CARRIER

111T16629-1
TABLE OF CONTENTS Sandvik DX700 110201

11. CARRIER
* 550 999 55 NSS TRACK ASSEMBLIES, DX..................................................................................................................................... 1
** 550 999 56 NSS CRAWLER BEAMS............................................................................................................................................. 4
* 550 998 72 FINAL DRIVES, TRASMITAL, DX.................................................................................................................................. 5
** 551 518 52 FINAL DRIVE ASSEMBLY, TRASMITAL, DX / DC..................................................................................................... 6
*** 550 946 72 FINAL DRIVE, DRIVE GEAR 706C3K..................................................................................................................... 8
**** 551 900 13 HYDRAULIC MOTOR, MAG 50 VP-12................................................................................................................ 10
** 550 996 32 HOSE SET, FINAL DRIVES, TRASMITAL, DX........................................................................................................... 12
* 551 531 16 NSS IDLER WHEELS, ROTER....................................................................................................................................... 13
** 551 526 93 IDLER WHEEL, TRACKS............................................................................................................................................ 14
* 551 531 20 NSS TRACK ROLLER SET............................................................................................................................................ 15
** 551 526 91 TRACK ROLLER.......................................................................................................................................................... 16
* 551 531 18 TRACKS, SINGLE GROUSER........................................................................................................................................ 17
** 551 526 89 TRACK CHAIN, SINGLE GROUSER.......................................................................................................................... 18
* 551 561 87 TOP FRAME ASSEMBLY............................................................................................................................................... 20
** 551 579 92 ASSEMBLY, TOP FRAME BUSHING......................................................................................................................... 25
** 551 670 74 ASSEMBLY, TOP FRAME BUSHING......................................................................................................................... 26
*** 551 709 20 TOP FRAME ASSEMBLY........................................................................................................................................ 27
** 551 554 15 FUEL TANK ASSEMBLY............................................................................................................................................. 30
*** 551 563 57 COVER..................................................................................................................................................................... 32
** 551 642 99 OIL COOLER ASSEMBLY DX..................................................................................................................................... 34
*** 551 785 19 COOLER ASSEMBLY.............................................................................................................................................. 36
**** 885 472 79 OIL COOLER....................................................................................................................................................... 39
**** 551 941 26 HOSE SET, OIL COOLER................................................................................................................................... 42
** 325 546 78 CYLINDER, D140 D80 LMIN1260 S850...................................................................................................................... 44
** 551 759 23 OIL RECEIVER ASSEMBLY, DX500-800................................................................................................................... 46
*** 551 561 38 HYDRAULIC RECEIVER ASSEMBLY..................................................................................................................... 50
**** 867 271 59 RETURN FILTER................................................................................................................................................. 54
*** 550 550 15 SUPPORTING BLOCK ASSEMBLY........................................................................................................................ 55
** 551 807 87 ADAPTER ASSEMBLY, TANK COLLECTOR............................................................................................................. 56
* 551 643 53 LOWER FRAME ASSEMBLY, 180DEG --- DX & DX***R.............................................................................................. 58
** 551 803 60 LOWER FRAME ASSEMBLY...................................................................................................................................... 62
** 550 129 75 BUSHINGS................................................................................................................................................................... 63
** 258 825 02 CYLINDER, D140 D70 LMIN655 S93......................................................................................................................... 66
** 550 143 29 CYLINDER, D140 D70 LMIN646 S280........................................................................................................................ 68
*** 550 387 17 VALVE ASSEMBLY................................................................................................................................................. 69
** 551 847 19 HOSE SET................................................................................................................................................................... 70
* 550 011 07 SHANK LUBRICATION ASSEMBLY.............................................................................................................................. 71
* 551 613 26 COVERS ASSEMBLY..................................................................................................................................................... 74
** 551 619 86 DOOR........................................................................................................................................................................... 76
* 550 571 25 SIGN SET........................................................................................................................................................................ 78
* 550 187 04 SIGN AND DECAL ASSEMBLY..................................................................................................................................... 80
* 550 909 43 SIGN AND DECAL ASSEMBLY..................................................................................................................................... 84
* 551 905 44 VALVE ATTACHMENTS................................................................................................................................................. 88
** 550 203 21 COLLECTING PIECE................................................................................................................................................... 90
* 550 801 78 ASSEMBLY, EXTRA SWING.......................................................................................................................................... 91

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 999 55 aA NSS
1 (91) TRACK ASSEMBLIES / DX 110201

Ref. Part no. Description EN Standard designation Qty

e
1 550 999 56 NSS CRAWLER BEAMS SECTION 11 PAGE 4 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 999 56 aA NSS
3 (91) CRAWLER BEAMS 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 999 56 aA NSS
110201 CRAWLER BEAMS 4 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 550 944 37 CRAWLER BEAM RIGHT 1
2 550 949 90 CRAWLER BEAM LEFT 1
9 237 707 51 GUARD 1
10 237 707 52 GUARD 1
11 800 460 49 HEXAGON HEAD SCREW M10X25-8.8 SFS-ISO 4017 10
. . . . .
12 851 282 09 DOUBLE LOCK WASHER M10 10
21 885 746 39 PLAIN BEARING 180/185*60 8
27 572 102 40 GREASE NIPPLE AR 1/8 2
28 804 318 29 STRAIGHT THREAD ADAPTER 7/16-20 JIC 4
29 592 012 47 HOSE ASSY 2SC04MS AB-540-JIC 1
. . . . .
39 592 012 47 HOSE ASSY 2SC04MS AB-540-JIC 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 998 72 aA
5 (91) FINAL DRIVES / TRASMITAL, DX 110201

Ref. Part no. Description EN Standard designation Qty

e
1 551 518 52 FINAL DRIVE ASSEMBLY SECTION 11 PAGE 6 2
800 550 996 32 HOSE SET SECTION 11 PAGE 12 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 518 52
110201 FINAL DRIVE ASSEMBLY / TRASMITAL, DX / DC 6 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 550 946 72 FINAL DRIVE SECTION 11 PAGE 8 1
2 550 947 49 FLANGE 1
3 550 951 28 DRIVE WHEEL 1
4 800 538 69 HEXAGON HEAD SCREW M16X45 12
5 442 219 80 HEXAGON HEAD SCREW M16X50 36
. . . . .
6 850 687 49 DOUBLE LOCK WASHER M16 48
7 550 987 85 STRAIGHT THREAD ADAPTER R 1/2 - JIC 1,1/16-12 (JIS) 2
8 550 987 86 STRAIGHT THREAD ADAPTER R 3/8 - JIC 3/4-16 (JIS) 1
9 816 701 89 STRAIGHT THREAD ADAPTER 40X-S10-1/4" (9/16-18JIC) 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 946 72 c
7 (91) FINAL DRIVE / DRIVE GEAR 706C3K 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 946 72 c
110201 FINAL DRIVE / DRIVE GEAR 706C3K 8 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 900 40 SCREW M10x25 - 12.9 10
2 551 900 32 PLUG Disengagement plug 1
3 551 900 41 WASHER 76,08x90,3x3,38 1
4 551 900 59 COVER ASSEMBLY Incl. parts: 2,3,5 1
5 551 901 13 PLUG M18x1,5 2
. . . . .
6 502871 O-RING O-Ring 1
7 551 900 84 SUN GEAR - 1
8 551 900 86 REDUCTION GEAR Reduction assembly 1
9 551 900 87 SUN GEAR - 1
10 551 900 89 REDUCTION GEAR Reduction assembly 1
. . . . .
11 551 900 90 CIRCLIP - 4
12 551 900 91 PLANET GEAR ASSEMBLY - 4
13 551 901 05 NUT M180x1,5 1
14 504099 HOUSING 1
15 551 901 06 CIRCLIP - 1
. . . . .
16 502872 SEAL to BPI Nr.:511370 1
17 551 901 07 CENTERING PIECE - 1
18 551 900 13 HYDRAULIC MOTOR SECTION 11 PAGE 10 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 900 13
9 (91) HYDRAULIC MOTOR / MAG 50 VP-12 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 900 13
110201 HYDRAULIC MOTOR / MAG 50 VP-12 10 (91)

Ref. Part no. Description EN Standard designation Qty

e
37 551 902 12 SCREW M12x25-12.9 8
100 551 902 13 HOUSING ASSEMBLY Incl. parts: 29,30,110,120,130,140 1
110 551 902 14 VALVE ASSEMBLY Incl. parts: 39,40,41,42,111 1
111 551 902 15 PISTON ASSEMBLY Incl. part: 38 1
120 551 902 16 ORIFICE Orifice assy - Incl. parts: 27,28,43 1
. . . . .
130 551 902 18 SPOOL ASSEMBLY Incl. parts: 44,45,46,47,48 1
140 551 902 19 PLUG Plug assy - Incl. parts: 26,35,36 1
200 551 902 29 CYLINDER BLOCK Incl. parts: 8,9,10,11,12,13,14,15,16,25 1
300 551 902 40 GUIDE PLATE Incl. parts: 3,5,6,7 1
400 551 902 41 SHAFT Motor shaft 1
. . . . .
500 551 902 42 SHAFT SEAL - 1
600 551 902 43 BEARING ASSEMBLY Incl. parts: 4,32 1
700 551 902 45 BRAKE ASSEMBLY Incl. parts: 17,18,20,22,23,24,31 1
800 504107 SEAL KIT 2,19,21,33,36,38,41,46,49,50,52,53,60-63,67,69 1
900 551 902 47 RELIEF VALVE ASSEMBLY Incl. parts: 51-66 1
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 996 32 a
11 (91) HOSE SET / FINAL DRIVES, TRASMITAL, DX 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 996 32 a
110201 HOSE SET / FINAL DRIVES, TRASMITAL, DX 12 (91)

Ref. Part no. Description EN Standard designation Qty

e
150 592 008 19 HYDRAULIC HOSE ASSEMBLY 2SC08MS AA-2000-JIC 1
245 592 012 49 HYDRAULIC HOSE ASSEMBLY 2SC12MS AA-950-JIC 1
246 592 012 45 HYDRAULIC HOSE ASSEMBLY 2SC12MS AA-1000-JIC 1
247 592 012 45 HYDRAULIC HOSE ASSEMBLY 2SC12MS AA-1000-JIC 1
248 592 012 45 HYDRAULIC HOSE ASSEMBLY 2SC12MS AA-1000-JIC 1
. . . . .
249 592 009 59 HYDRAULIC HOSE ASSEMBLY 2SC06MS AA-1950-JIC 1
250 592 012 51 HYDRAULIC HOSE ASSEMBLY 2SC08MS AA-1650-JIC 1
349 592 006 15 HYDRAULIC HOSE ASSEMBLY 2SC06MS AA-2200-JIC 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 531 16 A NSS
13 (91) Idler Wheels / ROTER 110201

Ref. Part no. Description EN Standard designation Qty

e
2 551 526 93 IDLER WHEEL SECTION 11 PAGE 14 2

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 526 93 aA
110201 Idler wheel / TRACKS 14 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 531 23 CYLINDER 1
2 551 533 29 SPRING 1
3 551 537 62 WHEEL 1
4 551 537 63 SHAFT 1
5 551 537 64 SLIDE 2
. . . . .
6 551 965 05 BUSHING 2
7 551 963 35 O-RING 2
8 551 963 36 CLEVIS 1
9 551 537 65 SEAL KIT 2
10 551 963 38 LOCKING PIN 2
. . . . .
20 551 533 31 WHEEL ASSEMBLY INCL. PARTS 3-10 1
*21 866 631 19 GREASE NIPPLE 1
*22 866 632 49 GASKET 1
*23 800 635 09 CONNECTOR PART 1
*24 800 634 89 HOSE 1
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 531 20 A NSS
15 (91) Track Roller Set 110201

Ref. Part no. Description EN Standard designation Qty

e
1 551 526 91 TRACK ROLLER SECTION 11 PAGE 16 16
2 133 355 98 FLAT BAR 32
3 850 687 49 DOUBLE LOCK WASHER M16 64
4 442 927 20 HEXAGON HEAD SCREW M16X1,5X80 m8.8 SFS 2065 64

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 526 91 aA
110201 TRACK ROLLER 16 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 965 05 BUSHING 2
2 551 963 35 O-RING 2
3 551 537 88 SEAL KIT 2
4 551 965 06 LOCKING PIN 2
5 551 965 07 PLUG 1
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 531 18 aA
17 (91) TRACKS / SINGLE GROUSER 110201

Ref. Part no. Description EN Standard designation Qty

e
8 551 526 89 TRACK CHAIN SECTION 11 PAGE 18 2

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 526 89 b
110201 Track chain / SINGLE GROUSER 18 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 847 24 TRACK LINK 43
2 551 847 25 TRACK LINK 43
3 551 537 36 PIN 42
4 551 537 38 BUSHING 42
5 551 537 39 BUSHING MASTER 1
. . . . .
6 551 537 37 PIN MASTER 1
7 551 537 34 SPACER 2
8 551 537 41 HEXAGON HEAD BOLT 172
9 551 537 42 HEXAGON NUT 172
10 551 537 40 GROUND PLATE SINGLE GROUSER 43
. . . . .
11 551 537 49 SEAL WASHER 2
20 551 537 35 TRACK CHAIN WITHOUT GROUND PLATES, INCL. PARTS 1
1-7, 11

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 561 87 iD
19 (91) TOP FRAME ASSEMBLY 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 561 87 iD
110201 TOP FRAME ASSEMBLY 20 (91)

Ref. Part no. Description EN Standard designation Qty

e
3 551 554 15 FUEL TANK ASSEMBLY SECTION 11 PAGE 30 1
9 550 130 61 DOUBLE LOCK WASHER M16 26
11 551 642 99 OIL COOLER ASSEMBLY DX SECTION 11 PAGE 34 1
15 325 546 78 CYLINDER SECTION 11 PAGE 44 1
16 551 594 52 COVER PLATE Oil cooler 1
. . . . .
24 802 198 29 HEXAGON HEAD BOLT M16X70 7
25 800 460 49 HEXAGON HEAD SCREW M10X25-8.8 SFS-ISO 4017 4
26 550 130 58 DOUBLE LOCK WASHER M10 4
55 550 310 98 POP-RIVET 2,49X5 16
88 883 301 39 WASHER DIN 6340 17/45x6 9
. . . . .
90 811 259 69 LOCK NUT M16 m8 B-lock 7
95 550 550 52 SIGN TYPE, CE-model 1
*1 551 579 92 ASSEMBLY SECTION 11 PAGE 25 1
*1 551 670 74 ASSEMBLY SECTION 11 PAGE 26 1
*21 551 759 23 OIL RECEIVER ASSEMBLY SECTION 11 PAGE 46 1
. . . . .
*98 551 924 85 SHIM 1 mm, As needed 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 561 87 iD
21 (91) TOP FRAME ASSEMBLY 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 561 87 iD
110201 TOP FRAME ASSEMBLY 22 (91)

Ref. Part no. Description EN Standard designation Qty

e
4 551 551 26 TOOL RACK 1
5 551 551 24 PLATE 1
6 551 594 76 PLATE 1
7 808 997 79 HEXAGON HEAD SCREW M12X50 m8.8 SFS 2064 2
8 800 821 49 HEXAGON NUT M12 m8 SFS-ISO 4032 2
. . . . .
9 550 130 61 DOUBLE LOCK WASHER M16 26
10 232 646 98 RING 2
17 258 187 28 COVER 1
18 258 141 28 BOTTOM PLATE RIGHT 1
19 258 142 58 BOTTOM PLATE LEFT 1
. . . . .
22 800 196 59 HEXAGON HEAD SCREW M16X30 2
30 442 381 50 HEXAGON HEAD BOLT M30x200 - 8.8 1
31 887 474 49 HEX SCREW m8.8 3
32 801 778 69 LOCK NUT M30 4
33 852 461 29 DOUBLE LOCK WASHER M30 8
. . . . .
34 263 784 98 TAPER PIN D70 L162 1
50 390 100 08 SIGN LIFTING 3
55 550 310 98 POP-RIVET 2,49X5 16
81 800 470 59 HEXAGON HEAD SCREW M12x30 m8.8 2
82 800 821 49 HEXAGON NUT M12 m8 SFS-ISO 4032 5
. . . . .
83 851 068 09 DOUBLE LOCK WASHER M12 5
84 801 093 59 HEXAGON HEAD SCREW M16X25-8.8 10
85 884 009 89 WASHER M12 DIN 9021 10
88 883 301 39 WASHER DIN 6340 17/45x6 9
89 550 130 59 DOUBLE LOCK WASHER M12 8
. . . . .
92 442 776 90 HEXAGON HEAD SCREW M12X35 8.8 SFS 2064 7
93 857 514 39 WASHER 13/35X5 2
96 811 260 29 LOCK NUT M12 m8 BH8 2
97 800 532 09 HEXAGON HEAD SCREW M12X45 m8.8 SFS 2064 2
*12 551 653 65 BASE PLATE 1
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 561 87 iD
23 (91) TOP FRAME ASSEMBLY 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 561 87 iD
110201 TOP FRAME ASSEMBLY 24 (91)

Ref. Part no. Description EN Standard designation Qty

e
9 550 130 61 DOUBLE LOCK WASHER M16 26
24 802 198 29 HEXAGON HEAD BOLT M16X70 7
27 412 113 00 LOCK NUT M12 DIN 985-8 2
35 551 807 87 ADAPTER ASSEMBLY SECTION 11 PAGE 56 1
40 314 681 68 FLANGE 1
. . . . .
41 800 538 69 HEXAGON HEAD SCREW M16X45 6
42 850 687 49 DOUBLE LOCK WASHER M16 6
43 550 166 27 ASSEMBLY 1
44 233 221 38 SHIM 2
45 550 166 32 CABLE HOLDER 1
. . . . .
46 550 612 36 PLATE 1
47 550 635 07 PLATE 1
70 550 149 52 LIGHT 1
70.1 806 693 69 BULB 24V/70W, H3 1
71 550 190 64 SUPPORTING BLOCK 1
. . . . .
72 801 779 99 LOCK NUT M8 DIN985 88ZN 1
73 800 824 29 HEXAGON HEAD SCREW 1
75 806 981 89 ONE-WAY RESTRICTOR 1
76 856 040 09 STRAIGHT THREAD ADAPTER F40X-S10-3/8 1
78 858 385 89 SWIVEL NUT MALE ADAPTER 9/16-18JIC 1
. . . . .
83 851 068 09 DOUBLE LOCK WASHER M12 5
86 802 488 09 HEXAGON HEAD BOLT M8X100 m8.8 SFS 2063 2
87 851 281 89 DOUBLE LOCK WASHER M8 2
88 883 301 39 WASHER DIN 6340 17/45x6 9
89 550 130 59 DOUBLE LOCK WASHER M12 8
. . . . .
90 811 259 69 LOCK NUT M16 m8 B-lock 7
92 442 776 90 HEXAGON HEAD SCREW M12X35 8.8 SFS 2064 7

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 579 92 a
25 (91) Assembly / TOP FRAME BUSHING 110201

Ref. Part no. Description EN Standard designation Qty

e
1 551 579 53 TOP FRAME Upper frame, Sandvik DX 1
2 314 682 98 BEARING BUSHING 2
5 550 420 66 BEARING BUSHING D85 d75 L39 2

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 670 74 b
110201 ASSEMBLY / TOP FRAME BUSHING 26 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 709 20 TOP FRAME ASSEMBLY SECTION 11 PAGE 27 1
2 314 682 98 BEARING BUSHING 2
5 550 420 66 BEARING BUSHING D85 d75 L39 2
6 850 687 49 DOUBLE LOCK WASHER M16 24
7 801 775 89 LOCK NUT M16 m8 DIN 985 9
. . . . .
8 818 020 09 HEXAGON HEAD BOLT M16X180 - 10.9 4
9 442 219 80 HEXAGON HEAD SCREW M16X50 2
10 800 495 09 HEXAGON HEAD BOLT M16X140 m8.8 5
11 442 218 50 HEXAGON HEAD SCREW M16x40 m8.8 4
12 551 671 18 SUPPORTING BLOCK 1
. . . . .
13 551 671 94 SUPPORTING BLOCK 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 709 20
27 (91) Top frame assembly 110201

Ref. Part no. Description EN Standard designation Qty

e
1 551 672 29 TOP FRAME 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 554 15 bB
29 (91) FUEL TANK ASSEMBLY 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 554 15 bB
110201 FUEL TANK ASSEMBLY 30 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 536 20 FUEL TANK 1
2 551 563 57 COVER SECTION 11 PAGE 32 1
3 816 769 59 STRAIGHT THREAD ADAPTER F40X-S18-1" (1,1/16-12JIC) 1
4 856 040 09 STRAIGHT THREAD ADAPTER F40X-S10-3/8 3
5 800 412 59 BALL VALVE 3/8" 2
. . . . .
6 801 031 49 BONDED SEAL U 17,4X24X1,5 2
7 857 302 19 PLUG FNTX-S10 1
9 851 281 89 DOUBLE LOCK WASHER M8 3
10 808 802 29 HEXAGON HEAD SCREW M8X20 m8.8 SFS 2064 3

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 563 57
31 (91) COVER 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 563 57
110201 COVER 32 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 563 54 COVER Cover, fuel tank, Sandvik DX 1
2 802 400 09 FILTER 1
3 885 374 09 FILLING CAP 1
4 235 779 58 COVER 1
5 811 292 09 LOCK NUT HD 1270-12 R3/4" 1
. . . . .
6 850 794 09 BREATHER 1
7 551 576 80 SENSOR ITS-60_202_001V1 Diesel Tanksensor-1150 1
mm
8 232 816 18 GASKET 1
9 851 282 09 DOUBLE LOCK WASHER M10 12
10 800 192 49 HEXAGON HEAD SCREW M10X30 DIN933 8.8ZN 1
. . . . .
11 800 820 19 HEXAGON NUT M10 m8 SFS 2067 1
12 800 460 49 HEXAGON HEAD SCREW M10X25-8.8 SFS-ISO 4017 10

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 642 99 cB
33 (91) OIL COOLER ASSEMBLY DX 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 642 99 cB
110201 OIL COOLER ASSEMBLY DX 34 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 785 19 COOLER ASSEMBLY SECTION 11 PAGE 36 1
2 551 547 30 MOUNTING BRACKET 1
3 551 600 30 COVER PLATE 1
4 551 603 86 LATH 1
5 551 603 85 RUBBER SHEET 1
. . . . .
6 800 823 09 HEXAGON HEAD SCREW M10x20 m8.8 4
7 808 802 29 HEXAGON HEAD SCREW M8X20 m8.8 SFS 2064 15
8 851 282 09 DOUBLE LOCK WASHER M10 4
9 851 281 89 DOUBLE LOCK WASHER M8 15
800 551 941 26 HOSE SET SECTION 11 PAGE 42 1
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 785 19 bB
35 (91) COOLER ASSEMBLY 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 785 19 bB
110201 COOLER ASSEMBLY 36 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 885 472 79 OIL COOLER SECTION 11 PAGE 39 1
2 550 746 45 THERMOSTAT 450 L/min, close 52 Celsius, 1 1/2" 1
3 886 640 59 THERMOSTAT VALVE 1
3.1 886 832 59 THERMOSTAT CARTRIDGE 1
4 800 350 09 USIT-SEAL AQ136-16 1
. . . . .
5 802 177 89 ADAPTER (HYDRAULIC) 135-24-20 (R1 1/2XR1 1/4) 1
6 816 699 59 STRAIGHT THREAD ADAPTER JIC 1,7/8-12 1
7 816 700 59 STRAIGHT THREAD ADAPTER 1,5/16-12 JIC 1
9 816 707 49 SWIVEL NUT ELBOW 90 1,7/8-12 JIC 2
10 816 708 79 SWIVEL NUT ELBOW 90 1,5/16-12 JIC 4
. . . . .
11 816 718 89 ADAPTER TEE 1,5/16-12 JIC 3
12 816 778 39 STRAIGHT THREAD ADAPTER 1,5/16-12JIC 2
14 817 247 59 FEMALE CONNECTOR JIC 1,7/8-12 1
17 858 324 09 SWIVEL NUT MALE ADAPTER 1,7/8-12JIC 1
18 869 606 59 STRAIGHT THREAD ELBOW 1,7/8-12 1
. . . . .
19 885 311 69 ADAPTER TEE 1,7/8-12JIC 2
24 802 284 39 USIT-SEAL 48,7X59X3 D2=50,8 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 785 19 bB
37 (91) COOLER ASSEMBLY 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 785 19 bB
110201 COOLER ASSEMBLY 38 (91)

Ref. Part no. Description EN Standard designation Qty

e
8 816 703 39 SWIVEL NUT MALE ADAPTER 1,5/16-12 JIC 1
10 816 708 79 SWIVEL NUT ELBOW 90 1,5/16-12 JIC 4
11 816 718 89 ADAPTER TEE 1,5/16-12 JIC 3
12 816 778 39 STRAIGHT THREAD ADAPTER 1,5/16-12JIC 2
13 817 166 19 TUBE END REDUCER 1 1/16"X3/4" JIC 2
. . . . .
15 866 363 19 ADAPTER TEE 1 1/16"-12 JIC 1
16 853 385 39 NUT JIC 1,1/16-12 2
20 234 570 48 FITTING 1,1/6-12JIC 2
21 522 077 80 O-RING 19,2X3 2
22 445 774 60 HEXAGON SOCKET HEAD SCREW M6X20 - 8.8 8
. . . . .
23 550 204 51 DOUBLE LOCK WASHER M6 8
25 817 163 39 ADAPTER TEE 3/4-16 JIC 1
26 551 784 80 SWIVEL NUT MALE ADAPTER BSPP 1/2-14 ->UNF 3/4-16 1
27 802 098 09 CHECK VALVE R1/2 0,1 bar 1
28 817 094 69 ADAPTOR JIC 3/4-16 1
. . . . .
29 816 701 89 STRAIGHT THREAD ADAPTER 40X-S10-1/4" (9/16-18JIC) 1
30 817 180 79 SWIVEL NUT ELBOW 90 9/16-18 JIC 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 885 472 79 d
39 (91) Oil cooler 110201

Ref. Part no. Description EN Standard designation Qty

e
1 886 704 59 FAN 1
2 550 403 32 HYDRAULIC MOTOR INCL. PARTS 21-23 1
5 887 697 09 FAN HOUSING 1
6 887 797 29 FAN GUARD 1
7 888 023 79 OIL COOLER COMPRESSOR 1
. . . . .
8 888 024 09 OIL COOLER HYDRAULIC 1
*21 886 816 49 SEAL KIT 1
*22 550 363 88 BEARING UNIT 1
*23 550 363 89 COUPLING 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 941 26 dC
41 (91) HOSE SET / OIL COOLER 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 941 26 dC
110201 HOSE SET / OIL COOLER 42 (91)

Ref. Part no. Description EN Standard designation Qty

e
43 592 009 97 HYDRAULIC HOSE ASSEMBLY 1SN16MS AA-750-JIC 1
44 592 052 53 HOSE ASSY 1SN24MS AD-900-JIC 1
168 592 052 51 HYDRAULIC HOSE ASSEMBLY 1SN24MS AB-1200-JIC 1
267 592 021 61 HYDRAULIC HOSE ASSEMBLY 2SC12MS AA-550-JIC 1
366 592 008 13 HYDRAULIC HOSE ASSEMBLY 2SC08MS AA-500-JIC 1
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 325 546 78 aD
43 (91) CYLINDER / D140 D80 LMIN1260 S850 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 325 546 78 aD
110201 CYLINDER / D140 D80 LMIN1260 S850 44 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 325 547 08 CYLINDER TUBE D140 INCL. PARTS 27-29 1
2 322 480 98 PISTON ROD 80 INCL. PARTS 27-29 1
3 322 477 78 PISTON D140 1
4 325 549 58 FRONT COVER D140 1
5 872 527 39 DOUBLE OVERCENTER VALVE 1
. . . . .
7 264 135 18 PIPE ASSEMBLY 2
8 869 758 89 CHECK VALVE R1/4 2
9 816 714 79 STRAIGHT THREAD ELBOW "C40X-S16-1/2""" 1
10 816 698 29 STRAIGHT THREAD ADAPTER 7/8-14 JIC 3
11 816 976 39 PISTON SEAL 140-115-18,4/36,8 1
. . . . .
12 882 149 29 ROD SEAL 80-95-11.4 1
13 807 249 89 WIPER 80-90-7-10 1
14 817 053 09 O-RING 129,54X6,99-1 2
15 800 805 39 O-RING 69,5X3 1
17 812 605 29 PLUG 139-8 R1/2" 1
. . . . .
18 800 347 99 BONDED SEAL U 21,5X28,7X2,5 D2=23,15 1
19 445 827 20 HEXAGON SOCKET HEAD SCREW M12x40 m8.8 SFS 2219 18
20 816 709 09 SWIVEL NUT ELBOW 90 C6X-S14 2
21 885 070 09 PISTON ROD GUIDE RING 2
22 330 851 08 NUT 40X1.5 1
. . . . .
24 816 702 09 STRAIGHT THREAD ADAPTER JIC 9/16-18 2
25 857 302 19 PLUG FNTX-S10 2
27 550 576 60 PLAIN BEARING 2
28 802 353 09 CIRCLIP 105X4 DIN 472 2
29 572 102 40 GREASE NIPPLE AR 1/8 2
. . . . .
*6 264 136 48 BRACKET 1
*23 801 779 99 LOCK NUT M8 m8 DIN 985 2
*801 882 161 29 SEAL KIT INCL. PARTS 11, 14-15 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 759 23 eC
45 (91) OIL RECEIVER ASSEMBLY / DX500-800 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 759 23 eC
110201 OIL RECEIVER ASSEMBLY / DX500-800 46 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 561 38 HYDRAULIC RECEIVER ASSEMBLY SECTION 11 PAGE 50 1
2 551 653 65 BASE PLATE 1
3 550 550 15 SUPPORTING BLOCK ASSEMBLY SECTION 11 PAGE 55 1
4 551 636 51 BRACKET 1
5 551 868 14 BRACKET 1
. . . . .
6 551 801 15 BRACKET 1
7 551 787 01 VALVE PLATE 1
8 551 636 53 BRACKET 1
9 551 790 10 SUPPORT 1
10 800 538 69 HEXAGON HEAD SCREW M16X45 3
. . . . .
14 550 130 59 DOUBLE LOCK WASHER M12 24
15 800 821 49 HEXAGON NUT M12 m8 SFS-ISO 4032 6
18 800 820 19 HEXAGON NUT M10 m8 SFS 2067 4
20 811 259 69 LOCK NUT M16 m8 B-lock 3
24 442 776 90 HEXAGON HEAD SCREW M12X35 8.8 SFS 2064 6
. . . . .
25 551 785 17 VALVE BRACKET for double pressure relief valve 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 759 23 eC
47 (91) OIL RECEIVER ASSEMBLY / DX500-800 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 759 23 eC
110201 OIL RECEIVER ASSEMBLY / DX500-800 48 (91)

Ref. Part no. Description EN Standard designation Qty

e
10 800 538 69 HEXAGON HEAD SCREW M16X45 3
11 550 130 61 DOUBLE LOCK WASHER M16 2
12 800 470 59 HEXAGON HEAD SCREW M12x30 m8.8 12
13 412 113 00 LOCK NUT M12 DIN 985-8 4
14 550 130 59 DOUBLE LOCK WASHER M12 24
. . . . .
15 800 821 49 HEXAGON NUT M12 m8 SFS-ISO 4032 6
16 800 192 49 HEXAGON HEAD SCREW M10X30 DIN933 8.8ZN 4
17 550 130 58 DOUBLE LOCK WASHER M10 8
18 800 820 19 HEXAGON NUT M10 m8 SFS 2067 4
19 883 301 39 WASHER DIN 6340 17/45x6 4
. . . . .
20 811 259 69 LOCK NUT M16 m8 B-lock 3
21 550 204 51 DOUBLE LOCK WASHER M6 2
22 802 421 59 HEXAGON HEAD SCREW M6x18m8.8 SFS 2
23 884 009 89 WASHER M12 DIN 9021 4
24 442 776 90 HEXAGON HEAD SCREW M12X35 8.8 SFS 2064 6
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 561 38 cD
49 (91) HYDRAULIC RECEIVER ASSEMBLY 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 561 38 cD
110201 HYDRAULIC RECEIVER ASSEMBLY 50 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 561 45 HYDRAULIC RECEIVER WELDING 1
3 884 065 29 LEVEL SWITCH 1
5 850 794 09 BREATHER 1
6 811 294 69 ADAPTER (HYDRAULIC) HD 1260-12 R3/4" 1
7 811 292 09 LOCK NUT HD 1270-12 R3/4" 2
. . . . .
8 871 769 79 PLUG 1
9 808 616 99 USIT-SEAL U 76,08X90,3X3,38 ,D2=79 1
10 801 031 49 USIT-SEAL U 17,4X24X1,5 3
11 817 180 79 SWIVEL NUT ELBOW 90 9/16-18 JIC 6
12 049 429 78 ADAPTER R3/8" - 9/16-18 UNF, L=65 3
. . . . .
13 817 095 99 COUPLING 8-12F42EDMXS (3/4-16JIC) 1
14 817 183 59 SWIVEL NUT ELBOW 90 , 3/4-16JIC 5
15 856 040 09 STRAIGHT THREAD ADAPTER F40X-S10-3/8 3
17 817 226 09 STRAIGHT THREAD ADAPTER 1,5/8-12 JIC 2
18 817 241 99 SWIVEL NUT ELBOW 90 C6X-S32 2
. . . . .
19 816 768 29 STRAIGHT FITTING 1,1/16"-12 JIC 4
20 816 710 69 STRAIGHT THREAD ELBOW C40X-S25-1'' (1.5/16-12JIC) 1
21 051 715 98 SPLIT FLANGE FITTING 2
22 811 038 69 O-RING 2
23 811 039 99 MOUNTING PIECE 4
. . . . .
24 445 827 20 HEXAGON SOCKET HEAD SCREW M12x40 m8.8 SFS 2219 8
25 851 068 09 DOUBLE LOCK WASHER M12 8
28 817 991 29 STRAIGHT THREAD ADAPTER 3/8" 4
29 818 001 09 NUT JIC 3/4-16 1
30 853 780 09 TUBE END REDUCER 9/16JIC, 3/4X 1
. . . . .
37 885 971 89 THERMOSTAT (TEMP. SW.) 1
38 816 711 99 STRAIGHT THREAD ELBOW 9/16-18 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 561 38 cD
51 (91) HYDRAULIC RECEIVER ASSEMBLY 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 561 38 cD
110201 HYDRAULIC RECEIVER ASSEMBLY 52 (91)

Ref. Part no. Description EN Standard designation Qty

e
2 867 271 59 RETURN FILTER SECTION 11 PAGE 54 1
4 802 443 29 O-RING 199,2X5,7 2
19 816 768 29 STRAIGHT FITTING 1,1/16"-12 JIC 4
26 800 823 09 HEXAGON HEAD SCREW M10x20 m8.8 12
27 851 282 09 DOUBLE LOCK WASHER M10 12
. . . . .
31 551 561 76 COVER 1
32 551 561 84 COVER 1
35 551 710 86 COLLECTING PIECE 1
36 806 870 19 SHEATH 4A 24VDC, 30psi 1
39 817 245 09 STRAIGHT THREAD ADAPTER 1,7/8-12 JIC 1
. . . . .
40 811 038 69 O-RING 1
41 442 481 80 HEXAGON HEAD BOLT M12X110 m8.8 SFS 2063 4
42 851 068 09 DOUBLE LOCK WASHER M12 4
43 819 560 89 SWIVEL NUT ELBOW 90 1 1/16"-12 JIC 1
44 816 761 39 SWIVEL NUT MALE ADAPTER 1,1/16-12JIC 1
. . . . .
45 813 158 29 CHECK VALVE R3/4 16/0,1BAR 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 867 271 59 e
53 (91) RETURN FILTER 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 867 271 59 e
110201 RETURN FILTER 54 (91)

Ref. Part no. Description EN Standard designation Qty

e
*1 867 272 89 FILTER ELEMENT 1
*2 550 093 67 SEAL KIT 1
*2.1 812 233 99 O-RING NBR 130X4 70sh 1
*2.2 800 662 59 O-RING NBR 109,1X5,7 1
*2.3 551 667 54 GASKET PLATE NBR, 70 sh 1
. . . . .
*2.4 866 809 69 O-RING 168X3 1
*3 550 069 09 GUARD FUNNEL FOR FILTER 1
*3.1 866 809 69 O-RING 168X3 1
*4 551 632 93 SPRING Holding coin spring 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 550 15 aD
55 (91) Supporting block assembly 110201

Ref. Part no. Description EN Standard designation Qty

e
1 551 910 76 BRACKET 1
2 235 973 48 HOSE SUPPORT D=140 1
3 800 531 79 HEXAGON HEAD SCREW M12x40 m8.8 SFS 2064 2
4 811 260 29 LOCK NUT M12 m8 BH8 2
5 851 068 09 DOUBLE LOCK WASHER M12 2
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 807 87 bB
110201 Adapter assembly / TANK COLLECTOR 56 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 643 27 COLLECTING PIECE 1
2 817 245 09 STRAIGHT THREAD ADAPTER 1,7/8-12 JIC 2
4 816 769 59 STRAIGHT THREAD ADAPTER F40X-S18-1" (1,1/16-12JIC) 2
5 551 805 68 STRAIGHT THREAD ADAPTER JIC 3/4 -16 1
6 865 275 49 ADAPTER TEE 1,1/16-12JIC 1
. . . . .
7 819 560 89 SWIVEL NUT ELBOW 90 1 1/16"-12 JIC 1
8 816 700 59 STRAIGHT THREAD ADAPTER 1,5/16-12 JIC 1
9 816 708 79 SWIVEL NUT ELBOW 90 1,5/16-12 JIC 1
10 881 142 29 PLUG 138-16 (R1") 2
11 550 642 19 SWIVEL NUT ELBOW 45 24V6XS (1,7/8-12JIC) 2
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 643 53 eA
57 (91) LOWER FRAME ASSEMBLY / 180DEG --- DX & DX***R 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 643 53 eA
110201 LOWER FRAME ASSEMBLY / 180DEG --- DX & DX***R 58 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 803 60 LOWER FRAME ASSEMBLY SECTION 11 PAGE 62 1
2 550 129 75 BUSHINGS SECTION 11 PAGE 63 1
3 263 781 08 TAPER PIN D50 L150 6
4 258 825 02 CYLINDER SECTION 11 PAGE 66 2
8 236 409 18 THRUST PLATE 2
. . . . .
16 442 776 90 HEXAGON HEAD SCREW M12X35 8.8 SFS 2064 20
17 851 068 09 DOUBLE LOCK WASHER M12 28
24 550 149 31 SHAFT 1
26 550 149 35 FLANGE 1
30 134 424 78 FLANGE 1
. . . . .
31 800 824 29 HEXAGON HEAD SCREW 2
40 446 270 20 HEX.SOCKET HEAD CAP SCR. M12X25 3
50 550 143 29 CYLINDER SECTION 11 PAGE 68 1
74 572 102 40 GREASE NIPPLE AR 1/8 1
*9 233 622 78 ADJUSTING PLATE OF THE OSC. 2
. . . . .
*11 550 156 55 GUARD 1
*12 550 160 03 GUARD 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 643 53 eA
59 (91) LOWER FRAME ASSEMBLY / 180DEG --- DX & DX***R 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 643 53 eA
110201 LOWER FRAME ASSEMBLY / 180DEG --- DX & DX***R 60 (91)

Ref. Part no. Description EN Standard designation Qty

e
8 236 409 18 THRUST PLATE 2
10 550 148 23 PLAIN BEARING 1
16 442 776 90 HEXAGON HEAD SCREW M12X35 8.8 SFS 2064 20
17 851 068 09 DOUBLE LOCK WASHER M12 28
19 235 562 08 BEARING 1
. . . . .
21 800 538 69 HEXAGON HEAD SCREW M16X45 2
22 811 259 69 LOCK NUT M16 m8 B-lock 2
23 850 687 49 DOUBLE LOCK WASHER M16 2
25 800 192 49 HEXAGON HEAD SCREW M10X30 DIN933 8.8ZN 4
35 851 282 09 DOUBLE LOCK WASHER M10 2
. . . . .
36 819 560 89 SWIVEL NUT ELBOW 90 1 1/16"-12 JIC 2
37 816 746 59 ADAPTER (HYDRAULIC) 1.1/16-12JIC 4
38 853 815 09 SWIVEL NUT ELBOW 45 12V6MXS (1,1/16-12-JIC) 2
39 232 646 98 RING 2
51 550 172 26 GUARD 1
. . . . .
64 800 619 09 HEXAGON SOCKET SET SCREW M24X25 16
70 851 601 19 MALE CONNECTOR R1/8" 2
71 865 909 89 HOSE STUD 2
72 851 604 09 BUSHING 2
73 851 606 59 HOSE 8,4/4 2
. . . . .
800 551 847 19 HOSE SET SECTION 11 PAGE 70 1
*9 233 622 78 ADJUSTING PLATE OF THE OSC. 2

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 803 60 bC
61 (91) LOWER FRAME ASSEMBLY 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 803 60 bC
110201 LOWER FRAME ASSEMBLY 62 (91)

Ref. Part no. Description EN Standard designation Qty

e
2 550 160 71 SHAFT 1
3 232 832 28 RING 2
4 235 677 78 BUSHING D179,8 d160 L150 4
5 550 422 14 IDENTIFICATION LABEL 1
6 550 156 55 GUARD 1
. . . . .
7 550 160 03 GUARD 1
8 800 465 89 HEXAGON HEAD BOLT M12X25 - 8.8 8
9 550 130 59 DOUBLE LOCK WASHER M12 8

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 129 75 bB
63 (91) Bushings 110201

Ref. Part no. Description EN Standard designation Qty

e
1 550 129 74 PILLOW BLOCK 1
2 550 129 61 PLAIN BEARING 285/290 L=60 2
3 134 421 98 BEARING BUSHING D80 d70 L39 2
4 550 425 89 EXTENSION SLEEVE L=30 2
5 550 425 96 EXTENSION SLEEVE L=23 1
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 258 825 02 cH
65 (91) CYLINDER / D140 D70 LMIN655 S93 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 258 825 02 cH
110201 CYLINDER / D140 D70 LMIN655 S93 66 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 258 826 38 CYLINDER TUBE 1
2 237 738 08 PISTON ROD 1
3 321 369 88 COVER 1
4 237 480 58 PISTON 1
5 207 699 84 LIMIT BUSHING 1
. . . . .
6 816 976 39 PISTON SEAL 140-115-18,4/36,8 1
7 235 997 78 LOCK NUT 1
8 817 053 09 O-RING 129,54X6,99-1 1
9 800 805 39 O-RING 69,5X3 1
10 874 560 09 U-SEAL BS 7080 P5008 1
. . . . .
11 801 010 09 WIPER 70-80-7-10 1
12 817 054 29 PISTON ROD GUIDE RING I/PWR 70/76X13 3
13 445 827 20 HEXAGON SOCKET HEAD SCREW M12x40 m8.8 SFS 2219 18
14 886 623 19 HEXAGON SOCKET SET SCREW M8x16 - 12.9 3
17 871 830 29 CARTRIDGE 1
. . . . .
17.1 819 592 69 SEAL KIT 1
18 871 830 29 CARTRIDGE 1
18.1 819 592 69 SEAL KIT 1
19 885 093 09 DIRECTIONAL VALVE 2
21 817 991 29 STRAIGHT THREAD ADAPTER G 3/8" x JIC 3/4-16 2
. . . . .
22 856 040 09 STRAIGHT THREAD ADAPTER F40X-S10-3/8 2
23 817 183 59 SWIVEL NUT ELBOW 90 JIC 3/4-16 2
24 817 180 79 SWIVEL NUT ELBOW 90 9/16-18 JIC 2
25 207 974 08 BEARING BUSHING D60 d50 L59 2
26 855 920 29 PLAIN BEARING 2
. . . . .
27 422 292 00 CIRCLIP 90x3 DIN 472 4
28 572 102 40 GREASE NIPPLE AR 1/8 1
29 572 104 00 GREASE NIPPLE DIN 71412 1
30 851 782 49 EXTENSION PLATE KR1/8"XKR1/8" 1
*810 886 706 09 SEAL KIT INCL. PARTS 6, 8-12
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 143 29 gD
67 (91) CYLINDER / D140 D70 LMIN646 S280 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 143 29 gD
110201 CYLINDER / D140 D70 LMIN646 S280 68 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 550 143 00 CYLINDER TUBE INCL. PARTS 50, 52 1
2 550 143 21 PISTON ROD INCL. PARTS 50, 52 1
3 321 369 88 COVER 1
4 053 699 68 PISTON 1
5 550 387 17 VALVE ASSEMBLY SECTION 11 PAGE 69 1
. . . . .
6 871 374 39 LOCK NUT M60X2 1
7 816 976 39 PISTON SEAL 140-115-18,4/36,8 1
8 874 560 09 U-SEAL BS 7080 P5008 1
9 801 010 09 WIPER 70-80-7-10 1
10 817 054 29 PISTON ROD GUIDE RING I/PWR 70/76X13 3
. . . . .
11 817 053 09 O-RING 129,54X6,99-1 1
12 800 805 39 O-RING 69,5X3 1
13 445 827 20 HEXAGON SOCKET HEAD SCREW M12x40 m8.8 SFS 2219 18
14 550 143 30 PIPE 1
15 550 143 26 PIPE 1
. . . . .
17 134 461 28 BEARING BUSHING D60 d50 L62 2
23 810 468 99 HEXAGON HEAD SCREW M8X40-8.8 SFS-ISO 4017 2
25 857 302 19 PLUG FNTX-S10 2
30 851 281 89 DOUBLE LOCK WASHER M8 2
*50 572 102 40 GREASE NIPPLE AR 1/8 4
. . . . .
*51 550 579 33 PLAIN BEARING 2
*52 422 292 00 CIRCLIP 90x3 DIN 472 4
*200 550 974 18 SEAL KIT INCL. PARTS 7-12 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 387 17 aA
69 (91) VALVE ASSEMBLY 110201

Ref. Part no. Description EN Standard designation Qty

e
1 550 378 38 DOUBLE OVERCENTER VALVE INCL. PARTS 100-102 1
2 816 702 09 STRAIGHT THREAD ADAPTER JIC 9/16-18 2
3 856 040 09 STRAIGHT THREAD ADAPTER F40X-S10-3/8 1
4 816 698 29 STRAIGHT THREAD ADAPTER 7/8-14 JIC 2
5 816 709 09 SWIVEL NUT ELBOW 90 C6X-S14 2
. . . . .
6 853 813 59 SWIVEL NUT ELBOW 45 45, 9/16-18JIC 1
7 816 711 99 STRAIGHT THREAD ELBOW 9/16-18 1
8 817 180 79 SWIVEL NUT ELBOW 90 9/16-18 JIC 1
*100 550 391 12 OVERCENTER VALVE 2
*101 857 080 59 CHECK VALVE RB2 2
. . . . .
*102 885 855 49 SEAL KIT 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 847 19 A
110201 Hose set 70 (91)

Ref. Part no. Description EN Standard designation Qty

e
162 592 012 53 HYDRAULIC HOSE ASSEMBLY 2SC06MS AA-650-JIC 1
163 592 012 55 HYDRAULIC HOSE ASSEMBLY 2SC08MS AA-650-JIC 1
362 592 004 21 HYDRAULIC HOSE ASSEMBLY 2SC06MS AA-1100-JIC 1
363 592 004 21 HYDRAULIC HOSE ASSEMBLY 2SC06MS AA-1100-JIC 1
377 592 004 39 HYDRAULIC HOSE ASSEMBLY 2SC06MS AA-300-JIC 1
. . . . .
716 592 006 49 HYDRAULIC HOSE ASSEMBLY 2SC06MS AA-2000-JIC 1
717 592 004 39 HYDRAULIC HOSE ASSEMBLY 2SC06MS AA-300-JIC 1
718 592 009 25 HYDRAULIC HOSE ASSEMBLY 2SC08MS AA-900-JIC 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 011 07 b
71 (91) SHANK LUBRICATION ASSEMBLY 110201

Ref. Part no. Description EN Standard designation Qty

e
1 237 567 58 CONTAINER 1
4 887 256 29 OILSEPARATOR 1
5 551 597 51 RETURN HOSE 1SN16MS AA JIC, Nozzle, Spiral 1
6 879 395 59 ADAPTER (HYDRAULIC) 1,5/16-1,1/16 JIC 1
7 817 166 19 TUBE END REDUCER 1 1/16"X3/4" JIC 1
. . . . .
8 853 385 39 NUT JIC 1,1/16-12 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 613 26 dC
73 (91) COVERS ASSEMBLY 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 613 26 dC
110201 COVERS ASSEMBLY 74 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 612 16 COVER ASSEMBLY Top cover 1
2 551 613 12 COVER ASSEMBLY Left side top cover 1
3 551 613 00 COVER ASSEMBLY Top cover 1
4 551 584 79 COVER ASSEMBLY Right side cover 1
5 551 604 85 COVER ASSEMBLY Left side rear door 1
. . . . .
6 551 616 60 COVER ASSEMBLY Top cover 1
7 551 601 65 COVER ASSEMBLY 1
8 551 602 82 COVER ASSEMBLY Right front cover 1
10 551 646 14 PLATE 3
11 551 654 40 RUBBER BUFFER D25 / 20 X M6/1 6
. . . . .
12 883 990 59 RUBBER BUFFER D=40, L=40 2
13 551 645 11 MOUNTING PLATE 1
15 551 642 88 THRUST PLATE 2
16 551 644 93 MOUNTING PLATE 1
17 551 649 06 PLATE 2
. . . . .
18 133 964 38 LOCK 2
19 551 603 59 PLATE 2
20 551 642 95 LATCH 4
21 551 668 11 VIBRATION DAMPER 40/30 M8 2
22 551 655 09 RUBBER BUFFER D1=10 H2=8 H1=10 D3=M4 2
. . . . .
30 550 160 42 DOUBLE LOCK WASHER M8 20
31 800 916 09 HEXAGON HEAD SCREW M8x25 m8.8 SFS 10
32 800 917 29 HEXAGON NUT M8 m8 SFS 2067 6
33 550 130 58 DOUBLE LOCK WASHER M10 3
34 800 432 79 HEXAGON HEAD SCREW M10X16 3
. . . . .
35 550 130 59 DOUBLE LOCK WASHER M12 4
36 800 532 09 HEXAGON HEAD SCREW M12X45 m8.8 SFS 2064 2
37 800 821 49 HEXAGON NUT M12 m8 SFS-ISO 4032 2
38 550 770 58 DOUBLE LOCK WASHER M5 NORD-LOCK 8
39 800 954 89 HEXAGON HEAD SCREW M5X16-8.8 SFS-ISO 4017 8
. . . . .
40 853 239 79 DOUBLE LOCK WASHER M6 2
41 802 558 09 HEXAGON NUT M6 m8 SFS 2067 2
43 801 779 99 LOCK NUT M8 m8 DIN 985 4
44 421 168 00 WASHER M8 10
45 442 577 60 HEXAGON HEAD SCREW M8X35 - 8.8 2
. . . . .
46 442 535 70 HEXAGON HEAD SCREW M8X30-8.8 2
47 810 468 99 HEXAGON HEAD SCREW M8X40-8.8 SFS-ISO 4017 2
48 550 443 36 DOUBLE LOCK WASHER M4 2
49 801 772 09 HEXAGON NUT M4 m8 SFS 2067 2
50 551 932 53 BASEPLATE CUP - 2
. . . . .
*9 551 619 86 DOOR SECTION 11 PAGE 76 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 619 86 eE
75 (91) DOOR 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 619 86 eE
110201 DOOR 76 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 616 10 DOOR 1
2 551 616 11 TOOL BOX 1
3 551 613 68 BRACKET 1
4 133 964 38 LOCK 1
5 551 603 59 PLATE 1
. . . . .
6 884 292 29 WASHER M10 DIN 9021 3
7 550 130 58 DOUBLE LOCK WASHER M10 3
8 800 461 79 HEXAGON HEAD SCREW M10x35 m8.8 SFS 2064 3
9 550 954 72 GAS SPRING 1
10 800 824 29 HEXAGON HEAD SCREW 4
. . . . .
11 550 130 59 DOUBLE LOCK WASHER M12 4
12 445 760 40 HEXAGON SOCKET HEAD SCREW M5X14 - 8.8 4
15 551 642 91 MOUNTING PLATE 1
16 550 160 42 DOUBLE LOCK WASHER M8 6
17 808 802 29 HEXAGON HEAD SCREW M8X20 m8.8 SFS 2064 2
. . . . .
18 551 654 40 RUBBER BUFFER D25 / 20 X M6/1 1
19 853 239 79 DOUBLE LOCK WASHER M6 1
20 802 558 09 HEXAGON NUT M6 m8 SFS 2067 1
21 800 917 29 HEXAGON NUT M8 m8 SFS 2067 2
22 800 916 09 HEXAGON HEAD SCREW M8x25 m8.8 SFS 2
. . . . .
23 551 642 88 THRUST PLATE 1
24 551 977 89 VIBRATION DAMPER D40 H30 - M8 L8 (female) x2 2
25 851 281 89 DOUBLE LOCK WASHER M8 2
26 800 917 29 HEXAGON NUT M8 m8 SFS 2067 2
27 858 720 09 HEXAGON HEAD SCREW M8X45-8.8 SFS-ISO 4017 2
. . . . .
*13 551 677 91 PLATE SHIM 1MM 1
*14 551 677 92 PLATE SHIM 2MM 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 571 25 a
77 (91) SIGN SET 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 571 25 a
110201 SIGN SET 78 (91)

Ref. Part no. Description EN Standard designation Qty

e
10 390 064 48 SIGN 70X70 "FUEL" 1
14 551 925 49 INSTRUCTION PLATE 1
16 157 452 28 SYMBOL ''FUSE'' 1
17 550 213 17 SIGN Welding sign-Elect. controlled engines 1
18 550 591 55 SIGN MAIN SWITCH, CARRIER 1
. . . . .
20 390 503 08 PLATE''TOWING'' 1
25 390 097 58 SIGN ENGINE STOPPING INSTR. 1
26 136 219 68 SIGN Warning noise 1
30 390 099 08 SYMBOL ''OIL FILLING'' 1
35 390 103 98 SYMBOL ''COMP. PRESS. REGULATOR 1
. . . . .
36 390 102 68 SIGN AIR FILTER 1
37 390 098 88 SIGN AIR FILTER 1
38 390 108 28 SYMBOL ''FUEL'' "FILLING PUMP" 1
40 132 727 18 SIGN OILER DRAINAGE 1
42 390 034 18 SYMBOL 20X50 "RUNNING HOURS" 1
. . . . .
43 390 175 08 SYMBOL 1
44 550 019 45 SIGN PATENT NAME PLATE 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 187 04 dAa
79 (91) SIGN AND DECAL ASSEMBLY 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 187 04 dAa
110201 SIGN AND DECAL ASSEMBLY 80 (91)

Ref. Part no. Description EN Standard designation Qty

e
50 134 197 38 STICKER 1
54 550 955 76 DECAL 1
91 550 317 32 DECAL "Warning decal ""Rod dancer""" 1
92 550 306 99 DECAL Warning decal "Hot surfaces" 1
94 550 580 93 SIGN Warning sign "DUST HAZARD" 1
. . . . .
95 550 587 88 SIGN Warning sign "DUST HAZARD" 2
100 550 183 87 SIGN DRILLING STABILITY 1
102 233 045 08 ''GIVEN GRAD. ANGLE (TRAMMING)'' 1
103 233 038 88 SIGN 1
105 207 339 48 SIGN 2
. . . . .
107 207 329 38 SIGN DANGER AREA DRILLING 2
108 232 247 08 WARNING DECAL "Warning ""working area""" 1
110 233 040 78 STICKER/PLATE 1
110 233 040 78 STICKER/PLATE 2
112 232 482 66 SIGN 1
. . . . .
113 232 898 46 SIGN 1
130 550 184 01 CAUTION BOARD SET 1
131 233 030 68 CAUTION BOARD SET 1
*28 550 550 52 SIGN Type 1
*120 233 458 08 WARNING ''WATER TANK'' 1
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 187 04 dAa
81 (91) SIGN AND DECAL ASSEMBLY 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 187 04 dAa
110201 SIGN AND DECAL ASSEMBLY 82 (91)

Ref. Part no. Description EN Standard designation Qty

e
50 134 197 38 STICKER 1
54 550 955 76 DECAL 1
91 550 317 32 DECAL "Warning decal ""Rod dancer""" 1
92 550 306 99 DECAL Warning decal "Hot surfaces" 1
94 550 580 93 SIGN Warning sign "DUST HAZARD" 1
. . . . .
95 550 587 88 SIGN Warning sign "DUST HAZARD" 2
100 550 183 87 SIGN DRILLING STABILITY 1
102 233 045 08 ''GIVEN GRAD. ANGLE (TRAMMING)'' 1
103 233 038 88 SIGN 1
105 207 339 48 SIGN 2
. . . . .
107 207 329 38 SIGN DANGER AREA DRILLING 2
108 232 247 08 WARNING DECAL "Warning ""working area""" 1
110 233 040 78 STICKER/PLATE 1
110 233 040 78 STICKER/PLATE 2
112 232 482 66 SIGN 1
. . . . .
113 232 898 46 SIGN 1
130 550 184 01 CAUTION BOARD SET 1
131 233 030 68 CAUTION BOARD SET 1
*28 550 550 52 SIGN Type 1
*120 233 458 08 WARNING ''WATER TANK'' 1
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 909 43 eA
83 (91) SIGN AND DECAL ASSEMBLY 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 909 43 eA
110201 SIGN AND DECAL ASSEMBLY 84 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 550 909 50 DECAL SET DX700 1
52 232 184 38 DECAL 1
60 550 169 96 SIGN 1
300 810 004 19 FIRE EXTINGUISHER 1
302 235 106 48 PRESSURE GAUGE BRIEFCASE SECTION 4 PAGE 39 1
. . . . .
304 800 632 29 PUMP ASSEMBLY 1
310 133 342 08 PLASTIC BAG 4
324 850 953 99 EDGING PLATE 1
334 235 080 28 SHIM 2
335 449 691 00 LIFTING EYE M10 C15 DIN 580 2
. . . . .
*44 550 019 45 SIGN PATENT NAME PLATE 1
*96 550 611 26 SIGN 1
*330 886 182 09 MIRROR 1
2 550 571 25 SIGN SET SECTION 11 PAGE 78 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 909 43 eA
85 (91) SIGN AND DECAL ASSEMBLY 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 909 43 eA
110201 SIGN AND DECAL ASSEMBLY 86 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 550 909 50 DECAL SET DX700 1
53 000 217 68 LUMINOUS BADGE 4.4
55 550 331 88 DECAL 1
56 550 909 59 DECAL SERVICE PARTS, DX800\780\700 , TIER3 1
57 550 076 67 DECAL 1
. . . . .
58 550 076 66 DECAL 1
59 550 076 65 DECAL 1
340 819 991 49 SEAL 2
*93 550 539 47 DECAL 1
2 550 571 25 SIGN SET SECTION 11 PAGE 78 1
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 905 44 b
87 (91) VALVE ATTACHMENTS 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 551 905 44 b
110201 VALVE ATTACHMENTS 88 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 551 889 20 BRACKET 1
2 551 903 42 HOUSING 1
3 550 164 15 COVER PLATE 1
5 550 203 21 COLLECTING PIECE SECTION 11 PAGE 90 1
6 800 305 09 HEXAGON HEAD BOLT M6X60-8.8 SFS-ISO 4014 (SFS2063) 2
. . . . .
7 800 823 09 HEXAGON HEAD SCREW M10x20 m8.8 5
8 550 130 58 DOUBLE LOCK WASHER M10 5
9 853 239 79 DOUBLE LOCK WASHER M6 2
10 800 470 59 HEXAGON HEAD SCREW M12x30 m8.8 3
11 851 068 09 DOUBLE LOCK WASHER M12 3
. . . . .
12 445 774 60 HEXAGON SOCKET HEAD SCREW M6X20 m8.8 SFS 2219 4
13 442 935 80 HEXAGON HEAD SCREW M24X50 - 8.8 2
14 442 937 30 HEXAGON HEAD SCREW M24X70 - 8.8 2
15 851 284 69 DOUBLE LOCK WASHER M24 4
16 817 808 09 LOCK NUT VM24 m8 DIN 980 2
. . . . .
*4 851 291 99 HOUSING 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 203 21 bB
89 (91) COLLECTING PIECE 110201

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 203 21 bB
110201 COLLECTING PIECE 90 (91)

Ref. Part no. Description EN Standard designation Qty

e
1 161 490 88 COLLECTING PIECE 1
2 812 603 79 PLUG 1
3 812 605 29 PLUG 139-8 R1/2" 1
4 816 701 89 STRAIGHT THREAD ADAPTER 40X-S10-1/4" (9/16-18JIC) 2
5 817 180 79 SWIVEL NUT ELBOW 90 9/16-18 JIC 2
. . . . .
6 817 094 69 STRAIGHT THREAD ADAPTER G 1/2" x JIC 3/4-16 1
7 858 881 09 ADAPTER TEE JIC 3/4-16 1
8 816 702 09 STRAIGHT THREAD ADAPTER JIC 9/16-18 2
9 816 770 19 STRAIGHT THREAD ADAPTER JIC 1 1/16"-12 1
11 807 180 49 USIT-SEAL 22,7X30X2 D2=24,4 1
. . . . .
12 801 802 69 BONDED SEAL U 13,7X22X1,5 D2=15,4 1

Sandvik Mining and Construction Oy, Drills Tampere © 2011

 550 801 78 aA
91 (91) ASSEMBLY / EXTRA SWING 110201

Ref. Part no. Description EN Standard designation Qty

e
1 851 973 19 BASE PLATE 1
2 871 789 99 COVER PLATE 1
3 856 040 09 STRAIGHT THREAD ADAPTER F40X-S10-3/8 2
4 817 180 79 SWIVEL NUT ELBOW 90 9/16-18 JIC 3
5 816 702 09 STRAIGHT THREAD ADAPTER JIC 9/16-18 1
. . . . .
6 858 881 09 ADAPTER TEE JIC 3/4-16 1
7 817 094 69 STRAIGHT THREAD ADAPTER G 1/2" x JIC 3/4-16 1
8 800 347 99 BONDED SEAL U 21,5X28,7X2,5 D2=23,15 2
9 812 605 29 PLUG 139-8 R1/2" 2
10 812 604 09 PLUG R3/8 2
. . . . .
11 886 388 29 DIRECTIONAL VALVE SECTION 10 PAGE 28 1
12 801 031 49 BONDED SEAL U 17,4X24X1,5 2
13 819 257 89 HEXAGON SOCKET HEAD SCREW M5X50 m10,9 DIN 912 4
14 445 716 60 HEXAGON SOCKET HEAD SCREW M6x60 SFS 2219 3
15 853 323 29 HEXAGON SOCKET HEAD SCREW M5X30 m12.9 4
. . . . .
16 867 381 99 ONE-WAY RESTRICTOR 1
30 550 175 10 SUPPORTING BLOCK 1
32 879 368 09 PRE-WIRED PLUG CABLE 24DC, 3.0m 2
33 867 759 99 TERMINAL BUSHING 0.75mm2 L=8 4

Sandvik Mining and Construction Oy, Drills Tampere © 2011
