Bench Drilling
 HUMBLE BEGINNING
Founded 1994 formerly known as
Shin Sung. Several technical break-
throughs were made by technical
licenses with Toa-Boring-Tone in
JAPAN and Drill master USA. Since
then, new overburden system like
SUS and SIS were launched in the
market becoming popular among
corporate customers.
Acquired by Everdigm in 2011, it
is ready to leap to the world class
manufacturer of rocktools.

MASSIVE PRODUCTION FACILITY

Sprawling into 108,000 sqm headquarter and 10,300 sqm factory number 2, the mas-
sive production facility can do the job. In-house heat treatment. numerous CNC & MCT
machines. Also big size DTH hammer is the specialty for us.

1 Factory 2 in Jeonju
2 Headquarter in Jincheon
3 Machining
4 DTH bits in production

2 3 4

02
HIDDEN HERO

Everdigm has supplied DTH hammer for CR

12 X 5-1/2 hole opener, made by Centerrock
for USA in Chilean miner rescue operation.
Given the fact that the DTH hammer is the
core part for cluster drill, this shows that our
DTH hammer will endure in tough job site.

VARIOUS PRODUCTS RANGE

DTH hammer and bits, tophammer consumables, overburden tool,

RCD system. You name it. We have it. With strong R&D forces, we
have been paving the way for new products.

GOOD REFERENCE
Gammon ; the leading construc-
tion and engineering contractor
headquartered in Hong Kong
has been major customer for
Everdigm over a decade. The
requirement of overburden
system in hard formation is quite
high and Everdigm overburden
is the only one that satisfactorily
finishes the job.

03
 BUTTON BIT FACE DESIGNS

Flat Face Drop Center

- General purpose bit - Straight hole application
- Hard to medium conditions - Broken ground conditions

Convex
- Clearly defined raised face profiles
- Primary reaming applications in soft
ground

BUTTON BIT CARBIDE SHAPE

Spherical Button Ballistic Button

- Application Strength - universal button - Application Strength - fast penetration
- Best suited to hard ground - Best suited to soft ground
- Abrasive to very abrasive - Non abrasive ground

Semi-ballistic Button Conical Button

- Application Strength - universal button - Application Strength - fast penetration
- Best suited to medium ground - Suited for all non-abrasive ground types
- Midly abrasive ground - Smaller contact area
- Best suited for smaller diameter bits

04
PRODUCT CODE

Button Bits
064 R32 S F 30 36 3 N (1012)
Flushing groove
Gauge Carbide Face Gauge Flushing Skirt Carbide diameter
Thread type No. for face
diameter shape shape angle hole No. shape (optional)
and gauge

064 mm R32 S : Spherical F : Flat 30o Face + Gauge 2 N : Normal Face + Gauge
R38 P : Parabolic D : Drop 35o 3 R : Retrac (F : 10mm,
T38 B : Ballistic Center 40o 4 G : 12mm)
T45 C : Conical
T51

Rods
R EX R32 R32 3050
Thread Thread
R Type Length
(Male) (Male / Female)

R- Rod EX : Extension R32 R32 3,050

(Male / Male) R38 R38 3,660
T38 T38 4,270
MF : MF
T45 T45
(Male / Female)
T51 T51
HX : Hexagon
TD : Tandem

Coupling Sleeve
C R32 R32
Coupling Thread Thread

C- Coupling R32 R32

R38 R38
T38 T38
T45 T45
T51 T51

05
 Memo

06
Button Bits
T38 (1 1/2”) SERIES ........................................................................................... 08
T45 (1 3/4”) SERIES ........................................................................................... 09
T51 (2”) SERIES ................................................................................................... 10
GT60 (2 1/4”) SERIES ....................................................................................... 11

07
Button Bits
T38 (1 1/2”) Thread

Diameter Flushinghole No. Buttons

Front No. Gauge No. Part No. Product Code

mm in Front Gauge Angle Design
x size x size
Normal
64 2 1/2” 3 - 3 x 11 6 x 12 30 SP RT510-0001 064T38SF30363N
64 2 1/2” 4 - 5x9 8 x 10 35 SP RT510-0002 064T38SF35484N
70 2 3/4” 4 - 5 x 10 8 x 11 30 SP RT510-0003 070T38SF30484N
76 3” 3 - 4 x 11 6 x 12 35 SP RT510-0004 076T38SF35363N
Flat Face 89 3 1/2” 4 - 5 x 12 8 x 12 35 SP RT510-0005 089T38SF35484N
102 4” 4 - 6 x 12 8 x 14 35 SP RT510-0054 102T38SF35484N

64 2 1/2” 3 - 3 x 11 6 x 12 40 BA RT510-0006 064T38BD40363N

76 3” 3 - 4 x 11 6 x 11 35 SP RT510-0007 076T38SD35363N
76 3” 4 - 5 x 11 8 x 11 40 BA RT510-0008 076T38BD40484N
Drop Center 102 4” 4 - 6 x 12 8 x 14 35 SP RT510-0009 102T38SD35484N

Retrac
64 2 1/2” 3 - 3 x 11 6 x 12 30 SP RT510-0010 064T38SF30363R
64 2 1/2” 3 - 4 x 10 6 x 11 35 SP RT510-0011 064T38SF35363R
70 2 3/4” 4 - 5 x 10 8 x 11 30 SP RT510-0012 070T38SF30484R
76 3” 2 - 4 x 10 8 x 11 35 SP RT510-0013 076T38SF35282R
Flat Face
89 3 1/2” 4 - 5 x 12 8 x 12 35 SP RT510-0066 089T38SF35484R
102 4” 4 - 6 x 12 8 x 14 35 SP RT510-0014 102T38SF35484R

64 2 1/2” 3 - 4 x 10 6 x 11 35 SP RT510-0015 064T38SD35363R

76 3” 4 - 5 x 11 8 x 11 40 BA RT510-0016 076T38BD40484R
89 3 1/2” 4 - 6 x 11 8 x 12 35 SP RT510-0059 089T38SD35484R
Drop Center
102 4” 4 - 6 x 12 8 x 14 40 BA RT510-0017 102T38BD40484R

* Button bits are available with Spherical, Semi-ballistic, Ballistic or Conical.

08
Button Bits
T45 (1 3/4”) Thread

Diameter Flushinghole No. Buttons

Front No. Gauge No. Part No. Product Code

mm in Front Gauge Angle Design
x size x size
Normal
70 2 3/4” 4 - 5 x 10 8 x 11 30 SP RT510-0018 070T45SF30484N
76 3” 4 - 5 x 11 8 x 11 35 SP RT510-0019 076T45SF35484N
89 3 1/2” 3 - 6 x 10 9 x 11 35 SP RT510-0020 089T45SF35393N
89 3 1/2” 4 - 5 x 13 8 x 13 35 SP RT510-0021 089T45SF35484N
Flat Face 102 4” 4 - 5 x 13 8 x 13 35 SP RT510-0022 102T45SF35484N
115 4 1/2” 4 - 6 x 13 8 x 14 35 SP RT510-0053 115T45SF35484N

76 3” 4 - 5 x 11 8 x 11 35 BA RT510-0023 076T45BD35484N
89 3 1/2” 4 - 5 x 11 8 x 12 40 BA RT510-0024 089T45BD40484N
102 4” 3 - 9 x 11 9 x 13 40 BA RT510-0025 102T45BD40393N
Drop Center 115 4 1/2” 4 - 6 x 13 8 x 14 35 SP RT510-0026 115T45SD35484N

Retrac
70 2 3/4” 4 - 5 x 10 8 x 11 35 SP RT510-0027 070T45SF35484R
76 3” 4 - 5 x 11 8 x 12 35 SP RT510-0028 076T45SF35484R
89 3 1/2” 4 - 5 x 13 8 x 13 35 SP RT510-0029 089T45SF35484R
102 4” 2 - 6 x 12 8 x 14 35 SP RT510-0030 102T45SF35242R
Flat Face
115 4 1/2” 4 - 6 x 12 8 x 14 35 SP RT510-0031 115T45SF35484R

76 3” 4 - 5 x 11 8 x 11 35 SP RT510-0032 076T45SD35484R
89 3 1/2” 4 - 6 x 11 8 x 12 40 BA RT510-0033 089T45BD40484R
102 4” 3 - 9 x 11 9 x 13 40 BA RT510-0034 102T45BD40393R
Drop Center
115 4 1/2” 4 - 6 x 13 8 x 14 35 SP RT510-0035 115T45SD35484R

* Button bits are available with Spherical, Semi-ballistic, Ballistic or Conical.

09
Button Bits
T51 (2”) Thread

Diameter Flushinghole No. Buttons

Front No. Gauge No. Part No. Product Code

mm in Front Gauge Angle Design
x size x size
Normal
89 3 1/2” 4 - 5 x 13 8 x 13 35 SP RT510-0036 089T51SF35484N
102 4” 3 - 9 x 11 9 x 13 35 SP RT510-0037 102T51SF35393N
115 4 1/2” 4 - 7 x 13 8 x 14 35 SP RT510-0038 115T51SF35484N
127 5” 2 - 6 x 12 8 x 14 35 SP RT510-0039 127T51SF35242N
Flat Face
127 5” 2 - 7 x 13 8 x 14 35 SP RT510-0040 127T51SF35242N

89 3 1/2” 4 - 5 x 11 8 x 12 35 SP RT510-0041 089T51SD35484N

102 4” 3 - 9 x 11 9 x 13 40 BA RT510-0042 102T51BD40393N
115 4 1/2” 4 - 6 x 13 8 x 14 35 SP RT510-0043 115T51SD35484N
Drop Center

Retrac
89 3 1/2” 3 - 7 x 12 9 x 12 35 SP RT510-0044 089T51SF35393R
89 3 1/2” 4 - 5 x 13 8 x 13 35 SP RT510-0045 089T51SF35484R
102 4” 3 - 9 x 11 9 x 13 35 SP RT510-0046 102T51SF35393R
115 4 1/2” 3 - 10 x 12 9 x 14 35 SP RT510-0047 115T51SF35393R
Flat Face 127 5” 2 - 6 x 12 8 x 14 35 SP RT510-0048 127T51SF35242R
127 5” 2 - 6 x 12 8 x 14 35 BA RT510-0055 127T51BF35242R

89 3 1/2” 4 - 6 x 11 8 x 12 35 SP RT510-0049 089T51SD35484R

89 3 1/2” 4 - 6 x 11 8 x 12 40 BA RT510-0050 089T51BD40484R
102 4” 4 - 6 x 12 8 x 14 40 BA RT510-0051 102T51BD40484R
Drop Center 115 4 1/2” 3 - 10 x 12 9 x 14 40 BA RT510-0052 115T51BD40393R
127 5” 4 - 6 x 12 8 x 14 40 BA RT510-0056 127T51BD40484R

* Button bits are available with Spherical, Semi-ballistic, Ballistic or Conical.

10
Button Bits
GT60 (2 1/4”) Thread

Diameter Flushinghole No. Buttons

Front No. Gauge No. Part No. Product Code

mm in Front Gauge Angle Design
x size x size
Normal
102 4” 3 - 9 x 11 9 x 13 35 SP RT510-0062 102GT60SF35393N
115 4 1/2” 3 - 10 x 12 9 x 14 35 SP RT510-0063 115GT60SF35393N
127 5” 3 - 10 x 13 9 x 16 35 SP RT510-0064 127GT60SF35393N
Flat Face 140 5 1/2” 3 - 10 x 13 9 x 16 35 SP RT510-0065 140GT60SF35393N

102 4” 3 - 9 x 11 9 x 13 35 SP RT510-0071 102GT60SD35393N

115 4 1/2” 3 - 9 x 12 9 x 14 35 SP RT510-0072 115GT60SD35393N
127 5” 3 - 9 x 13 9 x 16 35 SP RT510-0073 127GT60SD35393N
Drop Center 140 5 1/2” 3 - 9 x 13 9 x 16 35 SP RT510-0074 140GT60SD35393N

Retrac
102 4” 3 - 9 x 11 9 x 13 35 SP RT510-0061 102GT60SF35393R
115 4 1/2” 3 - 10 x 12 9 x 14 35 SP RT510-0060 115GT60SF35393R
127 5” 3 - 10 x 13 9 x 16 35 SP RT510-0057 127GT60SF35393R
Flat Face 140 5 1/2” 3 - 10 x 13 9 x 16 35 SP RT510-0058 140GT60SF35393R

102 4” 3 - 9 x 11 9 x 13 35 SP RT510-0067 102GT60SD35393R

115 4 1/2” 3 - 9 x 12 9 x 14 35 SP RT510-0068 115GT60SD35393R
127 5” 3 - 9 x 13 9 x 16 35 SP RT510-0069 127GT60SD35393R
Drop Center 140 5 1/2” 3 - 9 x 13 9 x 16 35 SP RT510-0070 140GT60SD35393R

* Button bits are available with Spherical, Semi-ballistic, Ballistic or Conical.

11
 Memo

12
Rods
R32 (1 1/4”) SERIES .......................................................................................... 14
T38 (1 1/2”) SERIES .......................................................................................... 15
T45 (1 3/4”) SERIES .......................................................................................... 16
T51 (2”) SERIES .................................................................................................. 17
ST58 (2 1/4”) SERIES .........................................................................................18
T60/GT60 SERIES ...............................................................................................19
ST68 (2 3/4”) SERIES .........................................................................................20

13
Rods
R32 (1 1/4”) Thread
Dimensions
Length Diameter Part No. Product Code
mm ft mm in
Hex Drifting Rod / R32 - Hex - R32
3,050 10’ 32 1 1/4” RT530-0001 RHXR32R323050
L
3,660 12’ 32 1 1/4” RT530-0002 RHXR32R323660

Coupling Sleeve

Dimensions
Length Diameter Part No. Product Code
mm in mm in
R32 - R32
150 6 45 1 3/4” RT540-0001 CR32R32

14
Rods
T38 (1 1/2”) Thread
Dimensions
Length Diameter Part No. Product Code
mm ft mm in
Ex-rod / T38 - round 38 - T38
L
3,050 10’ 39 1 1/2” RT530-0003 REXT38T383050
3,660 12’ 39 1 1/2” RT530-0004 REXT38T383660

MF-rod / T38 - round 38 - T38

3,050 10’ 39 1 1/2” RT530-0005 RMFT38T383050
3,660 12’ 39 1 1/2” RT530-0006 RMFT38T383660
4,265 14’ 39 1 1/2” RT530-0007 RMFT38T384265
L

Coupling Sleeve

Dimensions
Length Diameter Part No. Product Code
mm in mm in
T38 - T38
190 7 1/2” 55 2 5/32” RT540-0002 CT38T38

15
Rods
T45 (1 3/4”) Thread
Dimensions
Length Diameter Part No. Product Code
mm ft mm in
Ex-rod / T45 - round 45 - T45
L
3,050 10’ 46 1 3/4” RT530-0008 REXT45T453050
3,660 12’ 46 1 3/4” RT530-0009 REXT45T453660
4,265 14’ 46 1 3/4” RT530-0010 REXT45T454265

MF-rod / T45 - round 45 - T45

3,050 10’ 46 1 3/4” RT530-0011 RMFT45T453050
3,660 12’ 46 1 3/4” RT530-0012 RMFT45T453660
4,265 14’ 46 1 3/4” RT530-0013 RMFT45T454265
L

Coupling Sleeve

Dimensions
Length Diameter Part No. Product Code
mm in mm in
T45 - T45
209 8 1/8” 63 1 2/1” RT540-0003 CT45T45

16
Rods
T51 (2”) Thread
Dimensions
Length Diameter Part No. Product Code
mm ft mm in
Ex-rod / T51 - round 51 - T51
L 1,830 6’ 51 2” RT530-0014 REXT51T511830
3,660 12’ 51 2” RT530-0015 REXT51T513660
4,265 14’ 51 2” RT530-0016 REXT51T514265

MF-rod / T51 - round 51 - T51

1,830 6’ 51 2” RT530-0017 RMFT51T511830
3,660 12’ 51 2” RT530-0018 RMFT51T513660
4,265 14’ 51 2” RT530-0019 RMFT51T514265
L

Coupling Sleeve

Dimensions
Length Diameter Part No. Product Code
mm in mm in
T51 - T51
230 9 3/64” 71 2 7/8” RT540-0004 CT51T51

17
Rods
ST58 (2 1/4”) Thread
Dimensions
Length Diameter Part No. Product Code
mm ft mm in
Drill tube
1,525 5’ 77 3” RT550-0001 DTMFST581525
D 1,830 6’ 77 3” RT550-0002 DTMFST581830

18
Rods
T60/GT60 Thread
Dimensions
Length Diameter Part No. Product Code
mm ft mm in
Ex-rod / T60 - round 60 - T60
L 3,660 12’ 60 2 3/8” RT530-0020 REXT60T603660
4,240 14’ 60 2 3/8” RT530-0021 REXT60T604265

MF-rod / T60 - round 60 - T60

3,660 12’ 60 2 3/8” RT530-0022 REXT60T603760
4,265 14’ 60 2 3/8” RT530-0023 REXT60T604370
6,095 20’ 60 2 3/8” RT530-0024 REXT60T606198
L

MF-rod / GT60 - round 60 - GT60

L 3,660 12’ 60 2 3/8” RT530-0025 RMFGT60GT603660
4,265 14’ 60 2 3/8” RT530-0026 RMFGT60GT604265

D
6,095 20’ 60 2 3/8” RT530-0027 RMFGT60GT606095

Coupling Sleeve

Dimensions
Length Diameter Part No. Product Code
mm in mm in
T60 - T60
315 1 3/8” 85 3 11/32” RT540-0005 CT60T60

19
Rods
ST68 (2 3/4”) Thread
Dimensions
Length Diameter Part No. Product Code
mm ft mm in
Drill tube
1,525 5 87 3 1/2” RT550-0003 DTMFST681525
D 1,830 6 87 3 1/2” RT550-0004 DTMFST681830

20
Shank Adaptors
Altas Copco ......................................................................................................... 22
Furukawa ............................................................................................................. 26
Gardner-Denver, Ingersoll-Rand and Klemm .....................................27
Montabert ........................................................................................................... 28
Sandvik ................................................................................................................. 30
Secoma and Toyo ............................................................................................. 35
Everdigm .............................................................................................................. 36

21
Shank Adaptors
Atlas copco
Drill Thread L Part No. Product Code

BBC 43, 44, 45 and 100 R32 380 - -

31.7 32
48

20.5 19
L

R32 380 - -
38.1 BBC 51, 52, 54 and 120
57.2 T38 390 - -
25.4 32
L

BBE 57 T38 537 - -

44.4 44.6
64.4

80
13.4 L

COP 125, 130 and 131 T38 380 - -

38.1 38.7
52

32
L

COP 1032 HD R32 340 - -

34 45
54
58
9 L

34 55
COP 1032 HD R38 340 - -
54

58
9 L

COP 1032 T35 550 - -

33.9 44.9
53.9
58.5
8.8 L

22
Shank Adaptors
Atlas copco
Drill Thread L Part No. Product Code

34 45
COP 1032 LE R32 550 - -
54

58
9 L

R32 500 - -
COP 1036/1038 HB
T38 500 - -
34 38
54

9 74
L

COP 1036/1038 HB T45 500 - -

34 38
54

74
9 L

R32 485 - -
COP 1038 HD/1238 R38 485 - -
T38 485 - -
34 38
54

74
9
L

R32 575 - -
COP 1038 HL
T38 575 - -
34 38
54

74
9 L

COP 1038 HL T45 575 - -

34 45
54

74
9 L

23
Shank Adaptors
Atlas copco
Drill Thread L Part No. Product Code

R32 500 - -
34 38
T38 500 - -
54 COP 1238
74 R38 485 - -
9 L
T38 485 - -

34 45 COP 1238 T45 500 - -

54
74
9 L

38
R32 575 - -
34
54 COP 1238 T35 575 - -
74
9 L T38 575 - -

34 45
T38 575 - -
54 COP 1238
74
L
T45 575 - -
9

R38 435 - -
38
COP 1432, 1532, 1440, T35 435 - -
54
84.5
1838 HD/ME T38 435 - -
9 L
R32 435 - -

38
R32 525 - -
COP 1432, 1532, 1440,
54 T35 525 - -
84.5
1838 HD/ME
9 L T38 525 - -

R38 341 - -
55
COP 1432 Female
R32 341 - -
54
84.5
9 L

24
Shank Adaptors
Atlas copco and Boart
Drill Thread L Part No. Product Code

T38 525 - -
52 COP 1550, 1838 ME/HE T45 525 - -
54

9
84.5
L T51 525 - -

T38 730 - -
COP 1550 EX, 1838 EX
59.8 T45 730 - -
54

94
9 L

T45 565 - -
COP 1840 HE, 1850
59.8 T51 565 - -
54

94
9
L

COP 2150 PG T51 770 - -

59.8
54

94
9 LL

COP 4050 EX ST68 805 - -

70

68

136
11.2 L

COP 4050 MUX ST68 835 - -

90
68

11.2 112
L

R38 495 - -
HD 125, 150, 160
66.1 45 T38 495 - -
64
15 L

25
Shank Adaptors
Furukawa
Drill Thread L Part No. Product Code

R32 330 - -
44.5 44.3 R38 350 - -
55.5 M 120 and PD 200
T38 380 - -
64
18.2 L
T38 446 - -

PD 200R T38 484 - -

44.2 44
71

69 L
21

T38 655 - -
44.3 45 HD 260, 300
T45 655 - -
64.4
79
13.6 L

T38 620 - -
35.7 44.8
HD 609 T38 690 - -
56.9
T45 620 - -
9.9 75
L

HD 612 T45 710 - -

41.7 50.8
64.9

11.75 89
L

HD 709 T38 620 - -

44.9
83

10 93
L

HD 712 T45 788 7305-7417-01 -

50.8
71.8

12.3 99.5
L

26
Shank Adaptors
Gardner-Denver
Drill Thread L Part No. Product Code

R32 330 - -
44.5 44.3
R38 350 - -
55.5 PR 123
T38 446 - -
64
18.2 L T38 380 - -

Ingersoll-Rand

R32 330 - -
44.5 44.3 URD 475, URD 550, R38 350 - -
55.5 VL 120, EVL 130,
T38 380 - -
VL 140 and F 16
64
18.2 L T38 446 - -

T38 495 - -
YH 65, YH 80
T45 500 - -

64.3

46 45
13.5 85
L

YH 65 RP, 70 RP, 75 RP, 80 RP T45 700 - -

46 45

64.3

119
13.5 L

Klemm

R55 500 1) -
4053
R55 500 2) -
56.3
64.3

154 56.5 1) LH-Rotation

13.5 L 2) RH-Rotation

27
Shank Adaptors
Montabert
Drill Thread L Part No. Product Code

HC 40 R32 447 - -
HC 40 R38 447 - -
38.1

52.7

58
8.4 L

HC 40 (female) R32 270 - -

52.6

52.6

8.4 58
L

HC 80, 90, 105 T38 440 - -

HC 80, 90, 105 T38 500 - -

38.1
52.7

97
13.4 L

HC 100 T38 537 - -

44.4 44.6

64.4

80
13.4 L

28
Shank Adaptors
Montabert
Drill Thread L Part No. Product Code

HC 120, 150 T45 490 - -

45

59.7

95
9.4 L

T45 670 RT520-0014 -

HC 80R, 120R, 150R
T51 670 RT520-0005 -
51

59.7

102
9.4 L

T51 840 - -
HC 200A
GT60 840 - -
60

73

138
11.4
L

SIG

HBM 50, 100 and 120 R32 340 - -

34 45

54

58
9 L

HBM 100 and 120 R38 340 - -

34 55

54

58
9 L

HBM 50, 100 and 120 R32 550 - -

34 55

54

58
9 L

101 R32 500 - -

34 38
54
74
9 L 29
Shank Adaptors
Sandvik
Drill Thread L Part No. Product Code

HL 300 R32 400 - -

32
58.8

10 39
L

HL 300S R28 245 - -

45
HL 300S R32 245 - -
58.8

39
10 L

HLX 3 R32 324 - -

44.85

58.75

53
7.9 L

44.85 HLX 3 F R32 205 - -

58.75

7.9 53
L

L 400, 410, 500, 510, 550 R32 380 - -

31.7 32

48

20.5 20
L

HLR 438L, 438T R32 380 - -

38 38
HLR 438L, 438T T38 400 - -
57

25.7 37
L

HLR R32 450 - -

38 38
438LS,
57 438TS, R38 450 - -
HL 538, T38 455 - -
25.7 37
L 538L,
L550S T38 545 - -

30
Shank Adaptors
Sandvik
Drill Thread L Part No. Product Code

R32 550 - -
38
58.8 HL 500-38 / 510-38 T35 550 - -
49
10 L T38 550 - -

R32 550 - -
T35 550 - -
58.8 HL 500-45 / 510-45
49 45 T38 550 - -
10 L
T45 550 - -

R32 550 - -
38
T35 550 - -
58.8 HL 500-45 / 510-45
49
L
T38 550 - -
10
T45 550 - -

45 HL 500 F / 510 F R32 350 - -

58.8
58
10 L

45
T35 550 - -
HL 550 SUPER /
58.8 R38 500 - -
49
560 SUPER / 510 S-45
10 L T38 500 - -

R32 500 - -
45
T35 500 - -
58.7
49 T38 500 - -
7.9 L
R38 500 - -
HLX 5 / HLX 5T
R32 575 - -
T35 575 - -
T38 575 - -
T45 575 - -

R32 575 - -
HLX 5 PE-45
T38 575 - -
45
58.7

9.9 126
L
31
Shank Adaptors
Sandvik
Drill Thread L Part No. Product Code

R32 600 - -
39.8 45 T38 600 - -
HL 600-45 /
60 T45 600 - -
600 S-45
75 T38 525 - -
10 L
T45 525 - -

T45 650 - -
HL 600-52
T51 600 - -
39.8
60

75
10
L

T38 600 - -
HL 645
T45 600 - -
43.8

59

68
L

HL 650-45 / 700-45 / T38 600 - -

700T-45 / 710-45 / 800T-45 T45 600 - -
45
69

95
12.9 L

HL 650-52, 700-52 / PE-52 / T38 600 - -

S-52, 710-52 / S-52 / PE-52 / T45 600 - -
SPE-52, 800T-52 / PE-52 T51 600 - -
52

69

12.9 95
L

HL 850S T45 670 - -

52

69

80
12.9 L

32
Shank Adaptors
Sandvik
Drill Thread L Part No. Product Code

T45 670 - -
52
HL 1000-52 / T51 670 - -
79
1000 S-52 T45 590 - -

14
79
L
T51 590 - -

T51 670 - -
HL 1000-52 / 1000 S-52
GT60 670 - -
60

79

75
14 L

HL 1000-80, Shoulder drive GT60 670 - -

79

75 80
14 L

ST58 635 - -
HL 1000 S-80 Tube drilling
ST68 640 - -

79

75 80
14 L

HL 1000 PE-52 T51 840 * -

52

79

* suited only early drills with the long type of Power Extractor
136 with 52 mm bearing diameter
14 L

HL 1000 PE-65 / HL 1500 T51 760 - -

PE-65 / HL 1560 T-65 GT60 760 - -
65

79

14 111
L

33
Shank Adaptors
Sandvik
Drill Thread L Part No. Product Code

HL 1500-52 / 1500 T-52 T51 710 - -

52

79

111.5
14
L

T51 760 - -
HL 1500-60 / 1500 T-60
GT60 760 - -
60

79

111.5
14 L

HL 1500 T-80, Shoulder drive GT60 760 - -

80

79

14 111.5
L

ST58 635 - -
HL 1500 S-80 Tube drilling
ST68 635 - -
80

79

111.5
14 L

ST58 635 - -
HL 1500 SPE-90 Tube drilling
ST68 635 - -
90

79

14 111
L

34
Shank Adaptors
Secoma
Drill Thread L Part No. Product Code
Secoma
Hydrastar 200 R32 351 - -
34 45

54

9 90
L

Secoma
R32 485 - -
Hydrastar 200, 300 and X2 R38 485 - -
T38 351 - -
34 38
54

9 74
L

Secoma
R32 500 - -
Hydrastar 350 R38 485 - -
T38 500 - -
34 45

54

90
9 L

Toyo
Toyo
R32 330 - -
PR 220 R38 350 - -
T38 446 - -
44.5 44.3

55.5

90
18.2 L

Toyo
TH 501 T38 565 - -
44.5 44.3

55.5

90
18.2 L

35
Shank Adaptors
Everdigm
Drill Thread L Part No. Product Code

T38 620 RT520-0010 -

ED 100
T45 620 RT520-0004 -

66
55.8

72

16 L

T38 620 RT520-0011 -

ED 150 T45 620 RT520-0012 -
T51 620 RT520-0013 -
45(T38, T45)
53(T51)

63

98.5
10 L

36
Memo

37
 Memo

38
Memo

39
MINING AND CONSTRUCTION DRILLING PRODUCTS

TOP HAMMER CRAWLER DRILL CORE DRILL RIG

DOWN THE HOLE OVERBURDEN SYSTEM

Vol.04 RTTHE1307-11 26.Jul.2013

Head Office & Factory

Distributed by 332-3, Janggwan-Ri, Jincheon-Eub, Chungcheongbuk-Do, Korea
Tel_+82-43-530-3300 Fax_+82-43-530-3429

Sales & Marketing Office

Room #1203, Woolim Lion’s Valley 2, 680, Gasan-Dong, Geumcheon-Gu, Seoul, Korea
Tel_+82-2-801-0800 Fax_+82-2-801-0899
EVERDIGM Corp. Printed in Korea

E-mail : rocktool@everdigm.com
