CHAPTER 1
INTRODUCTION
track them. So, there is a need for a tool that should assess the surface
roughness before machining a part and, at the same time, it can be easily used
in the shop floor environment for contributing to the minimization of
machining time and cost for the desired surface quality.
parameters can produce better surface roughness, higher tool life with
minimum chip thickness.
There are several types of Stainless steels which are discussed in the
coming paragraphs. They are classified broadly under four main categories of
martensitic, ferritic, austenitic and precipitation hardened stainless steel.
safely be used in sea water applications, and this is against the fact that it is
generally less durable than the austenitic type of stainless steel. This corrosion
resistance ability makes it suitable that it is also the material of choice when
manufacturing boilers and washing machines. It is also highly useful when
making things such as car trim and exhaust systems.
Corrosion resistance
Fabrication characteristics
Availability
Product cost
TYPE 409: Ferritic (plain chromium stainless steel category) stainless steel
suitable for high temperature. This grade has the lowest chromium content of
all stainless steels and thus is the least expensive.
TYPE 410: The most widely used martensitic (plain chromium stainless class
with exceptional strength) stainless steel, enabling a high level of strength
advised by the martensitic stainless steel. It is a heat treatable grade of low
cost which is suitable for non-severe corrosion applications.
TYPE 430: The most widely used ferritic (plain chromium stainless category)
stainless steel, offering general-purpose corrosion resistance, often in
decorative applications.
The most widely used stainless grades are the austenitic 18/9 type
stainless steels, i.e. AISI 304 and 304L, which accounts for more than 50% of
the global production of stainless steel. After this type, most widely used
grades are the ferritic steels such as AISI 410, followed by the molybdenum-
alloyed austenitic steels AISI 316 and 316L. Together these grades (austenitic
and ferritic) account over 80% of the total tonnage of stainless steels. To
identify the grades, American standard (AISI) designations are normally used.
14
If a certain grade of stainless steel does not have a standard designation, then
From the development of stainless steels
the number of grades has increased rapidly. There are a large number of
stainless steels with widely varying compositions.
High Strength
Stainless steel is used for jewellery and watches with 316L being
the type commonly used for such applications. It can be re-finished by any
jeweller and will not oxidize or turn black. Some firearms incorporate
stainless steel components as an alternative to blued or parkerized steel. Some
handgun models, such as the Smith & Wesson Model 60 and the Colt M1911
pistol, can be made entirely from stainless steel. This gives a high-luster finish
17
similar in appearance to nickel plating. Unlike plating, the finish is not subject
to flaking, peeling, wear-off from rubbing (as when repeatedly removed from
a holster), or rust when scratched.
The Taguchi method is a quality tool that helps improve the work
efficiently. It is possible to select suitable factors and their levels in the
cutting experiment. In this research work the parameters selected are cutting
speed with two levels, feed with three levels and depth of cut with three
levels. The experimental results are designed as given by orthogonal array of
the Taguchi Technique.
vi) Analysis the experimental result using the S/N ratio and
ANOVA test.
19
vii) Find the optimal level for each of the process parameters.
S/N (1.1)
The S/N ratio for each parameter level is calculated by finding the
average of S/N ratios at the corresponding level. The analysis of S/N ratio of
tool life found that the first factor that causes tool life to be great is cutting
speed, having feed rate and depth of cut as secondary factors, respectively.
From ANOVA analysis the significant parameter on response parameter can
be found.
20
= + + X² + +€ (1.2)
22
Figure 1.6 Flow chart for non dominated sorting genetic algorithm
Atxaga & Irisarri (2009) founded the reason for the failure of a
group of duplex stainless steel valves after a service of 15 years. Chemical
analysis did not agreed with the required quality. Metallographic analysis
affirmed some small crater with corrosive products inside which were
accursed to be the origin of long cracks and which consequently leads to
failure. Cracks and pitting continued along the interface of ferrite and
austenite, where carbides and brittle phases are precipitated. They
recommended the usage of steels with higher pitting resistance and to avoid
working in the temperature range where both carbides and brittle phases are
formed.
Iris Alvarez Armas (2008) described the history and some recent
developments of duplex stainless steel grades. He also discussed the
enhancement made on the standard S32205 duplex stainless steel by lowering
the Ni and Mo additions. This was done to produce an cost effective substitute
of the regular grade or in the case of the super duplex S32750 grade by
expanding the additions of Cr, Mo and N or elevating the content of
chromium, nickel, copper and tungsten in consolidation with nearly lower
contents of Ni and Mo to improve the toughness, strength and corrosion
resistance properties which are well suitable for the oil industry.
28
results were analyzed to quantify the crack resistance term. The obtained
results can be used for assessment of the probability of tubular failure caused
by ductile fracture.
Okushima & Minato (1959) developed the chip flow model for nose
radius tools mathematically. They experimentally proved that the cutting
speed does not affect the angle of the chip flow. The cutting edge was divided
into small segments, and it was pretended that chip flow angles were upright
to the cutting edge in each segment. Then, the primitive chip flow angles were
added along the cutting edge to find the overall chip flow angle. Based on this
hypothesis, they developed six variant mathematical expressions by allocating
the cutting patterns.
determine the optimal rake angle for each material. The experimental results
showed that the main cutting force had an increasing trend with the increasing
depth of cut and not interrelated with the work piece material. But the
influence of the tool rake angle on the main cutting force mainly depends
upon the work piece material type.
Hakif Zeqiri et al (2010) stated that the chip morphology and chip
formation were surely affected by tool geometry and turning parameters such
as cutting speed, feed rate, and depth of cut. An experiment investigation was
presented to understand the influence of tool geometry on chip deformation
and chip morphology in orthogonal cutting. The obtained results showed that
tool geometry affect the chip morphology significantly and among the turning
parameters, the cutting speed was the most predominant factor that influence
the chip morphology.
tool hardness over work piece hardness can be achieved. Optimal cutting
temperature is independent of the cutting process parameters and machining
condition and is only based on the material properties of the cutting tool and
work piece materials.
Aznijar Ahmad et al (2010) proposed that the tool life gets severely
affected by the heat generated during metal cutting process. Researchers all
over the world undergone various attempts to understand the mechanism
behind the generated heat during machining, thereby to achieve a optimized
machining procedure. The latest attempt was through the use of chilled air,
i.e. cryogenic cooling. A Ranque Hilsch vortex tube, a device with no moving
parts, was used for this low cost refrigeration. Various studies conducted on
its background, its application and performance were discussed for the high
speed metal cutting cooling application for die and mould steels.
Sun et al (2010) machined nickel alloys, and found that due to its
high strength, a very high temperatures and cutting forces were produced
during cutting process. As the thermal conductivity of nickel is very low, the
heat generated cannot be efficiently discharged through the work piece and
through chip removal. Traditionally used cutting fluids cannot penetrate the
chip tool interface and it reaches the highest temperature at the cutting zone
especially at high cutting speeds. They tends to vaporize at high temperatures
and form a high temperature covering over the cutting zone which results in
further increase of the temperature
38
Hong (2001) stated that the gaseous cutting fluids are relatively
cleaner and more environment friendly to use during machining. However
they are more costly alternatives than cutting fluids which require extra
equipment which are not provided with the machine tools. Also, gas based
cutting liquids cannot be circulated in the machine tool as they vaporize after
application. But, it eliminates the disposal costs, disposal time and cost
associated with cleaning the parts, machining chips and machine tools. As
nitrogen is lighter than air, it can be easily evaporated into the atmosphere.
The CO2 is heavier than air and accumulates at the shop floor increasing the
risk of oxygen reduction (Dogra et al 2010)
When comparing the three gases for cooling, CO2 gas had more
lubricating effect than oxygen and oxygen had more lubricating effect than
nitrogen. Hollis (1961) carried out a turning experiment using CO 2 along with
argon gas and CO2 alone as coolant. Argon, an inert gas creates an inert
atmosphere and provides less hardening at the machined surface which results
in enhanced tool life. Podgorkov (1998) introduced a new pollution free
machining technique which uses water vapor of temperature less than 1000C
as a coolant when turning stainless steel with cemented carbide tools. It had
been observed that water vapor lubrication increases the tool life of cemented
carbide tools by about 1.5 times and causes more uniform cooling during the
turning process.
39
than by any other approaches. Even when the number of parameters being
investigated is quite large, a fewer number of tests are needed. (Kang &
Hadfield 2001). Ashish yadav et al (2012) stated that the Taguchi method is a
powerful tool for the design of high quality systems. It provides a simple,
systematic and efficient approach to optimize design for performance, quality
and cost. to design of experiments is easy to adopt and
40
can be easily applied by any users with limited knowledge of statistics, and
thereby gained wide popularity in the engineering and scientific community.
Hari singh & Pradeep kumar (2004) machined EN24 steel with
titanium carbide coated carbide inserts as cutting tool and adopted a approach
based on design of experiment to obtain optimal setting of turning parameters
that yield optimal values of tool wear. The effect of the selected turning
process parameters on tool wear and subsequent optimal settings of the
parameters had been polished using Taguchi approach. The forecasted
44
optimal values of flank wear width and crater wear depth of coated carbide
tool are 0.172mm and 0.244 micron respectively.
The interactions between cutting tool and the work piece form the
cutting temperature and contact stress, which subsequently leads to flank
wear. When the cutting speed and feed rate were increased, the rubbing action
would be more faster and enormous heat will be generated even though there
was less contact time between tool and work piece. The generation of heat at
flank side rubs the edge and more wear occurred. Increase in cutting speed
causes the faster tool wear and leads to reduction in the tool life. (Yisik 2007)
cutting forces and surface roughness. The authors found that the applied
tangential cutting force was very sensitive to the variation of depth of cut. It
was also observed that surface roughness was very sensitive to the variation
of feed rate and the flank wear had a great predominance on the evolution of
cutting force and on the criteria of surface roughness.
Ishan shah & Kishore (2012) optimized tool life by using design of
experiment to develop model for end milling process that used solid carbide
flat end mill as the cutting tool and stainless steels SS304 as work material.
For conducting the experiments, CNC milling machine was used. The inputs
of the model are feed rate, cutting speed and depth of cut while the output
odel
was validated by the experimental values compared with their predicted
counterparts.
turning. This procedure develops the best set of turning conditions to be used
in tool life tests which results in a rapid confluence of the coefficients and
their corresponding confidence intervals. This technique was compared with
the conventional fractional factorial design during face milling operation of
AISI 1045 steel with cemented carbide cutting tools. The results revealed a
considerable reduction in the number of tests when the optimum experimental
procedure was used when compared to the fractional factorial design.
increase of feed rate and it reduces the surface roughness with the increase of
cutting speed.
Lee & Tarng (2000) proposed the optimal cutting parameters for
maximizing production rate or minimizing production cost in multistage
turning operations. A machining model was constructed based on a
polynomial network. It can learn the relationships between turning parameters
and output responses by means of a self-organizing adaptive modeling
technique. The optimal cutting parameters were subjected to an objective
function of maximum production rate or minimum production cost with the
constraints of a permissible limit of surface roughness and cutting force and a
feasible range of cutting parameters.
Sing & Kumar (2006) used Taguchi's parameter design approach for
optimizing the feed force when turning EN24 steel using TiC coated tungsten
carbide inserts as cutting tool. They determined the optimal values of turning
process parameters. The authors concluded that the depth of cut and feed rate
have more significant effect on feed force when comparing with the cutting
speed. Thamizhmanii et al (2007) utilized Taguchi method for finding out the
47
optimal value of surface roughness when turning SCM 440 alloy steel. Using
Taguchi method they designed the experiments and the obtained results
thereof were analyzed with the help of analysis of variance. The causes for
poor surface finish were detected as tool chattering and machine tool
vibrations. It was found that depth of cut was the only predominant factor
which affects the surface roughness.
The obtained experimental results were used in the gray relational analysis
and the weight of the output quality characteristics were determined by the
entropy measurement method. Based on the optimization results, pulse
pulse
optimal combination of the analysis.
interfaced with the genetic algorithm to find the optimal turning parameter
values.
Abolfazl et al (2010) founded that the net energy stored and the
discharge time of phase change material in a solar system, were the important
conflicting objectives to be optimized simultaneously. Multi objective genetic
algorithms were used for pareto approach optimization of a solar system using
modified NSGA-II algorithms. The competing objectives like net energy
stored, discharge time and design variables are some geometrical parameters
of solar system. It was shown that some interesting and important
relationships as useful optimal design principles involved in the performance
of solar system can be discovered.
From the above literatures, it is clear that most of the researchers studied
the micro structure analysis, surface integrity, welding fatigue performance,
corrosion properties and applications of super duplex stainless steel. However,
further machinabilty studies on super duplex stainless steel are required to improve
the machining performances. Considering these requirements, the experiment was
carried out to study the effects of machining parameters on the output responses
like surface roughness, flank wear, cutting zone temperature and cutting force
under different machining conditions namely dry, wet and gas cooled operations.
The work material is machined without using any coolant or cutting oil
in dry machining. The water soluble cutting oil, which gets mixed with water is
used as coolant in wet machining. The liquid CO2 is used as coolant in case of gas
cooled machining. The importance and advantages of using liquid CO2 as coolant
instead of cutting oils when machining super duplex stainless steel are discussed in
the coming chapters. At present, the water soluble cutting oils are generally used
during machining in shop floor. Based on the obtained experimental results, the
gas cooled machining is found to be superior than the dry and wet machining.
temperature and cutting force. The benefits of gas cooled machining over dry and
wet machining in terms of output responses are discussed in results and discussion
chapter elaborately. Thus the outcomes of this research work can be effectively
used in Industrial applications for machining of super duplex stainless steel.
This study also obtains a mathematical model that relates the surface
roughness, Flank wear, Cutting zone Temperature and Cutting force. The
cutting speed, feed rate and depth of cut are considered as the process
parameters in this research work. Turning operations are widely used in
workshop practice for applications carried out in conventional machine tools,
as well as in NC and CNC machine tools, machining centers and related
manufacturing system.
and methodology
the details of the work material, cutting tool, experimental set up carried out
in this research. The experimental conditions and results for machining
characteristics of Super duplex stainless steel with different conditions of
machining such as, dry, wet and gas cooled machining are discussed.
62
and Recommendations
contribution, limitations and future scope of this research work. The content
of the entire thesis is summarized in this chapter.
