PROJECT PHASES:
(The 1977 National Building Code of the Philippines/ Revised IRR NBCP)
SCOPE OF APPLICATION
▪ The National Building Code (NBC) applies to the design, location, siting, construction,
alteration, repair, conversion, use, occupancy, maintenance, moving, demolition of and addition
to public and private buildings, except traditional dwellings and BP 220 projects.
Definition of terms
Construction
All on-site work done from site preparation, excavation, foundation, assembly of all the
components and installation of utilities and equipment of buildings/structure
Addition
Any new construction which increases the height or area of an existing building/structure
Alteration
Construction in a building/ structure involving changes in the materials used, partitioning,
location/ size of openings, structural parts, existing utilities and equipment but does not increase
the overall area thereof.
Renovation
Any physical change made on a building/ structure to increase its value, utility and/ or to
improve its aesthetic quality
Conversion
A change in the use or occupancy of a building/ structure or any portion/s thereof which has
different requirements
Repair
Remedial work done on any damaged or deteriorated portion/s of a building/structure to restore
its original condition
Demolition
The systematic dismantling or destruction of a building/ structure, in whole or in part
Ancillary building/structure
A secondary building/ structure located within the same premises, the use of which is incidental
to that of the main building/structure
RULE 2
Administration + Enforcement
THE SECRETARY
▪ Secretary of the DPWH
▪ Duties include:
▪ Policy making
▪ Memorandum circulars
▪ Prescription of fees
▪ Appointment of building officials in all municipalities
THE BUILDING OFFICIAL
▪ Tasked with the enforcement of the Code in his
jurisdiction
▪ Issues, denies, suspends and revokes permits
▪ Undertakes inspection of buildings
▪ Acts on claims
FEES
▪ The DPWH Secretary prescribes the fees
▪ The Building Official collects the fees
FEE EXEMPTIONS
▪ Public buildings
▪ Traditional family dwellings
▪ A dwelling intended for the use by one family and
constructed of native materials (bamboo, nipa, logs,
lumber), the total cost of which does not exceed
PHP15,000.
PROHIBITED ACTS
▪ Proceeding with work without a permit
▪ Unauthorized deviations from the drawings during
construction
▪ Non-compliance with work stoppage order
▪ Non-compliance with order to demolish
Use of a building without securing a Certificate of
Occupancy
▪ Change in use without the corresponding
Certification of Change of Use
▪ Failure to post Cert. of Occupancy
▪ Change in type of construction without permit
DANGEROUS BUILDINGS
▪ Structural hazard
▪ Fire hazard
▪ Unsafe electrical wiring
▪ Unsafe mechanical installation
▪ Inadequate sanitation and health facilities
▪ Architectural deficiency
OPTIONS FOR DANGEROUS BLDGS
▪ Repair
▪ Vacation
▪ Demolition
RULE 3
Permits
BUILDING PERMIT
▪ A written authorization granted by the Building Official to an applicant allowing him to
proceed with construction after plans, specifications and other pertinent documents have been
found to be in conformity with the Code
WHEN IS A PERMIT REQUIRED?
▪ Before constructing, altering, repairing, converting, moving, adding to, demolishing a building.
BUILDING PERMIT EXEMPTIONS
▪ Minor constructions
▪ Repair works
MINOR CONSTRUCTION
▪ Minor structures 6sqm. or less detached fromother buildings, for private use only.
(Example:sheds, poultry houses, greenhouses)
▪ Open terraces or patios not exceeding 20sqm.
MINOR CONSTRUCTION
▪ Window grilles
▪ Garden pools 500mm deep or shallower
▪ Garden masonry walls not exceeding 1.20m in height
REPAIRS
▪ Not involving structural members
▪ Of non-load bearing partition walls
▪ Not involving addition or alteration
▪ Of doors, windows, floors, fences and walls
▪ Of plumbing fixtures
PERMIT REQUIREMENTS
▪ Application forms
▪ If lot is owned,
▪ OCT or TCT
▪ Tax declaration
▪ Current real property tax receipt
PERMIT REQUIREMENTS
▪ If lot is NOT owned,
▪ Contract of Lease or Deed of Absolute Sale in place of
TCT
▪ Five sets of plans and specs, signed and sealed
by various professionals
ISSUANCE OF PERMITS
▪ 15 days from payment of fees
LIABILITY CLAUSE
▪ Article 1723 of the Civil Code states that the engineer or architect who drew up the plans and
specifications is liable for 15 years from completion of the building should it collapse due to
defects in the plans or the ground.
In case the building collapses due to defects in construction or the use of inferior materials, the
contractor, along with the construction supervisor, shall be liable.
EXPIRATION OF PERMITS
▪ Construction does not commence within 1 year from date of issue
▪ Construction does not resume 120 days after suspension or abandonment of work
NON-ISSUANCE, SUSPENSION,
REVOCATION
▪ Errors in plans and specs
▪ Incorrect or inaccurate data declared
▪ Non-compliance with the Code
INSPECTION + SUPERVISION
▪ The owner of the building must engage the services of a licensed architect or civil engineer to
undertake the full-time inspection and supervision of the construction.
RULE 4
Types of Construction
TYPE I
▪ Wood construction
TYPE II
▪ Wood construction with fire-resistant materials
▪ One-hour fire-resistive throughout
TYPE III
▪ Masonry and wood construction
▪ One hour fire resistive throughout
▪ Incombustible exterior walls
TYPE IV
▪ Steel, iron, concrete, or masonry construction
▪ Incombustible interiors (ceilings, walls)
TYPE V
▪ Four-hour fire resistive throughout
▪ Structural elements of steel, iron, concrete or
masonry
RULE 5
Fire Zones
FIRE ZONE
▪ An area within which only certain types of construction are allowed, based on their occupancy,
type of construction, and resistance to fire
FIRE ZONE DESIGNATIONS
1. Non-fire restricted zones
▪ All types of construction allowed
2. Fire restrictive zones
▪ Type I construction NOT allowed
3. Highly fire restrictive zones
▪ Types I, II, and III NOT allowed
BUILDINGS IN MULTIPLE FIRE ZONES
▪ Shall be considered as part of the more restrictive zone if more than 1/3 of its total floor area is
in that zone
RULE 6
Fire Resistive Requirements
FIRE RESISTIVE RATING
▪ The degree to which a material can withstand fire
▪ Usually expressed in the form of a time period rating (how long a material can
withstand being burned)
FIRE RESISTIVE STANDARDS
RULE 7
Occupancies + Zones + Requirements
OCCUPANCY VERSUS ZONING
▪ Occupancies are assigned to buildings, whilezones are assigned to lands.
OCCUPANCIES
▪ A – Residential dwellings
▪ B – Residentials, hotels, apartments
▪ C – Education and recreation
▪ D – Institutional
▪ E – Business and mercantile
▪ F – Industrial
▪ G – Storage and hazardous
▪ H – Assembly other than Group I
▪ I – Assembly with 1,000 or more occupant load
▪ J - Accessory
ZONING
▪ R –Residential
▪ C – Commercial
▪ GI – General institutional
▪ I – Industrial
▪ UTS – Utilities, Transportation, Services
▪ SPE - Special
▪ PRE - Park structures, recreation, entertainment
▪ CUL – Cultural
▪ A – Agricultural
▪ AI – Agroindustrial
▪ PUD – Planned unit development
A: RESIDENTIAL DWELLINGS
▪ A-1: Residential building for single family
occupants
▪ A-2: Residential building for non-leasing
occupants not exceeding 10 persons
B: RESIDENTIALS, HOTELS, APARTMENTS
▪ Multiple dwelling units including boarding or lodging houses, hotels, apartment buildings,
rowhouses, convents, monasteries and other similar building each of which accommodates more
than 10 persons.
C: EDUCATION + RECREATION
▪ Buildings used for school or day-care purposes not classified in Group H or I occupancies
D: INSTITUTIONAL
▪ D-1: Institutions where personal liberties are restrained (mental hospitals, jails)
▪ D-2: Institutions for the care of non-ambulatory patients and children under kindergarten age
▪ D-3: Institutions for ambulatory patients and homes for children over kindergarten age
E : BUSINESS + MERCANTILE
▪ E-1: No work is done except exchange of parts,maintenance without open flame, welding, or
highly flammable liquids (gasoline filling station, storage garage)
▪ E-2: Wholesale and retail stores, office buildings, dining establishments
▪ E-3: Aircraft hangars and open parking garages (no repair work)
F: LIGHT INDUSTRIAL
▪ Light industrial
▪ Ice plants, power plants, pumping plants, cold
storage, factories and workshops using
incombustible and non-explosive materials
G: STORAGE + HAZARDOUS
▪ G-1: Medium industrial, storage of highly flammable materials
▪ G-2: Medium industrial, storage of flammable materials: dry cleaning plants, paint stores,
spraypainting rooms
▪ G-3: Medium industrial structures where loose combustible fibers are generated: wood working
establishments
▪ G-4: Medium industrial for repair garages and engine manufacturing
▪ G-5: Medium industrial for aircraft repair
H: ASSEMBLY FOR LESS THAN 1,000
▪ H1: Assembly buildings with stage for less than 1,000
▪ H2: Assembly buildings without stage for 300 or more
▪ H3: Assembly buildings without stage for less than 300
▪ H4: Recreational/tourism developments not
included in other H classifications (stadiums,
reviewing stands, and amusement parks)
I: ASSEMBLY FOR 1,000 OR MORE
▪ Any assembly building with a stage and an occupant load of 1,000 or more
J: ACCESSORY
▪ J1: Agricultural structures
▪ J2: Carports/garages, fences, towers and pools
▪ J3: Stages, courts, tombs, mausoleums, zoos, and
banks
Zones
R1
▪ Low-density residential zone
▪ Characterized by single-family and single detached dwellings
R2
▪ Medium-density residential zone
▪ Characterized by low-rise single-attached, duplex, or multilevel buildings for use as multiple
family dwellings
▪ Further subclassified into:
▪ Basic R2
▪ Single attached or duplex, 1-3 floors
▪ Maximum R2
▪ Low-rise multi-level building, 3-5 floors
R3
▪ High-density residential zone
▪ Characterized low-rise or medium-rise buildings for use as multiple family dwellings
▪ Includes low-rise or medium-rise condominium buildings
▪ Further subclassified into:
▪ Basic R3
▪ Rowhouses 1-3 storeys high
▪ Maximum R3
▪ Medium-rise multilevel structure 6-12 storeys high
R4
▪ Medium to high-density residential zone
▪ Characterized by low-rise townhouses or buildings for use as multiple family dwellings
▪ Refers to structures on an individual lot (“townhouse”)
R5
▪ Very high density residential zone
▪ Characterized by medium-rise to high-rise condominiums
C1
▪ Light commercial
▪ Neighborhood to community in scale
▪ Low-rise buildings (1-3 storeys)
▪ Low-intensity trade/activity
▪ Example: Small shopping centers
C2
▪ Medium commercial
▪ City or municipal in scale
▪ Medium-rise buildings (3-5 storeys)
▪ Medium to high intensity trade
▪ Example: Shopping centers
C3
▪ Metropolitan commercial
▪ Metropolitan in scale
▪ Medium to high-rise buildings (3-5 storeys)
▪ Very high intensity trade
▪ Example: Large to very large shopping malls
GI
▪ General institutional
▪ Community to national level of institutional use.
Low-rise to high-rise.
▪ Two types:
▪ Education/Recreation
▪ Medical/Government
I-1 (INDUSTRIAL)
▪ Light industrial use
▪ Low-rise but sprawling
▪ Low-intensity manufacturing
I-2 (INDUSTRIAL)
▪ Medium industrial use
▪ Low-rise but sprawling
▪ Medium-intensity manufacturing
UTS (UTILITIES, TRANSPO, SERVICES)
▪ Utilitarian, functional uses
▪ Low-rise to medium rise
▪ Low to high-intensity community support
functions
▪ Two clusters:
▪ Transport terminals, intermodals, depots
▪ Power/water generation/distribution, telcos, waste
management facilities
SPE (SPECIAL)
▪ Other vertical facilities not yet mentioned
▪ Included cemeteries and memorial parks
PRE (PARKS, RECREATION,
ENTERTAINMENT)
▪ Low-rise to medium rise
▪ Low to medium intensity recreational functions related to educational uses (parks on campus,
other recreational/assembly structures on campus)
CUL (CULTURAL)
▪ Community to national level of use or occupancy
▪ Low-rise to medium rise
(AGRICULTURAL)
▪ Low to medium rise
▪ Low to high intensity agricultural activity
▪ Includes farms, but also offices and facilities for
agricultural research and training
AI (AGROINDUSTRIAL)
▪ Low rise
▪ Low to high intensity agroindustrial activity
▪ Includes offices and facilities for agroindustrial
education and research
PUD (PLANNED UNIT DEVELOPMENT)
▪ Land development or redevelopment schemes for
a new project which has a CDMP (Comprehensive
Development Masterplan) or equivalent
▪ Example: Bonifacio Global City
MIXED OCCUPANCIES
▪ Rule of thumb: The building adheres to the stricter
requirements.
▪ Exceptions:
▪ If it’s a one-storey building, in which case each portion
shall conform to applicable rules
▪ If the minor occupancy does not exceed 10% of the
building, in which case it is ignored
Location on
property
RIGHT OF WAY
▪ No building shall be constructed unless it adjoins or has direct access to a public space, yard,
or street on at least one of its sides.
EAVES OVER WINDOWS
▪ Eaves over required windows shall at least be 750mm from the side and rear property lines.
FIREWALLS
▪ A fireproof barrier used to prevent the spread of fire between or through buildings
▪ Why are firewalls important? Because when they are built, the building or part of the building
extends into the setbacks.
ALLOWABLE FIREWALLS
▪ R1: Not allowed
▪ However, an abutment up to 3.20m high is OK for carports provided that above 1.50m, the
abutment shall be constructed of perforated concrete blocks.
Development
controls
TERMS DEFINED
▪ TLA = Total lot area
▪ PSO = Percentage of site occupancy
▪ The part of the lot occupied by the building (A.K.A.
building footprint expressed in %)
▪ TOSL = Total open space within lot
▪ The part of the lot NOT occupied by the building
▪ TLA = PSO + TOSL
▪ USA = Unpaved surface area
▪ The portion of the open space that is unpaved
▪ ISA = Impervious surface area
▪ The portion of the open space that is paved
▪ Since “open space” = TOSL,
▪ TOSL = USA + ISA
▪ MACA = PSO + ISA
▪ Hence, TLA = MACA + USA
▪ Note: MACA stands for Maximum Allowable Construction Area
▪ AMBF = Allowable max. building footprint
▪ Footprint expressed in square meters
▪ GFA = Gross floor area
▪ Total enclosed floor area (including balconies)
▪ Excludes the following enclosed areas:
▪ Parking, services, utilities
▪ Vertical penetrations in parking floors if not used for residential or
commercial purposes
▪ Balconies exceeding 10sqm, uncovered areas, fire escape
structures, etc.
▪ TGFA = Total gross floor area
▪ Includes all enclosed floor areas, no exceptions
▪ AMVB = Allowable max. volume of building
▪ OFB = Outer faces of the building
▪ FLAR = Floor and lot area ratio
BUILDING BULK
▪ A volume quantity
▪ In the simplest sense,
▪ Building bulk = Footprint x Height
▪ However, the Code prescribes several different
methods for determining this quantity
METHOD 1: AMBF PROJECTION
▪ Determine the AMBF
▪ Determine the BHL (in meters)
▪ AMBF x BHL = Building bulk
METHOD 2: FLAR
▪ FLAR : Floor to lot area ratio
▪ Total floor area / lot area
▪ For example, a FLAR designation of 1.50 means that a
lot measuring 100sqm may accommodate a building
whose total floor area is 150sqm.
▪ In a way, FLAR tells us how many lots can fit inside the
building.
METHOD 2: FLAR
▪ Building bulk = Footprint x Height
▪ To get footprint:
▪ FLAR x TLA = Total floor area
▪ Total floor area/Number of storeys = Footprint
▪ Hence, building bulk is equal to:
▪ [(FLAR x TLA)/number of storeys] x BHL
METHOD 3: AMVB
1. AMBF x BHL = initial AMVB (“prism”)
2. Superimpose the angular plane originating from
the RROW onto the “prism”
▪ Angular plane: a plane originating from the RROW that
establishes the outer limit for walls and building
projections.
3. Use the angular plane to reduce the volume of
the prism. This is the AMVB.
OTHER FORMULAS
▪ PSO = AMBF / TLA
▪ GFA = TLA x FLAR
▪ TGFA = GFA + Non-GFA
RULE 8
Light + Ventilation
INTENT
▪ Every building shall be designed, constructed, and equipped to provide adequate
light and ventilation.
VARIABLES
▪ Setbacks
▪ Site occupancy
▪ Room sizes
▪ Ceiling heights
▪ Window sizes
▪ Courts
MEASUREMENT OF SITE
OCCUPANCY
▪ Taken at ground level and exclusive of courts,
yards, and light wells.
PSO, TOSL, USA, ISA
▪ TLA = PSO + TOSL
▪ TOSL = USA + ISA
▪ USA = minimum value
▪ ISA = maximum value
▪ These values are given in Table VII.1 on p.131
LOT TYPES
▪ The Code defines seven lot types
▪ Inside lot
▪ Interior lot
▪ Corner lot
▪ Through lot
▪ Corner through lot
▪ Corner through lot abutting 3 or more streets
▪ End lot
YARD VERSUS SETBACK
▪ Yard: the required open space left between the
outermost face of the building and the property
lines
▪ Setback: the width of the yard
COURTS
▪ Minimum dimension: 2.00m
▪ Hence, minimum area: 4.00sqm
▪ All inner courts shall be connected to a street or
yard by a passageway at least 1.20m wide
JOINING OF COURTS
▪ Minimum dimension may be reduced to 1.50m in
cluster living units with adjacent courts
▪ Minimum area per court: 3.00sqm
▪ Separation wall: 2.00m high maximum
PARKING SPACES AND CARPORTS
▪ If a carport is roofed, it will be considered part of
the building footprint and not the TOSL
FRONT YARDS AS PARKING
▪ Only allowed for single family dwelling units falling
under the following zoning classifications:
▪ Basic R-2
▪ Basic R-3
▪ R-4
FIREWALL EXTENSIONS
▪ Above the roof line: 400mm
▪ Under the eaves: 300mm
▪ From the building edges: 600mm
MINIMUM CEILING HEIGHTS
AIR SPACE REQUIREMENTS
Easements
EASEMENT IS PUBLIC LAND
▪ Situated outside of private property limits
▪ Should be equally enjoyed by all members of the
community
▪ The only uses allowed are those that support its
public recreational character
MINIMUM EASEMENTS
RROW
VIEW CORRIDORS + SIGHTLINES
▪ The carriageway shall be free of structures,
particularly commercial signs that will impede the
view corridor and sightlines within the RROW
▪ To dignify important public/historical buildings, all
forms of commercial signs intruding into the
RROW leading to or away said structures shall be
disallowed
ACCESS TO PROPERTY
▪ No building shall be constructed unless it adjoins
or has direct access to a public space, yard, or
road on at least one side.
▪ Interior or rear lots shall have an access road with
a minimum width of 3.00m. Provide a 4.00m wide
chaflan at the intersection with the main RROW.
THREE RROW LEVELS
▪ RROW above grade
▪ RROW at grade
▪ RROW below grade
RROW ABOVE GRADE
▪ From the finished surface of the roadway all the
way up to the air
▪ If utilized for whatever purpose, the use or air
rights must be compensated for (leased from the
government)
▪ Minimum clear height: 4.27m from crown of
carriageway
RROW AT GRADE
▪ From natural grade line to the finished surface of
the carriageway or sidewalk
▪ Generally utilized for the movement of the general
public (motorists and pedestrians)
▪ If utilized for whatever purpose, proponent must
lease/pay the government
RROW BELOW GRADE
▪ From finished surface of roadway all the way
down into the ground
▪ If utilized for whatever purpose, proponent must
lease/pay the government
SIDEWALKS
▪ The local planning authority shall determine which
streets shall have an open sidewalk or an arcaded
sidewalk, or a combination of both
▪ For a RROW width of 9.00m or more, the
minimum sidewalk width shall be 1.20m on each
side of the RROW. For RROW less than 9.00m,
refer to Table VIII.G.3
GRADE OF SIDEWALKS
▪ As much as possible, sidewalks shall be level and of
uniform grade throughout the length of the street
▪ When the street slope does not exceed 1/12, the
sidewalk shall follow the street slope
▪ When the street slope is 1/10, the sidewalk shall be
maintained level for every 20-40 meters of run, each
level joined by a ramp of a slope not exceeding 1/6.
DRIVEWAYS ACROSS SIDEWALKS
▪ If curb height = 200mm or lower, the driveway and
the sidewalk shall be on the same plane. Provide
entry ramp of slope 1/3 to ¼ connecting the
carriageway to the sidewalk/curb.
PLANTING STRIPS
▪ Sidewalks 2.00m or more in width shall include on
its outer side a planting strip of not less than
800mm wide up to a maximum of 1/3 of the
sidewalk width
▪ The planting strip is meant to separate the curb
from the sidewalk, and must always be placed
near the curbline.
FRONT YARDS AS PARKING
▪ Not allowed for the following:
▪ R2 Maximum
▪ R3 Maximum
▪ GI
▪ C1, C2 and C3
▪ 50% of front yard may be used as parking for R2
Basic and R3 Basic
Minimum requirements:
Group A dwellings
SANITATION
▪ At least one sanitary toilet and adequate washing
and draining facilities
FOUNDATION
▪ At least 250mm thick
▪ At least 600mm below the surface of the ground
STRUCTURAL LOADS
▪ First floor live load: 200kg/sqm
▪ Second floor live load: 150kg/sqm
▪ Wind load for roofs: 120kg/sqm (vertical)
STAIRS
▪ Minimum width: 750mm
▪ Maximum riser: 200mm
▪ Minimum tread: 200mm
▪ Note: These riser/tread dimensions do not match the general
dimensions prescribed in Rule 12.
ENTRANCE + EXIT
▪ At least one entrance, and another one for exit
Development
controls
TERMS DEFINED
▪ TLA = Total lot area
▪ PSO = Percentage of site occupancy
▪ The part of the lot occupied by the building (A.K.A.
building footprint expressed in %)
▪ TOSL = Total open space within lot
▪ The part of the lot NOT occupied by the building
▪ TLA = PSO + TOSL
▪ USA = Unpaved surface area
▪ The portion of the open space that is unpaved
▪ ISA = Impervious surface area
▪ The portion of the open space that is paved
▪ Since “open space” = TOSL,
▪ TOSL = USA + ISA
▪ MACA = PSO + ISA
▪ Hence, TLA = MACA + USA
▪ Note: MACA stands for Maximum Allowable Construction Area
