APMR

SKM Packaged Air Conditioners
APMR Series - R-410A

R-410A
APMR Series
Packaged Air conditioners
Range 5 TR to 54 TR
(18 kW to 190 kW)
Sharjah Economic Excellence

facebook.com/skmaircon @skmaircon Award winner
www.skmaircon.com 1
AIR CONDITIONING EQUIPMENT
Contents
Introduction........................................2 Fan Performance Data....................15
Legend..............................................2 Field Connections............................17 Introduction
Nomenclature....................................2 Field Wiring Requirement Schem... 17
Component Features.........................3 Typical Wiring Diagram...................18 SKM APMR Series Packaged Air Conditioners
Optional Features............................. 6 Electrical Data.................................19 are designed and manufactured to meet the
Selection Procedure..........................8 Filters and Weights..........................21 requirements of the Gulfs severe climatic
Engineering Specifications 50Hz.......9 Dimensional Data............................22 conditions and are built specifically for outdoor
Engineering Specifications 60Hz.....10 Installation & Space Requirement. 25 installations, either on ground or roof level.
Capacity Ratings 50Hz....................11 Guide Specifications........................26
Capacity Ratings 60Hz....................13
The APMR Series Packaged Air Conditioners
are ideal for warehouses, large halls, schools,
mosques, or wherever the requirement is for
a heavy duty unit with a hermetic compressor.
APMR Series Air cooled package (hermetic

scroll) are available in 32 models covering
Legend nominal capacity ranges from 5 TR – 54 TR (18
kW to 190 kW) in 50Hz and 60Hz.
The following legends are used throughout this manual:
AFR.......Air Flow Rate MBh........BTUH x 1000 APMR units are designed to operate in a wide
BPF.......By-pass Factor Ph...........Phase ambient temperature range from 50°F(10°C) to
C.Cap.... Cooling Capacity Pa...........Pascal 120°F (48.9°C) and even lower if an optional
CFM...... Cubic feet per minute PD..........Pressure Drop head pressure control system is provided .
EER.......Energy Efficiency Ratio PI...........Compressor Power Input in kW
Hz..........Hertz RPM.......Revolutions per Minute
in.wg......inches of water gauge RPS........Rated Power Supply
kW..........Kilowatt TR..........Tons of refrigeration = 12 MBh APMR units are designed and rated
Kg...........Kilogram V.............Volts in accordance with AHRI-210/240 and
lbs..........Pounds weight (British units) FPI.........Fins per Inch 340/360 standards.
L/s..........Liters per second
APMR Series Packaged Air Conditioners are

completely assembled, internally wired, charged
with R-410A refrigerant at factory, tested before
despatch and ready for installation. All that is
Nomenclature required on site is connecting ducting and
power supply. This greatly reduces installation
A P M R - 5 1 009 work and costs. They are designed for ducted
systems which will enable them to be installed
on roof tops or on the ground.
SKM provides qualified service and stocks

Nominal Capacity in TR
of replacement parts in all major cities of the
1: Single Circuit G.C.C. countries, Egypt, Jordan, and Pakistan.
2: Double Circuit See back cover for details or call SKM.
5= 50 Hz & 6=60 Hz
R410A
Scroll Compressor
Package
Air Cooled
SKM Air Conditioning LLC
SKM reserves the right to change, in part or in

whole the specifications of its Air Conditioning
Equipment at any time in order to add the latest
technology. Therefore, the enclosed information
may change without any prior notice.
You name it.....We cool it

2
General Features Condenser

The APMR Series Packaged Air Conditioners is yet another unique Condenser coils are manufactured of seamless copper tubes
series from SKM incorporating a high efficiency cooling coil, heavy mechanically bonded to aluminum fins to ensure optimum heat
duty evaporator blower and motor resulting in an extremely rugged, transfer.
long-life, energy efficient, self-contained unit that will provide cooling
at higher efficiency over a long and extended life. Compared to the
traditional units available in the market, the APMR series Packaged
Units are very Iow on energy consumption.
The flexibility of the APMR series is ideal for consideration on

special applications including:
Condenser Coil
• 100% fresh air units or units with high incidence of outdoor
fresh air. All coils are tested against leakage by air pressure under water. All
• Units with unusual filtration requirements incorporating carbon, standard coils are 2,3 or 4 rows/14 FPI, 3/8” (9.5 mm) O.D. tubes.
bag and/or other filters. An integral subcooling circuit is provided to increase the cooling
• Special units for ducted condenser air using centrifugal type capacity, without additional operating cost.
condenser air fans.
• Units constructed of aluminium or stainless steel. For different application requirements, other optional condenser fin
• For those special off-shore or refinery or sewage treatment materials are available:
applications requiring specially coated heat transfer coils.
• Factory installed, advanced and user friendly microprocessor • Copper fins.
based control system. • Electrotinned Copper Fins.
• Interface capability with major BMS protocols (option). • Copper finned coils with electro-tinned after manufacturing.
• Precoated Aluminum fins
All of these flexibilities cannot be cataloged nor all the possible The pre-coated is hydrophobic polyurethane resin. This option
options listed. They are available and SKM has over 38 years provides substantial corrosion protection beyond standard coil
of experience in designing and building such units to meet the construction.
most stringent requirements of most applications. For your special • Aeris Guard Coil Coating
requirements please consult SKM. The Aeris Guard Coil is a self etching high performance modified
epoxy finish that is specifically designed to coat and protect
Aluminum and Copper surfaces. In addition, the coating is
ideal for the protection of ferrous and non ferrous materials.
SKM APMR series, all models, are restricted to a 14FPI (1.8 mm)
Component Features fin spacing condenser coil. Gulf dust storms and the general level
of available maintenance in Gulf countries ensures this condenser
The common standard features of all APMR series Packaged Units coil design shall provide long life and maintenance-free operation
include the following. with the least possibility operational blockage on the condenser.
Ample condenser surface and sensible air flow across the condenser
ensures a low temperature differential between condensing
temperature and the high Gulf ambients making the APMR
Compressor packaged unit perform efficiently and durably.
Compressors used in APMR packaged unit series are hermetically

sealed, compact scroll with the following features: Condenser Fans
The condenser fans are propeller type, aluminium alloy blades,
• High Efficiency. directly driven by electric motors.
• Quite operation, Low Sound levels.
• Compact and light . Motors are Totally Enclosed Air Over (TEAO) six pole with class ‘F’
• Limited wear. insulation and minimum IP55 protection.
• 70% fewer moving parts than comparably sized reciprocating
compressors The TEAO and class ‘F’ Insulation
• Unique ability to handle liquid refrigerant. features ensure long life and are
• Suction gas motor cooling. unique to SKM. The motors are
• Centrifugal oil pumps. factory wired using wires specially
• Brazed fittings or Rotalock as options. selected for high ambient operation,
• Two refrigerant circuits on larger units provides efficient part to unit control panel where the
load. motor contactors are located to
control the operation of these
motors. Condenser Fan Motor
3
The condenser fans are individually statically and dynamically • A bag filter section to house 15”, 21” or 30” deep bag filters
balanced at the factory Complete fan assembly is provided with having efficiencies as desired can also be provided, as required.
Suitable acrylic coated fan guard. Filter sections come with latches to provide easy access for
removal and for maintenance.
• On 100% fresh air applications an initial sand trap louvre can
Evaporator effectively minimize entrance of sand into the air stream.
• High efficiency mini pleat panel filters are available as an
Evaporator coils are manufactured of seamless copper tubes
alternative for bag filter where space is limited. Filter sections
mechanically bonded to aluminium fins to ensure optimum heat
come with latches to provide easy access for removal and for
transfer. All evaporator coils are tested against leakage by air
maintenance.
pressure under water. The DX evaporator coils are complete with
headers of seamless copper tubing. Supply headers incorporate
To order a sand trap louvre from SKM specify fresh air opening
a correctly sized distributor. For different application requirements,
size with option ASL.
other evaporator coil material and/or treatment are available on
request.
• Copper fins. Casing/Structure

• Electrotinned Copper fins. The unit casing used in APMR Packaged units is made of zinc
• Copper finned coils with electro-tinned after manufacturing. coated galvanized steel sheets conforming 10 JIS-G 3302 and
• Precoated Aluminum fins. ASTM A525
The pre-coated is hydrophobic polyurethane resin. This option which is phosphatized before application of an electrostatic powder
provides substantial corrosion protection beyond standard coil coat of approximately 60 microns and then oven-baked for a tough and
construction. lasting weather resistant finish. This finish and coating can pass a
• Aeris Guard Coil Coating. 1000 hour in 5 % salt spray testing at 95°F (35°C) and 95% relative
The Aeris Guard Coil is a self etching high performance modified humidity as per ASTM B117. The entire casing panels are designed
epoxy finish that is specifically designed to coat and protect to be leak proof against rain and ensure rain water cannot enter the
Aluminum and Copper surfaces. In addition, the coating is packaged air conditioner interior.
ideal for the protection of ferrous and non ferrous materials.
The evaporator section is sealed with vinyl gaskets.
Evaporator coils are rated in accordance with AHRI-410. Evaporator
coil supplied with suitable size thermostatic expansion valve(s) The standard evaporator section is insulated from all sides with
and multi-circuited distributors providing capacity modulation to black-neoprene faced heavy density 1” thick fiber glass insulation.
match the compressors. The cross wave fins and staggered tubes
design uses the evaporator surface effectively by creating uniform The insulation-cum-sound liner meets the fire requirements of
air turbulance and optimum heat transfer over the entire finned NFPA90A & 90B and is secured with mechanical fasteners in addition
surface. Requirements for higher face velocities can be handled to water resistant adhesive.
by use of moisture eliminators to avoid carryover.
For applications requiring an inner skin in the evaporator section,
option DSE provides an 0.7mm galvanized inner skin. Suitable
isolation to ensure no cold-bridges and no condensation on the
Evaporator Fan & Drive exterior of the units is provided. The condensate drain pan is heavily
Standard evaporator fan is forward curved centrifugal DIDW, insulated to ensure condensation does not occur. Stainless steel
statically and dynamically balanced complete with shaft, self-aligning, condensate drain pans are available on request.
lubricated for life ball bearings.
APMR series models 52019 & 62023 onwards have dual fans Electrical Control Panel
mounted on a Single heavy duty shaft. The fan(s) are driven by a The unit mounted control panel enclosure is fabricated out of heavy
single speed electric motor, Class F insulated, IP55 protected & gauge sheet steel in phosphatized powder coated baked finish.
are totally enclosed 4 pole motor rated for continuous operation at The enclosure conforms to IP54 as per guidelines in IEC 529. A
design conditions. hinged access door and key-fastener is provided for easy access
The motor is fitted with an adjustable V-belt drive, as standard. and security. The panel is factory wired in accordance with NEC
Shaft ends insert into oversized, tapered lock self-aligning, long- 430 & 440, labelled, tagged and features 220V / 240V controls.
life bearings Motor is factory wired to the control panel where the • All compressors are with DOL starting.
motor contactor is located. • Individual compressor, condenser fan motors and evaporator fan
motor contactors.
• Motor protector circuit breaker for condenser and evaporator fan
motors.
Filter Section • Voltage monitoring module for protection against under voltage,
APMR series can be with a range of filter sections and filters to over voltage, phase loss, phase reversal and phase unbalance
meet requirements for the most demanding applications. of the incoming voltage.
• Control circuit breaker.
• Flat or vee filter sections to accommodate 1” or 2” cleanable • Control circuit on/off switch.
aluminium media filters can be provided. • Microprocessor control boards.
• Control Relays.
• Power and control terminal blocks.
4
Microprocessor Controller Display Information
SKM APMR series Packaged Air Conditioners units offer LCD display
which allows the operator to access different parameters of the unit.
Operator can view and change the unit parameters. The display
information includes:
• Status.
• Outputs.
• Inputs.
Microprocessor Controller
• Alarms.
All APMR series Packaged Air Conditioners units are equipped with • Set points.
a full function microprocessor based controller as a standard feature. • Password.
The controller is factory programmed for the control of evaporator
fan, compressors and condenser fans. The controller comes with a
built in keypad and display for simple but meaningful man machine
interface. This controller provides complete operational control for System Control Philosophy
the unit and has built-in auto diagnostic capability that can signal The unit may be enabled or disabled through the control on/off
normal operation or alarm conditions as well as shutting down the switch in the unit mounted control panel. Control is based on room
unit or system if necessary. temperature sensed by room unit. Evaporator fan motor starts first.
Compressors will be staged based on the set point and actual room
temperature. On an increase in room temperature, cooling stages
will be added and on a decrease in room temperature, cooling
stages will be removed from the system.
System Protection
The intelligent microprocessor based controller monitors all the
safeties related to the unit and makes the necessary protections,
by shutting down the entire unit or the effected circuit. The
Room Unit protection includes:
The controller comes with a loose supplied sleek and elegant design
room unit for installing in the conditioned space. Communication • Low suction pressure.
between unit controller and room unit is through two wire interface. The • High discharge pressure.
communication cable should be 2 core, twisted pair, unscreened
with stranded conductors. Maximum distance between room unit • High compressor motor temperature. (For compressors with
and controller can be 700 meters. The room unit has a built in sensor internal motor protector).
for measuring the room temperature. It transmits room temperature, • Compressor short cycling.
set point, unit operating mode etc. to the unit controller. Control of • Evaporator fan motor overload
the compressors is based on room temperature and the set point, as
standard. If unit control needs to be based on duct temperature,
please specify during time of order.
BMS Connectivity (Optional)
Volt free contacts for run status, common fault status, auto mode
The Main Features of the controller are as follows: status and provision for remote on/off shall be provided as option
if required.
• Built in LCD display with back light.
In addition, the APMR microprocessor can support the major BMS
• Roll & push knob and 3 function buttons. protocols such as BACnet, Modbus & LON. Extra hardware may
be required depending on the protocol.
• Battery backed up built in real time clock.
• Multiple authorization level to provide tight security for the control
system.
• Capacity control based on room temperature or return air
temperature.
• Alarm history.
• A sleek & elegant design room unit.
5
Optional Features
APMR series heavy duty packaged air- conditioners are available • Flat or vee filter sections to accommodate 1” or 2” cleanable
with a multitude of optional features which makes design and aluminium media filters can be provided.
selection extremely easy and capable of matching the most stringent
• A bag filter section to house 15”, 21” or 30” deep bag filters having
of requirements.
efficiencies as desired can also be provided, as required. Filter
Alternative Condenser Material sections come with latches to provide easy access for removal
Made of copper tubes and alternative fin material and/or protective and for maintenance.
coating. • On 100% fresh air applications an initial sand trap louvre can
• For Copper Fins, specify (FC). effectively minimize entrance of sand into the air stream, sand
• For electrotinned Copper Fins only, specify (CFT). trap louvre (ASL) available on request.
• For Copper Finned Coils electrotinned post manufacturing,
• High efficiency mini pleat panel filters are available as an
specify (FCT).
alternative for bag filter where space is limited. Filter sections
• For Pre-Coated aluminum fins, specify (FAP).
come with latches to provide easy access for removal and for
• For Aluminum Fins with Aeris post Coat Protection, specify
maintenance.
(FAA).
• For Copper Fins with Aeris post Coat Protection,specify (FCA).
To order a sand trap louvre from SKM specify fresh air opening
size with option ASL.
Alternative Evaporator Material
Made of copper tubes and alternative fin material and/or protective
HEPA filters (FIHP)
coating.
Ultra high Absolute HEPA (High Efficiency Particulate Air filter
• For Copper Fins, specify (EFC).
• For electrotinned Copper Fins only, specify (ECFT). with efficiency in excess of 99% when measured by using DOP
• For Copper Finned Coils electrotinned post manufacturing, (Di-Octyle Phthalate) method. In accordance with EN1882
specify (EFCT). standards. Eff : H13 (including section)
• For Pre-Coated aluminum fins, specify (EFAP).
• For Aluminum Fins with Aeris post Coat Protection, specify Sand trap louver (ASL)
(EFAA). To extract coarse sand prior to the entry in the unit.
• For Copper Fins with Aeris post Coat Protection, specify (EFCA).
Condenser Coil Guard (CGP) Galvanized Frame And Base (GFB)

Steel frame and base which are hot dip galvanized after
Wire mesh guard, in painted finish for condensers coils. manufacturing process. This is recommended for highly corrosive
Recommended on ground level installation where coil needs to
environments.
be protected against vandalism.
Double Skin Evaporator (DSE) Pressure Gauges (SDG1)

Inner skin of 0.7 mm galvanized sheet in the evaporator section Suction and discharge indication of each refrigerant circuit. Gauges
provided with no cold bridges. Recommended for 100% fresh air mounted outside the Control Panel.
applications.
Pressure Relief Valve (PRV)
Marine Paint (MP) To protect the unit from being over-pressurized.
To provide increased corrosion resistance coastal environments
and offshore location.
Stainless Steel Drain Pan (SSP)
Heavy gauge 316 stainless steel drain pan under the entire cooling
Filter Section (FFS/VFS/BFS) coil and moisture eliminator. Insulation under drain pan as per SKM
APMR series can be with a range of filter sections and filters to meet
standard.
requirements for the most demanding applications.
Option code Stainless steel drain pan (Grade 304) (SDP)
S.No Filter Type APMR 61006/51005 to Stainless steel drain pan(Grade 304). Insulation under drain pan
APMR62054/52046- as per SKM standard.
Flat Filter Section with Media
1 25) "1 mm) /50) "2 mm) Thick Washable Aluminum.G2 [FSIP1]/[FSIP2] Extra Shut Off Valve(s) (XFV)
2 25) "1 mm) / 50) "2 mm) Thick Synthetic.G3 [FSIS1]/[FSIS2]
To fully Isolate refrigerant filter drier, additional shut-off valve (s)
Vee Filter Section with Media
3 25) "1 mm) /50) "2 mm) Thick Washable Aluminum.G2 [FSVP1]/[FSVP2]
can be incorporated in the liquid line.
4 25) "1 mm) / 50) "2 mm) Thick Synthetic.G3 [FSVS1]/[FSVS2]
Bag Filter Section with Media* Rotalock Valves on compressors (RVC)
5 380) “15 mm) deep bag filter FSBG-0F8
For additional facilitation of maintenance of unit.
6 534) “21 mm) deep bag filter FSBG-1F8
7 762) “30 mm) deep bag filter FSBG-2F8 Condenser & Evaporator Fans with polyglycoat
Pleated Filter Midea*
8 100) "4 mm) thick FSMP-4F8 coating (PGF)
*F8 idicates the efficieny, For F9 change option code. Table 1 To provide protection against corrosion for evaporator or
condenser fans.
6
Anti Spark Fan & Belt (SPF) Low Ambient Operation Kit (LAO)
For special applications like explosion proof units. For unit operation down to lower than normal gulf ambient. Please
specify during the time of order.
Isolated Condenser Fan Motors (CMS)
For elimination of extraneous noise and vibration from condenser IP 55 Control Panel (ICP)
fan motor, the motors are individually isolated from the frame. Control Panel for special applications to meet IP55 requirements.
Condenser Fan motors with anti-condensation heaters Main Isolator (without door interlock) (ISO)
built-in (CFMA) For main power isolation. (consult SKM)
Where application so requires.
Control Transformer (CXT)
Mixing Box (BMX) This option is necessary and available for APMR models rated
With or without sand trap louvre and bird screen on fresh air Side. for 440V/3PH/50Hz or 460V/3PH/60Hz or power supplies without
neutral. When ordering for these voltages, this option must be
Two inch insulation (2SG) ordered.
for evaporator section.
Voltage Monitoring Module as per DEWA (DVM)
Electric Heating (HTR1)
Electric heating batteries are made up of finned heating elements, Under voltage relay as per DEWA regulations. This option is available
constructed from high quality 80/20 nickel chrome resistance wire for Dubai, UAE only.
centred in metal tube by compressed magnesium oxide. Helical
fins are tightly wound around the tubular heating element. Circuit Breaker for Compressor (CBC)
For those electrical specification which requires additional short-
Heater batteries when ordered comes with stage contactors, primary
auto reset thermal safety cut-out, secondary manual reset thermal circuit and overload protection for the compressors.
safety cut-out and air flow switch. Power fuses / circuit breaker are
provided for heaters with total ampere exceeding 48 amperes. For External Overload Protection (EOP)
smaller heaters, power fuses can be provided if specified. Control For those electrical specification which requires additional overload
of the heaters will be from the APMR microprocessor. protection for the compressors.
Following are the optional kW ratings for electric heater. Ratings
other Soft Starter (SFS)
Cataloguethan
Table those specified here can be supplied on request. Consult
SKM for details To reduce the starting current of compressors using reduced voltage
starting method. Compressors will be started using electronic solid
MODEL APMR HEATER (kW) STAGES
state soft starters that will ramp up the speed of the compressors
to rated speed within few seconds thus reducing the mechanical
51005 61006 7.5 1 & electrical stresses .
51007 61008 9 1
51008 61009 12 1 Suction Pressure read out Capability (SPC)
51009 61011 15 1 Additional transducer in suction line to display suction pressure in
microprocessor.
52010 62011
18
51012 61014
52013 62014
BMS Interface Volt free Contacts (BMVF)
24 Volt free contacts for run status, common fault status, auto mode
52015 62018
status and provision for remote on/off shall be provided as option if
52019 62023 30 required. For additional requirements, please contact SKM.
52022 62026
36 2
52025 62030 BMS Interface thru protocol (BMSP)
52028 62034
52032 62038 For interfacing the units with major BMS protocols such as BACNet,
52036 62042 48 Modbus or LON. Extra hardware may be required depending on the
52042 62048 protocol.
52046 62054
Table 2 Pump Down Facility (PD)
Hot Gas Bypass System (GBP) The compressor will switch off each time with a Pump Down Cycle
With solenoid to enable operation of a large sized unit at very low in order to prevent Liquid refrigerant migration to the compressor
loads, during low load demand due to application requirements or during off Cycle periods.
where unit is selected to work on 100% fresh air applications. With this option, each circuit will be provided with an additional
discharge check valve (if required) to prevent Refrigerant Migration
from High side to Low side when the compressor is off.
Electronic Expansion Valve (EEV)
To provide energy saving benefits over mechanical thermostatic
expansion valve (TXV).
7
Options for Field Installations Capacity Control Steps

The Standard Capacity Control Steps are shown below.
Anti-vibration mounts (CAVM)
Recommended for roof mounted units or other locations in the vicinity APMR Standard Number of steps
of occupied spaces, where noise may be objectionable.
51005 61006 100-0 1
51007 61008 100-0 1
Hi-Lo Pressure Gauges (CSDG1) 51008 61009 100-0 1
Without piping or isolating pet cocks.
51009 61011 100-0 1
52010 62011 100-50-0 2
Duct Temperature Sensor (DTS) 51012 61014 100-0 1
In order to control the unit based on return / supply air duct temperature. 52013 62014 100-50-0 2
52015 62018 100-50-0 2
52019 62023 100-50-0 2
Special custom built units incorporating specially required features 52022 62026 100-50-0 2
like units for larger capacities , anti-condensation resistance heaters 52025 62030 100-50-0 2
embedded in evaporator motors, units can be manufactured on 52028 62034 100-50-0 2
request. Consult SKM with detailed requirements.
52032 62038 100-56-0 2
Contact SKM for all such applications or requirements. 52036 62042 100-50-0 2
52042 62048 100-55-0 2
52046 62054 100-50-0 2
Table 3
Selection Procedure
APMR series packaged air-conditioners should be selected with care and using sound engineering judgement. Selections based on
matching total capacity alone or air flow rate alone may not be correct. To meet requirements of a specific application, sample procedure
for selection is given in examples below.
Example 1: English Units Example 2: SI Units

Application Requirements
Required total cooling capacity.................................. 186.0 MBh..........................................................54.5 kW
Sensible cooling capacity........................................... 126.0 MBh...........................................................36.9 kW
Condenser entering air temp db..................................... 115°F.................................................................46°C
Evaporator entering air temp. db/wb............................ 80/67°F.......................................................... 26.7/19.4°C
Evaporator air flow rate...............................................6,600 cfm.......................................................... 3115 l/s
External static pressure............................................... 1.00 inwg.......................................................... 250 Pa
Electric power supply ............................................380V/3PH/50Hz............................................ .. 380V/3PH/50Hz
Refrigerant ....................................................................R-410A.......................................................... .. R-410A
Determine cooling capacity at design conditions.
Selection Procedure :
Enter packaged unit capacity ratings at given condition and select unit size APMR - 52019A having total cooling capacity 199.9 MBh
(58.6 kW), and sensible cooling 147.8 MBh (43.3 kW), PI = 20.1 kW. Total sensible cooling capacities & power to be interpolated for
untabulated data.
- For EDB other than 80ºF (26.7ºC), use following formula:
Actual sensible capacity = Rated sensible capacity + 0.0011 (1 - BPF)(EDB - 80) x cfm - IP Units
Actual sensible capacity = Rated sensible capacity + 0.00123 (1 - BPF)(EDB - 26.7) x l/s - SI Units
Fan Speed & Motor Power

Refer to fan performance table on page 15 and adjust fan RPM = 1139, fan brake power 2.75 kw. Standard motor size for selected model
is 4 kW.
SKM Computer Selections are available for quick, detailed and accurate selections.
8
ENGINEERING SPECIFICATIONS - 50 Hz
Model APMR 51005 51007 51008 51009 52010 51012 52013 52015
TR 5.0 6.4 7.4 9.5 10.0 10.7 13.0 14.6
Cooling Capacity (1)
kW 17.7 22.5 25.9 33.5 35.3 37.6 45.7 51.3
TR 4.5 5.8 6.6 8.5 8.9 9.5 11.7 12.9
kW 15.7 20.3 23.0 29.9 31.4 33.4 41.2 45.3
Type - Hermetic Scroll Compressor
Quantity - 1 1 1 1 2 1 2 2
Compressor US Gal 0.47 0.48 0.71 0.90 0.47/0.47 0.90 0.48/0.48 0.71/0.71
Oil Charge
Ckt (A / B) 1.77 1.80 2.70 3.40 1.77/1.77 3.40 1.8/1.8 2.7/2.7
Liter
Type - Air cooled 2, 3 or 4 rows 14 FPI (1.8mm) fin spacing, Cu tubes, Al fins
Condenser Coil ft² 9.7 12.2 19.4 19.4 19.4 19.4 24.4 26.3
Face Area
m² 0.9 1.1 1.8 1.8 1.8 1.8 2.3 2.4
Type - Propeller direct drive 960 RPM
Code / Quantity - 628/1 723/1 628/2 628/2 628/2 628/2 723/2 723/2
Condenser Fan
cfm 4460 6620 9240 8920 8920 8920 13240 13400
Air Flow Rate
l/s 2105 3124 4361 4210 4210 4210 6249 6324
Type - Totally enclosed, air over Class F insulation, 6-pole, IP-55
Condenser Motor
Size / Quantity kW 0.37/1 0.75/1 0.37/2 0.37/2 0.37/2 0.37/2 0.75/2 0.75/2
Type - Direct expansion, Aluminum Fins, Copper Tubes
Evaporator Coil ft² 4.7 5.6 5.6 6.7 9.0 9.0 11.7 11.7
Face Area
m² 0.4 0.5 0.5 0.6 0.8 0.8 1.1 1.1
Type - Centrifugal double inlet double width belt drive
Code / Qty. - N10/1 N10/1 N10/1 N12/1 N15/1 N15/1 N15/1 N15/1
Evaporator Fan
cfm 2000 2500 2700 3200 4170 4500 5200 5200
Air Flow Rate
l/s 944 1180 1274 1510 1968 2124 2454 2454
Type - Totally enclosed, fan cooled Class F insulation, 4-pole IP55
Evaporator Motor
Size kW 1.1 1.1 1.5 1.5 2.2 2.2 2.2 2.2
lbs 8.8 10.6 12.2 17.2 8.4 / 8.4 18.1 10.4 / 10.4 12.3 / 12.3
Refrigerant Operating Charge Ckt (A / B)
kg 4.0 4.8 5.5 7.8 3.8 / 3.8 8.2 4.7 / 4.7 5.6 / 5.6
Number of Refrigerant Circuits - 1 1 1 1 2 1 2 2
lbs 1063 1099 1382 1464 1538 1490 1613 1985
Unit Operating Weight
kg 482 499 627 664 697 676 732 900
Model APMR 52019 52022 52025 52028 52032 52036 52042 52046
TR 18.8 21.1 24.2 27.5 31.0 34.9 40.8 46.3
kW 66.2 74.3 85.0 96.7 109.1 122.8 143.4 162.9
TR 16.7 18.7 21.3 24.5 27.8 31.3 36.5 41.1
kW 58.6 65.7 75.1 86.3 97.6 110.1 128.3 144.6
Quantity - 2 2 2 2 2 2 2 2
Compressor US Gal 0.9/0.9 0.9/0.9 0.9/0.9 0.9/0.9 1.22/0.9 1.23/1.23 1.82/1.23 1.82/1.82
Oil Charge
Ckt (A / B) 3.4/3.4 3.4/3.4 3.4/3.4 3.4/3.4 4.62/3.4 4.64/4.64 6.9/4.66 6.9/6.9
Liter
Type - Air cooled 3 or 4 rows 14 FPI (1.8mm) fin spacing, Cu tubes, Al fins
Face Area
m² 2.4 2.4 3.3 3.7 3.7 5.0 5.9 6.7
Code / Quantity - 823/2 823/2 823/3 823/3 823/3 829/3 823/4 829/4
Condenser Fan
cfm 17360 16400 25200 26160 24780 32040 36480 42880
Air Flow Rate
l/s 8193 7740 11893 12346 11695 15121 17217 20237
Condenser Motor
Size / Quantity kW 1.5/2 1.5/2 1.5/3 1.5/3 1.5/3 1.5/3 1.5/4 1.5/4
Face Area
m² 1.3 1.4 1.6 1.7 1.9 2.2 2.7 3.2
Evaporator Fan
cfm 6600 7300 8600 9400 10400 11700 14600 17200
Air Flow Rate
l/s 3115 3445 4059 4436 4908 5522 6890 8117
Evaporator Motor
Size kW 3.0 4.0 4.0 5.5 5.5 7.5 7.5 11.0
lbs 12.6 /12.6 15.9 / 15.9 16.4 / 16.4 18.9 / 18.9 23 / 17.3 25.5 / 25.5 34.2 / 29.2 34.7 / 34.7
kg 5.7 / 5.7 7.2 / 7.2 7.5 / 7.5 8.6 / 8.6 10.4 / 7.9 11.6 / 11.6 15.5 / 13.2 15.7 / 15.7
lbs 2153 2234 2704 2895 3167 3469 4512 4838
kg 977 1014 1227 1313 1436 1574 2047 2195
Table 4
Notes :
(1). Capacity rating in accordance with AHRI standard 210/240 & 340 / 360.
(2). Capacity ratings based on evaporator entering air temperatures of 80/67 ºF (26.7/19.4 ºC) dry bulb/wet bulb and condenser entering air
temperature of 115 ºF (46 ºC).
(3). Capacity is gross capacity which does not include the effect of evaporator fan motor heat.
9
ENGINEERING SPECIFICATIONS - 60 Hz
Model APMR 61006 61008 61009 61011 62011 61014 62014 62018
TR 6.0 7.6 8.6 11.1 12.1 12.8 15.5 17.0
kW 21.2 26.8 30.3 39.1 42.6 45.0 54.4 59.9
TR 5.4 6.9 7.8 9.9 10.8 11.3 13.9 15.4
kW 19.0 24.1 27.4 34.8 38.0 39.8 48.9 54.0
Quantity - 1 1 1 1 2 1 2 2
Compressor US Gal 0.47 0.48 0.71 0.90 0.47/0.47 0.90 0.48/0.48 0.71/0.71
Oil Charge Ckt (A /B)
Liter 1.77 1.80 2.70 3.40 1.77/1.77 3.40 1.8/1.8 2.7/2.7
Type - Air cooled 2, 3 or 4 rows 14 FPI (1.8mm) fin spacing, Cu tubes, Al fins
Face Area
m² 0.9 1.1 1.8 1.8 1.8 1.8 2.3 2.4
Code / Quantity - 628/1 723/1 628/2 628/2 628/2 628/2 723/2 723/2
Condenser Fan
cfm 5410 7830 11200 10820 10820 10820 15660 15880
Air Flow Rate
l/s 2553 3695 5286 5106 5106 5106 7391 7495
Condenser Motor
Size / Quantity kW 0.55/1 1.1/1 0.55/2 0.55/2 0.55/2 0.55/2 1.1/2 1.1/2
Face Area
m² 0.4 0.5 0.5 0.6 0.8 0.8 1.1 1.1
Evaporator Fan
cfm 2000 2500 2700 3200 4170 4500 5200 5200
Air Flow Rate
l/s 944 1180 1274 1510 1968 2124 2454 2454
Evaporator Motor
Size kW 1.1 1.1 1.5 1.5 2.2 2.2 2.2 3.0
lbs 9.3 11.1 12.7 17.8 8.8 / 8.8 18.9 10.9 / 10.9 12.8 / 12.8
kg 4.2 5.0 5.8 8.1 4.0/4.0 8.6 4.95/4.95 5.8/5.8
lbs 1076 1117 1396 1477 1558 1507 1645 2029
kg 488 507 633 670 707 683 746 920
Model APMR 62023 62026 62030 62034 62038 62042 62048 62054
TR 21.9 24.6 28.1 32.0 36.2 40.7 47.6 54.0
kW 76.9 86.5 99.0 112.4 127.3 143.1 167.4 190.0
TR 19.3 21.8 24.8 28.5 32.4 36.5 42.6 48.3
kW 68.0 76.5 87.3 100.3 114.0 128.5 149.9 169.9
Quantity - 2 2 2 2 2 2 2 2
Compressor
US Gal 0.9/0.9 0.9/0.9 0.9/0.9 0.9/0.9 1.22/0.9 1.23/1.23 1.82/1.23 1.83/1.83
Oil Charge Ckt (A /B)
Liter 3.4/3.4 3.4/3.4 3.4/3.4 3.4/3.4 4.63/3.4 4.65/4.65 6.91/4.67 6.91/6.91
Type - Air cooled 3 or 4 rows 14 FPI (1.8mm) fin spacing, Cu tubes, Al fins
Face Area
m² 2.4 2.4 3.3 3.7 3.7 5.0 5.9 6.7
Code / Quantity - 823/2 823/2 823/3 823/3 823/3 829/3 823/4 829/4
Condenser Fan
cfm 21140 20020 30720 31860 30210 38700 44400 51760
Air Flow Rate
l/s 9977 9448 14498 15036 14258 18264 20954 24428
Condenser Motor
Size / Quantity kW 2.2/2 2.2/2 2.2/3 2.2/3 2.2/3 2.2/3 2.2/4 2.2/4
Face Area
m² 1.3 1.4 1.6 1.7 1.9 2.2 2.7 3.2
Evaporator Fan
cfm 6600 7300 8600 9400 10400 11700 14600 17200
Air Flow Rate
l/s 3115 3445 4059 4436 4908 5522 6890 8117
Evaporator Motor
Size kW 4.0 4.0 5.5 5.5 5.5 7.5 7.5 11.0
lbs 13.1 / 13.1 16.5 / 16.5 17.2 / 17.2 19.7 / 19.7 24 / 18.1 26.5 / 26.5 35.6 / 30.3 36.2 / 36.2
kg 5.96/5.96 7.5/7.5 7.8/7.8 8.95/8.95 10.9 / 8.2 12.0 / 12.0 16.1 / 13.7 16.4 / 16.4
lbs 2200 2271 2780 2945 3222 3526 4585 4920
kg 998 1030 1261 1336 1462 1600 2080 2232
Table 5
Notes :
(1). Capacity rating in accordance with AHRI standard 210/240 & 340 / 360.
(2). Capacity ratings based on evaporator entering air temperatures of 80/67 ºF (26.7/19.4 ºC) dry bulb/wet bulb and condenser entering air
temperature of 115 ºF (46 ºC).
(3). Capacity is gross capacity which does not include the effect of evaporator fan motor heat.
10
GROSS CAPACITY RATINGS - 50 Hz
AFR Condenser Entering Air Temperature
Model cfm EWB 95°F (35°C) 105°F (40.6°C) 115°F (46.1°C) 125°F (51.7°C)
APMR l/s Total Capacity Sensible Capacity PI* Total Capacity Sensible Capacity PI* Total Capacity Sensible Capacity PI* Total Capacity Sensible Capacity PI*
(BPF) °F °C MBh kW MBh kW kW MBh kW MBh kW kW MBh kW MBh kW kW MBh kW MBh kW kW
1633 62 16.7 54 15.8 47 13.8 4.2 50.3 14.7 45.4 13.3 4.8 46.6 13.7 43.9 12.9 5.4 43.1 12.6 42.4 12.4 6
771 67 19.4 58.5 17.2 39.1 11.5 4.3 55.5 16.3 37.9 11.1 4.9 52.2 15.3 36.7 10.7 5.5 48.9 14.3 35.4 10.4 6.1
0.2 72 22.2 63 18.5 30.9 9.1 4.3 59.6 17.5 29.8 8.7 4.9 56.1 16.4 28.6 8.4 5.6 52.5 15.4 27.4 8 6.3
2000 62 16.7 54.7 16 51.6 15.1 4.2 51.2 15 50.2 14.7 4.8 47.6 14 47.6 14 5.4 44.2 13 44.2 13 6
51005 944 67 19.4 60.4 17.7 42.7 12.5 4.3 57.1 16.7 41.5 12.2 4.9 53.7 15.7 40.3 11.8 5.5 49.7 14.6 38.9 11.4 6.2
0.22 72 22.2 64.7 19 33.2 9.7 4.4 61.2 17.9 32 9.4 5 57.5 16.9 30.8 9 5.7 55.7 16.3 30.2 8.9 6.1
2567 62 16.7 55.8 16.4 55.8 16.4 4.2 52.4 15.4 52.4 15.4 4.8 48.9 14.3 48.9 14.3 5.4 45.4 13.3 45.4 13.3 6
1211 67 19.4 62.3 18.2 48 14.1 4.3 58.8 17.2 46.8 13.7 4.9 54.5 16 45.3 13.3 5.6 50.5 14.8 43.8 12.8 6.2
0.26 72 22.2 66.6 19.5 36.4 10.7 4.4 62.9 18.4 35.3 10.3 5 0 0 0 0 0 0 0 0 0 0
1944 62 16.7 68.2 20 57.7 16.9 5 64.8 19 56.2 16.5 5.8 60.4 17.7 54.3 15.9 6.6 56.1 16.5 52.5 15.4 7.4
917 67 19.4 73.8 21.6 48.1 14.1 5.1 70.4 20.6 46.8 13.7 5.9 66.7 19.5 45.3 13.3 6.7 62.9 18.4 43.9 12.9 7.5
0.2 72 22.2 79.7 23.4 38.5 11.3 5.2 76 22.3 37.2 10.9 6 72 21.1 35.8 10.5 6.8 68 19.9 34.4 10.1 7.6
2500 62 16.7 70.2 20.6 64.9 19 5.1 66 19.3 63.2 18.5 5.8 61.7 18.1 61.5 18 6.6 57.7 16.9 57.7 16.9 7.4
51007 1180 67 19.4 76.8 22.5 53.7 15.7 5.2 73.2 21.4 52.3 15.3 5.9 69.3 20.3 50.9 14.9 6.7 65.3 19.1 49.5 14.5 7.5
0.23 72 22.2 82.8 24.3 42 12.3 5.3 78.8 23.1 40.7 11.9 6 74.6 21.9 39.3 11.5 6.8 70.4 20.6 37.9 11.1 7.6
3056 62 16.7 71.1 20.8 71.1 20.8 5.1 67 19.6 67 19.6 5.8 62.9 18.4 62.9 18.4 6.6 58.8 17.2 58.8 17.2 7.4
1442 67 19.4 78.9 23.1 58.8 17.2 5.2 75.1 22 57.4 16.8 5.9 71 20.8 56 16.4 6.8 66.2 19.4 54.3 15.9 7.5
0.26 72 22.2 84.9 24.9 45.2 13.2 5.3 80.7 23.7 43.8 12.8 6.1 76.4 22.4 42.4 12.4 6.9 74.2 21.7 41.8 12.2 7.3
1944 62 16.7 76.9 22.5 64.4 18.9 5.3 72.3 21.2 62.4 18.3 6.1 67.2 19.7 60.1 17.6 7 62.3 18.3 58 17 8
917 67 19.4 83.2 24.4 54 15.8 5.5 79.1 23.2 52.3 15.3 6.2 74.7 21.9 50.6 14.8 7.2 70.2 20.6 48.8 14.3 8
0.11 72 22.2 89.7 26.3 43.3 12.7 5.6 85.3 25 41.7 12.2 6.4 80.5 23.6 40 11.7 7.2 75.7 22.2 38.4 11.2 8
2700 62 16.7 79.3 23.3 75.6 22.2 5.4 74.8 21.9 73.7 21.6 6.1 70 20.5 70 20.5 7.1 65.3 19.1 65.3 19.1 8
51008 1274 67 19.4 88.3 25.9 62.9 18.4 5.6 83.9 24.6 61.2 17.9 6.4 78.6 23 59.3 17.4 7.2 72.8 21.3 57.1 16.7 8
0.13 72 22.2 94.8 27.8 48.9 14.3 5.7 89.9 26.4 47.3 13.9 6.5 84.8 24.9 45.6 13.4 7.3 0 0 0 0 0
3056 62 16.7 80.3 23.5 80.3 23.5 5.4 75.9 22.2 75.9 22.2 6.2 71 20.8 71 20.8 7.1 66.3 19.4 66.3 19.4 8
1442 67 19.4 89.9 26.4 66.7 19.6 5.6 85.1 24.9 65 19 6.4 79.2 23.2 62.8 18.4 7.2 73.6 21.6 60.8 17.8 8
0.14 72 22.2 96.4 28.2 51.3 15 5.8 91.4 26.8 49.7 14.6 6.6 0 0 0 0 0 0 0 0 0 0
2333 62 16.7 99.8 29.3 80.8 23.7 7.1 94.5 27.7 78.3 23 8.2 87.7 25.7 75.3 22.1 9.4 80.5 23.6 72.1 21.1 10.6
1101 67 19.4 107.7 31.6 68 19.9 7.2 102.2 30 65.8 19.3 8.2 96.1 28.2 63.3 18.6 9.5 90 26.4 60.8 17.8 10.7
0.11 72 22.2 116.2 34 55.1 16.2 7.3 110.3 32.3 52.9 15.5 8.3 103.8 30.4 50.6 14.8 9.6 97.2 28.5 48.3 14.1 10.7
3200 62 16.7 104.7 30.7 94.2 27.6 7.2 97.9 28.7 91.3 26.8 8.2 90.7 26.6 88.3 25.9 9.4 83.9 24.6 83.9 24.6 10.6
51009 1510 67 19.4 114.4 33.5 78.3 23 7.2 108.5 31.8 76.1 22.3 8.3 101.9 29.9 73.6 21.6 9.5 95 27.8 71 20.8 10.7
0.13 72 22.2 123.2 36.1 61.7 18.1 7.3 116.6 34.2 59.4 17.4 8.4 109.5 32.1 57 16.7 9.6 102.5 30 54.7 16 10.8
3667 62 16.7 105.8 31 100.7 29.5 7.2 99.1 29.1 98 28.7 8.2 92.2 27 92.2 27 9.4 85.4 25 85.4 25 10.6
1731 67 19.4 116.9 34.3 83.5 24.5 7.3 110.7 32.5 81.1 23.8 8.3 104 30.5 78.6 23 9.6 95.8 28.1 75.7 22.2 10.7
0.14 72 22.2 125.6 36.8 64.8 19 7.3 118.8 34.8 62.6 18.3 8.4 111.5 32.7 60.2 17.6 9.7 107.9 31.6 59 17.3 10.3
3135 62 16.7 112.6 33 94.1 27.6 8.3 106.4 31.2 91.4 26.8 9.6 98.3 28.8 87.9 25.8 10.9 90.4 26.5 84.6 24.8 12.3
1480 67 19.4 121.5 35.6 78.6 23 8.5 115.1 33.7 76 22.3 9.7 108.1 31.7 73.4 21.5 11.1 101.2 29.7 70.7 20.7 12.5
0.2 72 22.2 131 38.4 62.9 18.4 8.6 124 36.4 60.5 17.7 9.9 116.6 34.2 57.9 17 11.3 109.1 32 55.4 16.2 12.6
4500 62 16.7 117.2 34.4 111.7 32.7 8.4 109.4 32.1 108.5 31.8 9.6 101.4 29.7 101.4 29.7 11 93.9 27.5 93.9 27.5 12.3
51012 2124 67 19.4 128.3 37.6 91.9 26.9 8.6 121.3 35.6 89.3 26.2 9.9 113.8 33.4 86.7 25.4 11.3 105.7 31 83.8 24.6 12.6
0.24 72 22.2 138 40.4 71.2 20.9 8.7 130.2 38.2 68.7 20.1 10.1 122.2 35.8 66.2 19.4 11.5 114.4 33.5 63.7 18.7 12.8
4927 62 16.7 117.9 34.5 116.7 34.2 8.4 110.1 32.3 110.1 32.3 9.6 102.3 30 102.3 30 11 94.7 27.8 94.7 27.8 12.3
2325 67 19.4 129.8 38 95.7 28.1 8.6 122.6 35.9 93.2 27.3 9.9 115 33.7 90.5 26.5 11.3 106.2 31.1 87.4 25.6 12.6
0.26 72 22.2 139.4 40.8 73.6 21.6 8.8 131.5 38.5 71.1 20.8 10.1 123.4 36.2 68.5 20.1 11.5 119.4 35 67.3 19.7 12.2
3135 62 16.7 106.8 31.3 91.6 26.8 8.4 100 29.3 88.6 26 9.5 92.5 27.1 85.5 25 10.8 85.4 25 82.5 24.2 12
1480 67 19.4 115.5 33.9 76.2 22.3 8.5 109.5 32.1 73.9 21.7 9.7 103.1 30.2 71.4 20.9 11 96.6 28.3 69 20.2 12.2
0.2 72 22.2 124.4 36.5 60.6 17.8 8.7 117.9 34.5 58.3 17.1 9.9 110.9 32.5 55.9 16.4 11.2 103.9 30.4 53.6 15.7 12.6
4170 62 16.7 109.4 32.1 104.7 30.7 8.4 102.3 30 101.9 29.9 9.6 95.2 27.9 95.2 27.9 10.8 88.3 25.9 88.3 25.9 12
52010 1968 67 19.4 120.5 35.3 86.4 25.3 8.6 114.1 33.4 84.1 24.6 9.8 107.3 31.5 81.6 23.9 11.1 99.3 29.1 78.8 23.1 12.3
0.23 72 22.2 129.3 37.9 66.9 19.6 8.7 122.3 35.8 64.6 18.9 10 114.9 33.7 62.3 18.2 11.4 111.2 32.6 61.1 17.9 12.1
4927 62 16.7 110.7 32.4 110.7 32.4 8.4 103.8 30.4 103.8 30.4 9.6 96.7 28.4 96.7 28.4 10.9 89.9 26.3 89.9 26.3 12.1
2325 67 19.4 123 36.1 93.3 27.4 8.6 116.4 34.1 91 26.7 9.8 108.5 31.8 88.2 25.9 11.1 100.3 29.4 85.3 25 12.4
0.26 72 22.2 131.7 38.6 71.2 20.9 8.7 124.5 36.5 68.9 20.2 10 0 0 0 0 0 0 0 0 0 0
4083 62 16.7 138.5 40.6 119 34.9 10.1 130.5 38.2 115.5 33.9 11.6 121.8 35.7 111.9 32.8 13.2 113.5 33.3 108.4 31.8 14.8
1927 67 19.4 150.1 44 99.1 29.1 10.3 143 41.9 96.4 28.2 11.8 135.5 39.7 93.5 27.4 13.4 127.8 37.5 90.6 26.6 15
0.2 72 22.2 162.1 47.5 78.9 23.1 10.5 154.4 45.3 76.3 22.4 12 146.2 42.8 73.5 21.5 13.6 138 40.4 70.7 20.7 15.1
5200 62 16.7 141.3 41.4 133.3 39.1 10.2 133 39 129.9 38.1 11.6 124.7 36.6 124.7 36.6 13.2 116.6 34.2 116.6 34.2 14.8
52013 2454 67 19.4 155.9 45.7 110.3 32.3 10.4 148.4 43.5 107.6 31.5 11.8 140.5 41.2 104.6 30.7 13.5 131.7 38.6 101.5 29.8 15
0.23 72 22.2 167.9 49.2 85.9 25.2 10.6 159.7 46.8 83.2 24.4 12.1 151.1 44.3 80.4 23.6 13.7 142.6 41.8 77.7 22.8 15.2
6417 62 16.7 143.5 42.1 143.5 42.1 10.2 135.5 39.7 135.5 39.7 11.6 127.3 37.3 127.3 37.3 13.2 119.1 34.9 119.1 34.9 14.8
3028 67 19.4 160.2 46.9 121.5 35.6 10.5 152.4 44.7 118.8 34.8 11.9 143.3 42 115.6 33.9 13.5 133.3 39.1 112.1 32.9 15.1
0.26 72 22.2 172.1 50.5 92.9 27.2 10.7 163.6 48 90.2 26.4 12.2 154.8 45.4 87.4 25.6 13.8 0 0 0 0 0
4083 62 16.7 153.3 44.9 131.7 38.6 10.9 143.8 42.1 127.4 37.4 12.5 133.9 39.2 123.1 36.1 14.5 124.4 36.5 119.1 34.9 16.3
1927 67 19.4 167.4 49.1 110.4 32.4 11.3 158.9 46.6 107 31.4 12.9 149.9 43.9 103.5 30.3 14.7 140.7 41.2 99.9 29.3 16.4
0.11 72 22.2 180.1 52.8 88 25.8 11.6 170.8 50.1 84.7 24.8 13.2 161.1 47.2 81.3 23.8 14.8 151.5 44.4 78 22.9 16.3
5200 62 16.7 157 46 148.4 43.5 11 147.9 43.3 144.6 42.4 12.6 138.3 40.5 138.3 40.5 14.5 128.9 37.8 128.9 37.8 16.3
52015 2454 67 19.4 174.9 51.3 123.7 36.3 11.5 165.8 48.6 120.3 35.3 13.1 154.7 45.4 116.1 34 14.8 143.5 42 112 32.8 16.3
0.12 72 22.2 187.5 54.9 96.3 28.2 11.9 177.6 52.1 93 27.3 13.4 0 0 0 0 0 0 0 0 0 0
6417 62 16.7 160.6 47.1 160.6 47.1 11.1 151.5 44.4 151.5 44.4 12.7 141.9 41.6 141.9 41.6 14.6 132.4 38.8 132.4 38.8 16.4
3028 67 19.4 180.1 52.8 137 40.1 11.6 168.7 49.4 132.8 38.9 13.2 157.1 46.1 128.7 37.7 14.8 146.2 42.8 124.8 36.6 16.3
0.14 72 22.2 192.8 56.5 104.6 30.7 12 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Table 6
Notes:
(1). Ratings are based on 80ºF (26.7ºC) entering air dry bulb temperature. (2). Capacity is gross capacity which does not include the
effect of evaporator fan motor heat. (3). Direct interpolation is permissible. Do not extrapolate. (4). Shaded values are at 120ºF (49ºC)
condenser entering air temperature.
* Power input mentioned in this page should not be used for cable or fuse selection. MCA and MFA values given in the electrical data
pages (19 - 20) should be referred for the same.
11
GROSS CAPACITY RATINGS - 50 Hz

4769 62 16.7 197.2 57.8 162 47.5 15 185.6 54.4 156.7 45.9 17.2 170.7 50 150.1 44 19.6 157.1 46 144.1 42.2 21.9
2251 67 19.4 212.8 62.4 136 39.9 15.2 201.1 59 131.2 38.5 17.5 188.8 55.3 126.3 37 19.9 176.8 51.8 121.5 35.6 22.1
0.11 72 22.2 229.1 67.2 109.6 32.1 15.4 216.7 63.5 105 30.8 17.7 203.5 59.6 100.3 29.4 20.2 190.7 55.9 95.9 28.1 22.3
6600 62 16.7 205.1 60.1 189.6 55.6 15.1 191.3 56.1 183.8 53.9 17.3 177.4 52 177.4 52 19.7 164.4 48.2 164.4 48.2 22
52019 3115 67 19.4 225.9 66.2 157.6 46.2 15.3 213.2 62.5 152.8 44.8 17.7 199.9 58.6 147.8 43.3 20.1 184.5 54.1 142.1 41.6 22.2
0.13 72 22.2 242.4 71.1 123.2 36.1 15.5 228.7 67 118.5 34.7 17.9 214.4 62.8 113.8 33.3 20.3 207.4 60.8 111.5 32.7 21.4
7494 62 16.7 207.3 60.8 202.2 59.3 15.1 193.8 56.8 193.8 56.8 17.4 180.1 52.8 180.1 52.8 19.8 167.1 49 167.1 49 22
3537 67 19.4 230.2 67.5 167.3 49 15.4 217.2 63.7 162.4 47.6 17.7 201.7 59.1 156.8 46 20.1 186.3 54.6 151.3 44.3 22.2
0.14 72 22.2 246.7 72.3 129.2 37.9 15.6 232.6 68.2 124.6 36.5 18 0 0 0 0 0 0 0 0 0 0
5104 62 16.7 219.9 64.4 177.4 52 16.9 207.4 60.8 171.7 50.3 19.5 192.6 56.4 165 48.4 22.3 176.7 51.8 158 46.3 24.9
2409 67 19.4 236.9 69.4 149.4 43.8 17.3 224.1 65.7 144.1 42.2 19.9 210.5 61.7 138.5 40.6 22.7 197 57.7 133.1 39 25.2
0.11 72 22.2 255.3 74.8 121.1 35.5 17.6 241.5 70.8 115.9 34 20.3 227 66.5 110.7 32.4 23.1 212.5 62.3 105.6 30.9 25.6
7300 62 16.7 231.4 67.8 211.1 61.9 17.1 215.6 63.2 204.4 59.9 19.7 199.9 58.6 197.9 58 22.5 185 54.2 185 54.2 25
52022 3445 67 19.4 253.4 74.3 175.2 51.4 17.6 239.2 70.1 169.9 49.8 20.3 224.3 65.7 164.3 48.1 23 208.1 61 158.2 46.4 25.5
0.14 72 22.2 272.2 79.8 137.4 40.3 18 256.6 75.2 132.1 38.7 20.7 240.7 70.5 126.7 37.1 23.5 225.4 66.1 121.8 35.7 26
8021 62 16.7 233.1 68.3 221.1 64.8 17.2 217.6 63.8 214.6 62.9 19.7 201.9 59.2 201.9 59.2 22.5 187.1 54.8 187.1 54.8 25
3785 67 19.4 257 75.3 183.1 53.7 17.7 242.5 71.1 177.6 52.1 20.3 227.2 66.6 172 50.4 23.1 209.4 61.4 165.5 48.5 25.5
0.14 72 22.2 275.6 80.8 142.2 41.7 18 259.8 76.2 136.9 40.1 20.7 243.7 71.4 131.6 38.6 23.6 235.8 69.1 129.1 37.8 24.9
6016 62 16.7 251.3 73.7 205.5 60.2 18.5 237.2 69.5 199 58.3 21.1 218.5 64 190.7 55.9 23.9 200.5 58.8 182.8 53.6 26.6
2839 67 19.4 271.2 79.5 172.7 50.6 19 256.7 75.2 166.8 48.9 21.6 240.8 70.6 160.3 47 24.4 224.8 65.9 154 45.1 27
0.11 72 22.2 292.5 85.7 139.5 40.9 19.5 276.7 81.1 133.7 39.2 22.1 259.3 76 127.5 37.4 24.8 241.9 70.9 121.4 35.6 27.2
8600 62 16.7 262.7 77 244.5 71.6 18.8 245.4 71.9 237.2 69.5 21.3 227.6 66.7 227.6 66.7 24.1 210.4 61.7 210.4 61.7 26.7
52025 4059 67 19.4 289.9 85 203.2 59.6 19.5 273.7 80.2 197.1 57.8 22 256.1 75.1 190.5 55.8 24.7 235.2 68.9 182.8 53.6 27.1
0.14 72 22.2 311.5 91.3 158.7 46.5 20.1 293.5 86 152.6 44.7 22.6 274.3 80.4 146.3 42.9 25.1 0 0 0 0 0
9453 62 16.7 264.8 77.6 256.4 75.2 18.8 247.8 72.6 247.8 72.6 21.4 230 67.4 230 67.4 24.1 212.8 62.4 212.8 62.4 26.8
4461 67 19.4 294 86.2 212.4 62.3 19.6 277.5 81.3 206.2 60.4 22.1 257.8 75.6 199 58.3 24.7 236.8 69.4 191.5 56.1 27.1
0.14 72 22.2 315.5 92.5 164.4 48.2 20.2 297.1 87.1 158.3 46.4 22.7 0 0 0 0 0 0 0 0 0 0
6563 62 16.7 286.1 83.9 229.7 67.3 22.5 271 79.4 222.7 65.3 25.4 254.3 74.5 215.2 63.1 28.5 234.6 68.8 206.4 60.5 31.3
3097 67 19.4 308 90.3 193.5 56.7 23.1 292.6 85.8 187.1 54.8 26 276.1 80.9 180.4 52.9 28.9 259.7 76.1 173.7 50.9 31.6
0.11 72 22.2 332.2 97.4 157.1 46.1 23.8 315.5 92.5 150.9 44.2 26.6 297.7 87.3 144.4 42.3 29.2 279.8 82 138 40.5 31.7
9400 62 16.7 302 88.5 273.5 80.2 23 282.7 82.9 265.3 77.8 25.7 263.3 77.2 257.2 75.4 28.7 244.9 71.8 244.9 71.8 31.4
52028 4436 67 19.4 329.8 96.7 226.9 66.5 23.8 312.6 91.6 220.5 64.6 26.5 294.5 86.3 213.6 62.6 29.2 275.9 80.9 206.6 60.6 31.7
0.14 72 22.2 354.5 103.9 178.3 52.3 24.5 335.5 98.3 171.7 50.3 27.1 315.5 92.5 165.1 48.4 29.4 296 86.8 158.6 46.5 31.8
10313 62 16.7 304.1 89.1 286.1 83.8 23 285 83.5 278.2 81.5 25.8 265.9 77.9 265.9 77.9 28.7 247.6 72.6 247.6 72.6 31.5
4867 67 19.4 334.5 98 236.9 69.4 23.9 316.9 92.9 230.3 67.5 26.6 298.4 87.5 223.4 65.5 29.2 277.4 81.3 215.7 63.2 31.7
0.14 72 22.2 359.1 105.2 184.3 54 24.7 339.6 99.5 177.8 52.1 27.2 319.3 93.6 171.2 50.2 29.4 309.2 90.6 167.9 49.2 30.6
7292 62 16.7 322.4 94.5 257.4 75.4 25.7 305.8 89.6 249.6 73.2 29.1 288 84.4 241.5 70.8 32.9 266.5 78.1 231.9 68 36.3
3441 67 19.4 347.2 101.8 217.1 63.6 26.3 330.2 96.8 210 61.5 29.8 312.1 91.5 202.5 59.4 33.5 293.8 86.1 195.1 57.2 36.9
0.11 72 22.2 374.9 109.9 176.8 51.8 27.1 356.4 104.5 169.8 49.8 30.6 336.8 98.7 162.6 47.7 34.1 316.9 92.9 155.5 45.6 37.3
10400 62 16.7 342.1 100.3 306.1 89.7 26.2 320.1 93.8 296.7 87 29.5 298.3 87.4 287.5 84.3 33.1 277.6 81.4 277.6 81.4 36.5
52032 4908 67 19.4 372.1 109.1 254 74.4 27 353.1 103.5 246.7 72.3 30.5 333.1 97.6 239.2 70.1 34 312.9 91.7 231.6 67.9 37.2
0.13 72 22.2 400.8 117.5 200.2 58.7 27.9 379.6 111.3 193 56.6 31.2 357.5 104.8 185.5 54.4 34.5 335.5 98.3 178.1 52.2 37.7
11458 62 16.7 344.3 100.9 320.6 94 26.2 322.7 94.6 311.5 91.3 29.6 301.3 88.3 301.3 88.3 33.2 280.7 82.3 280.7 82.3 36.6
5408 67 19.4 377.9 110.7 265.6 77.8 27.1 358.4 105 258.2 75.7 30.6 337.8 99 250.5 73.4 34.1 315.6 92.5 242.3 71 37.3
0.14 72 22.2 406.4 119.1 207.3 60.8 28 384.7 112.7 200 58.6 31.4 362.1 106.1 192.6 56.4 34.6 339.6 99.5 185.3 54.3 37.8
8203 62 16.7 362.2 106.2 289.3 84.8 28.7 343.9 100.8 280.8 82.3 32.7 324.4 95.1 271.9 79.7 37.1 300.7 88.1 261.2 76.6 41.2
3871 67 19.4 390.5 114.5 244.2 71.6 29.3 371.7 109 236.3 69.3 33.4 351.7 103.1 228.1 66.9 37.9 331.3 97.1 219.8 64.4 42
0.11 72 22.2 422.1 123.7 199 58.3 30.2 401.5 117.7 191.3 56.1 34.4 379.8 111.3 183.3 53.7 38.7 357.4 104.8 175.2 51.4 42.7
11700 62 16.7 384.6 112.7 344.2 100.9 29.2 360.2 105.6 333.8 97.8 33.1 336.1 98.5 323.7 94.9 37.4 313.1 91.8 313.1 91.8 41.5
52036 5522 67 19.4 418.9 122.8 285.8 83.8 30.1 397.8 116.6 277.8 81.4 34.2 375.6 110.1 269.4 79 38.6 352.9 103.4 260.9 76.5 42.6
0.13 72 22.2 451.6 132.4 225.5 66.1 31 428 125.5 217.4 63.7 35.2 403.4 118.3 209.1 61.3 39.4 378.6 111 200.8 58.9 43.4
12891 62 16.7 387.1 113.5 360.5 105.7 29.3 363.2 106.5 350.6 102.7 33.2 339.5 99.5 339.5 99.5 37.5 316.6 92.8 316.6 92.8 41.6
6084 67 19.4 425.4 124.7 298.9 87.6 30.3 403.8 118.3 290.7 85.2 34.4 381 111.7 282.2 82.7 38.8 356.3 104.4 273.1 80 42.7
0.14 72 22.2 458 134.2 233.5 68.4 31.2 433.8 127.2 225.4 66.1 35.4 408.7 119.8 217.1 63.6 39.6 383.4 112.4 208.8 61.2 43.5
10208 62 16.7 423.5 124.1 347.4 101.8 32.5 401.8 117.8 337.4 98.9 36.9 373.8 109.6 324.9 95.2 41.6 346.6 101.6 313 91.7 46.1
4818 67 19.4 457.6 134.1 292 85.6 33.2 435.1 127.5 282.8 82.9 37.7 411.2 120.5 273.1 80.1 42.5 386.9 113.4 263.4 77.2 47.1
0.11 72 22.2 493.8 144.7 235.8 69.1 33.9 469.3 137.5 226.8 66.5 38.4 443 129.9 217.4 63.7 43.4 416.2 122 208 61 47.9
14600 62 16.7 442.4 129.7 413.5 121.2 32.9 415.8 121.9 402.3 117.9 37.2 389 114 389 114 42 363 106.4 363 106.4 46.5
52042 6890 67 19.4 489.3 143.4 343.9 100.8 33.8 464.2 136.1 334.4 98 38.3 437.7 128.3 324.4 95.1 43.3 406 119 312.7 91.7 47.6
0.14 72 22.2 526 154.2 268.4 78.7 34.4 498.1 146 259.1 75.9 39 468.8 137.4 249.3 73.1 44.1 454 133.1 244.5 71.7 46.5
16042 62 16.7 446.1 130.7 433.8 127.1 33 419.8 123.1 419.8 123.1 37.3 393.2 115.3 393.2 115.3 42.1 367.1 107.6 367.1 107.6 46.6
7571 67 19.4 496.3 145.5 359.5 105.4 33.9 470.6 137.9 349.8 102.5 38.5 441.2 129.3 339 99.4 43.4 408.5 119.7 327.3 95.9 47.7
0.14 72 22.2 532.8 156.2 278.1 81.5 34.4 504.3 147.8 268.7 78.8 39.2 474.3 139 259 75.9 44.3 0 0 0 0 0
12031 62 16.7 481.6 141.2 401.4 117.6 36.2 453.4 132.9 388.7 113.9 40.8 421.8 123.6 374.7 109.8 45.9 391.9 114.9 361.7 106 50.9
5678 67 19.4 520.8 152.7 336.6 98.6 36.9 495.1 145.1 326.1 95.6 41.6 467.6 137 315.1 92.4 47 439.6 128.9 304.1 89.1 52.1
0.11 72 22.2 561.6 164.6 270.5 79.3 37.2 533.4 156.3 260.3 76.3 42.2 502.8 147.4 249.5 73.1 47.9 472 138.3 238.7 70 53.1
17200 62 16.7 499.5 146.4 478 140.1 36.5 470.3 137.8 466 136.6 41.2 440.5 129.1 440.5 129.1 46.4 411.2 120.5 411.2 120.5 51.4
52046 8117 67 19.4 555.8 162.9 397.4 116.5 37.2 527.1 154.5 386.5 113.3 42.1 493.5 144.6 374 109.6 47.7 457.1 134 360.7 105.7 52.6
0.14 72 22.2 596.7 174.9 308.5 90.4 37.2 564.9 165.6 297.9 87.3 42.4 531 155.6 286.8 84.1 48.6 0 0 0 0 0
18906 62 16.7 504.2 147.8 502.3 147.2 36.6 475.2 139.3 475.2 139.3 41.3 445.3 130.5 445.3 130.5 46.5 415.9 121.9 415.9 121.9 51.5
8923 67 19.4 563.6 165.2 415.6 121.8 37.2 533.9 156.5 404.7 118.6 42.2 496.3 145.5 391 114.6 47.7 460.3 134.9 378.2 110.8 52.7
0.14 72 22.2 604.3 177.1 320 93.8 37.2 571.8 167.6 309.4 90.7 42.5 0 0 0 0 0 0 0 0 0 0
Table 7
Notes:
12
GROSS CAPACITY RATINGS - 60 H z
1633 62 16.7 64.5 18.9 54.1 15.9 5.2 60.3 17.7 52.2 15.3 5.9 56 16.4 50.3 14.7 6.6 51.9 15.2 48.6 14.2 7.3
771 67 19.4 69.7 20.4 45.3 13.3 5.3 66.2 19.4 43.9 12.9 6 62.5 18.3 42.4 12.4 6.7 58.7 17.2 40.9 12 7.4
0.11 72 22.2 75.2 22 36.3 10.6 5.4 71.3 20.9 35 10.2 6.1 67.2 19.7 33.5 9.8 6.8 63.1 18.5 32.1 9.4 7.5
2000 62 16.7 65.8 19.3 59.6 17.5 5.2 61.6 18.1 57.8 16.9 5.9 57.5 16.8 56 16.4 6.6 53.5 15.7 53.5 15.7 7.3
61006 944 67 19.4 72.5 21.2 49.7 14.6 5.3 68.7 20.1 48.3 14.1 6 64.8 19 46.8 13.7 6.7 60.2 17.6 45.1 13.2 7.4
0.12 72 22.2 78 22.9 39.1 11.5 5.4 73.9 21.7 37.7 11.1 6.1 69.5 20.4 36.2 10.6 6.9 67.3 19.7 35.5 10.4 7.2
2567 62 16.7 67.4 19.7 67.4 19.7 5.2 63.4 18.6 63.4 18.6 5.9 59.3 17.4 59.3 17.4 6.6 55.3 16.2 55.3 16.2 7.3
1211 67 19.4 75.4 22.1 56 16.4 5.4 71.2 20.9 54.5 16 6 66.1 19.4 52.6 15.4 6.8 61.4 18 51 14.9 7.4
0.14 72 22.2 80.9 23.7 43.1 12.6 5.5 76.5 22.4 41.6 12.2 6.2 0 0 0 0 0 0 0 0 0 0
1944 62 16.7 80.5 23.6 66.1 19.4 6.1 76.5 22.4 64.2 18.8 7 71.2 20.9 61.9 18.1 8 66.1 19.4 59.7 17.5 9
917 67 19.4 87.1 25.5 55.6 16.3 6.2 82.9 24.3 53.9 15.8 7.2 78.5 23 52.1 15.3 8.2 74 21.7 50.3 14.7 9.2
0.11 72 22.2 94.1 27.6 44.9 13.2 6.4 89.6 26.3 43.3 12.7 7.4 84.8 24.9 41.6 12.2 8.4 80 23.4 39.9 11.7 9.3
2500 62 16.7 83.3 24.4 74.7 21.9 6.1 78.3 23 72.5 21.2 7.1 73.2 21.5 70.4 20.6 8.1 68.4 20 68.4 20 9.1
61008 1180 67 19.4 91.5 26.8 62.3 18.3 6.3 87.1 25.5 60.6 17.8 7.3 82.3 24.1 58.8 17.2 8.3 77.5 22.7 57 16.7 9.2
0.13 72 22.2 98.6 28.9 49.2 14.4 6.5 93.7 27.5 47.5 13.9 7.5 88.6 26 45.7 13.4 8.4 83.6 24.5 44.1 12.9 9.3
3056 62 16.7 84.8 24.9 82.6 24.2 6.2 80 23.4 80 23.4 7.1 75 22 75 22 8.1 70.1 20.6 70.1 20.6 9.1
1442 67 19.4 94.5 27.7 68.5 20.1 6.4 89.8 26.3 66.7 19.6 7.4 84.5 24.8 64.8 19 8.3 78.6 23 62.6 18.3 9.2
0.14 72 22.2 101.6 29.8 53 15.5 6.7 96.4 28.3 51.3 15 7.6 91.2 26.7 49.6 14.5 8.5 0 0 0 0 0
1944 62 16.7 89 26.1 71.7 21 6.7 84.9 24.9 69.7 20.4 7.6 79.7 23.4 67.4 19.7 8.6 74.4 21.8 64.9 19 9.5
917 67 19.4 96.3 28.2 60.6 17.8 6.8 92 27 58.8 17.2 7.7 87.4 25.6 56.9 16.7 8.7 82.6 24.2 54.9 16.1 9.6
0.07 72 22.2 104 30.5 49.4 14.5 6.9 99.3 29.1 47.6 14 7.8 94.4 27.7 45.8 13.4 8.8 89.2 26.2 43.9 12.9 9.7
2700 62 16.7 93.4 27.4 84.4 24.7 6.8 88.3 25.9 82.2 24.1 7.7 83.1 24.3 80 23.4 8.6 77.9 22.8 77.8 22.8 9.6
61009 1274 67 19.4 103.5 30.3 70.8 20.7 6.9 98.7 28.9 68.9 20.2 7.8 93.6 27.4 66.9 19.6 8.8 87.6 25.7 64.7 19 9.7
0.09 72 22.2 111.4 32.7 55.9 16.4 7 106.1 31.1 54 15.8 7.9 100.6 29.5 52.1 15.3 8.9 95.1 27.9 50.2 14.7 9.8
3056 62 16.7 94.7 27.8 90.1 26.4 6.8 89.7 26.3 87.9 25.8 7.7 84.5 24.8 84.5 24.8 8.6 79.3 23.3 79.3 23.3 9.6
1442 67 19.4 105.9 31 75.2 22 7 100.9 29.6 73.3 21.5 7.9 94.9 27.8 71.1 20.8 8.8 88.6 26 68.7 20.1 9.7
0.1 72 22.2 113.7 33.3 58.6 17.2 7.1 108.2 31.7 56.7 16.6 8 102.6 30.1 54.9 16.1 9 0 0 0 0 0
2333 62 16.7 115.4 33.8 90.2 26.4 8.6 109.2 32 87.2 25.6 9.9 102.2 30 83.9 24.6 11.4 94 27.6 80.1 23.5 12.8
1101 67 19.4 124.2 36.4 76.5 22.4 8.7 117.9 34.6 73.8 21.6 10.1 110.9 32.5 70.8 20.7 11.5 103.9 30.4 67.9 19.9 12.9
0.07 72 22.2 134.1 39.3 62.9 18.4 8.9 127.3 37.3 60.2 17.6 10.2 119.8 35.1 57.4 16.8 11.7 112.4 33 54.6 16 13.1
3200 62 16.7 123.4 36.2 105.7 31 8.7 115 33.7 102 29.9 10 106.3 31.2 98.2 28.8 11.4 98.2 28.8 94.7 27.8 12.8
61011 1510 67 19.4 133.5 39.1 88.3 25.9 8.9 126.4 37.1 85.4 25 10.2 118.8 34.8 82.4 24.1 11.7 111.2 32.6 79.4 23.3 13
0.09 72 22.2 143.8 42.1 70.4 20.6 9 136.1 39.9 67.7 19.8 10.4 127.7 37.4 64.7 19 11.8 119.5 35 61.9 18.1 13.2
3667 62 16.7 124.8 36.6 112.9 33.1 8.8 116.6 34.2 109.3 32 10 108.2 31.7 105.8 31 11.5 100.1 29.4 100.1 29.4 12.9
1731 67 19.4 137 40.1 94.1 27.6 8.9 129.6 38 91.2 26.7 10.2 121.7 35.7 88.2 25.9 11.7 112.9 33.1 84.9 24.9 13.1
0.1 72 22.2 147.3 43.2 74.1 21.7 9 139.2 40.8 71.3 20.9 10.4 130.6 38.3 68.3 20 11.9 126.3 37 66.9 19.6 12.6
3135 62 16.7 133 39 108 31.7 10.2 125.4 36.8 104.6 30.6 11.7 116.1 34 100.4 29.4 13.4 106.7 31.3 96.2 28.2 14.9
1480 67 19.4 143.4 42 90.9 26.6 10.4 135.7 39.8 87.7 25.7 12 127.4 37.4 84.3 24.7 13.6 119.2 34.9 81.1 23.8 15.2
0.11 72 22.2 154.6 45.3 73.5 21.5 10.6 146.2 42.9 70.4 20.6 12.2 137.3 40.2 67.2 19.7 13.9 128.5 37.7 64.1 18.8 15.4
4500 62 16.7 139.5 40.9 128.7 37.7 10.3 130.2 38.1 124.8 36.6 11.8 120.8 35.4 120.8 35.4 13.5 111.9 32.8 111.9 32.8 15
61014 2124 67 19.4 153.4 45 106.9 31.3 10.6 144.8 42.4 103.7 30.4 12.2 135.8 39.8 100.3 29.4 13.8 125.4 36.8 96.5 28.3 15.3
0.14 72 22.2 164.7 48.3 83.6 24.5 10.8 155.3 45.5 80.4 23.6 12.4 145.5 42.6 77.2 22.6 14.1 140.7 41.2 75.6 22.2 14.9
4927 62 16.7 140.5 41.2 134.7 39.5 10.3 131.3 38.5 130.9 38.4 11.9 122 35.8 122 35.8 13.5 113.1 33.2 113.1 33.2 15
2325 67 19.4 155.5 45.6 111.6 32.7 10.6 146.7 43 108.3 31.7 12.2 137.1 40.2 104.7 30.7 13.9 126.2 37 100.8 29.5 15.3
0.14 72 22.2 166.8 48.9 86.5 25.3 10.9 157.1 46.1 83.3 24.4 12.5 147.1 43.1 80 23.5 14.2 0 0 0 0 0
3135 62 16.7 127.5 37.4 105.5 30.9 10.4 119.9 35.2 102.1 29.9 11.8 111.1 32.6 98.2 28.8 13.3 102.9 30.1 94.6 27.7 14.6
1480 67 19.4 137.6 40.3 88.5 25.9 10.5 130.6 38.3 85.6 25.1 11.9 123.3 36.1 82.7 24.2 13.3 116 34 79.8 23.4 14.7
0.11 72 22.2 148.4 43.5 71.2 20.9 10.7 140.9 41.3 68.5 20.1 12.1 132.9 39 65.7 19.2 13.5 124.8 36.6 62.8 18.4 14.9
4170 62 16.7 131.6 38.6 121 35.5 10.5 123.3 36.1 117.5 34.4 11.8 115 33.7 114.1 33.4 13.3 107.2 31.4 107.2 31.4 14.6
62011 1968 67 19.4 145.2 42.6 100.8 29.5 10.6 137.7 40.4 98 28.7 12 129.8 38 95 27.8 13.5 120.5 35.3 91.5 26.8 14.8
0.13 72 22.2 156.2 45.8 79 23.2 10.8 147.9 43.4 76.2 22.3 12.2 139.2 40.8 73.3 21.5 13.7 134.7 39.5 71.8 21 14.5
4927 62 16.7 133.6 39.2 131.8 38.6 10.5 125.5 36.8 125.5 36.8 11.8 117.4 34.4 117.4 34.4 13.3 109.5 32.1 109.5 32.1 14.6
2325 67 19.4 149 43.7 109.1 32 10.7 141.2 41.4 106.2 31.1 12.1 131.6 38.6 102.7 30.1 13.5 121.9 35.7 99.3 29.1 14.8
0.14 72 22.2 160 46.9 84.2 24.7 10.9 151.4 44.4 81.4 23.9 12.3 0 0 0 0 0 0 0 0 0 0
4083 62 16.7 163.5 47.9 136.2 39.9 12.2 154.1 45.2 132 38.7 14.1 143.6 42.1 127.4 37.3 16.1 133.6 39.2 123 36.1 18.1
1927 67 19.4 177.1 51.9 114.4 33.5 12.5 168.6 49.4 110.9 32.5 14.4 159.5 46.8 107.3 31.4 16.5 150.4 44.1 103.7 30.4 18.4
0.11 72 22.2 191.2 56 92 27 12.9 182 53.3 88.7 26 14.8 172.1 50.5 85.2 25 16.8 162.4 47.6 81.8 24 18.5
5200 62 16.7 167.8 49.2 153 44.9 12.3 157.9 46.3 148.8 43.6 14.1 147.9 43.4 144.6 42.4 16.2 138.2 40.5 138.2 40.5 18.2
62014 2454 67 19.4 185.6 54.4 127.8 37.5 12.7 176.5 51.7 124.3 36.4 14.6 166.8 48.9 120.7 35.4 16.6 155.8 45.7 116.5 34.2 18.5
0.12 72 22.2 199.8 58.6 100.5 29.5 13.2 189.7 55.6 97.1 28.4 15 179.4 52.6 93.6 27.4 16.9 174.3 51.1 91.9 26.9 17.8
6417 62 16.7 171.3 50.2 170.6 50 12.4 161.7 47.4 161.7 47.4 14.2 151.8 44.5 151.8 44.5 16.3 142 41.6 142 41.6 18.2
3028 67 19.4 191.9 56.3 141.3 41.4 12.9 182.3 53.4 137.7 40.4 14.8 170.1 49.9 133.3 39.1 16.7 158.4 46.4 129.1 37.8 18.5
0.14 72 22.2 205.8 60.3 108.8 31.9 13.4 195.3 57.3 105.4 30.9 15.2 0 0 0 0 0 0 0 0 0 0
4083 62 16.7 179 52.5 146.8 43 13.9 169.2 49.6 142.3 41.7 15.6 158.4 46.4 137.3 40.3 17.6 148 43.4 132.7 38.9 19.4
1927 67 19.4 193.8 56.8 123.8 36.3 14.1 184.8 54.2 120 35.2 15.9 175.4 51.4 116.1 34 17.9 165.7 48.6 112.2 32.9 19.7
0.07 72 22.2 209.2 61.3 100.2 29.4 14.3 199.4 58.4 96.6 28.3 16.2 189.1 55.4 92.7 27.2 18.1 178.7 52.4 89 26.1 19.9
5200 62 16.7 184.3 54 165.3 48.4 13.9 174 51 160.8 47.1 15.7 163.7 48 156.3 45.8 17.7 153.5 45 152.1 44.6 19.5
62018 2454 67 19.4 204.3 59.9 138.9 40.7 14.3 194.6 57 135 39.6 16.1 184.4 54 131 38.4 18.1 172.2 50.5 126.4 37 19.8
0.08 72 22.2 219.7 64.4 109.7 32.2 14.5 209 61.2 106 31.1 16.4 198.1 58.1 102.2 30 18.3 192.6 56.5 100.3 29.4 19.2
6417 62 16.7 189.1 55.4 185 54.2 14 179 52.5 179 52.5 15.8 168.7 49.4 168.7 49.4 17.8 158.4 46.4 158.4 46.4 19.6
3028 67 19.4 212.4 62.2 154.1 45.2 14.4 200.9 58.9 149.8 43.9 16.2 188 55.1 144.9 42.5 18.1 175.6 51.5 140.4 41.2 19.9
0.1 72 22.2 227.5 66.7 119.2 34.9 14.7 216.2 63.4 115.4 33.8 16.5 0 0 0 0 0 0 0 0 0 0
Table8
Notes:
13
GROSS CAPACITY RATINGS - 60 H z
4769 62 16.7 227.3 66.6 180.2 52.8 18.4 214 62.7 173.8 50.9 21.1 198.7 58.2 166.6 48.8 24 182.2 53.4 159.2 46.6 26.6
2251 67 19.4 244.7 71.7 152.4 44.7 18.7 231.2 67.8 146.6 43 21.5 217 63.6 140.6 41.2 24.4 203.4 59.6 135 39.6 26.9
0.07 72 22.2 263.6 77.3 124.4 36.5 19 249.1 73 118.9 34.8 21.9 234.2 68.6 113.2 33.2 24.8 219.7 64.4 107.9 31.6 27.2
6600 62 16.7 240.2 70.4 211.6 62 18.6 223.3 65.4 204.2 59.8 21.3 206.6 60.6 197 57.7 24.2 191.4 56.1 190.6 55.9 26.7
62023 3115 67 19.4 262.5 76.9 176.8 51.8 19 247.5 72.6 170.9 50.1 21.8 232.1 68 164.9 48.3 24.7 215.9 63.3 158.7 46.5 27.2
0.09 72 22.2 281.9 82.6 139.9 41 19.4 265.6 77.9 134.2 39.3 22.3 248.9 73 128.4 37.6 25.2 240.9 70.6 125.7 36.8 26.4
7494 62 16.7 243.1 71.2 225.5 66.1 18.7 226.6 66.4 218.5 64 21.4 210.2 61.6 210.2 61.6 24.2 195 57.2 195 57.2 26.8
3537 67 19.4 268.5 78.7 187.8 55 19.1 253.1 74.2 181.9 53.3 22 236.3 69.3 175.6 51.5 24.8 218.1 63.9 168.7 49.5 27.2
0.1 72 22.2 287.8 84.4 146.8 43 19.5 271 79.4 141 41.3 22.4 253.8 74.4 135.2 39.6 25.3 0 0 0 0 0
5104 62 16.7 253.8 74.4 198 58 20.6 239.3 70.1 190.9 56 23.9 223.8 65.6 183.5 53.8 27.2 206 60.4 175.3 51.4 30.3
2409 67 19.4 272.6 79.9 167.8 49.2 21.1 257.9 75.6 161.4 47.3 24.3 242.3 71 154.7 45.4 27.7 226.9 66.5 148.3 43.5 30.7
0.07 72 22.2 294.1 86.2 137.8 40.4 21.6 278.1 81.5 131.6 38.6 24.8 261.4 76.6 125.3 36.7 28.1 245 71.8 119.1 34.9 31
7300 62 16.7 272.1 79.8 236.4 69.3 21.1 252.7 74.1 227.9 66.8 24.2 233.7 68.5 219.7 64.4 27.5 216.1 63.3 212.2 62.2 30.5
62026 3445 67 19.4 295.1 86.5 197.1 57.8 21.6 278.5 81.6 190.5 55.8 24.8 261.1 76.5 183.7 53.8 28.1 244.1 71.5 177.2 51.9 31
0.1 72 22.2 317.4 93 156.6 45.9 22.1 299.1 87.7 150.1 44 25.4 280.2 82.1 143.5 42.1 28.7 271 79.4 140.4 41.1 30.2
8021 62 16.7 274.1 80.3 247.4 72.5 21.1 255.2 74.8 239.2 70.1 24.3 236.5 69.3 231.3 67.8 27.5 219 64.2 219 64.2 30.5
3785 67 19.4 300.3 88 206 60.4 21.8 283.2 83 199.4 58.4 25 265.3 77.8 192.6 56.5 28.2 245.8 72 185.2 54.3 31.1
0.1 72 22.2 322.5 94.5 162.1 47.5 22.3 303.6 89 155.6 45.6 25.5 284.3 83.3 149 43.7 28.8 275 80.6 145.9 42.8 30.3
6016 62 16.7 290.1 85 228.9 67.1 22.5 273.5 80.2 220.9 64.8 25.7 254.8 74.7 212.1 62.2 29.2 232.9 68.3 202.1 59.2 32.4
2839 67 19.4 312.3 91.5 193.8 56.8 23 295.3 86.6 186.5 54.7 26.2 276.8 81.1 178.7 52.4 29.6 258.6 75.8 171.2 50.2 32.8
0.07 72 22.2 337 98.8 158.7 46.5 23.5 318.5 93.3 151.6 44.4 26.7 298.6 87.5 144.1 42.2 30.1 278.9 81.8 136.8 40.1 33.1
8600 62 16.7 308.5 90.4 273.2 80.1 22.9 287.1 84.2 263.9 77.3 26 265.5 77.8 254.6 74.6 29.4 245.1 71.8 245.1 71.8 32.6
62030 4059 67 19.4 337.7 99 228.3 66.9 23.5 318.5 93.3 220.7 64.7 26.7 297.9 87.3 212.7 62.3 30.1 275.4 80.7 204.2 59.9 33.1
0.1 72 22.2 363.1 106.4 180.6 52.9 24.1 341.7 100.1 173.1 50.7 27.3 319.2 93.6 165.4 48.5 30.5 308.3 90.3 161.6 47.4 32
9453 62 16.7 311.2 91.2 286.4 83.9 22.9 290.2 85.1 277.4 81.3 26.1 268.8 78.8 268.5 78.7 29.5 248.5 72.8 248.5 72.8 32.6
4461 67 19.4 343.6 100.7 238.8 70 23.6 323.8 94.9 231.2 67.8 26.9 302.3 88.6 223.1 65.4 30.2 277.4 81.3 213.7 62.6 33.1
0.1 72 22.2 368.7 108.1 187.1 54.8 24.2 346.7 101.6 179.6 52.6 27.4 323.8 94.9 171.8 50.4 30.6 0 0 0 0 0
6563 62 16.7 330.2 96.8 256.4 75.2 27.5 312.7 91.7 247.9 72.7 31 294.1 86.2 239 70 34.6 274 80.3 229.6 67.3 38
3097 67 19.4 354.3 103.8 217.5 63.7 28.1 336.5 98.6 209.6 61.4 31.6 317.6 93.1 201.5 59.1 35.3 298.8 87.6 193.6 56.7 38.6
0.07 72 22.2 382 112 178.8 52.4 28.8 362.7 106.3 171.2 50.2 32.3 342.3 100.3 163.4 47.9 35.9 322.2 94.4 155.8 45.7 39.3
9400 62 16.7 355 104 306.5 89.8 28.1 331.3 97.1 296 86.8 31.5 307.9 90.2 285.8 83.8 35 286.1 83.8 276.6 81.1 38.3
62034 4436 67 19.4 383.6 112.4 255.3 74.8 28.9 363.4 106.5 247.2 72.5 32.3 342.2 100.3 238.9 70 35.9 321.4 94.2 230.9 67.7 39.2
0.1 72 22.2 412.5 120.9 202.9 59.5 29.5 390.2 114.4 195.1 57.2 33 366.9 107.5 186.9 54.8 36.6 344.4 100.9 179.2 52.5 39.9
10313 62 16.7 357.4 104.8 320.2 93.9 28.2 334.2 98 310.2 90.9 31.6 311.2 91.2 300.4 88.1 35.1 289.6 84.9 289.6 84.9 38.4
4867 67 19.4 390.2 114.4 266.5 78.1 29 369.4 108.3 258.4 75.7 32.5 347.7 101.9 250.1 73.3 36.1 325.1 95.3 241.6 70.8 39.3
0.1 72 22.2 419.1 122.8 210 61.6 29.7 396 116.1 202 59.2 33.2 372.2 109.1 193.8 56.8 36.7 360.6 105.7 189.9 55.7 38.4
7292 62 16.7 372.9 109.3 287.9 84.4 31.4 353.9 103.7 278.6 81.6 35.4 333.7 97.8 268.8 78.8 39.7 313.2 91.8 259.2 76 43.7
3441 67 19.4 401.1 117.6 245 71.8 32.1 381 111.7 236 69.2 36.2 360.4 105.6 227.1 66.6 40.5 339.6 99.5 218.3 64 44.4
0.07 72 22.2 432.4 126.7 201.8 59.2 33 411.2 120.5 193.4 56.7 37.1 388.9 114 184.8 54.2 41.3 366.6 107.5 176.4 51.7 45
10400 62 16.7 401.7 117.7 343.2 100.6 32.2 377.1 110.5 332.2 97.4 36.1 350.8 102.8 320.7 94 40.2 326.1 95.6 310.1 90.9 44
62038 4908 67 19.4 434.2 127.3 286.5 84 33 412.1 120.8 277.6 81.4 37.1 388.9 114 268.4 78.7 41.2 365.7 107.2 259.3 76 45
0.09 72 22.2 467.6 137.1 228.6 67 33.9 443.4 130 220 64.5 38 417.9 122.5 211 61.9 42 392.6 115.1 202.3 59.3 45.7
11458 62 16.7 406.6 119.2 359.9 105.5 32.3 380.4 111.5 348.5 102.2 36.2 354.6 103.9 337.5 98.9 40.3 330.2 96.8 327.3 95.9 44.1
5408 67 19.4 442.3 129.6 299.5 87.8 33.3 419.5 122.9 290.6 85.2 37.3 395.6 116 281.4 82.5 41.4 371.8 109 272.4 79.8 45.2
0.1 72 22.2 475.9 139.5 237 69.5 34.2 450.6 132.1 228.1 66.9 38.2 424.4 124.4 219.1 64.2 42.2 411.4 120.6 214.6 62.9 44.1
8203 62 16.7 418.5 122.7 323.4 94.8 35.4 397.7 116.6 313.1 91.8 40 375.6 110.1 302.5 88.7 44.9 353 103.5 291.8 85.5 49.4
3871 67 19.4 450.6 132.1 275.3 80.7 36.3 428.5 125.6 265.5 77.8 40.9 405.9 119 255.7 74.9 45.8 382.9 112.2 245.9 72.1 50.2
0.07 72 22.2 486.2 142.5 227 66.5 37.3 462.9 135.7 217.7 63.8 42 438.4 128.5 208.2 61 46.7 413.6 121.2 198.9 58.3 50.9
11700 62 16.7 451.3 132.3 385.8 113.1 36.3 424.1 124.3 373.7 109.5 40.8 395.1 115.8 361 105.8 45.5 367.7 107.8 349.2 102.4 49.8
62042 5522 67 19.4 488.3 143.1 322.2 94.4 37.4 463.9 136 312.4 91.6 42 438.4 128.5 302.3 88.6 46.7 412.6 120.9 292.2 85.7 50.9
0.09 72 22.2 526.3 154.3 257.2 75.4 38.5 499.6 146.4 247.7 72.6 43.1 471.5 138.2 237.9 69.7 47.7 457.3 134 232.9 68.3 49.8
12891 62 16.7 456.7 133.9 404.6 118.6 36.5 427.8 125.4 392 114.9 40.9 399.4 117.1 379.9 111.4 45.6 372.4 109.1 368.6 108 49.9
6084 67 19.4 497.5 145.8 337 98.8 37.6 472.3 138.4 327.1 95.9 42.3 446.1 130.8 317 92.9 46.9 419.6 123 307 90 51.1
0.1 72 22.2 535.8 157 266.7 78.2 38.8 507.8 148.8 256.9 75.3 43.3 479 140.4 247 72.4 47.9 464.5 136.1 242 70.9 49.9
10208 62 16.7 490.1 143.6 387.3 113.5 40.3 465.3 136.4 375.4 110 45.3 438.9 128.6 363 106.4 50.7 406.4 119.1 348.1 102 55.5
4818 67 19.4 527.9 154.7 328.1 96.2 41.2 502.4 147.3 317 92.9 46.4 475.3 139.3 305.5 89.6 51.8 447.8 131.3 294.2 86.2 56.8
0.07 72 22.2 569.8 167 268.5 78.7 42.4 541.8 158.8 257.7 75.5 47.6 512.5 150.2 246.7 72.3 53 482.5 141.4 235.5 69 57.9
14600 62 16.7 520.9 152.7 462.6 135.6 41 488.7 143.2 448.5 131.5 46 456.8 133.9 434.9 127.5 51.2 426.3 124.9 422 123.7 56.1
62048 6890 67 19.4 571.1 167.4 386.6 113.3 42.4 542 158.8 375.1 110 47.6 511.5 149.9 363.3 106.5 53 478.9 140.4 351 102.9 57.7
0.1 72 22.2 614.1 180 305.8 89.6 43.8 581.7 170.5 294.5 86.3 49 548.2 160.7 282.9 82.9 54.3 514.7 150.9 271.5 79.6 58.9
16042 62 16.7 525.5 154 484.9 142.1 41.2 493.9 144.8 471.4 138.2 46.1 462.4 135.5 458.2 134.3 51.4 431.9 126.6 431.9 126.6 56.3
7571 67 19.4 580.9 170.3 404.4 118.5 42.7 550.9 161.5 392.8 115.1 47.9 519.6 152.3 381 111.7 53.2 482.1 141.3 366.9 107.5 57.8
0.1 72 22.2 623.6 182.8 316.8 92.9 44.1 590.4 173 305.4 89.5 49.4 556.2 163 293.8 86.1 54.6 539 158 288 84.4 57
12031 62 16.7 557.1 163.3 446.6 130.9 45.1 528.6 154.9 433.2 127 50.6 494.3 144.9 417.2 122.3 56.3 458.3 134.3 400.9 117.5 61.7
5678 67 19.4 600.9 176.1 377.4 110.6 46.1 571.5 167.5 364.9 106.9 51.8 540.2 158.3 351.8 103.1 57.8 508.6 149.1 338.8 99.3 63.4
0.07 72 22.2 647.9 189.9 307.2 90 47.4 615.6 180.4 295.1 86.5 53.3 581.6 170.5 282.3 82.7 59.4 546.8 160.3 269.5 79 64.9
17200 62 16.7 586.8 172 533.2 156.3 45.8 551.6 161.7 518 151.8 51.2 516.3 151.3 503.1 147.5 57 482.2 141.3 482.2 141.3 62.5
62054 8117 67 19.4 648.4 190 445.8 130.7 47.4 614.9 180.2 432.8 126.8 53.2 579.7 169.9 419.4 122.9 59.3 537.7 157.6 403.6 118.3 64.5
0.1 72 22.2 695.7 203.9 350.6 102.8 49.1 658.5 193 337.6 99 55.1 620 181.7 324.4 95.1 61 600.8 176.1 317.9 93.2 63.8
18906 62 16.7 592.7 173.7 560.1 164.2 45.9 558 163.6 545.5 159.9 51.4 522.9 153.3 522.9 153.3 57.2 488.6 143.2 488.6 143.2 62.7
8923 67 19.4 659.2 193.2 466.7 136.8 47.8 624.7 183.1 453.7 133 53.6 584.3 171.3 438.5 128.5 59.5 541.8 158.8 422.6 123.9 64.7
0.1 72 22.2 706.1 206.9 363.5 106.5 49.6 667.9 195.8 350.4 102.7 55.5 0 0 0 0 0 0 0 0 0 0
Table 9
Notes:
14
FAN PERFORMANCE 50Hz
Internal Static External Static Pressure - in.wg(Pa)
Model AirFlowRate
Pressure 0 (0) 0.2 (50) 0.4 (100) 0.6 (150) 0.8 (200) 1 (250) 1.2 (300) 1.4 (350) 1.6 (400) 1.8 (450) 2 (500)
APMR
cfm l/s in.wg Pa RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW
1633 771 0.41 101.69 620 0.18 730 0.23 833 0.28 932 0.34 1024 0.39 1112 0.45 1195 0.52 1273 0.58 1348 0.65 1419 0.72 1488 0.79
51005 2000 944 0.63 156.81 768 0.34 857 0.39 944 0.45 1028 0.52 1109 0.58 1186 0.65 1261 0.72 1333 0.8 1402 0.87 1469 0.95 1533 1.03
2567 1211 1.07 266.89 997 0.72 1067 0.79 1136 0.87 1203 0.94 1269 1.02 1334 1.11 1397 1.19 1459 1.28 1519 1.37 1577 1.46 1635 1.55
1944 917 0.41 101.68 658 0.26 752 0.31 844 0.37 933 0.43 1019 0.49 1101 0.56 1180 0.62 1255 0.69 1328 0.77 1398 0.84 1465 0.92
51007 2500 1180 0.7 174.33 855 0.56 929 0.62 1002 0.69 1073 0.76 1143 0.84 1211 0.92 1278 1 1343 1.08 1407 1.16 1469 1.25 1529 1.34
3056 1442 1.07 266.9 1053 1.03 1114 1.11 1173 1.19 1232 1.27 1291 1.36 1348 1.45 1405 1.54 1461 1.64 1516 1.73 1571 1.83 1624 1.93
1944 917 0.47 117.64 688 0.28 782 0.33 873 0.39 961 0.45 1045 0.51 1126 0.58 1204 0.65 1279 0.72 1351 0.79 1420 0.87 1486 0.94
51008 2700 1274 0.96 238.72 972 0.75 1040 0.82 1107 0.9 1172 0.98 1237 1.06 1300 1.14 1362 1.23 1423 1.32 1483 1.41 1541 1.5 1598 1.59
3056 1442 1.25 310.45 1106 1.1 1166 1.18 1225 1.26 1284 1.35 1341 1.44 1398 1.53 1454 1.63 1510 1.72 1564 1.82 1618 1.92 1670 2.02
2333 1101 0.47 117.66 557 0.28 649 0.35 739 0.43 824 0.51 905 0.6 981 0.69 1053 0.79 1120 0.89 1185 0.99 1246 1.1 1304 1.2
51009 3200 1510 0.93 232.41 779 0.74 846 0.84 913 0.94 979 1.04 1042 1.15 1105 1.26 1165 1.38 1224 1.5 1280 1.63 1335 1.75 1389 1.88
3667 1730 1.25 310.42 899 1.13 958 1.23 1016 1.35 1074 1.46 1131 1.58 1186 1.71 1241 1.84 1295 1.97 1347 2.11 1398 2.24 1448 2.38
3135 1479 0.41 101.7 443 0.33 521 0.41 596 0.51 668 0.62 736 0.73 800 0.86 860 0.98 917 1.11 971 1.25 1023 1.39 1072 1.53
51012 4500 2124 0.89 220.78 648 0.98 703 1.1 757 1.23 809 1.37 861 1.52 912 1.67 961 1.83 1009 1.99 1055 2.16 1100 2.33 1144 2.5
4927 2325 1.07 266.81 712 1.29 762 1.43 811 1.57 860 1.72 908 1.87 954 2.03 1000 2.2 1045 2.37 1089 2.55 1132 2.73 1174 2.91
3135 1479 0.41 101.7 443 0.33 521 0.41 596 0.51 668 0.62 736 0.73 800 0.86 860 0.98 917 1.11 971 1.25 1023 1.39 1072 1.53
52010 4170 1968 0.75 187.57 598 0.78 657 0.89 715 1.01 772 1.14 827 1.28 880 1.43 932 1.58 982 1.73 1031 1.89 1078 2.06 1123 2.22
4927 2325 1.07 266.81 712 1.29 762 1.43 811 1.57 860 1.72 908 1.87 954 2.03 1000 2.2 1045 2.37 1089 2.55 1132 2.73 1174 2.91
4083 1927 0.41 101.72 488 0.57 551 0.67 612 0.78 672 0.89 730 1.02 787 1.15 842 1.29 896 1.43 948 1.58 998 1.74 1046 1.9
52013 5200 2454 0.69 170.75 627 1.19 677 1.31 725 1.44 773 1.58 820 1.73 867 1.88 913 2.03 958 2.2 1003 2.37 1046 2.54 1089 2.72
6417 3028 1.07 266.85 779 2.25 819 2.4 859 2.56 898 2.72 937 2.89 976 3.06 1014 3.24 1052 3.43 1089 3.62 1126 3.82 1163 4.02
4083 1927 0.47 117.67 508 0.6 570 0.7 631 0.81 690 0.93 748 1.06 805 1.19 860 1.33 913 1.48 964 1.63 1013 1.79 1061 1.95
52015 5200 2454 0.79 197.87 654 1.25 703 1.38 751 1.52 799 1.66 846 1.81 892 1.96 938 2.12 982 2.29 1026 2.46 1070 2.64 1112 2.82
6417 3028 1.25 310.39 814 2.38 854 2.54 893 2.7 932 2.87 971 3.04 1009 3.22 1047 3.41 1085 3.6 1122 3.79 1159 3.99 1195 4.2
4769 2250 0.43 107.07 0 0 663 0.75 756 0.91 845 1.09 930 1.28 1011 1.47 1087 1.68 1159 1.89 1227 2.11 1292 2.34 1354 2.57
52019 6600 3115 0.88 218.22 803 1.63 872 1.83 941 2.04 1008 2.27 1075 2.5 1139 2.75 1202 3 1264 3.26 - - - - - -
7494 3536 1.15 286.84 918 2.4 979 2.63 1040 2.87 1100 3.12 - - - - - - - - - - - - - -
5104 2409 0.43 107.05 0 0 668 0.84 757 1.01 843 1.19 925 1.38 1004 1.58 1079 1.8 1150 2.02 1219 2.24 1283 2.47 1346 2.71
52022 7300 3445 0.94 234.43 847 2.06 910 2.28 972 2.5 1034 2.74 1096 2.98 1156 3.24 - - - - - - - - - -
8021 3785 1.15 286.83 935 2.75 992 2.98 1049 3.23 1106 3.49 1162 3.75 1218 4.02 1272 4.3 - - - - - - - -
6016 2839 0.43 107.07 0 0 554 0.85 635 1.06 711 1.29 783 1.54 850 1.8 913 2.06 973 2.34 1029 2.62 1083 2.91 1135 3.21
52025 8600 4058 0.94 234.21 690 2 749 2.27 807 2.55 864 2.84 920 3.16 973 3.48 1026 3.82 1076 4.16 1125 4.52 1169 4.88 - -
9453 4461 1.15 286.81 762 2.68 816 2.97 870 3.27 922 3.59 973 3.93 1023 4.27 1068 4.63 1116 5 1162 5.38 - - - -
6563 3097 0.43 107.08 0 0 558 0.98 635 1.19 708 1.43 777 1.68 843 1.95 906 2.23 965 2.51 1021 2.81 1075 3.11 1127 3.42
52028 9400 4436 0.94 235.2 704 2.37 759 2.64 814 2.93 867 3.23 920 3.55 971 3.89 1021 4.23 1066 4.58 1114 4.95 1160 5.33 - -
10313 4867 1.15 286.85 776 3.14 827 3.44 877 3.76 926 4.09 974 4.43 1018 4.79 1065 5.15 1110 5.53 1155 5.92 1199 6.32 - -
7292 3441 0.43 107.07 0 0 568 1.17 639 1.4 707 1.64 773 1.9 836 2.18 897 2.46 955 2.77 1011 3.08 1064 3.4 1116 3.72
52032 10400 4908 0.94 233.03 723 2.89 774 3.17 824 3.47 874 3.78 922 4.11 970 4.45 1016 4.82 1062 5.19 1108 5.57 1152 5.96 1196 6.36
11458 5407 1.15 286.8 800 3.88 847 4.19 892 4.52 935 4.87 979 5.22 1023 5.59 1066 5.96 1109 6.35 1151 6.75 1193 7.16 - -
8203 3871 0.43 107.06 0 0 586 1.47 650 1.71 712 1.96 773 2.23 833 2.51 890 2.81 946 3.13 1000 3.45 1053 3.78 1103 4.13
52036 11700 5521 0.94 233.03 756 3.72 803 4.03 848 4.34 892 4.69 936 5.03 980 5.39 1023 5.75 1066 6.13 1108 6.52 1149 6.93 1191 7.34
12891 6083 1.15 286.84 0 0 877 5.35 918 5.7 958 6.06 999 6.42 1039 6.8 1078 7.19 1118 7.59 1156 8.01 1195 8.43 - -
10208 4817 0.43 107.05 0 0 478 1.63 538 1.96 594 2.3 648 2.66 700 3.03 749 3.41 796 3.81 841 4.22 884 4.65 926 5.08
52042 14600 6890 0.94 234.43 607 4.01 651 4.44 695 4.89 737 5.35 778 5.82 818 6.31 857 6.81 895 7.31 932 7.83 968 8.36 - -
16042 7570 1.15 286.83 670 5.35 710 5.83 750 6.32 789 6.82 827 7.33 864 7.86 900 8.39 935 8.93 970 9.49 - - - -
12031 5677 0.43 107.06 441 1.88 497 2.23 551 2.59 603 2.97 652 3.36 700 3.76 746 4.18 791 4.61 834 5.05 875 5.51 916 5.97
52046 17200 8117 0.94 234.21 643 5.64 683 6.13 721 6.63 759 7.15 796 7.67 833 8.21 868 8.75 903 9.3 937 9.87 971 10.44 - -
18906 8922 1.15 286.81 0 0 746 8.07 781 8.62 816 9.18 850 9.75 883 10.33 916 10.91 949 11.51 981 12.12 - - - -
Table 10
Notes :
1. Areas shaded in grey indicate the operating range of a standard fan motor; out of this range shift to next larger motor size.
2. Internal static pressure is based on pressure drops through evaporator coil, fan casing and 2" washable flat filters.
3. For external static pressure more than 2.0 in.wg. (498 Pa) and for the data corresponding to the blank boxes, please consult SKM.
15
FAN PERFORMANCE 60Hz
Internal Static External Static Pressure - in.wg(Pa)
Model AirFlowRate
Pressure 0 (0) 0.2 (50) 0.4 (100) 0.6 (150) 0.8 (200) 1 (250) 1.2 (300) 1.4 (350) 1.6 (400) 1.8 (450) 2 (500)
APMR
cfm l/s in.wg Pa RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW RPM kW
1633 771 0.47 117.64 656 0.2 763 0.24 866 0.3 962 0.35 1053 0.41 1139 0.47 1220 0.54 1297 0.6 1371 0.67 1442 0.74 1509 0.81
61006 2000 944 0.73 181.65 813 0.36 901 0.42 986 0.48 1068 0.55 1148 0.62 1224 0.69 1297 0.76 1368 0.84 1436 0.91 1501 0.99 1565 1.07
2567 1211 1.25 310.44 1059 0.78 1127 0.86 1195 0.93 1261 1.01 1326 1.1 1389 1.18 1451 1.27 1511 1.36 1570 1.45 1628 1.54 1684 1.64
1944 917 0.47 117.64 688 0.28 782 0.33 873 0.39 961 0.45 1045 0.51 1126 0.58 1204 0.65 1279 0.72 1351 0.79 1420 0.87 1486 0.94
61008 2500 1180 0.81 202.03 896 0.59 969 0.66 1041 0.73 1112 0.81 1181 0.88 1248 0.96 1314 1.04 1379 1.13 1441 1.21 1502 1.3 1562 1.39
3056 1442 1.25 310.45 1106 1.1 1166 1.18 1225 1.26 1284 1.35 1341 1.44 1398 1.53 1454 1.63 1510 1.72 1564 1.82 1618 1.92 1670 2.02
1944 917 0.54 133.59 719 0.29 812 0.35 902 0.41 988 0.47 1072 0.53 1152 0.6 1229 0.67 1302 0.74 1373 0.81 1441 0.89 1507 0.97
61009 2700 1274 1.09 271.66 1017 0.8 1084 0.87 1150 0.95 1215 1.03 1279 1.11 1341 1.2 1403 1.29 1463 1.38 1521 1.47 1579 1.56 1635 1.66
3056 1442 1.42 354 1158 1.17 1218 1.25 1276 1.34 1334 1.43 1391 1.52 1447 1.61 1503 1.71 1557 1.81 1611 1.91 1664 2.01 1715 2.11
2333 1101 0.54 133.61 587 0.3 678 0.38 767 0.46 850 0.54 930 0.63 1004 0.72 1075 0.82 1141 0.92 1205 1.02 1265 1.13 1323 1.24
61011 3200 1510 1.06 264.44 822 0.8 889 0.9 955 1 1020 1.11 1083 1.22 1144 1.34 1203 1.46 1260 1.58 1316 1.71 1370 1.84 1422 1.97
3667 1730 1.42 353.96 950 1.22 1009 1.33 1067 1.45 1124 1.57 1179 1.69 1234 1.82 1288 1.95 1340 2.09 1391 2.23 1441 2.37 1490 2.51
3135 1479 0.47 117.66 468 0.35 545 0.44 620 0.55 690 0.66 757 0.77 819 0.9 879 1.02 935 1.16 988 1.29 1039 1.43 1087 1.57
61014 4500 2124 1.03 256.27 687 1.07 741 1.2 794 1.33 846 1.48 897 1.63 947 1.78 995 1.94 1042 2.11 1088 2.28 1132 2.45 1175 2.63
4927 2325 1.25 310.35 755 1.41 805 1.55 854 1.7 902 1.85 949 2.01 995 2.18 1040 2.35 1084 2.52 1127 2.7 1169 2.89 0 0
3135 1479 0.47 117.66 468 0.35 545 0.44 620 0.55 690 0.66 757 0.77 819 0.9 879 1.02 935 1.16 988 1.29 1039 1.43 1087 1.57
62011 4170 1968 0.87 217.46 634 0.84 692 0.96 749 1.09 805 1.23 859 1.37 912 1.52 962 1.67 1012 1.83 1059 1.99 1105 2.16 1150 2.33
4927 2325 1.25 310.35 755 1.41 805 1.55 854 1.7 902 1.85 949 2.01 995 2.18 1040 2.35 1084 2.52 1127 2.7 1169 2.89 - -
4083 1927 0.47 117.67 508 0.6 570 0.7 631 0.81 690 0.93 748 1.06 805 1.19 860 1.33 913 1.48 964 1.63 1013 1.79 1061 1.95
62014 5200 2454 0.79 197.87 654 1.25 703 1.38 751 1.52 799 1.66 846 1.81 892 1.96 938 2.12 982 2.29 1026 2.46 1070 2.64 1112 2.82
6417 3028 1.25 310.39 814 2.38 854 2.54 893 2.7 932 2.87 971 3.04 1009 3.22 1047 3.41 1085 3.6 1122 3.79 1159 3.99 1195 4.2
4083 1927 0.54 133.63 528 0.63 590 0.74 650 0.85 709 0.97 767 1.1 823 1.24 877 1.38 929 1.53 980 1.68 1029 1.84 1076 2
62018 5200 2454 0.9 224.98 681 1.32 729 1.46 777 1.59 824 1.74 871 1.89 917 2.05 962 2.21 1007 2.38 1050 2.56 1093 2.74 1135 2.92
6417 3028 1.42 353.93 849 2.52 889 2.68 927 2.85 966 3.02 1004 3.2 1042 3.38 1080 3.57 1117 3.77 1154 3.97 1191 4.17 - -
4769 2250 0.49 123.03 0 0 693 0.8 785 0.97 873 1.15 957 1.34 1036 1.54 1110 1.75 1181 1.96 1248 2.19 1312 2.41 1374 2.65
62023 6600 3115 1.01 250.92 848 1.76 917 1.97 985 2.19 1052 2.42 1117 2.66 1181 2.91 1243 3.17 - - - - - - - -
7494 3536 1.33 330.38 972 2.6 1032 2.84 1092 3.09 - - - - - - - - - - - - - - - -
5104 2409 0.49 123.01 0 0 697 0.89 785 1.07 869 1.25 951 1.45 1028 1.65 1102 1.87 1173 2.09 1240 2.32 1304 2.55 1365 2.79
62026 7300 3445 1.08 269.64 891 2.21 954 2.44 1016 2.67 1078 2.91 1138 3.16 - - - - - - - - - - - -
8021 3785 1.33 330.37 985 2.95 1042 3.2 - - - - - - - - - - - - - - - - - -
6016 2839 0.49 123.04 0 0 580 0.92 660 1.13 735 1.37 805 1.62 871 1.88 933 2.15 991 2.43 1047 2.72 1100 3.01 1150 3.31
62030 8600 4058 1.08 269.39 732 2.19 790 2.46 848 2.76 903 3.06 958 3.38 1010 3.72 1062 4.06 1111 4.41 1155 4.77 - - - -
9453 4461 1.33 330.35 810 2.93 863 3.23 915 3.55 967 3.88 1017 4.23 1063 4.6 1111 4.96 1157 5.34 - - - - - -
6563 3097 0.49 123.04 0 0 583 1.04 658 1.27 730 1.51 799 1.76 863 2.04 925 2.32 983 2.61 1039 2.91 1092 3.21 1143 3.52
62034 9400 4436 1.09 270.53 743 2.56 798 2.84 852 3.14 905 3.46 956 3.79 1007 4.13 1056 4.48 1102 4.86 1149 5.23 1194 5.62 - -
10313 4867 1.33 330.39 820 3.4 870 3.72 919 4.04 968 4.38 1013 4.75 1060 5.11 1106 5.49 1150 5.88 1194 6.28 - - - -
7292 3441 0.49 123.03 0 0 591 1.24 661 1.47 728 1.72 793 1.99 856 2.27 916 2.56 973 2.86 1028 3.18 1081 3.5 1132 3.83
62038 10400 4908 1.08 268.02 759 3.08 809 3.38 859 3.69 908 4.01 956 4.35 1002 4.72 1048 5.08 1094 5.45 1139 5.84 1183 6.24 - -
11458 5407 1.33 330.34 841 4.15 886 4.48 932 4.82 975 5.18 1019 5.55 1062 5.92 1105 6.31 1147 6.71 1189 7.12 - - - -
8203 3871 0.49 123.02 542 1.32 606 1.55 670 1.78 732 2.04 792 2.32 851 2.61 909 2.91 964 3.23 1017 3.56 1069 3.89 1119 4.24
62042 11700 5521 1.08 268.02 789 3.94 834 4.25 879 4.57 924 4.91 966 5.28 1011 5.64 1053 6.01 1095 6.42 1137 6.84 1178 7.21 - -
12891 6083 1.33 330.38 0 0 915 5.64 954 6.02 995 6.39 1035 6.76 174 7.15 1114 7.55 1153 7.97 1191 8.39 - - - -
10208 4817 0.49 123.01 435 1.42 497 1.74 556 2.07 612 2.41 665 2.78 716 3.15 764 3.54 810 3.94 855 4.36 898 4.78 939 5.22
62048 14600 6890 1.08 269.64 638 4.31 682 4.76 724 5.21 766 5.68 806 6.17 845 6.66 884 7.16 921 7.68 957 8.2 993 8.73 - -
16042 7570 1.33 330.37 705 5.77 745 6.26 784 6.76 822 7.27 859 7.79 895 8.32 931 8.86 966 9.42 - - - - - -
12031 5677 0.49 123.02 460 1.99 515 2.34 568 2.71 619 3.09 668 3.48 715 3.89 761 4.32 805 4.75 847 5.2 888 5.66 928 6.12
62054 17200 8117 1.08 269.39 671 5.99 710 6.49 748 7 785 7.52 822 8.05 858 8.59 893 9.14 927 9.7 961 10.27 994 10.86 - -
18906 8922 1.33 330.35 0 0 777 8.55 811 9.11 846 9.67 879 10.25 912 10.84 945 11.44 977 12.04 - - - - - -
Table 11
Notes :
1. Areas shaded in grey indicate the operating range of a standard fan motor; out of this range shift to next larger motor size.
2. Internal static pressure is based on pressure drops through evaporator coil, fan casing and 2" washable flat filters.
3. For external static pressure more than 2.0 in.wg. (498 Pa) and for the data corresponding to the blank boxes, please consult SKM.
16
Field Connections
APMR series self-contained heavy duty air cooled packaged units are designed for minimum field interaction.
Power hook-ups and control wiring of room unit as per Electrical hook-up diagram is all that is required to electrically connect any model of
APMR series .
Every APMR series package air conditioning unit requires, at most, field installed fused disconnect switches or circuit breakers, and room unit.
Refer below for a schematic representation of required field electrical hook-ups for a standard APMR series packaged air conditioning unit.
All field wiring must be done in accordance with applicable local and national codes.
For maximum recommended for fuse sizing and minimum circuit amps for cable sizing, see Page 19~20 of this bulletin.
Duct work should be connected with flexible connections to the APMR series. One or two drains suitably trapped, are required to be connected
to the drain outlet of all models of APMR series.
The APMR series is then ready to provide cooling, on demand.
Field Wiring Requirement Schematic
L1 L2 L3 N
**
L N
3 PHASE,
3 WIRE SYSTEM
220V/3PH/60HZ CIRCUIT BREAKER
460V/3PH/60HZ OR FUSED
DISCONNECT SWITCH
(NOT BY SKM)
3 PHASE,
4 WIRE SYSTEM
380-415V/3PH/50HZ
L1
L2
380V/3PH/60HZ
L3
N
REF. ACTUAL WIRING DIAGRAM FURNISHED
WITH THE UNIT FOR EXACT IDENTIFICATION
GROUND
L1
L2
OF WIRE NUMBERS.
LINE VOLTAGE
FIELD WIRING
LOW VOLTAGE
FIELD WIRING
24V WIRING
CE+
CE-
APMR-SERIES
CONTROL PANEL
CE- CE+
TYPICAL ROOM UNIT

1STAGE AND/OR 2STAGE COOLING/HEATING
**APMR- SERIES UNITS RATED FOR 440V/3PH/50HZ AND 460V/3PH/60HZ REQUIRE SEPARATE
SOURCE OF CONTROL POWER SUPPLY THRU FIELD SUPPLIED & INSTALLED 15A/220V FUSED
CONTROL DISCONNECT SWITCH OR ORDER WITH FACTORY BUILT OPTION ' CXT '.
17
POWER SUPPLY
**L1
L2
L3
18
N
C1 C2
N L1 MPCB1 MPCB2 MPCB3 MPCB4 MPCB5

T1 T2 T1 T2
MPM1 T3 MPM2 T3 I> I> I> I> I> I> I> I> I> I> I> I> I> I> I>
T2 T1 M1 M2 S2 S1 T2 T1 M1 M2 S2 S1 C3 C4 C5 C6 C7
CM-1 CM-2
MCB1 CFM1 CFM2 CFM3 CFM4 EFM
CR1 CR2
ROOM UNIT
(LOOSESUPPLY)
NOTE:-
* Typical wiring diagram given here is for units with 380~ 415/3/50 or
Typical Wiring Diagram
380/3/60, 4 wire power supplies.

G G
OL * Wiring diagrams for 440/3/50, 220/3/60 or 460/3/60
I I CR1 CR2 CS + - power supplies are available on request.
MPCB 5
2CORE UNSCREENED * For 440/3/50 or 460/3/60 or power supplies without neutral,
LPS-1
LPS-2
TWISTED PAIR CABLE CXT option is a must.
(BY OTHERS)
RUN/STOP
DISC. PRESSURE-1
DISC. PRESSURE-2
MCB2 L EGEND
TFR TRANSFORMER
CS CONTROL SWITCH MPM MOTOR PROTECTOR MODULE
C CONTACTOR MPCB MOTOR PROTECTORCIRCUT BREAKER
CCH CRANK CASEHEATER OL OVERLOAD RELAY
MCB MINIATURECIRCUIT BREAKER LSV LIQUID LINE SOLENOIDVALVE
CFM CONDENSER FAN MOTOR EFM EVAPORATOR FANMOTOR
CM COMPRESSOR MOTOR CR CONTROL RELAY
24~_ RS485 PB LPS LOW PRESSURESWITCH
FIELD WIRING
HPS HIGH PRESSURESWITCH
M
M
M
M
M
M
M
B-
X1
X2
X3
X4
X5
X6
X7
X8
B1
B2
B3
A+
D1
D2
DG
CE-
REF
CE+
5V=
5V=
DU1
DU2
T1
T2
T3
T4
T5
T6
T7
24V=
24V=

** Provide Overcurrent, short circuit, earth fault
protection & disconnect means as required by local
INFO and national electric mode.
MICROPROCESSSOR
CONTROLLER OK
TFR
24V
220~ 240V
ESC
C1 C2
T8
T9
24~_
G0
Q12
Q11
Q14
Q22
Q21
Q24
Q33
Q34
Q43
Q44
Q53
Q54
Q64
Q73
Q74
Q84
C
D01
D02
DL1
DN
DL2
T10
T11
T12
T13
T-IP
T-HI
CCH1
CCH2
HPS-1
HPS-2
LSV-1 LSV-2
COMP.-1
COMP.-2
CFM1
CFM2
CFM3
CFM4
EFM
E C1 C2 C3 C4 C5 C6 C7
Electrical Data 380~415/3/50

Power Supply : 380-415V/3PH/50Hz
Unit Characteristic Compressor Condenser Fan Motor Evap380~415/3/50
orator Fan Motor
Model
APMR
MFA MCA
Unit Characteristic ICF QTY ComRLA
pressor LRA QTY CondensFLA
er Fan Motor LRA EFLA orator Fan MLRA
vap380~415/3/50 otor
Model
51005
APMR 32 19 81 1 12 74 1 1.1 3.9 2.7 12.6
51007 MFA
40 MCA
23 ICF
113 QTY
1 RLA
14 LRA
101 QTY
1 FLA
2.4 LRA
8.9 FLA
2.7 LRA
12.6
Unit Characteristic Compressor Condenser Fan Motor Evaporator Fan Motor
Model
51005
51008 32
50 19
26 81
104 1 12
16 74
95 21 1.1 3.9 2.7
3.6 12.6
19.2
APMR
51007 40 23 113 14 101 1 2.4 8.9 2.7 12.6
51009 63
MFA 31
MCA 127
ICF 1
QTY 20
RLA 118
LRA 2
QTY 1.1
FLA 3.9
LRA 3.6
FLA 19.2
LRA
51008
52010
51005 50
32 26
34
19 104
96
81 1 +11 1 12 16
+ 12
12 74 95
+ 74
74 21 1.1
1.1 3.9
3.9 3.6
5.2
2.7 19.2
26.3
12.6
51009
51012
51007 63
40 31
34
23 127
128
113 11 20
21
14 118
101 21 1.1
2.4 3.9
8.9 3.6
5.2
2.7 19.2
26.3
12.6
52010
52013
51008 50
63
50 34
42
26 96
132
104 1 +1 1 1216
14 12
+ 14 7495
101 74
+ 101 22 1.1
2.4
1.1 3.9
8.9
3.9 5.2
3.6 26.3
19.2
51012
52015
51009 63
63 34
46
31 128
127 1 +11 1 16 21
+ 16
20 95118
+ 95
118 22 1.1
2.4
1.1 3.9
8.9
3.9 5.2
3.6 26.3
19.2
52013
52019
52010 63
80
50 42
59
34 132
166
96 11 ++ 11 14
20 14
12 ++ 20
12 101
118 101
74 ++ 118
74 22 2.4
3.9
1.1 8.9
17.2
3.9 5.2
6.6
5.2 26.3
35.6
26.3
52015
52022
51012 63
100
63 46
64
34 128
169
128 1 +1 1 1621
21 16
+ 21 95118
118 95
+ 118 22 2.4
3.9
1.1 8.9
17.2
3.9 5.2
8.6
5.2 26.3
45.6
26.3
52019
52025
52013 80
125
63 59
77
42 166
199
132 11 ++ 11 20
14 +
25 20
+ 25
14 118
101 +
140 118
+ 140
101 322 3.9
2.4 17.2
8.9 6.6
8.6
5.2 35.6
45.6
26.3
52022
52028
52015 100
125
63 64
89
46 169
240
128 11 ++ 11 21
29 + 21
29
16 + 16 118
174 + 118
174
95 + 95 322 3.9
2.4 17.2
8.9 8.6
11.8
5.2 45.6
67.3
26.3
52025
52032
52019 125
160
80 77
95
59 199
291
166 11 ++ 11 25
34 25
20 ++ 29
20 140
225 140
118 ++ 174
118 32 3.9
3.9 17.2
17.2 8.6
11.8
6.6 45.6
67.3
35.6
52028
52036
52022 125
160
100 89
104
64 240
300
169 11 ++ 11 29
34 + 29
34
21 + 21 174
225 + 174
225
118 + 118 32 3.9
3.9 17.2
17.2 11.8
16
8.6 67.3
105.6
45.6
52032
52042
52025 160
200
125 95
124
77 291
351
199 11 ++ 11 34
47 29
25 ++ 34
25 225
272 174
140 ++ 225
140 433 3.9
3.9 17.2
17.2 11.8
16
8.6 67.3
105.6
45.6
52036
52046
52028 160
200
125 104
145
89 300
371
240 11 ++ 11 34
47 34
29 ++ 47
29 225
272 225
174 ++ 272
174 433 3.9
3.9 17.2
17.2 16
23.2
11.8 105.6
148.5
67.3
52042
52032 200
160 124
95 351
291 11 + + 11 47
34 ++ 34
29 272
225 ++ 225
174 43 3.9
3.9 17.2
17.2 16
11.8 105.6
Table 12
67.3
52046 200 145 371 11 + 440-3-50 148.5
52036 160 104 300 + 11 47
34 ++ 47
34 272
225 ++ 272
225 43 3.9
3.9 17.2
17.2 23.2
16 105.6
52042 200 124 351 1+1 47 + 34 272 + 225 4 3.9 17.2 16 105.6
Model
52046 200 Unit Characteristic
145 371 1+1 Com
47p+re47
ssor 272 + 272 4 r Fan MPower
Condense3.9 por440-3-50
otor 17.2SupplyE23.2
:va440V/3PH/50Hz
ator Fan M148.5
otor
APMR
Model MFA MCA
er Fan Motor LRA FLA
E ator Fan MLRA
vapor440-3-50 otor
51005
APMR 32 18 80 1 12 74 1 0.95 3.4 2.4 10.9
51007 MFA
40 MCA
22 ICF
111 QTY
1 RLA
14 LRA
101 QTY
1 FLA
2.1 LRA
7.6 FLA
2.4 LRA
10.9
Model Unit Characteristic Compressor Condenser Fan Motor Evaporator Fan Motor
51005
51008 32
50 18
25 80
102 1 12
16 74
95 21 0.95 3.4 2.4
3.1 10.9
16.6
APMR
51007
51009 40
50
MFA 22
30
MCA 111
125
ICF 1
QTY 14
20
RLA 101
118
LRA 21
QTY 2.1
0.95
FLA 7.6
3.4
LRA 2.4
3.1
FLA 10.9
16.6
LRA
51008
52010
51005 50
32 25
33
18 102
95
80 1 +11 1 16
12 12
+ 12 95
74 74
+ 74 21 0.95
0.95 3.4
3.4 3.1
4.5
2.4 16.6
22.7
10.9
51009
51012
51007 50
63
40 30
33
22 125
127
111 11 20
21
14 118
101 21 0.95
2.1 3.4
7.6 3.1
4.5
2.4 16.6
22.7
10.9
52010
52013
51008 50
63
50 33
40
25 95
129
102 1 +1 1 1216
14 12
+ 14 7495
101 74
+ 101 22 0.95
2.1
0.95 3.4
7.6
3.4 4.5
3.1 22.7
16.6
51012
52015
51009 63
50 33
45
30 127
125
125 1 +11 1 16 21
+ 16
20 95118
+ 95
118 22 0.95
2.1
0.95 3.4
7.6
3.4 4.5
3.1 22.7
16.6
52013
52019
52010 63
80
50 40
58
33 129
162
95 11 ++ 11 14
20 14
12 ++ 20
12 101
118 101
74 ++ 118
74 22 2.1
3.5
0.95 7.6
14.7
3.4 4.5
5.7
4.5 22.7
30.8
22.7
52015
52022
51012 63
100
63 45
62
33 125
165
127 1 +1 1 1621
21 16
+ 21 95118
118 95
+ 118 22 2.1
3.5
0.95 7.6
14.7
3.4 4.5
7.4
4.5 22.7
39.3
22.7
52019
52025
52013 80
100
63 58
74
40 162
194
129 11 ++ 11 20
25 20
14 ++ 25
14 118
140 118
101 ++ 140
101 322 3.5
2.1 14.7
7.6 5.7
7.4
4.5 30.8
39.3
22.7
52022
52028
52015 100
125
63 62
86
45 165
235
125 11 ++ 11 21
29 21
16 ++ 29
16 118
174 118
95 ++ 174
95 322 3.5
2.1 14.7
7.6 7.4
10.2
4.5 39.3
58
22.7
52025
52032
52019 100
160
80 74
92
58 194
286
162 11 ++ 11 25
34 25
20 ++ 29
20 140
225 140
118 ++ 174
118 32 3.5
3.5 14.7
14.7 7.4
10.2
5.7 39.3
58
30.8
52028
52036
52022 125
160
100 86
101
62 235
295
165 11 ++ 11 29
34 29
21 ++ 34
21 174
225 174
118 ++ 225
118 32 3.5
3.5 14.7
14.7 10.2
13.8
7.4 58
91.1
39.3
52032
52042
52025 160
200
100 92
121
74 286
345
194 11 ++ 11 34
25 +
47 29
+ 34
25 225
140 +
272 174
+ 225
140 433 3.5
3.5 14.7
14.7 10.2
13.8
7.4 58
91.1
39.3
52036
52046
52028 160
200
125 101
140
86 295
364
235 11 ++ 11 34
47 + 34
47
29 + 29 225
272 + 225
272
174 + 174 433 3.5
3.5 14.7
14.7 13.8
20
10.2 91.1
128.1
58
52042
52032 200
160 121
92 345
286 11 + + 11 47
34 ++ 34
29 272
225 ++ 225
174 43 3.5
3.5 14.7
14.7 13.8
10.2 91.1
58
52046 200 140 364 11 + 380-3-60
52036 160 101 295 + 11 47
34 + 47
+ 34 272
225 + 272
+ 225 43 3.5
3.5 14.7
14.7 20
13.8 128.1
91.1
52042 200 121 345 1+1 47 + 34 272 + 225 4 3.5 14.7 13.8 91.1
Table 13
Unit Characteristic Compressor Condenser 380-3-60
52046
Model 200 140 364 1+1 47 + 47 272 + 272 4 3.5Fan Motor 14.7 Evaporator
20 Fan Motor
128.1
APMR MFA MCA ICF QTY RLA LRA QTY FLAFan Motor LRA FLA 380-3-60 LRA
Unit Characteristic Compressor Condenser
Model Power SupplyEvaporator Fan Motor
: 380V/3PH/60Hz
61006 32 19 95 1 12 88 1 1.5 4.5 2.6 11.9
APMR MFA MCA ICF QTY RLA LRA QTY FLA LRA FLA LRA
61008 50 26 106 1 16 94 1 3.1 9.6 2.6 11.9
61006
Model
61009 32
50 19
30 95
133 1 12
19 88
123 21 1.5 4.5 2.6
3.6 11.9
18.9
APMR
61008
61011 50
80
MFA 26
39
MCA 106
155
ICF 1
QTY 16
26
RLA 94
145
LRA 21
QTY 3.1
1.5
FLA 9.6
4.5
LRA 2.6
3.6
FLA 11.9
18.9
LRA
61009
62011
61006 50
32 30
35
19 133
111
95 1 +11 1 12 19
+ 12
12 88123
+ 88
88 21 1.5
1.5 4.5
4.5 3.6
4.9
2.6 18.9
25
11.9
61011
61014
61008 80
50 39
40
26 155
156
106 11 26
16 145
94 21 1.5
3.1 4.5
9.6 3.6
4.9
2.6 18.9
25
11.9
62011
62014
61009 50
63
50 35
47
30 111
128
133 1 +1 1 1219
16 12
+ 16 88123
94 88
+ 94 22 1.5
3.1
1.5 4.5
9.6
4.5 4.9
3.6 25
18.9
61014
62018
61011 80
80 40
55
39 156
161
155 1 +11 1 26
19 26
+ 19 145
123145
+ 123 22 1.5
3.1
1.5 4.5
9.6
4.5 4.9
6.3
3.6 25
34
18.9
62014
62023
62011 63
125
50 47
78
35 128
202
111 11 ++ 11 16 ++ 26
26
12 16
12 94 ++ 145
145
88 94
88 22 3.1
5.3
1.5 9.6
17.5
4.5 4.9
8.4
4.9 25
44.3
25
62018
62026
61014 80
125
80 55
78
40 161
202
156 1 +1 1 1926
26 19
+ 26 123145
145 123
+ 145 22 3.1
5.3
1.5 9.6
17.5
4.5 6.3
8.4
4.9 34
44.3
25
62023
62030
62014 125
63 78
88
47 202
205
128 11 ++ 11 26
27 26
16 ++ 27
16 145
138 145
94 ++ 138
94 322 5.3
3.1 17.5
9.6 8.4
11.5
4.9 44.3
65.5
25
62026
62034
62018 125
160
80 78
113
55 202
274
161 11 ++ 11 26
19 +
38 26
+ 38
19 145
123 +
196 145
+ 196
123 322 5.3
3.1 17.5
9.6 8.4
11.5
6.3 44.3
65.5
34
62030
62038
62023 125
200
125 88
119
78 205
368
202 11 ++ 11 27
43 27
26 ++ 38
26 138
290 138
145 ++ 196
145 32 5.3
5.3 17.5
17.5 11.5
8.4 65.5
44.3
62034
62042
62026 160
200
125 113
128
78 274
377
202 11 ++ 11 38
43 38
26 ++ 43
26 196
290 196
145 ++ 290
145 32 5.3
5.3 17.5
17.5 11.5
15.5
8.4 65.5
102.3
44.3
62038
62048
62030 200
250
125 119
152
88 368
445
205 11 ++ 11 43
58 38
27 ++ 43
27 290
353 196
138 ++ 290
138 433 5.3
5.3 17.5
17.5 11.5
15.5
11.5 65.5
102.3
65.5
62042
62054
62034 200
250
160 128
175
113 377
467
274 11 ++ 11 43
58 43
38 ++ 58
38 290
353 290
196 ++ 353
196 433 5.3
5.3 17.5
17.5 15.5
23
11.5 102.3
147.1
65.5
62048
62038 250
200 152
119 445
368 11 + + 11 58
43 ++ 43
38 353
290 ++ 290
196 43 5.3
5.3 17.5
17.5 15.5
11.5 102.3
65.5
62054
62042 250
200 175
128 467
377 11 + + 11 58
43 ++ 58
43 353
290 ++ 353
290 43 5.3
5.3 17.5
17.5 23 460-3-60 147.1
15.5 102.3
62048 250 152 445 1+1 58 + 43 353 + 290 4 5.3 17.5 15.5 102.3
175 467 1+1 Com
58p+re58
ssor 353 + 353 4 Condense5.3
r Fan Motor 17.5 apor460-3-60
Ev23 ator Fan M147.1
otor
Model
APMR Table 14
MFA MCA
er Fan Motor LRA FLA
E ator Fan MLRA
vapor460-3-60 otor
Model
61006
APMR 32 19 82 1 12 75 1 1.3 5.2 2.2 9.9
61008 MFA
40 MCA
23 ICF
114 QTY
1 RLA
14 LRA
100 QTY
1 FLA
3.1 LRA
11.8 FLA
2.2 LRA
9.9
Model
61006
61009
APMR
32
50 19
26 82
105 1 12
16 75
95 21 1.3 5.2 2.2
3 199.9
15.6
61008
61011 40
63
MFA 23 AIR CONDITIONING
31
MCA 114
135 1
ICF EQUIPMENT QTY 14
20
RLA 100
125
LRA 21
QTY 3.1
1.3
FLA 11.8
5.2
LRA 2.2
3
FLA 9.9
15.6
LRA
61009
62011
61006 50
32 26
34
19 105
98
82 1 +11 1 12 16
+ 12
12 75 95
+ 75
75 21 1.3
1.3 5.2
5.2 3
4.1
2.2 15.6
20.7
9.9
62023 125 78 202 1+1 26 + 26 145 + 145 2 5.3 17.5 8.4 44.3

62014
62026 63
125 47
78 128
202 11 ++ 11 16 ++ 26
26 16 94 ++ 145
145 94 22 3.1
5.3 9.6
17.5 4.9
8.4 25
44.3
62018
62030 80
125 55
88 161
205 11 ++ 11 19 + 19
27 + 27 123 + 123
138 + 138 32 3.1
5.3 9.6
17.5 6.3
11.5 34
65.5

62023
62034 125
160 78
113 202
274 11 ++ 11 26 ++ 38
38 26 145 ++ 196
196 145 32 5.3
5.3 17.5
17.5 8.4
11.5 44.3
65.5
62026
62038 125
200 78
119 202
368 11 ++ 11 26 + 26
43 + 38 145 + 145
290 + 196 32 5.3
5.3 17.5
17.5 8.4
11.5 44.3
65.5
62030
62042 125
200 88
128 205
377 11 ++ 11 27 ++ 43
43 27 138 ++ 290
290 138 33 5.3
5.3 17.5
17.5 11.5
15.5 65.5
102.3
62034
62048 160
250 113
152 274
445 11 ++ 11 38 + 38
58 + 43 196 + 196
353 + 290 43 5.3
5.3 17.5
17.5 11.5
15.5 65.5
102.3
62038
62054 200
250 119
175 368
467 11 ++ 11 43 ++ 58
58 38 290 ++ 353
353 196 43 5.3
5.3 17.5
17.5 11.5
23 65.5
147.1
62042 200 128 377 1+1 43 + 43 290 + 290 3 5.3 17.5 15.5 102.3
Electrical Data
62048 250 152 445 1+1 58 + 43 353 + 290 4 5.3 17.5
Power Supply
15.5 460-3-60 102.3
: 460V/3PH/60Hz
62054 250 175 467 1+1 58 + 58 353 + 353 4 5.3 17.5 23 147.1
Model 460-3-60
APMR
MFA MCA ICF QTY RLA LRA QTY FLA LRA FLA LRA
19 82 1 Comp12ressor 75 1 Condense1.3
r Fan Motor 5.2 E2.2
vaporator Fan Mo9.9
tor
Model
APMR
61008 40 23 114 1 14 100 1 3.1 11.8 2.2 9.9
61009 50 26 105 1 16 95 2 1.3 5.2 3 15.6
61006 32 19 82 1 12 75 1 1.3 5.2 2.2 9.9
61011 63 31 135 1 20 125 2 1.3 5.2 3 15.6
61008 40 23 114 1 14 100 1 3.1 11.8 2.2 9.9
62011 50 34 98 1+1 12 + 12 75 + 75 2 1.3 5.2 4.1 20.7
61009 50 26 105 1 16 95 2 1.3 5.2 3 15.6
61014 63 33 136 1 21 125 2 1.3 5.2 4.1 20.7
61011 63 31 135 1 20 125 2 1.3 5.2 3 15.6
62014 63 42 133 1+1 14 + 14 100 + 100 2 3.1 11.8 4.1 20.7
62011 50 34 98 1+1 12 + 12 75 + 75 2 1.3 5.2 4.1 20.7
62018 63 47 131 1+1 16 + 16 95 + 95 2 3.1 11.8 5.2 28.1
61014 63 33 136 1 21 125 2 1.3 5.2 4.1 20.7
62023 100 62 178 1+1 20 + 20 125 + 125 2 5 21.0 6.9 36.6
62014 63 42 133 1+1 14 + 14 100 + 100 2 3.1 11.8 4.1 20.7
62026 100 64 179 1+1 21 + 21 125 + 125 2 5 21.0 6.9 36.6
62018 63 47 131 1+1 16 + 16 95 + 95 2 3.1 11.8 5.2 28.1
62030 125 81 216 1+1 25 + 25 150 + 150 3 5 21.0 9.5 54.1
62023 100 62 178 1+1 20 + 20 125 + 125 2 5 21.0 6.9 36.6
62034 125 90 249 1+1 29 + 29 179 + 179 3 5 21.0 9.5 54.1
62026 100 64 179 1+1 21 + 21 125 + 125 2 5 21.0 6.9 36.6
62038 160 96 295 1+1 34 + 29 225 + 179 3 5 21.0 9.5 54.1
62030 125 81 216 1+1 25 + 25 150 + 150 3 5 21.0 9.5 54.1
62042 160 104 303 1+1 34 + 34 225 + 225 3 5 21.0 12.8 84.5
62034 125 90 249 1+1 29 + 29 179 + 179 3 5 21.0 9.5 54.1
62048 200 126 355 1+1 47 + 34 272 + 225 4 5 21.0 12.8 84.5
62038 160 96 295 1+1 34 + 29 225 + 179 3 5 21.0 9.5 54.1
62054 200 145 374 1+1 47 + 47 272 + 272 4 5 21.0 19 121.6
62042 160 104 303 1+1 34 + 34 225 + 225 3 5 21.0 12.8 84.5
Table 15
62048 200 126 355 1+1 47 + 34 272 + 225 4 5 21.0 12.8 84.5
62054 200 145 374 1+1 47 + 47 272 + 272 4 5 21.0 19
220-3-60 121.6
Unit Characteristic Compressor Condenser Fan MPower

otor SupplyE:va220V/3PH/60Hz
por220-3-60
ator Fan Motor
Model
APMR
Model
61006 63 38 161 1 25 149 1 2.5 7.5 4.5 20.6
APMR
61008 80
MFA 45
MCA 185
ICF QTY1 28
RLA 164
LRA 1
QTY 5.4
FLA 16.7
LRA 4.5
FLA 20.6
LRA
61009
61006 100
63 52
38 211
161 11 33
25 195
149 21 2.5
2.5 7.5
7.5 6.2
4.5 32.6
20.6
61011
61008 100
80 57
45 255
185 11 37
28 239
164 21 2.5
5.4 7.5
16.7 6.2
4.5 32.6
20.6
62011
61009 100
100 70
52 193
211 1 +1 1 2533+ 25 149195
+ 149 22 2.5
2.5 7.5
7.5 8.5
6.2 43.3
32.6
61014
61011 160
100 81
57 264
255 11 54
37 245
239 22 2.5
2.5 7.5
7.5 8.5
6.2 43.3
32.6
62014
62011 125
100 82
70 223
193 11 ++ 11 28
25 ++ 28
25 164
149 ++ 164
149 22 5.4
2.5 16.7
7.5 8.5
8.5 43.3
43.3
62018
61014 160
160 96
81 261
264 1 +1 1 3354
+ 33 195245
+ 195 22 5.4
2.5 16.7
7.5 10.9
8.5 58.7
43.3
62023
62014 160
125 116
82 329
223 11 ++ 11 37
28 ++ 37
28 239
164 ++ 239
164 22 9
5.4 29.7
16.7 14.4
8.5 76.5
43.3
62026
62018 250
160 154
96 352
261 11 ++ 11 54
33 ++ 54
33 245
195 ++ 245
195 22 9
5.4 29.7
16.7 14.4
10.9 76.5
58.7
62030
62023 250
160 175
116 425
329 1+1 57 + 37
37 57 300 + 239
239 300 23 9 29.7 19.9
14.4 113.1
76.5
62034
62026 250 186
154 470
352 1+1 62 + 54
54 62 340 + 245
245 340 23 9 29.7 19.9
14.4 113.1
76.5
62038
62030 315
250 211
175 635
425 1+1 82
57 + 62
57 505
300 + 340
300 3 9 29.7 19.9 113.1
62042
62034 400
250 238
186 662
470 1+1 82
62 + 82
62 505
340 + 505
340 3 9 29.7 26.8
19.9 176.6
113.1
62048
62038 400
315 264
211 771
635 1+1 95
82 + 82
62 605
505 + 505
340 43 9 29.7 26.8
19.9 176.6
113.1
62054
62042 400 289
238 796
662 1+1 95
82 + 95
82 605
505 + 605
505 43 9 29.7 39.7
26.8 254.1
176.6
62048 400 264 771 1+1 95 + 82 605 + 505 4 9 29.7 26.8 176.6
62054 400 289 796 1+1 95 + 95 605 + 605 4 9 29.7 39.7 254.1
Table 16
Legend
MFA Maximum Fuse Amps (for fuse/circuit breaker sizing), PWS Part Winding Start.
complies with NEC Article 440-22 & 430-52.
MCA Minimum Circuit Amps.(for wire sizing), complies with RLA Rated Load Amps. (at worst operating condition) .
NEC article 440-33.
LRA Locked Rotor Amps.
ICF Maximum Instantaneous Current Flow.
DOL Direct On-Line Start . FLA Full Load Amps.
Note :
Voltage imbalance not to exceed ± 2 % of the rated voltage.
20
APMR Series - R-410A FILTER SIZES & DIMENSIONS
FILTER SIZES & DIMENSIONS FLAT FILTER VEE FILTER BAG FILTER
G 1 5.6 1 26 26*
Filter Dimensions & Sizes [25]FLAT FILTER

[142] [25] VEE FILTER
[660] BAG FILTER
[660]
G 1 5.6 1 26 26*
[25] [142] [25] [660] [660]
F
F
F
MODEL FLAT FILTER VEE FILTER BAG FILTER
APMR F G
SIZE H x L QTY. SIZE H x L QTY. SIZE H x L QTY. SIZE H x L QTY. SIZE H x L QTY.
MODEL 20
51005 FLAT FILTER VEE FILTER 20x20 [508x508] 1 BAG FILTER
F 33.6G 20x16 [508x406] 2 16x16 [406x406] 4
APMR [508] [853]
61006 SIZE H x L QTY. SIZE H x L QTY. 20x12
SIZE [508x305]
HxL QTY.
1 SIZE H x L QTY. SIZE H x L QTY.
51005
51007 20 4033.6 20x16 [508x406] 2 20x20 [508x508] 1
61006 20[508] 16x16[406x508]
[406x406] 44
61008 [508] [1016] 20x20
[853] [508x508] 2 16x20 20x20
20x12 [508x508]
[508x305] 12
51007 20 40 20x20 [508x508] 2
51008 20 40
61008 [508] [1016]20x20 [508x508] 2 16x20 [406x508] 4 20x20 [508x508] 2
61009 16x20 [406x508] 4 20x20 [508x508] 2
51008 20 40
51009
61009 24 40 20x20 [508x508] 2 16x20 [406x508] 4 20x20 [508x508]
24x20 [610x508]
2
2
61011 [610] [1016] 24x20 [635x508] 2 20x20 [508x508] 4
51009 24 40 16x24 24x20 [610x508] 21
52010
61011 30[610] 43[1016] 24x20[406x535]
[635x508] 22 24x24
20x20[635x635]
[508x508] 24 12x24 [305x610] 12x20 [305x508] 1
6201 1 [762] [1092] 16x20 [406x508] 2 24x20 [635x508] 2 20x24 [508x610] 1 20x20 [508x508] 1
52010 30 43 16x24 [406x535] 2 24x24 [635x635] 2 12x24 [305x610] 1 12x20 [305x508] 1
51012 [1092]16x24
6201 1 30[762] 43 [406x535]
16x20 [406x508] 22 24x24
24x20[635x635]
[635x508] 22 12x24 [508x610]
20x24 [305x610] 11 12x20[508x508]
20x20 [305x508] 1 1
61014 [762] [1092] 16x20 [406x508] 2 24x20 [635x508] 2 20x24 [508x610] 1 20x20 [508x508] 1
51012 30 43 16x24 [406x535] 2 24x24 [635x635] 2 12x24 [305x610]
12x24 [305x610]
1 12x20 [305x508] 1
20x24[508x508]
[508x610]
52013
61014 30[762] 56[1092]16x20 [406x508]
16x20 [406x508] 42 24x20
24x20[635x508]
[635x508] 42 20x24 [508x610]
12x20 [305x508] 11 20x20
20x20 [508x508] 1
1
1 1
62014 [762] [1422] 16x16 [406x406] 2 24x16 [635x406] 2 12x24
12x12 [305x610]
[305x305] 11 20x24
20x12[508x610]
[508x305] 1
52013 30 56 16x20 [406x508] 4 24x20 [635x508] 4 1
[762] [1422] 12x20
12x24 [305x508]
[305x610] 11 20x20
20x24[508x508]
[508x610] 1 1
62014
52015 30 56 16x16
16x20 [406x406]
[406x508] 42 24x16[635x508]
24x20 [635x406] 42 12x12
12x20 [305x305]
[305x508] 11 20x12
20x20[508x305]
[508x508] 1 1
62018 [762] [1422] 16x16 [406x406] 24 24x16
52015 30 56 16x20 [406x508] 24x20[635x406]
[635x508] 24 12x24
12x12 [305x610]
[305x305]
12x20 [305x508]
11 20x24
20x12[508x610]
[508x305] 1 1
1 20x20 [508x508] 1
62018 30[762] 65.4
52019
[1422]16x24
16x16 [406x406]
[406x635] 42 24x16 [635x635]
24x24 [635x406] 42 12x24 [305x305]
12x12 [305x610] 11 20x24[508x305]
20x12 [508x610] 1 1
62023 [762] [1661] 16x16 [406x406] 24 24x16
24x24[635x406] 24 12x20 [305x610]
[305x508] 20x20[508x610]
[508x508] 1 2
52019 30 65.4 16x24 [406x635] [635x635] 12x24 12 20x24
62023 [762] [1661] 16x16 [406x406]
52022 30 70 16x24 [406x635] 42 24x16[635x635]
24x24 [635x406] 42 12x20
12x24 [305x508]
[305x610] 23 20x20 [508x508] 2
52022 [762]30 [1778]
62026 70 16x20 [406x508]
16x24 [406x635] 24 24x20
24x24[635x508]
[635x635] 24 20x24 [305x610]
12x24 [508x610] 33
62026 [762] [1778] 16x20 [406x508] 2 24x20 [635x508] 2 20x24 [508x610]
12x24 [305x610] 31 20x24 [508x610] 1
52025 33 75 16x24 [406x635] 6 24x24 [635x635] 6 12x20 [305x610]
[305x508] 20x20[508x610]
[508x508] 1
62030
52025 [838] [1905] 12x24 12 20x24 2
33 75 16x24 [406x635] 6 24x24 [635x635] 6 12x12 [305x508]
12x20 [305x305] 21 20x12[508x508]
20x20 [508x305] 2 1
62030 [838] [1905] [305x610]
12x24 [305x305]
12x12 11 24x24[508x305]
20x12 [610x610] 1 1
52028 36 75 20x24 [508x635] 3 24x24 [635x635] 6 12x20 [305x610]
[305x508] 24x20[610x610]
[610x508] 1
52028 [914]36 [1905]
62034 20x24 [508x635] 12x24 12 24x24 2
75 16x24 [406x635] 33 24x24 [635x635] 6 12x12 [305x508]
12x20 [305x305] 21 24x12[610x508]
24x20 [610x305] 2 1
62034 [914] [1905] 16x24 [406x635] 3 12x12
52032 40 75 20x24 [508x635] 20x24 [305x305]
[508x610] 12 24x12 [610x305] 1
52032[1016] 6 20x24 [508x635] 9 20x20 [508x610]
20x24 [508x508] 24
62038 40 [1905]
75 20x24 [508x635] 6 20x24 [508x635] 9 20x20
62038 [1016] [1905] 20x12 [508x508]
[508x305] 42
20x12
20x24 [508x305]
[508x610] 21 24x24 [610x610] 1
52036 45 75 24x24 [635x635] 3
20x20 [508x610]
20x24 [508x508] 12 24x24
24x20[610x610]
[610x508] 1 2
52036[1143]
62042 45 [1905] 24x24
75 20x24 [635x635] 3 20x24[508x635] 9
[508x635] 3 20x24[508x635] 9 20x20 [508x508]
20x12 [508x305] 21 24x20
24x12[610x508]
[610x305] 2 1
62042 [1143] [1905] 20x24 [508x635] 3 20x12
12x24 [508x305]
[305x610] 11 24x12
20x24[610x305]
[508x610] 1 1 24x24 [610x610] 1
52042
52042 56 75 20x24 [508x635]
20x24 [508x635]
6
6 24x24 [635x635] 9 12x24
12x20 [305x610]
[305x508] 12 20x24
20x20[508x610]
[508x508] 1 2 24x24 [610x610]
24x20 [610x508] 1 2
56 75
62048 [1422] [1905] 16x24 [406x635] 24x24 [635x635] 9 12x20
62048 [1422] [1905] 16x24 [406x635] 3
3 12x12 [305x508]
[305x305] 21 20x20
20x12[508x508]
[508x305] 2 1 24x20 [610x508]
24x12 [610x305] 2 1
12x12 [305x305] 1 20x12 [508x305] 1 24x12 [610x305] 1
52046 24x24 [635x635] 66 20x24 [508x610]
[508x610] 1 24x24 [610x610] 2
52046 66 66 7575 24x24 [635x635] 20x24
20x20 [508x508] 12 24x24
24x20[610x610]
[610x508] 2
24x24 4
62054 [1676] [1905]
62054 [1676] [1905]16x24 [406x635] 33 24x24[635x635]
[635x635] 12
12 20x20 [508x508]
[508x305]
20x12 [508x305] 2 24x20 [610x508]
24x12[610x305] 4
16x24 [406x635] 20x12 11 24x12 [610x305] 2 2
*BAG
*BAG
FILTER IS APPLICABLE
FILTER FOR
IS APPLICABLE 22"
FOR DEPTH
22" DEPTH Table 17
ALLALL
DIMENSIONS ARE
DIMENSIONS IN IN
ARE INCHES [mm]
INCHES [mm]
Loading Points
50 Hz 60 Hz
LOADING
LOADING
POINTS
POINTS TOTALTOTAL LOADING
LOADING
POINTS
POINTS TOTALTOTAL
APMR APMR UNIT UNIT APMR APMR UNIT UNIT
A1 A1 A2 A2 A3 A3 A4 A4 WEIGHT
WEIGHT A1 A1 A2 A2 A3 A3 A4 A4 WEIGHT
WEIGHT
Ib. Ib. 220 220 226 226 324 324 293 293 1063 1063 Ib. Ib. 224 224 230 230 326 326 295 295 1076 1076
51005 51005 61006 61006
Kg. Kg. 100 100 103 103 147 147 133 133 482 482 Kg. Kg. 102 102 104 104 148 148 134 134 488 488
Ib. Ib. 223 223 229 229 339 339 308 308 1099 1099 Ib. Ib. 229 229 235 235 342 342 311 311 1117 1117
51007 51007 61008 61008
Kg. Kg. 101 101 104 104 154 154 140 140 499 499 Kg. Kg. 104 104 107 107 155 155 141 141 507 507
Ib. Ib. 303 303 303 303 407 407 369 369 1382 1382 Ib. Ib. 308 308 308 308 409 409 371 371 1396 1396
51008 51008 61009 61009
Kg. Kg. 137 137 137 137 185 185 167 167 627 627 Kg. Kg. 140 140 140 140 186 186 168 168 633 633
Ib. Ib. 320 320 320 320 431 431 393 393 1464 1464 Ib. Ib. 325 325 325 325 432 432 394 394 1477 1477
51009 51009 61011 61011
Kg. Kg. 145 145 145 145 196 196 178 178 664 664 Kg. Kg. 148 148 148 148 196 196 179 179 670 670
Ib. Ib. 338 338 342 342 437 437 421 421 1538 1538 Ib. Ib. 346 346 351 351 439 439 422 422 1558 1558
52010 52010 62011 62011
Kg. Kg. 153 153 155 155 198 198 191 191 697 697 Kg. Kg. 157 157 159 159 199 199 192 192 707 707
Ib. Ib. 329 329 329 329 435 435 397 397 1490 1490 Ib. Ib. 337 337 337 337 436 436 397 397 1507 1507
51012 51012 61014 61014
Kg. Kg. 149 149 149 149 197 197 180 180 676 676 Kg. Kg. 153 153 153 153 198 198 180 180 683 683
Ib. Ib. 353 353 359 359 457 457 443 443 1613 1613 Ib. Ib. 364 364 370 370 462 462 448 448 1645 1645
52013 52013 62014 62014
Kg. Kg. 160 160 163 163 207 207 201 201 732 732 Kg. Kg. 165 165 168 168 210 210 203 203 746 746
Ib. Ib. 436 436 443 443 557 557 549 549 1985 1985 Ib. Ib. 451 451 458 458 564 564 556 556 2029 2029
52015 52015 62018 62018
Kg. Kg. 198 198 201 201 253 253 249 249 900 900 Kg. Kg. 205 205 208 208 256 256 252 252 920 920
Ib. Ib. 471 471 480 480 610 610 593 593 2153 2153 Ib. Ib. 488 488 497 497 616 616 600 600 2200 2200
52019 52019 62023 62023
Kg. Kg. 214 214 218 218 276 276 269 269 977 977 Kg. Kg. 221 221 225 225 279 279 272 272 998 998
Ib. Ib. 489 489 498 498 632 632 615 615 2234 2234 Ib. Ib. 502 502 511 511 636 636 621 621 2271 2271
52022 52022 62026 62026
Kg. Kg. 222 222 226 226 287 287 279 279 1014 1014 Kg. Kg. 228 228 232 232 289 289 282 282 1030 1030
Ib. Ib. 617 617 627 627 753 753 706 706 2704 2704 Ib. Ib. 646 646 657 657 762 762 715 715 2780 2780
52025 52025 62030 62030
Kg. Kg. 280 280 284 284 342 342 320 320 1227 1227 Kg. Kg. 293 293 298 298 346 346 324 324 1261 1261
Ib. Ib. 665 665 676 676 803 803 751 751 2895 2895 Ib. Ib. 685 685 694 694 809 809 757 757 2945 2945
52028 52028 62034 62034
Kg. Kg. 302 302 307 307 364 364 341 341 1313 1313 Kg. Kg. 311 311 315 315 367 367 344 344 1336 1336
Ib. Ib. 701 701 701 701 948 948 817 817 3167 3167 Ib. Ib. 722 722 721 721 955 955 824 824 3222 3222
52032 52032 62038 62038
Kg. Kg. 318 318 318 318 430 430 370 370 1436 1436 Kg. Kg. 328 328 327 327 433 433 374 374 1462 1462
Ib. Ib. 744 744 754 754 1011 1011 960 960 3469 3469 Ib. Ib. 766 766 775 775 1018 1018 967 967 3526 3526
52036 52036 62042 62042
Kg. Kg. 337 337 342 342 459 459 435 435 1574 1574 Kg. Kg. 348 348 352 352 462 462 438 438 1600 1600
Ib. Ib. 973 973 1004 1004 1311 1311 1223 1223 4512 4512 Ib. Ib. 999 999 1032 1032 1321 1321 1233 1233 4585 4585
52042 52042 62048 62048
Kg. Kg. 442 442 455 455 595 595 555 555 2047 2047 Kg. Kg. 453 453 468 468 599 599 559 559 2080 2080
Ib. Ib. 1053 1053 1092 1092 1379 1379 1314 1314 4838 4838 Ib. Ib. 1082 1082 1124 1124 1390 1390 1324 1324 4920 4920
52046 52046 62054 62054
Kg. Kg. 478 478 495 495 626 626 596 596 2195 2195 Kg. Kg. 491 491 510 510 630 630 600 600 2232 2232
Table 18
21
Dimensional Data
MODELS: APMR-51005A, 51007A & 61006A, 61008A
MODELS: APMR-51005A, 51007A & 61006A, 61008A
APMR Models: 51005 - 51007 & 61006 - 61008 6
L EGE ND 6
L EGE ND
CERTIFIED DRAWINGS ARE
1 - EVAPORATOR COIL CERTIFIED
AVAILABLE ONDRAWINGS
REQUEST ARE A1
1 - EVAPORATOR COIL AVAILABLE ON REQUEST A1
2 - EVAPORATOR FAN A3
2 - EVAPORATOR FAN DIMENSIONS A3
3 - EVAPORATOR FAN MOTOR MODEL
MODEL L DIMENSIONS
3 - EVAPORATOR FAN MOTOR APMR- W A E
4 - COMPRESSOR APMR- L W A E
4 - COMPRESSOR 51005 70 45 34 33.6
51005 70 45
61006 [1778] [1142] [864] [853] 34 33.6
5 - CONDENSER COIL 61006 [1778] [1142] [864] [853]
5 - CONDENSER COIL 51007 74 56 38 40
6 - CONTROL PAN EL 51007[1880]74 [1422]56 [965]38 [1016]
61008 40
6 - CONTROL PAN EL 61008 [1880] [1422] [965] [1016]
7 - CONDENSER FAN
7 - CONDENSER FAN
ALL DIMENSIONS ARE IN
ALL DIMENSIONS AREINCHES [mm]
IN INCHES [mm]
A2[A2[ A4
A4
10 10 DRAIN [25]
DRAINØ1Ø1 x2Nos.
[25] x2Nos. 10
10
254]
254] [254]
[254]
W W LL
E E 1 1 3636 AA
= [25]
[25] [914]
[914]
=13.03
13.03 = =
6 [331][331] 77
[38]
6 [38]
1.5
1.5
11.38
11.38
[289]
[289]
FILTERED
FILTERED
VENTILLATION [181] 55
7.1
[1312]
VENTILLATION [181]
7.1
[1312]
51.65
51.65
ON BOTH
SIDESSIDES
[1167]
ON BOTH
[1167]
45.94
45.94
[508]
[508]
20
20
CABLECABLE
ENTRYENTRY
[51]
RIGGING HOLES 1 1 22 3
3 ACCESS 4 4
[51]
2
RIGGING HOLES
[100]
ACCESS
2
Ø.79Ø.79 [20] 4Nos.

3.94
[100]
[20] 4Nos. 1515

3.94
ACCESS PANEL
ACCESS PANEL
BOTH SIDES
[381] BOTH SIDES
[381]
MODEL: APMR-51008A to 51012A & 61009A to 61014A

MODEL: APMR-51008A to 51012A & 61009A to 61014A
APMR Models: 51008 - 51012 & 61009 - 61014
10 10
10 10
MODEL DIMENSIONS [254] [254]
MODEL DIMENSIONS [254] A1 A3 [254]
APMR- L W H A B C D E J G A1 A3
APMR- L W H A B C D E J G
51008 81 68 45.94 36 45 20 7.13 40 11.38 13.03
510086100981 [2057]
68 [1727]
45.94[1167]36 [914]45[1143]20 [508]7.13[181] 40[1016]11.38
[289]13.03
[331]
6100951009
[2057] 85
[1727] 68
[1167]52.42
[914] 40[1143]45[508] 24[181]7.56[1016]40 [289] 13.43[331]
15.55
510096101185 [2159]
68 [1727]
52.42[1332]40 [1016]45[1143]24 [610]7.56[192] 40[1016] [341]15.55
13.43 [395]
6101152010
[2159] 85
[1727] 68
[1332]62.42
[1016] 40[1143]45[610] 30[192]9.08[1016]43 [341] 15.91[395]
* 18.54
* 520106201185 [2159]
6201151012
[2159] 85
68 [1727]
[1727] 68
62.42[1585]40 [1016]45[1143]30 [762]9.08[231] 43[1092]
[1585]62.42
[1016] 40[1143]45[762] 30[231]9.08[1092]43 [404]
[404]18.54
15.91 [407]
15.91[407]
18.54
510126101485 [2159]
68 [1727]
62.42[1585]40 [1016]45[1143]30 [762]9.08[231] 43[1092] [404]18.54
15.91 [407]
61014 [2159] [1727] [1585] [1016] [1143] [762] [231] [1092] [404] [407]
*MODEL WITH TWO CIRCUITS ACCESS
*MODELALLWITH TWO CIRCUITS
DIMENSIONS ARE IN INCHES [mm] ACCESS
ALL DIMENSIONS ARE IN INCHES [mm]
A2 A4
A2 DRAIN Ø1[25] x2Nos. A4
W DRAIN Ø1[25] x2Nos.
L
W L
E 1 A B
E 1 [25] A B
[38]
[38]1.5
G 7
[25] 6
1.5
G 7
6
J
FILTERED
VENTILLATION
J
ON BOTH SIDES
FILTERED
D
VENTILLATION
[1312]
51.65
ON BOTH SIDES
H
[1312]
51.65
[100]
H
3.94
C
[100]
DETACHABLE
3.94
PLATE FOR
CABLE ENTRY
DETACHABLE
PLATE FOR
CABLE ENTRY
[51]
RIGGING HOLES 1 2 3 5 4
[51] 2
Ø.79 [20] 4Nos. 15

RIGGING HOLES 1 2 3ACCESS PANEL
5 4
2
[381]
Ø.79 [20] 4Nos. 15
ACCESS PANEL
[381]
22
Dimensional Data
APMR Models: 52013 - 52015
MODEL: APMR-52013A, & 62014
52015A & 62014A, 62018A- 62018
LEGEND 10 10
[254] [254]
1 - EVAPORATOR COIL A1 A3
2 - EVAPORATOR FAN
3 - EVAPORATOR FAN MOTOR
4 - COMPRESSOR
5 - CONDENSER COIL
6 - CONTROL PANEL
7 - CONDENSER FAN
ALL DIMENSIONS ARE IN INCHES [mm] ACCESS
AVAILABLE ON REQUEST
A2 A4
DRAIN Ø1[25] x2Nos.
76
98
[1931]
[2489]
56
1 40 58
[1422]
18.54 [25] [1016] [1473]
[38]
1.5
[471]
7 6
[231]
15.91
9.08
[404]
FILTERED
[1585]
62.42
VENTILLATION
[1312]
51.65
ON BOTH SIDES
[762]
30
DETACHABLE
PLATE FOR
CABLE ENTRY
[51]
2
1 2 3 5 4
[100]
3.94
RIGGING HOLES
Ø.79 [20] 4Nos. 15 ACCESS PANEL
BOTH SIDES
[381]
MODEL: APMR-51014A & 61017A
APMR Models: 52019, 52022 & 62023, 62026

M ODELS: APM R- 52019A, 52022A & 62023A, 62026A
10
[254]
6 10
[254]
AVAILABLE ON REQUEST A1 A3
LE G END 10 10
[254] [254]
2 - EVAPORATOR FAN
4 - COMPRESSOR
5 - CONDENSER COIL
6 - CONTROL PANEL
7 - CONDENSER FAN
ACCESS
MODEL DIMENSIONS A2 A4
APMR W H H1 D E F J DRAIN Ø1 [25] x2Nos.
52019 84 58.42 7051.65 7.56 65.4 43.66 13.43 84
62023 [2134] [1484] [1312] [192] [1661] [1109] [341]
52022 84 58.42 [1778]
51.65 7.56 70 43.66 13.43 [2134]
62026 [2134] [1484] [1312]
56 [192] [1778] [1109] [341]
1 40 44
CERTIFIED DRAWINGS ARE[1422] [25] [1016] [1118]
AVAILABLE ON =REQUEST18.54 A2 A4
[38]
=
1.5
[471] DRAIN Ø1 [25] x2Nos.

W 98 7
9.1 15.91
[404]
[2489]
E 1 40
[231] [25] [1016]
F
[38]
1.5
[1585]
62.42
FILTERED
VENTILLATION 7 6
[1312]
51.65
ON BOTH SIDES 5
[762]
30
J
DETACHABLE
PLATE FOR
D
CABLE ENTRY
FILTERED
VENTILLATION
H
30[51]
ON BOTH SIDES
H1
1 2 3 4
2
[762]
[100]
RIGGING HOLES
3.94
Ø.79[20] 4Nos. ACCESS PANEL ACCESS

15
BOTH SIDES
[381]
DETACHABLE PLATE
FOR CABLE ENTRY
[51]
2
1 2 3 5 4
[100]
3.94
RIGGING HOLES
Ø.79[20] 4Nos. 15 ACCESS PANEL
BOTH SIDES
[381]
MODELS: APM R-52025A to 52036A & 62030A to 62042A
MODEL DIMENSIONS
10
[254]
10
[254]
23
A1 A3
APMR H H1 AIR
L CONDITIONING
B C EQUIPMENT
52025 64.89 52.65 120 80 33
62030 [1648] [1337] [3048] [2023] [838]
7 6
J
D
FILTERED
VENTILLATION
H
ON BOTH SIDES
H1
[762]
30
DETACHABLE PLATE
FOR CABLE ENTRY
[51]
2
1 2 3 5 4
[100]
Dimensional Data 3.94
RIGGING HOLES
Ø.79[20] 4Nos. 15 ACCESS PANEL
BOTH SIDES
[381]
APMR Models:
MODELS:52025 - 52036
APM R-52025A to 52036A& 62030
& 62030A - 62042
to 62042A
10 10
MODEL DIMENSIONS [254] [254]
A1 A3
APMR H H1 L B C
52025 64.89 52.65 120 80 33
62030 [1648] [1337] [3048] [2023] [838]
52028 67.89 60.65 116 76 36
62034 [1724] [1540] [2946] [1930] [914]
52032 71.88 60.65 116 76 40
62038 [1826] [1540] [2946] [1930] [1016]
52036 76.88 72.64 120 80 45
62042 [1953] [1845] [3048] [2023] [1143]
CERTIFIED DRAWINGS ARE ACCESS

AVAILABLE ON REQUEST
A2 A4
88 DRAIN Ø1 [25] x2Nos.
[2235] L
75
[1905] 1 40 B
52.28 [25] [1016]
[38]
1.5
[1328]
7 6
8.5 15.91
[404]
[217]
FILTERED
VENTILLATION
ON BOTH SIDES
H
H1
C
DETACHABLE PLATE
FOR CABLE ENTRY
[51]
RIGGING HOLES 1 2 3 5 4
2
[100]
3.94
Ø.79 [20] 4Nos.

15 ACCESS PANEL
[381] BOTH SIDES
APMR Models: 52042 - 52046 & 62048 - 62054

MODELS: APMR- 52042A, 52046A & 62048A, 62054A
LE GEND 10 10
[254] [254]
2 - EVAPORATOR FAN
4 - COMPRESSOR
5 - CONDENSER COIL
6 - CONTROL PANEL
7 - CONDENSER FAN
MODEL DIMENSIONS ACCESS

APMR H H1 C D
52042 93.98 77.63 56 10.75
62048 [2387] [1972] [1422] [273]
52046 99.24 85.63 66 6
62054 [2521] [2175] [1676] [152]

AVAILABLE ON REQUEST A2 A4
DRAIN Ø1 1/4 [32]x2Nos.
88 127
[2235] [3226]
75 1 43
[1905] [25] [1092]
21.93 21.93
[38]
1.5
[557] [557]
7 6
18.82
[478]
D
FILTERED
VENTILLATION
ON BOTH SIDES
H
H1
C
DETACHABLE
PLATE FOR
CABLE ENTRY
[51]
RIGGING HOLES 1 5 4
2
15 2 3
[125]
Ø.79 [20]4Nos.
4.9
[381] ACCESS PANEL

BOTH SIDES
24
SPACE REQUIRMENT
Models
A B C
APMR
MODELS: APMR- 52042A, 52046A & 62048A, 62054A
51005
51007 40 10 10
LE GEN 51008
D [254] [254]
A1 A3
51009 CERTIFIED50
DRAWINGS ARE
1 - EVAPORATOR COIL AVAILABLE ON REQUEST 65
52010
2 - EVAPORATOR FAN
50
51012
52013
4 - COMPRESSOR 62
52015
5 - CONDENSER COIL
52019 PANEL
6 - CONTROL 66
76 76
52022
7 - CONDENSER FAN
52025 ACC
MODEL DIMENSIONS
APMR-52028 81
H H1 C D 70
52042A52032
93.98 77.63 56 10.75
81 [273]
62048A [2387] [1972] [1422]
52046A52036
99.24 85.63 66 6 90
62054A [2521] [2175] [1676] [152]
52042 96
ALL DIMENSIONS ARE IN INCHES [mm] 78
52046 108
A2 A4
Table 19 DRAIN Ø1 1/4 [32]x2Nos.
88 127
Installation [2235]
75 1 43
[3226]
[1905] [25] [1092]

21.93 SINGLE
21.93 UNIT INSTALLATION
[38]
1.5
[557] [557]
7 6
18.82
[478]
SPACING FOR SERVICE SPACING FOR AIR FLOW
D
A B
F
V
ON
A
B
DETACH
DUCT
DUCT
PLATE F
CABLE
B
[51]
RIGGING HOLES 1 5 4
2
15 2 3
[125]
APMR-Ø.79 [20]4Nos.
4.9
51005 , 51007 APMR- 51008 [381]

- 52046 ACCESS PANEL
BOTH SIDES
MULTIPLE UNIT INSTALLATI ON

B B
DUCT
B
A
DUCT
C
DUCT
DUCT
B B
B
A
APMR- 51005, 51007 APMR- 51008 - 52046
25
GUIDE SPECIFICATIONS
GENERAL FEATURES EVAPORATOR FAN & MOTOR
Packaged air conditioners shall be composed of compressor(s), Fans of evaporators shall be forward curved, double inlet double
condenser coil(s), evaporator coil, expansion valve(s), connecting width (DIDW), centrifugal type, statically & dynamically balanced,
piping, all necessary liquid line accessories and safety controls. mounted on a single heavy duty shaft with permanently lubricated
bearings and belt driven by V belt with an adjustable variable pitch
Unit shall be factory assembled, internally wired, fully refrigerant motor pulley.
charged with R-410A and thoroughly tested before delivery. Units
should be capable to operate from 50°F (10°C) to 120°F (48.9°C) Motor shall be Totally Enclosed Fan Cooled (TEFC), 4 poles, class-F
ambient temperature, and shall be rated in accordance with AHRI insulated, minimum IP55 protection & wired to unit control panel.
210/240 and 340/360 standards.
REFRIGERANT PIPING
CONDENSER COIL(S)
The refrigerant circuit piping shall be fabricated from ACR grade
Coil shall be air cooled with integral sub-cooling circuit, constructed copper piping, with 1 & 2 refrigeration circuits, each liquid line shall
of seamless copper tubes 3/8” OD mechanically bonded to wavy include shut off valve, filter drier, sight glass, solenoid valve and
Aluminium (Copper) fins with maximum14 FPI (1.8mm) spacing. thermostatic expansion valve.
Coil shall be tested against leakage by pressurizing air in coil, under
water, cleaned and dehydrated at the factory. Suction line shall be insulated with ½” (12mm) wall thickness
enclosed cell pipe insulation with maximum K factor 0.28 Btu.in /ft2
.h.°F. (0.040 W/mK).
COMPRESSOR(S)
CASING
Compressor shall be hermetic scroll, refrigerant gas cooled furnished
with internal overload protection device, crankcase heater, and shall Unit casing shall be made of zinc coated galvanized steel sheets
be mounted on rubber isolators. conforming to JIS-G3302 and ASTMA653 which shall be phosphatized
and then electrostatically dry powder coated of approx.60 microns
to provide an extremely tough, scratch resistance, excellent anti-
corrosive protection that can pass 1000 hrs in 5% salt spray testing
CONDENSER FAN(S) & MOTOR(S) at 95°F (35°C) and 95% relative humidity as per ASTM B117.
The machine shall be furnished with direct driven propeller type Evaporator section shall be sealed with vinyl gaskets and completely
discharging air upward condenser fans. Fans shall be constructed insulated faced with black glass tissue (BGT) heavy density, fire
of corrosion resistant blades such as heavy gauge aluminum. The retardant, 32 Kg/m3 density having Max. K factor 0.23 Btu.in /ft2
fan and drive shall be held in proper alignment. Fan assemblies .h.°F (0.033 W/mK) and permanent odorless fibre glass insulation
shall be provided with heavy gauge, rust resistant steel wire fan of minimum 1” (25mm) thickness.
guard. All condenser fans shall be individually, statically, and
dynamically balanced for vibration free operation.Motors shall
be Totally Enclosed Air Over (TEAO), 6 poles, class F insulation,
minimum IP55 protection and factory wired to unit control panel. FILTERS
EVAPORATOR COIL Units shall be supplied with a range of filter sections with flat filter or
vee filter 1” or 2” thick, with 54% or 72% dust arrestance, respectively,
Evaporator coil shall be constructed of seamless copper tubes 3/8” in accordance with ASHRAE 52.2 if so specified.
OD mechanically bonded to aluminum (copper) cross-wave fins
with maximum 12 FPI (2.1mm) spacing. A bag filter section to house 15”, 21”, or 30” deep bag filters having
efficiency as desired shall be provided, if so specified.
Coil consists of headers of seamless copper tubing, thermostatic
expansion valve(s) & multi-circuited distributor(s). High efficiency pleat filter shall be provided as an alternative to bag
filter, if so specified.
These coils shall be tested against leakage by air pressure of under
water, cleaned & dehydrated at the factory. Coil shall conform to For 100%, Fresh Air application, a sand trap louver shall be provided,
AHRI-410. if so specified.
26
GUIDE SPECIFICATIONS
CONTROL PANEL The Main Features of the controller shall be as follows:
The unit mounted control panel enclosure shall be fabricated out • Built in LCD display with back light.
of heavy gauge sheet steel in phosphatized powder coated baked • Built in keypad.
finish. The enclosure shall conform to IP54 as per guidelines • Battery backed up built in real time clock.
in IEC 529. A hinged access door and key-fastener shall be • Multiple authorization level to provide tight security for the control
provided for easy access and security. The panel shall be factory system.
wired in accordance with NEC 430 & 440, labeled, tagged and • Capacity control based on room temperature or return air
features 220V / 240V controls and shall include the following as temperature.
a minimum. • Alarm history.
• A sleek & elegant design room unit.
• All compressors shall be with DOL starting.
• Individual compressor, condenser fan motors and evaporator
fan motor contactors.
• Voltage monitoring module for protection against under DISPLAY INFORMATION
voltage, over voltage, phase loss, phase reversal and phase
unbalance of the incoming voltage. The package units shall offer an LCD display which will allow
• Motor protector circuit breaker for condenser and evaporator
the operator to access different parameters of the unit. Operator
fan motors.
• Control circuit breaker. shall be able to view and change the unit parameters. The
• Control circuit on/off switch. display information shall include:
• Microprocessor control boards.
• Control Relays. • Status
• Power and control terminal blocks. • Outputs
• Inputs
• Alarms
• Set points
• Password
MICROPROCESSOR CONTROL
The intelligent microprocessor based controller shall monitor
Package units shall be equipped with a full function microprocessor all the safeties related to the unit and makes the necessary
based controller as a standard feature. The controller shall be factory protections, by shutting down the entire unit or the effected
programmed for the control of evaporator fan, compressors and circuit. The protections shall include:
condenser fans. The controller shall come with a built in keypad
and display for simple but meaningful man machine interface. This • Low suction pressure.
controller shall provide complete operational control for the unit and • High discharge pressure.
shall have built-in auto diagnostic capability that can signal normal • High compressor motor temperature.
operation or alarm conditions as well as shutting down the unit or • Compressor short cycling.
system if necessary. • Evaporator fan motor overload.
The controller shall come with a loose supplied sleek and Volt free contacts for run status, common fault status, auto mode
elegant design room unit for installing in the conditioned space. status and provision for remote on/off shall be available as option.
Communication between unit controller and room unit shall be
through two wire interface. The communication cable shall be 2 In addition, the unit microprocessor shall be able to support the
core, twisted pair, unscreened with stranded conductors. Maximum major BMS protocols such as BACnet, Modbus & LON as option.
distance between room unit and controller shall be 700 meters.
The room unit shall have a built in sensor for measuring the room
temperature. It shall transmit room temperature, set point, unit
operating mode, operating schedule etc. to the unit controller.
Control of the compressors shall be based on room temperature
and the set point, as standard. Control based on duct temperature
shall be available if required.
27
HEAD OFFICE
P.O Box: 6004
Sharjah, United Arab Emirates
Tel: +971 6 514 3333
Fax: +971 6 514 3300
Email: sales@skmaircon.com
Email: info@skmaircon.com
Spare Parts Division

Email: spareparts.skm@skmaircon.com
Service Centre
Email: aftersales.skm@skmaircon.com
REGIONAL OFFICES
United Arab Emirates
Abu Dhabi Dubai
P.O Box: 27788 P.O Box: 98822
Tel: +971 2 6445223 Tel: +971 4 2940900
Fax: +971 2 6445145 Fax: +971 4 2940029
Email: abudhabisales.skm@skmaircon.com Email: dubaisales.skm@skmaircon.com
Al Ain
Tel: +971 3 7619921 Kuwait
Fax: +971 3 7619941 Dasman
Email: alainsales.skm@skmaircon.com P.O Box: 1215-PC 15463
Tel: +965 2 2492200
Saudi Arabia (Production Facility) Fax: +965 2 2494400
Email: kuwaitsales.skm@skmaircon.com
SKM Air Conditioning Factory
Eastern province
AD Dammam Algeria
2nd industrial city Aissat Idir ( EX-ENMA) City
Abqiq main road Hail Street Bldg1, Flat 2, Dar El Beida Algiers
Tel: +966 3 8123332 / 4 / 5 Tel: +213 21 508197
Fax: +966 3 8123337 / +966 3 8123092 Fax: +213 21 508197
Email: saudifactory.skm@skmaircon.com Email: algeriasales.skm@skmaircon.com
For SKM Distributors visit:

www.skmaircon.com
28 105/2015
Supersedes # 105/2013

APMR

Uploaded by

Document Information

Original Description:

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

APMR

Uploaded by

Copyright:

Available Formats

SKM Packaged Air Conditioners

APMR Series - R-410A

Sharjah Economic Excellence

APMR Series Air cooled package (hermetic

APMR Series Packaged Air Conditioners are

SKM provides qualified service and stocks

SKM reserves the right to change, in part or in

You name it.....We cool it

General Features Condenser

The flexibility of the APMR series is ideal for consideration on

Compressors used in APMR packaged unit series are hermetically

• Copper fins. Casing/Structure

Microprocessor Controller Display Information

Condenser Coil Guard (CGP) Galvanized Frame And Base (GFB)

Double Skin Evaporator (DSE) Pressure Gauges (SDG1)

Options for Field Installations Capacity Control Steps

Example 1: English Units Example 2: SI Units

Determine cooling capacity at design conditions.

- For EDB other than 80ºF (26.7ºC), use following formula:

Fan Speed & Motor Power

GROSS CAPACITY RATINGS - 50 Hz

The APMR series is then ready to provide cooling, on demand.

Field Wiring Requirement Schematic

TYPICAL ROOM UNIT

N L1 MPCB1 MPCB2 MPCB3 MPCB4 MPCB5

MCB1 CFM1 CFM2 CFM3 CFM4 EFM

380/3/60, 4 wire power supplies.

Electrical Data 380~415/3/50

SKM Packaged Air Conditioners

APMR Series - R-410A

Unit Characteristic Compressor Condenser Fan MPower

Voltage imbalance not to exceed ± 2 % of the rated voltage.

Filter Dimensions & Sizes [25]FLAT FILTER

Ø.79Ø.79 [20] 4Nos.

[20] 4Nos. 1515

MODEL: APMR-51008A to 51012A & 61009A to 61014A

Ø.79 [20] 4Nos. 15

MODEL: APMR-51014A & 61017A

APMR Models: 52019, 52022 & 62023, 62026

[471] DRAIN Ø1 [25] x2Nos.

Ø.79[20] 4Nos. ACCESS PANEL ACCESS

MODELS: APM R-52025A to 52036A & 62030A to 62042A

CERTIFIED DRAWINGS ARE ACCESS

Ø.79 [20] 4Nos.

APMR Models: 52042 - 52046 & 62048 - 62054

MODEL DIMENSIONS ACCESS

CERTIFIED DRAWINGS ARE

[381] ACCESS PANEL

[1905] [25] [1092]

51005 , 51007 APMR- 51008 [381]

MULTIPLE UNIT INSTALLATI ON

APMR- 51005, 51007 APMR- 51008 - 52046

Spare Parts Division

For SKM Distributors visit:

You might also like
