Studies in Computational Intelligence 1074
Roger Lee Editor
Software
Engineering,
Artificial Intelligence,
Networking and
Parallel/Distributed
Computing
Studies in Computational Intelligence
Volume 1074
Series Editor
Janusz Kacprzyk, Polish Academy of Sciences, Warsaw, Poland
The series “Studies in Computational Intelligence” (SCI) publishes
new developments and advances in the various areas of computational
intelligence—quickly and with a high quality. The intent is to cover the theory,
applications, and design methods of computational intelligence, as embedded in
the fields of engineering, computer science, physics and life sciences, as well as
the methodologies behind them. The series contains monographs, lecture notes and
edited volumes in computational intelligence spanning the areas of neural networks,
connectionist systems, genetic algorithms, evolutionary computation, artificial
intelligence, cellular automata, self-organizing systems, soft computing, fuzzy
systems, and hybrid intelligent systems. Of particular value to both the contributors
and the readership are the short publication timeframe and the world-wide
distribution, which enable both wide and rapid dissemination of research output.
Indexed by SCOPUS, DBLP, WTI Frankfurt eG, zbMATH, SCImago.
All books published in the series are submitted for consideration in Web of Science.
Roger Lee
Editor
Software Engineering,
Artificial Intelligence,
Networking
and Parallel/Distributed
Computing
Editor
Roger Lee
Software Engineering and Information
Technology Institute
Central Michigan University
Mt. Pleasant, MI, USA
ISSN 1860-949X ISSN 1860-9503 (electronic)

Studies in Computational Intelligence
ISBN 978-3-031-19603-4 ISBN 978-3-031-19604-1 (eBook)
https://doi.org/10.1007/978-3-031-19604-1
© The Editor(s) (if applicable) and The Author(s), under exclusive license to Springer Nature
Switzerland AG 2023
This work is subject to copyright. All rights are solely and exclusively licensed by the Publisher, whether
the whole or part of the material is concerned, specifically the rights of translation, reprinting, reuse
of illustrations, recitation, broadcasting, reproduction on microfilms or in any other physical way, and
transmission or information storage and retrieval, electronic adaptation, computer software, or by similar
or dissimilar methodology now known or hereafter developed.
The use of general descriptive names, registered names, trademarks, service marks, etc. in this publication
does not imply, even in the absence of a specific statement, that such names are exempt from the relevant
protective laws and regulations and therefore free for general use.
The publisher, the authors, and the editors are safe to assume that the advice and information in this book
are believed to be true and accurate at the date of publication. Neither the publisher nor the authors or
the editors give a warranty, expressed or implied, with respect to the material contained herein or for any
errors or omissions that may have been made. The publisher remains neutral with regard to jurisdictional
claims in published maps and institutional affiliations.
This Springer imprint is published by the registered company Springer Nature Switzerland AG
The registered company address is: Gewerbestrasse 11, 6330 Cham, Switzerland
Preface
The purpose of the 23rd ACIS International Summer Conference on Software

Engineering, Artificial Intelligence, Networking and Parallel/Distributed Computing
(SNPD2022-Summer) held during July 4–6, 2022, in Kyoto City, is aimed at bringing
together researchers and scientists, businessmen and entrepreneurs, teachers and
students to discuss the numerous fields of computer science, and to share ideas and
information in a meaningful way. This Conference on Software Engineering, Artifi-
cial Intelligence, Networking and Parallel/Distributed Computing discussed a wide
range of issues with significant implications, from Artificial Intelligence to Commu-
nication Systems and Networks, Embedded Systems, Data Mining and Big Data,
Data driven business models, Data privacy and security issues, etc.
This publication captures 15 of the conference’s most promising papers, and we
impatiently await the important contributions that we know these authors will bring
to the field.
In the chapter “A-IDE: A Non-intrusive Cross-Platform Development Environ-
ment for AVR Programming in Assembly”, Antoine Bossard proposes a A-IDE,
a non-intrusive cross-platform development environment for AVR programming in
assembly, importantly retaining the pedagogical principles of popular development
environments, such as Arduino’s, support only high-level languages like C and C++.
They show that the proposed system outperforms existing ones from the disk space
requirement point of view and that it is on par with those with respect to memory
(RAM) utilization.
In the chapter “Develop a Horizontal Virtual Frame by Adding Field of View
Restrictions to Reduce VR Sickness”, Hexi Huang presents a method for preventing
VR sickness based on the previous development of the virtual horizontal frame. On
the basis of confirming that the virtual horizontal frame has a good effect on VR
sickness, he further studied the effect of restricting part of the field of view.
In the chapter “Represent Score as the Measurement of User Influence on Twitter”,
Yuto Noji, Ryotaro Okada and Takafumi Nakanishi present a novel method for quan-
tifying a user’s ability to spread information based on the number of Retweets (RTs)
and Likes they receive on Twitter. In this novel method, they propose a method for
extracting indicators that show the diffusion power, not of tweets alone, but users as
v
vi Preface
a unit, by measuring the ratio of the number of RTs and Likes based on the number
of RTs and Likes of users in the past.
In the chapter “The Experience of Developing a FAT File System Module
in the Rust Programming Language”, Shuichi Oikawa describes the experience of
developing the FAT file system as a kernel module in Rust employing Rust for Linux
as a basis of the development. They performed the experiments to measure its execu-
tion costs, and found that its performance is comparable with the original FAT file
system written in C.
In the chapter “Factors Influencing Consumers’ Online Grocery Shopping Under
the New Normal”, Satoshi Nakano aims to assess the psychological factors that
influence consumers’ actual online grocery purchases under the new normal by
combining purchase panel data and survey data. This study confirms that online
grocery purchase amount is affected by traditional utilitarian channel choice factors
including perceived risk, search cost, price-consciousness and quality-consciousness.
In the chapter “Skeletal Muscle Segmentation at the Third Lumbar Vertebral Level
in Radiotherapy CT Images”, Xuzhi Zhao, Haizhen Yue, Yi Du, Shuang Hou, Weiwei
Du and Yahui Peng propose a computer algorithm to segment skeletal muscles at
the third lumbar vertebral (L3) level in radiotherapy computed tomography (CT)
images. Included in the study are 20 patients who were diagnosed with rectal cancer
and their pelvic CT images were acquired with a radiotherapy CT scanner.
In the chapter “Speed-up Single Shot Detector on GPU with CUDA”, Chenyu
Wang, Toshio Endo, Takahiro Hirofuchi and Tsutomu Ikegami implemented a Single
Shot Multibox Detector (SSD) using GPU with CUDA. They have improved the
object detection speed of SSD, which is one of the most regularly used object
detection frameworks.
In the chapter “An Empirical Study on the Economic Factors Affecting
on the Export of Defense Industry Using Hofstede’s Culture Dimension Theory”,
Taeyeon Kim, Dongcheol Kim, Jaehwan Kwon and Gwangyong Gim propose the
necessity of considering the cultural factors of the countries listed to export in order
to establish a defense export marketing strategy effectively. To support the proposal,
the defense export marketing strategies and purchasing models of the other countries,
that are not clearly established at present, were proposed and partially verified in this
thesis by conducting statistical analysis using data related to defense, national and
military size of each country in the world.
In the chapter “A Study on the Application of Blockchain Technology in Non-gov-
ernmental Organizations”, Minwoo Lee, Saeyeon Lee, Heewon Lee and Gwangyong
Gim use block chain technology to study the market trend of Non-Profit Organiza-
tions (NGOs). They present the implications of data for introducing and utilizing
blockchain technology to non-profit organizations (NGOs) in the future and discussed
the limitations of this study and future research tasks.
In the chapter “Confidential Documents Sharing Model Based on Blockchain
Environment”, Sung-Hwa Han proposes a model that can share confidential docu-
ments in a blockchain environment. The proposed confidential document sharing
model operates on the blockchain platform and has the advantage of not using a key
management server.
Preface vii
In the chapter “Distance Based Clustering in Wireless Sensor Network”, Joong Ho

Lee proposes a single unit distance based two-hop clustering method for clustering
and analyzes the energy persistence of sensor nodes in the formed clusters. The
proposed cluster formation method can efficiently manage operational energy by
improving the non-uniformity of cluster groups. And their paper shows comparison
results between the conventional and proposed schemes of clustering algorithms.
In the chapter “Study on OSINT-Based Security Control Monitoring Utilization
Plan”, DAIN Lee and Hoo-Ki Lee present the definition and concept of OSINT,
and utilization plans in security monitor including characteristics are studied and
presented, and OSINT information collection tools are identified and analyzed.
Through this, OSINT-based security monitor utilization plans and considerations
are presented.
In the chapter “A Study on the Strategy of SWOT Extraction in the Metavers
Platform Review Data: Using NLP Techniques”, Jina Lee, Euntack Im, Inmo Yeo
and Gwangyong Gim propose a framework that addresses the major shortcomings of
traditional SWOT analysis through NLP based on review data from Metaverse appli-
cations. The framework presented in this study presents ways to establish business
strategic tools using secondary data and provides implications for important factors
in building a Metaverse application environment.
In the chapter “Does Facial Expression Accurately Reveal True Emotion?
Evidence from EEG Signal”, Huy Tung Phuong, Yangyoung Kun, Jisook Kim and
Gwangyong Gim conduct an experiment to collect facial expression data and EEG
signals of the participant. The results indicate that not all kinds of basic emotions
were expressed in facial expressions in the experiment environment. The study shows
the problems faced by facial emotion recognition systems and proposes future works
to improve the efficiency of those systems.
In the chapter “NSGA-II-AMO: A Faster Genetic Algorithm for QWSCP”, Zehui
Feng, Bei Wang, Mingjian Chen and Qi Chen propose an improved NSGA-II-AMO
algorithm, which uses an adaptive mutation operator to complete the mutation process
when generating children in the NSGA-II algorithm, so that the mutation probability
adaptively changes with different distributions of data, effectively improving the
search speed at the beginning of population iteration.
They compare the NSGA-II-AMO algorithm cross-sectionally with the PSO algo-
rithm, the NSGA-II algorithm and the ABC algorithm, and the adaptive mutation
operator achieves improved convergence with guaranteed distributivity.
It is our sincere hope that this volume provides stimulation and inspiration, and
that it will be used as a foundation for works to come.
Mount Pleasant, USA Roger Lee

June 2022
Contents
A-IDE: A Non-intrusive Cross-Platform Development

Environment for AVR Programming in Assembly . . . . . . . . . . . . . . . . . . . . 1
Antoine Bossard
Develop a Horizontal Virtual Frame by Adding Field of View
Restrictions to Reduce VR Sickness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Hexi Huang
Represent Score as the Measurement of User Influence on Twitter . . . . . 31
Yuto Noji, Ryotaro Okada, and Takafumi Nakanishi
The Experience of Developing a FAT File System Module
in the Rust Programming Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Shuichi Oikawa
Factors Influencing Consumers’ Online Grocery Shopping Under
the New Normal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Satoshi Nakano
Skeletal Muscle Segmentation at the Third Lumbar Vertebral
Level in Radiotherapy CT Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Xuzhi Zhao, Haizhen Yue, Yi Du, Shuang Hou, Weiwei Du,
and Yahui Peng
Speed-Up Single Shot Detector on GPU with CUDA . . . . . . . . . . . . . . . . . . 89
Chenyu Wang, Toshio Endo, Takahiro Hirofuchi, and Tsutomu Ikegami
An Empirical Study on the Economic Factors Affecting
on the Export of Defense Industry Using Hofstede’s Culture
Dimension Theory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Taeyeon Kim, Dongcheol Kim, Jaehwan Kwon, and Gwangyong Gim
A Study on the Application of Blockchain Technology
in Non-governmental Organizations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Minwoo Lee, Saeyeon Lee, Heewon Lee, and Gwangyong Gim
ix
x Contents
Confidential Documents Sharing Model Based on Blockchain

Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Sung-Hwa Han
Distance Based Clustering in Wireless Sensor Network . . . . . . . . . . . . . . . . 145
Joong Ho Lee
Study on OSINT-Based Security Control Monitoring Utilization
Plan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Dain Lee and Hoo-Ki Lee
A Study on the Strategy of SWOT Extraction in the Metavers
Platform Review Data: Using NLP Techniques . . . . . . . . . . . . . . . . . . . . . . . 173
Jina Lee, Euntack Im, Inmo Yeo, and Gwangyong Gim
Does Facial Expression Accurately Reveal True Emotion?
Evidence from EEG Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
Huy Tung Phuong, Yangyoung Kun, Jisook Kim, and Gwangyong Gim
NSGA-II-AMO: A Faster Genetic Algorithm for QWSCP . . . . . . . . . . . . . 203
Zehui Feng, Bei Wang, Mingjian Chen, and Qi Chen
Author Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215

Contributors
Antoine Bossard Graduate School of Science, Kanagawa University, Hiratsuka,

Japan
Mingjian Chen College of Computer Science and Technology, Zhejiang Univer-
sity, Hangzhou, China
Qi Chen College of Computer Science and Technology, Zhejiang University,
Hangzhou, China
Weiwei Du Department of Information Science, Kyoto Institute of Technology,
Kyoto, Japan
Yi Du Department of Radiation Oncology, Peking University Cancer Hospital and
Institute, Beijng, China
Toshio Endo Tokyo Institute of Technology, Tokyo, Japan
Zehui Feng Polytechnic Institude, Zhejiang University, Hangzhou, China
Gwangyong Gim Department of Business Administration, Soongsil University,
Seoul, South Korea
Sung-Hwa Han Depatment of Information Security, Tongmyong University Busan,
Busan, South Korea
Takahiro Hirofuchi National Institute of Advanced Industrial Science and Tech-
nology (AIST), Tokyo, Japan
Shuang Hou School of Electronic and information Engineering, Beijing Jiaotong
University, Beijng, China
Hexi Huang Department of Information Science, Aichi Institute of Technology,
Toyota, Japan
Tsutomu Ikegami National Institute of Advanced Industrial Science and Tech-
nology (AIST), Tokyo, Japan
xi
xii Contributors
Euntack Im Department of Business Administration, Soongsil University, Seoul,

South Korea
Dongcheol Kim Department of IT Policy and Management, Soongsil Univ. Seoul,
Seoul, South Korea
Jisook Kim Management Planning HQ, Soongsil University, Seoul, South Korea
Taeyeon Kim Department of Business Administration, Soongsil University Seoul,
Seoul, South Korea
Yangyoung Kun Department of IT Policy and Management, Soongsil University,
Seoul, South Korea
Jaehwan Kwon Department of IT Policy and Management, Soongsil Univ. Seoul,
Seoul, South Korea
Dain Lee Department of T&D Security, Daejeon-Si, South Korea
Heewon Lee Department of IT Policy and Management, Soongsil University Seoul,
Seoul, South Korea
Hoo-Ki Lee Department of Cyber Security Engineering, Konyang University
Nonsan-Si, Nonsan-Si, South Korea
Jina Lee Department of Business Administration, Soongsil University, Seoul,
South Korea
Joong Ho Lee Depatment of AI, Yongin University, Yongin-Si, South Korea
Minwoo Lee Department of IT Policy and Management, Soongsil University Seoul,
Seoul, South Korea
Saeyeon Lee Department of IT Policy and Management, Soongsil University Seoul,
Seoul, South Korea
Takafumi Nakanishi The Tokyo Foundation for Policy Research, Department of
Data Science, Musashino University, Tokyo, Japan
Satoshi Nakano Faculty of Economics, Meiji Gakuin University, Tokyo, Japan
Yuto Noji The Tokyo Foundation for Policy Research, Department of Data Science,
Musashino University, Tokyo, Japan
Shuichi Oikawa School of Industrial Technology, Advanced Institute of Industrial
Technology, Tokyo, Japan
Ryotaro Okada The Tokyo Foundation for Policy Research, Department of Data
Science, Musashino University, Tokyo, Japan
Yahui Peng School of Electronic and information Engineering, Beijing Jiaotong
Contributors xiii
Huy Tung Phuong Department of Business Administration, Soongsil University,

Seoul, South Korea
Bei Wang College of Computer Science and Technology, Zhejiang University,
Hangzhou, China
Chenyu Wang Tokyo Institute of Technology & National Institute of Advanced
Industrial Science and Technology (AIST), Tokyo, Japan
Inmo Yeo Samsung Town Finance Center, Samsung Securities Co., Ltd., Seoul,
South Korea
Haizhen Yue Department of Radiation Oncology, Peking University Cancer
Hospital and Institute, Beijng, China
Xuzhi Zhao School of Electronic and information Engineering, Beijing Jiaotong
A-IDE: A Non-intrusive Cross-Platform
Development Environment for AVR
Programming in Assembly
Antoine Bossard
Abstract Minimalistic devices such as microcontrollers make a large part of the

Internet of things (IoT), for instance to build sensors and sensor networks. Due to
severely limited resources, especially memory, microcontroller programming faces
various restrictions, such as hampered graphical data processing. In order to cir-
cumvent those weaknesses, direct programming of these devices with the assembly
language has proven effective. Because popular development environments, such
as Arduino’s, support only high-level languages like C and C++, we propose in
this paper A-IDE, a non-intrusive cross-platform development environment for AVR
programming in assembly, importantly retaining the pedagogical principles of those
existing popular solutions. Nowadays, microcontroller programming has indeed a
high educative value: refer, for example, to the BBC micro:bit and Arduino Uno, to
only cite a few. It is then quantitatively shown that the proposed system outperforms
existing ones from the disk space requirement point of view and that it is on a par
with those with respect to memory (RAM) utilisation.
Keywords Microcontroller · Sensor · Atmel · Microchip · Arduino · 8-bit ·

ASM · IoT
1 Introduction
Sensors and sensor networks are an important part of the Internet of things (IoT).
Sensors are often minimalistic devices based on cost-effective chips such as, typically,
microcontrollers. In order to reduce their cost as well as their power consumption,
such particular hardware comes with severely limited resources, especially memory.
Hence, microcontroller programming has to do with various restrictions, such as
the absence of libraries, let alone of an operating system. In order to circumvent
those inherent weaknesses, direct programming of these devices with the assembly
language has been shown to be effective [1, 3].
A. Bossard (B)
Graduate School of Science, Kanagawa University, 2946 Tsuchiya, Hiratsuka 259-1293, Japan
e-mail: abossard@kanagawa-u.ac.jp
© The Author(s), under exclusive license to Springer Nature Switzerland AG 2023 1

R. Lee (ed.), Software Engineering, Artificial Intelligence, Networking
and Parallel/Distributed Computing, Studies in Computational Intelligence 1074,
https://doi.org/10.1007/978-3-031-19604-1_1
2 A. Bossard
Microcontrollers based on the AVR architecture have proven popular over the
years, notably due to the widespread usage of the Arduino Uno boards equipped
with the ATmega328P microcontroller of Microchip Technology [2, 11]. The AVR
instruction set architecture (ISA) relies on the reduced instruction set computer
(RISC) principle; it is an 8-bit architecture [12]. (It can be noted though that a
32-bit version, AVR32, which is only partly related to AVR, did also exist but is not
supported any more.)
In addition, popular development environments for microcontrollers support high-
level languages such as C/C++ (e.g. the Arduino development environment [8]),
Python (e.g. Python Editor for BBC micro:bit [5]) and even visual programming
(e.g. Scratch for BBC micro:bit [9]). Combined with an accessible user interface,
these make performant solutions for general programming educational purposes.
However, they are less fit for, say, computer architecture lectures of undergradu-
ate computer science curricula. In this case, a precise understanding of hardware
units and their operation is required, which is why directly relying on the assembly
language is definitely meaningful in such a context [4, 6, 15].
The objective of this research project is thus to provide a non-intrusive, cross-
platform development environment for AVR programming in assembly which fea-
tures a high accessibility so as to be suitable for educational environments and appli-
cations. The proposed development environment is neither just a front-end nor just
a code editor, it is a combination of both, and with additional, specific features for
AVR programming in assembly. It is an integrated development environment (IDE).
We have called it A-IDE.
The rest of this paper is organised as follows: preliminary information is given in
Sect. 2. The proposal is described in detail in Sect. 3 and quantitatively evaluated in
Sect. 4. Finally, Sect. 5 concludes this paper.
2 Preliminaries
AVR programming relies in general on the tool chain provided by elements of the
GNU Binutils collection, namely the assembler avr-as from the GNU as assem-
bler collection, the linker avr-ld from GNU ld, the machine code translator
avr-objcopy from GNU objcopy and the machine code uploader avrdude.
In addition, A-IDE relies on the machine code size calculation utility avr-size
from GNU size.
For the sake of simplicity, portability and even robustness, these tools of the GNU
Binutils collection are purposefully not bundled with A-IDE, although they could
easily be, and so it is required to have them installed beforehand on the system. In
addition, the operating system driver to communicate with the microcontroller (USB
serial driver) also needs to be separately installed. These two prerequisites can be
easily cleared by installing, for example, the Arduino IDE, or they can be addressed
directly by manually installing these components in case memory usage is a concern
(see Sect. 4).
A-IDE: A Non-intrusive Cross-Platform Development Environment … 3
3 System Description
3.1 The User Interface
Because education is one important objective of microcontroller programming, A-

IDE features a user-friendly interface suited for this pedagogical matter as shown
by its proximity with, for instance, Arduino’s integrated development environment
and Python Editor for micro:bit, and by the educational projects records of these two
sample development solutions. As illustrated in Fig. 1, A-IDE’s interface consists of
a menu bar, a tool bar, an editor panel and an output panel.
The menu bar includes conventional features to load (e.g. open, save, reload) and
edit (e.g. undo, copy, paste, find) source code files.
The tool bar shows the current line number, that is that of the caret, the name of
the file being edited and an indicator of the saved/unsaved state thereof, space for an
information message to show, for instance, the size of the generated machine code,
and the build and upload buttons (see Sect. 3.3).
The editor panel is where the edition of the source code file happens. This com-
ponent is at the core of the proposal and as such it is described in detail below in
Sect. 3.2.
Finally, the output panel, which can be hidden if so wished by the user, displays
build- and output-related information.
So, a simple, conventional and intuitive interface. Note that widgets (controls)
native to the operating system that runs A-IDE are used to build the interface so as
to flatten the learning curve of the user. The sizes of the panels, and thus of the main
window, can be freely adjusted.
Figure 1 illustrates the case of the Microsoft Windows operating system. A similar
illustration this time in the case of the Linux operating system with the Ubuntu
distribution running on the Windows Subsystem for Linux (WSL) is given in Fig. 5
in appendix.
3.2 The Edition Component
Syntax colouring has been realised with the color:text% class of Racket’s
framework library and with the lexer feature provided by the parser-tools
library. Assembler directives, instructions, registers, numeric values, labels and com-
ments (both single and multiline) are automatically detected and emphasised (refer
to Fig. 1).
The conventional text edition operations have been implemented as well: for
example, text selection for the cut, copy and paste trio, the undo and redo duo, and a
bidirectional text search feature. In addition, deletion of the current line and deletion
of the rest of the current line are two other editing features provided in the editor
panel. The number of the line where the caret is located is shown in the tool bar
4 A. Bossard
menu
bar
tool
bar
editor
panel
output
panel
Fig. 1 An overview of the accessible user interface of A-IDE. This screenshot illustrates the case
of the Microsoft Windows operating system
as presented earlier. This is an important feature especially when debugging: error

messages from the assembler usually mention the number of the line that includes
faulty code.
The editor component of A-IDE also features optional automatic line wrapping
(i.e. soft wrap, which is exemplified in Fig. 1 by the small arrows on the right hand
side of the editor panel). And, it has extensive Unicode support.
3.3 The Build and Upload Component
3.3.1 Preferences
First and foremost, the tool chain that was described in Sect. 2 can be configured in the
preferences dialog of A-IDE; refer to Fig. 2. The path of each of all the components of
the tool chain (i.e. avr-as, avr-ld, avr-objcopy, avr-size and avrdude)
is specified, and either highlighted in green or red to indicate a successful setup or
not, respectively. The user is given the possibility to use a file selection dialog to
avoid typing in the full path. It is recalled that accessibility is essential to A-IDE.
In addition, the user can select which microcontroller is targeted, for instance
the ATmega328P chip, and which programmer to use. Once again for accessibility
reasons, a list of supported devices is provided, in other words, the user is not required
to type in the corresponding string constant (value). Of course, the connection port
(e.g. COM port on Microsoft Windows) of the device can also be declared, albeit
manually this time.
Fig. 2 The preferences dialog of A-IDE, which is used to configure, when necessary, the build and
upload tool chain
6 A. Bossard
3.3.2 Additional Technical Details
The build and upload process is conducted asynchronously: a second thread is started
to refrain from freezing the main thread, which is notably responsible for the respon-
siveness of the user interface. This is thus critical so as to retain system usability.
Technically, this is achieved with the thread function of Racket.
In addition, the build and upload commands, run in this second thread, are also
called in a non-blocking manner in order to retrieve their respective output data as
they are emitted. Otherwise, such data would be available only once the command
has finished its execution. As a result, it is possible to track in detail the execution
progress of the build and upload commands. Technically, this is achieved with the
subprocess function of Racket, and its siblings such as subprocess-wait
and subprocess-status.
Besides, the standard output and standard error streams are merged with the
merge-input function and are thus both redirected to A-IDE, the parent (call-
ing) process. Their content is displayed in the output panel.
Furthermore, the upload process can be aborted since avrdude could enter a
“retry loop” upon failure, for instance when the connection to the microcontroller
cannot be established. The flow of the build and upload thread is illustrated in Fig. 3;
each element of the tool chain is run asynchronously with this thread, which is thus
operating in a non-blocking mode.
Regarding the building process, any .eeprom section as output by the linker
avr-ld is excluded with the translation utility avr-objcopy as such a section
is not bound for the program memory in flash, obviously. But since programming
directly in assembly, the presence of an .eeprom section is unlikely, unless so
desired by the user.
3.4 System Requirements
As mentioned previously, the realised system is cross-platform: thanks to the Racket

language and its portable libraries, A-IDE can be seamlessly used on Microsoft Win-
dows, Apple MacOS and other Unix-based operating systems. Refer, for example,
to Figs. 1 and 5 for an illustration. In addition, both 32-bit and 64-bit systems are
supported. There are no specific CPU, RAM and so on requirements: a computer
that is modern enough will most likely do. For instance, only about 64.2 MB of free
disk space are required in the case of Microsoft Windows to run A-IDE. Additional
details, regarding system requirements, which we obtained after evaluation of the
proposal are given next in Sect. 4.
Fig. 3 Flow of the build and upload thread. Each element of the tool chain is run asynchronously
with this thread, which is thus non-blocking
4 Comparison to Related Systems and Evaluation
We use native controls unlike the Arduino IDE and Python Editor for micro:bit as
such controls are desirable to flatten the learning curve of the user: the system user
is already well accustomed to them. More generally, native controls are expected in
various scenarios [7, 10].
The installation package of A-IDE (i.e. the corresponding ZIP file) for Microsoft
Windows takes only 36.0 MB of disk space, and only 64.2 MB of disk space once
installed (i.e. unzipped) on this operating system. This is to be compared with the
200 MB of the installation package of the Arduino IDE (in the ZIP format) and
8 A. Bossard
the 539 MB of disk space taken once installed (for version 1.8.19). This is also
to be compared with the 933 MB required let alone by the installation package of
Microchip Studio (for the offline installer of version 7.0.2542) and the very large
amount of required disk space: 6 GB [13]. It should be noted as well that the size of
the installation package also directly impacts the data transfer costs over the network
as it is very likely that such data would be retrieved directly from the Internet.
Once installed, we have calculated that Microchip Studio (formerly Atmel Studio)
and bundled software take 1.77 GB for XC8, 750 MB for Microchip Studio (includ-
ing the tool chain), 234 MB for Visual Studio components, 13.5 MB for another
Microchip folder and 58.8 MB for MSBuild. So, about 2.83 GB in total. It is only an
approximation since it is difficult to track all the components installed by Microchip
Studio on the whole operating system. Note that for a fair comparison, Microchip
Studio was installed only for the AVR architecture, that is, not including the UC3
and SAM architectures, and without any extension.
Yet, it should be noted that, as explained in Sect. 2, A-IDE does not include the
tool chain, unlike the Arduino IDE and Microchip Studio. So, we add the size of
the tool chain to A-IDE for a fair comparison: the tool chain takes 54 MB of the
installation package of the Arduino IDE and 217 MB once installed. Besides, in the
case of Microchip Studio, it consumes 148 MB once the software has been installed.
So, we can consider that the size of the installation package of A-IDE plus the tool
chain is at most 36 + 54 = 90 MB, and that once installed, A-IDE together with the
tool chain take at most 64.2 + 217 = 281.2 MB. The comparison of these actual disk
space requirements is illustrated in Fig. 4 and summarised in Table 1. Note that the
USB serial communication driver files for the operating system, which are neither
included in A-IDE, are of negligible size and thus not taken into account here.
Of course, Microchip Studio is a development environment packed with numerous
features. However, A-IDE is cross-platform whereas Microchip Studio supports only
the Microsoft Windows operating system [13]. And, although Microchip Studio does
enable programming directly with the assembly language, its documentation rather
clearly shows that it favours programming in C/C++ instead [14]. As a result, A-IDE
is more suitable for the educational purposes mentioned previously in introduction.
Table 1 Comparison of the actual disk space required for the installation package and after instal-
lation of A-IDE (with the tool chain), Arduino IDE and Microchip Studio
A-IDE + tool chain Arduino IDE Microchip Studio
(in megabytes) (in megabytes) (in megabytes)
Installation package 90 200 933
After installation 281 548 2 826
Total 371 748 3 759
installation package after installation
3000 2 826
2500
2000
size (in megabytes)
1500
1000 933
548
500
281
200
90
0
A-IDE + tool chain Arduino IDE Microchip Studio
Fig. 4 Disk space required for the installation package and after installation of A-IDE (with the
tool chain), Arduino IDE and Microchip Studio (in megabytes)
After file edition and running a build and upload process, the RAM memory util-
isation of A-IDE stays at 333.8 MB on Microsoft Windows. This is to be compared
with the 221.2 MB taken in the RAM by the Arduino IDE after similar operations
on the same operating system. Hence, the RAM utilisation of our proposal is slightly
more demanding: this is due to the Racket libraries that are required to run the exe-
cutable file. The Java machine code that is required by the Arduino IDE consumes
less RAM in this case. But considering the amount of available RAM on a typical
modern computer—in the order of several gigabytes—, this difference of approxi-
mately 113 MB remains negligible.
Although an advanced text editor such as Emacs could provide syntax colouring
and the integration of system commands and their input and output streams, this
would require a more or less difficult setup and, besides, such a text editor can hardly
provide all the specialised features of A-IDE, like the facilitated build and upload
process configuration and the build information message which notably shows the
size of the produced machine code after build.
10 A. Bossard
5 Conclusions
The Internet landscape has evolved significantly with the advent of the Internet of
things, with sensors being one category of such devices. They are in general mini-
malistic devices to reduce costs as much as possible. As a result, their programming
faces several restrictions, severe memory limitations being one notable example.
Direct programming of the chip with the assembly language is thus important to
keep memory utilisation at a minimum.
In this research, we have introduced A-IDE, a non-intrusive and cross-platform
development environment for programming the AVR architecture in assembly.
Related systems often favour high-level languages instead, such as C/C++ for the
Arduino IDE. We have quantitatively shown the comparatively low requirements
of A-IDE, and we have qualitatively demonstrated its practicability, accessibility
and cross-platform ability. These results have shown that A-IDE enables a scenario,
programming within an IDE directly in assembly, which would be otherwise signifi-
cantly more costly—Microchip Studio: more intrusive, resource expensive, platform
specific (no portability), closed-source software.
Regarding future works, adding a serial monitor feature to further improve inter-
facing with the microcontroller is a meaningful objective. In addition, support for
common debugging features of microcontrollers such as JTAG and debugWIRE is
yet another possible research direction. Finally, integration of user-friendly library
dependency support could also be investigated.
Acknowledgements The author is sincerely grateful towards the reviewers for their comments and
suggestions. This research was partly supported by a Grant-in-Aid for Scientific Research (C) of
the Japan Society for the Promotion of Science under grant no. 19K11887.
Appendix
An illustration of the user interface in the case of the Linux operating system with the
Ubuntu distribution running on the Windows Subsystem for Linux (WSL) is given
in Fig. 5.
Finally, the source code of A-IDE as well as binaries can be downloaded from the
official homepage at https://www.sci.kanagawa-u.ac.jp/info/abossard/a-ide/.
Fig. 5 An overview of the accessible user interface of A-IDE. This screenshot illustrates the case
of the Linux operating system with the Ubuntu distribution running on WSL
References
1. Bossard, A.: Autonomous on-chip debugging for sensors based on AVR microcontrollers. J.
Sens. Technol. 11(2), 19–38 (2021). https://doi.org/10.4236/jst.2021.112002
2. Bossard, A.: Understanding microcontrollers -a gentle introduction to an AVR architecture-.
Ohmsha, Tokyo, Japan (2021)
3. Bossard, A.: Memory optimisation on AVR microcontrollers for IoT devices’ minimalistic
displays. Chips 1(1), 2–13 (2022). https://doi.org/10.3390/chips1010002
4. Chau, C.F., Fung, Y.F.: A tool for self-learning assembly language programming and computer
architecture: Design and evaluation. Comput. Appl. Eng. Educ. 19(2), 286–293 (2011). https://
doi.org/10.1002/cae.20310
5. Halfacree, G.: The official BBC micro:bit user guide. Hoboken, NJ, USA (2017)
12 A. Bossard
6. Hara, S., Imai, Y.: Register-transfer-level CPU simulator for computer architecture education
and its quantitative evaluation. IEEJ Trans. Electron. Inf. Syst. 138(9), 1123–1130 (2018).
https://doi.org/10.1541/ieejeiss.138.1123
7. Leijen, D.: WxHaskell: a portable and concise GUI library for Haskell. In: Proceedings of the
2004 ACM SIGPLAN Workshop on Haskell, Snowbird, Utah, USA, 22 September 2004, pp.
57–68 (2004). https://doi.org/10.1145/1017472.1017483
8. Margolis, M., Jepson, B., Weldin, N.R.: Arduino Cookbook: Recipes to Begin, Expand, and
Enhance Your Projects, 3rd edn. O’Reilly Media, Sebastopol, CA, USA (2020)
9. McManus, S.: Scratch Programming in Easy Steps, 2nd edn. Leamington Spa, UK (2019)
10. Meidinger, M., Ebbers, H., Reimann, C.: AeroFX – native themes for JavaFX. In: Dregvaite
G., Damasevicius R. (eds.) Information and Software Technologies (Proceedings of the 21st
International Conference on Information and Software Technologies; Druskininkai, Lithuania,
15–16 October 2015). Communications in Computer and Information Science, vol. 538, pp.
526–536 (2015). https://doi.org/10.1007/978-3-319-24770-0_45
11. Microchip Technology: ATmega48A/PA/88A/PA/168A/PA/328/P megaAVR data sheet
(2018). DS40002061A, ISBN: 978-1-5224-3502-0
12. Microchip Technology: AVR instruction set manual (2020). DS40002198A, ISBN: 978-1-
5224-5882-1
13. Microchip Technology: Microchip studio release note (2020). DS50002917C, ISBN: 978-1-
5224-7063-2
14. Microchip Technology: Microchip studio user guide (2022). DS50002718E, ISBN: 978-1-
5224-9776-9
15. Sondag, T., Pokorny, K.L., Rajan, H.: Frances: a tool for understanding computer architecture
and assembly language. ACM Trans. Comput. Educ. 12(4), 14:1–14:31 (2012). https://doi.org/
10.1145/2382564.2382566
Develop a Horizontal Virtual Frame
by Adding Field of View Restrictions
to Reduce VR Sickness
Hexi Huang
Abstract VR sickness is a symptom that similar to motion sickness such as strong

discomfort, nausea, dizziness, and headache, and 3D sickness when using VR. As
VR becomes more and more widely used, the accompanying VR sickness also needs
to be paid attention to. This research is based on the previous development of the
virtual horizontal frame. On the basis of confirming that the virtual horizontal frame
has a good effect on VR sickness, we will further study the effect of restricting part
of the field of view. The effect was visualized by using SSQ (Simulator Sickness
Questionnaire) to see the degree of sickness. Through experiments, it was found that
different visual field limitations can alleviate various symptoms to different degrees.
We can also formulate different visual specialization strategies according to different
results of each SSQ questionnaire.
Keywords VR sickness · Virtual horizontal frame · Field of view · SSQ
1 Introduction
In recent years, virtual reality has been widely used in real estate previews, reha-
bilitation of sequelae caused by cerebral infarction, work education, entertainment,
and advertising industries. However, as it became more widespread in the world,
the drawbacks of VR have become apparent. When using VR, symptoms similar to
motion sickness such as strong discomfort, nausea, dizziness, and headache, and 3D
sickness may occur. These are called “VR sickness”. The degree and type of sickness
symptoms vary greatly from person to person, and some people do not develop the
symptoms, some develop them immediately, and some people have the symptoms
for a long time.
In the previous research, we approached from the visual aspect among the elements
of VR sickness, and aimed to reduce sickness only by images without the need for
peripheral devices or special tools other than VR. Then, in order to suppress the
H. Huang (B)
Department of Information Science, Aichi Institute of Technology, Toyota, Japan
e-mail: b18803bb@aitech.ac.jp

https://doi.org/10.1007/978-3-031-19604-1_2
14 H. Huang
occurrence of vection and confusion of the spatial recognition function, which are
one of the causes of VR sickness, a virtual horizontal frame that “covers the peripheral
visual field” and “visualizes the actual horizontal position and the inclination of one’s
own field of view” was developed. Post-experimental SSQ results showed a decrease
in SSQ scores for all subjects wearing virtual horizontal frames. In particular, it was
found that the subjects with high SSQ scores in the “no virtual horizontal frame”
state were effective in reducing the feeling of discomfort and wobbling by wearing
the virtual horizontal frame.
However, in the previous study, the content that verified the effect of the virtual
horizontal frame was limited to the roller coaster. Therefore, we have not verified
the effect on VR content that can be moved arbitrarily in 3D space by operating
the controller while it is stationary, or that is performed while moving the body. We
also verified the virtual horizontal frame using the horizon and the ring, but did not
compare and verify it with the virtual frames of other designs. Therefore, it was not
possible to determine whether the effect of suppressing VR sickness was due to the
horizon placed in the center or the effect brought about by covering the peripheral
visual field.
Therefore, in this research, in order to verify the effect of the virtual horizontal
frame, in addition to the content that the player moves by himself/herself using the
controller, the effect on the content that cannot exist in reality such as shooting
games is measured. We will also develop a frame that only covers the peripheral
vision and verify whether the horizon has the effect of suppressing VR sickness.
We measured each of the frame that obscures the peripheral visual field, the virtual
horizontal frame of the previous study, and the virtual horizontal frame of this study,
and verified whether the horizon is effective.
2 Purpose of Research
2.1 Reduce VR Sickness Caused by VR Content
First of all, it is necessary to understand VR sickness in order to reduce VR sickness.

The main cause of VR sickness is an external stimulus to the body or a gap between
movement and visual information. VR sickness is considered as a type of agitation. In
this study, VR sickness was regarded as a type of motion sickness, and the study was
conducted with reference to existing preventive methods and solutions for motion
sickness.
Develop a Horizontal Virtual Frame by Adding Field of View … 15
2.2 Realized by Video Processing Without Using Auxiliary

Equipment
As a method of reducing VR sickness, a method of using an external stimulus to

the body and a method of giving supplementary information to visual information
can be considered. In this study, we reduce VR sickness by supplementing visual
information with filters and video effects. As a result, it can be realized only in the
environment necessary for using VR, and it can be easily introduced without the
need to prepare special equipment.
2.3 Compare Virtual Frames and Verify the Effect

of Horizontal Lines
In the previous study, we created a virtual horizontal frame, but we could not deter-
mine whether the effect of suppressing VR sickness was due to the horizontal line
placed in the center or the effect brought about by covering the peripheral visual
field. Therefore, in this study, we will develop a frame that only covers the peripheral
visual field and verify whether the horizon has the effect of suppressing VR sickness.
We measured each of the frame that obscures the peripheral visual field, the virtual
horizontal frame of the previous study, and the virtual horizontal frame of this study,
and verified whether the horizon is effective.
2.4 Prove that It Works for Various Contents
Actually, use the created virtual frame and compare the degree of sickness with the
unused state. At that time, a questionnaire for quantifying sickness by a simulator
called SSQ (Simulator Sickness Questionnaire) is used as an index. SSQ is performed
on the subject after viewing the content in a relaxed state and without using the virtual
frame, and after viewing the content with the virtual frame, and the effect of the virtual
frame is proved by comparing the results. In addition, the cerebral blood flow meter is
used under the same conditions, and the effect of the frame is confirmed by using not
only the subjective evaluation but also the physiological index. Also, in the previous
research, we experimented with one VR content, but in this research, we use various
VR contents and confirm that it is effective for a wide variety of contents.
16 H. Huang
3 VR Sickness
The cause of VR sickness is thought to be the same as that of motion sickness because
the symptoms of VR sickness and agitation are similar [1, 2].
One of the causes of motion sickness is the theory of sensory contradiction. There
is a contradiction between the body’s sense of balance information obtained by the
human semicircular canals and the visual information obtained by the eyes. Motion
sickness develops when they accumulate in the brain [3–5].
Since the cause of developing VR sickness is related to the cause of motion
sickness, it is necessary to apply the existing mechanism for reducing the symptoms
of motion sickness to VR and explore the effect in order to reduce VR sickness. VR
sickness is attributed to the discrepancy between sensory and visual information from
the vestibule and somatosensory, and one of the causes of VR sickness is visually
induced self-motion sensation (vection) [1].
VR sickness can be suppressed by suppressing the vection that occurs when using
VR content. In order to suppress vection, it is necessary to eliminate the discrepancy
between visual information and spatial information obtained from the vestibule and
somatosensory. There are two main methods for eliminating vection.
The first is a method that does not cause vection by making the VR environment
and the natural environment the same. By transmitting visual information from the
VR environment as motion information to the vestibule and somatosensory using a
machine, the spatial information from the VR environment and the natural environ-
ment are matched. In addition, the spatial information can be matched by completely
reproducing the natural environment on the VR environment. Reported that VR sick-
ness was significantly reduced by creating a motorcycle in a VR environment and
synchronizing the magnitude of engine sound and vibration with the image [6].
However, there are various problems in introducing a machine that reproduces
the motion of VR in the natural environment. In order to use the machine, VR can be
used only in a place where a sufficient range of movement is secured. Furthermore,
considering the increase in the cost of introducing a machine, it is not a casual measure
against VR sickness. In addition, the content that can be experienced is limited if the
natural environment is reproduced in the VR environment.
The second is to suppress the occurrence of vection by blocking or adjusting
the equilibrium information and peripheral visual field information related to spatial
recognition.
The human eye can see a range of about 200° in the horizontal direction and about
125° in the vertical direction when the front is 0°, and this range is called the field
of view.
A. The discriminative visual field is the central region (within about 5°) that has
excellent visual functions such as visual acuity and color discrimination.
B. Effective visual field is an area that can be instantly receptive only by eye
movement (horizontal about 30°, vertical within about 20°).
C. Stable gaze is the area where you can gaze comfortably with eyeball/head move-
ment (horizontal 60°–90°, vertical 45°–70°, range where effective information
reception is possible).
D. The guided visual field has low discriminating ability, but the area where the
viewing angle information affects the spatial coordinate system (horizontal 30°–
100°, vertical 20°–85° range has a large effect).
E. The auxiliary visual field (peripheral visual field) is a region where the presence
of stimuli can be seen (horizontal 100°–200°, vertical 85°–130°) [7].
The central visual field of the human eye is better at identifying given information
(color, shape, etc.) than the peripheral visual field. On the other hand, the peripheral
visual field is good at sensing changes in the position and shape of an object, and
performs motion perception [8]. Therefore, it has been clarified that the peripheral
visual field is deeply related to the occurrence of vection, and that the addition of
a mask area that covers the peripheral visual field makes it difficult for vection to
occur [9].
4 Development of Virtual Horizontal Frame
A virtual horizontal frame created by Unity is displayed on the VR screen to reduce

the occurrence of vection and confusion in the space recognition function, and to
reduce VR sickness. The virtual horizontal frame was created with Adobe Photoshop
CS6, and was read as a Sprite in Unity. It also performs rotation according to the
head movement, programmed by a C # script.
4.1 Creating a Coaster
In the previous study, we created a roller coaster using Unity’s asset Animated Steel
Coaster to create content that causes VR sickness. In the previous course, in order
to induce and amplify VR sickness, we created a roller coaster that reproduces yaw,
pitch, and roll movements in a VR environment and makes visual information and
spatial information from somatosensory inconsistent. Hereinafter, this content is
referred to as coaster α (Fig. 1).
We decided that a roller coaster, which is a mixture of fast linear motion and
rotational motion, is the most suitable content for generating effective spins on the
subject. In addition, since the roller coaster has multiple rotations of the roll axis, pitch
axis, and yaw axis, it is considered that the occurrence of vection can be expected. In
addition, realistic snow mountain objects are arranged so as not to lose the sense of
up and down. For the roller coaster course, we used Unity’s asset Track_and_Rails
and created a course of about 1 min 30 s per lap. Hereinafter, this content is referred
to as coaster β (Fig. 2).
18 H. Huang
Fig. 1 Coaster α
Fig. 2 Yaw, pitch, and roll axis course
We decided that a roller coaster, which is a mixture of fast linear motion and
rotational motion, is the most suitable content for causing sickness, but since the
viewpoint movement is constant, the target is placed on the course to increase the
viewpoint movement. I decided to create a simple shooting game. In addition, by
installing these, we tried to induce sickness more than a roller coaster. Using Unity’s
assets Tracks and Rails, I created a shooting course for about 1 min per lap, and
created an original shooting game. In addition, by recording the score at the time of
three laps, we improved the competitiveness and devised a way to concentrate more
on the game (Fig. 3).
Fig. 3 Shooting coaster
Since the roller coaster moves automatically, we thought that content for the
player to control the movement was necessary. We decided to create a game in which
the movement method in VR is slide movement, because the player operates it and
causes vection by linear motion and rotational motion more effectively. The outline
of the game is to operate the avatar with the controller and collect the items placed
in the map. In addition to stick operations, we also incorporated elements such as
crouching buttons, jump buttons, and dash buttons to bring them closer to general
game actions, and also tried to induce sickness when performing those actions. I
created an original game using the map of RPG/FPS Game Assets for PC/Mobile of
Unity assets (Fig. 4).
4.2 Virtual Horizontal Frame
In the previous research, we developed a frame that can easily grasp the angle of
view on the horizon. The horizon part is not affected by the movement of the camera
depending on the direction of the head, and is always displayed fixed on the screen.
This makes it possible to always grasp the horizontal position of the field of view.
The ring part rotates with the movement of the camera and gradually returns toward
the horizon with a slow movement. This movement visually represents the hori-
zontal position and the angle of inclination of oneself, and eliminates the gap in
spatial recognition. In addition, the ring part hides the peripheral vision and works
to suppress the occurrence of vection. However, since it is inevitable that displaying
the virtual horizontal frame obstructs the view when viewing the VR content, the
20 H. Huang
Fig. 4 Action game
range in which the VR content can be viewed is increased by using the broken lines
for both the horizontal line and the ring, and the VR content is displayed. I try not to
spoil the immersive feeling. Hereinafter, this frame is referred to as frame 1 (Fig. 5).
4.3 Omnidirectional Virtual Frame
In order to prove that the horizontal lines and rings of the virtual horizontal frame
are effective in suppressing VR sickness, we created a virtual frame for comparison
that obscures the peripheral visual field and provides a gaze point (Fig. 6).
Fig. 5 Virtual horizontal frame
Fig. 6 Omnidirectional virtual frame
4.4 Horizontal Sensation Retention Frame with Limited

Visual Field
We have developed a new virtual horizontal frame based on the virtual horizontal
frame developed in the previous research. We have devised a frame design that
inherits the rotation function of the horizon and ring of frame 1 and does not hinder
the immersive feeling of the horizon and ring. In addition, the design of the horizon
has been simplified. Therefore, it is assumed that the horizon is less likely to interfere
with the content. In addition, in order to cover the design of the ring over the entire
22 H. Huang
Fig. 7 Horizontal sensation retention frame with limited visual field
peripheral visual field, the ring, which was a semicircle, was changed to a circle. It
is speculated that this makes it possible to cover the peripheral visual field more and
suppress vection. Also, by changing the gradation of the upper half of the circle to
draw the horizontal line of the ring, the gradation and the boundary line of the lower
half of the circle can be created. This boundary line is used as a new horizontal line.
Hereinafter, this frame is referred to as frame 3 (Fig. 7).
The horizon part has been replaced with a black circle to provide a gaze point that
does not interfere with the immersive feeling of VR content. This makes it difficult
to grasp the horizontal position of the field of view, but its role as a gazing point does
not change. Therefore, the effect of suppressing VR sickness on the horizon can be
verified by comparing it with the virtual horizontal frame. In addition, by removing
the rotation function of the ring part and changing from a broken line to a solid line,
the frame is made to only cover the peripheral visual field. This makes it possible to
verify how effective the rotation of the ring in the peripheral vision is in suppressing
VR sickness. Hereinafter, this frame is referred to as frame 2.
5 Experiment
For the evaluation method of motion sickness, we used SSQ (Simulator Sickness
Questionnaire) to perform subjective evaluation as a psychological index measure-
ment. Although subjective evaluation is more prevalent in evaluation of motion sick-
ness, VRsickness is thought to be caused by disturbance of autonomic nervous system
due to sensory inconsistency of visual and brain perception.
5.1 Experimental Method
In order to evaluate VR sickness, SSQ and cerebral blood flow are measured. SSQ is
used as a subjective evaluation. Cerebral blood flow is used as a physiological index.
The reason for not using physiological indicators other than cerebral blood flow is
that the study by Graybiel et al. Could not confirm a significant tendency in the
onset of motion sickness and the tendency of fluctuations in physiological indicators
[10]. On the other hand, Seraglia et al. Demonstrated that cerebral blood flow can
be accurately measured even while experiencing VR in an experiment combining
VR and cerebral blood flow meter (NIRS) measurement [11]. Therefore, this study
verifies cerebral blood flow as a physiological index.
In this study, 5 subjects were assigned to each of the 4 contents, and a total of
20 male and female subjects cooperated. The subjects were asked to experience the
content in each of the states of no frame, frame 1, frame 2, and frame 3, and then
answered the SSQ questionnaire to compare the degree of sickness with and without
each frame. In addition, when VR was attached, a cerebral blood flow meter was also
attached at the same time, and changes in cerebral blood flow with and without each
frame were compared. In addition to SSQ, we also conducted a simple questionnaire
and decided to collect subjective evaluations for frames other than SSQ. In order to
unify the measurement environment, the measurement was performed on a sunny
day with more than 2 h after eating, and the room temperature was set to 25°.
5.2 SSQ Measurement
SSQ (Simulator Sickness Questionnaire) is one of the indicators of VR sickness.

SSQ is a measurement of subjective evaluation, and was devised by Kennedy et al.
In the United States as a method for diagnosing VR sickness using a drive simulator
or an airplane simulator. Table 1 shows the 16 subjective evaluation items that are
effective for simulator sickness by factor analysis of the subjective evaluation results
obtained from a large number of simulator users. Ask them to answer one of the
evaluations of each item from 0 to 3 (0 is no symptom, 3 is severe) and describe it.
Those that correspond to nausea (N: Nausea), eyestrain (O: Oculomotor), and light-
headedness (D: Disorientation) are marked with 1, and those that do not correspond
are marked with 0. After describing the evaluation, each value is calculated by Eq. (1).
In addition, a comprehensive index for VR sickness can be obtained by calculating
the total value of nausea, eyestrain, and light-headedness (TS below Total Score)
using Eq. (2) [12, 13].

rating of 1 + rating of 6 + rating of 7 + rating of 8
N = 9.54 × (1)
+ rating of 9 + rating of 15 + rating of 16
24 H. Huang
Table 1 Subjective evaluation items of SSQ

(i) Signs and Evaluation value x i Degree of Degree of eye Degree of
symptoms of (0–3) discomfort N i fatigue Oi dizziness Di
sickness
(1) General – 1 1 0
discomfort
(2) Feeling tired – 0 1 0
(3) Headache – 0 1 0
degree
(4) Eyestrain – 0 1 0
(5) The degree of – 0 1 1
difficulty in eye
focusing
(6) Increased saliva – 1 0 0
(7) Amount of – 1 0 0
sweating
(8) Degree of – 1 0 1
nausea
inattention
light-headedness
(11) Blurred eyes – 0 1 1
(12) Dizziness (eye – 0 0 1
open)
(13) Dizziness (eye – 0 0 1
closed)
(14) Degree of loss – 0 0 1
of balance
(15) Stomach – 1 0 0
discomfort
(16) Belching – 1 0 0

O = 7.58 ×

D = 13.92 ×
TS = 3.74 × (total of 16 ratings of N, O, D) (2)
In this study, cerebral blood flow is used as a physiological index of VR sickness,

and a cerebral blood flow meter (NIRS) is used to measure it. NIRS is a device
that non-invasively measures blood volume in the brain and visualizes changes in
blood volume in the frontal lobe. Hemoglobin, a blood component, scatters light,
and when oxygen is bound to it, the degree of scattering changes. Light absorption in
the near-infrared wavelength range is caused by oxygenated hemoglobin (oxy-Hb)
and deoxygenated hemoglobin (deoxy-Hb), both of which have different absorption
spectra. If the molar extinction coefficient of oxy-Hb and deoxy-Hb is known, the
concentration change of oxy-Hb and deoxy-Hb can be calculated by measuring the
change in absorbance at two or more wavelengths. A graph of cerebral hemoglobin
can be displayed by the software in real time [14].
Seraglia et al. Combined VR and NIRS measurement to measure brain activity
(parietal lobe/occipital lobe) when active on VR, and proved that cerebral blood flow
can be accurately measured even while experiencing VR [11]. In addition, oxy-Hb
increases by actively exercising by one’s own will, such as voluntary movement,
but oxy-Hb changes significantly in exercise that is not related to intention due to
external influences can not be observed [11, 15]. From these, changes in oxy-Hb can
be used as parameters that reflect brain activity.
The results of each SSQ questionnaire when experiencing content without a frame,
when experiencing with frame 1, when experiencing with frame 2, and when experi-
encing with frame 3 are for each of the four contents. It is summarized in the graph.
Each graph is the average value of N, O, D, and TS of all the subjects who experienced
the content.
Graph 1 is the result of SSQ of coaster α. In frame 1, all the values of N, O, D,
and TS were significantly reduced compared to those without a frame. In the case of
frame 2, although it decreased, the value did not decrease from frame 1. In frame 3,
the value of D decreased significantly, and the value of TS decreased from frame 2,
but did not decrease from frame 1.
Graph 2 shows the SSQ results of coaster β. The values of D and TS decreased
in all frames, and frame 2 decreased the most. In addition, the value of O decreased
only in frame 2 and increased in frame 3. The value of N resulted in an increase in
all frames.
Graph 3 is the result of SSQ of the shooting game. The overall value of frame 1
decreased compared to that without a frame, and the value of D in particular decreased
significantly. In the case of frame 2, the values of N, D, and TS decreased, but O
increased a little. As with frame 1, all values of frame 3 were reduced, and the result
was that it was further reduced than that of frame 1.
Graph 4 shows the SSQ results of the action game. Compared with the case without
a frame, the values of N, O, D, and TS were all reduced by adding a frame. Frame 2
had a small decrease compared to other frames. In frame 1 and frame 3, the values
of N and D decreased most in frame 1, the value of O decreased most in frame 3,
and the value of TS became similar.
In addition, in the four measured contents, all D values were large when there
was no frame. However, by adding a frame, it was confirmed that the value of D
decreased in all the contents. In particular, Figs. 8 and 11 in frame 1, Fig. 9 in frame
2, and Figs. 8 and 10 in frame 3 decreased significantly.
26 H. Huang
Fig. 8 [Coaster α] Average of each item of SSQ
Fig. 9 [Coaster β] Average of each item of SSQ
From the above, the result is that the SSQ value is reduced overall for all frames
compared to the case without frames. From this, it was confirmed that the system
using virtual frames for various contents is effective in suppressing VR sickness. In
addition, it was confirmed that frame 1 and frame 3 had lower SSQ values than frame
2, so the horizon is considered to be effective.
Fig. 10 [Shooting game] Average of each item of SSQ
Fig. 11 [Action game] Average of each item of SSQ
6 Conclusion
In this research, we improved the virtual horizontal frame developed in the previous
research and developed a horizontal sensation holding frame with visual field limi-
tation. This suppresses VR sickness and enables a more immersive VR experience.
From the experiment using the omnidirectional virtual frame developed on the way,
it was found that the effect of suppressing VR sickness like the virtual horizontal
frame cannot be obtained only by covering the peripheral visual field. In other words,
the horizontal lines and rings of the virtual horizontal frame were greatly involved
in suppressing VR sickness. In addition, in experiments using VR content, which
is performed while the player is stationary and arbitrarily moves in 3D space by
operating the controller, or while moving the body, the SSQ score was lowered after
28 H. Huang
experiencing each content displays a virtual frame. In other words, VR sickness

can be suppressed by using a virtual frame. In addition, since the SSQ score of all
contents has decreased, the virtual frame supports various contents.
When comparing the effect of suppressing VR sickness between the virtual hori-
zontal frame and the horizontal sensation holding frame with visual field limita-
tion, both were able to significantly suppress sickness, but no significant difference
was observed overall. However, the newly designed frame that does not hinder the
immersive feeling is more practical than other frames because it has the same effect
of suppressing VR sickness as the virtual horizontal frame. In addition to this, we
can formulate different visual specialization strategies according to different results
of each SSQ questionnaire when experiencing content without a frame, when expe-
riencing with frame 1, when experiencing with frame 2, and when experiencing with
frame 3. Extend on this basis, we can also alleviate a certain symptom of VR sick-
ness. We can even do the opposite, use visual elements to deepen the senses. Through
seven experiments, there is an evidence for a speed-abstraction effect, where the
perception of moving faster (vs. slower) leads people to rely on more abstract (vs.
concrete) mental representations during decision making [16]. Adjust the human
body sense through VR visual elements to generate a sense of speed that has a
different sense of movement. In this way, the VR experience can be increased in a
more three-dimensional manner. Even expand into more new directions of use.
References
1. Nobuhisa, T.: A survey of countermeasure design for virtual reality sickness. Trans. Virtual
Real. Soc. Jpn. 10(1), 129–138 (2005)
2. Nobuhisa, T., Takagi, H.: Design system of virtual reality environment based on VR presence
and VR sickness. Trans. Virtual Real. Soc. Jpn. 11(2), 301–312 (2006)
3. Reason, J.T., Brand, J.J.: Motion Sickness. Academic Press Inc. (1975)
4. Money, K.E.: Motion sickness. Am. Physiol. Soc. 50(1), 1–39 (1970)
5. Kitagawa, E., Tanaka, S., Abiko, S., Tsukada, Y., Shiomi, K.: Method for reducing kinetosis
using viewing mobile media in moving vehicles. J. Inst. Image Inf. Telev. Eng. 67(11), J388–
J399 (2013)
6. Sawada, Y., Itaguchi, Y., Hayashi, M., et al.: Effects of synchronized engine sound and vibration
presentation on visually induced motion sickness. Sci. Rep. 10, 7553 (2020)
7. Hatada, T. (Tokyo institute of Polytechnics): Measurement of information receiving and visual
field. Jpn. J. Ergon. 29, 86–88 (1993)
8. Kishishita, N., Orlosky, J., Kiyokawa, K., Mashita, T., Takemura, H.: Investigation on the
peripheral visual field for information display with wide-view see-through HMDs. Trans.
Virtual Real. Soc. Jpn. 19(2), 121–130 (2014)
9. Ryu, J., Hashimoto, N., Sato, M.: Analysis of vection using body sway in immersive virtual
environment. Technical report of IEICE (Multimed. Virtual Environ. 103, 63–68) (2003)
10. Graybiel, A., Lackner, J.R.: Evaluation of the relationship between motion sickness symptoma-
tology and blood pressure, heart rate, and body temperature. Aviat. Space Environ. Med. 51,
211–214 (1980)
11. Seraglia, B., Gamberini, L., Priftis, K., Scatturin, P., Martinelli, M., Cutini, S.: An exploratory
fNIRS study with immersive virtual reality: a new method for technical implementation. Front.
Hum. Neurosci. 5, 176 (2011)
12. Ujike, H.: Visually induced motion sickness. J. Inst. Image Inf. Telev. Eng. 61(8), 1124 (2007)
13. Kennedy, R.S., Lane, N.E., Berbaum, K.S.: Simulator sickness questionnaire: an enhanced
method for quantifying simulator sickness. Int. J. Aviat. Psychol. 3, 203–220 (1993)
14. Shimadzu: Functional brain imaging (fNIRS). https://www.an.shimadzu.co.jp/apl/lifescience/
invivo.html. Accessed 24 Oct 2020
15. Hirayama, K., Watanuki, K., Kaede, K.: Brain activation analysis of voluntary movement
and passive movement using near-infrared spectroscopy. Trans. Jpn. Soc. Mech. Eng. Ser. C
78(795), 3803–3811
16. Shani-Feinstein, Y., Kyung, E.J., Goldenberg, J.: Moving, fast or slow: how perceived speed
influences mental representation and decision making. J. Consum. Res. (2022)
Represent Score as the Measurement
of User Influence on Twitter
Yuto Noji, Ryotaro Okada, and Takafumi Nakanishi
Abstract In this paper, we present a novel method for quantifying a user’s ability to
spread information based on the number of Retweets (RTs) and Likes they receive
on Twitter. In today’s social network services, there are numerous users with the
ability to spread information, called “influencers”. However, even if they post the
same content, the reactions they receive vary from user to user. Therefore, it is useful
to create an index that represents the diffusion ability of each account to analyze
diffusion behavior in social network services. In general, the diffusion status of
information on Twitter is often quantified in terms of the number of RTs, Likes,
and impressions of tweets alone. In this novel method, we propose a method for
extracting indicators that show the diffusion power, not of tweets alone, but users as
a unit, by measuring the ratio of the number of RTs and Likes based on the number
of RTs and Likes of users in the past. The index obtained by this method can be used
as an indicator for analyzing diffusion behavior on Twitter and may help conduct
a more granular analysis. In this study, we conducted an experiment in which we
collected tweets from 10 international celebrities for three years, divided them into
multiple time series types, and applied this method to qualitatively evaluate them
from the tweet text. The results showed that a bias exists when the period covered
by the method is narrow, but when measured over a periodic unit of one year, there
was no significant blurring, and it was possible to determine the status of the user
in terms of the tweet text. We also found that each field was coherent and that there
was a nature to the field.
Keywords Influence · Social network analysis · Twitter
Y. Noji · R. Okada · T. Nakanishi (B)

The Tokyo Foundation for Policy Research, Department of Data Science, Musashino University,
Tokyo, Japan
e-mail: takafumi.nakanishi@ds.musashino-u.ac.jp
Y. Noji
e-mail: s1922026@stu.musashino-u.ac.jp
R. Okada
e-mail: ryotaro.okada@ds.musashino-u.ac.jp

https://doi.org/10.1007/978-3-031-19604-1_3
32 Y. Noji et al.
1 Introduction
Social networking services such as Twitter, Instagram, and Facebook have become
important communication, information transmission, and information-gathering
tools in the modern age. These services have replaced television and newspapers.
They are used to obtain important information promptly, as well as to share daily life
among friends. A common feature of these services is the ability to “share” posts.
Recently, there are “influencers” who can information on these services as much as
or more than television personalities and news organizations. Their posts are shared
more than the typical user’s. This means that the diffusion of information depends
not only on the information itself but also on the one disseminating it. Many social
networking services allow users to “Like” a post, which does not spread the informa-
tion, but shows a liking for the post. Although text mining and machine learning have
been used to study the diffusion of posts, we believe that it is promising to include
user characteristics that consider the different nature of these reactions as a factor.
In this paper, we propose a method to extract a represent score, which is a measure
of a user’s diffusion ability, from the number of RTs and Likes of a Twitter user.
The main features of this paper are as follows.
• Collected tweets from target users based on the defined rules, and constructed a
tweet database including reaction information.
• We proposed a method to calculate the Represent Score, which is an index of
diffusion power, using RTs and Likes in the tweet database. Represent Score
shows the degree to which a user represents (speaks for) the ideas of other users.
• We also applied this method to the accounts of international celebrities and
conducted a qualitative evaluation.
Most studies of user influence on Twitter use social graph analysis. These analyses
mainly use in-degree (following), RT, mention and reply as features. Our study
focuses on the ratio of RTs to Likes to determine the characteristics of user influence.
The remaining paper is organized as follows: In Sect. 2, we describe related
research. In Sect. 3, we propose the Represent Score, a measure of diffusion power
using the number of reactions to tweets on Twitter, which is our proposed method.
In Sect. 4, we show summarizes the evaluation results and discussion, and Sect. 5
concludes the study and highlights future research.
2 Related Work
Our research focuses on user influence on Twitter. Therefore, this section presents the
research on Twitter user influence. The Merriam-Webster dictionary defines influ-
ence as “the power or capacity of causing an effect in indirect or intangible ways.”
The role of influence and its effects is studied extensively in Sociology, Marketing,
Communication and Political Science [1].
Represent Score as the Measurement of User Influence on Twitter 33
Numerous definitions of influence on Twitter have been proposed. Antonakaki

et al. summarized the overall research on Twitter in a survey paper [2]. In the paper,
the study of User Influence is positioned as a type of analytical study on Social
Graphs. The mainstream method for calculating User Influence is to use PageRank
[3] and its variants [4–9]; another method is to use betweenness centrality and its
variants [10, 11].
Riquelme et al. presented 53 different Influence metrics on Twitter [12]. They
summarized what features were used to calculate the various User Influence metrics.
The features that can be obtained from Twitter are “follow-up relationships”,
“retweets”, “mentions”, “replies”, and “favorite (like)”.
Cha et al. conducted a study using large data sets on Twitter User influence [13].
They defined three metrics of User Influence: (1) Indegree influence (the number of
people who follow the account), (2) retweet influence, and (3) mention influence.
They investigated the characteristics of these metrics through a study using a large
data set. They clarified that In-degree represents the popularity of a user; retweets
represent the content value of one’s tweets; mentions represent the name value of a
user; the top users based on the three measures have little overlap.
In our proposed method, we focus on representativeness as one of the prominent
indicators of User Influence, and we use the ratio of retweets to likes as a user
characteristic. According to the paper [12], not many studies have focused on likes.
This is probably because “like” does not create a new edge on networks, therefore
has little influence in social graph studies.
We present two studies that use “like” in the definition of the metric for User
Influence.
Hajian et al. defined a metric named Influence Rank (IR) for identifying opinion
leaders on the Twitter social network [1]. They defined two types of social influence:
one is informational social influence (the need to be right) and the other is normative
social influence (the need to be liked). The IR for a node is defined as the average IR
of its neighborhoods combined with another index called magnitude of influence.
Montangero et al. proposed a metric named TRank [14]. TRank is designed to find
the most influential Twitter users on a given topic, defined through hashtags. This
approach combines different Twitter signals and provides three different indicators
that are intended to capture different aspects of being influent. The three indicators
are as follows: followers influence (FI), retweet influence (RI) and favorite influence
(FVI).
These two studies include “like” in their method of influence calculation based
on graph networks. Our method uses only retweets and likes of a user and focuses
on the user’s characteristics rather than overall influence.
34 Y. Noji et al.
3 Proposed Method
In this section, we present our proposed method of extracting a represent score for
measuring user influence on Twitter. This method collects users’ tweets, aggregates
their reactions to the tweets, and scores the users’ diffusion ability based on the aggre-
gate reactions. This is because the number of reactions on Twitter varies depending
on the status of the influencer. The Represent Score is defined as the ratio of RTs and
Likes as one of the indicators of the diffusion power of a post.
3.1 Overview
We show the overview of our proposed method in Fig. 1. The method consists of two
main modules: Scraping, and Extracting Represent Score.
Fig. 1 Overview of
proposed method. It consists
of two main modules:
scraping, extracting
represent score, the user is
specified, the user’s tweets
are collected, a tweet
database is built, RTs and
Likes are extracted from the
reactions to those tweets, and
the represent score is
calculated based on those
RTs and Likes
In our proposed method, we first input a username as a query and then collect
tweets from the username by scraping. The number of likes and retweets are extracted
from the collected tweets to build a database.
The Represent Score calculation for each account is applied to this database.
3.2 Scraping
In our method, we first enter a username as the search query, and then use the Twitter
API or a tweet collection library to collect tweets from the target user. We search by
specifying a period and collect all tweets during it. Replies are excluded during this
period.
The reason for this is that replies are more of a response to other users, in other
words, they are more conversational in nature. Since this method focuses on the ability
of users to share their reactions to posts, replies that are not considered to be aimed
for sharing by the influencer were excluded in consideration of this characteristic.
The collected tweets were saved as the “Database of tweets containing the
keyword”. In this database, we retrieve and save the information of “main text”,
“Like”, and “Retweet” from the tweet.
3.3 Extract Represent Score
On Twitter, there are two types of responses to a tweet: “Like” and “Retweet”. Like
is a response that exhibits a positive feeling about the tweet. Retweet is a response
corresponding to sharing a tweet.
In general, tweets receive more Likes than Retweets, but the ratio varies from
account to account. We assume that the ratio of Likes to Retweets represents the
characteristics of the account. For example, accounts that are rooted only in the
offline community will have a smaller ratio of retweets. In contrast, accounts that
talk about social issues will have a larger ratio of retweets. Even if two accounts
have the same number of followers, they have different abilities to spread tweets. We
defined represent score to express this propensity to be retweeted.
Twitter also has other reaction functions such as the number of replies and quoted
retweets, but only the typical RT and Like functions have been used in this method
to avoid complications.
The extraction represent score module consists of four steps:
1. Get the latest n tweets of the target account by scraping.
2. Extract the number of likes and retweets from those tweets.
3. Calculate the Approval Score with the following equation.
Represent Score is defined by the equation below.
36 Y. Noji et al.
n
ri
A = in
i si
A: approval Score
r i : number of retweets of tweet i
si : number of likes of tweet i.
3.4 Select the Period of Time to Be Used in the Represent

Score Calculation
Our method does not use all of the collected tweets in the database but selects
the usable data by setting a time condition, relative to the date that the tweet was
posted. This is to avoid bias differences due to environmental factors such as when
reactions are more likely or less likely to occur depending on the period of interest and
timing. For instance, this problem arises when comparing actors who are expected
to get more reactions during the airing of their performances, artists whose reactions
increase during the timing of their releases, or athletes whose competitions are held
at specific times of the year. We believe that aligning the period of interest is an
important factor in conducting an appropriately controlled experiment, except when
applied to specific cases or topics with fixed timing.
4 Experiment
In this section, we conducted a validation to evaluate the method for calculation of

the Represent Score. In Sect. 4.1, we describe the validation environment. In Sects.
4.2 and 4.3, we describe the time-series variation of the Represent Score. In Sect. 4.4,
we prove the validity of our method by comparing qualitative tweets in addition to
the comparison of Scores. In Sect. 4.5, we discuss the results of these validations.
4.1 Experiment Environment
In this experiment, we collected tweets from 2019 to 2021 from ten internation-
ally active celebrities, two from each field. The fields were “politician”, “athlete”,
“artist”, “actor” and “news”. A summary of target users and collected data is shown in
Table 1.
There is a difference in the number of tweets, but no down-sampling was
performed because it does not affect the calculation formula.
Table 1 Target information

Username Type Tweets count Followers
2019 2020 2021
BarckObama Politician 140 328 274 131.5 M
JoeBiden Politician 1814 3304 486 33.7 M
BBCBreaking News 897 704 721 49.7 M
cnnbreak News 3802 4497 3191 62.8 M
10Ronaldinho Athlete 155 83 160 20.5 M
Cristiano Athlete 178 138 120 98.8 M
jtimberlake Artist 55 67 32 114.3 M
justinbieber Artist 134 528 203 63.2 M
selenagomez Actor 57 237 174 65.7 M
Schwarzenegger Actor 279 310 262 5.1 M
Figure 2 shows the distribution of RTs and Likes for each tweet for each user in
2021. As can be seen in the figure, the scale of reactions is coherent for each user.
In this environment, there is a correlation between RTs and Likes, with a correlation
coefficient of 0.915956.
Fig. 2 RT and Like distribution chart. Scatterplot of RTs and Likes per tweet in 2021 for 10 subjects,
displayed as a logarithmic graph
38 Y. Noji et al.
Fig. 3 Monthly represent scores in 2021. This figure shows the results of calculating the represent
Score for the 10 target accounts’ tweets in 2021 by tallying the reactions by month
4.2 Monthly Represent Scores
Figure 3 shows the monthly Represent Score in 2021. First, using the data presented
in Sect. 4.1, we extracted the monthly Represent Score for each user. The results
show a range of scores for the same user at different times of the year. As shown
in Sect. 3.4, this indicates a bias depending on the time of year of the data used to
calculate the score. This can also be taken as an indication of the score for the topic
during that time period.
4.3 Yearly Represent Scores
Figure 4 shows a comparison of each user’s Represent Score by year. The data
presented in Sect. 4.1 was also used to extract each user’s Represent Score for each
year in the three-years: 2019, 2020, and 2021. The results show that, as with the
monthly results, there is a range in the user’s Represent Score depending on the time
of year. However, the rank order of the scores did not change significantly, and the
same trend can be seen even if the time period changes.
As with the monthly scores, there is a range of fluctuation, but because the scores
were extracted over a cyclical period of one year, they are considered to represent
changes in a person’s status, rather than in a topic.
Fig. 4 Yearly represent scores in 2021. This figure shows the results of calculating the Represent
Score for tweets from 2019 to 2021 for the 10 target accounts by tallying reactions by year
4.4 Most Retweeted Tweets Among the Collected Celebrity

Tweets, Excluding Outliers
Table 2 shows the most retweeted tweets from the users shown in Sect. 4.1, excluding
outliers; The Represent Score column lists each user’s 2021 Represent Score, which
is sorted in an ascending order. This shows that posts by users with high Represent
Scores, such as “cnnbreak”, “BBCBreaking”, and “justinbieber” are intended to
reach a large audience. For example, the first two accounts are news media accounts,
which specialize in sending out news related information, and “justinbieber” is an
artist who sends out information about new arrivals.
In addition, tweets that receive RTs from users with low Represent Score appear
to be daily tweets or highly communicative rather than informative. For example, the
tweet posted by “Cristiano” is topical, but lacks the importance of information, as
it reports on his achievements. “BarackObama” is an accomplished and influential
politician, but the post is directed to a specific individual and is long. Even if these
users with low Represent Score have potential influence, the content of their tweets
and the structure of their sentences suggest that they are less inclined to spread the
information.
4.5 Discussion
In Sects. 4.2 and 4.3, depict the existence of bias depending on the time period used
for score calculation. At the same time, the fact that the score fluctuates depending on
the timing also indicates that the Represent Score can be characterized for detailed
40 Y. Noji et al.
Table 2 Most retweeted tweets. excluding outliers

Username Followers Represent Tweet RT Like
score
Cristiano 98.8 M 0.059133 Thank you to the Guiness 32 K 455 K
World Records. Always
good to be recognized as a
world record breaker.
Let’s keep trying to set the
numbers even higher!
10Ronaldinho 20.5 M 0.069529 Foi pra onde? Kkkkkk 2.4 K 34 K
BarackObama 131.5 M 0.100082 Happy anniversary, 18 K 341 K
Miche! Over the past
29 years, I’ve loved
watching the world get to
know you not just as a
daughter of the South
Side, but as a mother,
lawyer, executive, author,
First Lady, and my best
friend. I can’t imagine life
without you
JoeBiden 33.7 M 0.106535 We’re seeing a 10 K 74 K
coordinated attack on
voting rights in this
country. It’s Jim Crow in
the twenty-first century,
and it must end.Congress
must enact legislation to
make it easier for all
eligible Americans to
access the ballot box and
prevent attacks on the
sacred right to vote
jtimberlake 63.2 M 0.120028 15 years ago today, I 2.8 K 29 K
released my 2nd album…
FutureSex/LoveSounds.
This album changed my
life. Every album is a
different chapter and
special to me but, this
one?? I don’t even know if
I have the words
selenagomez 65.7 M 0.132857 Gracias a todos mis fans 13 K 110 K
por tan lindas palabras
sobre “De Una Vez”. Los
amo a todos! Thank you to
all my fans for such kind
words about “De Una
Vez.” I love you guys!
(continued)
Table 2 (continued)
Username Followers Represent Tweet RT Like
score
Schwarzenegger 5.1 M 0.168353 I hope all of our 0.5 K 7K
politicians stand on the
side of the voters today.
I’ll be watching
justinbieber 114.3 M 0.168666 Justice World Tour 2022 19 K 82 K
International tickets on
sale Friday
cnnbrake 62.8 M 0.204531 Police found multiple 0.7 K 15 K
victims, including
fatalities, at an office
complex in Orange,
California, after
responding to a call of
shots fired
BBCBreaking 49.7 M 0.279938 Duke and Duchess of 1709 9042
Sussex tell Queen they
will not be returning as
working members of
Royal Family
topics by appropriately narrowing down the time period and topics. If there is no
topic or period condition in the analysis, it is considered better to calculate the Score
by year to obtain the most recent stable Represent Score.
In Sects. 4.1 and 4.3, indicate that even though there is a strong correlation between
RT and Like, the absolute difference in Represent Score is not very large, and it
would not be possible to say that Represent Score alone shows a precise difference
in diffusion ability.
Next, we compare the Represent Score including the number of followers and
the scale of reactions. First, in both cases, there seems to be no direct relationship
between the size of the Represent Score and the number of followers. This is prob-
ably because the Represent Score is a ratio index. However, further insight into the
power of diffusion can be gained by examining the relationship between these three
quantitative pieces of information among users. For example, compare “JoeBiden”
and “BarackObama,” they are both American politicians with similar attributes of
global visibility and voice as presidential officeholders, their Represent Scores are
0.100082 and 0.106535, respectively, which are very close to each other. Figure 2
shows that their reactions are similar in scale. However, when comparing the number
of followers, “JoeBiden” has about a quarter of the number of followers. In this case,
“JoeBiden” has more spreading power than “BarackObama” because “JoeBiden”
has more reactions despite of his small number of followers. From this point of view,
the ratio of RT and Like is used as the score in this method because of the differ-
ence in their characteristics. However, to indicate diffusion power, it is thought to be
more effective to set another index or weight that includes the relationship between
42 Y. Noji et al.
the number of followers and the scale of reactions. Depending on the number of
followers and the size of the reaction, these could be used as weights.
The order of the scores also shows that celebrities are grouped by field, with
athletes’ tweets being more community- oriented and news accounts as information
providers being more likely to be shared. Politicians also have lower scores and
political tweets from the “Schwarzenegger” account have more Likes compared to
RTs. This suggests that each field has its characteristics related to diffusion power.
From Sect. 4.4, it can be assumed that there is a difference in the Represent
Score between informational and community-oriented tweets when looking at the
qualitative tweets for each tweet. However, since there are differences in reactions to
each tweet, it is necessary to consider the nature of the user’s usual posting content
and its influence on the frequency of such content. In addition, although these 10
accounts were targeted as international celebrities in this study, the fact that they
were grouped by field suggests the need to conduct verification in an environment
that facilitates qualitative comparisons by narrowing down the fields and increasing
the number of people targeted to examine the aforementioned number of followers
and scale of reactions. By doing so, we believe that we will be able to qualitatively
examine the information that we were not able to explore in depth this time.
5 Conclusion
In this paper, we focus on the nature of Retweet and Like reactions on Twitter and
present a method to calculate the diffusion power of influencers using these reactions.
With this method, the diffusion power of each user can be quantified as an index called
the “Represent Score”.
In order to validate this method; we conducted a qualitative evaluation of its
effectiveness by selecting international celebrities from multiple fields. The results
showed that a bias exists when the period of application is narrow, but when measured
on a periodic basis of one year, there was no significant blurring, and it was possible
to determine the status of users in terms of the tweet text. It was also found that there
was a cohesiveness in each field and that there was a nature to the field.
In the near future, we will apply this analysis after organizing other reaction infor-
mation, such as the number of quoted retweets and replies; and account information,
such as the number of followers and fields of a user’s account, to apply more detailed
information to the analysis, conducting controlled experiments, incorporating such
information into the formula, or developing a formula that consists of such infor-
mation. New indicators are being proposed. In addition, it would be necessary to
compare and improve the formula, for example, by comparing statistics on the ratio
of tweets per tweet, rather than the ratio of totals.
As a development of this study, we believe that qualitative analysis of Twitter
diffusion behavior is possible by combining this method with text mining, such as
the sentence structure of the tweet body and the words it contains.
Acknowledgements This research is a product of the research program of The Tokyo Foundation
for Policy Research. We would like to thank Editage (www.editage.com) for English language
editing.
References
1. Hajian, B., White, T.: Modelling influence in a social network: Metrics and evaluation. In:
2011 IEEE Third International Conference on Privacy, Security, Risk and Trust and 2011 IEEE
Third International Conference on Social Computing, pp. 497–500. IEEE (2011)
2. Antonakaki, D., Fragopoulou, P., Ioannidis, S.: A survey of twitter research: data model, graph
structure, sentiment analysis and attacks. Expert Syst. Appl. 164, 114006 (2021). https://doi.
org/10.1016/j.eswa.2020.114006
3. Brin, S., Page, L.: The anatomy of a large-scale hypertextual Web search engine. Comput. Netw.
ISDN Syst. 30(1–7), 107–117 (1998). http://dl.acm.org/citation.cfm?id=297810.297827
4. Kwak, H., Lee, C., Park, H., Moon, S.: What is Twitter, a social network for a news media? In:
Proceedings of the 19th International Conference on World Wide Web - WWW ’10, p. 591.
ACM Press, New York, USA (2010). http://dl.acm.org/citation.cfm?id=1772690.1772751
5. Said, A., Bowman, T.D., Abbasi, R.A., Aljohani, N.R., Hassan, S.-U., Nawaz, R.: Mining
network-level properties of Twitter altmetrics data. Scientometrics 120(1), 217–235 (2019)
6. Weng, J., Lim, E.-P., Jiang, J., He, Q.: Twitterrank. In: Proceedings of the Third ACM Inter-
national Conference on Web Search and Data Mining - WSDM ’10, p. 261. ACM Press, New
York, USA (2010). http://dl.acm.org/citation.cfm?id=1718487.1718520
7. Priyanta, S., Trisna, I.P., Prayana, N.: Social network analysis of twitter to identify issuer of
topic using pagerank. Int. J. Adv. Comput. Sci. Appl. 10(1), 107–111 (2019)
8. Romero, D.M., Galuba, W., Asur, S., Huberman, B.A.: Influence and passivity in social media.
In: Proceedings of the 20th International Conference Companion on World Wide Web - WWW
’11, p. 113. ACM Press, New York, USA (2011)
9. Hirsch, J.: An index to quantify an individual’s scientific research output. Proc. Natl. Acad.
Sci. U.S.A. 102(46), 16569–16572 (2005)
10. Ediger, D., Jiang, K., Riedy, J., Bader, D.A., Corley, C., Massive social network analysis:
Mining twitter for social good. In: 2010 39th International Conference on Parallel Processing,
pp. 583–593. IEEE (2010). http://ieeexplore.ieee.org/document/5599247/
11. Laflin, P., Mantzaris, A.V., Ainley, F., Otley, A., Grindrod, P., Higham, D.J.: Discovering and
validating influence in a dynamic online social network. Soc. Netw. Anal. Min. 3(4), 1311–1323
(2013)
12. Riquelme, F., González-Cantergiani, P.: Measuring user influence on twitter: a survey. Inf.
Process. Manag. 52(5), 949–975 (2016)
13. Cha, M., Haddadi, H., Benevenuto, F., Gummadi, K.: Measuring user influence in twitter: the
million follower fallacy. In: Proceedings of the International AAAI Conference on Web and
Social Media, vol. 4, no. 1, pp. 10–17 (2010)
14. Montangero, M., Furini, M.: Trank: ranking twitter users according to specific topics. In:
2015 12th Annual IEEE Consumer Communications and Networking Conference (CCNC),
pp. 767–772. IEEE (2015)
The Experience of Developing a FAT File
System Module in the Rust Programming
Language
Shuichi Oikawa
Abstract The Linux kernel is a heart of the operating system, and provides the
abstractions of hardware resources and manages them to be used efficiently and effec-
tively by application programs. The operating system kernel has been programmed
by the C programming language. It has been a major system programming language
for a long time due to its efficiency and simplicity. Recently, there is a move towards
introducing the Rust programming language to the Linux kernel for the type and
memory safety; thus, it is meaningful to explore the possibility of utilizing Rust to
program Linux kernel modules. This paper describes the experience of developing
the FAT file system as a kernel module in Rust employing Rust for Linux as a basis of
the development. We performed the experiments to measure its execution costs, and
found that its performance is comparable with the original FAT file system written
in C.
Keywords Systems software · Operating systems · Programming languages ·

Linux · Rust
1 Introduction
The Linux operating system is used by a wide range of systems. It is employed

by personal mobile devices, such as smart phones and notebook PCs, servers in
data centers, and also large scale supercomputers, which equip with millions of
processors; thus, it is a part of the social infrastructure that constitutes information
societies around the world. Since they are used mostly everywhere, its vulnerability
is certainly a threat to societies. Therefore, its safety is very important.
The Linux kernel is a heart of the operating system. The kernel provides the
abstractions of hardware resources and manages them to be used efficiently and
S. Oikawa (B)
School of Industrial Technology, Advanced Institute of Industrial Technology, 1-10-40
Higashiooi, Shinagawa, Tokyo, Japan
e-mail: oikawa-shuichi@aiit.ac.jp

https://doi.org/10.1007/978-3-031-19604-1_4
46 S. Oikawa
effectively by application programs. Since the kernel needs to interact with hardware
directly, it is programmed in system programming languages, which provide the
functionalities to cope with hardware, such as inline assembler, controlling data
allocation on CPU registers, and data representations that fit hardware registers. The
C programming language has been a major system programming language for a long
time because of its efficiency and simplicity; thus, it has been used to program a
number of operating system kernels including the Linux kernel.
Recently, there is a move towards introducing the Rust programming language
to the Linux kernel for the type and memory safety [9]. The C language has been
used as the programming language for the Linux kernel. While C is a popular system
programming language, it is not a safe programming language. It is not strictly type
safe since the C compiler successfully compiles programs that include undefined
behavior while it checks the types of variables and functions. It is not memory safe
since the C compiler does not check the memory boundary. Such unsafety features
of C are the root cause of various vulnerability and defects.
The Rust programming language is a novel system programming language. It
features type safety and memory safety while it can be used for the low-level pro-
gramming that enables Rust programs to interact with hardware. Such features enable
safe programming and help the reduction of vulnerability and defects. Therefore, it
is significantly meaningful for the reduction of threats to societies to explore the
possibility of utilizing Rust to program Linux kernel modules.
This paper describes the experience of developing the FAT file system as a kernel
module written in the Rust programming language. We employ Rust for Linux [11]
as a basis of the development. While Rust for Linux defines the interface that enables
kernel modules written in Rust, it does not provide Rust interfaces required for a file
system module. Thus, the implemented file system module in Rust interacts with the
data structures defined in C. We discuss the impacts of such implementation in the
aspects of type safety and memory safety. We performed the experiments to measure
the execution costs of the programs that operate on the original FAT file system
written in C and our Rust FAT file system in order to compare their performance.
The experiment results showed that the performance of our Rust FAT file system is
comparable with the original FAT file system.
The rest of this paper is organized as follows. Section 2 describes the overview
of Rust for Linux. Section 3 describes the design and implementation of a FAT file
system module in Rust. Section 4 shows the preliminary experiment results. Section 5
describes the related work. Finally, Sect. 6 concludes this paper.
2 Rust for Linux: Introducing Rust to Linux
Rust for Linux [11] is an effort to introduce the Rust programming language to the
Linux kernel. First, this section introduce the overview of the Rust programming
language. Second, Rust for Linux is briefly described. Then, the development of the
Linux kernel with Rust modules is described.
The Experience of Developing a FAT File System Module … 47
2.1 The Rust Programming Language
The Rust programming language is a novel programming language. Its development

was announced as a Mozilla project in 2010 [3] in order to develop a web browser
engine [1]. Now, its development is actively conducted by the Rust Foundation.
The Rust programming language features type safety and memory safety. It is type
safe since the Rust compiler can successfully compiles only well-defined programs,
which do not exhibit undefined behavior. It is memory safe since its compiler can
successfully compiles only programs, in which memory pointers are used correctly
to point to valid memory.
The Rust programming language is a system programming language [4]. The
highest priority feature of system programming languages is performance [2]. The
Rust compiler produces efficient executable code since it does not perform garbage
collection, which is a fairly straightforward way to realize memory safety but can
be a source of inefficient execution. Rust realizes memory safety by the ownership
model, which manages a memory region, i.e. an object, by assigning the ownership of
an object to a variable. When the variable becomes out of scope, the object assigned
to the variable is freed. It is possible to gradually transfer the source code from the
C language to the Rust language since their programs can be linked and execute
together.
2.2 Rust for Linux
Rust for Linux attracted major attention when it became a part of Linux-next in
March, 2021 [8], which is followed by the request for comments (RFC) for its
development [9] and also the announcement from Google to support it for the Android
platform [12]. Linux-next is the source tree that is intended for integration testing
and is managed separately from the main line kernel. The integration into Linux-next
is a major step toward the integration into the main line kernel while it is not always
guaranteed and it often takes a long time especially for projects that include a large
amount of work. Actually, the latest patch of Rust for Linux posted for review is
already a fourth time but is still to be considered experimental [10].
Rust for Linux defines a platform to develop kernel modules in Rust. Since the
main body of the Linux kernel is the same, the majority of the source code remains
written in C. By taking advantage of the feature of Rust that its programs can be
linked with C programs, kernel modules written in Rust is linked with the Linux
kernel. Since the main functionality of the kernel remains in the main body of the
kernel, Rust modules must interact with the main body written in C.
Rust for Linux provides numerous interfaces defined in Rust as traits in order to
interact with the main body of the Linux kernel. A trait in Rust defines a group of
functions that can be invoked for its type; thus, it defines the behavior of the type.
The traits provided by Rust for Linux define the interface and behavior of the kernel
48 S. Oikawa
data structures by grouping the data structures and their supporting functions. Just
as C modules utilize the interfaces to the kernel data structures, Rust modules utilize
those traits defined by Rust for Linux.
At this moment, Rust for Linux is just an add on to the Linux kernel. It is possible
to gradually rewrite the source code from C to Rust. The development of the Linux
kernel is rapid, and its source code tree is always renewed. In other words, new source
code is added while old unused code is removed. The Rust foundation is supported
by major technology companies, such as Amazon, Meta, Google, and Microsoft, and
they are also among active major Linux developers. Once Rust for Linux becomes a
part of the main line kernel, it is possible that a number of Rust modules will replace
the current C modules, and the majority of the kernel will be written in Rust.
2.3 Building the Linux Kernel with Rust Modules
Building Rust for Linux means building the Linux kernel with the Rust support and
Rust modules. The Rust support option is found in the General setup menu of the
Linux kernel configuration. The option is displayed only when a compatible version
of the Rust compiler is found. Sample Rust modules can be compiled by selecting
the Rust sample option in the Sample kernel code menu of the Kernel hacking menu.
Figure 1 shows the display image of the General setup menu, in which the Rust
support option is enabled.
After the configuration, the Linux kernel is build. Rust for Linux requires the
LLVM C compiler (clang) along with the Rust compiler in order to correctly match
the compiler infrastructure. While only using clang by invoking the make command
with the CC=clang option is possible, using the whole LLVM tool chain is the most
portable way by invoking the make command with the LLVM=1 option. In this way,
the binary utility programs other than the C compiler are taken from the LLVM tool
chain.
2.4 Developing Linux Kernel Modules in Rust
The development of Rust modules is self contained. Rust modules can be written only
in Rust, and there is no need to write C programs in order to link them to the main
body of the Linux kernel. The following shows example kernel modules written in
C and Rust. First, a C kernel module definition example is described. A Rust kernel
module definition example is described, next.
A simple C kernel module can be defined as shown in Fig. 2. It just prints out a
message when it is loaded and unloaded. module_init() specifies the function,
which is helloworld_init() for this example, invoked when a module is loaded
and initialized. Similarly, helloworld_exit() specifies the function, which
is helloworld_exit(), invoked when a module exits and is unloaded. The
Fig. 1 Configuring Rust for Linux in the menuconfig command by selecting the Rust support
option in the General setup menu
Fig. 2 A simple kernel

module definition
example in C
printk() function is similar to printf() and is used to print out a message in

the kernel.
module_init() provides a mechanism to register a module with the kernel. Its
argument is a pointer to the initialization function of a module, and is automatically
placed in an array of a specific section. When the kernel is invoked and performs its
initialization, kernel modules were initialized by calling their initialization function
taken from the array. Similarly, helloworld_exit() registers the exit function.
A simple Rust kernel module can be defined as shown in Fig. 3. It behaves the
same as the previous C example. module! is a macro description in Rust for Linux
50 S. Oikawa
Fig. 3 A simple kernel

module definition example
in Rust equivalent to the
one in C
in order to register a module with the kernel. It replaces module_init() and

module_exit() of a C module. module! specifies a module data structure by
type:, which is HelloWorld in this example. KernelModule and Drop and
the traits of the HelloWorld. The init() function of the KernelModule trait
defines the module initialization function, and the drop() function of the Drop
trait defines the module exit function.
3 Developing a FAT File System Module in Rust
This section first describes our motivation to develop a file system module in the
Rust programming language. It then describes the interaction and interfaces with the
kernel and the operations on the kernel data structures.
3.1 Motivation to Develop a File System Module
We developed a FAT file system module in Rust. A number of subsystems can be

developed as modules in the Linux kernel, and a file system is one of such subsystems.
Except for a few that require tight integration with the other subsystems, such as
procfs (process file system) and tmpfs (temporary file system), the file systems in
the Linux kernel are implemented as kernel modules.
Rust for Linux provides several kernel modules as samples, and those modules can
be used as references for implementation. Most of them are device drivers, and the
rest of them are mere simple samples mostly similar to the Rust kernel module shown
in Fig. 3. The status that there is no Rust kernel modules other than device drivers
and mere samples motivated us to choose a file system as a target for development
since a file system interacts with the kernel main body in a completely different way
through different interfaces.
Next, the interaction of a file system with the kernel, the interfaces of the kernel
used by a file system, and how they are realized in a Rust file system module are
described.
3.2 Interaction and Interfaces with the Kernel
The interactions of a file system module with the kernel main body are typically
performed in the following order:
1. Initialization of a module.
2. Registration of a file system.
3. Mounting a file system.
4. Mounting a block device.
5. Initialization of a file system.
6. Performing read/write operations.
Figure 4 illustrates the direction of the above interactions.
Fig. 4 The interactions of a file system module with the Linux kernel from the initialization to start
read/write operations
52 S. Oikawa
The brief statement and the involving interfaces along with how each interaction
is realized in Rust are described below.
(1) Initialization of a module is performed when the module is loaded into the kernel,
and the main body of the kernel calls the specific initialization function of the
module. The initialization function is registered to the kernel as shown in the
Rust kernel module example of Fig. 3. The initialization performed in a module
is different depending on the functionality of the module. The subsystems a
module depends basically define the interfaces used for the initialization. If the
module is a part of the file system subsystem, the module calls the interface to
register it as a file system, and it is the second step described below.
(2) Registration of a file system is called by a file system module in order to liter-
ally register the module as a file system. Calling the register_filesystem
interface registers a module as a file system with the kernel. The interface is in
the main body of the kernel; thus, it is written in the C language. Since Rust for
Linux does not provide the interface, its declaration in Rust was generated as
shown in Fig. 5. The register_filesystem interface takes an argument of
the file_system_type structure, which include the mount and name mem-
bers. The mount member is a function pointer, and the name member is a charac-
ter string that represents the type (or name) of a file system. If the file system type
specified by the mount command matches the one specified by the name member
of file_system_type, the main body of the kernel calls the function pointer
specified by the mount member as the third step described below.
(3) Mounting a file system is called through the function pointer that was registered
for the file system module as described above. Figure 6 shows the msdos_mount
function that is called through the function pointer in order to mount the FAT file
system. It is written in Rust for this work. The msdos_mount function needs to be
callable from C programs since the file_system_type structure is defined in
Candthemainbodyofthekernelcallsthemsdos_mountfunctionspecifiedbyits
mount member. The extern "C" declaration is specified for this reason. More-
over, unsafe is specified since the function takes C pointers as its arguments. The
function simply transfers the received arguments by calling the mount_bdev
interface, which is the fourth step described below.
(4) Mounting a block device is performed by calling the mount_bdev interface. A
file system defines a logical management structure in order to store data on a block
device. Mounting a block device associates a file system with the block device
Fig. 5 The register_filesystem interface to register a module as a file system with the
kernel
Fig. 6 The msdos_mount

function called through the
function pointer to mount the
FAT file system
and makes the file system its logical management structure. Figure 6 shows
that the mount_bdev interface takes the msdos_fill_super function as
its argument. It creates such an association between a file system and a block
device through the initialization of a file system, which is the fifth step described
below.
(5) Initialization of a file system is called through the msdos_fill_super func-
tion that is passed to the main body of the kernel by calling the mount_bdev
interface as described above. Figure 7 shows the msdos_fill_super func-
tion that performs the initialization of the FAT file system. The function simply
transfers the received arguments by calling the fat_fill_super function,
which processes the detailed work of the FAT file system initialization. The ini-
tialization process first reads the management region (i.e. superblock) of the file
system from the block device in order to obtain the file system management
information, the location of the file allocation table, the block size, and so on,
created on the block device. It then reads the root directory that is the start point
to traverse to and perform read/write of directories and files on the file system,
which is the sixth step described below.
(6) Performing read/write operations is done through the inode_operations
interface, which is the structure of function pointers. The interface is created for
directories and files, separately. Each contains the function pointers, that perform
appropriate operations on them. While the inode_operations interface is
defined in C, its functions are written in Rust for this work.
Fig. 7 The msdos_fill_super function performs the initialization of the FAT file system
54 S. Oikawa
3.3 Operations on the Kernel Data Structures
The Linux kernel defines various data structures that manage subsystems, abstrac-
tions, and data. The main body of the kernel passes those data structures to kernel
modules as arguments. Kernel modules obtain necessary information from them,
perform necessary processing, store the results in them, and share them with the
main body of the kernel to return the results. Therefore, they play the important roles
in order to realize the functionalities of the kernel.
The followings are the major data structures that file system modules operate on.
• super_block
• dentry
• inode
• buffer_head
The above data structures are defined for the following purposes. The super_block
structure is for file system management information. The dentry structure is for a
directory. The inode structure is for a file on storage. The buffer_head structure
is for the read/write operations of data on storage.
Rust for Linux does provide no support for the above data structures as of the
current date of writing this paper. It means that Rust modules directly operate on
the data structures defined in C. In this case, Rust modules receive the raw pointers
to the data structures as their arguments. Such operations impact the safety features
provided by Rust. The impacts are discussed in the aspects of type safety and memory
safety below.
Rust can guarantee type safety even for the data structures defined in C. They can
be translated into the definitions in Rust automatically by the tool named bindgen, and
the data structures can be transparently handled in C and Rust programs. Therefore, it
is possible to write programs in C and Rust that process the same data of a certain type
of a data structure. In terms of type safety that is not provided by C, Rust performs no
implicit type translation. It requires explicit type translation everywhere necessary,
and there are a number of places where explicit type translation is necessary in the
Rust FAT file system module. It exposes the fact that the types used in the kernel
source code are not cleanly defined. While it is cumbersome to write explicit type
translation, it makes the type of variable and functions clear. Therefore, explicit type
translation is effective to improve the readability of the source code.
Rust in principle does not operate on raw pointers for memory safety since there
is no way to perform necessary checking at compile time. Rust requires the code
to deal with raw pointers to be placed in the unsafe block in order to tell the Rust
compiler that raw pointers are allowed in exchange for risk; thus, Rust does not
provide memory safety for the code in the unsafe block. Rust modules inherently
receive the raw pointers from the main body of the kernel. The raw pointers point
to the data structures defined in C. Therefore, the code that interacts with the kernel
interfaces ends up with being in the unsafe block.
4 Experiments
We performed the experiments to measure the execution costs of the programs that
operate on the original FAT file system written in C and our Rust FAT file system in
order to compare their performance. We first describe the experiment environment
that are used for the experiments, and then show the measurement results.
4.1 Experiment Environment
We employ the QEMU system emulator as a target environment for experiments. The
version of QEMU used for the evaluation is Sect. 2.1, and QEMU emulates x86_64.
The configuration of QEMU used for the evaluation is 1 CPU, 256MB of RAM, and
the virtio-blk paravirtual block device. Evaluation programs were stored in the initial
ram disk.
The evaluation of execution costs needs to measure execution times. Times
counted by the interrupts from a timer device are not accurate enough on system
emulators. Instead, the number of instructions executed is used as the measure of exe-
cution costs. The -icount 0 option of QEMU lets the TSC (time stamp counter)
register count the number of instructions executed. The RDTSC instruction reads the
value of TSC.
4.2 Measurement Results
We measured the execution times to read data from a file since it is the most basic
operation of a file system. We created files, of which sizes are 1, 4096, and 8192
bytes, on the FAT file system, and measured the execution times to read data from
them. The page cache is discarded before each measurement in order to read data
from storage. The measurements were performed 1000 times, and their averages are
shown as the results.
Table 1 shows the results of the measurements, and Fig. 8 depicts them. For a file
of which size is just 1 byte, the performance of the Rust FAT file system is comparable
with the original one. When the sizes of file are larger, however, the performance of
Table 1 The number of instructions to read data from a file

File size (Byte) Rust FAT Original FAT Ratio (%)
1 32,579 31,245 104.3
4096 77,660 40,461 191.9
8192 79,800 55,690 143.3
56 S. Oikawa
Fig. 8 Comparison of the number of instructions to read data from a file
the Rust FAT file system degrades significantly. The result does not match intuition.
Since a file system locates the block number of data in storage and the main body of
the kernel performs data transfer, the cost to read a 1 byte file is the basic cost mostly
affected by a file system. We will investigate the reason of the results.
5 Related Work
The language features of Rust as a system programming language are discussed in

[2, 4]. Balasubramanian et al. [2] discusses the mechanisms that were previously
hindered by the high cost and complexity of their implementation but can be enabled
by the capability of Rust. Jung et al. [4] discusses the requirements of systems
programming, of which main concern is the control of performance and resource
constraints. It argues for the features of Rust that are favorable for the requirements.
While they focuses on the language features, this paper showed the implementation
of a realistic file system module and discussed the impacts explored through the
implementation in the aspects of type safety and memory safety.
There are several studies that work on the implementation of the kernel and a
file system in Rust. Levy et al. [5] describes the implementation of an embedded
kernel in Rust. The kernel features only a small set of mechanisms that deal with
threads, interrupt and exception handling, and I/O memory mapping. RedLeaf [7] is
a new operating system that aims to show that the type and memory safety features
of Rust can enable language-based isolation domains. It is based on the microkernel

architecture, and it realizes the simple POSIX subsystem in an isolation domain.
While they leverages the features of Rust in order to explore new abstractions and
mechanisms, it takes time for them to be employed in practical systems. Bento [6] is
a file system implementation in Rust. Since it is implemented as a user-level service
by using the FUSE interface, it is different from our work that is implemented as a
kernel module.
6 Summary
Recently, there is a move to introduce the Rust programming language to the Linux
kernel for the type and memory safety. This paper described the experience of devel-
oping a FAT file system module in Rust employing Rust for Linux as a basis of the
development. We implemented the FAT file system as a kernel module in Rust. We
performed the preliminary experiments to measure its execution costs. We found
that they are comparable with the original FAT file system for a small file while the
performance of the Rust FAT file system degrades significantly for larger files. Our
future work include the investigation of the reason of the performance degradation
and the completion of the file system development by implementing the missing
functionalities. Moreover, the investigation of implementing the traits necessary for
the interface with file system modules.
References
1. Anderson, B., Bergstrom, L., Goregaokar, M., Matthews, J., McAllister, K., Moffitt, J., Sapin,
S.: Engineering the servo web browser engine using rust. In: Proceedings of the 38th Interna-
tional Conference on Software Engineering Companion, ICSE ’16, pp. 81–89. Association
for Computing Machinery, New York, NY, USA (2016). https://doi.org/10.1145/2889160.
2889229
2. Balasubramanian, A., Baranowski, M.S., Burtsev, A., Panda, A., Rakamarić, Z., Ryzhyk, L.:
System programming in rust: Beyond safety. In: Proceedings of the 16th Workshop on Hot
Topics in Operating Systems, HotOS ’17, pp. 156–161. Association for Computing Machinery,
New York, NY, USA (2017). https://doi.org/10.1145/3102980.3103006
3. Hoare, G.: Project servo: technology from the past come to save the future from itself. http://
venge.net/graydon/talks/intro-talk-2.pdf(2010). Accessed 01 July 2022
4. Jung, R., Jourdan, J.H., Krebbers, R., Dreyer, D.: Safe systems programming in rust. Commun.
ACM 64(4), 144–152 (2021). https://doi.org/10.1145/3418295
5. Levy, A., Campbell, B., Ghena, B., Pannuto, P., Dutta, P., Levis, P.: The case for writing
a kernel in rust. In: Proceedings of the 8th Asia-Pacific Workshop on Systems, APSys ’17.
Association for Computing Machinery, New York, NY, USA (2017). https://doi.org/10.1145/
3124680.3124717
6. Miller, S., Zhang, K., Chen, M., Jennings, R., Chen, A., Zhuo, D., Anderson, T.: High velocity
kernel file systems with bento. In: 19th USENIX Conference on File and Storage Technolo-
58 S. Oikawa
gies (FAST 21), pp. 65–79. USENIX Association (2021). https://www.usenix.org/conference/

fast21/presentation/miller
7. Narayanan, V., Huang, T., Detweiler, D., Appel, D., Li, Z., Zellweger, G., Burtsev, A.: RedLeaf:
isolation and communication in a safe operating system. In: 14th USENIX Symposium on
Operating Systems Design and Implementation (OSDI 20), pp. 21–39. USENIX Association
(2020). https://www.usenix.org/conference/osdi20/presentation/narayanan-vikram
8. Ojeda, M.: Linux-next rust support. https://git.kernel.org/pub/scm/linux/kernel/git/next/linux-
next.git/commit/?id=c7c4c9b88eecb28d3b48ba855cd6f9f7391a33b2. Accessed 01 July 2022
9. Ojeda, M.: [rfc] rust support (2021). https://lkml.org/lkml/2021/4/14/1023. Accessed 01 July
2022
10. Ojeda, M.: [patch v4 00/20] rust support (2022). https://lkml.org/lkml/2022/2/12/123.
Accessed 01 July 2022
11. Rust for linux. https://github.com/Rust-for-Linux/. Accessed 01 July 2022
12. Rust in the android platform. https://security.googleblog.com/2021/04/rust-in-android-
platform.html. Accessed 01 July 2022
Factors Influencing Consumers’ Online
Grocery Shopping Under the New
Normal
Satoshi Nakano
Abstract Adoption of online shopping for groceries has remained low compared to
other retail domains but has accelerated due to the long-term impact of COVID-19.
This study aims to assess the psychological factors that influence consumers’ actual
online grocery purchases under the new normal by combining purchase panel data
and survey data. This study confirms that online grocery purchase amount is affected
by traditional utilitarian channel choice factors including perceived risk, search cost,
price-consciousness, and quality-consciousness. In addition, under the new normal,
the results reveal that staying at home (especially during weekdays) and having
more time leads consumers to purchase more online. Further, consumers with higher
anxiety about COVID-19 are more likely to purchase online. The insights from this
paper help retailers and marketers develop customer strategies.
Keywords Online grocery shopping · COVID-19 · Stay at home · Channel

management · Psychographics
1 Introduction
The retail environment has changed dramatically with the spread of COVID-19 as
consumers become accustomed to a new way of shopping—the “new normal” [31].
An increasing number of consumers is purchasing online, even groceries, for which
online shopping adoption is still lower than in other online retail sectors. When
consumers discover the convenience of e-commerce technology and this technology
makes a significant change in their lives, new shopping styles will become habitual
[32]. However, little is known about how different factors are affecting consumer
shopping styles in the new normal than before the pandemic. Understanding this is
important for marketers and retailers for designing their channel strategies.
For grocery shopping, studies have shown that many consumers do not purchase
products online, but instead prefer to visit local offline stores [6, 24, 27]. This is
S. Nakano (B)
Faculty of Economics, Meiji Gakuin University, Tokyo, Japan
e-mail: nakanost@eco.meijigakuin.ac.jp

https://doi.org/10.1007/978-3-031-19604-1_5
60 S. Nakano
because grocery shopping is based on more habitual needs and lower product differ-
entiation compared to other product categories. Thus, making it difficult to take
advantage of the online convenience [23, 24]. In addition, from the standpoint of
logistics such as delivery and inventory management, it is difficult to take advan-
tage of online retailing, especially when dealing with highly perishable products, for
which a long-tail assortment may not be suitable [23] Hence, the adoption of online
grocery shopping still lags behind other online retail domains. Driving consumers to
this channel remains a challenge for retailers [11].
The motivation of this study is to assess the factors driving consumers’ online
grocery shopping under the new normal. Our research makes several contribu-
tions to the literature. First, we extend the research related to the determinants of
consumers’ channel choices. These determinants have been addressed by numerous
studies. Using online channels, consumers gain the utilitarian benefits of conve-
nience and time saving [7, 11, 24, 26], and product prices [9, 23], but they must also
accept the disadvantage of purchase risks [17, 26]. It is also known that consumers
gain hedonic benefits related to entertainment and exploration [21, 27]. However, it is
unclear whether these factors contribute to online grocery shopping after COVID-19.
In addition, since COVID-19 changed the way people work and spend their leisure
time, we also need to pay attention to context-specific factors in consumers’ lives of
post-COVID-19. More and more people work from home on weekdays and spend
their holidays at home as well. The perceived shopping values are also expected to
change. Therefore, we consider context-specific factors in addition to the traditional
channel choice factors.
Second, this study is among the first to provide an integrated view of consumer
actual online shopping behavior and psychological factors after COVID-19. Most
channel studies at the consumer or customer level can be divided into those based
on behavioral data using scanner panel data or ID-POS data (e.g., [6, 7, 24]), and
those using surveys (e.g., [11, 21]). The former is more accurate because they are
based on actual behavior, but cannot consider consumers’ internal factors. The latter
can incorporate a variety of factors, but cannot evaluate whether those factors are
linked to actual behaviors. To take advantage of both approaches, our study adopts
an integrated approach by combining purchase panel data and survey data. In doing
so, we aim to gain an integrated view of behavior and the psychology.
2 Theoretical Background
2.1 Online Grocery Retailing
Consumer adoption of online shopping has been the subject of numerous studies
in multichannel and omnichannel retailing. It is a fairly mature research area [29].
Among these, the studies on consumers’ online grocery shopping have also been
ongoing since the early 2000s [9, 17, 23]. With the spread of the Internet and mobile, it
Factors Influencing Consumers’ Online Grocery Shopping Under … 61
has been predicted that most consumers will adopt online grocery shopping. However,
this is not necessarily the case at this time.
One provocative finding that emerges from a review of the literature [29] is the
persistent existence of offline single channel consumers. Over the past two decades,
retailers have faced the reality that consumers have been slower than expected to
adopt online as a channel for purchasing groceries [11]. For example, in Japan, e-
commerce (EC) for groceries has been steadily gaining popularity, but the EC rate is
still low compared to other product categories such as electronics, clothes, stationery,
and books. According to the Ministry of Economy, Trade and Industry [25], in 2019,
the EC rate, which is the ratio of EC to total sales, for Japan’s merchandise sales
sector was 41.8% for office supplies and stationery, 34.2% for books, video and
music software, 32.8% for electronics and 13.9% for clothing, while the rate for
foods, beverages, and alcoholic beverages was only 2.9%.
There are several reasons why the EC is difficult to advance in the grocery sectors.
The business model of grocery retailing has a low margin and high turnover. The
degree of product differentiation among stores is small and leads to price competition
[23]. In addition, the EC of grocery face challenges such as the heavy burden of
picking and delivery and the limited capacity to accept orders. As a result, existing
brick-and-mortar grocery retailers may continue to lose money when adding new
online channels. Grocery retailers are finding it difficult to maintain both brick-and-
mortar and online channels [11].
However, this situation could change. The pandemic has forced consumers to
become more experienced online. This may well result in consumers who have
remained stuck in the single channel migrating to the multichannel [29]. The question
is how to predict the habitual formation of such behavior. In order to do that, it is
important to update the factors that influence consumers’ online grocery shopping in
a new normal environment. In this study, we construct the behavior model based on
the theory of consumer channel choice and the contextual factors after COVID-19.
2.2 Theory of Consumer Channel Choice
Previous research suggests that consumers’ channel choice can be explained by the
shopping utility maximization theory [6, 7, 34]. In line with this theory, consumers
can be expected to select the channel that provides the highest overall acquisition
and transaction utility. Acquisition utility refers to the net effect of the benefits and
costs of products that need to be purchased. Consumers can receive benefits such
as product quality, while they need to pay costs such as price. Transaction utility
is the utility (or disutility) of delivering products from stores to homes. From the
transactions of online shopping, consumers gain advantages such as convenience
and time savings, while they accept disadvantages such as purchase risk. Online
and physical stores each have positive or negative utility drivers, and the trade-offs
between them determine consumers’ channel usage.
62 S. Nakano
Quality and price for acquisition. The key aspects of acquisition utility are quality
and price [34]. In general, the advantage of online retailing is the “long tail,” which
allows retailers to deal with niche products. The depth and breadth of the assortment
allow retailers to target customer segments with varying needs for product quality
[30]. Quality-conscious consumers pay higher prices to get better product quality,
and tend to be more loyal to their primary channel [5].
Price is a cost that consumers must pay, but online shopping can lead to savings
benefits. Consumers have perceptions of pricing and value for each channel. When
a sales price is lower than the product’s perceived value, it is an incentive to use that
channel [33]. Since consumers can easily access a wide range of information through
the Internet, the online channel has the utilitarian benefit of price comparison ease.
For many product categories, the online price tends to be lower than offline, but this
is not always the case for groceries, where discounts may not apply [11]. This has
to do with the low margins in grocery retailing and the cost of picking and delivery.
Therefore, some research suggests that the role of price is less important in online
grocery retailing [23]. However, the results are mixed. Conversely, [9] finds that
consumers who shop online for groceries more frequently are more price sensitive.
Hedonic benefits (exploration and entertainment). In addition to these utilitarian
benefits and costs, consumers can also obtain hedonic benefits when acquiring prod-
ucts. The exploration benefit is one of the hedonic benefits. By searching several
channels, consumers get the opportunity to try new products. Consumers’ propensity
to seek hedonic exploration benefits is related to innovativeness [1, 21]. Reference
[21] suggests that multichannel shoppers have a higher tendency to be innovative in
their trialability of new and unpurchased products. Few grocery shoppers purchase
everything online, and many of those who purchase online are multichannel shoppers
who also use physical stores [23, 27]. In the grocery shopping context, [27] suggests
that multichannel shoppers with more media touchpoints, such as individuals using
multiple devices (e.g., PC and mobile phone) and social media, tend to be more
innovative.
The entertainment benefit is also a hedonic benefit that consumers can gain from
shopping [3]. The tendency to derive pleasure and excitement from shopping influ-
ences channel selection. Previous research reports the positive effects of shopping
enjoyment on multichannel selection for search and purchase [21, 33].
Convenience and perceived risk for transaction. Transaction utility includes conve-
nience and perceived risk. The online channel differs from offline grocery stores
regarding the convenience of 24 h ordering capabilities and home delivery. Since
online shopping allows consumers to make purchases without time constraints, the
online channel provides consumers with time-saving benefits. Several studies suggest
that there is a positive relationship between the lack of time and frequent online
shopping [7, 24, 26].
Further, online channels provide convenience in the information search process.
Using online channel, consumers have fast, optimal access to enormous amounts of
product information. It has been proposed that the ease of searching for information
online has a significant impact on the usage of online channels [33]. While online
purchasing has the benefit of convenience, consumers who have high loyalty to
physical stores may not necessarily feel the convenience. Reference [21] shows that
consumers who do not make online purchases and focus on stores tend to have higher
store loyalty than multichannel shoppers.
Regarding transaction disadvantages, the perceived purchase risk is a major factor.
This risk is higher for online purchases than for offline ones because consumers
cannot have direct contact with the product or retailer. At times, the product the
consumer receives may arrive damaged or may be different from what the consumer
expected. In particular, a significant risk in online grocery is associated with receiving
perishable food [26]. Previous research suggests that consumers who look to avoid
such risks are less likely to make online purchases [17, 26]. However, some recent
studies have shown that the perceived purchase risk does not strongly influence the
adoption of online shopping. In the context of online grocery, [11] suggests that this
is because consumers are more familiar and more trusting toward online shopping
than a decade ago.
2.3 The Impact of COVID-19 on Consumers
COVID-19 has impacted consumer behavior worldwide in various ways. As several

studies have shown, it has a tremendous impact on consumer channel usage in grocery
purchases. Reference [12] discusses the impact of COVID-19 on the adoption of
online shopping. Based on an online survey, they imply that the social share of
confirmed COVID-19 cases increases the possibility of consumers purchasing food
online. This tendency is also more pronounced among younger people, those who
have a lower perceived risk of online purchase, and those who live in large cities.
Reference [18] conducted a survey among U.S. households to evaluate utilization of
online grocery shopping during the COVID-19 pandemic. According to their results,
around 55% of respondents shopped for groceries online in June 2020, and of those,
20% were first-timers.
From a short-term perspective, context-specific factors of the pandemic related
to health and stable living may influence consumers’ online purchases. Reference
[15] shows that illness and food shortage concerns increased the frequency of online
shopping. Related to consumers’ concerns, in the early stages of the pandemic, panic
buying, which is the phenomenon of temporarily buying large quantities of foods
and daily necessities, was seen in many parts of the world. Panic buying is caused
by negative emotions such as anxiety and fear. The panic buying itself is a tempo-
rary phenomenon as the term “panic” implies. However, as the pandemic continues,
consumers become more rational in their stockpiling and tend to hoard groceries on
a regular basis [28]. In this study, we focus on the anxiety about COVID-19 to under-
stand consumer behaviors during a pandemic. If the anxiety felt by consumers has
a strong influence on online purchasing, the specific circumstances of the pandemic
could be causing online purchases.
64 S. Nakano
On the other hand, from a long-term perspective, we need to pay attention to

consumers’ living, as working styles are changing radically. For example, telecom-
muting may have reduced commuting time and increased leisure time. More people
are spending more time at home, even on holidays. This could trigger online
purchasing, but to best our knowledge, few studies have empirically demonstrated
this. Hence, we also examine the impact of staying home status on online purchasing.
In addition, [32] raises the issue of changes in consume as consumers spend more
and more time at home. While many things can be experienced from the comfort
of home, [32] (p. 281) points out that “what we need is to empirically study ‘IN-
home everything’ impacts consumer’s impulse buying and planned vs unplanned
consumption.” Traditionally, it has been assumed that unplanned purchases occur
mainly in physical stores. However, as online shopping increases, it is crucial to
examine whether unplanned purchases also occur online. Therefore, we treat impul-
siveness toward unplanned purchases as one of the contextual factors of new normal
and examine whether this influences online purchasing.
2.4 Research Questions
This study focuses on grocery shopping, which has been slow to adopt online, and
discusses how this is changing in the new normal. Figure 1 shows our conceptual
model. We set the following research questions.
Fig. 1 Conceptual model

• RQ1. Which of the existing consumer channel choice factors influence online
grocery purchase amount in the new normal environment?
• RQ2. What contextual factors related to after COVID-19 influence online grocery
purchase amount?
Existing channel choice factors include quality consciousness, price conscious-

ness, innovativeness, shopping enjoyment, time pressure, lower search cost online,
store loyalty and risk perceptions. Contextual factors include anxiety about COVID-
19, impulsiveness and the status of staying at home.
3 Methods
3.1 Data
We used a consumer scanner panel data, called the Syndicated Consumer Index
(SCI), operated by the Japanese marketing research company INTAGE Inc. The SCI
is the de facto standard scanner panel data used for marketing by many companies in
Japan. The data document individuals’ detailed purchase histories (purchase amount
and unit). The product categories covered in this study are staple foods, seasonings,
processed foods, snacks, ice cream, milk-based drinks, soft drinks, and alcohol (but
not fresh fish, vegetables, or prepared box lunches). The data period is six months,
from March 1 to August 31, 2020 from the beginning of the severe pandemic of
COVID-19 in Japan until it settled down to some extent. From the data, the monthly
online grocery purchase amount of each individual was extracted and used as the
dependent variable for the analysis.
In addition, we conducted an online questionnaire survey between October 9,
2020 and October 19, 2020 among the panelists to collect their staying at home
status and psychographics as described in detail later. Of the approximately 50,000
scanner panelists, we randomly conducted the online survey to the panelists. As a
result, the online survey was delivered to 1,226 panelists and the valid responses
were 883 (72.0%). These consumers are male and female between the ages of 20
and 69 who live in Japan.
The dependent variable, monthly online grocery purchase amount, includes a
large number of zeros (i.e., a large number of consumers who did not make an online
purchase during the month). This is a common phenomenon in data related to online
shopping and has been observed in many other previous studies [2, 22]. To address
this issue, we respond by using a Tobit regression model which corresponds the
dependent variable containing many zeroes as described in the next section.
Moreover, actual purchase data such as scanner panel data often includes outliers
on the right side. Therefore, we controlled for the effect of extreme outliers with
reference to [22], which analyzed similar online purchase transactional data. We stan-
dardized the total online grocery purchase amounts for each consumer and dropped
66 S. Nakano
Fig. 2 Histogram of the monthly online grocery purchase amount (excluding 0)
consumers with standard scores of 4 or greater [16]. As a result, 12 consumers were

excluded, resulting in a final sample of 871 consumers (total 5,226 opportunities for
6 months per consumer).
The summary statistics of the monthly online grocery purchase amount (thou-
sand yen) are mean = 1.784, sd = 4.515, median = 0, the percentage of zero =
68.9%. Figure 2 shows the histogram of the monthly online grocery purchase amount
(excluding 0).
3.2 Variable Measurements
We measured the psychographic variables using multiple items with five-point Likert
scales ranging from 1 (fully disagree) to 5 (fully agree), as shown in Table 1. Refer-
ence [1]’s items were used for quality consciousness, price consciousness, innova-
tiveness, shopping enjoyment, time pressure, store loyalty and impulsiveness. The
constructs proposed by [1] have been used in many other previous studies for under-
standing consumer heterogeneity in a multichannel environment [21, 27]; thus, we
also adopted them. For the lower search cost online, we used the items from [19].
For risk perceptions, we used [8]’s items. Anxiety was measured using four items
following [35].
Confirmatory factor analysis was used to create psychographic variables (Tables 1
and 2). As a result of the analysis, the model fits the data well (GFI = 0.924, CFI
= 0.946, RMSEA = 0.047). For reliability, Cronbach’s α values for all constructs
are greater than 0.7 [16]. The composite reliability (CR) values of all constructs
Table 1 Variable measurements

Construct with measurement items Factor loadings
Quality consciousness
It is important to me to buy high-quality products 0.707
I will not give up high quality for a lower price 0.705
I always buy the best 0.688
Price consciousness
I find myself checking the prices even for small items 0.797
I compare prices of at least a few brands before I choose one 0.766
It is important to me to get the best price for the products I buy 0.745
Innovativeness
I like to try new and different things 0.830
I am often among the first people to try a new product 0.768
When I see a product somewhat different from the usual, I check it out 0.735
Shopping enjoyment
I like grocery shopping 0.831
I take my time when I shop 0.729
I enjoy grocery shopping 0.839
Time pressure
I always seem to be in a hurry 0.951
Most days, I have no time to relax 0.844
I never seem to have enough time for the things I want to do 0.808
Lower search cost online
It is cheaper to seek product information online 0.670
It does not take much to collect product information online 0.840
It is economical to search for information online before purchasing offline 0.694
Store loyalty
I prefer to always shop at one grocery store 0.836
I am willing to make an effort to shop my favorite grocery store 0.893
Usually, I care a lot about which particular grocery store I shop at 0.840
Risk perceptions
If I purchase online, there is a high possibility of getting the wrong product 0.966
It is difficult to judge the quality of a product online 0.858
It is likely that product I purchase online will not meet my requirements 0.707
Anxiety
I feel tense about the COVID-19 pandemic 0.782
(continued)
68 S. Nakano
Table 1 (continued)
Construct with measurement items Factor loadings
I feel anxious about the COVID-19 pandemic 0.797
I feel stressed about the COVID-19 pandemic 0.675
I feel nervous about the COVID-19 pandemic 0.753
Impulsiveness
I often find myself buying products on impulse in the grocery store 0.847
I often make an unplanned purchase when the urge strikes me 0.787
are greater than 0.7, which is above the cut-off criterion of 0.6 [4]. For convergent
validity, average variance extracted (AVE) values of all constructs are greater than
0.5. For discriminant validity, we confirmed that the square root of the AVE for each
construct is higher than its correlations with another construct [10].
Besides psychographic variables, we measured the status of staying at home on
weekdays and holidays each month as time-variant variables. The question state-
ment is: “Since the spread of COVID-19, I feel the need to stay at home on
weekdays/holidays”. The questionnaire was answered with a five-point Likert scale
ranging from 1 (strongly disagree) to 5 (strongly agree). The items are measured
separately for weekdays and holidays on a monthly basis, from March to August
2020.
As control variables, we used demographics including gender, age, number of
family members, income (million yen). Gender is expressed as a dummy variable,
where 1 represents males. Other demographics are expressed as continuous variables.
We show the summary statistics for staying at home variables and demographics in
Table 3.
3.3 Model
We designed a Tobit model for panel data to predict the online purchase amount,
denoted by yit , which refers to consumer i’s (i=1,…, N ) online purchase amount in
the month of year t (t=1,…, T ). The Tobit model with individual random effect is
used considering that the panel data formulation includes repeated observations for
each individual. Since the distribution of online purchase amounts includes a large
number of individuals who do not make any online purchases (equal to zero), we
adopted a left-censored model. The Tobit model with a lower limit of zero can be
described as follows:

yit∗ = α + x it β + z i γ + μi + υit (1)
and
Table 2 Reliability, validity and correlation matrix
α CR AVE Correlation matrix
1 2 3 4 5 6 7 8 9 10
Quality consciousness 0.741 0.743 0.503 0.709
Price consciousness 0.812 0.814 0.595 0.558 0.771
Innovativeness 0.817 0.821 0.606 0.376 0.300 0.778
Shopping enjoyment 0.839 0.841 0.639 0.455 0.425 0.396 0.800
Time pressure 0.901 0.904 0.759 0.267 0.127 0.151 0.095 0.871
Lower search cost online 0.738 0.752 0.51 0.414 0.224 0.156 0.303 0.153 0.714
Store loyalty 0.891 0.893 0.736 −0.042 −0.089 −0.086 −0.113 0.184 −0.024 0.858
Risk perceptions 0.875 0.883 0.719 0.068 −0.021 0.034 −0.002 0.166 0.037 0.483 0.858
Anxiety 0.838 0.839 0.567 0.267 0.178 0.190 0.150 0.268 0.207 0.172 0.172 0.753
Factors Influencing Consumers’ Online Grocery Shopping Under …
Impulsiveness 0.799 0.799 0.665 0.115 −0.129 0.418 0.196 0.161 0.104 0.199 0.160 0.191 0.815
The diagonal values of the correlation matrix represent the square root of the AVE values. All other values represent the correlation coefficients
69
70 S. Nakano
Table 3 Summary sample

Demographics (N = 871) %
statistics
Gender (male = 1) 52.5%
Mean SD
Age 49.061 11.558
Number of family members 2.799 1.232
Income (million yen) 5.939 2.905
The status of staying at home (N × T = 5,226 opportunities)
Stay at home on weekdays 3.288 1.432
Stay at home on holidays 4.120 0.947

yit∗ i f yit∗ > 0
yit = (2)
0 i f yit∗ ≤ 0
where yit∗ refers to the unobserved latent variable. α is the constant term. μi is the
random effect term that follows the normal distribution with mean 0 and variance
σμ2 . υit is the remaining disturbance term which follows the normal distribution with
mean 0 and variance σν2 . x it is a vector of time-variant variables that capture the
status of staying at home on weekdays and holidays each month. z i is a vector of
time-invariant variables including psychographics and demographics. β and γ are
parameter vectors. In the random effect model, μi and the explanatory variables are
assumed to be independent.
4 Results
Our aim is to assess the impact of the existing consumer channel choice factors (RQ1)
and contextual factors (RQ2) on online purchase amount using Tobit regression
analysis. Table 4 shows the estimation result.
Concerning utilitarian benefits for acquisition utility, quality-consciousness
appears to have a significant effect (p < 0.01), suggesting that quality-conscious
consumers are more likely to purchase groceries online than those who are less
quality-conscious. Further, the estimate of price-consciousness is also significant
(p < 0.01). Therefore, we conclude that price-conscious consumers are more
likely to purchase groceries online than those less price-conscious. In contrast, as
hedonic benefits, innovativeness and shopping enjoyment appears to be insignificant
(p > 0.1).
Regarding transaction utility, the estimate of time pressure is significant (p < 0.01).
However, this result is contrary to the findings of previous studies [7, 24], which show
that consumers with less time purchase online. This study indicates that consumers
with lower time pressure are more likely to purchase groceries online than those
with higher time pressure in the new normal environment. The estimate of search
Table 4 Parameter estimates

coef s.e
Constant −12.207 1.658 **
Stay at home Stay at home on weekdays 0.256 0.112 *
Stay at home on holidays 0.113 0.175
Psychographics Quality consciousness 1.289 0.273 **
Price consciousness 1.043 0.294 **
Innovativeness −0.101 0.278
Shopping enjoyment 0.288 0.266
Time pressure −1.540 0.273 **
Lower search cost online 1.115 0.255 **
Store loyalty −0.486 0.267 †
Risk perceptions −1.623 0.234 **
Anxiety 0.590 0.292 *
Impulsiveness 0.027 0.245
Demographics Gender (male = 1) −5.276 0.564 **
Age 0.120 0.022 **
Number of family members −1.221 0.274 **
Income 0.313 0.097 **
**p < 0.01, *p < 0.05, †p < 0.1
cost online is positively significant (p < 0.01). Thus, consumers who perceive online
search costs to be lower are more likely to purchase groceries online. Further, store
loyalty is marginally significant (p < 0.1) with the expected sign. It was hypothesized
that store loyalty would be strongly negative and significant, but the result indicates
that store loyalty does not necessarily have a strong effect. The estimate of risk
perception is negative and significant (p < 0.01). Therefore, consumers with lower
perceived risk are more likely to purchase groceries online than those with higher
perceived risk.
As the contextual factors after COVID-19 related to RQ2, we discover that anxiety
is positive and significant (p < 0.05). Hence, consumers with high anxiety about
COVID-19 are more likely to purchase groceries online. However, this anxiety-
based purchasing is not as impulsive as panic buying. The estimate of impulsiveness
is insignificant (p > 0.1).
Another perspective under the pandemic is how staying at home leads to online
grocery shopping. The estimate of staying at home weekday is positive and significant
(p < 0.05), but the estimate of holiday is insignificant (p > 0.1). This result indicates
that consumers who feel the need to be home during the weekdays are more likely
to do online grocery shopping.
72 S. Nakano
5 Robustness Checks
We checked whether the insignificant explanatory variables could have created signif-
icant results for the other explanatory variables in the model [16]. After excluding
all variables that showed insignificant results in Table 4, we estimated the model
again. In the channel research context, [14] performs a robustness check in a similar
way. As a result, even after excluding four variables—staying at home on holidays,
innovativeness, shopping enjoyment and impulsiveness—the significance level and
directions of the remaining explanatory variables did not change. Therefore, we
confirmed the robustness of our results.
In addition, since this study used monthly data for six months, the time trend may
have influenced the results. Therefore, we included dummy variables for the month
in the model and re-estimated the model. As a result, none of the dummy variables
for the month became significant, and the significance level and directions of the
other explanatory variables did not change. Hence, we confirmed that our results are
not influenced by any particular month.
6 Discussion
While the adoption of online shopping for groceries has remained lower than that
in other retailing domains [24, 27], its popularity had been steadily increasing prior
to the beginning of the COVID-19 pandemic. However, the long-lasting impact of
COVID-19 has changed consumers’ daily lifestyles and has accelerated online shop-
ping. Under the new normal, better understanding the factors influencing consumers’
online grocery shopping is helpful to various practitioners such as retailers, marketers
and policymakers. Hence, this issue is influential for grocery retailing research [11].
We present an integrated approach to evaluate the impact of psychological factors
on the consumers’ actual purchasing behaviors. In previous studies, studies dealing
with psychological factors and behavioral traits have been studied separately, but we
propose a holistic view. Furthermore, this study captures the contextual factors of
consumer behavior after COVID-19, which is the novelty of this study.
Among the existing consumer channel choice factors, we showed that utilitarian
factors have more influence on online purchase amount than hedonic factors. One
reason for this is that the activity of grocery shopping is considered a mundane,
routine task in general [26]. Further, our result reveals that the convenience of online
search is positively associated with online grocery shopping. The result reflects the
consumers’ tendency to make everyday purchases more efficiently.
Perceived risk is the influential factor in our results. While many studies have
supported this [17, 26], recent research has suggested that this is not necessarily the
case as online grocery shopping becomes more common [11]. However, the evidence
shows that perceived risk is still strongly related to online grocery shopping in the
Japanese market. This tendency may depend on the maturity of the market in the
target country.
An interesting finding is about time pressure. This study indicates that consumers
with lower time pressure are more likely to purchase groceries online. However,
previous studies have shown that consumers with less time are likely to purchase
online for the purpose of time-saving [7, 11, 24, 26]. This study indicates that the
opposite is true; rather, staying at home (especially on weekdays) and having more
time to spare leads consumers to purchase more online. The self-restraint from going
out due to COVID-19 could have given consumers more time to adopt a new shopping
format. The dominance of physical stores in grocery shopping has made it difficult
for online shopping to become widespread in the past, but with more time available,
the new format may take root in the future.
Moreover, we find that consumers with higher anxiety about COVID-19 are more
likely to purchase groceries online. Current and future retailing is expected to provide
hygienic and efficient ways to shop for consumer convenience [13]. Therefore, this
format of online grocery shopping is expected to become more popular, alleviating
consumer anxiety.
In contrast, consumers’ propensity to seek hedonically and entertainment benefits
are not associated with online shopping. Further, the tendency for impulsive buying is
not associated. Based on the results, the shift to online shopping does not encourage
unplanned purchases. The critical question for retailers in the future would be whether
online grocery retailing will increase the total amount of shopping by consumers,
and if not, how to increase the total amount. According to [24], in the long run,
multichannel grocery shoppers expand the share of wallets allocated to the online-
visited chain compared to single-channel shoppers. However, there is a need for
additional validation as to whether these phenomena are also occurring in the new
normal environment. It will be a challenge for retailers to figure out how to make
online shopping more enjoyable for consumers and increase unplanned purchases.
COVID-19 has forced people to change their lives, and retail formats have evolved
along with it. Some of the changes could be permanent in the future. One of the
reasons for the lack of online purchasing diffusion may be that the cost of switching
channels was too high for consumers, either because of a lack of online experience
or because of offline purchasing habits and inertia [20]. However, the pandemic
forced consumers to try new formats. Moreover, as the effects of the pandemic
lingered, it became a habit. Based on the empirical data, this study has implica-
tions regarding several important consumer characteristics. It is expected that many
researchers and practitioners will use this knowledge to draw up strategies related to
customer acquisition and retention after COVID-19.
74 S. Nakano
7 Future Research
Our study has some limitations that point to areas of future research interest. The first
limitation is the timeframe of our study, which includes only six months following the
onset of COVID-19. A longitudinal study will be necessary in the future to identify
whether consumers’ online grocery shopping will become more popular. Second,
our study focuses on online purchasing for all groceries using scanner panel data
but does not consider any specific firm channels. Several studies of multichannel
retailing provide implications regarding profitability and customer retention when
a firm deploys multiple channels (e.g., [2, 7, 24]). It would be helpful to better
understand how the factors identified in this study can be applied to the channel
development of individual firms. Third, our online survey design has a limitation.
We measured the stay home status variable for March 2020 through September 2020
in a single online survey. However, it is difficult for consumers to recall their past
monthly stay home situation. To collect more accurate data, future studies should
conduct monthly surveys.
Acknowledgements We appreciate INTAGE Inc. for permission to use the dataset.
References
1. Ailawadi, K.L., Neslin, S.A., Gedenk, K.: Pursuing the value-conscious consumer: Store brands
versus national brand promotions. J. Mark. 65(1), 71–89 (2001)
2. Ansari, A., Mela, C.F., Neslin, S.A.: Customer channel migration. J. Mark. Res. 45(1), 60–76
(2008)
3. Babin, B.J., Darden, W.R., Griffin, M.: Work and/or fun: measuring hedonic and utilitarian
shopping value. Journal of Consumer Research 20(4), 644–657 (1994)
4. Bagozzi, R.P., Yi, Y.: On the evaluation of structural equation models. J. Acad. Mark. Sci.
16(1), 74–94 (1988)
5. Briesch, R.A., Chintagunta, P.K., Fox, E.J.: How does assortment affect grocery store choice?
J. Mark. Res. 46, 176–189 (2009)
6. Campo, K., Breugelmans, E.: Buying groceries in brick and click stores: category allocation
decisions and the moderating effect of online buying experience. J. Interact. Mark. 31(3), 63–78
(2015)
7. Chintagunta, P.K., Chu, J., Cebollada, J.: Quantifying transaction costs in online/off-line
grocery channel choice. Mark. Sci. 31(1), 96–114 (2012)
8. Chiu, H.C., Hsieh, Y.C., Roan, J., Tseng, K.J., Hsieh, J.K.: The challenge for multichannel
services: cross-channel free-riding behavior. Electron. Commer. Res. Appl. 10(2), 268–277
(2011)
9. Chu, J., Arce-Urriza, M., Cebollada-Calvo, J.J., Chintagunta, P.K.: An empirical analysis of
shopping behavior across online and offline channels for grocery products: the moderating
effects of household and product characteristics. J. Interact. Mark. 24(4), 251–268 (2010)
10. Fornell, C., Larcker, D.F.: Structural equation models with unobservable variables and
measurement error: algebra and statistics. J. Mark. Res. 18(3), 328–388 (1981)
11. Frank, D.A., Peschel, A.O.: Sweetening the deal: the ingredients that drive consumer adoption
of online grocery shopping. J. Food Prod. Mark. 26(8), 535–544 (2020)
12. Gao, X., Shi, X., Guo, H., Liu, Y.: To buy or not buy food online: the impact of the COVID-19
epidemic on the adoption of e-commerce in China. PLoS ONE 15(8), e0237900 (2020)
13. Gauri, D.K., Jindal, R.P., Ratchford, B., Fox, E., Bhatnagar, A., Pandey, A., Navallo, J.R.,
Fogarty, C.S., Howerton, E.: Evolution of retail formats: past, present, and future. J. Retail.
97(1), 42–61 (2021)
14. Gensler, S., Neslin, S.A., Verhoef, P.C.: The showrooming phenomenon: it’s more than just
about price. J. Interact. Mark. 38, 29–43 (2017)
15. Grashuis, J., Skevas, T., Segovia, M.S.: Grocery shopping preferences during the COVID-19
pandemic. Sustainability 12(13), 5369 (2020)
16. Hair, J.F., Black, W.C., Babin, B.J., Anderson, R.E.: Multivariate Data Analysis, 7th edn.
Prentice Hall (2010)
17. Hansen, T.: Determinants of consumers’ repeat online buying of groceries. Int. Rev. Retail
Distrib. Consum. Res. 16(1), 93–114 (2006)
18. Jensen, K.L., Yenerall, J., Chen, X., Yu, T.E.: US consumers’ online shopping behaviors and
intentions during and after the COVID-19 pandemic. J. Agric. Appl. Econ. 53, 416–434 (2021)
19. Jepsen, A.L.: Factors affecting consumer use of the internet for information search. J. Interact.
Mark. 21(3), 21–34 (2007)
20. Kannan, P.K., Kulkarni, G.: The impact of Covid-19 on customer journeys: implications for
interactive marketing. J. Res. Interact. Mark. 16(1), 22–36 (2022)
21. Konuş, U., Verhoef, P.C., Neslin, S.A.: Multichannel shopper segments and their covariates. J.
Retail. 84(4), 398–413 (2008)
22. Li, J., Konuş, U., Pauwels, K., Langerak, F.: The hare and the tortoise: do earlier adopters of
online channels purchase more? J. Retail. 91(2), 289–308 (2015)
23. Melis, K., Campo, K., Breugelmans, E., Lamey, L.: The impact of the multi-channel retail mix
on online store choice: does online experience matter? J. Retail. 91(2), 272–288 (2015)
24. Melis, K., Campo, K., Lamey, L., Breugelmans, E.: A bigger slice of the multichannel grocery
pie: when does consumers’ online channel use expand retailers’ share of wallet? J. Retail.
92(3), 268–286 (2016)
25. Ministry of Economy, Trade and Industry: FY2020 e-commerce market survey. https://www.
meti.go.jp/english/press/2021/0730_002.html. Accessed 3 Mar 2022
26. Mortimer, G., Fazal, H.S., Andrews, L., Martin, J.: Online grocery shopping: the impact of
shopping frequency on perceived risk. Int. Rev. Retail Distrib. Consum. Res. 26(2), 202–223
(2016)
27. Nakano, S., Kondo, F.N.: Customer segmentation with purchase channels and media touch-
points using single source panel data. J. Retail. Consum. Serv. 41, 142–152 (2018)
28. Nakano, S., Akamatsu, N., Mizuno, M.: Consumer panic buying: understanding the behavioral
and psychological aspects. SSRN 3796825 (2021)
29. Neslin, S.A.: The omnichannel continuum: integrating online and offline channels along the
customer journey. J. Retail. 98(1), 111–132 (2022)
30. Neslin, S.A., Shankar, V.: Key issues in multichannel customer management: current knowledge
and future directions. J. Interact. Mark. 23(1), 70–81 (2009)
31. Roggeveen, A.L., Sethuraman, R.: How the COVID-19 pandemic may change the world of
retailing. J. Retail. 96(2), 169–171 (2020)
32. Sheth, J.: Impact of Covid-19 on consumer behavior: will the old habits return or die? J. Bus.
Res. 117, 280–283 (2020)
33. Verhoef, P.C., Neslin, S.A., Vroomen, B.: Multichannel customer management: understanding
the research-shopper phenomenon. Int. J. Res. Mark. 24(2), 129–148 (2007)
34. Vroegrijk, M., Gijsbrechts, E., Campo, K.: Close encounter with the hard discounter entry: a
multiple-store shopping perspective on the impact of local hard-discounter entry. J. Mark. Res.
50(5), 606–626 (2013)
35. Winterich, K.P., Haws, K.L.: Helpful hopefulness: the effect of future positive emotions on
consumption. J. Consum. Res. 38(3), 505–524 (2011)
Skeletal Muscle Segmentation
at the Third Lumbar Vertebral Level
in Radiotherapy CT Images
Xuzhi Zhao, Haizhen Yue, Yi Du, Shuang Hou, Weiwei Du, and Yahui Peng
Abstract A computer algorithm is proposed to segment skeletal muscles at the third

lumbar vertebral (L3) level in radiotherapy computed tomography (CT) images.
Included in the study are 20 patients who were diagnosed with rectal cancer and
their pelvic CT images were acquired with a radiotherapy CT scanner. An oncol-
ogist selects an axial CT slice at the L3 level for each patient and manually anno-
tates the ground truth, or the skeletal muscles, including both the abdominal and
the paraspinal muscles. The abdominal muscles are segmented with morphological
techniques while the paraspinal muscles are segmented with an approach including
an adaptive thresholding method, connected component analysis, and morphologi-
cal techniques. Both Dice similarity coefficient and 95th percentile of the Hausdorff
distance are used to assess the segmentation accuracy, and they are 93.8 ± 1.6 %
and 4.8 ± 1.2 mm, respectively, averaged over the entire dataset. In conclusion, the
proposed algorithm is demonstrated to be accurate in segmenting skeletal muscles
at the L3 level in radiotherapy CT images.
X. Zhao · S. Hou · Y. Peng (B)

School of Electronic and information Engineering, Beijing Jiaotong University, Beijng, China
e-mail: yhpeng@bjtu.edu.cn
X. Zhao
e-mail: 20111055@bjtu.edu.cn
S. Hou
e-mail: 21120007@bjtu.edu.cn
H. Yue · Y. Du
Department of Radiation Oncology, Peking University Cancer Hospital and Institute, Beijng,
China
e-mail: haizhenyue@bjcancer.org
Y. Du
e-mail: yidu@bjcancer.org
W. Du
Department of Information Science, Kyoto Institute of Technology, Kyoto, Japan
e-mail: duweiwei@kit.ac.jp

https://doi.org/10.1007/978-3-031-19604-1_6
78 X. Zhao et al.
Keywords Skeletal muscles · Muscle segmentation · Third lumbar vertebral (L3)

level · CT images · Radiotherapy
1 Introduction
Rectal cancer is one of the common malignant neoplasm diseases in the world [1]
and the nutritional status of patients is of great significance to the prognosis outcome
[2]. Skeletal muscle mass at the third lumbar vertebral (L3) level has been shown to
correlate with patient nutritional status [3, 4]. Computed tomography (CT) plays an
import role in muscle mass evaluation since the morphology of the muscles can be
demonstrated clearly [5]. How to develop a computer program to segment skeletal
muscles accurately at the L3 level in CT images has been investigated extensively
[6–13].
Previous studies on the segmentation of skeletal muscles at the L3 level in
CT images revolved around traditional image processing algorithms [6–9] and
deep learning-based methods [10–13]. Traditional algorithms include shape prior
modeling-based image registration [6, 9], atlas-based segmentation [7] and fuzzy
c-means clustering [8]. Deep learning-based methods include fully convolutional
neural networks [10, 11], UNet-based models [10, 12] and YOLOv3-based models
[13]. However, the existing traditional algorithms tend to rely on complex mod-
eling and thus, having trouble reproducing the results on different datasets, while
deep learning-based methods generally require a large number of images with labels
manually annotated by skilled radiologists for network training.
In this study, a novel computer algorithm is proposed to segment skeletal muscles
at the L3 level in radiotherapy CT images. The algorithm is based on the morpho-
logical characteristics of skeletal muscles in radiotherapy CT images. Because the
algorithm only consists of basic image processing techniques, it does not require a
large number of labeled images for training.
2 Materials and Methods
2.1 Patients
Included in the study are 20 rectal cancer patients (15 males and 5 females) who
were admitted to the Department of Radiation Oncology at Peking University Cancer
Hospital & Institute from April 2015 to December 2016. The patient age ranges from
31 to 77 years, with the mean of 61 years.
Skeletal Muscle Segmentation at the Third Lumbar Vertebral … 79
Table 1 CT imaging parameters

Imaging parameter Value
Tube voltage (kVp) 120
Tube current (mAs) 190
Slice thickness (mm) 5
Matrix size 512X512
Pixel spacing (mm) (1.27, 1.27)
2.2 CT Image Acquisition
All patients underwent both plain and contrast-enhanced pelvic CT studies with a
Sensation Open CT scanner (Siemens Healthineers, Erlangen, Germany) for radio-
therapy. The corresponding CT imaging parameters are shown in Table 1.
Only the plain pelvic CT images are used for muscle segmentation in this study.
2.3 Ground Truth
On the axial CT images at the L3 level, an oncologist selects a best slice that demon-
strates the structure of the spine morphology for each patient and annotates the skele-
tal muscles manually with the ITK-SNAP software [14]. A total of 20 axial images
are annotated and used as the ground truth for the assessment of the segmentation
accuracy.
Figure 1a shows a selected radiotherapy CT image at the L3 level and Fig. 1b
shows the ground truth annotated by the oncologist.
2.4 Skeletal Muscle Segmentation
The flowchart of the proposed skeletal muscle segmentation algorithm is shown in

Fig. 2. The abdominal and paraspinal muscles are segmented separately after prepro-
cessing [15].
2.4.1 Preprocessing
• Global thresholding: The input image is first segmented with a given pair of lower
and upper thresholds, −29 and 150 Hounsfield unit (HU), respectively, which are
considered the range of standard skeletal muscle CT values [16]. This step removes
most pixels belonging to subcutaneous and visceral adipose tissue.
80 X. Zhao et al.
Fig. 1 A radiotherapy CT image at the level of the third lumbar vertebral (a) and the corresponding
manually-annotated skeletal muscles (b), including both the abdominal muscles (blue) and the
paraspinal muscles (orange), given by an oncologist. Note that, for better visualization, the annotated
image is cropped, and the gray level is adjusted
Fig. 2 Flowchart of the proposed algorithm
• Skin removal: The outermost pixels of skin tissue is removed through connected
component analysis and morphology processing.
2.4.2 Abdominal Muscle Segmentation
• Convex hull extraction: The outer contour of the segmented region is found, then
the convex hull of the outer contour is extracted (Fig. 3).
• Distance map generation: To identify the thin layer of the abdominal muscles, a
Chebyshev distance map is generated from the convex hull (Fig. 4).
• Abdominal muscle identification: Inside the segmented region, the most probable
distance of the segmented pixels from the convex hull is recorded (Fig. 5). Seg-
mented pixels whose corresponding distance greater than or equal to the most
probable distance are removed.
Fig. 3 An example showing

the outer contour (red) and
the corresponding convex
hull (green) of the muscles
Fig. 4 The Chebyshev

distance map inside the
convex hull
Fig. 5 Using the most

probable distance to estimate
the inside boundary of the
abdominal muscles (red
contour)
• Abdominal muscle refinement: To refine the inner side of the region obtained in the
previous step, the convex hull of the inner contour of the previous result is extracted
(Fig. 6). Segmented pixels inside the convex hull are removed. The updated inner
side is repeatedly refined using the same method until the number of removed
pixels is less than 150.
82 X. Zhao et al.
Fig. 6 The convex hull

(blue) of the original inner
contour (red) refines the
inner profile of the
abdominal muscles
2.4.3 Paraspinal Muscle Segmentation
• Adaptive thresholding: Caring about pixels of the input image that lie within the
region of the preprocessed result, the histogram profile is fitted to a normal distribu-
tion to obtain the mean value μ and the standard deviation σ . Adaptive thresholds
are then set to be µ − 1.5σ and μ + 1.5σ (Fig. 7), which are used as the lower and
upper limits. Pixels whose value in between are segmented.
• Paraspinal muscle localization: The L3 vertebral body is segmented using a thresh-
old of 110HU. Then, the bounding box of the vertebral body is identified. An
enlarged region is cropped after dilating the upper bound by three pixels and
extending the left and right bounds to evenly double the width (Fig. 8).
• Noise removal: To remove noise in the previous result, connected components
analysis is used to remove small regions. The largest eight connected components
are retained.
• Paraspinal muscle identification: A series of rectangular boxes are generated adap-
tively in the upper left and upper right regions of the cropped image in the following
way. Some fixed-length lines in vertical direction are set in the upper left (right)
region of the image and the end part of each line is checked whether intersects
with muscle tissue. If it intersects, skip. If not, a horizontal line is generated from
the left (right) border of the image to the end of the vertical line. Then, the spatial
position of the horizontal line lowers continuously along the y-axis until its end
part intersects with muscle tissue. By removing the pixels inside the rectangular
regions, the paraspinal muscles are roughly identified (Fig. 9).
• Paraspinal muscle refinement: The connected component analysis is then used.
Criteria regarding the size and location of the regions are enforced to filter out the
connected components of non-muscle tissue. Regions inside the vertebral body
are removed. Regions with size smaller than or equal to 8 are removed. Small
regions near the top, left, and right border of the image are removed. The holes in
the image are filled.
Finally, the results of the abdominal muscle segmentation and the paraspinal
muscle segmentation are combined to get the complete skeletal muscles.
Fig. 7 The histogram in a certain range is fitted to a normal distribution (green) to determine the
adaptive lower and upper thresholds (red) for paraspinal muscle segmentation
Fig. 8 Using the bounding box of the vertebral body (yellow) to localize the region of paraspinal
muscles (red)
Fig. 9 By removing non-muscle pixels on the left a and right b upper regions, paraspinal muscles
are identified
84 X. Zhao et al.
Fig. 10 The abdominal

muscle segmentation result
Fig. 11 The paraspinal

muscle segmentation result
2.5 Evaluation Metrics
To assess the segmentation accuracy, Dice similarity coefficient (DSC) and 95th
percentile of the Hausdorff distance (HD95) are used [17]. The DSC is a measure of
pixel-wise overlap of the segmented and reference regions and HD95 evaluates the
distance between segmented and reference boundaries.
3 Results
The segmented abdominal muscles, paraspinal muscles and complete skeletal mus-
cles are shown in Figs. 10, 11, and 12, respectively.
Two segmentation results of skeletal muscles at the L3 level are shown in Fig. 13,
representing the best and worst segmentation performance in terms of DSC. HD95
is also given for reference.
The histograms of segmentation accuracy are compared between results from
using simple global thresholding method and the proposed algorithm (Fig. 14). The
statistics of the histograms are shown in Table 2. It is clear that the proposed algorithm
improves the segmentation performance on top of the global thresholding method.
Fig. 12 The complete

skeletal muscle segmentation
result
Fig. 13 Demonstration of
the best (a) and worst (b)
skeletal muscle segmentation
results from using the
proposed algorithm. The
proposed skeletal muscle
segmentation result (cyan)
and manual segmentation
result (red) are highly
overlapped (yellow). DSC:
Dice similarity coefficient.
HD95: 95th percentile of the
Hausdorff distance
86 X. Zhao et al.
Fig. 14 Histograms of Dice similarity coefficient (a) and 95th percentile of the Hausdorff dis-
tance (b) over the entire dataset for the global thresholding method and the proposed segmentation
algorithm
Table 2 Comparison of segmentation results obtained using different methods. All values are
reported as MEAN ± SD
Method Evaluation Metric
DSC (%) HD95 (mm)
Thresholding 69.1 ± 6.2 102.2 ± 52.9
Proposed 93.8 ± 1.6 4.8 ± 1.2
4 Discussion
The nutrition status of rectal cancer patients is closely related to the prognosis of the
disease [2]. Features derived from skeletal muscles at the L3 level are correlated to
the nutritional status of the patients [3, 4]. Hence, it is of great importance to segment
skeletal muscles accurately at the L3 level in CT images.
The average DSC of the proposed algorithm is 93.8 ± 1.6 on the dataset in study.
For comparison, previous studies reported DCS of 94.53 ± 5.06 [9], 98.11 ± 1.47
[10], and 98 [13], not on the same dataset. Although the mean segmentation accuracy
of the proposed algorithm is slightly lower than similar studies [9, 10, 13], the
proposed algorithm is much less expensive. The proposed algorithm circumvents
the drawbacks of complex modeling and the need for a large number of images
with annotations manually labeled for network training. In addition, the proposed
method worked in radiotherapy CT images, whose quality is normally not as good
as diagnostic CT images.
There are limitations of this study. First, the number of cases is relatively small.
The segmentation accuracy of the proposed algorithm is estimated using 20 radiother-
apy CT images. More cases can be used to improve the reliability of the estimation.
Second, the proposed algorithm is tested on plain CT images acquired with a single
radiotherapy device. In future studies, the proposed algorithm will be tested on more
imaging devices and other imaging modes.
5 Conclusion
In conclusion, the promising results indicate that the proposed image-processing

algorithm is accurate in segmenting skeletal muscles at the L3 level in radiotherapy
CT images. It might be served as an annotation tool for the assessment of nutritional
status of rectal cancer patients.
Acknowledgements This study was partially supported by the Beijing Natural Science Foundation
(No. 1212011, 1202009) and National Natural Science Foundation of China (No. 12005007).
References
1. Valentini, V., Beets-Tan, R., Borras, J.M., Krivokapi, Z., Verfaillie, C.: Evidence and research
in rectal cancer. Radiother. Oncol. 87(3), 449–474 (2008)
2. Aleksandrova, K., et al.: Metabolic syndrome and risks of colon and rectal cancer: The European
prospective investigation into cancer and nutrition study. Cancer Prev. Res. 4(11), 1873–1883
(2011)
3. Wang, S., et al.: The value of L3 skeletal muscle index in evaluating preoperative nutritional
risk and long-term prognosis in colorectal cancer patients. Sci. Rep. 10(1), 1–11 (2020)
4. Bamba, S., et al.: Assessment of body composition from CT images at the level of the third
lumbar vertebra in inflammatory bowel disease. Inflamm. Bowel Dis. 27(9), 1435–1442 (2021)
5. Goldman, L.W.: Principles of CT and CT technology. J. Nucl. Med. Technol. 35(3), 115–128
(2007)
6. Chung, H., Cobzas, D., Birdsell, L., Lieffers, J., Baracos, V.: Automated segmentation of muscle
and adipose tissue on CT images for human body composition analysis. In: Medical Imaging
2009: Visualization, Image-Guided Procedures, and Modeling, vol. 7261, pp. 197–204 (2009)
7. Meesters, S. et al.: Multi atlas-based muscle segmentation in abdominal CT images with varying
field of view. In: International Forum on Medical Imaging in Asia (IFMIA), pp. 16–17 (2012)
8. Wei, Y., Tao, X., Xu, B., Castelein, A.: Paraspinal muscle segmentation in CT images using
GSM-based fuzzy C-means clustering. J. Comput. Commun. 2(9), 70–77 (2014)
88 X. Zhao et al.
9. Popuri, K., Cobzas, D., Esfandiari, N., Baracos, V., Jägersand, M.: Body composition assess-
ment in axial CT images using FEM-based automatic segmentation of skeletal muscle. IEEE
Trans. Med. Imaging 35(2), 512–520 (2015)
10. Dabiri, S., Popuri, K., Feliciano, E.M.C., Caan, B.J., Baracos, V.E., Beg, M.F.: Muscle seg-
mentation in axial computed tomography (CT) images at the lumbar (L3) and thoracic (T4)
levels for body composition analysis. Comput. Med. Imaging Graph. 75, 47–55 (2019)
11. Liu, Y., Zhou, J., Chen, S., Liu, L.: Muscle segmentation of L3 slice in abdomen CT images
based on fully convolutional networks. In: 2019 Ninth International Conference on Image
Processing Theory, Tools and Applications (IPTA), pp. 1–5 (2019)
12. Dabiri, S., et al.: Deep learning method for localization and segmentation of abdominal CT.
Comput. Med. Imaging Graph. 85, 101776 (2020)
13. Ha, J., et al.: Development of a fully automatic deep learning system for L3 selection and body
composition assessment on computed tomography. Sci. Rep. 11(1), 1–12 (2021)
14. Yushkevich, P.A., et al.: User-guided 3D active contour segmentation of anatomical structures:
significantly improved efficiency and reliability. Neuroimage 31(3), 1116–1128 (2006)
15. Engelke, K., Museyko, O., Wang, L., Laredo, J.-D.: Quantitative analysis of skeletal muscle
by computed tomography imaging-state of the art. J. Orthop. Transl. 15, 91–103 (2018)
16. Amini, B., Boyle, S.P., Boutin, R.D., Lenchik, L.: Approaches to assessment of muscle mass
and myosteatosis on computed tomography: A systematic review. J. Gerontol. A Biol. Sci.
Med. Sci. 74(10), 1671–1678 (2019)
17. Menze, B.H., et al.: The multimodal brain tumor image segmentation benchmark (BRATS).
IEEE Trans. Med. Imaging 34(10), 1993–2024 (2015)
Speed-Up Single Shot Detector on GPU
with CUDA
Chenyu Wang, Toshio Endo, Takahiro Hirofuchi, and Tsutomu Ikegami
Abstract Nowadays, most of the current research on object detection is to improve

the whole framework, in order to improve the accuracy of detection, but another
problem of object detection is the detection speed. The more complex the archi-
tecture, the slower the speed. This time, we implemented a Single Shot Multibox
Detector(SSD) using GPU with CUDA. We have improved the object detection speed
of SSD, which is one of the most regularly used objects detection frameworks. The
most time-consuming part, the VGG16 network, is rewritten by using cuDNN, which
is made faster by about 9%. The second time-consuming part is post-processing,
where non-maximum-suppression (NMS) is performed. We accelerated NMS by
implementing our new algorithms that are suitable for GPUs, which is about 52%
faster than the original PyTorch version [16]. We also ported those parts that were
originally executed on CPU to GPU. In total, our GPU-accelerated SSD can detect
objects 22.5% faster than the original version. We demonstrate that using GPUs to
accelerate existing frameworks is a viable approach.
Keywords Object detection · GPU · CUDA · Single shot multibox detector ·

Parallel algorithm
C. Wang (B)
Tokyo Institute of Technology & National Institute of Advanced Industrial Science and
Technology (AIST), Tokyo, Japan
e-mail: wang.c.ao@m.titech.ac.jp
T. Endo
Tokyo Institute of Technology, Tokyo, Japan
e-mail: endo@is.titech.ac.jp
T. Hirofuchi · T. Ikegami
National Institute of Advanced Industrial Science and Technology (AIST), Tokyo, Japan
e-mail: t.hirofuchi@aist.go.jp
T. Ikegami
e-mail: t-ikegami@aist.go.jp

https://doi.org/10.1007/978-3-031-19604-1_7
90 C. Wang et al.
1 Introduction
1.1 Context
Object detection is a type of computer vision that recognizes real-world objects in

an image or video sequence. Humans have an innate ability to recognize objects:
despite the fact that an object might seem different depending on the viewpoint,
scale, translation, or rotation, a human can identify it with minimal effort. Even if an
item is partially obscured, it may sometimes be recognized. Our ultimate objective
is to discover objections to a contemporary computing system with human precision
as well as computer speed. In the realm of computer vision, this problem is still
difficult. Artificial Neural Networks (ANNs), which are inspired by our biological
nervous system, have been presented as a way to educate computers to learn in the
same way that people do. Artificial neural networks are constructed by individual
“neurons” with weights that mimic the connectivity of neurons, similar to biological
neural networks. Training is the process of determining each neuron’s weight, while
inference is the process of utilizing a trained neural network to do a computing job.
An ANN is made up of at least two layers, input, and output, each of which may
contain many perceptrons. The “hidden layer” is the layer that sits between the input
and output layers. An ANN with several hidden layers is known as a deep neural
network.
With the rapid development of object detection, the commercial value of object
detection has been found in many areas, such as massive security surveillance and
autonomous driving. Many commercial companies have launched their products
or services based on object detection and the market keeps growing. However, an
efficient and reliable object detection system is yet to be found on the market. Because
for commercial use, the speed of detection has always been an issue [13]. Although
object detection using deep convolutional neural networks has advanced dramatically
in recent years, there is still a long way to go to achieve commercial use to ensure
the accuracy rate, we must also achieve real-time detection. Object detection is the
process of identifying whether or not an object of interest is present in a picture or
video frame, independent of its size, orientation, or surroundings. There are numerous
techniques for performing detection operations, the simplest of which is the template
matching approach employing a moving window slide, like R-CNN [9]. However,
the method’s calculating time is a significant issue.
Due to the rising resolutions of both image and video, sequential processing of
high-resolution pictures and videos using a single core processor cannot satisfy the
needed speedup to detect an item. As a result, modern academics are focusing on
parallel processing, which involves doing several calculations at the same time uti-
lizing either a software paradigm such as a GPU or a soft-hardware paradigm such
as FPGA. Both of the paradigms have greater performance than a single core CPU.
The GPU may be utilized as a general-purpose accelerator. The Compute Unified
Device Architecture (CUDA) technology included with NVIDIA products is now
frequently used to speed up image/video processing applications rather than graph-
Speed-Up Single Shot Detector on GPU with CUDA 91
ics. In 2010, Mehta et al. presented a novel [20], high-performance implementation

of SAD(The Sum of Absolute Differences), which is a measure of the similarity
between image blocks, on the general purpose GPU architecture using NVIDIA’s
CUDA [1]. Their research proved that object detection can achieve faster detection
speed through GPU acceleration, and can have a good effect. Real-time execution of
very complicated computer vision algorithms has become a reality because of recent
breakthroughs in GPU computing speed. Multithreaded data-parallel GPU architec-
tures are commonly used in applications such as advanced driver assistance systems
(ADAS), autonomous driving, scene interpretation, intelligent video analytics, and
facial recognition, among others. It also has a lot of potential in the future, thus it’s
a terrific study topic.
1.2 Motivation
One of the most often utilized detection networks is SSD(Single Shot Multibox
Detector) [19]. When compared to other high-speed detection networks, it achieves
object detection with a high mean Average Precision(mAP). At the same time, SSD
has achieved a very good balance between accuracy and detection speed. It seems
to be an excellent research object. Major object identification networks are built on
convolutional neural networks, and numerous approaches have been developed to
speed up the computation of CNN’s convolution and full connection layers. However,
in detection networks, not only convolution and complete connection but also other
modules, need a significant amount of processing time. Therefore, in addition to the
CNN layer, attention should also be paid to the calculation of other layers. If we
accelerate other layers by GPU, we can also achieve a faster detection speed, which
is a major goal of our research.
1.3 Our Contribution
Our main contribution is SSD512 detection acceleration through CUDA, which is

about 22.5% faster than the normal version [16]. We implemented all the implemen-
tation using CUDA [25] and C++ and rewrite Backbone (VGG16) with cuDNN,
which made backbone about 9% faster than the original version. Based on the char-
acteristics of GPU, we processed the image and classification in parallel. Finally,
we proposed a CUDA-based Non-maximum Suppression(NMS) algorithm, which
is about 52% faster than the original version.
92 C. Wang et al.
2 Related Work
In this chapter, I will introduce the contents related to our research.
2.1 Object Detection
Since 2010, manual feature extraction-based object identification algorithms have

been stagnant. Region selection, feature extraction, and classification are the three
steps in the classical technique. Furthermore, in object detection contests such as the
“ImageNet Large Scale Visual Recognition Challenge (ILSVRC)” [24], “COCO:
Common Objects in Context Detection Challenge” [18] and “PASCAL VOC: The
PASCAL Visual Object Classes Challenge” [6], approaches using deep neural net-
works received the greatest scores. However, this pipeline has two problems: a good
region-selection method with a simple time complexity has yet to be discovered, and
the robustness of manual feature extraction cannot be guaranteed. A new method
[15] based on convolutional neural networks is introduced in 2012, which started
a new era to object detection. CNN significantly improved both issues, particularly
for approaches based on region suggestion called R-CNN [9]. Modern approaches
are divided into two categories: one-stage frameworks and two-stage frameworks.
YOLO [22], SSD [19], and RetinaNet [17] are examples of one-stage frameworks.
Faster R-CNN[14], Mask R-CNN [10], and Cascade R-CNN [3] are examples of
two-stage frameworks.
• Two-stage frameworks: The two-stage frameworks has higher accuracy, but the
detection speed will be relatively slower.
• One-stage frameworks: The one-stage frameworks has faster detection speed,
but the accuracy will be relatively lower.
Why did this happen? The reason for this is that the ratio of background to non-
background areas are not balanced. In the two-stage frameworks, background sam-
ples are screened through the proposal stage, and the number of candidates is firstly
reduced. There is no one statistic that can determine if two-stage frameworks are
superior to one-stage frameworks, or vice versa. With varying degrees of success,
both branches attempt to strike a balance between speed and precision. Two-stage
frameworks represent the pinnacle of object detection accuracy, but one-stage frame-
works are better suited to real-time circumstances such as video surveillance or
high-speed motion capture. In the later classification phase, the ratio of the number
of background and off-background fields is fixed at 3:1, with Online Hard Example
Mining(OHEM) [26] to maintain balance. In the one-stage frameworks, there are too
many fields simply classified as background, and these methods are very inefficient.
Therefore, RetinaNet proposed to introduce a new Loss function, Focal Loss, to solve
this problem.
A region proposal network (RPN) is used in two-stage frameworks to offer possi-
ble bounding boxes, which the detecting head network uses to refine the bounding box
coordinates and forecast classification scores. In a single network pass, the one-stage
frameworks predict the box coordinates and classification result. Non-maximum sup-
pression (NMS) is one of the most important post-processing procedures for remov-
ing boxes with comparable locations and shapes but with lower confidence levels.
In [13], they analyzed the comparison of various object detection frameworks. They
not only analyzed the correctness of different framework detection but also specifi-
cally analyzed the detection speed of various frameworks, which is also an important
indicator of the maturity of the framework.
2.2 CUDA
CUDA [1] is a parallel computing platform and application programming interface

(API) that enables applications to use specific types of graphics processing units
(GPUs) for general-purpose processing (a technique known as general-purpose com-
puting on GPUs) (GPGPU). CUDA is a software layer that allows computing kernels
to have direct access to the GPU’s virtual instruction set and parallel computational
units. C, C++, and Fortran are among the programming languages supported by
CUDA. In contrast to the previous APIs like Direct3D and OpenGL, which needed
significant graphics programming abilities, this accessibility makes it easy for paral-
lel programming experts to exploit GPU resources [25]. By compiling such code to
CUDA, CUDA-powered GPUs also support programming frameworks like OpenMP,
OpenACC, and OpenCL. There are several advantages that give CUDA an edge over
traditional general-purpose graphics processor (GPGPU) computers with graphics
APIs:
• Unified memory and unified virtual memory
• Shared memory:provides a faster area of shared memory for CUDA threads
• Scattered reads: code can be read from any address in memory
• Improved performance to transport data between CPU and GPU
• There is full support for bitwise and integer operations
2.3 Single Shot Multibox Detector
Single Shot Multibox Detector (SSD) is a well-known one-stage framework. In R-

CNN, the bounding box is moved in various ways and the calculation is performed
by CNN each time, so it took a considerable amount of processing time to detect
an object from a single image. On the other hand, SSD performs both “regional
candidate detection” and “classification” of objects in a single CNN operation, as
the name “Single Shot” implies. This has made it possible to speed up the object
detection process. SSD is designed to output multi-scale boxes from various output
layers. The model architecture is shown below in Fig. 1. According to the size of
94 C. Wang et al.
Fig. 1 Single Shot Multibox Detector Model(SSD512)
the input image, the Single Shot Multibox detector is mainly divided into two types,
SSD300 [19] and SSD512, shown in Fig. 1. The basic architecture of SSD, as shown
in Fig. 1, is based on VGG16 [27]. The layers of the first part of the network are
constructed according to the standard architecture for image classification, which is
called the base network. Eigenvalues are detected in the underlying network. The
subsequent layers are auxiliary structures for multiple object detection through multi-
scale feature maps. A total of 24,564 candidate boxes are generated in SSD512, which
is compared with 8,732 in SSD300. Because of the increased size of an input image,
a larger size of feature map is generated, and more candidate regions are generated.
This number of candidate boxes are sieved by NMS algorithm.
2.4 Non-maximum Suppression
Non Maximum Suppression (NMS) is a technique used in numerous computer vision

tasks. It is a class of algorithms to select one entity such as bounding boxes, out of
many overlapping entities. We can choose the selection criteria to arrive at the desired
results. The criteria are most commonly some form of probability number and some
form of overlap measure such as Intersection over Union. It is especially true for
high-resolution image detection, where more candidate regions are generated and
the calculation time of NMS increases. Among all object detection frameworks,
Non-maximum Suppression(NMS) is also an extremely important algorithm, which
greatly affects the accuracy and speed of detection. Especially at the present, for
high-resolution image detection, not only higher accuracy is achieved, but also more
bounding boxes are generated, so the calculation time of NMS gradually increases.
To improve detection accuracy, different NMS variants have been proposed [2,
11, 12]. Instead of discarding boxes, Soft NMS [2] reduces the confidence score as
a continuous function of intersection-union (IoU) and keeps all boxes. Continuous
functions are hand-designed in [2], and a special network is learned in [12] to regain
confidence. In addition to changing the confidence, in [11], the bounding box coor-
Fig. 2 Visualization of GPU-NMS proposal. a example candidates generated by a detector (3

objects, 9 detections); boolean matrix after b clustering and c cancellation of non-representatives;
and d result after and reduction
dinates are also updated when suppressing adjacent boxes to improve localization
accuracy. In terms of time cost, the worst-case network management complexity
is O(N 2 ), where N is the number of boxes. Therefore, when the number of boxes
is large, the time cost becomes remarkably high. This problem is exacerbated in
crowded scene object detection, as thousands of boxes are created in the RPN of
the Faster R-CNN, and the number of candidate boxes can even be over 10,000,
especially now that detection of high-resolution images is becoming more popular.
The map-reduce approach is based on [21], which is a base of our implementation,
and we present a few enhancements to it here. To begin with, the [21] technique
demands a sorted input, but our method takes inputs in any order. Second, [21]
violates the non-transitive characteristic. We begin with the method described in
[21]. The procedure is depicted in Fig. 2 [21]. Assume that each object class has a
bit matrix M of size N × N . The matrix is described as follows:

1 if i > j and I OUi, j > threashold
Mi, j =
0 otherwise
Mi, j is a symmetric matrix, as shown in Fig. 2, since I OU(i, j) = I OU( j,i) . All of
the 1 components in the lower triangle are marked with as −1. This is the stage of
the map. Row by row, the matrix is reduced: if a row of the matrix has a -1 element,
output 1, else output 0.
This method parallelizes the NMS algorithm and achieves remarkable achieve-
ment, but their tests are incomplete. In the case of different numbers of boxes, this
GPU-based algorithm also has different acceleration effects. Our research will fur-
ther test this algorithm, and on this basis, we make a little improvement to make it
more suitable for object detection.
96 C. Wang et al.
2.5 Faster R-CNN with GPU
Faster R-CNN [14] is the research object of another study [8]. Their study also
employs GPU and CUDA to produce Faster R-CNN and has obtained excellent
results, demonstrating that CUDA can be used to accelerate an existing object detec-
tion framework. Their research, on the other hand, may be better. However, there
is still much space for improvement. Furthermore, they only examined the detec-
tion speed in their study and did not assess the accuracy. Because accuracy is such
a crucial metric in object detection, their test findings are incomplete, and there is
still much space for improvement. Their research has provided me with ideas for my
study. Because accuracy is such a crucial metric in object detection, their test findings
are incomplete, and there is still much space for improvement. Their research has
provided us with ideas for our study.
3 Our Implementation and Optimization
In this chapter, we will first discuss how SSD512 is constructed using CUDA and
how to implement and improve the NMS algorithm using CUDA. Detailed results
are discussed in the next chapter.
3.1 Some Problems of Current Research
In SSD512 [19], we divide it into four parts: pre-processing layer, feature extraction
layer, proposal layer and post-processing layer. We use [16] as the test object. In
our test, the most time-consuming part is feature extraction layer, which accounts
for 55.38%, yet the rest also accounts for nearly half of the whole. However, in the
original SSD512, only feature extraction layer is calculated on GPU. The remaining
three parts are all computed on the CPU. Therefore, we propose that these three
parts be put on GPU to accelerate the computation. Later we will introduce our
implementation method on GPU.
3.2 Pre-Processing and Proposal Layer
The preprocessing resizes the input images and removes the average RGB values.
Each output pixel is given its own thread. The number of threads is equal to the
number of pixels in the output. Each thread is executed in parallel on GPU. In this
way, we can better preprocess images on the GPU. The pre-processing operation still
accounts for a small part of the whole framework. After the pre-processing, there is
the feature extraction layer, we rewrite it with cuDNN. Another part is the proposal
layer, and softmax, which is a major function in this layer, has been accelerated by
using GPU in Algorithm 1, achieving a great acceleration effect.
Algorithm 1: Softmax with GPU

Input: fea_in, class_num, height, channel
Output: fea_out
1 i ← thread I d x.x + block I d x.x ∗ block Dim.x;
2 j ← thread I d x.y + block I d x.y ∗ block Dim.y;
3 k ← block I d x.z ∗ class_num;
4 if k < channel then
5 k_iter ← k; step ← height ∗ channel
6 for k_iter < (k + class_num); do
7 coe f + = ex p f ( f ea_in[i ∗ step + j ∗ channel + k_iter ])
8 end
9 coe f ← 1/coe f ;
10 for k_iter < (k + class_num); do
11 f ea_in[i ∗ step + j ∗ channel + k_iter ] ←
ex p f ( f ea[i ∗ step + j ∗ channel + k_iter ]) ∗ coe f ;
12 end
13 end
14 f ea_out ← f ea_in;
3.3 Post Processing
Based on the algorithm of [21], we make the main improvement in the post-processing
is NMS. Our algorithm is a bit improved on the basis of [21], which makes it more
suitable for object detection and can bring faster speed. NMS’s purpose is to extract
a single, excellent representative from each clustered candidate object detection.
Therefore, NMS shares the same issues with the conventional clustering problem. It
generally consists of two fundamental operations: (1) determining which cluster each
detection belongs to, and (2) determining a representative for each cluster. An NMS
kernel must disclose a parallelization pattern in which each processing thread inde-
pendently assesses the overlapping between two specified bounding boxes in order to
use the underlying architecture of general-purpose GPUs. The goal is to prevent data
dependencies that serialize calculations to the greatest extent possible, overcoming
the scalability limits imposed by the traditional iterative clustering procedure. Our
solution solves this problem by employing a map/reduce parallelization pattern that
uses a boolean matrix to encode potential item detections as well as calculate cluster
representatives.
Data flow of the our method. Each dark grey box represents a block and light
grey box (in Fig. 2) a thread. The numbers within the thread are the default boxes’
98 C. Wang et al.
Algorithm 2: Our NMS method with GPU

Input: Scores and default Boxes
Output: Index Output
1 __shared__ score[NMS_MAX] ← scor es[thread I d x.x];
2 __shared__ bit[NMS_MAX] ← 1;
3 thread_score ← scor e[thread I d x.x];
4 thread_index ← index[thread I d x.x];
5 // Sort the default boxes by their scores;
6 default_box1 ← de f ault_box[thread_index];
7 __syncthreads();
8 // Compute IoU and eliminate boxes;
9 for i : 1 → N M S_M AX ; do
10 default_boxes2 ← de f ault_box[scor e[i]];
11 IoU← computeI oU (de f ault_box1, de f ault_box2);
12 if I oU > I oU _thr eshold then
13 bit[threadIdx.x] ← −1;
14 end
15 __syncthreads();
16 end
17 indexOut[threadIdx.x] ← bit[thread I d x.x] ∗ threadindex
score-index pairs. The default boxes are sorted by their scores. The sorted result
is placed in the shared memory. Each thread fetches the default box with the
highest score in the memory and computes the IoU for elimination. To use the
Algorithm 2, boxes have to be sorted according to their scores. Similarly, we imple-
mented the sorting algorithm on the GPU and improved mergesort’s algorithm to
parallelize the processing [7]. We also eliminated boxes with lower scores, because
the number of boxes left affects the accuracy of detection, we will discuss the specific
data in the next chapter. There are three stages to the parallel merge sort. We partition
the input data into ‘p’ equal-sized pieces in the first step. The second step involves
sorting all ‘p’ blocks using ‘p’ thread blocks. Sorted blocks are integrated into the
final sequence in the last phase. Let’s look at an example to better grasp the notion of
parallel merge sort. In the first phase, assign each thread to a number in the unsorted
array [7]. Figure 3 shows an example of parallel merge sort with two blocks and four
threads per block.
In Fig. 3, the blocks are sorted using the sor t Blocks() function. To do so, each
block is first compared to the element next to it, and then the elements are sorted. So
the group is made up of four items, and the third step repeats until the block is full
with sorted elements. The blocks are merged using the mergeBlocks() function. We
combine the blocks to create a bigger block, but we arrange the items in the resulting
array such that they are ordered. As the size of the block doubles, this function is
called until there is only one block left.
Fig. 3 Merge sort with CUDA. This is an example of a CUDA version of Merge Sort
Table 1 This is our test environment

CPU Intel(R) Xeon(R) CPU E5-2678 v3
GPU GeForce GTX 1080 Ti
OS Ubuntu 18.04
CUDA 11.0
cuDNN 8.0
OpenCV 4.2
4 Result
In this chapter, we will present the benchmark results of our implementation. The
result of the SSD512 will be first given, then we will discuss the performance of the
NMS algorithm. Our test environment summarized in Table 1.
This time our comparison object is [16], and the data set used for our tests is
PASCAL VOC2007 [5], which is a classic data set with 20 categories of objects to
be identified. I will conduct various analyses of correctness and speed later. First
of all, SSD512 consists of four parts: pre-processing, feature extraction, proposal
layer, and post-processing. The time ratio among them is not reported yet, which is
measured on our environment and shown in Fig. 4. The most time-consuming part
is feature extraction, which accounts for 55.38% of the total framework and 51.48%
of VGG16. The second most time-consuming part is the post-processing, where we
put most of our effort. In the original paper [19], they only tested the overall FPS,
but didn’t do any testing for the time ratio of each part.
100 C. Wang et al.
Fig. 4 Pytorch version of SSD512 time ratio. This is the overall time ratio diagram of SSD512,
where the part that takes the most time is the part of feature extraction
4.1 Accuracy
To confirm the validity of our rebuilt SSD512 network, the accuracy is compared with
the original work [19]. Precision and recall are two criteria used to assess accuracy.
Each output bounding box’s accuracy may be classified into four categories: true
positive, true negative, false positive, and false negative. Precision is defined as
follows:
TP
Pr ecision =
T P + FP
The number of true positives and false positives is denoted by T P and F P,

respectively. The recall is defined as:
TP
Recall =
T P + FN
where F N denotes the number of false negatives. The precision indicates how many
default boxes are used to designate the proper placements of target objects among the
outputs, i.e. the output bounding boxes’ correctness. The recall refers to the number
of target items that can be caught in the final output. Because items in datasets are
separated into many classes, another metric called “mean average precision” (mAP)
is established to reflect the overall precision:
1
m AP = Pr ecision(c)
|classes| c∈classes
Table 2 The mAP comparison of our SSD512 with the original. Experiments are run with PASCAL
VOC 2007 dataset. “Proposals” means the number of default boxes generated in the final output of
SSD512. The right column shows that in different proposals, our accelerated SSD512 is almost as
accurate as the original one
Model Proposals mAP(%)
Original SSD512 200 75.6
400 76.4
1000 76.8
4000 77.1
Our accelerated SSD512 200 75.2
400 76.1
1000 76.4
4000 76.7
where |classes| denotes the number of classes. We conducted an experiment to

evaluate the SSD512’s mAP. The author of the study provides the performance of the
original SSD512. The experiment uses the same PASCAL VOC 2007 [5] dataset as
the SSD512 publication. The results are compared with the reported value in Table 2.
The number of default boxes created in the final output of SSD512 is referred to as
“proposals”.
As shown in the Table 2, our mAP is almost equal to the original SSD512, and
the error between the two is within a reasonable range. In addition, we can see from
the table that as the number of boxes increases, the mAP increases gradually, we
observed that, however, mAP is not improved if the number of boxes exceeds over
4000, and eventually starts to decrease.
4.2 Speed
In this section, we will present our speed test results.

As shown in the Fig. 5, significant improvement is observed for the proposal layer
and the post-processing layer. We rewrote the feature extraction layer, which also
made it about 9% faster than the original part. As shown in the figure, significant
improvement is observed for the proposal layer and the post-processing layer. The
implementation of the proposal layer is 28.44% faster than the original version, and
the post-processing layer is 52.47% faster. Such a fast effect could not be achieved
without our improved algorithm and the full utilization of GPU. Although speed-up
in the feature extraction layer is not very obvious, it also plays an indispensable role
in the acceleration of the whole SSD512 framework. On the whole, we are 22.5%
faster than the original version, which further proves that it is feasible to use GPU to
accelerate the current object detection framework.
102 C. Wang et al.
Fig. 5 Execution time Comparison Result. This is a comparison of our implementation results with
the original SSD512. All parts of our implementation are faster than the original SSD512
Table 3 Execution time Of NMS and sorting. We set the threshold 0.3. The left column shows the
number of boxes for the proposal and the number of boxes left after sorting. The middle column
shows the results of the tests on the CPU and the right column shows the results of the GPU tests
Proposal/Boxes CPU(ms) GPU(ms) Speed-Up
200/24564 5.82 3.47 ×1.68
400/24564 6.37 3.58 ×1.78
1000/24564 7.46 4.01 ×1.86
4000/24564 13.13 6.47 ×2.03
Table 4 Execution time of Different NMS. This table is our test of various NMS algorithms, and
it shows that our method is the fastest
Proposal 200 400 1000 4000 20000
Faster python 0.67 1.32 2.17 8.06 78.61
Map-reduce 0.28 0.54 1.29 5.69 42.67
Our Method 0.08 0.13 0.66 3.28 28.75
Next we will focus at the NMS algorithm(with sort). In our test, there are 24,564
boxes, and the threshold is set to 0.3. And We eliminate the low-scoring boxes in the
sorting process. Then we sorted the rest, taking the first 200/400/1000/4000 boxes.
There are different numbers of boxes, so the test results are different. In the previous
overall test, we used data of 4000 default boxes. In the case of 4000 boxes, this is
the most time-consuming, but the relative mAP is also the highest (Table 3).
Our implementation on GPU is at least 1.6 times faster than on CPU and becomes
faster as the number of boxes is increased to achieve higher mAP. A comparison with
existing implementations is shown in Table 4. In this Table, only the NMS timing
(without sort) is shown. As can be seen from Table 4, when the number of boxes is
Table 5 CPU and GPU performances of NMS with different batch size. The method can guarantee
a speed-up ratio of at least 10 with batch size 1 and 400 proposals. And as the batch size gradually
increases, the acceleration effect becomes more and more obvious
Batch Size CPU(ms) GPU(ms)
1 1.32 0.129
2 3.16 0.147
4 7.51 0.162
8 16.68 0.193
16 35.93 0.285
gradually increasing, our method is becomes more advantageous, but the speed of
growth is gradually slowing down. This is because the number of GPU threads is
insufficient, and we need to wait for the previous threads to complete the task and
release it.
4.2.1 Different Batch Size
NMS algorithms of different batch sizes remove related boxes for different types of
boxes by using NMS, which will greatly increase the speed. The different Batch size
method is used in the NMS algorithm, which can be used to separate different kinds
of boxes. This method is achieved by adding an offset to boxes of different types.
However, the more categories, the more memory will be used, so the speed will be
reduced accordingly Table 5.
With batch size 1, the approach can ensure a speed-up ratio of at least 10. The
GPU method’s time does not scale linearly with batch size; in fact, when the batch
size is less than 16, the time is roughly the same. The reason for this is that when the
batch size is less than 16, the overhead of the kernel launch consumes the majority
of the time. As the batch size grows, thread-level parallelism grows as more threads
are started, allowing more calculations to be completed in the same amount of time.
When the batch size is equal to or more than 16, the number of threads launched
may exceed the number of threads that a GPU can operate at once, causing a longer
execution time. When the NMS is operating on the CPU, each image takes 1.32ms to
process when the batch size is 1 and the number of proposals is 400. Our approach in
Table 3 takes 47.17 ms to perform an image inference where the batch size is 1 and
the number of proposals is 4000, if the NMS runs on the GPU, it will take up 13.72%
of the whole time. The NMS will finish in roughly 3ms when utilizing the GPU,
which may be disregarded throughout the pipeline. This is a significant performance
speedup.
104 C. Wang et al.
Fig. 6 Execution time Comparison Result with Other Framework. This is the speed of our accel-
erated SSD512 compared to several other target detection frameworks
4.2.2 Other Framework
Although it is difficult to make a fair comparison, we have tried to compare our

implementation with other frameworks. There is no simple solution to the ques-
tion of which model is the best. We make decisions in real-world applications to
strike a balance between accuracy and speed. Aside from detector kinds, we must
be mindful of other options that have an influence on performance such as Fea-
ture extractors (VGG16, ResNet, Inception, MobileNet), Non-max suppression IoU
threshold, Boundary box encoding, and so on. In Fig. 6, our speed test results for
different kinds of object detection frameworks. It can be seen that the overall speed
of the two-stage framework [4, 14] is slower than that of the one-stage framework
[23], while the two-stage frameworks obtain higher accuracy. Anyway, as far as the
detection speed is concerned, our implementation is fastest among them.
5 Conclusions
We used GPU to accelerate SSD512. Our speed-up approaches are also applicable
to other significant detection networks such as R-FCN, YOLO, and M2det [28],
since we obtained a speed-up of the common fundamental computation of detection
networks. With the default parameters of the Pytorch version [16] whose CNN layer
is VGG16, we tested the speed-up of SSD512. Convolution and complete connection
layers still require a long time to process, as seen in Fig. 5. If we apply our ideas
to a network that spends less time computing convolution, we anticipate seeing a
more substantial speedup. Our test is run on a pretty strong GPU, but if we want
to commercialize our technology, we’ll need to consider GPUs with lower power
consumption, which has lesser performance but may be used in a wider range of
applications, such as vehicles, unmanned aerial vehicles, and so on.
Acknowledgements This work was partly supported by JSPS KAKENHI Grant Number
20H04165.
References
1. Nvidia cuda home page. https://developer.nvidia.com/zh-cn/cuda-toolkit (2017)

2. Bodla, N., Singh, B., Chellappa, R., Davis, L.S.: Soft-nms–improving object detection with
one line of code. In: Proceedings of the IEEE International Conference on Computer Vision,
pp. 5561–5569 (2017)
3. Cai, Z., Vasconcelos, N.: Cascade r-cnn: Delving into high quality object detection. In: Pro-
ceedings of the IEEE Conference on Computer Vision and Pattern Recognition, pp. 6154–6162
(2018)
4. Dai, J., Li, Y., He, K., Sun, J.: R-fcn: Object detection via region-based fully convolutional
networks. In: Advances in Neural Information Processing Systems, vol. 29 (2016)
5. Everingham, M., Van Gool, L., Williams, C.K.I., Winn, J., Zisserman, A.: The PASCAL Visual
Object Classes Challenge (VOC2007) Results. http://www.pascal-network.org/challenges/
VOC/voc2007/workshop/index.html (2007)
6. Everingham, M., Van Gool, L., Williams, C.K.I., Winn, J., Zisserman, A.: The pascal visual
object classes (voc) challenge. Int. J. Comput. Vis. 88(2), 303–338 (2010)
7. Faujdar, N., Ghrera, S.P.: Performance evaluation of merge and quick sort using gpu computing
with cuda. Int. J. Appl. Eng. Res. 10(18) (2015)
8. Fukagai, T., Maeda, K., Tanabe, S., Shirahata, K., Tomita, Y., Ike, A., Nakagawa, A.: Speed-up
of object detection neural network with gpu. In: 2018 25th IEEE International Conference on
Image Processing (ICIP), pp. 301–305. IEEE (2018)
9. Girshick, R., Donahue, J., Darrell, T., Malik, J.: Rich feature hierarchies for accurate object
detection and semantic segmentation. In: Proceedings of the IEEE Conference on Computer
Vision and Pattern Recognition, pp. 580–587 (2014)
10. He, K., Gkioxari, G., Dollár, P., Girshick, R.: Mask r-cnn. In: Proceedings of the IEEE Inter-
national Conference on Computer Vision, pp. 2961–2969 (2017)
11. He, Y., Zhu, C., Wang, J., Savvides, M., Zhang, X.: Bounding box regression with uncertainty
for accurate object detection. In: Proceedings of the IEEE/CVF Conference on Computer Vision
and Pattern Recognition, pp. 2888–2897 (2019)
12. Hosang, J., Benenson, R., Schiele, B.: Learning non-maximum suppression. In: Proceedings
of the IEEE Conference on Computer Vision and Pattern Recognition, pp. 4507–4515 (2017)
13. Huang, J., Rathod, V., Sun, C., Zhu, M., Korattikara, A., Fathi, A., Fischer, I., Wojna, Z., Song,
Y., Guadarrama, S., et al.: Speed/accuracy trade-offs for modern convolutional object detectors.
In: Proceedings of the IEEE Conference on Computer Vision and Pattern Recognition, pp.
7310–7311 (2017)
14. Jiang, H., Learned-Miller, E.: Face detection with the faster r-cnn. In: 2017 12th IEEE Interna-
tional Conference on Automatic Face & Gesture Recognition (FG 2017), pp. 650–657. IEEE
(2017)
15. Krizhevsky, A., Sutskever, I., Hinton, G.E. Imagenet classification with deep convolutional
neural networks. In: Advances in Neural Information Processing Systems, p. 25 (2012)
16. Li, C.: High quality, fast, modular reference implementation of SSD in PyTorch. https://github.
com/lufficc/SSD (2018)
17. Lin, T.Y., Goyal, P., Girshick, R., He, K., Dollár, P.: Focal loss for dense object detection. In:
Proceedings of the IEEE International Conference on Computer Vision, pp. 2980–2988 (2017)
106 C. Wang et al.
18. Lin, T.Y., Maire, M., Belongie, S., Hays, J., Perona, P., Ramanan, D., Dollár, P., Lawrence
Zitnick, C.: Microsoft coco: Common objects in context. In: European Conference on Computer
Vision, pp. 740–755. Springer (2014)
19. Liu, W., Anguelov, D., Erhan, D., Szegedy, C., Reed, S., Fu, C.Y., Berg, A.C.: Ssd: Single shot
multibox detector. In: European Conference on Computer Vision, pp. 21–37. Springer (2016)
20. Mehta, S., Misra, A., Singhal, A., Kumar, P., Mittal, A.: A high-performance parallel imple-
mentation of sum of absolute differences algorithm for motion estimation using CUDA. In:
HiPC Conf, p. 6 (2010)
21. Oro, D., Fernández, C., Martorell, X., Hernando, J.: Work-efficient parallel non-maximum
suppression for embedded GPU architectures. In: 2016 IEEE International Conference on
Acoustics, Speech and Signal Processing (ICASSP), pp. 1026–1030. IEEE (2016)
22. Redmon, J., Farhadi, A.: Yolo9000: Better, faster, stronger. Preprint at arXiv:1612.08242 (2016)
23. Redmon, J., Farhadi, A.: Yolov3: An incremental improvement. Preprint at arXiv:1804.02767
(2018)
24. Russakovsky, O., Deng, J., Hao, S., Krause, J., Satheesh, S., Ma, S., Huang, Z., Karpathy, A.,
Khosla, A., Bernstein, M., Berg, A.C., Fei-Fei, L.: ImageNet large scale visual recognition
challenge. Int. J. Comput. Vis. (IJCV) 115(3), 211–252 (2015)
25. Sachetto Oliveira, R., Rocha, B.M., Amorim, R.M., Campos, F.O., Meira, W., Toledo, E.M.,
Santos, R.W.D.: Comparing CUDA, OpenCL and OpenGl implementations of the cardiac mon-
odomain equations. In: International Conference on Parallel Processing and Applied Mathe-
matics, pp. 111–120. Springer (2011)
26. Shrivastava, A., Gupta, A., Girshick, R.: Training region-based object detectors with online
hard example mining. In: Proceedings of the IEEE Conference on Computer Vision and Pattern
Recognition, pp. 761–769 (2016)
27. Simonyan, K., Zisserman, A.: Very deep convolutional networks for large-scale image recog-
nition. Preprint at arXiv:1409.1556 (2014)
28. Zhao, Q., Sheng, T., Wang, Y., Tang, Z., Chen, Y., Cai, L., Ling, H.: M2det: A single-shot
object detector based on multi-level feature pyramid network. In: Proceedings of the AAAI
Conference on Artificial Intelligence, vol. 33, pp. 9259–9266 (2019)
An Empirical Study on the Economic
Factors Affecting on the Export
of Defense Industry Using Hofstede’s
Culture Dimension Theory
Taeyeon Kim, Dongcheol Kim, Jaehwan Kwon, and Gwangyong Gim
Abstract The defense industry export of Korea has been consistently increased
since the Defense Acquisition Program Administration (DAPA) was established in
2006; it has positive impacts on the domestic economy. Nevertheless, as competition
between countries has gradually intensified in the global defense industry market,
efforts to occupy the market for defense exports also have been constantly demanded.
Therefore, this thesis proposes the necessity of considering the cultural factors of the
countries listed to export in order to establish a defense export marketing strategy
effectively. To support the proposal, the defense export marketing strategies and
purchasing models of the other counties, that are not clearly established at present,
was proposed and partially verified in this thesis by conducting statistical analysis
using data related to defense, national, and military size of each country in the world.
Through this study, it was confirmed that cultural factors are related to indirect
influences on defense exports. Therefore, further discussion is needed to consider
cultural factors in developing future defense export marketing strategies.
Keywords DAPA · Defense industry · Marketing strategy · Cultural factors ·

Indirect influences
T. Kim · G. Gim (B)

Department of Business Administration, Soongsil University Seoul, Seoul, South Korea
e-mail: gygim@ssu.ac.kr
T. Kim
e-mail: tyk1708@gmail.com
D. Kim · J. Kwon
Department of IT Policy and Management, Soongsil Univ. Seoul, Seoul, South Korea
e-mail: onodckim@ssu.ac.kr
J. Kwon
e-mail: wcdma0225@gmail.com
https://doi.org/10.1007/978-3-031-19604-1_8
108 T. Kim et al.
1 Introduction
Nowadays, various factors such as society and culture in addition to economic factors
affect exports of the defense industry unlike in the past when military scale and
national economic power determine the flow of international relations and affect
exports of the defense industry. In particular, cultural activity is used to promote
friendship between countries, and furthermore, it contributes to increasing exports
of the defense industry. Therefore, there is a need to consider cultural factors besides
military and economic factors (defense budget, military force, and etc.) when carrying
out the defense export marketing.
In an international trade environment where the export market is diversified around
the world, the strategy of Korea’s defense export companies needs to change from a
competitive advantage strategy based on price competitiveness to an export competi-
tive advantage strategy by enhancing export marketing capabilities. An understanding
of cultural differences is essential for the segmentation of the target market, which
is the core of exporting marketing, and if the culture of the importing country is
different from that of the exporting country, the trade negotiation strategy has to be
different [1].
The Korean government is targeting niche markets with various policies and
promotional strategies to boost exports of the defense industry despite difficult
circumstances. Korea’s defense export figure was only 0.25 billion dollars in 2006,
when the Defense Acquisition Program Administration was established, but has
continued to increase and achieved an average of more than 3 billion dollars annu-
ally since 2013 through the government’s export support activities and the defense
industry’s export efforts. The performance of defense exports is showing a notice-
able increase as the government’s active investment in the defense industry and direct
intervention in defense sales diplomacy for the export of domestic R&D weapons
systems. Therefore, it is an important time when an integrated and strategic approach
by companies and government is needed to continue to expand our defense exports
at a time when defense spending is being reduced globally [2, 3].
This study identified the possibility of applying cultural considerations to defense
export marketing strategies in addition to existing considerations.
The study proposes a conceptual model of defense export that links defense
export marketing strategies and purchasing models of importing countries; seeks
the applicability of marketing strategies according to the cultural characteristics of
each country.
To this end, the study analyzes whether marketing strategies can be applied differ-
ently according to cultural characteristics between countries by utilizing real-world
data. Through this study, the study aims to contribute to the development of ideas
for marketing strategies in consideration of the cultural factors of each country when
governments and businesses establish defense export strategies.
An Empirical Study on the Economic Factors Affecting on the Export … 109
2.1 Definition of Defense Industry
The defense industry is an industry engaged in the production and development of

military supplies, including direct combat weapons such as weapons and ammunition,
as well as general supplies such as sheath and military supplies, but usually refers to
industries engaged in the production and development of critical devices that forms
a national defense power such as guns, ammunition, ships, and aircraft [4].
2.2 Features of Defense Industry
The most important feature of the defense industry is the ‘security industry’. National
security can be defined as ‘protecting all national human and physical assets and all
tangible and intangible values against external threats.’ There are various means and
methods to protect them, but above all, diplomacy and defense must be premised [5].
The second feature of the defense industry is that it is an industry integrated with
high-technology [6].
The third feature is that the defense industry is an industry with a consumer-
centered market structure. The defense industry has a bilateral monopolistic market
structure, with the only demand of the military, and only a single or a small number
of major suppliers.
2.3 Features of Defense Industry Export
Defense industry export generally means exporting military supplies, such as defense
products, or defense science and technology abroad. It has various features that are
very different from exporting commercial products [7].
First, the biggest feature is that it is a “Bilateral monopoly” that does not apply
to market economy logic. In other words, products (weapon systems) produced by
some limited producers (defense companies) are sold to particular buyers (foreign
governments). This applies both domestically and internationally [8].
Second, most of the defense industry exports are carried out as secret projects,
and joint efforts by the private, government, and military are needed. For that reason,
it is extremely difficult to export weapon systems by defense companies alone, so
strategic support from the government is essential. Various departments, including
the government as well as defense companies, can achieve defense exports through
close cooperation [9, 10].
Third, defense industry export must have close trust and cooperation between
the exporting and importing countries, as well as necessary to consider diplomatic
110 T. Kim et al.
and security situations such as regional circumstances in neighboring countries

surrounding the two countries. Since the weapons system is closely related to national
security, neighboring countries or hostile countries should be considered [11, 12].
Finally, defense industry export is a long-term business. Unlike commercial prod-
ucts, the weapon system has a very long-life cycle [13]. Once the weapon system
is adopted, the weapon system must be used for 30 to 40 years. Subsequent mili-
tary support for maintaining operations should be considered during the use of the
weapons system. Thus, the exporting and importing countries should maintain a
desired relationship until the weapons system is scrapped.
2.4 Definition of Hofstede Insights
In general, cultural factors are strong influencers in consumer choice behavior and
value judgment and are shown by differences in social members’ preferences and
ways of satisfying their needs [14]. It is impossible to define cultural factors in one
way because cultural variables vary in age, gender, language, and history. Therefore,
many scholars have tried to understand the cultural background of a country, and
among them, cross-cultural scholar Hofstede proposed ways to quantify cultural
factors through six representative cultural indicators (Index) [15].
Dr. Hofstede’s Cultural Dimension Theory is defined as a total of six variables
and has been continuously studied to date. Hofstede’s theory has limitations that it
is not significant at the level of local research and organization within the country
but is known to be very useful in identifying differences between cultures based on
empirical research [16] (Table 1).
3 Study Direction and Results
Sousa, etc. (2008) analyzed 52 papers from 1998 to 2005, and Chen, etc. meta-
analyzed 124 papers from 2006 to 2014; according to their analysis, it was found
that the culture of the other country had a decisive impact on international marketing
[17, 18]. Therefore, the marketing strategy of defense exports needs to be approached
differently from the general way. It will help to establish an export strategy if the
results of the identification and correlation analysis of factors affecting defense
exports and the empirical analysis of how they affect export performance are
referenced [19, 20].
This study presented a conceptual model that distinguishes factors affecting
a country’s defense exports (the amount of defense imports) into two categories
(independent variables and regulatory variables).
Table 1 Hofstede’s influencing factor

Influencing Meaning Low High Main country
factor
Power distance The concept of Equality Hierarchical China
how much power orientation orientation
is distributed to
members of a
society or
organization
Individualistic Believing that Group-centered Individual-centered USA, UK
personal profits
should be
prioritized over
collective profits
Uncertainty Cultural Risk taking Risk avoidance Japan, China
avoidance characteristics of
how people react
to dangerous
situations
Masculinity Tendency to Masculinity Masculinity oriented Japan, France
emphasize and non-oriented
value the
conventional role
of sex
Long-term Having a practical Short-term Long-term Republic of
orientation and future-oriented orientation orientation Korea, Japan
perspective
Indulgence Attitudes toward Suppression of Pleasure oriented South
the enjoyment of pleasure America
human life and the
satisfaction of
possession
The direct defense-related factors (national defense budget, GDP, military force,
mid-term defense budget, total population, and etc.) and the size of defense imports
are expected to be correlated. However, it is difficult to develop into a marketing
strategy using these influential factors. For instance, even if we understand the corre-
lation that the bigger the military force, the larger the amount of defense imports, it
is difficult to use it for marketing strategies [21].
Therefore, we set up a hypothesis that depending on the difference in cultural
characteristics, it is likely to affect the size of defense imports. The size of defense
imports is expected to be higher in cultures that value national security and avoid
risks, and in cultures that prefer a long-term perspective. Thus, after identifying the
cultural characteristics that influence defense imports, it is necessary to establish a
marketing strategy for defense exports in consideration of cultural characteristics
unlike direct influencing factors [22, 23].
112 T. Kim et al.
Fig. 1 Research model
3.1 Research Model
The research model for this study is shown below as (Fig. 1). Based on the theoretical
background, in order to conduct an empirical analysis on the influence of economic
factors of defense industry and Hofstede’s cultural dimension on defense imports,
the economic factors of the defense industry are set as independent variables, the
amount of defense imports as a dependent variable, and the cultural dimension of
Hofstede as the moderator variable; the following research model was established.
3.2 Selection of Variables
3.2.1 Selection of Independent Variables, Dependent Variables,

and Moderator Variables
The research model of this study is a model to analyze the impact of defense industry’s
economic factors on defense exports (imports). Therefore, the economic factors of
the defense industry are set as independent variables, and defense import is set as
dependent variables [24].
In this study, independent variables and dependent variables are selected in Ha
Kwang-ryong’s (2018) paper, which demonstrated the determinant of arms trade in
Table 2 Independent
Independent Moderator Dependent variable
variable, moderator variable,
variable variable
and dependent variable
National defense Power distance Defense import
budget
GDP Individualism
GDP per capita Masculinity
Military force Uncertainty
avoidance
Mid-term defense Long-term
budget orientation
Total Population Indulgence
the global arms market, and the moderator variables are selected from samples of
Hofstede’s cultural dimension.
Hofstede’s cultural dimension theory is defined as a total of six variables and
has been continuously studied to date. Hofstede’s theory has limitations that it is
not significant at the level of local research and organization within the country
but is known to be very useful in identifying differences between cultures based on
empirical research.
These independent variables, moderator variables, and dependent variables are
arranged in (Table 2).
3.2.2 Operational Definition of Independent, Dependent

and Moderator Variables
The operational definitions of the variables used in this study are described in
(Table 3).
4 Empirical Analysis
4.1 Effects of Economic Factors in Defense Industry

on Defense Export
As a result of the correlation analysis, defense import has a strong positive correla-
tion with defense budget, GDP, military force, mid-term defense budget, and total
population variables [25]. This shows that the defense budget, GDP, troops, mid-term
defense budget, and the total population have a relatively large impact on defense
exports and defense imports. GDP also has a strong positive correlation with defense
budget, military force, mid-term defense budget, total population, and defense import.
The correlation between other variables are shown in (Table 4).
114 T. Kim et al.
Table 3 Operational definition of variables

Category Variables Operational definition
Independent variable Defense budget Budget required to organize and maintain
the national army
GDP Market value of all final products produced
within a country’s borders over a period of
time
GDP per capita GDP divided by the average population of
the year
Military force Number of troops in major countries that
have defense imports
Mid-term defense budget Defense budget required after a period
(5–10 years)
Total population Total population in major countries that
have defense imports
Moderator variable Power distance The concept of how much power is
distributed to members of a society or
organization
Individualistic Believing that personal profits should be
prioritized over collective profits
Masculinity Tendency to emphasize and value the
conventional role of sex
Uncertainty avoidance Cultural characteristics of how people react
to dangerous situations
Long-term orientation Having a practical and future-oriented
perspective
Indulgence Attitudes toward the enjoyment of human
life and the satisfaction of possession
Dependent variable Defense import Amount of defense imports of countries
with potential defense exports
The regression standardization coefficients and hypothesis verification result in

(Table 4) shows that the factors influencing the defense import, which is depen-
dent variable were defense budget, GDP per capita, military force, defense medium
budget, and total population at 95% confidence level. It shows that the national
defense budget has negative impacts, and the other factors have positive impacts on
the defense import.
The fact that the national defense budget has negative impacts on the defense
import is that countries with higher defense budgets have a negative impact on defense
weapons imports because they prefer to secure defense technology through R&D in
their own countries.
Table 4 Regression standardization coefficients and Hypothesis validation results

Category Non-standardization Standardized t Significance Hypothesis
coefficients coefficient probability testing
B Standard Beta
error
Constant −256.231 82.729 −3.097 0.003
Defense −0.072 0.010 −3.836 −6.951 0.000 Accepta
budget
GDP 0.000 0.000 −0.170 −1.028 0.309 Reject
GDP per 0.006 0.002 0.078 2.355 0.022 Accepta
capita
Military 0.705 0.287 0.189 2.459 0.017 Accepta
force
Mid-term 0.068 0.009 4.100 7.240 0.000 Accepta
defense
budget
Total 0.000 0.000 0.341 2.368 0.022 Accepta
population
a P < 0.05
4.2 Analysis of the Moderate Effect of Hofstede Cultural

Index
The total results of hypothesis testing of the research model by moderator variables
are as shown in (Table 5).
The GDP, which is rejected in the hypothesis test of independent variables, is
shown to have a moderate effect on defense imports due to influence of cultural
factors, and the GDP per capita among the variables adopted is analyzed to have
no moderate effect. In particular, variables such as power distance, individualism,
long-term orientation, and indulgence among moderator variables are proven to have
a large moderate effect, with most of the R-square changes exceeding 50%.
This study intended to establish and verify a hypothesis that the Hofstede’s
Cultural Dimensions Index has a moderate effect in relation to the effect of economic
factors in defense industry on defense import. The summary of research hypothesis
validation results is as shown in (Table 6).
4.3 Case Study of Moderator Variables Through Hypothesis

Test Results
The analysis of the factors influenced by the moderator variables through the actual
examples of major importers are as shown in (Table 7).
In general, countries with high GDP (China, Korea, and etc.) have a high defense
import ranking. However, some countries (Iraq, Morocco, Pakistan, Singapore,
116 T. Kim et al.
Table 5 Correlation analysis of economic factors in defense industry

Dependent Independent Moderator R R F variance Significance Hypothesis
variables variables variables square square probability testing
variance F variance
Defense Defense Power 0.858 0.710 264.780 0.000 Accept
import budget distance
(Accept) Individualistic 0.937 0.745 627.226 0.000 Accept
Masculinity 0.231 0.096 6.593 0.013 Accept
UAI 0.478 0.320 32.466 0.000 Accept
Long term 0.890 0.702 337.2967 0.000 Accept
orientation
Indulgence 0.887 0.737 344.807 0.000 Accept
GDP Power 0.927 0.613 447.636 0.000 Accept
(Reject) distance
Individualistic 0.927 0.550 397.367 0.000 Accept
Masculinity 0.319 0.028 2.217 0.142 Reject
UAI 0.565 0.256 31.233 0.000 Accept
Long term 0.834 0.514 164.331 0.000 Accept
orientation
GDP per Power 0.011 0.000 0.019 0.890 Reject
capita distance
(Accept) Individualistic 0.027 0.002 0.118 0.732 Reject
Masculinity 0.035 0.016 0.870 0.355 Reject
UAI 0.087 0.028 1.596 0.212 Reject
Long term 0.133 0.042 2.544 0.117 Reject
orientation
Indulgence 0.010 0.000 0.000 0.991 Reject
Defense Military Power 0.645 0.056 8.424 0.005 Accept
import force distance
UAI 0.851 0.239 85.130 0.000 Accept
Long term 0.779 0.187 44.862 0.000 Accept
orientation
Mid-term Power 0.946 0.694 678.245 0.000 Accept
defense distance
budget Individualistic 0.975 0.673 1,410.308 0.000 Accept
(Accept)
UAI 0.672 0.421 68.088 0.000 Accept
(continued)
Table 5 (continued)
Dependent Independent Moderator R R F variance Significance Hypothesis
variables variables variables square square probability testing
variance F variance
Long term 0.946 0.666 650.185 0.000 Accept
orientation
Total Power 0.928 0.030 22.171 0.000 Accept
population distance
UAI 0.950 0.055 58.320 0.000 Accept
Long term 0.0965 0.067 99.670 0.000 Accept
orientation
Table 6 Summary of research hypothesis validation results

No Hypothesis Result
1 Economic factors in the defense industry have a significant impact on
defense import
1–1 Defense budget has a significant impact on defense import Accept
1–2 GDP has a significant impact on defense import Reject
1–3 GDP per capita has a significant impact on defense import Accept
1–4 Military force has a significant impact on defense import Accept
1–5 Mid-term defense budget has a significant impact on defense import Accept
1–6 Total population has a significant impact on defense import Accept
2 The cultural indices play a role as a moderator in the influencing
relationship between economic factors of the defense industry and defense
import
2–1 The cultural indices play a role as a moderator in the influencing Accept
relationship between defense budget and defense import
2–2 The cultural indices play a role as a moderator in the influencing Partly accept
relationship between GDP and defense import
2–3 The cultural indices play a role as a moderator in the influencing Reject
relationship between GDP per capita and defense import
relationship between military force and defense import
relationship between Mid-term defense budget and defense import
relationship between total population and defense import
118 T. Kim et al.
Table 7 Comparative analysis of factors affecting moderator variables

Country GDP Defense import Power distance Long term
(ranking/number of (ranking/number of orientation
countries) countries)
China, P.R. 13,407,400 (2/57) 12,667 (1/57) 80 87
Korea, South 1,619,420 (11/57) 1317 (2/57) 60 100
Pakistan 312,570 (33/57) 777 (3/57) 55 50
Turkey 766,428 (16/57) 685 (5/57) 66 46
Iraq 226,070 (39/57) 596 (7/57) 95 25
Viet Nam 241,272 (37/57) 546 (9/57) 70 57
Singapore 361,109 (28/57) 510 (12/57) 74 72
Morocco 118,309 (43/57) 387 (14/57) 70 24
Turkey, and Vietnam) have high defense import rankings despite their low GDP.
In both cases, the countries have high cultural indices such as the country’s power
distance and long-term orientation. Therefore, cultural factors of the country are
analyzed to affect defense import.
5 Conclusion and Future Research
This study is to derive direct factors affecting defense exports through real data and
to find and analyze factors that indirectly affect defense exports.
Specifically, it is a practical analysis of the impact of factors affecting defense
exports on major national’s amount of defense imports. In accordance with the
proposed research procedures, the study first identified the factors influencing the
defense sector, defined the amount of defense imports, and conducted a test on the
hypothesis after presenting a research hypothesis on the causal relationship between
direct & indirect influencing factors and the amount of defense imports.
As the results of a study, the direct factors (national defense budget, GDP per
capita, military force, Mid-term defense budget, and total population) and indirect
factors (individualistic, power distance, uncertainty avoidance, Masculinity, long-
term orientation, and indulgence) that influence the amount of defense imports were
presented, and it was analyzed that it was reasonable to define the amount of defense
imports as an index of exportable country.
The major achievements and contributions of this study are as follows:
First, the study established the research and analysis procedures for factors
affecting defense exports.
Second, the study empirically verified through the Hofstede Cultural Dimension
Index that not only economic factors in the defense industry but also indirect factors
such as the cultural characteristics of each country can affect defense exports by the
empirical analysis.
Third, the study presents a research model that can effectively analyze the causal
relationship between economic factors in the defense sector, Hofstede’s cultural
dimension factors, and amounts of defense imports.
Fourth, the study provides a basis for verifying hypotheses based on accurate
figures with empirical analysis through real-world data breaking away from the
qualitative survey method.
It is true that Korea’s defense exports have increased rapidly since the opening
of the DAPA (Defense Acquisition Program Administration) due to environmental
analysis of purchasing countries and active efforts. However, defense exports are
greatly influenced by the global crisis and changes in the global defense environment.
Korea is currently in the ranks of emerging defense export economies, and export
markets are limited due to the nature of the defense industry. Therefore, the effective
marketing strategy is needed to maintain steady defense exports.
The marketing steps can be sorted into 3 stages and approached differently in
order to establish the marketing strategies.
The initial stage (stage 1) is to explore countries that are capable of defense import,
the expansion stage (stage 2) is to expand defense exports with countries that started
importing defense, and the final stage (stage 3) is the continuous stage of defense
exports. This study identified that cultural differences affect defense industry exports
especially in the early stages of exploring countries that are capable of importing
defense before establishing a marketing strategy.
This paper is meaningful in that it attempted an empirical analysis through real-
world data on the factors necessary to establish strategies for survival in the global
defense market. Following the research methods and results of this study, the future
research directions are presented as followed.
First, detailed and diversified identification of the factors affecting defense
exports is required. In this study, the empirical analysis of socio-cultural factors
was conducted for the first time. However, it is true that the analysis of the direct
factors affecting defense exports is insufficient. For instance, it is necessary to include
and analyze the World Peace Index or the Corruption Index, and etc. as factors.
Second, various studies on variables that affect defense exports are needed. The
results of this study show that economic and cultural factors affect the defense
industry directly and indirectly. The variables in this study were demonstrated based
on the defense-related indices of major defense export countries and the cultural
dimension indices of Hofstede-considering the importance of the effects of these vari-
ables on defense import, research should be done considering time-series analyses
or associations between variables.
Third, research results need to be harmonized with actual policy, institutional
establishment, decision-making system, and feedback. This naturally establishes a
defense export marketing strategy and can lead to actual defense export performance.
120 T. Kim et al.
References
1. Chung, Y.K.: The relationship between export marketing negotiation and national cultures in
Hofstede and Hall’s perspectives. IASR 11(2), 253–290 (2007)
2. DTAQ: 2019 Global Defense Market Yearbook (2019)
3. Akerman, A., Seim, A.L.: The global arms trade network 1950–2007. J. Comp. Econ. 42(3),
535–551 (2014)
4. DAPA: Defense Terminology Dictionary, 214 (2013)
5. Kim, Y.-N.: A Study on activating strategic exports of defense industry: focused on government
subsidy policy and system reform, Ph.D. paper at Kyungnam Univ. (2011)
6. Hwang, I.B.: Market analysis and support system for export revitalization, MD paper SKG
Univ. (2009)
7. KOTRA: Defense export comprehensive guidebook, 4. (2019)
8. Ha, K.Y.: Determinants of arms trade in the global arms market: focusing on the characteristics
and interrelation of exporting and importing countries. KATIS 23(1), 25–54 (2018)
9. Kil, B.-O.: South Korea’s refinement plans of supporting institutions for the export revitalization
of the defense industries. J. Korean Assoc. Def. Indus-Try Stud. 26(2), 1–16 (2019)
10. Kim, S.Y.: A study on the development of defense R&D for improving the competitiveness of
defense industry export, defense & technology, 392, KDIA. (2012)
11. Kim, C.M., Jang, W.J: Recent trends in defense industry exports and future challenges, KIET
(2012)
12. An, Y.S.: A study on the regulations for implementation management of export contracts
between governments, KIET (2017)
13. Lee, J.Y.: The performance and growth factors of Korea’s defense industry export. Def. Technol.
428, KDIA, 44–55 (2014)
14. Hye, J.K., Jae, S.L.: Individualistic/collectivistic orientations and organizational citizenship
behavior: moderating effects of affective commitment and turn-over intention. JHRMR 19(1),
47–69 (2012)
15. Hofstede, G.: Culture’s Consequences: International Differences in Work-related Values,
Beverly Hills. Sage Publications, Calif (1980)
16. Hofstede, G.: Culture and Organizations: Software of the Mind. Mcgraw Hill, London, England
(1991)
17. Sung, M.J., Sung, J.P., Yoon, C.C.: An Analysis of the impact factors on the export performance
of the defense industry: the analysis of correlations using key statistical indicators in OECD
countries. Def. Technol., KDIA, 104–119 (2018)
18. Sousa, C.M.P., Martinez-Lopez, F.J., Coelho, F.: A review of the research in the literature
between 1998 and 2005. Int. J. Mark. 10(4), 343–374 (2008)
19. Moon, J.-Y., Kwon, H.-C., Kim, D.-Y.: Estimation of defense industry export function for
defense industry promotion plan. J. Korean Assoc. Def. Ind. Stud. 26(2), KADIS, 67–80 (2019)
20. Park, W.J.: The reality and development of Korea’s defense export control system. Def.
Technol., KDIA, 38–46 (2011)
21. Jang, W.J.: Top 10 promising countries for 2014 KIET defense exports, KIET (2014)
22. Branton, S. L.: Foreign policy in transition human right, democracy and U. S. Arms Exports.
Int. Stud. Q. 49, 647–667 (2005)
23. Eriskson, J.: L: Market imperative meets normative power: human rights and European arms
transfer policy. Eur. J. Int. Rel. 19(2), 209–234 (2011)
24. Chen, J., Sousa, C.M.P., He, X.: The determinants of export performance: a review of the
literature 2006–2014. Int. Mark. Rev. 33(5), 626–670 (2016)
25. Jane’s IHS: Defense Budgets, Jane’s IHS (2018)
A Study on the Application of Blockchain
Technology in Non-governmental
Organizations
Minwoo Lee, Saeyeon Lee, Heewon Lee, and Gwangyong Gim
Abstract Looking at the market trend of Non-Profit Organizations (NGOs), the

number of non-profit private organizations is steadily increasing due to the rapid
growth of civil society and as the importance of public interest activities of private
organizations are highlighted. However, the size of domestic donations has been in
decline since its peak in 2013. Transparency and reliability are important for donation
organizations’ selection criteria, and the most necessary thing to spread the donation
culture is to strengthen the transparency of fundraising organizations. Blockchain
technology is well known for Bitcoin, but its true value comes from that fact that
it can secure transparency and reliability at low cost. In addition, it is a technology
that has an advantage in strengthening security, and has recently attracted attention
in many industries. Blockchain technology is a key platform in the new era that
can dramatically reduce transaction costs and ensure transparency in institutions
and donations of non-profit organizations required by sponsors or those who want
to sponsor. It is a technology optimized for NGOs that have to operate under IT
operating costs and security at a low cost. Because blockchain technology is superior
in transparency and security, companies are starting to systematically research and
apply it. However, non-profit organizations currently lack a lot of research cases and
have little application. This study presented the implications of data for introducing
and utilizing blockchain technology to non-profit organizations (NGOs) in the future
and discussed the limitations of this study and future research tasks.
M. Lee · S. Lee · H. Lee

Department of IT Policy and Management, Soongsil University Seoul, Seoul, South Korea
e-mail: andy_lee@worldvision.or.kr
S. Lee
e-mail: saeyeon9@naver.com
H. Lee
e-mail: steve.hw.lee@gmail.com
G. Gim (B)
Department of Business Administration, Soongsil University Seoul, Seoul, South Korea
https://doi.org/10.1007/978-3-031-19604-1_9
122 M. Lee et al.
Keywords Blockchain · Donation · NGO · Non-governmental organizations
1 Introduction
Looking at the market trend of Non-Profit Organizations (NGOs), the number of

non-profit private organizations is steadily increasing due to the rapid growth of civil
society and as the importance of public interest activities of private organizations are
highlighted. However, the size of domestic donations has been in decline.
According to Statistics Korea’s social survey, Korea’s donation or donation partic-
ipation rate continued to grow until 2011, peaking at 36.4%, and continually declined
to 25.6% in 2019 and 21.6% in 2021. According to the results of the survey on the
change in donation awareness and attitude, the items that accounted for a large part of
the area needed to spread the donation culture overall were enhanced transparency
in the operation of donation organizations (33.3%), and convenience of donation
methods (3.4%) [1].
Although the donation culture is spreading due to the COVID-19 incident,
according to a survey by the Chosun Ilbo’s public service session, “The Better
Future,” 68.6% of people replied that their choice of which donation organizations to
donate to is made by transparency and reliability, and 43.3% of the respondents need
transparency to spread the donation culture. Not only that, 46.4% of the respondents
said they did not trust the fundraising organization for the reason for not donating
[2].
Blockchain technology can secure transparency and reliability at low cost. In addi-
tion, as a technology that has strengths in strengthening security, it is receiving atten-
tion in the industrial field and playing an important role in the era of the 4th Industrial
Revolution. Also, the technology has potential for development and connection.
Blockchain technology is a key platform in the new era that can dramati-
cally reduce the transparency and transaction costs of institutions and donations
required by sponsors or those who want to sponsor, and is optimized for non-profit
organizations (NGOs) that have to operate IT operating costs or security at low costs.
Because blockchain technology is superior in transparency and security, compa-
nies are starting to systematically research and apply it. However, non-profit
organizations currently lack a lot of research cases and have little application.
This study aims to conduct an empirical study on the acceptance of blockchain
technology by non-profit organizations (NGOs).
A Study on the Application of Blockchain Technology … 123
2.1 The Definition of Blockchain
Blockchain was first introduced in 2008 with the advent of Bitcoin, which was
invented by Satoshi Nakamoto. It was also introduced in a paper titled ‘Bitcoin:
Apeer-to-peer electronic cash system’ published in the cryptographic technology
community Maine in October 2008, and in this paper, blockchain technology was
described by suggesting how to prevent double payments using P2P networks [3].
Blockchain is a security technology that checks and shares the transaction books
of traders who want to use banks or financial institutions, not some, so that the trans-
action can be traded safely. The existing transaction method is made after confirming
the previous financial transaction details by an institution called a bank or the financial
sector, and the biggest difference from the blockchain is that only the minimum insti-
tution called a bank or the financial sector knows such financial transaction details.
Blockchain stores records of new transactions that are generated when one block
exists in another block and generates blocks at 10-min intervals. When it is confirmed
that the generated block is the correct transaction, all blocks are connected to the
existing block in the chain on which the transaction is recorded. All transactions in
which blocks are stacked one by one and connected to form a blockchain. According
to Deloitte’s “Technology Trends 2022,” blockchain and distributed account informa-
tion technology platforms among the seven technologies fundamentally change the
nature of business performance across organizational boundaries, and many compa-
nies are reimagining how to create and manage tangible and digital assets [4]. Due
to the various usability of the blockchain, active introduction in the public sector as
well as finance is being attempted, and it is expected to develop in various forms. It
is also being used in the non-profit sector.
2.2 A Study on Technology Acceptance Theory—The Unified

Theory of Acceptance and Use of Technology (UTAUT)
Many researchers in the IT field recognized the importance of the introduction of

these technologies and the spread of innovation and conducted research on what prior
factors lead to the introduction and spread of innovation [5]. The technology accep-
tance model is a model that applies new technologies or services or new products
to identify variables that are affected by an individual or organization’s intention to
accept them [6].
Since the 1980s, it is estimated that about 50% of new capital investments have
been invested in in information technology in corporate organizations [7]. In addition,
acceptance of information technology is a very important issue because employees
must use and accept new technologies to improve productivity within the organization
[8].
124 M. Lee et al.
There is a problem with the existing technology acceptance theory. There is a

difference between the causal relationship that affects the usefulness of consumption
through the acceptance of information technology by individuals and the accep-
tance of organizational members to information technology introduced to improve
organizational productivity. In addition, with the development and convergence of
technology, it has been argued that existing theories and models can explain only
about 40% of the user’s intention to accept information technology. There is also a
limitation in that existing technology acceptance models do not sufficiently support
the validity of the relationship between various variables and variables. In addition,
as the level of IT increases and complex and hyper-convergence develops, a situation
in which research models must be expanded is emerging [8].
Based on these problems and backgrounds, eight existing theories (TRA, TAM,
MM, TPB, C-TAM-TPB, MPCU, IDT, and SCT) are integrated and supplemented.
Then, the Unified Theory of Acceptance and Use of Technology, which consists
of four independent variables (performance expectations, effort expectations, social
impact, and facilitation conditions), four moderating variables (gender, age, expe-
rience, spontaneity), one parameter (action intention), and one dependent variable
(use behavior) was presented [8].
3 Research Method
In order to predict the actual acceptance of non-profit organizations (NGOs), which

are potential beneficiaries of blockchain technology, It plans to build a research model
focused on acceptance as follows (Fig. 1).
3.1 Research Hypothesis
The theoretical basis for the research model on the acceptance of blockchain tech-
nology by non-profit organizations (NGOs) includes the hypothesis of 14 causal
relationships and the hypothesis of two moderating effects through previous studies.
In addition to the four key variables suggested in the UTAUT theory: performance
expectation, effort expectation, social impact, and promotion conditions, five charac-
teristic variables of blockchain technology expected as leading factors of performance
expectation and effort expectation were additionally applied to the model. Perfor-
mance expectations were viewed similarly to the perceived usefulness and effort
expectations of the technology acceptance model, and how the security, availability,
reliability, diversity, and economy of the blockchain influenced acceptance through
performance expectations and effort expectations. Also, the hypothesis shown in
Table 1 was derived through the composition of the research model.
Fig. 1 Research model
3.2 Operational Definition of Variables
Operational definitions of independent variables, parameters, and dependent vari-

ables included in the research model and research hypothesis were defined and
summarized.
Security is the degree to which non-profit organizations using blockchain believe
that the system is safe due to intrusion and attack such as external hacking or
ransomware, and that there is no possibility of forgery or tampering with data [9–13].
Availability and stability is the degree to which a non-profit organization’s oper-
ating system is always available and stable to perform functions because technologies
using blockchain are distributed (shared) structures [9, 10, 14–16].
Reliability and transparency are the degree to which data is accurately and trans-
parently processed in the system of non-profit organizations that use blockchain to
maintain integrity without errors in data [9, 10, 13, 17–20].
Diversity and scalability are the degree to which the system using blockchain as a
non-profit organization can be used for various purposes (such as security documents)
and in various fields (such as fundraising) [9, 15, 21, 22].
Economic efficiency and effectiveness are expected to be economically effective
by reducing system construction and maintenance costs by introducing technology
using blockchain [9, 15, 21, 22].
126 M. Lee et al.
Table 1 Research hypothesis

H1-1 The security of blockchain technology utilization will have a positive (+) effect on
performance expectations
H1-2 The security of blockchain technology utilization will have a positive (+) effect on
expectations of effort
H2-1 The availability of blockchain technology utilization will have a positive (+) effect on
H2-2 The availability of blockchain technology utilization will have a positive (+) effect on
H3-1 The reliability of blockchain technology utilization will have a positive (+) effect on
H3-2 The reliability of blockchain technology utilization will have a positive (+) effect on
H4-1 The diversity of blockchain technology utilization will have a positive (+) effect on
H4-2 The diversity of blockchain technology utilization will have a positive (+) effect on
H5-1 The economic feasibility of using blockchain technology will have a positive (+) effect
on performance expectations
H5-2 The economic feasibility of using blockchain technology will have a positive (+) effect
on expectations of effort
H6 Performance expectations will have a positive (+) effect on the acceptance of blockchain
technology
H7 Expectations of effort will have a positive (+) effect on the acceptance of blockchain
technology
H8 The social impact will have a positive (+) effect on the acceptance of blockchain
technology
H9 The promotion conditions will have a positive (+) effect on the acceptance of blockchain
technology
H10 Organizational innovation will regulate the relationship between blockchain technology
acceptance
3.3 UTAUT Independent, Dependent Variables
Performance expectations are the degree to which it is expected to help improve work
performance and the company grow by using blockchain technology. Expectation
of effort is the extent to which blockchain technology is believed to be easy to use
for non-profit organizations (NGOs). In addition, the social impact is the degree to
which our organization or organization thinks that blockchain technology should be
utilized and used in the overall environment of society. Facilitation conditions are
organized to the extent of belief in the existence of an organization or a technical
foundation that can support the use or use of blockchain technology in a non-profit
organization [8, 9, 23–29].
Finally, acceptance of dependent variables indicates the degree to which

blockchain technology is intended to be used or introduced by non-profit organi-
zations [8, 9, 30].
4 Empirical Data Analysis
4.1 Data Collection
This study developed research models based on previous studies to understand the
intention of non-profit organizations (NGOs) to accept the technology of blockchain,
established research hypotheses, and conducted empirical analysis to verify each
hypothesis.
In order to collect data necessary for analysis, a questionnaire was prepared to
measure the variables of the research model. Next, an online survey was conducted
on this. Currently, blockchain technology is in the early stages of introduction to non-
profit organizations (NGOs) or there is a lack of commercialized services, so a survey
was conducted on several non-profit organizations (NGOs) workers in anticipation
of potential users and recipients. The survey period was conducted for 8 days from
November 12, 2018 to November 20, 2018, and a total of 161 survey responses were
collected. Among the data collected online, 155 cases of data were used for final
analysis, excluding 6 copies that were missing or responded faithfully.
Demographic characteristics were identified through frequency analysis, relia-
bility and validity analysis were conducted on measurement variables, and SmartPLS
3.0 were used for statistical data analysis. First, PLS Algorithm was performed
to evaluate the measurement model. Next, Bootstrapping and Blindfolding were
performed to evaluate the structural model, hypothesis verification, and mediating
effect verification.
4.2 Reflective Measurement Model Fit
This study attempted to understand the causal relationship by applying the Smart
PLS structural equation model to check the significant path coefficient between
each variable presented in the research model. In addition, the appropriate model
composition and the concentrated validity and discrimination validity of each item
were confirmed.
128 M. Lee et al.
4.2.1 Intensive Validity
As for the outer loading value, all measurement variables were higher than the refer-
ence value of 0.70 and the Average Variance Extracted (AVE) also exceeded the
reference value of 0.5, so it can be seen that the concentration validity is secured
(Table 2).
4.2.2 Reliability Verification of Measurement Model
According to the evaluation results, all of the values of kronbaha alpha were 0.60
or more, and rho_A(ρA) was higher than the threshold value of 0.70 or higher.
All values of Composite Reliability (CR) were found to be 0.60 or more. There-
fore, it seems that all the variables in the study have internal consistency reliability
(Table 3).
4.2.3 Determination Feasibility Evaluation Results
Finally, discrimination validity should be verified to measure the degree to which

variables and variables can be well distinguished. In order to evaluate discrimi-
nation validity, the HTMT criteria with the highest validity among Fornell-Larker
criteria, cross loading, and HTMT (heterotrite-monotrite ratio) methods are shown in
Table 4.
4.3 Structural Model Evaluation and Hypothesis Verification
The effect of the characteristics of the blockchain (availability, economy, diversity,

security, reliability) on effort expectations, performance expectations, and social
effects and promotion conditions was verified. In addition, the influence of parameters
(efforts expectations, social effects, performance expectations, and conditions for
promotion) on the acceptance of non-profit organizations’ blockchain technology
was verified. Table 5 shows the result of basic hypothesis verification.
This means that trustworthiness affects expectations of effort and performance,
and diversity affects expectations of performance. Also, economic feasibility affects
expectations of effort and performance, and performance expectations, social influ-
ences, and conditions for promotion affect the intention of non-profit organizations
(NGOs) to accept blockchain.
Table 2 Intensive validity result

Variable Measurement Outer loading Indicator reliability AVE
item
Availability Availability 1 0.877 0.769 0.8
Availability 2 0.915 0.837
Economic Economic 0.942 0.887 0.909
efficiency efficiency 1
Economic 0.964 0.929
efficiency 2
Economic 0.96 0.922
efficiency 3
efficiency 4
efficiency 5
Effort Effort expectancy 0.893 0.797 0.845
expectancy 1
Effort expectancy 0.941 0.885
2
3
4
5
Variety Variety 1 0.911 0.830 0.813
Variety 2 0.945 0.893
Variety 3 0.89 0.792
Variety 4 0.861 0.741
Variety 5 0.898 0.806
Security Security 1 0.955 0.912 0.909
Security 2 0.974 0.949
Security 3 0.958 0.918
Security 4 0.944 0.891
Security 5 0.937 0.878
Social influence Social influence 1 0.941 0.885 0.895
Social influence 2 0.938 0.880
(continued)
130 M. Lee et al.
Table 2 (continued)
Variable Measurement Outer loading Indicator reliability AVE
item
Performance Performance 0.927 0.859
expectancy expectancy 1
Table 3 Measurement model

Factors Cronbach’s rho_A Composite
reliability analysis results
Alpha Reliability
Availability 0.938 0.947 0.952
Economic 0.975 0.975 0.98
efficiency
Effort 0.954 0.954 0.956
expectancy
Variety 0.942 0.943 0.956
Security 0.975 0.976 0.98
Social influence 0.971 0.971 0.977
Performance 0.961 0.962 0.970
expectancy
Acceptance 0.967 0.967 0.974
intention
Reliability 0.929 0.930 0.955
Facilitating 0.908 0.918 0.931
condition
Table 4 Evaluation results of discriminant validity based on HTMT criteria

1 2 3 4 5 6 7 8 9 10
1
2 0.667
3 0.604 0.732
4 0.47 0.438 0.37
5 0.769 0.476 0.546 0.513
6 0.572 0.635 0.656 0.507 0.545
7 0.578 0.658 0.654 0.682 0.538 0.748
8 0.558 0.52 0.615 0.623 0.661 0.791 0.769
9 0.87 0.621 0.689 0.599 0.848 0.661 0.714 0.745
10 0.413 0.505 0.682 0.296 0.46 0.704 0.504 0.716 0.554
1 = Availability, 2 = Economic efficiency, 3 = Effort Expectancy, 4 = Variety, 5 = Security, 6 =
Social Influence, 7 = Performance Expectancy, 8 = Acceptance intention, 9 = Reliability, 10 =
Facilitating Condition
Table 5 Results of hypothesis testing

Original sample (O) P values Adoption
Security → Performance expectations −0.064 0.623 Dismiss
Security → Expectation of efforts 0.069 0.515 Dismiss
Availability → Performance expectations −0.125 0.253 Dismiss
Availability → Expectation of effort −0.124 0.257 Dismiss
Reliability → Performance expectations 0.424 0.003 Selection
Reliability → Expectation of effort 0.425 0.002 Selection
Diversity → Performance expectations 0.352 0 Selection
Diversity → Expectation of effort −0.094 0.139 Dismiss
Economical economy → Performance expectations 0.349 0 Selection
Economical → Expectation of effort 0.543 0 Selection
Performance expectations → Acceptance intention 0.416 0 Selection
Effort expectations → Acceptance intention −0.061 0.368 Dismiss
Social impact → Acceptance intention 0.283 0.022 Selection
Facilitation conditions → Acceptance intention 0.333 0 Selection
5 Conclusions
This study conducted an empirical study on the acceptance of blockchain technology

by non-profit organizations (NGOs). Through previous studies, the characteristics
of blockchain technology were investigated, and an analysis was conducted on how
the mediating effect was applied to acceptance as a variable that had a mediating
effect. Through various technology acceptance models, the model of UTAUT’s study
suitable for this study was found and designed. Research on the acceptance of new
technology called blockchain in non-profit organizations (NGOs) has a meaning
and importance of research that it has been a new attempt at blockchain acceptance
intention to companies and public institutions.
Data were collected and empirically analyzed to verify each hypothesis between
research models, and the following results could be derived based on the verification
results.
First, among the independent variables of the characteristics of the blockchain,
the hypothesis that security and availability affect performance expectations or effort
expectations was rejected. It was interpreted that the blockchain is still considered
to be just a cryptocurrency, Bitcoin, and lacks confidence that it is safe and safe
against the risk of hacking. Also, most non-profit organizations (NGOs) workers
who are familiar with the system of viewing, storing, and processing sponsors’ data
with servers in the center lack confidence in blockchain that allows stable use of P2P
methods.
Second, among the characteristics of the blockchain, security and availability
were rejected, but it was derived that reliability and economy influenced performance
132 M. Lee et al.
expectations and effort expectations, and acceptance intention influenced the perfor-
mance expectations. Unlike security, reliability was judged to have the belief that the
trust in the information that would be contained within the block was accurate and that
it would be stored safely without errors. Also, it was interpreted that the IT expendi-
ture cost, which is the most controversial in non-profit organizations, and the existing
high-priced IT construction cost can reduce maintenance costs along with system
operation with low cost. In addition, diversity, a characteristic of blockchain, affects
performance expectations, but the hypothesis of effort expectations was rejected.
Third, along with performance expectations and social influences, the hypothesis
that facilitation conditions affect acceptance intention was adopted. However, the
hypothesis that the expectation of parameter effort affects acceptance was rejected.
Expectations for blockchain performance in the future, an opportunity for organiza-
tions to do new business and grow in the currently saturated domestic fundraising
market, and arguments that blockchain should be introduced and done around them
were interpreted as influencing acceptance intention. The judgment that blockchain
technology can be educated or helped was also interpreted as having an effect on
acceptance intention. This interpretation aligns with the results of many previous
studies.
Finally, when blockchain technology is activated and applied to all fields, research
that affects before acceptance and research on how much difference there is after
acceptance are required, as in this study. In addition, by comparing the differences in
how effective the variables adopted were, research will be able to contribute on finding
its impact on the new technologies of future NGOs. Also, it will be a meaningful
study to conduct a wide range of empirical studies targeting individuals, not groups
or organizations.
References
1. Statistics Korea: The results of the 2021 Social Survey ‘(Welfare, Social Participation, Leisure,
Income and Consumption, Labor)’, 2021, Access:2022/04/23, URL: https://kostat.go.kr/por
tal/korea/kor_nw/1/1/index.board?bmode=read&aSeq=415115
2. Chosun Ilbo, The Better Future: “Public opinion of the better future distrusts fundraising
organizations, and donors trust fundraising organizations.“, 2021, Access: 2022/04/23, URL:
https://futurechosun.com/archives/59549
3. Nakamoto, S.: Bitcoin: A Peer-to-Peer Electronic Cash System. 2008, Access: 2022/04/23,
URL: https://bitcoin.org/bitcoin.pdf
4. Tech Trends 2022: Engineer your tech-forward future. 2021, Access: 2022/04/23, https://
www2.deloitte.com/content/dam/insights/articles/US164706_Tech-trends-2022/DI_Tech-tre
nds-2022.pdf
5. Kim, D.H.: A Study of Factors Affecting the Adoption of Cloud Computing. The Journal of
Society for e-Business Studies 17(1), 111–136 (2012)
6. Jeong, C.Y.: A Study of Factors Affecting Intention to Accept the Personal Information
Protection Accreditation in Medical Centers. Doctoral Thesis. Soongsil University (2015)
7. Westland, C., Clark, T.: Global Electronic Commerce: Theory & Case Studies. Massachusetts
Institute of Technology, London (2000)
8. Venkatesh, V., Morris, M.G., Davis, G.B., Davis, F.D.: User acceptance of in-formation
technology: Toward a unified view. MIS Q. 27(3), 425–478 (2003)
9. Kim, J.S.: A Study on Factors Affecting the Intention to Accept Blockchain Technology, Master
Thesis. Soongsil University (2017)
10. Kim, J.H., Jung, M.H., Kim, J.M. and YOO, Y.S.:: Block Chain Prime, KOBIT CO., LTD
(2016)
11. Moon, J.H.: A Study on the Improvement of Coupon Services in the Block Chain Based: Master
Thesis. Dongkuk University (2017)
12. Song, S.H.: Transforming the Blockchain in the Age of Hyper-Connection. CLO 7(82), 40–43
(2017)
13. Shrier, D., W. Wu, and A. Pentland.: Blockchain & Infrastructure (Identity, Data Security).
MIT Connection Science. Part 3 (2016)
14. Lorenz, JT., Münstermann, B., Higginson, M., Olesen, PB., Bohlken, N., and Ric-ciardi, V.:
Blockchain in insurance – opportunity or threat?. McKinsey & Company. (2016)
15. Go, Y.S., And Choi, H,S.: Changing Business Paradigm and Its Application - Focused on the
Block Chain Technology. The Korean Society of Science & Art, 27, 13–29 (2017)
16. Kim, S.Y., Ahn, S.B.: A Study on Identifying Affecting Factors to Accept Blockchain System
-Focused on Logistics Industry-. Korea Logistics Research Association 28(1), 71–85 (2018)
17. Tung, F.C., Chang, S.C., Chou, C.M.: An extension of trust and TAM model with IDT in the
adoption of the electronic logistics information system in HIS in the medical industry. Int. J.
Med. Informatics 77(5), 324–335 (2008)
18. Vatanasombut, B., Igbaria, M., Stylianou, A.C., Rodgers, W.: Information sys-tems continuance
intention of web-based applications customers: The case of online banking". Information &
Management 45, 419–428 (2008)
19. Hong, S.P. H. In, K.H. Kim, K.J. Kim, S.M. Park, Y.J. Jung, H.J. Kang, J.E. Lee, S.J. Shim, and
D.H. Hong,: “Study on the Plan for the Introduction of the Blockchain Technology in Financial
Section”, Financial Services Commission, (2016)
20. Seo, K.K.: Factor Analysis of the Cloud Service Adoption Intension of Korean Firms : Applying
the TAM and VAM. Journal of Digital Convergence. 11(12), 155–160 (2013)
21. Jovanovic, B., Rousseau, P.L.: General purpose technologies. Handbook of Economic Growth.
1, 1181–1224 (2005)
22. Chung, S.H.: Legal Issues for the Introduction of Distributed Ledger Based on Blockchain
Technology-Focused On the Financial Industry-. Korea Financial Law Association 13(2), 107–
138 (2016)
23. Suh, B.S.: A Study on the Factors Affecting the Intention to Adapt PMO in Public Sectors.
Doctoral Thesis. Soongsil University (2013)
24. Jeon, S.H., Park, N.R., Lee, C.C.: Study on the Factors Affecting the Intention to Adopt Public
Cloud Computing Service. Entrue Journal of Information Technology. 10(2), 97–112 (2011)
25. Kim, Y.G.: The Effect of Perceived Risk and Trust on Users’ Acceptance of Cloud Computing
:Mobile Cloud Computing. Doctoral Thesis. Inchon University (2011)
26. Tai, Y.M., Ku, Y.C.: Will stock investors use mobile stock trading? A benefit-risk assessment
based on a modified UTAUT model". Journal of Electronic Com-merce Research 14(1), 67–84
(2011)
27. Chang, MK., Cheung, W., Cheng CH., and Yeung, Jeff HY.: Understanding ERP system
adoption from the user’s perspective”. International Journal of Production Economics. 113(2),
928–942 (2008)
28. Yoon, K.: The Factors Affecting the Intention to Use Cloud Computing Services: Focusing on
the Financial Industry. Doctoral Thesis. DanKooK University (2015)
29. Gonzalez, G.C., Sharma, P.N., Galletta, D.: Factors influencing the planned adoption of
continuous monitoring technology. J. Inf. Syst. 26(2), 53–69 (2012)
30. Lee, J.W., Kim, E.H.: Impacts of small and medium enterprises’ recognition of social media on
their behavioral intention and use behavior. Journal of Information Technology Service 14(1),
195–215 (2015)
Confidential Documents Sharing Model
Based on Blockchain Environment
Sung-Hwa Han
Abstract The blockchain platform has the advantage of providing shared informa-
tion integrity assurance, data loss recovery, and configuration history tracing func-
tions by applying cryptographic technology. This blockchain platform is used as
a base technique for sharing information among users. However, when important
information is shared through the blockchain platform, there is a disadvantage that
other users can access the shared information. In the information service using the
blockchain platform, it may be necessary to share defined users. Limited user’s access
to sharing information is allowed, but unauthorized user’s access may have to be
denied. To satisfy this requirement, this study proposes a model that can share confi-
dential documents in a blockchain environment. The proposed confidential document
sharing model operates on the blockchain platform and has the advantage of not using
a key management server. If the proposed model is applied to the enterprise envi-
ronment, it has the advantage of sharing confidential information while keeping all
the advantages provided by the blockchain environment. However, since this study
focused on the method on confidential file sharing, the sharing performance is inferior
to other techniques, so additional research is needed.
Keywords Confidential document sharing · Blockchain platform · Distribute

database · Privilege management · Limited users
1 Introduction
In an enterprise environment, various information is processed. The organization also

generates information open to external and information shared by internal users. Of
course they generate and use confidential information. Information is a concept and
has no form. Information has a logical form only when it is saved to a database or
file. The user accesses this stored information and uses the information.
S.-H. Han (B)

Depatment of Information Security, Tongmyong University Busan, Busan, South Korea
e-mail: shhan@tu.ac.kr
https://doi.org/10.1007/978-3-031-19604-1_10
136 S.-H. Han
Many organizations use encrypted documentation to share confidential informa-

tion among internal users. A confidential document uses an encryption key to encrypt
the document, and users who can access the document share the encryption key. Then,
the user who possesses the encryption key can access the confidential document.
Conversely, an unauthorized user who has not obtained an encryption key cannot
access confidential documents. This is because the decryption point is when the user
opens the document using the application. When the document is decrypted, the user
can get the information saved in the document [1].
This document encryption function is suitable for denying unauthorized users
access to confidential information saved in the document. This function can protect
the confidentiality of enterprise information. However, in an enterprise environment,
confidentiality is not the only requirement. Depending on the purpose and feature of
information, other attributes such as integrity, availability, fault tolerance, and trace-
ability may be required. In particular, integrity and availability of public information
are emphasized [2].
The document encryption function can satisfy confidentiality, availability, and
traceability, but not integrity and fault tolerance. If an authorized user has a malicious
purpose, they can delete this confidential document or modify important informa-
tion into other information. This is because ownership of confidential documents is
assigned to authorized users. If an authorized user deletes a confidential document,
the document’s availability is compromised. Also, if the authorized user arbitrarily
modifies the confidential document, the user who uses the modified information may
get an unintended result, which may cause a problem that the enterprise goal cannot
be met.
This study proposes a confidential documents sharing model based on blockchain
platform as a method to protect information emphasizing such integrity and avail-
ability. The model proposed in this study guarantees confidentiality, integrity, and
availability by applying the encryption function to confidential documents, and
can identify and authenticate users accessing confidential documents through the
encryption key management function. In addition, since confidential documents are
managed on the blockchain platform, the integrity of confidential documents can be
guaranteed. By sharing the user access log when necessary, it is possible to trace
users who access confidential documents.
The confidential documents sharing model based on blockchain platform proposed
in this study is a conceptual model. Therefore, this study includes considerations
when implementing the proposed model empirically.
This study is organized as follows. Section 1 describes the background, purpose,
and effect of this study. Section 2 identifies the method of processing confidential
information in the enterprise environment and the security threat that occurs here, and
introduces the blockchain platform. Section 3 introduces the confidential documents
sharing model based on blockchain platform, which is the goal of this study, and
explains considerations when implementing it empirically. Section 4 summarizes
this study.
Confidential Documents Sharing Model Based on Blockchain Environment 137
2 Related Work
2.1 Enterprise Environment for Confidential Information

Process
In an enterprise environment, a lot of information is processed. Among them, confi-

dential information is protected and monitored from the time of information creation.
Confidential information is created only by the use of limited applications in the
system and limited network designated by the limited user. The information created
in this way is saved in the designated storage in a fixed way. Confidential information
is saved in various ways depending on storage, but databases or files are mainly used
[3, 4].
When the confidential information save type is file, EDRM (Enterprise Digital
Right Management) system is used. The structure of EDRM is shown in Fig. 1.
Confidential documents are managed by the EDRM Controller. The EDRM
Controller manages encryption keys and privileges, and saves confidential docu-
ments. The author encrypts the confidential document using a crypto tool terminal.
After that, the author defines the user who can access the confidential document using
the terminal, and then saves it in Rights. Rights are a list of confidential documents that
each user can access. The recipient can only access documents registered in Rights.
When a recipient accesses a confidential document, authentication is enforced by
the EDRM controller. Then, the EDRM Controller checks the rights to see if the
recipient can make a confidential document. If recipient privilege is registered, the
Fig. 1 Confidential
information protect
mechanism by DRM
138 S.-H. Han
EDRM Controller decrypts the confidential document using the decryption key of
the confidential document that the recipient wants to access. The recipient will then
be able to access the decrypted confidential document [5].
2.2 Security Threats About Confidential Document Sharing
An encrypted confidential document has the advantage of ensuring its confidentiality

by accessing only limited users. However, information used in the enterprise is not
always required to be confidential. Table. 1 is a representative information security
requirement required in an enterprise environment [6–8].
This security requirement may require other security attributes depending on the
purpose of the information and the user.
Since public information is a matter to be known to many people, confidentiality
is not usually required [9]. This information was created for the purpose of being
shared with other users for the public benefit. Since this information is used by
everyone, everyone should share the same information. If some users or user groups
use information different from other users or user groups, the stakeholder related to
the user or user group may suffer damage. Therefore, since this information should
not be arbitrarily changed, integrity is required [10].
In addition, users should be able to access this information using methods that are
accessible at any point in time. As shown Fig. 2, when a user who needs information
cannot use the information because he cannot access it, that user suffers damage.
Therefore, since the user should always be able to access this information at a desired
time, availability is required [6].
EDRM is a system for sharing confidential documents between internal users. If
EDRM provides service all the time, availability is guaranteed. In addition, if EDRM
correctly provides user authentication and encryption functions, confidentiality is
also guaranteed [11]. However, integrity cannot be guaranteed.
When an internal user has access to a confidential document and has the privilege to
modify the document, the user can edit the confidential document. If an internal user
has a malicious purpose, other internal users may be damaged by the information the
Table 1 Iinformation security requirement required in an enterprise environment

Requirement Description
Confidentiality • When an unauthorized user gets the information value, the owner may suffer
damage
• It is necessary to protect the value of information
Integrity • When an unauthorized user modifies or deletes information value, the user
may suffer damage due to wrong information use
• It is necessary to keep the configuration of information
Availability • Information is used when the user needs it
• It is necessary to maintain information status and access channels
Fig. 2 Availability about confidential document
user has arbitrarily modified. This modified confidential information can be traced by
the EDRM controller, but there is a problem that it cannot be restored to its previous
status.
2.3 Blockchain Platform
Blockchain is a platform that can share transaction ledgers in a distributed database

proposed by Satoshi Nakamoto in 2008. It is a predefined platform to implement the
proposed cryptocurrency to improve the problems of electronic money [12].
This blockchain platform can theoretically share all data by nodes in the
blockchain network. The shared data verifies whether the author generated it at the
time of sharing. The verified data is saved in a chain method by applying the hash
algorithm, and as shown in Fig. 3, it is hashed including the entire previously saved
data [13].
Fig. 3 Blockchain chain structure

140 S.-H. Han
Due to this save mechanism, it is difficult to modify the chain saved in the
blockchain node. Since each blockchain node performs chain verification every time
it accesses the blockchain platform, even if the chain stored in one node is tampered
with, the altered chain has the advantage of being restored immediately [14].
The blockchain platform selected ledger data as sharing data. This ledger is usually
text, but if you use a DApp, you can share various files such as images, audio, and
video [15].
3 Confidential Document Sharing Model Based

on Blockchain Platform
3.1 Security Environment Analysis and Requirements
In an enterprise environment, confidential documents may be shared among limited

users, but the shared confidential documents may not be modified. A global company
or an international organization shares a lot of confidential information. Also, since
the time difference is applied due to different regions, the information shared for
a certain period should not be changed. Not only that, even if it is modified, it
should be possible to immediately restore the existing confidential document. Finally,
Confidentiality, Integrity, and Availability must all be satisfied.
Although these enterprise security requirements are emphasized, EDRM, which is
used by many organizations, has a problem that cannot satisfy all three requirements.
EDRM can satisfy Confidentiality and Availability, and additionally, traceability.
However, EDRM cannot satisfy integrity or recoverability by itself. However, all
these security functions are required in an enterprise environment.
3.2 Confidential Document Sharing Model Based

on Blockchain Platform
In this study, we propose a confidential document sharing model based on blockchain

platform that can satisfy all of the confidentiality, integrity, and availability required
in an enterprise environment.
As shown in Fig. 4, the proposed model consists of a blockchain platform, an
EDRM DApp with an EDRM role, and a user terminal.
EDRM DApp is in charge of Authenticator, Privilege Manager, and Key Manager
functions. The authenticator authenticates whether the blockchain node is a user who
can access confidential documents. Even if it is a blockchain node, users of nodes
who cannot access confidential documents are blocked from accessing them. The
Privilege Manager manages the user’s access authority. The Key Manager manages
the encryption key required to decrypt confidential documents.
Fig. 4 Confidential document sharing model based on blockchain platform
User Terminal provides two functions. The first function is a privilege define. The
document creator uses the User Terminal to define users who can access confidential
documents, and configures privileges for each user. The second function is the user
interface of EDRM service. By using this user terminal, user login or access decrypted
confidential document.
The confidential document sharing model based on blockchain platform proposed
in this study is the way EDRM function operates on the blockchain platform. There-
fore, all events that occur in EDRM are shared by all blockchain nodes using
blockchain transactions. In addition, the saved EDRM event is saved in a chain
method, so it is safe from modification attack on the external side. If a previous
version of a confidential document is needed, the previous version stored in the
chain can be accessed immediately.
4 Implement
4.1 Verification Environment and Items
The confidential document sharing model proposed in this study should correctly
provide the targeted security function and should not interfere with the execution
of other application processes. Therefore, after empirical implementation of the
confidential document sharing model proposed in this study, verify its function.
142 S.-H. Han
Table 2 Function verify items

Verify ID Description
Func_01 • Verify that the distribute confidential document with other blockchain nodes
• If the confidential document shareing function is provide correctly, each
blockchain nodes can share other information
Func_02 • Blockchain nodes can verify received confidential document
• For this function, each blockchain node should be join to blockchain network
Func_03 • Check that the verified confidential document are save as blockchain in each
blokchain
• If it is saved correctly, user can review that confidential document
The hardware environment of the linux system to verify the function of the
confidential document sharing model proposed in this study was implemented in
an i5-8500 CPU, 8Gbyte memory, and 256Gbyte SSD environment for blockchain
node.
For the software environment, Redhat Enterprise Linux 8.4 was chosen for both
systems. For the blockchain nodes, SSH2 and Telnet service were chosen.
The confidential document sharing model proposed in this study provides a secu-
rity function that can distribute confidential documents and verify, store. Therefore,
the functions verify items of the system proposed in this study are defined as shown
in Table 2.
In order to implement the confidential document sharing model based on
blockchain platform proposed in this study, it is necessary to structurally link the
blockchain platform and EDRM. Although legacy EDRM has a CS structure, the
confidential document sharing model based on blockchain platform proposed in this
study has a distribute database type, so the operation environment is also different.
Therefore, various matters should be considered when implementing.
4.2 Verification Process
First, a detailed analysis of the business process including the creation and distribution
of confidential documents and user access is required. In a business environment, the
usage of confidential documents does not occur only internally. Also, since access
is not always online, various business environments must be considered.
Confidential documents of the confidential document sharing model based on
blockchain platform are shared by all blockchain nodes. When the shared confidential
document is saved as an application file, there is a possibility of accessing confidential
information from outside the blockchain platform. Therefore, the shared confidential
document should be stored in an isolated area such as a sandbox.
Key management for decrypting confident documents should also define various
use cases and then define the key management process. If the key for decrypting
the confidential document is exported externally, you can use this key to decrypt the
confidential document at another point in time. In addition, since the confidential

document decryption key is also shared by all blockchain nodes, key storage must
also be stored in an isolated area.
Documents used in an enterprise environment often contain various images. So the
document size is large. Therefore, to implement the confidential document sharing
model based on blockchain platform proposed in this study, it is necessary to check
the storage capacity of the user device.
5 Conclusion
In an enterprise environment, there are various business processes, and these

processes change frequently. The use of confidential documents in such an envi-
ronment is a basic condition to prepare for business opportunity while building a
safe environment. However, EDRM that provides this confidential document service
can guarantee Confidentiality and Availability, but has a problem in not guaranteeing
integrity.
In this study, in order to solve this problem, a confidential document sharing
model based on blockchain platform was proposed and the role of each component
was defined. Also, we checked the considerations to be applied when implementing
the model proposed in this study.
The blockchain platform is used in various fields, and its expansion potential is
very high. In particular, it shows the greatest effect in public service. We will study
other application service models that can apply the many advantages provided by
the blockchain platform to the business environment. Since this study focused on
the method on confidential file sharing, the sharing performance is inferior to other
techniques, so additional research is needed.
References
1. Krishnan, S., Neyaz, A., Shashidhar, N.: A survey of security and forensic features in popular
eDiscovery software suites. Int. J. Secur. (IJS) 10(2), 16 (2019)
2. Popescu, A., Lammich, P., Hou, P.: CoCon: A conference management system with formally
verified document confidentiality. J. Autom. Reason. 65(2), 321–356 (2021)
3. Westmacott, P., Obhi, H.: The database right: Copyright and confidential information. J.
Database Mark. Cust. Strategy Manag. 9(1), 75–78 (2001)
4. Sevak, B.: Security against side channel attack in cloud computing. Int. J. Eng. Adv. Technol.
(IJEAT) 2(2), 183–186 (2012)
5. Van Beek, M. H.: Comparison of enterprise digital rights management systems. Advice Rep.,
Aia Software 33 (2007)
6. Khidzir, N. Z., Mat Daud, K. A., Ismail, A. R., Ghani, A., Affendi, M. S., Ibrahim, M., Hery,
A.: Information security requirement: The relationship between cybersecurity risk confiden-
tiality, integrity and availability in digital social media. In Regional Conference on Science,
Technology and Social Sciences (RCSTSS 2016), Springer, Singapore, pp 229–237 (2018)
144 S.-H. Han
7. Alkhudhayr, F., Alfarraj, S., Aljameeli, B. and Elkhdiri, S.: Information security: A review of
information security issues and techniques. In 2019 2nd International Conference on Computer
Applications & Information Security (ICCAIS), IEEE, pp. 1–6 (2019)
8. Von Solms, R., Van Niekerk, J.: From information security to cyber security. Comput. Secur.
38, 97–102 (2013)
9. Qiu, H., Qiu, M., Liu, M., Ming, Z.: Lightweight selective encryption for social data protection
based on ebcot coding. IEEE Trans. Comput. Soc. Syst. 7(1), 205–214 (2019)
10. Yuan, Y., Zhang, J., Xu, W. and Li, Z.: Identity-based public data integrity verification scheme
in cloud storage system via blockchain. J. Supercomput., 1–22 (2022)
11. Joshi, K.P., Elluri, L., Nagar, A.: An integrated knowledge graph to automate cloud data
compliance. IEEE Access 8, 148541–148555 (2020)
12. Leeming, G., Cunningham, J., Ainsworth, J.: A ledger of me: personalizing healthcare using
blockchain technology. Front. Med. 6, 171 (2019)
13. Raikwar, M., Gligoroski, D., Kralevska, K.: SoK of used cryptography in blockchain. IEEE
Access 7, 148550–148575 (2019)
14. Dragomir, V. D. and Dumitru, M.: Practical solutions for circular business models in the fashion
industry. Clean. Logist. Supply Chain., 100040 (2022)
15. Khatal, S., Rane, J., Patel, D., Patel, P. and Busnel, Y.: Fileshare: A blockchain and ipfs frame-
work for secure file sharing and data provenance. In Advances in Machine Learning and
Computational Intelligence, Springer, Singapore, pp. 825–833 (2021)
Distance Based Clustering in Wireless
Sensor Network
Joong Ho Lee
Abstract Wireless sensor networks (WSNs) with large sensor nodes are deployed
under battery constraints. Low power operation for sensor could be achieved from
clustering algorithm in a field of WSNs. In a wireless sensor network, the oper-
ating lifetime of sensor nodes composed of cluster members should be maximized.
Therefore, this paper proposed a hierarchical clustering algorithm that can minimize
the power consumption of sensor nodes. Multi-hop routing and distance-based clus-
tering method have proposed to improve the lifetime of sensors in the network. This
article proposes a single unit distance based two-hop clustering method for clustering
and analyzes the energy persistence of sensor nodes in the formed clusters. Sensor
nodes clustering based on physical distances which method has many limitations
in recruiting cluster members due to the limitation of the distance between cluster
members and the transmission energy. The proposed cluster formation method can
efficiently manage operational energy by improving the non-uniformity of cluster
groups. And the simulation results of the proposed method are compared with the
existing method.
Keywords Wireless sensor networks (WSNs) · Sensors node · Multi-hop routing ·

Distance-based clustering
1 Introduction
Micro-Electro-Mechanical System (MEMS) sensors capable of low-power operation

in the field of sensor technology have been developed due to semiconductor tech-
nology capable of miniaturization. The sensor’s low-power technology has played
an innovative role in extending the lifespan of the sensors [1]. WSN’s sensors have
been developed to monitor a wide range of natural environments under limited power
conditions. Sensors deployed over large areas must ensure robust operation to reli-
ably transmit data collected in extreme natural environments [2]. Since sensors are
J. H. Lee (B)
Depatment of AI, Yongin University, Yongin-Si, South Korea
e-mail: joongho65@yongin.ac.kr
https://doi.org/10.1007/978-3-031-19604-1_11
146 J. H. Lee
deployed in a wide area, they collect data until the end of their lifespan, and it is
impossible to replace batteries to extend their lifespan [3, 4]. In order to minimize
power consumption in wireless sensor network technology, research on the group
formation algorithm of sensor nodes is continuously being conducted. Reducing
power consumption is a key factor in wireless sensor network technology [5]. As
for the existing clustering technology, research on the clustering technology based
on a uniform network environment has been achieved. In the real network environ-
ment, the distribution of sensor nodes may not be uniform due to the characteristics
of the natural environment [6]. When sensors form a cluster in a non-uniformly
distributed network, the density difference of sensor nodes occurs between cluster.
The Cluster head (CH) node based on the existing absolute hop-based clustering
method, collects data from member sensors node and transmits it to the destination,
but the non-uniformity of the sensor nodes causes a difference in energy consumption.
The CH node of a cluster with large number of sensor nodes consumes more energy
than a cluster with a relatively small number of sensor nodes, which shortens the life
of the cluster and consequently shortens the lifetime of the network [7]. When a CH
node reaches the end of its lifespan, it cannot receive data from member sensors nor
transmit it to its destination. Therefore, other sensor nodes among member nodes
must be replaced with new head nodes. The shorter the replacement cycle of the
cluster head node shortens the lifespan of the cluster and ultimately shortens the
lifespan of the entire network [8, 9]. We should also consider the lifetime of the
CH nodes in the cluster to extend the lifetime of the network. A method to increase
energy efficiency, such as the clustering hierarchy (LEACH) algorithm [10], was
applied to the WSN. It is a single-hop-based communication method using a single-
hop clustering scheme, in which the CH node communicates directly with the sink
node. However, this algorithm is less effective in saving energy for member nodes
located more than 1 hop away from the sink node.
Therefore, in this study present a method to improve the cluster size for a cluster
formed by non-uniformly deployed sensor nodes in WSN. In this paper, we present
a clustering algorithm based on the distance between sensor nodes to enable energy-
efficient clustering by forming a uniform cluster size. An algorithm for CH node
selection was also presented to improve the energy efficiency of the CH node. In
addition, the simulation result comparing the proposed algorithm with the existing
algorithm was shown.
2 Related Review
The CH node should collect data sent from the sensor nodes in the group. If a group
has n member nodes, the member node transmits data only once, but the CH node
receives the data n times. Therefore, CH nodes consume more energy than member
nodes. It is more energy efficient for a CH node to collect data from member node
and send it to its destination (sink node) rather than each member node transmit data
directly to the sink node [11]. The LEACH scheme was proposed as a way to reduce
Distance Based Clustering in Wireless Sensor Network 147
energy consumption by electing a CH node and sending data to the sink node [12].
In order to collect data from adjacent sensor nodes and transmit it to the sink node,
the LEACH scheme adopted a single-hop clustering method. LEACH periodically
elects a new CH node from member nodes before the lifetime of the CH node expires.
The selected CH node sends messages from members in the cluster to other nodes,
and also receives messages from other nodes and forwards them to other nodes.
2.1 Radio Channel Model
To apply the data transmitter/receiver model of the wireless sensor network, E device
= 50 nJ/bit was applied to model the transmitter/receiver devices with ∈ ∈amp 100
pJ/bit/m2 [12]. Figure 1 shows the radio model.
In order to transmit k-bit information up to distance d in the radio model, the radio
model is as follows:
E T x (k, d) = E T x−device (k) + E T x−amp (k, d)

(1)
E T x (k, d) = E device × k+ ∈amp ×k × d 2
To receive a k-bit message from the transmit node, the radio model expands as
follows [12]:
Fig. 1 Radio energy model between transmit and receive nodes

148 J. H. Lee
E Rx (k, d) = E Rx−device (k)

(2)
E Rx (k, d) = E device × k
Based on the radio model, the total energy consumption depends on the routing
method.
3 Cluster Formation
Clustering can form from adjacent sensor node which nodes located at adjacent
distances communicate with each other to form a cluster. To complete the cluster
configuration, it is necessary to select the cluster head (CH) and gate node (GW)
within the cluster group member nodes. When a cluster group is initially formed,
there are overlapping nodes between the groups, so group settings must be re-set so
that these nodes are registered in only one cluster group.
3.1 Distance Based Cluster Algorithm
The clustering algorithm presented in this paper is based on distance. Clustering was
based on the concept of forces that interact according to the distance between nodes.
The strength of the interaction force defined as f AB (from node A to B) according to
the distance is expressed as follows by defining the physically separated distance:
= 1/d1 --- case 1
In order to represent the mutual attraction force between nodes, the distance
between nodes is defined as 1 distance in d1 units. That is, the unit distance between
two nodes (A–B) is d1, and the interaction force is defined in inverse proportion to
the distance. Assuming three adjacent nodes, there are two types (Case 2–3) between
nodes that can be formed for a unit distance in the x-axis and y-axis directions:
When the number of adjacent nodes is expanded to 4, the form of nodes that can
be formed is the same as Case 4–7.
= 1/d1, = 1/d2 , = 1/d3
= 1/(d1+d2), = 1/√ + , = 1/√ +

--- case 4
= 1/(d2+d3), = 1/(d1+d2), = 1/(d1+d2+d3)

--- case 5
In the same way, by expanding the number of neighboring nodes, it is possible to

consider variously distributed neighboring nodes.
3.2 Node-to-Node Cohesion
In the previous section, a simplified model of mutual tension between nodes based on
distance was shown. To form a cluster group, cohesion between nodes is considered
as a model. For example, it shows that if a mutual force is applied between nodes
from the initial state of case 1, cohesion inter nodes occurs and can be changed to
the next state. Figures 2 and 3 shows the state of realignment of nodes considering
cohesion for each case. Figure 2 shows the configuration in which A and C gather
around node B. Figure 3 shows the cohesion form when B and D are located at right
angles with respect to node A and node C is adjacent to node B.
The process of cohesion considering the mutual influence between adjacent nodes
is an effective concept to form an appropriate cluster. Figure 4 shows the example of
the process of group formation for randomly deployed sensor nodes. The neighboring
150 J. H. Lee
Fig. 2 Rearrangement state

for the case 1 from initial
state
Fig. 3 Rearrangement state

for the case 6 from initial
state
nodes have diagrammed the process of gathering nodes located close to each other
which is unit 1 distance. In this paper, to simplify the distance between adjacent
sensor nodes, the unit distance is set to 1. The distance between the closest nodes is
set as the unit distance 1. That is, the distance between adjacent nodes horizontally
and vertically is 1, and the diagonally located nodes are also included in the unit
distance 1. Figure 4a shows an example of randomly distributed adjacent sensor
nodes, and Fig. 4b shows the results of aggregation into appropriate groups to form
a cluster. And Fig. 4c shows the results of cluster groups. For a node at coordinates
(4, 4), adjacent cells affect this node with similar strength, but eventually become
incorporated into a strongly pulling group. Consequently, three groups are formed
and located at coordinates (4, 4) node is registered as members of group B. In this
way, cluster can be formed by applying an interaction force between a node and its
neighbors.
Figure 5 shows an example in which about 1000 sensors are randomly distributed
in a 100 × 100 unit area and then a cluster is formed between adjacent nodes. Figure 5
shows simulation results of the proposed clustering algorithm. The cluster formation
consists of two steps. First, to form a cluster from randomly scattered sensor nodes,
each node searches for a node located at a distance of unit 1 (1d) between each node.
If they find unit 1 distance node, they communicate with each other and note
the id number of each node for node identification. Second, each node searches for
adjacent nodes that extend to unit 2 distance (2d). In this simulation, the distance
between nodes affected by reciprocal attraction is limited to 2d.
Fig. 4 Example of group formation
Fig. 5 Sensor node clustering simulation for a 100 × 100 Unit Area
152 J. H. Lee
3.3 Clustering
In order to form a cluster group between adjacent nodes in the distance-based model of
adjacent nodes as in the cases described previous, the following process is performed.
p1. Every node sends a broadcast message containing latitude and longitude
information to neighboring nodes.
p2. Each sensor node receives a broadcast message from the nearest node. The
received message contains latitude and longitude information. It registers first for
the earliest received message and calculates the distance.
p3. Sends a group member request message to the sensor node of the received
message.
p4. Receive acknowledgment message from node that requested group member by
p3.
p5. When node receive an acknowledgment message, node register as a member of
itself.
Group formation for all the sensor nodes is completed by performing the above
processes p1–p5.
3.4 Cluster Uniformation
Sensors are randomly deployed over a large area under hostile weather conditions.
Due to the random distribution, the sensors are not evenly distributed. So, some clus-
ters have a high density distribution and some clusters have a low density distribution.
The more sensors are located adjacent to each other, the higher the probability that
the size of the cluster will increase.
The sensor node communicates with the CH (Cluster Head) node to send data to
the CH node in the same cluster, and the CH node sends the collected data from the
member sensor node to the sink node. If the size of the cluster is large, the amount of
data to be collected from the member nodes in the cluster increases, and consequently,
the CH node consumes more batteries, and the lifespan is shortened. As the battery
consumption of the CH node becomes faster, the lifespan is shortened, and the CH
node election from member nodes in the cluster may become frequent. Accordingly,
the life span of all member nodes in the cluster can be shortened quickly. Therefore,
if the size of a cluster is larger than that of other clusters, the size of the cluster can
be made uniform by dividing the cluster. When the size of the cluster is reduced, the
amount of data to be collected by the CH node from the member nodes is reduced,
thereby reducing battery consumption. In the distance-based clustering process, the
process of dividing the cluster when the size of the cluster is large is shown in the
Fig. 6. Figure 6a shows an example of a group in which adjacent member nodes
are composed of unit distance 1. Group 1 composed of excessively dense members
Fig. 6 Group division for a group with a high density of members within the group
can be divided into 4 groups (Group 1–1 to Group 1–4) as shown in Fig. 6b. In
Fig. 6b, the interaction force according to the distance between each sensor in the
same group is expressed numerically. The sensor located at the coordinates (6, 3)
has four vertically and horizontally adjacent sensors and one diagonally adjacent
sensor, so the magnitude of the interaction force is calculated as 4.6. Unit distance 1
included horizontally and vertically adjacent sensors and diagonally adjacent sensors.
The horizontal and vertical interaction force was calculated as 1 and the diagonal
interaction force was calculated as 0.6.
Figure 7 shows an example of many groups form in which about 1000 sensors
are randomly distributed in a 100 × 100 unit area and then a cluster is formed
between adjacent nodes. Figure 7a shows simulation results of the un-uniformed
group. Figure 7b shows the results with the groups being properly uniformized. In
the simulation result, the black dot indicates the sensor node, the red dot indicates
the CH node which is elected from the member nodes within the same group, and
red solid lines indicate that each member node in the same group is connected to CH.
3.5 Cluster Head Election—Scheme of Finding Center

of Gravity Node
After cluster formation, each cluster group has to elect a CH node. Each node has
connected to the nodes among the members of the cluster group. From this connec-
tivity, the node having maximum connectivity among the members can be found.
This node is selected to be a CH node. The process of selecting the CH node from
the formed cluster is shown below.
p6. For all nodes within the group, each node calculate the interconnection strength
between the member nodes of the group.
154 J. H. Lee
Fig. 7 Simulation results for group division for a group with a high density of members within the
group
p7. Find the node corresponding to the center of gravity in the group. The node with
the greatest connection strength among member nodes corresponds to the center of
gravity in the group.
p8. The node with the weakest connection strength is removed first.
p9. Repeat p6 until there are no adjacent nodes.
p10. The last remaining node is elected as a CH node and broadcasts the CH node
to its members.
p11. All member nodes register the CH.
The selection of CH nodes is completed by repeating the process from p6 to p11.
Figure 8 shows the process of selecting a CH node from its members, assuming a
specific cluster. The process of excluding cluster members one by one in each step
is shown for a specific cluster group as shown inf the Fig. 8. Finally, the node at
coordinates (3, 4) is elected as the CH node.
3.6 Energy Consumption Modeling of CH Node
If the CH (Cluster Head) has a shorter lifetime than other member nodes during
the data collection and transfer operation after cluster group completion, the cluster
head must be re-elected among other member nodes in the cluster group. Initially,
assume that all of the node has an energy level 1 and the energy level is reduced
by 0.1 for data collection and transmission. The member node should only transmit
data to the cluster head node, and the cluster head should transmit the collected data
Fig. 8 Example of CH node election
from the sensor node to the base station. CH node consumes much more energy
than sensor node. Figure 9 shows the energy consumption results for each CH nodes
in the group. To predict the battery consumption of the CH node in the group, this
paper makes several assumptions. It is simply assumed that the CH node consumes
0.01 J/time step of energy when collecting data from each sensor node once. When
election a CH node, additional energy consumption is required because selection
signals must be received from all member nodes in the group. Initially, the lifetime
value of all nodes is set to 1, and at every time step, the CH node consumes the
energy required to collect data from all member nodes, so the amount of energy is
subtracted. Based on the energy consumed by each CH node for the group shown in
Fig. 9, the results are shown until the remaining battery power reaches 0. Group 1
consists of 26 sensor nodes, and it is assumed that the CH node consumes 0.26 J of
energy when collecting data from these sensor nodes at each time step. In conclusion,
the battery of the CH node was exhausted within 4 time steps of Group 1. In the case
of group 1–4, there were 5 member nodes and it was performed for 20 time steps.
5 times longer operation time than Group 1 is guaranteed. Figure 9 shows the result
of simply calculating the amount of battery consumed by the CH node when the CH
node receives data from the member node in the group for each time step.
156 J. H. Lee
Fig. 9 Lifespan of CH node in the group
3.7 Cluster Uniformity
Consisting of a uniform cluster is an essential in extending the network lifespan. The

overcrowding of the cluster group due to the uneven distribution of sensor nodes is
the cause of the cluster non-uniformity. In this study, it was possible to uniformize
the size of the clusters through the second clustering process from the first stage of
cluster formation. By reconfiguring the CH node for a group with a higher density
than the adjacent cluster group, group can be divided into two or more groups.
4 Simulation Results
The size of each group member node for each generated cluster group was confirmed
through simulation. Figure 10 shows the distribution of the size of the sensor nodes
configured in the created cluster group. This is the result when it is repeatedly created
3 times, and most of the member nodes of each cluster consist of 1 to 10.
Figure 11 shows that about 1000 nodes are created and the results of 100 iterations
results are accumulated. At this time, the node distribution area was set to 100 × 100
unit area. Comparing the results without cluster uniformity and after equalization, it
can be seen that there is an effect of improving the cluster size by about 20–30%.
Fig. 10 Simulation Results for Number of Groups with the Same Number of Members
5 Conclusion
This paper describes a clustering algorithm based on distance and shows the algo-
rithm of distance-based CH node election. And shows the simulation results of cluster
formation in Fig. 5. Proposed algorithm is based on the concept of reciprocal attrac-
tion between nodes. We started with the assumption that there is a pulling force
(reciprocal attraction) between nodes. Based on this assumption this paper presented
clustering and cluster head (CH) election algorithm. By finding the node corre-
sponding to the center of gravity of the group, it can be selected as a CH node. This
procedure is shown in the p6–p11. In the clustering stage, this paper proposed reset-
ting the CH node for overcrowded sensor nodes to improve the uniformity for the
ununiformed groups. Divide of the group for the overcrowded member can improve
the battery consumption of the CH node by solving the overcrowding of member
nodes in the group. Figure 5 shows the clustering simulation results for 1000 random
nodes. The proposed clustering method makes it possible to distribute members
evenly by applying distance between sensors. Figure 7 shows the simulation results
when there is an overcrowded groups and the overcrowded group is divided into
small groups. In conclusion, it was confirmed that the overcrowded group could
be improved by about 30%. As shown in Fig. 10, we obtained improved results
for the uniformity of the clusters. The degree of uniformity can be improved by
158 J. H. Lee
Fig. 11 Simulation Results for Cluster Groups Uniformity with the Same Number of Members
repeating the clustering step. In the case of ungrouped sensor, it reduced up to ~30%.
The proposed clustering algorithm is effective for clustering of WSNs because it is
simple to implement and is expected to be effective for low power implementation.
References
1. Md. Zair Hussain, M. P., Singh, R. K.: Singh Analysis of Lifetime of Wireless Sensor Network.
Int. J. Adv. Sci. Technol. 53, 117–126, (2013)
2. Hill Jason Hill, J., Szewczyk, R., Woo, A., Hollar, S., Culler, D., Pister, K.: System architec-
ture directions for networked sensors. In: Proc. Ninth Int’l Conf. Architectural Support for
Programming Languages and Operating Systems (ASPLOS ’00), pp. 93–104 (2000)
3. Mukhopadhyay, S., Panigrahi, D., Dey, S.: Model based error correction for wireless sensor
networks. Sens. Ad Hoc Commun. Netw. (2004)
4. Jianzhong, L., Hong, G.: Survey on sensor network research. J. Comput. Res. Dev. 45(1), 1–15
(2008)
5. Liu, C., Wu, K., Pei, J.: An energy-efficient data collection framework for wireless sensor
networks by exploiting spatiotemporal correlation. IEEE Trans. Parallel Distrib. Syst. 18, 1010–
1023 (2007)
6. Wong, S., Lim, J., Rao, S., Seah, W.: Multihop localization with density and path length
awareness in non-uniform wireless sensor networks. In: Proc. Of the International Symposium
on Parallel Architectures Algorithm, and Networks, vol. 4, pp. 2551–2555 (2005)
7. Kim, E., Kim, D., Park, J.: Min-distance hop count based multi-hop clustering in non-uniform
wireless sensor networks. Int. J. Contents 8(2), 13–18 (2012)
8. Heizelman, W., Chandrakasan, A., Balakrishnan, H.: An application-specific protocol archi-
tecture for wireless microsensor networks. IEEE Trans. Wireless Commun. 1(4), 660–670
(2002)
9. Saleh, S., Al-Awamry, A., Mahmoud, F. M.: Energy-efficient communication protocol for
wireless sensor networks. Int. J. Eng. Res. Technol. 4 (2015)
10. Younis, O., Fahmy, S.: HEED: a hybrid energy-efficient distributed clustering approach for ad
hoc sensor networks. IEEE Trans. Mob. Comput. 3(4) (2004)
11. Jeon, H., Park, K., Hwang, D.-J., Choo, H.: Sink-oriented dynamic location service protocol
for mobile sinks with an energy efficient grid-based approach. MDPI Sensors 90, 1433–1453
(2009)
12. Heinzelman, W. R., Chandrakasan, A. P., Balakrishnan, H.: Energy-efficient communication
protocol for wireless microsensor networks. In: Proc. of the Hawaii International Conference
on System Sciences, pp. 3005–3014 (2000)
Study on OSINT-Based Security Control
Monitoring Utilization Plan
Dain Lee and Hoo-Ki Lee
Abstract Recently, as cybercrime and security threats that abuse the anonymity of
the dark web and various social media continue to increase, the need for data anal-
ysis through OSINT has emerged. However, the reality is that public institutions and
private companies are far short of response strategies compared to the increasing
number of cases of infringement and public information that collect vast amounts of
data. Today, with the development of the Internet, OSINT collects information from
various public sources such as deep web and dark web as well as surface web such
as social media, online community, and Internet news, so it must be able to monitor,
collect and prevent public information using OSINT to effectively prevent leakage
and infringement. In this study, the definition and concept of OSINT, and utiliza-
tion plans in security monitor including characteristics are studied and presented,
and OSINT information collection tools are identified and analyzed. Through this,
OSINT-based security monitor utilization plans and considerations are presented.
Keywords OSINT · Social · Development · Security monitor
1 Introduction
Among the information media developed by mankind, the Internet has the largest
variety and amount of information, delivers it throughout the world at the fastest pace,
and has become a convenient and inexpensive information access medium shared by
the largest number of people. Ultimately, all the public information that humanity
needs is expected to exist on the Internet. As much of the information that had to
rely on collectors in the past can now be collected in real time through the Internet,
the act of abusing public information is increasing day by day [1].
D. Lee
Department of T&D Security, Daejeon-Si, South Korea
H.-K. Lee (B)
Department of Cyber Security Engineering, Konyang University Nonsan-Si, Nonsan-Si, South
Korea
e-mail: hk0038@konyang.ac.kr
https://doi.org/10.1007/978-3-031-19604-1_12
162 D. Lee and H.-K. Lee
Recently, the need for data analysis through OSINT has emerged as cybercrime
and security threats that exploit the anonymity of the dark web and various social
media continue to increase. About 533 million personal information leaked from
social network services in 2021 was released free of charge on the Dark Web Forum,
of which 120,000 were also included in Korean information. In March 2021, Doppel-
Paymer, a cyber attack organization, carried out malicious code attacks on global
automobile manufacturers, which leaked internal information such as email backup
files. They attempted to make financial demands by releasing the leaked information
little by little on the dark web. Information disclosed in such public source informa-
tion can be feared to cause secondary damage by exploiting it. Currently, it is possible
to easily penetrate servers, databases, and IoT devices with simple filtering searches
using public tools. However, the reality is that the response strategies of public insti-
tutions and private companies are far insufficient compared to the increase in public
information and infringement cases that collect vast amounts of data. Institutions
dealing with important information need to collect and analyze information from
various sources including the dark web and the deep web. OSINT is the easiest way
to get information because it uses public information accessible to anyone [2], but
finding accurate and significant content from the vast amount of information spread
on the real web, and tracking the identity of criminals behind anonymity requires
a lot of time and know-how. In particular, it is virtually impossible for the general
public to monitor spaces that can be used as open sources like the dark web, but are
difficult to access, unlike the surface web, and collect necessary information. Since
OSINT collects information from various public sources such as deep web and dark
web as well as surface webs such as social media, online communities, and Internet
news, OSINT should be used to monitor, collect, and prevent public information.
This study researches and presents ways to use OSINT in security monitor,
including the definition, concept, and characteristics of OSINT, and identifies
and analyzes current OSINT tools. Through this, OSINT-based security monitor
utilization plans and considerations are presented.
2 OSINT Definitions and Concepts
2.1 Definition of OSINT
OSINT stands for Open Source Intelligence, which is a combination of Open Source,
which means a public source, and Intelligence, which means information collected
for purpose through filtering, analysis, and processing, and refers to information
obtained from public sources. OSINT is also called open source intelligence or
public information, disclosed information, and open source information.
OSINT began to be used by countries and private intelligence organizations to
identify information related to terrorism and criminal activities, and began to collect
open-source information through traditional media such as newspapers, radio, and
Study on OSINT-Based Security Control Monitoring Utilization Plan 163
TV. In addition, it is used for the purpose of establishing an effective threat strategy
to protect against cyber attacks. Blogs, e-mails, IP addresses, SNS, and dark web are
being used for the purpose of collecting specific information.
2.2 Concept of OSINT
OSINT is a collection of data in a public and legal manner, It includes information

obtained through public observation on foreign political, economic, and military
activities, and information obtained from radio and television.
The concept of information is often used without distinction between “Informa-
tion” and “Intelligence,” but it is actually divided into different meanings. Informa-
tion obtained through the fact-checking stage is defined as “Intelligence” for public
information, and only information that has been analyzed and evaluated is referred
to as “Intelligence”. Data collected using public information at the stage before anal-
ysis and evaluation are defined as “information”. OSINT is a method of information
collection, which refers to information collection activities from the collection stage
to the information being useful through analysis and evaluation [3].
2.3 Features of OSINT
The types of information collection can be classified into HUMINT, TECGINT,

and OSINT, and the characteristic of OSINT is to produce useful information by
collecting and analyzing information from data from public sources such as Table 1.
The type of OSINT can be classified into two perspectives: Offensive and
Defensive in terms of security. Offensive refers to directly collecting information
by searching for keywords, etc., and Defensive refers to checking the collected
information [4] (Fig. 1).
OSINT has the advantage of being able to acquire information relatively quickly,
ensuring the speed of data access. In addition, it is characterized by securing more
data than secret intelligence data. It can be obtained at a low cost, and anyone can
Table 1 Comparison of input and output variables in previous research

Sortation content
HUMINT It is an information collection activity technique that collects information using
human information and interpersonal contact, and refers to the information itself
collected by human assets
TECGINT Technology information activities are activities that collect information using
advanced technologies, not human information sources
OSINT Information gathering techniques that produce useful information by collecting and
analyzing information from public sources available to anyone without restriction
Fig. 1 Comparison of input

and output variables in
previous research
easily access and use it conveniently. Of course, OSINT’s characteristics do not

only have advantages. Excessive amounts of data, organizational and cultural biases
in the information community, security issues, and technical constraints should be
con-sidered before effective use or use [5].
2.4 Application Field
Information processed by OSINT’s intelligence activities is used in many areas to

identify hidden facts related to national security threats, terrorism, and criminal activ-
ities. In addition, it is widely used in fields such as Internet betting and Crime Inves-
tigation. Examples include three applications: cybercriminal and organized crime,
social opinion and sentiment analysis, and cybersecurity and cyber defence, as shown
in Fig. 2 [6].
Fig. 2 OSINT field of

application
3 OSINT Processes and Tools
3.1 OSINT Process
INFOSEC proposed the basic structure of the OSINT process as shown in Fig. 3 to
efficiently collect information using OSINT [7].
In the basic structure of the OSINT process proposed by INFOSEC, relevant data
are collected from the identified sources through the step of identifying the source,
filtered, and final results are derived.
However, the OSINT process is not limited to one, but is gradually modified and
used depending on the situation. If additional information is needed in the analysis
stage analysis of the basic structure of (Fig. 3), the OSINT process of the new structure
can be constructed by repeating the information collection, processing, and analysis
steps to find and refine the association between the information (Fig. 4) [8].
Fig. 3 Basic structure of OSINT process
Fig. 4 Application Structure of OSINT Process

3.2 OSINT Tools
If you need to collect the necessary information on the web, it takes a lot of time
to analyze it on search sites and professional sites until you get the correct results.
However, when using the OSINT tool, it is desirable to actively use the OSINT tool
because it is provided in various forms such as text format, file, and image and can
collect and process information within seconds. Knowledge Nile selected ‘Top 14
OSINT tools as of 2021’ as shown in Table 2.
Censys
Censys is an OSINT search tool site that can collect information about hosts
and networks, helping to continually discover unknown assets and solve Internet
problems facing risks, and performs weekly scans worldwide using a Zmap scan
method.
Censys performs ping operations through ZMap and ZGarb, which query infor-
mation on numerous systems connected to the external Internet, to recognize which
type of device responded and to identify details such as configuration and encryption.
As shown in Fig. 5, Censys generates and manages data by performing scan tasks
and important field extraction, structured data generation, Zdb central management,
and recording procedures.
Table 2 Top 14 OSINT tools

No. Name No. Name
as of 2021
1 OSINT Framework 8 Metagoofil
2 theHarvester 9 Aircrack-ng
3 SHODAN 10 Censys
4 Searchcode 11 Google Dorks
5 Nmap 12 ZoomEye
6 SpiderFoot 13 Maltego
7 ExifTool 14 BuiltWith
Fig. 5 Censys system architecture

Table 3 Shodan filter list

Filter Explanation
City Limit search results to within a given city
Country Limit search results to within a given country
geo Search with specific latitude/longitude information
Os Check search results for a specific OS
Port Check search results for a specific port
Hostname Provides results that match a given hostname in the search results
Net Check search results only for specific classes
Before/after View search results before and after a specific date
Shodan
After scanning the port, Shodan is a tool that collects metadata from banner informa-
tion and collects and displays information about devices connected to the external
Internet, and can identify sensitive information such as IP addresses and network
connectivity as well as equipment location information. Shodan’s original purpose
was to make it easier for security professionals to find vulnerabilities, but it is now
also used to collect information maliciously. Like a general search engine, Shodan
can obtain data through search, but it has limitations in viewing results depending on
whether or not it is a paid/free member. The search method adopts a search method
by filtering, and supports various filters such as country, city, os, hostname, and port,
as shown in Table 3.
Unlike search engines that generate indexes on web content, Shodan operates in
the form of collecting information through banner grabbing through open ports on
servers or equipment that use the Internet, creating indexes, and returning them
to clients. The returned data provides necessary information such as equipment
information and services to the user through the Shodan Web UI.
SpiderFoot
SpiderFoot is one of the top OSINT tools designed to automate OSINT information
collection. In addition to automatically collecting data from more than 100 sources
to manipulate key scans and support information retrieval, it also includes modules
equipped with data investigation functions such as Fig. 6.
Information collected through SpiderFoot includes IP addresses,
domain/subdomain names, hostname.network subnet (CIDR), ASN, email address,
phone number, and user name, and integrates with almost any available data source
to focus on data analysis.
Fig. 6 SpiderFoot data investigation capability
4 OSINT Security Monitoring Utilization Plan
The use of OSINT in terms of security monitoring can include various activities, and
many OSINT tools have been developed to support this activity. Most tools support
more than one function, but since they are often specialized in one function, OSINT
tools and target selection methods should be reviewed to facilitate the use of security
monitoring on the OSINT basis [9].
4.1 Collecting and Taking Action on Internal Asset

Information
The security monitoring can safely protect internal assets by monitoring and checking
the leakage status of internal asset information and performing measures using the
OSINT information collection tool. When collecting information based on IP, the
risk of infringement should be reduced by checking open port information, server
and version information exposure, service exposure, and presence of vulnerabilities.
The following Fig. 7 is an OSINT-based internal asset information leakage collec-
tion and action process. After selecting the inspection target and inspection scope
based on internal assets, OSINT tools to be used for information collection are
selected and carried out. Using the selected inspection method and OSINT tool, the
security monitoring center collects information and utilizes the calculated results to
implement security measures such as removing vulnerabilities, blocking ports, and
removing services.
It is also a good idea to check the exposure status of internal domains such as
administrator pages and intranets using search engine information collection tools
Fig. 7 OSINT-based internal asset information leakage collection and action process
such as Google Dorks. It is very important to collect and monitor OSINT-based

internal asset information at all times to eliminate possible security risks in advance.
4.2 Gather and Prevent Published Threat Information
In security monitoring, the OSINT information collection tool can be used to collect
disclosed threat information and vulnerabilities and block security risks in advance,
thereby protecting internal assets.
As shown in Table 4, the disclosed threat information includes Malware Infor-
mation, new vulnerability information, and malicious domains, and in addition,
numerous information can be obtained using the OSINT information collection tool.
The following Fig. 8 is an OSINT-based open threat information collection and
prevention process. It is very important to collect threat information using the OSINT
information collection tool, and then primarily to identify damage from threat infor-
mation collected through event information and log analysis. Depending on the occur-
rence of damage, accident investigation and recovery work may be required, and
finally, it is important to block security threats collected through the creation of new
patterns and registration of blocking policies.
Table 4 Types of threat

No. kind
information disclosed
1 Malware Information
2 New Vulnerability Information
3 Phishing Site Information
4 Maliciousness IP, URL
5 Malicious mail Information
170
Fig. 8 OSINT-based published threat information collection and prevention processes

D. Lee and H.-K. Lee
Fig. 9 Examples of personal information disclosure
4.3 Inspection of Exposure of Important Information
With the development of search engines, information can be searched quickly, but
as there are vast amounts of data, damage such as using search engines for personal
information hacking purposes from outside or exposing important data on search
engines is continuing [10]. As shown in Fig. 9, it is possible to browse the file of a
document containing personal information even with a simple keyword search.
Therefore, security monitoring should check and take action on the exposure of
important information such as personal information and documents using search
engine information collection tools such as Google Dorks among OSINT informa-
tion collection tools to prevent leakage of internal personal information and impor-
tant data. When conducting an information exposure check, it should be possible
to proceed using ’filtering’ to distinguish vast amounts of data. After entering the
internal asset domain or IP as follows, the keyword can be combined to proceed with
the check.
OSINT-based critical information exposure checks are very important to perform
monitoring at all times to eliminate possible security risks in advance.
5 Conclusions
Since OSINT collects information from various public sources such as deep web
and dark web, it is necessary to monitor, collect, and prevent public information
using OSINT information collection tools in terms of security monitoring in order
to effectively prevent leakage and infringement. However, in order to accommodate
this, it is necessary to establish an information collection and response strategy that
meets the organization’s goals and vision, and to establish a process for utilizing
OSINT-based security monitoring.
In this study, a method that can be used in security monitoring was studied for
this content. An overview of the definition, concept, and utilization plan of OSINT
was presented, while the characteristics of various OSINT information collection

tools were presented. In addition, as OSINT-based security monitoring utilization
measures, internal asset information collection and action, public threat information
collection and prevention, and important information exposure check were classified
and studied.
Based on this study, it is hoped that by realizing OSINT-based security system
utilization measures, invisible threats can be prevented and a more strengthened
security system can be established.
Acknowledgements This paper was supported by the Konyang University Research Fund in 2022.
References
1. Byungchul, C.: A system for national intelligence activity based on all kinds of OSINT (Open
Source INTelligence on the Internet) (2003)
2. Kyuyong, S., Jincheol, Y., Changhee, H., Kyoung, M. K., Sungrok, K., Minam, M., Jongwan,
L.: A study on building a cyber attack database using open source intelligence (OSINT) (2019)
3. Wanhee, L., Minwoo, Y., JinSeok, P.: Intelligence in the Internet Era: understanding OSINT
and case analysis (2013)
4. Wonhyung, P.: Security with open search service (OSINT) (2021)
5. Woong, C.: Open source intelligence in the information age (2008)
6. Javier, P.-G., Pantaleone, N., Félix, G. M., Gregorio, M. P.: The not yet exploited goldmine of
OSINT: opportunities, open challenges and future trends (2016)
7. Irfan, S.: The art of searching for open source intelligence (2016)
8. Robert, A. F.: Open source intelligence methodology (2019)
9. Gajin, N., Neul, L.: A study on the limitations of OSINT and SOCMINT investigation and
analysis work from a security perspective and the requirements for overcoming it (2021)
10. Yang, H. K., Lee, K. H., Choi, J. H.: A study on personal information hacking using domestic
search engines (2007)
A Study on the Strategy of SWOT
Extraction in the Metavers Platform
Review Data: Using NLP Techniques
Jina Lee, Euntack Im, Inmo Yeo, and Gwangyong Gim
Abstract The Metaverse application industry has recently emerged as an impor-

tant industry, and user review data has become a rich resource for business oppor-
tunities. This study proposes a framework that addresses the major shortcomings
of traditional SWOT analysis through NLP based on review data from Metaverse
applications. We collect review data on ZEPETO and ROBLOX from the Google
Play Store and extract the aspects of each review data and perform sentiment anal-
ysis through natural language processing. Based on ZEPETO, we conduct research
on the strategic positioning of Metaverse applications. The framework presented in
this study presents ways to establish business strategic tools using secondary data
and provides implications for important factors in building a Metaverse application
environment.
Keywords Metaverse · SWOT analysis · Strategic positioning · Business straegy

tool · Secondary data · Sentiment analysis · Application · NLP
1 Introduction
Recently Metaverse has emerged as an important issue in countries around the

world. Metaverse has begun to attract attention as a new space that can maximize
immersion as it coincides with a situation where non-face-to-face situations become
J. Lee · E. Im · G. Gim (B)

Department of Business Administration, Soongsil University, Seoul, South Korea
J. Lee
e-mail: kmtca1355@naver.com
E. Im
e-mail: iet030507@gmail.com
I. Yeo
Samsung Town Finance Center, Samsung Securities Co., Ltd., Seoul, South Korea
e-mail: visionfor1@naver.com
https://doi.org/10.1007/978-3-031-19604-1_13
174 J. Lee et al.
common and time and space problems need to be solved in all daily fields (education,
games, work, consumption, etc.) because of Pandemic situation prolonged due to
COVID- 19. Recently, global companies and governments have been aggressively
investing and expanding in Metaverse, but empirical research and strategies how to
use them are still insufficient. Various Metaverse-based businesses require research
on strategic utilization plans and directions, and SWOT analysis has long been used
as a proposed business strategy planning tool [1]. Successful strategies derived from
SWOT analysis are based on suitability between internal competencies and external
situations [2] and have been widely adopted throughout the industry due to the
simplicity of processes that are easy to analyze and derive results [3]. However,
SWOT analysis is too simple, leading to strategic planning errors [4] or mainly
analyzed by subjective evaluation of experts, so it has a qualitative characteristic that
additional quantitative analysis must be supplemented, and empirical verification is
often insufficient [5].
Therefore, this study proposes a framework to solve the shortcomings of SWOT
analysis while examining what is important in establishing a metaverse applica-
tion environment by conducting SWOT analysis through machine learning tech-
niques based on online review data of metaverse mobile applications (User Generated
Contents). The SWOT analysis targets for this study are ZEPETO and ROBLOX,
which currently provide metaverse mobile services, and through Google Play Store,
reviews of US users using ZEPETO and ROBLOX are collected, doing sentimental
analysis and aspect extraction, and data are placed on S, W, O, and T, respectively.
2.1 Metaverse
Metaverse is a combination of the words ’Meta’ which means transcendence and

’Universe’ and can be viewed as a virtual world or space connected to the physical
world [6]. considers this to be a virtual mixture of digital and physical environments
facilitated by convergence and expansion between the Internet and Web technolo-
gies and states that all individual users possess their respective avatars to utilize them
similarly to the user’s physical self or to experience alternative life. Various technolo-
gies such as blockchain (cryptocurrency, virtual assets, NFT, etc.), cloud, computer
vision, artificial intelligence, and extended reality technology should be combined
to build and utilize metaverse applications. From Google, Meta, and Microsoft, to
companies in the fashion, entertainment, and financial industries, they have recently
built or used metaverse applications. According to Grand View Research, the global
metaverse market is expected to reach $678.8 billion by 2030 and to record a CAGR
of 39.4% over the forecast period due to increased demand in the end-use industry
[7]. Like the movie Ready Player One, Metaverse is still developing a wearable
device that connects all parts of the body and allows you to experience a completely
A Study on the Strategy of SWOT Extraction in the Metavers Platform … 175
new world. In addition, a metaverse application has emerged as a virtual world and
a virtual space that can be immersed without immersive devices. These applications
mainly provide users with various functions such as interaction between users such
as SNS, playing games, and working in mobile and PC environments.
2.1.1 ZEPETO
Naver Z that aims to become a virtual world platform that anyone can create what they
have dreamed of in their hearts based on 3D avatars and has more than 300 million
users in more than 200 countries around the world. ZEPETO not only provides inter-
action between users and game functions by providing virtual spaces with various
themes called ’world’, but also provides a service that allows users to create virtual
spaces on their own through its own program called ’Build it’. In addition, it provides a
“ZEPETO Creator” function that allows users to produce various contents (short form
contents, webtoons, etc.) based on avatars and through this function ZEPETO users
can generates profits by producing and selling avatar items not only purchasing items
through ZEPETO’s virtual currency called “Zem” and “coin”. ZEPETO provides a
“LIVE” function that allows users to communicate with other users through real-time
broadcasting using avatars and also collaborates with various brands. Collaboration
is a virtual production of many products such as movies, cars, and fashion brands
to provide users with various experiences, promote songs by various artists such as
Black Pink and BTS, and hold virtual fan signing events to communicate with fans
and artists’ avatars. ZEPETO provides various functions based on avatars, especially
communication and self-expression such as SNS, and is free to create and generate
profits. In this study, ZEPETO is designated as its own company in SWOT analysis.
2.1.2 ROBLOX
ROBLOX is an online game platform and game creation system that explores millions
of immersive 3D experiences created by the global developer community with the aim
of allowing everyone to imagine, create, and have fun with their friends. ROBLOX
is run by a global community of millions of developers who offer ’Roblox Studio’
each month to produce their own immersive multiplayer experience and has 230
million users [8]. From the perspective of a metaverse, a virtual environment with a
mix of physical and digital environments, ROBLOX can be viewed as a game-type
metaverse application in terms of creating, selling, or purchasing games through its
own virtual currency ’Robux’, and providing a variety of games (virtual space or the
world) for users to interact within ROBLOX [9]. ROBLOX, like ZEPETO, can use
services in both mobile and PC environments, and is used as a virtual performance
venue and educational platform such as collaboration with fashion brands such as
VANS and NIKE, Virtual Grammy Week. In both applications, teenagers called Z
generation, or zoomers, account for more than half of the users and can create and
experience virtual spaces. In addition, it has something in common with ZEPETO that
176 J. Lee et al.
it has its own virtual currency and communication and game functions. Therefore,
in this study, ROBLOX was designated as a competitor for ZEPETO.
2.2 SWOT Analysis with Secondary Data
SWOT analysis identifies the strengths and weaknesses of the internal capacities
of the target to be analyzed, and factors related to opportunities and threats in the
external environment. This analysis is developed to eliminate weaknesses based
on advantages and exploit opportunities or respond to threats. SWOT analysis has
been widely adopted throughout the industry due to the simplicity of processes that
facilitate analysis and decision-making [3] and is a strategic planning tool that can
be used to achieve goals and efficiently serve customers [10].
There are still not many studies that have conducted SWOT analysis using
secondary data. Most of these studies often semi-automated or automated SWOT
analysis using machine learning techniques. In addition, the criteria for classifying
S, W, O, and T are shown in Fig. 1. In the case of SWOT analysis using secondary data,
the internal capability to classify strengths and weaknesses uses own company(or
product)’s review data. The external environment, which classifies opportunities and
threats, designates competitors and then classifies their strengths as their own threats
and classify competitors’ weaknesses as their own opportunities.
In the studies of [12, 13], both studies used review data to propose and verify the
RE-SWOT MARTIX, that is, a semi-automatic SWOT analysis method. In the study
of [11], feature extraction and sentiment analysis were performed using online review
data in the tourism field, and each feature was assigned to S, W, O, and T based on the
FPS score suggested in the study in [12]. FPS is a formula that categorizes S, W, O, T
based on the number of reviews that mention product-related features and the user’s
rating-based feature words divided into positive and negative. In both studies, it is
meaningful to semi-automate the SWOT analysis by classifying the user’s ratings by
performing sentiment analysis with stars(in reviews) or review texts, but there is a
limitation that more research is needed on the verification of the FPS formula. In the
study of [3], UGC (User Generated Contents) data including customer opinions and
reviews was used to view and analyze the competitive advantage from the consumer’s
point of view. In this study, the disadvantages of the existing SWOT analysis are
overcome by using the review data to automate the SWOT analysis using the NLP
technique. In this study, aspect-based sentiment analysis is performed by collecting
Fig. 1 SWOT analysis classification

and pre-processing online reviews for tablet PCs of various brands on Amazon. In this
case, the review data is collected by generations of products of several brands. After
that, Aspect-sentiment pairs are created, Association Rules are extracted, and Aspect-
sentiment pairs of the cluster of Association Rule mining are applied. Extract frequent
association rule patterns based on different products of different product generations.
Then, one brand product is designated as the own company, and if the difference from
the previous generation within the same brand is positive, it is designated as a strength,
and if it is negative, it is designated as a weakness. After extracting related rule
patterns in the same way for reviews of products of other brands, researchers of this
study look at those brands as competitors. Weaknesses of competitors (competitive
brand products) are positioned as opportunities and strengths as threats. In the case
of this study, since aspect-based sentiment analysis is performed and S and W are
identified by product generation, there are limitations in that many analysis targets
must exist in the market or labeled prior data is required.
3 Research Method
3.1 Research Model
In this study, metaverse mobile application ZEPETO is designated as ‘own company

(brand, product)’ and ROBLOX is designated as ‘competing company (brand,
product)’. We conduct SWOT analysis with machine learning applied through the
review data of both applications. First, we collected review data of ZEPETO and
ROBLOX from the Google Play Store. The collection period is from January 1,
2021 to March 17, 2022, and the data collected thereafter is separated into sentences.
The separated sentence data was subjected to sentiment analysis through the VADER
algorithm to derive a polarity value (compound). In addition, the separated sentence
data was pre-processed through tokenization, part-of-speech tagging, and stop word
removal, and then aspects of each application were extracted and classified through
LDA topic modeling. Afterwards, the aspect corresponding to each sentence and the
derived polarity value (compound) are composed into one dataset, and the average
of the polarity values (compound) of each aspect is calculated as a positive aspect
if it exceeds 0, and a negative aspect if it is less than 0 classified. Finally, positive
aspects of ZEPETO were placed in S, negative aspects were placed in W, positive
aspects of ROBLOX were placed in T, and negative aspects were placed in O, and
the results were interpreted. The research model of this study is shown in Fig. 2.
178 J. Lee et al.
Fig. 2 Research model of this study
3.2 Research Method
3.2.1 Data Collection and Preprocessing
The data to be used in this study is the review data left by users after using the
application directly, and was collected after writing the code using Python in the
Google Colab Pro environment. The data collected reviews from US users on the
Google Play Store, and the collection period is from January 1, 2021 to March 17,
2022. The number of collected review data was 126,824 in ZEPETO and 82,784 in
ROBLOX, respectively, and each collected data was first separated into sentences.
As for the data of the separated sentence unit, ZEPETO had 306,666 of ZEPETO
and ROBLOX had 332,436. Thereafter, positive datasets and negative datasets were
constructed based on the average of the star (Out of five) of each application review
data. To extract aspects, only features were extracted and tokenization was performed,
and part of speech was tagged to each feature to extract only nouns and verbs and
remove stop words. At this time, exclamations classified as abbreviations or nouns
were produced as a stop word dictionary and removed, and characters of less than 2
characters were deleted.
3.2.2 Extracting and Classifying Aspects
In this study, LDA Topic Modeling was performed on preprocessed review data to
extract aspects. There are no classification standard for S, W, O, T of the metaverse
application or a set evaluation standard. In this background, there was no labeled data,
so LDA Topic Modeling, an unsupervised learning method, was used. As mentioned
above, the latest industrial applications that do not have criteria to classify topics
are the subject of this analysis and as mentioned in Chap. 2, although ROBLOX
and ZEPETO have a lot in common, each has different detailed functions and their
own terminology. So, the extracted topics (aspects) were arbitrarily designated by
the researcher based on the classified keywords. Therefore, in this study, research
and previous studies on ROBLOX and ZEPETO were reviewed, and topics were
designated based on the experience of using each application for about two months.
3.2.3 Sensitivity Analysis and Dataset Composition
Sentiment analysis was performed on the sentence data of each review data separated
based on the average of the stars in the review, and in this case, the rule-based VADER
algorithm was used. The reason for using VADER is that this algorithm performs well
when dealing with texts from social media, movie reviews, and product reviews [13].
The VADER algorithm gives a sensitivity score between −1 and 1, and a ‘compound
‘ is derived by appropriately combining positive, negative, and neutral values. In this
study, the compound was used as the polarity value.
3.2.4 Assign Dataset to SWOT
A final dataset was constructed based on the classification results of aspects extracted
through sentiment analysis and LDA topic modeling. Based on the sentences sepa-
rated from each positive and negative review dataset, the dataset consists of the
emotional polarity value for each sentence and the topics with the highest weight
in the sentence. Afterwards, in this study, since ZEPETO was designated as own
company, positive aspects of ZEPETO were placed in S and negative aspects of
ZEPETO were placed in W. Positive aspects of ROBLOX are placed in T and nega-
tive aspects are placed in O. The average of the polarity values of each sentence was
calculated based on the topic, and the importance was judged by the ranking of the
topics arranged in each S, W, O, and T based on this.
4 Results
In this study, SWOT analysis was conducted by designating ZEPETO as the own
company and ROBLOX as the competitor. As for the data set used at this time,
according to the criteria of previous studies, the positive dataset of ZEPETO was used
for S (strengths) and the negative dataset of ZEPETO was used for W (weakness). The
negative dataset of ROBLOX was used for O(opportunity) and the positive dataset of
ROBLOX was used for T(threatens). Afterwards, LDA topic modeling was carried
out based on each data set, and the topics(aspects) were arranged on S, W, O, T.
The results were interpreted by judging the importance of each aspect by taking the
average of the sentiment analysis results (polar value; compound) of aspects.
In addition, in this study, negative aspects of ROBLOX can be viewed as opportuni-
ties for ZEPETO, but overlapping topics (aspects) were judged as common challenges
of metaverse applications. However, the aspects of each application were identified
and interpreted through the keywords of each aspect. Similarly, positive aspects of
180 J. Lee et al.
Table 1 SWOT analysis

ZEPETO (own) ROBLOX (competitor)
result
Positive S T
1. Creating items 1. Connecting devices
2. Character(Avatar) 2. Experience
3. Feeds (Avatar-based 3. Making game
Shortform Content) 4. Communication
4. K Pop (Interaction)
5. Playing Game 5. Playing game
6. Communication 6. Character(avatar)
(Interaction)
7. Worlds(virtual spaces)
Negative W O
1. Inducing excessive 1. Inappropriate
spending (zem) contents
2. Security 2. Inappropriate
3. Meeting Strangers meeting
4. Hacking 3. System error
5. System Error 4. Hacking and fraud
5. Addiction
ROBLOX can be seen as threats of ZEPETO, but overlapping topics (aspects) were
judged as common advantages of metaverse elements, and aspects of each applica-
tion were identified and interpreted through the order and keywords of each aspect.
The final SWOT analysis results are shown in Table 1.
4.1 SWOT: S, W (ZEPETO Positive and Negative Data)
Each aspect was placed in S (strengths) through the positive dataset of ZEPETO
separated based on stars. Table 2 shows the average and rank of each derived aspect,
keyword, and polarity value. Aspects are Communication (Interaction), Game, Char-
acter (Avatar), Feeds (Avatar-based Shortform Content), Creating items, Worlds
(virtual spaces), K Pop. Aspects are specified based on keywords derived through
LDA topic modeling, and these constitute S. In addition, as a result of analyzing
the importance of each aspect in S based on the average of the polarity values,
Creating items>Character (Avatar)>Feeds (Avatar-based Shortform Content)>K
Pop>Game>Communication (Interaction)>Worlds (virtual spaces) is the order. In
this case, the closer to 1, the higher the priority because the positive dataset was
used.
First, as a result of averaging the polarity values of aspects placed in S, aspects
related to avatars were selected in the 1st and 2nd rankings for ZEPETO. ZEPETO
allows users to use it as a multi-persona through 3D-based avatars and various items,
and can create avatars similar to users with user photos through its own technology.
In addition, it is interpreted that this result was obtained because it is providing a
variety of items through collaboration with various brands. In addition, ZEPETO
Table 2 S(Strengths) and W(Weakness) aspects results
S: ZEPETO Positive W: ZEPETO Negaitive
Importance ranking Topic Keyword Importance ranking Topic Keyword
6 Communication Make Friend 5 System error Bugs Crashing
(Interaction) Friends Hangout Laggy Loading
Meet Follow Uninstall Post
Chat Talk Disconnection Glitches
People Play System Download
5 Playing game Game Minigame 1 Inducing excessive Zem Purchase
Player Download spending (zem) Induce Ads
Group Update Coin Diamond
Gameplay Laggy Expensive Quest
Jumpmaster Party Items Clothes
2 Character (Avatar) Character Hair 4 Hacking Hacking Error
Outfits Clothes Account Login
Fashion Item Hacker Problem
Buy Change Email Delete
Edit Price Password Games
A Study on the Strategy of SWOT Extraction in the Metavers Platform …
3 Feeds (Avatar-based Videos Dances 2 Security Stalking Spying

Shortform Content) Make Photos Track Spyware
Entertainment Watch Avatar Virus
Tiktok Followers Camera Records
Followers Challenges Photos Trackers
(continued)
181
Table 2 (continued)
182
S: ZEPETO Positive W: ZEPETO Negaitive

Importance ranking Topic Keyword Importance ranking Topic Keyword
1 Creating items Avatar Item 3 Meeting Strangers Scam Meeting
Create Make Kids Kidnaps
Edit Creator Stranger Chat
Clothes Zepetostudio Dating Crews
Zem Earn Child Scammers
7 Worlds (Virtual World Experience **BTS member name
spaces) Make Map
Graphics Theme
Epic Loading
Graphics Creator
4 K Pop BTS Twice
Blackpink Jungkook
Entertainment Jimin**
Fans Idol
K Pop Pop
J. Lee et al.
allows users to create various items by using 3d design tools directly from simple
image upload through the mobile application (Becoming a Creator) and PC (ZEPETO
studio). Users can also sell the items to generate revenue through ZEPETO’s virtual
currency called zem. The fact that you can make a variety of items yourself very
easily and sell them to generate profits is interpreted as being recognized as a very
big advantage for ZEPETO users. ’Feeds’, which can produce and view short-form
content and images (photos) based on the user’s avatar, also ranked third in ZEPETO’s
strengths.
Many users of ZEPETO are Generation Z, and they enjoy short video content such
as tiktok and shorts. From this point of view, it is interpreted that it was selected as a
strength because it is possible to easily create various contents based on the avatar. In
addition, K-pop has recently been gaining popularity in global countries, and K-pop
artists, who had difficulty communicating with their fans due to the coronavirus,
conducted various virtual spaces, avatars, and events through collaboration with
ZEPETO. Accordingly, fans of Kpop artists encountered various Kpop contents
through ZEPETO, and from this point of view, it is interpreted that Kpop is placed as
ZEPETO’s strength. In addition, the world and game that function as virtual space,
which can be seen as the biggest characteristics of the metaverse, were selected as
strengths.
Table 2 also shows the averages and ranks of aspects, keywords, and polarity
values arranged in W (weakness). Aspects are System Error, inducement to pay
(zem), Hacking, Security, and Meeting Strangers and as a result of analyzing the
importance of W of each aspect based on the average of the polarity values, the order is
Inducing excessive spending (zem)>Security>Meeting Strangers>Hacking>System
Error. In this case, the closer to −1, the higher the priority because a negative data
set is used. As a result of the average polarity value of aspects placed in W, the
first is about paying zem, the ZEPETO virtual currency. In ZEPETO, zem and coin
are used to purchase various items, and items are sold through collaboration with
many brands. Users can use the avatar as a multi-persona and purchase products
from expensive brands as avatar items at a much lower price in reality. From this
point of view, it is interpreted that users spend excessively on item purchases and are
placed on a weakness. Also, in the case of security, which is second, if you look at
keywords, you can see words such as tracking, stalking, and records. As a result of the
investigation in this regard, there was a content that the photos used to generate avatars
in ZEPETO and the user’s activity records (log records) could be used or recorded
regardless of the user’s intention. However, this part was collected with the consent
of the user, and most of the reviews related to this were confirmed to be rumors.
Third was about ethical problems that could arise from meeting various people in an
avatar-based virtual space where anonymity was guaranteed. In particular, users can
meet various people through ZEPETO’s ’crew’ function and ’match’ function, but
from a different point of view, you can meet strangers and be exposed to crimes such
as online grooming. 4th and 5th places were also related to system errors such as
delays, errors, disconnections, and crashing, as well as problems caused by account
hacking.
184 J. Lee et al.
4.1.1 SWOT: O, T (ROBLOX Positive and Negative Data)
Table 3 is the result of placing each aspect in O (Opportunity) through the nega-
tive dataset of ROBLOX. Aspects of O are Addiction, System error, Hacking and
fraud, Inappropriate contents, Inappropriate contents, and Inappropriate meeting and
the order of importance is Inappropriate contents>Inappropriate meeting>Making
game>System error>Hacking and fraud>Addiction. First, in the case of ‘inappro-
priate contents’, it is about ethical issues that can occur in an anonymous virtual space.
There are various game types such as survival, adventure, and action in ROBLOX,
and there are many games that allow actions such as killing or attacking a certain
target. In the virtual space where immersion is maximized, these games can expe-
rience inappropriate content and furthermore, by playing certain roles and actions,
can instill awareness of unethical behavior. This is a part that has been frequently
mentioned as one of the negative problems of online games. In addition, there were
a lot of reviews saying that there are virtual spaces where you can experience uneth-
ical and sexual content like ‘condos’ in ROBLOX, allowing young users to provide
inappropriate content in many ROBLOX. Here, ‘condos’ is a term commonly used
when referring to Roblox sex games, and it is a space created by users, where people
can talk about sex and their avatars can have virtual sex [14].
This is interpreted as something that ZEPETO can take as an opportunity by being
careful and preventing it in advance when developing the game. “addiction” means
that users are addicted to games, accessing and playing for a long time, or recklessly
paying for ROBLOX’s cryptocurrency, “robux”. The addiction problem is one of
the issues of ROBLOX, and it is interpreted as highly addictive because most users
are young or can play many kinds of games with various devices. In addition, in
the case of ROBLOX, it is interpreted that many users can spend indiscriminately
because a significant part of it is a paid game, that is, because they have to pay to play
the game. In the case of ZEPETO, it is interpreted that this can be an opportunity
for ZEPETO, as it does not require extra spending to enjoy the game except for
decorating the current avatar. In this regard, ROBLOX provides monthly spending
restrictions, spending notification control functions, and game account restrictions
to help parents prevent their children from excessive spending, game addiction, and
inappropriate experiences.
Table 3 shows the results placed in T (threatens) through the positive data
set of ROBLOX. Aspects are Experience, Playing game, Character(avatar),
Connecting devices, Interaction, Making game. As a result of analyzing the
T priority of each aspect, the order is Connecting devices>Experience>Making
game>Interaction>Playing game>Character (avatar). First, connecting devices is
ZEPETO’s number one threat, and both applications provide pc and mobile versions,
but in the case of ROBLOX, it provides services through a game-only device called
xbox to induce more immersion and interest. In addition, ROBLOX supports Oculus
Rift and HTC Vive devices to provide a more immersive experience, and global
major companies are entering the VR and AR device market recently. Against this
background, in the case of ZEPETO, it is interpreted that it is necessary to provide
the experience that ROBLOX provides through support for more diverse devices. In
Table 3 W(Weakness) and T(Treathens) aspects results
T: ROBLOX Positive O: ROBLOX Negaitive
Importance ranking Topic (Aspect) Keyword Importance ranking Topic (Aspect) Keyword
2 Experience Role Bloxburg 5 Addiction Games Dollars
Simulator Livetopia Playing Robux
Family Meepcity Addicted Purchase
Cousin Brookhaven Hours Stuck
Adopt Tycoons Spending Items
5 Playing game Games Connect 3 System error Fix Disconnection
Playing Adventures Server Update
Obbys Simulator Glithces Fail
Roleplay Multiplayer Lag Reconnect
Noob Mode Bugs Login
6 Character(avatar) Character Avatars 4 Hacking and fraud Hacking Password
Clothes Buy Scammers Account
Bacon Customize Exploiter Robux
Hair Style Cheater Trading
Acc Premium Scam Player
A Study on the Strategy of SWOT Extraction in the Metavers Platform …
1 Connecting Tablet Mobile 1 Inappropriate contents Slender Problems

devices Xbox Connection Killing Murder
Phone Laptop Condos Bypass
Lagging Device Adults Toxic
iPad Problem Sex Violence
(continued)
185
Table 3 (continued)
186
T: ROBLOX Positive O: ROBLOX Negaitive

Importance ranking Topic (Aspect) Keyword Importance ranking Topic (Aspect) Keyword
4 Communication Friends Games 2 Inappropriate meeting Chat Community
(Interaction) Make Interact People Couple
Community Teens Slender Sexy
Play People Bullying Moderator
Meet Talk Dating Messages
3 Making game Game Robux
Tycoons Money
Make Creator
Code Developer
J. Lee et al.
addition, ROBLOX provides games that can be experienced in a variety of ways, such
as role-playing and simulator. These games enable users to create their own business
like playing ’tycoon’, from simply experiencing a certain role. ’tycoon’ is a genre of
experience in ROBLOX where the player owns his or her base (usually a business or
company) [14]. As such, it is interpreted that ZEPETO needs to provide a function
that enables a more diverse experience within the virtual space. ROBLOX also has
the ability to easily create games and provides a ROBLOX studio where users can
design and create their own games, environments and other objects through a simple
coding language called LUA [15]. In this regard, ROBLOX operate the ’Roblox
Star Program’, an invitation-only program for top developers who want to expand
and expand the license of intellectual property (IP) related to the ROBLOX experi-
ence to ROBLOX. The Roblox Star Program is a program designed to grant Roblox
an exclusive worldwide license to use the developer’s username, avatar, and any
user-generated content they choose to include [16]. This enables ROBLOX to create
games and content, monetize it and attract more users [17]. ZEPETO also provides
tools to create virtual spaces, but currently, virtual spaces containing game functions
can be created through ’unity’ by writing a Typescript. However, since the feature
was released not long ago, many users are not actively using it. From this point of
view, ZEPETO is expected to be better if it provides tools and functions that can
directly create various games through simple and easy coding and programming like
ROBLOX.
5 Conclusions
In this study, UGC(User Generated Contents) was used, but since data from a new
industry was used, there was no labeled data or no evaluation criteria, so subjectivity
could not be completely excluded. For this, feature extraction using more diverse
unsupervised learning methods is required. Therefore, it is necessary to conduct
comparative analysis through reviews of various metaverse applications other than
ZEPETO and ROBLOX, or to supplement the limitations by using more diverse data
such as article data in addition to online reviews. In addition, even though aspects
were placed in S, W, O, and T, simple noun phrases and noun-centered aspects were
used, so there is a limitation that human subjective judgment and interpretation are
required for strategic use. However, this study was able to overcome the limitations
that the existing SWOT analysis mainly consisted of subjective evaluation by experts
or there was no empirical verification by presenting a framework for deriving busi-
ness strategies through online review data. It is also expected that this framework
will be useful in industries with evaluation criteria or labeled data. It is meaningful
to provide practical implications for building various metaverse applications and
providing services in the coming metaverse era by understanding what character-
istics are important for building metaverse applications, which are emerging as an
important industry recently.
188 J. Lee et al.
References
1. Niranjanamurthy, M., Nithya, B.N., Jagannatha, S.J.C.C.: Analysis of blockchain technology:

pros, cons and SWOT. Clust. Comput. 22(6), 14743–14757 (2019)
2. Agarwal, R., Grassl, W, Pahl, J.: Meta-SWOT: Introducing a new strategic planning tool. J.
Bus. Strat. (2012)
3. Cheng, L.C., et al.: User-defined SWOT analysis–A change mining perspective on user-
generated content. Inf. Process Manag. 58.5,102613 (2021)
4. Pickton, D.W., Weight, S.: What’s swot in strategic analysis? Strat. Chang. 7(2), 101−109
(1998)
5. Gurl, E.: SWOT Analysis: A Theoretical Review (2017)
6. Lee, L.H et al.: All one needs to know about metaverse: a complete survey on technological
singularity, virtual ecosystem, and research agenda (2021). arXiv preprint arXiv:2110.05352
7. Bloomberg: Metaverse Market Size Worth $678.8 Billion by 2030, Grand View Research, Inc.
https://www.bloomberg.com/press-releases/2022-03-09/metaverse-market-size-worth-678-8-
billion-by-2030-grand-view-research-inc. (2022)
8. ActivePlayer.io: Roblox Live Player Count and Statistics. https://activeplayer.io/roblox/#:
~:text=Roblox%20has%20over%20230%20Million%20registered%20players%20and%
2030%20million%20daily%20players
9. Santoro, J: Does Roblox Have a Plan to Win the Metaverse?. https://www.fool.com/investing/
2022/02/12/does-roblox-have-a-plan-to-win-the-metaverse/ (2022)
10. Culp III, K., et al.: Using a SWOT Analysis: Taking a Look at Your Organization (2016)
11. Fehringer, D.: Six steps to better SWOTs. Compet. Intell. Mag. 10(1), 54 (2007)
12. Dalpiaz, F., Parente, M.: RE-SWOT: from user feedback to requirements via competitor anal-
ysis. In: International Working Conference On Requirements Engineering: Foundation For
Software Quality, pp. 55−70. Springer, Cham (2019)
13. Tu, S.F., Hsu, C.S., Lu, Y.T.: Improving RE-SWOT analysis with sentiment classification: a
case study of travel agencies. Futur. Internet. 13 (9), 26 (2021)
14. Clayton, A., Dyer, J.: Roblox: The children’s game with a sex problem. BBC News,
2022.02.15. https://www.bbc.com/news/technology-60314572#:~:text=Roblox%20sex%20g
ames%20are%20commonly,thrown%20out%20of%20the%20window
15. Tycoon: Roblox Wiki. https://roblox.fandom.com/wiki/Tycoon
16. Roblox Star Program: Devleoper, https://developer.roblox.com/en-us/resources/Stars-About#:
~:text=The%20Stars%20program%20is%20designed,the%20ones%20they%20don’t
17. Virginia: Can roblox be educational? absolutely! Here’s how.., iD Tech, 2021.05.24, https://
www.idtech.com/blog/roblox-educational-benefits
Does Facial Expression Accurately
Reveal True Emotion? Evidence
from EEG Signal
Huy Tung Phuong, Yangyoung Kun, Jisook Kim, and Gwangyong Gim
Abstract Facial expression is one of the ways in which human expresses emotion.
However, there has been evidence that facial expression does not always accurately
reflect inner emotions, leading to the shaking of theories about human basic universal
emotions. In this study, we conduct an experiment to collect facial expression data
and EEG signals of participant. The results indicate that not all kinds of basic emotion
were expressed in facial expressions under the experiment environment. On the other
hand, brain signals have proven to be a highly reliable tool for emotion recognition
task. This study shows the problems faced by facial emotion recognition systems
and proposes future works to improve the efficiency of those systems.
Keywords EEG · Facial expression · Emotion measurement · Emotional AI ·

Affective computing
1 Introduction
Affective computing has emerged as an important field of study that aims to develop
systems that can automatically recognize emotions. Emotion recognition has gained
substantial attention in the last decade because it is directly linked to psychology,
H. T. Phuong · G. Gim (B)

Department of Business Administration, Soongsil University, Seoul, South Korea
H. T. Phuong
e-mail: tungph@soongsil.ac.kr
Y. Kun
Department of IT Policy and Management, Soongsil University, Seoul, South Korea
e-mail: yyk0918@naver.com
J. Kim
Management Planning HQ, Soongsil University, Seoul, South Korea
e-mail: inispriblue@gmail.com
https://doi.org/10.1007/978-3-031-19604-1_14
190 H. T. Phuong et al.
physiology, learning studies, marketing, and healing. In 2019, the market for emotion-
detection technology is worth roughly 21.6 billion dollars, and its value is predicted
to reaching 56 billion dollars by 2024 [1].
Emotion has been defined in various ways in the twentieth century, and there
is currently no scientific consensus on a definition [2, 3]. From neurophysiological
perspective, emotions are mental states brought on by neurophysiological changes,
variously associated with thoughts, feelings, behavioral responses, and a degree
of pleasure or displeasure [3–7]. From mechanistic perspective, in the meanwhile,
emotions can be defined as a positive or negative experience that is associated with
a particular pattern of physiological activity [8, 9].
Facial expression is a convenient way for humans to communicate emotion. As
a result, research on emotional facial expression recognition has become a key
focus area of personalized human−computer interaction [10–12]. Influential obser-
vations in the 1960s and 1970s by US psychologist Paul Ekman suggested that,
around the world, humans could reliably infer emotional states from expressions
on faces−implying that emotional expressions are universal [13, 14]. This assump-
tion influences legal judgments, policy decisions, national security protocols, and
educational practices; guides the diagnosis and treatment of psychiatric illness, as
well as the development of commercial applications; and pervades everyday social
interactions as well as research in other scientific fields such as artificial intelligence,
neuroscience, and computer vision [15].
These ideas stood largely unchallenged for a generation. But a new cohort of
psychologists and cognitive scientists has been revisiting those data and ques-
tioning the conclusions. Many researchers now think that the picture is a lot more
complicated, and that facial expressions vary widely between contexts and cultures
[16].
Although AI companies market software for recognizing emotions in faces,
psychologists still debate whether expressions can be read so easily [16]. Facial
expressions are extremely difficult to interpret, even for people. With researchers
still wrangling over whether people can produce or perceive emotional expressions
with fidelity, many in the field think efforts to get computers to do it automatically
are premature−especially when the technology could have damaging repercussions
[16]. Thus, during the last decade, many research and development efforts have been
deployed to develop new approaches and techniques for emotion recognition. It is
becoming increasingly attractive to detect human emotions using biological brain
signals. Electroencephalography (EEG) is a reliable and cost-effective technology
used to measure brain activity [1].
In this study, we re-examine the results of recent studies, that facial expressions do
not completely accurately represent real emotions [16]. We also test our hypothesis
that EEG signals would provide a better tool to measure emotions more accurately
than facial expressions. In our experiment, participant was evoked to Ekman’s six
basic emotions (sad, surprise, enjoy, disgust, anger, fear) [17] through videos played
on a computer screen. While the participant watched the emotional videos, EEG
signals were recorded in 14 channels of signal. At the same time, the participant’
facial expressions were recorded by a camera mounted above the computer screen.
Does Facial Expression Accurately Reveal True Emotion? Evidence … 191
2.1 Emotions as Discrete Categories: Basic Emotion Theory,

Emotional Facial Expression, and Relevant Debates
Basic emotion theory proposes that human beings have a limited number of emotions
(e.g., fear, anger, joy, sadness) that are biologically and psychologically “basic”, each
manifested in an organized recurring pattern of associated behavioral components
[18].
This idea of basic emotion is not new. For instance, in the seventeenth
century, Descartes (1649/1996) already identified six “primitive passions” (“pas-
sion” formerly being used as a term for “emotion”): wonder (admiration), desire,
love, joy, hatred, and sadness [16]. Paul Ekman [13, 14, 17] identified the six basic
emotions as anger, surprise, disgust, enjoyment, fear, and sadness. Ekman suggested
that, around the world, humans could reliably infer emotional states from expressions
on faces—implying that emotional expressions are universal. His studies indicated
that some expressions, and their corresponding feelings, were recognized by people
of all cultures.
The viewpoint of basic emotion theory has had detractors. Many researchers now
think that the picture is a lot more complicated, and that facial expressions vary
widely between contexts and cultures, thus researchers are increasingly split over
the validity of Ekman’s conclusions [16].
The observational study of Chen et al. [19] reported that people experiencing pain
or orgasm produce facial expressions that are indistinguishable, which questions
their role as an effective tool for communication. This study found that although
Westerners and East Asians had similar concepts of how faces display pain, they had
different ideas about expressions of pleasure.
According to Barret et al. [15], the available scientific evidence suggests that
people do sometimes smile when happy, frown when sad, scowl when angry, and
so on, as proposed by the common view, more than what would be expected by
chance. However, how people communicate anger, disgust, fear, happiness, sadness,
and surprise varies substantially across cultures, situations, and even across people
within a single situation. The study concluded that, there was little to no evidence
that people can reliably infer someone else’s emotional state from a set of facial
movements.
A study conducted by Crivelli et al. [20], with two experiments on how residents
of Papua New Guinea interpret facial expressions produced spontaneously by other
residents of Papua New Guinea, also showed similar results. In both experiments
of Crivelli et al., agreement with Ekman’s predicted labels was extremely low. The
study found no evidence for Ekman’s conclusions, thus concluded that “trying to
assess internal mental states from external markers is like trying to measure mass in
metres” [16, 20].
Our research supports the view of Crivelli [20], Chen [19], Barret [15] and Heaven
[16] on the assertion that facial expressions are complex and cannot be an accu-
rate measurement of emotion. Thus, our view pointed to the reliability problem for
emotional AI researchers who are training their artificial intelligence using classic
dataset of faces for recognizing emotions.
2.2 Emotion as Dimensional Model: The Valence—Arousal

Circumplex Model
Clinicians and researchers have long noted the difficulty that people have in assessing,
discerning, and describing their own emotions [21]. This difficulty suggests that indi-
viduals do not experience, or recognize, emotions as isolated, discrete entities, but that
they rather recognize emotions as ambiguous and overlapping experiences. Emotions
seem to lack the discrete borders that would clearly differentiate one emotion from
another, thus discrete emotional classes (i.e., Ekman’s six basic emotions) are not
representative of the full spectrum of emotions displayed by humans on a daily basis
[22].
Indeed, researchers exploring the subjective experience of emotion have noted that
emotions are highly intercorrelated both within and between the subjects reporting
them [23, 24]. Subjects rarely describe feeling a specific positive emotion without
also claiming to feel other positive emotions [24]. These intercorrelations among
emotions, often obscured in experimental paradigms of basic emotions, are addressed
head-on by dimensional models of affect. Dimensional models regard affective
experiences as a continuum of highly interrelated and often ambiguous states [21].
The circumplex model of emotion was developed by James Russell in 1980
[25]. This model suggests that emotions are distributed in a two-dimensional
circular space, containing arousal and valence dimensions. Arousal represents the
vertical axis and valence represents the horizontal axis, while the center of the circle
represents a neutral valence and a medium level of arousal [26]. In this model,
emotional states can be represented at any level of valence and arousal, or at a neutral
level of one or both factors. Circumplex models have been used most commonly to
test stimuli of emotion words, emotional facial expressions, and affective states [27].
An attractive feature of dimensional approaches is their parsimony and their appli-
cability across multiple domains. Dimensional approaches have also proven to be
empirically powerful, successfully accounting for a wide range of emotion effects
[28].
2.3 Emotion Measurement Using Frontal EEG Asymmetry
Electroencephalography (EEG) is one of popular physiological indicators of emotion,

beside skin conductance, pupil dilation, heart rate, and functional magnetic resonance
imaging (fMRI) [2]. It is a reliable and cost-effective technology used to measure
brain activity [1].
Brain waves are oscillating electrical voltages in the brain measuring just a few
millionths of a volt. According to [29], there are five widely recognized brain
waves, and the main frequencies of human EEG waves are: gamma (>35 Hz); beta
(12−35 Hz); alpha (8−12 Hz); theta (4−8 Hz), delta (0.5−4 Hz).
Detecting emotion using EEG signals involves multiple steps being performed in
sequence to satisfy the requirements of a brain–computer interface (BCI). Tradition-
ally, these steps include removing artifacts from EEG signals, extracting temporal or
spectral features from the EEG signal’s time or frequency domain, respectively, and
finally, designing a multi-class classification strategy. Feature quality dramatically
increases the accuracy of the emotion classification strategy [1]. The most popular
features in the context of emotion recognition from EEG are band power features
from different frequency bands (Table 1). This assumes stationarity of the signal for
the duration of a trial. Commonly used algorithm to extract the band power features
are the estimation of Power Spectral Density (PSD) [30]. Welch [31] described
the method to calculate PSD using fast Fourier transform in his publication, called
Welch’s method.
Literature studies pointed specifically to the alpha and beta frequency bands for
emotion recognitions [32]. Schubring and Schupp [33], by conducting two exper-
iments on 16−18 participant, have confirmed that high arousal is associated with
talking in alpha and lower beta band power. Beta waves are associated with a state of
an alert or excited mind, while alpha waves are more dominant in a state of relaxation.
Location in the brain is associated with different functions of brain [34]. Figure 1
illustrates the four main lobes of the human brain namely frontal lobe (including
prefrontal lobe part), parietal lobe, occipital lobe, and temporal lobe. A parietal lobe
of brain takes care of processing of nerve impulses related to senses and language
functions, and a temporal lobe is a primary organization of sensory input [35]. The
prefrontal lobe of brain, according to Blaiech et al. [36], plays a crucial role in
the regulation of emotions and conscious experience. Inactivation of the left frontal
Table 1 Five basic EEG bands

Frequency band Frequency Brain states
Gamma >35 Hz Concentration
Beta 12−35 Hz Anxiety dominant, active, external attention, relaxed
Alpha 8−12 Hz Very relaxed, passive attention
Theta 4−8 Hz Deeply relaxed, inward focused
Delta 0.5−4 Hz Sleep
Fig. 1 Human brain

structure [38]
indicates a negative emotion, and even inactivation of the right frontal indicates a
positive emotion. Thus, the frontal EEG asymmetry’s beta/alpha ratio is a reasonable
indicator of the emotional state of a person [36, 37].
3 Methods
3.1 Participant and Experimental Procedure
In our study, data from one participant (female; age 24) was recorded. The participant
had no history of any neurological, psychiatric, or hearing problems. The participant
gave written informed consent before the experiment. The experiment was performed
in accordance with the Declaration of Helsinki [40].
We used a subset of 30 video clips to evoke participant’ emotion. We selected these
videos from a database of 2,185 emotional video clips by Cowen and Keltner [41].
We focused on six categories of videos to evoke Ekman’s six basic emotions (e.g.,
sad, surprise, enjoy, disgust, anger, fear). During the experiment, the participant’
facial expressions were recorded by a camera placed above the computer screen.
At the beginning of the experiment, we explained the purpose of the study and
the procedure for conducting the experiment. Then we set up the EEG device on the
participant’ head. After we had a stable EEG signal, we showed the participant 6
groups of videos that we had selected. After each group of videos, there was a rest
time for the participant to relax and report the emotions they felt while watching the
videos.
3.2 Data Recording and Preprocessing
The Emotiv EPOC X neuroheadset (a product of Emotiv Inc) [42] was used to obtain
the necessary EEG raw data signals. The neuroheadset EPOC X is an EEG device
that benefits from the ability of the nervous tissue to generate quantifiable electric
potentials to measure brain activity. The electrodes are metallic with a plastic base and
are placed on the scalp to measure brain activity. For optimal results, the electrodes
must be wet with a few drops of a saline conductive solution to increase conductivity,
and to improve their performance [39].
The headset is equipped with a total of 14 electrodes to measure brain activity,
plus two extra electrodes that work as reference points. The electrodes are distributed
on key points of the scalp as suggested by the international system 10–20 [39] as
shown in Fig. 2. The 14 electrode positions used by the EPOC are labeled as AF3,
F7, F3, FC5, T7, P7, 01, 02, P8, T8, FC6, F4, F8, and AF4.
In this study, the EEG signal of all 14 channels was recorded in 256 Hz sampling
mode, and the raw time series data was stored by EmotivPro software as a CSV
file. Simultaneously, facial expression was recorded by a high-definition camera and
saved as video in MP4 format.
After obtaining the raw data, we used EEGLAB software [43] to preprocess the
data, including artifact removing. Artifact is any component of the EEG signal that
is not directly produced by human brain activity. EEG artifacts can be classified
depending on their origin, which can be physiological or external to the human
body (non-physiological). In our study, we used MARA (Multiple Artifact Rejection
Algorithm) plugin for artifact rejection. The core of MARA is a supervised machine
learning algorithm that learns from expert ratings of 1290 components by extracting
Fig. 2 EEG channels’

location in the brain
suggested by the
international system 10–20
[39]
Table 2 Caculating valence and arousal

Valence Argument: Positive, happy emotions result in a higher frontal coherence in alpha, and
higher right parietal beta power, compared to negative emotion [34, 36, 37]. Equation:
V alence = α F4/ β F4 − α F3/ β F3 (*)
Arousal Argument: Excitation presented a higher beta power and coherence in the parietal
lobe, plus lower alpha activity [34, 36, 37]. Equation:
α(AF3+AF4+F3+F4)
Ar ousal = β(AF3+AF4+F3+F4) (*)
(*) Where αi and βi = PSD of alpha and beta frequency range obtained from ith channel of the
EEG signal
six features from the spatial, the spectral and the temporal domain. Features were
optimized to solve the binary classification problem “reject vs. accept”. Thus, MARA
should be able to handle eye artifacts, muscular artifacts, and loose electrodes equally
well [44].
3.3 Data Analysis
The emotions that participant reported after watching each group of videos was used
to evaluate the validity of those videos. We assumed that if the reported emotion
matches the emotion the video attempts to elicit, the data collected is valid.
As mentioned in Chap. 2, brain activation by changes in emotion are mostly
captured by electrodes located in the frontal area, e.g., AF3, AF4, F3, and F4 [34]. In
this study, we extract the mean PSD feature from alpha band and beta band of these
channels using Welch’s method. Then, we calculated the value of valence and arousal
based on the equations mentioned in Table 2. We then represented these emotional
states in the valence−arousal two-dimensional space (the circumplex model).
For facial expression data, we performed a blind analysis of facial expressions
with the help of an expert in this field. The expert received the 12 recorded videos
of participant expression (6 videos for each participant) without sound and did not
know the sequence in which emotions were evoked. The expert was asked to rate and
point out which is the main emotion of participant’ facial expression in each video.
4 Results
The emotions that participant reported after watching each group of videos was used
to evaluate the validity of those videos. The results showed that all the reports that
the participant gave were consistent with the videos’ emotions. Thus, the obtained
data is valid.
Table 3 The mean PSD (sample for sadness emotion). (Due to the limited number of pages, we
only present the case of sad emotion)
Emotion Mean PSD Channel
F3 F4 AF3 AF4
Sad meanPSD_alpha 2.6205 5.4297 0.3173 3.3108
meanPSD_beta −1.2412 1.7195 −3.4945 −0.3623
Table 4 Valence—arousal calculation

Valence Arousal Valence (normalization) Arousal (normalization)
Sad 5.268984 −3.456652 0.259429587 0
Surprise −5.86238 −0.467735 0 0.710211035
Enjoy 37.04469 −0.219423 1 0.769213643
Disgust −0.30834 0.5307271 0.129443438 0.94746035
Fear 0.886882 0.5555072 0.157299522 0.953348456
Anger −0.37264 0.3482074 0.127944947 0.904090959
Using Welch’s method, we extracted the mean PSD feature from alpha band and
beta band of frontal EEG as showed in Table 3. Then, we calculated the value of
valence and arousal (Table 4). After that, we represented these emotional states in
the valence—arousal two-dimensional space. The results show that the calculated
valence and arousal values, when being mapped on the circumplex model, fit with
the model. Five out of six evoked emotions were mapped in the right corresponding
quarter region in the original model. The difference is only apparent with respect to
the emotion of surprise (Fig. 3).
For facial expression data, we performed a blind analysis of facial expressions
with the help of an expert in this field. The expert received 12 recorded videos of
participant expression (6 videos for each participant) without sound and did not know
the sequence in which emotions were evoked. The expert was asked to rate and point
out which is the main emotion of participant’ facial expression in each video. The
results showed that only disgust was transiently expressed in the facial expressions
of the participant, while for emotions of sadness, surprise, enjoyment, fear and anger,
participant only expressed her faces in neutral state (Table 5).
5 Discussion and Conclusion
The results presented in Chap. 4 strongly support the emergent opinion that, facial
expressions cannot be the reliable reflection of a person’s innermost emotions they
were once thought to be. The results of this study are not alone as there are several
Fig. 3 Mapping the six emotional states in the circumplex model (left) The six emotional states
identified by valence and arousal values in Table 4; (right) Russell’s original model
Table 5 Comparison between emotion reported by the participant. and facial expression rated by
the expert
Emotion reported by Facial expression Emotion reported by Facial expression
the participant rated by the expert the participant rated by the expert
Sad Neutral Disgust Neutral, slightly
Disgust
Surprise Neutral Fear Neutral
Enjoy Neutral Anger Neutral
other studies that agree with us, such as Barrett et al. (2019), Chen et al. (2018),
Crivelli et al. (2017), Benitez-Quiroz et al. (2018) [3, 19, 20, 45].
This opinion poses a huge challenge for AI technology companies that are working
on developing emotion recognition systems. Based on experimental results, relying
only on facial expressions to identify emotions has been shown to be unilateral.
Therefore, it is necessary to consider other expressions in gestures, behaviors, as
well as biological indicators to be able to identify emotions more accurately [15].
While facial expressions did not show sufficient reliability, our study provides
evidence that EEG signaling is a reliable tool for emotion detection and measurement.
Only with PSD feature extraction, we have succeeded in modeling emotions on
two-dimensional model of valence and arousal. This promises that EEG signal will
be widely used in emotion recognition systems as input data in the future. Also,
this simplicity, efficiency and reliability will help neuro-marketing and neuro-IS
researchers in conducting their causal studies, especially when studying emotions as
a mediating variable or a dependent variable.
Our study has limitations that need to be overcome in the future. Firstly, the data
sample is small and lacks diversity. In the future, we will try to conduct experiments
on more subjects, in diverse cultures and in more diverse experimental environments.
Second, the circumplex model is limited in clearly categorizing emotions. Valence
and arousal measurements led to the clustering of emotions presented on the circum-
plex model. Thus, the circumplex model cannot be relied on to classify emotions. In
the future, we will conduct research on models with more than two dimensions to be
able to better separate emotional states.
Third, this study only used Ekman’s 6 basic emotions in experimental design.
However, recent studies have almost found common opinion that Ekman’s six basic
emotions are not enough to generalize human emotions. For example, Cowen and
Keltner [41] have captured 27 distinct categories of emotion bridged by continuous
gradients and developed the semantic space theory of emotion which states that
emotion is high dimensional. These new findings will form the background for us to
develop future studies.
Fourth, looking at our results, when trying to map six emotions onto the circumplex
model, only the surprise emotion was in a position that doesn’t match the original
circumplex model. In the original model, the emotion of surprise has a positive
tendency (positive valence value), but in our experiment, the emotion of surprise has
a negative valence value, i.e., has a negative tendency. This leads to an interesting
question that we want to find answers to in the future: When is the emotion of surprise
positive and when is it negative?
Fifth, our study did not consider the neutral state. In our opinion, neutral means
no emotion, so it is difficult to elicit neutrality when conducting experiments. We
assume that a person can only achieve “neutral emotion” when his brain’s activity
is reduced to the maximum, that is, only when he has fallen asleep, or has been
senseless. The validity of this assumption is currently untested, and the study of
neutral emotion is an interesting topic that we will focus on in the future.
Sixth, not as simple as collecting face data, collecting EEG signals is complicated
for most normal people under normal conditions. It requires specialized equipment
and software along with meticulous installation. The inconvenience that it brings
to the user is also a big obstacle for such devices to be used in everyday life, or
even in laboratories that do not specialize in brain research. Therefore, in the future,
studies and inventions for reducing the size and increasing the convenience of EEG
measuring devices are essential. How to integrate EEG measurement sensors into
common wearable devices, such as virtual reality headsets, is not a bad idea to work
on in the future.
References
1. Gannouni, S., Aledaily, A., Belwafi, K., Aboalsamh, H.: Emotion detection using elec-
troencephalography signals and a zero-time windowing-based epoch estimation and relevant
electrode identification. Sci. Rep. 11(1), 1–17 (2021)
2. Meiselman, H.L. (Ed.): Emotion Measurement. Woodhead publishing (2016)
3. Barrett, L.F., Lewis, M., Haviland-Jones, J.M. (Eds.): Handbook of Emotions. Guilford
Publications (2016)
4. Panksepp, J: Affective Neuroscience: The Foundations of Human and Animal Emotions.
Oxford university press (2004)
5. Damasio, A.R.: Emotion in the perspective of an integrated nervous system. Brain Res. Rev.
26(2–3), 83–86 (1998)
6. Ekman, P.E., Davidson, R.J: The Nature of Emotion: Fundamental Questions. Oxford
University Press (1994)
7. Cabanac, M.: What is emotion? Behav. Proc. 60(2), 69–83 (2002)
8. Schacter, D., Gilbert, D., Wegner, D., Hood, B.M.: Psychology: European Edition. Macmillan
International Higher Education (2011)
9. Pinker, S.: How the Mind Works, vol. 524. Norton, New York (1997)
10. Zeng, Z., Pantic, M., Roisman, G.I., Huang, T.S.: A survey of affect recognition methods:
audio, visual, and spontaneous expressions. IEEE Trans. Pattern Anal. Mach. Intell. 31(1),
39–58 (2009)
11. Fasel, B., Luettin, J.: Automatic facial expression analysis: a survey. Pattern Recognit. 36,
259–275 (2003)
12. Wang, S., Liu, Z., Lv, S., Lv, Y., Wu, G., Peng, P., Wang, X.: A natural visible and infrared facial
expression database for expression recognition and emotion inference. IEEE Trans. Multimedia
12(7), 682–691 (2010)
13. Ekman, P., Sorenson, E.R., Friesen, W.V.: Pan-cultural elements in facial displays of emotion.
Science 164(3875), 86–88 (1969)
14. Ekman, P., Friesen, W.V.: Constants across cultures in the face and emotion. J. Pers. Soc.
Psychol. 17(2), 124 (1971)
15. Barrett, L.F., Adolphs, R., Marsella, S., Martinez, A.M., Pollak, S.D.: Emotional expressions
reconsidered: challenges to inferring emotion from human facial movements. Psychol. Sci.
Public Interes. 20(1), 1–68 (2019)
16. Heaven, D.: Why faces don’t always tell the truth about feelings. Nature 578(7796), 502–505
(2020)
17. Ekman, P.: Facial expression and emotion. Am. Psychol. 48(4), 384 (1993)
18. Gu, S., Wang, F., Patel, N.P., Bourgeois, J.A., Huang, J.H.: A model for basic emotions using
observations of behavior in drosophila. Front. Psychol. 781 (2019)
19. Chen, C., Crivelli, C., Garrod, O.G., Schyns, P.G., Fernández-Dols, J.M., Jack, R.E.: Distinct
facial expressions represent pain and pleasure across cultures. Proc. Natl. Acad. Sci. 115(43),
E10013–E10021 (2018)
20. Crivelli, C., Russell, J.A., Jarillo, S., Fernández-Dols, J.M.: Recognizing spontaneous facial
expressions of emotion in a small-scale society of Papua new Guinea. Emotion 17(2), 337
(2017)
21. Posner, J., Russell, J.A., Peterson, B.S.: The circumplex model of affect: an integrative approach
to affective neuroscience, cognitive development, and psychopathology. Dev. Psychopathol.
17(3), 715–734 (2005)
22. Toisoul, A., Kossaifi, J., Bulat, A., Tzimiropoulos, G., Pantic, M.: Estimation of continuous
valence and arousal levels from faces in naturalistic conditions. Nat. Mach. Intell. 3(1), 42–50
(2021)
23. Russell, J.A., Carroll, J.M.: On the bipolarity of positive and negative affect. Psychol. Bull.
125(1), 3 (1999)
24. Watson, D., Clark, L.A.: Affects separable and inseparable: on the hierarchical arrangement of
the negative affects. J. Pers. Soc. Psychol. 62(3), 489 (1992)
25. Russell, J.A.: A circumplex model of affect. J. Pers. Soc. Psychol. 39(6), 1161 (1980)
26. Rubin, D.C., Talarico, J.M.: A comparison of dimensional models of emotion: evidence from
emotions, prototypical events, autobiographical memories, and words. Memory 17(8), 802–808
(2009)
27. Remington, N.A., Fabrigar, L.R., Visser, P.S.: Reexamining the circumplex model of affect. J.
Pers. Soc. Psychol. 79(2), 286 (2000)
28. Hamann, S.: Mapping discrete and dimensional emotions onto the brain: controversies and
consensus. Trends Cogn. Sci. 16(9), 458–466 (2012)
29. Abhang, P.A., Gawali, B.W., Mehrotra, S.C.: Technological basics of EEG recording and opera-
tion of apparatus. In: Introduction to EEG-and Speech-Based Emotion Recognition, pp. 19−50
(2016)
30. Jenke, R., Peer, A., Buss, M.: Feature extraction and selection for emotion recognition from
EEG. IEEE Trans. Affect. Comput. 5(3), 327–339 (2014)
31. Welch, P.: The use of fast fourier transform for the estimation of power spectra: a method based
on time averaging over short, modified periodograms. IEEE Trans. Audio Electroacoust. 15(2),
70–73 (1967)
32. Bos, D.O.: EEG-based emotion recognition. Influ. Vis. Audit. Stimuli 56(3), 1–17 (2006)
33. Schubring, D., Schupp, H.T.: Emotion and brain oscillations: high arousal is associated with
decreases in alpha-and lower beta-band power. Cereb. Cortex 31(3), 1597–1608 (2021)
34. Hwang, S., Jebelli, H., Choi, B., Choi, M., Lee, S.: Measuring workers’ emotional state during
construction tasks using wearable EEG. J. Constr. Eng. Manag. 144(7), 04018050 (2018)
35. Rusinov, V.S.: Electrophysiology of the Central Nervous System. Springer Science & Business
Media, (2012)
36. Blaiech, H., Neji, M., Wali, A., Alimi, A.M.: Emotion recognition by analysis of EEG signals.
In: 13th International Conference on Hybrid Intelligent Systems (HIS 2013), pp. 312−318.
IEEE (2013, December)
37. Ramirez, R., Vamvakousis, Z.: Detecting emotion from EEG signals using the emotive epoc
device. In: International Conference on Brain Informatics, pp. 175−184. Springer, Berlin,
Heidelberg (2012)
38. Kim, H.S., Lee, J.H.: Neuro-scientific approach to fashion visual merchandising-comparison
of brain activation to positive/negative VM in fashion store using fNIRS. J. Korean Soc. Cloth.
Text. 41(2), 254–265 (2017)
39. Benitez, D.S., Toscano, S., Silva, A.: On the use of the Emotiv EPOC neuroheadset as a
low cost alternative for EEG signal acquisition. In: 2016 IEEE Colombian Conference on
Communications and Computing (COLCOM), IEEE, 1−6 April 2016
40. General Assembly of the World Medical Association: World medical association declaration
of helsinki: ethical principles for medical research involving human subjects. J. Am. Coll. E
Dent. 81(3), 14–18 (2014)
41. Cowen, A.S., Keltner, D.: Self-report captures 27 distinct categories of emotion bridged by
continuous gradients. Proc. Natl. Acad. Sci. 114(38), E7900–E7909 (2017)
42. Available: https://www.emotiv.com/
43. Brunner, C., Delorme, A., Makeig, S.: Eeglaban open source matlab toolbox for electro-
physiological research. Biomed. Eng./Biomed. Tech. 58(SI-1-Track-G), 000010151520134182
(2013)
44. Winkler, I., Haufe, S., Tangermann, M.: Automatic classification of artifactual ICA-components
for artifact removal in EEG signals. Behav. Brain Funct. 7(1), 1–15 (2011)
45. Benitez-Quiroz, C.F., Srinivasan, R., Martinez, A.M.: Facial color is an efficient mechanism
to visually transmit emotion. Proc. Natl. Acad. Sci. 115(14), 3581–3586 (2018)
NSGA-II-AMO: A Faster Genetic
Algorithm for QWSCP
Zehui Feng, Bei Wang, Mingjian Chen, and Qi Chen
Abstract The task of the QoS-driven web service composition problem (QWSCP)
is to find the optimal combination of atomic web services to meet the high demand
for QoS parameters. However, different scenarios have various sensitivities to each
parameter, researchers prefer algorithms that solve the problem to output non-
dominated solution sets. NSGA-II, a genetic algorithm, has become one of the most
contacted algorithms for solving the QWSCP problem due to its ability to search
for non-dominated solution sets. However, NSGA-II algorithm still suffers from the
challenge of slow convergence and the tendency to fall into local optimum solutions.
In adjusting the NSGA-II mutation probabilities, it was found that the setting of the
mutation probabilities affects the effectiveness of the algorithm, and that the optimal
mutation probabilities for different loci are related to the distribution of data for that
locus. Therefore, this paper proposes an improved NSGA-II-AMO algorithm, which
uses an adaptive mutation operator to complete the mutation process when generat-
ing children in the NSGA-II algorithm, so that the mutation probability adaptively
changes with different distributions of data, effectively improving the search speed
at the beginning of population iteration; at the same time, in order to avoid the prob-
lem of oscillatory search at a later stage, AMO reduces the mutation probability as
the population converges, preventing the re-introduction of inferior genes into the
Z. Feng
Polytechnic Institude, Zhejiang University, Hangzhou, China
e-mail: zju_fengzehui@163.com
B. Wang · M. Chen · Q. Chen (B)
College of Computer Science and Technology, Zhejiang University, Hangzhou, China
e-mail: zju_chenqi@163.com
B. Wang
e-mail: wangbei@zju.edu.cn
M. Chen
e-mail: chenmj01@163.com
https://doi.org/10.1007/978-3-031-19604-1_15
204 Z. Feng et al.
population. We compare the NSGA-II-AMO algorithm cross-sectionally with the

PSO algorithm, the NSGA-II algorithm and the ABC algorithm, and the adaptive
mutation operator achieves improved convergence with guaranteed distributivity.
Keywords QoS-driven · Service composition · NSGA-II · Adaptive mutation

operator
1 Introduction
With the rapid growth of the Internet and the increasing complexity of web service
requirements, service composition has become mainstream [1, 2]. How to select and
combine a cluster of atomized services with high throughput, high availability, high
reliability, low cost and low latency among the huge number of atomized services
has become a hot issue of concern for the academic community [3]. An excellent
selection, combination and filtering algorithm, mechanism, system and scheme can
greatly assist in the rapid construction of services to achieve a portfolio of services
with high Quality of Service (QoS) values. The task of QWSCP can be described as
selecting a set of atomic services from a given set of optional atomicity services, such
that the combined set of atomic services fulfils the functional requirements of the
user while also having QoS parameters that satisfy the non-functional requirements
of the user.
A large body of works have been proposed to solve the service composition prob-
lem, mainly in the form of linear integer programming model (LIPM) methods,
Metaheuristic-based methods and Multi-objective optimization methods. The LIPM
approach treats the service composition problem as a linear integer programming
model that allows an optimal composition to be found [4, 5]. In the metaheuris-
tic approach, the service composition problem is then treated as a single-objective
optimization problem (SOOP) [6, 7], which returns an optimal or near-optimal solu-
tion. However, the evaluation of service composition solutions is personalized and
the importance of each QoS parameter is different in different business scenarios
and software styles. For example, high real-time and low latency in some scenarios,
and high reliability and availability in others. Therefore the ability of the above two
service composition solutions with a single output solution to meet the mutually
exclusive needs of the users is highly dependent on the expertise of the decision
maker and the design of the QoS parameter weights. For these reasons, more and
more researchers are beginning to view service composition as a multi-objective
optimization problem.
In this paper, the NSGA-II-AMO algorithm is proposed to solve the service com-
position problem, and three adaptive mutation operators are proposed according to
the data distribution of each gene locus, bringing an improvement in the convergence
effect while ensuring the distributional effect of the genetic algorithm.
NSGA-II-AMO: A Faster Genetic Algorithm for QWSCP 205
2 Related Work
In recent years, the number of service composition has grown rapidly to meet the
needs of users, and how to quickly and efficiently achieve a reasonable selection
of combined services from optional atomic service composition has become the
focus of many scholars’ research. Yin et al. [8] proposed a service composition
optimization model that considers eight QoS variables, such as response time, quality
of service, cost, availability, and concordance, and uses grey correlation analysis to
obtain the correlation between these QoS attributes so that the QoS metrics of the
combined solution can be improved. Yu [9] proposed a computational model that
can calculate skylines according to a service composition model, enabling service
users to optimally access a service set in the form of an integrated service package,
first by a one-pass algorithm determined entirely by a single service skyline, and
then using a double asymptotic algorithm A comparison is made to give the optimal
skyline composition of services.
However, as the above methods can only produce a single solution, more and
more multi-objective optimization methods are being proposed to solve the QWSCP
problem. The main advantage of multi-objective optimization methods is that this
class of methods ultimately outputs a set of non-dominated solutions from which
the user can select the non-dominated solution that best meets his or her needs.
Among them, multi-objective genetic algorithms have been extensively studied to
optimize multi-objective parameters simultaneously to solve service composition
problems [10]. For example, Niu et al. [11] modelled the process of constructing a
service composition as a constrained interval number multi-objective optimization
problem and proposed a decomposition-based uncertain multi-objective evolutionary
algorithm , which was used to build a mathematical model to calculate the optimal
service portfolio. Meanwhile, researchers have proposed some multi-objective ver-
sions of meta-heuristic single-objective optimization algorithms to solve the service
composition problem. For example, Sadouki et al. [12] proposed a multi-objective
version of an elephant grazing optimization algorithm; Wang [13] et al. proposed
a QoS-aware service-selection-specific algorithm based on the artificial bee colony
algorithm (ABC) in the discrete space for efficient local search. However, the above
multi-objective optimization algorithm requires the decision maker to set the vari-
ance probability, too large a variance probability will lead to oscillation in the final
stage of the search, too small a variance probability will cause the search process to
stall prematurely. The convergence effect of the above multi-objective optimization
method is extremely demanding in terms of matching the variance probability to the
data samples, which makes it difficult to meet the convergence requirements of the
user when performing service compositions.
206 Z. Feng et al.
3 Problem Formulation
The task of QoS-driven web service composition problem is to select specific services
to be filled into each node of the combined service, so that the combined service has
the best possible QoS parameters. When viewed as a multi-objective optimization
problem, this problem can be described as the following 5-tuple (P, S, Ω, F(x), R)
with the components shown below.
• P is the concrete process of the combined service, ( p1 , p2 , · · · , pn ) describes the

abstract atomic service types of n nodes which the combined service consists of.
• S is the set of optional subservices, each with an abstract service type and QoS
parameters.
• Ω is the space where the decision vector x = (x1 , x2 , · · · , xn ) located in. The
vector x represents the subservices (s1 , s2 , · · · , sn ) selected in turn for combining
each node of the combined service, where s1 , s2 , · · · , sn ∈ S. Also, si and pi have
the same abstract service type, which means they can perform similar functions.
• F(x) = ( f 1 (x), f 2 (x), ..., f m (x)), is the specific optimization objective, where m
is the number of QoS parameters and x ∈ Ω. In this problem, the optimization
objective can be expressed as max F(x) by operations such as data normaliza-
tion. In our research, four QoS parameters were selected: availability, reliability,
response time and throughput, so m = 4.
• R is the set of results, R = (x1 , x2 , · · · , xw ), where x1 , x2 , · · · , xw ∈ Ω and are
non-dominated relations with each other. w is the number of individuals in this
non-dominated solution.
The key of QoS-driven web service composition problem is to make the F of the
members in R as big as possible, given that P, S, Ω and F(x) are determined. As
stated above, different users have different sensitivities and needs for different F(x).
In most cases, however, it is difficult to find a xi , such that all four dimensions of
F(xi ) are optimal, but rather only a set of x for which F(x) has different dominance,
so the problem ultimately requires that the output set of results R is a non-dominated
set of x.
4 Our Solution
We propose the NSGA-II-AMO algorithm to solve the QoS-driven web service

composition problem. NSGA-II-AMO is an improvement on the NSGA-II algorithm.
NSGA-II improves the fitness of a population by constructing a population full
of competition, through elimination, crossover and mutation over and over again.
In applying the NSGA-II algorithm to solve QoS-driven web service composition
problem, each decision vector x is considered as an individual, each part on vector
x is considered as a genetic loci of the individual, and the set of multiple decision
vectors x is considered as a population.
The main flow of the NSGA-II-AMO algorithm is as follows:

Step 1: Primary population production
Set the number of primary populations to N . This step randomly generates N
decision variables (x1 , x2 , · · · , x N ) as the incipient parent population P0 , where
x1 , x2 , · · · , x N ∈ Ω.
Step 2: Generation of children
Select two individuals as parents from the parent population Pt and generation a new
child by parental crossover. Then repeat until N children individuals are produced to
form the children population Q t . At the same time, there is a probability of variation
during the generation of individuals, expanding the search area. It is important to
set the probability of variation in the generation of children. A large probability of
variation can lead to the replacement of introduced superior genes by inferior genes,
causing oscillatory search in the late convergence period; a too small probability
of variation can make it difficult to introduce optional superior genes from outside
the population and stall the search process prematurely. When the probability of
variation is the same for all loci, this value is too large for some loci and too small
for another, making it difficult to achieve good convergence. Therefore, this paper
proposes three adaptive mutation operators (AMO) that calculate the probability of
variation separately according to the data distribution of each locus.
• AMO1: We first design an adaptive mutation operator based on the number of
selectable genes at each locus, which calculates the probability of mutation for
each locus as in:
num − min
λ1 = exp − 0.5 λ0 (1)
max − min
where num is the number of genes available for the locus, max and min are the
maximum and minimum values of the number of genes available for all loci,
respectively, and λ0 is the base variation probability, usually set to 0.05. In AMO1,
the probability of mutation is simply related to the number of available genes at
each locus, with the larger the number, the higher the probability of mutation.
• AMO2: We designed AMO2 by considering the effect of the degree of data dis-
persion, which calculates the probability of mutation for each locus as in:

n
si
λ2 = (2)
i=1
QoSi
where n is the number of QoS parameters, 4 in this experiment; si is the standard

deviation of the ith parameter for that locus and QoSi is the mean. λ2 reflects
the data dispersion for each locus, the greater the data dispersion, the greater the
probability of variation.
• AMO3: As mentioned earlier, when using a fixed variation probability, too large a
variation probability at a later stage can cause oscillatory search problems, so we
designed AMO3 with a negative correlation between the variation probability and
208 Z. Feng et al.
the number of Generations to solve this problem, which calculates the probability
of mutation for each locus as in:
λ3 = (exp(−gen/40) + 0.5)λ2 (3)
where gen is the number of generations. AMO3 has a progressively lower prob-
ability of variation as the number of population generations increases, based on
AMO2 considering the degree of dispersion.
Step 3: Combine Pt and Q t into a new population Rt

NSGA-II adopts a retention strategy for the parent, and the new generation population
Rt consists of the parent population Pt and the offspring population Q t combined,
i.e. Rt = Pt ∪ Q t .
Step 4: Sorting
An undominated sort is performed on Rt , and a further crowding sort is performed
on individuals of the same undominated rank. These two kinds of sorting ensure the
richness of the population, allowing the search for the optimal solution to remain in
different directions.
Since the results of the ranking are seriously affected by the different magnitudes
of the different QoS in the process of crowding sorting, the data need to be normalized.
In our paper, we use a min-max normalization as in:
QoS − min
QoS+ = (4)
max − min
QoS − min
QoS− = 1 − (5)
max − min
where QoS+ and QoS− are the results after data normalization, QoS is the original
value before normalization, max is the maximum value of the parameter and min
is the minimum value of the parameter. Equation (4) is used for larger and better
QoS parameters, such as reliability, availability and throughput, and Equation (5) is
used for smaller and better QoS parameters, such as response time. After the above
data normalization operation, all four QoS parameters were converted to parameters
whose values were distributed within [0, 1] and the larger the better, eliminating the
influence of the different parameter’s magnitudes on the ranking.
When sorting, we need to calculate the QoS parameters of the services after the
combination by using the QoS parameters of the atomic services. It is worth noting
that the calculation of this step varies with the topology of the services. The topology
of the services can be divided into four main types: sequence, cyclic, parallel and
branch, whose topology and calculation are shown in Fig. 1 and Table 1.
Step 5: Select the first half of the individuals in Rt to form a new parent population
Pt+1
The algorithm will repeat step 2–step 5, increasing the fitness of the population
through continuous filtering. When the end condition is reached, (e.g. the fitness
Fig. 1 Example of four topologies
Table 1 QoS calculation for four topologies

Sequence Cyclic Parallel Branch
n n n
Reliability R Ri Rn Ri pi Ri
i=1 i=1 i=1

n
n n
Availability A Ai An Ai pi Ai
i=1 i=1 i=1
n T n T n
Throughtout T Mini=1 n T Mini=1 n pi Ti
i=1

n n
Response time RTi n ∗ RT n
Maxi=1 RTn pi RTi
RT i=1 i=1
has converged or the number of iterations has been reached, etc.), the final set of
non-dominated solutions of the filtered population is output.
5 Algorithm Implementation and Results
5.1 Dataset
The dataset used in this paper is the QWS Dataset Version 2.0, which collects infor-
mation on 2507 web services, containing eleven attributes for each service and a
functional classification. The four QoS parameters of availability, reliability, response
210 Z. Feng et al.
time and throughput for each service are used in this study, while services with the
same functional classification are considered as atomic services with similar func-
tions.
5.2 Evaluation Indicators
This paper uses 2 metrics recognized in the field for the evaluation of multi-objective
optimization problems, a measure of their convergence and a measure of their pop-
ulation diversity [14].
• Convergence indicator
The convergence indicators are evaluated as in:

n
r= di /n (6)
i=1
where n is the number of solution vectors in the final output non-dominated solu-
tion set; di is the Euclidean distance between each solution vector in the obtained
non-dominated solution set and the nearest member of the true Pareto front (mea-
sured in the optimization objective parameter space after data normalization). This
indicator mainly reflects the convergence effect of the multi-objective optimization
algorithm. The lower the value of r , the better the population convergence.
• Distributional Indicator
The distributional indicators are evaluated as in:
n−1
di
d = i=1 (7)
n−1
n−1
d f + dl + i=1 di − d̄
Δ= (8)
d f + dl + (n − 1)d
where di is the Euclidean distance between the ith individual and the (i + 1)st
individual in the final output set of non-dominated solutions, d f and dl represent
the distance between the extreme value solution of the true Pareto frontier and the
solution at the boundary of the output set, and d is the average of di . As mentioned
earlier, the importance attached to different parameters varies from scenario to
scenario, users tend to expect a better distribution of the solution set obtained. The
smaller the value of Δ, the better the distribution.
Fig. 2 Data pre-processing

effect
5.3 Data Pre-process
In the set S of atomic services, the number of atomic services providing the same
function is quite large. If there exist atomic services si and s j , satisfying Q r (si ) ≤
Q r (s j ), Q a (si ) ≤ Q a (s j ), Q t (si ) ≤ Q t (s j ), Q r t (si ) ≤ Q r t (s j ), it means that si does
not exceed s j in all four QoS parameters, in other words, si is an inferior gene at
that locus, and selecting si will result in an individual with inferior QoS parameters
to selecting s j of similar individuals and should therefore be eliminated directly.
Therefore, during the data pre-processing process, the skyline algorithm was used to
eliminate inferior genes like si . The above data pre-processing operation can greatly
improve the speed of population convergence.
Figure 2 shows the effect of data pre-processing on the speed of population con-
vergence. It can be seen that when no data pre-processing is performed, the initial
population convergence index is very poor due to the large number of “inferior”
genes incorporated into the initial population generation, and it takes fifty iterations
before the initial pre-processed population converges.
5.4 Selection of the Initial Population Size N
This section verifies the effect of the initial number of populations N on the con-
vergence effect. To ensure the fairness of the experiment, the experiment tests the
metrics of the output non-dominated solution set after the same running conditions
and running time. The setting of the initial number of populations, N , must have an
effect on the convergence effect. When N is too large, the number of computations
will increase in non-polynomial time, resulting in fewer iterations and slower con-
vergence in the same time; when N is too small, a large number of initial populations
cannot enter the initial population, resulting in low genetic richness of the popula-
tion itself. Therefore, in this section set the N values to 60, 80, 100, 120, 140. The
experimental results are shown in Table 2.
As can be seen from Table 2, the distributional indicator gradually becomes better
as the population size increases, while the convergence indicator becomes better in
212 Z. Feng et al.
Table 2 Convergence for different values of N

PSO ABC NSGA-II NSGA-II-
AMO3(ours)
r 0.0455 0.0356 0.0397 0.0367
Δ 0.3428 0.2787 0.2531 0.2501
Table 3 Results for different AMO

p mutation Fixed AMO1 AMO2 AMO3
operator
r 0.0397 0.0391 0.0382 0.0367
Δ 0.2531 0.2544 0.2511 0.2501
60–80 and worse in 80–140. It is also worth noting that changes in N values have a
greater impact on r , with the difference between the best and worst reaching 8.43%,
while the impact on is smaller, with the difference between the best and worst being
only 1.42%. Therefore, the initial population size N was set to 80 in the subsequent
experiments.
5.5 Selection of AMO
We propose three adaptive mutation operators: AMO1 is a consideration of the num-

ber of optional genes, and the probability of variation increases with increasing
number; AMO2 is a consideration of the data dispersion of optional genes, and the
greater the data dispersion, the higher the probability of variation; AMO3 adds a
consideration of the current generation to AMO2, and the probability of variation
gradually decreases with increasing population generation. Similarly, we conduct
experiments on the QWS dataset, which will use the NSGA-II algorithm of fixed
mutation value and three AMOs run for the same time under the same conditions,
for which the r and Δ values of the non-dominated set (Table 3).
It can be seen that all three variational operators achieve an improvement in r
values, especially AMO2 and AMO3, which improve in both metrics as they take
into account the degree of data dispersion and can mitigate the effects of local optimal
solutions. On the comparison between AMO2 and AMO3, it can be seen that AMO3
works better. AMO3 is 3.93% ahead of AMO2 in r value and 0.40% ahead in value.
From the calculation of the variation probabilities of amo2 and amo3, it can be
seen that the variation probability of AMO3 is higher than that of AMO2 before
27 generations, while the opposite is true after 27 generations. In other words, in
the early stages of convergence, when a large number of “good” genes have not yet
entered the population, AMO3 has a higher probability of mutation and can introduce
these genes faster; while after a period of convergence, AMO3 has a lower probability
Table 4 Results for different algorithms

N 60 80 100 120 140
r 0.0401 0.0397 0.0398 0.0422 0.0427
Δ 0.2535 0.2531 0.2511 0.2517 0.2499
of mutation and can effectively prevent shock search or mutation to produce “bad”
genes. Therefore, AMO3 has a better convergence effect than AMO2.
5.6 Comparison with Other Algorithms
The NSGA-II algorithm, the Particle Swarm optimization (PSO) algorithm and the
Artificial bee colony(ABC) algorithm were selected as comparison algorithms and
tested in the same way to compare their r and Δ values.
As can be seen from Table 4, thanks to the application of AMO3, the Δ value of our
method compared to NSGA-II improved from 0.2531 to 0.2501, an improvement of
1.19%, and the r value improved from 0.0397 to 0.0367, an improvement of 7.56%.
The main reason for this improvement is that our adaptive variation operator takes into
account the effects of data distribution and population generation, and the variation
probabilities are changed adaptively so that the variation probabilities at each locus
match the current data distribution and iteration level more closely at all times, and
therefore converge better during the iteration. Compared to the ABC algorithm, our
algorithm lags behind in r value by 3.00%, but improves in Δ from 0.2787 to 0.2501,
an improvement of 10.26%. In other words, our algorithm suffers from a relatively
small lag in convergence relative to the ABC algorithm, but has a large advantage in
distributivity. The main reason for this effect is that our algorithm devotes a significant
amount of computational time to ensuring distributivity, including the non-dominated
sorting and congestion sorting processes at each iteration. As we stated earlier, users
of the combined service have different needs for the four parameters of the service,
so a better population richness helps to match the needs of a more diverse set of
users.
6 Conclusion
In this paper, we propose the NSGA-II-AMO algorithm, which adds an adaptive

variation operator to the NSGA-II algorithm, allowing the variation probability to
change adaptively and dynamically with the data distribution and the number of
population iterations. Thanks to the introduction of AMO, our algorithm achieves
a 7.56% improvement in convergence compared to the original NSGA-II algorithm
214 Z. Feng et al.
on the QWS dataset, with a 1.19% improvement in distributivity, and performs well
against other algorithms. Overall, our algorithm achieves an improvement in conver-
gence speed while maintaining distributivity.
Acknowledgements This research is funded by the National Key Research and Development
Program of China (Grant No. 2018YFB2101200) and ZJU-Guangxi Province Collaborative Project
(Grant No. ZD20302004).
References
1. Yuan, Y., Zhang, W.S., Zhang, X.G.: A context-aware self-adaptation approach for web ser-
vice composition. In: 2018 3rd International Conference on Information Systems Engineering
(ICISE), pp. 33–38 (2018)
2. Gustavo, A.: Review: Perspectives on web services—applying SOAP, WSDL and UDDI to
Real-World Projects. IEEE Internet Comput. 47, 505–505 (2018)
3. Jatoth, C., Gangadharan, G., Buyya, R.: Computational intelligence based QoS-aware Web
service composition: A systematic literature review. IEEE Trans. Serv. Comput. 10, 475–492
(2015)
4. Ghobaei-Arani, M., Souri, A.: LP-WSC: A linear programming approach for Web service
composition in geographically distributed cloud environments. J. Supercomput. 75, 2603–2628
(2019)
5. Alrifai, M., Risse, T., Nejdl, W.: A hybrid approach for efficient web service composition with
end-to-end QoS constraints. ACM Trans. Web 6(2), 7 (2012)
6. Dahan, F., El Hindi, K., Ghoneim, A.: Enhanced artificial bee colony algorithm for QoS-aware
Web service selection problem. Computing 99, 507–517 (2017)
7. Huo, Y., Zhuang, Y., Gu, J., Ni, S., Xue, Y.: Discrete gbest-guided artificial bee colony algorithm
for cloud service composition. Appl. Intell. 42, 661–678 (2015); (Int. J. Artif. Intell. Neural
Netw. Complex Probl. Solving Technol.)
8. Yin, C., Zhang, Y., Zhong, T.: Optimization model of cloud manufacturing service resource
combination for new product development. Comput. Integr. Manuf. Syst. 18, 1368–1378 (2012)
9. Yu, Q., Bouguettaya, A.: Computing service Skylines over sets of services. In: Proceedings
of the IEEE International Conference Web Services. IEEE Computer Society, pp. 481–488.
Washington DC (2017)
10. Cremene, M., Suciu, M., Pallez, D., et al.: Comparative analysis of multi-objective evolutionary
algorithms for QoS-aware web service composition. Appl. Soft Comput. 39, 124–139 (2016)
11. Niu, S., Zou, G., Gan, Y., et al.: Towards uncertain QoS-aware service composition via multi-
objective optimization. In: IEEE 24th International Conference Web Service, 25–30 June 2017,
pp. 894–897. IEEE, Honolulu, HI, USA (2017)
12. Sadouki, S.C., Tari, A.: Multi-objective and discrete elephants herding optimization algorithm
for QoS aware web service composition. RAIRO-Oper. Res. 53, 445–459 (2019)
13. Wang, X.Z., Wang, Z.J., & Xu, X.F.: An improved artificial bee colony approach to QoS-aware
service selection. In: Proceedings of the 20th IEEE International Conference Web Service.
IEEE Computer Society, pp. 395–402. Washington DC (2013)
14. Seghir, F.: FDMOABC: Fuzzy discrete multi-objective artificial bee colony approach for solv-
ing the non-deterministic QoS-driven web service composition problem. Expert Syst. Appl.
167, 114413 (2021)
Author Index
B Im, Euntack, 173

Bossard, Antoine, 1
K
C Kim, Dongcheol, 107
Chen, Mingjian, 203 Kim, Jisook, 189
Chen, Qi, 203 Kim, Taeyeon, 107
Kun, Yangyoung, 189
Kwon, Jaehwan, 107
D
Du, Weiwei, 77
Du, Yi, 77 L
Lee, Dain, 161
Lee, Heewon, 121
E Lee, Hoo-Ki, 161
Endo, Toshio, 89 Lee, Jina, 173
Lee, Joong Ho, 145
Lee, Minwoo, 121
F Lee, Saeyeon, 121
Feng, Zehui, 203
N
G Nakanishi, Takafumi, 31
Gim, Gwangyong, 107, 121, 173, 189 Nakano, Satoshi, 59
Noji, Yuto, 31
H
Han, Sung-Hwa, 135 O
Hirofuchi, Takahiro, 89 Oikawa, Shuichi, 45
Hou, Shuang, 77 Okada, Ryotaro, 31
Huang, Hexi, 13
P
I Peng, Yahui, 77
Ikegami, Tsutomu, 89 Phuong, Huy Tung, 189
© The Editor(s) (if applicable) and The Author(s), under exclusive license 215
to Springer Nature Switzerland AG 2023
https://doi.org/10.1007/978-3-031-19604-1
216 Author Index
W Yue, Haizhen, 77
Wang, Bei, 203
Wang, Chenyu, 89
Y Z
Yeo, Inmo, 173 Zhao, Xuzhi, 77

Software Engineering Ai Networking Computing

Uploaded by

Copyright:

Available Formats

You might also like

Software Engineering Ai Networking Computing

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Software Engineering Ai Networking Computing

Uploaded by

Copyright:

Available Formats

Studies in Computational Intelligence 1074

ISSN 1860-949X ISSN 1860-9503 (electronic)

The purpose of the 23rd ACIS International Summer Conference on Software

In the chapter “Distance Based Clustering in Wireless Sensor Network”, Joong Ho

Mount Pleasant, USA Roger Lee

A-IDE: A Non-intrusive Cross-Platform Development

Confidential Documents Sharing Model Based on Blockchain

Author Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215

Antoine Bossard Graduate School of Science, Kanagawa University, Hiratsuka,

Euntack Im Department of Business Administration, Soongsil University, Seoul,

Huy Tung Phuong Department of Business Administration, Soongsil University,

Abstract Minimalistic devices such as microcontrollers make a large part of the

Keywords Microcontroller · Sensor · Atmel · Microchip · Arduino · 8-bit ·

© The Author(s), under exclusive license to Springer Nature Switzerland AG 2023 1

3.1 The User Interface

Because education is one important objective of microcontroller programming, A-

3.2 The Edition Component

as presented earlier. This is an important feature especially when debugging: error

3.3 The Build and Upload Component

3.3.2 Additional Technical Details

3.4 System Requirements

As mentioned previously, the realised system is cross-platform: thanks to the Racket

4 Comparison to Related Systems and Evaluation

installation package after installation

A-IDE + tool chain Arduino IDE Microchip Studio

Abstract VR sickness is a symptom that similar to motion sickness such as strong

Keywords VR sickness · Virtual horizontal frame · Field of view · SSQ

© The Author(s), under exclusive license to Springer Nature Switzerland AG 2023 13

2.1 Reduce VR Sickness Caused by VR Content

First of all, it is necessary to understand VR sickness in order to reduce VR sickness.

2.2 Realized by Video Processing Without Using Auxiliary

As a method of reducing VR sickness, a method of using an external stimulus to

2.3 Compare Virtual Frames and Verify the Effect

2.4 Prove that It Works for Various Contents

4 Development of Virtual Horizontal Frame

A virtual horizontal frame created by Unity is displayed on the VR screen to reduce

4.1 Creating a Coaster

Fig. 2 Yaw, pitch, and roll axis course

Fig. 3 Shooting coaster

4.2 Virtual Horizontal Frame

Fig. 4 Action game

4.3 Omnidirectional Virtual Frame

Fig. 5 Virtual horizontal frame

Fig. 6 Omnidirectional virtual frame

4.4 Horizontal Sensation Retention Frame with Limited

Fig. 7 Horizontal sensation retention frame with limited visual field

5.1 Experimental Method

5.2 SSQ Measurement

SSQ (Simulator Sickness Questionnaire) is one of the indicators of VR sickness.

Table 1 Subjective evaluation items of SSQ

TS = 3.74 × (total of 16 ratings of N, O, D) (2)

In this study, cerebral blood flow is used as a physiological index of VR sickness,

Fig. 8 [Coaster α] Average of each item of SSQ

Fig. 9 [Coaster β] Average of each item of SSQ

Fig. 10 [Shooting game] Average of each item of SSQ

Fig. 11 [Action game] Average of each item of SSQ

experiencing each content displays a virtual frame. In other words, VR sickness

Yuto Noji, Ryotaro Okada, and Takafumi Nakanishi
