Seneca QRH

5
PA34-220T
Piper Seneca V
Quick Reference
Handbook
Revision 05
1 January 2020
Reference No: PTR-TRM-70
Your worldwide
training partner
of choice
The Materials contained herein are the sole property of CAE Aviation
Academy. No part of this publication may be reproduced or transmitted in
any form or by any means, electrical, mechanical, photocopying, recording or
otherwise used in any manner whatsoever without the express permission of
CAE Aviation Academy.
PA34-220T QRH
INDEX OF EMERGENCY AND ABNORMAL CHECKLISTS
INDEX
Air Data Computer (ADC) Failure.................................................................43
Alternator Failure - Double...........................................................................52
Alternator Failure - Single.............................................................................55
Aspen In-Flight AHRS Reset........................................................................42
Attitude and Heading Reference System Failure.........................................44
Autopilot Malfunction....................................................................................30
Avionics Cooling Fan Failure........................................................................45
Baggage Door Open....................................................................................38
Communications Failure..............................................................................47
Complete Loss of Engine Power..................................................................88
Crew Alerting System (CAS) Failure............................................................46
Cylinder Head Temperature (CHT)..............................................................59
Electrical Fire in Flight..................................................................................32
Emergency Battery Failure...........................................................................57
Emergency Descent.....................................................................................39
Engine Failure / Fire in Flight.......................................................................34
Engine Failure in Icing Conditions................................................................60
Engine Fire During Start...............................................................................33
Engine / Fuel Display Failure........................................................................67
Engine Power Overboost..............................................................................87
Engine Securing Procedure..........................................................................61
E VOLT Pre Flight Test Fail..........................................................................56
Fuel Management During One Engine Inoperative......................................72
Fuel Pump Failure........................................................................................70
Fuel Quantity.................................................................................................71
Gear Extension - Manual..............................................................................73
Gear Pump Failure.......................................................................................74
Gear Pump Overrun.....................................................................................75
Published by CAE Aviation Academy

© CAE Aviation Academy All Rights Reserved 3
PA34-220T QRH
Gear System - Flight.....................................................................................76

INDEX
Gear System - Ground.................................................................................77

Gear Up Landing Procedure........................................................................78
GPS Dead Reckoning (DR) Mode...............................................................48
GPS Loss of Integrity (LOI) Mode................................................................49
Heater (Cabin) Overheat..............................................................................80
Main Battery Failure.....................................................................................58
MFD Failure..................................................................................................51
Oil Pressure - High.......................................................................................63
Oil Pressure - Low........................................................................................64
Oil Temperature............................................................................................65
Partial Loss of Engine Power........................................................................89
PFD1 Failure................................................................................................50
PFD2 Failure.................................................................................................51
Pitch Trim Runaway......................................................................................31
Pitot Heat Failure..........................................................................................81
Propeller Heat Failure...................................................................................82
Propeller Heat Malfunction...........................................................................83
Propeller Overspeed.....................................................................................36
Rejected Take-Off (RTO).............................................................................40
Spin Recovery...............................................................................................41
Starter Engaged...........................................................................................37
Surface De-Ice Failure..................................................................................84
Turbine Inlet Temperature (TIT)...................................................................66
Turbine Inlet Temperature (TIT) Indicator Failure.........................................68
Unfeathering Procedure...............................................................................62
Vacuum Pump Failure - Double....................................................................85
Vacuum Pump Failure - Single.....................................................................85
Windshield Heat Failure...............................................................................86

4 © CAE Aviation Academy All Rights Reserved
PA34-220T QRH
CAS MESSAGES
INDEX
CAS Message CAS Event
Alternator failure - Single, page 55

ALTR FAIL
Alternator failure - Double, page 52
BAGGAGE DOOR Baggage Door Open, page 38
ENG CHT Cylinder Head Temperature (CHT), page 59
FUEL QTY Fuel Quantity, page 71
GEAR SYS Gear System - Ground, page 77
HTR OVRHEAT Heater (Cabin) Overheat, page 80
PROP HEAT FAIL Propeller Heat Failure, page 82
START ENGD Starter Engaged, page 37
GEAR SYS Gear System - Flight, page 76
HYDR PUMP ON Gear Pump Overrun, page 75
PITOT HEAT FAIL Pitot Heat Failure, page 81
SURF DEICE FAIL Surface De-Ice Failure, page 84
VAC PRESS LOW Vacuum Pump Failure - Double, page 85
AV FAN FAIL
MFD FAN FAIL
Avionics Cooling Fan Failure, page 45
PFD1 FAN FAIL
PFD2 FAN FAIL
EMERG BATT ON Main Battery Failure, page 58
VAC FAIL Vacuum Pump Failure - Single, page 85

PA34-220T - NORMAL CHECKLIST
PRELIMINARY INSPECTION
A CHECK
Tie-down Straps...............................................................REMOVE & STOW

Aircraft Document Bag.........................................................................STOW
Windscreen................................................................CLEAN AS REQUIRED
THE A CHECK
Park Brake...................................................................EXERCISE THEN ON
First Aid Kit.........................................................................................CHECK
Fire Extinguisher................................................................................CHECK
IF Hood..............................................................................................CHECK
Partial Panel Screen..........................................................................CHECK
Checklist............................................................................................CHECK
Camera..............................................................................CHECK/SECURE
Static System......................................................................................DRAIN
Eng Mags................................................................................................OFF
Fuel Pumps.............................................................................................OFF
Flight Controls....................................................................................CHECK
Gear Selector......................................................................................DOWN
Throttles.................................................................................................IDLE
Mixtures..........................................................................................CUT-OFF
Alternate Static................................................................................NORMAL
Cowl Flaps............................................................................................OPEN
Trim..................................................................EXERCISE THEN NEUTRAL
Fuel...........................................................................................................ON
Avionics Master.......................................................................................OFF
All Electrical Switches..............................................................................OFF
Battery Master...........................................................................................ON
Flaps..........................................................................................................40°
Gear Indications............................................................................3 GREENS
Fuel Quantity.....................................................................................CHECK
Interior Lights (Night)..........................................................................CHECK

All Exterior Lights......................................................................................ON

Pitot/Stall Warn Heat.................................................................................ON
Wing Ice Light...........................................................................................ON
Pitot Head..............................................................................CHECK WARM
Stall Warning Vanes...............................................................CHECK WARM
All Exterior Lights...............................................................................CHECK
A CHECK
Pitot/Stall Warn Heat...............................................................................OFF
All Lighting Switches................................................................................OFF
Heater Fan.........................................................................................CHECK
Battery Master.........................................................................................OFF
Standby Instrument................................................................CONFIRM OFF
Crossfeed Drains................................................................................DRAIN

A CHECK - STARBOARD WING

Crossfeed Drains................................................................CHECK CLOSED
Surface Condition..............................................................................CHECK
Flap and Hinges.................................................................................CHECK
Aileron................................................................................................CHECK
Static Wicks.......................................................................................CHECK
A CHECK
Wing tip and Lights............................................................................CHECK

Fuel Filler Cap....................................................................................CHECK
Fuel Quantity and Colour...................................................................CHECK
Fuel Filler Cap.................................................................................SECURE
Surface De-Ice Boots.........................................................................CHECK
Fuel Tank Vent.......................................................................CHECK CLEAR
Wing Tank Drains (2)...........................................................................DRAIN
Fuel Filter Drain...................................................................................DRAIN
Engine Cowling..................................................................................CHECK
Engine Oil and Cap............................................................................CHECK
Propeller and Spinner........................................................................CHECK
Air Inlets................................................................................CHECK CLEAR
Cowl Flap Area...................................................................................CHECK
Main Gear Strut..................................................................................CHECK
Tyre and Gear Door............................................................................CHECK
Brake, Block and Disc........................................................................CHECK

A CHECK - NOSE SECTION

General Condition..............................................................................CHECK
Windshield.........................................................................................CHECK
Landing Lights...................................................................................CHECK
Tow Bar...........................................................................CHECK REMOVED
Chock.............................................................................CHECK REMOVED
A CHECK
Nose Gear Strut.................................................................................CHECK
Tyre and Gear Doors..........................................................................CHECK
Forward Baggage..............................................................................CHECK
Hydraulic Fluid Level..........................................................................CHECK
Forward Baggage Door....................................................................SECURE

A CHECK - PORT WING

Main Gear Strut..................................................................................CHECK
Tyre and Gear Door............................................................................CHECK
Brake, Block and Disc........................................................................CHECK
Cowl Flap Area...................................................................................CHECK
A CHECK
Engine Cowling..................................................................................CHECK
Propeller and Spinner........................................................................CHECK
Air Inlets................................................................................CHECK CLEAR
OAT Probe.........................................................................................CHECK
Engine Oil and Cap............................................................................CHECK
Fuel Filter Drain...................................................................................DRAIN
Wing Tank Drains (2)...........................................................................DRAIN
Fuel Tank Vent.......................................................................CHECK CLEAR
Pitot Tube..........................................................................................CHECK
OAT Probe.........................................................................................CHECK
Stall Warning Vanes (2)......................................................................CHECK
Fuel Filler Cap....................................................................................CHECK
Fuel Quantity and Colour....................................................................CHECK
Fuel Filler Cap.................................................................................SECURE
Wing tip and Lights.............................................................................CHECK
Aileron...............................................................................................CHECK
Flap and Hinges.................................................................................CHECK

A CHECK - FUSELAGE (PORT SIDE)

Antennae...........................................................................................CHECK
Door.................................................................................................SECURE
External Power Receptacle................................................................CHECK
Static Pressure Port...........................................................................CHECK
A CHECK
Fresh Air Inlet.....................................................................................CHECK
A CHECK - EMPENNAGE
Anti-Collision Light.............................................................................CHECK
Nav Light............................................................................................CHECK
Stabilator and Trim Tab......................................................................CHECK
Rudder and Trim Tab..........................................................................CHECK
A CHECK - FUSELAGE (STARBOARD SIDE)

Fresh Air Inlet.....................................................................................CHECK
Heater Intake.....................................................................................CHECK
Static Pressure Port...........................................................................CHECK
Cabin Door.........................................................................................CHECK
Battery.......................................................................................................ON
Flaps..........................................................................................................UP
Battery.....................................................................................................OFF
Aspen........................................................................................CHECK OFF

THE A1 CHECK
Park Brake................................................................................................ON
Eng Mags................................................................................................OFF
IF Hood..............................................................................................CHECK
Partial Panel.......................................................................................CHECK
Checklist............................................................................................CHECK
A CHECK
Gear....................................................................................................DOWN
Propeller Area.......................................................................CHECK CLEAR
Gear Indications............................................................................3 GREENS
Fuel Quantity......................................................................................CHECK
Batt Master..............................................................................................OFF
Standby Instrument.................................................................................OFF
Airframe Condition.............................................................................CHECK
Flying Controls...................................................................................CHECK
Flaps..................................................................................................CHECK
Windscreen........................................................................................CHECK
Landing Gear.....................................................................................CHECK
Pitot Head..........................................................................................CHECK
Static Vents........................................................................................CHECK
OAT Probes........................................................................................CHECK
Fuel Tanks..........................................................................................CHECK
Oil Contents.......................................................................................CHECK

PRE-START
Preflight Check............................................................................COMPLETE
Aft Cabin Doors................................................................................SECURE
Forward Cabin Door................................................................AS REQUIRED
Seats............................................................................................ADJUSTED
Seat Belts.....................................................................................ADJUSTED
Park Brake...........................................................ON, RELEASE & REAPPLY
Gear.....................................................................................................DOWN
Throttles..................................................................................................IDLE
Propellers............................................................................FULL INCREASE
BEFORE T/O
Mixtures...........................................................................................CUT-OFF
Friction Handle.......................................................................AS REQUIRED
Prop Sync................................................................................................OFF
ALT Air.....................................................................................................OFF
Cowl Flaps...........................................................................................OPEN
Trims..............................................................................................NEUTRAL
Fuel..........................................................................................................ON
Cabin Heat..............................................................................................OFF
Defrost.....................................................................................................OFF
Avionics Master.......................................................................................OFF
Batt Master..............................................................................................OFF
All Electrical Switches..............................................................................OFF
Circuit Breakers.................................................................................CHECK
Day/Night Switch....................................................................AS REQUIRED
Emerg Battery.........................................................................................ARM
E Volts Indication......................................................................≥ 23.3 VOLTS
Nav Light...................................................................................................ON
Engine Temp.........................................................SELECT START METHOD

COLD ENGINE START (OIL TEMPERATURE BELOW 100°F)

Throttles...........................................................................................1” OPEN
Left/Right Altr.............................................................................................ON
Battery Voltage...................................................................................CHECK
Gear Indications..............................................................................3 GREEN
CAS Messages...................................................................................CHECK
PFD Annunciations.............................................................................CHECK
ATIS & Start Clearance...........................................................AS REQUIRED
BEFORE T/O
Strobe.......................................................................................................FIN
For First Engine:
* Fuel Pump Switch...................................................................................ON
* Mag Left/Right Switches.........................................................................ON
* Mixture........................................................................RICH then CUT-OFF
* Propeller Area...................................................................................CLEAR
* Eng Start Switch..............................................................................PRESS
* Mixture.......................................................................................FULL RICH
* Throttle.................................................................................AS REQUIRED
* Oil Pressure.....................................................................................CHECK
* Fuel Pump Switch.................................................................................OFF
Repeat (*) for second engine.
Throttles................................................................................1000-1200 RPM
Volts.......................................................................................28.8 ± 0.5 VOLT
Alternator Amps.......................................................................CHECK LOAD

COLD WEATHER ENGINE START (FROST)

Throttles..........................................................................................½” OPEN
Left/Right ALTR.........................................................................................ON
CAS Messages..................................................................................CHECK
PFD Annunciations............................................................................CHECK
BEFORE T/O
Strobe Lights............................................................................................FIN
For First Engine:
* Fuel Pump..............................................................................................ON
* Mag Left/Right........................................................................................ON
* Wait 5 seconds.....
* Throttle...........................................................................................CLOSED
* Eng Start Switch...............................................................................PRESS
* Fuel Pump Switch.................................................................................OFF
Throttles................................................................................1000-1200 RPM
Volts.......................................................................................28.8 ± 0.5 VOLT

HOT ENGINE START (OIL TEMPERATURE ABOVE 100°F)

Throttles..........................................................................................½” OPEN
Mixture............................................................................................CUT-OFF
Left/Right ALTR Switches..........................................................................ON
Battery Master Switch...............................................................................ON
BEFORE T/O

Fuel Pump Switches................................................................................OFF
For First Engine:
Throttles...............................................................................1000-1200 RPM
Volts......................................................................................28.8 ± 0.5 VOLT

FLOODED ENGINE START

Throttles......................................................................................FULL OPEN
Mixture............................................................................................CUT-OFF
For Flooded Engine:
* Magneto Left/Right Switches...................................................................ON
* Throttle........................................................................................1000 RPM
BEFORE T/O
Throttles................................................................................1000-1200 RPM

EXTERNAL POWER ENGINE START

Battery Master Switch..............................................................................OFF
Left/Right ALTR Switches........................................................................OFF
Emerg Battery.........................................................................................ARM
All Electrical Equipment...........................................................................OFF
External Power Supply..................................................................CONNECT
Throttles...........................................................................................1” OPEN
BEFORE T/O
For First Engine:
* Fuel Pump..............................................................................................ON
* Mixture........................................................................RICH then CUT-OFF
* Mixture.......................................................................................FULL.RICH
Battery Master............................................................................................ON
External Power Plug................................................................DISCONNECT
Receptacle Door..............................................................................CLOSED
Throttles.................................................................................1000-1200 RPM
Left/Right ALTR.........................................................................................ON
Oil Pressure.......................................................................................CHECK
Volts........................................................................................28.8 ± 0.5 VOLT

AFTER START
Avionics Master Switch..............................................................................ON
Emerg Battery Switch.............................................................................ARM
Magnetos............................................................................................CHECK
MFD.........................................................................................................SET
PFD.........................................................................................................SET
Com/Nav Radios....................................................................TEST and SET
Callsign ID...............................................................................................SET
Heat/Defrost...........................................................................TEST and SET
BEFORE T/O
Autopilot................................................................................................TEST
Electric Trim...........................................................................................TEST
Stabilator Trim................................................................................NEUTRAL
Standby Flight Instrument..................................................................CHECK
Ice Protections Systems........................................................................TEST
Fuel..........................................................CHECK X-FEED/SELECT X-FEED
Taxi Light...................................................................................................ON

TAXIING
Brakes................................................................................................CHECK
Flight Instruments...............................................................................CHECK
POWER CHECKS
Park Brake................................................................................................ON
Fuel...........................................................................................................ON
Mixtures.......................................................................................FULL RICH
Props..................................................................................FULL INCREASE
Throttles........................................................................................1000 RPM
BEFORE T/O
Engine Instruments............................................................................CHECK
Oil Temperature....................................................................................≥ 75°F
Throttles.........................................................................................1500 RPM
Props (individually)............................................................CHECK FEATHER
Throttles.........................................................................................2300 RPM
ALT Air.......................................................................................ON then OFF
Props (together)............................................................................EXERCISE
Throttles........................................................................................2000 RPM
Eng Mags...........................................................................................CHECK
Voltage..................................................................................28.8 ± 0.5 VOLT
Alternator Amps.................................................................................CHECK
Throttles.................................................................................................IDLE
Throttles........................................................................................1000 RPM
Friction Handle.......................................................................AS REQUIRED
If the E VOLT indication during pre-start was below 23.3 volts refer to E
VOLT Pre Flight Test Fail, page 54

BEFORE TAKE-OFF
Cabin...............................................................................................SECURE
Battery Master Switch...............................................................................ON
Left/Right Alternator Switches...................................................................ON
Emergency Battery Switch......................................................................ARM
Flight Instruments..............................................................................CHECK
Standby Flight Instruments................................................................CHECK
System Messages..............................................................................CHECK
BEFORE T/O
Engine Indications..............................................................................CHECK
Autopilot.........................................................................................FD MODE
Flight Controls....................................................................................CHECK
Props..................................................................................FULL INCREASE
Mixtures.......................................................................................FULL RICH
Prop Sync................................................................................................OFF
ALT Air.....................................................................................................OFF
Flaps............................................................................................................0°
Prop Heat...............................................................................AS REQUIRED
Stabilator & Rudder Trim................................................................NEUTRAL
Fuel Selectors...........................................................................................ON
Departure Clearance..............................................................AS REQUIRED
Radio / Nav Equipment..........................................................CONFIRM SET
Doors...........................................................................CLOSED & LATCHED
Take-Off Briefing..................................................................................STATE

TAKE-OFF
Entering the Runway
Strobe Lights..............................................................................................ON
Take-off Clearance Received
Landing Lights...........................................................................................ON
Lined Up with Clearance
Throttles.........................................................................................2000 RPM
Fuel Pumps................................................................................................ON
Pitot/Stall Warning Heat.............................................................................ON
Alternator............................................................................................CHECK
MP/Fuel Flow......................................................................................CHECK
AIRBORNE
CAS Messages...................................................................................CHECK
Start Take-off Run
Throttles...................................................................................FULL POWER
AFTER TAKE-OFF / GO-AROUND

Brakes........................................................................................ON then OFF
Gear............................................................................................................UP
Flaps.............................................................................................................0°
Power.......................................................................................................SET
Engine Indications...............................................................................CHECK
If leaving the circuit:
Taxi Light..................................................................................................OFF
Landing Lights..........................................................................................OFF
Fuel Pumps...............................................................................................OFF
Cowl Flaps...............................................................................AS REQUIRED
Altimeters................................................................................CONFIRM SET
MFD...............................................................................................MAP PAGE
Autopilot Switch.....................................................................................AP/FD
PFD Window..............................................................................FLIGHT PLAN

CLIMB
Power.......................................................................................................SET
Engine Indications...............................................................................CHECK
Ammeters...........................................................................................CHECK
OAT.....................................................................................................CHECK
Icing Considerations................................................................AS REQUIRED
TOP OF CLIMB CHECK

Power.......................................................................................................SET
Mixtures....................................................................................................SET
Instruments.........................................................................................CHECK
Cowl Flaps........................................................................................CLOSED
Icing....................................................................................................CHECK
Autopilot..................................................................ENGAGE AS REQUIRED
EN ROUTE CLIMB USING AUTOPILOT
AIRBORNE
PFD ALT Select.........................................................................................SET
Autopilot (Modes).............................................................................VS & ALT
Autopilot (Climb Rate)...............................................................................SET
Mixture..........................................................................................FULL RICH
Propellers.......................................................................................2500 RPM
Throttles.............................................................................................32" MAP
Autopilot (Climb Rate).................................ADJUST TO MAINTAIN 110 KTS
Autopilot (Modes)......................................................VS GREEN, ALT WHITE
EN ROUTE DESCENT USING AUTOPILOT

PFD ALT Select.........................................................................................SET
Autopilot (Modes)..............................................................................VS & ALT
Autopilot (Descent Rate)...........................................................................SET
Throttles...................................................................................................SET
Autopilot (Modes)......................................................VS GREEN, ALT WHITE

ROUTINE CRUISE CHECK

Fuel....................................................................................................CHECK
Engine Indications..............................................................................CHECK
Flight Instruments...............................................................................CHECK
CO Monitor.........................................................................................CHECK
Icing....................................................................................................CHECK
PRE-STALL CHECKS
Height........................................................................................SUFFICIENT
Airframe.................................................................................AS REQUIRED
Security.........................................................................................CHECKED
Engine...........................................................................................CHECKED
Location.........................................................................................SUITABLE
Lookout.....................................................................................COMPLETED
FUEL CROSSFEED DRILL (ALL ENGINES)

Fuel (low fuel side).............................................................................X-FEED
Fuel (high fuel side)....................................................................................ON

AIRFRAME ICING DRILL

When OAT Falls to +5 Deg C
Cabin Heater..............................................................................................ON
Defrost Fan................................................................................................ON
When Entering Icing Conditions
Prop Heat...................................................................................................ON
Pitot Stall Warning....................................................................CONFIRM ON
When Ice Starts Forming
Windscreen Heat.......................................................................................ON
When 1/4" of Ice Forms on Wings
Surface De-Ice...............................................................................OPERATE
If More than 1/2" of Ice Forms on Wings
ALT Air........................................................................................................ON
Autopilot...... ..................................................................................MONITOR
Consider a Change of Altitude/Level to Leave Icing Conditions
On Leaving Icing Conditions
ALT Air......................................................................................................OFF
Windscreen Heat.....................................................................................OFF
Prop Heat.................................................................................................OFF
BEFORE DESCENT CHECKS

Briefing..............................................................................................STATED
GNSS Approach........................................................ACTIVATE (If Required)
Navigation Aids........................................................................................SET
Aspen Altimeter..............................................................................SET QNH
Minimum Safe Altitude.......................................................................CHECK
Fuel..................................................SELECTORS ON / CHECK CONTENTS
Engine Ts & Ps...................................................................................CHECK
Cabin...............................................................................................SECURE

INITIAL APPROACH CHECKS

Taxi Light...................................................................................................ON
Landing Lights...........................................................................................ON
Fuel Pumps...............................................................................................ON
Prop Sync................................................................................................OFF
Mixtures.................................................................................................RICH
Props.................................................................................FULLY FORWARD
Altimeters.....................................................................SET and X-CHECKED
GNSS Approach Type................................................ACTIVATED & STATED
Radios......................................................................................................SET
DA or ODA or MDA..................................STATED and BARO MIMIMUM SET
Cabin................................................................................................SECURE
LANDING CHECKS
Gear....................................................................................DOWN 3 GREEN
Brakes................................................................................................CHECK
AIRBORNE
Flaps......................................................................................AS REQUIRED
Mixtures.................................................................................................RICH
Propellers..........................................................................FULLY FORWARD
VAT.......................................................................................................STATE
FINAL CHECK
Mixtures.................................................................................................RICH
Propellers.........................................................................FULLY FORWARD
Gear....................................................................................DOWN 3 GREEN

AFTER LANDING
Strobe Lights.............................................................................................FIN
Landing Lights..........................................................................................OFF
Fuel Pumps..............................................................................................OFF
Transponder...................................................................................GND 2000
Pitot / Stall Warn Heat...............................................................................OFF
Prop Heat.................................................................................................OFF
Windsheild Heat.......................................................................................OFF
Flaps.............................................................................................................0°
ALT Air......................................................................................................OFF
Cowl Flaps............................................................................................OPEN
Cabin Heat & Stopwatch..........................................................AS REQUIRED
Air Intake...............................................................................................OPEN
Trims...............................................................................................NEUTRAL
SHUTDOWN

CLOSING DOWN
Park Brake.................................................................................................ON
Taxi Light Switch.......................................................................................OFF
Cabin Heat...............................................................................AS REQUIRED
Avionics Master........................................................................................OFF
Emerg Battery...........................................................................................OFF
Magnetos............................................................................................CHECK
Cabin Fan.................................................................................................OFF
Autopilot Master.......................................................................................OFF
Throttles..................................................................................................IDLE
Mixtures...........................................................................................CUT-OFF
All Eng Magnetos.....................................................................................OFF
Alternators................................................................................................OFF
Interior Lights...........................................................................................OFF
Exterior Lights..........................................................................................OFF
Battery Master..........................................................................................OFF
Fuel Selectors..........................................................................................OFF
Seat Belts.................................................................................................SET
Post Flight Inspection...........................................................................BY PIC

POWER SETTINGS
Climbing
Situation Flap Gear MAP RPM Fuel Flow Mixture Pitch IAS
Rotate 0° DOWN 38” MAX RICH +10° 81 kts
Best angle of climb VX 0° UP 38” MAX RICH +14° 83 kts
Best rate of climb VY 0° UP 38” MAX RICH +13° 88 kts
Best single engine rate
0° UP 38” MAX RICH +5° 88 kts
of climb VYSE
Normal 0° UP 32” 2500 RICH +7° 110 kts
Cruise 0° UP 28” 2200 LEAN +4° 115 kts
Level Flight
Stall on base turn 25° DOWN 15” MAX RICH Inc to + 10° VSO
Stall on final 40° DOWN 15” MAX RICH Inc to +13° VSO
Visual Circuit 0° UP 22” 2500 RICH +2° 115 kts
Asymmetric cruise 0° UP 32” 2500 LEAN +2° 110 kts
Holding 0° UP 22” 2200 LEAN +2° 115 kts
Long range 0° UP 25” 2200 18 GPH LEAN +1° 125 kts
Economy (Standard
0° UP 28” 2200 22 GPH LEAN +0° 140 kts
cruise use at Oxford)
Normal 0° UP 30” 2300 24 GPH LEAN +0° 150 kts
High speed 0° UP 30” 2500 28 GPH LEAN +0° 155 kts
Descent
Cruise descent 0° UP 18” 2200 LEAN -3° 140 kts
Initial approach 0° UP 15” 2200 LEAN -2° 115 kts
Asymmetric initial
0° UP 17” 2500 LEAN -2° 115 kts
approach
POWER
IFR final & VFR base 25° DOWN 18” 2500 RICH -4° 100 kts
Asymmetric IFR final 10° DOWN 20” MAX RICH -4° 100 kts
Asymmetric VFR final 25° DOWN 20” MAX RICH -4° 90 kts
VFR final 40° DOWN 20” 2500 RICH -4° 88 kts
VAT 40° DOWN A/R 2500 RICH A/R 82 kts

PA34-220T - EMERGENCY CHECKLIST
AUTOPILOT MALFUNCTION
Indication: Unexpected or uncommanded autopilot control inputs.

Condition: A failure has occurred in the autopilot.
Objective: To disengage the autopilot and regain control of the aeroplane.
Autopilot malfunctions can cause significant attitude and altitude deviations of

up to 57° bank and 380' altitude loss.
Regain aeroplane control by firmly grasping the control wheel and
overpowering the autopilot servos
1. AP DISC / TRIM INTER BUTTON...............................PRESS

2. FD / AP MASTR SWITCH.................................................OFF
3. AUTOPILOT CIRCUIT BREAKER..................................PULL
Row 1, column 12
• Do not re-engage the autopilot

EMERGENCY

PITCH TRIM RUNAWAY
Indication: Uncommanded pitch trim motion

Condition: A failure in the electrical pitch trim system has occurred
Objective: To disengage the electric pitch trim and regain control of the
aeroplane.
Regain aeroplane control by firmly grasping the control wheel and

overpowering the autopilot servos
1. AP DISC / TRIM INTER BUTTON.............PRESS and HOLD

2. ELEV TRIM MASTR SWITCH..........................................OFF
3. PITCH TRIM CIRCUIT BREAKER..................................PULL
Row 1, column 13
4. STABILATOR TRIM.........................................AS REQUIRED
Manually re-trim the aeroplane
5. AP DISC / TRIM INTER BUTTON...........................RELEASE
Autopilot operation will require the aeroplane to be manually
trimmed.
EMERGENCY

ELECTRICAL FIRE IN FLIGHT
Condition: An electrical fire has occurred in flight.

Objective: To eliminate fumes in the cabin, extinguish fire and achieve a
safe landing.
1. FLOOR VENTS..............................................................OPEN
2. AIR INTAKE LEVER......................................................OPEN
3. EMERG BATT SWITCH...................................................ARM
4. BATT MASTER SWITCH..................................................OFF
5. LEFT / RIGHT ALTR SWITCHES.....................................OFF
6. CABIN HEAT SWITCH......................................................OFF
• If able attempt to extinguish fire with fire extinguisher.
• Consider an emergency descent.
• Flaps inoperative.
• Prior to landing complete Gear Extension - Manual, page 73

EMERGENCY

ENGINE FIRE DURING START
Condition: An engine fire has occurred during start.

Objective: To extinguish fire.
If fire has spread to the ground from excess fuel:

• Attempt to taxi away if possible
If / When fuel spread is not a factor:

Affected Engine:
1. ENGINE START.................................CONTINUE TO CRANK

2. MIXTURE.................................................................CUT-OFF
3. THROTTLE....................................................................OPEN
4. FUEL.................................................................................OFF
5. FUEL PUMP......................................................................OFF
EMERGENCY

ENGINE FAILURE / FIRE IN FLIGHT
Condition: An engine has failed / an engine fire has occurred in flight.

Objective: To obtain maximum thrust from the operating engine and to
reduce drag and secure the failed engine.
To extinguish fire, reduce risk of fumes entering the cabin and
secure the failed engine.
Immediate actions:
1. MIXTURES.....................................................................RICH
2. PROPELLERS.................................................................MAX
3. THROTTLES.............................................................38" MAP
4. FLAPS................................................................................UP
5. GEAR.................................................................................UP
6. AFFECTED ENG THROTTLE..................................CLOSED
7. AFFECTED ENG PROPELLER.............................FEATHER
8. AFFECTED ENG MIXTURE.............................................ICO
9. AFFECTED ENG COWL FLAP.................................CLOSED
10. TRIMMED FLIGHT..........................................ESTABLISHED
Subsequent Actions:
11. AFFECTED ENG FUEL SELECTOR...............................OFF
12. PROP SYNC....................................................................OFF
13. AFFECTED ENG ALTERNATOR.....................................OFF
14. AFFECTED ENG FUEL PUMP........................................OFF
EMERGENCY
15. AFFECTED ENG MAGNETOS (individually)...................OFF

16. CHECK FOR FIRE
Continued on next page...

ENGINE FAILURE / FIRE IN FLIGHT ..Continued
FIRE
NO
17. ENGINE INSTRUMENTS (MFD)..........................CHECK
18. LIVE ENGINE COWL FLAP......................AS REQUIRED
19. ELECTRICAL LOAD...........................................REDUCE
20. X-FEED.....................................................AS REQUIRED
21. LAND......................................AS SOON AS PRACTICAL
22. ATC......................................................................INFORM
YES
17. CABIN HEAT..............................................................OFF
18. DEFROST...................................................................OFF
19. COWL FLAP............................................................OPEN
20. FIRE..........................................................CHECK AGAIN
If fire persists
21. AIRSPEED...................INCREASE TO BLOW OUT FIRE
22. LAND........................................AS SOON AS POSSIBLE
23. ATC......................................................................INFORM
EMERGENCY

PROPELLER OVERSPEED
Indication: Master warning, flashing red RPM indication

Condition: Propeller speed exceeds 2600 RPM
Objective: To regain propeller control.
A propeller overspeed is usually caused by a malfunction in the propeller

governor which allows the blades to rotate to full low pitch.
Affected Engine:
1. THROTTLE...............................................................REDUCE
2. PROPELLER........................................................DECREASE
Do not feather propeller
3. OIL PRESSURE INDICATION.....................................CHECK
4. AIRSPEED................................................................REDUCE
5. THROTTLE.....................................................AS REQUIRED
Set to maintain propeller speed below 2600 RPM
EMERGENCY

STARTER ENGAGED
L START ENGD R START ENGD
Indication: Master warning, CAS warning message.

Condition: A starter has been engaged for more than 30 seconds.
Objective: To prevent the starter causing significant damage to the
electrical system.
An engaged starter can cause a significant electrical current drain and excess
heat in the aeroplane's electrical system.
If on the ground
Affected Engine:
1. THROTTLE...............................................................REDUCE
2. ENG START CIRCUIT BREAKER..................................PULL
Row 3, column 6
• Shutdown engine
If in flight
Affected Engine:
3. THROTTLE...............................................................REDUCE
4. ENG START CIRCUIT BREAKER..................................PULL
Row 3, column 6
• Land as soon as possible

EMERGENCY

BAGGAGE DOOR OPEN
BAGGAGE DOOR BAGGAGE DOOR

Condition: The forward baggage door has opened in flight.
Objective: To keep the baggage door closed.
• Attempt to find a stable attitude and airspeed which keeps the

bagage door closed.
• Land as soon as possible.

EMERGENCY

EMERGENCY DESCENT
Objective: To rapidly lose height.
1. THROTTLES.............................................................CLOSED
2. PROPELLERS.............................................FULL INCREASE
3. MIXTURES......................................................AS REQUIRED
Set mixtures for smooth operation.
When speed is below 128 KIAS (VLO)

4. GEAR SELECTOR.......................................................DOWN
Maintain a maximum airspeed of 128 KIAS (VLE)
EMERGENCY

REJECTED TAKE-OFF (RTO)
Objective: To bring the aeroplane to a complete stop following a

malfunction during the take-off.
A take-off must be aborted for control difficulties, loss of power, sustained

master warning.
1. THROTTLES.............................................................CLOSED
• Apply brakes as required to bring aircraft to a complete stop.
If insufficient runway remains for a complete stop:

2. MIXTURES...............................................................CUT-OFF
3. FUEL SELECTORS..........................................................OFF
4. ENG MAG SWITCHES.....................................................OFF
5. FUEL PUMP SWITCHES..................................................OFF
EMERGENCY

SPIN RECOVERY
Indication: Uncontrollable yaw accompanied by a low airspeed and a

potentially high rate of descent.
Condition: The aeroplane has inadvertently entered a spin.
Objective: To regain control.
The Seneca V is not required to nor has it been spin tested. The recovery
technique is based upon the manufacturer's best available information.
Intentional spins are prohibited.
1. THROTTLES......................................................FULL CLOSE
2. RUDDER..................FULL OPPOSITE OF SPIN DIRECTION
3. CONTROL WHEEL.......................CENTRALLY FORWARDS
When rotation stops:

• Centralise rudder
• Ease out of resulting dive
EMERGENCY

PA34-220T - ABNORMAL CHECKLIST
ASPEN IN-FLIGHT AHRS RESET
Red X across ASPEN display with “attitude fail” message or

Indication: “cross check attitude” message over attitude indication without
any red X’s.
Attitude pitch or roll data invalid or potential degradation of
Condition:
attitude information.
To restore stable and correct attitude and HDG on the ASPEN
Objective:
standby instrument.
• Maintain Straight & Level flight.
• Consider exiting IMC flight.
To attempt to reset AHRS:
• Fly by visual reference or PFD.

• Disconnect the autopilot.
• Press the MENU button.
• Rotate the right knob to display GENERAL SETTINGS A menu page.
• Press the AHRS RESET? menu key.
A confirmation message displays prompting the user to confirm
the reset request.
• Press the AHRS Menu Key again to confirm the AHRS reset.
The confirmation message clears.
AHRS is reset:
• Press the MENU button to exit.
ABNORMAL

AIR DATA COMPUTER (ADC) FAILURE
Indication: Red x's and amber text on all ADC parameters.

Condition: The air data computer has failed.
Objective: To regain sufficient equipment to continue flight.
• Use standby flight instrument for airspeed, altitude and vertical

speed information.
• Loss of ADC affects autopilot capability:

Simultaneous use of ALT and VS modes unavailable.
• Consider any PFD system messages.
To attempt to restore ADC:
1. ADC 1 CIRCUIT BREAKER.........................................RESET

Row 1, column 6
If ADC is not restored:

• Exit and avoid IMC and icing conditions.
If ADC is restored:
ABNORMAL

ATTITUDE & HEADING REFERENCE SYSTEM FAILURE
Indication: Sky / ground presentation removed, course pointer straight up,

red x's and amber text over some or all AHRS parameters.
Condition: The attitude and heading reference system has failed.
• Use standby flight instrument for attitude and heading information.
• Set the desired course on the PFD.

The course pointer will continue to point stright up.
• Loss of AHRS affects autopilot capability:
The autopilot will no longer function in HDG mode but will track a
selected course in NAV mode (using NAV or GPS information).
• Consider any PFD system messages.
To attempt to restore AHRS:
1. AHRS 1 CIRCUIT BREAKER.......................................RESET

Row 1, column 5
If AHRS is not restored:

If ADC is restored:
ABNORMAL

AVIONICS
AVIONICS COOLING FAN FAILURE
AV FAN FAIL MFD FAN FAIL

PFD1 FAN FAIL PFD2 FAN FAIL
Indication: CAS advisory message.

Condition: One or more avionics cooling fans have failed.
Identify corresponding Circuit Breaker:

If Circuit Breaker has not tripped:
1. CORRESPONDING CIRCUIT BREAKER.................................PULL
• Wait 5 seconds
2. CORRESPONDING CIRCUIT BREAKER................................PUSH
• Wait 5 seconds
3. CAS ADVISORY MESSAGE INDICATED?...........................YES/NO
4. CAS ADVISORY MESSAGE STILL INICATED....................PULL CB
If Circuit Breaker has tripped do not attempt to reset
• It is possible to exceed the manufacturer's temperature limits for

the affected equipment.
The avionics fan (AV FAN) provides cooling to the transponder,
autopilot and the integrated avionics unit.

AVIONICS
CREW ALERTING SYSTEM (CAS) FAILURE
Indication: Red x's over CAS message window or erroneous CAS

messages.
Condition: A failure has occurred withing the CAS system.
Objective: To utilise remaining equipment to continue flight.
If red x appears over CAS message window:
• Monitor MFD ENGINE page to detect system failures.

Master warning and caution indicators are unavailable as are
CAS messages.
• Exit and avoid icing conditions.
• Land as soon as practical.
If CAS messages do not activate when an abnormal condition exists or

disagree with abnormal indication:
• Try to determine whether condition is real.
• If condition cannot to confirmed as an erroneous indication then

treat as real.

AVIONICS
COMMUNICATIONS FAILURE
Indication: Inability to transmit / receive on COM1 and COM2.

Condition: A failure has occurred withing the COM system.
Objective: To re-establish radio communication.
If power is lost to the audio panel a fail-safe communications path becomes

available between the P1 headset / microphone and COM1.
To remove power from the audio panel:
1. AUDIO MKR CIRCUIT BREAKER..................................PULL

Row 1, column 7

AVIONICS
GPS DEAD RECKONING (DR) MODE
Indication: Amber DR annunciation on HSI, amber DR annunciation

superimposed over aeroplane symbol on the moving map.
Condition: A failure of both GPS systems has occurred.
Objective: To reestablish adequate navigation information.
If alternative navigation sources are available:
• Use alternative navigation sources
If alternative navigation sources are not available:
• GPS navigation may be accomplished using the aeroplane symbol

on the MAP display and the amber CDI on the HSI.
Information normally derived from GPS turns amber and
becomes more inaccurate over time. Amber CDI will disappear
after 20 minutes.
• Expect GPS LOSS OF INTEGRITY (LOI) MODE, page 49.

GPS LOSS OF INTEGRITY (LOI) MODE
AVIONICS
Indication: All information derived from GPS or DR is removed from the
displays. NO GPS POSITION is displayed in the centre of the
map.
Condition: GPS integrity is insufficient for the current phase of flight.
Objective: To re-establish adequate navigation information.
• Use alternative navigation sources
• RNAV approaches are unavailable.
• Traffic advisory system is unavailable.

PFD1 FAILURE
AVIONICS
Indication: PFD1 display goes blank.

Condition: PFD1 has failed.
• Maintain aircraft control using standby flight instrument.

NAV1, GPS1, COM1 (except 121.5 MHz) and traffic advisory
system are unavailable.
To transfer primary flight instruments to MFD:
1. DISPLAY BACKUP BUTTON.........................................PUSH

The DISPLAY BACKUP is the red button on the audio panel.
It is active when the button is extended.
To re-establish communications and nav equipment:
2. COM2....................................................TUNE AS REQUIRED
3. NAV2.....................................................TUNE AS REQUIRED
4. COM2 MIC...................................SELECT ON AUDIO PANEL
5. DME.................................................................AS REQUIRED
DME will continue operating normally but frequencies cannot
be selected on NAV1.
6. AP DISC / TRIM INTER SWITCH................................PRESS
Conduct the remainder of the flight manually.

PFD2 FAILURE
AVIONICS
Indication: PFD1 display goes blank.
Condition: PFD1 has failed.
COM2, NAV2, DME, ADF, GPS2 and right engine's indications are unavailable.
MFD FAILURE
Indication: MFD display goes blank.

Condition: MFD has failed.
Objective: To regain sufficent equipment to continue flight.
GPS2 is unavailable.
To ensure transfer of engine indications to the PFDs:
1. DISPLAY BACKUP BUTTON.........................................PUSH
The DISPLAY BACKUP is the red button on the audio panel.
It is active when the button is extended.

ELECTRICS
ALTERNATOR FAILURE - DOUBLE
L ALTR FAIL R ALTR FAIL

Condition: Both alternators have failed.
Objective: To restore alternator output and, if this is not possible, reduce
electrical load.
• Verify alternator failure by checking ALTR AMPS indication.
If in icing conditions:
1. NON ESS BUS 1 CIRCUIT BREAKER...........................PULL
Disables vent fan, heater and prop sync.
Disables all ice protection systems except pitot and stall
warning heat.
3. LIGHTING BUS CIRCUIT BREAKER.............................PULL
Disables all internal and external lights.
4. AVIONICS MASTER SWITCH........................................PULL
Disables COM2, DME, MFD, PFD2, ADF, autopilot and
traffic system.
• Continue with step 5
If not in icing conditions:

6. LEFT / RIGHT ALTR CIRCUIT BREAKERS.................RESET
Located on the instrument panel.
7. ALTR FIELD CIRCUIT BREAKER...............................RESET
L ALTR FIELD: Row 3, Column 10
R ALTR FIELD: Row 4, Column 10
8. LEFT / RIGHT ALTR SWITCHES.......................................ON
Continues next page ..

ALTERNATOR FAILURE - DOUBLE ..Continued
If single alternator remains failed:

Affected Alternator:
9. ALTR SWITCH..................................................................OFF
ELECTRICS
• Monitor remaining alternator output and maintain below 85 amps.
• Avoid use of high current drawing and de-icing equipment.
If both alternators remain failed:

Disables vent fan, heater and prop sync.
Disables all ice protection systems except pitot and stall
warning heat.
13. LIGHTING BUS CIRCUIT BREAKER.............................PULL
Disables all internal and external lights.
14. AVIONICS MASTER SWITCH........................................PULL
Disables COM2, DME, MFD, PFD2, ADF, autopilot and
traffic system.
Continues next page ..

ALTERNATOR FAILURE - DOUBLE ..Continued
To ensure 30 minutes of battery life:

• Maintain battery discharge below 20 amps.
• Limit pitot/stall warning heat usage to a maximum of 15 minutes.

ELECTRICS
• Limit COM usage to a maximum of 3 minutes.
• Limit flaps to 1 extension or retraction.
• Limit landing gear to 1 extension only.
• The battery is the primary source of electrical power. As battery

power is depleted there may be a point where the system voltage
reduces to a level that is insufficient to support the required
electrical load. If this occurs the emergency battery should take
over automatically but can be forced to do so by turning the BATT
MASTR, LEFT ALTR and RIGHT ALTR switches OFF.
• Gear Extension - Manual, page 73 may be required.

ALTERNATOR FAILURE - SINGLE
L ALTR FAIL R ALTR FAIL

Condition: An alternator has failed.
ELECTRICS
Objective: To restore alternator output and, if this is not possible, reduce
electrical load.
• Verify alternator failure by checking ALTR AMPS indication.
• Reduce electrical load to less than 85 amps.
1. ALTR SWITCH..................................................................OFF
2. ALTR FIELD CIRCUIT BREAKER...............................RESET
L ALTR FIELD: Row 3, Column 10
R ALTR FIELD: Row 4, Column 10
3. ALTR SWITCH...................................................................ON
If issue is resolved:
If issue is not resolved:

4. ALTR SWITCH..................................................................OFF
• Monitor remaining alternator output and maintain below 85 amps.
• Avoid use of high current drawing and de-icing equipment.

E VOLT PRE FLIGHT TEST FAIL
Indication: E VOLT indication below 23.3 volts during Pre-Start check.

Condition: Emergency battery voltage too low for IFR flight.
Objective: To establish whether emergency battery has been sufficiently
ELECTRICS
charged during taxi and power checks for IFR flight.
To test emergency battery voltage all other power sources must be removed
from the electrical system. During the test power will be lost to all services not
on the EMERGENCY BUS.

2. AVIONICS MASTER SWITCH..........................................OFF
3. L ALTR SWITCH...............................................................OFF
4. R ALTR SWITCH..............................................................OFF
5. BATT MASTER SWITCH.................................................OFF
6. E VOLTS INDICATION......................................≥ 23.3 VOLTS
If the E VOLTS indication is still below 23.3 volts, IFR flight is
prohibited.
8. BATT MASTER SWITCH....................................................ON
9. L ALTR SWITCH.................................................................ON
10. R ALTR SWITCH................................................................ON
11. AVIONICS MASTER SWITCH............................................ON
12. MFD...................................................................................SET

EMERGENCY BATTERY FAILURE
Indication: Master warning, flashing E VOLTS indication.

Condition: Emergency battery voltage ≤ 20 volts or ≥ 32 volts.
• A complete electrical failure is imminent.
ELECTRICS

MAIN BATTERY FAILURE
EMERG BATT ON EMERG BATT ON
Indication: CAS advisory message. E VOLTS indication on engine

indication system window.
ELECTRICS
Condition: The main battery has been depleted and the aeroplane is
operating on emergency battery power.
Objective: To achieve a safe landing.
• The emergency battery is designed to provide electrical power to

the emergency bus for a minimum of 30 minutes.
The emergency bus provides power to the ADC, AHRS, engine
indications, avionics lights, COM1, PFD1 and the standby
instrument.
• Expect PFD1 FAN FAIL and AV FAN FAIL CAS message
advisories.
• Use PFD1 and standby flight instrument for aircraft control.
To ensure emergency battery power supply remains uninterrupted:

• Flaps inoperative.
• Prior to landing complete Gear Extension - Manual, page 73

CYLINDER HEAD TEMPERATURE (CHT)
L ENG CHT R ENG CHT
Indication: Master warning. CAS warning message.

Condition: CHT ≥ 460°F
Objective: To reduce cylinder head temperature.
Affected Engine:
1. THROTTLE...............................................................REDUCE
2. MIXTURE...............................................................FULL RICH
ENGINES
3. COWL FLAP...................................................................OPEN
4. AIRSPEED...................................INCREASE IF PRACTICAL

ENGINE FAILURE IN ICING CONDITIONS
Condition: An engine has failed in icing conditions.

Objective: To restart engine.
Affected Engine:
1. ALT AIR...............................................................................ON
2. ENGINE RESTART..................................................ATTEMPT
If able to restart engine:

ENGINES
If unable to restart engine:

Inoperative Engine:
3. PROPELLER...........................................................FEATHER
4. AIRSPEED...............................................................≥ 88 KIAS
• Avoid further icing conditions.
• Use a minimum final approach speed of 89 KIAS.
• Do not extend gear or flaps until landing is assured.
• Land as soon as practical

ENGINE SECURING PROCEDURE
Condition: An engine requires feathering.

Objective: To reduce drag and secure the failed engine.
1. THROTTLE......................................................................IDLE
2. PROPELLER...........................................................FEATHER
3. MIXTURE.................................................................CUT-OFF
4. COWL FLAP..............................................................CLOSED
5. FUEL.................................................................................OFF
6.
ENGINES
ALTR SWITCH..................................................................OFF
7. FUEL PUMP SWITCH......................................................OFF
8. MAG LEFT / RIGHT SWITCHES......................................OFF
9. PROP SYNC.....................................................................OFF
10. ELECTRICAL LOAD........................REDUCE AS REQUIRED
11. X-FEED...........................................................AS REQUIRED

UNFEATHERING PROCEDURE
Condition: Engine Inoperative.

Objective: To re-start inoperative engine.
1. FUEL SELECTOR..............................................................ON
2. FUEL PUMP SWITCH........................................................ON
3. THROTTLE...............................................................½" OPEN
5. MAG LEFT / RIGHT SWITCHES........................................ON
6. PROPELLER.......................................................MID RANGE
ENGINES
7. ENG START SWITCH.........................PRESS MAX 10 SECS

8. THROTTLE......................................................AS REQUIRED
10. ALTR SWITCH...................................................................ON
11. ENGINE INDICATIONS..............................................CHECK
12. COWL FLAP.....................................................AS REQUIRED
13. PROPELLER........MANUALLY SYNC WITH OTHER ENGINE
15. PROP SYNC....................................................AS REQUIRED

OIL PRESSURE - HIGH
Indication: Master warning. flashing oil pressure indication.

Condition: Oil pressure ≥ 100 PSI
Objective: To reduce oil pressure.
Affected Engine:
1. THROTTLE..........................................MINIMUM REQUIRED
ENGINES

OIL PRESSURE - LOW
Indication: Master warning. flashing oil pressure indication.

Condition: Oil pressure ≤ 10 PSI.
Objective: To minimise the risk of engine damage.
Affected Engine:
If accompanied by high oil temperature

ENGINES
If accompanied by normal oil temperature


OIL TEMPERATURE
Indication: Master warning. flashing oil temperature indication.

Condition: Oil temperature ≥ 240°F
Objective: To reduce oil temperature.
An abnormally high oil temperature may be caused by low oil quantity, an

obstruction in the oil cooler, damaged or improper baffle seals, a faulty
indication or other causes.
Affected Engine:
ENGINES
3. COWL FLAP...................................................................OPEN
4. AIRSPEED...................................INCREASE IF PRACTICAL
• Monitor oil pressure indication for an accompanying loss of oil

pressure.

TURBINE INLET TEMPERATURE (TIT)
Indication: Master warning. flashing TIT indication.

Condition: TIT ≥ 1650°F.
Objective: To reduce turbine inlet temperature.
Affected Engine:
1. MIXTURE...............................................................INCREASE
If condition rectified:
ENGINES
If condition persists:
2. THROTTLE...............................................................REDUCE
3. CHT INDICATIONS.................................................MONITOR
CHT indications are displayed on the MFD ENGINE page only.

ENGINE / FUEL DISPLAY FAILURE
Indication: Red x's over affected engine parameters of fuel displays or

indications which do not agree with other displays / system
data.
Condition: An "Engine Airframe" unit (GEA) has failed.
Objective: To utilise remaining equipment to continue flight.
• Set power based on throttle lever position, engine sound and

speed. Use known power settings and power settings tables for
approximate fuel flow values.
• Monitor other indications to determine the health of the engine.
ENGINES
Use other system information such as annunciator messages, fuel
totalizer quantity and flow to safely complete the flight.
• In the event that sufficient indications are unavailable and cannot be

restored, land as soon as practical.
If left engine, VOLTS, BATT AMPS, VACUUM or left fuel quantity indications
are invalid:
1. GEA 1 CIRCUIT BREAKER.........................................RESET
Row 3, column 9.
If right engine, VOLTS, BATT AMPS, VACUUM or right fuel quantity

indications are invalid:
1. GEA 2 CIRCUIT BREAKER.........................................RESET
Row 4, column 9.

TURBINE INLET TEMPERATURE (TIT) INDICATOR FAILURE
Indication: Erroneous TIT indication.

Condition: A TIT sensor has failed.
Objective: To minimise the risk of engine damage through running with too
lean a mixture.
Flight planning range and endurance figures will no longer be applicable.

Higher fuel flow will result in reduced range and endurance.
If failure occurs during take-off, climb or landing:

ENGINES
• At top of climb continue with item 2.
If failure occurs prior to setting cruise power:

Affected engine:
2. POWER...........................................................AS REQUIRED
High speed cruise: 30" MAP / 2500 RPM
Normal cruise: 30" MAP / 2300 RPM
Economy cruise: 28" MAP / 2200 RPM
Long range cruise: 25" MAP / 2200 RPM
3. MIXTURE........................................................AS REQUIRED
High speed cruise: 18 GPH
Normal cruise: 16 GPH
Economy cruise: 15 GPH
Long range cruise: 13 GPH
Continues next page .

TURBINE INLET TEMPERATURE (TIT) INDICATOR FAILURE

..Continued
If failure occurs after setting cruise power:

Affected engine:
4. POWER................................NOTE SETTING AND MAINTAIN
5. MIXTURE..............................................INCREASE BY 1 GPH
If failure occurs prior to or during descent:
ENGINES
6. POWER...................................................SET FOR DESCENT

FUEL PUMP FAILURE
Indication: Complete or total loss of engine power.

Condition: An engine driven fuel pump has failed.
Objective: To restore engine power.
Affected Engine:
1. THROTTLE...................................................................CLOSE
2. FUEL PUMP SWITCH.........................................................ON
3. THROTTLE.......................................................AS REQUIRED
ENGINES
4. MIXTURE.........................................................AS REQUIRED
If normal engine operation and fuel flow are not immediately re-established:
Affected Engine:
A lack of fuel flow indication could indicate a leak in the fuel
system or fuel exhaustion.
• Complete ENGINE SECURING PROCEDURE, page 61.
If normal engine operation and fuel flow are immediately re-established:

• Leave standby fuel pump on and use normal cruise, descent and
landing procedures.
Any combination of RPM and manifold pressure may be used but leaning may
be required for smooth operation.

FUEL QUANTITY
L FUEL QTY R FUEL QTY

Condition: Fuel quantity ≤ 5 US gallons.
Objective: To prevent engine power loss due to fuel starvation
Avoid unusual attitudes such as prolonged slips towards the low quantity tank
as this will reduce the time remaining prior to fuel starvation.
If one tank has low fuel quantity:
ENGINES
Affected Engine:
1. FUEL SELECTOR.......................................................X-FEED
If both tanks have low fuel quantity:

2. FUEL SELECTORS............................................................ON

FUEL MANAGEMENT DURING ONE ENGINE INOPERATIVE
Indication: One engine is inoperative, and the fuel on the side of the
remaining engine is low.
Objective: To use fuel from the fuel tank with more fuel in it.
Crossfeed should only be used when it is necessary to extend range during

single engine operation. Crossfeed must be OFF for take-offs and landings.
To begin crossfeeding:
1. FUEL SELECTOR.(Operative Engine).......................X-FEED
2. FUEL SELECTOR (Inoperative Engine)...........................OFF
ENGINES
To come out of crossfeed:

3. FUEL PUMP SWITCH (Operative Engine).........................ON
4. FUEL SELECTOR.(Operative Engine)...............................ON
5. FUEL SELECTOR (Inoperative Engine)...........................OFF
6. FUEL PUMP SWITCH (Operative Engine).......................OFF

GEAR EXTENSION - MANUAL
Condition: The normal method of extending the landing gear has failed or
is unavailable.
Objective: To extend landing gear.
1. EMERGENCY GEAR EXT. GUARD..........................REMOVE

Pull the guard down to clear the red handle.
2. AIRSPEED................................................................≤ 85 KIAS
3. GEAR SELECTOR........................................................DOWN
4. EMERGENCY GEAR EXT. .....................................PULL OUT
5. LANDING GEAR INDICATIONS...............................3 GREEN
If gear extension is achieved:
• Leave emergency gear extension knob out.
• Do not retract gear.
GEAR
If gear extension is not achieved:
• Complete GEAR UP LANDING PROCEDURE, page 78.

GEAR PUMP FAILURE
Indication: Gear indications remain in current position.

Condition: The hydraulic pump has failed.
Objective: To restore hydraulic pump.
1. GEAR SELECTOR...................SET TO ORIGINAL POSITION

Set GEAR selector to match current position of landing gear.
2. GEAR PUMP CIRCUIT BREAKER...............................RESET
Row 4, column 13
3. GEAR SELECTOR....................SET TO DESIRED POSITION
If landing gear remains up:

Prior to landing:
• Complete GEAR EXTENSION - MANUAL, page 73.

GEAR
If landing gear remains down:

• Maintain airspeed below 128 KIAS (VLE).

GEAR PUMP OVERRUN
HYDR PUMP ON HYDR PUMP ON
Indication: Master caution. CAS caution message.

Condition: The hydraulic pump continues to run for more than 16 seconds.
Objective: To deactivate hydraulic pump.
1. GEAR PUMP CIRCUIT BREAKER.................................PULL

Row 4, column 13
Prior to landing:
2. GEAR PUMP CIRCUIT BREAKER..............................RESET
Row 4, column 13
If gear pump circuit breaker remains in:
GEAR
If gear pump circuit breaker trips:

GEAR SYSTEM - FLIGHT
GEAR SYS GEAR SYS

Condition: A malfunctioning gear selector, gear position switch or landing
gear pump failure.
Objective: To rectify the malfunction.
1. GEAR PUMP CIRCUIT BREAKER..............................RESET

Row 4, column 13
2. BATT MASTER SWITCH....................................................ON
3. LEFT / RIGHT ALTR SWITCHES........................................ON
4. GEAR SELECTOR..................................................RECYCLE
GEAR

GEAR SYSTEM - GROUND
GEAR SYS GEAR SYS

Condition: A malfunctioning gear selector, gear position switch.
Objective: To reduce the risk of gear retraction on the ground.
1. GEAR SELECTOR........................................................DOWN
• Seek engineering assistance.
GEAR

GEAR UP LANDING PROCEDURE
Condition: The emergency method of extending the landing gear has failed
and a gear up landing is required.
Objective: To achieve a safe gear up landing.
During a gear up landing, red landing gear position indications as well as CAS
messages such as CHECK GEAR and / or GEAR SYS may be present.
• Select a suitable landing area.
• Inform ATC if possible.
• Burn off fuel if time allows.
• Fasten seat belts and check inertia reels.
• Brief passengers.
• Expect to complete a normal approach using the normal LANDING

CHECKS but omitting the GEAR.
• Aim to touchdown at minimum airspeed and in a level attitude.

GEAR
1. FD / AP MASTER SWITCH..............................................OFF
If during the day:

2. BATT MASTER.................................................................OFF
If at night:
3. BATT MASTER...................................................................ON
Leaving battery on provides power to the landing lights.
Continues next page .

GEAR UP LANDING PROCEDURE ..Continued
When runway / landing is assured:

4. MIXTURES................................................................CUT-OFF
5. PROPELLERS..........................................................FEATHER
6. FUEL SELECTORS...........................................................OFF
7. BATT MASTER SWITCH...................................................OFF
After motion stops:

• Complete EVACUATION procedure.
GEAR

HEATER (CABIN) OVERHEAT
HTR OVERHEAT HTR OVERHEAT

Condition: An overheat in the cabin heater has been detected.
The combustion heater will automatically switch off.
• Do not attempt to restart the heater.

ICE PROTECT

PITOT HEAT FAILURE
PITOT HEAT FAIL PITOT HEAT FAIL

Condition: A failure in the pitot / stall warning system has occurred.
Objective: To restore pitot / stall warning heat.
1. PITOT / STALL WARN HEAT SWITCH.............................OFF

2. PITOT HEAT CIRCUIT BREAKER...............................RESET
Row 2, column 11
3. PITOT / STALL WARN HEAT SWITCH..............................ON
• Exit and avoid IMC.
ICE PROTECT

PROPELLER HEAT FAILURE
PROP HEAT FAIL PROP HEAT FAIL

Condition: A failure of the propeller heat.
1. PROP HEAT SWITCH......................................................OFF

Row 5, column 13

ICE PROTECT

PROPELLER HEAT MALFUNCTION
Indication: Excessive vibration with no accompanying indications.

Condition: The propeller heating system is providing uneven blade heating.
Objective: To reduce the risk of propeller unbalancing and engine failure.
Affected Engine:
1. PROPELLER..........................................................EXERCISE
• Check PROP HEAT AMPS indication is in the normal range.
Heat is supplied to one set of blades for 90 seconds and then the other set of
blades for 90 seconds.
Insufficient heat being supplied to one set of propeller blades may be verified
by a reduction in current during one on the 90 second cycles.
If vibration is resolved:
If vibration persists:
2. PROP HEAT SWITCH......................................................OFF
ICE PROTECT
Propeller heat must be switched off if vibration persists. Uneven
heating may lead to propeller or engine failure.

SURFACE DE-ICE FAILURE
SURF DEICE FAIL SURF DEICE FAIL

Condition: Surface de-ice system has either failed to achieve adequate air
pressure or failed to deflate.
Objective: To restore surface de-ice system.
1. SURF DE-ICE CIRCUIT BREAKER.............................RESET

Row 5, column 13

ICE PROTECT

VACUUM PUMP FAILURE - DOUBLE
VAC PRESS LOW VAC PRESS LOW

Condition: Both vacuum pumps have failed.
1. VACUUM INDICATION................................................CHECK
The vacuum indication is on the MFD ENGINE page.

Wing and tail icing boots are inoperative.
• Depending upon conditions, consider a precautionary landing.
VACUUM PUMP FAILURE - SINGLE
L VAC FAIL R VAC FAIL
Indication: CAS advisory message.
ICE PROTECT
Condition: One vacuum pump has failed.
1. VACUUM INDICATION................................................CHECK
The vacuum indication is on the MFD ENGINE page.
• Operate de-icing boots as normal.

Either pump has sufficient capacity to operate the deicing boots
but intentional operation in icing conditions is not recommended.

WINDSHIELD HEAT FAILURE
Indication: Ice on heated plate and no amp rise when windshield heat
activated.
Condition: A failure in the windshield heat system has occurred.
Objective: To restore windshield heat.
1. WSHLD HEAT SWITCH....................................................OFF

2. WSHLD HEAT CIRCUIT BREAKER............................RESET
Row 5, column 12
3. WSHLD HEAT SWITCH.....................................................ON

ICE PROTECT

ENGINE POWER OVERBOOST
Indication: Master warning, flashing manifold pressure indication.

Condition: A partial loss of engine power due to a turbocharger malfunction.
Likely to be caused by the waste gate failing in the CLOSED
position.
If a failure in the exhaust system is suspected:
If a failure in the exhaust system is not suspected:

Affected Engine:
1. THROTTLE.............................................................≤ 38" MAP
Expect sensitive manifold pressure response to be throttle
movements.
2. PROPELLER....................................................AS REQUIRED
3. MIXTURE................................................................FULL RICH

TURBO

COMPLETE LOSS OF ENGINE POWER
Condition: A complete loss of engine power due to a turbocharger

malfunction.

Affected Engine:
1. MIXTURE.................................................................CUT-OFF
2. THROTTLE................................................CRUISE SETTING
3. PROPELLER................................................FULL INCREASE
4. MIXTURE................................................ADVANCE SLOWLY
When engine restarts adjust for smooth engine operation.
5. POWER...............................................MINIMUM REQUIRED

TURBO

PARTIAL LOSS OF ENGINE POWER
Condition: A partial loss of engine power due to a turbocharger malfunction.

Likely to be caused by the waste gate failing in the OPEN
position.

Affected Engine:
2. PROPELLER....................................................AS REQUIRED
3. MIXTURE..........................................................AS REQUIRED
TURBO

caeoaa.com

Seneca QRH

Uploaded by

Copyright:

Available Formats

You might also like

Seneca QRH

Uploaded by

Document Information

Original Description:

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Seneca QRH

Uploaded by

Copyright:

Available Formats

5

INDEX OF EMERGENCY AND ABNORMAL CHECKLISTS

Published by CAE Aviation Academy

Gear System - Flight.....................................................................................76

Gear System - Ground.................................................................................77

Published by CAE Aviation Academy

Alternator failure - Single, page 55

BAGGAGE DOOR Baggage Door Open, page 38

ENG CHT Cylinder Head Temperature (CHT), page 59

FUEL QTY Fuel Quantity, page 71

GEAR SYS Gear System - Ground, page 77

HTR OVRHEAT Heater (Cabin) Overheat, page 80

PROP HEAT FAIL Propeller Heat Failure, page 82

START ENGD Starter Engaged, page 37

GEAR SYS Gear System - Flight, page 76

HYDR PUMP ON Gear Pump Overrun, page 75

PITOT HEAT FAIL Pitot Heat Failure, page 81

SURF DEICE FAIL Surface De-Ice Failure, page 84

VAC PRESS LOW Vacuum Pump Failure - Double, page 85

EMERG BATT ON Main Battery Failure, page 58

VAC FAIL Vacuum Pump Failure - Single, page 85

Published by CAE Aviation Academy

Tie-down Straps...............................................................REMOVE & STOW

Published by CAE Aviation Academy

All Exterior Lights......................................................................................ON

Published by CAE Aviation Academy

A CHECK - STARBOARD WING

Wing tip and Lights............................................................................CHECK

Published by CAE Aviation Academy

A CHECK - NOSE SECTION

Published by CAE Aviation Academy

A CHECK - PORT WING

Published by CAE Aviation Academy

A CHECK - FUSELAGE (PORT SIDE)

A CHECK - FUSELAGE (STARBOARD SIDE)

Published by CAE Aviation Academy

Published by CAE Aviation Academy

Published by CAE Aviation Academy

COLD ENGINE START (OIL TEMPERATURE BELOW 100°F)

Published by CAE Aviation Academy

COLD WEATHER ENGINE START (FROST)

Published by CAE Aviation Academy

HOT ENGINE START (OIL TEMPERATURE ABOVE 100°F)

ATIS & Start Clearance...........................................................AS REQUIRED

Published by CAE Aviation Academy

FLOODED ENGINE START

Published by CAE Aviation Academy

EXTERNAL POWER ENGINE START

Published by CAE Aviation Academy

Published by CAE Aviation Academy

Published by CAE Aviation Academy

Published by CAE Aviation Academy

AFTER TAKE-OFF / GO-AROUND

Published by CAE Aviation Academy

TOP OF CLIMB CHECK

EN ROUTE CLIMB USING AUTOPILOT

EN ROUTE DESCENT USING AUTOPILOT
