MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide Preface
Preface
Thank you for purchasing the MCTC-ARD-C series elevator emergency automatic rescue
device.
Before using the product, read this guide carefully to have a better understanding of the
product features and to use the product more safely. This guide describes the product
specifications, mounting dimensions, terminals, commissioning, and troubleshooting.
Introduction
The ARD is a backup power unit that continuously monitors the elevator mains supply.
During an event of a power failure or phase loss, the MCTC-ARD-C automatically enters
the emergency rescue state and supplies power to the elevator. The ARD drives the car
for the light-load operation to the nearest floor at the emergency rescue speed, and
then the door opens to ensure any onboard passengers' safety.
Product Features
◆◆ A perfect match with the MONARCH elevator controller and commissioning-free design;
◆◆ Redundancy protection and reliable performance;
◆◆ Smart battery management and longer service life;
◆◆ Fault classification for quick fault location;
◆◆ Modular design for easier maintenance.
Safety Precautions
This device is connected to high voltage and may cause severe elec-
tric shock or even death.
DANGER
◆◆ Always be on high alert when using or being close to the device
that has been connected to the power supply.
The product is an elevator safety device for emergency rescue when

a power failure or phase loss occurs.
WARNING ◆◆ Incorrect installation may result in safety risks. System instal-
lation, commissioning and maintenance personnel must have
prior trainings on safety and product use.
-1-
Preface MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide
◆◆ It is prohibited to rely solely on startup, stop or input signals of

the device for personal safety during elevator maintenance as
CAUTION these signals cannot isolate dangerous voltage.
◆◆ Before electrical wiring, use a reliable insulation component to

disconnect the power supply of the elevator.
The following table describes the safety signs.
◆◆ High voltage!
◆◆ Before maintenance, cut off all power supplies

and wait 10 minutes.
◆◆ Before using the product, read the user guide

and safety instructions carefully.
-2-
MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide Revision History
Revision History
Date Version Change Description
◆◆ Add batter y maintenance information of

replacement once every 2 years and charging
and discharging once every 3 to 6 months
◆◆ Modify the parameter description of A0-02, A0-

April 2022 A02
15 and A0-20
◆◆ Delete the parallel connection-related content

in the chapter Preface
◆◆ Update front and back cover style
◆◆ Delete the contents about parallel connection
November 2021 A01 ◆◆ Add the size of the driver board
◆◆ Delete A0-17 and Err26
April 2021 A00 First issue
-3-
Contents MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide
Contents
Chapter 1 Product Information......................................................................................... 5
1.1 Designation Rule.................................................................................................. 5
1.2 Product Dimensions............................................................................................ 6
1.3 Technical Specifications...................................................................................... 9
Chapter 2 Installation....................................................................................................... 11
2.1 Installation Environment.................................................................................. 11
2.2 Installation Method............................................................................................ 11
Chapter 3 Wiring............................................................................................................... 15
3.1 Description of Terminals................................................................................... 15
3.2 Wiring Guidance................................................................................................. 18
Chapter 4 Commissioning................................................................................................ 22
4.1 Operating Panel................................................................................................. 22
4.1.1 LED Display Digital Tube ..................................................................... 22
4.1.2 Keys....................................................................................................... 26
4.1.3 Inspection Button................................................................................ 27
4.2 Function Description......................................................................................... 27
4.3 Commissioning.................................................................................................. 29
4.3.1 Commissioning Flowchart.................................................................. 29
4.3.2 Safety and Circuit Inspections............................................................ 29
4.3.3 Elevator and ARD State Inspection..................................................... 30
4.3.4 Main ARD Parameters.......................................................................... 31
4.3.5 ARD Operation...................................................................................... 31
Chapter 5 Maintenance.................................................................................................... 32
Chapter 6 Fault Code Description................................................................................... 34
6.1 Fault Category Description............................................................................... 34
6.2 Troubleshooting................................................................................................ 34
-4-
MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide Product Information
Chapter 1 Product Information
1.1 Designation Rule

MCTC - ARD - C - XPX - XXA - N
Code Product series Code Battery configuration
MCTC Optional parts N No battery
Code Optional part type Code Contactor current

ARD Emergency automatic 18 A 18 A
rescue device 32 A 32 A
Code Power rating 50 A 50 A
0P6 0.6 kW 65 A 65 A
0P8 0.8 kW 80 A 80 A
1P6 1.6 kW
Table 1-1 Model selection guidance
Battery
Size Model Typical elevator load/speed
specification
630 Kg ≤ 1.75 m/s
800 Kg ≤ 1.0 m/s 12 V 5.5 AH
1,000 Kg ≤ 1.0 m/s
MCTC-ARD-C-0P6-18A Three batteries in
1,150 kg ≤ 1.0 m/s
1,250 kg ≤ 0.63 m/s series connection
1,350 kg ≤ 0.63 m/s
800 kg ≤ 2 m/s
1,000 kg ≤ 1.75 m/s
1,150 kg ≤ 1.5 m/s
Size 1 MCTC-ARD-C-0P8-32A
1,250 kg ≤ 1.0 m/s
1,350 kg ≤ 1.0 m/s 12 V 7 AH
1,600 kg ≤ 1.0 m/s
Three batteries in
800 kg ≤ 2.5 m/s
1,150 kg ≤ 2.0 m/s
MCTC-ARD-C-0P8-50A
1,250 kg ≤ 2.0 m/s
1,350 kg ≤ 2.0 m/s
1,600 kg ≤ 1.6 m/s
-5-
Product Information MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide
Battery
Size Model Typical elevator load/speed
specification
Function of rescue on certain
defined floors supported
600 Kg 0.1 to 0.2 m/s (Rescue 12 V 10 AH
distance of greater than or
MCTC-ARD-C-1P6-18A Three batteries in
equal to 10 m)
800 Kg 0.1 to 0.2 m/s (Rescue series connection
distance of greater than or
equal to 6 m)
Size 2 1,150 kg ≤ 2.5 m/s
1,250 kg ≤ 2.5 m/s
MCTC-ARD-C-1P6-65A
1,350 kg ≤ 2.5 m/s
1,600 kg ≤ 2.5 m/s 12 V 12 AH
1,150 kg ≤ 2.5 m/s Three batteries in
MCTC-ARD-C-1P6-80A 1,350 kg ≤ 2.5 m/s
1,600 kg ≤ 2.5 m/s
2,000 kg ≤ 2.5 m/s
1.2 Product Dimensions

8 %
)
8
Figure 1-1 Product dimensions (unit: mm)
-6-
W1 W H1 H D
Size Model
(mm) (mm) (mm) (mm) (mm)
MCTC-ARD-C-0P6-18A
MCTC-ARD-C-0P6-18A-N
MCTC-ARD-C-0P8-32A
Size 1 - 262 - 525 174
MCTC-ARD-C-0P8-50A
MCTC-ARD-C-1P6-65A
MCTC-ARD-C-1P6-18A
Size 2 353 320 720 680 156
MCTC-ARD-C-1P6-80A

#PBSEUIJDLOFTT

Figure 1-2 Size 1 Driver board dimensions (unit: mm)
-7-

#PBSEUIJDLOFTT

Figure 1-3 Size 2 Driver board dimensions (unit: mm)
-8-
1.3 Technical Specifications

Table 1-2 Technical specifications
Specifications
Item
0.6 kW 0.8 kW 1.6 kW
Three-phase five-wire 380 VAC (± 15%), 50/60 Hz

Three-phase four-wire 220 VAC (-20 % to +15%),
Input parameter
50/60 Hz
Single-phase 220 VAC (-20 % to +15 %), 50/60 Hz
Single-phase 380 VAC (-15 % to +10%)

Output parameters
Single-phase 220 VAC (-15 % to +10%)
Basic
220 V, 3.9 A 220 V, 5.2 A 220 V, 10.4 A
specifica- Output current
380 V, 2.3 A 380 V, 3 A 380 V, 6 A
tions
Light-load direction res-
cue of elevator system of
Recommended power Light-load direction res-
37 kW and below
of compatible eleva- cue of elevator system of
Defined direction rescue
tors 22 kW and below
of elevator system of
7.5 kW and below
Battery discharging
Available
overcurrent protection
Inverter output over-

Available
current protection
Protection Bus overvoltage pro-

Available
features tection
Battery undervoltage
Available
protection
Battery retirement
Available
monitoring
Forced activation Available
Rescue ARD maintenance

Available
function mode
ARD test mode Available
-9-
Specifications
Item
0.6 kW 0.8 kW 1.6 kW
Place of service Indoor use (no corrosive gases or dust)
The altitude of the actual usage is below 1000 m. If it

exceeds, derate the current by 1% for every addi-
Altitude
tional 100 m. The maximum operating altitude is
3000 m.
Environ- 0° C to +50° C (Derate the current by 1.5% for each
ment Operating temperature 1° C higher if the ambient temperature is above

40° C. The maximum operating temperature is 50° C)
Storage temperature -20℃ to +60℃
Humidity < 95％ RH, non-condensing
Vibration Below 5.9 m/s2 (0.6 g)
IP rating IP 20
- 10 -
MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide Installation
Chapter 2 Installation
2.1 Installation Environment

The ARD is installed close to the elevator control cabinet inside the elevator machine
room or along the shaft. Sufficient room for maintenance must be reserved. The operat-
ing environment must meet the requirements in Table 1-2.
2.2 Installation Method

Backplate and floor-standing installation methods are provided.
◆◆ Please prepare M6 screws and Phillips screwdrivers before installa-

NOTE tion.
Backplate Installation
◆◆ There are 3 mounting holes.

NOTE ◆◆ The lower mounting holes are inside the cabinet and the cover plate
needs to be removed first.
❶ Make hole openings in the wall as per the position and size shown in the figure;
❷ Loosen the ARD cover plate screws and remove the plate;
❸ Align the ARD device with the wall openings, tighten the screws and complete the
installation process.
- 11 -
Installation MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide
.TDSFX
.PVOUJOH
IPMFT

3FTFSWFEIPMFT

Figure 2-1 Size 1 Backplate installation (Unit: mm)
.TDSFX
.PVOUJOH
IPMFT

Figure 2-2 Size 2 Backplate installation (Unit: mm)
■ Floor-standing Installation
◆◆ There are 4 mounting holes and they are located at the bottom left
NOTE and right sides.
- 12 -
MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide Installation
❶ Make hole openings in the floor as per the position and size shown in the figure;
❷ Align the ARD device mounting holes with the floor openings;
❸ Tighten the screws and complete the installation process.

.PVOUJOH
IPMFT

Figure 2-3 Size 1 Floor-standing installation (Unit: mm)
- 13 -
Installation MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide

.PVOUJOH
IPMFT

Figure 2-4 Size 2 Floor-standing installation (Unit: mm)
- 14 -
MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide Wiring
Chapter 3 Wiring
3.1 Description of Terminals

Table 3-1 Description of Terminal Block Board Terminals
Category Terminals Description of terminals Function
PE
N1
Three-phase AC power
L1 The mains power is connected to
supply input
L2 terminals L1, L2 and L3 of the ARD.
Main
Terminals R, S and T are connected
power L3
to the elevator control cabinet. This
terminals R ensures the elevator operates in
S both normal and emergency states.
Output terminals
T
Low level active (0 to 10 V). After

receiving this signal, the ARD
assumes that emergency rescue is
completed, stops output, and exits
Rescue completion signal
DI1 the emergency state for the power
input
to be back on. If the ARD does not
receive this signal, it automatically
stops output after running for 3
minutes (set by parameters).
CNM1 Low level active (0 to 10V). After

receiving this signal, the ARD
Manual disconnection of
assumes that the air switch is dis-
DI2 the air switch with signal
connected. Even if a power failure
input of no rescue
occurs, ARD rescue will not come
into play.
Low level active (0 to 10V). After

DI3 Forced rescue receiving this signal, the ARD will
start forced rescue.
COM Ground -
- 15 -
Wiring MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide
Category Terminals Description of terminals Function
Connected when the ARD is in

Emergency state output emergency state;
Y1
signal Disconnected when the ARD emer-
gency state stops.
CNM1
M1
Y2 Fault output Connected in case of an ARD fault.
M2
/ -
CAN-H CAN (+) CAN communication terminals with

CNM2
CAN-L CAN (-) the main board
COM Ground
CAN-H CAN (+)
CAN-L CAN (-) CAN communication terminals
CNM3 COM Ground
Y3 Battery fault output sig- Connected in case of an ARD bat-

M3 nal (Reserved) tery fault
Y4 When there is a phase sequence
/ relay, this terminal works:

Short the phase sequence Connected when the ARD is in
CNM4
relay emergency state;
M4 Disconnected when the ARD emer-
gency state stops.
One switch end for forced

SW+ ARD activation (Without
machine room) Forced rescue terminal (Without
CNM5
The other switch end for machine room)
SW- forced ARD activation
(Without machine room)
Self-reset
Long press the switch for 3 seconds
rocker S2 Forced activation switch
for forced activation.
switch
Programming port/wire- Update the program or connect to

USB port CNM6
less port the WiFi module.
- 16 -
Plug type:
NOTE ◆◆ CNM1:Plug-in terminal block - Plug - Screw type - 3.81 mm - 10P -
Green
◆◆ CNM2: Connector of rubber housing - Plug - 2.5 mm - One row -

1*4P - White - XH2.5 series
◆◆ CNM3: Plug-in terminal block - Plug - Screw

type - / - 3.81 mm - 5P - Green

type - / - 3.81 mm - 3P - Green

type - / - 3.81 mm - 2P - Green
Note: It is recommended to use shielded twisted pair for the CAN com-
munication.
- 17 -
3.2 Wiring Guidance
◆◆ When there is no feedback from the main air switch, DI2 needs to be
NOTE set to the normally open (A0-07=2) state; Otherwise ARD rescue will not
come into play.
■ Three-phase Five-wire 380 V Input Wiring Diagram
Power distribution cabinet

Main air switch
disconnection monitoring ARD
DI2
13 14
COM
Main air switch

Input power cable
L1 L1
1 2
L2 L2
3 4
L3 L3
5 6
N N1
7 8
Cable in yellow and green
PE PE
■ Three-phase Four-wire 220 V Input Wiring Diagram

Main air switch
disconnection monitoring DI2 ARD
13 14
COM
Main air switch

Input power cable
L1 L1
1 2
L2 L2
3 4
L3 L3
5 6
N1
PE PE
- 18 -
■ Single-phase 220 V Input Wiring Diagram

Main air switch monitoring
DI2 ARD
13 14
COM
Main air switch

Input power cable
L1 L1
1 2
L2
L3
N N1
3 4
PE PE
■ Wiring Between ARD and Control Cabinet
Elevator control cabinet

Output power cable
R R
ARD
S S
T T
N N
PE PE
CAN communication
CAN+ CAN+
CAN- CAN- Communication
COM COM
Rescue completed
DI1 DO
COM COM
Initiate emergency rescue
Y1 DI
M1 301
Fault output
Y2 DI
M2 301 Non-communication
Y3
Battery fault output
DI
M3 301
Short the phase phase sequ-
ence relay
Y4 sequence relay 11
M4 14
- 19 -
◆◆ If the ARD is used with the four-quadrant AC drive (not from Inovance
subsidiary MONARCH), it is necessary to ensure that the feedback func-
NOTE
tion of the AC drive is disabled during rescue, and adjust the rescue
speed properly to avoid overvoltage fault.
■ Wiring of Single-phase 220 V ARD Used with an AFE
◆◆ The AFE can only work with the single-phase (not three-phase) ARD.
NOTE ◆◆ When used with AFE, it is necessary to ensure that the feedback func-
tion of the AC drive is disabled during rescue, and adjust the rescue
speed properly to avoid overvoltage fault.
◆◆ For more information about AFE wiring with the control cabinet, refer
to Elevator Active Front End User Guide.
Wiring of the ARD used with the four-quadrant AFE
AFE
ARD
R
L1
S
L2 + -
T
L3
AC drive
- 20 -
Wiring of the ARD used with the regenerative AFE
AFE
ARD
+ -
R
L1
S
L2
AC drive
T
L3
- 21 -
Commissioning MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide
Chapter 4 Commissioning
4.1 Operating Panel

The operation panel consists of the LED display digital tube, keys and inspection but-
ton. You can view the ARD information and input commands on the panel.
-&%EJTQMBZEJHJUBMUVCF
,FZT
*OTQFDUJPOCVUUPO
Figure 4-1 Operation panel appearance
4.1.1 LED Display Digital Tube
◆◆ If the LED display digital tube flashes when ARD is powered on, there
NOTE may be phase loss on L2 or L3. Please cut off the power and check the
wiring before getting power back on.
The LED display digital tube is of 5 bits and 7 segments:

" " " " "
' # ' # ' # ' # ' #
( ( ( ( (
& $ & $ & $ & $ & $
% %1 % %1 % %1 % %1 % %1
◆◆ It has a three-tier menu to perform operations such as parameter set-
NOTE tings. The details are:
Tier 1: Default
Tier 2: Function code
Tier 3: Parameters
- 22 -
MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide Commissioning
■ Tier 1: Default Example
4UBUFEJTQMBZ 7BMVFEJTQMBZ
"3%/0
$"/JOEJDBUPS
'MBTIJOH4VDDFTTGVMDPNNVOJDBUJPO
0"COPSNBMDPNNVOJDBUJPO
Table 4-1 Description of state indicators
State Example Description
Charging state, upper half flashing

Charging state ARD No. 0, charging state, battery volt-
age 40.1 V
Discharging state
Discharging state, shape U flashing
(Give display priority to
ARD No. 0, discharging state, battery
the voltage lower than
voltage 29.1 V
30 V)
Discharging state Remaining rescue time, lower half

(Give display priority to flashing
the voltage higher than ARD No. 0, discharging state, remaining
30 V) rescue time 360s
Standby state, no flashing

Standby state ARD No. 0, standby state, battery volt-
age 40.1 V
Fault state
(Give display priority Fault display E
to the fault higher than Fault code 003
level 3)
Rescue prohibited, middle flashing

In standby or charging
ARD No. 0, standby state, battery volt-
state, S1 inspection
age 40.1 V
input valid and rescue
ARD No. 0, charging state, upper half
prohibited
flashing, battery voltage 40.1 V
- 23 -
State Example Description
Temperature state, shape C flashing

Temperature display
ARD No. 0, temperature 60 ℃
■ Tier 2: Function Code Example
Table 4-2 Tier 2: Function code description
Function
Name Description
code
A0-00 Password -
Emergency rescue response time
A0-01 3s to 45s (China National Standards)
setting
A0-02 Emergency rescue time 60s to 480s (default : 360s)
0: 220 V (by default)
A0-03 Rescue voltage selection
1: 380 V
0: Forced rescue signal invalid
A0-04 Forced rescue signal
1: Forced rescue signal valid
0 to 3 (Manual reset is required after 3
A0-05 Fault auto reset times
auto reset times at most)
DI1 normally open or closed se- 0: Null

A0-06
lection after rescue completion 01: Normally open
02: MCCB auxiliary contact normally open
DI2 MCCB auxiliary contact nor-
A0-07 03: Forced rescue normally open
mally open or closed selection
04: Contactor auxiliary contact normally
DI3 Forced rescue normally open
A0-08 open
or closed selection
05: Inspection switch normally open
JP1 Contactor auxiliary contact 32: Null
A0-09 normally open or closed selec- 33: Normally closed
tion 34: MCCB auxiliary contact normally
closed
35: Forced rescue normally closed
STS1 Inspection normally open
A0-10 36: Contactor auxiliary contact normally
or closed selection
closed
37: Inspection switch normally closed
- 24 -
Function
Name Description
code
Y1-M1 Output normally open or 0: Null

A0-11
closed selection 01: Rescue output normally open
02: Fault output normally open
Y2-M2 Output normally open or
A0-12 03: Battery fault output normally open
closed selection
04: Phase sequence relay output normal-
A0-13 ly open
closed selection
32: Null
33: Rescue output normally closed
34: Fault output normally closed
A0-14 35: Battery fault output normally closed
closed selection
36: Phase sequence relay output normal-
ly closed
0: Three-phase five-wire 380 V
Wiring system 1: Three-phase four-wire 380 V
(Wiring system setting is related 2: Three-phase five-wire 480 V (Custom-
to ARD phase loss identification. ized)
Please set this parameter accord- 3: Three-phase four-wire 480 V (Custom-
A0-15
ing to the actual conditions. If ized)
the ARD does not work due to 4: Three-phase five-wire 220 V (Custom-
phase loss, check whether this ized)
parameter is set correctly.) 5: Three-phase four-wire 220 V
6: Single-phase 220 V
1: 800 W
A0-16 Model (read-only)
2: 1,600 W
Software version (non-modifi-
A0-18 XX.XX
able)
Software version (Non-modifi-
A0-19 Temporary version LXX.XX
able)
Software version (non-modifi-
A0-20 Manufacturer No. FXX.XX
able)
0: 50 Hz (by default)
A0-21 Grid frequency
1: 60 Hz
- 25 -
■ Tier 3: Parameters Example
4.1.2 Keys
■ Definition
Key Function
Setting key
Return key; Fault reset function enabled after pressing for 5s
Up key
Down key / left key (when setting parameters)
■ Key Operation
Tier 1 Menu
Key Function
/ Up/Down key for display content change
+ Press them for 2s at the same time to enter the tier 2 menu
Return key
Tier 2 menu interface (Without operation for 3 min, it automatically exits and returns to
the tier 1 menu interface.)
Key Function
/ Up/Down key for function code change
Enter tier 3 menu interface
Back to tier 1 menu interface
Tier 3 menu interface (Without operation for 3 min, it automatically exits and returns to
the tier 1 menu interface.)
Key Function
/ Up/Down key for parameter adjustment
- 26 -
Tap to save parameters and return to the tier 2 menu interface
Tap to return to the tier 2 menu interface and long press for 3s to return to
the tier 1 menu interface
4.1.3 Inspection Button
Start-up
Description
switch
In normal state, automatic rescue function is effective with the button
indicator off
After pressing the button, it enters inspection state and automatic rescue
function is invalid with the button indicator on
4.2 Function Description

This is how the ARD functions:
① When the mains power is normal, the ARD charges the battery.
Figure 4-2 LED display digital tube (charging status, battery voltage 40.1 V)
② When a fault occurs in the mains power, the ARD operates according to the following
flowchart.
- 27 -
Power Elevator
failure enters the
After 10s of power ARD discharging ARD sends emergency
failure (Rescue voltage set emergency state
(Time set by A0-01) by A0-03) rescue signal
ARD emergency Y Elevator sends

rescue completion rescue com-
pletion signal? Continued ARD
discharging (Rescue
After 360s, the
voltage set by A0-03)
Y rescue is over?
(Time set by
A0-02)
Figure 4-3 Emergency rescue flowchart
Figure 4-4 LED display digital tube (discharging state, battery voltage 39.1 V)
Figure 4-5 LED digital tube display (discharging state, remaining rescue time 360s)
③ When the mains power comes back on, the ARD transmits power to the elevator con-
trol cabinet, and the elevator transfers back to normal operation.
- 28 -
4.3 Commissioning
4.3.1 Commissioning Flowchart
Start
Safety and circuit inspections
Power on and check the elevator and ARD state
Main ARD parameters
ARD operation
End
Figure 4-6 Commissioning flowchart
4.3.2 Safety and Circuit Inspections
■ System Wiring Safety Inspection
Step 1: Check the mechanical safety
Step 2: Check the electrical wiring
Step 3: Check the electrical safety
Figure 4-7 Flowchart of safety and circuit inspection before power-on
Step 1: Mechanical safety inspection
Check for a totally clear shaft, car and car roof to create a safe operating environment
for the elevator.
- 29 -
Step 2: Electrical wiring inspection
No. Item
1 Check whether the power input terminals are connected correctly and firmly.
2 Check whether the ARD output terminals are connected correctly and firmly.
3 Check whether the ARD is reliably grounded.
Ensure that the safety circuit functions normally and the emergency stop but-
4
tons and switches in the control system operate properly.
Step 3: Electrical safety inspection
No. Item
1 Ensure that the user power voltage is within the ARD specified range.
2 The wire specifications and total switch capacity meet the requirements.
3 Check whether the inter-phase short-circuit or short-circuit to ground occurs.
4.3.3 Elevator and ARD State Inspection
No. Item
Power on the elevator with the mains power and check whether it runs nor-
1
mally.
Check that the LED digital tube displays. If it does not flash, check the power
2
supply.
3 Check the ARD battery and ensure that the energy level is not less than 30 V.
◆◆ Charge the battery if the energy level is below 30 V.
NOTE ◆◆ Check the battery if the operating panel shows Err01.
Initial Commissioning
NOTE ◆◆ Do not perform commissioning on the top or bottom floor. Run the
elevator to the middle floor. Bring the elevator up or down. Cut off
the main power when the elevator runs to the non-door zone.
- 30 -
4.3.4 Main ARD Parameters
Function
Name Description
code
Emergency rescue response time
A0-01 3s to 45s (China National Standards)
setting
Emergency rescue duration
A0-02 60s to 480s (default : 360s)
setting
A0-03 Rescue voltage selection 220 V (by default) / 380 V
0: Three-phase five-wire 380 V
Wiring system 1: Three-phase four-wire 380 V
(Wiring system setting is related 2: Three-phase five-wire 480 V (Custom-
to ARD phase loss identification. ized)
Please set this parameter accord- 3: Three-phase four-wire 480 V (Custom-
A0-15
ing to the actual conditions. If ized)
the ARD does not work due to 4: Three-phase five-wire 220 V( Custom-
phase loss, check whether this ized)
parameter is set correctly.) 5: Three-phase four-wire 220 V
6: Single-phase 220 V
4.3.5 ARD Operation
Some ARD faults may occur during the commissioning process, especially for the initial
power-on. The faults at this stage may be Err01, Err02, Err03 and so on. Please refer to
Fault Code Description for solutions.
◆◆ The recommended rescue speed can be set at 0.1 to 0.2 m/s

NOTE
- 31 -
Maintenance MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide
Chapter 5 Maintenance
CAUTION
◆◆ Before maintenance, disconnect the air switch to ensure that the ARD is
disconnected from the mains power.
◆◆ After power-off, wait 10 min until the capacitor of the drive board is com-
pletely discharged.
◆◆ Use a screwdriver with an insulated handle, and do not lay tools or other
metal objects on the battery.
◆◆ Correct polarity of the battery must be maintained to prevent the battery

from being damaged because of a short-circuit.
◆◆ Replace the battery as the fault code indicates （or once every 2 years）
and charge and discharge it once every three to six months.
- 32 -
MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide Maintenance
Battery replacement Precautions
① Open the door plate, remove the two ◆◆ To prevent a short-circuit on positive
screws on the battery bracket, discon- and negative poles of the battery, do not
nect the terminals to take out the bat- remove the battery terminal screws on
the PCB. Just remove the plug-and-pull
tery;
terminals of the battery.
◆◆ Correct polarity must be maintained for

right connection and ensure that the
indicator signifying reverse polarity con-
nection does not alarm.
Battery terminal screws

on the PCB
(Do not remove)
3FNPWFTDSFXTPO
UIFCBUUFSZCSBDLFU
BAT+ BAT-
D66
WARNING!
REVERSE
BATTERY
Reverse battery
connection alarm
Figure 5-2 Size 1 PCB battery terminal

and alarm indicator
Figure 5-1 Battery replacement Battery terminal screws

on the PCB
(Do not remove)
② Put the new battery back in place to
complete the replacement process.
WARNING!
REVERSE
BATTERY
BAT+ BAT-
D86
Reverse battery
connection alarm
Figure 5-3 Size 2 PCB battery terminal

and alarm indicator
- 33 -
Fault Code Description MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide
Chapter 6 Fault Code Description
6.1 Fault Category Description

Fault
Fault display In standby state In charging state In discharging state
level
Fault is displayed.
Fault is displayed.
Normal The ARD is charged Fault is displayed.
The ARD discharges
1A charging and normally, and The ARD is charged
for emergency rescue
rescue discharges for normally.
normally.
emergency rescue.
Fault is displayed.
Normal The ARD is charged Fault is displayed. Fault is displayed. The
2A charging and normally, and does The ARD is charged ARD does not discharge
failed rescue not discharge for normally. for emergency rescue.
emergency rescue.
Fault is displayed.
Failed The ARD is not Fault is displayed. Fault is displayed. The
3A charging and charged, and does The ARD is not ARD does not discharge
rescue not discharge for charged. for emergency rescue.
emergency rescue.
6.2 Troubleshooting
Fault Fault
Fault analysis Solution
code level
Err01 Battery fault ◆◆ Check the battery 1A
Battery not connected ◆◆ Cut off power and check the battery con-
Err02 3A
or connected reversely nection
◆◆ Phase loss on power supply or wrongly

Err03 Abnormal power input 3A
connected neutral wire and live wire
◆◆ During discharging, the battery voltage is

Battery undervoltage
Err04 lower than the undervoltage threshold of 2A
protection
30 V and charging is needed
◆◆ The main contactor is detected as stuck.

Err06 Main contactor stuck 2A
Ask for maintenance support
- 34 -
MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide Fault Code Description
Fault Fault
code level
Zero drift protection

Err07 ◆◆ Ask for maintenance support 2A
fault
Overtemperature ◆◆ Get the temperature down before use

Err08 2A
protection fault again
Push-pull circuit over-

Err09 ◆◆ Replace with a larger ARD 2A
load
Bus undervoltage
protection
Bus overvoltage pro-

tection
◆◆ Shut down the ARD and tr y to rescue

Push-pull circuit input
Err13 again. If this fault is reported after many 2A
overcurrent
attempts, ask for maintenance support
◆◆ Rescue disabled by the AC drive fault (CAN

Rescue disabled by communication mode only). Check wheth-
Err14 2A
the AC drive er the control cabinet parameters are set
for rescue

Err15 ◆◆ Replace with a larger ARD 2A
load
◆◆ Shut down the ARD and tr y to rescue

Err16 again. If this fault is reported after many 2A
current
attempts, ask for maintenance support
Inspection button not ◆◆ Check the state of ARD panel inspection

Err23 2A
closed button
◆◆ Check the feedback contact of the main air

switch
◆◆ Check whether the main air switch is

Main air switch not
Err24 closed 2A
closed
◆◆ If there is no feedback input of the main
air switch, check whether the DI setting is
correct
Contactor can not be

Err25 ◆◆ Check contactor wiring 2A
closed
- 35 -
Fault Code Description MCTC-ARD-C Series New Elevator Emergency Automatic Rescue Device User Guide
Fault Fault
code level
◆◆ Check if the output FUSE is disconnected
Abnormal output
Err28 2A
voltage
- 36 -
*19011603A02*
&RS\ULJKWk6KHQ]KHQ,QRYDQFH7HFKQRORJ\&R/WG
$
6KHQ]KHQ,QRYDQFH7HFKQRORJ\&R/WG $GG ,QRYDQFH+HDGTXDUWHUV7RZHU+LJKWHFK,QGXVWULDO3DUN

*XDQODQ6WUHHW/RQJKXD1HZ'LVWULFW6KHQ]KHQ
ZZZLQRYDQFHFRP 7HO )D[
6X]KRX,QRYDQFH7HFKQRORJ\&R/WG $GG 1R<RX[LDQJ5RDG<XH[L7RZQ

:X]KRQJ'LVWULFW6X]KRX35&KLQD
ZZZLQRYDQFHFRP 7HO )D[

0&7&$5'&6HULHV1HZ (OHYDWRU (Phujhqf/$Xwrpdwlf5Hvfxh'Hylfh: 8vhu XLGH

Uploaded by

Document Information

Original Description:

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

0&7&$5'&6HULHV1HZ (OHYDWRU (Phujhqf/$Xwrpdwlf5Hvfxh'Hylfh: 8vhu XLGH

Uploaded by

Copyright:

Available Formats

0&7&$5'&6HULHV1HZ(OHYDWRU

,QGXVWULDO ,QWHOOLJHQW 1HZ(QHUJ\ ,QGXVWULDO 5DLO

◆◆ Redundancy protection and reliable performance;

◆◆ Smart battery management and longer service life;

◆◆ Fault classification for quick fault location;

◆◆ Modular design for easier maintenance.

The product is an elevator safety device for emergency rescue when

◆◆ It is prohibited to rely solely on startup, stop or input signals of

◆◆ Before electrical wiring, use a reliable insulation component to

The following table describes the safety signs.

◆◆ Before maintenance, cut off all power supplies

◆◆ Before using the product, read the user guide

Date Version Change Description

◆◆ Add batter y maintenance information of

◆◆ Modify the parameter description of A0-02, A0-

◆◆ Delete the parallel connection-related content

◆◆ Update front and back cover style

◆◆ Delete the contents about parallel connection

November 2021 A01 ◆◆ Add the size of the driver board

◆◆ Delete A0-17 and Err26

April 2021 A00 First issue

1.1 Designation Rule.................................................................................................. 5

1.2 Product Dimensions............................................................................................ 6

1.3 Technical Specifications...................................................................................... 9

2.1 Installation Environment.................................................................................. 11

2.2 Installation Method............................................................................................ 11

3.1 Description of Terminals................................................................................... 15

3.2 Wiring Guidance................................................................................................. 18

4.1 Operating Panel................................................................................................. 22

4.1.1 LED Display Digital Tube ..................................................................... 22

4.1.3 Inspection Button................................................................................ 27

4.2 Function Description......................................................................................... 27

4.3.1 Commissioning Flowchart.................................................................. 29

4.3.2 Safety and Circuit Inspections............................................................ 29

4.3.3 Elevator and ARD State Inspection..................................................... 30

4.3.4 Main ARD Parameters.......................................................................... 31

4.3.5 ARD Operation...................................................................................... 31

Chapter 6 Fault Code Description................................................................................... 34

6.1 Fault Category Description............................................................................... 34

Chapter 1 Product Information

1.1 Designation Rule

Code Optional part type Code Contactor current

Table 1-1 Model selection guidance

1.2 Product Dimensions

Figure 1-1 Product dimensions (unit: mm)

Figure 1-2 Size 1 Driver board dimensions (unit: mm)

Figure 1-3 Size 2 Driver board dimensions (unit: mm)

1.3 Technical Specifications

Three-phase five-wire 380 VAC (± 15%), 50/60 Hz

Single-phase 380 VAC (-15 % to +10%)

Inverter output over-

Protection Bus overvoltage pro-

Forced activation Available

Rescue ARD maintenance

ARD test mode Available

Place of service Indoor use (no corrosive gases or dust)

The altitude of the actual usage is below 1000 m. If it

Environ- 0° C to +50° C (Derate the current by 1.5% for each

ment Operating temperature 1° C higher if the ambient temperature is above

Storage temperature -20℃ to +60℃

Humidity < 95％ RH, non-condensing

Vibration Below 5.9 m/s2 (0.6 g)

0&7&$5'&6HULHV1HZ(OHYDWRU

◆◆ CNM2: Connector of rubber housing - Plug - 2.5 mm - One row -
