Switchgear Components

N O R T H A M E R I C A N ( U L / C S A )
SWITCHGEAR COMPONENTS
SOCOMEC POWER CONTROL & MANAGEMENT,
Listening to
our customers...
Teams of specialised designers, a highly integrated pro-

duction and a dedicated sales network have led the
SOCOMEC group to develop the most extensive ranges
on the market for high-quality low-voltage industrial
switching & protection components.
Our ‘Control & Protection Systems’ division is today

centred on three distinct fields :
- low-voltage SWITCHGEAR components
- electronic CONTROL & PROTECTION
- mounting & cabling, and integrated

distribution SYSTEMS
Our solutions are in permanent evolution thanks to our

customer contact, and are backed up by substantial R&D
resources.
For over 75 years our customer-partners have recognised

the quality of our products, our attentiveness and adapta-
bility to their requirements as well as our close involvement.
An independant manufacturer
SOCOMEC is an independent group employing over
1200 people and has a turnover in the region of 130 million
Euros (150 million $).
A global presence ensures that SOCOMEC is always on

hand.
F ounded in 1894, Underwriters Laboratories Inc. (UL)

is chartedred as a not for profit, independent organiza-
tion testing for public safety. It maintains and operates
laboratories for the examination and testing of devices,
CORPO 023A
systems ans materials to determine their relation to life,

fire, casualty hazards and crime prevention.
Three factories The UL standards are very different of the international
in France (Alsace), standards.
and another one in Italy
Even if the products must not necessary be listed or
recognized UL to be sold in the USA , it is almost impos-
sible to sell them without the UL mark.
WHEREVER IT’S NEEDED
Summary
LBS Load Break Disconnect Switches

from 16 to 100 A - UL 508
• Generalities p. 4
• Product features p. 5
• Switch body / rotary operation p. 6
• Handles and schafts p. 7
• Technical characteristics p. 8
• Dimensions p. 9
SIRCO Non-Fusible Disconnect Switches
from 30 to 1200 A - UL 98
• Switch body p. 10
• Handles and schafts p. 11-12
• Accessories p. 13
• Technical characteristics p. 14-15
• Dimensions p. 16 to 19
FUSERBLOC Fusible Disconnect Switches
from 30 to 800 A - UL 98
• Switch body with
standard operation (ON-OFF) p. 22
• Switch body with
Test-Position (ON-OFF-TEST) p. 23
• Handles and schafts p. 24-25
• Accessories p. 26-27
• Technical characteristics p. 28-29
• Dimensions p. 30 to 33
• SOCOMEC it’s also… p. 34 to 35
A complete range of IEC products
3
LBS & SIRCO NON-FUSIBLE DISCONNECT SWITCHES FROM 16 TO 1200 A
GENERALITIES
The SIRCO is a multipolar manually

DEFINITION AND FUNCTION operated disconnect switch. It is based COMPOSITION OF THE RANGE
on the most up-to-date disconnect
The LBS load break Disconnect LBS:
switch technology available. Designed
Switches have been designed around
around North American standard UL98 it • 3 frame sizes to cover the range from
North American standard UL508 for
gives you a product that “makes and 16 to 100 A - 600 V
today’s industrial control systems. The
breaks” power circuits on load. • 3 pole switches as standard
switch line has been designed for base
The switch line is tested and approved • 4 pole version on request
mounting, DIN Rail mounting.
for use in the most stringent application • Rotary as standard or toggle available
Cable clamps integrated to the switch
such as “Service Entrance”. • Direct handle & external front operation
accept copper cable.
Complete ranges of IEC Non Fusible • Base mounting or DIN Rail mounting
Disconnect Switches are available from
20 to 4000 A. SIRCO:
• 9 ratings from 30 to 1200 A
• Various operations:
- External front
- Direct
• Visible blade up to 200 A
• Test function available up to 200 A
WELDED CONTACT PROTECTION

In case of welded contacts due to an
overload or short circuit, the switch will
not reach the OFF position unless the
contacts are truly open.
CLEAR POSITION INDICATION

All switches and handles have clear ON
SIRCO 84A
and OFF designation.
CONFORMITY TO STANDARDS
LBS:
• UL508 as Motor Controller (UL Files
E 164205)
Switch & general Purpose Switch
• IEC 60 947-3 as Load Break
Disconnector
• CE Mark
SIRCO:
• UL98 (UL Files E201138)
• CSA 22.2 No.4 CSA Files
LR 112964-2-3-4
• IEC 60 947-3
• CE Mark
4
PRODUCT FEATURES
A COMPLETE RANGE OF HANDLES

The LBS and SIRCO series offers a full
line of Nema/IP rated handles.
Nema rating 1,3R, 12, 4 and 4X
All external handles are available in two
colors (black and red/yellow).
Handles offer the user the largest
COMO 67A
COMO 68A
COMO 64A
SIRCO 83A
selection of option in operating the
switch:
Standard configuration:
ON/OFF (2 positions)
Test configuration:
ON/OFF/TEST (3 positions)
(Test configuration is available, for
SIRCO 30 to 200 A).
FAST AND SAFE COMMISIONING

(For SIRCO 30 to 200 A)
The TEST facility enables testing of the
control circuit auxiliaries without
switching the main contacts.
This function provides a serious
SIRCO 85A
technical and commercial alternative

to a separately wired push buttom.
1x 2x 3x
PADLOCKING
maxi. ø 5 in / 8 mm
16
Handles can be padlocked in the OFF
position with up to 3 padlocks. Meets
OSHA requirement for lockout/tagout
SIRCO 86A
procedures.
For safety reasons, the door can not be
opened when the handle is padlocked.
DOOR INTERLOCK IN ON POSITION

The handles allow opening of door in the
OFF position only.
In the ON position the door can not be
opened.
This interlocking can however be by-
SIRCO 87A
passed by authorized personal (defeater

option on handle) for maintenance,
testing or commisioning.
DEFEATER
The defeat function allows qualified
personal to by-pass the door interlock
when the switch is in the ON position by
SIRCO 88A
means of a tool.
This exclusive design is also available in
a 4 and 4X rating.
5
LBS LOAD BREAK DISCONNECT SWITCHES FROM 16 TO 100 A
PLEASE SELECT ONE OF EACH
1 SWITCH
+ 1 SHAFT EXTENSION
+ 1 EXTERNAL HANDLE
COMO 65A
LBS M 16 Shaft 7,9 inches/200 mm Black handle

ref 2411 3U00 ref 2499 1U20 ref 2109 0U14
SWITCH BODY/ROTARY OPERATION

LBS M
LBS M 16 TO 25 A
Maximum horse power rating
Type Amps No. of Three Phase Test function Reference
Poles 240 V 480 V 600 V
LBS M 16 3 3 7.5 10 No 2411 3U00
LBS M 25 3 5 10 15 No 2411 3U02
LBS R 30 TO 100 A
COMO 59/61/63A

Poles 240 V 480 V 600 V
LBS R1 30 3 7.5 15 25 No 2101 3U03
LBS R LBS R1 40 3 10 20 30 No 2101 3U04
LBS R2 60 3 15 30 40 No 2101 3U06
LBS R2 80 3 20 40 50 No 2101 3U08
LBS R2 100 3 25 50 60 No 2101 3U10
6
HANDLES AND SHAFTS
FOR LBS M-LBS R

Selector handles type M
Nema IEC Defeatable Padlockable Color Operation Reference
Type Type
COMO 60A
COMO 67A
1,3R, 12 IP65 No Yes Black On/Off & O/l 2109 0U14
1,3R, 12 IP65 No Yes R/Y On/Off & O/l 2109 0U13
5 mm x 5 mm Shaft - for use with selector handles type M

Shaft length Reference
(inches/mm)
COMO 71A
7.9/200 2499 1U20
12.6/300 2499 1U30
Pistol handles type D2

Type Type
1,3R, 12 IP54 No Yes Black On/Off & O/l 3729 7015
1,3R, 12 IP54 No Yes R/Y On/Off & O/l 3729 7017
COMO 68A
COMO 62A
1,3R, 12 IP54 Yes Yes Black On/Off & O/l 3729 7026
1,3R, 12 IP54 Yes Yes R/Y On/Off & O/l 3729 7028
5 mm x 5 mm Shaft - for use with pistol handles type D

(inches/mm)
7.9/200 379D 0520
COMO 72A
12.6/320 379D 0532

15.7/400 379D 0540
Pistol handles type G1

Type Type
4,4X IP65 Yes Yes Black On/Off & O/l 3729 7056
4,4X IP65 Yes Yes R/Y On/Off & O/l 3729 7058
COMO 64A
COMO 69A
4,4X IP65 Yes Yes Black Test On, Off 3729 8056
4,4X IP65 Yes Yes R/Y Test On, Off 3729 8058
5 mm x 5 mm Shaft - for use with pistol handles type G

(inches/mm)
7.9/200 379G 0520
12.6/320 379G 0532
COMO 70A
15.7/400 379G 0540
OTHERS OPTION MODELS AND ACCESSORIES AVAILABLE ON REQUEST

• 4 pole switches
• Door mounted switches
• Toggle version (LBS T 30 to LBS T 80)
• LBS R 125 A (availability to be
announced upon request)
• Neutral modules
• Direct handle
• DIN escutcheon for LBS R and LBS T
COMO 66A
version
LBS 12A
• Auxiliary contact
7
LBS LOAD BREAK DISCONNECT SWITCHES FROM 16 TO 100 A
UL AND CSA TECHNICAL CHARACTERISTICS
LBS M LBS R
2411 3U00 2411 3U02 2101 3U03 2101 3U04 2101 3U06 2101 3U08 2101 3U10
Rating (3 poles) 16 A 25 A 30 A 40 A 60 A 80 A 100 A
UL approval UL508 UL508 UL508 UL508 UL508 UL508 UL508
Short-circuit rating kA 5 5 10 10 10 10 10
- Fuse type RK5 RK5 RK5 RK5 RK5 RK5 RK5
- Fuse rating (A) 30 30 80 80 150 150 150
Maximum UL Horsepower220-240 V AC 3 5 7.5 10 15 20 25
ratings (3-ph) 440-480 V AC 7.5 10 15 20 30 40 50
600 V AC 10 15 25 30 40 50 60
Maximum UL Horsepower 120 V AC 1 1.5 2 2 3 5
ratings (1-ph) 240 V AC 2 3 5 5 10 15 15
Electrical endurance (operation cycles) 6000 6000 6000 6000 6000 6000 6000
Mechanical endurance (operation cycles) 6000 6000 6000 6000 6000 6000 6000
Terminal lugs Wire size #6-#10 #6-#10 #14-#8 #14-#8 #14-#3 #14-#3 #14-#3
Wire type Cu Cu Cu Cu Cu Cu Cu
Weight (lb) .32 .32 .44 .44 .66 .66 .66
IEC TECHNICAL CHARACTERISTICS
LBS M LBS R
2411 3U00 2411 3U02 2101 3U03 2101 3U04 2101 3U06 2101 3U08 2101 3U10
THERMAL CURRENT Ith (40 °C) 16 A 25 A 32 A 40 A 63 A 80 A 100 A
RATED INSULATION VOLTAGE Ui (V) 800 800 690 690 690 690 690
RATED IMPULSE WITHSTAND Uimp (kV) 8 8 8 8 8 8 8
OPERATIONAL CURRENT (A) 3 poles 3 poles 3 poles 3 poles 3 poles 3 poles 3 poles
400 V AC AC 22 A 16 25 32 40 63 80 80
AC 23 A 16 25 25 25 63 63 63
500 V AC AC 22 A 16 25 32 40 63 80 80
AC 23 A 16 20 25 25 45 45 45
690 V AC AC 22 A 16 25 32 40 63 80 80
AC 23 A 16 20 25 25 40 40 40
MOTOR POWER (kW)
400 V AC - AC 23 5.5 7.5 11 11 25 25 25
500 V AC - AC 23 7.5 9 15 15 25 25 25
690 V AC - AC 23 9 11 15 15 25 25 25
OVERLOAD CAPACITY
Short circuit current with fuses (kA rms) 50 50 50 50 50 50 50
Maximum rating for associated fuses gG (A) 16 25 32 40 63 80 80
Cut-off current (kA peak) 5.9 5.9 5 5 8 8 8
Short time withstand current Icw 1 s (kA) 1.2 1.2 1 1 11/2 11/2 11/2
WITHSTAND
Mechanical 100 000 100 000 20 000 20 000 20 000 20 000 20 000
Electrical 400 V AC 23 1 500 1 500 5 000 5 000 1 500 1 500 1 500
CONNECTION
Cu (mm2) 11/2 to 6 11/2 to 6 11/2 to 16 11/2 to 16 11/2 to 35 11/2 to 35 11/2 to 35
8
DIMENSIONS
LBS M LBS 16 TO 100 A

D A
55 / 2.17 J LBS R1
D E
67.5 / 2.66
62.5 / 2.46
1.5
38
E 8.5
2 / 0.08 J
0.34
LBS 14 A
1.26
L
32
1L1 3 L2 5 L3
45 / 1.77
D
B
K
A
58 / 2.28 LBS R2
J
E
LBS 13 A
2 T1 4 T2 6 T3
A
8.5
LBS 15 A
0.34
B
L
A B D E J K L
RATING
mm in mm in mm in mm in mm in mm in mm in
LBS M 16 A
36 1 5/12 80 3 3/20 70.0 2 65/86 44.5 1 3/4 22 13/15 74 2 21/23 – –
LBS M 25 A
LBS R1 30 A
51 2 70 2 65/86 68 2 21/31 42 1 17/26 48 1 8/9 – – 4.2 1/6
LBS R1 40 A
LBS R2 60 A
LBS R2 80 A 53 2 2/23 85 3 9/26 73 2 7/8 43 1 9/13 52 2 1/21 – – 4.2 1/6
LBS R2 100 A
HANDLES SELECTOR HANDLE TYPE M PISTOL HANDLE TYPE D2
62 12.4
DOOR DRILLING
2.44 0.49
2.58 1.83 1 8"
65.5 46.5 2 ø 4.5
11 4"
ø 31
2.44
62
2"
50 -OFF
COMO 87 A
2.48
63
SIRCO 113 A
COMO 75 A
90°
17.5 8 -ON
0.69 0.31
38
1.5
1 16"
PISTOL HANDLE TYPE G1
ø 2.2
DOOR DRILLING
5 8"
16
COMO 89 A
2.87 2.75 1 8" 2"

73 70 50
4 ø 4.5 TEST POSITION
7 8"
65°
ø 23
o -OFF
50
2"
2.78
70.5
SIRCO 112 A
COMO 74 A
11 4" 90°
ø 31
MOUNTING DEPTH (mm/in) -ON
HANDLE TYPE M HANDLE TYPE D HANDLE TYPE G

mm in mm in mm in
h LBS M 16-25 A 76 3 96 3 46/59 96 3 46/59
COMO 90 A
LBS R1 30-40 A 76 3 96 3 46/59 96 3 46/59

LBS R2 60-100 A 83 3 3/20 100 3 15/16 100 3 15/16
9
SIRCO NON-FUSIBLE DISCONNECT SWITCHES FROM 30 TO 1200 A
1 SWITCH
+ 1 SHAFT
+ 1 HANDLE
+ IF NEEDED, 1 LUGS KIT
SIRCO 89A
SIRCO 90A
SIRCO 83A
SIRCO 91A
SIRCO 800 Shaft 7,9 inches/200 mm Black handle Terminal lugs kit
ref 2700 3080 ref 379H 1520 ref 3729 7145 ref 3954 6120
Line side shrouding are supplied as standard
SWITCH BODY
SIRCO V 30 A
SIRCO 92A
Poles 240 V 480 V 600 V

SIRCO V 30 3 7.5 15 20 Yes* 2700 3003
*Test function is available as standard but it can only be active with test handle.
SIRCO V 60 TO 200 A
Poles 240 V 480 V 600 V
SIRCO 95A
SIRCO V 60 3 15 30 50 Yes* 2700 3006

SIRCO V 100 3 30 60 75 Yes* 2700 3010
SIRCO V 200 3 60 125 150 Yes* 2700 3020
*Test function is available as standard but it can only be active with test handle.
SIRCO 400 AND 1200 A

Poles 240 V 480 V 600 V
SIRCO 400 3 200 400 350 No 2700 3040
SIRCO 600 3 200 400 350 No 2700 3060
SIRCO 93A
SIRCO 800 3 250 500 500 No 2700 3080

SIRCO 1000 3 250 500 500 No 2700 3100
SIRCO 1200 3 250 500 500 No 2700 3120
10
HANDLES AND SHAFTS
FOR SIRCO V 30 A
Type Type
COMO 60A
1,3R, 12 IP65 No Yes Black On/Off & O/l 2109 0U14
COMO 67A
1,3R, 12 IP65 No Yes R/Y On/Off & O/l 2109 0U13

(inches/mm)
7.9/200 379M 0520
COMO 71A
12.6/320 379M 0532
15.7/400 379M 0540

Type Type
1,3R, 12 IP54 No Yes Black On/Off & O/l 3729 7015
1,3R, 12 IP54 No Yes R/Y On/Off & O/l 3729 7017
COMO 68A
COMO 62A

(inches/mm)
7.9/200 379D 0520
COMO 72A
12.6/320 379D 0532

15.7/400 379D 0540

Type Type
COMO 64A
COMO 69A

COMO 70A
(inches/mm)
7.9/200 379G 0520
12.6/320 379G 0532
15.7/400 379G 0540
11
SIRCO NON-FUSIBLE DISCONNECT SWITCHES
FROM 30 TO 1200 A
HANDLES AND SHAFTS (cont.)
FOR SIRCO V 60 TO 100 A
Type Type
COMO 64A
FOR SIRCO V 200 A

Type Type
COMO 64A
4,4X IP65 Yes Yes Black Test, On,Off 3729 8076
4,4X IP65 Yes Yes R/Y Test, On,Off 3729 8078
10 x 10 mm Shaft - for use with pistol handles type G

(inches/mm)
7.9/200 379G 1020
12.6/320 379G 1032
15.7/400 379G 1040
COMO 70A
FOR SIRCO 400 TO 1200 A

Pistol handles - for use with shaft type H
Type Type
1,3R, 4,4X, 12 IP65 No Yes Black On/Off & O/l 3729 7145
1,3R, 4,4X, 12 IP65 No Yes R/Y On/Off & O/l 3729 7147
1,3R, 4,4X, 12 IP65 Yes Yes Black On/Off & O/l 3729 7146
1,3R, 4,4X, 12 IP65 Yes Yes R/Y On/Off & O/l 3729 7148
SIRCO 83A
15 mm x 15 mm Shaft - for use with pistol handles type H

(inches/mm)
7.9/200 379H 1520
12.6/320 379H 1532 (1)
SIRCO 90A
15.7/400 379H 1540
OTHER PRODUCTS
• 2 pole switches (1)
• Mixed poles (1)
• Flange operation (1)
• Direct operation (1)
• Flat mounting operation (1)
• Rear connections (1)
• Automatic disconnect switches (shunt trip & undervoltage coil) (1)
• Changeover 30 A (1)
(1) Not UL listed
12
ACCESSORIES
AUXILIARY CONTACTS
For SIRCO V 30 A
Type Description Reference
U Standard products allow up to 4 auxiliary contacts
without any extra contacts holder
Contacts holder (for 5 to 8 auxiliary contacts) 3999 0710 (1)
SIRCO 100A
10 Amp 1 NO contact block 3999 0701
600 V AC 1 NC contact block 3999 0702
For SIRCO V 60 A to 200 A

U Contacts holder (for 1 to 8 auxiliary contacts) 3999 0700
SIRCO 101A
S 1 NO + NC contacts blocks 3999 U041
2 NO + NC contacts blocks 3999 U042
For SIRCO 400 A to 1200 A

SIRCO 102A
TERMINAL LUGS KIT

For use on Wire size No. of wires Wire Lugs Reference
per lug type per kit
SIRCO V 30 A #14 - #10 1 Cu – Standard
SIRCO V 200 A #6 - 3/0 1 Cu/Al 6 3994 6020
SIRCO 400 A & 600 A 2x2 - 2x600 2 Cu/Al (1) 6 3994 6060
SIRCO 800 A & 1000 A (2) 3x2 - 3x600 3 Cu/Al (1) 6 3994 6100
SIRCO 98A
2x2 - 2x600 2 Cu/Al (1) 12 3994 6120

SIRCO 1200 A 2x2 - 2x600 2 Cu/Al (1) 12 3994 6120
(2) SIRCO 800 A & 1000 A can receive 1 lug for 3 cables per terminal or 2 lugs for 2 cables per terminal
TERMINAL SHROUDS
For line or load side
For use on Reference
SIRCO V 30 A Standard
SIRCO V 200 A 3798 3020
SIRCO 99A
SIRCO 400 A & 600 A 2798 3060

SIRCO 800 A & 1000 A 2798 3120
SHAFT PADLOCKING KIT

SIRCO V 30 A 3999 0710 (1)
SIRCO V 60 to 200 A Standard
SIRCO 400A & 1200 A 3999 1001 (1)
(1) Not UL listed
13
Catalog number 2700 3003 2700 3006 2700 3010 2700 3020
Rating A 30 60 100 200
Operating voltage V 600 600 600 600
Max horsepower rating/
Max motor FLA current
Three phase
240 V 7.5/22 15/42 30/80 60/154
480 V 15/21 30/40 60/77 125/156
600 V 20/22 50/52 75/77 150/144
DC 125 V (1) 3/25 (1) 3/25 (1) 7.5/58 (1) 15/112
DC 250 V (1) 5/20 (2) 10/38 (2) 20/72 (2) 40/140
Short circuit rating with fuses kA 50 200 200 200
Fuse type J or CC J J J
Fuse rating (A) 30 60 100 200
Endurances
Electrical endurance 6000 6000 6000 6000
Mechanical endurance 10000 10000 10000 8000
Dimension 3 pole H in 4.57 5.87 5.87 8.12
W in 3.8 6.72 6.72 9.45
D in 2.56 3.9 3.9 3.4
Shaft size square in 0.2 x 0.2 0.4 x 0.4 0.4 x 0.4 0.4 x 0.4
mm 5x5 10 x 10 10 x 10 10 x 10
Switch operating torque Ib. in. 21 88 88 106
Terminal lug kits Standard Standard Standard
Wire range AWG min #14 #10 #10 #6
max #10 #3 #3 3/0
Wire tightening Ib. in. 27 58 58 200
Lug mounting Ib. in. Integrated Integrated Integrated
Auxiliary contacts
Nema rating, AC A600 A600 A600 A600
Nema rating, DC N600 N600 N600 N600
(1) 2 pole in series

Catalog number 2700 3003 2700 3006 2700 3010 2700 3020
Rating A 32 63 100 200
Rated Insulation voltage Ui (V) V 800 750 750 750
Rated impulse voltage (Uimp) 8 kV 8 kV 8 kV 8 kV
Operation current le (A)
400 V AC AC 22A 32 63 100 200
AC 23A 32 63 100 200
690 V AC AC 22A 32 63 100 200
AC 23A 32 63 100 200
Motor power (kW)
400 V AC AC 23A 15 30 51 100
500 V AC AC 23A 18.5 40 63 140
690 V AC AC 23A 25 55 90 185
Maxi. peak let through current kA peak 5.5 17.6 17.6 32
Connection
Minimum Cu cable section mm2 6 10 25 50
Minimum CU busbar section mm2
14
2700 3040 2700 3060 2700 3080 2700 3100 2700 3120
400 600 800 1000 1200
600 600 600 600 600
125/312 200/480 250/602 250/602 250/602

250/302 400/477 500/590 500/590 500/590
350/336 350/336 500/472 500/472 500/472
(1) 20/148 (1) 20/148
(2) 50/173 (2) 50/173
200 200 100 100 100
J J L L L
400 600 800 1000 1200
1000 1000 500 500 500

6000 6000 3500 3500 3500
12.6 12.6 13 13 13
11 11 14.65 14.65 14.65
6.54 6.54 6.54 6.54 6.54
0.59 x 0.59 0.59 x 0.59 0.59 x 0.59 0.59 x 0.59 0.59 x 0.59
15 x 15 15 x 15 15 x 15 15 x 15 15 x 15
320 320 320 320 320
2x2 2x2 3x2 3x2 4x2

2 x 600 MCM 2 x 600 MCM 3 x 600 MCM 3 x 600 MCM 4 x 600 MCM
500 500 500 500 500
2700 3040 2700 3060 2700 3080 2700 3100 2700 3120
400 600 800 1000 1250
1000 1000 1000 1000 1000
12 kV 12 kV 12 kV 12 kV 12 kV
400 630 800 1000 1200

400 630 800 1000 1000
400 500 630 630 630
200 200 400 400 400
220 355 450 560 560

280 450 560 560 560
185 185 400 400 400
48 48 75 75 75
185 2 x 150 2 x 185 2 x 240

2 x 30 x 5 2 x 40 x 5 2 x 50 x 5 2 x 60 x 5
15
DIMENSIONS
SIRCO V 30 A
C A
Y J J1
Y
K1
X
B K
SIRCO 104B
SIRCO V 60 - 100 A
C .40 1.14 J J1
10.3 29
K1
5 X K B
126.5
SIRCO 105B
Y A
RATING A B C H H1 H2 H3 J J1 K K1 Y
mm in mm in mm in mm in mm in mm in mm in mm in mm in mm in mm in mm in
V 30 A .n c SG
ds zznv Lqh nn x Qds
L \ \ \ \ \ \ \ \ c m.cz Qdszb
G Qds
L m.,bc Qkxb.n z x,.n z
Qk
16
SIRCO V 200 A
C .40 1.14 J J1
10.3 29
H2 Y
K1
5 X K B
126.5
H3
H2
SIRCO 106B
SIRCO 400 - 600 A
C J
Y J1
K1
X
K2
K B
H2 H
SIRCO 107B
H1 A
xvx . Qsx/n.v, Qk,n..c Jqj \

V 200 A \ \ \ zmv.bn Jkzzz.nv Dknx x Jqh .c.bc Q Qqh z./.bm Qs.b.xc Df
xv.c Q G
qh
17
DIMENSIONS
SIRCO 800 - 1000 - 1200 A
J
C
Y J1
K1
X
K2
B K
8.48 1
215.5 H
8.85
225
1 2
SIRCO 108A
H1
A
800 A
1000 A cmxzv Gkcc/ zc zv/ b Qs xc/. Qqh zc,b Jqh \ \ cvmzc Q Qqh nc x Qs zmbn Jk b..bb Gqh x, z Qk v m
z Jk
18
HANDLES
SELECTOR HANDLE TYPE M PISTOL HANDLE TYPE D2

62 12.4 1 16" DOOR DRILLING
2.44 0.49 ø 2.2 2.58 1.83 1 8"

65.5 46.5 2 ø 4.5
11 4"
5 8"
16
ø 31
2"
50
2.44
-OFF
62
2.48
63
SIRCO 113 A
COMO 75 A
7 8"
90°
COMO 89 A ø 23
-ON
17.5 8
COMO 87 A
0.69 0.31
38
1.5
PISTOL HANDLE TYPE G1 & G2 PISTOL HANDLE TYPE H

DOOR DRILLING 80
3.15
2.87 2.75 1 8" 2"
DOOR DRILLING
73 70 50
65° 50 2"
50 2"
o -OFF
50
2"
2.78
70.5
SIRCO 114 A
7.48
190
31 1 1 4 "
11 4" 90°
126.5
4.98
ø 31
COMO 74 A
-ON
G1
4.5 1 8"
COMO 88 A
G2
100
3.937
MOUNTING DEPTH (mm/in)

HANDLE TYPE M HANDLE TYPE D HANDLE TYPE G HANDLE TYPE H
mm in mm in mm in mm in
SIRCO V 30 A 100 3 15/16 105 4 2/15 100 3 15/16 – –
SIRCO V 60-100 A – – – – 115 4 48/91 – –
h SIRCO V 200 A – – – – 115 4 48/91 – –
COMO 90 A
SIRCO 400-600 A – – – – – – 212 8 9/26

SIRCO 800-1000-1200 A – – – – – – 212 8 9/26
TERMINAL LUGS
3954 6020 3954 6060 / 3954 6120 3954 6100

for use with SIRCO V 200 A for use with SIRCO 400 A - 600 A - 800 A - for use with SIRCO 800 A - 1000 A
1000 A - 1200 A
7"
16
11
3"
10.2
7
8
16
.6
11
1"
16
1
2
2
9
63
38
1
2
25
1
1" 9 "
1 3 3
1 8 16
2
80 90.5
38.8
28.6
1
8
1
7"
76
3"
8
73
SIRCO 115 A
SIRCO 116 A
SIRCO 117 A
2
310 max 2 x 600 MCM max 3 x 600 MCM max

19
FUSERBLOC FUSIBLE DISCONNECT SWITCHES FROM 30 TO 800 A
GENERALITIES
DEFINITION AND FUNCTION RANGE CONFORMITY TO STANDARDS

The FUSERBLOC is a multipolar • 7 ratings from 30 to 800 A, using CC, • UL98 (UL Files E201138)
manually operated fusible disconnect J and L fuses. • CSA 22.2 No.4 CSA Files
switch. It is based on the most up-to- • Various operations : LR 112964-2-3-4
date operated disconnect switch - Front, standard (ON-OFF) and Test. • IEC 60 947-3, IEC 60 269-1
technology. Designed around North - Flange • CE Mark
American standard UL98 it gives you a - Direct
product that “makes and breaks” under Complete ranges of IEC (DIN, BS or
load. The most recent Fuse technologies french ferrule) Fusible disconnect
were combined with the switch to switches are available from 20 to
provide the best protection against 1800 A.
overload and short circuit in your
systems.
The switch line is tested and approved
for use in the most stringent application
such as “Service Entrance Rating”.
PRODUCT FEATURES
PRACTICAL SAFEGUARD
Double break :
This modern designed mechanism
disconnects on both side of the fuses
using two double breaking contacts per
pole. This assures the complete isolation
of the fuses in OFF position.
FUSER 155A
Touch safe :
Our design reduces or eliminates the
danger of accidental contact with live,
energized parts.
All our products are supplied standard
with fuse cover.
EXCEPTIONAL 200 KA SHORT

FUSER 156A
CIRCUIT PROTECTION
The Fuserbloc Series with the use of CC
Fuse Circuit Breaker or J type fuses provides exceptional
high short circuit protection, up to
200 kA.
The CC and J fuses are more current
Fusible limiting than older classes of fuses or
disconnect circuit breaker.
switch
PANEL SPACE SAVING

This proven switch technology has the
Switch fuses incorporated on the top of the
with older switch mechanism to reduce the foot
fuse classes print of the product and save you
valuable real estate in your panel.
The space saving can be as much as
FUSER 157A
50% from the switches designed with

Panel use of older fuse classes.
20
PRODUCT FEATURES
A COMPLETE RANGE OF HANDLES

The FUSERBLOC series offers a full line
of Nema/IP rated handles.
Nema rating 1,3R, 12, 4 and 4X
All external handles are available in two
colors (black and red/yellow).
Handles offer the user the largest
selection of option in operating the
switch :
COMO 67A
COMO 68A
COMO 64A
SIRCO 83A
Standard configuration : ON / OFF
(2 positions)
Test configuration : ON / OFF / TEST
(3 positions)
1x 2x 3x
PADLOCKING
Handles can be padlocked in the OFF maxi. ø 5 in / 8 mm
16
position with up to 3 padlocks. Meets
OSHA requirement for lockout / tagout
procedures.
SIRCO 86A
For safety reasons, the door can not be

openned when the handle is padlocked.
DOOR INTERLOCK IN ON POSITION

The handles allow opening of door in the
OFF position only.
In the ON position the door can not be
opened.
This interlocking can however be by-
passed by authorized personal (defeater
SIRCO 87A
option on handle) for maintenance,

testing or commisioning.
DEFEATER
The defeat function allows qualified
personal to by-pass the door interlock
when the switch is in the ON position by
means of a tool.
This exclusive design is also available in
SIRCO 88A
a 4 and 4X rating.
FAST AND SAFE COMMISIONING

The TEST facility enables the testing of
the control circuit auxiliaries without
switching the main contacts or removing
the fuses.
This function provides a serious
technical and commercial alternative
to a separately wired push buttom.
SIRCO 85A
21
1 SWITCH
(see below) + 1 SHAFT
+ 1 HANDLE
+ IF NEEDED, 1 LUGS KIT
FUSER 158A
COMO 70A
COMO 64A
SIRCO 91B
Fuserbloc J 200 A Shaft 7,9 inches/200 mm Black handle Lugs kit
ref. 3710 3020 ref. 379G 1020 ref. 3729 7066 ref. 3994 3020
Line side shrouding are supplied as standard
SWITCH BODY WITH STANDARD OPERATION

(ON - OFF)
FUSERBLOC CD 30 A
Type Fuses Amps No. of Three Phase Reference
FUSER 161A
Poles 240 V 480 V 600 V

Fuserbloc CD CC 30 3 7.5 15 20 3710 3003
Fuserbloc CD J 30 3 7.5 15 20 3710 3004
FUSERBLOC 30 TO 400 A
Poles 240 V 480 V 600 V
Fuserbloc CC 30 3 7.5 15 20 3712 3003
Fuserbloc J 30 3 7.5 15 20 3712 3004
FUSER 162A
Fuserbloc J 60 3 15 30 50 3712 3006

Fuserbloc J 100 3 30 60 75 3712 3010
Fuserbloc J 200 3 60 125 150 3712 3020
Fuserbloc J 400 3 125 250 350 3712 3040

FUSER 163A
Poles 240 V 480 V 600 V

Fuserbloc J 600 3 250 500 500 3712 3060
Fuserbloc L 800 3 250 500 500 3712 3080
22
SWITCH BODY WITH TEST POSITION
(ON - OFF - TEST)
FUSERBLOC CD 30 A
FUSER 164A

Poles 240 V 480 V 600 V
Fuserbloc CD CC 30 3 7.5 15 20 3710 3003
Fuserbloc CD J 30 3 7.5 15 20 3710 3004
FUSER 165A
Poles 240 V 480 V 600 V

Fuserbloc CC 30 3 7.5 15 20 3711 3003
Fuserbloc J 30 3 7.5 15 20 3711 3004
Fuserbloc J 60 3 15 30 50 3710 3006
Fuserbloc J 100 3 30 60 75 3710 3010
Fuserbloc J 200 3 60 125 150 3710 3020
Fuserbloc J 400 3 125 250 350 3710 3040
Test function can only be active with test handle.
23
FUSERBLOC FUSIBLE DISCONNECT SWITCHES
FROM 30 TO 800 A
HANDLES AND SHAFTS
FOR FUSERBLOC CD 30 A
Type Type
1,3R,12 IP 65 No Yes Black On/Off & O/I 2109 0U14
1,3R,12 IP 65 No Yes R/Y On/Off & O/I 2109 0U13
COMO 60A
COMO 67A

(inches/mm)
7.9 / 200 379M 0520
12.6 / 320 379M 0532
COMO 71A
15.7 / 400 379M 0540

Type Type
1,3R,12 IP 54 No Yes Black On/Off & O/I 3729 7015
1,3R,12 IP 54 No Yes R/Y On/Off & O/I 3729 7017
1,3R,12 IP 54 Yes Yes Black On/Off & O/I 3729 7026
COMO 68A
COMO 62A
1,3R,12 IP 54 Yes Yes R/Y On/Off & O/I 3729 7028

(inches/mm)
7.9 / 200 379D 0520
12.6 / 320 379D 0532
COMO 72A
15.7 / 400 379D 0540

Type Type
1,3R,4,4X,12 IP 65 Yes Yes Black On/Off & O/I 3729 7056
COMO 64A
COMO 69A
1,3R,4,4X,12 IP 65 Yes Yes R/Y On/Off & O/I 3729 7058

4,4X IP 65 Yes Yes Black Test,On,Off 3729 8056
4,4X IP 65 Yes Yes R/Y Test,On,Off 3729 8058

(inches/mm)
7.9 / 200 379G 0520
12.6 / 320 379G 0532
15.7 / 400 379G 0540
COMO 70A
24
FOR FUSERBLOC 30 TO 60 A
Type Type
4,4X IP 65 Yes Yes Black On/Off & O/I 3729 7056
4,4X IP 65 Yes Yes R/Y On/Off & O/I 3729 7058
COMO 64A
4,4X IP 65 Yes Yes Black Test,On,Off 3729 8056
4,4X IP 65 Yes Yes R/Y Test,On,Off 3729 8058
FOR FUSERBLOC 100 TO 400 A

Type Type
COMO 64A
1,3R,4,4X,12 IP 65 Yes Yes Black Test,On,Off 3729 8076
1,3R,4,4X,12 IP 65 Yes Yes R/Y Test,On,Off 3729 8078

(inches/mm)
7.9 / 200 379G 1020
12.6 / 320 379G 1032
15.7 / 400 379G 1040
COMO 70A
FOR FUSERBLOC 600 & 800 A

Pistol handles - for use with shaft type H
Type Type
1,3R,4,4X,12 IP 65 No Yes Black On/Off & O/I 3729 7125
1,3R,4,4X,12 IP 65 No Yes R/Y On/Off & O/I 3729 7127
SIRCO 83A
15 mm x 15 mm Shaft - for use with pistol handles type H

(inches/mm)
7.9 / 200 379H 1520
12.6 / 320 379H 1532 (1)
SIRCO 90A
15.7 / 400 379H 1540
(1) Not UL listed
25
FUSERBLOC FUSIBLE DISCONNECT SWITCHES
FROM 30 TO 800 A
ACCESSORIES
AUXILIARY CONTACTS
For FUSERBLOC CD 30 A
U Standard products allow up to 4 auxiliary contacts
without any extra contacts holder.
SIRCO 100A
Contacts holder (for 5 to 8 auxiliary contacts) 3999 0710 (1)

For FUSERBLOC 30 A to 400 A

S
10 Amp 1 NO + NC contact block 3999 U041
SIRCO 101A
600 V AC 2 NO + NC contacts blocks 3999 U042
For FUSERBLOC 600 A to 800 A

Microswitch 1 NO.NC contact 3999 UL51 (1)
2 NO.NC contacts 3999 UL52 (1)
TERMINAL LUGS KIT

For use on Wire size No. of wire Wire type Lugs Reference
per lug per kit
Fuserbloc CD 30 A CC #14 - #10 1 Cu - Standard
Fuserbloc CD 30 A J #14 - #10 1 Cu - Standard
Fuserbloc 30 A CC #14 - #10 1 Cu - Standard
Fuserbloc 30 A J #10 - #3 1 Cu - Standard
Fuserbloc 60 A J #10 - #3 1 Cu - Standard
Fuserbloc 100 A J #14 - 2/0 1 Cu/Al 6 3954 6010
Fuserbloc 200 A J #6 - 3/0 1 Cu/Al 6 3954 6020
Fuserbloc 400 A J 2x2 - 2x600 2 Cu/Al 6 3954 6060
SIRCO 98A
Fuserbloc 600 A J (2) 2x2 - 2x600 2 Cu/Al (1) 6 3954 6060

Fuserbloc 800 A L (2) 3x2 - 3x600 3 Cu/Al (1) 6 3954 6100
(1) Not UL listed
(2) Fuserbloc 600 A & 800 A can receive 2 lugs with 2 holes (3954 6060) per terminal and so accept up to 4 wires
26
TERMINAL SHROUDS
For Line or Load side
Fuserbloc CD 30 A CC Standard
Fuserbloc CD 30 A J Standard
Fuserbloc 30 A CC Standard
Fuserbloc 30 A J Standard
Fuserbloc 60 A J Standard
Fuserbloc 100 A J 3798 3010
SIRCO 99A
Fuserbloc 600 A J * 3798 3080
Fuserbloc 800 A L * 3798 3080
* For line side only
SHORTING LINKS
For use on Shorting Links per kit Reference
Fuserbloc 60 A J 3 3799 9006
Fuserbloc 100 A J 3 3799 9010
Fuserbloc 200 A J 3 3799 9020
Fuserbloc 400 A J 3 3799 9040
FUSER 168A
Fuserbloc 600 A J 3 3799 9080
Fuserbloc 800 A L 3 3799 9080
SHAFT PADLOCKING KIT

Fuserbloc CD 30 A 3999 0710 (1)
Fuserbloc 30 to 400 A Standard
Fuserbloc 600 and 800 A 3999 1001 (1)
OTHER PRODUCTS
• Mixed poles (1)
• Flange operation (1)
• Direct operation (1)
• Flat mounting operation (1)
• Rear connections (1)
• Automatic fusible disconnect switches (shunt trip & undervoltage coil) (1)
• Fused changeover 30 A (1)
(1) Not UL listed
27
Catalog number 3710 3003 3710 3004 3711 3003 3711 3004
Rating 30 CD 30 CD 30 30
Fuse type A CC J CC J
Operating voltage V 600 600 600 600
Max horsepower rating/
Max motor FLA current
Three phase
240 V 7.5/22 7.5/22 7.5/22 7.5/22
480 V 15/21 15/21 15/21 15/21
600 V 20/22 20/22 20/22 20/22
DC 125 V
DC 250 V }2 pole in series
except (1)
3/25
5/20
3/25
5/20
3/25
5/20
3/25
5/20
Short circuit rating with fuses kA 50 50 100 200
Fuse type CC J CC J
Fuse rating (A) 30 30 30 30
Endurances
Electrical endurance 6000 6000 6000 6000
Mechanical endurance 10000 10000 10000 10000
Dimension 3 pole H in. 4.56 4.56 5.87 5.87
W in. 3.8 4.15 5.62 6.72
D in. 3.3 3.9 3.9 5.63
Shaft size square in. 0.2 x 0.2 0.2 x 0.2 0.4 x 0.4 0.4 x 0.4
mm 5x5 5x5 10 x 10 10 x 10
Switch operating torque Ib. in. 21 21 53 88
Terminal lug kits Standard Standard Standard Standard
Wire range AWG min #14 #14 #14 #10
max #10 #10 #10 #3
Wire tightening Ib. in. 27 27 48 58
Lug mounting Ib. in. Integrated Integrated Integrated Integrated
Auxiliary contacts
Nema rating, AC A600 A600 A600 A600
Nema rating, DC N600 N600 N600 N600
(2) Tests in process
Catalog number 3710 3003 3710 3004 3711 3003 3711 3004
Rating A 32 CD 32 CD 32 32
Rated Insulation voltage Ui V 800 800 750 750
Rated Impulse voltage (Uimp) 8 kV 8 kV 8 kV 8 kV
Operation current le A
400 V AC AC 22 A 32 32 32 32
AC 23 A 32 32 32 32
690 V AC AC 22 A 32 32 32 32
AC 23 A 32 32 32 32
Motor power (kW)
400 V AC AC 23 A 15 15 15 15
500 V AC AC 23 A 18.5 18.5 18.5 18.5
690 V AC AC 23 A 25 25 25 25
Maxi. peak let through current kA peak 5.5 5.5 7.6 17.6
Connection
Minimum Cu cable section mm2 6 6 6 6
Minimum Cu busbar section mm2
28
3710 3006 3710 3010 3710 3020 3710 3040 3710 3060 3710 3080
60 100 200 400 600 800
J J J J J L
600 600 600 600 600 600
15/42 30/80 60/154 125/312 250/602 250/602

30/40 60/77 125/156 250/302 500/590 500/590
50/52 75/77 150/144 350/336 500/472 500/472
3/25 7.5/58 15/112 20/148
10/38 20/38 40/140(1) 50/173(1)
200 200 200 200 200 200
J J J J J L
60 100 200 400 600 800
6000 6000 6000 1000 1000 1000

10000 10000 8000 6000 5000 5000
5.87 7.19 8.12 14.17 14.25 14.25
6.72 8.27 9.45 11.43 17.16 17.16
5.63 5.63 5.99 5.51 12.93 12.93
0.4 x 0.4 0.4 x 0.4 0.4 x 0.4 0.4 x 0.4 0.59 x 0.59 0.59 x 0.59
10 x 10 10 x 10 10 x 10 10 x 10 15 x 15 15 x 15
88 88 106 132 350 350
Standard
#10 #14 #6 2x2 2x2 3x2
#3 2/0 #3/0 2x600 MCM 2x600 MCM 3x600 MCM
58 120 200 500 500 500
Integrated
A600 A600 A600 A600

N600 N600 N600 N600
3710 3006 3710 3010 3710 3020 3710 3040 3710 3060 3710 3080
63 100 200 400 630 800
750 750 750 800 1000 1000
8 kV 8 kV 8 kV 8 kV 12 kV 12 kV
63 100 200 400 630 800

63 100 200 400 630 800
63 100 200 400 630 800
63 100 200 250 630 630
30 51 100 220 355 450

40 63 140 220 450 560
55 90 185 220 600 600
17.6 22 32 36 77 77
10 25 50 185 2 x 150
2 x 40 x 5
29
DIMENSIONS
FUSERBLOC CD 30 A CC
C A
Y J J1
Y
K1
X
B K
FUSER 169B
H1
FUSERBLOC CD 30 A J
C
A
Y
J J1
K1
X
B K
FUSER 170B
30 A CC .n c SG
ds zznv Lqh,c.bc Qds
L \ \ zcxb Dqh \ \ \ \ c m.cz Qdszb
G Qds
L m..bc Qkxb.n z x,.n z
Qk
30
FUSERBLOC 30 CC - 30 J - 60 J
C .40 1.14 J J1
10.3 29
Y
K1
5 X
B K
126.5
FUSER 171B
Y A
FUSERBLOC 100 J - 200 J
C
.40 1.14 J J1
10.3 29
H2
Y
K1
5 X K B
126.5
H3
H2
H
A
Y
FUSER 172B
H1
30 CC zvc b Gkzv..xb Jk . c Jk \ \ \ \ \ \ \ \ x. z Qk n/.bx Dkzcbb Gqh nn.m x Gkc/., z

Dqh
30 J zm/.,n Dfzv..xb Jkzvx..b Gk \ \ \ \ \ \ \ \ c,.x z Qs n..m x Dfzcbb Gqh nn.m x Gkxv.c
QG
qh
60 J zm/.,n Dfzv..xb Jkzv..xb Gk \ \ \ \ \ \ \ \ c,.x z Qs n..m x Dfzcbb Gqh nn.m x Gkxv.c
31
DIMENSIONS
FUSERBLOC 400 A J
C 40 1.14 J J1
10.3 29
H2
Y K1
5 X
K
B 126.5
H
H3
H2
FUSER 175B
A
Y
H1
FUSERBLOC 600 A J & 800 A L

C
H3
J J1
4.173 5.984
106 152
Y
H2
K1
B X K
5.528
242
2
1
9.173
233 H
9.528
242
1 2
Y A
FUSER 174B
H1
400 A J c/czz Q G
q h cnc.nzv Q G
q h zvz.cb Lqh zcv.c b Gqh x,..,zz Jqh zm.m Qqh znm.nn Gkm x.zx Q Dqh bz.. x
Qqh xxv.x, Q Dqh zzx.zv Jqhx mz Qqh
32
HANDLES
SELECTOR HANDLE TYPE M PISTOL HANDLE TYPE D
62 12.4 1 16" DOOR DRILLING
2.44 0.49 ø 2.2 2.58 1.83 1 8"

65.5 46.5 2 ø 4.5
11 4"
5 8"
16
ø 31
2"
50
2.44
-OFF
62
2.48
63
SIRCO 113 A
COMO 75 A
7 8"
90°
COMO 89 A
ø 23
-ON
17.5 8
COMO 87 A
0.69 0.31
38
1.5
PISTOL HANDLE TYPE G PISTOL HANDLE TYPE H

DOOR DRILLING
80
2.87 2.75 2" 3.15
1 8"
73 70 50 DOOR DRILLING
65°
50 2"
o -OFF
50
2"
50 2"
2.78
70.5
7.48
190
11 4" 90° 31 1 1 4 "

126.5
4.98
ø 31
SIRCO 112 A
COMO 74 A
-ON
G1
4.5 1 8"
G2
COMO 88 A
SIRCO 114 A
100
3.937
MOUNTING DEPTH (mm/in)
HANDLE TYPE M HANDLE TYPE D HANDLE TYPE G HANDLE TYPE H
mm in mm in mm in mm in
FUSERBLOC CD 30 CC 100 3 15/16 105 4 2/15 105 4 2/15 – –
FUSERBLOC CD 30 J 130 5 2/17 150 5 48/53 130 5 2/17 – –
h FUSERBLOC CD 30 CC – – – – 100 3 15/16 – –
COMO 90 A
FUSERBLOC 30 J-60 J – – – – 155 6 4/39 – –

FUSERBLOC 100 J-200 J – – – – 165 6 1/2 – –
FUSERBLOC 400 J – – – – 175 6 8/9 – –
FUSERBLOC 600 J-800 J – – – – – – 416 16 17/45
TERMINAL LUGS
3954 6010 3954 6020 3954 6060 3954 6100

for use with FUSERBLOC 100 J for use with FUSERBLOC 200 J for use with FUSERBLOC for use with FUSERBLOC 800
400 J - 600 J - 800 L
7"
16
11
3"
10.2
7
8
1
16
.6
4
6.9
11
1"
16
1
2
2
9
63
38
1
2
25
1
1"
15.4
1 3 9 "
8
3
5
7 1 8 16
2
8 80 90.5
38.8
22.3
28.6
1
8
19.8
1
3
4
7"
76
3"
8
FUSER 208 A
73
SIRCO 115 A
SIRCO 116 A
SIRCO 117 A
2
210 max 310 max 2 x 600 MCM max 3 x 600 MCM max 33
SOCOMEC IT’S ALSO…
A COMPLETE RANGE
Load-break Changeover
switches switches
Machine load-break switches
COMO M Machine changeover switches
• 3 or 4 poles
• from 20 to 100 A; 7 ratings
COMO C
COMO 79A
• Direct operation or external front • 3 or 4 poles ; 2 positions (I / II) or

operation 3 positions (I / 0 / II or I / I + II / II)
COMO 25A
COMO 80A
• Direct operation or external front operation
Remote-trip load-break switches

Manual changeover switches
IDE
• 3 or 4 poles
SIRCOVER
• from 32 to 160 A; 4 ratings • 3 or 4 poles ; 3 positions (I - 0 - II)
• Direct operation or external front operation • from 125 to 3150 A; 10 ratings
SIRCOVER By Pass
IDE 15A
SVR 001 AT
• 3 - 6 poles or 4 - 8 poles ;
3 positions (I - 0 - II)
Modular load-break switches • Direct operation or external front
with visible breaking operation
SIRCO VM
• 3 or 4 poles
SIRCO 045A
• Direct operation or external front or

left/right side operation
Automatic changeover switches
Motorized SIRCOVER VS
• 3 or 4 poles
• Positions 1 and 2 by remote control
• Position 0 via safety handle with direct front
Load-break switch with operation
disconnection
SIRCO
• 3, 4, 6 or 8 poles
SVRMO 72A

SIRCO 14B
side operation
Automatic changeover switches

Remote-trip load-break switches
Motorized SIRCOVER VE
SIDERMAT
• 3 or 4 poles
• 3 or 4 poles • from 250 to 3150 A; 8 ratings
• from 250 to 1800 A; 6 ratings • Positions 1, 0 and 2 by remote control
• Direct operation or external front operation • Safety handle with direct
SDMAT 002A
front operation
SVRMO 101
34
OF IEC PRODUCTS
Fuse Fuse
combination protection
switches Short circuit
Industrial Fuse Links
• Sizes: 10.3 x 38, 14 x 51, 22 x 58, T00, T0,
Fuse combination switches T0P, T1, T2, T3, T4
FUSIB 49A
FUSERBLOC • from 0.16 to 1250 A
• 2, 3 or 4 poles as standard • With or without striker
• 5, 6, 7 or 8 poles programmable • 500 or 690 V AC
• IEC, NF, DIN, BS, UL and ‘UR’
High speed fuses
multi-standard fuses
• Sizes: 14 x 51, 22 x 58, T000, T0, T0P, T1, T2, T3
FUSER 135A

FUSIB 54A
• from 10 to 2000 A
left/right side operation
• DIN 43620 or threaded hole contact principle
• Operation with auxiliaries
TEST function
FUSER 91A
Fuse holders
for cylindrical fuses
RM
• 1, 2, 3 or 4 poles
• Sizes: 10.3 x 38, 14 x 51, 22 x 58
• from 32 to 100 A
• 3 models:
RM 11A
RM (without indicator)
RMS (with indicator)
Fuse combination switches
RMSC (with indicator and padlock support)
FUSERBLOC V
• 3 or 4 poles
• IEC, NF, DIN, BS and ‘UR’ multi- Fuse holders
standard fuses • 1, 3 or 4 poles
FUSER 144 A
• Direct operation or external front or • Sizes: T00, T0, T0P, T1, T2, T3, T4, T5
SOCLE 22A
right side operation • from 160 to 2500 A

• With or without indicator
Fuse combination switches

remote-trip
FUSOMAT
• 3 or 4 poles
• IEC, NF, DIN, BS and ‘UR’ multi-standard fuses
• Direct operation or external front or right side
operation
• Shunt-trip opening
FUSER 40A
35
SOCOMEC: WORLDWIDE
SUBSIDIARIES
Belgium
SOCOMEC BELGIUM
1190 BRUXELLES
Tel. (32) 23 40 02 30
Fax (32) 23 46 28 99
e-mail: socomec.belgium@socomec.be
Germany
SOCOMEC Schaltgeräte GmbH
35510 BUTZBACH
Tel. (49) 6033 98 07 0
Fax (49) 6033 98 07 13
e-mail: socomec_schaltgeraete_gmbh@t-online.de
Berlin Office:
12277 BERLIN
Tel. (49) 3072 24 685
Fax (49) 3072 24 661
Portugal
SOCOMEC RDC Lda
CARTE 10 B
2685 SACAVEM
Tel. (35) 11 948 8970
Fax (35) 11 947 2608
Italy
SOCOMEC Elettrotecnica Spa
20098 S. GIULIANO MILANESE (MI) REPRESENTATIVE NETWORK
Tel. (39) 02 9883 131
Fax (39) 02 9828 9088 Africa - Japan - Switzerland
e-mail: socomec@tin.it - Algeria - Korea - Czech. Republic
- Egypt - Malaysia - Hungary
United Kingdom
- Marocco - Philippines
SOCOMEC Ltd.
KNOWL PIECE - Mauritius - Singapore Middle East
WILBURY WAY, HITCHIN - Nigeria - Sri Lanka - Bahrain
HERTFORDSHIRE - South Africa - Taiwan - Iran
SQ4 0TY - Tunisia - Thailand - Israel
Tel. (44) 146 244 00 33 - Vietnam - Jordan
Fax (44) 146 243 11 43 America - Kingdom of Saudi Arabia
e-mail: socomecuk@aol.com - Argentina Europe - Kuwait
- Guadeloupe - Austria - Lebanon
Ref. DCG 68013 / 11.99 - 3.575 - Gyss Imprimeur Obernai - 992332 - Photo : Martin Bernhart - Réalisation : EUROGRAPHICS
- Martinique - Cyprus - Pakistan
REGIONAL OFFICES - Uruguay
- USA
- Denmark
- Finland
- Qatar
- Sultanate of Oman
- Brazil - Greece - Syria
South East Asia - Chite - Ireland - Turkey
SOCOMEC THAILAND - Netherlands - United Arabian Emirates
BANGKOK Asia - Norway - Yemen
Tel. (66) 250 39 379 - Cambodia - Poland
Fax (66) 250 39 377 - China - Serbia Oceania
e-mail: socomcbk@ksc.th.com
- Hong Kong - Slovenia - Australia
China - India - Spain - New Caledonia
SOCOMEC - Indonesia - Sweden - New Zealand
200070 SHANGHAI
Tel. (86) 21 635 35 120
Fax (86) 21 635 35 121
e-mail: socomecs@shanghai.cngb.com
Your representative
HEAD OFFICE - INTERNATIONAL SALES DEPARTMENT
SOCOMEC S.A.
1 rue de Westhouse
P.O. Box 10
67230 Benfeld - France
Tel. (33) 3 88 57 41 41
Fax (33) 3 88 74 08 00
www.socomec.com
This document is not a contract. SOCOMEC reserves the right to

modify features without prior notice in view of continued improvement.

Switchgear Components

Uploaded by

Document Information

Original Description:

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Switchgear Components

Uploaded by

Copyright:

Available Formats

N O R T H A M E R I C A N ( U L / C S A )

Teams of specialised designers, a highly integrated pro-

Our ‘Control & Protection Systems’ division is today

- low-voltage SWITCHGEAR components

- electronic CONTROL & PROTECTION

- mounting & cabling, and integrated

Our solutions are in permanent evolution thanks to our

For over 75 years our customer-partners have recognised

A global presence ensures that SOCOMEC is always on

F ounded in 1894, Underwriters Laboratories Inc. (UL)

systems ans materials to determine their relation to life,

LBS Load Break Disconnect Switches

The SIRCO is a multipolar manually

WELDED CONTACT PROTECTION

CLEAR POSITION INDICATION

and OFF designation.

A COMPLETE RANGE OF HANDLES

FAST AND SAFE COMMISIONING

technical and commercial alternative

DOOR INTERLOCK IN ON POSITION

passed by authorized personal (defeater

LBS M 16 Shaft 7,9 inches/200 mm Black handle

SWITCH BODY/ROTARY OPERATION

Type Amps No. of Three Phase Test function Reference

FOR LBS M-LBS R

5 mm x 5 mm Shaft - for use with selector handles type M

Pistol handles type D2

5 mm x 5 mm Shaft - for use with pistol handles type D

12.6/320 379D 0532

Pistol handles type G1

5 mm x 5 mm Shaft - for use with pistol handles type G

15.7/400 379G 0540

OTHERS OPTION MODELS AND ACCESSORIES AVAILABLE ON REQUEST

IEC TECHNICAL CHARACTERISTICS

LBS M LBS 16 TO 100 A

HANDLES SELECTOR HANDLE TYPE M PISTOL HANDLE TYPE D2

2.87 2.75 1 8" 2"

HANDLE TYPE M HANDLE TYPE D HANDLE TYPE G

LBS R1 30-40 A 76 3 96 3 46/59 96 3 46/59

Line side shrouding are supplied as standard

Poles 240 V 480 V 600 V

SIRCO V 60 3 15 30 50 Yes* 2700 3006

SIRCO 400 AND 1200 A

SIRCO 800 3 250 500 500 No 2700 3080

5 mm x 5 mm Shaft - for use with selector handles type M

Pistol handles type D2

5 mm x 5 mm Shaft - for use with pistol handles type D

12.6/320 379D 0532

Pistol handles type G1

5 mm x 5 mm Shaft - for use with pistol handles type G

FOR SIRCO V 200 A

10 x 10 mm Shaft - for use with pistol handles type G

FOR SIRCO 400 TO 1200 A

15 mm x 15 mm Shaft - for use with pistol handles type H

15.7/400 379H 1540

For SIRCO V 60 A to 200 A

For SIRCO 400 A to 1200 A

TERMINAL LUGS KIT

2x2 - 2x600 2 Cu/Al (1) 12 3994 6120

SIRCO 400 A & 600 A 2798 3060

SHAFT PADLOCKING KIT

(1) Not UL listed
