Data Link Layer Specification
Design Specifications
Revision 1.0
8 March 2024
TABLE OF CONTENTS
TABLE OF CONTENTS 2
LIST OF FIGURES 3
LIST OF TABLES 4
REVISION HISTORY 5
1. Data Link Layer Architecture 6
2. Link Management Control 7
3. Data Link Layer Transmitter 8
3.1. Interface 9
3.1.1. Pins Description 9
3.1.2. Parameters Description 10
3.2. Function Description 10
3.2.1. TLP Gen 10
3.2.2. Retry Buffer 10
3.2.3. DLLP Gen 12
3.2.4. Tx Control 13
3.2.5. DLLP Manager 14
3.2.6. Transmit Mux 15
3.3. Timing Diagram 15
4. Data Link Layer Receiver 16
4.1. Interface 16
4.1.1. Pins Description 16
4.1.2. Parameters Description 18
4.2. Function Description 19
4.2.1. Order_Control 19
4.2.2. Queues 19
4.2.3. Check_seq_num 19
4.2.4. Check_LCRC 19
4.2.5. Check_ECRC 20
4.2.6. De_frame_TLP 20
4.2.7. Next_tlp_counter 20
4.2.8. Check DLLP_CRC 20
4.3. Timing Diagram 21
LIST OF FIGURES
Figure 1. Data Link Layer architecture ............................................................................................................... 6
Figure 2. Link Management Control finite state machine ................................................................................... 7
Figure 3. Architecture of dll_tx top ..................................................................................................................... 8
Figure 4. FSM of Retry buffer controller ........................................................................................................... 12
Figure 5 Architecture of Tx Controller .............................................................................................................. 13
Figure 6 FSM of Tx controller .......................................................................................................................... 14
Figure 7 Timing diagram of Tx controller ......................................................................................................... 15
Figure 8. Data Link Layer Receiver architecture .............................................................................................. 16
Figure 9. Order Control finite state machine .................................................................................................... 19
Figure 10. Receiver Timing diagram ................................................................................................................ 21
LIST OF TABLES
Table 1. Pins description of dll_tx 9
Table 2 . Parameter description of dll_tx 10
Table 3. Size of Retry buffer 11
Table 4. Pin Description of dll_rx 16
Table 5. Parameters Description 18
REVISION HISTORY
Revision Date Description of Changes
1.0 03-05-24 Document created
1.0 03-08-24 Document finished
This module control training process between two Links and also enable transmitting/receiving data from
Transaction Layer :
DL_InActive : this is the initial state (dl_down = 0 and dl_up = 0). It waits until Physical Layer finishes the
training process (physical_link_up = 1) and begins to sponsor Flow Control of two devices .
DL_InitFC1 : transmits Init FC1 to the other end of Link once per 34us and switches to DL_InitFC2 when
receives 3 InitFC1 in the right order (tx_fc1 & rx_fc1).
DL_InitFC2 : transmit Init Flow_Control2 to confirm the buffer space of two devices. Data from
Transaction Layer can even be exchanged in this state (dl_up = 1).
DL_Active : normal state in which data is usually exchanged
3.1. Interface
clk input
reset_n input
tlp_hdr input
tlp_data input
tlp_ecrc input
tlp_rdy input
tlp_vld input
tx_credit input
next_rcv_seq input
ack_nak_rx_flag input
ack_nak_rx_flag_vld input
tlp_rx_seq_num input
MAC_TLP_SEQ_WIDTH
FRM_DATA_WIDTH
MAC_DLLP_DATA_WIDTH
Next Transmit Seq: This module stores the Sequence number that will be added at the beginning of the next TLP
to transmit.
LCRC Calculator: This module calculates a 32-bit CRC. The LCRC value is added to the tail of the TLP.
This module stores the TLPs which are transmitted to the Physical Layer. When it is necessary, the Retry Buffer
retransmits the stored TLPs that are unacknowledged.
CRC Calculator: This module generates a 16 bit CRC, which corresponds to a DLLP.
DLLP Gen: Create DLLP Packets.
3.2.4. Tx Control
Replay num: received from Retry buffer, counts the number of retransmissions. It counts from 00b to 11b. When
the Replay num rolls over 11b to 00b, the Data Link Layer indicates to the Physical Layer to retrain Link.
Ack/Nak notifications: Notifies to Retry Buffer the TLPs acknowledged or unacknowledged in the receiver.
DLLP Manager: Manages transmission of DLLPs. Control Transmit Mux, DLLP is FC_DLLP or Ack/Nak_DLLP.
ST_UPDATE_FC: The receiver must regularly update its neighboring device with Flow Control credits that
become available when transactions are removed from the buffer.
Select the outgoing port of the Data Link Layer Transmitter, where the TLPs that are transmitted by the Transaction
Layer of the TLPs that are retransmitted by Retry Buffer.
4.1. Interface
clk input
reset_n input
[MAC_TLP_INTF_NUM - 1 : 0] [LANE_NUM
* MAC_LANE_DATA_BYTE *
rx_tlp_data input MAC_BYTE_WIDTH - 1:0]
[MAC_TLP_INTF_NUM - 1 : 0]
rx_tlp_lcrc input [31:0]
[MAC_TLP_INTF_NUM - 1 : 0]
rx_tlp_len input [MAC_TLP_LEN_WIDTH - 1 : 0 ]
[MAC_TLP_INTF_NUM - 1 : 0]
rx_tlp_seq input [MAC_TLP_SEQ_WIDTH - 1:0]
[MAC_DLLP_DATA_BYTE *
rx_dllp_data input MAC_BYTE_WIDTH - 1:0]
rx_dllp_vld input
rx_dllp_malformed input
rx_dllp_unbound input
Header of
transaction layer
tlp_hdr output logic 0 packet
Data of transaction
tlp_data output logic 0 layer packet
Digest of transaction
layer packet
tlp_digest output logic 0 (Optional)
4.2.1. Order_Control
IDLE : this is the initial state. It waits until the Data Link Layer finishes the training process (dl_up = 1) and one of
the ports contains data, then switches to PROCESS state.
PROCESS : received data will be processed along these steps :
o Calculate the order of processing data in queues.
o Pop received data with calculated order.
o Check LCRC and sequence_number of each packet.
o Return Ack/Nak flag : if packet passes all the checks, return ACK flag and transmit packet to Transaction
Layer. Otherwise, it returns the NAK flag (!good_tlp) and switches to SUSPEND state.
o De-frame : extract packet into main information’s Transaction Layer : Header, Data, Digest.
SUSPEND : If received data is not a valid packet, all data in queues are removed and wait for next rx_tlp_start to
switch to PROCESS state again.
4.2.2. Queues
Synchronous buffer which saves content of packets before it has been transferred to the next block to process.
4.2.3. Check_seq_num
This module counts the sequence number and compares which is received.
4.2.4. Check_LCRC
This module calculates LCRC-32bit based on the content of packets : Sequence number, Header, Data. And compare
with received LCRC from the other end of Link. And each packet must be processed in one cycle.
4.2.5. Check_ECRC
4.2.6. De_frame_TLP
If all the checker blocks indicate that TLP is valid, this block will de-frame packets into frames : Header, Data, Digest.
4.2.7. Next_tlp_counter
When a good TLP is transmitted to the Transaction Layer, this block will increment the counter and transmit to
DLL_Tx to gen Ack/Nak flag.
This module calculates CRC-16 bit based on DLLP data received and compares with CRC received, if passed it will
send data corresponding with each type of DLL packet.
In PROCESS state :
Each packet must be processed in one cycle and follow the calculated order of ports.
If any packet is an error, return the NAK flag and remove all relevant remaining data from buffers. It also
switches to SUSPEND state.
If the last state is SUSPEND, now it checks for the first received packet, and the same process is maintained
like the above step.
In SUSPEND state : now it waits for next rx_tlp_start to return to PROCESS state.
