Preface …
I take an opportunity to present this Text Book on "Data Structures and Algorithms-II"
to the students of Second Year B.Sc. (Computer Science) Semester-IV as per the New
Syllabus, June 2020.
The book has its own unique features. It brings out the subject in a very simple and lucid
manner for easy and comprehensive understanding of the basic concepts. The book covers
theory of Tree, Efficient Search Trees, Graph and Hash Table.
A special word of thank to Shri. Dineshbhai Furia, and Mr. Jignesh Furia for
showing full faith in me to write this text book. I also thank to Mr. Amar Salunkhe and
Mr. Akbar Shaikh of M/s Nirali Prakashan for their excellent co-operation.
I also thank Ms. Chaitali Takle, Mr. Ravindra Walodare, Mr. Sachin Shinde, Mr. Ashok
Bodke, Mr. Moshin Sayyed and Mr. Nitin Thorat.
Although every care has been taken to check mistakes and misprints, any errors,
omission and suggestions from teachers and students for the improvement of this text book
shall be most welcome.
Author
Syllabus …
1. Tree (10 Hrs.)
1.1 Concept and Terminologies
1.2 Types of Binary Trees - Binary Tree, Skewed Tree, Strictly Binary Tree, Full Binary Tree,
Complete Binary Tree, Expression Tree, Binary Search Tree, Heap
1.3 Representation - Static and Dynamic
1.4 Implementation and Operations on Binary Search Tree - Create, Insert, Delete, Search, Tree
Traversals - Preorder, Inorder, Postorder (Recursive Implementation), Level-Order Traversal
using Queue, Counting Leaf, Non-Leaf and Total Nodes, Copy, Mirror
1.5 Applications of Trees
1.5.1 Heap Sort, Implementation
1.5.2 Introduction to Greedy Strategy, Huffman Encoding (Implementation using Priority
Queue)
2. Efficient Search Trees (8 Hrs.)
2.1 Terminology: Balanced Trees - AVL Trees, Red Black Tree, Splay Tree, Lexical Search
Tree -Trie
2.2 AVL Tree - Concept and Rotations
2.3 Red Black Trees - Concept, Insertion and Deletion
2.4 Multi-Way Search Tree - B and B+ Tree - Insertion, Deletion
3. Graph (12 Hrs.)
3.1 Concept and Terminologies
3.2 Graph Representation - Adjacency Matrix, Adjacency List, Inverse Adjacency List, Adjacency
Multi-list
3.3 Graph Traversals - Breadth First Search and Depth First Search (With Implementation)
3.4 Applications of Graph
3.4.1 Topological Sorting
3.4.2 Use of Greedy Strategy in Minimal Spanning Trees (Prim’s and Kruskal’s Algorithm)
3.4.3 Single Source Shortest Path - Dijkstra’s Algorithm
3.4.4 Dynamic Programming Strategy, All Pairs Shortest Path - Floyd Warshall Algorithm
3.4.5 Use of Graphs in Social Networks
4. Hash Table (6 Hrs.)
4.1 Concept of Hashing
4.2 Terminologies - Hash Table, Hash Function, Bucket, Hash Address, Collision, Synonym,
Overflow etc.
4.3 Properties of Good Hash Function
4.4 Hash Functions: Division Function, Mid Square, Folding Methods
4.5 Collision Resolution Techniques
4.5.1 Open Addressing - Linear Probing, Quadratic Probing, Rehashing
4.5.2 Chaining - Coalesced, Separate Chaining
Contents …
1. Tree 1.1 – 1.64
2. Efficient Search Trees 2.1 – 2.40
3. Graph 3.1 – 3.58
4. Hash Table 4.1 – 4.24

CHAPTER
1
Tree
Objectives …
To study Basic Concepts of Tree Data Structure
To learn Basic Concepts of Binary Tree and its Types
To study Representation of Tree
To understand Binary Search Tree (BST)
To study the Applications of Tree
1.0 INTRODUCTION
• A tree is a non-linear data structure. A non-linear data structure is one in which its
elements do not forms a sequence.
• A tree data structure is a widely used Abstract Data Type (ADT) that simulates a
hierarchical tree structure, with a root value and subtrees of children with a parent
node, represented as a set of linked nodes.
• A tree data structure stores the data elements in a hierarchical manner. A tree is a
hierarchical data structure that consists of nodes connected by edges.
• Let us see an example of a directory structure stored by operating system. The
operating system organizes files into directories and subdirectories. This can be
viewed as tree shown in Fig. 1.1.
Desktop
My computer Game Network neighbourhood
C:\ D:\ H:\
Win TC Java
include lib
Fig. 1.1: Tree Representation of Directory Structure
1.1
Data Structures & Algorithms - II Tree
• Common uses for tree data structure are given below:

1. To manipulate hierarchical data.
2. To make information easily searchable.
3. To manipulate sorted lists of data.
• A tree data structure widely used for improving database search time, game
programming, 3D graphics, data compression and in file systems.
1.1 BASIC CONCEPTS AND TERMINOLOGY

• A tree is a non-linear data structure used to represent the hierarchical structure of one
or more data elements, which are known as nodes of the tree.
• Each node of a tree stores a data value and has zero or more pointers pointing to the
other nodes of the tree which are known as its child nodes.
• Each node in a tree can have zero or more child nodes, which is at one level below it.
However, each child node can have only one parent node, which is at one level above
it.
• The node at the top of the tree is known as the root of the tree and the nodes at the
lowest level are known as the leaf nodes.
• Fig. 1.2 shows a tree, in which G node have no child. The nodes without any child node
are called external nodes or leaf nodes, whereas, the nodes having one or more child
nodes are called internal nodes.
• Siblings represent the collection of all of the child nodes to one particular parent. An
edge is the route between a parent and child node.
• A subtree of a tree is a tree with its nodes being a descendent of some other tree.
Root A
Subtree Edge
Parent B C
node Siblings
Child node D Leaf

E F G
node
Fig. 1.2: Structure of Tree
1.1.1 Definition
• A tree may be defined as, a finite set ‘T’ of one or more nodes such that there is a node
designated as the root of the tree and the other nodes (excluding the root) are divided
into n ≥ 0 disjoint sets T1, T2, … Tn and each of these sets is a tree in turn. The trees
T1, T2 … Tn are called the sub-trees or children of the root.
1.2
• The Fig. 1.3 (a) shows the empty tree, there are no nodes. The Fig. 1.3 (b) shows the
tree with only one node. The tree in Fig. 1.3 (c) has 12 nodes.
root A
root = NULL
(a) (b)
Level
root A 0
B C 1
D E F G 2
H I J K
3
L 4
(c)
Fig. 1.3: Examples of Tree
• The root of tree is A, it has 2 subtrees. The roots of these subtrees are called the
children of the root A.
• The nodes with no subtrees are called terminal node or leaves. There are 5 leaves in
the tree of Fig. 1.3 (c).
• Because family relationship can be modeled as trees, we often call the root of a tree (or
subtree) the parent and the nodes of the subtrees the children; the children of a node
are called siblings.
1.1.2 Operations on Trees

• Various operations on tree data structure are given below:
1. Insert: An insert operation allows a new node to be added or inserted as a child of
an existing node in the tree.
2. Delete: The delete operation will remove a specified node from the tree.
3. Search: The search operation searches an element in a tree.
4. Prune: The prune operation in tree will remove a node and all of its descendants
from the tree. Removing a whole selection of a tree called pruning.
5. Graft: The graft operation is similar to insert operation except, that the node being
inserted has descendants of its own, meaning it is a multilayer tree. Adding a
whole section to a tree called grafting.
6. Enumerate: An enumeration operation will return a list or some other collection
containing every descendant of a particular node, including the root node itself.
7. Traversal: Traversal means to visit all nodes in a binary tree but only once.
1.3
1.1.3 Terminology
• A tree consists of following terminology:
1. Node: In a tree, every individual element is called as node. Node in a tree data
structure, stores the actual data of that particular element and link to next element
in hierarchical structure. Fig. 1.3 (c) has 12 nodes.
2. Root Node: Every tree must have a root node. In tree data structure, the first node
from where the tree originates is called as a root node. In any tree, there must be
only one root node.
3. Parent Node: In tree data structure, the node which is predecessor of any node is
called as parent node. Parent node can be defined as, "the node which has
child/children". In simple words, the node which has branch from it to any other
node is called as parent node.
4. Child Node: In tree data structure, the node which is descendant of any node is
called as child node. In simple words, the node which has a link from its parent
node is called as child node. In tree data structure, all the nodes except root node
are child nodes.
5. Leaf Node: The node which does not have any child is called as a leaf node. Leaf
nodes are also called as external nodes or terminal nodes.
6. Internal Node: In a tree data structure, the leaf nodes are also called as external
nodes. External node is also a node with no child. In a tree, leaf node is also called
as terminal node.
7. Edge: In tree data structure, the connecting link between any two nodes is called
as edge. In a tree with 'n' number of nodes there will be a maximum of 'n-1'
number of edges.
8. Path: In tree data structure, the sequence of nodes and edges from one node to
another node is called as path between that two nodes. Length of a path is total
number of nodes in that path.
9. Siblings: Nodes which belong to the same parent are called as siblings. In other
words, nodes with the same parent are sibling nodes. [Oct. 17]
10. Null Tree: A tree with no nodes is called as a null tree (Refer Fig. 1.3 (a)).
11. Degree of a Node: Degree of a node is the total number of children of that node.
The degree of A is 2, degree of K is 1 and degree of L is 0, (Refer Fig. 1.3 (c)).
12. Degree of a Tree: The highest degree of a node among all the nodes in a tree is
called as degree of tree. In Fig. 1.3 (c), degree of the tree is 2. [April 18]
13. Depth or Level of a Node: In tree data structure, the root node is said to be at
Level 0 and the children of root node are at Level 1 and the children of the nodes
which are at Level 1 will be at Level 2 and so on. In simple words, in a tree each
step from top to bottom is called as a Level and the Level count starts with '0' and
incremented by one (1) at each level (step).
14. Descendants: The descendents of a node are those nodes which are reachable
from node. In Fig. 1.3 nodes J, K, L are descendents of G.
1.4
15. Ancestor: The ancestor of a node are all the nodes along the path from the root to
that node. In Fig. 1.3 nodes A and C are ancestor of G.
16. In-degree: The in-degree of a node is the total number of edges coming to that
node.
17. Out-degree: The out-degree of a node is the total number of edges going outside
from the node.
18. Forest: A forest is a set of disjoint trees.
19. Sub Tree: In tree data structure, each child from a node forms a subtree
recursively. Every child node will form a subtree on its parent node.
20. Height: In tree data structure, the total number of edges from leaf node to a
particular node in the longest path is called as height of that node. In a tree, height
of the root node is said to be height of the tree. In a tree, height of all leaf nodes is
'0'.
21. Depth: Total number of edges from root node to a particular node is called
as depth of that node. In tree, depth of the root node is ‘0’. The tree of Fig. 1.3 (c),
has depth 4.
1.2 BINARY TREE AND TYPES OF BINARY TREE

• In this section we will study binary tree and its types.
1.2.1 Binary Tree

• A tree in which every node can have a maximum of two children is called as binary
tree.
• Binary tree is a special type of tree data structure in which every node can have a
maximum of two children. One is known as left child and the other is known as right
child.
• Fig. 1.4 represents binary tree in which node A has two children B and C. Each child
has one child namely D and E respectively.
A
B C
D
E
G F
Fig. 1.4: Binary Tree
1.2.2 Skewed Binary Tree [April 17, 19]

• A tree in which every node has either only left subtree or right subtree is called as
skewed binary tree.
• The tree can be left skewed tree or right skewed tree (See Fig. 1.5).
1.5
A A
B B
C C
D D
(a) Left Skewed Binary

(a) Tree (b) Right Skewed
(b) Binary Tree
Fig. 1.5: Skewed Binary Tree
1.2.3 Strictly Binary Tree

• A strictly binary tree is a binary tree where all non-leaf nodes have two branches.
• When every non-leaf node in binary tree is filled with left and right sub-trees, the tree
is called strictly binary tree.
A
B C
D E
F G
Fig. 1.6: Strictly Binary Tree of Height 3
1.2.4 Full Binary Tree

• If each node of binary tree has either two children or no child at all, is said to be a full
binary tree.
• A full binary tree is defined as a binary tree in which all nodes have either zero or two
child nodes.
• A full binary tree is a binary tree in which all of the leaves are on the same level and
every non-leaf node has two children (See Fig. 1.7).
A
B C
D E F G
Fig. 1.7: Full Binary Tree
1.2.5 Complete Binary Tree [Oct. 18]

• A binary tree is said to be complete binary tree, if all its level, except the last level,
have maximum number of possible nodes, and all the nodes of the last level appear as
far left as possible.
• A complete binary tree is a binary tree in which every level, except possibly the last, is
completely filled, and all nodes are as far left as possible.
1.6
• Fig. 1.8 shows is a complete binary tree.

A
B C
D E F G
B I J K L
Fig. 1.8: Complete Binary Tree
1.2.6 Expression Tree

• Binary tree representing an arithmetic expression is called expression tree. The leaves
of expression trees are operands (variables or constants) and interior nodes are
operators.
• Expression tree is a binary tree in which each internal node corresponds to operator
and each leaf node corresponds to operand.
• Expression tree is a tree which represent an expression where leaves are labeled with
operands of the expression and nodes other than leaves are labeled with operators of
the expression.
• A binary expression tree is a specific kind of a binary tree used to represent
expressions.
• Consider the expression tree in the Fig. 1.9, what expression this tree represents? what
is the value of expression?
• As per the properties of expression tree, always expressions are solved from bottom to
up.so first expression we will get is 4+2, then this expression will be multiplied by 3.
Hence, we will get the expression as (4+2) * 3 which gives the result as 18.
*
+ 3
4 2
Fig. 1.9
1.2.7 Binary Search Tree

• A binary search tree is a binary tree in which the nodes are arranged according to
their values.
• The left node has a value less than its parent and the right node has a value greater
than the parent node.
• Hence, all nodes in the left subtree have values less than the root and the nodes in the
right subtree have values greater than the root.
1.7
32 32
26 45 20 59
15 30 40 48 15 26 78
11
38
Fig. 1.10: Binary Search Tree
1.2.8 Heap
• A heap is a special tree-based data structure in which the tree is a complete binary
tree.
• Generally, heaps can be of following two types:
1. Max-Heap: In a max-heap the key present at the root node must be greatest among
the keys present at all of its children. The same property must be recursively true
for all sub-trees in that binary tree.
2. Min-Heap: In a min-heap the key present at the root node must be minimum
among the keys present at all of its children. The same property must be
recursively true for all sub-trees in that binary tree.
10 100
15 30 40 50
40 50 100 40 10 15 50 40
(a) Min Heap (b) Max Heap

1.3 REPRESENTATION OF TREE (STATIC AND DYNAMIC)

• Tree data structure can be represented in following two ways:
1. Using an array (sequential/linear/static representation).
2. Using a linked list (link/dynamic representation).
• We shall give more emphasis to linked representation as is more popular than the
corresponding sequential structure. The two main reasons are:
1. A tree has a natural implementation in linked storage.
2. The linked structure is more convenient for insertions and deletions.
1.3.1 Static Representation of Tree (Using Array)
• In static representation, tree is represented sequentially in the memory by using single
one-dimensional array.
• In static representation of tree, a block of memory for an array is to be allocated
before going to store the actual tree in it.
1.8
• Hence, nodes of the tree are stored level by level, starting from the zero level where
the root is present.
• The root node is stored in the first memory location as the first element in the array.
• Static representation of tree needs sequential numbering of the nodes starting with
nodes on level zero, then those on level 1 and so on.
h+1
• A complete binary tree of height h has (2 − 1) nodes in it. The nodes can be stored in
h+1 d
one dimensional array. A array of size (2 − 1) or 2 − 1 (where d = no. of levels) is
required.
th
• Following rules can be used to decide the location of any i node of a tree:
For any node with index i, where i, 1 ≤ i ≤ n
i
(a) PARENT (i) = 2 if i ≠ 1
 
If i = 1 then it is root which has no parent
(b) LCHILD (i) = 2 * i, if 2i ≤ n
If 2i > n, then i has no left child
(c) RCHILD(i) = 2i + 1, if 2i + 1 ≤ n
If (2i + 1) > n, then i has no right child.
• Let us, consider complete binary tree in the Fig. 1.12.
A
B
E
C D F G
Fig. 1.12
• The representation of the above tree in Fig. 1.12 using array is given in Fig. 1.13.
1 2 3 4 5 6 7 8 9
A B E C D F G – –
Fig. 1.13
• The parent of node i is at location (i/2)
Example, Parent of node D = (5/2) =2 i.e. B
i
• Left child of a node i is present at position 2i + 1 if 2 + 1 < n
i
Left child of node B = 2 = 2*2= 4 i.e. C
i
• Right child of a node i is present at position 2 + 1
i
Right child of E = 2 +1= (2*3) +1= 6+1=7 i.e. G.
1.9
Examples:
Example 1: Consider the complete binary tree in Fig. 1.14.
0
A
1 2
B E
3 4 5 6
C D F G
Fig. 1.14
In Fig. 1.14,
Number of levels = 3 (0 to 2) and height = 2
3 2+1 3
Therefore, we need the array of size 2 −1 or 2 − 1 is 2 − 1 = 7.
The representation of the above binary tree using array is as followed:
1 2 3 4 5 6 7
A B C D E F G
We will number each node of tree starting from the root. Nodes on same level will be
numbered left to right.
Example 2: Consider almost complete binary tree in Fig. 1.15.
A
B C
D E
F G H I
Fig. 1.15
4
Here, depth = 4 (level), therefore we need the array of size 2 − 1 = 15. The
representation of the above binary tree using array is as follows:
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
A B C D E − − F G H I − − − −
level 0 1 2 3
We can apply the above rules to find array representation.
i 5
1. Parent of node E (node 5) = 2 = 2 = 2 i.e. B.
Hence, node B is at position 2 in the array.
1.10
i
2. Left (i) = 2 .
For example, left of E = 2 × 5 = 10 i.e. H.
th
Since, E is the 5 node of tree.
i
3. Right (i) = 2 + 1
For example: Right of D = 2 × 4 + 1 = 8 + 1 = 9 i.e. G.
th th
Since, D is the 4 node of tree and G is the 9 element of an array.
Example 3: Consider the example of skewed tree.
A
D
Fig. 1.16: Skewed Binary Tree
The tree has following array representation.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
A B – C – – – D – – – – – – –
4
We need the array of size 2 – 1 = 15.
Thus, only four positions are occupied in the array and 11 are wasted.
From the above example it is clear that binary tree using array representation is
easier, but the method has certain drawbacks. In most of the representation, there will
be lot of unused space. For complete binary trees, the representation is ideal as no
space is wasted.
But for the skewed binary tree (See Fig. 1.16), less than half of the array is used and
the more is left unused. In the worst case, a skewed binary tree of depth k will require
k
2 − 1 locations of array and occupying only few of them.
Advantages of Array Representation of Tree:
1. In static representation of tree, we can access any node from other node by
calculating index and this is efficient from the execution point of view.
2. In static representation, the data is stored without any pointers to their successor
or ancestor.
3. Programming languages like BASIC, FORTRAN etc., where dynamic allocation is
not possible, use array representation to store a tree.
Disadvantages of Array Representation of Tree:
1. In static representation the number of the array entries are empty.
2. In static representation, there is no way possible to enhance the tree structure.
Array size cannot be changed during execution.
3. Inserting a new node to it or deleting a node from it are inefficient for this
representation, (here, considerable data movement up and down the array
happens, thus more/excessive processing time is used).
1.11
Program 1.1: Program for static (array) representation of tree (Converting a list of array
in to binary tree).
#include<stdio.h>
typedef struct node
{
struct node*left;
struct node*right;
char data;
}node;
node* insert(char c[],int n)
{
node*tree=NULL;
if(c[n]!='\0')
{
tree=(node*)malloc(sizeof(node));
tree->left=insert(c,2*n+1);
tree->data=c[n];
tree->right=insert(c,2*n+2);
}
return tree;
}
/*traverse the tree in inorder*/
void inorder(node*tree)
{
if(tree!=NULL)
{
inorder(tree->left);
printf("%c\t",tree->data);
inorder(tree->right);
}
}
void main()
{
node*tree=NULL;
char c[]={'A','B','C','D','E','F','\0','G','\0','\0','\0','\0','\0','
\0','\0','\0','\0','\0','\0','\0','\0'};
1.12
tree=insert(c,0);
inorder(tree);
}
Output:
G D B E A F C
1.3.2 Dynamic Representation of Tree (Using Linked List)

• Another way to represent a binary tree is using a linked list. In a linked list
representation, every node consists of three fields namely, left child (Lchild), data and
right child (Rchild).
• Fig. 1.17 shows node structure in linked list representation of tree.
• Linked list representation of tree, is more memory efficient than the array
representation. All nodes should be allocated dynamically.
• In dynamic representation of tree, a block of memory required for the tree need not
be allocated beforehand. They are allocated only on demand.
Data
Node
Lchild Data Rchild Lchild Rchild
Fig. 1.17: Fields of a Node of a Binary Tree in Linked Representation

• A node in linked in a linked representation of tree has two pointers (left and right)
fields, one for each child. When a node had no children, the corresponding pointer
fields are NULL.
• The data field contains the given values. The Lchild field holds the address of its left
node and the Rchild field holds the address of right node.
• The Fig. 1.18 (a) and (b) shows the linked representation of binary tree.
• In Fig. 1.18 (a) and (b), NULL stored at Lchild and Rchild field represent that respective
is not present.
Linked representation
A Root node
Tree
A Root
B C
B
C
D E F G D NULL E NULL F NULL NULL G NULL
H I J
NULL H NULL NULL I NULL NULL J NULL
(a)
1.13
Linked representation
A Root NULL A
B
NULL B
C
NULL C
D
NULL D NULL
(b)
Fig. 1.18: Linked Representation of Binary Tree
• Each node represents information (data) and two links namely, Lchild and Rchild are
used to store addresses of left child and right child of a node.
Declaration in 'C': We can define the node structure as follows:
struct tnode
{
struct tnode *left;
<datatype> data; /* data type is a data type of field data */
struct tnode *right;
};
• Using this declaration for linked representation, the binary tree representation can be
logically viewed as in Fig. 1.19 (c). In Fig. 1.19 (b) physical representation shows the
memory allocation of nodes.
Address node
A
left data right
B 50 NULL D NULL
A C
D 75 50 B 40
B E F G
C
40 NULL E NULL
D E FH G I
89 75 A 46
(a) A Binary Tree 62 NULL F NULL
H I
(a)
46 62 C 58
(a)
66 NULL H NULL
58 66 G 74
74 NULL I NULL
(b)
(b) A Binary Tree and its various Nodes
(Physical View)
75 A 46
1.14
50 B 40 62 C 58
NULL D NULL NULL E NULL NULL F NULL 66 G 74
NULL H NULL NULL I NULL

75 A 46
50 B 40 62 C 58
NULL D NULL NULL E NULL NULL F NULL 66 G 74
NULL H NULL NULL I NULL
(c)
(c) Logical View
Fig. 1.19: Linked Representation of Binary Tree
Advantages of Linked Representation of Binary Tree:
1. Efficient use of memory than that of static representation.
2. Insertion and deletion operations are more efficient.
3. Enhancement of tree is possible.
Disadvantages of Linked Representation of Binary Tree:
1. If we want to access a particular node, we have to traverse from root to that node;
there is no direct access to any node.
2. Since, two additional pointers are present (left and right), the memory needed per
node is more than that of sequential/static representation.
3. Programming languages not supporting dynamic memory management are not
useful for dynamic representation.
Program 1.2: Program for dynamic (linked list) representation of tree.
#include <stdio.h>
#include <malloc.h>
struct node {
struct node * left;
char data;
struct node * right;
};
struct node *constructTree( int );
void inorder(struct node *);
char array[] = {'A', 'B', 'C', 'D', 'E', 'F', 'G', '\0', '\0', 'H'};
int leftcount[] = {1, 3, 5, -1, 9, -1, -1, -1, -1, -1};
int rightcount[] = {2, 4, 6, -1, -1, -1, -1, -1, -1, -1};
void main() {
struct node *root;
root = constructTree( 0 );
1.15
printf("In-order Traversal: \n");

inorder(root);
}
struct node * constructTree( int index ) {
struct node *temp = NULL;
if (index != -1) {
temp = (struct node *)malloc( sizeof ( struct node ) );
temp->left = constructTree( leftcount[index] );
temp->data = array[index];
temp->right = constructTree( rightcount[index] );
}
return temp;
}
void inorder( struct node *root ) {
if (root != NULL) {
inorder(root->left);
printf("%c\t", root->data);
inorder(root->right);
}
}
Output:
In-order Traversal:
D B H E A F C G
• The primitive operations on binary tree are as follows:
1. Create: Creating a binary tree.
2. Insertion: To insert a node in the binary tree. Insertion operation is used to insert
a new node into a binary tree. Fig. 1.20 shows the insertion of node with data G as
a left of a node having data ‘D’. The Insertion involves two steps:
(i) Search for a node in the given binary tree after which insertion is to be made.
(ii) Create a link for a new node and new node becomes either left or right.
A
B NULL C
D NULL NULL E NULL NULL F NULL
NULL G NULL
Fig. 1.20: Insertion of Node G
1.16
3. Deletion: To delete a node from the binary tree. Deletion operation deletes any
node from any non-empty binary tree. In order to delete a node in a binary tree, it
is required to reach at the parent node of the node to be deleted. The link field of
the parent node which stores the address of the node to be deleted is then set by a
NULL entry as shown in Fig. 1.21.
A
B NULL C NULL
NULL D NULL NULL E NULL

Link is deleted
NULL G NULL
Fig. 1.21: Node with Data G is Deleted and Left of D becomes NULL
4. Traversal: Binary tree traversal means visiting every node exactly once. There are
three methods of traversing a binary tree. These are called as inorder, postorder
and preorder traversals.
BINARY SEARCH TREE (BST) IMPLEMENTATION AND

1.4
OPERATIONS
• Consider an example where we want to search a data from the linked list. We have to
search sequentially which is slower than binary search. If the list is ordered list stored
in contiguous sequential storage, binary search is faster.
• If we want to insert or delete a data from the list, then in sequential list more data
movements are required. With link list only few pointer manipulations are required.
• Binary search tree provides quick insertion and deletion operation. Hence, binary
trees provide an excellent solution for searching, inserting and deleting a node.
• The Binary Search Tree (BST) is a binary tree with the property that the value in a
node is grater than any value in a node's left subtree and less than any value in the
node's right subtree.
• There are two ways to represent binary search tree i.e., static and dynamic. Static
representation of binary search tree in which the set of values in the nodes is known
in advance and in dynamic representation, the values in a tree may change over
time.
Definition of BST:
• A Binary Search Tree (BST) is a binary tree which is either empty or non-empty. If it is
non-empty, then every node contains a key which is distinct and satisfies the following
properties:
1. Values less than its parent are placed at left side of parent node.
2. Values greater than its parent are placed at right side of parent node.
3. The left and right subtrees are again binary search trees.
1.17
• Fig. 1.22 shows examples of binary search trees.

40 Jan
32 48 Dec May
25 35 45 52 Aug Feb Jun Nov
5 27 42 Apr
Fig. 1.22: Binary Search Trees
1.4.1 Operations on Binary Search Tree

• Following operations are commonly performing on BST,
1. Search a key
2. Insert a key
3. Delete a key
4. Traverse the tree.
1.4.1.1 Creating Binary Search Tree [April 16, 18, 19, Oct. 17]
• The function create() simply creates an empty binary search tree. This initializes the
root pointer to NULL.
struct tree * root = NULL;
• The actual tree is build through a call to insert BST function, for every key to be
inserted.
Algorithm:
1. root = NULL
2. read key and create a new node to store key value
3. if root is null then new node is root
4. t = root, flag = false
5. while (t ≠ null) and (flag = false) do
case 1: if key < t → data
attach new node to t → left
case 2: if key > t → data
attach new node to t → right
case 3: if t → data = key
then print "key already exists"
6. Stop.
1.18
C Function for Creating BST:

BSTNODE createBST(BSTNode *root)
{
BSTNODE *newnode, *temp;
char ans;
do
{
newnode=(BSTNODE *) malloc(sizeof(BSTNODE));
printf("\n Enter the element to be inserted:");
scanf("%d", &newnode→data);
newnode→left=newnode→right=NULL;
if(root==NULL)
root=newnode;
else
{
temp=root;
while(temp!=NULL)
{
if(newnode→data<temp→data)
{
if(temp→left==NULL)
{
temp→left=newnode;
break;
}
else
temp=temp→left;
}
else if(newnode→data>temp→data)
{ if(temp→right==NULL)
{
temp→right=newnode;
break;
}
else
temp=temp→right;
}
}
printf("\n Do u want to add more numbers?");
scanf("%c", &ans);
} while(ans=='y' || ans =='y')
return(root);
}
1.19
Example: Construct Binary Search Tree (BST) for the following elements:
15, 11, 13, 8, 9, 17, 16, 18
1. 2. 3.
15 15
15
11 11
13
Key = 15 Key < 15 Key = 13

Key = 11
4. 5. 6.
15 15 15
11 11 11 17
8 13 8 13 8 13
9 9
Key = 8 Key = 9 Key = 17
7. 15 8. 15
17 17
11 11
8 13 16 8 13 16 18
9 9
Key = 16 Key = 18
• Here, all values in the left subtrees are less than the root and all values in the right
subtrees are greater than the root.
Program 1.3: Program to create a BST.
#include<stdio.h>
#include<malloc.h>
#include<stdlib.h>
struct node
{
int data;
struct node *right;
struct node *left;
};
1.20
struct node *create(struct node *, int);

void postorder(struct node *);
int main()
{
struct node *root = NULL;
setbuf(stdout, NULL);
char ch;
int item;
root = NULL;
do{
printf("\nEnter data for node ");
scanf("%d",&item);
root=create(root,item);
printf("Do you want to insert more elements?");
scanf(" %c",&ch); //use a space before %c to clear stdin
}while(ch=='y'||ch=='Y');
printf("****BST created***\n");
}
struct node *create(struct node *root, int item)
{
if(root == NULL)
{
root = (struct node *)malloc(sizeof(struct node));
root->left = root->right = NULL;
root->data = item;
return root;
}
else
{
if(item < root->data )
{
printf("%d inserted left of %d\n",item,root->data);
root->left = create(root->left,item);
}
else if(item > root->data )
{
printf("%d inserted right of %d\n",item,root->data);
root->right = create(root->right,item);
}
else
printf(" Duplicate Element is Not Allowed !!!");
return(root);
}
}
1.21
Output:
Enter data for node 10
Do you want to insert more elements?y
20 inserted right of 10
5 inserted left of 10
15 inserted right of 10
Do you want to insert more elements?
1.4.1.2 Searching in a BST [April 17]
• To search a target key, we first compare it with the key at the root of the tree. If it is
the same, then the search ends and if it is less than key at root, search the target key in
left subtree else search in the right subtree.
• Example: Consider BST in the Fig. 1.23.
Jan
Dec May
Aug Feb Jun Nov
Apr

• To search 'Apr', we first compare 'Apr' with key of root 'Jan'. Since, Apr < Jan
(alphabetical order) we move to left and next compare with 'Dec'. Since,
Apr < Dec, we move to the left again and compare with ‘Aug’.
• As Apr < Aug we move to the left. Here we find the key ‘Apr’ and search is successful.
If not, we continue searching until we hit an empty subtree.
• We can return the value of the pointer to send the result of the search function back to
the caller function.
1.22
Procedure: Search − BST (Key)

Steps:
1. Initialize t = root, flag = false
case 1: t⋅ data = key
flag = true /*successful search*/
case 2: Key < t → data
t = t → left /* goto left subtree*/
case 3: Key > t → data
t = t → right /*goto right subtree*/
end case
end while
3. if (flag = true) then
display "Key is found at node", t
else
display "Key is not exist"
end if;
4. Stop
The Non Recursive C Function for search key:
BSTNODE *search (BSTNODE *root, int key)
{
BSTNODE *temp=root;
while (temp != NULL) && (temp data != NULL)
{
if (key < temp → data)
temp = temp → left;
else
temp = temp → right;
}
return(temp);
}
The recursive C function for search key:
BSTNODE *research (BSTNODE *root, int key)
{
BSTNODE *temp=root;
if (temp == NULL) || (temp → data == key)
return(temp);
else
if (key < temp → data)
research (temp → left, key);
else
research (temp → right, key);
}
1.23
1.4.1.3 Inserting a Node into BST [April 16, 18, Oct. 17, 18]
• We insert a node into binary search tree in such a way that resulting tree satisfies the
properties of BST.
Algorithm: Insert_BST (Key)
Steps: 1. t = root, flag = false
2. while (t ≠ null) & (flag = false) do
case 1: key < t → data
t1 = t;
t = t → left;
case 2: key > t → data
t1 = t
t = t → right
case 3: t → data = key
flag = true
display "item already exist"
break
end case
end while
3. if (t = null) then
new = getnode (node) //create node
new → data = key
new → left = null //initialize a node
new → right = null
if (t1 → data < key) then //insert at right
t1 → right = new
else t1 → left = new //insert at left
endif
4. Stop
Recursive C function for inserting node into BST:
BSTNODE *Insert-BST (BSTNODE *root, int n)
{
if (root == NULL)
{
root = (BSTNODE *) malloc (sizeof(BSTNODE));
root → data = n;
root → left = root → right = NULL;
}
1.24
else
if (n < root → data)
root → left = Insert-BST (root → left, n);
else
root → right = Insert–BST (root → right, n);
return(root);
}
Non-Recursive C function for inserting node into BST:
BSTNODE *Insert-BST (BSTNODE *root, int n)
{
BSTNODE *temp, *newnode;
newnode = (BSTNODE*) malloc (sizeof(BSTNODE));
newnode → data = n;
newnode → left = root → right = NULL;
if (root==NULL)
root = newnode;
else
{
temp = root;
while (temp)
{
if (n < temp → data)
{
if (temp → left==NULL)
{
temp → left = newnode;
break;
}
else
else if (n > temp → data)
{
if(temp → right==NULL)
{
temp → right = newnode;
break;
}
else
temp = temp → Rchild;}
}
}
return root;
}
}
}
1.25
• Example: Consider the insertion of keys: Heena, Deepa, Tina, Meena, Beena, Anita.
• Initially tree is empty. The first key 'Heena' is inserted, it becomes a root. Since, 'Deepa'
< 'Heena', it is inserted at left. Similarly insert remaining keys in such a way that they
satisfy BST properties.
• Now, suppose if we want to insert a key 'Geeta'. It is first compared with root. Since,
‘Geeta’ < ‘Heena’, search is proceeding to left side. Since, 'Geeta' > ‘Deepa’ and right of
‘Deepa’ is null then ‘Geeta’ is inserted as a right of ‘Deepa’.
Heena Heena
Heena Deepa Deepa Teena
Key = Heena Key = Deepa Key = Teena

(a) (b) (c)
Heena Heena Heena
Deepa Teena Deepa Teena Deepa Teena
Meena Beena Meena Beena Meena
Key = Meena Key = Anita

Key = Beena
Anita
(d) (e) (f)
Fig. 1.24: Insertion in BST
1.4.1.4 Deleting Node from BST
• Delete operation is frequently used operation of BST. Let T be a BST and X is the node
with key (K) to be deleted from T, if it exists in the tree let y be a parent node of X.
• There are three cases with respective to the node to be deleted:
1. X is a leaf node.
2. X has one (either left or right).
3. X has both nodes.
Algorithm: Delete BST (key)
Steps:
1. t = root, flag = false
case 1: key < t→data
parent = t
t = t → left
1.26
case 2: key > t → data

parent = t
t = t → right
case 3: t → data = key
flag = true
end case
end while
3. if flag = false
then display "item not exist".
exit.
4. /* case 1 if node has no child */
if (t → left = null) and (t → right = null) then
if (parent → left = t) then
parent → left = null //set pointer to its parent when node is left child
else
parent → right = null
5. /* case 2 if node contains one child */
if (parent → left = t) then //when node contains only one child
if (t → left = null) then //if node is left child
parent → left = t → right
else
parent → left = t → left
endif
else
if (parent → right = t) then
if (t → left = null) then
parent → right = t → right
else
parent → right = t → left
endif
endif
endif
6. /* Case 3 if node contains both child */
t1 = succ(t) //find inorder successor of the node
key1 = t1 → data
Delete BST (key1) //delete inorder successor
t → data = key //replace data with the data of an order successor
7. Stop.
1.27
Recursive C function for deletion from BST:

BSTNODE *rec_deleteBST(BSTNODE *root, int n)
{
BSTNODE *temp, *succ;
if(root==NULL)
{
printf("\n Number not found.");
return(root);
}
if(n<root→data) //deleted from left subtree
root→left=rec_deleteBST(root→left, n);
elseif(n>root→data) //deleted from right subtree
root→right=rec_deleteBST(root→right, n);
else //Number to be deleted is found
{
if(root→left ! = NULL && root→right ! =NULL)//2 children
{
succ=root→right;
while(succ→left)
succ=succ→left;
root→data=succ→data;
root→right=rec_deleteBST(root→right, succ→data);
}
else
{
temp=root;
if(root→left !=NULL) //only left child
root=root→left;
elseif (root→right!=NULL) //only right child
root=root→right;
else //no child
root=NULL;
free(temp);
}
}
return(root);
}
1.28
Non-recursive C function for deleting node from BST:

BSTNODE *non_rec_DeleteBST (BSTNODE *root, int n)
{
BSTNODE *temp, *parent, *child, *succ, *parsucc;
temp==root;
parent=NULL;
while(temp != NULL)
{
if (n == temp → data)
break;
parent = temp;
if(n < temp → data)
else
temp = temp → right;
}
if(temp == NULL)
{
printf("\nNumber not found.");
return(root);
}
if(temp→left !=NULL && temp→right !=NULL)
// a node to be deleted has 2 children
{
parsucc=temp;
succ=temp→right;
while(succ→left!=NULL)
{
parsucc=succ;
succ=succ→left;
}
temp → data = succ → data;
temp = succ;
parent = parsucc;
}
if(temp→left! = NULL) //node to be deleted has left child
child=temp→left;
else //node to be deleted has right child or no child
child=temp→right;
1.29
if(parent==NULL) //node to be deleted is root node

root=child;
elseif(temp==parent → left) //node is left child
parent→left=child;
else //node is right child
parent→right=child;
free(temp);
return(root);
}
• Example: Consider all above three cases. Nodes with double circles indicates node to
be deleted.
Case 1: If the node to be deleted is a leaf node, then we only replace the link to the
deleted node by NULL.
22
12 30
10 15 25 35
32
33
After deletion of leaf node with data 33.
22 22
12 30 Node 33 is 12 30
deleted
10 15 10 15
25 35 25 35
32 32
33
Fig. 1.26: Deletion of node 33

Case 2: If the node to be deleted has a single node, then we adjust the link from parent
node to point to its subtree.
Consider tree of Fig. 1.27, delete the node with data ≠ 35 which has only left with data
32.
22 22
12 30 12 30
10 15 10 15
25 35 25 32
32
Fig. 1.27: Deletion of Node 35
1.30
Case 3: The node to be deleted having both nodes. When the node to be deleted has
both non-empty subtrees, the problem is difficult.
One of the solution is to attach the right subtree in place of the deleted node and then
attach the left subtree to the appropriate node of right subtree.
From Fig. 1.28, delete the node with data 12.
22 22
12 15
30 30
10 15 10
25 35 25 35
32 32
33
33
Pictorial representation is shown in Fig. 1.29.
Delete x
x z
y z y
Fig. 1.29: Pictorial Representation
The another approach is to delete x from T by first deleting inorder successor of node
x say z, then replace the data content in node x by the data content in node z.
Inorder successor means the node which comes after node x during the inorder
traversal of T.
• Example: Consider 1.30 and delete node with data 15.
10 10
Delete 15
8 15 8 16
6 6
20 11 20
11
16 22 18 22
18
1.31
1.4.2 Compute the Height of a Binary Tree

• Recursive function which returns the height of linked binary tree:
int tree_height(struct node *root)
{
if (root == NULL)
return 0;
else
return (1+ max (tree_height (root → left), tree_height
(root → right)));
}
Here, function max() is defined as follows:
int max(int x, int y)
{
if (x > y)
return x;
else
return y;
}
1.4.3 Tree Traversals (Preorder, Inorder and Postorder) [April 16, 19]
• Traversing a binary tree refers to the process of visiting each and every node of the
tree exactly once.
• Traversal operation is used to visit each node (or visit each node exactly once). There
are two methods of traversal namely, recursive and non-recursive.
1. Recursive is a straight forward approach where the programmer has to convert
the definitions into recursions. The entire load is on the language translator to
carry out the execution.
2. Non-recursive approach makes use of stack. This approach is more efficient as it
requires less execution time.
• In addition, it is good for the programming language which do not support dynamic
memory management scheme.
• The sequence in which these entities processed defines a particular traversal method.
• There are three traversal methods i.e. inorder traversal, preorder traversal and post
order traversal.
• These traversal techniques are applicable on binary tree as well as binary search tree.
Preorder Traversal (DLR):
• In preorder traversal, the root node is visited before traversing it’s the left child and
right child nodes.
1.32
• In this traversal, the root node is visited first, then its left child and later its right child.
This preorder traversal is applicable for every root node of all subtrees in the tree.
(i) Process the root Data (D) (Data)
(ii) Traverse the left subtree of D in preorder (Left)
(iii) Traverse the right subtree of D in preorder (Right)
Preorder ⇒ Data − Left − Right (DLR)
Example:
• A preorder traversal of a tree in Fig. 1.31 (a) visit node in a sequence ABDECF.
A
B
C
D E F
Fig. 1.31 (a): Tree

• For the expression tree, preorder yields a prefix expression.
+
Prefix expression
- C is + - ABC
A B
Fig. 1.31 (b): Prefix Expression
• In preorder traversal, we visit a node, traverse left and continue again. When we
cannot continue, move right and begin again or move back, until we can move right
and stop. Preorder function can be written as both recursive and non-recursive way.
Recursive preorder traversal:
Algorithm:
Step 1 : begin
Step 2 : if tree not empty
visit the root
preorder (left child)
preorder(right child)
Step 3 : end
C Function for Recursive Preorder Traversal:
void preorder (struct treenode * root)
{
if (root)
{
printf("%d \t", root → data); /*data is integer type */;
preorder (root → left);
preorder (root → right);
}
}
1.33
Example:
• In the Fig. 1.32, tree contains an arithmetic expression. It gives us prefix expression as,
+ * − A/BCDE. The preorder traversal is also called as depth first traversal.
+
* E
- D
A l
B C
Fig. 1.32: Binary Tree for Expression
((A − B/C) * D) + E
Inorder Traversal (LDR):
• In Inorder traversal, the root node is visited between the left child and right child.
• In this traversal, the left child node is visited first, then the root node is visited and
later we go for visiting the right child node.
• This inorder traversal is applicable for every root node of all subtrees in the tree. This
is performed recursively for all nodes in the tree.
(i) Traverse the left substree of D in inorder (Left)
(ii) Process of root Data (D) (Data)
(iii) Traverse the right subtree of R in inorder (Right)
Inorder ⇒ Left − Data − Right (LDR)
Algorithm for Recursive Inorder Traversal:
Step 1 : begin
Step 2 : if tree is not empty
inorder (left child)
visit the root
inorder (right child)
Step 3 : end
'C' function for Inorder Traversal:
• The in order function calls for moving down the tree towards the left until, you can go
on further. Then visit the node, move one node to the right and continue again.
void inorder (tnode * root)
{
if(root)
{
inorder (root → left);
printf("%d", root → data);
inorder (root → right);
}
}
• This traversal is also called as symmetric traversal.
1.34
Postorder Traversal (LRD):

• In Postorder traversal, the root node is visited after left child and right child. In this
traversal, left child node is visited first, then its right child and then its root node. This
is recursively performed until the right most node is visited.
(i) Traverse the left subtree of D in postorder (Left)
(ii) Traverse the right subtree of D in postorder (Right)
(iii) Process of root Data (D) (Data)
Postorder ⇒ Left − Right − Data (LRD)
Algorithm for Recursive Postorder Traversal:
Step 1: begin
Step 2: if tree not empty
postorder (left child )
postorder(right)
visit the root
Step 3: end
'C' Function for Postorder Traversal:
void postorder (tnode * root)
{
if (root)
{
postorder(root → left);
postorder(root → right);
printf("%d", root → data);
}
}
Example: Traverse each of the following binary tree in inorder, preorder and
postorder.
(a)
log
Fig. 1.33
Traversals: Preorder Traversal: log ! n
Inorder Traversal: log n!
Postorder Traversal: n! log
1.35
(b)
and
and <
<
< d
c
a b
b c
Fig. 1.34
Traversals: Preorder Traversal: and and < a b < b c < c d
Inorder Traversal: a < b and b < c and c < d
Postorder Traversal: a b < b c and c d < and
(c)
1
Fig. 1.35
Traversals: Preorder Traversal: 1 2 3 4 5
Inorder Traversal: 2 4 5 3 1
Postorder Traversal: 5 4 3 2 1
(d)
1
2 3
4 5 6
7 8 9
Fig. 1.36
Traversals: Preorder Traversal: 1 2 4 7 3 5 6 8 9
Inorder Traversal: 4 7 2 1 5 3 8 6 9
Postorder Traversal: 7 4 2 5 8 9 6 3 1
1.36
Examples:
Example 1: Perform in order, post order and pre order traversal of the binary tree
shown in Fig. 1.37.
A In order traversal (left-root-right):
DCEBGFAIHJ
B H
Pre order traversal (root-left-right):

C F I J ABCDEFGHIJ
D E G Post order traversal (left-right-root):

Fig. 1.37 DECGFBIJHA
Example 2: Perform in order, post
order and pre-order traversal of the binary
tree shown in Fig. 1.38.
8
5 4
Pre-order: 8, 5, 9, 7, 1, 12, 2, 4, 11, 3
9 7 11 In-order: 9, 5, 1, 7, 2, 12, 8, 4, 3, 11
Post-order: 9, 1, 2, 12, 7, 5, 3, 11, 4, 8
1 12 3
Fig. 1.38
Program 1.4: Menu driven program for binary search tree creation and tree traversing.
#include<stdio.h>
#include<malloc.h>
#include<stdlib.h>
struct node
{
int data;
struct node *right;
struct node *left;
};
struct node *Create(struct node *, int);
void Inorder(struct node *);
void Preorder(struct node *);
void Postorder(struct node *);
1.37
int main()
{
struct node *root = NULL;
int choice, item, n, i;
printf("\n*** Binary Search Tree ***\n");
printf("\n1. Creation of BST");
printf("\n2. Traverse in Inorder");
printf("\n3. Traverse in Preorder");
printf("\n4. Traverse in Postorder");
printf("\n5. Exit\n");
while(1)
{
printf("\nEnter Your Choice :(1.Create 2.Inorder 3.Preorder
4.Postorder 5.Exit)\n");
scanf("%d",&choice);
switch(choice)
{
case 1:
root = NULL;
printf("Enter number of nodes:\n");
scanf("%d",&n);
for(i = 1; i <= n; i++)
{
printf("\nEnter data for node %d : ", i);
scanf("%d",&item);
root = Create(root,item);
}
break;
case 2:
Inorder(root);
break;
case 3:
Preorder(root);
break;
case 4:
Postorder(root);
break;
1.38
case 5:
exit(0);
default:
printf("Wrong Choice !!\n");
}
}
return 0;
}
struct node *Create(struct node *root, int item)
{
if(root == NULL)
{
root = (struct node *)malloc(sizeof(struct node));
root->left = root->right = NULL;
root->data = item;
return root;
}
else
{
if(item < root->data )
root->left = Create(root->left,item); //recursive function call
else if(item > root->data )
root->right = Create(root->right,item);
else
printf(" Duplicate Element is Not Allowed !!!");
return(root);
}
}
void Inorder(struct node *root)
{
if( root != NULL)
{
Inorder(root->left); //recursive function call
printf("%d ",root->data);
Inorder(root->right);
}
}
1.39
void Preorder(struct node *root)

{
if( root != NULL)
{
Preorder(root->left);//recursive function call
Preorder(root->right);
}
}
void Postorder(struct node *root)
{
if( root != NULL)
{
Postorder(root->left);//recursive function call
Postorder(root->right);
}
}
Output:
*** Binary Search Tree ***
1. Creation of BST
2. Traverse in Inorder
3. Traverse in Preorder
4. Traverse in Postorder
5. Exit
Enter Your Choice :(1.Create 2.Inorder 3.Preorder 4.Postorder 5.Exit)
1
Enter number of nodes:
5
Enter data for node 1 : 10
2
5 10 15 20 25
3
10 5 20 15 25
4
5 15 25 20 10
5
1.40
1.4.4 Level-order Traversal using Queue

• The level-order traversal of a binary tree traverses the nodes in a level-by-level
manner from top to bottom and among the nodes of the same level they are traversed
from left to right. A data structure called queue is used to keep track of the elements
yet to be traverse.
• Level order traversal of a tree is breadth first traversal for the tree. Level order
traversal of the tree in Fig. 1.39 is 1 2 3 4 5.
1
2 3
4 5
Fig. 1.39
1.4.5 Count Total Nodes of a Binary Tree [April 19]
• To count total nodes of a binary tree, we traverse a tree. We can use any of the three
traversal methods.
'C' Function:
int CountNode(struct node *root)
{
static int count;
if (root== NULL)
return 0;
else
count=1+CountNodes(root  left)+CountNodes(root  right);
return count;
}
OR
int CountNode (struct node * root)
{
if(root == NULL)
return 0;
else
return (1 + CountNode(root → left) + CountNode (root → right));
}
1.41
1.4.6 Count Leaf Nodes of a Binary Tree

• The node which do not have child node is called as leaf node.
'C' Function:
int CountLeaf(Tree * root)
{
if (root==NULL)
leafcount = 0;
else
if ((root  left == NULL) && (root  right == NULL))
return(1);
else
return((CountLeaf (root  left) + CountLeaf (root  right));
}
1.4.7 Count Non-Leaf Nodes of a Binary Tree

• The node which have at least one child is called as non-leaf node.
'C' Function:
int count_non_leaf(struct node * root)
{
if(root == NULL)
return 0;
if(root -> left == NULL && root -> right == NULL)
return 0;
return(1+ count_non_leaf(root -> left) + count_non_leaf(root->right));
}
1.4.8 Mirror Image of a Binary Tree

• The mirror image of a tree contains its left and right subtrees interchanged as shown
in Fig. 1.40.
20 20
10 30 30 10
5 8 32 8
32 5
Original tree Mirror image
Fig. 1.40: Mirror image of a Binary Tree

• Here, we start with lower level (leaves) and move upwards till the children of the root
are interchanged.
1.42
'C' Function:
struct node * mirror(struct node * root)
{
struct node * temp=NULL;
if (root != NULL)
{
temp = root -> left;
root -> left = mirror(root  right);
root -> right = mirror(temp);
}
return root;
}
1.5 APPLICATIONS [April 16]

• In this section we study various applications on tree such as heap sort, priority queue
implementation (Huffman encoding).
1.5.1 Heap Sort with its Implementation [April 19]
• Heap is a special tree-based data structure. Heap sort is one of the sorting algorithms
used to arrange a list of elements in order.
• The heaps are mainly used for implementing priority queue and for sorting an array
using the heap sort technique.
• Heap sort algorithm uses one of the tree concepts called Heap Tree. A heap tree data
structure is a complete binary tree, where the child of each node is equal to or smaller
in value than the value of its parent.
• There can be two types of heap:
1. Max Heap: In this type of heap, the value of parent node will always be greater
than or equal to the value of child node across the tree and the node with highest
value will be the root node of the tree.
2. Min Heap: In this type of heap, the value of parent node will always be less than
or equal to the value of child node across the tree and the node with lowest value
will be the root node of tree.
• Example: Given the following numeric data,
2 7 15 25 40 55 75
Max heap and min heap trees are shown in Fig. 1.41.
75 2
55 40 7 15
25 15 7 2 25 40 55 75
(a) Max Heap (b) Min Heap
Fig. 1.41: Heap Trees
• Heap sort It is one of the important application of heap tree.
• Heap sort is based on heap tree and it is an efficient sorting method. We can sort
either in ascending or descending using heap sort.
1.43
• Sorting includes three steps:

1. Built a heap tree with a given data.
2. Delete the root node from the heap.
• Rebuilt the heap after deletion and
• Place the deleted node is the output.
3. Continue step 2 until heap tree is empty.
Example: Consider the following set of data to be sort in ascending order.
32 15 64 2 75 67 57 80
We first create binary tree and then convert into heap tree.
32
15 64
2 75 67 57
80
Fig. 1.42
The tree of Fig. 1.42 is not a heap (max) tree, we convert it into heap tree as follows:
32 32
15 64 15 64
2 75 67 57 80 75 67 57
80 2
(a) (b)
32 80
80 64 32 64
15 75 67 57 15 75 67 57
2 2
(c) (d)
80
75 67
15 32 64 57
2
(e)
Fig. 1.43: Heap Tree (Max)
Here, if the keys in the children are greater than the parent node, the key in parent
and in child are interchanged.
1.44
Heap Sort Method/Implementation:

Algorithm Heap_Sort:
Step 1 : Accept n elements in the array A.
Step 2 : Convert data into heap (A).
Step 3 : Initialize i = n
Step 4 : while (i > 1) do
{swap (A[1], A[i]) /*swapping first (top) and last element*/
i=i−1 /*pointer is shifted to left*/
j=1 /*rebuilt the heap*/
Step 5 : while (j < i) do
{
lchild = 2 * j /*left child
rchild = 2 * j + 1 /*right child
if (A[j] < A[lchild]) and (A[lchild] > A[rchild]) then
{ swap(A[j]; A[lchild])
j = lchild
else
if (A[j] < A[rchild]) & (A[rchild] > A[lchild]) then
{
swap (A[j], A[rchild])
j = rchild
else
break
}
} /*endif*/
} /*endwhile*/
}/*endwhile of step 4*/
Step 6: Stop
Consider the heap tree of Fig. 1.44.
Iteration 1:
80
75 67
15 32 64 57 80 75 67 15 32 64 57 2
(a)
1.45
Iteration 2: (a)
2
75 67
15 32 64 57 2 75 67 15 32 64 57 80
80
(b) Swapping the root node and last node
Iteration 3:
75 57
15 67 15 67
2 32 64 57 2 32 64
(c) Rebuilt the heap tree (d) Swapping 57 and root node
67 15 64 2 32 57 75 80
67
64
67 15 64
(e) Rebuilt
15 57
15 64 2 32 57
2 32
2 32 57
64
64 15 57 2 32 32 67 75 80
(e) Rebuilt 57
15
(f)15
Swapping and 57
Rebuilt
64 15 57 2 32 67 75 80
2 32 57
(f) Swapping and Rebuilt 2
(g) After
15 swapping 32
32and 64
32
2
15 57
57 15 32 2 64 67 75 80
2
(g) After swapping 32 and 64 (h) Rebuilt
15 32
2 15 32 57 64 67 75 80
2 15 32 57 64 67 75 80
Sorted list when heap is empty
(i) After swapping 2 and 57 (j) Continue and we get emptyheap
Fig. 1.44: Tracing of Heap Sort
Hence we get the array sorted in ascending order.
1.46
Program 1.5: Program for heap sort.

#include <stdio.h>
void main()
{
int heap[10], no, i, j, c, root, temp;
printf("\n Enter no of elements :");
scanf("%d", &no);
printf("\n Enter the nos : ");
for (i = 0; i < no; i++)
scanf("%d", &heap[i]);
for (i = 1; i < no; i++)
{
c = i;
do
{
root = (c - 1) / 2;
if (heap[root] < heap[c]) /* to create MAX heap array */
{
temp = heap[root];
heap[root] = heap[c];
heap[c] = temp;
}
c = root;
} while (c != 0);
}
printf("Heap array : ");
for (i = 0; i < no; i++)
printf("%d\t ", heap[i]);
for (j = no - 1; j >= 0; j--)
{
temp = heap[0];
heap[0] = heap[j]; /* swap max element with rightmost leaf element */
heap[j] = temp;
root = 0;
do
{
c = 2 * root + 1; /* left node of root element */
if ((heap[c] < heap[c + 1]) && c < j-1) c++;
1.47
if (heap[root]<heap[c] && c<j)/* again rearrange to max heap array */

{
temp = heap[root];
heap[root] = heap[c];
heap[c] = temp;
}
root = c;
} while (c < j);
}
printf("\n The sorted array is : ");
for (i = 0; i < no; i++)
printf("\t %d", heap[i]);
printf("\n Complexity : \n Best case = Avg case = Worst case = O(n logn) \n");
}
Output:
Enter no of elements :5
Enter the nos :
10
6
30
9
40
Heap array : 40 30 10 6 9
The sorted array is : 6 9 10 30 40
Complexity :
Best case = Avg case = Worst case = O(n logn)
1.5.2 Introduction to Greedy Strategy

• Generally, optimization problem or the problem where we have to find maximum or
minimum of something or we have to find some optimal solution, greedy
technique/strategy is used.
• Greedy algorithm is an algorithm is designed to achieve optimum solution for a given
problem.
• In greedy algorithm approach, decisions are made from the given solution domain. As
being greedy, the closest solution that seems to provide an optimum solution is
chosen.
• Greedy algorithms try to find a localized optimum solution, which may eventually
lead to globally optimized solutions. However, generally greedy algorithms do not
provide globally optimized solutions.
1.48
• An optimization problem has two types of solutions:

1. Feasible Solution: This can be referred as approximate solution (subset of
solution) satisfying the objective function and it may or may not build up to the
optimal solution.
2. Optimal Solution: This can be defined as a feasible solution that either maximizes
or minimizes the objective function.
• A greedy algorithm proceeds step–by-step, by considering one input at a time. At each
stage, the decision is made regarding whether a particular input (say x) chosen gives
an optimal solution or not.
o Our choice of selecting input x is being guided by the selection function (say
select).
o If the inclusion of x gives an optimal solution, then this input x is added into the
partial solution set.
o On the other hand, if the inclusion of that input x results in an infeasible solution,
then this input x is not added to the partial solution.
o The input we tried and rejected is never considered again.
o When a greedy algorithm works correctly, the first solution found in this way is
always optimal.
• In brief, at each stage, the following activities are performed in greedy method:
1. First we select an element, say x, from input domain C.
2. Then we check whether the solution set S is feasible or not. That is, we check
whether x can be included into the solution set S or not. If yes, then solution set. If
no, then this input x is discarded and not added to the partial solution set S.
Initially S is set to empty.
3. Continue until S is filled up (i.e. optimal solution found) or C is exhausted
whichever is earlier.
(Note: From the set of feasible solutions, particular solution that satisfies or nearly
satisfies the objective of the function (either maximize or minimize, as the case
may be), is called optimal solution.
1.5.3 Huffman Encoding (Implementation using Priority Queue)

• Huffman encoding developed by David Huffman. Data can be encoded efficiently
using Huffman codes.
• Huffman code is a data compression algorithm which uses the greedy technique for its
implementation. The algorithm is based on the frequency of the characters appearing
in a file.
• Huffman code is a widely used and beneficial technique for compressing data.
Huffman's greedy algorithm uses a table of the frequencies of occurrences of each
character to build up an optimal way of representing each character as a binary
string.
• Huffman encoding is used to compress a file that can reduce the memory storage.
1.49
• How can we represent the data in a compact way?

1. Fixed Length Code: Each letter represented by an equal number of bits. With a
fixed length code, at least three (3) bits per character.
2. Variable Length Code: It can do considerably better than a fixed-length code, by
giving many characters’ short code words and infrequent character long code
words.
Greedy Algorithm for Constructing a Huffman Code:
• Huffman invented a greedy algorithm that creates an optimal prefix code called a
Huffman Code.
• There are following mainly two major parts in Huffman Coding:
1. Build a Huffman Tree from input characters.
2. Traverse the Huffman Tree and assign codes to characters.
Steps to build Huffman Tree:
• Input is an array of unique characters along with their frequency of occurrences and
output is Huffman Tree.
1. Create a leaf node for each unique character and build a min heap of all leaf nodes
(Min Heap is used as a priority queue. The value of frequency field is used to
compare two nodes in min heap. Initially, the least frequent character is at root).
2. Extract two nodes with the minimum frequency from the min heap.
3. Create a new internal node with a frequency equal to the sum of the two nodes
frequencies. Make the first extracted node as its left child and the other extracted
node as its right child. Add this node to the min heap.
4. Repeat Steps 2 and 3 until the heap contains only one node. The remaining node is
the root node and the tree is complete.
• Let us understand the algorithm with an example:
Character Frequency
a 5
b 9
c 12
d 13
e 16
f 45
Step 1 : Build a min heap that contains 6 nodes where each node represents root of a
tree with single node.
Step 2 : Extract two minimum frequency nodes from min heap. Add a new internal
node with frequency 5 + 9 = 14.
14
a 5 b 9
1.50
Now min heap contains 5 nodes where 4 nodes are roots of trees with single
element each, and one heap node is root of tree with 3 elements
Character Frequency
c 12
d 13
Internal Node 14
e 16
f 45
Step 3 : Extract two minimum frequency nodes from heap. Add a new internal node
with frequency 12 + 13 = 25.
25
c 12 d 13
Now min heap contains 4 nodes where 2 nodes are roots of trees with single
element each, and two heap nodes are root of tree with more than one nodes.
Character Frequency
Internal Node 14
e 16
Internal Node 25
f 45
Step 4 : Extract two minimum frequency nodes. Add a new internal node with
frequency 14 + 16 = 30.
30
e 16
14
a 5 b 9
Now min heap contains 3 nodes.

Character Frequency
Internal Node 25
Internal Node 30
f 45
1.51
frequency 25 + 30 = 55.
55
30
e 16
25
14 14
c 12 d 13 a 5 b 9
Now min heap contains 2 nodes.

Character Frequency
f 45
Internal Node 55
frequency 45 + 55 = 100.
100
f 45
55
30
e 16
25
14 14
c 12 d 13 a 5 b 9
Now min heap contains only one node.

Character Frequency
Internal Node 100
Since, the heap contains only one node, the algorithm stops here.
Steps to print codes from Huffman Tree:
Traverse the tree formed starting from the root. Maintain an auxiliary array.
While moving to the left child, write 0 to the array. While moving to the right
child, write 1 to the array. Print the array when a leaf node is encountered.
1.52
100
0 1
f 45
55
1
0 30
0 1
e 16
25
14 14
0 1 0 1
c 12 d 13 a 5 b 9
The codes are as follows:

Character Code word
f 0
c 100
d 101
a 1100
b 1101
e 111
Program 1.6: Program for Huffman Coding.
#include <stdio.h>
#include <stdlib.h>
/*This constant can be avoided by explicitly*/
/*calculating height of Huffman Tree*/
#define MAX_TREE_HT 100
/*A Huffman tree node*/
struct MinHeapNode {
/* One of the input characters */
char data;
/* Frequency of the character */
unsigned freq;
/* Left and right child of this node */
struct MinHeapNode *left, *right;
};
/* A Min Heap: Collection of */
/* min-heap (or Huffman tree) nodes */
struct MinHeap {
/* Current size of min heap */
unsigned size;
1.53
/* capacity of min heap */

unsigned capacity;
/* Array of minheap node pointers */
struct MinHeapNode** array;
};
/* A utility function allocate a new */
/* min heap node with given character */
/* and frequency of the character */
struct MinHeapNode* newNode(char data, unsigned freq)
{
struct MinHeapNode* temp = (struct MinHeapNode*)malloc
(sizeof(struct MinHeapNode));
temp->left = temp->right = NULL;
temp->data = data;
temp->freq = freq;
return temp;
}
/* A utility function to create */
/* a min heap of given capacity */
struct MinHeap* createMinHeap(unsigned capacity)
{
struct MinHeap* minHeap = (struct MinHeap*)malloc(sizeof(struct
MinHeap));
/* current size is 0 */
minHeap->size = 0;
minHeap->capacity = capacity;
minHeap->array = (struct MinHeapNode**)malloc(minHeap->
capacity * sizeof(struct MinHeapNode*));
return minHeap;
}
/* A utility function to */
/* swap two min heap nodes */
void swapMinHeapNode(struct MinHeapNode** a, struct MinHeapNode** b)
{
struct MinHeapNode* t = *a;
*a = *b;
*b = t;
}
/* The standard minHeapify function. */
1.54
void minHeapify(struct MinHeap* minHeap, int idx)

{
int smallest = idx;
int left = 2 * idx + 1;
int right = 2 * idx + 2;
if (left < minHeap->size && minHeap->array[left]->
freq < minHeap->array[smallest]->freq) smallest = left;
if (right < minHeap->size && minHeap->array[right]->
freq < minHeap->array[smallest]->freq) smallest = right;
if (smallest != idx) {
swapMinHeapNode(&minHeap->array[smallest], &minHeap->array[idx]);
minHeapify(minHeap, smallest);
}
}
/* A utility function to check */
/* if size of heap is 1 or not */
int isSizeOne(struct MinHeap* minHeap)
{
return (minHeap->size == 1);
}
/* A standard function to extract */
/* minimum value node from heap */
struct MinHeapNode* extractMin(struct MinHeap* minHeap)
{
struct MinHeapNode* temp = minHeap->array[0];
minHeap->array[0] = minHeap->array[minHeap->size - 1];
--minHeap->size;
minHeapify(minHeap, 0);
return temp;
}
/* A utility function to insert */
/* a new node to Min Heap */
void insertMinHeap(struct MinHeap* minHeap, struct MinHeapNode*
minHeapNode)
{
++minHeap->size;
int i = minHeap->size - 1;
while (i && minHeapNode->freq < minHeap->array[(i - 1) / 2]->freq) {
1.55
minHeap->array[i] = minHeap->array[(i - 1) / 2];

i = (i - 1) / 2;
}
minHeap->array[i] = minHeapNode;
}
/* A standard function to build min heap */
void buildMinHeap(struct MinHeap* minHeap)
{
int n = minHeap->size - 1;
int i;
for (i = (n - 1) / 2; i >= 0; --i)
minHeapify(minHeap, i);
}
/* A utility function to print an array of size n */
void printArr(int arr[], int n)
{
int i;
for (i = 0; i < n; ++i)
printf("%d", arr[i]);
printf("\n");
}
/* Utility function to check if this node is leaf */
int isLeaf(struct MinHeapNode* root)
{
return !(root->left) && !(root->right);
}
/* Creates a min heap of capacity */
/* equal to size and inserts all character of */
/* data[] in min heap. Initially size of */
/* min heap is equal to capacity */
struct MinHeap* createAndBuildMinHeap(char data[], int freq[], int size)
{
struct MinHeap* minHeap = createMinHeap(size);
for (int i = 0; i < size; ++i)
minHeap->array[i] = newNode(data[i], freq[i]);
minHeap->size = size;
buildMinHeap(minHeap);
return minHeap;
}
1.56
/* The main function that builds Huffman tree */

struct MinHeapNode* buildHuffmanTree(char data[], int freq[], int size)
{
struct MinHeapNode *left, *right, *top;
/* Step 1: Create a min heap of capacity */
/* equal to size. Initially, there are */
/* modes equal to size. */
struct MinHeap* minHeap = createAndBuildMinHeap(data, freq, size);
/* Iterate while size of heap doesn't become 1
while (!isSizeOne(minHeap)) {
/* Step 2: Extract the two minimum */
/* freq items from min heap */
left = extractMin(minHeap);
right = extractMin(minHeap);
/* Step 3: Create a new internal */
/* node with frequency equal to the */
/* sum of the two nodes frequencies. */
/* Make the two extracted node as */
/* left and right children of this new node. */
/* Add this node to the min heap */
/* '$' is a special value for internal nodes, not used */
top = newNode('$', left->freq + right->freq);
top->left = left;
top->right = right;
insertMinHeap(minHeap, top);
}
/* Step 4: The remaining node is the */
/* root node and the tree is complete. */
return extractMin(minHeap);
}
/* Prints huffman codes from the root of Huffman Tree. */
/* It uses arr[] to store codes */
void printCodes(struct MinHeapNode* root, int arr[], int top)
{
/* Assign 0 to left edge and recur */
if (root->left) {
arr[top] = 0;
printCodes(root->left, arr, top + 1);
}
/* Assign 1 to right edge and recur */
1.57
if (root->right) {
arr[top] = 1;
printCodes(root->right, arr, top + 1);
}
/* If this is a leaf node, then */
/* it contains one of the input */
/* characters, print the character */
/* and its code from arr[]
if (isLeaf(root)) {
printf("%c: ", root->data);
printArr(arr, top);
}
}
/* The main function that builds a */
/* Huffman Tree and print codes by traversing */
/* the built Huffman Tree */
void HuffmanCodes(char data[], int freq[], int size)
{
/* Construct Huffman Tree */
struct MinHeapNode* root = buildHuffmanTree(data, freq, size);
/* Print Huffman codes using */
/* the Huffman tree built above */
int arr[MAX_TREE_HT], top = 0;
printCodes(root, arr, top);
}
/* Driver program to test above functions */
int main()
{
char arr[] = { 'a', 'b', 'c', 'd', 'e', 'f' };
int freq[] = { 5, 9, 12, 13, 16, 45 };
int size = sizeof(arr) / sizeof(arr[0]);
HuffmanCodes(arr, freq, size);
return 0;
}
Output:
f: 0
c: 100
d: 101
a: 1100
b: 1101
e: 111
1.58
PRACTICE QUESTIONS
Q. I Multiple Choice Questions:
1. Which is widely used non-linear data structure?
(a) Tree (b) Array
(c) Queue (d) Stack
2. Which in a tree data structure stores the actual data of that particular element and
link to next element in hierarchical structure?
(a) Root (b) Node
(c) Child (d) Leaf
3. Which is the operation in tree will remove a node and all of its descendants from
the tree?
(a) Prune (b) Graft
(c) Insert (d) Delete
4. The depth of the root node = .
(a) 1 (b) 3
(c) 0 (d) 4
5. Which is a set of several trees that are not linked to each other.
(a) Node (b) Forest
(c) Leaf (d) Root
6. In which tree, every node can have a maximum of two children, which are known
as left child and right child.
(a) Binary (b) Binary search
(c) Strictly (d) Extended
7. Which is data structure like a tree-based data structure that satisfies a property
called heap property?
(a) Tree (b) Graph
(c) Heap (d) Stack
8. How many roots contains a tree?
(a) 1 (b) 3
(c) 0 (d) 4
9. The total number of edges from root node to a particular node is called as,
(a) Height (b) Path
(c) Depth (d) Degree
10. In which binary tree every node has either two or zero number of children?
(a) Binary (b) Binary search
(c) Strictly (d) Extended
11. Which tree operation will return a list or some other collection containing every
descendant of a particular node, including the root node itself?
(a) Prune (b) Graft
(c) Insert (d) Enumerate
1.59
12. The ways to represent binary trees are,

(a) Array (b) Linked list
(c) Both (a) and (b) (d) None of these
13. Which coding is a technique of compressing data to reduce its size without losing
any of the details?
(a) Huffman (b) Greedy
14. Which strategy provides optimal solution to the problem?
(a) Huffman (b) Greedy
15. Consider the following tree:
1
3
2
4 5 6 7
If the postorder traversal gives (ab–cd*+) then the label of the nodes 1, 2, 3, 4, 5, 6
will be,
(a) +, –, *, a, b, c, d (b) a, –, b, +, c, *, d
(c) a, b, c, d, –, *, + (d) –, a, b, +, *, c, d
16. Which of the following statement about binary tree is correct?
(a) Every binary tree is either complete or full
(b) Every complete binary tree is also a full binary tree
(c) Every full binary tree is also a complete binary tree
(d) A binary tree cannot be both complete and full
17. Which type of traversal of binary search tree outputs the value in sorted order?
(a) Preorder (b) Inorder
(c) Postorder (d) None of these
Answers
1. (a) 2. (b) 3. (a) 4. (c) 5. (b) 6. (a) 7. (c)
8. (a) 9. (c) 10.(c) 11. (d) 12. (c) 13. (a) 14. (b)
15. (a) 16. (c) 17. (b)
Q. II Fill in the Blanks:
1. A tree is a non-linear ______ data structure.
2. There is only ______ root per tree and one path from the root node to any node.
3. In tree data structure, every individual element is called as ______.
4. Nodes which belong to ______ parent are called as siblings.
5. The ______ operation will remove a specified node from the tree.
6. Height of all leaf nodes is ______.
7. A ______ tree is simply a tree with zero nodes.
1.60
8. In a binary tree, every node can have a maximum of ______ children.

9. ______External node is also a node with no child.
10. In a ______ binary tree, every internal node has exactly two children and all leaf
nodes are at same level.
11. In array representation of binary tree, we use a ______ dimensional array to
represent a binary tree.
12. Binary tree representing an arithmetic expression is called ______ tree.
13. In a binary search tree, the value of all the nodes in the left sub-tree is ______ than
the value of the root.
14. In ______ heap all parent node’s values are greater than or equal to children node’s
values, root node value is the largest.
Answers
1. hierarchical 2. one 3. Node 4. same 5. delete 6. 0
7. null 8. sequence 9. two 10. complete 11. one 12. expression
13. less 14. max
Q. III State True or False:

1. Tree is a linear data structure which organizes data in hierarchical structure.
2. The total number of children of a node is called as height of that Node.
3. A binary tree in which every internal node has exactly two children and all leaf
nodes are at same level is called Complete Binary Tree.
4. In any tree, there must be only one root node.
5. A tree is hierarchical collection of nodes.
6. The root node is the origin of tree data structure.
7. the leaf nodes are also called as External Nodes.
8. Removing a whole selection of a tree called grafting.
9. Total number of edges that lies on the longest path from any leaf node to a
particular node is called as height of that node.
10. A binary tree is a tree data structure in which each parent node can have at most
two children.
11. Adding a whole section to a tree called pruning.
12. In min heap all parent node’s values are less than or equal to children node’s
values, root node value is the smallest.
13. A heap is a complete binary tree.
14. An algebraic expression can be represented in the form of binary tree which is
known as expression tree.
Answers
1. (F) 2. (F) 3. (T) 4. (T) 5. (T) 6. (T) 7. (T)
8. (F) 9. (T) 10. (T) 11. (F) 12. (T) 13. (T) 14. (T)
1.61
Q. IV Answer the following Questions:

(A) Short Answer Questions:
1. What is tree?
2. List operations on tree.
3. Define the term binary tree.
4. What are the types of binary trees?
5. Define heap.
6. What is binary search tree?
7. List tree traversals.
8. Define expression tree.
9. What is heap sort?
10. What are the applications of trees?
11. List representations on trees.
12. Define node of tree.
13. What is path of tree.
14. Define skewed tree.
(B) Long Answer Questions:
1. Define tree. Describe array and linked representation of binary tree.
2. Explain various types of tree with diagram.
3. Define:
(i) Height of tree
(ii) Level of tree
(iii) Complete binary tree
(iv) Expression tree
(v) Binary search tree.
4. Describe full binary tree with example.
5. With the help of example describe binary tree.
6. Write a program to construct binary search tree of given numbers (data).
7. Root of a binary tree is an ancestor of every node, comment.
8. Write a function to count the number of leaf nodes of a given tree.
9. Write a function for postorder and preorder traversal of binary tree.
10. Define binary tree and its types.
11. Write a 'C' program to create a tree and count total number of nodes in a tree.
12. Write a recursive function in C that creates a mirror image of a binary tree.
13. Construct Binary search tree for the following data and give inorder, preorder and
postorder tree traversal.
20, 30, 10, 5, 16, 21, 29, 45, 0, 15, 6.
14. Write a 'C' function to print minimum and maximum element from a given binary
search tree.
15. Explain sequential representation of binary tree.
16. Define the following terms:
(i) Complete binary tree.
(ii) Strictly binary tree.
17. Write an algorithm to count leaf nodes in a tree.
1.62
18. What are different tree traversal methods? Explain with example.
19. What is binary search tree? How to implement it? Explain with example.
20. Traverse following trees in:
(i) Inorder (ii) Preorder (iii) Postorder
1
UNIVERSITY QUESTIONS AND ANSWERS

April 2016
1. List any two applications of tree data structure. [1 M]
Ans. Refer to Section 1.5.
2. Write a recursive ‘C’ function to insert an element in a binary search tree. [5 M]
Ans. Refer to Section 1.4.1.3.
3. Write the steps for creating a binary search tree for the following data:
13, 4, 25, 3, 21, 20, 7 [3 M]
4. Traverse the following binary tree using three traversals techniques (preorder,
postorder, inorder). [3 M]
A
B P
Q S
T
I J
Ans. Refer to Section 1.4.3.
April 2017
1. Write a ‘C’ function to compare two BST. [5 M]
2. Define skewed binary tree. [1 M]
October 2017
1. What is siblings? [1 M]
Ans. Refer to Section 1.1.3, Point (9).
1.63
2. Write a ‘C’ function to insert an element in a binary search tree. [5 M]

3. Show steps in creating a binary search tree for the data:
40, 70, 60, 50, 65, 20, 25 [3 M]
April 2018
1. Define degree of the tree. [1 M]
2. Write a recursive ‘C’ function to insert an element in a binary search tree. [5 M]
3. Write the steps for creating a binary search tree for the following data:
15, 11, 13, 8, 9, 18, 16 [4 M]
October 2018
1. What is complete binary tree? [1 M]
2. Write a recursive ‘C’ function to insert an element in a binary search tree.[5 M]
April 2019
1. Define the term right skewed binary tree. [1 M]
2. The indegree of the root node of a tree is always zero. Justify (T/F). [1 M]
3. Write a Recursive ‘C’ function to count total nodes in a BST. [1 M]
4. Write the steps for creating a BST for the following data:
22, 13, 4, 6, 25, 23, 20, 18, 7, 27. [4 M]
5. Define the term heap tree. [1 M]
6. Traverse the following binary tree using preorder, postorder, inorder. [3 M]
A
B F
C D G
H I

1.64
CHAPTER
2
Efficient Search Trees
Objectives …
To study AVL Trees with its Operations
To learn Red Black Trees
To understand B and B+ Tree with its Operations
2.0 INTRODUCTION
• The efficiency of many operations on trees is related to the height of the tree - for
example searching, inserting, and deleting.
• The efficiency of various operations on a Binary Search Tree (BST) decreases with
increase in the differences between the heights of right sub tree and left sub tree of the
root node.
• Hence, the differences between the heights of left sub tree and right sub tree should be
kept to the minimum.
• Various operations performed on binary tree can lead to an unbalanced tree, in which
either the height of left sub tree is much more than the height of right sub tree or vice
versa.
• Such type of tree must be balanced using some techniques to achieve better efficiency
level.
• The need to have balanced tree led to the emergence of another type of binary search
tree known as height-balanced tree (also known as AVL tree) named after their
inventor G. M. Adelson-Velsky and E. M. Landis.
• The AVL tree is a special kind of binary search tree, which satisfies the following two
conditions:
1. The heights of the left and right sub trees of a node differ by one.
2. The left and right sub trees of a node (if exist) are also AVL trees.
2.1 TERMINOLOGY
• In 1962, Adelson-Velsky and Landis introduced a binary tree structure that is balanced
with respect to the height of subtree. That is why it is called a height balanced tree.
• The basic objective of the height balanced tree is to perform the searching, insertion
and deletion operations efficiently.
• A balanced binary tree is a binary tree in which the heights of two sub trees (left and
right) of every node never differ by more than 1.
2.1
Data Structures & Algorithms - II Efficient Search Trees
• A binary search tree is said to height balanced binary tree if all its nodes have a
balance factor of 1, 0 or − 1 i.e.,
|hL − hR | ≤ 1
Where, hL and hR are heights of left and right subtrees respectively.
1. Balance Factor: [Oct. 17, April 19]
• The term Balancing Factor (BF) is used to determine whether the given binary
search tree is balanced or not.
• The BF of a code is calculated as the height of its left sub tree minus the height of
right sub tree i.e.,
Balance factor = hL − hR
• The balance factor of a node is a binary tree can have value +1, −1 or 0 depending on
whether the height of its left sub tree is greater than or equal to the height of its right
subtree.
• The balance factor of each node is indicated in the Fig. 2.1.
o If balance factor of any node is +1, it means that the left sub-tree is one level higher
than the right sub-tree.
o If balance factor of any node is 0, it means that the left sub-tree and right sub-tree
contain equal height.
o If balance factor of any node is −1, it means that the left sub-tree is one level lower
than the right sub-tree.
-1
L
0 E +1
T
0 0 +1
B J 0
N V
0
P
Fig. 2.1: Balance Factor in Binary Tree

2. AVL Tree:
• AVL tree is a binary search tree in which the difference of heights of left and right
subtrees of any node is less than or equal to one.
• The technique of balancing the height of binary trees was developed by in the year
1962 by G. M. Adelson-Velsky and E. M. Landis in the year 1962 and hence given the
short form as AVL tree Balanced Binary Tree.
• AVL trees are height balancing binary search tree. AVL tree checks the height of the
left and the right sub-trees and assures that the difference (balance factor) is not more
than 1.
• Fig. 2.2 shows a binary search tree and every node is satisfying balance factor
condition. So this tree is said to be an AVL tree.
2.2
0
25
1 0
Balance factor 20 36
-1 0 1 0
10 22 30 40
0 0 0 0
12 28 38 48
Fig. 2.2
3. Red Black Tree:
• A red black tree is a variant of Binary Search Tree (BST) in which an additional
attribute, ‘color’ is used for balancing the tree. The value of this attribute can be
either red or black.
• The red black trees are self-balancing binary search tree. In this type of tree, the leaf
nodes are the NULL/NIL child nodes storing no data.
• In addition to the conditions satisfied by binary search tree, the following
conditions/rules must also be satisfied for being a red black tree:
(i) Each and every node is either red or black.
(ii) The roof node and leaf nodes are always black in color.
(iii) If any node is red, then both its child nodes are black.
(iv) Each and every path from a given node to the leaf node contains same
number of black nodes. The number of black nodes on such a path is known
as black-height of a node.
• Fig. 2.3 shows a red back tree.
4
2 6
1 3 5 8
7 9
NULL node
Fig. 2.3
2.3
• The AVL trees are more balanced compared to red black trees, but they may cause
more rotations during insertion and deletion.
• So if the application involves many frequent insertions and deletions, then Red Black
trees should be preferred.
• And if the insertions and deletions are less frequent and search is a more frequent
operation, then AVL tree should be preferred over red black tree.
4. Splay Tree:
• Splay tree was invented by D. D. Sleator and R. E. Tarjan in 1985. According them the
tree is called splay tree (splay means to spread wide apart).
• Splay tree is another variant of a Binary Search Tree (BST). In a splay tree, recently
accessed element is placed at the root of the tree.
• Splay Tree is a self-adjusted/self-balancing Binary Search Tree in which every
operation on element rearranges the tree so that the element is placed at the root
position of the tree.
• All normal operations on a binary search tree are combined with one basic operation,
called splaying.
• Splaying the tree for a certain element rearranges the tree so that the element is
placed at the root of the tree.
• Fig. 2.4 shows an example of splay tree.
j
f l
b i k m
a e g
d h
Fig. 2.4
Rotations in Splay Tree:
• In zig rotation, every node moves one position to the right from its current position.
• In zag rotation, every node moves one position to the left from its current position.
• In zig-zig rotation, every node moves two positions to the right from its current
position.
• In zag-zag rotation, every node moves two positions to the left from its current
position.
• In zig-zag rotation, every node moves one position to the right followed by one
position to the left from its current position.
• In zag-zig rotation, every node moves one position to the left followed by one position
to the right from its current position.
2.4
5. Lexical Search Tree (Trie):

• Instead of searching a tree using the entire value of a key, we can consider the key to
be a sequence of characters, such as word or non-numeric identifier.
• When placed in a tree, each node has a place for each of the possible values that the
characters in the lexical tree can assume.
• For example, if a key can contain the complete alphabet, each node has 26 entries one
for each of the letters of the alphabet and known as a lexical 26-ary tree.
• Each and every entry in the lexical search tree contains a pointer to the nest level. In
addition, each node of 26-ary tree contains 26 pointers, the first representing the
letter A, the second the letter B, and so forth until the last pointer which represents the
letter Z.
• Because each letter in the first level must point to a complete set of values, the second
level contains 26*26 entries, one node of 26 entries for each of the 26 letters in the first
level.
• At the third level 26*26*26 entries and finally we store the actual key at the leaf.
• If a key has three letters, these are at least three levels in the tree. If a key has ten
letters, these are ten levels in the tree. Because of a lexical tree can contain many
different keys, the largest word determines the height of the tree.
• Fig. 2.5 shows a lexical tree.
A B C Y Z
A B C Y Z A B C Y Z A B C Y Z
...
A B C Y Z A B C Y Z
... ...
AAA AAZ ZZA ZZZ
Fig. 2.5: Lexical Tree Structure

Trie:
• A trie is a lexical m-ary tree in which the pointers pointing to non-existing characters
are replaced by null pointers.
• All the search trees are used to store the collection of numerical values but they are
not suitable for storing the collection of words or strings.
• Trie is a data structure which is used to store the collection of strings and makes
searching of a pattern in words more easy.
• The term trie came from the word retrieval. Trie is an efficient information storage
and retrieval data structure.
2.5
• Trie data structure makes retrieval of a string from the collection of strings more
easily.
• Trie is also called as Prefix Tree and sometimes Digital Tree. Trie is a tree like data
structure used to store collection of strings.
• Fig. 2.6 shows an example of trie. Consider a list of strings Cat, Bat, Ball, Rat, Cap, Be.
Root *
B C R
a e a a
l t $ t t
l $ $ $
$
Indicates end of a string
Fig. 2.6
2.2 AVL TREE

• In this section we will study concept of AVL tree and its rotations.
2.2.1 Concept
• AVL, named after inventors Adelson-Velsky and Landis, is a binary tree that self-
balances by keeping a check on the balance factor of every node.
• The balance factor of a node is the difference in the heights of the left and right
subtrees. The balance factor of every node in the AVL tree should be either +1, 0 or -1.
• AVL trees are special kind of binary search trees. In AVL trees, difference of heights of
left subtree and right subtree of any node is less than or equal to one.
• AVL trees are also called as self-balancing binary search trees. The node structure of
AVL tree are given below:
struct AVLNode
{
int data;
struct AVLNode *left, *right;
int balfactor;
};
• AVL tree can be defined as, let T be a non-empty binary tree with TL and TR as its left
and right subtrees. The tree is height balanced if:
o TL and TR are height balanced.
o hL − hR ≤ 1, where hL − hR are the heights of TL and TR.
2.6
J
+1
F -1 P
+1
D
G 0 L V -1
-1 +1
C 0
0 N S X 0
0
Q U
0 0
Fig. 2.7: AVL Tree with Balance Factors
• Balance factor of a node is the difference between the heights of the left and right
subtrees of that node. Consider the following binary search tree in Fig. 2.8.
90
63 200
30
175 300
21 35
180 220 320
10
184
182 186
Fig. 2.8: Binary Search Tree (BST)
Height of tree with root 90 (90) = 1 + max (height (63), height (200))
Height of (63) = 1 + height (30)
Height (30) = 1 + max (height (21), height (35))
Height (21) = 1 + height (10)
Height (10) = 1
Therefore,
Height (21) = 1 + 1 = 2
Height (30) = 1 + max (2, 1) = 1 + 2 = 3
Height (63) = 1 + 3 = 4
Height (175) = 1 + height (180)
Height (180) = 1 + height (184)
Height (182) = 1
Height (186) = 1
2.7
Height (184) = 1 + 1 = 2
Height (180) = 1 + 2 = 3
Height (175) = 1 + 3 = 4
Height (200) = 1 + max. (height (175), height (300))
= 1 + max (4, 2)
= 1+4=5
= 1 + max (4, 5)
= 1+5=6
• Thus, this tree has height 6. But from this we do not get any information about balance
of height. The tree is said to be balanced if the difference in the right subtree and left
subtree is not more than 1.
• Consider the above example in which all the leaf nodes have a balance factor of 0.
BF (21) = hL (10) − 0 = 1 − 0 = 1
BF (30) = hL − hR = 2 − 1 = 1
BF (63) = 3 − 0 = 3
BF (184) = 1 − 1 = 0
BF (180) = 0 − 2 = − 2
BF (175) = 0 − 3 = − 3
BF (300) = 1 − 1 = 0
BF (200) = 4 − 2 = 2
BF (90) = 4 − 5 = − 1
• Hence, the above tree is not height balanced. In order to balance a tree, we have to
perform rotations on the tree.
2.2.2 Rotations
• Rotation is the process of moving nodes either to left or to right to make the tree
balanced. To balance itself, an AVL tree may perform the following four kinds of
rotations:
1. Left Rotation (LL Rotation)
2. Right Rotation (RR Rotation)
3. Left-Right Rotation (LR Rotation)
4. Right-Left Rotation (RL Rotation)
• The first two rotations are single rotations and the next two rotations are double
rotations.
Single Left Rotation (LL Rotation):
• In LL Rotation, every node moves one position to left from the current position.
• To understand LL Rotation, let us consider the following insertion operation in AVL
tree.
2.8
insert 1, 2 and 3
-2 -2
1 1
-1 -1
0
2 2
2
0 0 0
0
1 3
3 3
Tree is imbalanced To make balanced we use LL Rotation After LL Rotation

which moves nodes one position to left Tree is Balanced
Fig. 2.9
Single Right Rotation (RR Rotation):
• In RR Rotation, every node moves one position to right from the current position.
• To understand RR Rotation, let us consider the following insertion operation in AVL

tree.
insert 3, 2 and 1
2 2
3 3
1 1
0
2 2
2
0 0 0 0
1 3
1 1
Tree is imbalanced To make balanced we use RR Rotation After RR Rotation

because node 3 has which moves nodes one position to right Tree is Balanced
balance factor 2
Fig. 2.10
Left Right Rotation (LR Rotation):
• The LR Rotation is a sequence of single left rotation followed by a single right rotation.
• In LR Rotation, at first, every node moves one position to the left and one position to
right from the current position.
• To understand LR Rotation, let us consider the following insertion operation in AVL

tree.
2.9
insert 3, 1 and 2
2
2 2 3
3 3 0
-1 -1 1 2
1 1 After LL 2 After RR 0 0
Rotation Rotation
0 0 1 3
0
2 2
1
Tree is imbalanced LL Rotation RR Rotation After LR Rotation

because node 3 has Tree is Balanced
balance factor 2
Fig. 2.11
Right Left Rotation (RL Rotation):
• The RL Rotation is sequence of single right rotation followed by single left rotation.
• In RL Rotation, at first every node moves one position to right and one position to left
from the current position.
• To understand RL Rotation, let us consider the following insertion operation in AVL
tree.
insert 1, 3 and 2
-2
-2 -2
1
1 1 0
1 1 -1
2
3 3 After RR 2 After LL 0 0
Rotation Rotation
0 0 1 3
0
2 2
3
Tree is imbalanced RR Rotation LL Rotation
After RL Rotation
because node 1 has
Tree is Balanced
balance factor -2
Fig. 2.12
Operations on AVL Tree:
• The operations are performed on AVL tree are search, insert and delete.
• The search operation in the AVL tree is similar to the search operation in a binary
search tree. In AVL tree, a new node is always inserted as a leaf node.
• The deletion operation in AVL tree is similar to deletion operation in BST. But after
every deletion operation, we need to check with the Balance Factor (BF) condition. If
the tree is balanced after deletion go for next operation otherwise perform suitable
rotation to make the tree balanced.
2.10
Example: Construct an AVL Tree by inserting numbers from 1 to 8.

insert 1
0
1 Tree is balanced
insert 2
-1
1
Tree is balanced
0
2
insert 3
-2 -2
1 1 0
2
-1 -1 After LL Rotation 0 0
2 2 1 3
0 0
3 3
Tree is imbalanced LL Rotation Tree is balanced

insert 4
-1
2
0 -1 Tree is balanced
1 3
0
4
insert 5
-2 -2 -1
2 2 2
0 0 0
-2 -2 0
1 1 1
3 3 4
After LL
-1 -1 Rotation at 3 0 0
4 4 3 5
0 0
5 5
Tree is imbalanced LL Rotation at 3 Tree is balanced
2.11
insert 6
-2 -2
2 2
0 0
-1 -1 0
1 1
4 3 4
0 0 After LL 0
-1 -1 Rotation at 2 -1
3 5 3 4 2 5
0 0 0 0 0
Becomes right
6 child of 2 5 1 3 6
insert 7
-1 -1
4 4
0 0
-2 -2 0
2 2
5 5 4
0 0 0 0 After LL 0
-1 -1 Rotation at 5
1 3 6 1 3 6 2 6
0 0 0 0 0 0
7 7 1 3 5 7
insert 8
-1
4
0 -1
2 6
0 0 0 -1
1 3 5 7
0
8
Tree is balanced
2.12
Example: Delete the node 30 from the AVL tree shown in the Fig. 2.13.
(0)
15
(0) (0)
12 54
(0) (-1) (1) (0)
8 13 18 60
(0) (0) (0) (0) (0)

(0)
5 9 14 16 56 70
Fig. 2.13
Step 1:
• The node to be deleted from the tree is 8.
• If we observe it is the parent node of the node 5 and 9.
• Since the node 8 has two children it can be replaced by either of its child nodes.
(0)
15
(0) (0)
12 54
(0) (-1) (1) (0)
8 13 18 60
(0) (0) (0) (0) (0)

(0)
5 9 14 16 56 70
Fig. 2.14
Step 2:
• The node 8 is deleted from the tree.
• As the node is deleted we replace it with either of its children nodes.
• Here we replaced the node with the inorder successor, i.e. 9.
• Again we check the balance factor for each node.
(0)
15
(0) (0)
12 54
(1) (-1) (1) (0)
9 13 18 60
(0) (0) (0) (0)

(0)
5 14 16 56 70
Fig. 2.15
2.13
Step 3:
• Now The next element to be deleted is 12.
• If we observe, we can see that the node 12 has a left subtree and a right subtree.
• We again can replace the node by either it’s inorder successor or inorder
predecessor.
• In this case we have replaced it by the inorder successor.
(0)
15
(0) (0)
12 54
(1) (-1) (1) (0)
9 13 18 60
(0) (0) (0) (0)

(0)
5 14 16 56 70
Fig. 2.16
Step 4:
• The node 12 is deleted from the tree.
• Since we have replaced the node with the inorder successor, the tree structure
looks like shown in the Fig. 2.17.
• After removal and replacing check for the balance factor of each node of the tree.
(0)
15
(1) (0)
13 54
(1) (0) (1) (0)
9 14 18 60
(0) (0) (0) (0)

5 16 56 70
Fig. 2.17
Step 5:
• The next node to be eliminated is 14.
• It can be seen clearly in the image that 14 is a leaf node.
• Thus it can be eliminated easily from the tree.
2.14
(0)
15
(1) (0)
13 54
(1) (0) (1) (0)
9 14 18 60
(0) (0) (0) (0)

5 16 56 70
Fig. 2.18
Step 6:
• As the node 14 is deleted, we check the balance factor of all the nodes.
• We can see the balance factor of the node 13 is 2.
• This violates the terms of the AVL tree thus we need to balance it using the rotation
mechanism.
(0)
15
(2) (0)
13 54
(1) (1) (0)
9 18 60
(0) (0) (0) (0)

5 16 56 70
Fig. 2.19
Step 7:
• In order to balance the tree, we identify the rotation mechanism to be applied.
• Here, we need to use LL Rotation.
• The nodes involved in the rotation is shown in Fig. 2.20.
(0)
15
(2) (0)
13 54
(1) (1) (0)
9 18 60
(0) (0) (0) (0)

5 16 56 70
Fig. 2.20
2.15
Step 8:
• The nodes are rotated and the tree satisfies the conditions of an AVL tree.
• The final structure of the tree is shown as follows.
• We can see all the nodes have their balance factor as ‘0’, ‘1’ and ‘-1’.
(-1)
15
(0) (0)
9 54
(0) (0) (1) (0)
5 13 18 60
(0) (0) (0)

16 56 70
Fig. 2.21
Examples: [April 16, 17, 18, 19, Oct. 17, 18]

Example 1: Create AVL tree for the following data:
Manisha, Kamal, Archana, Reena, Nidhi, Shalaka, Priya, Leena, Meena
Solution: We check the BST is balanced, if not, rotation is performed. The number
within each node indicates the balance factor. It is − 1, 0, 1 if tree is balanced.
(i) Manisha Manisha
0
(ii) Kamal Manisha

1
Kamal
0
(iii) Archana
Manisha
2 Kamal
0
LL
Rotation
Kamal
1
Archana Manisha
0 0
Archana
0
2.16
(iv) Reena
Kamal
-1
No balancing is required
Archana Manisha
0 -1
Manisha
2 Kamal
0
LL
Rotation
Kamal
1
Archana Manisha
0 0
Archana
Data Structures0& Algorithms - II Efficient Search Trees
(iv) Reena
Kamal
-1
Archana Manisha
0 -1
Reena
(v) Nidhi 0
Kamal Kamal
-2 -1
RL
Archana Manisha Rotation Archana Nidhi
0 -2 0 0
Reena Manisha Reena

1 0 0
Nidhi
0
(vi) Shalaka
Kamal Nidhi
-2 0
RR
Rotation
Archana Nidhi Kamal Reena
0 -1 0 -1
Manisha Reena Archana Manisha Shalaka

0 -1 0 0 0
Shalaka
0
(vii) Priya Nidhi

-1
Kamal Reena
0 0
Archana Manisha Priya Shalaka

0 0 0 0
(viii) Leena Nidhi

-1 2.17
Kamal Reena
-1 0

0 1 0 0
(vii) Priya Nidhi
-1
Kamal Reena
0 0

0
Data Structures & Algorithms - II 0 0 0 Efficient Search Trees
(viii) Leena Nidhi

-1
Kamal Reena
-1 0

0 1 0 0
Leena
0
(ix) Meena Nidhi

-1
Kamal Reena No balancing is required

-1 0

0 0 0 0
Leena Meena
0 0
Example 2: Consider AVL tree for following data:

Mon Sun Thur Fri Sat Wed Tue
Solution:
Sun
Mon Mon Mon RR 0
(i) 0 (ii) -1 (iii) -2 Rotation
Sun Thur
Sun Sun
0 Mon Thur
-1
0 0
Thur
(iv) Fri Sun 0
+1
Mon Thur No balancing required

+1 0
Fri
0
(v) Sat Sun (vi) Wed Sun

1 2.18 0
No balancing
Mon Thur Mon Thur required
0 0 0 -1
Fri Fri Wed

Sat Sat
0 0 0
0 0
Thur
(iv) Fri Sun 0
+1
Mon ThurSun No balancing required Sun

Mon Mon Mon RR
Mon
+1 0 0 Mon RR
(iii) 0
-1 (i)
-2 0 (ii) Rotation
-1 (iii) -2 Rotation
Thur Sun Thur
Data Structures Fri
& Algorithms - II Efficient Search Trees
Sun Sun Sun Sun
Mon Thur
0 -1 0 0 -1
Mon Thur
0 0 0 0
(v) Sat Sun (vi) Wed Sun
Thur 1 0
Thur
Sun (iv) Fri 0 Sun 0
+1 +1
No balancing
Mon Thur Mon Thur required
0 0 0 -1
Mon Thur No balancingMon
required Thur No balancing required
+1 0 +1 0
Fri Fri Wed
Sat Sat
0 0 0
0 0
Fri
0
(vii) Tue Sun Sun
Sun
(v)(vi)
SatWed Sun
(vi) Wed Sun Sun
1 0 1
-1 0 0
RL
No balancing
Rotation Thur No balancing
Thur MonMon
Mon Thur
Thur required Mon Mon Thur
Thur -2 required
0 00 0 -1 -2
0 0 0 -1
Tue
-1
Fri Fri
Fri Sat Sat Wed
Wed Fri Sat Wed
Sat Sat Fri Sat
00 0 01 0 0
0 00 0 0 0 0
Wed
Tue 0
n (vii) Tue Sun 0
Sun Sun
-1 0 Sun 0
0
RL RL
Rotation RL Thur Rotation
Thur Thur
Mon MonRotation Thur-2 Mon
Tue
0 0 Mon -2
-2 -2 00
0
Tue Tue
-1 -1
t Wed Fri Fri Sat Sat Wed Fri Sat
1 0 0 Fri Sat 0 Thur
0 0 1 0Wed
0 0 Wed 0 0 Wed
Tue 0 0
Tue
0 0
Sun Sun
0 0
RL RL
ation Tue Rotation
Mon Tue
0 Mon
0 0
0
Fri Sat Thur Wed Fri Sat Thur Wed

0 0 0 0 0 0 0 0
This is now balance tree.
2.19
Example 3: Construct an AVL tree for the following data:

50, 40, 20, 100, 80, 200, 150
Solution:
40
50 50 50 LR
(i) 50 (ii) 40 (iii) 20 0
0 1 2 Rotation
40 40
0 1 20 50
0 0
20
0
(iv) 100 40 (v) 80 40 40

-1 -2 RL -1
Rotation
20 50 20 50 20 80
0 -1 0 -2 0 0
100 100 50 100

0 1 0 0
80
No balancing required
0
(vi) 200 40 80
-2 0
RL
Rotation 100
20 80 40
0 -1 0 -1
50 100
0 -1 20 50 200
0 0 0
200
0
(vii) 150 Hence, above tree is balanced tree

80 80
-1 RL 0
Rotation
40 100 40 150
0 -2 0 0
20 50 200 20 50 100 200

0 0 1 0 0 0 0
150
0
Hence, above tree is balanced tree.
2.20
Example 4: Construct AVL tree for following data:

Red, blue, green orange, pink, black, grey, white, violet
Solution:
Green
Red Red Red LR
(i) Red (ii) Blue (iii) Green 0
0 1 2 Rotation
Blue Blue
0 -1 Blue Red
0 0
Green
0
(iv) Orange Green (v) Pink Green Green

-1 -2 -1
LR
Rotation
Blue Red Blue Red Blue Pink
0 1 0 2 0 0
Orange Red
Orange Orange 0
-1 0
0
Pink
0
(vi) Green
0
Blue Pink
1 0
Black Red
Orange
0 0
0
(vii) Grey Green (viii) White Green

0 -1
Blue Pink Blue Pink

1 1 1 0
Black Red Black Red

Orange Orange
0 0 0 -1
0 1
Grey Grey White

0 0 0
No balancing required No balancing required
Hence, the tree is balance tree.
2.21
2.3 RED BLACK TREE

• In this section we will study concept of red black tree and its operations like insertion
and deletion.
2.3.1 Concept
• A red-black tree is a type of binary search tree. It is self-balancing like the AVL tree.
• They are called red-black trees because each node in the tree is labeled/colored as red
or black.
Properties of Red-Black Tree:
1. Each node is either red or black.
2. The root of the tree is always black.
3. All leaves are NULL/NIL and they are black.
4. If a node is red, then its children are black.
5. Any path from a given node to any of its descendant leaves contains the same
amount of black nodes.
• Fig. 2.22 shows a representation of a red-black tree. Notice how each leaf is actually a
black, null value.
13
8 17
1 11 15 25
NIL 6 NIL NIL NIL NIL 22 27
NIL NIL NIL NIL NIL NIL

Fig. 2.22: Red-Black Tree
2.3.2 Operations
• In a red-black tree, there are two operations that can change the structure of the tree,
insert and delete.
• These changes might involve the addition or subtraction of nodes, the changing of a
node's color, or the re-organization of nodes via a rotation.
Insertion into Red Black Tree:
• In a red black tree, every new node must be inserted with the color red. The insertion
operation in red black tree is similar to insertion operation in binary search tree. But
it is inserted with a color property.
• After every insertion operation, we need to check all the properties of red-black tree. If
all the properties are satisfied, then we go to next operation otherwise we perform the
operations like recolor, rotation, rotation followed by recolor to make it red black tree.
2.22
insert (8)
Tree is Empty. So insert new node as Root node with black color.
8
insert (18)
Tree is not Empty. So insert new node with red color.
18
insert (5)
Tree is mat Empty. So insert new node with red color.
5 18
insert ( 15 )
8
Here there are two consecutive Red nodes (18 and 15).
5 18 The new node's parent sibling color is Red
and parent's parent is root node.
15 So we use RECOLOR to make it Red Black Tree.
After RECOLOR
5 18 After Recolor operation, the tree is satisfying

all Red Black Tree properties.
15
insert (17)
8
Here there are two consecutive
Red nodes (15 and 17).
5 18
The new node's parent sibling is NULL.
So we need rotation.
15 Here. we need LR Rotation and Recolor
17
After Left Rotation
8 After Right Rotation 8

and Recolor
5 18 5 17
17 15 18
15
2.23
insert ( 25 )
8
5 17 Red nodes (18 and 25),
The new node's parent sibling color is Red
18 and parent's parent is not root node.
15
So we use RECOLOR and Recheck.
25
After Recolor
8
After Recolor operation, the tree is satisfying
5 17 all Red Black Tree properties.
15 18
25
insert (40)
8
5 17 Red nodes (25 and 40).
The new node's parent sibling is NULL
15 18 So we need a Rotation and Recolor.
Here, we use LL Rotation and Recheck
25
After LL Rotation 40
and Recolor
5 17
After LL Rotation and Recolor operation,
the tree is satisfying all Red Black Tree properties.
15 25
18 40
2.24
Insert (80)
8
5 17 Red nodes (40 and 80). The new node's
parent sibling color is Red
15 25 and parent's parent is not root node.
So we use RECOLOR and Recheck.
18 40
80
After Recolor
8
After Recolor again there are two consecutive
5 17 Red nodes (17 and 25). The new node's
parent sibling color is Black. So we need
15 25 Rotation. We use Left Rotation and Recolor.
18 40
80
After Left Rotation and Recolor
17
8 25
5 15 18 40
80
Finally above tree is satisfying all the properties of Red Black Tree and
it is a perfect Red Black tree.
Deletion Red Black Tree:
• The deletion operation in red black tree is similar to deletion operation in BST. but
after every deletion operation, we need to check with the red-black tree properties.
• If any of the properties are violated then make suitable operations like recolor,
rotation and rotation followed by recolor to make it red-black tree.
• In this example, we show the red black trees that result from the successful deletion of
the keys in the order 8, 12, 19,31,38,41.
2.25
Delete 8
B B
38 38
R B R B
19 41 19 41
R B
R B
12 31 12 31
8
Delete 12
B B
38 38
R B B B
Case-2
19 41 19 41
B
B R
12 31 31
Delete 19
B B
38 38
B B R B
19 41 31 41
R
31
Delete 31
B B
38 38
B R
Case-2
31 41 41
Delete 38 B
B
38
41
R
41
Delete 41
No/Empty Tree.
2.4 MULTIWAY SEARCH TREE

• A multiway tree is a tree that can have more than two children. If a multiway tree can
have maximum m children, then this tree is called as multiway tree of order m (or an
m-way search tree).
2.26
• A multiway tree can have more than one value/child per node. They are written as m-
way trees where the m means the order of the tree. A multiway tree can have m-1
values per node and m children.
• An m-way tree is a search tree in which each node can have from 0 to m subtrees,
where m is defined as the B-tree order.
• Fig. 2.23 shows an example of m-way tree of order 4.
50 100 150
35 45 85 95 125 135 175
60 70 90 110 120
75
Fig. 2.23: Four-way Tree

2−3 Multi-way Search Tree:
• The 2−3 trees were invented by John Hopcroft in 1970. A 2-3 tree is a B-tree of order 3.
• A 2–3 tree is a tree data structure, where every node with children (internal node) has
either two children (2-node) and one data element or three children (3-nodes) and two
data elements.
• Fig. 2.24 shows complete 2-3 multi-way search tree. It has the maximum number of
entries for its heights.
33 72
17 23 42 68 85 96
Fig. 2.24: Complete 2-3 Tree

2–3–4 Multi-way Search Tree:
• A 2-3-4 tree is a B-tree of order 4. It is also called as called a 2–4 tree.
• In 2-3-4 tree every node with children (internal node) has either two, three, or four
child nodes.
• Fig. 2.25 shows 2-3-4 tree.
42
16 21 57 78 91
11 17 19 21 23 24 45 63 65 85 90 95
Fig. 2.25: 2-3-4 Tree

2.27
2.4.1 B-Tree
• In search trees like binary search tree, AVL tree, red-black tree, etc., every node
contains only one value (key) and a maximum of two children.
• But there is a special type of search tree called B-tree in which a node contains more
than one value (key) and more than two children.
• B-Tree was developed in the year 1972 by Bayer and McCreight with the name Height
Balanced m-way Search Tree. Later it was named as B-Tree.
• A B-tree is a specialized m-way tree that is widely used for disk access. A B tree of
order m can have a maximum of m–1 keys and m pointers to its sub-trees.
• B-tree is a type of tree in which each node can store multiple values and can point to
multiple subtrees.
• The B-trees are useful in case of very large data that cannot accommodated the main
memory of the computer and is stored on disks in the form of files.
• The B-tree is a self-balancing search tree like AVL and red-black trees. The main
objective of B-trees is to minimize/reduce the number of disk accesses for accessing a
record.
• Every B-tree has an order. B-tree of order m has the following properties:
1. All leaf nodes must be at same level.
2. All nodes except root must have at least [m/2]-1 keys and maximum of m-1 keys.
3. All non-leaf nodes except root (i.e. all internal nodes) must have at
least m/2 children.
4. If the root node is a non-leaf node, then it must have at least two children.
5. A non-leaf node with n-1 keys must have n number of children.
6. All the key values in a node must be in Ascending Order.
• Fig. 2.26 shows an example of B-tree of order 5.
66
35 45 80 100
20 30 38 40 48 52 56 68 70 73 77 85 90 110 115
Fig. 2.26: B-Tree of Order 5
2.4.1.1 Insertion and Deletion Operations on B-Tree

• The two most common operations insert and delete are performed on B-trees.
Insertion Operation on B-Tree:
• In a B-tree, all the insertion operations take place at the leaf nodes. To insert an
element, first the appropriate leaf node is found and then an element is inserted in
that node.
2.28
• Now, while inserting the element in the searched leaf node following one of the two
cases may arise:
1. There may be a space in the leaf node to accommodate more elements. In that
case, the element is simply added to the node in such a way that the order of
elements is maintained.
2. There may not be a space in the leaf node to accommodate more elements. In that
case, after inserting new element in the full leaf node, a single middle element is
selected from these elements and is shifted to the parent node and the leaf is split
into two nodes namely, left node and right node (at the same level).
• All the elements less than the middle element are placed in the left node and all the
elements greater than the middle element are placed in the right node.
• If there is no space for middle element in the parent node, the splitting of the parent
node takes place using the same procedure.
• The process of splitting may be repeated all the way to the root. In case the splitting of
root node takes place, a new root node is created that comprises the middle element
from the old root node.
• The rest of the elements of the old root node are distributed in two nodes created as a
result of splitting. The splitting of root node increases the height of B-tree by one.
• For example, consider the following step-by-step procedure for inserting elements in
the B-tree of order 4, i.e. any node can store at most 3 elements and can point to at
most 4 subtrees.
• The elements to be inserted in the B-tree are 66, 90, 40, 75, 30, 35, 80, 70, 20, 50, 45, 55,
110, 100, and 120.
• The element 66 forms the part of new root node, as B tree is empty initially
[Fig. 2.27 (a)].
• Since, each node of B tree can store up to 3 elements, the elements 90 and 40 also
become part of the root node [Fig. 2.27 (b)].
• Now, since the root node is full, it is split into two nodes. The left node stores 40, the
right node stores 90, and middle element 66 becomes the new root node. Since, 75 is
less than 90 and greater than 66, it is placed before 90 in the right node [Fig. 2.27 (c)].
• The elements 30 and 35 are inserted in left sub tree and the element 80 is inserted in
the right sub tree such that the order of elements is maintained [Fig. 2.27 (d)].
• The appropriate position for the element 70 is in the right sub tree, and since there is
no space for more elements, the splitting of this node takes place.
• As a result, the middle element 80 is moved to the parent node, the element 75 forms
the part of the left sub tree (of element 80) and the element 90 forms the part of the
right sub tree (of element 80). The new element 70 is placed before the element 75
[Fig. 2.27 (e)].
• The appropriate position for the element 20 is in the left most sub tree, and since
there is no space for more elements, the splitting of this node takes place as discussed
in the previous step. The new element 20 is placed before the element 30
[Fig. 2.27 (f)].
2.29
• This tree can be used for future insertions, but a situation may arise when any of the
sub trees splits and it will be required to adjust the middle element from that sub tree
to the root node where there is no space for more elements.
• Hence, keeping in mind the future requirements, as soon as root node becomes full,
splitting of root node must take place [Fig. 2.27 (g)]. This splitting of root node
increases the height of tree by one.
• Similarly, other elements 50, 45, 55, 110, 100, and 120 can be inserted in this B-tree.
The resultant B-tree is shown in Fig. 2.27 (h).
66 66
66 40 66 90 40 90 40 75 90
(a) (b) (c)
66
30 35 40 75 80 90
(d)
66 80 66 80
30 35 40 75 90 30 35 40 70 75 90
(e)
35 66 80 35 66 80
30 40 70 75 90 20 30 40 70 75 90
(f)
66
35 80
20 30 40 70 75 90
(g)
2.30
66
35 45 80 100
20 30 40 50 55 70 75 90 110 120
(h)
Fig. 2.27: Insertion Operation in B-Tree Deletion Operation on B-Tree:
• Deletion of an element from a B-tree involves following two steps:
1. Searching the desired element and
2. Deleting the element.
• Whenever, an element is deleted from a B-tree, it must be ensured that no property of
B-tree is violated after the deletion.
• The element to be deleted may belong to either leaf node or internal node.
• Consider a B-tree in Fig. 2.28.
13
4 7 17 20
1 3 5 6 8 11 12 14 16 18 19 23 24 25 26
Fig. 2.28
• If we want to delete 8 then it is very simple (See Fig. 2.29).
13
4 7 17 20
1 3 5 6 11 12 14 16 18 19 23 24 25 26
Fig. 2.29
• Now we will delete 20, the 20 is not in a leaf node so we will find its successor which is
23. Hence, 23 will be moved upto replace 20.
2.31
13
4 7 17 23
1 3 5 6 11 12 14 16 18 19 24 25 26
Fig. 2.30
• Next we will delete 18. Deletion of 18 from the corresponding node causes the node
with only one key, which is not desired in B-tree of order 5.
• The slibling node to immediate right has an extra key. In such a case we can borrow a
key from parent and move spare key of sibling to up (See Fig. 2.31).
13
4 7 17 24
1 3 5 6 11 12 14 16 19 23 25 26
Fig. 2.31
• Now delete 5. But deletion of 5 is not easy. The first thing is 5 is from leaf node.
Secondly this leaf node has no extra keys nor siblings to immediate left or right.
• In such a situation we can combine this node with one of the siblings. That means
removes 5 and combine 6 with the node 1, 3.
• To make the tree balanced we have to move parent's key down. Hence, we will move 4
down as 4 is between 1, 3 and 6. The tree will be looks like as shown in Fig. 2.32.
13
7 17 24
1 3 4 6 11 12 14 16 19 23 25 26
Fig. 2.32
• But again internal node of 7 contains only one key which not allowed in B-tree. We
then will try to borrow a key from sibling.
2.32
• But sibling 17, 24 has no spare key. Hence, what we can do is that, combine 7 with 13
and 17, 24. Hence the B-tree will be looks like as shown in Fig. 2.33.
7 13 17 24
1 3 4 6 11 12 14 16 19 23 25 26
Fig. 2.33
2.4.2 B+ Tree
• B+ (B Plus) Tree is a balanced, multi-way binary tree. The B+ Trees are extended
version of B-Trees.
• A B+ tree is an m-ary tree with a variable but often large number of children per node.
A B+ tree consists of a root, internal nodes and leaves. The root may be either a leaf or
a node with two or more children.
• A B+ tree can be viewed as a B-tree in which each node contains only keys (not key–
value pairs), and to which an additional level is added at the bottom with linked
leaves.
• The B+ tree is a variation of B-tree in a sense that unlike B-tree, it includes all the key
values and record pointers only in the leaf nodes, and key values are duplicated in
internal nodes for defining the paths that can be used for searching purposes.
• In addition, each leaf node contains a pointer, which points to the next leaf node, that
is, leaf nodes are linked sequentially (See Fig. 2.34).
• Hence, B+ tree supports fast sequential access of records in addition to the random
access feature of B-tree.
• Note that in case txt B+ trees, if key corresponding to the desired record is found in
any internal node, the traversal continues until its respective leaf node is reached to
access the appropriate record pointer.
• Fig. 2.34 shows a sample B+ tree.
Duplicated key
40
values
30 40 77 90
20 30 38 40 48 52 56 68 70 73 77 85 90 110 115
Only leaf nodes having record pointers with the key values
Fig. 2.34
2.33
4.2.2.1 Insertion and Deletion in B+ Tree

• The two most common operations insert and delete performed on B+ trees.
Insertion in B+ Tree:
• In B+ tree insert the new node as a leaf node.
• Example: Insert the value 195 into the B+ tree of order 5 shown in the Fig. 2.35.
60 78 108 120
48 53 57 69 74 83 88 110 119 129 154 190 200
Fig. 2.35
• The value 195 will be inserted in the right sub-tree of 120 after 190. Insert it at the
desired position (See Fig. 2.36).
60 78 108 120
48 53 57 69 74 83 88 110 119 129 154 190 195 200
Fig. 2.36
• The node contains greater than the maximum number of elements i.e. 4, therefore
split it and place the median node up to the parent.
60 78 108 120 190
48 53 57 69 74 83 88 110 119 129 154 195 200
Fig. 2.37
• Now, the index node contains 6 children and 5 keys which violates the B+ tree
properties, therefore we need to split it, shown in Fig. 2.38.
108
60 78 120 190
48 53 57 69 74 83 88 110 119 129 154 195 200
Fig. 2.38
Deletion in B+ Tree:
• Delete the key and data from the leaves.
• Delete the key 200 from the B+ tree shown in the Fig. 2.39.
2.34
108
60 78 120 190
48 53 57 69 74 83 88 110 119 129 154 195 200
Fig. 2.39
• The value 200 is present in the right sub-tree of 190, after 195, delete it.
108
60 78 120 190
48 53 57 69 74 83 88 110 119 129 154 195
Fig. 2.40
• Merge the two nodes by using 195, 190, 154 and 129.
108
60 78 120
48 53 57 69 74 83 88 110 119 129 154 190 195
Fig. 2.41
• Now, element 120 is the single element present in the node which is violating the
B+ Tree properties. Therefore, we need to merge it by using 60, 78, 108 and 120.
• Now, the height of B+ tree will be decreased by 1.
60 78 108 120
48 53 57 69 74 83 88 110 119 129 154 190 195
Fig. 2.42
PRACTICE QUESTIONS
1. Which factor on many tree operations related to the height of the tree?
(a) Efficiency (b) Degree
(c) Sibling (d) Path
2.35
2. An AVL tree named after inventors,

(a) Adelson (b) Velsky
(c) Landis (d) All of these
3. Which tree is a binary search tree that is height balanced?
(a) BST (b) B+
(c) AVL (d) Red-black
4. Which tree is a self-balancing binary search tree in which each node contains an
extra bit for denoting the color of the node, either red or black?
(a) AVL (b) BST
(c) Red-black (d) None of these
5. Which trees are a self-adjusting binary search tree?
(a) BST (b) Splay
(c) B+ (d) None of these
6. Which is is a tree-like data structure whose nodes store the letters of an alphabet?
(a) Trie (b) AVL
(c) B+ (d) Extended
7. Which search tree is one with nodes that have two or more children?
(a) Multiway (b) Red-black
(c) Splay (d) AVL
8. A binary tree is said to be balanced if the height of left and right children of every
node differ by either,
(a) -1 (b) +1
(c) 0 (d) All of these
9. A 2-3 tree is a B-tree of order,
(a) 2 (b) 1
(c) 3 (d) None of these
10. In which tree a new element must be added only at the leaf node.
(a) B-Tree (b) AVL
(c) Red-black (d) Splay
11. A balanced binary tree is a binary tree in which the height of the left and right
subtree of any node differ by not more than ______.
(a) 0 (b) 1
(c) 3 (d) 2
12. In an AVL tree which factor is the difference between the height of the left subtree
and that of the right subtree of that node.
(a) Root (b) Node
(c) Degree (d) Balance
13. Which of the following is the most widely used external memory data structure?
(a) AVL tree (b) B-tree
(c) Lexical tree (d) Red-black tree
2.36
14. A B-tree of order 4 and of height 3 will have a maximum of _______ keys.
(a) 255 (b) 63
(c) 127 (d) 188
15. Consider the below formations of red-black tree:
100 100 100
50 50 50
NULL NULL NULL
18 18 18
NULL NULL NULL
All the above formations are incorrect for it to be a red black tree. then what may
be the correct order?
(a) 50-black root, 18-red left subtree, 100-red right subtree
(b) 50-red root, 18-red left subtree, 100-red right subtree
(c) 50-black root, 18-black left subtree, 100-red right subtree
(d) 50-black root, 18-red left subtree, 100-black right subtree
16. What is the special property of red-black trees and what root should always be?
(a) a color which is either red or black and root should always be black color
(b) height of the tree
(c) pointer to next node
(d) a color which is either green or black
Answers
1. (a) 2. (d) 3. (c) 4. (c) 5. (b) 6. (a) 7. (a)
8. (d) 9. (c) 10.(a) 11. (b) 12. (d) 13. (b) 14. (a)
15. (a) 16. (a)

1. Balancing or self-balancing (height balanced) tree is a ______ search tree.
2. A binary tree is said to be balanced if, the difference between the heights of left
and right subtrees of every node in the tree is either ______.
3. The ______ tree is a variant of Binary Search Tree (BST) in which every node is
colored either red or black.
4. ______ is a process in which a node is transferred to the root by performing suitable
rotations.
5. ______ is a tree-based data structure, which is used for efficient retrieval of a key in
a large data-set of strings.
6. ______ tree is a self-balancing binary search tree in which each node maintains
extra information called a balance factor whose value is either -1, 0 or +1.
7. In the ______ m-ary tree, the key is represented as a sequence of characters.
2.37
8. Trie is an efficient information ______ data structure.

9. A splay tree also known as ______ tree is a type of binary search tree which
reorganizes the nodes of tree to move the most recently accessed node to the root
of the tree.
10. A ______ is a specialized M-way tree which is widely used for disk access.
11. A ______ tree is a multi-way search tree in which each node has two children
(referred to as a two node) or three children (referred to as a three node).
12. 2–3–4 trees are B-trees of order ______.
13. The B-tree generalizes the binary search tree, allowing for nodes with more than
______ children.
14. In a splay tree, splaying an element rearranges all the elements in the tree so that
splayed element is placed at the ______ of the tree.
15. A red-black tree is a ______ search tree in which each node is colored either red or
black.
Answers
1. binary 2. −1, 0 or +1 3. red black 4. Splaying 5. Trie 6. AVL
7. lexical 8. retrieval 9. self-adjusting 10. B-Tree 11. 2-3 12. 4
13. two 14. root 15. binary
1. An AVL tree is a self-balancing binary search tree.
2. The self-balancing property of an AVL tree is maintained by the balance factor.
The value of balance factor should always be -1, 0 or +1.
3. An AVL tree is a binary search tree where the sub-trees of every node differ in
height by at most 1.
4. B Tree is a self-balancing data structure based on a specific set of rules for
searching, inserting, and deleting the data in a faster and memory efficient way.
5. Red-black Tree is a self-balancing Binary Search Tree (BST).
6. In a AVL tree, every operation is performed at the root of the tree. All the
operations in splay tree are involved with a common operation called Splaying
(the process of bringing it to the root position by performing suitable rotation
operations).
7. A trie, also called digital tree or prefix tree used to store collection of strings.
8. To have an unbalanced tree, we at least need a tree of height 1.
9. Rotation is required only if, the balance factor of any node is disturbed upon
inserting the new node, otherwise the rotation is not required.
10. The B-tree is a generalization of a binary search tree in that a node can have more
than two children.
11. B+ Tree is an extension of B Tree which allows efficient insertion, deletion and
search operations.
Answers
1. (T) 2. (T) 3. (T) 4. (T) 5. (T) 6. (F) 7. (T)
8. (F) 9. (T) 10. (T) 11. (T)
2.38

1. What is height balance tree?
2. List operations on AVL tree.
3. What is Trie?
4. Define B-Tree.
5. List rotations on AVL tree.
6. Define multi-way search trees.
7. Define splay tree.
8. What is lexical search tree?
9. Define balance factor.
1. Describe need for height balanced trees.
2. With the help of example describe concept of AVL tree.
3. Explain concept of red-black tree diagrammatically.
4. Write short note on: Trie.
5. Describe lexical search tree with example.
6. How to insert and delete operations carried by red-black tree? Explain with
example.
7. Describe AVL tree rotations with example,
8. With explain B-Tree insert and delete operation.
9. Compare B-Tree and B+ Tree (any four points).
10. Write short note on: Splay tree.
11. With the help of example describe multi-way search tree.

April 2016
1. Construct AVL tree for the following data: [5 M]
Mon., Wed., Tue., Sat., Sun., Thur.
Ans. Refer to Section 2.2, Examples.
April 2017
Pen, Eraser, Book, Scale, Sketch pen, Crayon, Color pencil.
October 2017
1. Define balance factor. [1 M]
Ans. Refer to Section 2.1, Point (1).
2.39

NFD, ZIM, IND, AUS, NEL, ENG, SRL, PAK.
April 2018
SUN, FRI, MON, WED, TUE, THUR, SAT.
October 2018
55, 40, 25, 100, 80, 200, 150.
April 2019
1. Define balance factor. [1 M]
Ans. Refer to Section 2.1, Point (1).
2. Construct the AVL tree for the following data: [5 M]
Chaitra, Magh, Vaishakh, Kartik, Falgun, Aashadh.

2.40
CHAPTER
3
Graph
Objectives …
To study Basic Concepts of Graph Data Structure
To learn Graph Terminology
To understand Representation and Operations of Graph
To study Graph Traversals
To learn Greedy Strategy, Dynamic Programming Strategy of Graphs
3.0 INTRODUCTION
• Graph is one of the most important non-linear data structure. A graph is a pictorial
representation of a set of objects where some pairs of objects (vertices) are connected
by links (edges).
• A graph is a pair of sets (V, E), where V is the set of vertices and E is the set of edges,
connecting the pairs of vertices.
3.1 CONCEPT AND TERMINOLOGY

• In this section we study basic concepts and terminology in graph.
3.1.1 Concept
• A graph G is a set of two tuples G = (V, E) where, V is a finite non-empty set of vertices,
and E is the set of pairs of vertices called edges.
• Fig. 3.1 shows an example of graph.
B
A
C D
Fig. 3.1: Graph

The set of vertices in the above graph is, V = {A, B, C, D, E}.
The set of edges, E = {(A, B), (A, C), (C, D), (A, E), (E, D)}.
3.1
Data Structures & Algorithms - II Graph
• There are two types of Graph, Undirected graph and Directed graph.
1. Undirected Graph:
• In an undirected graph, the pair of vertices representing any edge is unordered i.e. the
pairs (v1, v2) and (v2, v1) represent the same edge.
• In other words, the edges have no direction in undirected graph.
Example: Consider the Fig. 3.2.
B B A
A A
B C
D C D C D E
(a) (b) (c)

Fig. 3.2: Undirected Graph
• In Fig. 3.2 (a) G = (V, E) where V = {A, B, C, D} and E = {(A, B), (A, C), (B, C), (C, D)}.
• In Fig. 3.2 (b) G = (V, E) where V = {A, B, C, D} and E = {(A, B), (A, C), (A, D), (B, D), (B, C),
(D, C)}.
• In Fig. 3.2 (c) G = (V, E) where V = {A, B, C, D, E} and E= {(A, B), (A, C), (C, D), (C, E)}.
This undirected graph is called Tree. Tree is a special case of graph.
2. Directed Graph:
• In a directed graph each edge is represented by a directed pair (v1, v2), v1 is the tail and
v2 is head of the edge i.e. the pairs (v1, v2) and (v2, v1) are different edges.
• In other words, the edges have direction in directed graph. Directed graph is also
called as Digraph.
• Fig. 3.3 shows the three directed graphs.
A
B A
A
B C B C
C D
E D D E F
(a)
(a) (b) (c)
(b) (c)
Fig. 3.3: Directed Graphs
• In Fig. 3.3 (a) G = (V, E) where V = {A, B, C, D, E} and E = {(A, B), (A, C), (C, D),
(A, E), (E, D)}.
• In Fig. 3.3 (b) G = (V, E) where V = {A, B, C, D} and E = {(A, B), (A, C), (C, D), (D, B)}.
• In Fig. 3.3 (c) G = (V, E) where V = {A, B, C, D} and E = {(A, B), (A, C), (B, D), (B, E), (C, F)}.
3.2
• Following table compares tree and graph data structures:

Sr.
Tree Graph
No.
1. A tree is a data structure in which each A graph is a collection of vertices or
node is attached to one or more nodes nodes, which are joined as pairs by
as children. lines (links) or edges.
2. Tree is a non-linear data structure. Graph is also a non-linear data
structure.
3. All the trees can be graphs. All the graphs are not trees.
4. The common tree traversal methods The two common graph traversal
are inorder, preorder, postorder method are Breadth First Search (BFS)
traversals. and Depth First Search (DFS).
5. It is undirected and connected. It can be directed or undirected; can be
connected or not-connected.
6. It cannot be cyclic. It can be cyclic or acyclic.
7. There is a root (first) node in trees. There is no root node in graph.
8. Tree data is represented in hierar- Graph did not represent the data is
chical manner so parent to child hierarchical manner so there is no
relation exists between the nodes. parent child relation between data
representation.
9. A tree cannot have a loop structure. A graph can have a loop structure.
3.1.2 Terminology
• Basic graph terminology listed below:
1. Adjacent Vertex: When there is an edge from one vertex to another then these
vertices are called adjacent vertices. Node 1 is called adjacent to node 2 as there
exists an edge from node 1 and node 2 as shown in Fig. 3.4.
4
2
3
Fig. 3.4
2. Cycle: A path from a vertex to itself is called a cycle. Thus, a cycle is a path in
which the initial and last vertices are same.
3.3
Example: Fig. 3.5 shows the path (A, B, C, A) or (A, C, D, B, A) are cycles of different
lengths. If a graph contains a cycle it is cyclic otherwise acyclic.
A
B C
Fig. 3.5: Cycle

3. Complete Graph: A graph G is said to be complete if every vertex in a graph is
adjacent to every other vertex. In this graph, number of edges = n(n-1)/2, where n =
no. of vertices.
A B
C D
Fig. 3.6: Complete Graph

Example: In Fig. 3.6, Number of vertices n=4, Number of edges=4(4–1)/2=6.
4. Connected Graph: An undirected graph G is said to be connected if for every pair
of distinct vertices vi, vj in V(G) there is a path from vi to vj.
A B A D
C C
Fig. 3.7: Connected
(a) Graph Fig. 3.8 Non-connected Graph
5. Degree of a Vertex: It is the number of edges incident(b)
to a vertex. It is written as
degree(V), where V is a vertex.
6. In-degree of a Vertex: In directed graph, in-degree of a vertex ‘v’ is the number of
edges for which ‘v’ is the head.
A B
Indegree of vertex B = 1
D Indegree of vertex C = 2
Indegree of vertex D = 2
E C Indegree of vertex E = 1
Indegree of vertex F = 1
F Indegree of vertex A = 1
Fig. 3.9: Digraph
3.4
7. Out-degree of a Vertex: In directed graph, the out-degree of a vertex ‘v’ is the total
number of edges for which ‘v’ is the tail.
From Fig. 3.9:
Outdegree of A = 1
Outdegree of B = 2
Outdegree of C = 2
Outdegree of D = 0
Outdegree of E = 2
Outdegree of F = 1
8. Isolated Vertex: If any vertex does not belong to any edge then it is called isolated
vertex.
B
D
A
Fig. 3.10: Isolated Node D in the Graph

9. Source Vertex: A vertex with in-degree zero is called a source vertex, i.e., vertex
has only outgoing edges and no incoming edges. For example, in Fig. 3.11, ‘C’ is
source vertex.
10. Sink Vertex: A vertex with out-degree zero is called a sink vertex i.e. vertex has
only incoming edge and no outgoing edge. For example, in Fig. 3.11, ‘B’ is sink
node.
11. Acyclic Graph: A graph without cycle is called acyclic graph. [Oct. 18]
A
C B
Fig. 3.11: Acyclic Graph

12. Subgraph: A subgraph of G is a graph G' such that V(G') ⊆ V(G) and E(G') ⊆ E(G).
A
B C A
D B C
(a) Graph
(a) G (b) Subgraph of G
Fig. 3.12
3.5 (b)
13. Weighted Graph: A weighted graph is a graph in which every edge is assigned a
weight. In Fig. 3.13 weight in a graph denote the distance between the two vertices
connected by the corresponding edge. The weight of an edge is also called its cost.
In case of a weighted graph, an edge is a 3-tuple (U, V, W) where U and V are
vertices and W is weight of an edge (U, V).
5
4
1
2
5
2 58
14
4
3 34
5
Fig. 3.13: Weighted Graph

14. Pendant Vertex: When in-degree of vertex is one and out-degree is zero then such
a vertex is called pendant vertex.
15. Spanning Tree: A spanning tree of a graph G = (V, E) is a subgraph of G having all
vertices of G and containing only those edges that are necessary to join all the
vertices in the graph. A spanning tree does not contain cycle in it. Fig. 3.14 shows
spanning Trees for graph in Fig. 3.6.
A B A B
C D C D
Fig. 3.14: Spanning Trees

16. Sling or Loop: An edge of a graph, which joins a node to itself, is called a sling or
loop. Fig. 3.15 shows an example of loop.
1 2
3 4
Fig. 3.15: Loop
3.6
3.2 REPRESENTATION OF GRAPH

• Representation of graph is a process to store the graph data into the computer
memory. Graph is represented by the following three ways:
1. Sequential representation using Arrays, (by means of Adjacency Matrix).
2. Linked representation using Linked List, (by means of Adjacency List).
3. Inverse adjacency list.
4. Adjacency multi-list representation.
3.2.1 Sequential Representation of Graph [April 16, 17, 18, 19 Oct. 17, 18]
• Graphs can be represented through matrix (array) in computer system's memory. This
is sequential in nature. This type of representation is called sequential representation
of graphs.
• The graph when represented using sequential representation using matrix, is
commonly known as Adjacency Matrix.
• Let G = (V, E) be a graph with n vertices, where n>=1. An adjacency matrix of G is a
2-dimentional n × n array, say A, with the following property:
A[i][j] = 1 if the edge (vi, vj) is in E(G)
= 0 if there is no such edge in G
• If the graph is undirected then,
A[i] [j] = A[j] [i] = 1
1 1
1
2 3 2 3 2
4 5 6 7 3
4
G1 G2 G3
Fig. 3.16: Undirected Graph G1, G2 and Directed Graph G3
• The graphs G1, G2 and G3 of Fig. 3.16 are represented using adjacency matrix in
Fig. 3.17.
1 2 3 4 1 2 3
1 0 1 1 1 1 0 1 0
2 1 0 1 1 2 1 0 1
3 1 1 0 1 3 0 0 0
4 1 1 1 0
G1 G3
3.7
1 2 3 4 5 6 7
1 0 1 1 1 0 0 1
2 1 0 1 1 1 0 0
3 1 1 0 0 0 1 1
4 1 1 0 0 1 0 0
5 0 1 0 1 0 0 0
6 0 0 1 0 0 0 1
7 1 0 1 0 0 1 0
G2
Fig. 3.17 (a): Adjacency Matrix for G1, G2 and G3 of Fig. 3.16
• Adjacency Matrix Representation of a Weighted Graph:
For weighted graph, the matrix A is represented as,
A[i] [j] = weight of the edge (i, j)
= 0 otherwise 1
Here, weight is labelled associated with edge.
Example, following is the weighted graph and its associated adjacency matrix.
1 19
1 2 3 4 5
10 15 1 0 15 12 19 0
4
2 10 0 14 0 0
2 12
3 0 0 0 0 9
8
14 6 4 0 0 0 0 0
3 5 5 0 0 6 8 0
9
Fig. 3.17 (b)
Example 1: Consider the following undirected graph and provide adjacency matrix.
The graph has 4 vertices and it is undirected graph. Write 1 to Number of vertices i.e. 1 to
4 as row and column headers to represent it in adjacency matrix. If edge exists between
any two nodes (row, column headers indicate nodes) write it as 1 otherwise 0 in the
matrix.
1 1 2 3 4
1 0 1 1 1
1 
2 3 2  0 1 0 
31 1 0 1 
4 1 0 
4
0 1
(a) Undirected Graph (b) Adjacency Matrix
Fig. 3.18
3.8
Example 2: Consider the following directed graph and 1 2

provide adjacency matrix. The graph has 5 vertices and it is
directed graph. Write 1 to Number of vertices i.e. 1 to 5 as row
5
and column headers to represent it in adjacency matrix. If edge
exists between any two nodes (row, column headers indicate
3 4
nodes) write it as 1 at (i, j) and (j, i) position in matrix otherwise 0
in the matrix. Fig. 3.19
The representation of the above graph using adjacency matrix
is given below:
1 2 3 4 5
1 0 1 0 0 0
2 0 0 1 0 0 
Adj-matrix = 3
 0 1 0 1 0 
4 1 0 0 0 1 
5 0 1 1 0 0 
Program 3.1: Program to represent graph as adjacency matrix.
#include <stdio.h>
#define MAX 10
void degree(int adj[][MAX],int x,int n)
{
int i,incount=0, outcount =0;
for(i=0;i<n;i++)
{
if( adj[x][i] ==1)
outcount++;
if( adj[i][x] ==1)
incount++;
}
printf("The indegree of the node %d is %d\n",x,incount++);
printf("The outdegree of the node %d is %d\n",x,outcount++);
}
int main()
{
int adj[MAX][MAX],n,i,j;
printf("Enter the total number of nodes in graph");
scanf("%d",&n);
for(i=0;i<n;i++)
3.9
for(j=0;j<n;j++)
{
printf("Enter Edge from %d to %d,(1: Edge 0: No edge) \n",i,j);
scanf("%d",&adj[i][j]);
}
for(i=0;i<n;i++)
{
degree(adj,i,n);
}
return 0;
}
Output:
Enter the total number of nodes in graph4
Enter Edge from 0 to 0,(1: Edge 0: No edge)
0
1
0
1
1
0
1
1
0
1
0
1
1
1
1
0
3.10
The indegree of the node 0 is 2

The outdegree of the node 0 is 2
Advantages of Array representation of Graph:
1. Simple and easy to understand.
2. Graphs can be constructed at run-time.
3. Efficient for dense (lots of edges) graphs.
4. Simple and easy to program.
5. Adapts easily to different kinds of graphs.
Disadvantages of Array representation of Graph:
1. Adjacency matrix consumes huge amount of memory for storing big or large
graphs.
2. Adjacency matrix requires huge efforts for adding/removing a vertex.
3. The matrix representation of graph does not keep track of the information related
to the nodes.
4. Requires that graph access be a command rather than a computation.
3.2.2 Linked Representation of Graphs [April 16, 17, 18, 19 Oct. 17, 18]
• We use the adjacency list for the linked representation of the graph. In adjacency lists
representation the n rows of the adjacency matrix are represented as n linked lists.
• The adjacency list representation maintains each node of the graph and a link to the
nodes that are adjacent to this node. When we traverse all the adjacent nodes, we set
the next pointer to null at the end of the list.
• Example: Consider the graph G. The Fig. 3.20 shows the graph G and linked
representation of G in memory. The linked representation will contain two lists:
1. A node vertex list: To keep the track of all the N nodes of the graph.
2. An edge list: To keep the information of adjacent vertices of each and every vertex
of a graph.
• Head node is used to represent each list, i.e. we can represent G by an array Head,
where Head [i] is a pointer to the adjacency list of vertex i.
1 2
5
C 4
Fig. 3.20: Directed graph

3.11
Vertex and its Adjacent Vertices

Vertex Adjacent Vertices
1 2, 4, 5
2 3, 4
3 4
4 −
5 4
head
2 4 5 NULL
1
2 3 4 NULL
3 4 NULL
5 4 NULL
Vertex list Edge list

Fig. 3.21: Adjacency List Representation (Directed Graph)
Adjacency List Representation for Undirected Graph:
• In this representation, n rows of the adjacency matrix are represented as n linked lists.
The nodes in list i represent the vertices that are adjacent to vertex i. head[i] is used to
th
represent i vertex adjacency list.
• Example: Consider the Fig. 3.22.
1 2 3 4 NULL
1
2 1 3 4 NULL
2 3
3 1 2 4 NULL
4 1 2 3 NULL
4
Undirected graph G1
Fig.3.22: Adjacency List Representation of G1 (Undirected Graph)
• The structure for adjacency list representation can be defined in C as follows:
#define MAX_V 20
struct node
{
int vertex;
struct node * next;
}
struct node head[MAX_V];
• In this representation every edge (vi, vj) of an undirected graph is represented twice,
once in the list of vi and in the list of vj.
• For directed graph time required is O(n) to determine whether, there is an edge from
vertex i to vertex j and for undirected graph time is O(n + e).
3.12
Example 1: Consider the undirected graph in Fig. 3.23 and provide adjacency list.
1 2 3
4 5
6 7
Fig. 3.23
Solution: The adjacency list is given in Fig. 3.24
First edge
1 2 5 4
2 1 3
3 2 5
4 1 6
5 1 3 6
6 4 5
7
Fig. 3.24
Example 2: Consider the weighted undirected graph in Fig. 3.25 and provide
adjacency list.
12
A B
7 1
17
15 F 2 C
19 10 6
E D
14
Fig. 3.25
Solution: An adjacency list for this graph is:
A B 12 E 15 F 17
B A 12 C 1 D 2 F 7
C B 1 D 6
D B 2 C 6 E 14 F 10
E A 15 D 14 F 19
F A 17 B 7 D 10 E 19
Fig. 3.26
3.13
Advantages of Linked List representation n of Graph:

1. Less storage for sparse (few edges) graphs.
2. Easy to store additional information in the data structure like vertex degree, edge
weight etc.
3. Better memory space usage.
4. Better graph traversal times.
5. Generally better for most algorithms.
Disadvantages of Linked List representation of Graph:
1. Generally, takes some pre-processing to create Adjacency list.
2. Algorithms involving edge creation, deletion and querying edge between two
vertices are better way with matrix representation than the list representation.
3. Adding/removing an edge to/from adjacent list is not so easy as for adjacency
matrix.
3.2.3 Inverse Adjacency List [Oct. 17]

• Inverse adjacency lists are a set of lists that contain one list for vertex. Each list
contains a node per vertex adjacent to the vertex it represents.
• Fig. 3.27 shows a graph and its inverse adjacency list.
G2 Head
1
1 2
2
2
3 1 2
3
(a) Graph (b) Linked List

Fig. 3.27
3.2.4 Adjacency Multi-Lists

• Adjacency multi-list is an edge, rather than vertex based graph representation.
• With adjacency lists, each edge in an undirected graph appears twice in the list. Also,
there is an obvious asymmetry for digraphs - it is easy to find the vertices a given
vertex is adjacent to (simply follow its adjacency list), but hard to find the vertices
adjacent to a given vertex (we must scan the adjacency lists of all vertices). These can
be rectified by a structure called an adjacency multi-list.
• In adjacency multi-list nodes may be shared among several list (an edge is shared by
two different paths).
• Typically, the following structure is used to represent an edge.
Visited Vertex at Vertex at Pointer to next edge Pointer to next edge
tail head containing vertex at tail containing vertex at head
3.14
Example: Consider following undirected graph G = (V, E)

where, V={0,1,2,3}, E={(0,1),(0,2),(0,3),(1,2),(1,3),(2,3)}
0 N1 0 1 N2 N4 edge (0,1)
1
N2 0 2 N3 N4 edge (0,2)
2
3 0 3 N5
N3 edge (0,3)
0 edge (1,2)
N4 1 2 N5 N6
N5 1 3 N6 edge (1,3)
1 2
N6 2 3 edge (2,3)
3
Lists: Vertex 0: N1 N2 N3, Vertex 1: N1 N4 N5
Vertex 2: N2 N4 N6, Vertex 3: N3 N5 N6
Fig. 3.28: Adjacency Multi-List Representation
3.3 GRAPH TRAVERSAL

• Graph traversal means visiting every vertex and edge exactly once in a well-defined
order.
• In many situations, we need to visit all the vertices and edges in a systematic fashion.
The graph traversal is used to decide the order of vertices to be visited in the search
process.
• A graph traversal finds the edges to be visited without creating loops that means using
graph traversal we visit all vertices of graph without getting into looping path.
• Traversal means visiting each element of the data structure representation, in graph it
refers to visiting each vertex of the graph. Traversing a graph means visiting all the
vertices in a graph exactly one.
• The two techniques are used for traversals:
1. Depth First Search (DFS), and
2. Breadth First Search (BFS).
3.3.1 Depth First Search (DFS) [April 16, 17, 18, 19 Oct. 17, 18]
• Depth First Search (DFS) is used to perform traversal of a graph.

• In this method, all the vertices are stored in a Stack and each vertex of the graph is
visited or explored once.
• The newest vertex (added last) in the Stack is explored first. To traverse the graph,
Adjacent List of a graph is created first.
3.15
• We use the following steps to implement DFS traversal:

Step 1 : Select any vertex as starting point for traversal. Visit that vertex and push
it on to the Stack.
Step 2 : Visit any one of the adjacent vertex of the vertex which is at top of the
stack which is not visited and push it on to the stack.
Step 3 : Repeat step 2 until there are no more vertices to be visited which are
adjacent to the vertex which is on top of the stack.
Step 4 : When there are no more vertices to be visited then use back tracking and
pop one vertex from the stack. (Back tracking is coming back to the vertex
from which we came to current vertex)
Step 5 : Repeat steps 2, 3 and 4 until stack becomes empty.
Step 6 : When stack becomes empty, then stop. DFS traversal will be sequence of
vertices in which they are visited using above steps.
• The algorithm for DFS can be outlined as follows:
1. for V = 1 to n do (Recursive)
visited[V] = 0 {unvisited}
2. i = 1 {start at vertex 1)
3. DFS (i)
begin
visited[i] = 1
display vertex i
for each vertex j adjacent to i do
if (visited[j] = 0)
then DFS(j)
end.
• Non-recursive DFS can be implemented by using stack for pushing all unvisited
vertices adjacent to the one being visited and popping the stack to find the next
unvisited vertex.
Algorithm for DFS (Non-recursive) using Stack:
1. Push start vertex onto STACK
2. While (not empty (STACK)) do
begin
v = POP (STACK)
if (not visited (v))
3.16
begin
visited[v] = 1
display vertex i
push anyone adjacent vertex x of v onto STACK which is not visted
end
end
3. Stop.
Pseudo 'C' Code for Recursive DFS:
int visited[MAX]={0};
DFS (int i)
{ int k;
visited[i] = 1;
printf(“ %d”,i);
for(k=0;k<n;k++)
if (A[i,k]==1 && visited[k]==0)
DFS (k);
}
• Let us consider graph 3.29 drawn below:
b c f
a e
d g h i
Fig. 3.29: Graph

• Let us traverse the graph using DFS algorithm which uses stack. Let 'a' be a start
vertex. Initially stack is empty.
Note: Doubled circle indicates backtracking point.
Sr.
Steps Stack Spanning Tree
No.
1. Select vertex 'a' as starting point
(visit 'a'). Push 'a' onto the stack a a
a a
Visited = {a} Visited = {a}
2. Visit any adjacent vertex of 'a' which b

is not visited ('b'). Push newly visited b b
a
vertex 'b' onto the stack. a a
Visited = {a,b}
contd. …
3.17
c
3. Visit any adjacent vertex of 'b' which c b c
bb c
b a
is not visited ('c'). Push 'c' onto the a a
a
stack. Visited = {a,b,c}
Visited = {a,b,c}
f f b bc cf f
4. Visit any adjacent vertex of 'c' which c c
is not visited ('f'). Push 'f' onto the b ba a
stack. a a ={a,b,c,f
Visited Visited ={a,b,c,f
} }
5. There is no new vertex to be visited c b b c c f f

c
from 'f'. So backtrack. Pop 'f' from b b a a
a a
the stack.
6. There is no new vertex to be visited b b c c f

f
b b a
form 'c'. So backtrack. Pop 'c' from a
a a
the stack.
e
7. Visit any adjacent vertex of 'b' which e b c f
b b c f
b a
is not visited ("e"). Push 'e' onto the a
a
a
stack. e Visited = {a, b, c, f, e}
e Visited = {a, b, c, f, e}
8. Visit any adjacent vertex of 'e' which b c f
g a
is not visited ('g'). Push 'g' onto the
e
stack. b
e
a g
Visited = {a, b, c, f, e, g}
9. Visit any adjacent vertex of 'g' which b c f

d
is not visited ('d'). Push 'd' onto the a
g
e
stack. e
b
d g
a
Visited = {a, b, c, f, e, g, d}
10. There is no new vertex to be visited b c f

g
from 'd'. So backtrack. Pop 'd' from e a
b e
the stack.
a
d g
contd. …
3.18
11. Visit any adjacent vertex of 'g' which b c f

is not visited ('h'). Push 'h' onto the h
a
g
stack. e
e
b d g h
a
Visited = {a, b, c, f, e, g, d, h}
12. Visit any adjacent vertex of 'h' which i b c f
is not visited ('i'). Push 'i' onto the h a
stack. g e
e
d g h i
b
a Visited = {a, b, c, f, e, g, d, h, i}
13. There is no new vertex to be visited h b c f
from 'i'. So backtrack pop 'i' from the g a
stack. e e
b
a d g h i

g
from 'h'. So backtrack. Pop 'h' from
e a
the stack.
b e
a
f g h i

from 'g'. So backtrack. Pop 'g' from
e a
the stack.
b e
a
d g h i

from 'e'. So backtrack. Pop 'e' from a
the stack. e
b
a
d g h i

from 'b'. So backtrack. Pop 'b' from a
the stack. e
a
d g h i
contd. …
3.19

from 'a'. So backtrack. Pop 'a' from a
the stack. e
d g h i
Stack becomes Empty. So Stop DFS traversal, final result of DFS traversal is following
spanning tree.
b c f
a
e
d g h i
3.3.2 Breadth First Search (BFS) [April 16, 17, 18, 19 Oct. 17, 18]
• Another systematic way of visiting the vertices is Breadth-First Search (BFS). Starting
at vertex v and mark it as visited, the BFS differs from DFS, in that all unvisited
vertices adjacent to i are visited next.
• Then unvisited vertices adjacent to these vertices are visited and so on until the all
vertices has been in visited. The approach is called 'breadth first' because from vertex
i that we visit, we search as broadly as possible by next visiting all the vertices
adjacent to i.
• In BFS method, all the vertices are stored in a Queue and each vertex of the graph is
visited or explored once.
• The oldest vertex (added first) in the Queue is explored first. To traverse the graph
using breadth first search, Adjacent List of a graph is created first.
• For example, the BFS of graph of Fig. 3.30 results in visiting the nodes in the following
order: 1, 2, 3, 4, 5, 6, 7, 8.
1
2 3
4 5 6
7
Fig. 3.30
• This search algorithm uses a queue to store the adjacent vertices of each vertex of the
graph as and when it is visited.
3.20
• These vertices are then taken out from queue in a sequence (FIFO) and their adjacent
vertices are visited and so on until all the vertices have been visited. The algorithm
terminates when the queue is empty.
• The algorithm for BFS is given below. The algorithm initializes the Boolean array
visited[ ] to 0 (false) i.e. marks each vertex as unvisited.
for i = 1 to n do
visited[i] = 0.
Algorithm:
BFS (i)
begin
visited[i] = 1
add (Queue, i)
while not empty (Queue) do
begin
i = delete (Queue)
for all vertices j adjacent to i do
begin
if (visited[j] = 0)
add (Queue, j)
visited[j] = 1
end
end
end
• Here, while loop is executed n time as n is the number of vertices and each vertex is
inserted in a queue once. If adjacency list representation is used, then adjacent nodes
are computed in for loop.
Pseudo 'C' code for recursive BFS:
BFS (int i)
{
int k,visited[MAX];
struct queue Q;
for(k=0;k<n;k++)
visited[k] = 0;
visited[i] = 1;
printf(“ %d”,i);
insert(Q,i);
3.21
while (!Empty (Q))

{
j = delete(Q);
for(k=0;k<n;k++)
{
if (A[j,k]&&!visited[k])
{
insert(Q,k);
visited[k] = 1;
printf(“ %d”,k);
}
}
}
}
• Let us consider following graph,
b c f
a e
d g h i
• Let us traverse the graph using non-recursive algorithm which uses queue. Let 'a' be a
start vertex. Initially queue is empty. Initial set of visited vertices, V = φ.
(i) Add ‘a’ to the queue. Mark ‘a’ as visited. V = {a}
a
Front
Rear
(ii) As queue is not empty,
vertex = delete( ) = ‘a’.
Add all unvisited adjacent vertices of ‘a’ to the queue. Also mark them visited.
V = {a, b, d, e}
b d e
Front Rear
3.22
(iii) As queue is not empty,

Vertex = delete( ) = ‘b’. Insert all adjacent, unvisited vertices of ‘b’ to the queue.
V = {a, b, d, e, c}
d e c
Front Rear
(iv) As queue is not empty,
Vertex = delete( ) = ‘d’. Now insert all adjacent, unvisited vertices of ‘d’ to the
queue and mark them as visited
V = {a, b, d, e, c, g}
e c g
Front Rear
(v) As queue is not empty,

Vertex = delete( ) = ‘e’. There are no unvisited adjacent vertices of ‘e’. The queue
is as:
V = {a, b, d, e, c, g}.
c g
Front Rear
(vi) As queue is not empty, vertex = delete( ) = ‘c’.
Insert all adjacent, unvisited vertices of ‘c’ to the queue and mark them visited.
V = {a, b, d, e, c, g, f}
g f
Front Rear
(vii) As queue is not empty, vertex = delete( ) = ‘g’.
Insert all unvisited adjacent vertices of ‘g’ to the queue and mark them visited.
V = {a, b, d, e, c, g, f, h}
f h
Front Rear
3.23
(viii) As queue is not empty, vertex = delete( ) = ‘f’.

There are no unvisited adjacent vertices of ‘f’. The queue is as:
V = {a, b, d, e, c, g, f, h}
h
Front Rear
(ix) As queue is not empty, vertex = delete( ) = ‘h’.
Insert its unvisited adjacent vertices to queue and Mark them.
V = {a, b, d, e, c, g, f, h, i}
i
Front Rear
(x) As queue is not empty,
Vertex = delete( ) = ‘ i ’, No adjacent vertices of i are unvisited.
(xi) As queue is empty, stop.
The sequence in which vertices are visited by BFS is as:
a, b, d, e, c, g, f, h, i.
2 5 7
b c f
1 a e 4
d g h i
3 6 8 9
Fig. 3.31
Program 3.2: To create a graph and represent using adjacency matrix and adjacency list
and traverse in BFS order.
#include<stdio.h>
#include<stdlib.h>
struct q
{
int data[20];
int front, rear;
} q1;
struct node
{
int vertex;
struct node * next;
} * v[10];
3.24
void add (int n)

{
q1.rear++;
q1.data[q1.rear]=n;
}
int del()
{
q1.front++;
return q1.data[q1.front];
}
void initq()
{
q1.front = q1.rear = - 1;
}
int emptyq()
{
return (q1.rear == q1.front);
}
void create(int m[10][10], int n)
{
int i, j;
char ans;
for (i=0; i<n; i++)
for (j=0; j<n; j++)
{
m[i][i] = 0;
if(i != j)
{
printf("\n \t Is there an edge between %d and %d:", i+1, j+1);
scanf("%d", &m[i][j]);
}
}
} /* end of create */
void disp(int m[10][10], int n)
{
int i, j;
printf("\n \t the adjacency matrix is: \n");
3.25
for(i=0; i<n; i++)

{
for (j=0; j<n; j++)
printf("%5d", m[i][j]);
printf("\n");
}
} /* end of display */
void create1 (int m[10][10], int n)
{
int i, j;
struct node *temp, *newnode;
for(i=0; i<n; i++)
{
v[i] = NULL;
for(j=0; j<n; j++)
{
if(m[i][j] == 1)
{
newnode=(struct node *) malloc(sizeof(struct node));
newnode -> next = NULL;
newnode -> vertex = j+1;
if(v[i]==NULL)
v[i] = temp = newnode;
else
{
temp -> next = newnode;
temp = newnode;
}
}
}
}
}
void displist(int n)
{
struct node *temp;
int i;
for (i=0; i<n; i++)
{
printf("\nv%d | ", i+1);
temp = v[i];
3.26
while (temp)
{
printf("v%d -> ", temp -> vertex);
temp = temp -> next;
}
printf("null");
}
}
void bfs(int m[10][10], int n) //create adjacency list
{
int i, j, v, w;
int visited[20];
initq();
for(i=0; i<n; i++)
visited[i] = 0;
printf("\n \t The BFS traversal is: \n");
v=0;
visited[v] = 1;
add(v);
while(! emptyq())
{
v = del();
printf("\n v%d ", v + 1);
printf("\n");
for(w = 0; w < n; w++)
if((m[v][w] ==1) && (visited[w] == 0))
{
add(w);
visited[w] = 1;
}
}
}
/* main program */
void main()
{
int m[10][10], n;
printf("\n \t enter no. of vertices");
scanf("%d", &n);
create(m,n);
disp(m,n);
create1(m,n);
displist(n);
bfs(m,n);
}
3.27
Differentiation between DFS and BFS:

Sr.
DFS BSF
No.
1. DFS stands for Depth First Search. BFS stands for Breadth First Search.
2. DFS uses Stack implementation BFS uses Queue implementation
i.e. LIFO. i.e. FIFO.
3. DFS is faster. Slower than DFS.
4. DFS requires less memory. BFS uses a large amount of memory.
5. DFS is easy to implement in a DFS is complex or hard to implement
procedural language. in a procedural language.
6. The aim of DFS algorithm is to traverse The aim of BFS algorithm is to
the graph in such a way that it tries to traverse the graph as close as
go far from the root node. possible to the root node.
7. Used for topological sorting. Used for finding the shortest path
between two nodes.
8. Example: Example:
A A
B C B C
D E F D E F
A, B, D, C, E, F A, B, C, D, E, F
3.4 APPLICATIONS OF GRAPH [April 18, Oct. 18]
• In this we study various operations on graph like topological sorting, minimal

spanning tree, and so on.
3.4.1 Topological Sort [April 16, 19]
• A topological sort has important applications for graphs. Topological sorting is

possible if and only if the graph is a directed acyclic graph.
• Topological sorting of vertices of a directed acyclic graph is an ordering of the vertices
v1, v2, ... vn in such a way, that if there is an edge directed towards vertex vj from
vertex vi, then vi comes before vj.
• Topological ordering is not possible if the graph has a cycle. The Fig. 3.32 shows the
topological sorting.
3.28
P R
Q S P Q S R
Fig. 3.32: A Graph and its Topological Ordering

• The topological sort of a directed acyclic graph is a linear ordering of the vertices, such
that if there exists a path from vertex x to y, then x appears before y in the topological
sort.
• Formally, for a directed acyclic graph G = (V, E), where V = (V1, V2, V3, …, Vn}, if there
exists a path from any Vi to Vj, the Vi appears before Vj in the topological sort.
• An acyclic directed graph and have more than one topological sorts. For example, two
different topological sorts for the graph shown in Fig. 3.33 are (1, 4, 2, 3) and (1, 2, 4, 3).
2
1 3
Fig. 3.33: Acyclic Directed Graph

• Clearly, if a directed graph contains a cycle, topological ordering of vertices is not
possible. It is because for any two vertices Vi and Vj in the cycle, Vi precedes Vj as well
as Vj precedes Vi. To exemplify this, consider a simple cyclic directed graph shown in
Fig. 3.34.
• The topological sort for this graph is (1, 2, 3, 4) (assuming the vertex 1 as starting
vertex). Now, since there exists a path from the vertex 4 to 1, then according to the
definition of topological sort, the vertex 4 must appear before the vertex 1, which
contradicts the topological sort generated for this graph. Hence, topological sort can
exist only for the acyclic graph.
2
1 3
Fig. 3.34: Cyclic Directed Graph
3.29
• In an algorithm to find the topological sort of an acyclic directed graph, the indegree of
the vertices is considered. Following are the steps that are repeated until the graph is
empty.
1. Select any vertex Vi with 0 indegree.
2. Add vertex Vi to the topological sort (initially the topological sort is empty).
3. Remove the vertex Vi along with its edges from the graph and decrease the
indegree of each adjacent vertex of Vi by one.
• To illustrate this algorithm, consider an acyclic directed graph shown in Fig. 3.35.
2
3
2 6
0 1
1 3 5 3 Topological Short: Empty
4 7 3
2
Fig. 3.35: Acyclic Directed Graph
• The steps for finding topological sort for this graph are shown in Fig. 3.36.
2 1
3 3
2 6 2 6
0 1 0
1 3 5 3 Topological sort: 1 3 5 3
4 7 3 4 7 3
2 1
(a) Removing Vertex 1 with 0 Indegree
1 0
3 3
2 6 2 6
0
3 5 3 Topological sort: 1,3 5 2
4 7 3 4 7 2
1 0
(b) Removing Vertex 3 with 0 Indegree
3.30
0
3 2
2 6 6
5 2 Topological sort: 1,3,2 5 1

2
4 7 2 4 7 2
0 0
(c) Removing Vertex 2 with 0 Indegree
2 2
6 6
5 1 Topological sort: 1,3,2,4 5 0
4 7 2 7 1
0
(d) Removing Vertex 4 with 0 Indegree
2
6 6 1
5 0 Topological sort: 1,3,2,4,5
0
7 1 7
(e) Removing Vertex 5 with 0 Indegree

6 1
0
Topological sort: 1,3,2,4,5,7 6 Topological sort: 1,3,2,4,5,7,6
0
7
(f) Removing node 7 with 0 Indegree

Fig. 3.36: Steps for Finding Topological Sort
• Another possible topological sort for this graph is (1, 3, 4, 2, 5, 7, 6). Hence, it can be
concluded that the topological sort for an acyclic graph is not unique.
• Topological ordering can be represented graphically. In this representation, edges are
also included to justify the ordering of vertices (See Fig. 3.37).
3.31
1 3 2 4 5 7 6
(a)
1 3 4 2 5 7 6
(b)
Fig. 3.37: Graphical representation of Topological Sort
• Topological sort is useful for the proper scheduling of various subtasks to be executed
for completing a particular task. In computer field, it is used for scheduling the
instructions.
• For example, consider a task in which smaller number is to be subtracted from the
larger one. The set of instructions for this task is as follows:
1. if A>B then goto Step 2, else goto Step 3
2. C = A-B, goto Step 4
3. C = B-A, goto Step 4
4. Print C
5. End
• The two possible scheduling orders to accomplish this task are (1, 2, 4, 5) and
(1, 3, 4, 5). From this, it can be concluded that the instruction 2 cannot be executed
unless the instruction 1 is executed before it. Moreover, these instructions are non-
repetitive, hence acyclic in nature.
3.4.2 Use of Greedy Strategy in Minimal Spanning Trees

• There are many ways to construct a minimum spanning tree. One of the simplest
methods is known as a greedy strategy.
• Minimum Spanning Tree (MST) algorithms are a classic example of the greedy
method.
• Greedy strategy is used to solve many problems, such as finding the minimal spanning
tree in a graph using Prim’s /Kruskal’s algorithm.
Spanning Tree:
• A spanning tree is a subset of Graph G, which has all the vertices covered with
minimum possible number of edges.
3.32
• A spanning tree of a connected graph G is a tree that covers all the vertices and the
edges required to connect those vertices in the graph.
• Formally, a tree T is called a spanning tree of a connected graph G if the following two
conditions hold:
1. T contains all the vertices of G, and
2. All the edges of T are subsets of edges of G.
• For a given graph G with n vertices, there can be many spanning trees and each tree
will have n − 1 edges. For example, consider a graph as shown in Fig. 3.38.
• Since, this graph has 4 vertices, each spanning tree must have 4 − 1 = 3 edges. Some of
the spanning trees for this graph are shown in Fig. 3.39.
• Observe that in spanning trees, there exists only one path between any two vertices
and insertion of any other edge in the spanning tree results in a cycle.
• The spanning tree generated by using depth-first traversal is known as depth-first
spanning tree. Similarly, the spanning tree generated by using breadth-first traversal
is known as breadth-first spanning tree.
1
2 3 4
Fig. 3.38: A Graph G

1 1
2 3 4 2 3 4
(a) (b)
1 1
2 3 4 2 3 4
(c) (d)
Fig. 3.39: Spanning Trees of Graph G
• For a connected weighted graph G, it is required to construct a spanning tree T such
that the sum of weights of the edges in T must be minimum. Such a tree is called a
minimum spanning tree.
3.33
• There are various approaches for constructing a minimum spanning tree out of which
Kruskal's algorithm and Prim's algorithm are commonly used.
• If each edge of the graph is associated with a weight and there exists more than one
spanning tree, we need to find the minimum spanning tree of the graph.
• A Minimum Spanning Tree (MST) or minimum weight spanning tree is a subset of the
edges of a connected, edge-weighted undirected graph that connects all the vertices
together, without any cycles and with the minimum possible total edge weight.
• A minimum spanning tree in an undirected connected weighted graph is a spanning
tree of minimum weight (among all spanning trees).
• In a minimum spanning tree of a graph, the maximum weight of an edge is the
minimum possible from all possible spanning trees of that graph.
• In a minimum spanning tree of a graph, the maximum weight of an edge is the
minimum possible from all possible spanning trees of that graph.
• In the left image you can see a weighted undirected graph, and in the right image you
can see the corresponding minimum spanning tree.
5
4 3 4 3
9 8
3
5 1 3 6 5 1 3 6
4 7 4 7
1
C 2 1
C 2
2 2
(a) Weighted Undirected Graph (b) Minimum Spanning Tree
Fig. 3.40
Prim’s Minimum Spanning Tree (MST) Algorithm:
• Prim’s algorithm is a greedy strategy to find the minimum spanning tree. In this
algorithm, to form a MST we can start from an arbitrary vertex.
• Prim's algorithm shares a similarity with the shortest path first algorithms.
• Prim's algorithm, treats the nodes as a single tree and keeps on adding new nodes to
the spanning tree from the given graph.
• Example: Consider the following graph.
9
6
A B
7 5
4
S 3 2 T
8 2
C D
3
1
Fig. 3.41
3.34
Step 1: Remove all loops and parallel edges:

9
6
A B
7 5
4
S 3 2 T
8 2
C D
3
1
Fig. 3.42
• Remove all loops and parallel edges from the given graph. In case of parallel edges,
keep the one which has the least cost associated and remove all others.
6
A B
7 5
4
S 3 2 T
8 2
C D
3
Fig. 3.43
Step 2: Choose any arbitrary node as root node:
• In this case, we choose S node as the root node of Prim's spanning tree. This node is
arbitrarily chosen, so any node can be the root node. One may wonder why any video
can be a root node. So the answer is, in the spanning tree all the nodes of a graph are
included and because it is connected then there must be at least one edge, which will
join it to the rest of the tree.
Step 3: Check outgoing edges and select the one with less cost:
• After choosing the root node S, we see that S, A and S, C are two edges with weight 7
and 8, respectively. We choose the edge S, A as it is lesser than the other.
6
A B
7 5
4
S 3 2 T
8 2
C D
3
Fig. 3.44
• Now, the tree S-7-A is treated as one node and we check for all edges going out from it.
We select the one which has the lowest cost and include it in the tree.
6
A B
7 5
4
S 3 2 T
8 2
C D
3
Fig. 3.45
3.35
• After this step, S-7-A-3-C tree is formed. Now we'll again treat it as a node and will
check all the edges again. However, we will choose only the least cost edge. In this
case, C-3-D is the new edge, which is less than other edges' cost 8, 6, 4, etc.
6
A B
7 5
4
S 3 2 T
8 2
C D
3
Fig. 3.46
• After adding node D to the spanning tree, we now have two edges going out of it
having the same cost, i.e. D-2-T and D-2-B. Thus, we can add either one. But the next
step will again yield edge 2 as the least cost. Hence, we are showing a spanning tree
with both edges included.
A B
7
S 3 2 T
2
C D
3
Fig. 3.47
• We may find that the output spanning tree of the same graph using two different
algorithms is same.
Kruskal's Minimum Spanning Tree (MST) Algorithm:
• Kruskal's algorithm to find the minimum cost spanning tree uses the greedy strategy.
• Kruskal's algorithm treats the graph as a forest and every node it has as an individual
tree. A tree connects to another only and only if, it has the least cost among all
available options and does not violate MST properties.
• To understand Kruskal's algorithm let us consider the Fig. 3.48.
9
6
A B
7 5
4
S 3 2 T
8 2
C D
3
1
Fig. 3.48
3.36
Step 1: Remove all Loops and Parallel Edges:

• Remove all loops and parallel edges from the given graph.
9
6
A B
7 5
4
S 3 2 T
8 2
C D
3
1
Fig. 3.49
• In case of parallel edges, keep the one which has the least cost associated and remove
all others.
6
A B
7 5
4
S 3 2 T
8 2
C D
3
Fig. 3.50
Step 2: Arrange all edges in their increasing order of weight:
• The next step is to create a set of edges and weight, and arrange them in an ascending
order of weightage (cost).
B, D D, T A, C C, D C, B B, T A, B S, A S, C
2 2 3 3 4 5 6 7 8
Step 3: Add the edge which has the least weightage:
• Now we start adding edges to the graph beginning from the one which has the least
weight. Throughout, we shall keep checking that the spanning properties remain
intact. In case, by adding one edge, the spanning tree property does not hold then we
shall consider not to include the edge in the graph.
6
A B
7 5
4
S 3 2 T
8 2
C D
3
Fig. 3.51
• The least cost is 2 and edges involved are B, D and D, T. We add them. Adding them
does not violate spanning tree properties, so we continue to our next edge selection.
3.37
• Next cost is 3, and associated edges are A, C and C, D. We add them again:
6
A B
7 5
4
S 3 2 T
8 2
C D
3
Fig. 3.52
• Next cost in the table is 4, and we observe that adding it will create a circuit in the
graph.
6
A B
7 5
4
S 3 2 T
8 2
C D
3
Fig. 3.53
• We ignore it. In the process we shall ignore/avoid all edges that create a circuit.
6
A B
7 5
S 3 2 T
8 2
C D
3
Fig. 3.54
• We observe that edges with cost 5 and 6 also create circuits. We ignore them and move
on.
A B
7
S 3 2 T
8 2
C D
3
Fig. 3.55
• Now we are left with only one node to be added. Between the two least cost edges
available 7 and 8, we shall add the edge with cost 7.
A B
7
S 3 2 T
2
C D
3
Fig. 3.56
3.38
• By adding edge S, A we have included all the nodes of the graph and we now have
minimum cost spanning tree.
• Example: Consider the graph in Fig. 3.57.

0
3 6
1
1 3
5 5
3 2 2
6 4
2
C 5
6
Fig. 3.57
• Procedure for finding Minimum Spanning Tree:

Step 1:
No. of Nodes 0 1 2 3 4 5 0
Distance 0 3 1 6 ∞ ∞
1
Distance From 0 0 0
Step 2:
0
No. of Nodes 0 1 2 3 4 5 3
1
Distance 0 3 0 5 6 4 1
Distance From 0 2 2 2
2
Step 3:
0
3
No. of Nodes 0 1 2 3 4 5 1
1
Distance 0 0 0 5 3 4
3 2
Distance From 2 1 2
3.39
Step 4:
0
3
No. of Nodes 0 1 2 3 4 5 1
1
Distance From 2 2 3 2
4
4 5
Step 5:
0
3
No. of Nodes 0 1 2 3 4 5 1
1 3
Distance From 2 2 3 2 2
4
4 5
Minimum Cost = 1+2+3+3+4 = 13.
3.4.3 Single Source Shortest Path (Dijkstra’s Algorithm)

• Dijkstra's algorithm (or Dijkstra's Shortest Path First algorithm, SPF algorithm)[2] is an
algorithm for finding the shortest paths between nodes in a graph.
• Dijkstra’s algorithm solves the single-source shortest-paths problem on a directed
weighted graph G = (V, E), where all the edges are non-negative (i.e., w(u, v) ≥ 0 for
each edge (u, v) Є E).
• Dijkstra’s Algorithm can be applied to either a directed or an undirected graph to find
the shortest path to each vertex from a single source.
Example: Let us consider vertex 1 and 9 as the start and destination vertex
respectively. Initially, all the vertices except the start vertex are marked by ∞ and the start
vertex is marked by 0.
Step1 Step2 Step3 Step4 Step5 Step6 Step7 Step8
Vertex Initial
V1 V3 V2 V4 V5 V7 V8 V6
1 0 0 0 0 0 0 0 0 0
2 ∞ 5 4 4 4 4 4 4 4
3 ∞ 2 2 2 2 2 2 2 2
4 ∞ ∞ ∞ 7 7 7 7 7 7
5 ∞ ∞ ∞ 11 9 9 9 9 9
6 ∞ ∞ ∞ ∞ ∞ 17 17 16 16
7 ∞ ∞ 11 11 11 11 11 11 11
8 ∞ ∞ ∞ ∞ ∞ 16 13 13 13
9 ∞ ∞ ∞ ∞ ∞ ∞ ∞ ∞ 20
3.40
Hence, the minimum distance of vertex 9 from vertex 1 is 20. And the path is
1 → 3 →7 →8 →6 →9
This path is determined based on predecessor information.
7 8
2 5 6
5 3 4
2
7 9
1 2 4 5 3
6
2 3
3 7 8
9 2
Fig. 3.58
Example: Consider the graph in Fig. 3.59.
¥ ¥
2
B D
10
8
¥ A 1 4 7 9
3
C E
2
¥ ¥
Fig. 3.59
Procedure for Dijkstra's Algorithm:
Step 1 : Consider A as source Vertex.
¥
B
No. of Nodes A B C D E 10
Distance 0 10 3 ∞ ∞
0 A
Distance From A A
3
C
¥
Step 2 : Now consider vertex C.
10 ¥
B D
No. of Nodes A B C D E
10
Distance 0 7 3 11 5 8
0 A
Distance From C C C C
3
C E
2
3 ¥
3.41
Step 3 : Now consider vertex E.

10 ¥
B D
Distance 0 7 3 11 0 8
0 A 9
Distance From C A C E
3
C E
2
3 5
Step 4 : Now consider vertex B.

7 ¥
B D
10
4 9
0 A
Distance From C A B C
3
C E
2
3 5
Step 5 : Now consider vertex D.

7 9
B 2 D
10
Distance 0 7 3 9 11 8
4 9
0 A
Distance From A C A B C
3
C E
2
3 5
Therefore,
A B C D E
0 ∞ ∞ ∞ ∞
A 0 10 3 ∞ ∞
C 7 3 11 5
E 14 5
B 9
D 16
3.42
3.4.4 Dynamic Programming Strategy

• The all pairs shortest paths algorithm of Floyd and Warshall uses a dynamic
programming strategy.
• The shortest path problem is the problem of finding a path between two vertices (or
nodes) in a graph such that the sum of the weights of its constituent edges is
minimized.
• The problem of finding the shortest path between two intersections on a road map
may be modeled as a special case of the shortest path problem in graphs, where the
vertices correspond to intersections and the edges correspond to road segments, each
weighted by the length of the segment.
• Fig. 3.60 shows shortest path (A, C, E, D, F) between vertices A and F in the weighted
directed graph.
B 10 D
11
4
F
5 4
A
2
C E
3
Fig. 3.60
• The all-pairs shortest path problem, in which we have to find shortest paths between
every pair of vertices in the graph.
• The Floyd Warshall Algorithm is for solving the All Pairs Shortest Path problem. The
all pair shortest path algorithm is also known as Floyd-Warshall algorithm is used to
find all pair shortest path problem from a given weighted graph.
• The Floyd-Warshall algorithm is used for finding the shortest path between every pair
of vertices in the graph.
• This algorithm works for both directed as well as undirected graphs. This algorithm is
invented by Robert Floyd and Stephen Warshall hence it is often called as Floyed -
Warshall algorithm.
• Floyd-Warshall algorithm is used to find all pair shortest path problem from a given
weighted graph.
• As a result of this algorithm, it will generate a matrix, which will represent the
minimum distance from any node to all other nodes in the graph.
2 0 1 −3 2 −4
3 4
 3 0 −4 1 −1 
7 4 0 5 3 
7 1
1 3
8
-4 2 -5  2 −1 −5 0 −2 
C
5
6
4
8 5 1 6 0 
Fig. 3.61
3.43
• At first, the output matrix is the same as the given cost matrix of the graph. After that,
the output matrix will be updated with all vertices k as the intermediate vertex.
Input and Output:
Input: The cost matrix of the graph.
036∞∞∞∞
3021∞∞∞
620142∞
∞1102∞4
∞∞42021
∞∞2∞201
∞∞∞4110
Output: Matrix of all pair shortest path.
0345677
3021344
4201323
5110233
6332021
7423201
7433110
3.4.5 Use of Graphs in Social Networks

• A graph is made up of nodes; just like that a social media is a kind of a social network,
where each person or organization represents a node.
• A graph is made up of nodes; just like that a social media is a kind of a social network,
where each person or organization represents a node.
• In World Wide Web (WWW), web pages are considered to be the vertices. There is an
edge from a page u to other page v if there is a link of page v on page u. This is an
example of Directed graph.
• Graphs are awesome data structures that you use every day through Google Search,
Google Maps, GPS, and social media.
• They are used to represent elements that share connections. The elements in the graph
are called Nodes and the connections between them are called Edges.
• When we need to represent any form of relations in the society in the form of links, it
can be termed as Social Network.
• Social graphs draw edges between you and the people, places and things you interact
with online.
• Facebook's Graph API is perhaps the best example of application of graphs to real life
problems. The Graph API is a revolution in large-scale data provision.
3.44
• On The Graph API, everything is a vertice or node. This are entities such as Users,
Pages, Places, Groups, Comments, Photos, Photo Albums, Stories, Videos, Notes, Events
and so forth. Anything that has properties that store data is a vertice.
• The Graph API uses this, collections of vertices and edges (essentially graph data
structures) to store its data.
• The Graph API has come into some problems because of it's ability to obtain unusually
rich info about user's friends.
Jacie
John Juan
Jack Julia
Jade Jeff
Fig. 3.62: A sample Graph (in this graph, individuals are represented with nodes (circles) and
individuals who know each other are connected with edges (lines))
Example: Define spanning tree and minimum spanning tree. Find the minimum spanning
tree of the graph shown in Fig. 3.62.
Using Prim's Algorithm:
Let X be the set of nodes explored, initially X = {A}.
A
5
4
3
B E
6
2 5 6 7
C
C
1
D
Step 1 : Taking minimum weight edge of all Adjacent edges of X = {A}.

A
4
B X = {A, B}
Step 2 : Taking minimum weight edge of all Adjacent edges of X = {A, B}.
A
4
B
X = {A, B, C}
2
C
C
3.45
Step 3 : Taking minimum weight edge of all Adjacent edges of X = {A, B, C}.
A
4
2 X = {A, B, C, D)
C
C
1
D
Step 4 : Taking minimum weight edge of all Adjacent edges of X = {A, B, C, D}.
A
4
3
B E
2 X = {A, B, C, D, E}
C
C
1
D
All nodes of graph are there with set X, so we obtained minimum spanning tree of
cost: 4 + 2 + 1 + 3 = 10.
Using Kruskal's Algorithm:
• Let X be the set of nodes explored, initially X = (A).
A
5
4
3
B E
6
2 5 6 7
C
C
1
D
Step 1 : Taking minimum edge (C, D).
C
C
1
D
Step 2 : Taking next minimum edge (B, C).
B
C
C
1
D
Step 3 : Taking next minimum edge (B, E).
3
B E
C
C
1
D
3.46
Step 4 : Taking next minimum edge (A, B).

A
4
3
B E
C
C
1
D
Step 5 : Taking next minimum edge (A, E) it forms cycle so do not consider.
Step 6 : Taking next minimum edge (C, E) it forms cycle so do not consider.
Step 7 : Taking next minimum edge (A, D) it forms cycle so do not consider.
Step 8 : Taking next minimum edge (A, C) it forms cycle so do not consider.
Step 9 : Taking next minimum edge (E, D) it forms cycle so do not consider.
All edges of graph have been visited, so we obtained minimum spanning tree of
cost: 4 + 2 + 1 + 3 = 10.
Program 3.3: Program that accepts the vertices and edges of a graph. Create adjacency list
and display the adjacency list.
#include <stdio.h>
#include <stdlib.h>
#define new_node (struct node*)malloc(sizeof(struct node))
struct node
{
int vertex;
struct node *next;
};
void main()
{
int choice;
do
{
printf("\n A Program to represent a Graph by using an
Adjacency List \n ");
printf("\n 1. Directed Graph ");
printf("\n 2. Un-Directed Graph ");
printf("\n 3. Exit ");
printf("\n\n Select a proper choice : ");
scanf("%d", &choice);
3.47
switch(choice)
{
case 1 : dir_graph();
break;
case 2 : undir_graph();
break;
case 3 : exit(0);
}
}while(1);
}
int dir_graph()
{
struct node *adj_list[10], *p;
int n;
int in_deg, out_deg, i, j;
printf("\n How Many Vertices ? : ");
scanf("%d", &n);
for( i = 1 ; i <= n ; i++ )
adj_list[i] = NULL;
read_graph (adj_list, n);
printf("\n Vertex \t In_Degree \t Out_Degree \t Total_Degree ");
for (i = 1; i <= n ; i++ )
{
in_deg = out_deg = 0;
p = adj_list[i];
while( p != NULL )
{
out_deg++;
p = p -> next;
}
for ( j = 1 ; j <= n ; j++ )
{
p = adj_list[j];
while( p != NULL )
{
if ( p -> vertex == i )
in_deg++;
p = p -> next;
}
}
3.48
printf("\n\n %5d\t\t\t%d\t\t%d\t\t%d\n\n", i, in_deg,

out_deg, in_deg + out_deg);
}
return;
}
int undir_graph()
{
struct node *adj_list[10], *p;
int deg, i, j, n;
printf("\n How Many Vertices ? : ");
scanf("%d", &n);
for ( i = 1 ; i <= n ; i++ )
adj_list[i] = NULL;
read_graph(adj_list, n);
printf("\n Vertex \t Degree ");
for ( i = 1 ; i <= n ; i++ )
{
deg = 0;
p = adj_list[i];
while( p != NULL )
{
deg++;
p = p -> next;
}
printf("\n\n %5d \t\t %d\n\n", i, deg);
}
return;
}
int read_graph ( struct node *adj_list[10], int n )
{
int i, j;
char reply;
struct node *p, *c;
for ( i = 1 ; i <= n ; i++ )
{
for ( j = 1 ; j <= n ; j++ )
{
if ( i == j )
continue;
printf("\n Vertices %d & %d are Adjacent ? (Y/N) :", i, j);
scanf("%c", &reply);
3.49
if ( reply == 'y' || reply == 'Y' )

{
c = new_node;
c -> vertex = j;
c -> next = NULL;
if ( adj_list[i] == NULL )
adj_list[i] = c;
else
{
p = adj_list[i];
while ( p -> next != NULL )
p = p -> next;
p -> next = c;
}
}
}
}
return;
}
Output:
A Program to represent a Graph by using an Adjacency Matrix method
1. Directed Graph
2. Un-Directed Graph
3. Exit
Select a proper choice :
How Many Vertices ? :
Vertices 1 & 2 are Adjacent ? (Y/N) : N
Vertices 1 & 3 are Adjacent ? (Y/N) : Y
3.50
Vertex In_Degree Out_Degree Total_Degree
1 2 0 2
2 1 2 3
3 0 1 1
4 1 1 2
PRACTICE QUESTIONS
1. Which is a non-linear data structure?
(a) Graph (b) Array
(c) Queue (d) Stack
2. A graph G is represented as G = (V, E) where,
(a) V is set of vertices (b) E is set of edges
3. In which representation, the graph is represented using a matrix of size total
number of vertices by a total number of vertices.
(a) Adjacency List (b) Adjacency Matrix
(c) Adjacency Queue (d) Adjacency Stack
4. Each node of the graph is called a ______.
(a) Edge (b) Path
(c) Vertex (d) Cycle
5. Which representation of graph is based on linked lists?
(a) Adjacency List (b) Adjacency Matrix
6. Which of a graph means visiting each of its nodes exactly once?
(a) Insert (b) Traversal
(c) Delete (d) Merge
7. Which is a vertex based technique for finding a shortest path in graph?
(a) DFS (b) BST
(c) BFS (d) None of these
8. Which usually implemented using a stack data structure?
(a) DFS (b) BST
(c) BFS (d) None of these
9. Which is a graph in which all the edges are uni-directional i.e. the edges point in a
single direction?
(a) Undirected (b) Directed
(c) Cyclic (d) Acyclic
3.51
10. Which sorting involves displaying the specific order in which a sequence of
vertices must be followed in a directed graph?
(a) Cyclic (b) Acyclic
(c) Topological (d) None of these
11. Which is a subset of an undirected graph that has all the vertices connected by
minimum number of edges?
(a) Spanning tree (b) Minimum spanning tree
12. Which is a subset of edges of a connected weighted undirected graph that connects
all the vertices together with the minimum possible total edge weight?
(a) Spanning tree (b) Minimum Spanning Tree (MST)
Answers
1. (a) 2. (c) 3. (b) 4. (c) 5. (a) 6. (b) 7. (c)
8. (a) 9. (b) 10.(c) 11. (a) 12. (b)

1. Graph represented as ______.
2. A graph is ______ if the graph comprises a path that starts from a vertex and ends at
the same vertex.
3. Graph is a ______ data structure.
4. Individual data element of a graph is called as ______ (also known as node). An
edge is a connecting link between two vertices. Edge is also known as ______.
5. Graph traversal is a technique used for a ______ vertex in a graph.
6. We use ______ data structure with maximum size of total number of vertices in the
graph to implement DFS traversal.
7. The number of edges connected directly to the node is called as ______ of node.
8. The number edges pointing ______ the node are called in-degree/in-order.
9. A graph which has set of empty edges or is containing only isolated nodes is called
a ______ graph or isolated graph.
10. The ______ (or path) between two vertices is called an edge.
11. We use ______ data structure with maximum size of total number of vertices in the
graph to implement BFS traversal.
12. The graph traversal is also used to decide the order of vertices is ______ in the
search process.
3.52
13. The sequence of nodes that we need to follow when we have to travel from one
vertex to another in a graph is called the ______.
14. An adjacency ______ is a matrix of size n x n where n is the number of vertices in
the graph.
15. Topological ordering of vertices in a graph is possible only when the graph is a
______ acyclic graph.
16. A ______ (or minimum weight spanning tree) for a weighted, connected and
undirected graph is a spanning tree with weight less than or equal to the weight of
every other spanning tree.
17. The ______ algorithm is an example of an all-pairs shortest paths algorithm.
18. A graph ______ cycle is called acyclic graph.
Answers
1. G = (V, E) 2. cyclic 3. non-linear 4. Vertex, Arc
5. searching 6. Stack 7. degree 8. toward
9. Null 10. link 11. Queue 12. visited
13. path 14. matri 15. directed
16. Minimum Spanning Tree (MST) 17. Floyd-Warshall 18. without
1. An acyclic graph is a graph that has no cycle.
2. A Graph consists of a finite set of vertices (or nodes) and set of Edges which
connect a pair of nodes.
3. A graph in which weights are assigned to every edge is called acyclic graph.
4. The Floyd-Warshall algorithm is for solving the all pairs shortest path problem.
5. The number edges pointing away from the node are called out-degree/out-order.
6. In a graph, if two nodes are connected by an edge then they are called adjacent
nodes or neighbors.
7. Dijkstra's Algorithm can be applied to either a directed or an undirected graph to
find the shortest path to each vertex from a single source.
8. The graph is a linear data structures.
9. BFS usually implemented using a queue data structure.
10. The spanning tree does not have any cycle (loops).
11. Prim’s Algorithm will find the minimum spanning tree from the graph G.
12. Given an undirected, connected and weighted graph, find Minimum Spanning
Tree (MST) of the graph using Kruskal’s algorithm.
3.53
13. The number of edges that are connected to a particular node is called the path of
the node.
14. A spanning tree of that graph is a subgraph that is a tree and connects all the
vertices together.
15. Directed graph is also called as Digraph.
Answers
1. (T) 2. (T) 3. (F) 4. (T) 5. (T) 6. (T) 7. (T) 8. (T)
9. (F) 10. (T) 11. (T) 12. (T) 13. (F) 14. (T) 15. (T)

1. What is graph?
2. List traversals of graph.
3. Define the term cycle and path in graph.
4. Which data structure is used in to represent graph in adjacency list.
5. Define in-degree and out-degree of vertex.
6. What is weighted graph.
7. Define spanning tree.
8. List ways to represent a graph.
9. What are the applications of graph?
10. What is BFS and DFS.
11. Give uses of graphs in social networks.
12. Define MST?
1. Define graph. How to represent it? Explain with diagram.
2. What is topological sort. Explain with example.
3. What DFS? Describe in detail.
4. Give adjacency list representation of following graph:
4
2
1 3
5. Write short note on: Inverse adjacency list of graph.

6. Describe following algorithms with example:
(i) Dijkstra’s algorithm
(ii) Floyd Warshall.
3.54
7. With the help of diagram describe adjacency matrix representation of graph.

8. What is adjacency multi-list? How to represent it? Explain with example.
9. With the help of example describe BFS.
10. Describe the term MST with example.
11. Draw graph for following adjacency list:
1 2 3 NULL
2 1 3 NULL
3 2 3 NULL
12. Describe Prim’s algorithm in detail.

13. Explain Kruskal’s algorithm with example.
14. For the following graph, give result of depth first traversal and breadth first
traversal:
7
3
6
1 8
5
2
15. Give adjacency list representation of following graph.

A
B C

April 2016
1. Consider the following graph: [4 M]

V2
V1 V3 V5
V4 V6
3.55
(i) Write adjacency matrix

(ii) Draw adjacency list
(iii) DFS and BFS traversals (start vertex v1).
Ans. Refer to Sections 3.2.1, 3.2.2 and 3.3.
2. Define the following terms: [2 M]
(i) Degree of vertex
(ii) Topological sort.
Ans. Refer to Sections 3.1.2, Point (5) and 3.4.1.
April 2017
1. Which data structure is used for BFS. [1 M]

2. Define the term complete graph. [1 M]
October 2017
1. Consider the following adjacency matrix: [5 M]

1 2 3 4
1 0 1 0 0
0 
2
 0 1 0 
3 0 0 0 1 
4 1 0 0 0
(i) Draw the graph
(iii) Draw inverse adjacency list.
Ans. Refer to Section 3.2.1, 3.2.2 and 3.2.3.
2. Write an algorithm for BFS traversal of a graph. [3 M]
April 2018
1. List any methods of representing graphs. [1 M]

2. List two applications of graph. [1 M]
3.56

V4 V5
V1 V2 V3
V6 V7
Starting vertex v1
(i) Draw adjacency list
(ii) Give DFS and BFS traversals.
Ans. Refer to Sections 3.2.2 and 3.3.
October 2018
1. State any two applications of graph. [1 M]

2. Consider the following specification of a graph G:
V(G) = {1, 2, 3, 4}
E(G) = {(1, 2),(1, 3),(3, 3),(3, 4),(4, 1)}
(i) Draw a picture of the undirected graph.
(ii) Draw adjacency matrix of lists. [5 M]
Ans. Refer to Sections 3.2.1 and 3.2.2.
7
3
6
1 8
5
2

(ii) Give DFS and BFS (Source vertex v1). [3 M]
Ans. Refer to Sections 3.2.1 and 3.3.
4. Define the following terms: [2 M]
(i) Acrylic graph
(ii) Multigraph.
3.57
April 2019
V2
V5
V1 V3 V7
V6
V4

(iii) DFS and BFS traversals (start vertex v1).
Ans. Refer to Sections 3.2.1, 3.2.2 and 3.3.
2. Define the term topological sort. [1 M]

3.58
CHAPTER
4
Hash Table
Objectives …
To study Basic Concepts of Hashing
To learn Hash Table and Hash Function
To understand Terminologies in Hashing
To study Collision Resolution Techniques
4.0 INTRODUCTION
• Hashing is a data structure which is designed to use a special function called the hash
function which is used to map a given value with a particular key for faster access of
elements.
• Hashing is the process of mapping large amount of data item to smaller table with the
help of hashing function.
• The mapping between an item and the slot where that item belongs in the hash table
is called the hash function.
• The hash function will take any item in the collection and return an integer in the
range of slot names, between 0 and m−1.
• A hash table is a collection of items which are stored in such a way as to make it easy
to find them later.
Need for Hash Table Data Structure:
• In the linear search and binary search, the location of the item is determined by a
sequence/series of comparisons. The data item to be searched is compared with items
at certain locations in the list.
• If any item/element matches with the item to be searched, the search is successful.
The number of comparisons required to locate an item depends on the data structure
like array, linked list, sorted array, binary search tree, etc. and the search algorithm
used.
• For example, if the items are stored in sorted order in an array, binary search can be
applied which locates an item in O(log n) comparisons.
• On the other hand, if an item is to be searched in a linked list or an unsorted array,
linear search has to be applied which locates an item in O(n) comparisons.
4.1
Data Structures and Algorithms - II Hash Table
• However, for some applications, searching is very critical operation and they need a
search algorithm which performs search in constant time, i.e. O(1).
• Although, ideally it is almost impossible to achieve a performance of O(1), but still a
search algorithm can be derived which is independent of n and can give a
performance very close to O(1).
• That search algorithm is called hashing. Hashing uses a data structure called hash
table which is merely an array of fixed size and items in it are inserted using a
function called hash function.
• Best case timing behavior of searching using hashing = O(1) and Worst case timing
Behavior of searching using hashing = O(n).
• A hash table is a data structure in which the location of a data item is determined
directly as a function of the data item itself rather than by a sequence of comparisons.
• Under ideal condition, the time required to locate a data item in a hash table is O(1)
i.e. it is constant and does nor depend on the number of data items stored.
4.1 CONCEPT OF HASHING

• Hashing is the process of indexing and retrieving element (data) in a data structure to
provide a faster way of finding the element using a hash key.
• Here, the hash key is a value which provides the index value where the actual data is
likely to be stored in the data structure.
• In this data structure, we use a concept called hash table to store data. All the data
values are inserted into the hash table based on the hash key value.
• The hash key value is used to map the data with an index in the hash table. And the
hash key is generated for every data using a hash function.
• That means every entry in the hash table is based on the hash key value generated
using the hash function.
• Hash table is just an array which maps a key (data) into the data structure with the
help of hash function such that insertion, deletion and search operations are
performed.
• Generally, every hash table makes use of a function called hash function to map the
data into the hash table.
• Hash function is a function which takes a piece of data (i.e. key) as input and produces
an integer (i.e. hash value) as output which maps the data to a particular index in the
hash table.
• Basic concept of hashing and hash table is shown in the Fig. 4.1.
4.2
0 Key Actual data stored

Hash value
1
2
3
Key Hash
Hash value 4
function
5
Actual data to be store .
.
Fig. 4.1: Pictorial representation of Simple Hashing
4.2 TERMINOLOGY
• The basic terms used in hashing are explained below:
1. Hash Table: A hash table is a data structure that is used to store keys/value pairs.
Hashing uses a data structure called hash table which is merely an array of fixed
size and items in it are inserted using a hash function. It uses a hash function to
compute an index into an array in which an element will be inserted or searched.
A hash table is a data structure that maps keys to values. a hash table (hash map) is
a data structure that implements an associative array abstract data type, a
structure that can map keys to values. A hash table uses a hash function to
compute an index, also called a hash code, into an array of buckets or slots, from
which the desired value can be found.
2. Hash Function: A hash function is a function that maps the key to some slot in the
hash table. A hash function, is a mapping function which maps all the set of search
keys to the address where actual records are placed.
3. Bucket: A hash file stores data in bucket format. Bucket is considered a unit of
storage. A bucket typically stores one complete disk block, which in turn can store
one or more records.
4. Hash Address: A hash function is a function which when given a key, generates an
address in the table. Hash index is an address of the data block.
5. Collision: The situation where a newly inserted key maps to an already occupied
slot in the hash table is called collision. A collision occurs when two data elements
are hashed to the same value and try to occupy the same space in the hash table.
In simple words, the situation in which a key hashes to an index which is already
occupied by another key is called as collision.
6. Synonym: It is possible for different keys to hash to the same array location. This
situation is called collision and the colliding keys are called synonyms.
4.3
7. Overflow: An overflow occurs at the time of the bucket for a new pair (key,
element) is full.
8. Open Addressing: It is performed to ensure that all elements are stored directly
into the hash table, thus it attempts to resolve collisions implementing various
methods.
9. Linear Probing: It is performed to resolve collisions by placing the data into the
next open slot in the table.
10. Hashing: Hashing is a process that uses a hash function to get the key for the hash
table and transform it into an index that will point to different arrays of buckets,
which is where the information will be stored.
11. Chaining: It is a technique used for avoiding collisions in hash tables.
12. Collision Resolution: Collision should be resolved by finding some other location
to insert the new key, this process of finding another location is called as collision
resolution.
4.3 PROPERTIES OF GOOD HASH FUNCTION

• The properties of a good hash function are given below:
1. The hash function is easy to understand and simple to compute.
2. A number of collisions should be less while placing the data in the hash table.
3. The hash function should generate different hash values for the similar string.
4. The hash function "uniformly" distributes the data across the entire set of possible
hash values.
5. The hash function is a perfect hash function when it uses all the input data. A hash
function that maps each item into a unique slot is referred to as a perfect hash
function.
4.4 HASH FUNCTIONS

• A hash function h is simply a mathematical formula that manipulates the key in some
form to compute the index for the key in the hash table.
• The process of mapping keys to appropriate slots in a hash table is known as hashing.
Hash function is a function which is used to put the data in the hash table.
• Hence, one can use the same hash function to retrieve the data from the hash table.
Thus, hash function is used to implement the hash table.
• A hash function h is simply a mathematical formula that maps the key to some slot in
the hash table T.
• Thus, we can say that the key k hashes to slot h(k), or h(k) is the hash value of key k. If
the size of the hash table is N, then the index of the hash table ranges from 0 to N-1. A
hash table with N slots is denoted by T[N].
• Hashing (also known as hash addressing) is generally applied to a file F containing
R records. Each record contains many fields, out of these one particular field may
uniquely identify the records in the file.
4.4
• Such a field is known as primary key (denoted by k). The values k1, k2,… kn. in the key
field are known as keys or key values.
• The key through an algorithmic function determines the location of a particular
record.
The algorithmic function i.e. hashing function basically performs the key-to-address
transformation in which key is mapped to the addresses of records in the file as shown
in Fig. 4.2.
Key Address = Hash Function (Key) Address
Fig. 4.2: Hash Function
4.4.1 Division Method

• In division method, the key k is divided by the number of slots N in the hash table, and
the remainder obtained after division is used as an index in the hash table. That is, the
hash function is,
h(k) = k mod N
where, mod is the modulus operator. Different languages have different operators for
calculating the modulus. In C/C++, ‘%’ operator is used for computing the modulus.
• For example, consider a hash table with N=101. The hash value of the key value
132437 can be calculated as follows:
h(132437) = 132437 mod 101 = 26
• Note that above hash function works well if the index ranges from 0 to N−1 (like in
C/C++). However, if the index ranges from 1 to N, the function will be,
h(k) = k mod N + 1
• This technique works very well if N is either a prime number not too close to a power
of two. Moreover, since this technique requires only a single division operation, it is
quite fast.
• For examole, suppose, k = 23, N = 10 then
th
h(23) = 23 mod 10 + 1 = 3 + 1 = 4. The key whose value is 23 is placed in 4 location.
• Take another example, consider an example of hash table of size 20, and the following
items are to be stored. Item are in the (key, value) format.hash function is, h(k) = k
mod 20.
(1, 20)
(2, 70)
(42, 80)
(4, 25)
(12, 44)
(14, 32)
(17, 11)
(13, 78)
(37, 98)
4.5
• Hashing is a technique to convert a range of key values into a range of indexes of an

array.
Sr. No. Key Hash Array Index
1. 1 1 % 20 = 1 1
2. 2 2 % 20 = 2 2
3. 42 42 % 20 = 2 2
4. 4 4 % 20 = 4 4
5. 12 12 % 20 = 12 12
6. 14 14 % 20 = 14 14
7. 17 17 % 20 = 17 17
8. 13 13 % 20 = 13 13
9. 37 37 % 20 = 17 17
Basic Operations:
• Following are the basic primary operations of a hash table:
1. Search: Searches an element in a hash table.
2. Insert: inserts an element in a hash table.
3. Delete: Deletes an element from a hash table.
Program 4.1: Program for operations on hashing.
#include <stdio.h>
#include <string.h>
#include <stdlib.h>
#include <stdbool.h>
#define SIZE 20
struct DataItem
{
int data;
int key;
};
struct DataItem* hashArray[SIZE];
struct DataItem* dummyItem;
struct DataItem* item;
int hashCode(int key)
{
return key % SIZE;
}
4.6
struct DataItem *search(int key)

{
//get the hash
int hashIndex = hashCode(key);
//move in array until an empty
while(hashArray[hashIndex] != NULL)
{
if(hashArray[hashIndex]->key == key)
return hashArray[hashIndex];
//go to next cell
++hashIndex;
//wrap around the table
hashIndex %= SIZE;
}
return NULL;
}
void insert(int key,int data)
{
struct DataItem *item = (struct DataItem*) malloc(sizeof(struct DataItem));
item->data = data;
item->key = key;
//get the hash
//move in array until an empty or deleted cell
while(hashArray[hashIndex] != NULL && hashArray[hashIndex]->key != -1)
{
//go to next cell
++hashIndex;
hashIndex %= SIZE;
}
hashArray[hashIndex] = item;
}
struct DataItem* delete(struct DataItem* item)
{
int key = item->key;
//get the hash
//move in array until an empty
4.7
while(hashArray[hashIndex] != NULL)
{
if(hashArray[hashIndex]->key == key)
{
struct DataItem* temp = hashArray[hashIndex];
//assign a dummy item at deleted position
hashArray[hashIndex] = dummyItem;
return temp;
}
//go to next cell
++hashIndex;
hashIndex %= SIZE;
}
return NULL;
}
void display()
{
int i = 0;
for(i = 0; i<SIZE; i++)
{
if(hashArray[i] != NULL)
printf(" (%d,%d)",hashArray[i]->key,hashArray[i]->data);
else
printf(" ~~ ");
}
printf("\n");
}
int main()
{
dummyItem = (struct DataItem*) malloc(sizeof(struct DataItem));
dummyItem->data = -1;
dummyItem->key = -1;
insert(1, 20);
insert(2, 70);
insert(42, 80);
insert(4, 25);
insert(12, 44);
4.8
insert(14, 32);
insert(17, 11);
insert(13, 78);
insert(37, 97);
display();
item = search(37);
if(item != NULL)
{
printf("Element found: %d\n", item->data);
} else
{
printf("Element not found\n");
}
delete(item);
item = search(37);
if(item != NULL)
{
printf("Element found: %d\n", item->data);
} else
{
printf("Element not found\n");
}
}
Output:
$gcc -o hashpgm *.c
$hashpgm
~~ (1,20) (2,70) (42,80) (4,25) ~~ ~~ ~~ ~~ ~~ ~~ ~~ (12,44)
(13,78) (14,32) ~~ ~~ (17,11) (37,97) ~~
Element found: 97
Element not found
4.4.2 Mid Square Method

• In this method, we square the value of a key and take the number of digits required to
form an address, from the middle position of squared value.
• Suppose a key value is 16, then its square is 256. Now if we want address of two digits,
then we select the address as 56 (i.e., two digits starting from middle of 256).
• Mid square method operates in following two steps:
2
1. First, the square of the key k (that is, k ) is calculated and
2
2. Then some of the digits from left and right ends of k are removed.
4.9
• The number obtained after removing the digits is used as the hash value. Note that the
2
digits at the same position of k must be used for all keys.
• Thus, the hash function is given below,
h(k) = s
2
where, s is obtained by deleting digits from both sides of k .
• For example, consider a hash table with N = 1000. The hash value of the key value
132437 can be calculated as follows:
1. The square of the key value is calculated, which is, 17539558969.
th th th
2. The hash value is obtained by taking 5 , 6 and 7 digits counting from right,
which is, 955.
4.4.3 Folding Method

• The folding method also operates in two steps. In the first step, the key value k is
1 2 3 r
divided into number of parts, k , k , k , … , k , where each part has the same number of
digits except the last part, which can have lesser digits.
• In the second step, these parts are added together and the hash value is obtained by
ignoring the last carry, if any. For example, if the hash table has 1000 slots, each part
will have three digits, and the sum of these parts after ignoring the last carry will also
be three-digit number in the range of 0 to 999.
• For example, if the hash table has 100 slots, then each group will have two digits, and
the sum of the groups after ignoring the last carry will also be a 2-digit number
between 0 and 99. The hash value for the key value 132437 is computed as follows:
1. The key value is first broken down into a group of 2-digit numbers from the left
most digits. Therefore, the groups are 13, 24 and 37.
2. These groups are then added like 13 + 24 + 37 − 74. The sum 74 is now used the
hash value for the key value 132437.
• Similarly, the hash value of another key value, say 6217569, can be calculated as
follows:
1. The key value is first broken down into a group of 2-digit numbers from the left
most digits. Therefore, the groups are 62, 17, 56 and 9.
2. These groups are then added like 62 + 17 + 56 + 9 − 144. The sum 44 after ignoring
the last carry 1 is now used as the hash value for the key value 6217569.
4.5 COLLISION RESOLUTION TECHNIQUES

• Collision resolution is the main problem in hashing. The situation in which a key
hashes to an index which is already occupied by another key is called collision.
• Collision should be resolved by finding some other location to insert the new key. This
process of finding another location is called collision resolution.
4.10
• If the element to be inserted is mapped to the same location, where an element is

already inserted then we have a collision and it must be resolved.
• There are several strategies for collision resolution. The most commonly used are:
1. Separate Chaining: Used with open hashing.
2. Open Addressing: Used with closed hashing.
4.5.1 Open Addressing

• Open addressing or closed hashing is a method of collision resolution in hash tables.
With this method a hash collision is resolved by probing, or searching through
alternate locations in the array (the probe sequence) until either the target record is
found.
• In open addressing separate data structure is used because all the key values are
stored in the hash table itself. Since, each slot in the hash table contains the key value
rather than the address value, a bigger hash table is required in this case as compared
to separate chaining.
• Some value is used to indicate an empty slot. For example, if it is known that all the
keys are positive values, then −1 can be used to represent a free or empty slot.
• To insert a key value, first the slot in the hash table to which the key value hashes is
determined using any hash function. If the slot is free, the key value is inserted into
that slot.
• In case the slot is already occupied, then the subsequent slots, starting from the
occupied slot, are examined systematically in the forward direction, until an empty
slot is found. If no empty slot is found, then overflow condition occurs.
• In case of searching of a key value also, first the slot in the hash table to which the
key value hashes is determined using any hash function. Then the key value stored in
that slot is compared with the key value to be searched.
• If they match, the search operation is successful; otherwise alternative slots are
examined systematically in the forward direction to find the slot containing the
desired key value. If no such slot is found, then the search is unsuccessful.
• The process of examining the slots in the hash table to find the location of a key value
is known as probing. The linear probing, quadratic probing and double hashing that
are used in open addressing method.
4.5.1.1 Linear Probing

• Linear probing is a technique for resolving collisions in hash tables, data structures for
maintaining a collection of key–value pairs and looking up the value associated with a
given key.
• In linear probing whenever there is a collision, cells are searched sequentially (with
wraparound) for searching the hash-table free location.
4.11
• Let us suppose, if k is the index retrieved from the hash function. If the kth index is
already filled then we will look for (k+1) %M, then (k+2) %M and so on. When we get a
free slot, we will insert the object into that free slot.
• Below table shows the result of Inserting keys (5,18,55,78,35,15) using the hash
function h(k) = k % 10 and linear probing strategy.
Empty
After 5 After 18 After 55 After 78 After 35 After 15
Table
0 15
1
2
3
4
5 5 5 5 5 5 5
6 55 55 55 55
7 35 35
8 18 18 18 18 18
9 78 78 78
• Linear probing is easy to implement but it suffers from "primary clustering".
• When many keys are mapped to the same location (clustering), linear probing will not
distribute these keys evenly in the hash table. These keys will be stored in
neighborhood of the location where they are mapped. This will lead to clustering of
keys around the point of collision.
Example 1: Consider an example of hash table of size 20, and the following items are to be
stored. Item are in the (key, value) format. Here, we can search the next empty location in
the array by looking into the next cell until we find an empty cell. This technique is called
linear probing.
(1, 20)
(2, 70)
(42, 80)
(4, 25)
(12, 44)
(14, 32)
(17, 11)
(13, 78)
(37, 98)
4.12
Solution:
After Linear Probing,
Sr. No. Key Hash Array Index
Array Index
1. 1 1 % 20 = 1 1 1
2. 2 2 % 20 = 2 2 2
3. 42 42 % 20 = 2 2 3
4. 4 4 % 20 = 4 4 4
5. 12 12 % 20 = 12 12 12
6. 14 14 % 20 = 14 14 14
7. 17 17 % 20 = 17 17 17
8. 13 13 % 20 = 13 13 13
9. 37 37 % 20 = 17 17 18
Example 2: A hash table of length 10 uses open addressing with hash function h(k)=k mod
10, and linear probing. After inserting 6 values into an empty hash table, the table is as
shown below:
0
1
2 42
3 23
4 34
5 52
6 46
7 33
8
9
What is a possible order in which the key values could have been inserted in the table?
Solution: 46, 34, 42, 23, 52, 33 is the sequence in which the key values could have been
inserted in the table.
How many different insertion sequences of the key values using the same hash function
and linear probing will result in the hash table shown above?
Solution: 30
In a valid insertion sequence, the elements 42, 23 and 34 must appear before 52 and 33,
and 46 must appear before 33.
Total number of different sequences = 3! × 5 = 30
In the above expression, 3! is for elements 42, 23 and 34 as they can appear in any order,
and 5 is for element 46 as it can appear at 5 different places.
4.13
4.5.1.2 Quadratic Probing

• Quadratic probing is a collision resolving technique in open addressing hash table. It
operates by taking the original hash index and adding successive values of an
arbitrary quadratic polynomial until an open slot is found.
• One way of reducing "primary clustering" is to use quadratic probing to resolve
collision. In quadratic probing, we try to resolve the collision of the index of a hash
table by quadratically increasing the search index free location.
• Let us suppose, if k is the index retrieved from the hash function. If the kth index is
2 2
already filled then we will look for (k+1 ) %M, then (k+2 ) %M and so on. When we get
a free slot, we will insert the object into that free slot.
• It does not ensure that all cells in the table will be examined to find an empty cell.
Thus, it may be possible that key will not be inserted even if there is an empty cell in
the table.
Double Hashing:
• Double hashing is a collision resolving technique in open addressing hash table.
Double hashing uses the idea of using a second hash function to key when a collision
occurs.
• This method requires two hashing functions for f1(key) and f2 (key). Problem of
clustering can easily be handled through double hashing.
• Function f1 (key) is known as primary hash function. In case the address obtained by
f1 (key) is already occupied by a key, the function f2 (key) is evaluated.
• The second function f2 (key) is used to compute the increment to be added to the
address obtained by the first hash function f1 (key) in case of collision.
• The search for an empty location is made successively at the addresses
f1 (key) + f2 (key), f1 (key) + 2f2 (key), f1 (key) + 3f2(key), …
4.5.1.3 Rehashing
• As the name suggests, rehashing means hashing again. Rehashing is a technique in
which the table is resized, i.e. the size of table is doubled by creating a new table.
• Several deletion operations are intermixed with insertion operations while
performing operations on hash table. Eventually, a situation arises when the hash
table becomes almost full.
• At this time, it might happen that the insert, delete, and search operations on the hash
table take too much time. The insert operation even fails in spite of performing open
addressing with quadratic probing for collision resolution. This condition/situation
indicates that the current space allocated to the hash table is not sufficient to
accommodate all the keys.
4.14
• A simple solution to this problem is rehashing, in which all the keys in the original
hash table are rehashed to a new hash table of larger size.
• The default size of the new hash table is twice as that of the original hash table. Once
the new hash table is created, a new hash value is computed for each key in the
original hash table and the keys are inserted into the new hash table.
• After this, the memory allocated to the original hash table is freed. The performance of
the hash table improves significantly after rehashing.
0
Transferring 1
the contents 2
9
Old table
22
New table
Fig. 4.3: Rehashing
4.5.2 Chaining
• In hashing the chaining is one collision resolution technique. Chaining is a possible
way to resolve collisions. Each slot of the array contains a link to a singly-linked list
containing key-value pairs with the same hash.
• Chaining allows storing the key elements with the same hash value into linked list as
shown in Fig. 4.4.
• Thus, cach slots in the hash table contains a pointer to the head of the linked list of all
the elements that hashes to the value h.
• All collisions are chained in the lists attached to the appropriate slot. This allows an
unlimited number of collisions to be handled and does not require a prior knowledge
of how many elements are contained in the collection.
• The tradeoff is the same as with linked lists versus array implementations of
collections: linked list overhead in space and to a lesser extent, in time.
4.15
1
Head
2
122803 3
Hash Address = h(k)=4
Key%307 + 1 4 Uday Lodia 122803
151354
Key Value Next
Ashish Gang 151354

Key Value Next
Fig. 4.4: Chaining through Linked List
4.5.2.1 Coalesced Chaining

• Coalesced hashing also called coalesced chaining is a technique of collision resolution
in a hash table that forms a hybrid of separate chaining and open addressing.
• It uses the concept of open addressing (linear probing) to find first empty place for
colliding element from the bottom of the hash table and the concept of separate
chaining to link the colliding elements to each other through pointers.
• Given a sequence "qrj," "aty," "qur," "dim," "ofu," "gcl," "rhv," "clq," "ecd," "qsu" of
randomly generated three character long strings, the following table would be
generated with a table of size 10.
(null)
"clq"
"qur"
(null)
(null)
"dim"
"aty" "qsu"
"rhv"
"qrj" "ofu" "gel" "ecd"
(null)
(null)
• Fig. 4.5 shows an example of coalesced hashing example (for purpose of this example,
collision buckets are allocated increasing order, starting with bucket 0).
4.16
0 ofu
1 gcl
2 qur
3 clq
4 ecd
5 dim
6 aty
7 rhv
8 qrj
9 qsu
Fig. 4.5
• Coalesced hashing technique is effective, efficient, and very easy to implement.
4.5.2.2 Separate Chaining

• In separate chaining, hash table is an array of pointers and each element of array
points to the first element of the linked list of all the records that hashes to that
location.
• Open hashing is a collision avoidance method which uses array of linked list to
resolve the collision. It is also known as the separate chaining method (each linked list
is considered as a chain).
• In separate chaining collision resolution technique, a linked list of all the key values
that hash to the same hash value is maintained. Each node of the linked list contains a
key value and the pointer to the next node.
• Each index i (0 <= I < N) in the hash table contains the address of the first node of the
linked list containing all the keys that hash to the index i.
• If there is no key value that hashes to the index i, the slot contains NULL value.
Therefore, in this method, a slot in the hash table does not contain the actual key
values; rather it contains the address of the first node of the linked list containing the
elements that hash to this slot.
4.17
• In separate chaining technique, a separate list of all elements mapped to the same
value is maintained. Separate chaining is based on collision avoidance.
• If memory space is tight, separate chaining should be avoided. Additional memory
space for links is wasted in storing address of linked elements.
• Hashing function should ensure even distribution of elements among buckets;
otherwise the timing behavior of most operations on hash table will deteriorate.
• Fig. 4.6 shows a separate chaining hash table.
List of elements
0 10 50
2 12 32 62
4 4 24
7 7
9 9 69
Fig. 4.6: A separate Chaining Hash Table
Example 1: The integers given below are to be inserted in a hash table with 5 locations
using chaining to resolve collisions. Construct hash table and use simplest hash function.
1, 2, 3, 4, 5, 10, 21, 22, 33, 34, 15, 32, 31, 48, 49, 50,
Solution: An element can be mapped to a location in the hash table using the mapping
function h(k) = k % 10.
Hash Table Location Mapped Elements
0 5, 10, 15, 50
1 1, 21, 31
2 2, 22, 32
3 3, 33, 48
4 4, 34, 49
4.18
0 5 10 15 50
1 1 21 31
2 2 22 32
3 3 33 48
4 4 34 49
Fig. 4.7
Example 2: Consider the key values 20, 32, 41, 66, 72, 80, 105, 77, 56, 53 that need to be
hashed using the simple hash function h(k) = k mod 10. The keys 20 and 80 hash to index
0, key 41 hashes to index 1, keys 32 and 72 hashes to index 2, key 53 is hashed to index 3,
key 105 is hashed to index 5, keys 66 and 56 are hashed to index 6 and finally the key 77 is
hashed to index 7. The collision is handled using the separate chaining (also known as
synonyms chaining) technique as shown in Fig. 4.8.
0 80 20 NULL
1 41 NULL
2 72 32 NULL
3 53 NULL
4 NULL
5 105 NULL
6 56 66 NULL
7 77 NULL
8 NULL
9 NULL
Fig. 4.8: Collision Resoltuion by Separate Chaining
4.19
Comparison between Separate Chaining and Open Addressing:
Sr.
Separate Chaining Open Addressing
No.
1. Chaining is simpler to implement. Open addressing requires more
computation.
2. In chaining, hash table never fills up, In open addressing, table may become
we can always add more elements to full.
chain.
3. Chaining is less sensitive to the hash Open addressing requires extra care
function or load factors. for to avoid clustering and load factor.
4. Chaining is mostly used when it is Open addressing is used when the
unknown how many and how frequency and number of keys is
frequently keys may be inserted or known.
deleted.
5. Cache performance of chaining is not Open addressing provides better cache
good as keys are stored using linked performance as everything is stored in
list. the same table.
6. Wastage of space (some parts of hash In open addressing, a slot can be used
table in chaining are never used). even if an input does not map to it.
7. Chaining uses extra space for links. No links in open addressing.
PRACTICE QUESTIONS
1. Which data structure is designed to use a special function called the hash
function?
(a) Hashing (b) Stacking
(c) Queueing (d) None of these
2. Which is a data structure that represents data in the form of key-value pairs?
(a) Hash function (b) Hash table
(c) Hashing (d) None of these
3. Which is any function that can be used to map a data set of an arbitrary size to a
data set of a fixed size, which falls into the hash table?
(a) Hash function (b) Hash table
(c) Hash values (d) None of these
4.20
4. A good hash function has the following properties:

(a) Easy to compute: It should be easy to compute and must not become an
algorithm in itself.
(b) Uniform distribution: It should provide a uniform distribution across the
hash table and should not result in clustering.
(c) Less collisions: Collisions occur when pairs of elements are mapped to the
same hash value. These should be avoided.
(d) All of these
5. Which tables are used to perform insertion, deletion and search operations very
quickly in a data structure?
(a) Root (b) Hash
(c) Routing (d) Root
6. Which is in a hash file is unit of storage that can hold one or more records?
(a) Bucket (b) Hash values
(c) Token (d) None of these
7. A ______ occurs when two data elements are hashed to the same value and try to
occupy the same space in the hash table.
(a) Bucket (b) Underflow
(c) Collision (d) Token
8. In which method all the key values are stored in the hash table itself?
(a) Open addressing (b) Chaining
(c) Separate chaining (d) None of these
9. Which is a technique in all the keys in the original hash table are rehashed to a
new hash table of larger size?
(a) Chaining (b) Hashing
(c) Rehashing (d) None of these
10. In which hashing method, successive slots are searched using another hash
function?
(a) Linear probing (b) Quadratic probing
(c) Double (d) All of these
11. Name which methods are used by open addressing for hashing?
(a) Linear probing (b) Quadratic probing
(c) Double hashing (d) All of these
4.21
12. Hashing is implementing using,

(a) Hash table (b) Hash function
13. Hash table is a data structure that represents data in the form of,
(a) value-key pairs (b) key-value pairs
(c) key-key pairs (d) None of these
Answers
1. (d) 2. (c) 3. (b) 4. (a) 5. (c) 6. (d) 7. (c)
8. (a) 9. (c) 10. (b) 11. (d) 12. (a) 13. (b)

1. ______ is the process of mapping large amount of data item to a hash table with the
help of hash function.
2. The situation where a newly inserted key maps to an already occupied slot in the
hash table is called ______.
3. In rehashing the default size of the new table is ______ as that of the original hash
table.
4. The process of examining the slots in the hash table to find the location of a key
value is known as ______.
5. A ______ function is simply a mathematical formula that manipulates the key in
some form to compute the index for this kay in the hash table.
6. Hash ______ is an array of fixed size and items in it are inserted using a hash
function.
7. In ______ method the key is divided by number of slots in the hash table and the
remainder obtained after division is used as an index in the hash table.
8. In ______ hash table is an array of pointers and each element/item of array points
to the first element of the linked list of all the records that hashes to that location.
9. ______ allows storing the key elements with the same hash value into linked list.
10. ______ hashing is a combination of both Separate chaining and Open addressing.
Answers
1. Hashing 2. collision 3. twice 4. probing 5. hash
6. table 7. division 8. Separate 9. Chaining 10. Coalesced
chaining
4.22

1. The process of mapping kays to appropriate slots in a hash table is known as
hashing.
2. In mid-square method we first square the item, and then extract some portion of
the resulting digits.
3. The hash table is depending upon the remainder of division.
4. In open addressing, all elements are stored in the hash table itself.
5. The idea of separate chaining is to make each cell of hash table point to a linked
list of records that have same hash function value.
6. open addressing is a method for handling collisions.
7. In linear probing, we linearly probe for next slot.
8. Double hashing uses the idea of applying a second hash function to key when a
collision occurs.
9. A hash function is a data structure that maps keys to values.
10. Quadratic probing operates by taking the original hash index and adding
successive values of an arbitrary quadratic polynomial until an open slot is found.
11. Coalesced hashing is a collision avoidance technique when there is a fixed sized
data.
Answers
1. (T) 2. (T) 3. (F) 4. (T) 5. (T) 6. (T) 7. (T) 8. (T) 9. (F) 10. (T) 11. (T)

1. What is hashing?
2. What is hash function?
3. Define bucket.
4. List steps for mid square method.
5. What is collision?
6. List techniques for collision resolution.
7. Define rehashing?
8. What is linear probing?
9. Define quadratic probing.
10. Define separate chaining?
1. Define hashing. State need for hashing. Also list advantages of hashing.
2. What is chaining? Explain with diagram.
3. With the help of example describe separate chaining?
4.23
4. Describe quadratic probing with example.

5. With the help of diagram describe concept of hashing.
6. What is hash table? Explain in detail.
7. Write a short note on: Linear probing.
8. Compare separate chaining and open addressing?
9. What is rehashing? Describe with diagrammatically.
10. Differentiate between hashing and rehashing?
11. With the help of diagram describe hash function.
12. Describe coalesced chaining with example.
4.24

Data Structures and Algorithms-II

Uploaded by

Copyright:

Available Formats

You might also like

Data Structures and Algorithms-II

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Data Structures and Algorithms-II

Uploaded by

Copyright:

Available Formats

A Book Of

Dr. Ms. Manisha Bharambe

Published By : Polyplate Printed By :

1. Tree 1.1 – 1.64

2. Efficient Search Trees 2.1 – 2.40

3. Graph 3.1 – 3.58

4. Hash Table 4.1 – 4.24

My computer Game Network neighbourhood

C:\ D:\ H:\

• Common uses for tree data structure are given below:

1.1 BASIC CONCEPTS AND TERMINOLOGY

Child node D Leaf

Fig. 1.2: Structure of Tree

1.1.2 Operations on Trees

1.2 BINARY TREE AND TYPES OF BINARY TREE

1.2.1 Binary Tree

Fig. 1.4: Binary Tree

1.2.2 Skewed Binary Tree [April 17, 19]

(a) Left Skewed Binary

1.2.3 Strictly Binary Tree

Fig. 1.6: Strictly Binary Tree of Height 3

1.2.4 Full Binary Tree

Fig. 1.7: Full Binary Tree

1.2.5 Complete Binary Tree [Oct. 18]

• Fig. 1.8 shows is a complete binary tree.

Fig. 1.8: Complete Binary Tree

1.2.6 Expression Tree

1.2.7 Binary Search Tree

Fig. 1.10: Binary Search Tree

(a) Min Heap (b) Max Heap

1.3 REPRESENTATION OF TREE (STATIC AND DYNAMIC)

Hence, node B is at position 2 in the array.

1.3.2 Dynamic Representation of Tree (Using Linked List)

Lchild Data Rchild Lchild Rchild

Fig. 1.17: Fields of a Node of a Binary Tree in Linked Representation

NULL H NULL NULL I NULL NULL J NULL

NULL D NULL NULL E NULL NULL F NULL 66 G 74

NULL H NULL NULL I NULL

NULL D NULL NULL E NULL NULL F NULL 66 G 74

NULL H NULL NULL I NULL

printf("In-order Traversal: \n");

D NULL NULL E NULL NULL F NULL

Fig. 1.20: Insertion of Node G

NULL D NULL NULL E NULL

BINARY SEARCH TREE (BST) IMPLEMENTATION AND

• Fig. 1.22 shows examples of binary search trees.

25 35 45 52 Aug Feb Jun Nov

Fig. 1.22: Binary Search Trees

1.4.1 Operations on Binary Search Tree

C Function for Creating BST:

Key = 15 Key < 15 Key = 13

Key = 8 Key = 9 Key = 17

struct node *create(struct node *, int);

1.4.1.2 Searching in a BST [April 17]

Aug Feb Jun Nov

Fig. 1.23: Binary Search Tree

Procedure: Search − BST (Key)

Heena Deepa Deepa Teena

struct node create(struct node , int);
