Title
Getting All Routing Layers in IC Compiler II

Description
Question:

In the IC Compiler tool, I used the following command to get all the routing layers:

icc_shell> get_layers -filter "is_routing_layer == true && layer_type != via"

The IC Compiler II tool does not support the is_routing_layer attribute. How can I get all the routing layers in the IC Compiler II tool?

Answer:

In the IC Compiler II tool, the routing layers have a layer_type attribute that differentiates between the routing layer types. This attribute has the following values:

interconnect, which is used for metal routing layers, including RDL routing layers
via_cut, which is used for via layers
local_interconnect, which is used for poly layers
local_via_cut, which is used for poly via layers

To use the layer_type attribute to get all the routing layers in the IC Compiler II tool, use the following command:

icc2_shell> get_layers -filter "layer_type==interconnect"
