SkillsUSA
2014 Contest Projects
Mechatronics
Click the “Print this Section” button above to automatically print the specifications for
this contest. Make sure your printer is turned on before pressing the button.
Task #1: Assembly, commissioning and programming
of Distribution Station
Points 400
t min fastest team
t max 180 min
Situation
Your task is to assemble, commission and program the
Distribution station.
The task is fulfilled when the station is completely

assembled and commissioned according to the professional
practice agreement. The system has to fulfill the
specifications according to the evaluation sheet.
Task Description
Different workpieces (red, silver or black) are manually

put into the stack magazine.
The parts are ejected from the magazine, picked up by the

swing arm and then deposited to the right of the station.
The cycle continues until the stack is empty, at which

point operation stops and the LED in the start button and
the lamp Q1 are illuminated.
It is necessary to reload the stack magazine and press the

start button again before the machine starts up and cycle
resumes.
PLC program:
Initial situation:
No workpieces are on the station
On power up, LED in reset button is “on”

Press reset to reset machine. Part ejector cylinder is
extended, rotary arm is to the right and vacuum is off.
If successful, LED in reset button goes “off” and green

start button is lit up.
Place 3 parts in magazine
Page 1 of 7 Skills-USA Mechatronics Competition 2012 Kansas City

Description Evaluatio Max.
n evaluati
on
Function to check with SimuBox achieved Max

points points
IDENTIFY SENSOR AND FUNCTION BELOW
160
(I/O MUST
match print)
O0 5
O1 5
O2 5
O3 5
O4 5
O5 5
O6 5
O7 5
O8 5
O9 5
O10 5
O11 5
O12 5
013 5
O14 5
O15 5
I0 5
I1 5
I2 5
I3 5
I4 5
STOP
Have your table I5 5
inspected and I6 5
ititialed by a judge
I7 5
before proceeding!
I8 5
Make sure you have I9 5

filled out page 3 I10 5
identically to this
I11 5
page!
I12 5
Time: _____ I13 5
I14 5
Judge: _____
I15 5

Total
Description Evaluation Max.

evaluatio
n
Function to check with SimuBox achieved points Max

IDENTIFY SENSOR AND FUNCTION BELOW (I/O MUST match points
print) 160
O0 5
O1 5
O2 5
O3 5
O4 5
O5 5
O6 5
O7 5
O8 5
O9 5
O10 5
O11 5
O12 5
013 5
O14 5
O15 5
I0 5
I1 5
I2 5
I3 5
I4 5
I5 5
I6 5
I7 5
I8 5
I9 5
JUDGE I10 5
COPY I11 5
I12 5
Team: ___
I13 5
Time: _____ I14 5
Judge: _____
Page 3 of 7
Skills-USA Mechatronics Competition 2012 Kansas City
I15 5
Total

n evaluati
on
Function to check with plc program a chieved Max

points points
100
Preparation: Connect PLC to the I/O-

terminal of the station, prepare and
start the PLC
(r
r emove all workpieces from the
station)
Power up: Is RESET on? 5
Part ejector cylinder extended 5
Rotary arm to right 5
Vacuum off 5
Green “Start LED” on 5
Place 3 parts in magazine
Press Start
Green “Start LED” off 5
Cycle Begins 5
Check to see if part is available? 10
If no, Turn on lamp Q1 5
If no, Turn on LED in start 5
Otherwise: part ejector cylinder retracts 10

to eject part
Rotary arm to left
Vacuum on 5
Part gripped? 5
Part ejector cylinder extends
Swing arm to right 5
Vacuum off 10
No air flow (vacuum OR blow-off) at 10

suction cup
RETURN TO “Cycle Begins”
Total (100)
Page 5 of 7
n evaluati
on
Professional practice As a %-age of 100

build completion
(comments)
All components securely mounted in 20

correct position
50
Professional appearance (cable guides, 30
tie downs)
Correct tubing: (blue to extend

cylinders, black to retract)
Collisions or Pinch Points: -5 each.

n eval.
Time evaluation 40
Time points are only possible when

all points for function (with
SimuBox and with PLC) and minimum 4
points for professional practice are
achieved!
act. Time ____. ____min. Max time:

180 min.
Points for time = (max. time – act.time Max 40

)x max.points /(max.time – min.time) points
___.___
= (180.0 - .......) x 10 points / (180.0 points
- .......)
Total evaluation:
Description evaluation Max.
eval.
Points for Function with I/O box _____ 160
Points for Function to check with _____ 100

PLC board
Points for professional practice _____ 100
Points for time evaluation _____ 40

Total points _____ 400
Page 7 of 7
Task #2: Integrating a Pick and Place Station to
the Distribution Station for workpiece transfer
Points 500
t min fastest team
t max 180 min
Situation
Your task is to add a partially assembled pick and place
station so that a workpiece from the distribution station
will be placed on the stage and the pick and place station
will move the part from one stage to the other.
The task is fulfilled when the station is completely

assembled and commissioned according to the professional
practice agreement. The system has to fulfil the
specifications according to the evaluation sheet.
Collisions are not allowed and will be heavily penalized.
Task Description
Three pieces are placed in the stack magazine of the

Distribution station. The station will place the parts onto
the stage of the pick and place station. The pick and place
station will move each individual part from the outer stage
to the inner stage.
The operator will remove the part from the second stage.
The distribution station must wait for the pick and place
station to finish processing a part before another part can
be introduced.
When the stack is empty, Q1 on the front of the panel must

come on.
PLC program:
Initial situation:
A number (3) of workpieces are in the stack.

Max time: 150 min.
Team:

n evaluati
on
Function will be checked by judge achieved Max
IDENTIFY SENSOR AND FUNCTION BELOW points points
(I/O must 60
match print)
O 5
O 5
O 5
O 5
O 5
I 5
I 5
I 5
STOP I 5
Have your table
I 5
inspected and
initialed by a judge I 5
before proceeding! Total
Make sure you have

filed out page 3
identically to this
page!
Time: _____
Judge: _____
Page 3 of 6
n evaluati
on
Function will be checked by judge achieved Max

points points
IDENTIFY SENSOR AND FUNCTION BELOW
(I/O must 60
match print)
O 5
O 5
O 5
O 5
O 5
O 5
I 5
I 5
I 5
I 5
I 5
I 5
Total

n evaluati
on
Function to check with plc program achieved Max

points points
300
Part deposited at pick and place outer 20

JUDGE COPY platform
Distribution arm retracts 50

Team: _____
Gripper open 15
Time: _____ Cylinder out 15
Cylinder down 15
Judge: _____
Gripper closes 15
Part lifted 50
Cylinder retracts in 15
Cylinder down 15

Gripper opens 15
Cylinder up 15
MPS station starts next cycle 60
Totals

n as a evaluati
%-age of on
build
completi
on
Professional practice 90
comments)
All components securely mounted in 30

correct position
30
Professional appearance (cable guides, 30
tie downs)
Correct tubing: (blue to extend

cylinders, black to retract)
Collisions or Pinch Points: -5 each.

n eval.
Time evaluation
Time points are only possible when

all points for function (with
SimuBox and with plc) and minimum 4
points for professional practice are
achieved!
act. time ____. ____min. Max time:

180 min.
Points for time = (max. time – act.time Max 50

)x max.points /(max.time – min.time) points
___.___
= (180.0 - .......) x 10 points / (180.0 points
- .......)
Total evaluation:
Description evaluation Max.
eval.
Page 5 of 6
Points for Function with I/O box _____ 60
Points for Function to check with _____ 300

plc board
Points for professional practice _____ 90
Points for time evaluation _____ 50
Total points _____ 500
Expert evaluation team (names, signs):

Distribution station
Function chart
DE
01/04
Function chart according to DIN EN 60848
The following figure displays a comparison of symbols of DIN 40719-6 (1992-02) and
symbols of DIN EN 60848 (2002-12).
D delay t=3s 9
3s/X9 "delay"
Left: DIN 40719-6; right: DIN EN 60848
Note
The standard DIN 40719-6 is valid until 2005-04.
DIN 40719-6 Diagrams, charts, tables; rules for function charts;

1992-02 (IEC 848 modified)
DIN EN 60848 GRAFCET specification language for sequential function charts;

2002-12 (IEC 60848)
2 © Festo Didactic GmbH & Co. KG • MPS

Function chart Distribution station
sequential function chart according to DIN EN 60848 (IEC 60848) for the Distribution station
1-bit-link
1
Start
station is reset station is not reset

and in initial position
2
"reset" turn on "reset"
indicator indicator light
light
"reset" button pressed
3 move station
initial-
position to initial position
station in initial position
4
reset set flag "reset finished"
ok
C 16
flag "reset finished"is set
5
empty step:
cycle start
flag "start" is not set flag "start" is set

6
"start" turn on "start"
light
flag "start" is set
7
empty step:
downstream
station free
downstream station free

8
swivel arm swivel arm to position
to position
"downstream "downstream station"
station"
swivel arm to position "downstream station"

A9
© Festo Didactic GmbH & Co. KG • MPS 3

Function chart Distribution station
B 15 A 8
9
empty step:
magazine
status
workpiece in magazine and swivel arm no workpiece in magazine and swivel arm
in position "downstream station" in position "downstream station"
10
"magazine" turn on "magazine empty"
light
turn on "start" indicator light
workpiece in magazine and

error acknowledged
11
eject extend magazine slide
workpiece (retract ejecting cylinder)
workpiece ejected
12
swivel arm move swivel arm to position
to position "magazine"
"magazine"
swivel arm in position "magazine"

and downstream station free
13
workpiece turn on vacuum
picked up
retract magazine slide

(extend ejecting cylinder)
workpiece picked up and magazine slide retracted
and downstream station free
14
swivel arm move swivel arm to position
to position
"downstream "downstream station"
station"
swivel arm in position "downstream station"
15
drop off turn off vacuum
workpiece
no workpiece picked up no workpiece picked up

and manual mode and automatic mode
16 B9
cycle set flag "cycle end"
end
swivel arm to position

"magazine"
swivel arm in position "magazine"
C5
4 © Festo Didactic GmbH & Co. KG • MPS

Distribution station
Assembly
Instructions
EN
10/02
Intended use
This station has been developed and produced exclusively for vocational and further
training in the field of automation and communication. The training authority and/or
the instructors are to ensure that trainees observe the safety instructions described
in the manual provided.
Festo Didactic herewith rules out all liability for damage or injury to trainees, the
training authority or other third parties which may occur during the use/operation of
this equipment other than purely in a training situation, unless it can be proved that
Festo Didactic has caused such damage or injury through malicious intent or gross
negligence.
Description MONT.ANLEIT
Designation: D:MP-MA-S-VERT-1-GB
Status: 11/2002
Author: Frank Ebel
Graphics: Doris Schwarzenberger, Albert Sigel
Layout: 11/2002
© Festo Didactic GmbH & Co., D-73770 Denkendorf, 2002
Internet: www.festo.com/didactic
e-mail: did@festo.com
The copying, distribution and utilisation of this document, as well as the communication of its contents
to others without the express authorisation of Festo Didactic is prohibited. Offenders will be held liable
for the payment of damages. All rights reserved, in particular the right to carry out patent, utility model
or ornamental design registration
2 © Festo Didactic GmbH & Co. • Distribution station

Contents
1. Notes on safety ________________________________________________ 5
2. Short description ______________________________________________ 6
3. Views and tools ________________________________________________ 8

3.1 Views ________________________________________________________ 8
3.2 Tools_________________________________________________________ 9
4. Assembling the station_________________________________________ 10

4.1 Step 1 _______________________________________________________ 10
4.2 Step 2 _______________________________________________________ 11
4.3 Step 3 _______________________________________________________ 12
4.4 Step 4 _______________________________________________________ 13
4.5 Step 5 _______________________________________________________ 14
4.6 Step 6 _______________________________________________________ 15
4.7 Step 7 _______________________________________________________ 17
4.8 Step 8 _______________________________________________________ 18
4.9 Step 9 _______________________________________________________ 19
© Festo Didactic GmbH & Co. • Distribution station 3

Contents

1. Notes on safety
In the interests of your own safety, please observe the following safety instructions:
General
• Trainees must only work on a station under the supervision of an instructor.
• Observe the data in the data sheets for the individual components, particularly
all safety instructions!
Electrical
• Electrical connections are to be wired-up or disconnected only when the power
supply is turned off!
• Use only extra-low-voltages of up to max. 24 V DC.
Pneumatic
• Do not exceed the maximum permissible pressure of 8 bar (800 kPa).
• Do not switch on the compressed air supply until you have established and
secured all tubing connections.
• Do not disconnect air lines under pressure.
• Particular care is to be taken when switching on the compressed air supply.
Cylinders may advance or retract as the compressed air is switched on.
Mechanical
• Attach all components securely on the mounting plate.
• No manual intervention is to take place unless the machine is at rest.

2. Short description
View of the Distribution station
The Distribution station is a feed device. According to VDI 3240, feed devices are
defined as units which fulfill the function of bunkering, sorting and feeding of
components. In addition, feed devices can facilitate the sorting of components
according to various sorting characteristics (shape, weight etc. of the component).
The following are feed devices:

• Magazines with feed limiting,
• Vibratory bowl feeder,
• Inclined conveyors and
• Hoppers with sorting devices.
Workpieces handled by feed devices are

• Electroplated parts,
• Shaped parts made of plastic,
• Punched parts and
• Turned components.

Short description
The function fo the Distribution station is
• to separate out workpieces from a magazine and

• to transfer workpieces by means of a rotary drive using a suction cup.
The Distribution station consists of the following:
• Stack magazine module

• Changer module
• Profile plate
• Trolley
• Control console
• PLC board

3. Views and tools
3.1
Views
Distribution station, plan view
Distribution station, r.h. side view

Views and tools
Distribution station, front view
3.2 Tube spanner, 9 x 10 mm

Required tools
Open-ended spanners 6 x 7, 12 x 13, 22 x 24 mm
Slot-head screwdriver, 3.5 mm
Allen key, 5 mm

4. Assembling the station
4.1
Step 1
1 14. Nut
13.
12.
11.
10.
9.
8.
7.
6.
5.
4.
3.
2.
1.
1 Profile plate

Assembling the station
4.2
Step 2
2.1 (2x)
2.5
2.2 (4x)
2.3 (4x)
2.6 (2x)
2.7 (2x)
2.4 (4x) 2.8 (2x)
2.1 Cable duct
2.2 Socket-head screw M5 x 10
2.3 Washer B5.3
2.4 T-head nut M5-32
2.5 Mounting rail
2.6 Socket-head screw M5 x 10
2.7 Washer B5.3
2.8 T-head nut M5-32

4.3
Step 3
5. 2
3.
1.
2 Mounting the electrical system

4.4
Step 4
3
13.
12.
11.
9.
8.
7.
6. 8
6 (6x)
3 I/O terminal
4 Vacuum switch
5 CP valve terminal
6 Cable clip (6x)
7 Changer module
8 Service unit

4.5
Step 5
Position of Changer module and cable clips

4.6
Step 6
9.1 (2x)
9.10 (4x) 9.2 (4x)
9.9 (2x) 9.3
9.11 9.4 10.6 (2x)
9.5 (2x) 10.1
9.6
9.8 (2x)
10.7 (2x)
9.7 (2x)
10.8 (2x)
9.1 Socket head screw M 4 x 16 (2x)
9.2 Washer B 4.3 (4x)
9.3 Mounting bracket
9.4 Fibre optic device
9.5 Nut M 4 (2x)
9.6 Socket connector cable
9.7 T-head nut M 4-32 (2x)
9.9 Adapter(2x)
9.10 Nut M 5 (4x)
9.11 Fibre optic cable “Light barrier”

10.1 Socket connector cable
10.2 StationLink receiver
10.3 Mounting bracket
10.4 Washer B 4.3 (4x)
10.7 T-head nut M 4-32 (2x)
10.8 Nut M 4 (2x)

4.7
Step 7
12
13 12.
8.
7.
6.
6.
11 (2x)
2.
10
9 Fibre optic device
10 StationLink receiver
11 Connector (2x)
12 Stack magazine module
13 Cable clip

4.8
Step 8
14
Complete assembling of Stack magazine module and cable clips
14 Fibre optic cable “Light barrier”

4.9
Step 9
Station completely assembled


0 2 4 5 7 9
Diese Zeichnung ist Eigentum der Festo Didactic GmbH & Co. KG
Schaltungsunterlagen / Circuit diagrams
System MPS-C
MPS R Station Verteilen
MPS R Distributing station
<< 2 >>
†‡ MPS-C Verteilen/Distributing
Date 22.03.06 Festo Didactic GmbH & Co. KG
Konstr. MBEL Rechbergstraße 3 Titelblatt
Certif. D-73770 Denkendorf DPJ VN = Pg. 1
Title page STATION
Drw-No 195780 el. R.: FDMR02E F.: R:\EPLAN4 \P\FESTO\_MPS\STATION\01_VE_DI .P + last: 5
0 2 4 5 7 9
Inhaltsverzeichnis / Index page

Anlage / Station Seite / Page Seitenbenennung Page description Datum / Date Bearbeiter X
1 Titelblatt Title page 22.03.06 MBEL

2 Inhaltsverzeichnis Index page 05.04.06 FAA
3 Aufbauplan Layout 28.02.06 MBEL
4 Station Eingänge Station inputs 05.04.06 MBEL
5 Station Ausgänge Station outputs 05.04.06 MBEL
FD01MPS 05/2005
01_VE_DI
FESTO\_MPS\STATION
<< 1 3 >>
Konstr. FAA Rechbergstraße 3 Inhaltsverzeichnis
Index page STATION
Drw-No 195780 el. R.: FDMR02E F.: FD01MP S R:\EPLAN4 \P\FESTO\_MPS\STATION\01_VE_DI .P + last: 5
0 2 4 5 7 9
2M2 2M1
1M1
3M2 3M1 14
2B1
-XMA2
12
E M N
IP_ FI
XMA2 = Syslink Station / station

XMG1 = Syslink Bedienpanel / control console
<< 2 4 >>
Konstr. MBEL Rechbergstraße 3 Aufbauplan
Layout STATION
0 2 4 5 7 9
24VB_EXT
XMA2 21 22
XA2 24VB 24V B 24VB 24VB 24VB 24VB 24VB 24VB
24V 24V 24V 24V 24V

BN BN BN BN BN
1B2 1B1 2B1 B4 A IP_FI

3 3
A A A BK A
P1
3B1 3B2
BK BK
p1=p2 BK
4 4
BK
WH
P2
BU BU BU BU BU
0V 0V 0V 0V Empfänger 0V
XA2 0VB I0 0VB I1 0VB I2 0VB I3 0VB I4 0VB I5 0V B I6 0VB I7
XMA2 13 14 15 16 17 18 19 20
XMA2 23 24
0VB_EXT
Spannung- Ausschiebezylinder Ausschiebezylinder Werkstück Schwenkzylinder in Schwenkzylinder in Magazin leer Folgestation

versorgung ausgefahren eingefahren angesaugt Position Magazin Position Folgestation frei
Power Ejecting cylinder Ejecting cylinder Workpiece Swivel drive in Swivel drive in Magazine empty Downstream station
supply extended retracted gripped magazine position downstream station pos. free
<< 3 5 >>
Konstr. MBEL Rechbergstraße 3 Station Eingänge
Station inputs STATION
0 2 4 5 7 9
24VA_EXT
XMA2 9 10
XMA2 1 2 3 4 5 6 7 8
XA2 24VA 24VA XA2 O0 O1 O2 O3 O4 O5 O6 O7 24VA 24VA

Ventilinsel valve terminal
+ + + + +
1M1 2M1 2M2 3M1 3M2

- M - - E - - N
XA2 0VA 0VA 0VA 0VA 0VA 0VA 0VA 0VA 0VA 0VA 0VA 0VA
XMA2 11 12
0VA_EXT
Spannung- Ausschiebezylinder Vakuum ein Abwurfimpuls Schwenkzylinder Schwenkzylinder zu

versorgung Werkstück ausschieben ein zu Magazin Folgestation
Power Ejecting cylinder Vacuum on Ejection impulse Swivel drive Swivel drive to
supply push out workpiece on to magazine downstream station
<< 4 >>
Konstr. MBEL Rechbergstraße 3 Station Ausgänge
Station outputs STATION
522222222222222222222222222
&! %:89<
+%&%19= '&%
.
%)$&#'%&! /&$& %!%&%-- &>8F"!)$,
.
'&! 1$('+0$( '+$(
394 9?:= !&!$

394 ;8.9'&! $!*
3<4</= '+%
3<4;/8 '+%
3>4=0@ &%
3<4E 1&%
3:4;8!!& &$$%
G222222222222222222222:="&%222222222
G222222222222222222222:="&%222222222
G222222222222222222222:="&%222222222
?=222222222

.---------------------
$ #1/02
(#$#,03 %$#
*
%"$$$#) $#)!#) # $ $ "$/2/+
*
501/&
$"
!!
"'"&"
------------/-------------
54+3!$#-----
50/!$#-----
50/!$#-----
50/!$#-----
-----------2/--------------
54+3!$#-----
50/!$#-----
50/!$#-----
50/!$#-----
43------------

100000000000000000000
&"!%5347
"&"$"!&$"%*$%/63 !'&%
-
'57("!&$"%+%& &"$'!443( "&"$.%& !' ""!&6#"%&"!%&"$%)&

&""#$&&$'&.!&"#$%%& " !&$+$!#'%'&&"!&""#$&& "&"$
!(&$!&"!)$'!!!.!'& $!+%&"#!&!!!"&$'&.
)$!% &&"%")+"'$)"$"$!+)"$!%.
-
$-57(:;,57(/;,443("&;',443(/;&
443(&$ !&"!%-')$$" 4/4&"4; 4
')$$" 4/4&"9/7
&)$$" 4/7&"9/8
57("!&&"$
&$ %
$)$($
$%&$##$%
- $&!&(," "!,"$$"'!.
$! &;83#&%0000000000
"$;83#&%0000000000
4330000000000000000

21111111111111111111
'#" &6458
#'#%#"'%# &+%&074 "('&
.
( 68)#"'%# &,&'!'#%("554)!#'#%/&'&" $(&(''#"'#&'%''!#'#%

*'' "'#% '#"'#&#*'!#'#%&%("""/%&&'&" $(&(''#"'#
&'#$'!#'#%")'"'#%#"'#&#*!#'#%&#/&' "'#% ''#
&#*'!#'#%&%("""#%%,'#%("/ " ('!%",'#$"'"""#'%('/
*%"&!''#&#*,#(%%('#%",*#%"&/
.
%&.68);<-68)0< -554)#'< (-554)#!!#"<'
554)'%!"'#"&. (*%%#!505'#50 5
(*%%#!505'#:08
'*%%#!508'#:09
68)#"''#%
'% &
%*%)%
%&'%$$%&
. %'"')-#!!#"-#%%#("/
%"!'<94$'&1111111111
#%<94$'&1111111111
5441111111111111111

0 2 4 5 7 9
Schaltungsunterlagen / Circuit diagrams
R
System MPS -C
Bedienpult
Control console
<< 2 >>
†‡ MPS-C Bedienpult/Control console

Konstr. MBEL Rechbergstraße 3 Titelblatt
Title page
Drw-No R.: FDMR02E F.: R:\EPLAN4 \P\FESTO\_MPS\BEDIENEN\PULT.P + last: 6
0 2 4 5 7 9
Inhaltsverzeichnis / Index page

Anlage / Station Seite / Page Seitenbenennung Page description Datum / Date Bearbeiter X
1 Titelblatt Title page 05.04.06 MBEL

2 Inhaltsverzeichnis Index page 05.04.06 MBL
3 Aufbauplan Layout 05.04.06 MBEL
4 Eingänge Inputs 05.04.06 MBEL
5 Ausgänge Outputs 05.04.06 MBEL
6 Weitere Steckverbinder Additional connectors 05.04.06 MBEL
FD01MPS 05/2005
PULT
FESTO\_MPS\BEDIENEN
<< 1 3 >>

Konstr. MBL Rechbergstraße 3 Inhaltsverzeichnis
Index page
Drw-No R.: FDMR02E F.: FD01MP S R:\EPLAN4 \P\FESTO\_MPS\BEDIENEN\PULT.P + last: 6
0 2 4 5 7 9
+H1
FESTO
I4 Q6
I5 Q7
Start Stop
Q4 I6
Q5 I7
Reset Auto/Man
GND GND
Q1 Q2
I/O I/O
links rechts
left Vorderseite / front view right
24
24
20
19
37
12
12
1
-XMG1
-X4
-X3
-X2
13
13
1
1 1
-X5 -X8
20
19
37
-X2R -X2L
1
1 5 5 1
1 -X6 1
18
rechts 1 -X7 18 links

right left
Rückseite / rear view -XMG1=Syslink Bedienpult / Control console
<< 2 4 >>

Konstr. MBEL Rechbergstraße 3 Aufbauplan
Layout
0 2 4 5 7 9
24V /5.0
0V(24V) /5.0
NOTAUS Signal von SPS bei

Verwendung mit MPS-C
EMG.STOP from PLC if

used with MPS-C
-XN8 1 2 3 4 5
-X8 1 2 3 4 5
I6 Q6
I4 I5 GND Q4 Q5 I7 GND Q7
3 1 3 3 -XL -XR
S1 S2 S3 S4
4 2 4 4
Syslink Phoenix2 -XL 1 2 3 4 5 -XR 1 2 3 4 5
-XMG1 -X7
E0/I0
13 1 -X2L 1 2 3 4 5 -X2R 1 2 3 4 5
14 2
15 3
16 4 ge gr ws br gn ge gr ws br gn
YE GY WH BN GN YE GY WH BN GN
17 5
18 6
19 7
E7/I7
20 8
21
22
23
24
A0/Q0
1 9
2 10
3 11
4 12
5 13
6 14
7 15
A7/Q7
8 16
9
10
11
12
17
18
Zusatz E/As Frontplatte links Zusatz E/As Frontplatte rechts
Additional I/Os Frontplate left Additional I/Os Frontplate right
Spannungsversorgung Taster Taster STOP Schalter Taster Externer NOTAUS Externer Externer
START (Öffner) AUTO/MAN RICHTEN Eingang E4 extern E5 Eingang E6 Eingang E7
Power supply START STOP button Key switch RESET External EMG STOP External External
button (norm. closed) AUTO/MAN button input I4 ext. I5 input I6 input I7
<< 3 5 >>

Konstr. MBEL Rechbergstraße 3 Eingänge
Inputs
0 2 4 5 7 9
4.9/ 24V 24V /6.0

4.9/ 0V(24V) 0V(24V) /6.0
I6 Q6
I4 I5 GND Q4 Q5 I7 GND Q7
-XL -XR
Syslink Phoenix2 -XL 1 2 3 4 5 -XR 1 2 3 4 5

-XMG1 -X7
E0/I0
13 1 -X2L 1 2 3 4 5 -X2R 1 2 3 4 5
14 2
15 3
16 4 ge gr ws br gn ge gr ws br gn
YE GY WH BN GN YE GY WH BN GN
17 5
18 6
19 7
E7/I7
20 8
21
22
23
24
A0/Q0
1 9
2 10
3 11
4 12
5 13
6 14
7 15
A7/Q7
8 16
9 X1 X1 X1 X1
10 P1 P2 P3 P4
11 X2 X2 X2 X2
12
17
18
Zusatz E/As Frontplatte links Zusatz E/As Frontplatte rechts
Additional I/Os Frontplate left Additional I/Os Frontplate right
Leuchtmelder Leuchtm. Leuchtm. Leuchtm. Externer Externer Externer Externer

START RESET Sonderf. Q1 Sonderf. Q2 Ausgang A4 Ausgang A5 Ausgang A6 Ausgang A7
START RESET Q1 special Q2 special External External External External

indicator light ind. light ind.light ind.light output Q4 output Q5 output Q6 output Q7
<< 4 6 >>

Konstr. MBEL Rechbergstraße 3 Ausgänge
Outputs
0 2 4 5 7 9
5.9/ 24V 24V

5.9/ 0V(24V) 0V(24V)
Syslink Phoenix2 Syslink Phoenix1

-XMG1 -X7 -X2 -X6
E0/I0 E10/I10
13 1 13 1
14 2 14 2
15 3 15 3
16 4 16 4
17 5 17 5
18 6 18 6
19 7 19 7
E7/I7 E17/I17
20 8 20 8
21 21
22 22
23 23
24 24
A0/Q0 A10/Q10
1 9 1 9
2 10 2 10
3 11 3 11
4 12 4 12
5 13 5 13
6 14 6 14
7 15 7 15
A7/Q7 A17/Q17
8 16 8 16
9 9
10 10
11 11
12 12
17
17 18
18
-X3 19 37 1 20
5 4 3 2 21 22 23 24 10 11 12 13 14 15 16 17 18 29 30 31 31 32 32 34 35 36 9 8 7 6 25 26 27 28
37pin D-SUB Stecker / male = alle Eingänge / all inputs
-X5
1
NOTAUS
-X4
EMG.STOP 2 19 37 1 20
5 4 3 2 21 22 23 24 10 11 12 13 14 15 16 17 18 29 30 31 31 32 32 34 35 36 9 8 7 6 25 26 27 28
37pin D-SUB Buchse / female = alle Ausgänge / all outputs
<< 5 >>

Konstr. MBEL Rechbergstraße 3 Weitere Steckverbinder
Additional connectors
1 2 3 4 5 6 7 8
-1A1 -2A1 -3A1

-1B1 -1B2 -3S1 -3S2
A A
-2B1
B -1V2 -1V3 -2V2 -2V3 -2Z1 -3V2 -3V3 B
C C
-0V1
-1V1 4 2 -2V1 4 2 -3V1 4 2
X M E N
D D
112 14 112
10 110
14 14 112 10 110
-1M1 -2M1 -2M2 -3M1 -3M2
82/84 82/84 82/84 82/84 82/84
12/14 12/14 12/14 12/14 12/14
3/5 3/5 3/5 3/5 3/5
E 11 11 11 11 11 E
1 1 1 1 1
AUSSCHIEBEZYLINDER VAKUUM GREIFER SCHWENKZYLINDER

-3S1: POSITION MAGAZIN -3S2: POSITION FOLGESTATION
EJECTING CYLINDER VACUUM SUCTION CUP SWIVEL DRIVE
F -3S1: POSITION MAGAZINE -3S2: POSITION DOWNSTR. STATION F
Datum 11.04.05 MPS-C Station Verteilen Pneumatik
Bearb. MBEL Distributing Station Pneumatic
Festo Didactic GmbH & Co.
Gepr. --- Rechbergstr. 3 / D-73770 Denkendorf BLATT
Aenderung Datum Name Norm DIN5 Urspr keiner Ers.f. Ers.d. FOLGE
1 2 3 4 5 6 7 8

Mechatronics

Uploaded by

Document Information

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Mechatronics

Uploaded by

Copyright:

Available Formats

SkillsUSA

2014 Contest Projects

t min fastest team

t max 180 min

The task is fulfilled when the station is completely

Different workpieces (red, silver or black) are manually

The parts are ejected from the magazine, picked up by the

The cycle continues until the stack is empty, at which

It is necessary to reload the stack magazine and press the

On power up, LED in reset button is “on”

If successful, LED in reset button goes “off” and green

Place 3 parts in magazine

Page 1 of 7 Skills-USA Mechatronics Competition 2012 Kansas City

Function to check with SimuBox achieved Max

Make sure you have I9 5

Page 2 of 7 Skills-USA Mechatronics Competition 2012 Kansas City

Description Evaluation Max.

Function to check with SimuBox achieved points Max

Time: _____ I14 5

Page 4 of 7 Skills-USA Mechatronics Competition 2012 Kansas City

Function to check with plc program a chieved Max

Preparation: Connect PLC to the I/O-

Power up: Is RESET on? 5

Part ejector cylinder extended 5

Rotary arm to right 5

Green “Start LED” on 5

Place 3 parts in magazine

Green “Start LED” off 5

Check to see if part is available? 10

If no, Turn on lamp Q1 5

If no, Turn on LED in start 5

Otherwise: part ejector cylinder retracts 10

Rotary arm to left

Part ejector cylinder extends

Swing arm to right 5

No air flow (vacuum OR blow-off) at 10

RETURN TO “Cycle Begins”

Professional practice As a %-age of 100

All components securely mounted in 20

Correct tubing: (blue to extend

Collisions or Pinch Points: -5 each.

Description Evaluatio Max.

Time points are only possible when

act. Time ____. ____min. Max time:

Points for time = (max. time – act.time Max 40

Points for Function with I/O box _____ 160

Points for Function to check with _____ 100

Points for professional practice _____ 100

Points for time evaluation _____ 40

Page 6 of 7 Skills-USA Mechatronics Competition 2012 Kansas City

t min fastest team

t max 180 min

The task is fulfilled when the station is completely

Collisions are not allowed and will be heavily penalized.

Three pieces are placed in the stack magazine of the

When the stack is empty, Q1 on the front of the panel must

Page 1 of 6 Skills-USA Mechatronics Competition 2012 Kansas City

Description Evaluatio Max.

Function will be checked by judge achieved Max

IDENTIFY SENSOR AND FUNCTION BELOW points points

Make sure you have

Function will be checked by judge achieved Max

Description Evaluatio Max.

Function to check with plc program achieved Max

act. Time . min. Max time:

act. time . min. Max time:
