PT RIMEX INTERNATIONAL INDONESIA

CATALOGUE WHEEL / RIM

PT. KTC
 KOMATSU HD 465-7 RIGID DUMP TRUCK

TYRE SIZE : 24.00 R 35

WHEEL TYPE : 3517 MES/EV

PARTS BREAK DOWN P/N RIMEX DESCRIPTION

WHEEL ASSEMBLY 825-035-0157-01-A WHEEL ASSY,3517 MES/EV, HD 465-7

WHEEL BASE 820-035-0157-01 WHEEL BASE,3517 MES/EV, HD 465-7
SIDE RING (EACH) 100-035-0002 SIDE RING, 3535,HF
BEAD SEAT BAND 200-035-0014 BEAD BAND, 35, EM
LOCK RING 300-035-0013 LOCK RING, 35, EV

820-035-0157-01 825-035-0157-01-A
 KOMATSU HD 465-7 RIGID DUMP TRUCK

CONSUMABLE HARDWARE “LARGE BORE VALVES”

PARTS BREAK DOWN PART NUMBER DESCRIPTION

O RING HAL-OR-335-T O RING 35"

SPUD HAL-H-41 LB, CLAMP-IN SPUD
SPUD HAL-C-10 LB, SCREW-IN SPUD
VALVE STEM HAL-569-30-71600 LB SWIVEL VALVE COMPLETE ( VALVE STEM & SPUD )
FLEXIBLE EXTENSION VALVE HAL-810F-32 LB FLEXIBLE EXTENSION VALVE 32" LENGTH
STRAIGHT VALVE HAL-H-42 SCREW IN VALVE 1/4" C/W CORE AND CAP
VALVE CORE HAL-A-145 LARGE BORE VALVE CORE
VALVE CAP HAL-A-149 LARGE BORE HEX CAP

569-30-71600

810F-32
 CATERPILLAR 740 ARTICULLATED DUMP TRUCK

TYRE SIZE : 29.5 R 25

WHEEL TYPE : 2525 MES/EM

PARTS BREAK DOWN P/N RIMEX DESCRIPTION

WHEEL ASSEMBLY 825-025-0299-01-A WHEEL ASSY,2525,MES/EM,CATERPILLAR,740
WHEEL BASE 820-025-0299-01 WHEEL BASE,2525,MES/EM,CATERPILLAR,740
SIDE RING (EACH) 100-025-0017 SIDE RING,3525,HF
BEAD SEAT BAND 200-025-0004-01 BEAD BAND,25,EM-H,RADIAL,PKT,DR31A
LOCK RING 300-025-0004 LOCK RING,25,EM
DRIVE KEY 710-000-0012 DRIVER KEY,F31C
 CATERPILLAR 740 ARTICULLATED DUMP TRUCK

CONSUMABLE HARDWARE

PARTS BREAK DOWN PART NUMBER DESCRIPTION

O RING HAL-OR-325-T 25" O-RING
SPUD HAL-H-41 CLAMP-IN SPUD
VALVE STEM HAL-WH-300-J-650 SWIVEL VALVE STEM
 VOLVO A40D ARTICULLATED DUMP TRUCK

TYRE SIZE : 29.5 R 25

WHEEL TYPE : 2525 MES/EM

PARTS BREAK DOWN P/N RIMEX DESCRIPTION

WHEEL ASSEMBLY 825-025-0300-01-A WHEEL ASSY,2525,MES/EM,VOLVO,A40D
WHEEL BASE 820-025-0300-01 WHEEL BASE,2525,MES/EM,VOLVO,A40D
SIDE RING (EACH) 100-025-0017 SIDE RING,3525,HF
BEAD SEAT BAND 200-025-0004-01 BEAD BAND,25,EM-BIAS,PKT
LOCK RING 300-025-0004 LOCK RING, 25,EM
DRIVE KEY 710-000-0012 DRIVER KEY,F31C

825-025-0300-01-A
 VOLVO A40D ARTICULLATED DUMP TRUCK

CONSUMABLE HARDWARE

PARTS BREAK DOWN PART NUMBER DESCRIPTION

O RING HAL-OR-325-T 25" O-RING
SPUD HAL-H-41 CLAMP-IN SPUD
VALVE STEM HAL-WH-300-J-650 SWIVEL VALVE STEM
 CATERPILLAR 785C RIGID DUMP TRUCK

TYRE SIZE : 33.00 R 51

WHEEL TYPE : 5124 MES/HDT

PARTS BREAK DOWN P/N RIMEX DESCRIPTION

WHEEL ASSEMBLY 825-051-0114-01-A WHEEL ASSY,5124 MES/HDT,CAT785,53H
WHEEL BASE 820-051-0114-01 WHEEL BASE,5124 MES/HDT,CAT785,53H
SIDE RING (EACH) 100-051-0022 SIDE RING, 5051,HF
BEAD SEAT BAND 200-051-0015 BEAD BAND, 51, HDT, RADIAL, GR
LOCK RING 300-051-0012 LOCK RING, 51, HDT
 CATERPILLAR 785C RIGID DUMP TRUCK

ACCESSORIES

PARTS BREAK DOWN PART NUMBER DESCRIPTION

STUD 730-000-0013 STUD,8X2560,CAT 785/789,1 UNC,CLP HD
STUD 730-000-0014 STUD,8X2561,CAT 785/789,1 UNC,CLP HD
NUT 730-000-0009 NUT,2J3507,CAT 785/789,1 UNC,HEX
WASHER 730-000-0010 WASHER,5P8250,CAT 785/789,1,HARDENED
ADAPTOR 630-057-0023 ADAPTOR,CAT 785/789,PRESS FIT STUDS
ADAPTOR, LESS STUD 630-057-0012 ADAPTOR,CAT 785/789,W/O STUD
 CATERPILLAR 785C RIGID DUMP TRUCK

CONSUMABLE HARDWARE “SUPER LARGE BORE VALVE”

PARTS BREAK DOWN PART NUMBER DESCRIPTION

O RING HAL-OR-451-T O RING 51"
SPUD HAL-T-81 SLB, CLAMP-IN SPUD
SPUD HAL-C-100 SLB, SCREW-IN SPUD
SWIVEL CONNERTOR HAL-R-660 SWIVEL VALVE CONNECTOR 60 DEGREE
CORE HOUSING HAL-R-520 CORE HOUSING COMPLETE
SWIVEL CONNERTOR HAL-R-525 SWIVEL VALVE CONNECTOR 90 DEGREE
EXTENSION TUBING HAL-R-760-100 1/2" ID EXTENSION TUBING 100 FOOT/ROLL
SWIVEL VALVE HAL-MR-800-8 RIGIT METAL SWIVEL VALVE
VALVE KIT HAL-969-K PART KIT FOR SLB EXTENSION
VALVE CORE HAL-A-149 LARGE BORE VALVE CORE
VALVE CAP HAL-A-145 LARGE BORE HEX CAP
 CATERPILLAR 785C RIGID DUMP TRUCK

5124 MES/DGS WHEEL TYPE - TO SUIT POS# 3 & POS# 6

PARTS BREAK DOWN P/N RIMEX DESCRIPTION

WHEEL ASSY,5124 MES/DGS,CAT785,53H,INTEGRAL
WHEEL ASSEMBLY 825-051-0139-02-A
ADAPTOR
WHEEL BASE,5124 MES/DGS,CAT785,53H,INTEGRAL
WHEEL BASE 820-051-0139-02
ADAPTOR
SIDE RING (EACH) 100-051-0022 SIDE RING, 5051,HF
BEAD SEAT BAND (EACH) 200-051-0015 BEAD BAND, 51, HDT, RADIAL, GR
LOCK RING (EACH) 300-051-0018 LOCK RING, 51, HDT,2PCS ASSY
 CATERPILLAR 777D RIGID DUMP TRUCK

TYRE SIZE : 27.00 R 49

WHEEL TYPE : 4919 MES/EV

PARTS BREAK DOWN P/N RIMEX DESCRIPTION

WHEEL ASSEMBLY 825-049-0140-01-A WHEEL ASSY,4919,MES/EV,CAT 777,20H
WHEEL BASE 820-049-0140-01 WHEEL BASE,4919,MES/EV,CAT 777,20H
SIDE RING (EACH) 100-049-0017 SIDE RING,4049,HF,3.5" W
BEAD SEAT BAND 200-049-0023 BEAD BAND,49,EM-H-V,RADIAL,GR
LOCK RING 300-049-0014 LOCK RING,49,EV
 CATERPILLAR 777D RIGID DUMP TRUCK

CONSUMABLE HARDWARE “LARGE BORE VALVE”

PARTS BREAK DOWN PART NUMBER DESCRIPTION

O RING HAL-OR-449-T 49" O-RING
SPUD HAL-H-41 CLAMP-IN SPUD
SPUD HAL-C-100 SCREW-IN SPUD
STRAIGHT VALVE HAL-H-42 STRAIGHT VALVE
REAR INNER VALVE HAL-WHG-8018VC SPECIAL FORM VALVE
REAR OUTER VALVE HAL-WHG-8019VC SPECIAL FORM VALVE
VALVE CORE HAL-A-145 LARGE BORE VALVE CORE
VALVE CAP HAL-A-149 LARGE BORE HEX CAP
 KOMATSU HD 785-5 RIGID DUMP TRUCK

TYRE SIZE : 27.00 R 49

RIM TYPE : 4919 MES/EV

PARTS BREAK DOWN P/N RIMEX DESCRIPTION

RIM ASSEMBLY 815-049-0121-05-A RIM,4919,MES/EV,KOMATSU 785-3/5,SCB 4.50
RIM BASE 810-049-0121-05 RIM,4919,MES/EV,KOMATSU 785-3/5,SCB 4.50
SIDE RING (EACH) 100-049-0017 SIDE RING,4049,HF,3.5" W
BEAD SEAT BAND 200-049-0023 BEAD BAND,49,EM-H-V,RADIAL,GR
LOCK RING 300-049-0014 LOCK RING,49,EV
 KOMATSU HD 785-5 RIGID DUMP TRUCK

ACCESSORIES

PARTS BREAK DOWN PART NUMBER DESCRIPTION

SPACER BAND 750-049-0021 SPACER,49,11.75,1.12,45.12 ID,IC
WEDGE BAND 760-049-0012 WEDGE BAND,49,4.25,0.75,KOM 785-3
STUD 730-000-0047 DOUBLE ENDED STUD,KOMATSU HD785-3/5,6.50"L
NUT 730-000-0048 NUT,KOMATSU HD785-3/5,M30,HEX

750-049-0021
 KOMATSU HD 785-5 RIGID DUMP TRUCK

CONSUMABLE HARDWARE “LARGE BORE AND SUPER LARGE BORE VALVE”

PARTS BREAK DOWN PART NUMBER DESCRIPTION

O RING HAL-OR-449-T 49" O-RING
SPUD HAL-H-41 CLAMP-IN SPUD
VALVE STEM HAL-WH-45-4 1/2 SWIVEL VALVE STEM
VALVE STEM FOR REAR INNER POSITION HAL-WH-45-24 SWIVEL VALVE STEM
SPUD HAL-T-81 SLB CLAMP-IN SPUD
SWIVEL CONNERTOR HAL-R-525 SWIVEL VALVE CONNECTOR 90 DEGREE
CORE HOUSING HAL-R-520 CORE HOUSING COMPLETE
EXTENSION TUBING HAL-R-760-100 1/2" ID EXTENSION TUBING 100 FOOT/ROLL
VALVE KIT HAL-969-K PART KIT FOR SLB EXTENSION
SWIVEL CONNECTOR HAL-R-660 SWIVEL VALVE CONNECTOR 60 DEGREE
VALVE CORE HAL-A-149 LARGE BORE VALVE CORE
VALVE CAP HAL-A-145 LARGE BORE HEX CAP

WH-45-4 1/2

WH-45-24
 CATERPILLAR 773D RIGID DUMP TRUCK

TYRE SIZE : 24.00 R 35

WHELL TYPE : 3517 MES/EV

PARTS BREAK DOWN P/N RIMEX DESCRIPTION

WHEEL ASSEMBLY 825-035-0125-02-A WHEEL ASSY,3517,MES/EV,CAT 773,14H
WHEEL BASE 820-035-0125-02 WHEEL BASE,3517,MES/EV,CAT 773,14H
SIDE RING (EACH) 100-035-0002 SIDE RING,3535,HF
BEAD SEAT BAND 200-035-0014 BEAD BAND,35,EM-H-V,RADIAL,PKT
LOCK RING 300-035-0013 LOCK RING,35,EV
 CATERPILLAR 773D RIGID DUMP TRUCK

CONSUMABLE HARDWARE “LARGE BORE VALVE”

PARTS BREAK DOWN PART NUMBER DESCRIPTION

O RING HAL-OR-335-T 35" O-RING
SPUD HAL-H-41 CLAMP-IN SPUD
SPUD HAL-C-10 SCREW-IN SPUD
VALVE STEM HAL-WH-45-4 1/2 VALVE STEM, FRONT
VALVE STEM HAL-WHG-0570-VC VALVE STEM, REAR INNER
VALVE STEM WH-45-28 VALVE STEM, REAR OUTER
VALVE CORE HAL-A-149 LARGE BORE VALVE CORE
VALVE CAP HAL-A-145 LARGE BORE HEX CAP

WH-45-28

WH-45-4 1/2
 KOMATSU HM400-1 ARTICULLATED DUMP TRUCK

TYRE SIZE : 29.5 R 25

WHELL TYPE : 2525 MES/EM

PARTS BREAK DOWN P/N RIMEX DESCRIPTION

WHEEL ASSEMBLY 825-025-0708-01-A WHEEL ASSY,2525,MES/EM,KOMATSU,HM400
WHEEL BASE 820-025-0708-01 WHEEL BASE,2525,MES/EM,KOMATSU,HM400
SIDE RING (EACH) 100-025-0017 SIDE RING,3525,HF
BEAD SEAT BAND 200-025-0004-01 BEAD BAND,25,EM-H,RADIAL,PKT,DR31A
LOCK RING 300-025-0004 LOCK RING,25,EM
DRIVE KEY 710-000-0012 DRIVER KEY,F31C
 KOMATSU HM400-1 ARTICULLATED DUMP TRUCK

CONSUMABLE HARDWARE “LARGE BORE VALVES”

PARTS BREAK DOWN PART NUMBER DESCRIPTION

O RING HAL-OR-325-T 25" O-RING
SPUD HAL-H-41 CLAMP-IN SPUD
VALVE STEM HAL-WH-300-J-650 SWIVEL VALVE STEM

WH-300-J-650
 CATERPILLAR 14H/M MOTOR GRADER

TYRE SIZE : 20.5 R 25

WHELL TYPE : 2517 FS/T

PARTS BREAK DOWN P/N RIMEX DESCRIPTION

WHEEL ASSEMBLY 825-025-0351-01-A WHEEL ASSY,2517,FS/T,CAT 14H/M,10H
WHEEL BASE 820-025-0351-01 WHEEL BASE,2517,FS/T,CAT 14H/M,10H
FLANGE 210-025-0023 FLANGE,1025,T
LOCK RING 300-025-0003 LOCK RING,25,T
 CATERPILLAR 14H/M MOTOR GRADER

CONSUMABLE HARDWARE “LARGE BORE VALVES”

PARTS BREAK DOWN PART NUMBER DESCRIPTION

O RING HAL-OR-325-T 25" O-RING
SPUD HAL-H-41 CLAMP-IN SPUD
VALVE STEM HAL-WH-300-J-650 SWIVEL VALVE STEM

WH-300-J-650
 CATERPILLAR 16H/M MOTOR GRADER

TYRE SIZE : 23.5 R 25

WHELL TYPE : 2519 MES/EM

PARTS BREAK DOWN P/N RIMEX DESCRIPTION

WHEEL ASSEMBLY 825-025-0186-01-A WHEEL ASSY,2519,MES/EM,CAT 16H/M,10H
WHEEL BASE 820-025-0186-01 WHEEL BASE,2519,MES/EM,CAT 16H/M,10H
SIDE RING (EACH) 100-025-0018 SIDE RING,2525,HF
BEAD SEAT BAND 200-025-0015 BEAD BAND,25,EM-H,BIAS,PKT
LOCK RING 300-025-0004 LOCK RING,25,EM
DRIVE KEY 710-000-0012 DRIVER KEY,F31C
 CATERPILLAR 16H/M MOTOR GRADER

CONSUMABLE HARDWARE “LARGE BORE VALVES”

PARTS BREAK DOWN PART NUMBER DESCRIPTION

O RING HAL-OR-325-T 25" O-RING
SPUD HAL-H-41 CLAMP-IN SPUD
VALVE STEM HAL-WH-300-J-650 SWIVEL VALVE STEM

WH-300-J-650
 SCANIA P124CB-8x4-420 ROAD TYPE TRUCK

TYRE SIZE : 12.00 R 24

WHELL TYPE : 2485 - 3PCS

PARTS BREAK DOWN PART NUMBER DESCRIPTION

WHEEL ASSEMBLY JTA-85300 UNI,DUAL,24x8.50,335mm-10H,3pc
