HACK SAW MACHINE AND BAND SAW MACHINE
HACKSAW MACHINE
Features:
• Coolant system
• Hydraulic feeding
Specification
Cutting Scope: mm Ø 160
mm 160 x 160
Hacksaw Blade Size mm 350 x 25 x 1.25 (14”)
Blade Stroke Length mm 100 ~ 190
Input Voltage kW/V/Hz/Ph 0.37/220/50/1
Coolant Pump Gear Pump
Dimension (L x W x H) mm 910 x 330 x 640
Weight kg 160
Order No Type Description

KW1500005 KW15-05 Hack Saw Machine 14 - 16”
HORIZONTAL HACK SAW MACHINE
Cutting Cap. Saw Size

10” 18” Features:
• Coolant system
Specification
Cutting Scope: mm Ø 250
mm 220 x 220
Oblique Saw ° 45
Frequency of Sawing Bow
75 ; 90 ; 108
Reciprocation
Stroke of Sawing Bow Cutting mm 135
Hacksaw Blade Size mm 450 x 45 x 2.25 (18”)
Weight kg 600
Order No. Type Description

KW1500415 KW15-415 Horizontal Hack Saw Machine 18”
BAND SAW MACHINE
Cutting Cap. Feature:

5” Pulley System
Specification
Motor HP 1/3
Input Voltage kW/V/Hz/ Ph 0.25/220/50/1
Saw Blade Speed Step Pulley F.P.M 65 ~ 95 ~ 165
Blade Size mm 12.7 x 0.65 x 1635
Weight kg 62
Cutting Capacity
mm (inch) 128 (5)
0o
Vertical Position mm (inch) 115 x 150 (41/2 x 6)
mm (inch) 76 (3)
45o
mm (inch) 76 x 115 (3 x 41/2)

KW1500055 KW15-55 Metal Cutting Band Saw 5”
www.krisbow.com Machinery 405

BAND SAW MACHINE
BAND SAW MACHINE
Cutting Cap.
8”
Cutting Cap.
9”
KW15-52
Features:
• Coolant system
• Pulley system
• Quick Clamping vise
KW15-53
Features:
• Coolant system
• Pulley system
• Quick clamping vise
Specification KW15-52 KW15-53

Motor HP 3/4 1
Input Voltage kW/V/Hz/Ph 0.55/220/50/1 0.75/220/50/1
Saw Blade Speed Step Pulley F.P.M 81~ 135 ~ 203 ~ 270 130 ~ 177 ~ 255
Blade Size mm 19.05 x 0.8 x 2.362 27 x 0.9 x 2.655
Dimension (L x W x H) mm 1235 x 430 x 1100 1380 x 460 x 1050
Weight kg 200 200
Cutting Capacity
mm 200 (8) 230 (9)
0o
mm 178 x 305 x (7x12) 178 x 305 (7 x 12)
mm 127 (5) 150 (6)
45o
mm 120 x 125 (43/4 x 47/8”) 127 x 150 (5 x 6)

406 Machinery www.krisbow.com

BAND SAW MACHINE
BAND SAW MACHINE
Cutting Cap.
10”
Features:
• Coolant system
• Variable speed gear box
• Head of band Saw can swivel ± 900 horizontally, with precision scale
Specification
Motor HP 2
Saw Blade Speed Variable Saw Blade Speed
Motor Speed FPM 81 ~ 327
Blade Size mm 27 x 0.9 x 3352
Weight kg 430
Specification
X° O
0° 254 (10”) 254 x 254 (10”x 10”) 76 x 458 (3”x 18”)
± 45° 254 (10”) 254 x 254 (10”x 10”) 254 x 280 (10”x 11”)
+ 60° 204 (8”) 178 x 178 (7”x 7”) 127 x 204 (5”x 8”)

KW1500458 KW15-458 Metal Cutting Band Saw 10” 2HP
OPTIONAL ACCESSORIES FOR KW15-52, KW15-53, KW15-55 AND KW15-458
Coolant System For All Machine Coolant Pump Kit

KW15-51 KW04-286

CIRCULAR SAW AND MAGNETIC CORE DRILL
CIRCULAR SAW
Specification
Blade10” Motor HP/Ph 1.3/1
Reduction Gear in an Oil Bath Ratio 1 : 33
Maximum Disk Diameter mm 250
Disk Rotation Speed rpm 42
Hole of Saw Blade mm 32
Vice Opening mm 100
Weight kg 85
Dimension Unit (L x Wx H) mm 1050 x 410 x 830
Stand mm 760 x 410 x 440
Dimension (L x W x H)
Packing mm 760 x 200 x 440

KW1500261 KW15-261 Circular Saw Machine 250mm complete with Stand
Optional Accessories
Circular Saw Blade for steel
KW0200048 ~ KW0200051
KW15-261
Order No. Description Size Order No. Description Size

KW0200048 Circular Saw Blade for steel 250 x 1.5 x 32 -3T KW0200055 Circular Saw Blade for steel 275 x 2.5 x 40 -6T
ELECTRIC BEVELLER
Features:
• The AC induction motor offers long life and quiet running
• Powerful motor up to 1100W with high torque
• Angular adjustment form 16-600
• Compact, Handy and Robust for easy moving and convenience
for construction operation
Specification
Power Input W 1100
Voltage V/Hz 230/50, 110/60
No Load Hz/rpm 60/3600, 50/3000
Standard Accessories 60 Deg 12.7mm
• Tool holder • Hex. Wrench M3 45 Deg 16mm
• Carbide insert 12 pcs • M 32 combination wrench Max
Angular Adjustment 37.5 Deg 15.6mm
• Hex. wrench M8 • wrench 27 x 24mm Cut
30 Deg 14mm
15 Deg 12mm
KW1500990 KW15-990 Electric Beveller 1100W
Net Weight kg 19.3
HOLE CUTTING DRILL

Features:
• Our Hole cutting drill has been designed to quickly cut holes
for up to 210mm.
• Build in bubble levels for multiple hole alignment.
• Tool free quick-release handle can mounted on either side.
Specification
Power Input W 1200
Voltage V/Hz 230/50-60, 110/50-60
No Load Speed rpm 110
Drill Chuck Max. capacity mm 203
Pipe clamping Capacity mm 210
Insulation Double insulation/class II

KW1500992 KW15-992 Hole Cutting Drill 1200W

MAGNETIC CORE DRILL
4 SPEED MAGNETIC CORE DRILL
MAGNETIC CORE DRILL
4 Speed 1 Speed 2 Speed

for KW15-380 for KW15-381
Specification
Motor V/Hz/Ph 230/50/1
Power W 1800
Speed 1 (max/min) 150/90
No/Full Load rpm
Speed 3 (max/min) 300/180 Specification KW15-380 KW15-381
Ø x Depth of cut Power W 1100 1800
75 x 50 (3 x 2) Speed 1 (max/min)
(Hand Feed) 380/230
No Load rpm 620/350
Ø x Depth of MT3 32 x 150 Speed 2 (max/min) 500/300
Twist Drill Bit (1-1/4 x 5-7/8) Ø x Depth of Cut mm 35 x 50 50 x 75
Max Capacity Ø x Depth of MT3 mm/inch Max Capacity Ø x Depth of Twist Drill Bit mm 13 x 110 16 x 110
16 x 110
Chuck Adaptor with
(5/8 x 4-5/16) Ø x Depth of Taps mm NA NA
Twist Drill Bit
25.4 x 40 Magnetic Adhesion N 15000 32000
Ø x Depth of Taps Weight kg 12.6 21
(1 x 1-9/16)
Magnetic Adhesion N 32000
Weight kg 24.8
KW1500380 KW15-380 Magnetic Core Drill 35 x 50mm
Order No. Type Description KW1500381 KW15-381 2 Speed Magnetic Core Drill 50 x 75mm
4 Speed Magnetic Core Drill 75 x
KW1500382 KW15-382 50mm w/Chuck
Standard Accessories for KW15-380 and KW15-381
• 13mm Tapping Adaptor
• Tapping Attachment
Drill Chuck and Arbor Coolant Tank Key Chuck Cover
Optional no.3 morse taper accessories available for tapping up to 25mm,

taper 3 shank twist drills up to 32mm, chucks, reamers, countersinks and more
Standard Accessories for KW15-382 Handle

Chain Tool Case
OPTIONAL ACCESSORIES FOR KW15-380,

KW15-381 AND KW15-382
Chain
Drill Chuck Open end STRAPPING MACHINE
and Arbor Wrench
Tool Case
Core Drill Center Pin

Key Chuck Coolant Tank Cover Handle Punch Hexagonal Key KW0200606 ~ KW0200624 KW0200686 ~ KW0200687

DRILL PRESS MACHINE
DRILL PRESS MACHINE
Max. Twist Drill Max. Twist Drill Max. Drill

13mm 13mm 16mm
Swing 208mm Swing 252mm Swing 340mm
KW15-538
KW15-539 KW15-540
Specification KW15-538 KW15-539 KW15-540

Motor V/ W/Ph 220/250/1 220/250/1 220/250/1
Swing mm 208 252 340
Max. Drilling Capacity mm 13 13 16
Chuck Capacity mm 13 13 16
Taper Arbor/drill Chuck Arbor JT33/B16 JT33/ B16 MT2/B16
Spindle Travel mm 50 60 80
1 Spindle Speed Motor Hz/rpm 50/500 ~ 2500 50/460 ~ 2480 50/180 ~ 2740
Overall Height mm 580 720 1065
Dimension (L x W x H) mm 465 x 235 x 345 560 x 390 x 255 895 x 490 x 290
Weight kg 19 32 59
Swing 340mm Swing 430mm Swing 515mm
KW15-543
KW15-541 KW15-542

Motor V/W/Ph 220/375/1 220/750/1 220/1000/1
Swing mm 340 430 515
Max. Drilling Capacity mm 16 28 32
Chuck Capacity mm 16 20 20
Taper Arbor/Drill Chuck Arbor MT2/B16 MT3/B22 MT3/B22
Spindle Travel mm 80 80 120
1 spindle Speed Motor Hz/rpm 50/180 ~ 2740 50/160 ~ 3000 50/110 ~ 2880
Dimension (L x W x H) mm 1420 x 510 x 256 1410 x 540 x 265 1,453 x 653 x 333
Weight kg 65 90 150
Order No. Type Description Order No. Type Description

KW1500538 KW15-538 Drill Press 13mm, Swing 208mm KW1500541 KW15-541 Floor Stand Drill Press 16mm, Swing 340mm

DRILLING MACHINE
DRILLING MACHINE
AUTOMATIC DRILLING MACHINE
Specification
Max. Drilling Diamater mm 16
Diameter of Column mm 85
Spindle Stroke mm 100
Distance Spindle Axis to Column Surface mm 180
Max. Distance Spindle Nose to Table mm 425
Max. Distance Spindle Nose to Base mm 610
Spindle Taper MT.2
Spindle Speeds Range rpm 290 - 2000
Spindle Speeds 6
Working Area of Table mm 280 x 310mm
Working Area of Base mm 250 x 250
Overall Height mm 1050
Motor Power W/Ph/V 750/3/380
G.W/N.W kg 118/108
Ship Measurement (Wooden Case) mm 790 x 460 x 1140
Features: Order No. Type Description

• Auto Feeding
• Pulley System KW1500941 KW15-941 Drilling Machine With Auto Feeding Spindle 16mm
Specification
Max. Drilling Diamater mm 25
Diameter of Column mm 102
Distance Spindle Axis to Column Surface mm 230
Max. Distance Spindle Nose to Table mm 680
Max. Distance Spindle Nose to Base mm 965
Spindle Taper - MT.3
Spindle Speeds Range rpm 230 - 2160
Spindle Speeds - 6
Working Area of Table mm 330 x 380
Working Area of Base mm 300 x 320
Overall Height mm 1681
Motor Power W/Ph /V 1500/3/380
G.W/N.W kg 220/200
Ship Measurement (Wooden Case) mm 930 x 570 x 1800

KW1500942 KW15-942 Drilling Machine with Auto Feeding Spindle 25mm
Features:
• Auto Feeding
• Coolant System

DRILLING AND TAPPING MACHINE
DRILLING AND TAPPING MACHINE
KW15-868 KW15-869 KW15-870

Features: Features:
• Foot Switch Features:
• Foot Switch
• Pulley System • Coolant System
• Pulley System
• Auto Reverse • Pulley System • Auto Reverse
• Auto Reverse
Include 1 set Include 1 set

Standard Accessories Standard Accessories
for KW15-870 : for KW15-870 :
• COLLET : M5, M6-8, M10, • COLLET : M12, M14, M16,
M12, M14, M16 M18-20, M22, M24
• 1 Collet key • 1 Collet key
• Arbor • Arbor
Order No. Description

Order No. Description KW1500925 M12 Collet
KW1500920 M6-8 Collet KW1500926 M14 Collet
KW1500921 M10 Collet KW1500927 M16 Collet
KW1500922 M12 Collet KW1500928 M18-20 Collet

Max. Drilling and Tapping Capacity 16mm/T:M12 16mm/T:M16 25mm/T:M24
Diameter of Column mm 70 85 102
Spindle Stroke mm 100 93 130
Distance Spindle axis to Column Surface mm 193 180 230
Max. Distance Spindle Nose to Table mm 340 425 620
Max. Distance Spindle Nose to Base mm 580 610 1095
Spindle Taper MT.2 MT.2 MT.3
Spindle Speeds Range rpm 320 - 2700 160 - 1820 160 - 1880
Spindle Speeds 5 9 9
Working Area of Table mm 265 x 265 Ø320 330 x 380
Working Area of Base mm 250 x 300 250 x 250 300 x 320
Motor Power kW/V/Ph 750/380/3 750/380/3 1,500/380/3
Net Weight kg 100 108 210
Ship Measurement (Wooden Case) mm 780 x 450 x 950 790 x 460 x 1140 930 x 570 x 180
M5, M6, M8, M10, M12, M14, M16,
Collet Diameter (Include Acc.) metric -
M12, M14, M16 M18-20, M22, M24
KW1500868 KW15-868 Drilling and Taping Machine 16mm/T:M12 w/Auto Reverse

RADIAL DRILLING MACHINE
RADIAL DRILLING MACHINE
Max. Drill KW15-764 Stand for Mini Radial Drill
32mm
Working capacity
In Mild Steel
Drilling mm 32
Face Mill mm 76
End Mill mm 20
Tapping mm 16
Specification
Motor HP 1,5
Spindle Speed Range rpm 300 ~ 2600
Spindle Taper MT3
KW15-284 Spindle Nose to Column Surface mm 460
Working Table mm 550 x 500
Features:
Cross Travel mm 380
• Pulley System
• Clock Wise and Counter Clock Wise Revolution Column Diameter mm Ø 115
Weight kg 350

KW1500284 KW15-284 Mini Radial Drilling 32mm, 1.5HP
OPTIONAL ACCESSORIES FOR KW15-10, KW15-46, KW15-47, KW15-256 , KW15-260, KW15-284 AND KW15-889
Drill Vise Standard Type Drill Vise Quick Type Leader Clamp Vise
Coolant System For All Machine
KW0400185 ~ KW0400188 KW0400189 ~ KW0400191 KW0400300 ~ KW0400301 KW1500051

MILLING, DRILLING, AND TAPPING MACHINE
MILLING AND DRILING MACHINE
MILLING AND DRILLING MILLING, DRILLING, AND TAPPING
Max. Drill
32mm
Max. Drill
32mm
Power Table Feed KW04-380 for:
• KW15-10, 46, 47, 256, 260
KW15-10
KW15-46
Working Capacity KW15-10 Working Capacity KW15-46

For Cutting Mild Steel For Cutting Mild Steel
Drilling mm 32
Drilling mm 32
Face Mill mm 76
Face Mill mm 76
End Mill mm 20
End Mill mm 20
Tapping m 16

Motor HP 2 2
Spindle Speed rpm 125 ~ 2500 125 ~ 2500
Spindle Taper MT3 MT3
Spindle Stroke mm 130 130
Swing mm 340 340
Working Table mm 730 x 210 730 x 210
Longitudinal Travel mm 430 430
Cross Travel mm 185 185
Column Diameter mm Ø115 Ø115
800 x 737 x 1143 800 x 737 x 1143
Dimension (L x W x H) mm
Without stand Without Stand
Weight kg 270 270

KW1500010 KW15-10 Milling and Drilling Machine 32mm With Stand
KW1500046 KW15-46 Milling, Drilling and Tapping Machine 32mm With Stand

Max. Drill Max. Drill

32mm 32mm
Power Table Feed KW04-380 for :
• KW15-10, 46, 47, 256, 260
KW15-47 KW15-260
Specification KW15-47 KW015-260 Features for KW15-47:

- Pulley system
Motor HP 1.5 1.5 - Clock wise and counter cock wise revolution
Input Voltage kW/V/Hz/Ph 1.1/380/50/3 1.1/380/50/3 Features for KW15-260:
- Automatic spindle return after power feeding
Spindle Speed rpm 125 ~ 2500 50 ~ 1250 - Head of milling machine can swivel ± 900
Spindle Taper MT3 MT3
Spindle Stroke mm 130 130
Spindle Nose to Working Capacity
mm 205 170
Column Surface For Cutting Mild Steel
Working Table mm 555 x 495 585 x 190 Drilling mm 32 32
Swing mm 520 520 Face Mill mm 76 100
End Mill mm 20 20
T-slot Size mm 14 x 26 16 x 26
Longitudinal Tapping mm 16 16
mm 340 340
Travel For Cutting Light Alloy mm 32 32
Cross Travel mm 180 180
Column Diam-
mm Ø 115 Ø115
eter Milling, Drilling and Tapping
KW1500047 KW15-47
Dimension Machine 32mm
mm 737 x 889 x 1854 839 x 737 x 1817
(L x W x H) Milling, Drilling and Tapping
KW1500260 KW15-260
Weight kg 270 310 Machine Direct Driven 32mm,
OPTIONAL ACCESSORIES FOR MILLING MACHINE KW15-10, KW15-46, KW15-47, KW15-256, KW15-889 and KW15-260
Note : Optional trafo step down from 220V, 1Ph become 110v, 1Ph
Specification KW04-380
Voltage V 110
Speed Range rpm 0 - 165
Max. Torque inch/lb 450
Rapid Speed rpm 240
Weight kg 6.8

KW0400380 KW04-380 Power Table Feed

Max. Drill
50mm
Power Table Feed KW04-380 for:
• KW15-10, 46, 47, 256, 260
Features:
• Automatic spindle return after power
feeding
• Coolant system of machine base
• Gear change on front panel for conve-
nience
• MT4 spindle taper provides a maximum
of 65mm drilling capacity in cast iron
• Massive diameter quill provides high
rigidity
• Micro feed on spindle for precise work
• Spindle fitted with heavy duty taper
roller bearings
• Spindle over travel protection prevents
damage to transmission gears
• Tapping function with auto start and
auto reverse
• 4 steps spindle power down feed
Specification
Longitudinal Travel mm 460
Cross Travel mm 280
Number of Power Downfeeds mm 4(0.1~ 0.2 ~ 0.3 ~ 0.4)
Specification Number of Spindle Speeds 6
Drilling Capacity in Cast Iron mm 50 Range of Spindle Speeds rpm 100 ~ 300
Drilling Capacity in Mild Steel mm 50 Working Surface of Table mm 240 x 820
Tapping Capacity mm 33 T-Slot Size mm 22 x 35
Face Mill Capacity mm 100 Center Distance Between T-Slot mm 53
End Mill Capacity 25 Overall Height (L x W x H) mm 1162 x 1194 x 2324
Spindle Drive Geared Head Cooling Pump HP 1/8
Swing mm 700 Motor HP 3
Max. Spindle Nose to Table mm 690 Input Voltage kW/V/Hz/Ph 2.25/380/50/3
Spindle Taper MT4 Weight kg 805
Spindle Travel mm 200
Quill Diameter mm 100
Column Diameter mm 160 KW1500256 KW15-256 Milling Drilling and Tapping Machine 50mm
OPTIONAL ACCESSORIES FOR KW15-10, KW15-46, KW15-47, KW15-256 , KW15-260, KW15-284 AND KW15-889
Steel Clamping Kit

KW04-383 for KW15-47, 260
KW04-370 for KW15-10, 46,
256, 284, 889.
KW04-284 for KW24-37

VERTICAL AND HORIZONTAL MILLING MACHINE
VERTICAL AND HORIZONTAL MILLING MACHINE
Features:
• Vertical milling head can be moved forward or backward
• Vertical milling head can swivel 90o vertically and 360o horizontally
• Adjustable stops on table
• Manual quill feed
• High tensile casting iron elevative table
- Double motor with powerful force
Operating System
Specifications
Max. Drilling Capacity mm 50 (2”)
Max. Milling Capacity (End/Face) mm 32/100
Swivel Angle of Headstock (Perpendicular) 90
Spindle Taper (End/Face) MT 4
Standard Accessories for KW15-889 Distance from Spindle Nose to Worktable mm 80 – 480
Surface
Spindle Travel mm 130
Beam Travel mm 500
Step of Spindle Speed (End/face) 06/12/10
Range of Spindle Speed (End/face) rpm 90 – 1600/38 – 1280
Step of Spindle Auto Feeding (End/face) 3
Range of Spindle Auto Feeding (End/face) 0.12; 0.18; 0.25
Collet Set
Worktable Size mm 1000 x 240
Forward and Backward Travel of Worktable mm 300
Left and Right Travel of Worktable mm 785
Vertical Travel of Worktable mm 400
Vise Min. Distance from Spindle Axis to Column mm 290
Motor (End/face) HP 2/2
Spidle for Horizontal Milling
Cooling Pump Power kW 0.04
Overall Dimension (L x W x H) mm 1940 x 850 x 1320
Packing Size (L x W x H) mm 1220 x 1350 x 1850
Vertical/Horizontal Milling
KW1500889 KW15-889
Machine 50mm Nett Weight/Gross Weight kg 950/1050
OPTIONAL ACCESSORIES FOR MILLING MACHINE
BT40 Drill Chuck Arbor V Block with Clamp Semi Universal Dividing Head Horizontal / Vertical Rotary Table
KW04-280 1.5/8 x 2.3/4 x 1.3/4 inch KW04-323 KW04-330
KW04-117
NT30 ER32 NT 40 ER 32 BT 30-60L ER 32 BT 40-70L ER 32

Collect Chuck 4-20 (11pcs) Collet Chuck 4-20 (11pcs) Collet Chuck 4-20 (11pcs) Collet Chuck 4-20 (11pcs) Magnetic Working Beam
KW04-384 KW04-75 KW04-386 KW04-387 KW04-391

BENCH LATHE MACHINE
BENCH LATHE MACHINE
BENCH LATHE MACHINE
Capacity
250 x 750 mm
Include Accessories
• 3-jaws Chuck (125mm)
• 4-jaws Chuck
• Change Gears Set
• Tool Box with Standard Tools
• Steady Rest
• Follow Rest
• Face Plate
Specification
Max. Swing Over Bed mm 250
Max. Swing Over Cross Slide mm 140
Distance Between Centers mm 750
Spindle Bore mm 21
Taper of Spindle Bore M.T. #3
Range of Spindle Speed rpm 125 - 2000
Range of Longitudinal feeds mm/rev 0.1-0.2
Range of Matric Threads mm 0.25-2.5
Range of Inch Threads T.P.I 8-56
Max. Size of Tool Shank mm 14x14
Taper of Tailstock Bore M.T. #2
Motor Power kW/V/Ph 0.55/220/1
Weight kg 140

KW1500604 KW15-604 Bench Lathe Machine 250 x 750mm

BENCH LATHE MACHINE
BENCH LATHE MACHINE
BENCH LATHE MACHINE
Capacity
310 x 910mm
Include Accessories
• 4-jaws Chuck
• Tool Box with Standard Tools
• Steady Rest
• Follow Rest
• Face Plate
• Coolant System
Specification
Power W/Ph 1500/3
Motor V/Hz 380/50
Max. Swing Over Bed mm 310
Max. Swing Over Cross Slide mm 180
Max. Swing in Gap mm 450
Taper Of Spindle Bore mm MT#5
Spindle Bore mm 38
Range of Spindle Speeds rpm 65 ~ 1810
Range of Longitudinal Feeds mm/rev 0.0527 ~ 1.2912
Range of Cross Feeds mm/rev 0.011 ~ 0.276
Range of Metric Threads mm 0.4 ~ 7
Range of inch. Threads T.P.I 4 ~ 60
Max. of Size of Tool Shank mm 14 x14
Taper of Tailstock Bore MT#3
Weight kg 562 (693kg with stand)


BENCH LATHE MACHINE
BENCH LATHE MACHINE
BENCH LATHE MACHINE
Capacity
320 x1000mm
• 4-jaws Chuck
• Drill Chuck
• Tool Box and Standard Tool
• Steady Rest Feature:
• Follow Rest May select feedbox with
• Coolant System different operation handles
Specification Specification
Power W/HP/Ph 1500/2/3 Leadscrew Diameter mm 22
Motor V/Hz 380/50 Leadscrew Thread Pitch T.P.I/mm 8/3
Swing Over Bed mm 320 Cutting Tool Max Section mm 16 x 16
Swing Over Cross Slide mm 198 Threads Imperial Pitches 38 Nos.8 ~ 112T.P.I or (34 Nos.4 ~ 56TPI)
Max. Length of Workpiece 28 Nos.0.2 ~ 5mm pitch or (26
mm 210 Thread Metric Pitches
In Gap Nos.04 ~ 7mm pitch)
Swing in Gap Diameter mm 476 Thread Diametrical Pitches 36 Nos.8 ~ 112D.P
Center Height mm 166 Thread Module Pitches 22 Nos.0.2 ~ 3M.P
Max. Length of Workpiece mm 1000 36 Nos.0.0019” ~ 0.0273”/rev.
Longitudinal Feeds Imperial
Bed Width mm 187 or (32 Nos0.002 ~ 0.548”/rev)
Spindle Bore mm 38 36 Nos.0.050” ~ 0.696”/rev. or
Longitudinal Feeds Metric
(32 Nos0.052 ~ 1.392”/rev)
Spindle Nose D1-4”
36 Nos.0.006” ~ 0.0094”/rev. or (32
Taper in Nose MT#5 Cross Feeds Imperial
Nos0.0007 ~ 0.0187”/rev)
Taper in Sleeve MT#3
36 Nos.0.013” ~ 0.188”/rev. or
Speeds Number 8 or 16 Cross Feeds Metric
(32 Nos0.014 ~ 0.380/rev)
70 ~ 2000 or 35 ~ 2000
Speeds Range rpm Travel of Tailstock Quill mm 100
(2 speed motor)
Cross Slide Width mm 118 Diameter of Tailstock Quill mm 32
Cross Silde Travel mm 160 Taper Hole Of Tailstock Quill MT#3
Compound Rest Width mm 76 Gross Weight kg 524 (655kg with stand)
Compound Rest Travel mm 68 Dimension (L x W x H) mm 1860 x 750 x 730


BENCH LATHE MACHINE
BENCH LATHE MACHINE
BENCH LATHE MACHINE
Capacity
360 x 1000mm
Features: Standard Accessories

• Need not change any gears you
• 3-jaw chuck • Coolant system
can turn all the metric and inch
• Change gear kit • Machine lamp
thread indicating in chart
• Chip tray • 4-jaw chuck
• Three point Support for spindle
• Reduction bushes • Face plate
• Clutch in apron for safety and for
• Dead center • Steady rest
changing apron feed direction
• Splash guard • Follow rest
without changing spindle running
• Foot brake
direction
Specification
Turning Dia. Via Lathe Bed mm Dia. 356
Turning Dia. Via Slide mm Dia. 220
Bed Width mm 206
Max. Size of Tool Shank mm 16 x 16
Headstock
Spindle Bore mm Dia. 38
Spindle Taper MT5
Spindle Speeds rpm 45 - 1800
Tailstock Taper MT3
Pitch-Metric mm 0.45 - 1800
Pitch- Inch T.P.I 4-112
Motor
Motor Power kW/V/Ph 1.5/380/3
Dimension and Weight
Gross Weight kg 850/950

KW1500979 KW15-979 Lathe Machine 360 x 1000mm

LATHE MACHINE
GAP BED LATHE MACHINE
PRECISION GEARHEAD LATHE
Capacity
410 x 1000mm
Features:
• Need not change any gears you can turn all the metric
• 3 jaw Chuck and Adapter (200mm) • Thread Chasing Dial
and inch thread indicating in chart
• 4 jaw chuck and Adapter (320mm) • MT 6x4 Sleeve and MT4 Center
• Three point Support for spindle
• Face Plate 300mm • Brake System
• Clutch in apron for safety and for changing apron feed
• Steady Rest • Work Lamp
direction without changing spindle running direction
• Follow Rest • Coolant System
Specification Capacity Headstock

Swing Over Bed mm 410 (16”) Spindle Nose D1–6
Swing Over Cross Slide mm 255 (10”) Spindle Bore mm 52 (2”)
Swing in Gap mm 580 (23”) Taper of Spindle Bore MT 6
Length of Gap mm 250 (10”) 16 change
Range of Spindle Speed
Distance Between Centers mm 1000 (40”) 45 – 1800 rpm
Center Height mm 520 (20.5”) Tailstock
Width of Bed mm 250 (10”) Dia. of Tailstock Sleeve mm 50 (2”)
Travel of Tailstock Sleeve mm 120
Morse Taper of Tailstock Sleeve MT 4
Cross Adjustment mm ± 13 (1/2”)
Feeds and Threads

Max Travel of Compound Rest mm 102 (4”)
Max Travel of Cross Slide mm 210 (8 – 1/4”)
Leadscrew Pitch 4 T.P.I
Max Section of Tool mm 20 x 20 (13/16”)
Longitudinal Feed Range mm/rev 0.05 –1.7 (0.002” - 0.067”/rev)
Cross Feeds Range mm/rev 0.025 – 0.85 (0.001” - 0.0335”/rev)
Metric Threads Range 39 kinds 0.2-14mm
Inch Threads Range 45 kinds 2-72 TPI
Diametrical Pitches Range 21 kinds 8-44 D.P.
Module Pitches Range 18 kinds 0.3-3.5 M.P.
Motor
Power of Main Motor kW/Ph/HP 3.3/3/4.5
Power of Coolant Pump kW/Ph/HP 0.1/3 /1.8
Dimension And Weight
Nett Weight/Gross Weight kg 1550/1800

KW1500907 KW15-907 Precision Gear Head Lathe Machine 410 x 1000mm

LATHE MACHINE
Include Accessories
Capacity • 3 jaw chuck (250mm)
600 x 1500mm • 2 Driving plate
• 3 Centre Sleeve
• 4 Wrenches
• Oil gun
• Operation Manual
KW15-943
Specification Specification
Max. Swing Over Bed mm 600 Cross Feed Range mm/rev 0.036-2.019
Max. Swing Over Cross Slide mm 380 Rapid Traveling speed of Carriagge m/min 5
Center Distance mm 1500 Leadscrew size : Diameter Pitch mm 35/6
Max. Swing Over Gap mm 750 Cross Slide Travel mm 300
Effective Length of Gap mm 260 Compound Rest Travel mm 130
Bed Width mm 330 Max. Size of Tool Shank mm 25 x 25
Spindle Hole mm 85 Taper of Tailstock Sleeve Morse No. 5
Spindle Nose ISO-C6 or ISO D6 Diameter of Tailstock Sleeve mm 65
Spindle Taper mm Metric 70 Travel of Tailstock sleeve mm 120
Spindle Speeds number 22 – 1800rpm (15 steps) Main Drive Motor kW/V/Ph 7.5/380/3
Metric Threads range kinds 0.5 – 28mm (66 kinds) Coolant Pump Motor kW 0.125
Inch Thread range kinds 0.5 – 3.5” (33 kinds) Rapid Traverse Motor kW 0.12
Diametral Thread Range kinds 8 – 56D.P (33 Kinds) Packing Size ( L x W x H ) mm 2920 x 1150 x 1800
Longitudinal Feeds range kinds 0.072 – 4.038mm/rev (66 kinds)
KW1500943 KW15-943 Gap Bed Lathe Machine 600 x1500mm
Spindle Bore 80mm
OPTIONAL ACCESSORIES FOR LATHE MACHINE
Tool Bit Square

KW0200464 ~ KW0200469
KW0200954 ~ KW0200957
Coolant System For All Machine
KW15-51
B3B
10°
Coolant Pump Kit Cut Off Tool Bit Magnetic Working Beam
KW04-286 KW0200958 ~ KW0200961 KW04-391

UNIVERSAL TOOL AND CUTTER GRINDER
UNIVERSAL TOOL AND CUTTER GRINDER
Specifications
Horizontal Travel of the Operating Table mm 260
Longitudinal Travel of the Operating Table mm 150
Area of Operating Table mm 130 x 550
Elevating Distance of Wheel Head mm 120
Rotating Angle of Wheel Head 360˚
Grinding Wheel Size mm 150 x 50 x 32
Speed of Grinding Wheel rpm 2,800
Power HP/Ph/V 0.75/3/ 380
Net/Gross Weight kg 160/168
KW1500767 KW15-767 Universal Tool and Cutter Grinder(1Motor) Specifications
Max. Grinding Diameter mm 250
Longitudinal Travel of the Operating Table mm 150
Horizontal Travel of Operating Table mm 315
Elevating Distance of Wheel Head mm 120
o
Rotating Angle of Wheel Head 360
Speed of Grinding Wheel rpm 5,000
Motor Power HP/Ph/V 1/3/380
Height of the Head Holder mm 135
Taper Hole of Main Spindle of the Head Holder MT#4
Max. Hold Capacity of the Head and Back mm 450
Holder
Area of Operating Table mm 13 x 680
Grinding Wheel Size mm 125 x 50 x 32
Order No. Type Description N.W/G.W kg 209/222
KW1500768 KW15-768 Universal Tool and Cutter Grinder(2Motor) Packing Size (L x W x H) mm 730 x 710 x 715
Features and Benefits:

• The machine is applicable to sharpen high-speed steel, hard metal • The operating table adopts the imported high-precision linear ball slide rail
or cutters made of other materials and id\s convenient for cylindrical which can ensure the table stable and easy to operate.
grinding, plane groove processing and three-dimensional profiling, etc. • The motor can rotate 360°, the two sides of the motor can be installed with
If special accessories are equipped, it can also be used to grind various two grinding wheels at the same time.
gears, worm-wheel hobs, form tools, ball-end milling cutters, fluted twist • When you grind cutting tools of different materials, you may restart grinding
drills, taper taps, etc. by simply rotating the motor, which can enhance security and reduce the
• Available to operate with other accessories: shaped cutting tool, butt mill, time of disassembling and reparation. The machine used the Fc30 cast iron of
end mill, R-sharped mill, circular cutter, face and side cutter, single-angle high toughness to keep the smooth operation for a long time.
cutter, reamer, turning tool, R-shaped turning tool, hobbing cutter, drill, • The maximum linear speed of grind wheel is 40m/s and the tapered bore of
screw tap, graver, strong cutting tool, chamfering tool, round paper knife, inner ring for the spindle of the spindle stock can be provided as per customer
circular and plane grooves, and profiled faces, etc. demands in other structural dimensions.
OPTIONAL ACCESSORIES FOR UNIVERSAL TOOL AND CUTTER GRINDER
Aplication of KW15-864
MT4 Collet Chuck Set

KW15-862 KW15-895 KW0400083~KW0400084 KW15-775
KW15-853 KW15-854 KW15-855 KW15-856 KW15-861 Order No. Type Description
Order No. Type Description KW1500855 KW04-855 Collet System Ø 16mm F/KW15-770
KW1500769 KW15-769 50D End Mill Grinding Attachment KW1500856 KW04-856 Collet System Ø 20mm F/KW15-770
KW1500770 KW15-770 50E Universal R-Type End Mill Grinding Attachment KW1500861 KW04-861 Collet System Ø 6mm F/KW15-770
KW1500775 KW15-775 Stand for KW15-767, KW15-768, KW15-885 KW1500862 KW04-862 Collet System Ø 10mm F/KW15-770
KW0400083 KW04-83 MT4 ER32 Collet Chuck Kit 4-20(11) KW1500863 KW04-863 Collet System Ø 18mm F/KW15-770
KW0400084 KW04-84 MT4 ER40 Collet Chuck Kit 4-26(15) KW1500895 KW04-895 Collet System Ø 4mm F/KW15-770
KW1500853 KW04-853 Collet System Ø 8mm F/KW15-770 KW1500864 KW04-864 50L Spiral Grinding Attachment
KW1500854 KW04-854 Collet System Ø 12mm F/KW15-770 KW1500867 KW04-867 50K Multi Functional Cutter and Tool Grinding Attachment

SAW BLADE SHARPENER
SAW BLADE SHARPENER
With quality construction, precision sharpening is simple and easy. Setup can be completed in
just minutes. The elimination of time-consuming adjustment reduces labor costs.
Specification
Saw Blade Capacity mm Ø50 ~ 480
Pitch Range mm Max 25
Depth of Teeth mm Max 12
Range of Cutting Angle -5o ~ 30o
Feed Speed teeth/min 0 ~ 120
Max. Thickness of Blade mm Max 8
Grinding Wheel Size mm Ø150 x 10 x 32
Speed of Grinding Wheel rpm 2800/4800
Motor Power HP/V/Phase 0.5/220/1
Net Weight kg 105
Package Size (L x W x H) mm 800 x 750 x 680

KW1500865 KW15-865 Circular Saw Blade Sharpener 1Ph
Specification
Pitch Range mm Max. 40
Depth of Teeth mm Max. 12
Range of Cutting Angle 0o ~ 34o
Feed Speed teeth/min 0 ~ 120
Thickness of Blade mm 0~3
Motor Power HP/V/Ph 0.5/220/1
Speed of Grinding Wheel rpm 2800
Grinding Wheel Size mm Ø 150 Ø 32 x 10

KW1500866 KW15-866 Band Saw Blade Tooth Grinder 1Ph
GRAVER GRINDER
The universal dividing head of graver grinder can rotate 180o or 360o, in addition to settings of pushing angle and clearance angle. The moveable pusher
enables the grinding of the negative pushing angle more easily. It is very convenient to grind circular, semi circular, positive angle of taper, back draught
shaped cutters with single edge, or cutter punches of right, triangular, four, multi angles, or diamond shape. It is free of complicated settings. In addition,
the dividing head can be set every 15o
Optional Accessories Specification
Stand for KW15-767, Max Hoding Capacity mm 16-28
KW15-768, KW15-885 Max. Grinding Capacity mm 25
Pushing Angle o
0 ~ 180
Clearance Angle o
0 ~ 45
Negative Pushing Angle o
0 ~ 25
Rotating Speed of the Main Axle rpm 5000
Diameter of Dishaped Grinding Wheel mm Ø 100 x 50 x 20
Motor Power HP/V/Ph 1
/4 /220/1
N.W/G.W kg 46/60
KW15-775 Order No. Type Description

KW1500885 KW15-885 Graver Grinder
INCLUDE ACCESSORIES FOR GRAVER DRIVER
Inner Hexagon
Drill Tool Holder
Handle Spanner
Spring Collet Ø 4,6,8,10 and 12 Belt
Lathe Tool Holder
Lamp
Screw Driver Mill Tool Holder
Grinding Wheel Hexagonal Wrench Hook Spanner

PRECISION DRILL AND END MILL GRINDER
PRECISION DRILL AND END MILL GRINDER
KW04-445
KW04-389
Optional Accessories :
for KW04-445
Include Accessories: for KW04-445 Include Accessories: for KW04-389

Alloy Steel Collet ER-20 11pcs (3 - 13), Alloy Steel Collet ER-40 14pcs (12 - 25),
Collet Holder 1 unit, Hex. Wrench 2pcs Collet Holder 1 unit, Hex. Wrench 1pcs
KW04-446
Specification KW04-388 and KW04-445 KW04-389

2,1 3, 4, 5, 6, 7, 8, 9, 12, 13, 14, 15, 16, 17, 18, 19, 20,
Drill Diameter mm 10, 11, 12, 13 (collet ER-20) 21,22, 23, 24, 25 (collet ER-40)
o
Center Point Angle 90o - 140o 100o - 136o
R.P.M of Motor rpm 5100 5300
Grind Wheel CBN#200 CBN#200
Net Weight kg 9.7 29
Dimension (L x W x H) mm 185 x 282 x 110 240 x 380 x 200
KW0400389 KW04-389 ER-40 Precision Drill Grinder Set (14pcs)
KW0400445 KW04-445 ER-20 Precision Drill Grinder Set
VERTICAL CYLINDER HONING MACHINE
Specification
Dia. of Honing Hole mm 40 – 140
Max. Depth of Honing Hole mm 320
Spindle Speed rpm 128; 240
Longitudinal Travel of Honing mm 720
Head
Spindle Steps Vertical Speed m/min 0 – 10
Power of Honing Head Motor kW 0.75
Net Weight kg 510

KW1500987 KW15-987 Vertical Cylinder Honing Machine  40-140mm

CYLINDER BORING AND HONING MACHINE
Type KW15-50
Diameter of Boring and Honing Hole mm 39 ~ 72
Include Accessories Max. Boring and Honing Depth mm 160

Rotational Speed of Boring Spindle rpm 480
Steps of Variable Speed of Spindles 1 Step

Feed of Boring Spindle mm 0.09
Return and Rise Mode of Boring Spindle Hand operated
Rotational Speed of Honing Spindle rpm 300
Honing Spindle Feeding Speed m/min 6.5
Electric Motor, Power kW 0.75
Electric Motor, Rotational Speed rpm 1,400
Electric Motor, Voltage V 220
Electric Frequency Hz 50
Weight of Main Machine kg 170

KW1500050 KW15-50 Cylinder Boring and Honing 39-72mm
CYLINDER BORING MACHINE
Type KW15-295
Diameter of Boring Hole mm 39 ~ 72
Max. Boring Depth mm 160
Rotational Speed of Boring Spindle rpm 480
Steps of Variable Speed of Spindles 1 step
Feed of Spindle mm/s 0.09
Return and Rise Mode of Spindle Hand operated
Electric Motor, Power kW 0.25
Include Accessories
Electric Motor, Rotational Speed rpm 1400
Electric Motor, Voltage V 220
Electric Frequency Hz 50
Ø39 - 46 Ø46 - 54
Centering Range of Centering Device mm
Ø54 - 65 Ø65 - 72
Weight Of Main Machine (Approx) kg 80
KW15-295 KW1500295 KW15-295 Cylinder Boring Machine 39-72mm
OPTIONAL ACCESSORIES FOR HONING BORING
KW15-533 KW15-534 KW15-535 KW15-536

KW1500533 KW15-533 Honing Grinder D Ass 23mm, (8ea Grinder 80 x 8 x 8mm)
KW1500536 KW15-536 Boring Cutter and Spring Set for KW15-50 and KW15-295

MANUAL PIPE BENDER
MANUAL PIPE BENDER
6~22mm
Features:
• Anri spreang break mechanism standard
• Plastic case packing
• Simple instlaation and easy to operated
10~25mm
KW15-695
KW15-696
Mounts quickly and Easily to your workbench
Specification for KW15-696

Bending Formers mm 10, 12, 14, 16, 19, 22, 25
Specification for KW15-695
Pipe Wall Thickness mm 0.8 ~ 2
Bending Formers mm 6, 8, 10, 12, 15, 18, 22
Maximum Bending Angle o
180
Pipe Wall Thickness mm 1
Packing Size mm 640 x 250 x 150
Weight kg 5
Weight kg 24
Dies Type (mm) Radius (mm) Dies Type (mm) Radius (mm)
6 60 10 50
8 62 12 60
10 66 14 70
12 75 16 80
15 100 19 90
18 140 22 113
22 165 25 113

Manual Pipe Bender 10-25mm
KW1500695 KW15-695 Manual Pipe Bender 6-22mm Floor Type KW1500696 KW15-696
Floor Type

HAND AND HYDRAULIC PIPE BENDER
HAND PIPE BENDER
For Most INCH
Specification
Round Dies Pipe inch 3/8, 1/2, 9/16, 5/8, 3/4, 7/8
Square Dies Pipe inch 3/4, 1
Pipe Thickness mm 0.8 - 1.2
Max. Bending Angle ˚ 180
Weight kg 26

KW1500520 KW15-520 Hand Pipe Bender 3/8 - 7/8”
HYDRAULIC PIPE BENDER
Capacity Capacity Capacity
½ ~ 2” ½ ~ 3” ½ ~ 4”
KW15-591
KW15-589 KW15-590
Dies Type (inch) Radius

1/2 80mm
3/4 95mm
1 105mm
1.25 140mm
1.5 180mm
2 240mm
2.5 265mm
3 305mm
4 385mm
Max. Max. Crimping Tubing wall Weight Dimension

Type Allocated Mould (inch)
Pressure (T) Stroke (mm) Range (mm) Thickness (mm) (kg) L x W x H (mm)
KW15-589 9 250 Ø21.3 ~ Ø60 1/2, 3/4, 1, 1¼, 1½, 2 2.75 ~ 4.5 60 730 x 320 x 200
KW15-590 19 320 Ø21.3 ~ Ø88.5 1/2, 3/4, 1, 1¼, 1½, 2, 2½, 3 2.75 ~ 5 140 920 x 400 x 230
KW15-591 21 415 Ø21.3 ~ Ø108 1/2, 3/4, 1, 1¼, 1½, 2, 2½, 3, 4 2.75 ~ 6 215 1180 x 460 x 250

KW1500589 KW15-589 Hydraulic Pipe Bender 1/2 ~ 2”, Floor Type

HYDRAULIC PIPE BENDER AND DIGITAL PIPE BENDER
HYDRAULIC PIPE BENDER
HYDRAULIC PIPE BENDER Include Accessories
Specification
Max Force Ton 9
Stroke mm 280
Bending Formers inch /8, 1/2, 3/4, 1, 11/4, 11/2
3
Pipe Wall Thickness mm 2.75 ~ 4.5

Weight kg 122
KW15-697

KW1500697 KW15-697 Hydraulic Pipe Bender 3/8 - 1 1/2” Standing Type
HYDRAULIC PIPE BENDER WITH ELECTRIC MOTOR

Dies Type (inch) Radius
1/2 80 mm
3/4 95 mm
1 105 mm
1.25 140 mm
1.5 180 mm
2 240 mm
2.5 265 mm
Specification
Max. Pressure Ton 21
Motor V/W/Ph 220/750/1
Max. Stroke mm 415
Pipe External Diameter mm Ø21.5 ~ Ø108
Bending Angle a 90o < a< 180o
Pipe Wall Thickness mm 2.75 ~ 6
Weight kg 173

KW1500595 KW15-595 Hydraulic Pipe Bender 1/2”-21/2” with Electric Motor
DIGITAL PIPE BENDER MACHINE
This Portable Digital bending machine is unique in the industry in having a digital LCD degree display. It makes
it extremely fast and simple to produce accurate bends up to 190 degrees intubing up to 1 – 1/4”. Simply set
the desired degree of bend with the thumb wheel and that numberappears on the digital display. As soon as
the trigger is pressed. The actual degrees of bend are displayed, up until the bend is complete
Type KW15-991
Voltage V/Hz 230: 50/60, 115: 50/60
Features: Power Input W 1800
• Safety non Locking Trigger No Load Speed rpm 3.5
• Easy to use reversing switch Max. Capacity mm 32 ( 11/4” )
• Bending Shoe with gradation markings N.W ( Machine Only) kg 14
• Robust heavy duty Gearbox
KW15-991 • 1800W motor with externally accessible Order No. Type Description
brushes KW1500991 KW15-991 Digital Pipe Bender 3/4 - 11/4”

DIGITAL PIPE BENDER AND ELECTRIC PIPE BENDING
ELECTRIC PIPE BENDER MACHINE
145mm
230mm
Specification
16, 19, 22, 25, 32, 38, 51,
Round Formers mm
63, 76
Square Formers mm 16, 19, 22, 25, 30, 38, 40, 50
Bending Pipe Thickness mm 0.5 ~ 2
Motor Power Ph/V/kW/A 3/380 /1.5 / 7.21
Weight kg 250

KW15-698
KW1500698 KW15-698 Electric Pipe Bender Machine 16-76mm
PIPE NOTCHER
MANUAL PIPE NOTCHER

Tubing Capacity inch 3/4, 1, 1¼ 1½, 2
Packing Size (L x W x H) mm 500 x 180 x 160 500 x 180 x 160
N.W./G.W kg 8/9 15/16

KW1500958 KW15-958 Manual Pipe Notcher 3/4”, 1”, 1¼”
KW1500959 KW15-959 Manual Pipe Notcher 1.5", 2
ELECTRIC PIPE NOTCHER

Features:
• High productivity
• Low cost
• Simple and quick operation
• Several diameters instantly available
Include Stencil and Notcher
Specification Motor Power
Capacity inch 3/4, 1, 1¼, 1½, 2
Weight kg 92
KW1500517 KW15-517 Electric Pipe Notcher 3/4 - 2”

THREADING MACHINE
THREADING MACHINE
Bolt Size Capacity
M8-M24 1/2” ~ 2”
Specification
Size inch M8-M24, BSW1/4-1, BSPT/NPT1/2-2
1/2” ~ 3/4”, 1” ~ 2”; (BSW) 1/4”, 3/8”, 1/2”,
BSPT/
Dies 5/8”, 3/4”, 7/8”, 1”;M8, M10, M12, M14,
Metric
M16, M18, M20, M22, M24
Voltage V 220
Motor Power W/Ph 750/1
Speed rpm 27
Weight kg 90/75
Packing Size
mm 710 x 455 x 520
(L x W x H)

Threading Machine BSPT Pipe
KW1500368 KW15-368
1/2” ~ 2” Bolt M8-M24
KW15-368
Include Accessories
HSS Dies 1/2” - 3/4” HSS Dies 1” - 2”

For more detail information about
KW02-990 KW02-991 drill, please see Category 2
OPTIONAL ACCESSORIES FOR KW15-368
Pipe Size
1/2” ~ 2”
Specification
Size inch 1/2 ~ 2
Dies BSPT inch 1/2 ~ 3/4, 1 ~ 2
Voltages V 220
Speed rpm 27
Weight kg 86/70

KW1500369 KW15-369 Pipe Threading Machine Dies BSPT 1/2” ~ 2”

THREADING MACHINE
THREADING MACHINE
Pipe Size Optional Accessories
1/2” ~ 3”
KW15-684
Die Head 1/2”~2” for KW15-370
Specification
Size inch 1/2 ~ 3
Dies BSPT 1/2” ~ 3/4”,1” ~ 2”, 21/2” ~ 3”
Voltage V 220
Speed rpm 11/24
Weight kg 130/110
KW15-370
KW1500370 KW15-370 Pipe Threading Machine Dies BSPT 1/2”-3”
Pipe Size
1/2” ~ 4”
KW15-421
Die Head size 1/2”~2” for KW15-371
KW15-553
Die Head size 21/2”~4” for KW15-371
KW15-371
Specification Optional Accessories : for KW15-371

Size inch 1/2 ~ 4
Dies BSPT 1/2 ~ 3/4, 1”~ 2”, 21/2” ~ 4”
Voltage V 220
Speed rpm 10/22
Weight kg 160/140 HSS Dies 21/2” - 4”
Packing Size (L x W x H) mm 950 x 625 x 620 KW02-994
KW1500371 KW15-371 Pipe Threading Machine Dies BSPT 1/2” ~ 4”
OPTIONAL ACCESSORIES FOR THREADING MACHINE
HSS Dies 1” - 2”
HSS Dies 1/2” - 3/4” KW02-993
KW02-992

BENDER MACHINE
BENDER MACHINE
Mild steel capacity inch 8 x 32, 6 x 50, 5/16 x 1-1/4, ‘1/4 x 2
Bending angle 0-200˚
Weight kg 24
Dimensions (L x W x H) mm 880 x 260 x 260
KW15-519
KW1500519 KW15-519 Compact Bender 8 x 32.6 x 50mm with stand
Features:
• Easy and precise operation
• Bending angle up to 120˚
• Extremely high precision of bending within the bending range
• Wide supporting face ensuring safe and reliable operation
• Bending angle of various radiuses by changing and turning
KW1500388 KW15-388 Universal Bender 100 x 15mm
Cold 100 x 5
Flat Steel
Warm 100 x 15
Capacity Round Steel mm 18/30

Square Steel 16 x 16/30 x 30
Angle Steel 60 x 8/100 x 12
KW15-388 Weight kg 32
Dimension Body 390 x 290 x 280

mm
(L x W x H) Handle 720 x 180 x 130
ROUND BENDER MACHINE
Specification
Ring Size Range inch 1 to 3
Round Steel Capacity inch 1/4
Flat Steel Capacity inch 1 to 3/16
Handle inch 13-1/2
N.W./G.W. kg 6/8

KW1500955 KW15-955 Round Bender Machine 1/4”

MULTI PURPOSE METAL CRAFT TOOL AND ELECRIC REBAR BENDER
MULTI PURPOSE METAL CRAFT TOOL
Specification
Features: Punch Capacity flat 3/16”
• Create ornate metal fixture for home, garden or business
• Make plant hangers, candelabras, wire racks and even fenc- 1.18 x 0.20
ing out of mild steel strip Shear Capacity inch 0.236
• Includes scroll former, bender, twister 0.236
• Use up to 3/8” round or square bar in both scroll former and Weight kg 34
bender and up 1-3/6” x 3/16” flat strip in bender and 1” x
1-3/6” flat strip in scroll former Dimension (L x W x H) mm 1070 x 410 x 260
• One tool shears and punches square and rectangular
• Shear round stock too Order No. Type Description
• 1/4” base has four 3/8” mounting hotels
KW1500527 KW15-527 Multi Purpose Metal Craft Tool Set
ELECTRIC REBAR BENDER
Features:
• Simple setting to get prease angle
• Emergency stop for safety precaution

Steel A3 40 50
Max. Bend Diameter mm
Steel ø8 - ø36 ø10 - ø50
Max. Strength mm2 ≤450 ≤450
Working Table (LxW) mm 810 x 710 810 x 710
Motor Power kW/Ph/V 3/3/380 4/3/380
Work Plate Rotational
rpm 8 14
Speed
Electrical Machinery
rpm 1420 1440
Rotational Speed
Dimension (L x W x H) mm 830 × 750 × 750 880 × 780 × 730
Weight kg 310 340

KW1500837 KW15-837 Rebar Bender 40mm
KW1500838 KW15-838 Rebar Bender 50mm

BAR CUTTER
BAR CUTTER
Features:
• Best for cutting square steel, rod steel, flat steel
• It can be used to shear non-ferrous metal or plate and bar
• The machine is operate and carry, light in weight, small in size and
takes the advantage of no power consumption
Blade for bar cutter
Order No. Type Description Order No. Type Description

KW0100737 KW01-737 24mm Bar Cutter 12 x 27 x 24mm KW0101119 KW01-1119 Blade for Bar Cutter 24mm for KW0100737
Capacity Weight Packing Dimension

Type
(mm) (mm) (mm) (kg) L x W x H (mm)
KW01-737 24 35 x 12 20 x 20 31 410 x 370 x 200

KW01-738 28 40 x 12 24 x 24 43 460 x 280 x 430
KW01-739 32 40 X 14 28 x 28 56 520 x 290 x 440
ELECTRIC BAR CUTTER
Features:
• Design to be effident and accurate bar cutting for modern
construction site
• Easy to operated
• Fitted with cast iron wheel so it can be moveable on the site
Blade Accessories
KW1500945 KW15-945 Dies Cutter for KW15-871
Specification
Round Steel
6 ~ 50
Cut off Steel Bar Ø mm (Ub ≤450MPa)
Spiral Steel 6 ~ 38
Continuous Cutting times/min 32
Power Motor kW/HP/Ph 4/2/3
Weight kg 565

KW1500871 KW15-871 Electric Bar Cutter 50mm

SHEAR MACHINE
METAL SHEAR MACHINE
METAL SHEARS
10”
Features:
• Best for cutting metal plate, rod steel, flat steel
6”
• Durable steel frame cutter includes hardened high
carbon steel blade
• Bolt to bench or table top. Blade is easily replaceable

KW0102123 KW01-2123 Metal Shears 6”
KW0102125 KW01-2125 Metal Shears 10”
KW01-2123 KW01-2125
Capacity Weight Dimension

Type
(inch) (mm) (mm) (mm) (kg) L x W x H (mm)
KW01-2123 6” 6 70 X 6 11 13 330 x 160 x 330

KW01-2125 10” 6 70 X 6 13 23 740 x 160 x 440
STEEL SHEAR MACHINE
Max. Capacity Max. Capacity

8 mm 10mm
KW15-398 KW15-399
Specfiication KW15-398 KW15-399

Round Steel mm 16 22
Square Steel mm 16 20
Flat Steel mm 100 x 10 90 x 14
Capacity
Angle Steel mm 40 x 6 60 x 7
T-Steel mm 40 x 6 60 x 7 Order No. Type Description
Steel Plate mm 8 10 Shear for Plate
KW1500398 KW15-398
Weight kg 48 99 Bar and Section Steel, 8mm
Dimension Shear for Plate

mm 680 x 310 x 560 970 x 390 x 650 KW1500399 KW15-399
(L x W x H) Bar and Section Steel, 10mm

SHEAR MACHINE
MULTI PURPOSE SHEAR MACHINE
Max. Capacity 3mm
KW15-403
• Cut various kind of curve required

KW1500403 KW15-403 Multi Purpose Manual Shear , 3mm
Max. Capacity mm 3
Weight kg 22
GUILLOTINE SHEAR MACHINE
Max. Capacity
1.5 x 500mm
Max. Capacity
1.5 x 1000mm
Max. Capacity
1.5 x 800mm
KW15-512
KW15-511
KW15-510
Features: Bed Width Shearing Dimension Weight

Type (mm) Thickness L x W x H (mm) (kg)
• Continuous plate cutting
(mm)
• Knives made of hardened tool steel
• Knife length 500-1000mm
KW15-510 500 1.5 840 x 300 x 740 47
• For plates up to 1-1.5mm KW15-511 800 1.5 1120 x 300 x 740 55
KW15-512 1000 1.5 1380 x 300 x 800 70

KW1500510 KW15-510 Guillotine Shear 1.5 x 500mm

SHEAR MACHINE
SHEAR MACHINE
GUILLOTINE SHEAR
Max. Capacity
1.5 x 1000mm
Adjustable Stopper
Operating System of Spring
Features:
• Continuous plate cutting
• Knives made of hardened tool steel
• Knife length 500-1000mm
• For plates up to 1-1.5mm
Bed Width Shearing Thickness Dimension Weight

Type (mm) (mm) L x W x H (mm) (kg)
KW15-513 1000 1 1550 x 1000 x 580 295

KW1500513 KW15-513 Guillotine Shear 1.5 x 1000mm with Table
FOOT SHEAR MACHINE
Max. Capacity
1.5 x 1320mm
for KW15-495
Max. Capacity
2.0 x 1000mm
for KW15-496
Features:
• Use for mild steel, aluminum, cooper, brass, plastic and leads Specification KW15-495 KW15-496
• High carbon high chrome steel blade
Bed Width mm 1320 1000
• Foot control
Shearing Thickness mm 1.5 2.0
Order No. Type Description Back Gauge Range mm 0 - 840 0 - 840
KW1500495 KW15-495 Foot Shear Machine 1.5 x 1320mm Dimension (L x W x H) mm 1680 x 760 x 1150 1400 x 760 x 1150
KW1500496 KW15-496 Foot Shear Machine 2.0 x 1000mm Weight kg 545 490

ELECTRIC SHEAR MACHINE AND HAND NOTCHER
ELECTRIC SHEAR MACHINE
Max. Capacity
3.0 x 1300mm
Switch Power
KW15-901
Specification
Max. Shearing Thickness mm 3.0
Max. Shearing Width mm 1300
Shearing Angle 2o
No. of Stroke Stroke/minute 20
Input Voltage kW/V/Hz/Ph 3/380/50/3
Back Gauge mm 350
Weight kg 1500

KW1500901 KW15-901 Electric Shearing Machine 3.0 x 1300mm Adjustable Stopper
HAND NOTCHER
Features:
• For mild steel and plate
• Light metal more thickness
• Heavy-duty blade
Specification
Capacity ton 4
Shearing Thickness mm 1.6
Punches mm 152 x 152
90˚ Angle mm 152 x 152
Ram stroke mm 20
Dimension (L x W x H) mm 610 x 570 x 560 Order No. Type Description
Weight kg 85 KW1500389 KW15-389 Hand Notcher 1.6mm x 4ton

HAND BRAKE MACHINE
HAND BRAKE MACHINE
Max. Capacity
1 x 305mm
KW15-497
Max. Capacity
1 x 610mm
KW15-498
Max. Capacity
1.2 x 1300mm
KW15-387
Features:
• Removable finger
• Maximum gauge capacities are applicated when using mild steel.
Using galvanise steel lowers the maximum gauge capacity
• With segmented blade for bending of box sections
• Farious width segment, shiftable setup
Bed Shearing Angle

Width Thickness Dimension Weight
Type (O)
(mm) (mm) L x W x H (mm) (kg) Order No. Type Description
KW15-497 305 1.0 0 - 135 500 x 350 x 410 30 KW1500497 KW15-497 Hand Brake 1.0 x 305mm

HAND BRAKE AND FOLDING MACHINE
HAND BRAKE MACHINE
Max. Capacity
Max. Capacity 1.5 x 1260mm
1.5 x 1220mm
KW15-499 KW15-502
Features:
• Solid machine with stainless steel bending
segment for high precision Max. Capacity
2.5 x 1220mm
• With segment bending blade for the
bending of box section
• Various width segment, shiftable setup
Bed Shearing Angle Dimension

Type Width Thickness (O) Weight (kg)
(mm) (mm) L x W x H (mm)
KW15-499 1220 1.5 0 - 135 1610 x 480 x 680 151

KW15-502 1260 1.5 0 - 135 1670 x 480 x 680 161
KW15-503 1220 2.5 0 - 135 1750 x 770 x 900 580
KW15-503
KW1500499 KW15-499 Hand Brake 1.5 x 1220mm
FOLDING MACHINE
Max. Capacity
2.0 x 1270mm
Features:
• The two Types both has the optional structure of air spring
which can be installed into the arm
• Both the press blade and folding blade is segment structure
Benefit:
• The superflex machine are of a sturdy and fully welded
construction. Foot operated control of the clamp bar ensures
extremely fast and simple operation, and allowes both hands
to be kept free for adjustment of the material being folded.
• The segments can be used from 25mm width up to full working
length with 5mm increments
Specification
Working Length mm 1270
Sheet Thickness mm 2
Max. Clamping Bar Lift mm 48
Folding Angle ˚ 135
Weight kg 385

KW1500504 KW15-504 Folding Machine 2.0 x 1270mm

SLIP ROLL MACHINE
SLIP ROLL MACHINE
Max. Capacity
0.8 x 320mm
Features (KW15-505, KW15-506, KW15-507):

• High strength steel roll
KW15-505 • Top roll swing out
• Lower roll with adjustment lever and cam
Max. Capacity
0.8 x 305mm
Max. Capacity
0.8 x 610mm
KW15-506
KW15-507
Max. Capacity
1.5 x 1300mm Features (KW15-390):
• Maximum gage capaties are applicable
when using mild steel
• Using galvanized steel lowers the
maximum gage capacities
• Cast iron frame
• Quick release top roller
KW15-390
Max. Thickness Max. Width Dia. of roll Dimension Weight

Description
(mm) (mm) (mm) L x W x H (mm) (kg)
KW1500506 0.8 305 25.4 540 x 240 x 280 14.5
KW1500505 0.8 320 32 490 x 230 x 200 13
KW1500507 0.8 610 38 950 x 270 x 380 40
KW1500390 1.5 1300 75 - 220

KW1500506 KW15-506 Slip Roll Machine 0.8 x 305mm

ELECTRIC SLIP ROLL MACHINE
Max. Capacity
1.5 x 1300mm
KW15-508
Max. Capacity
1.5 x 1020mm
KW15-509
Features:
• Asymetrical roll bending machine with 3 rolls
• High strength steel rolls
• Fixed top roller, adjustable lower and rear rollers
• Worm gear and motor for prebending
• Standard series wire core groove
• Hand feed
• Supplied with conical bending feature
Max. Rolling Width Max. Rolling Thickness Dia. of Roller Power Motor Weight Dimension
Type
(mm) (mm) (mm) (kW) (KW/V/Ph) (kg) L x W x H (mm)
KW1500508 1300 1.5 75 1.5 0.75/220/50 420 1900 x 550 x 1100
KW1500509 1020 1.5 60 1.5 0.75/220/50 300 1740 x 700 x 1260

KW1500508 KW015-508 Electric Slip Roll Machine 1.5 x 1300mm, 1.5kW, 1HP
KW1500509 KW015-509 Electric Slip Roll Machine 1.5 x 1020mm, 1.5kW, 1HP

Max. Capacity
3.5 x 1550mm
Operating System
KW15-915
Features:
• Asymetrical roll bending machine with 3 rolls
Limit Switch for Safety • High strength steel rolls
• Fixed top roller, adjustable lower and rear rollers
• Worm gear and motor for prebending
• Standard series wire core groove
• Hand feed
• Supplied with conical bending feature
Max. Rolling Dia. of

Max. Rolling Power Motor Weight Dimension
Type Thickness Roller
Width (mm) (kW) (KW/V/Ph) (kg) L x W x H (mm)
(mm) (mm)
KW15-915 1550 3.5 120 2.2 2.2/380/3 750 2060 x 640 x 1050

KW1500915 KW015-915 Electric Slip Roll Machine 3.5 x 1550mm, 750W, 3HP

SHARE, BRAKE, AND ROLL MACHINE
SHARE, BRAKE, AND ROLL MACHINE
Max. Capacity
1.0 x 305mm
Shear
KW15-493
Max. Capacity
1.0 x 760mm
Break
Max. Capacity
1.0 x 1016mm
for KW15-400
Roll
Max. Capacity
1.0 x 1320mm
for KW15-401
KW15-494
Features:
• Removable male dies with female
• Back gage standard equipment
• With 2 position handle
• Shears cuts mild steel or equivalent
• Press Brake - bends boxes, channels, angles and other complex job
KW15-400 • Sectional fingers allow box and pan works
KW15-401 • Slip Roll-roll provided with forming grooves
Type KW15-493 KW15-494 KW15-400 KW15-401

Bed Width mm (inch) 305 (12) 760 (30) 1016 (40) 1320 (52)
Shearing Thickness mm 1
Bending Thickness mm 1
Bending Angle o 90
Rolling Thickness mm 1
Dia. of Roller mm 38 42 50
Min. Rolling Dia. mm 39 43
Dimension (L x W x H) mm 490 x 330 x 420 970 x 450 x 680 1350 x 450 x 680 1680 x 560 x 750
Weight kg 45 165 212 377

KW1500493 KW15-493 Shear, Brake and Roll Machine 1 x 305mm (12”)

ARBOR PRESS, HAND PUNCHER, AND SHRINKER
ARBOR PRESS with RATCHET WHEEL ARBOR
Aplikasi:
• Assembling component
• Instalation and remove of bearings
Pressure ton 2
Opening mm 180
N.W./G.W. kg 44/46

KW1500956 KW15-956 Arbor Press 2T
KW15-956
Aplikasi:
• Assembling component
• Instalation and remove of bearings
Pressure ton 3
Opening mm 280
N.W./G.W. kg 58/60

KW1500957 KW15-957 Arbor Press 3T
KW15-957
HAND PUNCHER
Features:
• Round, deep-hole, square or similar stamps
• Easy quick stamp sand stencil replacements
• Swing 160mm
• Stamp 75 x 2
• Stencil 34 x 34 x 16mm
• Length 440 height 800mm
• Stencil series (extra cost)
• The metric system (mm) : 3,4,5,6,7,8,9,10,11,12, 13,14,15
• The inch system (inch) : 1/8”, 3/16, 1/4”, 5/16”, 3/8”, 7/16”, 1/2”, 9/16”, 5/8”
Specification
Max. Punching Capacity mm 8 (thick)
Throat Depth mm 160
Punch Mold and Die mm 55 x 34 x 18
Weight kg 80
Body mm 520 x 230 x 920
Dimension (L x W x H)
Handle mm 1840 x 45 x 80

KW1500516 KW15-516 Hand Puncher 8mm

ROTARY MACHINE
MANUAL ROTARY MACHINE
Include Accessories
DIES SET FOR KW15-526
Features:
• Complete with five sets of rolls wiring
crimping single bead and bellow edging will
perform numberous operations
• Clamp-on offset base
• 50mm distance between shaft center
Specification
Capacity mm 0.8
Depth mm 177
Weight kg 24

KW1500526 KW15-526 Manual Rotary Machine 0.8mm
ELECTRIC ROTARY MACHINE
Features :
• Dilengkapi dengan 3 set roller
• Membuat lipatan pada plat
Specification Motor Power

Capacity mm 1.8
Throat Depth mm 238
N.W./G.W. kg 220/252
Motor Power W/Ph/V 1.5/3/380

KW1500960 KW15-960 Electric Rotary Machine 1.8mm

PACKAGING MACHINE
VACUUM PACKAGER
PLASTIC WRAPPING
Application Specification
Power Supply V/Hz 220/50-60
Heat Cut Length mm 32
Roller Width mm 452
Heat Shrinking Plate mm 385 x 123
Weight kg 6.5

KW1500973 KW15-973 Hand Wrapping Machine 450mm
KW15-973
Application
Specification
Cord Diameter mm 38/76

KW1500974 KW15-974 Hand Stretch Wrapper 38mm
KW15-974
LOCKING AND CAPPING

Specification
Type KW15-1019 KW15-1020
Power Supply Ph/V/Hz 1/110-220/ 1 / 110-220 /
50-60 50-60
Power kW 0.37 0.37
Diameter Suitable mm 20-40 15-46
Sealing Width mm 10-35 7-45
Height of Bottle mm 100-300 50-320
Sealing Speed bottle/hr 1200 1200
Type of Cover Plastic cover Metal cover
Machine Size (L x W x H) mm 560 x 200 x 920 560 x 200 x 900
Weight kg 65 68

Locking and Capping Machine Plastic
KW1501019 KW15-1019
Cap Model 20-40mm
Locking and Capping Machine Metal Cap
KW1501020 KW15-1020
Model 15-46mm
KW15-1020
KW15-1019

PACKAGING MACHINE
VACUUM PACKAGER
Application
Specification
Type KW15-998
Power Supply V/Hz 220/50
Vacuum Mpa 0.35
KW15-998
Sealing Length mm 40-280
Order No. Type Description Machine Size (L x W x H) mm 350 x 140 x 70
KW1500998 KW15-998 Mini Vacuum Packager 280mm Weight kg 2.4
Application Feature:
This package is set with the fuction of combining vacuum, sealing, peinting in one process
and for different packing materials and requirements, with the adjustable devices for the
vacuum, hot sealing temperature and time so as for the users to get optimum selection and
adjustment for an optimum effect of packing.
The printing device with a convenient letter-change and clear printing is available per the
desire of the users, with which, users may print on the sealing at the same time for sealing
the valid period, date of ex-factory, code of ex-factory, etc.
Benefit:
The package features advanced design,full function,stable and reliable performance,good
sealing strength,strong packing capacity,conveninient operation and service,high economic
benefif,etc
KW15-975
Specification
Type KW15-975 KW15-976
Chamber Size mm 385 x 280 x 50 440 x 420 x 75
Single Sealing-Bar mm 260 x 8 400 x 10
Cycle Time sec 10-20 10-25
Capacity m³/h 10 10
Voltage Ph/ V/Hz 1/220/50 1/220/50
Power kW 0.4 0.9

KW1500975 KW15-975 Automatic Vacuum Packager 330 x 260mm
KW15-976
Double Sealing Bar by Request KW1500976 KW15-976 Automatic Vacuum Packager 400 x 335mm
Specification
Type KW15-999 KW15-1000
Double Sealing-Bar mm 500 x 10 500 x 10
Capacity m3/h 20 20
Voltage Ph/V/ Hz 1/220/50 1/220/50
Power kW 0.9 0.9
KW15-999 Machine Size (L x W x H) mm 630 x 620 x 460 630 x 620 x 460
KW15-1000 Application
Double Sealing Bar by Request
KW1500999 KW15-999 Automatic Vacuum Packager 500 x 445mm
KW1501000 KW15-1000 Automatic Vacuum Packager 500 x 445mm Gas-Flush

PACKAGING MACHINE
VACUUM PACKAGER
Specification
Type KW15-1001 KW15-1002
Capacity m3/h 20 20
Voltage Ph/V/Hz 1/220/50 1/220/50
Power kW 0.9 0.9
Application
KW15-1001 Automatic Vacuum Packager 400 x 335mm High
KW1501001 KW15-1001
KW15-1002 Table
Double Sealing Bar by Request Automatic Vacuum Packager 400 x 335mm High
KW1501002 KW15-1002
Table Gas-Flush
Specification
Type KW15-1003 KW15-1004
Double Sealing-Bar sec 500 x 10 500 x 10
Cycle Time mm 10-30 10-30
Capacity m3/h 20 20
Voltage Ph/V/Hz 1/220/50 1/220/50
Power kW 0.9 0.9
Application
KW1501003 KW15-1003 Automatic Vacuum Packager 500 x 445mm High Table
KW15-1003
KW15-1004 Automatic Vacuum Packager 500 x 445mm High Table
KW1501004 KW15-1004
Gas-flush
Double Sealing Bar by Request
Specification
Type KW15-1005 KW15-1006
Double Sealing-Bar sec 600 x 10 600 x 10
Cycle Time mm 10-35 10-35
Capacity m3/h 20 20
Voltage Ph/ V/Hz 1/320/50 1/320/50
Power kW 1.5 1.5
Application
KW15-1005 KW1501005 KW15-1005 Automatic Vacuum Packager 600 x 545mm High Table
KW15-1006
Automatic Vacuum Packager 600 x 545mm High Table
Double Sealing Bar by Request KW1501006 KW15-1006
Gas-flush

PACKAGING MACHINE
VACUUM PACKAGER
Specification
Type KW15-1007 KW15-1008
Capacity m /h 3
2 x 20 2 x 20
Voltage Ph/V/ Hz 3/380/50 3 /380 / 50
Power kW 1.5 1.5
KW15-1007
KW15-1008 Specification
KW15-1009 Type KW15-1009 KW15-1010
KW15-1010
Cycle Time sec 10 - 40 10 - 40
Capacity m /h 3
2 x 20 2 x 20
Voltage Ph/V/Hz 3/380/50 3/380/50
Power kW 3.2 3.2
Application
KW1501007 KW15-1007 Automatic Vacuum Packager 520 x 410mm Double Chamber
KW1501008 KW15-1008 Automatic Vacuum Packager 520 x 410mm Double Chamber Gas-Flush
KW1501009 KW15-1009 Automatic Vacuum Packager 620 x 410mm Double Chamber
KW1501010 KW15-1010 Automatic Vacuum Packager 620 x 410mm Double Chamber Gas-Flush
Specification
Type KW15-1011 KW15-1012
Capacity m /h
3
63 63
KW15-1011 Voltage Ph/V/Hz 3/380/50 3/380/50

KW15-1012 Power kW 2.2 2.2
Application
Automatic Vacuum Packager 800 x 600mm
KW1501011 KW15-1011
Double Chamber
Automatic Vacuum Packager 800 x 600 Double
KW1501012 KW15-1012
Chamber Gas-flush

STRAPPING MACHINE AND PRESSURE TEST PUMP
STRAPPING MACHINE
Electric
STRAPPING MACHINE
KW15-426
KW15-289
KW15-290
Specification
Type KW15-426 KW15-289 KW15-290
Power W/V/Hz 150/220/50 150/220/50
Min. Packing Size mm 40 x 60 30 x 60
Max. Packing Weight kg 20 100
Max. Binding Force N 40 > 450
Binding Ability Sec/Strap 2.4 < 4.5
Polypropylene mm Width < 8 Width < 14
Band Spec. mm Thickness = 0.6 Thickness = 0.8
Strapping Band Include Optional
Working Table Height mm 200 480 780
Work Bench Area mm 450 x 350 900 x 580
Overall Size (L x W x H) mm 700 x 335 x 200 1500 x 580 x 480 900 x 580 x 780
Weight kg 20 90 100

KW1500426 KW15-426 Table Strapping Machine 200mm
KW1500289 KW15-289 Auto Strapping Machine 480mm Mid Table
KW1500290 KW15-290 Auto Strapping Machine 780mm High Table

STRAPPING MACHINE
PLASTIC STRAPPING
Specification
Type KW15-1016
Strapping Tension Adjustable N 100 - 700
Strapping Speed sec/strap 2.0
Strap Width mm 9-15
Arch Size mm 1000
Power Supply V / Hz 220 / 50-60
Power Consumption kVA 0.5
Machine Size (L x W x H) mm 1860 x 560 x 1500
Weight kg 140

KW15-1016 KW1501016 KW15-1016 Automatic Strapping Machine Width 12mm, for Pallet
Specification
Application Type KW15-1017 KW15-1018

Max. Strapping Tension N 259 259
Strap Witdh mm 19 25

KW15-1018 KW1501017 KW15-1017 Pneumatic Strapping Machine Width 19mm
KW1501018 KW15-1018 Pneumatic Strapping Tools Width 25mm
Specification
Max. Strapping Tension 259
Strap Witdh mm 19

KW15-1013 KW1501013 KW15-1013 Melt Electric Strapping Tools 19mm
Specification
Model KW15-1014 KW15-1015
Strapping Tension
N 40-700 40-700
Adjustable
Strapping Speed sec/strap 2.0 2.0
Strap Width mm 8-19 5-12
Arch Size mm 800 x 600 800 x 600
Power Supply V / Hz 380/50-60 220/50-60
KW15-1014 Power Comsumption kVA 0.85 0.5

Weight kg 250 220

Semi Automatic Strapping Machine
KW1501014 KW15-1014
Width 8 -19mm Stand Model
Automatic Strapping Machine
KW1501015 KW15-1015
Width 5 - 12mm Stand Model
KW15-1015

PRESSURE TEST PUMP
PRESSURE TEST PUMP
KW15-239, KW15-240
KW15-241
Features:
• Suppress quick
• Convenient
• Pressure stability
• Simple operation
KW15-952
Application:
• Pressure tank testing
• Leakage test on piping
- Strength of hose rubber testing
Flow Motor Dimension

Pressure Weight (L x W x H)
Type Volume Power
(MPa) (NW/GW)
(ml) (kW/A/Ph) Unit (mm) Tank (mm)
KW15-239 15 20 - 8/10 430 x 200 x 510 370 x 180 x 240
KW15-240 24 20 - 10/12 460 x 210 x 550 400 x 200 x 280
KW15-241 25 40 1.5/9.75/1 30/40 800 x 470 x 800 740 x 360 x 330
KW15-952 16 20 - 6/6.5 310 x 200 x 310 310 x 200 x 200

KW1500239 KW15-239 Pressure Test Pump Manual 15MPa
KW1500241 KW15-241 Pressure Test Pump 25Mpa Electric 220V

SYMBOL AND ABBREVIATIONS
Symbol or
Unit SI unit Conversion Factor Phisical Quantity Comment
Abbreviation
Ampere-hour Ah 3,6 x 103C (Exact) Quantity of electricty Used for storage batteries
Angstrom A 10-1om (Exact) Length Wavelength, atomic distance
Bar bar 105Pa (Exact) Pressure Fluids
Barrel (US) bbl 0.158,987,3m3 Volume 1 barrel (US) = 42 gallons (US)
Calorie I.T cal 4.186.8J (Exact) Energy Quantity of heat
Candela cd Basic SI unit Luminous intensity
Chavel vapeur (horsepower) ch 735.498,75W (Exact) Power 1ch = 75kgm/s (exact)
Degree o
1.745,329 x 10-2 rad (2/360rad) Angle
The origin of the Celcius scale is set
Degree Celsius o
C Tk = 0OC+273.15 (Exact) Temperature
by convention at 273.15K
Degree Fahrenheit o
F Tk = 5/9 (0oF+459.67) (Exact) Temperature 0oC = 5/9 (0oF-32) (exact)
Electronvolt eV 1.602,177,33 x 10-19J Energy Atomic and nuclear Physics
Farad F Derived SI unit 1F = 1C/V Electric capacitance
Faraday 9.648,70 x 10-4C Quantity of electricity Based on carbon 12
Fluid Ounce (UK) fl oz (UK) 2.841.30 x 10-5m3 Volume
Fluid Ounce (US) fl oz (US) 2.957,35 x 10-5m3 Volume Liquids
Foot ft 30,48cm (Exact) Length The symbol ‘ is also used
Gallon (UK) gal (UK) 4.546,09 x 10-3m3 Volume
Gallon (US) gal (US) 3.785,41 x 10-3m3 Volume Liquids
Hertz Hz Derived SI unit 1Hz = 1s-1 Frequency
A
Horsepower (UK) hp 745.700W Power
The US value of horse power varies
according to the field
B
Inch in 2.54cm (Exact) Length The symbol ‘ is also used B
S Joule
Kelvin
J
K
Derived SI unit
Basic SI unit
Energy
Temperature
Work, quantity of heat
Thermodynamics
R
Y Kilogram-meter kgm 9.806,65J (Exact) Work E
M Kilogram-force
Kilowatt-hour
kgf
kWh
9.806,65N (Exact)
3.6 x 10-6J (Exact)
Force
Energy Electrical energy consumption
V
B Liquid pint (US) liq pt (US) 4.731,76 x 10-4m3 Volume Liquids I
O Liquid quart (US)
Litre
liq pt
I, L
4.463,529 x 10-4m3
10-3m3 (Exact)
Volume
Volume
Liquids
C.G.P.M. 1964
A
L Lux lx Derived SI unit 1xl = 1lm/m2 Illumination T
S Micron
Mile
µ
mile
10-6m (Exact)
1.609,344 x 103m (Exact)
Length
Length
Replaced by micrometer
Also called “statute mile”
I
International nautical mile 1.852 x 103m (Exact) Length Sea and air navigation O
Milimetre of mercury
(conventional)
mmHg 133.322,4Pa Pressure Equal to 13.595,1 mmH20 (exact) N
Nautical mile (UK) 1.852 x 103m (Exact) Length
Since1970, the UK nautical mile is equal
to the international nautical mile
S
Newton N Derived SI unit 1N = 1kg.m.s-2 Force
Ohm Ω Derived SI unit 1Ω = 1V/A Electrical Resistance
Ounce oz 28.349,5gr Mass 16oz + 1lb
Pascal Pa Derived SI unit 1Pa = 1N/m2 Pressure, stress
Pound lb 0.453,592,37kg (Exact) Mass
Pound-force lbf 4.448,22N Force
Abbreviation of “poundforce per
Psi psi 6.894,757 x 103Pa Pressure
square inch”.
The symbol rd has also been used
Radian rad Drived SI unit 1m/m Angle (plane)
in France
Second s Basic SI unit Time
Torr torr 133.322,4Pa Pressure 1/760 normal atmosPhere (exact)
Volt V Derived SI unit 1V = 1W/A Electrical Potential
Voltampere VA 1W (Exact) Apparent Electricity
Watt W Derived SI unit 1W = 1J/s Power
Watthour Wh 3600J (Exact) Energy Electrical energy consumption
Weber Wb Derived SI unit 1Wb = 1V.s Magnetic Induction
Yard yd 0.914,4m (Exact) Length

Untitled

Uploaded by

Document Information

Original Description:

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Untitled

Uploaded by

Copyright:

Available Formats

HACK SAW MACHINE AND BAND SAW MACHINE

Order No Type Description

HORIZONTAL HACK SAW MACHINE

Cutting Cap. Saw Size

Order No. Type Description

BAND SAW MACHINE

Cutting Cap. Feature:

Order No. Type Description

www.krisbow.com Machinery 405

Specification KW15-52 KW15-53

Order No. Type Description

406 Machinery www.krisbow.com

Order No. Type Description

OPTIONAL ACCESSORIES FOR KW15-52, KW15-53, KW15-55 AND KW15-458

Coolant System For All Machine Coolant Pump Kit

www.krisbow.com Machinery 407

Order No. Type Description

Order No. Description Size Order No. Description Size

HOLE CUTTING DRILL

Order No. Type Description

408 Machinery www.krisbow.com

4 Speed 1 Speed 2 Speed

Drill Chuck and Arbor Coolant Tank Key Chuck Cover

Optional no.3 morse taper accessories available for tapping up to 25mm,

Standard Accessories for KW15-382 Handle

OPTIONAL ACCESSORIES FOR KW15-380,

Core Drill Center Pin

www.krisbow.com Machinery 409

Max. Twist Drill Max. Twist Drill Max. Drill

Specification KW15-538 KW15-539 KW15-540

Swing 340mm Swing 430mm Swing 515mm

Specification KW15-541 KW15-542 KW15-543

Order No. Type Description Order No. Type Description

410 Machinery www.krisbow.com

Features: Order No. Type Description

Order No. Type Description

www.krisbow.com Machinery 411

KW15-868 KW15-869 KW15-870

Include 1 set Include 1 set

Order No. Description

Specification KW15-868 KW15-869 KW15-870

412 Machinery www.krisbow.com

Order No. Type Description

www.krisbow.com Machinery 413

Working Capacity KW15-10 Working Capacity KW15-46

Specification KW15-10 KW15-46

Order No. Type Description

414 Machinery www.krisbow.com

Max. Drill Max. Drill

Specification KW15-47 KW015-260 Features for KW15-47:

Order No. Type Description

www.krisbow.com Machinery 415

Steel Clamping Kit

416 Machinery www.krisbow.com

OPTIONAL ACCESSORIES FOR MILLING MACHINE

NT30 ER32 NT 40 ER 32 BT 30-60L ER 32 BT 40-70L ER 32

www.krisbow.com Machinery 417

Order No. Type Description

418 Machinery www.krisbow.com

Order No. Type Description

www.krisbow.com Machinery 419

Order No. Type Description

420 Machinery www.krisbow.com
