PUMP SKID OPERATING INSTRUCTIONS

1 Control Panel
The operator panel is composed by a set of switches,
pushbuttons and a touchscreen HMI.

1.1 Main Controls

Two switches are provided: one to select the control
mode (LOCAL or REMOTE), one to select the running
pump (if redundant pump is available).

Two buttons are provided to start and stop the

selected pump.

1.2 HMI panel

The touchscreen HMI panel handles the interaction
between the operator and the control system.

The HMI is a touch panel with a software program;

simply tap the panel with a fingertip to operate on it.

The HMI program contains many different screens.

The operator can navigate between screens as
described in this chapter.

4
OPERATING INSTRUCTIONS PUMP SKID

1.2.1 Control Bar Menu

Menu button: tap on menu to view menu options.

Menu allows the operator to access to other pages.

Login page: tap on Login to change access level.

The system has two access level:

- Operator
- ALSE (Alfa Laval Service Engineer)

5
PUMP SKID OPERATING INSTRUCTIONS

To login in a desired access level:

- Tap on User name button and select the
desired access level.
- Tap on the Password button and insert the
correct password.
- Tap on Log in button
To logout:
- Go to Log in page
- Tap on Log out button

Setting page: tap on Settings to access to:

- Login (already described above)
- Parameters
- Time
- Service

Info page: tap on info page for information about

installed software version.

6
OPERATING INSTRUCTIONS PUMP SKID

1.2.2 Settings Menu

Parameter page: tap on Parameters button to access

the Parameters page.

Parameters > Installed Devices

This page allows to change the configuration of the
system.

NOTE

Installed Devices menu is only available

with ALSE (Alfa Laval Service Engineer)
access level.

Parameters > Process Parameters

This page allows the operator to change parameters

related to process components.

NOTE

In this page is possible to set the switching

temperature for the heat tracing (if installed).

Parameters > Alarms Delays

This page allows the operator to set the delay for

pressure and temperature alarms to be active.
See the Parameter List for full listing.

7
PUMP SKID OPERATING INSTRUCTIONS

Parameters > Alarms Limits

This page allows the operator to set the threshold of

pressure and temperature alarms.
See the Parameter List for full listing.

Parameters > Reset to factory setpoints

It is always possible to reset all the process

parameters to factory setpoint tapping the button
“Reset to factory setpoints”

Factory setpoints are indicated on the column

“default” in the parameter list.

Time page: tap on Time button to change date and

time.

NOTE

To change time settings the operator (user) has to be

logged as “Advanced operator”.

To enable manual setting:

- tap the button “Enable to set the time
manually”.
- Change date and time
- tap the button “Set Time”.

8
OPERATING INSTRUCTIONS PUMP SKID

Service page: This page allows the operator to

access to the following functions:

Service > Info

Tap on info page to check installed software version.

Service > Counters

Tap on info page to know running time (minutes) of

pump(s).

Service > Overview

Tap on info page to check the status of the digital and

analog inputs and outputs from the PLC.

9
PUMP SKID OPERATING INSTRUCTIONS

1.2.3 Alarm History

The presence of any active alarms is indicated by a

red and blue alarm icon at main bar. The red and
blue alarm icon flashes until all active alarms have
been acknowledged.

A white and blue icon means no active alarms.

Tap on Alarms button to enter Alarms page.

In case there is an active alarm, the alarm button

leads directly to alarm list.
In case there is not an active alarm, the alarm button
leads to a page where is possible to view the alarms
history.

10
OPERATING INSTRUCTIONS PUMP SKID

Unacknowledged alarms
If there is at least an unacknowledged alarm the
Alarm symbol is blinking (red and white) and the
related active alarm is marked in RED colour.

Unacknowledged alarms have a red background colour.

On this page the operator can:

- Acknowledge alarms one by one using the
white arrows on the HMI and tapping on
the single green button.
- Acknowledge all alarms together tapping
on the multiple green button.

Never reset an alarm without first finding and

remedying the cause.

Acknowledged alarms
To acknowledge an alarm select it tapping on
alarm line and then tap the Acknowledge button.

The alarms page stays in this status until all alarms

are acknowledged and not active.

When the alarm condition is no longer fulfilled,

acknowledged alarms disappear from the alarm list.

If all alarms are acknowledged but there is at least

an acknowledged alarm that is still active, the
Alarm symbol is of a fixed RED color (not blinking).
11
PUMP SKID OPERATING INSTRUCTIONS

Acknowledged alarms currently active have yellow

background colour.

Refer to Alarms and Faults Finding booklet for

further information on alarms and the related
troubleshooting actions.

1.2.4 Speed selection

Modules designed to pump HFO can be operated at

two different fixed speeds/pump capacities by mean
of a Frequency converter; the frequency converter
controls ramp-up speed when pumping high viscosity
fuel.

Speed selection can be chosen by pressing the button

on the HMI panel. Every push of the button will cycle
between “Speed 1” (high speed / high capacity) and
“Speed 2” (low speed / low capacity).

12
OPERATING INSTRUCTIONS PUMP SKID

2 Normal Operation
2.1 Before start
The following procedures assumes that the system
pipework and the valves arrangement is set for
operation (valves open and pipework secured).
Moreover, it is assumed that the commissioning
actions described in the Installation System Reference
booklet have been successfully performed.

Make sure that the pumps are filled with oil before start,
otherwise the pumps shaft seal will be damaged. For
pumps startup recommendations, see Installation
System Reference booklet.

NOTE
Make sure that all pipelines have been flushed before
start, otherwise all main components will be damaged.
For first startup procedure, see Installation System
Reference booklet.

• Turn the main switch on the cabinet to ON.

• Put the selector switch to LOCAL mode.

2.2 Initial settings

Set parameters and setpoint for the temperature control
by heat tracing (see Parameter List booklet).

Set the required speed / pump capacity (only for pumps

equipped with optional VFD).

2.3 Start
Select the running pump with the selector switch (if installed)
and start the pump by pressing the START button.

2.4 Stop
Stop the running pump by pressing the STOP button.
By stopping the system as described below, no
alarms will be activated.

13
PUMP SKID OPERATING INSTRUCTIONS

NOTE
The pump changeover in case of low pressure
alarm is not automatic. The system is designed
to start automatically the second pump (if installed)
only when the selector switch “pump priority” is
operated while any pump is running.

NOTE
Since the pumps shaft seal has to be lubricated, a small
amount of oil will drop from the pump. About 10 drops
per hours is considered normal.

If the leakage amount is higher, the shaft seal should be

replaced immediately to avoid additional damages.
See Oil Feed Pumps booklet for details.

2.5 Remote Control

The remote control of the Pump Skids can be
performed through the Remote Control Box
(if installed, according to order).

For further information, see Installation System

Reference book.

NOTE
It is always possible to stop the system by mean of
the STOP pushbutton on the local control panel,
regardless the system is in LOCAL or REMOTE mode.

Modbus TCP/IP is available for Remote

monitoring. See Modbus List booklet for details.

2.6 Regular checks on the

system
Regularly check the process values to note any
unusual changes.

When the outside ambient temperature is high,

regularly check the internal control panel
temperature. This should be max 55°C.

14
OPERATING INSTRUCTIONS PUMP SKID

2.7 Emergency stop

In case of emergency, the module can be stopped by
pushing the emergency stop pushbutton on the
control panel or the remote control box (if installed)
or by energizing the Emergency Shutdown Device.

To reset the emergency stop release the emergency

pushbutton and press the RESET EMERGENCY STOP
button. Alarm A01 should also be acknowledged on
the HMI before operating the system again.

Never reset emergency stop without first

remedying the problem.
