ONE-PIECE BRAIDED MESH FIRE HOSE

4 1 3

5 2
Rated working pressure：1.6MPa
Maximum ambient temperature：107℃ /225 ℉

MATERIAL DETAIL：

NO. Description Material Material list

1 Hose Stainless steel 304 1

2 Outer Shackle Stainless steel 304 2

3 Inlet Nipple Stainless steel 304 1

4 Outlet Nipple Stainless steel 304 1

5 Net Stainless steel 304 1

SPECIFICATIONS：

Name Total length of hose Dimensions of inlet and outlet connections

Intake stub Water outlet

Model number MM
DN IN DN IN
20 3/4" 15 1/2"
FB20 500
25 1" 20 3/4"
20 3/4" 15 1/2"
FB28 700
25 1" 20 3/4"
20 3/4" 15 1/2"
FB40 1000
25 1" 20 3/4"
20 3/4" 15 1/2"
FB48 1200
25 1" 20 3/4"
20 3/4" 15 1/2"
FB60 1500
25 1" 20 3/4"
20 3/4" 15 1/2"
FB72 1800
25 1" 20 3/4"
20 3/4" 15 1/2"
FB80 2000
25 1" 20 3/4"

Certification/ Attestation： FM
APPROVED

SPH0123
1
TWO-SECTION BRAIDED MESH FIRE HOSE（DN20）

5 3 1

6 4 2 2

Rated working pressure：1.6MPa

Additional pressure：6.4MPa
Blasting pressure：12.8MPa

MATERIAL DETAIL：

NO. Description Material Material list

Stainless steel 304 (FBQ)

1 Inlet Nipple 1
Stainless steel 201(FBX)

2 Outer Shackle Stainless steel 304 2

3 Hose Stainless steel 304 1

4 Connecting piece Stainless steel 304 1

5 Hexagon nut Carbon Steel (Galvanizing) 1

6 Outlet Nipple Carbon Steel (Galvanizing) 1

7 Net Stainless steel 304 1

SPECIFICATIONS：

Name Total length of hose Dimensions of inlet and outlet connections

Intake stub Water outlet

Model number MM
DN IN DN IN
15 1/2"
FBQ/FBX28 700 25 1"
20 3/4"
15 1/2"
FBQ/FBX40 1000 25 1"
20 3/4"
15 1/2"
FBQ/FBX48 1200 25 1"
20 3/4"
15 1/2"
FBQ/FBX60 1500 25 1"
20 3/4"
15 1/2"
FBQ/FBX72 1800 25 1"
20 3/4"

Certification / Attestation：3C certification

SPH0123
2
THREE-SECTION BRAIDED MESH FIRE HOSE（DN20）

5 2 7 3 4 1 6

Maximum working pressure：1.6MPa / 232 Psi

Maximum ambient temperature：107℃ /225 ℉

MATERIAL DETAIL：

NO. Description Material Material list

1 Nylon ring Nylon 2

2 Hexagon nut Carbon Steel (Galvanizing) 2

3 Hose Stainless steel 304 1

4 Outer Shackle Stainless steel 304 2

5 Outlet Nipple Carbon Steel (Galvanizing) 1

6 Inlet Nipple Carbon Steel (Galvanizing) 1

7 Net Stainless steel 304 1

SPECIFICATIONS：

Name Total length of hose Dimensions of inlet and outlet connections

Water Inlet Water outlet

Model number MM
DN IN DN IN
15 1/2"
FBC1-700 700 25 1"
20 3/4"
15 1/2"
FBC1-1000 1000 25 1"
20 3/4"
15 1/2"
FBC1-1200 1200 25 1"
20 3/4"
15 1/2"
FBC1-1500 1500 25 1"
20 3/4"
15 1/2"
FBC1-1800 1800 25 1"
20 3/4"

Certification/ Attestation： FM C
UL
R US （ Unlimited Bending Number Type）
APPROVED LISTED

SPH0123
3
THREE-SECTION BRAIDED MESH FIRE HOSE（DN25）

6 4 7 1 2 3 5

Maximum working pressure：1.4MPa/ 200 Psi

Maximum ambient temperature：107℃ /225 ℉

MATERIAL DETAIL：

NO. Description Material Material list

1 Hose Stainless steel 304 1

2 Outer Shackle Stainless steel 304 2

3 Welding ring Stainless steel 304 2

4 Hexagon nut Carbon Steel (Galvanizing) 2

5 Inlet Nipple Carbon Steel (Galvanizing) 1

6 Outlet Nipple Carbon Steel (Galvanizing) 1

7 Net Stainless steel 304 1

SPECIFICATIONS：

Name Total length of hose Dimensions of inlet and outlet connections

Water Inlet Water outlet

Model number MM
DN IN DN IN
15 1/2"
FBC2-700 700 25 1"
20 3/4"
15 1/2"
FBC2-790 790 25 1"
20 3/4"
15 1/2"
FBC2-915 915 25 1"
20 3/4"
15 1/2"
FBC2-1000 1000 25 1"
20 3/4"
15 1/2"
FBC2-1200 1200 25 1"
20 3/4"
15 1/2"
FBC2-1500 1500 25 1"
20 3/4"
15 1/2"
FBC2-1800 1800 25 1"
20 3/4"

Certification/ Attestation： FM C
UL
R US （ Unlimited Bending Number Type）
APPROVED LISTED

SPH0123
4
THREE-SECTION BELLOWS TYPE FIRE HOSE

3 2 1 4
5

Maximum working pressure：1.2MPa/175 Psi

Maximum ambient temperature：107℃ /225 ℉

MATERIAL DETAIL：

NO. Description Material Material list

1 Hose Stainless steel 304 1

2 Hexagon nut Stainless steel 304 2

3 Outlet Nipple Carbon Steel (Galvanizing) 1

4 Inlet Nipple Carbon Steel (Galvanizing) 1

5 Nylon ring Nylon 2

SPECIFICATIONS：

Name Total length of hose Dimensions of inlet and outlet connections

Water Inlet Water outlet

Model number MM
DN IN DN IN
15 1/2"
FUC1-700 700 25 1"
20 3/4"
15 1/2"
FUC1-1000 1000 25 1"
20 3/4"
15 1/2"
FUC1-1200 1200 25 1"
20 3/4"
15 1/2"
FUC1-1500 1500 25 1"
20 3/4"
15 1/2"
FUC1-1800 1800 25 1"
20 3/4"

Certification/ Attestation： C
UL
R US （ Limited number of bends）
LISTED

SPH0123
5
FASTENER BRACKET DETAILS

Application
Name Picture Material Quality Dimensions (mm)
Description
50

Galvanized Carbon Steel

Common fastener
ASTM A283 Gr.D 62

Galvanized Carbon Steel

Fastening fastener ASTM A283 Gr.D
60

60

Galvanized Carbon Steel

65.3
Self-locking fastener
ASTM A283 Gr.D

60

30

Galvanized Carbon Steel

E-frame ASTM A283 Gr.D 62.24

30

Galvanized Carbon Steel

E-type long bracket 102
ASTM A283 Gr.D

32

Galvanized Carbon Steel

LONG support
ASTM A283 Gr.D 92

32

Galvanized Carbon Steel

SHORT support
ASTM A283 Gr.D
70

30

Galvanized Carbon Steel

J-frame
ASTM A283 Gr.D 40

35

Galvanized Carbon Steel

Keel fitting 87.4
ASTM A283 Gr.D

SPH0123
6
INLET NIPPLE

1 2
4 5
Material Describe
Galvanized Carbon Steel
1 length 48mm，inlet Rc 1
ASTM
Galvanized Carbon Steel
2 length 64mm，inlet Rc 1
3 ASTM
Galvanized Carbon Steel
3 length 64mm，inlet Rc 1
ASTM
Galvanized Carbon Steel
4 length 76mm，inlet Rc 1
ASTM
Galvanized Carbon Steel
5 length 76mm，inlet Rc 1 welding
ASTM
Galvanized Carbon Steel
6 length 70mm，inlet Rc 1-1/4
ASTM
6

OUTLET NIPPLE

Material Describe

1 304 length 100mm，outlet Rc1/2

2 304 length 100mm square head，Rc1/2

Galvanized Carbon Steel
3 length 110mm，outlet Rc1/2orRc3/4
ASTM
Galvanized Carbon Steel
4 length 140mm，outlet Rc1/2orRc3/4
ASTM
Galvanized Carbon Steel
5 length 184mm，outlet Rc1/2orRc3/4
ASTM
Galvanized Carbon Steel
6 length 330mm，outlet Rc1/2orRc3/4
ASTM
1 2 3 4 5 6

Material Describe

length 80mm，outlet：M34 nut

Galvanized Carbon Steel
1
ASTM

2 304 length 89mm，outlet Rc1/2orRc3/4

1 2
Galvanized Carbon Steel
3 length 85mm，outlet Rc1/2orRc3/4
ASTM
Galvanized Carbon Steel
4 length 115mm，outlet Rc1/2orRc3/4
ASTM
Galvanized Carbon Steel
5 length 147mm，outlet Rc1/2
ASTM

3 4 5

SPH0123
7
INSTALLATION NOTES

Step 1：Install the fire sprinkler head into the
short water outlet pipe, Seal the threads with
Teflon anti-bleed tape or glue. For the specific
method of installing the sprinkler, please refer
to the installation instructions of the
manufacturer of the fire sprinkler used.
Step 2：Connect the water inlet spool of the
hose to the fire water supply line and seal the
threads with glue or Teflon anti-bleed tape.
The tightening torque is about 35ft-lbs/50N m

Figure 1 Figure 2 Figure 3

Step 3：Tighten the hexagonal nut on the upper Step 4：Install fasteners
end of the hose with the water inlet short pipe, the Place the square tube fasteners on both sides of the main T-shaped steel frame, and then
maximum tightening torque is 15ft-lbs/20N m; place the quick-release fasteners in the middle of the square tube first, and then install the
meanwhile, check and make sure that the sealing ring square tube on the square tube fasteners on both sides. Tighten all the screws of the square
is in good condition and installed in place. Do not tube fastener (recommended torque is about 3ft-lbs/4N m)
over-tighten the hexagon nut. Excessive torque may
damage the sealing ring.
▶ Pipe adhesive, hemp wire, Teflon leak-proof tape
cannot be used when connecting here, and the
product comes with an O-ring seal to provide
effective sealing performance.

Figure 1 Figure 2

Step 5：Insert the galvanized square tube into
the reserved hole of the bracket, insert the
fastener into the square tube, and place it in the
two brackets. Tighten the bolts above the two
brackets and secure the square tube with a
tightening torque of about 3ft-lbs/4N m.
Step 6：The quick release fastener moves to the desired position. Bend the hose and
place the outlet stub of the hose in the quick-release fastener. Adjust the height of the
outlet spool to ensure the correct position of the sprinkler.
Note: When bending the hose, the bending radius and bending angle must not be less
than the data in Table 1, otherwise the actual flow resistance coefficient will not match
the certification data and design requirements.
Close the short tube fastener as shown and tighten the screw to 3ft-lbs/4N m.
The outlet short pipe is locked.
Ordinary fastener installation as shown in Figure 2
