PARTS CATALOG
0CG10-M32503EN
FOR SPARE PARTS & AFTER SALES SERVICE

PLEASE CONTACT:
PT. PIONEER
JL. IR. H. JUANDA NO. 40-42, JAKARTA 10120
TEL. +62 (21) 344 8486 ; 231 2312
FAX. +62 (21) 384 8995
EMAIL: support@pioneer-trading.com
Last update Apr., 2014

Introduction
1.This parts catalog for 6AY-ET/GT,6AYM-ETE/GTE/STE is published as a revised
edition of the Diesel engine.
Parts catalog No. Date of issue Remarks

First edition 000Y00G3250 June,2004 No need
1st edition(supplement) 000Y00G3251 July,2007 No need
2nd edition(supplement) 000Y00G3252 May,2008 No need
3rd revised edition 0CG10-G32503 Mar.,2011
2.Standard finish color. Yanmar ecole silver(Metallic)

Parts No. 977620-10070 1L(Packed in a can)
Parts No. 977620-40070 4L(Packed in a can)
Parts No. TOR-94800250 Spray(1 piece)
3.This parts catalog does not contain the technical data needed for maintenance
service.
4.The illustrations used in this parts catalog have been simplified for clarity.
5.The contents of this parts catalog are subject to change without notice.
6.Be sure to use only Yanmar genuine part for repairs.If imitation parts are used,
it may cause engine defects.
Contents
Fig. No. Fig. Name Fig. No. Fig. Name
6AY-ET/GT,6AYM-ETE/GTE/STE 23. BONNET
1. CYLINDER BLOCK 24. SUC.MANIFOLD
2. CYLINDER LINER & HEAD GASKET 133. (24A)AIR PIPE
3. CAMSHAFT COVER 25. EXHAUST MANIFOLD
4. GEAR HOUSING 26. CAMSHAFT
5. OIL SEAL CASE(S.F.W.) 27. IDLE GEAR
6. OIL SEAL CASE(O.F.W.) 28. WORKING VALVE DEVICE
7. FLYWHEEL HOUSING 29. TURBOCHARGER
8. LUB.OIL SUMP(STANDARD) 30. TURB.COMPONENT PART
9. LUB.OIL SUMP(SHALLOW TYPE) 31. EXHAUST BEND
131. (9A)LUB.OIL SUMP(ELASTIC MOUNTING:STANDAR) 32. BELLOWS
132. (9B)LUB.OIL SUMP(ELASTIC MOUNTING:SHALLOW TYPE) 33. SILENCER
10. COVER(O.F.W.) 34. AIR DUCT & AIR HEATER
11. ENGINE MOUNT 35. AIR COOLER
12. LUB.OIL FEEDER 36. CRANKSHAFT & FLYWHEEL
13. CAMSHAFT METAL 37. PISTON & CONNECTING ROD
14. BREATHER PIPE 38. DAMPER & V-PULLEY
15. BREATHER PIPE(ABS SPEC.) 39. CG-COUPLING
16. MIST FLEXIBLE PIPE(JG SPEC.) 40. LUB.OIL PUMP
17. LABEL 41. LUB.OIL COOLER
18. SAFETY LABEL 42. L.O.PRESS.CONTROL VALVE
19. ENGINE LIFTER 43. DIPSTICK
20. CYLINDER HEAD 44. LUB.OIL STRINER(EARTH TYPE)
21. CYLINDER HEAD(OPTIONAL) 45. LUB.OIL STRINER(EARTH FLOAT TYPE)
22. LOCKER ARM 46. LUB.OIL BY-PASS STRAINER

Contents
47. LUB.OIL WASTE PUMP 72. C.S.W.PIPE(CLUTCH IN/OUT)
48. LUB.OIL PIPE(LUB.OIL COOLER) 73. C.F.W.BEND(HEAD-EXH.MANIFOLD)
49. LUB.OIL PIPE(TURBOCHARGER) 74. SUPPORT(SEA WATER PIPE)
50. LUB.OIL PIPE(RETURN) 75. COVER(CYLINDER BLOCK)
51. LUB.OIL PIPE(BY-PASS) 76. FUEL INJECTION PUMP
52. LUB.OIL PIPE(F.I.PUMP) 77. FUEL FEED PUMP
53. LUB.OIL WING PUMP 78. COUPLING
54. LUB.OIL WING PIPE 79. GOVERNOR
55. COOLING FRESH WATER PUMP 80. BOOST COMPENSATER
56. COOLING SEA WATER PUMP 81. FUEL INJECTION VALVE
57. COOLING FRESH WATER PUMP(LOW TEMP.WATER) 82. F.I.PUMP DRIVING DEVICE
58. FRESH WATER COOLER 83. FUEL PUMP BRACKET
59. COOLING FRESH WATER THERMOSTAT 84. FUEL STRAINER(SINGLE)
60. BILGE PUMP(OPTIONAL) 85. FUEL STRAINER(DUPLEX)
61. KINGSTON VALVE 86. OIL/WATER SEPARATOR
62. SEA WATER STRAINER(SINGLE) 87. FUEL PIPE(PUMP IN)
63. SEA WATER STRAINER(DUPLEX) 88. FUEL PIPE(INLET/OUTLET HOSE)
64. C.F.W.PIPE(THERMOSTAT-PUMP) 89. FUEL PIPE(PUMP-STRAINER)(SINGLE)
65. C.F.W.PIPE(THERMOSTAT-PUMP) 90. FUEL PIPE(PUMP-STRAINER)(DUPLEX)
66. C.F.W.PIPE(L.O.COOLER-BLOCK) 91. FUEL INJECTION PIPE
67. C.S.W.PIPE(C.S.W.PUMP-AIR COOLER-F.W.COOLER) 92. SUPPORT(F.I.PIPE)
68. C.S.W.PIPE(L.C.W.PUMP-AIR COOLER-ENGINE OUT) 93. FUEL OVERFLOW PIPE(F.I.VALVE)
69. C.S.W.PIPE(CLUTCH IN/OUT) 94. FUEL PIPE(PUMP RETURN)
70. C.S.W.PIPE(CLUTCH IN/OUT) 95. FUEL OVERFLOW PIPE(F.I.PUMP)
71. C.S.W.PIPE(CLUTCH IN/OUT) 96. FUEL OVERFLOW PIPE(F.I.PUMP)

Contents
97. FUEL OVERFLOW PIPE(DOUBLE INJECTION PIPE) 120. ELECTORIC TROLLING CONTROL BOX
98. FUEL OVERFLOW TANK 121. CLUTCH ATTACHED BOLT
99. FUEL OVERFLOW ALARM 122. INSTRUMENT PANEL
100. SPEED RELAY 123. SUB-PANEL
101. MAGNETICK PICK-UP 124. INSTRUMENT PANEL(ENGINE ATTACHED)
102. ENGINE STOP DEVICE(MOTOR SOLENOID)(JCI:WOODEN & FRP) 125. INSTRUMENT PANEL BRACKET
103. ENGINE STOP DEVICE(MOTOR SOLENOID)(JCI:STEEL & ALUMINUM) 126. PRESSUER GAUGE PIPE
104. ENGINE STOP DEVICE(ELECTRIC MAGNET)(JG) 136. (126A)PRESSUER GAUGE PIPE(CLUTCH LUB.OIL)
105. WIRE REMOTE CONTROL RECEIVER(GOVERNOR) 127. THERMOMETER
106. WIRE REMOTE CONTROL RECEIVER(CLUTCH) 128. NOZZLE TESTTER
107. REMOTE CONTROL HEAD 129. TOOL
108. AIR MOTOR 137. (129A)TOOL(OPTIONAL)
109. STARTING MOTOR(EARTH TYPE)(UP TO E0141) 130. SPECIAL TOOL(OPTIONAL)
134. (109A)STARTING MOTOR(EARTH TYPE)(FROM E0142)
110. STARTING MOTOR(ERATH FLOAT TYPE)(UP TO E0141)
135. (110A)STARTING MOTOR(EARTH FLOAT TYPE)(FROM E0142)
111. GENERATOR
112. GENERATOR COMPONENT PART(1KW)
113. GENERATOR COMPONENT PART(600W)
114. WIRE HARNESS
115. SUB-HARNESS & NEUTRAL SWITCH
116. SENSOR(EARTH TYPE)
117. SENSOR(EARTH FLOAT TYPE)
118. BATTERY SWITCH
119. AIR HEATER DEPENDENCE

0CG10-M32503
(A)=6AY-ET (D)=6AY-GT
Fig.1. CYLINDER BLOCK (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
No. Lev. Parts No. Description Q'ty I R
(A) (B) (C) (D) (E) (F)
1 1 748620-01701 BLOCK ASSY, CYLINDER 1 1 1
1-1 1 748620-01702 BLOCK ASSY, CYLINDER 1 1 1 S
(A=E00128) (B=E00128) (D=E00128)
1-2 1 748620-01703 BLOCK ASSY, CYLINDER 1 1 1 1 S
(A=*2006.04) (B=*2006.04) (D=*2006.04)
1-3 1 748620-01704 BLOCK ASSY, CYLINDER 1 1 1 1 1 S
(A=E00663) (B=E00663) (C=E00663) (D=E00663)
1-4 1 748620-01705 BLOCK ASSY, CYLINDER 1 1 1 1 1 S
(A=*2008.08) (B=*2008.08) (C=*2008.08) (D=*2008.08) (E=*2008.08)
1-5 1 748620-01706 BLOCK ASSY, CYLINDER 1 1 1 1 1 S 5
(A=*2012.10) (B=*2012.10) (C=*2012.10) (D=E04001) (E=*2012.10)
5 2 148620-02070 BOLT 14 14 14 14 14
6 2 148620-02250 BOLT 14 14 14 14 14
7 2 148620-02120 METAL ASSY, MAIN 7 7 7 7 7
10 2 748620-02590 METAL ASSY, THRUST 2 2 2 2 2
12 2 22312-060100 PIN, PARALLEL M6X10 2 2 2 2 2
13 2 27241-350000 PLUG, 35 1 1 1 1 1
14 2 27241-500000 PLUG, 50 1 1 1 1 1
15 2 23876-040000 PLUG, R04 7 7 7 7 7
16 2 23876-010000 PLUG, R01 4 4 4 4 4
17 2 22312-080100 PIN, PARALLEL M8X10 12 12 12 12 12
18 2 148620-01090 PLUG, M36X2 1 1 1 1 1
18-1 2 148620-01091 PLUG, M36X2 1 1 1 1 1 R
(A=*2010.11) (B=*2010.11) (C=*2010.11) (D=*2010.11) (E=*2010.11)
19 2 23414-360000 GASKET, 36X1.0 1 1 1 1 1
20 2 22312-120280 PIN, PARALLEL M12X28 4 4 4
20-1 2 22312-120320 PIN, PARALLEL M12X32 4 4 4 4 4 N
(A=*2006.02) (B=*2006.02) (D=*2006.02)
21 2 26216-100302 STUD, M10X 30 2 2 2 2 2
21A 2 23887-200002 PLUG, 20 1 1 1 1 1 W
(A=E00663) (B=E00663) (C=E00663) (D=E00663)
21B 2 23414-200000 GASKET, 20X1.0 1 1 1 1 1 W
(A=E00663) (B=E00663) (C=E00663) (D=E00663)
21C 2 148616-02400 BEARING, CAMSHAFT 2 2 2 2 2 W
(A=FROM 1ST) (B=FROM 1ST) (C=FROM 1ST) (D=FROM 1ST) (E=FROM 1ST)
21D 2 148616-02420 BEARING, CAMSHAFT 5 5 5 5 5 W
21E 2 22312-060080 PIN, PARALLEL M6X 8 6 6 6 6 6 W
(A=*2012.10) (B=*2012.10) (C=*2012.10) (D=E04001) (E=*2012.10)
22 1 148620-01451 COVER 1 1 1
22-1 1 148620-01452 COVER 1 1 1 1 1 S
(A=E00128) (B=E00128) (D=E00128)
23 1 148620-01460 GASKET 1 1 1 1 1
24 1 26106-100252 BOLT, M10X 25 PLATED 8 8 8 8 8
Remarks 25 1 148620-01390 COVER 6 6 6 6 6
(1)Under sized(U.S.=0.25)part 27 2 148620-01400 GASKET 6 6 6 6 6
(2)Under sized(U.S.=0.5)part
(3)Over sized(O.S.=0.25)part 28 1 26106-100222 BOLT, M10X 22 PLATED 24 24 24 24 24
(4)Over sized(O.S.=0.5)part 28-1 1 26106-100252 BOLT, M10X 25 PLATED 24 24 24 24 24 S
(5)Interchangeable by simultaneous replacement of the following combinations. (A=*2008.08) (B=*2008.08) (C=*2008.08) (D=*2008.08) (E=*2008.08)
For 6AY-ET, ETE, STE: Fig.1 No.1-5 & Fig.20 No.1-3, 34-1, 35-1. 29 1 26216-121202 STUD, M12X120 8 8 8 8 8
For 6AY-GT, GTE: Fig.1 No.1-5 & Fig.20 No.1A-4, 34-1, 35-1.
30 1 26716-120002 NUT, M12 8 8 8 8 8
For optional cylinderhead: Fig.1 No.1-5 & Fig.21 No.1-1, 33-1, 34-1.
++ CONTINUE ++ Copyright (C) YANMAR CO., LTD. All RightsReserved.

0CG10-M32503
Fig.1. CYLINDER BLOCK (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
31 1 22217-120000 WASHER, SPRING 12 8 8 8 8 8
32 1 26232-161602 STUD, M16X160 3 3 3 3 3
33 1 26232-160402 STUD, M16X 40 2 2 2 2 2
34 1 26732-160002 NUT, M16 5 5 5 5 5
35 1 128633-66020 WASHER, 16 5 5 5 5 5
35-1 1 148688-54550 WASHER 5 5 5 5 5 N
(A=*2008.11) (B=*2008.11) (C=*2008.11) (D=*2008.11) (E=*2008.11)
36 1 23887-120002 PLUG, 12 1 1 1 1 1
37 1 23414-120000 GASKET, 12X1.0 1 1 1 1 1
38 1 23887-180002 PLUG, 18 2 2 2 2 2
39 1 23414-180000 GASKET, 18X1.0 2 2 2 2 2
40 1 23887-160002 PLUG, 16 1 1 1 1 Z
(A=E00663) (B=E00663) (C=E00663) (D=E00663)
41 1 23414-160000 GASKET, 16X1.0 1 1 1 1 Z
(A=E00663) (B=E00663) (C=E00663) (D=E00663)
42 1 23414-120000 GASKET, 12X1.0 1 1 1 1 1 W
(A=E00128) (B=E00128) (D=E00128)
43 1 23887-120002 PLUG, 12 1 1 1 1 1 W
(A=E00128) (B=E00128) (D=E00128)
44 1 23414-130000 GASKET, 13X1.0 1 1 1 1 1 W
(A=E00128) (B=E00128) (D=E00128)
45 1 23897-020002 PLUG G1/4 1 1 1 1 1 W
(A=E00128) (B=E00128) (D=E00128)
46 1 23414-170000 GASKET, 17X1.0 1 1 1 1 1 W
(A=E00128) (B=E00128) (D=E00128)
47 1 23897-030002 PLUG G3/8,HEX. 1 1 1 1 1 W
(A=E00128) (B=E00128) (D=E00128)
48 1 23857-100000 BOLT, JOINT 10 6 6 6 6 6
49 1 133670-39340 BRACKET 6 6 6 6 6
50 1 148620-39300 NOZZLE ASSY, COOLING 6 6 6 6 6
52 2 26911-050052 SCREW, M5X 5 6 6 6 6 6
53 1 22312-060120 PIN, PARALLEL M6X12 6 6 6 6 6
54 1 748620-02770 METAL ASSY, MAIN .25 7 7 7 7 7 1
57 1 748620-02780 METAL ASSY, MAIN .50 7 7 7 7 7 2
60 1 748620-02950 METAL ASSY, 0.25 OS 2 2 2 2 2 3
62 1 748620-02940 METAL ASSY, 0.50 OS 2 2 2 2 2 4
Remarks
(3)Over sized(O.S.=0.25)part
(4)Over sized(O.S.=0.5)part
(5)Interchangeable by simultaneous replacement of the following combinations.
For 6AY-ET, ETE, STE: Fig.1 No.1-5 & Fig.20 No.1-3, 34-1, 35-1.
For 6AY-GT, GTE: Fig.1 No.1-5 & Fig.20 No.1A-4, 34-1, 35-1.
For optional cylinderhead: Fig.1 No.1-5 & Fig.21 No.1-1, 33-1, 34-1.
Copyright (C) YANMAR CO., LTD. All RightsReserved.

0CG10-M32503
Fig.2. CYLINDER LINER & HEAD GASKET (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748620-01900 LINER ASSY, CYLINDER 6 6 6 6 6
3 2 148620-01280 O-RING 6 6 6 6 6
4 2 148620-01290 PACKING, LINER 6 6 6 6 6
5 2 148620-01300 GASKET, LINER 12 12 12 12 12
6 1 148620-01241 GASKET, HEAD 1.5 6 6 6
6-1 1 148620-01242 GASKET, HEAD 1.5 6 6 6 6 6 N
(A=*2006.03) (B=*2006.03) (D=*2006.03)
6-2 1 148620-01243 GASKET, HEAD 1.5 6 6 6 6 6 N
(A=*2008.01) (B=*2008.01) (C=*2008.01) (D=*2008.01) (E=*2008.01)
7 1 24316-570480 O-RING, 4DP48A 12 12 12 12 12

0CG10-M32503
Fig.3. CAMSHAFT COVER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-01470 COVER 2 2 2 2 2
2 1 148620-01480 GASKET, COVER 2 2 2
2-1 1 148628-01411 GASKET, COVER 2 2 2 2 2 N
(A=*2006.09) (B=*2006.09) (D=*2006.09)
3 1 26106-100222 BOLT, M10X 22 PLATED 24 24 24 24 24
3-1 1 26106-100252 BOLT, M10X 25 PLATED 24 24 24 24 24 S
(A=EZZZZZ) (B=EZZZZZ) (C=EZZZZZ) (D=EZZZZZ) (E=EZZZZZ)

0CG10-M32503
Fig.4. GEAR HOUSING (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-01500 CASE, GEAR 1 1 1
1-1 1 148620-01501 CASE, GEAR 1 1 1 1 1 S
(A=E0128) (B=E0128) (D=E0128)
2 1 148620-01520 GASKET 1 1 1 1 1
3 1 126684-01440 COVER 1 1 1 1 1
4 1 148616-01451 GASKET 1 1 1
4-1 1 148620-01440 PACKING 1 1 1 1 1 N
(A=*2004.06) (B=*2004.06) (D=*2004.06)
5 1 26206-100182 BOLT, M10X 18 PLATED 2 2 2 2 2
5-1 1 26106-100202 BOLT, M10X 20 PLATED 2 2 2 2 2 N
(A=EXXX) (B=EXXX) (C=EXXX) (D=EXXX) (E=EXXX)
6 1 22312-120320 PIN, PARALLEL M12X32 2 2 2 2 2
7 1 26116-120302 BOLT, M12X 30 PLATED 12 12 12 12 12
8 1 22217-120000 WASHER, SPRING 12 12 12 12 12 12
9 1 148688-01561 PACKING 1 1 1
9-1 1 148620-01560 GASKET 1 1 1 1 1 N
(A=*2004.06) (B=*2004.06) (D=*2004.06)
10 1 148620-01760 COVER 1 1 1 W
(A=E0128) (B=E0128) (D=E0128)
10-1 1 148620-01761 COVER 1 1 1 1 1 N
(A=*2004.06) (B=*2004.06) (D=*2004.06)
11 1 135410-35320 GASKET 1 1 1 W
(A=E0128) (B=E0128) (D=E0128)
11-1 1 148628-35321 PACKING 1 1 1 1 1 N
(A=*2004.06) (B=*2004.06) (D=*2004.06)
12 1 26106-100182 BOLT, M10X 18 PLATED 4 4 4 4 4 W
(A=E0128) (B=E0128) (D=E0128)
12-1 1 26106-100202 BOLT, M10X 20 PLATED 4 4 4 4 4 N
13 1 148688-01550 COVER 1 1 1 1 1 1
Remarks
(1)Engine attached insturument panel
spec.
0CG10-M32503
Fig.5. OIL SEAL CASE(S.F.W.) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-01810 CASE, OIL SEAL 1 1 1 1 1
1-1 1 148620-01811 CASE, OIL SEAL 1 1 1 1 1 N
2 1 148620-01830 GASKET 1 1 1
2-1 1 148620-01831 GASKET 1 1 1 1 1 N
(A=*2006.09) (B=*2006.09) (D=*2006.09)
3 1 148620-01880 SEAL, OIL 1 1 1 1 1
4 1 26106-080252 BOLT, M8X 25 PLATED 10 10 10
4-1 1 26106-080202 BOLT, M8X 20 PLATED 10 10 10 10 10 N
(A=*2006.02) (B=*2006.02) (D=*2006.02)
5 1 22190-080003 WASHER, SEAL 8 10 10 10 10 10

0CG10-M32503
Fig.6. OIL SEAL CASE(O.F.W.) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-01810 CASE, OIL SEAL 1 1 1 1 1
1-1 1 148620-01811 CASE, OIL SEAL 1 1 1 1 1 N
2 1 148620-01830 GASKET 1 1 1
2-1 1 148620-01831 GASKET 1 1 1 1 1 N
(A=*2006.09) (B=*2006.09) (D=*2006.09)
3 1 148620-01890 SEAL, OIL 1 1 1 1 1
4 1 26106-080252 BOLT, M8X 25 PLATED 10 10 10
4-1 1 26106-080202 BOLT, M8X 20 PLATED 10 10 10 10 10 N
(A=*2006.02) (B=*2006.02) (D=*2006.02)
5 1 22190-080003 WASHER, SEAL 8 10 10 10 10 10

0CG10-M32503
Fig.7. FLYWHEEL HOUSING (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-01600 HOUSING, FLYWHEEL 1 1 1
1-1 1 148660-01601 HOUSING, FLYWHEEL 1 1 1 1 S
(A=E0128) (B=E0128) (D=E0128)
1-2 1 148660-01602 HOUSING, FLYWHEEL 1 1 1 1 1 N
(A=E0663) (B=E0663) (C=E0663) (D=E0663)
1-3 1 148660-01603 HOUSING, FLYWHEEL 1 1 1 1 1 S 1
(A=*2008.10) (B=*2008.10) (C=*2008.10) (D=*2008.10) (E=*2008.10)
1-4 1 148660-01604 HOUSING, FLYWHEEL 1 1 1 1 1 R
2 1 148620-01621 GASKET 1 1 1
2-1 1 148620-01630 GASKET 1 1 1 1 1 S
(A=E0128) (B=E0128) (D=E0128)
5 1 148620-01870 COVER 1 1 1
5-1 1 148816-01820 COVER 1 1 1 1 1 N
(A=*2004.06) (B=*2004.06) (D=*2004.06)
6 1 148616-01811 GASKET, MOUNT 1 1 1
6-1 1 148660-01810 GASKET 1 1 1 1 1 N
(A=*2004.06) (B=*2004.06) (D=*2004.06)
7 1 26106-100202 BOLT, M10X 20 PLATED 3 3 3 3 3
8 1 26106-100402 BOLT, M10X 40 PLATED 21 21 21 21 21
9 1 26106-100752 BOLT, M10X 75 PLATED 4 4 4 4 4
10 1 148616-01611 COVER 1 1 1 1 1
11 1 26106-080122 BOLT, M8X 12 PLATED 2 2 2 2 2
12 1 26116-121602 BOLT, M12X160 PLATED 1 1 1 1 1
13 1 133970-01670 PLUG 5/8 UNF,HEX. 1 1 1 1 1
14 1 23414-160000 GASKET, 16X1.0 1 1 1 1 1
15 1 148620-01800 BRACKET 1 1 1 1 1
16 1 148690-01900 SUPPORT 1 1 1 1 1 W
(A=E0663) (B=E0663) (C=E0663) (D=E0663)
17 1 148690-01910 SUPPORT 1 1 1 1 1 W
(A=E0663) (B=E0663) (C=E0663) (D=E0663)
18 1 126618-11820 WASHER 4 4 4 4 4 W
(A=E0663) (B=E0663) (C=E0663) (D=E0663)
19 1 22137-160000 WASHER, 16 4 4 4 4 4 W
(A=E0663) (B=E0663) (C=E0663) (D=E0663)
20 1 26152-160252 BOLT, M16X 25 6 6 6 6 6 W
(A=E0663) (B=E0663) (C=E0663) (D=E0663)
21 1 26152-160402 BOLT M16X 40 4 4 4 4 4 W
(A=E0663) (B=E0663) (C=E0663) (D=E0663)
Remarks
(1)Interchangeable by simultaneous
replacement with Fig.56 No.25-1.
0CG10-M32503
Fig.8. LUB.OIL SUMP(STANDARD) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748660-01540 SUMP ASSY, OIL 1 1 1 1 1
3 3 135410-01780 PLUG, M30 BC 1 1 1 1 1
4 3 23414-300000 GASKET, 30X1.0 1 1 1 1 1
6A 2 23887-140002 PLUG M14 1 1 1 1 1 W
(A=FROM 1ST) (B=FROM 1ST) (D=FROM 1ST)
6B 2 23414-140000 GASKET, 14X1.0 1 1 1 1 1 W
7 1 22137-100000 WASHER, 10 2 2 2 Z
(A=EXXX) (B=EXXX) (D=EXXX)
8 1 148620-01770 GASKET, OIL SUMP 1 1 1 1 1
8-1 1 148620-01771 GASKET, OIL SUMP 1 1 1 1 1 N
(A=*2008.08) (B=*2008.08) (C=*2008.08) (D=*2008.08) (E=*2008.08)
11 1 26106-100302 BOLT, M10X 30 PLATED 34 34 34 34 34
12 1 26116-101802 BOLT, M10X180 PLATED 2 2 2 2 2

0CG10-M32503
Fig.9. LUB.OIL SUMP(SHALLOW TYPE) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748690-01700 SUMP ASSY, OIL 1 1 1 1 1
3 2 135410-01780 PLUG, M30 BC 2 2 2 2 2
4 2 148620-01770 GASKET, OIL SUMP 1 1 1 1 1
4-1 2 148620-01771 GASKET, OIL SUMP 1 1 1 1 1 N
(A=*2008.08) (B=*2008.08) (C=*2008.08) (D=*2008.08) (E=*2008.08)
7 2 23221-340001 FLANGE, 34 1 1 1 1 1
8 2 23414-140000 GASKET, 14X1.0 1 1 1 1 1
9 2 23414-300000 GASKET, 30X1.0 2 2 2 2 2
10 2 23428-360000 GASKET, 36X1.5 1 1 1 1 1
11 2 23887-140002 PLUG M14 1 1 1 1 1
12 2 26106-100302 BOLT, M10X 30 PLATED 34 34 34 34 34
13 2 26106-100302 BOLT, M10X 30 PLATED 2 2 2 2 2
14 2 26116-101802 BOLT, M10X180 PLATED 2 2 2 2 2
15 2 26116-120302 BOLT, M12X 30 PLATED 2 2 2 2 2
16 2 43320-001250 FLANGE, BLIND 1 1 1 1 1
17 2 148628-01641 GASKET 1 1 1 1 1

0CG10-M32503
Fig.131. (9A)LUB.OIL SUMP(ELASTIC MOUNTING:STANDAR) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748660-01550 SUMP ASSY, OIL 1 1 1 1 1
3 3 135410-01780 PLUG, M30 BC 1 1 1 1 1
5 3 23414-300000 GASKET, 30X1.0 1 1 1 1 1
6 2 23414-140000 GASKET, 14X1.0 1 1 1 1 1
7 2 23887-140002 PLUG, 14 1 1 1 1 1
8 1 148620-01771 GASKET, OIL SUMP 1 1 1 1 1
12 1 26106-100302 BOLT, M10X 30 PLATED 34 34 34 34 34
13 1 26116-101802 BOLT, M10X180 PLATED 2 2 2 2 2

0CG10-M32503
Fig.132. (9B)LUB.OIL SUMP(ELASTIC MOUNTING:SHALLOW TYPE) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748690-01550 SUMP ASSY, OIL 1 1 1 1 1
3 3 135410-01780 PLUG, M30 BC 2 2 2 2 2
5 3 23414-300000 GASKET, 30X1.0 2 2 2 2 2
6 2 23414-140000 GASKET, 14X1.0 1 1 1 1 1
7 2 23887-140002 PLUG, 14 1 1 1 1 1
8 1 148628-01641 GASKET 1 1 1 1 1
9 1 148620-01771 GASKET, OIL SUMP 1 1 1 1 1
13 1 23221-340001 FLANGE, 34 1 1 1 1 1
14 1 23428-360000 GASKET, 36X1.5 1 1 1 1 1
15 1 26106-100302 BOLT, M10X 30 PLATED 34 34 34 34 34
16 1 26106-100302 BOLT, M10X 30 PLATED 2 2 2 2 2
17 1 26116-101802 BOLT, M10X180 PLATED 2 2 2 2 2
18 1 26116-120302 BOLT, M12X 30 PLATED 2 2 2 2 2
19 1 43320-001250 FLANGE 1 1 1 1 1

0CG10-M32503
Fig.10. COVER(O.F.W.) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-01880 COVER 1 1 1 1 1
2 1 148620-01860 GASKET 1 1 1 1 1
3 1 26106-100302 BOLT, M10X 30 PLATED 12 12 12
3-1 1 26106-100302 BOLT, M10X 30 PLATED 8 8 8 8 8 K
(A=*2006.02) (B=*2006.02) (D=*2006.02)
4 1 26366-100002 NUT, M10 2 2 2 2 2
5 1 23876-040000 PLUG, R04 1 1 1 1 1
6 1 26106-100352 BOLT, M10X 35 PLATED 4 4 4 4 4 W
(A=*2006.02) (B=*2006.02) (D=*2006.02)

0CG10-M32503
Fig.11. ENGINE MOUNT (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-01640 FOOT, MOUNTING 2 2 2 2 2
2 1 26156-160452 BOLT, M16X 45 PLATED 8 8 8 8 8
3 1 22312-120200 PIN, PARALLEL M12X20 4 4 4 4 4
4 1 148620-01650 FOOT, MOUNTING 2 2 2 2
4-1 1 148620-01651 FOOT, MOUNTING 2 2 2 2 2 N
(A=E0663) (B=E0663) (C=E0663) (D=E0663)
5 1 22312-120200 PIN, PARALLEL M12X20 4 4 4 4 4
6 1 26156-160802 BOLT, M16X 80 PLATED 8 8 8 8 8
7 1 744626-92400 BOLT ASSY, M20X350 12 12 12 12 12
8 2 144626-92900 BOLT, M20X350 12 12 12 12 12
9 2 26716-200002 NUT, M20 24 24 24 24 24
10 1 22137-200000 WASHER, 20 12 12 12 12 12
11 1 22157-200000 WASHER, 20 12 12 12 12 12
12 1 26756-200002 NUT, LOCK M20 24 24 24 24 24
13 1 148660-08100 PLATE, BED 2 2 2 2
13A 1 148692-08100 PLATE, BED 2
13B 1 148692-08110 PLATE, BED 2
13C 1 41608-033480 BED 2 2
13D 1 42212-026280 PLATE, BED 2 W
(B=EZZZZZ)
13E 1 42212-026290 PLATE, CLUTCH BED 2 W
(B=EZZZZZ)
14 1 148816-08200 SHIM SET 12 12 12 12 12
19 1 42212-550800 LINER, FOOT 2 2 2 2 2
20 1 42212-551190 LINER, FOOT 2 2 2 2 2
21 1 45521-552460 BOLT 12 12 12 12 12 1
22 1 22137-200000 WASHER, 20 24 24 24 24 24 1
23 1 26716-200002 NUT, M20 24 24 24 24 24 1
24 1 22312-120280 PIN, PARALLEL M12X28 4 4
25 1 26111-200452 BOLT, M20X 45 12 12
26 1 41608-553170 FOOT, MOUNTING 2 2
27 1 42212-500370 LINER, FOOT T=35 2 W
(C=FROM 1ST)
27A 1 42212-551190 LINER, FOOT 2 2 2 2 W 1
27B 1 42212-026000 LINER, FOOT 2 2 2 2 W 2
(A=*2008.06) (B=*2008.06) (D=*2008.06)
27C 1 42212-501360 LINER, FOOT 2 2 W 1
(A=*2008.06) (D=*2008.06)
27D 1 42212-026180 LINER, FOOT 2 2 W 2
(A=*2008.06) (D=*2008.06)
28 1 45522-550050 BOLT BOLT 4 4 4 4 W
(A=YSEAY07-400) (B=YSEAY07-400) (C=YSEAY07-400) (D=YSEAY07-400) (E=YSEAY07-400)
29 1 22137-200000 WASHER, 20 8 8 8 8 8 W 2
(A=*2007.11) (B=*2007.11) (C=*2007.11) (D=*2007.11) (E=*2007.11)
30 1 26716-200002 NUT, M20 8 8 8 8 8 W 2
(A=*2007.11) (B=*2007.11) (C=*2007.11) (D=*2007.11) (E=*2007.11)
31 1 26756-200002 NUT, LOCK M20 8 8 8 8 8 W 2
(A=*2007.11) (B=*2007.11) (C=*2007.11) (D=*2007.11) (E=*2007.11)
Remarks
(1)JCI
(2)jg
0CG10-M32503
Fig.12. LUB.OIL FEEDER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-01350 FILLER 1 1 1 1 1
2 1 148616-01641 PACKING, COVER 1 1 1
2-1 1 148628-01641 GASKET 1 1 1 1 1 N
(A=*2006.08) (B=*2006.08) (D=*2006.08)
3 1 26106-100452 BOLT, M10X 45 PLATED 2 2 2 2 2
3-1 1 26106-100502 BOLT, M10X 50 PLATED 2 2 2 2 2 N
4 1 24316-000320 O-RING, 4DP32.0 1 1 1 1 1
5 1 124160-01751 COVER, FILLER 1 1 1 1 1

0CG10-M32503
Fig.13. CAMSHAFT METAL (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148616-02400 BEARING, CAMSHAFT 2 2 2 2 2
2 1 148616-02420 BEARING, CAMSHAFT 5 5 5 5 5
3 1 148620-02481 METAL, CAMSHAFT 1 1 1 1 1
4 1 26013-120302 BOLT, M12X 30 2 2 2 2 2
5 1 22137-120000 WASHER, 12 2 2 2 2 2

0CG10-M32503
Fig.14. BREATHER PIPE (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 43730-552151 CLIP 51,HOSE 2 2 2 2 2
2 1 148620-03450 HOSE, RUBBER 1 1 1
2-1 1 148620-03451 HOSE, RUBBER 1 1 1 1 1 S
(A=E0128) (B=E0128) (D=E0128)
3 1 26106-100252 BOLT, M10X 25 PLATED 1 1 1
3-1 1 26106-100252 BOLT, M10X 25 PLATED 2 2 2 2 2 K
(A=E0128) (B=E0128) (D=E0128)
4 1 148620-03420 BEND, BREATHER 1 1 1
4-1 1 148620-03421 BEND, BREATHER 1 1 1 1 1 S
(A=E0128) (B=E0128) (D=E0128)
5 1 148616-01451 GASKET 1 1 1
5-1 1 148620-01440 PACKING 1 1 1 1 1 N
(A=*2004.06) (B=*2004.06) (D=*2004.06)
6 1 26106-100552 BOLT, M10X 55 PLATED 1 1 1 Z
(A=E0128) (B=E0128) (D=E0128)
7 1 148620-03400 SEPARATOR 1 1 1 1 1
7-1 1 148620-03401 SEPARATOR 1 1 1 1 1 R
(A=*2009.01) (B=*2009.01) (C=*2009.01) (D=*2009.01) (E=*2009.01)
8 1 148620-03410 BRACKET 1 1 1
8-1 1 148620-03460 BRACKET 1 1 1 1 1 S
(A=E0128) (B=E0128) (D=E0128)
9 1 124298-01760 JOINT 1 1 1 1 1
10 1 23414-120000 GASKET, 12X1.0 1 1 1 1 1
11 1 26106-080182 BOLT, M8X 18 PLATED 4 4 4 4 4
11-1 1 26106-080202 BOLT, M8X 20 PLATED 4 4 4 4 4 S
12 1 26106-080162 BOLT, M8X 16 PLATED 3 3 3
12-1 1 26106-080162 BOLT, M8X 16 PLATED 4 4 4 4 4 K
(A=E0128) (B=E0128) (D=E0128)
13 1 22137-080000 WASHER, 8 3 3 3
13-1 1 22137-080000 WASHER, 8 4 4 4 4 4 K
(A=E0128) (B=E0128) (D=E0128)
14 1 148620-03431 PIPE ASSY, DRAIN 1 1 1
14-1 1 148620-03480 PIPE ASSY, DRAIN 1 1 1 1 1 N
(A=*2006.05) (B=*2006.05) (D=*2006.05)
17 1 128634-03150 HOSE, L=500 1 1 1
17-1 1 148620-03150 HOSE, RUBBER L=420 1 1 1 1 1 S
(A=*2006.05) (B=*2006.05) (D=*2006.05)
18 1 23414-160000 GASKET, 16X1.0 2 2 2
18-1 1 23414-160000 GASKET, 16X1.0 1 1 1 1 1 K
(A=*2006.05) (B=*2006.05) (D=*2006.05)
19 1 23857-100000 BOLT, JOINT 10 1 1 1
19-1 1 23831-100000 UNION, 10 1 1 1 1 1 S
(A=*2006.05) (B=*2006.05) (D=*2006.05)
20 1 23000-022000 CLAMP, 22 2 2 2 2 2
21 1 23297-100121 CLAMP, A10X12 1 1 1 1 1
22 1 148816-03160 PIPE, BREATHER 1 1 1 1 1
23 2 148816-03170 FLANGE 1 1 1 1 1
25 1 23414-160000 GASKET, 16X1.0 2 2 2 2 2
26 1 23421-510000 GASKET, 51X1.5 1 1 1 1 1
27 1 26113-160452 BOLT, M16X 45 2 2 2 2 2

0CG10-M32503
Fig.14. BREATHER PIPE (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
28 1 26713-160002 NUT, M16 2 2 2 2 2
29 1 126683-03150 HOSE, BREATHER 1 1 1 1 1
30 1 43730-552171 CLIP HOSE,71 2 2 2 2 2
31 1 148690-03480 PIPE ASSY, DRAIN 1 1 1 1 1

0CG10-M32503
Fig.15. BREATHER PIPE(ABS SPEC.) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-01440 PACKING 1 1 1
2 1 148616-01641 PACKING, COVER 2 2 2
3 1 148690-03320 BEND, BREATHER 1 1 1
4 1 148690-03330 PIPE, WATER DRAIN 1 1 1
5 1 26106-100252 BOLT, M10X 25 PLATED 2 2 2
6 1 26106-100302 BOLT, M10X 30 PLATED 2 2 2
7 1 26106-100402 BOLT, M10X 40 PLATED 2 2 2
7-1 1 26106-100352 BOLT, M10X 35 PLATED 2 2 2 S
(B=*2009.01) (C=*2009.01) (E=*2009.01)
8 1 26366-100002 NUT, M10 2 2 2 Z
(B=*2009.01) (C=*2009.01) (E=*2009.01)
9 1 148690-03300 SEPARATOR 1 1 1
9-1 1 148690-03301 SEPARATOR 1 1 1 S
(B=*2009.01) (C=*2009.01) (E=*2009.01)
12 1 148620-03460 BRACKET 1 1 1
13 1 148690-03472 UNION, M12-G3/8 1 1 1
14 1 22137-080000 WASHER, 8 4 4 4
15 1 23414-120000 GASKET, 12X1.0 1 1 1
16 1 26106-080162 BOLT, M8X 16 PLATED 4 4 4
17 1 26106-080182 BOLT, M8X 18 PLATED 4 4 4
17-1 1 26106-080202 BOLT, M8X 20 PLATED 4 4 4 S
(B=EZZZZZ) (C=EZZZZZ) (E=EZZZZZ)
18 1 148690-03431 PIPE ASSY, DRAIN 1 1 1
23 1 148690-03461 HOSE, RUBBER 1 1 1
24 1 23297-100121 CLAMP, A10X12 1 1 1
25 1 23414-160000 GASKET, 16X1.0 1 1 1
26 1 23831-100000 UNION, 10 1 1 1
27 1 148690-03500 PIPE ASSY, DRAIN 1 1 1

0CG10-M32503
Fig.16. MIST FLEXIBLE PIPE(JG SPEC.) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 23211-050061 FLANGE, 5K 50 1 1 1 1 1
2 1 23438-050000 GASKET, 5K50X1.5 1 1 1 1 1
3 1 26116-120402 BOLT, M12X 40 PLATED 4 4 4 4 4
4 1 26716-120002 NUT, M12 4 4 4 4 4
5 1 43560-550590 JOINT 1 1 1 1 1
6 1 43720-555060 PIPE, FLEXIBLE 1 1 1 1 1
6-1 1 43720-018700 JOINT, RUBBER 1 1 1 1 1 N
(A=*2008.02) (B=*2008.02) (C=*2008.02) (D=*2008.02) (E=*2008.02)
7 1 43730-552191 CLIP 85,HOSE 4 4 4 4 4

0CG10-M32503
Fig.17. LABEL (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
4 1 148620-07301 LABEL, TURNING GUIDE 1 1 1 1 1
5 1 22217-060000 WASHER, SPRING 6 2 2 2 2 2
6 1 26106-060122 BOLT, M6X 12 PLATED 2 2 2 2 2
7 1 42222-550301 LABEL 1 1 1 1 1
8 1 148616-07362 LABEL, DANGER 1 1 1 1 1
9 1 133670-07090 LABEL 1 1 1 1 Z
(A=EXXX) (B=EXXX) (C=EXXX) (D=EXXX)
10 1 148620-07150 LABEL, VALVE ADJUST 1 1
11 1 148620-07160 LABEL, VALVE ADJUST 1 1 1
12 1 22624-200030 RIVET, 2.0X 3 4 4 4 4 4
13 1 123682-07852 LABEL, CAUTION 3 3 3 3 3
14 1 126630-07361 LABEL, TANK CAUTION 1 1 1 1 1
15 1 129198-07350 LABEL 1 1 1 1 1
16 1 135665-07200 LABEL, CAUTION 1 1
17 1 135665-07210 LABEL, WATER PUMP 1 1 1
18 1 148619-28980 LABEL 1 1
19 1 148619-28990 LABEL 1 1 1
20 1 124220-09340 LABEL 8 8 8 8 8
22 1 42221-554790 LABEL 1 1 1 1 1
23 1 126630-07990 LABEL, CAUTION 1 1 1 1 1
24 1 148619-07931 LABEL 2 2 2 2 2
25 1 126618-07250 LABEL 1 1
25A 1 42222-551580 LABEL 1
26 1 126684-07250 LABEL, YANMAR 1 1
27 1 22624-200030 RIVET, 2.0X 3 8 8 8
28 1 137900-91451 RIVET 8 8
29 1 137900-91451 RIVET 4 4
30 1 127692-07250 LABEL 1 1
31 1 126687-07991 LABEL 2 2 2 2 2

0CG10-M32503
Fig.18. SAFETY LABEL (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 141616-07200 LABEL, BLOW 1 1 1 1 1
2 1 141616-07220 LABEL, CAUTION 2 2 2 2 2
3 1 141616-07210 LABEL, CAUTION 3 3 3 3 3
4 1 128296-07260 LABEL, DANGER 1 1 1 1 1

0CG10-M32503
Fig.19. ENGINE LIFTER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-07910 LIFTER 1 1 1 1 1
2 1 148660-07920 LIFTER 1 1 1 1 1
3 1 26156-160352 BOLT, M16X 35 PLATED 3 3 3 3 3
4 1 26156-160352 BOLT, M16X 35 PLATED 4 4 4 4 4
5 1 148690-07910 LIFTER 1 1 1 W
(B=*2007.11) (C=*2007.11) (E=*2007.11)

0CG10-M32503
Fig.20. CYLINDER HEAD (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1-1 1 748620-11500 HEAD ASSY, CYLINDER 6 6 6
1-2 1 748620-11050 HEAD ASSY, CYLINDER 6 6 6 R
(A=*2011.03) (B=*2011.03) (C=*2011.03)
1-3 1 748620-11051 HEAD ASSY, CYLINDER 6 6 6 S 3
(A=*2012.10) (B=*2012.10) (C=*2012.10)
1-4 1 748620-11052 HEAD ASSY, CYLINDER 6 6 6 S 5
(A=*2013.05) (B=*2013.05) (C=*2013.05)
1A 1 748660-11500 HEAD ASSY, CYLINDER 6
1A-2 1 748660-11501 HEAD ASSY, CYLINDER 6 6 S 1
(D=E00117)
1A-3 1 748660-11050 HEAD ASSY, CYLINDER 6 6 R
(D=*2011.03) (E=*2011.03)
(D=E04001) (E=*2012.10)
(D=*2013.05) (E=*2013.05)
4 3 23876-010000 PLUG, R01 6 6 6 6 6
5 3 23876-030000 PLUG, R03 18 18 18 18 18
6 3 23876-040000 PLUG, R04 12 12 12 12 12
7 3 27241-250000 PLUG, 25 6 6 6 6 6
8 3 27241-300000 PLUG 30 12 12 12 12 12
9 3 27241-400000 PLUG, 40 6 6 6 6 6
10 3 148620-11770 SLEEVE, NOZZLE 6 6 6 6 6
11 3 24326-000400 O-RING, 4DG40.0 12 12 12 12 12
12 3 146673-11870 PACKING 6 6 6 6 6
13 3 148620-11070 SEAT, VALVE 12 12 12 12 12
13-1 3 148660-11080 SEAT, SUCTION VALVE 12 12 12 12 12 S
(A=*2013.05) (B=*2013.05) (C=*2013.05) (D=*2013.05) (E=*2013.05)
14 3 148620-11092 SEAT, VALVE 12 12 12 12 12
15 3 148616-11970 COVER 6 6 6 6 6
16 3 148616-11981 GASKET 6 6 6 6 6
17 3 26106-100202 BOLT, M10X 20 PLATED 12 12 12 12 12
18 2 148616-11170 GUIDE, VALVE 24 24 24 24 24
19 2 148620-11530 GUIDE, BRIDGE 12 12 12 12 12
20 2 148620-11180 VALVE, SUCTION 12 12 12 12 12
20-1 2 148660-11100 VALVE, SUCTION 12 12 12 12 12 S
(A=*2013.05) (B=*2013.05) (C=*2013.05) (D=*2013.05) (E=*2013.05)
21 2 148620-11110 VALVE, EXHAUST 12 12 12 12 12
22 2 148628-11140 SEAL, VALVE STEM 24 24 24 24 24
22-1 2 148928-11160 SEAL, VALVE STEM 24 24 24 24 24 S
(A=*2013.05) (B=*2013.05) (C=*2013.05) (D=*2013.05) (E=*2013.05)
23 2 148620-11460 SPRING, VALVE 24 24 24 24 24
24 2 148620-11470 SPRING, VALVE 24 24 24 24 24
25 2 175149-11700 ROTATOR ASSY, VALVE 24 24 24 24 24
25-1 2 175149-11701 ROTATOR, VALVE 24 24 24 24 24 N
(A=*2009.09) (B=*2009.09) (C=*2009.09) (D=*2009.09) (E=*2009.09)
Remarks 26 2 148633-11190 COTTER 48 48 48 48 48
(1)Interchangeadle by simultaneous replacement with all cylinder.
27 2 148620-11911 STUD 6 6 6 6 6
(2)Level changed:from 2 to 1.
(3)Interchangeable by simultaneous replacement with No.1-3, 34-1, 35-1 & Fig.1 No.1-5. 28 2 22312-080100 PIN, PARALLEL M8X10 12 12 12 12 12 W
(4)Interchangeable by simultaneous replacement with No.1A-4, 34-1, 35-1 & Fig.1 No.1-5. (A=*2006.11) (B=*2006.11) (D=*2006.11)
(5)Interchangeable by simultaneous replacement with No.1-4, 13-1 & No.20-1. 29 1 148616-11930 GASKET, T=2.0 6 6 6 2
(6)Interchangeable by simultaneous replacement with No.1A-5, 13-1 & No.20-1.

0CG10-M32503
Fig.20. CYLINDER HEAD (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
29-1 1 126635-11840 GASKET, T=2.5 6 6 S
(A=*2009.01) (B=*2009.01)
30 1 126635-11840 GASKET, T=2.5 6 6 2
30-1 1 148610-11930 GASKET, T=3.0 6 6 S
(D=*2009.01) (E=*2009.01)
31 1 148620-11900 RETAINER, VALVE 6 6 6 6 6 2
31-1 1 148620-11901 RETAINER, VALVE 6 6 6 6 6 S
(A=*2009.01) (B=*2009.01) (C=*2009.01) (D=*2009.01) (E=*2009.01)
32 1 140623-53360 WASHER 6 6 6 6 6 2
33 1 26602-140002 NUT, M14 6 6 6 6 6 2
34 1 148620-11800 BOLT, HEAD 36 36 36 36 36 2
34-1 1 148620-11801 BOLT, HEAD 36 36 36 36 36 S
(A=*2012.10) (B=*2012.10) (C=*2012.10) (D=E04001) (E=*2012.10)
35 1 148620-11820 WASHER 36 36 36 36 36 2
35-1 1 148620-11821 WASHER 36 36 36 36 36 S
(A=*2012.10) (B=*2012.10) (C=*2012.10) (D=E04001) (E=*2012.10)
Remarks
(1)Interchangeadle by simultaneous replacement with all cylinder.
(3)Interchangeable by simultaneous replacement with No.1-3, 34-1, 35-1 & Fig.1 No.1-5.
(4)Interchangeable by simultaneous replacement with No.1A-4, 34-1, 35-1 & Fig.1 No.1-5.
(5)Interchangeable by simultaneous replacement with No.1-4, 13-1 & No.20-1.
(6)Interchangeable by simultaneous replacement with No.1A-5, 13-1 & No.20-1.

0CG10-M32503
Fig.21. CYLINDER HEAD(OPTIONAL) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748620-11550 HEAD ASSY, CYLINDER 6 6 6 6 6
1-1 1 748620-11590 HEAD ASSY, CYLINDER 6 6 6 6 6 S 1
(A=*2012.10) (B=*2012.10) (C=*2012.10) (D=E04001) (E=*2012.10)
1-2 1 748620-11551 HEAD ASSY, CYLINDER 6 6 6 6 6 S 3
(A=*2013.05) (B=*2013.05) (C=*2013.05) (D=*2013.05) (E=*2013.05)
4 3 23876-010000 PLUG, R01 6 6 6 6 6
5 3 23876-030000 PLUG, R03 18 18 18 18 18
6 3 27241-250000 PLUG, 25 6 6 6 6 6
7 3 27241-300000 PLUG 30 12 12 12 12 12
8 3 27241-400000 PLUG, 40 6 6 6 6 6
9 3 148620-11760 SLEEVE, NOZZLE 6 6 6 6 6
10 3 126618-11750 PROTECTOR, NOZZLE 6 6 6 6 6
11 3 148620-11840 INSULATOR 6 6 6 6 6
12 3 24326-000400 O-RING, 4DG40.0 12 12 12 12 12
13 3 146673-11870 PACKING 6 6 6 6 6
14 3 148620-11070 SEAT, VALVE 12 12 12 12 12
14-1 3 148660-11080 SEAT, SUCTION VALVE 12 12 12 12 12 S
(A=*2013.05) (B=*2013.05) (C=*2013.05) (D=*2013.05) (E=*2013.05)
15 3 148620-11092 SEAT, VALVE 12 12 12 12 12
16 3 148616-11970 COVER 6 6 6 6 6
17 3 148616-11981 GASKET 6 6 6 6 6
18 3 26106-100202 BOLT, M10X 20 PLATED 12 12 12 12 12
18A 3 23876-040000 PLUG, R04 12 12 12 12 12
19 2 148616-11170 GUIDE, VALVE 24 24 24 24 24
20 2 148620-11530 GUIDE, BRIDGE 12 12 12 12 12
21 2 148620-11180 VALVE, SUCTION 12 12 12 12 12
21-1 2 148660-11100 VALVE, SUCTION 12 12 12 12 12 S
(A=*2013.05) (B=*2013.05) (C=*2013.05) (D=*2013.05) (E=*2013.05)
22 2 148620-11110 VALVE, EXHAUST 12 12 12 12 12
23-1 2 148620-11150 SEAL, VALVE STEM 24 24 24 24 24
24 2 148620-11460 SPRING, VALVE 24 24 24 24 24
25 2 148620-11470 SPRING, VALVE 24 24 24 24 24
26 2 175149-11700 ROTATOR ASSY, VALVE 24 24 24 24 24
26-1 2 175149-11701 ROTATOR, VALVE 24 24 24 24 24 N
(A=*2009.09) (B=*2009.09) (C=*2009.09) (D=*2009.09) (E=*2009.09)
27 2 148633-11190 COTTER 48 48 48 48 48
28 2 148620-11911 STUD 6 6 6 6 6
28A 2 22312-080100 PIN, PARALLEL M8X10 12 12 12 12 12 W
(A=*2006.11) (B=*2006.11) (C=*2006.11) (D=*2006.11) (E=*2006.11)
29 1 148616-11930 GASKET, T=2.0 6 6 6 6 6 1
30 1 148620-11900 RETAINER, VALVE 6 6 6 6 6
30-1 1 148620-11901 RETAINER, VALVE 6 6 6 6 6 S
(A=*2009.01) (B=*2009.01) (C=*2009.01) (D=*2009.01) (E=*2009.01)
31 1 140623-53360 WASHER 6 6 6 6 6
32 1 26602-140002 NUT, M14 6 6 6 6 6
33 1 148620-11800 BOLT, HEAD 36 36 36 36 36
33-1 1 148620-11801 BOLT, HEAD 36 36 36 36 36 S
(A=*2012.10) (B=*2012.10) (C=*2012.10) (D=E04001) (E=*2012.10)
34 1 148620-11820 WASHER 36 36 36 36 36
Remarks
34-1 1 148620-11821 WASHER 36 36 36 36 36 S
(A=*2012.10) (B=*2012.10) (C=*2012.10) (D=E04001) (E=*2012.10)
(2)Interchangeable by simultaneous replacement with No.1-1, 33-1, 34-1 & Fig.1-5.
(3)Interchangeable by simultaneous replacement with No.1-2, 14-1 & No.21-1.
0CG10-M32503
Fig.22. LOCKER ARM (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748620-11152 ARM ASSY, ROCKER 6 6 6 6
1-1 1 748620-11153 ARM ASSY, ROCKER 6 6 6 6 6 N
(A=*2007.10) (B=*2007.10) (C=*2007.10) (D=*2007.10)
1-2 1 748960-11151 ARM ASSY, ROCKER 6 6 6 6 6 R
2 2 748620-11201 ARM ASSY, ROCKER 6 6 6 6 6
2-1 2 748960-11871 ARM ASSY, ROCKER 6 6 6 6 6 R
4 3 148620-11220 BUSH 6 6 6 6 6
4-1 3 148960-11221 BUSH 6 6 6 6 6 R
5 3 148616-11230 SCREW, VALVE ADJUST 6 6 6 6 6
6 3 26692-140002 NUT, LOCK M14 6 6 6 6 6
7 2 748620-11212 ARM ASSY, ROCKER 6 6 6 6 6
7-1 2 748960-11881 ARM ASSY, ROCKER 6 6 6 6 6 R
9 3 148620-11220 BUSH 6 6 6 6 6
9-1 3 148960-11221 BUSH 6 6 6 6 6 R
10 3 148616-11230 SCREW, VALVE ADJUST 6 6 6 6 6
11 3 26692-140002 NUT, LOCK M14 6 6 6 6 6
12 2 748620-11251 SHAFT ASSY 6 6 6 6
12-1 2 748620-11252 SHAFT ASSY 6 6 6 6 6 N
(A=*2007.10) (B=*2007.10) (C=*2007.10) (D=*2007.10)
12-2 2 748960-11891 SHAFT CMP, ROCKERARM 6 6 6 6 6 R
14 3 23876-005000 PLUG, R005 6 6 6 6 6
15 2 22242-000320 RING, 32 6 6 6 6 6
16 2 148620-11260 SUPPORT 6 6 6 6 6
17 1 748620-11261 BRIDGE ASSY, VALVE 12 12 12 12 12
19 2 140623-11740 RETAINER 12 12 12 12 12
20 2 148616-11520 SCREW 12 12 12 12 12
21 2 26776-120002 NUT, LOCK M12 12 12 12 12 12
22 1 148620-11272 BOLT 6 6 6 6 6
23 1 148620-11290 BOLT 6 6 6 6 6
24 1 148620-11281 BOLT 6 6 6 6 6
24-1 1 148960-11280 BOLT 6 6 6 6 6 R

0CG10-M32503
Fig.23. BONNET (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-11301 HOUSING, ROCKER ARM 6 6 6
1-1 1 148620-11302 HOUSING, ROCKER ARM 6 6 6 N
(A=*2005.03) (B=*2005.03) (D=*2005.03)
1-2 1 148620-11303 HOUSING, ROCKER ARM 6 6 6 6 F 1
(A=*2006.11) (B=*2006.11) (D=*2006.11)
1-3 1 148620-11304 HOUSING, ROCKER ARM 6 6 6 6 6 N
(A=*2007.08) (B=*2007.08) (C=*2007.08) (D=*2007.08)
2 1 148620-11700 GASKET, HOUSING 6 6 6
2-1 1 148620-11701 GASKET, HOUSING 6 6 6 6 6 N
(A=*2006.11) (B=*2006.11) (D=*2006.11)
3 1 26106-080302 BOLT, M8X 30 PLATED 6 6 6 6 6
4 1 26116-120902 BOLT, M12X 90 PLATED 18 18 18 18 18
5 1 26106-080852 BOLT, M8X 85 PLATED 12 12 12 12 12
6 1 26106-081052 BOLT, M8X105 PLATED 12 12 12 12 12
7 1 22117-120000 WASHER, 12 18 18 18 18 18
8 1 748620-11311 BONNET ASSY, HEAD 6 6 6 6 6
8-1 1 748960-11310 BONNET ASSY, HEAD 6 6 6 6 6 N
9 2 22242-000160 RING, 16 6 6 6 6 6
12 3 148628-11330 GASKET, BONNET 6 6 6 6 6
13 2 126650-11440 BOLT 6 6 6 6 6
13-1 2 148620-11440 BOLT 6 6 6 6 6 N
(A=*2008.08) (B=*2008.08) (C=*2008.08) (D=*2008.08) (E=*2008.08)
13-2 2 148620-11441 BOLT 6 6 6 6 6 N
14 2 22190-160003 WASHER, SEAL 16 6 6 6 6 6
14-1 2 22190-160001 WASHER, SEAL 16 6 6 6 6 6 S
Remarks
(1)Interchangeadle by simultaneous
replacement with No.2-1.
0CG10-M32503
Fig.24. SUC.MANIFOLD (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-12100 MANIFOLD, INTAKE 1 1 1 1 1
2 1 148620-12150 GASKET, MANIFOLD 6 6 6 6 6
3 1 23876-030000 PLUG, R03 1 1 1 1 1
4 1 22137-120000 WASHER, 12 24 24 24 24 24
5 1 23010-015000 CLAMP, 15 2 2 2 2 2
6 1 23414-120000 GASKET, 12X1.0 2 2 2 2 2
7 1 23414-170000 GASKET, 17X1.0 1 1 1 1 1
8 1 23887-120002 PLUG, 12 2 2 2 2 2
9 1 23897-030002 PLUG G3/8,HEX. 1 1 1 1 1
10 1 23897-010002 PLUG, G1/8 2 2 2 2 2
11 1 23414-100000 GASKET, 10X1.0 2 2 2 2 2
12 1 126684-49910 PLUG 1 1 1 1 1
13 1 23414-120000 GASKET, 12X1.0 1 1 1 1 1
14 1 127610-11750 PLUG, M33X1.5 3 3 3 3 3
15 1 127610-11760 GASKET 3 3 3 3 3
16 1 26116-120302 BOLT, M12X 30 PLATED 24 24 24 24 24
17 1 148660-18640 DRAIN ASSY, AUTO 1 1 1 1 1
23 1 126684-12300 HOSE ASSY, RUBBER 1 1 1 1 1 Z
24 1 148688-12610 JOINT PF1/4,BALL 1 1 1 1 1
24-1 1 148660-12630 JOINT, BALL PF1/4 1 1 1 1 1 N
(A=*2007.12) (B=*2007.12) (C=*2007.12) (D=*2007.12) (E=*2007.12)
24-2 1 148660-12630 JOINT, BALL PF1/4 1 1 1 1 1 Z
25 1 126616-12620 JOINT, BALL PF1/4 1 1 1 1 1
25-1 1 148660-12640 JOINT, BALL PF1/4 1 1 1 1 1 N
(A=*2007.12) (B=*2007.12) (C=*2007.12) (D=*2007.12) (E=*2007.12)
25-2 1 148660-12640 JOINT, BALL PF1/4 1 1 1 1 1 Z
26 1 148688-39320 BOLT,BALL JOINT 1 1 1 1 1
26-1 1 148660-12660 BOLT, JOINT M10 1 1 1 1 1 N
(A=*2007.12) (B=*2007.12) (C=*2007.12) (D=*2007.12) (E=*2007.12)
26-2 1 148660-12660 BOLT, JOINT M10 1 1 1 1 1 Z
27 1 23414-100000 GASKET, 10X1.0 2 2 2 2 2 Z
28 1 23414-120000 GASKET, 12X1.0 2 2 2 2 2 Z
29 1 23857-060000 BOLT, JOINT 6 1 1 1 1
29-1 1 23854-060000 BOLT, JOINT 6 1 1 1 1 1 N
(A=E*****) (B=E*****) (C=E*****) (D=E*****)
29-2 1 23854-060000 BOLT, JOINT 6 1 1 1 1 1 Z
30 1 129590-18520 JOINT 1 1 1 1 1
30-1 1 148660-12610 JOINT, BALL 10 1 1 1 1 1 N
(A=*2007.12) (B=*2007.12) (C=*2007.12) (D=*2007.12) (E=*2007.12)
30-2 1 148660-12610 JOINT, BALL 10 1 1 1 1 1 Z
31 1 124160-39140 BOLT, PIPE JOINT M10 1 1 1 1
31-1 1 148660-12650 BOLT, JOINT M10 1 1 1 1 1 N
(A=E*****) (B=E*****) (C=E*****) (D=E*****)

0CG10-M32503
Fig.24. SUC.MANIFOLD (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
31-2 1 148660-12650 BOLT, JOINT M10 1 1 1 1 1 Z
32 1 104264-59020 JOINT 1 1 1 1 1
32-1 1 148660-12620 JOINT, BALL 12 1 1 1 1 1 N
(A=*2007.12) (B=*2007.12) (C=*2007.12) (D=*2007.12) (E=*2007.12)
32-2 1 148660-12620 JOINT, BALL 12 1 1 1 1 1 Z
33 1 119173-59120 PIPE, FUEL 1 1 1 1 1 Z
34 1 23000-013000 CLAMP, 13 2 2 2 2 2 Z
35 1 23414-100000 GASKET, 10X1.0 2 2 2 2 2 Z

0CG10-M32503
Fig.133. (24A)AIR PIPE (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-12410 PIPE, AIR 1 1 1 1 1 W
6 1 148660-12430 PIPE, AIR 1 1 1 1 1 W
10 1 148660-12660 BOLT, JOINT M10 1 1 1 1 1 W
11 1 23297-080121 CLAMP, A8X12 3 3 3 3 3 W
12 1 23414-100000 GASKET, 10X1.0 2 2 2 2 2 W
13 1 23414-140000 GASKET, 14X1.0 2 2 2 2 2 W
14 1 23854-080000 BOLT, JOINT 8 1 1 1 1 1 W
15 1 26106-100162 BOLT, M10X 16 PLATED 2 2 2 2 2 W

0CG10-M32503
Fig.25. EXHAUST MANIFOLD (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-13000 MANIFOLD ASSY 1 1 1
1A 1 148660-13020 MANIFOLD ASSY 1 1 2
1B 1 148660-13100 MANIFOLD ASSY 1 1 1 3
1C 1 148660-13120 MANIFOLD ASSY 1 1 1 4
3 2 27241-400000 PLUG, 40 14 14 14 14 14
4 2 23894-040002 PLUG G1/2,HEX. 10 10 10 10 10
5 2 23414-210000 GASKET, 21X1.0 10 10 10 10 10
6 2 148660-13500 COVER 2 2
6-1 2 148660-13501 COVER 2 2 N
(A=*2006.12) (D=*2006.12)
7 2 148660-13510 GASKET 2 2
7-1 2 148660-13511 GASKET 2 2 N
(A=*2006.12) (D=*2006.12)
8 2 26106-100202 BOLT, M10X 20 PLATED 8 8 8 8 8
8A 2 148660-13030 LAGGING 6 6 6 6 6 5
9 1 148620-13250 GASKET 6 6 6 6 6
10 1 26203-120302 BOLT, M12X 30 PLATED 24 24 24 24 24
11 1 119620-49290 COCK ASSY, 1/4 2 2 2 2 2
14 1 26213-120302 STUD, M12X 30 4 4 4 4 4
15 1 148660-13550 SUPPORT 2 2 2 2 2
16 1 26106-100202 BOLT, M10X 20 PLATED 6 6 6 6 6
Remarks
(1)JCI
(2)jg
(3)NKS
(4)NK,AB,LR,RINA,HK
(5)Inc.in the No.1A & 1C.
0CG10-M32503
Fig.26. CAMSHAFT (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-14020 CAMSHAFT 1 1 1 1 1
2 1 148620-14101 GEAR, CAMSHAFT 1 1 1 1 1
3 1 148616-14320 RETAINER 1 1 1 1 1
4 1 148616-14330 WASHER 1 1 1 1 1
5 1 26106-080202 BOLT, M8X 20 PLATED 4 4 4 4 4
6 1 26156-200402 BOLT, M20X 40 PLATED 1 1 1 1 1
7 1 22512-120450 KEY, 12X 45 1 1 1 1 1
8 1 148660-14750 GEAR, CAMSHAFT 1 1 1 1 1
9 1 26156-120202 BOLT, M12X 20 PLATED 4 4 4 4 4

0CG10-M32503
Fig.27. IDLE GEAR (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-14900 GEAR ASSY, IDLE 1 1 1 1 1
4 2 148620-14710 BUSH 1 1 1 1 1
5 1 148620-14720 BRACKET 1 1 1
5-1 1 148620-14721 BRACKET 1 1 1 1 1 F 1
(A=*2006.03) (B=*2006.03) (D=*2006.03)
6 1 148620-14730 PLATE 1 1 1 1 1
7 1 22312-040120 PIN, PARALLEL M4X12 1 1 1 1 1
8 1 152623-14740 WASHER 1 1 1 1 1
9 1 26156-180302 BOLT, M18X 30 PLATED 1 1 1
9-1 1 26152-180252 BOLT, M18X 25 1 1 1 1 1 S
(A=*2006.03) (B=*2006.03) (D=*2006.03)
10 1 26156-140302 BOLT, M14X 30 PLATED 4 4 4 4 4
Remarks
(1)Interchangeadle by simultaneous
0CG10-M32503
Fig.28. WORKING VALVE DEVICE (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 130618-14200 TEPPET 12 12 12 12 12
2 1 148620-14460 ROD ASSY, PUSH 12 12 12 12 12

0CG10-M32503
Fig.29. TURBOCHARGER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148690-18010 TURBINE ASSY 1 1 1
1-1 1 148690-18011 TURBINE ASSY 1 1 R 1
(A=*2005.02) (B=*2005.02)
1-2 1 148690-18012 TURBINE ASSY 1 1 R 1
(A=EZZZZZ) (B=EZZZZZ)
1A 1 148690-18020 TURBINE ASSY 1 2
1A-1 1 148690-18021 TURBINE ASSY 1 R 2
(B=*2005.02)
1A-2 1 148690-18012 TURBINE ASSY 1 R 2
(B=EZZZZZ)
1B 1 148690-18030 TURBINE ASSY 1 3
1B-1 1 148690-18031 TURBINE ASSY 1 R 3
(B=*2005.02)
1B-2 1 148690-18012 TURBINE ASSY 1 R 3
(B=EZZZZZ)
1C 1 148690-18040 TURBINE ASSY 1 4
1C-1 1 148690-18041 TURBINE ASSY 1 R 4
(B=*2005.02)
1C-2 1 148690-18012 TURBINE ASSY 1 R 4
(B=EZZZZZ)
1D 1 148690-18050 TURBINE ASSY 1 5
1D-1 1 148690-18051 TURBINE ASSY 1 R 5
(B=*2005.02)
1D-2 1 148690-18012 TURBINE ASSY 1 R 5
(B=EZZZZZ)
1E 1 148690-18061 TURBINE ASSY 1 W 8
(B=EXXX)
1E-1 1 148690-18012 TURBINE ASSY 1 R 8
(B=EZZZZZ)
1F 1 148690-18071 TURBINE ASSY 1 W 9
(B=EXXX)
1F-1 1 148690-18012 TURBINE ASSY 1 R 9
(B=EZZZZZ)
2 1 148640-18021 TURBINE ASSY 1 1
2-1 1 148640-18022 TURBINE ASSY 1 R 1
(C=EZZZZZ)
2-2 1 148640-18023 TURBINE ASSY 1 S 1
(C=EZZZZZ)
2A 1 148640-18041 TURBINE ASSY 1 2
2A-1 1 148640-18042 TURBINE ASSY 1 R 2
(C=EZZZZZ)
Remarks 2A-2 1 148640-18023 TURBINE ASSY 1 N 2
(1)JCI,jg (C=EZZZZZ)
(2)NK 2B 1 148640-18051 TURBINE ASSY 1 3
(3)AB
2B-1 1 148640-18052 TURBINE ASSY 1 R 3
(4)LR
(5)BV (C=EZZZZZ)
(6)6AY-GT:S-spec, 6AYM-GTE:Optional 2B-2 1 148640-18023 TURBINE ASSY 1 S 3
TD13L-54QRC40 (C=EZZZZZ)
(7)6AY-GT:P-spec 2C 1 148640-18061 TURBINE ASSY 1 4
TD13L-50QRC34
(8)RINA 2C-1 1 148640-18062 TURBINE ASSY 1 R 4
(9)HK (C=EZZZZZ)

0CG10-M32503
Fig.29. TURBOCHARGER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
2C-2 1 148640-18023 TURBINE ASSY 1 S 4
(C=EZZZZZ)
2D 1 148640-18071 TURBINE ASSY 1 5
2D-1 1 148640-18072 TURBINE ASSY 1 R 5
(C=EZZZZZ)
2D-2 1 148640-18023 TURBINE ASSY 1 S 5
(C=EZZZZZ)
2E 1 148640-18081 TURBINE ASSY 1 8
2E-1 1 148640-18082 TURBINE ASSY 1 R 8
(C=EZZZZZ)
2E-2 1 148640-18023 TURBINE ASSY 1 S 8
(C=EZZZZZ)
2F 1 148640-18091 TURBINE ASSY 1 9
2F-1 1 148640-18092 TURBINE ASSY 1 R 9
(C=EZZZZZ)
2F-2 1 148640-18023 TURBINE ASSY 1 S 9
(C=EZZZZZ)
3 1 148665-18020 TURBINE ASSY 1 6
3-1 1 148665-18021 TURBINE ASSY 1 1 R 6
(D=*2005.02)
3A 1 148665-18040 TURBINE ASSY 1 1 W 7
(D=E0192)
4 2 126684-18150 O-RING 2 2 2 2 2
5 2 148634-18340 LAGGING 1 1 1 1 1
6 2 126616-18390 V-CLAMP 1 1 1 1 1
7 1 126684-18401 GASKET, TURBINE 1 1 1 1 1
8 1 26703-120002 NUT, M12 4 4 4 4 4
9 1 148620-18551 SILENCER 1 1 1
9-1 1 148620-18552 SILENCER 1 1 1 N
(A=*2003.10) (B=*2003.10) (D=*2003.10)
9-2 1 148620-18553 SILENCER 1 1 1 N
(A=*2004.06) (B=*2004.06) (D=*2004.06)
9-3 1 148620-18554 SILENCER 1 1 1 1 1 N
(A=*2005.11) (B=*2005.11) (D=*2005.11)
10 2 148620-18570 BAND 1 1 1 1 1
12 1 148620-18250 PLATE 1 1 1 W
(A=FROM 1ST) (B=FROM 1ST)
13 1 26573-040162 SCREW, M4X16 3 3 3 W
(A=FROM 1ST) (B=FROM 1ST)
Remarks
(1)JCI,jg
(2)NK
(3)AB
(4)LR
(5)BV
(6)6AY-GT:S-spec, 6AYM-GTE:Optional
TD13L-54QRC40
(7)6AY-GT:P-spec
TD13L-50QRC34
(8)RINA
(9)HK

0CG10-M32503
Fig.30. TURB.COMPONENT PART (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148690-18010 TURBINE ASSY 1 1 1
1-1 1 148690-18011 TURBINE ASSY 1 1 R 1
(A=*2005.02) (B=*2005.02)
1-2 1 148690-18012 TURBINE ASSY 1 1 R 1
1A 1 148690-18020 TURBINE ASSY 1 2
1A-1 1 148690-18021 TURBINE ASSY 1 R 2
(B=*2005.02)
1A-2 1 148690-18012 TURBINE ASSY 1 1 R 2
1B 1 148690-18030 TURBINE ASSY 1 3
1B-1 1 148690-18031 TURBINE ASSY 1 R 3
(B=*2005.02)
1B-2 1 148690-18012 TURBINE ASSY 1 1 R 3
1C 1 148690-18040 TURBINE ASSY 1 4
1C-1 1 148690-18041 TURBINE ASSY 1 R 4
(B=*2005.02)
1C-2 1 148690-18012 TURBINE ASSY 1 1 R 4
1D 1 148690-18050 TURBINE ASSY 1 5
1D-1 1 148690-18051 TURBINE ASSY 1 R 5
(B=*2005.02)
1D-2 1 148690-18012 TURBINE ASSY 1 1 R 5
1E 1 148690-18061 TURBINE ASSY 1 W 8
(B=EXXX)
1E-1 1 148690-18012 TURBINE ASSY 1 1 R 8
1F 1 148690-18071 TURBINE ASSY 1 W 9
(B=EXXX)
1F-1 1 148690-18012 TURBINE ASSY 1 1 R 9
2 1 148640-18021 TURBINE ASSY 1 1
2-1 1 148640-18022 TURBINE ASSY 1 R 1
(C=EZZZZZ)
2-2 1 148640-18023 TURBINE ASSY 1 S 1
(C=EZZZZZ)
2A 1 148640-18041 TURBINE ASSY 1 2
2A-1 1 148640-18042 TURBINE ASSY 1 R 2
(C=EZZZZZ)
Remarks 2A-2 1 148640-18023 TURBINE ASSY 1 N 2
(1)JCI,jg (C=EZZZZZ)
(2)NK 2B 1 148640-18051 TURBINE ASSY 1 3
(3)AB
2B-1 1 148640-18052 TURBINE ASSY 1 R 3
(4)LR
(5)BV (C=EZZZZZ)
(6)6AY-GT:S-spec, 6AYM-GTE:Optional 2B-2 1 148640-18023 TURBINE ASSY 1 S 3
TD13L-54QRC40 (C=EZZZZZ)
(7)6AY-GT:P-spec 2C 1 148640-18061 TURBINE ASSY 1 4
TD13L-50QRC34
(8)RINA 2C-1 1 148640-18062 TURBINE ASSY 1 R 4
(9)Hk (C=EZZZZZ)

0CG10-M32503
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
2C-2 1 148640-18023 TURBINE ASSY 1 S 4
(C=EZZZZZ)
2D 1 148640-18071 TURBINE ASSY 1 5
2D-1 1 148640-18072 TURBINE ASSY 1 R 5
(C=EZZZZZ)
2D-2 1 148640-18023 TURBINE ASSY 1 S 5
(C=EZZZZZ)
2E 1 148640-18081 TURBINE ASSY 1 8
2E-1 1 148640-18082 TURBINE ASSY 1 R 8
(C=EZZZZZ)
2E-2 1 148640-18023 TURBINE ASSY 1 S 8
(C=EZZZZZ)
2F 1 148640-18091 TURBINE ASSY 1 9
2F-1 1 148640-18092 TURBINE ASSY 1 R 9
(C=EZZZZZ)
2F-2 1 148640-18023 TURBINE ASSY 1 S 9
(C=EZZZZZ)
3 1 148665-18020 TURBINE ASSY 1 6
3-1 1 148665-18021 TURBINE ASSY 1 1 R 6
(D=*2005.02)
3A 1 148665-18040 TURBINE ASSY 1 1 W 7
(D=E0192)
4 2 X4918255650 COVER 1 1
5 2 X4918255630 COVER,COMPRESSOR 1
6 2 X4918253910 COVER 1 1 6
6A 2 X4918255250 COVER COMPRESSOR 1 1 7
7 2 X4918245070 WHEEL 1 1
8 2 X4918245010 WHEEL 1
9 2 X4918245120 WHEEL 1 1 6
9A 2 X4918245070 WHEEL 1 1 7
10 2 X4918142230 NUT, LOCK 1 1 1 1 1
11 2 X4918142100 SLEEVE, FLINGER 1 1 1 1 1
12 2 X4918123100 RING, PISTON 2 2 2 2 2
13 2 X4918122500 INSERT 1 1 1 1 1
14 2 X4916223200 RING SNAP 1 1 1 1 1
14-1 2 949162-23200 RING SNAP 1 1 1 1 1 R
(A=EXXXXX) (B=EXXXXX) (C=EXXXXX) (D=EXXXXX) (E=EXXXXX)
15 2 X4918122600 O-RING 1 1 1 1 1
15-1 2 X0550720700 O-RING 1 1 1 1 1 N
16 2 X4918121600 BEARING 1 1 1 1 1
Remarks 17 2 X4918142300 RING, THRUST 1 1 1 1 1
(1)JCI,jg 18 2 X4918142400 RING, THRUST 1 1 1 1 1
(2)NK 19 2 X4918122200 DEFLECTOR, OIL 1 1 1 1 1
(3)AB
20 2 X4918122300 RING SNAP 3 3 3 3 3
(4)LR
(5)BV 21 2 X4918121100 BEARING 2 2 2 2 2
(6)6AY-GT:S-spec, 6AYM-GTE:Optional 22 2 X4918230130 SHAFT, GEAR 1 1 1 1
TD13L-54QRC40 23 2 X4918230230 SHAFT 1
(7)6AY-GT:P-spec 23-1 2 X4918230231 SHAFT 1 R
TD13L-50QRC34
(C=EZZZZZ)
(8)RINA
(9)Hk 24 2 X4918225210 HOUSING 1 1

0CG10-M32503
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
24-1 2 X4918225630 HOUSING 1 1 1 S
(A=*2005.02) (B=*2005.02)
25 2 X4918225220 HOUSING 1 6
25-1 2 X4918225640 HOUSING 1 1 S 6
(D=*2005.02)
25A 2 X4918225630 HOUSING 1 1 7
26 2 X4918122700 O-RING 1 1 1
27 2 X4918122710 O-RING 1 1
28 2 X4918123700 BOLT 8 8 8 8 8
29 2 X4918114004 V CLAMP 1 1 1 Z
(A=*2005.02) (B=*2005.02) (D=*2005.02)
30 2 X4918210550 HOUSING 1 1 1
30-1 2 X4918210560 HOUSING,TURBINE 1 1 1 1 S 6
(A=*2005.02) (B=*2005.02) (D=*2005.02)
30A 2 X4918210460 HOUSING 1 1 1 1 7
31 2 X4918211460 HOUSING,TURBINE 1
32 2 148634-18340 LAGGING 1 1 1 1 1
33 2 X4918219300 PLATE,TURBINE BACK 1 1 1 1 1
36 2 X4918123500 PLATE 4 4 4 4 4
37 2 126684-18150 O-RING 2 2 2 2 2
38 2 126616-18390 V-CLAMP 1 1 1 1 1
39 2 X3253207320 BOLT 8 8 8 8 8 W
(A=*2005.02) (B=*2005.02) (D=*2005.02)
40 2 X4918217280 PLATE, CLAMP 4 4 4 4 4 W
(A=*2005.02) (B=*2005.02) (D=*2005.02)
Remarks
(1)JCI,jg
(2)NK
(3)AB
(4)LR
(5)BV
(6)6AY-GT:S-spec, 6AYM-GTE:Optional
TD13L-54QRC40
(7)6AY-GT:P-spec
TD13L-50QRC34
(8)RINA
(9)Hk

0CG10-M32503
Fig.31. EXHAUST BEND (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148616-18420 BEND 1 1 1
1-1 1 148616-18421 BEND 1 1 1 1 N
(A=*2005.12) (B=*2005.12) (D=*2005.12)
1-2 1 148616-18550 BEND ASSY 1 1 1 1 N
(A=EZZZZZ) (B=EXXXXX) (D=EXXXXX) (E=EXXXXX)
1B 2 148616-18920 LAGGING 1 1 1 1 W
(B=EXXXXX) (D=EXXXXX) (E=EXXXXX)
2 1 148616-18961 BEND 1
2-1 1 148616-18520 BEND ASSY 1 N
(C=EXXXXX)
2B 2 148616-18900 LAGGING 1 W
(C=EXXXXX)
3 1 148660-18450 SUPPORT 1 1 1 1 1
4 1 23414-210000 GASKET, 21X1.0 2 2 2 2 2
5 1 23894-040002 PLUG G1/2,HEX. 2 2 2 2 2
6 1 26203-120202 BOLT, M12X 20 PLATED 2 2 2 2 2
7 1 26116-120252 BOLT, M12X 25 PLATED 2 2 2 2 2
8 1 148660-18350 BEND ASSY 1 1 1 1
10 2 148660-18370 LAGGING 1 1 1 1
11 1 148692-18350 BEND ASSY 1
13 2 148692-18370 LAGGING 1
14 1 148660-18390 SUPPORT 1 1 1 1 1
15 1 23414-210000 GASKET, 21X1.0 2 2 2 2 2
16 1 23894-040002 PLUG G1/2,HEX. 2 2 2 2 2
17 1 26116-120252 BOLT, M12X 25 PLATED 2 2 2 2 2
18 1 26116-120252 BOLT, M12X 25 PLATED 2 2 2 2 2

0CG10-M32503
Fig.32. BELLOWS (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 23211-200218 FLANGE, 5K200 2 2 2 2
2 1 23970-200001 BELLOWS, 200A 1 1 1 1
3 1 26116-200602 BOLT, M20X 60 PLATED 16 16 16 16
3-1 1 26116-200652 BOLT, M20X 65 PLATED 16 16 16 16 N
(A=EZZZZZ) (B=EZZZZZ) (D=EZZZZZ) (E=EZZZZZ)
4 1 26716-200002 NUT, M20 16 16 16 16
5 1 23211-200218 FLANGE, 5K200 1 1 1 1 1
6 1 23970-200001 BELLOWS, 200A 1 1 1 1 1
7 1 26116-200702 BOLT, M20X 70 PLATED 16 16 16 16 1
8 1 26716-200002 NUT, M20 16 16 16 16 1
9 1 148620-18910 JOINT, EXPANSION 1 1 1 1 2
10 1 23211-200218 FLANGE, 5K200 1 1 1 1 2
11 1 26116-200702 BOLT, M20X 70 PLATED 16 16 16 16 2
12 1 26716-200002 NUT, M20 16 16 16 16 2
13 1 23211-150166 FLANGE, 5K150 2
14 1 23970-150001 BELLOWS, 150A 1
15 1 26116-160552 BOLT, M16X 55 PLATED 16
16 1 26716-160002 NUT, M16 16
17 1 23211-150166 FLANGE, 5K150 1 W
(C=EXXX)
18 1 23970-150001 BELLOWS, 150A 1 W
(C=EXXX)
19 1 26116-160552 BOLT, M16X 55 PLATED 16 W
(C=EXXX)
20 1 26716-160002 NUT, M16 16 W
(C=EXXX)
21 1 23211-150166 FLANGE, 5K150 1 W
(C=EXXX)
22 1 26116-160552 BOLT, M16X 55 PLATED 16 W
(C=EXXX)
23 1 26716-160002 NUT, M16 16 W
(C=EXXX)
24 1 43720-550960 PIPE, FLEXIBLE 1 W
(C=EXXX)
Remarks
(1)Direct mounting spec.
(2)Elastic mounting spec.
0CG10-M32503
Fig.33. SILENCER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 43100-553541 SILENCER, 200A 1 1 1 1
2 1 23211-200218 FLANGE, 5K200 2 2 2 2
3 1 23440-200000 GASKET, 200 2 2 2 2
4 1 26116-200652 BOLT, M20X 65 PLATED 16 16 16 16
5 1 26716-200002 NUT, M20 16 16 16 16
6 1 43100-569941 SILENCER, 150A 1
7 1 23211-150166 FLANGE, 5K150 2
8 1 23440-150000 GASKET, 150 2
9 1 26116-160552 BOLT, M16X 55 PLATED 16
10 1 26716-160002 NUT, M16 16

0CG10-M32503
Fig.34. AIR DUCT & AIR HEATER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-18110 DUCT, AIR 1 1 1 1 1
1-1 1 148660-18111 DUCT, AIR 1 1 1 1 1 S
2 1 148660-18150 DUCT, AIR 1 1 1
2-1 1 148660-18151 DUCT, AIR 1 1 1 1 1 N
(A=*2004.05) (B=*2004.05) (D=*2004.05)
3 1 148620-18901 JOINT, EXPANSION 2 2 2
3-1 1 126684-18900 JOINT, EXPANSION 2 2 2 2 2 N
(A=*2004.06) (B=*2004.06) (D=*2004.06)
4 1 126684-18911 GASKET 4 4 4 4 4
5 1 26106-100402 BOLT, M10X 40 PLATED 16 16 16 16 16
6 1 26366-100002 NUT, M10 16 16 16 16 16
7 1 148660-18121 DUCT, AIR 1 1 1 1 1
7-1 1 148660-18122 DUCT, AIR 1 1 1 1 1 S
8 1 148620-18180 GASKET, AIR DUCT 1 1 1 1 1
9 1 26106-100302 BOLT, M10X 30 PLATED 4 4 4 4 4
10 1 26116-101402 BOLT, M10X140 PLATED 2 2 2 2 2
11 1 22137-100000 WASHER, 10 2 2 2 2 2
12 1 23897-030002 PLUG G3/8,HEX. 2 2 2 2 2
13 1 23414-170000 GASKET, 17X1.0 2 2 2 2 2
14 1 148660-18131 DUCT, AIR 1 1 1 1 1
14-1 1 148660-18132 DUCT, AIR 1 1 1 1 1 S
15 1 127695-18190 GASKET 3 3 3 3 3
16 1 26106-080452 BOLT, M8X 45 PLATED 4 4 4 4 4
17 1 26116-081302 BOLT, M8X130 PLATED 2 2 2 2 2
18 1 26106-080252 BOLT, M8X 25 PLATED 6 6 6 6 6
19 1 148660-18160 SUPPORT 1 1 1 1 1
19-1 1 148660-18161 SUPPORT 1 1 1 1 1 N
(A=*2008.04) (B=*2008.04) (C=*2008.04) (D=*2008.04) (E=*2008.04)
20 1 26106-100202 BOLT, M10X 20 PLATED 2 2 2 2 2
21 1 26106-100252 BOLT, M10X 25 PLATED 2 2 2 2 2
22 1 148660-18400 COVER 1 1 1 1 1
23 1 148660-18410 COVER 1 1 1 1 1
23-1 1 148660-18411 COVER 1 1 1 1 1 N
(A=*2008.01) (B=*2008.01) (C=*2008.01) (D=*2008.01) (E=*2008.01)
24 1 148628-18750 WASHER 9 9 9 9 9
25 1 148628-18760 GUROMET 9 9 9 9 9
26 1 148628-18770 CUSHION 18 18 18 18 18
27 1 26226-080252 STUD, M8X 25 9 9 9 9 9
28 1 26366-080002 NUT, M8 9 9 9 9 9
29 1 26756-080002 NUT, LOCK M8 9 9 9 9 9
30 1 127695-18180 JOINT 1 1 1 1 1
31 1 26106-100452 BOLT, M10X 45 PLATED 2 2 2 2 2 W
32 1 127695-77500 HEATER, AIR 22V2KW 1 1 1 1 1

0CG10-M32503
Fig.35. AIR COOLER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748660-18111 COOLER ASSY, INTER 1 1 1
1-1 1 748660-18112 COOLER ASSY, INTER 1 1 1 1 N
(A=*2004.11) (B=*2004.11) (D=*2004.11)
1-2 1 748660-18113 COOLER ASSY, INTER 1 1 1 1 N
1A 1 748692-18110 COOLER ASSY, INTER 1
1A-1 1 748692-18111 COOLER ASSY, INTER 1 N
(C=EZZZZZ)
2 2 148660-18501 BODY, COOLER 1 1 1 1 1
3 2 148660-18511 COVER 1 1 1 1
3-1 2 148660-18512 COVER 1 1 1 1 N
3A 2 148692-18510 COVER 1
3A-1 2 148692-18511 COVER 1 N
(C=EZZZZZ)
4 2 148660-18520 COVER 1 1 1 1 1
5 2 148660-18101 CORE 1 1 1
5-1 2 148660-18102 CORE 1 1 1 1 N
(A=*2004.11) (B=*2004.11) (D=*2004.11)
5A 2 148692-18100 CORE 1
6 2 24326-001900 O-RING, 4DG190.0 3 3 3 3 3
7 2 135410-33310 PLUG 4 4 4 4 4
8 2 27210-200550 ZINC, SCREW20X55 4 4 4 4 4
9 2 123210-09310 GASKET 4 4 4 4 4
10 2 23414-250000 GASKET, 25X1.0 4 4 4 4 4
11 2 26106-100352 BOLT, M10X 35 PLATED 8 8 8 8 8
12 2 26106-100752 BOLT, M10X 75 PLATED 4 4 4 4 4
13 2 148660-18640 DRAIN ASSY, AUTO 1 1 1 1 1
19 2 23897-030002 PLUG G3/8,HEX. 2 2 2 2 2
20 2 23414-170000 GASKET, 17X1.0 2 2 2 2 2
20A 2 23877-040000 PLUG, R04 1 1 1 1 1 W
21 1 26106-100702 BOLT, M10X 70 PLATED 4 4 4 4 4
22 1 26116-101102 BOLT, M10X110 PLATED 4 4 4
22-1 1 26106-101102 BOLT, M10X110 PLATED 4 4 4 4 4 R
(A=*2005.03) (B=*2005.03) (D=*2005.03)
23 1 148660-18700 SUPPORT 1 1 1 1 1
23-1 1 148660-18701 SUPPORT 1 1 1 1 1 N
24 1 26116-140352 BOLT, M14X 35 PLATED 2 2 2 2 2
25 1 26156-140252 BOLT, M14X 25 PLATED 2 2 2 2 2
26 1 23010-015000 CLAMP, 15 1 1 1 1 1

0CG10-M32503
Fig.36. CRANKSHAFT & FLYWHEEL (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-21150 CRANKSHAFT ASSY 1 1 1 1 1
1A 1 148640-21130 CRANKSHAFT ASSY 1 Z 1
(A=*2004.04)
1B 1 148640-21140 CRANKSHAFT ASSY 1 1 1 1 1 2
1C 1 148640-21150 CRANKSHAFT ASSY 1 1 1 3
1D 1 148640-21160 CRANKSHAFT ASSY 1 1 1 4
1E 1 148640-21170 CRANKSHAFT ASSY 1 1 1 W 5
(B=*2006.12)
1F 1 148640-21180 CRANKSHAFT ASSY 1 1 1 W 6
(B=*2007.06) (C=*2007.06) (E=*2007.06)
1G 1 148640-21190 CRANKSHAFT ASSY 1 1 1 W 7
(B=*2006.13)
3 2 148620-21201 GEAR, CRANKSHAFT 1 1 1 1 1
4 2 121850-21920 PIN, M10X22 1 1 1 1 1
5 2 22312-060060 PIN, PARALLEL M6X 6 1 1 1 1 1
6 1 148620-21350 FLYWHEEL ASSY 1 1 1 1 1
8 2 133670-21600 GEAR,RING 1 1 1 1 1
9 1 152673-21500 BOLT,FLYWHEEL 12 12 12 12 12
10 1 22451-200000 WIRE, 2.0 6 6 8
Remarks
(1)jg (was integrated into No.1B).
(2)NK & jg
(3)AB
(4)LR
(5)RINA
(6)BV
(7)Hk
(8)jg

0CG10-M32503
Fig.37. PISTON & CONNECTING ROD (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748620-22803 PISTON ASSY 6 6 6
1A 1 748660-22800 PISTON ASSY 6 6
3 2 748620-22501 RING SET, PISTON 6 6 6
3A 2 748660-22500 RING SET, PISTON 6 6
9 1 148620-22310 PIN, PISTON 6 6 6 6 6
10 1 22252-000620 RING, 62 12 12 12 12 12
11 1 748620-23100 ROD ASSY, CONNECTING 6 6 6 6 6
11A 1 748640-23140 ROD ASSY, CONNECTING 6 6 6 W 4
(B=*2008.04) (C=*2008.04) (E=*2008.04)
11B 1 748640-23150 ROD ASSY, CONNECTING 6 6 6 W 5
(B=*2008.04) (C=*2008.04) (E=*2008.04)
11C 1 748640-23160 ROD ASSY, CONNECTING 6 6 6 W 6
(B=*2008.04) (C=*2008.04) (E=*2008.04)
11D 1 748640-23170 ROD ASSY, CONNECTING 6 6 6 W 7
(B=*2008.04) (C=*2008.04) (E=*2008.04)
11E 1 748640-23180 ROD ASSY, CONNECTING 6 6 6 W 8
(B=*2008.04) (C=*2008.04) (E=*2008.04)
11F 1 748640-23190 ROD ASSY, CONNECTING 6 6 6 W 9
(B=*2008.04) (C=*2008.04) (E=*2008.04)
15 3 148620-23201 BOLT, ROD 24 24 24
15-1 3 148620-23202 BOLT, ROD 24 24 24 24 24 R
(A=*2006.05) (B=*2006.05) (D=*2006.05)
16 3 148620-23220 NUT, ROD BOLT 24 24 24 24 24
17 2 748620-23600 METAL ASSY, CRANK 6 6 6 6 6
19 2 148620-23820 METAL, PISTON PIN 6 6 6 6 6 1
20 1 748620-23610 METAL ASSY, 0.25 US 6 6 6 6 6 2
22 1 748620-23620 METAL ASSY, 0.50 US 6 6 6 6 6 3
Remarks
(1)Repair parts
(4)NK
(5)AB
(6)LR
(7)RINA
(8)BV
(9)Hk

0CG10-M32503
Fig.38. DAMPER & V-PULLEY (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 22217-100000 WASHER, SPRING 10 4 4 4
2 1 26106-100352 BOLT, M10X 35 PLATED 4 4 4
3 1 45220-551780 V-PULLEY, P200XBX3 1 1 1
4 1 148660-28210 JOINT 1 1 1
5 1 152623-28270 REAMER BOLT 12 12 12
6 1 130618-28101 DAMPER 1 1 1 1 1
7 1 148660-28240 BOLT 6 6 6 6 6 1
8 1 144626-28900 COVER 1 1 1 1 1
8-1 1 144626-28901 COVER 1 1 1 1 1 S
9 1 26106-100182 BOLT, M10X 18 PLATED 10 10 10 10 10
9-1 1 26106-100182 BOLT, M10X 18 PLATED 6 6 6 6 6 K
Remarks
(1)Not illustrated.
0CG10-M32503
Fig.39. CG-COUPLING (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 45423-023400 JOINT 1 1
2 1 45423-571940 COUPLING, CGM5508 1 1
3 1 45423-023290 COUPLING, CGM5508S1 1 1
4 1 45521-020670 BOLT 12 12

0CG10-M32503
Fig.40. LUB.OIL PUMP (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748620-32011 PUMP ASSY, OIL 1 1 1 1 1
16 2 148620-32201 GEAR, PUMP 1 1 1 1 1
17 2 148620-32260 COVER 1 1 1 1
17-1 2 148620-32261 COVER 1 1 1 1 1 N
(A=*2007.09) (B=*2007.09) (C=*2007.09) (D=*2007.09)
18 2 148620-32271 COVER 1 1 1 1
18-1 2 148620-32272 COVER 1 1 1 1 1 N
(A=*2007.09) (B=*2007.09) (C=*2007.09) (D=*2007.09)
19 2 148816-32280 PLATE 2 2 2 2 2
20 2 26106-080142 BOLT, M8X 14 PLATED 4 4 4 4 4
21 2 148633-32140 NUT 1 1 1 1 1
23 2 22522-070220 KEY, WOODRUFF 7X22 1 1 1 1 1
26 2 26106-060142 BOLT, M6X 14 PLATED 5 5 5 5 5
27 2 26346-060002 NUT, M6 5 5 5 5 5
28 2 726616-32200 VALVE ASSY, SAFETY 1 1 1 1 1
29 3 138613-84232 RETAINER, SPRING 1 1 1 1 1
30 3 144626-32330 SPRING 1 1 1 1 1
31 3 145410-32310 BODY, VALVE 1 1 1 1 1
32 3 145610-32320 VALVE, SAFETY 1 1 1 1 1
33 3 145410-32400 PLATE,ADJUSTING 1 1 1 1 1
36 4 128633-32410 VALVE 1 1 1 1 1
37 4 128633-32420 SPRING, VALVE 1 1 1 1 1
38 4 128633-32430 COVER 1 1 1 1 1
40 3 128633-32450 PLATE 1 1 1 1 1
41 2 26106-100302 BOLT, M10X 30 PLATED 4 4 4 4 4
42 1 148620-32500 PIPE ASSY, INTAKE 1 1 1 1 1
46 1 26106-100402 BOLT, M10X 40 PLATED 4 4 4 4 4
47 1 126650-03072 GASKET, BREATHER 1 1 1 1 1
48 1 148690-32500 PIPE ASSY, INTAKE 1 1 1 1 1 1
Remarks
(1)Shallow type lub.Oil Sump
0CG10-M32503
Fig.41. LUB.OIL COOLER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748620-33010 COOLER ASSY, OIL 1 1 1 1 1
1-1 1 748620-33011 COOLER ASSY, OIL 1 1 1 1 1 S
2 2 148620-33030 BODY, COOLER 1 1 1 1 1
3 2 148620-33040 COVER 1 1 1 1 1
3-1 2 148620-33041 COVER 1 1 1 1 1 S
4 2 148620-33010 CORE ASSY 2 2 2 2 2
5 2 26376-100002 NUT, M10 8 8 8 8 8
6 2 24326-000300 O-RING, 4DG30.0 4 4 4 4 4
7 2 24316-000140 O-RING, 4DP14.0 8 8 8 8 8
8 2 26106-100652 BOLT, M10X 65 PLATED 1 1 1 1 1
9 2 26106-100252 BOLT, M10X 25 PLATED 9 9 9 9 9
10 2 23887-200002 PLUG, 20 1 1 1 1 1
11 2 23414-200000 GASKET, 20X1.0 1 1 1 1 1
12 2 23897-030002 PLUG G3/8,HEX. 1 1 1 1 1
13 2 23414-170000 GASKET, 17X1.0 1 1 1 1 1
14 2 26106-100282 BOLT, M10X 28 PLATED 2 2 2 2 2
14-1 2 26106-100302 BOLT, M10X 30 PLATED 2 2 2 2 2 S
15 2 26106-100802 BOLT, M10X 80 PLATED 6 6 6 6 6
16 2 148620-33061 COVER 1 1 1 1 1
17 2 148620-33050 GASKET 1 1 1 1 1
18 2 148620-33070 GASKET 1 1 1 1 1
19 2 23897-040002 PLUG, G1/2 2 2 2 2 2
20 2 23414-210000 GASKET, 21X1.0 2 2 2 2 2
21 2 23414-200000 GASKET, 20X1.0 1 1 1 Z
22 2 23887-020002 PLUG 1 1 1 Z
23 2 26366-100002 NUT, M10 8 8 8 8 8
24 2 26216-101402 STUD, M10X140 8 8 8 8 8

0CG10-M32503
Fig.42. L.O.PRESS.CONTROL VALVE (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748620-34010 VALVE ASSY, CONTROL 1 1 1 1 1
1-1 1 748620-34011 VALVE ASSY, CONTROL 1 1 1 1 1 S
(A=*2004.10) (B=*2004.10) (C=*2004.10) (D=*2004.10) (E=*2004.10)
1-2 1 748620-34012 VALVE ASSY, CONTROL 1 1 1 1 1 N
(A=*2008.09) (B=*2008.09) (C=*2008.09) (D=*2008.09) (E=*2008.09)
3 2 138613-34100 BOLT,L.O.PRS.ADJUST. 1 1 1
3-1 2 139653-34050 SCREW, ADJUSTING 1 1 1 1 1 N
4 2 139653-34090 CAP NUT 1 1 1 1 1
5 2 140623-34060 RETAINER 1 1 1 1 1
6 2 144626-34140 SUPPORT 1 1 1 1 1
7 2 144626-34210 SPRING 1 1 1 1 1
8 2 136610-34112 VALVE, CONTROL 1 1 1 1 1
9 2 23887-120002 PLUG, 12 1 1 1 1 1
10 2 23414-120000 GASKET, 12X1.0 1 1 1 1 1
11 2 23414-330000 GASKET, 33X1.0 1 1 1 1 1
12 2 26772-160002 NUT, LOCK M16 1 1 1 1 1
13 2 23414-160000 GASKET, 16X1.0 2 2 2 2 2
14 2 23897-030002 PLUG G3/8,HEX. 1 1 1 1 1
15 2 23414-170000 GASKET, 17X1.0 1 1 1 1 1
16 2 23897-020002 PLUG G1/4 1 1 1 1 1
17 2 23414-130000 GASKET, 13X1.0 1 1 1 1 1
18 1 24326-000450 O-RING, 4DG45.0 2 2 2 2 2
19 1 26106-100902 BOLT, M10X 90 PLATED 2 2 2 2 2
19-1 1 26106-100502 BOLT, M10X 50 PLATED 2 2 2 2 2 S
(A=*2004.10) (B=*2004.10) (C=*2004.10) (D=*2004.10) (E=*2004.10)
20 1 26106-100222 BOLT, M10X 22 PLATED 2 2 2 2 2
20-1 1 26106-100252 BOLT, M10X 25 PLATED 2 2 2 2 2 S

0CG10-M32503
Fig.43. DIPSTICK (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 41632-005130 DIPSTICK, OIL 1 1 1 1 1
2 1 148620-34830 GUIDE, DIPSTICK 1 1 1 1 1
5 1 23414-140000 GASKET, 14X1.0 1 1 1 1 1
5-1 1 23414-130000 GASKET, 13X1.0 1 1 1 1 1 N
6 1 148690-34830 GUIDE, DIPSTICK 1 1 1 1 1 1
9 1 41632-005170 DIPSTICK, OIL 1 1 1 1 1 1
Remarks
(1)Shallow type lub.Oil Sump
0CG10-M32503
Fig.44. LUB.OIL STRINER(EARTH TYPE) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-35120 STRAINER ASSY, OIL 1 1 1 1 1
1A 1 148620-35100 STRAINER ASSY, OIL 1 1 1 1 1
2 2 148620-35130 BODY, FILTER 1 1 1 1 1
2A 2 148620-35110 BODY, FILTER 1 1 1 1 1
3 2 148633-35400 CARTRIDGE 2 2 2 2 2
4 2 148687-35300 VALVE 1 1 1 1 1
5 1 26216-100252 STUD, M10X 25 3 3 3 3 3
6 1 26366-100002 NUT, M10 3 3 3 3 3
7 1 24316-000480 O-RING, 4DP48.0 1 1 1 1 1
8 1 26106-100252 BOLT, M10X 25 PLATED 1 1 1 1 1
8-1 1 26106-100302 BOLT, M10X 30 PLATED 1 1 1 1 1 S
9 1 148620-35160 LABEL, COCK SWITCH 1 1 1 1 1

0CG10-M32503
Fig.45. LUB.OIL STRINER(EARTH FLOAT TYPE) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-35150 STRAINER ASSY, OIL 1 1 1 1 1
1A 1 148620-35140 STRAINER ASSY, OIL 1 1 1 1 1
2 2 148620-35130 BODY, FILTER 1 1 1 1 1
2A 2 148620-35110 BODY, FILTER 1 1 1 1 1
3 2 148633-35400 CARTRIDGE 2 2 2 2 2
4 2 148688-35301 VALVE ASSY, RELIEF 1 1 1 1 1
5 1 26216-100252 STUD, M10X 25 3 3 3 3 3
6 1 26366-100002 NUT, M10 3 3 3 3 3
7 1 24316-000480 O-RING, 4DP48.0 1 1 1 1 1
8 1 26106-100252 BOLT, M10X 25 PLATED 1 1 1 1 1
8-1 1 26106-100302 BOLT, M10X 30 PLATED 1 1 1 1 1 S
9 1 148620-35160 LABEL, COCK SWITCH 1 1 1 1 1

0CG10-M32503
Fig.46. LUB.OIL BY-PASS STRAINER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 135410-35310 STRAINER, LUB OIL 1 1 1 1 1
1-1 1 148620-35310 STRAINER, OIL 1 1 1 1 1 R
2 2 135410-35950 O-RING 27.4X33.6 1 1 1 1 1
3 2 135410-35960 O-RING 117.4X123.6 1 1 1 1 1
4 2 135410-35970 PACKING 138X146 1 1 1 1 1
5 2 135410-35980 NUT 1 1 1 1 1
6 2 135410-35990 GASKET 1 1 1 1 1
7 2 135410-35940 SPINDLE 1 1 1 1 1
7A 2 135410-35890 NUT 1 1 1 1 1
7B 2 135410-35900 LABEL 1 1 1 1 1
7C 2 135410-35910 LABEL 1 1 1 1 1
7D 2 135410-35920 THRUST WASHER 1 1 1 1 1
7E 2 135410-35930 THRUST WASHER 1 1 1 1 1
8 1 26216-100222 STUD, M10X 22 4 4 4 4 4
9 1 26366-100002 NUT, M10 4 4 4 4 4
10 1 135410-35320 GASKET 1 1 1
10-1 1 148628-35321 PACKING 1 1 1 1 1 N
(A=*2004.06) (B=*2004.06) (D=*2004.06)
11 1 148620-35330 BRACKET 1 1 1 W
(A=E0128) (B=E0128) (D=E0128)
11-1 1 148620-35331 BRACKET 1 1 1 1 1 S
(A=*2006.06) (B=*2006.06) (D=*2006.06)
12 1 24326-000450 O-RING, 4DG45.0 1 1 1 W
(A=E0128) (B=E0128) (D=E0128)
12-1 1 24326-000450 O-RING, 4DG45.0 1 1 1 Z
(A=*2006.06) (B=*2006.06) (D=*2006.06)
13 1 26106-100252 BOLT, M10X 25 PLATED 2 2 2 2 2 W
(A=E0128) (B=E0128) (D=E0128)
14 1 26106-100702 BOLT, M10X 70 PLATED 2 2 2 W
(A=E0128) (B=E0128) (D=E0128)
14-1 1 26106-100702 BOLT, M10X 70 PLATED 2 2 2 Z
(A=*2006.06) (B=*2006.06) (D=*2006.06)
15 1 148620-35320 GASKET 1 1 1 1 1 W
(A=*2006.06) (B=*2006.06) (D=*2006.06)
16 1 26216-100252 STUD, M10X 25 2 2 2 2 2 W
(A=*2006.06) (B=*2006.06) (D=*2006.06)
17 1 26366-100002 NUT, M10 2 2 2 2 2 W
(A=*2006.06) (B=*2006.06) (D=*2006.06)

0CG10-M32503
Fig.47. LUB.OIL WASTE PUMP (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148616-39010 PUMP, ROTARY 1 1 1 1 1
2 1 145610-39901 HOSE 2 2 2 2 2
3 1 148616-39950 BRACKET 1 1 1 1 1
4 1 148616-39960 JOINT 1 1 1 1 1
5 1 148616-39970 JOINT 1 1 1 1 1
6 1 26106-060302 BOLT, M6X 30 PLATED 3 3 3 3 3
7 1 43730-552141 CLIP 39,HOSE 1 1 1 1 1
8 1 43730-552141 CLIP 39,HOSE 2 2 2 2 2

0CG10-M32503
Fig.48. LUB.OIL PIPE(LUB.OIL COOLER) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-39150 PIPE, OIL 1 1 1 1 1 2
1A 1 148660-39150 PIPE, OIL 1 1 1 1 1 Z 1
(A=E0142) (B=E0142) (C=E0142) (D=E0142) (E=E0142)
2 1 148620-39160 PIPE, OIL 1 1 1 1 1
3 1 26106-100222 BOLT, M10X 22 PLATED 4 4 4 4 4
3-1 1 26106-100252 BOLT, M10X 25 PLATED 4 4 4 4 4 S
4 1 24326-000500 O-RING, 4DG50.0 2 2 2 2 2
5 1 23897-030002 PLUG G3/8,HEX. 1 1 1 1 1
6 1 23414-170000 GASKET, 17X1.0 1 1 1 1 1
7 1 26106-100222 BOLT, M10X 22 PLATED 1 1 1 1 1
7-1 1 26106-100252 BOLT, M10X 25 PLATED 1 1 1 1 1 S
8 1 26106-100602 BOLT, M10X 60 PLATED 1 1 1 1 1
9 1 24326-000500 O-RING, 4DG50.0 2 2 2 2 2
10 1 26366-100002 NUT, M10 2 2 2 2 2
11 1 23897-030002 PLUG G3/8,HEX. 2 2 2 2 2
12 1 23414-170000 GASKET, 17X1.0 2 2 2 2 2
Remarks
(1)Earth float type(was integrated
into No.1).
(2)Eath type and eath float type
0CG10-M32503
Fig.49. LUB.OIL PIPE(TURBOCHARGER) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-39412 PIPE ASSY, OIL 1 1 1 1 1
6 1 144626-39543 GASKET, TURBINE 1 1 1 1 1
7 1 148620-39420 SUPPORT 1 1 1 1 1
8 1 141644-59830 RUBBER,SHOCK ABSORB. 1 1 1 1 1
9 1 133660-59320 REST,STEADY 1 1 1 1 1
10 1 26106-100502 BOLT, M10X 50 PLATED 2 2 2
10-1 1 26106-100452 BOLT, M10X 45 PLATED 2 2 2 2 2 N
(A=*2004.06) (B=*2004.06) (D=*2004.06)
11 1 23831-120000 UNION, 12 1 1 1 1 1
12 1 23414-180000 GASKET, 18X1.0 2 2 2 2 2
13 1 23297-120121 CLAMP, A12X12 1 1 1 1 1
14 1 26106-100162 BOLT, M10X 16 PLATED 1 1 1 1 1
15 1 26106-080302 BOLT, M8X 30 PLATED 1 1 1 1 1
15-1 1 26106-080252 BOLT, M8X 25 PLATED 1 1 1 1 1 S
16 1 148660-39580 PIPE, OIL 1 1 1
16-1 1 148660-39581 PIPE, OIL 1 1 1 1 1 N
(A=E0128) (B=E0128) (D=E0128)
17 1 144626-39562 GASKET, TURBINE 1 1 1 1 1
17-1 1 144626-39563 PACKING 1 1 1 1 1 N
18 1 23428-260000 GASKET, 26X1.5 1 1 1 1 1
19 1 26106-100162 BOLT, M10X 16 PLATED 1 1 1 1 1
20 1 26106-100452 BOLT, M10X 45 PLATED 2 2 2 2 2
21 1 26106-100302 BOLT, M10X 30 PLATED 1 1 1 1 1
22 1 26106-100252 BOLT, M10X 25 PLATED 1 1 1 1 1
23 1 23297-250121 CLAMP, A25X12 1 1 1 1 1
24 1 148620-39840 ABSORBER 1 1 1 1 1

0CG10-M32503
Fig.50. LUB.OIL PIPE(RETURN) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-39740 PIPE, OIL 1 1 1 1
1-1 1 148660-39741 PIPE, OIL 1 1 1 1 1 S
(A=E0663) (B=E0663) (C=E0663) (D=E0663)
2 1 23831-100000 UNION, 10 1 1 1 1
2-1 1 23831-150000 UNION, 15 1 1 1 1 1 S
(A=E0663) (B=E0663) (C=E0663) (D=E0663)
3 1 23414-160000 GASKET, 16X1.0 1 1 1 1
3-1 1 23414-200000 GASKET, 20X1.0 1 1 1 1 1 S
(A=E0663) (B=E0663) (C=E0663) (D=E0663)
4 1 23857-100000 BOLT, JOINT 10 1 1 1 1
4-1 1 146602-39800 UNION M16XM25 1 1 1 1 S 1
4-2 1 23831-150000 UNION, 15 1 1 1 1 1 S 2
(A=E0663) (B=E0663) (C=E0663) (D=E0663)
5 1 23414-160000 GASKET, 16X1.0 2 2 2 2
5-1 1 23414-200000 GASKET, 20X1.0 1 1 1 1 1 S 2
(A=E0663) (B=E0663) (C=E0663) (D=E0663)
Remarks
(1)For cylinder block:748620-01703
(2)For cylinder block:748620-01704
0CG10-M32503
Fig.51. LUB.OIL PIPE(BY-PASS) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-39800 PIPE ASSY, OIL 1 1 1
1-1 1 148660-39801 PIPE ASSY, OIL 1 1 1 1 1 S
(A=E0128) (B=E0128) (D=E0128)
2 1 23414-180000 GASKET, 18X1.0 4 4 4 4 4
3 1 23857-120000 BOLT, JOINT 12 2 2 2 2 2
4 1 23297-120081 CLAMP, A12X 8 1 1 1 Z
(A=E0128) (B=E0128) (D=E0128)

0CG10-M32503
Fig.52. LUB.OIL PIPE(F.I.PUMP) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-39262 PIPE, OIL 1 1 1 1 1
4 1 148620-39281 PIPE, OIL 1 1 1 1 1
5 1 23297-060121 CLAMP, A6X12 1 1 1 1 1
7 1 23414-120000 GASKET, 12X1.0 4 4 4 4 4
8 1 23414-220000 GASKET, 22X1.0 2 2 2 2 2
9 1 23414-220000 GASKET, 22X1.0 2 2 2 2 2
10 1 23857-060000 BOLT, JOINT 6 2 2 2 2 2
11 1 23857-180000 BOLT, JOINT 18 1 1 1 1 1
12 1 23857-180000 BOLT, JOINT 18 1 1 1 1 1

0CG10-M32503
Fig.53. LUB.OIL WING PUMP (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 27501-020000 WING PUMP, 20 1 1
2 1 740623-39342 COCK ASSY, 3-WAY 1 1
4 2 43600-010080 COVER 1 1
5 2 43600-010090 SPINDL 1 1
6 2 43600-010100 NUT 1 1
7 2 43600-010110 GASKET 1 1
8 2 43600-010120 NUT,CAP 1 1
9 2 43600-010130 O-RING 1 1
10 2 43600-010141 GASKET 1 1
11 2 43600-010150 HANDLE 1 1
12 2 43600-010160 SCREW 1 1
13 2 43600-010170 FLANGE 1 1
14 2 43600-010210 LABEL 1 1
15 1 137600-39210 FLANGE 1 1
16 1 140623-39440 RETAINER 1 1
17 1 139653-39330 SPRING ASSY 1 1
21 1 177125-04680 PIPE ASSY, OIL 1 1 Z
(A=EZZZZZ) (D=EZZZZZ)
23 2 135410-39460 FLANGE 1 1 Z
24 1 137602-39650 FLANGE,SPECTACLE 1 1
25 1 145610-84881 GASKET 5 5
26 1 26106-100252 BOLT, M10X 25 PLATED 8 8
27 1 43320-550420 FLANGE 1 1
28 1 43321-000860 FLANGE 1 1

0CG10-M32503
Fig.54. LUB.OIL WING PIPE (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 22137-160000 WASHER, 16 1 1
2 1 23211-015015 FLANGE, 5K 15 2 2
3 1 23297-150121 CLAMP, A15X12 2 2
4 1 23414-200000 GASKET, 20X1.0 3 3
5 1 23432-015000 GASKET, 5K15X0.5 2 2
6 1 23831-150000 UNION, 15 1 1
7 1 23857-150000 BOLT, JOINT 15 1 1
8 1 26106-100182 BOLT, M10X 18 PLATED 1 1
9 1 26106-100222 BOLT, M10X 22 PLATED 1 1
10 1 26156-160552 BOLT, M16X 55 PLATED 1 1
11 1 26206-100302 BOLT, M10X 30 PLATED 8 8
12 1 26366-100002 NUT, M10 1 1
13 1 26706-100002 NUT, M10 8 8
14 1 43590-551040 ADAPTER 1 1
15 1 43711-087520 PIPE, OIL 1 1
16 1 43711-096980 PIPE, OIL 1 1
16-1 1 43711-096981 PIPE, OIL 1 1 N
17 1 43730-026500 SUPPORT 1 1
18 1 23414-300000 GASKET, 30X1.0 1 1
19 1 43711-102250 PIPE, OIL 1 1
19-1 1 43711-102251 PIPE, OIL 1 1 N

0CG10-M32503
Fig.55. COOLING FRESH WATER PUMP (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748660-43010 PUMP ASSY, WATER 1 1 1 1 1
2 2 148660-43100 CASE 1 1 1 1 1
3 2 148660-43131 IMPELLER 1 1 1 1 1
4 2 148660-43140 SHAFT 1 1 1 1 1
5 2 148616-43630 SPACER 1 1 1 1 1
6 2 24101-063054 BEARING, BALL 6305 1 1 1 1 1
7 2 24101-062054 BEARING, BALL 6205 1 1 1 1 1
8 2 22252-000620 RING, 62 1 1 1 1 1
9 2 148633-43400 SEAL, MECHANICAL 1 1 1 1 1
10 2 24311-000250 O-RING, 1AP25.0 1 1 1 1 1
11 2 148633-43700 GEAR, PUMP 1 1 1 1 1
12 2 22512-070200 KEY, 7X 20 1 1 1 1 1
13 2 26356-200002 NUT, M20 1 1 1 1 1
14 2 22137-200000 WASHER, 20 1 1 1 1 1
15 2 148660-43110 COVER 1 1 1 1 1
16 2 148660-43120 PACKING 1 1 1 1 1
17 2 148616-54420 SEAL, TC32488 1 1 1 1 1
18 2 148616-43640 JOINT, PIPE 1 1 1 1 1
19 2 135210-11280 WASHER 1 1 1 1 1
20 2 119620-49290 COCK ASSY, 1/4 1 1 1 1 1
21 2 26106-100252 BOLT, M10X 25 PLATED 9 9 9 9 9
22 1 26106-100202 BOLT, M10X 20 PLATED 5 5 5 5 5
23 1 148660-43200 GASKET, PUMP 1 1 1
23-1 1 148660-43201 GASKET, PUMP 1 1 1 1 1 N
(A=*2004.05) (B=*2004.05) (D=*2004.05)
24 1 148660-42601 CASE, DRIVE 1 1 1 1
24-1 1 148660-42602 CASE, DRIVE 1 1 1 1 1 S
(A=E0663) (B=E0663) (C=E0663) (D=E0663)
25 1 148660-42620 PACKING 1 1 1
25-1 1 148660-42621 GASKET 1 1 1 1 1 N
(A=*2004.05) (B=*2004.05) (D=*2004.05)
26 1 26106-100282 BOLT, M10X 28 PLATED 8 8 8 8 8
26-1 1 26106-100302 BOLT, M10X 30 PLATED 8 8 8 8 8 S
27 1 22312-120360 PIN, PARALLEL M12X36 2 2 2 2 2
28 1 148660-42631 PACKING 1 1 1
28-1 1 148660-42632 GASKET 1 1 1 1 1 N
(A=*2004.05) (B=*2004.05) (D=*2004.05)
29 1 148660-42611 COVER 1 1 1 1 1
29-1 1 148660-42612 COVER 1 1 1 1 1 S
30 1 26292-141202 BOLT, M14X120 2 2 2 2 2
31 1 26106-100602 BOLT, M10X 60 PLATED 11 11 11 11 11
32 1 22312-100630 PIN, PARALLEL M10X63 2 2 2 2 2

0CG10-M32503
Fig.56. COOLING SEA WATER PUMP (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748660-42011 PUMP ASSY, WATER 1 1 1
1-1 1 748660-42012 PUMP ASSY, WATER 1 1 1 1 1 N
(A=E0471) (B=E0471) (D=E0471)
2 2 148018-42030 IMPELLER 1 1 1
2-1 2 148018-42031 IMPELLER 1 1 1 1 1 N
(A=E0471) (B=E0471) (D=E0471)
3 2 148218-42090 SEAL,MECHANICAL 1 1 1 1 1
4 2 148634-42100 BODY, PUMP 1 1 1 1 1
5 2 148660-42431 CASE, BEARING 1 1 1 1 1
6 2 120130-42130 PIPE 1 1 1 1 1
7 2 148660-42420 NUT 1 1 1 1 1
8 2 148018-42170 COVER 1 1 1 1 1
9 2 148660-42440 SHAFT 1 1 1 1 1
10 2 148634-42340 PLATE 1 1 1 1 1
11 2 148018-42361 HOUSING 1 1 1 1 1
12 2 148660-42400 GEAR, PUMP 1 1 1 1 1
13 2 22213-080000 WASHER, SPRING 8 8 8 8 8 8
14 2 22252-000900 RING, 90 1 1 1 1 1
15 2 22512-100260 KEY, 10X 26 1 1 1 1 1
16 2 24101-063084 BEARING, BALL 6308 2 2 2 2 2
17 2 24311-000400 O-RING, 1AP40.0 1 1 1 1 1
18 2 24321-000700 O-RING, 1AG70.0 1 1 1 1 1
19 2 24321-001000 O-RING, 1AG100.0 1 1 1 1 1
20 2 24321-001300 O-RING, 1AG130.0 2 2 2 2 2
21 2 24421-405508 SEAL, OIL TC405508 1 1 1 1 1
22 2 26113-080162 BOLT M 8X 16 (STEN 8 8 8 8 8
23 2 26106-080302 BOLT, M8X 30 PLATED 8 8 8 8 8
24 1 148660-42450 GASKET, PUMP 1 1 1
24-1 1 148660-42451 GASKET 1 1 1 1 1 N
(A=*2004.05) (B=*2004.05) (D=*2004.05)
25 1 26106-100282 BOLT, M10X 28 PLATED 4 4 4 4 4
25-1 1 26106-100302 BOLT, M10X 30 PLATED 4 4 4 4 4 S
(A=*2008.10) (B=*2008.10) (C=*2008.10) (D=*2008.10) (E=*2008.10)
26 1 26216-101002 STUD, M10X100 4 4 4 4 4
27 1 26366-100002 NUT, M10 4 4 4 4 4

0CG10-M32503
Fig.57. COOLING FRESH WATER PUMP(LOW TEMP.WATER) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748690-43020 PUMP ASSY, WATER 1 1 1
2 2 148690-43100 CASE 1 1 1
3 2 148690-43110 COVER 1 1 1
4 2 148690-43120 IMPELLER 1 1 1
5 2 148690-43130 SHAFT 1 1 1
6 2 24321-002100 O-RING, 1AG210.0 2 2 2
7 2 147673-42260 COLOR 1 1 1
8 2 148620-42330 SEAL, MECHANICAL 1 1 1
9 2 24423-355511 SEAL, OIL TC355511 1 1 1
10 2 24101-063074 BEARING, BALL 6307 1 1 1
11 2 24101-062074 BEARING, BALL 6207 1 1 1
12 2 22252-000800 RING, 80 1 1 1
13 2 26731-160002 NUT, M16 1 1 1
14 2 22133-160000 WASHER, 16 1 1 1
15 2 22512-070320 KEY, 7X 32 1 1 1
16 2 26732-240002 NUT, M24 1 1 1
17 2 22137-240000 WASHER, 24 1 1 1
18 2 26106-100202 BOLT, M10X 20 PLATED 9 9 9
19 2 23414-130000 GASKET, 13X1.0 1 1 1
20 2 23894-020002 PLUG, G1/4 1 1 1
21 2 23876-010000 PLUG, R01 1 1 1
22 2 148690-43140 GEARS 1 1 1
23 2 24321-001000 O-RING, 1AG100.0 1 1 1
24 2 148690-43150 BEND 1 1 1
25 2 120130-42130 PIPE 1 1 1
26 1 148660-42451 GASKET 1 1 1
27 1 26106-100282 BOLT, M10X 28 PLATED 4 4 4
28 1 26216-101002 STUD, M10X100 4 4 4
29 1 26366-100002 NUT, M10 4 4 4

0CG10-M32503
Fig.58. FRESH WATER COOLER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748660-44801 COOLER ASSY, WATER 1 1 1 1 1
2 2 126683-44400 COVER 1 1 1 1 1
3 2 148218-33061 GASKET, COVER 1 1 1 1 1
4 2 127610-11750 PLUG, M33X1.5 3 3 3
4-1 2 127610-11750 PLUG, M33X1.5 2 2 2 2 2 K
(A=*2004.06) (B=*2004.06) (D=*2004.06)
4A 2 23897-040002 PLUG, G1/2 1 1 1 1 1 W
(A=*2004.06) (B=*2004.06) (D=*2004.06)
5 2 127610-11760 GASKET 3 3 3
5-1 2 127610-11760 GASKET 2 2 2 2 2 K
(A=*2004.06) (B=*2004.06) (D=*2004.06)
5A 2 23414-210000 GASKET, 21X1.0 1 1 1 1 1 W
(A=*2004.06) (B=*2004.06) (D=*2004.06)
6 2 128623-44210 FILLER ASSY 1 1 1 1 1
7 2 126650-44610 GASKET 1 1 1 1 1
8 2 132310-09330 PACKING 4 4 4 4 4
9 2 145640-09320 FLANGE 4 4 4 4 4
10 2 126685-09330 GASKET 4 4 4 4 4
12 2 148633-44211 CORE ASSY 1 1 1 1 1
20 2 148633-44310 COVER 1 1 1 1 1
21 2 148660-44320 COVER 1 1 1 1 1
21-1 2 148660-44321 COVER 1 1 1 1 1 S 1
(A=*2008.10) (B=*2008.10) (C=*2008.10) (D=*2008.10) (E=*2008.10)
22 2 148633-44530 GUARD ASSY 1 1 1 1 1
25 2 26113-060102 BOLT, M6X 10 2 2 2 2 2
25-1 2 26113-060122 BOLT, M6X 12 2 2 2 2 2 S
(A=*2008.10) (B=*2008.10) (C=*2008.10) (D=*2008.10) (E=*2008.10)
26 2 24321-002300 O-RING, 1AG230.0 2 2 2 2 2
27 2 26226-100352 STUD, M10X 35 12 12 12 12 12
28 2 26716-100002 NUT, M10 4 4 4 4 4
29 2 27200-400400 ZINC, NUT40X40 4 4 4 4 4
30 2 26366-100002 NUT, M10 16 16 16 16 16
31 2 148660-44350 COVER, THERMOSTAT 1 1 1 1 1
31-1 2 148660-44351 COVER, THERMOSTAT 1 1 1 1 1 S
32 2 148660-44360 GASKET 1 1 1 1 1
33 2 23414-170000 GASKET, 17X1.0 2 2 2 2 2
34 2 23894-030002 PLUG, G3/8 2 2 2 2 2
35 2 26106-080162 BOLT, M8X 16 PLATED 4 4 4 4 4
36 2 26106-100202 BOLT, M10X 20 PLATED 8 8 8 8 8
37 2 26106-100222 BOLT, M10X 22 PLATED 4 4 4 4 4
37-1 2 26106-100252 BOLT, M10X 25 PLATED 4 4 4 4 4 S
(A=*2008.10) (B=*2008.10) (C=*2008.10) (D=*2008.10) (E=*2008.10)
38 2 26106-100602 BOLT, M10X 60 PLATED 9 9 9 9 9
39 2 23887-120002 PLUG, 12 1 1 1 1 1
40 2 23414-120000 GASKET, 12X1.0 1 1 1 1 1
41 2 41649-000130 PLUG, BLIND 1 1 1 1 1 Z
Remarks 42 2 43416-000060 PACKING T=1,ROUND 1 1 1 1
replacement with No.25-1. 42-1 2 22190-360002 WASHER, SEAL 36 1 1 1 1 1 N
(2)For non instrument panel of out (A=*2007.09) (B=*2007.09) (C=*2007.09) (D=*2007.09)
sea.
0CG10-M32503
Fig.58. FRESH WATER COOLER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
42-2 2 22190-360002 WASHER, SEAL 36 1 1 1 1 1 Z
43 1 43230-556830 SUB RESERVOIR ASSY 1 1 1 1 1
44 1 42215-570330 BRACKET 1 1 1 1 1
45 1 148660-44690 BRACKET 1 1 Z
(A=E1406) (D=E1406)
46 1 42215-570340 BELT, TANK 1 1 1 1 1
47 1 148660-44700 BELT, TANK 1 1 Z
(A=E1406) (D=E1406)
48 1 23061-071700 PIPE, 7X1700 1 1 1 1 1
49 1 148616-44560 PIPE, OVERFLOW 1 1 Z
(A=E1406) (D=E1406)
50 1 123482-44570 PIPE 1 1 1 1 1
51 1 23000-013000 CLAMP, 13 2 2 2 2 2
52 1 23010-009000 CLAMP, 9 1 1 1 1 1
53 1 22217-080000 WASHER, SPRING 8 4 4 4 4 4
54 1 26106-080162 BOLT, M8X 16 PLATED 4 4 4 4 4
55 1 26366-080002 NUT, M8 2 2 2 2 2
56 1 26106-100162 BOLT, M10X 16 PLATED 2 2 Z
(A=E1406) (D=E1406)
57 1 26106-080162 BOLT, M8X 16 PLATED 2 2 Z
(A=E1406) (D=E1406)
58 1 26366-080002 NUT, M8 2 2 Z
(A=E1406) (D=E1406)
59 1 148660-44610 BRACKET 1 1 1 1
59-1 1 148660-44611 BRACKET 1 1 1 1 1 N
(A=*2007.09) (B=*2007.09) (C=*2007.09) (D=*2007.09)
60 1 26156-160402 BOLT, M16X 40 PLATED 2 2 2 2 2
61 1 26156-140352 BOLT, M14X 35 PLATED 2 2 2 2 2
61-1 1 26156-140402 BOLT, M14X 40 PLATED 2 2 2 2 2 S
62 1 26116-120402 BOLT, M12X 40 PLATED 2 2 2 2 2
63 1 26106-100252 BOLT, M10X 25 PLATED 7 7 7 7
63-1 1 26106-100252 BOLT, M10X 25 PLATED 9 9 9 9 9 K
(A=*2007.09) (B=*2007.09) (C=*2007.09) (D=*2007.09)
63-2 1 26106-100302 BOLT, M10X 30 PLATED 9 9 9 9 9 S
64 1 148616-48200 THERMOSTAT, 71C 54 3 3 3 3 3
65 1 126634-48180 THERMOSTAT, 76.5-90 3 3 3 3 3
66 1 41649-000130 PLUG, BLIND M36 1 1 1 1 1 W 2
67 1 22190-360002 WASHER, SEAL 36 1 1 1 1 1 W 2
Remarks
(2)For non instrument panel of out
sea.
0CG10-M32503
Fig.59. COOLING FRESH WATER THERMOSTAT (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-48102 BODY, THERMOSTAT 1 1 1
2 1 148620-49380 GASKET 1 1 1
3 1 148620-49400 GASKET, THERMO.OUT 1 1 1
4 1 148690-49770 COVER 1 1 1
5 1 148620-49800 PIPE, WATER 1 1 1
6 1 23414-170000 GASKET, 17X1.0 1 1 1
7 1 23875-040000 PLUG, R04 1 1 1
8 1 23897-030002 PLUG, G 3/8 1 1 1
9 1 26106-100202 BOLT, M10X 20 PLATED 4 4 4
10 1 26106-100502 BOLT, M10X 50 PLATED 10 10 10
11 1 126634-48180 THERMOSTAT, 76.5-90 3 3 3
12 1 148616-48200 THERMOSTAT, 71C 54 3 3 3

0CG10-M32503
Fig.60. BILGE PUMP(OPTIONAL) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 977780-02411 PUMP,BILGE (24V 1 1 1 1 1
2 2 X0318121011 MOTOR ASSY, PUMP 1 1 1 1 1
3 2 X158606402X SWITH 1 1 1 1 1
4 3 X8636008003 FUSE 1 1 1 1 1
5 2 X179100022X STRAINER 1 1 1 1 1
6 2 X179100100X PIPE ASSY 1 1 1 1 1
7 2 X0044021509 HOSE A 1 1 1 1 1
8 2 X199906101X SCREW SET 1 1 1 1 1
9 2 977780-03000 INPELLER 1 1 1 1 1

0CG10-M32503
Fig.61. KINGSTON VALVE (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 43662-065010 COCK, KINGSTON 1 1 1 1 1
2 1 148816-48910 JOINT, HOSE 1 1 1 1 1
3 1 23431-065000 PACKING 1 1 1 1 1
4 1 26203-120352 BOLT, M12X 35 PLATED 4 4 4 4 4
5 1 43665-077010 VALVE 5KX65A,KINGSTN 1 1 1 1 1
6 1 23431-065000 PACKING 1 1 1 1 1
7 1 26203-120452 BOLT, M12X 45 PLATED 4 4 4 4 4
8 1 26703-120002 NUT, M12 4 4 4 4 4
9 1 41649-552910 JOINT, HOSE 1 1 1 1 1
9A 1 23211-065077 FLANGE, 5K 65 1 1
10 1 43600-021660 SIDE COVER 1 1 1
11 1 23211-065077 FLANGE, 5K 65 1 1 1
12 1 23431-065000 PACKING 1 1 1
13 1 26203-120452 BOLT, M12X 45 PLATED 4 4 4
14 1 26703-120002 NUT, M12 4 4 4
15 1 43600-025971 ANGLE VALVE(5K-65) 1 1 1 1 1
16 1 148816-48910 JOINT, HOSE 1 1 1 1 1
16A 1 23211-065077 FLANGE, 5K 65 1 1
17 1 23431-065000 PACKING 1 1 1 1 1
18 1 26203-120452 BOLT, M12X 45 PLATED 4 4 4 4 4
19 1 26704-120002 NUT, M12 4 4 4 4 4

0CG10-M32503
Fig.62. SEA WATER STRAINER(SINGLE) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 43600-028190 C.W.STRAINER 1 1 1 1 1
2 2 40000-011100 ZINC, ANTI-CORROSIVE 1 1 1 1 1
3 2 40000-014640 O-RING G150 1 1 1 1 1
4 2 40000-014900 GASKET 2 2 2 2 2
5 2 42430-015400 ELEMENT,CW.STRAINER 1 1 1 1 1
6 1 23431-065000 PACKING 2 2 2 2 2
7 1 26203-120452 BOLT, M12X 45 PLATED 8 8 8 8 8
8 1 26703-120002 NUT, M12 8 8 8 8 8
9 1 41649-552910 JOINT, HOSE 2 2 2 2 2
9A 1 23211-065077 FLANGE, 5K 65 2 2 2 2 2 1
Remarks
(1)jg
0CG10-M32503
Fig.63. SEA WATER STRAINER(DUPLEX) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 43600-021920 FILTER 65A,DUPLX.C.W 1 1 1 1 1
2 2 40000-009970 ZINC 1 1 1 1 1
3 2 40000-014600 O-RING G115 2 2 2 2 2
4 2 40000-014610 O-RING G120 1 1 1 1 1
5 2 40000-014900 GASKET 2 2 2 2 2
6 2 40000-014910 GASKET 2 2 2 2 2
7 2 40000-014920 O-RING P35.5 1 1 1 1 1
8 2 42430-015330 ELEMENT,CW.STRAINER 2 2 2 2 2
9 1 23431-065000 PACKING 2 2 2 2 2
10 1 26203-120302 BOLT, M12X 30 PLATED 8 8 8 8 8
11 1 41649-552910 JOINT, HOSE 2 2 2 2 2
11A 1 23211-065077 FLANGE, 5K 65 2 2 2 2 2 1
Remarks
(1)jg
0CG10-M32503
Fig.64. C.F.W.PIPE(THERMOSTAT-PUMP) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-49231 BEND 1 1 1 1
1-1 1 148660-49232 BEND, CFW.COOLER IN 1 1 1 1 1 N
(A=*2007.10) (B=*2007.10) (C=*2007.10) (D=*2007.10)
1-2 1 148660-49233 BEND 1 1 1 1 1 S 1
(A=*2008.11) (B=*2008.11) (C=*2008.11) (D=*2008.11) (E=*2008.11)
2 1 148660-49240 PACKING 1 1 1 1 1
3 1 24321-000800 O-RING, 1AG80.0 1 1 1 1 1
4 1 26106-100222 BOLT, M10X 22 PLATED 3 3 3 3 3
4-1 1 26106-100252 BOLT, M10X 25 PLATED 3 3 3 3 3 S
(A=*2008.11) (B=*2008.11) (C=*2008.11) (D=*2008.11) (E=*2008.11)
5 1 26106-100602 BOLT, M10X 60 PLATED 1 1 1 1 1
6 1 26116-101102 BOLT, M10X110 PLATED 2 2 2 2 2
7 1 22137-100000 WASHER, 10 2 2 2 2 2
8 1 23897-030002 PLUG G3/8,HEX. 1 1 1
8-1 1 23897-030002 PLUG G3/8,HEX. 3 3 3 3 3 K
(A=*2007.04) (B=*2007.04) (D=*2007.04)
9 1 23414-170000 GASKET, 17X1.0 1 1 1
9-1 1 23414-170000 GASKET, 17X1.0 3 3 3 3 3 K
(A=*2007.04) (B=*2007.04) (D=*2007.04)
10 1 23897-040002 PLUG, G1/2 2 2 2 2 2
11 1 23414-210000 GASKET, 21X1.0 2 2 2 2 2
12 1 23876-040000 PLUG, R04 1 1 1 Z
(A=*2007.04) (B=*2007.04) (D=*2007.04)
13 1 23887-120002 PLUG, 12 1 1 1 Z
(A=*2007.04) (B=*2007.04) (D=*2007.04)
14 1 133954-53900 PLUG M12X1.5 1 1 1 1 1
15 1 23414-120000 GASKET, 12X1.0 2 2 2
15-1 1 23414-120000 GASKET, 12X1.0 1 1 1 1 1 K
(A=*2007.04) (B=*2007.04) (D=*2007.04)
16 1 148660-49500 PIPE, WATER 1 1 1 1 1
17 1 24321-000950 O-RING, 1AG95.0 1 1 1 1 1
18 1 24321-000900 O-RING, 1AG90.0 2 2 2 2 2
19 1 26106-100252 BOLT, M10X 25 PLATED 3 3 3 3 3
19-1 1 26106-100302 BOLT, M10X 30 PLATED 3 3 3 3 3 S
(A=*2088.10) (B=*2088.10) (C=*2088.10) (D=*2088.10) (E=*2088.10)
20 1 23875-100000 PLUG, R10 1 1 1 1 1 W
(A=*2007.10) (B=*2007.10) (C=*2007.10) (D=*2007.10)
Remarks
0CG10-M32503
Fig.65. C.F.W.PIPE(THERMOSTAT-PUMP) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148690-49230 BEND 1 1 1
2 1 148620-49391 GASKET, PIPE OUT 1 1 1
3 1 23414-170000 GASKET, 17X1.0 2 2 2
4 1 23414-210000 GASKET, 21X1.0 2 2 2
5 1 23897-030002 PLUG, G 3/8 2 2 2
6 1 23897-040002 PLUG, G1/2 2 2 2
7 1 24321-000800 O-RING, 1AG80.0 1 1 1
8 1 26106-100222 BOLT, M10X 22 PLATED 3 3 3
9 1 26106-100252 BOLT, M10X 25 PLATED 4 4 4
10 1 148660-49500 PIPE, WATER 1 1 1
11 1 24321-000900 O-RING, 1AG90.0 2 2 2
12 1 24321-000950 O-RING, 1AG95.0 1 1 1
13 1 26106-100352 BOLT, M10X 35 PLATED 3 3 3
14 1 26366-100002 NUT, M10 3 3 3
15 1 148690-49200 SUPPORT 1 1 1
16 1 148620-49410 GASKET, BY-PASS 1 1 1
17 1 148690-49700 PIPE, WATER 1 1 1
18 1 148690-49710 PLATE 1 1 1
19 1 148690-49780 PIPE, WATER 1 1 1
20 1 148690-49790 SUPPORT 1 1 1
21 1 26106-100202 BOLT, M10X 20 PLATED 4 4 4
22 1 26106-100252 BOLT, M10X 25 PLATED 10 10 10
23 1 26106-100302 BOLT, M10X 30 PLATED 4 4 4
24 1 26116-120352 BOLT, M12X 35 PLATED 4 4 4
25 1 26116-160252 BOLT, M16X 25 PLATED 2 2 2
26 1 26366-100002 NUT, M10 4 4 4
27 1 26464-065000 U-BOLT, 65 2 2 2
28 1 26716-120002 NUT, M12 4 4 4
29 1 43400-004792 PACKING, 50X1.5 2 2 2

0CG10-M32503
Fig.66. C.F.W.PIPE(L.O.COOLER-BLOCK) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-49110 PIPE, WATER 1 1 1 1 1
2 1 148620-49360 GASKET 1 1 1 1 1
3 1 26106-100252 BOLT, M10X 25 PLATED 4 4 4 4 4
4 1 23887-120002 PLUG, 12 1 1 1 1 1
5 1 23414-120000 GASKET, 12X1.0 1 1 1 1 1
6 1 148660-49120 PIPE, WATER 1 1 1 1 1
7 1 148620-49360 GASKET 1 1 1 1 1
8 1 26106-100252 BOLT, M10X 25 PLATED 6 6 6 6 6
9 1 148620-49520 O-RING 1 1 1 1 1
10 1 148816-49710 PIPE, RUBBER 1 1
11 1 43730-552201 HOSE CLIP 100 4 4
12 1 148016-49900 COVER 1 1 1
13 1 43720-563350 HOSE, ID76X100 1 1 1
13A 1 148616-49930 HOSE, RUBBER 1 1 1 1
14 1 43730-552201 HOSE CLIP 100 4 4 4
Remarks
(1)NK
0CG10-M32503
Fig.67. C.S.W.PIPE(C.S.W.PUMP-AIR COOLER-F.W.COOLER) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-49400 PIPE, WATER 1 1 1 1 1
1-1 1 148660-49401 PIPE, WATER 1 1 1 1 1 N
2 1 148018-49531 GASKET, PUMP 1 1 1 1 1
2-1 1 148660-49270 GASKET,SWP 1 1 1 1 1 N
3 1 26106-100252 BOLT, M10X 25 PLATED 2 2 2 2 2
4 1 26106-101052 BOLT, M10X105 PLATED 2 2 2 2 2
5 1 148660-49300 PIPE, WATER 1 1 1
5-1 1 148660-49250 PIPE, WATER 1 1 1 1 1 F 1
(A=*2004.09) (B=*2004.09) (D=*2004.09)
5-2 1 148660-49251 PIPE, WATER 1 1 1 1 1 N
6 1 148660-49260 PIPE, WATER 1 1 1 1 1 W
(A=*2004.09) (B=*2004.09) (D=*2004.09)
7 1 148816-49710 PIPE, RUBBER 1 1 1 1 1 W
(A=*2004.09) (B=*2004.09) (D=*2004.09)
7A 1 148616-49930 HOSE,EXH.OTLT.RUBBER 1 1 1 2
7B 1 43720-563350 HOSE, ID76X100 1 1 1 W 3
(B=EXXX) (C=EXXX) (E=EXXX)
7C 1 148016-49900 COVER 1 1 1 W 4
(B=EXXX) (C=EXXX) (E=EXXX)
8 1 43730-552201 HOSE CLIP 100 4 4 4 4 4 W
(A=*2004.09) (B=*2004.09) (D=*2004.09)
9 1 148660-49410 FLANGE 1 1 1 1 1
10 1 148018-49531 GASKET, PUMP 2 2 2
10-1 1 148660-49270 GASKET 2 2 2 2 2 N
(A=*2004.09) (B=*2004.09) (D=*2004.09)
11 1 26106-100302 BOLT, M10X 30 PLATED 4 4 4
11-1 1 26106-100352 BOLT, M10X 35 PLATED 4 4 4 4 4 N
(A=*2004.09) (B=*2004.09) (D=*2004.09)
12 1 23893-030002 PLUG, G3/8 2 2 2 2 2
13 1 23414-170000 GASKET, 17X1.0 2 2 2 2 2
14 1 23883-120002 PLUG, 12 1 1 1 1 1
15 1 23414-120000 GASKET, 12X1.0 1 1 1 1 1
16 1 23893-060002 PLUG, G3/4 1 1 1 1 1
17 1 23414-270000 GASKET, 27X1.0 1 1 1 1 1
18 1 130605-49150 GASKET 1 1 1
18-1 1 148660-49280 GASKET 1 1 1 1 1 N
(A=*2004.09) (B=*2004.09) (D=*2004.09)
19 1 26116-120252 BOLT, M12X 25 PLATED 2 2 2
19-1 1 26116-120352 BOLT, M12X 35 PLATED 2 2 2 2 2 S
(A=*2004.09) (B=*2004.09) (D=*2004.09)
20 1 23221-610001 FLANGE, 61 1 1 1 1 1
21 1 23428-620000 GASKET, 51X1.5 1 1 1 1 1
22 1 26116-160502 BOLT, M16X 50 PLATED 2 2 2 2 2
Remarks 22-1 1 26116-160552 BOLT, M16X 55 PLATED 2 2 2 2 2 S
(1)Interchangeable by simultaneous (A=EXXX) (B=EXXX) (C=EXXX) (D=EXXX) (E=EXXX)
replacement with No.5-1,6,7,
8 & 19-1. 23 1 26716-160002 NUT, M16 2 2 2 2 2
(2)NK 24 1 148660-49360 PIPE, WATER 1 1 1 1 1
(3)LR,AB,BV,HK,RINA 25 1 130605-49150 GASKET 2 2 2
(4)LR,RINA

0CG10-M32503
Fig.67. C.S.W.PIPE(C.S.W.PUMP-AIR COOLER-F.W.COOLER) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
25-1 1 148660-49280 GASKET 2 2 2 2 2 N
(A=*2004.09) (B=*2004.09) (D=*2004.09)
26 1 26116-120252 BOLT, M12X 25 PLATED 4 4 4 4 4
26-1 1 26116-120302 BOLT, M12X 30 PLATED 4 4 4 4 4 S
27 1 148688-49900 JOINT, RUBBER 2 2 2 2 2
27A 1 148660-49430 JOINT, RUBBER 2 2 2 2
27B 1 43720-563360 HOSE, ID76X140 2 2 2 3
28 1 148660-49450 COVER 2 2 2 4
29 1 43730-552201 HOSE CLIP 100 8 8 8 8 8
30 1 148660-49370 PIPE, WATER 1 1 1 1 1
31 1 148660-49380 PIPE, WATER 1 1 1 1 1
32 1 124060-59380 PLUG, 6 1 1 1 1 1
33 1 22190-060002 WASHER, SEAL 6 1 1 1 1 1
34 1 126628-49650 UNION 1 1 1 1 1
35 1 23414-100000 GASKET, 10X1.0 1 1 1 1 1
36 1 148660-49390 PIPE, WATER 1 1 1 1 1
37 1 148606-49112 GASKET, PUMP 1 1 1 1 1
38 1 26106-100252 BOLT, M10X 25 PLATED 4 4 4 4 4
39 1 23414-120000 GASKET, 12X1.0 1 1 1 1 1 W
(A=*2004.11) (B=*2004.11) (D=*2004.11)
40 1 23414-170000 GASKET, 17X1.0 1 1 1 1 1 W
(A=*2004.11) (B=*2004.11) (D=*2004.11)
41 1 23884-120002 PLUG M12,HEX. 1 1 1 1 1 W
(A=*2004.11) (B=*2004.11) (D=*2004.11)
42 1 23894-030002 PLUG, G3/8 1 1 1 1 1 W
(A=*2004.11) (B=*2004.11) (D=*2004.11)
43 1 148688-49730 HOSE,BRAIDED 2 2 2 2 2
44 1 43730-552201 HOSE CLIP 100 4 4 4 4 4
Remarks
replacement with No.5-1,6,7,
8 & 19-1.
(2)NK
(3)LR,AB,BV,HK,RINA
(4)LR,RINA

0CG10-M32503
Fig.68. C.S.W.PIPE(L.C.W.PUMP-AIR COOLER-ENGINE OUT) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148690-49250 PIPE, WATER 1 1 1
2 1 148660-49260 PIPE, WATER 1 1 1
3 1 148660-49270 GASKET,SWP 2 2 2
4 1 148660-49280 GASKET,I/C IN 1 1 1
5 1 148660-49410 FLANGE 1 1 1
6 1 23414-120000 GASKET, 12X1.0 1 1 1
7 1 23414-170000 GASKET, 17X1.0 2 2 2
8 1 23414-270000 GASKET, 27X1.0 1 1 1
9 1 23883-120002 PLUG, 12 1 1 1
10 1 23893-030002 PLUG, G3/8 2 2 2
11 1 23893-060002 PLUG, G3/4 1 1 1
12 1 26106-100352 BOLT, M10X 35 PLATED 4 4 4
13 1 26116-120352 BOLT, M12X 35 PLATED 2 2 2
14 1 148660-49280 GASKET,I/C IN 1 1 1
15 1 148660-49360 PIPE, WATER 1 1 1
16 1 148660-49370 PIPE, WATER 1 1 1
17 1 148690-49380 PIPE, WATER 1 1 1
18 1 148690-49390 SUPPORT 1 1 1
19 1 148688-49900 JOINT, RUBBER 2 2 2
19A 1 148660-49430 JOINT, RUBBER 2 2 2 1
19B 1 43720-563360 HOSE, ID76X140 2 2 2 2
20 1 148816-49710 JOINT, RUBBER 1 1 1
20A 1 148616-49930 HOSE, RUBBER 1 1 1 1
20B 1 43720-563350 HOSE, ID76X100 1 1 1 2
21 1 148660-49450 COVER 2 2 2 3
22 1 148016-49900 COVER 1 1 1 3
23 1 26106-100202 BOLT, M10X 20 PLATED 2 2 2
24 1 26116-120202 BOLT, M12X 20 PLATED 2 2 2
25 1 26116-120252 BOLT, M12X 25 PLATED 2 2 2
26 1 43730-552201 CLIP, HOSE 100 4 4 4
27 1 43730-552201 CLIP, HOSE 100 8 8 8
Remarks
(1)NK
(2)LR,AB,BV,HK,RINA
(3)LR,RINA
0CG10-M32503
Fig.69. C.S.W.PIPE(CLUTCH IN/OUT) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-49310 PIPE, WATER 1 1 1 1
2 1 151623-49380 FLANGE,SPECTACLE 1 1 1 1
3 1 127620-49650 JOINT, RUBBER 1 1 1 1
3A 1 126440-49650 JOINT, RUBBER 1 1 W 1
(B=*2007.11)
3B 1 43720-018050 HOSE, RUBBER 1 1 W 2
(B=*2007.11)
4 1 23000-054000 CLAMP, 54 4 4 4 4
5 1 23421-440000 GASKET, 44X1.5 2 2 2 2
6 1 26116-120252 BOLT, M12X 25 PLATED 2 2 2 2
6-1 1 26116-120302 BOLT, M12X 30 PLATED 2 2 2 2 S
6A 1 22137-120000 WASHER, 12 2 2 2 2 W
7 1 148660-49330 PIPE, WATER 1 1 1 1
8 1 127620-49650 JOINT, RUBBER 1 1 1 1
8A 1 126440-49650 JOINT, RUBBER 1 1 W 1
(B=*2007.11)
8B 1 126440-49650 JOINT, RUBBER 1 1 W 2
(B=*2007.11) (E=*2007.11)
9 1 23000-054000 CLAMP, 54 4 4 4 4
10 1 23421-440000 GASKET, 44X1.5 1 1 1 1
11 1 26116-120252 BOLT, M12X 25 PLATED 2 2 2 2
11-1 1 26116-120302 BOLT, M12X 30 PLATED 2 2 2 2 S
11A 1 22137-120000 WASHER, 12 2 2 2 2 W
12 1 148016-49910 COVER 1 1 W 3
(B=*2007.11)
13 1 148016-49910 COVER 1 1 W 3
(B=*2007.11)
Remarks
(1)NK
(2)LR,AB,BV,HK,RINA
(3)LR,RINA
0CG10-M32503
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148691-49310 PIPE, WATER 1
4 1 151623-49380 FLANGE, SPECTACLE 1
5 1 127620-49650 JOINT, RUBBER 1
5A 1 126440-49650 JOINT, RUBBER 1 1
5B 1 43720-018050 HOSE, RUBBER 1 2
6 1 23000-054000 CLAMP, 54 4
7 1 23421-440000 GASKET, 44X1.5 2
8 1 26116-120252 BOLT, M12X 25 PLATED 2
8-1 1 26116-120302 BOLT, M12X 30 PLATED 2 S
(B=EZZZZZ)
8A 1 22137-120000 WASHER, 12 2 W
(B=EZZZZZ)
9 1 148691-49330 PIPE, WATER 1
12 1 127620-49650 JOINT, RUBBER 1
12A 1 126440-49650 JOINT, RUBBER 1 1
12B 1 43720-018050 HOSE, RUBBER 1 2
13 1 23000-054000 CLAMP, 54 4
14 1 23421-440000 GASKET, 44X1.5 1
15 1 26116-120252 BOLT, M12X 25 PLATED 2
15-1 1 26116-120302 BOLT, M12X 30 PLATED 2 S
(B=EZZZZZ)
15A 1 22137-120000 WASHER, 12 2 W
(B=EZZZZZ)
16 1 148016-49910 COVER 1 3
17 1 148016-49910 COVER 1 3
Remarks
(1)NK
(2)LR,AB,BV,HK,RINA
(3)LR,RINA
0CG10-M32503
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148692-49310 PIPE, WATER 1
4 1 151623-49380 FLANGE,SPECTACLE 1
5 1 127620-49650 JOINT, RUBBER 1
5A 1 126440-49650 JOINT, RUBBER 1 W 1
(C=*2007.11)
5B 1 43720-018050 HOSE, RUBBER 1 W 2
(C=*2007.11)
6 1 23000-054000 CLAMP, 54 4
7 1 23421-440000 GASKET, 44X1.5 2
8 1 26116-120252 BOLT, M12X 25 PLATED 2
8-1 1 26116-120302 BOLT, M12X 30 PLATED 2 S
(C=EZZZZZ)
8A 1 22137-120000 WASHER, 12 2 W
(C=EZZZZZ)
9 1 148692-49330 PIPE, WATER 1
12 1 127620-49650 JOINT, RUBBER 1
12A 1 126440-49650 JOINT, RUBBER 1 W 1
(C=*2007.11)
12B 1 43720-018050 HOSE, RUBBER 1 W 2
(C=*2007.11)
13 1 23000-054000 CLAMP, 54 4
14 1 23421-440000 GASKET, 44X1.5 1
15 1 26116-120252 BOLT, M12X 25 PLATED 2
15-1 1 26116-120302 BOLT, M12X 30 PLATED 2 S
(C=EZZZZZ)
15A 1 22137-120000 WASHER, 12 2 W
(C=EZZZZZ)
16 1 151623-49380 FLANGE,SPECTACLE 1
17 1 148692-49410 PIPE, WATER 1
20 1 127620-49650 JOINT, RUBBER 1
20A 1 126440-49650 JOINT, RUBBER 1 W 1
(C=*2007.11)
20B 1 43720-018050 HOSE, RUBBER 1 W 2
(C=*2007.11)
21 1 23000-054000 CLAMP, 54 4
22 1 23421-440000 GASKET, 44X1.5 2
23 1 26116-120252 BOLT, M12X 25 PLATED 2
23-1 1 26116-120302 BOLT, M12X 30 PLATED 2 S
(C=EZZZZZ)
23A 1 22137-120000 WASHER, 12 2 W
(C=EZZZZZ)
24 1 148692-49430 PIPE, WATER 1
27 1 127620-49650 JOINT, RUBBER 1
27A 1 126440-49650 JOINT, RUBBER 1 W 1
(C=*2007.11)
27B 1 43720-018050 HOSE, RUBBER 1 W 2
(C=*2007.11)
28 1 23000-054000 CLAMP, 54 4
29 1 23421-440000 GASKET, 44X1.5 1
Remarks
30 1 26116-120252 BOLT, M12X 25 PLATED 2
(1)NK
(2)LR,AB,BV,HK,RINA 30-1 1 26116-120302 BOLT, M12X 30 PLATED 2 S
(3)LR,RINA
0CG10-M32503
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
(C=EZZZZZ)
30A 1 22137-120000 WASHER, 12 2 W
(C=EZZZZZ)
31 1 148016-49910 COVER 1 W 3
(C=*2007.11)
32 1 148016-49910 COVER 1 W 3
(C=*2007.11)
33 1 148016-49910 COVER 1 W 3
(C=*2007.11)
34 1 148016-49910 COVER 1 W 3
(C=*2007.11)
Remarks
(1)NK
(2)LR,AB,BV,HK,RINA
(3)LR,RINA
0CG10-M32503
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
2 1 23421-360000 GASKET, 36X1.5 1 1
3 1 23421-440000 GASKET, 44X1.5 2 2
4 1 26116-120302 BOLT, M12X 30 PLATED 2 2
4A 1 22137-120000 WASHER, 12 2 2 W
5 1 26116-120302 BOLT, M12X 30 PLATED 2 2
5A 1 22137-120000 WASHER, 12 2 2 W
6 1 43711-097540 PIPE, WATER 1 1
7 1 43711-097550 PIPE, WATER 1 1
8 1 43720-561870 HOSE 1 1
9 1 43730-552151 CLIP 51,HOSE 4 4
10 1 23421-360000 GASKET, 36X1.5 1 1
11 1 23421-440000 GASKET, 44X1.5 1 1
12 1 26116-120282 BOLT, M12X 28 PLATED 2 2
12-1 1 26116-120302 BOLT, M12X 30 PLATED 2 2 S
12A 1 22137-120000 WASHER, 12 2 2 W
13 1 26116-120302 BOLT, M12X 30 PLATED 2 2
13A 1 22137-120000 WASHER, 12 2 2 W
14 1 43711-097540 PIPE, WATER 1 1
15 1 43711-097560 PIPE, WATER 1 1
16 1 43720-561870 HOSE 1 1
17 1 43730-552151 CLIP 51,HOSE 4 4
20 1 23421-360000 GASKET, 36X1.5 1 1
21 1 23421-440000 GASKET, 44X1.5 2 2
22 1 26116-101152 BOLT, M10X115 PLATED 1 1
23 1 26116-120302 BOLT, M12X 30 PLATED 2 2
23A 1 22137-120000 WASHER, 12 2 2 W
24 1 26116-120302 BOLT, M12X 30 PLATED 2 2
24A 1 22137-120000 WASHER, 12 2 2 W
25 1 26366-080002 NUT, M8 2 2
26 1 26464-025000 U-BOLT, 25 1 1
27 1 43711-097570 CW PIPE 1 1
28 1 43711-097580 PIPE, WATER 1 1
29 1 43720-561870 HOSE 1 1
30 1 43730-026710 SUPPORT 1 1
31 1 43730-552151 CLIP 51,HOSE 4 4
32 1 23421-360000 GASKET, 36X1.5 1 1
33 1 23421-440000 GASKET, 44X1.5 1 1
34 1 26116-120282 BOLT, M12X 28 PLATED 2 2
34-1 1 26116-120302 BOLT, M12X 30 PLATED 2 2 S
34A 1 22137-120000 WASHER, 12 2 2 W

0CG10-M32503
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
35 1 26116-120302 BOLT, M12X 30 PLATED 2 2
35A 1 22137-120000 WASHER, 12 2 2 W
36 1 26366-080002 NUT, M8 4 4
37 1 26464-025000 U-BOLT, 25 2 2
38 1 43711-097590 PIPE, WATER 1 1
39 1 43711-097600 PIPE, WATER 1 1
40 1 43720-561870 HOSE 1 1
41 1 43730-026720 SUPPORT 1 1
42 1 43730-552151 CLIP 51,HOSE 4 4
45 1 23421-360000 GASKET, 36X1.5 1 1
46 1 23421-440000 GASKET, 44X1.5 2 2
47 1 26116-120302 BOLT, M12X 30 PLATED 2 2
47A 1 22137-120000 WASHER, 12 2 2 W
48 1 26116-120302 BOLT, M12X 30 PLATED 2 2
48A 1 22137-120000 WASHER, 12 2 2 W
49 1 43711-097540 PIPE, WATER 1 1
50 1 43711-097610 PIPE, WATER 1 1
51 1 43720-561870 HOSE 1 1
52 1 43730-552151 CLIP 51,HOSE 4 4
53 1 23421-360000 GASKET, 36X1.5 1 1
54 1 23421-440000 GASKET, 44X1.5 1 1
55 1 26116-120282 BOLT, M12X 28 PLATED 2 2
55-1 1 26116-120302 BOLT, M12X 30 PLATED 2 2 S
55A 1 22137-120000 WASHER, 12 2 2 W
56 1 26116-120302 BOLT, M12X 30 PLATED 2 2
56A 1 22137-120000 WASHER, 12 2 2 W
57 1 43711-097540 PIPE, WATER 1 1
58 1 43711-097620 PIPE, WATER 1 1
59 1 43720-561870 HOSE 1 1
60 1 43730-552151 CLIP 51,HOSE 4 4
62 1 148690-49310 PIPE, WATER 1 1
66 1 23421-440000 GASKET, 44X1.5 2 2
67 1 26116-120252 BOLT, M12X 25 PLATED 2 2
68 1 43720-561870 HOSE 1 1
69 1 43730-552151 CLIP 51,HOSE 4 4
70 1 148690-49330 PIPE, WATER 1 1
73 1 23421-440000 GASKET, 44X1.5 1 1
74 1 26116-120252 BOLT, M12X 25 PLATED 2 2
75 1 43720-561870 HOSE 1 1
76 1 43730-552151 CLIP 51,HOSE 4 4

0CG10-M32503
Fig.73. C.F.W.BEND(HEAD-EXH.MANIFOLD) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-49600 BEND 6 6 6 6 6
2 1 133670-49331 PACKING 36 12 12 12 12 12
3 1 26106-100502 BOLT, M10X 50 PLATED 6 6 6 6 6
4 1 26106-100702 BOLT, M10X 70 PLATED 6 6 6 6 6
5 1 26106-100402 BOLT, M10X 40 PLATED 6 6 6 6 6
6 1 26106-100502 BOLT, M10X 50 PLATED 6 6 6 6 6

0CG10-M32503
Fig.74. SUPPORT(SEA WATER PIPE) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-49340 SUPPORT 2 2 2
1-1 1 148660-49340 SUPPORT 3 3 3 K
(A=*2004.09) (B=*2004.09) (D=*2004.09)
1-2 1 148660-49341 SUPPORT 3 3 3 N
(A=*2005.09) (B=*2005.09) (D=*2005.09)
1-3 1 148660-49342 SUPPORT 3 3 3 3 3 N
(A=*2007.04) (B=*2007.04) (D=*2007.04)
2 1 26106-100252 BOLT, M10X 25 PLATED 4 4 4
2-1 1 26106-100252 BOLT, M10X 25 PLATED 6 6 6 6 6 K
(A=*2004.09) (B=*2004.09) (D=*2004.09)
3 1 26464-065000 U-BOLT, 65 2 2 2
3-1 1 26464-065000 U-BOLT, 65 3 3 3 K
(A=*2004.09) (B=*2004.09) (D=*2004.09)
3-2 1 148660-49980 BOLT 3 3 3 3 3 N
(A=*2005.09) (B=*2005.09) (D=*2005.09)
4 1 26366-100002 NUT, M10 4 4 4
4-1 1 26366-100002 NUT, M10 6 6 6 K
(A=*2004.09) (B=*2004.09) (D=*2004.09)
4-2 1 26366-100002 NUT, M10 6 6 6 Z
(A=*2005.11) (B=*2005.11) (D=*2005.11)
5 1 26706-100002 NUT, M10 6 6 6 6 6 W
(A=*2005.11) (B=*2005.11) (D=*2005.11)
6 1 26796-100002 NUT, LOCK M10 6 6 6 6 6 W
(A=*2005.11) (B=*2005.11) (D=*2005.11)

0CG10-M32503
Fig.75. COVER(CYLINDER BLOCK) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-49511 COVER, BLOCK 1 1 1 1 1
2 1 148620-49520 O-RING 1 1 1 1 1
3 1 26106-100222 BOLT, M10X 22 PLATED 2 2 2 2 2
3-1 1 26106-100202 BOLT, M10X 20 PLATED 2 2 2 2 2 S

0CG10-M32503
Fig.76. FUEL INJECTION PUMP (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748691-51300 PUMP ASSY, INJECTION 1 1 1
1-1 1 748691-51301 PUMP ASSY, INJECTION 1 1 N 1
(A=*2005.04) (B=*2005.04)
1-2 1 748691-51302 PUMP ASSY, INJECTION 1 1 1 N 1
(A=*2006.01) (B=*2006.01)
1A 1 748665-51310 PUMP ASSY, INJECTION 1 1
1A-1 1 748665-51311 PUMP ASSY, INJECTION 1 1 N 1
(D=*2005.06)
4 2 148620-51030 CAMSHAFT 1 1 1
4A 2 148665-51030 CAMSHAFT 1 1
5 2 152623-51050 BEARING, HR32307J 2 2 2
5A 2 152696-51050 BEARING 2 2
6 2 148620-51060 SUPPORT A 1 1 1
6A 2 148665-51060 SUPPORT 1 1
7 2 148620-51071 SEAL, OIL 1 1 1
7A 2 148665-51070 SEAL, OIL 1 1
8 2 152623-51070 COLLAR 1 1 1 1 1
9 2 148620-51080 O-RING, 4D P11.0 1 1 1 1 1
10 2 130605-51100 PLUNGER ASSY 6 6
10-1 2 130605-51101 PLUNGER ASSY 6 6 6 R
(A=*2005.03) (B=*2005.03)
10A 2 148665-51600 PLUNGER ASSY 6
10A-1 2 148665-51601 PLUNGER ASSY 6 6 N
(D=*2004.02)
13 2 152623-51150 DEFLECTOR 6 6 6
13A-1 2 148665-51750 DEFLECTOR 6 6
14 2 148620-51160 SPRING, PLUNGER 6 6 6
14A 2 148665-51160 SPRING, PLUNGER 6 6
15 2 152623-51170 RETAINER, SPRING A 6 6 6
15A 2 148665-51170 RETAINER, SPRING A 6 6
16 2 152623-51181 RETAINER, SPRING B 6 6 6
16A 2 148665-51180 RETAINER, SPRING 6 6
17 2 152623-51190 SCREW 6 6 6 6 6
18 2 148691-51200 TAPPET ASSY 6 6 6
18A 2 148665-51200 TAPPET ASSY 6 6
19 3 148691-51250 TAPPET ASSY 6 6 6
19A 3 148665-51220 TAPPET ASSY 6 6
23 3 152673-51240 TAPPET 6 6 6
23A 3 148665-51240 TAPPET 6 6
24 3 152673-51250 CIRCLIP 6 6 6 6 6
25 2 152623-51270 SCREW 6 6 6 6 6
26 2 144626-51281 O-RING, P9 7 7 7 7 7
27 2 144626-51290 O-RING, P6 6 6 6 6 6
28 2 144626-51290 O-RING, P6 8 8 8 8 8
29 2 148691-51400 VALVE ASSY, DELIVERY 6 6
29-1 2 148691-51700 VALVE ASSY, DELIVERY 6 6 6 S 2
(A=*2005.04) (B=*2005.04)
29A 2 148665-51760 VALVE ASSY, DELIVERY 6 6
Remarks 32 2 137600-51332 SPRING, DELIVERY 6 6 6 6 6
(1)Fig.77,78,79,80 is incorporated
in this fuel injection pump. 33 2 148691-51351 HOLDER, DELIVERY 6 6
(2)Interchangeable by simultaneouss 33-1 2 148691-51352 VALVE ASSY, DELIVERY 6 6 N
replacement with all cylinder.
0CG10-M32503
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
(A=*2004.11) (B=*2004.11)
33-2 2 148691-51450 VALVE ASSY, DELIVERY 6 6 6 S 2
(A=*2005.04) (B=*2005.04)
33A 2 148665-51640 HOLDER, DELIVERY 6
33A-1 2 148665-51641 HOLDER ASSY,DELIVERY 6 6 N
(D=*2004.11)
34 3 148691-51361 HOLDER, DELIVERY 6 6
34-1 3 148691-51460 HOLDER, DELIVERY 6 6 6 S
(A=*2005.04) (B=*2005.04)
34A 3 148665-51650 HOLDER, DELIVERY 6 6
35 3 130618-51370 PIECE 6 6 6 6 6
36 3 148218-51370 VALVE, CHECK 6 6
36-1 3 152696-51370 VALVE, CHECK 6 6 6 S
(A=*2005.04) (B=*2005.04)
36A 3 152696-51370 VALVE, CHECK 6 6
37 3 130618-51380 STOPPER, VALVE 6 6 6 6 6
38 3 152696-51380 GUARD,CHECK VALVE 6 6 6
38-1 3 148691-51380 RETAINER 6 6 6 6 6 S
(A=*2004.11) (B=*2004.11) (D=*2004.11)
39 3 148691-51390 SPRING, VALVE 6 6
39-1 3 148691-51370 SPRING, VALVE 6 6 6 6 S
(A=*2004.11) (B=*2004.11)
39A 3 119187-51391 SPRING, VALVE 6
39A-1 3 148691-51370 SPRING, VALVE 6 6 S
(D=*2004.11)
40 2 152673-51360 O-RING 6 6 6 6 6
41 2 152673-51390 GASKET, DELIVERY 6 6 6 6 6
42 2 152679-51390 SUPPORT ASSY, BARREL 6 6 6
42A 2 148665-51400 SUPPORT ASSY, BARREL 6 6
44 3 144626-51410 PIN 6 6 6
44A 3 144626-51410 PIN 6 6
45 2 152673-51420 O-RING 18 18 18 18 18
46 2 144626-51430 PIN 6 6 6 6 6
47 2 152673-51430 O-RING 6 6 6 6 6
48 2 152623-51450 SHIM SET, CAMSHAFT 1 1 1 1 1
54 2 130605-51500 RACK, CONTROL 1 1 1 1 1
55 2 152623-51510 PINION 6 6 6
55A 2 148665-51510 PINION 6 6
56 2 144626-51521 SCREW 1 1 1 1 1
57 2 140623-51530 SPRING, RACK 1 1 1 1 1
58 2 140623-51540 WASHER 1 1 1 1 1
59 2 152623-51540 CIRCLIP 6 6 6 6 6
60 2 140623-51580 BUSH 1 1 1 1 1
61 2 148616-51671 PLUG 1 1 1 1 1
62 2 152673-51660 O-RING 2 2 2 2 2
63 2 144626-51670 PLUG 1 1 1 1 1
64 2 144626-51680 O-RING 2 2 2
64-1 2 24356-190180 O-RING, 4D19018 2 2 2 2 2 N
Remarks
(A=*2006.09) (B=*2006.09) (D=*2006.09)
in this fuel injection pump. 65 2 136603-51690 PLUG, M16 L17 1 1 1 1 1
(2)Interchangeable by simultaneouss 66 2 144626-51700 WASHER, SEAL 2 2 2 2 2
0CG10-M32503
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
67 2 144626-51730 PLUG 8 8 8 8 8
68 2 144626-51730 PLUG 2 2 2 2 2
69 2 152623-51750 SHIM, T=1.0 12 12 12 12 12
70 2 152623-51760 SHIM SET, ADJUSTING 6 6 6 6 6
74 2 152623-51800 STUD, M12 12 12 12
74A 2 148665-51800 STUD, M12 12 12
75 2 152623-51810 WASHER 12 12 12 12 12
76 2 152623-51830 PROTECTOR 2 2
76-1 2 130605-51830 PROTECTOR 2 2 2 R
(A=*2006.09) (B=*2006.09)
76A 2 148665-51830 PROTECTOR 2
76A-1 2 130605-51830 PROTECTOR 2 2 R
(D=*2006.09)
77 2 152623-51850 BEARING, CAMSHAFT 1 1 1
77A 2 152696-51850 BEARING, CAMSHAFT 1 1
78 2 124220-51890 RIVET 6 6 6 6 6
79 2 130605-51910 LABEL 1 1 1 1
79-1 2 148665-51810 LABEL, CAUTION 1 1 N
(D=*2004.11)
80 2 144626-51930 LABEL 1 1 1
80-1 2 124610-51970 LABEL 1 1 1 1 1 R
(A=*2006.08) (B=*2006.08) (D=*2006.08)
81 2 144626-51940 PLUG 2 2 2 2 2
82 2 144626-51940 PLUG 1 1 1 1 1
83 2 144626-51950 O-RING, 1016 2 2 2 2 2
84 2 144626-51950 O-RING, 1016 1 1 1 1 1
85 2 158805-85900 PLUG, G1/4 1 1 1 1 1
86 2 144626-51290 O-RING, P6 2 2 2 2 2
87 2 22190-120002 WASHER, SEAL 12 1 1 1 1 1
88 2 22190-160002 WASHER, SEAL 16 1 1 1 1 1
89 2 22217-060000 WASHER, SPRING 6 3 3 3 3 3
90 2 22217-120000 WASHER, SPRING 12 12 12 12 12 12
91 2 24341-000900 O-RING, 1AS90.0 2 2 2 2 2
92 2 22512-070222 KEY, 7X 22 1 1 1 1 1
93 2 22512-100340 KEY, 10X 34 1 1 1
93A 2 22512-070200 KEY, 7X 20 1 1
94 2 124410-51861 GASKET 1 1 1 1 1
95 2 124220-51890 RIVET 2 2 2 2 2
96 2 23887-120002 PLUG, 12 1 1 1 1 1
97 2 23887-160002 PLUG, 16 1 1 1 1 1
98 2 26013-080302 BOLT, M8X 30 4 4 4 4 4
99 2 26226-060162 STUD, M6X 16 3 3 3 3 3
100 2 26450-060252 BOLT, M6X 25 2 2 2 2 2
101 2 26716-060002 NUT, M6 3 3 3 3 3
102 2 26736-120002 NUT, M12 12 12 12 12 12
104 2 148691-51950 VALVE ASSY, OVERFLOW 1 1
104-1 2 148691-51951 VALVE ASSY, OVERFLOW 1 1 1 N
(A=*2006.01) (B=*2006.01)
Remarks 104-2 2 148691-51952 VALVE ASSY,OVER FLOW 1 1 1 N
(A=EXXXXX) (B=EXXXXX) (C=EXXXXX)
in this fuel injection pump.
(2)Interchangeable by simultaneouss 104A 2 148620-51950 VALVE ASSY, OVERFLOW 1 1
0CG10-M32503
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
104A-1 2 148620-51951 VALVE ASSY,OVER FLOW 1 1 N
(D=EXXXXX) (E=EXXXXX)
110 2 148620-52001 PUMP ASSY, FEED 1 1 1 1 1
111 2 130605-54500 JOINT ASSY 1 1 1
111A 2 148691-54500 JOINT ASSY 1 1
112 2 148620-54690 COUPLING ASSY 1 1 1 1 1
112-1 2 148965-54690 COUPLING ASSY 1 1 1 1 1 R
113 2 148620-51090 SLEEVE 1 1 1
113A 2 148665-51090 SLEEVE 1 1
114 2 130605-51580 BUSH 1 1 1 1 1
115 2 152696-51090 COLLAR 2 2
117 2 130605-61490 COMPENSATER, BOOST 1 1 1
117-1 2 148691-61490 COMPENSATER, BOOST 1 1 1 1 1 N
(A=*2005.12) (B=*2005.12) (D=*2005.12)
119 2 22351-050010 PIN, SPRING 5.0X10 1 1 1 1 1 W
(A=*2006.06) (B=*2006.06) (D=*2006.06)
120 2 130605-61510 GASKET 1 1 1 1 1 W
121 2 26106-080222 BOLT, M8X 22 PLATED 2 2 2 2 2 W
122 2 26106-080902 BOLT, M8X 90 PLATED 2 2 2 2 2 W
Remarks
in this fuel injection pump.
(2)Interchangeable by simultaneouss
0CG10-M32503
Fig.77. FUEL FEED PUMP (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 2 148620-52001 FEED PUMP ASSY 1 1 1 1 1
2 3 148688-52012 BODY ASSY, PUMP 1 1 1 1 1
2-1 3 148688-52013 BODY ASSY, PUMP 1 1 1 1 1 S
3 4 124210-21230 PLUG 1 1 1 1 1
6 4 148616-52161 SPINDLE, INTER 1 1 1 1 1
7 4 144626-52270 SEAL, KB5-14-5 2 2 2 2 2
7-1 4 144626-52270 SEAL, KB5-14-5 1 1 1 1 1 K
7A 4 148620-52070 SEAL, OIL 1 1 1 1 1 W
7B 4 22252-000140 RING, 14 1 1 1 1 1 W
8 3 135200-52071 CIRCLIP 1 1 1 1 1
9 3 148620-52100 GUIDE ASSY, ROLLER 1 1 1 1 1
10 4 148620-52110 ROLLER 1 1 1 1 1
11 4 148688-52120 PIN, ROLLER 1 1 1 1 1
13 4 148688-52141 RETAINER 2 2 2 2 2
14 3 135200-52170 PISTON 1 1 1 1 1
15 3 148620-52190 SPRING, PISTON 1 1 1 1 1
16 3 148620-52180 SPRING, VALVE 1 1 1 1 1
17 3 127692-52210 RETAINER, SPRING 1 1 1 1 1
18 3 135200-52213 VALVE, FEED PUMP 4 4 4 4 4
19 3 144626-52230 RETAINER, SPRING 3 3 3 3 3
20 3 135200-52301 PUMP ASSY, PRIMING 1 1 1 1 1
21 4 148616-52240 HOLDER, SPRING 1 1 1 1 1
22 4 135200-52320 PACKING 1 1 1 1 1
23 4 152623-52300 KNOB ASSY 1 1 1 1 1
27 5 135200-52350 SPRING, PRIMING 1 1 1 1 1
28 5 135200-52361 KNOB 1 1 1 1 1
29 5 22322-030180 PIN, TAPER 3X18 1 1 1 1 1
30 3 148616-52420 JOINT 1 1 1 1 1
31 3 135200-52510 SPRING, CHECK VALVE 4 4 4 4 4
32 3 23414-180023 GASKET, 18X1.0 4 4 4 4 4
33 3 23414-250031 GASKET, 25X1.0 1 1 1 1 1
34 3 144626-52921 LABEL,INJECTION PUMP 1 1 1 1 1 W
Remarks
* This figure(fuel feed pump)is
incorporated in the fuel injection
pump assy(Fig.76).
0CG10-M32503
Fig.78. COUPLING (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 2 130605-54500 JOINT ASSY 1 1 1
1A 2 148691-54500 JOINT ASSY 1 1
2 3 130605-54420 WASHER, SPRING 1 1 1
3 3 130605-54550 COUPLING, IDLE 1 1 1
3A 3 148691-54550 JOINT 1 1
4 3 26736-270002 NUT, M27 1 1 1
4A 3 152696-54790 NUT, END 1 1
5 2 148620-54690 COUPLING ASSY 1 1 1 1 1
5-1 2 148965-54690 COUPLING ASSY 1 1 1 1 1 R
6 3 148688-54490 JOINT 1 1 1 1 1
7 3 148620-54510 JOINT 1 1 1 1 1
7-1 3 148965-54510 JOINT 1 1 1 1 1 R
8 3 148688-54520 SHIM 16 16 16 16 16
9 3 148688-54540 RETAINER 8 8 8 8 8
10 3 148688-54550 WASHER 8 8 8 8 8
11 3 148688-54580 WASHER,PLAIN 2 2 2 2 2
12 3 22217-140000 WASHER, SPRING 14 1 1 1 1 1
13 3 26138-120252 BOLT, 12X 25 6 6 6 6 6
14 3 26138-120402 BOLT, 12X 40 2 2 2 2 2
15 3 26156-140602 BOLT, M14X 60 PLATED 1 1 1 1 1
16 3 26376-120002 NUT, M12 2 2 2
16-1 3 121450-01220 NUT, CYLINDER HEAD 2 2 2 2 2 N
(A=*2004.11) (B=*2004.11) (D=*2004.11)
Remarks
* This figure(coupling)is
pump assy(Fig.76)
0CG10-M32503
Fig.79. GOVERNOR (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
2 3 135210-51080 SEAL, OIL 1 1 1 1 1
3 3 122710-51360 O-RING 1 1 1 1 1
4 3 124220-51890 RIVET 2 2 2 2 2
5 3 148640-61010 CASE 1 1 1 1 1
6 4 144626-61431 BUSH 2 2 2 2 2
7 4 144626-61800 O-RING, 1015 2 2 2 2 2
8 3 152623-61051 GASKET, CASE 1 1 1 1 1
9 3 148640-61070 GASKET 1 1 1 1 1
11 3 148640-61140 LINK 1 1 1 1 1 1
12 3 148640-61150 LINK 1 1 1 1 1 1
13 3 148640-61160 LINK 1 1 1 1 1 1
14 3 148640-61170 LINK 1 1 1 1 1 1
15 3 148640-61180 LINK 1 1 1 1 1 1
15A 3 144626-61140 LINK, L50 1 1 1 1 1 W 1
(A=*2005.11) (B=*2005.11) (D=*2005.11)
15B 3 144626-61150 LINK, L51 1 1 1 1 1 W 1
(A=*2005.11) (B=*2005.11) (D=*2005.11)
15C 3 148691-61140 LINK, B 1 1 1 1 1 W 1
15D 3 148691-61150 LINK, B 1 1 1 1 1 W 1
15E 3 148691-61160 LINK, B 1 1 1 1 1 W 1
16 3 140673-61160 LINK, GOVERNOR 1 1 1 1 1
17 3 148640-61200 WEIGHT ASSY,GOVERNOR 1 1 1 1 1
19 4 135210-61221 PIN, GOVERNOR WEIGHT 2 2 2 2 2
20 4 135210-61230 BUSH,PIN 4 4 4 4 4
21 4 148640-61240 PIN 2 2 2 2 2
22 4 148640-61250 ROLLER 2 2 2 2 2
24 4 22117-100000 WASHER, 10 4 4 4 4 4
25 4 22242-000100 RING, 10 4 4 4 4 4
26 3 148640-61270 PLATE 1 1 1 1 1
27 3 140623-61310 WASHER 1 1 1 1 1
28 3 135210-61320 THRUST BEARING 1 1 1 1 1
29 3 148609-61330 SHIFTER 1 1 1 1 1
31 4 140673-61350 BUSH 1 1 1 1 1
32 3 140623-61500 SPACER, CAMSHAFT 1 1 1 1 1
33 3 144626-61510 SHAFT 1 1 1 1 1
34 3 136603-61530 LEVER 1 1 1
34-1 3 144626-61530 LEVER 1 1 1 1 1 R
(A=*2005.05) (B=*2005.05) (D=*2005.05)
35 3 135210-61540 RETAINER 2 2 2 2 2
36 3 748609-61510 SHAFT (2ND) SET 1 1 1 1 1
36-1 3 148609-61550 SHAFT ASSY 1 1 1 1 1 R
38 4 22322-030180 PIN, TAPER 3X18 1 1 1 1 1
39 3 148616-61570 BEARING 1 1 1
39A 3 148640-61570 BEARING 1 1
40 3 135210-61590 BOLT 1 1 1 1 1
41 3 136603-61590 LEVER 1 1 1 1 1
Remarks
* This figure(governor) is incorporated in the fuel injection pump assy(Fig.76). 42 3 136603-61600 BEARING, D24L12 1 1 1 1 1
(1)Selection use parts.
0CG10-M32503
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
43 3 144626-61620 SLEEVE 1 1 1 1 1
44 3 148616-61640 BEARING 1 1 1 1 1
45 3 148616-61650 SEAL, VC081404 2 2 2 2 2
46 3 144626-61790 BRACKET 1 1 1
46-1 3 148640-61790 BRACKET 1 1 1 1 1 S
(A=*2006.09) (B=*2006.09) (D=*2006.09)
47 3 148640-61800 STUD 4 4 4 4 4
48 3 148640-61810 STUD 4 4 4 4 4
49 3 135210-61830 HANDLE (L=86) 1 1 1 1 1
50 3 144626-61840 PLATE 1 1 1 1 1
51 3 135210-61850 PIN 1 1 1 1 1
52 3 148640-61850 LINK 1 1 1 1 1
53 3 136603-61860 GUIDE 1 1 1 1 1
54 3 144626-61890 SPRING 1 1 1 1 1
55 3 152623-61910 BUSH 1 1 1 1 1
56 3 180110-66410 PIN 4 4 4 4 4
57 3 131110-66420 WASHER 4 4 4 4 4
58 3 22117-080000 WASHER, 8 1 1 1 1 1
59 3 22190-120002 WASHER, SEAL 12 1 1 1 1 1
60 3 22190-220002 WASHER, SEAL 22 1 1 1 1 1
60-1 3 23414-220029 GASKET, 22X1.0 1 1 1 1 1 N
61 3 22217-060000 WASHER, SPRING 6 1 1 1 1 1
62 3 22217-140000 WASHER, SPRING 14 1 1 1 1 1
63 3 22242-000110 RING, 11 2 2 2 2 2
64 3 22272-000070 RING, E- 7 1 1 1 1 1
64-1 3 22276-000070 RING, 7 1 1 1 1 1 R
65 3 22312-060140 PIN, PARALLEL M6X14 1 1 1 1 1
66 3 22312-060140 PIN, PARALLEL M6X14 2 2 2 2 2
67 3 22417-160120 PIN, COTTER 1.6X12 4 4 4 4 4
68 3 22522-030100 KEY, WOODRUFF 3X10 1 1 1 1 1
69 3 23887-120002 PLUG, 12 1 1 1 1 1
70 3 23897-040002 PLUG, G1/2 1 1 1 1 1
71 3 24311-000080 O-RING, 1AP8.0 2 2 2 2 2
72 3 24312-000050 O-RING, 2P5.0 1 1 1 1 1
73 3 24312-000200 O-RING 2 P-20.0 2 2 2 2 2
74 3 26106-060162 BOLT, M6X 16 PLATED 1 1 1 1 1
75 3 26106-060162 BOLT, M6X 16 PLATED 3 3 3 3 3
76 3 26106-060182 BOLT, M6X 18 PLATED 1 1 1 1 1
77 3 26106-080222 BOLT, M8X 22 PLATED 1 1 1
77A 2 26450-080222 BOLT, M8X 22 1 1
78 3 26106-080322 BOLT, M8X 32 PLATED 7 7 7 7 7
79 3 26601-140002 NUT, M14 1 1 1 1 1
80 2 752623-61430 COVER ASSY,GOV.CASE 1 1
80-1 2 748690-61430 COVER ASSY 1 1 N
(A=*2004.09) (B=*2004.09)
80-2 2 748690-61431 COVER ASSY 1 1 N
(A=*2005.05) (B=*2004.05)
80-3 2 148640-61100 COVER ASSY 1 1 1 N
Remarks
(A=*2005.06) (B=*2005.06)
* This figure(governor) is incorporated in the fuel injection pump assy(Fig.76).
0CG10-M32503
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
80A 2 752623-61430 COVER ASSY,GOV.CASE 1
80A-1 2 748665-61430 COVER ASSY 1 N
(D=*2004.09)
80A-2 2 748665-61431 COVER ASSY 1 N
(D=*2005.05)
80A-3 2 148640-61100 COVER ASSY 1 1 N
(D=*2005.06)
81 3 135210-51610 LOCK NUT 1 1 1 1 1
83 3 135210-61080 SCREW 1 1 1 1 1
84 3 135210-61090 LEAD 3 3 3 3 3
84-1 3 114780-61090 TIN 3 3 3 3 3 N
85 3 135210-61100 WIRE 1 1 1
85-1 3 120325-61100 WIRE, 1.0 3 3 3 3 N
(A=*2004.09) (B=*2004.09) (D=*2004.09)
85-2 3 135210-61100 WIRE 1 1 1 1 1 N
(A=EXXXXX) (B=EXXXXX) (C=EXXXXX) (D=EXXXXX)
86 3 148616-61361 RETAINER, SPRING 1 1 1 1 1
88 4 135210-61380 STOPPER 2 2 2 2 2
89 3 148616-61400 LEVER ASSY, CONTROL 1 1 1
89-1 3 148640-61400 LEVER ASSY, CONTROL 1 1 1 1 1 N
(A=*2005.06) (B=*2005.06) (D=*2005.06)
90 4 148616-61410 SPRING 1 1 1 1 1
92 4 148616-61440 RETAINER, SPRING 1 1 1 1 1
94 4 22217-050000 WASHER, SPRING 5 1 1 1 1 1
95 4 26577-050162 SCREW, M5X16 1 1 1
95-1 4 26567-050162 SCREW, M5X16 1 1 1 1 1 R
(A=*2005.06) (B=*2005.06) (D=*2005.06)
96 3 152623-61420 SHAFT, CONTROL LEVER 1 1 1 Z
(A=*2005.06) (B=*2005.06) (D=*2005.06)
97 3 144626-61441 BUSH 2 2 2 Z
(A=*2005.06) (B=*2005.06) (D=*2005.06)
98 3 144626-61450 GUIDE 1 1 1 1 1
99 3 144626-61461 GASKET, GUIDE 2 2 2 2 2
100 3 148616-61470 LEVER ASSY 1 1 1 Z
(A=*2005.06) (B=*2005.06) (D=*2005.06)
101 3 135600-61481 SHAFT 1 1 1 1 1
102 3 135600-61491 HANDLE, GOVERNOR 1 1 1 1 1
103 3 148616-61730 SPRING 1 1
103-1 3 148616-61730 SPRING 1 1 Z
(A=*2005.06) (B=*2005.06)
103A 3 148616-61730 SPRING 1
103A-1 3 126616-61730 SPRING 1 N
(D=*2004.09)
103A-2 3 126616-61730 SPRING 1 Z
(D=*2005.06)
104 3 144626-61740 BRACKET, LEVER 1 1 1 1 1
105 3 148616-61740 RETAINER, SPRING 1 1 1 1 1
106 3 144626-61761 LEVER 1 1 1
106-1 3 148640-61760 LEVER 1 1 1 N
Remarks
(A=*2005.05) (B=*2005.05) (D=*2005.05)
0CG10-M32503
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
106-2 3 144626-61761 LEVER 1 1 1 1 1 N
(A=*2005.10) (B=*2005.10) (D=*2005.10)
107 3 148616-61761 SCREW 1 1 1 1 1
108 3 144626-61771 BOLT 1 1 1 1 1
109 3 144626-61781 PIECE 2 2 2 2 2
110 3 148616-61780 BRACKET, HANDLE 1 1 1 1 1
111 3 144626-61800 O-RING, 1015 2 2 2 Z
(A=*2005.06) (B=*2005.06) (D=*2005.06)
112 3 148616-61800 SCREW 1 1 1 1 1
113 3 144626-61900 BOLT 1 1 1 1 1
114 3 148640-61930 BOLT ASSY 1 1 1 1 1 W
(A=EXXXXX) (B=EXXXXX) (C=EXXXXX) (D=EXXXXX)
114A 4 140673-61940 BOLT 1 1 1
114A-1 4 148640-61940 BOLT, CONTROL 1 1 1 1 1 N
(A=*2005.05) (B=*2005.05) (D=*2005.05)
115 4 140673-61950 NUT 1 1 1 1 1
116 4 140673-61960 GUIDE 1 1 1 1 1
117 3 135200-61970 CIRCLIP (7) 1 1 1 1 1
118 3 22117-080000 WASHER, 8 2 2 2
118-1 3 22111-080000 WASHER 2 2 2 2 2 R
(A=EXXXXX) (B=EXXXXX) (D=EXXXXX)
119 3 22190-060001 WASHER, SEAL 6 1 1 1 1 1
120 3 22190-080003 WASHER, SEAL 8 1 1 1
120-1 3 22190-080002 WASHER, SEAL 6 1 1 1 1 1 R
(A=*2005.08) (B=*2005.08) (D=*2005.08)
121 3 22217-080000 WASHER, SPRING 8 2 2 2
121-1 3 22212-080000 WASHER 8 2 2 2 N
(A=*2004.09) (B=*2004.09) (D=*2004.09)
121-2 3 22217-080000 WASHER, SPRING 8 2 2 2 2 2 N
122 3 22312-060120 PIN, PARALLEL M6X12 1 1 1
122-1 3 148616-61390 PIN 1 1 1 1 1 N
(A=*2005.06) (B=*2005.06) (D=*2005.06)
123 3 22322-040220 PIN, TAPER 4X22 1 1 1 Z
(A=*2005.06) (B=*2005.06) (D=*2005.06)
124 3 22417-160150 PIN, COTTER 1.6X15 2 2 2
124-1 3 22411-160150 COTTER PIN 1.6X15 2 2 2 2 2 R
126 3 22512-050120 KEY, 5X 12 1 1 1 1 1
127 3 22522-040130 KEY, WOODRUFF 4X13 2 2 2 2 2
128 3 23414-200000 GASKET, 20X1.0 1 1 1 1 1
129 3 23887-080002 PLUG 8 1 1 1 1 1
130 3 24311-000080 O-RING, 1AP8.0 1 1 1 Z
(A=*2005.06) (B=*2005.06) (D=*2005.06)
131 3 24311-000110 O-RING, 1AP11.0 1 1 1 1 1
132 3 24312-000070 O-RING, 2P7.0 1 1 1 1 1
133 3 26106-060222 BOLT, M6X 22 PLATED 2 2 2 2 2
134 3 26106-080182 BOLT, M8X 18 PLATED 1 1 1 1 1
135 3 26106-080302 BOLT, M8X 30 PLATED 3 3 3 3 3
136 3 26716-060002 NUT, M6 1 1 1
Remarks
* This figure(governor) is incorporated in the fuel injection pump assy(Fig.76). 136-1 3 26756-060002 NUT, LOCK M6 1 1 1 1 1 N
0CG10-M32503
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
(A=*2006.04) (B=*2006.04) (D=*2006.04)
137 3 26696-120002 NUT, LOCK M12 1 1 1
137-1 3 26776-120002 NUT, LOCK M12 1 1 1 1 1 N
138 3 144626-61751 SPRING 1 1 1 W
(A=*2004.09) (B=*2004.09) (D=*2004.09)
138-1 3 148640-61750 SPRING 1 1 1 N
(A=*2005.05) (B=*2005.05) (D=*2005.05)
138-2 3 144626-61751 SPRING 1 1 1 1 N
(A=*2005.10) (B=*2005.10) (D=*2005.10)
140 3 148640-61110 HOUSING ASSY 1 1 1 1 1 W
(A=*2005.06) (B=*2005.06) (D=*2005.06)
142 4 152623-61430 BUSH 2 2 2 2 2 W
(A=*2005.06) (B=*2005.06) (D=*2005.06)
143 4 144626-61800 O-RING, 1015 2 2 2 2 2 W
(A=*2005.06) (B=*2005.06) (D=*2005.06)
144 3 148640-61450 SHAFT ASSY 1 1 1 1 1 W
(A=*2005.06) (B=*2005.06) (D=*2005.06)
145 4 148640-61430 SHAFT, LEVER 1 1 1 1 1 W
(A=*2005.06) (B=*2005.06) (D=*2005.06)
146 4 148616-61470 LEVER ASSY 1 1 1 W
(A=*2005.06) (B=*2005.06) (D=*2005.06)
146-1 4 148640-61480 LEVER 1 1 1 1 1 R
(A=*2006.06) (B=*2006.06) (D=*2006.06)
147 4 148016-61550 PIN 1 1 1 1 1 W
(A=*2005.06) (B=*2005.06) (D=*2005.06)
148 3 26706-080002 NUT, M8 8 8 8 W
148-1 3 26706-080002 NUT, M8 6 6 6 6 6 K
(A=*2005.06) (B=*2005.06) (D=*2005.06)
149 3 22217-080000 WASHER, SPRING 8 8 8 8 8 8 W
150 3 136603-61440 NUT 2 2 2 2 2 W
(A=*2005.06) (B=*2005.06) (D=*2005.06)
151 3 152623-61440 RETAINER 2 2 2 2 2 W
(A=*2005.06) (B=*2005.06) (D=*2005.06)
152 3 152623-61460 O-RING 2 2 2 2 2 W
(A=*2005.06) (B=*2005.06) (D=*2005.06)
153 2 148616-61710 SPRING, GOVERNOR 1 1 1 1 1
154 2 148640-61730 SPRING 1 1 1 W
(A=*2005.06) (B=*2005.06)
154A 2 126616-61730 SPRING 1 1 W
(D=*2005.06)
Remarks
0CG10-M32503
Fig.80. BOOST COMPENSATER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 130605-61490 COMPENSATER, BOOST 1 1 1
1-1 1 148691-61490 COMPENSATER, BOOST 1 1 1 1 1 N
(A=*2005.10) (B=*2005.10) (D=*2005.10)
2 2 119660-01570 STUD, M6X12 2 2 2 2 2
3 2 129155-61480 SPACER ASSY 2 2 2 2 2
9 2 148688-61500 CASE, ACTUATOR 1 1 1 1 1
10 2 130605-61510 GASKET 1 1 1 1 1 Z
11 2 129595-61600 CASE 1 1 1 1 1
12 2 126684-61610 BUSH 1 1 1 1 1
13 2 126684-61620 ROD, SLIDER 1 1 1 1 1
14 2 148688-61630 LEVER, SETTING 1 1 1 1 1
15 2 148688-61640 COLLAR 1 1 1 1 1
16 2 126684-61650 DIAPHRAGM ASSY 1 1 1 1 1
16-1 2 126684-61651 DIAPHRAGM ASSY 1 1 1 1 1 N
17 2 148688-61650 SPRING 1 1 1 1 1
18 2 148688-61660 NUT 1 1 1 1 1
19 2 129595-61670 BOLT, ADJUSTER 1 1 1 1 1
19-1 2 129595-61671 BOLT, ADJUSTING 1 1 1 1 1 N
20 2 148688-61680 SPRING, DIAPHRAGM 1 1 1 1 1
21 2 148688-61790 SPRING, DIAPHRAGM 1 1 1 1 1
22 2 148688-61810 SHIM, T=0.5 2 2 2 2 2
23 2 148688-61820 SHIM, T=1.0 2 2 2 2 2
24 2 148688-61890 BUSH 1 1 1 1 1
25 2 148688-61900 SHAFT 1 1 1 1 1
26 2 126617-61910 LEVER 1 1 1 1 1
27 2 148688-61920 SPRING, SET 1 1 1 1 1
28 2 148688-61940 PIN 1 1 1 1 1
29 2 148688-61950 COVER 1 1 1 1 1
30 2 148688-61960 GASKET 1 1 1 1 1
31 2 158835-85990 WASHER 1 1 1 1 1
32 2 22190-080000 WASHER, SEAL 8 2 2 2 2 2
33 2 22190-100002 WASHER, SEAL 10 1 1 1 1 1
34 2 22272-000060 RING, E- 6 1 1 1 1 1
34-1 2 22276-000060 RING, E- 6 1 1 1 1 1 R
35 2 22287-080000 WASHER, 8 1 1 1 1 1
36 2 22351-050010 PIN, SPRING 5.0X10 2 2 2 2 2
37 2 23887-100002 PLUG, 10 1 1 1 1 1
38 2 24311-000120 O-RING, 1AP12.0 1 1 1 1 1
39 2 24311-000160 O-RING, 1AP16.0 1 1 1 1 1
40 2 26106-060142 BOLT, M6X 14 PLATED 2 2 2 2 2
41 2 26106-060182 BOLT, M6X 18 PLATED 3 3 3 3 3
42 2 26106-080162 BOLT, M8X 16 PLATED 1 1 1 1 1
43 2 26106-080222 BOLT, M8X 22 PLATED 2 2 2 2 2 Z
44 2 26106-080902 BOLT, M8X 90 PLATED 2 2 2 2 2 Z
Remarks
* This figure(compensater,boost)is
incorporated in the fuel injection 45 2 26366-060002 NUT, M6 2 2 2 2 2
pump assy(Fig.76).
0CG10-M32503
Fig.80. BOOST COMPENSATER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
46 2 26366-080002 NUT, M8 1 1 1 1 1
47 2 26667-080002 NUT, CAP M8 1 1 1 1 1
48 2 26757-080002 NUT, LOCK M8 2 2 2 2 2
Remarks
* This figure(compensater,boost)is
pump assy(Fig.76).
0CG10-M32503
Fig.81. FUEL INJECTION VALVE (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748691-53100 VALVE ASSY,INJECTION 6 6 6
1-1 1 748691-53101 VALVE ASSY,INJECTION 6 6 6 N
(A=EZZZZZ) (B=EZZZZZ) (E=EZZZZZ)
1-2 1 748691-53102 VALVE ASSY,INJECTION 6 6 6 R
1A 1 748691-53120 VALVE ASSY,INJECTION 6
1B 1 748665-53100 VALVE ASSY,INJECTION 6
1B-1 1 748665-53101 VALVE ASSY,INJECTION 6 S
(D=*2004.04)
1B-2 1 748665-53102 VALVE ASSY,INJECTION 6 N
(D=*2005.03)
(D=*2006.02)
(D=EZZZZZ)
1B-5 1 748691-53102 VALVE ASSY,INJECTION 6 R
(D=EZZZZZ)
2 2 148691-53000 VALVE ASSY,INJECTION 6 6 6
2-1 2 148691-53001 VALVE ASSY,INJECTION 6 6 6 N
2-2 2 148691-53002 NOZZLE ASSY 6 6 6 R
2A 2 148691-53070 NOZZLE ASSY 6
2B 2 148665-53000 NOZZLE ASSY 6
2B-1 2 148665-53001 NOZZLE ASSY 6 S
(D=*2004.04)
2B-2 2 148665-53002 NOZZLE ASSY 6 N
(D=*2005.03)
(D=*2006.02)
(D=EZZZZZ)
2B-5 2 148691-53002 NOZZLE ASSY 6 R
(D=EZZZZZ)
5 2 148620-53080 NUT, NOZZLE 6 6 6 6 6
7 2 126616-53120 SPRING 6 6 6 6 6
8 2 126616-53130 HOLDER,SPRING 6 6 6 6 6
9 2 148620-53160 BOLT 6 6 6 6 6
10 2 139684-53170 NUT,ADJ,SCREW. 6 6 6 6 6
11 2 103200-53210 KNOCK, VALVE 24 24 24 24 24
12 2 148620-53240 SPACER, VALVE STOP 6 6 6 6 6
13 2 126616-53300 RETAINER 6 6 6 6 6
14 2 152623-53360 O-RING 6 6 6 6 6
15 2 139684-53450 CAP, SCREW 6 6 6 6 6
16 2 23414-120000 GASKET, 12X1.0 12 12 12 12 12
17 2 24311-000420 O-RING, 1AP42.0 6 6 6 6 6

0CG10-M32503
Fig.82. F.I.PUMP DRIVING DEVICE (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748620-54371 DRIVE ASSY 1 1 1 1 1
3 2 148620-54391 SHAFT, DRIVE 1 1 1 1 1
4 2 148620-54420 SPACER 1 1 1 1 1
5 2 148620-54710 PLATE 1 1 1 1 1
6 2 24101-063104 BEARING, BALL 6310 1 1 1 1 1
7 2 24101-062104 BEARING, BALL 6210 1 1 1 1 1
8 2 24211-050002 NUT, BEARING 50 1 1 1 1 1
9 2 24231-050000 WASHER, 50 1 1 1 1 1
10 2 24421-405508 SEAL, OIL TC405508 1 1 1 1 1
11 2 26106-100202 BOLT, M10X 20 PLATED 4 4 4 4 4
12 1 148660-54300 GEAR, PUMP 1 1 1 1 1
13 1 22512-120300 KEY, 12X 30 1 1 1 1 1
14 1 148620-54721 PLATE 1 1 1 1 1
15 1 26106-080162 BOLT, M8X 16 PLATED 2 2 2 2 2
16 1 148620-54730 WASHER 1 1 1 1 1
17 1 26772-270002 NUT, LOCK M27 1 1 1 1 1
18 1 22512-100360 KEY, 10X 36 1 1 1 1 1
19 1 148620-54440 GASKET 1 1 1
19-1 1 148620-54441 GASKET 1 1 1 1 1 N
(A=*2006.09) (B=*2006.09) (D=*2006.09)
20 1 148620-54261 COVER 1 1 1
20-1 1 148620-54262 COVER 1 1 1 1 1 R
(A=*2006.12) (B=*2006.12) (D=*2006.12)
20-2 1 148620-54263 COVER 1 1 1 1 1 N
21 1 26106-100122 BOLT, M10X 12 PLATED 4 4 4 4 4
22 1 148620-54461 BRACKET 1 1 1 1 1
23 1 148620-01490 BOLT 2 2 2 2 2
24 1 22137-100000 WASHER, 10 2 2 2 2 2
25 1 26366-100002 NUT, M10 2 2 2 2 2
26 1 26116-120302 BOLT, M12X 30 PLATED 6 6 6 6 6

0CG10-M32503
Fig.83. FUEL PUMP BRACKET (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-54020 BRACKET 1 1 1 1 1
2 1 148620-54100 SHIM SET 2 2 2 2 2
7 1 148620-54150 SHIM SET 1 1 1 1 1
12 1 22312-120320 PIN, PARALLEL M12X32 2 2 2 2 2
13 1 26116-121202 BOLT, M12X120 PLATED 4 4 4 4 4
14 1 26116-121152 BOLT, M12X115 PLATED 2 2 2 2 2
15 1 22137-120000 WASHER, 12 6 6 6 6 6
16 1 148620-54481 SUPPORT 1 1 1 1 1
17 1 148620-54491 SUPPORT 1 1 1 1 1
18 1 148620-54200 SHIM SET 2 2 2 2 2
21 1 26116-120202 BOLT, M12X 20 PLATED 4 4 4 4 4

0CG10-M32503
Fig.84. FUEL STRAINER(SINGLE) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-55010 STRAINER, FUEL 1 1 1 1 1
2 2 152676-55510 CASE ASSY. 1 1 1 1 1
3 2 41650-501140 FILTER, FUEL 1 1 1 1 1
4 3 41650-550830 ELEMENT, FILTER 1 1 1 1 1
5 3 41650-501160 O-RING 21X15 1 1 1 1 1
6 2 41650-501740 RETAINER, SPRING 1 1 1 1 1
7 2 41650-501170 O-RING 1 1 1 1 1
8 2 123678-55880 PLUG, M14 1 1 1 1 1
9 2 43400-501170 WASHER 1 1 1 1 1
10 2 123672-55750 PLUG, DRAIN M8 2 2 2 2 2
11 2 43400-500410 SEAL WASHER 8S 2 2 2 2 2
12 2 41650-501180 LABEL, CAUTION 1 1 1 1 1
13 1 26116-120252 BOLT, M12X 25 PLATED 3 3 3 3 3
14 1 148620-55201 SUPPORT 1 1 1 1 1
15 1 127612-55850 PAD 6 6 6 6 6
16 1 137600-71040 RETAINER 6 6 6 6 6
17 1 26106-100252 BOLT, M10X 25 PLATED 4 4 4 4 4
18 1 26206-120452 BOLT, M12X 45 PLATED 3 3 3 3 3
19 1 26756-120002 NUT, LOCK M12 3 3 3 3 3

0CG10-M32503
Fig.85. FUEL STRAINER(DUPLEX) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748640-55100 STRAINER ASSY, FUEL 1 1 1 1 1
2 2 125600-02451 LOCK BOLT 1 1 1 1 1
3 2 137600-35310 GASKET 1 1 1 1 1
4 2 137600-35330 WASHER 1 1 1 1 1
8 2 148619-55520 LABEL 1 1 1 1 1
9 2 148619-55530 RETAINER 1 1 1 1 1
10 2 43570-552130 JOINT 1 1 1 1 1
11 2 23414-100000 GASKET, 10X1.0 2 2 2 2 2
12 2 23414-120000 GASKET, 12X1.0 4 4 4 4 4
13 2 23414-200000 GASKET, 20X1.0 2 2 2 2 2
14 2 23691-020010 COCK, 1/8 1 1 1
14-1 2 43600-006951 NEEDLE VALVE,6M 1 1 1 1 1 N
(A=*2004.06) (B=*2004.06) (D=*2004.06)
15 2 124250-59350 BOLT, PIPE JOINT M12 2 2 2 2 2
15-1 2 43510-550590 BOLT, BALL JOINT 2 2 2 2 2 R
16 2 23887-200002 PLUG, 20 2 2 2 2 2
17 2 24311-000400 O-RING, 1AP40.0 1 1 1 1 1
18 2 26226-100252 STUD, M10X 25 2 2 2
18-1 2 26226-100382 STUD, M10X 38 2 2 2 2 2 N
(A=*2004.11) (B=*2004.11) (D=*2004.11)
19 2 26706-100002 NUT, M10 2 2 2 2 2
20 2 26796-100002 NUT, LOCK M10 2 2 2 2 2
21 2 41650-501120 STRAINER, FUEL OIL 2 2 2 2 2
22 3 41650-501140 FILTER, FUEL 2 2 2 2 2
24 4 41650-501160 O-RING 21X15 2 2 2 2 2
25 4 41650-501170 O-RING 2 2 2 2 2
27 3 41650-501150 BOLT 2 2 2 2 2
28 3 X0307160715 WASHER 2 2 2 2 2
29 3 X2772311701 RETAINER ASSY 2 2 2 2 2
30 3 123678-55880 PLUG, M14 2 2 2 2 2
31 3 22190-140002 WASHER, SEAL 14 2 2 2 2 2
32 3 123672-55750 PLUG, DRAIN M8 2 2 2 2 2
33 3 22190-080002 WASHER, SEAL 6 2 2 2 2 2
34 3 41650-501180 LABEL, CAUTION 2 2 2 2 2
34A 2 23311-060001 JOINT, 6 1 1 1 1 1 W
(A=*2004.06) (B=*2004.06) (D=*2004.06)
34B 2 23821-060001 NUT, CAP 6 1 1 1 1 1 W
(A=*2004.06) (B=*2004.06) (D=*2004.06)
35 1 148690-55200 SUPPORT 1 1 1 1 1
36 1 127612-55850 PAD 8 8 8 8 8
37 1 137600-71040 RETAINER 4 4 4 4 4
38 1 26106-100252 BOLT, M10X 25 PLATED 4 4 4 4 4
39 1 26106-100502 BOLT, M10X 50 PLATED 4 4 4
39-1 1 26106-100502 BOLT, M10X 50 PLATED 2 2 2 2 2 K
(A=*2005.03) (B=*2005.03) (D=*2005.03)
40 1 26366-100002 NUT, M10 4 4 4 4 4
41 1 26756-100002 NUT, LOCK M10 4 4 4 4 4
42 1 26216-100402 STUD, M10X 40 2 2 2 2 2 W
(A=*2005.03) (B=*2005.03) (D=*2005.03)

0CG10-M32503
Fig.86. OIL/WATER SEPARATOR (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148616-55902 SEPARATOR 2 2
2 2 127695-55760 ELEMENT 2 2
3 2 X0582980573 PACKING 4 4
4 2 X0307150415 SEAT, SPRING 8 8
5 2 X0602250122 SPRING 4 4
6 2 X2551045000 CASE 4 4
7 2 X0588080273 WASHER 4 4
8 2 X0313080110 BOLT 4 4
9 2 X0353101112 PLUG 2 2
10 2 X0588100773 GASKET 4 4
11 2 X0321101210 BOLT 4 4
12 2 X0588080273 WASHER 2 2
13 2 X0314080110 PLUG 2 2
14 2 X2551034100 BRACKET 2 2
15 1 148616-59430 BOLT, M14X26 4 4
16 1 148616-59330 JOINT, PIPE 15 M14 4 4
17 1 23414-140000 GASKET, 14X1.0 2 2
18 1 23414-140000 GASKET, 14X1.0 8 8
19 1 23887-140002 PLUG M14 2 2

0CG10-M32503
Fig.87. FUEL PIPE(PUMP IN) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148616-59050 PIPE ASSY, FUEL 1 1 1 1 1
4 1 23857-150000 BOLT, JOINT 15 1 1 1 1 1
5 1 23414-200000 GASKET, 20X1.0 2 2 2 2 2
6 1 148620-59250 JOINT, PIPE 1 1 1 1 1
7 1 23857-150000 BOLT, JOINT 15 1 1 1 1 1
8 1 23414-200000 GASKET, 20X1.0 2 2 2 2 2

0CG10-M32503
Fig.88. FUEL PIPE(INLET/OUTLET HOSE) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 128633-59240 PIPE, FUEL 2 2 2 2 2
2 1 43730-552121 CLIP,HOSE 4 4 4 4 4

0CG10-M32503
Fig.89. FUEL PIPE(PUMP-STRAINER)(SINGLE) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148616-59360 HOSE 1 1 1 Z 1
(A=*2007.04) (B=*2007.04) (D=*2007.04)
1A 1 148690-59280 HOSE, L=700 1 1 1 Z 2
(A=*2007.04) (B=*2007.04) (D=*2007.04)
1B 1 148690-59390 HOSE, L=700 1 1 1 1 1 W 3
(A=*2007.04) (B=*2007.04) (D=*2007.04)
2 1 148616-59340 JOINT, PIPE PF4 M20 2 2 2 2 2
3 1 23857-150000 BOLT, JOINT 15 2 2 2 2 2
4 1 23414-200000 GASKET, 20X1.0 4 4 4 4 4
5 1 126658-59050 PIPE,RUBBER 1 1 1 1
5-1 1 148690-59100 HOSE 1 1 1 N 1
(A=*2004.10) (B=*2004.10) (D=*2004.10)
5-2 1 148690-59100 HOSE 1 1 1 Z 1
(A=*2007.04) (B=*2007.04) (D=*2007.04)
5A 1 133615-59310 PIPE (L=500) 1 1 1 2
5A-1 1 148690-59290 PIPE (L=500) 1 1 1 N 2
(A=*2004.10) (B=*2004.10) (D=*2004.10)
5A-2 1 148690-59290 PIPE (L=500) 1 1 1 Z 2
(A=*2007.04) (B=*2007.04) (D=*2007.04)
5B 1 148690-59380 HOSE, L=500 1 1 1 1 1 W 3
(A=*2007.04) (B=*2007.04) (D=*2007.04)
6 1 148616-59340 JOINT, PIPE PF4 M20 2 2 2
6-1 1 148640-59050 JOINT, PIPE 2 2 2 2 2 N
(A=*2006.03) (B=*2006.03) (D=*2006.03)
7 1 23857-150000 BOLT, JOINT 15 2 2 2
7-1 1 148640-59040 BOLT, BALL JOINT M15 2 2 2 2 2 N
(A=*2006.03) (B=*2006.03) (D=*2006.03)
8 1 23414-200000 GASKET, 20X1.0 4 4 4 4 4
9 1 148620-59020 PIPE, FUEL 1 1 1 1 1
12 1 148620-59040 PIPE, FUEL 1 1 1 1 1
15 1 136686-59570 CLAMP 2 2 2 2 2
16 1 136686-59580 CLAMP 2 2 2 2 2
17 1 23414-200000 GASKET, 20X1.0 4 4 4 4 4
18 1 23414-200000 GASKET, 20X1.0 4 4 4 4 4
19 1 26106-100302 BOLT, M10X 30 PLATED 2 2 2 2 2
20 1 26366-100002 NUT, M10 2 2 2 2 2
21 1 43521-000231 BOLT 2 2 2 2 2
22 1 43521-000231 BOLT 2 2 2
(A=*2006.03) (B=*2006.03) (D=*2006.03)
Remarks
(1)JCI
(2)jg
(3)jg, JCI & EACH CLASSIFICATION
0CG10-M32503
Fig.90. FUEL PIPE(PUMP-STRAINER)(DUPLEX) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 126658-59050 PIPE,RUBBER 1 1 1 Z 1
(A=*2007.04) (B=*2007.04) (D=*2007.04)
1A 1 133615-59310 PIPE (L=500) 1 1 1 Z 2
(A=*2007.04) (B=*2007.04) (D=*2007.04)
1B 1 148690-59380 HOSE, L=500 1 1 1 1 1 W 3
(A=*2007.04) (B=*2007.04) (D=*2007.04)
2 1 148690-59100 HOSE 1 1 1 Z 1
(A=*2007.04) (B=*2007.04) (D=*2007.04)
2A 1 148690-59290 PIPE (L=500) 1 1 1 Z 2
(A=*2007.04) (B=*2007.04) (D=*2007.04)
2B 1 148690-59380 HOSE, L=500 1 1 1 1 1 W 3
(A=*2007.04) (B=*2007.04) (D=*2007.04)
3 1 23857-150000 BOLT, JOINT 15 2 2 2
(A=*2006.03) (B=*2006.03) (D=*2006.03)
4 1 148616-59340 JOINT, PIPE PF4 M20 2 2 2
4-1 1 148640-59050 JOINT, PIPE 2 2 2 2 2 N
(A=*2006.03) (B=*2006.03) (D=*2006.03)
5 1 148816-59320 UNION 1 1 1 1 1
6 1 148616-59340 JOINT, PIPE PF4 M20 1 1 1 1 1
7 1 23414-200000 GASKET, 20X1.0 2 2 2 2 2
8 1 23414-200000 GASKET, 20X1.0 1 1 1 1 1
9 1 23414-200000 GASKET, 20X1.0 4 4 4 4 4
10 1 23857-150000 BOLT, JOINT 15 1 1 1 1 1
11 1 148640-59080 PIPE, FUEL 1 1 1 1 1
16 1 148640-59090 PIPE, FUEL 1 1 1 1 1
19 1 43521-000231 BOLT 1 1 1 1 1
20 1 43521-000231 BOLT 2 2 2
(A=*2006.03) (B=*2006.03) (D=*2006.03)
21 1 148640-59060 UNION 1 1 1 1 1
22 1 23414-200000 GASKET, 20X1.0 3 3 3 3 3
23 1 23414-200000 GASKET, 20X1.0 4 4 4 4 4
Remarks
(1)JCI
(2)jg
(3)jg, JCI & EACH CLASSIFICATION
0CG10-M32503
Fig.91. FUEL INJECTION PIPE (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148690-59030 PIPE, INJECTION 1 1 1
1A 1 148690-59210 PIPE, INJECTION 1 1
6 1 148690-59040 PIPE, INJECTION 1 1 1
6A 1 148690-59220 PIPE, INJECTION 1 1
11 1 148690-59050 PIPE, INJECTION 1 1 1
11A 1 148690-59230 PIPE, INJECTION 1 1
16 1 148690-59060 PIPE, INJECTION 1 1 1
16A 1 148690-59240 PIPE, INJECTION 1 1
21 1 148690-59070 PIPE, INJECTION 1 1 1
21A 1 148690-59250 PIPE, INJECTION 1 1
26 1 148690-59080 PIPE, INJECTION 1 1 1
26A 1 148690-59260 PIPE, INJECTION 1 1
31 1 148690-59510 PIPE, INJECTION 1 1 1 1
31A 1 148665-59310 PIPE, INJECTION 1 1 1
43 1 148690-59520 PIPE, INJECTION 1 1 1 1
43A 1 148665-59320 PIPE, INJECTION 1 1 1
55 1 148690-59530 PIPE, INJECTION 1 1 1 1
55A 1 148665-59330 PIPE, INJECTION 1 1 1
67 1 148690-59540 PIPE, INJECTION 1 1 1 1
67A 1 148665-59340 PIPE, INJECTION 1 1 1
79 1 148690-59550 PIPE, INJECTION 1 1 1 1
79A 1 148665-59350 PIPE, INJECTION 1 1 1
91 1 148690-59560 PIPE, INJECTION 1 1 1 1
91A 1 148665-59360 PIPE, INJECTION 1 1 1
103 1 24341-000140 O-RING, 1AS14.0 6 6 6 6 6 1
104 1 24316-000220 O-RING, 4DP22.0 6 6 6 6 6 1
105 1 148620-59490 JOINT, PIPE 6 6 6 6 6
106 1 148620-59470 NUT, CAP 6 6 6
106-1 1 148620-59471 NUT, CAP 6 6 6 6 6 N
(A=*2004.06) (B=*2004.06) (D=*2004.06)
107 1 24316-000140 O-RING, 4DP14.0 6 6 6 6 6
108 1 148620-59440 GASKET 6 6 6
108-1 1 148620-59441 GASKET 6 6 6 N
(A=*2005.03) (B=*2005.03) (D=*2005.03)
108-2 1 148620-59442 GASKET 6 6 6 6 N
(A=*2006.11) (B=*2006.11) (D=*2006.11)
108-3 1 148961-59440 GASKET 6 6 6 6 6 N
(A=*2007.07) (B=*2007.07) (C=*2007.07) (D=*2007.07)
109 1 22190-200003 WASHER, SEAL 20 6 6 6 6 6
Remarks
(1)Covering pipe spec.
0CG10-M32503
Fig.92. SUPPORT(F.I.PIPE) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 152623-59560 SUPPORT 16 16 16 16 16
2 1 152672-59560 SUPPORT 16 16 16 16 16 1
3 1 152623-59990 PIPE,STEEL 4 4 4 4 4
4 1 26106-080302 BOLT, M8X 30 PLATED 8 8 8 8 8
5 1 22312-100200 PIN, PARALLEL M10X20 4 4 4 4 4 1
6 1 26106-080302 BOLT, M8X 30 PLATED 8 8 8 8 8 1
Remarks
(1)Covering pipe spec.
0CG10-M32503
Fig.93. FUEL OVERFLOW PIPE(F.I.VALVE) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-59910 PIPE 1 1 1 1 1
2 1 23857-060000 BOLT, JOINT 6 6 6 6 6 6
3 1 23414-120000 GASKET, 12X1.0 12 12 12 12 12
4 1 23297-100121 CLAMP, A10X12 6 6 6 6 6
5 1 148620-59951 PIPE 1 1 1 1 1
11 1 148620-59942 PIPE, FUEL 1 1 1 1 1
15 1 23857-060000 BOLT, JOINT 6 1 1 1 1 1
16 1 23414-120000 GASKET, 12X1.0 2 2 2 2 2
17 1 23297-080081 CLAMP, A8X 8 1 1 1 1 1
18 1 26106-080122 BOLT, M8X 12 PLATED 1 1 1 1 1

0CG10-M32503
Fig.94. FUEL PIPE(PUMP RETURN) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-59101 PIPE, FUEL 1 1 1 1 1 1
6 1 148620-59070 SUPPORT 1 1 1 1 1
7 1 26116-121252 BOLT, M12X125 PLATED 1 1 1 1 1
8 1 26106-100352 BOLT, M10X 35 PLATED 2 2 2 2 2
9 1 26366-100002 NUT, M10 2 2 2 2 2
10 1 135310-59930 PACKING, 14 2 2 2 2 2
11 1 148690-59110 PIPE, FUEL 1 1 1 1 1 2
Remarks
(1)jg
(2)JCI
0CG10-M32503
Fig.95. FUEL OVERFLOW PIPE(F.I.PUMP) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148690-59920 PIPE, FUEL 1 1 1 1 1
4 1 148620-59920 PIPE, FUEL 1 1 1 1 1
8 1 23857-060000 BOLT, JOINT 6 1 1 1 1 1
9 1 23414-120000 GASKET, 12X1.0 2 2 2 2 2
10 1 126683-59900 HOSE, L=650 1 1 1 1 1
11 1 23000-013000 CLAMP, 13 2 2 2 2 2
12 1 23821-060001 NUT, CAP 6 1 1 1 1 1
13 1 23311-060001 JOINT, 6 1 1 1 1 1
14 1 23297-060121 CLAMP, A6X12 2 2 2 2 2

0CG10-M32503
Fig.96. FUEL OVERFLOW PIPE(F.I.PUMP) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-59920 PIPE, FUEL 1 1 1 1 1
4 1 23857-060000 BOLT, JOINT 6 1 1 1 1 1
5 1 23414-120000 GASKET, 12X1.0 2 2 2 2 2
6 1 23297-060121 CLAMP, A6X12 2 2 2 2 2
7 1 23297-060121 CLAMP, A6X12 2 2 2 2 2
8 1 43711-097370 PIPE, FUEL 1 1 1 1
8-1 1 43711-097371 PIPE, FUEL 1 1 1 1 1 S 1
(A=*2008.04) (B=*2008.04) (C=*2008.04) (D=*2008.04)
Remarks
replacement with Fig.96 No.8-1,
Fig.97 No.14-1, and Fig.98 No.5-1.
0CG10-M32503
Fig.97. FUEL OVERFLOW PIPE(DOUBLE INJECTION PIPE) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148640-59930 PIPE, FUEL 1 1 1 1 1
5 1 23857-030000 BOLT, JOINT 3 6 6 6 6 6
6 1 23414-080000 GASKET, 8X1.0 12 12 12 12 12
7 1 23297-060121 CLAMP, A6X12 2 2 2 2 2
7-1 1 43730-014240 BRACKET 2 2 2 2 2 N
8 1 23414-120000 GASKET, 12X1.0 2 2 2 2 2 W
(D=FROM 1ST)
9 1 23414-160000 GASKET, 16X1.0 2 2 2 2 2 W
(D=FROM 1ST)
10 1 23857-060000 BOLT, JOINT 6 1 1 1 1 1 W
(D=FROM 1ST)
11 1 23857-100000 BOLT, JOINT 10 1 1 1 1 1 W
(D=FROM 1ST)
12 1 43711-098690 PIPE, FUEL 1 1 1 1
13 1 43711-097390 PIPE, FUEL 1 1 1 1 1 W
(D=FROM 1ST)
14 1 43711-097400 PIPE 1 1 1 1 W
(D=FROM 1ST)
14-1 1 43711-097401 PIPE 1 1 1 1 1 S 3
(A=*2008.04) (B=*2008.04) (C=*2008.04) (D=*2008.04)
15 1 43711-098090 PIPE, FUEL 1 1 1 2
16 1 23297-060121 CLAMP, A6X12 1 1 1 1 1 W
(A=FROM 1ST) (B=FROM 1ST) (C=FROM 1ST) (D=FROM 1ST)
17 1 23311-060001 JOINT, 6 1 1 1 1 1 W
18 1 23821-060001 NUT, CAP 6 1 1 1 1 1 W
19 1 43711-103600 PIPE 1 1 1 1 1 W
20 1 43711-103530 PIPE 1 1 W 2
(D=FROM 1ST)
21 1 43711-103610 PIPE 1 1 W 1
(D=FROM 1ST)
Remarks
(1)Motor solenoid spec.
(2)Electric magnet solenoid spec.
Fig.97 No.14-1, and Fig.98 No.5-1.
0CG10-M32503
Fig.98. FUEL OVERFLOW TANK (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 133615-09110 SPACER 1 1 1 1 1
2 1 126683-77250 SPACER 1 1 1 1 1
3 1 26106-100182 BOLT, M10X 18 PLATED 2 2 2 2 2
4 1 26106-100282 BOLT, M10X 28 PLATED 1 1 1 1 1
5 1 43230-027840 TANK 1 1 1 1
5-1 1 43230-027841 TANK 1 1 1 1 1 S 1
(A=*2008.04) (B=*2008.04) (C=*2008.04) (D=*2008.04)
5-2 1 43230-027842 TANK 1 1 1 1 1 N
(A=EZZZZZ) (B=EZZZZZ) (C=EZZZZZ) (D=EZZZZZ)
Remarks
Fig.97 No.14-1, and Fig.98 No.5-1.
0CG10-M32503
Fig.99. FUEL OVERFLOW ALARM (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 23414-080000 GASKET, 8X1.0 1 1 1 1 1
2 1 26206-080162 BOLT, M8X 16 PLATED 4 4 4 4 4
3 1 43230-014360 GASKET,FLOAT SWITCH 1 1 1 1 1
4 1 43230-014440 WASHER,FLOAT SWITCH 1 1 1 1 1
5 1 43230-027850 TANK 1 1 1 1 1
6 1 43590-006870 PLUG 1 1 1 1 1
7 1 46111-018771 FLOAT SWITCH 1 1 1 1 1

0CG10-M32503
Fig.100. SPEED RELAY (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 46111-045610 RELAY, SPEED 1
2 1 46111-045620 RELAY, SPEED 1
3 1 46111-045630 RELAY, SPEED 1
4 1 46111-045640 RELAY, SPEED 1
5 1 46111-045600 RELAY, SPEED 1 1 W
(B=EZZZZZ) (C=EZZZZZ)
6 1 46111-045960 RELAY, SPEED 1 W
(E=EZZZZZ)
7 1 46111-047970 RELAY, SPEED 1 W
(B=EZZZZZ)

0CG10-M32503
Fig.101. MAGNETICK PICK-UP (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 46150-026100 PICKUP, MAGNET 1 1 1
2 1 46150-049971 HARNESS,2-PIN CONNTR 1 1 1
3 1 23414-160000 GASKET, 16X1.0 1 1 1
4 1 45511-006890 NUT, 5/8-18UNF 1 1 1

0CG10-M32503
Fig.102. ENGINE STOP DEVICE(MOTOR SOLENOID)(JCI:WOODEN & FRP) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148690-65460 BRACKET 1 1 1 1 1
2 1 148660-59170 BOLT, M10 3 3 3 3 3
3 1 22137-100000 WASHER, 10 3 3 3 3 3
4 1 26106-100162 BOLT, M10X 16 PLATED 3 3 3 3 3
5 1 124411-67830 STOPPER ASSY 1 1 1 1 1 1
6 1 41411-001581 PAD 4 4 4 4 4
7 1 26366-060002 NUT, M6 8 8 8 8 8
8 1 126616-67300 LEVER 1 1 1 1 1
9 1 22522-030100 KEY, WOODRUFF 3X10 1 1 1 1 1
10 1 26106-060182 BOLT, M6X 18 PLATED 1 1 1 1 1
10-1 1 26106-060202 BOLT, M6X 20 PLATED 1 1 1 1 1 N
11 1 22217-060000 WASHER, SPRING 6 1 1 1 1 1
12 1 126650-66270 JOINT ASSY 1 1 1 1 1
16 1 126650-66260 PIN 1 1 1 1 1
17 1 22417-160100 COTTER PIN 1 1 1 1 1
18 1 46150-571360 SOLENOID 1 1 1 1 1 Z 2
19 1 42215-581470 BRACKET 1 1 1 1 1 Z 2
20 1 46150-571380 CAP, RUBBER 1 1 1 1 1 Z 2
21 1 148690-65500 ABSORBER 1 1 1 1 1 W
(A=*2004.05) (B=*2004.05) (D=*2004.05)
22 1 22137-060000 WASHER, 6 1 1 1 1 1 W
(A=*2005.09) (B=*2005.09) (D=*2005.09)
23 1 26756-060002 NUT, LOCK M6 8 8 8 8 8 W
(A=*2004.05) (B=*2004.05) (D=*2004.05)
24 1 29621-100000 BAND, TR100 2 2 2 2 2 W
(A=*2004.05) (B=*2004.05) (D=*2004.05)
Remarks
(1)Earth type
(2)Earth float type
0CG10-M32503
Fig.103. ENGINE STOP DEVICE(MOTOR SOLENOID)(JCI:STEEL & ALUMINUM) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-59170 BOLT, M10 3 3 3 3 3
2 1 148690-65460 BRACKET 1 1 1 1 1
3 1 148690-65500 ABSORBER 1 1 1 1 1
4 1 148690-65530 LINK ASSY 1 1 1 1 1
7 1 126650-66260 PIN 1 1 1 1 1
8 1 148690-66260 JOINT 1 1 1 1 1
9 1 126616-67300 LEVER 1 1 1 1 1
10 1 124411-67830 STOPPER ASSY 1 1 1 1 1
11 1 22137-060000 WASHER, 6 1 1 1 1 1
12 1 22137-080000 WASHER, 8 2 2 2 2 2
13 1 22137-080000 WASHER, 8 2 2 2 2 2
14 1 22137-100000 WASHER, 10 3 3 3 3 3
15 1 22217-060000 WASHER, SPRING 6 1 1 1 1 1
16 1 22417-160100 COTTER PIN 1 1 1 1 1
17 1 22417-200120 COTTER PIN 2.0X12 1 1 1 1 1
18 1 22486-080220 PIN, H 8X 22 1 1 1 1 1
19 1 22522-030100 KEY, WOODRUFF 3X10 1 1 1 1 1
20 1 26106-060182 BOLT, M6X 18 PLATED 1 1 1 1 1
21 1 26106-100162 BOLT, M10X 16 PLATED 3 3 3 3 3
22 1 26366-060002 NUT, M6 8 8 8 8 8
23 1 26716-080002 NUT, M8 2 2 2 2 2
24 1 26756-060002 NUT, LOCK M6 8 8 8 8 8
25 1 26756-080002 NUT, LOCK M8 2 2 2 2 2
26 1 29311-093000 GROMET, 8.5X3 2 2 2 2 2
27 1 29311-093000 GROMET, 8.5X3 1 1 1 1 1
28 1 29621-100000 BAND, TR100 2 2 2 2 2
29 1 41411-001581 PAD 4 4 4 4 4

0CG10-M32503
Fig.104. ENGINE STOP DEVICE(ELECTRIC MAGNET)(JG) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 46116-000680 SOLENOID VALVE,DC24V 1 1 1 1 1
2 1 148640-65010 LEVER, FUEL SHUT-OFF 1 1 1 1 1
3 1 22522-030100 KEY, WOODRUFF 3X10 1 1 1 1 1
4 1 26106-060202 BOLT, M6X 20 PLATED 1 1 1 1 1
5 1 148640-65050 LINK, FUEL CUT-OFF 1 1 1 1 1
6 1 130605-65260 PIN 1 1 1 1 1
7 1 148633-66590 PIN 1 1 1 1 1
8 1 22137-080000 WASHER, 8 2 2 2 2 2
9 1 22417-200160 PIN, COTTER 2.0X16 2 2 2 2 2
10 1 148640-65460 BRACKET 1 1 1 1 1
10-1 1 148640-65461 BRACKET 1 1 1 1 1 S
11 1 45521-010781 BOLT 1 1 1 1 1
12 1 26106-100252 BOLT, M10X 25 PLATED 1 1 1 1 1
13 1 26106-080122 BOLT, M8X 12 PLATED 1 1 1 1 1
14 1 148620-01490 BOLT 3 3 3 3 3
15 1 22137-100000 WASHER, 10 4 4 4 4 4
16 1 26366-100002 NUT, M10 3 3 3 3 3

0CG10-M32503
Fig.105. WIRE REMOTE CONTROL RECEIVER(GOVERNOR) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148690-86100 BRACKET 1 1 1 1
1-1 1 148690-86101 BRACKET 1 1 1 N 1
(A=*2005.05) (B=*2005.05) (D=*2005.05)
1-2 1 148690-86102 BRACKET 1 1 1 1 1 R 1
(A=*2006.03) (B=*2006.03) (D=*2006.03)
1A 1 148690-86151 BRACKET 1 1 1 1 1 2
2 1 148660-59170 BOLT, M10 3 3 3 3 3
3 1 22137-100000 WASHER, 10 3 3 3 3 3
4 1 26106-100202 BOLT, M10X 20 PLATED 3 3 3 3 3
5 1 41701-001720 BRACKET 1 1 1 1 1
6 1 26106-080182 BOLT, M8X 18 PLATED 1 1 1 1 1
6-1 1 26106-080202 BOLT, M8X 20 PLATED 1 1 1 1 1 N
7 1 26366-080002 NUT, M8 1 1 1 1 1
8 1 41710-000410 CLAMP 2 2 2 2 2
9 1 26116-050162 BOLT, M5X 16 PLATED 4 4 4 4 4
10 1 22212-050000 WASHER 5 4 4 4 4 4
11 1 26717-050002 NUT, M5 4 4 4 4 4
12 1 41710-001300 JOINT, BALL 1 1 1 1 1
Remarks
(1)Earth type
(2)Earth float type
0CG10-M32503
Fig.106. WIRE REMOTE CONTROL RECEIVER(CLUTCH) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 41710-004030 MOUNT,WIRE 1 1
2 1 41701-001720 BRACKET 1 1
3 1 41710-000410 CLAMP 1 1
4 1 41710-001300 JOINT, BALL 1 1
5 1 22212-050000 WASHER 5 2 2
6 1 26116-050162 BOLT, M5X 16 PLATED 2 2
7 1 26206-080162 BOLT, M8X 16 PLATED 1 1
8 1 26706-080002 NUT, M8 1 1
9 1 26717-050002 NUT, M5 2 2

0CG10-M32503
Fig.107. REMOTE CONTROL HEAD (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 41730-501200 HEAD ASSY. REMO-CON 1 1 1 1 1
2 1 41730-501250 HEAD, REMOTE-CONTROL 1 1 1 1 1
3 1 41730-500370 HEAD, REMOTE-CONTROL 1 1 1 1 1
4 1 46150-573490 BOX, SWITCH 1 1 1 1 1
5 1 27720-407001 CABLE, 100X 7000 2 2 2
5A 1 27720-410001 CABLE, 100X10000 2 2 2
5B 1 27720-412001 CABLE, 100X12000 2 2 2
5C 1 27720-414001 CABLE, 100X14000 2 2 2

0CG10-M32503
Fig.108. AIR MOTOR (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 133670-76510 GASKET 1 1 1 1 1
2 1 133670-76510 GASKET 1 1 1 1 1
3 1 22217-140000 WASHER, SPRING 14 3 3 3 3 3
4 1 23111-100007 ELBOW, R1 1 1 1 1 1
5 1 23111-120007 ELBOW, R1+1/4 1 1 1 1 1
6 1 23112-120007 ELBOW, R1+1/4 1 1 1 1 1
7 1 23163-100007 NIPPLE, R1 2 2 2 2 2
8 1 23163-120007 NIPPLE, R1+1/4 1 1 1 1 1
9 1 26292-140352 BOLT, M14X 35 3 3 3 3 3
10 1 26450-060202 BOLT, M6X 20 4 4 4 4 4
11 1 26450-060202 BOLT, M6X 20 4 4 4 4 4
12 1 43100-552880 SILENCER 1 1 1 1 1
12-1 1 43100-552881 SILENCER 1 1 1 1 1 N
13 1 44100-019900 OILER 1 1 1 1 1
14 2 44100-019930 GUIDE, OILER 1 1 1 1 1 1
15 2 44100-019940 O-RING, OILER 1 1 1 1 1 1
16 2 44100-019950 O-RING, OILER 1 1 1 1 1 1
17 1 44100-563330 FLANGE 1 1 1 1 1
18 1 44100-564340 FLANGE 1 1 1 1 1
19 1 44100-564130 MOTOR, AIR 1 1 1 1 1
20 1 148640-71010 SUPPORT 1 1 1 1 1
21 1 148640-71040 SOCKET 1 1 1 1 1
22 1 22137-100000 WASHER, 10 8 8 8 8 8
23 1 23034-030030 PIPE, 10AX 30 4 4 4 4 4
24 1 23414-330000 GASKET, 33X1.0 2 2 2 2 2
25 1 26106-100552 BOLT, M10X 55 PLATED 4 4 4 4 4
26 1 23112-100000 ELBOW, R1 1 1 1 1 1
Remarks
(1)Not illustrated.
0CG10-M32503
Fig.109. STARTING MOTOR(EARTH TYPE)(UP TO E0141) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-77020 STARTING MOTOR 1 1 1 1 1 Z 1
(A=E0142) (B=E0142) (C=E0142) (D=E0142) (E=E0142)
2 2 X131011700 YORK ASSY 1 1 1 1 1
3 2 X2240213618 BRACKET, REAR 1 1 1 1 1
5 2 X1331043309 HOLDER ASSY, BRUSH 1 1 1 1 1 2
6 3 X2660074006 BRUSH 1 1 1 1 1
7 4 X2660074007 BRUSH 4 4 4 4 4
8 3 X525003000 SPRING, BRUSH 4 4 4 4 4
9 2 X500010500 SCREW 2 2 2 2 2
10 2 X132011500 ARMATURE ASSY 1 1 1 1 1
11 3 X620600540 BALL BEARING 1 1 1 1 1
12 3 X620600520 BALL BEARING 1 1 1 1 1
13 2 X816707175 BOLT 2 2 2 2 2
14 2 X224502010 GEAR CASE 1 1 1 1 1
15 2 X503105700 SHIM 1 1 1 1 1
16 2 X244104100 SHAFT 1 1 1 1 1
17 2 X503105200 SHIM 1 1 1 1 1
18 2 X224406100 HOLDER, CENTER 1 1 1 1 1
19 2 X136106201 CLUTCH ASSY, PINION 1 1 1 1 1
20 2 X366101900 STOPPER 1 1 1 1 1
21 2 X522101000 RITEANER 2 2 2 2 2
22 2 X505804100 RING 1 1 1 1 1
23 2 X501027430 BOLT 1 1 1 1 1
24 2 X414129400 PACKING 1 1 1 1 1
25 2 X137204501 LEVER ASSY 1 1 1 1 1
26 2 X360017800 ROD 1 1 1 1 1
27 2 X422305600 HOLDER, LEVER 1 1 1 1 1
28 2 X520109300 COIL, SPRING 1 1 1 1 1
29 2 X2246043009 CASE ASSY, PINION 1 1 1 1 1
30 3 X2620096109 METAL 1 1 1 1 1
31 3 X340928900 COVER 1 1 1 1 1
32 2 X414004200 FELT 1 1 1 1 1
33 2 X1350129019 SWITCH, ENGAGE 1 1 1 1 1
34 3 X1359063006 COVER ASSY, TERMINAL 1 1 1 1 1
35 4 X1359051006 TERMINAL ASSY, NUT 1 1 1 1 1
36 3 X135903700 MOVING CONTACT ASSY 1 1 1 1 1
37 3 X135304821 CORE ASSY, MOVING 1 1 1 1 1
38 3 X641403220 O-RING 1 1 1 1 1
39 3 X520107500 COIL, SPRING 1 1 1 1 1
40 3 X501027300 BOLT 2 2 2 2 2
41 1 26292-140352 BOLT, M14X 35 3 3 3 3 3
42 1 22217-140000 WASHER, SPRING 14 3 3 3 3 3
43 1 41903-650040 CAP,TERMINAL RUBBER 1 1 1 1 1
44 1 148633-77540 WIRE 1 1 1
Remarks 44-1 1 148660-77541 WIRE 1 1 1 1 1 S
(1)Eearth type (A=E0128) (B=E0128) (D=E0128)
(2)Repair part
(3)Not illustrated. 45 1 26106-060102 BOLT, M6X 10 PLATED 2 2 2 2 2
*Parts of this figure are executed 45-1 1 26106-060122 BOLT, M6X 12 PLATED 2 2 2 2 2 S
to the following engine number. (A=EZZZZZ) (B=EZZZZZ) (C=EZZZZZ) (D=EZZZZZ) (E=EZZZZZ)
*E0141 46 1 148633-77090 STARTING RELAY 1 1 1 1 1
*Please refer to Fig.134(109A) since
47 1 148620-77500 CAP 1 1 1 1 1 3
abovementioned engine number.

0CG10-M32503
Fig.109. STARTING MOTOR(EARTH TYPE)(UP TO E0141) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
48 1 152633-78280 CAP,TERMINAL 1 1 1 1 1 3
Remarks
(1)Eearth type
(2)Repair part
(3)Not illustrated.
*Parts of this figure are executed
to the following engine number.
*E0141
*Please refer to Fig.134(109A) since
abovementioned engine number.

0CG10-M32503
Fig.134. (109A)STARTING MOTOR(EARTH TYPE)(FROM E0142) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148620-77080 MOTOR, STARTING 1 1 1 1 1 W
(A=E0142) (B=E0142) (C=E0142) (D=E0142) (E=E0142)
2 2 148620-77100 10-32UNF-2A 1 1 1 1 1
3 2 148620-77110 1/2-13UNC 1 1 1 1 1
4 1 148620-77500 CAP 1 1 1 1 1
5 1 152633-78280 CAP,TERMINAL ,TYPE C 2 2 2 2 2
6 1 22217-140000 WASHER, SPRING 14 3 3 3 3 3
7 1 26292-140352 BOLT, M14X 35 3 3 3 3 3
8 1 41903-650040 CAP, TERMINAL RUBBER 1 1 1 1 1
9 1 148633-77090 RELAY, STARTING 1 1 1 1 1
10 1 148660-77541 WIRE 1 1 1 1 1
11 1 26106-060122 BOLT, M6X 12 PLATED 2 2 2 2 2

0CG10-M32503
Fig.110. STARTING MOTOR(ERATH FLOAT TYPE)(UP TO E0141) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148633-77540 WIRE 1 1 1
1-1 1 148660-77541 WIRE 1 1 1 1 1 S
(A=E0128) (B=E0128) (D=E0128)
2 1 22217-140000 WASHER, SPRING 14 3 3 3 3 3
3 1 26106-060102 BOLT, M6X 10 PLATED 2 2 2 2 2
3-1 1 26106-060122 BOLT, M6X 12 PLATED 2 2 2 2 2 S
4 1 26292-140352 BOLT, M14X 35 3 3 3 3 3
5 1 41903-650040 CAP,TERMINAL RUBBER 1 1 1 1 1
6 1 46120-551450 RELAY, STARTER 1 1 1 1 1
7 1 148633-77530 WIRE 1 1 1 1 1 1
8 1 152923-77010 STARTER 1 1 1 1 1 2
9 2 X4041052000 IF BUSING 1 1 1 1 1
10 2 X5000083100 SCREW 4 4 4 4 4
11 2 X1316085000 FIELD COIL 1 1 1 1 1
12 2 X1330038009 BRACKET ASSY 1 1 1 1 1
13 3 X2240162000 BRACKET, REAR 1 1 1 1 1
14 3 X1331034009 HOLDER ASSY, BRUSH 1 1 1 1 1
15 4 X5250024000 SPRING, BRUSH 4 4 4 4 4
16 4 X4041060000 IF BUSING 1 1 1 1 1
17 3 X4030057000 WASHER 1 1 1 1 1
18 3 X2660056000 BRUSH 4 4 4 4 4
19 2 X1320063000 ARMATURE ASSY 1 1 1 1 1
20 3 X6206005200 BALL BEARING 1 1 1 1 1
21 3 X6206005500 BALL BEARING 1 1 1 1 1
22 2 X5010233300 BOLT 1 1 1 1 1
23 2 X5010233000 BOLT 1 1 1 1 1
24 2 X2245006000 HOUSING, GEARS 1 1 1 1 1
25 2 X2441006000 SHAFT 1 1 1 1 1
26 2 X5031011000 SHIM 1 1 1 1 1
27 2 X5031053000 SHIM 1 1 1 1 1
28 2 X5201086000 COIL, SPRING 1 1 1 1 1
29 2 X3000098000 R-PLATE 1 1 1 1 1
30 2 X3000099000 R-PLATE 1 1 1 1 1
31 2 X2244055210 BRACKET 1 1 1 1 1
33 2 X6414029900 O-RING 1 1 1 1 1
34 2 X1372036000 LEVER ASSY 1 1 1 1 1
35 2 X5010239000 BOLT 1 1 1 1 1
36 2 X3051023000 LOCK PLATE 1 1 1 1 1
37 2 X1361035000 CLUTCH ASSY, PINION 1 1 1 1 1
38 2 X3661020000 PINION, STOPPER 1 1 1 1 1
39 2 X5221012000 RITEANER 2 2 2 2 2
40 2 X5058042000 RING 1 1 1 1 1
41 2 X2046113009 HOUSING ASSY, PINION 1 1 1 1 1
43 3 X4101073000 CAP 1 1 1 1 1
44 2 X5010233400 BOLT 3 3 3 3 3
45 2 X1350091019 SWITCH, ENGAGE 1 1 1 1 1
46 2 X5010190200 BOLT 2 2 2 2 2
47 2 X3001116000 D-PLATE 1 1 1 1 1
48 2 X1338021009 CLAMP ASSY 1 1 1 1 1
Remarks
(1)Not illustrated. 49 2 X2425133009 BAR ASSY 1 1 1 1 1
(2)jg
0CG10-M32503
Fig.110. STARTING MOTOR(ERATH FLOAT TYPE)(UP TO E0141) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
50 2 X4101059000 CAP 1 1 1 1 1
51 2 X4101030000 CAP 1 1 1 1 1
52 2 X5010187000 BOLT 1 1 1 1 1
53 2 X5022006000 NUT 1 1 1 1 1
54 2 X5030021000 WASHER 3 3 3 3 3
55 2 X4030055000 I-WASHER 1 1 1 1 1
56 2 X4101006000 CAP 1 1 1 1 1 1
57 2 X4101007000 CAP 2 2 2 2 2 1
58 1 148660-77100 MOTOR, STARTING 1 1 1 1 1 1
Remarks
(1)Not illustrated.
(2)jg
0CG10-M32503
Fig.135. (110A)STARTING MOTOR(EARTH FLOAT TYPE)(FROM E0142) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-77080 MOTOR, STARTING 1 1 1 1 1 W
(A=E0142) (B=E0142) (C=E0142) (D=E0142) (E=E0142)
1A 1 148660-77080-A MOTOR, STARTING 1 1 1 1 1 W 1
(A=E0142) (B=E0142) (C=E0142) (D=E0142) (E=E0142)
2 2 X131015520X0 YOKE ASSY 1 1 1 1 1
3 2 X133107510X0 HOLDER ASSY, BRUSH 1 1 1 1 1
4 2 X224033900X0 BRACKET, REAR 1 1 1 1 1
5 2 X525003200X0 SPRING, BRUSH 4 4 4 4 4
6 2 X266010620X0 BRUSH 4 4 4 4 4
7 2 X404006510X0 EYE BUSHING 1 1 1 1 1
8 2 X404006410X0 EYE BUSHING 1 1 1 1 1
9 2 X132014210X0 ARMATURE 1 1 1 1 1
10 2 X620605500X0 BALL BEARING 1 1 1 1 1
11 2 X342904500X0 COVER 1 1 1 1 1
12 2 X414133200X0 PACKING 1 1 1 1 1
13 2 X365003300X0 GEAR, INTERNAL 1 1 1 1 1
14 2 X137100020X0 GEAR ASSY, PLANETARY 1 1 1 1 1
15 2 X503107600X0 SHIM WASHER 1 1 1 1 1
16 2 X137300010X0 SHAFT ASSY 1 1 1 1 1
17 2 X625600100X0 STEEL BALL 1 1 1 1 1
18 2 X134200420X0 BRACKET ASSY, CENTER 1 1 1 1 1
19 2 X360027810X0 ROD 1 1 1 1 1
20 2 X323205410X0 LEVER 1 1 1 1 1
21 2 X136107400X0 CLUTCH ASSY, PINION 1 1 1 1 1
22 2 X641407200X0 DUST SEAL 1 1 1 1 1
23 2 X366102710X0 STOPPER, PINION 1 1 1 1 1
24 2 X522102910X0 HOOK 1 1 1 1 1
25 2 X134100200X0 CASE ASSY, PINION 1 1 1 1 1
26 2 X620605400X0 NEEDLE BEARING 1 1 1 1 1
27 2 X641407410X0 O-RING 2 2 2 2 2
28 2 X135017810X9 SWITCH ASSY, ENGAGE 1 1 1 1 1
29 2 X135913300X0 TERMINAL ASSY 1 1 1 1 1
30 2 148620-77100 10-32UNF-2A 1 1 1 1 1
31 2 148620-77110 1/2-13UNC 1 1 1 1 1
32 1 148633-77530 WIRE 1 1 1 1 1
33 1 148660-77541 WIRE 1 1 1 1 1
34 1 22217-140000 WASHER, SPRING 14 3 3 3 3 3
35 1 26106-060122 BOLT, M6X 12 PLATED 2 2 2 2 2
36 1 26292-140352 BOLT, M14X 35 3 3 3 3 3
37 1 41903-650040 CAP, TERMINAL RUBBER 1 1 1 1 1
38 1 46120-551450 RELAY, STARTER 1 1 1 1 1
Remarks
(1)jg
0CG10-M32503
Fig.111. GENERATOR (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 128610-77200 ALTERNATOR, 24V-1KW 1 1 1 1 1 1
2 1 144626-77201 ALTERNATOR 1 1 1 2
3 1 148660-77300 ADJUSTER 1 1 1 1 1
4 1 26116-141502 BOLT, M14X150 PLATED 1 1 1 1 1 1
5 1 26116-121202 BOLT, M12X120 PLATED 1 1 1 2
6 1 26706-140002 NUT, M14 1 1 1 1 1 1
7 1 26706-120002 NUT, M12 1 1 1 2
8 1 22217-140000 WASHER, SPRING 14 1 1 1 1 1 1
9 1 22217-120000 WASHER, SPRING 12 1 1 1 2
10 1 26156-100404 BOLT, M10X 40 PLATED 1 1 1 1 1
11 1 26606-100002 NUT, M10 1 1 1 1 1
12 1 26106-100252 BOLT, M10X 25 PLATED 1 1 1 1 1
13 1 148660-77350 SPACER 1 1 1 1 1 1
14 1 25132-002800 V-BELT, A28 2 2 2 2 2 1
14A 1 25132-002800 V-BELT, A28 1 1 1 2
15 1 148660-77330 COVER, BELT 1 1 1
15-1 1 148660-77331 COVER, BELT 1 1 1 1 1 R
(A=*2004.09) (B=*2004.09) (D=*2004.09)
15-2 1 148660-77332 COVER, BELT 1 1 1 1 1 S
15A 2 29311-124000 GROMET, 12.0X4 4 4 4 4 4 W
16 1 26106-100252 BOLT, M10X 25 PLATED 4 4 4
16-1 1 26216-100302 STUD, M10X 30 4 4 4 4 4 S
(A=*2004.06) (B=*2004.06) (D=*2004.06)
16-2 1 26216-100302 STUD, M10X 30 4 4 4 4 4 Z
17 1 748660-77200 DRIVE ASSY 1 1 1 1 1
18 2 145613-77420 WASHER 2 2 2 2 2
19 2 148660-77230 SPACER 1 1 1 1 1
20 2 148633-77410 V-PULLEY 1 1 1 1 1
21 2 148660-77210 SHAFT 1 1 1 1 1
22 2 148660-77220 CASE, BEARING 1 1 1 1 1
23 2 136600-42480 OIL SEAL TC304508 1 1 1 1 1
24 2 22252-000520 RING, 52 1 1 1 1 1
25 2 22512-070140 KEY, 7X 14 2 2 2 2 2
26 2 24101-062054 BEARING, BALL 6205 2 2 2 2 2
27 2 26776-200002 NUT, LOCK M20 2 2 2 2 2
28 2 148633-43700 GEAR, PUMP 1 1 1 1 1
29 1 26106-100302 BOLT, M10X 30 PLATED 5 5 5 5 5
30 1 148806-01841 PACKING, COVER 1 1 1 1 1
31 1 26706-100002 NUT, M10 4 4 4 4 4 W
(A=*2004.06) (B=*2004.06) (D=*2004.06)
31-1 1 26706-100002 NUT, M10 4 4 4 4 4 Z
32 1 26796-100002 NUT, LOCK M10 4 4 4 4 4 W
(A=*2004.06) (B=*2004.06) (D=*2004.06)
32-1 1 26796-100002 NUT, LOCK M10 4 4 4 4 4 Z
33 1 148806-01830 COVER 1 1 1 1 1 W
Remarks
(A=*2004.05) (B=*2004.05) (D=*2004.05)
(1)1kw spec.
(2)600w spec.
0CG10-M32503
Fig.111. GENERATOR (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
34 1 148806-01841 PACKING, COVER 1 1 1 1 1 W
(A=*2004.05) (B=*2004.05) (D=*2004.05)
35 1 26106-100202 BOLT, M10X 20 PLATED 5 5 5 5 5 W
(A=*2004.05) (B=*2004.05) (D=*2004.05)
36 1 22137-100000 WASHER, 10 8 8 8 8 8 W
37 1 26216-100752 STUD, M10X 75 2 2 2 2 2 W
38 1 26216-101102 STUD, M10X110 2 2 2 2 2 W
39 1 26366-100002 NUT, M10 4 4 4 4 4 W
40 1 26756-100002 NUT, LOCK M10 4 4 4 4 4 W
41 1 43711-572540 SPACER, 10AXL45 2 2 2 2 2 W
42 1 43711-572570 SPACER, 10AXL80 2 2 2 2 2 W
Remarks
(1)1kw spec.
(2)600w spec.
0CG10-M32503
Fig.112. GENERATOR COMPONENT PART(1KW) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 128610-77200 ALTERNATOR, 24V-1KW 1 1 1 1 1
2 2 X121114620 STATER ASSY 1 1 1 1 1
3 2 X224016730 BRACKET 1 1 1 1 1
4 2 X123504200 HEAT SINK ASSY 1 1 1 1 1
4-1 2 X123517100X7 HEAT SINK ASSY 1 1 1 1 1 F 1
5 2 X123504300 HEAT SINK ASSY 1 1 1 1 1
5-1 2 X123517220X9 HEAT SINK ASSY 1 1 1 1 1 F 1
6 2 X501019900 BOLT 4 4 4 4 4
7 2 X404105600 IF BUSHING 5 5 5 5 5
8 2 X403000100 I-WASHER 4 4 4 4 4
9 2 X404100200 IF BUSHING 4 4 4 4 4
10 2 X404100900 IF BUSHING 1 1 1 1 1
11 2 X190602610 CONDENSER ASSY 1 1 1 1 1
12 2 X421500800 INSULATOR 1 1 1 1 1
13 2 X123903600 CONNECTOR 1 1 1 1 1
14 2 X123902580 LAMP, CHARGING 1 1 1 1 1
15 2 X322027600 SUPPORT 1 1 1 1 1
16 2 X620600200 BALL BEARING 1 1 1 1 1
17 2 X322123200 COVER 1 1 1 1 1
18 2 X125100030 COIL ASSY 1 1 1 1 1
19 2 X1221074000 ROTATOR ASSY 1 1 1 1 1
20 2 X224205920 BRACKET 1 1 1 1 1
21 2 X620600320 BALL BEARING 1 1 1 1 1
22 2 X340914700 COVER 1 1 1 1 1
23 2 X414000810 FELT 2 2 2 2 2
24 2 X220201011 COVER 1 1 1 1 1
25 2 X414200900 O-RING 1 1 1 1 1
26 2 X340901320 COVER 1 1 1 1 1
27 2 X501021500 BOLT 3 3 3 3 3
28 2 X859050719 KEY 1 1 1 1 1
29 2 X300007810 D-PLATE 1 1 1 1 1
30 2 X8264183005 NUT 1 1 1 1 1
31 2 X198011201 PULLEY ASSY 1 1 1 1 1
32 2 X501004740 BOLT 3 3 3 3 3
33 2 X129100300 REGULATOR 1 1 1 1 1
34 2 X410100800 CAP 4 4 4 4 4
Remarks
(1)Interchangeable by simultaneous replacement with No.4-1,5-1.
0CG10-M32503
Fig.113. GENERATOR COMPONENT PART(600W) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 144626-77201 ALTERNATOR 1 1 1
2 2 X121100320 STATOR ASSY 1 1 1
3 2 X123015301 BRACKET ASSY,REAR 1 1 1
4 3 X224015400 BRACKET,REAR 1 1 1
5 3 X123500010 HEAT SINK ASSY 1 1 1 Z
6 3 X123500110 HEAT SINK ASSY 1 1 1 Z
6A 3 X123517000X9 HEAT SINK ASSY 1 1 1 W 1
7 3 X123902560 CIRCUIT ASSY 1 1 1
8 3 X190602900 CONDENSER ASSY 1 1 1
9 3 X322031600 HOLDER 1 1 1
10 3 X8160050509 BOLT 1 1 1
11 3 X322002300 SUPPORT 1 1 1
12 3 X8160050409 BOLT 2 2 2
13 3 X322027600 SUPPORT 1 1 1
14 3 X421500800 INSULATOR 1 1 1
15 3 X501021000 BOLT 1 1 1
16 3 X421500400 INSULATOR 3 3 3
17 3 X404100200 IF BUSHING 4 4 4
18 3 X404100800 IF BUSHING 5 5 5
19 3 X403000100 I-WASHER 6 6 6
20 2 X123104800 BRUSH HOLDER ASSY 1 1 1
21 3 X266000110 BRUSH 2 2 2
22 3 X521000110 SPRING, BRUSH 2 2 2
23 2 X122105800 ROTOR ASSY 1 1 1
24 2 X620600760 BALL BEARING 1 1 1
25 2 X340900210 COVER 1 1 1
26 2 X124006301 BRACKET ASSY,FRONT 1 1 1
27 3 X224206901 BRACKET, FRONT 1 1 1
28 3 X620600710 BALL BEARING 1 1 1
29 3 X340100410 COVER, BEARING 1 1 1
30 3 X340900500 COVER 1 1 1
31 3 X340900400 COVER 1 1 1
32 3 X414000000 FELT 1 1 1
33 2 X501016110 BOLT 3 3 3
34 2 X8590407160 KEY 1 1 1
35 2 X8264143005 NUT 1 1 1
36 2 X198010300 PULLEY ASSY 1 1 1
37 2 X129100300 REGULATOR 1 1 1
38 2 X340005110 COVER 1 1 1
39 2 X410100810 CAP 4 4 4
40 2 X8160100305 BOLT 1 1 1
Remarks
(1)Interchangeable by simultaneous replacement with No.5,6.
0CG10-M32503
Fig.114. WIRE HARNESS (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-77571 HARNESS, WIRE 1 1 1 1 1
2 1 148660-77581 HARNESS, WIRE 1 1 1 1 1
3 1 194180-51640 CLAMP, HARNESS 1 1 1 1 1
4 1 23297-150121 CLAMP, A15X12 1 1 1 1 1
5 1 23297-180121 CLAMP, A18X12 1 1 1 1 1
6 1 23297-200121 CLAMP, A20X12 1 1 1 1 1

0CG10-M32503
Fig.115. SUB-HARNESS & NEUTRAL SWITCH (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148690-77700 HARNESS, WIRE 1 1 1 1 1
2 1 124617-91860 RELAY 1 1 1 1 1
3 1 120270-77101 SWITCH, SAFETY 1 1 1
3-1 1 120270-77102 SWITCH, SAFETY 1 1 N 1
(A=*2007.11) (D=*2007.11)
4 1 194180-51640 CLAMP, HARNESS 1 1 1
5 1 46150-571100 HARNESS, WIRE 1 1 1
6 1 46150-571090 HARNESS, WIRE 1 1 1
7 1 126617-77500 HARNESS, WIRE 1 1 1 2
8 1 129574-77700 HARNESS, WIRE 3M 1 1 1 1 1
9 1 129574-77710 HARNESS, WIRE 4M 1 1 1 1 1
10 1 129574-77720 HARNESS, WIRE 6M 1 1 1 1 1
11 1 46150-570800 HARNESS, WIRE 1 1 1 1 1
Remarks
(1)w/ start in gear protection
(2)w/o start in gear protection
0CG10-M32503
Fig.116. SENSOR(EARTH TYPE) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 121250-39450 SWITCH, 1.0KG 1 1 1 1 1
2 1 123482-39670 DAMPER 1 1 1 1 1
3 1 124411-91160 SENSOR 1 1 1 1 1
4 1 127610-91221 SWITCH, FLOAT 1 1 1 1 1
5 1 127610-91350 SWITCH, 95 1 1 1 1 1
6 1 126684-91410 SENSOR 2 2 2 2 2
7 1 126438-91501 JOINT,HYD.RUBBER 2 2 2 2 2
11 2 126438-91541 WIRE, EARTH 2 2 2 2 2
12 2 22217-040000 WASHER, SPRING 4 4 4 4 4 4
13 2 26557-040062 SCREW, M4X 6 4 4 4 4 4
14 1 144626-91570 SENDER UNIT 1 1 1 1 1
14A 1 129574-91570 SENSOR 1 1 1 1 1 1
15 1 144626-91820 SPACER 2 2 2 2 2
16 1 22190-360002 WASHER, SEAL 36 1 1 1 1 1
17 1 46150-552450 SWITCH 1 1 1 1 1
18 1 23414-120000 GASKET, 12X1.0 2 2 2 2 2
19 1 124060-39451 SWITCH, 0.2KG 1 1 1 2
20 1 123482-39660 DAMPER 1 1 1 2
24 1 124060-39451 SWITCH, 0.2KG 1 1 1 1 3
25 1 123482-39680 DAMPER 1 1 1 1 3
26 1 23112-010007 ELBOW, R1/8 1 1 1 1 1 W
Remarks
(1)2-panel spec.
(2)For MGN99L,MGA99L
(3)For YX(2)-240
0CG10-M32503
Fig.117. SENSOR(EARTH FLOAT TYPE) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 123482-39670 DAMPER 1 1 1 1 1
2 1 124411-91160 SENSOR 1 1 1 1 1
3 1 148633-91230 SWITCH 1 1 1 1 1
4 2 127610-77720 PROTECTOR 1 1 1 1 1
5 2 123682-77740 PROTECTOR 1 1 1 1 1
6 2 123672-91220 SWITCH, FLOAT 1 1 1 1 1
7 2 127610-91850 PLUG 1 1 1 1 1
8 2 127610-91860 SPACER 1 1 1 1 1
9 2 22190-160003 WASHER, SEAL 16 1 1 1 1 1
10 2 23414-100014 GASKET, 10X1.0 1 1 1 1 1
11 1 126630-91350 SWITCH, THERMO 1 1 1 1 1
12 1 126684-91410 SENSOR 2 2 2 2 2
13 1 126684-91502 JOINT, RUBBER 2 2 2 2 2
14 1 126630-91570 SENDER UNIT 1 1 1 1 1
15 1 126630-91581 SWITCH, PRESSURE 1 1 1 1 1
16 1 144626-91820 SPACER 2 2 2 2 2
17 1 22190-360002 WASHER, SEAL 36 1 1 1 1 1
18 1 46150-504710 SWITCH, THERMO 1 1 1 1 1
19 1 23414-120000 GASKET, 12X1.0 2 2 2 2 2
20 1 126630-91570 SENDER UNIT 2 2 2 2 2 1
21 1 43570-023440 BUSH 1 1 1 1 1 1
22 1 46150-571270 HARNESS, WIRE 1 1 1 1 1 1
23 1 126630-91591 SWITCH,OIL PRESSURE 1 1 1 2
24 1 123482-39660 DAMPER 1 1 1 2
28 1 126630-91591 SWITCH,OIL PRESSURE 1 1 1 1 3
29 1 123482-39680 DAMPER 1 1 1 1 3
30 1 23112-010007 ELBOW, R1/8 1 1 1 1 1 W
Remarks
(1)2-panel spec.
(3)For YX(2)-240
0CG10-M32503
Fig.118. BATTERY SWITCH (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 22137-100000 WASHER, 10 1 1 1 1 1
2 1 22217-100000 WASHER, SPRING 10 1 1 1 1 1
3 1 22724-800380 SCREW, 8.0X38 4 4 4 4 4
4 1 26106-100202 BOLT, M10X 20 PLATED 1 1 1 1 1
5 1 29110-080010 TERMINAL, 80.0-10 2 2 2 2 2
6 1 29110-150010 TERMINAL, 150.0-10 1 1 1 1 1
7 1 29110-150012 TERMINAL, 150.0-12 2 2 2 2 2
8 1 46120-000950 SWITCH 1 1 1 1 1

0CG10-M32503
Fig.119. AIR HEATER DEPENDENCE (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 194180-51640 CLAMP, HARNESS 1 1 1 1 1
2 1 128634-77530 RELAY, GROW 1 1 1 1 1
2-1 1 128634-77531 RELAY, GLOW 1 1 1 1 1 N
3 1 148660-77640 HARNESS, WIRE 1 1 1 1 1
4 1 148660-77650 WIRE 1 1 1 1 1
5 1 148660-77660 WIRE 1 1 1 1 1
6 1 148660-77670 WIRE 1 1 1 1 1 1
7 1 126683-77700 CONTROLLER 1 1 1 1 1
8 1 148660-77900 BRACKET 1 1 1 1 1
9 1 26106-060122 BOLT, M6X 12 PLATED 2 2 2 2 2
10 1 26106-080352 BOLT, M8X 35 PLATED 2 2 2 2 2
11 1 26366-060002 NUT, M6 4 4 4 4 4
12 1 26366-060002 NUT, M6 2 2 2 2 2
13 1 26756-060002 NUT, LOCK M6 4 4 4 4 4
14 1 41411-001581 PAD 2 2 2 2 2
15 1 148660-77680 WIRE 1 1 1 1 1 2
16 1 29621-100000 BAND, TR100 2 2 2 2 2 2
Remarks
(1)Earth type
(2)Earth float type
0CG10-M32503
Fig.120. ELECTORIC TROLLING CONTROL BOX (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 185700-00201 CONTROLLER ASSY 1 1 1 1
2 1 177503-04311 DIAL, TROLLING 1 1 1 1
3 2 177503-04390 CAP 1 1 1 1
4 2 177503-04400 COVER ASSY 1 1 1 1
5 1 177561-04630 HARNESS, WIRE 1 1 1 1
6 1 177561-04850 BOX ASSY, CONTROLLER 1 1 1 1
7 2 177561-04860 COVER 1 1 1 1
8 2 175046-05550 PLATE 2 2 2 2
9 2 104507-07190 LABEL, YANMAR 1 1 1 1
10 2 126684-07660 LABEL 1 1 1 1
11 2 105430-67110 CLAMP, CORD 2 2 2 2
12 2 126684-77201 BRACKET 1 1 1 1
13 2 126684-77210 PLATE 1 1 1 1
14 2 126684-77220 COVER 1 1 1 1
17 2 126684-77240 BRACKET 1 1 1 1
18 2 26106-080122 BOLT, M8X 12 PLATED 5 5 5 5
19 2 26106-080122 BOLT, M8X 12 PLATED 2 2 2 2
20 2 26106-080122 BOLT, M8X 12 PLATED 3 3 3 3
21 2 26366-060002 NUT, M6 4 4 4 4
22 2 26366-060002 NUT, M6 8 8 8 8
23 2 26366-080002 NUT, M8 2 2 2 2
24 2 26366-080002 NUT, M8 3 3 3 3
25 2 26756-060002 NUT, LOCK M6 4 4 4 4
26 2 26756-060002 NUT, LOCK M6 8 8 8 8 Z
27 2 41411-001581 PAD 4 4 4 4

0CG10-M32503
Fig.121. CLUTCH ATTACHED BOLT (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 26206-120302 BOLT, M12X 30 PLATED 16 16 16 16 16
2 1 22117-120000 WASHER, 12 16 16 16 16 16
3 1 22312-100250 PIN, PARALLEL M10X25 1 1 1 1 1
4 1 26116-120352 BOLT, M12X 35 PLATED 16 16 1
5 1 22217-120000 WASHER, SPRING 12 16 16 1
6 1 26236-160402 STUD, M16X 40 6 6 1
7 1 26736-160002 NUT, M16 6 6 1
8 1 26776-160002 NUT, LOCK M16 6 6 1
Remarks
0CG10-M32503
Fig.122. INSTRUMENT PANEL (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148018-91211 PANEL ASSY 1 1 1 1 1
2 2 148018-91201 METER, TACHO./HOUR 1 1 1 1 1
3 2 129574-91870 HARNESS, WIRE 4 4 4 4 4
4 2 127620-91660 BULB, 24V-1.5W 7 7 7 7 7
5 2 127692-91210 METER 1 1 1 1 1
6 2 126684-91301 METER, BOOST 1 1 1 1 1
7 2 129170-91810 COVER 1 1 1 1 1
8 2 119189-91260 BOX, PANEL 1 1 1 1 1
9 2 127692-91860 HARNESS, WIRE 1 1 1 1 1
10 2 129574-91240 CLOCK 1 1 1 1 1
11 2 127620-91250 CELL 1 1 1 1 1
12 2 129574-91490 HOLDER 1 1 1 1 1
13 2 129574-91880 HARNESS, WIRE 1 1 1 1 1
14 2 127687-91760 BULB, 24V-1.5W T5 1 1 1 1 1
15 2 129574-91410 BRACKET, SWITCH 1 1 1 1 1
16 2 121575-91250 SWITCH, KEY 1 1 1 1 1
17 2 123482-91291 KEY 1 1 1 1 1
18 2 127692-91350 BUZZER 1 1 1 1 1
19 2 129574-91800 SWITCH ASSY 1 1 1 1 1
20 2 129574-91780 CAP, RUBBER 2 2 2 2 2
21 2 129574-91790 SWITCH 1 1 1 1 1
22 2 127692-91270 CIRCUIT, ALARM 1 1 1 1 1
23 2 129470-91190 SWITCH, STOP 1 1 1 1 1
24 2 129574-91930 PANEL 1 1 1 1 1
25 2 129574-91620 BEZEL 1 1 1 1 1
26 2 129574-91420 BRACKET 1 1 1 1 1
27 2 129574-91720 GASKET 1 1 1 1 1
28 2 129574-91630 BEZEL 4 4 4 4 4
29 2 129574-91430 BRACKET 4 4 4 4 4
30 2 129574-91730 GASKET 4 4 4 4 4
31 2 129574-91640 BEZEL 1 1 1 1 1
32 2 129574-91440 BRACKET 1 1 1 1 1
33 2 129574-91740 GASKET 1 1 1 1 1
34 2 129170-91610 BEZEL 1 1 1 1 1
35 2 129574-91710 GASKET 1 1 1 1 1
36 2 129574-91750 GASKET 1 1 1 1 1
37 2 129574-91770 KNOB 2 2 2 2 2
38 2 129574-91600 COVER 1 1 1 1 1
39 2 129574-91650 BEZEL 1 1 1 1 1
40 2 127692-91410 SCREW 27 27 27 27 27
41 2 127692-91440 SCREW 4 4 4 4 4
42 2 127692-91450 SCREW 2 2 2 2 2
43 2 X55109575A0 HARNESS, WIRE 1 1 1 1 1
44 3 46150-003620 FUSE 1 1 1 1 1
45 2 127687-91880 WASHER 6 6 6 6 6
46 2 127687-91870 BOLT, M6X35 6 6 6 6 6
47 2 126684-91321 METER, LUB.OIL PRES. 1 1 1 1 1
48 2 129574-91890 HARNESS, WIRE 1 1 1 1 1
49 2 126684-91330 BOX, CONTROL 1 1 1 1 1
50 2 126684-91340 CONTROLL BOX,LUB.OIL 1 1 1 1 1
51 2 126684-91350 BRACKET 1 1 1 1 1

0CG10-M32503
Fig.122. INSTRUMENT PANEL (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
52 2 126684-91360 COVER 1 1 1 1 1
53 2 126684-91370 SCREW, 6X12 4 4 4 4 4
54 2 126684-91380 HARNESS, WIRE 1 1 1 1 1
55 2 126684-91390 HARNESS, WIRE 1 1 1 1 1

0CG10-M32503
Fig.123. SUB-PANEL (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148634-91211 PANEL ASSY 1 1 1 1 1
2 2 148018-91201 METER, TACHO./HOUR 1 1 1 1 1
3 2 127692-91210 METER 1 1 1 1 1
4 2 126684-91321 METER, LUB.OIL PRES. 1 1 1 1 1
5 2 119189-91260 BOX, PANEL 1 1 1 1 1
6 2 129574-91240 CLOCK 1 1 1 1 1
7 2 129574-91620 BEZEL 1 1 1 1 1
8 2 129574-91420 BRACKET 1 1 1 1 1
9 2 129574-91720 GASKET 1 1 1 1 1
10 2 129574-91630 BEZEL 2 2 2 2 2
11 2 129574-91430 BRACKET 2 2 2 2 2
12 2 129574-91730 GASKET 2 2 2 2 2
13 2 129574-91640 BEZEL 1 1 1 1 1
14 2 129574-91440 BRACKET 1 1 1 1 1
15 2 129574-91740 GASKET 1 1 1 1 1
16 2 129170-91610 BEZEL 1 1 1 1 1
17 2 129574-91710 GASKET 1 1 1 1 1
18 2 129574-91750 GASKET 1 1 1 1 1
19 2 129574-91770 KNOB 2 2 2 2 2
20 2 129574-91650 BEZEL 1 1 1 1 1
21 2 127692-91270 CIRCUIT, ALARM 1 1 1 1 1
22 2 127692-91410 SCREW 19 19 19 19 19
23 2 127692-91440 SCREW 4 4 4 4 4
24 2 127692-91450 SCREW 2 2 2 2 2
25 2 127692-91860 HARNESS, WIRE 1 1 1 1 1
26 2 127620-91660 BULB, 24V-1.5W 7 7 7 7 7
27 2 129574-91890 HARNESS, WIRE 1 1 1 1 1
28 2 129574-91870 HARNESS, WIRE 3 3 3 3 3
29 2 127620-91660 BULB, 24V-1.5W 3 3 3 3 3
30 2 129574-91880 HARNESS, WIRE 1 1 1 1 1
31 2 127684-91760 BULB 1 1 1 1 1
32 2 129574-91760 COVER 1 1 1 1 1
33 2 126684-91340 CONTROLL BOX,LUB.OIL 1 1 1 1 1
34 2 126684-91350 BRACKET 1 1 1 1 1
35 2 126684-91360 COVER 1 1 1 1 1
36 2 126684-91370 SCREW, 6X12 4 4 4 4 4
37 2 126684-91390 HARNESS, WIRE 1 1 1 1 1
38 2 198220-56160 PACKING 2 2 2 2 2
39 2 119593-91100 BOX ASSY 1 1 1 1 1
40 2 123482-91291 KEY 1 1 1 1 1
41 2 127687-91870 BOLT, M6X35 6 6 6 6 6
42 2 127687-91880 WASHER 6 6 6 6 6
43 2 127620-91250 CELL 1 1 1 1 1
44 2 129574-91490 HOLDER 1 1 1 1 1
45 2 198451-78680 CLAMP, CORD 2 2 2 2 2
46 2 129170-91930 PANEL 1 1 1 1 1
47 2 X55107948A0 HARNESS, WIRE 1 1 1 1 1
48 3 46150-003620 FUSE 1 1 1 1 1
49 2 126683-91820 WIRE 1 1 1 1 1 1
Remarks
50 1 129574-77980 HARNESS, WIRE 1 1 1 1 1
(1)This part is connected to
terminal 30 and terminal AC 51 1 124617-91860 RELAY 1 1 1 1 1
of the key switch.
0CG10-M32503
Fig.124. INSTRUMENT PANEL(ENGINE ATTACHED) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 122117-39150 PACKING D11.5,RD. 5 5 5 5 5
2 1 148660-91010 BODY, PANEL 1 1 1 1 1 1
2-1 1 42150-556240 HOUSING, PANEL 1 1 1 1 1 R 1
2A 1 148640-91020 BODY, PANEL 1 1 1 1 1 2
2A-1 1 42150-556250 HOUSING, PANEL 1 1 1 1 1 R 2
3 1 137600-91021 ABSORBER,SHOCK 3 3 3 3 3
4 1 139653-91170 CONNECTOR 5 5 5 5 5
5 1 137600-91302 VALVE, PRESSURE CAUG 5 5 5 5 5
6 1 137900-91451 RIVET 4 4 4 Z
7 1 22212-040000 SPRING WASHER 4 15 15 15 15 15
8 1 26106-060162 BOLT, M6X 16 PLATED 6 6 6 6 6
9 1 26106-100302 BOLT, M10X 30 PLATED 3 3 3 3 3
10 1 26366-060002 NUT, M6 6 6 6 6 6
11 1 26366-100002 NUT, M10 3 3 3 3 3
12 1 26557-040122 SCREW, M4X12 15 15 15 15 15
13 1 26717-040002 NUT, M4 15 15 15 15 15
14 1 28886-040000 GAUGE, 0.4MP 3 3 3 3
14-1 1 28886-040000 GAUGE, 0.4MP 2 2 2 2 2 K 3
15 1 28886-060530 GAUGE, 0.6MP 1 1 1 1 1 4
15A 1 125604-91190 PLATE 1 1 1 1 1 5
15A-1 1 150623-91300 COVER, BLIND 1 1 1 1 1 R 5
15B 1 28886-100000 GAUGE, 1.0MP 1 1 1 6
16 1 28886-104555 GAUGE, 1.0MP 1 1 1 1 1 7
17 1 42130-400240 SHAFT(600),FLEXIBLE 1 1 1 1 1
18 1 42221-021220 NAMEPLATE,DANGER MIN 1 1 1 Z
19 1 42222-003380 LABEL 1 1 1 1 1 1
20 1 46150-001150 SWITCH 1 1 1 1 1 1
21 1 46150-500470 PILOT LAMP 1 1 1 1 1 1
22 1 28886-041025 GAUGE, 0.4MP 1 1 1 1 1 W 8
23 1 42130-551340 GAUGE (TACHOMETER) 1 1 1 1 1 W
24 1 46150-005190 JOINT 1 1 1 1 1 W
24-1 1 46150-005191 JOINT 1 1 1 1 1 N
25 1 41903-650040 CAP, TERMINAL RUBBER 3 3 3 3 3 W
Remarks (A=EZZZZZ) (B=EZZZZZ) (C=EZZZZZ) (D=EZZZZZ) (E=EZZZZZ)
(1)Cell starting
(2)Air starting
(3)For boost & sea water
(4)For clutch lub. oil
(5)For blind, w/o clutch lub. oil
(6)For doplex fuel strainer,
(w/o clutch lub.oil)
(7)For engine lub.oil
(8)For fresh water

0CG10-M32503
Fig.125. INSTRUMENT PANEL BRACKET (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-91100 BRACKET, PANEL 1 1 1 1 1
1A 1 148660-91120 BRACKET, PANEL 1 1 1 1 1
2 1 148660-91110 SUPPORT 1 1 1
2-1 1 148660-91111 SUPPORT 1 1 1 1 1 N
(A=*2005.10) (B=*2005.10) (D=*2005.10)
3 1 26106-100252 BOLT, M10X 25 PLATED 4 4 4 4 4
4 1 26106-100282 BOLT, M10X 28 PLATED 2 2 2 2 2
5 1 26366-100002 NUT, M10 2 2 2 2 2

0CG10-M32503
Fig.126. PRESSUER GAUGE PIPE (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 148660-91200 PIPE, GAUGE 1 1 1
1-1 1 148660-91201 PIPE, GAUGE 1 1 1 1 1 S
(A=*2004.08) (B=*2004.08) (D=*2004.08)
6 1 23414-120000 GASKET, 12X1.0 2 2 2 2 2
7 1 23857-060000 BOLT, JOINT 6 1 1 1 1
7-1 1 23854-060000 BOLT, JOINT 6 1 1 1 1 1 N
8 1 148660-91210 PIPE, GAUGE 1 1 1 W
8-1 1 148660-91211 PIPE, GAUGE 1 1 1 1 1 R
(A=*2004.08) (B=*2004.08) (D=*2004.08)
12 1 148660-91220 PIPE, GAUGE 1 1 1 1 1 W
12-1 1 148660-91221 PIPE, GAUGE 1 1 1 1 1 S
12-2 1 148660-91222 PIPE, GAUGE 1 1 1 1 1 N
16 1 23297-060121 CLAMP, A6X12 2 2 2 2 2 W
17 1 23297-060121 CLAMP, A6X12 1 1 1 1 1 W
18 1 23297-060121 CLAMP, A6X12 2 2 2 2 2 W
19 1 23414-120000 GASKET, 12X1.0 2 2 2 2 2 W
20 1 23857-060000 BOLT, JOINT 6 1 1 1 1 1 W
20-1 1 23854-060000 BOLT, JOINT 6 1 1 1 1 1 N
21 1 148660-91300 PIPE, GAUGE 1 1 1 W
21-1 1 148660-91301 PIPE, GAUGE 1 1 1 1 1 S
(A=*2004.08) (B=*2004.08) (D=*2004.08)
25 1 148660-91310 PIPE, GAUGE 1 1 1 W
25-1 1 148660-91311 PIPE, GAUGE 1 1 1 1 1 S
(A=*2004.08) (B=*2004.08) (D=*2004.08)
25-2 1 148660-91312 PIPE, GAUGE 1 1 1 1 1 S
29 1 148016-59760 RETAINER (B) 6 6 6 6 6 W
30 1 23297-060121 CLAMP, A6X12 1 1 1 1 1 W
31 1 23414-120000 GASKET, 12X1.0 2 2 2 2 2 W
32 1 23857-060000 BOLT, JOINT 6 1 1 1 1 1 W
33 1 26106-060202 BOLT, M6X 20 PLATED 6 6 6 6 6 W
34 1 26366-060002 NUT, M6 6 6 6 6 6 W

0CG10-M32503
Fig.126. PRESSUER GAUGE PIPE (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
35 1 148660-91230 PIPE, GAUGE 1 1 1 1 1
39 1 23414-120000 GASKET, 12X1.0 1 1 1 1 1
40 1 23831-060000 UNION, 6 1 1 1 1 1
41 1 148660-91450 PIPE, PRESSURE 1 1 1 W
(B=EXXX)
42 1 148016-59770 RETAINER 4 4 4 W
(B=EXXX)
43 1 148640-91480 PLUG, M20 1 1 1 W
(B=EXXX)
44 1 23414-120000 GASKET, 12X1.0 2 2 2 W
(B=EXXX)
45 1 23414-200000 GASKET, 20X1.0 1 1 1 W
(B=EXXX)
46 1 23857-060000 BOLT, JOINT 6 1 1 1 W
(B=EXXX)
47 1 26106-060252 BOLT, M6X 25 PLATED 2 2 2 W
(B=EXXX)

0CG10-M32503
Fig.136. (126A)PRESSUER GAUGE PIPE(CLUTCH LUB.OIL) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 43711-104420 PIPE, GAUGE 1 1 1 1 1 W
2 1 43711-105250 PIPE, GAUGE 1 1 1 1 W
3 1 43711-104430 PIPE, GAUGE 1 W
(C=EZZZZZ)
4 1 148016-59750 CLAMP, A 2 2 2 2 2 W
5 1 23297-060081 CLAMP, A6X 8 2 2 2 2 W
6 1 23297-060121 CLAMP, A6X12 4 W
7 1 23854-060000 BOLT, JOINT 6 1 1 1 1 W
8 1 23414-120000 GASKET, 12X1.0 2 2 2 2 W
9 1 23854-100000 BOLT, JOINT 10 1 W
(C=EZZZZZ)
10 1 23414-160000 GASKET, 16X1.0 2 W
(C=EZZZZZ)
11 1 26106-060222 BOLT, M6X 22 PLATED 4 4 4 4 4 W
12 1 26366-060002 NUT, M6 4 4 4 4 4 W

0CG10-M32503
Fig.127. THERMOMETER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 28551-030300 THERMOMETER, 100 S 2 2 1
2 1 28575-620075 THERMOMETER, 620 6 6 2
3 1 23414-210000 GASKET, 21X1.0 6 6
4 1 42130-016991 THERMOMETER, EXHAUST 2 2 2 2 2 3
5 1 23414-210000 GASKET, 21X1.0 2 2 2 2 2
Remarks
(1)For lub.oil cooler
(2)For each cylinder of exhaust
(3)For turbocharger in
0CG10-M32503
Fig.128. NOZZLE TESTTER (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 737600-93103 TESTER ASSY, NOZZLE 1 1 1 1 1
2 2 180110-51160 SPRING, PLUNGER 1 1 1 1 1
3 2 180110-51170 WASHER, SPRING 1 1 1 1 1
4 2 180110-54200 BOLT 1 1 1 1 1
5 2 130110-54210 NUT 1 1 1 1 1
7 2 137600-93130 GASKET 1 1 1 1 1
8 2 137600-93140 PLUNGER 1 1 1 1 1
9 3 137600-93110 PLUNGER 1 1 1 1 1
10 3 137600-93120 BARREL, PLUNGER 1 1 1 1 1
11 2 137600-93150 TAPPET 1 1 1 1 1
12 2 137600-93200 BRACKET 1 1 1 1 1
13 2 137600-93210 RETAINER 1 1 1 1 1
14 2 137600-93220 PIN 1 1 1 1 1
15 2 137600-93230 HANDLE 1 1 1 1 1
16 2 137600-93252 RETAINER 1 1 1 1 1
17 2 137600-93280 NUT 1 1 1 1 1
18 2 137600-93301 JOINT, PIPE 1 1 1 1 1
19 2 137600-93310 JOINT 1 1 1 1 1
20 2 137600-93350 GASKET, DELIVERY 1 1 1 1 1
21 2 132310-93370 WASHER 1 1 1 1 1
22 2 137600-93372 SCREW 1 1 1 1 1
23 2 137600-93500 TANK, FUEL 1 1 1 1 1
25 3 132310-93171 COVER 1 1 1 1 1
26 3 132310-93180 KNOB 1 1 1 1 1
27 3 137600-93190 ELEMENT ASSY 1 1 1 1 1
28 3 137600-93390 FITTINGS,OIL TANK 1 1 1 1 1
30 2 101300-51330 SPRING, DELIVERY 1 1 1 1 1 2
31 2 101300-51390 BALL, STEEL 1 1 1 1 1 2
32 2 137600-93362 VALVE, DELIVERY 1 1 1 1 1 2
33 2 137600-93850 JOINT 1 1 1 1 1 1
34 2 21151-030252 BOLT 3/8X25 4 4 4 4 4
35 2 21151-030322 BOLT 3/8X32 2 2 2 2 2
36 2 22411-200150 COTTER PIN 1 1 1 1 1
37 2 23061-070500 PIPE, 7X 500 1 1 1 1 1 1
38 2 23351-080000 BOLT, JOINT 6 1 1 1 1 1
39 2 23414-110000 GASKET, 11X1.0 1 1 1 1 1 1
40 2 23414-140000 GASKET, 14X1.0 3 3 3 3 3
41 2 24311-000070 O-RING, 1AP7.0 1 1 1 1 1
42 2 24311-000180 O-RING, 1AP18.0 2 2 2 2 2
43 2 28816-990000 GAUGE, AVS 100X6.0MP 1 1 1 1 1
44 1 130605-93400 INJECTION.PIPE ASSY. 1 1 1 1 1
Remarks
(1)Not illustrated.
(2)Level changed:from 3 up to 2.
0CG10-M32503
Fig.129. TOOL (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 748620-92010 TOOL ASSY 1 1 1 1 1 Z
2 2 104200-92350 DRIVER, SCREW 1 1 1 1 1
3 2 122210-92600 BOX, TOOL 1 1 1
3-1 2 122210-92601 BOX 1 1 1 1 1 R
(A=*2005.08) (B=*2005.08) (D=*2005.08)
4 2 126410-92720 HANDLE 1 1 1 1 1
5 2 127610-92760 PINCERS 1 1 1 1 1
6 2 28110-070080 SPANNER, 7X8 1 1 1 1 1
7 2 28110-100130 SPANNER, 10X13 1 1 1 1 1
8 2 28110-120140 SPANNER, 12X14 1 1 1 1 1
9 2 28110-170190 SPANNER, 17X19 1 1 1 1 1
10 2 28110-220240 SPANNER, 22X24 1 1 1 1 1
11 2 28110-270300 SPANNER, 27X30 1 1 1 1 1
12 2 28120-002000 WRENCH, 200 1 1 1 1 1
13 2 28160-170190 WRENCH, 17X19 1 1 1 1 1
14 2 28210-000140 OILER 1 1 1 1 1
15 2 28312-300750 GAUGE, 0.30X75 1 1 1 1 1
16 2 28312-400750 GAUGE, 0.40X75 1 1 1
16-1 2 28312-500750 GAUGE, 0.50X75 1 1 1 1 1 N
(A=*2005.05) (B=*2005.05) (D=*2005.05)
17 2 28322-020000 RING, GAUGE 1 1 1 1 1
18 2 148620-92400 GAUGE, ANGLE 1 1 1 1 1 W
(A=*2006.02) (B=*2006.02) (D=*2006.02)
19 1 719195-92500 TOOL ASSY 1 1 1 1 1 W
20 2 104200-92350 DRIVER, SCREW 1 1 1 1 1
21 2 104200-92600 BOX, TOOL 1 1 1 1 1
22 2 28110-080100 SPANNER, 8X10 1 1 1 1 1
23 2 28110-100130 SPANNER, 10X13 1 1 1 1 1
24 2 28110-120140 SPANNER, 12X14 1 1 1 1 1
25 2 28110-170190 SPANNER, 17X19 1 1 1 1 1
26 1 126410-92720 HANDLE 1 1 1 1 1 W
27 1 177501-09051 SPANNER 1 1 1 1 W
28 1 177101-09281 WRENCH 1 W
(C=EZZZZZ)

0CG10-M32503
Fig.137. (129A)TOOL(OPTIONAL) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 726677-92110 TOOL ASSY 1 1 1 1 1 W
2 2 104200-92350 DRIVER, SCREW 1 1 1 1 1
3 2 122210-92601 BOX 1 1 1 1 1
4 2 127610-92750 WRENCH, FILTER 1 1 1 1 1
5 2 28110-080100 SPANNER, 8X10 1 1 1 1 1
6 2 28110-100130 SPANNER, 10X13 1 1 1 1 1
7 2 28110-120140 SPANNER, 12X14 1 1 1 1 1
8 2 28110-170190 SPANNER, 17X19 1 1 1 1 1
9 2 28110-220240 SPANNER, 22X24 1 1 1 1 1
10 2 28110-270300 SPANNER, 27X30 1 1 1 1 1
11 2 28160-220240 WRENCH, 22X24 1 1 1 1 1
12 2 28312-100750 GAUGE, 0.10X75 1 1 1 1 1
13 2 28312-250750 GAUGE, 0.25X75 1 1 1 1 1
14 2 28312-300750 GAUGE, 0.30X75 1 1 1 1 1
15 2 28312-350750 GAUGE, 0.35X75 1 1 1 1 1
16 2 28312-500750 GAUGE, 0.50X75 1 1 1 1 1
17 2 28322-020000 RING, GAUGE 1 1 1 1 1
18 1 126410-92720 HANDLE 1 1 1 1 1 W
19 1 177501-09051 SPANNER 1 1 1 1 W
20 1 177101-09281 WRENCH 1 W
(C=EZZZZZ)

0CG10-M32503
Fig.130. SPECIAL TOOL(OPTIONAL) (B)=6AYM-ETE (E)=6AYM-GTE
(C)=6AYM-STE (F)=
(A) (B) (C) (D) (E) (F)
1 1 142903-92060 BOLT 1 1 1 1 1
2 1 148620-92170 TOOL, NOZZLE 1 1 1 1 1
3 1 26366-100002 NUT, M10 1 1 1 1 1
4 1 133670-92010 TOOL,CYL.LINER REMG 1 1 1 1 1
5 1 140612-92020 TOOL 1 1 1 1 1
6 1 140623-92030 BOLT M24,LINER REMG 1 1 1 1 1
7 1 22137-240000 WASHER, 24 2 2 2 2 2
8 1 26732-240002 NUT, M24 2 2 2 2 2
9 1 26772-240002 NUT, LOCK M24 1 1 1 1 1
10 1 148660-92140 TOOL, PISTON INSERT 1 1 1 1 1
11 1 148660-92850 TOOL 1 1 1 1 1
12 1 42111-000020 GAUGE,DEFLECTION 1 1 1 1 1
13 1 42111-000980 BORE GAUGE 1 1 1 1 1
14 1 42111-001420 MIRROR, GAUGE 1 1 1 1 1
15 1 42111-550590 SOCKET 1 1
16 1 42112-005901 TORQUE WRENCH(550N,M 1 1
17 1 42112-007020 TORQ WRENCH 1 1
18 1 127610-92770 HAMMER 1 1 1 Z
19 1 127610-92760 PINCERS 1 1 1 1 1 W
20 1 28110-070080 SPANNER, 7X8 1 1 1 1 1 W
21 1 28120-002000 WRENCH, 200 1 1 1 1 1 W
22 1 28160-170190 WRENCH, 17X19 1 1 1 1 1 W
23 1 28210-000140 OILER 1 1 1 1 1 W
24 1 148620-92400 GAUGE, ANGLE 1 1 1 1 1 W

Parts No. Index
Parts No. Fig. No. Ref. No. Parts No. Fig. No. Ref. No. Parts No. Fig. No. Ref. No. Parts No. Fig. No. Ref. No.
101300-51330 128 30 124060-39451 116 19 126618-11750 21 10 126684-91330 122 49
101300-51390 128 31 24 126618-11820 7 18 126684-91340 122 50
103200-53210 81 11 124060-59380 67 32 126628-49650 67 34 123 33
104200-92350 129 2 124160-01751 12 5 126630-07361 17 14 126684-91350 122 51
20 124160-39140 24 31 126630-07990 17 23 123 34
137 2 124210-21230 77 3 126630-91350 117 11 126684-91360 122 52
104200-92600 129 21 124220-09340 17 20 126630-91570 117 14 123 35
104264-59020 24 32 124220-51890 76 78 20 126684-91370 122 53
104507-07190 120 9 95 126630-91581 117 15 123 36
105430-67110 120 11 79 4 126630-91591 117 23 126684-91380 122 54
114780-61090 79 84 -1 124250-59350 85 15 28 126684-91390 122 55
119173-59120 24 33 124298-01760 14 9 126634-48180 58 65 123 37
119187-51391 76 39 A 124410-51861 76 94 59 11 126684-91410 116 6
119189-91260 122 8 124411-67830 102 5 126635-11840 20 29 -1 117 12
123 5 103 10 30 126684-91502 117 13
119593-91100 123 39 124411-91160 116 3 126650-03072 40 47 126685-09330 58 10
119620-49290 25 11 117 2 126650-11440 23 13 126687-07991 17 31
55 20 124610-51970 76 80 -1 126650-44610 58 7 127610-11750 24 14
119660-01570 80 2 124617-91860 115 2 126650-66260 102 16 58 4
120130-42130 56 6 123 51 103 7 4 -1
57 25 125600-02451 85 2 126650-66270 102 12 127610-11760 24 15
120270-77101 115 3 125604-91190 124 15 A 126658-59050 89 5 58 5
120270-77102 115 3 -1 126410-92720 129 4 90 1 5 -1
120325-61100 79 85 -1 26 126683-03150 14 29 127610-77720 117 4
121250-39450 116 1 137 18 126683-44400 58 2 127610-91221 116 4
121450-01220 78 16 -1 126438-91501 116 7 126683-59900 95 10 127610-91350 116 5
121575-91250 122 16 126438-91541 116 11 126683-77250 98 2 127610-91850 117 7
121850-21920 36 4 126440-49650 69 3 A 126683-77700 119 7 127610-91860 117 8
122117-39150 124 1 8 A 126683-91820 123 49 127610-92750 137 4
122210-92600 129 3 8 B 126684-01440 4 3 127610-92760 129 5
122210-92601 129 3 -1 70 5 A 126684-07250 17 26 130 19
137 3 12 A 126684-07660 120 10 127610-92770 130 18
122710-51360 79 3 71 5 A 126684-12300 24 23 127612-55850 84 15
123210-09310 35 9 12 A 126684-18150 29 4 85 36
123482-39660 116 20 20 A 30 37 127620-49650 69 3
117 24 27 A 126684-18401 29 7 8
123482-39670 116 2 126616-12620 24 25 126684-18900 34 3 -1 70 5
117 1 126616-18390 29 6 126684-18911 34 4 12
123482-39680 116 25 30 38 126684-49910 24 12 71 5
117 29 126616-53120 81 7 126684-61610 80 12 12
123482-44570 58 50 126616-53130 81 8 126684-61620 80 13 20
123482-91291 122 17 126616-53300 81 13 126684-61650 80 16 27
123 40 126616-61730 79 103 A-1 126684-61651 80 16 -1 127620-91250 122 11
123672-55750 84 10 103 A-2 126684-77201 120 12 123 43
85 32 154 A 126684-77210 120 13 127620-91660 122 4
123672-91220 117 6 126616-67300 102 8 126684-77220 120 14 123 26
123678-55880 84 8 103 9 126684-77240 120 17 29
85 30 126617-61910 80 26 126684-91301 122 6 127684-91760 123 31
123682-07852 17 13 126617-77500 115 7 126684-91321 122 47 127687-91760 122 14
123682-77740 117 5 126618-07250 17 25 123 4 127687-91870 122 46
Parts No. Index
127687-91870 123 41 129574-91420 122 26 130605-51500 76 54 135210-61090 79 84
127687-91880 122 45 123 8 130605-51580 76 114 135210-61100 79 85
123 42 129574-91430 122 29 130605-51830 76 76 -1 85 -2
127692-07250 17 30 123 11 76 A-1 135210-61221 79 19
127692-52210 77 17 129574-91440 122 32 130605-51910 76 79 135210-61230 79 20
127692-91210 122 5 123 14 130605-54420 78 2 135210-61320 79 28
123 3 129574-91490 122 12 130605-54500 76 111 135210-61380 79 88
127692-91270 122 22 123 44 78 1 135210-61540 79 35
123 21 129574-91570 116 14 A 130605-54550 78 3 135210-61590 79 40
127692-91350 122 18 129574-91600 122 38 130605-61490 76 117 135210-61830 79 49
127692-91410 122 40 129574-91620 122 25 80 1 135210-61850 79 51
123 22 123 7 130605-61510 76 120 135310-59930 94 10
127692-91440 122 41 129574-91630 122 28 80 10 135410-01780 8 3
123 23 123 10 130605-65260 104 6 9 3
127692-91450 122 42 129574-91640 122 31 130605-93400 128 44 131 3
123 24 123 13 130618-14200 28 1 132 3
127692-91860 122 9 129574-91650 122 39 130618-28101 38 6 135410-33310 35 7
123 25 123 20 130618-51370 76 35 135410-35310 46 1
127695-18180 34 30 129574-91710 122 35 130618-51380 76 37 135410-35320 4 11
127695-18190 34 15 123 17 131110-66420 79 57 46 10
127695-55760 86 2 129574-91720 122 27 132310-09330 58 8 135410-35890 46 7 A
127695-77500 34 32 123 9 132310-93171 128 25 135410-35900 46 7 B
128296-07260 18 4 129574-91730 122 30 132310-93180 128 26 135410-35910 46 7 C
128610-77200 111 1 123 12 132310-93370 128 21 135410-35920 46 7 D
112 1 129574-91740 122 33 133615-09110 98 1 135410-35930 46 7 E
128623-44210 58 6 123 15 133615-59310 89 5 A 135410-35940 46 7
128633-32390 40 35 129574-91750 122 36 90 1 A 135410-35950 46 2
128633-32410 40 36 123 18 133660-59320 49 9 135410-35960 46 3
128633-32420 40 37 129574-91760 123 32 133670-07090 17 9 135410-35970 46 4
128633-32430 40 38 129574-91770 122 37 133670-21600 36 8 135410-35980 46 5
128633-32450 40 40 123 19 133670-39340 1 49 135410-35990 46 6
128633-59240 88 1 129574-91780 122 20 133670-49331 73 2 135410-39460 53 23
128633-66020 1 35 129574-91790 122 21 133670-76510 108 1 135600-61481 79 101
128634-03150 14 17 129574-91800 122 19 2 135600-61491 79 102
128634-77530 119 2 129574-91870 122 3 133670-92010 130 4 135665-07200 17 16
128634-77531 119 2 -1 123 28 133954-53900 64 14 135665-07210 17 17
129155-61480 80 3 129574-91880 122 13 133970-01670 7 13 136600-42480 111 23
129170-91610 122 34 123 30 135200-52071 77 8 136603-51690 76 65
123 16 129574-91890 122 48 135200-52170 77 14 136603-61440 79 150
129170-91810 122 7 123 27 135200-52213 77 18 136603-61530 79 34
129170-91930 123 46 129574-91930 122 24 135200-52301 77 20 136603-61590 79 41
129198-07350 17 15 129590-18520 24 30 135200-52320 77 22 136603-61600 79 42
129470-91190 122 23 129595-61600 80 11 135200-52350 77 27 136603-61860 79 53
129574-77700 115 8 129595-61670 80 19 135200-52361 77 28 136610-34112 42 8
129574-77710 115 9 129595-61671 80 19 -1 135200-52510 77 31 136686-59570 89 15
129574-77720 115 10 130110-54210 128 5 135200-61970 79 117 136686-59580 89 16
129574-77980 123 50 130605-49150 67 18 135210-11280 55 19 137600-35310 85 3
129574-91240 122 10 25 135210-51080 79 2 137600-35330 85 4
123 6 130605-51100 76 10 135210-51610 79 81 137600-39210 53 15
129574-91410 122 15 130605-51101 76 10 -1 135210-61080 79 83 137600-51332 76 32
Parts No. Index
137600-71040 84 16 140673-61940 79 114 A 144626-61761 79 106 148018-91201 123 2
85 37 140673-61950 79 115 106 -2 148018-91211 122 1
137600-91021 124 3 140673-61960 79 116 144626-61771 79 108 148218-33061 58 3
137600-91302 124 5 141616-07200 18 1 144626-61781 79 109 148218-42090 56 3
137600-93110 128 9 141616-07210 18 3 144626-61790 79 46 148218-51370 76 36
137600-93120 128 10 141616-07220 18 2 144626-61800 79 7 148606-49112 67 37
137600-93130 128 7 141644-59830 49 8 111 148609-61330 79 29
137600-93140 128 8 142903-92060 130 1 143 148609-61550 79 36 -1
137600-93150 128 11 144626-28900 38 8 144626-61840 79 50 148610-11930 20 30 -1
137600-93190 128 27 144626-28901 38 8 -1 144626-61890 79 54 148616-01451 4 4
137600-93200 128 12 144626-32330 40 30 144626-61900 79 113 14 5
137600-93210 128 13 144626-34140 42 6 144626-77201 111 2 148616-01611 7 10
137600-93220 128 14 144626-34210 42 7 113 1 148616-01641 12 2
137600-93230 128 15 144626-39543 49 6 144626-91570 116 14 15 2
137600-93252 128 16 144626-39562 49 17 144626-91820 116 15 148616-01811 7 6
137600-93280 128 17 144626-39563 49 17 -1 117 16 148616-02400 1 21 C
137600-93301 128 18 144626-51281 76 26 144626-92900 11 8 13 1
137600-93310 128 19 144626-51290 76 27 145410-32310 40 31 148616-02420 1 21 D
137600-93350 128 20 28 145410-32400 40 33 13 2
137600-93362 128 32 86 145610-32320 40 32 148616-07362 17 8
137600-93372 128 22 144626-51410 76 44 145610-39901 47 2 148616-11170 20 18
137600-93390 128 28 44 A 145610-84881 53 25 21 19
137600-93500 128 23 144626-51430 76 46 145613-77420 111 18 148616-11230 22 5
137600-93850 128 33 144626-51521 76 56 145640-09320 58 9 10
137602-39650 53 24 144626-51670 76 63 146602-39800 50 4 -1 148616-11520 22 20
137900-91451 17 28 144626-51680 76 64 146673-11870 20 12 148616-11930 20 29
29 144626-51700 76 66 21 13 21 29
124 6 144626-51730 76 67 147673-42260 57 7 148616-11970 20 15
138613-34100 42 3 68 148016-49900 66 12 21 16
138613-84232 40 29 144626-51930 76 80 67 7 C 148616-11981 20 16
139653-34050 42 3 -1 144626-51940 76 81 68 22 21 17
139653-34090 42 4 82 148016-49910 69 12 148616-14320 26 3
139653-39330 53 17 144626-51950 76 83 13 148616-14330 26 4
139653-91170 124 4 84 70 16 148616-18420 31 1
139684-53170 81 10 144626-52230 77 19 17 148616-18421 31 1 -1
139684-53450 81 15 144626-52270 77 7 71 31 148616-18520 31 2 -1
140612-92020 130 5 7 -1 32 148616-18550 31 1 -2
140623-11740 22 19 144626-52921 77 34 33 148616-18900 31 2 B
140623-34060 42 5 144626-61140 79 15 A 34 148616-18920 31 1 B
140623-39440 53 16 144626-61150 79 15 B 148016-59750 136 4 148616-18961 31 2
140623-51530 76 57 144626-61431 79 6 148016-59760 126 29 148616-39010 47 1
140623-51540 76 58 144626-61441 79 97 148016-59770 126 42 148616-39950 47 3
140623-51580 76 60 144626-61450 79 98 148016-61550 79 147 148616-39960 47 4
140623-53360 20 32 144626-61461 79 99 148018-42030 56 2 148616-39970 47 5
21 31 144626-61510 79 33 148018-42031 56 2 -1 148616-43630 55 5
140623-61310 79 27 144626-61530 79 34 -1 148018-42170 56 8 148616-43640 55 18
140623-61500 79 32 144626-61620 79 43 148018-42361 56 11 148616-44560 58 49
140623-92030 130 6 144626-61740 79 104 148018-49531 67 2 148616-48200 58 64
140673-61160 79 16 144626-61751 79 138 10 59 12
140673-61350 79 31 138 -2 148018-91201 122 2 148616-49930 66 13 A
Parts No. Index
148616-49930 67 7 A 148620-01440 4 4 -1 148620-03431 14 14 148620-11900 21 30
68 20 A 14 5 -1 148620-03450 14 2 148620-11901 20 31 -1
148616-51671 76 61 15 1 148620-03451 14 2 -1 21 30 -1
148616-52161 77 6 148620-01451 1 22 148620-03460 14 8 -1 148620-11911 20 27
148616-52240 77 21 148620-01452 1 22 -1 15 12 21 28
148616-52420 77 30 148620-01460 1 23 148620-03480 14 14 -1 148620-12150 24 2
148616-54420 55 17 148620-01470 3 1 148620-07150 17 10 148620-13250 25 9
148616-55902 86 1 148620-01480 3 2 148620-07160 17 11 148620-14101 26 2
148616-59050 87 1 148620-01490 82 23 148620-07301 17 4 148620-14460 28 2
148616-59330 86 16 104 14 148620-11070 20 13 148620-14710 27 4
148616-59340 89 2 148620-01500 4 1 21 14 148620-14720 27 5
6 148620-01501 4 1 -1 148620-11092 20 14 148620-14721 27 5 -1
90 4 148620-01520 4 2 21 15 148620-14730 27 6
6 148620-01560 4 9 -1 148620-11110 20 21 148620-14900 27 1
148616-59360 89 1 148620-01621 7 2 21 22 148620-18180 34 8
148616-59430 86 15 148620-01630 7 2 -1 148620-11150 21 23 -1 148620-18250 29 12
148616-61361 79 86 148620-01640 11 1 148620-11180 20 20 148620-18551 29 9
148616-61390 79 122 -1 148620-01650 11 4 21 21 148620-18552 29 9 -1
148616-61400 79 89 148620-01651 11 4 -1 148620-11220 22 4 148620-18553 29 9 -2
148616-61410 79 90 148620-01760 4 10 9 148620-18554 29 9 -3
148616-61440 79 92 148620-01761 4 10 -1 148620-11260 22 16 148620-18570 29 10
148616-61470 79 100 148620-01770 8 8 148620-11272 22 22 148620-18901 34 3
146 9 4 148620-11281 22 24 148620-18910 32 9
148616-61570 79 39 148620-01771 8 8 -1 148620-11290 22 23 148620-21150 36 1
148616-61640 79 44 9 4 -1 148620-11301 23 1 148620-21201 36 3
148616-61650 79 45 131 8 148620-11302 23 1 -1 148620-21350 36 6
148616-61710 79 153 132 9 148620-11303 23 1 -2 148620-22310 37 9
148616-61730 79 103 148620-01800 7 15 148620-11304 23 1 -3 148620-23201 37 15
103 -1 148620-01810 5 1 148620-11440 23 13 -1 148620-23202 37 15 -1
103 A 6 1 148620-11441 23 13 -2 148620-23220 37 16
148616-61740 79 105 148620-01811 5 1 -1 148620-11460 20 23 148620-23820 37 19
148616-61761 79 107 6 1 -1 21 24 148620-32201 40 16
148616-61780 79 110 148620-01830 5 2 148620-11470 20 24 148620-32260 40 17
148616-61800 79 112 6 2 21 25 148620-32261 40 17 -1
148619-07931 17 24 148620-01831 5 2 -1 148620-11530 20 19 148620-32271 40 18
148619-28980 17 18 6 2 -1 21 20 148620-32272 40 18 -1
148619-28990 17 19 148620-01860 10 2 148620-11700 23 2 148620-32500 40 42
148619-55520 85 8 148620-01870 7 5 148620-11701 23 2 -1 148620-33010 41 4
148619-55530 85 9 148620-01880 5 3 148620-11760 21 9 148620-33030 41 2
148620-01090 1 18 148620-01890 6 3 148620-11770 20 10 148620-33040 41 3
148620-01091 1 18 -1 148620-02070 1 5 148620-11800 20 34 148620-33041 41 3 -1
148620-01241 2 6 148620-02120 1 7 21 33 148620-33050 41 17
148620-01242 2 6 -1 148620-02250 1 6 148620-11801 20 34 -1 148620-33061 41 16
148620-01243 2 6 -2 148620-02481 13 3 21 33 -1 148620-33070 41 18
148620-01280 2 3 148620-03150 14 17 -1 148620-11820 20 35 148620-34830 43 2
148620-01290 2 4 148620-03400 14 7 21 34 148620-35100 44 1 A
148620-01300 2 5 148620-03401 14 7 -1 148620-11821 20 35 -1 148620-35110 44 2 A
148620-01350 12 1 148620-03410 14 8 21 34 -1 45 2 A
148620-01390 1 25 148620-03420 14 4 148620-11840 21 11 148620-35120 44 1
148620-01400 1 27 148620-03421 14 4 -1 148620-11900 20 31 148620-35130 44 2
Parts No. Index
148620-35130 45 2 148620-54261 82 20 148628-11330 23 12 148640-18041 30 2 A
148620-35140 45 1 A 148620-54262 82 20 -1 148628-18750 34 24 148640-18042 29 2 A-1
148620-35150 45 1 148620-54263 82 20 -2 148628-18760 34 25 30 2 A-1
148620-35160 44 9 148620-54391 82 3 148628-18770 34 26 148640-18051 29 2 B
45 9 148620-54420 82 4 148628-35321 4 11 -1 30 2 B
148620-35310 46 1 -1 148620-54440 82 19 46 10 -1 148640-18052 29 2 B-1
148620-35320 46 15 148620-54441 82 19 -1 148633-11190 20 26 30 2 B-1
148620-35330 46 11 148620-54461 82 22 21 27 148640-18061 29 2 C
148620-35331 46 11 -1 148620-54481 83 16 148633-32140 40 21 30 2 C
148620-39150 48 1 148620-54491 83 17 148633-35400 44 3 148640-18062 29 2 C-1
148620-39160 48 2 148620-54510 78 7 45 3 30 2 C-1
148620-39262 52 1 148620-54690 76 112 148633-43400 55 9 148640-18071 29 2 D
148620-39281 52 4 78 5 148633-43700 55 11 30 2 D
148620-39300 1 50 148620-54710 82 5 111 28 148640-18072 29 2 D-1
148620-39420 49 7 148620-54721 82 14 148633-44211 58 12 30 2 D-1
148620-39840 49 24 148620-54730 82 16 148633-44310 58 20 148640-18081 29 2 E
148620-42330 57 8 148620-55010 84 1 148633-44530 58 22 30 2 E
148620-48102 59 1 148620-55201 84 14 148633-66590 104 7 148640-18082 29 2 E-1
148620-49360 66 2 148620-59020 89 9 148633-77090 109 46 30 2 E-1
7 148620-59040 89 12 134 9 148640-18091 29 2 F
148620-49380 59 2 148620-59070 94 6 148633-77410 111 20 30 2 F
148620-49391 65 2 148620-59101 94 1 148633-77530 110 7 148640-18092 29 2 F-1
148620-49400 59 3 148620-59250 87 6 135 32 30 2 F-1
148620-49410 65 16 148620-59440 91 108 148633-77540 109 44 148640-21130 36 1 A
148620-49511 75 1 148620-59441 91 108 -1 110 1 148640-21140 36 1 B
148620-49520 66 9 148620-59442 91 108 -2 148633-91230 117 3 148640-21150 36 1 C
75 2 148620-59470 91 106 148634-18340 29 5 148640-21160 36 1 D
148620-49800 59 5 148620-59471 91 106 -1 30 32 148640-21170 36 1 E
148620-51030 76 4 148620-59490 91 105 148634-42100 56 4 148640-21180 36 1 F
148620-51060 76 6 148620-59910 93 1 148634-42340 56 10 148640-21190 36 1 G
148620-51071 76 7 148620-59920 95 4 148634-91211 123 1 148640-59030 89 22 -1
148620-51080 76 9 96 1 148640-18021 29 2 90 20 -1
148620-51090 76 113 148620-59942 93 11 30 2 148640-59040 89 7 -1
148620-51160 76 14 148620-59951 93 5 148640-18022 29 2 -1 90 3 -1
148620-51950 76 104 A 148620-77020 109 1 30 2 -1 148640-59050 89 6 -1
148620-51951 76 104 A-1 148620-77080 134 1 148640-18023 29 2 -2 90 4 -1
148620-52001 76 110 148620-77100 134 2 2 A-2 148640-59060 90 21
77 1 135 30 2 B-2 148640-59080 90 11
148620-52070 77 7 A 148620-77110 134 3 2 C-2 148640-59090 90 16
148620-52100 77 9 135 31 2 D-2 148640-59930 97 1
148620-52110 77 10 148620-77500 109 47 2 E-2 148640-61010 79 5
148620-52180 77 16 134 4 2 F-2 148640-61070 79 9
148620-52190 77 15 148620-92170 130 2 30 2 -2 148640-61100 79 80 -3
148620-53080 81 5 148620-92400 129 18 2 A-2 80 A-3
148620-53160 81 9 130 24 2 B-2 148640-61110 79 140
148620-53240 81 12 148628-01411 3 2 -1 2 C-2 148640-61140 79 11
148620-54020 83 1 148628-01641 9 17 2 D-2 148640-61150 79 12
148620-54100 83 2 12 2 -1 2 E-2 148640-61160 79 13
148620-54150 83 7 132 8 2 F-2 148640-61170 79 14
148620-54200 83 18 148628-11140 20 22 148640-18041 29 2 A 148640-61180 79 15
Parts No. Index
148640-61200 79 17 148660-12640 24 25 -2 148660-39581 49 16 -1 148660-49280 67 25 -1
148640-61240 79 21 148660-12650 24 31 -1 148660-39740 50 1 68 4
148640-61250 79 22 31 -2 148660-39741 50 1 -1 14
148640-61270 79 26 148660-12660 24 26 -1 148660-39800 51 1 148660-49300 67 5
148640-61400 79 89 -1 26 -2 148660-39801 51 1 -1 148660-49310 69 1
148640-61430 79 145 133 10 148660-42400 56 12 148660-49330 69 7
148640-61450 79 144 148660-13000 25 1 148660-42420 56 7 148660-49340 74 1
148640-61480 79 146 -1 148660-13020 25 1 A 148660-42431 56 5 1 -1
148640-61570 79 39 A 148660-13030 25 8 A 148660-42440 56 9 148660-49341 74 1 -2
148640-61730 79 154 148660-13100 25 1 B 148660-42450 56 24 148660-49342 74 1 -3
148640-61750 79 138 -1 148660-13120 25 1 C 148660-42451 56 24 -1 148660-49360 67 24
148640-61760 79 106 -1 148660-13500 25 6 57 26 68 15
148640-61790 79 46 -1 148660-13501 25 6 -1 148660-42601 55 24 148660-49370 67 30
148640-61800 79 47 148660-13510 25 7 148660-42602 55 24 -1 68 16
148640-61810 79 48 148660-13511 25 7 -1 148660-42611 55 29 148660-49380 67 31
148640-61850 79 52 148660-13550 25 15 148660-42612 55 29 -1 148660-49390 67 36
148640-61930 79 114 148660-14020 26 1 148660-42620 55 25 148660-49400 67 1
148640-61940 79 114 A-1 148660-14750 26 8 148660-42621 55 25 -1 148660-49401 67 1 -1
148640-65010 104 2 148660-18101 35 5 148660-42631 55 28 148660-49410 67 9
148640-65050 104 5 148660-18102 35 5 -1 148660-42632 55 28 -1 68 5
148640-65460 104 10 148660-18110 34 1 148660-43100 55 2 148660-49430 67 27 A
148640-65461 104 10 -1 148660-18111 34 1 -1 148660-43110 55 15 68 19 A
148640-71010 108 20 148660-18121 34 7 148660-43120 55 16 148660-49450 67 28
148640-71040 108 21 148660-18122 34 7 -1 148660-43131 55 3 68 21
148640-91020 124 2 A 148660-18131 34 14 148660-43140 55 4 148660-49500 64 16
148640-91480 126 43 148660-18132 34 14 -1 148660-43200 55 23 65 10
148660-01600 7 1 148660-18150 34 2 148660-43201 55 23 -1 148660-49600 73 1
148660-01601 7 1 -1 148660-18151 34 2 -1 148660-44320 58 21 148660-49980 74 3 -2
148660-01602 7 1 -2 148660-18160 34 19 148660-44321 58 21 -1 148660-54300 82 12
148660-01603 7 1 -3 148660-18161 34 19 -1 148660-44350 58 31 148660-59170 102 2
148660-01604 7 1 -4 148660-18350 31 8 148660-44351 58 31 -1 103 1
148660-01810 7 6 -1 148660-18370 31 10 148660-44360 58 32 105 2
148660-01880 10 1 148660-18390 31 14 148660-44610 58 59 148660-77080 135 1
148660-07910 19 1 148660-18400 34 22 148660-44611 58 59 -1 148660-77080-A 135 1 A
148660-07920 19 2 148660-18410 34 23 148660-44690 58 45 148660-77100 110 58
148660-08100 11 13 148660-18411 34 23 -1 148660-44700 58 47 148660-77210 111 21
148660-11080 20 13 -1 148660-18450 31 3 148660-49110 66 1 148660-77220 111 22
21 14 -1 148660-18501 35 2 148660-49120 66 6 148660-77230 111 19
148660-11100 20 20 -1 148660-18511 35 3 148660-49231 64 1 148660-77300 111 3
21 21 -1 148660-18512 35 3 -1 148660-49232 64 1 -1 148660-77330 111 15
148660-12100 24 1 148660-18520 35 4 148660-49233 64 1 -2 148660-77331 111 15 -1
148660-12410 133 1 148660-18640 24 17 148660-49240 64 2 148660-77332 111 15 -2
148660-12430 133 6 35 13 148660-49250 67 5 -1 148660-77350 111 13
148660-12610 24 30 -1 148660-18700 35 23 148660-49251 67 5 -2 148660-77541 109 44 -1
30 -2 148660-18701 35 23 -1 148660-49260 67 6 110 1 -1
148660-12620 24 32 -1 148660-28210 38 4 68 2 134 10
32 -2 148660-28240 38 7 148660-49270 67 2 -1 135 33
148660-12630 24 24 -1 148660-39150 48 1 A 10 -1 148660-77571 114 1
24 -2 148660-39412 49 1 68 3 148660-77581 114 2
148660-12640 24 25 -1 148660-39580 49 16 148660-49280 67 18 -1 148660-77640 119 3
Parts No. Index
148660-77650 119 4 148665-51760 76 29 A 148690-03301 15 9 -1 148690-43110 57 3
148660-77660 119 5 148665-51800 76 74 A 148690-03320 15 3 148690-43120 57 4
148660-77670 119 6 148665-51810 76 79 -1 148690-03330 15 4 148690-43130 57 5
148660-77680 119 15 148665-51830 76 76 A 148690-03431 15 18 148690-43140 57 22
148660-77900 119 8 148665-53000 81 2 B 148690-03461 15 23 148690-43150 57 24
148660-91010 124 2 148665-53001 81 2 B-1 148690-03472 15 13 148690-49200 65 15
148660-91100 125 1 148665-53002 81 2 B-2 148690-03480 14 31 148690-49230 65 1
148660-91110 125 2 148665-59310 91 31 A 148690-03500 15 27 148690-49250 68 1
148660-91111 125 2 -1 148665-59320 91 43 A 148690-07910 19 5 148690-49310 72 62
148660-91120 125 1 A 148665-59330 91 55 A 148690-18010 29 1 148690-49330 72 70
148660-91200 126 1 148665-59340 91 67 A 30 1 148690-49380 68 17
148660-91201 126 1 -1 148665-59350 91 79 A 148690-18011 29 1 -1 148690-49390 68 18
148660-91210 126 8 148665-59360 91 91 A 30 1 -1 148690-49700 65 17
148660-91211 126 8 -1 148687-35300 44 4 148690-18012 29 1 -2 148690-49710 65 18
148660-91220 126 12 148688-01550 4 13 1 A-2 148690-49770 59 4
148660-91221 126 12 -1 148688-01561 4 9 1 B-2 148690-49780 65 19
148660-91222 126 12 -2 148688-12610 24 24 1 C-2 148690-49790 65 20
148660-91230 126 35 148688-35301 45 4 1 D-2 148690-55200 85 35
148660-91300 126 21 148688-39320 24 26 1 E-1 148690-59030 91 1
148660-91301 126 21 -1 148688-49730 67 43 1 F-1 148690-59040 91 6
148660-91310 126 25 148688-49900 67 27 30 1 -2 148690-59050 91 11
148660-91311 126 25 -1 68 19 1 A-2 148690-59060 91 16
148660-91312 126 25 -2 148688-52012 77 2 1 B-2 148690-59070 91 21
148660-91450 126 41 148688-52013 77 2 -1 1 C-2 148690-59080 91 26
148660-92140 130 10 148688-52120 77 11 1 D-2 148690-59100 89 5 -1
148660-92850 130 11 148688-52141 77 13 1 E-1 5 -2
148665-18020 29 3 148688-54490 78 6 1 F-1 90 2
30 3 148688-54520 78 8 148690-18020 29 1 A 148690-59110 94 11
148665-18021 29 3 -1 148688-54540 78 9 30 1 A 148690-59210 91 1 A
30 3 -1 148688-54550 1 35 -1 148690-18021 29 1 A-1 148690-59220 91 6 A
148665-18040 29 3 A 78 10 30 1 A-1 148690-59230 91 11 A
30 3 A 148688-54580 78 11 148690-18030 29 1 B 148690-59240 91 16 A
148665-51030 76 4 A 148688-61500 80 9 30 1 B 148690-59250 91 21 A
148665-51060 76 6 A 148688-61630 80 14 148690-18031 29 1 B-1 148690-59260 91 26 A
148665-51070 76 7 A 148688-61640 80 15 30 1 B-1 148690-59280 89 1 A
148665-51090 76 113 A 148688-61650 80 17 148690-18040 29 1 C 148690-59290 89 5 A-1
148665-51160 76 14 A 148688-61660 80 18 30 1 C 5 A-2
148665-51170 76 15 A 148688-61680 80 20 148690-18041 29 1 C-1 90 2 A
148665-51180 76 16 A 148688-61790 80 21 30 1 C-1 148690-59380 89 5 B
148665-51200 76 18 A 148688-61810 80 22 148690-18050 29 1 D 90 1 B
148665-51220 76 19 A 148688-61820 80 23 30 1 D 2 B
148665-51240 76 23 A 148688-61890 80 24 148690-18051 29 1 D-1 148690-59390 89 1 B
148665-51400 76 42 A 148688-61900 80 25 30 1 D-1 148690-59510 91 31
148665-51510 76 55 A 148688-61920 80 27 148690-18061 29 1 E 148690-59520 91 43
148665-51600 76 10 A 148688-61940 80 28 30 1 E 148690-59530 91 55
148665-51601 76 10 A-1 148688-61950 80 29 148690-18071 29 1 F 148690-59540 91 67
148665-51640 76 33 A 148688-61960 80 30 30 1 F 148690-59550 91 79
148665-51641 76 33 A-1 148690-01900 7 16 148690-32500 40 48 148690-59560 91 91
148665-51650 76 34 A 148690-01910 7 17 148690-34830 43 6 148690-59920 95 1
148665-51750 76 13 A-1 148690-03300 15 9 148690-43100 57 2 148690-65460 102 1
Parts No. Index
148690-65460 103 2 148692-49310 71 1 152623-51810 76 75 177561-04850 120 6
148690-65500 102 21 148692-49330 71 9 152623-51830 76 76 177561-04860 120 7
103 3 148692-49410 71 17 152623-51850 76 77 180110-51160 128 2
148690-65530 103 4 148692-49430 71 24 152623-52300 77 23 180110-51170 128 3
148690-66260 103 8 148806-01830 111 33 152623-53360 81 14 180110-54200 128 4
148690-77700 115 1 148806-01841 111 30 152623-59560 92 1 180110-66410 79 56
148690-86100 105 1 34 152623-59990 92 3 185700-00201 120 1
148690-86101 105 1 -1 148816-01820 7 5 -1 152623-61051 79 8 194180-51640 114 3
148690-86102 105 1 -2 148816-03160 14 22 152623-61420 79 96 115 4
148690-86151 105 1 A 148816-03170 14 23 152623-61430 79 142 119 1
148691-49310 70 1 148816-08200 11 14 152623-61440 79 151 198220-56160 123 38
148691-49330 70 9 148816-32280 40 19 152623-61460 79 152 198451-78680 123 45
148691-51200 76 18 148816-48910 61 2 152623-61910 79 55 21151-030252 128 34
148691-51250 76 19 16 152633-78280 109 48 21151-030322 128 35
148691-51351 76 33 148816-49710 66 10 134 5 22111-080000 79 118 -1
148691-51352 76 33 -1 67 7 152672-59560 92 2 22117-080000 79 58
148691-51361 76 34 68 20 152673-21500 36 9 118
148691-51370 76 39 -1 148816-59320 90 5 152673-51240 76 23 22117-100000 79 24
39 A-1 148928-11160 20 22 -1 152673-51250 76 24 22117-120000 23 7
148691-51380 76 38 -1 148960-11221 22 4 -1 152673-51360 76 40 121 2
148691-51390 76 39 9 -1 152673-51390 76 41 22133-160000 57 14
148691-51400 76 29 148960-11280 22 24 -1 152673-51420 76 45 22137-060000 102 22
148691-51450 76 33 -2 148961-59440 91 108 -3 152673-51430 76 47 103 11
148691-51460 76 34 -1 148965-54510 78 7 -1 152673-51660 76 62 22137-080000 14 13
148691-51700 76 29 -1 148965-54690 76 112 -1 152676-55510 84 2 13 -1
148691-51950 76 104 78 5 -1 152679-51390 76 42 15 14
148691-51951 76 104 -1 150623-91300 124 15 A-1 152696-51050 76 5 A 103 12
148691-51952 76 104 -2 151623-49380 69 2 152696-51090 76 115 13
148691-53000 81 2 70 4 152696-51370 76 36 -1 104 8
2 B-3 71 4 36 A 22137-100000 8 7
148691-53001 81 2 -1 16 152696-51380 76 38 34 11
2 B-4 72 1 152696-51850 76 77 A 64 7
148691-53002 81 2 -2 19 152696-54790 78 4 A 82 24
2 B-5 44 152923-77010 110 8 102 3
148691-53070 81 2 A 65 158805-85900 76 85 103 14
148691-54500 76 111 A 152623-14740 27 8 158835-85990 80 31 104 15
78 1 A 152623-28270 38 5 175046-05550 120 8 105 3
148691-54550 78 3 A 152623-51050 76 5 175149-11700 20 25 108 22
148691-61140 79 15 C 152623-51070 76 8 21 26 111 36
148691-61150 79 15 D 152623-51150 76 13 175149-11701 20 25 -1 118 1
148691-61160 79 15 E 152623-51170 76 15 21 26 -1 22137-120000 13 5
148691-61490 76 117 -1 152623-51181 76 16 177101-09281 129 28 24 4
80 1 -1 152623-51190 76 17 137 20 69 6 A
148692-08100 11 13 A 152623-51270 76 25 177125-04680 53 21 11 A
148692-08110 11 13 B 152623-51450 76 48 177501-09051 129 27 70 8 A
148692-18100 35 5 A 152623-51510 76 55 137 19 15 A
148692-18350 31 11 152623-51540 76 59 177503-04311 120 2 71 8 A
148692-18370 31 13 152623-51750 76 69 177503-04390 120 3 15 A
148692-18510 35 3 A 152623-51760 76 70 177503-04400 120 4 23 A
148692-18511 35 3 A-1 152623-51800 76 74 177561-04630 120 5 30 A
Parts No. Index
22137-120000 72 4 A 22217-040000 116 12 22312-080100 20 28 23000-013000 95 11
5 A 22217-050000 79 94 21 28 A 23000-022000 14 20
12 A 22217-060000 17 5 22312-100200 92 5 23000-054000 69 4
13 A 76 89 22312-100250 121 3 9
23 A 79 61 22312-100630 55 32 70 6
24 A 102 11 22312-120200 11 3 13
34 A 103 15 5 71 6
35 A 22217-080000 58 53 22312-120280 1 20 13
47 A 79 121 11 24 21
48 A 121 -2 22312-120320 1 20 -1 28
55 A 149 4 6 23010-009000 58 52
56 A 22217-100000 38 1 83 12 23010-015000 24 5
83 15 118 2 22312-120360 55 27 35 26
22137-160000 7 19 22217-120000 1 31 22322-030180 77 29 23034-030030 108 23
54 1 4 8 79 38 23061-070500 128 37
22137-200000 11 10 76 90 22322-040220 79 123 23061-071700 58 48
22 111 9 22351-050010 76 119 23111-100007 108 4
29 121 5 80 36 23111-120007 108 5
55 14 22217-140000 78 12 22411-160150 79 124 -1 23112-010007 116 26
22137-240000 57 17 79 62 22411-200150 128 36 117 30
130 7 108 3 22417-160100 102 17 23112-100000 108 26
22157-200000 11 11 109 42 103 16 23112-120007 108 6
22190-060001 79 119 110 2 22417-160120 79 67 23163-100007 108 7
22190-060002 67 33 111 8 22417-160150 79 124 23163-120007 108 8
22190-080000 80 32 134 6 22417-200120 103 17 23211-015015 54 2
22190-080002 79 120 -1 135 34 22417-200160 104 9 23211-050061 16 1
85 33 22242-000100 79 25 22451-200000 36 10 23211-065077 61 9 A
22190-080003 5 5 22242-000110 79 63 22486-080220 103 18 11
6 5 22242-000160 23 9 22512-050120 79 126 16 A
79 120 22242-000320 22 15 22512-070140 111 25 62 9 A
22190-100002 80 33 22252-000140 77 7 B 22512-070200 55 12 63 11 A
22190-120002 76 87 22252-000520 111 24 76 93 A 23211-150166 32 13
79 59 22252-000620 37 10 22512-070222 76 92 17
22190-140002 85 31 55 8 22512-070320 57 15 21
22190-160001 23 14 -1 22252-000800 57 12 22512-100260 56 15 33 7
22190-160002 76 88 22252-000900 56 14 22512-100340 76 93 23211-200218 32 1
22190-160003 23 14 22272-000060 80 34 22512-100360 82 18 5
117 9 22272-000070 79 64 22512-120300 82 13 10
22190-200003 91 109 22276-000060 80 34 -1 22512-120450 26 7 33 2
22190-220002 79 60 22276-000070 79 64 -1 22522-030100 79 68 23221-340001 9 7
22190-360002 58 42 -1 22287-080000 80 35 102 9 132 13
42 -2 22312-040120 27 7 103 19 23221-610001 67 20
67 22312-060060 36 5 104 3 23297-060081 136 5
116 16 22312-060080 1 21 E 22522-040130 79 127 23297-060121 52 5
117 17 22312-060100 1 12 22522-070220 40 23 95 14
22212-040000 124 7 22312-060120 1 53 22624-200030 17 12 96 6
22212-050000 105 10 79 122 27 7
106 5 22312-060140 79 65 22724-800380 118 3 97 7
22212-080000 79 121 -1 66 23000-013000 24 34 16
22213-080000 56 13 22312-080100 1 17 58 51 126 16
Parts No. Index
23297-060121 126 17 23414-120000 95 9 23414-170000 67 40 23421-360000 72 2
18 96 5 68 7 10
30 97 8 23414-180000 1 39 20
136 6 116 18 49 12 32
23297-080081 93 17 117 19 51 2 45
23297-080121 133 11 126 6 23414-180023 77 32 53
23297-100121 14 21 19 23414-200000 1 21 B 23421-440000 69 5
15 24 31 41 11 10
93 4 39 21 70 7
23297-120081 51 4 44 50 3 -1 14
23297-120121 49 13 136 8 5 -1 71 7
23297-150121 54 3 23414-130000 1 44 54 4 14
114 4 42 17 79 128 22
23297-180121 114 5 43 5 -1 85 13 29
23297-200121 114 6 57 19 87 5 72 3
23297-250121 49 23 23414-140000 8 6 B 8 11
23311-060001 85 34 A 9 8 89 4 21
95 13 43 5 8 33
97 17 86 17 17 46
23351-080000 128 38 18 18 54
23414-080000 97 6 128 40 90 7 66
99 1 131 6 8 73
23414-100000 24 11 132 6 9 23421-510000 14 26
27 133 13 22 23428-260000 49 18
35 23414-160000 1 41 23 23428-360000 9 10
67 35 7 14 126 45 132 14
85 11 14 18 23414-210000 25 5 23428-620000 67 21
133 12 18 -1 31 4 23431-065000 61 3
23414-100014 117 10 25 15 6
23414-110000 128 39 15 25 41 20 12
23414-120000 1 37 42 13 58 5 A 17
42 50 3 64 11 62 6
14 10 5 65 4 63 9
15 15 97 9 127 3 23432-015000 54 5
24 6 101 3 5 23438-050000 16 2
13 136 10 23414-220000 52 8 23440-150000 33 8
28 23414-170000 1 46 9 23440-200000 33 3
42 10 24 7 23414-220029 79 60 -1 23691-020010 85 14
52 7 34 13 23414-250000 35 10 23821-060001 85 34 B
58 40 35 20 23414-250031 77 33 95 12
64 15 41 13 23414-270000 67 17 97 18
15 -1 42 15 68 8 23831-060000 126 40
66 5 48 6 23414-300000 8 4 23831-100000 14 19 -1
67 15 12 9 9 15 26
39 58 33 54 18 50 2
68 6 59 6 131 5 23831-120000 49 11
81 16 64 9 132 5 23831-150000 50 2 -1
85 12 9 -1 23414-330000 42 11 4 -2
93 3 65 3 108 24 54 6
16 67 13 23414-360000 1 19 23854-060000 24 29 -1
Parts No. Index
23854-060000 24 29 -2 23884-120002 67 41 23897-040002 58 4 A 24321-002300 58 26
126 7 -1 23887-020002 41 22 64 10 24326-000300 41 6
20 -1 23887-080002 79 129 65 6 24326-000400 20 11
136 7 23887-100002 80 37 79 70 21 12
23854-080000 133 14 23887-120002 1 36 23970-150001 32 14 24326-000450 42 18
23854-100000 136 9 43 18 46 12
23857-030000 97 5 24 8 23970-200001 32 2 12 -1
23857-060000 24 29 42 9 6 24326-000500 48 4
52 10 58 39 24101-062054 55 7 9
93 2 64 13 111 26 24326-001900 35 6
15 66 4 24101-062074 57 11 24341-000140 91 103
95 8 76 96 24101-062104 82 7 24341-000900 76 91
96 4 79 69 24101-063054 55 6 24356-190180 76 64 -1
97 10 23887-140002 8 6 A 24101-063074 57 10 24421-405508 56 21
126 7 9 11 24101-063084 56 16 82 10
20 86 19 24101-063104 82 6 24423-355511 57 9
32 131 7 24211-050002 82 8 25132-002800 111 14
46 132 7 24231-050000 82 9 14 A
23857-100000 1 48 23887-160002 1 40 24311-000070 128 41 26013-080302 76 98
14 19 76 97 24311-000080 79 71 26013-120302 13 4
50 4 23887-180002 1 38 130 26106-060102 109 45
97 11 23887-200002 1 21 A 24311-000110 79 131 110 3
23857-120000 51 3 41 10 24311-000120 80 38 26106-060122 17 6
23857-150000 54 7 85 16 24311-000160 80 39 109 45 -1
87 4 23893-030002 67 12 24311-000180 128 42 110 3 -1
7 68 10 24311-000250 55 10 119 9
89 3 23893-060002 67 16 24311-000400 56 17 134 11
7 68 11 85 17 135 35
90 3 23894-020002 57 20 24311-000420 81 17 26106-060142 40 26
10 23894-030002 58 34 24312-000050 79 72 80 40
23857-180000 52 11 67 42 24312-000070 79 132 26106-060162 79 74
12 23894-040002 25 4 24312-000200 79 73 75
23875-040000 59 7 31 5 24316-000140 41 7 124 8
23875-100000 64 20 16 91 107 26106-060182 79 76
23876-005000 22 14 23897-010002 24 10 24316-000220 91 104 80 41
23876-010000 1 16 23897-020002 1 45 24316-000320 12 4 102 10
20 4 42 16 24316-000480 44 7 103 20
21 4 23897-030002 1 47 45 7 26106-060202 102 10 -1
57 21 24 9 24316-570480 2 7 104 4
23876-030000 20 5 34 12 24321-000700 56 18 126 33
21 5 35 19 24321-000800 64 3 26106-060222 79 133
24 3 41 12 65 7 136 11
23876-040000 1 15 42 14 24321-000900 64 18 26106-060252 126 47
10 5 48 5 65 11 26106-060302 47 6
20 6 11 24321-000950 64 17 26106-080122 7 11
21 18 A 59 8 65 12 93 18
64 12 64 8 24321-001000 56 19 104 13
23877-040000 35 20 A 8 -1 57 23 120 18
23883-120002 67 14 65 5 24321-001300 56 20 19
68 9 23897-040002 41 19 24321-002100 57 6 20
Parts No. Index
26106-080142 40 20 26106-100182 98 3 26106-100252 64 4 -1 26106-100352 65 13
26106-080162 14 12 26106-100202 4 5 -1 19 67 11 -1
12 -1 12 -1 65 9 68 12
15 16 7 7 22 94 8
58 35 20 17 66 3 26106-100402 7 8
54 21 18 8 15 7
57 25 8 67 3 34 5
80 42 16 38 40 46
82 15 34 20 74 2 73 5
26106-080182 14 11 55 22 2 -1 26106-100452 12 3
15 17 57 18 84 17 34 31
79 134 58 36 85 38 49 10 -1
105 6 59 9 104 12 20
26106-080202 5 4 -1 65 21 111 12 26106-100502 12 3 -1
6 4 -1 68 23 16 42 19 -1
14 11 -1 75 3 -1 125 3 49 10
15 17 -1 82 11 26106-100282 41 14 59 10
26 5 105 4 55 26 73 3
105 6 -1 111 35 56 25 6
26106-080222 76 121 118 4 57 27 85 39
79 77 26106-100222 1 28 98 4 39 -1
80 43 3 3 125 4 26106-100552 14 6
26106-080252 5 4 42 20 26106-100302 8 11 108 25
6 4 48 3 9 12 26106-100602 48 8
34 18 7 13 55 31
49 15 -1 54 9 10 3 58 38
26106-080302 23 3 58 37 3 -1 64 5
49 15 64 4 15 6 26106-100652 41 8
56 23 65 8 34 9 26106-100702 35 21
79 135 75 3 40 41 46 14
92 4 26106-100252 1 24 41 14 -1 14 -1
6 28 -1 44 8 -1 73 4
26106-080322 79 78 3 3 -1 45 8 -1 26106-100752 7 9
26106-080352 119 10 14 3 49 21 35 12
26106-080452 34 16 3 -1 55 26 -1 26106-100802 41 15
26106-080852 23 5 15 5 56 25 -1 26106-100902 42 19
26106-080902 76 122 34 21 58 63 -2 26106-101052 67 4
80 44 41 9 64 19 -1 26106-101102 35 22 -1
26106-081052 23 6 42 20 -1 65 23 26111-200452 11 25
26106-100122 82 21 44 8 67 11 26113-060102 58 25
26106-100162 49 14 45 8 89 19 26113-060122 58 25 -1
19 46 13 111 29 26113-080162 56 22
58 56 48 3 -1 124 9 26113-160452 14 27
102 4 7 -1 131 12 26116-050162 105 9
103 21 49 22 132 15 106 6
133 15 53 26 16 26116-081302 34 17
26106-100182 4 12 55 21 26106-100352 10 6 26116-101102 35 22
38 9 58 37 -1 15 7 -1 64 6
9 -1 63 35 11 26116-101152 72 22
54 8 63 -1 38 2 26116-101402 34 10
Parts No. Index
26116-101802 8 12 26116-120302 82 26 26203-120302 63 10 26366-060002 124 10
9 14 132 18 26203-120352 61 4 126 34
131 13 26116-120352 65 24 26203-120452 61 7 136 12
132 17 67 19 -1 13 26366-080002 34 28
26116-120202 68 24 68 13 18 58 55
83 21 121 4 62 7 58
26116-120252 31 7 26116-120402 16 3 26206-080162 99 2 72 25
17 58 62 106 7 36
18 26116-120902 23 4 26206-100182 4 5 80 46
67 19 26116-121152 83 14 26206-100302 54 11 105 7
26 26116-121202 83 13 26206-120302 121 1 120 23
68 25 111 5 26206-120452 84 18 24
69 6 26116-121252 94 7 26213-120302 25 14 26366-100002 10 4
11 26116-121602 7 12 26216-100222 46 8 15 8
70 8 26116-140352 35 24 26216-100252 44 5 34 6
15 26116-141502 111 4 45 5 41 23
71 8 26116-160252 65 25 46 16 44 6
15 26116-160502 67 22 26216-100302 1 21 45 6
23 26116-160552 32 15 111 16 -1 46 9
30 19 16 -2 17
72 67 22 26216-100402 85 42 48 10
74 33 9 26216-100752 111 37 54 12
84 13 67 22 -1 26216-101002 56 26 56 27
26116-120282 72 12 26116-200602 32 3 57 28 57 29
34 26116-200652 32 3 -1 26216-101102 111 38 58 30
55 33 4 26216-101402 41 24 65 14
26116-120302 4 7 26116-200702 32 7 26216-121202 1 29 26
9 15 11 26226-060162 76 99 74 4
24 16 26138-120252 78 13 26226-080252 34 27 4 -1
67 26 -1 26138-120402 78 14 26226-100252 85 18 4 -2
69 6 -1 26152-160252 7 20 26226-100352 58 27 82 25
11 -1 26152-160402 7 21 26226-100382 85 18 -1 85 40
70 8 -1 26152-180252 27 9 -1 26232-160402 1 33 89 20
15 -1 26156-100404 111 10 26232-161602 1 32 94 9
71 8 -1 26156-120202 26 9 26236-160402 121 6 104 16
15 -1 26156-140252 35 25 26292-140352 108 9 111 39
23 -1 26156-140302 27 10 109 41 124 11
30 -1 26156-140352 58 61 110 4 125 5
72 4 26156-140402 58 61 -1 134 7 130 3
5 26156-140602 78 15 135 36 26376-100002 41 5
12 -1 26156-160352 19 3 26292-141202 55 30 26376-120002 78 16
13 4 26346-060002 40 27 26450-060202 108 10
23 26156-160402 58 60 26356-200002 55 13 11
24 26156-160452 11 2 26366-060002 80 45 26450-060252 76 100
34 -1 26156-160552 54 10 102 7 26450-080222 79 77 A
35 26156-160802 11 6 103 22 26464-025000 72 26
47 26156-180302 27 9 119 11 37
48 26156-200402 26 6 12 26464-065000 65 27
55 -1 26203-120202 31 6 120 21 74 3
56 26203-120302 25 10 22 3 -1
Parts No. Index
26557-040062 116 13 26717-050002 106 9 28110-070080 129 6 29621-100000 103 28
26557-040122 124 12 26731-160002 57 13 130 20 119 16
26567-050162 79 95 -1 26732-160002 1 34 28110-080100 129 22 40000-009970 63 2
26573-040162 29 13 26732-240002 57 16 137 5 40000-011100 62 2
26577-050162 79 95 130 8 28110-100130 129 7 40000-014600 63 3
26601-140002 79 79 26736-120002 76 102 23 40000-014610 63 4
26602-140002 20 33 26736-160002 121 7 137 6 40000-014640 62 3
21 32 26736-270002 78 4 28110-120140 129 8 40000-014900 62 4
26606-100002 111 11 26756-060002 79 136 -1 24 63 5
26667-080002 80 47 102 23 137 7 40000-014910 63 6
26692-140002 22 6 103 24 28110-170190 129 9 40000-014920 63 7
11 119 13 25 41411-001581 102 6
26696-120002 79 137 120 25 137 8 103 29
26703-120002 29 8 26 28110-220240 129 10 119 14
61 8 26756-080002 34 29 137 9 120 27
14 103 25 28110-270300 129 11 41608-033480 11 13 C
62 8 26756-100002 85 41 137 10 41608-553170 11 26
26704-120002 61 19 111 40 28120-002000 129 12 41632-005130 43 1
26706-080002 79 148 26756-120002 84 19 130 21 41632-005170 43 9
148 -1 26756-200002 11 12 28160-170190 129 13 41649-000130 58 41
106 8 31 130 22 66
26706-100002 54 13 26757-080002 80 48 28160-220240 137 11 41649-552910 61 9
74 5 26772-160002 42 12 28210-000140 129 14 62 9
85 19 26772-240002 130 9 130 23 63 11
111 31 26772-270002 82 17 28312-100750 137 12 41650-501120 85 21
31 -1 26776-120002 22 21 28312-250750 137 13 41650-501140 84 3
26706-120002 111 7 79 137 -1 28312-300750 129 15 85 22
26706-140002 111 6 26776-160002 121 8 137 14 41650-501150 85 27
26713-160002 14 28 26776-200002 111 27 28312-350750 137 15 41650-501160 84 5
26716-060002 76 101 26796-100002 74 6 28312-400750 129 16 85 24
79 136 85 20 28312-500750 129 16 -1 41650-501170 84 7
26716-080002 103 23 111 32 137 16 85 25
26716-100002 58 28 32 -1 28322-020000 129 17 41650-501180 84 12
26716-120002 1 30 26911-050052 1 52 137 17 85 34
16 4 27200-400400 58 29 28551-030300 127 1 41650-501740 84 6
65 28 27210-200550 35 8 28575-620075 127 2 41650-550830 84 4
26716-160002 32 16 27241-250000 20 7 28816-990000 128 43 41701-001720 105 5
20 21 6 28886-040000 124 14 106 2
23 27241-300000 20 8 14 -1 41710-000410 105 8
33 10 21 7 28886-041025 124 22 106 3
67 23 27241-350000 1 13 28886-060530 124 15 41710-001300 105 12
26716-200002 11 9 27241-400000 20 9 28886-100000 124 15 B 106 4
23 21 8 28886-104555 124 16 41710-004030 106 1
30 25 3 29110-080010 118 5 41730-500370 107 3
32 4 27241-500000 1 14 29110-150010 118 6 41730-501200 107 1
8 27501-020000 53 1 29110-150012 118 7 41730-501250 107 2
12 27720-407001 107 5 29311-093000 103 26 41903-650040 109 43
33 5 27720-410001 107 5 A 27 110 5
26717-040002 124 13 27720-412001 107 5 B 29311-124000 111 15 A 124 25
26717-050002 105 11 27720-414001 107 5 C 29621-100000 102 24 134 8
Parts No. Index
41903-650040 135 37 43510-550590 85 15 -1 43711-102250 54 19 43730-552191 16 7
42111-000020 130 12 43521-000231 89 21 43711-102251 54 19 -1 43730-552201 66 11
42111-000980 130 13 22 43711-103530 97 20 14
42111-001420 130 14 90 19 43711-103600 97 19 67 8
42111-550590 130 15 20 43711-103610 97 21 29
42112-005901 130 16 43560-550590 16 5 43711-104420 136 1 44
42112-007020 130 17 43570-023440 117 21 43711-104430 136 3 68 26
42130-016991 127 4 43570-552130 85 10 43711-105250 136 2 27
42130-400240 124 17 43590-006870 99 6 43711-572540 111 41 44100-019900 108 13
42130-551340 124 23 43590-551040 54 14 43711-572570 111 42 44100-019930 108 14
42150-556240 124 2 -1 43600-006951 85 14 -1 43720-018050 69 3 B 44100-019940 108 15
42150-556250 124 2 A-1 43600-010080 53 4 70 5 B 44100-019950 108 16
42212-026000 11 27 B 43600-010090 53 5 12 B 44100-563330 108 17
42212-026180 11 27 D 43600-010100 53 6 71 5 B 44100-564130 108 19
42212-026280 11 13 D 43600-010110 53 7 12 B 44100-564340 108 18
42212-026290 11 13 E 43600-010120 53 8 20 B 45220-551780 38 3
42212-500370 11 27 43600-010130 53 9 27 B 45423-023290 39 3
42212-501360 11 27 C 43600-010141 53 10 43720-018700 16 6 -1 45423-023400 39 1
42212-550800 11 19 43600-010150 53 11 43720-550960 32 24 45423-571940 39 2
42212-551190 11 20 43600-010160 53 12 43720-555060 16 6 45511-006890 101 4
27 A 43600-010170 53 13 43720-561870 72 8 45521-010781 104 11
42215-570330 58 44 43600-010210 53 14 16 45521-020670 39 4
42215-570340 58 46 43600-021660 61 10 29 45521-552460 11 21
42215-581470 102 19 43600-021920 63 1 40 45522-550050 11 28
42221-021220 124 18 43600-025971 61 15 51 46111-018771 99 7
42221-554790 17 22 43600-028190 62 1 59 46111-045600 100 5
42222-003380 124 19 43662-065010 61 1 68 46111-045610 100 1
42222-550301 17 7 43665-077010 61 5 75 46111-045620 100 2
42222-551580 17 25 A 43711-087520 54 15 43720-563350 66 13 46111-045630 100 3
42430-015330 63 8 43711-096980 54 16 67 7 B 46111-045640 100 4
42430-015400 62 5 43711-096981 54 16 -1 68 20 B 46111-045960 100 6
43100-552880 108 12 43711-097370 96 8 43720-563360 67 27 B 46111-047970 100 7
43100-552881 108 12 -1 43711-097371 96 8 -1 68 19 B 46116-000680 104 1
43100-553541 33 1 43711-097390 97 13 43730-014240 97 7 -1 46120-000950 118 8
43100-569941 33 6 43711-097400 97 14 43730-026500 54 17 46120-551450 110 6
43230-014360 99 3 43711-097401 97 14 -1 43730-026710 72 30 135 38
43230-014440 99 4 43711-097540 72 6 43730-026720 72 41 46150-001150 124 20
43230-027840 98 5 14 43730-552121 88 2 46150-003620 122 44
43230-027841 98 5 -1 49 43730-552141 47 7 123 48
43230-027842 98 5 -2 57 8 46150-005190 124 24
43230-027850 99 5 43711-097550 72 7 43730-552151 14 1 46150-005191 124 24 -1
43230-556830 58 43 43711-097560 72 15 72 9 46150-026100 101 1
43320-001250 9 16 43711-097570 72 27 17 46150-049971 101 2
132 19 43711-097580 72 28 31 46150-500470 124 21
43320-550420 53 27 43711-097590 72 38 42 46150-504710 117 18
43321-000860 53 28 43711-097600 72 39 52 46150-552450 116 17
43400-004792 65 29 43711-097610 72 50 60 46150-570800 115 11
43400-500410 84 11 43711-097620 72 58 69 46150-571090 115 6
43400-501170 84 9 43711-098090 97 15 76 46150-571100 115 5
43416-000060 58 42 43711-098690 97 12 43730-552171 14 30 46150-571270 117 22
Parts No. Index
46150-571360 102 18 748620-54371 82 1 748960-11151 22 1 -2 X1330038009 110 12
46150-571380 102 20 748620-92010 129 1 748960-11310 23 8 -1 X1331034009 110 14
46150-573490 107 4 748640-23140 37 11 A 748960-11871 22 2 -1 X1331043309 109 5
719195-92500 129 19 748640-23150 37 11 B 748960-11881 22 7 -1 X133107510X0 135 3
726616-32200 40 28 748640-23160 37 11 C 748960-11891 22 12 -2 X1338021009 110 48
726677-92110 137 1 748640-23170 37 11 D 752623-61430 79 80 X134100200X0 135 25
728633-32200 40 34 748640-23180 37 11 E 80 A X134200420X0 135 18
737600-93103 128 1 748640-23190 37 11 F 949162-23200 30 14 -1 X1350091019 110 45
740623-39342 53 2 748640-55100 85 1 977780-02411 60 1 X1350129019 109 33
744626-92400 11 7 748660-01540 8 1 977780-03000 60 9 X135017810X9 135 28
748609-61510 79 36 748660-01550 131 1 X0044021509 60 7 X135304821 109 37
748620-01701 1 1 748660-11050 20 1 A-3 X0307150415 86 4 X135903700 109 36
748620-01702 1 1 -1 748660-11051 20 1 A-4 X0307160715 85 28 X1359051006 109 35
748620-01703 1 1 -2 748660-11052 20 1 A-5 X0313080110 86 8 X1359063006 109 34
748620-01704 1 1 -3 748660-11500 20 1 A X0314080110 86 13 X135913300X0 135 29
748620-01705 1 1 -4 748660-11501 20 1 A-2 X0318121011 60 2 X1361035000 110 37
748620-01706 1 1 -5 748660-18111 35 1 X0321101210 86 11 X136106201 109 19
748620-01900 2 1 748660-18112 35 1 -1 X0353101112 86 9 X136107400X0 135 21
748620-02590 1 10 748660-18113 35 1 -2 X0550720700 30 15 -1 X137100020X0 135 14
748620-02770 1 54 748660-22500 37 3 A X0582980573 86 3 X1372036000 110 34
748620-02780 1 57 748660-22800 37 1 A X0588080273 86 7 X137204501 109 25
748620-02940 1 62 748660-42011 56 1 12 X137300010X0 135 16
748620-02950 1 60 748660-42012 56 1 -1 X0588100773 86 10 X158606402X 60 3
748620-11050 20 1 -2 748660-43010 55 1 X0602250122 86 5 X179100022X 60 5
748620-11051 20 1 -3 748660-44801 58 1 X121100320 113 2 X179100100X 60 6
748620-11052 20 1 -4 748660-77200 111 17 X121114620 112 2 X190602610 112 11
748620-11152 22 1 748665-51310 76 1 A X122105800 113 23 X190602900 113 8
748620-11153 22 1 -1 748665-51311 76 1 A-1 X1221074000 112 19 X198010300 113 36
748620-11201 22 2 748665-53100 81 1 B X123015301 113 3 X198011201 112 31
748620-11212 22 7 748665-53101 81 1 B-1 X123104800 113 20 X199906101X 60 8
748620-11251 22 12 748665-53102 81 1 B-2 X123500010 113 5 X2046113009 110 41
748620-11252 22 12 -1 748665-61430 79 80 A-1 X123500110 113 6 X220201011 112 24
748620-11261 22 17 748665-61431 79 80 A-2 X123504200 112 4 X224015400 113 4
748620-11311 23 8 748690-01550 132 1 X123504300 112 5 X2240162000 110 13
748620-11500 20 1 -1 748690-01700 9 1 X123517000X9 113 6 A X224016730 112 3
748620-11550 21 1 748690-43020 57 1 X123517100X7 112 4 -1 X2240213618 109 3
748620-11551 21 1 -2 748690-61430 79 80 -1 X123517220X9 112 5 -1 X224033900X0 135 4
748620-11590 21 1 -1 748690-61431 79 80 -2 X123902560 113 7 X224205920 112 20
748620-22501 37 3 748691-51300 76 1 X123902580 112 14 X224206901 113 27
748620-22803 37 1 748691-51301 76 1 -1 X123903600 112 13 X2244055210 110 31
748620-23100 37 11 748691-51302 76 1 -2 X124006301 113 26 X224406100 109 18
748620-23600 37 17 748691-53100 81 1 X125100030 112 18 X2245006000 110 24
748620-23610 37 20 1 B-3 X129100300 112 33 X224502010 109 14
748620-23620 37 22 748691-53101 81 1 -1 113 37 X2246043009 109 29
748620-32011 40 1 1 B-4 X131011700 109 2 X2425133009 110 49
748620-33010 41 1 748691-53102 81 1 -2 X131015520X0 135 2 X2441006000 110 25
748620-33011 41 1 -1 1 B-5 X1316085000 110 11 X244104100 109 16
748620-34010 42 1 748691-53120 81 1 A X1320063000 110 19 X2551034100 86 14
748620-34011 42 1 -1 748692-18110 35 1 A X132011500 109 10 X2551045000 86 6
748620-34012 42 1 -2 748692-18111 35 1 A-1 X132014210X0 135 9 X2620096109 109 30
Parts No. Index
X266000110 113 21 X4101030000 110 51 X4918255630 30 5 X641403220 109 38
X2660056000 110 18 X4101059000 110 50 X4918255650 30 4 X641407200X0 135 22
X2660074006 109 6 X4101073000 110 43 X5000083100 110 10 X641407410X0 135 27
X2660074007 109 7 X414000000 113 32 X500010500 109 9 X8160050409 113 12
X266010620X0 135 6 X414000810 112 23 X501004740 112 32 X8160050509 113 10
X2772311701 85 29 X414004200 109 32 X501016110 113 33 X8160100305 113 40
X300007810 112 29 X414129400 109 24 X5010187000 110 52 X816707175 109 13
X3000098000 110 29 X414133200X0 135 12 X5010190200 110 46 X8264143005 113 35
X3000099000 110 30 X414200900 112 25 X501019900 112 6 X8264183005 112 30
X3001116000 110 47 X421500400 113 16 X501021000 113 15 X8590407160 113 34
X3051023000 110 36 X421500800 112 12 X501021500 112 27 X859050719 112 28
X322002300 113 11 113 14 X5010233000 110 23 X8636008003 60 4
X322027600 112 15 X422305600 109 27 X5010233300 110 22
113 13 X4916223200 30 14 X5010233400 110 44
X322031600 113 9 X4918114004 30 29 X5010239000 110 35
X322123200 112 17 X4918121100 30 21 X501027300 109 40
X323205410X0 135 20 X4918121600 30 16 X501027430 109 23
X3253207320 30 39 X4918122200 30 19 X5022006000 110 53
X340005110 113 38 X4918122300 30 20 X5030021000 110 54
X340100410 113 29 X4918122500 30 13 X5031011000 110 26
X340900210 113 25 X4918122600 30 15 X503105200 109 17
X340900400 113 31 X4918122700 30 26 X5031053000 110 27
X340900500 113 30 X4918122710 30 27 X503105700 109 15
X340901320 112 26 X4918123100 30 12 X503107600X0 135 15
X340914700 112 22 X4918123500 30 36 X505804100 109 22
X340928900 109 31 X4918123700 30 28 X5058042000 110 40
X342904500X0 135 11 X4918142100 30 11 X520107500 109 39
X360017800 109 26 X4918142230 30 10 X5201086000 110 28
X360027810X0 135 19 X4918142300 30 17 X520109300 109 28
X365003300X0 135 13 X4918142400 30 18 X521000110 113 22
X366101900 109 20 X4918210460 30 30 A X522101000 109 21
X3661020000 110 38 X4918210550 30 30 X5221012000 110 39
X366102710X0 135 23 X4918210560 30 30 -1 X522102910X0 135 24
X403000100 112 8 X4918211460 30 31 X5250024000 110 15
113 19 X4918217280 30 40 X525003000 109 8
X4030055000 110 55 X4918219300 30 33 X525003200X0 135 5
X4030057000 110 17 X4918225210 30 24 X55107948A0 123 47
X404006410X0 135 8 X4918225220 30 25 X55109575A0 122 43
X404006510X0 135 7 X4918225630 30 24 -1 X620600200 112 16
X404100200 112 9 25 A X620600320 112 21
113 17 X4918225640 30 25 -1 X620600520 109 12
X404100800 113 18 X4918230130 30 22 X6206005200 110 20
X404100900 112 10 X4918230230 30 23 X620600540 109 11
X4041052000 110 9 X4918230231 30 23 -1 X6206005500 110 21
X404105600 112 7 X4918245010 30 8 X620600710 113 28
X4041060000 110 16 X4918245070 30 7 X620600760 113 24
X4101006000 110 56 9 A X620605400X0 135 26
X4101007000 110 57 X4918245120 30 9 X620605500X0 135 10
X410100800 112 34 X4918253910 30 6 X625600100X0 135 17
X410100810 113 39 X4918255250 30 6 A X6414029900 110 33
FOR SPARE PARTS & AFTER SALES SERVICE
PLEASE CONTACT:
PT. PIONEER
JALAN IR. H. JUANDA NO. 40-42, JAKARTA 10120
TEL. +62 (21) 344 8486 ; 231 2312
FAX. +62 (21) 384 8995
EMAIL: support@pioneer-trading.com

Part Catalog ME

Uploaded by

Copyright:

Available Formats

You might also like

Part Catalog ME

Uploaded by

Document Information

Original Description:

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Part Catalog ME

Uploaded by

Copyright:

Available Formats

PARTS CATALOG

FOR SPARE PARTS & AFTER SALES SERVICE

Last update Apr., 2014

Parts catalog No. Date of issue Remarks

2.Standard finish color. Yanmar ecole silver(Metallic)

6AY-ET/GT,6AYM-ETE/GTE/STE 23. BONNET

1. CYLINDER BLOCK 24. SUC.MANIFOLD

2. CYLINDER LINER & HEAD GASKET 133. (24A)AIR PIPE

3. CAMSHAFT COVER 25. EXHAUST MANIFOLD

4. GEAR HOUSING 26. CAMSHAFT

5. OIL SEAL CASE(S.F.W.) 27. IDLE GEAR

6. OIL SEAL CASE(O.F.W.) 28. WORKING VALVE DEVICE

7. FLYWHEEL HOUSING 29. TURBOCHARGER

8. LUB.OIL SUMP(STANDARD) 30. TURB.COMPONENT PART

9. LUB.OIL SUMP(SHALLOW TYPE) 31. EXHAUST BEND

131. (9A)LUB.OIL SUMP(ELASTIC MOUNTING:STANDAR) 32. BELLOWS

132. (9B)LUB.OIL SUMP(ELASTIC MOUNTING:SHALLOW TYPE) 33. SILENCER

10. COVER(O.F.W.) 34. AIR DUCT & AIR HEATER

11. ENGINE MOUNT 35. AIR COOLER

12. LUB.OIL FEEDER 36. CRANKSHAFT & FLYWHEEL

13. CAMSHAFT METAL 37. PISTON & CONNECTING ROD

14. BREATHER PIPE 38. DAMPER & V-PULLEY

15. BREATHER PIPE(ABS SPEC.) 39. CG-COUPLING

16. MIST FLEXIBLE PIPE(JG SPEC.) 40. LUB.OIL PUMP

17. LABEL 41. LUB.OIL COOLER

18. SAFETY LABEL 42. L.O.PRESS.CONTROL VALVE

19. ENGINE LIFTER 43. DIPSTICK

20. CYLINDER HEAD 44. LUB.OIL STRINER(EARTH TYPE)

21. CYLINDER HEAD(OPTIONAL) 45. LUB.OIL STRINER(EARTH FLOAT TYPE)

22. LOCKER ARM 46. LUB.OIL BY-PASS STRAINER

47. LUB.OIL WASTE PUMP 72. C.S.W.PIPE(CLUTCH IN/OUT)

48. LUB.OIL PIPE(LUB.OIL COOLER) 73. C.F.W.BEND(HEAD-EXH.MANIFOLD)

49. LUB.OIL PIPE(TURBOCHARGER) 74. SUPPORT(SEA WATER PIPE)

50. LUB.OIL PIPE(RETURN) 75. COVER(CYLINDER BLOCK)

51. LUB.OIL PIPE(BY-PASS) 76. FUEL INJECTION PUMP

52. LUB.OIL PIPE(F.I.PUMP) 77. FUEL FEED PUMP

53. LUB.OIL WING PUMP 78. COUPLING

54. LUB.OIL WING PIPE 79. GOVERNOR

55. COOLING FRESH WATER PUMP 80. BOOST COMPENSATER

56. COOLING SEA WATER PUMP 81. FUEL INJECTION VALVE

58. FRESH WATER COOLER 83. FUEL PUMP BRACKET

59. COOLING FRESH WATER THERMOSTAT 84. FUEL STRAINER(SINGLE)

60. BILGE PUMP(OPTIONAL) 85. FUEL STRAINER(DUPLEX)

61. KINGSTON VALVE 86. OIL/WATER SEPARATOR

62. SEA WATER STRAINER(SINGLE) 87. FUEL PIPE(PUMP IN)

63. SEA WATER STRAINER(DUPLEX) 88. FUEL PIPE(INLET/OUTLET HOSE)

64. C.F.W.PIPE(THERMOSTAT-PUMP) 89. FUEL PIPE(PUMP-STRAINER)(SINGLE)

65. C.F.W.PIPE(THERMOSTAT-PUMP) 90. FUEL PIPE(PUMP-STRAINER)(DUPLEX)

66. C.F.W.PIPE(L.O.COOLER-BLOCK) 91. FUEL INJECTION PIPE

67. C.S.W.PIPE(C.S.W.PUMP-AIR COOLER-F.W.COOLER) 92. SUPPORT(F.I.PIPE)

68. C.S.W.PIPE(L.C.W.PUMP-AIR COOLER-ENGINE OUT) 93. FUEL OVERFLOW PIPE(F.I.VALVE)

69. C.S.W.PIPE(CLUTCH IN/OUT) 94. FUEL PIPE(PUMP RETURN)

70. C.S.W.PIPE(CLUTCH IN/OUT) 95. FUEL OVERFLOW PIPE(F.I.PUMP)

71. C.S.W.PIPE(CLUTCH IN/OUT) 96. FUEL OVERFLOW PIPE(F.I.PUMP)

98. FUEL OVERFLOW TANK 121. CLUTCH ATTACHED BOLT

99. FUEL OVERFLOW ALARM 122. INSTRUMENT PANEL

100. SPEED RELAY 123. SUB-PANEL

101. MAGNETICK PICK-UP 124. INSTRUMENT PANEL(ENGINE ATTACHED)
