parameter)
1037 ILLEGAL WORD IN G10 BLOCK Alarm 2 RESET key
Cause : Illegal format is used in the G10 command block.

eg: Program for offset setting on increment.
G10D_R_; Offset setting D: Offset
G10D_Q_; Offset increment R: Setting data
Q: Increment
1038 WORD DATA ERROR IN G10 BLOCK Alarm 2 RESET key
Cause : The word in the G10 command block exceeds the allowable range.
1039 MOVEMENT COMND ON OPTION AXIS Alarm 2 RESET key
Cause : The movement exceeding the set number of axes was specified.
1041 OVERLAP COMND FOR POWER SUPPLY Alarm 3 RESET key
Cause : The G10 command for power supply is overlapped. System error
Statement: G10 L13 P0 for machining OFF
G10 L31 P1 for machining ON
26
1042 OVERLAP COMND FOR MACHINE CONTROL Alarm 3 RESET key
Cause : The G10 command for machine control is overlapped. System error
G10 L60 Statement.
1043 NO M02, M30 IN MAIN PROGRAM Alarm 2 RESET key
Cause : The program end M code (M02 or M30) command was not in the main program.
Remedy : Specify the M02 or M30 command at the end of the main program.
1044 COMND OVER Alarm 3 RESET key
Cause : There are five or more G10 commands in a block. System error
Note: Those codes (M17, M07) that generate G10 internally are included.
1045 UNDEFINED G, M COMND Alarm 3 RESET key
Cause : An unused G or M code was specified.

Check G and M codes.
Check the system parameters No. 984–999, if this error occurs in G or M codes that can be
used.
1046 DECIMAL POINT ERROR Alarm 2 RESET key
Causes : (1) In case of metric command unit, command can be made only down to the 3rd decimal
place.
In case of inch command unit, command can be made only down to the 4th decimal
place.
(2) Smaller than the decimal point is unavailable with an F command.
1047 NUMERICAL COMND ERROR Note 3) W ARN RESET key
Description : Numerical command is out of the following range.
Causes : (1) ±99999.999 or ±9999.9999 for the metric command unit. (Note 1)
(2) ±9999.9999 or ±999.99999 for the inch command unit. (Note 1)
(3) Standard value 1000 for the F command (Note 2)
(4) PQ values of M600, M610, M620, or M630 (Note 3) or F value of M650 for the machine
with pallet magazine.
Note 1: The allowable range varies depending on the set data No.0063 for linear axis,
or set data No.0537 for rotary axis.
Note 2: The allowable range varies depending on the machine parameter No.0561.
Note 3: Warning 3 when this message is output under control of pallet magazine, or
otherwise alarm 2.
Remedy : For causes (1) to (3), correct the program.

For cause (4), correct the program and turn off and on the power switch.
1048 ZERO RETURN NOT EXECUTED Alarm 2 RESET key
Cause : The axis was moved in the automatic run mode, though the reference point return has not
been completed yet.
Remedy : Execute the reference point return operation.
28
1049 CANNOT MDI RUN DURING MEM RUN Warning 3 W ARN RESET key
Cause : Halfway in the machining block in memory run, MDI interrupt (switching to MDI run) was
made and a machining block was specified.
Remedy : Don’t make machining interrupt while machining.

Switch from MDI run to memory run and press the START key to continue or press the
RESET key to restart.
Note: In case modal change was made by command in MDI, such portion may be
valid. Check again, therefore, when continuing in memory operation.
1050 ILLEGAL SELECTION OF AUTO MODE Warning 3 W ARN RESET key
Cause : System error
1051 USE COND. NOT MET FOR ADDITIONAL AXIS Warning 3 W ARN RESET key
Cause : The axis with servo OFF is in the current valid axis.
1052 AT INDEX FIXED LS ON
1054 U, V COMND ON TAPER Alarm 2 RESET key
Cause : U- and V-axes movement command is in the G51 and G52 taper mode.
However, in case the following G codes are in the same block, the U- and V-axes
commands become that G code command, causing no alarm.
G04, G10, G22, G28, G29, G30, G53
1055 U, V COMND ON G2, G3 BLOCK Alarm 2 RESET key
Cause : U- and V-axes movement command is in the G02 and G03 circle mode.
Cause : An axis other than X and Y axes was specified for the rotation center position of
G68X_Y_A_;.
Cause : An axis other than X and Y axes was specified for the rotation center position of
G26X_Y_A_;, on a copy angle A_ was not input.
30
1058 G24 ERROR (NOT TANGENT TO BEFORE, AFTER BLKS) Alarm 2 RESET key
Cause : The G24 command block is not adjacent to both before and after blocks (straight line and
circle).
Remedy : Correct the program or increase the setting of set data No. 0083 (from 17 to about 50).
1059 G24 ERROR (INTERSECT. CANNOT BE DETERMINED) Alarm 2 RESET key
Causes : (1) Compensated figures of blocks before and after G24 command block were without
intersection. (Fig. 1)
(2) When block either before or after G24 command block is an arc, compensation by G24
resulted in 0 radius of block before and after (every in rare case). (Fig. 2)
Program Program
D G24 command
G24 command
Because of too small

L value, intersection
L cannot be determined.
Intersection cannot
D be determined.
r=0
Fig. 1 Fig. 2
Remedy : Change G24 L_ command.
1060 G24 ERROR (OVERCUT BY NEGATIVE RAD. CALC.) Alarm 2 RESET key
Cause : Either block before and after G24 command was circle and compensation resulted in
negative radius.
Program
G24 command
D
D r
r<D
Where figure like this
would be obtained if D
without G24, commanding
G24 will cause an alarm.
Remedy : Change the offset amount.

Correct the program.
1061 INCORRECT TAPER PLANE DATA See Note See Note
Causes : (1) The height of program plane or subprogram plane is set higher than actual upper guide
height.
Note) Warning 2, Warm reset key
(2) The height of program plane or subprogram plane is set lower than actual lower guide
height.
Note) Warning 2, Warm reset key
(3) The upper guide height is too small, compared with the sub plane height.
Note) Alarm 2, Reset key
In general taper machining, the above case is very rare and there is high possibility of
misentry. Therefore, warning is output to alert the operator.
Remedy : Correct the program or check the setting.
Press the SET key and then the OFFSET key to check the value on the OFFSET
screen.
32
Causes : At least one of the following conditions must be met.

(1) The G49 command block must be circle.
(2) The blocks before and after the G49 command must be with movement and linear.
1063 RADIUS OVERCUT BY G44
1064 TAPER COMND WITHOUT G41 G42 Alarm 2 RESET key
Cause : The taper command (G51, G52) is not in the same block as the G41 or G42 command.
The taper cancel command (G50) is not in the same block as the G40 command.
1065 CAN’T CHANGE INCH/MM BY PROGRAM Alarm 2 RESET key
Cause : G20 command for the metric command system was specified.
G21 command for the inch command system was specified.

To chasngeover the unit system between inch and metric, set it to the set data No. 0063 bit
0, then turn off and on the power switch.
1066 G48P COMND EXIST AT TAPER MODE2 Alarm 2 RESET key
Cause : The G48P command cannot be given in the taper mode 2.

Make taper mode setting at machining side on the NC FUNC screen.
Make taper mode setting at graphic side on the DRAW SET screen.
Remedy : Delete the G48P command.

Then, at the cutting side, press the SET key and then the OFFSET key to set a value
to the drawing scale on the OFFSET screen.
At the graphic side, the drawing scale is automatically set to "1".
Cause : A value other than A0 to A9 was commanded in the block of G92 A_; block.
1068 AXIS-COMMAND IS OVER IN 1 BLOCK Alarm 2 RESET key
Cause : Movement for more than 3 axes including C and Z axes was specified simultaneously.
1069 MOVE Z AXIS TO HEIGHT OF Z POS. DISPLAY Guide W ARN RESET key
Description : In the Z axis manual machine, this message is displayed along with STOP status lamp ON
when the G95 (Z axis position control) is turned on.
Remedy : Move the Z axis to the specified height and restart operation.
34
1070 ILLEGAL SELECT OF INTERPOLATION UNIT Alarm 2 RESET key
1071 G46 IN G40 INVALID Warning 3 W ARN RESET key
Cause : The corner override (G46) was specified in the radius compensation cancel (G40) block.
Remedy : Check the program.

Continue operation if there is radius compensation command in the following blocks, or
correct the program if not.
1072 DUPLICATE INSTRUCTIONS OF G44 AND G46 Warning 2 W ARN RESET key
Cause : G46 was specified in the G44 block, or G44 was specified in the G46 block.
Note: Normally, the G44 is used for 1st cut and G46 for 2nd and subsequent cuts.
If they are specified in the same block, G44 has priority.
Remedy : Check or correct the program.
1073 IMPOSSIBLE TO SET COORD. (G92) DURING G41, G42 Alarm 2 RESET key
1075 DUPLICATE INSTRUCTIONS OF G31 Alarm 2 RESET key
Cause : Midway in taking measurement in memory run, MD1 interrupt was made to perform
measurement.
Remedy : Reset
1076 SAVING OR RESTORATION ERROR OF INSIDE COORD. Alarm 2 RESET key
1077 G41/G42 P_ COMND ERROR Alarm 2 RESET key
Cause : In the vertical irregular shape mode (G41/G42P_), the command other than P0, P1 and P2
is specified.
36
1078 INCONSISTENT COMND WITH G41/G42P_ COMND Guide W ARN RESET key
Description : (1) Taper command (G51/G52) is specified in the vertical irregular shape mode(G41/
G42P_).
(2) Circular interpolation (G02/G03) is specified in the vertical irregular shape mode (G41/
G42P_).
(3) The mirror image, scalling or axis exchange is specified in the vertical irregular shape
mode.

(1) The taper command cannot be used in the vertical irregular shape mode.
(2) The program for vertical irregular shape must be made in the linear interpolation (G00/
G01).
(3) NC functions such as mirror image, scalling and axis exchange cannot be used in the
vertical irregular shape mode.
1079 N NO. FOUND FOR I/O CANCEL MACRO Alarm 2 RESET key
Cause : Both cancel N number and reset processing N number are registered when ICON macro
execution request is made during execution of ICON macro. System error.
1080 THE MANUAL RUN KEY IS INVALID NOW Warning 1 W ARN RESET key
Cause : MANUAL key on FPB operation panel or MAN RUN key on the screen was pressed
during execution of return operation by RETRACT key in the manual interruption mode for
wire break recovery or one touch M6 operation.
Remedy : Cancel the return operation to restore the operation mode because manual interruption is
invalid during return operation using the RETRACT key.
1081 COMMAND ERROR IN FIXED CYCLE MACRO
1082 RETURN IS ONLY DURING MANUAL RUN Warning 1 W ARN RESET key
Cause : The RETRACT key was pressed without performing manual interruption in the operation
mode (MEN RUN or MDI RUN mode) other than MAN RUN mode (except one touch keys).
Or, RETRACT key was pressed without performing retraction in the manual interruption
mode.
Remedy : Because the retract and return function is invalid in the mode other than manual
interruption, switch the mode to manual interruption mode (eg. MAN RUN key ON in
MEM RUN mode), and press RETRACT key after performing retraction.
1083 MDI, MEM RUN INVALID DURING MAN. ZERO RETURN Warning 2 W ARN RESET key
Cause : When operating in a mode (MDI, memory) other than the manual mode, manual operation
interrupt was attempted to manually return to the zero point.
Remedy : Manual return to the zero point is not possible during the automatic operation.
Cancel the zero point return mode before changing the operation mode, and then turn
power on again.
1084 RETURN, RECOVERY W. BREAK NOT IN EFFECT Warning 2 W ARN RESET key
Description : No retract operation can be done during recovery from wire breakage.
38
1085 G590, G591, G592 VALID AT HEAD BLOCK ONLY Alarm 2 RESET key
Cause : Input resolution setting G code (G590, G591, G592) must be specified at the head of a
block, but actually it is specified in the middle of block.
Remedy : Check and correct the program.

G590: Set by parameter
G591: Standard resolution
G592: High resolution
1086 INPUT VALUE IS ROUNDED OFF Warning 1 W ARN RESET key
Description : In the standard resolution mode (set data No. 0063), a value with decimal point that
exceeds the standard resolution is entered, and therefore it is rounded off to standard
resolution.
Example: Metric system 1.2345 → 1.235
Inch system 1.23456 → 1.2346
Remedy : Check and correct, or continue programming.
1087 ILLEGAL G04 VALUE Alarm 2 RESET key
Cause : A value larger than the upper limit (14744.7) was specified for the G94 dwell command.
1090 RECOVERY WIRE BREAK Warning 1 W ARN RESET key
Cause : Wire breakage occurred during machining and the automatic wire breakage recovery
function was actuated.
Remedy : When the wire breakage point is reached, the message automatically disappears.
1091 AT DRYRUN Warning 1 W ARN RESET key
Cause : During automatic wire break recovery of RECOVERY WIRE BREAK 1, AUTOMATIC WIRE
LOADING RETRY 1 or 2 on the NC FUNC screen, the following state occurred.
This message appears when moving in DRY RUN to next machining start point.
Remedy : When the next machining start point is reached, the message automatically disappears.
1092 RECOVERY WIRE BREAK OVERTIMIES Warning 1 W ARN RESET key
Causes : The number of wire break times in the current machining process reached the number set
to the set data No. 100.
In case the recovery wire break 1 or 2 on the NC FUNC screen has been set, the following
operations are made.
(1) RECOVERY WIRE BREAK 1
The message "1741: M6 SEARCHED BY M74, A.W.T. MISSED (1)" is displayed, and
the head moves to the next machining start point in the dry run mode.
(2) RECOVERY WIRE BREAK 2
Return is made to the machining start point where movement stops. Pressing the
START key again from this condition starts the recovery wire break operation. The
number of recovery wire breaks is cleared to 0.
1093 RECOVERY POWER FAILURE (WAIT FOR PRM No.575) Warning 1 W ARN RESET key
Cause : Power failure occurred and the automatic power failure recovery function was actuated
during MEMORY RUN operation.
The system waits for the power failure recovery function to operate for the duration of the
set time, if the machine parameter No.575 has been set.
Remedy : Upon returning to the position where power failure occurred, the message automatically
disappears.
40
1094 RECOVERY POWER FAILURE INVALID Warning 1 W ARN RESET key
Causes : Power failure occurred in auto mode under one of the following conditions so that the
automatic power failure recovery cannot be made.
(1) During MDI RUN operation.
(2) At stop.
(3) Automatic wire loading skip of NC function is valid.
(4) Without automatic wire loading unit.
Remedy : After resetting by the RESET key, restart.

Note: When all of the following conditions are met, the automatic power failure
recovery is made.
(1) At machining by memory operation (started with M17).
(2) Dry run and machine lock of NC function is invalid.
(3) Automatic wire loading skip of NC function is invalid and power failure
recovery is valid.
(4) With automatic wire loading unit.
1095 WIRE BREAK Warning 3 W ARN RESET key
Description : The wire break signal is turned on (WDN=1).
Causes and Remedy:

[Cause of wire break]
The causes of wire break can be estimated by the conditions when it occurred, although not
definitely. Many causes are often involved.
The break position on the work:

immediately after the
1 start of machining
within 3 to 5mm from the
2 start point of machining
after machining more than
3 5mm
Wire Wire
1
Concentration of discharge
on a narrow area
Existence of insulator Aerial discharge
like rust, raw surface (air inclusion)
etc.
Decrease machining conditions
at the start of machining.
Air inclusion or insufficient fluid Decrease machining conditions at the lead.

pressure against the conditional value
(a)
(b)
(c)
3 Closely
(d)
check wire
break
position (e)
(f)
(Check the wear length of (g)

the upper wire.)
42
(a) (g) (b) (f) (d)
Guide
Too large power Too large

and flaw holding force
Closely check the energying plate and guide in case of wire break
(c) (e)
Inclination of nozzle Too far Adhesion of

causes turbulent flow. nozzle insulator
Closely check workpiece, nozzle, and fluid pressure in case of
wire break around the workpiece.
Too large Centralized Wear Aerial Insulative Insufficient

energy discharge (wire feed discharge foreign flushing
(bent wire) rate) (pin hole) matter
REST
Irreqular Very Wire break Rust caused Centralized discharge

wire travel complicated due to rust for a long time at the time of manual
shape on wire wire break recovery
Tool large
Machining too holding force Insufficient
close to edge wear stripe flushing
Pay special attension to the fluid pressure in case wire break

in the center of workpiece
Selection of Machining Continuation Method:

In order to continue machining when wire breakage occurred, select one of the following methods
before start of machining.
Method 1. Manually load wire at the point where wire was broken.
(Set the recovery wire breakage to 0).
Method 2. After pressing the "RESET" key, return the head to the machining start point and connect
the wire. Turn on the DRY RUN and make the head approach the wire break point
(normally, 2 to 3 mm before that point) with the wire connected, the stop operation.
Turn off the DRY RUN on the NC FUNCTION screen, press the START key with the
TOUCH on the MACH OPERATE screen turned on, and turn off the TOUCH when the
head reaches the wire break point. (Wire break recovery count should be 0)
Method 3. Use the recovery wire breakage (recovery wire breakage 1 or 2) (only when equipped with
automatic wire loading unit).
The above methods have their own advantage and disadvantage. Determine the method to be used
in advance considering the machining accuracy, ease of wire breakage recovery and other factors.
Table 1. Machining continuation methods after wire breakage and their features
Feature
Advantage Disadvantage Example of application
Method
Method 1 • Machined portions • Somewhat difficult to thread. • Products requiring high

(recovery 0, left as they are accuracy
load on site) • Machining cannot be • Machining in single
continued in the case of operation of relatively
unattended operation as thick plate
temporary stop is caused.
• Not adequate for high
speed machining
Method 2 • Machined portions • Return to start hole, dry run • Products requiring high
(recovery 0 Dry left as they are ON, OFF and many other accuracy
run + touch) operations are involved. • Machining in single
• Machining cannot be operation of relatively
continued in the case of thick plate
unattended operation as • Not adequate for high
temporary stop is caused. speed machining
Method 3 • Machining continued • There is possibility of some • Products not requiring

(recovery 1 or even at unattended additional machining if high accuracy
2) operation machined portion has been
distorted. • High speed machining
• Recovery causes
almont no flaws if • Available only when • Rough machining to
machined portion equipped with automatic micron order
has not been wire loading unit.
distorted.
44
1096 CHECK WORK COORD. AND OFFSET VALUE
1097 POWER FAILURE Warning 1 W ARN RESET key
Description : Power failed during machining with the powe failure recovery function (optional) turned on,
and the power failure recovery operation is executed.
Remedy : Check influence of power failure recovery operation on the workpiece.
1098 M6 INVALID IN TAPER MODE Alarm RESET key
Cause : M6 command was specified in the taper mode or vertical irregular shape mode.
Remedy : Specify M6 command in other than taper mode or vertical irregular shape mode.
1099 RETURN NOT EXECUTED Warning 3 W ARN RESET key
Description : An attempt to start the machining was made, skipping the return operation after the axis
retraction.
Remedy : Return the axis to the original position.
1100
∼ NPC SYSTEM ERROR Alarm 3 RESET key
1356
Cause : System error.
1102 MACRO COMND ORDER ERROR Alarm 2 RESET key
Cause : The macro command codes of which commanding order is limited were not specified in the
correct order.
Example: The PRED command was specified before the PROP command in the
external data command.
Remedy : Correct the macro program.
1116 O NO. IS NOT WITHIN 1 – 9999 Alarm 2 RESET key
Cause : O number is memory operation was 0 or more than 9999.
Remedy : Check the input command value. Specify the correct O No.
1118 O NO. (MAIN, SUB) IS NOT REGISTERED IN MEMORY Alarm 2 RESET key
Cause : O No. started in memory operation or called by the subprogram is not registered.
The subprogram O No. called from the subprogram is also checked.
Remedy : Find the unregistered O No. and register it. Correct the program.
1119 EDIT IN BLOCK DISP. OR ERROR IN MAIN PROGRAM Alarm 2 RESET key
Causes : O No. started in memory operation is in the following state.

(1) Currently, being displayed on the EDIT BLOCK screen or being registered or deleted
on the EDIT, LIST screen or being tape input/output.
(2) A block error or grammatical error was found in O No.
Remedy : (1) Press the LIST key to close the program being displayed on the EDIT, BLOCK
screen. Start under the condition other than registering, deleting on the EDIT, LIST
screen or tape inputting/outputting.
(2) Correct O No. error.
46
1120 EDIT IN BLOCK DISP. OR ERROR IN BUS PROGRAM Alarm 2 RESET key
Causes : O No. by subprogram call or subprogram called from subprogram is in the following state.
(1) Being displayed on the EDIT BLOCK screen or being registered or deleted on the EDIT,
LIST screen or being tape input/output.
(2) There is an illegal block or grammar in O number.
Remedy : (1) Press the LIST key to close the program being displayed on the EDIT, BLOCK
screen. Start under the condition other than registering, deleting on the EDIT, LIST
screen or tape inputting/outputting.
(2) Correct O No. error.
1132 N NO. NOT FOUND Alarm 2 RESET key
Causes : Block sequence No. is not found due to the following causes.
(1) Error of N No. started in memory operation.
(2) Specification error of subprogram call M98 O_P_ or retract M99 P_.
(3) Error of destination N No. of macro command GOTO statement.
1136 EXCESS NESTING OF SUB PROGRAM Alarm 2 RESET key
Cause : The nesting level in subprogram call exceeds the limit.

G and M codes with limited nesting were used at above specified level.
Sub- Sub- Sub-

Main program program program
program (1) (2) (3)
Maximum 9 levels
1137 M99 PRESENT IN MAIN PROGRAM Alarm 2 RESET key
Cause : O No. of subprogram was specified to start in-memory operation.
1138 NO M99 IN SUB PROGRAM Alarm 2 RESET key
Cause : The retract command (M99, M99P_) is not found in the subprogram.
1139 MACRO COMND PRESENT AT TAPE MODE Alarm 2 RESET key
1149 ILLEGAL WORD IN BLOCK Alarm 2 RESET key
Cause : Illegal NC command was found in an NC tape.
Remedy : Correct the tape.
1150 BLOCK FORMAT ERROR Alarm 2 RESET key
Causes : (1) External data output macro (PROP, PRED, PRCL).

(2) System call macro (SYSCALL).
48
1151 INPUT/OUTPUT DEVICE ERROR Alarm 2 RESET key
Cause : The tape input/output drive failed during program input/output on the EDIT screen.
Remedy : Recheck the program input/output condition (set data No. 20 to 26), tape I/O drive, and the
cable.
1152 BLOCK WITH MORE THAN 126 DIGITS PRESENT Alarm 2 RESET key
Cause : A block containing more than 126 characters is detected during tape input on the EDIT
screen.
Remedy : Correct the tape.
1160 NPC COMND NO. ERROR Alarm 2 RESET key
1161 NPC COMND NO. INCORRECT Alarm 2 RESET key
1162 AT PROTECT Alarm 2 RESET key
1163 O NO. EXISTENT Alarm 2 RESET key
1164 COMPILE ERROR Alarm 2 RESET key
1165 PROGRAM HEAD Alarm 2 RESET key
1166 PROGRAM END Alarm 2 RESET key
1167 MEMORY SHORTAGE Alarm 2 RESET key
1180 MACRO VARIABLE NO. ERROR Alarm 2 RESET key
Cause : Macro variable No. not in use was used.
1181 MACRO VARIABLE VALUE ERROR Alarm 2 RESET key
Cause : A macro variable not allowed was used.
1182 PROHIBITED MACRO VAL. IN THIS TYPE MACHINE Alarm 2 RESET key
Cause : A macro variable not allowed was used.
1184 MACRO CALCULATION ERROR Alarm 2 RESET key
Cause : In calculation equation of macro instruction, the function argument value or system variable
substitution value or NC code replacement value was outside of allowable range.
1185 MACRO DIVISOR IS 0 Alarm 2 RESET key
Cause : In macro instruction calculation equation, the divisor was 0.
50
1186 MACRO CALCULATION ACCURACY ERROR (1) Alarm 2 RESET key
Cause : In macro instruction calculation equation, an extremely large absolute value occurred.
1187 MACRO CALCULATION ACCURACY ERROR (2) Alarm 2 RESET key
Cause : In macro instruction calculation equation, an extremely small absolute value occurred.
1196 NO O NO. IN G93 SPECIFIED Alarm 2 RESET key
Cause : P_G_ were commanded successively in G93 command.
Example:G93 P_ G_
Defining G code
Subprogram to be called.
1197 EXCESS NESTING OF G66 Alarm 2 RESET key
Cause : G66 modal call nesting exceeding level 4.
1198 G93 SPECIFIED MORE THAN TWICE Alarm 2 RESET key
Cause : G93 commanded 2 times during execution of program between resets.
1199 EXCESS NESTING OF MACRO CALL Alarm 2 RESET key
Cause : In macro level 4 state, modal call by G65, G66 or G, M code with nest level limit was
commanded.
G66
G65 M98 G65 T100
X10
G67
T100: Pseudo command code
1 Level 2 Level 3 Level 4 Level
1200 SUB.PRO FORMAT ERROR (L/R, B) Alarm 2 RESET key
Cause : Subprogram call condition exceeded allowable value range.

(1) Repetition number L/R over 9999.
(2) G26 command B value over 255.
(3) G26 command M value over 2.
52
1220 FORMAT ERROR OF GRAPHIC MACRO CODE Guide W ARN RESET key
Description : (1) In complete address code is used in the G code for graphic.
(2) The PRFM command is specified without executing G400, G430 or G440.
Example : (Wrong) G400Y_; (Correct) G400C _X_Y_;
1221 ILLEGAL INPUT DATA OF GRAPHIC MACRO CODE Guide W ARN RESET key
Description : The address code in the G code for graphic is out of allowable range.
Example : (Wrong) G400C10X_Y_; (Correct) G400C ~7X_Y_;
1222 ILLEGAL G CODE IN GRAPHIC MACRO CODE Guide W ARN RESET key
Causes : (1) In the graphic macro program, the G code other than G400–G439 is used.
(2) In the user menu creating program by the modal plan, the G code other than G440 –
G449 is used.
1223 SO MANY G CODE IN GRAPHIC MACRO CODE Guide W ARN RESET key
Cause : Multiple graphic macro codes G400–G439 are used in the same block.
Remedy : Correct the program. The graphic macro code must be used in an individual block
respectively.
1224 GRAPHIC MACRO CODE OUT OF DRAWING AREA Guide W ARN RESET key
Cause : A graphic macro code exceeding allowable drawing range is specified in a program.
Remedy : Check and correct the program.

Allowable range: A square block having diagonal line determined by the following
coordinates.
In text coordinates : MIN (0, 1) – MAX (65, 17)
In graphic coordinates : MIN (0, 18) – MAX (527, 323)
1230 CHR’S ENTRY AREA OVERFLOW Guide W ARN RESET key
Cause : The number of characters of PRFM command following G440–G449 is larger than internal
memory area.
Remedy : Correct the program to decrease the number of characters of entire PRFM command.
1100 NPC SYSTEM ERROR Alarm 3 RESET key
: : : :
: : : :
1356 NPC SYSTEM ERROR Alarm 3 RESET key
54
1500 ILLEGAL MACHING COND. SPECIFIED See Note See Note
Description : The programmed E No. exists, but either value of machining condition elements of that E
No. is out of the setting range.
Causes : (1) E No. having illegal machining condition element value was specified in the program.
Note: Warning 3, WARN RESET key
(2) E No. having illegal machining condition element value was input IN on the MAIN
COND or SUB or COND screen.
Note: Guide, WARN RESET key
Remedy : (1) Confirm E No. and M/C condition element value, and correct it on the COND LIST
screen and COND (MAIN, SUB) screen, then restart operation.
(2) Confirm E No. and M/C condition element value, and correct value on the COND LIST
screen, then input IN the E No. on the COND (MAIN, SUB) screen.
1501 ILLEGAL CHANGE DATA OF MACHING COND. See Note See Note
Description : Although each machining condition element has the setting range, the programmed
element value is out of that range.
Causes : (1) A value, character or symbol out of the setting range was enteredt IN in the cursor
line of either COND screen (MAIN, SUB or LIST).
(2) In the machining condition element change command (G10L10RP_;) in a program, the
value P_ specified by R_ is out of the setting range.
Note: Alarm 2, RESET key
Remedy : (1) Confirm the cursor position and value to be input, then input it IN .
(2) Press the RESET key. Confirm R_ and P_ values, and correct it, then restasrt
operation.
1502 OPTION MACHING COND. SPECIFIED See Note See Note
Description : Optional machining condition element was specified on the machine having no options.
Causes : (1) Optional E No. was programmed.

Note: Warning 3, WARN RESET key
(2) An attempt to input IN optional E No. was made on the COND MAIN or COND SUB
screen.
(3) An attempt to input IN optional element value was made on the COND MAIN or
COND SUB screen.
Remedy : (1) Check E No. and element set value, and correct either one, then restart machining.
(2) Check E No. and element set value, and correct either one.
(3) Check element set value, and correct it.
1503 E NO. NOT FOUND See Note See Note
Description : Unregistered E No. was specified.
Causes : (1) Unregistered E No. was programmed.

Note: Alarm 2, RESET key
(2) Unregistered E No. was input IN on the COND MAIN or SUB screen.
(3) Unregistered E No. was searched SEARCH on the COND LIST screen.
Remedy : (1) Press the RESET key. Check E No. and correct it, then restart machining.
(2) Check E No. and input correct E No. IN .
(3) Check E No. and search correct E No. SEARCH .

(4) For other than MGW-K, make sure that the wire diameter is correct.
56
1504 IMPOSSIBLE TO EDIT STANDART COND. Guide W ARN RESET key
Description : An attempt to write a machining condition element to an E No. failed, because that E No.
has Makino standard condition attribute.
Remedy : (1) Failure in writing is normal because of Makino standard condition attribute.
(2) On the MGW-K, if a condition element is to be written to that E No. overriding the
attribute, turn on the set data No.336 bit0, then write it to that E No.
1505 IMPOSSIBLE TO ERASE STANDARD COND. Guide W ARN RESET key
Description : An attempt to erase a machining condition E No. on the COND LIST screen failed, because
that E No. has Makino standard condition attribute.
Remedy : (1) Failure in erasing is normal because of Makino standard condition attribute.
(2) On the MGW-K, if that E No. is to be erased overriding the attribute, turn on the set data
No.336 bit3, then erase that E No.
1506 M71L COMMAND IS 0, 1 Warning 3 W ARN RESET key
Cause : The L of M71L for approach function ON/OFF command is other than 0 and 1. To turn ON
the function, specify L0 or omit L, or to turn OFF the function, specify L1.
Remedy : Open the second function key screen of COND MAIN screen. Turn ON or OFF the
APPROACH key, then press START key. After automatic operation is finished, correct
the program.
1507 APPROACH 1 ILLEGAL MACHINING COND. Warning 3 W ARN RESET key
Cause : The approach 1 machining condition specified by M17S_ is illegal. (Invalid for MGW-K)
Remedy : On the COND LIST screen, correct machining condition of E No. to be registered as
approach 1 condition. Then, open the second page of COND MAIN screen, and register
the E No. of corrected machining condition with APPROACH 1 E. NO. key. Next, press
the START key.
1508 APPROACH 2 ILLEGAL MACHINING COND. Warning 3 W ARN RESET key
Cause : The approach 2 machining condition specified by M17A_ is illegal. (Invalid for MGW-K)
Remedy : On the COND LIST screen, correct machining condition of E No. to be registered as
approach 2 condition. Then, open the second page of COND MAIN screen, and register
the E No. of corrected machining condition with APPROACH 2 E. NO. key. Next, press
the START key.
1509 APPROACH E NO. IS E9000 – E9999 See Note W ARN RESET key
Cause : In manual or automatic run mode, an attempt to register E No. other than E9000 – E9999
as approach 1 or approach 2 condition was made. (Invalid for MGW-K)
Remedy : (1) Open the second page of COND MAIN screen, and when operating the
APPROACH 1 E. NO. or APPROACH 2 E. NO. key:
Register again the machining condition within the range of E9000 – E9999.
(2) In the automatic run mode, if operation is stopped when M71S_A_ approach condition
is changed in a program:
Register approach 1 or 2 condition manually in the same manner as (1) above, the
press START key.
Note: In manual run mode on COND screen : Guide
During execution of M71S_A_ block in auto mode : Warning 3
58
1510 WRITE PROTECTED CONDITION Guide W ARN RESET key
Description : An attempt to write a machining condition element to E No. on the COND LIST screen
failed, because that E No. has the write protected attribute. (After MGW-K)
Remedy : (1) Failure in writing is normal by current setting because of write protected attribute.
(2) If that E No. is to be written overriding the attribute, turn on the set data No.336 bit1,
then write the condition element to that E No.
1511 MISTAKEN ERASE PROTECTED CONDITION Guide W ARN RESET key
Description : An attempt to erase a machining condition E No.on the COND LIST screen failed, because
that E No. has the accidental erasure protected attribute. (After MGW-K)
Remedy : (1) Failure in erasing is normal by current setting because of accidental erasure protected
attribute.
(2) If that E No. is to be erased overriding the attribute, turn on the set data No.336 bit2,
then erase that E No.
1512 ERASE PROTECTED CONDITION Guide W ARN RESET key
Description : An attempt to erase a machining condition E No.on the COND LIST screen failed, because
that E No. has the erasure protected attribute. (After MGW-K)
At present, there is no E No. assigned with the erase protected attribute.
Remedy : Only the E No. except the E No. assigned with the erase protected attribute can be erased.
1513 NO USER CONDITION AREA Guide W ARN RESET key
Description : An attempt to add E No. was made, but the user condition area is full and no more E No.
can be added. (After MGW-K)
Registrable machining conditions are total 600 conditions including Makino standard
conditions and user own conditions (Note).
Note: 600 conditions are guaranteed minimum value. In fact, more conditions can be
registered, but the quantity (another several ten conditions) may vary
depending on the software version. This warning guide is given when this
memory quantity is also full.
Remedy : Erase unnecessary E numbers, then add necessary E numbers.

Example: G10 command is used to erase and add E No.
(1) Erase unnecessary E No. (E1000-E1999) G10L22I1000J1999;
(2) Add necessary E No. (E3000-E3009) G10L20I3000J3009;
1514 EXISTING E NO SPECIFIED Guide W ARN RESET key
Description : An attempt to add E No. on the COND LIST screen failed because that E No. already exists.
(After MGW-K)
Remedy : Failure in addition is normal because that E No. already exists.

To add that E No. as initial value, erase it once, then add it again.
Example: Initialize E9000 (if using G10 command)
(1) Erase E9000 (G10L22I9000;)
(2) Add E9000 (G10L20I9000;)
1521 M90 COMND ERROR Alarm 2 RESET key
Description : In M90P_Q_; block, a value out of the P0-P2 or Q0-Q1 range was specified.
60
1522 CANNOT CONTROL CUTOFF MACHINING Warning 2 W ARN RESET key
Description : The remain/cutoff machining command was specified during radius compensation cancel
mode (G40).
1523 STOP BEFORE M08 Warning 1 W ARN RESET key
Description : The program stopped at the head of M08 block due to a setting on the SET, M08 CONTROL
screen.
1524 STOP AFTER M08 Warning 1 W ARN RESET key
Description : The program stopped after movement of M08 block due to a setting on the SET, M08
CONTROL screen.
1525 MACHING SKIP UNTIL M8 BLOCK BY M90Q1 Warning 1 W ARN RESET key
Description : On the M8 CONTROL screen, M17 was specified for "SHAPE PART: 1 (SKIP
MACHINING)". If "SHAPE PART" is set to 1 (SKIP MACHINING), the machining power is
not turned on until the M8 block even though M17 was specified.
Cause : Besides a direct change on the M8 CONTROL screen, if the same N No. is set to "SHAPE
N NO." and "CUT-OFF N NO." of the model plan, "SHAPE PART" is set to 1 (SKIP
MACHINING).
1526 M8 BLOCK DIVISION INVALID IN G40 Warning 1 W ARN RESET key
Description : In the radius compensation cancel mode, M8 was specified with "BD BLOCK DIVISION"
set to 1 (DIVIDE) on the M8 CONTROL screen.
The M8 block divide function is invalid during radius compensation cancel mode.
1530 G10 (E) COMMAND ERROR Warning 3 W ARN RESET key
1531 G10 (L) COMMAND ERROR Warning 3 W ARN RESET key
1532 G10 (P) COMMAND ERROR Warning 3 W ARN RESET key
1533 G10 (Q) COMMAND ERROR Warning 3 W ARN RESET key
1534 G10 (R) COMMAND ERROR Warning 3 W ARN RESET key
1535 G10 (I) COMMAND ERROR Warning 3 W ARN RESET key
1536 G10 (J) COMMAND ERROR Warning 3 W ARN RESET key
1537 G10 (K) COMMAND ERROR Warning 3 W ARN RESET key
1538 G10 (G) COMMAND ERROR Warning 3 W ARN RESET key
1539 G10 (M) COMMAND ERROR Warning 3 W ARN RESET key
Description : Set value of address word (E,L,P,Q,R,I,J,K,G,M) in the G10 block (G10L10, G10L20-L23)
is illegal. (After MGW-K)
Remedy : Check the G10 command format, and correct the program.
1540 TRANSFER CAN ONLY IN RESET MODE Guide W ARN R ESET key
Cause : On the COND, MODEL SEARCH screen, an attempt to transfer the searched rough
machining conditions as modal data was made though the machine is not in RESET status.
Remedy : Place the machine in RESET status, and then transfer the data as modal data.
62
1700 ILLEGAL FEED RATE PARAMETER Alarm 2 RESET key
Cause : The parameter value related to the feed rate is illegal and thus the feed rate cannot be
calculated.
1716 MEASURING COMND SPECIFIED AXIS ERROR Alarm 2 RESET key
Causes : The following errors were caused when specifying X- and Y-axes in the automatic
measuring by G76 to G85.
(1) G76, 77, 80 : X- and Y-axes were specified
(Only one of them needs be specified.)
(2) G76 – G85 : No axis was specified.
(3) G83 : G83 L specification or I, J specification error
(4) G79, G80, G82, G84, G85 : It is necessary to specify X- and Y-axes.
(5) G83 was specified when either mirror image, axis exchange, scalling or rotation is
activated (G92 miss setting prevention).
1717 MEASURING COMND ANGLE REGISTER ERROR Alarm 2 RESET key
Cause : The angle A numerical values of G79, G84 and G85 are other than 0 to 9.
1720 MEASURING APPROACH NEVER TOUCHED PART Alarm 2 RESET key
Cause : When approach movement was made in the automatic measuring, the workpiece was not
touched.
Remedy : Check the specified value, the measuring start position and the workpiece position.
Clean the wire surface and the workpiece touch surface.
1722 MEASURING SKIP (DRY RUN, MACH LOCK, GRAPHICS) Warning 1 W ARN RESET key
Cause : At dry run, at machine lock or at graphic, skip was made due to presence of G76 to G85
(automatic measuring) command.
Remedy : Execute G76 to G85, during condition other than at dry run, at machine lock or at graphic.
1730 G86, G87 PROGRAM FORMAT ERROR Alarm 2 RESET key
Cause : Improper value was specified for G86/G87 command.
1731 MEASURE AND MACHINING MODE MEASURING Warning 1 W ARN RESET key
Cause : This message is displayed at the time of measurement start in the automatic measuring and
machining mode.
64
1732 G86, G87 EXCESS STOCK REMOVAL Warning 3 W ARN RESET key
Cause : If the measurement result shows that the stock removal to the finish reference dimension
exceeds the set data No. 205 value, the system determines that the stock removal is too
large and stops operation.
Skip or remeasurement is determined depending on the setting of set data No. 200 bit 1.
1733 G86, G87 SKIP REMEASURING Warning 1 W ARN RESET key
Cause : This message is displayed when measurement was skipped by the setting of set data No.
200 bit 1.
1734 IN MEASURE AND MACHINING MODE Warning 1 W ARN RESET key
Cause : This message is displayed when a proper stock removal was left by the setting of set data
No. 200 bit 2, and a machining is executed.
1735 MEASURE AND MACHINING MODE COMPLETION Warning 1 W ARN RESET key
Cause : If the measurement result shows that the stock removal to the finish reference dimension
is smaller than set data No. 206 value, the system determines that the stock removal is too
small for additional machining and ends automatic measuring and machining operation.
This case is a normal finish condition, so it is not a stop status.
1736 G86, G87 EXCESS DEVIATION OF MEASURED DIM. See Note W ARN RESET key
Cause : If difference between maximum and minimum of measured values obtained in the edge
face measurements of 5 times per side is larger than set data No. 203 value, the system
determines that measurement reliability is low and displays this message.
Note: Operation does not go in stop status when the set data No. 200 bit 2 is set to
"1".
Bit 2 0: Machining is executed if measured values do not disperse and there is proper
stock removal remained. (Warning 3)
1: Only measurement is done, but not machining. (Warning 2)
1740 STOP STS BY M74, PROCESSES WERE SKIPPED Warning 3 W ARN RESET key
Cause : The system goes in stop status with this message displayed at the time of automatic wire
threading for the part (non-machined part) targeted by "M6 search" of additional machining
function.
Note: When operation is restarted, automatic wire threading and machining for that
hole are executed. To skip also that part, press the M.COND.SKIP key, then
the START key, so that automatic wire threading and machining for that hole
are skipped.
1741 M6 SEARCHED BY M74, A.W.T. MISSED (1) Warning 1 W ARN RESET key
1742 M6 SEARCHED BY M74, A.W.T. MISSED (2) Warning 1 W ARN RESET key
Cause : The part that was not targeted by "M6 search" (i.e., already machined part) at the time of
"SKIPPED MACHING" OFF is automatically targeted by the "M6 searched by M74, A.W.T.
mised (1), (2)" (i.e., skipped from machining) at the time of "SKIPPED MACHING" ON.
66
1800 TV ERROR AT I/O INPUT Warning 1 W ARN RESET key
Cause : Parity error in the tape vertical direction.

Parity check of one block in the vertical direction of the input tape indicated an odd number
of characters in one block (from the code next to LF to LF).
Remedy : Correct the program tape or make invalid the TV check of the set data No. 0025 bit 0.
1801 TH ERROR AT I/O INPUT Warning 1 W ARN RESET key
Causes : Parity error in the tape horizontal direction.

The number of holes of the character read after detecting the first CR (EIA code) or LF (ISO
code) of the input tape does not meet the following conditions.
(1) EIA code: The number of holes is odd.
(2) ISO code: The number of holes is even.
Remedy : Correct the program tape.
1802 IMPOSSIBLE TO CANCEL INPUT/OUTPUT Warning 1 W ARN RESET key
Cause : The tape input/output operation was canceled by the RESET key, but cancel operation
was not completed within the fixed time (0.5 s).
Remedy : (1) Retry operation, or turn on the power again.

(2) In case of frequent failure, contact to us of the trouble condition.
1810 ALL NC PROGRAMS CLEARED AT PW OFF BY MISTAKE Alarm 2 See Remedy.
Causes : The power supply was turned OFF under the following conditions.
(1) The program was closed by pushing LIST key in the Editing Block screen.
(2) Indexing was operating in the Editing List screen.
(3) The tape was being input in the Editing List screen.
(4) During deleting in the Editing List screen.
Remedy : Register the program again.
1811 SYS. RESERVE PRO-CLEARED AT PW OFF BY MISTAKE Alarm 2 See Remedy.
Remedy : Since the system macro (from O10000 on) is normally maintained as ROM, it is not required
to register it again. When the machine is provided with a specific macro in paper tape on
floppy disk, however, re-register it.
1812 USER PROGRAM CLEARED AT PW OFF BY MISTAKE Alarm 2 See Remedy.
Remedy : Register the program again.
68
1813 EDIT STOPPED AT PW OFF BY MISTAKE Alarm 2 RESET key
Cause : The power was turned off during the program editing on the EDIT BLOCK screen.
Remedy : Reedit the O No. program which was being edited on the EDIT, LIST screen and press
the LIST key to close the program.
1990 BLOCK DATA ERROR (1) Alarm RESET key
Cause : Internal data check error in the NC program run system.
2000 AUTOMATIC WIRE THREADING SKIPPED Warning 3 W ARN RESET key
Cause : The automatic wire loading (M6, M7) was specified although the automatic wire loading skip
on the NC FUNC screen was valid or there is no automatic wire loading unit.
Remedy : Reset the automatic skip on the NC FUNC screen and press the START key.
Alternatively, manually make wire cutoff and loading and then press the START key.
2001 CLAMP LEVER OPEN Warning 3 W ARN RESET key
Description : Not used (L_SUP).
2002 WIRE REVERSE FEED TIME OVER Warning 3 W ARN RESET key
Cause : In rewinding the wire during automatic wire threading, the wire tip cannot be detected within
the wire reverse feed limit time (machine parameter No. 686). (*WT_SEN=1)
Remedy : If a wire is not rewound completely or it is caught by workpiece, remove the wire and press
the START key.
If a wire is not left, clean and adjust the sensor, then press the START key.
2003 DANCING ROLLER POSITION ABNORMAL Warning 3 W ARN RESET key
Description : Not used (L_WD, L_WU).
2004 CUTTER MOTION ABNORMAL Warning 3 W ARN RESET key
Cause : The cutter for automatic wire threading malfunctions, or a wire cut-off cannot be confirmed.
(WDN=0)
Remedy : Check the cutter operation (CUTTER=1) or the wire feed system. Remove the cause of
cut-off failure, and press the START key.
2005 WIRE WAS REVERSED BUT STILL TOUCHES WORK Warning 3 W ARN RESET key
Cause : In the automatic wire threading (NC AWT retry 1–3), the wire touch cannot be reset
(*TOUCH_B=0) though the wire is rewound up to the wire tip sensor (*WT_SEN=0).
Remedy : Check the wire feed system. Remove the cause of touch and then press the START key.
70
2006 WIRE FORWARD FEED TIME OVER Warning 3 W ARN RESET key
Cause : In the automatic wire threading (NC AWT retry 0, 1, 3), the AWT does not complete within
the wire feed limit time (machine parameter No. 693) or the wire feed length reached the
value (MGW-H, machine parameter No. 591).
Remedy : Remove the cause of failure and cut off excess wire. Then press the START key.
2007 AUTOMATIC WIRE THREADING RETRY OVER MAX. Warning 1 W ARN RESET key
Cause : The head moves to the next M6 point by M6 search function due to post-processing set by
set data No. 101 after AWT failure within the specified retry count or time.
2008 WIRE NOT PRESENT AT OPTICAL SENSOR (WL_SEN1) Warning 3 W ARN RESET key
Cause : When the NC function automatic wire loading retry 2 was set, there was no wire detected
on the wire path sensor at stasrt of automatic wire threading. (*WL_SEN=0)
Remedy : Set wire at the front of the wire path sensor and press the START key.
2009 A.W.T. RETRY TIME OVER FOR SMALL HOLE A.W.T. Warning 1 W ARN RESET key
Cause : The head moves to the next M6 point by the M6 search function due to the post-processing
(set data No. 101) after fine hole AWT was not completed within the specified time (machine
parameter No. 695).
2010 NO WIRE AT EDGE SENSOR (WT_SEN) Warning 3 W ARN RESET key
Cause : Upon completion of automatic wire threading, the wire was not detected at the wire tip edge
sensor. (*WT_SEN=0)
Remedy : Press the RESET key to restart because the AWT was completed in erroneous path, or
thread the wire manually and press the START key.
2011 U, V AXIS NOT ZERO BEFORE A.W.T. START (M6) Warning 3 W ARN RESET key
Cause : U- and V-axes are not at the vertical position at automatic wire loading (M6).
Remedy : Return them to the vertical position manually or by MDI operation and press the START
key. Even without returning to the vertical position, operation can be resumed by press the
START key.
2012 ILLEGAL MACHINE TYPE SELECTED Warning 3 W ARN RESET key
Cause : In registering the parameters by machine type (O13900), selection of machine type (setting
of system parameter No. 930 bits 0–7) is improper.
Remedy : Press the RESET key, then confirm the model by pressing the HELP key for the
system parameter No.930/No.940 (type of amplifier: MGW-K ~), and press the START
key with correct values.
2013 AUTOMATIC START HOLE DEVICE NOT READY Alarm 2 RESET key
72
2014 SEARCH IN NEXT PROCESS M6 BY M74 Warning 1 W ARN RESET key
Cause : The process number targeted by "M6 search" inthe process skip function (M74L_) is
skipped from all subsequent operations (e.g., a part targeted by M6 search in a rough
machining is prevented from a finish machining).
Remedy : Perform machining of the skipped part later (see SKIPPED MACHING key, M74).
2015 A.W.T. RETRY AT REFERENCE HOLE Warning 1 W ARN RESET key
Cause : The head moves to the reference position specified by M75M_Y_ and makes a new wire
leading edge via loading → cut, then again returns to the original point for automatic wire
loading retry.
This message is displayed during above operation.
2016 REFERENCE HOLE RETRY OVERTIMES Warning 3 W ARN RESET key
Cause : This message is displayed when the number of retry times exceeds the machine parameter
No. 717 setting (reference hole retry times limit, standard 3 times).
2017 MC SEQUENCE MACRO PROGRAM ERROR Warning 3 W ARN RESET key
Cause : An error occurred in the operating process of the system program "Machine sequence
macro".
2018 AT TOUCH RETRY Warning 1 W ARN RESET key
Cause : After the wire threading succeeded, the touch sensing function checks if the wire touches
the workpiece. If it touches (*TOUCH_B=0), the wire is cut off, then threaded again.
This message is displayed during above operation.
Remedy : To disable the touch sensing function, set the set data No. 45 bit 3 to "0".
2019 TOUCH RETRY OVERTIMES Warning 3 W ARN RESET key
Cause : This message is displayed when the number of retry times exceeds the machine parameter
No. 716 setting (touch retry times limit, standard 3 times).
2020 TANK DOOR UNLOCK Warning 3 W ARN RESET key
Cause : The TANK FILL key (option: M. CONTROL screen or COND SUB screen) was pressed
while the work tank door was open. (*DR_OPN=0)
Remedy : Close the work tank door and operate the key.
2021 WORK TANK UPPER LIMIT Warning 3 W ARN RESET key
2022 R.W.B/R.P.F. M6PQR FORMAT ERROR Alarm 2 RESET key
Cause : A combination of P, Q and R is illegal.
Remedy : Program a set of P and Q or P, Q and R.
74
2023 TAPER MODE = 2! (= DRAW PLANE) Warning 3 W ARN RESET key
Description : M17 (machining ON) is specified in the taper mode 2 on the NC FUNC screen.
The taper mode 2 is for checking graphic at arbitrary height of taper program, and it is
seldom used for machining, and therefore this warning message is displayed to alert the
operator, but operation is not stopped.
Note: This warning is not displayed in the graphic mode.
Remedy : (1) If you are under graphic checking, continue operation.
(2) If you forgot to change taper mode after graphic check, press RESET key, then
change taper mode.
2024 SLUICE OVERTRAVEL OR MOTOR CURRENT OVER Alarm 2 RESET key
2025 SLUICE PLATE DRIVING UNIT ABNORMAL Warning 3 W ARN RESET key
2026 SLUICE PLATE HEIGHT CONTROLLED BY Z POS. Warning 1 W ARN RESET key
2027 M28Q NUMERICAL COMND ERROR Warning 1 W ARN RESET key
Cause : The fluid level command M28Q_ is out of the allowable range for M28 (TANK FILL).
Remedy : Correct the M28 program (setting range: 0 – 3000 mm)
2028 CUTTER UNIT IS NOT VERTICAL OR RECESSION Warning 3 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2, the cutter unit is not in vertical (UPH-1) or reverse position
(UPH-2/UH-2) when the work tank starts to rise.
Remedy : Press the RESET key, then execute M6 I/O RETURN to set the cutter unit in vertical or
reverse position.
2029 WIRE FORWARD FEED LENGTH OVER Warning 3 W ARN RESET key
Cause : On the machines with the wire length measuring function, automatic wire threading does
not finish though the wire feed length exceeds the parameter No.591 set value.
Remedy : Remove a cause, then cut off excessive wire and press START key for restart.
2030 WATER CONDUCTIVITY DOWN Warning 2 W ARN RESET key
2031 ION EXCHANGE RESIN NEEDS REPLACING Warning 3 W ARN RESET key
Cause : The water conductivity is out of the set value though ion exchange has been turned on
(MION=1) for more than 24 hours.
The warning message will be displayed every 4 hours since then.
Remedy : Replace ion exchange resin.

The flow rate may be deficient due to clogged piping to the ion exchange resin.
2032 PUMPS SWITCHED OFF Warning 3 W ARN RESET key
Cause : The PUMPS OFF key on the MACH OPE screen is turned on.
Remedy : After making sure the safety around the dielectric fluid supply unit, turn off the
PUMPS OFF key.
76
2033 WATER RESERVOIR LOW Warning 1 W ARN RESET key
Cause : On the machine except UPH-1, the specified time has elapsed (Note) where the fluid level
in a dirty tank of dielectric fluid supply unit is below the lower float (*FLOAT2=0).
Note: 60 seconds for MGW-J/K, MV-30 or 30 seconds for other machines.
Remedy : Add dielectric fluid.

For the machine with automatic water feeder (option), the water is fed from city water, and
stopped at the upper float (*FLOAT1=0).
2034 WATER RESERVOIR UPPER LIMIT SWITCH BROKEN Warning 3 W ARN RESET key
Description : On the machine with automatic water feeder (option), automatic water feed failed due to
faulty upper float in a dirty tank of dielectric fluid supply unit.
Causes : (1) The float signal is faulty, if the lower float in dirty tank dropped (*FLOAT2=0), then after
the specified time (Note), the upper float rises (*FLOAT1=0).
Note: 60 seconds for MGW-J/K, MV-30 or 30 seconds for other machines.
(2) Both upper and lower floats dropped and automatic water feed valve turned on
(SVP1=1), but the upper float or lower float is left down though 10 minutes elapsed.
Note: On the MGW-K power supply unit, the warning 2034 in (2) will not occur in
the 12.2 or later versions. The water supply completes in the time set to
the machine parameter No.728 (standard 10 minutes).
Remedy : (1) Clean or replace the float.

(2) Check or replace signal lines, if 0/1 of upper float (*FLOAT1) is contradictory to up/down
position on the DIAGNOSE EIO screen.
(3) If float operation in (1) and (2) is normal, turn on the automatic water feed valve
(SVP1=1) for 10 seconds on the DIAGNOSE EIO screen, then confirm that water is fed
actually. If not fed, check the water line from main valve of city water up to water filling
port.
(4) Refill water automatically or manually up to proper level, then restart operation.
Notes:(1) If piping has not been connected on the machine with automatic water
feeder, turn off the system parameter No.0934 bit 0, and turn off and on
the power switch to feed the water in manual mode.
(2) Please contact us for further information.
2035 WATER RESERVOIR FILTER NEEDS REPLACING Warning 3 W ARN RESET key
Description : On the machines with the MGW-J/K/JP/MV-30, the water filter reached its life.
(PR_OVER1=0)
Or, an attempt to restart the operation was made without turning on/off the PUMPS OFF
key.
Cause : Water filter is clogged.
Remedy : Turn ON the PUMPS OFF key on the MACH OPE screen, then replace the water filter.
After replacement, turn OFF the PUMPS OFF key. Be sure to turn ON/OFF the
PUMPS OFF key.
2036 A.W.T. JET FILTER NEEDS REPLACING Warning 3 W ARN RESET key
Description : Not used (*PR_OVER2).
2037 UPPER HEAD SUBMERGED Warning 3 W ARN RESET key
Description : On the machine with FILL function, the upper head submerged detection float rose.
(*W_OVHEAD=0)
Cause : The fluid level during filling is too high, compared to upper head height.
Remedy : Submerged upper head results in short lifetime.
Turn on the TANK FILL key, lower the fluid level so that upper head is not submerged,
then restart.
78
2038 CLEAN RESERVOIR LOW Warning 3 W ARN RESET key
2039 START SUPPLYING TO CLEAN TANK FOR TANK FILL Warning 3 W ARN RESET key
2040 CHANGE SLUDGE BAG Warning 3 W ARN RESET key
2041 BACK FLUSHED Warning 3 W ARN RESET key
2042 WORK TANK FLUID LEVEL LOW Warning 3 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2/W-PG1, the fluid level in the work tank lowers during the
FLUID key ON, and the float lowers accordingly. (UPH-1/UPH-2/UH-2: F_FLT=0,
W-PG1:F_FLAT=0)
Cause : The dielectric fluid supply unit is faulty, float malfunctions, or fluid filter is clogged.
Remedy : In case of frequent failure, contact to us of the trouble condition.
2043 WAIT UNTIL WORK TANK FLUID LEVEL UP Warning 1 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2, this message is displayed while the float now on low level rises
up to the specified level. (F_FLT=0)
2044 WORK TANK UP/DOWN MOTOR OVERLOAD Alarm 2 RESET key
Cause : On the MGW-J/K or MV-30 with the work tank elevator, the work tank failed.
(MGW-J:W_GATE_AL:1 MGW-K/MV-30:TNK_INV_AL))
2045 WORK TANK POSITION IS BELOW FILL LOWER LIMIT Warning 3 W ARN RESET key
Cause : On the PF-32, the work tank height is below 130 mm (machine parameter No. 7670) during
a tank fill operation.
Remedy : Rais the work tank over 130 mm, then execute the tank fill operation.
2046 WATER MODE ALLOWING FLUSHING AT TANK FILL Warning 3 W ARN RESET key
Cause : On the machine with MGW-G/MGW-J and the work tank elevator, only the WATER key
was turned on without turning on the TANK FILL key though the WATER mode in which
the flushing is possible with a full tank only is selected.
Remedy : Turn on the TANK FILL key, then the WATER key.
Or, change the setting of set data No. 106 "FLUSHING ALLOWABLE WATER MODE AT
TANK FILL" to make flushing possible at any time, the press the RESET key to turn on
the WATER key.
2047 NO PALLET IN CHUCK Warning 3 W ARN RESET key
Description : Not used (CHUCK_CLMP).
2048 ION EXCHANGED OFF Warning 1 W ARN RESET key
Description : The ON OFF key on the MACH OPE screen is turned on. (Replacing ion exchange resin
during automatic operation)
Remedy : Turn off this key when replacement of ion exchange resin is finished.
80
2049 WATER IS OFF Warning 3 W ARN RESET key
Description : The MACHING POWER key on the MACH OPE screen is inactive during water off mode.
(After MGW-K)
Remedy : The MACHING POWER key on the MACH OPE screen is active only when the
WATER ON is turned on.
2050 WATER RESERVOIR 1 FILTER NEEDS REPLACING Warning 3 W ARN RESET key
2051 WATER RESERVOIR 2 FILTER NEEDS REPLACING Warning 3 W ARN RESET key
Description : On the machine with additional filters (optional), the filter pressure exceeds the tolerance
(machine parameter No.898) when the water filter 1 or 2 is used.
Cause : Filter is clogged with chips, etc.
Remedy : Depending on the filter mode used during failure, perform as follows.
(1) In the case of fixed filter 1 mode, change mode to fixed filter 2 and restart, then replace
the filter 1.
(2) In the case of fixed filter 2 mode, change mode to fixed filter 1 and restart, then replace
the filter 2.
(3) In the case of automatic filter switching mode, operation is not stopped, but another filter
is automatically selected.
Note: If currently selected filter is replaced, be sure to turn on the PUMPS OFF
key.
2052 WATER RESERVOIR 1, 2 FILTERS NEED REPLACING Warning 3 W ARN RESET key
Description : On the machine with additional filters (optional), the pressure of both filters exceeds the
tolerance (machine parameter No.898) when both water filters 1 and 2 are used.
Cause : Filters are clogged with chips, etc.
Remedy : Turn on the PUMPS OFF key, replace both filters, reset the PUMPS OFF key, then
restart.
2053 FILTER PRESSURE SENSOR ERROR Warning 3 W ARN RESET key
Description : On the MU43 or MUQ32, the value sensed by filter pressure sensor is too low.
With this warning, the filter pump speed becomes constant speed (50 Hz)
Cause : Filter pressure sensor is defective or malfunctions.

Values of "AD-IN10 – AD-IN17" is below 80% of machine parameter No. 902.
Remedy : After machining is finished, turn on/off the PUMPS OFF key, then reset the warning
stastus.
If this failure occurs again, contact to us of the trouble condition.
2054 WATER OVERFLOW TO PUMPS STOP Warning 3 W ARN RESET key
Description : The water flowed over the work tank when the FLUID or TANK FILL key on the W-PG1 is
turned on.
Causes : (1) Unbalanced tank filling and drain causes the water level to rise gradually.
(2) The rapid feed pump did not stop due to faulty float.
(3) The water leaked from work tank by a centrifugal force during C-axis rotation.
2055 AUTO SUPPLY START Warning 1 W ARN RESET key
Description : On the machine with MGW-J or MGW-K attached with the tank fill function and dielectric
fluid automatic adding function, this message is displayed to indicate that the total fluid
volume in the dielectric fluid supply unit is checked when the M28 (tank fill ON) is executed
or the OPT.TANKFILL key on COND SUB screen or MACH OPE screen is turned on, if
the set data No. 57 bit 4 is set to ON (standard setting OFF).
82
2056 AUTO SUPPLY COMPLETION Warning 1 W ARN RESET key
Description : This message indicates that the fluid volume was checked in the above No. 2055, and
automatic fluid addition by the amount of shortage has completed.
2057 AUTO SUPPLY STOP Warning 1 W ARN RESET key
Description : This message indicates that the low fluid level was detected in the above No. 2055, but
automatic fluid addition is not executed because of faulty upper level float.
Causes : (1) In the previous automatic fluid addition, the upper level float in dirty tank was not turned
on (*FLOAT=0) within the max. fluid feed time.
(2) The upper level float in dirty tank is faulty.
Remedy : The float will be faulty or disconnected. Contact to us of the trouble condition.
2058 MACHING IS POSSIBLE IN WORK TANK FILLED Warning 3 W ARN RESET key
Description : On the EU64, an attempt to turn on the MACHING POWER key was made though the
TANK FILL key is in OFF status.
Remedy : Turn on the TANK FILL key first, then turn on the MACHING POWER key.
2059 FILLING-OFF IS IMPOSSIBLE IN MC POWER ON Warning 3 W ARN RESET key
Description : On the EU64, an attempt to turn off the TANK FILL key was made though the
MACHING POWER key is in ON status.
Remedy : Turn off the MACHING POWER key first when turning off the TANK FILL key.
2060 PLEASE CONFIRM WIRE CUTOFF CONDITION Warning 3 W ARN RESET key
2061 PLEASE CONFIRM WIRE THREADING CONDITION Warning 3 W ARN RESET key
2062 PLEASE M6 I/O RETURN Warning 3 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2, the I/O signal for M6 (automatic wire threading) is out of the
wire threading position.
Remedy : At the power ON, or if M6 is interrupted, press the RESET key, then turn on the
M6 I/O RETURN key on the RUN MANUAL screen.
2063 WIRE BREAK IN M06 Warning 3 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2, when automatic wire threading finished, a continuity check
between L/M shafts and energizing plate found a wire break.
Cause : A wire was broken when it was inserted in the guide and the guide closed.
Remedy : As a wire debris may be pinched in the wire guide, clean the wire guide, then restart
operation.
When this trouble occurs frequently, please contact to us of the trouble condition.
2064 M6 Y POSITION INCORRECT Warning 3 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2, an attempt to start automatic wire threading was made though
the Y axis machine coordinate is below 90.0mm (UPH-1) or 110.0mm (UPH-2/UH-2).
Remedy : On the UPH-1/UPH-2/UH-2, automatic wire threading with the Y axis position below the
value mentioned above will cause the interference between workpiece and cutter unit. First
move the Y axis machine coordinate to the position over 90.0mm (UPH-1) or 110.0mm
(UPH- 2/UH-2), then perform automatic wire threading.
84
2065 NONCONTACT POINT SEARCHING EXECUTION Warning 1 W ARN RESET key
Description : This message is displayed when the noncontact point search function is operating.
2066 NONCONTACT POINT SEARCHING COMPLETION Warning 1 W ARN RESET key
Description : The noncontact point search function found a noncontact point, then the operation stopped
there.
Remedy : Restart operation to execute the program.
2067 NONCONTACT POINT NOT FOUND Warning 3 W ARN RESET key
Description : The noncontact point search function could not find a noncontact point within the specified
range (parameter No.328 set value), then the operation stopped.
Remedy : (1) Change the search limit (parameter No.328), and execute again the noncontact point
search function.
(2) Correct the program.
2070 UPPER HEAD WATER PRESS. LOW Guide W ARN RESET key
2071 LOWER HEAD WATER PRESS. LOW Guide W ARN RESET key
Description : On the EQF5, in the water mode 6 for MF high speed machining, the upper or lower head
water pressure does not rise up to the value set to machine parameter No. 7656 (HIGH
PRESS. PUMP PRESS. MODE LOWER LIMIT).
Causes : (1) MF high speed nozzle has worn.

(2) MF high speed nozzle has been broken.
(3) Gap between nozzle and workpiece is over 0.5 mm.
(4) There is not workpiece between upper and lower heads.
(5) There is a spot face or slit in workpiece.
(6) Machining started from edge face.
Remedy : For (1) to (3), check the position of upper or lower head and the workpiece condition as well
as checking of MF high speed nozzle.
2072 UPPER HEAD PUMP ROTATION FREQ. LIMIT Guide W ARN RESET key
2073 LOWER HEAD PUMP ROTATION FREQ. LIMIT Guide W ARN RESET key
Description : On the EQF5, in the water mode 8 for MF high speed machining, the pump speed was
lowered to the value set to the machine parameter No. 7657 (HIGH PRESS. PUMP
ROTATION FREQ. LIMIT) because the pump speed that could destroy the upper or lower
head if the circuit is completely closed by a workpiece, etc. was specified.
Cause : Faulty parameter setting for water mode 8 for MF high speed machining (machine
parameters No. 887, 888).
Remedy : Set smaller parameter value of water mode 8 for MF high speed machining than machine
parameter No. 7657 (HIGH PRESS. PUMP ROTATION FREQ. LIMIT).
2101 MEASUREMENT IMPOSSIBLE.WIRE TOUCHES WORK Alarm 2 RESET key
Cause : While wire and the machine were in touch, measurment was attempted.
Remedy : Detach the wire, then perform again the touch sensing operation.
86
2102 EIS ALARM (2)
2103 APPROACH CYCLE ERROR AT MEASURING Alarm 3 RESET key
Cause : Illegal interruption occurred during touch sensing operation. (EIS card side)
Remedy : Repeat touch sensing operation.
2200 ARM NOT STANDBY POSITION Warning 3 W ARN RESET key
Cause : On the UPH-1/UPH-2/UH-2, with the core removing unit (option), the core removing
cylinder is not returned to the reverse position. (C_CYL_ARET_LS=0)
2201 ARM LOWER LIMIT SW. OFF Warning 3 W ARN RESET key
2202 ARM POSITION INCORRECT Warning 3 W ARN RESET key
2205 M73 FORMAT ERROR Alarm 2 RESET key
Cause : The address word following the core removing command M73 is illegal. On the UPH-1 /
UPH-2/UH-2, the L value is other than 0 and 1.
2206 M73 APPROACH ERROR Alarm 2 RESET key
2207 M73 TIME ELAPSED ERROR Alarm 2 RESET key
Cause : On the UPH-1/UPH-2/UH-2, with the core removing unit (option), the END signal is not
returned within the specified time.
2210 STOP STS DUE TO M73 Warning 3 W ARN RESET key
Causea : (1) On the UPH-1/UPH-2/UH-2, the M73 was specified in the graphic or dry run mode.
(2) On the UPH-1/UPH-2/UH-2, the M73 was executed though the optional unit is not
attached.
Remedy : Remove the core by hand if it remains. Then, press the START key.
2211 POWER FAILURE DURING M73 Warning 3 W ARN RESET key
Cause : On the UPH-1/UPH-2/UH-2, power failed during core following operation.
Remedy : Remove the core by hand if it remains. Then, press the START key.
88
2215 INVALID M73P1 BEFORE M73S1 Alarm 2 RESET key
2216 INVALID M73P0 BEFORE M73P1 Warning 3 W ARN RESET key
2217 SLUG NOT PRESENT AT MAGNET Warning 3 W ARN RESET key
2218 INPUT NOZZLE LEN. BEYOND LIMITS Warning 3 W ARN RESET key
2219 M73 PROHIBITED AREA Warning 3 W ARN RESET key
2300 +X EDGE MEASURING Warning 1 W ARN RESET key
2301 –X EDGE MEASURING Warning 1 W ARN RESET key
2302 +Y EDGE MEASURING Warning 1 W ARN RESET key
2303 –Y EDGE MEASURING Warning 1 W ARN RESET key
2304 HOLE CENTER Warning 1 W ARN RESET key
2305 VERTICAL ALIGNMENT Warning 1 W ARN RESET key
2306 WORK ZERO RETURN Warning 1 W ARN RESET key
2307 MACHINE HOME Warning 1 W ARN RESET key
2308 M6 POINT RETURN Warning 1 W ARN RESET key
2309 AT M6 Warning 1 W ARN RESET key
2310 M6 SHIFT RETURN Warning 1 W ARN RESET key
2311 AT M7 Warning 1 W ARN RESET key
2312 –Z AXIS EDGE FACE POSITIONING Warning 1 W ARN RESET key
2313 C AXIS CENTERING Warning 1 W ARN RESET key
2314 AT M6 I/O RETURN Warning 1 W ARN RESET key
2315 START POSITION RETURN Warning 1 W ARN RESET key
Description : The function displayed is being executed by the one-touch key operation.
Remedy : Confirm that correct key was pressed.

If a wrong key was pressed, stop the operation by pressing either STOP , RESET ,
or EMERGENCY STOP key.
2320 Z WORK ZERO RETURN? yes:START key no:RESET Warning 3 W ARN RESET key
Description : On the machine with automatic Z axis, in executing the work zero return operation with the
function key, operation may be stopped before the Z axis moves, accompanied by this
warning message.
Cause : This warning occurs only if the set data No. 0057 bits 6 and 7 are both set to "1" (selectable
by the user).
Remedy : Press the START key if the Z axis is to be returned to the work zero point after it stopped
by the warning.
Or, if the Z axis is not to be returned, press the RESET key, then change the setting of
set data No. 0057.
2321 IF COEFF. REVISED? yes:START KEY no:RESET --- ---
2322 TAPER ANGLE 3 ∼15 DEGREE --- ---
2325 C MACHINE HOME? yes:START KEY no:RESET Warning 3 W ARN RESET key
2326 C WORK ZERO RETURN? yes:START KEY no:RESET Warning 3 W ARN RESET key
2327 C M6 POSITION RETURN? yes:START KEY no:RESET Warning 3 W ARN RESET key
Description : On the machine with C axis, the operation was performed with the one-touch keys (Note)
while the set data No.0059 "FUNCTION SELECTION 9" bit6 is 0 and bit7 is 1.
Note: The one-touch keys refer to MACHINE HOME, WORK ZERO RETURN, and M6
P. RETURN.
Remedy : After the operation stopped with this warning message, press START key if the C axis
returned to the work zero point, M6 point, reference point, or start point.
If the C axis is not to be moved, press the RESET key, then change the set data No.0059
setting.
90
2330 WORK DRYING OFF Warning 3 W ARN RESET key
Description : This message indicates that the work drying off command (executed by pseudo code
M200) was executed to the work drying function (optional).
Remedy : Make sure that the desired command was specified.
2331 WORK DRYING ON Warning 1 W ARN RESET key
Description : This message indicates that the work drying off command (executed by pseudo code
M201) was executed to the work drying function (optional).
Remedy : Make sure that the desired command was specified.
2344 SUCTION NOZZLE ADJUSTMENT (O13904) Warning 1 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2, this message is displayed when the maintenance program
(O13904) to adjust a clearance between suction nozzle of automatic wire threader and left
side of workpiece is executed.
Remedy : Adjust the clearance to 0.2 to 0.4 mm when the suction nozzle comes to the right side and
the operation stops. The suction nozzle will return to the left if the START key is pressed.
2400 TENSION ADJUSTMENT COMPLETED Warning 1 W ARN RESET key
Description : This message is displayed at the end of second measurement (message No. 2402) of wire
tension ajustment macro (O13901) stored in the ROM on the MGW-J or MGW-K.
If the message No. 2400 is displayed, the tension set values of machine parameters (No.
0780–0795) have already been updated.
Remedy : After completion of all adjustment, record the updated set values of machine parameters
(No. 0780–0795).
2401 MEASURE 1ST TENSION Warning 3 W ARN RESET key
2402 MEASURE 2ND TENSION Warning 3 W ARN RESET key
2403 MEASURE 3RD TENSION Warning 3 W ARN RESET key
2404 MEASURE 4TH TENSION Warning 3 W ARN RESET key
Description : This message is displayed while the wire tension adjustment macro (O13901) stored in the
ROM on the MGW-J or MGW-K are being executed.
Remedy : Measure wire tension following the instruction given in the Instruction Manual "Operation".
After completion of macro, record updated setting values of machine parameters (No.
0780–0795).
2405 TANK MUST BE FILLED BEFORE SENSING Warning 3 W ARN RESET key
Description : This message will be displayed when the tank filling and measurement (optional function
for MGW-J, or standard function for MGW-K) starts.
Remedy : Check the work tank position, and then execute the tank filling and measurement. If the
work tank position is low, raise it and execute the tank filling and measurement again.
2410 TIMEUP OF PERIODICAL TENSION ADJUSTMENT Warning 1 W ARN RESET key
2411 PERIODICAL TENSION ADJUSTMENT STARTED Warning 1 W ARN RESET key
2412 PERIODICAL TENSION ADJUSTMENT COMPLETED Warning 1 W ARN RESET key
2413 WIRE BREAK AT TENSION ADJUSTMENT Alarm 2 RESET key
2414 RANGE OVER AT TENSION ADJUSTMENT Alarm 2 RESET key
2415 EXCESS TENSION ERROR Warning 3 W ARN RESET key
2416 TENSION ADJUSTMENT PROHIBITED (THIN WIRE) Alarm 2 RESET key
2420 AUTO TENSION ADJUSTMENT EXECUTED Warning 1 W ARN RESET key
92
2430 LESS WIRE REMAINS Warning 1 W ARN RESET key
Description : This message is displayed when the wire winding amount on wire winding shaft (P shaft) of
W-PG1 reaches the limit. (WP_FUL=1)
Remedy : After machining is finished, remove the wire bobbin set to the wire winding shaft (P shaft)
and set an empty bobbin.
2431 TENSION CONTROL ALARM Warning 3 W ARN RESET key
Description : The wire tensioning unit is on the W-PG1 is faulty. (TN_OVER=1)

Replacement of the part of wire tensioning unit will necessary.
2432 WIRE IS NOT FED WITH WINDING SHAFT RELEASED Warning 3 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2, the wire feed was attempted (by WIRE FEED key, M17 or
MEASURE-MENT, etc.) though the wire winding shaft is not engaged completely
(M_UP_LS=0).
Cause : The wire feed with the wire winding shaft released disorders meshing of gears on wire
winding shaft.
This failure will occur after auto wire threading is interrupted.
Remedy : Press the RESET key, then turn on the M6 I/O RETURN key on RUN, MANUAL
screen.
2800 M66W-M68W CODE MISSING (AWC RANDOM OFF) Warning 3 W ARN RESET key
Cause : M66W_~M68W_ were started in the AWC Sequential mode with the AWC RANDOM
key on the MACH OPE, AWC screen turned OFF and the set data No.135: FUNC
SELECTION 10, bit4 set to OFF.
Remedy : (1) Correct the program (change the AWC command to the one for Sequential mode (no
W command)).
(2) If AWC is to be executed in the random mode, turn on AWC RANDOM key on MACH
OPE, AWC screen, and restart M66W_ ;. (This key can be turned on in the MAN RUN
mode only.)
Note : Initially, the AWC mode has been set to free change mode.
Normally, use the AWC in the free change mode (set data No. 135: FUNC SELECTION
10, bit4 ON).
(Free change mode: Sequential and Random commands can be specified with the M
codes only.)
2801 M66W-M68W or M66P-M68P CODE MISSING Warning 3 W ARN RESET key
Cause : (1) In the AWC mode other than Sequential mode, M66W_~M68W_ commands were
started with the W_ value larger than the set value of machine parameter No.7900: NO.
OF AWC WORKS/PALLETS.
(2) In the AWC Random mode, M66~M68 were started without W command with the
AWC RANDOM key on the MACH OPE, AWC screen turned ON and the set data
No.135: FUNC SELECTION 10, bit4 set to OFF.
Remedy : (1) Specify M66W_~M68W_ commands within the set value of machine parameter
No.7900.
(2) If AWC is performed in the Sequential mode, delete W_ of M66W_~M68W_
commands, then restart.
Note 1 : Initially, the AWC mode has been set to free change mode. Normally, use the AWC
in the free change mode (set data No.135: FUNC SELECTION 10, bit4 ON).
(Free change mode: Sequential and Random commands can be specified with the M
codes only.)
Note 2 : For the 4-work or 3-work AWC, make a program with the value subtracted by 1 from
the set value of machine parameter No.7900: NO. OF AWC WORKS/PALLETS.
94
2802 AWC MOVE POSITION ERROR Warning 3 W ARN RESET key
Description : Start condition is not satisfied when executing AWC command (M66, M67 or M68).
Cause : (1) The spindle is not at AWC work change position set to the machine parameter No. *070
[2ND ZERO POINT] or No. *071 [*3RD ZERO POINT].
(2) In the gripper movement (magazine → spindle), the spindle positions in the range:
X-axis, machine PRM No.1070-42.0 (mm)
Y-axis, machine PRM No.2070-40.0 (mm)
from the AWC work change position. (AWC16 only)
Remedy : For both (1) and (2), press the RESET key and restart operation.
If this error recurs frequently, contact to us of the trouble condition. (In such a case, give
us information on macro variable value #510 (displayed on RUN PROG, MACRO DATA
screen) so that a cause will be known.)
2803 MODAL W SET VALUE ERROR Warning 3 W ARN RESET key
Description : In AWC automatic operation, illegal value was set to modal W.

(W=0 (Note) or value larger than the set value of machine parameter No.7900: NO. OF AWC
WORKS/PALLETS)
Remedy : Re-set the modal W to the value within the set value of machine parameter No.7900: NO.
OF AWC WORKS/PALLETS, then retry AWC automatic operation.
Note : This message is displayed only when M67 or M68 was started.
(M66 executes work loading only.)
2804 AWC START COND. NOT SATISFIED Warning 3 W ARN RESET key
Description : A failure occurred during operation with AWC automatic run M codes M66/M67/M68.
Cause : (1) In the AWC magazine work check, a work is present in the spindle though it should not
exist on the spindle side.
(2) In the AWC magazine work check, a work is not present in the spindle though it should
exist on the spindle side.
(3) During AWC operation, each axis has not returned to the specified position (machine
parameter No. *070 "2ND ZERO POINT" and No. *071 "3RD ZERO POINT").
(4) An attempt to move the arm was made with the gripper unclamped or the magazine in
forward position. (AWC16 only)
Remedy : (1) Confirm the presence of work on the magazine side, correct the machining program,
and restart the program. (Remedy for causes (1) and (2))
(2) Turn off and on the power once, then turn on the MACHINE HOME key on the RUN
MANUAL screen to return each axis to the reference point, and restart the program.
(Remedy for cause (3))
If this alarm recurs, please contact us.
(3) Move the arm to the magazine side and the clamp the gripper manually, then restart the
program. (Remedy for cause (4))
If this alarm recurs, please contact us.
Note : To make troubleshooting easier, please let us know the macro variable #510 value
(this can be confirmed on the RUN PROG, MACRO screen) when getting in touch with
us.
2805 VALID IN AWC SAFETY COVER OPEN Warning 1 W ARN RESET key
Description : On the machine with AWC safety cover (AWC16 only), the cover was opened, so that
manual work change becomes ready the even during automatic operation.
96
2806 M66-M68 INTERRUPTED BY AWC SAFETY COVER OPEN Warning 1 W ARN RESET key
Description : M66~M68 stopped because AWC safety cover was opened during operation of M66~M68.
(AWC16 only)
The operation related to AWC is disabled during operation of M66~M68.
Remedy : To restart the operation, close the AWC safety cover and turn on the START key.
2807 CANNOT AWC SAFETY COVER CLOSE DURING Warning 1 W ARN RESET key
OPERATE
Description : On the UPH-1/W-PG1 with the AWC safety cover (optional), an attempt to perform AWC
related manual operation was made with the AWC safety cover closed.
Remedy : Open the AWC safety cover when performing the AWC operation manually.
2808 CANNOT M66-M68 DURING OPERATION Warning 1 W ARN RESET key
Description : During operation of M66~M68, a function key on MACH OPE, AWC screen, or a switch was
operated.
The AWC operation is disabled during operation of M66~M68.
2809 ONLY VALID IN MANUAL MODE Warning 1 W ARN RESET key
Description : During auto run mode (MDI RUN or MEM RUN), a function key on switch that is only valid
in manual mode (Note) was operated.
Note : MDI RUN or MEM RUN → MAN RUN (including manual interruption).
2810 MC RUN TIME OUT (1) Warning 3 W ARN RESET key
Causes : The operation listed below is not completed within the predetermined time.
MC RUN TIME OUT (1) Wire feed, auto wire threading control
MC RUN TIME OUT (2) Fluid, tank control
MC RUN TIME OUT (3) AWC control
MC RUN TIME OUT (4) Pallet magazine control
MC RUN TIME OUT (5) Pallet magazine control
Remedy : The solenoid, pump or limit switch will be faulty. Contact to us of the trouble condition.
In such a case, give us information on macro variable values #510 (displayed on RUN
PROG, MACRO DATA screen) so that a cause will be known.
2815 MAGAZINE UPPER MODE Warning 1 W ARN RESET key
Description : On the UPH-1/W-PG1 with the 16-work AWC, this message indicates that the AWC
magazine is in the forward position.
Remedy : Move the magazine to the backward position, as the magazine rotation and M66~M68
commands are disabled if the AWC magazine is in forward position.
2816 GRIPPER CLAMP Warning 1 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2 with the 16-work AWC, the gripper cannot expand toward the
magazine because the gripper is closed.
Remedy : First unclamp the gripper, then advance it. (Turn on the GRIPPER UNC/CLAMP key on
the MACH OPE, AWC screen)
98
2817 FLUID TANK UPPER MODE Warning 1 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2, this message indicates that the work tank is in upper position
when AWC manual operation is performed.
Remedy : Move the work tank down, and then perform AWC manual operation.
2818 PREVENTIVE SPINDLE & GRIPPER, MAGAZINE CLASH Warning 1 W ARN RESET key
2819 PREVENTIVE MAGAZINE & GRIPPER CLASH Warning 1 W ARN RESET key
Description : On the UPH-1/UPH-2/ UH-2/W-PG1, when the AWC magazine zero return (3- or 4-work
AWC) or the arm movement (16-work AWC) is attempted, the magazine or arm cannot
move because the X or Y axis is within –40.00mm position from the work change position.
Remedy : Retract the X/Y axis over 40.00mm from the work change position (set values of machine
parameter No.1070/2070), then return the magazine to the zero point or move the arm.
2820 M63S CODE MISSING Warning 3 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2 with the spinning head, the rotation ON command M63S_ is
wrong.
Remedy : Check the M63S_ command in the program, and correct the program so that the command
is in a range of M63S00~S15.
2821 SPINDLE NO. RANGE OVER Warning 3 W ARN RESET key
2822 WORK UNCLAMP PROHIBITED AREA Warning 1 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2 with the spinning head or index head, an attempt to load/unload
the work holder was made at the position where the work holder loading/unloading is
prohibited.
Remedy : For the spinning head, first start the M62 command, then load/unload the work holder.
For the index head, first execute M60P1 or C-axis reference point return (UPH- 2/UH-2
only), then load/unload the work holder.
2823 SPINDLE START POSITION ERROR Warning 3 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2 with the spinning head, the spinning was attempted at the
position out of the X axis spinning allowable range. (Spinning allowable range, UPH-1: X
axis machine coordinate 30.0~90.0mm, UPH-2/UH-2: X axis machine coordinate 10.0~
270.0mm)
Remedy : Move the X axis within the spinning allowable range, and then operate the spinning head.
2824 AWC START COND. NOT SATISFIED (SPINDLE MODE) Warning 3 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2 with the spinning head, an attempt to start the AWC M code
(M66-M68) was made though the spinning head is unclamped.
Remedy : Execute M62 command (clamp the spinning head), then start M66-M68.
2825 SPINDLE UNCLAMP MODE Warning 1 See Rem edy
Description : On the UPH-1/UPH-2/UH-2 with the spinning head, the spinning head is unclamped.
Remedy : This message cannot be reset by the RESET or WARN RESET key.
Execute the M62 command to clamp the spinning head.
100
2826 M60 CODE MISSING Warning 1 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2 with the index head, the index command M60 is wrong.
Remedy : Check the M60 command in the program and correct the program.
2827 P.F. DURING M66-M68 R.P.F.? yes: START, no: RESET Warning 3 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2 with AWC unit, the power failed during execution of M66~M68.
Remedy : After confirming that AWC equipment does not interfere with axes on workpiece, press the
START key to execute the power failure recovery operation.
If interference is expected, press the RESET key and return manually the AWC
equipment to the home position to avoid interference between AWC equipment and axes
or workpiece. (To operate the AWC equipment, open the MACH OPE screen and AWC
screen.)
2828 NOT ZERO RETURN AWC MAGAZINE Warning 3 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2/W-PG1 with AWC unit, AWC magazine zero return operation
has not been completed.
Remedy : Perform the AWC magazine zero return operation (turn on the MAGAZINE ZERO RTN
key on the MACH OPE, AWC screen).
2829 TURNING-OVER POS. OF GRIPPER IS AWC MAGAZINE Warning 1 W ARN RESET key
Description : On the UPH-2/UH-2 with the 16-work AWC unit, manual magazine index operation is
disabled because the gripper turning position is on the magazine side.
Remedy : Turn the gripper toward the spindle side. (Turn on the GRIPPER TURN key on the MACH
OPE, AWC screen)

2830 GRIPPER FORWARD MODE Warning 1 W ARN RESET key
Description : On the UPH-2/UH-2 with the 16-work AWC unit, manual magazine index operation is
disabled because the gripper is in the forward position.
Remedy : Reverse the gripper, then turn the gripper toward the spindle side.
(Turn on the GRIPPER ADV/RET key, then GRIPPER TURN key on the MACH OPE,
AWC screen)
2831 SHUTTER IS CLOSED Warning 1 W ARN RESET key
Description : On the UPH-2/UH-2 with the 16-work AWC unit, the shutter is closed when an attempt to
move the arm was made.
Remedy : Open the shutter, then move the arm. (Turn on the SHUTTER key on the MACH OPE,
AWC screen)
2832 TURN OVER IN GRIPPER Warning 1 W ARN RESET key
Description : On the UPH-2/UH-2 with the 16-work AWC unit, an attempt to advance/retract the gripper
was made but the gripper turn position is not on the magazine side.
Remedy : Move the arm to the magazine side, then turn the gripper toward the magazine side.
(Turn on the ARM ← key, then GRIPPER TURN key on the MACH OPE, AWC screen)
2833 MOVE ARM TO SIDE OF AWC MAGAZINE Warning 1 W ARN RESET key
Description : Description: On the UPH-2/UH-2 with the 16-work AWC unit, an attempt to advance/retract
the gripper was made but the arm position is not on the magazine side.
Remedy : Move the arm to the magazine, and turn the gripper toward the magazine side.
(Turn on the ARM ← key, then GRIPPER TURN key on the MACH OPE, AWC screen)
102
2834 AWC MAGAZINE IS DURING OPERATION Warning 1 W ARN RESET key
Description : On the UPH-2/UH-2 with the 16-work AWC, an attempt to turn the gripper and to advance/
retract the gripper was made during operation of magazine.
Remedy : Perform the gripper operation after the magazine operation finished.
2835 GRIPPER ADVANCE MODE Warning 1 W ARN RESET key
Description : On the UPH-2/UH-2 with the 16-work AWC, an attempt to move the arm was made with the
gripper in advance position.
Remedy : Move the gripper in the retract position, then move the arm.
(Turn on the GRIPPER ADV/RET → GRIPPER TURN → ARM → key on the MACH
OPE, AWC screen)
2836 ARM IS DURING OPERATION Warning 1 W ARN RESET key
Description : On the UPH-2/UH-2 with the 16-work AWC, an attempt to operate the arm, gripper, or
magazine was made while the arm was moving.
Remedy : Operate the arm, gripper, or magazine after the arm movement finished.
2837 CANNOT AWC SAFETY COVER OPEN DURING OPERATE Warning 3 W ARN RESET key
Description : On the UPH-2/UH-2 with the AWC safety cover (optional), an attempt to perform AWC
related manual operation was made with the AWC safety cover left open.
Remedy : Close the AWC safety cover when AWC related manual operation is performed.

2838 INDEX INTERFERENCE CHECK? YES: START, NO: RESET Warning 3 W ARN RESET key
Description : On the UPH-2/UH-2 with the index head, this message is displayed by setting the set data
No. 136 bit 6 to ON to prevent interference between machine and work holder during index
head zero return at the power failure recovery operation, or during movement to the wire
threading position at the wire break recovery operation, or during AWC operation.
2840 LIFT UP THE WORK TANK Warning 3 W ARN RESET key
Description : On the UPH-2/UH-2 with the chuck fixed type spinning head, the work tank is in down
position when the cooling function is turned on.
Remedy : Move up the work tank, and then turn on the cooling function for the spinning head.
2901 PORTABLE (FPB) NOT CONNECTED Warning 3 W ARN RESET key
2902 PORTABLE (FPB) OUTPUT ERROR (1) Warning 3 W ARN RESET key
2903 PORTABLE (FPB) OUTPUT ERROR (2) Warning 3 W ARN RESET key
2904 PORTABLE (FPB) INPUT ERROR (1) Warning 3 W ARN RESET key
2905 PORTABLE (FPB) INPUT ERROR (2) Warning 3 W ARN RESET key
Cause : Loose cable connection between VOH card and FPB (portable operation panel), faulty VOH
card or FPB, or faulty connection cable.
Remedy : After checking the connection cable, turn on the power switch again.
If this error occurs frequently, contact to us of the trouble condition.
104
2990 CUSTOM MACRO MESSAGE 0
Description : There are fixed message registered in system software that are available to users.
Cause : The following command was specified in the custom macro program.
Example: # variable No. (3000–3002) = Message No. (2990–2999)
#3002 = 2990; . . . . .Message No. 2990 is displayed in yellow, and operation is
not stopped. (Warning level 1)
#3001 = 2991; . . . . .Message No. 2991 is displayed in yellow, and operation is
stopped. (Warning level 3)
#3000 = 2992; . . . . .Message No. 2992 is displayed in red, and operation is
stopped. (Alarm level 2)
Remedy : Check the custom macro program.

3000 BREAK (CB2 – CB5) TRIPPED Alarm 2 RESET key
Description : Either of CB2, CB3, CB4 or CB5 circuit breaker was turned OFF. (*MAL1=0)
Cause : Overcurrent in either of the following.
Cause Set current
CB2 200V line overcurrent of fan, etc. 5A
CB3 100V AC overcurrent 6A
CB4 24V power supply overcurrent 10A
CB5 Halogen lamp overcurrent 5A
Remedy : Remove the cause of trip and put the notch to reset.
If reset is impossible, contact to us.
3001 THERMAL (K3 – K6) TRIPPED Alarm 2 RESET key
Cause : Either of K3, K4, K5, or K6 thermal switch was turned off. (*MAL2=0)
Overcurrent flowed into either of the following components.
Cause Set current
K3 Filter pump motor overcurrent 4A
K4 Flush pump overcurrent, faulty inverter 10A
K5 Ion exchange pump motor overcurrent 1A
K6 Machining power related fault 10A
Remedy : Remove the cause of trip and press the button to reset.
106
3007 SEARCH POWER, OVER VOLTAGE LIMIT Alarm 2 RESET key
Description : Faulty AVR in the search power causes overvoltage. (FVAL11=1)
Cause : Defective CVC card
3008 SEARCH POWER OVERHEAT Alarm 2 RESET key
Description : The temperature of cooling fan for search power supply exceeds 85°C. (*FOH11=1)
Cause : Defective CVC card
3009 BOOSTER BREAKER OFF Alarm 2 RESET key
Description : Additional CVC unit for the machining power booster is faulty. (*FOH12=0)
3010 MAIN POWER, OVER VOLTAGE LIMIT Alarm 2 RESET key
Description : Overvoltage was caused due to fault of the main AVR in the main power. (FVAL21=1)
Causes : (1) Defective CVC card

(2) Faulty FET (TR1)

3011 MAIN POWER OVERHEAT OR CB20 TRIP Alarm 2 RESET key
Description : The temperature of cooling fan for main power supply exceeds 85°C. Or, CB20 is turned
off. (*TRAL11=0)
Causes : (1) Insufficient cooling

Faulty cooling fan (it is installed under the CPA2 unit).
(2) Defective CVC card
(3) Overcurrent flowed into CB20 (input of CVC unit) (8A or 10A).
(a) Faulty FET (TR1)
(b) Faulty rush current preventive circuit (CIO3 card, CVC unit)
3012 EXTERNAL MAIN POWER OVERHEAT OR CB20 TRIP Alarm 2 RESET key
Description : Additional CVC unit for machining power booster is faulty. (*TRAL12=0)
3013 BACK POWER, OVER VOLTAGE LIMIT Alarm 2 RESET key
3014 BACK POWER, UNDER VOLTAGE LIMIT Alarm 2 RESET key
Description : Faulty AVR for back power allows input voltage to exceed the specified range. (FVAL31,
FVAL41)
Causes : (1) Faulty CVC card.

(2) Faulty FET (TR2).
108
3015 BACK POWER CHARGE TIME UP Alarm 2 RESET key
Description : The charge end signal cannot be detected due to faulty back power.
Causes : (1) The voltage of C1 in CVC unit does not rise.

(a) Faulty rectifier (SB1).
(b) SW1 on the CIO3 card is turned off.
(2) The voltage of C4 in CVC unit does not rise.
(a) Faulty FET (TR2).
(b) Defective CVC card.
(c) Defective CPA2 unit.
3017 PEAK CURRENT OVER Alarm 2 RESET key
Description : Current flow between poles exceeded the specified value. (IP-AL=1)
Causes : (1) Defective CPG card.

(2) Defective CPA unit and CPA card.
3018 CPA UNIT OVERHEAT Alarm 2 RESET key
Description : Temperature of the cooling fan in the CPA unit exceeded 85 °C. (*CAP-AL=0)
Causes : (1) Insufficient cooling.

(a) Faulty cooling fan
(b) Clogged filter
(2) Faulty FET drive circuit.

3021 CRYSTAL UNIT OVERHEAT Alarm 2 RESET key
Cause : Temperature of the cooling fan in the external finish unit (CMF unit) exceeded 85°C.
3022 CWT UNIT OVERHEAT Alarm 2 RESET key
Cause : The thermal switch on the CWT unit (for EC-3141 tank filling pump) tripped.
Remedy : Remove the cause of trip and press the button to reset.
3030 SEARCH POWER FUSE TRIP Alarm 2 RESET key
Description : A fuse for search power input is blown out. (*FOL11=0)
Causes : (1) Defective CVC card.

(2) The rush current preventive circuit is faulty (CIO3 card, CVC unit).
3031 EXTERNAL CPA UNIT OVERHEAT Alarm 2 RESET key
Description : Additional CVC unit for the machining current booster is faulty. (*FOH12=0)
110
3033 MAIN POWER CURRENT OVER Warning 3 W ARN RESET key
Description : The output current of main power exceeds the specified range. (MV-OVR1=1)
Causes : (1) Defective CVC card/unit.

(2) Machining condition is improper.
3034 EXTERNAL MAIN POWER CURRENT OVER Warning 3 W ARN RESET key
Description : Additional CVC unit for the machining current booster is faulty. (MV-OVR2=1)
3036 EXTERNAL SEARCH POWER, OVER VOLTAGE LIMIT Alarm 2 RESET key
Description : Additional CVC unit for the machining current booster is faulty. (FVAL12=1)
3037 EXTERNAL MAIN POWER, OVER VOLTAGE LIMIT Alarm 2 RESET key
Description : Additional CVC unit for the machining current booster is faulty. (FVAL22=1)

3040 EXTERNAL BACK POWER, OVER VOLTAGE LIMIT Alarm 2 RESET key
3041 EXTERNAL BACK POWER, UNDER VOLTAGE LIMIT Alarm 2 RESET key
3042 EXTERNAL BACK POWER, CHARGE TIME UP Alarm 2 RESET key
Description : Additional CVC unit for the machining current booster is faulty. (FVAL32, FVAL42)
3045 PULSE CONTROL ABNORMAL Warning 3 W ARN RESET key
Description : Average gap voltage is extremely high. (GAP-AL=1 with CPG3A card)
Causes : (1) Defective CPA2 unit.

(2) Defective CVC card/unit.
(3) Defective CPGA3 card.
3050 LL POWER OVERVOLTAGE Alarm 2 RESET key
3051 LL POWER OVERHEAT Alarm 2 RESET key
3052 LL POWER OVERLOAD Alarm 2 RESET key
Cause : The LL unit for LL power supply is in alarm status.

(LL-OV=1, *LL-OH=0, *LL-OL=0 respectively)
112
3060 LL POWER SETTING ERROR (0) Warning 1 W ARN RESET key
Description : The voltage of LL power supply (mode 7, 8) exceeds the allowance (machine parameter
No. 7860–7863) for duration of time (machine parameter No. 7864 and 7865).
Cause : In the machining conditions of LL power supply (mode 7, 8), a combination of respective
elements is improper.
Remedy : (1) In the case of user machining conditions, change the machining condition.
(2) In the case of conditions registered to ROM, contact to us of the trouble condition.
3070 CPT UNIT ALARM Alarm 2 RESET key
Cause : The CPT unit is broken. (*CPT-AL=0)
3071 CPF UNIT OVERHEAT Alarm 2 RESET key
Cause : The CPF unit is overheated. (*CPF-OH=0)

3101 CVR UNIT 1 ALARM 1 Alarm 2 RESET key
Description : MV output voltage of CVR unit dropped extremely. (After MGW-K, *CVR-AL1=0)
Cause : Overload or faulty CVR unit. (Detection is enabled when system parameter 938 bit 0 is
turned on)
3102 CVR UNIT 1 OVERHEAT Alarm 2 RESET key
Description : The CVR unit overheated. (After MGW-K, *CVR-OH1=0)
Cause : Cooling fan for CVR unit stopped, or CVR unit is faulty. (Detection is enabled when system
parameter 938 bit 1 is turned on)
3103 CVR UNIT 1 ALARM 2 Alarm 2 RESET key
Description : Either of 3 phases of power supply to CVR unit is open. (After MGW-K, *CVR-FS1=0)
Cause : Faulty power supply control circuit or CVR unit.

(Detection is enabled when system parameter 938 bit 2 is turned on)
114
3104 CVR UNIT S OVERLOAD Alarm 2 RESET key
Description : SV output voltage of CVR unit dropped extremely. (After MGW-K, *CVR-ALS=0)
Cause : Overload for SV output or faulty CVR unit.

3105 CVR UNIT R OVERLOAD Alarm 2 RESET key
Description : RV output voltage of CVR unit dropped extremely. (After MGW-K, *CVR-ALR=0)
Cause : Overload for RV output or faulty CVR unit.

3106 RESERVE 1 Alarm 2 RESET key
3107 RESERVE 2 Alarm 2 RESET key
Description : Not used. (After MGW-K, *OP-AL1=0, *OP-AL2=0)
3108 CBD UNIT OVERHEAT Warning 3 W ARN RESET key
Description : The CBD unit overheated. (After MGW-K, *CBD-OH=0)
Cause : Cooling water stopped, or faulty CBD unit.


3109 CVS UNIT S OVER VOLTAGE AND OVER CURRENT Alarm 2 RESET key
Description : SV output voltage or current of CVS unit rose extremely. (After MGW-K, *CVS-ALS=0)
Cause : Overload for SV output or faulty CVS unit.

3110 CVS UNIT R OVER VOLTAGE AND OVER CURRENT Alarm 2 RESET key
Description : RV output voltage or current of CVS unit rose extremely. (After MGW-K, *CVS-ALR=0)
Cause : Overload for RV output or faulty CVS unit.

3111 CVS UNIT OVERHEAT Alarm 2 RESET key
Description : The CVS unit overheated. (After MGW-K, *CVS-OH=0)
Cause : Cooling fan for CVS unit stopped, or CVS unit is faulty.
(Detection is enabled when system parameter 938 bit A is turned on)
3112 CPA UNIT 1 ALARM Alarm 2 RESET key
Description : The CPA unit U is faulty. (After MGW-K, *CPA-AL1=0)

(Detection is enabled when system parameter 938 bit B is turned on)
116
3113 CPA UNIT 1 OVERHEAT Alarm 2 RESET key
Description : The CPA unit U overheated. (After MGW-K, *CPA-OH1=0)
Cause : Cooling fan for CPA unit stopped, or CPA unit U isfaulty.
(Detection is enabled when system parameter 938 bit C is turned on)
3114 CPA UNIT 2 ALARM Alarm 2 RESET key
Description : The CPA unit L is faulty. (After MGW-K, *CPA-AL2=0)

(Detection is enabled when system parameter 938 bit D is turned on)
3115 CPA UNIT 2 OVERHEAT Alarm 2 RESET key
Description : The CPA unit L overheated. (After MGW-K, *CPA-OH2=0)
Cause : Cooling fan for CPA unit stopped, or CPA unit L is faulty.
(Detection is enabled when system parameter 938 bit E is turned on)
3116 FPGA WRITE ERROR Alarm 2 RESET key
Description : The CPG card is faulty. (After MGW-K, *FPGA-AL=0)

(Detection is enabled when system parameter 938 bit F is turned on)

3117 CVR UNIT 2 BOOSTER ALARM 1 Alarm 2 RESET key
3118 CVR UNIT 2 BOOSTER OVERHEAT Alarm 2 RESET key
3119 CVR UNIT 2 BOOSTER ALARM 2 Alarm 2 RESET key
3120 CPA UNIT 3 BOOSTER ALARM Alarm 2 RESET key
3121 CPA UNIT 3 BOOSTER OVERHEAT Alarm 2 RESET key
3122 CPA UNIT 4 BOOSTER ALARM Alarm 2 RESET key
3123 CPA UNIT 4 BOOSTER OVERHEAT Alarm 2 RESET key
3124 BOOSTER BREAKER TRIPPED Alarm 2 RESET key
Description : Not used. (After MGW-K, Detection is enabled when system parameter 939 bit 0-7 are
turned on)
4001 +X OVERTRAVEL Alarm 2 RESET key
4002 +Y OVERTRAVEL Alarm 2 RESET key
4003 +U OVERTRAVEL Alarm 2 RESET key
4004 +V OVERTRAVEL Alarm 2 RESET key
4005 +Z OVERTRAVEL Alarm 2 RESET key
4006 +C OVERTRAVEL Alarm 2 RESET key
Cause : The axis with an alarm exceeded the + stroke range.
Remedy : Return the axis in trouble in – direction with the associated axis key on the RUN MANUAL
screen.
118
4007 –X OVERTRAVEL Alarm 2 RESET key
4008 –Y OVERTRAVEL Alarm 2 RESET key
4009 –U OVERTRAVEL Alarm 2 RESET key
4010 –V OVERTRAVEL Alarm 2 RESET key
4011 –Z OVERTRAVEL Alarm 2 RESET key
4012 –C OVERTRAVEL Alarm 2 RESET key
Cause : The axis with an alarm exceeded the – stroke range.
Remedy : Return the axis in trouble in + direction with the associated axis key on the RUN MANUAL
screen.
4013 +X SOFT OVERTRAVEL Warning 3 W ARN RESET key
4014 +Y SOFT OVERTRAVEL Warning 3 W ARN RESET key
4015 +U SOFT OVERTRAVEL Warning 3 W ARN RESET key
4016 +V SOFT OVERTRAVEL Warning 3 W ARN RESET key
4017 +Z SOFT OVERTRAVEL Warning 3 W ARN RESET key
4018 +C SOFT OVERTRAVEL Warning 3 W ARN RESET key
Cause : The axis displayed exceeds the + soft stroke range.
Remedy : Return the axis in trouble in – direction with the associated axis key on the RUN MANUAL
screen.
Restart is possible, if operation can continue by turning off the associated LIMIT key on the
MACH OPE screen.

4019 –X SOFT OVERTRAVEL Warning 3 W ARN RESET key
4020 –Y SOFT OVERTRAVEL Warning 3 W ARN RESET key
4021 –U SOFT OVERTRAVEL Warning 3 W ARN RESET key
4022 –V SOFT OVERTRAVEL Warning 3 W ARN RESET key
4023 –Z SOFT OVERTRAVEL Warning 3 W ARN RESET key
4024 –C SOFT OVERTRAVEL Warning 3 W ARN RESET key
Cause : The axis displayed exceeds the – soft stroke range.
Remedy : Return the axis in trouble in + direction with the associated axis key on the RUN MANUAL
screen.
Restart is possible, if operation can continue by turning off the associated LIMIT key on the
MACH OPE screen.
4025 PREVENTIVE CENTERING PLATE PROTECT --- ---
Cause : The workpiece collided with the centering plate. (Not used)
4026 REVENTIVE HEAD PROTECT Warning 3 W ARN RESET key
Description : On the UPH-1/UPH-2/UH-2/W-PG1, the head protection signal was detected.

(UPH-1/W-PG1:WT_SEN2=1) (UPH-2/UH-2:*PRT=0)
Causes : (1) The wire runs out of either upper or lower wire guide. (W-PB1)
(2) The wire touches the sensor on left or right head. (UPH-1/UPH-2/UH-2)
(3) On the 16-work AWC unit, the AWC work holder touched the outside of gripper.
(UPH-2/UH-2)
Remedy : Press the WARN RESET key, then return the axis, if moved manually, to the original
position.
(For the W-PG1, perform this remedy, then execute wire threading manually.)
120
4027 HEAD PROTECT DETECTED Warning 3 W ARN RESET key
Description : On the machine with MGW-J or MGW-K, the head protection signal was detected.
(*PRT=0)
Cause : Sensors (antenna) attached on the upper and lower heads touched the workpiece.
Remedy : Correct the program or remove a cause of trouble (presence of chips, etc.), then restart
operation.
Return the axis in the case of manual mode.
4028 AUTO RUN INTERRUPTED BY OVERTRAVEL Alarm 2 RESET key
Cause : Stroke limit was exceeded by axis movement during automatic operation.
Remedy : Correct the program or shift the workpiece position.
4029 IMPOSSIBLE TO CHANGE SOFT STROKE LIMIT Warning 3 W ARN RESET key
Causes : (1) The soft stroke limit cannot be changed to prevent over-travel which could be caused
by turning off (or on) the EXPAND STROKE key.
(2) The LIMIT key for either axis was turned on/off with either axis in over-travel position.
(All models)
(3) Setting of machine parameters No. *046~*051 is improper.
Remedy : (1) Move manually the machine coordinates within the standard stroke, then turn off (or on)
the EXPAND STROKE key.
(2) Move manually all axes to the position free from over-travel, then turn on/off the LIMIT
key.
(3) Check and correct parameter setting.

4030 –Z AUTO RUN INTERRUPTED BY OVERTRAVEL Warning 3 W ARN RESET key
4031 Z AXIS LOCK OR C AXIS LOCK ON Warning 3 W ARN RESET key
Description : The power failed or a wire broken while the Z AXIS LOCK or C AXIS LOCK on the NC
FUNC screen is turned on.
Remedy : To continue power failure recovery or wire break recovery, turn off Z AXIS LOCK or
C AXIS LOCK , then press the START key.
4036 UPPER PUMP INVERTER ABNORMAL Alarm 2 PO W ER O FF/O N
Description : On the machine with MGW-J or MGW-K, the inverter for upper head flushing pump is in
alarm status. (INV-AL-U=1)
Causes : (1) Upper head flushing pump is defective.

(2) Inverter unit for upper head is defective.
The above failures are attributable to either of the following causes (common causes to
inverter):
(A) Inverter overheat
Inverter is overheated by overload.
(B) Overcurrent
Overcurrent in motor during acceleration or deceleration or during operation is
detected.
(C) Overvoltage
Regenerative voltage or deceleration time failure is detected during deceleration.
(D) Low voltage
Power source voltage is low.
(E) Output terminals are shorted.

Defective pump or inverter unit must be replaced.
122
4037 PUMP INVERTER ABNORMAL
4038 EXCESS WATER PRESSURE
4039 EXCESS A.W.T. JET PRESSURE Warning 3 W ARN RESET key
Description : On the machine with MGW-J or MGW-K, the jet water pressure for automatic wire threading
exceeds the setting of machine parameter No. 738.
Causes : (1) The filter for jet water is clogged.

(2) Defective water valve.
(3) Defective piping.
Remedy : (1) Turn on the PUMP OFF key on the MACH OPE screen, and replace the jet water
filter. After replacement, turn off the PUMP OFF key. The PUMP OFF key must
always be turned on/off.
(2) Check the water valve and piping in cause (2) and (3).
4040 AIR PRESSURE LOW Warning 3 W ARN RESET key
Description : The air pressure lowered. (MGW-J/MGW-K/MV-30: *AIR-SL=0, MGW-JP/MV-20:

*AIR-PS=0)
Cause : The compressor or piping is faulty.
Remedy : Check the compressor. Check the piping.

4041 LOWER PUMP INVERTER ABNORMAL Alarm 2 RESET OFF/ON
Description : On the machine with MGW-J or MGW-K, the inverter for lower head flushing pump is in
alarm status. (INV-AL-L=1)
Causes : (1) Lower head flushing pump is defective.

(2) Lower head inverter unit is defective.
For detailed cause, see Alarm No. 4036.

4042 COOLER OVERHEAT Warning 1 W ARN RESET key
Cause : The water cooler is in alarm status (*COL-AL=0)

The compressor, fan and deionizing pump of cooler unit are turned off, but machining is
continued (standard setting of set data No. 57 bit 2).
Remedy : If this alarm persists several hours after machining was finished, contact to us of the trouble
condition.
4043 EXCESS WATER PRESSURE Warning 3 W ARN RESET key
Description : The water pressure exceeds the setting of machine parameter No. 737.
Causes : (1) Defective water valve.

(2) Defective inverter unit.
(3) Defective CIO card.
124
4044 FILL INVERTER ALARM Alarm 2 RESET key
Description : The inverter for tank filling pump is in alarm status. (*P-ALM=0)
Causes : (1) Tank filling pump is defective.

(2) Inverter unit for tank filling pump is defective.

4045 UPPER HI PRESS. INVERTER PUMP ABNORMAL Alarm 2 PO W ER O FF/O N
Description : On the machine with high pressure pump, the inverter for upper head high pressure pump
is in alarm status. (INV-AL-U2=1)
Causes : (1) Upper head high pressure pump is defective.

(2) Inverter unit for upper head high pressure pump is defective.
For detailed cause, see alarm No. 4036.

4046 LOWER HI PRESS. INVERTER PUMP ABNORMAL Alarm 2 PO W ER O FF/O N
Description : On the machine with high pressure pump, the inverter for lower head high pressure pump
is in alarm status. (INV-AL-L2=1)
Causes : (1) Lower head high pressure pump is defective.

(2) Inverter unit for lower head high pressure pump is defective.
For detailed cause, see alarm No. 4036.


4047 HI PRESS. INVERTER PUMP THREMAL TRIP Alarm 2 RESET key
Description : On the machine with high pressure pump, the thermal relay for high pressure pump inverter
is turned off. (*INV-OL=0)
Cause : Pump is overloaded, one phase is disconnected or thermal setting is faulty.

Remove a cause including pump replacement, then reset the thermal relay or circuit
breaker.
4048 HI PRESS. PUMP EXCESS PRESSURE Warning 3 W ARN RESET key
Description : On the machine with high pressure pump, the flushing pressure in water mode 6 exceeds
the value set to machine parameter No. 7650.
Causes : (1) Pump switching valve is defective. (P-CHG, air supply, etc.)
(2) High pressure inverter unit is defective.
(3) CIO card is defective.
4049 OPEN GUIDE DETECTED Warning 3 W ARN RESET key
Cause : On the machine other than W-PG1, automatic operation was taken place with the guide
opened or not closed completely. This alarm will occur if M7 or M6 is reset during operation.
The guide must be closed again through a correct sequence.
Remedy : Close the guide and restart operation when the guide lamp is lighting. If the guide lamp is
off, open the guide once, then close it and restart operation.
4050 OPEN COVER DETECTED Warning 3 W ARN RESET key
126
4051 WIR-ST MOTOR OVERLOAD Warning 3 W ARN RESET key
Description : The current in wire winding motor exceeds the rated current.
The input signal name is different depending on the model.
(1) Machine with MGW-J, MGW-K or MV-30: MOL=1
(2) UPH-1 : MOL-C=1
(3) W-PG1 : MOL-P=1
Causes : (1) Gear box is defective.

(2) Wire winding motor is defective.
(3) Wire gets twisted round the winding part (L/M axis).
Remedy : Remove wire if twisted round the winding part (L/M axis), press the WASRN RESET key,
then restart.
If this failure recurs or wire is not twisted, contact to us of the trouble condition.
4054 EXCESSIVE ENERGIZER WEAR Warning 3 W ARN RESET key
Description : The section of energizing plate touching the top of upper head or bottom of lower head to
supply power to wire was worn and deeply scarred or the plate was stained, resulting in
poor transmission of electric power to wire.
Cause : The energizing plate is dirty or worn out.
Remedy : Clean the energizing plate, and use unworn face, or replace it.

4056 AIR DRYER ALARM Warning 1 W ARN RESET key
Description : The air dryer is in alarm status (DR-AL=1).
Causes : (1) When power fails,

(a) No power is supplied to the air dryer.
(b) The circuit protector operated.
(2) When condeser temperature exceeds 55°C,
(a) The condenser is dirty.
(b) Ambient temperature is high.
(c) Inlet air temperature is high.
(d) The air flow rate is large.
(e) Inlet air pressure is low.
(f) Flon gas leaks (RDH_302 type water unit)
Remedy : Check the above possible causes. Contact to us.

Note: This warning level can be changed to warning 3 (operation is stopped) by the
set data No. 57 bit 2.
4060 EXT. CONTROLLER ALARM 2 Alarm 2 RESET key
4061 EXT. CONTROLLER ALARM 1 Alarm 2 RESET key
Description : Not used (initial hole machining).
4065 EMF FILTER ABNORMAL Warning 3 W ARN RESET key
Description : Not used. (*EMF-AL=0)
128
4066 OPEN WORK TANK COVER DETECTED Warning 3 W ARN RESET key
Description : On the UPH-1 or W-PG1, the work tank cover is opened during machining (SFG-LS=0), and
the operation is stopped to ensure safety.
Causes : (1) The work tank cover is open.

(2) The work tank cover open limit switch is faulty.
Remedy : (1) Close the work tank cover, and restart operation.
(2) Check the safeguard LS (SFG-LS=1 must be attained when the work tank cover is
closed).
4067 FLUIID TEMPERATURE ALARM Alarm 2 RESET key
Cause : On the UPH-1/UPH-2/UH-2, the dielectric fluid temperature rose extremely. (F-TMP=1)
4068 CIRCULATION PUMP INVERTER ALARM Alarm 2 RESET key
Description : On the UPH-1/UPH-2/UH-2, the circulation pump inverter is in alarm status.

(UPH-1:INV-AL-B=1,UPH-2/UH-2:INV-AL-BL/BR=1)
Causes : (1) Circulation pump is faulty.

(2) Circulation pump unit is faulty.

4069 VACUUM UNIT INVERTER ALARM Alarm 2 RESET key
Description : On the UPH-1/UPH-2/UH-2, the inverter for vacuum unit (UPH-1) or the inverter for wire
vacuuming pump (hereinafter referred to as vacuum unit) becomes alarm state. (INV-AL-
V=1)
Causes : (1) The vacuum unit is faulty.

(2) The vacuum unit is faulty.
4070 FILTER PUMP INVERTER ABNORMAL Alarm 2 PO W ER O FF/O N
Description : Not used. (INV-F-AL=1)
4071 PUMP OVERLOAD (P-MAL) Alarm 2 RESET key
Description : Not used. (*P-MAL=0)
4072 BREAKER (CB9) TRIPPED Alarm 2 RESET key
Description : Not used. (*CB9-ALM=0)
4075 BACK TENSION MOTOR OVERLOAD (BT-OL) Alarm 2 RESET key
Description : Not used. (BT-OL=1)
130
4076 POWDER CLUTCH NEEDS REPLACING (TN-ALM) Warning 2 W ARN RESET key
Description : Not used. (*TN-ALM=0)
4077 NO WIRE AT WIRE BOBBIN Warning 3 W ARN RESET key
Description : (1) MGW-J/MGW-K

The specified time (machine parameter No.700) elapsed after the wire was fed in the
automatic wire threading operation, and no wire remains at the wire bobbin detection
sensor (LS76).
(2) UPH-1/UPH-2/UH-2
When the specified time (machine parameter No.700) elapsed after the wire was fed,
or when a checking was made during automatic wire threading, no wire remains on the
C-roller (UPH-1:W- CONFIRM-LS=0, UPH-2/UH-2:W-CONF-LS=0), and also the
F-shaft lowers (UPH-1:WDN-C=0, UPH- 2/UH-2:WDN=0).
Causes : (1) The wire in wire bobbin has been used up.
(2) The wire threading method is not correct.
(3) The wire detection limit switch is faulty.
Remedy : Replace the wire bobbin, or route the wire correctly and restart.
4078 FINE A.W.T. UNIT ALARM (VSH-ALM) Warning 2 W ARN RESET key
Description : On the MU43 or MUQ32, in a fine hole automatic wire threading, the unit goes in alarm
status, and AWT at fine hole is not executed but normal AWT sequence is executed.
(*VSH-ALWM=0)
Cause : Fine hole AWT unit is defective.

4081 Z STROKE RESTRICTING! Warning 1 W ARN RESET key
4082 Z STROKE EXPANDING! Warning 1 W ARN RESET key
Description : On the machine having Z-axis stroke restriction in use of fine wire AWT(Note), the current
Z-axis stroke condition is displayed when RESET or MAIN RUN key is pressed.
Note : These messages are for the machine with automatic Z-axis and fine wire AWT
function (EC32, EC64, ECQ53).
4083 Z STROKE RESTRICTING IMPOSSIBLE! Warning 3 W ARN RESET key
4084 Z STROKE EXPANDING IMPOSSIBLE! Warning 3 W ARN RESET key
Description : On the machine having Z-axis stroke restriction in use of fine wire AWT(Note), selection of
"use/store" of fine wire AWT unit failed due to either cause listed below.
Causes : (1) Emergency stop, alarm, start, or stop status

(2) Z-axis machine coord.> machine parameter No. 0681 (Z stroke in use of fine wire AWT)
(3) X-axis machine coord.> machine parameter No. 1050 (X stroke 3 (+))
(4) X-axis machine coord.> machine parameter No. 1051 (X stroke 3 (–))
(5) Y-axis machine coord.> machine parameter No. 2050 (Y stroke 3 (+))
(6) Y-axis machine coord.> machine parameter No. 2051 (Y stroke 3 (–))
(7) MACH OPE screen EXPAND STROKE key ON/OFF failed or setting disabled status
is present.
Remedy : Press the RESET key to clear warning or alarm message, and retry "use/store" of thin
wire AWT unit.
Note : These messages are for the machine with automatic Z-axis and fine wire AWT
function (EC32, EC64, ECQ53).
132
4085 Z STROKE RESTRICTED! Warning 3 W ARN RESET key
4086 Z STROKE EXPANDED! Warning 3 W ARN RESET key
Description : On the machine having Z-axis stroke restriction in use of thin wire AWT(Note), "use/store"
(Z-EXSL=0/1) of fine wire AWT unit has successfully been executed and "restriction/
expansion" of Z-axis stroke has completed.
Note : (EC32, EC64, ECQ53) and machines with automatic Z axis and fine hole automatic
wire threading function.
4087 Z AX IS LO W ER S D UR ING R EFE RE NC E PO S ITIO N R ETU RN Warning 3 W ARN RESET key
Description : On the machine with automatic Z-axis, when the Z-axis reference point return is executed
(by MACHINE HOME key, G28 or power failure recovery), current Z-axis machine
coordinate is higher than reference point coord. (machine parameter No. 5067) and the Z-
axis lowers at the time of restasrt.
Cause : If there is possibility of interference between head and workpiece when the Z-axis lowers
to the reference point, the operation is stopped by warning to prevent head damage.
Remedy : Check correlation between head and workpiece, and select either (1) or (2).
(1) In case of no interference, press the START key to execute Z-axis reference point
return. Note that the Z-axis lowers.
(2) In case of interference, press the RESET key.
Remove the workpiece, then execute Z-axis reference point return.

4090 SAFETY GUARD OPEN Warning 3 W ARN RESET key
Description : On the machine with MGW-J, MGW-K or MV-30, this message indicates that the safeguard
is open. (*CVRL=0)
(1) If the safeguard in closed status is opened
→ By this warning message, the operation stops (warning 3) and also the machining
power is turned off.
(2) If an operation that is invalid during open safeguard was attempted when the safeguard
is open
→ This warning is displayed (warning 1), and that operation is not executed.
Invalid operation during open safeguard
1) START key
2) RETRACT key
3) All f • 1 – f • 8 keys on 2nd and 3rd sets of function keys on RUN MANUAL screen
4) TOUCH CHECK key and MACHING POWER key on MACH OPE screen
Cause : Safety measures (inhibited machining power ON, inhibited starting of automatic operation)
Remedy : (1) When the safeguard is open, execute only the necessary operation except the above
1) to 4), while taking care of the following consideration.
• In the MAN RUN mode, the axis moves during the time that the jog keys such as ±X
and ±Y keys on portable operation panel are pressed. In such a case, take care not
to have your body, cloth, or a tool pinched. Release the key when you feel danger.
• The water is injected when the WATER, JET, OR TANK FILL key is turned on. Make
sure that the splashguard is closed, then turn on the key while taking care not to allow
the water to enter your eyes.
• Respective shafts and rollers in the wire feed system rotate when the WIRE FEED
key or UNSPOOL WIRE key is turned on. Keep yourself off these parts, then turn on
the key.
(2) Close the safeguard.
(3) After closing the safeguard, execute only the necessary operation such as the one
which is invalid during open safeguard.
134
4092 RUN MODE LOCKING! Warning 1 W ARN RESET key
Description : On the machines with the MGW-J or subsequent power supply units, this message
indicates that the run mode has been locked by the machine operator.
Under this condition, no operation mode can be changed in all statuses of start, stop, and
reset. An attempt to change the operation mode under this condition results in display of
this warning message.
Note: The following operations 1) to 5) on RUN MANUAL screen are all inhibited.
1) Change of MAN RUN/MDI RUN/MEM RUN mode
2) Change of RAPID/JOG/STEP/HANDLE in MAN RUN mode
3) Change of LOW/MED/HIGH in MAN RUN mode
4) Change of x1/x10 for STEP in MAN RUN mode
5) Use of 2nd and 3rd sets of f • 1 – f • 8 function keys in MAN RUN mode
Cause : The operation mode is locked to prevent a danger or failure that could occur due to an
accidental change of operation mode by the third person other than the operator that locked
the operation mode.
Remedy : (1) Do not reset the mode lock by the third person without permission from the operator that
locked the operation mode.
(2) When resetting the mode lock by the operator that locked the operation mode, make
sure that the third person is not in the machine moving range.
1) To lock the operation mode
Set the set data No. 0368 on SET DATA screen to "1".
2) To reset the locked operation mode
Set the set data No. 0368 on SET DATA screen to "0".

4101 X ZRN DOG POSITION INCORRECT Alarm 2 RESET key
4102 Y ZRN DOG POSITION INCORRECT Alarm 2 RESET key
4103 U ZRN DOG POSITION INCORRECT Alarm 2 RESET key
4104 V ZRN DOG POSITION INCORRECT Alarm 2 RESET key
4105 Z ZRN DOG POSITION INCORRECT Alarm 2 RESET key
4106 C ZRN DOG POSITION INCORRECT Alarm 2 RESET key
Description : During reference point return operation (power failure recovery, one-touch reference point
return, G28), the axis concerned is at the ZRN dog position (machine parameter *068) but
the dog signal of the axis concerned is not turned on and therefore the subsequent
sequence cannot be continued.
Causes : (1) ZRN dog signal (*DECX∼DECC) is faulty.

(2) ZRN dog position (machine parameter *068) is incorrect.
Remedy : Observing the dog signal (*DECX∼DECC) of the axis concerned on the DIAGNOSE EIO
screen, move the axis forward or reverse in manual mode to check if the signal changes
between 0 and 1.
(1) If the signal does not change between 0 and 1, check wiring or replace the ZRN dog
limit switch.
(2) If the signal changes between 0 and 1, confirm the set value of ZRN dog position
(machine parameter *068) and adjust the axis as follows.
Observing the dog signal (*DECX∼*DECC) of the axis concerned, move the axis
forward or reverse at low speed in manual mode, then set almost center machine
coordinates of 0 point (plus side and minus side) to the machine parameter *068.
4201 POWDER CLUTCH NEEDS REPLACING (TN-ALM) Warning 2 W ARN RESET key
Description : On the machines with the MGW-K or subsequent power supply units and the powder clutch,
the specified torque cannot be generated with the powder clutch rated current.
Wire tension is dropped (*TN-ALM=0)
Cause : Power clutch reached its life.
Remedy : Please contact us. It will have to be replaced.
136
5001 X UNDEFINED ALARM Alarm 3 RESET key
5002 Y UNDEFINED ALARM Alarm 3 RESET key
5003 U UNDEFINED ALARM Alarm 3 RESET key
5004 V UNDEFINED ALARM Alarm 3 RESET key
5005 Z UNDEFINED ALARM Alarm 3 RESET key
5006 C UNDEFINED ALARM Alarm 3 RESET key
Description : Unregistered ASC alarm occurred.
Causes : (1) Defective VMC card.

(2) Defective ASU unit.

(1) Replace the VMC card.
(2) Replace the ASU unit.
5011 X P FEEDBACK PULSE ERROR Alarm 3 RESET key
5012 Y P FEEDBACK PULSE ERROR Alarm 3 RESET key
5013 U P FEEDBACK PULSE ERROR Alarm 3 RESET key
5014 V P FEEDBACK PULSE ERROR Alarm 3 RESET key
5015 Z P FEEDBACK PULSE ERROR Alarm 3 RESET key
5016 C P FEEDBACK PULSE ERROR Alarm 3 RESET key
Description : The position feedback signal is faulty.
Causes : (1) Defective position sensor.

(2) Defective position feedback cable.

(1) Replace the position sensor.
(2) Replace the position feedback cable.

5021 X ENCODER PULSE ERROR Alarm 3 RESET key
5022 Y ENCODER PULSE ERROR Alarm 3 RESET key
5023 U ENCODER PULSE ERROR Alarm 3 RESET key
5024 V ENCODER PULSE ERROR Alarm 3 RESET key
5025 Z ENCODER PULSE ERROR Alarm 3 RESET key
5026 C ENCODER PULSE ERROR Alarm 3 RESET key
Description : The encorder signal (PA, PB phases) is faulty.
Causes : (1) Defective encorder.

(2) Defective encorder feedback cable.

(1) Replace the motor
(2) Replace the encorder feedback cable.
5031 X COMMUTATION PULSE ERROR Alarm 3 RESET key
5032 Y COMMUTATION PULSE ERROR Alarm 3 RESET key
5033 U COMMUTATION PULSE ERROR Alarm 3 RESET key
5034 V COMMUTATIONPULSE ERROR Alarm 3 RESET key
5035 Z COMMUTATION PULSE ERROR Alarm 3 RESET key
5036 C COMMUTATION PULSE ERROR Alarm 3 RESET key
Description : The commutation siignal (PU, PV, PW phases) is faulty.


(1) Replace the motor
138
5051 X CIRCUIT PROTECTOR OFF Alarm 3 RESET key
5052 Y CIRCUIT PROTECTOR OFF Alarm 3 RESET key
5053 U CIRCUIT PROTECTOR OFF Alarm 3 RESET key
5054 V CIRCUIT PROTECTOR OFF Alarm 3 RESET key
5055 Z CIRCUIT PROTECTOR OFF Alarm 3 RESET key
5056 C CIRCUIT PROTECTOR OFF Alarm 3 RESET key
Description : The driver circuit protector is turned off.
Causes : (1) Overload.

(2) Defective driver motor.

(1) Check the operating condition.
(2) Replace the driver motor.
If this alarm occurred during operation, do not turn the POWER switch on until the cause is
removed.
5061 X TRANSISTOR OVERHEAT Alarm 3 RESET key
5062 Y TRANSISTOR OVERHEAT Alarm 3 RESET key
5063 U TRANSISTOR OVERHEAT Alarm 3 RESET key
5064 V TRANSISTOR OVERHEAT Alarm 3 RESET key
5065 Z TRANSISTOR OVERHEAT Alarm 3 RESET key
5066 C TRANSISTOR OVERHEAT Alarm 3 RESET key
Description : The power device in the driver is overheated.



5071 X REGENERATIVE RESISTOR OVERHEAT Alarm 3 RESET key
5072 Y REGENERATIVE RESISTOR OVERHEAT Alarm 3 RESET key
5073 U REGENERATIVE RESISTOR OVERHEAT Alarm 3 RESET key
5074 V REGENERATIVE RESISTOR OVERHEAT Alarm 3 RESET key
5075 Z REGENERATIVE RESISTOR OVERHEAT Alarm 3 RESET key
5076 C REGENERATIVE RESISTOR OVERHEAT Alarm 3 RESET key
Description : The regenerative resistor is overheated.


5091 X CONVERTER LOW VOLTAGE Alarm 3 RESET key
5092 Y CONVERTER LOW VOLTAGE Alarm 3 RESET key
5093 U CONVERTER LOW VOLTAGE Alarm 3 RESET key
5094 V CONVERTER LOW VOLTAGE Alarm 3 RESET key
5095 Z CONVERTER LOW VOLTAGE Alarm 3 RESET key
5096 C CONVERTER LOW VOLTAGE Alarm 3 RESET key
Description : The converter voltage is too low.
Causes : (1) Main power voltage dropped.

(2) Defective driver.

(1) Check the generator.
(2) Replace the driver.
140
5101 X MOTOR OVERHEAT Alarm 3 RESET key
5102 Y MOTOR OVERHEAT Alarm 3 RESET key
5103 U MOTOR OVERHEAT Alarm 3 RESET key
5104 V MOTOR OVERHEAT Alarm 3 RESET key
5105 Z MOTOR OVERHEAT Alarm 3 RESET key
5106 C MOTOR OVERHEAT Alarm 3 RESET key
Description : The motor is overheated.


5191 X ASC +15V VOLTAGE ALARM Alarm 3 RESET key
5192 Y ASC +15V VOLTAGE ALARM Alarm 3 RESET key
5193 U ASC +15V VOLTAGE ALARM Alarm 3 RESET key
5194 V ASC +15V VOLTAGE ALARM Alarm 3 RESET key
5195 Z ASC +15V VOLTAGE ALARM Alarm 3 RESET key
5196 C ASC +15V VOLTAGE ALARM Alarm 3 RESET key
Description : The +15 V voltage is not out put from the driver controller (ASC).
Cause : Defective driver.

Replace the driver.

5201 X ASC –15V VOLTAGE ALARM Alarm 3 RESET key
5202 Y ASC –15V VOLTAGE ALARM Alarm 3 RESET key
5203 U ASC –15V VOLTAGE ALARM Alarm 3 RESET key
5204 V ASC –15V VOLTAGE ALARM Alarm 3 RESET key
5205 Z ASC –15V VOLTAGE ALARM Alarm 3 RESET key
5206 C ASC –15V VOLTAGE ALARM Alarm 3 RESET key
Description : The –15 V voltage is not out put from the driver controller (ASC).
Cause : Defective driver.

Replace the driver.
5211 X INVERTER CURRENT OVER Alarm 3 RESET key
5212 Y INVERTER CURRENT OVER Alarm 3 RESET key
5213 U INVERTER CURRENT OVER Alarm 3 RESET key
5214 V INVERTER CURRENT OVER Alarm 3 RESET key
5215 Z INVERTER CURRENT OVER Alarm 3 RESET key
5216 C INVERTER CURRENT OVER Alarm 3 RESET key
Description : An overcurrent flows to the inverter.

(3) Parameter setting error.

(3) Reset the parameter.
142
5221 X CONVERTER CURRENT OVER Alarm 3 RESET key
5222 Y CONVERTER CURRENT OVER Alarm 3 RESET key
5223 U CONVERTER CURRENT OVER Alarm 3 RESET key
5224 V CONVERTER CURRENT OVER Alarm 3 RESET key
5225 Z CONVERTER CURRENT OVER Alarm 3 RESET key
5226 C CONVERTER CURRENT OVER Alarm 3 RESET key
Description : An overcurrent flows to the converter.


5241 X CONVERTER VOLTAGE OVER Alarm 3 RESET key
5242 Y CONVERTER VOLTAGE OVER Alarm 3 RESET key
5243 U CONVERTER VOLTAGE OVER Alarm 3 RESET key
5244 V CONVERTER VOLTAGE OVER Alarm 3 RESET key
5245 Z CONVERTER VOLTAGE OVER Alarm 3 RESET key
5246 C CONVERTER VOLTAGE OVER Alarm 3 RESET key
Description : The converter voltage is too high.
Causes : (1) Main power voltage error.

(2) Defective driver.

(1) Check the generator.

5251 X ASC WATCHDOG ALARM Alarm 3 RESET key
5252 Y ASC WATCHDOG ALARM Alarm 3 RESET key
5253 U ASC WATCHDOG ALARM Alarm 3 RESET key
5254 V ASC WATCHDOG ALARM Alarm 3 RESET key
5255 Z ASC WATCHDOG ALARM Alarm 3 RESET key
5256 C ASC WATCHDOG ALARM Alarm 3 RESET key
Description : The processor in the driver controller (ASC) is faulty.
Cause : Defective driver controller.

Replace the driver.
5271 X ASC BUS COMMUNICATION ERROR Alarm 3 RESET key
5272 Y ASC BUS COMMUNICATION ERROR Alarm 3 RESET key
5273 U ASC BUS COMMUNICATION ERROR Alarm 3 RESET key
5274 V ASC BUS COMMUNICATION ERROR Alarm 3 RESET key
5275 Z ASC BUS COMMUNICATION ERROR Alarm 3 RESET key
5276 C ASC BUS COMMUNICATION ERROR Alarm 3 RESET key
Description : The bus communication unit in the driver controller (ASC) is faulty.
Causes : (1) Defective driver controller.

(2) Defective ASU bus cable.

(2) Replace the ASU bus cable.
144
5291 X ASC A/D ERROR (CH.1) Alarm 3 RESET key
5292 Y ASC A/D ERROR (CH.1) Alarm 3 RESET key
5293 U ASC A/D ERROR (CH.1) Alarm 3 RESET key
5294 V ASC A/D ERROR (CH.1) Alarm 3 RESET key
5295 Z ASC A/D ERROR (CH.1) Alarm 3 RESET key
5296 C ASC A/D ERROR (CH.1) Alarm 3 RESET key
Description : The channel 1 of A/D converter in the driver controller (ASC) is faulty.

Replace the driver.
5301 X ASC A/D ERROR (CH. 2) Alarm 3 RESET key
5302 Y ASC A/D ERROR (CH. 2) Alarm 3 RESET key
5303 U ASC A/D ERROR (CH. 2) Alarm 3 RESET key
5304 V ASC A/D ERROR (CH. 2) Alarm 3 RESET key
5305 Z ASC A/D ERROR (CH. 2) Alarm 3 RESET key
5306 C ASC A/D ERROR (CH. 2) Alarm 3 RESET key
Description : The channel 2 of A/D converter in the driver controller (ASC) is faulty.

Replace the driver.

5331 X DROOP OVER Alarm 3 RESET key
5332 Y DROOP OVER Alarm 3 RESET key
5333 U DROOP OVER Alarm 3 RESET key
5334 V DROOP OVER Alarm 3 RESET key
5335 Z DROOP OVER Alarm 3 RESET key
5336 C DROOP OVER Alarm 3 RESET key
Description : The droop (position deviation value) is too large.


(2) Replace the closed position detector.
5361 X MOTOR REVOLVING SPEED EXCEEDED Alarm 3 RESET key
5362 Y MOTOR REVOLVING SPEED EXCEEDED Alarm 3 RESET key
5363 U MOTOR REVOLVING SPEED EXCEEDED Alarm 3 RESET key
5364 V MOTOR REVOLVING SPEED EXCEEDED Alarm 3 RESET key
5365 Z MOTOR REVOLVING SPEED EXCEEDED Alarm 3 RESET key
5366 C MOTOR REVOLVING SPEED EXCEEDED Alarm 3 RESET key
Description : The motor speed exceeds the tolerance.

(2) The closed feedback system is faulty or its cable is disconnected.

(2) Replace the closed position sensor.
146
5371 X POSITION FEEDBACK DISCONNECTED Alarm 3 RESET key
5372 Y POSITION FEEDBACK DISCONNECTED Alarm 3 RESET key
5373 U POSITION FEEDBACK DISCONNECTED Alarm 3 RESET key
5374 V POSITION FEEDBACK DISCONNECTED Alarm 3 RESET key
5375 Z POSITION FEEDBACK DISCONNECTED Alarm 3 RESET key
5376 C POSITION FEEDBACK DISCONNECTED Alarm 3 RESET key
Description : The position feedback signal does not come.
Causes : (1) Defective position sensor.

(2) Defective position feedback cable.

(1) Replace the position sensor.
(2) Replace the position feedback cable.
5381 X ENCORDER FEEDBACK DISCONNECTED Alarm 3 RESET key
5382 Y ENCORDER FEEDBACK DISCONNECTED Alarm 3 RESET key
5383 U ENCORDER FEEDBACK DISCONNECTED Alarm 3 RESET key
5384 V ENCORDER FEEDBACK DISCONNECTED Alarm 3 RESET key
5385 Z ENCORDER FEEDBACK DISCONNECTED Alarm 3 RESET key
5386 C ENCORDER FEEDBACK DISCONNECTED Alarm 3 RESET key
Description : The encorder signal (PA, PB phases) does not come.


(1) Replace the motor.

5491 X PEAK CURRENT OVER 1 Alarm 3 RESET key
5492 Y PEAK CURRENT OVER 1 Alarm 3 RESET key
5493 U PEAK CURRENT OVER 1 Alarm 3 RESET key
5494 V PEAK CURRENT OVER 1 Alarm 3 RESET key
5495 Z PEAK CURRENT OVER 1 Alarm 3 RESET key
5496 C PEAK CURRENT OVER 1 Alarm 3 RESET key
Description : An overcurrent flows continuously for duration of the set time.


Description : An overcurrent flow continuously for duration of the set time.


148
5511 X EFFECTIVE CURRENT OVER Alarm 3 RESET key
5512 Y EFFECTIVE CURRENT OVER Alarm 3 RESET key
5513 U EFFECTIVE CURRENT OVER Alarm 3 RESET key
5514 V EFFECTIVE CURRENT OVER Alarm 3 RESET key
5515 Z EFFECTIVE CURRENT OVER Alarm 3 RESET key
5516 C EFFECTIVE CURRENT OVER Alarm 3 RESET key
Description : An effective overcurrent flows continuously for duration of the set time.


5521 X UNEFFECTIVE CURRENT OVER Alarm 3 RESET key
5522 Y UNEFFECTIVE CURRENT OVER Alarm 3 RESET key
5523 U UNEFFECTIVE CURRENT OVER Alarm 3 RESET key
5524 V UNEFFECTIVE CURRENT OVER Alarm 3 RESET key
5525 Z UNEFFECTIVE CURRENT OVER Alarm 3 RESET key
5526 C UNEFFECTIVE CURRENT OVER Alarm 3 RESET key
Description : An overcurrent flows and the motor does not run.
Causes : (1) The motor is in lock status.



Description : An overcurrent flows continuously for duration of the set time.


5571 X OVER SPEED Alarm 3 RESET key
5572 Y OVER SPEED Alarm 3 RESET key
5573 U OVER SPEED Alarm 3 RESET key
5574 V OVER SPEED Alarm 3 RESET key
5575 Z OVER SPEED Alarm 3 RESET key
5576 C OVER SPEED Alarm 3 RESET key
Description : The command speed is too high.
Cause : Parameter setting error.

Reset the parameter.
150
5601 X ASC PARAMETER INCORRECT Alarm 3 RESET key
5602 Y ASC PARAMETER INCORRECT Alarm 3 RESET key
5603 U ASC PARAMETER INCORRECT Alarm 3 RESET key
5604 V ASC PARAMETER INCORRECT Alarm 3 RESET key
5605 Z ASC PARAMETER INCORRECT Alarm 3 RESET key
5606 C ASC PARAMETER INCORRECT Alarm 3 RESET key
Description : The parameter for driver controller (ASC) is not correct.
Cause : Parameter setting error.

Reset the parameter.
5731 X ASC INVERTER CURRENT OVER 2 Alarm 3 RESET key
5732 Y ASC INVERTER CURRENT OVER 2 Alarm 3 RESET key
5733 U ASC INVERTER CURRENT OVER 2 Alarm 3 RESET key
5734 V ASC INVERTER CURRENT OVER 2 Alarm 3 RESET key
5735 Z ASC INVERTER CURRENT OVER 2 Alarm 3 RESET key
5736 C ASC INVERTER CURRENT OVER 2 Alarm 3 RESET key
Description : An overcurrent flows to the inverter.



5781 X ACS TIME OUT 3 Alarm 3 RESET key
5782 Y ACS TIME OUT 3 Alarm 3 RESET key
5783 U ACS TIME OUT 3 Alarm 3 RESET key
5784 V ACS TIME OUT 3 Alarm 3 RESET key
5785 Z ACS TIME OUT 3 Alarm 3 RESET key
5786 C ACS TIME OUT 3 Alarm 3 RESET key
5791 X ASC TIME OUT 2 Alarm 3 RESET key
5792 Y ASC TIME OUT 2 Alarm 3 RESET key
5793 U ASC TIME OUT 2 Alarm 3 RESET key
5794 V ASC TIME OUT 2 Alarm 3 RESET key
5795 Z ASC TIME OUT 2 Alarm 3 RESET key
5796 C ASC TIME OUT 2 Alarm 3 RESET key
5801 X ASC TIME OUT 1 Alarm 3 RESET key
5802 Y ASC TIME OUT 1 Alarm 3 RESET key
5803 U ASC TIME OUT 1 Alarm 3 RESET key
5804 V ASC TIME OUT 1 Alarm 3 RESET key
5805 Z ASC TIME OUT 1 Alarm 3 RESET key
5806 C ASC TIME OUT 1 Alarm 3 RESET key
Description : A processing of driver controller (ASC) is not completed successfully.

Replace the driver.
152
5900 SBC DETECTION NONREGISTRY ALARM Alarm 3 RESET key
Description : Unregistered SBC detection alarm occurred.
Causes : (1) Defective VMC card.

(2) Defective EIS card.

(1) Replace the VMC card.
(2) Replace the EIS card.
5911 SBC DETECTION HORIZONTAL PARITY ALARM Alarm 3 RESET key
5912 SBC DETECTION VERTICAL PARITY ALARM Alarm 3 RESET key
Description : An error is found in the data transmitted from the ASC.
Causes : (1) Defective ASC card.

(2) Defective ASU bus cable.

(1) Replace the ASC card.
(2) Replace the ASU bus cable.
5913 SBC DETECTION DUPLICATE AXIS DECLARD Alarm 3 RESET key
Description : The same axis is set twice on the ASC card.
Cause : ASC card axis setting error.

Correct the axis setting on the ASC card.

5914 SBC DETECTION TRANSMISSION ERROR Alarm 3 RESET key
Description : ASU bus transfer alarm (not used at present).
5915 SBC DETECTION TRANSMISSION TIME OUT Alarm 3 RESET key
Description : No response was returned from ASC card to EIS card within the specified time.
Cause : Defective ASC card.

Replace the ASC card.
5916 SBC DETECTION WATCHDOG ALARM Alarm 3 RESET key
Description : An access to the SBC on the EIS card was not made within the specified time.
Cause : The EIS processing error or defective EIS card.

Replace the EIS card.
5917 ASU HARDWARE ERROR Alarm 3 RESET key
Description : A hardware alarm was detected in the ASU unit.
Cause : Defective ASU unit.

Replace the ASU unit.
154
5921 X SERVO ON/OFF CONDITION ERROR Alarm 3 RESET key
5922 Y SERVO ON/OFF CONDITION ERROR Alarm 3 RESET key
5923 U SERVO ON/OFF CONDITION ERROR Alarm 3 RESET key
5924 V SERVO ON/OFF CONDITION ERROR Alarm 3 RESET key
5925 Z SERVO ON/OFF CONDITION ERROR Alarm 3 RESET key
5926 C SERVO ON/OFF CONDITION ERROR Alarm 3 RESET key
Description : The ASU turns off the servo though the main controller sends the servo ON command to
the ASU. Or, the ASU turns on the servo through the main controller sends the servo OFF
command.
Cause : Defective ASU unit (driver controller failure).

Replace the ASU unit.
5951 X SERVO ALARM Alarm 3 RESET key
5952 Y SERVO ALARM Alarm 3 RESET key
5953 U SERVO ALARM Alarm 3 RESET key
5954 V SERVO ALARM Alarm 3 RESET key
5955 Z SERVO ALARM Alarm 3 RESET key
5956 C SERVO ALARM Alarm 3 RESET key
Description : On the machines with an open servo unit, the servo alarm occurred in the axis concerned.
For the details of servo alarm, refer to the 7-segment LED value on the servo amplifier.
Cause : See the Servo Amplifier Description.
Remedy : See the Servo Amplifier Description.

5961 X SERVO NOT READY Alarm 3 RESET key
5962 Y SERVO NOT READY Alarm 3 RESET key
5963 U SERVO NOT READY Alarm 3 RESET key
5964 V SERVO NOT READY Alarm 3 RESET key
5965 Z SERVO NOT READY Alarm 3 RESET key
5966 C SERVO NOT READY Alarm 3 RESET key
Description : On the machines with an open servo unit, the servo for the axis concerned does not
become ready (SRD).
Cause : Defective servo amplifier.
Remedy : Replace the servo amplifier.
5990 SERVO HARDWARE ERROR Alarm 3 RESET key
Description : On the machines with an open servo unit, the servo alarm occurred in non-specific axis.
Causes : (1) Faulty CSI card, or faulty connection cable

(2) Overflow in processing by EIS
Remedy : Check CSI card and the connection cable.

Check the parameters.
5991 CSI CARD FPGA WRITE ERROR Alarm 3 POWER OFF/ON
Description : On the machines with an open servo unit, data writing to the FPGA on the CSI card failed.
Cause : Faulty CSI card
Remedy : Replace the CSI card.
156
5992 CSI CARD 24V DRIP Alarm 3 RESET key
Description : 24V to be supplied to the CSI card dropped.
Cause : Defective 24V power supply
Remedy : Replace the 24V power supply.
6001 AT MDI EXECUTION Guide W ARN RESET key
Cause : At MDI operation, the STOP key was pressed and then the program was attempted to
input while stopping. Or the IN key was pressed.
Remedy : At stop, the program cannot be input. Press the RESET key to reset the stop condition
and then input the program. Or, press the START key to continue.
6002 NUMBER OF BLOCKS EXCEEDS MDI CAPACITY Guide W ARN RESET key
Cause : The program having more than 195 blocks as attempted to input on the MDI screen.
6003 BLOCK WAS CUT Guide W ARN RESET key
Description : When the MDI program (O14999) as input from a screen other than RUN screen, the
number of characters in all blocks exceeded the maximum MDI program area (195
characters).
Remedy : Delete them in block unit down to the allowable range of the MDI program.

6004 NO BLOCK PRESENT ON KEY-IN LINE Guide W ARN RESET key
Cause : Although input command was absent, the IN or ADD IN key was pressed on the MDI
screen.
Remedy : Give the input command and then press the IN or ADD IN key.
6005 ERROR IN BLOCK ON KEY-IN LINE See Note W ARN RESET key
Cause : (1) A command not meeting the input format was attempted to enter on the MDI screen.
(2) The format of M code for pallet magazine control is illegal.
Note: (1) is guide level, and (2) is warning 3 level.
Causes : (1) Correct the input command.

(2) Reset the NC unit, then correct the program.
6006 NOT IN RESET STATUS Guide W ARN RESET key
Cause : The O or N No. was entered during the memory operation in stop status.
Remedy : To change the O or N No. of the memory operation, do so after the program execution is
completed or the RESET key is pressed.
6010 KEY-IN LINE IS EMPTY Guide W ARN RESET key
Cause : After input commands of the run block display area were deleted completely on the MDI
screen by pressing the ERASE key, the ERASE key was pressed again. Or although
there was no input command, the ERASE key was pressed.
158
6011 SEARCHED BLOCK NOT FOUND Guide W ARN RESET key
Cause : Though the SEARCH key was pressed on the RUM MDI screen, searching failed
because there is no block in the execution block display area.
Remedy : Press the SEARCH key with a block displayed on the screen by pressing, for example,
the LAST M.D.I key.
6012 LAST M.D.I BLOCK NOT FOUND
6013 KEY-IN LINE EMPTY, PRESS SEARCH KEY Guide W ARN RESET key
Cause : In executing, for example, the LAST M.D.I key on the RUN MDI screen, the ERASE
key was pressed though there is no block to be erased in the buffer area.
Remedy : Turn off/on the LAST M.D.I key again to call the last program, and press the SEARCH
key to position the cursor at the block to be erased, then press the ERASE key.
6014 SPECIFY O NO. OR N NO. BEFORE INPUT KEY Guide W ARN RESET key
Cause : The IN key was pressed without specifying the O or N No. on the RUN MEMORY screen.
Or, only the O or N of O No. or N No. was specified, and the IN key was pressed.

6015 NPC INTERVAL ERROR Guide W ARN RESET key
6016 TO CANCEL MDI, PRESS f • c, MDI CANCEL KEY Guide W ARN RESET key
Cause : At start on the MEMORY screen, the screen was changed to the MDI screen (MDI
interrupt), and then a program was entered and the START key was pressed.
At start, the MDI RESET key was pressed.
When there was nothing to cancel, the MDI RESET key was pressed in the reset state.
Remedy : In the reset or stop state, press the MDI RESET key.
Note: In case an alarm was causedwhen changing to the MDI screen (MDI interrupt)
at start and the program was run, all programs at MDI interrupt will also be
cancelled.
6025 NO PROGRAM IS RUNNING Guide W ARN RESET key
Cause : The screen was switched to the RUN PROG, BLOCK screen though the program is not
being executed.
Remedy : Operate during program run.
160
6026 SPECIFIED MACRO VARIABLE NO. NOT FOUND Guide W ARN RESET key
Cause : A macro variable No. out of the user macro range was specified on the RUN PROG,
MACRO screen, then the SEARCH key was pressed.
Remedy : Input command error. Press the HELP key with the set data No. 133 (MASKING FUNC.
OF MACRO VR-NO.) to confirm the classification of user/system macro variable numbers.
6051 INTERNAL PROCESSING ERROR Guide W ARN RESET key
6052 PROGRAM BEING RUN CANNOT BE EDITED Guide W ARN RESET key
Cause : The program at execution was attempted to correct on the EDIT BLOCK screen.
Remedy : To edit the program being run, place it in the reset status.
This is also true when the program is being drawn.
6053 MEMORY FULL Guide W ARN RESET key
Cause : The memory becomes full during tape input on the EDIT LIST screen or during manual input
on the EDIT LIST screen.
Remedy : Erase unnecessary programs.

The programs at the time of cancel have been stored. Check the contents of program.
(In particular, care should be taken when a program was canceled in the halfway.)

6054 O NO. ALREADY USED Guide W ARN RESET key
Cause : Entry of the same O No. as one already entered on the EDIT LIST screen was attempted.
The O** ADD IN key was pressed.
Remedy : Select O No. not in use.
6055 O NO. NOT FOUND Guide W ARN RESET key
Cause : On the EDIT LIST screen, O No. not entered was specified and then the
PROGRAM OUTPUT , DIVIDE PROGRAM , SEARCH or ERASE key was
pressed.
Remedy : Check the O No.
6056 MEMORY FULL
6057 SPECIFIED N NO. NOT FOUND Guide W ARN RESET key
Cause : When specifying N No. and pressing the SEARCH key to search it on the EDIT BLOCK
screen, the N No. was not found (search operation in the program).
When specifying N No. from the current cursor position and pressing the ERASE key to
attempt deletion, the specified N No. was not found.
Remedy : Check the N no.
162
6058 SPECIFIED CHARACTER STRING NOT FOUND Guide W ARN RESET key
Cause : When specifying character string and pressing the SEARCH key to search it on the EDIT
BLOCK screen, the character string was not found (search operation in the program).
Remedy : Check the character string.
6059 ALARM BLOCK NOT FOUND Guide W ARN RESET key
Cause : When pressing the ERRORBLK SEARCH key to search an alarm block on the EDIT
BLOCK screen, it was not found.
6060 PROGRAM BEING RUN CANNOT BE DELETED Guide W ARN RESET key
Cause : O No. at execution was attempted to delete on the EDIT LIST screen.
Remedy : Reset and then restart. This also true when the program is being drawn.
6061 ERROR ON KEY-IN LINE Guide W ARN RESET key
Cause : On the EDIT LIST screen, incorrect input command was made and then the
PROGRAM INPUT , PROGRAM OUTPUT , DIVIDE PROGRAM , SEARCH or
ERASE key was pressed.
6062 TAPE ERROR

6063 PROGRAM BEING RUN CANNOT BE DELETED Guide W ARN RESET key
Cause : When some or may O Nos. were deleted on the EDIT LIST screen, some of them were left
undeleted (or O Nos. at execution were included).
6064 DIVIDED RESULT IN FILE CANNOT BE EDITED Guide W ARN RESET key
6065 (MAIN) INTERNAL PROCESSING ERROR Guide W ARN RESET key
6066 (SUB) INTERNAL PROCESSING ERROR Guide W ARN RESET key
6067 INTERPRETATION ERROR Guide W ARN RESET key
6068 ILLEGAL PROGRAM NO. SPECIFIED Guide W ARN RESET key
Cause : On the EDIT LIST screen, O No. other than 1 to 9999 was specified and the
PROGRAM INPUT key was pressed.
Remedy : Specify O No. of 1 to 9999.
6069 (NPC) INTERNAL PROCESSING ERROR Guide W ARN RESET key
164
6070 BLOCK LARGER THAN 192 CHAR. Guide W ARN RESET key
Cause : NC block longer than 192 characters was entered.
Remedy : Reduce the block length to 192 characters or shorter.
6071 (NPC) INTERNAL PROCESSING ERROR Guide W ARN RESET key
Remedy : (1) Repeat operation.

(2) When it occurs frequently, contact to us of the trouble condition .
6072 I/O PROGRAM INPUT EMPTY FILE Guide W ARN RESET key
Description : This message is displayed while on the EDIT LIST screen a program is registered from a
tape to O number area.
6073 I/O PROGRAM ADDING TO EXISTING FILE Guide W ARN RESET key
Description : This message is displayed while, on the EDIT LIST screen, an additional program is
registered from a tape to O number with which a program has already been registered.
6074 OUTPUT OF PROGRAM TO I/O Guide W ARN RESET key
Description : This message is displayed during execution of "PROGRAM OUTPUT" on the EDIT LIST
screen.

6076 ALARM BLOCK FOUND! STOP I/O Guide W ARN RESET key
Cause : An alarm block was found during "PROGRAM INPUT" on the EDIT LIST screen, and the
operation stopped there.
The alarm block is the section indicated with a yellow block cursor on the screen.
Remedy : Press the RESET key to discontinue tape input and then correct the tape. Or, press the
PROGRAM INPUT key again to continue. Upon completion of input, correct the alarm
position.
6077 PROGRAM I/O ABORTED Guide W ARN RESET key
Description : Tape input/output was discontinued by the following operation during tape input/output on
the EDIT LISIT screen.
TRANSFER STOP → TRANSFER ABORT
6078 PROGRAM I/O INPUT COMPLETED Guide W ARN RESET key
Description : Tape data entry to O No. was successfully completed on the EDIT LIST screen.
6079 PROGRAM I/O OUTPUT COMPLETED Guide W ARN RESET key
Description : This message is displayed when, on the EDIT LIST screen, the contents of a program with
O number have successfully been output on the tape puncher.
166
6080 TAPE READER ERROR Guide W ARN RESET key
Description : The tape reader unit input has been stop or reader operation is forcibly canceled by
the RESET key.
Remedy : Check the tape reader.
6081 I/O PORT ERROR Guide W ARN RESET key
Description : During tape output on the EDIT LIST screen;

(1) Program did not output only for a limited time.
(2) The output was forced to cancel by RESET key.
Remedy : In case of description (1), check the tape puncher.
6082 TAPE READER NOT READY Guide W ARN RESET key
Cause : On the EDIT LIST screen, an attempt to input a program from external I/O device such as
a tape reader (optional) was made, but it was not connected.
Remedy : Check the taper reader for connection, and also check a paper tape.
6083 I/O PORT NOT READY Guide W ARN RESET key
Cause : On the EDIT LIST screen, an attempt to output a program to external I/O device such as a
tape puncher (optional) was made, but it was not connected.
Remedy : Check connection of the device.

6084 I/O INPUT STOPPED Guide W ARN RESET key
Cause : During tape inputting on the EDIT LIST screen, the PROGRAM STOP key was pressed.
Remedy : To continue tape inputting, press the PROGRAM INPUT key again.
Note that when TRANSFER ABORT or RESET key is pressed, input cannot be
continued. If you have pressed the TRANSFER ABORT or RESET key, specify the O
No. and then begin from the first.
6085 I/O OUTPUT STOPPED Guide W ARN RESET key
Cause : During tape outputting on the EDIT LIST screen, the PROGRAM STOP key was
pressed.
Remedy : To continue tape outputting, press the PROGRAM OUTPUT key again.
Note that when TRANSFER ABORT or RESET key is pressed, output cannot be
continued. If you have pressed the TRANSFER ABORT or RESET key, specify the O
No. and then begin from the first.
6086 I/O INPUT ABORTED Guide W ARN RESET key
Cause : During tape inputting on the EDIT LIST screen, the TRANSFER ABORT key was
pressed.
Remedy : Tape inputting cannot be continued. Delete the input O No. and then begin from the first.
168
6087 I/O OUTPUT ABORTED Guide W ARN RESET key
Cause : During tape outputting on the EDIT LIST screen, the TRANSFER ABORT key was
pressed.
Remedy : Tape outputting cannot be continued. Specify the O No. and then begin from the first.
6088 AT TAPE REWIND Guide W ARN RESET key
Cause : The TAPE REWIND key was pressed on the EDIT LIST screen. Message indicates that
tape rewind is under way.
6089 TAPE REWIND DONE Guide W ARN RESET key
Cause : Message indicating that tape rewind is completed on the EDIT LIST screen.
6090 TAPE REWIND ERROR Guide W ARN RESET key
Cause : During tape rewind on the EDIT LIST screen, an error (fault) was caused in the tape
rewinder.
Remedy : Check the tape rewinder.
6091 (FATAL) INTERNAL PROCESSING ERROR Guide W ARN RESET key
Remedy : If this error occurs frequently, contact to us of the trouble condition.

6092 PROGRAM I/O CANCELLED Guide W ARN RESET key
Cause : The RESET key was pressed and thus tape input or output was canceled.
Remedy : If during tape input, the input data up to the canceled point is stored.
6093 SEARCHING Guide W ARN RESET key
Cause : The message shows thast when the following key was pressed on the EDIT BLOCK
screen, the program search was under way.
(1) ERRORBLK SEARCH key
(2) Character string to be searched was specified and the SEARCH key was pressed.
6094 EDIT INHIBITED BY PARAMETER Guide W ARN RESET key
Description : The contents of protection vary depending on the setting of set data No. 30, 31, or 32.
Example: Writing or deletion was attempted though the set data No. 30 is set to "1" (O No.
8000–8999 are protected from writing and deletion).
Remedy : Check the setting of set data No. 30, 31, or 32.
6095 DIVIDING OF PROGRAM COMPLETED Guide W ARN RESET key
Cause : The message shows that after inputting to O No. from tape on the EDIT LIST screen, the
DIVIDE PROGRAM was pressed to complete program dividing.
170
6096 KEY IN PROGRAM NO. Guide W ARN RESET key
Cause : O No. was not specified on the EDIT LIST screen and the DIVIDE PROGRAM key was
pressed.
Remedy : Input O No.
6097 NO FILE TO STORE DIVIDED PROGRAM Guide W ARN RESET key
Cause : When the program division was executed on the EDIT LIST screen, the file for temporarily
storing the result was deleted.
Remedy : Turn power OFF and ON again to resume the operation.
6098 DIVIDING PROGRAM Guide W ARN RESET key
Cause : This message is displayed if the O No. is entered and DIVIDE PROGRAM key is pressed
on the EDIT LIST screen.
6099 (R_FILE) INTERNAL PROCESSING ERROR Guide W ARN RESET key
6100 (READ) INTERNAL PROCESSING ERROR Guide W ARN RESET key
6101 (REWRITE) INTERNAL PROCESSING ERROR Guide W ARN RESET key
Remedy : In case of frequent occurrence, contact to us of the trouble condition.

6102 PROGRAM BEING RUN CANNOT BE EDITED Guide W ARN RESET key
Cause : The NC program is being used by NC internal processing and cannot be edited from the
EDIT LIST screen.
Remedy : Stop editing.
6103 INPUT STARTING N NO. FOR PROG. COMPARE Guide W ARN RESET key
Cause : N No. at which to start tape collate was not entered and the PROGRAM COMPARE key
was pressed.
Remedy : When making tape collate from the beginning of the program, enter "N" and then press the
PROGRAM COMPARE key.
6104 TO CONTINUE, CLEAR KEY-IN LINE OR ENTER "C" Guide W ARN RESET key
Cause : When resumption of collation was attempted after stopping during collation or due to finding
mismatch block, characters other than "C" were in the key input line.
Remedy : Empty the key input line or enter "C" and then press the PROGRAM COMPARE key to
resume.
When empty : Collation is resumed from the block next to the cursor.
When "C" entered : Collation is resumed from the block where the cursor is.
6105 COMPARING PROGRAM Guide W ARN RESET key
Cause : The message shows that the tape program and the memory program are being collated.
172
6106 PROGRAM COMPARE STOPPED Guide W ARN RESET key
Cause : During tape collation, the TRANSFER STOP key was pressed and collation was once
stopped.
Remedy : Press the PROGRAM COMPARE key to resume tape collation.
Press the TRANSFER ABORT key or RESET key to stop tape collation.
6107 DIFFERENT BLOCK FOUND Guide W ARN RESET key
Cause : During tape collation, a difference between the tape block and the memory block was found
and tape collation was stopped.
Remedy : The block (memory program) with cursor on the screen and the block (program on the tape
at the right side of "@") are different. The memory block can be corrected as it is.
Press the PROGRAM COMPARE key to resume collation.
6108 PROGRAM COMPARE ABORTED Guide W ARN RESET key
Cause : During tape collation, the TRANSFER ABORT key was pressed and collation was
stopped.
6109 NO DIFFERENCES FOUND Guide W ARN RESET key
Cause : In tape collation, difference between the tape program and the memory program was not
found and collation was completed normally.

6110 PROGRAM COMPARE ABORTED Guide W ARN RESET key
Cause : During tape collation, the RESET key was pressed.
6111 CAN’T GO TO LIST SCREEN DURING PROG. COMPARE Guide W ARN RESET key
Cause : During tape collation, the LIST key was pressed.
Remedy : During tape collation, you cannot return to the LIST screen. Be sure to stop or finish the
tape collation before it.
6112 FILE Q’TYPE OVERFLOW Guide W ARN RESET key
Description : Program No. can be registered to any number from O1 to 9999 but not all of these numbers
can be used. Total 3000 numbers are available for registration.
Cause : More than available numbers were used.
Remedy : Delete unnecessary program No.
6113 MEMORY OVERFLOW Guide W ARN RESET key
Description : During tape input on the EDIT LIST screen or during manual input on the EDIT BLOCK
screen, memory overflow.
Cause : Too many program.
Remedy : Delete unnecessary program.

The program up to the canceled point has been stored.
Check the program content. (Especially when canceled halfway of the program, pay
attention.)
174
6114 BUBBLE MEMORY OVERFLOW
6115 (MEDIA3) INTERNAL PROCESSING ERROR Guide W ARN RESET key
Remedy : (1) Operation again.

(2) In case of frequent occurrence, contact to us of the trouble condition.
6116 (NPC 2EH) INTERNAL PROCESSING ERROR Guide W ARN RESET key
Cause : Defective VMC card or ROM.

6119 ALARM BLOCK PRESENT IN PROGRAM Guide W ARN RESET key
6120 (MACRO) MORE THAN 20 VARIABLES IN EXPRESSION Guide W ARN RESET key
6121 (MACRO) ILLEGAL OPERATOR USAGE Guide W ARN RESET key
6122 (MACRO) MORE THAN 20 OPERATORS IN EXPRESSION Guide W ARN RESET key
6123 (MACRO) TOO COMPLICATED EXPRESSION (1) Guide W ARN RESET key
6124 (MACRO) TOO COMPLICATED EXPRESSION (2) Guide W ARN RESET key
6125 (MACRO) TOO COMPLICATED DIVISION IN EXPRES. Guide W ARN RESET key
6126 (MACRO) MEMORY FULL AT COMPILE Guide W ARN RESET key
Cause : The following phenomena occurred when on the EDIT BLOCK screen, the program was
entered and the LIST DISPLAY key was pressed to close the file and return to the EDIT
LIST screen.
(1) A check did not complete as there is an alarm block in the program. (6119)
(Alarm block: Indicated with yellow block cursor on the screen)
(2) A check did not complete as there is an expression containing more than 20 variables
in the program. (6120)
(3) A check did not complete as an operator is used improperly in the program. (6121)
(4) A check did not complete as there is an expression containing more than 20 operators
in the program. (6122)
(5) A check did not complete as there is a complicated expression in the program.
(6123~6125)
(6) Memory capacity for storing tapes is lack.
Remedy : (1) Correct the program. (6119~6125)

(2) Erase unnecessary programs. (6126)
6127 (COMPILE 48H) INTERNAL PROCESSING ERROR
6128 (COMPILE 49H) INTERNAL PROCESSING ERROR
Cause : System error (ROM is faulty, or RAM data is destroyed.)

Clear RAM, or replace ROM, or VMC card.
176
6129 NO. OF "[","]" IN PROGRAM DOES NOT MATCH Guide W ARN RESET key
Cause : The number of brackets ( [ ] ) in the program is not matching.
6131 NEST LEVEL ABOVE 10 Guide W ARN RESET key
Cause : On the EDIT BLOCK screen, program was input and then LIST key was pressed to close
the file and return to the EDIT LIST screen but check was not completed due to nest level
exceeding 10 in the program.
6132 CALLING SUB PROGRAMS MORE THAN 151 Guide W ARN RESET key
Cause : When the EDIT BLOCK screen is returned to the EDIT LIST screen, the O number and N
number of a subprogram are stored. However, 151 or more subprograms have already
been stored, and there is no space for additional subprograms.
Remedy : Correct the program using the nesting level so that the number of subprograms to be called
with one O number is within 150.
6133 (COMPILE 4EH) INTERNAL PROCESSING ERROR Guide W ARN RESET key
6134 (COMPILE 4FH) INTERNAL PROCESSING ERROR Guide W ARN RESET key
Description : System error
Cause : Defective VMC card.

Defective ROM.

6135 PROGRAM CLOSING, PLEASE WAIT Guide W ARN RESET key
Cause : The message shows that on the EDIT BLOCK screen, program was input and then
LIST key was pressed to close the file and return is being made to the EDIT LIST screen.
6136 PROGRAM ERASING, PLEASE WAIT Guide W ARN RESET key
Cause : The message shows that on the EDIT LIST screen O No. was specified and the ERASE
key was pressed and the program is being deleted.
6137 (ABO) ALARM BLOCK FOUND! I/O INPUT ABORTED Guide W ARN RESET key
6138 O NO. FOUND AFTER FIRST BLOCK Guide W ARN RESET key
Cause : When tape output was made on the EDIT LIST screen, O address block is in other than
head block (other than the block immediately after start).
Remedy : Delete the O No. which exists in other than first block. Or, if the output operation is
continued by the setting the set data No. 0011 (EDIT FUNC (2)) bit 3 to "1", the operation
does not stop even if O No. other than that at head exists.
6139 PLEASE INPUT "D" TO DELETE Guide W ARN RESET key
Cause : The set data No. 11 (EDIT FUNC (2)) bit 2 (for protection from data erasing by mistake) is
set to "1".
Remedy : (1) For example, if O1 is to be erased, press O 1 D ERASE in this order.

(2) If D is not to be input, set the set data No. 11 bit 2 to "0".
178
6140 COPYING PROGRAM Guide W ARN RESET key
6141 COPY END Guide W ARN RESET key
Description : This message is displayed when program copy is started or finished on the EDIT screen.
6142 MODEL BLOCK NOT PRESENT (G100–G139) Guide W ARN RESET key
Description : An attempt to compile a code other than model block codes (G100 –G139) of model plan
and conversion code (G180, G181) of program master (optional) was made.
6143 COMPILING MODEL INFORMATION Guide W ARN RESET key
Description : Compilation of a model block (G100–G139) or program master (G180, G181 optional)
started.
Compilation will stop if the RESET key is pressed or a screen is changed over during
compilation.
6145 ILLEGAL WIRE DIAMETER Guide W ARN RESET key
6250 ILLEGAL VALUE SET IN MACHINING CONDITION Guide W ARN RESET key
Cause : On the COND, LIST COND. screen, attempt was made to input a value outside of the
allowable range or delete was attempted without setting the cursor to the condition to be
deleted.
Remedy : Check the input command value.

Set the cursor to the condition to be deleted (cursor may be at any position) and press the
ERASE key.

6260 INVALID HELP KEY Guide W ARN RESET key
Description : The HELP key was pressed on the screen where it is inactive.
6261 COMMENT OF HELP IS NO ENTRY Guide W ARN RESET key
Description : No comment is registered though the HELP key was pressed.
6262 THIS KEY IS INVALID ON HELP DISPLAY Guide W ARN RESET key
Description : A key that cannot be used during display of HELP key was pressed.
Remedy : Press the HELP key again to erase the HELP display, then press that key.
6270 CALENDAR TIME OVER Warning 1 W ARN RESET key
Description : The input data exceeds the calendar range supported by the clock built in the NC.
(Calendar range 1980/1/10:00 to 2038/1/10:00)
6325 GRAPHICS DRAWING Guide W ARN RESET key
Causes : On the GRAPHIC screen, either of the following keys is pressed.

(1) After setting O No., the DRAWING START key was pressed.
(2) The TRACE MACHING key was pressed.
180
6326 AUTO SCALING Guide W ARN RESET key
Cause : On the GRAPHIC screen, after setting O No., the AUTO SCALING key was pressed.
6329 AUTO SCALING IMPOSSIBLE Guide W ARN RESET key
Causes : On the GRAPHIC screen, the AUTO SCALING key was pressed under the following
condition.
(1) O No. was not set.
(2) Drawing was being executed.
(3) Drawing was in stop status.
Remedy : Set O No.

Operate under drawing reset state.
6330 DRAWING IMPOSSIBLE Guide W ARN RESET key
Causes : On the GRAPHIC screen, either of the operations was made.

(1) O No. was not set → DRAWING START key → Drawing was in stop status →
DRAWING START key was pressed.
(2) The TRACE MACHING key was pressed while drawing was being executed.
Remedy : (1) Set O No. to operate again.

(2) Operate under drawing reset state.
6331 CANNOT STOP DRAWING NOW Guide W ARN RESET key
Cause : On the GRAPHIC screen, the DRAWING STOP key was pressed in the drawing reset
status.
Remedy : At drawing start, operate again.

6332 CANNOT CHANGE DRAWING SET NOW Guide W ARN RESET key
Cause : On the GRAPHIC screen, the operation was made in the following conditions.
At drawing stop, the SEARCH , ERASE , ADD IN or IN keys was pressed.
Remedy : Operate under drawing reset state.
6333 FIGURE MOVE IMPOSSIBLE Guide W ARN RESET key
6334 FIGURE SCALING IMPOSSIBLE Guide W ARN RESET key
6335 DISPLAY OF COORD. IMPOSSIBLE Guide W ARN RESET key
Cause : On the GRAPHIC, DRAW DSP screen, the following operation was made.
(1) The DRAWING MOVE key (6333) or DRAWING ZOOM key (6334) or
VERIFY POSITION key (6335) was pressed while the drawing start or trace
machining is under way.
(2) The DRAWING MOVE key (6333) or DRAWING ZOOM key (6334) or
VERIFY POSITION key (6335) was pressed while the drawing zoom or verify
position is selected.
Remedy : Press the DRAWING RESET key, and then perform the desired operation.
Check the selected mode.
6336 DRAW FINISHED Guide W ARN RESET key
Causes : On the GRAPHIC screen, the operation was made in the following conditions.
(1) The AUTO SCALING key was pressed. Drawing was displayed and the message
appears upon completion of drawing.
(2) At drawing start or drawing stop, the DRAWING RESET key was pressed.
182
6338 SCAL DECIDED Guide W ARN RESET key
Cause : On the GRAPHIC screen, the operation was made in the following conditions.
The AUTO SCALING key was pressed. While range is automatically setting, the
DRAWING RESET key was pressed.
Note: Scale when the DRAWING RESET key is set.
6341 SPECIFIED O NO. NOT FOUND Guide W ARN RESET key
Cause : On the GRAPHIC screen, an attempt to enter nonregistered O No. as DRAWING START
O: was made, or on the DISK FILE screen, illegal O No. was specified.
6342 DATA RECALL MEMORY EMPTY Guide W ARN RESET key
Cause : At drawing start or during execution of sync. on the GRAPHIC screen, the DATA SAVE
or DATA RECALL key was pressed.
Remedy : Once draw and then operate the key.
6343 O NO. ERROR Guide W ARN RESET key
6344 DATA ERROR

6345 SELECT LOWER RIGHT CORNER Guide W ARN RESET key
Cause : This message is displayed when the DRAWING ZOOM key on the GRAPHIC screen or
the AUTO SCALING key in the scaling mode 2 is pressed.
Move the cursor to the desired position with cursor key and press the IN key.
Remedy : To cancel operation, press the DRAWING ZOOM key or DRAWING RESET key.
6346 SELECT UPPER LEFT CORNER Guide W ARN RESET key
Description : This message is displayed when the DRAWING ZOOM key on the GRAPHIC screen or
AUTO SCALING key in the scaling mode 2 is pressed, and the IN key is pressed with
the cursor at the desired position. Move the cursor to the desired position with cursor key
and press the IN key.
6347 MOVE FROM THIS POSITION Guide W ARN RESET key
Cause : Message appearing at screen top when DRAWING MOVE key is pressed on the
GRAPHIC screen. Use cursor key to set the cursor at the figure center position and press
the IN key.
Remedy : To stop, press the DRAWING MOVE again.
184
6348 MOVE TO THIS POSITION Guide W ARN RESET key
Cause : On the GRAPHIC screen, press DRAWING MOVE key and use cursor key to set the
cursor at the new center position and then press the IN key.
Then, press DRAWING START key to draw the figure from the new center position.
Remedy : To stop, press the DRAWING MOVE again.
6349 DRAWING CLEAR ONLY IN DRAWING RESET STATUS Guide W ARN RESET key
Cause : On the GRAPHIC screen, the DRAWING CLEAR key was pressed during draw stop.
Remedy : Operate under drawing reset state.
6350 GRAPHICS DATA SAVED Guide W ARN RESET key
Cause : The message appears when on the GRAPHIC screen, the data currently being set was
saved in the save area in the memory.
The DATA SAVE key was pressed.
6351 ADD O NO. CAN NOT USED IN mm-MODE Guide W ARN RESET key

6352 SCREEN NOT VALID DURING TRACE MACHING DRAW Guide W ARN RESET key
Cause : On the GRAPHIC screen, the following operation was made during execution of sync.
drawing.
Attempt was made to turn page by pressing either
the POSITION MODAL , NEST MEVEL , BLOCK DISPLAY ,
MACRO VARIABLE , MACHING TIME or DRAWING CLEAR key.
Remedy : Turn page under drawing reset state.
6353 MOVE CURSOR AND SET DATA Guide W ARN RESET key
6354 ONLY POSSIBLE WITH ROTATE ANGLE 0 OR 90 Guide W ARN RESET key
Cause : On the GRAPHIC screen, the following operation was made when the rotation angle X or
Z setting was other than 0 or 90°.
Either the DRAWING MOVE , DRAWING ZOOM or VERIFY POSITION key was
attempted to select.
Remedy : Change the rotation angle X or Z setting to 0 or 90°C.
6355 SPECIFIED PARAMETER NOT FOUND Guide W ARN RESET key
Cause : On the SET DATA screen, a number not entered was specified and the SEARCH key
was pressed.
186
6356 CURSOR INCREMENT KEY NOT VALID NOW Guide W ARN RESET key
Cause : On the GRAPHIC screen, the CURSOR INCREMENT key was pressed when the
FIGURE MOVE , FIGURE ENLARGE or POSITION CONFIRM key was not

selected.
Remedy : Select either the FIGURE MOVE , FIGURE ENLARGE or POSITION CONFIRM
key.
6357 OFFSET DATA TRANSFERRED Guide W ARN RESET key
Cause : On the GRAPHIC screen, the offset data set on the graphic side was transferred to the
machining side by pressing the OFFSET → MC key.
6358 TAPER DATA TRANSFERRED Guide W ARN RESET key
Cause : On the GRAPHIC screen, the taper data set on the graphic side was transferred to the
machining side by pressing the TAPER → MC key.
6359 WORK OFFSET TRANSFERRED
6360 O NO., N NO. TRANSFERRED
6361 COORD. DATA TRANSFERRED
6362 START COORD. TRANSFERRED

6363 MACHINE INFO. TRANSFERRED Guide W ARN RESET key
Description : This message is displayed when the data on the machine side was transferred to the
graphic side by pressing the MC → GRAPHIC key on the GRAPHIC screen.
6364 DATA NOT TRANSFERRED NOW Guide W ARN RESET key
Cause : On the GRAPHIC screen, the MC → GRAPHIC key was pressed while drawing or trace
machining is being executed or in other than memory run mode.
Remedy : In the memory run mode, retry this operation in the drawing reset status.
6365 STROKE FRAME CANNOT BE DISPLAYED Guide W ARN RESET key
Description : When the AUTO SCALING key on the GRAPHIC screen was pressed in the scaling
mode 2, the frame cannot be displayed because the stroke 1, 3 range exceeds 3800 mm.
Remedy : Confirm the set values for X and Y software strokes of machine parameters (No. 1046–
2051).
6366 DRAWING START POINT? Guide W ARN RESET key
Description : This message is displayed when the auto scaling is executed in the mode 2 on the
GRAPHIC screen.
Remedy : Move the cursor to the desired start point with cursor keys and press the IN key.
188
6367 CLEAR THE DRAWING Guide W ARN RESET key
Description : This message indicates that the TRACE MACHING was pressed though a drawing was
not cleared, but a tracing cannot be executed unless a drawing is cleared.
Remedy : Clear the drawing first, then press the TRACE MACHING key.
6370 GRAPHIC DATA TRANSFERRED Guide W ARN RESET key
Description : This message indicates that the data was transferred successfully from graphic side to
machining side by the GRAPHIC → MC key on the GRAPHIC TEST screen.
Remedy : Confirm the data transferred to the machining side before machining (on the SET, OFFSET
screen or NC FUNC screen).
6375 TRANSFER GRAPHIC DATA? yes:IN KEY, no:ERASE KEY Guide W ARN RESET key
Description : This message indicates that an attempt to transfer the data on graphic side to the machining
side was made by pressing the GRAPHIC → MC key on the GRAPHIC TEST screen.
Remedy : (1) To transfer the data on graphic side to the machining side, press IN key.
(2) To cancel data transfer, press the ERASE key.
6400 ONLY VALID WITH OPTIONAL ITEM Guide W ARN RESET key
Cause : This message is displayed when an optional function key was pressed but that function is
invalid.

6401 ONLY VALID IN MANUAL MODE Guide W ARN RESET key
Cause : The function valid only in MANUAL mode was specified in other than this mode.
Remedy : Change to the MANUAL mode and then operate again.
6402 ONLY VALID IN MANUAL MODE & RESET STATUS Guide W ARN RESET key
Cause : The function valid only in MANUAL mode or under reset state was specified in condition
other than this mode.
Remedy : Reset and change to MANUAL mode and then, operate again.
6410 DON’T SAVE RAM MACRO AFTER O No.10000 Warning 3 W ARN RESET key
Description : This message indicates that the system macros (programs after O10000) registered in the
RAM area cannot be saved when G154 (data backup) is executed.
Remedy : In saving the system macros after O10000, reset the G154, set the set data No.30-32 to 0,
and save them using the FD drive built in the machine, or connect an external unit to the
machine and save them. After saving the programs, return the set data No.30~32 to original
value, and restart the G154.
190
6411 DON’T SAVE NC PROGRAM Warning 3 W ARN RESET key
Description : This message is displayed when the power supply unit with extended memory capacity
(tape storage length 3000m, optional) is used or when G154 (data backup) that does not
save the NC programs is specified.
Remedy : (1) For the power supply unit with extended memory capacity, NC programs cannot be
saved in one floppy disk, and therefore reset the G154 once and prepare another FD
to save NC programs individually. Then, restart the G154.
(2) If the G154 that does not save the NC programs is specified, recheck the NC programs
and press the START key to continue operation. In saving the NC programs, reset
the G154 and specify the G154 again so that it saves the NC programs, or save NC
programs individually in another FD.
6412 NOW DATA SAVING Warning 1 W ARN RESET key
6413 COMPLETE DATA SAVING Warning 1 W ARN RESET key
6414 NOW DATA REGISTRY ! Warning 1 W ARN RESET key
6415 COMPLETE DATA REGISTRATION Warning 1 W ARN RESET key
Description : This message indicates the on-going operation when G154 (data backup) was started.
6425 DUPLICATE G110–G139 BLOCKS IN SUCCESSION Guide W ARN RESET key
Cause : An attempt to develop the model blocks (G110-G139) in which multiple G codes are used
in the same block was made.
Remedy : Check the blocks in the model plan again, and erase an excessive block.
6426 MODEL BLOCKS ARE NOT COMPILED Guide W ARN RESET key
Cause : An attempt to develop incomplete model blocks was mode.
Remedy : Develop the model blocks with the DEVELOP key, then start operation or make a graphic
drawing.

6427 MODEL BLOCKS ARE NOT ENTERED COMPLETELY Guide W ARN RESET key
Cause : An attempt to develop incomplete model blocks was made.
Remedy : Reedit the model plan and add necessary model blocks.
6428 MODEL BLOCK ADD-IN COMPLETED Guide W ARN RESET key
Description : A model block was overwritten on the block on which the cursor is currently positioned on
the block screen by pressing the EOB IN keys on the model screen.
6429 MODEL BLOCK CHANGE COMPLETED Guide W ARN RESET key
Description : A model block was overwritten on the block on which the cursor is currently positioned on
the block screen by pressing the EOB IN keys on the model screen.
6430 NOT APPLICABLE TO MODEL BLOCK Guide W ARN RESET key
Cause : An attempt to edit in the talk mode a program other than model blocks (G110-G139) using
a function key MODEL PLAN was made on the EDIT BLOCK screen.
6431 DATA ON CURSOR LINE NOT PERFECT Guide W ARN RESET key
Cause : This message is displayed when an attempt to change data was made on the MODEL
TALK screen but that data is not registered.
Remedy : Correct the data to be changed.
192
6432 DATA NEEDED AT CURSOR POSITION Guide W ARN RESET key
Cause : This message is displayed when the NEXT PLAN key or EOB ADD IN keys or EOB
IN keys are pressed with data filed incompleted on the MODEL TANK, MACHINING
CONTROL TABLE, MACHINING FORMAT, or MACHINING PROCESS TABLE screen.
Remedy : Complete the data field.
6433 START OF EDIT SCREEN Guide W ARN RESET key
Cause : The MODEL MENU screen was opened and the PRE. BLOCK key was pressed with the
cursor positioned at head block on the EDIT BLOCK screen.
6434 END OF EDIT SCREEN Guide W ARN RESET key
Description : The MODEL MENU screen was opened and the NEXT BLOCK key was pressed with the
cursor positioned at end block on the EDIT BLOCK screen.
6435 ILLEGAL SCREEN DATA Guide W ARN RESET key
6436 PLEASE INPUT [;]+[ADD-IN] OR [;]+[IN] --- ---
6437 INPUT [;]+[ADD-IN] OR [;]+[IN] AFT. INPUT DATA --- ---

6440 HEAD CARD Guide Unnecessary
Description : In the Model Plan Ver. 2, the – key was pressed with the MENU screen.
6441 LAST CARD Guide Unnecessary
Description : In the Model Plan Ver. 2, the + key was pressed with the last process card L500.
6442 LAST CONDITION CARD Guide Unnecessary
Description : In the Model Plan Ver. 2, the IN key was pressed with the cursor at the "NEXT COND."
switch on the last condition card L301 screen.
6443 LAST PROCESS CARD Guide Unnecessary
Description : In the Model Plan Ver. 2, the IN key was pressed with the cursor at the "NEXT PROC."
switch on the last process card L500 screen.
6447 DISPLAYING CARD INITIALIZED Guide Unnecessary
Description : In the Model Plan Ver. 2, the IN key was pressed with the cursor at the "CARD INIT."
switch on each card screen to initialize the input data on card.
194
6448 CARD DATA CALLED Guide Unnecessary
Description : In the Model Plan Ver. 2, the IN key was pressed with the cursor at the "CALL" switch on
each card screen to call the stored data.
Or, another card No. was designated to take a copy.
6449 NO USE MSS. Guide Unnecessary
6450 NO STORED DATA Guide Unnecessary
Description : In the Model Plan Ver. 2, the "CALL" was attempted to the card that was not stored.
6451 CARD DATA STORED Guide Unnecessary
Description : In the Model Plan Ver. 2, the IN key was pressed with the cursor at the "STORE" switch
to store data on card in the internal memory.
6452 PROHIBITED LOCKING Guide Unnecessary
Description : In the Model Plan Ver. 2, an attempt to lock the item with "P" in lock area (initial value cannot
be locked) was made.
6453 NO LAST DATA Guide Unnecessary
Description : In the Model Plan Ver. 2, an attempt to display previous data with "NEXT DATA" switch
during display of top search data in the search window was made.

6454 NO NEXT DATA Guide Unnecessary
Description : In the Model Plan Ver. 2, an attempt to display next data with "LAST DATA" switch during
display of last search data in the search window was made.
6455 MODEL DATA DELETED Guide Unnecessary
Description : In the Model Plan Ver. 2, the user registered data of search data in the search window was
deleted with the "DEL" switch.
6456 MODEL DATA ADDED Guide Unnecessary
Description : In the Model Plan Ver. 2, the user registered data was added at the last of search data in
the search window with the "ADD" switch.
6457 MODEL DATA DELETED AND ADDED Guide Unnecessary
Description : In the Model Plan Ver. 2, the user registered data of search data was changed (deleted,
then added) in the search window with the "D&A" switch.
6458 MODEL DATA CANNOT BE DELETED Guide Unnecessary
Description : In the Model Plan Ver. 2, an attempt to delete standard data (stored in ROM) of search data
in the search window was made with the "DEL" switch.
6459 MODEL DATA CANNOT BE DELETED AND ADDED Guide Unnecessary
Description : In the Model Plan Ver. 2, an attempt to change standard data (stored in ROM) of search
data in the search window was made with the "D&A" switch.
196
6460 NO USE Guide Unnecessary
Description : An item of Model Plan Ver. 2 not used at present was searched.
6461 INDIRECT OFFSET DATA IN CONDITION TABLE Guide Unnecessary
Description : In the Model Plan Ver. 2, an attempt to register user data with the indirect offset No. entered
in the condition table was made.
6462 OFFSET DATA TRANSFERRED Guide Unnecessary
Description : In the Model Plan Ver. 2, the offset value was transferred from condition table to indirect
offset window with the "TRANSFER" function.
6463 OFFSET DATA CANNOT BE TRANSFERRED Guide Unnecessary
Description : In the Model Plan Ver. 2, an attempt to transfer offset value was made with the
"TRANSFER", but the indirect offset window is full.
6464 MODEL BLOCKS OUTPUT COMPLETED Guide Unnecessary
Description : In the Model Plan Ver. 2, the model blocks were output to the EDIT BLOCK screen with the
"OUTPUT & CONT." switch on the process card.
6465 QUIT & CLOSE? yes:IN KEY no:ERASE KEY Guide Unnecessary
Description : In the Model Plan Ver. 2, an attempt to close the model plan without output of data after
editing was made.

6466 WORK COORDINATES TRANSFERRED Guide Unnecessary
Description : In the Model Plan Ver. 2, current work coordinates were transferred to the MACH. START
points on process card with the "WORK COPY" function key.
6467 OUTPUTTING MODEL BLOCKS Guide Unnecessary
Description : This message is displayed when the data are output to the model blocks with the output
key.
6468 SPECIFIED CONDITION CARD IS NOT USED Guide Unnecessary
Description : In the Model Plan Ver. 2, the card No. not used was specified to the "COND. CARD NO."
on process card.
6469 INPUT MASTER BLOCKS O NO. Guide Unnecessary
Description : In the Model Plan Ver. 2, an attempt to register master blocks was made without setting
master block No. (0 is set now) to the set data No. 0177 (MODEL MASTER BLOCK O NO.).
6470 NO INPUT DATA Guide Unnecessary
Description : In the Model Plan Ver. 2, an attempt to register model blocks was made without entering
data.
6471 MASTER BLOCKS OUTPUT COMPLETED Guide Unnecessary
198
6472 MODEL DATA OUTPUT COMPLETED Guide Unnecessary
Description : In the Model Plan Ver. 2, the model data were output as model blocks to the specified O No.
6473 INPUT O NO. Guide Unnecessary
Description : In the Model Plan Ver. 2, an attempt to output model data was made without specifying O
No.
6474 SPECIFIED O NO. IS NOT EMPTY Guide Unnecessary
Description : In the Model Plan Ver. 2, an attempt to output model data to the O No. which is full was
made.
6475 OUTPUTTING MODEL DATA Guide Unnecessary
Description : This message is displayed when the user model data are being output to the specified O
No.
6476 READING BLOCKS Guide Unnecessary
Description : In the Model Plan Ver. 2, the model block or master block is being read.
6477 MASTER BLOCKS WERE READ Guide Unnecessary
Description : In the Model Plan Ver. 2, the master blocks were read when the MODEL PLAN key on
EDIT BLOCK screen was pressed.

6478 STANDARD CONDITIONS CANNOT BE DELETED Guide Unnecessary
Description : In the Model Plan Ver. 2, an attempt to delete standard conditions (stored in ROM) was
made during data searching in the search window.
6479 USER AREA IS FULL Guide Unnecessary
Description : In the Model Plan Ver. 2, the internal user area to register user model conditions is full.
6480 SPECIFIED O NO. IS EDITING Guide Unnecessary
Description : In the Model Plan Ver. 2, an attempt to output master block or user model condition to the
O No. being edited at present was made.
6481 NO REGISTERED DATA Guide Unnecessary
Description : An attempt to output data to the specified O No. was made though no data is registered in
the user model area.
6490 M74 RECORD BAD NUMBER OF RECORD ID Alarm 2 RESET key
Description : An attempt to add further data was made after the number of data saved on the M74 screen
reached 300.
Remedy : Specify M74 command to clear the data, or set the set data No.78 bit 1 to “1” to record the
skipped positions only.
Or, set the bit 3 to “1” to return to the beginning for recording.
200
6491 M74 RECORD BAD NUMBER OF ITEM ID Alarm 2 RESET key
Description : In the M74 data saving, illegal element number (M74 parameter) was specified.
6492 M74 RECORD DISCRIMINATOR (P/W/L) OVERLAP Alarm 2 RESET key
Description : In the M74 data re-registration, an attempt to register additionally the P/W/L data was made
though they have already been registered.
6493 M74 RECORD ITEM VALUE IS BEYOND THE LIMITS Alarm 2
Description : In the M74 data re-registration, the specified M74 parameter value is out of allowable range.
6500 START,STOP,RESET KEYS ARE INVALID Guide W ARN RESET key
Description : START , STOP , or RESET key was pressed when a process moved during schedule
operation.
6501 CANNOT CHANGE RUNNING MODE Guide W ARN RESET key
Description : An attempt to change the operation mode to other than MEM RUN mode was made
when a process moved during schedule operation.

6502 NOT MEMORY MODE OR ALARM SIGN EXIST Warning 3 W ARN RESET key
Description : An attempt to execute a schedule operation was made in other than MEM RUN mode or
during alarm.
Remedy : Select the MEM RUN mode and reset the alarm if alarm is present, then start the
schedule operation.
6503 PROCESS DATA IS EDITING Warning 3 W ARN RESET key
Description : The schedule operation was started though the process data is being edited.
Remedy : Return to the SCHEDULE LIST screen, then start the schedule operation.
6504 ILLEGAL SCHEDULE MODE Warning 3 W ARN RESET key
Description : Internal processing of schedule operation causes contradiction in operation mode.
6505 PROCESS IS NOT STORED Warning 3 W ARN RESET key
Description : The schedule operation was started with unregistered process number.
Remedy : Register the process, then start the schedule operation.
202
6506 ILLEGAL PROCESS No. (SCHEDULE DATA) See Note W ARN RESET key
Description : Process number is incorrect when reading or writing process data.
Remedy : Check the process number.

Note: The level is guide or warning 3.
6507 ILLEGAL ITEM No. (SCHEDULE DATA) See Note W ARN RESET key
Description : Item number of schedule data is incorrect when reading or writing process number.
Remedy : Check the schedule data.

Note: The level is guide or warning 3.
6508 PROCESS DATA ACCESS ERROR Warning 3 See Remedy
Description : Process execution error or data base destroyed by internal processing.
Remedy : Contact to us of the trouble condition, as internal data will be erroneous.
6509 CA NN OT CH AN GE PR OC ES S D ATA BY P RO C ESS STA TUS Warning 3 W ARN RESET key
Description : An attempt to change process data was made, where the "STATUS" area on the
SCHEDULE LIST screen is not blank.
6510 NO PROCESS TO EXECUTE Warning 3 W ARN RESET key
Description : There is no start process data for schedule operation.
Remedy : Enter "START" to the process to be executed first.

6511 CANNOT FIND CODE UNDER PROCESS --- ---
6512 CANNOT CHANGE PROCESS STATUS Guide W ARN RESET key
Description : An attempt to change the status of current process was made.
6513 OPERATION WITH INPUT "P [PROCESS No.]" Guide W ARN RESET key
Description : Original process is not specified when copying the process data.
Remedy : To specify the process, enter the process number on the key-in line.
6514 MEMORIZE A PACK OP PROCESS DATA --- ---
6515 MAKING IN GOOD ORDER Guide W ARN RESET key
Description : This message is displayed when process numbers are reassigned because of insertion or
deletion of processes.
6516 MACRO ERROR --- ---
204
6600 INVALID COMMAND ON KEY-IN LINE Guide W ARN RESET key
Causes : (1) On the MANUAL screen, the IN key was pressed by with an erroneous command.
(2) On the RUN PROG, MACRO screen, the IN , SEARCH , ERASE or ADD IN
key was pressed with an eroneous command.
(3) On the COND LIST screen, the IN key was pressed with an erroneous command.
(4) On the POSITION WORK or RELATIVE screen, the WORK SET and
RELATIVE SET keys were pressed with an erroneous command.
(5) On the SET OFFSET, WK OFFSET, or SET DAT screen, the IN key was pressed
with an erroneous command.
(6) On the M.CONTROL screen, the IN key was pressed with an erroneous command.
Remedy : Check the input command.
6601 NO MORE DISPLAYABLE PAGES Guide W ARN RESET key
Cause : No page to be changed over is left when the pages are changed over with the page keys.
Remedy : If this message appears when + page key is used, use – page key to turn pages.
If this message appears when – page key is used, use + page key to turn pages.
6602 WRITE PROTECTED Guide W ARN RESET key
Description : The set data value was attempted to input in the write prohibit condition.
Cause : Value was attempted to input to a write-protected parameter during starting, stopping or in
ZERO RETURN mode.
Remedy : Reset or turn OFF the zero return mode and then, operate again.

6603 WORK COORDINATE CAN ONLY BE SET IN RESET STS Guide W ARN RESET key
Cause : The WORK SET key was pressed during start or stop.
Remedy : Reset and operate again.
6604 SEARCH KEY INVALID ON THIS SCREEN Guide W ARN RESET key
6605 DELETE KEY INVALID ON THIS SCREEN Guide W ARN RESET key
6606 ADD KEY INVALID ON THIS SCREEN Guide W ARN RESET key
6607 INPUT KEY INVALID ON THIS SCREEN Guide W ARN RESET key
6608 + PAGE KEY INVALID ON THIS SCREEN Guide W ARN RESET key
6609 – PAGE KEY INVALID ON THIS SCREEN Guide W ARN RESET key
6610 UP CURSOR KEY INVALID ON THIS SCREEN Guide W ARN RESET key
6611 DOWN CURSOR KEY INVALID ON THIS SCREEN Guide W ARN RESET key
6612 RIGHT CURSOR KEY INVALID ON THIS SCREEN Guide W ARN RESET key
6613 LEFT CURSOR KEY INVALID ON THIS SCREEN Guide W ARN RESET key
6614 ADDRESS KEY INVALID ON THIS SCREEN Guide W ARN RESET key
6615 TEN KEY INVALID ON THIS SCREEN Guide W ARN RESET key
Cause : These keys were pressed on invalid screens.
Remedy : These keys are invalid and cannot be used on these screens.
6616 UNNECESSARY LETTER OF KEY-IN LINE Guide W ARN RESET key
Cause : While address key A to Z was unnecessary for the specified entry, such entry was
attempted.
Remedy : Delete address (A to Z) command on the key-in line.
206
6617 NUMBER TOO LARGE ON KEY-IN LINE Guide W ARN RESET key
6618 NUMBER TOO SMALL ON KEY-IN LINE Guide W ARN RESET key
Cause : The data entered on the key-in line was larger than the range of data value in the specified
entry.
Remedy : Change the value on the key-in line.
6619 NUMBER OUT OF RANGE ON KEY-IN LINE Guide W ARN RESET key
Description : The data entered on the key-in line was out of the numeric range of data value in the
specified entry.
Cause : On the SET DATA screen, a numeric value entered to the parameter was larger or smaller
than the maximum or minimum value for the entry.
Remedy : Change the value on the key-in line
6620 NUMBER HAS TOO MANY DIGITS ON KEY-IN LINE Guide W ARN RESET key
Cause : The data entered on the key-in line did not match the number of digits of data value in the
specified entry.
Remedy : Change the number of digits on the key-in line.

6621 KEY-IN LINE EMPTY Guide W ARN RESET key
Description : Operation which must be done with entering a numeric or alphabetical value in advance on
the key-in line was made without such procedure.
Cause : On the MDI screen, the IN key was pressed without entering a program.
On the COND, LIST screen, the COND COPY key was pressed without entering E No.
The RELATIVE SET or WORK SET key was pressed without entering anything.
Remedy : Enter data on the key-in line and then operate again.
6622 NOT VALID IN START, STOP STS & HW, ZERO RET MODE Guide W ARN RESET key
Cause : An function key was pressed in the start, stop, handwheel, or zero point return mode.
Remedy : Set the mode other than above, than retry.
6623 INHIBITED BY PARAMETER Guide W ARN RESET key
Cause : An attempt to clear the machining time by pressing the MC. TIME CLEAR key on the
DIAG MC TIME screen was made when the set data No. 180 bit 4 is "0".
Remedy : Set the bit 4 to "1" for clearing the machining time.
6630 VALID ONLY WITH OPTIONAL ITEM Guide W ARN RESET key
Description : Although an attempt to operate optional function was made, that function is not attached.
208
6650 NOW IMC MODE IS REMOTE MODE
6651 NOW IMC MODE IS LOCAL MODE See Causes W ARN RESET key
Description : On the IMC screen (optional), an attempt to operate the function that cannot be used when
the IMC mode is Local mode was made.
Causes : (1) On the MACH OPE, IMC screen, the function key for machining completion (IMC
control screen) or pseudo completion (IMC maintenance screen) was pressed. (Guide)
(2) NC code exclusively for IMC in the program was executed. (Warning 3)
Remedy : Change the IMC from LOCAL to REMOTE, and retry operation.
6652 CAN’T DO MANUAL PROGRAM RX FROM TERMINAL Guide W ARN RESET key
Causes : On the IMC screen (optional), this message is displayed by either of the following causes.
(1) In the IMC REMOTE mode, an attempt to input a program from the host computer was
made.
(2) The specified O No. already exists in NC unit.
Remedy : In case of cause (1), c hange IMC mode to LOCAL, and retry operation.
In case of cause (2), delete specified O No., if unnecessary, then retry operation.
6653 CAN’T DO MANUAL PROGRAM TX TO TERMINAL Guide W ARN RESET key
Cause : On the IMC screen (optional), the O No. to be output is not found in NC unit.
Remedy : Change O No. to be output, then retry operation.

6654 DON’T MATCH TERM R/T ABORT --- ---
6655 LINE INFORMATION IS NOT ON LINE Guide W ARN RESET key
Cause : On the IMC screen (optional), in the off-line status, a function key on IMC control screen or
IMC maintenance screen was operated.
Remedy : Set up on-line status, then retry operation.
6656 CAN’T CHANGE TERMINAL PARAM. UNTIL OF LINE Guide W ARN RESET key
Cause : On the IMC screen (optional), in the on-line status, communication conditions to host
computer were changed.
Remedy : Change communication conditions in the off-line status.
6657 PLEASE PUSH F.KEY (TERM RX OR TERM TX) Guide W ARN RESET key
Description : On the IMC screen (optional), this message is displayed to ask for next operation when O
No. is keyed in on the IMC control screen.
Remedy : Press the TERM RX PROGRAM key or TERM TX PROGRAM key on the IMC control
screen.
In case of misoperation, press the WARN RESET key to clear this message.
210
6658 CAN’T CHANGE OF IMC MODE Guide W ARN RESET key
Description : On the IMC screen (optional), the TM. MODE SELECT key was pressed to change IMC
mode to REMOTE during program input on the IMC control screen.
Remedy : Stop the program input or wait for completion of program input, then retry operation.
6659 CHANGE OF IMC MODE Guide W ARN RESET key
Description : On the IMC screen (optional), the TM. MODE SELECT key was pressed to change IMC
mode during execution of IMC mode change.
Remedy : Wait for completion of IMC mode change, then retry operation.
6660 TERMINAL IS DISABLED --- ---

6661 OCCURRENT OF FILE OPEN ERROR (TERMINAL) Guide W ARN RESET key
6662 TERMINAL IS BUSY NOW Guide W ARN RESET key
6663 FOUND OF O NUMBER ERROR (TERMINAL) Guide W ARN RESET key
Description : On the IMC screen (optional), this message is given during program I/O operation on the
IMC control screen.
Causes : (1) The O No. specified for program input is not found in the host computer.
(Message No.6661)
(2) The host computer is not ready for reception in the program output operation.
(Message No.6661)
(3) The program input operation was specified from NC unit, though the host computer is
under program output. (Message No.6662)
(4) The host computer judged that the O number specified in the NC unit is other than
1~9999. (Message No.6663)
Remedy : (1) Check the program registered to the host computer. (Message No.6661)
(2) Wait for completion of program output from host computer, then retry operation.
(Message No.6662)
(3) Check the program O No., and retry operation.
6664 PLEASE CHECK OF CHANNEL LINE TO TERMINAL Warning 1 W ARN RESET key
Description : On the IMC screen (optional), the RS-232C cable between host computer and NC unit is
faulty.
Causes : (1) The RS-232C cable is loosely connected or disconnected.

(2) Noise is present in control cables (CTS, etc.)
Remedy : Reconnect the cable.

If this failure occurrs frequently, contact to us of the trouble condition.
212
6665 CAN’T SET COMMAND Guide W ARN RESET key
Cause : On the IMC screen (optional), the function keys for pseudo completion on IMC maintenance
screen were pressed simultaneously.
Remedy : Press either one of function keys for pseudo completion.
6666 PUSH COMPLETE OR ABORT END KEY Guide W ARN RESET key
Description : On the IMC screen (optional), this message is displayed to ask for next operation when a
function key for pseudo completion on the IMC maintenance sceen is pressed.
Remedy : Press COMPLETE or ABORT key to select successful or unsuccessful pseudo

completion.
6667 CAN’T SET EXECUTING COMMAND Guide W ARN RESET key
Cause : On the IMC screen (optional), the command specified with a pseudo completion function
key on IMC maintenance screen is same as that being executed in the NC unit now.
Remedy : Wait for completion of execution by NC unit, then retry operation.
6668 CANCELED OF FUNCTION COMMAND Guide W ARN RESET key
Description : On the IMC screen (optional), this message is displayed to cancel the pseudo completion
setting if reversal-displayed pseudo completion function key on IMC maintenance screen is
pressed once more.

6735 INVALID EIO NO. SPECIFIED Guide W ARN RESET key
Cause : On the DIAGNOSE EIO screen, the SEARCH key was pressed without specifying a
number.
A number not registered was specified, then EIO or SEARCH keys were pressed.
Remedy : Check the input command.
6740 KEY-IN DATA IS NO GOOD Guide W ARN RESET key
Description : The entered address value (VMC memory location) is not correct.
Remedy : Reenter correct address value.
6750 USER MASKING PARAMETER NO. **** (BIT *) Guide W ARN RESET key
Description : The function key pressed is masked by the parameter and it is therefore inactive.
Remedy : To cancel masking and activate the functionkey, set the specified bit of parameter displayed
as guide to "0".
6751 MASKED BECAUSE FUNCTION IS NOT SUPPORTED Guide W ARN RESET key
Description : This message indicates that the specified function is not supported by your machine.
214
6800 THE FUNCTION KEY DEPRESSED IS INVALID Guide W ARN RESET key
Cause : On the DISK DIR. screen (valid for the machines with optional 3.5 inch floppy disk drive),
this key cannot be used since the other function is being executed.
Remedy : Press it after execution of current function is finished.
6801 TRANSFERRING FILE! Guide Unnecessary
Description : On the DISK DIR. screen (valid for the machines with optional 3.5 inch floppy disk drive),
an NC program is being transferred between disk and memory with the MEMORY → DISK or
DISK → MEMORY key.
6802 COPYING FILE! Guide Unnecessary
Description : On the DISK DIR. screen (valid for the machines with optional 3.5 inch floppy disk drive), a
fine on the disk is being codied to another file with COPY FILE key.
6803 CREATING DIRECTORY! Guide Unnecessary
directory is being created with CREATE DIR. key.
6804 DELETING DIRECTORY! Guide Unnecessary
directory is being deleted with DELETE DIR. key.

6805 DELETING FILE! Guide Unnecessary
file is being deleted with DELETE FILE key.
6806 CANCELING! Guide Unnecessary
when a function is being executed, it is canceled with ESCAPE key.
6807 FORMATTING! Guide Unnecessary
the disk format is being made with FORMAT DISK key.
6808 FILE TRANSFER COMPLETE Guide W ARN RESET key
an NC program transfer with MEMORY → DISK or DISK → MEMORY key as
completed.
6809 FILE COPY COMPLETE Guide W ARN RESET key
file copying with COPY FILE key has completed.
216
6810 FILE RENAME COMPLETE Guide W ARN RESET key
file renaming with RENAME FILE key has completed.
6811 FILE WRITE-PROTECT COMPLETE Guide W ARN RESET key
setting of write-protect for the file with PROTECT FILE key has completed.
6812 DIRECTORY COMPLETE Guide W ARN RESET key
directory making with CREATE DIR. key has completed.
6813 DIRECTORY DELETION COMPLETE Guide W ARN RESET key
directory deletion with DELETE DIR. key has completed.
6814 FILE DELETION COMPLETE Guide W ARN RESET key
file deletion with DELETE FILE key has completed.

6815 DISK FORMAT COMPLETE Guide W ARN RESET key
disk initialization with FORMAT DISK key has completed.
6816 CANCELED Guide W ARN RESET key
cancellation of operation being executed with ESCAPE key has completed.
6817 REPLACE? YES : IN KEY NO : ERASE KEY Guide W ARN RESET key
Description : On the DISK DIR. screen (valid for the machines with optional 3.5 inch floppy disk drive), if
a file is transferred or copied using the same name as that of existing file with
MEMORY → DISK , DISK → MEMORY or COPY FILE key, press the IN key to
replace the existing file, or the ERASE key to cancel file replacement.
6818 DELETE FILE? YES : IN KEY NO : ERASE KEY Guide Unnecessary
a file is deleted with DELETE FILE key, press the IN key to delete the file, or the
ERASE key to cancel file deletion.
6819 DISK FORMATTING? YES : IN KEY NO : ERASE KEY Guide Unnecessary
a disk is initialized with FORMAT DISK key, press the IN key to format the disk, or the
ERASE key to cancel the disk formatting.
218
6820 FILE CANNOT BE COPIED TO IDENTICAL NAME Guide W ARN RESET key
an attempt to copy a file with COPY FILE key using the same file name on both send and
receive sides was made.
Remedy : Change file name on either send or receive side.
6821 ILLEGAL FILE IS SPECIFIED Guide W ARN RESET key
an attempt to display the contents of file with DISPLAY FILE key was made, but it cannot
be displayed because of illegal file. (? mark is displayed if 65 or more undisplayable
characters continue and they are within 65 characters.)
Remedy : Specify another file.
6822 ILLEGAL CURSOR POSITION Guide W ARN RESET key
though an attempt to copy the data at the cursor position to the key-in line with IN key
was made, no data can be copied because of illegal cursor position.
Remedy : Shift the cursor position.
6823 VOLUME LABEL WITHIN 11 CHARACTERS Guide W ARN RESET key
when a disk is formatted with FORMAT DISK key, the volume label keyed in exceeds 11
characters.
Remedy : Change volume label within 11 characters.

6824 PA RA M ETE R S ETTIN G ERR O R FO R FO RM A T SE LECT ION Guide W ARN RESET key
wrong data is set to the bits 4 and 5 of set data No. 12 File Management Function.
Remedy : The bits 4 and 5 must be set as follows depending on the floppy disk format used.
MS-DOS*2HD/MP type (1.2 MB) format : bit 4, 5 = 0
PC-DOS*2DD (720 KB) format : bit 4 = 1, bit 5 = 0
FANUC-PG*2HD format : bit 4 = 0, bit 5 = 1
MS-DOS*2HD/MP type (1.44 MB) format : bit 4, 5 = 1
* MSDOS, PCDOS, FANUC-PG are registered trade marks of MICROSOFT, IBM and
FANUC respectively.
Also, of the MS-DOS/MP format machines, the machines with optional 3.5 inch floppy disk
drive manufactured before 1999 may not be able to read the 1.44M formatted floppy disks.
6825 1:2HD (1.2M) 2:2DD (720K) 3:PG 4:2HD (1.44M) Guide W ARN RESET key
select the type of floppy disk format. Enter a numeric key 1~4, and press the IN key.
6826 2HD (1.2M) DISK FORMATTING? YES : IN NO : ERASE Guide W ARN RESET key
6827 2DD (720K) DISK FORMATTING? YES : IN NO : ERASE Guide W ARN RESET key
6828 PG DISK FORMATTING? YES : IN NO : ERASE Guide W ARN RESET key
6829 2HD (1.44M) DISK FORMATTING? YES : IN NO : ERASE Guide W ARN RESET key
this message is displayed for confirmation if an attempt to format the disk with the
FORMAT DISK key was made. To execute the disk formatting, press the IN key, or to
cancel the disk formatting, press the ERASE key.
220
6830 NO FILE OR DIR. NAME FOUND Guide W ARN RESET key
in the operation COPY FILE , DELETE FILE , RENAME FILE , PROTECT FILE or
DISPLAY FILE , DELETE DIR. , OPEN DIR. , the specified file name or directory
name (path) is not found in the key-in line.
Remedy : Change file or directory name.
6831 FILE IS WRITE-PROTECTED Guide W ARN RESET key
in the operation MEMORY → DISK , DISK → MEMORY , COPY FILE ,
RENAME FILE , PROTECT FILE , CREATE DIR. , DELETE DIR. , DELETE FILE
or FORMAT DISK , an attempt to write data to the write-protected file was made.
Remedy : Cancel write-protect function or change file name.
6832 FILE IS FULL Guide W ARN RESET key
in the operation MEMORY → DISK , DISK → MEMORY , COPY FILE or
CREATE DIR. , an attempt to add a file or directory, but the number of files exceeds 192.
Remedy : Delete unnecessary files or replace the disk.

6833 ENTER FILE NAME Guide W ARN RESET key
in the operation MEMORY → DISK , DISK → MEMORY , COPY FILE ,
DISPLAY FILE , RENAME FILE , PROTECT FILE , DISK DIR. or

DELETE FILE , the directory name was used instead of file name.
Remedy : Change directory name to file name.
6834 IDENTICAL FILE NAME OR DIR. IS FOUND Guide W ARN RESET key
in the operation RENAME FILE or CREATE DIR. , the same name was used.
Remedy : Change file name of directory name.
6835 FILE EXISTS IN DIRECTORY Guide W ARN RESET key
an attempt to delete the directory with DELETE DIR. key was made, but a file remains
in the directory.
Remedy : Delete that file in the directory or change directory name.
6836 DIRECTORY CANNOT BE ERASED Guide W ARN RESET key
an attempt to delete current directory with DELETE DIR. key was made.
Remedy : Close the directory with EXIT DIR. key, or change directory name.
222
6837 DIRECTORY IS FULL Guide W ARN RESET key
Cause : On the DISK DIR. screen (valid for the machines with optional 3.5 inch floppy disk drive),,
in the operation MEMORY → DISK , DISK → MEMORY , COPY FILE or
CREATE DIR. , no available area remains in the disk (memory capacity is full).
Remedy : Delete unnecessary files or replace the disk.
6838 DISK IS WRITE-PROTECTED Guide W ARN RESET key
MEMORY → DISK , DISK → MEMORY , COPY FILE , DELETE FILE ,
PROTECT FILE , CREATE DIR. , DELETE DIR. , or FORMAT DISK was operated
to the disk of which write-protect switch is set to "write disabled" position.
Remedy : Set the write-protect switch of the disk to "write enabled" position.
6839 DISK IN POSITION? Guide W ARN RESET key
file operation was executed without loading a disk.
Remedy : Load a disk into the disk drive.
6840 DISK DATA IS DESTROYED Guide W ARN RESET key
data is destroyed during disk run.
Remedy : The disk head may be dirty. Clean it with a cleaning disk. If the message is displayed
again, replace the disk.

6841 ILLEGAL DISK IS USED Guide W ARN RESET key
the disk format is illegal.
Remedy : The disk head may be dirty. Clean it with a cleaning disk.
If the message is still displayed, replace the disk or format the disk.
6842 DISK SEEK ERROR Guide W ARN RESET key
6843 DISK WRITE ERROR Guide W ARN RESET key
6844 DISK READ ERROR (FORMATTED-DISK?) Guide W ARN RESET key
access to the disk fails.
Remedy : The disk head may be dirty. Clean it with a cleaning disk.
If the message is still displayed, replace the disk or format the disk.
6845 DRIVE NUMBER IS NOT CONNECTED Guide W ARN RESET key
6846 DRIVE MAY BE OUT OF ORDER Guide W ARN RESET key
Cause : On the DISK DIR. screen (valid for the machines with optional 3.5 inch floppy disk drive), a
system error, or ROM or card is faulty.
Remedy : Replace VFD card, drive unit or ROM.
224
6847 RS232C UNCONNECTED
6848 RS232C COMMUNICATION ERROR
6849 RS232C TIME ELAPSED ERROR
6850 RS232C ILLEGAL PARAMETER
6851 EMM FIRMWARE RAM CHECK ERROR Guide W ARN RESET key
6852 EMM FIRMWARE INTERNAL ERROR Guide W ARN RESET key
Cause : The VFD card or ROM is faulty.
Remedy : Replace the card or ROM.
6853 SYSTEM ERROR Guide W ARN RESET key
Cause : FEM internal processing eror.
Remedy : Please let us know about how did you operate the file management screen.
6854 DISABLE FUNCTION UNDER CURRENT FORMAT Guide W ARN RESET key
the function key that cannot be used in the format selected by set data No. 12 File
Management Function was used.
Remedy : Avoid using that function.

6855 DIRECTORY DESIGNATION IS NOT USED Guide W ARN RESET key
the function key for the directory was used in the format illegal to that directory.
Remedy : Avoid using that function.
6856 WILDCARD (*.?) CAN NOT USE Guide W ARN RESET key
in the format selected at present, a wild card cannot be used for file name of original file,
destination file, etc.
6857 FILE NAME IS NOT MP-1 TYPE Guide W ARN RESET key
the original file is not in the MP format when the file copy is executed in the MP format.
6860 SELECT DISK TO MEMORY FILE AND PUSH [IN] KEY Guide W ARN RESET key
this message is displayed when a file is transferred by pressing DISK → MEMORY in the
MP function mode. The file to be transferred to the memory is registered by selecting the
file and pressing the IN key.
6861 SELECT COPY FILE AND PUSH [IN] KEY Guide W ARN RESET key
this message is displayed when COPY FILE is pressed in the MP function mode. The
original file is registered by selecting the file and pressing the IN key.
226
6862 SELECT RENAME FILE AND PUSH [IN] KEY Guide W ARN RESET key
this message is displayed when RENAME FILE is pressed in the MP function mode.
The file to be renamed is registered by selecting the file and pressing the IN key.
6863 SELECT DELETE FILE AND PUSH [IN] KEY Guide W ARN RESET key
this message is displayed when DELETE FILE is pressed in the MP function mode.
The file to be deleted is registered by selecting the file and pressing the IN key.
6864 INPUT MEMORY TO DISK O NO. AND PUSH [IN] KEY Guide W ARN RESET key
this message is displayed when a program is transferred by pressing MEMORY → DISK
key in the MP function mode. The O number in NC memory transferred to disk is registered
when IN key is pressed after keying in the O number.
6865 INPUT FILE NAME AND PUSH [IN] KEY Guide W ARN RESET key
this message is displayed when a file is transferred by pressing MEMORY → DISK key
in the MP function mode. Key in file name and press the IN key, so that the file name on
the disk is registered and transfer starts.

6866 INPUT DISK TO MEMORY O NO. AND PUSH [IN] KEY Guide W ARN RESET key
this message is displayed when a program assigned with O No. is transferred by pressing
DISK → MEMORY key in the MP function mode. Key in O No. and press the IN key,
so that O No. for NC memory is reistered, and transfer starts.
this message is displayed COPY FILE is pressed in the MP function mode. Key in file
name and press the IN key, so that the file name at the destination is registered and file
copy starts.
this message is displayed when RENAME FILE is pressed in the MP function mode.
Key in file name and press the IN key, so that new file name is registered and file
renaming starts.
6900 END OF SYSTEM Guide W ARN RESET key
Description : This message is displayed when the END is selected on the MENU screen of the automatic
programming function (optional), and then the function ends and the automatic
programming startup screen appears.
228
6901 FAILED OF SYSTEM START Guide W ARN RESET key
Cause : This message is displayed when the start-up of automatic programming function (optional)
falled. The VOH card or the ROM on VOH card is faulty.
6902 FAILED OF SYSTEM RELEASE Guide W ARN RESET key
Cause : This message is displayed when the release of automatic programming function (optional)
failed. The VOH card or the ROM on VOH card is faulty.
6903 END OF RAM DISK FORMAT Guide W ARN RESET key
Description : This message is displayed when the RAM disk formatting for automatic programming
function (optional) ended.
6904 FAILED OF RAM DISK FORMAT Guide W ARN RESET key
Cause : This message is displayed when the RAM disk formatting for automatic programming
function (optional) failed. The VOH card or the ROM on VOH card is faulty.
6905 RAM DISK FORMATTING? YES : I N KEY NO : ERASE KEY Guide W ARN RESET key
Description : This message is displayed when the RAM disk is formatted for the automatic programming
function (optional). If the disk is formatted, files stored on the RAM disk are erased. The
message is displayed to prevent files from being erased by mistake.

6906 FORMATTING Guide W ARN RESET key
Description : This message is displayed while the RAM disk is being formatted for the automatic
programming function (optional).
7000 OC TIME ELAPSED ERROR Warning 1 W ARN RESET key
Description : The display of run program, position, etc. with the VOH card in a screen updating operation
was not completed within the specified time (10 sec).
Cause : Defective VOH card or VMC card.
Remedy : In case of frequent occurrence, contact to us.
7001 OC RESPONSE ERROR Alarm 3 W ARN RESET key
Description : Abnormal interruption was made from VOH card to VMC card during a screen updating to
display run program, position, etc. or when a keyboard key was pressed.
Cause : Defective VOH card or VMC card.
7019 OC NONREGISTRY ALARM Alarm 3 W ARN RESET key
Description : An undefined alarm occurred in the VOH card.
Cause : Defective VOH card.
230
7100 ESC0 RESERVE, RELEASE ERROR Alarm 3 RESET key
7101 ESC0 TIME ELAPSED ERROR Warning 3 W ARN RESET

key
(Option)
Causes : FMS or setting of external I/O unit.

Defective VMC card or ROM.
Remedy : Reconfirm the set values of FMS or external devices connected.
7102 ESC0 START, STOP BITS INCORRECT ORDER Alarm 3 RESET key
(Option)
Description : An error occurred when the data input/output was started or finished via external RS-232C
channel.
Cause : FMS or setting of external I/O unit.

7108 ESC0 FRAMING ERROR (0 STOP BITS) Warning 1 W ARN RESET key
(Option)
Description : The data frame error (0 is detected by the stop bit) was found during data input/output via
external RS-232C channel.
Cause : The bard rate setting of FMS or external I/O device is erroneous.
The data length of FMS or external I/O device is erroneous.

7109 ESC0 RX OVERRUN Warning 1 W ARN RESET key
7110 ESC0 PARITY ERROR Warning 1 W ARN RESET key
7111 ESC0 BUFFER OVERFLOW Warning 1 W ARN RESET key
7112 ESC0 TERMINAL NOT CONNECTED Warning 1 W ARN RESET key
(Option)
Description : (1) The data is read one character each from the external RS-232C channel, but external
RS-232C channel overruns and 4 or more characters are input at a time.
(Message No.7109)
(2) When the data is read one character each from the external RS-232C channel, the
even/odd parity of one character data is erroneous. (Message No.7110)
(3) The input buffer overflows during data reading from the external RS-232C channel.
(Message No.7111)
Cause : FMS or setting of external I/O unit.

Remedy : (1) Reconfirm the set values of FMS or external devices connected.
(Message No.7109/7110/7111)
(2) Check the connection of RS-232C connectors. (Message No.7112)
7119 ESC0 NONREGISTRY ALARM Alarm 3 RESET key
(Option)
Description : Unregistered alarm occurred in the external RS-232C channel.
Cause : Defective VMC card or ROM.
Remedy : (1) Operate again or turn power On again.

(2) In case of frequent occurrence, contact to us.
232
Description : The error occurred when the program input from a tape reader (optional) started or ended.
Cause : Defective ROM.
Remedy : Contact to us.
7121 ESC1 TIME ELAPSED ERROR Warning 1 W ARN RESET key
Description : In reading the data with a tape reader (optional), no data was entered within the time set to
the set data No. 22 (10 seconds).
Cause : Defective tape reader, VMC card, or ROM.
Remedy : Contact to us after checking the set value of set data No. 22.
7122 ESC1 START, STOP BITS INCORRECT ORDER Alarm 3 RESET key
Description : The error occurred when the program input from a tape reader (optional) started or ended.
7128 ESC1 FRAMING ERROR (0 STOP BITS) Warning 1 W ARN RESET key
Description : In reading the data with a tape reader (optional), a data framing error was found (0 was
detected in stop bit).
Remedy : Retry operation, and if this error occurs frequently, contact to us.

Description : (1) The data is read from the tape reader (optional) in characters. However, the next data
has been fed due to the delay in reading from the tape reader. (Message No.7129)
(2) When one characte of data was read from the tape reader (optional), its odd/even parity
was different from the specification. (Message No.7130)
Description : While data was being read from the tape reader (optional), the input buffer overflowed.
Description : The initial setting of tape reader (optional) is faulty, or the cable is defective or
disconnected.
Remedy : Check tape reader connectors.

In case of frequent occurrence, contact to us.
234
Description : An undefined alarm occurred in the tape reader (optional).
Cause : Defective VMC card, or ROM.
7141 ESC2 TIME ELAPSED ERROR Warning 3 W ARN RESET

key
7142 ESC2 START, STOP ORDER ERROR Alarm 3 RESET key
(Option)
Description : (1) An error occurred when tape input was started or ended by the RS232C.
(Message No.7140)
* ESC2: RS232C interface (2)
(2) When input/output was made through RS232C channel, data was not entered from
more than the time set by the set data.
The set value of the set data No. 0023 setting is 10 s. (Message No.7141)
(3) An error occurred when tape input was started or ended using external RS232C
channel. (Message No.7142)
Causes : Setting of external I/O unit.

Remedy : Reconfirm set data No. 0021, 0025, and 0026 and set value of external systems connected.

7148 ESC2 FRAMING ERROR Warning 1 W ARN RESET key
(Option)
Description : During input/output by the external RS-232C channel, data framing error was found (0 was
detected by stop bit).
Causes : Specification error of transfer speed (baud rate) of external input/output equipment.
Specification error of stop bit lenggh and data length of external input/output equipment.
(Option)
Description : (1) Data is normally read in one character unit from the external RS232C channel but the
channel was overrun and four characters or more were entered simultaneously.
(Message No.7149)
(2) When one character of data was read from the external RS232C channel, its odd/even
parity was different from the specification. (Message No.7150)
(3) While data was being read from the external RS232C channel, the input buffer
overflowed. (Message No.7151)

236
(Option)
Description : The initial setting of external RS-232C channel is improper, or the cable is defective or dis-
connected.

Remedy : Check external RS232C connectors.
(Option)
Description : Meaningless alarm was caused from the external RS232C channel.
Causes : Defective VMC card or ROM.
Remedy : (1) Operate again or turn power ON again.

7300 EIS NOT CONNECTED Alarm 3 RESET key
Description : Defective EIS card connections.
Causes : Defective EIS card.

Defective EIS card connections.
Remedy : Turn power On again.

Check EIS card connectors.
Contact to us.

7301 EIS TIME ELAPSED ERROR Alarm 3 See Remedy.
Description : When axis was moved and the machining condition was changed, with EIS card a response
was not received within 1–3 seconds.
Cause : The signal communication between VMC and EIS cards.

Defective EIS card.
Remedy : (1) Apply again RESET key or the electric source.

7302 SEND TO EIS NOT OK Alarm 3 See Remedy.
Description : Axis movement or machining condition command cannot be transferred to the EIS card.
Cause : Defective EIS card, VMC card.

Defective EIS card connections.

7303 ERRONEOUS INTERRUPT FROM EIS Alarm 3 See Remedy.
7304 EIS RESPONSE LENGTH ERROR Alarm 3 See Remedy.
Description : (1) Unexpected interruption was caused from the EIS card. (Message No.7303)
(2) Response format error of data reception from the EIS card. (Message No.7304)
Cause : Defective EIS card or ROM

238
7305 EIS PARAMETER INITIALIZE NOT OK Alarm 3 See Remedy.
Description : EIS card cannot be initialized at power ON.
Cause : The ASU cable or ASU terminator is not connected or it is disconnected.
Remedy : (1) Turn power ON again.

7306 WRONG OR DAMAGED EIS CARD MOUNTED Alarm 3 RESET key
Cause : EIS card in use is not suitable in combination or EIS common RAM is faulty.
The ASU cable or ASU terminator is not connected or it is disconnected.
Remedy : Apply the normal EIS card.
7307 EIS-ASC ERROR Alarm 3 RESET key
Causes : (1) The number of axes set to ASU is less than that set to the parameter. Or, the axis No.
setting on the ASU is wrong.
(2) The axis No. setting (rotary switch) on the ASU is overlapped.
(3) The ASU is defective and it cannot communicate with the EIS.

7321 EIS (LOCAL) ROM ERROR Alarm 3 RESET key
7322 EIS (LOCAL) RAM ERROR Alarm 3 See Remedy.
7323 EIS (LOCAL) EXECUTION OF NON-CODE SECTION Alarm 3 See Remedy.
Description : (1) EIS card ROM failed. (Message No.7321)

(2) EIS card RAM failed. (Message No.7322)
(3) Soft error of EIS card. (Message No.7323)
Cause : (1) Defective ROM on EIS card. (Message No.7321, 7323)

(2) Defective RAM on EIS card. (Message No.7322)

7324 EIS (LOCAL) ASC TIME ELAPSED ERROR Alarm 3 See Remedy.
Description : When axis movement data was output from the EIS card to the ASC card, response was
not made within the fixed time.
Causes : Defective ASC card.

Incorrect VMC card DIC switch setting.

7325 EIS (LOCAL) IO TIME ELAPSED ERROR Alarm 3 See Remedy.
Description : When EIS card is use, I/O operation are done to ASC card and resulted in time out.
Causes : EIS or ASC card is faulty.

EIS-ROM is faulty.
Remedy : Contact us of it because the cards must be changed according to the trouble.
240
7330 EIS (LOCAL) NDP ERROR
7331 EIS(LOCAL) MEMORY FULL Alarm 3 See Remedy.
Description : Interpolative EIS block is full.
Causes : EIS-ROM or VMC-FROM is faulty.
Remedy : Contact us of the trouble because ROM system may be faulty.
7332 EIS (LOCAL) DEAD LOCK Alarm 3 RESET key
Description : Faulty system ROM on the EIS card.
Remedy : The EIS card must be replaced. Contact to us.
7333 MACHINE COORD. IS OUT OF SOFT LIMIT Alarm 2 RESET key
Cause : Illegal soft limit value.

Machine position beyond soft limit.
Mode switching made while out of soft limit.
Remedy : (1) When the machine is out of limit, jog it to within limit and reset with RESET key.
(2) If the machine position is correct, check the limit value (machine parameters No. 1046–
6051).

7340 EIS (LOCAL) NO EQUIPMENT OPTION
Description : Not uded.
7341 BACK BLOCK OUT DUE TO SHORT WIRE-WORK Alarm 2 RESET key
Description : Wire and work were in contact at start of machining.
Cause : At the start of machining, the head reverse signal was output, but there is no reverse block.
The short between wire and workpiece is caused by a burr of workpiece, wire debris, or
dropped core.
Remedy : (1) Remove foreign matters that causes the short between wire and workpiece.
(2) If a cause is uncertain, check the set value of reverse block timer (machine parameter
No. 779, standard value 5), and contact to us of the trouble condition.
7342 SHORT STATE WIRE-WORK Alarm 2 RESET key
Cause : During measurement, even upon completion of retract block after 1st touch, wire and work
were still in touch.
Remedy : Check and clean the surface to be measured and wire feed system.
7343 APPROACH ERROR AT MEASURING Alarm 2 RESET key
Cause : During measurement, commanded movement (approach amount) was completed before
wire and work coming in touch.
Remedy : (1) Change the program or approach point.

(2) If this alarm occurs when a function key is pressed, the approach amount cannot be
changed. In this case, measure with the G codes (G76– ).
242
7344 BACK LENGTH OUT DUE TO SHORT WIRE-WORK Warning 3 W ARN RESET key
Cause : During machining, the head reversed from the front end position, exceeding the value set
to the machine parameter No. 680. The short between wire and workpiece is caused by a
deformed workpiece or dropped core.
Remedy : (1) Remove foreign matters that cause the short between wire and workpiece.
(2) If a cause is uncertain, check the set value of maximum reverse amount (machine
parameter No. 680), and contact to us of the trouble condition.
7349 EIS NONREGISTRY ALARM Alarm 3 RESET key
Description : An undefined alarm occurred in the EIS card.
Cause : Defective EIS card.
Remedy : (1) Retry operation, or turn off and on the power switch.
(2) If this alarm occurs frequently, contact to us of the trouble condition.
7800 EMM NOT CONNECTED Warning 1 W ARN RESET key
7801 EMM TIME ELAPSED ERROR Warning 1 W ARN RESET key
7802 EMM COMMAND REPLY ERROR Warning 1 W ARN RESET key
7803 EMM UNREGISTRATION ALARM Warning 1 W ARN RESET key
Cause : Defective VFD card, and ROM.
Remedy : The VFD card and ROM must be replaced. Contact to us of the trouble condition.

7900 RS232C EXECUTION Warning 3 See below
7901 COMMAND RETRY ERROR Warning 3 See below
7902 NO RESPONSE OF CONTROL COMMAND Warning 3 See below
7903 ACTION TIME OUT (P/M) Warning 3 See below
7904 NO PALLET (COMMAND STOCKER NO.) Warning 3 See below
7905 PALLET UNIT ERROR Warning 3 See below
7910 EXISTENCE OF WORK ERROR Warning 3 See below
7911 CONFIRMATION REACH Warning 3 See below
7912 UNIT NO. ERROR Warning 3 See below
7913 START COND. SATISFIED (P/M) Warning 3 See below
7914 MC RUN TIME OUT --- ---
7915 RESPONSE DATA ERROR Warning 3 See below
7916 MOVEMENT CONTINUE CANNOT BE DONE (P/M) Alarm 2 See below
7917 PALLET MAGAZINE IS IN STOP CONDITION --- ---
Description : These messages are output for the control of pallet magazine.
For detailed description of messages, see “Wire Electrical Discharge Machine Pallet
Magazine U53 PM4 InstructionManual” or “Wire Electrical Discharge Machine Pallet
Magazine U32 PM12,15,20 Instruction Manual”.
No. Name (MGH) Level Reset
10011 D PR AM CM M D PA CK AG E W R ITE E RR O R Dialog See Rem edy.

(V M C AC C ESS LIBR AR Y ER RO R )
10012 R ESP ON SE W A ITING TIM E-OU T O N N C SIDE Dialog See Rem edy.
10014 M EM O R Y PO O L FU LL Dialog See Rem edy.

10015 M EM O R Y PO O L FAILE D Dialog See Rem edy.

10016 SH AR ED EV EN T FULL Dialog See Rem edy.

10017 SH AR ED EV EN T FAILE D Dialog See Rem edy.

244
10018 AR GU M EN T ER RO R Dialog See Rem edy.

(VM C AC CES S LIB RA RY E RR O R)
10019 NC RE SO UR CE AC CE SS F AILED Dialog See Rem edy.

(VM C AC CES S LIB RA RY E RR O R)
10030 NC API C AU SE D E RR OR (C LASS LIB E RR OR ) D ialog See Remedy.
10033 US ER S PE CIFIE D B UFFE R P O INTE R IS NU LL Dialog See Rem edy.

(CLA SS LIB ER RO R )
10034 THR EA D C AN ’T S TAR T IN AS YN C P RO C (C LASS LIB ER RO R) Dialog See Rem edy.
10035 SH ARE D E VE NT B ETW E EN PR OC ES SE S CA N’T A CQ U IRE D Dialog See Rem edy.

10036 INTE RN AL R ESO U RC ES (M EM O RY , EV ENT ) CA N’T Dialog See Rem edy.

AC QU IRE D (C LAS S LIB ERR O R)
10037 ILLEG AL D ATA ARE A S IZE S PEC IFIED (C LASS LIB ER R OR ) Dialog See Rem edy.
10038 M EM O RY PO OL IN D ATA A RE A C AN ’T ACQ U IRE D Dialog See Rem edy.

10039 M EM O RY PO OL F OR SIZE STO R ING C AN’T A CQ U IRE D Dialog See Rem edy.
10042 ASY NC PR O CES SIN G THR EA D EN D TIM E-O U T Dialog See Rem edy.
10045 UN EXP EC TED W IN API E RR O R IN EV EN T W AIT ING Dialog See Rem edy.
10051 RE SO UR CE M AN AG E. N OT INITIA LIZED Dialog See Rem edy.

(NC AP I RE SPO N SE E RR O R)
10052 ILLEG AL FU NC TIO N N O . (NC AP I RE SPO N SE E RR O R) Dialog See Rem edy.
10053 FUN CT ION CLA SS IFICA TIO N O UT OF RAN G E Dialog See Rem edy.
10054 OP ER ATIO N CLAS SIFIC ATIN O UT O F R AN G E Dialog See Rem edy.

10055 M OD E ID O UT O F R AN GE (N CAP I RE SP ON SE ER RO R) Dialog See Rem edy.
10056 STA RT R EG ISTR AT ION FAILE D (N C API R ES PO NS E ER R OR ) Dialog See Rem edy.
10057 ILLEG AL M AN AG EM E NT N O . (N CAP I RE SP ON SE ER RO R) Dialog See Rem edy.
10058 RU N FU N CTIO N NO T FO U ND (NC AP I RE SPO N SE E RR O R) Dialog See Rem edy.
10059 DA TA TA BLE O F LIN K TA BLES NO T FO U ND Dialog See Rem edy.

10060 OP E M AN AG E ME NT OF LIN K T ABLE S N OT OB TAIN ED Dialog See Rem edy.


10061 R EG ISTR ATIO N FUN C TION D OE S N OT EXIS T Dialog See Rem edy.
(N CA PI R ESP O NSE ER RO R )
10062 EM P TY A RE A FO R N O TICE W A ITING N OT F OU N D Dialog See Rem edy.

10063 R EQ UE ST A LRE ADY BE ING EX EC UTE D Dialog See Rem edy.

Remedy : (1) Turn off the power switch once and then turn it on again, or press the [CONTINUE]
button.
(2) If this message is displayed frequently, please contact us after confirming the situations
where the message is given, and the message number and error value in the dialog
box.
10101 R EAD AC CE SS FAILED Guide W ARN RESET
10102 W R ITE A CC ES S FA ILED (W R ITE-P RO TE CTE D D ATA , ETC .) Guide W ARN RESET
10103 PA RA M ETE R IN JU ST ICE Guide W ARN RESET
Remedy : (1) Operate again.

(2) In case of frequent occurrence, contact us of the trouble procedure and message no.
10104 W R ITIN G E RR O R D UR ING A XIS A LLOC ATIO N Guide W ARN RESET
Cause : Rewriting operation was attempted during the axis allocation or in the manual zero return
mode.
Remedy : Retry after the axis allocation finished or manual zero return mode was cancelled.
246
10105 W RIT ING ER RO R DU RIN G AU TO M ATIC RU N Guide W ARN R ESET
Cause : Rewriting operation was attempted during automatic operation.
Remedy : Retry in the reset status after automatic operation finished.
10106 W RIT E-P RO TEC T S TATU S Guide W ARN R ESET
Cause : Rewriting operation was attempted in the write-protect status.
Remedy : Retry after the write-protect was cancelled.
10107 SET VALU E O UT OF RA NG E Guide W ARN R ESET
Cause : The set value is out of allowable range.
Remedy : Check the set value.
10109 NO TIC E PA CK ET LE NG TH ER RO R Guide W ARN R ESET


10110 ILLEG A L MO D E C OM M A ND M AS KING Guide W ARN RESET
10111 R UN M OD E N O T DE TER M INE D Y ET Guide W ARN RESET
10112 U NR EG ISTE RE D P OS ITIO N IN FO RM A TIO N ID SPE CIFIE D Guide W ARN RESET

(K EY)
Cause : (KEYCON) System error.

10113 ILLEG A L W O RK CO O RD . NO . Guide W ARN RESET
Cause : The specified work coordinate number is out of allowable range.
Remedy : Specify correct work coordinate number, and retry the operation.
Work coordinate numbers: 54 - 61
10114 ILLEG A L W O RK CO O RD . GR O UP NO . Guide W ARN RESET
Cause : The specified work coordinate group number is out of allowable range.
Remedy : Specify correct work coordinate group number, and retry the operation.
Work coordinate group numbers: 500 - 509
10115 U NR EG ISTE RE D U NIT S PE CIFIE D (K EY ) Guide W ARN RESET
10116 U NR EG ISTE RE D A CC UR AC Y S PEC IFIED (KE Y) Guide W ARN RESET

248
10117 DIS PLAY AXIS NO T FO U ND Guide W ARN R ESET
Cause : NC axis is not set.
Remedy : (1) Check the set value of parameter No.0500 "NC AXIS QUANTITY".
(2) Contact to us of the trouble condition.
10118 VALID AX IS N OT F OU N D IN SET CO O RD .CO M M AN D Guide W ARN R ESET
Cause : There is no valid axis when work coordinate and relative coordinate are set.

10119 INT P RO C ERR O R (PRT BL SW UN FIXE D) (KEY ) Guide W ARN R ESET
Cause : The JOG feedrate has not been selected yet with the portable operation panel.

10120 CA NC ELLED BY CO M M AN D S IM ILAR TO T HA T BEIN G RU N Guide W ARN R ESET

(KE Y)
10121 OP ER ATIO N MA NA G E TAB LE FO R RE QU ES T NO T FO U ND Guide W ARN R ESET

(KE Y)
10122 SET ERR O R O F R UN M O D C HA NG E O PE (KE Y) Guide W ARN R ESET
10123 SET ERR O R O F R UN M O D C HA NG E O PE (KE Y) Guide W ARN R ESET


10124 LO W FE ED DIS ABLE D A S TO UC H SEN SIN G IS EFF EC TIVE Guide W ARN RESET
Cause : An attempt to select low feedrate was made while the touch sensing is active.
Remedy : Select the touch sensing disable function, then select the low feedrate.
10125 TO U CH SEN S D ISA BLED AS TO UC H S EN S IS N O T Guide W ARN RESET

EF FEC TIVE
Cause : An attempt to select the touch sensing was made while the touch sensing disable function
is active.
Remedy : Select the touch sensing enable function, then select the touch sensing.
10126 O RIG IN RE TUR N D ISA BLED AS STE P FE ED IS O PER AT IN G Guide W ARN RESET
Cause : An attempt to select the zero return was made during the step feed.
Remedy : Select other than the step feed, then retry zero return operation.
10127 O RIG IN RE TUR N D ISA BLED AS HW IS O PE RAT ING Guide W ARN RESET
Cause : An attempt to select the zero return was made while the handwheel (optional) is operating.
Remedy : Select other than the handwheel mode, then retry zero return operation.
10128 H W IS O PT ION Guide W ARN RESET
Description : An attempt to select the handwheel (optional) was made.
250
10129 UN DE FINE D E RR O R D UR ING R UN M OD E C HA NG E Guide W ARN R ESET

RE QU ES T
10130 REQUESTED RUN MODE SETTING FAILURE Guide WARN RESET

10131 RE QU ES TED RU N M O D E C HAN G E FA ILED Guide W ARN R ESET
Cause : Changeover of operation mode failed.

10132 RU N M O D E CH AN G E TIM E -OU T Guide W ARN R ESET
Cause : The operation mode could not be changed over within the specified time.

10133 ILLEG AL W R ITE D ES T C OO R D ID (KE Y) Guide W ARN R ESET
10134 ILLEG AL R EAD M O DA L VALU E Guide W ARN R ESET
10135 ILLEG AL R EAD M O DA L ID Guide W ARN R ESET
10136 ILLEG AL IN TER RU PT R EQ U EST DES IG NA TION ID (KEY ) Guide W ARN R ESET
10137 ILLEG AL IN TER RU PT C HA NG E REQ U ES T SET (KE Y) Guide W ARN R ESET
10138 ILLEG AL IN TER RU PT M O D E D UR ING R UN (KE Y) Guide W ARN R ESET
10139 OP ER ATIO N STAT US UN DE FINE D E RR OR (K EY) Guide W ARN R ESET


10141 1 U SER RE FER EN CE RE SO UR CE (R EF) Guide W ARN RESET
10142 U ND EFIN ED RE SO UR CE ID S PEC IFIE D (R EF) Guide W ARN RESET
10143 C ON STA NT UPD AT E AR EA FULL (R EF ) Guide W ARN RESET
10144 ILLEG A L END SP EC IFYIN G RES O UR CE ID (R EF) Guide W ARN RESET
10145 EN D SPE CIFY ING R ESO U RC E A LREA DY FINIS HE D (R EF ) Guide W ARN RESET
10146 AR EA INTE RLO C K ER R OR O CC UR RE D (R EF ) Guide W ARN RESET
10147 N O R ES OU R CE A CC ES S R IGH T (R EF) Guide W ARN RESET
10148 U ND EFIN ED ER RO R OC CU RR ED (R EF) Guide W ARN RESET
Cause : (REFRESH) System error.

10150 SP EC IFIED PA RAM E TER NO . N O T FO UN D Guide W ARN RESET
Cause : A number not entered was specified.
10151 ILLEG A L UN IT CO M M AN D Guide W ARN RESET
Cause : The specified axis command is incorrect.
252
10152 UC NV CO NV ER SIO N R ES ULT U N FIXE D Guide W ARN R ESET
Cause : (SET) System error.

10153 ILLEG AL R EW R ITIN G S PEC IFIE D Guide W ARN R ESET
Cause : The specified parameter value setting method is wrong.

10154 UN DE FINE D E RR O R (S ET) Guide W ARN R ESET

10156 OF FSET RE SO UR CE AC CE SS E RR O R (S ET) Guide W ARN R ESET
Cause : Offset data writing failed.


10157 ILLEG A L OFF SET RES O UR CE CO M M AN D ID (SE T) Guide W ARN RESET

10158 ILLEG A L OFF SSE T NO . R AN GE Guide W ARN RESET
Cause : The specified offset number is out of allowable range.
Remedy : (1) Check the offset number, and retry.

10159 ILLEG A L OFF SSE T NO . R AN GE Guide W ARN RESET
Cause : The specified work offset group number is out of allowable range.
Remedy : (1) Check the work offset group number, and retry.
10160 U NIT A ND AX IS ATT RIB UTE INC ON SIS TEN T Guide W ARN RESET
Cause : The axis attribute and unit for the specified offset are inconsistent.

254
10161 W RIT E-P RO TEC TE D O FFS ET SP EC IFIED Guide W ARN R ESET
Cause : An attempt to rewrite the write-protected center offset was made.
Remedy : (1) Check the contents of operation.

10162 TO OL W OR K U NR EG IST RA TION ER R OR (SE T) Guide W ARN R ESET

10164 ALAR M M AN AG EM E NT U NR EG IST RA TION ER RO R (D GN ) Guide W ARN R ESET
Cause : (DGN) System error.

10166 DIS CR ETE W RIT ING FAILE D Guide W ARN R ESET
Cause : Discrete data writing failed.


10167 IN VALID BE CA USE O F O PTIO N Guide W ARN RESET
Description : The function button for an optional specification is operated.

The optional function is not provided.
10168 IN VALID FO R M O D E O THE R T HAN M AN UA L Guide W ARN RESET
Cause : The function valid only in MANUAL mode was operated.
Remedy : Change to MANUAL mode and then, operate again.
No. Name (MGH) Leve Reset
10169 IN VALID STA RT STAT US Guide W ARN RESET
Cause : An attempt to operate the function, which is only valid when the START lamp is off, was
made.
Remedy : STOP or RESET mode and then, operate again.
10170 IN VALID FO R M O D E O THE R T HAN M AN UA L AN D R ES ET Guide W ARN RESET
Cause : The function valid only in MANUAL mode and under reset state was operated.
Remedy : Reset and change to MANUAL mode and then, operate again.
10171 TH E FU NC TIO N K EY DEP RE SS ED IS INV ALID Guide W ARN RESET
Cause : An attempt to operate the function was made while the axis allocation is under way, manual
zero return mode is active, or the program is being executed or started.
Remedy : Retry after the axis allocation finished, manual zero return mode was cancelled, or in the
stop or reset status.
256
10172 DU M M Y SIG N AL IS IN VA LID Guide W ARN R ESET
10173 INP UT S IGN AL IS INV ALID Guide W ARN R ESET
10174 FUN CT ION SW ITC H M A NA GE M EN T ID O UT O F RA NG E (N CF) Guide W ARN R ESET
10175 I/O M A NA GE M EN T UN RE G ISTR ATIO N ERR O R (N C F) Guide W ARN R ESET
Cause : (NCFUNC) System error.

10177 PR OG R AM RU N M ANA G EM EN T U NR EG ISTR ATIO N ER RO R Guide W ARN R ESET

(AU T)
Cause : (AUTOMAN) System error.

10179 M ACR O RE SO UR C E M AN AG EM E NT U NR EG IST RA TIO N Guide W ARN R ESET

ER RO R (EXE )
Cause : (EXEPRG) System error.

10185 DO UB LE B OO KIN G ER RO R Guide W ARN R ESET


10187 U NIT C O NV ERS IO N P RO CE SS ING ER RO R (CN D) Guide W ARN RESET
10188 ILLEG A L ELEM E NT N O . SELE CTE D (CN D) Guide W ARN RESET
10189 G ET E LEM EN T SP EC IFIED W ITH PU T (C ND ) Guide W ARN RESET
10191 ILLEG A L NO TIC E W A ITING ITE M SELE CTE D (CN D) Guide W ARN RESET
Cause : (COND) System error.

10192 M O DE L DR AW IN G DIS ABLE D (CN D) Guide W ARN RESET
10193 M O DE L DR AW IN G CH AN G E D ISAB LED (CN D) Guide W ARN RESET
10194 ILLEG A L MO D EL D RA W IN G A XIS C O M M AN D (C ND ) Guide W ARN RESET
10195 ILLEG A L MO D EL D RA W IN G C YC LE (C ND ) Guide W ARN RESET

10196 M O DE L DR AW IN G DA TA N O T FO UN D (C N D) Guide W ARN RESET
Description : There is no drawing data on the MODEL MONITOR screen.
10197 M O DE L DR AW IN G INV ALID (CN D) Guide W ARN RESET
Description : The drawing on the MODEL MONITOR screen is invalid.
258
10198 OR BITIN G RA DIU S R EAD IN G E RR O R (C ND ) Guide W ARN R ESET
Cause : Reading of radius for pattern operation failed.

10199 IES FU N CTIO N ON SW ITCH ING D ISA BLED (C ND ) Guide W ARN R ESET
Cause : An attempt to turn on the IES function by manual operation was made.
Remedy : To enable the IES function by manual operation, turn on the bit 6 of parameter No.0046
"MC COND. FUNCTION SELECT 2", then retry.
10200 IES R EQ U EST D EC O DIN G TAB LE ER RO R (CN D ) Guide W ARN R ESET
10201 CO M M AN D C O NTR O L TAB LE DE CO D ING ER RO R (C ND ) Guide W ARN R ESET
Cause : COND) System error.

10202 SPE CIFIE D M O D EL D ATA N O . O UT O F R AN GE Guide W ARN R ESET
Cause : The specified model data number is out of allowable range.
Remedy : Check the entered value.

Model data numbers: 0 - 99

10203 ST AN DAR D CO ND ITIO N R EW RITIN G DIS ABLE D (C N D) Guide W ARN RESET
Cause : An attempt to rewrite the write-protected machining conditions or model data was made.
10204 ILLEG A L CO M M EN T RE W R ITING PO S ITIO N Guide W ARN RESET
Cause : The writing position of a comment for model data is wrong.

10205 U ND EFIN ED ER RO R (CN D) Guide W ARN RESET
Cause : (COND)System error.

10211 ILLEG A L INTE RN AL R ESO U RC E ID Guide W ARN RESET
10212 SP EC IFIED RE SO UR C E AR EA FULL Guide W ARN RESET
Cause : (MODEL) System error.

260
10213 SPE CIFIE D V AR IABLE NO . N OT FOU N D Guide W ARN R ESET
Cause : The specified macro variable number is not found.
10214 SPE CIFIE D V AR IABLE NO . O UT OF R AN G E Guide W ARN R ESET
Cause : The specified macro variable number is out of allowable range.
10215 ILLEG AL C OM M A ND ID S PEC IFIE D (M D L) Guide W ARN R ESET
10216 ILLEG AL R ESO U RC E ID SPE CIF IED (M DL) Guide W ARN R ESET

10217 INP UT V ALU E O UT O F R AN G E (M D L) Guide W ARN R ESET
Cause : The entered value is out of allowable range.
Remedy : Check the entered value, and retry.

Range: -99999999 to 99999999

10218 IN PU T VALU E D ES IGN AT ION ER RO R (M DL) Guide W ARN RESET
Cause : Incorrect command was specified.
Remedy : Check the specified command value, and retry.
10219 ILLEG A L CO M M AN D S PEC IFIED (M D L) Guide W ARN RESET

10220 IN TER LOC K E RR O R A UTO R UN EXE CU TIN G Guide W ARN RESET
Cause : An attempt to rewrite the setup simple macro data was made during automatic operation.
Remedy : Retry in the reset status.
10221 IN TER LOC K E RR O R A XIS M O VIN G Guide W ARN RESET
Cause : An attempt to rewrite the setup simple macro data was made while the axis is moving.
Remedy : Retry after the axis movement finished.
10222 ILLEG A L TABLE DA TA R EQ U ESTE D (MD L) Guide W ARN RESET
10223 U ND EFIN ED ER RO R (M DL) Guide W ARN RESET
Cause : (MODEL)System error.

262
10224 NC AN SW E R E RR O R Guide W ARN R ESET

(Option)
Cause : The online condition is not established.

10225 IM C C OM M U NIC ATIO N LO G A CQ ST ART PO S O UT OF Guide W ARN R ESET

RA NG E
(Option)
Cause : The IMC communication log cannot be read.

10226 FM S IN OF F-LINE M OD E Guide W ARN R ESET

(Option)
Cause : The IMC related operation was made in the offline mode.
Remedy : Retry in the online mode.
10227 M ACH IN ING CA NN O T FIN ISH Guide W ARN R ESET

(Option)
Cause : An attempt to finish the machining was made though the IMC command does not start the
machining.
Remedy : Retry after the machining has started.

10228 C OM M U NIC ATIO N M OD E C HA NG E ABLE ON LY IN FM S Guide W ARN RESET

O FF-LIN E
(Option)
Cause : An attempt to change the baud rate was made in other than offline mode.
Remedy : Retry in the offline mode.
10236 AS SIS TAN CE FUN CT ION UN D EFIN ED ERR O R (MC F) Guide W ARN RESET
Cause : (MCFUNC) System error.

10238 N OT RES ET Guide W ARN RESET
Cause : An attempt to enter O or N number was made during the memory run.
Remedy : Change the O or N number in the reset status.
10239 PLE AS E SP EC IFY O NO . O R N N O. Guide W ARN RESET
Cause : Only O or N address was specified without number, and the ENTER key was pressed.
10255 M O DE L BLO CK LEN GT H TO O SH O RT Guide W ARN RESET
Cause : The model block length is not enough.
Remedy : Check the model block length.

Range: 5 - 255
264
10256 M OD EL B LOC K LE NG TH OV ER Guide W ARN R ESET
Cause : The model block length is out of allowable range.
Remedy : Check the model block length.

Range: 5 - 255
10257 M OD EL B LOC K C HE CK ING Guide W ARN R ESET

10258 NO T M O DE L G B LO CK (M DL) Guide W ARN R ESET
Cause : The specified block does not contain G code.
Remedy : Correct the block data.
10259 ILLEG AL G CO D E SP EC IFIED (M D L) Guide W ARN R ESET
Cause : The specified block cannot be converted into the model plan.

G code : 100~137
Address code : A~Z

10260 N ON E B LOC K E ND CO D E (;)(M DL) Guide W ARN RESET
Cause : There is no ";" (EOB) in the block.
10261 VM C INT ER NAL D AT A VA RIA TIO N D ETE CTE D (M D L) Guide W ARN RESET

10263 ILLEG A L REA D S YS TEM (M D L) Guide W ARN RESET
10264 ILLEG A L REA D S PE CIFY ING PA CK ET LEN G TH (M DL) Guide W ARN RESET
10265 N UM BE R O F R EA D LIN ES S PE CIFIE D TO 0 (M D L) Guide W ARN RESET
10266 R EAD LINE CLE AR ED (M DL) Guide W ARN RESET
10267 N UM BE R O F R EA D LIN ES IS 0 (M DL) Guide W ARN RESET
10268 EF FEC TIVE LINE D AT A N OT F OU ND (M D L) Guide W ARN RESET

10269 O NU M BE R O UT OF RAN G E Guide W ARN RESET
Cause : The specified O number is out of allowable range (presetting).
Remedy : Specify the O number in a range of 1 to 14999.
266
10270 SEQ U EN TIAL R EAD FIN ISH ED (M DL) Guide W ARN R ESET
10271 RA ND OM R EA D P OS ITIO N O UT OF RA NG E (M D L) Guide W ARN R ESET

10272 M OD EL C O MP ILE O PE N E RR O R Guide W ARN R ESET
10273 M OD EL C O MP ILE M A CR O E RR O R Guide W ARN R ESET
10274 NO T C OM P ILE M O DE L Guide W ARN R ESET
10275 NO T C ON FIR M M OD EL S ET Guide W ARN R ESET

10400 BU TTO N A T SELE CT ED P O SITIO N IS INV ALID NO W Guide W ARN R ESET
Cause : In the SPARK COND. ADJ. view on the CONDITION screen, the jump adjustment was
attempted though the jump item is not selected or the bar chart is not activated.
Remedy : Select either jump amount, jump cycle, or jump speed, and then retry.
10401 JU M P M A NU AL C HA NG E P RO HIB ITED Guide W ARN R ESET
Cause : The jump manual change is prohibited, if the second digit of L code in the G76 command
block is set to "1". Under this condition, the operation of function buttons and the change of
jump amount, jump cycle, and jump speed with [←], [→] keys are disabled (program
preferential protect function).
Remedy : Execute G76L0*; to reset the "JUMP MANUAL CHANGE PROHIBITED".

10402 KE Y-IN LINE IS E MP TY O R IM PR OP ER Guide W ARN RESET
Cause : The key-in line is empty, or the out-of-range data was entered.
Remedy : Correct the input data.
10403 ILLEG A L ID D ETE CTE D IN EXE CU TE C O ND ITIO N Guide W ARN RESET

(A PPLI. E RR O R)
Cause : Undefined execution condition was specified.

10404 ILLEG A L ID D ETE CTE D IN EXE CU TE C O ND ITIO N Guide W ARN RESET

(A PPLI. E RR O R)

10405 D OC UM E NT C LAS S S ETU P FA ILE (AP PLI. E RR OR ) Guide W ARN RESET
Cause : The undefined jump command was specified. Or, the jump command was specified when
setting the execution condition.

268
10406 AT P RES EN T, CO O R DIN ATE S NO T D ISP LAYE D Guide W ARN R ESET
Cause : The COORDINATE CHANGE button was pressed though no coordinates are displayed in
the COORD. DIS view on the CONDITION screen.

10407 EXE CU TE C O ND ITIO N S CR EEN C LOS ED Guide W ARN R ESET
Cause : The CONDITION ADJ buttons or CURRENT DISPLAY button was pressed though the
MAIN view is not displayed on the CONDITION screen.

10408 UN NE CE SSA RY W O RD EX ISTS IN JUM P CO M M AN D Guide W ARN R ESET
Cause : An unnecessary word (alphabet) is contained in the G76 command block.
10409 NE CES SA RY W O RD DO ES NO T E XIST IN JUM P CO M M AN D Guide W ARN R ESET
Cause : The necessary words in combination (alphabet) are missing in the G76 command block. Be
sure to input the words which is not omissible in the intermittent jump function.

10410 JUM P CO M M AN D V ALU E IS IM P RO PE R Guide W ARN RESET
Cause : The set value that is not permitted is commanded in the G76 command block.
10411 JUM P CO M M AN D V ALU E IS T OO SM A LL Guide W ARN RESET
Cause : In the G76 command block, a smaller value than allowable range was specified.
10412 JUM P CO M M AN D V ALU E IS T OO LAR G E Guide W ARN RESET
Cause : In the G76 command block, a larger value than allowable range was specified.
10413 JUM P AM O UN T TA P 17 IS IN VA LID Guide W ARN RESET
Cause : In the G76 command block, the TAP 17 was specified.
10414 ILLEG A L MA CH ININ G CO N DITIO N SPE CIF IED Guide W ARN RESET
Description : Though the specified E number exists, either condition element value of that E number is
out of the allowable range.
Cause : (1) Illegal E number was specified.
(2) All element values are cleared to 0, or E number in which illegal value is set to even one
element was specified.
Remedy : Check the specified value, or review the machining conditions.
270
10415 SPE CIFIE D C O ND ITIO N C O M MA ND O UT O F R AN G E Guide W ARN R ESET
Cause : The value out of allowable range was entered when the condition element was changed.
10416 SPE CIFIE D C O ND ITIO N IS OP TIO NA L Guide W ARN R ESET
Cause : The machining condition (E number) requiring optional specifications such as power up
type (60A), booster (optional for the power exceeding 120A), or tungsten carbide machining
circuit was specified.
Remedy : Check the command value or E number.
10417 SPE CIFIE D V ALU E IS IN TER LO CK ER RO R Guide W ARN R ESET
Cause : The machining conditions are checked before output to prevent the overload on hardware
(such as PC boards) due to combined condition elements. This pre-check detected an
error.
Remedy : Correct the machining condition.
10418 DO UB LE C O ND ITIO N AD JUS TING C O MM A ND S P RO H IBITED Guide W ARN R ESET
Cause : One or more items were adjusted in the SPARK COND. ADJ view on the CONDITION
screen.
Remedy : Operate again.

10419 SP EC IFIC E IO NO . NO T F OU ND Guide W ARN RESET
Cause : (1) On the DIAGN EIO screen, the [EIO] F button was pressed without specifying a
number.
(2) The [EIO] F button were pressed specifying a number other than registered ones.
10420 ILLEG A L SPE CIFIC AD DR ES S VA LUE Guide W ARN RESET
Cause : On the DIAGN MEMORY screen, the entered address value (VMC memory location) is
incorrect.
Remedy : Re-enter correct address value.
10421 SP EC IFIED PA RAM E TER NO . N O T FO UN D Guide W ARN RESET
Cause : On the PARAMETER screen, unregistered number was specified and the [SEARCH]
button was pressed.
10422 ILLEG A L NU M ERIC O N K EY-IN LIN E Guide W ARN RESET
Description : The data entered on the key-in line was out of the numeric range of data value in the
specified entry.
272
10423 ILLEG AL D ATA ON KE Y-IN LINE Guide W ARN R ESET
Cause: The data entered on the key-in line was out of range.
Remedy: Check the entered command.
10426 INP UT O PE RA TIO N D ISAB LED Guide W ARN R ESET
Cause : The ENTER key was pressed for the item to which the input operation is disabled.
10448 SELE CT M A NU AL R UN M O DE Guide W ARN R ESET

(Option)
Cause : An attempt to operate the pallet change was made on the IMC screen in other than the
MANUAL RUN mode.
Remedy : Select the MANUAL RUN mode, then retry.
10450 M OD E C AN NO T B E CH AN G ED DU RIN G RO TAT ION Guide W ARN R ESET

(Option)
Cause : An attempt to change the mode was made during the rotation of MA/MR head.
Remedy : Select the ROTATE STOP, then retry.
10451 SELE CT R O TATIO N M OD E Guide W ARN R ESET

(Option)
Cause : On the MA/MR screen, an attempt to perform the ROTATE START or ROTATE STOP was
made, though the ROTATE MODE has not been selected.
Remedy : Select the ROTATE STOP, then retry.

10453 LIN E M O DE IS R EM O TE Guide W ARN RESET

(Option)
Causes : The program input/output operation was performed when the IMC mode is REMOTE mode.
Remedy : Change over the IMC mode to the LOCAL mode, and retry.
10454 LIN E M O DE IS LO CA L Guide W ARN RESET

(Option)
Cause : On the MACH OPE, IMC screen, the function key for machining completion (IMC control
screen) or pseudo completion (IMC maintenance screen) was pressed when IMC mode is
local mode.
Remedy : Change the IMC mode from LOCAL to REMOTE, and retry operation.
10455 M AN UA L PR O GR AM IN PU T FR OM H O ST IS D ISA BLED Guide W ARN RESET

(Option)
Causes : (1) In the IMC REMOTE mode, an attempt to input a program from the host computer was
made.
(2) The specified O No. already exists in NC unit.
Remedy : (1) Change IMC mode to LOCAL, and retry operation.

(2) Delete specified O No., if unnecessary, then retry operation.
10456 M AN UA L PR O GR AM O UT PU T TO HO ST IS DIS AB LED Guide W ARN RESET

(Option)
Cause : The O No. to be output is not found in NC unit.
Remedy : Change O No. to be output, then retry operation.
274
No. Name(MGH) Level Reset
10458 LIEN IS NO T IN O N-LIN E M O D E Guide W ARN R ESET

(Option)
Cause : In the off-line status, a function button on IMC control screen or IMC maintenance screen
was operated.
Remedy : Set up on-line status, then retry operation.
10459 CO M M UN ICA TIO N R E-S ETTA BLE ON LY IN O FF-LIN E M O DE Guide W ARN R ESET
(Option)
Cause : In the on-line status, communication conditions to host computer were changed.
Remedy : Change communication conditions in the off-line status.
10467 CO M M AN D C AN NO T B E SE T AT P RE SE NT Guide W ARN R ESET

(Option)
Cause : The function buttons for pseudo completion on IMC maintenance screen were pressed
simultaneously.
Remedy : Press either one of function buttons for pseudo completion.
10468 PR ESS M A CH ININ G C O M PLET E OR M ACH IN ING ABO R T KEY Guide W ARN R ESET
(Option)
Description : This message is displayed to ask for next operation when a function button for pseudo
completion on the IMC maintenance screen is pressed.
Press COMPLETE or ABORT button to select successful or unsuccessful pseudo
completion.

10470 ILLEGAL WORK OFFSET GROUP SPECIFIED Guide WARN RESET
Cause : On the ELECT. BASE OFFSET screen or ELECT. OFFSET screen, the work offset group
number out of allowable range was specified.
Remedy : Check the work offset group number.
10471 ILLEGAL WORK OFFSET NO. SPECIFIED Guide WARN RESET
Cause : On the ELECT. BASE OFFSET screen or ELECT. OFFSET screen, the work offset number
out of allowable range was specified.
Remedy : Check the work offset number.
10472 ILLEGAL OFFSET VALUE SPECIFIED Guide WARN RESET
Cause : On the WORK OFFSET screen, ELECT. BASE OFFSET screen, or ELECT. OFFSET
screen, the offset value out of allowable range was specified.
Remedy : Check the offset value.

10491 SPECIFIED VARIABLE No. NOT FOUND Guide WARN RESET
Cause : On the MACRO DATA screen, specify the macro variable No. other than The user specified
No. was specified and the SEARCH button was pressed.
Remedy : Input command error.
276
10492 ILLEGAL NUMERIC ON KEY-IN LINE Guide WARN RESET
Cause : Numeric value on the key-in line is out of allowable range.
10493 ILLEGAL DATA ON KEY-IN LINE Guide WARN RESET
Cause : On the MACRO DATA screen, wrong data was entered and then the ENTER key was
pressed.
Remedy : Check the entered command.
10494 THERE IS NO PAGE TO BE DISPLAYED Guide WARN RESET
Cause : In a mode with two or more pages, there was no more pages when pages are turned by
PAGE UP or PAGE DOWN key.
Remedy : If this message appears when PAGE UP key is used, use PAGE DOWN key to turn pages.
If this message appears when PAGE DOWN key is used, use PAGE UP key to turn pages.
10500 ALREADY EXIST, NOT REGISTRABLE Guide WARN RESET
Cause : Entry of the same O No. as one already entered on the EDIT•LIST screen was attempted.
Remedy : Select O No. not in use.
10501 SPECIFIED PROGRAM NOT FOUND Guide WARN RESET
Cause : On the EDIT•LIST screen, O No. not entered was specified and then the ERASE button
was pressed.
Remedy : Check the O No. and N No.

10502 C UR RE NT P RO G RA M CA NN OT BE D ELE TED Guide W ARN RESET
Cause : O No. at execution was attempted to delete on the EDIT•LIST screen.
Remedy : Reset and then restart.
10503 C UR RE NT P RO G RA M CA NN OT BE E DITE D Guide W ARN RESET
Cause : In the BLOCK view on the EDIT•PRG FILE screen, an attempt to edit the program that is
running was made.
Remedy : To edit the current program, perform in the reset status.
10504 D ATA IN KE Y-IN AR EA ER RO NE O US Guide W ARN RESET
Cause : In the BLOCK view on the EDIT•PRG FILE screen, the O number on the key-in line is wrong
during the PROGRAM COPY mode.
Remedy : Check the O number on the key-in line.
10505 ILLEG A L PRO G R AM NO . S PEC IFIED Guide W ARN RESET
Cause : (1) In the LIST view on the EDIT•PRG FILE screen, the O number out of range was
specified and then the [DELETE] button was pressed.
(2) On the EDIT•DISK screen, the O number registered to the NC is wrong. (Not used)
Remedy : (1) Specify the O number in allowable range.

O numbers: 0 - 14999
(2) Check the O number to be registered to the NC. (Not used)
278
10506 SEA RC H Guide W ARN R ESET
Cause : In the BLOCK view on the EDIT•PRG FILE screen, [CHARACTER SEARCH] or [ERROR
SEARCH] operation is under way.
10507 KEY IN P RO G RA M NO . Guide W ARN R ESET
Cause : In the LIST view on the EDIT•PRG FILE screen, the [NEW FILE] button was pressed
without entering O number.
Remedy : Enter the O number in the key-in line, then press the function button.
10508 NU M BER O F FILES O VER FLO W Guide W ARN R ESET
Description : Program No. can be registered to any number from O No. of 1 to 9999 but not all of these
numbers can be used.
Total 3000 numbers are available for registration.
Cause : More than available numbers were used.
Remedy : Delete unnecessary program No.
10509 M EM O RY OV ER -FLO W Guide W ARN R ESET
Description : The memory becomes full during the program input or manual input.
Remedy : Delete unnecessary programs for too many programs.

The program up to the canceled point has been stored.
Check the program content. (Especially when canceled halfway of the program, pay
attention.)

10510 PLE AS E W A IT FO R P RO G RA M CLO SE EN D Guide W ARN RESET
Description : This message is displayed while closing the edited program.

Moreover, the program is checked.
10511 PLE AS E W A IT FO R P RO G RA M DE LETE E ND Guide W ARN RESET
Description : The message shows that on the EDIT•LIST screen, O No. was specified and the program
is being deleted.
10512 TR AN SFE RR ING PR O GR AM Guide W ARN RESET
Cause : On the EDIT•DISK screen, this message is displayed during the transfer of a program.
10513 PR O G RAM T RAN SF ER F INIS HE D Guide W ARN RESET
Cause : On the EDIT•DISK screen, this message is displayed when the program transfer finished.
10514 ED ITE D PR O G RAM IS NO T S AVE D Guide W ARN RESET
Cause : On the EDIT•PRG FILE screen, the [FILE DESTRUCT] button was pressed.
Unused.
10515 PR O G RAM O P EN Guide W ARN RESET
Cause : The program in RAM is open.

Unused.
280
10516 CA N’T BE CH AN G ED D U RIN G P RO G RA M ED ITING Guide W ARN R ESET
Cause : An attempt to change the page was made during the program editing.
Remedy : Retry after the program editing finished.

Unused.
10517 SELE CT N C PRO G R AM Guide W ARN R ESET
Cause : In the LIST view on the EDIT•PRG FILE screen, the [FILE OUTPUT] button was pressed
without specifying O number.
Remedy : Enter the O number in the key-in line, and press the [FILE OUTPUT] button.
Unused.
10518 EN DED SE AR CH Guide W ARN R ESET
Cause : In the LIST view on the EDIT•PRG FILE screen, O number or comment search finished.
10519 SELE CT P RO G RA M TO BE T RA NSF ER RED Guide W ARN R ESET
Cause : On the EDIT•DISK screen, the [FILE SEND] button was pressed without specifying the
program.
Remedy : Specify the program to be transferred, then press the function button.
Unused.
10520 SAM E NA M E PR O GR AM E XIST S. DE LETE IT AN D R ETR Y Guide W ARN R ESET
Cause : On the EDIT•DISK screen, the file of same name exists at the destination of transfer.
Remedy : Change the file name at the destination, or delete the file at the destination and retry.
Unused.

10521 PR O G RAM T RAN SF ER C AN C ELLED Guide W ARN RESET
Cause : On the EDIT•DISK screen, the [CANCEL] button was pressed during the program transfer.
Unused.
10522 C HA RAC TE RS IN R EG ISTE RE D BLO C K TO O LO NG Guide W ARN RESET
Cause : One block entered in the key-in line exceeds 190 characters.
Remedy : The data up to 190 characters are registered. Note that the data exceeding 190 characters
are cleared.
10523 C HA RAC TE RS O N KE Y-IN LINE TOO LO N G Guide W ARN RESET
Cause : The number of characters entered in the key-in line exceeds the limit.
Remedy : The upper limit of the key-in line is 760 characters. Note that the data exceeding 760
characters are cleared.
10524 ER R OR O CC UR RE D D UR IN G P RO G RA M TRA NS FER Guide W ARN RESET
Cause : An error occurred during the program transfer.
Remedy : Check the contents of operation, and retry.
10540 C ON NE CT THE NE TW O RK Guide W ARN RESET
Cause : The machine is being connected to the network. The message will disappear when the
connection has completed.
Unused.
282
10541 CA N N OT FUN D N ETW O RK N AM E Guide W ARN R ESET
Cause : The network name to be connected is not found.
Remedy : Check the network path setting. (Not used at present)

Unused.
10542 THIS FUN CT ION N OT S UP PO RT ED Guide W ARN R ESET
Cause : An attempt to operate the function not supported was made on the EDIT screen.
Remedy : Check the contents of operation.
10550 (JUM P) EN TER LINE N O . FO R JU M P [↑]:TO P, [↓]:LA ST Guide W ARN R ESET
Cause : In the BLOCK view on the EDIT•PRG FILE screen, the JUMP mode is active.
To perform the jump, enter the line number in the key-in line.
Or, move to the top with [↑] key, or last with [↓] key.
10551 JU M P Guide W ARN R ESET
Cause : The line number is being searched in the JUMP mode.
10553 (SR CH ) EN TER CH AR A FO R SE AR CH [↑] [↓] FO R UP & D O W N Guide W ARN R ESET
Cause : In the BLOCK view on the EDIT•PRG FILE screen, the CHARACTER SEARCH mode is
active.
Enter the characters to be searched in the key-in line, and then start upward search with [↑]
key, or downward search with [↓] key.

10554 SP EC IFIED CH AR AC TER STR IN G N O T FO UN D Guide W ARN RESET
Cause : In the BLOCK view on the EDIT•PRG FILE screen, the specified character string is not
found in the CHARACTER SEARCH mode.
10556 (E RR OR SR CH ) [↑] [↓] K EY S FO R U P & DO W N SE AR CH Guide W ARN RESET
Cause : In the BLOCK view on the EDIT•PRG FILE screen, the ERROR SEARCH mode is active.
Perform the upward error search with [↑] key, or downward error search with [↓] key.
10557 ALA RM B LOC K IS NO T FO U ND O UT Guide W ARN RESET
Cause : In the BLOCK view on the EDIT•PRG FILE screen, an alarm block is not found in the
ERROR SEARCH mode.
10560 (P RO G RA M CO PY ) EN TER PR O GR AM (O N O.) TO B E Guide W ARN RESET

IN SER TED
Cause : In the BLOCK view on the EDIT•PRG FILE screen, the PROGRAM COPY mode is active.
Enter the O number in the key-in line.
10561 PR O G RAM C O PY Guide W ARN RESET
Cause : In the BLOCK view on the EDIT•PRG FILE screen, the program copy is under way.
10562 EN D ED C O PY Guide W ARN RESET
Cause : The program copy finished.
284
10565 (BLO CK ) SP EC IFY A RA NG E. P RE SS [S ELEC T] TO C ANC EL Guide W ARN R ESET
Cause : In the BLOCK view on the EDIT•PRG FILE screen, the SELECT mode is active.
Specify the range (blue highlighting) with [↑] [↓] keys or by touching directly the desired
block, and then press the [COPY] or [DELETE] button. Or, press the [SELECT] button to
cancel the SELECT mode.
10566 NO BLO C K IS S ELEC TE D Guide W ARN R ESET
Cause : The [COPY] or [DELETE] button was pressed without selecting the block.
Remedy : Select the block.
10567 CA N’T BE US ED DU RIN G SELE CTIO N Guide W ARN R ESET
Cause : The [PASTE] button was pressed in the SELECT mode.
Remedy : Specify the range and press the [COPY] button, then press the [PASTE] button.
10570 ILLEG AL N UM BE R O F D IG ITS O N KEY -IN LIN E Guide W ARN R ESET
Cause : The number of digits on the key-in line is out of allowable range.
Remedy : Change the number of digits on the key-in line.
10571 ILLEG AL N UM ER IC ON KE Y-IN LINE Guide W ARN R ESET
Cause : Numeric value on the key-in line is out of allowable range.
Remedy : Change the numeric value on the key-in line.

10572 M O DE L BLO CK AD DE D Guide W ARN RESET
Description : On the EDIT•MODEL screen, a block was added.
10573 M O DE L BLO CK AD DE D Guide W ARN RESET
Description : On the EDIT•MODEL screen, a block was changed.
10574 M O DE L BLO CK DE LETE Guide W ARN RESET
Description : On the EDIT•MODEL screen, a block was deleted.
10575 M O DE L BR OO K CAN ’T BE CO N VER T TO CO N VE RS ATIO N Guide W ARN RESET
Description : On MDI RUN screen and EDIT screen, when the MODEL button key is pushed, it is block
cannot be changed to model plan.
10576 N O M O D EL BLO C K Guide W ARN RESET
Description : There is no model block to be searched for or deleted when the previous or next block is
searched on the model screen, or block delete is conducted.
10577 C ON VE RS ATIO NA L INP UT E RR O R IN M O DEL B LO CK Guide W ARN RESET
Cause : The message appears when in a model screen block add or block change are pushed, and
the * mark item in the conversation item displays a message is blank.
Input the * mark item.
286
10578 ON LY IN ITIAL S ET M O D E IS E FFEC TIVE Guide W ARN R ESET
Cause : On the EDIT•MODEL screen, the [INITIAL DELETE] button or[INITIAL REGISTER] button
was pressed though the INITIAL SET mode is not active.
Remedy : Retry after the INITIAL SET mode is activated.
10579 CA NN OT BE U SE D IN TO INITIA L SET M OD E Guide W ARN R ESET
Cause : On the EDIT•MODEL screen, the [BLOCK DELETE], [BLOCK RENEW], or [BLOCK ADD]
button was pressed when the INITIAL SET mode is active.
Remedy : Deactivate the INITIAL SET mode, and then retry.
10590 US E PO R TAB LE O PER ATIO N PA NEL T O C H ANG E FEED R A Guide W ARN R ESET
Cause : The feedrate cannot be changed over on the RUN.MANUL screen. To change the feedrate,
use the portable operation panel.
10591 CA N N OT MD I-C AN CE L Guide W ARN R ESET
Cause : The [MDI-CANCEL] button was pressed when the MDI RUN is not in stop status.
Remedy : Retry after the MDI RUN has stopped.
10592 CA N N OT RE-ED IT Guide W ARN R ESET
Cause : The [RE-EDIT] button was pressed when the MDI RUN editing is disabled.
Remedy : Retry when the MDI RUN editing is enabled.

10593 R EED ITED PR O GR AM R EA DIN G F AILED Guide W ARN RESET
Cause : The re-edited program file for the MDI RUN may not be created yet.
10594 R EED ITIN G M A Y BE DIS ABLE D Guide W ARN RESET
Cause : The re-edited program file may not be saved during the editing of the MDI RUN program.
10610 D IAG NO ST IC IN FO RM AT ION W R ITIN G TO E XT FILE Guide W ARN RESET
10611 R EG ISTR Y W RITIN G FRO M EX TER NA L FILE Guide W ARN RESET
10612 R EG ISTR Y R EA DIN G F RO M EX TER NA L FILE Guide W ARN RESET
10613 D ETA IL S ET D ATA W R ITING TO E XTER N AL FILE Guide W ARN RESET
10614 D ETA IL S ET D ATA RE AD ING TO EX TER NA L FILE Guide W ARN RESET
10615 FILE W RIT ING SU CC EE DE D Guide W ARN RESET
10616 FILE W RIT ING FAILE D Guide W ARN RESET
10617 FILE REA DIN G SU CC EE DED Guide W ARN RESET
10618 FILE REA DIN G FAILE D Guide W ARN RESET
Cause : The message is displayed when the function buttons for maintenance are operated.
In case of frequent message display during normal operation, make sure the situation and
message number, then please contact us.
10630 C OP Y TH E S ELEC T BLO C K Guide W ARN RESET
Cause : In the BLOCK view on the EDIT•PRG FILE screen, the selected block is being copied to the
clipboard.
288
10631 US E [PA STE ] TO IN SE RT C O PY BLO CK IN C UR SO R PO S Guide W ARN R ESET
Cause : The copy of the selected block to the clipboard finished.

The block copied to the clipboard can be inserted in the cursor position by pressing the
[PASTE] button.
10632 SELE CTE D B LOC K D ELE TING Guide W ARN R ESET
Cause : The selected block is being deleted. At this time, the deleted block is inserted in the
clipboard.
10633 BLO CK DE LETED . [PA STE ] CA N R EST OR E B LOC K A T Guide W ARN R ESET
CU RS OR
Cause : The deletion of the selected block finished.

The deleted block can be inserted in the cursor position by pressing the [PASTE] button.
10634 EN DED PA STE Guide W ARN R ESET
Cause : The content of clipboard was pasted in the cursor position.
10636 UN DE R A TTAC HM E NT Guide W ARN R ESET
Cause : The content of clipboard is being pasted in the cursor position.
10637 NO DA TA T O S TICK Guide W ARN R ESET
Cause : The [PASTE] button was pressed though there is no copied or deleted block in the
clipboard. The [PASTE] button is effective when the [SELECT] and [COPY], or [SELECT]
and [DELETE] operation was performed after the power on.

3. ALARM MESSAGE (INDEX)

(
6137 (ABO) ALARM BLOCK FOUND! I/O INPUT 10560 (PROGRAM COPY) ENTER PROGRAM
ABORTED (O NO.) TO BE INSERTED
10565 (BLOCK) SPECIFY A RANGE. PRESS 6099 (R_FILE) INTERNAL PROCESSING
[SELECT] TO CANCEL ERROR
6127 (COMPILE 48H) INTERNAL 6100 (READ) INTERNAL PROCESSING
PROCESSING ERROR ERROR
6128 (COMPILE 49H) INTERNAL 6101 (REWRITE) INTERNAL PROCESSING
PROCESSING ERROR ERROR
6133 (COMPILE 4EH) INTERNAL 10553 (SRCH) ENTER CHARA FOR SEARCH
PROCESSING ERROR [↑] [↓] FOR UP&DOWN
6134 (COMPILE 4FH) INTERNAL 6066 (SUB) INTERNAL PROCESSING ERROR
PROCESSING ERROR
10556 (ERROR SRCH) [↑] [↓] KEYS FOR UP & +
DOWN SEARCH
4006 +C OVERTRAVEL
6091 (FATAL) INTERNAL PROCESSING
4018 +C SOFT OVERTRAVEL
ERROR
6608 + PAGE KEY INVALID ON THIS SCREEN
10550 (JUMP) ENTER LINE NO. FOR JUMP
[↑]:TOP, [↓]:LAST 2300 +X EDGE MESURING
6121 (MACRO) ILLEGAL OPERATOR USAGE 2302 +Y EDGE MESURING
6126 (MACRO) MEMORY FULL AT COMPILE 4017 +Z SOFT OVERTRAVEL
6122 (MACRO) MORE THAN 20 OPERATORS 4005 +Z OVERTRAVEL
IN EXPRESSION 4014 +Y SOFT OVERTRAVEL
6120 (MACRO) MORE THAN 20 VARIABLES IN 4002 +Y OVERTRAVEL
EXPRESSION
4013 +X SOFT OVERTRAVEL
6125 (MACRO) TOO COMPLICATED DIVISION
4001 +X OVERTRAVEL
IN EXPRES.
4016 +V SOFT OVERTRAVEL
6123 (MACRO) TOO COMPLICATED
EXPRESSION (1) 4004 +V OVERTRAVEL
6124 (MACRO) TOO COMPLICATED 4015 +U SOFT OVERTRAVEL
EXPRESSION (2) 4003 +U OVERTRAVEL
6065 (MAIN) INTERNAL PROCESSING
ERROR
–
6115 (MEDIA3) INTERNAL PROCESSING 6609 – PAGE KEY INVALID ON THIS SCREEN
ERROR
4012 –C OVERTRAVEL
6449 (NO USE MESS.)
4024 –C SOFT OVERTRAVEL
6116 (NPC 2EH) INTERNAL PROCESSING
ERROR 4009 –U OVERTRAVEL
6069 (NPC) INTERNAL PROCESSING ERROR 4021 –U SOFT OVERTRAVEL
6071 (NPC) INTERNAL PROCESSING ERROR 4010 –V OVERTRAVEL

4022 –V SOFT OVERTRAVEL
290
2301 –X EDGE MESURING 1810 ALL NC PROGRAMS CLEARED AT PW

4007 –X OVERTRAVEL OFF BY MISTAKE
4019 –X SOFT OVERTRAVEL 10500 ALREADY EXIST, NOT REGISTRABLE
2303 –Y EDGE MESURING 2103 APPROACH CYCLE ERROR AT

MEASURING
4008 –Y OVERTRAVEL
1509 APPROACH E.No. IS E9000~E9999
4020 –Y SOFT OVERTRAVEL
7343 APPROACH ERROR AT MEASURING
4030 –Z AUTO RUN INTERRUPTED BY
OVERTRAVEL 1507 APPROACH1 ILLEGAL MACHINING
COND.
2312 –Z AXIS EDGE FACE POSITIONING
1508 APPROACH2 ILLEGAL MACHINING
4011 –Z OVERTRAVEL COND.
4023 –Z SOFT OVERTRAVEL 10146 AREA INTERLOCK ERROR OCCURRED
(REF)
1 10018 ARGUMENT ERROR (VMC ACCESS
10141 1 USER REFERENCE RESOURCE (REF) LIBRARY ERROR)
6825 1:2HD(1.2M) 2:2DD(720K) 3:PG 2836 ARM IS DURING OPERATION
4:2HD(1.44M) 2201 ARM LOWER LIMIT SW. OFF
2200 ARM NOT STANDBY POSITION
2 2202 ARM POSITION INCORRECT
6827 2DD(720K) DISK FORMATTING? YES:IN 10236 ASSISTANCE FUNCTION UNDEFINED
NO:ERASE ERROR (MCF)
6826 2HD(1.2M) DISK FORMATTING? YES:IN 5917 ASU HARDWARE ERROR
NO:ERASE
10042 ASYNC PROCESSING THREAD END
6829 2HD(1.44M) DISK FORMATTING? YES:IN TIME-OUT(CLASS LIB ERROR)
NO:ERASE
1091 AT DRYRUN
1052 AT INDEX FIXED LS ON
A
2309 AT M6
7903 ACTION TIME OUT (P/M)
2314 AT M6 I/O RETURN
6606 ADD KEY INVALID ON THIS SCREEN
2311 AT M7
6351 ADD O No. CAN NOT USED IN mm-
MODE 6001 AT MDI EXECUTION
6614 ADDRESS KEY INVALID ON THIS 10406 AT PRESENT, COORDINATES NOT
SCREEN DISPLAYED
4040 AIR PRESSURE LOW 1162 AT PROTECT
4056 AIRDRYER ALARM 6088 AT TAPE REWIND
6076 ALARM BLOCK FOUND! STOP I/O 2018 AT TOUCH RETRY
10557 ALARM BLOCK IS NOT FOUND OUT 25 AUTO POWER OFF BY ALARM OR
WARNING
6059 ALARM BLOCK NOT FOUND
4028 AUTO RUN INTERRUPTED BY
6119 ALARM BLOCK PRESENT IN PROGRAM
OVERTRAVEL
10164 ALARM MANAGEMENT
6326 AUTO SCALING
UNREGISTRATION ERROR (DGN)
6329 AUTO SCALING IMPOSSIBLE
Alarm Message (Index) 291

2056 AUTO SUPPLY COMPLETION 1996 BLOCK DATA ERROR (7)

2055 AUTO SUPPLY START 10633 BLOCK DELETED. [PASTE] CAN
2057 AUTO SUPPLY STOP RESTORE BLOCK AT CURSOR
2420 AUTO TENSION ADJUSTMENT 1150 BLOCK FORMAT ERROR

EXECUTED 6070 BLOCK LARGER THAN 192 CHAR.
2013 AUTOMATIC START HOLE DEVICE NOT 6003 BLOCK WAS CUT
READY 1152 BLOCK WITH MORE THAN 126 DIGITS
2007 AUTOMATIC WIRE THREADING RETRY PRESENT
OVER MAX. 6483 BLOCKS MADE USE OF THE FORMER
2000 AUTOMATIC WIRE THREADING MODEL DATA
SKIPPED 3009 BOOSTER BREAKER OFF
2834 AWC MAGAZINE IS DURING 3124 BOOSTER BREAKER TRIPPED
OPERATION
3000 BREAKER(CB2~CB5) TRIPPED
2802 AWC MOVE POSITION ERROR
4072 BREAKER(CB9) TRIPPED (CB9-ALM)
2804 AWC START COND. NOT SATISFIED
6114 BUBBLE MEMORY OVERFLOW
2824 AWC START COND. NOT SATISFIED
(SPINDLE MODE) 10400 BUTTON AT SELECTED POSITION IS
INVALID NOW
2036 A.W.T. JET FILTER NEEDS REPLACING
2015 A.W.T. RETRY AT REFERENCE HOLE
C
2009 A.W.T. RETRY TIME OVER FOR SMALL
5196 C ASC +15V VOLTAGE ALARM
HOLL A.W.T.
5206 C ASC -15V VOLTAGE ALARM
1068 AXIS-COMMAND IS OVER IN 1 BLOCK
5296 C ASC A/D ERROR ch.1
5306 C ASC A/D ERROR ch.2
B
7341 BACK BLOCK OUT DUE TO SHORT 5276 C ASC BUS COMMUNICATION ERROR
WIRE-WORK 5736 C ASC INVERTER CURRENT OVER 2
2041 BACK FLUSHED 5606 C ASC PARAMETER INCORRECT
7344 BACK LENGTH OUT DUE TO SHORT 5806 C ASC TIME OUT 1
WIRE-WORK 5796 C ASC TIME OUT 2
3015 BACK POWER CHARGE TIME UP 5786 C ASC TIME OUT 3
3013 BACK POWER, OVER VOLTAGE LIMIT 5256 C ASC WATCHDOG ALARM
3014 BACK POWER, UNDER VOLTAGE LIMIT 2313 C AXIS CENTERING
4075 BACK TENSION MOTOR OVERLOAD 5056 C CIRCUIT PROTECTOR OFF
(BT-OL)
5036 C COMMUTATION PULSE ERROR
20 BATTERY DROP
5226 C CONVERTER CURRENT OVER
1990 BLOCK DATA ERROR (1)
5096 C CONVERTER LOW VOLTAGE
5246 C CONVERTER VOLTAGE OVER
5336 C DROOP OVER
5516 C EFFECTIVE CURRENT OVER
5386 C ENCORDER FEEDBACK
1995 BLOCK DATA ERROR (6) DISCONNECTED
292
5026 C ENCORDER PULSE ERROR 10120 CANCELLED BY COMMAND SIMILAR TO

5216 C INVERTER CURRENT OVER THAT BEING RUN (KEY)
2327 C M6 POSITION RETURN ? yes:START 2807 CANNOT AWC SAFETY COVER CLOSE
KEY no:RESET DURING OPERATE
2325 C MACHINE HOME ? yes:START KEY 2837 CANNOT AWC SAFETY COVER OPEN
no:RESET DURING OPERATE
5106 C MOTOR OVERHEAT 10579 CANNOT BE USED INTO INITIAL SET

MODE
5366 C MOTOR REVOLVING SPEED
EXCEEDED 6332 CANNOT CHANGE DRAWING SET NOW
5576 C OVERSPEED 1522 CANNOT CONTROL CUTOFF

MACHINING
5016 C P FEEDBACK PULSE ERROR
2808 CANNOT M66-M68 DURING
5496 C PEAK CURRENT OVER 1 OPERATION
5506 C PEAK CURRENT OVER 2 1049 CANNOT MDI RUN DURING MEM RUN
5546 C PEAK CURRENT OVER 3 6331 CANNOT STOP DRAWING NOW
5376 C POSITION FEEDBACK 6658 CANN’T CHANGE OF IMC MODE
DISCONNECTED
6656 CANN’T CHANGE TERMINAL
5076 C REGENERATIVE RESISTOR PARAM.UNTIL OFF LINE
OVERHEAT
6652 CANN’T DO MANUAL PROGRAM RX
5956 C SERVO ALARM FROM TERMINAL
5966 C SERVO NOT READY 6653 CANN’T DO MANUAL PROGRAM TX TO
5926 C SERVO ON/OFF CONDITION ERROR TERMINAL
5066 C TRANSISTOR OVERHEAT 6668 CANSELED OF FUNCTION COMMAND
5006 C UNDEFINED ALARM 1065 CAN’T CHANGE INCH/MM BY
5526 C UNEFFECTIVE CURRENT OVER PROGRAM
2326 C WORK ZERO RETURN ? yes:START 6111 CAN’T GO TO LIST SCREEN DURING
KEY no:RESET PROG. COMPARE
4106 C ZRN DOG POSITION INCORRECT 6665 CAN’T SET COMMAND
6270 CALENDAR TIME OVER 6667 CAN’T SET EXECUTING COMMAND
6132 CALLING SUB PROGRAMS MORE THAN 10516 CANíT BE CHANGED DURING
151 PROGRAM EDITING
6509 CAN NOT CHANDE PROCESS DATA BY 10567 CANíT BE USED DURING SELECTION
PROCESS STATUS 6448 CARD DATA CALLED
6512 CAN NOT CHANGE PROCESS STATUS 6451 CARD DATA STORED
6501 CAN NOT CHANGE RUNNING MODE 3108 CBD UNIT OVERHEAT
6511 CAN NOT FIND COME UNDER 21 CENTRAL CONTROLLER FAN ALARM
PROCESS 6659 CHANGE OF IMC MODE
10541 CAN NOT FUND NETWORK NAME 2040 CHANGE SLAG BAG
10591 CAN NOT MDI-CANCEL 10522 CHARACTERS IN REGISTERED BLOCK
10592 CAN NOT RE-EDIT TOO LONG
6816 CANCELED 10523 CHARACTERS ON KEY-IN LINE TOO
6806 CANCELING! LONG

17 CHECK SUM ERROR (EIS-ROM) 3113 CPA UNIT 1 OVERHEAT

16 CHECK SUM ERROR (PARAMETER) 3114 CPA UNIT 2 ALARM
15 CHECK SUM ERROR (VMC-ROM) 3115 CPA UNIT 2 OVERHEAT
1096 CHECK WORK COORD. AND OFFSET 3120 CPA UNIT 3 BOOSTER ALARM
VALUE 3121 CPA UNIT 3 BOOSTER OVERHEAT
1230 CHR’S ENTRY AREA OVER-FLOW 3122 CPA UNIT 4 BOOSTER ALARM
4068 CIRCULATION PUMP INVERTER ALARM 3123 CPA UNIT 4 BOOSTER OVERHEAT
2001 CLAMP LEVER OPEN 3018 CPA UNIT OVERHEAT
2038 CLEAN RESERVOIR LOW 3071 CPF UNIT OVERHEAT
6367 CLEAR THE DRAWING 3070 CPT UNIT ALARM
10467 COMMAND CANNOT BE SET AT 6803 CREATING DIRECTORY!
PRESENT
3021 CRYSTAL UNIT OVERHEAT
10201 COMMAND CONTROL TABLE
DECODINGERROR (CND) 5992 CSI CARD 24V DROP
1081 COMMAND ERROR IN FIXED CYCLE 5991 CSI CARD FPGA WRITE ERROR
MACRO 10502 CURRENT PROGRAM CANNOT BE
7901 COMMAND RETRY ERROR DELETED
6261 COMMENT OF HELP IS NO ENTRY 10503 CURRENT PROGRAM CANNOT BE

EDITED
10228 COMMUNICATION MODE
CHANGEABLE ONLY IN FMS OFF-LINE 6356 CURSOR INCREMENT KEY NOT VALID
NOW
10459 COMMUNICATION RE-SETTABLE ONLY
IN OFF-LINE MODE 2990 CUSTOM MACRO MESSAGE 0
1044 COMND OVER 2991 CUSTOM MACRO MESSAGE 1
6105 COMPARING PROGRAM 2992 CUSTOM MACRO MESSAGE 2
1164 COMPILE ERROR 2993 CUSTOM MACRO MESSAGE 3
6143 COMPILING MODEL INFORMATION 2994 CUSTOM MACRO MESSAGE 4
6415 COMPLETE DATA REGISTRATION 2995 CUSTOM MACRO MESSAGE 5
6413 COMPLETE DATA SAVING 2996 CUSTOM MACRO MESSAGE 6
7911 CONFIRMATION REACH 2997 CUSTOM MACRO MESSAGE 7
10540 CONNECT THE NETWORK 2998 CUSTOM MACRO MESSAGE 8
10143 CONSTANT UPDATE AREA FULL (REF) 2999 CUSTOM MACRO MESSAGE 9
10577 CONVERSATIONAL INPUT ERROR IN 2004 CUTTER MOTION ABNORMAL

MODEL BLOCK 2028 CUTTER UNIT IS NOT VERTICAL OR
4042 COOLER OVERHEAT RECESSION
6361 COORD. DATA TRANSFERED 3101 CVR UNIT 1 ALARM 1
6141 COPY END 3103 CVR UNIT 1 ALARM 2
10630 COPY THE SELECT BLOCK 3102 CVR UNIT 1 OVERHEAT
6802 COPYING FILE! 3117 CVR UNIT 2 BOOSTER ALARM 1
6140 COPYING PROGRAM 3119 CVR UNIT 2 BOOSTER ALARM 2
3112 CPA UNIT 1 ALARM 3118 CVR UNIT 2 BOOSTER OVERHEAT
294
3105 CVR UNIT R OVERLOAD 6840 DISK DATA IS DESTOROYED

3104 CVR UNIT S OVERLOAD 6815 DISK FORMAT COMPLETE
3111 CVS UNIT OVERHEAT 6819 DISK FORMATTING? YES:IN KEY
3110 CVS UNIT R OVER VOLTAGE AND NO:ERASE KEY
OVER CURRENT 6839 DISK IN POSITION?
3109 CVS UNIT S OVER VOLTAGE AND OVER 6837 DISK IS FULL
CURRENT 6838 DISK IS WRITE-PROTECTED
3022 CWT UNIT OVERHEAT 6844 DISK READ ERROR(FORMATTED-
DISK?)
D 6842 DISK SEEK ERROR
2003 DANCING ROLLER POSITION 6843 DISK WRITE ERROR
ABNORMAL
10117 DISPLAY AXIS NOT FOUND
6344 DATA ERROR
6335 DISPLAY OF COORD. IMPOSSIBLE
10504 DATA IN KEY-IN AREA ERRONEOUS
6447 DISPLAYING CARD INITIALIZED
6432 DATA NEEDED AT CURSOR POSITION
6064 DIVIDED RESULT IN FILE CANNOT BE
6364 DATA NOT TRANSFERED NOW EDITED
6431 DATA ON CURSOR LINE NOT PERFECT 6095 DIVIDING OF PROGRAM COMPLETED
6342 DATA RECALL MEMORY EMPTY 6098 DIVIDING PROGRAM
10059 DATA TABLE OF LINK TABLES NOT 10405 DOCUMENT CLASS SETUP FAILE
FOUND (NCAPI RESPONSE ERROR) (APPLI. ERROR)
1046 DECIMAL POINT ERROR 6654 DON’T MATCH TERM R/T ABORT
6818 DELETE FILE? YES:IN KEY NO:ERASE 6411 DON’T SAVE NC PROGRAM
KEY
6410 DON’T SAVE RAM MACRO AFTER O
6605 DELETE KEY INVALID ON THIS SCREEN No.10000
6804 DELETING DIRECTORY! 10185 DOUBLE BOOKING ERROR
6805 DELETING FILE! 10418 DOUBLE CONDITION ADJUSTING
10614 DETAIL SET DATA READING TO COMMANDS PROHIBITED
EXTERNAL FILE 6611 DOWN CURSOR KEY INVALID ON THIS
10613 DETAIL SET DATA WRITING TO SCREEN
EXTERNAL FILE 10011 DPRAM CMMD PACKAGE WRITE
10610 DIAGNOSTIC INFORMATION WRITING ERROR (VMC ACCESS LIBRARY
TO EXT FILE ERROR)
6107 DIFFERENT BLOCK FOUND 6336 DRAW FINISHED
6836 DIRECTORY CANNOT BE ERASED 6349 DRAWING CLEAR ONLY IN DRAWING
RESET STATUS
6812 DIRECTORY COMPLETE
6330 DRAWING IMPOSSIBLE
6813 DIRECTORY DELETION COMPLETE
6366 DRAWING START POINT?
6855 DIRECTORY DESIGNATION IS NOT
USED 6846 DRIVE MAY BE OUT OF ORDER
6854 DISABLE FUNCTION UNDER CURRENT 6845 DRIVE NUMBER IS NOT CONNECTED
FORMAT 10172 DUMMY SIGNAL IS INVALID
10166 DISCRETE WRITING FAILED

6425 DUPLICATE G110-G139 BLOCKS IN 6851 EMM FIRMWARE RAM CHEK ERROR
SUCCESSION 7800 EMM NOT CONNECTED
1075 DUPULICATE INSTRUCTIONS OF G31 7801 EMM TIME ELAPSED ERROR
1072 DUPULICATE INSTRUCTIONS OF G44 7803 EMM UNREGISTRATION ALARM
AND G46
10062 EMPTY AREA FOR NOTICE WAITING
NOT FOUND (NCAPI RESPONSE
E ERROR)
1503 E No. NOT FOUND 6434 END OF EDIT SCREEN
1119 EDIT IN BLOCK DISP. OR ERROR IN 6903 END OF RAM DISK FORMAT
MAIN PROGRAM
6900 END OF SYSTEM
1120 EDIT IN BLOCK DISP. OR ERROR IN
1006 END POINT INCORRECT IN G02,G03
SUB PROGRAM
COMND
6094 EDIT INHIBITED BY PARAMETER
10145 END SPECIFYING RESOURCE
1813 EDIT STOPPED AT PW OFF BY ALREADY FINISHED (REF)
MISTAKE
10562 ENDED COPY
10514 EDITED PROGRAM IS NOT SAVED
10634 ENDED PASTE
10268 EFFECTIVE LINE DATA NOT FOUND
10518 ENDED SEARCH
(MDL)
6833 ENTER FILE NAME
7324 EIS (LOCAL) ASC TIME ELAPSED
ERROR 1512 ERASE PROTECTED CONDITION
7332 EIS (LOCAL) DEAD LOCK 7303 ERRONEOUS INTERRUPT FROM EIS
7323 EIS (LOCAL) EXECUTION OF NON- 6005 ERROR IN BLOCK ON KEY-IN LINE
CODE SECTION 10524 ERROR OCCURRED DURING
7325 EIS (LOCAL) IO TIME ELAPSED ERROR PROGRAM TRANSFER
7331 EIS (LOCAL) MEMORY FULL 6061 ERROR ON KEY-IN LINE
7330 EIS (LOCAL) NDP ERROR 7111 ESC0 BUFFER OVERFLOW
7340 EIS (LOCAL) NO EQUIPMENT OPTION 7108 ESC0 FRAMING ERROR (0 STOP BITS)
7322 EIS (LOCAL) RAM ERROR 7119 ESC0 NONREGISTRY ALARM
7321 EIS (LOCAL) ROM ERROR 7110 ESC0 PARITY ERROR
2102 EIS ALARM (2) 7100 ESC0 RESERVE, RELEASE ERROR
7349 EIS NONREGISTRY ALARM 7109 ESC0 RX OVERRUN
7300 EIS NOT CONNECTED 7102 ESC0 START, STOP BITS INCORRECT
ORDER
7305 EIS PARAMETER INITIALIZE NOT OK
7112 ESC0 TERMINAL NOT CONNECTED
7304 EIS RESPONSE LENGTH ERROR
7101 ESC0 TIME ELAPSED ERROR
7301 EIS TIME ELAPSED ERROR
7131 ESC1 BUFFER OVERFLOW
7307 EIS-ASC ERROR
7128 ESC1 FRAMING ERROR (0 STOP BITS)
1 EMERGENCY STOP
7139 ESC1 NONREGISTRY ALARM
4065 EMF FILTER ABNORMAL
7130 ESC1 PARITY ERROR
7802 EMM COMMAND REPLY ERROR
7120 ESC1 RESERVE, RELEASE ERROR
6852 EMM FIRMWARE INTERNAL ERROR
7129 ESC1 RX OVERRUN
296
7122 ESC1 START, STOP BITS INCORRECT 3036 EXTERNAL SEARCH POWER, OVER
ORDER VOLTAGE LIMIT
7121 ESC1 TIME ELAPSED ERROR F
7151 ESC2 BUFFER OVERFLOW 6904 FAILED OF RAM DISK FORMAT
7148 ESC2 FRAMING ERROR 6902 FAILED OF SYSTEM RELEASE
7159 ESC2 NONREGISTRY ALARM 6901 FAILED OF SYSTEM START
7150 ESC2 PARITY ERROR 6333 FIGURE MOVE IMPOSSIBLE
7140 ESC2 RESERVE, RELEASE ERROR 6334 FIGURE SCALING IMPOSSIBLE
7149 ESC2 RX OVERRUN 6820 FILE CANNOT BE COPIED TO
IDENTICAL NAME
7142 ESC2 START, STOP ORDER ERROR
6809 FILE COPY COMPLETE
6814 FILE DELETION COMPLETE
7141 ESC2 TIME ELAPSED ERROR
6835 FILE EXISTS IN DIRECTORY
4039 EXCESS A.W.T. JET PRESSURE
6832 FILE IS FULL
1197 EXCESS NESTING OF G66
6831 FILE IS WRITE-PROTECTED
1199 EXCESS NESTING OF MACRO CALL
6857 FILE NAME IS NOT MP-1 TYPE
1136 EXCESS NESTING OF SUB PROGRAM
6112 FILE Q’TY OVERFLOW
2415 EXCESS TENSION ERROR
10618 FILE READING FAILED
10617 FILE READING SUCCEEDED
6810 FILE RENAME COMPLETE
4054 EXCESSIVE ENERGIZER WEAR
6808 FILE TRANSFER COMPLETE
10407 EXECUTE CONDITION SCREEN
CLOSED 6811 FILE WRITE-PROTECT COMPLETE
7910 EXISTENCE OF WORK ERROR 10616 FILE WRITING FAILED
1514 EXISTING E NO SPECIFIED 10615 FILE WRITING SUCCEEDED
4061 EXT.CONTROLLER ALARM 1 4044 FILL INVERTER ALARM
4060 EXT.CONTROLLER ALARM 2 2059 FILLING-OFF IS IMPOSSIBLE IN MC
POWER ON
3042 EXTERNAL BACK POWER CHARGE
TIME UP 2053 FILTER PRESSURE SENSOR ERROR
3040 EXTERNAL BACK POWER, OVER 4070 FILTER PUMP INVERTER
VOLTAGE LIMIT ABNORMAL(INV-F-AL)
3041 EXTERNAL BACK POWER, UNDER 4078 FINE A.W.T. UNIT ALARM (VSH-ALM)
VOLTAGE LIMIT 7 FIRE EXTINGUISHER OPERATED
3031 EXTERNAL CPA UNIT OVERHEAT 5 FLAME SENSOR ON
3034 EXTERNAL MAIN POWER CURRENT 2817 FLUID TANK UPPER MODE
OVER
4067 FLUID TEMPERATURE ALARM
3012 EXTERNAL MAIN POWER OVERHEAT
10226 FMS IN OFF-LINE MODE
OR CB20 TRIP
1220 FORMAT ERROR OF GRAPHIC MACRO
3037 EXTERNAL MAIN POWER, OVER
CODE
VOLTAGE LIMIT
6906 FORMATTING

6807 FORMATTING! 1028 G4 COMND WITHOUT P, X WORD

6663 FOUND OF O NUMBER ERROR 1012 G41, G42 IN G02, G03 BLOCK
(TERMINAL) 1077 G41/G42 P_ COMND ERROR
3116 FPGA WRITE ERROR 1019 G44 PROGRAMMED BEFORE G41, G42
10053 FUNCTION CLASSIFICATION OUT OF 1071 G46 IN G40 INVALID
RANGE (NCAPI RESPONSE ERROR)
1007 G48, G68 COMND ORDER ERROR
10174 FUNCTION SWITCH MANAGEMENT ID
OUT OF RANGE(NCF) 1005 G48, G68 OR G26 OVERLAP COMND
1066 G48P_ COMND EXIST AT TAPER
MODE2
G
1062 G49 COMND ERROR
1010 G CODES IN SAME GROUP CAN’T BE IN
SAME BLOCK 1022 G49 COMND WITHOUT OFFSET OR
TAPER
1530 G10(E) COMMAND ERROR
1030 G53 IS ONLY VALID AFTER REF. POS.
1538 G10(G) COMMAND ERROR
RETURN
1535 G10(I) COMMAND ERROR
1085 G590, G591, G592 VALID AT HEAD OF
1536 G10(J) COMMAND ERROR BLOCK ONLY
1537 G10(K) COMMAND ERROR 1056 G68 COMND ERROR
1531 G10(L) COMMAND ERROR 1736 G86, G87 EXCESS DEVIATION OF
1539 G10(M) COMMAND ERROR MEASURED DIM.
1532 G10(P) COMMAND ERROR 1732 G86, G87 EXCESS STOCK REMOVAL
1533 G10(Q) COMMAND ERROR 1730 G86, G87 PROGRAM FORMAT ERROR
1534 G10(R) COMMAND ERROR 1733 G86, G87 SKIP REMEASURING
1003 G2, G3 COMND. MISSING I, J OR R 1067 G92 COMND ERROR
VALUE 1009 G92 SPECIFIED AFTER G48, G68 OR
1023 G22 COMND ERROR G26
1021 G24 COMND WITHOUT OFFSET OR 1198 G93 SPECIFIED MORE THAN TWICE
TAPER 1033 G95 COMND ERROR
1059 G24 ERROR (INTERSECT. CANNOT BE 1025 G95 IN G41, G42 INVALID
DETERMINED)
10189 GET ELEMENT SPECIFIED WITH PUT
1058 G24 ERROR (NOT TANGENT TO (CND)
BEFORE, AFTER BLKS)
6370 GRAPHIC DATA TRANSFERED
1060 G24 ERROR (OVERCUT BY NEGATIVE
1224 GRAPHIC MACRO CODE OUT OF
RAD. CALC.)
DRAWABLE AREA
1020 G25 COMND WITHOUT OFFSET OR
6350 GRAPHICS DATA SAVED
TAPER
6325 GRAPHICS DRAWING
2835 GRIPPER ADVANCE MODE
2816 GRIPPER CLAMP
1032 G28, G29 COMND ORDER ERROR
2830 GRIPPER FORWARD MODE
1029 G30 IS ONLY VALID AFTER REF. POS.
RETURN
298
H 6841 ILLEGAL DISK IS USED

6440 HEAD CARD 10188 ILLEGAL ELEMENT NO.
SELECTED(CND)
4027 HEAD PROTECT DETECTED
10144 ILLEGAL END SPECIFYING RESOURCE
4047 HI PRESS. INVERTER PUMP THERMAL
ID (REF)
TRIP
1700 ILLEGAL FEED RATE PARAMETER
4048 HI PRESS. PUMP EXCESS PRESSURE
6821 ILLEGAL FILE IS SPECIFIED
2304 HOLE CENTER
10052 ILLEGAL FUNCTION NO. (NCAPI
10128 HW IS OPTION
RESPONSE ERROR)
1222 ILLEGAL G CODE IN GRAPHIC MACRO
I CODE
6086 I/O INPUT ABORTED 10259 ILLEGAL G CODE SPECIFIED (MDL)
6084 I/O INPUT STOPPED 1087 ILLEGAL G04 VALUE
10175 I/O MANAGEMENT UNREGISTRATION 10403 ILLEGAL ID DETECTED IN EXECUTE
ERROR(NCF) CONDITION (APPLI. ERROR)
6087 I/O OUTPUT ABORTED 10404 ILLEGAL ID DETECTED IN EXECUTE
6085 I/O OUTPUT STOPPED CONDITION (APPLI. ERROR)
6081 I/O PORT ERROR 1221 ILLEGAL INPUT-DATA OF GRAPHIC
6083 I/O PORT NOT READY MACRO CODE
6073 I/O PROGRAM ADDING TO EXISTING 10211 ILLEGAL INTERNAL RESOURCE ID

FILE 10137 ILLEGAL INTERRUPT CHANGE
6072 I/O PROGRAM INPUT EMPTY FILE REQUEST SET (KEY)
6834 IDENTICAL FILE NAME OR DIR. IS 10138 ILLEGAL INTERRUPT MODE DURING
FOUND RUN (KEY)
10199 IES FUNCTION ON SWITCHING 10136 ILLEGAL INTERRUPT REQUEST

DISABLED (CND) DESIGNATION ID (KEY)
10200 IES REQUEST DECODING TABLE 6507 ILLEGAL ITEM No. (SCHEDULE DATA)
ERROR (CND) 2012 ILLEGAL MACHINE TYPE SELECTED
2321 IF COEFF. REVICED ? yes:START KEY 1500 ILLEGAL MACHING COND. SPECIFIED
no:RESET 10414 ILLEGAL MACHINING CONDITION
1501 ILLEGAL CHANGE DATA OF MACHING SPECIFIED
COND. 10057 ILLEGAL MANAGEMENT NO. (NCAPI
10215 ILLEGAL COMMAND ID SPECIFIED RESPONSE ERROR)
(MDL) 10110 ILLEGAL MODE COMMAND MASKING
10219 ILLEGAL COMMAND SPECIFIED (MDL) 10194 ILLEGAL MODEL DRAWING AXIS
10204 ILLEGAL COMMENT REWRITING COMMAND (CND)
POSITION 10195 ILLEGAL MODEL DRAWING CYCLE
6822 ILLEGAL CURSOR POSITION (CND)
10037 ILLEGAL DATA AREA SIZE SPECIFIED 10191 ILLEGAL NOTICE WAITING ITEM
(CLASS LIB ERROR) SELECTED (CND)
10423 ILLEGAL DATA ON KEY-IN LINE 10570 ILLEGAL NUMBER OF DIGITS ON KEY-
10493 ILLEGAL DATA ON KEY-IN LINE IN LINE

10422 ILLEGAL NUMERIC ON KEY-IN LINE 10471 ILLEGAL WORK OFFSET NO.
10492 ILLEGAL NUMERIC ON KEY-IN LINE SPECIFIED
10571 ILLEGAL NUMERIC ON KEY-IN LINE 10133 ILLEGAL WRITE DEST COORD ID (KEY)
10157 ILLEGAL OFFSET RESOURCE 10225 IMC COMMUNICATION LOG ACQ

COMMAND ID (SET) START POS OUT OF RANGE
10472 ILLEGAL OFFSET VALUE SPECIFIED 1802 IMPOSSIBLE TO CANCEL INPUT/

OUTPUT
10158 ILLEGAL OFFSSET NO. RANGE
4029 IMPOSSIBLE TO CHANGE SOFT
10159 ILLEGAL OFFSSET NO. RANGE STROKE LIMIT
1015 ILLEGAL PLANE MOVE. COMND EXIST 1504 IMPOSSIBLE TO EDIT STANDARD
G41, G42 BLOCK COND.
6506 ILLEGAL PROCESS No. (SCHEDULE 1505 IMPOSSIBLE TO ERASE STANDARD
DATA) COND.
6068 ILLEGAL PROGRAM No. SPECIFIED 1073 IMPOSSIBLE TO SET COORD. (G92)
10505 ILLEGAL PROGRAM NO. SPECIFIED DURING G41, G42
10135 ILLEGAL READ MODAL ID 1734 IN MEASURE AND MACHINING MODE
10134 ILLEGAL READ MODAL VALUE 1078 INCONSISTENT COMND WITH G41/G42
10264 ILLEGAL READ SPECIFYING PACKET P_ COMND
LENGTH (MDL) 1061 INCORRECT TAPER PLANE DATA
10263 ILLEGAL READ SYSTEM (MDL) 2838 INDEX INTERFERENCE CHECK?
10216 ILLEGAL RESOURCE ID SPECIFIED YES:START NO:RESET
(MDL) 6482 INDIRECT OFFSET CARDS ARE
10153 ILLEGAL REWRITING SPECIFIED AVAILABLE ONLY ONE
6504 ILLEGAL SCHDULE MODE 6461 INDIRECT OFFSET DATA IN CONDITION

TABLE
6435 ILLEGAL SCREEN DATA
6623 INHIBITED BY PARAMETER
1070 ILLEGAL SELECT OF INTERPOLATION
UNIT 6437 INPUT [;]+[ADD-IN]OR[;]+[IN] AFT. INPUT
DATA
1050 ILLEGAL SELECTION OF AUTO MODE
6866 INPUT DISK TO MEMORY O No. AND
10420 ILLEGAL SPECIFIC ADDRESS VALUE PUSH [IN] KEY
10222 ILLEGAL TABLE DATA REQUESTED 6868 INPUT FILE MAME AND PUSH [IN] KEY
(MDL)
6867 INPUT FILE NAME AND PUSH [IN] KEY
10151 ILLEGAL UNIT COMMAND
6865 INPUT FILE NAME AND PUSH [IN] KEY
6250 ILLEGAL VALUE SET IN MACHINING
CONDITION 6607 INPUT KEY INVALID ON THIS SCREEN
6145 ILLEGAL WIRE DIAMETER 6469 INPUT MASTER BLOCKS O No.
1149 ILLEGAL WORD IN BLOCK 6864 INPUT MEMORY TO DISK O No. AND
PUSH [IN] KEY
1037 ILLEGAL WORD IN G10 BLOCK
2218 INPUT NOZZLE LEN. BEYOND LIMITS
10114 ILLEGAL WORK COORD. GROUP NO.
6473 INPUT O No.
10113 ILLEGAL WORK COORD. NO.
10426 INPUT OPERATION DISABLED
10470 ILLEGAL WORK OFFSET GROUP
SPECIFIED 10173 INPUT SIGNAL IS INVALID
300
6103 INPUT STARTING N No. FOR PROG. K

COMPARE
6096 KEY IN PROGRAM No.
10218 INPUT VALUE DESIGNATION ERROR
10507 KEY IN PROGRAM NO.
(MDL)
6740 KEY-IN DATA IS NO GOOD
1086 INPUT VALUE IS ROUNDED OFF
6621 KEY-IN LINE EMPTY
10217 INPUT VALUE OUT OF RANGE (MDL)
6013 KEY-IN LINE EMPTY, PRESS SEARCH
1151 INPUT/OUTPUT DEVICE ERROR
KEY
10119 INT PROC ERROR (PRTBL SW
6010 KEY-IN LINE IS EMPTY
UNFIXED) (KEY)
10402 KEY-IN LINE IS EMPTY OR IMPROPER
10220 INTERLOCK ERROR AUTO RUN
EXECUTING
10221 INTERLOCK ERROR AXIS MOVING L
6051 INTERNAL PROCESSING ERROR 6441 LAST CARD
10036 INTERNAL RESOURCES (MEMORY, 6442 LAST CONDITION CARD

EVENT) CANíT ACQUIRED (CLASS LIB 6012 LAST M.D.I. BLOCK NOT FOUND
ERROR) 6443 LAST PROCESS CARD
6067 INTERPRETATION ERROR 6613 LEFT CURSOR KEY INVALID ON THIS
1000 INTERSECTION POINT OUTSIDE OF SCREEN
PRM 83 LIMIT 2430 LESS WIRE REMAINS
10167 INVALID BECAUSE OF OPTION 10458 LIEN IS NOT IN ON-LINE MODE
6600 INVALID COMMAND ON KEY-IN LINE 6655 LINE INFOMATION IS NOT ON LINE
6735 INVALID EIO No. SPECIFIED 10454 LINE MODE IS LOCAL
10168 INVALID FOR MODE OTHER THAN 10453 LINE MODE IS REMOTE
MANUAL
3051 LL POWER OVERHEAT
10170 INVALID FOR MODE OTHER THAN
MANUAL AND RESET 3052 LL POWER OVERLOAD
6260 INVALID HELP KEY 3050 LL POWER OVERVOLTAGE
2216 INVALID M73P0 BEFORE M73P1 3060 LL POWER SETTING ERROR (0)
2215 INVALID M73P1 BEFORE M73S1 3061 LL POWER SETTING ERROR (1)
10169 INVALID START STATUS 3062 LL POWER SETTING ERROR (2)
2031 ION EXCHANGE RESIN NEEDS 3063 LL POWER SETTING ERROR (3)
REPLACING 10124 LOW FEED DISABLED AS TOUCH
2048 ION EXCHANGED OFF SENSING IS EFFECTIVE
10551 JUMP 2073 LOWER HEAD PUMP ROTATION FREQ.

LIMIT
10413 JUMP AMOUNT TAP 17 IS INVALID
2071 LOWER HEAD WATER PRESS. LOW
10410 JUMP COMMAND VALUE IS IMPROPER
4046 LOWER HI PRESS. INVERTER PUMP
10412 JUMP COMMAND VALUE IS TOO LARGE ABNORMAL
10411 JUMP COMMAND VALUE IS TOO SMALL 4041 LOWER PUMP INVERTER ABNORMAL
10401 JUMP MANUAL CHANGE PROHIBITED

M 2058 MACHING IS POSSIBLE IN WORK TANK

FILLED
1002 M02, M30 PROGRAMED BEFORE
OFFSET CANCEL (G40) 1525 MACHING SKIP UNTILL M8 BLOCK BY
M90Q1
2027 M28Q NUMERICAL COMND ERROR
10227 MACHINING CANNOT FINISH
1098 M6 INVALID IN TAPER MODE
1186 MACRO CALCULATION ACCURACY
2308 M6 POSITION RETURN
ERROR (1)
1741 M6 SEARCHED BY M74, A.W.T. MISSED
1187 MACRO CALCULATION ACCURACY
(1)
ERROR (2)
1742 M6 SEARCHED BY M74, A.W.T. MISSED
1184 MACRO CALCULATION ERROR
(2)
1102 MACRO COMND ORDER ERROR
2310 M6 SHIFT RETURN
1139 MACRO COMND PRESENT AT TAPE
2064 M6 Y POSITION INCORRECT
MODE
2826 M60 CODE MISSING
1185 MACRO DIVISOR IS 0
2820 M63S CODE MISSING
6516 MACRO ERROR
2806 M66-M68 INTERRUPTED BY AWC
10179 MACRO RESOURCE MANAGEMENT
SAFETY COVER OPEN
UNREGISTRATION ERROR (EXE)
2800 M66W-M68W CODE MISSING (AWC
1180 MACRO VARIABLE No. ERROR
RANDOM OFF)
1181 MACRO VARIABLE VALUE ERROR
2801 M66W-M68W OR M66P-M68P CODE
MISSING 2815 MAGAZINE UPPER MODE
1506 M71L COMMAND IS 0,1 3033 MAIN POWER CURRENT OVER
2206 M73 APROACH ERROR 3011 MAIN POWER OVERHEAT OR CB20
TRIP
2205 M73 FORMAT ERROR
3010 MAIN POWER, OVER VOLTAGE LIMIT
2219 M73 PROHIBITED AREA
6515 MAKING IN GOOD ORDER
2207 M73 TIME ELAPSED ERROR
10455 MANUAL PROGRAM INPUT FROM
6491 M74 RECORD BAD NUMBER OF ITEM
HOST IS DISABLED
ID
10456 MANUAL PROGRAM OUTPUT TO HOST
6490 M74 RECORD BAD NUMBER OF
IS DISABLED
RECORD ID
6751 MASKED BECAUSE FUNCTION IS NOT
6492 M74 RECORD DISCRIMINATER (P/W/L)
SUPPORTED
OVERLAP
6471 MASTER BLOCKS OUTPUT
6493 M74 RECORD ITEM VALUE IS BEYOND
COMPLETED
THE LIMITS
6477 MASTER BLOCKS WERE READ
1526 M8 BLOCK DIVISION INVALID IN G40
12 MC POWER, +15VDC DROP
1521 M90 COMND ERROR
13 MC POWER, +24VDC DROP
1137 M99 PRESENT IN MAIN PROGRAM
11 MC POWER, –15VDC DROP
7333 MACHINE COORD. IS OUT OF
SOFTLIMIT 7914 MC RUN TIME OUT
2307 MACHINE HOME 2810 MC RUN TIME OUT (1)
6363 MACHINE INFO. TRANSFERED 2811 MC RUN TIME OUT (2)
2812 MC RUN TIME OUT (3)
302
2813 MC RUN TIME OUT (4) 26 MISMATCHED ASC UNIT

2814 MC RUN TIME OUT (5) 1511 MISTAKEN ERASE PROTECTED
2017 MC SEQUENCE MACRO PROGRAM CONDITION
ERROR 2803 MODAL W SET VALUE ERROR
1014 MDI OR M6 DURING G41, G42 10450 MODE CANNOT BE CHANGED DURING
1083 MDI, MEM RUN INVALID DURING MAN. ROTATION
ZERO RETURN 10055 MODE ID OUT OF RANGE (NCAPI
2401 MEASURE 1ST TENSION RESPONSE ERROR)
2402 MEASURE 2ND TENSION 10572 MODEL BLOCK ADDED
2403 MEASURE 3RD TENSION 10573 MODEL BLOCK ADDED
2404 MEASURE 4TH TENSION 6428 MODEL BLOCK ADD-IN COMPLETED
1735 MEASURE AND MACHINING MODE 6429 MODEL BLOCK CHANGE COMPLETED
COMPLETION 10257 MODEL BLOCK CHECKING
1731 MEASURE AND MACHINING MODE 10574 MODEL BLOCK DELETE
MEASURING 10256 MODEL BLOCK LENGTH OVER
2101 MEASUREMENT IMPOSSIBLE, WIRE 10255 MODEL BLOCK LENGTH TOO SHORT
TOUCHES WORK
6142 MODEL BLOCK NOT PRESENT
1720 MEASURING APPROACH NEVER (G100-G139)
TOUCHED PART
6426 MODEL BLOCKS ARE NOT COMPILED
1717 MEASURING COMND ANGLE
REGISTER ERROR 6427 MODEL BLOCKS ARE NOT ENTERED
COMPLETELY
1716 MEASURING COMND SPECIFIED AXIS
ERROR 6464 MODEL BLOCKS OUTPUT COMPLETED
1722 MEASURING SKIP (DRY RUN, MACH 10575 MODEL BROOK CANíT BE CONVERT TO
LOCK, GRAPHICS) CONVERSATION
6514 MEMORIZE A PACK OP PROCESS DATA 10273 MODEL COMPILE MACRO ERROR
6056 MEMORY FULL 10272 MODEL COMPILE OPEN ERROR
6053 MEMORY FULL 6456 MODEL DATA ADDED
6113 MEMORY OVERFLOW 6458 MODEL DATA CANNOT BE DELETED
10509 MEMORY OVER-FLOW 6459 MODEL DATA CANNOT BE DELETED

AND ADDED
10015 MEMORY POOL FAILED (VMC ACCESS
LIBRARY ERROR) 6455 MODEL DATA DELETED
10039 MEMORY POOL FOR SIZE STORING 6457 MODEL DATA DELETED AND ADDED
CANíT ACQUIRED (CLASS LIB ERROR) 6472 MODEL DATA OUTPUT COMPLETED
10014 MEMORY POOL FULL (VMC ACCESS 10193 MODEL DRAWING CHANGE DISABLED
LIBRARY ERROR) (CND)
10038 MEMORY POOL IN DATA AREA CANíT 10196 MODEL DRAWING DATA NOT FOUND
ACQUIRED(CLASS LIB ERROR) (CND)
1036 MEMORY PROTECT PARAM. ILLEGAL 10192 MODEL DRAWING DISABLED (CND)
BY G10 10197 MODEL DRAWING INVALID (CND)
1167 MEMORY SHORTAGE 1017 MORE THAN 2 NON-MOVEMENT BLKS
1008 MIRROR IMAGE (G71) COMND ERROR DURING G41,G42

2833 MOVE ARM TO SIDE OF AWC 6454 NO NEXT DATA

MAGAZINE 1196 NO O No. IN G93 SPECIFIED
6353 MOVE CURSOR AND SET DATA 7904 NO PALETTE (COMMAND STOCKER
6347 MOVE FROM THIS POSITION NO.)
6348 MOVE TO THIS POSITION 2047 NO PALLET IN CHUCK
1069 MOVE Z AXIS TO HEIGHT OF Z POS. 6510 NO PROCESS TO EXECUTE
DISPLAY 6025 NO PROGRAM IS RUNNING
1039 MOVEMENT COMND ON OPTION AXIS 6481 NO REGISTERED DATA
7916 MOVEMENT CONTINUE BE NOT DONE 10147 NO RESOURCE ACCESS RIGHT (REF)
(P/M)
7902 NO RESPONSE OF CONTROL
1024 MOVEMENT END COORD. WITHIN COMMAND
PROHIBITED AREA
6450 NO STORED DATA
6460 NO USE
N
1513 NO USER CONDITION AREA
1132 N No. NOT FOUND
2010 NO WIRE AT EDGE SENSER (WT-SEN)
1079 N No. NOT FOUND FOR I/O CANSEL
MACRO 4077 NO WIRE AT WIRE BOBBIN (BT-LL, WB-
LS)
10224 NC ANSWER ERROR
6129 No. OF "[","]" IN PROGRAM DOES NOT
10019 NC RESOURCE ACCESS FAILED (VMC
MATCH
ACCESS LIBRARY ERROR)
2067 NONCONTACT POINT NOT FOUND
3 NC, +15VDC DROP
2066 NONCONTACT POINT SEARCHING
2 NC, +24VDC DROP
COMPLETION
4 NC, –15VDC DROP
2065 NONCONTACT POINT SEARCHING
10030 NCAPI CAUSED ERROR (CLASS LIB EXECUTION
ERROR)
10260 NONE BLOCK END CODE (;) (MDL)
10409 NECESSARY WORD DOES NOT EXIST
6430 NOT APPLICABLE TO MODEL BLOCK
IN JUMP COMMAND
10274 NOT COMPILE MODEL
6131 NEST LEVEL ABOVE 10
10275 NOT CONFIRM MODEL SET
10566 NO BLOCK IS SELECTED
6006 NOT IN RESET STATUS
6004 NO BLOCK PRESENT ON KEY-IN LINE
6502 NOT MEMORY MODE OR ALARM SIGN
10637 NO DATA TO STICK
EXIST
6109 NO DIFFERENCES FOUND
10258 NOT MODEL G BLOCK (MDL)
6830 NO FILE OR DIR. NAME FOUND
10238 NOT RESET
6097 NO FILE TO STORE DIVIDED PROGRAM
1001 NOT TANGENT DUE TO OFFSET
6470 NO INPUT DATA CHANGE, OUTSIDE RAD.
6453 NO LAST DATA 6622 NOT VALID IN START, STOP STS&HW,
1043 NO M02, M30 IN MAIN PROGRAM ZERO RET MODE
1138 NO M99 IN SUB PROGRAM 2828 NOT ZERO RETURN AWC MAGAZINE
10576 NO MODEL BLOCK 10109 NOTICE PACKET LENGTH ERROR
6601 NO MORE DISPLAYABLE PAGES 6414 NOW DATA REGISTRY !
6412 NOW DATA SAVING
304
6651 NOW IMC MODE IS LOCAL MODE 6357 OFFSET DATA TRANSFERED
6650 NOW IMC MODE IS REMOTE MODE 10156 OFFSET RESOURCE ACCESS ERROR
1160 NPC COMND No. ERROR (SET)
1161 NPC COMND No. INCORRECT 10578 ONLY INITIAL SET MODE IS EFFECTIVE
6015 NPC INTERNAL ERROR 6354 ONLY POSSIBLE WITH ROTATE ANGLE
0 OR 90
6620 NUMBER HAS TOO MANY DIGITS ON
KEY-IN LINE 6401 ONLY VALID IN MANUAL MODE
6002 NUMBER OF BLOCKS EXCEEDS MDI 2809 ONLY VALID IN MANUAL MODE
CAPCITY 6402 ONLY VALID IN MANUAL MODE &
10508 NUMBER OF FILES OVERFLOW RESET STATUS
10267 NUMBER OF READ LINES IS 0 (MDL) 6400 ONLY VALID WITH OPTIONAL ITEM
10265 NUMBER OF READ LINES SPECIFIED 10060 OPE MANAGEMENT OF LINK TABLES
TO 0 (MDL) NOT OBTAINED (NCAPI RESPONSE
ERROR)
6619 NUMBER OUT OF RANGE ON KEY-IN
LINE 4050 OPEN COVER DETECTED
6617 NUMBER TOO LARGE ON KEY-IN LINE 4049 OPEN GUIDE DETECTED
6618 NUMBER TOO SMALL ON KEY-IN LINE 4066 OPEN WORK TANK COVER DETECTED
1047 NUMERICAL COMND ERROR 10054 OPERATION CLASSIFICATIN OUT OF

RANGE (NCAPI RESPONSE ERROR)
10121 OPERATION MANAGE TABLE FOR
O REQUEST NOT FOUND (KEY)
1118 O No. (MAIN,SUB) IS NOT REGISTERED
10139 OPERATION STATUS UNDEFINED
IN MEMORY
ERROR (KEY)
6054 O No. ALREADY USED
6513 OPERATION WITH INPUT "P[PROCESS
6343 O No. ERROR No.]"
1163 O No. EXISTENT 1502 OPTION MACHING COND. SPECIFIED
6138 O No. FOUND AFTER FIRST BLOCK 1011 OPTIONAL G CODE SPECIFIED
1116 O No. IS NOT WITHIN 1~9999 10198 ORBITING RADIUS READING ERROR
6360 O No. N No. TRANSFERED (CND)
6055 O No. NOT FOUND 10127 ORIGIN RETURN DISABLED AS HW IS
OPERATING
10269 O NUMBER OUT OF RANGE
10126 ORIGIN RETURN DISABLED AS STEP
7019 OC NONREGISTRY ALARM
FEED IS OPERATING
7001 OC RESPONSE ERROR
6074 OUTPUT OF PROGRAM TO I/O
7000 OC TIME ELAPSED ERROR
6467 OUTPUTTING MODEL BLOCKS
6661 OCCURRENCE OF FILE OPEN ERROR
6475 OUTPUTTING MODEL DATA
(TERMINAL)
1018 OVERCUT CAUSED BY G44
1013 OFFSET CANCELLED (G40) IN G2, G3
COMPENSATION
BLOCK
1026 OVERCUT CAUSED BY G44
6463 OFFSET DATA CANNOT BE
Q-COMPENSATION
TRANSFERED
1016 OVERCUT CAUSED BY OFFSET OR
6462 OFFSET DATA TRANSFERED
TAPER

1042 OVERLAP COMND FOR MACHINE 2905 PORTABLE (FPB) INPUT ERROR (2)
CONTROL 2901 PORTABLE (FPB) NOT CONNECTED
1041 OVERLAP COMND FOR POWER 2902 PORTABLE (FPB) OUTPUT ERROR (1)
SUPPLY
2903 PORTABLE (FPB) OUTPUT ERROR (2)
8 OVERTRAVEL (OT2)
4076 POWDER CLUTCH NEEDS REPLACING
(TN-ALM)
P 4201 POWDER CLUTCH NEEDS REPLACING
2827 P.F. DURING M66-68 R.P.F.? yes:START (TN-ALM)
no:RESET
1097 POWER FAILURE
7917 PALETTE MAGAZINE IS IN STOP
2211 POWER FAILURE DURING M73
CONDITION
10468 PRESS MACHINING COMPLETE OR
7905 PALETTE UNIT ERROR
MACHINING ABORT KEY
10103 PARAMETER INJUSTICE
4025 PREVENTIVE CENTERRING PLATE
6824 PARAMETER SETTING ERROR FOR PROTECT
FORMAT SELECTION
4026 PREVENTIVE HEAD PROTECT
19 PARAMETERS INITIALIZED
2819 PREVENTIVE MAGAZINE & GRIPPER
3017 PEAK CURRENT OVER CLASH
2412 PERIODICAL TENSION ADJUSTMENT 2818 PREVENTIVE SPINDLE & GRIPPER,
COMPLETED MAGAZINE CLASH
2411 PERIODICAL TENSION ADJUSTMENT 6508 PROCESS DATA ACCESS ERROR
STARTED
6503 PROCESS DATA IS EDITING
6828 PG DISK FORMATTING? YES:IN
6505 PROCESS IS NOT STORED
NO:ERASE
27 PROCESS OF POWER FAIL
1004 PLANE INCONSISTENT IN G02,G03
UNCOMPLETELY
COMND
6063 PROGRAM BEING RUN CANNOT BE
6664 PLEASE CHECK OF CHANNEL LINE TO
DELETED
TERMINAL
2060 PLEASE CONFIRM WIRE CUTOFF
DELETED
CONDITION
2061 PLEASE CONFIRM WIRE THREADING
EDITED
CONDITION
6139 PLEASE INPUT "D" TO DELETE
EDITED
6436 PLEASE INPUT [;]+[ADD-IN] OR [;]+[IN]
6135 PROGRAM CLOSING,PLEASE WAIT
2062 PLEASE M6 I/O RETURN
6110 PROGRAM COMPARE ABORTED
6657 PLEASE PUSH F.KEY (TERM RX OR
6108 PROGRAM COMPARE ABORTED
TERM TX)
6106 PROGRAM COMPARE STOPPED
10239 PLEASE SPECIFY O NO. OR N NO.
10561 PROGRAM COPY
10510 PLEASE WAIT FOR PROGRAM CLOSE
END 1166 PROGRAM END
10511 PLEASE WAIT FOR PROGRAM DELETE 6136 PROGRAM ERASING,PLEASE WAIT
END 1165 PROGRAM HEAD
2904 PORTABLE (FPB) INPUT ERROR (1) 6077 PROGRAM I/O ABORTED
306
6092 PROGRAM I/O CANCELLED 10594 REEDITING MAY BE DISABLED

6078 PROGRAM I/O INPUT COMPLETED 2016 REFERENCE HOLE RETRY OVERTIMES
6079 PROGRAM I/O OUTPUT COMPLETED 10061 REGISTRATION FUNCTION DOES NOT
10515 PROGRAM OPEN EXIST (NCAPI RESPONSE ERROR)
10177 PROGRAM RUN MANAGEMENT 10612 REGISTRY READING FROM EXTERNAL

UNREGISTRATION ERROR (AUT) FILE
10521 PROGRAM TRANSFER CANCELLED 10611 REGISTRY WRITING FROM EXTERNAL

FILE
10513 PROGRAM TRANSFER FINISHED
6817 REPLACE? YES:IN KEY NO:ERASE KEY
6452 PROHIBITED LOCKING
10063 REQUEST ALREADY BEING EXECUTED
1182 PROHIBITED MACRO VAL. IN THIS (NCAPI RESPONSE ERROR)
TYPE MACHINE
10131 REQUESTED RUN MODE CHANGE
3045 PULSE CONTROL ABNORMAL FAILED
4037 PUMP INVERTER ABNORMAL 10130 REQUESTED RUN MODE SETTING
4071 PUMP OVERLOAD (P-MAL) FAILURE
2032 PUMPS SWITCHED OFF 3106 RESERVE 1
6666 PUSH COMPLETE OR ABORT END KEY 3107 RESERVE 2
10051 RESOURCE MANAGE. NOT INITIALIZED
Q (NCAPI RESPONSE ERROR)
6465 QUIT & CLOSE ? yes:IN KEY no:ERASE 7915 RESPONSE DATA ERROR
KEY 10012 RESPONSE WAITING TIME-OUT ON NC
SIDE (VMC ACCESS LIBRARY ERROR)
R 1082 RETURN IS ONLY DURING MANUAL
2022 R.W.B/R.P.F M6PQR FORMAT ERROR RUN
1063 RADIUS OVERCUT BY G44 1099 RETURN NOT EXECUTED
6905 RAM DISK FORMATTING? YES:IN KEY 1084 RETURN, RECOVERY W. BREAK NOT IN
NO:ERASE KEY EFFECT
22 RAM ERROR 6612 RIGHT CURSOR KEY INVALID ON THIS

SCREEN
10271 RANDOM READ POSITION OUT OF
RANGE (MDL) 36 ROM-MACRO ERROR
2414 RANGE OVER AT TENSION 34 ROM-MACRO IS NO ENTRY

ADJUSTMENT 35 ROM-MACRO NOT ENOUGH AREA
10101 READ ACCESS FAILED 6848 RS232C COMMUNICATION ERROR
10266 READ LINE CLEARED (MDL) 7900 RS232C EXECUTION
6476 READING BLOCKS 6850 RS232C ILLEGAL PARAMETER
1093 RECOVERY POWER FAILURE (WAIT 6849 RS232C TIME ELAPSED ERROR
FOR PRM No.575) 6847 RS232C UNCONNECTED
1094 RECOVERY POWER FAILURE INVALID 10058 RUN FUNCTION NOT FOUND (NCAPI
1090 RECOVERY WIRE BREAK RESPONSE ERROR)
1092 RECOVERY WIRE BREAK OVERTIMES 10132 RUN MODE CHANGE TIME-OUT
10593 REEDITED PROGRAM READING 4092 RUN MODE LOCKING!
FAILED

10111 RUN MODE NOT DETERMINED YET 10519 SELECT PROGRAM TO BE

TRANSFERRED
S 6862 SELECT RENAME FILE AND PUSH [IN]
KEY
4090 SAFETY GUARD OPEN
10451 SELECT ROTATION MODE
10520 SAME NAME PROGRAM EXISTS.
DELETE IT AND RETRY 6346 SELECT UPPER LEFT CORNER
1076 SAVING OR RESTRATION ERROR OF 10632 SELECTED BLOCK DELETING
INSIDE COORD. 7302 SEND TO EIS NOT OK
5913 SBC DETECTION DUPLICATE AXIS 10270 SEQUENTIAL READ FINISHED (MDL)
DECLARED
5990 SERVO HARDWARE ERROR
5911 SBC DETECTION HORIZONTAL PARITY
10122 SET ERROR OF RUN MOD CHANGE
ALARM
OPE (KEY)
5900 SBC DETECTION NONREGISTRY
10123 SET ERROR OF RUN MOD CHANGE
ALARM
OPE (KEY)
5914 SBC DETECTION TRANSMISSION
10107 SET VALUE OUT OF RANGE
ERROR
10035 SHARED EVENT BETWEEN
5915 SBC DETECTION TRANSMISSION TIME
PROCESSES CANíT ACQUIRED (CLASS
OUT
LIB ERROR)
5912 SBC DETECTION VERTICAL PARITY
10017 SHARED EVENT FAILED (VMC ACCESS
ALARM
LIBRARY ERROR)
5916 SBC DETECTION WATCHDOG ALARM
10016 SHARED EVENT FULL (VMC ACCESS
6338 SCALE DECIDED LIBRARY ERROR)
6352 SCREEN NOT VALID DURING TRACE 7342 SHORT STATE WIRE-WORK
MACHING DRAW
2831 SHUTTER IS CLOSED
10506 SEARCH
2217 SLUG NOT PRESENT AT MAGNET
6604 SEARCH KEY INVALID ON THIS
2024 SLUICE OVERTRAVEL OR MOTOR
SCREEN
CURRENT OVER
3030 SEARCH POWER FUSE TRIP
2025 SLUICE PLATE DRIVING UNIT
3008 SEARCH POWER OVERHEAT ABNORMAL
3007 SEARCH POWER, OVER VOLTAGE 2026 SLUICE PLATE HEIGHT CONTROLED
LIMIT BY Z POS.
6011 SEARCHED BLOCK NOT FOUND 1223 SO MANY G CODE IN GRAPHIC MACRO
2014 SEARCHIN NEXT PROCESS M6 BY M74 CODE
6093 SEARCHING 10419 SPECIFIC EIO NO. NOT FOUND
6861 SELECT COPY FILE AND PUSH [IN] KEY 6058 SPECIFIED CHARACTER STRING NOT
FOUND
6863 SELECT DELETE FILE AND PUSH [IN]
KEY 10554 SPECIFIED CHARACTER STRING NOT
FOUND
6860 SELECT DISK TO MEMORY FILE AND
PUSH [IN] KEY 6468 SPECIFIED CONDITION CARD IS NOT
USED
6345 SELECT LOWER RIGHT CORNER
10415 SPECIFIED CONDITION COMMAND
10448 SELECT MANUAL RUN MODE
OUT OF RANGE
10517 SELECT NC PROGRAM
308
10416 SPECIFIED CONDITION IS OPTIONAL 1523 STOP BEFORE M08

6026 SPECIFIED MACRO VARIABLE No. NOT 1740 STOP STS BY M74, PROCESSES WERE
FOUND SKIPPED
10202 SPECIFIED MODEL DATA NO. OUT OF 2210 STOP STS DUE TO M73
RANGE 6365 STROKE FRAME CANNOT BE
6057 SPECIFIED N No. NOT FOUND DISPLAYED
6480 SPECIFIED O No. IS EDITING 1200 SUB. PRO FORMAT ERROR (L/R, B)
6474 SPECIFIED O No. IS NOT EMPTY 2344 SUCTION NOZZLE ADJUSTMENT
6341 SPECIFIED O No. NOT FOUND (O13904)
10150 SPECIFIED PARAMETER NO. NOT 1811 SYS. RESERVE PRO-CLEARED AT PW

FOUND OFF BY MISTAKE
10421 SPECIFIED PARAMETER NO. NOT 6853 SYSTEM ERROR

FOUND
6355 SPECIFIED PARAMETER NOT FOUND T
10501 SPECIFIED PROGRAM NOT FOUND 2020 TANK DOOR UNLOCK
10212 SPECIFIED RESOURCE AREA FULL 2405 TANK MUST BE FILLED BEFORE
SENSING
10417 SPECIFIED VALUE IS INTERLOCK
ERROR 6062 TAPE ERROR
10213 SPECIFIED VARIABLE NO. NOT FOUND 6080 TAPE READER ERROR
10491 SPECIFIED VARIABLE No. NOT FOUND 6082 TAPE READER NOT READY
10214 SPECIFIED VARIABLE NO. OUT OF 6089 TAPE REWIND DONE
RANGE 6090 TAPE REWIND ERROR
6014 SPECIFY O No. OR N No. BEFORE 2322 TAPER ANGLE 3~15 DEGREE
INPUT KEY
1064 TAPER COMND WITHOUT G41 G42
2821 SPINDLE No. RANGE OVER
6358 TAPER DATA TRANSFERED
2823 SPINDLE START POSITION ERROR
2023 TAPER MODE = 2 ! (= DRAW PLANE)
2825 SPINDLE UNCLAMP MODE
6615 TEN KEY INVALID ON THIS SCREEN
10203 STANDARD CONDITION REWRITING
2400 TENSION ADJUSTMENT COMPLETED
DISABLED (CND)
2416 TENSION ADJUSTMENT PROHIBITED
6478 STANDARD CONDITIONS CANNOT BE
(THIN WIRE)
DELETED
2431 TENSION CONTROL ALARM
7913 START COND. NOT SATISFIED (P/M)
6662 TERMINAL IS BUSY NOW
6433 START COORD. TRANSFERED
6660 TERMINAL IS DISABLE
2315 START POSITION RETURN
1801 TH ERROR AT I/O INPUT
10056 START REGISTRATION FAILED (NCAPI
RESPONSE ERROR) 6800 THE FUNCTION KEY DEPRESSED IS
INVALID
2039 START SUPPLYING TO CLEAN TANK
FOR TANK FILL 10171 THE FUNCTION KEY DEPRESSED IS
INVALID
6500 START, STOP, RESET KEYS ARE
INVALID 1080 THE MANUAL RUN KEY IS INVALID
NOW
1524 STOP AFTER M08
10494 THERE IS NO PAGE TO BE DISPLAYED

3001 THERMAL(K3~K6) TRIPPED 5223 U CONVERTER CURRENT OVER

10542 THIS FUNCTION NOT SUPPORTED 5093 U CONVERTER LOW VOLTAGE
6262 THIS KEY IS INVALID ON HELP DISPLAY 5243 U CONVERTER VOLTAGE OVER
10034 THREAD CANíT START IN ASYNC PROC 5333 U DROOP OVER
(CLASS LIB ERROR) 5513 U EFFECTIVE CURRENT OVER
2410 TIMEUP OF PERIODICAL TENSION 5383 U ENCORDER FEEDBACK
ADJUSTMENT DISCONNECTED
6016 TO CANCEL MDI, PRESS f.c, MDI 5023 U ENCORDER PULSE ERROR
CANCEL KEY
5213 U INVERTER CURRENT OVER
6104 TO CONTINUE,CLEAR KEY-IN LINE OR
ENTER "C" 5103 U MOTOR OVERHEAT
10162 TOOL WORK UNREGISTRATION 5363 U MOTOR REVOLVING SPEED

ERROR (SET) EXCEEDED
2019 TOUCH RETRY OVERTIMES 5573 U OVERSPEED
10125 TOUCH SENS DISABLED AS TOUCH 5013 U P FEEDBACK PULSE ERROR

SENS IS NOT EFFECTIVE 5493 U PEAK CURRENT OVER 1
1540 TRANSFER CAN ONLY IN RESET MODE 5503 U PEAK CURRENT OVER 2
6375 TRANSFER GRAPH. DATA? yes:IN KEY 5543 U PEAK CURRENT OVER 3
no:ERASE KEY 5373 U POSITION FEEDBACK
6801 TRANSFERRING FILE! DISCONNECTED
10512 TRANSFERRING PROGRAM 5073 U REGENERATIVE RESISTOR
2832 TURN OVER IN GRIPPER OVERHEAT
2829 TURNING-OVER POS. OF GRIPPER IS 5953 U SERVO ALARM

AWC MAGAZINE 5963 U SERVO NOT READY
1800 TV ERROR AT I/O INPUT 5923 U SERVO ON/OFF CONDITION ERROR
5063 U TRANSISTOR OVERHEAT
U 5003 U UNDEFINED ALARM
5193 U ASC +15V VOLTAGE ALARM 5523 U UNEFFECTIVE CURRENT OVER
5293 U ASC A/D ERROR ch.1 4103 U ZRN DOG POSITION INCORRECT
5303 U ASC A/D ERROR ch.2 2011 U, V AXIS NOT ZERO BEFORE A.W.T.
5273 U ASC BUS COMMUNICATION ERROR START (M6)
5733 U ASC INVERTER CURRENT OVER 2 1055 U, V COMND ON G2, G3 BLOCK
5603 U ASC PARAMETER INCORRECT 1054 U, V COMND ON TAPER
5803 U ASC TIME OUT 1 10152 UCNV CONVERSION RESULT UNFIXED
5793 U ASC TIME OUT 2 10205 UNDEFINED ERROR (CND)
5783 U ASC TIME OUT 3 10223 UNDEFINED ERROR (MDL)
5253 U ASC WATCHDOG ALARM 10154 UNDEFINED ERROR (SET)
5203 U ASC –15V VOLTAGE ALARM 10129 UNDEFINED ERROR DURING RUN
MODE CHANGE REQUEST
5053 U CIRCUIT PROTECTOR OFF
10148 UNDEFINED ERROR OCCURRED (REF)
5033 U COMMUTATION PULSE ERROR
1045 UNDEFINED G, M COMND
310
10142 UNDEFINED RESOURCE ID V

SPECIFIED(REF)
5194 V ASC +15V VOLTAGE ALARM
10636 UNDER ATTACHMENT
5294 V ASC A/D ERROR ch.1
10045 UNEXPECTED WINAPI ERROR IN
5304 V ASC A/D ERROR ch.2
EVENT WAITING (CLASS LIB ERROR)
5274 V ASC BUS COMMUNICATION ERROR
10160 UNIT AND AXIS ATTRIBUTE
INCONSISTENT 5734 V ASC INVERTER CURRENT OVER 2
10187 UNIT CONVERSION PROCESSING 5604 V ASC PARAMETER INCORRECT
ERROR (CND) 5804 V ASC TIME OUT 1
7912 UNIT NO. ERROR 5794 V ASC TIME OUT 2
6616 UNNECESSARY LETTER ON KEY-IN 5784 V ASC TIME OUT 3
LINE
5254 V ASC WATCHDOG ALARM
10408 UNNECESSARY WORD EXISTS IN
5204 V ASC –15V VOLTAGE ALARM
JUMP COMMAND
5054 V CIRCUIT PROTECTOR OFF
10116 UNREGISTERED ACCURACY
SPECIFIED (KEY) 5034 V COMMUTATION PULSE ERROR
10112 UNREGISTERED POSITION 5224 V CONVERTER CURRENT OVER
INFORMATION ID SPECIFIED (KEY) 5094 V CONVERTER LOW VOLTAGE
10115 UNREGISTERED UNIT SPECIFIED (KEY) 5244 V CONVERTER VOLTAGE OVER
6610 UP CURSOR KEY INVALID ON THIS 5334 V DROOP OVER
SCREEN
5514 V EFFECTIVE CURRENT OVER
2072 UPPER HEAD PUMP ROTATION FREQ.
5384 V ENCORDER FEEDBACK
LIMIT
DISCONNECTED
2037 UPPER HEAD SUBMERGED
5024 V ENCORDER PULSE ERROR
2070 UPPER HEAD WATER PRESS. LOW
5214 V INVERTER CURRENT OVER
4045 UPPER HI PRESS. INVERTER PUMP
5104 V MOTOR OVERHEAT
ABNORMAL
5364 V MOTOR REVOLVING SPEED
4036 UPPER PUMP INVERTER ABNORMAL
EXCEEDED
10631 USE [PASTE] TO INSERT COPY BLOCK
5574 V OVERSPEED
IN CURSOR POS
5014 V P FEEDBACK PULSE ERROR
1051 USE COND. NOT MET FOR ADDITIONAL
AXIS 5494 V PEAK CURRENT OVER 1
6750 USE MASKING PARAMETER NO **** 5504 V PEAK CURRENT OVER 2
(BIT * ) 5544 V PEAK CURRENT OVER 3
10590 USE PORTABLE OPERATION PANEL TO 5374 V POSITION FEEDBACK
CHANGE FEEDRA DISCONNECTED
6479 USER AREA IS FULL 5074 V REGENERATIVE RESISTOR
1812 USER PROGRAM CLEARED AT PW OFF OVERHEAT
BY MISTAKE 5954 V SERVO ALARM
10033 USER SPECIFIED BUFFER POINTER IS 5964 V SERVO NOT READY
NULL (CLASS LIB ERROR)
5924 V SERVO ON/OFF CONDITION ERROR
5064 V TRANSISTOR OVERHEAT

5004 V UNDEFINED ALARM 2432 WIRE IS NOT FED WITH WINDING

5524 V UNEFFECTIVE CURRENT OVER SHAFT RELEASED
4104 V ZRN DOG POSITION INCORRECT 2008 WIRE NOT PRESENT AT OPTICAL
SENSOR (WL-SEN1)
4069 VACUUM UNIT INVERTER ALARM
2002 WIRE REVERSE FEED TIME OVER
10118 VALID AXIS NOT FOUND IN SET
COORD.COMMAND 2005 WIRE WAS REVERSED BUT STILL
TOUCHES WORK
2805 VALID IN AWC SAFETY COVER OPEN
4051 WIR-ST MOTOR OVERLOAD
6630 VALID ONLY WITH OPTIONAL ITEM
1038 WORD DATA ERROR IN G10 BLOCK
2305 VERTICAL ALIGNMNT
6603 WORK COORDINATE CAN ONLY BE
10261 VMC INTERNAL DATA VARIATION SET IN RESET STS
DETECTED (MDL)
6466 WORK COORDINATES TRANSFERED
6823 VOLUME LABEL WITHIN 11
CHARACTERS 2330 WORK DRYING OFF
2331 WORK DRYING ON
W 6359 WORK OFFSET TRANSFERED
2043 WAIT UNTILL WORK TANK FLUID LEVEL 2042 WORK TANK FLUID LEVEL LOW
UP 2045 WORK TANK POSITION IS BELOW FILL
2030 WATER CONDUCTIVITY DOWN LOWER LIMIT
2049 WATER IS OFF 2044 WORK TANK UP/DOWN MOTOR
OVERLOAD
2046 WATER MODE ALLOWING FLUSHING
AT TANK FILL 2021 WORK TANK UPPER LIMIT
2054 WATER OVER-FLOW TO PUMPS STOP 2822 WORK UNCLAMP PROHIBITED AREA
2035 WATER RESERVOIR FILTER NEEDS 2306 WORK ZERO RETURN
REPLACING 10102 WRITE ACCESS FAILED (WRITE-
2033 WATER RESERVOIR LOW PROTECTED DATA, ETC.)
2034 WATER RESERVOIR UPPER 6602 WRITE PROTECTED
LIMITSWITCH BROKEN 1510 WRITE PROTECTED CONDITION
2050 WATER RESERVOIR1 FILTER NEEDS 10106 WRITE-PROTECT STATUS
REPLACING
10161 WRITE-PROTECTED OFFSET
2052 WATER RESERVOIR1, 2 FILTERS NEED SPECIFIED
REPLACING
10105 WRITING ERROR DURING AUTOMATIC
2051 WATER RESERVOIR2 FILTER NEEDS RUN
REPLACING
10104 WRITING ERROR DURING AXIS
6856 WILDCARD(*,?) CAN NOT USE ALLOCATION
1095 WIRE BREAK 7306 WRONG OR DAMAGED EIS CARD
2413 WIRE BREAK AT TENSION MOUNTED
ADJUSTMENT
2063 WIRE BREAK IN M06 X
2029 WIRE FORWARD FEED LENGTH OVER 5191 X ASC +15V VOLTAGE ALARM
2006 WIRE FORWARD FEED TIME OVER 5291 X ASC A/D ERROR ch.1
5301 X ASC A/D ERROR ch.2
312
5271 X ASC BUS COMMUNICATION ERROR Y

5731 X ASC INVERTER CURRENT OVER 2 5192 Y ASC +15V VOLTAGE ALARM
5601 X ASC PARAMETER INCORRECT 5292 Y ASC A/D ERROR ch.1
5801 X ASC TIME OUT 1 5302 Y ASC A/D ERROR ch.2
5791 X ASC TIME OUT 2 5272 Y ASC BUS COMMUNICATION ERROR
5781 X ASC TIME OUT 3 5732 Y ASC INVERTER CURRENT OVER 2
5251 X ASC WATCHDOG ALARM 5602 Y ASC PARAMETER INCORRECT
5201 X ASC –15V VOLTAGE ALARM 5802 Y ASC TIME OUT 1
5051 X CIRCUIT PROTECTOR OFF 5792 Y ASC TIME OUT 2
5031 X COMMUTATION PULSE ERROR 5782 Y ASC TIME OUT 3
5221 X CONVERTER CURRENT OVER 5252 Y ASC WATCHDOG ALARM
5091 X CONVERTER LOW VOLTAGE 5202 Y ASC –15V VOLTAGE ALARM
5241 X CONVERTER VOLTAGE OVER 5052 Y CIRCUIT PROTECTOR OFF
5331 X DROOP OVER 5032 Y COMMUTATION PULSE ERROR
5511 X EFFECTIVE CURRENT OVER 5222 Y CONVERTER CURRENT OVER
5381 X ENCORDER FEEDBACK 5092 Y CONVERTER LOW VOLTAGE
DISCONNECTED
5242 Y CONVERTER VOLTAGE OVER
5021 X ENCORDER PULSE ERROR
5332 Y DROOP OVER
5211 X INVERTER CURRENT OVER
5512 Y EFFECTIVE CURRENT OVER
5101 X MOTOR OVERHEAT
5382 Y ENCORDER FEEDBACK
5361 X MOTOR REVOLVING SPEED DISCONNECTED
EXCEEDED
5022 Y ENCORDER PULSE ERROR
5571 X OVERSPEED
5212 Y INVERTER CURRENT OVER
5011 X P FEEDBACK PULSE ERROR
5102 Y MOTOR OVERHEAT
5491 X PEAK CURRENT OVER 1
5362 Y MOTOR REVOLVING SPEED
5501 X PEAK CURRENT OVER 2 EXCEEDED
5541 X PEAK CURRENT OVER 3 5572 Y OVERSPEED
5371 X POSITION FEEDBACK 5012 Y P FEEDBACK PULSE ERROR
DISCONNECTED
5492 Y PEAK CURRENT OVER 1
5071 X REGENERATIVE RESISTOR
OVERHEAT
5951 X SERVO ALARM
5372 Y POSITION FEEDBACK
5961 X SERVO NOT READY
DISCONNECTED
5921 X SERVO ON/OFF CONDITION ERROR
5072 Y REGENERATIVE RESISTOR
5001 X UNDEFINED ALARM OVERHEAT
5521 X UNEFFECTIVE CURRENT OVER 5952 Y SERVO ALARM
4101 X ZRN DOG POSITION INCORRECT 5962 Y SERVO NOT READY
5061 XTRANSISTOR OVERHEAT 5922 Y SERVO ON/OFF CONDITION ERROR
5062 Y TRANSISTOR OVERHEAT

5002 Y UNDEFINED ALARM 5375 Z POSITION FEEDBACK

5522 Y UNEFFECTIVE CURRENT OVER DISCONNECTED
4102 Y ZRN DOG POSITION INCORRECT 5075 Z REGENERATIVE RESISTOR

OVERHEAT
5955 Z SERVO ALARM
Z
5965 Z SERVO NOT READY
5195 Z ASC +15V VOLTAGE ALARM
5925 Z SERVO ON/OFF CONDITION ERROR
5295 Z ASC A/D ERROR ch.1
4086 Z STROKE EXPANDED!
5305 Z ASC A/D ERROR ch.2
4082 Z STROKE EXPANDING!
5275 Z ASC BUS COMMUNICATION ERROR
4084 Z STROKE EXPANSION IMPOSSIBLE!
5735 Z ASC INVERTER CURRENT OVER 2
4085 Z STROKE RESTRICTED!
5605 Z ASC PARAMETER INCORRECT
4081 Z STROKE RESTRICTING!
5805 Z ASC TIME OUT 1
4083 Z STROKE RESTRICTION IMPOSSIBLE!
5065 Z TRANSISTOR OVERHEAT
5005 Z UNDEFINED ALARM
5255 Z ASC WATCHDOG ALARM
5525 Z UNEFFECTIVE CURRENT OVER
5205 Z ASC –15V VOLTAGE ALARM
2320 Z WORK ZERO RETURN ? yes:START
4031 Z AXIS LOCK OR C AXIS LOCK ON
KEY no:RESET
4087 Z AXIS LOWERS DURING REFERENCE
4105 Z ZRN DOG POSITION INCORRECT
POSITION RETURN
1048 ZERO RETURN NOT EXECUTED
5055 Z CIRCUIT PROTECTOR OFF
5035 Z COMMUTATION PULSE ERROR
5225 Z CONVERTER CURRENT OVER
5095 Z CONVERTER LOW VOLTAGE
5245 Z CONVERTER VOLTAGE OVER
5335 Z DROOP OVER
5515 Z EFFECTIVE CURRENT OVER
5385 Z ENCORDER FEEDBACK
DISCONNECTED
5025 Z ENCORDER PULSE ERROR
5215 Z INVERTER CURRENT OVER
5105 Z MOTOR OVERHEAT
5365 Z MOTOR REVOLVING SPEED
EXCEEDED
5575 Z OVERSPEED
5015 Z P FEEDBACK PULSE ERROR
5495 Z PEAK CURRENT OVER 1
314

Alarm Message

Uploaded by

Document Information

Original Description:

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Alarm Message

Uploaded by

Copyright:

Available Formats

INSTRUCTION MANUAL

WIRE ELECTRICAL DISCHARGE MACHINE

MAKINO MILLING MACHINE CO., LTD.

1. In general, function not covered by this manual cannot be used.

1.1 Trouble Remedy List .............................................................................................. 2

1.2 Resetting Method ................................................................................................... 3

1.3 Dialog Box .............................................................................................................. 4

1.4 Classification of Message Numbers ..................................................................... 5

1.5 Confirming Contents of Alarm .............................................................................. 5

1.6 Confirming Conditions in Which Alarm Occurs .................................................. 6

1.7 Operation Buttons and Keyboard ......................................................................... 7

2. DESCRIPTION OF MESSAGES ............................................................................ 8

3. ALARM MESSAGE (INDEX) .................................................................................. 290

1. HOW TO SEE THE ALARM MESSAGE LIST

No. Name Level Reset

Number : Indicates the message number.

* The number and name are displayed on the screen.

How to See The Alarm Message List 1

1.1 Trouble Remedy List

Trouble remedy (minor major)

1.2 Resetting Method

(1) Alarm 1, 2, 3 : Press RESET key.

Or, if the key-in line is selected

RESET : Deletes message and stops action at this time.

The operation cannot continue.

How to See The Alarm Message List 3

1.3 Dialog Box

Dialog box display example

Error occurred. Reboot the NC unit. Operation guidance

10001 MESSAGE TEXT NOT FOUND Guide message

Error handling, if continued

Error value: Error value

Kind and meaning of buttons

1.4 Classification of Message Numbers

Number Group Contents

0001 – 0999 (Emerency stop levels)

1.5 Confirming Contents of Alarm

How to See The Alarm Message List 5

1.6 Confirming Conditions in Which Alarm Occurs

1.7 Operation Buttons and Keyboard

MGW-R generator MGW-K generator Description

STOP STOP Stops functional operation

RESET RESET Resets the alarm

WARN RESET WARN RESET Resets the warning and guide

BUZZER OFF BUZZER OFF Stops buzzer sounding

SEARCH Command key for search

DEL ERASE Command key for erasure

ADD IN Command key for addition

ENTER IN Command key for input

HELP HELP Help display

PAGE UP + Page changeover (+)

PAGE DOWN – Page changeover (–)

How to See The Alarm Message List 7

No. Name Level Reset

0001 EMERGENCY STOP Alarm 3 See Remedy.

Description : The EMERGENCY STOP signal was turned on (ESP=1).

Causes : (1) The EMERGENCY STOP switch was pressed.

Remedy : In the case of (1), reset the EMERGENCY STOP switch.

No. Name Level Reset

0002 NC, +24 VDC DROP Alarm 3 See Remedy.

0003 NC, +15 VDC DROP Alarm 3 See Remedy.

0004 NC, –15 VDC DROP Alarm 3 See Remedy.

Causes : (1) Defective switching power supply.
