VOLUME CONTROL
DAMPERS
www.airmasteremirates.com
16.0 VOLUME CONTROL
DAMPERS
16.0 index VOLUME CONTROL DAMPERS

INDEX
SECTION TOPIC PAGE
16.1 Volume Control Damper AVCD 3

16.2 Motorized Volume Control damper AVCD-M 5
16.3 Slip & Clip Volume Control damper AVCD-SC 6
16.4 Stainless Steel Volume Control damper AVCD-SS 7
16.5 Low Leakage Volume Control damper AVCD-ZL 8
16.6 GI Volume Control Damper AVCD-GI 9
16.7 Heavy Duty Volume Control Damper AVCD-HD 10
16.8 Pre-Insulated Volume Control damper AVCD-PI 11
16.9 Circular Volume Control Damper AVCD-C 12
16.10 Product Summary 12
Cover Page
Cover Page Photo
Photo Tornado Tower, Qatar.
www.airmasteremirates.com 02
Copyright reserved. Specifications subject to change without notice.
VOLUME CONTROL 16.1
DAMPERS

VOLUME CONTROL DAMPER model: AVCD
CONSTRUCTION:
Frame: High quality Galvanized Steel sheet Bushings: Self-lubricating nylon bushings.
of thickness 1.2mm as standard. Blade linkage: Nylon gear.
Frame size: 125mm depth and standard Handle: Galvanized Steel locking hand
flange height of 25mm. quadrant.
Blades: Double skinned high quality Blade stopper: G.I angle of thickness 0.7mm.
extruded Aluminium aerofoil profiles.
Drive shaft: Electro-plated square rod of
size 12.7mm x 12.7mm.
Description:
• Designed for use in heating, ventilating and air
conditioning systems.
• Joints are welded and protected by aluminium

spray coating to prevent rusting.
• Blades are coupled by toothed nylon gears

which provides opposed blade operation.
• Hand locking quadrant is provided with clear

open/close indication and three intermediate
open positions (1/4 – 1/2 - 3/4).
• Foam gasket is sealed across the blade edges

to minimize air leakage between the blades.
• Flanged edges are supplied un-drilled as

standard.
• Dampers without flanges available as option for

duct insertion purpose.
Optional Accessories:
• Frame: Thickness upto 2mm on request.
Aluminium frame available for light weight
applications.
• Handle: Cast Aluminium.
• Bush: Brass bush, S.S. Ball Bearing. 25
• Gear Wheel: Aluminium Alloy. 125

• Blade: Low leakage: S.S Jamb seal, Nylon
blade end caps
2015 Rev. 2
03
16.1 VOLUME CONTROL
DAMPERS
PERFORMANCE CHART
model: AVCD VOLUME CONTROL DAMPER ISO 9001 CERTIFIED COMPANY
Performance chart:
Model: AVCD
75° 60°
5000
3000
45°
1000
500
30°
300
100 15°
50 0°
P(N/m2)
30
10
5
3
1
0.1 0.3 0.5 1 3 5 10 20
V(m/s)
Pressure drop - Rectangular VCD aerofoil type blades
2015 Rev. 2
VOLUME CONTROL 16.2
DAMPERS
MOTORIZED
VOLUME CONTROL DAMPER model: AVCD-M
CONSTRUCTION:
Frame: High quality Galvanized Steel sheet Drive Shaft: Electro plated square rod of
of thickness 1.2mm as standard. size 12.7mm x 12.7mm.
Frame Size: 125mm depth and standard Bushings: Self-lubricating S.S Ball bearing.
flange height of 35mm. Blade linkage: Nylon gear.
Blades: Double skinned high quality Blade stopper: G.I angle of thickness
extruded Aluminium aerofoil profiles. 0.7mm.
Description:




standard.

• Actuators of client’s choice will be supplied

separately.
• Dampers will be provided with extended spindle to

fix actuator on-site.
35
• Bigger sizes will be provided with mechanical
linkage for stability and hassle-free operation.
125
Optional Accessories:
• Frame: Thickness up to 2mm upon request.
Aluminium frame available for off-shore or light
weight applications.
• Handle: Cast Aluminium
• Bush: Brass bush, S.S. Ball Bearing.
• Gear Wheel: Aluminium Alloy.
• Low Leakage: S.S. Jamb seal, nylon blade end caps
2015 Rev. 2
05
16.3 VOLUME CONTROL
DAMPERS
SLIP & CLIP TYPE
model: AVCD-SC VOLUME CONTROL DAMPER ISO 9001 CERTIFIED COMPANY
CONSTRUCTION:
Frame: High quality Galvanized Steel sheet Blade linkage: Nylon gear.
of thickness 0.9mm as standard. Bushings: Self-lubricating nylon bushings.
Frame size: 200mm depth. Blade stopper: G.I. angle of thickness 0.7mm..
Blades: Double skinned high quality Handle: Galvanized Steel locking hand
extruded aluminium aerofoil profiles. quadrant
Drive Shaft: Electro-plated square rod of
size 12.7mm x 12.7mm
Description:



open positions (1/4 – 1/2 - 3/4).

Options:
• Low Leakage: S.S Jamb seal, Nylon blade end
caps.
200
2015 Rev. 2
VOLUME CONTROL 16.4
DAMPERS
STAINLESS STEEL
VOLUME CONTROL DAMPER model: AVCD-SS
CONSTRUCTION: Drive Shaft: S.S square rod of size 12.7mm

Frame: High quality Stainless Steel sheet x 12.7mm.
(Grade 304/316L) of thickness 1.2mm Bushings: Self-lubricating S.S or brass
depending on the size. bushings.
Frame Size: 125mm depth and standard Blade linkage: Nylon gear.
flange height of 25mm. Blade stopper: S.S angle of thickness
Blades: Single skin ridge shaped blade 0.7mm.
constructed out of 1.2mm thick S.S sheet as Handle: S.S locking hand quadrant.
standard.
Description:
• Designed for offshore applications in heating,
ventilating and air-conditioning systems.
• Can also be used in chemical industries and

kitchen ventilation.
• Joints are welded and protected by chemical

cleaning process.


open positions (1/4 – 1/2 - 3/4).
• Foam gasket is sealed across the blade edges to

minimize air leakage between the blades.

standard.

Options:
• Frame: Thickness up to 1.6mm upon request.
• Low Leakage: S.S Jamb seal.
2015 Rev. 2
07
16.5 VOLUME CONTROL
DAMPERS
LOW LEAKAGE
model: AVCD-ZL VOLUME CONTROL DAMPER ISO 9001 CERTIFIED COMPANY
CONSTRUCTION: size 12.7mm x 12.7mm.

Frame: High quality Galvanized Steel sheet Bushings: Self-lubricating nylon bushings.
of thickness 1.2mm as standard. Blade linkage: Nylon gear.
Frame size: 125mm depth and standard Blade stopper: G.I angle of thickness
flange height of 25mm. 0.7mm.
Blades: Double skinned heavy duty extruded Handle: Galvanized Steel locking hand
Aluminium profiles. quadrant.
Drive shaft: Electro plated square rod of
Description:
• Designed for use in heating, ventilating and
air conditioning systems for low-leakage
applications.



open positions (1/4 – 1/2 - 3/4).


standard.
• Dampers without flanges available as option for • Handle: Cast Aluminium.

duct insertion purpose. • Bush: Brass bush, S.S. Ball Bearing.
• Air leakage from 0.18% to 1.33% only based • Low Leakage: S.S Jamb seal.
on tests conducted in accordance with AMCA
standard 500-D-98.
Options:
• Frame: G.I sheet of thickness up to 2mm
available upon request. Aluminium frame is also
available for light weight / offshore / exposed
area applications.
2015 Rev. 2
VOLUME CONTROL 16.6
DAMPERS

GI VOLUME CONTROL DAMPER model: AVCD-GI
CONSTRUCTION:
Frame: High quality Galvanized Steel of Bushings: Self-lubricating nylon bushings.
thickness 1.2mm as standard . Blade linkage: Nylon gear/mechanical linkage
Frame Size: 125mm depth and standard Blade stopper: G.I angle of thickness
flange height of 25mm. 0.7mm.
Blades: Single skinned 3-V type G.I blade of Handle: Galvanized Steel locking hand
1.5mm thickness. quadrant.
Drive Shaft: Electro plated square rod of
Description:



open positions (1/4 – 1/2 - 3/4).

• Flanged edges are supplied un-drilled as Double skin - aerofoil

standard.

Options:
• Frame: Thickness up to 2mm upon request.
• Blade: Double skin aerofoil type G.I blade of
thickness 0.7mm.
• Low Leakage: S.S Jamb seal.
Single skin - 3V
2015 Rev. 2
09
16.7 VOLUME CONTROL
DAMPERS
HEAVY DUTY
model: AVCD-HD
VOLUME CONTROL DAMPER ISO 9001 CERTIFIED COMPANY
CONSTRUCTION: Bushings: Sintered, self-lubricating bronze

Frame: High quality Galvanized Steel sheet bearing.
of thickness 1.2mm. Blade linkage: Galvanized steel flat bars of
Frame size: 180mm depth and 30mm flange 3mm thick.
height.
Blade stopper: 1.2mm G.I angle.
Blades: Double skinned aerofoil blades
made from galvanized steel with 165mm Handle: Heavy duty G.I quadrant.
blade spacing.
Drive shaft: Electro plated rod of size
14mmØ.
Description:
• Designed for heavy duty applications in heating,
ventilating and air-conditioning systems.
• Also applicable for explosive areas.
• Frame is constructed from galvanized steel

sheet and joined using corner-keys.
• Blades are of robust construction, roll formed G.I

having 1.2mm thickness designed to withstand
high pressure without clattering.
• Service temperature ranges from -40º C to +80º C.

open and close indication.
• Rubber edge seal is provided across blade

edges to minimize air leakage between the
blades.
• Standard model available with corner borehole.
Options:
• Silicon Edge Seal: For use in service
temperature of -40º C to +200º C.
• Jamb Seal: Between blade and frame,
includes slide film and special foam plastic.
35
180
2015 Rev. 2
VOLUME CONTROL 16.7
DAMPERS
HEAVY DUTY
VOLUME CONTROL DAMPER model: AVCD-HD
Pressure Drop Curve (open damper)
140
Opening Angel 45°

120
100
Pressure Drop [Pa]
80
60
40 Opening Angel 68°
20
Opening Angel 90°
0
0,0 0,5 1,0 1,5 2,0 2,5 3,0 3,5 4,0
W [m/]s
2015 Rev. 2
11
16.8 VOLUME CONTROL
DAMPERS
PRE-INSULATED
model: AVCD-PI
VOLUME CONTROL DAMPER ISO 9001 CERTIFIED COMPANY
CONSTRUCTION: Bushings: Self-lubricating nylon bushings.

Frame: 20mm thick polyurethane material Blade linkage: Nylon Gear.
with 2-sides Aluminium foil facing. Blade stopper: G.I angle of thickness
Frame Size: 200mm depth with flanges for 0.7mm.
side-fixing. Handle: Galvanized Steel locking hand
Blades: Double skinned high quality quadrant.
extruded Aluminium aerofoil profiles.
Drive Shaft: Electro plated square rod of
Description:
conditioning systems in open/limited access
areas and light weight applications.
• The edges are joined using special glue and

silicon.

which provides opposed blade operationn.

open positions (1/4 – 1/2 - 3/4).

Options:
• Frame: Thickness up to 25mm available upon
request.
• Bush: Brass bush.
200
2015 Rev. 2
VOLUME CONTROL 13.7
16.9
DAMPERS
CIRCULAR
VOLUME CONTROL DAMPER model: AVCD-C
CONSTRUCTION:
Frame & Blade: High quality Galvanized Bushings: Self-lubricating nylon bushings.
Steel.
Bearing pins: Electro plated steel rod of Handle: Galvanized Steel locking hand
10mmØ with square transition of size 12.7mm quadrant.
x 12.7mm
Description:
• Damper blades are fixed to the bearing pin

(which is coupled with hand locking quadrant)
and can be fully opened or closed.

open positions (1/4 – 1/2 - 3/4).
• Foam gasket is provided on the inner frame Round VCD with flange. Model AVCD-CF
surface.
Options:
• Bush: Brass bush
• Actuator: Of clients choice for motorized
applications
Dimensions:
D = Diameter L = Length Sheet Thickness
100 to 150 mm L = D+ 50 mm 0.7 mm
200 to 500 mm L=D 0.9 mm
550 to 1000 mm L = D+ 50 mm 1.2 mm
1000 mm&above L = D+ 100 mm 1.5 mm
Standard sizes:
D = Duct opening in mm dia
100 200 300 400 500 600
700 800 900 1000 1100 1200
Fixing details:
• Fixing by using Jubilee clip to flexible duct.
2015 Rev. 2
13
16.9 VOLUME CONTROL
DAMPERS PERFORMANCE CHART
model: AVCD-C VOLUME CONTROL DAMPER
Performance chart:
Model: AVCD-C
75° 60° 45°

5000
3000
30°
1000
500
15°
300
0°
100
50
P(N/m2)
30
10
5
3
1
0.1 0.3 0.5 1 3 5 10 20
V(m/s)
Pressure drop - Circular VCD
2015 Rev. 2
VOLUME CONTROL 16.10
13.7
PRODUCT SUMMARY & DAMPERS
ORDER CHECKLIST
Product Summary:
Model Product Description Remarks
AVCD GI Frame with double skin Al.Blades Manual Quadrant

AVCD-M GI Frame with double skin Al.Blades With actuator
AVCD-SC Slip & Clip type
AVCD-SS SS Frame with double skin SS blade Option: Single skin SS blade
AVCD-ZL GI Frame with double skin Al.Blades With Jamb seal for Low leakage
AVCD-GI GI Frame with double skin GI blade Option: Single skin GI blade
AVCD-HD Heavy Duty VCD
AVCD-PI Pre-Insulated VCD
AVCD-C Round/Circular VCD Manual Quadrant
Product Order check list:

• Model
• Size in Length x Width
• Quantity
• Refer options available for each product
Product Installation:

15
AIR MASTER EQUIPMENTS EMIRATES LLC.

Post Box - 3180, Ajman, U.A.E.
Tel: +971 6 7436900, 7439600 Fax: +971 6 7436700
E-mail: airmastr@eim.ae, sales@airmaster.ae

Air Master VCD

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Air Master VCD

Uploaded by

Copyright:

Available Formats

ARS O

ISO 9001 CERTIFIED COMPANY

16.0 index VOLUME CONTROL DAMPERS

16.1 Volume Control Damper AVCD 3

ISO 9001 CERTIFIED COMPANY

• Joints are welded and protected by aluminium

• Blades are coupled by toothed nylon gears

• Hand locking quadrant is provided with clear

• Foam gasket is sealed across the blade edges

• Flanged edges are supplied un-drilled as

• Dampers without flanges available as option for

• Gear Wheel: Aluminium Alloy. 125

Pressure drop - Rectangular VCD aerofoil type blades

• Joints are welded and protected by aluminium

• Blades are coupled by toothed nylon gears

• Foam gasket is sealed across the blade edges

• Flanged edges are supplied un-drilled as

• Dampers without flanges available as option for

• Actuators of client’s choice will be supplied

• Dampers will be provided with extended spindle to

• Joints are welded and protected by aluminium

• Blades are coupled by toothed nylon gears

• Hand locking quadrant is provided with clear

• Foam gasket is sealed across the blade edges

CONSTRUCTION: Drive Shaft: S.S square rod of size 12.7mm

• Can also be used in chemical industries and

• Joints are welded and protected by chemical

• Blades are coupled by toothed nylon gears

• Hand locking quadrant is provided with clear

• Foam gasket is sealed across the blade edges to

• Flanged edges are supplied un-drilled as

• Dampers without flanges available as option for

CONSTRUCTION: size 12.7mm x 12.7mm.

• Joints are welded and protected by aluminium

• Blades are coupled by toothed nylon gears

• Hand locking quadrant is provided with clear

• Foam gasket is sealed across the blade edges

• Flanged edges are supplied un-drilled as

• Dampers without flanges available as option for • Handle: Cast Aluminium.

ISO 9001 CERTIFIED COMPANY

• Joints are welded and protected by aluminium

• Blades are coupled by toothed nylon gears

• Hand locking quadrant is provided with clear

• Foam gasket is sealed across the blade edges to

• Flanged edges are supplied un-drilled as Double skin - aerofoil

• Dampers without flanges available as option for

CONSTRUCTION: Bushings: Sintered, self-lubricating bronze

• Also applicable for explosive areas.

• Frame is constructed from galvanized steel

• Blades are of robust construction, roll formed G.I

• Service temperature ranges from -40º C to +80º C.

• Hand locking quadrant is provided with clear

• Rubber edge seal is provided across blade

• Standard model available with corner borehole.

Pressure Drop Curve (open damper)

Opening Angel 45°

40 Opening Angel 68°

Opening Angel 90°

CONSTRUCTION: Bushings: Self-lubricating nylon bushings.

• The edges are joined using special glue and

• Blades are coupled by toothed nylon gears

• Hand locking quadrant is provided with clear

• Foam gasket is sealed across the blade edges to
