    Institute of Technology, Nirma University

    Electronic Devices & Circuits (2EC101)


    SEM-3
    Project Work Report

    Simple traffic light circuit

    VYOM PANDEY
    KUNAL YADAV
    ROLL NO.22BEC148
    22BEC149
    Title- Traffic signal system

    Introduction- The traffic signal is a system where


    different colored lights are used to indicate the vehicle
    drivers to control the flow of traffic and avoid cluttering
    at any point on roads. This project demonstrates the
    basic working of the traffic signal. The 555 timer IC is
    used to control the duration of the display of a particular

    Application- this type of circuit can be seen in devices


    that give a continuous or oscillating output which is
    time dependent such as alarm clocks, traffic signal, etc.
    Schematic/Block diagram-
    Components-
    1. 555 timer IC’s (x2)
    2. 100 micro F capacitors (x2)
    3. 100k ohm resistor
    4. 47k ohm resistor
    5. 390 ohms resistor (x2)
    6. 330 ohms resistor
    7. Breadboard
    8. Connecting wires
    9. LED lights 5mm (x3)

    Working principle-

     The 555 timer IC works in monostable and astable


    modes in this circuit.
     In Monostable mode, the 555 timer generates a
    single output pulse when it is triggered. It is used
    for controlling the length of a light or alarm
    staying on after the button is pressed.
     In Astable mode, the 555 timer generates a
    continuous square wave output. It is used in
    devices that require a regular oscillating signal.
     In this circuit, the timing of each LED is controlled
    by the capacitance and resistance value. The
    continuous output is given with the help of
    monostable mode. The repetition takes place
    because of the astable mode.
    Bill of materials-

    1. 555 timer IC’s (x2) = 50 Rs


    2. 100 micro F capacitors (x2) = 10 Rs
    3. 100k ohm resistor = 5 Rs
    4. 47k ohm resistor = 5 Rs
    5. 390 ohms resistor (x2) = 10 Rs
    6. 330 ohms resistor = 5Rs
    7. Breadboard = 20 Rs
    8. Connecting wires = 10 Rs
    9. LED lights 5mm (x3) = 90 Rs
    Total price = 200RS
    Conclusion- We learned about the of 555 IC and their
    applications across various fields and devices that are
    used in our day to day life.
