Rotator Cuff Repair: Fulfilling The Need For Precision and Speed

Rotator Cuff Repair
Fulfilling the Need for Precision and Speed
SpeedFix™
SpeedFix™
Rip-Stop
SpeedBridge™
DX Reinforcement
Matrix
Table of Contents
Fully Threaded Corkscrew® Suture Anchors�� 04
Knotless SwiveLock® Anchors and FiberTape®�� 06
SpeedFix™ Knotless Single Row Rotator Cuff Repair�� 07
SpeedBridge™�� 09
BioComposite Vented SwiveLock® With FiberTape® Loop�� 10
Scorpion™: Simple, Precise, ��
and Fast to Meet the Most Stringent Requirements�� 12
The Ultimate Suture Passer. Grasp, Pass and Retrieve�� 13
Accessory Instruments�� 14
Table of Contents I 03
Fully Threaded Corkscrew® Suture Anchors
BioComposite Corkscrew® FT, PEEK Corkscrew® FT, Corkscrew® FT
The fully threaded Corkscrew family of suture anchors

was designed for maximum fixation strength and simple
insertion. An internal drive mechanism is combined with
a unique FiberWire suture eyelet to allow for contin-
uous threads along the entire length of the anchor.
This design allows the anchor to be inserted flush with
the cortical bone surface providing excellent fixation
strength and stability while preventing the anchor
“pull-back” effect that can occur in conventional
anchors with protruding eyelets. The internal drive
configuration allows for high insertion torque and the
suture eyelet self-aligns to eliminate the need for spe-
cific eyelet orientation at the tissue edge. The anchors
are double-loaded with FiberWire suture to provide the
best possible combination for superior repair strength.
BioComposite Corkscrew® FT PEEK Corkscrew® FT Corkscrew® FT
The BioComposite Corkscrew FT The PEEK Corkscrew FT is made The Corkscrew FT family is made
features a strong internal square from polyetheretherketone, which of titanium. The 5.5 mm Corkscrew
drive mechanism that maximizes is a non-absorbable, thermoplastic FT II features the unique FiberWire
torque, while minimizing the material with excellent biocompati- eyelet to minimize suture abrasion
potential for stripping during bility and biostability characteristics. and maximize suture sliding during
insertion into hard cortical bone. The anchor is radiolucent and will knot tying. The 4.5 mm Corkscrew
This bioabsorbable suture anchor not cause an artifact on imaging FT II and 6.5 mm Corkscrew FT III
is composed of 15 % beta tricalcium studies. A punch is required to feature a metal crosspin eyelet. All
phosphate and 85 % PLLA. Studies prepare a bone socket for anchor have a strong internal hex drive
suggest that early bone formation insertion. mechanism. The anchor is inserted
can be connected to the favorable Combination punch / taps are avail- without the need for bone socket
osteoconductive and bioresorbable able for use in extremely hard bone. preparation. A mallet is used to
properties within β-TCP. introduce the anchor tip, then the
anchor is screwed in until flush.
Associated Literature:
New Materials in Sports LA0200
Medicine (PEEK)
04 I Fully Threaded Corkscrew Suture Anchors

BioComposite, PEEK, Titanium
Spade tip drill, for AR-1927D

BioComposite PEEK
5.5 mm Corkscrew FT
SwiveLock®
4.5 mm PEEK Corkscrew FT AR-1927PSF-45
suture anchor,
4.5 mm 4.75 mm 6.5 mm × 16 mm,
with two # 2 FiberWire®
5.5 mm 5.5 mm
6.5 mm 6.5 mm
Titanium
Product Description Item Number Product Description Item Number
BioComposite Corkscrew® AR-1927BCF-45 PEEK Corkscrew® FT AR-1927PSF-45

FT suture anchor, suture anchor,
4.5 mm × 15 mm, 4.5 mm × 15 mm,
4.5 mm
with two # 2 FiberWire® with two # 2 FiberWire®
Tap / punch AR-1927PTB-45 PEEK Corkscrew® FT AR-1927PNF-45 5.5 mm
for 4.5 mm Corkscrew® FT suture anchor with
Punch for 4.5 mm AR-1922P needles 4.5 mm × 15 mm, 6.5 mm
PushLock® and 4.5 mm with two # 2 FiberWire®
Corkscrew® FT Tap / punch, for 4.5 mm AR-1927PTB-45
Product Description Item Number
Disposable punch for AR-1922PBS Corkscrew® FT
4.5 mm PushLock® and Punch, for 4.5 mm AR-1922P Corkscrew® FT suture AR-1928SF-45
4.5 mm Corkscrew® FT PushLock® and 4.5 mm anchor, 4.5 mm × 15 mm,
Corkscrew® FT with two # 2 FiberWire®
BioComposite Corkscrew® AR-1927BCF
FT suture anchor, Disposable punch, for AR-1922PBS Corkscrew® FT II suture AR-1928SF-2
5.5 mm × 15 mm, 4.5 mm PushLock® and anchor, 5.5 mm × 16 mm,
with two # 2 FiberWire® 4.5 mm Corkscrew® FT with two # 2 FiberWire®
BioComposite Corkscrew® AR-1927BCFT PEEK CorkScrew® FT, AR-1927PST-475 Corkscrew® FT II suture AR-1928SNF-2
FT suture anchor, suture anchor double anchor, with needles,
5.5 mm × 15 mm, with two loaded, 4.75 mm, VE5 5.5 mm × 16 mm,
# 2 TigerTail® with two # 2 FiberWire®
PEEK CorkScrew® FT, AR-1927PSF-475
BioComposite Corkscrew® AR-1927BCF-3 suture anchor, tripleplay, Corkscrew® FT II suture AR-1928SFT-2
FT suture anchor, 4.75 mm, VE5 anchor, 5.5 mm × 16 mm,
5.5 mm × 15 mm, with two # 2 TigerTail
Punch / tap, for 4.75 mm AR-1927PTB-475
with three # 2 FiberWire® CorkScrew® FT Corkscrew® FT III suture AR-1928SF-3
BioComposite Corkscrew® AR-1927BCNF anchor, 5.5 mm × 16 mm,
PEEK Corkscrew® FT AR-1927PSF with three # 2 FiberWire®
FT suture anchor suture anchor,
with needles, 5.5 mm × 15 mm, Corkscrew® FT III suture AR-1928SF-3
5.5 mm × 15 mm, with two # 2 FiberWire® anchor, 6.5 mm × 16 mm,
with two # 2 FiberWire® with three # 2 FiberWire®
PEEK Corkscrew® FT AR-1927PSF-3
Punch, for 5.5 mm AR-1927PB suture anchor,
Corkscrew® FT 5.5 mm × 15 mm,
and SwiveLock® with three # 2 FiberWire®
Disposable punch, for AR-1927PBS Punch, for 5.5 mm AR-1927PB
5.5 mm Corkscrew® FT Corkscrew® FT
and SwiveLock® and 4.75 mm SwiveLock®
Tap / punch, for 5.5 mm AR-1927CTB Disposable punch, for AR-1927PBS
Corkscrew® FT and 5.5 mm Corkscrew® FT
5.5 mm SwiveLock® and SwiveLock®
Spade tip drill, for 5.5 mm AR-1927D Tap / punch, for 5.5 mm AR-1927CTB
Corkscrew® FT and Corkscrew® FT and
SwiveLock® 5.5 mm SwiveLock®
BioComposite Corkscrew® AR-1927BCF-65
FT, 6.5 mm × 15 mm,
with two # 2 FiberWire®
Fully Threaded Corkscrew Suture Anchors I 05
Knotless SwiveLock® Anchors and FiberTape®
Result: Very Flat Design With Very High Stability
Knotless SwiveLock® Anchors and FiberTape®
(c)
SpeedFix™ (b)
SpeedBridge™ (a)
SwiveLock® C (a)
■■Our maximum fixation strength
■■Vented: May allow bony ingrowth*
■■Combines with many variations of FiberTape and

FiberWire for extreme flexibility
SwiveLock® SP (b)
■■Self-punching design eliminates the need for a bone

socket preparation step
SwiveLock is preloaded with a # 2 FiberWire eyelet-
retention suture that can either be incorporated into the ■■Facilitates repair visualization prior to insertion
repair for additional fixation options or discarded.
■■BioComposite, PEEK and titanium material options
FiberTape® (c)
■■Allow 2 mm wide FiberTape or TigerTape sutures
■■2 mm wide FiberTape or TigerTape options provide

Cannulation
broad compression and increased tissue cut-through
with bony
resistance
ingrowth
■■# 2 FiberWire tails can be passed with a Scorpion
Vent
* Cross section of a vented BioComposite SwiveLock

8 weeks after implantation in a canine model showing
bony ingrowth in the vents and center cannulation.
* Data on file
06 I Knotless SwiveLock Anchors and FiberTape

SpeedFix™ Knotless Single Row Rotator Cuff Repair
SpeedFix™
Quick and secure single-row fixation can be obtained

with the SpeedFix. The SpeedFix takes advantage of
the PassPort Button cannula and the SCORPION-
multifire suture passer. The SCORPION-multifire suture
passer is used to pass an inverted mattress stitch in
1 step. The flexible PassPort cannulas help maximize
visibility and maneuverability inside and outside of
the arthroscopic work space. The double-dam 1-piece
molded design has low profile flanges that seat flush to
the skin and soft tissue. These flanges create a
stable portal that allows instruments to be inserted
and removed, without the concern of cannula loss.
1 2 3
Load both tails of the FiberTape into Retrieve both FiberTape tails Insert the SwiveLock into the pre-
the SCORPION-multifire and pass through the lateral portal and prepared bone socket until the anchor
mattress stitch in one step. load them through the SwiveLock body makes contact with bone.
eyelet. Prepare a bone socket using Adjust tension if necessary. Hold
a punch. the thumb pad steady and rotate
the driver handle in a clockwise
direction until the anchor body is
flush with bone. Cut the FiberTape
tails with a FiberTape cutter.
Optional: Rip-Stop SpeedFix™
The additional rip-stop with FiberLink increases the

pull-out strength of the reattachment.
SpeedFix™ Knotless Single Row Rotator Cuff Repair I 07

SwiveLock® C SwiveLock® SP FiberTape®
Product Description Item Number Product Description Item Number Product Description Item Number
BioComposite SwiveLock® C, AR-2324BCC Self-punching, AR-2324BCM FiberTape, blue, 2 mm, AR-7237-7

4.75 mm × 19.1 mm BioComposite SwiveLock® 18 cm, each end tapered to
BioComposite SwiveLock® C, AR-2323BCC SP, 4.75 mm × 24.5 mm # 2 FiberWire®, 76 cm
5.5 mm × 19.1 mm Self-punching, AR-2323BCM TigerTape™, black / white, AR-7237-7T
PEEK SwiveLock® C, AR-2324PSLC BioComposite SwiveLock® 2 mm, 18 cm, each end
4.75 mm × 19.1 mm SP, 5.5 mm × 24.5 mm tapered to # 2 TigerWire®,
Self-punching, PEEK AR-2324PSLM 76 cm
PEEK SwiveLock® C, AR-2323PSLC
5.5 mm × 19.1 mm SwiveLock® SP, FiberLink™, # 2 FiberWire®, AR-7235
4.75 mm × 24.5 mm blue, with loop
Punch, for 5.5 mm AR-1927PB Self-punching, PEEK AR-2323PSLM
Corkscrew FT, 4.75 mm and SwiveLock® SP,
5.5 mm SwiveLock® 5.5 mm × 24.5 mm
Tap / punch, for 5.5 mm AR-1927CTB SwiveLock SP, titanium, AR-2324SLM
Corkscrew FT and 5.5 mm 4.75 mm × 24.5 mm
SwiveLock®
Tap / punch, for 4.75 mm AR-2324PTB
SwiveLock® and
SwiveLock® C
The Science Behind the Technology...
Single Knotless Anchor Pull-Out Strength

Straight axial pull-out in laminated foam block (10 pcf cancellous core with a 2 mm thick 20 pcf cortical shell)*
80
Pull-Out Strength (lbf)
70
60 71.2
50
56.9
40
30
20
34.1
30.6
27.5
10 19.3
0
14.4
5.5 mm 4.75 mm Mitek Versalok Arthrocare Arthrocare Smith&Nephew 4.5 mm Linvatec

Bio-SwiveLock C Bio-SwiveLock C SpeedScrew Opus Magnum Footprint PK PopLok
with FiberTape with FiberTape
* Data on file
08 I Knotless SwiveLock Anchors and FiberTape

SpeedBridge™
Knotless Double Row
Knotless Double Row
The fully threaded SwiveLock can be combined with

FiberTape to create a quick and secure SutureBridge
construct with no knots and only 2 suture passing steps.
The result is a low profile, transosseous equivalent
suture bridge that enhances footprint compression to
maximize contact between tendon and bone.
1 2 3
Insert the SwiveLock preloaded Pass the tail of a FiberLink, for use Load both tails of the FiberTape
with 1 strand of FiberTape into a as a suture shuttle, through the through the FiberLink loop. Pull on
prepared medial bone socket. rotator cuff with a Scorpion. Retrieve the FiberLink tail, through the ante-
the FiberLink tail through the rior portal, to shuttle the FiberTape
anterior portal. through a single hole in the rotator
cuff.
4 5
Retrieve 1 FiberTape tail from each Hold the SwiveLock thumb pad
medial anchor and preload them steady and rotate the driver in a
through the SwiveLock eyelet. clockwise direction to insert the
Insert into a prepared lateral bone anchor body until it is flush with the
socket until the anchor body bone. Cut the FiberTape tails with
contacts bone. Adjust tension if a FiberTape cutter. Repeat steps 4
necessary. and 5 for the second lateral anchor.
SpeedBridge I 09
BioComposite Vented SwiveLock®
With FiberTape® Loop
BioComposite Vented SwiveLock®
The 4.75 mm BioComposite vented SwiveLock is now

available with a preloaded FiberTape loop that allows
easy FiberTape passage for the medial row of a Speed-
Bridge. The 2 limbs of the FiberTape are joined into a
single tail that can be easily passed with a Scorpion
suture passer, eliminating the need for more complex
suture shuttling techniques.
BioComposite SwiveLock® C, 4.75 mm × 19.1 mm, AR-2324BCCT

FiberTape® loop, blue
BioComposite SwiveLock® C, 4.75 mm × 19.1 mm, AR-2324BCCTT
TigerTape™ loop, white / black
1 2 3
Insert medial anchor normally and Load the single tail directly onto a The tail smoothly leads both
retrieve both FiberTape limbs at Scorpion and pass through the cuff FiberTape limbs through the tissue.
the same time with a FiberTape without the need for a FiberLink The spliced tail is cut off, allowing
retriever. suture shuttling step. each FiberTape limb to be sepa-
rated for normal lateral fixation.
SpeedBridge™ Implant System
SpeedBridge™ implant system, with BioComposite AR-2600SBS-4

SwiveLock® C
SpeedBridge™ implant system, with BioComposite AR-2600SBS-5
SwiveLock® SP
SpeedBridge™ implant system, with PEEK AR-2600SBS-6
SwiveLock® Anchors
SpeedBridge™ implant system, with PEEK AR-2600SBS-7
The SpeedBridge implant system provides all implants SwiveLock® SP
and sutures required to complete a SpeedBridge rotator SpeedBridge™ implant system, with AR-2600SBS-8
cuff repair in a single sterile tray that maximizes SCORPION-multifire needle, 4.75 × 19.1 mm
OR convenience and efficiency. The kits feature the SpeedBridge™ implant system, with AR-2600SBS-9
BioComposite vented SwiveLocks with FiberTape loops SCORPION-multifire needle, 4.75/5.5 × 19.1 mm
for use in the medial row.
10 I BioComposite Vented SwiveLock With FiberTape Loop

The Science Behind the Technology...
Cadaveric testing shows that the knotless SpeedBridge

Pull-Out Strength (lbf)
600
is equivalent to the standard SutureBridge in both
500
strength and gap formation.
400
300
Six matched pairs were used to compare the
200 SpeedBridge to the standard SutureBridge. The
100 constructs were cycled 500 times between 10 and 100
0 N and then pulled to failure. Both constructs were only
SpeedBridge Standard
limited by tendon quality. No anchors or sutures failed.
* Data on file
SutureBridge
FiberTape has 200 % more footprint area than The force required to pull FiberTape through tendon
# 2 FiberWire. tissue is significantly greater than that of # 2 FiberWire.
FiberTape # 2 FiberWire
200
189 N
100
149 N
0
FiberTape # 2 FiberWire
Pressure sensitive film study. Simple stitches pulled through cadaver tendons.
* Data on file * Data on file
SpeedBridge™ RCR Supported by DX Reinforcement Matrix Augmentation
The SpeedBridge rotator cuff reconstruction can be

combined with the decellularized porcine xenograft
(DX) reinforcement matrix for a strong augmentation of
the repair. This biomechanically strong, biocompatible
scaffold was developed for the reinforcement and repair
of soft tissues. It can be shuttled over the medial row
FiberTapes to the repair site to complete and reinforce
the repair.
■■OPTRIX processing method, without the need for

crosslinking
■■Sterile scaffold for immediate implantation without the
need for lengthy rehydration times
■■Biomechanically strong for suture retention
■■Provided in 2 sizes in a hydrated state for room

Associated Literature: temperature storage
SpeedBridge™ and LT2-0219-EN

■■Preservation of the native matrix structure and
SpeedFix™ Knotless support of the cell migration (Hackett ES, Harilal DO,
Rotator Cuff Repair Using Evaluation of porcine hydrated dermis augmented
the SwiveLock® C and repair in a fascial defect model, JMBR Part B: Applied
FiberTape® Biomaterials, 2011; 96(1): 134-8.)
BioComposite Vented SwiveLock With FiberTape Loop I 11

Scorpion™: Simple, Precise, and Fast to Meet the
Most Stringent Requirements
FastPass Scorpion™ SL
■■New, solid design of lower jaw prevents placed

sutures from being picked up again
■■Multi-functional instrument for grasping tissue as well
as passing and retrieving sutures
■■Sutures loaded in just 1 step
■■Flat jaws which fit down a 6 mm cannula and can

grasp up to 16 mm of tissue
■■Intended for use with the SCORPION-multifire needle
FastPass Scorpion™ SL AR-13999MFF

SCORPION-multifire needle AR-13995N
1 2 3
Load 3 - 5 cm of # 2 FiberWire into Introduce the Scorpion suture Detach the Scorpion suture passer
the lateral slot on the lower jaw and passer through the lateral portal from the tissue and retrieve it
pull right to the end of the slot. and actuate the handle to push the through the lateral portal together
needle through the tissue. with the FiberWire suture.
Releasing the handle retracts the
needle into the instrument while the
suture remains in the upper jaw.
12 I Scorpion: Simple, Precise, and Fast to Meet the Most Stringent Requirements
The Ultimate Suture Passer.
Grasp, Pass and Retrieve
FastPass Scorpion™
■■Multi-functional instrument grasps tissue, passes and

retrieves FiberWire
■■Ideal for all arthroscopic or mini-open passes of
# 2 FiberWire through soft tissue
■■Simplistic and ergonomic design allows for
one-handed operation
■■Low profile design fits down a 6 mm cannula
■■Ratcheting jaw design grasps up to 16 mm of tissue
■■Available in both single pass and SCORPION-multifire

versions
■■SCORPION-multifire version passes and retrieves
1 or 2 strands of # 2 FiberWire
FastPass SCORPION-multifire PassPort Button™ Cannula
Product Description Item Number Optimal view and maneuverability within and outside of
FastPass SCORPION-multifire AR-13997MFF the arthroscopic work space.
SCORPION-multifire needle AR-13995N
■■Low profile dual flange design seats flush to the skin
and soft tissue
■■Double dam, 1 piece molded silicone design in
6, 8, 10 mm IDs and 20 - 50 mm lengths
■■Indications in the shoulder, knee, hip and elbow
■■Sizes: AR-6592-xx-yy,
xx = ID: 6, 8, 10 mm, yy = Length: 20, 30, 40, 50 mm
The Ultimate Suture Passer. Grasp, Pass and Retrieve I 13

Accessory Instruments
Scorpion™ FiberWire® Grasper
(a)
(b)
The Scorpion suture passer adds simplicity to suture New, fully toothed grasper for problem-free retrieval of
passing in rotator cuff repair. Ergonomically designed multiple strands of FiberWire.
for one-hand use, the multi-function Scorpion grasps
cuff tissue, then directly passes and retrieves a Product Description Item Number
FiberWire. The low profile standard Scorpion grasps FiberWire® grasper AR-13975SRF
16 mm of tissue and fits through a 5.75 mm cannula.
A “humpback” version with locking jaws is available for
use in thicker rotator cuff tissue. The humpback requires
a 7 mm cannula. All Scorpions use the same disposable
needle which withstands multiple suture passes during
a single case. The FastPass Scorpion will pass and
retrieve FiberWire all in one step.
Scorpion™ suture passer, 16 mm (a) AR-13990F

SCORPION-multifire, humpback, 16 mm AR-13995F
Scorpion™ suture passer, humpback, 16 mm (b) AR-13993F
SCORPION-multifire, straight, 16 mm AR-13996F
Scorpion™ needle AR-13990N
SureFire® Scorpion™ needle AR-13991N
FastPass SCORPION-multifire, with FlushPort AR-13997MFF
FastPass Scorpion™ SL-MF, with FlushPort AR-13999MFF
14 I Accessory Instruments
Penetrator™ Suture Retriever FiberWire® Suture Cutters
(a)
(b)
This unique instrument combines a small penetrating The suture cutters were designed to facilitate
tip with a suture grasper to allow suture delivery and arthroscopic cutting of FiberWire and braided sutures.
retrieval in one step. The tip is 2.7 mm in diameter and The uniquely designed cutting jaws remain sharp even
slides easily through the tissue with the suture either after repeated use. The suture cutters are available in
sliding or grasped within the self-ratcheting mechanism. versions with a closed tip and with an open tip and left
A special version with broad jaws is available for simple notch.
handling of FiberTape.
The closed tip suture cutter prevents cutting of the knot
Product Description Item Number by preserving a 3-mm-long suture tail. The open tip
Penetrator™ suture retriever, 15˚ up curved (a) AR-2167-2F and left notch version allows you to cut sutures flush to
Penetrator™ suture retriever, straight AR-2167ST-2F
the bone in the joint without needing to introduce the
suture cutter over the suture.
Penetrator™ FiberTape® retriever, 15˚ up curved AR-2167-3F
Penetrator™ FiberTape® retriever, straight AR-2167ST-3F
Suture cutter, open ended left, 4.2 mm AR-11794LF

Suture cutter, straight, 4.2 mm AR-12250F
Accessory Instruments I 15
KingFisher® FiberTape® Cutter FiberTape® Suture Retriever
The KingFisher is the optimal instru- The FiberTape cutter allows simple, This instrument was developed to
ment for grasping and repositioning simultaneous cutting of 2 facilitate the handling of FiberTape.
of tissue, removing foreign bodies FiberTapes without extending The broad device on the upper jaw
and retrieving sutures / suture suture tails. makes it possible to pass the
management during arthroscopic FiberTape and retrieve it without
procedures. The user-friendly, Product Description Item Number any problems. The tip can also be
self-releasing jaw lock facilitates FiberTape® cutter AR-13250F used as a grasper.
clamping of the tissue. The flat jaws
of the KingFisher simplify work in Product Description Item Number
confined spaces. FiberTape® retriever, with AR-13974SRF
With its shaft diameter of just SR handle
4.2 mm, the KingFisher can be FiberTape® retriever, with AR-13974NRF
introduced down a narrow 5.75 mm NR handle
Crystal Cannula.
KingFisher® suture AR-13970SRF

retriever / tissue grasper,
with SR handle
FiberTape® KingFisher®, AR-13971NRF
NR handle, with FlushPort
FiberTape® KingFisher®, AR-13971SRF
SR handle, with FlushPort
QuickPass™ SutureLasso™ SutureLasso™ SD
The QuickPass family of lassos uses thumbwheels and The small diameter SutureLassos have an outer diam-
an ergonomic handle to quickly and easily advance the eter of 1.8 mm and feature a thumb pad for one-hand
supplied nitinol wire loop, a # 2 FiberStick or a monofil- wire advancement. These are available in various tip
ament (PDS) suture. Sterile, single-patient use assures a configurations.
sharp instrument every time. All current SutureLasso SD
tip configurations are available for arthroscopic labral Product Description Item Number
and rotator cuff repairs. Tip dimensions and color-cod- SutureLasso™ SD, 30˚ straight AR-4068-30
ing match the SutureLasso SD family. The tip diameter SutureLasso™ SD, 90˚ up AR-4068-90
is a small 1.8 mm and is combined with a stiffer 3.8 mm
SutureLasso™ SD, 25˚ tight curve left AR-4068-25TL
shaft to provide the perfect combination of atraumatic
SutureLasso™ SD, 25˚ tight curve right AR-4068-25TR
suture passage with a robust and ergonomic handle.
SutureLasso™ SD, 45˚ curve left AR-4068-45L
SutureLasso™ SD, 45˚ curve right AR-4068-45R
SutureLasso™ SD, 90˚ curve left AR-4068-90L
QuickPass™, 30˚ straight AR-6068-30
SutureLasso™ SD, 90˚ curve right AR-4068-90R
QuickPass™, 90˚ straight AR-6068-90
SutureLasso™ SD, crescent AR-4068C
QuickPass™, 25˚ tight curve left AR-6068-25TL
SutureLasso™ SD, with FiberStick™, 25˚ tight curve left AR-4068-25TLF
QuickPass™, 25˚ tight curve right AR-6068-25TR
SutureLasso™ SD, with FiberStick™, 25˚ tight curve right AR-4068-25TRF
QuickPass™, 45˚ curve left AR-6068-45L
SutureLasso™ SD wire loop AR-4068-05SD
QuickPass™, 45˚ curve right AR-6068-45R
QuickPass™, 90˚ curve left AR-6068-90L
QuickPass™, 90˚ curve right AR-6068-90R
QuickPass™, 90˚ tight curve AR-6068-90T
QuickPass™, crescent AR-6068C
QuickPass™ wire loop AR-6068-01
ReelPass SutureLasso™ BirdBeak®
(a)
(b)
The ReelPass SutureLasso contains 9 meters of blue

(c)
# 1 non-absorbable monofilament to provide the user
a continuous supply without the need to reload. The
ergonomic handle and thumbwheels were designed to
easily advance the monofilament. The 1.5 mm tip diame-
ter is the smallest on the market and is always sharp on
The BirdBeak has an extremely sharp tip to penetrate
this single use device.
soft tissue easily and a stiff shaft that resists bending
during tissue shifting procedures.
ReelPass SutureLasso™, 90° straight AR-6069-90 Product Description Item Number

ReelPass SutureLasso™, 45° curve left AR-6069-45L
BirdBeak®, 45˚ up tip (a) AR-11800F
ReelPass SutureLasso™, 45° curve right AR-6069-45R
BirdBeak®, 22˚ up tip (b) AR-11890F
BirdBeak®, straight (c) AR-11880F
Banana SutureLasso™ Straight BirdBeak®, right, 45˚ handle AR-11886F
Straight BirdBeak®, left, 45˚ handle AR-11887F
The Banana SutureLasso was developed specially for

passing sutures through the rotator cuff via a superior
percutaneous approach (modified Neviaser portal) or
along the acromial border.
Banana SutureLasso™ AR-4065B
Rhino Suture Passer ProWick®
(a)
(b)
(c)
The Rhino suture passer is the next generation in The ProWick shoulder postoperative dressing and cold
reusable suture passing devices. The extremely sharp, therapy system is revolutionary technology designed
small diameter tip will easily penetrate soft tissue and to meet the demands of arthroscopic and mini-open
the rigid 3.4 mm shaft will resist bending and flexing surgical techniques. ProWick features a tapeless design
during tissue shifting procedures. The configurations composed of state-of-the-art, super-absorbent mate-
include straight, left and right curve with an upturned rial that stores patient exudate away from the surgical
tip. The novel bottom opening jaw design is conve- incision sites while compression and cold therapy are
niently positioned to capture the suture from an anchor, applied to the healing joint.
eliminating the need to rotate the instrument.
Product Description Item Number ProWick® shoulder postoperative dressing and cold AR-1625P
Rhino suture passer, straight (c) AR-11850SRF therapy system (box of 10, packed individually, sterile)
Rhino suture passer, right curve (a) AR-11851SRF

Rhino suture passer, left curve (b) AR-11852SRF
View U.S. Patent information at
www.arthrex.com/corporate/virtual-patent-marking
www.arthrex.com
© Arthrex GmbH, 2019. All rights reserved. LB2-0219-EN_I

Rotator Cuff Repair: Fulfilling The Need For Precision and Speed

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Rotator Cuff Repair: Fulfilling The Need For Precision and Speed

Uploaded by

Copyright:

Available Formats

Rotator Cuff Repair

Fulfilling the Need for Precision and Speed

Knotless SwiveLock® Anchors and FiberTape®���������������������������� 06

SpeedFix™ Knotless Single Row Rotator Cuff Repair������������������� 07

BioComposite Vented SwiveLock® With FiberTape® Loop������� 10

Scorpion™: Simple, Precise, �������������������������������������������������������������������������

and Fast to Meet the Most Stringent Requirements������������������� 12

The Ultimate Suture Passer. Grasp, Pass and Retrieve��������������� 13

Fully Threaded Corkscrew® Suture Anchors

The fully threaded Corkscrew family of suture anchors

BioComposite Corkscrew® FT PEEK Corkscrew® FT Corkscrew® FT

04 I Fully Threaded Corkscrew Suture Anchors

Spade tip drill, for AR-1927D

BioComposite Corkscrew® AR-1927BCF-45 PEEK Corkscrew® FT AR-1927PSF-45

Knotless SwiveLock® Anchors and FiberTape®

■■Our maximum fixation strength

■■Vented: May allow bony ingrowth*

■■Combines with many variations of FiberTape and

■■Self-punching design eliminates the need for a bone

■■Allow 2 mm wide FiberTape or TigerTape sutures

■■2 mm wide FiberTape or TigerTape options provide

* Cross section of a vented BioComposite SwiveLock

06 I Knotless SwiveLock Anchors and FiberTape

Quick and secure single-row fixation can be obtained

Optional: Rip-Stop SpeedFix™

The additional rip-stop with FiberLink increases the

SpeedFix™ Knotless Single Row Rotator Cuff Repair I 07

BioComposite SwiveLock® C, AR-2324BCC Self-punching, AR-2324BCM FiberTape, blue, 2 mm, AR-7237-7

The Science Behind the Technology...

Single Knotless Anchor Pull-Out Strength

5.5 mm 4.75 mm Mitek Versalok Arthrocare Arthrocare Smith&Nephew 4.5 mm Linvatec

08 I Knotless SwiveLock Anchors and FiberTape

Knotless Double Row

The fully threaded SwiveLock can be combined with

The 4.75 mm BioComposite vented SwiveLock is now

Product Description Item Number

BioComposite SwiveLock® C, 4.75 mm × 19.1 mm, AR-2324BCCT

SpeedBridge™ Implant System

Product Description Item Number

SpeedBridge™ implant system, with BioComposite AR-2600SBS-4

10 I BioComposite Vented SwiveLock With FiberTape Loop

Cadaveric testing shows that the knotless SpeedBridge

FiberTape # 2 FiberWire

SpeedBridge™ RCR Supported by DX Reinforcement Matrix Augmentation

The SpeedBridge rotator cuff reconstruction can be

■■OPTRIX processing method, without the need for

■■Provided in 2 sizes in a hydrated state for room

SpeedBridge™ and LT2-0219-EN

BioComposite Vented SwiveLock With FiberTape Loop I 11

■■New, solid design of lower jaw prevents placed

■■Flat jaws which fit down a 6 mm cannula and can

Product Description Item Number

FastPass Scorpion™ SL AR-13999MFF

■■Multi-functional instrument grasps tissue, passes and

■■Ratcheting jaw design grasps up to 16 mm of tissue

■■Available in both single pass and SCORPION-multifire

FastPass SCORPION-multifire PassPort Button™ Cannula

The Ultimate Suture Passer. Grasp, Pass and Retrieve I 13

Scorpion™ FiberWire® Grasper

Product Description Item Number

Scorpion™ suture passer, 16 mm (a) AR-13990F

Penetrator™ Suture Retriever FiberWire® Suture Cutters

Suture cutter, open ended left, 4.2 mm AR-11794LF

Knotless SwiveLock® Anchors and FiberTape®�� 06

SpeedFix™ Knotless Single Row Rotator Cuff Repair�� 07

BioComposite Vented SwiveLock® With FiberTape® Loop�� 10

Scorpion™: Simple, Precise, ��

and Fast to Meet the Most Stringent Requirements�� 12

The Ultimate Suture Passer. Grasp, Pass and Retrieve�� 13
