3 floors
6 water closet for every floor
5 lavatory for every floor
6 x 3 x 6 = 108
2 x 3 x 5 = 30
Total dfu = 138 dfu
V=LXDXW
95. Water supply pipe – pipe from the source to the building served; min size of 12” diameter
96. Water main – water supply pipe laid along the street where household is connected; min size of
19 mm diameter
97. Corporation stop/cock – device directfly connected to the water main; used to control the
opening of the water main
98. Saddle/service clamp – clamp connected in the water main used for tighting purposes
99. Gooseneck – flexible pipe formed like a goose; connects water main to the curb stop
a. Polybutylene (PB) – color black flexible pipe denoted in outside diameter; length of 61m
b. Polyethylene (PE) - color black flexible pipe denoted in inside diameter; length of 61m
100. Street coupling – one end is internally threaded while the other end is externally
threaded
101. Adapter – fitting used to connect two dissimilar pipe/tube
102. Curb stop – a gate valve which is closed when doing maintenance for a long period of
time
103. Stop box – to protect the curb stop
104. Water service pipe – supply pipe from the water main to the water meter
105. Nipple – pipe in between fittings
a. Long nipple – 3” – 12” in length; threaded outside for both ends
b. Short nipple – 1” – 3” in length; threaded outside for both ends
c. Closed nipple – 1” in length; threaded for the entire length
106. Meter stop – located beside the water meter; used for temporary closure of water
meter for maintenance purposes
107. Water meter – used to measure water consumption; made from brass metal – 85%
alloy, 15% zinc
108. Gate valve – fully closed / fully open valve; manual control
109. Water distribution pipe – from water meter to fixture; min size of 12.5 mm diameter
110. Fixture branch – connected from water distribution pipe to fixture supply
111. Effective opening – cross sectional area of the lowest portion of fixture measured based
on diameter
112. Turbulent flow – flow of water in different directions
113. Laminar flow – flow of water in one direction
114. Water hammering - noisy flow of water due to excessive water pressure
115. Air chamber - to eliminate water hammering; 0.3 – 0.9 mm in length; 19 mm in
diameter
116. Rim – top edge of fixture
117. Air gap – unobstructed opening from the lowest part of a fixture to the rim of another
fixture
118. Air gap affected by sidewall – 3 times the effective opening
119. Air gap not affected by sidewall – 2 times the effective opening
120. Flood level – water begins to overflow
121. Flood level rim – when water overflows
122. Flooded – when water rises from the rim and spilled on the floor
123. Strainer – used to filter foreign objects
124. Tailpiece – pipe connected from fixture to trap
Min size of 38 mm in diameter; max length of 6 in
Material commonly used is lead pipe
125. Slip joint - operates by compression; used for exposed fixture only
126. Crown weir – top level of water inside the trap
127. Dip - water located at the bottom level
128. Trap seal – water inside the trap measured from crown weir to top of dip
129. Trap arm – pipe connected from trap to vent pipe
130. Developed length – measured from centerline of fitting to end of trap arm
*developed length of trap arm – must not be greater than 1.5m
