Aspen RMSV14 Release Notes
Aspen RMSV14 Release Notes
Aspen RMSV14 Release Notes
Aspen RMS™, Aspen Mette™, Aspen Tempest™, and the aspen leaf are trademarks or registered trademarks of
Aspen Technology, Inc., Bedford, MA or affiliated companies.
Big Loop™, METTE™, Model Driven Interpretation™, RMS™, Snap-to-Seismic™, and Tempest™ are registered
trademarks of Roxar Software Solutions AS.
All other brand and product names are trademarks or registered trademarks of their respective companies.
This document is intended as a guide to using AspenTech's software. This documentation contains AspenTech
proprietary and confidential information and may not be disclosed, used, or copied without the prior consent of
AspenTech or as set forth in the applicable license agreement. Users are solely responsible for the proper use of
the software and the application of the results obtained.
Although AspenTech has tested the software and reviewed the documentation, the sole warranty for the software
may be found in the applicable license agreement between AspenTech and the user. ASPENTECH MAKES NO
WARRANTY OR REPRESENTATION, EITHER EXPRESSED OR IMPLIED, WITH RESPECT TO THIS DOCUMENTATION,
ITS QUALITY, PERFORMANCE, MERCHANTABILITY, OR FITNESS FOR A PARTICULAR PURPOSE.
Contents
1 What’s New in RMS?
Key Benefits
2 Wells and Logs
Introduction
Enhancements
QA Wells
RMS-53780 Snap Targets
RMS-66771 Correlation View Toolbar
Fixes and improvements
RMS-58483 Well Intersections
RMS-63440 Wells in Data Tree
RMS-64358 Well Depth Filter
RMS-61169 Import Trajectory
3 3D Grids and Property Modeling
Introduction
New features
Enhancements
Petrophysical Modeling
RMS-65406 Volumetrics Report File
RMS-64965 Create QC Charts
Fixes and improvements
RMS-66037 Channels NGOM Extra facies
RMS-63743 Channels NGOM Facies probabilities
RMS-66309 Volumetrics
RMS-66288 Facies Composite
RMS-66429 Petrophysical Modeling
RMS-61854 Blocked Well Names
RMS-66287 Workflow Input Objects
RMS-66567 Geometric modeling
RMS-66589 Blocked Wells Discrete Labels
RMS-60755, RMS-66576 Blocked Wells Statistics
RMS-66777 Copy Grid with Active Filter
RMS-66794 Grid Visual Settings
RMS-66899 Parameter Utilities jobs
RMS-66427 Petrophysical modeling
RMS-67523 Facies Indicators
RMS-68088 Blocked wells
RMS-66940 Volumetrics
RMS-68128 Volumetrics
ii
4 Flow Modeling
Introduction
Enhancements
Perforations in Local Grids
Defects
RMS-67736 Create Flow Model Events
5 Roxar API
Introduction
Enhancements
Structural Models API
Uncertainty Tables
2D Seismic
Collections
Point Attributes
Time-Depth Tables
Extending the old Jobs API
Volumetrics
Petrophysical modeling
Horizon modeling
Fixes and improvements
RMS-60031 RMS-60032 RMS-65430 rms.onProjectChanged in Plugin
RMS-65625 Blocked Wells
RMS-66713 Discrete Log Curves
RMS-66466 Hello Progress Bar Plugin
RMS-67804 Uncertainty Report Tabl
6 Import/Export Features
Introduction
RMS-RESQML/Geolog connector version 1.7
Enhancements
RMS-65664 Export Grid Model Data
Fixes and Improvements
RMS-62906 Import Production Data
RMS-64381 Import Events
RMS-65885 Import Production Data
RMS-65968 RESCUE Import
RMS-66380 Create Events from Production Data
RMS-66446 Import Grid Model Data
RMS-66465 Import Grid Model Data
RMS-66793 Export Grid Model Data
RMS-66738 Export Grid Model Data
7 Regions
Introduction
iii
Modify Table
8 Mapping and Structural Modeling
Introduction
Enhancements
RMS-65769 Horizon Modeling
RMS-65449 Fault Statistics
RMS-64537 Extract Residuals
RMS-66000 Adjust to Points
RMS-61426 Polygon Operations
RMS-66324 Polygon Operations
RMS-62498, RMS-63448 Filter in the Point Table
RMS-54013 Point Table
Fixes and improvements
RMS-65800 Horizon Uncertainty Modeling
RMS-65584 Horizon Uncertainty Modeling
RMS-66736 Horizon Uncertainty Modeling
RMS-66737 Horizon Loading
RMS-54423 Model Box
RMS-55487 Data Filtering
RMS-63452 Remove Data Types
RMS-66467 Local B-Spline Algorithm
RMS-66529 Global B-Spline Algorithm
RMS-66530 Converging Average Algorithm
RMS-67107 Horizon Uncertainty Modeling
RMS-67103 2D Volumetrics
9 Other
Introduction
Enhancements
Fixes and improvements
RMS-66234 Information
RMS-62873 Information
RMS-66884 IPL
RMS-65944 Workflow Log
RMS-62636 RMS Licensing
RMS-66485 RMS License Availability
RMS-67528 IPL Script
RMS-67143 RMS Database Connection:
10 Software and Support
Introduction
Known Issues
Resizing and moving TkInter windows
Unicode in username or installation path
iv
Key Benefits
In Petrophysical Modeling:
Avoid introducing a bias from horizontal well data when defining trends by
choosing which wells to use as input to the transformation sequence.
Added flexibility when defining the transformation sequence by allowing
the Normal Score and Mean transformation to be automated per
transformation.
Quickly calculate an estimate of the output distribution based on the trans-
formation sequence for the properties being modeled, without having to
run the entire model.
When defining the structural model, skip time-consuming visual computations
for faster model iterations and QC.
Up to 50% reduction in run time for the Horizon Uncertainty Modeling job by im-
proved handling of well data.
Take advantage of the Region Attribute Table features in uncertainty and Big
Loop workflows.
Specify perforations in local grids for enhanced accuracy around wells.
Improved interoperability with SKUA™: Import repeat section grid/K-expanded
flow simulation grids from SKUA™ using RESQML.
Extended Roxar API support, for access to RMS project data and jobs using the
Python language. Roxar API can also be used to create customized plug-ins. RMS
V14 comes with updated Job API to support changes in the UI, multiple collection
as input to jobs, support for Time/Depth Tables, read access to 2D Seismic, and
Uncertainty Volume Tables.
1
Enhancements
QA Wells
The following improvements have been added to the QA
Wells job dialog:
A Filter on Wells option has been added in the QA
Wells dialog box to be able to run the job on a selec-
tion, or collection, of wells.
Two additional Tests have been added, Wells without
any trajectories and Trajectory without a default log
run.
The Output collections will only be created for the se-
lected Tests.
New features
Enhancements
6
Petrophysical Modeling
A series of improvements and additions have been made
in the Distributions tab of the Petrophysical Modeling job
increasing its usability:
A new option Set Blocked well filter has been added to
the tab. Clicking the button opens a Well selection panel.
You can use this panel to filter and select a subset of wells
from the Blocked wells object. This selection will be used
while setting up the transformation sequence and esti-
mating residuals.
RMS-66309 Volumetrics
Report file exported from the Volumetrics job displayed in-
correct zone names if the first character in the zone name
was a number.
RMS-66940 Volumetrics
Uncertainty volume table was not updated properly when
running Volumetrics job in batch.
RMS-68128 Volumetrics
When attempting to run a workflow where the Grid object
was empty, the Volumetrics job would trigger an uneces-
sary error message halting the workflow.
11
4 Flow Modeling
Introduction
This chapter provides information about the enhancements with respect to Flow
Modeling in RMS V14.
Enhancements
Perforations in Local Grids
The event model has been updated to support perfora-
tions in local grids for both non-segmented and seg-
mented wells. There is no visible change to the Create Flow
Model Events job. By default, if local grid refinements are
present in the grid they will be used when creating flow
model events.
Several events have been updated with new attributes.
CPERF and WSEGCELL has a new attribute providing the
name of the local grid the cell belongs to. CPERFCNTRL
and WSEGMOD now has an attribute with the option on
whether to use the local grid cells when creating flow
model events.
On export of events, there is support for the ECLIPSE sim-
ulation model format. If events for local grids are present,
then the relevant ECLIPSE keywords for local grids will be
exported. This includes WELSPECL, COMPDATL,
COMPSEGL and COMPLUMPL.
Visual display of local cell events in RMS is not supported.
Defects
12
5 Roxar API
Introduction
This chapter provides an overview of Roxar API version 1.7.1, that is delivered with
the RMS V14 release.
For more information about the new methods and attributes, refer to the Roxar API
User Guide.
Enhancements
Structural Models API
StructuralGeometry that was classified as an
Experimental class is now Commercial for this release.
Uncertainty Tables
Access to the Uncertainty Tables is now possible. Users
can read and modify the Volumetrics sub-table associated
with Uncertainty Table.
This feature is considered to solve the following issue:
RMS-52262.
2D Seismic
RoxarAPI has extended the ability to access seismic data
by providing read access to two-dimensional seismic lines.
It is now possible to get the seismic trace positions, the
line attributes, and the sample values.
Collections
With Roxar API 1.7, it is now possible to use multiple col-
lections as input to jobs. To support this and to distinguish
collection from other objects, additional keywords provid-
ing extra information are required in the path to identify a
collection.
14
Point Attributes
Deleting a Point Attribute is now possible through Roxar
API.
Time-Depth Tables
The Roxar API has added access to the Time-Depth Tables.
It is now possible to create, read, write, clear, and modify
properties of the Time-Depth tables.
This feature is considered to solve the following issues:
RMS-53560, RMS-55589, RMS-55402, and RMS-56385.
Petrophysical modeling
Horizon modeling
6 Import/Export Features
Introduction
This chapter provides an overview of enhancements to the existing Import and Export
features.
Enhancements
RMS-65664 Export Grid Model Data
Exporting grid parameters has been made more flexible
for exporting keyword information using CMG corner
point format. It is now possible for you to add array quali-
fiers to the exported keyword. Also, a parameter can be
exported without keyword information by leaving the ex-
ported keyword blank in the export jobs. This improve-
ment affects both Export Grid Model Data and Export
Parameter jobs.
7 Regions
Introduction
This chapter provides information about enhancements and issues that are ad-
dressed pertaining to Regions in RMS V14.
Enhancements
Modify Table
It is now possible to include the Region Attribute Table in
Uncertainty and Big Loop Variables workflows using the
Modify Table job.Existing attributes in the modified table
will be updated when running the job. It is recommended
to make a copy of the original table to avoid losing previ-
ous work. To include it in a workflow: 1. Add the Modify
Table job into a workflow. 2. Set up the value uncertainties
in the Uncertainty/Sensitivity Setup job of the workflow, or
3. Select the workflow in the Big Loop Variables job panel
and define the attribute value replacement. The Modify
Table dialog box is shown as below:
Enhancements
RMS-65769 Horizon Modeling
The performance of the Horizon Modeling job can now be
improved by clearing the Create polygon model for zone vi-
sualization checkbox. This enhances the job performance
when working with a huge project.
The created horizon model works the same as the normal
horizon models, except that, it cannot be used for running
the Create Region Partition job, and other Regions related
tasks. Also, the zones of the created horizon model can be
visualized only in the Intersection views. The output struc-
ture model of the Horizon Uncertainty Modeling job will in-
herit this zone visual mechanism if taking such horizon
model as the input.
RMS-67103 2D Volumetrics
The job 2D Volumetrics defined with only 1 interval and Use
volume boundaries in pre-RMS 13 projects, would fail to
run through in RMS 13.
24
9 Other
Introduction
This chapter provides an overview of enhancements done in other areas, apart from
the ones listed in earlier chapters.
Enhancements
Fixes and improvements
RMS-66234 Information
In the Information dialog box, the values of Date and Time
failed to be updated for some RMS objects.
RMS-62873 Information
The updated information was not displayed in the
Information dialog box for the parameters generated by
IPL.
RMS-66884 IPL
The points inside closed polygons weren’t set to UNDEF
successfully by the IPL command to filter the points out.
Known Issues
Resizing and moving TkInter windows
In some cases, moving and resizing windows created by
the TkInter graphical user interface package from the RMS
Python job can cause RMS to exit uncleanly. We recom-
mend using RMS Plugins for custom graphics.
OpenSpirit
When importing well logs, if more than 20% of the
total logs in the project are selected, then the import
can take a long time if any log in the entire project is
corrupted. This is due to embedded OpenSpirit per-
formance optimizations dealing with log retrievals
where the optimizations do not account for bad data
in the project.
As a workaround to this issue, create a
$HOME/OpenSpirit/osp.config file in the UNIX HOME
directory for the UNIX account used to start the
OpenWorks R5000 data server. In that file, add the
line: env.OSP_FULL_ITERATION_THRESHOLD=1000.
where: 1000 can be changed to an appropriate num-
ber for your typical database import workflow.
Seismic inversion
To perform inversion in RMS, it is a prerequisite that cer-
tain unit settings are specified. See the relevant RMS Help
for more details.
Support
Introduction
Aspen Technology operates a system of regional help
desks to provide a continuous e-mail and telephone sup-
port service during your local office hours. They are
equipped to handle most queries themselves, but they
also have access to specialist help and relevant program-
mers when the need arises.
Contact information
To locate contact information in RMS:
1. Select Contact AspenTech from the RMS Help menu.
A map shows the contact information for various
support offices around the world. This list is also pro-
vided in the support area of the AspenTech web site.
2. Access the client login area of the web site for useful
and current information, such as information about
the latest software releases.
29
