ARDUINO

SENSORS
 FINGERXPRINT SENSOR

• FINGERPRINT SCANNERS ARE SECURITY

SYSTEMS OF BIOMETRICS. THEY ARE USED TO
UNLOCK DOORS AND IN OTHER SECURITY
APPLICATIONS. DURING THE
2010S FINGERPRINT SCANNERS BECAME
COMMONPLACE ON MOBILE PHONES. PEOPLE
HAVE A PATTERN OF RIDGES ON THEIR FINGERS. ...
EVERY FINGERPRINT IS DIFFERENT FROM ANY
OTHER IN THE WORLD.
 JUAN VUCETICH
• ARGENTINE CHIEF POLICE OFFICER, CREATED
THE FIRST METHOD OF RECORDING THE
FINGERPRINTS OF INDIVIDUALS ON FILE,
ASSOCIATING THESE FINGERPRINTS TO THE
ANTHROPOMETRIC SYSTEM OF ALPHONSE BERTILLON,
WHO HAD CREATED, IN 1879

• FIRST CRIMINAL FINGERPRINT

IDENTIFICATION
 ANALOG CAPACITIVE SOIL MOI
STURE SENSOR- CORROSION RE
SISTANT
• THE ANALOG CAPACITIVE SOIL MOISTURE
SENSOR MEASURES SOIL MOISTURE LEVELS
BY CAPACITIVE SENSING, RATHER THAN
RESISTIVE SENSING LIKE OTHER TYPES OF MOISTURE
SENSOR. IT IS MADE OF A CORROSION RESISTANT
MATERIAL, GIVING IT A LONG SERVICE LIFE

• APPLICATION:
• GARDENING & FARMING
• MOISTURE DETECTION
• INTELLIGENT AGRICULTURE
 ANALOG FLAME SENSOR
• THE FLAME SENSOR CAN BE USED TO DETECT FIRE OR OTHER WAVELENGTH AT 760
NM ~ 1100 NM LIGHT. ... IT IS VERY EASY TO USE, YOU CAN USE IT WITH A PULL-UP
RESISTOR AND THE ARDUINO ANALOG PINS CAN GET ANALOG VALUE. YOU CAN
ALSO USE IT WITH OUR ANALOG TO DIGITAL MODULE TO OUTPUT DIGITAL VALUE.

• APPLICATIONS OF FLAME SENSORS

• HYDROGEN STATIONS
• COMBUSTION MONITORS FOR BURNERS
• OIL AND GAS PIPELINES
• AUTOMOTIVE MANUFACTURING FACILITIES
• NUCLEAR FACILITIES
• AIRCRAFT HANGARS
• TURBINE ENCLOSURES
 ANALOG SOUND SENSOR:

• IS TYPICALLY USED IN DETECTING THE

LOUDNESS IN AMBIENT, THE ARDUINO CAN
COLLECT ITS OUTPUT SIGNAL BY IMITATING THE
INPUT INTERFACE. YOU MAY USE IT TO MAKE
SOME FUNNY INTERACTIVE WORKS SUCH AS A
VOICE OPERATED SWITCH
Gravity: Analog UV Sensor V2

The Analog UV Sensor V2 with GUVA-S12SD

chip is suitable for detecting the UV radiation in
sunlight. It can be used in UV Index Monitoring,
DIY project, UV-A Lamp Monitoring, Plants
growing, Environmental monitoring, etc. It can
detect the UV wavelength of 200-370nm with a
quick response, linear analog voltage signal
output. Small size, easy to install.
Gravity: DHT11 Temperature and
Humidity Sensor

This DHT11 Temperature and Humidity Sensor

is powerful and easy to use! The DHT11 has a
full range temperature compensation, low power
consumption, long term stability and calibrated
digital signal. A high-performance 8-bit
microcontroller is integrated in the sensor with
calibration-coefficient saved in OTP memory to
provide accurate temperature readings. Reliable
and inexpensive with plenty of documentation
and projects online.
Grove - High Temperature Sensor

Thermocouples are very sensitive, requiring a

good amplifier with a cold-compensation
reference. The Grove - High Temperature
Sensor uses a K type thermocouple for
temperature detection, with a Thermistor to
detect the ambient temperature, used as a cold-
compensation reference. The detectable range
of this Sensor is -50℃ to 600℃ (-58ºF to
1112ºF), and the accuracy is rated at ±(2.0% +
2℃).
Light Sensor 1000 lux

Product Specifications Sensor Output Type:

Non-Ratiometric Response Time Max:2ms
Peak Sensitivity Wavelength:625 nm Light
Level Min:1 lux Light Level Max(5v): 1000 lux
Light Current Ratio:1.2 Device Current
Consumption: 5 mA Output Impedance: 1K
ohms Bandwidth / Reaction Time: 50 Hz
Minimum / Maximum Voltage: 2.4VDC to
5.5VDC
Operating Temp Min:-40° Operating Temp
Max:85° T
 LIGHT SENSOR

• LIGHT SENSOR INTEGRATES A PHOTO-RESISTOR(LIGHT

DEPENDENT RESISTOR) TO DETECT THE INTENSITY OF
LIGHT. THE RESISTANCE OF PHOTO-RESISTOR
DECREASES WHEN THE INTENSITY OF LIGHT INCREASES

• USES / PURPOSE OF GROVE – LIGHT SENSOR : THIS

MODULE CAN BE USED TO BUILD A LIGHT CONTROLLED
SWITCH I.E. SWITCH OFF LIGHTS DURING DAY TIME AND
SWITCH ON LIGHTS DURING NIGHT TIME.
 GROVE TEMPERATURE AND HUMIDITY
SENSOR
• THIS SENSOR PROVIDES A PRE-CALIBRATED
DIGITAL OUTPUT. IT IS ALSO MULTIFUNCTIONAL
SENSOR THAT GIVES YOU TEMPERATURE AND
RELATIVE HUMIDITY INFORMATION AT THE SAME
TIME. IT UTILIZES A DHT11 SENSOR THAT CAN
MEET MEASUREMENT NEEDS OF GENERAL
PURPOSES. IT PROVIDES RELIABLE READINGS
WHEN ENVIRONMENT HUMIDITY CONDITION IN
BETWEEN 20% RH AND 90% RH
 PHIDGETS PRECISION TEMPERATURE SENSOR

• - THE TEMPERATURE SENSOR COMPONENT IS

RATED AT -50°C TO +150°C, BUT THE OTHER
COMPONENTS ON THE BOARD, THE
CONNECTOR AND THE CABLE ARE RATED AT -
30°C TO +80°C.

• USES / PURPOSE OF PHIDGETS PRECISION

TEMPERATURE SENSOR : THIS PRECISION
TEMPERATURE SENSOR HAS A LARGE RANGE
AND A TYPICAL ERROR OF ±0.75 DEGREES
CELSIUS IN THE 0°C TO 80°C RANGE. A 60CM
SENSOR CABLE IS INCLUDED.
 THE GROVE -
SPECIFICATIONS
TEMPERATURE
SENSOR • VOLTAGE: 3.3 ~ 5V
• ZERO POWER RESISTANCE: 100 KΩ
• RESISTANCE TOLERANCE: ±1%
• OPERATING TEMPERATURE RANGE: -40 ~
+125 ℃
• NOMINAL B-CONSTANT: 4250 ~ 4299K
• RANGE: -40 - 125ºC
• ACCURACY: ±1.5ºC
 THE GROVE -
TEMPERATURE USES
SENSOR USES A THERMISTOR TO DETECT THE
AMBIENT TEMPERATURE. THE RESISTANCE OF
A THERMISTOR WILL INCREASE WHEN THE
AMBIENT TEMPERATURE DECREASES. IT'S
THIS CHARACTERISTIC THAT WE USE TO
CALCULATE THE AMBIENT TEMPERATURE.
 GROVE -
ALCOHOL
SENSOR
SPECIFICATIONS
• INPUT VOLTAGE: 5V
• WORKING CURRENT: 120MA
• DETECTABLE CONCENTRATION: 20-1000PPM
 USES
GROVE - A COMPLETE ALCOHOL SENSOR MODULE FOR
ALCOHOL ARDUINO OR SEEDUINO. IT IS BUILT WITH
SENSOR MQ303A SEMICONDUCTOR ALCOHOL SENSOR.
IT HAS GOOD SENSITIVITY AND FAST
RESPONSE TO ALCOHOL. IT IS SUITABLE FOR
MAKING BREATHALYZER. THIS GROVE
IMPLEMENTS ALL THE NECESSARY CIRCUITRY
FOR MQ303A LIKE POWER CONDITIONING AND
HEATER POWER SUPPLY. THIS SENSOR
OUTPUTS A VOLTAGE INVERSELY
PROPORTIONAL TO THE ALCOHOL
CONCENTRATION IN AIR.
PHIDGET SOUND
SENSOR
SPECIFICATIONS
• VOLTAGE INPUT (0-5V)
• SOUND LEVEL 50 DB - 100 DB
• SOUND FREQUENCY 100 HZ - 8 KHZ
• SOUND RESOLUTION:0.16 DB
• SOUND ERROR (AT 1000 HZ):± 3 DB
PHIDGET SOUND
SENSOR USES
MEASURES SOUND PRESSURE LEVEL FROM
50DB TO 100DB. THIS SENSOR IS TUNED TO
MEASURE IN THE FREQUENCY RANGE 100HZ
TO 8KHZ. OUTSIDE THIS RANGE THE SENSOR'S
BANDPASS FILTER WILL DRASTICALLY
REDUCE THE IMPACT ON THE MEASURED
QUANTITY.
 PHIDGET
SPECIFICATIONS
TEMPERATURE
SENSOR IR • FIELD OF VIEW:10°
• AMBIENT TEMPERATURE: 0°C -70 °C
• AMBIENT TEMPERATURE RESOLUTION: 0.02
°C
• OBJECT TEMPERATURE:-70 °C - 380 °C
• CONSUMPTION:27 MA
 USES

PHIDGET AN INTELLIGENT NON-CONTACT

TEMPERATURE SENSOR WITH A 10° FIELD OF
TEMPERATURE VIEW AND A USB INTERFACE FOR EASY
SENSOR IR CONNECTION TO YOUR COMPUTER. IT TAKES
AN AVERAGE OF THE TEMPERATURE OF
OBJECTS PLACED WITHIN ITS CONE OF
DETECTION.
THE 1045 OUTPUTS A CONTINUOUS DATA
FLOW EVERY 32MS WITH AN ACTIVE ALARM
RUNNING IN THE BACKGROUND.; THE
TEMPERATURE OUTPUT DATA FOR DISTANT
OBJECTS RANGES FROM -70°C TO 380°C.
 PHIDGET DIFFERENTIAL GAS PRESSURE
SENSOR

• THE 1126 DIFFERENTIAL PRESSURE SENSOR IS A DUAL

PORTED AIR PRESSURE SENSOR THAT MEASURES THE
PRESSURE DIFFERENCE BETWEEN THE TWO PORTS. IT CAN
MEASURE BOTH POSITIVE AND NEGATIVE PRESSURE FROM –
25KPA TO +25 KPA.

• USES - THIS SENSOR IS DESIGNED TO MEASURE THE

PRESSURE OF CLEAN, NON-CONDENSING AIR. WHILE THE
MEDIA RESISTANT GEL DOES ENABLE THE SENSOR TO BE
USED IN A WIDER VARIETY OF ENVIRONMENTS, THE
LIFESPAN OF THE SENSOR COULD STILL BE AFFECTED
 PHIDGETS HUMIDITY & TEMPERATURE
SENSOR

• THE PHIDGETS HUMIDITY/ TEMPERATURE

SENSOR MEASURES RELATIVE HUMIDITY
FROM 10% TO 95% WITH A TYPICAL ERROR OF
±2% RH AT 55% RH. THE TEMPERATURE
SENSOR COMPONENT IS RATED AT -40º C TO
+100º C, BUT THE OTHER COMPONENTS ON
THE BOARD, THE CONNECTOR AND THE
CABLE ARE RATED AT -30º C TO +80º C.
 PHIDGETS
TEMPERATURE
SENSOR 4-INPUT
 CONNECT UP TO FOUR THERMOCOUPLES TO THIS
BOARD TO MEASURE THE TEMPERATURE OF FOUR
DIFFERENT OBJECTS. PLUGS DIRECTLY INTO A USB
PORT. THERMOCOUPLES ARE WIDELY USED TO
MEASURE EXTREME TEMPERATURES IMPOSSIBLE
TO MEASURE WITH OTHER TYPES OF SENSORS. J, K,
E AND T THERMOCOUPLES ARE DIRECTLY
SUPPORTED IN THE LIBRARY AND RETURN THE
MEASURED TEMPERATURE IN °C.
Getting Started
Welcome to the 1048 user guide! In order to get started, make
sure you have the following hardware on hand:
 1048 Phidget TemperatureSensor 4-Input
 USB Cable and computer
 Thermocouple
Next, you will need to connect the pieces:

1. Connect the thermocouple to one of the inputs on the

Phidget TemperatureSensor. The datasheet or product
page for the thermocouple should tell you which wire
is positive and which is negative.
2. Connect the Phidget to your computer using the USB
cable.

Using the 1048

Phidget Control Panel
In order to demonstrate the functionality of the 1048, the
Phidget Control Panel running on a Windows machine will be
used.
Windows
To open the Phidget Control Panel on windows find the
icon In the taskbar. If it’s not there, open up the start menu and
search for Phidget Control Panel.

First Look
After plugging the1048 into your computer and opening
the phidget control panel, you will see something like
this.
  Serial number: Allows you to differentiate between similar
Phidgets.

 Channel: Allows you to differentiate between similar objects

on a Phidget.

 Version number: Corresponds to the firmware version your

Phidget is running. If your Phidget is listed in red, your
firmware is out of date. Update the firmware by double-
clicking the entry.

https://www.phidgets.com/docs/1048_User_Guide
 ROBOTGEEK
TEMPERATURE
SENSOR
THE ROBOTGEEK TEMPERATURE
SENSOR CAN FEEL ITS WAY THROUGH.
EACH SENSOR INCLUDES A MOUNTING
PLATE AND ALL HARDWARE NEEDED TO
MOUNT TO ANY WORKBENCH
OR ROBOTGEEK PRODUCT THAT HAS A
CENTIMETER GRID PATTERN. WITH THE 3-
PIN SENSOR CABLE STANDARD, YOU CAN
EASILY CONNECT THIS TO YOUR PROJECT
AND START READING THE TEMPERATURE
ROBOTGEEK LIGHT
SENSOR
THIS ROBOTGEEK LIGHT SENSOR IS AN
ANALOG SENSOR THAT WILL ALLOW YOU
TO MEASURE LIGHT FROM YOUR
ARDUINO OR OTHER
MICROCONTROLLER. THE MORE LIGHT
THE SENSOR DETECTS, THE HIGHER THE
YOUR ANALOG PORT WILL DETECT. EACH
ROBOTGEEK LIGHT SENSOR COMES WITH
A DUAL FEMALE-FEMALE JUMPER CABLE
SO THAT YOU CAN MOVE THE LIGHT
SENSOR OFF THE BOARD.
PHIDGETS MAGNETIC
SENSOR
LINEAR HALL EFFECT SENSOR. THIS
RATIOMETRIC HALL-EFFECT SENSOR
PROVIDES A VOLTAGE OUTPUT THAT IS
PROPORTIONAL TO THE APPLIED
MAGNETIC FIELD. INCLUDES 60CM SENSOR
CABLE. BOARD DIMENSIONS: 3.0 X 3.0 CM
MOUNTING HOLES: 2.3 X 2.3 CM“

THIS PHIDGET IS TO SET OF USB-BASED

BUILDING BLOCKS FOR LOW COST
SENSING AND CONTROL FROM YOUR PC. A
WIDE ARRAY OF SENSORS, I/O DEVICES
AND CONTROLLERS ARE AVAILABLE.
