Computer Networks LAB

Lab Report

Name Muhammad Hamad

Roll no BSSE-sp-22-040

Section B

Instructor Ma’am Tayyabah Hasan

Static Routing:

Step 1: Topology

Step 2: Add HWIC to routers

Select each router (R0 R4) and click on it open its configuration window , Click on Physical tab.
Switch off the port
Select HWIC 2T , Insert Module.
Now on the port
Repeat this process for All routers inlove in:
Step 3:
Assign IP addresses and write their Subnet Mask and
Default Gateway

Router/Device IP Address Subnet Mask Default Gateway

LAN1 192.168.1.0
Laptop0 192.168.1.1 255.255.255.0 192.168.1.4
Laptop1 192.168.1.2 255.255.255.0 192.168.1.4
Laptop2 192.168.1.3 255.255.255.0 192.168.1.4
Router0 192.168.1.4 255.255.255.0

LAN2 192.168.2.0 -
PC08 192.168.2.1 255.255.255.0 192.168.2.3
PC9 192.168.2.2 255.255.255.0 192.168.2.3
Router1 192.168.2.3 255.255.255.0

LAN3 192.168.3.0

PC10 192.168.3.1 255.255.255.0 192.168.3.3

PC11 192.168.3.2 255.255.255.0 192.168.3.3
Router4 192.168.3.3 255.255.255.0

LAN4 192.168.4.0
Laptop3 192.168.4.1 255.255.255.0 192.168.4.3
Laptop4 192.168.4.2 255.255.255.0 192.168.4.3
Router3 192.168.4.3 255.255.255.0

Step 4: IP Addresses Configuration

End Devices:
select end device for configuration
interface open
click on config
Port Status on
select fast ethernet 0/0
input ipv4:
subnet mask:
Repeat this process for all devices
and Routers.
Step 5: Connectivity Router to Router
Select a wire Copper straight wire

Routers:
Router Interface IP Address
1841 Router0 GigabitEthernet0/0 192.168.1.4
FA0/1/0 10.0.0.1
Fa0/1/1 11.0.0.1
1841 Router1 GigabitEthernet0/0 192.168.2.3
Fa0/1/0 10.0.0.2
Fa0/1/1 12.0.0.1
1841 Router2 GigabitEthernet0/0 192.168.3.3
Fa0/0/0 12.0.0.2
Fa0/0/1 13.0.0.2
Fa0/1/0 15.0.0.1
1841 Router3 GigabitEthernet0/0 192.168.4.3
Fa0/1/0 14.0.0.2
Fa0/1/1 15.0.0.2
1841 Router4 Serial0/0/0 11.0.0.2
Fa0/0/1 13.0.0.1
Fa0/1/0 14.0.0.1

Step 6: Static Routing:

interface:
 Router Destination Network Next Hop IP
1841 Router0 192.168.2.0/24 10.0.0.2
192.168.2.0/24 11.0.0.2
192.168.3.0/24 10.0.0.2
192.168.3.0/24 11.0.0.2
192.168.4.0/24 10.0.0.2
192.168.4.0/24 11.0.0.2
1841 Router1 192.168.1.0/24 10.0.0.1
192.168.3.0/24 10.0.0.1
192.168.4.0/24 10.0.0.1
192.168.1.0/24 12.0.0.2
192.168.3.0/24 12.0.0.2
192.168.4.0/24 12.0.0.2
1841 Router2 192.168.1.0/24 12.0.0.1
192.168.2.0/24 12.0.0.1
192.168.4.0/24 12.0.0.1
192.168.1.0/24 13.0.0.1
192.168.2.0/24 13.0.0.1
192.168.4.0/24 13.0.0.1
192.168.1.0/24 15.0.0.2
192.168.2.0/24 15.0.0.2
192.168.4.0/24 15.0.0.2
1841 Router3 192.168.1.0/24 13.0.0.1
192.168.3.0/24 13.0.0.1
192.168.2.0/24 13.0.0.1
192.168.1.0/24 15.0.0.2
192.168.3.0/24 15.0.0.2
192.168.2.0/24 15.0.0.2
1841 Router5 192.168.1.0/24 11.0.0.1
192.168.2.0/24 11.0.0.1
192.168.3.0/24 11.0.0.1
192.168.4.0/24 11.0.0.1
192.168.1.0/24 13.0.0.2
192.168.2.0/24 13.0.0.2
192.168.3.0/24 13.0.0.2
192.168.4.0/24 13.0.0.2
192.168.1.0/24 14.0.0.2
192.168.2.0/24 14.0.0.2
192.168.3.0/24 14.0.0.2
192.168.4.0/24 14.0.0.2
Communication:
