Integral E&M Engineering

A Member of Build King Group

1124 Admiralty Station

(ADM) Final Phase

Training Material of
Fire Services System
Content
1. Background Information
2. Fire Detection System (Point Type, Beam, Flame, Aspirating Smoke
Detection)
3. FH/HR System
4. Gaseous Suppression System (FM200)
5. Sprinkler System
6. Open-type Sprinkler System
 Fire Detection System

Components of AFA System

- AFA Fire Alarm Control Panel (N5)

- AFA Workstation
- Smoke Detectors
- Heat Detectors
- Monitor Modules
- Control Modules
- Relay Modules
- Line Isolators
 Fire Detection System

AFA Fire Alarm Control Panel (N5)

- Located at Concourse – Station

Control Room
- LCD Display with LED zone indicators
- Direct Link connect to Fire Bridge
- Interfacing to Alarm Bell / VFA / Exit
Sign / Fire Shutters etc.
- Interfacing to MCS/ SBCS
Fire Detection System
Fire Detection System

Summary of AFA field devices

Field device Quantity

No. of cable loop 10 loop
Smoke detector 891 nos.
Heat detector 49 nos.
Monitor module 539 nos.
Control module 28 nos.
Relay module 170 nos.
Line isolator 105 nos.
Fire Detection System

Testing and Commissioning

- Isolate the output point

- Suspend the FSDTL

- Use magnet to simulate fire alarm signal

- Point address and description show on LCD display

- Reset the AFA Panel

Beam Detection System

 Design Criteria

 BS 5839-1-2002+A2-2008
Beam Detection System

 Beam Detectors Location

Beam Detection System

 Building Geometry
Beam Detection System

 Component
Beam Detection System

 T&C
ASD System

Provided at area with ceiling height not exceeding 15m

Provide detection for area that has difficulties to access

e.g.: Atrium false ceiling, Atrium Voids
ASD Sampling Point
ASD Pipes distribution
ASD Pipes distribution
ASD System
Testing and Commissioning

Smoke test simulation by aerosol gas to trigger fire alarm signal within 120 second
Flame Detection System

 1 for <100kW, 2 for < 800kW

 Following the manufacture user guide

 Interfacing with Open type sprinkler system & AFA

 2 low sensitivity flame detector are activating the deluge

valve actuator

 1 high sensitivity flame detector is activating AFA

Flame Detection System

 2 low sensitivity flame detector are activating the deluge

valve actuator
Flame Detection System
 1 high sensitivity flame detector is activating AFA
Flame Detection System
 Components

Test Lamp

Flame Detector Angle restrictor

Flame Detection System
 Flame detector coverage
 Flame Detection System

 Installation – Ceiling Type

Flame Detection System

 Installation – Side Type

Flame Detection System

 Installation – Side Mounted Type With 90 Deg Elbow

Flame Detection System

 Testing and Commissioning

 Remember to disable the outputs, as a

full functional test includes activating
the ALARM outputs. A Honeywell
Analytics Test Lamp must be used for
this test. Point the Test Lamp directly at
the front of the Detector (on axis as
much as possible, within a distance of
about 1 to 25 feet / 7.5m). Activate
the Test Lamp by pressing and holding
its pushbutton. While watching the red
ALARM LED on the face of the
Detector, slowly move the Test Lamp’s
boresight to ensure the Detector
receives its full intensity.
 The Detector’s red ALARM LED will
illuminate, usually within three (3) to
ten (10) seconds.
FH/HR System

System Components:

 Single Fire Hydrant (Pressure reducing

type)
 Fire Hose Reel
 Manual Call Point
 Motorize Isolation Valve (MIV)
 Pressure Reducing Valve
FH/HR System

Summary of FH/HR System:

Equipment Quantity
Fire Hydrant (single outlet) 76 nos.
Fire Hose Reel 38 sets.
Manual Call Point 55 nos.
Motorized Isolation Valve (MIV) 4 nos.
Pressure Reducing Valve 1 set.
FH/HR System
System Schematic
FH/HR System
MIV configuration
FH/HR System

Testing and Commissioning:

Equipment Location Acceptance criteria
Fire Hydrant All level FOH/BOH Flow: 1350L/min in 3
FH
Pressure: 3.5‐8.5 Bar
Static: 3.5‐8.5 Bar
Hose Reel All level FOH/BOH Projecting a jet > 6m
MIV SCL Platform H/W & Functional :
T/W Remote / Manual
Open and Close
Manual Call Point All Level FOH/BOH Press the plastic plate
to actuate the FS
Pump and Alarm Bell
FM200 Total Gas Flooding System
FM200 Total Gas Flooding System
Typical System Schematic
FM200 Total Gas Flooding System
 FM200 Total Gas Flooding System

• Important notes:

• Activation
of FM200 gas release by Zone 1 and Zone 2 smoke detector
simultaneously;

• “DO NOT ENTER” red flashing lamp lit on Siren and Red flashing light
activated;

• Count down ~ 30 seconds and the gas will totally discharge;

• Undermanual mode operation, FM200 agent is allowed to discharge

by activating the manual release switch;

• Pressure
switch is wired to FM200 control panel for actuate an audible
and visual alarms after gas discharged.
Sprinkler System

System Schematic (1 of 4)
Sprinkler System

System Schematic (2 of 4)
Sprinkler System

System Schematic (3 of 4)
Sprinkler System

System Schematic (4 of 4)
Sprinkler System
Sprinkler Control Valve (CVS‐2 and 8)
Open Type Sprinkler System
System Overview
Open Type Sprinkler System
Summary of protected escalator void
Open Type Sprinkler System
Equipment
Open Type Sprinkler System
Testing and Commissioning (Flow & Pressure)
Open Type Sprinkler System
Testing and Commissioning (Supervisory signals)
