FOREWORD
We are pleased to present the Parts Catalogue for the New “YUVRAJ 215” Tractor.
This Parts Catalogue contains parts used on the above model. This Parts Catalogue shall help you in ordering
parts & also provide details & location of assembled parts on above model.
The following points will help you to understand the usage of the Parts Catalogue.
Symbol “‡” given in the Part Number column denotes, Part is not serviced seperately. Also the remark is given
below each page.
Symbol “*” written against Reference Number denotes, Part is Not Illustrated.
Symbol “” written against Reference Number denotes, Alternate Part No.
We hope this Parts Catalogue will serve useful to you. For any further help or query contact at the below
mentioned address.
Product Support
Customer Care Department
Mahindra & Mahindra Ltd.,
Farm Equipment Sector,

Akurli Road,
Kandivli (E)
Mumbai - 400 101
email - CCMIS@mahindra.com
PART NO: YUVR 215 PC01, 2 nd Edition, Mar 31st
215 yuvraj Parts Index 13.6.2011.pmd

1 6/15/2011, 2:26 PM
Getting F amiliar with P
Familiar arts Catalogue
Parts
The Parts Catalogue not only helps in ordering of Spare Parts but also gives information about the parts that
make a Tractor. This Parts Catalogue is divided in to four major sections as given below
• Engine
• Transmission
• Hydraulics
• Chassis & Sheet Metal
• Electricals
Following steps will help you to use this Catalogue.

Parts Catalogue Sections :
1) Each section has sub Groups, comprising of various sub-assembly.
2) Each page has 5 separate columns
Parts Number - Reference Number - Part Description- Unit Qty. & Revision No.
NOTE :-
a) The Parts numbers and Quantity mentioned indicates that the particular part is fitted on the model/variant.
b) Parts Catalogue should be updated for any changes in Part number, or any additional part. This information
is circulated through Service Bulletins, Products Updates etc.
c) On receipt of Service Bulletins / Updates, the same should be entered in. Revision / Remarks column .
For Locating the Parts easily, please follow the steps as given below :
a) If you know the part number of any part then
• Refer the part no. in the Numerical Index given at the end of the parts catalogue.
• Identify the page no. against that part.
• Refer to the relevant page and look for the part no. on this page.
b) If you know the assembly where the Part is fitted
• Refer to the Main Index.
• Locate the relevant chapter.
• Refer to the desired Part in that chapter.
c) If you do not know the part number but you know the assembly where the part is used, then
• Refer to the Main Index.
• Locate the relevant chapter.
• Refer to the desired Part in that chapter.

2 6/15/2011, 2:26 PM
INDEX
DESCRIPTION PAGE No.
ENGINE
Engine -------------------------------------------------------------------------------------------------------------------- 10 - 11
Intake System ----------------------------------------------------------------------------------------------------------- 12 - 13
Exhaust System --------------------------------------------------------------------------------------------------------- 14 - 15
Cylinder Head Assembly --------------------------------------------------------------------------------------------- 16 - 17
Crankcase Assembly --------------------------------------------------------------------------------------------------- 18 - 21
Crank Shaft Assembly ------------------------------------------------------------------------------------------------ 22 - 25
Counter Balance Assembly ------------------------------------------------------------------------------------------ 26 - 27
Governing System ----------------------------------------------------------------------------------------------------- 28 - 29
Lubrication System ---------------------------------------------------------------------------------------------------- 30 - 31
Oil Pump Assembly ---------------------------------------------------------------------------------------------------- 32 - 33
Fuel System -------------------------------------------------------------------------------------------------------------- 34 - 35
Cooling System --------------------------------------------------------------------------------------------------------- 36 - 37
Water Pump Assembly ----------------------------------------------------------------------------------------------- 38 - 39
TRANSMISSION
Clutch Cover Assembly ----------------------------------------------------------------------------------------------- 42 - 43
Clutch Housing & Connection ------------------------------------------------------------------------------------- 42 - 43
Transmission Drive Shaft Assembly -------------------------------------------------------------------------------- 44 - 45
Transmission Case ----------------------------------------------------------------------------------------------------- 44 - 45
Rail Assembly ------------------------------------------------------------------------------------------------------------ 46 - 47
Counter Shaft Assembly --------------------------------------------------------------------------------------------- 48 - 49
Spline Shaft Assembly ------------------------------------------------------------------------------------------------ 50 - 51
Reverse Idler Gear Assembly ---------------------------------------------------------------------------------------- 52 - 53
Differential Assembly ------------------------------------------------------------------------------------------------- 54 - 55
PTO Assembly ----------------------------------------------------------------------------------------------------------- 56 - 57
Rear Axle Assembly ---------------------------------------------------------------------------------------------------- 58 - 59
Brake Assembly --------------------------------------------------------------------------------------------------------- 60 - 61
Clutch Pedal & Linkages --------------------------------------------------------------------------------------------- 62 - 63
Brake Pedal & Linkages ---------------------------------------------------------------------------------------------- 62 - 63
Hand Brake & Linkages ---------------------------------------------------------------------------------------------- 64 - 65

3 6/15/2011, 2:26 PM
INDEX
DESCRIPTION PAGE No.
HYDRAULIC
Hydraulic Lift Housing ------------------------------------------------------------------------------------------------ 68 - 69
Hydraulic Lift Arm Assembly ---------------------------------------------------------------------------------------- 68- 69
Control Valve Assembly ---------------------------------------------------------------------------------------------- 70 - 71
Control Valve O Rings Kit -------------------------------------------------------------------------------------------- 70 - 71
Hydraulic Cylinder Head Assembly -------------------------------------------------------------------------------- 72- 73
Control Valve–Valve Body Assembly ------------------------------------------------------------------------------- 74- 77
Hydraulic Qudrant Assembly --------------------------------------------------------------------------------------- 78 - 79
PC & DC Internal Linkages ------------------------------------------------------------------------------------------ 80 - 81
Bell Crank Assembly --------------------------------------------------------------------------------------------------- 82 - 83
Hydraulic Suction & Pressure Pipe -------------------------------------------------------------------------------- 84 - 85
Three Point Linkages ------------------------------------------------------------------------------------------------- 86 - 87
CHASSIS & SHEET METAL
Front Axle & Support ------------------------------------------------------------------------------------------------- 90 - 91
Foot Plate Assembly --------------------------------------------------------------------------------------------------- 92 - 93
Battery Mounting Tray ----------------------------------------------------------------------------------------------- 92 - 93
Fender Assembly ------------------------------------------------------------------------------------------------------- 94 - 95
Bonnet Assembly (Hood Assembly) ------------------------------------------------------------------------------- 96 - 97
Scuttle & Fuel Tank Assembly --------------------------------------------------------------------------------------- 98 - 99
Wheel Rim & Disc Assembly ----------------------------------------------------------------------------------------- 100 - 101
Seat Assembly ---------------------------------------------------------------------------------------------------------- 100 - 101
Steering Gear Box Assembly ---------------------------------------------------------------------------------------- 102 - 103
Steering Wheel & Linkages ----------------------------------------------------------------------------------------- 104 - 105
Product Graphics & Sticker ----------------------------------------------------------------------------------------- 104 - 105
Hand Accelerator & linkages --------------------------------------------------------------------------------------- 106 - 107
Foot Accelerator & Linkages ---------------------------------------------------------------------------------------- 108 - 109
ELECTRICAL
Lamp Assembly --------------------------------------------------------------------------------------------------------- 112 - 113
Motors & Instruments ------------------------------------------------------------------------------------------------ 114 - 117
Numerical Index ------------------------------------------------------------------------------------------------------ 118 - 125

4 6/15/2011, 2:26 PM
INDEX
ENGINE INTAKE SYSTEM EXHAUST SYSTEM
PAGE - 10 PAGE - 12 PAGE - 14
CYLINDER HEAD ASSEMBLY CRANKCASE ASSEMBLY GOVERNING SYSTEM
LUBRICATION SYSTEM FUEL SYSTEM COOLING SYSTEM

5 6/15/2011, 2:26 PM
INDEX
CLUTCH & CLUTCH HOUSING RAIL ASSEMBLY DIFFERENTIAL ASSEMBLY
PAGE -42 PAGE - 46 PAGE - 54
PTO ASSEMBLY BRAKE ASSEMBLY CLUTCH PEDAL & LINKAGES
HYDRAULIC LIFT HOUSING & CONTROL VALVE ASSEMBLY HYDRAULIC CYLINDER HEAD
ARM ASSY ASSEMBLY

6 6/15/2011, 2:26 PM
INDEX
CONTROL VALVE–VALVE HYDRAULIC QUADRANT BELL CRANK ASSEMBLY

BODY ASSEMBLY ASSEMBLY
HYDRAULIC SUCTION & THREE POINT LINKAGES FRONT AXLE & SUPPORT
PRESSURE PIPE
SCUTTLE & FUEL TANK STEERING GEAR BOX LAMP ASSEMBLY

ASSEMBLY ASSEMBLY
PAGE - 98 PAGE - 102 PAGE - 112

7 6/15/2011, 2:26 PM
215 yuvraj Parts Catalogue 13.6.2011.pmd
8 6/15/2011, 2:13 PM
ENGINE
ENGINE

9 6/15/2011, 2:13 PM
Engine
11

10 6/15/2011, 2:13 PM
Engine
Qty/ Revision
Part No Ref. Description of Part
Tractor No.
210.00215.0155 * ENGINE Assembly 1
006015078B91 * ASSY. Half Engine 1
KIT for Repairs

006010079B91 * KIT Major Engine Repair 1
006013645B91 * KIT Minor Engine Repair 1
006013641B91 * SET of Piston, Rings and Liner Block 1
006009529B1 * GASKET for Cyl. Head 1
006011046B1 * VALVE Stem Seal Rane 2
006009799B1 * INLET Valve - Rane 1
006009801B1 * EXHAUST Valve - Rane 1
006013645B91 KIT Minor Engine Repair
006010083B91 * PACKAGE Gasket Engine 1
006008823B1 * O-Ring 23 X 29 X 3 1
006008836B1 * O-Ring 8 X 12 X 2 6
006008921B1 * O-Ring 152.5 X 157.5 X 2.5 1
006008956B1 * O-Ring 31 X 40 X 4.5 for Protection TU 2
006009030B1 * O-Ring 22 X 16 X 3 1
006008927B1 * SEAL Oil 64 X 90 X 10 1
006008954B1 * SEAL Oil 35 X 47 X 7 for Cam Shaft with 1
006008955B1 * SEAL Oil 40 X 52 X 7 for Crank Shaft WIT 1
006013247B91 * KIT Piston Rings 1
001081618R1 * WASHER Copper 1
005550766R3 * WASHER Copper Temp. Sensor 1
006009054B1 * WASHER 14 X 18 2
006009893B1 * WASHER A8 X 11.5 DIN7603 CU 1
006009042B1 * WASHER 12 X 15.5 2
006009736B1 * SET Main Bearing Standarad 1
006010085B91 * SET Main Bearing Standarad - 0.25 mm Undersize 1
006009735B1 * SET Bearing Con Rod - Standard 1
006010675B1 * SET Bearing Con Rod 0.25mm - Undersize 1
006010676B1 * SET Bearing Con Rod Shel 0.5mm - Undersize 1
006010083B91 * PACKAGE Gasket Engine 1
006009531B1 * GASKET For Breather 1
006009533B1 * GASKET For Exh. Manifold 1
006009534B1 * GASKET For Silencer Bend 1
006009535B1 * GASKET For Air Filter 1
006010323B1 * GASKET Air Intake Manifold 1
006009532B1 * GASKET For Injection Pump 1
006010081B91 * SET of Valves 1
006009799B1 * VALVE Inlet 1
006009801B1 * VALVE Exhaust 1
* Part Not Illustrated 12

11 6/15/2011, 2:13 PM
Intak
Intakee System
15 8
9
7
10
14
11
13
2
1
6
12
1
3
2a
18
19 6
16
20
21
22
17
13

12 6/15/2011, 2:13 PM
Intake System
Intake
Qty/ Revision
Tractor No.
006000999B1 1 STUD M10 2
006009535B1 2 GASKET Intake Manifold Cylinder Head Side 1
006010323B1 2a GASKET Intake Manifold Air Cleaner Side (2 mm Thick) 1
006009660B1 3 MANIFOLD Air Inlet 1
000012248P04 4 BOLT M10 Hex Headed 2
005555988R1 5 WASHER Spring Lock 2
000022055RD 6 NUT M10 Hex Headed 4
006011114B91 7 PRE-AIR Cleaner 1
006001241R1 8 NUT Clamping 1
006012580B1 9 COVER Top 1
006012581B1 10 COLLECTOR Dust 1
006012584B1 11 DISK Bottom 1
006012585B1 12 PIPE Inlet 1
006001249R1 13 CLIP Worm Drive 1
006012582B1 14 RUBBER Ring Bottom 1
006012583B1 15 STUD M6 1
006010912B1 16 FILTER Air Oil Bath 1
006012730B91 17 BOWL Oil 1
006012736B91 18 ASSY. Secondary Top Element 1
006012732B1 19 FOAM 1
006012734B1 20 GASKET Outer 1
006012735B91 21 ASSY. Primary Bottom Element 1
006012731B1 22 PLATE Oil Deflector 1
14

13 6/15/2011, 2:13 PM
Exhaust System
1a
1
1b
1c
15
12
7
14 9
2
13
11 10
4
13
8
3
6
5
15

14 6/15/2011, 2:13 PM
Exhaust System
Qty/ Revision
Tractor No.
006010350B11 1 ASSEMBLY SILENCER 1
‡ 1a SILENCER 1
006012578B1 1b HEAT Shield Lower 1
006012579B1 1c HEAT Shield Upper 1
006009064B1 2 CLAMP Exhaust Manifold 1
006009060B1 3 PIPE Stub 1
000020310E05 4 BOLT Stub Pipe 4
006009534B1 5 GASKET Stub Pipe 1
000934309R1 6 WASHER Spring 4
005553017R1 7 NUT 4
006009057B1 8 MANIFOLD Exhaust 1
006009533B1 10 GASKET Exhaust Manifold 1
006000999B1 11 STUD M10 2
006008962B1 12 STUD M8 1
005555988R1 13 Washer M10 2
000934309R1 14 WASHER M8 4
006008947B1 15 BOLT Hex M8 X 25 1
006014814B91 1 ASSEMBLY SILENCER 1 UY/68/F14/73
006014815B91 * SILENCER HORIZONTAL AGNI W/O TAIL PIPE 1 UY/68/F14/73
006014816B1 * PIPE EXTENSION TAIL AGNI 1 UY/68/F14/73
006009352B91 2 CLAMP EXHAUST 1 UY/68/F14/73
006014817B1 3 PIPE STUB 1 UY/68/F14/73
000020310E05 4 BOLT HEXFL M8 8 UY/68/F14/73
006009534B1 5 GASKET 2 UY/68/F14/73
000934309R1 6 WASHER SPRING L M8 8 UY/68/F14/73
005553017R1 7 NUT HEX M8 8 UY/68/F14/73
‡ Part Not Serviced Seperately 16

15 6/15/2011, 2:13 PM
Cylinder Head Assembly
2
1
4
3
5
7
8
10 9
13
12
11 14
15
16
17
18
19
20
21 23
22
25
24
26
27
29
30
28
38
31
32
33
34
35
36
37
17

16 6/15/2011, 2:13 PM
Cylinder Head Assembly
Qty/ Revision
Tractor No.
006008822B1 1 CAP Oil Inlet 1
006008823B1 2 O Ring Cap Oil Inlet 1
000020255E05 3 BOLT M8 X 40 Hex Headed 1
006008866B1 4 BOLT M8 X 75 Hex Headed 1
000934309R1 5 WASHER Spring Lock M8 2
006009014B1 6 COVER Cylinder Head 1
001233807R1 7 NUT M6 Hex Headed 2
006008982B1 8 STUD M6 2
006009021B91 9 ASSY. Breather 1
006009914B1 10 CLAMP Hose 1
006009913B1 11 ASSY. Pipe Hose Breather 1
006009531B1 12 ASSY. Gasket Breather 1
000020796E05 13 NUT M8 Hex Headed 2
006008992B1 14 SCREW Rocker Arm 2
006008991B2 15 ROCKER Inlet Valve 1 EY/138/F14/33
06008996B2 16 ARM Rocker Exhaust Valve 1 EY/138/F14/33
006008989B1 17 RETAINER Top Valve Spring 2
006008988B1 18 SPRING Valve 2
006008987B1 19 WASHER Valve Spring 2
006008986B1 20 RETAINER Bottom Valve Spring 2
006009240B1 21 NUT Cylinder Head 4
006009912B1 22 WASHER Cylinder Head Nut 4
006009008B1 23 BOLT M6 Hex Headed 2
005551426R2 24 SENSOR Water Temperature 1
005550766R3 25 WASHER Copper Temperature Sensor 1
006009151B91 26 HEAD Cylinder Water Cooled 1
006008997B1 27 SHIM Rocker Shaft - 4.0mm A/R
006009005B1 28 SHAFT Rocker 1
006008836B1 28a ‘O’ Ring 2
005552901R1 30 BOLT M10 Hex Headed 1
006008983B1 31 GUIDE Valve 2
006008990B1 32 COLLET Valve Cap 4
006009799B1 33 VALVE Inlet 1
006009801B1 34 VALVE Exhaust 1
006008978B1 35 SEAT Valve Inlet 1
006008979B1 36 SEAT Valve Exhaust 1
006009529B1 37 GASKET Cylinder Head 1
006011046B1 38 VALVE Stem Seal 2
006009911B1 * Security Plate for Rocker Shaft 2

17 6/15/2011, 2:14 PM
Crankcase Assembly
1
2
7 3
7a
5
6
4
8
13
12
11
9
18
19 15
10
20
22
23
14
12 17 24
16
21 25
37
26
27
38
39
40 31 36
28
41
29 35
42 31
30
43 31
44
32
45
34 33
45
19

18 6/15/2011, 2:14 PM
Crankcase Assembly
Qty/ Revision
Tractor No.
006009290B1 1 STUD Cylinder Head Injector End 2
006009291B1 2 STUD Cylinder Head Rocker Arm End 2
006008961B1 3 DOWEL Cylinder Head 2
006008960B1 4 BLOCK Cylinder 1
000934309R1 6 WASHER Plain 2
006000386F1 7 FLANGE Cylinder Block 1
006013228B1 7a GASKET Flange Cylinder Block 1
006008958B1 8 ROD Push 2
006008957B1 9 TUBE Protection Push Rod 1
006008956B1 10 O RING Protection Tube 2
006009029B91 11 ASSY. Extra Fuel Device 1
006009030B1 12 O RING 2
006008963B1 13 SHIM Cylinder Block 0.2mm 2
006009894B1 13 SHIM Cylinder Block 0.5mm 1
006009031B1 14 SCREW Grub M8 Extra Fuel Device 2
006008832B1 15 CIRCLIP Cam Spindle 2
006008826B1 16 CAM Follower 2
006008827B1 17 SHIM - 0.10mm A/R
006008828B1 17 SHIM - 0.20mm A/R
006008829B1 17 SHIM - 0.30mm A/R
006008830B1 17 SHIM - 0.50mm A/R
006008825B1 18 BRACKET Cam Follower 1
006008975B1 20 SCREW Allen M10 1
006008831B1 21 SPINDLE Cam Follower 1
006008824B1 22 BEARING Ball 1
006016664B1 ◆ BEARING Ball HCH Make 1 AY/260/F12/66
006008942B1 23 CAM Fuel 1
006008943B1 24 CAM Inlet Valve 1 EY/118/F12/63
006008944B1 25 CAM Exhaust Valve 1 EY/118/F12/63
006012363B2 * CAM shaft Intergral 1 EY/118/F12/63
006012363B4 * CAM shaft Intergral for Digital Hour Meter 1 EY/135/F14/20
006008939B1 26 HUB Cam Shaft 1
006008941B1 27 GEAR Cam Shaft 1
006012404B1 27 Gear Camshaft For Intergral Cam Shaft 1 EY/118/F12/63
006016662B1 28 BEARING Ball 1 AY/260/F12/66
006008955B1 29 SEAL Oil Crankshaft 1
006008845B1 30 SCREW Grub M8 1
006009111B1 31 PIN Dowel Crankcase 3
006008946B1 32 COVER Timing 1
006013251B1 32 COVER Timing For Intergral Cam Shaft 1 EY/118/F12/63
000934309R1 33 WASHER Timing Cover Spring 9
* Part Not Illustrated ◆ Alternate Part Number 20

19 6/15/2011, 2:14 PM
Crankcase Assembly
Qty/ Revision
Tractor No.
006009150B91 35 ASSY. Valve Relief 1
006008815B1 36 CRANKCASE 1
006008940B1 37 KEY Cam Shaft 1
006013251B1 37 KEY Cam Shaft For Intergral Cam Shaft 1 EY/118/F12/63
006016661B1 ◆ BEARING Ball HCL Make 1 AY/260/F12/66

Crankcase Assembly
47
49
48
46
50
41
42
43
44
45
45
22

20 6/15/2011, 2:14 PM
Crankcase Assembly
Qty/ Revision
Tractor No.
006009890B1 40 SPACER For Hour Meter 1
006009925B1 41 DRIVE Hour Mechanical 1 EY/118/F12/63
006009112B1 42 COUPLING Flange 1
006009117B1 43 BRACKET Hydraulic Pump 1
006008857B1 45 BOLT HEX M12 X 30 2
000020786E05 * PLUG Hex Socket Pipe M10 X 1 1
000020786E05 46 PLUG Hex Socket Pipe M10 X 1 3
006008817B1 47 STUD M10 4
006008819B1 49 PIN Crankshaft Bearing 1
006008817B1 * STUD M10 X 20 4
000020310E05 50 BOLT HEX 3
40.300 * LIQUID SEALENT LOCKTITE 5060 50 ml
Between Cover & Housing (apprx.)
* Part Not Illustrated

23

21 6/15/2011, 2:14 PM
Crankshaft Assembly
20 43
19 21
15
7 17 26
1 3 5 7 9 11 13
23
22
16 18
2 4 6 8 10 12 14 24
25
35
34
32 41
27 29
42
40
31 36 39
28 33 37 39a
37
30 38
24

22 6/15/2011, 2:14 PM
Crankshaft Assembly
Qty/ Revision
Tractor No.
006009113B1 1 BOLT Tappet For Hydraulic Pump Mtg 4
006009114B1 2 SHELL Rubber 4
006009110B1 3 PULLEY Crankshaft 1
006506443D1 4 BOLT M10 Hex Headed 1
006008950B1 5 WASHER Plain 1
006009902B1 6 SHAFT PTO For Counter Shaft 1
006010098B1 7 KEY 1
006009900B1 8 GEAR Counter Weight 1
006008913B1 9 KEY Crankshaft 1
006008920B1 10 GEAR Crankshaft 1
006008919B1 11 DISC Sliding 1
006008918B1 12 SHELL Ball With Hub 1
006008917B1 13 DISC Ball Hub 1
006008916B1 14 BALL Steel Spherical Dia 12mm 4
006008915B1 15 BALL Hub 1
006008914B1 16 EXTRA SPACER Ring 1
006009888B1 17 SPACER Ring For Governing 1
006008820B1 18 BEARING Main Crankshaft 1
006008821B1 19 BUFFER Bearing Crankshaft 1
006008912B1 20 COVER Crankshaft 1
006010784B91 * CRANKSHAFT Assembly With Weights 1
‡ 21 SHAFT Crank 1
‡ 22 WEIGHT Counter Camshaft Side 1
‡ 23 WEIGHT Counter Flywheel Side 1
006008937B1 25 SCERW Allen M10 4
006008928B1 26 DOWEL Crank shaft 1
006009887B1 27 WAHSER Thrust 2.1mm 1
006009886B1 27 WASHER Thrust 2.5mm 1
006008924B1 27 WAHSER Thrust 1
006009736B1 28 BEARING Main Flywheel Side 1
006008921B1 29 O Ring Crankshaft 1
006008922B1 30 FLANGE Bearing 1
006008927B1 31 SEAL Oil Crankshaft 1
006008855B1 34 FLANGE Engine 1
006008856B1 35 PIN Dowel 2
006008857B1 37 BOLT Hex Headed M12 6
006021353B91 38 ASSY. Flywheel Cpte. 1 KY/136/F14/21
‡ 39 FLYWHEEL
006008931B1 39a GEAR Ring Flywheel 1
006001042B1 40 BUSH Pilot Flywheel 6
006008932B1 41 DISC For Flywheel 1
006008933B1 42 SCERW Allen M12 Flywheel Mounting 6
006014739B1 43 SCREW Allen M10 2 EY/115/F12/27

Crankshaft Assembly
51
52
53
49 50
48
46 47
44
45
44
26

24 6/15/2011, 2:14 PM
Crankshaft Assembly
Qty/ Revision
Tractor No.
006009139B91 44 ROD Connecting 1
006009735B1 45 SET Bearing Con Rod - Standard 1
006010675B1 45 SET Bearing Con Rod 0.25mm - Undersize 1
006010676B1 45 SET Bearing Con Rod 0.5mm - Undersize 1
006009737B1 46 BUSH Connecting Rod Small End 1
006008970B1 47 ASSY. Piston With Pin 1
006008972B1 48 CIRCLIP 2
‡ 49 PISTON 1
006008971B1 50 PIN Piston 1
006013247B91 * ASSY. Kit Piston Ring 1
‡ 51 Ring Piston Top 1
‡ 52 Ring Piston Second 1
‡ 53 Ring Piston Oil Control 1
‡ Part Not Serviced Seperately

27

25 6/15/2011, 2:14 PM
Counter Balance Assembly
2
3
4 8
5
1 6
28

26 6/15/2011, 2:14 PM
Counter Balance Assembly
Qty/ Revision
Tractor No.
006016663B1 ◆ BEARING Ball HCH Make 2 AY/260/F12/66
006008824B1 1 BEARING Ball - 6205 1 EY/124/F13/54
006017848B1 2 WEIGHT Counter Balance New 1 EY/124/F13/54
006009905B1 2 WEIGHT Counter Balance 1
006009910B1 3 CIRCLIP External 1
006009903B1 4 SHAFT Counter Balance Weight 1
006009909B1 5 KEY Counter Balance Shaft 1
006009904B1 6 GEAR Counter Balance Weight 1
006008946B1 7 COVER Timing 1
006013373B1 8 ASSY Shim For Counter Wet 1
◆ Alternate Part Number 29

27 6/15/2011, 2:14 PM
Governing System
1
2
3
6 5
4
8
9
23
22
10
20
19 18
11 17 21
12
13
14
15
16
30

28 6/15/2011, 2:14 PM
Governing System
Qty/ Revision
Tractor No.
006009888B1 1 SPACER Ring for Governing 1
006008914B1 2 SPACER Ring 1
006008915B1 3 HUB Ball 1
006008916B1 4 BALL Steel 12mm 4
006008917B1 5 DISC Ball Hub 1
006008918B1 6 SHELL Ball for Ball Hub 1
006008919B1 7 DISC Sliding 1
006008844B1 8 PIN Cotter 1
006008842B1 9 SPRING Governor 1
006009238B91 10 ASSY. Lever Hand 1
006008838B1 11 LEVER Governor 1
006008895B1 12 KEY Variable Speed Lever 1
006008836B1 13 O RING 2
006008896B1 14 LEVER Pull to Stop 1
006008894B1 15 DISC Friction Governor Lever 1
001231889R1 16 NUT Nylock M10 1
006008835B1 19 SPINDLE Governor Lever 1
006008899B1 20 SPRING Hand Lever 1
005556032R1 21 ALLEN Screw M6 X 1 X 12 2
006008898B2 22 BRACKET Pull to Stop Lever 1
000060683M01 23 NUT M6 Nylock 1
006008843B1 * WASHER Plain 1
006008839B1 * CIRCLIP Governor 1

29 6/15/2011, 2:14 PM
Lubrication System
5 4
16
6 18 14 17
15
20 11
13 12
19
10
22
21 7 8
32

30 6/15/2011, 2:14 PM
Lubrication System
Qty/ Revision
Tractor No.
006008836B1 1 ‘O’ - RING 3
006008852B1 2 DIPSTICK 1
006012168B1 4 SCREW Allen M8 2
006010488B1 5 FILTER Oil 1
006008885B1 6 FLANGE Oil Filter Mounitng 1
001081618R1 7 PLUG Oil Drain 1
000060387M01 8 BOLT M8 Hex Headed 12
006010467B1 10 PAN Oil 1
006008882B1 11 SPACER Oil Pump Gear 1
006008881B1 12 GEAR Oil Pump 1
001231889R1 13 NUT M10 Nylock 1
006010218B1 14 KEY Shaft 1
006010219B1 16 HOUSING Oil Pump 1
000013085P04 18 SWITCH Oil Pressure 1
006011873B1 19 SUCTION Oil Strainer 1
006016758B1 19 SUCTION Oil Strainer 1
000020310E05 20 BOLT M8 Hex Headed 6
006008879B1 * WASHER 1
001081618R1 21 WASHER Copper Drain Plug 1
006010467B1 22 SUMP Oil Pan 1
40.300 * LIQUID Sealent Locktite 5060 50 ml

Between Oil Pan & Crankcase Bottom Face (apprx.)

31 6/15/2011, 2:15 PM
Oil Pump Assembly
34

32 6/15/2011, 2:15 PM
Oil Pump Assembly
Qty/ Revision
Tractor No.
006009239B91 1 ASSY. Pump Oil 1
35

33 6/15/2011, 2:15 PM
Fuel System
1
2
7
6
8
23
11
10
12 25
7 12
20
13 24
15
19
21
17 18
26
1
25
22
2
16 14 17
36

34 6/15/2011, 2:15 PM
Fuel System
Qty/ Revision
Tractor No.
006008980B1 3 STUD M8 2
006009050B1 4 BRACKET Injector 1
006012469B91 5 PIPE Over Flow FIP 1
006009049B91 6 ASSY. Injector FMW 100 1
001081727R2 7 BOLT Banjo 2 FY/09/F12/54
006009893B1 8 WASHER Copper 4
006009045B1 9 PIPE High Pressure 1
006009046B1 11 CLIP High Pressure Pipe 1
006008962B1 13 STUD M8 3
006009532B1 14 GASKET Fuel Injection Pump (Paper Gaskit) 2
006009035B1 15 SHIM FIP - 0.15mm A/R
006009036B1 15 SHIM FIP - 0.20mm A/R
006009037B1 15 SHIM FIP - 0.25mm A/R
006009038B1 15 SHIM FIP - 0.30mm A/R
006009039B91 16 FUEL Injection Pump FMW100 1
006009042B1 17 WASHER Copper M12 2
006009892B1 18 PIPE Fuel Filter to FIP 1
00123293R1 19 BOLT Banjo M14 1
006009054B1 20 WASHER Copper M14 2
006010610B91 21 FILTER Fuel 1
006009068B1 22 BRACKET Fuel Filter 1
006002097B1 23 WASHER Copper for Injector 1
006009044B1 24 BOLT Banjo M12 1 FY/09/F12/54
001081778R93 25 FILTER Element 1
001082277R1 26 RING Sealing 1
006016084B91 * Kit Conversion to Relief Valve Design 1 FY/09/F12/54
006016005B1 * Relief valve 1 FY/09/F12/54
006015378B91 5 Injector Overflow Pipe 1 FY/09/F12/54
006009042B1 8 Joint Washer 12 X 15.5_AGNI 3 FY/09/F12/54
006008898B2 * Bracket Pull to Stop 1 FY/09/F12/54
37

35 6/15/2011, 2:15 PM
Cooling System
5 15
17
18
24
26 16
1
2 4 9 3
8 10 11
7
3
19 21 5
13 14 3
27
12
22 3
20
5 6
30
23
25 29 28
38

36 6/15/2011, 2:15 PM
Cooling System
Qty/ Revision
Tractor No.
006009152B91 1 ASSY. Radiator 1
003041407R2 2 SPACER Rectangular 1
006001061B1 3 BOLT M8 Hex Headed 4 HY/10/F12/09
006009345B1 4 FAN Radiator Cooling 1
006009108B1 5 CLAMP Hose 6
006009105B2 6 PIPE Hose Radiator to Water Pump 1
006013467B1 6 PIPE Hose Radiator To Water Pump 1 HY/10/F12/09
006009008B1 7 BOLTS M6 Hex Headed 4
006009096B1 8 SPACER Radiator Fan 1
006009109B1 9 V Belt 1
006009090B1 10 BRACKET Water Pump Mounting 1
006013460B1 10 BRACKET Water Pump Mounting 1 HY/10/F12/09
006009094B91 11 ASSY. Pump Water 1
006009091B1 12 STRIP Top Water Pump Mounting 1
006009949B1 13 PIPE Hose Inlet Water Pump to Engine 1
006013472B1 13 PIPE Hose Inlet Water Pump to Engine 1 HY/10/F12/09
006009099B1 14 FLANGE for Water Inlet 1
006009107B2 15 PIPE Hose Outlet Engine to Radiator 1
006009102B1 16 FLANGE for Water Outlet 1
006009724B1 17 BRACER Radiator 1
‡ 18 BEADING Top Sealing 1
‡ 19 BOLT M6 Hex Headed 2
‡ 20 WASHER Plain 2
‡ 21 PLATE Top Radiator Sealing 1
‡ 22 PLATE Side Radiator Sealing - RH 1
‡ 23 PLATE Side Radiator Sealing - LH 1
006012234B1 24 COWL Radiator 1
006012235B1 25 PLUG Drain Radiator 1
006012236B1 26 CAP Pressure Radiator 1
006012237B1 27 GUARD Thrash 1
007539391B1 28 BEADING Radiator Sealing 1
007539387B1 29 PAD Foam Radiator Sealing Side 2
008001656B1 30 RADIATOR Mounting Bracket 1


37 6/15/2011, 2:15 PM
* Part Not Illustrated

Water Pump Assembly
40

38 6/15/2011, 2:15 PM
Water Pump Assembly
Qty/ Revision
Tractor No.
006009094B91 1 ASSY. Pump Water (LION Make) 1
006011797B91 1 ASSY. Pump Water (SFL Make) 1 HY/10/F12/09
006010533B1 2 PULLEY Water Pump (LION Make) 1
006016106B1 * GASKET Water Pump (SFL Make) 2 HY/10/F12/09

39 6/15/2011, 2:15 PM
40 6/15/2011, 2:15 PM
TRANSMIS
TRANSMIS SION
SION
TRANSMISSION

41 6/15/2011, 2:15 PM
Clutch Cover Assembly
Clutch Housing & Connection

9
20
10 11 12
13
7 8 9 1
19 14
15
17
16
18
8 9
2
3
44

42 6/15/2011, 2:15 PM
Clutch Cover Assembly
Qty/ Revision
Tractor No.
006507356B91 1 ASSY. Cover Cltuch 1
006507447B92 2 Plate Clutch 1 JY/24/F14/64
000934309R1 * WASHER Spring Lock 6
000022271RD * BOLT Clutch Mounitng 6
Clutch Housing & Connection

006505890B1 1 HOUSING Clutch 1
000022273RD 2 WASHER Spring Lock M10 8
001233891R1 3 BOLT M10 Clutch Housing to Transcase 8
006506556B1 4 GASKET Rubber Hand Hole Cover 1
006506558B1 5 COVER Hand Hole 1
000020308E05 6 BOLT M8 Hand Hole Cover Flange Headed 6
006507257B11 7 SHAFT Clutch Release 1
001127629R2 8 CIRCLIP Clutch Release Shaft 2
000109462 9 NIPPLE Grease Clutch Release Shaft 3
000022271RD 10 BOLT M8 Spring Holding Bkt 1
000934309R1 * WASHER Spring Lock M8 1
006507305B1 11 BRACKET Spring Holding 1
006506555B1 12 SLEEVE Clutch Release 1
006507044B1 13 BEARING Clutch Release 1
005553025R1 14 FORK Clutch Release 1
005556882R1 15 SPACER Clutch Release Fork 1
003047229R4 16 KEY Clutch Release Lever 1
000706732R1 18 BOLT Clutch Release Fork Clamping 2
005550488R1 19 SPRING Clutch Release Sleeve 1
000020280E05 20 DOWEL For Steering Mouting 2

43 6/15/2011, 2:15 PM
Transmission Drive Shaft Assembly
1
2
Transmission
Transmission Case
Case
3
2
46

44 6/15/2011, 2:15 PM
Transmission Drive Shaft Assembly
Qty/ Revision
Tractor No.
006505809B1 1 SHAFT Drive Transmission 1
006505895B1 2 COUPLING Drive Shaft 1
001233156R1 3 PIN Roll Drive Shaft 2
006509772B1 4 PIN Roll 2
Transmission Case
006505819B1 1 CASE Transmission 1
006511358B1 1 CASE TRANSMISSION ( For Spiral Bevel Set of Two ) 1 KY/109/F14/53
006508763B1 2 PIN Dowel 2
005554986R1 3 PLUG Expansion 1
005556606R1 4 PLUG Drain Magnetic 1
006508763B1 * PIN Dowel PTO Cover 2
006507260B1 5 STUD Hdraulic Mounting 2
008002872B1 * DOWEL for Hand Brake 1
008001780B1 * DOWEL Clutch Stopper 1

45 6/15/2011, 2:15 PM
Rail Assembly
22
2
3
23 4
3 5
27
24
26
12
6
11 8
7
8 10
13
11
9
26 14 15
7 6
8
10
8 20
7 21
6 17
11
16
26
14
19
25
18
48

46 6/15/2011, 2:15 PM
Qty/ Revision
Tractor No.
006506634B91 1 DIPSTICK Transmission 1
005558246R1 2 WASHER Copper Dipstick 1
000020309E05 3 BOLT M8 Flange Headed 9
006508837B1 4 COVER Transmission 1
006506474B91 5 LEVER Gear Shift 1
007535084C1 6 CIRCLIP 3
006506471B1 7 WASHER Shifter Shaft 3
006507465B1 8 SEAL Oil Shifter Shaft (0.625’’X1.125”X0.375”) 4
006505981B1 9 SHAFT Range Shifter 1
006506473B91 10 SHIFTER Cam Gear 2
001233156R1 11 PIN Roll 3
006506475B91 12 LEVER Range Shifter 1
006506475B91 12 LEVER Range Shifter 1 UY/66/F14/46
006511982B11 13 LINK Connecting Gear Shifter 1 KY/97/F13/69
007203302B1 * PIN Clevis Dia 8mm 1 KY/97/F13/69
007535860D1 * WASHER Spring Lock 1 KY/97/F13/69
006505967B1 14 FORK Gear Shifting 2
006507943B11 15 SHAFT Gear Shifter 1
006509934B1 16 SPRING Rail 2
006503662C1 17 BALL For Rail 8mm 2
006505966B1 18 RAIL Gear Shifting 1
006506341B1 19 SCREW Grub - Shifting Rail 1
000120393 20 WASHER Plain Connecting Link 2
000103373 21 PIN Cotter 2
008002639B1 22 KNOB Gear shifter Lever 1
008002640B1 23 KNOB Hi Low Reverse Gear Shifter Lever 1
000109462 24 NIPPLE Grease 1
000020723E05 25 WASHER Seal 1
006509772B1 26 PIN Slotted Spring 3
006506802B1 27 GASKET TC Cover 1
005557810R1 * Bolt M8 x 22 - T.C. Cover 1
000060686M01 * WASHER Plain M8 - H3 - TC. Cover 1
49
215 yuvaj Parts Catalogue 13.6.2011.pmd

47 6/15/2011, 2:16 PM
Counter Shaft Assembly
10
9
7
5 6
4
3
2
18
4
1
6
17
14
15
14
16
15
14
12
13
12
11
50

48 6/15/2011, 2:16 PM
Counter Shaft Assembly
Qty/ Revision
Tractor No.
000022271RD 1 BOLT M8 Hex Headed Counter Shaft Retainer 3
000934309R1 2 WASHER Spring Lock Retainer Counter Shaft 3
006506907B1 3 SEAL Oil Counter Shaft (25 X 45 X 08) 1
000032097B12 4 CIRCLIP External Counter Shaft 2
006505857B1 5 RETAINER Counter Shaft 1
006507466B1 6 BEARING Front Counter Shaft (6205) 2
006511389B1 ◆ BEARING Front Counter Shaft (6205) 2 AY/260/F12/66
006505631D1 7 CIRCLIP Internal Retainer Bearing 1
006505875B1 8 SHAFT Counter 1
000012353P04 9 CIRCLIP External 1
006505768D1 10 SHIMS Layshaft - 0.5 mm A/R
006505812B1 11 GEAR 2nd & 3rd Driving 1
006506338B1 12 SPACER Front Counter Shaft 2
006507467B1 13 BEARING Middle Counter Shaft (6206) 1
006511388B1 ◆ BEARING Middle Counter Shaft HCL Make 1 AY/260/F12/66
006506852B1 14 BEARING Needle Roller CM, Low & Reverse Gear (30X37X16) 3
006505862B1 15 SPACER Plastic CM, Low & Reverse Gear 2
006505810B1 16 GEAR Driving CM, Low & Reverse Gear 1
006506483B1 17 SPACER Rear Counter Shaft 1
006506336B1 18 BUSH Sintered Counter Shaft 1
◆ Alternate Part No 52

49 6/15/2011, 2:16 PM
Spline Shaft Assembly
10
8
9
7
5 6
3
2 4
1
23
22
21
20
19
18
17
15 16
13 14
12
11
52

50 6/15/2011, 2:16 PM
Spline Shaft Assembly
Qty/ Revision
Tractor No.
000022271RD 1 BOLT M8 Hex Headed Spline Shaft Retainer 3
006506479B1 3 RETAINER Spline Shaft 1
006502942C1 4 CIRCLIP Spline Shaft 1
006506847B1 5 BEARING Front Spline Shaft (6304 NR) 1
006505860B1 6 SPACER Front Spline Shaft 1
006505616D1 7 BEARING Needle Spline Shaft (25 X 30 X 17) 1
006505815B1 8 GEAR Driven 1st Speed 1
006505861B1 9 SPACER Rear Spline Shaft 1
006505813B1 10 GEAR Driven 2nd & 3rd 1
000012230P04 11 CIRCLIP Mid Spline Shaft 1
006507467B1 12 BEARING Middle Spline Shaft (6206) 1
006511388B1 ◆ BEARING Middle Spline Shaft HCL Make 1 AY/260/F12/66
006506478B1 13 SHAFT Spline 1
006505811B1 14 GEAR Driven Low Speed 1
000012353P04 15 CIRCLIP External Pinion Shaft 1
006508526B1 16 SPACER Bevel Pinion Shaft 1
006505490D1 17 SHIMS Bevel Pinion Shaft 0.5 mm A/R
006506848B1 18 BEARING Double Bevel Pinion Shaft 1
006505855B1 19 BEVEL Pinion Shaft 1
006507335B1 20 WASHER Bearing Retainer 1
006507336B1 21 PLATE Lock 1
006505619D1 23 BEARING Needle Pilot Spline Shaft (18 X 24 X 20) 1

51 6/15/2011, 2:16 PM
Reverse Idler Gear Assembly
5
4
3
2
2
54

52 6/15/2011, 2:16 PM
Reverse Idler Gear Assembly
Qty/ Revision
Tractor No.
006505858B1 1 SHAFT Reverse Idler 1
006506868B1 2 BEARING Needle Reverse Idler Gear (22 X 30 X 15) 2
006505818B1 3 GEAR Reverse Idler 1
006505859B1 4 WASHER Thrust 1
006500927C1 5 CIRCLIP Reverse Idler Shaft 1
006506636B1 6 SCREW Grub 1
000020723E05 7 WASHER Seal 1

53 6/15/2011, 2:16 PM
Differential Assembly
11
8 12
6
5 7
7a 9 10
3 4
1
2
18 21
19
17
14 15
16
20
13
18
2 1
4 23
5
7 6
9 7a
10 8
12
11
22
56

54 6/15/2011, 2:16 PM
Differential Assembly
Qty/ Revision
Tractor No.
005554915R1 1 BOLT M10 Bull Cage Mounting (M10 X 40) 12
006506909B1 2 SEAL Oil Bull Shaft 2
006506809B1 3 CAGE Bull - RH 1
006506828B1 4 O RING Bull Cage 2
006506680B1 5 SHIM Bull Cage - 0.15 mm A/R
006506681B1 5 SHIM Bull Cage - 0.25 mm A/R
006506683B1 5 SHIM Bull Cage - 0.1mm A/R
006506667B1 6 PLATE Adaptor Bull Cage 2
006507469B1 7 BEARING Bull Shaft (6308) 2
006511387B1 ◆ BEARING Bull Shaft HCL Make 2 AY/260/F12/66
000012128P04 7a SHIM - 0.5 mm A/R
000012204P04 7a SHIM - 0.2 mm A/R
000012205P04 7a SHIM - 0.05 mm A/R
006506965D1 8 CIRCLIP Bull Cage 2
000032140B12 9 NUT Stud Differential 2
006508540B1 10 PLATE Lock Bull Shaft 2
006506836B1 11 O RING Adjuster Shaft 2
006509406B1 12 INTEGRAL Stud 2
006509405B1 13 SHAFT Bull - RH 1
‡ 14 RING Gear 1
006505880B1 15 PINION Differential 2
006509432B1 16 SHAFT Differential Pinion 1
006511199B1 17 CROSS Shaft Ring Gear 1 KY/92/F12/65
001233156R1 18 PIN Roll 1
006506671B1 19 PLATE Lock Single Bolt 2
006506670B1 20 PLATE Lock Double Bolt 2
006505658D1 21 BOLT M10 Ring Gear Mounting 6
006509404B1 22 SHAFT Bull - LH 1
006505846B1 23 CAGE Bull - LH 1
006508665B91 * SET Of Two (Straight Bevel) 1
‡ 14 RING Gear
‡ * BEVEL Pinion Shaft
006511038B91 * SET OF TWO 9T/43T ( Spiral Bevel ) 1 KY/109/F14/53
006511363B1 * PLATE BEARING COVER 1 KY/109/F14/53
‡ Part Not Serviced Seperately ◆ Alternate Part No

57(

55 6/15/2011, 2:16 PM
PTO Assembly
6 7 8 9
5 2
4
3
33 1 2
10
12
15 14 13
16
31 17
18
29 11 19
30
28 27 21 20
26 22
23
24
25
32
58

56 6/15/2011, 2:16 PM
PTO Assembly
Qty/ Revision
Tractor No.
006506337B1 1 COUPLING PTO Shaft 1
000032097B12 2 CIRCLIP PTO Drive Shaft 2
006506357B1 3 SHAFT Driving PTO 1
006505630D1 4 CIRCLIP PTO Drive Shaft Bearing 1
006507466B1 5 BEARING PTO Drive Shaft (6205) 1
006511389B1 ◆ BEARING PTO Drive Shaft (6205) HCL Make 1 AY/260/F12/66
006505850B1 6 HOUSING PTO 1
000934309R1 7 WASHER PTO Housing 10
000022271RD 8 BOLT PTO Housing 9
005555715R1 9 PLUG Welch 1
000020307E05 10 BOLT M8 PTO Oil Seal Retainer 3
008001560B1 11 KNOB PTO Lever 1
006508535B1 12 RETAINER PTO Oil Seal 1
006508536B1 13 GASKET PTO Oil Seal Retainer 1
005558067R91 14 SEAL Oil PTO Shaft 1
000012353P04 15 CIRCLIP Main PTO Shaft 1
006505768D1 16 SHIMS - 0.5 mm A/R
006505769D1 16 SHIMS - 0.2 mm A/R
006505770D1 16 SHIMS - 0.05 mm A/R
006507939B1 17 BEARING Outer Main PTO Shaft (6207 ZR) 1
006511390B1 ◆ BEARING Outer Main PTO Shaft 1 AY/260/F12/66
006505856B1 18 SHAFT PTO Main 1
006506484B1 19 SPACER PTO Shaft Rear 1
006505817B1 20 GEAR Driven PTO 1
006506688B1 21 SPACER PTO Shaft Front 1
006507466B1 22 BEARING Inner PTO Shaft (6205) 1
006511389B1 ◆ BEARING Inner PTO Shaft HCL Make 1 AY/260/F12/66
000032097B12 23 CIRCLIP Front Main PTO Shaft 1
006506801B91 24 ASSY. PTO Shifter Lever 1
001233156R1 25 PIN Roll 1
006002571B1 26 BOLT PTO Clamping Plate 1
000934309R1 27 WASHER Spring Lock PTO Clamping Plate 1
006506800B1 28 PLATE PTO Clamping 1
006506343B1 29 SHAFT PTO Shifter 1
006506794B91 30 ASSY. Cam PTO Shifter 1
005551581R1 31 PIN Roll PTO Shifter Cam 1
006509934B1 * SPRING PTO Lever 1
006503662C1 * BALL PTO Lever 1
006507465B1 * SEAL Oil PTO Shifter 1
006509772B1 32 PIN SLOTTED SPRING 1
LIQUID Gasket 515 For PTO Housing 50 ml

(approx)
008001618B1 33 PTO Safety Cap 1
* Part Not Illustrated ◆ Alternate Part No 59

57 6/15/2011, 2:16 PM
Rear Axle Assembly
14
15 16
12 13
11
7
8
7
6
5 6
3 4
2
1
9 10
60

58 6/15/2011, 2:16 PM
Rear Axle Assembly
Qty/ Revision
Tractor No.
006505888B1 1 AXLE Rear 2
005555827R1 2 BOLT Wheel 10
000022271RD 3 BOLT M8 Rear Axle Retainer 8
006505852B1 5 RETAINER Rear Axle 2
006506912B1 6 SEAL Oil Double Lip Rear Axle Retainer (45 X 62 X 9) 4
006507469B1 7 BEARING Rear Axle (6308) 4
006511387B1 ◆ BEARING Rear Axle HCL Make 4 AY/260/F12/66
006505847B1 8 CARRIER Rear Axle - LH 1
006505848B1 8 CARRIER Rear Axle - RH 1
000020294SH 9 BOLT M10 hex Headed RAC Mounting 14
000022273RD 10 WASHER Spring Lock 14
006507253B1 11 SHIMS Rear Axle - 0.15 mm A/R
006506965D1 12 CIRCLIP Rear Axle Inner 2
006507251B1 13 SPACER Conical Bull Gear 2
006505823B1 14 GEAR Bull 2
006505990B1 15 PLATE Lock Bull Gear 2
006507252B1 16 NUT Lock Bull Gear 2
LIQUID Gasket 515 For RAC Mounting 50 ml
(approx)

59 6/15/2011, 2:16 PM
Brak
Brakee Assembly
25
24
1 2 26
27
4
5 7
10 5
6
4
9
3
8
12 10
11
13
14
16
17 15
18 21
19
17
22
18
20
22
23
62

60 6/15/2011, 2:16 PM
Brake Assembly
Brake
Qty/ Revision
Tractor No.
006507358B91 * ASSY. Brake - LH 1
006507359B91 * ASSY. Brake - RH 1
005556320R1 1 BOLT M10 Hex Headed Brake Mounting 8
000022273RD 2 WASHER Spring Lock Brake housing 8
006508606B1 3 HOUSING Brake - LH 1
006508607B1 3 HOUSING Brake - RH 1
006508608B91 4 ASSY. Disc Friction lined 4
006508609B91 * ASSY. Disc Actuating consist of 2
‡ 5 DISC Actuating 2
006508611B1 6 ASSY. Ball Actuating 4
006508612B1 7 SPRING Actuating Disc 2
006508613B1 8 LINK Cranked 2
006508614B1 9 PIN Pivot 2
‡ 10 NUT Lock 2
006508616B1 11 PIN Jaw 1
006508617B1 12 R Pin 1
006508618B1 13 ROD Pull 1
‡ 14 RING Steel 1
006508619B1 15 BOOT Rubber With Steel Ring 1
006508620B1 16 PIN Tension Link 1
006508612B1 17 PIN Split 5
006508623B1 19 LINK Tension 2
006508624B1 20 TRUNNION Block 2
006508625B1 21 NUT Hex Headed 1
‡ 22 NUT Lock Tension Link 2
006508627B1 23 ROD Pull 1
005556470R91 24 BREATHER Brake 2
005556465R1 25 BOLT Pipe Union Breather 1
005556469R1 26 PIPE Breather 1
005556486R1 27 WASHER Copper 2
KIT For Repair

006508630B91 * LINER Kit Brake Service 1
006508629B1 * LINER Brake 8
‡ * RIVET 32


61 6/15/2011, 2:16 PM
Clutch Pedal & Linkages
1
8
4 1 2
3
2
9
Brake
Brak e Pedal & Link ages
Linkages
8 9
12
2
10
11
4
3
5
11 2
13
6
7
64

62 6/15/2011, 2:16 PM
Clutch Pedal & Linkages
Qty/ Revision
Tractor No.
000103374 1 PIN Cotter 2
000120396 2 WASHER Plain 3
008002879B1 3 PIN Headed 2
008001465B11 4 ASSY. Clutch Linkage Longer 1
008001432B11 5 PEDAL Clutch 1
008001473B1 6 WASHER Clutch Pedal 1
000705252R3 7 SPRING Clutch Pedal 1
008001501B1 8 BUSH Clutch Pedal 2
008001780B1 * PIN Dowel Clutch Pedal 1
Brake Pedal & Link

Brake ages
Linkages
008001526B11 1 PEDAL Brake - RH 1
000705252R3 2 SPRING Brake Pedal 2
003064219R3 3 HEADED Pin Brake Shaft 2
000103374 5 PIN Cotter 2
008001473B1 6 WASHER Plain Brake Pedal 2
008001501B1 7 BUSH Brake Pedal 2
008001538B11 8 PEDAL Brake - LH 1
000124556 9 KEY Woodruff 1
008001187B11 10 SHAFT Brake 1
008001240B91 11 RUBBER Pad 2
000103411 12 PIN Cotter 1

63 6/15/2011, 2:16 PM
Hand Brak
Brakee & Link ages
Linkages
2
8
1
5
6 3
66

64 6/15/2011, 2:17 PM
Hand Brake & Link
Brake ages
Linkages
Qty/ Revision
Tractor No.
008001240B91 1 KNOB Hand Brake 1
008002872B1 2 DOWEL (Stopper) 1
008001241B11 3 HAND Brake Cpte 1
001081607R1 4 BOLT M8 Hand Brake Spring 1
000060686M01 5 WASHER Plain 1
000060684M01 6 BOLT M8 Hand Brake Mtg 1
000042000C11 7 SPRING Hand Brake 1
008002691B1 8 BUSH Hand Brake 1

65 6/15/2011, 2:17 PM
66 6/15/2011, 2:17 PM
HYDRA
HYDRA ULIC
ULIC
HYDRAULIC
ULICSS S

67 6/15/2011, 2:17 PM
Hydraulic Lift Housing
2
4 1
3 6
Hydraulic Lift Arm Assembly
4 7
2 3 5 6
1
2
10 1
9 5
3
13 6
4
8
11
12
70

68 6/15/2011, 2:17 PM
Hydraulic Lift Housing
Qty/ Revision
Tractor No.
007205025B91 * Assy. Hydraulic 1 PY/68/F13/44
007203164B91 * ASSY. Hydraulic 1
007203157B1 1 HOUSING Hydraulic Lift 1
007204345B1 1 HOUSING Hydraulic Lift New 1 PY/68/F13/44
005554657R91 2 ASSY. Breather Hydraulic Housing 1
007540522B1 3 BOLT Hydraulic Mounting 3
006510233B1 4 BOLT Flange Hex Hydraulic Mounting 2
007205397B1 4 BOLT Allen Hydraulic Mounting New 2 PY/68/F13/44
006510231B1 5 BOLT Flange Hex M10 1
006510518B1 6 NUT Flange Hex M10 2
Hydraulic Lift Arm Assembly

000032060B12 1 CIRCLIP Rockshaft 2
007203162B1 2 ASSY. Arm Lift Hydraulic 2
007204310B1 2 ARM Lift Hydraulic Assembly New 2 PY/68/F13/44
007203161B1 3 WASHER Oil Seal 2
007000048B1 4 SHIM Rockshaft A/R
007000010B1 5 SEAL Oil Rockshaft 2
007000009B1 6 BUSH Rockshaft 4
007203158B1 7 ROCKSHAFT Hdraulic 1
007203158B1 7 ROCKSHAFT Hydraulic New 1 PY/68/F13/44
007203159B1 8 ARM Rocker Hydraulic 1
007000053B1 9 BOLT M8 2
000934309R1 10 WASHER Spring Lock for CAM 1
007203163B1 11 ROD Connecting Hydraulic 1
000455183R1 12 PIN Slotted Spring 1
007203160B1 13 CAM Hydraulic 1

69 6/15/2011, 2:17 PM
Control V alve Assembly
Valve
4
3
6
alve O Rings Kit

Valve
Control V
3 3
6 1 2
4 5
72

70 6/15/2011, 2:17 PM
Control Valve Assembly
Valve
Qty/ Revision
Tractor No.
007203892B91 1 ASSY. Valve Control - 40HP 1
000179891 2 BOLT 7
000179890 3 BOLT 1
005558124R1 5 PLUG BSP Tapping Auxillary 1
000704337R1 6 WASHER Sealing BSP 1
000751580R3 7 BOLT Needle Valve Cover 1
003045118R1 8 WASHER 1
Control Valve O Rings Kit

Valve
005554404R1 1 ‘O’ RING Cylinder Head Face Ring 1
001232895R1 1 ‘O’ RING Cylinder Head Face Ring 1
005554405R1 2 ‘O’ RING – Spigot 1
000381871R1 2 ‘O’ RING – Spigot 1
000021433R1 3 ‘O’ RING Pressure Oulet 2
000377952R1 4 ‘O’ RING 2
003067183R1 5 ‘O’ RING Pressure Inlet 1
000379365R1 6 ‘O’ RING 1
73

71 6/15/2011, 2:17 PM
Hydraulic Cylinder Head Assembly
5
6
7
8
9
10 12
11
13
15
17
16 2
14
1
28
27
21
20
19
18 28 22
26
23
24
25
74

72 6/15/2011, 2:17 PM
Hydraulic Cylinder Head Assembly
Qty/ Revision
Tractor No.
000051712D01 * HEAD Cylinder Sub-Assembly (40HP Category) 1
000051708D02 * ASSY. Head Cylinder with Sleeve (40HP) 1
‡ 1 SLEEVE 1
000050857D01 22 SPOOL Compensator Flow 1
000050925D01 2 SPACER Compensator 1
‡ * WASHER Dowty 1
‡ 16 PLUG 1
000379365R1 * ‘O’ RING 2
000021433R1 * ‘O’ RING 2
003067183R1 * ‘O’ RING 1
001232895R1 * ‘O’ RING 1
005556038R1 * ‘O’ RING Rectangular 1
000381871R1 * ‘O’ RING 1
003045102R21 * ASSY. Valve Isolating 1
003045113R2 3 KNOB Isolating Valve Shut / Open 1
000017047R1 4 SPRING Pin 1
003045107R1 8 SHAFT Isolator Valve Knob 1
000023524R1 9 ‘O’ RING 1
003045104R1 5 PLATE Stop 1
003045106R1 11 BUSH Isolator Valve 1
003045116R1 10 ‘O’ RING 1
003045102R2 13 VALVE Isolator 1
000443137 12 PIN Groove 1
003067146R1 15 SEAT Isolator Valve 1
000179793 6 BOLT 2
000051165D01 23 SPRING Compensator 1
000051167D01 24 ASSY. Plug Retainer 1
003047246R1 25 CIRCLIP Internal 1
000751580R3 18 BOLT Valve Needle Cover 1
003045118R1 19 WASHER Dowty 1
003047294R95 20 ASSY. Orfice 1
000384937R1 21 ‘O’ RING 1
000377952R1 * ‘O’ RING 1
‡ * WASHER Spring Lock 2
000179796 * BOLT 1
000179799 * BOLT 1
003108188R1 * PLUG 1
‡ * PIN Slotted 1
000179890 26 BOLT 1
000179891 27 BOLT 7
001231204R1 * LOCK Isolating Valve 1


73 6/15/2011, 2:17 PM
Control V alve–V
Valve–V alve Body Assembly
alve–Valve
11
**
8
10
8
7
6
2 4 39
58
9 36
5 37
3 36
34 35 24
12 33
32
21
20
19 53
23
18 23
17
16
27 31
30
29
28
26 13
25
14
15
76

74 6/15/2011, 2:17 PM
Control Valve–V
Valve–Valve Body Assembly
alve–Valve
Qty/ Revision
Tractor No.
007203020B91 1 ASSY. Valve Body 40 HP
007203385B91 ** ASSY. Piston with RV & Rings 40 HP 1
000051521D01 2 PLUG Relief Valve 1
000051524D01 3 BALL 1
000379365R1 4 ‘O’ RING 1
000051523D01 5 RIDER Relief Valve Ball 1
003066410R1 6 SPRING Unloader Valve 1
‡ 7 PISTON 1
000387374R1 8 RING Cylinder Bearing 40 HP 2
000025205R1 9 SEAL Ring Retangular Section 40 HP 1
000545813R2 10 RING Outer Seal 40 HP 1
007203187B1 11 LIFT Cylinder Hydraulic - 40 HP 1
005555283R3 12 GASKET Valve Body 1
000444687 15 PLUG 4
‡ 14 ASSY. Bore Main Control Valve
000385713R1 16 ‘O’ RING 1
000051166D01 17 PLUG Main Sleeve 1
000050936D01 18 SPRING Main Valve 1
‡ 19 SLEEVE Control Valve 1
003040910R1 20 CIRCLIP 1
000051152D01 21 SPOOL Control Valve 1
007203170B11 23 ASSY. Spool Extension 1
007204019B1 24 SCREW Allen 1
000051695D01 * WASHER Spring Lock 1
‡ 13 ASSY. Relief Valve Bore
007200832C1 25 SEAT Relief Valve integrated 1
000377952R1 26 ‘O’ RING 1
003108946R3 28 BALL Rider Non Return Valve 1
003072883R1 27 BALL 3/8” Relief Valve 1
000751557R2 29 SPRING Relief Valve 1
0003110027R1 30 SHIMS Steel A/R
58 ASSY. Regulating Valve Bore
003108947R2 31 RELIEF Valve Spring Housing 1
000352026R2 32 SPRING Flow Control Valve Ball 1
000350084R2 33 RIDER Ball 1
003072912R1 34 BALL Flow Conrol Valve 1
000050993D01 35 SEAT Ball Valve 1
000704378R1 36 ‘O’ RING 1
007201178A91 37 ASSY. Piston Regulating - Reduced Width
007200882A91 * ASSY. Piston Regulating
000385713R1 38 RING Bearing - Indigenous 1
007201599B1
005557647R1 38 RING Bearing - Imported 1
007201180A1 39 GLIDE Ring - Indigenous 1
005554906R1 39 GLIDE Ring - Imported 1

Alternate Part Number

75 6/15/2011, 2:17 PM
Control V alve–V
Valve–V alve Body Assembly
alve–Valve
58
56
55
53
52
51
54
55
50
48 49
46 47
45
43 44
52
78

76 6/15/2011, 2:17 PM
Control Valve–V
Valve–Valve Body Assembly
alve–Valve
Qty/ Revision
Tractor No.
000050992D01 40 PLUG Valve 1
005557646R1 41 ‘O’ RING Below Glide Ring 1
000751567R1 42 CIRCLIP (Internal) 1
000379365R1 * ‘O’ RING 1
000444697 51 PLUG Nptf 1
000051228D01 * ORIFICE 1
55 ASSY. Bore Check Valve Comprising of
007200369C1 43 SPRING Check Valve Retainer 1
000051157D01 44 RETAINER Check Valve 1
000051155D01 45 SLEEVE Check Valve Ball 1
003074227R2 46 SPRING Non Return Valve 1
003063495R1 47 BALL Rider Non Return Valve 1
003072883R1 48 BALL 3/8” Non Return Valve 1
000051182D01 49 SEAT Check Valve 40 & 60 HP 1
000051181D01 50 ‘O’ RING 60 HP & 40 HP 1
007202286B91 * SEAL Ring KIT - Regulating Piston - Reduced Width 1
000051365D01 * ‘O’ RING Kit For 40 HP Hy - Tec Hydraulics 1
007205393B1 52 SCREW Allen M5 1
007203387B1 53 SPRING Feedback 1
007203176B1 54 WASHER Feedback 1
007203175B1 55 PIN Feedback 1
000103373 56 PIN Cotter 1
000051695D01 * WASHER Spring Lock Spool End Cap 1

77 6/15/2011, 2:17 PM
Hydraulic Qudrant Assembly
10
11
25
24 23
19 14 13
7 13
6 12
1 2
28
9
8
4 5
17 20
11
26
21
25 12
22 27
25
16
18
15
26
24 3
23
29
80

78 6/15/2011, 2:17 PM
Hydraulic Quadrant Assembly
Qty/ Revision
Tractor No.
001231899R1 1 BOLT M10 Qudrant Tightening 2
007203219B1 2 PLATE Spring Retainer 1
001231334R91 3 NUT Stop Control Lever 1
000180120 4 BOLT Hex Headed 2
005555967R1 5 STRIP Quadrant 1
007205118B11 6 SLIDE Draft Control Lever with Pin 1
007203558B1 7 SPACER DC Quadrant 2
007200949E1 8 SPRING Hydraulic Quadrant 1
007203248B11 9 ASSY. Lever Draft Control 1
005556899R1 10 KNOB Draft Control 1
005556032R1 11 BOLT Allen M6 Draft Control Knob 2
000377952R1 12 O Ring Draft Control Lever 2
003044397R1 13 DISC Friction Hydraulic Quadrant 2
007203221B1 14 PLATE Friction Retainer Hydraulic Quadrant 1
007203210B11 15 ASSY. Lever Position Control 1
‡ 16 WASHER Quadrant 1
005556901R1 17 KNOB Positon Control Lever 1
000350818R1 18 O Ring Position Control Lever 1
000051061D01 19 STOP Position Control Lever 1
003044388R2 20 STOP Control Lever 1
007203785B1 21 PLATE Quadrant Postion Control 1
001231009R2 22 BOLT Postion Control Lock 3
000120377 24 NUT Hex Headed 3
000704589R1 25 CIRCLIP External 2
000012248P04 26 BOLT M10 Quadrant Cross Shaft 2
007203217B1 27 BRACKET Quadrant Support 1
007204397B1 27 BRACKET Quadrant Support 1 PY/68/F13/44
007205117B91 28 STOP Nut DC Control Lever 1
007203166B91 29 ASSY. Quadrant 1
007205026B91 29 ASSY. Quadrant New 1 PY/68/F13/44


79 6/15/2011, 2:17 PM
PC & DC Internal Linkages
12 8 10
11
4 7
11 16
12
9
9 7
18
13
6 12 19
10
14
15
17
5
25
82

80 6/15/2011, 2:17 PM
PC & DC Internal Linkages
Qty/ Revision
Tractor No.
007200609A91 1 SEAL Oil Draft Link Plunger 1
007203259B11 2 SHAFT Inner DC Feedback Rocker 1
007203302B1 3 PIN Clevis Dia 8mm 1
000103373 4 PIN Cotter 2
007203250B11 5 ROD Complete DC Feed Back 1
000013262P04 6 SPRING DC Rod 1
007203278B1 7 SPACER DC Spring 2
007203253B11 8 LINK Cpte DC Actuating 1
007203275B1 9 BLOCK DC Link 1
007203279B11 10 ROCKER Draft Control 1
000051211D01 11 SCREW Allen DC Rocker 2
000013483P04 12 CIRCLIP External 5
007203268B1 13 PIVOT DC Block 1
007204050B1 14 CABLE DC Feedback 1
007203215B11 15 LINK Cpte PC Actuating 1
007203280B11 16 ROCKER Position Control 1
007203214B11 17 ASSY. Roller PC 1
007203288B1 18 ROLLER For Cam 1
007203289B1 19 ROLLER For Link 1
007203265B1 25 BUSH DC Feedback Shaft 1
83

81 6/15/2011, 2:17 PM
Bell Crank Assembly
14
13 12
15
18
16 20
4
1 2 23
21
3
24
19
22
25
5 6
8
9
11
10
84

82 6/15/2011, 2:17 PM
Bell Crank Assembly
Qty/ Revision
Tractor No.
007204018B1 1 NUT M14 1
006505678D1 2 NUT Flange Headed M14 1
007204076B1 3 SPINDLE Draft Sensing 1
007203228B1 4 CRANK Top link 1
007203233B11 5 ASSY. Mounting Draft Sensing 1
007203237B1 6 SLEEVE Draft Sensing 1
007203230B1 8 SPRING Outer Draft Sensing 1
000012506P04 9 BOLT M12 2
007204075B1 11 SLEEVE Bottom Draft Sensing 1
000020307E05 12 BOLT M8 1
007203240B11 14 ASSY. Pin Bell Crank 1
007203262B1 16 BLOCK Outer Draft Sensing Link 1
007204326B1 18 BOLT Step DC Outer Block 1
005553017R1 19 NUT Lock M8 1
007203263B11 20 LINK Outer Draft Sensing 1
007203249B11 21 ROCKER Cpte. Outer Draft Sensing 1
000017047R1 22 PIN Spring Slotted 1
000013483P04 23 CIRCLIP Special 5mm 1
007203267B1 24 SPACER DC Oil Seal 1
007203265B1 25 BUSH DC Feedback Shaft 1

83 6/15/2011, 2:18 PM
Hydraulic Suction & Pressure Pipe
26
25
18
24
17
17
16
15
20
14
13 23
7 21
5 22
4
3 27
8
2 11
6 9
1 10
86

84 6/15/2011, 2:18 PM
Hydraulic Suction & Pressure Pipe
Qty/ Revision
Tractor No.
000060684M01 1 BOLT Hex Headed Hydraulic Pump Mounting 4
000934309R1 2 WAHSER Spring Hydraulic Mounting 4
007203570B91 3 PUMP Hydraulic 7.03cc 1
‡ 4 KEY 1
006009112B1 5 ADAPTOR Pump Drive 1
‡ 6 NUT Hydraulic Pump 1
006009114B1 * SHEEL Rubber 4
006009113B1 7 BOLT Hydraulic Pump with damper 4
000377952R1 8 ‘O’ Ring Pressure Pipe 1
000706072R1 9 WASHER Spring Lock Pressure Pipe 2
001082252R1 10 BOLT Pressure Pipe Mounting 2
008002107B91 11 PIPE Pressure Pump to Control Valve 1
000364879R1 12 ‘O’ Ring Suction Pipe 1
000706053R1 13 WASHER Spring Lock Suction Pipe 2
001082253R1 14 BOLT Suction Pipe Mounting 2
008002087B91 15 PIPE Suction Pump to Suction Filter 1
005552915R91 16 CLIP Suction Hose 2
000704741R1 17 HOSE Suction Filter 2
001081607R1 18 BOLT Hydraulic Filter Mounting 2
007535860D1 19 WASHER Spring Lock 2
007205087B91 20 FILTER Suction 1
005552901R1 21 BOLT Filter Mounting Bracket 2
005555988R1 22 WASHER Spring Lock Filter Mtg Bkt 2
008001620B1 23 BRACKET Suction Filter Mtg 1
008002110B11 24 PIPE Suction Filter to Strainer with Filter Head 1
005559665B1 25 CLIP Hose Suction Filter 1
007203171B11 26 ASSY. Strainer Suction Line 1
000704348R1 * ASSY. ‘O’ Ring Suction Strainer 1
008002712B1 27 CLAMP Hyd. Pressure Pipe 1


85 6/15/2011, 2:18 PM
Three Point Linkages
6
4 3
5
2
6 5
4
3
7
17 14
16
3 16 15 17
9 12
10 3 8
13
10
18 11
9
21 13
22 20
19
19
10
18
23
88

86 6/15/2011, 2:18 PM
Three Point Linkages
Qty/ Revision
Tractor No.
008001394B91 1 TOP Link Cpte 1
008001410B1 2 PIN 1 Top Link 2
007200598C91 3 LYNCH Pin 4
008001489B1 4 PIN Lift Arm End 2
000012653P04 6 NUT M16 Hex Headed Lift Rod Top 2
008001393B91 7 ROD Lift - LH (Fixed Type) 1
008001160B91 8 ROD Lift - RH (Adjustable Type) 1
008001869B1 9 STANDARD Headed Pin 2
000050591D02 10 RING Pin 4
008001510B1 11 PIN Std Head Check Chain Mounting 2
008001406B1 12 BRACKET Check Chain Mtg 1
008001521B91 13 CHECK Chain Cpte. 2
008001399B91 14 BRACKET - LH Lower Link Mounting (Drawbar Bracket) 1
008001402B11 15 BRACKET - RH Lower Link Mounting (Drawbar Bracket) 1
007202841D1 16 STUD Lower Link Mounting Bracket 6
007535360D1 17 NUT M12 Collar 6
000020305E05 18 BOLT M14 Hex Headed 2
000013119P04 19 NUT M14 Hex Headed 2
006508490D1 20 BOLT Check Chain Mtg. Bracket M12 x 1.5 2
000041641C08 21 WASHER Spring Lock Check Chain Mtg Bracket 2
008001387B11 22 LINK Lower Cpte 2

87 6/15/2011, 2:18 PM
88 6/15/2011, 2:18 PM
CHAS
CHAS
CHASSISSIS
SIS & SHEET
& SHEET METAL
METAL
METAL

89 6/15/2011, 2:18 PM
Front Axle & Support
11 12
11
10 35 13
12 9
3
2 14 34
13 4
32
36
14 5
32
4 14 29
27
24 25
5 15 23
30 16 21
33 19
14 6
15 28
26
16
8
7 22
18 20
31
21 17
24 23
25 1
27
29
22 19
28 26
92

90 6/15/2011, 2:18 PM
Front Axle & Support
Qty/ Revision
Tractor No.
008001595B91 * ASSY. Front Axle 1
008002026B2 1 SUPPORT Front Axle 1 NY/49/F12/64
008001367B11 2 AXLE Front Cpte. 1
008001514B1 3 WASHER Thrust Front Axle Support 6.0 1
008001809B1 4 ‘O’ RING Pivot Pin Sleeve 4
008001304B1 5 BUSH Pivot Pin Sleeve 2
008001325B91 6 PIN Pivot Cpte 1
005557810R1 7 BOLT Pivot Pin 2
008001574B1 9 ARM Knuckle LH 1
008001518B1 10 ARM Knuckle RH 1
000012412P04 11 BOLT M12 2
0005550700R1 12 WAHSER Spring Lock 2
000012172P04 13 NUT M12 2
008001301B1 14 BUSH King Pin Sleeve 4
008001467B1 15 WASHER Cast Iron 2
008001425B1 16 SEAL Oil King Pin Sleeve 2
008001601B12 17 KNUCKLE Steering Cpte LH 1 NY/49/F12/64
008001505B12 18 KNUCKLE Steering Cpte RH 1 NY/49/F12/64
008001423B1 19 V SEAL Front Wheel Hub 2
008001299B1 20 DUST Shield 2
008001422B1 21 SEAL Oil Front Wheel Hub 2
008001827B1 22 SPACER Inner Bearing 2
008001420B1 23 BEARING Inner Front Wheel Hub 2
008001274B1 24 HUB Front Wheel 2
008001421B1 25 BEARING Outer Front Wheel Hub 2
008001300B1 26 WASHER Outer Bearing Retainer 2
008001587B1 27 NUT Slotted 2
008001592B1 28 PIN Split 2
008001585B1 29 CAP Front Wheel Hub 2
000110146R91 30 NIPPLE Grease 1
000114745 31 KEY Wood Ruff 2
008001808B1 32 ‘O’ RING King Pin Sleeve 4
006505859B1 33 WASHER Thrust Front Axle Support 2.5 2
008002696B1 34 SHIM King Pin Sleeve 0.6mm 4
008002669B1 35 SHIM Pivot Pin Sleeve 2
008003261B1 36 SHIM Pivot Pin 0.3mm 2
008002706B1 * FLANGE Headed Hexagonal Bolt M12 6

91 6/15/2011, 2:18 PM
F oot Plate Assembly
2
6 1 5 3
4
5
7 8
4 8
4 7
7
8 4 8 7
Battery Mounting Tray
7
3
10
5 9
2
4
94

92 6/15/2011, 2:18 PM
Foot Plate Assembly
Qty/ Revision
Tractor No.
007538673B91 1 ASSY. FLOOR Pannel - RH 1
007538669B91 2 ASSY. FLOOR Pannel - LH 1
000020306E05 3 BOLT Hex Flange Headed M8 6
007535860D1 4 WASHER Plain 10
000020777E05 5 NUT Flange Headed M8 6
‡ 6 PLATE Floor Pannel Support 2
Battery Mounting Tray

007609734B11 1 TRAY Battery Mounting 1 UY/66/F14/46
001233891R1 2 BOLT M10 Hexagonal Headed 4
008000630A1 5 L STUD Battery Clamping Outer 1
008000171B1 6 STUD Battery Clamping Inner (Engine Side) 1
001231333R91 7 NUT Wing Battery Clamping 3
001127951R97 8 PLATE Battery Retaining 1
001127951R98 8 PLATE BATTERY RETAINING 1 IY/75/F14/59
007539703B1 9 PAD Battery 1
007539975B1 10 COVER Battery 1
007610063B1 10 COVER BATTERY 1 IY/75/F14/59

93 6/15/2011, 2:18 PM
F ender Assembly
4
5
6
3
96

94 6/15/2011, 2:18 PM
Fender Assembly
Qty/ Revision
Tractor No.
007531513B94 1 ASSY. Fender Cpte. - RH 1
007531411B94 2 ASSY. Fender Cpte. - LH 1
007531826B93 3 FENDER Mounting Bracket - RH 1
007531825B93 * FENDER Mounting Bracket - LH 1
007531778B92 4 ASSY. Fender Mounting Interconnector Tube - LH 1
007543941B91 4 ASSY. Fender Mounting Interconnector Tube - LH 1 UY/66/F14/46
007540269B91 5 ASSY. Fender Mounting Interconnector Tube - RH 1
007543942B91 5 ASSY. Fender Mounting Interconnector Tube - RH 1 UY/66/F14/46
007531779B92 6 ASSY. Interconnector Holding 1
007543620B91 6 ASSY. Interconnector Holding 1 UY/66/F14/46
007531522B1 7 FENDER Liner 2
007531820B1 * FENDER Mounting Lock Plate 2
007540521B1 * FENDER Mounting Bolts M12 8
000012524P04 * BRACKET To Fender Mounting Bolts M12 X 1.5 12

95 6/15/2011, 2:18 PM
Bonnet Assembly (Hood Assembly)
7
5
1
6
21
4 3
24
22
22
11
17 17
9
18 19 10
23
13
21
20 8
14
16
15
98

96 6/15/2011, 2:18 PM
Bonnet Assembly (Hood Assembly)
Qty/ Revision
Tractor No.
007501252B91 1 ASSY. Hood 1
007538691B1 2 ASSY. Beading Hood 1
007501389B91 3 ASSY. Latch Hood 2
000020311E05 4 BOLT Hex M6 Flange Headed Latch Mounting 4
007535862D1 5 WASHER Spring Lock 4
001233807R1 7 NUT Hex Headed M6 4
007501277B91 8 ASSY. Grill Front 1
005555975R1 9 BOLT Hex Flange Headed M5 8
007535834D1 * WASHER Plain 8
005555975R1 11 BOLT 6
007501385B1 13 BRACKET Pivot Hood Mounting - LH 1
007501385B91 14 BRACKET Pivot Hood Mounting - RH 1
000020313E05 15 BOLT M10 Flange Headed 4
007501384B91 17 HINGE Mounting Bracket - LH 1
007539886B91 18 HINGE Mounting Bracket - RH 1
000020742E05 19 NUT Nylock 2
000020777E05 20 NUT Flange Headed 4
007538692B1 22 BEADING Head Lamp 2
007501387B1 23 PIN Pivot 2
007540176B1 * NYLON Spacer 2
008003191B1 24 MAHINDRA Logo 1

97 6/15/2011, 2:18 PM
Scuttle & F uel T
Fuel ank Assembly
Tank
27 26
29 28 1
3
30 4 3
4
5 5
16
27 17
7
8 9 14
10
26
18
23 19
28 25 20
12 32 21 31
24
15 27
22
13
11 34
37
33 36 35
100

98 6/15/2011, 2:18 PM
Scuttle & Fuel T
Fuel ank Assembly
Tank
Qty/ Revision
Tractor No.
007505706B1 1 SCUTTLE Dome 1
007505713B91 2 SCUTTLE Middle 1
000060971M01 3 SCREW Philips Head M6 12
007505707B1 6 PANNEL Scuttle - LH 1
007505708B1 7 PANNEL Scuttle - RH 1
000060971M01 8 SCREW Philips Head M6 4
000114605 9 WASHER Star 4
007501274B91 11 BRACKET Hood Latch 2
000020818E05 12 FLANG Headed Bolt 4
007535862D1 13 SPRING Washer M6 4
003047325R1 * WASHER Plain 4
007515484B1 14 BRACKET Fuse Box Mounting 1
007539731B1 15 WASHER Fuel Tank Ballata 2
007515341B92 16 ASSY. Tank Fuel (Old) 1
007515541B91 16 ASSY. Tank Fuel (New) 1
007540458B91 17 CAP (Lock) Fuel Tank with Key 1
000011104P03 18 BOLT M12 Hex Headed 2
000041641C08 19 WASHER Spring Lock 2
000060687M01 * WASHER Plain 2
007539911B1 20 PLATE Lock Fuel Tank 2
007539729B1 21 BALLATA Fuel Tank Mounting (Damper) 2
006000227F1 22 BOLT M8 Flange Headed 1
000020777E05 24 NUT M8 Flange Headed 1
007539725B1 * BALLATA Scuttle Mounting 6
007539726B1 * BALLATA For Support 3
007505710B1 * BALLATA For Latch Mounitng 2
007500378D91 * CLIP Nut 12
007505718B1 26 STEEl Strap Scuttle 1
007505719B2 27 RUBBER Strap Scuttle 1
007539965B1 28 SCREW M4 X 10 2
000060808M01 29 PLAIN Washer M4 2
000060809M01 30 SPRING Washer M4 2
008002711B1 31 PIPE Fuel Tank To Fuel Filter 1
006009053B1 32 BANJO Bolt M14 2
008001784B91 33 ASSY. Mirror 1
008002692B1 34 SPACER Mirror Mounting 2
008002693B1 35 STUD M6 2
008002352B11 36 BRACKET Mirror 1
000060683M01 37 NUT M6 2
003047325R1 * WASHER M6 2
001233066R92 * Fuel Tap 1

99 6/15/2011, 2:18 PM
Scuttle & Fuel T
Fuel ank Assembly
Tank
Qty/ Revision
Tractor No.
007515492B1 * Rear Mounting Ballata 1
* Part Not Illustrated 101a

99 6/15/2011, 2:18 PM
Wheel Rim & Disc Assembly
3
2
Seat Assembly
1
6
102

100 6/15/2011, 2:18 PM
Wheel Rim & Disc Assembly
Qty/ Revision
Tractor No.
008001905B1 1 RIM Front Wheel 2
003047573R1 2 BOLT M12 Hex Headed Front Wheel Mtg 8
003047574R1 3 NUT M12 Front Wheel Mtg 8
005550700R1 * WASHER Spring Lock Front Wheel Mtg 8
008001697B11 4 RIM Rear Wheel 2
005555828R1 5 NUT M12 Flange Headed 10
Seat Assembly
Seat Assembly
008002672B91 1 ASSY. Seat 1
007543383B91 1 ASSY. Seat New 1 UY/66/F14/46
005560237B91 * Kit Seat 1 UY/66/F14/46
005552901R1 2 BOLT M10 Hex Headed 4
000022079RD 3 WASHER Plain 4
008003202B11 4 BRACKET Seat Mounting 1
008003201B1 5 ASSY. Back Rest 1
008003200B1 6 ASSY Bottom Rest 1
New Seat Serviceable parts (007543383B91)

005560135B1 * Mtg Base Sub Assembly 1 UY/66/F14/46
005560136B1 * Box Assy. 1 UY/66/F14/46
005560137B1 * Back Assy. 1 UY/66/F14/46
005560138B1 * Cushion Assy. 1 UY/66/F14/46
005560139B1 * Seat Spring 2 UY/66/F14/46
005560140B1 * Swing Arm Assy. 1 UY/66/F14/46
005560143B1 * Seat Roller (Nylon) 2 UY/66/F14/46
005560146B1 * Rubber Pad (Rubber) 2 UY/66/F14/46
005560159B1 * Wt. Adjusting Screw 1 UY/66/F14/46
005560160B1 * Split Pin 1 UY/66/F14/46
005560162B1 * Washer 2 UY/66/F14/46
005560163B1 * Wt. Adjusting Nut 1 UY/66/F14/46
005560141B1 * Shock Absorber 1 UY/66/F14/46
005560154B1 * Hinge Pin Rear 1 UY/66/F14/46

101 6/15/2011, 2:19 PM
Seat
Steering Gear Box Assembly
Assembly
Qty/ Revision
Tractor No.
005560155B1 * Hinge Pin Front 1 UY/66/F14/46
005560158B1 * Top Cover 1 UY/66/F14/46
005560144B1 * Grommet (Rubber) 2 UY/66/F14/46
005560156B1 * Guide Bush 6 UY/66/F14/46
005560157B1 * Nylon Washer 4 UY/66/F14/46
008004551B1 * Circlip 4 UY/66/F14/46
005560153B1 * Round Head Phillips Screw 3 UY/66/F14/46
005560164B1 * Guide Bush 1 UY/66/F14/46
005560145B1 * Rubber Stop 1 UY/66/F14/46
005560147B1 * Hex Bolt M8-20 2 UY/66/F14/46
005560148B1 * Punched Washer M8 2 UY/66/F14/46
005560149B1 * Spring Washer M8 2 UY/66/F14/46
005560150B1 * Hex Bolt M6-20 4 UY/66/F14/46
005560152B1 * Spring Washer M6 4 UY/66/F14/46
005560165B1 * Calibrated Sticker 1 UY/66/F14/46

103 6/15/2011, 2:19 PM
10
11
2
4 3
9
22
20
5 18
9
14
8 4
19 21
13 17
12
15
7
6
16
15
105

102 6/15/2011, 2:19 PM
Qty/ Revision
Tractor No.
008002884B91 * ASSY. Steering Gear Box 1
008002567B1 1 BUSH Rubber 1
008002564B1 2 COLUMN Steering 1
000180120 3 BOLT Hex Headed 4
008002586B1 4 WASHER Spring Lock 4
008002574B1 5 SHIMS Steering Column A/R
008002582B1 6 NUT Hex Headed Steering Wheel 2
008002577B1 8 CUP Bearing 1
008002566B1 9 CAGE Bearing 1
008002580B1 10 KEY Woodruff 1
008002579B1 11 SHAFT Main Steering 1
008002021B1 12 Arm Drop Steering 1
008002573B1 13 SEAL Oil 1
008002562B1 14 HOUSING Steering Gear 1
008002572B1 15 BUSH Copper 2
008002563B1 16 SHAFT Steering 1
008002571B1 17 SCREW Preloading 1
008002570B1 18 WASHER Plain Preloading Screw 1
008002575B1 19 CIRCLIP 1
008002584B1 20 O Ring 1
008002565B1 21 CAP Steering Gear Housing 1
008005283B1 22 NUT Preloading Screw 1
000020280E05 * PIN Dowel Gear Box Mtg 2
000020313E05 * BOLT M10 Hex Headed 3
005555988R1 * WASHER 4

103 6/15/2011, 2:19 PM
Rane Make Steering Gear Box Assembly
Note : Art work is for Illustrative Purpose, Actual Parts may be different.
107
M&M Part Ref. Description of Part Remarks /
Number Unit Quantity Service
per tractor
Bulletin No.
008003981B91 I ASSY. Steering Gear Box (with Drop Arm) 1

008003982B11 A Box & Cover plate 1
# 1 Box 1
008004151B1 2 Bush 1
# 3 Cover plate Sub Assy 1
008004152B1 4 Bush 1
008003983B1 5 Oil Seal 1
008003984B11 B Inner Column & Main nut Assy. 1
# 6 Main Nut 1
# 7 Transfer Tube 2
# 8 Transfer Tube Retainer 1
# 9 Screw Transfer Tube Retainer 2
# 10 Toothead lock washer 2
# 11 Ball Steel 60
# 12 Inner Column 1
008003987B1 13 Shaft Sector 1
008003988B1 14 Adjuster 1
008003989B1 15 Spacer 1
008003990B1 16 Shim (0.008") 2
008003992B1 17 Shim (0.003") 2
008003993B1 18 Circlip Internal 1
008003994B11 19 Outer Column Assy (Includes Rubber Bush)" 1
008003995B1 20 Bush Rubber 1
008003996B11 C Bearing Sub Assy TOP 1
# 21 Nylon cage 1
# 22 Ball Steel 11
# 23 Race Inner (Top) 1
# 25 Race Outer 1
008003996B11 D Bearing Sub Assy Bottom 1
# 21 Nylon cage 1
# 22 Ball Steel 11
* Parts Not Illustrated 108

M&M Part Ref. Description of Part Remarks /
Number Unit Quantity Service
per tractor
Bulletin No.
# 24 Race Inner (Bottom) 1

# 25 Race Outer 1
008004002B1 26 Plug oil Filler 1
008004003B1 27 SHIMS 4
008004004B1 28 SHIMS 4
008004005B1 29 SHIMS 5
008004006B1 30 SHIMS 1
008004007B1 31 Washer Joint 1
008004008B1 32 Nut Lock (Drop Arm) 1
008004009B1 33 Nut Lock (Adjuster) 1
008004010B1 34 Bolt (Cover Plate) 4
008004011B1 35 Bolt (T Housing) 4
008002898B1 36 Spring Washer (C/P, E/P) 8
008004012B1 37 Spring Washer (R/S) 1
008004013B1 38 Seal Dust (Sector Shaft) 1
007537168B1 39 Seal Dust (Wheel End) 1
007537169B1 40 Key Woodruff 1
008004014B1 41 Drop Arm 1
008004015B1 42 Nut Lock (Wheel End) 1
* Parts Not Illustrated 109

Steering Wheel & Linkages
6
4
3
2
9
7
Product Graphics & Stick er

Sticker
110

104 6/15/2011, 2:19 PM
Steering Wheel & Linkages
Qty/ Revision
Tractor No.
007603357B1 1 WHEEL Steering 1
005552911R1 2 NUT Steering Wheel 1
000060869M01 3 CAP Steering Wheel 1
008003044B91 4 ASSY. Link Drag 1
007601656B91 5 END Drag Link - LH 1
007601657B91 6 END Drag Link - RH 1
008001429B91 7 ROD Tie Cpte 1
007601656B91 8 END Tie Rod - LH 1
007601657B91 9 END Tie Rod - RH 1
000103374 * PIN Split 4
Product Graphics & Stick er

Sticker
008002294B1 * PRODUCT Graphics - LH 1
008002295B1 * PRODUCT Graphics - RH 1
008002255B1 * STICKER Warning & Tyre Pressure 1
007600049R1 * STICKER Final Ok 1
005557811R1 * STICKER Engine Idling 1
008002256B1 * STICKER PTO Guard 1
007700973B91 * EMBLEM Slow Moving Vehicle (CMVR) 1
000016559R2 * WASHER Plain M6 2
001233807R1 * NUT Hex Headed M6 2
000016559R2 * WASHER Plain M6 2
001233807R1 * NUT Hex Headed M6 2
008001502B1 * PLATE Serial No 1
001127613R1 * REVIETS 4
008002129B91 * TOOL Kit 1

105 6/15/2011, 2:19 PM
Hand Accelerator & linkages
16
14
15
17
13
12
11
10 18
9
8c
8b
8
8a
7
19
5
4
6
3
1
2
112

106 6/15/2011, 2:19 PM
Hand Accelerator & linkages
Qty/ Revision
Tractor No.
000114605 2 STAR Washer Spring Lock 2
007500059C1 3 PIVOT Governor Control Rod 1
000103374 5 PIN Cotter 2
008001614B11 6 ROD Governor Control 1
008003041B91 7 ASSY. Bracket Cross Shaft 1
008001616B1 8 ROD Cross Shaft to Hand Governor Control lever 1
005550498R1 8a ASSY. Cover For Control Rod 1
000446161 8b WASHER Plain 1
000103361 8c PIN Cotter 1
008003040B91 9 LEVER Hand Governor Control 1
001121174R1 10 NUT Nylock 1
003047325R1 11 WASHER 4
003047323R1 12 SPRING Governor Control Lever 1
000704681R2 13 WASHER Friction 2
000179793 14 BOLT Hex Headed 1/4’’ 2
007535997B1 16 KNOB Governor Control Lever 1
000114492 17 NUT Hex Headed 2
000225507 18 SCREW 1/4’’ UNC X 13/4’’ 2
008002763B1 19 Return Spring Cross Shaft 1
113

107 6/15/2011, 2:19 PM
F oot Accelerator & Link ages
Linkages
5
5
9
10
7
4
8
6
4 7
114

108 6/15/2011, 2:19 PM
Foot Accelerator & Linkages
Linkages
Qty/ Revision
Tractor No.
008001608B11 1 PEDAL Foot Accelerator 1
000017047R1 2 PIN Roll 2
008001613B11 3 BRACKET Foot Accelerator Pedal 1
000114605 5 WASHER Star 2
007500059C1 6 PIVOT Governor Control Rod 1
000103361 8 PIN Cotter 2
000042000C11 9 SPRING Foot Accelerator 1
008001616B1 10 LINK Connecting Cross Shaft To Foot Pedal 1
115

109 6/15/2011, 2:19 PM
110 6/15/2011, 2:19 PM
ELECTRICALS
ELECTRICALS

111 6/15/2011, 2:19 PM
Lamp Assembly
3 6
5 8
7
4
118

112 6/15/2011, 2:19 PM
Lamp Assembly
Qty/ Revision
Tractor No.
005559210R91 1 ASSY. Lamp Head 2
007701039B91 2 BULB 12V, 35W Head Lamp 2
007701042B91 * SCREW Head Lamp 6
007701043B91 * SPRING Head Lamp Screw 6
007700845B91 3 ASSY. Lamp Parking & Turning - LH 1
007700951B91 3 ASSY. Lamp Parking & Turning - RH 1
ASSY. Parking & Turning Lamp Consist of
007701040B91 4 LENS P&T Lamp - LH 1
007701041B91 4 LENS P&T Lamp - RH 1
007701038B91 5 GASKET Rubber P&T Lamp 2
005556523R91 2 BULB Parking 12V, 5W P&T Lamp 2
005556522R91 2 BULB Turning 12V, 21W P&T Lamp 2
007701057B91 * SCREW Bolt P&T Lamp Lens Mounting 4
007701044B91 * WASHER Plain P&T Lamp Lens Screw 4
007701045B91 * NUT P&T Lamp Mtg 4
007701046B91 * WASHER Special (Star) P&T Lamp Mtg 4
007701047B91 * WASHER Plain P&T Lamp Mtg 4
007701393B91 6 ASSY. Lamp 3 in 1 Rear - LH 1
007701394B91 6 ASSY. Lamp 3 in 1 Rear - RH 1
ASSY. Lamp 3 in 1 Consist of
007701035B91 7 LENS 3 in 1 Lamp - LH 1
007701036B91 7 LENS 3 in 1 Lamp - RH 1
007701037B91 8 GASKET Rubber 3 in 1 Lamp 2
005556523R91 2 BULB Parking 12V, 5W 3 in 1 Lamp 2
005556522R91 2 BULB Turning 12V, 21W 2
007701058B91 * SCREW Bolt 3 in 1 Lamp Lens Mtg 8
007701048B91 * WASHER Plain 3 in 1 Lamp Lens Mtg Screw 8
007701045B91 * NUT 3 in 1 Lamp Mtg 4
007701046B91 * WASHER Special 3 in 1 Lamp Mtg 4
007701047B91 * WASHER Plain 3 in 1 Lamp Mtg 4
007701007B91 9 ASSY. Ploug Lamp 1
007701059B91 * BRACKET Plough Lamp 1
007701060B91 * BOLT Plough Lamp Bracket Mtg 1
007701061B91 * WASHER Plastic Plough Lamp Bkt 2
007701062B91 * WASHER Plain Plough Lamp Bkt 1
007701063B91 * WASHER Spring Plough Lamp Bkt 1
007701064B91 * NUT Hex Headed Plough Lamp Bkt 1
007701065B91 * BOLT Plough Lamp Mtg 1
007701066B91 * WASHER Plastic Plough Lamp Mtg 1
007701067B91 * WASHER Plain Plough Lamp Mtg 1
007701068B91 * WASHER Spring Plough Lamp Mtg 1
007701069B91 * NUT Nylock Hex Headed Plough Lamp Mtg 1
007701070B91 * Harness Plough Lamp 1
007701071B91 * SCREW Plough Lamp Lens 2
001081697R91 2 BULB Plough Lamp 1

113 6/15/2011, 2:19 PM
Motors & Instruments
1a 1 7
H 15 20
10 25
5 30
RPM X 100
C 0 35
0 0 0 0 1 0
HOURS
1b
2a 2
2b
8 3
>PBT<
FLASHER
120

114 6/15/2011, 2:19 PM
Qty/ Revision
Tractor No.
007700863B91 1 CLUSTER Instrument (Mechanical) 1
007701103B91 1a HOUSING 1
007701104B91 * WIRING Harness - Cluster 1
007701108B91 * BULB T10, 2W 12V 5
007701105B91 * BULB T10, 3W 12V 2
007701106B91 1b SEALING Ring 1
007701107B91 * ASSY. Dial 1
007701051B91 * CRYSTAL Instrument Cluster 1
000060971M01 * SCREW M6 Instrument Cluster Mtg 4
007701421B92 2 CLUSTER Instrument (Eletronic) 1 IY/68/F13/49
007701637B92 2a HOUSING 1 IY/68/F13/49
007701639B91 * WIRING Harness - Cluster 1
007701640B91 * SEALING Ring (Inner) 1
007701642B91 2b SEALING Ring (Outer) 1
007701642B91 * ASSY. Dial 1
007701638B92 * CRYSTAL Instrument Cluster 1 IY/68/F13/49
007701862B1 * SCREW M6 Instrument Cluster Mtg 4 IY/68/F13/49
007702037B1 * WASHER Plain 4 IY/68/F13/49
001233808R1 * WASHER Spring 4
001233807R1 * NUT M6 4 IY/68/F13/49
008002447B91 * CABLE Hour Meter 1
007700886B91 * CABLE Battery +ve 1
007700887B91 * CABLE Battery - ve 1
007701053B91 * BOLT Battery Cable 2
007701054B91 * NUT Battery Cable 2
005558982R93 * SWITCH Ignition 1
007701072B91 * NUT Ignition Switch Mtg 1
000061067M01 * SCREW For Tank Unit M5 6
007700960B91 3 SWITCH Brake 1
000061274M01 4 SPRNG Brake Switch 1
007700750B91 * HORN 1
000020311E05 * BOLT M6 Horn Mounting 2
007701422B91 * WIRING Harness Cpte. 1
007701646B91 * Fuse Box Cover 1
000040697C99 * FUSE 10 Amp 1
000040883C99 * FUSE 15 Amp 1
007701647B91 * FUSE 30 Amp
007535525D1 * SCREW M5 Fuse Box Mtg 2
007701149B91 * SOCKET Seven Pole Assembly Cpte. 1
007700371B92 * SOCKET Seven Pole Assembly Cpte. 1 UY/66/F14/46
007701326B91 * BRACKET Seven Pole Socket 1
007700338B1 * ASSY. Socket 1
001081607R1 * SCREW Bolt Seven Pole Socket Mtg 3
000934309R1 * WAHSER Spring Lock 3
005553086R93 5 FLASHER Unit 1
005558699R92 6 SWITCH Hazard 1
007700964B91 7 SWITCH Combination 1
008002988B1 8 CABLE Pull To Stop 1

115 6/15/2011, 2:19 PM
4
1 8
13
12
9 11
3 10
5
7
6
122

116 6/15/2011, 2:20 PM
Qty/ Revision
Tractor No.
006009085B1 1 BRACKET Radial Alternator Mounting 1
OE Part 4 ALTERNATOR 1
006009078B1 7 BRACKET Alternator Mounting 1
006009083B1 9 NUT Nylock 1
006009921B1 10 WASHER 1
OE Part 11 MOTOR Startor 1
007701423B91 * SENSOR Fuel Level (Fuel Level Unit) 1
00006106M01 * SCREW For Sensor 6

117 6/15/2011, 2:20 PM
Numerical Index
Part no. ................ Page No. Part no. ................ Page No. Part no. ................ Page No. Part no. ................ Page No.
40.300 21 000446161 107 ‡ 73 000022055RD 15

40.300 31 007200949E1 79 ‡ 75 000022055RD 23
000103361 107 000020255E05 17 ‡ 75 000022079RD 101
000103361 109 000020280E05 43 ‡ 75 000022271RD 43
000103373 47 000020280E05 103 ‡ 75 000022271RD 43
000103373 77 000020305E05 87 ‡ 79 000022271RD 49
000103373 81 000020306E05 93 ‡ 85 000022271RD 51
000103374 63 000020307E05 57 ‡ 85 000022271RD 57
000103374 63 000020307E05 83 ‡ 93 000022271RD 59
000103374 105 000020308E05 43 000011104P03 99 000022273RD 43
000103374 107 000020309E05 47 000012128P04 55 000022273RD 59
000103411 63 000020310E05 15 000012172P04 91 000022273RD 61
000109461 83 000020310E05 21 000012204P04 55 000023524R1 73
000109462 43 000020310E05 31 000012205P04 55 000025205R1 75
000109462 47 000020311E05 97 000012230P04 51 000030184R1 93
000109462 63 000020311E05 115 000012248P04 13 000032060B12 69
000109462 63 000020313E05 97 000012248P04 79 000032097B12 49
000114492 107 000020313E05 103 000012353P04 49 000032097B12 57
000114605 99 000020723E05 47 000012353P04 51 000032097B12 57
000114605 107 000020723E05 53 000012353P04 57 000032140B12 55
000114605 109 000020742E05 97 000012412P04 91 000040697C99 115
000114745 91 000020777E05 93 000012506P04 83 000040883C99 115
000120304 69 000020777E05 97 000012524P04 95 000041641C08 87
000120375 115 000020777E05 99 000012653P04 87 000041641C08 99
000120377 79 000020786E05 21 000013085P04 31 000042000C11 65
000120393 47 000020786E05 21 000013119P04 87 000042000C11 109
000120396 63 000020796E05 17 000013262P04 81 000050591D02 87
000120396 63 000020797E05 37 000013483P04 81 000050857D01 73
000124556 63 000020818E05 99 000013483P04 83 000050925D01 73
000133049 115 ‡ 15 000016559R1 107 000050936D01 75
000179793 73 ‡ 23 000016559R1 109 000050992D01 77
000179793 107 ‡ 25 000016559R2 37 000050993D01 75
000179796 73 ‡ 25 000016559R2 97 000051061D01 79
000179799 73 ‡ 25 000016559R2 99 000051152D01 75
000179890 71 ‡ 25 000016559R2 105 000051155D01 77
000179890 73 ‡ 55 000016559R2 105 000051157D01 77
000179891 71 ‡ 55 000016559R2 115 000051165D01 73
000179891 73 ‡ 55 000017047R1 73 000051166D01 75
000180120 79 ‡ 61 000017047R1 83 000051167D01 73
000180120 103 ‡ 61 000017047R1 109 000051181D01 77
000225507 107 ‡ 73 000020294SH 59 000051182D01 77
000443137 73 ‡ 73 000021433R1 71 000051211D01 81
000444687 75 ‡ 73 000021433R1 73 000051228D01 77
000444697 77 ‡ 73 000022055RD 13 000051365D01 77
124

118 6/15/2011, 2:20 PM
Numerical Index
000051521D01 75 000385713R1 75 000934309R1 99 001233807R1 107

000051523D01 75 000385713R1 75 000934309R1 115 001233807R1 109
000051524D01 75 000387374R1 75 001081607R1 65 001233808R1 115
000051695D01 75 000455183R1 69 001081607R1 85 001233891R1 43
000051695D01 77 000545813R2 75 001081607R1 115 001233891R1 93
000051708D02 73 0005550700R1 91 001081618R1 11 003040910R1 75
000051712D01 73 000704337R1 71 001081618R1 31 003041407R2 37
000060387M01 31 000704348R1 85 001081618R1 31 003044388R2 79
000060387M01 35 000704378R1 75 001081697R91 113 003044397R1 79
000060387M01 51 000704589R1 79 001081727R2 35 003045102R2 73
000060683M01 29 000704681R2 107 001081778R93 35 003045102R21 73
000060683M01 99 000704741R1 85 001082010R2 73 003045104R1 73
000060684M01 65 000705252R3 63 001082010R2 107 003045106R1 73
000060684M01 85 000705252R3 63 001082011R2 43 003045107R1 73
000060686M01 47 000706053R1 85 001082011R2 91 003045113R2 73
000060686M01 65 000706072R1 85 001082014R2 71 003045116R1 73
000060687M01 99 000706732R1 43 001082014R2 73 003045118R1 71
000060808M01 99 000751557R2 75 001082252R1 85 003045118R1 73
000060809M01 99 000751567R1 77 001082253R1 85 003047229R4 43
000060869M01 105 000751580R3 71 001082277R1 35 003047246R1 73
000060971M01 99 000751580R3 73 001082360R2 79 003047294R95 73
000060971M01 99 000934309R1 15 001121174R1 107 003047323R1 107
000060971M01 115 000934309R1 15 001127613R1 105 008002693B1 99
00006106M01 117 000934309R1 17 001127629R2 43 008002693B1 99
000061274M01 115 000934309R1 19 001127951R97 93 008002693B1 99
000061276M01 93 000934309R1 19 001231009R2 79 003047325R1 107
000110146R91 91 000934309R1 31 001231204R1 73 003047573R1 101
0003110027R1 75 000934309R1 31 001231333R91 93 003047574R1 101
000350084R2 75 000934309R1 31 001231334R91 79 003063495R1 77
000350818R1 79 000934309R1 35 001231889R1 29 003064219R3 63
000352026R2 75 000934309R1 35 001231889R1 31 003066410R1 75
000364879R1 85 000934309R1 43 001231899R1 79 003067146R1 73
000377952R1 71 000934309R1 43 001232895R1 71 003067183R1 71
000377952R1 73 000934309R1 49 001232895R1 73 003067183R1 73
000377952R1 75 000934309R1 51 00123293R1 35 003072883R1 75
000377952R1 79 000934309R1 57 001233150R1 87 003072883R1 77
000377952R1 85 000934309R1 57 001233156R1 45 003072912R1 75
000379365R1 71 000934309R1 59 001233156R1 47 003074227R2 77
000379365R1 73 000934309R1 69 001233156R1 55 003108188R1 73
000379365R1 75 000934309R1 83 001233156R1 57 003108946R3 75
000379365R1 77 000934309R1 85 001233807R1 17 003108947R2 75
000381871R1 71 000934309R1 93 001233807R1 97 005550488R1 43
000381871R1 73 000934309R1 97 001233807R1 105 005550498R1 107
000384937R1 73 000934309R1 97 001233807R1 105 005550700R1 21
125

119 6/15/2011, 2:20 PM
Numerical Index
005550700R1 23 005556032R1 79 006008821B1 23 006008900B1 29

005550700R1 83 005556038R1 73 006008822B1 17 006008901B1 29
005550700R1 101 005556320R1 61 006008823B1 11 006008911B1 23
005550766R3 11 005556465R1 61 006008823B1 17 006008912B1 23
005550766R3 17 005556469R1 61 006008824B1 19 006008913B1 23
005551426R2 17 005556470R91 61 006008825B1 19 006008914B1 23
005551581R1 57 005556486R1 61 006008826B1 19 006008914B1 29
005552901R1 17 005556521R1 87 006008827B1 19 006008915B1 23
005552901R1 85 005556522R91 113 006008828B1 19 006008915B1 29
005552901R1 101 005556522R91 113 006008829B1 19 006008916B1 23
005552911R1 105 005556523R91 113 006008830B1 19 006008916B1 29
005552915R91 85 005556523R91 113 006008831B1 19 006008917B1 23
005553017R1 15 005556606R1 45 006008832B1 19 006008917B1 29
005553017R1 21 005556882R1 43 006008835B1 29 006008918B1 23
005553017R1 35 005556899R1 79 006008836B1 11 006008918B1 29
005553017R1 83 005556901R1 79 006008836B1 17 006008919B1 23
005553025R1 43 005557646R1 77 006008836B1 29 006008919B1 29
005553086R93 115 005557647R1 75 006008836B1 31 006008920B1 23
005554172R1 105 005557810R1 47 006008838B1 29 006008921B1 11
005554404R1 71 005557810R1 91 006008839B1 29 006008921B1 23
005554405R1 71 005557811R1 105 006008842B1 29 006008922B1 23
005554657R91 69 005558067R91 57 006008843B1 29 006008924B1 23
005554906R1 75 005558124R1 71 006008844B1 29 006008925B1 117
005554915R1 55 005558246R1 47 006008845B1 19 006008927B1 11
005554986R1 45 005558383R91 85 006008852B1 31 006008927B1 23
005555283R3 75 005558699R92 115 006008855B1 23 006008928B1 23
005555715R1 57 005558982R93 115 006008856B1 23 006008931B1 23
005555827R1 59 005559210R91 113 006008857B1 21 006008932B1 23
005555828R1 101 006000227F1 99 006008857B1 23 006008933B1 23
005555967R1 79 006000386F1 19 006008866B1 17 006008934B1 23
005555975R1 97 006000999B1 13 006008876B1 117 006008935B1 23
005555975R1 97 006000999B1 15 006008876B1 117 006008937B1 23
005555976R1 97 006001042B1 23 006008879B1 31 006008939B1 19
005555976R1 99 006001061B1 37 006008881B1 31 006008940B1 19
005555988R1 13 006001241R1 13 006008882B1 31 006008941B1 19
005555988R1 15 006001249R1 13 006008883B1 19 006008942B1 19
005555988R1 17 006002097B1 35 006008883B1 31 006008943B1 19
005555988R1 19 006002571B1 57 006008883B1 37 006008944B1 19
005555988R1 23 006006473B91 11 006008885B1 31 006008946B1 19
005555988R1 23 006008815B1 19 006008894B1 29 006008946B1 27
005555988R1 85 006008817B1 21 006008895B1 29 006008947B1 15
005555988R1 93 006008817B1 21 006008896B1 29 006008950B1 23
005555988R1 103 006008819B1 21 006008898B2 29 006008951B1 117
005556032R1 29 006008820B1 23 006008899B1 29 006008952B1 19
126

120 6/15/2011, 2:20 PM
Numerical Index
006008953B1 19 006009035B1 35 006009117B1 21 006009894B1 19

006008954B1 11 006009036B1 35 006009139B92 25 006009900B1 23
006008954B1 19 006009037B1 35 006009150B91 19 006009902B1 23
006008955B1 11 006009038B1 35 006009151B91 17 006009903B1 27
006008955B1 19 006009039B91 35 006009152B91 37 006009904B1 27
006008956B1 11 006009042B1 11 006009238B91 29 006009905B1 27
006008956B1 19 006009042B1 35 006009239B91 33 006009909B1 27
006008957B1 19 006009044B1 35 006009240B1 17 006009910B1 27
006008958B1 19 006009045B1 35 006009290B1 19 006009912B1 17
006008960B1 19 006009046B1 35 006009291B1 19 006009913B1 17
006008961B1 19 006009049B91 35 006009345B1 37 006009914B1 17
006008962B1 15 006009050B1 35 006009529B1 11 006009921B1 117
006008962B1 35 006009053B1 99 006009529B1 17 006009922B1 117
006008963B1 19 006009054B1 11 006009531B1 11 006009922B1 117
006008971B1 25 006009054B1 35 006009531B1 17 006009925B1 21
006008972B1 25 006009057B1 15 006009532B1 11 006009949B1 37
006008975B1 19 006009060B1 15 006009532B1 35 006009949B1 37
006008975B1 23 006009061B1 19 006009533B1 11 006009960B1 27
006008978B1 17 006009064B1 15 006009533B1 15 006010079B91 11
006008979B1 17 006009068B1 35 006009534B1 11 006010081B91 11
006008980B1 35 006009078B1 117 006009534B1 15 006010083B91 11
006008982B1 17 006009082B1 117 006009535B1 11 006010083B91 11
006008983B1 17 006009083B1 117 006009535B1 13 006010085B91 11
006008986B1 17 006009085B1 117 006009660B1 13 006010086B91 11
006008987B1 17 006009090B1 37 006009724B1 37 006010088B91 11
006008988B1 17 006009091B1 37 006009735B1 11 006010092B91 11
006008989B1 17 006009094B91 37 006009735B1 25 006010098B1 23
006008990B1 17 006009094B91 39 006009736B1 11 006010218B1 31
006008991B1 17 006009096B1 37 006009736B1 23 006010219B1 31
006008992B1 17 006009099B1 37 006009737B1 25 006010323B1 11
006008996B1 17 006009102B1 37 006009799B1 11 006010323B1 13
006008997B1 17 006009105B2 37 006009799B1 11 006010350B11 15
006008998B1 17 006009105B2 37 006009799B1 17 006010352B91 25
006008999B1 17 006009107B2 37 006009801B1 11 006010467B1 31
006009000B1 17 006009108B1 37 006009801B1 11 006010467B1 31
006009005B1 17 006009109B1 37 006009801B1 17 006010488B1 31
006009008B1 17 006009110B1 23 006009886B1 23 006010533B1 39
006009008B1 37 006009111B1 19 006009887B1 23 006010610B91 35
006009014B1 17 006009112B1 21 006009888B1 23 006010675B1 11
006009021B91 17 006009112B1 85 006009888B1 29 006010675B1 25
006009029B91 19 006009113B1 23 006009890B1 21 006010676B1 11
006009030B1 11 006009113B1 85 006009892B1 35 006010676B1 25
006009030B1 19 006009114B1 23 006009893B1 11 006010793B91 23
006009031B1 19 006009114B1 85 006009893B1 35 006010912B1 13
127

121 6/15/2011, 2:20 PM
Numerical Index
006011046B1 11 006505630D1 57 006506337B1 57 006507251B1 59

006011046B1 17 006505631D1 49 006506338B1 49 006507252B1 59
006011114B91 13 006505658D1 55 006506341B1 47 006507253B1 59
006011797B91 39 006505678D1 83 006506343B1 57 006507254B1 59
006011873B1 31 006505768D1 49 006506357B1 57 006507255B1 59
006012168B1 31 006505768D1 57 006506443D1 23 006507257B11 43
006012234B1 37 006505769D1 49 006506471B1 47 006507260B1 45
006012235B1 37 006505769D1 57 006506473B91 47 006507305B1 43
006012236B1 37 006505770D1 49 006506474B91 47 006507335B1 51
006012237B1 37 006505770D1 57 006506475B91 47 006507336B1 51
006012469B91 35 006505809B1 45 006506478B1 51 006507356B91 43
006012578B1 15 006505810B1 49 006506479B1 51 006507358B91 61
006012579B1 15 006505811B1 51 006506483B1 49 006507359B91 61
006012580B1 13 006505812B1 49 006506484B1 57 006507447B91 43
006012581B1 13 006505813B1 51 006506555B1 43 006507465B1 47
006012582B1 13 006505815B1 51 006506556B1 43 006507465B1 57
006012583B1 13 006505817B1 57 006506558B1 43 006507466B1 49
006012584B1 13 006505818B1 53 006506634B91 47 006507466B1 57
006012585B1 13 006505819B1 45 006506636B1 53 006507466B1 57
006012730B91 13 006505823B1 59 006506667B1 55 006507467B1 49
006012731B1 13 006505846B1 55 006506670B1 55 006507467B1 51
006012732B1 13 006505847B1 59 006506671B1 55 006507469B1 55
006012734B1 13 006505848B1 59 006506680B1 55 006507469B1 59
006012735B91 13 006505850B1 57 006506681B1 55 006507939B1 57
006012736B91 13 006505852B1 59 006506683B1 55 006507943B11 47
006013228B1 19 006505855B1 51 006506688B1 57 006508490D1 87
006013247B91 11 006505856B1 57 006506794B91 57 006508526B1 51
006013247B91 25 006505857B1 49 006506800B1 57 006508535B1 57
006013373B1 27 006505858B1 53 006506801B91 57 006508536B1 57
006013460B1 37 006505859B1 53 006506802B1 47 006508540B1 55
006013641B91 11 006505859B1 91 006506809B1 55 006508606B1 61
006013645B91 11 006505860B1 51 006506828B1 55 006508607B1 61
006013645B91 11 006505861B1 51 006506836B1 55 006508608B91 61
006015078B91 11 006505862B1 49 006506847B1 51 006508609B91 61
006016106B1 39 006505875B1 49 006506848B1 51 006508611B1 61
006500927C1 53 006505880B1 55 006506852B1 49 006508612B1 61
006502942C1 51 006505888B1 59 006506868B1 53 006508612B1 61
006503662C1 47 006505890B1 43 006506907B1 49 006508613B1 61
006503662C1 57 006505895B1 45 006506909B1 55 006508614B1 61
006505490D1 51 006505966B1 47 006506912B1 59 006508615B1 61
006505491D1 51 006505967B1 47 006506965D1 55 006508616B1 61
006505492D1 51 006505981B1 47 006506965D1 59 006508617B1 61
006505616D1 51 006505990B1 59 006507044B1 43 006508618B1 61
006505619D1 51 006506336B1 49 006507128B1 47 006508619B1 61
128

122 6/15/2011, 2:20 PM
Numerical Index
006508620B1 61 007203159B1 69 007203570B91 85 007535525D1 115

006508622B1 61 007203160B1 69 007203785B1 79 007535834D1 97
006508623B1 61 007203161B1 69 007203892B91 71 007535860D1 85
006508624B1 61 007203162B1 69 007204018B1 83 007535860D1 93
006508625B1 61 007203163B1 69 007204019B1 75 007535860D1 97
006508626B1 61 007203164B91 69 007204050B1 81 007535860D1 99
006508627B1 61 007203166B91 79 007204075B1 83 007535862D1 97
006508628B1 61 007203170B11 75 007204076B1 83 007535862D1 99
006508629B1 61 007203171B11 85 007204326B1 83 007535997B1 107
006508630B91 61 007203175B1 77 007205087B91 85 007538669B91 93
006508665B91 55 007203176B1 77 007205117B91 79 007538673B91 93
006508763B1 45 007203187B1 75 007205118B11 79 007538691B1 97
006508763B1 45 007203210B11 79 007205393B1 77 007538692B1 97
006508837B1 47 007203214B11 81 007500059C1 107 007538785B91 93
006509401B1 55 007203215B11 81 007500059C1 109 007538895B1 37
006509404B1 55 007203217B1 79 007500378D91 99 007538901B1 37
006509405B1 55 007203219B1 79 007501252B91 97 007538905B91 37
006509406B1 55 007203221B1 79 007501274B91 99 007539387B1 37
006509432B1 55 007203228B1 83 007501277B91 97 007539390B91 37
006509772B1 45 007203230B1 83 007501384B91 97 007539391B1 37
006509772B1 47 007203233B11 83 007501385B1 97 007539703B1 93
006509772B1 57 007203237B1 83 007501385B91 97 007539725B1 99
006509934B1 47 007203240B11 83 007501387B1 97 007539726B1 99
006509934B1 57 007203248B11 79 007501389B91 97 007539729B1 99
006510231B1 69 007203249B11 83 007505706B1 99 007539731B1 99
006510233B1 69 007203250B11 81 007505707B1 99 007539886B91 97
006510518B1 69 007203253B11 81 007505708B1 99 007539911B1 99
007000009B1 69 007203259B11 81 007505710B1 99 007539965B1 99
007000010B1 69 007203262B1 83 007505713B91 99 007539975B1 93
007000048B1 69 007203263B11 83 007505718B1 99 007540176B1 97
007000053B1 69 007203265B1 81 007505719B1 99 007540269B91 95
007200369C1 77 007203265B1 83 007515341B92 99 007540458B91 99
007200598C91 87 007203267B1 83 007515484B1 99 007540521B1 95
007200609A91 81 007203268B1 81 007515541B91 99 007540522B1 69
007200832C1 75 007203275B1 81 007531411B92 95 00760049R1 105
007200882A91 75 007203278B1 81 007531513B92 95 007601656B91 105
007201178A91 75 007203279B11 81 007531522B1 95 007601656B91 105
007201180A1 75 007203280B11 81 007531778B92 95 007601657B91 105
007201599B1 75 007203288B1 81 007531779B92 95 007601657B91 105
007202286B91 77 007203289B1 81 007531820B1 95 007603357B1 105
007202841D1 87 007203302B1 81 007531825B92 95 007700338B1 115
007203020B91 75 007203385B91 75 007531826B92 95 007700750B91 115
007203157B1 69 007203387B1 77 007535084C1 47 007700845B91 113
007203158B1 69 007203558B1 79 007535360D1 87 007700863B91 115
129

123 6/15/2011, 2:20 PM
Numerical Index
007700886B91 115 007701104B91 115 008001423B1 91 008002026B1 91

007700887B91 115 007701105B91 115 008001425B1 91 008002087B91 85
007700951B91 113 007701106B91 115 008001429B91 105 008002107B91 85
007700960B91 115 007701107B91 115 008001432B11 63 008002110B11 85
007700964B91 115 007701108B91 115 008001465B11 63 008002129B91 105
007700973B91 105 007701149B91 115 008001467B1 91 008002255B1 105
007701007B91 113 007701326B91 115 008001473B1 63 008002256B1 105
007701035B91 113 007701393B91 113 008001473B1 63 008002294B1 105
007701036B91 113 007701394B91 113 008001489B1 87 008002295B1 105
007701037B91 113 007701421B91 115 008001501B1 63 008002352B11 99
007701038B91 113 007701422B91 115 008001501B1 63 008002447B91 115
007701039B91 113 007701423B91 117 008001502B1 105 008002562B1 103
007701040B91 113 007701637B91 115 008001505B11 91 008002563B1 103
007701041B91 113 007701642B91 115 008001510B1 87 008002564B1 103
007701042B91 113 007701642B91 115 008001514B1 91 008002565B1 103
007701043B91 113 007701639B91 115 008001518B1 91 008002566B1 103
007701044B91 113 007701640B91 115 008001521B91 87 008002567B1 103
007701045B91 113 007701642B91 115 008001526B11 63 008002570B1 103
007701045B91 113 007701646B91 115 008001538B11 63 008002571B1 103
007701046B91 113 007701647B91 115 008001560B1 57 008002572B1 103
007701046B91 113 008000171B1 93 008001574B1 91 008002573B1 103
007701047B91 113 008000630A1 93 008001585B1 91 008002574B1 103
007701047B91 113 008001160B91 87 008001587B1 91 008002575B1 103
007701048B91 113 008001187B11 63 008001592B1 91 008002577B1 103
007701051B91 115 008001240B91 63 008001595B91 91 008002579B1 103
007701053B91 115 008001240B91 65 008001601B11 91 008002580B1 103
007701054B91 115 008001241B11 65 008001608B11 109 008002581B1 103
007701057B91 113 008001274B1 91 008001613B11 109 008002582B1 103
007701058B91 113 008001299B1 91 008001614B11 107 008002584B1 103
007701059B91 113 008001300B1 91 008001616B1 107 008002586B1 103
007701060B91 113 008001301B1 91 008001616B1 109 008002639B1 47
007701061B91 113 008001304B1 91 008001618B1 57 008002640B1 47
007701062B91 113 008001325B91 91 008001620B1 85 008002669B1 91
007701063B91 113 008001367B11 91 008001656B1 37 008002672B91 101
007701064B91 113 008001387B11 87 008001697B11 101 008002691B1 65
007701065B91 113 008001393B91 87 008001780B1 45 008002692B1 99
007701066B91 113 008001394B91 87 008001780B1 63 008002696B1 91
007701067B91 113 008001399B91 87 008001784B91 99 008002706B1 91
007701068B91 113 008001402B11 87 008001808B1 91 008002711B1 99
007701069B91 113 008001406B1 87 008001809B1 91 008002712B1 85
007701070B91 113 008001410B1 87 008001827B1 91 008002763B1 107
007701071B91 113 008001420B1 91 008001869B1 87 008002872B1 45
007701072B91 115 008001421B1 91 008001905B1 101 008002872B1 65
007701103B91 115 008001422B1 91 008002021B1 103 008002879B1 63
130

124 6/15/2011, 2:20 PM
008002884B91 103
008002988B1 115
008003040B91 107
008003041B91 107
008003044B91 105
008003191B1 97
008003200B1 101
008003201B1 101
008003202B11 101
008003261B1 91
008005283B1 103
131

125 6/15/2011, 2:20 PM

Untitled

Uploaded by

Copyright:

Available Formats

You might also like

Untitled

Uploaded by

Document Information

Original Description:

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Untitled

Uploaded by

Copyright:

Available Formats

FOREWORD

Farm Equipment Sector,

PART NO: YUVR 215 PC01, 2 nd Edition, Mar 31st

215 yuvraj Parts Index 13.6.2011.pmd

Following steps will help you to use this Catalogue.

215 yuvraj Parts Index 13.6.2011.pmd

Intake System ----------------------------------------------------------------------------------------------------------- 12 - 13

Exhaust System --------------------------------------------------------------------------------------------------------- 14 - 15

Cylinder Head Assembly --------------------------------------------------------------------------------------------- 16 - 17

Crankcase Assembly --------------------------------------------------------------------------------------------------- 18 - 21

Crank Shaft Assembly ------------------------------------------------------------------------------------------------ 22 - 25

Counter Balance Assembly ------------------------------------------------------------------------------------------ 26 - 27

Governing System ----------------------------------------------------------------------------------------------------- 28 - 29

Lubrication System ---------------------------------------------------------------------------------------------------- 30 - 31

Oil Pump Assembly ---------------------------------------------------------------------------------------------------- 32 - 33

Fuel System -------------------------------------------------------------------------------------------------------------- 34 - 35

Cooling System --------------------------------------------------------------------------------------------------------- 36 - 37

Water Pump Assembly ----------------------------------------------------------------------------------------------- 38 - 39

Clutch Cover Assembly ----------------------------------------------------------------------------------------------- 42 - 43

Clutch Housing & Connection ------------------------------------------------------------------------------------- 42 - 43

Transmission Drive Shaft Assembly -------------------------------------------------------------------------------- 44 - 45

Transmission Case ----------------------------------------------------------------------------------------------------- 44 - 45

Rail Assembly ------------------------------------------------------------------------------------------------------------ 46 - 47

Counter Shaft Assembly --------------------------------------------------------------------------------------------- 48 - 49

Spline Shaft Assembly ------------------------------------------------------------------------------------------------ 50 - 51

Reverse Idler Gear Assembly ---------------------------------------------------------------------------------------- 52 - 53

Differential Assembly ------------------------------------------------------------------------------------------------- 54 - 55

PTO Assembly ----------------------------------------------------------------------------------------------------------- 56 - 57

Rear Axle Assembly ---------------------------------------------------------------------------------------------------- 58 - 59

Brake Assembly --------------------------------------------------------------------------------------------------------- 60 - 61

Clutch Pedal & Linkages --------------------------------------------------------------------------------------------- 62 - 63

Brake Pedal & Linkages ---------------------------------------------------------------------------------------------- 62 - 63

Hand Brake & Linkages ---------------------------------------------------------------------------------------------- 64 - 65

215 yuvraj Parts Index 13.6.2011.pmd

Hydraulic Lift Housing ------------------------------------------------------------------------------------------------ 68 - 69

Hydraulic Lift Arm Assembly ---------------------------------------------------------------------------------------- 68- 69

Control Valve Assembly ---------------------------------------------------------------------------------------------- 70 - 71

Control Valve O Rings Kit -------------------------------------------------------------------------------------------- 70 - 71

Hydraulic Cylinder Head Assembly -------------------------------------------------------------------------------- 72- 73

Control Valve–Valve Body Assembly ------------------------------------------------------------------------------- 74- 77

Hydraulic Qudrant Assembly --------------------------------------------------------------------------------------- 78 - 79

PC & DC Internal Linkages ------------------------------------------------------------------------------------------ 80 - 81

Bell Crank Assembly --------------------------------------------------------------------------------------------------- 82 - 83

Hydraulic Suction & Pressure Pipe -------------------------------------------------------------------------------- 84 - 85

Three Point Linkages ------------------------------------------------------------------------------------------------- 86 - 87

CHASSIS & SHEET METAL

Front Axle & Support ------------------------------------------------------------------------------------------------- 90 - 91

Foot Plate Assembly --------------------------------------------------------------------------------------------------- 92 - 93

Battery Mounting Tray ----------------------------------------------------------------------------------------------- 92 - 93

Fender Assembly ------------------------------------------------------------------------------------------------------- 94 - 95

Bonnet Assembly (Hood Assembly) ------------------------------------------------------------------------------- 96 - 97

Scuttle & Fuel Tank Assembly --------------------------------------------------------------------------------------- 98 - 99

Wheel Rim & Disc Assembly ----------------------------------------------------------------------------------------- 100 - 101

Seat Assembly ---------------------------------------------------------------------------------------------------------- 100 - 101

Steering Gear Box Assembly ---------------------------------------------------------------------------------------- 102 - 103

Steering Wheel & Linkages ----------------------------------------------------------------------------------------- 104 - 105

Product Graphics & Sticker ----------------------------------------------------------------------------------------- 104 - 105

Hand Accelerator & linkages --------------------------------------------------------------------------------------- 106 - 107
