WDM OTN Clock Synchronization Feature Guide 12
WDM OTN Clock Synchronization Feature Guide 12
Issue 12
Date 2023-03-30
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees
or representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Website: https://www.huawei.com
Email: support@huawei.com
The physical clock, IEEE 1588v2, and ITU-T G.8275.1/G.8273.2 features of the
WDM/OTN network support all-scenario, high-reliability, and high-performance
clock synchronization networks to provide clock synchronization for downstream
devices.
This document describes the clock functions of Huawei OSN series WDM/OTN
equipment, including application scenarios, technical principles, operation guide,
and capabilities of each equipment.
Related Versions
The following table lists the product initial versions to which this document can be
applied.
For details about the specifications of this feature supported by each product
version, see:
● Physical-Layer Clock Feature Updates
● IEEE 1588v2 Feature Updates
● ITU-T G.8275.1/G.8273.2 Feature Updates
● 5.8 Feature Updates
Intended Audience
This document is intended for:
● Commissioning engineers
● Network monitoring engineers
● Data configuration engineers
● Network administrators
● Maintenance engineers
● Onsite maintenance engineers
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Description
GUI Conventions
Convention Description
Convention Description
Change History
Updates between document issues are cumulative. The latest document issue
contains all the changes made in earlier issues.
Issue 12 (2023-03-30)
This issue is the twelfth official release. Compared with the last release, this
document is updated to match V100R022C10.
Topic Update Description
Type
Issue 11 (2022-10-30)
This issue is the eleventh official release. Compared with the last release, this
document is updated to match V100R022C00.
Topic Update Description
Type
Issue 10 (2022-05-30)
This issue is the tenth official release. Compared with the last release, this
document is updated to match OSN 9800 V100R021C10SPC300 and OSN 1800
V100R021C10SPC300.
Topic Update Description
Type
3.3.1 Feature Modified The 1800 V Pro and 1800 II Pro chassis newly
Limitations support automatic compensation for ring
3.8.1.1 network delay offset and automatic single-fiber
Configuration bidirectional compensation.
Process
3.8.1.9
Configuring
Ring Network
Automatic
Compensation
Issue 09 (2021-11-30)
This issue is the ninth official release. Compared with the last release, this
document is updated to match OSN 9800 V100R021C00SPC300 and OSN 1800
V100R021C00SPC300.
Topic Update Description
Type
Issue 08 (2021-03-30)
This is the eighth official release. Compared with the last release, this document is
updated to match OSN 9800 V100R020C10SPC300 and OSN 1800
V100R020C10SPC300.
Topic Update Description
Type
2.2.3 Clock Modified The OSN 9800/OSN 1800 newly supports clock
Source Port synchronization GE optical ports.
3.2.4 Time
Source Port
4.2.2 Time
Source Port
4.8.1.11.4 Modified The OSN 1800 and ports newly support the T-
Parameters: TC working mode and the external time port
Clock newly supports G.8271 packets.
Synchronization
Attribute
● Added the OptiX OSN 9800 M12 series subrack to support physical-layer
clocks, IEEE 1588v2, and ITU-T G.8275.1/G.8273.2.
● Added the TNU4CTU system control boards of the OSN 9800 U type series
subracks to support physical-layer clocks, IEEE 1588v2, and ITU-T G.8275.1.
● Added the 1800 II TP subracks to support physical-layer clocks, IEEE 1588v2,
and ITU-T G.8275.1/G.8273.2.
● Added the configuration guide for NCE.
Contents
obtain the active and standby clock sources from the building integrated timing
supply (BITS) system to implement clock synchronization on the entire network.
The PTN/SDH network needs only to use the clock source of the WDM/OTN
network to implement clock synchronization, and then provides the clock source
for base stations to achieve synchronization.
With the development of wireless networks such as LTE TDD and LTE FDD, service
networks, especially radio access networks (RANs), have strict requirements on
clock synchronization.
Solution Comparison
WDM/OTN devices support the following frequency synchronization solutions. You
are advised to use the same solution on an entire WDM/OTN network.
Typical Scenario
The following figure uses physical clocks as an example to describe the typical
scenario of frequency synchronization. In this scenario, all devices on the
WDM/OTN network must support physical clocks.
NOTE
The protection frequency tracing path shown in the preceding figure is an example of the
path for transmitting clock signals after the clock source is switched to the slave BITS
because the master BITS is faulty. The active and standby clock sources cannot be
concurrently transmitted on the network.
Solution Comparison
WDM devices support the following phase synchronization solutions. You are
advised to use the same solution on an entire WDM/OTN network.
Frequency synchronization is the basis of phase synchronization. That is, the
frequencies of devices with synchronized phases must also be synchronized.
IEEE 1588v2 frequency and This solution features easy deployment and
phase synchronization simple O&M. Compared with physical clock
frequency synchronization+IEEE 1588v2 phase
synchronization, this solution provides lower
synchronization precision but requires higher
bandwidth usage.
Solution Description
ITU-T G.8275.1 for frequency The BMCA algorithm is used to prevent reverse
synchronization and phase tracing.
synchronization
● (Recommended) 1PPS+TOD external time port: When the phase source needs
to be obtained from the BITS or the master and slave time subracks need to
be cascaded, the 1PPS+TOD external time port can be used to obtain the
phase source.
● Ethernet port: When the WDM/OTN devices are interconnected with PTN
devices, SDH devices, or routers, you are advised to obtain the phase source
from the Ethernet port.
Typical Scenario
The following figure uses physical-layer clocks + IEEE 1588v2 as an example to
describe a typical scenario of phase synchronization. In this scenario, all devices on
the WDM/OTN network must support IEEE 1588v2.
NOTE
The protection frequency tracing path shown in the preceding figure is an example of the
path for transmitting clock signals after the clock source is switched to the slave BITS
because the master BITS is faulty. The active and standby clock sources cannot be
concurrently transmitted on the network.
The phase tracing paths shown in the figure are used for reference only. On a practical
network, each NE determines the phase tracing paths based on algorithms.
NOTE
The protection frequency tracing path shown in the preceding figure is an example of the
path for transmitting clock signals after the clock source is switched to the slave BITS
because the master BITS is faulty. The active and standby clock sources cannot be
concurrently transmitted on the network.
The phase tracing paths shown in the figure are used for reference only. On a practical
network, each NE determines the phase tracing paths based on algorithms.
Description
In physical clock synchronization mode, WDM devices restore frequency signals
from physical signals such as Ethernet links, packet links, and SDH links to achieve
frequency synchronization between upstream and downstream devices. Physical
clocks require the device hardware to support clock extraction. Therefore, to
achieve network-wide frequency synchronization, each node must support
physical-layer clocks.
Application Scenario
Physical clocks can be used in the following scenarios:
● Physical-layer clock (OTN tributary): Supports synchronous Ethernet
processing and synchronous Ethernet transparent transmission to implement
frequency synchronization.
– Synchronous Ethernet processing: The system clock performs frequency
synchronization for upstream NEs one at a time. Synchronous Ethernet
processing can be used with IEEE 1588v2 to implement phase
synchronization.
– Synchronous Ethernet transparent transmission: It only transmits the
clock to the destination node to guarantee clock quality. This achieves
only internal free-run on an NE but no frequency synchronization with
the upstream NE. Synchronous Ethernet transparent transmission cannot
work with IEEE 1588v2 to implement phase synchronization.
● Physical clock (packet): On a packet network, packet boards can be used to
implement frequency synchronization.
NOTE
The protection frequency tracing path shown in the preceding figure is an example of the
path for transmitting clock signals after the clock source is switched to the slave BITS
because the master BITS is faulty. The active and standby clock sources cannot be
concurrently transmitted on the network.
2.2 Principles
At the physical layer, clock reference information is transported to each control
point with high accuracy based on the master-slave relationship between nodes
and the clock synchronization mechanism.
NOTICE
Figure 2-2 Clock source priorities when the SSM protocol is disabled
Clock Source ID
For simple networks such as chain networks, only the clock priority table needs to
be configured for clock protection. Clock source protection is not required. For
complex networks including ring networks and their derived networks such as
tangent and intersecting ring networks, the extended SSM protocol must be
enabled for clock source protection. To prevent clock loops, the clock source ID
must be configured.
● A clock source ID uses bit 1 to bit 4 of an SSM byte, and the value ranges
from 0x0 to 0xf. Basically, a clock source ID is used to distinguish the clock
information between local and other nodes to prevent a node from tracing
the clock signal that is locally transmitted and comes from the negative
direction. Hence, a timing loop is prevented.
● A value of 0 indicates that a clock source ID is invalid. Hence, the default
value of a clock source ID is 0 when an ID is not set for a clock source. When
enabling the extended SSM protocol, an NE does not select the clock source
whose ID is 0 as the current clock source.
● A clock source ID is a tag set for a reference timing source. The clock sources
at the same quality level that carry different IDs mean different timing signals
and are not different in priority levels and other aspects.
Set the clock source ID according to the following principles:
● Allocate a clock source ID to each external BITS device.
● Allocate a clock source ID to the internal clock source of each node that has
an external BITS device.
● Allocate a clock source ID to the internal clock source of each node that
enters into another ring network from one chain or ring network.
● Allocate a clock source ID to the line clock source of the node that enters into
another ring network from one chain or ring network when the line clock
source exists.
As shown in Figure 2-3, the PTN device obtains clock signals from the connected
BITS device and sends the clock signals to the connected product on the OTN
network over Ethernet services. Then, the product transmits the clock signals to
other devices on the network to implement frequency synchronization for the
entire network. All the NEs on the WDM/OTN network enable the extended SSM
protocol for clock source protection.
Basic Concepts
The following concepts are used in this document:
● Physical clock loop: indicates the logical clock loop state where an NE traces
an external clock source but finally traces the NE itself. If configurations are
incorrect, it may occur in various scenarios such as physical ring, chain, and
mesh networking. Mutual clock tracing between two NEs is the simplest clock
loop.
● Bidirectional clock path: indicates the interconnection link between two NEs
that is configured as the clock source tracing path by both NEs. For example,
NE A and NE B are interconnected through link K. On link K, clock signals
may be transmitted from NE A to NE B or from NE B to NE A depending on
the network status.
● Unidirectional clock path: indicates the interconnection link between two NEs
that is configured as the clock source tracing path by only one NE.
Typical Scenario
Table 2-2 lists the protection capabilities and precautions when different clock
protocols are used on typical ring and chain networks. A mesh network can be
considered as multi-level logical ring networks. The scenario where only two NEs
are interconnected can be considered as a special case of a chain network.
Standard ● Supports ring protection ● The first and last NEs can The standard SSM
SSM for clock paths. be connected to the protocol has good
protocol ● Supports master and master and slave BITS compatibility and is
slave BITS protection. devices separately for recommended when
protection. there is no special
For details, see Standard requirement.
SSM Protocol. ● Link fault protection is
not supported.
For details, see Standard
SSM Protocol.
Extended ● Supports ring protection ● The first and last NEs can The extended SSM
SSM for clock paths. be connected to the protocol is complex
protocol ● Supports master and master and slave BITS to configure.
slave BITS protection. devices separately for Therefore, it is used
protection. only when necessary.
● Supports protection
against multi-point path ● Supports link fault
faults. protection.
For details, see Extended For details, see Extended
SSM Protocol. SSM Protocol.
Non-SSM ● Ring protection for clock ● Only supports protection Non-SSM protocol
protocol paths is not supported. for multiple clock links in applies only to
● Master and slave BITS one direction. simple networking.
devices cannot be ● Master and slave BITS
configured for two NEs devices cannot be
for protection. configured for two NEs
For details, see Non-SSM for protection.
Protocol. For details, see Non-SSM
Protocol.
If clock links are correctly selected and clock source priorities are correctly
configured, services can be protected against a BITS fault or a link fault on the
ring network, as shown in Figure 2-4.
Figure 2-4 Example of correct ring network configuration (standard SSM protocol)
If the clock loop prevention links are not correctly configured on the ring network,
a loop may occur, as shown in Figure 2-5.
Non-SSM Protocol
When a ring network uses a non-SSM protocol, it does not support ring protection
for clock paths or master and slave BITS protection. In this case, you need to
divide the physical ring into two logical clock links. The basic configuration
principles are as follows:
● Only unidirectional clock paths can be configured. You can configure one or
two clock links on the ring.
● Two NEs cannot mutually use the peer NE as the alternative clock source.
● If multiple links exist between two NEs, you can plan multiple unidirectional
clock paths from the upstream NE to the downstream NE. The clock source
priority table can be configured to implement protection switching.
If BITS protection is not required, multiple unidirectional clock paths can be configured
between two NEs. In this case, the SSM protocol does not take effect. For details, see
the scenario where a non-SSM protocol is used.
Configure only one bidirectional clock path between NEs, as shown in Figure 2-8.
The standard SSM protocol supports clock source protection switching based on
the clock source quality information and clock source priority table.
If multiple clock paths are incorrectly configured between NEs, a clock loop may
occur when all external clock sources fail, as shown in Figure 2-9.
When the standard SSM protocol is used and no external BITS devices are
connected, multiple bidirectional clock paths cannot be configured between two
NEs either, and unidirectional clock paths with opposite tracing directions cannot
be configured on multiple links, as shown in Figure 2-13.
Non-SSM Protocol
When a network uses a non-SSM protocol, only unidirectional clock link protection
is supported, and master and slave BITS protection cannot be configured on two
NEs. The basic configuration principles are as follows:
● Only unidirectional clock paths can be configured between two NEs, and the
two NEs cannot mutually use the peer NE as the alternative clock source.
That is, only the downstream NE can trace the clock of the upstream NE, and
the reverse path is not allowed.
● If multiple links exist between two NEs, you can plan multiple unidirectional
clock paths.
Configure only unidirectional clock paths between NEs, as shown in Figure 2-12.
● Internal clock source: a clock that is generated from free-run oscillation of the
built-in clock of an NE. The internal clock source has the lowest priority
among all clock sources.
NOTE
For the port description and pin definitions of each board, see the panel description of each
board in Hardware Description.
On the NMS, set Enabled Status to specify different working modes. When this parameter
is set to Enabled, the cascading clock mode is used. When this parameter is set to
Disabled, the external clock mode is used.
NOTE
For the CLK&TOD composite port, a transfer cable is required to separate the CLK port from
the TOD port.
For boards that support multiple ports (CLK1/TOD1, CLK2/TOD2 ...), the cascading mode is
similar.
The clock synchronization GE optical port is used for BITS clock input, clock
synchronization between NEs, or clock cascading between master and slave
subracks. The clock synchronization GE optical port supports both physical clock
synchronization and PTP time synchronization, but does not support Ethernet
service transmission. Table 2-6 lists the names and types of the clock
synchronization GE optical ports.
NOTE
The clock synchronization GE optical port can be set to the physical clock cascading mode
or PTP clock cascading mode. On the NMS, set Enabled Status to specify different working
modes. When this parameter is set to Enabled, the cascading mode is used. When this
parameter is set to Disabled, the non-cascading mode is used.
● The clock synchronization GE optical port of the OSN 1800 supports both
non-cascading and cascading modes.
● The clock synchronization GE optical port of the OSN 9800 in
V100R021C00SPC300 or earlier does not support the cascading mode and
cannot be used for clock cascading between master and slave subracks. It is
used only for interconnection between WDM/OTN NEs or for clock/time
synchronization between WDM/OTN NEs and BITS/PTN/base station devices.
● The clock synchronization GE optical port of the OSN 9800 supports the
cascading mode and clock cascading between master and slave subracks since
V100R021C10SPC100.
The clock cascading and non-cascading modes can be set for different ports
separately.
● Figure 2-16 shows the fiber connections when both the cascading and non-
cascading modes are used.
● Figure 2-17 and Figure 2-18 show the fiber connections between NEs.
● Figure 2-19 and Figure 2-20 show the fiber connections for clock cascading
between master and slave subracks.
NOTE
When clock synchronization GE optical ports on system control boards or clock boards are
used for clock synchronization, the clock synchronization GE optical ports on both the active
and standby system control boards or clock boards must be used together to provide clock
protection.
Principle
Figure 2-22 shows the implementation principle of the synchronous Ethernet
function.
When the Ethernet port functions as the clock source of the NE:
1. The PHY component on the Ethernet port restores clocks from the bit streams
of the Ethernet links, divides the frequency, and then transmits the clocks to
the system clock module.
2. The system clock module selects the clock with the highest priority according
to the clock source priority table and synchronizes the clock with the system
clock.
When the Ethernet port functions as the output clock of local NE to the
downstream device:
NOTE
The support for synchronous Ethernet of Ethernet ports on packet boards and EoS boards
do not depend on service encapsulation types. For these ports, only synchronous Ethernet
processing is supported, and synchronous Ethernet transparent transmission is not
supported.
When Ethernet services are received by tributary ports on an OTN board, the port
supporting synchronous Ethernet varies according to the encapsulation type. The
following table lists the details.
Output of the external ● When AST2/AST4 functions as the OSC and clock
clock transmission board, it cannot be used as the phase-
locked source output by the external clock port.
● For OSN 9800 earlier than V100R001C20SPC300,
only the second external clock port CLK2 on the EFI
board can correctly export line source clocks, and
the outputs of the CLK1 and CLK2 external clock
ports on the EFI board must be the same. To
correctly export different line source clocks using
the CLK1 and CLK2 external clock ports on the EFI
board, you must upgrade the EFI board software to
OSN 9800 V100R001C20SPC300 or later.
AUX boards of the OSN When an OSN 1800 NE is configured with multiple
1800 AUX boards (F1AUX/B1AUX/B2AUX), you need to set
one AUX board as the main AUX board.
● In the master/slave subrack scenario, the main AUX
board must be configured on the master subrack.
● For the use restrictions on the external clock/time
ports of the TMB1AUX/TMB2AUX board, see Table
2-9.
Clock source ● The central node or the node with high reliability
provides the clock source.
● If there is a Building Integrated Timing Supply
(BITS) device or another external high-precision
clock device on the network, it is recommended
that NEs trace external clock sources. If there is no
BITS device or another external high-precision
clock device on the network, it is recommended
that NEs trace line clock sources. The internal clock
source usually has the lowest priority among all
the clock sources.
● Clock signals need to be compensated after a long
clock chain to avoid the drift of clock signals after
they are transmitted through multiple sites. ITU-T
G.781 stipulates that clock compensation is
required on a long chain consisting of 20 or more
NEs. Considering the transmission distance of
fibers, clock compensation is performed in practice
on a long chain consisting of more than 10 NEs.
● If a long clock chain contains more than 20 NEs,
clock signals need to be output to the BITS through
a 2M clock port (CLK port) for regeneration.
Moreover, the regenerated clock signals should be
sent back to the NEs and serve as the clock source
to be transmitted to the line side.
Shortest path If NEs need to trace a line clock source, ensure that
the clock tracing path is the shortest. The details are
as follows:
● On a ring network consisting of fewer than six NEs,
the NEs can trace the reference clock source in one
direction.
● On a ring network consisting of six or more NEs,
ensure that the tracing path is the shortest. That is,
on a ring network consisting of N NEs, a half of
the NEs trace the reference clock source in one
direction and the other half of the NEs trace the
reference clock source in the other direction. (If N
is an odd number, the intermediate NE can trace
the reference clock source in either of the
directions.)
Clock synchronization For the current OSN 1800 version, slave subracks
of slave subracks support clock synchronization only when master and
slave subracks are cascaded.
In a slave subrack, only the following boards support
clock synchronization (that is, the ports on the
following boards are used as clock source ports):
● B1AUX/B2AUX: HPn port
● TMB1DFS/TMB1SFS/TMB1FS: HP port
● TMB1CMD4: TX1/RX1 port
Other types of ports, such as OSC clock sources, line
clock sources, and Ethernet service ports, do not
support clock synchronization.
Table 2-9 Use restrictions on the external clock/time ports of the TMB1AUX/
TMB2AUX board
Board External External Clock/Time Clock
Clock/Time Output (CLKn/TODn) Cascading
Input Between
(CLKn/ Master and
TODn) Slave
Subracks
(CLKn/TODn)
Fiber Doctor system When the AST4 board works with the F5XCH/
F5UXCME/F5UXCM board, the line fiber quality
monitoring function and physical clocks or IEEE
1588v2 are mutually exclusive. If both are configured,
physical clocks and IEEE 1588v2 will become
abnormal.
When the AST2 board works with the 11STG/12STG/
K2STG/16SCC/16XCH/16UXCM board, the line fiber
quality monitoring function and physical clocks or
IEEE 1588v2 are mutually exclusive. If both are
configured, physical clocks and IEEE 1588v2 will
become abnormal.
2.4 Availability
This topic describes the board types and software versions that support physical
clocks.
Table 2-12 Boards and device versions that support physical clocks (OTN & Packet
& SDH) in the OSN 9800 universal platform subrack (optical-layer configuration)
TN13STG V100R002C10
AST2 V100R002C10
Table 2-13 Boards and device versions that support physical-layer clocks (OTN,
packet, and SDH) in OSN 9800 P series subracks (optical-layer configuration)
TMP3CTU V100R022C10
Table 2-14 Boards and device versions that support physical-layer clocks (OTN,
packet, and SDH) in OSN 9800 U series subracks (electrical-layer configuration)
TNS1CTU V100R001C30
TNU5CTU V100R019C10
TNV1EMS12 V100R021C10
U402 V100R005C00
TNU2N401P V100R006C10
When Ethernet services are received by tributary ports on an OTN board, the port
supporting synchronous Ethernet varies according to the encapsulation type. The
following table lists the details.
NOTE
NOTE
The packet service boards in Table 2-14 support synchronous Ethernet when receiving Ethernet
services.
Table 2-16 Boards and device versions that support physical-layer clocks (OTN,
packet, and SDH) in OSN 9800 M series subracks
Board Type Board Name Start Version
TME3CTU V100R020C10
TNG4CXP V100R021C00
TMF2AUX01 V100R021C10
TMF2AUX V100R021C10
TNG1T210E V100R022C10
N501P V100R006C10
When Ethernet services are received by tributary ports on an OTN board, the port
supporting synchronous Ethernet varies according to the encapsulation type. The
following table lists the details.
NOTE
Table 2-18 Boards and device versions that support physical-layer clocks (OTN
and packet) in OSN 8800 subracks
TN16XCH V100R006C00
TN16SCC V100R006C01
TN16UXCM V100R007C00
TN12STGa V100R008C10
TN54STG V100R009C10
AST2 V100R011C00
TEM28 V100R006C03
TN55TTX V100R009C00
EX8 V100R008C10
TN55TSC V100R011C10
LQCP V100R013C00
TN54NS3 V100R005C00
PND2 V100R007C00
Table 2-19 Boards and device versions that support physical-layer clocks (SDH) in
OSN 8800 subracks
TN54STG V100R009C10
TNK3STG V100R010C10
TN54HSNS4 V100R011C10
NOTE
The TX2/RX2 and TX4/RX4 optical ports of the N1EGSH board can process synchronous
Ethernet clock signals.
When Ethernet services are received by tributary ports on an OTN board, the port
supporting synchronous Ethernet varies according to the encapsulation type. The
following table lists the details.
Table 2-21 Boards and device versions that support physical-layer clocks (OTN) in
OSN 6800 subracks
Board Type Board Name Start Version
TN12STG V100R008C10
TN13STG V100R010C10
AST2 V100R011C00
When Ethernet services are received by tributary ports on an OTN board, the port
supporting synchronous Ethernet varies according to the encapsulation type. The
following table lists the details.
Table 2-23 Boards and device versions that support physical-layer clocks (OTN,
packet, and SDH) in OSN 1800 V subracks
TMB2AUX V100R021C10
AST4 V100R006C20
TMB1AST2 V100R009C00
TMB2AST2 V100R019C10
TDX V100R005C10
TTA V100R006C20
TSC V100R007C10
TMB1LQCB V100R022C00
HSNQ2 V100R005C10
Z5UNQ2 V100R006C10
TNZ8UNS4/TNZ9UNS4 V100R021C00
TNF3ELOM V100R020C10
TMB1LQCB V100R022C00
TMB1EG10 V100R021C10
TSP V100R006C20
TMB1PL1D V100R020C10
TMB2PD1 V100R021C00
EMS10 V100R019C10
TMB2EGS4 V100R021C00
HSNQ2 V100R005C10
F5NS4 V100R006C00
UNQ2 V100R006C10
TMB3SL41S V100R022C00
NOTE
● In ODU1_ODU0 mode (OTU1->ODU1->ODU0), the TOA/TTA board receives OTU1
services from the client side and supports physical-layer clock processing, but does not
support transparent transmission of physical-layer clock signals.
● When an electrical module is installed into a port, physical-layer clocks are not
supported.
● When the ODUk cross-connect granularity of an OTN line port is set to the maximum
granularity supported by the port, the physical-layer clock synchronization is not
supported. For OTN line ports, physical-layer clocks can be used only when lower-order
ODUk cross-connections are configured for the ports.
● For the tributary ports that receive Ethernet services, physical-layer clocks can be used
only after services are configured for the ports.
● In regeneration mode, boards support only transparent transmission of physical-layer
clocks, but not support physical-layer clock synchronization.
● The AUX board is an auxiliary board that provides the clock function.
a: The MD1 board supports physical-layer clocks (SDH) only when the SSM protocol is not
used.
When Ethernet services are received by tributary ports on an OTN board, the port
supporting synchronous Ethernet varies according to the encapsulation type. The
following table lists the details.
NOTE
● When receiving GE/10GE LAN/CPRI/OBSAI services, the OSN 810 (C15XnR) and OSN
810 (C15Xn) boards support transparent transmission of physical-layer clocks but do not
support processing of physical-layer clocks.
Table 2-25 Boards and device versions that support physical-layer clocks (OTN,
packet, and SDH) in OSN 1800 II Enhanced subracks
TMB2AUX V100R021C10
TMB1AST2 V100R009C00
TMB2AST2 V100R019C10
TMB2LDC V100R021C10
TNF3ELOM V100R020C10
TMB2LDC V100R021C10
TMB1EG10 V100R021C10
TMB1PL1D V100R020C10
TMB2PD1 V100R021C00
EMS10 V100R019C10
TMB2EGS4 V100R021C00
TMB3SL41S V100R022C00
When Ethernet services are received by tributary ports on an OTN board, the port
supporting synchronous Ethernet varies according to the encapsulation type. The
following table lists the details.
Table 2-27 Boards and device versions that support physical-layer clocks (OTN
and packet) in OSN 1800 I Enhanced subracks
Board Type Board Name Start Version
TMB1EG10 V100R021C10
TMB1PL1D V100R020C10
EMS10 V100R019C10
TMB2EGS4 V100R021C00
TMB3SL41S V100R022C00
NOTE
● The UXCL (G12A) board supports physical-layer clocks (packet) since 1800 I Enhanced
V100R008C10 and supports physical-layer clocks (OTN) since 1800 I Enhanced
V100R009C00.
● When the ODUk cross-connect granularity of an OTN line port is set to the maximum
granularity supported by the port, the physical-layer clock synchronization is not
supported. For OTN line ports, physical-layer clocks can be used only when lower-order
ODUk cross-connections are configured for the ports.
● For the tributary ports that receive Ethernet services, physical-layer clocks can be used
only after services are configured for the ports.
● In regeneration mode, boards support only transparent transmission of physical-layer
clocks, but not support physical-layer clock synchronization.
a: The MD1 board supports physical-layer clocks (SDH) only when the SSM protocol is not
used.
When Ethernet services are received on an OTN board, the port supporting
synchronous Ethernet varies according to the encapsulation type. The following
table lists the details.
Table 2-29 Boards and device versions that support physical-layer clocks (OTN) in
OSN 1800 I&II Compact subracks (TNF3SCC)
Board Type Board Name Start Version
AST4 V100R006C20
TMB1AST2 V100R009C00
TMB2AST2 V100R019C10
F1LDCA V100R008C10
TNF3ELOM V100R020C10
Table 2-30 Boards and device versions that support physical-layer clocks (SDH) in
OSN 1800 I&II Compact subracks (TNF3SCC)
Board Type Board Name Start Version
When Ethernet services are received by tributary ports on an OTN board, the port
supporting synchronous Ethernet varies according to the encapsulation type. The
following table lists the details.
Table 2-32 Boards and device versions that support physical-layer clocks in OSN
1800 V Pro subracks
Board Type Board Name Start Version
TMB1LQCB V100R022C00
TMK1UNS4MP V100R022C10
TNF3ELOM V100R020C10
TMB1LQCB V100R022C00
TMB3SL41S V100R022C00
TMB1PL1D V100R020C10
TMB2PD1 V100R021C00
TMB2EGS4 V100R021C00
TMB3EMS10D V100R022C10
NOTE
● When an electrical module is installed into a port, physical-layer clocks are not
supported.
● When the ODUk cross-connect granularity of an OTN line port is set to the maximum
granularity supported by the port, the physical-layer clock synchronization is not
supported. For OTN line ports, physical-layer clocks can be used only when lower-order
ODUk cross-connections are configured for the ports.
● For the tributary ports that receive Ethernet services, physical-layer clocks can be used
only after services are configured for the ports.
● In regeneration mode, boards support only transparent transmission of physical-layer
clocks, but not support physical-layer clock synchronization.
● The AUX board is an auxiliary board that provides the clock function.
When Ethernet services are received by tributary ports on an OTN board, the port
supporting synchronous Ethernet varies according to the encapsulation type. The
following table lists the details.
Table 2-34 Boards and device versions that support physical-layer clocks in OSN
1800 II Pro subracks
TMB2AUX V100R021C10
TMB1LQCB V100R022C00
TMK1UNS4MP V100R022C10
TNF3ELOM V100R020C10
TMB1LQCB V100R022C00
TMB3SL41S V100R022C00
TMB1PL1D V100R020C10
TMB2PD1 V100R021C00
TMB2EGS4 V100R021C00
TMB3EMS10D V100R022C10
NOTE
● When an electrical module is installed into a port, physical-layer clocks are not
supported.
● When the ODUk cross-connect granularity of an OTN line port is set to the maximum
granularity supported by the port, the physical-layer clock synchronization is not
supported. For OTN line ports, physical-layer clocks can be used only when lower-order
ODUk cross-connections are configured for the ports.
● For the tributary ports that receive Ethernet services, physical-layer clocks can be used
only after services are configured for the ports.
● In regeneration mode, boards support only transparent transmission of physical-layer
clocks, but not support physical-layer clock synchronization.
● The AUX board is an auxiliary board that provides the clock function.
When Ethernet services are received by tributary ports on an OTN board, the port
supporting synchronous Ethernet varies according to the encapsulation type. The
following table lists the details.
Table 2-36 Boards and device versions that support physical-layer clocks
Board Type Board Name Start Version
TMB2AST2 V100R019C10
TMB1LQCB V100R022C00
TNF3ELOM V100R020C10
TMB1LQCB V100R022C00
When Ethernet services are received by tributary ports on an OTN board, the port
supporting synchronous Ethernet varies according to the encapsulation type. The
following table lists the details.
Table 2-38 Boards and device versions that support physical-layer clocks (OTN
and packet) in OSN 1800 I Compact subracks
Board Type Board Name Start Version
When Ethernet services are received by an OTU board, the port supporting
synchronous Ethernet varies according to the encapsulation type. The following
table lists the details.
2.5 Specifications
This section describes the physical-layer clock specifications supported by the
equipment.
Item Specifications
Maximum number of 20
NEs on a clock chain
Item Specifications
Item Specifications
NOTE
This topic records feature updates of boards. However, new board hardware is not recorded
as feature updates. For details, see the "Availability" section.
The OptiX Added a new 2.4.4 OSN 9800 M Series Hardware and
OSN 9800 subrack to Version Support
M05 subrack support basic
configured functions.
with the
TME1CTU/
TME2CTU
board is
added to
support
physical-layer
clocks.
The TNU5CTU The product 2.4.3 OSN 9800 U Series Hardware and
board of the function is Version Support
OSN 9800 U enhanced.
series subrack
is added to
support
physical-layer
clocks.
The TNG4CXP The product 2.4.4 OSN 9800 M Series Hardware and
board of the function is Version Support
OSN 9800 enhanced.
M24 subrack
is added to
support
physical-layer
clocks.
The OSN Added a new 2.4.4 OSN 9800 M Series Hardware and
9800 M12 subrack to Version Support:
subrack is support basic Added OSN 9800 M12 subrack-related
added to functions. information.
support
physical-layer
clocks.
The TNU4CTU The product ● 2.4.3 OSN 9800 U Series Hardware and
board of the function is Version Support: Added the TNU4CTU
OSN 9800 U enhanced. board.
series subrack ● 2.8.1 Configuring Physical-Layer Clocks
is added to (OSN 1800/8800/9800Universal Platform
support Subrack/M Series/P Series/(U Series:
physical-layer U2CTU/S2CTU/U4CTU/U5CTU)): Added
clocks. the TNU4CTU board.
The TNG3CXP The product 2.4.4 OSN 9800 M Series Hardware and
board of the function is Version Support
OSN 9800 enhanced.
M24 subrack
is added to
support
physical-layer
clocks.
The OSN The product 2.4.2 OSN 9800 P Series Hardware and
9800 P series function is Version Support:
subrack is enhanced. Added the description of the OSN 9800 P
added to series subrack.
support
physical-layer
clocks.
The TNU2CTU The product ● 2.4.3 OSN 9800 U Series Hardware and
and TNS2CTU function is Version Support: Added TNU2CTU and
boards of the enhanced. TNS2CTU.
OSN 9800 U ● 2.8.1 Configuring Physical-Layer Clocks
series subrack (OSN 1800/8800/9800Universal Platform
are added to Subrack/M Series/P Series/(U Series:
support U2CTU/S2CTU/U4CTU/U5CTU)): Added
physical-layer TNU2CTU and TNS2CTU.
clocks.
The OSN 9800 M24 Added a new subrack to 2.4.4 OSN 9800 M
subrack is added to support basic functions. Series Hardware and
support physical-layer Version Support:
clocks. Added OSN 9800 M24
subrack-related
information.
The OSN 9800 U16 Added a new subrack to 2.4.3 OSN 9800 U Series
subrack is added to support basic functions. Hardware and Version
support physical-layer Support:
clocks. The OSN 9800 U16
subrack is added.
Updates in V100R001C20
Feature Update Reason for the Change Information Update
The OSN 8800 universal The clock functions are 2.3 Dependencies and
platform subrack newly enhanced. Limitations:
supports physical clocks. Descriptions of the OSN
8800 universal platform
subrack are added.
The EX2 and EG16 To enhance the clock 2.4.5 OSN 8800
boards are added, and functions of packet Hardware and Version
they support physical service boards. Support:
clocks. A description is added to
explain that packet
service boards support
physical clocks.
The new 1800 V Pro This subrack is new to Added 2.4.11 OSN 1800
chassis supports the product and should V Pro Hardware and
physical-layer clocks. support basic device Version Support.
functions.
The new 1800 II Pro This subrack is new to Added 2.4.12 OSN 1800
chassis supports the product and should II Pro Hardware and
physical-layer clocks. support basic device Version Support.
functions.
The new 1800 II TP This subrack is new to Added 2.4.13 OSN 1800
chassis supports the product and should II TP Hardware and
physical-layer clocks. support basic device Version Support.
functions.
The new 1800 This subrack is new to the product and should Added 2.4.9
I Enhanced support basic device functions. OSN 1800 I
chassis Enhanced
supports Hardware
physical-layer and Version
clocks (SDH Support.
and packet).
The new 1800 This subrack is new to the product and should Added 2.4.8
II Enhanced support basic device functions. OSN 1800 II
chassis Enhanced
supports Hardware
physical-layer and Version
clocks (OTN, Support.
SDH, and
packet).
Operation Description
Operation Description
Operation Description
Prerequisites
You are an NMS user with "Operator Group" privilege or higher.
Procedure
Step 1 Configure the frequency source mode.
NOTE
Before configuring clocks, you need to set the frequency source mode as required.
● If physical-layer clock frequency synchronization is used, select Physical
Synchronization.
● If IEEE 1588v2 frequency synchronization is used, select PTP Synchronization.
----End
Prerequisites
You are an NMS user with "Operator Group" privilege or higher.
Context
NOTICE
Changing the service type between GE(TTT-GMP) and GE(GFP-T) for a board will
interrupt services on the board. After the operation, the services will be
automatically restored.
NOTICE
For the OSN 6800, changing the value of Synchronous Clock Enabled for a board
will cause a transient service interruption on the board.
Procedure
Step 1 Set Service Type and Port Mapping for OTN boards.
For details about how to configure synchronous Ethernet on each board, see 2.4
Availability.
Step 2 Optional: Configure Synchronous Clock Enabled. For details about the
parameters, see 2.8.1.15.2 Parameters: Clock Attribute Configuration.
Step 3 Optional: When the following boards are interconnected with third-party devices,
you must set parameter SSM Timeout Period (500ms) for these boards to
guarantee SSM quality. You do not need to configure other boards. For details
about the parameters, see 2.8.1.15.2 Parameters: Clock Attribute Configuration.
NOTE
----End
Prerequisites
You are an NMS user with "Operator Group" privilege or higher.
Procedure
Step 1 Configure the clock center subrack.
----End
Prerequisites
You are an NMS user with "Operator Group" privilege or higher.
Context
● In the master/slave subrack scenario, the main AUX board must be configured
on the master subrack.
● For the use restrictions on the external clock/time ports of the TMB1AUX/
TMB2AUX board, see Table 2-9.
Procedure
Step 1 Configure the main AUX board.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● A clock board and a clock interface board have been created.
NOTICE
For the OSN 1800, if the TNF1AUX board is required, you must create the STG
logical board and then the AUX logical board. Otherwise, the external clock/
time port of the TNF1AUX board cannot work properly. In this case, you need
to delete and re-create the logical AUX board.
● For the OSN 6800, when concatenation of the external ports of a clock board
is configured, the 120-ohm external clock port cable should be used as the
network cable for concatenation.
NOTE
When an NE is equipped with master and slave subracks, you need to specify a subrack
with a clock board as the clock center subrack. If other subracks receive clock signals from
the upstream or output time signals to the downstream, you need to set the clock
cascading relationship between these subracks and the clock center subrack and correctly
connect the subracks. For details, see 2.8.1.4 Configuring the Clock Center Subrack under
2.8.1.1 Configuration Process.
When an OSN 1800 NE is configured with multiple AUX boards (F1AUX/B1AUX/B2AUX),
you need to set one AUX board as the main AUX board. For details, see 2.8.1.5 Configuring
a Main AUX Board under 2.8.1.1 Configuration Process.
● Each subrack has two clock ports and two time ports. These ports are used to
concatenate and transmit the clock or time signals among multiple subracks,
or are used to input or output external clock and time signals. By default,
Enabled Status of all ports is Unused. If any ports need to be used for the
input or output of external clock and time signals, Enabled Status of the
corresponding ports should be set to Disabled. One NE supports a maximum
of two ports for the input or output of external clock and time signals.
● After PTP Synchronization is enabled for an NE, the NE automatically
switches the frequency source mode to Physical Synchronization when
Enabled Status of the external clock port on the NE's clock board changes
from Enabled to Disabled or changes from Unused to Disabled. When this
occurs, manually set the frequency source mode of the NE to PTP
Synchronization.
NOTE
For details about the ports that support the cascading mode, see "Clock cascading between
master and slave subracks" in 2.5 Specifications.
Step 1 Configure Enabled Status. For details about the parameters, see 2.8.1.15.3
Parameters: Clock Port Link.
----End
Step 1 Configure Phase-Locked Source Output by External Clock. For details about the
parameters, see 2.8.1.15.16 Parameters: Phase-Locked Source Output by
External Clock.
NOTE
In the case of forced shutdown of the output of external clocks, the 2 Mbit/s and 2 MHz
two external clocks are shut down and there is no output signal from the two clocks. This
operation has a higher shutdown priority than all other automatic shutdown functions
provided by software. By default, the forced shutdown of the external clock output is
disabled.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● A clock synchronization GE optical port has been created on the NE Panel.
NOTE
Clock Cascading Status can be set to Enabled only when Synchronous Clock
Enabled of the clock synchronization GE optical port is set to Disabled. Clock
Cascading Status can be set to Disabled only when Synchronous Clock Enabled is
set to Enabled. For details, see Step 2 in 2.8.1.3 Configuring the Synchronization
Attributes of a Board.
Context
Clock cascading (frequency synchronization) and PTP cascading (time
synchronization) of clock synchronization GE optical ports can be configured
separately.
Enabled: The port works in cascading mode and is used for clock cascading
between master and slave subracks. The cascading port runs the internal protocol
of the NE.
● When Clock Cascading Port is set to Enabled, the cascading port does not
need to be added to the clock source priority list of the physical clock.
● When PTP Cascading Port is set to Enabled, you do not need to create a PTP
port.
Disabled: When the port works in the common synchronous Ethernet or PTP
mode, it supports interconnection with other NEs or devices.
● When Clock Cascading Port is set to Disabled, you need to add this
cascading port to the clock source priority list of the physical clock.
● When PTP Cascading Port is set to Disabled, you need to create a PTP port
as planned.
Procedure
Step 1 Configure the cascading mode of the clock GE optical port.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The required boards have been created.
Precautions
NOTICE
NOTE
Step 2 Select a clock source and click or to adjust the clock source
priority.
Step 3 Optional: Select a clock source and then click Delete to delete the clock source.
For details about the parameters, see 2.8.1.15.4 Parameters: System Clock
Source Priority List.
----End
Step 1 Check the 2M PLL clock source of the external clock port.
NOTE
● The relationship between the 2M PLL clock source and the external clock port depends
on the sequence of setting the cascaded external ports on the clock board.
● When the optical supervisory channel and clock transmission unit is AST2/AST4, the 2M
priority table cannot be configured.
Step 2 Configure Priority for PLL Clock Sources of 1st External Output or Priority for
PLL Clock Sources of 2nd External Output.
Step 3 Select a clock source and click or to adjust the clock source
priority.
NOTE
Step 5 Optional: Select a clock source and then click Delete to delete the clock source.
For details about the parameters, see 2.8.1.15.5 Parameters: Priority for PLL
Clock Sources of 1st External Output and 2.8.1.15.6 Parameters: Priority for
PLL Clock Sources of 2nd External Output.
----End
Step 1 Configure Clock Quality. For details about the parameters, see 2.8.1.15.8
Parameters: Clock Source Quality.
NOTE
NOTE
The SSM source selection algorithm of an NE first compares the quality level of a clock
source with the SSM Input Quality Threshold.
● SSM Input Quality Threshold: indicates the lowest input clock quality level. By
default, the value is Not Inferior to G.813 SETS Clock Signal.
● If the quality level is lower than the value of SSM Input Quality Threshold, the NE
reports an SSM_QL_FAILED alarm, and specifies the clock source as unavailable.
● If the quality level is higher than or the same as SSM Input Quality Threshold, the
NE transparently transmits the quality level of the clock source so that the source
selection flow selects the clock as its clock source.
Step 2 Configure Manual Setting of 0 Quality Level. For details about the parameters,
see 2.8.1.15.9 Parameters: Manual Setting of Quality Level 0.
----End
NOTE
● To prevent repeated switching when the clock is unstable, do not set Clock Source WTR
Time(min) to 0.
● Clock Source Hold-Off Time(100ms): The default value is 0, indicating that the hold-
off timer is disabled. The Clock Source Hold-Off Time(100ms) can be set within the
range of 300 ms to 1800 ms with the step length of 100 ms.
● When a clock source for an NE fails, the clock failure status is sent to the source
selection flow only after the time specified by Clock Source Hold-Off Time(100ms)
elapses. This ensures that a short-term clock signal failure is not sent to the source
selection flow for clock source switching.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The relevant board has been created.
NOTICE
If the extended SSM protocol is enabled, you are not advised to change the ID of
the clock source being traced by the master NE when the clock tracing
performance is stable. This ensures proper transmission of clock IDs and prevents
a clock loop.
NOTE
● The same SSM protection protocol must be used within the same clock protection subnet.
● Allocate the same subnet number to NEs tracing the same clock source.
Step 2 Optional: If the Clock Source ID is specified for the line clock of an NE, click the
Clock ID Output tab, and set the Output Clock ID to Enabled. Click Apply. For
details about the parameters, see 2.8.1.15.11 Parameters: Clock ID Status.
----End
Step 1 Set SSM Output. For details about the parameters, see 2.8.1.15.10 Parameters:
SSM Output Control.
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Procedure
Step 1 Query the clock synchronization status.
NOTE
● SSM Output Quality Threshold: indicates the highest output clock quality level. By
default the value is G.811 Clock Signal.
● If the SSM quality level of an NE is equal to or higher than SSM Output Quality
Threshold, the specified SSM Output Quality Threshold is sent to the downstream NE.
● If the SSM quality level is lower than the specified SSM Output Quality Threshold, the
actual clock quality level is sent to the downstream NE.
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Context
When the clock tracing relationship changes, NCE automatically updates the
tracing relationship in the clock view.
Procedure
Step 1 In the Main Topology, select Clock View from the Current View drop-down list.
Then, select an NE whose clocks are to be queried or set from the Object Tree.
Step 2 In the Clock View, right-click and choose Search Clock Link from the shortcut
menu.
Step 3 In the Search Clock Link window, set Clock Type and Search Mode, select the NE
to be queried, and click OK.
Step 4 In the Result dialog box, click Close.
Step 5 View the clock tracing relationships of NEs.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The clock source has been created.
Step 1 Double-click the parameter column and set the alarms and performance events
that are to be used as the clock source switching conditions to Yes. For details
about the parameters, see 2.8.1.15.15 Parameters: Clock Source Switching
Conditions.
----End
Step 1 Enable clock source switching. For details about the parameters, see 2.8.1.15.13
Parameters: Clock Source Switching.
----End
NOTICE
Step 1 Perform clock source switching, including the operation of selecting Forced
Switching or Manual Switching.
NOTE
Before switching the clock source, ensure that a new clock source that is not locked and
that has better quality is created in the priority table.
Step 2 Optional: To restore the automatic clock source selection mode, right-click the
switched clock source and choose Clear Switching.
----End
Prerequisites
You are an NMS user with "Operator Group" privilege or higher.
Context
NOTE
NOTICE
Changing the service type between GE(TTT-GMP) and GE(GFP-T) for a board will
interrupt services on the board. After the operation, the services will be
automatically restored.
Procedure
Step 1 Set Service Type and Port Mapping.
For details about how to configure synchronous Ethernet on each board, see 2.4
Availability.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● Required boards have been created.
Context
Procedure
Step 1 Configure clock pass-through. For details about the parameters, see 2.8.1.15.17
Parameters: Clock Signal Pass-through.
Step 2 Optional: You can delete clock pass-through on the NMS as required. Select the
existing clock pass-through record and click Delete. In the Are you sure to
delete? dialog box that is displayed, click OK.
----End
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Frequency Source Mode from Function Tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, click the NE and choose Configuration > Clock > Clock
Attribute Configuration.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > Port
Cascading from Function Tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Priority from the Function Tree. Click the System
Clock Source Priority List tab.
Parameters
Parameter Value Description
Synchronous Status Byte SA4, SA5, SA6, SA7, SA8 Specifies the timeslots
Default value: SA4 for the SSM quality
information in the input
external clock signals.
● SA4: sa4 timeslot
● SA5: sa5 timeslot
● SA6: sa6 timeslot
● SA7: sa7 timeslot
● SA8: sa8 timeslot
This parameter is valid
only when External
Clock Source Mode is
set to 2Mbit.
2.8.1.15.5 Parameters: Priority for PLL Clock Sources of 1st External Output
When you need to use the line clock source of the equipment as the phase-locked
source, you must configure the priority table for phase-locked sources in this user
interface. In this user interface, you can also query and set priority table for phase-
locked sources of first external output clocks and adjust the priority of each clock
source.
The available clock source with the highest priority can be used as the phase-
locked source to lock the phase of first external output clock. An internal source
can be assigned with the lowest priority level only.
NOTE
When two 2M phase-locked loops (PLLs) are required to track line sources, it is
recommended that the 2M PLLs of OSN 9800 universal platform subracks be used. The 2M
PLLs of OSN 9800 electrical subrack is used to track system clock sources by default.
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Priority from the Function Tree. Click the Priority for
PLL Clock Sources of 1st External Output tab.
Parameters
Field Value Description
Current Trace Source For example: 18- Displays the clock source
ST2-2(RM2/TM2) that the NE is currently
For example: Internal tracing.
Clock Source
2.8.1.15.6 Parameters: Priority for PLL Clock Sources of 2nd External Output
When you need to use the line clock source of the equipment as the phase-locked
source, you must configure the priority table for phase-locked sources in this user
interface. You can also query and set priority table for phase-locked sources of
second external output clocks and adjust the priority of each clock source.
The available clock source with the highest priority can be used as the phase-
locked source to lock the phase of second external output clock. An internal
source can be assigned with the lowest priority level only.
NOTE
When two 2M phase-locked loops (PLLs) are required to track line sources, it is
recommended that the 2M PLLs of OSN 9800 universal platform subracks be used. The 2M
PLLs of OSN 9800 electrical subrack is used to track system clock sources by default.
Navigation Path
In the NE Explorer, click the NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Priority from the Function Tree. On the page that is
displayed, click the Priority for PLL Clock Sources of 2nd External Output tab.
Parameters
Field Value Description
Current Trace Source For example: 18- Displays the clock source
ST2-2(RM2/TM2) that the NE is currently
For example: Internal tracing.
Clock Source
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Physical Clock > Clock Subnet Configuration > Physical Clock Subnet
Configuration from the Function Tree. Click the Clock Subnet tab.
Parameters
Field Value Description
network with
multiple clock
sources. The clock
signal carries
quality
information. It is
used when the
WDM/OTN device
interconnects with
a third-party
device.
● Extended SSM
protocol
– When the
extended SSM
protocol is
enabled, clock
source IDs are
introduced to
prevent clock
loops.
– This protocol is
applicable only to
a ring network. It
is a Huawei
proprietary
protocol and
cannot be used
when the
WDM/OTN device
interconnects with
a third-party
device. If the
extended SSM
protocol is enabled
on an NE, the
standard SSM
protocol can be
configured on the
downstream NEs;
however, if the
standard SSM
protocol is enabled
on an NE, the
extended SSM
protocol cannot be
configured on the
downstream NEs.
It is recommended
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Physical Clock > Clock Subnet Configuration > Physical Clock Subnet
Configuration from the Function Tree. Click the Clock Quality tab. Click the
Clock Source Quality tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Physical Clock > Clock Subnet Configuration > Physical Clock Subnet
Configuration from the Function Tree. Click the Clock Quality tab. Click the
Manual Setting of Quality Level tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Physical Clock > Clock Subnet Configuration > Physical Clock Subnet
Configuration from the Function Tree. Click the SSM Output tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Physical Clock > Clock Subnet Configuration > Physical Clock Subnet
Configuration from the Function Tree. Click the Clock ID Output tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Clock > Clock Source Switching from the Function Tree. Click the Clock Source
Reversion tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Clock > Clock Source Switching from the Function Tree. Click the Clock Source
Switching tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Clock > Clock Synchronization Status from the Function Tree.
Parameters
Field Value Description
SSM protocol is
enabled and the S1
byte synchronization
quality information
output by the
synchronous source is
the G.812 transit
clock.
● G.812 Local Clock:
indicates that the
SSM protocol is
enabled and the S1
byte synchronization
quality information
output by the
synchronous source is
the G.812 local clock.
● SDH equipment
timing source (SETS)
signal: indicates that
the SSM protocol is
enabled and the S1
byte synchronization
quality information
output by the
synchronous source is
the synchronous
equipment timing
source (SETS) clock.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Clock > Clock Source Switching from the Function Tree. Click the Clock Source
Switching Conditions tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Clock > Phase-Locked Source Output by External Clock from the Function Tree.
Parameters
Parameter Value Description
External Clock Output ALL, SA4, SA5, SA6, SA7, Specifies the timeslots
Timeslot SA8 used by the SSM quality
Default value: ALL information in the output
clock signals.
● ALL: All timeslots
● SA4: sa4 timeslot
● SA5: sa5 timeslot
● SA6: sa6 timeslot
● SA7: sa7 timeslot
● SA8: sa8 timeslot
This parameter is valid
only when External
Clock Output Mode is
set to 2Mbit/s.
2M Output S1 Byte
Unavailable or Send
AIS, this parameter is
ineffective.
Navigation Path
In the NE Explorer, click the NE and choose Configuration > Clock > Clock Signal
Pass-through.
Parameters
Field Value Description
Operation Description
Prerequisites
You are an NMS user with "Operator Group" privilege or higher.
Context
NOTE
Since OSN 9800 V100R001C20, you do not need to set Synchronous Clock Enabled for the
OSN 9800.
NOTICE
Changing the service type between GE(TTT-GMP) and GE(GFP-T) for a board will
interrupt services on the board. After the operation, the services will be
automatically restored.
Procedure
Step 1 Set Service Type and Port Mapping.
For details about how to configure synchronous Ethernet on each board, see 2.4
Availability.
Step 2 Add a port to the clock source priority table and set the priority to 0. For details,
see Configuring the System Clock Source Priority Table.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The required CTU board has been created.
----End
Procedure
When a clock signal passes through 10 or more NEs, frequency offset and drift
may occur. As a result, the clock signal transmitted to the downstream NE is
degraded. To prevent this from happening, a 2M phase-locked source must be
used to optimize the clock signal.
Step 1 Set the external clock attributes of the 2M phase-locked source, including the
external clock output switch, output mode, output timeslot, and output threshold.
2.8.2.10.9 Parameters: Phase-Locked Source Output by External ClockFor
details about these parameters, see 2.8.2.10.9 Parameters: Phase-Locked Source
Output by External Clock.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The required boards have been created.
Precautions
NOTICE
NOTE
If a port that supports synchronous Ethernet needs to output synchronous Ethernet clock
signals that carry SSM information, you need to add the port to System Clock Source
Priority List of the NE and set Clock Source Priority to 0. For details about the capabilities
of ports supporting synchronous Ethernet processing, see 2.4.3 OSN 9800 U Series
Hardware and Version Support.
Step 2 Optional: Select a clock source and then click Delete to delete the clock source.
For details about the parameters, see 2.8.2.10.1 Parameters: System Clock
Source Priority List.
----End
Step 1 Check the 2M PLL clock source of the external clock port.
NOTE
The relationship between the 2M PLL clock source and the external clock port depends on
the sequence of setting the cascaded external ports on the clock board.
Step 2 Configure Priority for PLL Clock Sources of 1st External Output List or Priority
for PLL Clock Sources of 2nd External Output List.
NOTE
Step 3 Optional: Select a clock source and then click Delete to delete the clock source.
For details about the parameters, see 2.8.2.10.2 Parameters: Priority for PLL
Clock Sources of 1st External Output and 2.8.2.10.3 Parameters: Priority for
PLL Clock Sources of 2nd External Output.
----End
Step 1 Configure Clock Quality to the desired level. For details about the parameters, see
2.8.2.10.5 Parameters: Clock Source Quality.
NOTE
----End
NOTE
● To prevent repeated switching when the clock is unstable, do not set Clock Source WTR
Time(min) to 0.
● Clock Source HoldOff Time(100ms): The Clock Source HoldOff Time(100ms) can be
set within the range of 300 ms to 1800 ms with the step length of 100 ms.
● When a clock source for an NE fails, the clock failure status is sent to the source
selection flow only after the time specified by Clock Source Hold-Off Time(100ms)
elapses. This ensures that a short-term clock signal failure is not sent to the source
selection flow for clock source switching.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The relevant board has been created.
Procedure
Step 1 Configure Enable Standard SSM Protocol Control or Enable Extend SSM
Protocol Control.
NOTE
The same SSM protection protocol must be used within the same clock protection subnet.
Step 2 Optional: If the Enable Extend SSM Protocol Control is selected, set the Clock
Source ID of the Clock Source. For details about these parameters, see 2.8.2.10.4
Parameters: Clock Subnet.
NOTICE
If the extended SSM protocol is enabled, you are not advised to change the ID of
the clock source being traced by the master NE when the clock tracing
performance is stable. This ensures proper transmission of clock IDs and prevents
a clock loop.
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Procedure
Step 1 Query clock synchronization status. For details about the parameters, see
2.8.2.10.8 Parameters: Clock Synchronization Status.
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Context
When the clock tracing relationship changes, NCE automatically updates the
tracing relationship in the clock view.
Procedure
Step 1 In the Main Topology, select Clock View from the Current View drop-down list.
Then, select an NE whose clocks are to be queried or set from the Object Tree.
Step 2 In the Clock View, right-click and choose Search Clock Link from the shortcut
menu.
Step 3 In the Search Clock Link window, set Clock Type and Search Mode, select the NE
to be queried, and click OK.
Step 4 In the Result dialog box, click Close.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The clock source has been created.
Procedure
When the traceable clock source in a network deteriorates, NEs may not be able
to execute a switch on the clock source. Users need to manually switch the clock
source to prevent clock deterioration from affecting the normal running of NEs.
NOTICE
Step 1 Perform clock source switching, including the operation of selecting Forcible
Source Selection or Manual Source Selection. For details about these
Step 2 Optional: To restore the automatic clock source selection mode, right-click the
switched clock source and choose Clear Source Selection.
----End
Prerequisites
You are an NMS user with "Operator Group" privilege or higher.
Context
NOTE
NOTICE
Changing the service type between GE(TTT-GMP) and GE(GFP-T) for a board will
interrupt services on the board. After the operation, the services will be
automatically restored.
Procedure
Step 1 Set Service Type and Port Mapping.
For details about how to configure synchronous Ethernet on each board, see 2.4
Availability.
----End
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Priority. Click the System Clock Source Priority List
tab.
Parameters
Field Value Description
Clock Source Type For example: Internal Displays the type of the
Clock Source clock source.
Synchronous Status Sa4, Sa5, Sa6, Sa7, Sa8 The Synchronous Status
Byte Default: Sa4 Byte parameter provides
an option to set the
timeslots for the SSM
quality information in
the input external clock
signals.
2.8.2.10.2 Parameters: Priority for PLL Clock Sources of 1st External Output
When you need to use the line clock source of the equipment as the phase-locked
source, you must configure the priority table for phase-locked sources in this user
interface. In this user interface, you can also query and set priority table for phase-
locked sources of first external output clocks and adjust the priority of each clock
source.
The available clock source with the highest priority can be used as the phase-
locked source to lock the phase of first external output clock. An internal source
can be assigned with the lowest priority level only.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Priority. Click the Priority for PLL Clock Sources of
1st External Output List tab.
Parameters
Field Value Description
Clock Source Type For example: Internal Displays the type of the
Clock Source clock source.
2.8.2.10.3 Parameters: Priority for PLL Clock Sources of 2nd External Output
When you need to use the line clock source of the equipment as the phase-locked
source, you must configure the priority table for phase-locked sources in this user
interface. You can also query and set priority table for phase-locked sources of
second external output clocks and adjust the priority of each clock source.
The available clock source with the highest priority can be used as the phase-
locked source to lock the phase of second external output clock. An internal
source can be assigned with the lowest priority level only.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Priority. Click the Priority for PLL Clock Sources of
2nd External Output List tab.
Parameters
Field Value Description
Clock Source Type For example: Internal Displays the type of the
Clock Source clock source.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Subnet Configuration from the Function Tree. Click the
Clock Subnet Configuration Attribute tab.
Parameters
Field Value Description
● Extended SSM
protocol
– When the
extended SSM
protocol is
enabled, clock
source IDs are
introduced to
prevent clock
loops.
– This protocol is
applicable only to
a ring network. It
is a Huawei
proprietary
protocol and
cannot be used
when the
WDM/OTN device
interconnects with
a third-party
device. If the
extended SSM
protocol is enabled
on an NE, the
standard SSM
protocol can be
configured on the
downstream NEs;
however, if the
standard SSM
protocol is enabled
on an NE, the
extended SSM
protocol cannot be
configured on the
downstream NEs.
It is recommended
that the extended
SSM protocol be
enabled on ring
networks.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Subnet Configuration from the Function Tree. Click the
Clock Quality tab.
Parameters
Field Value Description
Clock Source Type For example: Internal Displays the type of the
Clock Source clock source.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Switching. Click the Clock Source Reversion tab.
Parameters
Field Value Range Description
Clock Source HoldOff 3 to 18. The step is 1. Specifies the time period
Time(100ms) Default: 10 from the point when a
clock source switching
condition is generated to
the point when a clock
source switchover occurs.
When a clock source for
an NE fails, the status of
the clock is sent to the
select flow only after the
specified Clock Source
Hold-Off Time(100ms)
elapses so that the NE
can determine whether
to select another clock
source. This parameter
ensures that a short-
term clock signal failure
is not sent to the select
flow for clock source
switching.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Switching. Click the Clock Source Switching tab.
Parameters
Field Value Description
Clock Source Type For example: Internal Displays the type of the
Clock Source clock source.
Switching Source Type For example: Internal This field displays the
Clock Source switched clock source
type that the NE is
tracing.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Synchronization Status from the Function Tree.
Parameters
Field Value Description
Data Output Method in 24th Keep, Long Term The Data Output
Holdover Mode Keep Method in Holdover
Default: 24th Keep Mode parameter
provides an option to set
the method of
outputting data in
holdover mode. When all
the clock sources of an
NE are lost, the NE
enters the holdover
mode. The NE may keep
the latest data forever or
maintain the holdover
state for 24 hours or a
specified period. If the
NE maintains the
holdover state, the NE
switches to the free-run
mode when the period
of 24 hours or a
specified period expires.
Unknown SSM Level G.811 Clock, G.812 TNC, The Unknown SSM
Map G.812 LNC, SDH, Level Map parameter
Unavailable Clock Source provides an option to set
the quality level when
the quality information
of a clock source is
unknown.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Physical Layer Clock > Phase-Locked Source Output by External Clock from the
Function Tree.
Parameters
Field Value Description
External Clock Output ALL, Sa4, Sa5, Sa6, Sa7, The External Clock
Timeslot Sa8 Output Timeslot
Default: ALL parameter provides an
option to set the
timeslots used by the
SSM quality information
in the output clock
signals.
This parameter is valid
only when External
Clock Output Mode is
set to 2M Bit/s.
● ALL: All timeslots
● SA4: sa4 timeslot
● SA5: sa5 timeslot
● SA6: sa6 timeslot
● SA7: sa7 timeslot
● SA8: sa8 timeslot
2MPLL Los External Shutdown External Clock The 2MPLL Los External
Clock Output Action Output, External Clock Clock Output Action
Tx AIS Alarm, External parameter provides an
Clock Tx DNU Level option to specify the
Default: Shutdown type of the signals
External Clock Output output by the external
clock port when the 2M
phase-locked source
fails.
2.9.1.2 Mandatory.
Configuring the Before configuring clocks, you need to set the frequency
Frequency source mode as required.
Source Mode
● If physical clock frequency synchronization is used, select
Physical Synchronization.
● If IEEE 1588v2 frequency synchronization is used, select
PTP Synchronization.
2.9.1.3 Optional.
Configuring When the boards are used to provide clock synchronization,
Transport Clock Synchronous Clock Enabled, Service Type, and Port
Attributes of Mapping must be set.
Boards
2.9.1.4 Optional.
Configuring the When an NE is equipped with master and slave subracks,
Clock Center you need to specify a subrack with a clock board as the
Subrack clock center subrack. If other subracks receive clock signals
from the upstream or output clock signals to the
downstream, you need to set the clock cascading
relationship between these subracks and the clock center
subrack and correctly connect the subracks.
2.9.1.5 Optional.
Configuring When an NE needs to receive or transmit external clock
External Clock signals, you must set Port Cascading. The external port of a
Ports clock board can be used to receive external clock signals. In
addition, the external port can be used for cascading the
clock boards within a multi-subrack NE.
To prevent clock signal deterioration, you must add a BITS
clock source for clock compensation when more than 10
NEs are configured. In this case, you must set Phase-Locked
Source Output of External Clocks.
2.9.1.6 Mandatory.
Configuring This operation specifies the priority of each required clock
Clock Source source. This provides a criterion for selecting clock sources in
Attributes case of a clock switching event. To provide a clock source
selection basis for each clock source during clock switching,
you must set parameters System Clock Source Priority
Table, 2M External Clock Source Priority Table, Clock
Quality, and Higher-Priority Clock Source Reversion.
Operation Description
2.9.1.7 Mandatory.
Configuring the Physical clock synchronization supports selecting and
Clock Source switching a clock source under three SSM protocol modes:
Protection
● Non-SSM protocol: Clock source protection is not
required.
● Standard SSM protocol: The standard SSM protocol and
SSM output must be configured.
● Extended SSM protocol: The extended SSM protocol,
clock subnet, and SSM output must be configured.
2.9.1.10 Optional.
Configuring When the clock source quality deteriorates, you need to
Clock Source manually switch clock sources, including setting clock source
Switching switching conditions, enabling clock source switching, and
starting clock source switching.
Prerequisites
You are an NMS user with "Operator Group" privilege or higher.
Procedure
Step 1 Configure the frequency source mode.
NOTE
Before configuring clocks, you need to set the frequency source mode as required.
● If physical clock frequency synchronization is used, select Physical Synchronization.
● If IEEE 1588v2 frequency synchronization is used, select PTP Synchronization.
----End
Prerequisites
You are an NMS user with Operation Level rights or higher.
Context
NOTICE
Changing the service type between GE(TTT-GMP) and GE(GFP-T) for a board will
interrupt services on the board. After the operation, the services will be
automatically restored.
NOTICE
For OSN 6800, changing the value of Synchronous Clock Enabled for a board will
cause a transient service interruption on the board.
Procedure
Step 1 Configure Service Type and Port Mapping in the following way:
For details about how to configure synchronous Ethernet on each board, see 2.4
Availability.
Step 2 Optional: Configure Synchronous Clock Enabled. For details about the
parameters, see 2.9.1.13.2 Parameters: Clock Attribute Configuration.
Step 3 Optional: When the following boards are interconnected with third-party devices,
you must set parameter SSM Timeout Period (500ms) of the boards to
guarantee SSM quality. You do not need to configure the other boards. For details
about the parameters, see 2.9.1.13.2 Parameters: Clock Attribute Configuration.
NOTE
----End
Prerequisites
You are an NMS user with "Operator Group" privilege or higher.
Procedure
Step 1 Configure the clock center subrack.
----End
Prerequisites
● You are an NMS user with "Operator Group" authority or higher.
● The clock board has been created.
● For the OSN 6800, when concatenation of the external ports of a clock board
is configured, the 120-ohm external clock port cable should be used as the
network cable for concatenation.
Step 1 Configure Enabled Status. For details about the parameters, see 2.9.1.13.3
Parameters: Clock Port Link.
----End
Step 1 Configure Phase-Locked Source Output by External Clock. For details about the
parameters, see 2.9.1.13.16 Parameters: Phase-Locked Source Output by
External Clock.
NOTE
In the case of forced shutdown of the output of the external clock, the 2 Mbit/s and 2 MHz
two external clocks are shut down and there is no output signal from the two clocks. This
operation has a higher shutdown priority than all other automatic shutdown functions
provided by software. By default, the forced shutdown of the external clock output is
disabled.
----End
Prerequisites
● You are an NMS user with "Operator Group" authority or higher.
● The required boards have been created.
Precautions
NOTICE
NOTE
Step 2 Select a clock source and click or to adjust the clock source
priority.
Step 3 Optional: Select a clock source and then click Delete to delete the clock source.
For details about the parameters, see 2.9.1.13.4 Parameters: System Clock
Source Priority List.
----End
Step 1 Check the 2M PLL clock source of the external clock port.
NOTE
● The relationship between the 2M PLL clock source and the external clock port depends
on the sequence of setting the cascaded external ports on the clock board.
● When the optical supervisory channel and clock transmission unit is AST2/AST4, the 2M
priority table cannot be configured.
Step 2 Configure Priority for PLL Clock Sources of 1st External Output List or Priority
for PLL Clock Sources of 2nd External Output List.
Step 3 Select a clock source and click or to adjust the clock source
priority.
NOTE
Step 5 Optional: Select a clock source and then click Delete to delete the clock source.
For details about the parameters, see 2.9.1.13.5 Parameters: Priority for PLL
Clock Sources of 1st External Output and 2.9.1.13.6 Parameters: Priority for
PLL Clock Sources of 2nd External Output.
----End
Step 1 Configure Clock Quality. For details about the parameters, see 2.9.1.13.8
Parameters: Clock Source Quality.
NOTE
NOTE
The SSM source selection algorithm of an NE first compares the quality level of a clock
source with the SSM Input Quality Threshold.
● SSM Input Quality Threshold: indicates the lowest input clock quality level. By
default, the value is Not Inferior to G.813 SETS Clock Signal.
● If the quality level is lower than the value of SSM Input Quality Threshold, the NE
reports an SSM_QL_FAILED alarm, and specifies the clock source as unavailable.
● If the quality level is higher than or the same as SSM Input Quality Threshold, the
NE transparently transmits the quality level of the clock source so that the source
selection flow selects the clock as its clock source.
Step 2 Configure Manual Setting of Quality Level. For details about the parameters, see
2.9.1.13.9 Parameters: Manual Setting of Quality Level 0.
----End
NOTE
● To prevent repeated switching when the clock is unstable, do not set Clock Source WTR
Time(min) to 0.
● Clock Source Hold-Off Time(100ms): The default value is 0, indicating that the hold-
off timer is disabled. The Clock Source Hold-Off Time(100ms) can be set within the
range of 300 ms to 1800 ms with the step length of 100 ms.
● When a clock source for an NE fails, the clock failure status is sent to the source
selection flow only after the time specified by Clock Source Hold-Off Time(100ms)
elapses. This ensures that a short-term clock signal failure is not sent to the source
selection flow for clock source switching.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The relevant board has been created.
NOTICE
If the extended SSM protocol is enabled, you are not advised to change the ID of
the clock source being traced by the master NE when the clock tracing
performance is stable. This ensures proper transmission of clock IDs and prevents
a clock loop.
NOTE
● The same SSM protection protocol must be used within the same clock protection subnet.
● Allocate the same subnet number to NEs tracing the same clock source.
Step 2 Optional: If the Clock Source ID is specified for the line clock of an NE, click the
Clock ID Output tab, and set the Output Clock ID to Enabled. Click Apply. For
details about these parameters, see 2.9.1.13.11 Parameters: Clock ID Status.
----End
Step 1 Configure SSM Output. For details about these parameters, see 2.9.1.13.10
Parameters: SSM Output Control.
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Procedure
Step 1 View clock synchronization status.
NOTE
● SSM Output Quality Threshold: indicates the highest output clock quality level. By
default the value is G.811 Clock Signal.
● If the clock quality level of an NE is equal to or higher than SSM Output Quality
Threshold, the specified SSM Output Quality Threshold is sent to the downstream NE.
● If the clock quality level is lower than the specified SSM Output Quality Threshold, the
actual clock quality level is sent to the downstream NE.
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Context
When the clock tracing relationships are changed, the U2000 automatically
refreshes the tracing status in Clock View.
Procedure
Step 1 In the Main Topology, select Clock View from the Current View drop-down list.
Step 2 In the Clock View, right-click and choose Search Clock Link from the shortcut
menu.
Step 3 In the Search Clock Link window, set Clock Type and Search Mode, select the NE
to be queried, and click OK.
Step 4 In the Result dialog box, click Close.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The clock source has been created.
NE switches to other clocks when the clock source fails. Taking this measure will
minimize the impact that a clock failure has on services.
Step 1 Double-click the parameter column and set the alarms and performance events
that are to be used as the clock source switching conditions to Yes. For details
about these parameters, see 2.9.1.13.15 Parameters: Clock Source Switching
Conditions.
----End
----End
NOTICE
Step 1 Perform clock source switching, including the operation of selecting Forced
Switching or Manual Switching.
NOTE
Before switching the clock source, ensure that a new clock source that is not locked and
that has better quality is created in the priority table.
Step 2 Optional: To restore the automatic clock source selection mode, right-click the
switched clock source and choose Clear Switching.
----End
Prerequisites
You are an NMS user with "Operator Group" authority or higher.
Context
NOTE
NOTICE
Changing the service type between GE(TTT-GMP) and GE(GFP-T) for a board will
interrupt services on the board. After the operation, the services will be
automatically restored.
Procedure
Step 1 Set Service Type and Port Mapping.
For details about how to configure synchronous Ethernet on each board, see 2.4
Availability.
----End
Prerequisites
● You are an NMS user with "Monitor Group" authority or higher.
Context
Procedure
Step 1 Configure clock pass-through. For details about the parameters, see 2.9.1.13.17
Parameters: Clock Signal Pass-through.
Step 2 Optional: You can delete clock pass-through on the NMS as required. Select the
existing clock pass-through record and click Delete. In the Are you sure to
delete? dialog box that is displayed, click OK.
----End
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Frequency Source Mode from Function Tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, click the NE and choose Configuration > Clock > Clock
Attribute Configuration.
Parameters
Parameter Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > Port
Cascading from Function Tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Priority from the Function Tree. Click the System
Clock Source Priority List tab.
Parameters
Parameter Value Description
Synchronous Status Byte SA4, SA5, SA6, SA7, SA8 Specifies the timeslots
Default value: SA4 for the SSM quality
information in the input
external clock signals.
● SA4: sa4 timeslot
● SA5: sa5 timeslot
● SA6: sa6 timeslot
● SA7: sa7 timeslot
● SA8: sa8 timeslot
This parameter is valid
only when External
Clock Source Mode is
set to 2Mbit.
2.9.1.13.5 Parameters: Priority for PLL Clock Sources of 1st External Output
When you need to use the line clock source of the equipment as the phase-locked
source, you must configure the priority table for phase-locked sources in this user
interface. In this user interface, you can also query and set priority table for phase-
locked sources of first external output clocks and adjust the priority of each clock
source.
The available clock source with the highest priority can be used as the phase-
locked source to lock the phase of first external output clock. An internal source
can be assigned with the lowest priority level only.
NOTE
When two 2M phase-locked loops (PLLs) are required to track line sources, it is
recommended that the 2M PLLs of OSN 9800 universal platform subracks be used. The 2M
PLLs of OSN 9800 electrical subrack is used to track system clock sources by default.
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Priority from the Function Tree. Click the Priority for
PLL Clock Sources of 1st External Output tab.
Parameters
Field Value Description
Current Trace Source For example: 18- Displays the clock source
ST2-2(RM2/TM2) that the NE is currently
For example: Internal tracing.
Clock Source
2.9.1.13.6 Parameters: Priority for PLL Clock Sources of 2nd External Output
When you need to use the line clock source of the equipment as the phase-locked
source, you must configure the priority table for phase-locked sources in this user
interface. You can also query and set priority table for phase-locked sources of
second external output clocks and adjust the priority of each clock source.
The available clock source with the highest priority can be used as the phase-
locked source to lock the phase of second external output clock. An internal
source can be assigned with the lowest priority level only.
NOTE
When two 2M phase-locked loops (PLLs) are required to track line sources, it is
recommended that the 2M PLLs of OSN 9800 universal platform subracks be used. The 2M
PLLs of OSN 9800 electrical subrack is used to track system clock sources by default.
Navigation Path
In the NE Explorer, click the NE and select Configuration > Clock > Physical
Layer Clock > Clock Source Priority from the Function Tree. Click the Priority for
PLL Clock Sources of 2nd External Output tab.
Parameters
Field Value Description
Current Trace Source For example: 18- Displays the clock source
ST2-2(RM2/TM2) that the NE is currently
For example: Internal tracing.
Clock Source
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Physical Clock > Clock Subnet Configuration > Physical Clock Subnet
Configuration from the Function Tree. Click the Clock Subnet tab.
Parameters
Field Value Description
network with
multiple clock
sources. The clock
signal carries
quality
information. It is
used when the
WDM/OTN device
interconnects with
a third-party
device.
● Start Extended SSM
Protocol:
– When the
extended SSM
protocol is
enabled, clock
source IDs are used
to prevent clock
loops.
– This protocol is
applicable only to
a ring network. It
is a Huawei
proprietary
protocol and
cannot be used
when the
WDM/OTN device
interconnects with
a third-party
device. If the
extended SSM
protocol is enabled
on an NE, the
standard SSM
protocol can be
configured on the
downstream NEs;
however, it cannot
be configured on
the NE if the
standard SSM
protocol is enabled
on the upstream
NEs.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Physical Clock > Clock Subnet Configuration > Physical Clock Subnet
Configuration from the Function Tree. Click the Clock Quality tab. Click the
Clock Source Quality tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Physical Clock > Clock Subnet Configuration > Physical Clock Subnet
Configuration from the Function Tree. Click the Clock Quality tab. Click the
Manual Setting of Quality Level tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Physical Clock > Clock Subnet Configuration > Physical Clock Subnet
Configuration from the Function Tree. Click the SSM Output tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Physical Clock > Clock Subnet Configuration > Physical Clock Subnet
Configuration from the Function Tree. Click the Clock ID Output tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Clock > Clock Source Switching from the Function Tree. Click the Clock Source
Reversion tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Clock > Clock Source Switching from the Function Tree. Click the Clock Source
Switching tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Clock > Clock Synchronization Status from the Function Tree.
Parameters
Field Value Description
SSM protocol is
enabled and the S1
byte synchronization
quality information
output by the
synchronous source is
the G.812 transit
clock.
● G.812 Local Clock:
indicates that the
SSM protocol is
enabled and the S1
byte synchronization
quality information
output by the
synchronous source is
the G.812 local clock.
● SDH equipment
timing source (SETS)
signal: indicates that
the SSM protocol is
enabled and the S1
byte synchronization
quality information
output by the
synchronous source is
the synchronous
equipment timing
source (SETS) clock.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Clock > Clock Source Switching from the Function Tree. Click the Clock Source
Switching Conditions tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Clock > Phase-Locked Source Output by External Clock from the Function Tree.
Parameters
Parameter Value Description
External Clock Output ALL, SA4, SA5, SA6, SA7, Specifies the timeslots
Timeslot SA8 used by the SSM quality
Default value: ALL information in the output
clock signals.
● ALL: All timeslots
● SA4: sa4 timeslot
● SA5: sa5 timeslot
● SA6: sa6 timeslot
● SA7: sa7 timeslot
● SA8: sa8 timeslot
This parameter is valid
only when External
Clock Output Mode is
set to 2Mbit/s.
2M Output S1 Byte
Unavailable or Send
AIS, this parameter is
ineffective.
Navigation Path
In the NE Explorer, click the NE and choose Configuration > Clock > Clock Signal
Pass-through.
Parameters
Field Value Description
Operation Description
Prerequisites
You are an NMS user with Operation Level rights or higher.
Context
NOTE
Since OSN 9800 V100R001C20, you do not need to set Synchronous Clock Enabled for the
OSN 9800.
NOTICE
Changing the service type between GE(TTT-GMP) and GE(GFP-T) for a board will
interrupt services on the board. After the operation, the services will be
automatically restored.
Procedure
Step 1 Set Service Type and Port Mapping.
For details about how to configure synchronous Ethernet on each board, see 2.4
Availability.
Step 2 Add a port to the clock source priority table and set the priority to 0. For details,
see 2.9.2.4 Configuring Clock Attributes.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The CTU board has been created.
----End
Procedure
When a clock signal passes through 10 or more NEs, frequency offset and drift
may occur. As a result, the clock signal transmitted to the downstream NE is
degraded. To prevent this from happening, a 2M phase-locked source must be
used to optimize the clock signal.
Step 1 Set the external clock attributes of the 2M phase-locked source. Set the
parameters manually, such as External Clock Output Shutdown, External Clock
Output Mode, External Clock Output Timeslot, and External Source Output
----End
Prerequisites
● You are an NMS user with "Operator Group" authority or higher.
● The required boards have been created.
Precautions
NOTICE
NOTE
If a port that supports synchronous Ethernet needs to output synchronous Ethernet clock
signals that carry SSM information, you need to add the port to System Clock Source
Priority List of the NE and set Clock Source Priority to 0. For details about the capabilities
of ports supporting synchronous Ethernet processing, see 2.4.3 OSN 9800 U Series
Hardware and Version Support.
Step 2 Optional: Select a clock source and then click Delete to delete the clock source.
For details about the parameters, see 2.9.2.10.1 Parameters: System Clock
Source Priority List.
----End
Step 1 Check the 2M PLL clock source of the external clock port.
NOTE
The relationship between the 2M PLL clock source and the external clock port depends on
the sequence of setting the cascaded external ports on the clock board.
Step 2 Configure Priority for PLL Clock Sources of 1st External Output List or Priority
for PLL Clock Sources of 2nd External Output List.
NOTE
Step 3 Optional: Select a clock source and then click Delete to delete the clock source.
For details about the parameters, see 2.9.2.10.2 Parameters: Priority for PLL
Clock Sources of 1st External Output and 2.9.2.10.3 Parameters: Priority for
PLL Clock Sources of 2nd External Output.
----End
Step 1 Configure Clock Quality to the desired level. For details about the parameters, see
2.9.2.10.5 Parameters: Clock Source Quality.
NOTE
----End
NOTE
● To prevent repeated switching when the clock is unstable, do not set Clock Source WTR
Time(min) to 0.
● Clock Source HoldOff Time(100ms): The Clock Source HoldOff Time(100ms) can be
set within the range of 300 ms to 1800 ms with the step length of 100 ms.
● When a clock source for an NE fails, the clock failure status is sent to the source
selection flow only after the time specified by Clock Source Hold-Off Time(100ms)
elapses. This ensures that a short-term clock signal failure is not sent to the source
selection flow for clock source switching.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The relevant board has been created.
Procedure
Step 1 Configure Enable Standard SSM Protocol Control or Enable Extend SSM
Protocol Control.
NOTE
The same SSM protection protocol must be used within the same clock protection subnet.
Step 2 Optional: If the Enable Extend SSM Protocol Control is selected, set the Clock
Source ID of the Clock Source. For details about these parameters, see 2.9.2.10.4
Parameters: Clock Subnet.
NOTICE
If the extended SSM protocol is enabled, you are not advised to change the ID of
the clock source being traced by the master NE when the clock tracing
performance is stable. This ensures proper transmission of clock IDs and prevents
a clock loop.
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Procedure
Step 1 View clock synchronization status. For details about these parameters, see
2.9.2.10.8 Parameters: Clock Synchronization Status.
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Context
When the clock tracing relationships are changed, the U2000 automatically
refreshes the tracing status in Clock View.
Procedure
Step 1 In the Main Topology, select Clock View from the Current View drop-down list.
Step 2 In the Clock View, right-click and choose Search Clock Link from the shortcut
menu.
Step 3 In the Search Clock Link window, set Clock Type and Search Mode, select the NE
to be queried, and click OK.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The clock source has been created.
Procedure
When the traceable clock source in a network deteriorates, NEs may not be able
to execute a switch on the clock source. Users need to manually switch the clock
source to prevent clock deterioration from affecting the normal running of NEs.
NOTICE
Step 1 Perform clock source switching, including the operation of selecting Forcible
Source Selection or Manual Source Selection. For details about these
parameters, see 2.9.2.10.7 Parameters: Clock Source Switching.
Step 2 Optional: To restore the automatic clock source selection mode, right-click the
switched clock source and choose Clear Source Selection.
----End
Prerequisites
You are an NMS user with Operation Level rights or higher.
Context
NOTE
NOTICE
Changing the service type between GE(TTT-GMP) and GE(GFP-T) for a board will
interrupt services on the board. After the operation, the services will be
automatically restored.
Procedure
Step 1 Set Service Type and Port Mapping.
For details about how to configure synchronous Ethernet on each board, see 2.4
Availability.
----End
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Priority. Click the System Clock Source Priority List
tab.
Parameters
Field Value Description
Clock Source Type For example: Internal Displays the type of the
Clock Source clock source.
Synchronous Status Sa4, Sa5, Sa6, Sa7, Sa8 The Synchronous Status
Byte Default: Sa4 Byte parameter provides
an option to set the
timeslots for the SSM
quality information in
the input external clock
signals.
2.9.2.10.2 Parameters: Priority for PLL Clock Sources of 1st External Output
When you need to use the line clock source of the equipment as the phase-locked
source, you must configure the priority table for phase-locked sources in this user
interface. In this user interface, you can also query and set priority table for phase-
locked sources of first external output clocks and adjust the priority of each clock
source.
The available clock source with the highest priority can be used as the phase-
locked source to lock the phase of first external output clock. An internal source
can be assigned with the lowest priority level only.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Priority. Click the Priority for PLL Clock Sources of
1st External Output List tab.
Parameters
Field Value Description
Clock Source Type For example: Internal Displays the type of the
Clock Source clock source.
2.9.2.10.3 Parameters: Priority for PLL Clock Sources of 2nd External Output
When you need to use the line clock source of the equipment as the phase-locked
source, you must configure the priority table for phase-locked sources in this user
interface. You can also query and set priority table for phase-locked sources of
second external output clocks and adjust the priority of each clock source.
The available clock source with the highest priority can be used as the phase-
locked source to lock the phase of second external output clock. An internal
source can be assigned with the lowest priority level only.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Priority. Click the Priority for PLL Clock Sources of
2nd External Output List tab.
Parameters
Field Value Description
Clock Source Type For example: Internal Displays the type of the
Clock Source clock source.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Subnet Configuration from the Function Tree. Click the
Clock Subnet Configuration Attribute tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Subnet Configuration from the Function Tree. Click the
Clock Quality tab.
Parameters
Field Value Description
Clock Source Type For example: Internal Displays the type of the
Clock Source clock source.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Switching. Click the Clock Source Reversion tab.
Parameters
Field Value Range Description
Clock Source HoldOff 3 to 18. The step is 1. Specifies the time period
Time(100ms) Default: 10 from the point when a
clock source switching
condition is generated to
the point when a clock
source switchover occurs.
When a clock source for
an NE fails, the status of
the clock is sent to the
select flow only after the
specified Clock Source
Hold-Off Time(100ms)
elapses so that the NE
can determine whether
to select another clock
source. This parameter
ensures that a short-
term clock signal failure
is not sent to the select
flow for clock source
switching.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Source Switching. Click the Clock Source Switching tab.
Parameters
Field Value Description
Clock Source Type For example: Internal Displays the type of the
Clock Source clock source.
Switching Source Type For example: Internal This field displays the
Clock Source switched clock source
type that the NE is
tracing.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > Physical
Layer Clock > Clock Synchronization Status from the Function Tree.
Parameters
Field Value Description
Data Output Method in 24th Keep, Long Term The Data Output
Holdover Mode Keep Method in Holdover
Default: 24th Keep Mode parameter
provides an option to set
the method of
outputting data in
holdover mode. When all
the clock sources of an
NE are lost, the NE
enters the holdover
mode. The NE may keep
the latest data forever or
maintain the holdover
state for 24 hours or a
specified period. If the
NE maintains the
holdover state, the NE
switches to the free-run
mode when the period
of 24 hours or a
specified period expires.
Unknown SSM Level G.811 Clock, G.812 TNC, The Unknown SSM
Map G.812 LNC, SDH, Level Map parameter
Unavailable Clock Source provides an option to set
the quality level when
the quality information
of a clock source is
unknown.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Physical Layer Clock > Phase-Locked Source Output by External Clock from the
Function Tree.
Parameters
Field Value Description
External Clock Output ALL, Sa4, Sa5, Sa6, Sa7, The External Clock
Timeslot Sa8 Output Timeslot
Default: ALL parameter provides an
option to set the
timeslots used by the
SSM quality information
in the output clock
signals.
This parameter is valid
only when External
Clock Output Mode is
set to 2M Bit/s.
● ALL: All timeslots
● SA4: sa4 timeslot
● SA5: sa5 timeslot
● SA6: sa6 timeslot
● SA7: sa7 timeslot
● SA8: sa8 timeslot
2MPLL Los External Shutdown External Clock The 2MPLL Los External
Clock Output Action Output, External Clock Clock Output Action
Tx AIS Alarm, External parameter provides an
Clock Tx DNU Level option to specify the
Default: Shutdown type of the signals
External Clock Output output by the external
clock port when the 2M
phase-locked source
fails.
Overview
The IEEE 1588v2 standard specifies Precision Time Protocol (PTP) in a
measurement and control system. The PTP protocol enables precise clock
synchronization between distributed and standalone devices in the measurement
and control systems and ensures clock synchronization precision to
submicroseconds.
Traditional GPS signals can satisfy time synchronization requirements but feature
high installation and maintenance costs. In addition, GPS signals depend on
satellites, which may bring communication security risks. IEEE 1588v2 can function
as an alternative to the GPS or other complex timing systems, providing high-
precision time for NodeBs or eNodeBs.
Application Scenario
Different from physical clocks that recover clock information from service bit
streams, IEEE 1588v2 implements frequency and phase synchronization through
PTP packet exchanges, as shown in the following figure. The synchronization is
implemented hop by hop, which requires that all devices in the synchronization
network must support IEEE 1588v2.
NOTE
The protection frequency tracing path shown in the preceding figure is an example of the
path for transmitting clock signals after the clock source is switched to the slave BITS
because the master BITS is faulty. The active and standby clock sources cannot be
concurrently transmitted on the network.
The phase tracing paths shown in the figure are used for reference only. On a practical
network, each NE determines the phase tracing paths based on algorithms.
3.2 Principles
An IEEE 1588v2 clock transfers the reference time to each control point accurately
by building the master-slave relationship between network nodes, and by using
the time synchronization mechanism.
The best clock in the entire system is the GMC due to its stability, accuracy, and
certainty. According to the precision and level of clocks on each node and the
traceability of UTC, the BMC algorithm selects the master clock in each subnet
automatically (see 3.2.5 BMC Algorithm). In the system where there is only one
subnet, GMC is the master clock. Each system has only one GMC, and each subnet
has only one master clock. Slave clocks are kept synchronized with the master
clock.
In a PTP clock subnet, the master-slave hierarchy can be established between the
OC and BC, between OCs, or between BCs.
Figure 3-2 shows the process of building the master-slave hierarchy between the
OC and BC in a PTP clock subnet.
In Figure 3-2, Ordinary clock-1 is at the bottom of the hierarchy and is referred to
as grandmaster. Port-1 of Boundary clock-1 is a SLAVE (S for short) compared
with the grandmaster. The other ports of Boundary clock-1 are all MASTER (M for
short) compared with the clock equipment that is connected to the ports. Hence,
port-1 of Boundary clock-2 is a SLAVE compared with Boundary clock-1.
The master-slave hierarchy of a PTP clock system is built depending on the
Announce packets received by the port from other clock ports, port data sets, BMC
algorithms, and port state machines. The process of building the master-slave
hierarchy is as follows:
1. Receives and authenticates the Announce packets from other clock ports.
2. Uses the BMC algorithm to determine the recommended state of a port.
3. Updates the port data set based on the decision point specified by the port
status decision algorithm for entering the recommended state.
4. The port state machine determines the actual state of the port based on the
recommended state and status decision event, and builds the master-slave
hierarchy.
NOTE
The master-slave clock hierarchy exists only between the OC and BC, and only the BC can
have the branch nodes in the master-slave hierarchy. For example, trails 1, 2, 3, 4, and 5
may contain TCs, but the TC equipment is not involved in the master-slave hierarchy and
does not maintain the relationship.
● PASSIVE: The port on the path is not in the MASTER status and does not
maintain synchronization with the port in the MASTER status. That is, the
upstream port and downstream port are isolated.
● FAULTY: The state of a port changes from master, slave, or passive to faulty
when a LOS, AIS, LinkDown, or other alarm is reported for the port.
Clock Models
The following concepts are essential for the IEEE 1588v2 clock models:
● PTP device: A clock device that supports the IEEE 1588v2 protocol is defined
as a PTP device.
● PTP port: A port that supports the IEEE 1588v2 protocol on a PTP device is
defined as a PTP port.
TCs are classified into P2P TCs and E2E TCs according to different mechanisms of
processing packets.
● P2P TC: The device measures the residence time of an IEEE 1588v2 packet to
be forwarded and the transmission delay of the link connected to the port
that receives this IEEE 1588v2 packet. It also records the residence time and
link transmission delay in the IEEE 1588v2 packet for further processing at a
slave clock device.
● E2E TC: The device measures the residence time of an IEEE 1588v2 packet to
be forwarded and records the residence time in the IEEE 1588v2 packet for
future processing at a slave clock device.
Clock Subnet
An IEEE 1588v2 clock subnet is a logical set in which clocks are synchronized with
each other using the IEEE 1588v2 protocol. A physical packet switched network
can be divided into multiple logical clock subnets. The clocks within a subnet are
synchronized with each other. Each clock subnet uses its own synchronization
source.
Clock Source ID
A clock source ID identifies a clock in an IEEE 1588v2 clock subnet. In an IEEE
1588v2 packet, a clock source ID occupies eight bytes. It consists of two parts:
A synchronous network using the IEEE 1588v2 protocol obtains time signals from
the reference time source grandmaster clock using external time ports.
● 1PPS
1PPS is short for one pulse per second. 1PPS signals are used for time scaling
and work at the RS-422 levels. The pulse frequency of 1PPS is 1 Hz. That is,
one pulse is transmitted per second. The 1PPS signal pulse width ranges from
20 ms to 200 ms. The rising edge of the pulse is strictly coincident with the
UTC time.
● TOD
TOD is short for time of day. TOD messages provide time in ASCII format.
TOD signals also work at the RS-422 levels and provide a baud rate of 9600
bit/s. A TOD message contains information such as current date/time, time
standard ID, 1PPS status flag, date/time adjusted based on UTC leap seconds,
leap second adjustment directive, and GPS time.
● If the manually specified Time Quality Level is not the default value 187, the
manually specified IEEE 1588v2 time quality level applies.
● If the manually specified Time Quality Level is the default value 187, the
clock board automatically converts the quality information carried in the TOD
into the IEEE 1588v2 time quality level based on the predefined conversion
table.
Table 3-2 provides the mapping between TOD status information and PTP time
quality levels.
Table 3-2 Mapping between TOD status information and PTP levels
0x00: normal 6
NOTE
For the port description and pin definitions of each board, see the panel description of each
board in Hardware Description.
NOTE
On the NMS, set Enabled Status to specify different working modes. When this parameter
is set to Enabled, the cascading mode is used. When this parameter is set to Disabled, the
external time mode is used.
NOTE
For the CLK&TOD composite port, a transfer cable is required to separate the CLK port from
the TOD port.
For boards that support multiple ports (CLK1/TOD1, CLK2/TOD2 ...), the cascading mode is
similar.
The clock synchronization GE optical port is used for BITS clock input, clock
synchronization between NEs, or clock cascading between master and slave
subracks. The clock synchronization GE optical port supports both physical clock
synchronization and PTP time synchronization, but does not support Ethernet
service transmission. Table 3-5 lists the names and types of the clock
synchronization GE optical ports.
NOTE
The clock synchronization GE optical port can be set to the physical clock cascading mode
or PTP clock cascading mode. On the NMS, set Enabled Status to specify different working
modes. When this parameter is set to Enabled, the cascading mode is used. When this
parameter is set to Disabled, the non-cascading mode is used.
● The clock synchronization GE optical port of the OSN 1800 supports both
non-cascading and cascading modes.
● The clock synchronization GE optical port of the OSN 9800 in
V100R021C00SPC300 or earlier does not support the cascading mode and
cannot be used for clock cascading between master and slave subracks. It is
used only for interconnection between WDM/OTN NEs or for clock/time
synchronization between WDM/OTN NEs and BITS/PTN/base station devices.
● The clock synchronization GE optical port of the OSN 9800 supports the
cascading mode and clock cascading between master and slave subracks since
V100R021C10SPC100.
The clock cascading and non-cascading modes can be set for different ports
separately.
● Figure 3-7 shows the fiber connections when both the cascading and non-
cascading modes are used.
● Figure 3-8 and Figure 3-9 show the fiber connections between NEs.
● Figure 3-10 and Figure 3-11 show the fiber connections for clock cascading
between master and slave subracks.
NOTE
When clock synchronization GE optical ports on system control boards or clock boards are
used for clock synchronization, the clock synchronization GE optical ports on both the active
and standby system control boards or clock boards must be used together to provide clock
protection.
Overview
The BMC algorithm compares the description data of two clocks to determine
which data better describes the clock. In other words, the algorithm is used to
determine which of the multiple Announce messages received by the local clock
port describes the best clock. The algorithm is also used to determine whether a
new clock source (that is, the external MASTER) has better quality than the local
clock. The data that describes the external MASTER information is contained in
the Grandmaster field of an Announce message. The data that describes the local
clock is contained in the data set of the clock.
The BMC algorithm runs on each clock in a domain independently. That is, each
clock does not need to negotiate with the other clocks, but calculates the status of
its own ports. The algorithm prevents situations where multiple master clocks exist
in the PTP clock system at the same time, there is no master clock, or the PTP
clock system is in the free-run mode.
NOTE
● Static BMC can be set to either Enabled or Disabled to enable or disable the IEEE
1588v2 protocol. When it is set to Enabled, users can manually configure the port
status as master or slave.
● For OSN 9800 service boards (with OTN tributary and line functions), when multiple
clock ports are configured, the BMC algorithm determines which port is used as the
clock source based on the port number. The system algorithm complies with the
following rules:
● For the boards that support IEEE 1588v2/ITU-T G.8275.1/ITU-T G.8273.2 only on
ports 1 to 15, the system preferentially selects the port with a smaller port number
as the clock source.
● For the boards that support IEEE 1588v2/ITU-T G.8275.1/ITU-T G.8273.2 in all ports,
ports 1 to 15 and the ports with a number greater than 15 form two groups. The
system preferentially selects the latter group and then the former group. In each
group, the system preferentially selects the port with a smaller number as the clock
source. For example, if ports 3, 7, 16, and 20 are configured as clock ports, the
priority is port 16 > port 20 > port 3 > port 7.
Figure 3-12 shows a typical application of the BMC algorithm for clock C0 that
has N ports.
1. For each port, the BMC module compares the data groups of the qualified
announce packets received by other clock ports that are connected to the port
on the communication trail, and the data group comparison algorithm
determines the best packets Erbest for the port.
2. In the case of N ports of clock C0, the BMC module compares Erbest of each
port and determines the best packets Ebest of N ports.
3. In the case of each port of N ports of clock C0, the BMC module uses the
status decision algorithm and the state machine of the port to determine the
port status based on Ebest, Erbest, and the default data group D0.
NOTE
The external time port on the product is not a PTP port and does not support the IEEE
1588v2 protocol. The transmission delay cannot be measured automatically. Therefore, the
transmission delay of the cable connecting to the external time port must be measured
using a test instrument or computed based on the cable length.
NOTE
The IEEE 1588v2 protocol can detect the mean transmission delay of two connected PTP
ports but cannot detect the transmission delay caused by the PTP link asymmetry.
Asymmetric delay must be measured with a test instrument or computed based on the
cable lengths.
NOTE
Only the following boards on the following products support automatic compensation of
ring network delay offset. For details about the restrictions, see 3.3.1 Feature Limitations.
● OSN 1800 V (Z-series system control boards) V100R009C00 and later versions: UNS4,
EX4, EG10, and UNQ2
● OSN 1800 V Pro (K5UXCME system control board):
● V100R021C10 and later versions: UNS5, UNS4, GTA, UNQ2, UND3 and EX10
● V100R022C10 and later versions: K1GDC
● OSN 1800 II Pro (K2UXCLE system control board):
● V100R021C10 and later versions: UNS5, UNS4, GTA, UNQ2, UND3 and EX10
● V100R022C10 and later versions: K1GDC
NOTE
Only the following boards on the following products support single-fiber bidirectional
asymmetric compensation. For details about the restrictions, see 3.3.1 Feature Limitations.
● OSN 1800 V (Z-series system control boards) V100R009C00 and later versions: EX4 and
EG10
● OSN 1800 V Pro (K5UXCME system control board): EX10
● OSN 1800 II Pro (K2UXCLE system control board): EX10
Figure 3-13 shows the IEEE 1588v2 clock phase synchronization process.
1. At the time of t1, the master clock sends a Sync message. If the master clock
is a one-step clock, the t1 timestamp is contained in the Sync message and
sent to the slave clock. If the master clock is a two-step clock, then the t1
timestamp is contained in the subsequent Follow_Up message and sent to the
slave clock.
2. At the time of t2, the slave clock receives the Sync message (one-step mode)
and obtains the t1 timestamp from the Sync message or from the subsequent
Follow_Up message (two-step mode).
3. At the time of t3, the slave clocks send delay request messages.
4. At the time of t4, the master clocks receive delay request messages.
5. At the time of t5, the master clock sends delay response messages that carry
the information of the time of t4.
The method of calculating the time difference between slave clocks and the
master clock and the link delay is as follows:
Because
t2-t1=Delay+Offset
t4-t3=Delay-Offset
Hence,
Offset=[(t2-t1)-(t4-t3)]/2
Delay=[(t2-t1)+(t4-t3)]/2
NOTE
NOTE
Figure 3-14 shows the time of receiving and transmitting Sync messages between
clock A (slave) and clock B (master) when clock A synchronizes to clock B. Clock A
can correct its clock frequency after comparing the interval between two message
transmitting timestamps with the interval between two message receiving
timestamps. In this manner, clock A synchronizes to clock B. If the changes in the
link delay and residence time are negligible, the clock frequency of clock A can be
corrected using the following formula:
(t1[N] - t1[0])/(t2[N] - t2[0])
● If the value of the "t2[N] - t2[0]" is equal to the value of "t1[N] - t1[0]": This
means that clock A and clock B run at the same rate.
● If the value of the "t2[N] - t2[0]" is greater than the value of "t1[N] - t1[0]":
This means that clock A runs faster than clock B and needs to slow down its
frequency.
● If the value of the "t2[N] - t2[0]" is less than the value of "t1[N] - t1[0]": This
means that clock A runs slower than clock B and needs to accelerate its
frequency.
NOTE
● t2[N] - t2[0]: Indicates the number of clock cycles within the interval between two Sync
messages received by clock A.
● t1[N] - t1[0]: Indicates the number of clock cycles within the interval between two Sync
messages transmitted by clock B.
● In one-step mode, t1[n] is contained in the Sync message. In two-step mode, t1[n] is
contained in the Follow_Up message.
Clock source ● The central node or the node with high reliability
provides the clock source.
● If the BITS or other external clock equipment with
high precision exists, use the external timing mode
for the NE. Otherwise, use the line timing mode
instead. You are advised to use the internal timing
as a clock source of the lowest level.
Methods for obtaining If there are multiple NEs at a core site of a WDM/OTN
frequency and phase network, the frequency/phase information can be
information obtained in either of the following ways:
● If physical OSC or ESC connections are established
between the NEs, the OSC or ESC channels can be
used to transmit IEEE 1588v2 frequency and phase
information between the NEs.
● ESC two-fiber bidirectional phase synchronization is
easily affected by factors such as protection
switching and board delay difference. If the east-
west delay offset is too large, phase indicators
change and deteriorate. As a result, frequent
network switching occurs and maintenance cannot
be performed.
● If the NEs are deployed in the same
telecommunication room and the intervals
between them are less than 200 m, the external
2M clock ports or 1PPS+TOD time ports on the NEs
can be used to transmit the frequency and phase
information between them.
● When IEEE 1588v2 signals are transmitted between
OTN devices, line boards or OSC boards are
recommended. When OTN equipment is
interconnected with third-party equipment to
transmit IEEE 1588v2 signals, tributary boards are
recommended.
TN16AUX For the OSN 8800 T16, two TN16AUX boards must be
configured when the IEEE 1588v2 function is required.
10GE LAN tributary When the 10GE LAN tributary board is used on OSN
board 9800 V100R001C00 or V100R001C01 and Port
Mapping is set to MAC Transparent Mapping
(10.7G), if the OSN 9800 is upgraded to
V100R001C20, configuring the port as a PTP port to
support IEEE 1588v2 interrupts traffic on the port. The
traffic is restored automatically after the configuration
is completed.
AUX boards of the OSN When an OSN 1800 NE is configured with multiple
1800 AUX boards (F1AUX/B1AUX/B2AUX), you need to set
one AUX board as the main AUX board.
● In the master/slave subrack scenario, the main AUX
board must be configured on the master subrack.
● For the use restrictions on the external clock/time
ports of the TMB1AUX/TMB2AUX board, see Table
2-9.
SLAVE_ONLY For the OSN 1800, the port of the clock equipment in
the SLAVE_ONLY state cannot enter into the MASTER
state. That is, this clock equipment cannot function as
the clock source for the downstream equipment on
the trail. Only the port of the clock equipment in the
NON_SLAVE_ONLY state can enter into the MASTER
state. That is, this clock equipment can function as the
clock source for the downstream equipment on the
trail. Therefore, the PTP system must contain at least
one clock equipment that is in the NON_SLAVE_ONLY
state.
Clock synchronization For the current OSN 1800 version, slave subracks
of slave subracks support clock synchronization only when master and
slave subracks are cascaded.
In a slave subrack, only the following boards support
clock synchronization (that is, the ports on the
following boards are used as clock source ports):
● B1AUX/B2AUX: HPn port
● TMB1DFS/TMB1SFS/TMB1FS: HP port
● TMB1CMD4: TX1/RX1 port
Other types of ports, such as OSC clock sources, line
clock sources, and Ethernet service ports, do not
support clock synchronization.
CFP optical module For the boards that use CFP optical modules,
compensation for the asymmetrical transmission
delay is required after the boards are powered on or
undergo cold resets, the optical modules are replaced,
or the line code pattern is switched; otherwise, a time
deviation of about 100 ns may be generated.
Fiber parameters When the OSC board is used for high-precision clock
synchronization, you need to correctly set the fiber
type, fiber length, and fiber dispersion coefficient on
the WDM Interface > Advanced Attributes page of
the NMS.
Packet LAG/APS/ERPS ● When the IEEE 1588v2 feature works with packet
LAG/APS/ERPS, it is recommended that the P2P TC
mode be used if NE Clock Type is set to TC.
Otherwise, set NE Clock Type to TC+BC.
● When the IEEE 1588v2 feature works with packet
LAG, it is recommended that Load Balancing be
set to Non-Sharing for LAG on the interconnection
points of BC/OC equipment if NE Clock Type is set
to TC+BC.
Fiber Doctor system When the IEEE 1588v2 feature works with the Fiber
Doctor system, service running and the IEEE 1588v2
clock synchronization may be affected. For details, see
the feature dependencies and limitations of the Fiber
Doctor system.
If the single-fiber bidirectional OSC board is used to
implement PTP time synchronization and intelligent
fiber management at the same time, pay attention to
the following points when using the Fiber Doctor
system:
● If the OSC_CLK_MISMATCH alarm is found on the
live network, online fiber detection using Default
Mode or Online mode in Advanced Mode is not
allowed.
● If no OSC_CLK_MISMATCH alarm is found on the
live network but more than four OLA sites are
deployed in an OMS, clock boards that meet
requirements need to be configured at the next
OLA site behind every four OLA sites. Otherwise,
online fiber detection using Default Mode or
Online mode in Advanced Mode is not allowed
because PTP time synchronization is affected in
this scenario.
● If online monitoring has been started for an OTS of
an OMS but the monitoring is not completed,
online monitoring cannot be started for other OTSs
on the OMS; otherwise, PTP time synchronization is
affected.
● If PTP time synchronization is also enabled, ensure
that online monitoring is started for no more than
14 OTSs on the entire network; otherwise, PTP
time synchronization is affected.
Client 1+1 protection Client 1+1 protection and IEEE 1588v2 are mutually
exclusive. If both are configured, IEEE 1588v2 will
become abnormal.
Fiber Doctor system When the AST4 board works with the F5XCH/
F5UXCME/F5UXCM board, the line fiber quality
detection function cannot be configured together with
the physical-layer clock and IEEE 1588v2 functions.
Otherwise, the physical-layer clock and IEEE 1588v2
functions will be abnormal.
When the AST2 board works with the 11STG/12STG/
K2STG/16SCC/16XCH/16UXCM board, the line fiber
quality detection function cannot be configured
together with the physical-layer clock and IEEE
1588v2 functions. Otherwise, the physical-layer clock
and IEEE 1588v2 functions will be abnormal.
3.4 Availability
This section describes the board types and software versions that support IEEE
1588v2.
Table 3-10 Boards and device versions that support IEEE 1588v2 in the OSN 9800
universal platform subrack (optical-layer configuration)
Board Type Board Name Start Version
TN13STG V100R002C10
AST2 V100R002C10
NOTE
Only some boards support high-precision clock synchronization. For details, see 5 High-
Precision Clock Synchronization Solution.
Table 3-11 Boards and device versions that support IEEE 1588v2 in OSN 9800 P
series subracks (optical-layer configuration)
Board Type Board Name Start Version
TMP3CTUHP V100R022C10
NOTE
Only some boards support high-precision clock synchronization. For details, see 5 High-
Precision Clock Synchronization Solution.
Only OSN 9800 U32E/U64E enhanced subracks support high-precision clock
synchronization. OSN 9800 U32/U64 standard subracks do not support high-precision clock
synchronization.
Table 3-12 Boards and device versions that support IEEE 1588v2 in OSN 9800 U
series subracks (electrical-layer configuration)
TNS1CTU V100R001C30
TNU5CTUHP V100R019C10
U402 V100R005C00
TNU6U502 V100R020C10
TNS5NP400/TNS5NP400E V100R021C10
When OTN tributary ports receive Ethernet services, the working modes of the
ports that support IEEE 1588v2 vary according to the encapsulation type. The
following table lists the details.
Table 3-13 Port working modes supported by different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (TC, on
TC+OC, BC,
or OC)
NOTE
● When the port working mode is ODUflex non-convergence mode (Any->ODUflex), the
TC, TC+OC, BC, and OC modes and PTP ETH encapsulation are supported.
● All packet service boards listed in Table 3-12 support the TC, TC+OC, BC, and OC
working modes and the PTP ETH and PTP IP encapsulation modes.
NOTE
Only some boards support high-precision clock synchronization. For details, see 5 High-
Precision Clock Synchronization Solution.
Table 3-14 Boards, devices, and product versions that support IEEE 1588v2
Board Type Board Name Start Version
TNG4CXPHP V100R021C00
TMF2AUX01HP V100R021C10
TMF2AUX01HP V100R021C10
TNG1T210EHP V100R022C10
TNU6U502 V100R020C10
TNS5NP400/TNS5NP400E V100R021C10
When OTN tributary ports receive Ethernet services, the working modes of the
ports that support IEEE 1588v2 vary according to the encapsulation type. The
following table lists the details.
Table 3-15 Port working modes supported by different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (TC, on
TC+OC, BC,
or OC)
Table 3-16 Boards and device versions that support IEEE 1588v2 in OSN 8800
subracks
TN16XCH V100R006C00
TN16SCC V100R006C01
TN16UXCM V100R007C00
TN12STG V100R008C10
TN54STG V100R009C10
AST2 V100R011C00
TN55TSC V100R012C00
LQCP V100R013C00
TN54NS3 V100R005C00
When OTN tributary ports receive Ethernet services, the working modes of the
ports that support IEEE 1588v2 vary according to the encapsulation type. The
following table lists the details.
Table 3-17 Port working modes supported by different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (TC, on
TC+OC, BC,
or OC)
Table 3-18 Boards and device versions that support IEEE 1588v2 in OSN 6800
subracks
Board Type Board Name Start Version
TN12STG V100R008C10
TN13STG V100R010C10
AST2 V100R011C00
TN53TDX V100R006C01
When OTN tributary ports receive Ethernet services, the working modes of the
ports that support IEEE 1588v2 vary according to the encapsulation type. The
following table lists the details.
Table 3-19 Port working modes supported by different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (TC, on
TC+OC, BC,
or OC)
Table 3-20 Boards and device versions that support IEEE 1588v2 in OSN 1800 V
subracks
Board Type Board Name Start Version
TMB2AUX V100R021C10
AST4 V100R006C20
TMB1AST2 V100R009C00
TMB2AST2 V100R019C10
TMB1LQCB V100R022C00
TMB1EG10 V100R021C10
NOTE
● You are advised to use OSC boards to implement PTP time synchronization between
sites. The single-fiber bidirectional OSC mode supports commissioning-free and delay
compensation-free functions. However, when line boards are used to configure PTP time
synchronization, compensation for asymmetric delay is required, the construction cost is
high, and the maintainability is poor. Therefore, this mode is not recommended.
● For OTN line ports, IEEE 1588v2 can be used only when lower-order ODUk cross-
connections are configured for the ports.
● For the tributary ports that receive Ethernet services, IEEE 1588v2 can be used only after
services are configured for the ports.
● When an electrical module is inserted into a port of the board, IEEE 1588v2 is not
supported.
● When the EM20 board works with the Z5UXCMS system control board, IEEE 1588v2 is
supported since V100R020C10.
● The TQX board does not support IEEE 1588v2 with ODUflex non-aggregation mode
(Any->ODUflex).
● Boards do not support IEEE 1588v2 when working in relay mode.
● When the service cross-connections on the line board are switched, IEEE 1588v2 clock
tracing is affected. As a result, the clock source may be switched temporarily.
● The AUX board is an auxiliary board that provides the clock function.
When the OTN board receives Ethernet services, the working modes of the ports
that support IEEE 1588v2 vary according to the encapsulation types. The following
table lists the details.
Table 3-21 Port working modes supported by different port service mapping paths
NOTE
● For line boards, Clock Type can only be set to BC or OC, and P/E Mode can only be set to
E2E.
● When receiving Ethernet services, OTN tributary ports only support the BC or TC mode of
Clock Type, and only support the PTP ETH encapsulation mode.
● When receiving OTN services, OTN tributary ports only support the BC or OC mode of Clock
Type, and only support E2E of P/E Mode.
● The OSC boards support only BC and OC modes.
● When receiving GE or 10GE LAN services, the EM20 board (working with the F5UXCM/
F5UXCME board) supports the TC, TC+OC, BC, and OC modes and both PTP ETH
encapsulation and PTP IP encapsulation. When working with the Z5UXCMS board, the EM20
board supports only the BC mode and both PTP ETH encapsulation and PTP IP
encapsulation.
● When receiving GE or 10GE LAN services, the EX4 and EG10 boards support only the BC
mode but support both PTP ETH encapsulation and PTP IP encapsulation.
Table 3-22 Boards and device versions that support IEEE 1588v2 in OSN 1800 II
Enhanced subracks
Board Type Board Name Start Version
TMB2AUX V100R021C10
TMB1AST2 V100R009C00
TMB2AST2 V100R019C10
TMB2LDC V100R021C10
TMB1EG10 V100R021C10
NOTE
● You are advised to use OSC boards to implement PTP time synchronization between
sites. The single-fiber bidirectional OSC mode supports commissioning-free and delay
compensation-free functions. However, when line boards are used to configure PTP time
synchronization, compensation for asymmetric delay is required, the construction cost is
high, and the maintainability is poor. Therefore, this mode is not recommended.
● For OTN line ports, IEEE 1588v2 can be used only when lower-order ODUk cross-
connections are configured for the ports.
● For the tributary ports that receive Ethernet services, IEEE 1588v2 can be used only after
services are configured for the ports.
● When an electrical module is inserted into a port of the board, IEEE 1588v2 is not
supported.
● Boards do not support IEEE 1588v2 when working in relay mode.
● When the service cross-connections on the line board are switched, IEEE 1588v2 clock
tracing is affected. As a result, the clock source may be switched temporarily.
● The AUX board is an auxiliary board that provides the clock function.
When the OTN board receives Ethernet services, the working modes of the ports
that support IEEE 1588v2 vary according to the encapsulation types. The following
table lists the details.
Table 3-23 Port working modes supported by different port service mapping paths
NOTE
● The ST2, AST4, and LDCA boards support only BC and OC modes.
● When receiving GE or 10GE LAN services, the UXCL (EX1) board supports only the BC mode
and supports both PTP ETH encapsulation and PTP IP encapsulation.
● When receiving GE or 10GE LAN services, the EX4 and EG10 boards support only the BC
mode but support both PTP ETH encapsulation and PTP IP encapsulation.
Table 3-24 Boards and device versions that support IEEE 1588v2 in OSN 1800 I&II
Compact subracks (TNF3SCC)
AST4 V100R006C20
TMB1AST2 V100R009C00
TMB2AST2 V100R019C10
When OTN tributary ports receive Ethernet services, the working modes of the
ports that support IEEE 1588v2 vary according to the encapsulation type. The
following table lists the details.
Table 3-25 Port working modes supported by different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (TC, on
TC+OC, BC,
or OC)
NOTE
Only some boards support high-precision clock synchronization. For details, see 5 High-
Precision Clock Synchronization Solution.
Table 3-26 Boards and device versions that support IEEE 1588v2
TMB1DFSHP/TMB1SFSHP/TMB1FSHP V100R022C00
(OSC unit)
TMB1LQCB V100R022C00
TMK1UNS4MP V100R022C10
TMB3EMS10D V100R022C10
NOTE
● HP: indicates that the board supports high-precision clock synchronization. Only
products in V100R021C10SPC300 (with NCE V100R021C10SPC200) and later versions
support high-precision clock synchronization. XFIU units do not affect synchronization
precision.
● You are advised to use OSC boards to implement PTP time synchronization between
sites. The single-fiber bidirectional OSC mode supports commissioning-free and delay
compensation-free functions. However, when line boards are used to configure PTP time
synchronization, compensation for asymmetric delay is required, the construction cost is
high, and the maintainability is poor. Therefore, this mode is not recommended.
● For OTN line ports, IEEE 1588v2 can be used only when lower-order ODUk cross-
connections are configured for the ports.
● For the tributary ports that receive Ethernet services, IEEE 1588v2 can be used only after
services are configured for the ports.
● When an electrical module is inserted into a port of the board, IEEE 1588v2 is not
supported.
● Boards do not support IEEE 1588v2 when working in relay mode.
● When the service cross-connections on the line board are switched, IEEE 1588v2 clock
tracing is affected. As a result, the clock source may be switched temporarily.
● The AUX board is an auxiliary board that provides the clock function.
When the OTN board receives Ethernet services, the working modes of the ports
that support IEEE 1588v2 vary according to the encapsulation types. The following
table lists the details.
Table 3-27 Port working modes supported by different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (TC, on
TC+OC, BC,
or OC)
NOTE
● For line boards, Clock Type can only be set to BC or OC, and P/E Mode can only be set to
E2E.
● The OSC boards support only BC and OC modes.
NOTE
Only some boards support high-precision clock synchronization. For details, see 5 High-
Precision Clock Synchronization Solution.
Table 3-28 Boards and device versions that support IEEE 1588v2
Board Type Board Name Start Version
TMB2AUXHP V100R021C10
TMB1DFSHP/TMB1SFSHP/TMB1FSHP V100R022C00
(OSC unit)
TMB1LQCB V100R022C00
TMK1UNS4MP V100R022C10
TMK1NP400M/TMK1NP400ME V100R021C10
TMB3EMS10D V100R022C10
NOTE
● HP: indicates that the board supports high-precision clock synchronization. Only
products in V100R021C10SPC300 (with NCE V100R021C10SPC200) and later versions
support high-precision clock synchronization. XFIU units do not affect synchronization
precision.
● You are advised to use OSC boards to implement PTP time synchronization between
sites. The single-fiber bidirectional OSC mode supports commissioning-free and delay
compensation-free functions. However, when line boards are used to configure PTP time
synchronization, compensation for asymmetric delay is required, the construction cost is
high, and the maintainability is poor. Therefore, this mode is not recommended.
● For OTN line ports, IEEE 1588v2 can be used only when lower-order ODUk cross-
connections are configured for the ports.
● For the tributary ports that receive Ethernet services, IEEE 1588v2 can be used only after
services are configured for the ports.
● When an electrical module is inserted into a port of the board, IEEE 1588v2 is not
supported.
● Boards do not support IEEE 1588v2 when working in relay mode.
● When the service cross-connections on the line board are switched, IEEE 1588v2 clock
tracing is affected. As a result, the clock source may be switched temporarily.
● The AUX board is an auxiliary board that provides the clock function.
When the OTN board receives Ethernet services, the working modes of the ports
that support IEEE 1588v2 vary according to the encapsulation types. The following
table lists the details.
Table 3-29 Port working modes supported by different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (TC, on
TC+OC, BC,
or OC)
NOTE
● For line boards, Clock Type can only be set to BC or OC, and P/E Mode can only be set to
E2E.
● The OSC boards support only BC and OC modes.
NOTE
Only some boards support high-precision clock synchronization. For details, see 5 High-
Precision Clock Synchronization Solution.
Table 3-30 Boards and device versions that support IEEE 1588v2 (optical-layer
configuration)
Table 3-31 Boards and device versions that support IEEE 1588v2
TMB2AST2 V100R019C10
TMB1DFSHP/TMB1SFSHP/TMB1FSHP V100R022C00
(OSC unit)
TMB1LQCB V100R022C00
NOTE
● HP: indicates that the board supports high-precision clock synchronization. Only
products in V100R021C10SPC300 (with NCE V100R021C10SPC200) and later versions
support high-precision clock synchronization. XFIU units do not affect synchronization
precision.
● You are advised to use OSC boards to implement PTP time synchronization between
sites. The single-fiber bidirectional OSC mode supports commissioning-free and delay
compensation-free functions. However, when line boards are used to configure PTP time
synchronization, compensation for asymmetric delay is required, the construction cost is
high, and the maintainability is poor. Therefore, this mode is not recommended.
● For OTN line ports, IEEE 1588v2 can be used only when lower-order ODUk cross-
connections are configured for the ports.
● For the tributary ports that receive Ethernet services, IEEE 1588v2 can be used only after
services are configured for the ports.
● When an electrical module is inserted into a port of the board, IEEE 1588v2 is not
supported.
● Boards do not support IEEE 1588v2 when working in relay mode.
● The AUX board is an auxiliary board that provides the clock function.
When the OTN board receives Ethernet services, the working modes of the ports
that support IEEE 1588v2 vary according to the encapsulation types. The following
table lists the details.
Table 3-32 Port working modes supported by different port service mapping paths
Table 3-33 Boards and device versions that support IEEE 1588v2 in OSN 1800 I
Compact subracks
When OTN tributary ports receive Ethernet services, the working modes of the
ports that support IEEE 1588v2 vary according to the encapsulation type. The
following table lists the details.
Table 3-34 Port working modes supported by different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (TC, on
TC+OC, BC,
or OC)
3.5 Specifications
This section describes the specifications for IEEE 1588v2.
Table 3-35 lists the specifications for IEEE 1588v2.
Packet ● PTP packet encapsulation format: Ethernet 802.3 (PTP ETH) and
encapsul UDP/IPv4 (PTP IP)
ation ● PTP packet VLAN: supported
format
NOTE
● For ports on packet boards, the encapsulation format of PTP packets can
be set to PTP ETH or PTP IP, and the VLAN IDs can be set.
● When receiving Ethernet services, OTN tributary ports only support the
PTP ETH encapsulation mode, and VLAN IDs can be set.
● Clock synchronization GE optical ports only support the PTP ETH
encapsulation mode, and VLAN IDs can be set.
● OTN line ports and OSC ports transmit PTP packets through overhead
bytes, and neither encapsulation format nor VLAN ID is involved.
Item Specifications
Item Specifications
External Supports 1PPS+ToD external time ports. For details, see 3.2.4 Time
time Source Port.
port
Item Specifications
Item Specifications
NOTE
Clock cascading between master and slave subracks is supported only when
subracks are configured in master/slave mode. For details about the
specifications and capabilities of the master and slave subracks, see
● For carriers: WDM OTN Master-Slave Subrack Management Guide
● For enterprises: WDM OTN Master-Slave Subrack Management Guide
When the OSN 9800/OSN 8800/OSN 6800 subracks that support master-slave
subrack clock cascading implement the clock cascading function, two clock
boards need to be configured for each subrack. The master clock subrack can
be configured in the slave service subrack. Master and slave service subracks
can be separated from master and slave clock subracks.
NOTE
This topic records feature updates of boards. However, new board hardware is not recorded
as feature updates. For details, see the "Availability" section.
OSN 9800 U/M/P series The product function is 3.4.3 OSN 9800 P Series
subracks (with NCE enhanced. Hardware and Version
V100R021C10SPC200 Support
and later versions) newly 3.4.4 OSN 9800 U Series
support high-precision Hardware and Version
clock synchronization. Support
3.4.5 OSN 9800 M
Series Hardware and
Version Support
5 High-Precision Clock
Synchronization
Solution
The new Added a new 3.4.5 OSN 9800 M Series Hardware and
OptiX OSN subrack to Version Support:
9800 M05 support basic Added OptiX OSN 9800 M05 subrack-related
subrack functions. information.
(system
control board:
TME1CTU/
TME2CTU)
supports IEEE
1588v2.
The TNU5CTU The product 3.4.4 OSN 9800 U Series Hardware and
board of the function is Version Support
OSN 9800 U enhanced.
series subrack
is added to
support IEEE
1588v2.
The TNG4CXP The product 3.4.5 OSN 9800 M Series Hardware and
board of the function is Version Support
OSN 9800 enhanced.
M24 subrack
is added to
support IEEE
1588v2.
The OSN Added a new 3.4.5 OSN 9800 M Series Hardware and
9800 M12 subrack to Version Support:
subrack is support basic Added OSN 9800 M12 subrack-related
added to functions. information.
support IEEE
1588v2.
The TNU4CTU The product ● 3.4.4 OSN 9800 U Series Hardware and
board of the function is Version Support: Added the TNU4CTU
OSN 9800 U enhanced. board.
series subrack ● 3.8.1 Configuring IEEE 1588v2 (OSN
is added to 1800/8800/9800Universal Platform
support IEEE Subrack/M Series/P Series/(U Series:
1588v2. U2CTU/S2CTU/U4CTU/U5CTU)): Added
the TNU4CTU board.
The TNG3CXP The product 3.4.5 OSN 9800 M Series Hardware and
board of the function is Version Support
OSN 9800 enhanced.
M24 subrack
is added to
support
physical-layer
clocks.
The OSN The product 3.4.3 OSN 9800 P Series Hardware and
9800 P series function is Version Support:
subrack is enhanced. Added the description of the OSN 9800 P
added to series subrack.
support IEEE
1588v2.
The TNU2CTU The product ● 3.4.4 OSN 9800 U Series Hardware and
and TNS2CTU function is Version Support: Added TNU2CTU and
boards of the enhanced. TNS2CTU.
OSN 9800 U ● 3.8.1 Configuring IEEE 1588v2 (OSN
series subrack 1800/8800/9800Universal Platform
are added to Subrack/M Series/P Series/(U Series:
support IEEE U2CTU/S2CTU/U4CTU/U5CTU)): Added
1588v2. TNU2CTU and TNS2CTU.
The OSN 9800 M24 Added a new subrack to 3.4.5 OSN 9800 M
subrack is added to support basic functions. Series Hardware and
support IEEE 1588v2. Version Support:
Added OSN 9800 M24
subrack-related
information.
The OSN 9800 U16 Added a new subrack to 3.4.4 OSN 9800 U Series
subrack is added to support basic functions. Hardware and Version
support IEEE 1588v2. Support:
Added the OSN 9800
U16 subrack.
The NMS GUI for IEEE The NMS GUI is 3.8.2 Configuring IEEE
1588v2 of OSN 9800 optimized. 1588v2 (OSN 9800 U
U64/U32/U16 subrack is Series: U1CTU/S1CTU):
changed. Added the entire chapter.
Updates in V100R001C20
Feature Update Reason for the Change Information Update
The EX2 and EG16 The boards are new to ● 3.4.6 OSN 8800
boards are added and the product and should Hardware and
they support IEEE support the basic board Version Support: A
1588v2. functions. description is added to
explain that packet
service boards support
IEEE 1588v2.
● 3.3 Dependencies
and Limitations: A
description is added to
explain that packet
service boards support
IEEE 1588v2.
● 3.8.1.4 Configuring
PTP NEs: A description
is added to explain
that the packet service
boards support
Configuring the PTP
Clock Domain.
The OSN 8800 universal The clock function is 3.3 Dependencies and
platform subrack newly enhanced. Limitations:
supports IEEE 1588v2. A description is added to
explain that the OSN
8800 universal platform
subrack supports IEEE
1588v2.
The STG clock board The product function is 3.2.4 Time Source Port:
newly supports mutual optimized to meet the The STG clock board's
conversion between requirements of function of mutual
1PPS+TOD quality industrial standards. conversion between 1PPS
information and IEEE +TOD quality information
1588v2 time quality and IEEE 1588v2 time
levels. quality levels is described
in detail.
The 1800 V Pro, 1800 II The product function is 3.4.11 OSN 1800 V Pro
Pro, and 1800 II TP (with enhanced. Hardware and Version
NCE Support
V100R021C10SPC200 3.4.12 OSN 1800 II Pro
and later versions) newly Hardware and Version
support high-precision Support
clock synchronization.
3.4.13 OSN 1800 II TP
Hardware and Version
Support
5 High-Precision Clock
Synchronization
Solution
The 1800 V Pro and 1800 The product function is 3.3.1 Feature
II Pro chassis (with NCE enhanced. Limitations
V100R021C10SPC200 3.8.1.1 Configuration
and later versions) newly Process
support automatic
compensation for ring 3.8.1.9 Configuring Ring
network delay offset and Network Automatic
automatic single-fiber Compensation
bidirectional
compensation.
The new 1800 V Pro This subrack is new Added 3.4.11 OSN 1800 V Pro
chassis supports to the product and Hardware and Version Support.
IEEE 1588v2. should support basic
device functions.
The new 1800 II Pro This subrack is new Added 3.4.12 OSN 1800 II Pro
chassis supports to the product and Hardware and Version Support.
IEEE 1588v2. should support basic
device functions.
The new 1800 II TP This subrack is new Added 3.4.13 OSN 1800 II TP
chassis supports to the product and Hardware and Version Support.
IEEE 1588v2. should support basic
device functions.
Network
Compensa
tion
Calculatio
n, and
Ring
Network
Automatic
Compensa
tion.
● 3.8.1.4
Configurin
g PTP NEs:
Added the
procedure
for
configuring
a key for
securely
returning
an IEEE
1588v2
compensat
ion value.
● 3.8.1.5
Configurin
g PTP Port
Parameter
s: Added
the
procedure
for
configuring
single-fiber
bidirection
al
asymmetri
c
compensat
ion.
● 3.8.1.10.3
Parameter
s: Clock
Synchroni
zation
Attribute:
Added the
description
of
parameters
related to
ring
compensat
ion value
calculation,
ring
network
automatic
compensat
ion, and
single-fiber
bidirection
al
asymmetri
cal
compensat
ion.
● Added
3.8.1.10.10
Parameter
s: 1588
Compensa
tion Back
Safe
Password.
The new OSN This subrack is new to the product and should Added 3.4.9
1800 II support basic device functions. OSN 1800 II
Enhanced Enhanced
chassis Hardware
supports IEEE and Version
1588v2. Support.
Updates in V100R005C00
Feature Reason for the Change Information
Update Update
● IEEE 1588v2: IEEE Standard for a Precision Clock Synchronization Protocol for
Networked Measurement and Control Systems
● ITU-T G.781: Synchronization layer functions
● ITU-T G.8262: Timing characteristics of synchronous Ethernet equipment slave
clock
NOTICE
NOTE
The procedure provided in Table 3-37 is only used to configure IEEE 1588v2-compliant
frequency and phase synchronization. To provide physical clock frequency synchronization
and IEEE 1588v2-compliant phase synchronization, configure the physical-layer clocks by
referring to 2.8.1.1 Configuration Process and then perform the procedure provided in
Table 3-37 to configure IEEE 1588v2 packets.
Table 3-37 Procedure for configuring IEEE 1588v2-compliant frequency and phase
synchronization
Procedure Remarks
Procedure Remarks
Procedure Remarks
Procedure Remarks
Procedure Remarks
Procedure Remarks
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● IEEE 1588v2 license resources are available.
Context
In the case of an NE that is equipped with master and slave subracks, an IEEE
1588v2 license needs to be allocated to each subrack that requires PTP clock
synchronization, and clock cascading needs to be correctly configured for the
master and slave subracks.
Procedure
Step 1 Enable IEEE 1588v2 for a new subrack.
NOTE
ITU-T G.8275.1 and IEEE 1588v2 share license resources. After IEEE 1588v2 is enabled on
the NMS, ITU-T G.8275.1 is also enabled.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The high-precision clock license has been loaded. For details, see License
Guide.
Precautions
The high-precision clock synchronization can be implemented for NEs and boards
only after the high-precision clock mode is set. The high-precision clock mode
controls the time synchronization performance of NEs and boards. Other
operations such as configuring the functions and parameters of PTP NEs and PTP
ports are the same as those for the common-precision clock mode. Configure the
clock mode based on the protocol type.
Procedure
Step 1 Configure the number of high-precision clock function licenses.
NOTICE
To make the high-precision clock mode take effect, you must set the clock
precision mode of the corresponding board to high before creating a PTP port. If a
PTP port is created before you set the high-precision clock mode for a board, you
must delete the PTP port and then create a new one.
----End
Follow-up Procedure
When the OSC board is used for high-precision clock synchronization, you need to
correctly set the fiber type, fiber length, and fiber dispersion coefficient on the
WDM Interface > Advanced Attributes page of the NMS.
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● IEEE 1588v2 has been enabled.
NOTE
Before configuring clocks, you need to set the frequency source mode as required.
● If physical-layer clock frequency synchronization is used, select Physical
Synchronization.
● If IEEE 1588v2 frequency synchronization is used, select PTP Synchronization.
----End
NOTE
● The PTP System Time field can be set only when the NE traces local clock sources.
● The time range is 2000-01-01 00:00:00 to 2069-12-31 23:59:59.
Step 2 Configure NE Clock Type, Slave Only, PTP Time Adjustment. For details about
the parameters, see 3.8.1.10.3 Parameters: Clock Synchronization Attribute.
NOTE
● The Slave Only parameter is available only when NE Clock Type is set to OC.
● If an NE requires only frequency synchronization, set PTP Time Adjustment to
Disabled; if an NE requires both frequency and time synchronization, set PTP Time
Adjustment to Enabled.
● When NE Clock Type of an NE is set to OC, Clock Type of PTP ports on the NE must be
set to OC and only one PTP port on the NE can be enabled.
● When NE Clock Type of an NE is set to BC, Clock Type of PTP ports on the NE must be
set to BC.
● When NE Clock Type of an NE is set to TC, Clock Type of PTP ports on the NE must be
set to TC.
● When NE Clock Type of an NE is set to TC+OC, Clock Type of PTP ports on the NE can
be set to either TC+OC or TC.
● When NE Clock Type of an NE is set to TC+BC, Clock Type of PTP ports on the NE can
be set to either TC or BC.
● When NE Clock Type of an NE is set to TC+BC, and Static BMC is set to Enabled, do
not change the Clock Type of PTP ports on the NE to TC.
● The device that is in the BC or OC working mode can belong to only one clock subnet,
and its clock source can be selected only within the same clock subnet.
NOTICE
----End
----End
Step 1 Configure PTP Clock Subnet. For details about the parameters, see 3.8.1.10.5
Parameters: PTP Clock Subnet.
NOTE
● The NEs that have the same subnet number belong to the same clock subnet.
● Equipment that is in the BC or OC working mode can belong to only one clock subnet,
and its clock source can be selected only from within the same clock subnet.
----End
Step 1 Configure Time Quality Level, Time Precision, Clock Source Type, and so on. For
details about the parameters, see 3.8.1.10.6 Parameters: BMC (Clock Subnet).
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The required boards have been created.
● A clock synchronization GE optical port has been created on the NE Panel.
NOTE
● For OSN 1800, Frame Format can be set for the following boards:
● New OTU boards and OTN line boards (including universal line boards) in
V100R019C10 and later versions.
● UNS4 board of the OSN 1800 V.
● For the OSN 9800, Frame Format can be set for the following boards: new OTU boards
and OTN line boards (including universal line boards) in V100R007C00SPC700 and later
versions.
● After the Frame Format of the UNS4 board on the OSN 1800 V is set to HDLC, the PTP
Clock Message Location parameter can be set.
● PTP Clock Message Location can be set for the Z5UNQ2 board on OSN 1800. When
the overhead in row 1 and column 13 is used, the Frame Format is GFP. When the
overhead in row 2 and column 3 is used, the Frame Format is HDLC.
● For boards on other products, when the Frame Format is set to GFP, the overhead
bytes in row 1 and column 13 are used. When the Frame Format is set to HDLC, the
overhead bytes in row 2 and column 3 are used.
NOTICE
● When the same type of boards are interconnected, PTP Clock Message
Location and Frame Format can retain the default values.
● When different boards are interconnected, you must query and set PTP Clock
Message Location and Frame Format to ensure that they are consistent on
the interconnected ports.
For example, when a Z5UNS4 board on the OSN 1800 interconnects with a
K1UNS4/K1UNS5 board, PTP Clock Message Location and Frame Format
need to be modified.
● If the ODUk trail delay measurement function is required in the O&M
phase, set the PTP packet frame format to GFP for the Z5UNS4 and
K1UNS4/K1UNS5 boards.
● If the ODUk trail delay measurement function is not required, set PTP
Clock Message Location of the Z5UNS4 board to row 2 and column 3,
and set Frame Format to HDLC at both ends.
● When Frame Format of a local board changes between GFP and HDLC and is
different from that of the interconnected board, clock source tracing will be
affected.
----End
NOTICE
NOTE
NOTE
● After enabling static BMC, you must manually set the status of ports where IEEE 1588v2
is enabled. The default port state is LISTENING.
● If you want to modify a selected port, select the corresponding port in the Selected
Port field, and then click to add the port to Available Port.
----End
port is BC or OC, the domain ID of the port is the same as the clock subnet ID of
the NE.
Step 1 Configure Domain ID. For details, see 3.8.1.10.3 Parameters: Clock
Synchronization Attribute.
----End
Step 1 Select a port and set P/E Mode, SYNC Packet Period(s), DELAY Packet
Period(s), PDELAY Packet Period(s), ANNOUNCE Packet Period(s), and
ANNOUNCE Packet Timeout Coefficient. For details about the parameters, see
3.8.1.10.3 Parameters: Clock Synchronization Attribute.
NOTE
DELAY Packet Period(s) is available only when P/E Mode is set to E2E. PDELAY Packet
Period(s) is available only when P/E Mode is set to P2P.
----End
Step 1 Select a port, and set Warp Direction, Warp Mode, Warp Length(m), and Warp
Time(ns). For details about the parameters, see 3.8.1.10.3 Parameters: Clock
Synchronization Attribute.
NOTE
● The value Positive of the Warp Direction parameter specifies that transmission
distance in the receive direction is longer than the distance in the transmit direction, or
the transmission time in the receive direction is longer than the time in the transmit
direction; the value Negative specifies just the opposite.
● Warp Length(m) is available only when Warp Mode is set to Length; Warp Time(ns)
is available only when Warp Mode is set to Time.
● The values of Warp Length(m) and Warp Time(ns) are set depending on the
networking scheme for the site.
----End
NOTE
Only the following boards on the following products support single-fiber bidirectional
asymmetric compensation. For details about the restrictions, see 3.3.1 Feature Limitations.
● OSN 1800 V (Z-series system control boards) V100R009C00 and later versions: EX4 and
EG10
● OSN 1800 V Pro (K5UXCME system control board): EX10
● OSN 1800 II Pro (K2UXCLE system control board): EX10
----End
NOTE
Step 1 Select a port and set its MAC address. For details about the parameters, see
3.8.1.10.11 Parameters: MAC Address Configuration.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● IEEE 1588v2 has been enabled.
● A clock board and a clock interface board have been created.
NOTICE
For the OSN 1800, if the TNF1AUX board is required, you must create the STG
logical board and then the AUX logical board. Otherwise, the external clock/
time port of the TNF1AUX board cannot work properly. In this case, you need
to delete and re-create the logical AUX board.
● For the OSN 6800, you have prepared a 120-ohm external clock port cable as
the network cable for external port cascading of clock boards.
NOTE
When an NE is equipped with master and slave subracks, you need to specify a subrack
with a clock board as the clock center subrack. If other subracks receive clock signals from
the upstream or output time signals to the downstream, you need to set the clock
cascading relationship between these subracks and the clock center subrack and correctly
connect the subracks. For details, see 2.8.1.4 Configuring the Clock Center Subrack under
2.8.1.1 Configuration Process.
When an OSN 1800 NE is configured with multiple AUX boards (F1AUX/B1AUX/B2AUX),
you need to set one AUX board as the main AUX board. For details, see 2.8.1.5 Configuring
a Main AUX Board under 2.8.1.1 Configuration Process.
● Each subrack has two clock ports and two time ports. These ports are used to
concatenate and transmit the clock or time signals among multiple subracks,
or are used to input or output external clock and time signals. By default,
Enabled Status of all ports is Unused. If any ports need to be used for the
input or output of external clock and time signals, Enabled Status of the
corresponding ports should be set to Disabled. One NE supports a maximum
of two ports for the input or output of external clock and time signals.
● After PTP Synchronization is enabled for an NE, the NE automatically
switches the frequency source mode to Physical Synchronization when
Enabled Status of the external clock port on the NE's clock board changes
from Enabled to Disabled or changes from Unused to Disabled. When this
occurs, manually set the frequency source mode of the NE to PTP
Synchronization.
NOTE
For details about the ports that support the cascading mode, see "Clock cascading between
master and slave subracks" in 2.5 Specifications.
Step 1 Configure Enabled Status. For details about the parameters, see 2.8.1.15.3
Parameters: Clock Port Link.
----End
Step 1 Select an external time port and set Direction, Interface Protocol Type, and
Interface Level. For details about the parameters, see 3.8.1.10.7 Parameters:
Basic Attribute.
NOTE
For the Interface Level parameter, the OSN 6800 supports only the value RS422.
Step 2 Set Time Quality Level, Time Precision, Clock Source Type, Clock Source
Priority 1, Clock Source Priority 2, and Clock Source Deviation. For details about
the parameters, see 3.8.1.10.8 Parameters: BMC (External Time Interface).
The STG clock board supports mutual conversion between 1PPS+TOD quality
information and IEEE 1588v2 time quality levels.
● If the manually specified Time Quality Level is not the default value 187, the
manually specified IEEE 1588v2 time quality level applies.
● If the manually specified Time Quality Level is the default value 187, the STG
clock board automatically converts the quality information carried in the TOD
into the IEEE 1588v2 time quality level based on the predefined conversion
table.
Table 3-38 provides the mapping between the TOD status information and IEEE
1588v2 time quality level.
Table 3-38 Mapping between the TOD status information and IEEE 1588v2 time
quality level
TOD Status Information IEEE 1588v2 Time Quality Level
0x00: normal 6
----End
Step 1 Select an external time port and set Transmitting Direction, Transmitting
Distance Mode, Transmitting Length(m), and Transmitting Time(ns). For
details about the parameters, see 3.8.1.10.9 Parameters: Cable Transmitting
Distance.
NOTE
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● A clock port has been created.
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Context
When the clock tracing relationship changes, NCE automatically updates the
tracing relationship in the clock view.
Procedure
Step 1 In the Main Topology, select Clock View from the Current View drop-down list.
Then, select an NE whose clocks are to be queried or set from the Object Tree.
Step 2 In the Clock View, right-click and choose Search Clock Link from the shortcut
menu.
Step 3 In the Search Clock Link window, set Clock Type and Search Mode, select the NE
to be queried, and click OK.
Step 4 In the Result dialog box, click Close.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● Time synchronization has been implemented between NEs on the ring
network.
● The DCN communication between NEs on the ring network is normal.
Context
NOTE
Only the following boards on the following products support automatic compensation of
ring network delay offset. For details about the restrictions, see 3.3.1 Feature Limitations.
● OSN 1800 V (Z-series system control boards) V100R009C00 and later versions: UNS4,
EX4, EG10, and UNQ2
● OSN 1800 V Pro (K5UXCME system control board):
● V100R021C10 and later versions: UNS5, UNS4, GTA, UNQ2, UND3 and EX10
● V100R022C10 and later versions: K1GDC
● OSN 1800 II Pro (K2UXCLE system control board):
● V100R021C10 and later versions: UNS5, UNS4, GTA, UNQ2, UND3 and EX10
● V100R022C10 and later versions: K1GDC
● Ring network automatic compensation can be enabled only after an NE
achieves time synchronization (traces the grandmaster clock). Otherwise, the
calculated compensation value may be inaccurate.
● The ring network compensation value is returned through DCN channels.
Ensure that the DCN links between sites are normal.
● When Ring Network Automatic Compensation is set to Enabled:
– If the offset value is less than 50 ns, automatic compensation is not
performed on the ring network and the FIB_LEN_CHANGE alarm is not
reported. Only logs are recorded.
– If the offset value is within the automatic compensation range (50 ns to
500 ns), automatic compensation is performed on the ring network and
an event is reported.
– If the offset value is greater than 500 ns, the FIB_LEN_CHANGE and
FIBER_ASYMMETRIC_CHANGED alarms are reported. You need to
manually set the compensation value according to the recommended
value. After the configuration is complete, the alarms will be cleared.
● When Ring Network Automatic Compensation is set to Disabled, no
automatic compensation is performed but an alarm is reported. The alarm is
cleared after the compensation value is manually configured.
Procedure
Step 1 Set Ring Network Compensation Calculation and Ring Network Automatic
Compensation. For details about the parameters, see 3.8.1.10.3 Parameters:
Clock Synchronization Attribute.
Step 2 Set 1588 Compensation Back Safe Password. The values of 1588 Compensation
Back Safe Password must be consistent between the NEs at both ends. For details
about the parameters, see 3.8.1.10.10 Parameters: 1588 Compensation Back
Safe Password.
----End
Follow-up Operations
If Ring Network Automatic Compensation is set to Disabled, the system
provides the recommended compensation value in the alarm after the
asymmetrical offset value of the ring link changes. You need to set the
compensation value manually.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Frequency Source Mode from Function Tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > Port
Cascading from Function Tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > Clock Synchronization Attribute from the Function Tree.
Parameters
PTP System Time For example: Displays the PTP system time.
2009-02-01 01:01:01 You can manually modify this
parameter.
NE Clock Type OC, TC, BC, TC+BC, TC The NE Clock Type parameter
+OC provides an option to set the
Default: BC working mode (OC, TC, BC, TC
+BC, TC+OC) of the node that
adopts the IEEE 1588v2 clock.
According to the network
planning, an NE on the network
must work in the OC, TC, BC, TC
+BC, or TC+OC mode. The
specific working mode of the NE
must be determined in the
network planning phase.
During network planning, first
determine the position and
function of the NE and each port
on the NE. Then, set the working
mode of the NE according to the
features of each working mode.
● OC: As a clock device with
only one PTP port in the clock
domain, OC maintains the
time stamp used in the clock
domain. The clock device can
function as a master clock
device to provide a clock
source or as a slave clock
device to keep synchronous
with other clock devices.
● TC: TC forwards certain PTP
event messages and records
the residence time of the PTP
event messages on it. In
addition, TC provides the
recorded information to the
clock that receives the PTP
event messages. Then, the
recorded information is used
for transparent transmission
of packets and adjustment of
the residence time of the
packets on the equipment.
● BC: As a clock device with
multiple PTP ports in the clock
domain, BC maintains the
time stamp used in the clock
domain. The clock device can
function as a master clock
device to provide a reference
clock source or as a slave
Clock Type OC, BC, TC, TC+OC The Clock Type parameter
Default: BC provides an option to set the
working mode (OC, BC, TC, or
Each board supports TC+OC) of the node that adopts
the clock type, refer to the IEEE 1588v2 clock. According
the availability of IEEE to the network planning, an NE
1588v2. on the network must work in
the OC, BC, TC, or TC+OC mode.
The specific working mode of
the NE must be determined in
the network planning phase.
● OC: When ports on an NE are
set to OC mode, the NE can
work only in master or slave
status. A port in OC mode
can be used only for time
input or output.
● BC: When ports on an NE are
set to BC mode, the master or
slave status of the NE is
determined by using the BMC
algorithm.
● TC: If ports on an NE are set
to TC mode, the NE only
transparently transmits time
messages and does not
restore clock or time
information. In addition, the
NE does not have the master
or slave status.
● TC+OC: When ports on an NE
are set to TC+OC mode the
NE restores clock information
but does not restore time
information, achieving TC
performance transmission.
● When NE Clock Type of an
NE is set to OC, Clock Type
of PTP ports on the NE must
be set to OC and only one
PTP port on the NE can be
enabled.
● When NE Clock Type of an
NE is set to BC, Clock Type of
PTP ports on the NE must be
set to BC.
● When NE Clock Type of an
NE is set to TC, Clock Type of
Step Mode One step, Two step Specifies whether an IEEE 1588
Default: One step port works in the one-step or
two-step mode. Only tributary
boards support the settings of
one-step and two-step modes.
● In one-step mode, the actual
Tx time stamp is sent through
the Sync packet to be
transmitted. The one-step
mode requires the equipment
of high precision and
accuracy.
● In two-step mode, the actual
Tx time stamp is not added to
the Sync packet to be
transmitted. Instead, the time
stamp is sent through the
subsequent Follow-Up
message.
NOTE
Only the following boards on the following products support single-fiber bidirectional
asymmetric compensation. For details about the restrictions, see 3.3.1 Feature Limitations.
● OSN 1800 V (Z-series system control boards) V100R009C00 and later versions: EX4 and
EG10
● OSN 1800 V Pro (K5UXCME system control board): EX10
● OSN 1800 II Pro (K2UXCLE system control board): EX10
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Source at Port from Function Tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> PTP Clock Subnet Configuration from the Function Tree. Then, click the PTP
Clock Subnet tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> PTP Clock Subnet Configuration from the Function Tree. Then, click the BMC
tab.
Parameters
Field Value Description
Time Quality Level 6, 7, 13, 14, 52, 58, 68 to The Time Quality Level
122, 133 to 170, 216 to parameter provides an
232, 187, 193, 248, 255 option to set the quality
Default: 187 level of the time or
frequency allocated by
the master clock device.
A smaller parameter
value indicates a higher
quality level.
This parameter has an
impact on selection of
the external clock source
for tracing. If the PTP
Clock Source Priority 1
values of the clock
candidates are the same,
Time Quality Level
determines which clock
is preferred. That is, the
clock with a smaller
Time Quality Level
value is of a higher
quality level and is
preferred as the time
source for tracing.
PTP Clock Source Type ATOMIC_CLOCK, GPS, The PTP Clock Source
TERRESTRIAL_RADIO, Type parameter provides
PTP, NTP, HAND_SET, an option to set the type
OTHER, of the clock source.
INTERNAL_OSCILLATOR ● ATOMIC_CLOCK:
Default: Indicates an atomic
INTERNAL_OSCILLATOR clock.
● GPS: Indicates a GPS
time source.
● TERRESTRIAL_RADIO:
Indicates the clock
source synchronized
through any of the
radio distribution
systems that
distribute time and
frequency tied to
international
standards.
● PTP: Indicates a clock
source compliant with
the PTP protocol.
● NTP: Indicates a clock
source compliant with
the network time
protocol (NTP).
● HAND_SET: Indicates
a clock source
manually set.
● OTHER: Indicates
other clock sources.
● INTERNAL_OSCILLAT
OR: Indicates an
internal clock source.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the Basic Attribute
tab.
Parameters
Field Value Description
External Time Interface shelf ID (shelf name)- Displays the name of the
slot number-board input interface of the
name-external clock external clock source on
interface the NE.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the BMC tab.
Parameters
Field Value Description
External Time Interface shelf ID (shelf name)- Displays the name of the
slot number-board input interface of the
name-external clock external clock source on
interface the NE.
Time Quality Level 6, 7, 13, 14, 52, 58, 68 to The Time Quality Level
122, 133 to 170, 216 to parameter provides an
232, 187, 193, 248, 255 option to set the quality
Default: 187 level of the time or
frequency allocated by
the master clock device.
A smaller parameter
value indicates a higher
quality level.
This parameter has an
impact on selection of
the external clock source
for tracing. If the PTP
Clock Source Priority 1
values of the clock
candidates are the same,
Time Quality Level
determines which clock
is preferred. That is, the
clock with a smaller
Time Quality Level
value is of a higher
quality level and is
preferred as the time
source for tracing.
PTP Clock Source Type ATOMIC_CLOCK, GPS, The PTP Clock Source
TERRESTRIAL_RADIO, Type parameter provides
PTP, NTP, HAND_SET, an option to set the type
OTHER, of the clock source.
INTERNAL_OSCILLATOR ● ATOMIC_CLOCK:
Default: Indicates an atomic
INTERNAL_OSCILLATOR clock.
● GPS: Indicates a GPS
time source.
● TERRESTRIAL_RADIO:
Indicates the clock
source synchronized
through any of the
radio distribution
systems that
distribute time and
frequency tied to
international
standards.
● PTP: Indicates a clock
source compliant with
the PTP protocol.
● NTP: Indicates a clock
source compliant with
the network time
protocol (NTP).
● HAND_SET: Indicates
a clock source
manually set.
● OTHER: Indicates
other clock sources.
● INTERNAL_OSCILLAT
OR: Indicates an
internal clock source.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the Cable
Transmitting Distance tab.
Parameters
Field Value Description
External Time Interface shelf ID (shelf name)- Displays the name of the
slot number-board input interface of the
name-external clock external clock source on
interface the NE.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > PTP Clock >
Safety Password from the Function Tree.
Parameters
Navigation Path
In the NE Explorer, click the NE and choose Configuration > Clock > PTP Clock >
MAC Address Configuration.
Parameters
Field Value Description
Table 3-46 provides the detailed procedure for configuring IEEE 1588v2-compliant
frequency and phase synchronization.
NOTE
The procedure provided in Table 3-46 is only used to configure IEEE 1588v2-compliant
frequency and phase synchronization. To provide physical clock frequency synchronization
and IEEE 1588v2-compliant phase synchronization, configure the physical-layer clocks by
referring to 2.8.2.1 Configuration Process and then perform the procedure provided in
Table 3-46 to configure IEEE 1588v2 packets.
Table 3-46 Procedure for configuring IEEE 1588v2-compliant frequency and phase
synchronization
Operation Remarks
Operation Remarks
Operation Remarks
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● IEEE 1588v2 license resources are available.
● The required subracks have been created.
Procedure
Step 1 Change the 1588V2 attribute to Enabled.
NOTE
ITU-T G.8275.1 and IEEE 1588v2 share license resources. After IEEE 1588v2 is enabled on
the NMS, ITU-T G.8275.1 is also enabled.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● IEEE 1588v2 has been enabled.
NOTE
The PTP System Time field can be set only when the NE traces local clock sources.
Step 3 Set Ne Clock Type, Static BMC, Slave Only, Packet Multicast Mode, Protocol
Packet Format, Correct UTC Time. For details about the parameters, see 3.8.2.8.1
NOTE
The Slave Only parameter is available only when NE Clock Type is set to OC.
----End
Step 1 Configure Clock Subnet No.. For details about the parameter, see 3.8.2.8.3
Parameters: Clock Subnet.
NOTE
● The NEs that have the same subnet number belong to the same clock subnet.
● Equipment that is in the BC or OC working mode can belong to only one clock subnet,
and its clock source can be selected only from within the same clock subnet.
----End
Step 1 Set Time Quality Level, Time Precision, Clock Source Type, Clock Source
Priority 1, and Clock Source Priority 2. For details about the parameters, see
3.8.2.8.4 Parameters: BMC (Clock Subnet).
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The required boards have been created.
● IEEE 1588v2 has been enabled.
Step 1 Configure a clock port. For details about the parameters, see 3.8.2.8.1
Parameters: Clock Synchronization Attribute.
NOTICE
When the 10GE LAN tributary board is used on OSN 9800 V100R001C00 or
V100R001C01 and Port Mapping is set to MAC Transparent Mapping (10.7G), if
the OSN 9800 is upgraded to V100R001C20, configuring the port as a PTP port to
support IEEE 1588v2 interrupts traffic on the port. The traffic is restored
automatically after the configuration is completed.
NOTE
----End
NOTE
The value of Clock Source WTR Time(min) ranges from 0 to 12 with a step of 1 minute.
The default value is 5.
Step 2 Set Port, Clock Source No, and Clock Source PortNo.
----End
Step 1 Set P/E Mode, SYNC Packet Period(s), DELAY Packet Period(s), PDELAY Packet
Period(s), ANNOUNCE Packet Period(s), and ANNOUNCE Packet Timeout
Coefficient. For details about the parameters, see 3.8.2.8.1 Parameters: Clock
Synchronization Attribute.
NOTE
DELAY Packet Period(s) is available only when P/E Mode is set to E2E. PDELAY Packet
Period(s) is available only when P/E Mode is set to P2P.
----End
Step 1 Set Warp Direction, Warp Mode, Warp Length(m), and Warp Time(ns). For
details about the parameters, see 3.8.2.8.1 Parameters: Clock Synchronization
Attribute.
NOTE
● The value Positive of the Warp Direction parameter specifies that transmission
distance in the receive direction is longer than the distance in the transmit direction, or
the transmission time in the receive direction is longer than the time in the transmit
direction; the value Negative specifies just the opposite.
● Warp Length(m) is available only when Warp Mode is set to Length; Warp Time(ns)
is available only when Warp Mode is set to Time.
● The values of Warp Length(m) and Warp Time(ns) are set depending on the
networking scheme for the site.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● IEEE 1588v2 has been enabled.
● The required CTU board has been created.
Step 1 Select an external time port and set External Time Interface Direction and
Interface Protocol Type. For details about the parameters, see 3.8.2.8.5
Step 2 Set Bits Type, Bits Clock Class Level, Bits Precision, Bits Time Source, Bits
Priority 1, Bits Priority 2. For details about the parameters, see 3.8.2.8.6
Parameters: BMC (External Time Interface).
----End
Step 1 Select an external time port and set Input Warp Mode, Input Warp Length(m),
Input Warp Time(ns), Output Warp Mode, Output Warp Length(m), and
Output Warp Time(ns). For details about the parameters, see 3.8.2.8.7
NOTE
● Input Warp Length(m) is available only when Input Warp Mode is set to Length;
Input Warp Time(ns) is available only when Input Warp Mode is set to Time.
● Output Warp Length(m) is available only when Output Warp Mode is set to Length;
Output Warp Time(ns) is available only when Output Warp Mode is set to Time.
● The values of Input Warp Length(m), Output Warp Length(m), Input Warp
Time(ns), and Output Warp Time(ns) are set depending on the networking scheme
for the site.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● A clock port has been created.
Procedure
Step 1 Query the information about the clock source received at the port.
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Context
When the clock tracing relationship changes, NCE automatically updates the
tracing relationship in the clock view.
Procedure
Step 1 In the Main Topology, select Clock View from the Current View drop-down list.
Then, select an NE whose clocks are to be queried or set from the Object Tree.
Step 2 In the Clock View, right-click and choose Search Clock Link from the shortcut
menu.
Step 3 In the Search Clock Link window, set Clock Type and Search Mode, select the NE
to be queried, and click OK.
Step 4 In the Result dialog box, click Close.
----End
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > Clock Synchronization Attribute from the Function Tree.
Parameters
PTP System Time For example: Displays the PTP system time.
2009-02-01 01:01:01 You can manually modify this
parameter.
NE Clock Type OC, TC, BC, TC+BC, TC The NE Clock Type parameter
+OC provides an option to set the
Default: BC working mode (OC, TC, BC, TC
+BC, or TC+OC) of the node that
adopts the IEEE 1588v2 clock.
According to the network
planning, an NE on the network
must work in the OC, TC, BC, TC
+BC, or TC+OC mode. The
specific mode of the NE must be
determined in the network
planning phase.
Protocol Packet NMEA, UBX Sets and queries the IEEE 1588
Format Default: UBX clock protocol packet format.
Ingress of Current For example: PTP Displays the local clock input
Master Clock interface of the master clock
that the NE traces after you
specify the clock source for the
NE.
PTP Profile IEEE 1588v2, G.8275.1 Indicates the PTP protocol type
Default: IEEE 1588v2 used by the NE.
PTP Packet - -
Destination MAC
Address
PTP Packet - -
Destination IP
Address
Step Module One step, Two step Specifies whether an IEEE 1588
Default: One step port works in the one-step or
two-step mode.
● In one-step mode, the actual
Tx time stamp is sent through
the Sync packet to be
transmitted. The one-step
mode requires the equipment
of high precision and
accuracy.
● In two-step mode, the actual
Tx time stamp is not added to
the Sync packet to be
transmitted. Instead, the time
stamp is sent through the
subsequent Follow-Up
message.
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Source Priority Table from Function Tree. Click the Clock Source at Port
tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Subnet Configuration from the Function Tree. Then, click the Clock
Subnet tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Subnet Configuration from the Function Tree. Then, click the BMC tab.
Parameters
Field Value Description
PTP Clock Source Type ATOMIC_CLOCK, GPS, The PTP Clock Source
TERRESTRIAL_RADIO, Type parameter provides
PTP, NTP, HAND_SET, an option to set the type
OTHER, of the clock source.
INTERNAL_OSCILLATOR ● ATOMIC_CLOCK:
Default: Indicates an atomic
INTERNAL_OSCILLATOR clock.
● GPS: Indicates a GPS
time source.
● TERRESTRIAL_RADIO:
Indicates the clock
source synchronized
through any of the
radio distribution
systems that
distribute time and
frequency tied to
international
standards.
● PTP: Indicates a clock
source compliant with
the PTP protocol.
● NTP: Indicates a clock
source compliant with
the Network Time
Protocol (NTP).
● HAND_SET: Indicates
a clock source that is
manually set.
● OTHER: Indicates
other clock sources.
● INTERNAL_OSCILLAT
OR: Indicates an
internal clock source.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the External Time
Interface Attribute tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the BMC tab.
Parameters
Field Value Description
Bits 1PPS Status Available, Atomic Clock 1PPS status values can
Hold, Unavailable, be converted into time
Oscillator Hold, quality levels according
Transport Device Hold, to the conversion table.
Rubidiumc Clock Hold ● Available corresponds
to level 6.
● Atomic Clock Hold,
Unavailable
corresponds to level 7.
● Unavailable
corresponds to level
255.
● Oscillator Hold
corresponds to level
52.
● Transport Device Hold
corresponds to level
187.
● Rubidiumc Clock Hold
corresponds to level 8.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the Bits
Transmitting Warp tab.
Parameters
Field Value Description
Figure 3-17 shows the process of implementing time synchronization using IEEE
1588v2 packets.
Table 3-51 provides the detailed procedure for configuring IEEE 1588v2-compliant
frequency and phase synchronization.
NOTE
The procedure provided in Table 3-51 is only used to configure IEEE 1588v2-compliant
frequency and phase synchronization. To provide physical clock frequency synchronization
and IEEE 1588v2-compliant phase synchronization, configure the physical-layer clocks by
referring to 2.9.1.1 Configuration Process and then perform the procedure provided in
Table 3-51 to configure IEEE 1588v2 packets.
Table 3-51 Procedure for configuring IEEE 1588v2-compliant frequency and phase
synchronization
Operation Remarks
Operation Remarks
Operation Remarks
Operation Remarks
Operation Remarks
Prerequisites
● You are an NMS user with Operator Group rights or higher.
● IEEE 1588v2 license resources are available.
Procedure
Step 1 Enable IEEE 1588v2 for a new subrack.
NOTE
ITU-T G.8275.1 and IEEE 1588v2 share license resources. After IEEE 1588v2 is enabled on
the NMS, ITU-T G.8275.1 is also enabled.
NOTE
● OSN 9800:
– Universal platform subrack: The universal platform subracks on the same NE
implement frequency/phase synchronization through clock cascading between
master and slave subracks.
– U series subrack:
In versions earlier than V100R007C00, electrical subracks on the same NE do not
support clock cascading between master and slave subracks. Therefore, only one
electrical subrack on each NE supports frequency/phase synchronization. You are
advised to configure all boards requiring frequency and phase synchronization in
the same subrack.
In V100R007C00 and later versions, when the system control board is TNU2CTU or
TNS2CTU, electrical subracks on the same NE support clock cascading between
master and slave subracks. When the system control board is TNU4CTU or
TNU5CTU, electrical subracks on the same NE support clock cascading between
master and slave subracks.
– M series subracks: Clock cascading between master and slave subracks is
supported.
– P series subracks: Clock cascading between master and slave subracks is supported.
– Clock cascading between master and slave subracks cannot be implemented
between universal platform subracks and U/M series subracks.
● OSN 1800:
– Subracks that use the TMB1AUX board support clock cascading between master
and slave subracks since V100R020C10. The ports supported by the TMB1AUX
board are external clock/time ports and clock synchronization GE optical ports.
– Subracks that use the TMB2AUX/MD48AFS board support clock cascading between
master and slave subracks since V100R021C10. The ports supported by the
TMB2AUX board are external clock/time ports and clock synchronization GE optical
ports. The ports supported by the MD48AFS board are clock synchronization GE
optical ports.
– Subracks that use the TMK5SXCH/TMK5UXCME/TMK5XCH/TMK5GSCC board
support clock cascading between master and slave subracks since V100R022C00.
The ports supported by the board are clock synchronization GE optical ports.
– Subracks that use the TMK6XCH board support clock cascading between master
and slave subracks since V100R022C10. The ports supported by the board are clock
synchronization GE optical ports.
● OSN 8800/6800: Clock cascading between master and slave subracks is supported.
----End
Prerequisites
● You are an NMS user with "Operator Group" authority or higher.
● IEEE 1588v2 has been enabled.
NOTE
Based on the practical networking, you need to configure the frequency source mode of an
NE before configuring a clock.
● If physical-layer clocks are used to achieve frequency synchronization, select Physical
Synchronization.
● If IEEE 1588v2 packets are used for frequency synchronization, select PTP
Synchronization.
----End
NOTE
● The PTP System Time field can be set only when the NE traces local clock sources.
● The time range is 2000-01-01 00:00:00 to 2069-12-31 23:59:59.
Step 2 Configure NE Clock Type, Slave Only, PTP Time Adjustment, Ring Network
Compensation Calculation, Ring Network Automatic Compensation. For details
about the parameters, see 3.9.1.8.3 Parameters: Clock Synchronization
Attribute.
NOTE
● The Slave Only parameter is available only when NE Clock Type is set to OC.
● If an NE requires only frequency synchronization, set PTP Time Adjustment to
Disabled; if an NE requires both frequency and time synchronization, set PTP Time
Adjustment to Enabled.
● When NE Clock Type of an NE is set to OC, Clock Type of PTP ports on the NE must be
set to OC and only one PTP port on the NE can be enabled.
● When NE Clock Type of an NE is set to BC, Clock Type of PTP ports on the NE must be
set to BC.
● When NE Clock Type of an NE is set to TC, Clock Type of PTP ports on the NE must be
set to TC.
● When NE Clock Type of an NE is set to TC+OC, Clock Type of PTP ports on the NE can
be set to either TC+OC or TC.
● When NE Clock Type of an NE is set to TC+BC, Clock Type of PTP ports on the NE can
be set to either TC or BC.
● When NE Clock Type of an NE is set to TC+BC, and Static BMC is set to Enabled, do
not change the Clock Type of PTP ports on the NE to TC.
● The device that is in the BC or OC working mode can belong to only one clock subnet,
and its clock source can be selected only within the same clock subnet.
NOTICE
----End
----End
Step 1 Set PTP Clock Subnet. For details about the parameter, see 3.9.1.8.5 Parameters:
PTP Clock Subnet.
NOTE
● The NEs that have the same subnet number belong to the same clock subnet.
● Equipment that is in the BC or OC working mode can belong to only one clock subnet,
and its clock source can be selected only from within the same clock subnet.
----End
Step 1 Configure Time Quality Level, Time Precision, Clock Source Type, and so on. For
details about the parameters, see 3.9.1.8.6 Parameters: BMC (Clock Subnet).
----End
----End
Prerequisites
● You are an NMS user with "Operator Group" authority or higher.
● The required boards have been created.
● IEEE 1588v2 has been enabled.
NOTE
● Before configuring a port on a board as a PTP port, you need to configure the position
and frame format of PTP clock packets.
● PTP Clock Message Location is available only when Frame Format is set to HDLC.
● Only the UNS4 and UNQ2 boards of the OSN 1800 V support the setting of PTP Clock
Message Location.
● Only the UNS4 board of the OSN 1800 V supports the setting of Frame Format.
● When Frame Format of a local board changes between GFP and HDLC and is different
from that of the interconnected board, clock source tracing will be affected.
----End
NOTICE
NOTE
NOTE
● After enabling static BMC, you must manually set the status of ports where IEEE 1588v2
is enabled. The default port state is LISTENING.
● If you want to modify a selected port, select the corresponding port in the Selected
Port field, and then click to add the port to Available Port.
----End
Step 1 Set the domain ID. For details, see 3.9.1.8.3 Parameters: Clock Synchronization
Attribute.
----End
Step 1 Select a port and set P/E Mode, SYNC Packet Period(s), DELAY Packet
Period(s), PDELAY Packet Period(s), ANNOUNCE Packet Period(s), and
ANNOUNCE Packet Timeout Coefficient. For details about the parameters, see
3.9.1.8.3 Parameters: Clock Synchronization Attribute.
NOTE
DELAY Packet Period(s) is available only when P/E Mode is set to E2E. PDELAY Packet
Period(s) is available only when P/E Mode is set to P2P.
----End
Step 1 Select a port, and set Warp Direction, Warp Mode, Warp Length(m), and Warp
Time(ns). For details about the parameters, see 3.9.1.8.3 Parameters: Clock
Synchronization Attribute.
NOTE
● The value Positive of the Warp Direction parameter specifies that transmission
distance in the receive direction is longer than the distance in the transmit direction, or
the transmission time in the receive direction is longer than the time in the transmit
direction; the value Negative specifies just the opposite.
● Warp Length(m) is available only when Warp Mode is set to Length; Warp Time(ns)
is available only when Warp Mode is set to Time.
● The values of Warp Length(m) and Warp Time(ns) are set depending on the
networking scheme for the site.
----End
NOTE
This function is supported only when the system control board of the OSN 1800 V is
UXCMS and the product version is V100R009C00 or later. For details about the restrictions,
see 3.3.1 Feature Limitations.
----End
NOTE
Step 1 Select a port and set its MAC address. For details about the parameters, see
3.9.1.8.11 Parameters: MAC Address Configuration.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The IEEE 1588v2 has been enabled.
● The STG board has been created.
● For the OSN 6800, when concatenation of the external ports of a clock board
is configured, the 120-ohm external clock interface cable should be used as
the network cable for the concatenation.
Step 1 Configure Enabled Status. For details about the parameters, see 2.9.1.13.3
Parameters: Clock Port Link.
----End
The Enabled Status of the external time interface must be set to Disabled.
Step 1 Select an external time interface and configure the settings in the following fields:
Direction, Interface Protocol Type, and Interface Level. For parameter details,
see 3.9.1.8.7 Parameters: Basic Attribute.
NOTE
For the Interface Level field, the OSN 6800 only supports the value RS422.
Step 2 Configuring Time Quality Level, Time Precision, Clock Source Type, Clock
Source Priority 1, Clock Source Priority 2, and Clock Source Deviation fields.
Then configure the settings for each parameter. For parameter details, see
3.9.1.8.8 Parameters: BMC (External Time Interface).
The STG clock board supports mutual conversion between 1PPS+TOD quality
information and IEEE 1588v2 time quality levels.
● If the manually specified Time Quality Level is not the default value 187, the
manually specified IEEE 1588v2 time quality level applies.
● If the manually specified Time Quality Level is the default value 187, the STG
clock board automatically converts the quality information carried in the TOD
into the IEEE 1588v2 time quality level based on the predefined conversion
table.
Table 3-52 provides the mapping between the TOD status information and IEEE
1588v2 time quality level.
Table 3-52 Mapping between the TOD status information and IEEE 1588v2 time
quality level
TOD Status Information IEEE 1588v2 Time Quality Level
0x00: normal 6
----End
Step 1 Select an external time interface and configure settings in the following fields:
Transmitting Direction, Transmitting Distance Mode, Transmitting Length(m),
and Transmitting Time(ns). For parameter details, see 3.9.1.8.9 Parameters:
Cable Transmitting Distance.
NOTE
● The Transmitting Length(m) field is available only when the Transmitting Distance
Mode is set to Length; the Transmitting Time(ns) field is available only when the
Transmitting Distance Mode is set to Time.
● The values of the Transmitting Length(m) and Transmitting Time(ns) are set
depending on the networking scheme for the site.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The clock port has been created.
----End
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Context
When the clock tracing relationships are changed, the U2000 automatically
refreshes the tracing status in Clock View.
Procedure
Step 1 In the Main Topology, select Clock View from the Current View drop-down list.
Step 2 In the Clock View, right-click and choose Search Clock Link from the shortcut
menu.
Step 3 In the Search Clock Link window, set Clock Type and Search Mode, select the NE
to be queried, and click OK.
----End
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock >
Frequency Source Mode from Function Tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > Port
Cascading from Function Tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > PTP Clock >
Clock Synchronization Attribute from the Function Tree.
Parameters
PTP System Time For example: Displays the PTP system time.
2009-02-01 01:01:01 You can manually modify this
parameter.
NE Clock Type OC, TC, BC, TC+BC, TC The NE Clock Type parameter
+OC specifies the working mode (OC,
Default value: BC TC, BC, TC+BC, or TC+OC) of the
node that adopts the IEEE
1588v2 clock. According to the
network planning, an NE on the
network must work in the OC,
TC, BC, TC+BC, TC+OC mode. The
specific working mode of the NE
must be determined in the
network planning phase.
During network planning, first
determine the position and
function of the NE and each port
on the NE. Then, set the working
mode of the NE according to the
features of each working mode.
● OC: As a clock device with
only one PTP port in the clock
domain, OC maintains the
time stamp used in the clock
domain. The clock device can
function as a master clock
device to provide a clock
source or as a slave clock
device to keep synchronous
with other clock devices.
● TC: TC forwards certain PTP
event messages and records
the residence time of the PTP
event messages on it. In
addition, TC provides the
recorded information to the
clock that receives the PTP
event messages. Then, the
recorded information is used
for transparent transmission
of packets and adjustment of
the residence time of the
packets on the device.
● BC: As a clock device with
multiple PTP ports in the clock
domain, BC maintains the
time stamp used in the clock
domain. The clock device can
function as a master clock
device to provide a reference
clock source or as a slave
clock device to keep
Clock Type OC, BC, TC, TC+OC The Clock Type parameter
Default value: BC specifies the working mode (OC,
BC, TC, or TC+OC) of the node
For details about the that adopts the IEEE 1588v2
clock types supported clock. According to the network
by each board, see planning, an NE on the network
Availability in IEEE must work in the OC, BC, TC, or
1588v2. TC+OC mode. The specific
working mode of the NE must
be determined in the network
planning phase.
● OC: When ports on an NE are
set to OC mode, the NE can
work only in master or slave
status. A port in OC mode
can be used only for time
input or output.
● BC: When ports on an NE are
set to BC mode, the master or
slave status of the NE is
determined by using the BMC
algorithm.
● TC: If ports on an NE are set
to TC mode, the NE only
transparently transmits time
messages and does not
restore clock or time
information. In addition, the
NE does not have the master
or slave status.
● TC+OC: When ports on an NE
are set to TC+OC mode, the
NE restores clock information
but does not restore time
information, achieving TC
performance transmission.
● When NE Clock Type of an
NE is set to OC, Clock Type
of PTP ports on the NE must
be set to OC and only one
PTP port on the NE can be
enabled.
● When NE Clock Type of an
NE is set to BC, Clock Type of
PTP ports on the NE must be
set to BC.
● When NE Clock Type of an
NE is set to TC, Clock Type of
NOTE
This function is supported only when the system control board of the OSN 1800 V is
UXCMS and the product version is V100R009C00 or later. For details about the restrictions,
see 3.3.1 Feature Limitations.
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Source at Port from Function Tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> PTP Clock Subnet Configuration from the Function Tree. Then, click the PTP
Clock Subnet tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> PTP Clock Subnet Configuration from the Function Tree. Then, click the BMC
tab.
Parameters
Field Value Description
Time Quality Level 6, 7, 13, 14, 52, 58, 68 to The Time Quality Level
122, 133 to 170, 216 to parameter provides an
232, 187, 193, 248, 255 option to set the quality
Default: 187 level of the time or
frequency allocated by
the master clock device.
A smaller parameter
value indicates a higher
quality level.
This parameter has an
impact on selection of
the external clock source
for tracing. If the PTP
Clock Source Priority 1
values of the clock
candidates are the same,
Time Quality Level
determines which clock
is preferred. That is, the
clock with a smaller
Time Quality Level
value is of a higher
quality level and is
preferred as the time
source for tracing.
PTP Clock Source Type ATOMIC_CLOCK, GPS, The PTP Clock Source
TERRESTRIAL_RADIO, Type parameter provides
PTP, NTP, HAND_SET, an option to set the type
OTHER, of the clock source.
INTERNAL_OSCILLATOR ● ATOMIC_CLOCK:
Default: Indicates an atomic
INTERNAL_OSCILLATOR clock.
● GPS: Indicates a GPS
time source.
● TERRESTRIAL_RADIO:
Indicates the clock
source synchronized
through any of the
radio distribution
systems that
distribute time and
frequency tied to
international
standards.
● PTP: Indicates a clock
source compliant with
the PTP protocol.
● NTP: Indicates a clock
source compliant with
the Network Time
Protocol (NTP).
● HAND_SET: Indicates
a clock source that is
manually set.
● OTHER: Indicates
other clock sources.
● INTERNAL_OSCILLAT
OR: Indicates an
internal clock source.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the Basic Attribute
tab.
Parameters
Field Value Description
External Time Interface shelf ID (shelf name)- Displays the name of the
slot number-board input interface of the
name-external clock external clock source on
interface the NE.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the BMC tab.
Parameters
Field Value Description
External Time Interface shelf ID (shelf name)- Displays the name of the
slot number-board input interface of the
name-external clock external clock source on
interface the NE.
Time Quality Level 6, 7, 13, 14, 52, 58, 68 to The Time Quality Level
122, 133 to 170, 216 to parameter provides an
232, 187, 193, 248, 255 option to set the quality
Default: 187 level of the time or
frequency allocated by
the master clock device.
A smaller parameter
value indicates a higher
quality level.
This parameter has an
impact on selection of
the external clock source
for tracing. If the PTP
Clock Source Priority 1
values of the clock
candidates are the same,
Time Quality Level
determines which clock
is preferred. That is, the
clock with a smaller
Time Quality Level
value is of a higher
quality level and is
preferred as the time
source for tracing.
PTP Clock Source Type ATOMIC_CLOCK, GPS, The PTP Clock Source
TERRESTRIAL_RADIO, Type parameter provides
PTP, NTP, HAND_SET, an option to set the type
OTHER, of the clock source.
INTERNAL_OSCILLATOR ● ATOMIC_CLOCK:
Default: Indicates an atomic
INTERNAL_OSCILLATOR clock.
● GPS: Indicates a GPS
time source.
● TERRESTRIAL_RADIO:
Indicates the clock
source synchronized
through any of the
radio distribution
systems that
distribute time and
frequency tied to
international
standards.
● PTP: Indicates a clock
source compliant with
the PTP protocol.
● NTP: Indicates a clock
source compliant with
the network time
protocol (NTP).
● HAND_SET: Indicates
a clock source
manually set.
● OTHER: Indicates
other clock sources.
● INTERNAL_OSCILLAT
OR: Indicates an
internal clock source.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the Cable
Transmitting Distance tab.
Parameters
Field Value Description
External Time Interface shelf ID (shelf name)- Displays the name of the
slot number-board input interface of the
name-external clock external clock source on
interface the NE.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > PTP Clock >
Safety Password from the Function Tree.
Parameters
Navigation Path
In the NE Explorer, click the NE and choose Configuration > Clock > PTP Clock >
MAC Address Configuration.
Parameters
Field Value Description
Table 3-60 provides the detailed procedures for configuring IEEE 1588v2-
compliant frequency and phase synchronization.
NOTE
The procedures provided in Table 3-60 are only used to configure IEEE 1588v2-compliant
frequency and phase synchronization. To provide physical clock frequency synchronization
and IEEE 1588v2-compliant phase synchronization, configure the physical clock by referring
to 2.9.2.1 Configuration Process and then perform the procedures provided in Table 3-60
to configure IEEE 1588v2 packets.
Operation Remarks
Operation Remarks
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The license of IEEE 1588v2 resources is available.
● The corresponding subrack must be created.
Procedure
Step 1 Change the 1588V2 attribute to Enabled.
NOTE
ITU-T G.8275.1 and IEEE 1588v2 share the same license resources. ITU-T G.8275.1 is enabled
after IEEE 1588v2 is enabled on the U2000.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The IEEE 1588v2 has been enabled.
NOTE
The PTP System Time can be set only when the NE traces the local clock source.
Step 3 Configure Ne Clock Type, Static BMC, Slave Only, Packet Multicast Mode,
Protocol Packet Format, Correct UTC Time and select the required value from
the drop-down list respectively. For details about these parameters, see 3.9.2.8.1
Parameters: Clock Synchronization Attribute.
NOTE
The Slave Only parameter is available only when NE Clock Type is set to OC.
----End
Step 1 Configure Clock Subnet No. For details about these parameters, see 3.9.2.8.3
Parameters: Clock Subnet.
NOTE
● The NEs that have the same subnet number belong to the same clock subnet.
● Equipment that is in the BC or OC work mode can belong to only one clock subnet, and
its clock source can be selected only from within the same clock subnet.
----End
Step 1 Configure Time Quality Level, Time Precision, Clock Source Type, Clock Source
Priority 1, Clock Source Priority 2 fields. Then configure the settings for each
parameter. For details about these parameters, see 3.9.2.8.4 Parameters: BMC
(Clock Subnet).
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The corresponding board must be created.
● The IEEE 1588v2 has been enabled.
Step 1 Configure a clock port. For parameter details, see 3.9.2.8.1 Parameters: Clock
Synchronization Attribute.
NOTICE
For a port on each 10GE LAN tributary board installed on an OSN 9800
V100R001C00 or V100R001C01, Port Mapping can be set to MAC Transparent
Mapping (10.7G). After the OSN 9800 is upgraded to V100R001C20, configuring
the port as a PTP port to support IEEE 1588v2 interrupts traffic on the port. The
traffic is restored automatically after the configuration is completed.
NOTE
----End
NOTE
You can set any integer from 0 to 12 for Clock Source WTR Time(min), with a step of 1.
The default value is 5.
Step 2 Configure Port, Clock Source No, and Clock Source PortNo.
----End
Step 1 Configure P/E Mode, SYNC Packet Period(s), DELAY Packet Period(s), PDELAY
Packet Period(s), ANNOUNCE Packet Period(s), and ANNOUNCE Packet
Timeout Coefficient. For parameter details, see 3.9.2.8.1 Parameters: Clock
Synchronization Attribute.
NOTE
The DELAY Packet Period(s) field is available only when the P/E Mode is set to E2E; the
PDELAY Packet Period(s) field is available only when the P/E Mode is set to P2P.
----End
The transmission deviation of a cable means the time difference of the clock
signals in the cable transmission in the receiving and sending directions between
two NEs. Generally, the actual time difference of cable transmission for the two
directions is calculated by GPS in the deployment. The cable transmission
deviation can be represented by time or by length.
Step 1 Configure Warp Direction, Warp Mode, Warp Length(m), and Warp Time(ns).
For parameter details, see 3.9.2.8.1 Parameters: Clock Synchronization
Attribute.
NOTE
● The value Positive of the Warp Direction field specifies that transmission distance
through the receiving direction is longer than the distance through the sending
direction, or the transmission time of the receiving direction is longer than the time of
the sending direction; the value Negative specifies just the opposite.
● The Warp Length(m) field is available only when the Warp Mode is set to Length; the
Warp Time(ns) field is available only when the Warp Mode is set to Time.
● The values of the Warp Length(m) and Warp Time(ns) are set according to the
networking scheme for the site.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The IEEE 1588v2 has been enabled.
● The CTU board has been created.
Step 1 Select an external time interface and configure the settings in the following fields:
External Time Interface Direction, and Interface Protocol Type. For parameter
details, see 3.9.2.8.5 Parameters: Basic Attribute.
Step 2 Configure Bits Type, Bits Clock Class Level, Bits Precision, Bits Time Source, Bits
Priority 1, Bits Priority 2 fields. Then configure the settings for each parameter.
For parameter details, see 3.9.2.8.6 Parameters: BMC (External Time Interface).
----End
Step 1 Select an external time interface and configure settings in the following fields:
Input Warp Mode, Input Warp Length(m), Input Warp Time(ns), Output
Warp Mode, Output Warp Length(m), Output Warp Time(ns). For parameter
details, see 3.9.2.8.7 Parameters: Cable Transmitting Distance.
NOTE
● The Input Warp Length(m) field is available only when the Input Warp Mode is set to
Length; the Input Warp Time(ns) field is available only when the Input Warp Mode is
set to Time.
● The Output Warp Length(m) field is available only when the Output Warp Mode is
set to Length; the Output Warp Time(ns) field is available only when the Output
Warp Mode is set to Time.
● The values of the Input Warp Length(m), Output Warp Length(m), Input Warp
Time(ns), and Output Warp Time(ns) are set depending on the networking scheme
for the site.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The clock port has been created.
Procedure
Step 1 Query the information about the clock source received at the port is displayed.
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Context
When the clock tracing relationships are changed, the U2000 automatically
refreshes the tracing status in Clock View.
Procedure
Step 1 In the Main Topology, select Clock View from the Current View drop-down list.
Step 2 In the Clock View, right-click and choose Search Clock Link from the shortcut
menu.
Step 3 In the Search Clock Link window, set Clock Type and Search Mode, select the NE
to be queried, and click OK.
Step 4 In the Result dialog box, click Close.
----End
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > Clock Synchronization Attribute from Function Tree.
Parameters
PTP System Time For example: Displays the PTP system time.
2009-02-01 01:01:01 You can manually modify this
parameter.
NE Clock Type OC, TC, BC, TC+BC, TC The NE Clock Type parameter
+OC provides an option to set the
Default: BC working mode (OC, TC, BC, TC
+BC, or TC+OC) of the node that
adopts the IEEE 1588v2 clock.
According to the network
planning, an NE on the network
must work in the OC, TC, BC, TC
+BC, TC+OC mode. The specific
mode of the NE must be
determined in the network
planning phase.
Ingress of Current For example: PTP Displays the local clock input
Master Clock interface of the master clock
that the NE traces after you
specify the clock source for the
NE.
Ptp Profile IEEE 1588v2, G.8275.1 Indicates the PTP protocol type
Default: IEEE 1588v2 used by the NE.
PTP Packet - -
Destination MAC
Address
PTP Packet - -
Destination IP
Address
Step Module one step, two step Specifies whether an IEEE 1588
Default: one step port works in the one-step or
two-step mode.
● In the one-step mode, the
actual Tx time stamp is sent
through the Sync packet to be
transmitted. The one-step
mode requires the equipment
of high precision and
accuracy.
● In the two-step mode, the
actual Tx time stamp is not
added to the Sync packet to
be transmitted. Instead, the
time stamp is sent through
the subsequent Follow-Up
packet.
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Source Priority Table from Function Tree. Click the Clock Source at Port
tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Subnet Configuration from the Function Tree. Then, click the Clock
Subnet tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> PTP Clock Subnet Configuration from the Function Tree. Then, click the BMC
tab.
Parameters
Field Value Description
PTP Clock Source Type ATOMIC_CLOCK, GPS, The PTP Clock Source
TERRESTRIAL_RADIO, Type parameter provides
PTP, NTP, HAND_SET, an option to set the type
OTHER, of the clock source.
INTERNAL_OSCILLATOR ● ATOMIC_CLOCK:
Default: Indicates an atomic
INTERNAL_OSCILLATOR clock.
● GPS: Indicates a GPS
time source.
● TERRESTRIAL_RADIO:
Indicates the clock
source synchronized
through any of the
radio distribution
systems that
distribute time and
frequency tied to
international
standards.
● PTP: Indicates a clock
source compliant with
the PTP protocol.
● NTP: Indicates a clock
source compliant with
the Network Time
Protocol (NTP).
● HAND_SET: Indicates
a clock source that is
manually set.
● OTHER: Indicates
other clock sources.
● INTERNAL_OSCILLAT
OR: Indicates an
internal clock source.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the External Time
Interface Attribute tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the BMC tab.
Parameters
Field Value Description
Bits 1PPS Status Available, Atomic Clock 1PPS status values can
Hold, Unavailable, be converted into time
Oscillator Hold, quality levels according
Transport Device Hold, to the conversion table.
Rubidiumc Clock Hold ● Available corresponds
to level 6.
● Atomic Clock Hold,
Unavailable
corresponds to level 7.
● Unavailable
corresponds to level
255.
● Oscillator Hold
corresponds to level
52.
● Transport Device Hold
corresponds to level
187.
● Rubidiumc Clock Hold
corresponds to level 8.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the Bits
Transmitting Warp tab.
Parameters
Field Value Description
NOTE
The protection frequency tracing path shown in the preceding figure is an example of the
path for transmitting clock signals after the clock source is switched to the slave BITS
because the master BITS is faulty. The active and standby clock sources cannot be
concurrently transmitted on the network.
The phase tracing paths shown in the figure are used for reference only. On a practical
network, each NE determines the phase tracing paths based on algorithms.
4.2 Principles
ITU-T G.8275.1 defines the clock standards in the telecommunications field. It
establishes the master-slave relationship between network nodes and accurately
and precisely transmits clock reference information to each control point using the
time synchronization mechanism.
NOTE
ITU-T G.8275.1 V2.0 supports T-TC, which is similar to TC of IEEE 1588v2, and only
participates in delay testing as well as transparently transmits time synchronization packets,
but does not synchronize time.
Node Model
Figure 4-3 shows the positions of the three types of clock nodes on a time
synchronization network.
Figure 4-3 Positions of the three types of clock nodes on a time synchronization
network
NOTE
The T-BC clock functions include the functions of the T-GM and T-TSC clocks.
Figure 4-4 describes the process of establishing the master-slave clock hierarchy
between the T-GM, T-BC, and T-TSC clocks in a PTP clock domain.
As shown in Figure 4-4, the T-GM clock is located at the root and therefore is
called as the grandmaster clock. Port 1 of T-BC1 functions as the slave port of the
grandmaster clock and marked as S. The other ports of T-BC1 function as the
master ports of the clock device connected to T-BC1 and therefore are marked as
M. Therefore, port 1 of T-BC2 functions as a slave port of T-BC1. The rest can be
deduced.
The master-slave clock hierarchy establishment of the PTP clock system mainly
depends on the Announce messages of other clocks received by ports, port data
sets, BMCA, and port state machine. The PTP clock system performs the following
steps to establish the master-slave clock hierarchy:
1. Receives and authenticates the Announce messages from other clock ports.
2. Determines the recommended port status based on the BMCA.
3. Updates the port data sets based on the decision point in the recommended
status using the port status decision algorithm.
4. Determines the actual status of the port based on the recommended status
and status decision event in the port state machine to establish the master-
slave clock hierarchy.
A synchronous network using the IEEE 1588v2 protocol obtains time signals from
the reference time source grandmaster clock using external time ports.
● 1PPS
1PPS is short for one pulse per second. 1PPS signals are used for time scaling
and work at the RS-422 levels. The pulse frequency of 1PPS is 1 Hz. That is,
one pulse is transmitted per second. The 1PPS signal pulse width ranges from
20 ms to 200 ms. The rising edge of the pulse is strictly coincident with the
UTC time.
● TOD
TOD is short for time of day. TOD messages provide time in ASCII format.
TOD signals also work at the RS-422 levels and provide a baud rate of 9600
bit/s. A TOD message contains information such as current date/time, time
standard ID, 1PPS status flag, date/time adjusted based on UTC leap seconds,
leap second adjustment directive, and GPS time.
The clock board supports mutual conversion between 1PPS+TOD quality
information and IEEE 1588v2 time quality levels.
● If the manually specified Time Quality Level is not the default value 248, the
manually specified IEEE 1588v2 time quality level applies.
● If the manually specified Time Quality Level is the default value 248, the
clock board automatically converts the quality information carried in the TOD
into the IEEE 1588v2 time quality level based on the predefined conversion
table.
Table 3-2 provides the mapping between TOD status information and PTP time
quality levels.
Table 4-2 Mapping between TOD status information and PTP levels
TOD Status Information PTP Time Quality Level
0x00: normal 6
NOTE
For the port description and pin definitions of each board, see the panel description of each
board in Hardware Description.
NOTE
On the NMS, set Enabled Status to specify different working modes. When this parameter
is set to Enabled, the cascading mode is used. When this parameter is set to Disabled, the
external time mode is used.
NOTE
For the CLK&TOD composite port, a transfer cable is required to separate the CLK port from
the TOD port.
For boards that support multiple ports (CLK1/TOD1, CLK2/TOD2 ...), the cascading mode is
similar.
The clock synchronization GE optical port is used for BITS clock input, clock
synchronization between NEs, or clock cascading between master and slave
subracks. The clock synchronization GE optical port supports both physical clock
synchronization and PTP time synchronization, but does not support Ethernet
service transmission. Table 4-5 lists the names and types of the clock
synchronization GE optical ports.
NOTE
The clock synchronization GE optical port can be set to the physical clock cascading mode
or PTP clock cascading mode. On the NMS, set Enabled Status to specify different working
modes. When this parameter is set to Enabled, the cascading mode is used. When this
parameter is set to Disabled, the non-cascading mode is used.
● The clock synchronization GE optical port of the OSN 1800 supports both
non-cascading and cascading modes.
● The clock synchronization GE optical port of the OSN 9800 in
V100R021C00SPC300 or earlier does not support the cascading mode and
cannot be used for clock cascading between master and slave subracks. It is
used only for interconnection between WDM/OTN NEs or for clock/time
synchronization between WDM/OTN NEs and BITS/PTN/base station devices.
● The clock synchronization GE optical port of the OSN 9800 supports the
cascading mode and clock cascading between master and slave subracks since
V100R021C10SPC100.
The clock cascading and non-cascading modes can be set for different ports
separately.
● Figure 4-8 shows the fiber connections when both the cascading and non-
cascading modes are used.
● Figure 4-9 and Figure 4-10 show the fiber connections between NEs.
● Figure 4-11 and Figure 4-12 show the fiber connections for clock cascading
between master and slave subracks.
NOTE
When clock synchronization GE optical ports on system control boards or clock boards are
used for clock synchronization, the clock synchronization GE optical ports on both the active
and standby system control boards or clock boards must be used together to provide clock
protection.
1. At the time of t1, the master clock sends a Sync message. If the master clock
is a one-step clock, the t1 timestamp is contained in the Sync message and
sent to the slave clock. If the master clock is a two-step clock, then the t1
timestamp is contained in the subsequent Follow_Up message and sent to the
slave clock.
2. At the time of t2, the slave clock receives the Sync message and obtains the t1
timestamp from the Sync message (one-step mode) or from the subsequent
Follow_Up message (two-step mode) message.
3. At the time of t3, the slave clocks send delay request messages.
4. At the time of t4, the master clocks receive delay request messages.
5. At the time of t5, the master clock sends delay response messages that carry
the information of the time of t4.
The method of calculating the time difference between slave clocks and the
master clock and the link delay is as follows:
Because
t2-t1=Delay+Offset
t4-t3=Delay-Offset
Hence,
Offset=[(t2-t1)-(t4-t3)]/2
Delay=[(t2-t1)+(t4-t3)]/2
NOTE
NOTE
Figure 4-14 shows the time of receiving and transmitting Sync messages between
clock A (slave) and clock B (master) when clock A synchronizes to clock B. Clock A
can correct its clock frequency after comparing the interval between two message
transmitting timestamps with the interval between two message receiving
timestamps. In this manner, clock A synchronizes to clock B. If the changes in the
link delay and residence time are negligible, the clock frequency of clock A can be
corrected using the following formula:
(t1[N] - t1[0])/(t2[N] - t2[0])
● If the value of the "t2[N] - t2[0]" is equal to the value of "t1[N] - t1[0]": This
means that clock A and clock B run at the same rate.
● If the value of the "t2[N] - t2[0]" is greater than the value of "t1[N] - t1[0]":
This means that clock A runs faster than clock B and needs to slow down its
frequency.
● If the value of the "t2[N] - t2[0]" is less than the value of "t1[N] - t1[0]": This
means that clock A runs slower than clock B and needs to accelerate its
frequency.
NOTE
● t2[N] - t2[0]: Indicates the number of clock cycles within the interval between two Sync
messages received by clock A.
● t1[N] - t1[0]: Indicates the number of clock cycles within the interval between two Sync
messages transmitted by clock B.
● In one-step mode, t1[n] is contained in the Sync message. In two-step mode, t1[n] is
contained in the Follow_Up message.
In practical application, transmission delays and the residence times on a TC clock must be
considered and corrected.
BMCA Principles
Compared with the BMCA in IEEE 1588v2, the BMCA in ITU-T G.8275.1 has the
following new attributes:
● notSlave attribute:
– This attribute is added to each port to ensure the tracing relationship in
the ITU-T G.8275.1 synchronization network and to avoid the situation
that a T-GM traces a T-BC.
– In a network with a large number of devices and links, setting of the
notSlave attribute guarantees a tree structure of the master-slave tracing
path from top to down and prevents devices at the aggregation layer
from reversely tracing devices at the access layer.
● localPriority attribute: This attribute refers to the local priority and is used to
plan the device tracing sources. The attribute is used only inside local devices
and will not be forwarded to other devices through packets.
The following table lists the parameters to be compared in data sets in sequence.
NOTE
● For OSN 9800 service boards (with OTN tributary and line functions), when multiple
clock ports are configured, the BMC algorithm determines which port is used as the
clock source based on the port number. The system algorithm complies with the
following rules:
● For the boards that support IEEE 1588v2/ITU-T G.8275.1/ITU-T G.8273.2 only on
ports 1 to 15, the system preferentially selects the port with a smaller port number
as the clock source.
● For the boards that support IEEE 1588v2/ITU-T G.8275.1/ITU-T G.8273.2 in all ports,
ports 1 to 15 and the ports with a number greater than 15 form two groups. The
system preferentially selects the latter group and then the former group. In each
group, the system preferentially selects the port with a smaller number as the clock
source. For example, if ports 3, 7, 16, and 20 are configured as clock ports, the
priority is port 16 > port 20 > port 3 > port 7.
NOTE
The external time port on the product is not a PTP port and does not support the ITU-T G.
8275.1 protocol. The transmission delay cannot be measured automatically. Therefore, the
transmission delay of the cable connecting to the external time port must be measured
using a test instrument or computed based on the cable length.
The asymmetric delay correction mechanism defined in ITU-T G.8275.1 uses the
compensation value of the asymmetric transmission offset to correct the
calculation result, thereby achieving accurate time synchronization.
The delay compensation value for the transmission asymmetry can be obtained
according to the length difference between the cables in the signal receive and
signal transmit directions. Alternatively, the value can be obtained according to
the transmission time of a signal on the cables in the receive and transmit
directions using a test instrument. The compensation value takes effect only after
it is manually set for the PTP ports.
NOTE
The ITU-T G.8275.1 protocol can detect the mean transmission delay of two connected PTP
ports but cannot detect the transmission delay caused by the PTP link asymmetry.
Asymmetric delay must be measured with a test instrument or computed based on the
cable lengths.
NOTE
Only the following boards on the following products support automatic compensation of
ring network delay offset. For details about the restrictions, see 3.3.1 Feature Limitations.
● OSN 1800 V (Z-series system control boards) V100R009C00 and later versions: UNS4,
EX4, EG10, and UNQ2
● OSN 1800 V Pro (K5UXCME system control board):
● V100R021C10 and later versions: UNS5, UNS4, GTA, UNQ2, UND3 and EX10
● V100R022C10 and later versions: K1GDC
● OSN 1800 II Pro (K2UXCLE system control board):
● V100R021C10 and later versions: UNS5, UNS4, GTA, UNQ2, UND3 and EX10
● V100R022C10 and later versions: K1GDC
NOTE
Only the following boards on the following products support single-fiber bidirectional
asymmetric compensation. For details about the restrictions, see 3.3.1 Feature Limitations.
● OSN 1800 V (Z-series system control boards) V100R009C00 and later versions: EX4 and
EG10
● OSN 1800 V Pro (K5UXCME system control board): EX10
● OSN 1800 II Pro (K2UXCLE system control board): EX10
Clock source ● The central node or the node with high reliability
provides the clock source.
● If the BITS or other external clock equipment with
high precision exists, use the external timing mode
for the NE. Otherwise, use the line timing mode
instead. You are advised to use the internal timing
as a clock source of the lowest level.
TN16AUX For the OSN 8800 T16, two TN16AUX boards must be
configured when ITU-T G.8275.1 is required.
AUX boards of the OSN When an OSN 1800 NE is configured with multiple
1800 AUX boards (F1AUX/B1AUX/B2AUX), you need to set
one AUX board as the main AUX board.
● In the master/slave subrack scenario, the main AUX
board must be configured on the master subrack.
● For the use restrictions on the external clock/time
ports of the TMB1AUX/TMB2AUX board, see Table
2-9.
Clock synchronization For the current OSN 1800 version, slave subracks
of slave subracks support clock synchronization only when master and
slave subracks are cascaded.
In a slave subrack, only the following boards support
clock synchronization (that is, the ports on the
following boards are used as clock source ports):
● B1AUX/B2AUX: HPn port
● TMB1DFS/TMB1SFS/TMB1FS: HP port
● TMB1CMD4: TX1/RX1 port
Other types of ports, such as OSC clock sources, line
clock sources, and Ethernet service ports, do not
support clock synchronization.
CFP optical module For the boards that use CFP optical modules,
compensation for the asymmetrical transmission
delay is required after the boards are powered on or
undergo cold resets, the optical modules are replaced,
or the line code pattern is switched; otherwise, a time
deviation of about 100 ns may be generated.
Fiber parameters When the OSC board is used for high-precision clock
synchronization, you need to correctly set the fiber
type, fiber length, and fiber dispersion coefficient on
the WDM Interface > Advanced Attributes page of
the NMS.
Fiber Doctor system When the ITU-T G.8275.1/G.8273.2 feature works with
the Fiber Doctor system, service running and the IEEE
1588v2/G.8275.1 time synchronization may be
affected. For details, see the feature dependencies and
limitations of the Fiber Doctor system.
If the single-fiber bidirectional OSC board is used to
implement PTP time synchronization and intelligent
fiber management at the same time, pay attention to
the following points when using the Fiber Doctor
system:
● If the OSC_CLK_MISMATCH alarm is found on the
live network, online fiber detection using Default
Mode or Online mode in Advanced Mode is not
allowed.
● If no OSC_CLK_MISMATCH alarm is found on the
live network but more than four OLA sites are
deployed in an OMS, clock boards that meet
requirements need to be configured at the next
OLA site behind every four OLA sites. Otherwise,
online fiber detection using Default Mode or
Online mode in Advanced Mode is not allowed
because PTP time synchronization is affected in
this scenario.
● If online monitoring has been started for an OTS of
an OMS but the monitoring is not completed,
online monitoring cannot be started for other OTSs
on the OMS; otherwise, PTP time synchronization is
affected.
● If PTP time synchronization is also enabled, ensure
that online monitoring is started for no more than
14 OTSs on the entire network; otherwise, PTP
time synchronization is affected.
Client 1+1 protection Client 1+1 protection and ITU-T G.8275.1 are mutually
exclusive. If both are configured, ITU-T G.8275.1 will
become abnormal.
4.4 Availability
This topic describes the board types and software versions that support ITU-T G.
8275.1/G.8273.2.
Table 4-10 Boards and device versions that support ITU-T G.8275.1 in the OSN
9800 universal platform subrack (optical-layer configuration)
Board Type Board Name Start Version
TN13STG V100R003C10
TN12ST2 V100R006C10
NOTE
Only some boards support high-precision clock synchronization. For details, see 5 High-
Precision Clock Synchronization Solution.
Table 4-11 Boards and device versions that support ITU-T G.8275.1 in OSN 9800 P
series subracks (optical-layer configuration)
Board Type Board Name Start Version
TMP3CTUHP V100R022C10
NOTE
Only some boards support high-precision clock synchronization. For details, see 5 High-
Precision Clock Synchronization Solution.
Only OSN 9800 U32E/U64E enhanced subracks support high-precision clock
synchronization. OSN 9800 U32/U64 standard subracks do not support high-precision clock
synchronization.
Table 4-12 Boards and device versions that support ITU-T G.8275.1/G.8273.2Note in
OSN 9800 U series subracks (electrical-layer configuration)
Board Type Board Name Start Version
TNU5CTUHP V100R019C10
TNU6U502 V100R020C10
When OTN tributary ports receive Ethernet services, the working modes of the
ports that support ITU-T G.8275.1 vary according to the encapsulation type. The
following table lists the details.
Table 4-13 Support for ITU-T G.8275.1 in different port service mapping paths
NOTE
When the port working mode is ODUflex non-convergence mode (Any->ODUflex), the T-BC
mode and PTP ETH encapsulation are supported.
NOTE
Only some boards support high-precision clock synchronization. For details, see 5 High-
Precision Clock Synchronization Solution.
Table 4-14 Boards and device versions that support ITU-T G.8275.1/G.8273.2
TNG4CXPHP V100R021C00
TMF2AUX01HP V100R021C10
TMF2AUX01HP V100R021C10
TNG1T210E V100R022C10
TNU6U502 V100R020C10
TNS5NP400/TNS5NP400E V100R021C10
When OTN tributary ports receive Ethernet services, the working modes of the
ports that support ITU-T G.8275.1 vary according to the encapsulation type. The
following table lists the details.
Table 4-15 Support for ITU-T G.8275.1 in different port service mapping paths
NOTE
When the port working mode is ODUflex non-convergence mode (Any->ODUflex), the T-BC
mode and PTP ETH encapsulation are supported.
ITU-T G.8275.1
Table 4-16 Boards and device versions that support ITU-T G.8275.1 in OSN 8800
subracks
Board Type Board Name Start Version
TN12ST2 V100R013C00
TN11AST2 V100R013C10
TN55TSC V100R012C00
TN55TTX V100R012C10
When OTN tributary ports receive Ethernet services, the working modes of the
ports that support ITU-T G.8275.1 vary according to the encapsulation type. The
following table lists the details.
Table 4-17 Support for ITU-T G.8275.1 in different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (T- on
BC)
NOTE
When the port working mode is ODUflex non-convergence mode (Any->ODUflex), the T-BC
mode and PTP ETH encapsulation are supported.
NOTE
ITU-T G.8273.2
Table 4-18 Boards and device versions that support ITU-T G.8273.2 in OSN 8800
subracks
Board Type Board Name Start Version
Table 4-19 Boards and device versions that support ITU-T G.8275.1 in OSN 6800
subracks
Board Type Board Name Start Version
Table 4-20 describes the working modes of ITU-T G.8275.1 ports on each tributary
board intended for OSN 6800.
Table 4-20 Working modes of ITU-T G.8275.1 ports on each tributary board
Table 4-21 Boards and device versions that support ITU-T G.8275.1/G.8273.2 in
OSN 1800 V subracks
TMB2AUX V100R021C10
TMB1AST2 V100R009C00
TMB2AST2 V100R019C10
TMB1LQCB V100R022C00
TNZ8UNS4 V100R021C00
TMB1EG10 V100R021C10
NOTE
For the ITU G.8275.1 feature:
● You are advised to use OSC boards to implement PTP time synchronization between
sites. The single-fiber bidirectional OSC mode supports commissioning-free and delay
compensation-free functions. However, when line boards are used to configure PTP time
synchronization, compensation for asymmetric delay is required, the construction cost is
high, and the maintainability is poor. Therefore, this mode is not recommended.
● For OTN line ports, G.8275.1 time synchronization can be used only when lower-order
ODUk cross-connections are configured for the ports.
● For the tributary ports that receive Ethernet services, G.8275.1 time synchronization can
be used only after services are configured for the ports.
● When an electrical module is inserted into a board port, ITU-T G.8275.1 is not
supported.
● When working in relay mode, boards do not support ITU-T G.8275.1.
● When the EM20 board works with the Z5UXCMS system control board, ITU-T G.8275.1
is supported since V100R020C10.
● When the service cross-connections on the line board are switched, ITU-T G.8275.1 clock
tracing is affected. As a result, the clock source may be switched temporarily.
● The AUX board is an auxiliary board that provides the clock function.
For the ITU G.8273.2 feature:
● a: OSN 1800 V: When the system control board is UXCMS, the tributary board supports
the ITU-T G.8273.2 synchronization since the OSN 1800 V of V100R008C10.
● b: EM20 boards do not support G.8273.2.
● When working in relay mode, line boards do not support ITU-T G.8273.2.
● When the service cross-connections on the line board are switched, ITU-T G.8273.2 clock
tracing is affected. As a result, the clock source may be switched temporarily.
When Ethernet services are received by an OTN board, the working mode of the
port supporting ITU-T G.8275.1 varies according to the encapsulation type. The
following table lists the details.
Table 4-22 Support for ITU-T G.8275.1 in different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (T- on
BC)
NOTE
When the port working mode is ODUflex non-convergence mode (Any->ODUflex), the T-BC
mode and PTP ETH encapsulation are supported.
NOTE
● When receiving OTU1 services, the TOA board supports only T-BC but does not support PTP
ETH encapsulation.
● When receiving OTU2/OTU2e services, the TQX board supports only T-BC but does not
support PTP ETH encapsulation.
● When receiving GE or 10GE LAN services, the EM20, EX4 and EG10 boards support only the
T-BC mode and support PTP ETH encapsulation.
● ST2 and AST4 boards support the T-BC mode but do not support PTP ETH encapsulation.
Table 4-23 Boards and device versions that support ITU-T G.8275.1/G.8273.2 in
OSN 1800 II Enhanced subracks
Board Type Board Name Start Version
TMB2AUX V100R021C10
TMB1AST2 V100R009C00
TMB2AST2 V100R019C10
TMB2LDC V100R021C10
TMB1EG10 V100R021C10
NOTE
For the ITU G.8275.1 feature:
● You are advised to use OSC boards to implement PTP time synchronization between
sites. The single-fiber bidirectional OSC mode supports commissioning-free and delay
compensation-free functions. However, when line boards are used to configure PTP time
synchronization, compensation for asymmetric delay is required, the construction cost is
high, and the maintainability is poor. Therefore, this mode is not recommended.
● For OTN line ports, G.8275.1 time synchronization can be used only when lower-order
ODUk cross-connections are configured for the ports.
● For the tributary ports that receive Ethernet services, G.8275.1 time synchronization can
be used only after services are configured for the ports.
● When an electrical module is inserted into a board port, ITU-T G.8275.1 is not
supported.
● When working in relay mode, boards do not support ITU-T G.8275.1.
● When the service cross-connections on the line board are switched, ITU-T G.8275.1 clock
tracing is affected. As a result, the clock source may be switched temporarily.
● The AUX board is an auxiliary board that provides the clock function.
For the ITU G.8273.2 feature:
● The Z1UXCL board supports ITU G.8275.1 since V100R007C10, and supports ITU-T G.
8273.2 since V100R008C10.
When Ethernet services are received by an OTN board, the working mode of the
port supporting ITU-T G.8275.1 varies according to the encapsulation type. The
following table lists the details.
Table 4-24 Support for ITU-T G.8275.1 in different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (T- on
BC)
NOTE
When the port working mode is ODUflex non-convergence mode (Any->ODUflex), the T-BC
mode and PTP ETH encapsulation are supported.
NOTE
ST2 and AST4 boards support the T-BC mode but do not support PTP ETH encapsulation.
Table 4-25 Boards and device versions that support ITU-T G.8275.1/G.8273.2 in
OSN 1800 I&II Compact subracks
TMB1AST2 V100R009C00
TMB2AST2 V100R019C10
When Ethernet services are received by an OTN board, the working mode of the
port supporting ITU-T G.8275.1 varies according to the encapsulation type. The
following table lists the details.
Table 4-26 Support for ITU-T G.8275.1 in different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (T- on
BC)
NOTE
When the port working mode is ODUflex non-convergence mode (Any->ODUflex), the T-BC
mode and PTP ETH encapsulation are supported.
NOTE
ST2 and AST4 boards support the T-BC mode but do not support PTP ETH encapsulation.
NOTE
Only some boards support high-precision clock synchronization. For details, see 5 High-
Precision Clock Synchronization Solution.
Table 4-27 Boards and device versions that support ITU-T G.8275.1/G.8273.2
TMB1DFSHP/TMB1SFSHP/TMB1FSHP V100R022C00
(OSC unit)
TMB1LQCB V100R022C00
TMK1UNS4MP V100R022C10
TMB3EMS10D V100R022C10
NOTE
● HP: indicates that the board supports high-precision clock synchronization. Only
products in V100R021C10SPC300 (with NCE V100R021C10SPC200) and later versions
support high-precision clock synchronization. XFIU units do not affect synchronization
precision.
● You are advised to use OSC boards to implement PTP time synchronization between
sites. The single-fiber bidirectional OSC mode supports commissioning-free and delay
compensation-free functions. However, when line boards are used to configure PTP time
synchronization, compensation for asymmetric delay is required, the construction cost is
high, and the maintainability is poor. Therefore, this mode is not recommended.
● For OTN line ports, G.8275.1 time synchronization can be used only when lower-order
ODUk cross-connections are configured for the ports.
● For the tributary ports that receive Ethernet services, G.8275.1 time synchronization can
be used only after services are configured for the ports.
● When an electrical module is inserted into a board port, ITU-T G.8275.1 is not
supported.
● When working in relay mode, boards do not support ITU-T G.8275.1.
● When the service cross-connections on the line board are switched, ITU-T G.8275.1 clock
tracing is affected. As a result, the clock source may be switched temporarily.
● The AUX board is an auxiliary board that provides the clock function.
When Ethernet services are received by an OTN board, the working mode of the
port supporting ITU-T G.8275.1 varies according to the encapsulation type. The
following table lists the details.
Table 4-28 Support for ITU-T G.8275.1 in different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (T- on
BC)
NOTE
When the port working mode is ODUflex non-convergence mode (Any->ODUflex), the T-BC
mode and PTP ETH encapsulation are supported.
NOTE
Only some boards support high-precision clock synchronization. For details, see 5 High-
Precision Clock Synchronization Solution.
Table 4-29 Boards and device versions that support ITU-T G.8275.1/G.8273.2
Board Type Board Name Start Version
TMB2AUXHP V100R021C10
TMB1DFSHP/TMB1SFSHP/TMB1FSHP V100R022C00
(OSC unit)
TMB1LQCB V100R022C00
TMK1UNS4MP V100R022C10
TMB3EMS10D V100R022C10
NOTE
● HP: indicates that the board supports high-precision clock synchronization. Only
products in V100R021C10SPC300 (with NCE V100R021C10SPC200) and later versions
support high-precision clock synchronization. XFIU units do not affect synchronization
precision.
● You are advised to use OSC boards to implement PTP time synchronization between
sites. The single-fiber bidirectional OSC mode supports commissioning-free and delay
compensation-free functions. However, when line boards are used to configure PTP time
synchronization, compensation for asymmetric delay is required, the construction cost is
high, and the maintainability is poor. Therefore, this mode is not recommended.
● For OTN line ports, G.8275.1 time synchronization can be used only when lower-order
ODUk cross-connections are configured for the ports.
● For the tributary ports that receive Ethernet services, G.8275.1 time synchronization can
be used only after services are configured for the ports.
● When an electrical module is inserted into a board port, ITU-T G.8275.1 is not
supported.
● When working in relay mode, boards do not support ITU-T G.8275.1.
● When the service cross-connections on the line board are switched, ITU-T G.8275.1 clock
tracing is affected. As a result, the clock source may be switched temporarily.
● The AUX board is an auxiliary board that provides the clock function.
When Ethernet services are received by an OTN board, the working mode of the
port supporting ITU-T G.8275.1 varies according to the encapsulation type. The
following table lists the details.
Table 4-30 Support for ITU-T G.8275.1 in different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (T- on
BC)
NOTE
When the port working mode is ODUflex non-convergence mode (Any->ODUflex), the T-BC
mode and PTP ETH encapsulation are supported.
NOTE
Only some boards support high-precision clock synchronization. For details, see 5 High-
Precision Clock Synchronization Solution.
Table 4-31 Boards and device versions that support ITU-T G.8275.1/G.8273.2
Board Type Board Name Start Version
TMB2AST2 V100R019C10
TMB1DFSHP/TMB1SFSHP/TMB1FSHP V100R022C00
(OSC unit)
TMB1LQCB V100R022C00
NOTE
● HP: indicates that the board supports high-precision clock synchronization. Only
products in V100R021C10SPC300 (with NCE V100R021C10SPC200) and later versions
support high-precision clock synchronization. XFIU units do not affect synchronization
precision.
● For OTN line ports, G.8275.1 time synchronization can be used only when lower-order
ODUk cross-connections are configured for the ports.
● For the tributary ports that receive Ethernet services, G.8275.1 time synchronization can
be used only after services are configured for the ports.
● When an electrical module is inserted into a board port, ITU-T G.8275.1 is not
supported.
● When working in relay mode, boards do not support ITU-T G.8275.1.
● The AUX board is an auxiliary board that provides the clock function.
When Ethernet services are received by an OTN board, the working mode of the
port supporting ITU-T G.8275.1 varies according to the encapsulation type. The
following table lists the details.
Table 4-32 Support for ITU-T G.8275.1 in different port service mapping paths
Service Port Mapping Encapsulati Port PTP ETH
Type on Mode Working Encapsulati
Mode (T- on
BC)
NOTE
When the port working mode is ODUflex non-convergence mode (Any->ODUflex), the T-BC
mode and PTP ETH encapsulation are supported.
Table 4-33 Boards and device versions that support ITU-T G.8275.1/G.8273.2 in
OSN 1800 I Compact subracks
When Ethernet services are received by an OTN board, the working mode of the
port supporting ITU-T G.8275.1 varies according to the encapsulation type. The
following table lists the details.
Table 4-34 Support for ITU-T G.8275.1 in different port service mapping paths
NOTE
When the port working mode is ODUflex non-convergence mode (Any->ODUflex), the T-BC
mode and PTP ETH encapsulation are supported.
4.5 Specifications
This section describes the specifications of ITU-T G.8275.1 and ITU-T G.8273.2.
NOTE
Only specific products and boards support high-precision clock synchronization. For details,
see 5 High-Precision Clock Synchronization Solution.
Item Specifications
Item Specifications
Item Specifications
External time port 1PPS+ToD external time ports supported. For details,
see 4.2.2 Time Source Port.
Item Specifications
Item Specifications
Item Specifications
Low-frequency MTIE 40 ns 40 ns
jitter time offset
(dTEL) TDEV 4 ns 4 ns
Item Specifications
NOTE
For details about the device types and boards that support ITU-T G.8273.2, see 4.4
Availability.
NOTE
This topic records feature updates of boards. However, new board hardware is not recorded
as feature updates. For details, see the "Availability" section.
OSN 9800 U/M/P series The product function is 4.4.3 OSN 9800 P Series
subracks (with NCE enhanced. Hardware and Version
V100R021C10SPC200 Support
and later versions) newly 4.4.4 OSN 9800 U Series
support high-precision Hardware and Version
clock synchronization. Support
4.4.5 OSN 9800 M
Series Hardware and
Version Support
5 High-Precision Clock
Synchronization
Solution
The OptiX Added a new 4.4.5 OSN 9800 M Series Hardware and
OSN 9800 subrack to Version Support:
M05 subrack support basic Added OptiX OSN 9800 M05 subrack-related
(system functions. information.
control board:
TME1CTU/
TME2CTU) is
added to
support ITU-T
G.8275.1/G.
8273.2.
The TNU5CTU The product 4.4.4 OSN 9800 U Series Hardware and
board of the function is Version Support
OSN 9800 U enhanced.
series subrack
is added to
support ITU-T
G.8275.1/G.
8273.2.
The TNG4CXP The product 4.4.5 OSN 9800 M Series Hardware and
board of the function is Version Support
OSN 9800 enhanced.
M24 subrack
is added to
support ITU-T
G.8275.1/G.
8273.2.
The OSN Added a new 4.4.5 OSN 9800 M Series Hardware and
9800 M12 subrack to Version Support:
subrack is support basic Added OSN 9800 M12 subrack-related
added to functions. information.
support ITU-T
G.8275.1/G.
8273.2.
The TNU4CTU The product ● 4.4.4 OSN 9800 U Series Hardware and
board of the function is Version Support: Added the TNU4CTU
OSN 9800 U enhanced. board.
series is ● 4.8.1 Configuring ITU-T G.8275.1 (OSN
added to 1800/8800/9800Universal Platform
support ITU-T Subrack/M Series/P Series/(U Series:
G.8275.1. U2CTU/S2CTU/U4CTU/U5CTU)): Added
the TNU4CTU board.
The TNG3CXP The product 4.4.5 OSN 9800 M Series Hardware and
board of the function is Version Support
OSN 9800 enhanced.
M24 subrack
is added to
support ITU-T
G.8275.1/G.
8273.2.
The OSN 9800 P The product 4.4.3 OSN 9800 P Series Hardware and
subrack is function is Version Support:
added to enhanced. Added the description of the OSN 9800 P
support ITU-T G. series subrack.
8275.1.
The TNU2CTU The product ● 4.4.4 OSN 9800 U Series Hardware and
and TNS2CTU function is Version Support: Added TNU2CTU and
boards of the enhanced. TNS2CTU.
OSN 9800 U ● 4.8.1 Configuring ITU-T G.8275.1 (OSN
series are added 1800/8800/9800Universal Platform
to support ITU-T Subrack/M Series/P Series/(U Series:
G.8275.1. U2CTU/S2CTU/U4CTU/U5CTU)): Added
TNU2CTU and TNS2CTU.
The OSN 9800 M series ITU-T G.8275.1 and ITU-T Added 4.4.5 OSN 9800
subrack supports ITU-T G.8273.2 are carrier-level M Series Hardware and
G.8275.1/G.8273.2. PTP synchronization Version Support.
standards defined by
ITU-T.
Updates of V100R011C00
Feature Update Reason for the Change Information Update
The feature is available ITU-T G.8275.1 and ITU-T ● OSN 8800 and OSN
since this version. G.8273.2 are carrier-level 6800: The ITU-T G.
Precision Time Protocol 8275.1 feature is
(PTP) synchronization added.
standards defined by ● OSN 8800 T32 and
ITU-T. T16: The ITU-T G.
8273.2 feature is
added.
The 1800 V Pro, 1800 II The product function is 4.4.11 OSN 1800 V Pro
Pro, and 1800 II TP (with enhanced. Hardware and Version
NCE Support
V100R021C10SPC200 4.4.12 OSN 1800 II Pro
and later versions) newly Hardware and Version
support high-precision Support
clock synchronization.
4.4.13 OSN 1800 II TP
Hardware and Version
Support
5 High-Precision Clock
Synchronization
Solution
The 1800 V Pro and 1800 The product function is 3.3.1 Feature
II Pro chassis (with NCE enhanced. Limitations
V100R021C10SPC200 3.8.1.1 Configuration
and later versions) newly Process
support automatic
compensation for ring 3.8.1.9 Configuring Ring
network delay offset and Network Automatic
automatic single-fiber Compensation
bidirectional
compensation.
The NEs and ports The product function Added the description of the T-TC
newly support the T- is enhanced. mode and G.8271 packet format.
TC working mode. ● 4.5 Specifications
The external time
port newly supports ● 4.8.1.11.4 Parameters: Clock
G.8271 packets. Synchronization Attribute
The new 1800 V Pro This subrack is new Added 4.4.11 OSN 1800 V Pro
chassis supports to the product and Hardware and Version Support.
ITU-T G.8275.1/ITU-T should support basic
G.8273.2. device functions.
The new 1800 II Pro This subrack is new Added 4.4.12 OSN 1800 II Pro
chassis supports to the product and Hardware and Version Support.
ITU-T G.8275.1/ITU-T should support basic
G.8273.2. device functions.
The OSN 1800 II TP The product function 4.4.13 OSN 1800 II TP Hardware
newly supports ITU- is enhanced. and Version Support
T G.8275.1/ITU-T G.
8273.2.
New line boards are The product function is 4.4.8 OSN 1800 V
added to the OSN 1800 enhanced. Hardware and Version
V to support ITU-T G. Support:
8275.1/ITU-T G.8273.2. Added the descriptions
of line boards.
The new This subrack is new to the product and 4.4.9 OSN 1800 II
OSN 1800 should support basic device functions. Enhanced
II Hardware and
Enhanced Version Support:
chassis Added the
supports descriptions of
ITU-T G. ITU-T G.8273.2.
8273.2.
The new This subrack is new to the product and Added 4.4.9 OSN
OSN 1800 should support basic device functions. 1800 II Enhanced
II Hardware and
Enhanced Version Support.
chassis
supports
ITU-T G.
8275.1.
Updates in V100R006C20
Feature Reason for the Change Information
Update Update
NOTICE
NOTE
Table 4-38 describes the procedure for configuring ITU-T G.8275.1 packets to implement
phase synchronization. To provide physical clock frequency synchronization and ITU-T G.
8275.1-compliant phase synchronization, configure the physical-layer clocks by referring to
2.8.1.1 Configuration Process and then perform the procedure provided in Table 4-38 to
configure ITU-T G.8275.1 packets.
Procedure Remarks
Procedure Remarks
Procedure Remarks
Procedure Remarks
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● IEEE 1588v2 license resources are available.
NOTE
ITU-T G.8275.1 and IEEE 1588v2 share license resources. After IEEE 1588v2 is enabled
on the NMS, ITU-T G.8275.1 is also enabled.
Context
In the case of an NE that is equipped with master and slave subracks, an IEEE
1588v2 license needs to be allocated to each subrack that requires PTP clock
synchronization, and clock cascading needs to be correctly configured for the
master and slave subracks.
Procedure
Step 1 Enable IEEE 1588v2 for a new subrack.
NOTE
ITU-T G.8275.1 and IEEE 1588v2 share license resources. After IEEE 1588v2 is enabled on
the NMS, ITU-T G.8275.1 is also enabled.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● Operations in 4.8.1.2 Enabling PTP have been completed.
Procedure
Step 1 Configure PTP Profile.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The high-precision clock license has been loaded. For details, see License
Guide.
Precautions
The high-precision clock synchronization can be implemented for NEs and boards
only after the high-precision clock mode is set. The high-precision clock mode
controls the time synchronization performance of NEs and boards. Other
operations such as configuring the functions and parameters of PTP NEs and PTP
ports are the same as those for the common-precision clock mode. Configure the
clock mode based on the protocol type.
● If IEEE 1588v2 is used, see 3.8 Configuration Guide (NCE).
● If ITU G.8275.1 is used, see 4.8 Configuration Guide (NCE).
Procedure
Step 1 Configure the number of high-precision clock function licenses.
NOTICE
To make the high-precision clock mode take effect, you must set the clock
precision mode of the corresponding board to high before creating a PTP port. If a
PTP port is created before you set the high-precision clock mode for a board, you
must delete the PTP port and then create a new one.
----End
Follow-up Procedure
When the OSC board is used for high-precision clock synchronization, you need to
correctly set the fiber type, fiber length, and fiber dispersion coefficient on the
WDM Interface > Advanced Attributes page of the NMS.
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The ITU-T G.8275.1 function has been enabled.
Step 2 Set NE Clock Type, Slave Only, and PTP Time Adjustment. For details about the
parameters, see 4.8.1.11.4 Parameters: Clock Synchronization Attribute.
NOTE
NOTICE
----End
Step 1 Set PTP Clock Subnet No. For details about the parameter, see 4.8.1.11.6
Parameters: PTP Clock Subnet.
NOTE
● The NEs with the same clock subnet number belong to the same clock subnet.
● The devices whose NE Clock Type is set to T-BC can belong only to one clock subnet
and the clock sources must be selected from the clock subnet
----End
Step 1 Set PTP Clock Source Type and Local Priority. For details about the parameters,
see 4.8.1.11.7 Parameters: BMC (Clock Subnet).
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The required boards have been created.
● A clock synchronization GE optical port has been created on the NE Panel.
● For OSN 1800, Frame Format can be set for the following boards:
● New OTU boards and OTN line boards (including universal line boards) in
V100R019C10 and later versions.
● UNS4 board of the OSN 1800 V.
● For the OSN 9800, Frame Format can be set for the following boards: new OTU boards
and OTN line boards (including universal line boards) in V100R007C00SPC700 and later
versions.
● After the Frame Format of the UNS4 board on the OSN 1800 V is set to HDLC, the PTP
Clock Message Location parameter can be set.
● PTP Clock Message Location can be set for the Z5UNQ2 board on OSN 1800. When
the overhead in row 1 and column 13 is used, the Frame Format is GFP. When the
overhead in row 2 and column 3 is used, the Frame Format is HDLC.
● For boards on other products, when the Frame Format is set to GFP, the overhead
bytes in row 1 and column 13 are used. When the Frame Format is set to HDLC, the
overhead bytes in row 2 and column 3 are used.
NOTICE
● When the same type of boards are interconnected, PTP Clock Message
Location and Frame Format can retain the default values.
● When different boards are interconnected, you must query and set PTP Clock
Message Location and Frame Format to ensure that they are consistent on
the interconnected ports.
For example, when a Z5UNS4 board on the OSN 1800 interconnects with a
K1UNS4/K1UNS5 board, PTP Clock Message Location and Frame Format
need to be modified.
● If the ODUk trail delay measurement function is required in the O&M
phase, set the PTP packet frame format to GFP for the Z5UNS4 and
K1UNS4/K1UNS5 boards.
● If the ODUk trail delay measurement function is not required, set PTP
Clock Message Location of the Z5UNS4 board to row 2 and column 3,
and set Frame Format to HDLC at both ends.
● When Frame Format of a local board changes between GFP and HDLC and is
different from that of the interconnected board, clock source tracing will be
affected.
If you want to modify a selected port, select the corresponding port in the Selected Port
----End
Step 1 Set Not Slave and Local Priority. For details about the parameters, see 4.8.1.11.4
Parameters: Clock Synchronization Attribute.
----End
Step 1 Select a port and set SYNC Packet Period(s), DELAY Packet Period(s),
ANNOUNCE Packet Period(s), and ANNOUNCE Packet Timeout Coefficient. For
details about the parameters, see 4.8.1.11.4 Parameters: Clock Synchronization
Attribute.
NOTE
----End
Step 1 Select a port, and set Warp Direction, Warp Mode, Warp Length(m), and Warp
Time(ns). For details about the parameters, see 4.8.1.11.4 Parameters: Clock
Synchronization Attribute.
NOTE
● The value Positive of the Warp Direction parameter specifies that transmission
distance in the receive direction is longer than the distance in the transmit direction, or
the transmission time in the receive direction is longer than the time in the transmit
direction; the value Negative specifies just the opposite.
● Warp Length(m) is available only when Warp Mode is set to Length; Warp Time(ns)
is available only when Warp Mode is set to Time.
● The values of Warp Length(m) and Warp Time(ns) are set depending on the
networking scheme for the site.
----End
NOTE
Only the following boards on the following products support single-fiber bidirectional
asymmetric compensation. For details about the restrictions, see 3.3.1 Feature Limitations.
● OSN 1800 V (Z-series system control boards) V100R009C00 and later versions: EX4 and
EG10
● OSN 1800 V Pro (K5UXCME system control board): EX10
● OSN 1800 II Pro (K2UXCLE system control board): EX10
----End
NOTE
Step 1 Select a port and set its MAC address. For details about the parameters, see
4.8.1.11.11 Parameters: MAC Address Configuration.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The ITU-T G.8275.1 function has been enabled.
● The required STG boards have been created.
● For the OSN 6800, you have prepared a 120-ohm external clock port cable as
the network cable for external port cascading of clock boards.
● Each subrack has two clock ports and two time ports. These ports are used to
concatenate and transmit the clock or time signals among multiple subracks,
or are used to input or output external clock and time signals. By default, all
these ports are not used. If any ports need to be used for the input or output
of external clock and time signals, the ports should be disabled. One NE
supports a maximum of two ports for the input or output of external clock
and time signals.
● After PTP Synchronization is enabled for an NE, the NE automatically
switches the frequency source mode to Physical Synchronization when
Enabled Status of the external clock port on the NE's clock board changes
from Enabled to Disabled or changes from Unused to Disabled. Therefore,
you need to manually set the frequency source mode of the NE to PTP
Synchronization.
Step 1 Configure Enabled Status. For details about the parameters, see 4.8.1.11.3
Parameters: Clock Port Link.
----End
Step 1 Select an external time port and set Direction, Interface Protocol Type, and
Interface Level. For details about the parameters, see 4.8.1.11.8 Parameters:
Basic Attribute.
NOTE
For the Interface Level parameter, the OSN 6800 supports only the value RS422.
Step 2 Set PTP Clock Source Type and Local Priority. For details about the parameters,
see 4.8.1.11.9 Parameters: BMC (External Time Interface).
● If the manually specified Time Quality Level is not the default value 248, the
manually specified ITU-T G.8275.1 time quality level applies.
● If the manually specified Time Quality Level is the default value 248, the
clock board automatically converts the quality information carried in the TOD
into the ITU-T G.8275.1 time quality level based on the predefined conversion
table.
Table 4-39 provides the mapping between the TOD status information and ITU-T
G.8275.1 time quality level.
Table 4-39 Mapping between the TOD status information and ITU-T G.8275.1
time quality level
0x00: normal 6
----End
Step 1 Select an external time port and set Transmitting Direction, Transmitting
Length(m), and Transmitting Time(ns). For details about the parameters, see
4.8.1.11.10 Parameters: Cable Transmitting Distance.
NOTE
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● A clock port has been created.
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Context
When the clock tracing relationship changes, NCE automatically updates the
tracing relationship in the clock view.
Procedure
Step 1 In the Main Topology, select Clock View from the Current View drop-down list.
Then, select an NE whose clocks are to be queried or set from the Object Tree.
Step 2 In the Clock View, right-click and choose Search Clock Link from the shortcut
menu.
Step 3 In the Search Clock Link window, set Clock Type and Search Mode, select the NE
to be queried, and click OK.
Step 4 In the Result dialog box, click Close.
Step 5 View the clock tracing relationships of NEs.
----End
Prerequisites
● Ring network automatic compensation can be enabled only after an NE
achieves time synchronization (traces the grandmaster clock). Otherwise, the
calculated compensation value may be inaccurate.
● The compensation value is returned through DCN channels. Ensure that the
DCN links between sites are normal.
Procedure
Step 1 Set Ring Network Compensation Calculation and Ring Network Automatic
Compensation. For details about the parameters, see 3.8.1.10.3 Parameters:
Clock Synchronization Attribute.
Step 2 Set 1588 Compensation Back Safe Password. The values of 1588 Compensation
Back Safe Password must be consistent between the NEs at both ends. For details
about the parameters, see 3.8.1.10.10 Parameters: 1588 Compensation Back
Safe Password.
----End
Follow-up Operations
If Ring Network Automatic Compensation is set to Disabled, the system
provides the recommended compensation value in the alarm after the
asymmetrical offset value of the ring link changes. You need to set the
compensation value manually.
Navigation Path
On the NE Explorer, select the NE and choose Configuration > Clock > PTP clock
> PTP Protocol from the navigation tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > Frequency
Source Mode from the navigation tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > Port
Cascading from Function Tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > PTP Clock >
Clock Synchronization Attribute from the Function Tree.
Parameters
PTP System Time Example: 2009-02-01 Displays the PTP system time.
01:01:01 You can manually modify this
parameter.
Local PTP Clock For example: Displays the clock number of the
Source No. Company Code: 00259E local clock source of the NE.
Supplying Code: 30
NE ID: 007E028B
Ingress of Current Shelf ID (shelf name)- Specifies the local clock input
Master Clock slot number-board port for the master clock that an
name-port number NE currently traces.
(port name)
NOTE
Only the following boards on the following products support single-fiber bidirectional
asymmetric compensation. For details about the restrictions, see 3.3.1 Feature Limitations.
● OSN 1800 V (Z-series system control boards) V100R009C00 and later versions: EX4 and
EG10
● OSN 1800 V Pro (K5UXCME system control board): EX10
● OSN 1800 II Pro (K2UXCLE system control board): EX10
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Source at Port from Function Tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> PTP Clock Subnet Configuration from the Function Tree. Then, click the PTP
Clock Subnet tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> PTP Clock Subnet Configuration from the Function Tree. Then, click the BMC
tab.
Parameters
Field Value Description
PTP Clock Source Type ATOMIC_CLOCK, GPS, PTP Clock Source Type--
TERRESTRIAL_RADIO, Specifies the type of the
PTP, NTP, HAND_SET, clock source.
OTHER, ● ATOMIC_CLOCK:
INTERNAL_OSCILLATOR Indicates an atomic
Default: clock.
INTERNAL_OSCILLATOR ● GPS: Indicates a GPS
time source.
● TERRESTRIAL_RADIO:
Indicates the clock
source synchronized
through any of the
radio distribution
systems that
distribute time and
frequency tied to
international
standards.
● PTP: Indicates a clock
source compliant with
the PTP protocol.
● NTP: Indicates a clock
source compliant with
the Network Time
Protocol (NTP).
● HAND_SET: Indicates
a clock source that is
manually set.
● OTHER: Indicates
other clock sources.
● INTERNAL_OSCILLAT
OR: Indicates an
internal clock source.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the Basic Attribute
tab.
Parameters
Field Value Description
External Time Interface shelf ID (shelf name)- Displays the name of the
slot number-board input interface of the
name-external clock external clock source on
interface the NE.
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> External Time Interface from the navigation tree. Click the BMC tab.
Parameters
Field Value Description
External Time Interface shelf ID (shelf name)- Displays the name of the
slot number-board input interface of the
name-external clock external clock source on
interface the NE.
Time Quality Level 6, 7, 13, 14, 52, 58, 68 to Time Quality Level--
122, 133 to 170, 216 to Specifies the quality level
232, 187, 193, 248, 255 of the time or frequency
Default: 248 allocated by the master
clock device. A smaller
parameter value
indicates a higher quality
level.
PTP Clock Source Type ATOMIC_CLOCK, GPS, PTP Clock Source Type--
TERRESTRIAL_RADIO, Specifies the type of the
PTP, NTP, HAND_SET, clock source.
OTHER, ● ATOMIC_CLOCK:
INTERNAL_OSCILLATOR Indicates an atomic
Default: clock.
INTERNAL_OSCILLATOR ● GPS: Indicates a GPS
time source.
● TERRESTRIAL_RADIO
: Indicates the clock
source synchronized
through any of the
radio distribution
systems that
distribute time and
frequency tied to
international
standards.
● PTP: Indicates a clock
source compliant with
the PTP protocol.
● NTP: Indicates a clock
source compliant with
the Network Time
Protocol (NTP).
● HAND_SET: Indicates
a clock source that is
manually set.
● OTHER: Indicates
other clock sources.
● INTERNAL_OSCILLAT
OR: Indicates an
internal clock source.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the Cable
Transmitting Distance tab.
Parameters
Field Value Description
External Time Interface shelf ID (shelf name)- Displays the name of the
slot number-board input interface of the
name-external clock external clock source on
interface the NE.
Navigation Path
In the NE Explorer, click the NE and choose Configuration > Clock > PTP Clock >
MAC Address Configuration.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > PTP Clock >
Safety Password from the Function Tree.
Parameters
Table 4-47 provides the detailed procedure for configuring ITU-T G.8275.1 packets
to implement phase synchronization and query clock synchronization status.
NOTE
Table 4-47 shows the procedure for configuring ITU-T G.8275.1 packets to implement
phase synchronization. To provide physical clock frequency synchronization and ITU-T G.
8275.1-compliant phase synchronization, configure the physical-layer clocks by referring to
2.8.2.1 Configuration Process and then perform the procedure provided in Table 4-47 to
configure ITU-T G.8275.1 packets.
Operation Remarks
Operation Remarks
Prerequisites
You are an NMS user with "Operator Group" privilege or higher.
Procedure
Step 1 Configure Ptp Profile.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
Procedure
Step 1 Change the 1588V2 attribute to Enabled.
NOTE
ITU-T G.8275.1 and IEEE 1588v2 share license resources. After IEEE 1588v2 is enabled on
the NMS, ITU-T G.8275.1 is also enabled.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The ITU-T G.8275.1 function has been enabled.
NOTE
The PTP System Time field can be set only when the NE traces local clock sources.
Global Configuration.
----End
Step 1 Configure Clock Subnet No.. For details about the parameter, see 3.8.2.8.3
Parameters: Clock Subnet.
NOTE
● The NEs with the same clock subnet number belong to the same clock subnet.
● The devices whose NE Clock Type is set to T-BC can belong only to one clock subnet
and the clock sources must be selected from the clock subnet
----End
Step 1 Set Clock Source Type, Clock Source Priority 2, and Ptp Local Priority. For
details about the parameters, see 4.8.2.9.5 Parameters: BMC (Clock Subnet).
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The required boards have been created.
● The ITU-T G.8275.1 function has been enabled.
Step 1 Configure a clock port. For details about the parameters, see 4.8.2.9.2
Parameters: Clock Synchronization Attribute.
----End
The value of Clock Source WTR Time(min) ranges from 0 to 12 with a step of 1 minute.
The default value is 5.
Step 2 Set Port, Clock Source No, and Clock Source PortNo.
----End
Step 1 Select a port and set SYNC Packet Period(s), DELAY Packet Period(s),
ANNOUNCE Packet Period(s), and ANNOUNCE Packet Timeout Coefficient. For
details about the parameters, see 4.8.2.9.2 Parameters: Clock Synchronization
Attribute.
NOTE
----End
The cable transmission deviation means the time difference of transmitting clock
signals in the receive and transmit directions between two NEs. The cable
transmission deviation can be represented by time or by length.
Step 1 Select a port and set Warp Direction, Warp Mode, Warp Length(m), and Warp
Time(ns). For details about the parameters, see 4.8.2.9.2 Parameters: Clock
Synchronization Attribute.
NOTE
● The value Positive of the Warp Direction parameter specifies that transmission
distance in the receive direction is longer than the distance in the transmit direction, or
the transmission time in the receive direction is longer than the time in the transmit
direction; the value Negative specifies just the opposite.
● Warp Length(m) is available only when Warp Mode is set to Length; Warp Time(ns)
is available only when Warp Mode is set to Time.
● The values of Warp Length(m) and Warp Time(ns) are set depending on the
networking scheme for the site.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The ITU-T G.8275.1 function has been enabled.
Step 2 Configure Bits Type and Bits Clock Class Level. For details on parameter settings,
see 4.8.2.9.7 Parameters: BMC (External Time Interface).
----End
Step 1 Select an external time interface and set the following parameters: Input Warp
Mode, Input Warp Length(m), Input Warp Time(ns), Output Warp Mode,
Output Warp Length(m), and Output Warp Time(ns). For details on parameter
settings, see 3.8.2.8.7 Parameters: Cable Transmitting Distance.
NOTE
● The Input Warp Length(m) parameter is available only when Input Warp Mode is set
to Length; the Input Warp Time(ns) parameter is available only when Input Warp
Mode is set to Time.
● The Output Warp Length(m) parameter is available only when Output Warp Mode is
set to Length; the Output Warp Time(ns) parameter is available only when Output
Warp Mode is set to Time.
● Input Warp Length(m), Output Warp Length(m), Input Warp Time(ns), and Output
Warp Time(ns) needs to be set based on the actual network situations.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● A clock port has been created.
Procedure
Step 1 Query the information about the clock source received at the port.
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Context
When the clock tracing relationship changes, NCE automatically updates the
tracing relationship in the clock view.
Procedure
Step 1 In the Main Topology, select Clock View from the Current View drop-down list.
Select the desired NE from the navigation tree on the left.
Step 2 In the Clock View, right-click and choose Search Clock Link from the shortcut
menu.
Step 3 In the Search Clock Link window, set Clock Type and Search Mode, select the NE
to be queried, and click OK.
----End
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Global Configuration from the navigation tree.
Parameters
PTP System Time Example: 2009-02-01 Displays the PTP system time.
01:01:01 You can manually modify this
parameter.
Ptp Profile IEEE 1588v2, G.8275.1 Indicates the PTP protocol type
Default: IEEE 1588v2 used by the NE.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > PTP Clock >
Clock Synchronization Attribute from the Function Tree.
Parameters
PTP Packet - -
Destination IP
Address
Current Port Master, Slave, Passive, Displays the actual port status.
Status Listening
Port Manual Master, Slave, Passive, Specifies the status of the clock
Status Listening source port on the service board.
Default value: The BMC algorithm computes
Listening the port status based on the
quality and priority of the clock
source.
Step Module one step, two step Sets the one-step or two-step
Default value: one mode for an IEEE 1588 port.
step Only tributary boards support
the setting of one-step or two-
step mode.
● In one-step mode, the actual
Tx time stamp is sent through
the Sync packet to be
transmitted. The one-step
mode requires equipment
with high precision and
accuracy.
● In two-step mode, the actual
Tx time stamp is not added to
the Sync packet to be
transmitted. Instead, the time
stamp is sent through the
subsequent Follow-Up
message.
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Source Priority Table from Function Tree. Click the Clock Source at Port
tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Subnet Configuration from the navigation tree. Click the Clock Subnet
tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Subnet Configuration from the Function Tree. Then, click the BMC tab.
Parameters
Field Value Description
PTP Clock Source Type ATOMIC_CLOCK, GPS, PTP Clock Source Type--
TERRESTRIAL_RADIO, Specifies the type of the
PTP, NTP, HAND_SET, clock source.
OTHER, ● ATOMIC_CLOCK:
INTERNAL_OSCILLATOR Indicates an atomic
Default: clock.
INTERNAL_OSCILLATOR ● GPS: Indicates a GPS
time source.
● TERRESTRIAL_RADIO
: Indicates the clock
source synchronized
through any of the
radio distribution
systems that
distribute time and
frequency tied to
international
standards.
● PTP: Indicates a clock
source compliant with
the PTP protocol.
● NTP: Indicates a clock
source compliant with
the Network Time
Protocol (NTP).
● HAND_SET: Indicates
a clock source that is
manually set.
● OTHER: Indicates
other clock sources.
● INTERNAL_OSCILLAT
OR: Indicates an
internal clock source.
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP clock >
External Time Interface from the navigation tree. Click the Basic Attribute tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the BMC tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the Cable
Transmitting Warp tab.
Parameters
Field Value Description
Table 4-52 provides the detailed procedure for configuring ITU-T G.8275.1 packets
to implement phase synchronization and query clock synchronization status.
NOTE
Table 4-52 shows the procedure for configuring ITU-T G.8275.1 packets to implement
phase synchronization. To provide physical clock frequency synchronization and ITU-T G.
8275.1-compliant phase synchronization, configure the physical-layer clocks by referring to
2.9.1.1 Configuration Process and then perform the procedure provided in Table 4-52 to
configure ITU-T G.8275.1 packets.
Procedure Remarks
Procedure Remarks
Procedure Remarks
Procedure Remarks
Prerequisites
You are an NMS user with "Operator Group" privilege or higher.
Procedure
Step 1 Configure PTP Profile.
----End
Prerequisites
● You are an NMS user with Operator Group rights or higher.
● The license resources of ITU-T G.8275.1 are available.
Procedure
Step 1 Add a subrack and set its IEEE 1588v2 attribute to Enabled.
NOTE
ITU-T G.8275.1 and IEEE 1588v2 share license resources. After IEEE 1588v2 is enabled on
the NMS, ITU-T G.8275.1 is also enabled.
NOTE
● OSN 9800:
– Universal platform subrack: The universal platform subracks on the same NE
implement frequency/phase synchronization through clock cascading between
master and slave subracks.
– U series subrack:
In versions earlier than V100R007C00, electrical subracks on the same NE do not
support clock cascading between master and slave subracks. Therefore, only one
electrical subrack on each NE supports frequency/phase synchronization. You are
advised to configure all boards requiring frequency and phase synchronization in
the same subrack.
In V100R007C00 and later versions, when the system control board is TNU2CTU or
TNS2CTU, electrical subracks on the same NE support clock cascading between
master and slave subracks. When the system control board is TNU4CTU or
TNU5CTU, electrical subracks on the same NE support clock cascading between
master and slave subracks.
– M series subracks: Clock cascading between master and slave subracks is
supported.
– P series subracks: Clock cascading between master and slave subracks is supported.
– Clock cascading between master and slave subracks cannot be implemented
between universal platform subracks and U/M series subracks.
● OSN 1800:
– Subracks that use the TMB1AUX board support clock cascading between master
and slave subracks since V100R020C10. The ports supported by the TMB1AUX
board are external clock/time ports and clock synchronization GE optical ports.
– Subracks that use the TMB2AUX/MD48AFS board support clock cascading between
master and slave subracks since V100R021C10. The ports supported by the
TMB2AUX board are external clock/time ports and clock synchronization GE optical
ports. The ports supported by the MD48AFS board are clock synchronization GE
optical ports.
– Subracks that use the TMK5SXCH/TMK5UXCME/TMK5XCH/TMK5GSCC board
support clock cascading between master and slave subracks since V100R022C00.
The ports supported by the board are clock synchronization GE optical ports.
– Subracks that use the TMK6XCH board support clock cascading between master
and slave subracks since V100R022C10. The ports supported by the board are clock
synchronization GE optical ports.
● OSN 8800/6800: Clock cascading between master and slave subracks is supported.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The ITU-T G.8275.1 has been enabled.
Step 2 Configure PTP Time Adjustment and Protocol Packet Format. For details on
parameter settings, see 4.9.1.9.4 Parameters: Clock Synchronization Attribute.
NOTE
If an NE requires only frequency synchronization, set PTP Time Adjustment to Disabled; if
an NE requires both frequency and time synchronization, set PTP Time Adjustment to
Enabled.
NOTICE
Exercise caution when performing this operation. If PTP Time Adjustment is set
to Disabled, the time synchronization function will be unavailable. When only PTP
frequency synchronization is required and phase synchronization is not, PTP Time
Adjustment can be set to Disabled. By default, it is set to Enabled and the
default setting does not need to be changed in most cases.
----End
Step 1 Configure in PTP Clock Subnet. For details on parameter settings, see 4.9.1.9.6
Parameters: PTP Clock Subnet.
NOTE
● The NEs with the same clock subnet number belong to the same clock subnet.
● Devices in the T-BC working mode can belong to only one clock subnet, and its clock
source can be selected only from the same clock subnet.
----End
Step 1 Configure Clock Source Type and Local Priority. For details on parameter
settings, see 4.9.1.9.7 Parameters: BMC (Clock Subnet).
----End
----End
Prerequisites
● You are an NMS user with "Operator Group" authority or higher.
● The required boards have been created.
● The ITU-T G.8275.1 function has been enabled.
● Before configuring a port on a board as a PTP port, you need to configure the position
and frame format of PTP clock packets.
● PTP Clock Message Location is available only when Frame Format is set to HDLC.
● Only the UNS4 and UNQ2 boards of the OSN 1800 V support the setting of PTP Clock
Message Location.
● Frame Format can be set only when the UNS4 board of the OSN 1800 V works with
TNZ5UXCMS.
● When Frame Format of a local board changes between GFP and HDLC and is different
from that of the interconnected board, clock source tracing will be affected.
----End
If you want to modify a selected port, select the corresponding port in the Selected Port
----End
Step 1 Set Not Slave and Local Priority. For details about the parameters, see 4.9.1.9.4
Parameters: Clock Synchronization Attribute.
----End
Step 1 Select a port and set SYNC Packet Period(s), DELAY Packet Period(s),
ANNOUNCE Packet Period(s), and ANNOUNCE Packet Timeout Coefficient. For
details about the parameters, see 4.9.1.9.4 Parameters: Clock Synchronization
Attribute.
NOTE
----End
Step 1 Select a port, and set Warp Direction, Warp Mode, Warp Length(m), and Warp
Time(ns). For details about the parameters, see 4.9.1.9.4 Parameters: Clock
Synchronization Attribute.
NOTE
● The value Positive of the Warp Direction parameter specifies that transmission
distance in the receive direction is longer than the distance in the transmit direction, or
the transmission time in the receive direction is longer than the time in the transmit
direction; the value Negative specifies just the opposite.
● Warp Length(m) is available only when Warp Mode is set to Length; Warp Time(ns)
is available only when Warp Mode is set to Time.
● The values of Warp Length(m) and Warp Time(ns) are set depending on the
networking scheme for the site.
----End
NOTE
This function is supported only when the system control board of the OSN 1800 V is
UXCMS and the product version is V100R009C00 or later. For details about the restrictions,
see 4.3.1 Feature Limitations.
----End
NOTE
Step 1 Select a port and set its MAC address. For details about the parameters, see
4.9.1.9.11 Parameters: MAC Address Configuration.
----End
Prerequisites
● You are an NMS user with Operator Group rights or higher.
● The ITU-T G.8275.1 function has been enabled.
● STG boards have been created.
● For the OSN 6800, when the external port cascading mode is configured for
clock boards, the 120-ohm external clock port cable must be used as the
network cable for cascading.
● Each subrack has two clock ports and two time ports. These ports are used to
concatenate and transmit the clock or timing signals among multiple
subracks, or are used to input or output external clock and timing signals. By
default, the Enabled Status is unused. If any ports need to be used for the
input or output of external clock and timing signals, the ports should be set
to disabled state. One NE supports a maximum of two ports for the input or
output of external clock and timing signals.
● After PTP Synchronization is enabled for an NE, the NE automatically
switches the frequency source mode to Physical Synchronization when
Enabled Status of the external clock port on the NE's clock board changes
from Enabled to Disabled or changes from Unused to Disabled. When this
occurs, manually set the frequency source mode of the NE to PTP
Synchronization.
Step 1 Configure Enabled Status. For details on parameter settings, see 4.9.1.9.3
Parameters: Clock Port Link.
----End
Step 1 Select an external time interface and set the following parameters: Direction,
Interface Protocol Type, and Interface Level. For details on parameter settings,
see 4.9.1.9.8 Parameters: Basic Attribute.
NOTE
For the Interface Level parameter, OSN 6800 only supports the value RS422.
Step 2 Configure Clock Source Type and Local Priority. For details on parameter
settings, see
● If the manually specified Time Quality Level is not the default value 248, the
manually specified ITU-T G.8275.1 time quality level applies.
● If the manually specified Time Quality Level is the default value 248, the
STG clock board automatically converts the quality information carried in the
TOD into the ITU-T G.8275.1 time quality level based on the predefined
conversion table.
Table 4-53 provides the mapping between the TOD status information and ITU-T
G.8275.1 time quality level.
Table 4-53 Mapping between the TOD status information and ITU-T G.8275.1
time quality level
TOD Status Information ITU-T G.8275.1 Time Quality
Level
0x00: normal 6
----End
Step 1 Select an external time port and set the following parameters: Transmitting
Direction, Transmitting Length(m), and Transmitting Time(ns). For details on
parameter settings, see 4.9.1.9.10 Parameters: Cable Transmitting Distance.
NOTE
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The clock port has been created.
----End
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Context
When the clock tracing relationships are changed, the U2000 automatically
refreshes the tracing status in Clock View.
Procedure
Step 1 In the Main Topology window, select Clock View from the Current View drop-
down list. Select the desired NE from the navigation tree on the left.
Step 2 In Clock View on the right, right-click and choose Search Clock Link from the
shortcut menu.
Step 3 In the Search Clock Link window, set Clock Type and Search Mode, and select
the NE to be queried. Click OK.
----End
Navigation Path
On the NE Explorer, select the NE and choose Configuration > Clock > PTP clock
> PTP Protocol from the navigation tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > Frequency
Source Mode from the navigation tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > Port
Cascading from Function Tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > PTP Clock >
Clock Synchronization Attribute from the Function Tree.
Parameters
PTP System Time Example: 2009-02-01 Displays the PTP system time.
01:01:01 You can manually modify this
parameter.
NOTE
This function is supported only when the system control board of the OSN 1800 V is
UXCMS and the product version is V100R009C00 or later. For details about the restrictions,
see 4.3.1 Feature Limitations.
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Source at Port from Function Tree.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> PTP Clock Subnet Configuration from the Function Tree. Then, click the PTP
Clock Subnet tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> PTP Clock Subnet Configuration from the Function Tree. Then, click the BMC
tab.
Parameters
Field Value Description
PTP Clock Source Type ATOMIC_CLOCK, GPS, PTP Clock Source Type--
TERRESTRIAL_RADIO, Specifies the type of the
PTP, NTP, HAND_SET, clock source.
OTHER, ● ATOMIC_CLOCK:
INTERNAL_OSCILLATOR Indicates an atomic
Default: clock.
INTERNAL_OSCILLATOR ● GPS: Indicates a GPS
time source.
● TERRESTRIAL_RADIO:
Indicates the clock
source synchronized
through any of the
radio distribution
systems that
distribute time and
frequency tied to
international
standards.
● PTP: Indicates a clock
source compliant with
the PTP protocol.
● NTP: Indicates a clock
source compliant with
the Network Time
Protocol (NTP).
● HAND_SET: Indicates
a clock source that is
manually set.
● OTHER: Indicates
other clock sources.
● INTERNAL_OSCILLAT
OR: Indicates an
internal clock source.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the Basic Attribute
tab.
Parameters
Field Value Description
External Time Interface shelf ID (shelf name)- Displays the name of the
slot number-board input interface of the
name-external clock external clock source on
interface the NE.
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> External Time Interface from the navigation tree. Click the BMC tab.
Parameters
Field Value Description
External Time Interface shelf ID (shelf name)- Displays the name of the
slot number-board input interface of the
name-external clock external clock source on
interface the NE.
PTP Clock Source Type ATOMIC_CLOCK, GPS, PTP Clock Source Type--
TERRESTRIAL_RADIO, Specifies the type of the
PTP, NTP, HAND_SET, clock source.
OTHER, ● ATOMIC_CLOCK:
INTERNAL_OSCILLATOR Indicates an atomic
Default: clock.
INTERNAL_OSCILLATOR ● GPS: Indicates a GPS
time source.
● TERRESTRIAL_RADIO
: Indicates the clock
source synchronized
through any of the
radio distribution
systems that
distribute time and
frequency tied to
international
standards.
● PTP: Indicates a clock
source compliant with
the PTP protocol.
● NTP: Indicates a clock
source compliant with
the Network Time
Protocol (NTP).
● HAND_SET: Indicates
a clock source that is
manually set.
● OTHER: Indicates
other clock sources.
● INTERNAL_OSCILLAT
OR: Indicates an
internal clock source.
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the Cable
Transmitting Distance tab.
Parameters
Field Value Description
External Time Interface shelf ID (shelf name)- Displays the name of the
slot number-board input interface of the
name-external clock external clock source on
interface the NE.
Navigation Path
In the NE Explorer, click the NE and choose Configuration > Clock > PTP Clock >
MAC Address Configuration.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > PTP Clock >
Safety Password from the Function Tree.
Parameters
Table 4-61 provides the detailed procedures for configuring ITU-T G.8275.1
frequency and phase synchronization.
NOTE
Table 4-61 shows the procedure for configuring ITU-T G.8275.1 phase synchronization. To
implement both frequency and phase synchronization at the physical layer, configure
physical-layer clocks based on 2.9.2.1 Configuration Process of physical-layer clocks and
then configure ITU-T G.8275.1 messages with reference to Table 4-61 to implement phase
synchronization.
Table 4-61 Procedures for configuring ITU-T G.8275.1 frequency and phase
synchronization
Operation Remarks
Operation Remarks
Operation Remarks
Prerequisites
You are an NMS user with "Operator Group" privilege or higher.
Procedure
Step 1 Configure Ptp Profile.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The license resource of ITU-T G.8275.1 resources is available.
Procedure
Step 1 Change the 1588V2 attribute to Enabled.
NOTE
ITU-T G.8275.1 and IEEE 1588v2 share the same license resources. ITU-T G.8275.1 is enabled
after IEEE 1588v2 is enabled on the U2000.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The ITU-T G.8275.1 has been enabled.
NOTE
PTP System Time can be successfully set only when the NE traces local clock sources.
----End
The calculation of the PTP clock source is based on the clock subnet. Each clock
subnet calculates its own current clock source separately. For an NE, only one time
domain is supported at a time. Each T-BC device can be configured only with one
clock subnet. The clock source should be selected from within the same clock
subnet. The messages sent from different clock subnets are discarded by the NE.
Step 1 Configure in PTP Clock Subnet. For details on parameter settings, see 3.9.2.8.3
Parameters: Clock Subnet.
NOTE
● The NEs with the same clock subnet number belong to the same clock subnet.
● Devices in the T-BC working mode can belong to only one clock subnet, and its clock
source can be selected only from the same clock subnet.
----End
Step 1 Configure Clock Source Type, Clock Source Priority 2, and Ptp Local Priority to
set them. For details on parameter settings, see 4.9.2.9.5 Parameters: BMC
(Clock Subnet).
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● Required boards have been created.
● The ITU-T G.8275.1 has been enabled.
● The clock port is used to synchronize the time between two clock nodes.
Depending on the actual networking, several clock ports can be created for a
board to connect to other clock nodes.
Step 1 Configure a clock port. For details on parameter settings, see 4.9.2.9.2
Parameters: Clock Synchronization Attribute.
----End
Step 2 Configure Port, Clock Source No, and Clock Source PortNo.
----End
Step 1 Select a port and the set the following parameters for the port: SYNC Packet
Period(s), DELAY Packet Period(s), ANNOUNCE Packet Period(s), and
ANNOUNCE Packet Timeout Coefficient. For details on parameter settings, see
NOTE
----End
Step 1 Select a port and set the following parameters: Warp Direction, Warp Mode,
Warp Length(m), and Warp Time(ns). For details on parameter settings, see
NOTE
● The value Positive of the Warp Direction parameter specifies that transmission
distance in the receive direction is longer than the distance in the transmit direction, or
the transmission time in the receive direction is longer than the time in the transmit
direction; the value Negative specifies just the opposite.
● The Warp Length(m) parameter is available only when Warp Mode is set to Length.
The Warp Time(ns) parameter is available only when Warp Mode is set to Time.
● The values of Warp Length(m) and Warp Time(ns) are set based on the actual
networking situation.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The ITU-T G.8275.1 has been enabled.
● The CTU boards have been created.
Step 1 Select an external time interface and set the External Time Interface Direction
and Interface Protocol Type parameters. For details on parameter settings, see
4.9.2.9.6 Parameters: Basic Attribute.
Step 2 Configure Bits Type and Bits Clock Class Level. For details on parameter settings,
see 4.9.2.9.7 Parameters: BMC (External Time Interface).
----End
Output Warp Length(m), and Output Warp Time(ns). For details on parameter
settings, see 3.9.2.8.7 Parameters: Cable Transmitting Distance.
NOTE
● The Input Warp Length(m) parameter is available only when Input Warp Mode is set
to Length; the Input Warp Time(ns) parameter is available only when Input Warp
Mode is set to Time.
● The Output Warp Length(m) parameter is available only when Output Warp Mode is
set to Length; the Output Warp Time(ns) parameter is available only when Output
Warp Mode is set to Time.
● Input Warp Length(m), Output Warp Length(m), Input Warp Time(ns), and Output
Warp Time(ns) needs to be set based on the actual network situations.
----End
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The clock port has been created.
Procedure
Step 1 Query the clock source received at a port.
----End
Prerequisites
You are an NMS user with "Guests" privilege or higher.
Context
When the clock tracing relationships are changed, the U2000 automatically
refreshes the tracing status in Clock View.
Procedure
Step 1 In the Main Topology window, select Clock View from the Current View drop-
down list. Select the desired NE from the navigation tree on the left.
Step 2 In Clock View on the right, right-click and choose Search Clock Link from the
shortcut menu.
Step 3 In the Search Clock Link window, set Clock Type and Search Mode, select the NE
to be queried, and click OK.
Step 4 In the Result dialog box, click Close.
----End
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Global Configuration from the navigation tree.
Parameters
PTP System Time Example: 2009-02-01 Displays the PTP system time.
01:01:01 You can manually modify this
parameter.
Ptp Profile IEEE 1588v2, G.8275.1 Indicates the PTP protocol type
Default: IEEE 1588v2 used by the NE.
Navigation Path
In the NE Explorer, select an NE and choose Configuration > Clock > PTP Clock >
Clock Synchronization Attribute from the Function Tree.
Parameters
PTP Packet - -
Destination IP
Address
Current Port Master, Slave, Passive, Displays the actual port status.
Status Listening
Port Manual Master, Slave, Passive, Specifies the status of the clock
Status Listening source port on the service board.
Default value: The BMC algorithm computes
Listening the port status based on the
quality and priority of the clock
source.
Step Mode one step, two step Sets the one-step or two-step
Default value: one mode for an IEEE 1588 port.
step Only tributary boards support
the setting of one-step or two-
step mode.
● In one-step mode, the actual
Tx time stamp is sent through
the Sync packet to be
transmitted. The one-step
mode requires equipment
with high precision and
accuracy.
● In two-step mode, the actual
Tx time stamp is not added to
the Sync packet to be
transmitted. Instead, the time
stamp is sent through the
subsequent Follow-Up
message.
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Source Priority Table from Function Tree. Click the Clock Source at Port
tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Subnet Configuration from the navigation tree. Click the Clock Subnet
tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP Clock
> Clock Subnet Configuration from the Function Tree. Then, click the BMC tab.
Parameters
Field Value Description
PTP Clock Source Type ATOMIC_CLOCK, GPS, PTP Clock Source Type--
TERRESTRIAL_RADIO, Specifies the type of the
PTP, NTP, HAND_SET, clock source.
OTHER, ● ATOMIC_CLOCK:
INTERNAL_OSCILLATOR Indicates an atomic
Default: clock.
INTERNAL_OSCILLATOR ● GPS: Indicates a GPS
time source.
● TERRESTRIAL_RADIO
: Indicates the clock
source synchronized
through any of the
radio distribution
systems that
distribute time and
frequency tied to
international
standards.
● PTP: Indicates a clock
source compliant with
the PTP protocol.
● NTP: Indicates a clock
source compliant with
the Network Time
Protocol (NTP).
● HAND_SET: Indicates
a clock source that is
manually set.
● OTHER: Indicates
other clock sources.
● INTERNAL_OSCILLAT
OR: Indicates an
internal clock source.
Navigation Path
In the NE Explorer, select the NE and choose Configuration > Clock > PTP clock >
External Time Interface from the navigation tree. Click the Basic Attribute tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the BMC tab.
Parameters
Field Value Description
Navigation Path
In the NE Explorer, select an NE and then choose Configuration > Clock > PTP
Clock > External Time Interface from the Function Tree. Click the Cable
Transmitting Warp tab.
Parameters
Field Value Description
Definition
High-precision clock synchronization means that on the PTP time synchronization
network that complies with IEEE 1588v2 or ITU G.8275.1, the performance of each
clock node meets the requirements of ITU G.8273.2 Class C.
NOTE
Typically, a BITS device can function as both a PRC and a primary reference time clock
(PRTC). Its frequency source is an atomic clock, and its time source can be obtained from
the GNSS.
● It is recommended that core WDM/OTN devices obtain time synchronization signals
from the PRTC through PTP ports and the PRTC also function as the GM clock (defined
as T-GM in G.8275.1) in the PTP time domain.
● Core WDM/OTN devices can also obtain time synchronization signals from other PTP
devices such as PTN devices or core routers through PTP ports. However, it is
recommended that WDM/OTN devices be directly connected to the PRTC.
The GNSS includes the Global Positioning System (GPS), BeiDou Navigation Satellite
System, and GLONASS, which can provide precise UTC time source signals.
NOTE
You can configure BITSs at multiple core nodes to enhance the protection for reference
clock/time sources.
(A) Reference A.1 Dedicated PTP Dedicated PTP Synchronization Ports 5.3.1
clock input Synchronization support synchronous Ethernet and IEEE Reference
Port (HP optical 1588v2/G.8275.1 and can implement Clock Input
port) both frequency synchronization and
interconnection time synchronization.
(C) Intra-site C.1 Dedicated PTP Dedicated PTP Synchronization Ports can 5.3.2 Intra-
clock Synchronization only be used for clock synchronization, Site Clock
synchronization Port (HP optical and can implement both frequency Synchronizat
port) synchronization and time ion
interconnection synchronization. Dedicated PTP
Synchronization Ports cannot be used to
transmit services.
● If clock cascading is implemented
between master and slave subracks
on the same NE, the Dedicated PTP
Synchronization Ports work in
cascading mode.
● If NEs are interconnected through
Dedicated PTP Synchronization Ports,
the Dedicated PTP Synchronization
Ports work in non-cascading mode.
(D) Client-side D.1 Ethernet service WDM/OTN devices can interconnect 5.3.4 Client-
clock port with client-side devices such as base Side Clock
synchronization interconnection stations or routers through Ethernet Synchronizat
service ports that support synchronous ion
Ethernet and IEEE 1588v2/G.8275.1 to
implement both frequency
synchronization and time
synchronization.
(E) OLA site E.1 Clock pass- Frequency signals and PTP time packets 5.3.5 OLA
clock schemes through over OSC are transparently transmitted from Site Clock
upstream OSC ports to downstream OSC Schemes
ports. NEs do not participate in
synchronization.
TMF3AUX01 HP1
Figure 5-3 Reference clock input on the M24 subrack (through the Dedicated PTP
Synchronization Port)
NOTE
In the following figure, the CTU board is used as an example. The TMF3AUX01 board can
also be used. One E1CTU/E2CTU board provides two Dedicated PTP Synchronization Ports,
and one E3CTU/F3AUX01 board provides only one Dedicated PTP Synchronization Port.
Figure 5-4 Reference clock input on the M12 subrack (through the Dedicated PTP
Synchronization Port)
Figure 5-5 Reference clock input on the P32/P32C subrack (through the Dedicated
PTP Synchronization Port)
Figure 5-6 Reference clock input on the U32E/U64E enhanced subrack (through
the Dedicated PTP Synchronization Port)
Figure 5-7 Reference clock input on the 1800 V Pro subrack (through the
Dedicated PTP Synchronization Port)
In the following figures, HP ports are used as Dedicated PTP Synchronization Ports. The
number and names of Dedicated PTP Synchronization Ports vary depending on the board
type. For details, see 5.4.1 Dedicated PTP Synchronization Port (HP Optical Port).
When a board supports multiple HP ports, you are advised to configure active/standby
protection. If a site supports only one HP port, first/last node protection can be configured.
Figure 5-9 Example of intra-site clock synchronization (OSC ports for external
clock source input and Dedicated PTP Synchronization Ports for interconnection)
NOTE
For details about the number of high-precision OSCs supported by a board, see the
Hardware Description.
When service ports work in FlexE mode, high-precision clock synchronization is not
supported. In this scenario, Dedicated PTP Synchronization Ports can be used to connect to
customer devices and implement high-precision clock synchronization.
NOTE
● Clock pass-through is bidirectional. That is, clock and time signals can be transparently
transmitted in both RM1->TM2 and RM2->TM1 directions.
● In the preceding figure, one OSC is configured in each direction. The scheme for dual-
OSC configuration is similar.
● For OLA sites on the same OMS, if single-fiber bidirectional OSC interconnection is
configured, the OLA sites must use the OSC ports connecting to the same fiber for clock
pass-through or synchronization.
In the high-precision clock synchronization solution, external clock ports or external time
ports cannot be used for synchronization.
For details about the OSC boards that support high-precision clock
synchronization, see 5.6 Availability.
● For details about the port service types supported by a board, see the
functions and features of the board in Hardware Description.
NOTE
When service ports work in FlexE mode, high-precision clock synchronization is not
supported. In this scenario, Dedicated PTP Synchronization Ports can be used to connect to
customer devices and implement high-precision clock synchronization.
GE GE (GFP-T) GFP-T
5.5 Specifications
High-precision clock synchronization performance complies with ITU-T G.8273.2
Class C.
NOTE
This topic describes only the special requirements for high-precision clock synchronization.
For details about general specifications, see 3.5 Specifications of 3 IEEE 1588v2 (OTN &
Packet) and 4.5 Specifications of 4 ITU-T G.8275.1/G.8273.2 (OTN & Packet) .
Item Specifications
Low-frequency MTIE 40 ns 40 ns 10 ns
jitter time offset
(dTEL) TDEV 4 ns 4 ns 2 ns
5.6 Availability
This topic describes the license requirements for the high-precision clock
synchronization solution, and corresponding devices, boards, and versions.
NOTE
TNG1T210E V100R022C10
NOTE
● For OTN tributary ports (on OTN tributary boards or OTU boards), the service types and
mapping paths of the ports must meet the requirements described in Table 5-4.
● T216/T230/T220E/G216/G230: Only ports 1 to 15 support PTP synchronization.
● a: The TNG2OH9 board supports high-precision clock only when it uses the BIDI OSC
module.
● TNG1T210E: High-precision clock is not supported when its port type is VP.
● TNG1M828SM: Ports IN/OUT and TX1/RX1 to TX8/RX8 do not support high-precision
clock.
Table 5-9 Boards and versions that support high-precision clock in OSN 9800
U32E/U64E subracks
TMP3CTU V100R022C10
TMK5GSCC V100R022C00
TMK6XCH V100R022C10
External time port, External time (TOD) ports and external clock (CLK) ports
external clock port do not support high-precision clock synchronization.
External time ports and external clock ports cannot be
used to implement high-precision clock synchronization
in scenarios such as BITS interconnection and clock
cascading between master and slave subracks.
Fiber parameters When the OSC board is used for high-precision clock
synchronization, you need to correctly set the fiber type,
fiber length, and fiber dispersion coefficient on the WDM
Interface > Advanced Attributes page of the NMS.
OSN 9800 U/M/P series The product Added the description of the
subracks (with NCE function is high-precision clock
V100R021C10SPC200) newly enhanced. synchronization solution.
support high-precision clock
synchronization.
The 1800 V Pro, 1800 II Pro, The product Added the description of the
and 1800 II TP (with NCE function is high-precision clock
V100R021C10SPC200) newly enhanced. synchronization solution.
support high-precision clock
synchronization.
Prerequisites
● You are an NMS user with "Operator Group" privilege or higher.
● The high-precision clock license has been loaded. For details, see License
Guide.
Precautions
The high-precision clock synchronization can be implemented for NEs and boards
only after the high-precision clock mode is set. The high-precision clock mode
controls the time synchronization performance of NEs and boards. Other
operations such as configuring the functions and parameters of PTP NEs and PTP
ports are the same as those for the common-precision clock mode. Configure the
clock mode based on the protocol type.
Procedure
Step 1 Configure the number of high-precision clock function licenses.
NOTICE
To make the high-precision clock mode take effect, you must set the clock
precision mode of the corresponding board to high before creating a PTP port. If a
PTP port is created before you set the high-precision clock mode for a board, you
must delete the PTP port and then create a new one.
----End
Follow-up Procedure
When the OSC board is used for high-precision clock synchronization, you need to
correctly set the fiber type, fiber length, and fiber dispersion coefficient on the
WDM Interface > Advanced Attributes page of the NMS.
