Lecture 01
Lecture 01
Assistant Professor
Introduction
Support Reactions.
The surface forces that develop at the
supports or points of contact between
bodies are called reactions. For two-
dimensional problems, i.e., bodies subjected
to coplanar force systems, the supports
most commonly encountered are shown in
Fundamentals of Engineering
Mechanics
Fundamentals of Engineering
Mechanics
As a general rule, if support prevents
translation in a given direction, a force must
be developed on the member in that
direction. Likewise, if rotation is prevented, a
couple moment must be exerted on the
member. For example, roller support only
prevents translation normal to the surface.
Hence, the roller exerts a normal force on
the member at its point of contact. Since
member can freely rotate about roller, a
couple moment can not be developed on the
Fundamentals of Engineering
Mechanics
Equations of Equilibrium.
Equilibrium of a body requires both a
balance of forces, to prevent the body from
translating or having accelerated motion
along a straight or curved path, and a
balance of moments, to prevent the body
from rotating. These conditions can be
expressed mathematically by two vector
equations
Fundamentals of Engineering
Mechanics
Here, ∑F represents the sum of all the
forces acting on the body, and ∑M o is the
sum of the moments of all the forces about
any point O either on or off the body. If an x,
y, z coordinate system is established with
the origin at point O, the force and moment
vectors can be resolved into components
along each coordinate axis and the above
two equations can be written in scalar form
as six equations, namely,
Fundamentals of Engineering
Mechanics
• Establish x, y
and z axis at
origin O and
split the
resultant into
respective
components.
Analysis of Internal Forces
Vx, Vy Shear Force
Nz Normal Force
Mx, My Bending Moment
Tz Torsion
OR
What is Strength?
STRESS
OR
a) free-body diagram of a
segment of the bar,
Example:
• If two bars of same
length and different
cross-sectional areas are
subjected to different
loading, load carrying
capacity of a bar cannot
be justified by the
amount of load being
carried by any bar.
STRESS
• If we see the dispersion of load on respective
cross-sections we will find a common factor
of comparison for which bar is stronger than
the other. This common factor is Stress
denoted by σ.
Therefore,
w = 180 N/m
STRESS
2). Free-Body Diagram.
The magnitude of the resultant of the
distributed load is equal to the area under the
loading curve (triangle) and acts through the
centroid of this area.
Which acts at
from C
STRESS
3). Equations of Equilibrium.
Applying the equations of equilibrium we
have
Solution:
1). Support Reactions.
Let us consider the segment AC and
compute the reaction at A
STRESS
Solution:
In order to determine the stress in each
segment, find out the axial load at each
section.
(Tension)
(Compression)
STRESS
Applying the stress equation;
STRESS
Solving simultaneously,
STRESS
Now;
For AB;
For AC;
Problem Statement:
STRESS
Solution:
• The first step is to calculate the reaction at
supports.
STRESS
• Since Pin at A is subjected to double shear
and that at B is subjected to single shear.
STRESS
• Since
STRESS
• So we can select the bolt size nearest to
1/16, therefore
dA=7/16 in
dB=5/8 in
• Now the diameter of rod BC can be
determined by normal stress equation.
STRESS
So choose dBC=9/16in
STRESS
Problem Statement: Figure shows a W460
x 97 beam riveted to a W610 x 125
girder by 100x90x10mm angles with
19mm diameter rivets. There are two
angles, one on each side of the beam.
For each rivet, assume
= 80MPa and = 170MPa. The web
of the girder is 11.9mm thick, and the
web of the beam is 11.4mm thick.
Determine the allowable end reaction.
STRESS
STRESS
Solution:
• At the girder;
STRESS
• At the beam;
We Obtain
STRESS
Determination of the Normal Stress in Rod BC.
However, the flat parts of the rod are also under tension
and at the narrowest section, where a hole is located, we
have
