Chapter 3
Chapter 3
Operations and
Supply Chain
Management
CHASE | SHANKAR | JACOBS
3–1
DESIGN OF
PRODUCTS AND
SERVICES
Chapter Three
McGraw-Hill/Irwin Copyright © 2014 by The McGraw-Hill Companies, Inc. All rights reserved.
3–2
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Learning Objectives
• LO3–1: Know the issues associated with product design and
the typical processes used by companies.
• LO3–2: Illustrate how different criteria can impact the design
of a product.
• LO3–3: Contrast how service products can have different
design criteria compared to manufactured products.
• LO3–4: Evaluate the economic impact of a new product on a
company.
• LO3–5: Illustrate how product development is measured in a
company.
3–3
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
The Product Design Process
• Companies continuously bring new products to
market
• Product design is integral to success
• Product design differs significantly depending on the
industry
• Companies often outsource major functions
– Contract manufacturer: an organization capable of
manufacturing and/or purchasing all the components
needed to produce a finished product
3–4
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Core Competency
• Core competency: the one thing a company
can do better than its competitors
• A core competency has three characteristics:
– It provides potential access to a wide variety of
markets
– It increases perceived customer benefits
– It is hard for competitors to imitate
3–5
Examples of Successes in
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Design
• Sun Microsystems designs the SPARC chips used in its high-
performance workstations but subcontracts the fabrication of those
chips to specialized chip makers (while maintaining ownership of
the intellectual property).
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Design
• Dell has developed a set of highly specialized systems that
support its make-to-order operating strategy. Dell has created a
set of proprietary logistical processes that range from the design
of its web page through its information systems infrastructure (a
process that has proved difficult for others to imitate).
• Dell owns the data about what people are buying and in which
combinations. It also has been vertically integrated into final
assembly facilities that are designed to efficiently produce in lot
sizes of one.
• Finally, while it outsources components, Dell uses longer-term
relationships with its suppliers and links them into its information
system to support quick response.
3–7
Brainstorming: A General
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Method for Problem Solving
• Defer judgment
• Build on the ideas of others
• Stay focused on the topic
• One person at a time
• Go for quantity
• Encourage wild ideas
• Be visual
3–8
Six Phases of the Generic
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Development Process (Formal
Process)
• Phase 0: Planning
• Phase 1: Concept development
• Phase 2: System-level design
• Phase 3: Design detail
• Phase 4: Testing and refinement
• Phase 5: Production ramp-up
3–9
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Phase 0: Planning
• Precedes project approval
• Begins with corporate strategy
• Includes assessment of technology
developments and market objectives
• Output is the project mission statement
3–10
Phase 1: Concept
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Development
• Needs of the target market are identified
• Alternative product concepts are generated and
evaluated
• One or more concepts are selected for further
development and testing
– Concept: a description of the form, function, and
features of a product
3–11
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Phase 2: System-Level Design
• Definition of the product architecture
• Decomposition of the product into subsystems and
components
• Final assembly scheme for the production system is
usually defined
• Output:
– Geometric layout of the product
– Functional specifications for each subsystem
– Preliminary process flow diagram
3–12
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Phase 3: Design Detail
• Complete specification of the geometry, materials, and
tolerances for all parts
• Identification of all the standard parts to be purchased from
suppliers
• Process plan is established
• Tooling is designed
• Output:
– Drawings describing the geometry of each part and its tooling
– Specifications of purchased parts
– Process plan
3–13
Phase 4: Testing and
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Refinement
• Construction and evaluation of multiple
preproduction versions of product
– Same geometry and material as production version
– Not necessarily fabricated with the actual
production processes
3–14
Phase 5: Production Ramp-
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Up
• Product is made using the intended production
system
• Need to train workers and resolve any
remaining problems
• Products may be supplied to preferred
customers for evaluation
• Transition to ongoing production is gradual
3–15
The Generic Product
Development Process
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
3–16
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Generic Product Development Process
3–17
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Generic Product Development Process
Continued
3–18
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Generic Product Development Process
Continued
3–19
Product Development Process
Summary of Variants of Generic
3-20
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
3–20
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Designing for the Customer
House of Quality
Ideal
Quality Function Value Analysis/
Deployment
Customer Value Engineering
Product
3–21
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Quality Function Deployment
• Interfunctional teams from marketing, design
engineering, and manufacturing
• House of quality
3–22
QFD: An Example from the
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Auto Industry
QFD involves converting the expectations and
demands of the customers into clear objectives,
which are then translated into the vehicle
specification. For example, Topspeed found that
passengers became uncomfortable if the car rolled
more than two degrees and side acceleration
exceeded 13.2 feet per second squared. These data
were used to help define design criteria for the
chassis engineers. 3–23
Completed House of Quality Matrix for
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
a Car Door
Customer requirements
information forms the
basis for this matrix,
used to translate them
into operating or
engineering goals
https://hbr.org/1988/05/the-house-of-quality
3–24
Value Analysis/Value Engineering
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
(VA/VE)
• Purpose is to simplify products and processes
3–25
Designing Products for
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Manufacture and Assembly
• Traditional approach
– “We design it, you build it” or “over the
wall”
• Concurrent engineering
– “Let’s work together simultaneously”
3–26
Design for Manufacturing and
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Assembly
• Greatest improvements related to DFMA arise from
simplification of the product by reducing the number
of separate parts:
– During the operation of the product, does the part move
relative to all other parts already assembled?
– Must the part be of a different material or be isolated from
other parts already assembled?
– Must the part be separate from all other parts to allow the
disassembly of the product for adjustment or maintenance?
3–27
Proposed Motor Drive Design
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
3–28
Analysis
Following Design for Assembly
Redesign of Motor Drive Assembly
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
3–29
Copyright © 2014 by McGraw Hill Education (India) Private Limited. All rights reserved.
Ecodesign
• Ecodesign: the incorporation of environmental
considerations in the design and development
of products or services
– The whole life cycle is considered
– The product is considered as a system
– A multi-criteria approach is used
• Application of ecodesign can benefit business
3–30
