Foreword

We are pleased to welcome you to the family of Perodua owners. As you know,
the performance and durability of a vehicle depends, to a large extent, upon
the way it is maintained and driven.
This Quick Reference Guide is a summary of basic vehicle operations. It
contains brief description of fundamental operations so you can locate and
use the vehicle’s main equipment quickly and easily.
The Quick Reference Guide is not intended as a substitute for the vehicle
Owner’s Manual.
Full Owner’s Manual can be downloaded from Perodua Official Website
(www.perodua.com.my) or Perodua e-Owner ’s Manual page
(https://eownersmanual.perodua.com.my).
For full awareness of your rights under the warranty granted and limitation
set, please refer to the Warranty Booklet in Perodua e-Owners Manual page.
We strongly encourage you to review the Owner’s Manual and any other
supplementary manuals so you will have better understanding of your vehicle’s
capabilities and limitations.
If you have any questions, feel free to contact your authorised Perodua Service
Centre. We are ready to provide qualified service and assistance

PERODUA SALES SDN. BHD.

©2021 PERODUA SALES SDN. BHD.


All rights reserved. This material may not be produced or copied, in whole or in part, without
the written permission of Perodua Sales Sdn. Bhd.

Scan the QR code to visit the Scan the QR code to download the
e-Owner’s Manual Website e-Owner’s Manual Mobile App

Owner’s
Manual

QRG_D51A.indd 1 11/11/2021 11:50:27 AM


DISCLAIMER
The information in this manual is subject to change without notice. No part of
this manual may be reproduced or transmitted in any form or by any means
electronic or mechanical including photocopying, recording or information
storage and retrieval systems for any purpose other than personal use without
our written permission.
While every effort has been made to ensure that the information and contents
in the manual are complete, accurate, up-to-date, reliable and non-misleading,
we cannot be held responsible for mistakes, inaccuracies, or errors found in the
manual. Nor is any liability assumed for damages resulting from the reliance
and use of information contained herein. This manual is provided without any
representation or warranties, express or implied.

PERODUA SALES SDN. BHD.

QRG_D51A.indd 2 11/11/2021 11:50:28 AM


INDEX
OVERVIEW FEATURES & OPERATIONS
INSTRUMENT PANEL 1 (continued)
INSTRUMENT CLUSTER 2
HILL - START ASSIST SYSTEM 30
INDICATOR SYMBOL 3
BLIND SPOT MONITOR (BSM)* 31
SMART ENTRY 5
REAR CROSS TRAFFIC ALERT (RCTA)* 32
PUSH START/STOP BUTTON 8
FRONT & REAR CORNER SENSOR 33
FUEL TANK DOOR RELEASE AND CAP
REVERSE CAMERA* 33
RELEASE 10
VSC & TRC SYSTEMS 34
HOOD RELEASE 10
EMERGENCY STOP SIGNAL 35
ELECTRONIC TOLL COLLECTION
FEATURES & OPERATIONS SYSTEM* 36
CLOCK 11 AIR CONDITIONING SYSTEM 37
SEATS 13 AUDIO 38
TILT STEERING 14 BLUETOOTH OPERATION 39
SIDE VIEW MIRRORS 15 STEERING WHEEL SWITCH* 40
POWER WINDOW 15 USB SOCKET* 40
OPERATION OF CVT 16 POWER SOCKET 40
PARKING BRAKE 16
LIGHTS, TURN SIGNALS AND WIPERS 17 SAFETY & EMERGENCY
ADVANCED SAFETY ASSIST (ASA) 20 FLOOR MAT INSTALLATION 41
PRE-COLLISION WARNING 21 SEAT BELTS 41
PRE-COLLISION BRAKING 21 FRONT SEAT BELT PRETENSIONERS 41
PEDAL MISOPERATION CONTROL 22 SRS AIRBAGS 42
LANE DEPARTURE WARNING (LDW) 22 TYPE OF CHILD RESTRAINT SYSTEM 42
LANE DEPARTURE PREVENTION (LDP) 23 DOOR LOCK 43
FRONT DEPARTURE ALERT 23 CHILD LOCK 43
ADAPTIVE CRUISE CONTROL (ACC)* 24 JAM PROTECTION FUNCTION 44
LANE KEEP CONTROL (LKC)* 27 IF VEHICLE BREAKS DOWN 44
IDLING STOP SYSTEM (eco IDLE) 28 TOOL, JACK AND TYRE LOCATION 45

* : The equipment may vary according to the vehicle grade and options.

QRG_D51A.indd 3 11/11/2021 11:50:28 AM


QRG_D51A.indd 4 11/11/2021 11:50:28 AM
OVERVIEW
INSTRUMENT PANEL
17 18 19 20

23 24

9 8 7 6 5 4 3 2 1 21 22

MAX COOL MAX


M

A/C MODE MEM OFF


FRONT REAR

16

15 14 13 12 11 10

1 Turn signal lever $ Engine start/stop button


2 Headlight switch % USB socket
3 Daytime Running Lights (DRL)* & Power socket
4 Meters ' Air conditioning
5 Wiper and washer switch (‘ Side mirror switches*
6 Audio* ) Advanced Safety Assist OFF switch
7 Hazard light switch * VSC OFF switch
8 SRS air bags for front passenger + eco IDLE OFF switch
9 Glove compartment , AHB switch*
! Hood lock release lever - Headlight levelling switch
" SRS air bags for driver . Central door lock switch
# Tilt steering lock release lever / Front Corner sensor switch*

* : The equipment may vary according to the vehicle grade and options.

QRG_D51A.indd 1 11/11/2021 11:50:28 AM


INSTRUMENT CLUSTER
LCD MULTI-INFORMATION DISPLAY*
1 2 3 4 10 5

DM

RANGE
AVG
CFC
A B

13 7 6 12

TFT COLOUR MULTI-INFORMATION DISPLAY*

1 8 9 10 11 5

IIIIIIIIIIIIIIIIIII
IIII III
III III
I III II
II I
II
II

II
II

III
III

III
III

IIII
IIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIII
IIII

14 3 4 13 12

1 Tachometer 8 TFT colour multi-information display


2 Multi-information display 9 Driving assist display
3 Fuel gauge ! Clock
4 Shift position display " Content display
5 Speedometer # ODO/Trip information
6 Display change button $ Service information reminder
7 Clock adjustment button % Eco drive assist lighting
* : The equipment may vary according to the vehicle grade and options.
2

QRG_D51A.indd 2 11/11/2021 11:50:33 AM


INDICATOR SYMBOL
For details, refer to “Warning lights and Indicators” in Section 2 Owner’s Manual.

Lane Departure Warning


! Brake system warning light activated light

Battery charge warning light Master warning light*

Low engine oil pressure ACC warning light (yellow)/ACC


warning light indicator (green)*

High engine coolant temperature LKC warning light (yellow)/LKC


warning light (red)/Low engine indicator (green)*
coolant temperature indicator (blue)

Engine malfunction warning light Slip indicator

CVT warning light


A eco IDLE OFF indicator
OFF

SRS airbags/pretensioner
warning light A eco IDLE indicator

ABS warning light BSM OFF indicator*

Electric power steering


warning light (red/yellow) RCTA OFF indicator*

Brake override system warning


Key-free system warning light light

AHB warning light (yellow)/


Hands-free driving warning light*
AHB activated light (green)*

Advanced Safety Assist OFF Door ajar warning light


indicator

* : The equipment may vary according to the vehicle grade and options.
3

QRG_D51A.indd 3 11/11/2021 11:50:44 AM


Low fuel warning light Eco driving indicator*

Driver seat belts reminder light Side-view mirrors indicator*

Front passenger seat belts Advanced Safety Assist


reminder light~ operation indicator

Rear seat passenger seat


Lane recognition indicator*
belts reminder light~

Steering operation support


P Parking brake warning light activated light*

Lane Departure Warning OFF


Service information reminder indicator

Turn signal indicator Cruise Control indicator*

Headlights high beam indicator ACC SET indicator*

Security indicator Leading vehicle indicator*

Tail lights indicator ACC OFF indicator*

VSC OFF indicator LKC OFF indicator*


OFF

TRC TRC OFF indicator Power mode indicator*


OFF

If indicator does not turn off within a few seconds of starting engine, there may be a malfunction.
Have the system checked by an authorised Perodua Service Centre.

~ : This light illuminates on the center panel.


* : The equipment may vary according to the vehicle grade and options.
4

QRG_D51A.indd 4 11/11/2021 11:50:50 AM


SMART ENTRY
LOCKING OPERATION UNLOCKING OPERATION

QPress once to unlock driver door


Press once to lock
QPress twice to unlock all doors

BACK DOOR
UNLOCKING OPERATION PANIC ALARM BUTTON

2
QTo activate :
3 Q Press 4 more than
1 second. (Within 10
meters distance around)
4 QTo stop :
Q Press 1, 2, or 4.
Q The alarm will sound for
Press more than 1 second to 45 seconds if any of these
Press and hold.
unlock. buttons are not pressed.

EMERGENCY KEY

Knob

Unlock Lock

Emergency key

Push the knob downwards to release the emergency key.


Use the emergency key if the Smart Key battery is weak or if the Smart Entry function does not
operate properly.

QRG_D51A.indd 5 11/11/2021 11:50:50 AM


LOCK / UNLOCK DOOR

Request switch

Lock and Unlock


Smart key

UNLOCK BACK DOOR

Smart key Press button to open boot

Operating range may vary by surrounding conditions.


(i) Key-free: Within 3 meter from centre of vehicle.
(ii) Request switch: When the smart key is within approximately 80 cm from outer door handle.

QRG_D51A.indd 6 11/11/2021 11:50:56 AM


DOOR AUTO LOCK AND UNLOCK FUNCTION
These functions designed to automatically lock or unlock all doors depending on the vehicle’s
situations.
Auto-lock functions Auto-unlock functions

All doors locked when : All doors unlocked when :


QVehicle speed more than 20 km/h (initial setting). QEngine switch is set to 'ACC' or 'OFF' after
QShift lever moved from P while the engine is running at a speed of 20 km/h or more
running. (initial setting).
QShift lever is in P

QRG_D51A.indd 7 11/11/2021 11:51:01 AM


PUSH START/STOP BUTTON
PUSH START SYSTEM

Engine switch indicator

The Push Start/Stop Button


allows you to start and stop the
engine without inserting a key
into ignition.

TO START ENGINE TO STOP ENGINE


1 4 Shift lever button

P
2 B
S

3
P 1 Stop vehicle completely.
B
S
2 Apply parking brake & shift lever to P.
3 Press engine switch.
4 Release brake pedal (make sure engine
switch indicator off).

TO CHANGE ENGINE SWITCH MODE

`OFF´*
QEnable hazard lights.
OFF ACC ON `ACC´
QEnable electrical components.
(such as accessory sockets)
`ON´
QEnable all electrical components.
Shift lever not in P
Shift lever in P * The engine switch will be set to `ACC´
and not `OFF´ if the shift lever is other
than P position.

When brake pedal is not depressed, pressing the Push Start/Stop Button will change the engine mode.

QRG_D51A.indd 8 11/11/2021 11:51:02 AM


SWITCHING ENGINE ON WHEN SMART KEY BATTERY IS WEAK

P
S
B

1 Move the shift lever to ‘P’ while depressing the brake pedal.

2 Touch the Smart Key to the engine switch until the indicator lights up in green and the alarm
will deactivate.
3 Press the engine switch.

QRG_D51A.indd 9 11/11/2021 11:51:08 AM


FUEL TANK DOOR RELEASE AND CAP RELEASE
Close
Open

Turn and open the cap slowly. To close after


refill, turn the cap opposite until clicking sound
can be heard.

Hanger

Pull up the opener and open the fuel filler door. During filling, place the cap on the hanger.

HOOD RELEASE

Pull the hood release lever.

Unlatch and insert the supporting rod into the slot.


Lifting the lever and open the hood.

10

QRG_D51A.indd 10 11/11/2021 11:51:08 AM


FEATURES & OPERATIONS
CLOCK
LCD multi-information display*

1 To set the hour (H).


2 To set the minutes (M).
3 To set the minutes to ‘00’.
Q Press and hold button 1 and 2
together at the same time.
1 2
3

TFT colour multi-information display*


Time and date setting

3 4

Display Brightness

2 Time and Date

1 Press ENTER buttons to switch to Setting Menu.


2 Press U V buttons to select ‘Time and Date’ and press ENTER button.
3 Time
Q For Hour/minutes, after T displayed, press U V buttons to set minutes and hour,
then press ENTER.
slot. Q For 12H/24H will switch between ’12H’ (12 hour display) and ‘24H’ (24 hour display)
every time the ENTER button is pressed.
Q Regardless of 12H/24H settings, the clock will be displayed in a 24-hour format during
adjustment.
4 Date
Q For ‘Sort by Date’, after T is displayed, press the U V buttons to select the display
order of the date and pressing the ENTER button again.
Q For “Day”, “Month”, and “Year”, after T displayed, press U V buttons to set day,
month and year, then press ENTER.

* : The equipment may vary according to the vehicle grade and options.
11

QRG_D51A.indd 11 11/11/2021 11:51:14 AM


Clock display setting

4 Clock 1 Clock 2

Display Brightness Ending Display Type STD

2 Display Settings

3 Clock Display Type

1 Press ENTER buttons to switch to setting menu.


2 Press U V buttons to select ‘Display Setting’ and press ENTER button.
3 Switch between the screens in ‘Display Setting’ either by pressing and holding or pressing
the U V buttons several times. Select ‘Clock Display Type’ and press ENTER button.
4 Press U V buttons to select ‘Clock 1’ or ‘Clock 2’ and press ENTER button.

12

QRG_D51A.indd 12 11/11/2021 11:51:19 AM


SEATS
ADJUSTING THE SEATS
Front seats Rear seats
1

1
1 Adjusts seat positions.
2 Adjusts seat back reclining positions. 1 Adjust reclining positions.
3 Adjusts seat height. (Driver’s seat only) (Two stages reclining)

FOLDING THE SEAT BACK DOWN


Rear seats

1 Store seat belt buckle. 3 Pull the lever.


2 Lower the headrest. 4 Fold down the seat back.

13

QRG_D51A.indd 13 11/11/2021 11:51:19 AM


ADJUSTING THE HEAD RESTRAINTS
Front seats Rear seats*

1 1

2
2

Release button Release button


1 Up 1 Up
2 Down 2 Down

Installing Adjusting (front seats)

Release button

Align the head restraint and push release button Adjusting its centre align with your ears.
while push the head restraint down.

TILT STEERING

1 Hold the steering and pull the lever up. 2 Adjust steering wheel and push the lever
down to lock.

* : The equipment may vary according to the vehicle grade and options.
14

QRG_D51A.indd 14 11/11/2021 11:51:20 AM


SIDE VIEW MIRRORS
TO ADJUST TO FOLD

1 2

1 To fold mirrors.
1 Set the switch to left or right. 2 To open mirrors.
2 Push the switch to adjust the mirror. 3 Automatic fold and open mirrors.

This component is enabled when the engine switch is in “ACC” or “ON” mode.

POWER WINDOW
Master switch Passenger

Driver side
Up
Window lock
switch
Down
Front passenger
side

Rear
passenger sides

Automatic operation
Push the switch down or pull it completely up and release to fully open or close. To stop window
partially, push the switch lightly in the opposite direction during opening or closing.

15

QRG_D51A.indd 15 11/11/2021 11:51:21 AM


OPERATION OF CVT
CVT TRANSMISSION

P Parking or start engine

R Reverse

N Neutral

D D Normal driving
S

B
S B
Shift
S Driving on a slope
lever
B Driving down a steep hill

d
button

: Operate with the brake pedal depressed and the shift lever button
pressed with the engine switch set to IGNITION ON mode.
v : Operate with the shift lever button pressed.
e : Operate without the shift lever button pressed.

TO SELECT DRIVING MODE


Power mode : Enables the vehicle to accelerate more
by increasing the engine power. Suitable
when driver wants to quickly speed up
while driving.

Normal mode : Suitable for normal driving which can be


defined as driving under optimal condition
such as good weather, clear traffic, and
good vehicle and road condition.

PARKING BRAKE
1 2

1 To engage : Pull brake lever while pressing


brake pedal.

2 To release : Slightly pull brake lever up and


all the way down while pressing
the lever button.

16

QRG_D51A.indd 16 11/11/2021 11:51:26 AM


LIGHTS, TURN SIGNALS AND WIPERS
TURN SIGNAL LEVER
1 Left turn. 1
2 Lane change (left).
ne 3 Lane change (right).
2
4 Right turn.

p hill HEADLIGHT SWITCH


Q Type 1 2 Q Type 2*
2
1 1
4
3
3
re
ble 1 Clearance lights, tail lights, license plate light.
p 2 Lights on.
6 3 Lights off.
4 Lights on/off automatically.
be 5 High beam.
ition 5
6 Headlight flasher.
nd

FOLLOW ME HOME SYSTEM HEADLIGHT LEVELLING SWITCH*

1 Switch ‘OFF’ engine switch.


1 Upward adjustment.
2 Pull lever towards self.
2 Downward adjustment.
3 Release light switch in O or AUTO.

* : The equipment may vary according to the vehicle grade and options.
17

QRG_D51A.indd 17 11/11/2021 11:51:32 AM


DAYTIME RUNNING LIGHT (DRL)*

Daytime running light

Daytime running light operation condition:


QEngine is ON
QHeadlight switch position in AUTO
QParking brake release

AUTO HIGH BEAM (AHB)


AHB helps to switch the headlights automatically into high beam or low beam depending on the
surroundings brightness. (e.g. lights from street lamps, preceding vehicle or opposite directions
vehicles.)

To activate, make sure to :


1 Switch ‘ON’ the engine switch.
2 Set lever to original position.
3 Set light switch to (type 1), or
AUTO (type 2).
4 Turn ‘ON’ AHB switch.
5 Do not set front wiper to high speed
operation.

Automatic high beam condition : Automatic low beam condition :


QVehicle speed : 30 km/h or more. QVehicle speed : 20 km/h or less.
QVehicle’s front area : Dark. QVehicle’s front area : Bright.
QNo vehicle is coming in opposite direction. QThere is vehicle coming in opposite direction.
QStreet lamps in front : Dark. QStreet lamps in front: Bright.

* : The equipment may vary according to the vehicle grade and options.

18

QRG_D51A.indd 18 11/11/2021 11:51:32 AM


FRONT WIPERS AND WASHER

5
6
1

1 f : OFF. 4 s : High speed operation.


2 q : Intermittent operation. 5 o : Temporary operation.
3 r : Low speed operation. 6 k : Washer.

During intermittent (INT) operation, the interval becomes shorter as the driving speed rises.

19

QRG_D51A.indd 19 11/11/2021 11:51:32 AM


ADVANCED SAFETY ASSIST (ASA)
ASA is a system designed to support the driver’s awareness, decision making and vehicle
operation contributing to a safe driving experience.
STEREO CAMERA

Horizontal view
about 40 degrees

Stereo camera
detection range

Vertical view
about 25 degrees
Stereo camera
detection range

i) A stereo camera mounted in front of the inside rear view mirror which detect vehicle up to
about 70 m (pedestrian up to 45 m) in front.
ii) The stereo camera will not operate properly if the wind shield view in front of the camera is
obstructed by something, dirt, foggy, sticker etc.

ASA OFF SWITCH

A.S.A OFF indicator light

Press and hold more than 2 seconds


to turn on/off A.S.A function

ASA OFF indicator light will illuminate at the meter panel. Every time you start the engine by the
engine switch operation, ASA function will return to ready state.
Refer to the Owner’s Manual (Section 4) for additional information on operation, settings
adjustments, limitations and precautions before attempting to use it.

20

QRG_D51A.indd 20 11/11/2021 11:51:33 AM


PRE-COLLISION WARNING
Alert the driver when the stereo camera recognizes the high collision risk during day and night.

Q When the system determines if there is a risk


of collision, it will alerted and urged the driver
Pipipipipipi
to take evasive action by the buzzer and display.

Q This function operates when the vehicle speed


and speed difference between the front
obstacles are :
4-120 km/h (vehicles, two-wheeled vehicles)
4-60 km/h (pedestrian)

PRE-COLLISION BRAKING
Control the brakes to assist in avoiding collision as well as contributing in mitigating collision
damage during day and night.

Q If the system recognizes the front obstacles and


determines that there is a high collision risk, it will
change buzzer and control brakes.
Pipipipipi... Q This function operates when the vehicle speed and
speed difference between the front obstacles are :
4-120 km/h (vehicles, two-wheeled vehicles).
4-60 km/h (pedestrian).
Q If the brake pedal is depressed under following
conditions, it helps to decelerate with more braking
force than normal :
30-120 km/h (vehicles, two-wheeled vehicles).
30-60 km/h (pedestrian).

Q Continuously press the brake pedal to continue stop the vehicle because the vehicle will
slowly start moving after 1.5 seconds.
Q The operation cancelled if it determines low collision risk made by the driver such as pressing
the brake pedal or operating the steering wheel.

Refer to the Owner’s Manual (Section 4) for additonal information on operation, settings
adjustments, limitations and precautions before attempting to use it.

21

QRG_D51A.indd 21 11/11/2021 11:51:33 AM


PEDAL MISOPERATION CONTROL
This function assist driver in avoiding collision by controlling engine output when the driver accidently
press the accelerator pedal.

Pipipipipi
The systems activates by following conditions :

QStereo camera recognizes obstacle 4 m ahead.


QPressing wrong pedal while driving slowly
approximately 10 km/h or slower.

If the accelerator is pressed accidentally at approximately 4 km/h or less, the driver will be alerted
by the buzzer and display.

LANE DEPARTURE WARNING (LDW)


Alert the driver when there is a risk of the driver unintentionally depart from the vehicle lane.
Lane recognition indicator*

Pipipipip
Pipipipip

The system activates by following conditions :


QEngine switch is ‘ON’.
QVehicle speed : 60 km/h or more.
QLane Departure Warning OFF indicator is off.
QTurn signal indicator off for 4 seconds after the turn signal indicator is turned off.
QVehicle lane width approximately 2.5 to 4.2 m.

Refer to the Owner’s Manual (Section 4) for additional information on operation, settings
adjustments, limitations and precautions before attempting to use it.

* : The equipment may vary according to the vehicle grade and options.

22

QRG_D51A.indd 22 11/11/2021 11:51:34 AM


LANE DEPARTURE PREVENTION (LDP)
Provides small steering force to the steering wheel to avoid the vehicle departing from the vehicle
lane by alerts using buzzer and display.

The system activates by following conditions :

QEngine switch is ‘ON’.


QVehicle speed : 60 km/h or more.
QLane departure warning OFF indicator is off.
QTurn signal indicator off for 1 second after the
turn signal indicator is turned off.
QVehicle lane width approximately 3 to 4 m.

FRONT DEPARTURE ALERT


Alerts the driver when the vehicle in front has moved.

Pipipi

Warning will sound when your vehicle


keep stopping although the preceding
vehicle has already moved forward more
than about 3 meter away.

Shift position is other than H & I and distance between the stopped preceding vehicle and own
vehicles is within about 10 meter.

Refer to the Owner’s Manual (Section 4) for additional information on operation, settings
adjustments, limitations and precautions before attempting to use it.

23

QRG_D51A.indd 23 11/11/2021 11:51:35 AM


ADAPTIVE CRUISE CONTROL (ACC)*
This system consist of two modes :
QDistance control mode : Detect the presence of front vehicle (by stereo camera) and automatically
accelerates or decelerates based on the speed change by the front vehicle.
QConstant speed control mode : Allow driver to drive at constant speed set by the driver.
System components

Driving Assist Display Operation switch

5 4

1 2
1

5 2

4 3
3

1 Set vehicle distance 1 ' RES switch


2 Leading vehicle indicator 2 ACC main switch
3 Set vehicle speed 3 Cancel switch
4 ACC set indicator 4 ( SET switch
5 ACC OFF indicator 5 Set vehicle distance change switch

Refer to the Owner’s Manual (Section 4) for additional information on operation, settings
adjustments, limitations and precautions before attempting to use it.

* : The equipment may vary according to the vehicle grade and options.

24

QRG_D51A.indd 24 11/11/2021 11:51:35 AM


DISTANCE CONTROL MODE
1 2 3

1 Constant speed driving (no vehicle in front).


2 Decelerated driving-cruise control driving (front vehicle slower than set speed).
3 Accelerated driving (slower speed front vehicle no longer in front).

Setting the set speed (Distance control mode)

1 Press ACC main switch (the display will be displayed as ‘_ _ km/h’).


2 Accelerate/decelerate using accelerator to the desired speed (30 km/h or higher).
3 Press ‘(SET’ switch.
Changing the set speed (Distance control mode)

1 1 Increase speed.
2 Reduce speed.

Q Press 'RES or (SET switch until get


2 the desired speed.

Refer to the Owner’s Manual (Section 4) for additional information on operation, settings
adjustments, limitations and precautions before attempting to use it.
25

QRG_D51A.indd 25 11/11/2021 11:51:36 AM


CONSTANT SPEED CONTROL MODE
This mode allow vehicle moves at a constant speed set by driver without matching the changes
in speed made by the vehicle in front.

Setting the speed (Constant speed control mode)

1 Press and hold ACC main switch for 2 seconds or longer (the display will displayed as ‘_ _ km/h’).
2 Accelerate/decelerate using accelerator to desire speed (30 km/h or higher).
3 Press ‘(SET’ switch

Changing the set speed (Constant speed control mode)

1 1 Increase speed.
2 Reduce speed.

Q Press 'RES or (SET switch until get


2 the desired speed.

Refer to the Owner’s Manual (Section 4) for additional information on operation, settings
adjustments, limitations and precautions before attempting to use it.

26

QRG_D51A.indd 26 11/11/2021 11:51:36 AM


LANE KEEP CONTROL (LKC)*
This system assist the driver’s steering operation to ensure the vehicle drives in the current lane
by recognizing the white or yellow lines on the left or right of the vehicle using the stereo camera.
The LKC does not operate when the ACC is not active.

The driver is informed on LKC operation by the indicator in meter and display. The system activates
by following conditions.
Q Vehicle speed : 60 km/h or more.
Q ACC (distance control mode) : 60 km/h or more
Q ACC (set speed) : 60 km/h or more
Q LKC indicator : Lights up

LKC indicator To set or cancel the function

2 While the ACC (Distance control mode) is


operating.
1 LKC OFF indicator. 1 Press the LKC switch to switch ON.
2 Lane recognition indicator. 2 Press the LKC switch again to switch OFF.

Refer to the Owner’s Manual (Section 4) for additional information on operation, settings
adjustments, limitations and precautions before attempting to use it.

* : The equipment may vary according to the vehicle grade and options.

27

QRG_D51A.indd 27 11/11/2021 11:51:37 AM


IDLING STOP SYSTEM (eco IDLE)
The ‘eco IDLE’ is a system that stop and restart the engine with
the brake pedal without using the engine switch while the vehicle
stops at a red traffic light or an intersection.

eco IDLE is ready eco IDLE is OFF

1 When conditions for ‘eco IDLE’ mode are


fulfilled during driving, the ‘eco IDLE’ ready
indicator turns on in green (standby state).

eco IDLE 2 While the shift lever is in D, depress the brake


pedal and stop your vehicle for ‘eco IDLE’
mode. The indicator will remain on in green
during ‘eco IDLE’ mode.

3 The engine restarts when foot is released


from the brake pedal. The ‘eco IDLE’ ready
Release the foot
from the brake indicator will turn off.
pedal
4 The ‘eco IDLE’ ready indicator turn on in
green again after conditions for ‘eco IDLE’
mode are fulfilled.

Engine restart

Refer to the Owner’s Manual (Section 4) for additional information on operation, settings
adjustments, limitations and precautions before attempting to use it.

28

QRG_D51A.indd 28 11/11/2021 11:51:47 AM


‘eco IDLE’ may not operate normally under the following conditions. Have the vehicle checked by
an authorized Perodua Service Centre.

The interior light turns on when the driver’s


door is closed and does not turn on when
the driver’s door is opened.

Door

Door ajar warning light turns on when the


driver’s door is closed and does not turn on
when the driver’s door is opened.

Seat belt reminder light flashes when driver’s


seatbelt is fastened, and/or does not flash
when driver’s seat belt is not fastened.

Refer to the Owner’s Manual (Section 4) for additional information on operation, settings
adjustments, limitations and precautions before attempting to use it.

29

QRG_D51A.indd 29 11/11/2021 11:51:48 AM


HILL - START ASSIST SYSTEM
Hill-Start Assist System helps to prevent the vehicle from rolling back when starting up again from
a stopped position on an incline.

1 Release the brake pedal slowly.

2 Vehicle retains brake force for 2


seconds.

3 Accelerate to continue driving.

30

QRG_D51A.indd 30 11/11/2021 11:51:49 AM


BLIND SPOT MONITOR (BSM)*
BSM overview : Assists driver when changing lanes.
1
2 2

1 TFT colour multi-information display.


4 2 Side-view mirror indicator.
3 BSM OFF indicator.
4 Buzzer.
3

BSM function : Detects the next vehicle running in the next lane using radar sensor and informs
driver using side-view mirror indicator and buzzer.

1 Vehicle running in a zone not reflected in the side-view mirror (blind spot).
2 Vehicle rapidly approaching from rear to a zone not reflected in the side-view mirror (blind spot).

BSM function effective range

2 3 4

1 Approximately 3.5 m from 0.5 m (both sides). 3 Approximately 3 m (behind rear bumper).
2 Approximately 1 m (in front rear bumper). 4 Approximately 3 to 60 m (behind rear bumper).

Refer to the Owner’s Manual (Section 4) for additional information on operation, settings
adjustments, limitations and precautions before attempting to use it.

* : The equipment may vary according to the vehicle grade and options.
31

QRG_D51A.indd 31 11/11/2021 11:51:50 AM


REAR CROSS TRAFFIC ALERT (RCTA)*
RCTA overview : Assist driver when reversing.
1
2 2

1 TFT colour multi-information display.


4 2 Side-view mirror indicator.
3 RCTA OFF indicator.
4 Buzzer.
3

RCTA function

1
2 2

1 Approaching vehicle.
2 The range that can detect approaching vehicle.

RCTA function effective range

1 1

For fast vehicles, the buzzer will sound when the vehicle is further away.
Approaching vehicle speed 1 Alert distance (estimate)
Approximately 28 km/h (fast) Approximately 20 m
Approximately 8 km/h (slow) Approximately 5.5 m

Refer to the Owner’s Manual (Section 4) for additional information on operation, settings
adjustments, limitations and precautions before attempting to use it.

* : The equipment may vary according to the vehicle grade and options.
32

QRG_D51A.indd 32 11/11/2021 11:51:50 AM


FRONT & REAR CORNER SENSOR
SONAR LOCATIONS AND TYPES

1 Front sonar
2 Rear sonar

1 2

FRONT CORNER SENSOR SWITCH

• This function will assist driver to park


the vehicle during front parking.
• Press the switch to activate the system.

REVERSE CAMERA*
Screen display

Parts of the vehicle body are displayed


on the screen (bumpers, etc.).
Any object under the bumper or near both ends of the bumper are out of the reverse camera
display range.

* : The equipment may vary according to the vehicle grade and options.

33

QRG_D51A.indd 33 11/11/2021 11:51:51 AM


VSC & TRC SYSTEMS
Vehicle Stability Control (VSC)
Keeps the vehicle stable during sudden turns or on slippery roads.
Traction Control (TRC)
Assists with keeping the stability of the vehicle when accelerating on slippery roads.
VSC & TRC OPERATION

Front wheels skid Rear wheels skid Rear wheels skid

With VSC - The vehicle is


Without VSC - Skidding occur
stabilized

Q These situations may arise depending on road, tyre and weather conditions.
Q The vehicle is more secure if it is equipped with ABS (Anti-lock Braking System) & EBD
(Electronic Brake force Distribution.)

IMPORTANT:
Even when VSC & TRC are operation, there are
limits to the systems’ traction and stability control.
Dangerous driving may still cause accidents.

34

QRG_D51A.indd 34 11/11/2021 11:51:51 AM


Pressing

OFF
switches VSC off

OFF
illuminates
Pressing and holding

OFF

switches VSC & TRC off


TRC and
OFF OFF
illuminates
If there is an error,

illuminates

EMERGENCY STOP SIGNAL


Emergency stop signal system reduces the risk of collision by automatically flashing the hazard
lights when the brakes applied suddenly to alert the vehicle behind.

1 Hard braking

2 Brake lights
come on

3 Hazard warning
lights flash

4 Hazard warning indicators blink


Emergency stop signal operating conditions :
Q Hazard warning signal light is OFF.
Q Vehicle speed is about more than 60 km/h.
Q The system determines from the vehicle deceleration and the pressed brake pedal that involve
in sudden braking or when ABS system is activated.

Driver is obliged for a safe driving and avoid unnecessary sudden braking.

35

QRG_D51A.indd 35 11/11/2021 11:51:52 AM


ELECTRONIC TOLL COLLECTION SYSTEM*
1
Front windscreen

1 LCD
3 2 2 Card slot
3 Press button to check the
prepaid card balance
Prepaid Antenna
card

* : The equipment may vary according to the vehicle grade and options.
36

QRG_D51A.indd 36 11/11/2021 11:51:53 AM


AIR CONDITIONING SYSTEM
Make sure the ignition switch is ON to operates the air conditioner blower.

TURN ON AIR CONDITIONER TEMPERATURE CONTROL


A/C FRONT REAR

MAX COOL MAX


1

1 1 2

k the MODE M1 M2 OFF

MAX COOL MAX MAX COOL MAX


M M

A/C MODE MEM OFF A/C MODE MEM OFF


FRONT REAR FRONT REAR

2
2
1 Press to increase level.
1 Press to on blower. 2 Press to decrease level.
2 Press A/C to on air conditioner. QMAXCOOL will appear after pressing to the
maximum/end.

BLOWER FAN SWITCH SET MEMORY


A/C FRONT REAR

MAX COOL MAX


1
2 1
MODE M1 M2 OFF

MAX COOL MAX MAX COOL MAX


M M

A/C MODE MEM OFF A/C MODE MEM OFF


FRONT REAR FRONT REAR

2 MEM

1 Press to increase level. 1 Set preferred setting of air conditioner by


2 Press to decrease level. pressing MEM button.
QPress and hold button to increase or 2 Place and hold memory button to set the
decrease continuously. memory.

37

QRG_D51A.indd 37 11/11/2021 11:51:54 AM


AUDIO
(Type 1) 6 1 3

4 5 2

Refer to the Owner’s Manual (Section 5) for more details.

(Type 2)
6 1 3

4 5 2
Refer to the Owner’s Manual (Section 5) for more details.

1 Power/Mode button 4 Equalizer/clock button


2 Auto store/Select (AS-SEL) button 5 Volume button
3 Mute button 6 Clock button (Type 1)/
Bluetooth button (Type 2)

38

QRG_D51A.indd 38 11/11/2021 11:51:54 AM


BLUETOOTH OPERATION
Type 1 & 2

Bluetooth button
1 Press and hold Bluetooth button for 5 seconds until beep sound.
2 LCD will display “PAIRING” and “ ” will flashing.
3 Confirm default passkey “0000” in mobile phone.
4 LCD will display “CONNECTED” and “ ” will stop flashing.

Refer to the Owner’s Manual (Section 5) for more details.

For LCD display type

1 Select ‘Bluetooth’ button on main menu screen.


2 Select ‘Pairing’ button to enter into pairing
mode.
3 Use mobile phone to search for new
bluetooth device mode.
4 Confirm the 6-digits passkey and press
‘YES’.
5 Select ‘OK’ at mobile phone if the passkey
is same.
6 LCD will display “CONNECTED” and ready
to use.

Refer to the Multimedia Manual for more details.

39

QRG_D51A.indd 39 11/11/2021 11:51:56 AM


STEERING WHEEL SWITCHES*
1 2 5 6

3 4 2 7
1 Audio remote control switches*¹ 5 LKC switch
2 Meter control switch 6 ACC switch
3 Phone switch*¹ 7 Driving mode switch
4 Voice command for smartphone link*¹
*1: Refer to the Multimedia Manual for more details.

USB SOCKET*
Front Rear

5V/2A

QFor charging only. QFor charging only.

POWER SOCKET

0W
/12
12V MAX

* : The equipment may vary according to the vehicle grade and options.

40

QRG_D51A.indd 40 11/11/2021 11:51:56 AM


SAFETY & EMERGENCY
FLOOR MAT INSTALLATION

Floor mat

Before driving, ensure that the


floor mat is installed securely
in the correct position.

SEAT BELTS
Fasten Unfasten

Release button

FRONT SEAT BELT PRETENSIONERS

Q Actuated when subjected to a strong impact


from the front.
Q Seat belt will instantly retracts to secure the
upper body of occupant.

41

QRG_D51A.indd 41 11/11/2021 11:51:57 AM


SRS AIRBAGS

3
1

2
1

1 SRS driver airbags/front passenger airbag (reduce impact of head and chest).
2 SRS side airbags (reduce impact to the chest of front seat passenger).
3 SRS curtain shield airbags (reduce impact to the head for front and rear passengers).

TYPE OF CHILD RESTRAINT SYSTEM


Infants seats Toddlers seats Junior seats

Q This vehicle is equipped with ISOFIX child restraint system seat.


Q The child restraint system should be properly installed on the rear seat.

42

QRG_D51A.indd 42 11/11/2021 11:51:58 AM


DOOR LOCK

Front of vehicle Front of vehicle

1 2

2 1 Lock
Unlock

Inside handle

1 Locks the door.


2 Unlocks the door :
• Driver door
Pull the inside handle lever.
• Passengers door
Release locking knob and pull the inside handle lever.

CHILD LOCK

Lock

Unlock

43

QRG_D51A.indd 43 11/11/2021 11:51:58 AM


JAM PROTECTION FUNCTION
Jam Protection Function is only available for driver’s window only. If an object caught between the
window and window frame still closing, the window will open slightly and stop moving

Obstruction

• Turn engine switch ‘‘ON’’.


k

• Push and hold the power window switch


Rising down until window has opened completely.
• Hold the power window switch in the one -
Glass touch closing position.
• Continue holding the switch for a further 2
seconds after the window has closed
completely.
k

Retract Window Jam Protection will not a activate


if obstruction is too small.
Glass

IF VEHICLE BREAKS DOWN


1 2

Put at more than


50 m rearward
3

1 Turn on the emergency flasher.


2 Evacuate the occupants.
3 Place a triangle hazard sign (50 m or more from vehicle’s rear).
4 Evacuate to safe place.

44

QRG_D51A.indd 44 11/11/2021 11:51:58 AM


TOOL, JACK AND TYRE LOCATION

1 3

1 Tool bag.*
2 Jack.
3 Spare tyre.
*Jack handle, wheel nut wrench, towing hook,.

Refer to the Owner’s Manual (Section 7) for tyre changing and jack positioning procedure.

45

QRG_D51A.indd 45 11/11/2021 11:51:59 AM


QRG_D51A.indd 46 11/11/2021 11:51:59 AM
The following Wireless Communication products in
this vehicle is certified (Type Approved) by SIRIM under
Communication and Multimedia Act 1998

Immobilizer equipment (body ECU)


HIDF18000025 HIDF20000224

Keyless entry systems / immobilizer


(smartkey transmitter),
CIDF15000184 Blind spot monitor systems

QRG_D51A.indd 47 11/11/2021 11:52:00 AM


QRG_D51A.indd 48 11/11/2021 11:52:00 AM

You might also like
