BRACKET DESIGN REPORT

DESIGN FORMATION
PROJECT NAME : BRACKET DESIGN Information
BS 5950: Part 1: 2000 Structural use of steelwork design Codes
General Loading:
Dead Loaded
Self-weight of the bracket generated by the software General Load
Live Load, LL requirement
1. Load case 1 = 8.0 KN

Load Combinations General Load

• Ultimate Limit State (1.4DL + 1.6LL)
Combinations
• Serviceability Limit state (1.0DL +1.0LL)

Main Rebar (Grade/Unit Weight) : N/A

Rebar Links (Grade/Unit Weight) : N/A Material Date
Steel (Grade/Unit Weight) : S275 / 7850kg/cu.m
• Main Members

• Other members Member type

• All dimensions &Sketches shown on drawing are in meter Other info

Page | 1
3D Rendering

Live Load

Page | 2
Support Reaction under (ULS)

Summary Reaction Table

Page | 3
 Deflection Criteria

*Max Deflection 2 mm < allowable L/180 = 1810/180 = 10.05 mm (OK)

Ref: Table 8, BS 5950-1 cantilever Deflection Criteria

Utilization Ratio is within allowable, 0.78 < 1.0 (Allowable Ratio 1.0)

Page | 4
CONNECTION DESIGN CHECK
HILTI HAS stud anchor
RAAMSARA CONSULT SDN BHD (812105-A) Job No. Sheet No.
(Formally known as KAR CONSULTANTS
SDN.BHD) Job Title.
Suite 904,9 floor, Wisma Hangsam, No.1, Client.
th

Jalan Hang Lekir 50000 Kuala Lumpur.

Tell: 603-2070 0861
Email: karconsult@gmail.com

CALCULATION SHEET
DESIGN FORCE

Maximum forces taken from the analysis.

• Fx= 18.63 kN
• Fy = 13.98 kN

Resultant Forces ,Frv = √𝑓𝑥 2 + 𝑓𝑦 2

• Frv = 23.3 kN (Resultant Force)

Check adequacy of bolt connection (Reference: HILTI HSA Stud Anchor )

Using 4 Nos at top & 2 Nos at bottom anchor bolt M16

For Tensile Load, NRD = 16.6 kN

Thus, the capacity of four (4) bolts = 16.6 x 4 = 66.4 kN > Frv = 23.3 kN
Therefore, the tensile force is within the limit.

For Shear Load, VRD= 18.9 kN

Thus, the capacity of four (4) bolts = 18.9 x 4 = 75.6 kN > Frv = 23.3 kN
The shear force is within the limit.

Therefore, the tensile force capacity is adequate to sustain the bracket load
 OUTPUT REPORT
STEEL MEMBER DESIGN & UTILIZATION RATIO
 STEEL DESIGN
----------------------------------------------------------------------------------------------------------------------------------------
CODE: British Standard BS 5950:2000
ANALYSIS TYPE: Member Verification
----------------------------------------------------------------------------------------------------------------------------------------
CODE GROUP:
MEMBER: 1 POINT: 3 COORDINATE: x = 0.82 L = 1.479 m
---------------------------------------------------------------------------------------------------------------------- ------------------
LOADS:
Governing Load Case: 3 1.4DL+1.65LL 1*1.40+2*1.65
----------------------------------------------------------------------------------------------------------------------------- -----------
MATERIAL
S275 py = 275.00 MPa E = 205000.00 MPa
----------------------------------------------------------------------------------------------------------------------------- -----------

SECTION PARAMETERS: EQA 80x6

D=80 mm
B=80 mm Ay=480 mm2 Az=480 mm2 A=936 mm2
t=6 mm Iy=560000 mm4 Iz=560000 mm4 Ix=11100 mm4
T=6 mm Wely=9605 mm3 Welz=9605 mm3
----------------------------------------------------------------------------------------------------------------------------- -----------
INTERNAL FORCES
Fc = 5.13 kN My = 2.01 kN*m
Mlt = 2.01 kN*m Mymax = 2.01 kN*m Fvz = 5.07 kN
mlt = 1.00 my = 0.64
----------------------------------------------------------------------------------------------------------------------------- -----------
CAPACITIES
Pc = 231.66 kN Mcy = 2.64 kN*m
Section class = 4 Mey = 2.64 kN*m Pvz = 79.20 kN
----------------------------------------------------------------------------------------------------------------------------------------

LATERAL BUCKLING PARAMETERS:

----------------------------------------------------------------------------------------------------------------------------------------
BUCKLING PARAMETERS:

About Y axis: About Z axis:

----------------------------------------------------------------------------------------------------------------------------- -----------
VERIFICATION FORMULAS:
Section check
Fc/Pc + My/Mcy = 0.78 < 1.00 (4.8.3.2)
Fvz/Pvz = 0.06 < 1.00 (4.2.3)
Member stability check
Not analyzed
----------------------------------------------------------------------------------------------------------------------------- -----------
Section OK !!!
Autodesk Robot Structural Analysis Professional 2020
Author: File: Type 4.rtd
Address: Project: Type 4

Symbol Value Unit Symbol description Article

MEMBER: 1 Simple bar_1 ; COORDINATE: x = 0.82 L = 1.479 m

Cross-section properties: EQA 80x6

A 936 mm2 Cross-sectional area

Ay 480 mm2 Shear area - Y-axis
Az 480 mm2 Shear area - Z-axis
Ix 11100 mm4 Torsional constant
Iy 560000 mm4 Moment of inertia of a section about the Y-axis
Iz 560000 mm4 Moment of inertia of a section about the Z-axis
Zy,u 9605 mm3 Elastic section modulus about the y axis - upper edge
Zy,l 25806 mm3 Elastic section modulus about the y axis - lower edge
Zz,r 9605 mm3 Elastic section modulus about the z axis - right edge
Zz,l 25806 mm3 Elastic section modulus about the z axis - left edge
D 80 mm Height of cross-section
B 80 mm Width of cross-section
T 6 mm Flange thickness
t 6 mm Web thickness
ry 24 mm Radius of gyration - Y-axis
rz 24 mm Radius of gyration - Z-axis
Material

Name S275 (3.1)

py 275.00 MPa Design strength (3.1)
E 205000.00 MPa Modulus of elasticity of steel (3.1)
Section class

Beta1f 9.00 Limiting slenderness of flange (1 class) (Table 11)

Beta2f 10.00 Limiting slenderness of flange (2 class) (Table 11)
Beta3f 15.00 Limiting slenderness of flange (3 class) (Table 11)
bf 80 mm Flange width (Figure 5)
Tf 6 mm Flange thickness (Figure 5)
bf/Tf 13.33 Flange slenderness (Table 11)
KLF 3 Flange class (Table 11)
bf2/Tf2 26.67 Lower flange slenderness (Table 11)
KLF2 4 Lower flange class (Table 11)
Beta1w 9.00 Limiting slenderness of web (1 class) (Table 11)
Beta2w 10.00 Limiting slenderness of web (2 class) (Table 11)
Beta3w 15.00 Limiting slenderness of web (3 class) (Table 11)
d 80 mm Web height (Figure 5)
tw 6 mm Web thickness (Figure 5)
d/tw 13.33 Web slenderness (Table 11)
KLW 3 Web class (Table 11)
KL 4 Class of the member section (Table 11)
Parameters of effective section (class 4)

Aeff 842 mm2 Effective cross-sectional area (class 4) (3.6)

Zy,eff 9605 mm3 Effective plastic modulus (section class 4) - y axis (3.6)
Mb 2.64 kN*m Buckling resistance moment (lateral-torsional buckling) (4.3)
Internal forces at the section characteristic points

Fc 5.13 kN Axial force N

About the y axis of cross-section
My 2.01 kN*m Bending moment My
Mymax 2.01 kN*m Maximum moment My for bar (segment)
my 0.64 Equivalent uniform moment factor my
Mlt 2.01 kN*m Maximum moment Mlt for bar (segment) - lateral-torsional
buckling
mlt 1.00 Equivalent uniform moment factor mlt
About the z axis of cross-section
Fvz 5.07 kN Shear force Vz
Capacities:
Pc 231.66 kN Compression resistance (4.7)
Pcy 231.66 kN Compression resistance (4.7)
Pcz 231.66 kN Compression resistance (4.7)
Pcyz 231.66 kN Compression resistance (4.7)
About the y axis of cross-section
Mpy 2.64 kN*m Plastic moment capacity (4.2.5)
Mey 2.64 kN*m Elastic moment capacity (4.2.5)
Mcy 2.64 kN*m Moment capacity (4.2.5)
About the z axis of cross-section
Pvz 79.20 kN Shear capacity (4.2.3)
Verification formulas
Section
check
UFS[NMy] 0.78 Fc/Pc + My/Mcy (4.8.3.2)
UFS[Vz] 0.06 Fvz/Pvz (4.2.3)
Ratio
UF 0.78 Ratio Section OK

Page : 1
 STEEL DESIGN
----------------------------------------------------------------------------------------------------------------------------- -----------
CODE: British Standard BS 5950:2000
ANALYSIS TYPE: Member Verification
----------------------------------------------------------------------------------------------------------------------------------------
CODE GROUP:
MEMBER: 5 POINT: 1 COORDINATE: x = 0.00 L = 0.000 m
------------------------------------------------------------------------------------ ----------------------------------------------------
LOADS:
Governing Load Case: 3 1.4DL+1.65LL 1*1.40+2*1.65
----------------------------------------------------------------------------------------------------------------------------- -----------
MATERIAL
S275 py = 275.00 MPa E = 205000.00 MPa
----------------------------------------------------------------------------------------------------------------------------- -----------

SECTION PARAMETERS: EQA 50x6

D=50 mm
B=50 mm Ay=300 mm2 Az=300 mm2 A=572 mm2
t=6 mm Iy=130000 mm4 Iz=130000 mm4 Ix=6770 mm4
T=6 mm Wely=3662 mm3 Welz=3662 mm3
--------------------------------------------------------------------------------------------------------------------------- -------------
INTERNAL FORCES
Ft = -0.68 kN My = 0.51 kN*m
Mlt = 0.51 kN*m Mymax = 0.51 kN*m Fvz = -3.70 kN
mlt = 1.00
-------------------------------------------------------------------------------------------------------------------------- --------------
CAPACITIES
Pt = 157.30 kN Mcy = 1.01 kN*m
Section class = 3 Mey = 1.01 kN*m Pvz = 49.50 kN
----------------------------------------------------------------------------------------------------------------------------- -----------

LATERAL BUCKLING PARAMETERS:

----------------------------------------------------------------------------------------------------------------------------- -----------
BUCKLING PARAMETERS:

About Y axis: About Z axis:

----------------------------------------------------------------------------------------------------------------------------- -----------
VERIFICATION FORMULAS:
Section check
Ft/Pt + My/Mcy = 0.50 < 1.00 (4.8.2.2)
Fvz/Pvz = 0.07 < 1.00 (4.2.3)
Member stability check
Not analyzed
----------------------------------------------------------------------------------------------------------------------------- -----------
Section OK !!!
Autodesk Robot Structural Analysis Professional 2020
Author: File: Type 4.rtd
Address: Project: Type 4

Symbol Value Unit Symbol description Article

MEMBER: 5 Simple bar_5 ; COORDINATE: x = 0.00 L = 0.000 m

Cross-section properties: EQA 50x6

A 572 mm2 Cross-sectional area

Ay 300 mm2 Shear area - Y-axis
Az 300 mm2 Shear area - Z-axis
Ix 6770 mm4 Torsional constant
Iy 130000 mm4 Moment of inertia of a section about the Y-axis
Iz 130000 mm4 Moment of inertia of a section about the Z-axis
Zy,u 3662 mm3 Elastic section modulus about the y axis - upper edge
Zy,l 8966 mm3 Elastic section modulus about the y axis - lower edge
Zz,r 3662 mm3 Elastic section modulus about the z axis - right edge
Zz,l 8966 mm3 Elastic section modulus about the z axis - left edge
D 50 mm Height of cross-section
B 50 mm Width of cross-section
T 6 mm Flange thickness
t 6 mm Web thickness
ry 15 mm Radius of gyration - Y-axis
rz 15 mm Radius of gyration - Z-axis
Material

Name S275 (3.1)

py 275.00 MPa Design strength (3.1)
E 205000.00 MPa Modulus of elasticity of steel (3.1)
Section
class

Beta1f 9.00 Limiting slenderness of flange (1 class) (Table 11)

Beta2f 10.00 Limiting slenderness of flange (2 class) (Table 11)
Beta3f 15.00 Limiting slenderness of flange (3 class) (Table 11)
bf 50 mm Flange width (Figure 5)
Tf 6 mm Flange thickness (Figure 5)
bf/Tf 8.33 Flange slenderness (Table 11)
KLF 1 Flange class (Table 11)
bf2/Tf2 16.67 Lower flange slenderness (Table 11)
KLF2 3 Lower flange class (Table 11)
Beta1w 9.00 Limiting slenderness of web (1 class) (Table 11)
Beta2w 10.00 Limiting slenderness of web (2 class) (Table 11)
Beta3w 15.00 Limiting slenderness of web (3 class) (Table 11)
d 50 mm Web height (Figure 5)
tw 6 mm Web thickness (Figure 5)
d/tw 8.33 Web slenderness (Table 11)
KLW 1 Web class (Table 11)
KL 3 Class of the member section (Table 11)
Mb 1.01 kN*m Buckling resistance moment (lateral-torsional buckling) (4.3)
Internal forces at the section characteristic points

Ft -0.68 kN Axial force N

About the y axis of cross-section
My 0.51 kN*m Bending moment My
Mymax 0.51 kN*m Maximum moment My for bar (segment)
Mlt 0.51 kN*m Maximum moment Mlt for bar (segment) - lateral-torsional
buckling
mlt 1.00 Equivalent uniform moment factor mlt
About the z axis of cross-section
Fvz -3.70 kN Shear force Vz
Capacities:

Pt 157.30 kN Tension capacity (4.6)

About the y axis of cross-section
Mpy 1.01 kN*m Plastic moment capacity (4.2.5)
Mey 1.01 kN*m Elastic moment capacity (4.2.5)
Mcy 1.01 kN*m Moment capacity (4.2.5)
About the z axis of cross-section
Pvz 49.50 kN Shear capacity (4.2.3)
Verification formulas
Section check
UFS[NMy] 0.50 Ft/Pt + My/Mcy (4.8.2.2)
UFS[Vz] 0.07 Fvz/Pvz (4.2.3)
Ratio
UF 0.50 Ratio Section OK

Page : 1
