LionRock Hybrid

Power Solution
Solution for Algeria Telecom

Page 2
Power People
 Overview

PC

DC A/C

Solar

Energy
Battery
cabinet

DG
Multi energy
Page 3
Power People
 Overview

Page 4
Power People
 Energy cabinet overview

DC distribution unit

FSU(Field Supervision Unit)

Control unit
Rectifier

MPPT

AC Input AC Output

Solar input

Page 5
Power People
 Hybrid Controller

■ 2U*1U*182.5mm

■ 128*128mm LCD screen

■ Rectifiers\solar\Grid\Genset \Battery

management

■ RS485, CAN, Ethernet, RS232; USB interface

■ screen different language, 4Key, 3LED indicator

■ Protocol : Modbus, TCP/IP。

■ Event log (up to 9000 records, totally)

■ Alarm log (up to 10000 records)

Page 6
Power People
Hybrid controller

Page 7
Power People
Hybrid controller

Page 8
Power People
Hybrid controller

Page 9
Power People
 Control logic
Control order: solar > battery > genset (insufficient solar energy)

When the solar energy is insufficient, the battery discharges. When the voltage or
capacity of the battery is lower than the setting value, genset starts to charge for
battery and is on load. When the voltage or capacity of the battery is higher than
the setting value, the genset shutdown

Page 10
Power People
 Control logic

Control order: solar energy > battery (solar energy is sufficient)

When solar energy is sufficient, solar energy charges the battery and is on load.
When there is no light, the battery is loaded with light and the solar energy and
battery are loaded circularly.

Page 11
Power People
 Hybrid controller configuration web

■ As the default IP address of hybrid controller is 192.168.1.5, to

successfully establish communication between it and the laptop, we
need to firstly modify our laptop IP address.

Page 12
Power People
Hybrid controller configuration web

Click here

Page 13
Power People
 Hybrid controller configuration web

Set the IP address as 192.168.1.x

Page 14
Power People
 Hybrid controller configuration web

Open google browser input ‘192.168.1.5’

Page 15
Power People
 Web Interface Overview
Menu bar Status field Content box

Page 16
Power People
 Current alarm
■ View the current alarm in ‘current alarm’

Page 17
Power People
 DC info

■ View the branch information in ‘DC info’

Page 18
Power People
 Temperature info
■ View the temperature information in ‘Temperature info’

Page 19
Power People
DIDO Setting

Page 20
Power People
DIDO Setting

Page 21
Power People
 Clean DG start fail alarm

■ System setting > Hybrid setting > Diesel Generator setting > Clear DG alarm

■ Select the DG1,press “Clear”

■ Press the “Save” button

Page 22
Power People
 Manual control

System Control > Operation Ctrl > System mode > Manual
In manual mode, you can manually control LLVD disconnection and connection
control the genset start and stop

Page 23
Power People
 Hybrid controller configuration web
Check the rectifier and solar module in the web

Page 24
Power People
 Rectifier/MPPT

■ 108W*327.8D*41.6H(mm)

■ Power：3000W

■ Input range：rectifier:187~300Vac MPPT:187~430Vdc (full power range)

85~300Vac 100~430Vdc (voltage range)

■ Input current: ≤18Arms at nominal input

■ THD：<5%(full load);<10%(half load)

■ Output range：53.5Vdc(Rated)

42~58Vdc(adjustable)

■ Io-limited：56.6±0.5A

■ Efficiency：≥96.2% ，MPPT efficiency ≥99%

■ Temperature:-40 to +75℃(operating temp)

Page 25
Power People
 DCDU-12B

■ 442mm*42mm*65mm

■ Fulfill the function of one way -48V DC input，ten way -48V DC output

■ Input capability 1*160A or 2*63A

■ Six Large fast plug terminals support 2.5~10 mm² power cord，four small fast
plug terminals support 2.5~4 mm² power cord.

■ Power distribution 10*30A

Page 26
Power People
 Connect the DCDU-12B cable

Secondary
-48V

load
0V
Push

Step 1 Hold the handle to take out the terminal

Step 2 Push the cover
Step 3 Plug the cable into the hole，then tighten the screw
Step 4 Check that the output cable properly connects to the terminal. Pull the
cover and plug the terminal back.

Page 27
Power People
 SC210
SC210 Power distribution monitoring with power-off protection is used to detect
system bus voltage and current as well as battery voltage and current.
CAN communication
5V output 12V output Power off drive
RS485 communication

Hall current detection

Battery current detection

Dip switch

Load current detection Power input

Load current detection 12V output

Battery fuse
Voltage detection voltage detection Load fuse detection

Green indicator: flashes when working normally, continuously lit up when working improperly

Page 28
Power People
 SC340
SC340 is used for the detection of the on-off state of the fuse of the DC power system.
Power RS485 Fuse state detection
input communication 24--13

Fuse state detection

12--1

12V power
output

Dip switch

Green indicator: flashes when working normally, continuously lit when working improperly

Page 29
Power People
 SC320
The SC501 controller contains 6 DI and 6 DO. And the rest is implemented by extending
SC320. The detailed interface is as follows:

■ * 8 DI detection interfaces

■ * Maximum 8 channels DO control output

■ * Two NTC sensor type of temperature detection

■ * A temperature and humidity detection

■ * A water immersion detection

Page 30
Power People
 Temperature sensor

NTC temperature sensor

The temperature sensor should be placed in the middle of

the battery pack on the side between the two batteries.

Each battery branch needs to monitor the temperature of

the battery. When the battery temperature is higher than
42 °C, the system will have a high battery temperature
alarm. The SC501 can also compensate the temperature
according to the temperature of the battery.
Page 31
Power People
 Temperature and humidity sensor

Power supply: 12V±8%

Output range: DC4～20mA
Measuring range: temperature: -20℃～80℃
humidity: 0～100%RH
Sensitivity: temperature: ±0.5 ℃
humidity: ±5%RH
Dimensions: 71mm*60mm*30mm（±0.5mm）

The temperature and humidity sensor is installed inside the cabinet, the temperature
and humidity in the cabinet can be monitored in real time. When the temperature
exceeds 45 ℃, the system will have an environmental high temperature alarm.
Noted: For the first use, please balance the product for 30 minutes before
measurement, which may ensure a high accuracy.
Page 32
Power People
 Smoke sensor

3
Working voltage: 9V～35V
Alarm: Red indicator lit up 2
Work temperature: -30℃～90℃
Environment humidity: Max 95%RH 4 1
Anti-Rf interference: 10MHz～1GHz 20V/m
Alarm output: NC
Reset mode: automatic reset Mounting base Sensor
Implementation criteria: GB4715-2005,EN54-7
Sensitivity: 0.5dB/m（±0.1dB/m） 1 and 2 port: DC input
Dimensions: 104mm(diameter)*51mm(height) 3 and 4 port: Relay output (connect to
DI4)
The smoke sensor is mounted on the top of the cabinet and triggers a smoke
alarm when it detects smoke.
Noted: It is recommended to run a smoke test every six months to check if the
smoke detector is working properly.
Page 33
Power People
 Solar input
DC SPD Solar input

Page 34
Power People
 AC input
AC input AC SPD AC socket

L1 L2 L3 N

Page 35
Power People
 Lightning protector failure
1. Check the window on the lightning protector. If the color turns red, replace the lightning protector. If
the color does not turn red, check if the AC lightning protector fault detection line is plugged in, and if
the cable is broken. If yes, replace the signal detection line and plug it back in again. If the connection
is normal, this indicates the alarm loop is faulty, SC501 needed to be replaced.

2. If the fault has not been eliminated after replacing the SC501, replace the DIDO expansion board.

Lightning protector instruction：

AC DC
SPD SPD
Warning display of the lightning protector:

Page 36
Power People
 DC distribution Unit
Second Prima Battery
ary ry
Load Load
-48V 0V -48V 0V -48V
-48V 0V

DC SPD LLVD BLVD Battery fuse

Page 37
Power People
 Solar panel

Page 38
Power People
Solar panel connection

To energy cabinet
Page 39
Power People
 PV mounting rack

■ PV mounting rack components

Stopping position protective

frame with PV cleaner self-
cleaning brush
H PV cleaner stand
G
I

Side locking
block
J
PV cleaner stand
F
PV cleaner
with sensor E
K switching stand
Column with sensor
Mid locking block +
conducting strip

Page 40
Power People
 PV mounting rack
 Components:
A：Beam B：Beam connector

C：Trigeminal locking block D：Grounding piece

Page 41
Power People
 PV mounting rack
 Components name：
F：PV cleaner switching G：Stopping position protective
E：Column frame with PV cleaner self-cleaning
stand with sensor
brush

H：PV cleaner stand I：Side locking block J：PV cleaner stand

with sensor

Page 42
Power People
 PV mounting rack

Mid locking block

K：Mid locking block +

conducting strip

Conducting
strip

Page 43
Power People
 Automatic PV Cleaning robot

 Self-powered, automatic and water-free cleaning,

 Large capacity lithium battery pack.

 Flexible working modes can be set.

 Remote control and management

Before First During First

Cleaning Cleaning

Before Second After Second

Cleaning Cleaning
Self cleaning mechanism
Page 44
Power People
 Control box structure

■ The internal components of the control box is shown in the

figure:

Picture of the control

box
Page 45
Power People
 Installation of PV cleaner
■ The distance between the probe and the iron of the sensor can be adjusted to:
3±1mm (as shown in the figure)

3±1m
m

Page 46
Power People
 Basic operation of display screen
■ Display screen parameter view
1. Open the cover of the control box and switch on the power.
2. The switch has two labelling “O” and “I”. Pressing “I” means to open, pressing “O” means to close.
3. Once power on, data will be displayed on the monitor of the control box, indicates the remaining
automatic cleaning time. As shown in the figure:

4. The figure above displays 01.07.03, which means it will begin to run automatically in 1 day 7 hours
3 minutes.
5. Press the “SET” button will switch into different parameters of the cleaner. The basic parameters
are described below

Page 47
Power People
 Description of display screen parameter
Basic parameter sheet
Denotation Meaning

For example, the display of 01.02.03 indicates that automatic cleaning will
XX.XX.XX be performed after 1 day, 2 hours and 3 minutes. It will count down
automatically until 00.00.00.

Here XX.XX represents the current battery voltage. For example, display
1-XX.XX
1-26.54 indicates that the battery voltage is 26.54v.
Here, XXX represents the estimated battery power. For example, the
2-XXX
display of 2-072 indicates that the remaining battery power is72%.
Here XX represents the corresponding address of this cleaner. For
3-XX
example, displaying 3-32 indicates that the sweeper is no. 32.
Here XXXX represents the first 4 digits of the serial number of the cleaning
4-XXXX
machine control system.
Here XXXX represents middle 4 digits in the serial number of the cleaning
5-XXXX
machine control system.
Here XXXX represents the last 4 digits if the serial number of the cleaning
6-XXXX
machine control system.
7-X The X here represents the communication channel of the cleaner.

Page 48
Power People
 Description of display screen parameter
■ View and modify running parameters

When the display shows any one of 1-XX.XX, 2-XXX, 3-XX, 4-XXXX, 5-XXXX, 6-XXXX, and 7-X, press
and hold the “▲” button for 3 seconds or longer to enter the parameter modification interface, which is
displayed as b0---X (X can be any value, expressed as a password), then press “▲” to increase the
value. When the value is displayed to b0---8, press the “SET” button to enter the parameter setting
interface, and other values are invalid. Press the “SET” button to return automatically.

• When displaying 01-XX (X can be any number), pressing the “SET” button will change to 02-XX (X
can be any number).
• Similarly, when displaying 15-X , pressing the “SET” button will change to XX.XX.XX (X can be any
number).
• The following is the parameter modification table:

Denotation Meaning
Here XX represents the current year ,For example 01-17 indicates year
01-XX 2017, press "▲"and "▼" to change the current year, data must be true and
reliable.
XX here said the current month, for example shows 02-10 indicates October,
02-XX press "▲" and "▼" to change the current month, data must be real and
reliable.
XX represents the current date. For example, 03-20 indicates that today is
03-XX the 20th day of the Gregorian calendar, press "▲“ and "▼“ to change the
current date, data must be true and reliable.
Page 49
Power People
 Description of display screen parameter

Here XX shows current hour, 04-16 represents 4pm. Press “▲" and "▼"
04-XX
to adjust the hour. The parameter must be correctly set.

Here XX shows minute count, 05-16 represents 16 minutes. Press “▲"

05-XX and "▼" to adjust the minute count. The parameter must be correctly
set.
Here XX represents the scheduled cleaning time hour, as following 06-
06-XX 16 indicates cleaning program set to 4pm. Press “▲ " and " ▼ " to
adjust the scheduled cleaning time.
Here XX represents the scheduled cleaning time minute count, as
07-XX following 07-16 indicates a cleaning time set at X hour past 16 minutes.
Press “▲" and "▼" to adjust the scheduled cleaning time minute count.
Here XX represents the frequency of cleaning in days, as following 08-
02 shows the cleaning frequency to be once every 2 days. Press “▲"
08-XX
and "▼” to adjust the cleaning frequency.
Here, XXX represents the total length of the array, 09-200 for a total
length of 200 meters. Press "▲" and "▼ “ to adjust the total length of the
09-XXX
array. Hold "▲” and "▼ “ to perform quick changes. This data must be
true and reliable.

Page 50
Power People
 Description of display screen parameter

Here X represents the autonomy level of the operation degree of the

10-X cleaning robot. Press "▲" and "▼" to increase or decrease the
autonomy level of the cleaning robot.
Here X represents the standby position of the sweeper, press “▲" and "
11-X ▼" to adjust. 0 for a standby position on the right-hand side and 1 for a
standby position on the left-hand side.
Here XXX shows the longitude of the power station, as following
displays 12-113 for a longitude of 113°. Press "▲" and "▼" to adjust
12-XXX
the longitude accordingly. The parameters should be set on the correct
value.
Here XX shows the latitude of the power station, as following displays
13-XX 13-43 for a latitude of 43°. Press "▲" and "▼" to adjust the latitude
accordingly. The parameters should be set on the correct value.

Here XX displays the address of the cleaning robot, as following

14-XX displays 14-43 for address number 43. Press "▲" and "▼" to change
the address. Different cleaning robots cannot have the same address.
Here X shows the communication channel of the sweeper, as following
15-X displays 15-1 for communication channel number 1. Press "▲" and "▼"
to adjust the communication channel.

Page 51
Power People
Battery system

Page 52
Power People
 Battery system
 Exquisite design for premium quality, high reliability and stability

 About 3800 cycles @60% DOD on 25℃

 Or 3000 cycles @60% DOD on 35℃

 Life span 8-10 years with average one discharge cycle daily

Page 53
Power People
Generator set

Page 54
Power People
 OwlEye Architecture

Local Server
Base Station 1

1.Generator Base Station 1

RS485
2.Solar OwlEye Controller

3.Battery Ethernet (TCP/IP)

Base Station 1 to Base Station 30

MQTT Intranet

Base Station 30

1.Generator Ethernet (TCP/IP)

RS485 Base Station 30
2.Solar
OwlEye Controller
3.Battery Administrator Platform
Web Browser
Page 55
Power People
 Site Summary

Supports charts to display the measurements.

Page 56
Power People
 Site Energy Dashboard

Power Sources Selection for Analysis

Page 57
Power People
 Site Energy Dashboard
Energy Generation/Consumption Selection for Analysis;
Sliding X-axis for the detailed timeframe

Page 58
Power People
 Site Schematic

Individual Site Schematic with Energy Flow Direction

Page 59
Power People
Thank you!

Page 60
Power People
