Swaging is a metalworking process that uses dies to form shapes by hammering or pressing. Swaging machines have rolls or dies that shape metal stock into cylindrical objects. Common shapes produced include stiffeners, reinforcements, and ornamentation. Rotary swaging machines have special rolls that shape the metal through rotation. The main components are handling shafts, aprons, swages or rolling dies, and a protective casing frame. Power-operated machines add components like pulleys, motors, and gearing. Swaging can produce shapes like corrugations or widen diameters using different types of rolling wheels. More advanced machines include automated feeding systems, machine bases, mandrels, and computer controls.
Original Description:
This document is written by Addis Ababa Science and Technology University student.
Swaging is a metalworking process that uses dies to form shapes by hammering or pressing. Swaging machines have rolls or dies that shape metal stock into cylindrical objects. Common shapes produced include stiffeners, reinforcements, and ornamentation. Rotary swaging machines have special rolls that shape the metal through rotation. The main components are handling shafts, aprons, swages or rolling dies, and a protective casing frame. Power-operated machines add components like pulleys, motors, and gearing. Swaging can produce shapes like corrugations or widen diameters using different types of rolling wheels. More advanced machines include automated feeding systems, machine bases, mandrels, and computer controls.
Swaging is a metalworking process that uses dies to form shapes by hammering or pressing. Swaging machines have rolls or dies that shape metal stock into cylindrical objects. Common shapes produced include stiffeners, reinforcements, and ornamentation. Rotary swaging machines have special rolls that shape the metal through rotation. The main components are handling shafts, aprons, swages or rolling dies, and a protective casing frame. Power-operated machines add components like pulleys, motors, and gearing. Swaging can produce shapes like corrugations or widen diameters using different types of rolling wheels. More advanced machines include automated feeding systems, machine bases, mandrels, and computer controls.
French word "souage" to mean "ornamental groove”. Swaging are used for shaping of a metal item Swaging is accomplished by hammering the metal stock while it is held on the anvil within any one of various concave tools called swages. Swages are formed on cylindrical objects to serve as Stiffeners Reinforcement Ornamentation The standard shapes of swage are the single swage Ogee(double curve) swage Triple swage The swaging process will have two categories the extrusion and the swaging machine which is rotary machine equipped with special swaging rolls. In sheet metal technology mostly we use rotary machine. The machine may be either hand or power operated. The handling shaft; apron, swages or rolling die tool and the casing frame are the main part in hand operating. While in power operate machine there will be a pulley that connects the shaft with the motor and transfer motion .The motor can also be listed as a part of the machine. Gear system will also be used if the machine supports speed changing mechanisms. Types of Rolling Wheels types Crimping: - This wheel has a structure of a gear and used to make a corrugated shape on the sheet metal. This method is used to make one side of the metal shortened than the other side. So that our sheet metal can be connect to other sheet metal if it is in a pipe form. Jogging:-This roll is used when it is needed to widen a diameter of some extent of cylindrical metal. To make other metal to fit in to it. As the machine advance and becomes in industrial level it will use additional tools. To list some Feeding system: - as the area of operation advances it will be tire some to hold and wait until the process is complete. So an automated feed system can be applies that can supply a metal when the prior process is complete. Machine Base: - Some computer programmed switches will be attached to the machine base like that controls the feed system. In addition to this the machine can get its best support from this base. Mandrel device: A hydraulic device which is used to push the metal which is feed to the rolls. Controls: - CNC systems can be installed as an operating mechanism. The Basic Operation with Rolling Swaging SWAGING A WIDE DIAMETER PIPE. The sheet metal can be in the form of a wide pipe. And if it is need to do A line on sheet metal opening rolls by loosening top roll adjusting screw. SWAGING CYLINDERICAL WITH FULL GROOVED JOINTS SWAGE MALE AND FEMALE OPERATION:– The male and female method in the sheet metal is used to join different sheet metal by making the first sheet metal on the second one to join them together. The swages might be in joined internal or external swage Depending on the process which is going to be used in the manufacturing step. When the two sections of the metals are assembled together the male swage sits neatly into the female swage forming an interlocking joint. An allowance of Material usually 3 to 5 mm must add to the length of the metal to allow for each swage.
