CANON LENS CHART
3.5
.80

40
72
0

2,8
°
72

For Canon cameras with 1:6 sensor 1,7

0
5
40

14
3.1

2.9

0
,36
39

02
1,2
35
2,8
5.1
85

TYPE 2
 Canon Type 2 lens chart

4" Dome port lens chart (#18410) OPTIONAL ACCESSORIES

* Neoprene dome cover # 18508 included with port PORT DOME

GEARS PORT LOCKING DOME SHADE REAR PORT

Camera lens Zoom Focus EXTENSION COLLAR SHADE COVER COVER

Canon EF 8-15mm f/4L USM FISHEYE *(1) 19001 AF Only 18463 N/R Built-In Included 18790
Canon EF 15mm f/2.8 Fisheye *(2)
Sigma 10mm f/2.8 EX DC HSM Fisheye *(3)
Sigma 15mm f/2.8 EX DG Fisheye *(3)
Tokina AT-X 10-17mm f/3.5-4.5 AF DX Fisheye 18717 AF Only 18456 N/R Built-In Included 18790
Tokina AT-X 10-17mm f/3.5-4.5 AF DX Fisheye + 1.4x TC 17831 AF Only 18453 N/R Built-In Included 18790

*(1) This port has a built-in shade that prevents using the whole zoom range of this circular fisheye lens
*** It is possible, by special request, to order this dome port with the shade machined off ***
*(2) This lens does not focus close enough to be used with this dome port.
*(3) The protubing length of this lens shade prohibits using it with this dome port, damages could results to the internal surface of the dome lens
N/R = Not Required Revised September 10, 2014

6" Dome port lens chart (#18409) OPTIONAL ACCESSORIES

* Neoprene dome cover # 18502 included with port PORT DOME

GEARS PORT LOCKING DOME SHADE REAR PORT

Camera lens Zoom Focus EXTENSION COLLAR SHADE COVER COVER
Canon EF 15mm f/2.8 Fisheye N/R 18702 N/R N/R 18484 18504 18790
Canon EF 20mm f/2.8 N/R AF only 18456 18469 18484 18504 18790
Canon EF 24mm f/1.4L II USM N/R 19002 18456 18469 18484 18504 18790
Canon EF 8-15mm f/4L USM FISHEYE 19001 AF only 18463 18469 N/R N/R 18790
Canon EF-S 10-22mm f/3.5-4.5 USM 18706 AF only 18453 18469 18484 18504 18790
Sigma 4.5mm f/2.8 EX DC HSM Circular Fisheye N/R AF only 18456 18469 N/R N/R 18790
Sigma 8mm F3.5 EX DG Circular Fisheye N/R AF only 18456 18469 N/R N/R 18790
Sigma 10mm f/2.8 EX DC HSM Fisheye N/R AF only N/R N/R 18484 18504 18790
Sigma 10-20mm f/3.5 EX DC HSM 18770 AF only 18453 18469 18484 18504 18790
Sigma 10-20mm f/4-5.6 EX DC HSM 18698 AF only 18453 18469 18484 18504 18790
Sigma 15mm F2.8 EX DG Fisheye N/R 18715 N/R N/R 18484 18504 18790
Sigma 17-70mm f/2.8-4 DC MACRO (HSM OS) 18719 AF only 18462 18469 18484 18504 18790
Sigma 17-70mm f/2.8-4 DC MACRO (HSM OS) © Contemporary *(1) 19008 AF only 18457 18469 18484 18504 18790
Tokina AT-X 10-17mm f/3.5-4.5 AF DX Fisheye 18717 AF only 18456 18469 18484 18504 18790
Tokina AT-X 10-17mm f/3.5-4.5 AF DX Fisheye + 1.4x TC 18731 AF only 18456 18469 18484 18504 18790

(1) There are multiple versions of this lens, please confirm that your lens fits this description
N/R = Not required Revised September 10, 2014

http://www.aquatica.ca/en/charts/canon_type_2.pdf
 Canon Type 2 lens chart

8" Dome port lens chart (#18405) OPTIONAL ACCESSORIES

* Neoprene dome cover # 18500 included with port Port Dome REAR PORT

Gears Port Locking Dome Shade Port

Camera lens Zoom Focus Extension Collar Shade Cover Cover

Canon EF 14mm f/2.8 L TYPE II USM N/R 18771 18462 18469 18480 18503 18790
Canon EF 14mm f/2.8 L OLDER TYPE N/R AF only 18453 18469 18480 18503 18790
Canon EF 15mm f/2.8 Fisheye N/R 18702 N/R N/R 18480 18503 18790
Canon EF 20mm f/2.8 N/R AF only 18456 18469 18480 18503 18790
Canon EF 24mm f/1.4L II USM N/R 19002 18456 18469 18480 18503 18790
Canon EF 8-15mm f/4L USM FISHEYE 19001 AF only 18463 18469 N/R N/R 18790
Canon EF-S 10-22mm f/3.5-4.5 USM 18706 AF only 18453 18469 18480 18503 18790
Canon EF-S 15-85 mm f/3.5-5.6 IS USM 18730 AF only 18458 18469 18480 18503 18790
Canon EF 16-35 mm f/2.8 L II USM 18708 AF only 18457 18469 18480 18503 18790
Canon EF 16-35 mm f/2.8 L II USM *(2) 18708 19064(2) 18464(2) 18469 18480 18503 18790
Canon EF 17-40mm F/4L USM 18708 AF only 18457 18469 18480 18503 18790
Canon EF 17-40mm F/4L USM *(2) 18708 19065(2) 18465 (2) 18469 18480 18503 18790
Canon EF-S 17-85mm f/4-5.6 IS 18707 AF only 18453 18469 18480 18503 18790
Canon EF-S 18-55mm f/3.5-5.6 USM 18703 AF only 18456 18469 18480 18503 18790
Canon EF 24-105mm f/4L USM *(1) 18700.1 AF only 18458 18469 18480 18503 18790
Canon EF 24-70mm f/2.8L USM (older type) *(3) 18723 AF only 18458 18469 18480 18503 18790
Canon EF 24-70mm f/2.8L USM Type II (newer type) 19004 AF only 18458 18469 18480 18503 18790
Sigma 4.5mm f/2.8 EX DC HSM Circular Fisheye N/R AF only 18456 18469 N/R N/R 18790
Sigma 8mm F3.5 EX DG Circular Fisheye N/R AF only 18456 18469 N/R N/R 18790
Sigma 10mm F2.8 EX DC HSM Fisheye N/R AF only N/R N/R 18480 18503 18790
Sigma 10-20mm f/3.5 EX DC HSM 18770 AF only 18453 18469 18480 18503 18790
Sigma 10-20mm f/4-5.6 EX DC HSM 18698 AF only 18453 18469 18480 18503 18790
Sigma 14mm F2.8 EX ASPHERICAL HSM N/R AF only 18462 18469 18480 18503 18790
Sigma 15mm F2.8 EX DG FISHEYE N/R 18715 N/R N/R 18480 18503 18790
Sigma 17-70mm f/2.8-4 DC MACRO (HSM OS) *(4) 18719 AF only 18462 18469 18480 18503 18790
Sigma 17-70mm f/2.8-4 DC MACRO (HSM OS) © *(4) 19008 AF only 18457 18469 18480 18503 18790
Tokina AT-X 10-17mm f/3.5-4.5 AF DX Fisheye 18717 AF only 18456 18469 18480 18503 18790
Tokina AT-X 11-16mm f/2.8 AF PRO DX 18722 AF only 18453 18469 18480 18503 18790
Tokina AT-X 12-24mm f/4 AF pro DX 18722 AF only 18453 18469 18480 18503 18790

*(1) This lens requires a + 3 diopter to focus on the virtual image of the dome.
*(2) This port extension has a manual focusing knob and is supplied with a focus gear for that specific lens.
*(3) Compatible with 5D Mk II (# 20062) housings only.
*(4) There are multiple versions of this lens, please confirm that your lens fits this description.
N/R = Not Required Revised September 10, 2014

http://www.aquatica.ca/en/charts/canon_type_2.pdf
 Canon Type 2 lens chart

9.25" Dome port lens chart (#18407) OPTIONAL ACCESSORIES

* Neoprene dome cover # 18506 included with port Port Dome Rear

Gear Port Locking Dome Shade Port

Camera lens Zoom Focus Extension Collar Shade Cover Cover

Canon EF 14mm f/2.8 L TYPE II USM N/R 18771 18462 18469 18790
Canon EF 14mm f/2.8 L OLDER TYPE N/R AF only 18453 18469 18790
Canon EF 15mm f/2.8 Fisheye N/R 18702 N/R N/R 18790
Canon EF 20mm f/2.8 N/R AF only 18456 18469 18790
Canon EF 24mm f/1.4L II USM N/R 19002 18456 18469 18790
Canon EF 8-15mm f/4L USM FISHEYE (1) 19001 AF only 18463 18469 18790
Canon EF-S 10-22mm f/3.5-4.5 USM 18706 AF only 18453 18469 18790
Canon EF-S 15-85 mm f/3.5-5.6 IS USM 18730 AF only 18458 18469 18790

18506 (included)
Canon EF 16-35 mm f/2.8 L II USM 18708 AF only 18457 18469 18790

INTEGRATED
Canon EF 16-35 mm f/2.8 L II USM *(2) 18708 19064(2) 18464(2) 18469 18790
Canon EF 17-40mm F/4L USM 18708 AF only 18457 18469 18790
Canon EF 17-40mm F/4L USM *(2) 18708 19065(2) 18465 (2) 18469 18790
Canon EF-S 17-85mm f/4-5.6 IS 18707 AF only 18453 18469 18790
Canon EF-S 18-55mm f/3.5-5.6 USM 18703 AF only 18456 18469 18790
Canon EF 24-105mm f/4L USM *(3) 18700.1 AF only 18458 18469 18790
Canon EF 24-70mm f/2.8L USM (older type) *(4) 18723 AF only 18458 18469 18790
Canon EF 24-70mm f/2.8L USM Type II (newer type) 19004 AF only 18458 18469 18790
Sigma 10mm F2.8 EX DC HSM Fisheye N/R AF only N/R N/R 18790
Sigma 10-20mm f/3.5 EX DC HSM 18770 AF only 18453 18469 18790
Sigma 10-20mm f/4-5.6 EX DC HSM 18698 AF only 18453 18469 18790
Sigma 14mm F2.8 EX ASPHERICAL HSM N/R AF only 18462 18469 18790
Sigma 15mm F2.8 EX DG FISHEYE N/R 18715 N/R N/R 18790
Sigma 17-70mm f/2.8-4 DC MACRO (HSM OS) *(5) 18719 AF only 18462 18469 18790
Sigma 17-70mm f/2.8-4 DC MACRO (HSM OS) © *(5) 19008 AF only 18457 18469 18790
Tokina AT-X 10-17mm f/3.5-4.5 AF DX Fisheye 18717 AF only 18456 18469 18790
Tokina AT-X 11-16mm f/2.8 AF PRO DX 18722 AF only 18453 18469 18790
Tokina AT-X 12-24mm f/4 AF pro DX 18722 AF only 18453 18469 18790

*(1) This port has an integrated dome shade that will limit the usable zoom range of this circular fisheye lens
*(2) This port extension has a manual focusing knob and is supplied with a focus gear for that specific lens.
*(3) This lens requires a + 3 diopter to focus on the virtual image of the dome
*(4) Compatible with 5D Mk II (# 20062) housings only
*(5) There are multiple version of this lens, please confirm that your lens actually fits this description
Revised September 10, 2014

http://www.aquatica.ca/en/charts/canon_type_2.pdf
 Canon Type 2 lens chart

** This port is equipped with a manual focusing knob **

AF/MF Macro Port (#18426) OPTIONAL ACCESSORIES

* Neoprene front cover # 18505 included with port Gear Neoprene Replacement lens rear

Camera lens Focus extension cover Acrylic BK7a glass cover

Canon EF 50mm f/2.5 18705 18453 18582 18583 18790

(included)
Canon EF-S 60mm f/2.8 18710.1 N/R 18582 18583 18790

18505
Canon EF 100mm f/2.8 18700.1 18453 18582 18583 18790
Canon EF 100mm f/2.8L IS USM 18700.1 18453 18582 18583 18790
Sigma 50mm F2.8 EX Macro AF Only 18453 18582 18583 18790

AF Macro Port (#18428) OPTIONAL ACCESSORIES

* Neoprene front cover # 18505 included with port gear Neoprene Replacement lens Rear
Camera lens Focus Extension cover Acrylic BK7a glass Cover
Canon EF 50mm f/2.5 AF Only 18453 18582 18583 18790

(included)
Canon EF-S 60mm f/2.8 18710.1 N/R 18582 18583 18790
18505
Canon EF 100mm f/2.8 AF Only 18453 18582 18583 18790
Canon EF 100mm f/2.8L IS USM AF Only 18453 18582 18583 18790
Sigma 50mm F2.8 EX Macro AF Only 18453 18582 18583 18790

AF Low Profile Macro Port (#18429) OPTIONAL ACCESSORIES

* Neoprene front cover # 18508 included with port Gear Neoprene Replacement lens Rear
Camera lens Focus Extension cover Acrylic BK7a glass Cover
(included)

Canon EF-S 60mm f/2.8 18710.1 N/R 18582 18583 18790

18508

Canon EF 100mm f/2.8 AF Only 18458 18582 18583 18790

Canon EF 100mm f/2.8L IS USM AF Only 18458 18582 18583 18790

Revised September 10, 2014
