A Brief
Pegasus Equipments is a 10 year old company, with exclusive focus on design, development of complete range of
products in the fields on RFID, Biometrics and Locks, thereby providing comprehensive solutions on Time
Attendance, Access Control, Hotel Locks, Parking, Employee Identification, Visitor Management, Canteen
Management, Campus Management, Apartment Security, among others.
has been a pioneer in ushering new technologies, creating innovations in the field of biometrics and
integrating all the hardware produced by Pegasus into a single common software platform, thereby providing
seamless integration and easy accessibility for all its users. Pegasus was a pioneer in introducing "Auto Adapt"
feature in fingerprint in the middle of last decade, and was also one among the firsts to introduce built in Web-
Servers in the multi door controller and finger print terminals in 2008!
houses its software development and hardware design division in India and sub-contracts the
manufacturing of its products to well established manufacturers in China, thereby providing you with the best of
both software and hardware. With the time zone difference and Pegasus offices being strategically placed, a
client of Pegasus can be assured of support being available almost round the clock.
Pegasus Equipments Pvt Ltd, was awarded ISO 9001 certification in the year 2008 for its offices and most of
the products of Pegasus are CE approved, ROHS Compliant, FCC Certified for its keen focus on quality in design
and developmental process.
Products from include:
? LF - Low Frequency - 125 KHz Card readers, Long range readers, Controllers
? HF - High Frequency - 13.56 MHz Card readers, Gate Antenna, Controllers
? UHF - Ultra High Frequency - 868 MHz ~ 928 MHz Card readers
? Single Door Controllers
? Multi Door Controllers
? Fingerprint Readers, Controllers
? Face Recognition Systems
? Locks
oElectromagnetic Locks (EM)
oElectric Strikes
oDrop bolt Locks
oShear Locks
oRFID Integrated Stand Alone Locks
oMifare integrated Hotel Locks
oBoom Barriers
oTurnstiles
oSlide Gates
o Accessories
?Video Door Phones, Audio Door Phones
?Anti Theft Systems / Electronic Article Surveillance
?Solutions
oTime Attendance
oAccess Control
oAccess Control Integrated with CCTV
oVisitor Management
oParking
oHotel Lock Solutions
oCanteen Management
oCampus Management
 TM
Security at your fingertips

Principles of Fingerprint Biometrics

A fingerprint is made of a a number of ridges and valleys on the surface of the finger. Ridges are the upper skin
layer segments of the finger and valleys are the lower segments. The ridges form so-called minutia points: ridge
endings (where a ridge end) and ridge bifurcations (where a ridge splits in two). Many types of minutiae exist,
including dots (very small ridges), islands (ridges slightly longer than dots, occupying a middle space between
two temporarily divergent ridges), ponds or lakes (empty spaces between two temporarily divergent ridges),
spurs (a notch protruding from a ridge), bridges (small ridges joining two longer adjacent ridges), and
crossovers (two ridges which cross each other).
The uniqueness of a fingerprint can be determined by the pattern of ridges and furrows as well as the minutiae
points. There are five basic fingerprint patterns: arch, tented arch, left loop, right loop and whorl. Loops make
up 60% of all fingerprints, whorls account for 30%, and arches for 10%.
Fingerprints are usually considered to be unique, with no two fingers having the exact same dermal ridge
characteristics.

How Does Fingerprint Biometrics Work

The main technologies used to capture the fingerprint image with sufficient detail are optical, silicon, and
ultrasound.
There are two main algorithm families to recognize fingerprints:
Minutia matching compares specific details within the fingerprint ridges. At registration (also called
?
enrollment), the minutia points are located, together with their relative positions to each other and their
directions. At the matching stage, the fingerprint image is processed to extract its minutia points, which
are then compared with the registered template.
Pattern matching compares the overall characteristics of the fingerprints, not only individual points.
?
Fingerprint characteristics can include sub-areas of certain interest including ridge thickness,
curvature, or density. During enrollment, small sections of the fingerprint and their relative distances
are extracted from the fingerprint. Areas of interest are the area around a minutia point, areas with low
curvature radius, and areas with unusual combinations of ridges.
Issues with Fingerprint Systems
The tip of the finger is a small area from which to take measurements, and ridge patterns can be affected by cuts,
dirt, or even wear and tear. Acquiring high-quality images of distinctive fingerprint ridges and minutiae is
complicated task.
People with no or few minutia points (surgeons as they often wash their hands with strong detergents, builders,
people with special skin conditions) cannot enroll or use the system. The number of minutia points can be a
limiting factor for security of the algorithm. Results can also be confused by false minutia points (areas of
obfuscation that appear due to low-quality enrollment, imaging, or fingerprint ridge detail).
Note: There is some controversy over the uniqueness of fingerprints. The quality of partial prints is however the
limiting factor. As the number of defining points of the fingerprint become smaller, the degree of certainty of
identity declines. There have been a few well-documented cases of people being wrongly accused on the basis of
partial fingerprints.
Benefits of Fingerprint Biometric Systems
Easy to use
?
Economical
?
Small size
?
Low power
?
Non-intrusive
?
Large database already available
?
Applications of Fingerprint Biometrics
Fingerprint sensors are best for devices such as cell phones, USB flash drives, notebook computers and other
applications where price, size, cost and low power are key requirements. Fingerprint biometric systems are also
used for law enforcement, background searches to screen job applicants, healthcare and welfare.
Security at your fingertips
TM
T-5

Professional
Reliable
Best Value
 Finger Print Time Security at your fingertips
TM

Recording Access Controller

ADVANTAGES SPECIFICATIONS
Highly Accurate Fingerprint Recognition Model T-5
Sensor Optical
Optical Fingerprint sensor with scratch
resistant surface Resolution 600 DPI
Dimensions 188mm x 126mm x 48mm
Lightning Fast Fingerprint Recognition Operation Mode Offline
"Tick Tock", a second, you are either rejected Operation Voltage DC 9V (with battery) / DC 5V (without battery)
or accepted by our T-5 Authentication Fingerprint / PIN + Card (optional)
Smart Fingerprint Update Fingerprint Verification Mode 1 : 1, 1 : N
Finger Print Sensor Area 16mm x 14mm
Automatically analyze the tiny difference of the
latest fingerprints vs. the previous fingerprints Fingerprint Recognition Speed about 1 second
and update accordingly to ensure the high accuracy Max. ID Records 2,000
and the optimum speed of fingerprint recognition Max. Management Records 1,000
Max. Attendance Records 50,000
Ultra Low False Acceptance Rate Display Screen 128 x 64 Blue Lit LCD
FAR < 0.0001% Display Language Standard : English
Options : Other Languages
SD Card for Data Upload / Download Fingerprint Update Smart Auto Update
The most commonly used data storage device, SD Card Bell Schedule Time Bell (Can connect to external bell)
is employed in our T-5 for easy data transfer via Internal or External Speakers
Door Access (Optional) Relay Output, Wiegand 26
Backup Battery (Optional) about 4 hours of minimal operations
Data Communication Channel Communication Interface USB Cable Link
Data transfer via USB Link, SD Card, TCP / IP SD Card
TCP / IP
Card Reader (Optional) EM Card / Mifare Card
Name Display Employee Name Display
Data Communication
Uploading / Downloading Data via SD Card Connecting to Server via LAN / WAN Router

TCP/IP

SD Card

Connecting to Server via USB Link

USB-Linking
Security at your fingertips
TM
T-6

Color Display Fingerprint Time

Recording Access Controller
Color Display Fingerprint Time
Recording Access Controller
ADVANTAGES SPECIFICATIONS
Highly Accurate Fingerprint Recognition Model
Optical Fingerprint sensor with scratch Sensor
resistant surface
Resolution
Lightning Fast Fingerprint Recognition Dimensions
"Tick Tock", a second, you are either rejected
or accepted by our T-6 Operation Mode
Operation Voltage
Smart Fingerprint Update
Automatically analyze the tiny difference of the Authentication
latest fingerprints vs. the previous fingerprints Fingerprint Verification Mode
and update accordingly to ensure the high accuracy Finger Print Sensor Area
and the optimum speed of fingerprint recognition
Fingerprint Recognition Speed
Ultra Low False Acceptance Rate Max. ID Records
FAR < 0.0001%
Max. Management Records
Max. Attendance Records
SD Card for Data Upload / Download
The most commonly used data storage device, Display Screen
SD Card is employed in our T-6 for easy data transfer Display Language
Data Communication Channel
Data transfer via USB Link, SD Card, TCP / IP Fingerprint Update
Alarm
Door Access (Optional)
Backup Battery (Optional)
Data Communication Channel
Card Reader
Access Control
Door Contact
Security at your fingertips
TM
T-6
T-6
Optical
600 DPI
185mm x 128mm x 40mm
Offline
DC 9V (with battery) / DC 5V (without battery)
Fingerprint+PIN/Card (optional)
1 : 1, 1 : N
16mm x 14mm
about 1 second
1,000
1,000
50,000
320 x240 Color Display
Standard : English
Options : Other Languages
Smart Auto Update
Time Bell (Can connect to external bell)
Relay Output, Wiegand 26
about 4 hours of minimal operations
USB Link / SD Card / TCP / IP
EM Card / Mifare Card (Optional)
Lock Relay Connectivity COM, NC or COM, NO
Door Sensor Input
 TM
Security at your fingertips
T-7

T-7

High Capacity & speed: Attendance recording within 1 sec for 1,000 persons or less
An indispensable tool for staff management: Ideal solution for Time & Attendance recording

Expertise in Business Time- Keeping Solutions Satisfaction Guaranteed

Easy & Efficient Staff Management at your fingertips
 TM
Security at your fingertips

T-7

T-7
ADVANTAGES SPECIFICATIONS
Highly Accurate Fingerprint Recognition Model T-7
Optical Fingerprint sensor with scratch
resistant surface Sensor Optical
Lightning Fast Fingerprint Recognition Resolution 500 DPI
"Tick Tock", a second, you are either rejected Sensing Area 18 mm x 21 mm
or accepted by our T-7
Fingerprint Template Capacity 3,000
Smart Fingerprint Update
Automatically analyze the tiny difference of the Transaction Capacity 80,000
latest fingerprints vs. the previous fingerprints Verification Mode 1:1 or 1:N
and update accordingly to ensure the high accuracy
and the optimum speed of fingerprint recognition Communication TCP/IP, USB, RS232C, RS485 & Weigand 26 bit
Ultra Low False Acceptance Rate Keyboard and Display 128 x 64 LCD; with blue backlight and 16-key keypad
FAR < 0.0001% Power Supply 9 V DC; Standby Current: 1A; Operating Current: 400mA
Identification speed < 1 seconds
USB for Data Upload / Download
The most commonly used data storage device, FRR (False Rejection Ratio) < 0.01%
is employed in our T-7 for easy data transfer FAR (False Acceptance Ratio) < 0.0001%
Temperature: 00C-50 C, Humidity: 20%-80%
0

Data Communication Channel Operating Environment

Data transfer via USB, TCP / IP, RS232/ 485 Language Support English
Dimension 189(L) x 137(W) x50(H)mm
Data Backup USB Fingerprint template
Battery Backup Built in 7200 mAh
Card Reader EM Card Reader / Mifare Card Reader (Optional)
Access Control Lock Relay Output COM, NC or COM, NO

T-7

T-7 T-7 T-7

 TM
Security at your fingertips

Sensor Verification T-8

i g h Speed Identification
H Performance Technology

Colour Display Machine

5,000 Users..... 1 s
Free
ATTENDANCE MANAGEMENT SOFTWARE
False Acceptance Rate....0.0001%

Award winning fingerprint Standalone/Network USB data & fingerprint Automatic recognition
identification algorithm (TCP/IP) templates download or registered fingerprint

www.pegasus.hk www.pegasusequipments.com
 T-8
TM
Colour Display Machine
Security at your fingertips

ADVANTAGES SPECIFICATIONS
Strong Recognition Ability : Model T-8
New Optical Fingerprint Technology, Sensor Optical
Fast / Accurate / Economical Resolution 600 DPI
Sensing Area 18mm x 21mm
Language : Size L215 x W141 XH52 mm
Double Voice Power DC 12V 1.5A
Triple Language Weight 1.2 Kg
False Rejection Rate < 0.01%
Connection : False Acceptance Rate < 0.0001%
Support Multiple Machines Connections Recognition Time 1s
Fingerprint Memory 5,000
Transaction Memory 200,000
LCD Display : Template Authentication 1:1, 1:N
QVGA Colour LCD Display Authentication Method FP / PW / Card (Optional)
Prompt Voice / Buzzer / LED
Communication RS232/485, TCP/IP, USB
Voice Recorder : Download Online Yes
Built-in MIC. Support Voice Recording E Lock Control Yes
Image Icon Yes
Attendance Record Inquiry Yes
Name Display : Summer Time Yes
Key Pad Input Method Alarm Yes
Keypad Input Method Chinese / English
Key Pad Input Method

SYSTEM CONFIGURATION :

EXTERNAL INTERNAL

FP
T-8

RFID
T-8
Computer
PIN
PASSWORD

T-8

www.pegasus.hk www.pegasusequipments.com
 TM
Security at your fingertips

T-9
 Colour Display Fingerprint Time
Recording Access Controller Security at your fingertips
TM

Key Features

Authentication
Fingerprint+PIN+EM / Mifare Card (Optional) optional Access Control
T-9
Built-in Camera for Real Time Picture Taking & Built-in Mic. For Voice Recording
Multi Devices in Multi Regions Support Server and Client Connection
Backup Battery for 4 hours operation

Data Communication SPECIFICATIONS

Sensor Optical
Connect to Server via USB Link or RS232/485
Resolution 600 DPI
Sensing Area 18mm x 21mm
RS232/485 Dimensions L198 x W128 X H43 mm
FRR < 0.01%
FAR < 0.0001%
FP Recognition Speed 1 sec
FP Template Capacity 5,000 pc (Standard), 30,000 pc (Optional)
Connect to Server via LAN / WAN Transaction Memory
Router Capacity 200,000
Verification Modes 1:1, 1:N
TCP / IP Authentication Method FP, PIN, RFID Card (Optional)
Operation Mode Stand Alone or Connect with PC
Communication RS232/485, TCP/IP, USB Drive
Operation Power < 5W
Power Input DC 12V
Weight 1.2 kg
Upload / Download Data via U Drive Display QVGA 76800 pixels color backlit LCD
Voice Input Voice Recording with built-in Mic
Image Capture Instant Photo taking with built in camera
Image Display Support Image retrieval & display
Languages Display : English/T, Chinese/S. Chinese
Voice : English / Cantonese (Customization feasible)
U Drive Access Control Feature Standard with Time Zone Management
Alarm Programmable Alarm with Signal Output Interface
Input Method T-9 Chinese / English Text Output
Summer Daylight Saving Standard Feature
Distributor :
Attendance Checking Any staff may check own attendance
Indication Feature FP Verfication success / failure indication
Network Connectivity Support multi machine connection over network
and support server & client feature
 TM
Security at your fingertips

CE ROHS
CERTIFICATES CERTIFICATES

T-5 T-6 T-5 T-6

T-7 T-8 T-7 T-8

T-9 T-9
 TM
Security at your fingertips

Face Biometrics

Principles of Face Biometrics

The dimensions, proportions and physical attributes of a person's face are unique.

How does Face Biometrics Work

Biometric facial recognition systems will measure and analyze the overall structure, shape and
proportions of the face: Distance between the eyes, nose, mouth, and jaw edges; upper outlines of the
eye sockets, the sides of the mouth, the location of the nose and eyes, the area surrounding the
cheekbones.

At enrolment, several pictures are taken of the user's face, with slightly different angles and facial
expressions, to allow for more accurate matching. For verification and identification, the user stands
in front of the camera for a few seconds, and the scan is compared with the template previously
recorded.

To prevent an image / photo of the face or a mask from being used, face biometric systems will require
the user to smile, blink, or nod their head. Also, facial thermography can be used to record the heat of
the face (which won't be affected by a mask).

The main facial recognition methods are: feature analysis, neural network, eigenfaces, and automatic
face processing.

Benefits of Face Biometric Systems

?
Not intrusive, can be done from a distance, even without the user being aware of it (for instance
when scanning the entrance to a bank or a high security area).

Weaknesses of Face Biometric Systems

?
Face biometric systems are more suited for authentication than for identification purposes, as
it is easy to change the proportion of one's face by wearing a mask, a nose extension, etc.

?
User perceptions / civil liberty: Most people are uncomfortable with having their picture
taken.

Applications of Face Biometrics

Access to restricted areas and buildings, banks, embassies, military sites, airports, law enforcement.
Face
Security at your fingertipsTM
Recognization
Systems
Embedded facial
recognition system:
Adopt US advanced DSP technology
* keeps processing and matching right
on the device
Standalone application as time
* attendance. Access control and user
identification

Accurate and Fast

Identification:

* Industrial Leading “Dual Sensor”

Facial Recognition Algorithm,
FAR<0.01%
1:Many up to 1400 users less than
* 1 second
Large user and log capacity:

* User capacity from 500 to 1400

Over 150,000 logs and optional image capacity over 70,000
*
Reliable perfor mance under different environments
** The
Different source-light within Infrared-light based Technology
system can work in different light condition even in the dark

Time Attendance
& Payroll software
router/switch
TCP/IP
TCP/IP
 TM
Security at your fingertips

Flexible I/O interfaces

* Internet Protocol based enables LAN or Network deployment
USB Host for User data upload or download via USB flash driver
* Wiegand output makes system compatible with different access control panel
*
User friendly design:
3.5 inch color screen for face positioning
*Contactless authentication for the ultimate in hygienic
*Voice prompt
*
Other Functionalities:
Low power consumption,12Watts in operation, less than 5Watts in resting mode
*
Processor TI DM 6446 CPU 594MHz
User Capacity 500 Users
Record Capacity 150,000 Records
Recognition Algorithm Dual Sensor TM V2.0
Sensor Specialized double sensor
Verification Method Facial Recognition
Verification Speed Less than 1 Second (500 Users)
Keyboard 4*4 Touch Keypad
3.5 inch TFT Color Screen
LCD 65,000 Bright Color
320*240 Resolution
Communication Method Standard TCP/IP USB Host
Power 12V DC Working Current 500mA
Environment Light 0-5000Lux
Wor king Distance 30-80cm
0 C-40 0C
0
Wor king Temperature

Wor king Humidity 20% - 80%

Size 200* 95* 115 mm
Weight 505g
Installation Method Wall Mounting
Card Reader EM Card : Mifare Card Reader (Optional)
 TM
Security at your fingertips

Pegasus Equipments Pvt. Ltd. Pegasus Equipments Ltd.,

Corporate Office :
Add: #361,3rd Floor,8th Main,
Basaveshwar Nagar,
Bangalore 560 079.India
Ph: +91 80 2323 6001
Fax:+91 80 2323 6002
China Representative Office :
Add: # 1802 B, Shandong Building
Nanhai Street, Nanshang District
Shenzhen, China-518054
Tel: +86-755-2641 7573
Fax: +86-755-2641 7345

Regional Office :
Add: #415, 3rd Floor, Ramphal Chowk,
Sector-7, Dwarka,
New Delhi 110095
Ph: +91 11 2507 4778 / 79 / 80
Fax:+91 11 2507 4793
