BATCH PLANT CONTROL

PANEL USER GUIDE

www.geotek-tr.com
INDEX
GENERAL INSTRUCTIONS..................................................................................... 3
CONTROL PANEL
Warnings : Electrical Systems........................................................................................ 4
Appereance : Panel Buttons ........................................................................................... 5
Explanation : Panel Button Functions ............................................................................ 6
Apperance : Inside of the Panel.................................................................................... 20
Explanation : Materials Inside of the Panel ................................................................. 21
OPERATOR PANEL
Entrance Page ............................................................................................................... 22
Main Page..................................................................................................................... 23
Recipe Page .................................................................................................................. 24
Alarm Page ................................................................................................................... 28
Working Page ............................................................................................................... 29
Settings Page ................................................................................................................ 30
Aggregate Settings ....................................................................................................... 31
Cement Settings............................................................................................................ 32
Water Settings .............................................................................................................. 33
Additive Settings .......................................................................................................... 34
Mixer Settings .............................................................................................................. 35
Alarm Settings .............................................................................................................. 36
Vibration Settings ......................................................................................................... 37
Skip Winch Settings ..................................................................................................... 38
Motors Working Times ................................................................................................ 39
Watching Values .......................................................................................................... 40
Manuel Records............................................................................................................ 41
Weighing Calibration ................................................................................................... 42
Multimeter .................................................................................................................... 44

1
GENERAL INSTRUCTIONS

Batch plant control panel, controls the whole system and is the main unit which has
two different running modes as manuel and automatic.

The controlling of the whole system is made by the control panel So keeping this
panel healty is an important point. This can be obtained by supplying a clean&stable
energy and earthing. If supplied voltage or earthing not healty, user may have problems
and may not use the system. To prevent this, user has to control the supplied voltage
stability and earthing periodically.

Pls do not setup any other softwares to the computer which is running the “Batch Plant
Control Software”. Any other sofware or viruses may harm your PC or Operating
System.

Control panel has two running modes as manuel and automatic. The operator can
choose the required one.

Control Panel Electrical Characteristic

1 AC Supplying Voltage 220 V AC


2 DC Voltage 24 V DC (-%15 , +%20) , (20.4, 28.8)
3 Max. Out(A) 5A
4 Max. In(A) 2A
5 Tempereture -20 – +60 C
6 Humidity %10 - %90

2
CONTROL PANEL

WARNINGS : THE ELECTRICAL SYSTEM

The loadcell‟s over the weighing platform, weighing indicators inside of the control
panel, PLC and the computer system is highly sensitive equipments to the current
leakages. So, user has to control the supplied voltage stability and earthing periodically.

Before a welding operation on the concrete plant‟s body, all main switches should be
shut off. The cables between the loadcells and indicators should be taken off. Chassis
cable for the welding, must be placed near the place where will be welded.

When the system energized at the first time, operator has to wait for 2-3 minutes to let
system components warm&run correctly.

The equipments which connected to the computer and PLC (printer, monitor,
weighing indicators, etc.) must be grounded same reference.

Pls do not setup any other softwares to the computer which is running the “Batch Plant
Control Software”. Any other sofware or viruses may harm your PC or Operating
System.

If any thermal switch trips, the light over the atteched motor blinks and warns the
operator. Operator panel and PC Program warns the operator too.

3
CONTROL PANEL APPEARANCE

There are three(3) different type control panel !


Please follow the instructions which is suitable your panel-type !

1. Quick Master & Skip Winch Type Control Panel

2. Mobil Master Type Control Panel

3. Transfer Conveyer Type Control Panel

4
1. Quick Master & Skip Winch Type Control Panel

50

8 4
51
1 28

9
52 5
2

53 6

54

31
11

15 12 35 36 37 38

16 13 39 40

17
10
14 19
32

18

46 41

20
23
47 42

21 24 48 43 33

26 49 45 44

22 25

27

30 34

29

5
QUICK MASTER & SKIP WINCH TYPE CONTROL PANEL

Button No: Button Name: Button Function


1 Aggregate2 Vibration Runs vibrators on bunkers, lights on if
2 Aggregate3 Vibration vibrators run.
3 Aggregate 1 Opens the bunker lids and lets aggregate
4 Aggregate 2 discharge to the weighing band. It works
5 Aggregate 3 with 3-seconds delay for a stable weighing.
6 Aggregate 4 After 3-seconds, the attached bunker‟s lid
opens&the attached lamp lights. if no
discharging; control the compressor is
running, control the bunker is not empty, be
sure the bunker‟s lid is working properly.
Only one bunker lid can be opened at the
same time so you cannot open any cover
before the others are closed.
7 Emergency Stop Emergency stop button of the system. The
energy of the system shuts off when this
button is pushed. The lock of the button
must be opened with the key over it to make
the system active again. Push that button if
there is an emergency situation&repairing
or cleaning.
8 Weighing Band Runs the weighing band. If the weighing
band runs the lamp lights. If there is a
problem check the weighing band pull cord.
9 Weigh Band Vibration Vibrates the weighing band.
10 Mixer‟s Lid Opens the mixer‟s lid. The lamp lights
when the mixer‟s lid is opened. If the cover
can‟t open, control the compressor is
running, lid‟s sensor and check if there is a
mechanical jamming.
11 Washing Additive Used to wash “additive weigher”.
12 Additive Bunker‟s Lid Opens the additive bunker‟s lid without any
delay. The lamp lights, when the additive
bunker‟s lid is opened. The weighed
additive is discharged in to the mixer. If the
lid doesn‟t work properly; control if the
compressor is running, lid‟s sensor and
check if there is a mechanical jamming.
13 Water Discharging Lid Opens the water bunker‟s lid without any
delay. The lamp lights, when the water
bunker‟s lid is opened. The weighed water
is discharged in to the mixer. If the cover
doesn‟t work properly; control if the

6
compressor is running, lid‟s sensor and
check if there is a mechanical jamming.
14 Cement Discharging Opens the cement bunker‟s lid without any
Lid delay. The lamp lights, when the cement
bunker‟s lid is opened. The weighed cement
is discharged in to the mixer. If the cover
doesn‟t work properly; control if the
compressor is running, lid‟s sensor and
check if there is a mechanical jamming
15 Mixer Start Runs mixer. The lamp lights, when the
mixer is running. If there is a problem
control the lids over mixer if problem goes
on control the switches over lids.
16 Mixer Full The red light turns on when the mixer
current is over limit. You can change
overload current limit and overload current
delay time from the alarm parameter page.
If there is an overloading, open the mixer
cover in manuel mode and let the materials
to discharge. If you force mixer to run in
overloading limits, mixer thermal switch
may trip or mixer arms can be damaged .
17 Mixer Stop Stops the mixer.
18 Filter Over Mixer Activates the filter over mixer. If active the
lamp lights & provides mixer air flow. In
automatic mode it works automatically
when the material starts to discharge into
the mixer and stops working when mixer
discharge lid is closed.
19 Cement Discharging Runs vibrator on the cement weigher
Vibrator bunker.
20 Compressor Runs the compressor. The lamp ligts, when
the compressor is running. If the button is
pushed, compressor works automatically
according to set air pressure.
21 Horn Activates the horn. The lamp ligfts, when
the horn is running. Running the horn for a
long time can damage horn‟s coil.
22 Panel ON/OFF Supplies voltage to the control panel
23 System Start Starts system in automatic mode. When it is
pushed in automatic mode, the system starts
tı work if all starting conditions are
provided. If not, you can see alarm on both
operator panel and PC program. At any
alarm conditions that stops process, you can
keep going process by pushing start button
after correcting the alarm reason. At critical

7
alarm conditions you may not keep going
process and you need to start the production
at the beginning. You can push start button
in operator panel or PC Program too.
24 System Stop Stops system in automatic mode. When it is
pushed, the system stands by on automatic
mode. You can stop the automatic system
from the operator panel and PC program
too.
25 Manuel\Automatic Chooses the running mode (Auto \ Man). In
manuel mode operator can work manually.
In automatic mode you cannot run anything
except mixer and compressor.
26 Manuel Lamp The lamp lights when manuel mode
choosen.
27 Automatic Lamp The lamp lights when automatic mode
choosen.
28 Operator Panel It provides user interface to link PLC.
29 Ampermeter It shows mixer‟s current.
30 Multimeter It measures 3 phase currents, AC RMS
Values of 6 different line voltages,
maximum demand values in adjustable
periods, maxiumum and minimum voltages.
31 Weighing Indicators These indicators show weighing values
32 coming from loadcells. Weighing systems
33 are calibrated by these indicators. Values
34 are considered by kilograms.

35-36 Additive Pumps Runs the additive pumps. Runs with 3-


37-38 seconds delay for a stable weighing. Only
one pump can run at the same time so you
cannot run any pump without the others
stop.
39 1.Water Pump Runs the water pump. The lamp lights,
40 2.Water Pump when the water pump is running. Runs with
3-seconds delay for a stable weighing.
41 Filters Over Spirals Activates the filters over spirals. The lamp
42 lights, when the filter is running. The
43 attached spiral filter must run when the
44 cement is filled. Control the compressor
before filters are activated.
45 Cement Silos Vibration Runs the Cement Silos (3-4) vibration unit.
(Shock) In automatic mode it runs automatically.
The lamp lights, when this vibration unit is
running.
46 Spirals Runs the spirals. The lamp lights, when the
47 cement spiral is running. Runs with 3-

8
48 seconds delay for a stable weighing. Only
49 one spiral can run at the same time so you
cannot run any spiral without the others
stop.
50 Skip winch at below It is the skip winch‟s down limit position.
To start the system in automatic mode, the
winch must be at below position. If not, an
alarm accurs that blinking „skip winch
doesn‟t its position‟. If the skip winch
doesn‟t stop at this position and keep on
moving, check the down limit switch.

51 Skip winch to down It moves the skip winch down. When the
skip winch moving down, the lamp lights. It
moves two different modes. (fast and slow)
It moves slow down and after 2 seconds
fastens. If the skip winch doesn‟t move
check the skip winch brakes.

52 Skip winch at middle It is the skip winch‟s middle position.


53 Skip winch to up It moves the skip winch up. When the skip
winch moving up the lamp lights.

54 Skip winch at top It is the skip winch‟s top limit position.


When the winch is up, the lamp lights. If the
skip winch doesn‟t stop at top position
check the limit switch.

9
2. Mobil Master Type Control Panel

7 3

4 1
8
31
5 2

32

11
15 35 36 37 38
12

16
13 39 40

17
33
10 14 19

18
48
41 43

49
20 23 42 44

50 45 34

21 24
51 47 46
26

22 25
27

29

28 30

10
MOBIL MASTER TYPE CONTROL PANEL

Button No: Button Name: Button Function


1 Aggregate2 Vibration Runs vibrators on bunkers, lights on if vibrators run.
2 Aggregate3 Vibration
3 Aggregate 1 Opens the bunker lids and lets aggregate discharge to the
4 Aggregate 2 weighing band. It works with 3-seconds delay for a
5 Aggregate 3 stable weighing. After 3-seconds, the attached bunker‟s
6 Aggregate 4 lid opens&the attached lamp lights. if no discharging;
control the compressor is running, control the bunker is
not empty, be sure the bunker‟s lid is working properly.
Only one bunker lid can be opened at the same time so
you cannot open any cover before the others are closed.
7 Emergency Stop Emergency stop button of the system. The energy of the
system shuts off when this button is pushed. The lock of
the button must be opened with the key over it to make
the system active again. Push that button if there is an
emergency situation&repairing or cleaning.
8 Weighing Band Runs the weighing band. If the weighing band runs the
lamp lights. If there is a problem check the weighing
band pull cord.
9 Weigh Band Vibration Vibrates the weighing band.
10 Mixer‟s Lid Opens the mixer‟s lid. The lamp lights when the mixer‟s
lid is opened. If the cover can‟t open, control the
compressor is running, lid‟s sensor and check if there is
a mechanical jamming.
11 Washing Additive Used to wash “additive weigher”.
12 Additive Bunker‟s Opens the additive bunker‟s lid without any delay. The
Lid lamp lights, when the additive bunker‟s lid is opened.
The weighed additive is discharged in to the mixer. If the
lid doesn‟t work properly; control if the compressor is
running, lid‟s sensor and check if there is a mechanical
jamming.

13 Water Discharging Lid Opens the water bunker‟s lid without any delay. The
lamp lights, when the water bunker‟s lid is opened. The
weighed water is discharged in to the mixer. If the cover
doesn‟t work properly; control if the compressor is
running, lid‟s sensor and check if there is a mechanical
jamming.
14 Cement Discharging Opens the cement bunker‟s lid without any delay. The
Lid lamp lights, when the cement bunker‟s lid is opened. The
weighed cement is discharged in to the mixer. If the
cover doesn‟t work properly; control if the compressor is
running, lid‟s sensor and check if there is a mechanical
jamming
15 Mixer Start Runs mixer. The lamp lights, when the mixer is running.

11
If there is a problem control the lids over mixer if
problem goes on control the switches over lids.
16 Mixer Full The red light turns on when the mixer current is over
limit. You can change overload current limit and
overload current delay time from the alarm parameter
page. If there is an overloading, open the mixer cover in
manuel mode and let the materials to discharge. If you
force mixer to run in overloading limits, mixer thermal
switch may trip or mixer arms can be damaged .
17 Mixer Stop Stops the mixer.
18 Filter Over Mixer Activates the filter over mixer. If active the lamp lights
& provides mixer air flow. In automatic mode it works
automatically when the material starts to discharge into
the mixer and stops working when mixer discharge lid is
closed.
19 Cement Discharging Runs vibrator on the cement weigher bunker.
Vibrator
20 Compressor Runs the compressor. The lamp ligts, when the
compressor is running. If the button is pushed,
compressor works automatically according to set air
pressure.
21 Horn Activates the horn. The lamp ligfts, when the horn is
running. Running the horn for a long time can damage
horn‟s coil.
22 Panel ON/OFF Supplies voltage to the control panel
23 System Start Starts system in automatic mode. When it is pushed in
automatic mode, the system starts tı work if all starting
conditions are provided. If not, you can see alarm on
both operator panel and PC program. At any alarm
conditions that stops process, you can keep going process
by pushing start button after correcting the alarm reason.
At critical alarm conditions you may not keep going
process and you need to start the production at the
beginning. You can push start button in operator panel or
PC Program too.
24 System Stop Stops system in automatic mode. When it is pushed, the
system stands by on automatic mode. You can stop the
automatic system from the operator panel and PC
program too.
25 Manuel\Automatic Chooses the running mode (Auto \ Man). In manuel
mode operator can work manually. In automatic mode
you cannot run anything except mixer and compressor.
26 Manuel Lamp The lamp lights when manuel mode choosen.
27 Automatic Lamp The lamp lights when automatic mode choosen.

28 Operator Panel It provides user interface to link PLC.


29 Ampermeter It shows mixer‟s current.

12
30 Multimeter It measures 3 phase currents, AC RMS Values of 6
different line voltages, maximum demand values in
adjustable periods, maxiumum and minimum voltages.
31-32 Weighing Indicators These indicators show weighing values coming from
33-34 loadcells. Weighing systems are calibrated by these
indicators. Values are considered by kilograms.

35-36 Additive Pumps Runs the additive pumps. Runs with 3-seconds delay for
37-38 a stable weighing. Only one pump can run at the same
time so you cannot run any pump without the others stop.
39 1.Water Pump Runs the water pump. The lamp lights, when the water
40 2.Water Pump pump is running. Runs with 3-seconds delay for a stable
weighing.
41
42
43 Filters Over Spirals Activates the filters over spirals. The lamp lights, when
44 the filter is running. The attached spiral filter must run
45 when the cement is filled. Control the compressor before
46 filters are activated.
47 Cement Silos Runs the Cement Silos (3-4) vibration unit. In automatic
Vibration (Shock) mode it runs automatically. The lamp lights, when this
vibration unit is running.
48 Spirals Runs the spirals. The lamp lights, when the cement spiral
49 is running. Runs with 3-seconds delay for a stable
50 weighing. Only one spiral can run at the same time so
51 you cannot run any spiral without the others stop.

13
1. Transfer Conveyer Type Control Panel

8 4 1

31

9 5 2
52

32

15 35 36 37 38
12 11

16
13

17 39 40 33

10 14 19

18
41
48 43

42
20 23
49 44

34

21 24 50 45

26 51 47 46
22 25
27

29

28

30

14
TRANSFER CONVEYER TYPE CONTROL PANEL

Button No: Buton Adı: Buton İşlevi


1 Aggregate2 Vibration Runs vibrators on bunkers, lights on if vibrators run.
2 Aggregate3 Vibration
3 Aggregate 1 Opens the bunker lids and lets aggregate discharge to the
4 Aggregate 2 weighing band. It works with 3-seconds delay for a
5 Aggregate 3 stable weighing. After 3-seconds, the attached bunker‟s
6 Aggregate 4 lid opens&the attached lamp lights. if no discharging;
control the compressor is running, control the bunker is
not empty, be sure the bunker‟s lid is working properly.
Only one bunker lid can be opened at the same time so
you cannot open any cover before the others are closed.
7 Emergency Stop Emergency stop button of the system. The energy of the
system shuts off when this button is pushed. The lock of
the button must be opened with the key over it to make
the system active again. Push that button if there is an
emergency situation&repairing or cleaning.
8 Weighing Band Runs the weighing band. If the weighing band runs the
lamp lights. If there is a problem check the weighing
band pull cord.
9 Weigh Band Vibration Vibrates the weighing band.
10 Mixer‟s Lid Opens the mixer‟s lid. The lamp lights when the mixer‟s
lid is opened. If the cover can‟t open, control the
compressor is running, lid‟s sensor and check if there is
a mechanical jamming.
11 Washing Additive Used to wash “additive weigher”.
12 Additive Bunker‟s Opens the additive bunker‟s lid without any delay. The
Lid lamp lights, when the additive bunker‟s lid is opened.
The weighed additive is discharged in to the mixer. If the
lid doesn‟t work properly; control if the compressor is
running, lid‟s sensor and check if there is a mechanical
jamming.

13 Water Discharging Lid Opens the water bunker‟s lid without any delay. The
lamp lights, when the water bunker‟s lid is opened. The
weighed water is discharged in to the mixer. If the cover
doesn‟t work properly; control if the compressor is
running, lid‟s sensor and check if there is a mechanical
jamming.
14 Cement Discharging Opens the cement bunker‟s lid without any delay. The
Lid lamp lights, when the cement bunker‟s lid is opened. The
weighed cement is discharged in to the mixer. If the
cover doesn‟t work properly; control if the compressor is
running, lid‟s sensor and check if there is a mechanical
jamming.

15
15 Mixer Start Runs mixer. The lamp lights, when the mixer is running.
If there is a problem control the lids over mixer if
problem goes on control the switches over lids.
16 Mixer Full The red light turns on when the mixer current is over
limit. You can change overload current limit and
overload current delay time from the alarm parameter
page. If there is an overloading, open the mixer cover in
manuel mode and let the materials to discharge. If you
force mixer to run in overloading limits, mixer thermal
switch may trip or mixer arms can be damaged .
17 Mixer Stop Stops the mixer.
18 Filter Over Mixer Activates the filter over mixer. If active the lamp lights
& provides mixer air flow. In automatic mode it works
automatically when the material starts to discharge into
the mixer and stops working when mixer discharge lid is
closed.
19 Cement Discharging Runs vibrator on the cement weigher bunker.
Vibrator
20 Compressor Runs the compressor. The lamp ligts, when the
compressor is running. If the button is pushed,
compressor works automatically according to set air
pressure.
21 Horn Activates the horn. The lamp ligfts, when the horn is
running. Running the horn for a long time can damage
horn‟s coil.
22 Panel ON/OFF Supplies voltage to the control panel
23 System Start Starts system in automatic mode. When it is pushed in
automatic mode, the system starts tı work if all starting
conditions are provided. If not, you can see alarm on
both operator panel and PC program. At any alarm
conditions that stops process, you can keep going process
by pushing start button after correcting the alarm reason.
At critical alarm conditions you may not keep going
process and you need to start the production at the
beginning. You can push start button in operator panel or
PC Program too.
24 System Stop Stops system in automatic mode. When it is pushed, the
system stands by on automatic mode. You can stop the
automatic system from the operator panel and PC
program too.
25 Manuel\Automatic Chooses the running mode (Auto \ Man). In manuel
mode operator can work manually. In automatic mode
you cannot run anything except mixer and compressor.
26 Manuel Lamp The lamp lights when manuel mode choosen.
27 Automatic Lamp The lamp lights when automatic mode choosen.

28 Operator Panel It provides user interface to link PLC.

16
29 Ampermeter It shows mixer‟s current.
30 Multimeter It measures 3 phase currents, AC RMS Values of 6
different line voltages, maximum demand values in
adjustable periods, maxiumum and minimum voltages.
31-32 Weighing Indicators These indicators show weighing values coming from
33-34 loadcells. Weighing systems are calibrated by these
indicators. Values are considered by kilograms.

35-36 Additive Pumps Runs the additive pumps. Runs with 3-seconds delay for
37-38 a stable weighing. Only one pump can run at the same
time so you cannot run any pump without the others stop.
39 1.Water Pump Runs the water pump. The lamp lights, when the water
40 2.Water Pump pump is running. Runs with 3-seconds delay for a stable
weighing.
41
42
43 Filters Over Spirals Activates the filters over spirals. The lamp lights, when
44 the filter is running. The attached spiral filter must run
45 when the cement is filled. Control the compressor before
46 filters are activated.
47 Cement Silos Runs the Cement Silos (3-4) vibration unit. In automatic
Vibration (Shock) mode it runs automatically. The lamp lights, when this
vibration unit is running.
48 Spirals Runs the spirals. The lamp lights, when the cement spiral
49 is running. Runs with 3-seconds delay for a stable
50 weighing. Only one spiral can run at the same time so
51 you cannot run any spiral without the others stop.
52 Transfer Conveyer Runs the transfer conveyer.

17
Alternative Mixer Lid Usage

56 55 57

If your mixer looks like above, please follow the explanations below.

55 Mikser Lid Open/Close Opens or closes the mixer‟s lid.


Button
56-57 Mixer Lid Shows mixer‟s lid position.
Opened/Closed Lamps

Alternative Additive Counter Usage

60

If your additive receiving process with counter instead of with weigher(60);


Please follow the document : “EN - EC442 COUNTER.pdf”

18
APPEARANCE : INSIDE THE PANEL

11

2
10

16 6

5
14

12

15

13

19
EXPLANATION : INSIDE THE PANEL

No: Adı: İşlevi:


1 PLC Programmable Logic Controller. It is an industrial
computer which is working under a suitable control
program and has Input-Output units which are suitable to
control and command systems circuits. Controls the
whole automation system.
2 Ethernet Switch Switches the Ethernet communication between PLC –
Operator Panel and PC.
3 Power Supply 24 V DC power supply.
4 Current Transformer Current transformer. Transforms the current value to a
signal, suitable for the PLC.
5 Fuses Main fuses of the control panel. Activate or deactivate 24
V DC and 220 V AC power. Fuse blow in over current
and fault current conditions. In the panel, there are fuses
to protect PLC and Operator Panel
6 Socket 1 These are the sockets that connect control panel to MCC
7 Socket 2 panel.
8 Socket 3
9 Socket 4
10 Socket 5
11 Fan Ventilates the air inside the control panel.
12 Aggregate Scale These are the sockets that connects the loadcells to
13 Cement Scale loadcell indicators on the control panel. Control the
14 Water Scale earthing on the sockets periodically. If there is a problem
15 Additive Scale about weighing, first check these sockets.
Loadcell
Connection
Sockets

20
OPERATOR PANEL

ENTRANCE PAGE

At this page you can choose language. Turkish, English and Russian are standart
languages. Optional language can be Hungarian, Polish, French, …etc. according to
special request. button takes you to Main Page.

button is used for transferring program to the operator panel, so it is useless


except this option. The operators can not do any operation with this button. If it is pressed
by mistake, there will not be any problem and you return previous page by pressing the
CANCEL.

21
MAIN PAGE

By Main Page you can brunch the all other pages. Follow the explanations below.

: Takes you to the Recipe Page where you can prepare new recipes, change
or load existed recipes.
: Takes you to the Settings Page where you can enter or change the whole
system parameters.

: Takes you to the Entrance Page where you can change language.

: This page is for only ELKON authorized personel.

: Takes you to the Working Page where you can watch the production
data.
: Takes you to the Page where you can watch motor‟s runtimes.
: Takes you to the Alarm Page where you can check automatically
generated alarms.
: Takes you to the Manuel Records Page where you can watch production
data, made manually.

22
RECIPE PAGES

You can prepare new recipes, save&load&delete or change existing recipes on these
pages.

1- At first page you can see a list of prepared recipes. For new recipes, press the
right arrow (4).

2- At this page, touch “new” to open the new recipe page.

23
4

3- At this page, you can enter recipe values. You can confirm values by pressing
right arrow.

4- Now you can name your recipe, and confim by pressing OK.

24
7

5- Choose a recipe from the list of prepared recipes .

6- Load your chosen recipe to PLC by pressing “to PLC”.

25
ALARM PAGE

Mixer Stop Mixer can not run.


Cement Bunker Cover Cement cover can not be moved.
Fault
Compressor Thermic Fault Compressor thermic is tripped.
Additive Bunker Cover Additive cover can not be moved.
Fault
Mixer Cover Open Mixer cover can not be move.
Weighing Band Thermic Weighing band thermic is tripped.
Fault
Aggregate Filling Fault Can not be reached to intended quantity, caused by an error at the aggregate
covers.
Weighing Band Overload Weighing band is overloaded.
Skip Winch Brake Fault The skip winch‟s break has a problem. (Skip Type Plant)
Skip General Security Put the limit switch out of this position. (Skip Type Plant)
Fault
Mixer Full Mixer is overloaded.
Phase Fault Supplied voltage problem.
Mixer Thermic Fault Mixer thermic is tripped.
Cement Filling Fault Can not be reached to intended quantity, caused by an error at the cement
covers.
Skip Winch Is Not At An error situation that the skip winch is not at position. (Skip Type Plant)
Position
Water Bunker Cover Fault Water cover can not be moved.
General Thermic Fault One of the thermics in the system, is tripped.
Skip Winch Thermic Fault Skip Winch Thermic is tripped. (Skip Type Plant)
Intermediate Bant Intermediate Bant Thermic is tripped. (If existed)
Thermic Fault

If any alrm exists, ALARM!! Warning is activated. By pressing button, can


be passed trough Alarm Page. Occurred alarm helps operator by blinking.
button takes you to the Main Page.

26
WORKING PAGES

1
4

5 5

10 11

The working pages help operator to follow production. On this page, some kind of
data like present weighing values, requested concrete quantity, the cycles which has done
and will be done, the mixing time, system total working time, can be seen.

START, STOP, RESET buttons at the right down side of the screen are used for
starting, stopping and resetting the operation.

1 Makes a blinking animation while the system is running. If any alarm situation
occurs or system is stopped by the Stop button, the blinking animation disappears and
helps the operator to see if the system is running or not.
2
Requested concrete quantity is entered to the field shown as “Quantity”. According to
the entered quantity, the cycle number is calculated automatically by the PLC program
and shown at the field “CYCLE”. The user can see how many cycle is operated by the
field “CYCLE MADE”.

3
Makes a blinking animation when the operation is at the first cycle and waits
command from the operator to open the mixer cover. At this situation operator must
control the truck position under the mixer and then push the SEND button. At the cycles
excepting the first one, the system will not wait any command from the operator to open
the mixer‟s cover so there will not be any blinking animation.

4 Shows the current of mixer.

5 Shows weighing values & mixer current with bigger fonts.

Can be watched how many seconds remain to the end of mixing time at
“REMAINING TIME” field.

Use left side buttons to pass the other pages.

27
SETTINGS PAGE

12

Can be passed to the specific setting pages of Aggregate, Water, Mixer, Vibration,
Cement, Additive, Alarm, Skip Winch via this page.

takes you to Main Page.

takes you to previous page.

28
AGGREGATE SETTINGS

13 14

Aggregate Scale Discharge The limit value for the aggregate scale that is accepted
Quantity empty.
Aggregate Scale Discharge Extra time for the aggregate cover to open after the
Time aggregate scale gets under the empty acceptance limit.
Aggregate Scale Balancing The waiting time for the aggregate scale to be balanced
Time between the different aggregate bunkera discharge.
Aggregate Scale Overload Overloaded weight for aggregate scale
Limit
AG 1 Humidity Humidity for Aggregate 1.
AG 2 Humidity Humidity for Aggregate 2.
AG 3 Humidity Humidity for Aggregate 3.
AG 4 Humidity Humidity for Aggregate 4.
AG1 Cover Fault The quantity of material which is hanging on the air after the
covers closed for aggregate 1.
AG2 Cover Fault The quantity of material which is hanging on the air after the
covers closed for aggregate 2.
AG3 Cover Fault The quantity of material which is hanging on the air after the
covers closed for aggregate 3.
AG4 Cover Fault The quantity of material which is hanging on the air after the
covers closed for aggregate 4.

buttons can be used to pass trough pages.

29
CEMENT SETTINGS

15 16

Cement Scale Discharge The limit value for the cement scale that is accepted empty.
Quantity
Cement Scale Balancing The waiting time for the cement scale to be balanced between
Time the different cement silos discharge.
Cement Discharge Time Extra time for the cement cover to open after the cement scale
gets under the empty acceptance limit.
Air Shock Waiting Time If the cement scale can not get the quantity of cement which is
shown at “Filling error quantity” field during the time entered
here, the vibration starts running.
Air Shock Working Time The running time period for the vibration after the Vibration
Waiting Time.
Cement 1 Filling Fault The quantity of material which is discharging after the covers
closed for Cement 1.
Cement 2 Filling Fault The quantity of material which is discharging after the covers
closed for Cement 2.
Cement 3 Filling Fault The quantity of material which is discharging after the covers
closed for Cement 3.
Cement 4 Filling Fault The quantity of material which is discharging after the covers
closed for Cement 4.

buttons can be used to pass trough pages.

30
WATER SETTINGS

17

Water Scale Discharge Time The limit value for the water scale that is accepted empty.
Water Discharge Time Extra time for the water cover to open after the water scale
gets under the empty acceptance limit.
Water 1 Filling Fault The quantity of material which is discharging after the
covers closed for Water 1.
Water 2 Filling Fault The quantity of material which is discharging after the
covers closed for Water 2.

31
ADDITIVE SETTINGS

18

Additive Scale Balancing The waiting time for the additive scale to be balanced
Time between the different additive silos pour out.
Additive Scale Discharge The limit value for the additive scale that is accepted empty.
Ratio
Additive Discharge Time Extra time for the additive cover to open after the additive
scale gets under the empty acceptance limit.
Additive 1 Filling Tolerance The quantity of material which is discharging after the pump
Limit closed for additive 1.
Additive 2 Filling Tolerance The quantity of material which is discharging after the pump
Limit closed for additive 2.
Additive 3 Filling Tolerance The quantity of material which is discharging after the pump
Limit closed for additive 3.
Additive 4 Filling Tolerance The quantity of material which is discharging after the pump
Limit closed for additive 4.

32
MIXER SETTINGS

19

Mixer Cover Mid Opening In hidrolic systems mixer cover opens during this time
Time
Mixer Cover Mid Position In hidrolic systems mixer cover waits during this time and
Waiting Time opens again.

33
ALARM SETTINGS

20

Aggregate Covers Maximum Opening Time Standing max. opened time for the aggregate
covers during the filling time.
Scale Covers Maximum Opening Time Standing max. opened time for the scale
covers during the filling time.
Mixer Cover Maximum Opening/Closing Maximum time for the mixer cover to be
Time closed or opened.

Weighing Band Maximum Running Time Maximum time for the weighing band to pull
out the load over it.
Cement Screws Maximum Running Time Maximum time for the taking requested
cement.
Horn Running Time. Horn running period.
Mixer Overload Current Limit Overload current limit for mixer motor. If
mixer current is over this limit, it waits for
“mixer overload current delay time” and if it‟s
still over the limit, the red overload current
lamp on the control panel turn on.
Mixer Overload Current Delay Time Maximum acceptable time for overloaded
current.

34
VIBRATING SETTINGS

21 22

Weighing Scale Vibration Waiting Limit Discharging material for the weighing band is
under this limit, weighing scale vibrator runs.
Cement Discharge Vibration Running Discharging material for the cement scale is under
Limit this limit, cement discharge vibrator runs.
Weighing Scale Vibration Waiting Time The waiting time period for the Weighing Scale
Vibration
Weighing Scale Vibration Running Time The running time period for the vibration after the
Weighing Scale Vibration Waiting Time.
Cement Discharge Vibration Waiting The waiting time period for the Cement Discharge
Time Vibration
Cement Discharge Vibration Running The running time period for the vibration after the
Time Cement Discharge Vibration Waiting Time.
Weighing Scale Discharge Per Second Discharging material for weighing scale per
second.
Cement Discharge Per Second Discharging material for cement scale per second.
Cement Vibrator Working Limit Discharging materials are under this limit when
taking materials, cement wibrator runs.
Cement Vibrator Waiting Time The waiting time period for the Cement Vibrator
Cement Vibrator Working Time The running time period for the vibration after the
Cement Vibrator Waiting Time.
Ag2 Vibration Waiting Time The waiting time period for the Ag2 Vibrator
Ag2 Vibration Running Time The running time period for the vibration after the
Ag2 Vibration Waiting Time.
Ag3 Vibration Waiting Time The waiting time period for the Ag3 Vibrator
Ag3 Vibration Running Time The running time period for the vibration after the
Ag3 Vibration Waiting Time.

35
SKIP WINCH SETTINGS

(This page is for only QUICK MASTER or SKIP WINCH TYPE Plants ! If your
plant is not one of these, please pass to next page !)

23

Waiting Time For Skip Winch When the skip winch reaches top position, waits for
Top Position this time to discharge.
Skip Winch Middle Running The skip winch during moving up if necessary
Time conditions aren‟t provided the skip winch starts to
move along the entry time than waits here. When the
conditions are provided the skip winch start to move.
Skip Winch Maximum Running The maximum time for skip winch‟s movement.
Time

36
MOTOR RUNNING TIMES

24 25

Screw1 It shows screw1 motor running time.


Screw2 It shows screw2 motor running time.
Screw3 It shows screw3 motor running time.
Screw4 It shows screw4 motor running time.
Mixer It shows mixer motor running time.
Transfer It shows transfer conveyor motor running time.
Conveyor
Additive 1 It shows Additive 1 Pump running time.
Additive 2 It shows Additive 2 Pump running time.
Additive 3 It shows Additive 3 Pump running time.
Additive 4 It shows Additive 4 Pump running time.

37
WATCHING VALUES

26 27

INTENDED QUANTITY : The quantity of material that calculated by PLC


automatically according to the recipe and intended cubic meter.
TAKEN QUANTITY : The real quantity that is taken and weighed by the scales.

Intended and taken quantities can be compared on these pages and if necessary
parameters can be changed.

buttons can be used to pass trough pages.

38
MANUEL RECORDS

28 29

Manuel Daily Records Manuel Archive

On “Manuel Daily Records” Manuel Production Records can be shown at this page for
present day.

Pressing button you can pass to archive pages


By buttons, manuel production records can be shown for last 10 days.

39
WEIGHING CALIBRATING

30

On this page, scale‟s capacity values & mixer‟s slumpmeter and humidity coefficients.

This parameters must be entered when first setup of the plant correctly. This
parameters are entered ELKON Authorized Personel. To prevent any unauthorized
access, this page is password-protected !

Before calibrating scales, be sure that no materials on scales. Also be sure that no
mechanical standings to scales & scale is holded only by loadcell arms and swinging
freely.

40
WEIGHING INDICATOR’S CALIBRATION

There are three-type of indicators, used in control panels.

Please check the indicator types below and follow suitible indicator’s user guide !

AXE :

ASAHI :

ESIT :

41
MULTIMETER

42

You might also like
